OWNER’S MANUAL
LCD TV
Please read this manual carefully before operating
your set and retain it for future reference.
The model and serial number of the TV is located
on the back and one side of the TV.
Record it below should you ever need service.
MODEL
1-800-243-0000 USA, Consumer User
1-888-865-3026 USA, Commercial User
1-888-542-2623 CANADA
SERIAL
LG Customer Information Center
This product qualifies for ENERGY STAR in the “factory default”
setting.
Changing the factory default settings or enabling other features
may increase power consumption that could exceed the limits
necessary to quality for ENERGY STAR.
32LG710H
37LG710H
42LG710H
32LD650H
37LD650H
42LD650H
47LD650H
55LD650H
32LD655H
37LD655H
42LD655H
P/NO : SAC34134301 (1007-REV02)
www.lg.com
WARNING / CAUTION
WARNING / CAUTION
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating
and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING/CAUTION
TO REDUCE THE RISK OF FIRE AND ELECTRIC
SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the National
Electric Code (U.S.A.). The code provides guidelines for
proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system
of the building, as close to the point of the cable entry
as practical.
2
To prevent fire or shock hazards, do not expose
this product to rain or moisture.
FCC NOTICE
Class B digital device
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause (harmful)
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation (of the device).
Any changes or modifications in construction of this
device which are not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
CAUTION
Do not attempt to modify this product in any way
without written authorization from LG Electronics.
Unauthorized modification could void the user’s
authority to operate this product
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
1
Do not use this apparatus near water.
2
Clean only with a dry cloth.
3
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
4
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers)that produce heat.
5
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong, The
wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
6
Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
7
Only use attachments/accessories specified by the
manufacturer.
8
Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from
tip-over.
9
Unplug this apparatus during lighting storms or
when unused for long periods of time.
10
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
11
Never touch this apparatus or antenna during a
thunder or lighting storm.
12
When mounting a TV on the wall, make sure not to
install the TV by the hanging power and signal cables
on the back of the TV.
13
Do not allow an impact shock or any objects to fall
into the product, and do not drop onto the screen
with something.
3
14
15
16
4
CAUTION concerning the Power Cord :
It is recommend that appliances be placed upon a
dedicated circuit; that is, a single outlet circuit which
powers only that appliance and has no additional
outlets or branch circuits. Check the specification
page of this owner's manual to be certain.
Do not connect too many appliances to the same
AC power outlet as this could result in fire or electric shock.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords,
frayed power cords, or damaged or cracked wire
insulation are dangerous. Any of these conditions
could result in electric shock or fire. Periodically
examine the cord of your appliance, and if its
appearance indicates damage or deterioration,
unplug it, discontinue use of the appliance, and
have the cord replaced with an exact replacement
part by an authorized servicer. Protect the power
cord from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a door, or
walked upon. Pay particular attention to plugs, wall
outlets, and the point where the cord exits the
appliance.
Do not make the TV with the power cord plugged
in. Do not use a damaged or loose power cord. Be
sure do grasp the plug when unplugging the power
cord. Do not pull on the power cord to unplug the
TV.
WARNING - To reduce the risk of fire or electrical
shock, do not expose this product to rain, moisture
or other liquids. Do not touch the TV with wet
hands. Do not install this product near flammable
objects such as gasoline or candles or expose the
TV to direct air conditioning.
As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power
source even if you turn off this unit by SWITCH.
17
Do not expose to dripping or splashing and do not
place objects filled with liquids, such as vases, cups,
etc. on or over the apparatus (e.g. on shelves above
the unit).
18
GROUNDING
Ensure that you connect the earth ground wire to
prevent possible electric shock. (i.e. a TV with a
three-prong grounded AC plug must be connected
to a three-prong grouned AC outlet) If grounding
methods are not possible, have a qualified electrician install a separate circuit breaker.
Do not try to ground the unit by connecting it to
telephone wires, lightening rods, or gas pipes.
Short-circuit
Breaker
Power
Supply
19
DISCONNECTING DEVICE FROM MAINS
Mains plug is the disconnecting device. The plug
must remain readily operable.
20
Dot Defect
The Plasma or LCD panel is a high technology
product with resolution of two million to six million
pixels. In a very few cases, you could see fine dots
on the screen while you’re viewing the TV. Those
dots are deactivated pixels and do not affect the
performance and reliability of the TV.
21
Generated Sound
“Cracking” noise: A cracking noise that occurs
when watching or turning off the TV is generated
by plastic thermal contraction due to temperature and humidity. This noise is common for products where thermal deformation is required.
Electrical circuit humming/panel buzzing: A low
level noise is generated from a high-speed switching circuit, which supplies a large amount of current to operate a product. It varies depending
on the product.
This generated sound does not affect the performance and reliability of the product.
22
ANTENNAS
Outdoor antenna grounding
If an outdoor antenna is installed, follow the precautions below. An outdoor antenna system should not
be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it can
come in contact with such power lines or circuits as
death or serious injury can occur.
Be sure the antenna system is grounded so as to provide some protection against voltage surges and
built-up static charges.
Section 810 of the National Electrical Code (NEC) in
the U.S.A. provides information with respect to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding
electrodes and requirements for the grounding electrode.
Antenna grounding according to the
National Electrical Code, ANSI/NFPA 70
Ground Clamp
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Electric Service
Equipment
Grounding Conductor
(NEC Section 810-21)
Ground Clamps
Power Service Grounding
Electrode System (NEC
Art 250, Part H)
NEC: National Electrical Code
23
Cleaning
When cleaning, unplug the power cord and scrub
gently with a soft cloth to prevent scratching. Do not
spray water or other liquids directly on the TV as
electric shock may occur. Do not clean with chemicals such as alcohol, thinners or benzene.
24
Moving
Make sure the product is turned off, unplugged
and all cables have been removed. It may take 2 or
more people to carry larger TVs. Do not press
against or put stress on the front panel of the TV.
25
Ventilation
Install your TV where there is proper ventilation. Do
not install in a confined space such as a bookcase.
Do not cover the product with cloth or other materials (e.g.) plastic while plugged in. Do not install in
excessively dusty places.
26
Take care not to touch the ventilation openings.
When watching the TV for a long period, the ventilation openings may become hot.
27
If you smell smoke or other odors coming from the
TV, unplug the power cord contact and authorized
service center.
28
Do not press strongly upon the panel with a hand or
sharp object such as nail, pencil or pen, or make a
scratch on it.
29
Keep the product away from direct sunlight.
30
For LCD TV
If the TV feels cold to the touch, there may be
a small “flicker” when it is turned on. This is
normal, there is nothing wrong with TV.
Some minute dot defects may be visible on the
screen, appearing as tiny red, green, or blue
spots. However, they have no adverse effect on
the monitor's performance.
Avoid touching the LCD screen or holding your
finger(s) against it for long periods of time.
Doing so may produce some temporary distortion effects on the screen.
ON DISPOSAL
(Only Hg lamp used LCD TV)
The fluorescent lamp used in this product contains
a small amount of mercury. Do not dispose of
this product with general household waste.
Disposal of this product must be carried out in
accordance to the regulations of your local authority.
5
CONTENTS
WARNING / CAUTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 3
FEATURES OF THIS TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PREPARATION
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front Panel Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Back Panel Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Stand Instuctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cable Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Desktop Pedestal Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Swivel Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Attaching the TV to a desk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
VESA Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Securing the TV to the wall to prevent falling
When the TV is used on a stand . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Antenna or Cable Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 24
MPI Card Slot / PPV Card Installation . . . . . . . . . . . . . . 25
EXTERNAL EQUIPMENT SETUP
HD Receiver Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
VCR Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Other A/V Source Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Audio Out Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
PC Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
WATCHING TV / CHANNEL CONTROL
Remote Control Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Turning On The TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Channel Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
On-Screen Menus Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Channel Setup
- Auto Scan (Auto Tuning) . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
- Add / Delete Channel (Manual Tuning) . . . . . . 43
- Channel Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Channel Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Input List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Example Electronic Program Guide . . . . . . . . . . . . . . . . . . . 46
USB
Entry Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6
Photo List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Music List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Extra Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
PICTURE CONTROL
PIP (Picture-In-Picture) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Picture Size (Aspect Ratio) Control . . . . . . . . . . . . . . . . . . 58
Preset Picture Settings (Picture Mode) . . . . . . . . . . . . . 61
Manual Picture Adjustment - User Mode . . . . . . . . . . 62
Picture Improvement Technology . . . . . . . . . . . . . . . . . . . . . 63
Picture Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Demo mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
SOUND & LANGUAGE CONTROL
Auto Volume Leveler (Auto Volume) . . . . . . . . . . . . . . . . . 67
Preset Sound Settings (Sound Mode) . . . . . . . . . . . . . . 68
Sound Setting Adjustment - User Mode . . . . . . . . . . . 69
- SRS TruSurround XT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
- Infinite Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Clear Voice ll . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
TV Speakers On/Off Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Audio Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Stereo/SAP Broadcast Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
On-Screen Menus Language Selection . . . . . . . . . . . . . . 77
Caption Mode
- Analog Broadcasting System Captions . . . . . . . 78
- Digital Broadcasting System Captions . . . . . . . . 79
- Caption Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
TIME SETTING
Clock Setting
- Auto Clock Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
- Manual Clock Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Auto On/Off Time Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Sleep Timer Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
PARENTAL CONTROL / RATINGS
Set Password & Lock System . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Channel Blocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Movie & TV Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Downloadable Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
External Input Blocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
APPENDIX
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Reference: LT2002 Cloning Procedure
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Troubleshooting Flow Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Commercial Mode Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Reference: RJP model list and input hierarchy . . 127
Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Programming the Remote Control . . . . . . . . . . . . . . . . . . . 132
IR Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Open Source License . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
COMMERCIAL MODE SETUP
Interactive TV Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Installer Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Interactive TV Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Commercial Mode Setup for Master TV . . . . . . . . . . . 99
Master TV Profile Setup Learning/Teaching with
USB Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
TLL-1100A Cloning Connections/Learning Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
LT2002 Cloning Connections/Learning Setup 103
LT2002 Cloning Learning Setup . . . . . . . . . . . . . . . . . . . . . 104
Cloning Connections/Teaching Setup . . . . . . . . . . . . . 105
Installer Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Reference: Detailed Instructions For Making A
Master TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Reference: Procedures for adding Channel Label
Icons/Custom Channel Labels (2-5-4 + MENU
Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Reference: Clonable Menu Features . . . . . . . . . . . . . . . . . 114
Reference: Power Saving Setup . . . . . . . . . . . . . . . . . . . . . . . . 115
TV Camport Auto Sense Operation . . . . . . . . . . . . . . . . 117
FTG Operation Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
FTG Channel Map Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .119
FTG Installer Menu Overview . . . . . . . . . . . . . . . . . . . . . . . . .120
FTG Operation Troubleshooting . . . . . . . . . . . . . . . . . . . .121
TV Aux Input Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
B-LAN Setup and Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .122
7
FEATURES OF THIS TV
■
This feature is not available for all models.
High-definition television. High-resolution digital
television broadcast and playback system composed
of roughly a million or more pixels, 16:9 aspect-ratio
screens, and AC3 digital audio. A subset of digital
television, HDTV formats include 1080i and 720p
resolutions.
Unlike other sensors which can only sense brightness
of ambient light, LG’s “Intelligent Sensor” uses 4,096
sensing steps to evaluate its surroundings. Using a
sophisticated algorithm, the LG processes picture
quality elements including brightness, contrast, color,
sharpness and white balance. The result is a picture
optimized for it’s surroundings, more pleasing to
watch and which can also save up to 50% in power
consumption.
View videos and photos and listen to music on your
TV through USB 2.0 (‘videos’ dependent on model).
LG TV include a unique invisible speaker system,
tuned by renowned audio expert, Mr. Mark Levinson.
Speakers are embedded in strategic spots behind the
front cabinet and use minute vibrations to turn the
entire front bezel into the speaker system. The result
is a clean, polished look, and enhanced audio by
increasing the “sweet spot”, giving a wider and richer
sound field.
Manufactured under license from Dolby Laboratories.
“Dolby “and the double-D symbol are trademarks of
Dolby Laboratories.
is a trademark of SRS Labs, Inc.
TruSurround XT technology is incorporated under
license from SRS Labs, Inc.
Automatically enhances and amplifies the sound of
human voice frequency range to help keep dialogue
audible when background noise swells.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC."
Matches the original frame rate of the film for a more
film-like experience
IMPORTANT INFORMATION TO PREVENT “IMAGE BURN
/ BURN-IN” ON YOUR TV SCREEN
■
■
■
8
When a fixed image (e.g. logos, screen menus, video game, and computer display) is displayed on the TV
for an extended period, it can become permanently imprinted on the screen. This phenomenon is known
as “image burn” or “burn-in.” Image burn is not covered under the manufacturer’s warranty.
In order to prevent image burn, avoid displaying a fixed image on your TV screen for a prolonged period
(2 or more hours for LCD, 1 or more hours for Plasma).
Image burn can also occur on the letterboxed
areas of your TV if you use the 4:3 aspect
ratio setting for an extended period.
PREPERATION
ACCESSORIES
TV
PO
W
ER
ST
GU
IDE
B
DV
PO
RTA
D
L
VC
INFO R
i
EN
TE
R
RE
TU
Owner’s Manual
PREPARATION
Ensure that the following accessories are included with your TV. If an accessory is missing, please contact the
dealer where you purchased the TV.
The accessories included may differ from the images below.
RN
ME
NU
CD Manual
INP
VO
L
UT
CC
AL
PH
A/N
UM
1
RE
.:/,
MUT
E
MO
VE
4
2
GH
5
7
PQ
RS
8
0
-
P
6
MN
O
9
WX
YZ
DE
F
1.5V 1.5V
TIM
ER
CH
+
3
JK
L
V
FLAS
HBK
RA
TIO
PIP
TU
&@
PIP
CH
E
AB
A
G
C
I
PIP
CH
PIP
SW
AP
SA
P
PIP
INP
UT
x2
Torx plus
Star head screw
(Refer to P.15, P.16)
* Wipe spots on the exterior only with the polishing cloth.
Optional Extras
* Do not wipe roughly when removing stains.
Excessive pressure may cause scratches or
discoloration.
Polishing Cloth
(Not included with all
models.)
Power Cord
Remote Control,
Batteries
Protective Bracket and
Screw for Power Cord
(Refer to P.17, P.18)
D-sub 15 pin Cable
When using the VGA (D-sub 15 pin
cable) PC connection, the user
must use shielded signal interface
cables with ferrite cores to maintain
standards compliance.
For 32/37/42LG710H
(For 32LG710H)
x4
x4
Screws for stand
assembly
(Refer to P.15)
Cable Holder
(Refer to P.17)
Screw for
stand fixing
(Refer to P.20)
Protection Cover
(Refer to P.15)
Plug-in type Holder
(Refer to P.17)
For 32/37/42/47/55LD650H, 32/37/42LD655H
(For 32/37/42LD650H, 32/37/42LD655H)
x4
Cable Holder Plug-in type Holder Rubber for stand
(Refer to P.18)
fixing
(Refer to P.18)
(Refer to P.20)
x2
x2
x8
(M4 x 20)
Screws for stand assembly Protection Cover
(Refer to P.16)
(Refer to P.16)
x2
Screws for stand Washers for stand Nuts for stand
fixing
fixing
fixing
(Refer to P.20)
(Refer to P.20) (Refer to P.20)
Screw for stand fixing
(Refer to P.20)
9
PREPARATION
FRONT PANEL INFORMATION
■
Image shown may differ from your TV.
PREPARATION
32/37/42LG710H
CH
Intelligent Sensor
Adjusts picture according to
the surrounding conditions.
VOL
CHANNEL(
Buttons
,
VOLUME (+, -)
Buttons
ENTER
ENTER Button
MENU
MENU Button
Power/Standby Indicator
Illuminates red in standby mode.
Illuminates blue when the set is
switched on.
Remote Control Sensor
POWER Button
10
INPUT
INPUT Button
)
CH
VOL
SPEAKER
CHANNEL(
Buttons
,
)
PREPARATION
32/37/42/47/55LD650H, 32/37/42LD655H
VOLUME (+, -)
Buttons
ENTER
ENTER Button
MENU
MENU Button
INPUT
Power/Standby Indicator
Illuminates red in standby mode.
Illuminates blue when the set is
switched on.
Remote Control Sensor
INPUT Button
POWER Button
Intelligent Sensor
Adjusts picture according to the surrounding conditions.
11
R
PREPARATION
BACK PANEL INFORMATION
■
Image shown may differ from your TV.
14
6
15
3
2
4
6
5
LAN
(SERVICE ONLY)
HDMI/DVI IN
2
OPTICAL
DIGITAL
AUDIO OUT
RGB IN
RESET
1(DVI)
RGB(PC)
(
AUDIO
(RGB/DVI)
SPEAKER OUT
8
RS-232C IN
(SERVICE ONLY)
REMOTE
CONTROL OUT
)
AUDIO
VIDEO
COMPONENT IN
AUDIO
/ MONO VIDEO
11
12
R
12
9
UPDATE
RJP
INTERFACE
13
8
GAME
CONTROL
TV-LINK
CFG
1
7
16
VIDEO L/MONO AUDIO R
M.P.I.
USB IN
R
ANTENNA IN
AV IN 1
PREPARATION
32/37/42LG710H
10
AV IN 2
11
R
M.P.I.
14
6
AC IN
6
8
11
9
SPEAKER
OUT
8
GAME
CONTROL
LAN
1
4
5
AV IN 1
3
VIDEO L/MONO AUDIO R
15
UPDATE
RESET
HDMI/DVI IN
TV-LINK CFG
2
VIDEO
/ MONO AUDIO
AUDIO OUT
)
(
R
L
RJP
INTERFACE
13
7
2
11
REMOTE
CONTROL
OUT
RS-232C IN
(SERVICE ONLY)
AUDIO IN
(RGB/DVI)
RGB IN (PC)
AV IN 2
COMPONENT
IN
1
OPTICAL
DIGITAL
16
PREPARATION
ANTENNA IN
USB IN
32/37/42LD650H, 32/37/42LD655H
10
12
USB IN
47/55LD650H
AC IN
15
11
6
8
14
GAME CONTROL
/ M.P.I.
LAN
1
4
5
RESET
UPDATE
HDMI/DVI IN
VIDEO
ANTENNA
IN
R
2
OPTICAL
DIGITAL
/ MONO AUDIO
AV IN 1
TV-LINK CFG
SPEAKER
OUT
8
AUDIO OUT
L
RJP
INTERFACE
13
RGB IN (PC)
2
AUDIO IN
(RGB/DVI)
R
9
AV IN 2
11
REMOTE
CONTROL
OUT
RS-232C IN
(SERVICE ONLY)
7
COMPONENT
IN
1
VIDEO L/MONO AUDIO R
3
16
12
10
13
PREPARATION
PREPARATION
1
2
RGB (PC)
Analog PC Connection. Uses a D-sub 15 pin cable
(VGA cable).
AUDIO (RGB/DVI)
1/8” headphone jack for analog PC audio input.
11
AV (Audio/Video) IN 1/2
Analog composite connection. Supports standard
definition video only (480i).
12
COMPONENT IN
Analog Connection. Supports HD.
Uses a red, green, and blue cable for video & a red
and white cable for audio.
13
RJP INTERFACE (REMOTE JACK PACK PORT)
Connect this to an LG remote jack pack system.
14
GAME CONTROL
Input port for third party game Controllers.
M.P. I.
Allows VOD/PPV devices or set-top boxes to control
the TV.
ANTENNA IN
Connect an antenna to receive over-the-air (OTA)
signals.
15
RS-232C IN (SERVICE ONLY)
Used for software updates.
Power Cord Socket
AC power input.
Caution: Never attempt to operate the TV on DC
power.
16
USB IN
Used for viewing multimedia files.
4
RESET
Performs a hardware reset.
UPDATE
Enables/disables software downloads and debug mode.
7
9
OPTICAL DIGITAL AUDIO OUT
Optical digital audio output for use with amps and
home theater systems.
Note: In standby mode, this port doesn’t work.
SPEAKER OUT 8Ω
For use with external speakers.
REMOTE CONTROL OUT
IR output for controlling an auxiliary device.
LAN (SERVICE ONLY)
For connecting to a control network.
6
8
10
3
5
14
HDMI/DVI IN
Digital Connection. Supports HD video and Digital
audio.
Accepts DVI video using an adapter or HDMI to DVI
cable (not included)
TV - LINK CFG
Computer input for programming Free To Guest services.
STAND INSTRUCTIONS
■
Image shown may differ from your TV.
32/37/42LG710H
DETACHMENT
1
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
2
Assemble the parts of the S T A N D B O D Y
with the S T A N D B A S E of the TV.
1
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
2
Remove the four screws that hold the base on.
3
Detach the stand from the TV.
PREPARATION
INSTALLATION
STAND BODY
STAND BASE
3
Insert the stand as shown.
4
x4
Tighten the stand with the
four screws (provided as parts
of the TV).
or
PROTECTION COVER
After removing the stand, install the included
p r o t e c t i o n c o v e r over the hole for the stand.
Press the P R O T E C T I O N C O V E R into the TV
until you hear it click.
Tighten the two of these four screws
x 2 and the two Torx plus star head screws
(provided as parts of the TV) to secure the TV. Tighten
the two Torx plus star head screws with a star head driver bit (not provided as parts of the TV).
x2
! NOTE
G
When assembling the desk type stand, make sure
the screws are fully tightened (If not tightened
fully, the TV can tilt forward after the protuct
installation). Do not over tighten.
15
PREPARATION
32/37/42/47/55LD650H, 32/37/42LD655H
INSTALLATION
DETACHMENT
PREPARATION
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
1
1
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
AC IN
CABLE MANAGEMEN
T
AC IN
CABLE MANAGEMENT
Assemble the parts of the S T A N D B O D Y
with the S T A N D B A S E of the TV.
2
2
STAND BODY
Remove the screws that hold the stand on.
AC IN
CABLE MANAGEMENT
M4 x 20
STAND BASE
3
Assemble the TV as shown.
3
Detach the stand from TV.
AC IN
AC IN
CABLE MANAGEMENT
CABLE MANAGEMENT
4
x4
Tighten the stand with the
four screws (provided as parts
of the TV).
or
Tighten the two of these four screws
x 2 and the two Torx plus star head screws
(provided as parts of the TV) to secure the TV. Tighten
the two Torx plus star head screws with a star head driver bit (not provided as parts of the TV).
x2
! NOTE
G
16
When assembling the desk type stand, make sure
the screws are fully tightened (If not tightened
fully, the TV can tilt forward after the protuct
installation). Do not over tighten.
PROTECTION COVER
After removing the stand, install the included
p r o t e c t i o n c o v e r over the hole for the stand.
Press the P R O T E C T I O N C O V E R into the TV
until you hear it click.
CABLE MANAGEMENT
■
Image shown may differ from your TV.
32/37/42LG710H
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
To help prevent the power cable from being
removed by accident, secure the power
cable with the included P ROTECTIVE
BRACKET /SCREW. The 32LG710H use a
Plug-in type Holder instead of using a
screw.
3
! NOTE
PROTECTIVE BRACKET/SCREW
G
Do not hold the CABLE MANAGEMENT CLIP
when moving the TV.
- If the TV is dropped, you may be injured or the
product may be broken.
G
With some TVs, the PLUG-IN TYPE HOLDER
and the CABLE HOLDER are included. If these
holders are inserted into the hole provided on
back of the TV, they cannot be removed.
Or
PLUG-IN TYPE HOLDER
(For 32LG710H model)
2
Put the cables inside the CABLE MANAGEMENT
CLIP and snap it closed.
PREPARATION
1
Open the CABLE MANAGEMENT CLIP as
shown.
If a CABLE HOLDER was included with your
TV, install it as shown.
