Canon IXUS 900 TI Digital Camera User Manual

ENGLISH

CDI-E293-010 XX06XXX © 2006 CANON INC.

PRINTED IN JAPAN

The Components Guide

Preparations

Shooting

Playback/Erasing

Menus and Settings

Printing

Basic

Downloading Images to a Computer

Camera User Guide

Please Read This First

This guide explains how to prepare the camera and use its basic features.

Flowchart and Reference Guides

The following guides are available. Refer to them as necessary according to the flowchart below.

For information on included items and items sold separately

System Map

The Components Guide

Preparations

• Charging the battery

• Installing the battery and memory card

• Setting the date, time and language

Shooting

Playback/Erasing

Menus and Settings

Basic Camera User

Guide (This Guide)

• Read this first.

Handling precautions, references to the various shooting and playback functions

Advanced Camera

User Guide

Printing

Direct Print User

Guide

• Installing the software

• Downloading images to a computer

• Using the software

Basic Camera User

Guide (This Guide)

Software Starter

Guide

ZoomBrowser EX/

ImageBrowser Software

User Guide

• PDF manuals available on the Canon website.

http://web.canon.jp/

Imaging/information-e.html

In this guide, the Basic Camera User Guide is called the Basic Guide, and the Advanced Camera User Guide is called the Advanced Guide. Also,

"battery" refers to the battery pack.

The Components Guide

„ Front View

Attaching the Wrist Strap*

Wrist Strap Mount

Microphone (Advanced Guide pp. 42, 86)

AF-assist Beam (Advanced Guide p. 24)

Red-Eye Reduction Lamp (Advanced Guide p. 33)

Self-Timer Lamp (p. 16)

Viewfinder Window (Advanced Guide p. 18)

Flash (p. 14)

Lens

* When carrying the camera by the strap, be careful not to swing the camera or catch it on other items.

1

„ Back View

2

LCD Monitor (Advanced Guide pp. 12, 15)

Viewfinder (Advanced Guide p. 18)

DIGITAL Terminal (p. 27)

A/V OUT (Audio/Video output) Terminal (Advanced Guide p. 103)

Terminal Cover

Tripod Socket

Memory Card Slot/Battery Cover Lock Release Switch (p. 7)

DC Coupler Terminal Cover (Advanced Guide p. 125)

Memory Card Slot/Battery Cover (p. 7)

The interface cable and AV cable cannot be connected simultaneously.

„ Controls

Speaker

Indicators (p. 5)

Power Lamp

Power Button (p. 10)

Zoom Lever (p. 14, Advanced Guide p. 73)

Shooting: (Wide Angle)/ (Telephoto)

Shutter Button (p. 10)

Mode Dial (pp. 10, 11)

(Print/Share) Button (pp. 22, 30)

DISP. (Display) Button (Advanced Guide p. 12)

FUNC./SET (Function/Set) Button (p. 20, Advanced Guide p. 22)

Touch Control Dial (pp. 4, 18)

MENU Button (p. 21, Advanced Guide p. 23)

(Macro)/ (Infinity)/ Button (p. 15)

(ISO Speed)/ (Jump)/ Button (Advanced Guide pp. 65, 76)

(Flash)/ Button (p. 14)

(Single Image Erase)/ (Continuous)/ (Self-timer)

/ Button (pp. 16, 19, Advanced Guide p. 37)

3

4

„Touch Control Dial

Placing a finger on the touch control dial displays the playback mode and shooting mode touch icons on the LCD monitor. You can confirm the functions assigned to each button.

Touch Icons

Sample of shooting mode

• Unavailable buttons are grayed out.

• Place a finger on the touch control dial over a function you want to set, and the icon will enlarge on the LCD monitor.

• You can easily select images using the touch control dial during playback (p. 18).

• You can easily select time zones for the world clock using the touch control dial (Advanced Guide p. 20).

• You can set the touch icons to On/Off in the (Set up) menu

(Advanced Guide p. 26).

Indicators

The camera indicators light or flash under the following circumstances.

