Cyber-shot Handbook
DSC-H55
© 2010 Sony Corporation
4-172-679-12(1)
GB
Table of
contents
How to use this handbook
Click on a button at upper right to jump to the corresponding page.
This is convenient when searching for a function you want to view.
Operation
Search
Search for information by operation.
MENU/Settings
Search
Search for information in a listing of
MENU/Settings items.
Marks and notations used in this handbook
MENU/Settings
Search
Index
Search for information by keyword.
Operation
Search
Table of
contents
Search for information by function.
The default setting is indicated by
Index
In this handbook, the sequence of
operations is shown by arrows (t).
Operate the camera in the order indicated.
Marks are shown as they appear in the
camera’s default setting.
.
Indicates cautions and limitations relevant
to the correct operation of the camera.
z
Indicates information that is useful to
know.
2GB
• For details on “Memory Stick Duo” media, see
page 125.
When using a “Memory Stick Duo”
media with standard sized “Memory
Stick” media slot
You can use the “Memory Stick Duo” media
by inserting it into the “Memory Stick Duo”
media Adaptor (sold separately).
“Memory Stick
Duo” media
Adaptor
Notes on the LCD screen and lens
• The LCD screen is manufactured using
extremely high-precision technology so over
99.99% of the pixels are operational for
effective use. However, some tiny black and/or
bright dots (white, red, blue or green) may
appear on the LCD screen. These dots are a
normal result of the manufacturing process and
do not affect the recording.
Index
When recording movies, it is recommended
that you use the following memory cards:
–
(Mark2) (“Memory
Stick PRO Duo” (Mark2) media)
–
(“Memory Stick PROHG Duo” media)
– SD memory card, SDHC memory card or
SDXC memory card (Class 4 or faster)
• Charge the battery pack (supplied) before using
the camera for the first time.
• You can charge the battery pack even if it is not
completely discharged. In addition, even if the
battery pack is not fully charged, you can use the
partially charged capacity of the battery pack as
is.
• If you do not intend to use the battery pack for a
long time, use up the existing charge and
remove it from the camera, then store it in a
cool, dry place. This is to maintain the battery
pack functions.
• For details on the usable battery pack, see
page 127.
MENU/Settings
Search
• “Memory Stick Duo” media of up to 32 GB and
SD memory cards of up to 64 GB have been
tested and proven to operate with your camera.
Notes on the battery pack
Operation
Search
Notes on the types of memory card
that you can use (sold separately)
The following memory cards are compatible
with this camera: “Memory Stick PRO Duo”
media, “Memory Stick PRO-HG Duo”
media, “Memory Stick Duo” media, SD
memory cards, SDHC memory cards and
SDXC memory cards. MultiMediaCard is not
compatible.
In this handbook, “Memory Stick PRO Duo”
media, “Memory Stick PRO-HG Duo” media
and “Memory Stick Duo” media are called
“Memory Stick Duo” media and SD memory
cards, SDHC memory cards and SDXC
memory cards are called SD memory cards.
Table of
contents
Notes on using the camera
Black, white, red, blue or
green dots
• Exposing the LCD screen or the lens to direct
sunlight for long periods may cause
malfunctions. Be careful when placing the
camera near a window or outdoors.
• Do not press against the LCD screen. The screen
may be discolored and that may cause a
malfunction.
• Images may trail across on the LCD screen in a
cold location. This is not a malfunction.
• Be careful not to bump the movable lens, and be
careful not to apply force to it.
3GB
Continued r
On moisture condensation
The images used as examples in this Handbook are
reproduced images, and are not actual images shot
using this camera.
Operation
Search
The images used in this Handbook
Table of
contents
• If the camera is brought directly from a cold to a
warm location, moisture may condense inside or
outside the camera. This moisture condensation
may cause a malfunction of the camera.
• If moisture condensation occurs, turn off the
camera and wait about an hour for the moisture
to evaporate. Note that if you attempt to shoot
with moisture remaining inside the lens, you
will be unable to record clear images.
MENU/Settings
Search
Index
4GB
Notes on using the camera
MENU/Settings
Search
Shooting
Operation
Search
How to use this handbook····································· 2
Notes on using the camera ··································· 3
Operation Search ·················································· 8
MENU/Settings Search ······································· 10
Identifying parts··················································· 14
List of icons displayed on the screen ·················· 15
Using the mode dial ············································ 17
Using the internal memory ·································· 18
Table of
contents
Table of contents
Index
Intelligent Auto Adjustment ································· 19
Easy Shooting ····················································· 20
Program Auto ······················································ 22
Manual Exposure Shooting ································· 23
Sweep Panorama················································ 24
Scene Selection ·················································· 26
Movie Mode························································· 28
Zoom ··································································· 29
DISP (Screen Display Settings) ····························30
Flash ··································································· 32
Smile Shutter······················································· 33
Self-Timer···························································· 34
5GB
MENU (Shooting)
MENU (Viewing)
MENU items (Viewing) ········································ 11
MENU/Settings
Search
MENU items (Shooting) ······································ 10
Operation
Search
Viewing still images············································· 35
Playback zoom···················································· 36
Image Index ························································ 37
Delete·································································· 38
Viewing movies ··················································· 39
Table of
contents
Viewing
Index
Settings
Setting items ······················································· 12
TV
Viewing an image on a TV ································ 100
Computer
Using with your computer·································· 103
Using the software ············································ 104
Connecting the camera to the computer···············106
Uploading images to a media service ···················108
6GB
Printing still images ··········································· 110
Table of
contents
Printing
Troubleshooting
“Memory Stick Duo” media································ 125
Battery pack ······················································ 127
Battery charger·················································· 128
MENU/Settings
Search
Others
Operation
Search
Troubleshooting ················································ 112
Warning indicators and messages ···················· 120
Index
Index
Index ································································· 129
7GB
Leaving the settings to Intelligent Auto Adjustment ······························· 19
the camera
Scene Selection ··················································· 26
Table of
contents
Operation Search
Scene Recognition ·············································· 55
Manual Exposure Shooting ······························ 23
Shooting panoramic
images
Sweep Panorama ················································ 24
Shooting best shots of
your pet
Pet ············································································ 26
Shooting moving
objects
Movie Mode··························································· 28
Advanced Sports Shooting ······························· 26
Burst Settings ······················································· 45
Shooting without blur
High Sensitivity····················································· 26
2-second delay self-timer ·································· 34
ISO ··········································································· 48
SteadyShot ···························································· 62
Index
Shooting in manual
mode
MENU/Settings
Search
Soft Snap ······························································· 26
Twilight Portrait ···················································· 26
Smile Shutter ························································ 33
Scene Recognition ·············································· 55
Face Detection ····················································· 58
Anti Blink ································································ 61
Red Eye Reduction ············································· 78
Operation
Search
Shooting portraits
Shooting with backlight Forced Flash ························································· 32
Scene Recognition ·············································· 55
DRO········································································· 60
8GB
Shooting in dark places High Sensitivity····················································· 26
Focus ······································································ 52
Face Detection ····················································· 58
Changing image size
Image Size····························································· 41
Deleting images
Delete ································································ 38, 68
Format ···································································· 92
Displaying enlarged
images
Playback zoom ····················································· 36
Trimming (Resize) ··············································· 67
Editing images
Retouch ·································································· 67
Index
Changing focus
position
MENU/Settings
Search
EV ············································································ 47
Operation
Search
Adjusting exposure
Table of
contents
Slow Synchro ························································ 32
ISO ··········································································· 48
Playing back a series of Slideshow ······························································ 63
images in order
Shooting/Viewing with
easy-to-see indicators
Easy Shooting ······················································ 20
Printing images with
the date
Using the “PMB (Picture Motion Browser)”
Changing date and
time settings
Area Setting ·························································· 98
Date & Time Setting············································ 99
Initializing settings
Initialize··································································· 84
Printing images
Print ······································································· 110
Viewing on TVs
Viewing an image on a TV ······························ 100
················································································ 104
9GB
Table of
contents
MENU/Settings Search
MENU items (Shooting)
You can select the various shooting functions easily from the MENU button.
ON/OFF (Power)
button
2 Press the MENU button to display the Menu
screen.
3 Select the desired menu item with v/V/b/B on
the control button.
MENU button
Control button
In the table below, indicates settings that can be changed, while — indicates settings that
cannot be changed. A setting may be fixed or restricted depending on the shooting mode. For
details, see the page for each item. The icons below
indicate the available modes.
MENU/Settings
Search
4 Press the MENU button to turn off the Menu
screen.
Operation
Search
1 Press the ON/OFF (Power) button and set the
camera to shooting mode.
Mode dial
Scene Selection
—
—
—
—
Shooting Direction
—
—
—
—
—
—
—
—
—
—
—
—
Index
Menu items
Image Size
Flash
—
Burst Settings
Bracket Settings
—
—
EV
—
—
—
—
—
—
—
—
—
—
ISO
—
—
White Balance
—
—
Focus
—
—
—
Metering Mode
—
—
—
Scene Recognition
—
Smile Detection Sensitivity
—
—
Face Detection
—
—
—
—
—
DRO
—
—
—
Anti Blink
—
—
—
—
—
SteadyShot
—
—
—
—
—
(Settings)
—
—
—
—
—
—
—
—
—
—
Note
• Only the items that are available for each mode are displayed on the screen.
10GB
MENU items (Viewing)
1 Press the
(Playback) button to switch to
playback mode.
Control button
Operation
Search
2 Press the MENU button to display the Menu
screen.
3 Select the desired menu item with v/V/b/B on
the control button.
4 Press z on the center of the control button.
View Mode
Menu items
(Playback)
button
MENU button
Internal
Memory
Memory card
Date View
Folder view
(Still)
Folder view
(Movie)
Folder View
MENU/Settings
Search
In the table below, indicates settings that can be changed, while
— indicates settings that cannot be changed.
Table of
contents
You can select the various viewing functions easily from the MENU button.
(Slideshow)
(View Mode)
—
Index
(Retouch)
—
(Delete)
(Protect)
DPOF
—
(Print)
—
(Rotate)
—
(Select Folder)
—
—
—
(Settings)
Note
• Only the items that are available for each mode are displayed on the screen.
11GB
Setting items
(Settings) screen.
1 Press the MENU button to display the Menu
screen.
Control button
Operation
Search
2 Select
(Settings) with V on the control button,
then press z on the center of the control button to
display the setup screen.
3 Select each item with v/V/b/B, then press z.
4 Select the desired setting, then press z.
Shooting Settings
Items
AF Illuminator
Grid Line
Disp. Resolution
MENU/Settings
Search
MENU button
Categories
Table of
contents
You can change the settings on the
Digital Zoom
Auto Orientation
Index
Red Eye Reduction
Blink Alert
Main Settings
Beep
Language Setting
Function Guide
Demo Mode
Initialize
COMPONENT
Video Out
USB Connect
LUN Settings
Download Music
Format Music
Power Save
Memory Card Tool
Format
Create REC.Folder
Change REC.Folder
Delete REC.Folder
Copy
File Number
Internal Memory Tool
Format
File Number
12GB
Continued r
Categories
Area Setting
Date & Time Setting
Notes
Table of
contents
Clock Settings
Items
• [Shooting Settings] appears only when settings have been entered from shooting mode.
• [Memory Card Tool] appears only when a memory card is inserted in the camera, while [Internal
Memory Tool] appears only when a memory card is not inserted.
Operation
Search
MENU/Settings
Search
Index
13GB
Table of
contents
Identifying parts
A Shutter button
B Mode dial (17)
C For shooting: W/T (zoom) lever (29)
For viewing: (Playback zoom) lever/
(Index) lever (36, 37)
E ON/OFF (Power) button
F Microphone
G Self-timer lamp/Smile Shutter lamp/AF
illuminator
Operation
Search
D Flash
H Lens
J Hook for wrist strap*
K
L
(Playback) button (35)
(Delete) button (38)
M MENU button (10)
N Control button
Menu on: v/V/b/B/z
Menu off: DISP/ / /
Index
O Tripod receptacle
MENU/Settings
Search
I LCD screen
P Speaker
Q Multi connector
R Battery/Memory card cover
S Access lamp
T Battery insertion slot
U Battery eject lever
V Memory card slot
* Using the wrist strap
The wrist strap is already attached to the camera at
the factory. Place your hand through the loop to
prevent the camera from damage by being
dropped.
Hook
14GB
Icons are displayed on the screen to indicate the camera status.
You can change the screen display using DISP (Screen Display Settings) on the control button.
When shooting still images
A
Indication
Battery remaining
Low battery warning
Image Size
When shooting movies
Mode dial (Intelligent Auto
Adjustment/Movie Mode/Sweep
Panorama/Manual Exposure
Shooting/Program Auto)
White Balance
Index
Scene Recognition icon
MENU/Settings
Search
Scene Selection
Operation
Search
Display
• The icons are limited in Easy Shooting mode.
Table of
contents
List of icons displayed on the
screen
Metering Mode
When playing back
Vibration warning
Scene Recognition
Burst Settings
Bracket Shooting
Bracket Settings
DRO
Smile Detection Sensitivity
indicator
15GB
Continued r
Display
Indication
Display
White Balance
PictBridge connecting
Protect
ISO 400
Database file full/Database file
error
Print order (DPOF)
Playback zoom
View Mode
Display
Indication
z
AE/AF lock
ISO400
ISO number
Indication
Self-timer
C:32:00
Self-diagnosis display
Destination
Overheating warning
Face Detection
125
Shutter speed
F3.5
Aperture value
Database file full/Database file
error
+2.0EV
Exposure value
AF range finder frame
Focus
0:12
Recording time (m:s)
101-0012
Folder-file number
2010 1 1
9:30 AM
Recorded date/time of the
playback image
C
Display
Indication
Spot metering cross hair
+2.0EV
Exposure value
500
Shutter speed
F3.5
Aperture value
N
Playback
Playback bar
Recording folder
Playback folder
96
Number of recordable images
12/12
Image number/Number of
images recorded in date range,
selected folder
100Min
Recordable time
Recording/Playback Media
(Memory card, internal memory)
Index
Recording a movie/Standby a
movie
MENU/Settings
Search
NR slow shutter
REC
Standby
Operation
Search
D
Display
B
ISO number
Table of
contents
Zoom scaling
Indication
00:00:12
Counter
Direction
GPS information
35° 37’ 32” N
139° 44’ 31” E
Latitude and Longitude display
Histogram
•
appears when histogram
display is disabled.
Volume
Changing folder
AF Illuminator
Red-eye reduction
Metering Mode
Flash mode
Flash charging
16GB
Set the mode dial to the desired function.
Mode dial
Table of
contents
Using the mode dial
Operation
Search
Allows you to record movies (page 28).
(Sweep Panorama)
Allows you to shoot a panoramic image after composing images
(page 24).
(Manual Exposure
Shooting)
Allows you to shoot after adjusting the exposure manually (both the
shutter speed and the aperture (F value)) (page 23).
(Program Auto)
Allows you to shoot with the exposure adjusted automatically (both
the shutter speed and the aperture (F value)) (page 22). You can set
various functions using the menu.
(Easy Shooting)
(Scene Selection)
Allows you to shoot with the settings adjusted automatically
(page 19).
Allows you to shoot/view still images with easy-to-see indicators
(page 20).
Index
(Intelligent Auto
Adjustment)
MENU/Settings
Search
(Movie Mode)
Allows you to shoot with preset settings according to the scene
(page 26).
17GB
The camera has approximately 45 MB of internal memory. This memory is not removable.
You can record images on the internal memory when there is no memory card inserted in the
camera.
B
Internal
memory
MENU/Settings
Search
B
When there is no memory card inserted
[Recording]: Images are recorded using the internal
memory.
[Playback]: Images stored in the internal memory are played
back.
[Menu, Settings, etc.]: Various functions can be
performed on images in the internal memory.
Operation
Search
When a memory card is inserted
[Recording]: Images are recorded on the memory card.
[Playback]: Images on the memory card are played back.
[Menu, Settings, etc.]: Various functions can be
performed on images on the memory card.
Table of
contents
Using the internal memory
On image data stored in the internal memory
To copy (back up) data on a hard disk of your computer
Perform the procedure on pages 106 without a memory card inserted in the camera.
Index
We recommend that you copy (back up) data without error using one of the following methods.
To copy (back up) data on a memory card
Prepare a memory card with sufficient free capacity, then perform the procedure explained in
[Copy] (page 96).
Notes
• You cannot transfer image data on a memory card to the internal memory.
• By making a USB connection between the camera and a computer with a cable for multi-use terminal,
you can transfer data stored in the internal memory to a computer. However you cannot transfer data on a
computer to the internal memory.
18GB
Allows you to shoot still images with the setting adjusted automatically.
1 Set the mode dial to
(Intelligent Auto Adjustment).
Table of
contents
Intelligent Auto Adjustment
2 Shoot with the shutter button.
Note
zOn Scene Recognition
Operation
Search
• Flash mode is set to [Auto] or [Off].
Scene Recognition operates in Intelligent Auto Adjustment mode. This function lets the
camera automatically recognize the shooting conditions and shoot the image.
• The camera recognizes (Twilight),
(Twilight Portrait),
(Twilight using a tripod),
(Backlight),
(Backlight Portrait),
(Landscape),
(Macro) or
(Portrait), and displays
the corresponding icon and guide on the LCD screen when the scene is recognized.
For details, see page 55.
Index
zIf you shoot a still image of a subject that is difficult
MENU/Settings
Search
Scene Recognition icon and guide
to focus on
• The shortest shooting distance is approximately 5 cm (2 inches) (W)/100 cm (3 ft 3 3/8 inches) (T).
• When the camera cannot focus on the subject automatically, the AE/AF lock indicator changes to
slowly flashing and the beep does not sound. Either recompose the shot or change the focus setting
(page 52).
