Operating Instructions

Manual de instrucciones

High Defi nition Hospitality Plasma Display

Pantalla de plasma de alta defi nición para la industria hotelera

Model No.

Número de modelo.

TH-37PR10U

TH-42PR10U

English

Español

The illustration shown is an image.

Before connecting, operating or adjusting this product, please read these instructions completely.

Please keep this manual for future reference.

La ilustración mostrada es una imagen.

Antes de conectar, utilizar o ajustar este producto, lea completamente este manual de instrucciones; y guárdelo para consultarlo en el futuro en caso de ser necesario.

TQB2AA0801-1

2

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: To reduce the risk of electric shock, do not remove cover or back.

No user-serviceable parts inside. Refer servicing to qualifi ed service personnel.

The lightning flash with arrow-head within a triangle is in tend ed to tell the user that parts inside the product are a risk of electric shock to per sons.

The exclamation point within a t r i a n g l e i s i n t e n d e d t o tell the user that important o p e r a t i n g a n d s e r v i c i n g instructions are in the papers with the ap pli ance.

WARNING : To prevent damage which may result in fire or shock hazard, do not expose this apparatus to rain or mois ture.

Do not place containers with water (flower vase, cups, cosmetics, etc.) above the set.

(including on shelves above, etc.)

WARNING : 1) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personnel.

2) Do not remove the grounding pin on the power plug. This apparatus is equipped with a three pin grounding-type power plug. This plug will only fit a grounding-type power outlet. This is a safety fea ture.

If you are unable to insert the plug into the outlet, contact an electrician.

Do not defeat the purpose of the grounding plug.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi ers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fi t into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments / accessories specifi ed by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specifi ed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.

3

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment from your new Plasma Display.

To obtain maximum benefit from your set, please read these Instructions before making any adjustments, and retain them for future reference.

Retain your purchase receipt as well, and record the model number and serial number of your set in the space provided on the rear cover of these instructions.

4

Table of Contents

Important Safety Instructions .................................. 3

FCC STATEMENT ...................................................... 5

Safety Precautions ................................................... 6

Maintenance .............................................................. 7

Accessories .............................................................. 8

Accessories Supplied .............................................. 8

Connections .............................................................. 9

PC Input Terminals connection .............................. 10

SERIAL Terminals connection ............................... 11

Power ON / OFF ..................................................... 12

Initial selections ..................................................... 13

Selecting the input signal ...................................... 13

Selecting the On-Screen Menu Language ............ 13

Basic Controls ........................................................ 14

On-Screen Menu Displays ..................................... 16

ASPECT Controls ................................................... 18

Adjusting POS. /SIZE ............................................. 19

MULTI PIP ................................................................ 20

Advanced PIP .......................................................... 21

PICTURE Adjustments ........................................... 22

ADVANCED SETTINGS ........................................ 23

SOUND Adjustment ................................................ 24

MUTE .................................................................... 24

Digital Zoom ............................................................ 25

PRESENT TIME SETUP / SET UP TIMER .............. 26

PRESENT TIME SETUP ....................................... 26

SET UP TIMER ..................................................... 27

SCREENSAVER (For preventing image retention) .. 28

Setup of SCREENSAVER Time ............................ 29

Reduces screen image retention ........................... 29

SIDE BAR ADJUST ............................................... 30

Reduces power consumption ............................... 31

Customizing the Input labels ................................. 31

SET UP for Input Signals ....................................... 32

COMPONENT / RGB IN SELECT ......................... 32

3D Y/C FILTER ...................................................... 32

COLOR SYSTEM / Panasonic AUTO ................... 33

3:2 PULLDOWN / VIDEO NR ................................ 33

SYNC .................................................................... 34

REFRESH RATE ................................................... 34

H-FREQ. (kHz) / V-FREQ. (Hz) ............................. 34

Options Adjustments ............................................. 35

Weekly Command Timer ....................................... 39

Shipping condition ................................................. 41

Troubleshooting ..................................................... 42

PC input signals ..................................................... 43

Command list of Weekly Command Timer ........... 44

Specifications ......................................................... 45

Limited Warranty .................................................... 46

LIMITED WARRANTY STATEMENT ....................... 47

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced technician for help.

This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC CAUTION:

To assure continued compliance, use only shielded interface cables when connecting to computer or peripheral devices. Any changes or modifications not expressly approved by Panasonic Corporation of

North America could cause harmful interference and would void the user’s authority to operate this device.

FCC Declaration of Conformity

Model No. TH-37PR10U, TH-42PR10U

Responsible Party: Panasonic Corporation of North America

One Panasonic Way, Secaucus, NJ 07094

Contact Source: Panasonic Professional Display Company

Panasonic Plasma Concierge 1-888-972-6276 email: [email protected]

CANADIAN NOTICE:

This Class B digital apparatus complies with Canadian ICES-003.

Note:

Do not allow a still picture to be displayed for an extended period, as this can cause permanent image retention to remain on the Plasma Display.

Examples of still pictures include logos, video games, computer images, teletext and images displayed in NORMAL mode.

Trademark Credits

• VGA is a trademark of International Business Machines Corporation.

• Macintosh is a registered trademark of Apple Computer, USA.

• S-VGA is a registered trademark of the Video Electronics Standard Association.

Even if no special notation has been made of company or product trademarks, these trademarks have been fully respected.

5

Safety Precautions

CAUTION

This Plasma Display is for use only with the following optional accessories. Use with any other type of optional

accessories may cause instability which could result in the possibility of injury.

(All of the following accessories are manufactured by Matsushita Electric Industrial Co., Ltd.)

• Pedestal ...................................................................................................................... TY-ST09GR-K

• Wall-hanging bracket (vertical) .................................................................................... TY-WK42PV3U

• Wall-hanging bracket (angled) .................................................................................... TY-WK42PR3U

• BNC Component Video Terminal Board ...................................................................... TY-42TM6A

• BNC Composite Video Terminal Board ....................................................................... TY-42TM6B

• BNC Dual Video Terminal Board ................................................................................. TY-FB9BD

• Ir Through Terminal Board .......................................................................................... TY-FB9RT

• RCA Component Video Terminal Board ...................................................................... TY-42TM6Z

• RCA Composite Video Terminal Board ....................................................................... TY-42TM6V

• PC Input Terminal Board ............................................................................................. TY-42TM6P

• RGB (Digital) Terminal Board ...................................................................................... TY-42TM6D

• HDMI Terminal Board .................................................................................................. TY-FB8HM

• AV Terminal Box .......................................................................................................... TY-TB10AV

Always be sure to ask a qualified technician to carry out set-up.

Small parts can present choking hazard if accidentally swallowed. Keep small parts away from young children. Discard unneeded small parts and other objects, including packaging materials and plastic bags/sheets to prevent them from being played with by young children, creating the potential risk of suffocation.

When using the Plasma Display

Do not bring your hands, face or objects close to the ventilation holes of the Plasma Display.

• Top of the Plasma Display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes. Burns or personal injuries can happen if any body parts are brought too close. Placing any object near the top of the display could also result in heat damages to the object as well as to the Display if its ventilation holes are blocked.

Be sure to disconnect all cables before moving the

Plasma Display.

• Moving the Display with its cables attached might damage the cables which, in turn, can cause fire or electric shock.

Disconnect the power plug from the wall outlet as a safety precaution before carrying out any cleaning.

• Electric shocks can result if this is not done.

Clean the power cable regularly to prevent it from becoming dusty.

• Built-up dust on the power cord plug can increase humidity which might damage the insulation and cause fire. Unplug the cord from the wall outlet and clean it with a dry cloth.

This Plasma Display radiates infrared rays, therefore it may affect other infrared communication equipment.

Install your infrared sensor in a place away from direct or reflected light from your Plasma Display.

Note:

Do not allow a still picture to be displayed for an extended period, as this can cause a permanent image retention to remain on the Plasma Display.

Examples of still pictures include logos, video games, computer images, teletext and images displayed in

NORMAL mode.

6

Safety Precautions / Maintenance

WARNING

Setup

Do not place the Plasma Display on sloped or unstable surfaces.

• The Plasma Display may fall off or tip over.

Do not place any objects on top of the Plasma

Display.

• If water spills onto the Plasma Display or foreign objects get inside it, a short-circuit may occur which could result in fire or electric shock. If any foreign objects get inside the Plasma Display, please consult an Authorized

Service Center.

Do not cover the ventilation holes.

• Doing so may cause the Plasma Display to overheat, which can cause fire or damage to the Plasma

Display.

If using the pedestal (optional accessory), leave a space of 3

15

/

16

” (10 cm) or more at the top, left and right, 2

3

/

8

(6 cm) or more at the bottom, and 2

3

/

4

” (7 cm) or more at the rear. If using some other setting-up method, leave a space of 3

15

/

16

” (10 cm) or more at the top, bottom, left and right, and 2

3

/

4

” (7 cm) or more at the rear.

Transport only in upright position!

• Transporting the unit with its display panel facing upright or downward may cause damage to the internal circuitry.

AC Power Supply Cord

The Plasma Display is designed to operate on 120 V

AC, 50/60 Hz.

Do not use any power supply cord other than that provided with this unit.

• Doing so may cause fire or electric shocks.

Securely insert the power cord plug as far as it will go.

• If the plug is not fully inserted, heat may be generated which could cause fire. If the plug is damaged or the wall socket plate is loose, they should not be used.

Do not handle the power cord plug with wet hands.

• Doing so may cause electric shocks.

Do not do anything that might damage the power cable.

When disconnecting the power cable, hold the plug, not the cable.

• Do not make any modifications, place heavy objects on, place near hot objects, heat, bend, twist or forcefully pull the power cable. Doing so may cause damage to the power cable which can cause fire or electric shock.

If damage to the cable is suspected, have it repaired at an Authorized Service Center.

If the Plasma Display will not be used for a long period of time, unplug the power cord from the wall outlet.

If problems occur during use

If a problem occurs (such as no picture or no sound), or if smoke or an abnormal odor is detected from the

Plasma Display, unplug the power cord immediately.

• Continuous use of the Display under these conditions might cause fire or permanent damage to the unit.

Have the Display evaluated at an Authorized Service

Center. Services to the Display by any unauthorized personnel are strongly discouraged due to its high voltage dangerous nature.

If water or foreign objects get inside the Plasma Display, if the Plasma Display is dropped, or if the cabinet becomes damaged, disconnect the power cord plug immediately.

• A short may occur, which could cause fire. Contact an

Authorized Service Center for any repairs that need to be made.

Maintenance

The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning cloth or a soft, lint-free cloth.

• If the surface is particularly dirty, wipe with a soft, lint-free cloth which has been soaked in pure water or water in which neutral detergent has been diluted 100 times, and then wipe it evenly with a dry cloth of the same type until the surface is dry.

• Do not scratch or hit the surface of the panel with fingernails or other hard objects, otherwise the surface may become damaged. Furthermore, avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the surface may be adversely affected.

If the cabinet becomes dirty, wipe it with a soft, dry cloth.

• If the cabinet is particularly dirty, soak the cloth in water to which a small amount of neutral detergent has been added and then wring the cloth dry. Use this cloth to wipe the cabinet, and then wipe it dry with a dry cloth.

• Do not allow any detergent to come into direct contact with the surface of the Plasma Display. If water droplets get inside the unit, operating problems may result.

• Avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the cabinet surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods in contact with articles made from rubber or PVC.

7

8

Accessories

Accessories Supplied

Check that you have the Accessories and items shown

Operating Instruction book AC cord Fixing bands × 2

The remote control is not included with this set. Available for purchase separately.

Object model : EUR7636070R

Connections

AC cord connection (see page 12)

– AC cord fixing

To tighten:

Close

Unplug the AC cord

1

Push until t h e h o o k clicks.

2

1

Plug the AC cord into the display unit.

Plug the AC cord until it clicks.

2

Fix the AC cord with

Note:

Make sure that the AC cord is locked on both the left and right sides.

the clamper which is attached to the unit.

Open

2. Pull off.

1. Keep the

knob

pressed.

Unplug the AC cord pressing the two knobs.

Note:

When disconnecting the AC cord, be absolutely sure to disconnect the AC cord plug at the socket outlet first.

– Cable fixing bands

Secure any excess cables with bands as required.

Pass the attached cable fixing band through the clip as shown in the figure.

To secure cables connected to Terminals, wrap the cable fixing band around them then pass the pointed end through the locking block, as shown in the figure.