CABLE MANAGEMENT CLIP
CABLE HOLDER
17
PREPARATION
32/37/42/47/55LD650H, 32/37/42LD655H
PREPARATION
1
3
Connect the cables as necessary.
To connect additional equipment, see the
EXTERNAL EQUIPMENT SETUP section.
To help prevent the power cable from being
removed by accident, secure the power cable
with the included P ROTECTIVE BRACKET
/SCREW. The 32/37/42LD650H,
32/37/42LD655H use a Plug-in type
Holder instead of using a screw.
Put the cables inside the CABLE MANAGEMENT CLIP and snap it closed.
AC IN
AC IN
! NOTE
PROTECTIVE BRACKET/SCREW
G
Do not hold the CABLE MANAGEMENT CLIP
when moving the TV.
- If the TV is dropped, you may be injured or the
product may be broken.
G
With some TVs, the PLUG-IN TYPE HOLDER
and the CABLE HOLDER are included. If these
holders are inserted into the hole provided on
back of the TV, they cannot be removed.
Or
PLUG-IN TYPE HOLDER
(For 32/37/42LD650H,
32/37/42LD655H model)
2
Open the CABLE MANAGEMENT CLIP as
shown.
If a CABLE HOLDER was included with your
TV, install it as shown.
AC IN
CABLE MANAGEMENT CLIP
CABLE HOLDER
(For 32/37/42LD650H,
32/37/42LD655H model)
18
PREPARATION
DESKTOP PEDESTAL INSTALLATION
■
Image shown may differ from your TV.
For proper ventilation, allow a clearance of 4 inches on all four sides from the wall.
PREPARATION
4 inches
4 inches
4 inches
CAUTION
4 inches
G
Ensure adequate ventilation by following the clearance recommendations.
G
Do not mount near or above any type of heat source.
SWIVEL STAND
After installing the TV, you can adjust the TV set manually to the left or right direction to suit your viewing position.
20°: 47/55LD650H
90°: Other Models
19
PREPARATION
ATTACHING THE TV TO A DESK
The TV should be attached to a desk so it cannot be pulled in a forward/backward direction, potentially causing
injury or damaging the product.
32/37/42LG710H
PREPARATION
Stand
4-Screws
(not provided as parts of the product)
Desk
Recommended screw size: M5 x L (*L: Table depth + 8~10mm)
ex) Table depth: 15mm, Screw: M5 x 25
G
32/37/42LD650H, 32/37/42LD655H
Type 2
Type 1
Stand
2-Screws
2-Screws, 2-Washers, 2-Nuts, 4-Rubber
(not provided as parts of the product) (provided as parts of the product)
G
G
You can select any type of attachment (Type 1 or Type 2)
Do not over tighten.
47/55LD650H
Stand
4-Screws
(not provided as parts of the product)
Desk
Stand
1-Screw
(provided as parts of the product)
Desk
WARNING
G
20
To prevent TV from falling over, the TV should be securely attached to the floor/wall per installation
instructions. Tipping, shaking, or rocking the TV may cause injury.
Desk
VESA WALL MOUNTING
A
PREPARATION
Install your wall mount on a solid wall perpendicular to the floor. When attaching to other building materials, please
contact an installer. If installed on a ceiling or slanted wall, it may fall and result in severe personal injury.
We recommend that you use an LG brand wall mount when mounting the TV to a wall.
LG recommends that wall mounting be performed by a qualified professional installer.
B
VESA (A * B)
Model
32LG710H
A
B
200 * 100
Standard Screw
Quantity
M4
4
Wall Mounting Bracket
(sold separately)
RW230
37LG710H,
42LG710H
200 * 200
M6
AW-47LG30M
4
AW-47LG30M
32LD650H,
32LD655H
200 * 100
M4
4
LSW100B, LSW100BG
37LD650H,
37LD655H,
42LD650H,
42LD655H,
47LD650H
200 * 200
55LD650H
400 * 400
M6
4
LSW200B, LSW200BG
M6
4
LSW400B, LSW400BG,
DSW400BG
21
PREPARATION
! NOTE
PREPARATION
G
G
G
G
G
Screw length needed depends on the wall mount
used. For further information, refer to the instructions included with the mount.
Standard dimensions for wall mount kits are shown
in the table.
When purchasing our wall mount kit, a detailed
installation manual and all parts necessary for
assembly are provided.
Do not use screws longer then the standard dimension, as they may cause damage to the inside of
the TV.
For wall mounts that do not comply with the VESA
standard screw specifications, the length of the
G
G
screws may differ depending on their specifications.
Do not use screws that do not comply with the
VESA standard screw specifications.
Do not use fasten the screws too strongly, this may
damage the TV or cause the TV to a fall, leading to
personal injury. LG is not liable for these kinds of
accidents.
LG is not liable for TV damage or personal injury
when a non-VESA or non specified wall mount is
used or the consumer fails to follow the TV installation instructions.
CAUTION
G
22
Do not install your wall mount kit while the TV is plugged in. It may result in personal injury due to electric shock.
SECURING THE TV TO THE WALL TO PREVENT FALLING
WHEN THE TV IS USED ON A STAND
■
You should purchase necessary components to prevent the TV from tipping over (when not using a wall mount).
Image shown may differ from your TV.
We recommend that you set up the TV close to a wall so it cannot fall over if pushed backwards.
Additionally, we recommend that the TV be attached to a wall so it cannot be pulled in a forward direction,
potentially causing injury or damaging the product.
Caution: Please make sure that children don’t climb on or hang from the TV.
■
PREPARATION
■
Insert the eye-bolts (or TV brackets and bolts) to tighten the product to the wall as shown in the picture.
* If your product has the bolts in the eye-bolts position before inserting the eye-bolts, loosen the
bolts.
* Insert the eye-bolts or TV brackets/bolts and tighten them securely in the upper holes.
Secure the wall brackets with the bolts (sold separately) to the wall. Match the height of the bracket
that is mounted on the wall to the holes in the product.
Ensure the eye-bolts or brackets are tightened securely.
■
Use a sturdy rope (sold separately) to tie the product. It is safer to
tie the rope so it becomes horizontal between the wall and the product.
! NOTE
G
G
Use a platform or cabinet strong enough and large enough to support the size and weight of the TV.
To use the TV safely make sure that the height of the bracket on the wall and the one on the TV are the same.
23
PREPARATION
■
To prevent damage, do not connect to the power outlet until all connections are made between the devices.
ANTENNA OR CABLE CONNECTION
PREPARATION
1. Antenna (Analog or Digital)
This image refers to using a Wall Antenna Socket or Outdoor
Antenna without a Cable Box Connection.
Wall
Antenna
Socket
Outdoor
Antenna
(VHF, UHF)
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
ANTENNA IN
M.P.I.
RF Coaxial Wire (75 Ω)
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Copper Wire
Be careful not to bend the copper wire
when connecting the antenna.
- For optimum picture quality, adjust the antenna direction if needed.
■ To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly.
■ If the antenna needs to be split for two TV’s, install a 2-Way Signal Splitter.
■ If the antenna is not installed properly, contact your dealer for assistance.
2. Cable
This image refers to using a cable connection without a cable box.
ANTENNA IN
Cable TV
Wall Jack
RF Coaxial Wire (75 Ω)
- If you experience a poor signal when using cable, make sure the RF cable is screwed in completely.
Contact your cable company is a poor signal persists.
24
M.P.I.
MPI CARD SLOT / PPV CARD INSTALLATION (Except 47/55LD650H)
The MPI card is equipped with an RF jack for antenna/cable signal source connection.
This card can be removed and replaced with a third-party PPV (Pay-Per-View) card.
1. Remove the two MPI card retainer screws.
2. Pull out current MPI card far enough so that the RF cable can be detached from the old card.
3. Detach RF cable.
4. Place new PPV card into slot and slide it in far enough to reconnect RF cable.
5. Insert card all the way into the slot making sure it is fully seated into back plane connector.
6. Replace the two card retainer screws.
ANTENNA IN
PREPARATION
MPI Card Removal / PPV Card Installation
M.P.I.
RF CABLE
M.P. I.
Card Slot
WARNING
G
There is an RF cable connected to the back of the card. Remove the card slowly.
25
EXTERNAL EQUIPMENT SETUP
■
■
To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.
Image shown may differ from your TV.
HD RECEIVER SETUP
This TV can receive Digital Over-the-air or Digital Cable signals without an external digital set-top box. However,
if you do receive digital signals from a digital set-top box or other digital external device, refer to the figure as
shown below.
EXTERNAL EQUIPMENT SETUP
Component Connection
1. How to connect
1
2
Y
PB
PR
L
R
Connect the video outputs (Y, PB, PR) of the digital settop box to the C O M P O N E N T I N V I D E O jacks on
the TV. Match the jack colors (Y = green, PB = blue, and
PR = red).
TV-LINK
CFG
Connect the audio output of the digital set-top box to
the C O M P O N E N T I N A U D I O jacks on the TV.
1
LAN
(SERVICE ONLY)
2
RESET
R
(S
■
Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
■
Select C o m p o n e n t input source using the I N P U T button
on the remote control.
RGB IN
2. How to use
AUDIO
(RGB/DVI)
RGB(PC)
AUDIO
AUDIO
VIDEO
COMPONENT
COMPONENTININ
Y, CB/PB, CR/PR
Supported Resolutions
Signal
Component
HDMI
480i
Yes
No
480p
Yes
Yes
720p
Yes
Yes
1080i
Yes
Yes
1080p
Yes
Yes
For 37/42/47/55LD650H, 37/42LD655H
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720x480i
15.73
15.73
59.94
60.00
720x480p
31.47
31.47
59.94
60.00
1280x720p
44.96
45.00
59.94
60.00
1920x1080i
33.72
33.75
59.94
60.00
1920x1080p
67.50
60.00
For 37/42/47/55LD650H, 37/42LD655H
26
U
HDMI Connection
HDMI/DVI IN
1. How to connect
2
2
No separate audio connection is necessary.
HDMI supports both audio and video.
1(DVI)
RGB
Connect the digital set-top box to H D M I / D V I I N 1
( D V I ) or 2 jack on the TV.
RJP
INTERFACE
VID
1
2. How to use
■
Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
■
Select H D M I 1 or H D M I 2 input source with using the I N P U T
button on the remote control.
EXTERNAL EQUIPMENT SETUP
1
HDMI-DTV OUTPUT
! NOTE
G
G
If the HDMI cables don’t support High Speed
HDMI, it can cause flickers or no screen display. In
this case use the latest cables that support High
Speed HDMI.
HDMI mode supports PCM, Dolby Digital audio
format.
HDMI-DTV
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720x480p
31.47
31.47
59.94
60.00
1280x720p
44.96
45.00
59.94
60.00
1920x1080i
33.72
33.75
59.94
60.00
1920x1080p
26.97
27.00
33.71
33.75
67.432
67.50
23.94
24.00
29.97
30.00
59.939
60.00
For 37/42/47/55LD650H, 37/42LD655H
27
EXTERNAL EQUIPMENT SETUP
DVI to HDMI Connection
1. How to connect
1
CO
HDMI/DVI IN
RESET
2
Connect the audio output of the digital set-top box to
the A U D I O ( R G B / D V I ) jack on the TV.
2
1(DVI)
RGB(PC)
UPDA
AUDIO
(RGB/DVI)
R
(S
RJP
INTERFACE
AUDIO
VIDEO
COMPONENT IN
2. How to use
1
Turn on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.)
■ Select the H D M I 1 input source on the TV using the
I N P U T button on the remote control.
■
2
DVI-DTV OUTPUT
! NOTE
G
28
LAN
(SERVICE ONLY)
RGB IN
EXTERNAL EQUIPMENT SETUP
TV-LINK
CFG
Connect the DVI output of the digital set-top box to
the H D M I / D V I I N 1 ( D V I ) jack on the TV.
A DVI to HDMI cable or adapter is required for this
connection. DVI doesn't support audio, so a separate
audio connection is necessary.
LL
R
/
DVD SETUP
Component Connection
Y
PB
PR
L
R
1. How to connect
TV-LINK
CFG
1
Connect the audio outputs of the DVD to the
C O M P O N E N T I N A U D I O jacks on the TV.
2. How to use
■
■
■
RESET
Turn on the DVD player, insert a DVD.
Select the C o m p o n e n t input source on the TV using the
I N P U T button on the remote control.
Refer to the DVD player's manual for operating instructions.
U
R
(S
RGB(PC)
RGB IN
2
2
LAN
(SERVICE ONLY)
AUDIO
(RGB/DVI)
AUDIO
AUDIO
VIDEO
COMPONENT
COMPONENTININ
EXTERNAL EQUIPMENT SETUP
Connect the video outputs (Y, PB, PR) of the DVD to the
C O M P O N E N T I N V I D E O jacks on the TV.
Match the jack colors (Y = green, PB = blue, and PR = red).
1
Component Input ports
To get better picture quality, connect a DVD player to the component input ports as shown below.
Video output ports
on DVD player
Y
PB
PR
Y
PB
PR
Y
B-Y
R-Y
Y
Cb
Cr
Y
Pb
Pr
HDMI Connection
1. How to connect
1
2
Connect the HDMI output of the DVD to the
H D M I / D V I I N 1 ( D V I ) or 2 jack on the TV.
No separate audio connection is necessary.
HDMI supports both audio and video.
HDMI/DVI IN
(S
2
RGB IN
Component ports on the TV
1(DVI)
RJP
INTERFACE
VIDEO
COM
1
2. How to use
■
■
Select the HDMI1 or HDMI2 input source on the TV
using the I N P U T button on the remote control.
Refer to the DVD player's manual for operating instructions.
HDMI OUTPUT
29
/
EXTERNAL EQUIPMENT SETUP
VCR SETUP
■
To avoid picture noise (interference), leave an adequate distance between the VCR and TV.
Antenna Connection
1. How to connect
EXTERNAL EQUIPMENT SETUP
Connect the RF antenna out socket of the
VCR to the A N T E N N A I N socket on the
TV.
1
ANTENNA IN
1
S-VIDEO
2
Connect the antenna cable to the RF
antenna in socket of the VCR.
VIDEO
L
ANT OUT
R
ANT IN
OUTPUT
SWITCH
Wall Jack
2
2. How to use
■
■
Set VCR output switch to 3 or 4 and then
tune TV to the same channel number.
Insert a video tape into the VCR and press
PLAY on the VCR. (Refer to the VCR owner’s
manual.)
Antenna
Composite (RCA) Connection
1. How to connect
V I D E O jacks between TV and
Connect the A U D I O/V
VCR. Match the jack colors (Video = yellow, Audio Left
= white, and Audio Right = red)
1
2. How to use
Select the A V 1 input source on the TV using the I N P U T
button on the remote control.
■ If connected to A V I N 2, select A V 2 input source on the TV.
! NOTE
G
30
If you have a mono VCR, connect the audio cable
from the VCR to the A U D I O L / M O N O jack of the
TV.
VIDEO S-VIDEO
L
OUTPUT
SWITCH
GAME
CONTROL
Insert a video tape into the VCR and press PLAY on the
VCR. (Refer to the VCR owner’s manual.)
■
R
ANT IN
1
OPTICAL SPEAKER
DIGITAL
OUT
AUDIO OUT
8
UPDATE
RS-232C IN
(SERVICE ONLY)
AV IN 1
■
ANT OUT
AUDIO
REMOTE
CONTROL
OUT
/ MONO VIDEO
M.P.I.
OTHER A/V SOURCE SETUP
Camcorder
1. How to connect
V I D E O jacks
Connect the A U D I O/V
between TV and external equipment.
Match the jack colors.
(Video = yellow, Audio Left = white, and
Audio Right = red)
■
■
■
Select the A V 2 input source on the TV using the
I N P U T button on the remote control.
If connected to A V I N 1 input, select the A V 1
input source on the TV.
Operate the corresponding external equipment.
R
USB IN
L
1
VIDEO L/MONO AUDIO R
2. How to use
VIDEO
EXTERNAL EQUIPMENT SETUP
1
Video Game Set
AV IN 2
AUDIO OUT CONNECTION
Send the TV’s audio to external audio equipment via the Audio Output port.
1. How to connect
Connect one end of the optical cable to the TV’s O P T IC A L D I G ITAL AUDIO OUT.
2
Connect the other end of the optical cable to the digital
audio input on the audio equipment.
3
Set the “TV Speaker option - Off” in the AUDIO menu. (G
p .73). See the external audio equipment instruction manual for operation.
! NOTE
G
When connecting with external audio equipment, such as
amplifiers or speakers, you can turn the TV speakers off in
the menu. (G p . 7 3)
GAME
CONTROL
OPTICAL SPEAKER
DIGITAL
OUT
AUDIO OUT
8
UPDATE
RS-232C IN
(SERVICE ONLY)
AV IN 1
1
AUDIO
1
REMOTE
CONTROL
OUT
/ MONO VIDEO
2
CAUTION
G
G
Do not look into the optical output port. Looking at the
laser beam may damage your vision.
Audio with ACP(Audio Copy Protection) function my
block digital audio output.
31
EXTERNAL EQUIPMENT SETUP
PC SETUP
This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.
(
)
RESET
RS-232C IN
(SERVICE ONLY
1. How to connect
EXTERNAL EQUIPMENT SETUP
Connect the VGA output of the PC to the R G B ( P C)
jack on the TV.
2
Connect the PC audio output to the A U D I O ( R G B / D V I)
jack on the TV.
RGB(PC)
AUDIO
(RGB/DVI)
AV IN 1
RGB IN
VGA (D-Sub 15 pin) Connection
1
UPDATE
AUDIO
VIDEO
COMPONENT IN
1
AU
/
2
2. How to use
■
■
Turn on the PC and the TV.
Select the R G B - P C input source on the TV using the
I N P U T button on the remote control.
RGB OUTPUT
AUDIO
DVI to HDMI Connection
1. How to connect
1
Connect the DVI output of the PC to the H D M I / D V I I N
1 ( D V I ) jack on the TV.
TV-LINK
CFG
LAN
(SERVICE ONLY)
HDMI/DVI IN
RESET
2
Connect the PC audio output to the A U D I O ( R G B / D V I )
jack on the TV.
(S
RGB IN
2
UP
1(DVI)
RGB(PC)
AUDIO
(RGB/DVI)
RJP
INTERFACE
2. How to use
■
■
Turn on the PC and the TV.
Select the HDMI1 input source on the TV using the
I N P U T button on the remote control.
2
DVI-PC OUTPUT
32
AUDIO
VIDEO
COMPONENT IN
1
AUDIO
/
! NOTES
be a noise on the screen.
G
Avoid keeping a fixed image on the screen for a
long period of time. The fixed image could become
permanently imprinted on the screen.
G
Depending on the graphics card, DOS mode may
not work if a HDMI to DVI Cable is in use.
G
The synchronization input form for Horizontal and
Vertical frequencies is separate.
G
In PC mode, there may be noise associated with
the resolution, vertical pattern, contrast or brightness. If noise is present, change the PC output to
another resolution, change the refresh rate to
another rate or adjust the brightness and contrast
on the PICTURE menu until the picture is clear.
When you use too long RGB-PC cable, there might
G
Depending on the graphics card, some resolution
settings may not allow the image to be positioned
on the screen properly.
Supported Display Specifications
RGB-PC
EXTERNAL EQUIPMENT SETUP
To get the best picture quality, adjust the PC graphics card to 1 3 6 0 x 7 6 8 (32/37/42LG710H,
32LD650H, 32LD655H) or 1 9 2 0 x 1 0 8 0
(37/42/47/55LD650H, 37/42LD655H).
G
HDMI-PC
Horizontal
Resolution Frequency
(kHz)
Vertical
Frequency(Hz)
Horizontal
Resolution Frequency
(kHz)
Vertical
Frequency(Hz)
720x400
31.469
70.08
720x400
31.469
70.08
640x480
31.469
37.861
59.94
72.80
640x480
31.469
59.94
800x600
37.879
48.077
60.31
72.18
800x600
35.156
37.879
56.25
60.31
48.363
56.476
60.00
70.06
1024x768
1024x768
48.363
60.00
1280x768
47.776
59.87
1280x768
47.776
60.289
59.870
74.893
1360x768
47.712
60.015
1360x768
47.712
60.015
1280x1024
63.981
60.02
1280x1024
63.981
79.976
60.020
75.025
1920x1080
67.50
60.00
1920x1080
66.587
59.934
For 37/42/47/55LD650H, 37/42LD655H
For 37/42/47/55LD650H, 37/42LD655H
33
EXTERNAL EQUIPMENT SETUP
Screen Setup for PC mode
Selecting Resolution
When using RGB-PC input, change the resolution in the menus to match the PC’s.
The P o s i t i o n, P h a s e, and S i z e can also be adjusted.
EXTERNAL EQUIPMENT SETUP
Move
SCREEN
Enter
E
• Brightness
50
• Sharpness
50
• Color
50
• Tint
0
Resolution
Auto Config.
R
G
Position
• Advanced Control
• Picture Reset
Size
Screen (RGB-PC)
Phase
Reset
1 MENU
Select P I C T U R E.
2
ENTER
Select S c r e e n ( R G B - P C ).
ENTER
Select R e s o l u t i o n.
3
4
ENTER
5
34
Move
ENTER
Select the desired resolution.
1024 x 768
1280 x 768
1360 x 768
Prev.
Auto Configure
Automatically adjusts picture position and minimizes image instability. After adjustment, if the image is still
not correct, try using the manual settings or a different resolution or refresh rate on the PC.
Move
SCREEN
Enter
E
• Brightness
50
• Sharpness
50
• Color
50
• Tint
0
Move
Prev.
Resolution
Auto Config.
R
G
Position
• Advanced Control
• Picture Reset
Screen (RGB-PC)
Size
To Set
Yes
No
Phase
Reset
EXTERNAL EQUIPMENT SETUP
1 MENU
Select P I C T U R E.
2
ENTER
Select S c r e e n ( R G B - P C ).
ENTER
Select A u t o c o n f i g ..
3
4
ENTER
• If the position of the image is still not
correct, try Auto adjustment again.
• If picture needs to be adjusted again
after Auto adjustment in RGB-PC, you
can adjust the P o s i t i o n , S i z e or
P h a s e.
Select Y e s.
5
ENTER
Start Auto Configuration.
35
EXTERNAL EQUIPMENT SETUP
Adjustment for screen Position, Size, and Phase
Move
Enter
SCREEN
Move
Prev.
E
EXTERNAL EQUIPMENT SETUP
If the picture is not clear after auto adjustment and especially if characters are still trembling, adjust the picture
phase manually.
This feature operates only in RGB-PC mode.
• Brightness
50
• Sharpness
50
• Color
50
• Tint
0
Resolution
Auto Config.
R
G
D
Position
• Advanced Control
• Picture Reset
Screen (RGB-PC)
F
G
E
Size
Phase
Reset
1 MENU
Select P I C T U R E.
■
2
ENTER
Select S c r e e n ( R G B - P C ).
■
3
ENTER
Select P o s i t i o n, S i z e, or P h a s e.
■
4
ENTER
5
ENTER
36
Make appropriate adjustments.
P o s i t i o n: This function is to adjust picture to left/right and up/down as you
prefer.
S i z e: This function is to minimize any
vertical bars or stripes visible on the
screen background. And the horizontal
screen size will also change.
P h a s e : This function allows you to
remove any horizontal noise and clear or
sharpen the image of characters.
Screen Reset (Reset to original factory values)
Returns P o s i t i o n, S i z e, and P h a s e to the default factory settings.
This feature operates only in RGB-PC mode.
Move
SCREEN
Enter
Move
Prev.
E
• Brightness
50
• Sharpness
50
• Color
50
• Tint
0
Resolution
Auto config.
R
G
Position
• Advanced Control
• Picture Reset
Screen (RGB-PC)
Size
Phase
Reset
To Set
Yes
No
EXTERNAL EQUIPMENT SETUP
1 MENU
Select P I C T U R E.
