WORKGROUP SYSTEMS
1. Product Positioning
The LASER CLASS® 510, LASER CLASS 310, and
LASER CLASS 2050P multifunction devices provide
low- to mid-volume solutions for a wide variety of
customers.
Canon has been an industry leader for over a decade, and one reason is the LASER CLASS 510/310/2050P low- to mid-volume series of
laser multifunction devices. These LASER CLASS machines answer
the needs of a wide range of audiences, including enterprises, workgroups, small companies, and individuals.
The popularity and desirability of the LASER CLASS 510/310/2050P
begin with the powerful and flexible capabilities built into these
multifunction devices. The small footprint, the range of high-speed,
high-quality features, and the ease-of-use that’s designed to make
operation simple complement these capabilities.
The LASER CLASS 510 is built to provide unsurpassed quality for volumes of up to 8,000 pages per month, and can fax or copy from its
unique standard platen glass. With its 8MB memory that can store
up to 500 pages,** the LASER CLASS 510 offers a standard Windows®
print driver for Windows 98/Me/2000/XP via the USB port, and
network printing (when configured with the optional AXIS 1650 Print
Server) up to 15 pages per minute (letter). The LASER CLASS 510 can
improve workflow, increase office productivity, and become an integral
part of a company’s communication solution.
For workgroups or small companies, the LASER CLASS 310 is an
ideal productivity partner. This desktop multifunction device comes
with a built-in Windows print driver. It provides 19-page-per-minute
(letter) laser printing and offers unsurpassed facsimile transmission
speed via Super G3 Technology. With 8MB of memory, you can store
up to 510 pages,** and the LASER CLASS 310 is designed to produce
volumes of up to 8,000 pages per month. The LASER CLASS 310
has an easy-to-use control panel that makes for simple operation as
a fax machine, printer, or convenience copier.
* Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart (MMR, Standard Mode) at 33.6 Kbps modem
speed when transmitting to another V.34 machine. The Public Switched Telephone Network (PSTN) currently supports 28.8 Kbps
modem speeds or lower, depending on telephone line conditions.
** Based on ITU-T No. 1 Chart (Standard Mode).
*** 20 lb., less than 120µm, 15-27° C, 20-80% RH
† Alternative 10-Sheet Manual Feeder supports the same paper size, weight, and type as cassette.
The LASER CLASS 2050P is a compact, stand-alone desktop unit
with a variety of productivity features that can be initiated at the
touch of a button. With the ability to handle volumes of up to 6,000
pages per month, it also has a range of handy features, including
Print-in-Order and face-down collated output. Additionally,
the LASER CLASS 2050P has 4MB of memory that can store up
to 256 pages,** and a standard, 350-sheet front-loading, adjustable paper supply that’s ready for any job. What’s more, the
LASER CLASS 2050P offers the convenience of providing multiple
office uses with a single source of service and support from the
Canon nationwide network of approved technicians.
Key Selling Points
• 3-Second-Per-Page* Transmission Speed via the Super G3
Fax Modem
• Large-Capacity Automatic Document Feeder
— LASER CLASS 510/310: 50 Sheets
— LASER CLASS 2050P: 40 Sheets***
• Print Speed
— LASER CLASS 510: 15 ppm (Letter) (Direct/Optional Network)
— LASER CLASS 310: 19 ppm (Letter) (Direct/Optional Network)
— LASER CLASS 2050P: 6 ppm (Letter) (Direct)
• Print Resolution
— LASER CLASS 510/310: 1200 x 600 dpi Enhanced
— LASER CLASS 2050P: 600 x 600 dpi Enhanced
• Large Standard Memory
— LASER CLASS 510: 8MB/500 Pages**
— LASER CLASS 310: 8MB/510 Pages**
— LASER CLASS 2050P: 4MB/256 Pages**
• Standard Paper Capacity
— LASER CLASS 510: 250/10 Sheets† (Total 250/10 Sheets)
— LASER CLASS 310: 500/1 Sheets (Total 501 Sheets)
— LASER CLASS 2050P: 250/100 Sheets (Total 350 Sheets)
• UHQ (Ultra High Quality) Image Processing
• Speed-Dials
— LASER CLASS 510/310: 200 Locations
— LASER CLASS 2050P: 124 Locations
• Single Full-Yield Cartridge Included
— LASER CLASS 510/310: FX8
— LASER CLASS 2050P: FX3
• One-Hour Battery Backup
• 90-Day Limited Warranty
2. Potential Market
3. Selling Strategy
For virtually any low- to mid-volume business—from
a small home office or executive suite to workgroups
or large enterprises with remote locations—the
LASER CLASS 510/310/2050P devices can provide
solutions that increase productivity and a significant
return on investment (ROI).