While ensuring there is sufficient slack in cables to minimize stress (especially in the power cord), firmly bind all cables with the supplied fixing band.

To loosen:

Push the catch

Pull

1 2

Pull

Optional Terminal

Board Insert Slot

(covered)

AUDIO

SERIAL

From EXTERNAL monitor terminal on

Computer (see page 10)

From SERIAL

Terminal on Computer

(see page 11)

9

Connections

PC Input Terminals connection

COMPUTER

PC IN

AUDIO

Conversion adapter

(if necessary)

RGB

PC cable

Mini D-sub 15p

Audio

Connect a cable which matches the audio output terminal on the computer.

Stereo plug

Notes:

• Due to space limitations, occasionally you may have trouble connecting Mini D-sub 15P cable with ferrite core to PC input Terminal.

• Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical scanning frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200 lines.)

• The display resolution is a maximum of 768 × 720 dots (TH-37PR10U), 768 × 768 dots (TH-42PR10U) when the aspect mode is set to “NORMAL”, and 1,024 × 720 dots (TH-37PR10U), 1,024 × 768 dots (TH-42PR10U) when the aspect mode is set to “FULL”. If the display resolution exceeds these maximums, it may not be possible to show fine detail with sufficient clarity.

• The PC input terminals are DDC2B-compatible. If the computer being connected is not DDC2B-compatible, you will need to make setting changes to the computer at the time of connection.

• Some PC models cannot be connected to the set.

• There is no need to use an adapter for computers with DOS/V compatible Mini D-sub 15P terminal.

• The computer shown in the illustration is for example purposes only.

• Additional equipment and cables shown are not supplied with this set.

• Do not set the horizontal and vertical scanning frequencies for PC signals which are above or below the specified frequency range.

• Component Input is possible with the pin 1, 2, 3 of the D-sub 15P Connector.

• Change the “COMPONENT/RGB-IN SELECT” setting in the “SET UP” menu to “COMPONENT”

(when component connection) or “RGB” (when RGB signal connection). (see page 32)

Signal Names for Mini D-sub 15P Connector

5

10

4

9

3

8

2

7

1

6

15 14 13 12 11

Pin Layout for PC Input

Terminal

Pin No.

Signal Name

1 R (P

R

/C

R

)

2 G (Y)

3

4

5

B (P

B

/C

B

)

NC (not connected)

GND (Ground)

Pin No.

6

7

8

9

10

Signal Name Pin No.

GND (Ground) 11

GND (Ground)

12

13 GND (Ground)

NC (not connected)

GND (Ground)

14

15

Signal Name

NC (not connected)

SDA

HD/SYNC

VD

SCL

10

Connections

SERIAL Terminals connection

The SERIAL terminal is used when the Plasma Display is controlled by a computer.

COMPUTER

RS-232C Straight cable

SERIAL

1 2 3 4 5

6 7 8 9

Pin layout for SERIAL Terminal

D-sub 9p

Notes:

• Use the RS-232C cable to connect the computer to the Plasma Display.

• The computer shown is for example purposes only.

• Additional equipment and cables shown are not supplied with this set.

The SERIAL terminal conforms to the RS-232C interface specification, so that the Plasma Display can be controlled by a computer which is connected to this terminal.

The computer will require software which allows the sending and receiving of control data which satisfies the conditions given below. Use a computer application such as programming language software. Refer to the documentation for the computer application for details.

Communication parameters

Signal level

Synchronization method

Baud rate

Parity

Character length

Stop bit

Flow control

RS-232C compliant

Asynchronous

9600 bps

None

8 bits

1 bit

-

RS-232C Conversion cable

D-sub 9-pin female Details

2

3

5

R X D

T X D

GND

Non use 4

6

7

8

Shorted

1

9 NC

Basic format for control data

The transmission of control data from the computer starts with a STX signal, followed by the command, the parameters, and lastly an ETX signal in that order.

If there are no parameters, then the parameter signal does not need to be sent.

STX C1 C2 C3

Start

(02h)

: P1 P2 P3 P4 P5 ETX

Colon

3-character command (3 bytes)

Parameter(s)

(1 - 5 bytes)

End

(03h)

Notes:

• If multiple commands are transmitted, be sure to wait for the response for the first command to come from this unit before sending the next command.

• If an incorrect command is sent by mistake, this unit will send an “ER401” command back to the computer.

• SL1A, SL1B, SL2A and SL2B of Command IMS are available only when a dual input terminal board is attached.

Command

Command Parameter

PON None

POF

AVL

None

**

AMT

IMS

0

1

None

SL1

SL2

SL3

PC1

SL1A

SL1B

SL2A

SL2B

Control details

Power ON

Power OFF

Volume 00 - 63

Audio MUTE OFF

Audio MUTE ON

Input select (toggle)

Slot1 input

Slot2 input

Slot3 input

PC input

Slot1 input (INPUT1A)

Slot1 input (INPUT1B)

Slot2 input (INPUT2A)

Slot2 input (INPUT2B)

DAM None

NORM

ZOOM

FULL

JUST

SELF

Screen mode select (toggle)

NORMAL (4 : 3)

ZOOM

FULL

JUST

Panasonic AUTO

With the power off, this display responds to PON command only.

11

Power ON / OFF

Connecting the AC cord plug to the Plasma Display.

Fix the AC cord plug securely to the Plasma Display with the clamper. (see page 9)

Connecting the plug to the Wall Outlet

Note:

When disconnecting the AC cord, be absolutely sure to disconnect the AC cord plug at the socket outlet first.

Press the Power switch on the Plasma Display to turn the set on: Power-On.

Power Indicator: Green

Example: The screen below is displayed for a while after the

Plasma Display is turned on. (setting condition is an example.)

Remote Control Sensor

POWER

Power Indicator

Press the button on the remote control to turn the Plasma Display off.

Power Indicator: Red (standby)

Press the button on the remote control to turn the Plasma Display on.

Power Indicator: Green

Turn the power to the Plasma Display off by pressing the switch on the unit, when the Plasma Display is on or in standby mode.

Note:

During operation of the power management function, the power indicator turns orange in the power off state.

12

Initial selections

Selecting the input signal

Select the input signals to be connected by installing the optional Terminal Boards.

Press to select the input signal to be played back from the equipment which has been connected to the Plasma

Display.

Input signals will change as follow:

INPUT1 INPUT2 INPUT3 PC

Notes:

• Selecting is also possible by pressing the INPUT button on the unit.

• Input terminal will not be selected if the terminal board is not installed into the

SLOT.

• Select to match the signals from the source connected to the component/RGB input terminals. (see page 32)

• In 2 screen display, the same input mode cannot be selected for the main picture and sub picture.

INPUT MENU

VOL

ENTER/

Swing up the door at “PULL”.

Selecting the On-Screen Menu Language

Press to display the SET UP menu.

Press to select OSD LANGUAGE.

Press to select your preferred language.

Selectable languages

English(UK)

Deutsch

Français

Italiano

Español

ENGLISH(US)

.......(Chinese)

.......(Japanese)

Русский

.......(Russian)

SET UP 1/2

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

RGB

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

13

14

Basic Controls

Remote control sensor

INPUT button

(INPUT1, INPUT2, INPUT3 and

PC selection)

(see page 13)

POWER

INPUT MENU

VOL

ENTER/

Power Indicator

The Power Indicator will light.

• Power-OFF .... Indicator not illuminated (The unit will still consume some power as long as the power cord is still inserted into the wall outlet.)

• Standby ......... Red

• Power-ON ...... Green

• DPMS .............Orange (With PC input signal and during operation of PC’s screensaver.)

Main Power On / Off Switch

How to release button lock

MENU and ENTER/

■ buttons are locked before shipping.

You can unlock them with unit buttons.

1. Press +/

▲ 4 times.

2. Press INPUT 4 times.

3. Press –/

▼ 4 times.

4. Press ENTER/

■.

Note:

After unlocking the buttons, Button lock in

OPTIONS menu is set to “Off”. (see page 36)

SURROUND button

The surround setting switches on and off each time the SURROUND button is pressed.

The benefits of surround sound are enormous. You can be completely enveloped in sound; just as if you were at a concert hall or cinema.

Note:

The surround settings are memorized separately for each AUDIO MENU (STANDARD, DYNAMIC,

CLEAR).

ON OFF

Volume Adjustment

Volume Up “+” Down “–”

When the menu screen is displayed:

“+” : press to move the cursor up

“–” : press to move the cursor down

(see page 16)

Enter / Aspect button

This button is locked by initial setting.

(see page 16, 18)

MENU Screen ON / OFF

This button is locked by initial setting.

Each time the MENU button is pressed, the menu screen will switch. (see page 16)

Normal Viewing

SOUND


POS. /SIZE

SET UP

N button (see page 19, 22, 23, 24)

POS. /SIZE button (see page 19)

PICTURE button (see page 22)

INPUT button

(INPUT1, INPUT2, INPUT3 and PC selection)

Press to select INPUT1, INPUT2, INPUT3 and PC input

SLOTS sequentially. (see page 13)

Sound mute On / Off (see page 24)

Numeric buttons

ASPECT button

Press to adjust the aspect. (see page 18)

MULTI Window buttons (see page 20)

SURROUND ON

Basic Controls

The remote control is not included with this set. Available for purchase separately.

Object model : EUR7636070R

Standby (ON / OFF) button

The Plasma Display must first be plugged into the wall outlet and turned on at the power switch (see page 12).

Press ON to turn the Plasma Display On, from Standby mode. Press OFF to turn the Plasma Display Off to Standby mode.

R button (see page 17)

Press the R button to return to previous menu screen.

Status button

POSITION buttons

ACTION button

Press to make selections.

Press the “Status” button to display the current system status.

P C

N O R M A L

1

SOUND button

(see page 24)

OFF TIMER 90

2

3

1

Input label

2

Aspect mode (see page 18)

3

Off timer

The off timer indicator is displayed only when the off timer has been set.

SET UP button (see page 16, 17)

DIRECT INPUT buttons

Press the INPUT “1”, “2”, “3” or “PC” input mode selection button to select the INPUT mode.

This button is used to switch directly to INPUT mode.

These buttons can only display the slot which is installed. If you press the button whose slot is not installed, it automatically displays the current input signal.

When a dual input terminal board is attached, A or B is displayed depending on the selected input signal. (Ex. INPUT1A, INPUT1B)

Note:

Image retention (image lag) may occur on the plasma display panel when a still picture is kept on the panel for an extended period. The function that darkens the screen slightly is activated to prevent image retention (see page 42), this function is not the perfect solution to image retention.

Channel Adjustment

You can use this button when U/V Tuner Board with MATE I/F is installed

(optional accessories). Refer to each Board's Operating Instruction for detail.

Volume Adjustment

Press the Volume Up “+” or Down “–” button to increase or decrease the sound volume level.

OFF TIMER button

The Plasma Display can be preset to switch to stand-by after a fixed period. The setting changes to 30 minutes, 60 minutes, 90 minutes and

0 minutes (off timer cancelled) each time the button is pressed.

30 60 90

0

When three minutes remain, “OFF TIMER 3” will flash.

The off timer is cancelled if a power interruption occurs.

Digital Zoom (see page 25)

Press to access

Digital Zoom.

This displays an enlargement of the designated part of the displayed image.

15

On-Screen Menu Displays

The MENU button on the unit can also be pressed.

To PICTURE adjust menu

(see page 22)

PICTURE 1/2

NORMALIZE NORMAL

PICTURE MENU


BRIGHTNESS

COLOR

TINT

SHARPNESS

STANDARD

25

0

0

0

5


COLOR TEMP

COLOR MANAGEMENT

ADVANCED SETTINGS

NORMAL

OFF

ON

2/2

1

Press to select .

INPUT MENU ENTER/

VOL

Each time the MENU button is pressed, the menu screen will switch.

Normal Viewing PICTURE SETUP

SOUND POS. /SIZE

[ from the unit ]

INPUT MENU

1

VOL

2

ENTER/

1

2

Press to select.

Press to access each adjust screen.

Press to select

“ON”.

Press to enter

ADVANCED

SETTINGS.