2
ENTER
Select S c r e e n ( R G B - P C ).
ENTER
Select R e s e t.
3
4
ENTER
Select Y e s.
5
ENTER
37
WATCHING TV / CHANNEL CONTROL
REMOTE CONTROL FUNCTIONS
When using the remote control, aim it at the remote control sensor on the TV.
POWER Turns your TV or any other programmed equipment on
or off, depending on mode.
TV
POWER
VCR
STB
TV/STB/DVD/VCR Selects the remote’s operating mode: TV, STB, DVD, or
VCR.
GUIDE
DVD
PORTAL
INFO i
WATCHING TV / CHANNEL CONTROL
GUIDE Displays and removes the electronic channel guide.
PORTAL Displays and removes the hotel interactive menu.
ENTER
INFO Displays information about the selected or current events.
NUMBER Enters channel numbers or other numbers required. Also
button supports characters.
RETURN
— (DASH) Selects a program number for multiple program channels
such as 2-1, 2-2, etc.
FLASHBK Tunes to the last channel or input viewed.
RATIO Changes the aspect ratio. G p.58
TIMER Turns the TV off in a set amount o f time. G p.84
SAP
INPUT
CC
VOL
ALPHA/NUM
CH
MUTE
VCR/DVD/USB Controls video cassette recorders or DVD players or USB.
control buttons
PIP Toggles through picture-in-picture options.
MENU
REMOVE
1
2
ABC
3
DEF
GHI
5
JKL
6
MNO
PQRS
8
TUV
9
0
&@
FLASHBK
.:/,
4
7
Analog mode: Selects MTS sound (Mono, Stereo, or a
SAP) G p.75
DTV mode: Changes the audio language.
WXYZ
PIP CH +/- Changes the PIP channel.
PIP
PIP SWAP Exchanges the main/sub images.
RATIO
TIMER
SAP
PIP CH- PIP CH+ PIP SWAP PIP INPUT
PIP INPUT Selects the connected input source for the sub-picture.
38
P
A
G
E
THUMBSTICK Navigates the on-screen menus and adjusts the system settings to your preference.
(Up/Down/Left
Right/ENTER)
RETURN Clears all on-screen displays and returns to TV viewing from any menu.
INPUT Rotates through inputs.
Also switches the TV on from standby.
VOLUME UP Adjusts the volume.
/DOWN
CC Selects a closed caption. G p.78
MUTE Switches the sound on or off. G p.40
WATCHING TV / CHANNEL CONTROL
MENU Displays the main menu.
CHANNEL Selects available channels.
UP/DOWN
PAGE Moves from one full set of screen information to the next one.
UP/DOWN
Installing Batteries
■
Open the battery compartment cover on the back side and install
the batteries with the correct polarity (+with +,-with -).
■
Install two 1.5V AAA batteries. Don’t mix old or used batteries with
new ones.
■
Close cover.
39
WATCHING TV / CHANNEL CONTROL
TURNING ON THE TV
WATCHING TV / CHANNEL CONTROL
1
First, connect the power cord correctly.
At this moment, the TV switches to standby mode.
■ In standby mode to turn TV on, press the
button on the TV or press
the P O W E R button on the remote control.
2
Select the viewing source by using the INPUT button on the remote control.
3
When finished using the TV, press the POWER button on the remote control.
The TV reverts to standby mode.
! NOTE
G
If you intend to be away on vacation, disconnect the power plug from the wall power outlet.
CHANNEL SELECTION
1
Press the CH(
or
) or NUMBER buttons to select a channel number.
VOLUME ADJUSTMENT
Adjust the volume to suit your personal preference.
40
1
Press the V O L ( + or - ) button to adjust the volume.
2
If you want to switch the sound off, press the M U T E button.
3
You can cancel the Mute function by pressing the MUTE or V O L ( + or - )
button.
ON-SCREEN MENUS SELECTION
Your TV's OSD (On Screen Display) may differ slightly from that shown in this manual.
CHANNEL
Move
Enter
Move
AUDIO
Enter
Move
Auto Volume
Auto Tuning
Aspect Ratio : 16:9
Manual Tuning
Picture Mode : Standard
Clear Voice II
: On
• Level
3
-
+
0
L
R
Channel Edit
• BackLight
90
Channel Label
• Contrast
90
Balance
• Brightness
50
Sound Mode
• Sharpness
60
• SRS TruSurround XT: Off
• Color
60
• Treble
50
• Bass
50
0
: Standard
E
E
OPTION
Move
Menu Language
: English
Audio Language
: English
Caption
: Off
Set ID
:1
Demo Mode
: Off
TIME
Enter
Move
Enter
Clock
CHANNEL
AUDIO
TIME
Off Time
: Off
On Time
: Off
Sleep Timer
: Off
Data Broadcasting
OPTION
LOCK
Move
Lock System
LOCK
USB
INPUT
Enter
: Off
INPUT
Lock System
: Off
Move
Enter
USB
TV
Photo List
Set Password
Set Password
AV1
Music List
Block Channel
Block Channel
AV2
Extra Contents
Movie Rating
TV Rating-English
Component
Eject
TV Rating-Children
TV Rating-French
RGB-PC
TV Rating-General
Downloadable Rating
HDMI1
Downloadable Rating
Input Block
HDMI2
Move
WATCHING TV / CHANNEL CONTROL
• Tint
Enter
: On
Enter
Input Block
For USA
1 MENU
2
For CANADA
Display each menu.
! NOTE
G
ENTER
3
ENTER
4 MENU
Select a menu item.
Infinite Sound: For 32/37/42/47/55LD650H,
32/37/42LD655H
Accept the current selection.
Return to TV viewing.
41
WATCHING TV / CHANNEL CONTROL
CHANNEL SETUP
Auto Scan (Auto Tuning)
Automatically finds all channels available through antenna or cable inputs and stores them in memory on the
channel list.
Run Auto Tuning again after any Antenna/Cable connection changes.
WATCHING TV / CHANNEL CONTROL
CHANNEL
Move
CHANNEL
Auto Tuning
Manual Tuning
Manual Tuning
Channel Edit
Channel Edit
Channel Label
Channel Label
Move
Enter
Check your antenna connection.
The previous channel information
will be updated during Auto
Tuning.
Yes
No
1 MENU
Select C H A N N E L.
2
ENTER
Select A u t o T u n i n g.
3
ENTER
4
ENTER
Select Y e s.
Run A u t o t u n i n g.
5 RETURN
Return to the previous menu.
MENU
Return to TV viewing.
42
Enter
Auto Tuning
■
A password is required to gain access to
Auto Tuning menu if the Lock System is
turned on.
Add/Delete Channel (Manual Tuning)
If selecting DIGITAL input signal, you can view the on-screen signal strength monitor to see the quality of the
signal being received.
CHANNEL
Move
Enter
CHANNEL
Auto Tuning
Manual Tuning
Manual Tuning
Channel Edit
Channel Edit
Channel Label
Channel Label
Move
Enter
F
DIGITAL
G
Select channel type and
RF-channel number.
Channel
2
DIGITAL 2-1
Bad
Normal
Good
Delete
Close
1 MENU
Select C H A N N E L.
2
WATCHING TV / CHANNEL CONTROL
Auto Tuning
Select M a n u a l T u n i n g.
ENTER
3
■
ENTER
Select D I G I T A L or A N A L O G.
4
A password is required to gain access to
Manual Tuning menu if the Lock System
is turned on.
Select channel you want to add
or delete.
5
ENTER
Select A d d or D e l e t e.
6 RETURN
Return to the previous menu.
MENU
Return to TV viewing.
43
WATCHING TV / CHANNEL CONTROL
Channel Editing
The channels in the Channel Edit List are displayed in black and the channels deleted from the Channel Edit
List are displayed in blue. When a channel number is deleted, it means that you will be unable to select it using
CH
button during TV viewing.
If you wish to select the deleted channel, directly enter the channel number with the NUMBER buttons or select
it in the C h a n n e l E d i t menu.
CHANNEL
Move
Enter
Auto Tuning
Manual Tuning
Channel Edit
Channel Label
WATCHING TV / CHANNEL CONTROL
Ch. Change
Navigation
CH
Page Change
Previous
Add/Delete
1 MENU
2
4
Select C H A N N E L.
BLUE
ENTER
Select C h a n n e l E d i t.
ENTER
Select a channel.
5 RETURN
3
MENU
Select channel you want to add or delete.
Return to the previous menu.
Return to TV viewing.
CHANNEL LABEL
Choose preset labels for your channels.
If a channel label is provided on the signal from the broadcasting station, the TV displays a short name for a
channel even if you didn't preset a label for the channel.
CHANNEL
Move
CHANNEL
Enter
Auto Tuning
Auto Tuning
Manual Tuning
Manual Tuning
Channel Edit
Channel Edit
Channel Label
Channel Label
Move
Enter
ANALOG 2-0
Channel
Logo
F
Disney
G
Close
1 MENU
2
ENTER
5
Select the appropriate logo for the
channel.
Select C H A N N E L.
Select C h a n n e l L a b e l.
6 RETURN
Return to the previous menu.
3
ENTER
4
44
Select a Channel.
Select a channel to set logo.
MENU
Return to TV viewing.
INPUT LIST
TV
ENTER
AV2
Component
RGB-PC
Select the desired input source.
TV
HDMI2
AV1
HDMI1
AV2
RGB-PC
Component
■
■
■
■
■
T V: Select it to watch over-the-air, cable
and digital cable broadcasts.
A V 1 - 2: Select them to watch a VCR or
other external equipment.
C o m p o n e n t : Select them to watch
DVD or a Digital set-top box.
R G B - P C: Select it to view PC input.
H D M I 1 - 2: Select them to watch high
definition devices.
WATCHING TV / CHANNEL CONTROL
1 INPUT
AV1
45
WATCHING TV / CHANNEL CONTROL
EXAMPLE ELECTRONIC PROGRAM GUIDE
This is an example of a typical TV electronic program guide showing available programming.
CHANNEL INDICATOR
Currently tuned channel
and program.
PROGRAMMING GRID
Program listings arranged in
time slots.
TV PROGRAM
Current program on selected channel.
DATE/TIME OSD
Shows current Date/Time.
WATCHING TV / CHANNEL CONTROL
Kids
K&M
Kids Movies
Channel 01:30 AM
Mon. 29 May 2009 11:07
2:30 AM
17 XYZ
On The Political Scene
18 K&M
Kids Movies
19 PQX
Top Fashions
20 WBD
World Events Today
2:45 AM
Kids ...
3:00 AM
Kids ...
New Release
Greatest Hits
EVENT CHANNEL SELECTION
PORTAL INFO
ENTER
CHANNEL LIST
Shows available
channels in numerical
order.
1 GUIDE
PROGRAM TITLES
Highlight a title and press
Enter to display additional
program information.
Select G U I D E button to shows available TV programs.
2
ENTER
46
Select a Channel.
FEATURED ATTRACTION
Highlight and click to get
expanded information.
USB
■
Image shown may differ from your TV.
ENTRY MODES
When you connect a USB device, this pop-up menu is displayed automatically.
When the Pop-Up menu does not appear, you can select Photo List or Music List on Extra contents.
On a USB device, you can not add a new folder or delete an existing folder.
1 Connect the USB device to the U S B
I N jack
USB IN
on the side of TV.
■
This TV supports playback of JPG pictures and MP3
audio.
or
Memory Key
R
USB
2
Select P H O T O L I S T or M U S I C L I S T or E X T R A C O N T E N T S.
i
Choose the media you want.
Photo List
Music List
Fl
Extra Contents
Close
3
ENTER
When removing the USB device
USB
Move
Enter
USB
Move
Photo List
Photo List
Music List
Music List
Extra Contents
Extra Contents
Eject
Eject
i
Enter
Now you can eject USB.
Close
1 MENU
Select U S B.
2
ENTER
4 RETURN
Return to the previous menu.
MENU
Select E j e c t.
Return to TV viewing.
3
ENTER
47
USB
Precautions with USB devices.
G
G
G
G
G
G
G
USB
G
G
G
G
G
G
G
G
G
G
G
G
48
Only a USB storage device is recognizable.
If the USB storage device is connected through a USB hub, the device is not recognizable.
A USB storage device using an automatic recognition program may not be recognized.
A USB storage device which uses its own driver may not be recognized.
The recognition speed of a USB storage device may depend on each device.
In case of a card reader, up to four memory cards are concurrently recognizable.
Please do not turn off the TV or unplug the USB device when the connected USB storage device is working.
When such device is suddenly separated or unplugged, the stored files or the USB storage device may be damaged.
Only use a USB storage device which has normal music, image or movie files.
Please connect power to a USB storage device (over 0.4A) which requires an external power supply. If not, the
device may not be recognized.
Please connect a USB storage device with cable is offered by USB maker. If connected with cable is not offered
by USB maker or an excessively long cable, the device may not be recognized.
Some USB storage devices may not be supported or operate properly.
File alignment method of USB storage device is similar to Window XP and filename can recognize up to 100
English characters.
Please backup important files because data on the USB device may be damaged. Data management is the consumer's responsibility and as a result, the manufacturer does not cover data damage.
Please use only a USB storage device which was formatted as a FAT32, NTFS file system provided with the Windows
operating system. In case of a storage device formatted as a different utility programme which is not supported by
Windows, it may not be recognized.
Data in a USB storage device cannot be deleted in the NTFS file system.
If your USB memory device has multiple partitions, or if you use a USB multi-card reader, you can use up to 4
partitions or USB memory devices.
The recommended capacity is 1TB or less for a USB external hard disk and 32GB or less for USB memory.
Any device with more than the recommended capacity may not work properly.
When using a USB HDD via the USB extensing cable, connect a support electric power source.
PHOTO LIST
This TV only supports picture in JPEG(.jpg) format.
The On-Screen Display on your model may be slightly different.
Supported photo file: *.JPG
• You can view JPG files only.
• Only baseline scan is supported among JPG.
• Supported JPG size: 64 pixel (width) x 64 pixel (height) to 15360 pixel (width) x 8640 pixel (height)
USB
Screen Components
1 MENU
1
Moves to upper level folder
2
Preview: Displays the
thumbnail/folder name of
the photo in the selected
folder
3
2
Select U S B.
Current page/Total pages
4
Total number of marked photos
5
Corresponding buttons on
the remote control
ENTER
ENTER
Select P h o t o L i s t.
3
Photo List
Page 2/3
Drive1
JMJ001
1366x768, 125KB
Up Folder
Navigation
No Marked
Up Folder
2
1
4
KY103
03/30/2008
KY101
06/10/2008
KY104
06/19/2008
KY102
04/03/2008
KY105
01/31/2008
JMJ001
01/01/2000
JMJ005
05/13/2008
JMJ002
06/15/2008
JMJ006
05/26/2008
JMJ003
04/03/2008
JMJ007
02/18/2008
JMJ004
02/18/2008
JMJ008
02/18/2008
Popup Menu
Exit
5
49
USB
Photo Selection and Pop-up Menu
Photo List
Drive1
JMJ001
Up Folder
Navigation
USB
Drive1
JMJ001
Up Folder
50
03/30/2008
06/10/2008
KY104
06/19/2008
KY102
04/03/2008
KY105
01/31/2008
JMJ001
01/01/2000
JMJ005
05/13/2008
JMJ002
06/15/2008
JMJ006
05/26/2008
JMJ003
04/03/2008
JMJ007
02/18/2008
JMJ004
02/18/2008
JMJ008
02/18/2008
Exit
Page 2/3
No Marked
Up Folder
1366x768, 125KB
KY103
03/30/2008
KY101
06/10/2008
125KB
KY1041366x768,
06/19/2008
KY102
04/03/2008
View
KY105
01/31/2008
JMJ001
01/01/2000
Mark
JMJ005
05/13/2008
JMJ002
06/15/2008
Mark All05/26/2008
JMJ006
JMJ003
04/03/2008
Delete
JMJ007
02/18/2008
JMJ004
02/18/2008
JMJ008
Close
02/18/2008
Popup Menu
Select the target folder or drive.
2
ENTER
3
ENTER
4
KY103
KY101
Popup Menu
Photo List
1
No Marked
Up Folder
1366x768, 125KB
Navigation
Page 2/3
Select the desired photos.
Show the Pop-up menu.
ENTER
Select the desired Popup menu.
Exit
When you select a file (not folder), this Pop-Up
menu is displayed.
G V i e w: Display the selected item.
G M a r k: Use to mark a photo.
G U n m a r k: Use to unmark a photo.
G Mark All: Mark all photos on the screen.
G U n m a r k A l l: Deselect all marked photos.
G D e l e t e or Delete Marked: Delete the selected
photo item.
G C l o s e: Close the pop-up menu.
■
When one or more photos are marked, you can
view individual photos or a slide show of the
marked photos. If no photos are marked, you
can view all photos individually or all photos in
the folder in a slide show.
Full Screen Menu
You can change the Photo List view so that it fills the screen. More operations are available in full
screen mode.
Photo List
Page 2/3
Drive1
JMJ001
1366x768,
125KB
Photo List
Drive1
JMJ001
1366x768, 125KB
Up Folder
KY103
03/30/2008
KY101
06/10/2008
KY104
06/19/2008
KY102
04/03/2008
KY105
01/31/2008
JMJ001
01/01/2000
JMJ005
05/13/2008
JMJ002
06/15/2008
JMJ006
05/26/2008
JMJ003
04/03/2008
JMJ007
02/18/2008
JMJ004
02/18/2008
JMJ008
02/18/2008
Exit
Popup Menu
Page 2/3
USB
Up Folder
Navigation
No Marked
Up Folder
No Marked
Up Folder
KY103
03/30/2008
KY101
06/10/2008
125KB
KY1041366x768,
06/19/2008
KY102
04/03/2008
KY105
View
01/31/2008
JMJ001
01/01/2000
JMJ005
Mark
05/13/2008
JMJ002
06/15/2008
JMJ006
Mark All05/26/2008
JMJ003
04/03/2008
JMJ007
Delete
02/18/2008
JMJ004
02/18/2008
JMJ008
Close
02/18/2008
1/17
Navigation
Popup Menu
Exit
Slideshow
BGM
Delete
Option
Hide
The aspect ratio of a photo may change the size of the
photo displayed on the screen in full size.
Press the R E T U R N button to move to the previous menu
screen.
1
Select the target folder or drive.
2
ENTER
3
ENTER
4
5
■
Use the C H
photo page.
button to navigate in the
Select the desired photos.
Show the Pop-up menu.
Select V i e w.
ENTER
The selected photo is displayed in
full size.
51
USB
6
ENTER
Select the Slideshow, B G M,
(Rotate), D e l e t e, Option,
or Hide.
■
1/17
Slideshow
BGM
Delete
Option
Hide
Use
button to select the previous or
next photo.
■ Use
button to select and control
the menu on the full-sized screen.
USB
S l i d e s h o w: Selected photos are displayed during the
slide show. If no photo is selected, all photos in the current folder are displayed during slide show.
■ Set the time interval of the slide show in O p t i o n.
G B G M: Listen to music while viewing photos in full size.
■ Set the BGM device and album in O p t i o n.
( R o t a t e ): Rotate photos.
G
■ Rotates the photo 90°, 180°, 270°, 360° clockwise.
G D e l e t e: Delete photos.
G O p t i o n: Set values for S l i d e S p e e d and M u s i c
A l b u m.
■ Use
button and E N T E R button to set
values. Then go to
and press E N T E R to save
the settings.
■ You cannot change M u s i c A l b u m while BGM is
playing.
G H i d e : Hide the menu on the full-sized screen.
■ To see the menu again on the full-sized screen, press
E N T E R button to display.
G
52
Press F G to set the time interval between slides.
Slide Speed
Music Album
Enter
Fast
...
Cancel
MUSIC LIST
You can use the Music List menu to play MP3 files from a USB storage device.
This TV cannot play back copy-protected files.
The On-Screen Display on your model may be slightly different.
USB
Supported music file: *.MP3
Bit rate range 32 Kbps - 320 Kbps
• Sampling rate (Sampling Frequency)
MPEG1 layer 3: 32 kHz, 44.1 kHz, 48 kHz
MPEG2 layer 3: 16 kHz, 22.05 kHz, 24 kHz
MPEG2.5 layer 3: 8 kHz, 11.025 kHz, 12 kHz
Screen Components
1 MENU
2
Select U S B.
ENTER
ENTER
Select M u s i c L i s t.
3
1
Moves to upper level folder
2
Preview: If a supported picture of the album jacket is
in the file, it will be displayed here.
3
Current page/Total pages
4
Total number of marked files
5
Corresponding buttons on
the remote control
Music List
4
Page 2/3
No Marked
Drive1
Title
Duration
Up Folder
2
A
1
00:00 / 04:16
Up Folder
Navigation
Popup Menu
Exit
5
53
USB
Music Selection and Pop-up Menu
P l a y (During stop): Play the selected file.
Once a song finishes playing, the next selected
one will be played. When there are no selected
files to play, the next one in the current folder
will be played. If you go to a different folder and
press the E N T E R button, the current song in
playback will stop.
G P l a y M a r k e d: Play the selected files. Once a
file finishes playing, the next selected one will
be played automatically.
G S t o p P l a y (During playback): Stop the playing files.
G P l a y w i t h P h o t o: Start playing the selected
files and then move to the Photo List.
G M a r k : Use to mark a file.
G U n m a r k : Use to unmark a file.
G M a r k A l l: Mark all files in the folder.
G U n m a r k A l l: Deselect all marked files.
G D e l e t e or Delete Marked: Delete the selected
files.
G C l o s e: Close the pop-up menu.
G
Music List
No Marked
Page 2/3
Drive1
Duration
Title
Up Folder
A
00:00 / 04:16
Up Folder
USB
Navigation
Popup Menu
Music List
Page 2/3
Exit
No Marked
Drive1
Duration
Title
Up Folder
3945 KB
128 Kbps
Play
Play with Photo
A
Mark
00:00 / 04:16
Mark All
Up Folder
Navigation
1
2
3
Close
Select the target folder or drive.
Select the desired musics.
ENTER
ENTER
4
5 RETURN
54
Delete
Popup Menu
Show the Pop-up menu.
ENTER
Select the desired Pop-up menu.
Return to TV viewing.
■
Use the C H
button to navigate in the
music page.
■ If no music is marked, all the music in the folder will be played in sequence. When one or
more music files are marked, the marked music
files will be played in sequence. If you want to
listen to only one song repeatedly, just mark
that one file and play.
■
The play information box (as shown below) will automatically
move across the screen when there is no user input to prevent a fixed image remaining on the screen for a extended
period of time.
G
G
G
G
When music is playing,
is displayed in front of the music play time.
A damaged or corrupted music file that does not play displays 00:00 as the play time.
Files downloaded from a paid service with copyright protection are not supported and will not play.
Press E N T E R, A or R E T U R N button to stop the screen saver.
USB
! NOTE
EXTRA CONTENTS
Extra Contents will be activated when Data Channel service is available.
i
Choose the media you want.
1 MENU
Photo List
Select U S B.
Music List
Fl
Extra Contents
Close
2
ENTER
ENTER
Select E x t r a C o n t e n t s.
! NOTE
G
G
Pro:Centric contents in USB memory stick can be played.
For more information. contact to Customer Support.(www.lgcommercial.com)
55
PICTURE CONTROL
PIP (PICTURE-IN-PICTURE)
PIP enables the end user to view two sources on the screen at the same time. The end user can switch
between the Main and Sub picture sizes.
■
Note: Actual size of Main screen and PIP inset may be different than
shown above.
PICTURE CONTROL
PIP
Turns PIP mode on and off.
PQRS
8
TUV
0&@
PIP CHSelects next lower channel
for PIP window.
PIP CH+
Selects next higher channel
for PIP window.