With the size of the multifunction marketplace increasing annually, the LASER CLASS 510, LASER CLASS 310,
and LASER CLASS 2050P devices provide customers
with a range of excellent low- to mid-volume multifunction device solutions ideal for a variety of
businesses.
With facsimile, laser printing, and copying capabilities, these
LASER CLASS multifunction devices are easy to use, easy to maintain, and dependable—and ensure both unsurpassed quality and
unmatched capabilities. They can give you selling solutions that
address:
•Companies with branch offices in remote locations
With a solid foundation built on Canon’s leading-edge technologies,
these LASER CLASS models meet the needs of companies requiring
high-performance, high-speed, high-quality capabilities—at an affordable price point. With desktop convenience that’s just right for a wide
range of customers, the LASER CLASS 510/310/2050P line-up can
increase productivity while providing unsurpassed convenience. For
companies needing to upgrade outdated technology, or for those
organizations wanting to add new capabilities and ensure top-of-theline quality, these Canon LASER CLASS multifunction devices are a
perfect fit. With state-of-the-industry facsimile capabilities, crisp laser
print resolution via a standard Windows print driver, and maximum
monthly duty cycles of up to 8,000 pages on the LASER CLASS 510/310
and up to 6,000 pages per month on the LASER CLASS 2050P, these
multifunction devices are ready to do business right out-of-the-box.
•Businesses that depend on telecommuting workforces or field staff
Productivity
•Home office businesses that want quality communications capabilities at an affordable cost
Canon LASER CLASS multifunction devices give your customers
powerful productivity features to handle their most important tasks.
With high-speed faxing and desktop printing using a Windows print
driver, the Canon LASER CLASS 510/310/2050P devices are built to
address any low- to mid-volume need your customer may have. The
LASER CLASS 510/310 models also support network printing.
•Businesses ready to upgrade from single-function plain paper laser
facsimile machines to a laser multifunction device that addresses a
variety of office needs, including full copying capabilities
•Workgroups within large enterprises that need low- to mid-volume
faxing, printing, or copying capabilities
•Multiple users in small offices as shared network printers
(LASER CLASS 510/310)
•Executive offices that require a dedicated facsimile machine and
printer to handle confidential material, or for personal use
•Low- to mid-volume businesses needing clear print resolution at
speeds of up to 19 pages per minute
Speed
Canon Super G3 Technology ensures the fastest transmission speeds
available to streamline workflow and save on phone line costs.
Unsurpassed Canon Quality
Each LASER CLASS 510/310/2050P device offers clear, crisp print
resolution and powerful memory functions that enable users to store
multiple documents. The face-down, collated output features mean
customers can work more efficiently, and in less time.
Compact Size
Each LASER CLASS 510/310/2050P model has a small footprint, so the
devices fit comfortably on a desktop.
Reliability
The Canon LASER CLASS 510/310/2050P devices come with a Canon
standard 90-day limited warranty and are backed by one of the world’s
largest service and support networks to keep your customers up and
running.
Affordability
The LASER CLASS 510/310/2050P devices have a range of advanced
features to meet your customers’ most demanding requirements,
while keeping the bottom line in focus.
4. The features…and how they benefit users.
Crisp Laser Output
Added Features
For faxing, printing, or copying, these Canon LASER CLASS devices provide crisp, clear output at speeds of up to 15 pages per minute (letter)
on the LASER CLASS 510, up to 19 pages per minute (letter) on the
LASER CLASS 310, and up to 6 pages per minute (letter) on the
LASER CLASS 2050P.
Easily employ One-Touch Speed-Dialing, Coded Dialing, and
Group Dialing to sequentially broadcast to up to 200 locations
(LASER CLASS 510/310) or 124 locations (LASER CLASS 2050P)
to save time and take advantage of sending documents when
telephone charges are the most economical.