SET UP 1/2

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

RGB

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

To ADVANCED SETTINGS

(see page 22, 23)

ADVANCED SETTINGS

1/2

NORMALIZE

NORMAL

BLACK EXTENSION

INPUT LEVEL

GAMMA

AGC

0

0

2.2

OFF

2/2 ADVANCED SETTINGS

W/B HIGH R

W/B HIGH G

W/B HIGH B

W/B LOW R

W/B LOW G

W/B LOW B

0

0

0

0

0

0

SET UP

SCREENSAVER

MULTI DISPLAY SETUP

SET UP TIMER

PRESENT TIME SETUP

2/2

16

To POS. /SIZE adjust menu (see page 19)

During “VIDEO (S VIDEO)”,

“COMPONENT” and “Digital” input signal.

POS. /SIZE

During “RGB/PC” input signal.

POS. /SIZE

NORMALIZE

H-POS

H-SIZE

V-POS

V-SIZE

NORMAL

0

0

0

0

NORMALIZE

H-POS

H-SIZE

V-POS

V-SIZE

NORMAL

CLOCK PHASE

0

0

0

0

0

To SOUND adjust menu

(see page 24)

SOUND

NORMALIZE

AUDIO MENU

NORMAL

BASS

MID

TREBLE

BALANCE

SURROUND

AUDIO OUT (PIP)

STANDARD

0

0

0

0

OFF

MAIN

On-Screen Menu Displays

Note:

Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting.

To SIGNAL screen for VIDEO

(S VIDEO) (see page 32, 33)

SIGNAL

[ VIDEO ]

[ from the unit ]

2 Press to access e a c h a d j u s t screen.

INPUT MENU

VOL

ENTER/

Press to return to next menu screen.

To SIGNAL screen for

COMPONENT (see page 33)

SIGNAL

[ COMPONENT ]

To SIGNAL screen for RGB

(see page 33, 34)

SIGNAL

[ RGB ]

Press the R button to return to previous menu.

To SIGNAL screen for Digital

(see page 33, 34)

SIGNAL

[ Digital ]

3D Y/C FILTER (NTSC)

COLOR SYSTEM

3 : 2 PULLDOWN

Panasonic AUTO (4 : 3)

VIDEO NR

ON

AUTO

OFF

NORMAL

OFF

3 : 2 PULLDOWN

VIDEO NR

OFF

OFF

SYNC

3 : 2 PULLDOWN

VIDEO NR

H-FREQ.

V-FREQ.

33.8

60.0

kHz

Hz

AUTO

OFF

OFF

3 : 2 PULLDOWN

VIDEO NR

H-FREQ.

V-FREQ.

33.8

60.0

kHz

Hz

OFF

OFF

Note: “SIGNAL” setup menu displays a different setting condition for each input signal. (see page 13)

To setup SCREENSAVER

(See page 28-30)

SCREENSAVER

PRESENT TIME OF DAY 15:00

START

FUNCTION

MODE

START TIME

FINISH TIME

WHITE BAR SCROLL

TIME OF DAY

6:15

12:30

SIDE BAR ADJUST

WOBBLING

PEAK LIMIT

BRIGHT

OFF

OFF

SCREENSAVER

PRESENT TIME OF DAY 15:00

START

FUNCTION WHITE BAR SCROLL

MODE

SHOW DURATION

INTERVAL

12:00

SAVER DURATION

SIDE BAR ADJUST

WOBBLING

PEAK LIMIT

3:00

BRIGHT

OFF

OFF

To SET UP TIMER selection screen. (see page 26, 27)

SET UP TIMER

PRESENT TIME OF DAY 10:00

POWER ON FUNCTION

POWER ON TIME

POWER OFF FUNCTION

POWER OFF TIME

OFF

0:00

OFF

0:00

To PRESENT TIME SETUP.

(see page 26)

PRESENT TIME SETUP

PRESENT TIME OF DAY MON 99:99

SET

DAY

PRESENT TIME OF DAY

MON

99:99

Press to select START TIME/ FINISH TIME (When TIME OF DAY is selected).

Press to select SHOW DURATION/ SAVER DURATION (When

INTERVAL is selected).

SCREENSAVER

Press to set up.

PRESENT TIME OF DAY 15:00

START

FUNCTION

MODE

START TIME

FINISH TIME

SIDE BAR ADJUST

WOBBLING

PEAK LIMIT

WHITE BAR SCROLL

TIME OF DAY

6:15

12:30

BRIGHT

OFF

OFF

Press the R button to return to

“SET UP” menu.

SCREENSAVER

PRESENT TIME OF DAY 15:00

START

FUNCTION

MODE

WHITE BAR SCROLL

SHOW DURATION

SAVER DURATION

INTERVAL

12:00

3:00

SIDE BAR ADJUST

WOBBLING

PEAK LIMIT

BRIGHT

OFF

OFF

Press to select POWER ON

TIME / POWER OFF TIME.

Press to set up POWER

ON TIME / POWER OFF

TIME.

SET UP TIMER

PRESENT TIME OF DAY 10:00

POWER ON FUNCTION

POWER ON TIME

POWER OFF FUNCTION

POWER OFF TIME

OFF

12:00

OFF

18:00

Press the R button to return to

“SET UP” menu.

SET UP TIMER

PRESENT TIME OF DAY 10:00

POWER ON FUNCTION

POWER ON TIME

POWER OFF FUNCTION

POWER OFF TIME

OFF

12:00

OFF

18:00

17

ASPECT Controls

The Plasma Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format picture.

[from the unit]

Press repeatedly to move through the aspect options:

NORMAL ZOOM FULL

Panasonic AUTO JUST

Note:

When selecting an input slot that attaches BNC Dual Video Terminal

Board (TY-FB9BD), Panasonic AUTO cannot be selected.

The aspect mode changes each time the ENTER button is pressed.

INPUT MENU ENTER/

VOL

[During MULTI PIP Operations]

• Picture and Picture, Picture in Picture :

• Others

NORMAL FULL

: Aspect switching is not possible.

Notes:

• For PC signal input, the mode switches between “NORMAL”, “ZOOM” and “FULL” only.

• For a 1125 (1080) / 60i · 50i · 24p · 25p · 30p · 24sF, 1250 (1080) / 50i, 750 (720) / 60p · 50p signal input, the mode is set to “FULL” mode, and switching is not possible.

• Panasonic AUTO can be selected only during Video signal input.

• The aspect mode is memorized separately for each input terminal.

Mode

4

NORMAL

Picture Explanation

NORMAL will display a 4:3 picture at its standard 4:3 size.

NORMAL

3

ZOOM

4

3

16

ZOOM

9

ZOOM mode magnifies the central section of the picture.

FULL

4

3

16

FULL

9

FULL will display the picture at its maximum size but with slight elongation.

JUST

4

3

16

JUST

9

JUST mode will display a 4:3 picture at its maximum size but with aspect correction applied to the center of the screen so that elongation is only apparent at the left and right edges of the screen. The size of the picture will depend on the original signal.

Panasonic

AUTO

4

3

16

Panasonic AUTO

9

For an elongated image Image is expanded

4

3

Changes in accordance with the

Panasonic AUTO mode setting (see page 33).

For a 4:3 image

The display will automatically become enlarged (depending on the picture source), allowing you to view the picture at its maximum size.

Notes:

• Panasonic AUTO mode is designed to automatically adjust the aspect ratio to handle a mix of 16:9 and 4:3 program material. Certain 4:3 program material, such as stock market data screens, may occasionally cause the image size to change unexpectedly. When viewing such programs, it is recommended that the ASPECT be set to NORMAL.

• If adjusting the PICTURE V-POS/V-SIZE in Panasonic AUTO with FULL mode, the adjustment is not memorized. When exiting the mode, the screen will return to a former adjustment.

• Panasonic AUTO can not be selected while BNC Dual Video Terminal

Board (TY-FB9BD) is installed.

Note: Do not allow the picture to be displayed in NORMAL mode for an extended period, as this can cause a permanent image retention to remain on the Plasma Display Panel.

18

1

2

Adjusting POS. /SIZE

Press to display the POS. /SIZE menu.

Press to select H-POS / H-SIZE / V-POS / V-SIZE /

CLOCK PHASE.

Press to adjust POS. /SIZE.

3

4

Press to exit from adjust mode.

Notes:

• Adjustment details are memorized separately for different input signal formats

(Adjustments for component signals are memorized for 525 (480) / 60i · 60p, 625

(575) / 50i · 50p, 1125 (1080) / 60i · 50i · 24p · 25p · 30p · 24sF, 1250 (1080) / 50i,

750 (720) / 60p · 50p each, and RGB/PC/Digital signals are memorized for each frequency.)

• If a “Cue” or “Rew” signal from a VCR or DVD player is received, the picture position will shift up or down. This picture position movement cannot be controlled by the

POS. /SIZE function.

• If adjusting the PICTURE V-POS / V-SIZE in Panasonic AUTO with FULL mode, the adjustment is not memorized. When exiting the mode, the screen will return to a former adjustment.

H-POS

Adjust the horizontal position.

During “VIDEO (S VIDEO)”,

“COMPONENT” and “Digital” input signal.

POS. /SIZE

NORMALIZE

H-POS

H-SIZE

V-POS

V-SIZE

NORMAL

During “RGB / PC” input signal.

POS. /SIZE

NORMALIZE

H-POS

NORMAL

H-SIZE

V-POS

V-SIZE

CLOCK PHASE

H-SIZE

Adjust the horizontal size.

0

0

0

0

0

0

0

0

0

V-POS

Adjust the vertical position.

V-SIZE

Adjust the vertical size.

CLOCK PHASE

(RGB/PC in mode)

Eliminate the flickering and distortion.

Helpful Hint ( /

NORMALIZE

Normalization)

While the POS. /SIZE display is active, if either the N button on the remote control is pressed at any time or the ACTION

( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

19

MULTI PIP

Press repeatedly.

Each time pressing this button main picture and sub picture will be displayed as follows below.

Normal

Viewing

[Picture and Picture]

Main picture Sub picture

[Picture out Picture]

Main picture Sub picture

[Picture in Picture]

Main picture Sub picture

A B

A

B

A

B

Press to swap main picture and sub picture.

B A

B

A

B

A

Press to select the input mode.

Under main Picture and sub picture display, select the picture which you would like to change input modes.

Notes:

• The sub picture sound is heard while a sub picture operation is underway.

• The sub picture operation automatically returns to the main picture operation if a sub picture operation has not been performed for about 5 seconds or if any of the remote control buttons is pressed (except button).

[Example]

Main picture label is bright Sub picture label is bright

A

PC1

VIDEO2

B

Input modes switching is possible

Main picture label is changed Sub picture label is changed

VIDEO2

VIDEO1

A

PC1

VIDEO2

B

PC1

VIDEO2

C

A

B D

Press to change input signal.

Picture is changed

Press to move the sub picture.

Each time the location of the sub picture will be moved.

Notes:

• This button is effective only in the picture in picture.

• The sub picture may be hidden by the on screen display, depending on its position.

Notes:

• If “Input lock” in Options menu is set to other than “Off”, MULTI PIP function isn’t available.

• Sound output is from the picture which is selected in Audio OUT(PIP) (See page 24).

• In 2 screen display, the same input mode cannot be selected for the main picture and sub picture.

• The main picture and sub picture are processed by different circuits, resulting in a slight difference in the clarity of the pictures. There may also be a difference in the picture quality of the sub picture depending on the type of signals displayed on the main picture and depending on the 2-picture display mode.

• Due to the small dimensions of the sub pictures, these sub pictures cannot be shown in detail.

• Computer screen picture is displayed in a simplified format, and it may not be possible to discern details on them satisfactorily.

• Following combinations of two analog signals cannot be displayed simultaneously.

Component - Component, Component - PC (RGB), PC (RGB) - Component, PC (RGB) - PC (RGB)

20

1

2

Advanced PIP

Press to display the Setup menu.

Press to select “OSD Language”.

3

4

Press and hold until the Options menu is displayed.

Press to select Advanced PIP.

5

Press to adjust the menu.

Off : Sets normal two screen display mode

(see page 20).

On : Sets Advanced PIP mode.

Options

Weekly Command Timer

Onscreen display

Initial INPUT

Initial VOL level

Maximum VOL level

INPUT lock

Button lock

Remocon User level

Advanced PIP

On

Off

Off

Off

Off

Off

Off

Off

0

0

1/3

One screen Advanced PIP

6

Press to exit from

Options menu.

2 3

Sub screen

1

Main screen

(When Advanced PIP is On)

7

Press repeatedly.

Each time pressing this

6 5 4 button main picture and sub picture will be displayed as above.

Note:

Notes:

To use , , , buttons for the screen operations, follow the procedures in the previous page.

