Electrolux 726494 (RH06FE1FS) Datasheet

Electrolux 726494 (RH06FE1FS) Datasheet
Digital Cabinets
Heavy Duty Smart Freezer-650
lt 1 Door
Main Features
Digital Cabinets
Heavy Duty Smart Freezer-650 lt 1 Door
726494 (RH06FE1FS)
Heavy Duty Smart
Freezer-650 lt 1 Door- 230
• Choice of doors to suit various kitchen requirements.
• Freezer models have operating temperatures that can be
adjusted from -24 to -15 °C to suit both meat and dairy
storage requirements.
• Performance guaranteed at ambient temperatures of 43 °C.
• Forced air circulation for rapid cooling and an even
temperature distribution.
• Accommodates GN 2/1 containers or shelves on anti-tilt
• External digital temperature display.
• Interior light and lockable door.
• Smart electronic control gives the following benefits:
- HACCP: when temperature exceeds critical limits, an
acoustic and visual alarm are activated. All events are
recorded displaying date time of all events.
- Smart defrost: the defrost cycle is activated only when ice
in the evaporator is detected by a dedicated probe.
- Intelligence when failure: when a probe breaks it
remembers the performances of the last 24h of operation
and continues to work.
- Diagnostic: four probes constantly control the working
conditions of appliances.
- Food categories: depending on the type of food stored the
appropriate temperature and humidity level can be set just
pushing a button.
• Fault indication from the smart control.
• Smart electronics defrost only when required to save energy.
• IPX5 certified control panel (appliance is IP21 protected).
Short Form Specification
The Electrolux range of refrigerated cabinets are built externally and
internally with AISI 304 Stainless steel. High-density expanded polyurethane
insulating foam, 75 mm in thickness. Full door with lock and microswitch
to switch off the fan when the door is opened. Built-in refrigeration unit;
ventilated operating mode; SMART ELECTRONIC control equipped with:
history (HACCP) for critical high temperature, alarm service, full diagnostic,
remote control via modem; electronic defrost only when required; defrost
outlet pipe; external digital temperature display. Humidity level adjustment.
Internal lighting. Cavity drain. For ambient temperatures up to 43 °C. CFC
and HCFC free. R134a gas in refrigeration circuit. Gas in foam: Cyclopentane.
Supplied with n. 4x2/1GN Rilsan coated grids and n. 4 sets of 2 Stainless
steel grid runners.
The model detailed in this sheet is a 650 liter, 1 door freezer with Smart
Included Accessories
Optional Accessories
Electrolux Professional
[email protected]
PNC 922166 ❑
Digital Cabinets
Heavy Duty Smart Freezer-650 lt 1 Door
Item No.
• Mounted on adjustable Stainless steel feet, with castors as
an option.
• Constructed from the highest quality AISI 304 Stainless
• Interior base with corners, pressed from a single sheet.
• Sides and back of the 1-door models are formed from a
single sheet of Stainless steel to avoid dirt traps.
• Evaporator unit is placed outside the cell to provide the
maximum storage capacity.
• Refrigerators are fitted with outlet pipe.
• Heavy-duty construction that avoids use of any plastic parts.
• The cooling unit (compressor, condenser and evaporator)
can be removed with a single operation from either the top
or back.
• Evaporator cover is easily removable for service.
• Cabinet fitted with up to 75 mm thickness of Cyclopentane
insulation for best insulating performance. CFC and HCFCfree insulation.
• Refrigerant type: R134a or R404a.
Digital Cabinets
Heavy Duty Smart Freezer-650
lt 1 Door
Supply voltage:
230 V/1N ph/50 Hz
Key Information
Door hinges:
Right Side
Built-in Compressor and Refrigeration Unit
External dimensions, Height
2050 mm
External dimensions, Width
750 mm
External dimensions, Weight
138 kg
Number and type of doors:
Net weight:
138 kg
Number and type of grids
4 GN 2/1
Refrigeration Data
Compressor power:
Refrigerant type:
Refrigeration power:
Refrigerant weight:
Operating temperature min.:
Operating temperature max.:
Type of external material:
Type of internal material:
ED =
EI =
1/2 hp
802 W
230 kg
-22 °C
-15 °C
Stainless Steel AISI 304 - Din
Stainless Steel AISI 304 - Din
Remote electrical connection
Electrical connection
Digital Cabinets
Heavy Duty Smart Freezer-650 lt 1 Door
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