Fast Transmission Times
Convenience Features
These LASER CLASS multifunction devices offer Canon’s Super G3
Technology to transmit data at 33.6 Kbps speed (approximately 3
seconds per page*)—twice as fast as ordinary G3 facsimile machines—
to speed workflow and reduce phone line charges. They also employ
state-of-the-art compression protocols to compress image data,
especially effective when transmitting halftones.
Enjoy Print-in-Order output that prints incoming documents face-down,
in the correct order, at speeds of up to 15 pages per minute on the
LASER CLASS 510, up to 19 pages per minute on the LASER CLASS 310,
and up to 6 pages per minute on the LASER CLASS 2050P.
Powerful Memory Capabilities
For incoming or outgoing faxes, the LASER CLASS 510 offers a powerful
8MB of memory (up t0 500 pages**), while the LASER CLASS 310 has
8MB (up to 510 pages**), and the LASER CLASS 2050P offers 4MB (up
to 256 pages**).
Automatic Document Feeder Capacity
The LASER CLASS 510/310 have a 50-sheet Automatic Document
Feeder, while the LASER CLASS 2050P has a 40-sheet*** Automatic
Document Feeder, for convenient, multipage document-feeding for
either transmission or copying. Or take advantage of the standard,
built-in platen glass in the LASER CLASS 510 to use Book Mode to
capture three-dimensional images for either faxing or copying.
Efficiency By Design
The LASER CLASS 510/310/2050P devices use a single cartridge system
to simplify user-maintenance and provide consistent, high-quality output. With the standard one-hour battery backup in all these multifunction
devices, you can safely store incoming documents during a power outage. In addition, these ENERGY STAR® qualified LASER CLASS multifunction devices reduce energy consumption, have quick warm-up
time, and require little power.
Fax and Copy from the LASER CLASS 510
Platen Glass or the 50-Sheet ADF
Handy Dual Paper Supply
The LASER CLASS 510 comes with one 250-sheet front-loading letter/
legal-sized adjustable cassette and a 10-sheet letter-/A4-/legal-sized
Alternative Manual Feeder.† The LASER CLASS 310 model comes with
one 500-sheet front-loading letter-/legal-sized adjustable cassette
and a one-sheet letter-/A4-/legal-sized MultiPurpose Tray. The
LASER CLASS 2050P comes with one 250-sheet front-loading letter-/
A4-sized adjustable cassette and one 100-sheet letter-/legal-/A4-sized
MultiPurpose Tray.
LASER CLASS 310 500-Sheet Cassette
Enhanced Image Quality
By using Canon UHQ (Ultra High Quality) image processing system,
you’ll be able to transmit superior images that distinguish between
text and images on outgoing faxes.
* Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart (MMR, Standard Mode) at 33.6 Kbps modem
speed when transmitting to another V.34 machine. The Public Switched Telephone Network (PSTN) currently supports 28.8 Kbps
modem speeds or lower, depending on telephone line conditions.
** Based on ITU-T No. 1 Chart (Standard Mode).
*** 20 lb., less than 120µm, 15-27° C, 20-80% RH
† Alternative 10-Sheet Manual Feeder supports the same paper size, weight,
and type as cassette.
LASER CLASS 510 User-Friendly Operation Panel
Product Positioning Guide
1. Product Positioning
2. Potential Market
3. Selling Strategy
4. The Features
The LASER CLASS 510, LASER CLASS 310, and LASER CLASS 2050P devices offer integrated faxing, printing,
and copying solutions—plus advanced technology features. They are ideal for any size business or workgroup
needing low- to mid-volume laser multifunction device capabilities that increase productivity and help
keep an eye on your bottom line.