• Advanced PIP corresponding signal

Sub screen Main screen

NTSC, PAL, SECAM (tuner, video)

525i, 525p, 625i, 625p, 750/60p, 750/50p, 1125/60i, 1125/50i,

1250/50i (Component Video, RGB, DVI, SDI, HDMI)

[email protected], [email protected], [email protected],

[email protected] (RGB, DVI, HDMI)

[email protected] (DVI)

• If “Input lock” in Options menu is set to other than “Off”, MULTI PIP function isn’t available.

• Sound output is from the picture which is selected in Audio OUT (PIP) (See page 24).

• In 2 screen display, the same input mode cannot be selected for the main picture and sub picture.

• The main picture and sub picture are processed by different circuits, resulting in a slight difference in the clarity of the pictures. There may also be a difference in the picture quality of the sub picture depending on the type of signals displayed on the main picture and depending on the 2-picture display mode.

• Due to the small dimensions of the sub pictures, these sub pictures cannot be shown in detail.

• Computer screen picture is displayed in a simplified format, and it may not be possible to discern details on them satisfactorily.

• Following combinations of two analog signals cannot be displayed simultaneously.

Component - Component, Component - PC (RGB), PC (RGB) - Component, PC (RGB) - PC (RGB)

• Refer to each board's operating instruction for DVI, SDI, HDMI's corresponding signals.

21

PICTURE Adjustments

1

Press to display the PICTURE menu.

2

Select to adjust each item.

Press to select the menu to adjust.


NORMALIZE

NORMAL

PICTURE MENU


BRIGHTNESS

COLOR

TINT

SHARPNESS

1/2

STANDARD

25

0

0

0

5


COLOR TEMP

COLOR MANAGEMENT

ADVANCED SETTINGS

NORMAL

OFF

ON

2/2

Select the desired level by looking at the picture behind the menu.

Note:

Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting.

Press the left or right button to switch between modes.

STANDARD

and PICTURE.

STANDARD

CINEMA DYNAMIC

For viewing in standard (evening lighting) environments.

This menu selects the normal levels of BRIGHTNESS

DYNAMIC

For viewing in brighter environments.

T h i s m e n u s e l e c t s h i g h e r t h a n n o r m a l l e v e l s o f

BRIGHTNESS and PICTURE.

CINEMA

Ideal for movies.

Press to select “ON”.

Press to enter

Advanced Settings.

ADVANCED SETTINGS ON

Enables fine picture adjustment at a professional level (see next page).

ADVANCED SETTINGS 1/2

NORMALIZE NORMAL

BLACK EXTENSION

INPUT LEVEL

GAMMA

AGC

0

0

2.2

OFF

ADVANCED SETTINGS 2/2

W/B HIGH R

W/B HIGH G

W/B HIGH B

W/B LOW R

W/B LOW G

W/B LOW B

0

0

0

0

0

0

ADVANCED SETTINGS OFF

Displays images with settings of the PICTURE menu.

Note:

If you would like to change the picture and color of the selected

PICTURE menu to something else, adjust using the items in the PICTURE menu. (see next page)

Press the left or right button to switch between modes.

NORMAL

COLOR MANAGEMENT ON

COOL WARM

Enables vivid color adjustment automatically.

Helpful Hint ( /

NORMALIZE

Normalization)

While the “PICTURE” menu is displayed, if either the N button on the remote control is pressed at any time or the ACTION

( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

22

PICTURE Adjustments

Item


BRIGHTNESS

COLOR

Less

Effect Adjustments

Darker

Less

More

Brighter

More

Adjusts the proper picture contrast.

Adjusts for easier viewing of dark pictures such as night scenes and black hair.

Adjusts color saturation.

TINT

SHARPNESS

Reddish Greenish

Less More

Adjusts for natural flesh tones.

Adjusts picture sharpness.

Notes:

• “COLOR” and “TINT” settings cannot be adjusted for “RGB/PC” and “Digital” input signal.

• You can change the level of each function

(PICTURE, BRIGHTNESS, COLOR, TINT,

SHARPNESS) for each PICTURE MENU.

• The setting details for STANDARD,

DYNAMIC and CINEMA respectively are memorized separately for each input terminal.

• The “TINT” setting can be adjusted for NTSC signal only during “VIDEO

(S VIDEO)” input signal.

• In PICTURE, there is not a noticeable change even when contrast is increased with a bright picture or reduced with a dark picture.

ADVANCED SETTINGS

Item

BLACK

EXTENSION

Less

INPUT

LEVEL

Less

Effect Details

More

More

Adjusts the dark shades of the image in gradation.

Adjustment of parts which are extremely bright and hard to see.

(This cannot be adjusted when the input signal is Digital.)

GAMMA

Down Up

S CURVE 2.0 2.2 2.5

AGC

Increases the brightness of dark signal automatically.

OFF ON

W/B HIGH R

Adjusts the white balance for light red areas.

Less More

W/B HIGH G

Adjusts the white balance for light green areas.

Less More

W/B HIGH B

Adjusts the white balance for light blue areas.

Less More

W/B LOW R

Adjusts the white balance for dark red areas.

Less More

W/B LOW G

Adjusts the white balance for dark green areas.

Less More

W/B LOW B

Adjusts the white balance for dark blue areas.

Less More

Notes:

• Carry out “W/B” adjustment as follows.

1. Adjust the white balance of the bright sections using the “W/B HIGH R” , “W/B HIGH G” and “W/B HIGH B” settings.

2. Adjust the white balance of the dark sections using the “W/B LOW R” , “W/B LOW G” and “W/B LOW B” settings.

3. Repeat steps 1 and 2 to adjust.

• The adjustment values are memorized separately for each input terminal.

• The adjustment range values should be used as an adjustment reference.

Helpful Hint ( /

NORMALIZE

Normalization)

On the remote control unit, while the “ADVANCED SETTINGS” menu is displayed, if either the N button is pressed at any time or the ACTION ( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

23

SOUND Adjustment

1

Press to display the SOUND menu.

2

Select to adjust each item.

Press to select the menu to adjust.

Select the desired level by listening to the sound.

BASS

Adjusts low pitch sounds

MID

Adjusts normal sounds

TREBLE

Adjusts pitch sounds

BALANCE

Adjusts left and right volumes

SURROUND

Select On or Off

SOUND

NORMALIZE

AUDIO MENU

NORMAL

BASS

MID

TREBLE

BALANCE

SURROUND

AUDIO OUT (PIP)

0

0

0

STANDARD

0

OFF

MAIN

STANDARD

DYNAMIC

CLEAR

Emits the original sound.

Accentuates sharp sound.

Attenuates human voice.

MAIN

Selects main picture sound.

INPUT1

PC

(When main picture sound is chosen.)

A

B

SUB

Selects PIP frame sound.

INPUT1

PC

(When PIP frame sound is chosen.)

A

B

Musical note is displayed on right side of the audio output screen label.

Notes:

• Press the SURROUND button to directly turn the surround effect ON and OFF. (see page 14)

• BASS, MID, TREBLE and SURROUND settings are memorized separately for each AUDIO MENU.

Helpful Hint ( /

NORMALIZE

Normalization)

While the “SOUND” menu is displayed, if either the N button on the remote control is pressed at any time or the ACTION

( ) button is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

MUTE

Useful when answering the phone or receiving unexpected visitors.

Press this button to mute the sound.

Press again to reactivate sound. Sound is also reactivated when power is turned off or volume level is changed.

24

Digital Zoom

This displays an enlargement of the designated part of the displayed image.

1

Display the operation guide.

Press to access Digital Zoom.

The operation guide will be displayed.

During Digital Zoom, only the following buttons can be operated.

[Remote control] [Unit]

POSITION /

ACTION button

VOL button

INPUT MENU

VOL

VOL button

MUTE button

SURROUND button

OFF TIMER button

ENTER/

2

Select the area of the image to be enlarged.

Press on the enlargement location to select.

The cursor will move.

EXIT

1

EXIT

3

Select the magnification required for the enlarged display.

Each time this is pressed, the magnification factor changes.

This is shown in the image being displayed.

×

1

×

2

×

3

4

Return to normal display (quit Digital Zoom).

Press to exit from the Digital Zoom.

Notes:

• When power goes OFF (including “Off Timer” operation), Digital Zoom terminates.

• The Digital Zoom function cannot be selected while in the following operation state:

“Multi-viewer” (Picture in Picture, Picture out Picture, Picture and Picture) operation. (see page 20)

• While Digital Zoom is in operation, “Adjusting POS. /SIZE” cannot be used.

×

4

25

PRESENT TIME SETUP / SET UP TIMER

The timer can switch the Plasma Display ON or OFF.

Before attempting Timer Set, confirm the PRESENT TIME OF DAY and adjust if necessary.

Then set POWER ON TIME / POWER OFF TIME.

1

Press to display the SET UP menu.

2

Press to select SET UP TIMER or

PRESENT TIME SETUP.

Press to display the SET UP TIMER screen or

PRESENT TIME SETUP screen.

SET UP 1/2

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

RGB

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

2/2 SET UP

SCREENSAVER

MULTI DISPLAY SETUP

SET UP TIMER

PRESENT TIME SETUP

PRESENT TIME SETUP

Display the PRESENT TIME SETUP screen.

To set up DAY and PRESENT TIME OF DAY, follow the procedure described below.

1

Press to select DAY or PRESENT TIME OF DAY.

PRESENT TIME SETUP

PRESENT TIME OF DAY MON 99:99

Press to set up DAY or PRESENT TIME OF DAY.

button: Forward

button: Back

Notes:

DAY

SET

PRESENT TIME OF DAY

MON

99:99

• Pressing “ ” or “ ” button once changes PRESENT TIME OF DAY 1minute.

• Pressing “ ” or “ ” button continuously changes PRESENT TIME OF DAY by 15 minutes.

2

Press to select SET.

PRESENT TIME SETUP

PRESENT TIME OF DAY MON 99:99

SET

DAY

PRESENT TIME OF DAY

TUE

10:00

3

Press to store PRESENT TIME SETUP.

Notes:

• SET cannot be selected unless PRESENT TIME OF DAY is set.

• Unless setting the present time other than “99:99”, DAY setting is invalid.

Press to exit from PRESENT TIME SETUP.

26

PRESENT TIME SETUP / SET UP TIMER

SET UP TIMER

Display the SET UP TIMER SCREEN.

1

Press to select

POWER ON TIME / POWER OFF TIME.

SET UP TIMER

PRESENT TIME OF DAY 10:00

Press to set up POWER ON TIME / POWER OFF

TIME.

button: Forward

button: Back

POWER ON FUNCTION

POWER ON TIME

POWER OFF FUNCTION

POWER OFF TIME

OFF

12:00

OFF

18:00

Notes:

• Pressing “ ” or “ ” button once changes POWER ON TIME / POWER OFF TIME

1minute.

• Pressing “ ” or “ ” button continuously changes POWER ON TIME / POWER OFF

TIME by 15 minutes.

2

Press to select POWER ON FUNCTION

/ POWER OFF FUNCTION.

Press to select ON.

SET UP TIMER

PRESENT TIME OF DAY 10:00

POWER ON FUNCTION

POWER ON TIME

POWER OFF FUNCTION

POWER OFF TIME

ON

12:00

ON

18:00

3

Press twice to exit from SET UP.

Note:

Timer function will not work unless “PRESENT TIME OF DAY” is set.

27

SCREENSAVER

(For preventing image retention)

Do not display a still picture, especially in NORMAL mode, for any length of time.

If the display must remain on, a SCREENSAVER should be used.

1

2

Press to display the SET UP menu.

Press to select the SCREENSAVER.

SET UP

SCREENSAVER

MULTI DISPLAY SETUP

SET UP TIMER

PRESENT TIME SETUP

2/2

Press to select the SCREENSAVER screen.

3

4

5

NEGATIVE / SCROLL selection

MODE selection

START setting

Press to select the FUNCTION.

Press to select the desired function.

WHITE BAR SCROLL NEGATIVE

SCREENSAVER

PRESENT TIME OF DAY 99:99

START

FUNCTION

MODE

WHITE BAR SCROLL

OFF

START TIME

FINISH TIME

6:15

12:30

SIDE BAR ADJUST

WOBBLING

PEAK LIMIT

BRIGHT

OFF

OFF

WHITE BAR SCROLL : A white bar will scroll from left to right.

NEGATIVE : A negative image will be displayed on the screen.