•
–
–
–
–
–
–
Focusing may be difficult in the following situations:
It is dark and the subject is distant.
The contrast between the subject and the background is poor.
The subject is seen through glass.
The subject is moving quickly.
There is reflective light or shiny surfaces.
The subject is backlit or there is a flashing light.
19GB
Table of
contents
Easy Shooting
Allows you to shoot still images using the minimum necessary functions.
The text size increases and indicators become easier to see.
1 Set the mode dial to
(Easy Shooting).
2 Shoot with the shutter button.
• The battery charge is used up more quickly because the screen brightness increases automatically.
zFunctions available in Easy Shooting mode
MENU t [Image Size] t z on the control button t desired
mode t z
Select between [Large] or [Small] size.
Self-Timer:
on the control button t desired mode
Select between [10sec] or [Off] mode.
Flash:
on the control button t desired mode
Select between [Auto] or [Off] mode.
Smile Shutter:
on the control button
Index
MENU t [Flash] t z on the control button t desired mode
tz
Select between [Auto] or [Off] mode.
MENU/Settings
Search
Image Size:
Operation
Search
Note
zOn Scene Recognition
Scene Recognition operates in Easy Shooting mode. This function lets the camera
automatically recognize the shooting conditions and shoot the image.
Scene Recognition icon
• The camera recognizes (Twilight),
(Twilight Portrait),
(Twilight using a tripod),
(Backlight),
(Backlight Portrait),
(Landscape),
(Macro) or
(Portrait), and displays
an icon on the LCD screen when the scene is recognized.
For details, see page 55.
20GB
Continued r
When you press the
(Playback) button with the mode dial set to
(Easy Shooting),
the playback screen text becomes larger and easier to see. In addition, only the deletion
function becomes available.
(Delete) button
MENU button
• [View Mode] is set to [Date View] when using a memory card.
Operation
Search
You can delete the currently displayed image.
Select [OK] t z on the control button.
You can delete the currently displayed image with [Delete Single
Image] and delete all images in the selected date range or internal
memory (if selected) with [Delete All Images].
Table of
contents
zOn Easy Viewing mode
MENU/Settings
Search
Index
21GB
Allows you to shoot with the exposure adjusted automatically (both the shutter speed and the
aperture value). Also you can select various settings using the menu.
1 Set the mode dial to
Table of
contents
Program Auto
(Program Auto).
2 Shoot with the shutter button.
Operation
Search
MENU/Settings
Search
Index
22GB
You can shoot at your favorite exposure by manually setting the shutter speed and aperture
value.
1 Set the mode dial to
Table of
contents
Manual Exposure Shooting
(Manual Exposure Shooting).
2 Press z on the control button.
Control button
Feature
z
Return
vV
Shutter speed
bB
Aperture (F value)
4 Press the shutter button to shoot the image.
MENU/Settings
Search
• Select a shutter speed from 1/1600 to 30 seconds.
• When zoom is set fully to W, you can select an aperture of F3.5 or F8 (when used with the Internal
ND (Neutral Density) Filter).
When zoom is set fully to T, you can select an aperture of F5.5 or F13 (when used with the Internal
ND (Neutral Density) Filter).
Operation
Search
3 Select the shutter speed and aperture (F value) using control button.
Notes
Index
• If proper exposure is not obtained by your settings, the setting value indicators on the screen will flash
when the shutter button is pressed halfway down. You can shoot in this condition, but exposure
readjustment is recommended.
• The flash is set to [On] or [Off].
• You cannot select the shutter speed and aperture (F value) when the self-timer is set to [Self-portrait One
Person] or [Self-portrait Two People].
zSetting the shutter speed and aperture (F value)
The difference between the settings and proper exposure judged by the camera appears as an
EV value on screen.
Shutter speed/aperture (F value)
Exposure value
0EV is the value judged as the most suitable by the camera.
• When the shutter speed is one second or slower, the shutter speed is indicated by [”], for example,
[1”].
• When you set the shutter speed slower, using a tripod is recommended to prevent the effects of
vibration.
• When the shutter speed becomes slower than a certain speed, the NR slow shutter function is
activated automatically to reduce image noise, and [NR] appears on the screen.
• If you select slow shutter speeds, it takes time to process the data.
23GB
Table of
contents
Sweep Panorama
Allows you to create a panoramic image from composed images.
Operation
Search
1 Set the mode dial to
(Sweep Panorama).
2 Point the camera at the edge of the subject, then
press the shutter button fully down.
3 Pan the camera to the end, following the
guidance on the LCD screen.
MENU/Settings
Search
This part will not be taken
Guidance
bar
Index
Notes
• If you cannot pan the camera across the entire subject within the given time, a gray area occurs in the
composed image. If this happens, move the camera fast to record a full panoramic image.
• Since several images are stitched together, the stitched part will not be recorded smoothly.
• Under low light conditions, panoramic images may be blurred.
• Under lights that flicker such as fluorescent light, the brightness or color of the combined image is not
always the same.
• When the whole angle of panoramic shooting and the angle in which you fixed the focus and exposure
with AE/AF lock are extremely different in brightness, color and focus, the shooting will not be
successful. If this happens, change the lock angle and shoot again.
• Sweep Panorama is not suitable for the following situations:
– Objects are moving
– Objects are too close to the camera
– Image with a repeating pattern such as tiles and image with little contrast such as sky, sandy beach, or
lawn
– Image with constant change such as waves or water falls
– Image with the sun or electric lights, etc. that are much brighter than surroundings
• You cannot create panoramic images in the following situations:
– You pan the camera too fast or too slow
– There is too much camera shake
24GB
Continued r
panoramic image
Shooting Direction: MENU t [Shooting Direction] t select [Right], [Left], [Up]
and [Down] t z on the control button
Image Size:
MENU t [Image Size] t select [Standard] or [Wide] t z
Pan the camera in an arc with a constant velocity and in the same direction as the indication
on the LCD screen. Sweep Panorama is better suited for still subjects, rather than moving
ones.
Operation
Search
zTips for shooting a panoramic image
Table of
contents
zChanging the shooting direction or image size of a
MENU/Settings
Search
Horizontal direction
• Determine the scene and press the shutter button halfway, so that you can lock the focus exposure
and white balance.
• Adjust the frame composition so that a portion with greatly varied scenery is in the center of the
image.
Index
Vertical direction
Radius as short
as possible
zPlaying back scrolling panoramic images
You can scroll panoramic images by pressing z on the control button while panoramic
images are being displayed. Turn the W (zoom) lever to display the whole image again.
Operation button/
lever
Description
z
Plays back scrolling images/Stops
b/B/v/V
Scrolls images
W
Displays the whole image
Shows the displayed area of
the whole panoramic image
• Panoramic images are played back with the supplied software “PMB” (page 104).
• Panoramic images shot with other cameras may not be scrolled correctly.
25GB
Table of
contents
Scene Selection
Allows you to shoot with preset settings according to the scene.
1 Set the mode dial to
(Scene Selection).
2 Select the desired mode t z on the control button.
If you want to switch to another scene, press the MENU button.
Operation
Search
(High Sensitivity) Allows you to shoot images without a
flash under low light conditions,
reducing blur.
(Soft Snap)
(Landscape)
MENU/Settings
Search
(Advanced
Sports Shooting)
Allows you to shoot images with a softer atmosphere for
portraits and flowers, etc.
Allows you to shoot subjects with fast movements such
as sports. While the shutter is pressed halfway, the
movement of the subject is predicted and the focus will
be adjusted.
Allows easy shooting of distant scenes by focusing in
the distance. Shoots vivid blue sky and flora colors.
Index
(Twilight Portrait) Allows you to shoot sharp images of people with the
night view in the background without compromising the
atmosphere.
(Twilight)
(Gourmet)
(Pet)
(Beach)
(Snow)
Allows you to shoot night scenes at far distance without
losing the dark atmosphere of the surroundings.
Shifts to Macro mode, allowing you to shoot food
arrangements in delicious and bright color.
Allows you to shoot images of your pet with the best
settings.
Allows you to record the blue of the water clearly when
shooting seaside or lakeside scenes.
Allows you to record clear images preventing sunken
colors in snowy scenes or other places where the whole
screen appears white.
26GB
Continued r
(Fireworks)
Allows you to record fireworks in all their splendor.
Table of
contents
Note
• When you shoot images using
(Twilight Portrait), (Twilight) or
(Fireworks) mode, the shutter
speed is slower and the images tend to blur. To prevent blurring, the use of a tripod is recommended.
Flash
Face Detection/
Self-Timer
Smile Shutter
Burst Settings/
Bracket
Settings
ISO
—
—
2
*3
*
—
*3
White
Balance
*1
Anti Blink
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
*
3
—
—
—
*3
—
—
—
—
—
—
*
—
3
—
Index
—
—
MENU/Settings
Search
For shooting an image appropriately according to the scene condition, a combination of
functions is determined by the camera. indicates an available function, — indicates an
unavailable function. The icons below [Flash] and [Self-Timer] indicate the available modes.
Some functions are not available, depending on the Scene Selection mode.
Operation
Search
Functions you can use in Scene Selection
*1 [Flash] for [White Balance] cannot be selected.
*2 [Off] for [Face Detection] cannot be selected.
*3 [White Balance] for [Bracket Settings] cannot be selected.
27GB
Allows you to record movies.
1 Set the mode dial to
(Movie Mode).
Table of
contents
Movie Mode
2 Press the shutter button fully down.
3 To stop recording, press the shutter button fully down again.
Operation
Search
MENU/Settings
Search
Index
28GB
You can enlarge the image when shooting. The camera’s optical zoom function can enlarge
images up to 10×.
1 Turn the W/T (zoom) lever.
Table of
contents
Zoom
T side
Turn the W/T (zoom) lever to (T) to zoom in, and to (W) to
zoom out.
W side
• Zoom is fixed to the W side when shooting in Sweep Panorama mode.
• The operating sound of the lens is recorded when the zoom function operates while shooting a movie.
MENU/Settings
Search
Notes
Operation
Search
• Turn the W/T (zoom) lever lightly for a slower zoom. Move it
further for a faster zoom.
• When the zoom scale exceeds 10×, see page 76.
Index
29GB
1 Press DISP (Screen Display Settings) on the control button.
2 Select the desired mode with the control button.
(Bright +
Exposure Data)
Sets screen brighter and displays the
information.
Displays a recorded image.
A histogram is also displayed.
(Bright)
Sets screen brighter and displays the
information.
(Normal)
Sets screen to standard brightness and displays
the information.
MENU/Settings
Search
Sets screen brighter and displays only images.
Operation
Search
(Bright +
Image Only)
Table of
contents
DISP (Screen Display Settings)
Index
Note
• If you view images in bright outside light, adjust the screen brightness up. However, the battery power
may decrease faster under such condition.
30GB
Histogram
Table of
contents
A histogram is a graph showing the brightness of an image. The graph display indicates a bright
image when skewed to the right side, and a dark image when skewed to the left side.
A Number of pixels
B Brightness
A
Bright
1 Press DISP (Screen Display Settings) on the control button, then select
[Bright + Exposure Data].
MENU/Settings
Search
Notes
Index
• The histogram also appears when playing back a single image, but you cannot adjust the exposure.
• The histogram does not appear when:
– Recording movies
– Playing back movies
– Viewing vertical orientation images
– Rotating still images
– Shooting with Sweep Panorama
– Viewing images shot with Sweep Panorama
• A large difference in the histogram displayed during shooting and playback may occur when:
– The flash strobes.
– The shutter speed is slow or fast.
• The histogram may not appear for images recorded using other cameras.
Operation
Search
B
Dark
31GB
1 Press
(Flash) on the control button.
2 Select the desired mode with the control button.
(Auto)
(Slow
Synchro)
(Off)
Flash automatically operates in dark locations or when there is
backlight.
Flash always operates.
Flash always operates.
The shutter speed is slow in a dark place to clearly shoot the
background that is out of flash light.
Flash does not operate.
The flash strobes twice. The first flash adjusts the light quantity.
While charging the flash,
is displayed.
You cannot use the flash during burst or bracket.
In Intelligent Auto Adjustment mode, Easy Shooting mode, you can select only [Auto] or [Off].
In Manual Exposure Shooting mode, only [On] or [Off] can be selected.
In Sweep Panorama, flash is set to [Off].
MENU/Settings
Search
Notes
•
•
•
•
•
•
Operation
Search
(On)
Table of
contents
Flash
zWhen the “White circular spots” appears in flash
This is caused by particles (dust, pollen, etc.) floating close to the lens. When they are
accentuated by the camera’s flash, they appear as white circular spots.
Index
photos
Camera
Subject
Particles (dust, pollen, etc.)
in the air
How can the “White circular spots” be reduced?
• Light the room and shoot the subject without a flash.
• Select
(High Sensitivity) mode in Scene Selection. ([Off] is automatically selected.)
32GB
Table of
contents
Smile Shutter
When the camera detects a smile, the shutter is released automatically.
1 Press
(Smile) on the control button.
2 Wait for a smile to be detected.
3 To stop shooting, press
(Smile) again.
Face Detection frame
Notes
• Shooting using the Smile Shutter ends automatically when either the memory card or internal memory
becomes full.
• Smiles may not be detected correctly depending on the conditions.
• You cannot use the digital zoom function.
• If Sweep Panorama or Movie Mode is selected, you cannot use the Smile Shutter function.
MENU/Settings
Search
Smile Detection Sensitivity
indicator
Operation
Search
When the smile level exceeds the b point on the indicator, the
camera records images automatically.
If you press the shutter button during Smile Shutter, the camera
shoots the image, then returns to Smile Shutter mode.
zHints for better capturing of smiles
Index
Do not cover the eyes with the bangs.
Do not obscure the face by hat, masks, sunglasses, etc.
2 Try to orient the face in front of the camera and be as
level as possible. Keep the eyes narrowed.
3 Give a clear smile with an open mouth. The smile is
easier to detect when the teeth are shown.
1
• The shutter operates when any person whose face is being detected smiles.
• You can select the priority subject for face detection with [Face Detection]. To perform smile
detection for a different face, change the priority face with z on the control button (page 58).
• If a smile is not detected, set the [Smile Detection Sensitivity] in setting menu.
33GB
1 Press
(Self-Timer) on the control button.
2 Select the desired mode with the control button.
(Off)
Does not use the self-timer.
Sets the 10-second delay self-timer.
When you press the shutter button, the self-timer lamp flashes and a
beep sounds until the shutter operates.
To cancel, press again.
(2sec)
Sets the 2-second delay self-timer.
Notes
• In Easy Shooting mode, you can select only [10sec] or [Off].
• In Movie Mode, [Self-portrait One Person] or [Self-portrait Two People] cannot be selected.
• The self-timer is not valid when shooting in Sweep Panorama mode.
MENU/Settings
Search
(Self-portrait
Two People)
Set the self-timer to Self-portrait timer.
When the camera detects the specified number of faces, a beep
sounds, and the shutter operates 2 seconds later. Do not move the
camera during this while.
Operation
Search
(10sec)
(Self-portrait
One Person)
Table of
contents
Self-Timer
zAutomatic shooting with Self- portrait timer
Index
Point the lens at yourself so your face is reflected in the LCD screen. The camera detects the
subjects, and then the shutter operates. The camera determines the optimal composition and
prevents faces from being cut out of the LCD screen.
• You can also shoot an image by pressing the shutter button during this
operation.
zHints for preventing blur
If your hands or body moves while holding the camera and pressing the shutter button,
“Camera shake” occurs. Camera shake occurs frequently under low-light or slow shutter
speed conditions, such as those encountered in
(Twilight Portrait) or (Twilight) mode.
In such a case, shoot with the below tips in mind.
• Shoot with a 2-second delay self-timer and stabilize
the camera by holding your arms firmly at your side
after pressing the shutter button.
• Use a tripod or place the camera on a flat surface to
hold the camera steady.
34GB
1 Press the
(Playback) button to switch to playback mode.
2 Select an image with the control button.
Table of
contents
Viewing still images
zViewing images taken with a different camera
MENU/Settings
Search
• For registration, use a fully charged battery pack. If you attempt to register unregistered files using a
battery pack with little remaining charge, the battery pack may run out, causing copying to fail or
possibly corrupting the data.
Operation
Search
This camera creates a database file in a memory card and registers every shot image to it for
later playback. If the camera detects images that have not been registered to the database file
in the memory card, the registration screen “Files found which were not recognized Import
files” appears.
If you want to view unregistered images, select [OK] to register the images.
Index
35GB
Table of
contents
Playback zoom
Plays back the enlarged image.
1 Turn the
(Playback zoom) lever to (T) during still
image playback.
2 Adjust the position with the control button.
3 Change the zoom scale with the
lever.
(Playback zoom)
Turn the lever to (T) to zoom in, to (W) to zoom out.
Press z to cancel playback zoom.
You can save an enlarged image by using the trimming function.
Press MENU t [Retouch] t [Trimming (Resize)].
MENU/Settings
Search
zTo save enlarged images
Shows the displayed
area of the whole
Operation
Search
The image is enlarged to twice the previous size, at the center of the
image.
Index
36GB
Displays multiple images at the same time.
1 Press the
2 Turn the
(Playback) button to switch to playback mode.
Table of
contents
Image Index
(Index) lever to (W) to display the image index screen.
3 To return to the single-image screen, select an image with the control
button, then press z.
Note
• When the mode dial is set to
Operation
Search
Turn the lever again to display an index screen with more images. Turn the lever yet again to
view images with the Calendar while playing back in [Date View].
(Easy Shooting), you cannot view images in index mode.
Select the left side bar with the control button, then select the
desired date/folder with v/V.
When [View Mode] is set to [Date View], turn the
Calendar, while the index displays more images.