56
7
PIP Operation
1. Connect auxiliary source(s) to TV
connections panel.
2. Enter Installer menu to be sure
source(s) is enabled.
3. Use the interactive remote provided
in the room to operate PIP.
4. Press PIP on remote.
Use the PIP function keys to
operate the available PIP features.
5. To exit PIP mode, simply press PIP.
9
WXYZ
FLASHBK
PIP
RATIO
TIMER
SAP
PIP CH-
PIP CH+
PIP SWAP
PIP INPUT
PIP INPUT
Selects viewing source for PIP
window.
PIP SWAP
Switches Main screen and
PIP window sources.
Available Sub Picture Sources
TV
AV1, AV2, HDMI1, HDMI2
AV1or AV2
TV, AV1or AV2, HDMI1, HDMI2
HDMI1or HDMI2
TV, AV1, AV2, HDMI1or HDMI2
Component, RGB-PC
TV, AV1, AV2, HDMI1, HDMI2
PICTURE CONTROL
Main Picture Source
57
PICTURE CONTROL
PICTURE SIZE (ASPECT RATIO) CONTROL
This feature lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV.
■ RGB-PC input source can only use 4:3 or 16:9 aspect ratio.
16:9
1
PICTURE CONTROL
RATIO
2 RETURN
Press the R A T I O button repeatedly to select the picture options
: S e t B y P r o g r a m , 4 : 3 , 1 6 : 9 , Z o o m , J u s t S c a n.
Return to TV viewing.
■
58
You can also adjust A s p e c t R a t i o in
the PICTURE menu.
Set by program
16:9
Selects the proper picture proportion to match
the source’s image.
Adjust the picture horizontally, in a linear proportion to fill the entire screen.
(4:3
4:3)
Set By Program
(16:9
16:9)
PICTURE CONTROL
Set By Program
4:3
Choose 4:3 when you want to view a picture
with an original 4:3 aspect ratio.
59
PICTURE CONTROL
Zoom
Choose Zoom when you want to view the picture
without any alteration. However, the top and
bottom portions of the picture will be cropped.
Just Scan
PICTURE CONTROL
60
Normally the edges of video signals are cropped
1-2%. Just Scan turns off this cropping and
shows the complete video.
Notes: If there is noise on the edges of the original
signal, it will be visible when Just Scan is activated.
J u s t S c a n operates only with
DTV/CADTV/HDMI-DTV/DVI-DTV
(720p/1080i), Component(720p/1080i) input
sources.
PRESET PICTURE SETTINGS (PICTURE MODE)
There are factory presets for picture settings available in the user menus. You can use a preset, change each
setting manually, , or use the Intelligent Sensor.
Move
Enter
Aspect Ratio : 16:9
Picture Mode : Standard
Picture Mode : Standard
• Backlight
70
Vivid
• Contrast
90
• Contrast
90
Standard
• Brightness
50
• Brightness
50
Natural
• Sharpness
70
• Sharpness
70
Cinema
• Color
60
• Color
60
Sport
0
R
Game
0
R
G
• Tint
■
Select P I C T U R E.
■
Select P i c t u r e M o d e.
■
3
Select I n t e l l i g e n t S e n s o r, V i v i d,
S t a n d a r d, N a t u r a l, C i n e m a, S p o r t or
G a m e.
G
E
■
4 RETURN
Return to the previous menu.
■
MENU
Return to TV viewing.
■
■
■
■
■
When selecting I n t e l l i g e n t S e n s o r is
changed to A u t o automatically.
When selecting I n t e l l i g e n t S e n s o r, it
is changed contrast, brightness, sharpness, color and tint automatically.
V i v i d, S t a n d a r d, N a t u r a l, C i n e m a,
S p o r t, and G a m e Settings are preset
for the optimum picture quality at the
factory.
I n t e l l i g e n t S e n s o r: The most suitable
picture is automatically adjusted according to the surrounding conditions.
V i v i d: This is the mode to maximize the
effect of the video in the retail store.
Strengthen the contrast, brightness,
color and sharpness for vivid picture.
S t a n d a r d: This is the mode to realize
optimum viewing condition for the general user.
N a t u r a l: This is the mode to display the
most natural screen status.
C i n e m a: This mode optimizes video for
watching movies.
S p o r t : This is the video mode to
emphasize dynamic video and primary
color (e.g, white, uniform, grass, sky blue
etc.) by realizing the optimal screen for
sports.
G a m e: This is the mode to realize fast
response speed in a fast gaming screen.
PICTURE CONTROL
1 MENU
ENTER
Intelligent Sensor
70
E
ENTER
Enter
• Backlight
• Tint
2
Move
Aspect Ratio : 16:9
61
PICTURE CONTROL
MANUAL PICTURE ADJUSTMENT - USER MODE
Adjust the picture appearance to suit your preference and viewing situations.
P i c t u r e M o d e - I n t e l l i g e n t S e n s o r”.
This feature is disable in “P
Move
Enter
Aspect Ratio : 16:9
Picture Mode : Standard
90
• Brightness
50
• Sharpness
70
• Color
60
• Tint
0
• Back Light
70
E
R
E
E
70
• Contrast
E
• Backlight
Enter
G
E
PICTURE CONTROL
1 MENU
Select P I C T U R E.
2
3
ENTER
Select P i c t u r e M o d e.
ENTER
Select V i v i d, S t a n d a r d, N a t u r a l,
C i n e m a, S p o r t or G a m e.
4
ENTER
5
ENTER
Select B a c k l i g h t , C o n t r a s t ,
Brightness, Sharpness, Color,
or T i n t .
■
■
■
Make appropriate adjustments.
6 RETURN
■
Return to the previous menu.
MENU
Return to TV viewing.
■
■
62
B a c k l i g h t: This function adjusts the
brightness of LCD panel, to control the
brightness of the screen. Adjusting the
backlight is recommended when setting
the brightness of the set. When decreasing the backlight, the brightness of the
black becomes darker without any loss in
video signal and the power consumption
is reduced.
C o n t r a s t: Increase or decrease the gradient of the video signal. You may use
Contrast when the bright part of picture
is saturated.
B r i g h t n e s s: Adjusts the base level of
the signal in the picture. You may use
Brightness when the dark part of the picture is saturated.
S h a r p n e s s: Adjusts the level of crispness in the edges between the light and
dark areas of the picture. The lower the
level, the softer the image.
C o l o r: Adjusts intensity of all colors.
T i n t: Adjusts the balance between red
and green levels.
PICTURE IMPROVEMENT TECHNOLOGY
You can calibrate the screen for each Picture Mode or set the video value according to the special video screen.
You can set the video seeing differently for each input.
To reset to the factory default after making adjustments to each input source, execute the P i c t u r e R e s e t
function for each Picture Mode.
Move
Enter
Picture Mode : Standard
Move
• Backlight
70
• Backlight
70
• Contrast
90
• Contrast
90
• Brightness
50
• Brightness
50
• Sharpness
70
• Sharpness
70
• Color
60
• Color
60
• Tint
Enter
Picture Mode : Standard
0
R
G
• Advanced Control
0
Medium
Dynamic Contrast
Dynamic
Color
R
F
Noise Reduction
Medium
Gamma
Medium
• Advanced Control Black Level
Off
Real Cinema
Off
E
Close
2
Select P I C T U R E.
ENTER
Select A d v a n c e d C o n t r o l.
ENTER
Select your desired options.
G
Low
E
Eye Care
1 MENU
Medium
Low
G
PICTURE CONTROL
E
• Tint
Color Temperature
3
4
Make appropriate adjustments.
5 RETURN
Return to the previous menu.
MENU
Return to TV viewing.
63
PICTURE CONTROL
Color Temperature
Dynamic Contrast
■
Set to warm to enhance hotter colors such as red, or set to cool to enhance cooler
colors such as blue.
■
Adjusts the contrast to keep it at the best level according to the brightness of the
screen. The picture is improved by making bright parts brighter and dark parts darker.
■
Adjusts screen colors so that they look livelier, richer and clearer. This feature
enhances hue, saturation and luminance so that red, blue, green and white look
more vivid.
■
Reduces screen noise without compromising video quality.
Dynamic Color
Noise Reduction
Gamma
PICTURE CONTROL
Black Level
Low : Make dark and middle gray level area of the picture brighter.
Medium: Express original picture levels.
High: Make dark and middle gray level area of the picture darker.
■ You can adjust brightness of dark area and middle gray level area of the picture.
Low: The reflection of the screen gets darker.
High: The reflection of the screen gets brighter.
■ Set black level of the screen to proper level.
■ This function enables to select 'Low' or 'High' in the following mode: AV (NTSC-M),
HDMI or Component.
■
Adjust the brightness of the screen to prevent the screen from being too bright.
Dims extremely bright pictures.
P i c t u r e M o d e - I n t e l l i g e n t S e n s o r, V i v i d , C i n e m a”.
This feature is disabled in “P
■
Makes video clips recorded in film look more natural by eliminating judder effect.
■
Eye Care
Real Cinema
Color Gamut
64
Standard: Displays standard set of colors.
Wide: Increase number of colors used.
■ Maximize the utilization of color to increase color quality.
PICTURE RESET
Settings of the selected picture modes return to the default factory settings.
Move
Enter
Move
E
?
70
• Contrast
90
All picture settings will be resetted.
• Brightness
50
Continue?
• Sharpness
70
• Color
Yes• Tint
60
No
0
R
G
i
3
ENTER
Select P i c t u r e R e s e t.
ENTER
Select Y e s.
90
• Brightness
50
• Sharpness
70
G
• Picture Reset
Screen (RGB-PC)
PICTURE CONTROL
2
Select P I C T U R E.
70
• Contrast
• Advanced Control
• Picture Reset
1 MENU
• Backlight
• Color
60
Resetting video configuration...
• Tint
0 R
• Advanced Control
Screen (RGB-PC)
Enter
E
• Backlight
4
ENTER
5 MENU
Initialize the adjusted value.
Return to TV viewing.
65
PICTURE CONTROL
DEMO MODE
Displays a slide show to explain the various feature of this TV.
OPTION
Move
Enter
PICTURE CONTROL
2
ENTER
3
ENTER
4 MENU
66
Move
Menu Language
: English
Menu Language
: English
Audio Language
: English
Audio Language
: English
Caption
: Off
Caption
: Off
Set ID
:1
Set ID
:1
Demo Mode
: Off
Demo Mode
: Off
Data Broadcasting
1 MENU
OPTION
Select O P T I O N.
Select D e m o M o d e.
Select O n to show the various
feature of the TV.
Return to TV viewing.
After a while, D e m o M o d e starts.
If you want to stop the demo, press any button
(Except VOL +, - and MUTE button).
Data Broadcasting
Enter
Off
On
SOUND & LANGUAGE CONTROL
AUTO VOLUME LEVELER (AUTO VOLUME)
Auto Volume makes sure that the volume level remains consistent whether you are watching a commercial or a
regular TV program.
Because each broadcasting station has its own signal conditions, volume adjustment may be needed every
time the channel is changed. This feature allows users to enjoy stable volume levels by making automatic
adjustments for each program.
AUDIO
Move
Auto Volume
: On
Clear Voice II
: On
Clear Voice II
: On
Balance
Sound Mode
3
-
+
0
L
R
: Standard
ENTER
4 RETURN
Balance
3
-
+
0
L
R
: Standard
• SRS TruSurround XT: Off
• Treble
50
• Treble
50
• Bass
50
• Bass
50
Select A U D I O.
Select A u t o V o l u m e.
Select O n or O f f.
Return to the previous menu.
E
SOUND & LANGUAGE CONTROL
3
ENTER
On
• Level
Sound Mode
Enter
Off
• SRS TruSurround XT: Off
E
2
Move
: Off
• Level
1 MENU
AUDIO
Enter
Auto Volume
MENU
Return to TV viewing.
67
SOUND &LANGUAGE CONTROL
PRESET SOUND SETTINGS (SOUND MODE)
Sound Mode lets you enjoy the best sound without any special adjustment as the TV sets the appropriate
sound options based on the program content.
AUDIO
Move
Auto Volume
: Off
Clear Voice II
: Off
• Level
Balance
Sound Mode
AUDIO
Enter
3
-
+
0
L
R
: Standard
Move
Auto Volume
: Off
Clear Voice II
: Off
• Level
Balance
Sound Mode
Enter
3
-
+
0
L
R
: Standard
• SRS TruSurround XT: Off
Standard
Off
• SRS TruSurround XT:
Music
• Treble
50
• Treble
50
• Bass
50
• Bass
50
E
E
Cinema
Sport
Game
SOUND & LANGUAGE CONTROL
1 MENU
Select A U D I O.
■
2
3
ENTER
Select S o u n d M o d e.
■
■
ENTER
4 RETURN
Select S t a n d a r d, M u s i c,
C i n e m a, S p o r t, or G a m e.
■
■
Return to the previous menu.
■
MENU
Return to TV viewing.
68
S t a n d a r d, M u s i c, C i n e m a, S p o r t,
and G a m e are preset for optimum
sound quality at the factory.
S t a n d a r d : Offers standard-quality
sound.
M u s i c: Optimizes sound for listening to
music.
C i n e m a: Optimizes sound for watching
movies.
S p o r t: Optimizes sound for watching
sports events.
G a m e: Optimizes sound for playing
games.
SOUND SETTING ADJUSTMENT - USER MODE
Adjust the sound to suit your taste and room situations.
Move
Enter
AUDIO
Move
Auto Volume
: Off
Auto Volume
: Off
Clear Voice II
: Off
Clear Voice II
: Off
• Level
Balance
Sound Mode
3
-
+
0
L
R
: Standard
• Level
Balance
Sound Mode
3
-
+
0
L
R
: Standard
• SRS TruSurround XT: Off
• SRS TruSurround XT: Off
• Treble
50
• Treble
• Bass
50
• Bass
E
50
• SRS TruSurround XT
50
• Treble
50
• Bass
50
E
E
Enter
Off
E
AUDIO
Close
2
3
Select A U D I O.
ENTER
Select S o u n d M o d e.
ENTER
Select S t a n d a r d, M u s i c,
C i n e m a, S p o r t, or G a m e.
ENTER
Select T r e b l e or B a s s.
ENTER
Make appropriate adjustments.
4
5
6 RETURN
SOUND & LANGUAGE CONTROL
1 MENU
Return to the previous menu.
MENU
Return to TV viewing.
69
SOUND &LANGUAGE CONTROL
SRS TRUSURROUND XT / INFINITE SOUND
Takes advantage of any multi-channel format without needing to add extra speakers or equipment. Dialog
clarity, bass enrichment, and the addition of stereo audio enhancement produces an immersive sound experience from standard stereo material.
32/37/42LG710H
AUDIO
Move
Enter
AUDIO
Move
Auto Volume
: Off
Auto Volume
: Off
Clear Voice II
: Off
Clear Voice II
: Off
• Level
Balance
Sound Mode
3
-
+
0
L
R
: Standard
• Level
Balance
Sound Mode
• SRS TruSurround XT: Off
Enter
3
-
+
0
L
R
: Standard
• Treble
50
• SRS TruSurround XT: Off
• SRS TruSurround XT
• Treble
50
• Bass
50
• Bass
E
50• Treble
50
• Bass
50
Off
E
Close
SOUND & LANGUAGE CONTROL
32/37/42/47/55LD650H, 32/37/42LD655H
AUDIO
Move
Auto Volume
: Off
Clear Voice II
: Off
Move
Clear Voice II
Balance
3
-
+
0
L
R
: Standard
: Off
Balance
Off
Enter
: Off
• Level
Sound Mode
• Infinite Sound:
3
-
+
0
L
R
: Standard
• Infinite Sound:
• Treble
50
• Treble
Off
• Infinite Sound
50
• Bass
50
• Bass
50• Treble
50
• Bass
50
E
Off
E
Close
1 MENU
2
ENTER
Select A U D I O.
Select S R S T r u S u r r o u n d X T
or I n f i n i t e S o u n d.
3
ENTER
4 RETURN
Select O n or O f f.
Return to the previous menu.
MENU
Return to TV viewing.
70
AUDIO
Auto Volume
• Level
Sound Mode
Enter
■
■
■
■
If sound quality or volume is not at the
level you want, it is recommended to use a
separate home theater system or amp to
cope with different user environments.
C l e a r V o i c e I I - O n”, S R S
If you select “C
T r u S u r r o u n d X T feature will not work.
S R S T r u S u r r o u n d X T: TruSurround XT
is a patented SRS technology that solves
the problem of playing 5.1 multichannel
content over two speakers.
I n f i n i t e S o u n d: Infinite Sound is a
patented LG proprietary sound processing technology that strives immersive 5.1
surround sound with just two front speakers. (For 32/37/42/47/55LD650H,
32/37/42LD655H)
CLEAR VOICE II
By differentiating the human sound range from others, it improves the sound quality of voices.
AUDIO
Move
Auto Volume
: Off
Clear Voice II
: On
• Level
Balance
Sound Mode
AUDIO
Enter
3
-
+
0
L
R
: Standard
On
+
0
L
R
: Standard
50
• Treble
50
• Bass
50
• Bass
50
E
Select A U D I O.
ENTER
Select O n or O f f.
Adjustment for Clear Voice ll Level
With selecting O n
ENTER
Select L e v e l.
ENTER
Make appropriate adjustments.
MENU
Balance
3
• Treble
3
6RETURN
Off
• Level
• SRS TruSurround XT: Off
Select C l e a r V o i c e I I.
5
: On
Sound Mode
ENTER
4
Clear Voice II
Enter
SOUND & LANGUAGE CONTROL
2
: Off
• SRS TruSurround XT: Off
E
1 MENU
Move
Auto Volume
Return to the previous menu.
Return to TV viewing.
71
SOUND &LANGUAGE CONTROL
BALANCE
Adjust the left/right sound of speaker to suit your taste and room situations.
Move
Enter
: Off
Auto Volume
: Off
Clear Voice II
: Off
Clear Voice II
: Off
• Level
3
-
+
0
L
R
: Standard
Sound Mode
+
• Treble
50
• Bass
50
• Bass
50
SOUND & LANGUAGE CONTROL
Select B a l a n c e.
ENTER
Make appropriate adjustments.
Return to the previous menu.
Return to TV viewing.
0
: Standard
• SRS TruSurround XT: Off
Select A U D I O.
R
Balance
50
MENU
72
L
• Treble
ENTER
4 RETURN
3
0
• SRS TruSurround XT: Off
E
3
• Level
Balance
Enter
E
Sound Mode
2
Move
Auto Volume
Balance
1 MENU
AUDIO
E
Close
L
R
E
AUDIO
TV SPEAKERS ON/OFF SETUP
If you wish to use an external Hi-Fi system or a SRS System, turn off the TV’s internal speakers.
In A V, C o m p o n e n t, R G B and H D M I with HDMI to DVI cable, the TV speaker can be operational even when
there is no video signal.
Turn the TV speakers off if using external audio equipment.
AUDIO
Move
Enter
AUDIO
Move
E
Sound Mode
E
• Level
Balance
3
-
+
0
L
R
: Standard
• Level
Balance
Sound Mode
3
-
+
0
L
R
: Standard
• SRS TruSurround XT: Off
• SRS TruSurround XT: Off
• Treble
50
• Treble
50
• Bass
50
• Bass
50
• Reset
TV Speaker
Enter
: On
• Reset
TV Speaker
: On
Off
On
2
Select A U D I O.
ENTER
Select T V S p e a k e r.
ENTER
Select O n or O f f.
3
4 RETURN
MENU
Return to the previous menu.
SOUND & LANGUAGE CONTROL
1 MENU
Return to TV viewing.
73
SOUND &LANGUAGE CONTROL
AUDIO RESET
Settings of the selected Sound Mode return to the default factory settings.
AUDIO
Move
Enter
AUDIO
Move
E
E
• Level
Balance
Sound Mode
3
-
+
0
L
R
• Level
Balance
Sound Mode
: Standard
• Treble
50
• Bass
50
• Reset
E
SOUND & LANGUAGE CONTROL
74
2
3
ENTER
ENTER
Select A U D I O.
Select R e s e t.
Initialize the adjusted value.
4 MENU
Return to TV viewing.
3
-
+
0
L
R
: Standard
• SRS TruSurround XT: Off
• SRS TruSurround XT: Off
1 MENU
Enter
i
• Treble
50
Resetting audio configuration...
• Bass
50
• Reset
E
STEREO/SAP BROADCAST SETUP
For Analog only: This TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accompanies the stereo program if the station transmits an additional sound signal. Mono sound is automatically used
if the broadcast is only in Mono.
If other languages are available on the digital signal,select them with the S A P button.
MONO
SAP
Each time you press the S A P button,
M o n o, S t e r e o, or S A P appear in turn.
2 RETURN
Return to TV viewing.
SAP
SOUND & LANGUAGE CONTROL
1
STEREO
75
SOUND &LANGUAGE CONTROL
AUDIO LANGUAGE
Other languages may be available if a digital signal is provided by the broadcasting station.
This feature operates only in DTV mode.
OPTION
Move
Enter
SOUND & LANGUAGE CONTROL
2
ENTER
4RETURN
MENU
76
Enter
Menu Language
: English
Audio Language
: English
Audio Language
: EnglishEnglish
Caption
: Off
Caption
: Off
Spanish
Set ID
:1
Set ID
:1
French
Demo Mode
: Off
Demo Mode
: Off
Select O P T I O N.
Select A u d i o L a n g u a g e.
3
ENTER
Move
: English
Data Broadcasting
1 MENU
OPTION
Menu Language
Select your desired language.
Return to the previous menu.
Return to TV viewing.
Data Broadcasting
ON-SCREEN MENUS LANGUAGE SELECTION
The menus can be shown on the screen in the selected language.
OPTION
Move
Enter
ENTER
3
ENTER
4RETURN
MENU
Enter
: English
Menu Language
Audio Language
: English
Audio Language
Caption
: Off
Caption
Set ID
:1
Set ID
: English
English
: English
Español
: Off
Français
:1
Demo Mode
: Off
Demo Mode
: Off
Select O P T I O N.
Select M e n u L a n g u a g e.
Select your desired language.
From this point on, the on-screen menus will
be shown in the selected language.
Return to the previous menu.
Data Broadcasting
SOUND & LANGUAGE CONTROL
2
Move
Menu Language
Data Broadcasting
1 MENU
OPTION
Return to TV viewing.
77
SOUND &LANGUAGE CONTROL
CAPTION MODE
Analog Broadcasting System Captions
Captions are provided to help the hearing impaired watch TV. Select a caption mode for displaying captioning
information if provided on a program. Analog caption displays information at any position on the screen and is
usually the program's dialog. Caption/Text, if provided by the broadcaster, would be available for both digital
and analog channels on the Antenna/Cable. This TV is programmed to memorize the caption/text mode which
was last set when you turned the power off. This function is only available when C a p t i o n Mode is set O n.
OPTION
Move
Enter
OPTION
Move
Menu Language
: English
Menu Language
: English
Audio Language
: English
Audio Language
: English
Caption
: Off
Caption
: CC1
Set ID
:1
Set ID
:1
Demo Mode
: Off
Demo Mode
: Off
Data Broadcasting
Data Broadcasting
Enter
F
Mode
On
G
CC1
Digital Option
Close
SOUND & LANGUAGE CONTROL
1 MENU
2
Select O P T I O N.
■
ENTER
Select C a p t i o n.
■
ENTER
Select O n.
3
■
4
4 or T e x t 1-4
4.
Select C C 1-4
5RETURN
MENU
78
Return to the previous menu.
Return to TV viewing.
When selecting O f f, Sub-menus for
Analog, DTV, and Digital Option become
disabled.
CAPTION
The term for the words that scroll
across the bottom of the TV screen;
usually the audio portion of the program provided for the hearing impaired.