LOW- TO MID-VOLUME LINE-UP COMPARISON CHART
MODEL
LASER CLASS ®
510
LASER CLASS ®
310
LASER CLASS ®
2050P
3,500■
3,500■
2,700■
Laser
Laser
Laser
Yes
Yes
Yes
One Hour
One Hour
One Hour
33.6 Kbps/3 spp*
33.6 Kbps/3 spp*
33.6 Kbps/3 spp*
BASICS
Toner Yield
Print Technology
®
ENERGY STAR Qualified
Battery Backup
LASER CLASS 510
FAXING
Transmission Speed
JBIG Compression
Standard/Maximum Memory
Print-in-Order Output
Yes
No
Up to 510 Pages**
Up to 256 Pages**
Yes, Face-Down
Yes, Face-Down
Yes, Face-Down
Maximum TX Resolution
406 x 391 lpi
406 x 391 lpi
406 x 391 lpi
One-Touch Speed Dials
30
32
24
Coded Speed-Dials
LASER CLASS 310
Yes
Up to 500 Pages**
Network Fax
170
168
100
Optional
No
No
Standard USB
Standard USB
Standard USB
Optional
Optional
No
Windows Printing
Windows Printing
Windows Printing
PRINTING
Direct Printing
Network Printing
PDL/PCL
Print Speed (Letter)
Enhanced Print Resolution
Maximum Paper Supply
15 ppm
19 ppm
6 ppm
1200 x 600 dpi
†
250/10 Sheets
1200 x 600 dpi
600 x 600 dpi
501 Sheets
350 Sheets
50 Pages
50 Pages
40 Pages***
8.4"
8.34"
8.4"
SCANNING
ADF Capacity (Letter)
LASER CLASS 2050P
Effective Scanning Width
* Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart (MMR,
Standard Mode) at 33.6 Kbps modem speed when transmitting to another V.34 machine. The
Public Switched Telephone Network (PSTN) currently supports 28.8 Kbps modem speeds or
lower, depending on telephone line conditions.
** Based on ITU-T No. 1 Chart (Standard Mode).
*** 20 lb., less than 120µm, 15-27° C, 20-80% RH
■
Based on 4% original, 5% coverage.
† Alternative 10-Sheet Manual Feeder supports the same paper size, weight, and type as cassette.
LASER CLASS 510/310/2050P Specifications
Type:
Applicable Line:
Compatibility:
Automatic Document Feeder
LASER CLASS 510:
LASER CLASS 310:
LASER CLASS 2050P:
Scanning Method:
Document Sizes
LASER CLASS 510:
LASER CLASS 310:
LASER CLASS 2050P:
Effective Scanning Width
LASER CLASS 510/2050P:
LASER CLASS 310:
Scanning Resolution:
LASER CLASS 510:
LASER CLASS 310:
LASER CLASS 2050P:
Data Compression System:
LASER CLASS 510/310:
LASER CLASS 2050P:
Modem Speed:
Transmission Speed:
Printing Method:
Printing Speed
LASER CLASS 510:
LASER CLASS 310:
LASER CLASS 2050P:
Halftone
LASER CLASS 510/310:
LASER CLASS 2050P:
Tx/Rx Resolution:
Ultra Fine Mode:
(LASER CLASS 510/310 Only)
Super Fine Mode:
Fine Mode:
Standard Mode:
Effective Printing Width
LASER CLASS 510/310:
LASER CLASS 2050P:
Paper Supply
LASER CLASS 510:
LASER CLASS 310:
LASER CLASS 2050P:
Desktop Transceiver
Public Switched Telephone Network
G3
Up to 50 Sheets (Letter)
Up to 30 Sheets (Legal)
Up to 50 Sheets (Letter)
Up to 20 Sheets (Legal)
Up to 40 Sheets (Letter)***
Up to 20 Sheets (Legal)
Contact Image Sensor
Maximum (Platen): 8.5" x 11.6"
(216mm x 297mm)
Maximum (ADF): 8.5" x 39-3/8"††
(216mm x 1m)
Minimum (ADF): 5.8" x 4.1"
(148mm x 105mm)
Maximum (ADF): 8.5" x 39-3/8"††
(216mm x 1m)
Minimum (ADF): 5.8" x 4.1"
(148mm x 105mm)
Maximum (Manual): 8.5" x 39"
(216mm x 1m)
Minimum (ADF): 5.8" x 4.1"
(148mm x 105mm)
Minimum (Manual): 3.5" x 1.75"
(88.9mm x 44.5mm)
8.4" (214mm)
8.34" (212mm)
LASER CLASS 310:
LASER CLASS 2050P:
Weight
LASER CLASS 510:
LASER CLASS 310:
600 x 600 dpi
300 x 300 dpi
400 x 300 dpi
MH, MR, MMR, JBIG
MH, MR, MMR
33.6/31.2/28.8/26.4/24.0/21.6/
19.2/16.8/14.4/12.0/9.6/7.2/4.8/
2.4 Kbps Automatic Fallback
Approx. 3 Sec./Page*
Laser Dry Electrostatic Transfer
Approx. 15 Pages/Min. (Letter)
Approx. 19 Pages/Min. (Letter)
Approx. 6 Pages/Min. (Letter)
256 Shades of Gray
64 Shades of Gray
Horizontal
406 pels/in.