Index
zViewing images with the Calendar
MENU/Settings
Search
zDisplaying images of the desired date/folder
(Index) lever to view images with the
• To select the month you want to display, select / with the
control button, then the desired month.
• To view images in selected date in index mode, select the date with
the control button and press z.
• To exit the Calendar, select
with the control button, then press
z.
37GB
Allows you to select unwanted images for deletion. You can also delete images from the MENU
button (page 68).
1 Press the
2
Table of
contents
Delete
(Playback) button to switch to playback mode.
(Delete) button t desired mode t z on the control button
All in This Folder
Multiple Images
Deletes all images in the selected date range or folder at once.
Press [OK] t z after step 2.
Allows you to select and delete multiple images.
Do as the following after step 2.
2MENU t [OK] t z
This Image
Deletes the currently displayed image in single-image mode.
Exit
Cancels the deletion.
MENU/Settings
Search
1Select an image then press z.
Repeat the above step until there are no more images to be
deleted. Select an image with a
mark again to release the
mark.
Operation
Search
All in Date Range
Notes
Index
• In Easy Viewing mode, you can delete only the currently displayed image.
• When the internal memory is used to record images, View Mode is set to Folder View.
zYou can switch between index and single-image
mode when selecting images
Turn the lever to (T) of the W/T (zoom) lever in index mode
to return to single-image mode, and turn the
(Index) lever to
(W) in single-image mode to return to index mode.
• You can also switch between index and single-image mode in
[Protect], [DPOF] or [Print].
38GB
1 Press the
(Playback) button to switch to playback mode.
2 Select a movie with the control button.
Table of
contents
Viewing movies
3 Press z.
Movie playback starts.
Playback feature
z
Play/Stop
B
Fast forward
b
Fast rewind
V
Displays the volume control screen.
Note
• You may not be able to play back some images shot using other cameras.
zOn the movie viewing screen
MENU/Settings
Search
• Adjust the volume with v/V on the control button, then press
z.
Operation
Search
Control button
Select the image you want to display using b/B on the control button, and press z.
The Playback bar appears, you can check a playback position of a movie.
Index
,
or
appears on the movie viewing screen.
The icon displayed may vary depending on image size and quality.
Playback bar
39GB
Sets the direction to pan the camera when you shoot a Sweep Panorama images.
1 MENU t
(Shooting Direction) t desired direction
Pan from left to right.
(Left)
Pan from right to left.
(Up)
Pan from down to up.
(Down)
Pan from up to down.
Operation
Search
(Right)
Table of
contents
Shooting Direction
MENU/Settings
Search
Index
40GB
The image size determines the size of the image file that is recorded when you take a image.
The larger the image size, the more detail will be reproduced when the image is printed on largeformat paper. The smaller the image size, the more images can be recorded.
1 MENU t
Table of
contents
Image Size
(Image Size) t desired size
Image size
Usage guidelines
(4320×3240) For prints up to A3+ size
No. of
images
Printing
Fine
More
Rough
Less
Fine
More
Rough
MENU/Settings
Search
Less
Operation
Search
When shooting still images
(3648×2736)
(2592×1944) For prints up to L/2L/A4 size
Index
(640×480)
For e-mail attachments
(4320×2432) For viewing on a high-definition TV,
and for prints up to A3 size
(1920×1080) For viewing on a high-definition TV
Note
• When you print still images recorded with 16:9 aspect ratio, both edges may be cut off.
41GB
In Easy Shooting mode
Shoots images in [14M] size.
Small
Shoots images in [5M] size.
Table of
contents
Large
When shooting Sweep Panorama images
Operation
Search
(Standard)
Shoots images using standard size.
(Vertical: 3424×1920)
(Horizontal: 4912×1080)
(Wide)
Shoots images using wide size.
When shooting movies
The larger the image size, the higher the image quality. The higher the amount of data used per
second (average bit-rate), the smoother the playback image.
The movies shot with this camera will be recorded in MPEG-4, Approx. 30 fps, Progressive,
AAC, mp4 format.
Movie image size
Usage guidelines
1280×720(Fine)
9 Mbps
Shoots highest quality movie for display
on HDTV.
1280×720(Standard)
6 Mbps
Shoots standard quality movie for
display on HDTV.
VGA
3 Mbps
Shoots at an image size suitable for
WEB upload.
Index
Average bit-rate
MENU/Settings
Search
(Vertical: 4912×1920)
(Horizontal: 7152×1080)
Note
• A telephoto image results when the [VGA] image size is selected for movies.
42GB
Continued r
A digital image is made up of a collection of small dots called pixels.
If it contains a large number of pixels, the image becomes large, it takes up more memory,
and the image is displayed in fine detail. “Image size” is shown by the number of pixels.
Although you cannot see the differences on the screen of the camera, the fine detail and data
processing time differ when the image is printed or displayed on a computer screen.
Image size: 14M
4320 pixels × 3240 pixels = 13,996,800 pixels
2 Image size: VGA
640 pixels × 480 pixels = 307,200 pixels
1
Pixels
Many pixels
(Fine image quality and large file size)
Few pixels
(Rough image quality but small file size)
MENU/Settings
Search
Pixel
Operation
Search
Description of the pixels and the image size
Table of
contents
zOn “image quality” and “image size”
Index
43GB
In Easy Shooting mode, you can select the Flash setting also from the MENU button.
1 Set the mode dial to
(Easy Shooting).
Table of
contents
Flash
2 MENU t [Flash] t z on the control button
3 Select the desired mode.
Flash automatically operates in dark locations or when there is
backlight.
Off
Does not use the flash.
Operation
Search
Auto
MENU/Settings
Search
Index
44GB
You can select single-image mode or burst mode.
1 MENU t
(Single)
Shoots a single image.
Shoots up to 100 images in succession when you press and hold
down the shutter button.
Operation
Search
(Burst)
(Burst Settings) t desired mode
Table of
contents
Burst Settings
Notes
MENU/Settings
Search
Index
• The Burst mode is not available in Easy Shooting mode, Sweep
Panorama, Movie Mode, or smile shutter.
• The flash is set to [Off].
• When recording with the self timer, a series of a maximum of five
images is recorded.
• The recording interval becomes longer, depending on the setting for the
image size.
• When the battery level is low, or when the internal memory or the
memory card is full, the Burst stops.
• [Focus], [White Balance] and [EV] are adjusted for the first image, and
these settings are also used for the other images.
45GB
You can set the type of the bracket shooting. In the bracket shooting mode, you can record a
series of 3 images with the setting changed. You can select the most suitable image afterwards.
1 MENU t
(Bracket Settings) t desired mode
Does not use the bracket shooting.
(EXP±0.3)
Records a series of 3 images with the exposure shifted in the
following order: bright, standard, and dark.
The larger the bracket step value, the larger the shift of the
exposure value.
(EXP±1.0)
(White
Balance)
Operation
Search
(Off)
(EXP±0.7)
Table of
contents
Bracket Settings
Records a series of 3 images with the white balance shifted in the
following order: current color tone, toward blue, and toward red.
Notes
(Scene Selection).
Index
• You cannot select [White Balance] when the mode dial is set to
• You cannot select [Bracket Settings] in the following cases:
– In Intelligent Auto Adjustment mode
– In Easy Shooting mode
– In Movie Mode
– In Sweep Panorama mode
– When [Burst Settings] is set to [Burst]
– When the Smile Shutter function is activated
MENU/Settings
Search
• When you set [White Balance] to other than [Auto], the color tone is
shifted based on the selected white balance.
46GB
You can adjust the exposure manually in 1/3 EV steps in a range of –2.0 EV to +2.0 EV.
1 MENU t
(EV) t desired EV setting
Table of
contents
EV
Notes
zAdjusting the exposure for better looking images
Lower EV setting –
Correct exposure
MENU/Settings
Search
Overexposure = too much light
Whitish image
Operation
Search
• In Easy Shooting mode or Manual Exposure Shooting mode, the [EV] setting cannot be adjusted.
• If you shoot a subject in extremely bright or dark conditions, or when you use the flash, the exposure
adjustment may not be effective.
Higher EV setting +
Index
Underexposure = too little light
Darker image
47GB
Adjusts the luminous sensitivity when the camera is set to Program Auto, Manual Exposure
Shooting or
(Advanced Sports Shooting) in Scene Selection.
1 MENU t
(ISO) t desired mode
(Auto)
/
/
/
Sets the ISO sensitivity automatically.
/
You can reduce image blurring in dark locations or moving subjects
by increasing ISO sensitivity (select a larger number).
Notes
zAdjusting ISO Sensitivity (Recommended Exposure
Index)
High ISO sensitivity
Records a bright image even in dark locations while increasing
shutter speed to reduce blur.
However, the image tends to become noisy.
Index
ISO sensitivity is a speed rating for recording media that incorporates an image sensor that
receives light. Even when the exposure is the same, images differ depending on the ISO
sensitivity.
MENU/Settings
Search
• You cannot select [ISO AUTO] in Manual Exposure Shooting mode.
• You cannot select ISO settings other than [ISO AUTO], [ISO 80] to [ISO 800] in the following cases:
– When Burst/Bracket mode is selected
– When Scene Selection is set to
(Advanced Sports Shooting)
– When [DRO] is set to [DRO plus]
Operation
Search
/
/
Table of
contents
ISO
Low ISO sensitivity
Records a smoother image.
However, when the exposure is insufficient, the image may become
darker.
48GB
Continued r
Even though the camera is steady, the subject moves during the exposure and is captured
blurred when the shutter button is pressed. Camera shake is reduced automatically,
however, the function does not effectively reduce subject blur.
Subject blur occurs frequently under low-light or slow shutter speed conditions.
In such a case, shoot with the below tips in mind.
Operation
Search
• Select a higher ISO sensitivity to make the shutter
speed faster, and press the shutter button before the
subject moves.
• Select
(High Sensitivity) mode in Scene
Selection.
Table of
contents
zHints for preventing blur
MENU/Settings
Search
Index
49GB
Adjusts color tones according to the surrounding light conditions. Use this function if image
color appears unnatural.
1 MENU t
Table of
contents
White Balance
(White Balance) t desired mode
(Auto)
(Daylight)
Adjusts for outdoors conditions on a fine day, evening views, night
scenes, neon signs, fireworks, etc.
(Cloudy)
Adjusts for a cloudy sky or a shady location.
[Fluorescent White Balance 1]: Adjusts for white fluorescent
lighting.
[Fluorescent White Balance 2]: Adjusts for natural white
fluorescent lighting.
[Fluorescent White Balance 3]: Adjusts for day white fluorescent
lighting.
n
(Incandescent)
Adjusts for places under incandescent lamp, or under bright
lighting, such as in a photo studio.
Adjusts for the flash conditions.
(One Push)
Adjusts the white balance depending on the light source. The white
color memorized in [One Push Set] mode becomes the basic white
color. Use this mode when [Auto] or other modes cannot be set the
color properly.
(One Push
Set)
Memorizes the basic white color which will be used in [One Push]
mode.
Index
(Flash)
MENU/Settings
Search
(Fluorescent
White Balance 1)
(Fluorescent
White Balance 2)
(Fluorescent
White Balance 3)
Operation
Search
Adjusts the white balance automatically so that the colors appear
natural.
Notes
• [White Balance] cannot be adjusted in Intelligent Auto Adjustment, or Easy Shooting mode.
• [Flash] in [White Balance] cannot be adjusted in the following situations:
– In Sweep Panorama
– In Movie Mode
– When Scene Selection is set to
(High Sensitivity) mode.
• Under fluorescent lights that flicker, the white balance function may not work correctly even though you
select [Fluorescent White Balance 1], [Fluorescent White Balance 2], or [Fluorescent White Balance 3].
• When shooting with a flash in other than [Flash] mode, [White Balance] is set to [Auto].
• When flash is [On] or [Slow Synchro], the white balance can only be adjusted to [Auto], [Flash], [One
Push], or [One Push Set].
• [One Push Set] is unable to be selected while charging the flash.
50GB
1 Frame a white object such as a piece of paper filling the screen under the
same lighting conditions as you will shoot the subject.
2 MENU t
button
Table of
contents
To capture the basic white color in [One Push
Set] mode
(White Balance) t [One Push Set] t z on the control
Notes
zEffects of lighting conditions
The apparent color of the subject is affected by the lighting conditions.
The color tones are adjusted automatically, but you can adjust color tones manually using
the White Balance function.
Daylight
Cloudy
Fluorescent
Incandescent
Characteristics of
light
White (standard)
Bluish
Green-tinged
Reddish
Index
Weather/lighting
MENU/Settings
Search
• If the
indicator flashes while shooting, the white balance is either not set or cannot be set. Use
automatic white balance.
• Do not shake or strike the camera while [One Push Set] is in progress.
• When flash is set to [On] or [Slow Synchro], the white balance is adjusted to the condition with the flash
emitting.
Operation
Search
The screen momentarily turns black, and when the white balance has been adjusted and stored
in the memory, the recording screen is displayed again.
51GB
You can change the focus method. Use the menu when it is difficult to get the proper focus in
auto focus mode.
AF stands for “Auto Focus,” a function that adjusts the focus automatically.
1 MENU t
Table of
contents
Focus
(Focus) t desired mode
Focuses on a subject in all ranges of the
finder frame automatically.
When you press the shutter button halfway
down in still image shooting mode, a green
frame is displayed around the area that is in
focus.
Operation
Search
(Multi AF)
AF range finder frame
(Center AF)
MENU/Settings
Search
• When the Face Detection function is active, AF
operates with priority on faces.
Focuses on a subject in the center of the
finder frame automatically. Using the AF
lock function together, you can compose the
image the way you want.
AF range finder frame
(Spot AF)
Index
Focuses on an extremely small subject or a
narrow area automatically. Using the AF
lock function together, you can compose the
image the way you want. Hold the camera
steady so as not to misalign the subject and
the AF range finder frame.
AF range finder frame
Notes
• When you use [Digital Zoom] or [AF Illuminator], the AF range finder frame is disabled and appears in a
dotted line. In this case, the camera works to focus on the subjects at the center of the screen.
• When the focus mode is set to other than [Multi AF], you cannot use the Face Detection function.
• The focus mode is fixed to [Multi AF] in the following situations:
– In Intelligent Auto Adjustment mode
– In Easy shooting mode
– In Movie Mode
– When the Smile Shutter function is activated
– When the self-timer is set to [Self-portrait One Person] or [Self-portrait Two People]
52GB
Continued r
If the subject is out of focus, do as follows:
AF range finder
frame
2When the AE/AF lock indicator stops flashing and
remains on, return to the fully composed shot, and
press the shutter button fully down.
• As long as you do not press the shutter button fully
down, you can retry the procedure as many times as
necessary.
Operation
Search
AE/AF lock
indicator
1Recompose the shot so that the subject is centered
in the AF range finder, and press the shutter
button halfway to focus on the subject (AF lock).
Table of
contents
zFocusing on subjects near the edge of the screen
MENU/Settings
Search
Index
53GB
Selects the metering mode that sets which part of the subject to measure to determine the
exposure.
1 MENU t
Table of
contents
Metering Mode
(Metering Mode) t desired mode
(Center)
Measures the center of the image, and determines the exposure
based on the brightness of the subject there (Center-weighted
metering).
(Spot)
Measures only a part of the subject
(Spot metering). This function is useful
when the subject is backlit or when
there is strong contrast between the
subject and the background.
Spot metering cross
hairs
Positions on the subject
MENU/Settings
Search
Divides into multiple regions and measures each region. The
camera determines a well-balanced exposure (Multi-pattern
metering).
Operation
Search
(Multi)
Notes
Index
• In Movie Mode, [Spot] cannot be selected.
• If you set Metering Mode to other than [Multi], the Face Detection function cannot be used.
• Metering Mode is fixed to [Multi] in the following situations:
– In Intelligent Auto Adjustment
– In Easy Shooting mode
– When the Smile Shutter function is activated
– When the self-timer is set to [Self-portrait One Person] or [Self-portrait Two People]
54GB
In Intelligent Auto Adjustment mode, the camera automatically detects shooting conditions, and
then takes the shot. When motion is detected, the ISO sensitivity is increased according to the
movement to reduce subject blur (Motion Detection).
Table of
contents
Scene Recognition
Example of an image where
(Backlight) has activated.
Scene Recognition icon and guide
(Twilight),
(Twilight Portrait),
(Twilight
using a tripod),
(Backlight),
(Backlight
Portrait),
(Landscape),
(Macro),
(Portrait)
2 MENU t
(Auto)
(Advanced)
(Intelligent Auto Adjustment).
(Scene Recognition) t desired mode
When the camera recognizes the scene, it switches to the optimal
settings and shoots the image.
• When you shoot two images consecutively, the + mark on the
icon
will turn green.
• When two frames are shot, the two images are displayed side by side
immediately after shooting.
• When [Anti Blink] is displayed, 2 images are taken automatically and
the image with eyes are open is selected automatically. For details on the
Anti Blink function, see “What is the Anti Blink function?”.
Index
When the camera recognizes the scene, it switches to the optimal
settings. If the camera recognizes (Twilight), (Twilight
Portrait),
(Twilight using a tripod), (Backlight) or
(Backlight Portrait), it automatically changes the setting and
shoots another image.
MENU/Settings
Search
1 Set the mode dial to
Operation
Search
The camera recognizes the following types of scenes.
When the camera determines the optimal scene, it
displays the corresponding icon and guide.
Notes
• Scene Recognition does not function when using digital zoom.
• Scene Recognition is fixed to [Auto] in the following situations:
– During burst shooting
– When the Smile Shutter function is activated
– When the self-timer is set to [Self-portrait One Person] and [Self-portrait Two People]
• The available flash settings are [Auto] and [Off].