TEXT
The term for the words that appear in a
large black frame and almost cover the
entire screen; usually messages provided by the broadcaster.
Digital Broadcasting System Captions
Choose the language you want the DTV/CADTV Captions to appear in.
Other Languages can be chosen for digital sources only if they are included on the program.
This function in only available when Caption Mode is set On.
OPTION
Move
Enter
OPTION
Move
Menu Language
: English
Menu Language
: English
Audio Language
: English
Audio Language
: English
Caption
: Off
Caption
: CC1
Set ID
:1
Set ID
:1
Demo Mode
: Off
Demo Mode
: Off
Data Broadcasting
Data Broadcasting
Enter
F
Mode
On
G
CC1
Digital Option
Close
2
Select O P T I O N.
ENTER
Select C a p t i o n.
ENTER
Select O n.
3
4
4 , T e x t 1-4
4 , or
Select C C 1-4
S e r v i c e 1 - 6.
5RETURN
MENU
SOUND & LANGUAGE CONTROL
1 MENU
Return to the previous menu.
Return to TV viewing.
79
SOUND &LANGUAGE CONTROL
Caption Option
Customize the DTV captions that appear on your screen.
This function in only available when Caption Mode is set On.
OPTION
Move
Menu Language
: English
Audio Language
: English
Caption
: Off
Set ID
:1
Demo Mode
: Off
Enter
Data Broadcasting
F
OPTION
Move
Enter
Menu Language
: English
Audio Language
: English
Caption
: Off
Set ID
Demo Mode
:1
Mode
: Off
Data Broadcasting
On
CC1
Digital Option
Close
Custom
G
Size
A Standard
Font
Font 1
Text Color
White
Text Opacity
Solid
Bg Color
Black
Bg Opacity
Solid
Edge Type
None
Edge Color
Black
Close
SOUND & LANGUAGE CONTROL
1 MENU
2
ENTER
Select O P T I O N.
Select C a p t i o n.
■
3
■
ENTER
Select O n.
■
4
5
Select D i g i t a l O p t i o n.
ENTER
Select C u s t o m.
■
■
■
6
7 RETURN
Customize the S i z e, F o n t, etc., to your
preference. A preview icon is provided at
the bottom of the screen, use it to see the
caption language.
Return to the previous menu.
MENU
Return to TV viewing.
80
■
■
S i z e: Set the word size.
F o n t: Select a typeface for the text.
T e x t C o l o r: Choose a color for the
text.
T e x t O p a c i t y: Specify the opacity
for the text color.
B g ( B a c k g r o u n d ) C o l o r: Select a
background color.
B g ( B a c k g r o u n d ) O p a c i t y: Select
the opacity for the background color.
E d g e T y p e: Select an edge type.
E d g e C o l o r: Select a color for the
edges.
TIME SETTING
CLOCK SETTING
Auto Clock Setup
The time is set automatically from a digital channel signal.
The digital channel signal includes information for the current time provided by the broadcasting station.
Set the clock manually if the current time is set incorrectly by the auto clock function.
TIME
Move
Enter
Clock
TIME
Move
Clock
F
Enter
Auto
G
Off Time
: Off
Off Time
On Time
: Off
On Time
: Off
:Month
Off
Sleep Timer
: Off
Sleep Timer
:Date
Off
21
Year
2009
Hour
10 AM
02
Minute
10
Eastern
Time Zone
Daylight
Saving
Auto
Close
1 MENU
ENTER
Select C l o c k.
ENTER
Select A u t o.
3
4
TIME SETTING
2
Select T I M E.
Select your viewing area time zone.
• U.S.A: E a s t e r n, C e n t r a l, M o u n t a i n,
P a c i f i c, A l a s k a, or H a w a i i.
• Canada: E a s t e r n, C e n t r a l, M o u n t a i n,
P a c i f i c, N e w F . l a n d, or A t l a n t i c.
5
Select A u t o, O f f, or O n (depending on
whether or not your viewing area observes
Daylight Saving time).
6RETURN
MENU
Return to the previous menu.
Return to TV viewing.
81
TIME SETTING
Manual Clock Setup
If the current time setting is wrong, reset the clock manually.
TIME
Move
Enter
Clock
Off Time
TIME
Move
: Off
Off Time
On Time
: Off
Sleep Timer
: Off
Enter
F
Clock
Manual
Month
On Time
: Off
Date
21
Sleep Timer
: Off
Year
2009
Hour
10 AM
02
Minute
10
Eastern
Time Zone
Daylight
Saving
Auto
Close
1 MENU
TIME SETTING
2
ENTER
Select C l o c k.
ENTER
Select M a n u a l.
3
4
Select the Year, Month, Date, Hour, or Minutes
option.
5
Set the Year, Month, Date, Hour, or Minutes
option.
6RETURN
MENU
82
Select T I M E.
Return to the previous menu.
Return to TV viewing.
G
: Off
AUTO ON/OFF TIME SETTING
This function operates only if the current time has been set.
The O f f T i m e function overrides the O n T i m e function if they are both set to the same time.
The TV must be in standby mode for the O n T i m e to work.
TIME
Move
Enter
Clock
TIME
Move
Off Time
: Off
Off Time
On Time
: Off
On Time
Sleep Timer
: Off
Sleep Timer
Enter
Feb. 21, 2009 10:10 AM
Clock
: Off
Repeat
: 6:30 AM (Once)
Hour
: Off
Minute
F
Once
G
6 AM
30
Close
1 MENU
ENTER
Select O f f T i m e or O n T i m e.
ENTER
Select R e p e a t.
3
4
TIME SETTING
2
Select T I M E.
Select O f f, O n c e, D a i l y, M o n .~FF r i .,
M o n .~S
S a t ., S a t .~ S u n ., or S u n ..
5
Select and set H o u r or M i n u t e.
6RETURN
MENU
Return to the previous menu.
Return to TV viewing.
83
TIME SETTING
SLEEP TIMER SETTING
The Sleep Timer turns the TV off at the preset time.
Note that this setting is cleared when the TV is turned off.
TIME
Move
Enter
Clock
TIME
Move
Enter
Clock
Off Time
: Off
Off Time
: Off
Off
On Time
: Off
On Time
: Off
10 min.
Sleep Timer
: Off
Sleep Timer
: Off
20 min.
30 min.
60 min.
90 min.
120 min.
180 min.
240 min.
1 MENU
2
ENTER
TIME SETTING
3
ENTER
4RETURN
MENU
84
Select T I M E.
Select S l e e p T i m e r.
Make appropriate adjustments.
Return to the previous menu.
Return to TV viewing.
■
■
To cancel the S l e e p T i m e r, select O f f.
Press the S L E E P button repeatedly to
select the number of minutes.
PARENTAL CONTROL / RATINGS
Parental Control can be used to block specific channels, ratings and other viewing sources.
The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broadcasting station. The default setting is to allow all programs to be viewed. Viewing can be blocked by choosing the
type of the program and the categories. It is also possible to block all program viewing for a time period. To use
this function, the following must be done :
1. Set ratings and categories to be blocked.
2. Specify a password
3. Enable the lock
V-Chip rating and categories
Rating guidelines are provided by broadcasting stations. Most television programs and television movies can be
blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or direct-tovideo movies use the Movie Rating System (MPAA) only.
Ratings for Television programs including made-for-TV movies :
TV-G (General audience)
■ TV-PG (Parental guidance suggested)
■ TV-14 (Parents strongly cautioned)
TV-MA (Mature audience only)
(All children)
■ TV-Y
■ TV-Y7 (Children 7 years older)
■
■
Setting up Your Password
Set up blocking schemes to block specific channels, ratings, and external viewing sources.
A password is required to gain access to this menu.
LOCK
Lock System
Move
Enter
: On
Enter Password
Set Password
*
Block Channel
*
*
*
Movie Rating
Close
TV Rating-Children
TV Rating-General
PARENTAL CONTROL / RATING
SET PASSWORD & LOCK SYSTEM
Downloadable Rating
Input Block
1 MENU
2
ENTER
Select L O C K.
■
■
1
.:/,
4
7
GHI
PQRS
2
ABC
3
DEF
5
JKL
6
MNO
8
TUV
9
0
&@
Input the password.
When you select O n, the Lock System
is enable.
The TV is set up with the initial password “0-0-0-0”.
WXYZ
85
PARENTAL CONTROL /RATINGS
Lock System
Enables or disables the blocking scheme you set up previously.
LOCK
Move
Lock System
1 MENU
2
: On
Set Password
Block Channel
Block Channel
Movie Rating
Movie Rating
TV Rating-Children
TV Rating-Children
TV Rating-General
TV Rating-General
Downloadable Rating
Downloadable Rating
Input Block
Input Block
ENTER
Select L O C K.
4RETURN
MENU
Select L o c k S y s t e m.
Select O n or O f f.
Enter
Off
On
Return to the previous menu.
Return to TV viewing.
■
ENTER
Move
Lock System
Set Password
3
PARENTAL CONTROL / RATING
86
LOCK
Enter
: Off
When you select O n, the Lock System
is enable.
Set Password
Set up blocking schemes to block specific channels, ratings, and external viewing sources.
A password is required to gain access to this menu.
LOCK
Move
Lock System
1 MENU
2
1
.:/,
4
7
GHI
PQRS
2
ABC
3
DEF
5
JKL
6
MNO
8
TUV
9
0
&@
Enter
: Off
LOCK
Lock System
Move
: Off
Set Password
Set Password
Block Channel
Block Channel
Movie Rating
Movie Rating
TV Rating-Children
TV Rating-Children
TV Rating-General
TV Rating-General
Downloadable Rating
Downloadable Rating
Input Block
Input Block
ENTER
Enter
New
*
*
*
*
Confirm
*
*
*
*
Close
Select L O C K.
Input the password.
WXYZ
3
Select S e t P a s s w o r d.
1
2
ABC
3
DEF
GHI
5
JKL
6
MNO
PQRS
8
TUV
9
0
&@
.:/,
ENTER
4
7
5RETURN
MENU
WXYZ
Choose any 4 digits for your new password.
As soon as the 4 digits are entered, re-enter
the same 4 digits on the C o n f i r m.
Return to the previous menu.
Return to TV viewing.
PARENTAL CONTROL / RATING
4
87
PARENTAL CONTROL /RATINGS
CHANNEL BLOCKING
Blocks any channels that you do not want to watch or that you do not want your children to watch.
LOCK
Move
Lock System
Enter
: Off
Set Password
Block Channel
Movie Rating
TV Rating-Children
TV Rating-General
Downloadable Rating
Input Block
Ch. Change
Navigation
Block/Unblock
1 MENU
2
1
ENTER
2
ABC
3
DEF
GHI
5
JKL
6
MNO
PQRS
8
TUV
9
0
&@
.:/,
4
7
Input the password.
WXYZ
3
PARENTAL CONTROL / RATING
88
Select L O C K.
Select B l o c k C h a n n e l.
4
ENTER
Select a channel to block or unblock.
5
Block or unblock a channel.
6RETURN
MENU
Return to the previous menu.
Return to TV viewing.
CH
Page Change
Previous
MOVIE & TV RATING
Movie Rating (MPAA) - For USA
Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You can
set the ratings limit by blocking out all the movies with the ratings above a specified level. Keep in mind that
the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas.
LOCK
Move
Enter
LOCK
Move
Enter
Blocking off : Permits all programs
Lock System
1 MENU
2
1
.:/,
4
PQRS
2
ABC
3
DEF
5
JKL
6
MNO
8
TUV
9
0
&@
Set Password
Block Channel
Block Channel
Movie Rating
Movie Rating
TV Rating-Children
TV Rating-Children
TV Rating-General
TV Rating-General
Downloadable Rating
Downloadable Rating
Input Block
Input Block
ENTER
Select L O C K.
Input the password.
Select M o v i e R a t i n g.
4
ENTER
5RETURN
MENU
: Off
Set Password
WXYZ
3
Lock System
Select G , P G, P G - 1 3, R , N C - 1 7,
X , or B l o c k i n g O f f.
Return to the previous menu.
G
PG
PG-13
R
NC-17
X
Blocking Off
G (General audience)
■ PG (Parental guidance suggested)
■ PG-13 (Parents strongly cautioned)
■ R (Restricted)
■ NC-17 (No one 17 and under admitted)
■ X (Adult only)
■ Blocking Off (Permits all programs)
G If you set PG-13: G and PG movies will
be available, PG-13, R, NC-17 and X will
be blocked.
■
PARENTAL CONTROL / RATING
7
GHI
: Off
Return to TV viewing.
89
PARENTAL CONTROL /RATINGS
TV Rating Children - For USA
Prevents children from watching certain children's TV programs, according to the ratings limit set. The children
rating does not apply to other TV programs. Unless you block certain TV programs intended for mature audiences in the TV Rating - sub menu, your children can view those programs.
LOCK
Move
Lock System
1 MENU
2
1
.:/,
4
7
GHI
PQRS
PARENTAL CONTROL / RATING
ABC
3
DEF
5
JKL
6
MNO
8
TUV
9
0
&@
Lock System
Move
Enter
: Off
Set Password
Block Channel
Block Channel
Movie Rating
Movie Rating
TV Rating-Children
TV Rating-Children
TV Rating-General
TV Rating-General
Downloadable Rating
Downloadable Rating
Input Block
Input Block
Age
Fantasy Violence
Close
Select L O C K.
Input the password.
WXYZ
3
Select T V R a t i n g - C h i l d r e n.
4
■
ENTER
Select A g e or F a n t a s y V i o l e n c e.
ENTER
Select block options.
5
6 RETURN
Return to the previous menu.
MENU
Return to TV viewing.
90
: Off
LOCK
Set Password
ENTER
2
Enter
■
Age (applies to TV-Y, TV-Y7)
Fantasy Violence (applies to TV-Y7)
TV Rating General - For USA
Based on the ratings, blocks certain TV programs that you and your family do not want to view.
LOCK
Move
Lock System
Enter
: Off
LOCK
Move
Lock System
Enter
: Off
Set Password
Set Password
Block Channel
Block Channel
Age
Movie Rating
Movie Rating
Dialogue
TV Rating-Children
TV Rating-Children
Language
TV Rating-General
TV Rating-General
Sex
Downloadable Rating
Downloadable Rating
Violence
Input Block
Input Block
Close
1 MENU
2
1
.:/,
4
7
GHI
PQRS
ENTER
2
ABC
3
DEF
5
JKL
6
MNO
8
TUV
9
0
&@
Select L O C K.
Input the password.
WXYZ
Select T V R a t i n g - G e n e r a l.
4
■
ENTER
Select A g e, D i a l o g u e, L a n g u a g e,
S e x or V i o l e n c e.
5
■
■
Select block options.
■
6 RETURN
Return to the previous menu.
■
Age (applies to TV-G,TV-PG,TV-14,TVMA).
Dialogue-sexual dialogue (applies to
TV-PG,TV-14).
Language-adult language (applies to
TV-PG, TV-14, TV-MA).
Sex-sexual situations (applies to TV-PG,
TV-14, TV-MA).
Violence (applies to TV-PG, TV-14, TVMA).
PARENTAL CONTROL / RATING
3
MENU
Return to TV viewing.
91
PARENTAL CONTROL /RATINGS
TV Rating English - For CANADA
Selecting Canadian English rating system.
LOCK
Move
Lock System
Enter
: Off
LOCK
Lock System
Move
: Off
Enter
Blocking off : Permits all programs
E
Set Password
Set Password
C
Block Channel
Block Channel
C8+
TV Rating-English
TV Rating-English
G
TV Rating-French
TV Rating-French
PG
Downloadable Rating
Downloadable Rating
14+
Input Block
Input Block
18+
Blocking Off
1 MENU
2
1
2
3
4
5
6
8
9
7
ENTER
Select L O C K.
■
Input the password.
0
3
PARENTAL CONTROL / RATING
92
■
Select T V R a t i n g - E n g l i s h.
■
■
4
ENTER
5RETURN
Select E , C , C 8 +, G , P G,
1 4 +, 1 8 +, or B l o c k i n g O f f.
■
■
■
Return to the previous menu.
■
■
MENU
Return to TV viewing.
If T V R a t i n g - E n g l i s h or T V R a t i n g F r e n c h is locked, enter the password
to unlocked it temporarily.
E (Exempt)
C (Children)
C8+ (Children eight years and older)
G (General programming, suitable for
all audiences)
PG (Parental Guidance)
14+ (Viewers 14 years and older)
18+ (Adult programming)
Blocking Off (Permits all programs)
TV Rating French - For CANADA
Selecting Canadian French rating system.
LOCK
Move
Lock System
Enter
: Off
LOCK
Move
Lock System
: Off
Enter
Blocking off : Permits all programs
E
Set Password
Set Password
G
Block Channel
Block Channel
8ans+
TV Rating-English
TV Rating-English
13ans+
TV Rating-French
TV Rating-French
16ans+
Downloadable Rating
Downloadable Rating
18ans+
Input Block
Input Block
Blocking Off
1 MENU
ENTER
Select L O C K.
■
■
2
1
2
3
4
5
6
8
9
7
■
Input the password.
0
3
■
Select T V R a t i n g - F r e n c h.
ENTER
5RETURN
MENU
Select E , G , 8 a n s +, 1 3 a n s +,
1 6 a n s +, 1 8 a n s +, or B l o c k i n g o f f.
Return to the previous menu.
Return to TV viewing.
■
■
PARENTAL CONTROL / RATING
4
■
E (Exempt)
G (General)
8ans+ (General-Not convenient for little children)
13ans+ (Not convenient for children of
13 years and younger)
16ans+ (Not convenient for children of
16 years and younger)
18ans+ (This programs is only for
adults)
Blocking off (Permits all programs)
93
PARENTAL CONTROL /RATINGS
DOWNLOADABLE RATING
This function is available only for digital channels.
This function operates only when TV has received Region5 Rating data.
Move
Lock System
Enter
: Off
LOCK
Move
Lock System
Enter
: Off
E
LOCK
Set Password
Set Password
Block Channel
Block Channel
Movie Rating
Movie Rating
Humor
Humor
Sport
TV Rating-Children
TV Rating-Children
Cruelty
TV Rating-General
TV Rating-General
Language
Downloadable Rating
Downloadable Rating
Sadness
Input Block
Input Block
Genre
Age
E
Close
■
1 MENU
PARENTAL CONTROL / RATING
2
1
ENTER
2
ABC
3
DEF
GHI
5
JKL
6
MNO
PQRS
8
TUV
9
0
&@
.:/,
4
7
Input the password.
WXYZ
3
Select D o w n l o a d a b l e R a t i n g.
4
ENTER
Select desired D o w n l o a d a b l e
R a t i n g option.
ENTER
Select desired option and block it.
5
6RETURN
MENU
94
Select L O C K.
Return to the previous menu.
Return to TV viewing.
Based on rating table, your TV's OSD
(On Screen Display) may differ slightly
from what is shown in this manual.
EXTERNAL INPUT BLOCKING
Enables you to block an input.
LOCK
Move
Lock System
Enter
: Off
LOCK
Lock System
Move
Enter
: Off
AV1
F
Off
Set Password
Set Password
Block Channel
Block Channel
AV2
Off
Movie Rating
Movie Rating
Component
Off
TV Rating-Children
TV Rating-Children
RGB-PC
Off
TV Rating-General
TV Rating-General
HDMI1
Off
Downloadable Rating
Downloadable Rating
HDMI2
Off
Input Block
Input Block
G
Close
1 MENU
2
1
ABC
3
DEF
GHI
5
JKL
6
MNO
PQRS
8
TUV
9
0
&@
.:/,
4
7
2
ENTER
Select L O C K.
Input the password.
WXYZ
Select I n p u t B l o c k.
4
ENTER
5
Select input source.
Select O n or O f f.
6 RETURN
Return to the previous menu.
MENU
PARENTAL CONTROL / RATING
3
Return to TV viewing.
95
COMMERCIAL MODE SETUP
INTERACTIVE TV SETUP
Channel Guide
Hotel Information
Help
Exit
POWER
TV
STB
DVD
VCR
PORTAL
GUIDE
PPV GEM-TV Setup
1. Make all connections as required of PPV system.
2. Set TV to default condition.
3. Configure all relevant installer menu items and TV features.
4. Install PPV card. In most cases the PPV card is preprogrammed with the PPV
provider master TV setup.
GEM-TV Setup Without PPV Card
Refer to Commercial Mode Setup on page 98.
1. See installer menu pages and make settings as required for Gem operation.
2. Specify a Gem Start Channel for item 119 that will tell the TV which channel
to tune in for Gem operation.
3. Set TV features on TV Channel, Picture, Audio etc. menus as indicated on
page 98.
INFO i
Gem Operation Interactive Menu Features
Use the Gem remote provided in the room to operate both interactive menu and
the regular TV features.
ENTER
RETURN
MENU
INPUT
CC
VOL ALPHA/NUM CH
MUTE
REMOVE
COMMERCIAL MODE SETUP
96
3
2
ABC
GHI
5
JKL
6
PQRS
8
TUV
9
1
.:/,
4
7
0&@
Channel Guide
Shows available TV programs. Indicates channel, program start and finish time
and identifies the TV network.
P
A
G
E
Hotel Information
Shows typical hotel information. Such as photos of Guestroom, Dining, Business
Center, Fitness, Pool, and Facility. And any contributing Partners such as local
schools in co-operation programs with the lodge.
DEF
MNO
WXYZ
FLASHBK
PIP
RATIO
TIMER
SAP
PIP CH-
PIP CH+
PIP SWAP
PIP INPUT
Help
Provides help for the interactive menus.
Exit
Removes the interactive menu from the screen.
Note: The TV clock must be set before Gem data can be downloaded.
INSTALLER OVERVIEW
GEM PTC INSTALLER MENU
Operating Installer Menu
To set up the controls for the TV you will need to know how to
enter the TV Installer menu and make changes to the default values as required. If necessary, familiarize yourself with the TV
Installer menu and how to make and save changes in the menu.
LG Installer Remote
You will need an L G I n s t a l l e r r e m o t e control similar to the one
shown to the right. The installer remote must have a “Source” button or its equivalent. The remote shown in this manual has
“INPUT” -- this button serves the purpose of a Source button.
000
INSTALLER SEQ
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
Typical Installer Menu
POWER
TV
STB
The TV’s clonable features need to be set up. This is a critical
step. If the Master TV display panel’s clonable features like adding
channel icons or channel labels are not done correctly, then all the
cloned TVs will have problems. Refer to the Owner’s Manual for
other TV features: Video, Audio, Closed captions, V-Chip, etc.
000
DVD
VCR
PORTAL
GUIDE
INFO i
ENTER
RETURN
MENU
INPUT
TLL-1100A Clone Programmer
The TLL is a very simple cloner to use. It can be set up to clone a
master TV setup and transfer it into a target TV. Cloning is accomplished using the TV/Cloner MPI ports for communication. Be sure
the Master TV is set up completely. Cloning is only
possible when the TV is tuned to an Analog channel, not a digital channel.
TLL1100A
TV Link
Loader-Demo
Ready
RECEIVE
MUTE
REMOVE
1
.:/,
SEND
TLL1100A
2
GHI
5
PQRS
8
4
7
ABC
3
JKL
6
TUV
9
0&@
MENU
ENTER
P
A
G
E
DEF
MNO
WXYZ
FLASHBK
PIP
RATIO
TIMER
SAP
PIP CH-
PIP CH+
PIP SWAP
PIP INPUT
COMMERCIAL MODE SETUP
MODE
CC
VOL ALPHA/NUM CH
97
COMMERCIAL MODE SETUP
INTERACTIVE TV OVERVIEW
Channel Guide
Hotel Information
Help
Exit
Through the interactive TV, the lodging guest is offered a more complete
venue of lodge services and amenities. Using the TV in the comfort of the
hotel room, the guest can browse the lodge resources available and make
selections quickly. Charges for these offerings are billed at the time of order.