Never do the following while an indicator is flashing green.

These actions may corrupt image data.

• Shake or jolt the camera

• Shut off the power, or open the memory card slot/battery cover

„ Right Indicator

Green:

Ready to shoot

Blinking Green:

Image recording/reading/erasing/transferring

(when connected to a computer)

Orange:

Ready to shoot (flash on)

Blinking Orange: Ready to shoot (camera shake warning)

„ Left Indicator

Yellow:

Macro mode/infinity mode/AF lock mode

Blinking Yellow: Focusing difficulty (camera beeps once)

5

Preparations

1.

Charging the Battery.

Charge the battery before use under the following circumstances.

• When using the battery for the first time.

• When the "Change the battery pack" message displays.

1. Insert the battery into the battery charger.

2. Plug the battery charger (CB-2LX) into a power outlet, or attach the power cord to the battery charger (CB-2LXE) and plug it into a power outlet.

• Battery charger model names and types vary by region.

The charge indicator will light orange while the battery is charging. It will change to green when the charge is complete.

Charging takes approximately 2 hours 5 minutes.

Align these symbols

6

Charge Indicator

For CB-2LX For CB-2LXE

To protect the battery and prolong its life, do not charge it for longer than 24 hours continuously.

Î See the Advanced Guide: Battery Handling (p. 121).

2.

Installing the Battery.

1. Slide the lock release switch in the direction of the arrow

( ), and open the memory card slot/battery cover ( ).

2. Push the battery lock in the direction of the arrow ( ) and insert the battery until it locks.

To remove the battery, push the battery lock in the direction of the arrow ( ) and hold it while pulling the battery out.

Battery Lock

Back

3.

Inserting the Memory Card.

1. Insert the memory card until it clicks into place.

2. Close the memory card slot/battery cover.

Back

Ensure that the memory card is correctly oriented before inserting it in the camera. Inserting it backward may cause the camera to fail to recognize the memory card or to malfunction.

Î

See the Advanced Guide: Handling the Memory Card (p. 123).

Î See the Advanced Guide: Formatting Memory Cards (p. 29).

7

8

„ To Remove the Memory Card

Use a finger to push the memory card in until you hear a click, then release it.

You can use SD memory cards, SDHC memory cards and MultiMediaCards with this camera.

These cards are collectively called memory cards in this guide.

First Time Settings

„ Setting the Date/Time

1. Press the power button ( ).

2. Use the or button to select an item and the or button to change its value ( ).

To set the daylight saving option, select the icon and use the

or button to configure the setting.

3. Confirm that the correct time is displayed and press the

FUNC./SET button ( ).

The date and time can also be set in the Set up menu (p. 21).

• A rechargeable lithium battery is built into the camera to save such settings as the date/time. This battery charges when the main battery is in the camera. When you purchase the camera, place the main battery in it for approximately four hours or use AC Adapter Kit ACK-DC30

(sold separately) to charge the lithium battery. It will charge even if the camera is turned off.

• The date/time settings may be lost after approximately three weeks if you remove the main battery. Reset the date/time settings if this occurs.

Î See the Advanced Guide: Setting the World Clock (p. 20).

„ Setting the Display Language

1. Turn the mode dial to (playback).

2. Hold down the FUNC./SET button and press the MENU button.

3. Use the , , or button to select a language and press the FUNC./SET button.

The display language can also be set in the Set up menu (p. 21).

9

Shooting

1.

Press the power button.

Power button

The start-up sound will play and the start-up image will display in the LCD monitor.

• Pressing the power button again turns the power off.

• To switch to the setting that mutes all sounds (except for the warning sound), press and hold the DISP. button while pressing the power button.

Î See the Advanced Guide: Using the LCD Monitor (p. 12).

Î See the Advanced Guide: Power Saving Function (p. 19).

Î See the Advanced Guide: Set up Menu (p. 26).

Î

See the Advanced Guide: My Camera Menu (p. 28).

2.

Turn the mode dial to (Auto).

10

3.

Aim the camera at the subject.