•
(Twilight using a tripod) scenes sometimes cannot be recognized in an environment where vibrations
are transferred to the camera even though it is fixed on a tripod.
• Sometimes a slow shutter results when a scene is recognized as a
(Twilight using a tripod). Keep the
camera still during shooting.
• These scenes may not be recognized depending on the situation.
55GB
Continued r
more convenient! ([Advanced])
In [Advanced], when the camera recognizes a difficult-to-shoot scene ( (Twilight),
(Twilight Portrait),
(Twilight using a tripod), (Backlight) and (Backlight
Portrait)), it changes the settings as follows and shoots two images with different effects,
allowing you to select the one you like.
Shoots in Slow Synchro
Shoots with sensitivity increased and shake
reduced
Shoots in Slow Synchro with the face
which the flash strobes on as guide
Shoots with sensitivity increased with the face as
guide and shake reduced
Shoots in Slow Synchro
Shoots with even slower shutter speed without
increasing sensitivity
Shoots with the flash
Shoots with the brightness and contrast of the
background adjusted (DRO plus)
Shoots with the face which the flash
strobes on as guide
Shoots with the brightness and contrast of the
face and the background adjusted (DRO plus)
* When flash is set to [Auto].
MENU/Settings
Search
Second Image
Operation
Search
First Image*
Table of
contents
z Shooting twice, choosing the best image later - it’s
zWhat is the Anti Blink function?
Index
When set to [Advanced], the camera automatically shoots two images consecutively* when
it recognizes
(Portrait). The camera will select, display, and record the image which the
eyes are not blinked automatically. If the eyes are closed in both images, the message
“Blinked eye detected” is displayed.
* except when the flash strobes/when the shutter speed is slow
56GB
Sets the sensitivity of the Smile Shutter function for detecting smiles.
1 MENU t
(Smile Detection Sensitivity) t desired mode
(Big Smile)
Detects a big smile.
Detects a normal smile.
(Slight Smile) Detects even a slight smile.
Notes
MENU/Settings
Search
• Smiles may not be detected correctly depending on the conditions.
• [Smile Detection Sensitivity] cannot be adjusted in the following situations:
– In Easy Shooting mode
– In Sweep Panorama
– In Movie Mode
Operation
Search
(Normal
Smile)
Table of
contents
Smile Detection Sensitivity
Index
57GB
Detects the faces of your subjects and adjusts the focus, flash, exposure, white balance and redeye reduction settings automatically.
Face Detection frame (Orange)
Face Detection frame (White)
1 MENU t
(Auto)
Does not use Face Detection function.
Selects the face the camera is to automatically focus on.
(Child
Priority)
Detects and shoots with priority on child’s face.
(Adult
Priority)
Detects and shoots with priority on adult’s face.
MENU/Settings
Search
(Off)
(Face Detection) t desired mode
Operation
Search
When the camera detects more than one subject, the camera will judge which is the main
subject and set focus by priority. The Face Detection frame for the main subject will turn
orange. The frame for which the focus is set will turn green by pressing the shutter button
halfway down.
Table of
contents
Face Detection
Notes
Index
• [Face Detection] cannot be selected in the following situations:
– In Easy Shooting mode
– In Movie Mode
– In Sweep Panorama mode
• You cannot select [Off] when the self-timer is set to [Self-portrait One Person] or [Self-portrait Two
People].
• You can select [Face Detection] only when the focus mode is set to [Multi AF] or the metering mode is
set to [Multi].
• The Face Detection function does not work when using the digital zoom.
• Up to 8 faces of your subjects can be detected.
• Adults and children may not be recognized correctly depending on the conditions.
• During Smile Shutter shooting, [Face Detection] is automatically set to [Auto] even if it is set to [Off].
58GB
Continued r
Normally the camera automatically selects the face to focus on according to the [Face
Detection] setting, but you can also select a face to be given priority.
1Press z on the control button during Face Detection. The leftmost face is selected as the
priority face, and the frame changes from
to an orange frame ( ).
Operation
Search
Face Priority Frame Off
Table of
contents
zSelecting the priority face
2Each time you press z, the priority face moves one face to the right. Press z repeatedly
until the orange frame ( ) is on the face you want to select.
• It may not be possible to detect the selected face correctly depending on the surrounding brightness,
the subject’s hairstyle, etc. In this case, select the face again under the conditions where the image
will be shot.
• When the Smile Shutter function is used with the Face Detection frame selected, Smile Detection is
performed only on the selected face.
• You cannot select the priority face in Easy Shooting mode, Manual Exposure Shooting mode or
when the self-timer is set to [Self-portrait One Person] or [Self-portrait Two People].
MENU/Settings
Search
3To cancel the face selection (Off), move the orange frame to the rightmost face, then
press z again.
Index
59GB
In Program Auto or Manual Exposure Shooting mode, the camera analyzes the shooting scene
and automatically corrects the brightness and contrast to improve the image quality.
DRO stands for “Dynamic Range Optimizer,” a function that automatically optimizes the
difference between light and dark parts of an image.
1 MENU t
Table of
contents
DRO
(DRO) t desired mode
(DRO
standard)
(DRO plus)
Does not adjust.
Adjusts the brightness and contrast of the images automatically.
Operation
Search
(Off)
Adjusts image brightness and contrast automatically and strongly.
• Depending on shooting conditions, it may not be possible to obtain correction effects.
• Only [ISO AUTO] or values from [ISO 80] to [ISO 800] can be set for the ISO value when [DRO plus] is
set.
MENU/Settings
Search
Notes
Index
60GB
When Scene Selection is set to
(Soft Snap) while you are shooting an image, the camera
automatically shoots two images consecutively. The camera will select, display and record the
image which the eyes are not blinked automatically.
1 Set the mode dial to
(Scene Selection).
(Soft Snap).
3 MENU t
(Anti Blink) t desired mode
(Auto)
When Face Detection is active, the Anti Blink function operates so
that images with the subject’s eyes open are recorded.
(Off)
Does not use the Anti Blink function.
• [Anti Blink] does not function in the following situations:
– When using the flash
– When Burst mode is selected
– When the Face Detection function does not work
– When the Smile Shutter function is activated
• Sometimes the Anti Blink function does not work depending on the situation.
• When the Anti Blink function is set to [Auto] but only images with the subject’s eyes closed are
recorded, the message “Blinked eye detected” is displayed on the LCD screen. Shoot again as necessary.
MENU/Settings
Search
Notes
Operation
Search
2 Select
Table of
contents
Anti Blink
Index
61GB
In Movie Mode, you can vary the strength of SteadyShot.
1 Set the mode dial to
2 MENU t
(Movie Mode).
Table of
contents
SteadyShot
(SteadyShot) t desired mode
Provides the SteadyShot effect under stable recording conditions.
(Active)
Provides a more powerful SteadyShot effect.
Operation
Search
(Standard)
MENU/Settings
Search
Index
62GB
Images are automatically played back in succession.
1 Press the
(Playback) button to switch to playback mode.
2 MENU t
button
(Slideshow) t desired slideshow t z on the control
(Slideshow with music)
Plays back all the images in succession.
Plays back images in succession, with added effects and
music.
1 Select the desired image for playing with the control button.
2 MENU t
(Slideshow) t [Continuous Playback] t z
Playback feature
z
Stop
v
Sets the display settings.
V
Displays the volume control screen.
• Adjust the volume with v/V on the control button, then press
z.
b
Rewinds image.
B
Forwards image.
Index
Control button
MENU/Settings
Search
Continuous Playback
Operation
Search
(Continuous Playback)
Table of
contents
Slideshow
zViewing panoramic images during continuous
playback
The whole panoramic image is displayed for 3 seconds.
You can scroll a panoramic image by pressing z.
Press z again while scrolling, the screen returns to the whole panoramic image.
63GB
Slideshow with music
(Slideshow) t [Slideshow with music] t z on the control
Displays the setting screen.
Table of
contents
1 MENU t
button
2 Select a desired setting.
3 [Start] t z
Operation
Search
4 Press z to end the slideshow.
Notes
• You cannot play back movies or panoramic images.
• Settings other than [Image] are stored until the next time they are changed.
All
Plays a slideshow of all the images in order.
This Date
Plays a slideshow of images with the currently selected date range
when View Mode is [Date View].
Folder
Plays a slideshow of images in the currently selected folder when
View Mode is Folder View.
MENU/Settings
Search
Selects the group of images to be shown.
Note
Index
• This setting is fixed to [Folder] when the internal memory is used to record images.
Effects
Selects the playback speed and mood for slideshows.
Simple
A simple slideshow switching images at a preset interval.
The playback interval is adjustable in [Interval] and you can
thoroughly enjoy your images.
Nostalgic
A moody slideshow reproducing the atmosphere of a movie scene.
Stylish
A stylish slideshow proceeding at a middle tempo.
Active
A high-tempo slideshow suitable for active scenes.
64GB
Continued r
The default setting for a [Simple] slideshow.
Music2
The default setting for a [Nostalgic] slideshow.
Music3
The default setting for a [Stylish] slideshow.
Music4
The default setting for a [Active] slideshow.
Mute
Does not use BGM.
Interval
Sets the screen switching interval. The setting is fixed to [Auto] when [Simple] is not selected
as the [Effects].
Sets the display interval of images for a [Simple] slideshow.
3 sec
5 sec
10 sec
Auto
The interval is set to suit the selected [Effects] item.
MENU/Settings
Search
1 sec
Operation
Search
Music1
Table of
contents
Music
Specifies the music to be played during slideshows. You can select more than one background
music track. Press V on the control button to display the volume control screen, then press
v/V to adjust the volume.
Repeat
Turns slideshow repeat on or off.
Plays back images in a continuous loop.
Off
After all the images have been played back, the slideshow ends.
Index
On
zSelecting background music
You can transfer a desired music file from your CDs or MP3 files to the camera to play back
during slideshow. To transfer music, install the “Music Transfer” software (supplied) to
your computer. For details, see pages 104 and 105.
• You can record up to four pieces of music on the camera (The 4 preset pieces (Music1 – Music4)
can be replaced with the ones you transferred).
• The maximum length of each music file for music playback of the camera is about 5 minutes.
• If you cannot play back a music file due to damage or other malfunctions of the file, execute
[Format Music] (page 90) and transfer the music again.
65GB
Allows you to select the display format for images.
1 Press the
2 MENU t
(Playback) button to switch to playback mode.
(View Mode) t desired mode t z on the control button
Displays images by the date.
(Folder view
(Still))
Displays only still images.
(Folder view
(Movie))
Displays only movie files.
• When using the internal memory, the view mode is set to Folder View and still images and movies are
played from the same folder.
• Event View is not available on this camera.
Displaying the Calendar
2 Turn the
MENU/Settings
Search
Notes
Operation
Search
(Date View)
1 MENU t
Table of
contents
View Mode
(View Mode) t [Date View] t z on the control button
(Index) lever repeatedly until the Calendar is displayed.
Index
Use the control button to select / , then select the month you want to display. Select the
date and press z to view images of the selected date in index mode.
zViewing images taken with a different camera
This camera creates a database file in a memory card and registers every shot image to it for
later playback. If the camera detects images that have not been registered to the database file
in the memory card, the registration screen “Files found which were not recognized Import
files” appears.
If you want to view unregistered images, select [OK] to register the images.
• For registration, use a fully charged battery pack. If you attempt to register unregistered files using a
battery pack with little remaining charge, the battery pack may run out, causing copying to fail or
possibly corrupting the data.
66GB
Retouches a recorded image and saves it as a new file. The original image is retained.
1 Press the
2 MENU t
(Playback) button to switch to playback mode.
Table of
contents
Retouch
(Retouch) t desired mode t z on the control button
3 Perform retouching according to the operation method in each mode.
Records the zoomed playback
image.
(Red Eye
Correction)
Corrects the red-eye phenomenon
caused by flash.
Select [OK] with the control
button t z.
• You may not be able to correct the
red-eye phenomenon depending on the image.
1
Sharpens the image within a
chosen frame.
Select the area (frame) of the
desired image to retouch with the
control button t MENU.
2 [OK] t z
• Depending on the image, sufficient
correction may not be applied and
the image quality may deteriorate.
1
Index
(Unsharp
masking)
MENU/Settings
Search
Turn the lever to (T) to zoom in
and turn to (W) to zoom out.
2 Set the zoom point with the control
button.
3 MENU t select an image size to save t z
4 [OK] t z
• The quality of trimmed images may deteriorate.
• The image size that you can trim may vary depending on the image.
1
Operation
Search
(Trimming
(Resize))
Note
• You cannot retouch movies or panoramic images.
67GB
Allows you to select unwanted images for deletion.
You can also delete images using the (Delete) button (page 38).
1 Press the
2 MENU t
(Playback) button to switch to playback mode.
(Delete) t desired mode t z on the control button
(This Image)
Deletes the currently displayed image in single-image mode.
(Multiple Images) You can select and delete multiple images.
Do as the following after step 2.
2MENU t [OK] t z
Deletes all images in date range, or the selected folder at once.
MENU/Settings
Search
1Select an image then press z.
Repeat the above step until there are no more images to be
deleted. Select an image with a
mark to release the
mark.
Operation
Search
3 [OK] t z
(All in Date
Range)
(All in This
Folder)
Table of
contents
Delete
Notes
Index
• In Easy Viewing mode, you can select between [Delete Single Image] or [Delete All Images].
• When the internal memory is used to record images, View Mode is set to Folder View.
68GB
Protects recorded images against accidental erasure.
The
mark is displayed for registered images.
1 Press the
(Playback) button to switch to playback mode.
2 MENU t
(Protect) t desired mode t z on the control button
(Multiple
Images)
Protects the currently displayed image in single-image mode.
You can select and protect multiple images.
Do as the following after step 2.
2MENU t [OK] t z
Note
• When the internal memory is used to record images, View Mode is set to Folder View.
zTo cancel the protection
Index
Select the image for which you want to cancel protection, and unlock it by pressing z on
the control button as the same procedure to protect it.
The
indicator disappears, and the protection is released.
MENU/Settings
Search
1Select an image then press z.
Repeat the above step until there are no more images to be
protected. Select an image with a
mark to release the
mark.
Operation
Search
(This Image)
Table of
contents
Protect
69GB
DPOF (Digital Print Order Format) is a function that allows you to specify the images of the
memory card that you want to print out later.
The
(Print order) mark is displayed for registered images.
(Playback) button to switch to playback mode.
2 MENU t
t desired mode t z on the control button
(This Image)
(Multiple
Images)
Orders printing the currently displayed image in single-image
mode.
You can select and order printing multiple images.
Do as the following after step 2.
2MENU t [OK] t z
Notes
• The
(Print order) mark cannot be added to movies or to images in the internal memory.
• You can add a
(Print order) mark to a maximum 999 images.
Select the image to clear the DPOF registration, then press z on the control button in the
same procedure as when making a
mark.
The
mark disappears and the DPOF registration is cleared.
Index
zClearing the DPOF mark
MENU/Settings
Search
1Select an image then press z.
Repeat the above step until there are no more images to be
printed. Select an image with a
mark to release the
mark.
Operation
Search
1 Press the
Table of
contents
DPOF
70GB
Rotates a still image. Use this to display a horizontal orientation image in vertical orientation.
2 MENU t
(Playback) button to switch to playback mode.
(Rotate) t z on the control button
Operation
Search
1 Press the
Table of
contents
Rotate
3 Rotate the image with [ / ] t b/B.
Notes
• You cannot rotate movies or protected still images.
• You may not be able to rotate images shot with other cameras.
• When viewing images on a computer, the image rotation information may not be reflected depending on
the software.
MENU/Settings
Search
4 [OK] t z
Index
71GB
When multiple folders are created in a memory card, this selects the folder containing the image
you want to play back.
1 Press the
(Playback) button to switch to playback mode.
(Select Folder) t z
4 Select the folder with b/B.
5 [OK] t z
zViewing images across multiple folders
When multiple folders are created, the following indicators appear on the first and last
images in the folder.
: Moves to the previous folder
: Moves to the next folder
: Moves to either the previous or next folders
MENU/Settings
Search
Note
• This item is not displayed when the internal memory is used to record images.
Operation
Search
2 MENU t
(View Mode) t [Folder view (Still)] or [Folder view
(Movie)] t z on the control button
3 MENU t
Table of
contents
Select Folder
Index
72GB
The AF illuminator supplies fill light to focus more easily on a subject in dark surroundings.
The AF illuminator emits red light allowing the camera to focus easily when the shutter button is
pressed halfway, until the focus is locked. The
indicator appears at this time.
Table of
contents
AF Illuminator
1 Set the camera to shooting mode.
Auto
Uses the AF illuminator.
Off
Does not use the AF illuminator.
Index
• Focus is achieved as long as the AF illuminator light reaches the subject, regardless of whether light fails
to reach the center of the subject.
• You cannot use the AF illuminator when:
– In Sweep Panorama mode
–
(Advanced Sports Shooting),
(Landscape), (Twilight),
(Pet) or (Fireworks) mode is
selected in Scene Selection.
– The self-timer is set to [Self-portrait One Person] or [Self-portrait Two People].
• When you use the AF illuminator, the normal AF range finder frame is disabled and a new AF range
finder frame is displayed by a dotted line. AF operates with priority on subjects located near the center of
the frame.
• The AF illuminator emits very bright light. Although there is no health hazard, do not look directly into
the AF illuminator emitter at close range.
MENU/Settings
Search
Notes
Operation
Search
2 MENU t
(Settings) t
(Shooting Settings) t [AF Illuminator] t
desired mode t z on the control button
73GB
With reference to the grid lines, you can easily set a subject in a horizontal/vertical position.
1 Set the camera to shooting mode.
Table of
contents
Grid Line
2 MENU t
(Settings) t
(Shooting Settings) t [Grid Line] t
desired mode t z on the control button
Displays the grid lines. The grid lines are not recorded.