x
(16 pels/mm x
203 pels/in.
x
(8 pels/mm
x
x
203 pels/in.
x
(8 pels/mm
203 pels/in.
x
x
(8 pels/mm
Receiving Paper Tray:
Recording Paper Size:
Enhanced Imaging Quality:
Enhanced Printing Resolution
LASER CLASS 510/310:
LASER CLASS 2050P:
Toner Cartridge
LASER CLASS 510/310:
LASER CLASS 2050P:
Cartridge Yield
LASER CLASS 510/310:
LASER CLASS 2050P:
Power Consumption
LASER CLASS 510:
LASER CLASS 310:
LASER CLASS 2050P:
ENERGY STAR® Qualified:
Handset Kit:
Dimensions (H x W x D)
(Excluding Tray)
LASER CLASS 510:
Vertical
391 lines/in.
15.4 lines/mm)
391 lines/in.
15.4 lines/mm)
196 lines/in.
7.7 lines/mm)
98 lines/in.
3.85 lines/mm)
8.34" (212mm)
8.19" (208mm)
250-Sheet Cassette (Letter/Legal)
10-Sheet Alternative Manual Feeder†
500-Sheet Cassette (Letter/Legal)
1-Sheet MultiPurpose Tray
250-Sheet Cassette (Letter)
100-Sheet MultiPurpose Tray (Letter/Legal)
LASER CLASS 2050P:
Environmental Conditions
Temperature:
Humidity:
Maximum Monthly Print Volume
LASER CLASS 510/310:
LASER CLASS 2050P:
Support OS:
Dialing:
One-Touch Speed-Dialing
LASER CLASS 510:
LASER CLASS 310:
LASER CLASS 2050P:
Coded Speed-Dialing
LASER CLASS 510:
LASER CLASS 310:
LASER CLASS 2050P:
Group Dialing:
LASER CLASS 510/310:
LASER CLASS 2050P:
Sequential Broadcast
LASER CLASS 510/310:
LASER CLASS 2050P:
1200 x 600 dpi
600 x 600 dpi
Memory Transmission/Reception
LASER CLASS 510:
8MB (500 Pages**)
LASER CLASS 310:
8MB (510 Pages**)
LASER CLASS 2050P:
4MB (256 Pages**)
Receiving Restriction
Convenience:
Auto Receive Reduction (70% - 100%)
Remote Reception by Extension Phone
Transmission Reservation:
Up to 20 Reservations
Copy Zoom: (50% - 200%)
LASER CLASS 510/310
Book Sending:
LASER CLASS 510
PC Faxing:
LASER CLASS 510
Windows Fax Driver Included
Quick On-Line Tx:
LASER CLASS 2050P
LCD (Liquid Crystal Display):
20-Digit x 2-Line
Local Copy Function:
Multiple Copies Up to 99 Pages
Memory Backup:
One Hour
Report/Reference:
Activity Report (Up to 20 Transactions)
Non-Delivery Report
Yes
ECM (Error Correction Mode):
Warranty:
90 Days
Options:
Braille Kit-A1 (510/310)
Braille Kit-C1 (2050P)
AXIS 1650 Print Server (510/310)
FX8 Cartridge
FX3 Cartridge
Approx. 3,500 Pages ■
Approx. 2,700 Pages ■
Max: 650W/Standby, 11W
Max: 600W/Standby, 9W
Max: 660W/Standby, 5W
Yes
Standard
17-7/8" x 24" x 18"
(453mm x 626mm x 457mm)
15-1/2" x 17-3/8" x 18-3/8"
(392mm x 441mm x 466mm)
12" x 18-1/8" x 19"
(303.5mm x 460mm x 483mm)
35.9 lb. (16.3kg)
(Including Handset and Cartridge)
26.7 lb. (12.1kg)
(Including Handset and Cartridge)
28.7 lb. (13kg) (Excluding Handset)
50°F - 90.5°F (10°C - 32.5°C)
20% - 80% RH
8,000 Prints
6,000 Prints
Windows 98/Me/2000/XP
Automatic Dialing
30 Locations
32 Locations
24 Locations
170 Locations
168 Locations
100 Locations
199 Groups; Each Group Can Accommodate up to 199 Locations
123 Groups; Each Group can Accommodate up to 123 Locations
120
Maximum Dial Digits:
On-Hook Dialing
Manual Dialing with 10-Button Keypad
Automatic Redialing:
Redial Times: 1 to 10 Times
Redial Interval: 2 to 99 Min.