4.

Focus and shoot.

1. Press the shutter button halfway to focus.

Indicators

When the camera focuses, it beeps twice and the indicator lights green (orange when the flash fires). In addition, a green AF frame appears in the

LCD monitor on the portion of the image used to set the focus.

2. Press the shutter button fully to shoot.

The shutter sound will play and the image will record. The indicator will blink green while the image is recorded to the memory card.

Î See Indicators (p. 5).

Î

See the Advanced Guide for the various shooting methods available.

„ Reviewing an Image Right After Shooting

After a shot is taken, the image appears in the LCD monitor for approximately 2 seconds.

You can continue to display images regardless of the review duration setting with the following procedures.

• Keeping the shutter button pressed after a shot.

• Pressing the FUNC./SET or DISP. button while the image is displayed in the LCD monitor.

To stop displaying the image, press the shutter button halfway.

Î

See the Advanced Guide: Review (p. 24).

Î

See the Advanced Guide: Checking for Focus Right After

Shooting (p. 67).

Î See Erasing (p. 19).

Selecting a Shooting Mode

1.

Turn the mode dial to the desired mode ( ).

In the , and modes, press the FUNC./SET button

( ) and use the or button to select a shooting mode ( ), then press the FUNC./SET button ( ).

11

12

„ Shooting Modes

The camera automatically selects settings.

AUTO

Manual

Allows you to select settings yourself, such as the exposure compensation, white balance, my colors or ISO speed. Î See the Advanced Guide (p. 32).

Digital Macro

Allows you to shoot when the distance from the lens (at maximum wide angle) to the subject is within 5 – 50 cm (2.0 in. – 1.6 ft.). The subject can be shown larger than in standard macro mode because the camera trims the image edges and zooms in with the digital zoom.

Î See the Advanced Guide (p. 34).

MANUAL

Color Accent

Use this option to have only the color specified in the LCD monitor remain and to transform all others to black and white.

Î

See the Advanced Guide (p. 60).

Color Swap

Use this option to transform a color specified in the LCD monitor into another.

Î See the Advanced Guide (p. 62).

Stitch Assist

Allows you to shoot overlapping images that can later be merged (stitched) to create one panoramic image on a

Portrait

Produces a soft effect when photographing people.

SPECIAL

SCENE

Kids&Pets

Allows you to capture subjects that move around, such as children and pets, without missing photo opportunities.

Foliage

Shoots trees and leaves—such as new growth, autumn leaves or blossoms— in vivid colors.

Night

Snapshot

Allows you to take snapshots of people against twilight or night backgrounds by reducing the effects of camera shake even without using a tripod.

Indoor

Prevents camera shake and maintains the subject's true color when shooting under fluorescent or tungsten lighting.

Snow

Shoots without a blue tinge and without making people appear dark against a snowy background.

Beach

Shoots without making people appear dark near water or sand where reflected sunlight is strong.

Fireworks

Captures fireworks in the sky sharply and at optimal exposure.

SPECIAL

SCENE

Aquarium

Selects the optimal

ISO speed, white balance and color balance to capture fish and other items in an indoor aquarium.

ISO 3200

Shoots with the

ISO speed set to

3200. Use it when high speed is required. (Twice as sensitive as ISO 1600.) Avoids blurring of the subject and the effects of camera shake.

Underwater

Appropriate for shooting images with Waterproof Case WP-

DC7 (sold separately). This mode uses an optimal white balance setting to reduce bluish tones and record images with a natural hue.

MOVIE

Shoots a movie when you press the shutter button.

You can select from the following modes: [ Standard]; [ High Resolution] for viewing on computer monitors at large sizes; [ Compact] convenient for email attachments; [ Color Accent] for recording all colors in black and white except for the selected color; and [ Color Swap] for recording a selected color as a different color.

Î

See the Advanced Guide (p. 40).

• In mode, the resolution is fixed at .

The shutter speed is slow in mode. Always use a tripod to avoid camera shake.

In , , , , , , may increase and cause noise in the image depending on the scene being shot.