Off
Does not display the grid lines.
Operation
Search
On
MENU/Settings
Search
Index
74GB
Selects the display quality on the LCD screen for shooting.
1 Set the camera to shooting mode.
Table of
contents
Disp. Resolution
2 MENU t
(Settings) t
(Shooting Settings) t [Disp. Resolution]
t desired mode t z on the control button
Displays a standard-quality image for shooting.
High
Displays a high-quality image for shooting.
Notes
MENU/Settings
Search
• The battery charge is used up more quickly when [Disp. Resolution] is set to [High].
• In Sweep Panorama and Movie Mode, [Disp. Resolution] is set to [High].
• In Easy Shooting mode, [Disp. Resolution] is set to [Standard].
Operation
Search
Standard
Index
75GB
Selects the digital zoom mode. The camera enlarges the image using optical zoom (up to 10×).
When the zoom scale is exceeded, the camera uses either smart or precision digital zoom.
Table of
contents
Digital Zoom
1 Set the camera to shooting mode.
Smart (
)
Precision (
)
Enlarges all image sizes by the total zoom scale of approximately
20× including the optical zoom 10×. However, note that the image
quality deteriorates when the optical zoom scale is exceeded
(Precision digital zoom).
Does not use the digital zoom.
Notes
Index
• The Digital Zoom function does not operate in the following situations:
– When the Scene Selection is set to
(Advanced Sports Shooting)
– In Movie Mode
– In Sweep Panorama mode
– When the Smile Shutter function is activated
– When the self-timer is set to [Self-portrait One Person] or [Self-portrait Two People]
• The smart zoom is not available when the image size is set to [14M], or [16:9(11M)].
• The Face Detection function does not work when using the digital zoom.
MENU/Settings
Search
Off
Enlarges the image digitally within the range where the image will
not be distorted, according to the image size (Smart zoom).
Operation
Search
2 MENU t
(Settings) t
(Shooting Settings) t [Digital Zoom] t
desired mode t z on the control button
Total zoom scale when using Smart zoom
(including optical zoom 10×)
The supported zoom ratio differs depending on the image size.
Size
Total zoom scale
10M
Approx. 11×
5M
Approx. 16×
VGA
Approx. 67×
16:9(2M)
Approx. 22×
76GB
When the camera is rotated to shoot a portrait (vertical) image, the camera records its position
change and displays the image in the portrait position.
Table of
contents
Auto Orientation
1 Set the camera to shooting mode.
On
Records the image with the correct orientation.
Off
Does not use Auto Orientation.
Operation
Search
2 MENU t
(Settings) t
(Shooting Settings) t [Auto Orientation]
t desired mode t z on the control button
Notes
zRotating images after recording
If the orientation of an image is incorrect, you can use the [Rotate] on the Menu screen to
display the image in portrait position.
MENU/Settings
Search
• Black is displayed to the left and right of vertical orientation images.
• Depending on the shooting angle of the camera, the orientation of the image may not be recorded
correctly.
• You cannot use Auto Orientation in Movie Mode.
Index
77GB
The flash strobes two or more times before shooting to reduce the red-eye phenomenon when
using the flash.
Table of
contents
Red Eye Reduction
1 Set the camera to shooting mode.
Auto
When the Face Detection function is activated, the flash strobes
automatically to reduce the red-eye phenomenon.
On
The flash always strobes to reduce the red-eye phenomenon.
Off
Does not use Red Eye Reduction.
zWhat causes the red-eye phenomenon?
Index
• To avoid blurring of images, hold the camera firmly until the shutter is released. It usually takes a second
until the shutter is released, and also be sure not to allow the subject to move during this period.
• Red Eye Reduction may not produce the desired effects. It depends on individual differences and
conditions, such as distance to the subject, or if the subject looked away from the pre-strobe.
• If you do not use the Face Detection function, Red Eye Reduction does not work, even when you select
[Auto].
• [Red Eye Reduction] is set to [Off] in the following situations:
– When Scene Selection is set to
(High Sensitivity) mode
– When the Smile Shutter function is activated
MENU/Settings
Search
Notes
Operation
Search
2 MENU t
(Settings) t
(Shooting Settings) t [Red Eye
Reduction] t desired mode t z on the control button
Pupils become dilated in dark environments. Flash light is reflected off the blood vessels at
the back of the eye (retina), causing the “red-eye” phenomenon.
Camera
Eye
Retina
Other ways to reduce red-eye
• Select
(High Sensitivity) mode in Scene Selection. (The flash is set to [Off] automatically.)
• When the eyes of the subject turn out red, correct the image with [Retouch] t [Red Eye
Correction] on the viewing menu or with the supplied software “PMB”.
78GB
When an image with the subject’s eyes closed is recorded while Face Detection is activated, the
message “Blinked eye detected” is displayed.
Table of
contents
Blink Alert
1 Set the camera to shooting mode.
Auto
Displays the “Blinked eye detected” message.
Off
Does not display the message.
Operation
Search
2 MENU t
(Settings) t
(Shooting Settings) t [Blink Alert] t
desired mode t z on the control button
MENU/Settings
Search
Index
79GB
Selects or turns off the sound produced when you operate the camera.
1 MENU t
(Settings) t
(Main Settings) t [Beep] t desired
mode t z on the control button
Turns on the shutter sound when you press the shutter button.
High
Low
Turns on the beep/shutter sound when you press the control/shutter
button.
If you want to lower the volume, select [Low].
Off
Turns off the beep/shutter sound.
Operation
Search
Shutter
Table of
contents
Beep
MENU/Settings
Search
Index
80GB
Selects the language to be used in the menu items, warnings and messages.
1 MENU t
(Settings) t
(Main Settings) t [Language Setting] t
desired mode t z on the control button
Table of
contents
Language Setting
Operation
Search
MENU/Settings
Search
Index
81GB
You can select whether or not the function guide is displayed when you operate the camera.
1 MENU t
(Settings) t
(Main Settings) t [Function Guide] t
desired mode t z on the control button
Displays the function guide.
Off
Does not display the function guide.
Operation
Search
On
Table of
contents
Function Guide
MENU/Settings
Search
Index
82GB
You can set whether to use a demonstration of the Smile Shutter and Scene Recognition.
When there is no need to view a demonstration, set to [Off].
Table of
contents
Demo Mode
1 MENU t
(Settings) t
(Main Settings) t [Demo Mode] t
desired mode t z on the control button
Demonstrates Scene Recognition mode.
Demo Mode2
Automatically starts the Smile Shutter demonstration when no
operation is performed for 15 seconds.
Off
Does not perform a demonstration.
MENU/Settings
Search
Note
• Pressing the shutter button during the Smile Shutter demonstration operates the shutter, but no image is
recorded.
Operation
Search
Demo Mode1
Index
83GB
Initializes the setting to the default setting.
Even if you execute this function, the images are retained.
1 MENU t
(Settings) t
z on the control button
Table of
contents
Initialize
(Main Settings) t [Initialize] t [OK] t
Operation
Search
Note
• Be sure not to turn off the camera while initializing.
MENU/Settings
Search
Index
84GB
Selects the video output signal type from SD and HD(1080i) when you connect the camera and
TV using an HD Output Adaptor Cable (sold separately), according to the TV connected.
Use a Type2b-compliant HD Output Adaptor Cable (sold separately).
Table of
contents
COMPONENT
1 MENU t
(Settings) t
(Main Settings) t [COMPONENT] t
desired mode t z on the control button
Select this item to connect the camera to a 1080i-capable High
Definition TV.
SD
Select this item to connect the camera to a TV that is not
compatible with an HD(1080i) signal.
MENU/Settings
Search
Note
• When shooting movies in the condition with the camera and a TV connected using an HD Output
Adaptor Cable (sold separately), the image being shot is not displayed in the TV side.
Operation
Search
HD(1080i)
Index
85GB
Sets the video signal output according to the TV color system of the connected video equipment.
The TV color systems differ depending on the country and region.
To view images on a TV screen, check the TV color system of the country or region of use
(page 102).
NTSC
Sets the video output signal to NTSC mode (e.g., for the USA,
Japan).
PAL
Sets the video output signal to PAL mode (e.g., for Europe, China).
Operation
Search
1 MENU t
(Settings) t
(Main Settings) t [Video Out] t desired
mode t z on the control button
Table of
contents
Video Out
MENU/Settings
Search
Index
86GB
Selects the USB mode when connecting the camera to a computer or a PictBridge-compliant
printer using the cable for multi-use terminal.
Table of
contents
USB Connect
1 MENU t
(Settings) t
(Main Settings) t [USB Connect] t
desired mode t z on the control button
PictBridge
Connects the camera to a PictBridge-compliant printer.
PTP/MTP
When you connect the camera to a computer, the AutoPlay Wizard
appears, and the still images in the recording folder on the camera
are imported to the computer. (with Windows 7/Vista/XP,
Mac OS X)
Mass Storage
Establishes a Mass Storage connection between the camera and a
computer or other USB device.
Notes
Index
• If you cannot connect the camera to a PictBridge-compliant printer with the [Auto] setting, select
[PictBridge].
• If you cannot connect the camera to a computer or a USB device with the [Auto] setting, select [Mass
Storage].
• When [USB Connect] is set to [PTP/MTP], you cannot export movies to a computer. To export movies to
a computer, set [USB Connect] to [Auto] or [Mass Storage].
MENU/Settings
Search
The camera recognizes automatically and sets up communication
with a computer or PictBridge-compliant printer.
Operation
Search
Auto
87GB
Sets the display method for the recording media displayed on a computer screen or other monitor
when the camera is connected with a computer or AV component using a USB connection.
Table of
contents
LUN Settings
1 MENU t
(Settings) t
(Main Settings) t [LUN Settings] t
desired mode t z on the control button
Single
When the memory card is inserted into the camera, the images on
the memory card are displayed; when it is not inserted, the images
in the internal memory are displayed. Select this setting in cases
where the images of both the memory card and the internal memory
are not displayed when the camera is connected to a device other
than a computer.
Note
• You must always select [Multi] in [LUN Settings] when uploading images to a media service using
“PMB Portable”.
MENU/Settings
Search
The images both on the memory card and in the internal memory
are displayed. Select this setting when you connect the camera to a
computer.
Operation
Search
Multi
Index
88GB
You can use “Music Transfer” in the CD-ROM (supplied) to change background music tracks.
1 MENU t
(Settings) t
z on the control button
(Main Settings) t [Download Music] t
Table of
contents
Download Music
The message “Connect to PC” appears.
3 Follow the instructions on the screen to change music files.
Operation
Search
2 Make a USB connection between the camera and a computer, then start
“Music Transfer”.
MENU/Settings
Search
Index
89GB
You can delete all the background music files stored in the camera. It can be used in cases such
as when the background music files are damaged and cannot be played.
1 MENU t
(Settings) t
t z on the control button
Table of
contents
Format Music
(Main Settings) t [Format Music] t [OK]
camera
You can use “Music Transfer” in the CD-ROM (supplied) to reset music files to the preset
ones.
2Start “Music Transfer”, then restore the default music.
• For details on using “Music Transfer”, see the help in “Music Transfer”.
MENU/Settings
Search
1Execute [Download Music] and make a USB connection between the camera and a
computer.
Operation
Search
zRestoring the music preset at the factory to the
Index
90GB
Sets the time until the screen darkens, and the camera turns off. If you do not operate the camera
running on a battery pack for a certain amount of time, the brightness level on the LCD screen
becomes dark, and then the camera automatically turns off to prevent wearing down the battery
pack (Auto Power off).
The LCD screen darkens after about 30 seconds of no operation.
The camera turns off after another 30 seconds of no operation.
Standard
The LCD screen darkens after 1 minute of no operation. The
camera turns off after another 1 minute of no operation.
Off
The LCD screen does not darken and the camera does not turn off
automatically.
MENU/Settings
Search
Stamina
Operation
Search
1 MENU t
(Settings) t
(Main Settings) t [Power Save] t
desired mode t z on the control button
Table of
contents
Power Save
Index
91GB
Formats the memory card or the internal memory. When you use a memory card with this
camera for the first time, it is recommended to format the card using the camera for stable
performance of the memory card before shooting. Note that formatting permanently erases all
data on the memory card, and is unrecoverable. Save precious data on a computer, etc.
Note
• Note that formatting permanently erases all data including even protected images.
Operation
Search
1 MENU t
(Settings) t
(Memory Card Tool) or
(Internal
Memory Tool) t [Format] t [OK] t z on the control button
Table of
contents
Format
MENU/Settings
Search
Index
92GB
Creates a folder in the memory card for recording images.
Images are recorded in the newly created folder until you create another folder or select another
recording folder.
Table of
contents
Create REC.Folder
1 MENU t
(Settings) t
(Memory Card Tool) t [Create
REC.Folder] t [OK] t z on the control button
After a new folder is created, you can change the storage destination folder (page 94) and
select the folder for viewing images (page 72).
MENU/Settings
Search
zOn the folders
Operation
Search
Notes
• This item is not displayed when the internal memory is used to record images.
• When you insert a memory card that was used with other equipment into the camera and shoot images, a
new folder may be automatically created.
• Up to 4,000 images can be stored in one folder. When the folder capacity is exceeded, a new folder is
automatically created.
Index
93GB
Changes the folder in the memory card that is currently used for recording images.
1 MENU t
(Settings) t
REC.Folder]
(Memory Card Tool) t [Change
Table of
contents
Change REC.Folder
2 Select a folder with b/B on the control button.
Notes
MENU/Settings
Search
• This item is not displayed when the internal memory is used to record images.
• The following folder cannot be selected as a recording folder.
– “100” folder
– A folder with a number that has only either “sssMSDCF” or “sssMNV01”.
• You cannot move recorded images to another folder.
Operation
Search
3 [OK] t z
Index
94GB
Deletes a folder for recording images in the memory card.
1 MENU t
(Settings) t
REC.Folder]
(Memory Card Tool) t [Delete
Table of
contents
Delete REC.Folder
2 Select a folder with b/B on the control button.
Notes
MENU/Settings
Search
• This item is not displayed when the internal memory is used to record images.
• If you delete the folder set as the recording folder using [Delete REC.Folder], the folder that has the
largest folder number is selected as the next recording folder.
• You can delete only empty folders. If a folder contains images, or files that cannot be played back by the
camera, first delete these images and files, and then delete the folder.
Operation
Search
3 [OK] t z
Index
95GB
Copies all images in the internal memory to a memory card.
1 Insert a memory card with sufficient free capacity into the camera.
2 MENU t
(Settings) t
t z on the control button
Table of
contents
Copy
(Memory Card Tool) t [Copy] t [OK]
MENU/Settings
Search
• Use a fully charged battery pack. If you attempt to copy image files using a battery pack with little
remaining charge, the battery pack may run out, causing copying to fail or possibly corrupting the data.
• Images cannot be copied individually.
• The original images in the internal memory are retained even after copying. To delete the contents of the
internal memory, remove the memory card after copying, then format the internal memory ([Format] in
[Internal Memory Tool]).
• A new folder is created on the memory card and all the data will be copied to it. You cannot choose a
specific folder and copy images to it.
Operation
Search
Notes
Index
96GB
Selects the method used to assign file numbers to images.
1 MENU t
(Settings) t
(Memory Card Tool) or
(Internal
Memory Tool) t [File Number] t desired mode t z on the control
button
Reset
Starts from 0001 each time the folder is changed. (When the
recording folder contains a file, a number one higher than the
largest number is assigned.)
MENU/Settings
Search
Assigns numbers to files in sequence even if the recording folder or
the memory card is changed. (When the replaced memory card
contains a file with a number higher than the last assigned number,
a number one higher than the largest number is assigned.)
Operation
Search
Series
Table of
contents
File Number
Index
97GB
Adjusts the time to the local time of a selected area.
1 MENU t
(Settings) t
(Clock Settings) t [Area Setting] t
desired setting t z on the control button
You use the camera in your area.
When the currently set area differs from your home area, you must
make the Area Setting.
Destination
You use the camera set to the time at your destination.
Set the destination area.
Setting a frequently visited destination lets you easily adjust the time when you visit that
destination.
MENU/Settings
Search
zChanging Area Setting
Operation
Search
Home
Table of
contents
Area Setting
Daylight Savings icon
Index
1Select the area part for [Destination], then press z on the control button.
2Select an area with b/B on the control button, and select Daylight Savings time with
v/V.
98GB
Sets the date and time again.
1 MENU t
(Settings) t
(Clock Settings) t [Date & Time Setting]
t desired setting t z on the control button
Table of
contents
Date & Time Setting
2 Set the numeric value and desired settings with v/V/b/B.
Date & Time Format
You can select the date and time display format.
Daylight Savings
You can select Daylight Savings On/Off.
Date & Time
You can set the date and time.
MENU/Settings
Search
Note
• The camera does not have a feature for superimposing dates on images. By using “PMB” in the CDROM (supplied), you can print or save images with the date.
Operation
Search
3 [OK] t z
Index
99GB
Table of
contents
Viewing an image on a TV
You can view images on a TV by connecting the camera to a TV.
Refer also to the operating instructions supplied with the TV.
1 Turn off both the camera and the TV.
2 Connect the camera to the TV with the cable for multi-use terminal
(supplied).
Cable for multi-use terminal
MENU/Settings
Search
(Playback) button
1 To audio/video input jacks
Operation
Search
Viewing images by connecting the camera to a TV
with the supplied cable for multi-use terminal
2 To the multi connector
4 Press
(Playback) button to turn on the camera.
Index
3 Turn on the TV and set the input.
Images shot with the camera appear on the TV. Select the desired image with the control
button.