The Prp:Centric TV is connected to the lodge’s billing computer.
After the interactive TV is installed, the following hotel and other resources
may be available to the hotel guest, assuming that they are provided by the
lodge.
Interactive Amenities may include the following
■
Pro:Centric Interactive TV
Notes
Pro:Centric-TV Setup for
PPV (Pay-per-view)
Operation
A PPV card usually has a channel lineup included with the
master TV setup. If this is the
case, reset TV to default condition, set any TV features and
installer menu items as
required and then insert the
PPV pre-programmed card into
the MPI slot.
■
COMMERCIAL MODE SETUP
98
After TV setup, remove the AC
power cord for 15 seconds.
Important!
■ The TV will take a few minutes
to load electronic program
information. If enough time
has not elapsed for the TV to
acquire EPG data, the TV may
operate erratically; menus
may not work or TV will not
respond to IR remote key
presses.
■
■
■
■
■
■
■
■
■
■
Hotel Information, News and Events.
Directory Services, (Tourist attractions, Restaurants, etc.)
Reservation Service (Business Meetings, Fitness, SPA, etc.)
Weather, Traffic Information.
Shopping Services (Delivery to Guest Room)
Room Service (Menu Ordering, Memo Service, Morning Wake Up Call, Laundry, etc.)
Ticketing Services.
Check Out Service (in the Guest Room).
Gaming Services.
Email resources, guest can access an email account, etc.
Other offerings as they become available.....
COMMERCIAL MODE SETUP FOR MASTER TV
This page provides an overview of a Master TV configuration.
N o t e 1: Disconnect all Aux inputs. Under certain conditions, Auto
Tuning (Channel search) is disabled if there is an Aux input active.
Commercial Mode Setup Procedure
1. Set Installer Menu Items
(Enter TV Installer Menu, see Installer menus for detailed instructions.)
a. Set Installer menu item 1 1 7 F A C T D E F A U L T, to 0 0 1 and press
E N T E R on Installer remote. (This clears all installer menu custom
settings, channel labels / icons etc. and reloads the factory default
settings.)
b. Set Item 0 0 3 B A N D / A F C.
- B r o a d c a s t: set to 0 0 0.
- H R C: set to 0 0 2
- C A T V: set to 0 0 1.
- I R C: set to 0 0 3
c. Set item 0 2 8 C H O V E R I D E to 0 0 1. This allows access to channel search, Auto Tuning and Channel List/Edit options in the
Channel Menu.
d. Set other particular installer items that affect your TV programming
network. Enable/Disable Aux sources, set a G e m S t a r t C h a n n e l etc.
e. After all required installer menu item settings have been adjusted,
press ENTER on the remote to remove Installer Menu.
2. Set Up TV Features
(Channel, Picture, Audio, Lock, Time, Option, Digital Captions etc.
See TV Clonable options list and TV menus pages.)
4. Transfer TV Setup to Internal TV Controller: 2-5-5 + Menu Mode
After the TV channel scan has been edited and channel label icons
added, enter the Installer menu. Once in the Installer menu, press 2-55 and MENU on the remote. This transfers the TV setup to the internal controller box.
5. Add Custom Channel Labels for Analog Channels: 2-5-4 + Menu Mode
Enter Installer menu, press 2-5-4 and MENU. Add your own custom
text labels to channel onscreen displays. Note: Digital Channels often
have a broadcaster generated label. (See 2-5-4+Menu pages.)
When finished, to exit 2-5-4+Menu mode, press M E N U.
xxLG710H PTC INSTALLER MENU
000
INSTALLER SEQ
000
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
For 32/37/42/47/55LD650H
xxLD650H PTC INSTALLER MENU
000
INSTALLER SEQ
000
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
For 32/37/42LD655H
xxLD655H PTC INSTALLER MENU
000
INSTALLER SEQ
000
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
Typical TV Installer Menu
117
FACT DEFAULT
00X
003
BAND/AFC
00X
028
CH. OVERIDE
001
Adjust the settings for
these Installer Menu Items
DIGITAL 19-3
MONO STEREO SAP
WXYZ
Custom Text Label ‘WXYZ’ created in
2-5-4 + Menu (Add Channel Label)
Mode
093
RJP AVAILABLE
001
Set 093 RJP Available to 001 if
using a remote jack pack
028
CH. OVERIDE
000
After Master TV setup has been
completed, set item 028 Ch
Overide to 000.
COMMERCIAL MODE SETUP
3. Run Auto Tuning (Channel Search)
(Search for all available channels.) Go to the Channel menu and
access the Auto Tuning option, follow onscreen instructions.
a. Edit Channel Scan. In the Channel Menu, access Channel Edit
option.
■ Add/Delete channels per your system requirements.
Note: Physical channel numbers are used to identify Virtual channels.
■ Add familiar channel trademarks/logos like ABC, CBS, NBC etc. to
the Channel-Time onscreen display. In the Channel menu, select the
Channel Label option. Add identifiable labels (logos) for the end
user to readily know what common networks are available.
For 32/37/42LG710H
Verify TV Setup
At this point, verify that the channel lineup, channel icons and custom
labels are correct. Make sure the TV features are set per your requirements. Set item 0 2 8 C h O v e r i d e to 0 0 0 to lock the channel scan.
After the preceding has been completed, the Master TV setup is ready
to be copied to a Clone Programmer, see cloning options pages.
99
COMMERCIAL MODE SETUP
MASTER TV PROFILE SETUP LEARNING/TEACHING WITH USB
MEMORY CARD
On Master TV, Create Profile and Learn
1. Set up all Master TV features on the menus and do
a Channel Search. Add Channel and Aux Labels etc.
Do 255+menu on Installer Menu to save current TV
into flash memory.
2. Plug a USB memory drive into the USB In port on
the master TV.
3. Press the Menu key to open the Main menu.
Highlight the Option icon.
4. Press the Left arrow key once, the Option icon on
left side of menu will be highlighted.
5. Press number key ‘7’ a total of 7 times.
6. Gain access to “Learn From TV”.
A. First, the Expert Download Menu page will not
show the “Learn From TV” option. In order to make
it available, key in the password which is used to
enter Installer Menu. Example 9-8-7-6.
B. By pressing the up/down arrow keys(if there are
other menus), place the cursor on Learn From TV,
then press the Enter Key.
7. Using the Up/Down arrow keys, highlight “Learn
From TV” and then press Enter.
8. To identify this profile from others, you can change
the last 5 digits. Key in a custom file name and
then press the Enter key.
9. The Learning status will be shown in the progress
bar. As soon as learning is complete, a message will
appear on the screen indicating the learning process
is done.
10. Remove the USB memory card.
!
USB Download Menu
Upgrade TV Software
Learn From TV
UPGRADING...
Upgrade TV Software
100%
Teach To TV
Do not unplug!
Learn From TV
Optional: Edit/Change File Name
If necessary, the file name can be edited or changed.
Learn From TV
Select the file name and press OK to start
E
xxLG710H-UA00001.TLL
E
Previous
Enter
For 32/37/42/47/55LD650H
Learn From TV
Select the file name and press OK to start
E
COMMERCIAL MODE SETUP
For 32/37/42LG710H
xxLD650H-UA00001.TLL
E
Previous
Enter
For 32/37/42LD655H
Learn From TV
Select the file name and press OK to start
E
xxLD655H-UA00001.TLL
E
Previous
100
Enter
! NOTES
Do not remove TV power cord or USB memory
card while Learning, doing so might harm your
USB memory card.
Do
not remove TV power cord or USB memory
G
card while Teaching, doing so may cause the TV
to malfunction.
G You are allowed to edit the file name, however, a
file with edited contents will not be recognized.
G Since clock data is copied into USB memory card
as numeric data, the time difference between
teaching and learning is not automatically adjusted. Either set the clock manually, or use Auto
Clock set on TV main menu.
G
On Target TV, Teach Master TV Profile
1. Plug the USB memory card with the Master TV
Profile setup into the Target TV’s USB input port.
2. Press Menu key to open the Main menu and then
highlight the Option Menu icon.
3. Press the Left arrow key once, this will highlight the
Option icon on left side of menu.
4. Press the number key ‘7’, a total of 7 times.
5. Using the Up/Down arrow key, select ‘Teach to TV’,
then press Enter key.
6. Use the Up/Down arrow keys to navigate through
profiles. Select the profile that you want to install by
highlighting it and pressing the Enter key.
7. Teaching progress will be shown on the progress bar.
As soon as teaching is done, a message will appear
indicating that the teaching process has been completed.
8. When the Teaching is done, Remove the USB memory card and unplug TV power cord.
9. Reconnect the TV’s power cord. Power the TV On
and the master setup should be resident on the TV.
For 32/37/42LG710H
Teach To TV
xxLG710H-UA00001.TLL
Previous
Enter
For 32/37/42/47/55LD650H
Teach To TV
xxLD650H-UA00001.TLL
Previous
Enter
For 32/37/42LD655H
Teach To TV
xxLD655H-UA00001.TLL
Previous
!
Enter
Teach To TV
UPGRADING...
40%
Do not unplug!
COMMERCIAL MODE SETUP
101
COMMERCIAL MODE SETUP
TLL-1100A CLONING CONNECTIONS/LEARNING SETUP
Connections for the TLL-1100A Clone Programmer to Learn the TV Master TV Setup
On Master TV
Set up all Master TV features in the
menus and do a Channel Search.
Add Channel and Aux labels etc. See
previous page. Insert an MPI cable
into the TV’s MPI port.
On TLL-1100A
1. Turn On the TLL-1100A.
2. Use the Mode button to select
Clone Mode.
3. Use the Left/Right arrow to
select the CBank (1 - 8) to store
the master setup in.
4. Plug the other end of the MPI
cable into the MPI port on the
bottom of the TLL.
5. With the Installer remote control,
select item 1 on TLL menu.
6. Press Enter, to transfer the
Master setup into CBankX on the
TLL. The TLL will copy the master
setup.
7. When learning is done, disconnect MPI cable from Master TV.
8. Reconnect TV power cord. Power
the TV On and the master setup
should be resident on the TV.
COMMERCIAL MODE SETUP
102
On Target TV
1. Connect MPI cable from the TLL
to the MPI port on the Target
TV. Assure that the correct
CBank(X) is selected on TLL..
2. With the Installer remote control
select item 2, to Teach the target
TV the master TV setup.
3. Press Enter to begin teaching.
4. When Teaching is done, disconnect MPI cable and power the TV
Off. Unplug TV power cord.
5. Reconnect TV power cord. Power
the TV On and the master setup
should be resident on the TV.
CLONE SELECTION MENU
Selected Bank: CBank X Saved
(1) LEARN FROM TV
(2) TEACH TO TV
(3) SET CLONE CLOCK FROM TV
(4) SET TV CLOCK FROM CLONE
(5) DISPLAY TV SETUP
(6) DISPLAY CLONE SETUP
M.P.I. Learning Setup
Antenna
(or CATV)
TV Link
Loader-Demo
CLONE CLOCK = 00:00
TV
CLOCK = 00:00
THE CLONE IS VERSION V2.2.2
-To change menu items, Press
channel keys or digits.
-To execute item, Press ENTER.
TLL1100A
Ready
MODE
MENU
ENTER
RECEIVE
SEND
TLL1100A
M.P.I. Teaching Setup
Antenna
(or CATV)
TV Link
Loader-Demo
CLONE SELECTION MENU
Selected Bank: CBank X Saved
(1) LEARN FROM TV
(2) TEACH TO TV
(3) SET CLONE CLOCK FROM TV
(4) SET TV CLOCK FROM CLONE
(5) DISPLAY TV SETUP
(6) DISPLAY CLONE SETUP
TLL1100A
Ready
MODE
MENU
ENTER
RECEIVE
CLONE CLOCK = 00:00
TV
CLOCK = 00:00
THE CLONE IS VERSION V2.2.2
-To change menu items, Press
channel keys or digits.
-To execute item, Press ENTER.
SEND
TLL1100A
Warning
G
Do not use the TLL-1100A while any PPV card is installed in the TV
or the clone programmer device will be damaged.
! NOTE
It is assumed that the TV is connected to a signal source, the TV
source selected is Antenna (RF) In, the signal is from an Analog
channel, not a digital channel, all equipment is connected to power
and turned on and the TLL Cloner main menu is displayed on the
TV screen, see above.
G If an analog channel is not available, tune the TV to an Aux source
like AV-1 for cloning purposes.
G
LT2002 CLONING CONNECTIONS/LEARNING SETUP
Connections for the LT2002 Clone Programmer to Learn the TV Master TV Setup
Antenna
or CATV
Ferrite Core
(TDK, ZCAT
2035-0930)
Connect cable to
TV MPI Jack and
follow on screen
instructions
Status
Indicator
MPI
Color
• green
• red
Reset
battery ok
battery low
Blink pattern
• slow
power on
no communications
• heartbeat power on
communications ok
THE CLONE HAS CONTROL OF THE TV
THE CLONE IS VERSION
THE TV IS VERSION
THE SW IS REVISION
XX
XX
XX
QuickSet II Programmer
LT2002
CLONE CLOCK = XX:XX
TV CLOCK
= XX:XX
-PRESS ANY KEY TO CONTINUE.
-DISCONNECT CLONE WHEN DONE.
Clone Programmer
Master TV
Warning
G
Do not use LT2002 while any PPV card is installed in TV or the clone programmer device will be damaged.
! NOTE
It is assumed that the TV is connected to a signal source, the source selected is Antenna (RF) In, the
signal is from an Analog channel, not a digital channel, all equipment is connected to power and turned
on and the LT2002 Clone Programmer main menu (THE CLONE HAS CONTROL OF THE TV) menu is
displayed on the TV screen, see above and next page.
G If an analog channel is not available, tune TV to an Aux source like AV-1 for cloning purposes.
G
■
■
■
■
The Master TV should be connected to a good, stable
signal from an over-the-air antenna or cable service
Analog channel and connected to power. (See above.)
Teaching and Learning is only possible between identical model devices. (However, the LT2002 Clone programmer can store up to 3 different ‘master’ setups.)
WARNING: Copying a blank or incorrect memory into
a TV, STB or other device will cause the TV, STB or
other device to operate erratically or become inoperable.
Use an Installer’s remote to operate Learning and
Teaching menus.
Make sure that the batteries in the Clone programmer
are fresh.
■
■
■
■
■
If batteries are removed, the Clone Clock time will be
lost.
Decide if you want to set the time from the Clone
programmer or copy the time to the Clone programmer; from a compatible TV which has the clock set to
the current time.
Setting the time and transferring it to the Clone or
other device is a separate procedure.
Follow the connection diagram above to connect the
Clone to a Master TV TV display panel. After learning
is complete, to another identical TV TV display panel
to “teach” it the master setup.
See the Clone Troubleshooting section to resolve
problems.
COMMERCIAL MODE SETUP
Before you begin cloning...
Turn to the next page to continue Cloning Setup.
103
COMMERCIAL MODE SETUP
LT2002 CLONING LEARNING SETUP
Learning the Master TV Setup
Instructions for the Clone Programmer to Learn the Master TV Setup
Use MPI Cable to Connect LT2002 Clone
Programmer to Master TV MPI Port
If there is a good connection, “THE CLONE HAS
CONTROL OF TV”
message will appear. Press any key on the Installer remote.
Learn Setup from Master TV
Press 1 to select the “LEARN FROM TV” option, then
press ON/OFF, POWER, or ENTER to go to the Memory
Bank Selection Menu. Pick the Memory ”Bank” you want to
store the master TV’s setup in by pressing either Channel
key repeatedly to choose Memory 1, 2 or 3. (If you
choose a Memory “Bank” that has a master device’s setup
programmed into it, that setup will be overwritten by the
new master TV’s setup.) Once the Clone memory bank is
selected, press ON/OFF, POWER, or ENTER. The Clone
memory bank you have selected will be shown. Press
ON/OFF or POWER to begin copying the master TV’s
setup.
Set the Clock (Optional)
COMMERCIAL MODE SETUP
104
Set the time on a Master TV’s Clock. (If the time has
already been copied from a TV into the Clone programmer,
you can set a master TV’s clock by copying the time from
the Clone programmer.) The Clone Programmer can copy
the current time to both a master TV and to the Clone’s
internal clock; accurate to within one minute. (Another reason that the Clone programmer should be equipped with
fresh, high-quality alkaline batteries, is for it to keep the
time as accurately as possible.)
Since the Clone Programmer’s time cannot be set directly,
the current time needs to be copied from a Zenith/LG TV
equipped with M.P.I. input capability.
After the time is copied to the Clone programmer, the current time can then be transferred to another TV. (This can
be a master TV, or another TV which has already had the
features set up.)
THE CLONE HAS CONTROL OF THE TV
THE CLONE IS VERSION
THE TV IS VERSION
THE SW IS REVISION
CLONE CLOCK=
TV
CLOCK=
XX
XX
XX
XX:XX
XX:XX
-PRESS ANY KEY TO CONTINUE.
-DISCONNECT CLONE WHEN DONE.
This menu should appear by itself after
the LT2002 is connected to the TV MPI
port.
CLONE SELECTION MENU
(1) LEARN FROM TV
(2) TEACH TO TV
(3) SET CLONE CLOCK FROM TV
(4) SET TV CLOCK FROM CLONE
(5) DISPLAY TV SETUP
(6) DISPLAY CLONE SETUP
-TO CHANGE MENU ITEMS, PRESS
CHANNEL KEYS OR DIGITS.
-TO EXECUTE ITEM, PRESS ON/OFF,
POWER, OR ENTER
This menu should appear after any key is
pressed on the Installer remote.
LT2002 Clone Programmer Communication
Problems
■ A slow flashing green light indicates there are
communication problems between the TV and
the LT2002 clone programmer. If this is the
case, check for a damaged cable, poor contacts,
or other connection troubles.
■ If the status indicator is red, the programmer
batteries are low and should be replaced. Install
4 high-quality alkaline AA batteries.
CLONING CONNECTIONS/TEACHING SETUP
Teaching the Master Setup to Another TV
Connections for the LT2002 to Teach another TV the Master Setup
Antenna
or CATV
Ferrite Core
(TDK, ZCAT
2035-0930)
Connect cable to
TV MPI Jack and
follow on screen
instructions
Status
Indicator
MPI
Color
• green
• red
Reset
battery ok
battery low
Blink pattern
• slow
power on
no communications
• heartbeat power on
communications ok
THE CLONE HAS CONTROL OF THE TV
THE CLONE IS VERSION
THE TV IS VERSION
THE SW IS REVISION
XX
XX
XX
CLONE CLOCK = XX:XX
TV CLOCK
= XX:XX
-PRESS ANY KEY TO CONTINUE.
-DISCONNECT CLONE WHEN DONE.
Target TV
QuickSet II Programmer
LT2002
Clone Programmer
! NOTE
G
If an analog channel is not available, tune TV to an Aux source like AV-1 for cloning purposes.
CLONE SELECTION MENU
(1) LEARN FROM TV
(2) TEACH TO TV
(3) SET CLONE CLOCK FROM TV
(4) SET TV CLOCK FROM CLONE
(5) DISPLAY TV SETUP
(6) DISPLAY CLONE SETUP
Teach Master TV’s Setup to
the target TV
Disconnect TV Power for 15 Seconds
Unplug the AC power cord of the newly-cloned TV from the
power outlet for about 15 seconds to activate the newly-copied
setup.
This menu should appear
after any key is pressed
on the Installer remote.
TEACHING IN PROGRESS,
PLEASE WAIT
This display will appear
during Teaching function.
COMMERCIAL MODE SETUP
After learning is complete, remove the M.P.I. cable from the master TV and connect it to the target TV that you want to copy
the master TV’s setup into. With “THE CLONE HAS CONTROL
OF TV” message displayed, press 2 or use either Channel key to
go to the “TEACH TO TV” option, press ON/OFF, POWER, or
ENTER. Select the LT2002 memory that the new setup is in.
Press On/Off to transfer the new setup and other information to
the new TV. Teaching usually takes 2-3 minutes.
After the “TEACHING COMPLETE” message is displayed, press
any key to return to the Clone menu, then press ON/OFF,
POWER, or ENTER. If finished, detach M.P.I. cable from the
target, newly-cloned TV.
-TO CHANGE MENU ITEMS, PRESS
CHANNEL KEYS OR DIGITS.
-TO EXECUTE ITEM, PRESS ON/OFF,
POWER, OR ENTER
TEACHING COMPLETE
This display will appear
after Teaching is complete.
105
COMMERCIAL MODE SETUP
INSTALLER MENU
Use the Installer’s Menu to set up or change operational settings.
See more detailed descriptions of the Installer menu items on the following pages...
Accessing the Installer’s Menu
Make sure TV is on. Installer’s menu items can be accessed by using
an installer’s remote control. Just press MENU repeatedly until the
TV seems to stop responding, then press 9, 8, 7, 6, then ENTER to
access the Installer’s menu. To remove the Installer’s menu, press
ENTER again. Any changes you make will be stored in nonvolatile
memory. (The menu also disappears automatically.)
The Installer’s menu opens with item 000 INSTALLER SEQ 000.
Use the Up/Down arrow keys to sequence through the available
menu items. Or, access an item directly by keying in the line number,
then pressing MENU. For example, to access the Sleep Timer option
which is item 015, press 0-1-5, then MENU. To change a setting,
use the Left/Right arrow keys. Or, enter a value directly.
For 32/37/42LG710H
xxLG710H PTC INSTALLER MENU
000
INSTALLER SEQ
000
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
For 32/37/42/47/55LD650H
xxLD650H PTC INSTALLER MENU
000
INSTALLER SEQ
000
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
For 32/37/42LD655H
Using the Installer’s Menu
Items 000 ~ 119 are immediately accessible only upon entering the
Installer’s Menu. Their numbers, descriptions, ranges, factory default
settings, and a place for listing any changes made on-site are given
below and on the following pages.
Typical Installer Menu
Activating changes made to the Installer’s Menu
After exiting the Installer menu, power the TV off and then back on to activate changes to the Installer menu.
xxLD655H PTC INSTALLER MENU
000
INSTALLER SEQ
000
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
Installer Menu Items 000 through 034
COMMERCIAL MODE SETUP
106
Menu Item
000
001
002
003
004
005
007
008
009
010
011
015
016
017
021
022
023
028
029
030
031
032
034
Function
Value Range Default Value
Brief Description of Function and Comments
INSTALLER SEQ
0~3
0
Leave default set to 0.
POWER MANAGE
0~7
0
Sets number of hours of no activity before auto shut Off.
AC ON
0/1
0
Set to 1 to enable auto turn On at power up.
BAND/AFC
0~3
1
Selects Tuning Band: 0=Broadcast, 1=CATV, 2=HRC, 3=IRC
STRT CHANNEL 0 ~ 127, 255
255
Channel at turn-on (Set to 255 to tune in last channel before power Off).
CHAN LOCK
0/1
0
If set to 1, cannot tune from current channel.
STRT VOLUME
0 ~ 63, 255
255
Sets Volume level at TV turn-on (Set 255 to retain last volume level).
MIN VOLUME
0 ~ 63
0
Sets minimum allowable volume setting.
MAX VOLUME
0 ~ 63
63
Sets maximum allowable volume setting.
MUTE DISABLE
0/1
0
Set to 1 to disable mute function.
KEY DEFEAT
0/1
0
Set to 1 to disable menu navigation keys on display panel.
SLEEP TIMER
0/1
1
Set to 1 to enable Sleep Timer.
EN TIMER
0/1
0
Set to 1 to enable On/Off Timers.
ALARM
0/1
1
Set to 1 to enable Alarm.
V-CHIP
0/1
1
Set to 1 to enable V-Chip functions.
MAX BLK HRS
0 ~ 99
12
Sets number of V-Chip (Parental Control) blocking hours.