• In mode, shoot with the subject 1 m (3.3 ft.) or more from the end of the lens.

To shoot underwater, install the camera in Waterproof Case

WP-DC7 (sold separately).

We recommend you use Waterproof Case WP-DC7 for shooting at ski resorts or beaches.

13

14

Using the Zoom

1.

Press the zoom lever toward or .

The zoom can be adjusted from 37 – 111 mm (focal length) in

35mm film equivalent terms.

Telephoto: Zooms in on the subject.

Wide Angle: Zooms out from the subject.

Using the Flash

1.

Press the button ( ) and use the or button to switch between modes ( ).

Auto

On

Off

Î See the Advanced Guide: Red-Eye Reduction Function (p. 33).

Î See the Advanced Guide: Setting the Slow Synchro (p. 33).

You are recommended to shoot with the camera attached to a tripod or other device if the camera shake warning

The option cannot be set in (Auto) mode.

Î See the Advanced Guide: Functions Available in Each Shooting Mode (p. 144).

Î

See Selecting a Shooting Mode (p. 11).

Shooting Close-Ups/Infinity Shots

1.

Press the / button ( ) and use the or button to switch between modes ( ).

To Cancel: press the / button and use the or button to display .

Macro

Use this mode to shoot close-ups of flowers or small items.

Image Area at Minimum Shooting Distance from End of Lens to Subject

• Maximum wide angle setting: 57 × 42 mm (2.2 × 1.7 in.)

Minimum shooting distance: 5 cm (2 in.)

• Maximum telephoto setting: 107 × 80 mm (4.2 × 3.1 in.)

Minimum shooting distance: 30 cm (12 in.)

Infinity

Use this mode to record subjects 3 m (9.8 ft.) or more from the end of the lens.

Use the LCD monitor to compose close-ups in macro mode since images composed with the viewfinder may be off-center.

The exposure may not be optimal when the flash is used in macro mode.

The option cannot be set in (Auto) mode.

Î See the Advanced Guide: Functions Available in Each Shooting Mode (p. 144).

Î

See Selecting a Shooting Mode (p. 11).

15

Using the Self-Timer

1.

Press the button ( ) and use the or button to display , or ( ).

• When the shutter button is pressed fully, the self-timer will activate and the self-timer lamp will blink (when using red-eye reduction, it will stay lit for the last 2 seconds).

• You can change the delay time and number of shots with the option (p. 17).

To Cancel: press the button and display .

16

10 sec. Self-Timer: shoots 10 sec. after you press the shutter button.

• 2 sec. before the shutter releases, the self-timer lamp and sound speed up*

1

.

2 sec. Self-Timer: shoots 2 sec. after you press the shutter button.

• The self-timer sound beeps quickly*

1

when you press the shutter button and the shutter releases 2 sec. later.

Custom Timer: you can change the delay time (0–10*

2

, 15, 20, 30 sec.) and number of shots (1–10*

3

).

• When [Delay] is set to 2 or more sec., the self-timer sound begins to beep 2 sec. before the shutter releases. When [Shots] is set to more than 1, the self-timer sound only beeps before the first shot.

*1 This may differ depending on your My Camera settings (Advanced Guide p. 104).

*2 Default setting.

*3 Default setting is 3 shots.

The self-timer cannot be used in some shooting modes.

Î

See the Advanced Guide: Functions Available in Each Shooting Mode (p. 144).

Î See Selecting a Shooting Mode (p. 11).

„ Changing the Delay Time and Number of Shots ( )

1.

In the [ (Rec)] menu, select

[Self-timer] and press the FUNC./

SET button.

Î See Menus and Settings (p. 21).

2.

Use the or button to select

[Delay] or [Shots] and the or button to change the setting and press the FUNC./SET button.

3.

Press the MENU button.

If the [Shots] option is set to 2 or more shots, the following occurs.

The exposure and white balance are locked at the settings selected for the first shot.

If the flash is used, the interval between shots lengthens because the flash must charge.