Notes
• When using the camera abroad, it may be necessary to switch the video signal output to match that of
your TV system (page 86).
• The shooting image will not be displayed on the TV when the movie is shot under the condition of the
camera and TV connected.
• When output to TV, Easy Viewing mode is invalid.
100GB
You can view an image recorded on the camera by connecting the camera to an HD (High
Definition) TV with the HD Output Adaptor Cable (sold separately). Use a Type2b-compliant
HD Output Adaptor Cable (sold separately).
Table of
contents
Viewing an image by connecting the camera to an
HD TV
1 Turn off both the camera and the TV.
Green/Blue/Red
(Playback) button
MENU/Settings
Search
1 To audio/video
input jacks
COMPONENT AUDIO
VIDEO IN
Operation
Search
2 Connect the camera to the TV with an HD Output Adaptor Cable (sold
separately).
White/Red
2 To the multi connector
Index
HD Output
Adaptor Cable
(sold separately)
3 Turn on the TV and set the input.
4 Press
(Playback) button to turn on the camera.
Images shot with the camera appear on the TV. Select the desired image with the control
button.
Notes
• Set [COMPONENT] to [HD(1080i)] (page 85).
• Images shot in [VGA] image size cannot be played back in HD format.
• When shooting movies in the condition with the camera and a TV connected using an HD Output
Adaptor Cable (sold separately), the image being shot is not displayed in the TV side.
• When using the camera abroad, it may be necessary to switch the video signal output to match that of
your TV system (page 86).
• When output to TV, Easy Viewing mode is invalid.
z“PhotoTV HD”
This camera is compatible with the “PhotoTV HD” standard.
By connecting Sony PhotoTV HD-compatible devices using an HD Output Adaptor Cable
(sold separately), whole new world of photos can be comfortably enjoyed in breathtaking
Full HD quality.
• PhotoTV HD allows for a highly-detailed, photo-like expression of subtle textures and colors.
• The settings are also required to be made on the TV. For details, refer to the operating instruction of
the TV.
101GB
On TV color systems
PAL-M system
Brazil
PAL-N system
Argentina, Paraguay, Uruguay
MENU/Settings
Search
PAL system
Australia, Austria, Belgium, China, Croatia, Czech Republic, Denmark, Finland, Germany,
Holland, Hong Kong, Hungary, Indonesia, Italy, Kuwait, Malaysia, New Zealand, Norway,
Poland, Portugal, Rumania, Singapore, Slovak Republic, Spain, Sweden, Switzerland, Thailand,
Turkey, United Kingdom, Viet Nam, etc.
Operation
Search
NTSC system
Bahama Islands, Bolivia, Canada, Central America, Chile, Colombia, Ecuador, Jamaica, Japan,
Korea, Mexico, Peru, Surinam, Taiwan, the Philippines, the U.S.A., Venezuela, etc.
Table of
contents
If you want to view images on a TV screen, you need a TV with a video input jack and the cable
for multi-use terminal. The color system of the TV must match that of the digital still camera.
Check the following lists for the TV color system of the country or region where the camera is
used.
SECAM system
Bulgaria, France, Greece, Guiana, Iran, Iraq, Monaco, Russia, Ukraine, etc.
Index
102GB
“PMB” and other applications are contained on the CD-ROM (supplied) to allow more versatile
use of images shot with your Cyber-shot camera.
Table of
contents
Using with your computer
Recommended computer environment (Windows)
Microsoft Windows XP*1 SP3/Windows Vista*2 SP2/
Windows7
Others
CPU: Intel Pentium III 800 MHz or faster (For playing/
editing the High Definition movies: Intel Core Duo
1.66 GHz or faster/ Intel Core 2 Duo 1.20 GHz or faster)
Memory: 512 MB or more (For playing/ editing the High
Definition movies: 1 GB or more)
Hard Disk: Disk space required for installation—
approximately 500 MB
Display: Screen resolution: 1,024 × 768 dots or more
*1 64-bit editions and Starter (Edition) are not supported.
Recommended computer environment
(Macintosh)
Index
Windows Image Mastering API (IMAPI) Ver.2.0 or later is required to use the function for creating
discs.
*2 Starter (Edition) is not supported.
MENU/Settings
Search
OS (pre-installed)
Operation
Search
The following computer environment is recommended when using the supplied software
“PMB”, “Music Transfer” or “PMB Portable” and importing images via a USB connection.
The following computer environment is recommended when using the supplied software,
“Music Transfer” or “PMB Portable” and importing images via a USB connection.
OS (pre-installed)
USB Connection: Mac OS X (v10.3 to v10.6)
Music Transfer/PMB Portable: Mac OS X (v10.4 to v10.6)
Notes
• Operation is not assured in an environment based on an upgrade of the operating systems described
above or in a multi-boot environment.
• If you connect two or more USB devices to a single computer at the same time, some devices, including
the camera, may not operate, depending on the types of USB devices you are using.
• Connecting the camera using a USB interface that is compatible with Hi-Speed USB (USB 2.0
compliant) allows advanced transfer (high speed transfer), as the camera is compatible with Hi-Speed
USB (USB 2.0 compliant).
• When your computer resumes activity from suspend or sleep mode, communication between the camera
and your computer may not recover at the same time.
103GB
Installing “PMB (Picture Motion Browser)” and
“Music Transfer” (Windows)
The installation menu screen appears.
• If it does not appear, double-click [Computer] (in Windows XP, [My Computer]) t
(SONYPMB).
• If the AutoPlay screen appears, select “Run Install.exe” and follow the instructions that appear on the
screen to proceed with the installation.
Operation
Search
1 Turn on your computer, and insert the CD-ROM (supplied) into the CDROM drive.
Table of
contents
Using the software
2 Click [Install].
3 Select the desired language, then proceed to the following screen.
The “License Agreement” screen appears.
4 Carefully read the agreement, click the radio button (
the terms of the agreement, and then click [Next].
t
) to accept
5 Follow the instructions on the screen to complete the installation.
6 Remove the CD-ROM after the installation is complete.
Index
• For the installation, connect the camera to the computer during the procedure (page 106).
• When the restarting confirmation message appears, restart the computer following the instructions on
the screen.
• DirectX may be installed depending on the system environment of your computer.
MENU/Settings
Search
The “Choose Setup Language” screen appears.
7 Start up the software.
• To start up “PMB”, click
(PMB) on the desktop.
For the detailed operation method, see “PMB” Support page below (English only) or click
(PMB
Help).
http://www.sony.co.jp/pmb-se/
• To start up “PMB” from the Start menu, select [Start] t [All Programs] t
(PMB).
• If “PMB” is already installed in your computer, by installing “PMB” from the CD-ROM (supplied),
you can start up all of the application from “PMB Launcher”.
To start up “PMB Launcher”, double-click
(PMB Launcher) on the desktop.
Notes
• Log on as Administrator.
• When “PMB” is started up for the first time, the confirmation message of the Information tool appears on
the screen. Select [Start].
104GB
Installing “Music Transfer” (Macintosh)
2 Double-click
(SONYPMB).
Table of
contents
1 Turn on your Macintosh computer, and insert the CD-ROM (supplied) into
the CD-ROM drive.
3 Double-click the [MusicTransfer.pkg] file in the [Mac] folder.
The installation of the software starts.
• “PMB” is not compatible with Macintosh computers.
• Shut down all other application software before you install “Music Transfer”.
• For installation, you need to log on as Administrator.
Index
• “PMB” allows you to import images shot with the camera to a computer for display. Make a USB
connection between the camera and your computer, and click [Import].
• Images on a computer can be exported to a memory card, and displayed on the camera. Make a USB
connection between the camera and your computer, click [Export] t [Easy Export (PC Sync)] in
the [Manipulate] menu, and click [Export].
• You can save and print images with the date.
• You can display images stored on a computer by shooting date in a calendar display.
• You can correct (Red Eye Reduction, etc.) still images, and change the shooting date and time.
• You can create discs with CD or DVD disc-writing drive.
• You can upload images to media services. (An internet connection environment is required.)
• For other details, see
(PMB Help).
MENU/Settings
Search
zIntroduction to “PMB”
Operation
Search
Notes
zIntroduction to “Music Transfer”
“Music Transfer” allows you to replace the Music files provided in the camera at the factory
with your favorite tracks, and to delete and add Music files.
You can also restore the tracks stored at the factory to your camera.
The following track types can be imported using “Music Transfer”.
–
–
–
•
MP3 files stored on the hard disk of your computer
Music CD tracks
Preset-music saved on the camera
Before starting up “Music Transfer”, perform MENU t
[Download Music], and connect the camera to a computer.
(Settings) t [Main Settings] t
For other details, see the help in “Music Transfer”.
105GB
• Use a Type2b-compliant USB/AV/DC IN Cable (sold separately).
2 Turn on the computer, then press
(Playback) button.
3 Connect the camera to your computer.
Operation
Search
1 Insert a sufficiently charged battery pack into the camera, or connect the
camera to a wall outlet (wall socket) using the AC-LS5 AC Adaptor (sold
separately) and the USB/AV/DC IN Cable for multi-use terminal (sold
separately).
Table of
contents
Connecting the camera to the
computer
• When a USB connection is established for the first time, your computer automatically runs a program
to recognize the camera. Wait for a while.
MENU/Settings
Search
1 To a USB jack of the computer
Index
2 To the multi connector
Cable for multi-use terminal (supplied)
Importing images to a computer (Windows)
“PMB” allows you to easily import images.
For details on “PMB” functions, see the “PMB Help”.
Importing images to a computer without using “PMB”
When the AutoPlay Wizard appears after making a USB connection between the camera and a
computer, click [Open folder to view files] t [OK] t [DCIM] or [MP_ROOT] t copy the
desired images to the computer.
106GB
Importing images to a computer (Macintosh)
Table of
contents
1 Connect the camera to your Macintosh computer first. Double-click the
newly recognized icon on the desktop t [DCIM] or [MP_ROOT] t the
folder where the images you want to import are stored.
2 Drag and drop the image files to the hard disk icon.
The image files are copied to the hard disk.
The image is displayed.
Operation
Search
3 Double-click the hard disk icon t the desired image file in the folder
containing the copied files.
Deleting the USB connection
•
•
•
•
Disconnecting the cable for multi-use terminal.
Removing a memory card.
Inserting a memory card into the camera after copying images from the internal memory.
Turning off the camera.
1 Double-click the disconnect icon on the
tasktray.
2 Click
Windows Vista
(USB Mass Storage Device) t [Stop].
Index
Windows XP
3 Confirm the device on the confirmation
window, then click [OK].
Note
MENU/Settings
Search
Perform the procedures from step 1 to 3 below before:
Disconnect icon
• Drag and drop the icon of the memory card or the drive icon to the “Trash” icon beforehand when you
use a Macintosh computer, and the camera is disconnected from the computer.
107GB
This camera has a built-in application “PMB Portable”.
You can use this application to do the following:
For details on “PMB Portable”, see the “PMB Portable” help.
Starting up “PMB Portable” (Windows)
1 Make a USB connection between the camera and a computer.
When you connect the camera and your computer, AutoPlay Wizard appears.
Click [×] to close the AutoPlay Wizard for any unnecessary drives.
MENU/Settings
Search
When using “PMB Portable” for the first time, you must select the language. Follow the
procedure below to make the selection. Once the language selection has been made, steps 3 to 5
are unnecessary the next time you use “PMB Portable”.
Operation
Search
• You can easily upload images to a blog or other media service.
• You can upload images from a computer connected to the Internet even when you are away from home or
the office.
• You can easily register the media services (such as blogs) you use frequently.
Table of
contents
Uploading images to a media
service
• If the desired AutoPlay Wizard does not appear, click [Computer] (in Windows XP, [My Computer])
t [PMBPORTABLE], then double-click “PMBP_Win.exe”.
• If [PMB Portable] is not displayed within the AutoPlay Wizard, click [Computer] t
[PMBPORTABLE], then double-click “PMBP_Win.exe”.
Index
2 Click “PMB Portable”.
(in Windows XP, click “PMB Portable” t [OK])
The Language Selection screen appears.
3 Select the desired language, then click [OK].
The Region Selection screen appears.
4 Select the appropriate [Region] and [Country/Area], and then click [OK].
The User Agreement screen appears.
5 Read the agreement carefully. If you accept the terms of the agreement,
click [I Agree].
“PMB Portable” starts up.
108GB
Starting up “PMB Portable” (Macintosh)
When you connect the camera and your computer, [PMB Portable] appears on the desktop.
Click [×] to close any unnecessary drives.
Table of
contents
1 Make a USB connection between the camera and a Macintosh computer.
2 Click [PMBPORTABLE] folder, then click [PMBP_Mac].
The Region Selection screen appears.
The User Agreement screen appears.
4 Read the agreement carefully. If you accept the terms of the agreement,
click [I Agree].
Operation
Search
3 Select the appropriate [Region] and [Country/Area], and then click [OK].
“PMB Portable” starts up.
• Set [LUN Settings] in [Main Settings] to [Multi].
• Always connect to a network when using “PMB Portable”.
• When uploading images over the Internet, the cache may remain in the computer being used depending
on the service provider. This is also true when this camera is used for this purpose.
• When a bug occurs in “PMB Portable” or you delete “PMB Portable” by mistake, you can repair “PMB
Portable” by downloading the PMB Portable installer from the web site.
MENU/Settings
Search
Notes
Notes on “PMB Portable”
Index
“PMB Portable” makes it possible to download the URLs of a number of websites from the
server administered by Sony (the “Sony server”).
In order to use “PMB Portable” to enjoy the benefits of the image uploading service or other
services (the “services”) provided by these and other websites, you must consent to the
following.
• Some websites require registration procedures and/or fees to use their services. In using such services,
you must comply with the terms and conditions established by the websites concerned.
• Services may be terminated or changed in accordance with the convenience of the website operators.
Sony will not be held responsible for any trouble occurring between the users and third parties or any
inconvenience caused to users relating to the utilization of the services inclusive of the termination of or
changes to such services.
• To view a website, you will be redirected to it by the Sony server. There may be times when you cannot
access the website because of server maintenance or for other reasons.
• If the operation of the Sony server is to be terminated, you will be notified of the termination ahead of
time on Sony’s website, etc.
• The URLs to which you are redirected by the Sony server and other information may be recorded for the
purposes of improving Sony’s future products and services. However, no personal data will be recorded
on such occasions.
109GB
Notes
Operation
Search
You can print still images using the following methods.
• Printing directly using a PictBridge-compliant printer
• Printing directly using a printer which supports your memory card type
For details, see the operating instructions supplied with the printer.
• Printing using a computer
You can import images to a computer using the supplied “PMB” software and print the
images. You can insert the date on the image and print it.
For details, see the “PMB Help”.
• Printing at a shop (page 111)
Table of
contents
Printing still images
• When you print still images shot in [16:9] mode, both edges may be cut off.
• You cannot print panoramic images depending on the printer.
Even if you do not have a computer, you can print images shot using the camera by connecting
the camera directly to a PictBridge-compliant printer.
MENU/Settings
Search
Printing images directly using a PictBridgecompliant printer
“PictBridge” is based on the CIPA standard. (CIPA: Camera & Imaging
Products Association)
Index
1 Insert a sufficiently charged battery pack into the camera.
2 Connect the camera to the printer.
1 To a USB jack of
the printer
2 To the multi connector
Cable for multi-use terminal
3 Turn on the camera and the printer.
After the connection is made, the
indicator appears on the screen.
If the indicator flashes on the screen of the camera (error notification), check the connected
printer.
110GB
Continued r
4 MENU t
(Print) t desired mode t z on the control button
Prints the currently displayed image in single-image mode.
Multiple Images
You can select and print multiple images.
After step 4, perform the following.
1Select an image then press z.
Repeat the above step until there are no more images to be
printed. Select an image with a mark again to release the
mark.
5 Desired item t [Start] t z
Quantity
Selects the number of copies of the specified image to be printed.
Operation
Search
2MENU t [OK] t z.
Table of
contents
This Image
• The designated number of images may not all fit onto a single sheet
depending on the quantity of images.
Selects the number of images you want to print side by side on a
sheet.
Size
Selects the size of the printing sheet.
Date
Selects [Date] or [Day&Time] to insert the date and time on
images.
• When you choose [Date], the date will be inserted in the order you have
selected using [Date & Time Setting] on the camera. This function may
not be available depending on the printer.
Index
Notes
• Movies cannot be printed.
• If the camera could not be connected to the printer, be sure to set [USB Connect] under (Main
Settings) to [PictBridge].
• Do not disconnect the cable for multi-use terminal while the
(PictBridge Connecting) indicator
appears on the screen.
MENU/Settings
Search
Layout
Printing at a shop
You can take a memory card containing images shot with the camera to a photo printing service
shop. As long as the shop supports photo printing services conforming to DPOF, you can make a
(Print order) mark on images in advance in the playback mode so that you do not have to
reselect them when you print them out at the shop.
Notes
• You cannot print images stored in the internal memory at a print shop directly from the camera. Copy the
images to a memory card (page 96), then take the memory card to the print shop.
• Consult your photo printing service shop as to what types of memory card they handle.
• A memory card adaptor (sold separately) may be necessary. Consult your photo printing service shop.
• Before you take image data to a shop, always copy (back up) your data to a disk.
• You cannot set the number of prints.
• If you want to superimpose dates on images, consult your photo printing service shop.
111GB
If you experience trouble with the camera, try the following solutions.
1 Check the items on pages 112 to 119.
Table of
contents
Troubleshooting
If a code such as “C/E:ss:ss” appears on the screen, see
page 120.
4 Consult your Sony dealer or local authorized Sony service
facility.
Be aware that by sending the camera for repair, you give consent that the contents of the internal
memory, music files may be checked.