Press to select the MODE.

Press to select each mode items.

SCREENSAVER

PRESENT TIME OF DAY 99:99

START

FUNCTION

MODE

START TIME

FINISH TIME

WHITE BAR SCROLL

OFF

SIDE BAR ADJUST

6:15

12:30

BRIGHT

WOBBLING

PEAK LIMIT

OFF

OFF

OFF

INTERVAL : Operates when SHOW DURATION and SAVER DURATION are set up and those times arrive.

TIME OF DAY : Operates when START TIME and FINISH TIME are set up and those times arrive.

ON : Operates when START is selected and the ACTION ( ) button is pressed.

SCREENSAVER

When the MODE is set to ON, press to select

START.

PRESENT TIME OF DAY 99:99

START

FUNCTION

MODE

START TIME

FINISH TIME

WHITE BAR SCROLL

ON

SIDE BAR ADJUST

6:15

12:30

BRIGHT

WOBBLING

PEAK LIMIT

OFF

OFF

Press to start SCREENSAVER.

The menu screen will disappear and the SCREENSAVER will be activated. To stop the

SCREENSAVER under ON, press the R button.

28

SCREENSAVER (For preventing image retention)

Setup of SCREENSAVER Time

After selecting TIME OF DAY or INTERVAL, the relevant Time Setup will become available for selection and the Operating

Time may be set. (Time cannot be set when “MODE” is “ON” or “OFF”.)

SCREENSAVER

PRESENT TIME OF DAY 15:10

START

FUNCTION WHITE BAR SCROLL

TIME OF DAY MODE

START TIME

FINISH TIME

6:15

12:30

SIDE BAR ADJUST

WOBBLING

PEAK LIMIT

BRIGHT

OFF

OFF

SCREENSAVER

PRESENT TIME OF DAY 15:00

START

FUNCTION

MODE

SHOW DURATION

WHITE BAR SCROLL

INTERVAL

SAVER DURATION

SIDE BAR ADJUST

12:00

3:00

BRIGHT

WOBBLING

PEAK LIMIT

OFF

OFF

SCREENSAVER

PRESENT TIME OF DAY 99:99

START

FUNCTION WHITE BAR SCROLL

OFF MODE

START TIME

FINISH TIME

6:15

12:30

SIDE BAR ADJUST

WOBBLING

PEAK LIMIT

BRIGHT

OFF

OFF

Press to select START TIME / FINISH TIME

(When TIME OF DAY is selected).

Press to select SHOW DURATION / SAVER

DURATION (When INTERVAL is selected).

SCREENSAVER

PRESENT TIME OF DAY 15:00

START

FUNCTION

MODE

START TIME

FINISH TIME

SIDE BAR ADJUST

WOBBLING

PEAK LIMIT

WHITE BAR SCROLL

TIME OF DAY

6:15

12:30

BRIGHT

OFF

OFF

Press to setup.

button: Forward

Notes:

button: Back

• Pressing “ ” or “ ” button once changes the Time 1minute.

[However, switching occurs every 15 minutes when Periodic Time is selected.]

• Pressing “ ” or “ ” button continuously changes the Time by 15 minutes.

SCREENSAVER

PRESENT TIME OF DAY 15:10

START

FUNCTION

MODE

START TIME

FINISH TIME

SIDE BAR ADJUST

WHITE BAR SCROLL

TIME OF DAY

0:00

0:00

BRIGHT

WOBBLING

PEAK LIMIT

OFF

OFF

SCREENSAVER

PRESENT TIME OF DAY 15:00

START

FUNCTION

MODE

SHOW DURATION

SAVER DURATION

SIDE BAR ADJUST

WHITE BAR SCROLL

INTERVAL

0:00

0:00

WOBBLING

PEAK LIMIT

BRIGHT

OFF

OFF

Note: Timer function will not work unless “PRESENT TIME OF DAY” is set.

SCREENSAVER

PRESENT TIME OF DAY 15:00

START

FUNCTION

MODE

WHITE BAR SCROLL

SHOW DURATION

SAVER DURATION

INTERVAL

12:00

SIDE BAR ADJUST

WOBBLING

PEAK LIMIT

3:00

BRIGHT

OFF

OFF

Reduces screen image retention

These functions prevent the occurrence of an “image retention” on the display when turned ON.

WOBBLING: Automatically shifts the display image (therefore unnoticeable to the eye) to prevent image retention of sharper contour of image.

ON1: Shifts the image every 30 seconds.

ON2: Shifts the image at a dot level pitch depending on screen-detection.

PEAK LIMIT: Suppresses image contrast (peak brightness).

Note: When a still picture is viewed for an extended time, the screen may become slightly darker. (see page 42)

1

SET UP 2/2

Press to display the SET UP menu.

2

Press to select “SCREENSAVER”.

SCREENSAVER

MULTI DISPLAY SETUP

SET UP TIMER

PRESENT TIME SETUP

3

Press to display SCREENSAVER menu.

Press to select “WOBBLING” or “PEAK LIMIT”.

Press to select “ON1”, “ON2” or “OFF” (WOBBLING).

“ON” or “OFF” (PEAK LIMIT).

SCREENSAVER

PRESENT TIME OF DAY 99:99

START

FUNCTION

MODE

START TIME

FINISH TIME

PEAK LIMIT

WHITE BAR SCROLL

OFF

6:15

SIDE BAR ADJUST

WOBBLING

12:30

BRIGHT

OFF

OFF

29

SCREENSAVER (For preventing image retention)

SIDE BAR ADJUST

side bars

Do not display a picture in NORMAL mode for an extended period, as this can cause an image retention to remain on the side bars on either side of the display field.

To reduce the risk of such an image retention, change the brightness of the side bars.

NORMAL mode

This function may be applicable to the non-picture area.

Non picture area image retention

Picture out Picture Picture and Picture

Display the SCREENSAVER screen.

(Refer to the previous page, operation guide steps 1 and 2)

1

Press to select the SIDE BAR ADJUST.

Press to select OFF, DARK, MID, BRIGHT.

OFF DARK MID BRIGHT

SCREENSAVER

PRESENT TIME OF DAY 99:99

START

FUNCTION

MODE

START TIME

FINISH TIME

WHITE BAR SCROLL

OFF

SIDE BAR ADJUST

6:15

12:30

BRIGHT

WOBBLING

PEAK LIMIT

OFF

OFF

2

Press to exit from SCREENSAVER.

Notes:

• To reduce the occurrence of image retention, set the SIDE BAR ADJUST to BRIGHT.

• The side bar may flash (alternate black/white) depending on the picture being shown on the screen. Using Cinema mode will reduce such flashing.

30

Reduces power consumption

• POWER SAVE:

• STANDBY SAVE:

When this function is turned ON, luminous level of the Plasma Display is suppressed, so power consumption is reduced.

When this function is turned ON, power consumption of the microcomputer is reduced during power supply standby (see page 12, 14-15), so standby power of the set is reduced.

• POWER MANAGEMENT: The unit power supply is turned ON or OFF depending on whether or not there is a signal during PC input mode.

This function is enabled when it is turned ON. (Only during input from PC(Mini D-sub) terminal)

• AUTO POWER OFF: Equipment power supply is turned OFF when there is no signal.

When this is set to On, the power supply of the unit goes Off 10 minutes after the input signals stop.

This function is effective for input signals except input from PC (Mini D-sub) terminal.

1

2

Press to select

“POWER SAVE”

“STANDBY SAVE”

“POWER MANAGEMENT”

“AUTO POWER OFF”.

Press to select “ON” or “OFF”.

On Off

SET UP 1/2

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

RGB

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

3

Press to exit from SET UP.

Note:

“POWER MANAGEMENT” and “AUTO POWER OFF” are effective during normal viewing (one picture screen) only.

Customizing the Input labels

This function can change the label of the Input signal to be displayed.

Select the input signal which you would like to change its label before customizing the Input labels. (see page 13, 15)

Press to select INPUT LABEL.

Press to change the INPUT LABEL.

SET UP 1/2

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

RGB

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

Note:

While selecting a Input signal through Optional Terminal Board connected to Slot 1, Slot 2 and Slot 3, the Input label will depend on each Optional Terminal Board.

INPUT LABELS for Slot 1, Slot 2, Slot 3 and Mini D-sub:

[Slot1 Input] INPUT1/VIDEO1/COMPONENT1/RGB1/DIGITAL1/PC1/DVD1/CATV1/VCR1/STB1

[Slot2 Input] INPUT2/VIDEO2/COMPONENT2/RGB2/DIGITAL2/PC2/DVD2/CATV2/VCR2/STB2

[Slot3 Input] INPUT3/VIDEO3/COMPONENT3/RGB3/PC3/DVD3/CATV3/VCR3/STB3

[PC (Mini D-sub) input] PC/COMPONENT/RGB/DVD/STB

When BNC Dual Video Terminal Board (TY-FB9BD) is used, an “A” or “B” is added at the end of each input label, depending on the input selected (see below).

Addition sign

Selected Input

“A”

Composite

“B”

S VIDEO

31

SET UP for Input Signals

COMPONENT / RGB IN SELECT

Select to match the signals from the source connected to the COMPONENT / RGB input terminals.

Y, P

B

, P

R

signals “COMPONENT”

R, G, B, HD, VD signals “RGB”

1

Press to display the SET UP menu.

2

Press to select the “COMPONENT / RGB-IN

SELECT”.

Press to select the desired mode.

COMPONENT RGB

3

Press to exit from adjust mode.

SET UP 1/2

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

RGB

PC

OFF

OFF STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

OFF

OFF

ENGLISH (US)

Note:

Selection may not be possible, depending on which optional board is installed.

3D Y/C FILTER

– For NTSC AV images

Select “SIGNAL” from the “SET UP” menu during VIDEO (S VIDEO) input signal mode.

(“SIGNAL [VIDEO]” menu is displayed.)

1

2

Note:

Press to select the “3D Y/C FILTER (NTSC)”.

Press to set ON / OFF.

Press to exit from adjust mode.

When ON, this setting only affects NTSC input signals.

SET UP 1/2

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

RGB

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

Press ACTION ( ) button

SIGNAL

[ VIDEO ]

3D Y/C FILTER (NTSC)

COLOR SYSTEM

3 : 2 PULLDOWN

Panasonic AUTO (4 : 3)

VIDEO NR

ON

AUTO

OFF

NORMAL

OFF

32

SET UP for Input Signals

COLOR SYSTEM / Panasonic AUTO

Select SIGNAL from the “SET UP” menu during VIDEO (S VIDEO) input signal mode.(“SIGNAL [VIDEO]” menu is displayed.)

SET UP 1/2

Press to select the “COLOR SYSTEM” or “Panasonic

AUTO”.

Press to select each function.

If the image becomes unstable:

With the system set on Auto, under conditions of low level or noisy input signals the image may in rare cases become unstable. Should this occur, set the system to match the format of the input signal.

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

RGB

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

Press ACTION ( ) button

SIGNAL

[ VIDEO ]

3D Y/C FILTER (NTSC)

COLOR SYSTEM

3 : 2 PULLDOWN

Panasonic AUTO (4 : 3)

VIDEO NR

ON

AUTO

OFF

NORMAL

OFF

Mode Function

COLOR SYSTEM

Set the color system to match the input signal. When selecting “AUTO”, the color system is automatically selected from NTSC/PAL/SECAM, however, M.NTSC signal is not displayed properly depending on the attached terminal board. To display M.NTSC signal, select “M.NTSC” in COLOR SYSTEM.

AUTO PAL SECAM M.NTSC

NTSC

Panasonic AUTO

(4 : 3 )

Set to “NORMAL” to view 4:3 images in an unchanged format when Panasonic AUTO is selected. If you would like to view 4:3 images in Just format, set to “JUST”.

Note:

Panasonic AUTO does not function when BNC Dual Video Terminal Board (TY-FB9BD) is used.

3:2 PULLDOWN / VIDEO NR

3:2 PULLDOWN: When ON, the display attempts to reproduce a more natural interpretation of sources such as movie pictures, which are recorded at 24 frames per second.

SET UP 1/2

If the picture is not stable, turn the setting to OFF.

Notes:

When ON, this setting only affects the following signal input:

SIGNAL

COMPONENT/RGB-IN SELECT

RGB

• NTSC / PAL signal input during “VIDEO (S VIDEO)” input signal.

• 525i(480i) 625i(575i), 1125(1080)/60i signal input during “COMPONENT” input signal.