The interval between shots lengthens when the built-in memory of the camera fills.

Shooting will automatically cease if the memory card becomes full.

17

Playback

1.

Turn the mode dial to (playback) ( ).

The last image that was played back appears (Resume Playback).

If additional images were shot after viewing images in playback mode, the last image that was shot will appear instead. If the memory card has been switched, or the images on the memory card have been edited with a computer, the newest image on the memory card appears.

18

2.

Use the or button to display the image you wish to view ( ).

• Use the button to move to the previous image and the button to move the next image.

Holding the button down advances the images more rapidly, but shows them less clearly.

• Circling a fingertip to the left or right on the touch control dial selects an image as follows. Moving fingertip in a counterclockwise direction displays the previous image, and clockwise displays the next image.

Playback screen when the touch control dial is activated.

Î

See the Advanced Guide for the various playback methods available

Î See Touch Control Dial (p. 4).

Erasing

1.

In the playback mode, use the or button to select an image to erase ( ) and press the button ( ).

You can also select an image with the touch control dial.

2.

Confirm that [Erase] is selected and press the FUNC./SET button ( ).

To exit instead of erasing, select [Cancel].

Please note that erased images cannot be recovered.

Exercise adequate caution before erasing an image.

Î See the Advanced Guide: Erasing Images (p. 95).

19

Menus and Settings

Settings for the shooting or playback modes or such camera settings as the print settings, date/time and sounds are set using the FUNC. menu or the Rec., Play, Print, Set up or My Camera menu.

FUNC. Menu

This menu sets many of the common shooting functions.

20

This example shows the FUNC. menu in (Auto) mode.

Turn the mode dial to ,

Press the FUNC./SET button.

, or .

Use the or button to select a menu item.

• Some items may not be selectable in some shooting modes.

Use the or button to select an option for the menu item.

• You can select further options with the MENU button for some options.

• After selecting an option, you can press the shutter button to shoot immediately. After shooting, this menu will appear again, allowing you to adjust the settings easily.

Press the FUNC./SET button.

Î See the Advanced Guide: Menu List (p. 24).

Rec., Play, Print, Set up and My Camera Menus

Convenient settings for shooting, playback or printing can be set with these menus.

(Rec.) Menu

(Set up) Menu

(My Camera) Menu

You can switch between menus with the or button when this part is selected.

• This example shows the Rec. menu in (Auto) mode.

• In playback mode, the Play, Print, Set up and My Camera menus display.

Press the MENU button.

Use the or button to switch between menus.

• You can also use the zoom lever to switch between menus.

Use the or button to select a menu item.

• Some items may not be selectable in some shooting modes.

Use the or button to select an option.

• Menu items followed by an ellipsis (...) can only be set after pressing the FUNC./SET button to display the next menu.

Press the FUNC./SET button again to confirm the setting.

Press the MENU button.

Î See the Advanced Guide: Menu List (p. 24).

21

22

Printing

You can easily print by connecting the camera to a direct print compatible printer

*1

with a cable and simply pressing the button on the camera.

1.

Connect the camera to a Direct Print compatible printer and turn on the printer's power.

Canon Brand Printers

SELPHY CP Series Compact

Photo Printers*

2

Interface Cable

Camera

PIXMA Series/SELPHY DS

Series Bubble Jet Printers

*1 Since this camera uses a standard protocol (PictBridge), you can use it with other

PictBridge-compliant printers in addition to Canon-brand printers.

*2 You can also use card photo printers such as the CP-10/CP-100/CP-200/CP-300.

2.

Set the camera to the playback mode, turn on the power and confirm that , or is displayed in the upper left of the LCD monitor ( ).

• The button will light blue.

• The displayed icon will vary according to the printer model.

• will display in the movie mode.

3.

Use the or button to select an image to print ( ) and press the button ( ).

• You can also select an image with the touch control dial.

• The button will blink blue and printing will start.

Î See the Advanced Guide: Setting the DPOF Print Settings (p. 97).

Î See the Direct Print User Guide.

Î See the user guide for your printer.