Index
Additional information on this product and answers to frequently asked questions can
be found at our Customer Support Website.
http://www.sony.net/
MENU/Settings
Search
3 Initialize the settings (page 84).
Operation
Search
2 Remove the battery pack, wait for about one minute, re-insert
the battery pack, then turn on the power.
Battery pack and power
Cannot insert the battery pack.
• Make sure the direction of the battery is correct, and insert it until the battery eject lever is locked.
Cannot turn on the camera.
• After inserting the battery pack into the camera, it may take a few moments for the camera to power
up.
• Insert the battery pack correctly.
• The battery pack is discharged. Insert a charged battery pack.
• The terminal section of the battery is dirty. Wipe any dust with a soft cloth lightly to clean the battery.
• Use a recommended battery pack.
The power turns off suddenly.
• Depending on the camera and battery temperature, the power may turn off automatically to protect
the camera. In this case, a message is displayed on the LCD screen before the power turns off.
• When [Power Save] is set to [Stamina] or [Standard], if you do not operate the camera for a certain
period of time while the power is on, the camera turns off automatically to prevent wearing down the
battery pack. Turn on the camera again.
112GB
The remaining charge indicator is incorrect.
Table of
contents
• This phenomenon occurs when you use the camera in an extremely hot or cold location.
• A discrepancy arose between the remaining charge indicator and the actual remaining battery charge.
Fully discharge the battery pack once, then charge it to correct the indication.
• Battery capacity decreases over time and through repeated use. If decreased usage time between
charges becomes significant, it is probably time to replace it with a new one.
Cannot charge the battery pack.
The CHARGE lamp flashes while charging the battery.
Shooting still images/movies
Cannot record images.
Index
• If images are recorded on the internal memory even when a memory card is inserted into the camera,
make sure that the memory card is fully inserted into the camera.
• Check the free capacity of the internal memory or memory card. If it is full, do one of the following:
– Delete unnecessary images (page 38).
– Change the memory card.
• You cannot record images while charging the flash.
• When recording movies, it is recommended that you use the following memory cards:
– “Memory Stick PRO Duo” (Mark2) media, “Memory Stick PRO-HG Duo” media
– SD memory card, SDHC memory card or SDXC memory card (Class 4 or faster)
• Set [Demo Mode] to [Off] (page 83).
MENU/Settings
Search
• Remove and reinsert the battery pack, making sure it is installed correctly.
• The temperature may be inappropriate for charging. Try charging the battery pack again within the
proper charging temperature range (10 °C to 30 °C (50 °F to 86 °F)).
• Refer to page 128 for details.
Operation
Search
• You cannot charge the battery pack using the AC Adaptor (sold separately). Use the battery charger
to charge the battery.
Smile Shutter function does not work.
• No image is shot if a smiling face is not detected.
• Set [Demo Mode] to [Off] (page 83).
Anti-blur function does not work.
• The anti-blur function may not work properly when shooting night scenes.
• Shoot after pressing the shutter button halfway down.
• If camera shake is excessive, the anti-blur function may not be effective even when [SteadyShot] is
activated.
Recording takes a long time.
• When the shutter speed becomes slower than a certain speed in low light conditions, the NR (Noise
Reduction) slow shutter function is activated automatically to reduce the image noise. Under such
conditions, recording takes a long time.
• The Anti Blink function is working. Reset [Anti Blink] to [Off] (page 61).
113GB
The image is out of focus.
Table of
contents
• The subject is too close. When shooting, make sure to position the lens farther away from the subject
than the shortest shooting distance (approximately 5 cm (2 inches) (W)/100 cm (3ft 3 3/8 inches) (T)
from the lens).
•
(Advanced Sports Shooting), (Twilight),
(Landscape) or (Fireworks) mode is selected in
the Scene Selection when shooting still images.
Zoom does not work.
• You can select Face Detection only when the focus mode is set to [Multi AF] and the metering mode
is set to [Multi].
The flash does not work.
(Fireworks) mode is
(Landscape),
Index
• You cannot use the flash when:
– Burst mode is selected (page 45).
–
(High Sensitivity),
(Advanced Sports Shooting), (Twilight) or
selected in Scene Selection.
– In Sweep Panorama mode
– In Movie Mode
• Set the flash to (On) (page 32) when the Scene Selection mode is set to
(Gourmet),
(Pet),
(Beach) or (Snow) mode.
MENU/Settings
Search
Cannot select the Face Detection function.
Operation
Search
• You cannot use the zoom when shooting in Sweep Panorama mode.
• You cannot use the Smart zoom depending on the image size (page 76).
• You cannot use the digital zoom when:
– In Movie Mode
– The Smile Shutter is working.
– When
(Advanced Sports Shooting) mode in the Scene Selection is selected
Fuzzy white circular spots appear in images shot using the flash.
• Particles (dust, pollen, etc.) in the air reflected the flash light and appeared in the image. This is not a
malfunction.
The close-up shoot function (Macro) does not work.
• The camera automatically adjusts the focus. Press and hold the shutter button halfway down. Focus
adjustment may take some time when shooting a close subject.
•
(Advanced Sports Shooting),
(Landscape), (Twilight) or (Fireworks) mode is selected in
the Scene Selection.
The date and time are not displayed on the LCD screen.
• While shooting, the date and time are not displayed. They are displayed only during playback.
Cannot insert dates on images.
• This camera does not have a feature for superimposing dates on images. By using “PMB”, you can
print or save images with the date (page 104).
The F value and shutter speed flash when you press and hold the shutter button
halfway down.
• The exposure is incorrect. Correct the exposure (page 47).
114GB
The image colors are not correct.
White or purple streaks appear in bright areas of the subject, or the whole screen
of the image becomes reddish.
Table of
contents
• Adjust the White Balance (page 50).
• This phenomenon is called smearing. This is not a malfunction. Smearing is not recorded on still
images, but is recorded as streaks or uneven colors on Sweep Panorama images or movies. (“Bright
areas” refers to the sun or electric lights which are much brighter than surroundings.)
• The camera is attempting to increase the visibility of the screen by temporarily brightening the image
under conditions of low illumination. There is no effect on the recorded image.
Operation
Search
Noise appears in the image when you view the screen in a dark place.
The eyes of the subject come out red.
Dots appear and remain on the screen.
MENU/Settings
Search
• Set [Red Eye Reduction] to [Auto] or [On] (page 78).
• Shoot the subject at a distance closer than the flash range using the flash.
• Light the room and shoot the subject.
• Retouch the image using [Retouch] t [Red Eye Correction] in viewing menu (page 67), or correct
using “PMB”.
• This is not a malfunction. These dots are not recorded.
• The internal memory or memory card is full. Delete unnecessary images (page 38).
• The battery level is low. Insert charged battery pack.
Index
Cannot shoot images in succession.
The same image is shot several times.
• Set [Burst Settings] to [Single] (page 45).
• Set [Bracket Settings] to [Off] (page 46).
• [Scene Recognition] is set to [Advanced] (page 55).
Viewing images
Cannot play back images.
• Make sure that the memory card is fully inserted into the camera.
• The folder/file name has been changed on your computer.
• No guarantees are made for playing back, on this camera, files containing images which were
processed on a computer or images which were shot using other cameras.
• The camera is in USB mode. Delete the USB connection (page 107).
• Use “PMB” to play images stored on a PC with this camera.
The date and time are not displayed.
• The screen display is set to display images only. Press the DISP (Screen Display Settings) button to
display information (page 30).
Left and right sides of the screen are shown in black.
• [Auto Orientation] is set to [On] (page 77).
115GB
Cannot display images in index mode.
Cannot hear music during slideshow.
• Transfer music files to the camera with “Music Transfer” (pages 104, 105).
• Confirm that the volume setting and slideshow setting are correct (page 63).
• Slideshow is played back with [Continuous Playback]. Select [Slideshow with music] and play back.
Deleting
Cannot delete an image.
• Cancel the protection (page 69).
“Memory Stick PRO Duo” media is not recognized by a computer with a “Memory
Stick” media slot.
Index
Computers
MENU/Settings
Search
• Check [Video Out] to see if the video output signal of the camera is set to the color system of your TV
(page 86).
• Check whether the connection is correct (page 100).
• If the USB connector of the cable for multi-use terminal is connected to another device, disconnect it
(page 107).
• When shooting movies with the camera and a TV connected, the image being shot is not displayed on
the TV.
Operation
Search
The image does not appear on the TV.
Table of
contents
• Cancel the Easy Viewing mode if activated.
• Check that the computer and the “Memory Stick” media Reader/Writer support “Memory Stick PRO
Duo” media. Users of computers and “Memory Stick” media Readers/Writers made by manufacturers
other than Sony should contact those manufacturers.
• If “Memory Stick PRO Duo” media is not supported, connect the camera to the computer (pages 106,
107). The computer recognizes the “Memory Stick PRO Duo” media.
Your computer does not recognize the camera.
• When the battery level is low, insert the charged battery pack or use the AC adaptor (sold separately).
• Set [USB Connect] to [Auto] or [Mass Storage] (page 87).
• Use the cable for multi-use terminal (supplied).
• Disconnect the cable for multi-use terminal from both the computer and the camera, and connect it
again firmly.
• Disconnect all equipment other than the camera, the keyboard and the mouse from the USB
connectors of your computer.
• Connect the camera directly to your computer without passing through a USB hub or other device.
Cannot import images.
• Connect the camera and your computer correctly making a USB connection (page 106).
• When you shoot images with a memory card formatted by a computer, you may not be able to import
the images to a computer. Shoot using a memory card formatted by the camera (page 92).
After making a USB connection, “PMB” does not start automatically.
• Make the USB connection after the computer is turned on.
116GB
After making a USB connection, “PMB Portable” does not start.
Table of
contents
• Set [LUN Settings] to [Multi].
• Set [USB Connect] to [Auto] or [Mass Storage].
• Connect the computer to the network.
Cannot play back images on your computer.
• If you are using “PMB”, refer to “PMB Help” (page 104).
• Consult the computer or software manufacturer.
• You are playing back the movie directly from the internal memory or the memory card. Import the
images to your computer using “PMB” and play it back (page 104, 106).
• Use “PMB” to play images stored on a PC with this camera.
• Register the image to the image database file, then play back in [Date View] (page 66).
• Event View is not available on this camera.
Memory card
MENU/Settings
Search
Images once exported to a computer cannot be viewed on the camera.
Operation
Search
The image and sound are interrupted by noise when you view a movie on a
computer.
Cannot insert a memory card.
• Insert the memory card in the correct direction.
Index
You have formatted a memory card by mistake.
• All the data on the memory card is deleted by formatting. You cannot restore it.
Images are recorded on the internal memory even when a memory card is
inserted into the camera.
• Make sure that the memory card is fully inserted into the camera.
Internal memory
Cannot play back or record images using the internal memory.
• There is a memory card inserted in the camera. Remove it.
Cannot copy the data stored in the internal memory to a memory card.
• The memory card is full. Copy to a memory card with sufficient capacity.
Cannot copy the data on the memory card or the computer to the internal
memory.
• This feature is not available.
117GB
Printing
Table of
contents
See “PictBridge-compliant printer” together with the following items.
Cannot print an image.
• Refer to the operation manual of the printer.
• Depending on your printer, all the edges of the image may be cut off. Especially when you print an
image shot with the image size set to [16:9], the lateral end of the image may be cut off.
• When printing images using your printer, cancel the trimming or borderless settings. Consult the
printer manufacturer as to whether the printer provides these functions or not.
• When having images printed at a digital print shop, ask the shop whether they can print the images
without cutting off both edges.
• Using “PMB”, you can print images with date (page 104).
• The camera does not have a feature for superimposing dates on images. However, because the images
shot with the camera include information on the recording date, you can print images with the date
superimposed if the printer or the software can recognize Exif information. For compatibility with
Exif information, consult the manufacturer of the printer or the software.
• If you use a photo printing service, ask them to superimpose the dates on images.
Index
PictBridge-compliant printer
MENU/Settings
Search
Cannot print images with the date.
Operation
Search
Images are printed with both edges cut off.
A connection cannot be established.
• The camera cannot be connected directly to a printer that is not compliant with the PictBridge
standard. Consult the printer manufacturer as to whether the printer is compliant with PictBridge or
not.
• Check that the printer is turned on and can be connected to the camera.
• Set [USB Connect] to [PictBridge] (page 87).
• Disconnect and connect the cable for multi-use terminal again. If an error message is indicated on the
printer, refer to the operating instructions supplied with the printer.
Cannot print images.
• Check that the camera and the printer are properly connected using the cable for multi-use terminal.
• Turn on the printer. For details, refer to the operating instructions supplied with the printer.
• If you select [Exit] during printing, images may not be printed. Disconnect and connect the cable for
multi-use terminal again. If you still cannot print your images, disconnect the cable for multi-use
terminal, turn the printer off and then on, then connect the cable for multi-use terminal again.
• Movies cannot be printed.
• Images shot using other cameras, or images modified with a computer may not be printed.
• Panoramic images may not be printed depending on the printer or may be printed in cut off panoramic
image.
Printing is canceled.
• Confirm you did not disconnect the cable for multi-use terminal while the
Connecting) mark was displayed.
(PictBridge
118GB
Cannot insert the date or print images in the index mode.
Table of
contents
• The printer does not provide these functions. Consult the printer manufacturer as to whether the
printer provides these functions or not.
• The date may not be inserted in the index mode depending on the printer. Consult the printer
manufacturer.
“---- -- --” is printed on the date-inserted part of the image.
Cannot print the image at the size selected.
Cannot operate the camera after cancelling printing.
• Wait for a while as the printer is carrying out the cancellation. It may take some time depending on
the printer.
MENU/Settings
Search
• When you use paper of a different size after connecting the printer to the camera, disconnect and then
reconnect the cable for multi-use terminal.
• The print setting of the camera differs from that of the printer. Change the setting of either the camera
(page 110) or the printer.
• Consult the printer manufacturer as to whether the printer can provide the desired size.
Operation
Search
• The image does not have the recording data so the date cannot be inserted. Set [Date] to [Off] and
print the image again (page 110).
Others
• Moisture condensation has occurred. Turn off the camera and leave it for about an hour before using
it.
Index
The lens gets fogged.
The camera turns off with the lens portion extended.
• The battery pack is discharged. Replace it with a charged battery pack, then turn the camera on again.
• Do not attempt to force the lens that has stopped moving.
The camera becomes warm when you use it for a long time.
• This is not a malfunction.
The Clock Set screen appears when you turn on the camera.
• Set the date and time again (page 99).
• The internal rechargeable backup battery has discharged. Insert a charged battery, and set aside for
24 hours or more with the power left off.
The date or time is incorrect.
• The Area Setting is set to a different location than your current location. Change the setting by
MENU t
(Settings) t [Clock Settings] t [Area Setting].
119GB
Table of
contents
Warning indicators and
messages
Self-diagnosis display
• There is trouble with the camera’s hardware. Turn the power off and on again.
C:13:ss
• The camera cannot read or write data on the memory card. Try turning off and on the camera again, or
taking out and inserting the memory card several times.
• The internal memory has experienced a format error, or an unformatted memory card is inserted.
Format the internal memory or the memory card (page 92).
• The inserted memory card cannot be used with the camera, or the data is damaged. Insert a new
memory card.
Index
E:61:ss
MENU/Settings
Search
C:32:ss
Operation
Search
If a code starting with a letter of the alphabet appears, the self-diagnosis function on the camera
is working. The last two digits (indicated by ss) will differ depending on the state of the
camera.
If you cannot solve the problem even after trying the following corrective actions a few times,
the camera may need repair.
Contact your Sony dealer or local authorized Sony service facility.
E:62:ss
E:91:ss
• A camera malfunction has occurred. Initialize the camera (page 84), then turn the power on again.
E:94:ss
• A malfunction that you cannot service has occurred. Contact your Sony dealer or local authorized
Sony service facility. Inform them of the 5-digit code, which starts from “E”.
Messages
If the following messages appear, follow the instructions.
• The battery level is low. Charge the battery pack immediately. Depending on the conditions of use or
the type of battery pack, the indicator may flash even though there are still 5 to 10 minutes of
remaining battery time left.
For use with compatible battery only
• The battery inserted is not an NP-BG1 (supplied) or NP-FG1 (sold separately) battery pack.
System error
• Turn the power off and then on again.
120GB
• The camera temperature has risen. The power may turn off automatically, or you may be unable to
record movies. Leave the camera in a cool location until the temperature goes down.
Table of
contents
Camera overheating
Allow it to cool
Internal memory error
• Turn the power off and then on again.
• The inserted memory card cannot be used in the camera (page 3).
• The terminal section of the memory card is dirty.
• The memory card is damaged.
Operation
Search
Reinsert the memory card
Memory card type error
This memory card may not record or play
• The inserted memory card cannot be used in the camera (page 3).
Error formatting internal memory
Error formatting memory card
MENU/Settings
Search
• The inserted memory card cannot be used in the camera (page 3).
• Format the media again (page 92).
• You are using the memory card with the write-protect switch, and the switch is set to the LOCK
position. Set the switch to the recording position.
Index
Memory card locked
Read only memory card
• The camera cannot record or delete images on this memory card.
No images
• No images that can be played back have been recorded in the internal memory.
• No images that can be played back have been recorded in this folder of the memory card.
No still images
• The selected folder or date does not contain a file that can be played back in a slideshow.
File found which was not recognized
• You tried to delete a folder containing a file that cannot be played on this camera. Delete the file with
a computer and then delete the folder.
Folder error
• A folder with the same first three digit number already exists on the memory card (for example:
123MSDCF and 123ABCDE). Select another folder, or create a new folder (pages 93, 94).
121GB
Cannot create more folders
Empty folder contents
Table of
contents
• The folder with a name beginning with “999” exists on the memory card. You cannot create any
folders if this is the case.