VIDEO NR: Automatically reduces unwanted picture noise.

Note:

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

VIDEO NR cannot be adjusted while a PC signal is being applied.

Press ACTION ( ) button

1

Press to select 3:2

PULLDOWN or VIDEO NR.

Press to set ON/OFF.

SIGNAL

3D Y/C FILTER (NTSC)

COLOR SYSTEM

3 : 2 PULLDOWN

Panasonic AUTO (4 : 3)

VIDEO NR

[ VIDEO ]

ON

AUTO

OFF

NORMAL

OFF

SIGNAL

SYNC

3 : 2 PULLDOWN

VIDEO NR

H-FREQ.

V-FREQ.

33.8

60.0

kHz

Hz

[ RGB ]

AUTO

OFF

OFF

[ COMPONENT ] [ Digital ]

SIGNAL SIGNAL

2

Press to exit from adjust mode.

3 : 2 PULLDOWN

VIDEO NR

OFF

OFF

3 : 2 PULLDOWN

VIDEO NR

H-FREQ.

V-FREQ.

33.8

60.0

kHz

Hz

OFF

OFF

33

SET UP for Input Signals

SYNC

Select SIGNAL from the “SET UP” menu during RGB input signal.

1

Press to adjust.

2

Press to exit from adjust mode.

Setting RGB sync signal

Confirm that the input is set to RGB INPUT (this setting is valid only for RGB INPUT signal).

AUTO: The H and V sync or synchronized signal are automatically selected.

If both input, it is selected the H and V sync.

ON G: Uses a synchronized signal on the Video G signal, which is input from the G connector.

VBS: Uses a synchronized signal of Composite Sync input, which is input from the HD connector.

SET UP 1/2

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

RGB

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

Press ACTION ( ) button

SIGNAL

[ RGB ]

SYNC

3 : 2 PULLDOWN

VIDEO NR

H-FREQ.

V-FREQ.

33.8

60.0

kHz

Hz

AUTO

OFF

OFF

SYNC AUTO

SYNC

SYNC

ON G

VBS

REFRESH RATE

This function sets the refresh rate of the display.

This menu is displayed when the input signal is 50 Hz system (50i, 50p, 25p, 24p, 24sF) of vertical scan rate.

100 Hz: Reduce screen flicker.

50 Hz: Enhance the resolution of moving images.

Note:

It is recommended to set to 100 Hz normally.

Press to select REFRESH RATE.

1

Press to adjust.

SIGNAL

3D Y/C FILTER (NTSC)

COLOR SYSTEM

3 : 2 PULLDOWN

Panasonic AUTO (4 : 3)

VIDEO NR

REFRESH RATE

[ VIDEO ]

AUTO

OFF

NORMAL

OFF

100 Hz

SIGNAL

SYNC

3 : 2 PULLDOWN

VIDEO NR

REFRESH RATE

H-FREQ.

V-FREQ.

33.8

60.0

kHz

Hz

AUTO

OFF

OFF

100 Hz

[ RGB ]

[ COMPONENT ]

SIGNAL

SIGNAL

[ Digital ]

2

Press to exit from adjust mode.

3 : 2 PULLDOWN

VIDEO NR

REFRESH RATE

OFF

OFF

100 Hz

3 : 2 PULLDOWN

VIDEO NR

REFRESH RATE

H-FREQ.

V-FREQ.

33.8

60.0

kHz

Hz

OFF

OFF

100 Hz

H-FREQ. (kHz) / V-FREQ. (Hz)

Displays the H (Horizontal) / V (Vertical) frequencies.

This display is valid only for RGB/PC and Digital input signal.

Display range:

Horizontal 15 - 110 kHz

Vertical 48 - 120 Hz

34

H-FREQ.

V-FREQ.

33.8

60.0

kHz

Hz

1

2

Options Adjustments

Press to display the Setup menu.

Press to select “OSD Language”.

3

4

Press and hold until the Options menu is displayed.

Press to select your preferred menu.

5

Press to adjust the menu.

Options

Weekly Command Timer

Onscreen display

Initial INPUT

Initial VOL level

Maximum VOL level

INPUT lock

Button lock

Remocon User level

Advanced PIP

On

O f f

Off

Off

Off

Off

Off

Off

0

0

1/3

6

Press to exit from

Options menu.

Item

Weekly

Command

Timer

Effect Adjustments

Sets Weekly Command Timer. (see page 39)

Onscreen display

Initial INPUT

On Off

On: Displays all the following on screen.

• Power on display

• Input signal switch display

• No signal display

• Mute and the remaining time of off-timer after was pressed.

Off: Hides all the items above from view.

Off PC INPUT1 INPUT2

INPUT3

Adjusts the input signal when the unit is turned on.

Notes:

• Only the adjusted signal is displayed. (see page 13).

• Signal can be displayed when the Terminal board is installed.

• This menu is available only when “INPUT lock” is “Off”.

• When a dual input terminal board is attached, A or B is displayed depending on the selected input signal. (Ex. INPUT1A, INPUT1B)

35

Options Adjustments

Options

Weekly Command Timer

Onscreen display

Initial INPUT

Initial VOL level

Maximum VOL level

INPUT lock

Button lock

Remocon User level

Advanced PIP

On

Off

Off

Off

Off

Off

Off

Off

0

0

1/3

Item

Initial VOL level

Maximum VOL level

Off On

INPUT lock

Button lock

Remocon

User level

Effect Adjustments

Off On

Advanced PIP

Off On

Press button to adjust the volume when the unit is turned on.

Off On

Off: Sets normal volume.

On: Sets your preferred volume.

Notes:

• When “Maximum VOL level” is “On”, the volume can only be adjusted between 0 and your maximum range.

• You can hear the changed volume regardless of your volume setting before opening the options menu if you adjust the volume when “Initial VOL level” is “On” and cursor is on the menu.

Press button to adjust the maximum volume.

Off On

Off: Sets auto maximum volume.

On: Sets your preferred maximum volume.

Notes:

• If the “Maximum VOL level” is set lower than the “Initial VOL level”, the “Initial VOL level” automatically becomes the same as the “Maximum VOL level”.

• The volume display can go up to 63 regardless of the settings.

• You can hear the changed volume regardless of your volume setting before opening the options menu if you adjust the volume when “Maximum VOL level” is “On” and cursor is on the menu.

Off PC INPUT1 INPUT2 INPUT3

Locks the input switch operation.

Notes:

• Only the adjusted signal is displayed (see page 13).

• Signal can be displayed when the Terminal board is installed.

• Input switch can be used when this is set to “Off”.

• In two screen display mode, if anything other than “Off” is set, the value will be fixed as the value input in the single screen display mode.

• When a dual input terminal board is attached, A or B is displayed depending on the selected input signal. (Ex. INPUT1A, INPUT1B)

Off MENU&ENTER

On

Off: All the buttons at the bottom of the main unit can be used.

MENU & ENTER: Locks

MENU

and

ENTER/

buttons on bottom face of main unit.

On: Locks all the button on bottom face of main unit.

Sets Button lock with the unit buttons in the following procedure.

Off:

→Press

INPUT

four times

→Press four times→Press

ENTER/

Press

ENTER/

four times

→Press four times→Press

INPUT

four times

→Press

ENTER/

On:

→Press

ENTER/

four times

→Press four times→Press

ENTER/

Off User1 User2 User3

Off: You can use all of the buttons on the remote control.

User1: You can only use , , , , , , , buttons on the remote control.

User2: You can only use , , buttons on the remote control.

User3: Locks all the buttons on remote control.

Off: Sets normal two screen display mode (see page 20).

On: Sets Advanced PIP mode (see page 21).

Notes:

• When “INPUT lock” is “On”, you cannot use all the two screen display functions.

• , buttons are unavailable during Advanced PIP mode operation.

36

Options Adjustments

Options

Off-timer function

Initial Power Mode

ID select

Remote ID

Serial ID

Display size

Studio W/B

Studio Gain

Enable

Normal

0

Off

Off

Off

Off

Off

2/3

Item

Off-timer function

Effect Adjustments

Enable Disable

Enable: Enables the “Off-timer function”.

Disable: Disables the “Off-timer function”.

Note: When “Disable” is set, the Off-timer is cancelled.

Initial Power

Mode

ID select

Remote ID

Serial ID

Off

Off

On

On

Normal Standby On

Sets the power mode of the unit for when the power recovers from failure or after plugging off and in again.

Normal: Power returns in as the same state as before the power interruption.

Standby: Power returns in standby mode. (Power Indicator : red/orange)

On: Power returns in power On. (Power Indicator : green)

Note: When using multiple displays, “Standby” is preferred to be set in order to reduce a power load.

Sets panel ID number when panel is used in “Remote ID” or “Serial ID”.

Set value range: 0 - 100

(Standard value: 0)

Off: Disables ID remote control functions. You can use normal remote control operations.

On: Enable ID remote control functions.

Sets the panel ID Control.

Off: Disables external control by the ID.

On: Enables the external control by the ID.

Adjusts the image display size on screen.

Off: Sets the normal image display size on screen.

On: Sets the image display size approximately 95 % of the normal image display.

Display size

Studio W/B

Studio Gain

Off

Off

Off

On

On

On

Notes:

• This setting is valid only when the input signals are as follows;

NTSC, PAL, SECAM, M.NTSC, PAL60, PAL-M, PAL-N (BNC Dual Video Terminal Board (TY-FB9BD))

525i, 525p, 625i, 625p, 750/60p, 750/50p, 1125/60i, 1125/50i, 1125/24sF, 1125/25p, 1125/24p, 1125/30p,

1250/50i (Component Video, RGB, DVI, SDI, HDMI)

• This setting is invalid when two screen display, digital zoom or Multi screen is selected.

• When “Display size” is set to “On”, “POS. /SIZE” adjustment cannot be used.

• Refer to each board's operating instruction for DVI, SDI, HDMI's corresponding signals.

Off: Nullify all the settings adjusted.

On: Sets the color temperature for TV studio.

Note: Valid only when the low is set as color temperature on screen adjustment.

Sharpens the contrast for a better view when a part of the image is too light to see.

Off: Disables “Studio Gain”.

On: Enables “Studio Gain”.

Note: This setting is valid only when the input signals are as follows:

Component Video, RGB (analog), SDI, HDMI

37

Options Adjustments

Options

Slot power

V. lnstallation

Rotate

Serial Slot Select

Off

Off

Off

Slot1

3/3

Item Effect Adjustments

Slot Power

Off: Power is not transmitted to the slot power.

Auto: Power is transmitted to the slot power only when main power is on.

On: Power is transmitted to the slot power when main power is on or in the standby state.

Note: In some cases, power is transmitted to the slot power when main power is on or in the standby state regardless of the slot power setting.

Note: This mode is unavailable.

V.Installation

Off On

Rotate

Off On

Off: Does not rotate the image.

On: Rotates the image 180 degrees.

Serial Slot

Select

Slot1 Slot2 Slot3

Selects the slot which communicates serial.

Note: The setting of an external command can be set only from the fi xed serial terminal (see page 11).

Normalization

When both main unit buttons and remote control are disabled due to the “Button lock”, “Remocon User level” or “Remote

ID” adjustments, set all the values “Off” so that all the buttons are enabled again.

Press the

VOL button on main unit together with button on the remote control and hold for more than 5 seconds. The

“SHIPPING” menu is displayed and the lock is released when it disappears.

38

Options Adjustments

Weekly Command Timer

You can set 7-day timer programming by setting time and command.

Note:

Before setting Weekly Command Timer, set PRESENT TIME SETUP. (see page 26)

1

Press to select Function.

Press to select “On”.

Note:

• When Function is set to On, SET UP TIMER

(see page 27) is unavailable and INTERVAL

/ TIME OF DAY in MODE of SCREENSAVER

(see page 28) cannot be selected.

Options

1/3

Weekly Command Timer

Onscreen display On

Press ACTION ( ) button

Weekly Command Timer

Function

Monday

Tuesday

Wednesday

Thursday

Friday

Saturday

Sunday

Program Edit

On

Program1

Program3

---

Program3

---

Program6

Program4

2

3

Press to select a day.

Press to select a program number.

Note:

• You can set the program from 1 to 7.

--- indicates unset.

Press to select Program Edit.

Weekly Command Timer

Function

Monday

Tuesday

Wednesday

Thursday

Friday

Saturday

Sunday

Program Edit

On

Program1

Program3

---

Program3

---

Program6

Program4

Program number

Thursday

Friday

Saturday

Sunday

Program Edit

Program3

---

Program6

Program4

Press to show the Program Edit screen.