CAPTION LOCK
0/1
0
Set to 1 to retain caption setting at power Off.
CH. OVERIDE
0/1
1
If set to 0, limits direct access to favorite channels.
OLD OCV
0/1
0
Set to 1 to change M.P.I. operation to OCV.
ACK MASK
0/1
0
If set to 1, changes M.P.I. for some OCV boxes.
POLL RATE
20 ~ 169
94
Selects poll rate for M.P.I.
TIMING PULSE
186 ~ 227
207
Sets baud rate for M.P.I.
CAMPORT EN
0/1
1
Set to 1 to enable Video 2 input.
Installer Menu Items 035 through 119
Menu Item Function
Value Range Default Value
Brief Description of Function and Comments
035
038
039
COMPPORT EN.
YPrPb EN.
REAR AUX EN
0/1
0/1
0/1
1
1
1
Note 1. Set to 0 to disable HDMI 1. Set to 1 to enable HDMI 1.
Set to 1 to enable display panel Component Video 1 input jacks.
Set to 1 to enable display panel Video 1 input jack.
040
AUTO CAMPORT
0/1
1
046
STRT AUX SRCE
1 ~ 6, 255
6
Set to 1 to automatically switch to Camport. If set to 1, STRT AUX
SRCE cannot be set to 2.
Sets the starting AUX source.
047
AUX STATUS
0/1
0
053
069
070
071
DIS. CH-TIME M.
EN. CH-T COL.
FOR. CH-TIME
BCK. CH-TIME
0/1
0/1
0~7
0~7
0
1
2
2
073
CH NOT AVBLE
0/1
0
If set to 1 and channel override is 0, “NOT AVAILABLE” message is
displayed when directly accessing a channel not in the favorite channel list.
075
078
079
080
081
082
REVERT CH
UPN MSB
UPN MSB-1
UPN MSB-2
UPN LSB
CHKSM ERROR
0/1
0 ~ 255
0 ~ 255
0 ~ 255
0 ~ 255
0/1
0
0
0
0
0
1
If set to 1 and loss of M.P.I. communication occurs, TV tunes to Start Channel.
User programmable number, most significant byte.
User programmable number, most significant byte - 1.
User programmable number, most significant byte - 2.
User programmable number, least significant byte.
Enforces rigid M.P.I. checksum.
083
HANDSHK TIME
0~5
5
Relaxes M.P.I. timing to be compatible with PC based
Windows-controlled systems.
084
PERMANENT BLK
0/1
0
Removes block hours setting for Parental Control and makes block
permanent.
087
REAL BGB EN.
088
090
091
EN NOISE MUTE
KEY LOCK
YPrPb2
0 / 2 / 18 (For LG710H) 2 (For LG710H)
0 / 1 / 17 (For LD650H, 1 (For LD650H,
LD655H)
LD655H)
0/1
1
0/1
0
0/1
1
093
RJP AVAILABLE
0, 1, 2, 5, 6
0
Set to 0 to disable. Set to 1, 2, 5 or 6 for HDMI or DVI mode. (See
detailed descriptions)
094
SAP MENU EN
0/1
1
Set to 0 to disable feature on Function menu. Set to 1 to enable feature
on Function menu.
096
DEF. ASP. RATIO
0~4
2
Sets default aspect ratio at power up. See detailed descriptions
and item 106.
099
BACK LIGHTING
102
ATSC BAND
1 ~ 100
101 ~ 200
201, 202, 255
0~4
Set to 1 for M.P.I. AUX source to be reported as a channel number
instead of Channel 0.
Set to 1 to disable Channel-Time display.
Set to 1 to enable custom color for the Channel-Time display.
Chooses custom foreground color for the Channel-Time display.
Chooses custom background color for the Channel-Time display.
Note 1. Set to 0 to disable RGB1. Set to 2 for PC.
Note 1. Set to 0 to disable RGB. Set to 1 to enable RGB.
If set to 1, mutes audio if no signal is present.
If set to 1, keyboard is locked out, IR is still functional.
Set to 0 to disable HDMI 2. Set to 1 to enable HDMI 2.
103
ATSC TUNE MODE
0/1
1
Default 01 for physical channel scan. Set to 0 for Virtual Channel scan.
104
START MINOR CH
0 ~ 255
0
Selects Minor start channel. Set 0 for NTSC. Not 0, sets Minor
channel number.
106
ASP RATIO LOCK
0/1
0
116
117
VIDEO MUTE EN
FACT DEFAULT
0/1
0/1
0
0
To retain set aspect ratio on power cycle, set to 1. Set to 0 for
default ratio on power cycle.
Set to 0 for normal, set to 1 for Blank.
0=Normal. 1=Loads presets of all above settings.
118
POWER SAVING
1, 3, 7
3
119
DATA CHANNEL
0 ~ 135
0
COMMERCIAL MODE SETUP
4
Sets the brilliance of the TV picture backlighting.
Settings above 101 control dynamic back lighting and enable
power saving mode.
Selects ATSC band.
202
Set to 1 to be powered at b-Lan module. Set to 3 to bo
powered at b-Lan module only when TV is powered
on. Set to 7 to be not powered at b-Lan module.
Sets the DATA Channel.
N o t e 1: Dependent on item 093 RJP Available setting.
107
COMMERCIAL MODE SETUP
Detailed Descriptions of Installer Menu Items
000 - INSTALLER SEQUENCE
Specifies entry sequence to the Installer Menu.
0 = 9876
1 = 4321
2 = 1478
3 = 3698
001 - POWER MANAGE (Power Management)
Determines hours of no activity before automatic shutoff.
The POWER MANAGE function is for saving energy. If
set to 0, Power Manage is Off. Settings range from 0 ~ 7,
with 1 ~ 7 representing the hours that the unit will
remain On, unless there has been activity from either the
control panel or remote control.
002 - AC ON (AC Power Switchable)
If set to 1, allows the TV to turn On just by applying
AC power. Pressing the On button is not necessary. This
is desirable if the TV is plugged into a cable box or a
power outlet controlled by a wall switch. Use ADJ
Left/Right arrow to choose 0 or 1 where 0 is the
default is Off, and 1 is On.
NOTE: If set to 1 (On), the TV does not respond to
On/Off commands from either the remote or the display control panel, and the SLEEP TIMER is also nonfunctional.
003 - BAND/AFC (Band/Automatic Frequency
Control)
There are 4 possible settings for this option:
0 = Broadcast
2 = HRC
1 = CATV
3 = IRC
COMMERCIAL MODE SETUP
If some channels were not found by Auto Tuning
(Channel Search), select the appropriate Band setting
here and add the channels using the Channel Edit
option in the Channel Menu.
004 - STRT CHANNEL (Start Channel)
If active, this function allows you to determine the initial
channel number when the TV is turned On. This feature
is useful for an in-house information channel, since the
TV would always select that channel when it is turned
On. Setting this to 255 causes the last channel viewed
when the TV was turned Off, to be the tuned to channel when the TV is turned On again. Note: For a digital
Start Channel, always remember to set item 104 to the
Minor Start Channel number.
0 = Aux
255 = Last channel
1 ~ 125 = Ch X
126 Map to Channel 3. 127 Map to Channel 4.
108
005 - CHAN LOCK (Channel Lock)
CHAN LOCK is ideal if the system must always be on
the same channel. Changing channels with Channel
Up/Down or keypad numbers is impossible. Channel
Lock is inactive if set to 0 (default).
Generally, this feature is used in connection with START
CHANNEL (Installer item 004) where the start channel
may, for example, be set to 3 or 4. If the start channel
is 3, then the TV will remain locked on Channel 3.
NOTE: For Items 007, 008 and 009
For legacy reasons, the scale used is 0 - 63. The PTC
software will translate this to the 0 - 100 scale used by
the TV.
To translate a TV volume level to the installer menu
value, use the following formula:
Installer Value = TV Value x 63
100
Enter only the whole number (disregard fractions).
007 - STRT VOLUME (Start Volume)
This function allows the Installer to determine the initial
volume level setting when the TV is turned On. This feature is useful for an in-house information channel, since
the TV would always select that volume level when it is
turned On. The range of values are 0 - 63, 255. If 255
is selected, the current volume level will be retained in
memory when the TV is turned Off; at turn On, the volume level will be automatically set at the previous or
last level.
008 - MIN VOLUME (Minimum Volume)
This function determines the minimum volume level
allowable with the VOLUME (VOL) Up/Down control. In
this way, for example, someone cannot set the volume
too low to hear. The value range is from 0 to 63 —
change values with ADJ Left/Right arrow. The factory
default is 0, which provides the full range of volume
control, if item 009 MAX VOLUME is also set to 63. It
may be best to set the same value on every TV.
NOTE: The minimum volume level cannot have a value
setting higher than the MAX VOLUME level (described
below).
009 - MAX VOLUME (Maximum Volume)
This function determines the maximum volume level
allowable with the VOLUME (VOL) Up/Down controls.
In this way, for example, someone can not set the volume level high enough to disturb others. The value
range is 0 to 63, with 63 as the default, which gives the
user the full range of volume control, if item 008 MIN
VOLUME is also set at 0. Change values with ADJ
Left/Right arrow keys. It may be best to set the same
value on every TV.
NOTE: The maximum volume level cannot have a value
setting lower than the MIN VOLUME level (described
previously).
010 - MUTE DISABLE
Enables or disables sound mute function. If set to 1,
sound cannot be muted. If set to 0, sound can be
muted.
011 - KEY DEFEAT (Keyboard Defeat)
If set to 1, key defeat prevents the end user from
accessing the on-screen menus with the display front
panel—MENU, SELECT, and Left / Right arrow keys do
not function. If set to 0, those keys do function.
NOTE: The menus can always be accessed by pressing
MENU on the remote.
015 - SLEEP TIMER
If set to 1, the SLEEP TIMER feature may be used. If
set to 0, the Sleep Timer is not available.
016 - EN TIMER (Enable On/Off Timers)
If set to 1, Timer function is available to user and
enabled continuously. Set to 0 to disable On/Off
Timers. (Clock must be set in order to use Timers.)
021 - V-CHIP (Parental Control) *
Set to 1 to activate V-Chip (Parental Control); have it
available to end user to filter and control or otherwise
restrict programming content that can appear. Set to 0
to turn V-Chip feature Off, not available to user; no
programming restrictions can be set.
022 - MAX BLK HRS (Maximum Block Hours) *
Sets hours from 0 to 99 for the maximum V-Chip
(Parental Control) block hours. Default setting is for
12 blocking hours.
028 - CH. OVERIDE (Channel Override)
If set to 1, the user can select channels with either
Channel up/down or by direct keypad entry. If set to
0, only those channels that are entered for scanning
can be selected.
029 - OLD OCV (On Command VideoTM)
Set to 1 for operation with systems from On
Command Corporation.
030 - ACK MASK
M.P.I. Communication Parameter. Leave at default setting unless changed by Pay-Per-View provider. When set
to 1, changes M.P.I. for some OCV boxes.
031 - POLL RATE
M.P.I. Communication Parameter. Selects Poll Rate for
M.P.I. Leave at default setting unless changed by PayPer-View provider. Step size of 16 ms.
032 - TIMING PULSE
M.P.I. Communication Parameter. Leave at default setting unless changed by Pay-Per-View provider. Sets
baud rate. Step size of 4.3 uS.
034 - CAMPORT EN. (Camera Port Enable)
Set to 1 to enable Video 2 input on display panel. If
set to 0, Video 2 input on display panel is not functional.
NOTE: S-Video overrides Video jack.
035 - COMPPORT EN. (Computer Port Enable)
Enable/disables display panel HDMI1 input jack. Set to
0 to disable, set to 1 to enable.
NOTE: The setting above is ignored if Installer item
093 RJP AVAILABLE, is set to 1.
038 - YPrPb EN. (Rear Component Video Enable)
Set to 1 to enable display panel rear Component
Video input jacks.
Set to 0 to disable display panel rear Component
Video input jacks.
039 - REAR AUX EN. (Rear Aux Enable)
Set to 1 to enable display panel rear AUX (Video 1) input.
Set to 0 to disable display panel rear AUX (Video 1)
input.
Note: S-Video overrides Video.
COMMERCIAL MODE SETUP
017 - ALARM *
Gives the installer the option of making the Alarm
function available to the end user. If set to 1, Alarm
function is available to end user. Set to 0 to disable
the Alarm function.
NOTE: Clock must be set before the Alarm function
will work.
023 - CAPTION LOCK
Set to 1 to restore previous caption On/Off state after
turn Off. If set to 0, captions are always Off at turn
On.
* Only affects Function Menu if enabled by
some PPV providers.
109
COMMERCIAL MODE SETUP
040 - AUTO CAMPORT
Set to 1 to automatically switch to Camport when equipment is connected to front Video input.
Set to 0 to disable front Video automatic source selection.
NOTE: If set to 1, 093 RJP Available is automatically set to 0.
073 - CH NOT AVBLE (Channel Not Available)
If set to 1 and item 028 CHANNEL OVERRIDE is set to 0,
“NOT AVAILABLE” message is displayed when directly
accessing a channel not in the channel scan list available in
memory.
046 - STRT AUX SRCE (Start Aux Source)
Sets the starting AUX source. At power up, TV will tune to
starting Aux source if item 004 Start Channel is set to 0.
If item 093 RJP Available is set to 0 and item
040 Auto Camport is set to 0:
1 = Video 1
4 = RGB
255 = Last Aux
2 = Video 2
5 = HDMI 2
3 = HDMI 1
6 = Component
075 - REVERT CH (Revert to Start Channel)
If set to 1 and loss of M.P.I. communication occurs, TV automatically tunes to the specified Start Channel.
If item 093 RJP Available is set at 1:
2 = Video 2
5 = HDMI 2
6 = Component
If item 040 Auto Camport is set to 1:
1 = Video 1
5 = HDMI 2
3 = HDMI 1
6 = Component
4 = RGB
047 - AUX STATUS
Set to 1 for M.P.I. AUX source to be reported as a channel
number instead of channel 0. Set to 0 to disable AUX identification change. Controls M.P.I. status channel response for
AUX inputs.
053 - DIS. CH-TIME (Disable Channel-Time)
Set to 1 to disable the Channel-Time display, Channel-Time
display will not appear.
Set to 0 to enable the Channel-Time display.
COMMERCIAL MODE SETUP
110
069 - EN. CH-T COL. (Enable Channel-Time Custom
Color)
Set to 1 to enable custom color for the Channel-Time display.
Set to 0 to disable custom color for the Channel-Time display.
070 - FOR. CH-TIME (Channel-Time Display Foreground
Color)
Set according to Color Chart.
0 = Black
3 = Yellow
6 = Cyan
1 = Red
4 = Blue
7 = White
2 = Green
5 = Violet
NOTE: If foreground and background color are the same,
menu background is transparent.
071 - BCK. CH-TIME (Channel-Time Display
Background Color)
Set according to Color Chart.
0 = Black
3 = Yellow
6 = Cyan
1 = Red
4 = Blue
7 = White
2 = Green
5 = Violet
NOTE: If foreground and background color are the same,
menu background is transparent.
078 - UPN MSB (UPN Most Significant Byte)
User programmable number, most significant byte readable
by M.P.I. command. Note: Not linked to serial number.
079 - UPN MSB-1 (UPN Most Significant Byte-1)
User programmable number, most significant byte-1 readable by M.P.I. command. Not linked to serial number.
080 - UPN MSB-2 (UPN Most Significant Byte-2)
User programmable number, most significant byte-2 readable by M.P.I. command. Not linked to serial number.
081 - UPN LSB (UPN Least Significant Byte)
User programmable number, least significant byte readable
by M.P.I. command. Not linked to serial number.
082 - CHKSM ERROR (Checksum Error)
Enforces rigid M.P.I. checksum validation.
Set to 1 for validation.
Set to 0 to disable (does not check checksum on M.P.I.
async port). SPI is always checked.
083 - HANDSHK TIME (Handshake Time)
Adds an additional delay to the handshake time which is 64
msec, thus relaxing M.P.I. timing requirements to be compatible with PC based Windows controlled systems, range is 0 5.
(Timeout = 25.5MS + [25.5 MS* Handshake time]).
084 - PERMANENT BLK (Permanent Block)
Allows Lock (Parental Control) blocking schemes to be permanent by disabling the blocking hours function.
Set to 1 to install Parental Control restrictions permanently.
Set to 0 for user-specified hours control of blocking
schemes.
087 - REAR RGB EN. (Rear RGB Enable)
Controls access to rear RGB input on TV.
Set to 0 to disable RGB input.
Set to 2 for PC for STB RGB input. (For 32/37/42LG710H)
Set to 1 for PC for STB RGB input. (For 32/37/42/47/55LD650H,
32/37/42LD655H)
Set to 18 for Auto Configure one time only with power
cord removal and reinsertion. (For 32/37/42LG710H)
Set to 17 for Auto Configure one time only with power
cord removal and reinsertion.(For 32/37/42/47/55LD650H,
32/37/42LD655H)
088 - EN NOISE MUTE (Enable Noise Mute)
If set to 1, audio mutes if no signal is present.
090 - KEY LOCK
If set to 1, display panel keyboard is locked out, not
available to end user. IR receiver remains functional.
091 - YPrPb2 (HDMI2 Enable)
Set to 0 to disable display panel HDMI2 input.
Set to 1 to enable DTV mode. Set to 2 to enable PC
mode.
093 - RJP AVAILABLE (Remote Jack Pack Available)
0 = Remote jack pack is not available or disabled.
1 = Legacy Model RJPs: HDMI Mode
Enables RJP when an HDMI cable is inserted into RJP.
Video is from HDMI. Audio stream is expected from HDMI
source. If no audio is present, no audio will be heard.
2 = Legacy Model RJPs, DVI Mode
Enables RJP when an HDMI cable is inserted into RJP.
Video is from HDMI however, Audio is from selected audio
source, based on the RJP’s audio hierarchical priority.
5 = Scaler Model RJPs, HDMI Mode
Enables RJP when an HDMI cable is inserted into RJP.
VIdeo is from HDMI. Audio stream is expected from HDMI
source. If no audio is present, no audio will be heard.
6 = Scaler Model RJPs, DVI Mode
Enables RJP when an HDMI cable is inserted into RJP.
Video is from HDMI however, Audio is from selected audio
source, based on the RJP’s audio hierarchical priority.
Notes :
■ See Reference section, RJP Input Hierarchy and RJP
Models page.
■ If set to 1, 2, 5 or 6, item 040 Auto Camport is automatically set to 0.
Settings 1, 2, 5 and 6 allow the lodge staff to customize
each TV’s RJP setup based on customer requirements.
096 - DEF. ASP. RATIO (Default Aspect Ratio)
Selects default aspect ratio at power up, see settings
below.
Set to 0 “Set By System”.
Set to 1 for 4:3.
Set to 2 for 16:9 (Factory Default).
Set to 3 for ‘Just Scan’
Set to 4 for Zoom
099 - BACK LIGHTING
Sets the TV screen brightness at power up, see settings
below.
Default setting value is 202.
1 - 100 Static Backlighting.
(1 = Dimmest picture, 100 = Brightest picture.)
101 - 200 Dynamic Backlighting.
(101 = Dimmest picture, 200 = Brightest picture.)
102 - ATSC BAND
Sets up TV to receive different types of incoming signals:
0=Broadcast, 1=CATV, 2=HRC, 3=IRC, 4=Same as NTSC.
103 - ATSC TUNE MODE
Sets ATSC tuning mode: Default set to 1 for Physical channel scan.
Set to 0 for Virtual Channel scan.
104 - START MINOR CHANNEL
Sets XX-XX minor start channel number at power up:
0=NTSC. If not 0, number selected is the Minor start
channel number.
106 - ASP RATIO LOCK (Aspect Ratio Lock)
Set to 1 to retain previous aspect ratio with power Off.
Set to 0 to retain default aspect ratio with power Off. See
item 96 Default Aspect Ratio above.
116 - VIDEO MUTE EN (Video Mute Enable)
Set to 0 for normal.
Set to 1 for blank.
117 - FACT DEFAULT (Factory Default)
Set to 0 for normal.
Set to 1 to load presets to all of the previous item settings.
WARNING: Setting this to 1 will reload the factory defaults and clear the channel list including erasing any assigned Channel Icons and
custom channel Labels.
118 - POWER SAVING
Default is set to 3. When TV is in Standby mode, MPI card
slot is powered by Standby power supply and embedded
BLAN is not powered. When TV is in Power On mode, MPI
card slot is powered by main 12V power supply and
embedded BLAN is powered. Note, TV must be powered
on in order to communicate with the embedded BLAN
module for configuration and control.
Notes :
■ See Reference section, B-LAN SETUP AND OVERVIEW
page.
COMMERCIAL MODE SETUP
094 - SAP MENU EN (2nd Audio Program)
Set to 1 to enable SAP feature on Function menu, if
Function menu is available.
Set to 0 to disable SAP feature on Function menu, if
Function menu is available.
201 Automatic Static Backlighting.
202 Automatic Dynamic Backlighting.
Set to between 101 and 200, TV automatically controls
backlighting depending upon the picture level of the current program.
Set to 201, TV automatically controls backlighting
depending upon external spectral sensitivity.
Set to 202, TV automatically controls backlighting
depending upon external spectral sensitivity and picture
level of the current program.
Set to 255, to disable power saving mode.
119 - DATA CHANNEL
Sets the Data channel. Set the channel number that will
provide data to the TV at turn on. Initially the TV may take
several minutes to load program data from AC power off
state.
111
COMMERCIAL MODE SETUP
REFERENCE: DETAILED INSTRUCTIONS FOR MAKING A
MASTER TV
IMPORTANT INSTALLER SETUP INFORMATION! PLEASE READ THE FOLLOWING...
To set up a master TV you will need to know
how to enter the TV Installer menu and make
changes to the default values as required. If
necessary, familiarize yourself with the TV
Installer menu and how to make and save changes in the
menu, before attempting to clone the TV Master TV
setup.
You will also need an L G I n s t a l l e r r e m o t e c o n t r o l
similar to the one shown in the front of this manual. The
installer remote must have a “Source” button or its equivalent. The remote shown in this manual has a “INPUT”
button -- this button serves the purpose of a Source button.
is a critical step. If the Master TV display panel’s clonable
features like adding channel icons or channel labels, digital font options etc., are not correctly added, then the
cloned TVs will all have problems.
As the cloning procedure is being performed, specific
steps need to be done at the indicated times to achieve
the desired result. Be sure to do each task as indicated. If
a procedure or step is left out or not performed completely, cloning may not work. At each step, pay attention
to assure the TV screen shows the proper message when
cloning. If the message indicated does not appear, there
is a problem with that step and cloning may not be successful. Cloning is only possible when the signal source is
an Analog channel, not a digital channel.
Finally, the TV’s clonable features need to be set up. This
Making a Master TV
Detailed Instructions
COMMERCIAL MODE SETUP
112
The following describes the procedure for preparing a
Master TV for cloning and the procedure for adding
Channel Icons and/or Labels.
Note 1: Disconnect all Aux inputs. Under certain conditions, Auto Tuning Channel Search is disabled if there is an
Aux input active.
Note 2: Under certain conditions, changes to the input
mode of the RGB inputs will not take effect until the power
is cycled (TV is turned Off and On). To avoid confusion, disconnect all RGB inputs before entering the Installer menu.
1. Enter the TV installer menu.
a. Reset the internal controller to factory default by
accessing installer menu item 117 FACT DEFAULT, set it
to 1 and press “ENTER”. The value will change back to 0
after the TV’s internal controller has been restored to
factory default condition. This step will ensure that the
TV channel memory will be the active channel list. Check
the Status LED. If it is blinking rapidly then the TV channel map is in use.
b. Within the Installer menu, set the Installer menu items
to the configuration required of your institution.
c. It is important to set the tuning band at this time, see
Installer menu item 03 BAND/AFC.
d. Set Installer menu item 28 – CH OVERIDE to 001 to
allow access to the Auto Tuning and Ch. Edit features in
the Channel Menu. Exit the Installer menu.