Networking
Delayed Transmission
Up to 210 destinations and up to 20
LASER CLASS 510/310:
reservations
LASER CLASS 2050P:
Up to 125 destinations and up to 20
reservations
Memory/Polling Transmission
Polling Reception
Up to 210 Locations
LASER CLASS 510/310:
LASER CLASS 2050P:
Up to 125 Locations
As an ENERGY STAR® Partner, Canon U.S.A., Inc. has determined that these products meet the ENERGY STAR® guidelines for energy efficiency. ENERGY STAR and the
ENERGY STAR mark are registered U.S. marks. Windows and Windows NT are registered trademarks of Microsoft Corporation in the United States and/or other countries. Canon and LASER CLASS are registered trademarks, and the SUPER G3 logo
and the GENUINE logo are trademarks of Canon Inc. and may also be registered
trademarks or trademarks in other countries. IMAGEANYWARE is a trademark of
Canon U.S.A., Inc. All referenced product names and other marks are trademarks of
their respective owners.
Specifications subject to change without notice.
©2005 Canon U.S.A., Inc. All rights reserved.
1005-LCPPG-PDF-NW
50 Sheets, Face-Down
Letter/Legal/A4
UHQ (Ultra High Quality)
Up to 210 Locations
Up to 125 Locations
Delay Broadcast Command/Delayed
Relay Broadcast Command
AXIS 1650 Print Server (Optional for LASER CLASS 510/310)
CPU:
AXIS ETRAX 100LX 32-Bit 100MHz RISC
8MB
Memory (RAM):
Memory (ROM):
2MB (Flash™)
Supported Systems:
Windows 98/Me/2000/XP/Server 2003■■
Printing Protocol:
Windows: TCP/IP
Supported Protocols
LDP, FTP, BOOTP, ARP, RARP, DHCP, ICMP,
TCP/IP:
IGMP, IP, TCP, UDP, HTTP, SLP v1/v2, SNMP v1,
RawTCP, DNS, DDNS, WINS, SNTP
Network Management:
NetSpot Device Installer, AXIS CAPT Print
Monitor (for printer installation, can be used
regardless of the printer type), DSNMP-MIB II
compliant (RFC1213), Canon MIB, Printer MIB
(RFC1759), HOST MIB (RFC1514)
Printer Connection:
Parallel, USB (Including USB Cable)
Power Consumption:
Max. 5.6W (From External Power Supply)
0.18 lb. (.08kg)
Weight:
Dimensions (H x W x D):
1-1/8” x 2-1/2” x 4-5/8”
(29mm x 62mm x 117mm)
* Approximate 3-second-per-page fax transmission time based on ITU-T No. 1 Chart (MMR,
Standard Mode) at 33.6 Kbps modem speed when transmitting to another V.34 machine.
The Public Switched Telephone Network (PSTN) currently supports 28.8 Kbps
modem speeds or lower, depending on telephone line conditions.
** Based on ITU-T No. 1 Chart (Standard Mode).
*** 20 lb., less than 120µm, 15-27° C, 20-80% RH
† Alternative 10-Sheet Manual Feeder supports the same paper size, weight, and type as
cassette.
†† One page document for fax sending only.
■
■■
Based on 4% original, 5% coverage.
LASER CLASS 510/310 do not support Windows 2003.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