4

Press to select Program.

Press to change the program numbers (1-7).

Program Edit screen

Weekly Command Timer

Program

05

06

07

08

01

02

03

04

8:00

10:30

--:--

--:--

--:--

12:00

9:12

--:--

PON

1

IMS:SL1

---

---

---

DAM:ZOOM

AVL:10

---

1/8

39

5

6

Options Adjustments

Press to select a command number.

Press to show the previous / next command pages (1-8) of the selected program.

Press to show the command setting screen.

Weekly Command Timer 1/8

Program

05

06

07

08

01

02

03

04

8:00

10:30

--:--

--:--

--:--

12:00

9:12

--:--

PON

1

IMS:SL1

---

---

---

DAM:ZOOM

AVL:10

---

Command (--- indicates unset)

Set time of timer(--:-- indicates unset)

Command numbers

Weekly Command Timer

Program

57

58

59

60

61

62

63

64

20:00

20:30

22:00

--:--

--:--

--:--

--:--

--:--

---

---

---

---

---

1

AVL:00

DAM:NORM

POF

8/8

Press to select Command No.

Press to select a command number.

Command setting screen

Weekly Command Timer

Command No

Time

Command

Program

02

10:30

IMS:SL1

1

7

Press to select Time / Command.

Weekly Command Timer

Program 1

Press to set each item.

Time: Set the time to execute a command program.

Pressing “ ” or “ ” button once changes

“Time” 1 minute.

Command No

Time

Command

10:30

IMS:SL1

02

Pressing “ ” or “ ” button continuously changes “Time” by 15 minutes.

Command: Select a command to execute at the set time. This unit has 64 commands to set. (see page 44)

Notes:

• Command is performed in order of execution time, regardless of the command number.

• If a command execution time overlaps with that of other commands, these commands are performed in number order.

• Pressing , Time becomes --:-- and Command becomes ---.

Note:

• Press to return to the previous screen.

40

Shipping condition

This function allows you to reset the unit to the factory setting.

1

Press to display the SET UP menu.

2

Press to select “OSD LANGUAGE”.

3

4

Press and hold till the SHIPPING menu is displayed.

Press to select “YES”.

SET UP

1/2

SIGNAL

COMPONENT/RGB-IN SELECT

INPUT LABEL

POWER SAVE

STANDBY SAVE

POWER MANAGEMENT

AUTO POWER OFF

OSD LANGUAGE

RGB

PC

OFF

OFF

OFF

OFF

ENGLISH (US)

SHIPPING YES

Press to confirm.

[from the unit]

1 Press the MENU button till the Setup menu is displayed.

2 Press the Volume Up “+” or Down “–” button to select “OSD LANGUAGE”.

3 Press and hold the ENTER button till the SHIPPING menu is displayed.

4 Press the Volume Up “+” or Down “–” button to select “YES”.

5 Press the ENTER button and wait for 10 sec.

Note:

Press the R button to return to SET UP menu when SHIPPING menu is displayed.

41

Troubleshooting

Before you call for service, determine the symptoms and make a few simple checks as shown below.

Symptoms


Interference

Normal Picture

No Picture

No Picture

Sound

Noisy Sound

No Sound

No Sound

Normal Sound

Checks

Electrical Appliances

Cars / Motorcycles

Fluorescent light

Volume

(Check whether the mute function has been activated on the remote control.)

Not plugged into AC outlet

Not switched on

PICTURE and BRIGHTNESS/Volume setting

(Check by pressing the power switch or stand-by button on the remote control.)

If a signal with a non-applicable color system format, or frequency is input, only the input terminal indication is displayed.

No Color Normal Sound

Color controls set at minimum level. (see page 22, 23)

COLOR SYSTEM (see page 33)

No remote control operations can be performed.

Check whether the batteries have discharged completely and, if they have not, whether they were inserted properly.

Check whether the remote control sensor is exposed to an outdoor light or a strong fluorescent light.

Check whether the remote control designed specifically for use with the unit is being used.

(The unit cannot be operated by any other remote control.)

A cracking sound is sometimes heard from the unit.

If there is nothing wrong with the picture or sound, this is the sound of the cabinet undergoing very slight contractions in response to changes in the room temperature. There are no adverse effects on the performance or other aspects.

Adjust the position of the picture on the screen.

The top or bottom of the picture on the screen is cut off when I use the zoom function.

Areas at the top and bottom of the screen where the image is missing appear when I use the zoom function.

When using a video software program (such as a cinema size program) with a screen wider than one in the 16:9 mode, blank areas separate from the images are formed at the top and bottom of the screen.

I can hear sounds coming from inside the unit.

When the power is turned on, a sound of the display panel being driven may be heard: This is normal and not indicative of malfunctioning.

This Plasma Display uses special image processing. Hence a slight time lag may occur between image and audio, depending on the type of input signal. However, this is not a malfunction.

Plasma Display panel

Symptoms

The screen darkens slightly when bright pictures with minimal movements are shown.

It takes a while for the picture to appear.

The edges of the images flicker.

The brightness on both sides of images in NORMAL mode changes.

Some parts of the screen do not light up.

Image retention appears

Check

The screen will darken slightly when photos, still images of a computer or other pictures with minimal movements are shown for an extended period. This is done to reduce image retention on the screen and the shortening of the screen’s service life: It is normal and not indicative of malfunctioning.

The unit digitally processes the various signals in order to reproduce esthetically pleasing images. As such, it sometimes takes a few moments for the picture to appear when the power has been turned on, when the input has been switched or when the images for the main picture and sub picture on the two screens are swapped.

Due to the characteristics of the system used to drive the panel, the edges may appear to flicker in the fast-moving parts of the images: This is normal and not indicative of malfunctioning.

When viewing the side panels at the “BRIGHT” or “MID” setting, the brightness on both sides may change depending on the kind of program shown: This is normal and not indicative of malfunctioning.

The plasma display panel is manufactured using an extremely high level of precision technology, however, sometimes some parts of the screen may be missing picture elements or have luminous spots. This is not a malfunction.

Do not allow a still picture to be displayed for an extended period, as this can cause a permanent image retention to remain on the Plasma Display.

Examples of still pictures include logos, video games, computer images, teletext and images displayed in NORMAL mode.

Note:

The permanent image retention on the Plasma Display resulting from fixed image use is not an operating defect and as such is not covered by the Warranty.

This product is not designed to display fixed images for extended periods of time.

42

PC input signals

Applicable input signals for Mini D-sub 15P (Component) / Mini D-sub 15P (RGB) (* Mark)

Signal name

Horizontal frequency

(kHz)

Vertical frequency (Hz)

Dot clock frequency

(MHz)

Mini D-sub 15P Mini D-sub 15P

(Component) (RGB)

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

525 (480) / 60i

525 (480) / 60p

625 (575) / 50i

625 (575) / 50p

750 (720) / 60p

750 (720) / 50p

1,125 (1,080) / 60i

1,125 (1,080) / 50i

1,125 (1,080) / 24sF

1,125 (1,080) / 30p

1,125 (1,080) / 25p

1,125 (1,080) / 24p

1,250 (1,080) / 50i

640 × 400 @70 Hz

640 × 480 @60 Hz

640 × 480 @72 Hz

640 × 480 @75 Hz

640 × 480 @85 Hz

852 × 480 @60 Hz

800 × 600 @56 Hz

800 × 600 @60 Hz

800 × 600 @72 Hz

800 × 600 @75 Hz

800 × 600 @85 Hz

1,024 × 768 @60 Hz

1,024 × 768 @70 Hz

1,024 × 768 @75 Hz

1,024 × 768 @85 Hz

1,152 × 864 @75 Hz

1,280 × 960 @60 Hz

1,280 × 960 @85 Hz

1,280 × 1,024 @60 Hz

1,280 × 1,024 @75 Hz

1,280 × 1,024 @85 Hz

1,600 × 1,200 @60 Hz

1,600 × 1,200 @65 Hz

1,066 × 600 @60 Hz

1,366 × 768 @60 Hz

Macintosh13” (640 × 480)

15.73

31.47

15.63

31.25

45.00

37.50

33.75

28.13

27.00

33.75

28.13

27.00

31.25

31.46

31.47

37.86

37.50

43.27

31.47

35.16

37.88

48.08

46.88

53.67

48.36

56.48

60.02

68.68

67.50

60.00

85.94

63.98

79.98

91.15

75.00

81.25

37.64

48.36

35.00

59.94

59.94

50.00

50.00

60.00

50.00

60.00

50.00

47.92

30.00

25.00

24.00

50.00

70.07

59.94

72.81

75.00

85.01

59.94

56.25

60.32

72.19

75.00

85.06

60.00

70.07

75.03

85.00

75.00

60.00

85.00

60.02

75.03

85.02

60.00

65.00

59.94

60.00

66.67

13.5

27.0

13.5

27.0

74.25

74.25

74.25

74.25

74.25

74.25

74.25

74.25

74.25

25.17

25.18

31.5

31.5

36.0

33.54

36.0

40.0

50.0

49.5

56.25

65.0

75.0

78.75

94.5

108.0

108.0

148.5

108.0

135.0

157.5

162.0

175.5

53.0

86.71

30.24

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

*

2

*

*

2

*

*

*

*

*

*

*

*

*

*

*

*

*

*

1

*

*

*

*

*

*

*

*

*

*

*

*

40

41

Macintosh16” (832 × 624)

Macintosh21” (1,152 × 870)

49.72

68.68

74.54

75.06

57.28

100.0

*

*

1: When selected the RGB format and 525p signal input to the Mini D-sub 15P terminal, it is recognized as VGA 60Hz signal.

2: When inputted VGA 60Hz format signal from the other than Mini D-sub 15P terminal, it is recognized as 525p signal.

Note: Signals without above specification may not be displayed properly.

43

Command list of Weekly Command Timer

38

39

40

41

42

34

35

36

37

30

31

32

33

26

27

28

29

55

56

57

58

51

52

53

54

59

60

61

62

63

47

48

49

50

43

44

45

46

22

23

24

25

18

19

20

21

13

14

15

16

17

6

7

8

4

5

No.

1

2

3

9

10

11

12

DAM:JUST

DAM:NORM

DAM:SELF

DAM:ZOOM

DWA:OFF

DWA:OVL1

DWA:OVL2

DWA:OVL3

DWA:OVL4

DWA:OVL5

DWA:OVL6

DWA:OVLOF

DWA:OVLON

DWA:PIN0

DWA:PIN1

DWA:PIN2

DWA:PIN3

DWA:PIP

DWA:POP

DWA:SWP

DWA:TWN

IMS:PC1

IMS:SL1

IMS:SL1A

IMS:SL1B

IMS:SL2

IMS:SL2A

IMS:SL2B

IMS:SL3

ISS:PC1

ISS:SL1

ISS:SL1A

ISS:SL1B

ISS:SL2

ISS:SL2A

ISS:SL2B

ISS:SL3

OSP:SCR0

OSP:SCR1

POF

PON

SSC:FNC0

SSC:FNC1

SSC:MOD0

SSC:MOD3

VMT:0∗

Command

AAC:MENCLR Audio Menu (Clear)

AAC:MENDYN Audio Menu (Dynamic)

AAC:MENSTD Audio Menu (Standard)

AAC:SURMON Surround (ON)

AAC:SUROFF

AMT:0

AMT:1

ASO:M

Surround (OFF)

Audio Mute (OFF)

Audio Mute (ON)

Control details

Audio out when PIP mode (Main Picture)

ASO:S

AVL:00

AVL:10

AVL:20

AVL:30

AVL:40

AVL:50

AVL:60

DAM:FULL

Audio out when PIP mode (Sub Picture)

Audio Volume (00)

Audio Volume (10)

Audio Volume (20)

Audio Volume (30)

Audio Volume (40)

Audio Volume (50)

Audio Volume (60)

Aspect (FULL)

Aspect (JUST)

Aspect (NORMAL)

Aspect (Panasonic AUTO)

Aspect (ZOOM)

Dual Picture mode (OFF)

Advanced PIP mode (1) (see page 21)

Advanced PIP mode (2) (see page 21)

Advanced PIP mode (3) (see page 21)

Advanced PIP mode (4) (see page 21)

Advanced PIP mode (5) (see page 21)

Advanced PIP mode (6) (see page 21)

Advanced PIP mode (OFF) (normal two screen display mode)

Advanced PIP mode (ON)

The location of the sub picture (lower right)

The location of the sub picture (lower left)

The location of the sub picture (upper left)

The location of the sub picture (upper right)

Dual Picture mode (Picture in Picture)

Dual Picture mode (Picture out Picture)

Swap main picture and sub picture when PIP mode

Dual Picture mode (Picture and Picture)

Input select (PC1) (Main Picture when PIP mode)

Input select (SLOT1) (Main Picture when PIP mode)

Input select (SLOT1A) (Main Picture when PIP mode)

Input select (SLOT1B) (Main Picture when PIP mode)

Input select (SLOT2) (Main Picture when PIP mode)

Input select (SLOT2A) (Main Picture when PIP mode)

Input select (SLOT2B) (Main Picture when PIP mode)

Input select (SLOT3) (Main Picture when PIP mode)

Sub Picture Input Select (PC1)

Sub Picture Input Select (SLOT1)

Sub Picture Input Select (SLOT1A)

Sub Picture Input Select (SLOT1B)

Sub Picture Input Select (SLOT2)

Sub Picture Input Select (SLOT2A)

Sub Picture Input Select (SLOT2B)

Sub Picture Input Select (SLOT3)

Screen Saver WHITE BAR SCROLL (OFF)

Screen Saver WHITE BAR SCROLL (ON)

Power OFF

Power ON

Screen Saver function (WHITE BAR SCROLL)

Screen Saver function (NEGATIVE)

ScreenSaver (Mode (OFF))

ScreenSaver (Mode (ON))

Picture Mute (OFF)

64 VMT:1∗ Picture Mute (ON)

Picture Mute cannot be unlocked by powering off/on with the remote control. Turn off and on again with the button on the unit or enter the command VMT:0 to unlock Picture Mute.