23

24

Downloading Images to a Computer

The following methods can be used to download images recorded by the camera to a computer. Some methods, depending on the OS used, may not be available. Please read System Requirements (p. 25) in advance.

„ Camera to Computer Connection

Supplied Software

Install It

Downloading Method

Computer

Procedure

Camera

Procedure

OS Windows 98

Second Edition (SE)

z z

Windows Me

Windows 2000

Windows XP

Mac OS X

z z z z z z z z

Do Not Install It

Computer

Procedure

z z

Computer System

Requirements

Basic Guide (p. 25)

Software Starter Guide

Connecting the Camera to a Computer

Basic Guide (p. 27)

•Windows

®

XP and Mac OS X

Users leaflet

Downloading Images to a Computer

Basic Guide (pp. 28–29)

Software Starter Guide

„ Using a Memory Card Reader

A memory card reader can be used with all the operating systems listed above. See the Software Starter Guide for details.

System Requirements

Please install the software on a computer meeting the following minimum requirements.

„ Windows

OS Windows 98 Second Edition (SE)

Windows Me

Windows 2000 Service Pack 4

Windows XP (including Service Pack 1 and Service Pack 2)

Computer Model The above OS should be pre-installed on computers with built-in USB ports.

CPU

RAM

Interface

Pentium 500 MHz or higher processor

Windows 98 SE/Windows Me

Windows 2000/Windows XP

USB

128 MB or more

256 MB or more

Free Hard Disk

Space

Display

• Canon Utilities

- ZoomBrowser EX

- PhotoStitch

• Canon Camera TWAIN Driver

• Canon Camera WIA Driver

200 MB or more

40 MB or more

25 MB or more

25 MB or more

1,024 x 768 pixels/High Color (16 bit) or better

„ Macintosh

OS

Computer Model The above OS should be pre-installed on computers with built-in USB ports.

CPU

RAM

Mac OS X (v10.2–v10.4)

PowerPC G3/G4/G5 or Intel Processor*

256 MB or more

Interface USB

Free Hard Disk

Space

Display

• Canon Utilities

- ImageBrowser

- PhotoStitch

200 MB or more

40 MB or more

1,024 x 768 pixels/32,000 Colors or better

* EOS Utility (software for EOS DIGITAL series cameras) is only supported by

PowerPC.

25

26

Preparing to Download Images

Ensure that you install the software first before connecting the camera to the computer.

„ Items to Prepare

• Camera and computer

• Canon Digital Camera Solution Disk supplied with the camera

• Interface cable supplied with the camera

1.

Install the software.

1. Place the Canon Digital Camera Solution Disk in the computer's CD-ROM drive.

Double-click the [Canon

Digital Camera Installer] icon in the

CD-ROM window. When the installer panel appears, click [Install].

2. Click [Easy Installation].

Select [Easy Installation] as the setup type and click [Next].

Proceed with the installation while reviewing installation settings.

3. When the installation is finished, the

[Finish] or [Restart] button appears.

Click the one that appears.

When the installation is finished, click [Exit].

4. When the screen returns to the desktop display, remove the

Canon Digital Camera Solution Disk from the CD-ROM drive.

2.

Connecting the camera to a computer.

1. Connect the supplied interface cable to the computer's USB port and to the camera's DIGITAL terminal.

Slip a fingernail under the bottom edge of the camera's DIGITAL terminal cover, lift up and plug the interface cable in all the way.

USB Port DIGITAL Terminal

Interface Cable

2. Turn the camera's mode dial to

(playback) and turn on the power.

The camera and computer will be able to communicate.

Interface Cable

Always grasp the sides of the connector when disconnecting the interface cable from the camera's

DIGITAL terminal.

If the Digital Signature Not Found window appears, click [Yes]. The USB driver will automatically finish installing onto the computer when you attach the camera and open a connection.

27

28

Downloading Images to a Computer

A window allowing you to set the preferences will appear when a connection is established between the camera and computer.

1.

Select [Canon CameraWindow] and click [OK] (first time only).