• You tried to delete a folder containing one or more files. Delete all of the files and then delete the
folder.
• You tried to delete a folder that was made read-only by PC or an other device.
File error
Read only folder
• You have selected a folder that cannot be set as a recording folder on the camera. Select another
folder (page 94).
File protected
MENU/Settings
Search
• An error occurred while the image was playing back.
No guarantees are made for playing back, on this camera, files containing images which were
processed on a computer or images which were shot using other cameras.
Operation
Search
Folder protected
• Release the protection (page 69).
• You are playing back an image with size that cannot be played back on the camera.
Index
Image size over limit
Unable to detect face for retouch
• You may not be able to retouch the image depending on the image.
(Vibration warning indicator)
• Camera shake may occur due to insufficient light. Use the flash, or mount the camera on a tripod to
secure the camera.
1280×720 (Fine) is not supported with this memory card
1280×720 (Standard) is not supported with this memory card
• For recording movies, it is recommended that you use a memory card of 1 GB or larger.
Turn the power off and on again
• The lens malfunction.
Maximum number of images already selected
• Up to 100 files can be selected when using [Multiple Images].
• You can add
(Print order) marks to up to 999 files. Cancel the selection.
• The data transmission to the printer may not be completed yet. Do not disconnect the cable for multiuse terminal.
122GB
Processing...
Error Playing Music
Table of
contents
• The printer is canceling the current print job. You cannot print until it is finished. This may take time,
depending on the printer.
• Delete the Music file, or replace it with an uncorrupted Music file.
• Execute [Format Music], then download new Music files.
• Execute [Format Music].
Operation cannot be executed in unsupported files
Operation
Search
Error Formatting Music
• Processing and other editing functions of the camera cannot be performed on image files that have
been processed using a computer or images that were recorded with other cameras.
• The camera restores the date information etc. in cases where images have been deleted on a PC, etc.
• The camera creates the necessary database files after the memory card is formatted.
MENU/Settings
Search
Preparing Image Database File
• The number of images exceeds that for which date management in a database file by the camera is
possible. To register new image files to the database file, delete unnecessary images from [Date
View].
Index
No internal memory space remaining
Delete images?
• The internal memory is full. To record to the internal memory, select [Yes] and delete unwanted
images.
• Unable to register to the database file or play back in [Date View]. Import all the images to a
computer using “PMB” and recover the memory card or internal memory.
Image Database File error
Cannot recover
• Import all of the images to the computer with “PMB”, and format the memory card or the internal
memory (page 92).
When you cannot import all of the images to the computer with “PMB”, import all of the images to
the computer without using “PMB” (page 106).
To view the images again with the camera, export the imported images to the camera with “PMB”.
Recording function unavailable due to high internal temperature
• The camera temperature has risen. You cannot record images until the temperature has dropped.
Recording has stopped due to increased camera temperature
• Recording has stopped due to a rise in temperature while recording a movie. Please wait until the
temperature goes down.
123GB
Table of
contents
• When you record movies for a long time, the camera temperature rises. In this case, stop recording
movies.
Operation
Search
MENU/Settings
Search
Index
124GB
A “Memory Stick Duo” media is a compact, portable IC recording medium. The types of
“Memory Stick Duo” media that can be used with the camera are listed in the table below.
However, proper operation cannot be guaranteed for all “Memory Stick Duo” media functions.
“Memory Stick” media type
Memory Stick Duo (without MagicGate)
Table of
contents
“Memory Stick Duo” media
Recording/Playback
a*1
a*2
a*1*2
Memory Stick PRO Duo
Memory Stick PRO-HG Duo
a*2*3
a*2*3*4
Notes
Index
• This product is compatible with “Memory Stick Micro” media (“M2”). “M2” is an abbreviation for
“Memory Stick Micro” media.
• A “Memory Stick Duo” media formatted with a computer is not guaranteed to operate with the camera.
• Data read/write speeds differ depending on the combination of the “Memory Stick Duo” media and the
equipment used.
• Do not remove the “Memory Stick Duo” media while reading or writing data.
• Data may be corrupted in the following cases:
– When the “Memory Stick Duo” media is removed or the camera is turned off during a read or write
operation
– When the “Memory Stick Duo” media is used in locations subject to static electricity or electrical noise
• We recommend backing up important data.
• Do not attach a label on the “Memory Stick Duo” media itself nor on a “Memory Stick Duo” media
Adaptor.
• Do not touch the terminal section of the “Memory Stick Duo” media with your hand or a metal object.
• Do not strike, bend or drop the “Memory Stick Duo” media.
• Do not disassemble or modify the “Memory Stick Duo” media.
• Do not expose the “Memory Stick Duo” media to water.
• Do not leave the “Memory Stick Duo” media within the reach of small children. They might accidentally
swallow it.
• Do not insert anything other than a “Memory Stick Duo” media into the “Memory Stick Duo” media slot.
Doing so will cause a malfunction.
• Do not use or store the “Memory Stick Duo” media under the following conditions:
– High temperature locations such as the hot interior of a car parked in direct sunlight
– Locations exposed to direct sunlight
– Humid locations or locations with corrosive substances present
MENU/Settings
Search
*1 High-speed data transfer using a parallel interface is not supported.
*2 “Memory Stick Duo” media, “MagicGate Memory Stick Duo” media and “Memory Stick PRO Duo”
media are equipped with MagicGate functions. MagicGate is copyright protection technology that uses
encryption technology. Data recording/playback that requires MagicGate functions cannot be performed
with the camera.
*3 [1280×720] movies cannot be recorded to internal memory or a “Memory Stick” media other than a
“Memory Stick PRO Duo” media, “Memory Stick PRO-HG Duo” media.
*4 This camera does not support 8-bit parallel data transfer. It performs the same 4-bit parallel data transfer
as the “Memory Stick PRO Duo” media.
Operation
Search
Memory Stick Duo (with MagicGate)
MagicGate Memory Stick Duo
125GB
Continued r
Operation
Search
• To use a “Memory Stick Duo” media with a “Memory Stick” media compliant device, be sure to insert
the “Memory Stick Duo” media into a “Memory Stick Duo” media Adaptor. If you insert a “Memory
Stick Duo” media into a “Memory Stick” media compliant device without a “Memory Stick Duo” media
Adaptor, you might not be able to remove it from the device.
• When inserting a “Memory Stick Duo” media into a “Memory Stick Duo” media Adaptor, make sure the
“Memory Stick Duo” media is inserted facing in the correct direction, then insert it all the way in.
Incorrect insertion may result in a malfunction.
• When using a “Memory Stick Duo” media inserted into a “Memory Stick Duo” media Adaptor with a
“Memory Stick” media compliant device, make sure that the “Memory Stick Duo” media Adaptor is
inserted facing the correct direction. Note that improper use may damage the equipment.
• Do not insert a “Memory Stick Duo” media Adaptor into a “Memory Stick” media compliant device
without a “Memory Stick Duo” media attached. Doing so may result in malfunction of the unit.
Table of
contents
Notes on using the “Memory Stick Duo” media Adaptor (sold
separately)
Notes on using “Memory Stick Micro” media (sold separately)
MENU/Settings
Search
• To use a “Memory Stick Micro” media with the camera, be sure to insert the “Memory Stick Micro”
media into an “M2” Adaptor as large as of Duo size. If you insert a “Memory Stick Micro” media into the
camera without an “M2” Adaptor as large as of Duo size, you might not be able to remove it from the
camera.
• Do not leave the “Memory Stick Micro” media within the reach of small children. They might
accidentally swallow it.
Index
126GB
On charging the battery pack
• We recommend charging the battery pack in an ambient temperature of between 10 °C to 30 °C (50 °F to
86 °F). The battery pack may not be effectively charged in temperatures outside this range.
Table of
contents
Battery pack
Effective use of the battery pack
Index
• Fully discharge the battery pack before storing and store it in a cool, dry place. To maintain the battery
pack’s function, fully charge the battery pack and then fully discharge it on the camera at least once a
year while storing.
• To use the battery pack up, leave the camera in slideshow playback mode until the power goes off.
• To prevent staining the terminal, short-circuiting, etc., be sure to use a supplied battery case when
carrying or storing.
MENU/Settings
Search
How to store the battery pack
Operation
Search
• Battery performance decreases in low temperature surroundings. So in cold places, the operational time
of the battery pack is shorter. We recommend the following to ensure longer battery pack use:
– Put the battery pack in a pocket close to your body to warm it up, and insert it in the camera
immediately before you start shooting.
• The battery pack will run out quickly if you use the flash or zoom frequently.
• We recommend having spare battery packs handy for two or three times the expected shooting time, and
making trial shots before taking the actual shots.
• Do not expose the battery pack to water. The battery pack is not water-resistant.
• Do not leave the battery pack in extremely hot places, such as in a car or under direct sunlight.
• You may not be able to turn on the camera or the battery pack may not be effectively charged if the
terminal section of the battery is dirty. In this case, wipe any dust with a soft cloth lightly to clean the
battery.
On battery life
• The battery life is limited. Battery capacity decreases over time and through repeated use. If decreased
usage time between charges becomes significant, it is probably time to replace it with a new one.
• The battery life varies according to how it is stored and the operating conditions and environment in
which each battery pack is used.
Compatible battery pack
• The NP-BG1 (supplied) can be used only in G type compatible Cyber-shot models.
• If you use the NP-FG1 battery pack (sold separately), the minutes also appear after the battery remaining
indicator (
60 Min).
127GB
Operation
Search
MENU/Settings
Search
• NP-BG type, NP-FG type battery packs (and no others) can be charged in the battery charger (supplied).
Batteries other than the specified kind may leak, overheat, or explode if you attempt to charge them,
posing a risk of injury from electrocution and burns.
• Remove the charged battery pack from the battery charger. If you leave the charged battery pack in the
charger, battery life may be shortened.
• The CHARGE lamp of the supplied battery charger flashes in either way:
– Fast flashing: Turns the light on and off repeatedly at the interval of 0.15 seconds.
– Slow flashing: Turns the light on and off repeatedly at the interval of 1.5 seconds.
• When the CHARGE lamp flashes fast, remove the battery pack being charged, and then insert the same
battery pack into the battery charger securely again. When the CHARGE lamp flashes fast again, this
may indicate a battery error or that a battery pack other than the specified type has been inserted. Check
that the battery pack is the specified type. If the battery pack is the specified type, remove the battery
pack, replace it with a new one or another one and check if the battery charger operates correctly. If the
battery charger operates correctly, a battery error may have occurred.
• When the CHARGE lamp flashes slowly, it indicates that the battery charger stops charging temporarily
on standby. The battery charger stops charging and enters the standby status automatically when the
temperature is outside of the recommended operating temperature. When the temperature gets back
within the appropriate range, the battery charger resumes charging and the CHARGE lamp lights up
again. We recommend charging the battery pack in an ambient temperature of between 10 °C to 30 °C
(50 °F to 86 °F).
Table of
contents
Battery charger
Index
128GB
A
Download Music ...............................................................89
Advanced Sports Shooting ...........................................26
DPOF .....................................................................................70
AF Illuminator ...................................................................73
DRO .......................................................................................60
AF range finder frame ....................................................52
E
Area Setting ........................................................................98
Easy Shooting ....................................................................20
Easy Viewing .....................................................................21
B
EV ...........................................................................................47
Battery charger ................................................................128
Exposure ...............................................................................47
Battery pack ......................................................................127
F
Beach .....................................................................................26
Blink Alert ...........................................................................79
Bracket Settings ................................................................46
Burst Settings .....................................................................45
Face Detection ...................................................................58
File Number ........................................................................97
Fireworks .............................................................................27
Flash .......................................................................................32
Focus ......................................................................................52
C
Folder
Changing .......................................................................94
CD-ROM ............................................................................104
Creating .........................................................................93
Center AF .............................................................................52
Deleting .........................................................................95
Center-weighted metering ............................................54
Selecting ........................................................................72
Change REC.Folder.........................................................94
Format ...................................................................................92
Clock Settings ....................................................................99
Format Music .....................................................................90
COMPONENT ..................................................................85
Function Guide ..................................................................82
Computer ............................................................................103
G
Importing images.............................................106, 107
Connecting
Computer ....................................................................106
Printer ...........................................................................110
TV ..................................................................................100
Continuous Playback ......................................................63
Control button ....................................................................14
Copy .......................................................................................96
Create REC.Folder ...........................................................93
D
Date & Time Setting .......................................................99
Delete ...............................................................................38, 68
Delete REC.Folder ...........................................................95
Demo Mode ........................................................................83
Digital Zoom ......................................................................76
DISP .......................................................................................30
Disp. Resolution ................................................................75
Index
Calendar ................................................................................66
MENU/Settings
Search
Beep ........................................................................................80
Operation
Search
Auto Orientation ...............................................................77
Table of
contents
Index
Gourmet ................................................................................26
Grid Line ..............................................................................74
H
HD(1080i) ............................................................................85
High Sensitivity .................................................................26
I
Identifying parts ................................................................14
Image Index ........................................................................37
Image Size ...........................................................................41
Initialize ................................................................................84
Install ...................................................................................104
Intelligent Auto Adjustment ........................................19
Internal memory ................................................................18
ISO ..........................................................................................48
129GB
R
Landscape ............................................................................26
Red Eye Correction .........................................................67
Language Setting ..............................................................81
Red Eye Reduction ..........................................................78
LUN Settings ......................................................................88
Retouch .................................................................................67
Rotate .....................................................................................71
Table of
contents
L
M
Manual Exposure Shooting ..........................................23
Scene Recognition............................................................55
Mass Storage ......................................................................87
Scene Selection..................................................................26
Memory card ........................................................................3
Screen ....................................................................................30
“Memory Stick Duo” media ......................................125
SD ............................................................................................85
MENU ...................................................................................10
Select Folder .......................................................................72
Metering Mode ..................................................................54
Self-diagnosis display ...................................................120
Mode dial .............................................................................17
Self-Portrait .........................................................................34
Movie Mode........................................................................28
Self-Timer ............................................................................34
MTP ........................................................................................87
Settings ..................................................................................12
Multi AF ...............................................................................52
Shooting
Multi connector ...............................................100, 106, 110
Movie..............................................................................28
Multi-pattern metering ...................................................54
Still Image ....................................................................19
Music Transfer .........................................................104, 105
Shooting Direction ...........................................................40
N
O
Slideshow .............................................................................63
Slideshow with music .....................................................64
Slow Synchro .....................................................................32
Smart zoom .........................................................................76
Smile Detection Sensitivity ..........................................57
Optical zoom ................................................................29, 76
Smile Shutter ......................................................................33
OS ..........................................................................................103
Snow.......................................................................................26
P
Index
NTSC .............................................................................86, 102
MENU/Settings
Search
S
Operation
Search
Macintosh computer ......................................................103
Soft Snap ..............................................................................26
Software ..............................................................................104
PAL.................................................................................86, 102
Spot AF .................................................................................52
PC ..........................................................................................103
Spot metering .....................................................................54
Pet ............................................................................................26
SteadyShot ...........................................................................62
PictBridge ....................................................................87, 110
Sweep Panorama ...............................................................24
Pixel ........................................................................................43
Playback ...............................................................................35
T
Playback zoom ...................................................................36
Trimming (Resize) ...........................................................67
PMB .....................................................................................104
Troubleshooting ..............................................................112
PMB Portable ...................................................................108
TV .........................................................................................100
Power Save ..........................................................................91
Twilight.................................................................................26
Precision digital zoom ....................................................76
Twilight Portrait ................................................................26
Print ................................................................................70, 110
Print order mark ........................................................70, 111
U
Program Auto .....................................................................22
Unsharp masking ..............................................................67
Protect ....................................................................................69
USB Connect ......................................................................87
PTP .........................................................................................87
130GB
V
Video Out .............................................................................86
View Mode ..........................................................................66
Table of
contents
VGA .......................................................................................41
W
Warning indicators and messages ...........................120
White Balance ....................................................................50
Z
Zoom ......................................................................................29
Operation
Search
Windows computer ........................................................103
MENU/Settings
Search
Index
131GB
Notes on the License
MENU/Settings
Search
NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL,
INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM
MPEG LA, LLC.
SEE
HTTP://WWW.MPEGLA.COM
Operation
Search
THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO
LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR
(i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD
(“MPEG-4 VIDEO”)
AND/OR
(ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED
IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED
FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO.
Table of
contents
“C Library”, “Expat”, “zlib”, “dtoa”, “pcre” and “libjpeg” software are provided in the camera.
We provide this software based on license agreements with their owners of copyright. Based on
requests by the owners of copyright of these software applications, we have an obligation to
inform you of the following. Please read the following sections.
Read “license1.pdf” in the “License” folder on the CD-ROM. You will find licenses (in English)
of “C Library”, “Expat”, “zlib”, “dtoa”, “pcre” and “libjpeg” software.
On GNU GPL/LGPL applied software
Index
The software that is eligible for the following GNU General Public License (hereinafter referred
to as “GPL”) or GNU Lesser General Public License (hereinafter referred to as “LGPL”) are
included in the camera.
This informs you that you have a right to have access to, modify, and redistribute source code for
these software programs under the conditions of the supplied GPL/LGPL.
Source code is provided on the web. Use the following URL to download it.
http://www.sony.net/Products/Linux/
We would prefer you do not contact us about the contents of source code.
Read “license2.pdf” in the “License” folder on the CD-ROM. You will find licenses (in English)
of “GPL”, and “LGPL” software.
To view the PDF, Adobe Reader is needed. If it is not installed on your computer, you can
download it from the Adobe Systems web page:
http://www.adobe.com/
Regarding the license for “Music Transfer” included on the
CD-ROM (supplied)
MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and
Thomson.
132GB