44

Specifications

TH-37PR10U TH-42PR10U

Power Source

Power Consumption

Power on

Stand-by condition

Power off condition

Plasma Display panel

Screen size

(No.of pixels)

120 V AC, 50/60 Hz

340 W

Save OFF 0.7 W, Save ON 0.5 W

0.2 W

Drive method : AC type 37-inch,

16:9 aspect ratio

32.2” (819 mm) (W) × 18.0” (457 mm) (H)

× 37” (938 mm) (diagonal)

737,280 (1,024 (W) × 720 (H))

[3,072 × 720 dots]

380 W

Save OFF 0.7 W, Save ON 0.5 W

0.2 W

Drive method : AC type 42-inch,

16:9 aspect ratio

36.3” (922 mm) (W) × 20.4” (518 mm) (H)

× 42” (1,057 mm) (diagonal)

786,432 (1,024 (W) × 768 (H))

[3,072 × 768 dots]

Operating condition

Temperature

Humidity

Applicable signals

Scanning format

32 °F - 104 °F (0 °C - 40 °C)

20 % - 80 %

PC signals

525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 50i · 24p · 25p

· 30p · 24sF ···· SMPTE274M, 1250 (1080) / 50i

VGA, SVGA,

XGA, SXGA, UXGA ···· (compressed)

Horizontal scanning frequency 15 - 110 kHz

Vertical scanning frequency 48 - 120 Hz

VGA, SVGA, XGA,

SXGA, UXGA ···· (compressed)

Horizontal scanning frequency 15 - 110 kHz

Vertical scanning frequency 48 - 120 Hz

Connection terminals

PC IN (HIGH-DENSITY MINI D-SUB 15PIN) Y or G with/sync 1.0 Vp-p (75

Ω)

Y or G without/sync 0.7 Vp-p (75

Ω)

B/P

B

/C

B

:

Ω)

R/P

R

/C

R

:

Ω)

AUDIO IN (M3 JACK) 0.5 Vrms (high impedance)

EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE SERIAL

Accessories Supplied

Fixing bands

Dimensions (W × H × D)

TMME203 × 2

36.1” (917 mm) × 25.4” (644 mm) × 3.7” (95 mm)

(4.3” (109 mm) when including protruding portion of slots) approx. 55.1 lbs

40.2” (1,020 mm) × 27.8” (705 mm) × 3.7” (95 mm)

(4.3” (109 mm) when including protruding portion of slots) approx. 61.7 lbs

Mass (weight)

Sound

Speaker

Audio Output

4.8 ” (120 mm) × 2.4 ” (60 mm) × 2 pcs, 8

Ω

20W [10 W + 10 W] (10 % THD)

Note:

Design and specifications are subject to change without notice. Mass and dimensions shown are approximate.

45

46

Panasonic Professional Display

Company, Unit of Panasonic Corporation of

North America

One Panasonic Way 2A-4

Secaucus, NJ 07094

Panasonic Puerto Rico, Inc.

Ave. 65de Infanteria, Km.9.5

San Gabriel Industrial Park

Carolina, Puerto Rico 00985

PANASONIC PLASMA SCREEN

Limited Warranty

Panasonic Professional Display Company or Panasonic

Puerto Rico, Inc. (collectively referred to as “the Warrantor”) will repair this product and all included accessories with new or refurbished parts, free of charge in the USA or Puerto Rico, of the original purchase in the event of a defect in materials or workmanship as follow: inadequate signal pickup, maladjustment of consumer controls, improper operation, power line surge, improper voltage supply, lighting damage, or service by anyone other than an authorized repair facility, or damaged this attributable to acts of God.

LIMITS AND EXCLUSIONS

Models or Parts

Part

Warranty

Labor

Warranty

There are no express warranties except as listed above.

Plasma Screen

1 Year 1 Year

Carry-in or mail-in service in the USA may be obtained during the warranty period by contacting Panasonic

Professional Display Company Factory Servicenter listed in the Service Directory or call toll free 1-888-972-6276 to locate an authorized Servicenter.

Carry-in or mail-in service in Puerto Rico can be obtained during the warranty period by 787-750-5135

THE WARRANTOR SHALL NOT BE LIABLE FOR

INCIDENTAL OR CONSEQUENTIAL DAMAGES

(INCLUDING, WITHOUT LIMITION, DAMAGE

TO DISCS) RESULTING FROM THE USE OF THIS

PRODUCT, OR ARISING OUT OF ANY BREACH OF

THE WARRANTY. ALL EXPRESS AND IMPLIED

WARRANTIES, INCLUDING THE WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR

PARTICULAR PURPOSE, ARE LIMITED TO THE

APPLICABLE WARRANTY PERIOD SET FORTH

ABOVE.

This warranty is extended only to the original purchaser and is non transferable. A purchase receipt or other proof of date of original purchase will be required before warranty service is rendered.

Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above exclusions or limitations may nor apply to you. This warranty gives you specific legal rights and you may other rights, which vary from state to state.

This warranty only covers failures due to defects in materials or workmanship, which occur during normal use. The warranty does not cover damage which occur in shipment, or failures which are caused by products not supplied by the warrantor, or failures which result installation, set-up adjustments, improper antenna,

If you have a problem with this product that is not handled to your satisfaction, then write the Consumer

Affairs Department at the Company address indicated above.

In the USA

FOR THE NEAREST SERVICE CENTER

1-888-972-6276

50 Meadowland Parkway

Panazip #1F-10

Secaucus, NJ 07094

In Puerto Rico

For service call 787-750-5135

Panasonic Canada Inc.

5770 Ambler Drive, Mississauga, Ontario L4W 2T3

LIMITED WARRANTY STATEMENT

Panasonic Canada Inc. (also known as PCI) warrants this product to be free of defects in material and workmanship under normal use during the applicable warranty coverage period described below. PCI agrees to repair, or at its option, exchange, any part that becomes defective. However, the product must be purchased and serviced in Canada. The product or part that shows evidence of defect must be delivered prepaid or carried in to an authorized Panasonic Broadcast

Service Center. This warranty does not cover shipping costs.

The warranty coverage period is one year for both parts and labour beginning with the date of original end user purchase, subject to the exceptions as stated below.

Repaired or replacement parts supplied during the warranty coverage period carry the unexpired portion of the original warranty coverage period. Proof of product purchase is a condition of warranty service. The owner must produce the product purchase receipt or other satisfactory evidence of date of original purchase.

This warranty does not apply to external appearance items, such as handles, knobs, safety windows, etc. This warranty does not apply to any part, or parts, of the product, installed, altered, repaired or misused in any way that, in the opinion of PCI, affects the reliability of or detracts from the performance of the product.

For products requiring routine preventive maintenance, that maintenance must be performed in order to maintain warranty coverage.

Serial numbers that have been altered, defaced or removed void this warranty. This warranty does not cover replacements or repairs necessitated by loss or damage resulting from any cause beyond the control of PCI.

Marking or retained images (sometimes called “burn-in”) resulting from the display of fixed images on video display products are not defects and are not covered under this warranty.

THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR

ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES.

In certain instances, some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, or the exclusion of implied warranties, so the above limitations and exclusions may not be applicable.

WARRANTY COVERAGE PERIOD EXCEPTIONS

Item Parts

Video Tape 30 days—Replacement only

(content not covered)

P2/SD Cards

Video Heads

D5 Video heads

Maintenance Items

Colour Camera CCD

Imaging Block

LCD/CRT Monitors

* DLP™ Projectors

* LCD Projectors above

2,500 ANSI Lumens

* LCD Projectors below

2,500 ANSI Lumens

Projector Lamps

103 inch Plasma displays

Hard Drive Disk Unit

(Content not covered)

1 year or 2,000 hrs. (prorated)

Whichever comes first

1 year or 1,000 hrs.

Whichever comes first

90 days

2 years

2 years

3 years or 17,000 hrs.

Whichever comes first

3 years or 2,500 hrs.

Whichever comes first

3 years or 1,500 hrs.

Whichever comes first

50% of the rated lamp life or 1 year.

Whichever comes first

3 year (burn-in not covered)

1 year plus balance (if any) of the original Manufacturer’s

Limited Warranty.

(Content not covered)

Labour

N/A

N/A

1 year or 2,000 hrs.

Whichever comes first

1 year or 1,000 hrs.

Whichever comes first

90 days

1 year

1 year

3 years or 17,000 hrs.

Whichever comes first

3 years or 2,500 hrs.

Whichever comes first.

3 years or 1,500 hrs.

Whichever comes first

50% of the rated lamp life or 1 year.

Whichever comes first.

3 year

1 year

• Dust, smoke, rental/staging environment and twenty-four/seven operation, dramatically decreases the interval between performances of routine preventive maintenance required to maintain this warranty coverage.

Warranty Service

If the product needs to be shipped for service, carefully pack (preferably in the original carton) and enclose a letter, detailing the complaint. Send prepaid and adequately insured to the local authorized Panasonic Service Centre in your area or to Panasonic Technical Support and Product Services Department, 5770

Ambler Drive, Mississauga, Ontario, L4W 2T3. Shipping to the latter location requires a return authorization before shipment. No liability is assumed for loss or damage to the product while in transit.

47

Customer’s Record

The model number and serial number of this product can be found on its back cover. You should note this serial number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of your purchase to aid in identification in the event of theft or loss, and for Warranty Service purposes.

Model Number Serial Number

©

2007 Matsushita Electric Industrial Co., Ltd. All Rights Reserved.

Panasonic Professional Display Company

Unit of Panasonic Corporation of North America

Executive Office :

One Panasonic Way 4E-7, Secaucus, NJ 07094 (201) 348-7000

EASTERN ZONE : One Panasonic Way 4E-7 Secaucus, NJ 07094 (201) 348-7621

Mid-Atlantic/New England : One Panasonic Way 4E-7 Secaucus, NJ 07094 (201) 348-7621

Southeast Region : 1225 Northbrook Parkway, Ste 1-160 Suwanee GA 30024 (770)338-6835

Central Region : 1707 N Randall Road E1-C-1, Elgin, IL 60123 (847)468-5200

WESTERN ZONE : 3330 Cahuenga Blvd W., Los Angeles, CA 90068 (323) 436-3500

Dallas Region : 6226 Abington Way, Houston, TX 77008 (713) 802-2726

No. CA/Northwest Region : 5870 Stone Ridge, #3, Pleasanton, CA (925) 416-5108

Government Marketing Department : 52 West Gude Drive, Rockville, MD 20850 (301) 738-3840

Panasonic Canada Inc.

5770 Ambler Drive

Mississauga, Ontario

L4W 2T3

Printed in U.S.A.