If the window to the right does not appear, click the [Start] menu and select [All Programs] or [Programs], followed by

[Canon Utilities],

[CameraWindow], [PowerShot -

IXY - IXUS - DV 6] and

[CameraWindow].

2.

Download the images.

• Download the images using the camera or the computer.

• By default, the downloaded images are saved into the [My

Pictures] folder.

Downloading Images Using the Camera

(p. 30).

Downloading Images Using a Computer.

By default, all images that have yet to be downloaded will download.

You can set the type of image to download and the destination folder.

Thumbnails (small versions) of the downloaded images will display in the

ZoomBrowser EX Main Window. By default, the downloaded images are saved into subfolders according to their shooting dates.

Downloading Images to a Computer

The following window will appear when you establish a connection between the camera and computer. If it fails to appear, click the [Canon

CameraWindow] icon on the Dock (the bar which appears at the bottom of the desktop).

1.

Download the images.

• Download the images using the camera or the computer.

• By default, the downloaded images are saved into the [Pictures] folder.

Downloading Images Using the Camera

(p. 30).

Downloading Images Using a Computer.

By default, all images that have yet to be downloaded will download.

You can set the type of image to download and the destination folder.

Thumbnails (small versions) of the downloaded images will display in the

ImageBrowser Browser Window. By default, the downloaded images are saved into folders according to their shooting dates.

29

30

Downloading Images Using the Camera

(Direct Transfer)

Use this method to download images using camera operations.

Install the supplied software and adjust the computer settings before using this method for the first time (p. 26).

All Images

New Images

DPOF Trans.

Images

Select & Transfer

Wallpaper

Transfers and saves all images to the computer.

Transfers and saves to the computer only the images that have not been previously transferred.

Transfers and saves to the computer only the images with DPOF Transfer Order settings

(Advanced Guide, p. 101).

Transfers and saves single images to the computer as you view and select them.

Transfers and saves single images to the computer as you view and select them. The transferred images display on the computer desktop.

1.

Confirm that the Direct Transfer menu is displayed on the camera's

LCD monitor.

• The button will light blue.

• Press the MENU button if the Direct

Transfer menu fails to appear.

Direct Transfer Menu

„ All Images/New Images/DPOF Trans. Images

2.

Select , or and press the

button.

• The images will download. The button will blink blue while downloading is in progress. The display will return to the Direct Transfer menu when the download is complete.

• To cancel the download, press the FUNC./SET button.

„ Select & Transfer/Wallpaper

2.

Select or and press the button (or the

FUNC./SET button).

3.

Select images to download and press the button

(or the FUNC./SET button).

• The images will download. The button will blink blue while downloading is in progress.

• Images can also be selected during index playback (Advanced Guide p. 74).

• Press the MENU button to return to the

Direct Transfer menu.

Only JPEG images can be downloaded as wallpaper for a computer. On the Windows platform, the files are automatically created as BMP images.

The option selected with the button is retained even when the camera's power is turned off.

The previous setting will be in effect the next time the

Direct Transfer menu is displayed. The image selection screen will appear directly when the [Select & Transfer] or the [Wallpaper] option was last selected.

31

32

MEMO

Safety Precautions

Be sure to read, understand and follow the safety precautions below when using the camera, in order to prevent injury, burns or electrical shock to yourself and others.

Be sure to also read the safety precautions listed in the

Advanced Camera User Guide.

Warnings

• Do not trigger the flash in close proximity to human or animal eyes.

• Store this equipment out of the reach of children and infants.

• Avoid dropping or subjecting the camera to severe impacts. Do not touch the flash portion of the camera if it has been damaged.

• Stop operating the equipment immediately if it emits smoke or noxiousfumes.

• Do not handle the power cord if your hands are wet.

• Use only recommended batteries and accessories.

• The battery charger and compact power adapter are designed for exclusive use with your camera. Do not use it with other products or batteries.

Caution

• Do not sit with the camera in a back pocket as it may cause the camera to malfunction or damage the LCD monitor.

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