2. Access the Master TV menus and set the clonable
options on the menus to the desired configuration.
Refer to the Clonable Menu Features Chart in this manual.
3. Run Auto Tuning to find analog and digital channels.
4. Enter the Channel Edit menu and edit the channel lineup
to include the Free-To-Guest Channels only.
5. Assign ICONs to the channels using the Channel Label
Menu.
Note: You can add Channel ICONS typically network
logos like ABC, NBC, PBS etc. in this step. Or, in Step 7,
add Channel ICONS or labels for channels without Icons.
6. Transfer the TV setup: Enter the TV installer menu. Press
‘2’, ‘5’, ‘5’, ‘MENU’ to start the transfer of the TV’s setup
to the internal controller. Once the transfer is complete,
the system will exit the Installer menu. Check the Status
LED inside the TV. It should be blinking slowly (1 blink
per second).
7. Edit/Add Channel ICONs and Channel Labels as needed.
Enter Installer menu. With menu displayed, press 2-5-4
+ MENU. See next page for detailed instructions:
- Editing/Adding Channel ICON and Labels on
Master TV
- Changing a Channel’s ICON on Master TV
- Changing/Adding Channel Labels on Master TV
- Changing Source Labels on Master TV
8. Verify Master TV setup and feature configuration:
■ Did you add Channel ICONS?
■ Did you add Channel Labels?
■ Did you add Source Labels?
■ Did you adjust all TV menu options as required?
After verifying master setup, enter the TV Installer menu
and set Installer menu item 28 CH OVERIDE to 000.
Press ENTER to remove and exit the Installer menu.
REFERENCE: PROCEDURES FOR ADDING CHANNEL LABEL
ICONS/CUSTOM CHANNEL LABELS (2-5-4 + MENU MODE)
Adding Channel Icons and Labels in the 2-5-4 + Menu Mode
Editing/Adding Channel ICONs and/or
Labels
If there is no pre-assigned ICON, you can make a custom channel label of up to 7 characters to help in
identifying the channel or network. At your option,
channel labels can also be added in addition to a preassigned ICON. You may also add labels for the Aux
input sources to clearly identify the devices that are
connected to the Aux inputs.
(Icon)
XYZ
XYZ
XYZ
NETWORK
1 2 3 4 5 6 7
(Label)
Editing and adding the labels can only be done if there
are channels entered into the TV’s channel map either
by using the method described in item 6, by cloning or
by the use of the master remote control from the PPV
provider.
Note: A blank letter space is available between ‘Z’ and
‘!’.
To Do Channel Editing/Labeling, Proceed as
Follows
1. Enter TV Installer menu.
2. Once the installer menu appears, press ‘2’, ‘5’, ‘4’,
‘MENU’. This enters the channel label editing mode.
Add your channel icons and channel labels in this
menu, see below. (You can do this more than once.)
3. To exit the menu when done press “MENU”.
Changing/Adding Channel
Labels on Master TV
Changing Source Labels on
Master TV
1. With Channel Up/Down, select the
channel you want to change the
Icon for.
2. With the Right or Left ADJ arrow,
select the thin letter ‘I’ on the
channel ID display.
3. With the Up or Down arrow, select
the desired ICON you want to
appear to identify the channel. (If
you know the ICON number, enter
the number followed by Enter /
Select.)
4. Proceed with Changing/Adding
Labels or go to the next channel.
1. Channel Up/Down to select the
desired channel.
2. Press the Right or Left ADJ arrow
repeatedly until the numbers 1 to
7 show up. The number shows the
position of the character that can
be changed. Number 1 is the first
character, number 2 the second
character and so on.
3. With the Up or Down arrow, select
the desired character.
4. Proceed to the next number position or use Channel Up/Down to
go to the next channel.
1. Press “INPUT” to select the desired
Aux input source; A/V 1, A/V 2,
HDMI Component, RGB etc.
2. Press the Right or Left arrow
repeatedly until the numbers 0 to 9
shows up. The number shows the
position of the character that can
be changed.
3. Use the Up or Down arrows to
select the desired character.
4. Press “INPUT” for the next Aux
source or proceed with Changing
Icon or Changing/Adding Labels.
Press Ch Up/Down to return to
channels.
Installer Remote Control Key Functions for Master TV Channel
Editing/Labeling Menu
■
■
■
CHANNEL Up/Down - Tunes in the next channel in
scan.
Left/Right Arrows - Select the item to change. If “I”
is shown, the ICON can be changed. If a number is
shown, it indicates the position of the character that
can be changed.
Up/Down Arrows - Select the ICON or the character to be displayed. Tip: Arrows can be held down for
fast scrolling.
■
■
■
■
0 – 9 - Use to enter the index number of the ICON,
if known.
ENTER/SELECT - Changes the ICON after the
number has been entered.
INPUT - Changes the Aux input label. (“Source” on
the remote shown in this manual is INPUT.)
MENU - Exits the editing process.
COMMERCIAL MODE SETUP
Changing a Channel’s ICON on
Master TV
113
COMMERCIAL MODE SETUP
REFERENCE: CLONABLE MENU FEATURES
Clonable Menu Features
Menu /Sub Menu Features
Installer Menu
Installer Item settings
Channel
Auto Tuning (Channel Lineup)
Channel Edit
Channel label
Aspect Ratio
Picture Mode
Advanced Control
Audio
Auto Volume
Clear Voice ll
Sound Mode
Balance
Audio Contd.
Treble
Bass
SRS TruSoundXT
Infinite Sound
TV Speaker
Option
Language
Caption
Caption Mode
DTV Captions Style - Style
DTV Captions Style - Size
DTV Captions Style - Font
DTV Captions Style - Text Color
DTV Captions Style - Text Opacity
DTV Captions Style - BG Color
DTV Captions Style - BG Opacity
DTV Captions Style - Edge Type
DTV Captions Style - Edge Color
Lock
Movie Rating
TV Rating – Children Age
TV Rating – Children Fantasy
Violence
TV Rating – General Age
Input Block
Time
Auto Clock
Manual Clock
Off Time
On Time
Auto Off
! NOTE
Picture Menu and other menu settings shown above are not clonable on all TVs.
End user has access to Picture, Sound and Ratio on user remote control.
Menu
options vary between Analog / Digital channels and Aux Sources.
G
G
Procedure for Checking Software Version
COMMERCIAL MODE SETUP
The software version of the TV may be checked by accessing the INSTALLER MENU.
To do this, press the MENU button repeatedly until the menu display ceases to respond to MENU key presses.
Then, press "9", "8", "7", "6", "ENTER/SELECT". Press ENTER/SELECT again to remove the installer menu from
screen.
For 32/37/42LG710H
For 32/37/42/47/55LD650H
xxLG710H PTC INSTALLER MENU
000
INSTALLER SEQ
000
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
xxLD650H PTC INSTALLER MENU
000
INSTALLER SEQ
000
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
Typical Installer Menu
114
For 32/37/42LD655H
xxLD655H PTC INSTALLER MENU
000
INSTALLER SEQ
000
UPN 000-000-000-000
FPGA E0F1
PTC V1.00.000
CPU V3.06.00
REFERENCE: POWER SAVING SETUP
Power Savings Setup
Installer Item 118 Power Saving: set to 003, enabled (Default).
Installer Item 099 Backlighting: value set as shown below. (Default value is 202)
For 32LG710H
Item 099
Backlighting
(Static)
100
90
80
70
60
50
40
30
20
10
1
Lumin.
206
204
203
172
147
127
108
86
66
50
39
Power
Consumption
(Watts)
104
103.5
103
93
85
79
73.5
67
60
55.5
51.5
Power
Savings
Rating
0%
0.48 %
0.96 %
10.58 %
18.27 %
24.04 %
29.33 %
35.58 %
42.31 %
46.63 %
50.48 %
Item 099
Backlighting
(Dynamic)
200
190
180
170
160
150
140
130
120
110
101
Lumin.
103
96
84
73
64
57
51
44
38
33
29
Power
Consumption
(Watts)
74
73
69.5
65.5
62
60
57.5
55
52.5
50.5
49
Power
Savings
Rating
28.85 %
29.81 %
33.17 %
37.02 %
40.38 %
42.31 %
44.71 %
47.12 %
49.52 %
51.44 %
52.88 %
Power
Consumption
(Watts)
91.5
85.5
80
74.8
70.8
67.5
63.5
59.3
56.5
54.5
52.8
Power
Savings
Rating
39.60 %
43.56 %
47.19 %
50.63 %
53.27 %
55.45 %
58.09 %
60.86 %
62.71 %
64.03 %
65.15 %
Power
Consumption
(Watts)
109
103
96.4
89.7
84.5
80.2
75.2
69.9
66.1
63.5
61.4
Power
Savings
Rating
41.08 %
44.32 %
47.89 %
51.51 %
54.32 %
56.65 %
59.35 %
62.22 %
64.27 %
65.68 %
66.81 %
Note: Values are results of controlled experiments under laboratory conditions.
For 37LG710H
Lumin.
258
230
201
170
145
120
95
72
54
41
31
Power
Consumption
(Watts)
151.5
136.5
122.5
111
101.3
91.5
81.3
71
63.5
58
53
Power
Savings
Rating
0%
9.90 %
19.14 %
26.73 %
33.14 %
39.60 %
46.34 %
53.14 %
58.09 %
61.72 %
65.02 %
Item 099
Backlighting
(Dynamic)
200
190
180
170
160
150
140
130
120
110
101
Lumin.
93
79
67
58
50
44.5
38
31.5
27
23.5
21
Note: Values are results of controlled experiments under laboratory conditions.
For 42LG710H
Item 099
Backlighting
(Static)
100
90
80
70
60
50
40
30
20
10
1
Lumin.
286
250
216
185.5
159
133.5
107.5
81
61
46.5
35
Power
Consumption
(Watts)
185
164.5
147.5
133.5
121.3
109.5
97
84
75
67.5
61.5
Power
Savings
Rating
0%
11.08 %
20.27 %
27.84 %
34.43 %
40.81 %
47.57 %
54.59 %
59.46 %
63.51 %
66.76 %
Item 099
Backlighting
(Dynamic)
200
190
180
170
160
150
140
130
120
110
101
Lumin.
113
108
96
83
73.8
65.2
55.8
46.13
39.6
34.4
29.85
Note: Values are results of controlled experiments under laboratory conditions.
COMMERCIAL MODE SETUP
Item 099
Backlighting
(Static)
100
90
80
70
60
50
40
30
20
10
1
115
COMMERCIAL MODE SETUP
For 32LD650H, 32LD655H
Item 099
Backlighting
(Static)
100
90
80
70
60
50
40
30
20
10
1
Lumin.
290.2
258.2
220.2
189.1
166.6
145.2
126.4
108.2
90.2
72.1
57.5
Power
Consumption
(Watts)
96.1
90.9
84.8
80.2
75.5
69.1
63.9
58.8
53.2
48.6
44.0
Power
Savings
Rating
0%
94.59 %
88.24 %
83.45 %
78.56 %
71.90 %
66.49 %
61.19 %
55.36 %
50.57 %
45.79 %
Item 099
Backlighting
(Dynamic)
202
200
190
180
170
160
150
140
130
120
110
Lumin.
105.1
85.5
80.0
75.7
70.6
67.1
63.2
60.0
56.6
52.5
49.2
Power
Consumption
(Watts)
56.1
51.5
50.5
49.7
48.6
48.0
47.1
46.3
45.7
44.7
44.1
Power
Savings
Rating
58.38 %
53.59 %
52.55 %
51.72 %
50.57 %
49.95 %
49.01 %
48.18 %
47.55 %
46.51 %
45.89 %
Power
Consumption
(Watts)
82.7
72.1
70.1
67.7
65.3
63.0
61.5
59.0
56.4
54.1
51.8
Power
Savings
Rating
72.93 %
63.58 %
61.82 %
59.70 %
57.58 %
55.56 %
54.06 %
52.03 %
49.74 %
47.71 %
45.68 %
Power
Consumption
(Watts)
98.2
85.8
82.8
79.7
76.6
73.6
71.2
68.2
65.2
62.1
59.8
Power
Savings
Rating
68.15 %
59.54 %
57.46 %
55.31 %
53.16 %
51.08 %
49.41 %
47.33 %
45.25 %
43.10 %
41.50 %
Note: Values are results of controlled experiments under laboratory conditions.
For 37LD650H, 37LD655H
COMMERCIAL MODE SETUP
Item 099
Backlighting
(Static)
100
90
80
70
60
50
40
30
20
10
1
Lumin.
193.5
178.5
163.1
149.0
134.6
118.9
104.1
89.1
72.6
57.1
41.5
Power
Consumption
(Watts)
113.4
106.5
100.1
93.8
88.0
81.5
75.2
69.2
62.5
56.1
49.7
Power
Savings
Rating
0%
93.92 %
88.27 %
82.72 %
77.60 %
71.87 %
66.31 %
61.02 %
55.11 %
49.47 %
43.83 %
Item 099
Backlighting
(Dynamic)
202
200
190
180
170
160
150
140
130
120
110
Lumin.
116.4
94.1
88.6
83.1
77.5
71.9
67.1
61.4
55.8
50.2
44.3
Note: Values are results of controlled experiments under laboratory conditions.
For 42LD650H, 42LD655H
Item 099
Backlighting
(Static)
100
90
80
70
60
50
40
30
20
10
1
Lumin.
212.8
195.8
177.9
160.0
143.7
124.7
107.6
90.8
72.6
55.3
39.4
Power
Consumption
(Watts)
96.1
135.0
125.7
117.5
109.1
100.1
91.8
83.4
74.2
65.7
57.5
Power
Savings
Rating
0%
93.68 %
87.23 %
81.54 %
75.71 %
69.47 %
63.71 %
57.88 %
51.49 %
45.59 %
39.90 %
Item 099
Backlighting
(Dynamic)
202
200
190
180
170
160
150
140
130
120
110
Lumin.
109.8
90.1
84.2
78.6
72.5
66.6
62.2
56.3
50.7
45.1
39.5
Note: Values are results of controlled experiments under laboratory conditions.
116
TV CAMPORT AUTO SENSE OPERATION
The CAMPORT Auto Sense function is enabled when:
1. Installer Menu Item 34, CAMPORT EN is set to 1 AND
2. Installer Menu Item 40, AUTO CAMPORT is enabled (1).
Selectable= Can be accessed with INPUT key, direct access,
etc.
Auto Sense= Switches to this input when connector is inserted.
The camport (Side Video) has the highest priority and will
override any commands including tuning to the Start Channel.
CAMPORT (Front Video) Functionality Control
Item 34
Item 40
Front Video
CAMPORT EN
AUTO CAMPORT
Operation
0
0
Disabled
0
1
Disabled
1
0
Selectable
1
1
Auto Sense
CAMPORT Operation (Stand-Alone)
When Camport Auto Sense is enabled as above, the TV’s
source will switch to the side video aux source whenever a
plug is inserted into any of the side video panel inputs
(either composite Video or S-Video).
Previous State
Operation
Before Inserting While CAMPORT
CAMPORT
Is Active
Aux or RF Channel
None
When the plug is removed, the TV will switch back to the
previous channel or input source that the TV was using
before the plug was inserted. However, if any direct access
to an RF channel or Aux channel is requested while the camport is active, then, when the camport plug is removed, the
TV will switch to the last requested channel. Source changes
using any Source Keys (INPUT) are ignored. Channel
Up/Channel Down and Flashback Commands are not direct
access tuning commands and they are also ignored.
Aux or RF Channel
Direct Access
Aux or RF Channel
Ch Up/Down,
Flashback
and TV/AV Keys
State
Upon Removal
Of CAMPORT
Previous Aux
or RF Channel
Last Requested
RF or Aux Channel
Previous Aux
or RF Channel
CAMPORT Operation (PPV)
Previous State
Operation
Before Inserting While CAMPORT
CAMPORT
Is Active
Aux or RF Channel
None
State
Upon Removal
Of CAMPORT
Previous Aux
or RF Channel
Aux or RF Channel Direct Access
Last Requested RF
or Aux Channel
Aux or RF Channel Ch Up/Down,
Last Requested
Flashback
Channel if PPV
and TV/AV Keys
translates it to
direct access tuning
command. Otherwise,
goes to Previous Aux
or RF Channel
COMMERCIAL MODE SETUP
The operation will be similar to that of the StandAlone mode. However, the PPV providers may send different commands to the TV for the same user commands. For instance, some providers will always send a
direct tune command when it receives a channel
up/down or a flashback command while other PPV
providers will just send a key command.
117
COMMERCIAL MODE SETUP
FTG OPERATION SETUP
Communications Setup Menu
Sets up the communications link between the FTG Configuration
Application and the Z7 card installed in a TV/STB.
CHANNEL
AUDIO
TIME
OPTION
LOCK
INPUT
USB
Typical TV/STB Setup Menu
Shows that the Z7 card is in pass-through mode. This
menu can also be accessed by turning IR remote access
‘On’ in the FTG Configuration Application, while the TV/STB
is in FTG mode.
ASPECT RATIO
Move
Enter
Set By Program
ABC
4:3
16:9
COMMERCIAL MODE SETUP
Zoom
Just Scan
End User ‘Aspect Ratio’ or Function Menu
Shows that the Z7 card is in FTG mode. While this menu is
present on-screen, the only way the Installer menu can be
accessed is by the FTG Configuration Application.
Network Icon Selection Menu
Select channel icons like ABC, NBC etc., to add to the channel
OSDs to identify common networks for the end user.
118
FTG CHANNEL MAP OVERVIEW
LOGICAL CHANNEL NUMBERS
Channels appear in numerical order.
Select logical, Major and Minor numbers on menu.
CUSTOM CHANNEL LABELS/ICONS
Set custom labels and select icons on
menu.
SET CHANNEL ATTRIBUTES
Set encrypted, OSD on or off or
blank video only.
DELETE
Removes channel from lineup.
ADD
After inputting a new channel’s
data, press to add channel to list.
CHANNEL MAP EDITOR
Shows both channel data
and logical channel lineup.
COMMERCIAL MODE SETUP
EXIT
Exits menu and returns to logical
channel listing.
UPDATE
After editing a channel’s data, press
to include the changes in the channel list.
119
COMMERCIAL MODE SETUP
FTG INSTALLER MENU OVERVIEW
CONFIGURATION SETTINGS
Select tabs for Installer submneu
items to set up TV/STB.
COMMERCIAL MODE SETUP
INSTALLER DEFAULTS
Press to reset TV/STB to Installer
menu defaults.
IR REMOTE ACCESS
Toggle IR remote access to On to get access to
TV/STB feature menus or Installer menu.
WRITE
Press to transfer the FTG Installer menu
values to the FTG card and TV/STB.
READ
Press to transfer the Installer menu values on the FTG card to
the PC FTG Configuration Application.
120
HOSPITAL GRADE TV/STB ITEMS
Set hospital only items on Installer menu for
Hospital grade TV/STBs.
EXIT
Returns to logical channel
map menu.
LEARN
Press to transfer the
installer menu settings on
the TV/STB to the FTG card
and PC FTG Configuration
Application.
FTG OPERATION TROUBLESHOOTING
LMT7Z7 Configured Card in FTG Mode of Operation
Error Messages
Problem
Probable Cause
Solution
Cannot contact
target.
FTG application
already open.
Close extra FTG application on computer.
Cable(s) not
connected.
Check and connect communication cables.
TV off.
Turn TV on.
Wrong Communication port.
Select correct Comm port on computer.
TV AUX INPUT CONFIGURATION
ENABLE
DIRECT ACCESS
Tuning
TV
Installer Menu
OLD_OCV OLD_OCV=
Source Input Source Mode Number
=0
1
MPI DATA
MPI DATA
STATUS TYPE
0x41 SOURCES
ENABLED (R/W)
Labeling
Value
Labeling
Value
Labeling
Video Front
(Camport)
0
Video Front
(Camport)
90
Video2 (Side) CV/SVIDEO
34
CAMPORT_EN
0x01
131
91
Video1 (Rear) CV/SVIDEO
39
REAR_AUX_EN
0x02
DTV
91
YPrPb2 EN = 1
0x04
132
92
PC
91
YPrPb2 EN = 2
0x04
DTV
35
COMPPORT EN = 1 0x08
PC
35
COMPPORT EN = 2 0x08
PC
87
REAR RGB EN = 2
0x10
SVGA Rear
Computer
38
YPrPb EN
0x40
Y/UV
Component
93
HDMI2
HDMI1/DVI
134
94
RGB
136
96
Component
137
97
USB
121
USB Options
Rear Video
(Aux)
S-Video
Rear
S-Video
Rear
Front
Computer
Front
Computer
0x80 Y/C Front
Video
DATA
START AUX
STATUS
SOURCE
TYPE 0X0D
ASSIGNMENT
AUX SOURCE
(R)
0 (VIDE0)
2
Rear Video
0 (VIDE0)
(Aux)
S-Video
0 (VIDE0)
Rear
S-Video
2
Rear
(COMPUTER)
Front
0 (VIDE0)
Computer
Front
2
Computer (COMPUTER)
5
4
SVGA Rear
2
Computer (COMPUTER)
4
6
Rear
Y/PrPb
Componen
video
0 (VIDE0)
6
2 (Comp)
NA
1
2
2
3
3
6
Front t
S-Video
1
5
3
3
COMMERCIAL MODE SETUP
130
133
DATA STATUS
TYPE 0xD2
CURRENT AV
SOURCE (R)
121
COMMERCIAL MODE SETUP
B-LAN SETUP AND OVERVIEW
B-LAN Setup and Overview
Power to the B-LAN module is controlled by Installer Menu Item 118 Power savings. By default, value 003, the BLAN module is only powered on when the TV is powered on. There are two bits in the Power Savings item to control
power to the B-LAN module, one for power during TV Standby mode and one for power during TV Power On mode.
When the bit is 0, the B-LAN module is powered. When the bit is 1, the B-LAN module is not powered (Power
Savings is Enabled).
TV Standby State
TV Power On State
Power Saving
COMMERCIAL MODE SETUP
122
BLAN Power
MPI Slot Power
BLAN Power
MPI Slot Power
1
On
Standby
On
Main
3
Off
Standby
On
Main
7
Off
Standby
Off
Main
The B-LAN module is internal to the TV. It allows the Hotel/Institution headend equipment to communicate with the
TV for configuration and control. This communication is via the institution’s RF distribution system. The control
device at the headend (ex FMA-LG101) can control multiple TVs. When the TV is first installed, it must be powered
on in order for the headend to be able to communicate with the B-LAN. At this point, if it is desired for the BLAN
to always be powered on, particularly during Standby mode, the BLAN Standby Power Saving mode setting should be
downloaded as Disabled. The new settings will not be active until the BLAN actually downloads the configuration
data to the PTC and the PTC is reset.
If it known that the application requires only using the MPI card slot and not the embedded BLAN, the installer can
go into the Installer Settings menu and enable the BLAN Power Savings mode, in both Standby and TV power on.
APPENDIX
TROUBLESHOOTING
Abnormal Operation
Check to see if there is any object between the product and the remote control
causing obstruction. Ensure you are pointing the remote control directly at the TV.
■ Ensure that the batteries are installed with correct polarity (+ to +, - to -).
■ Ensure that the correct remote operating mode is set: TV, VCR etc.
■ Install new batteries.
■
The remote control
doesn’t work
Power is suddenly
turned off
Is the sleep timer set?
■ Check the power control settings. Power interrupted.
■
Video Problems
Check whether the product is turned on.
■ Try another channel. The problem may be with the broadcast.
■ Is the power cord inserted into wall power outlet?
■ Check your antenna direction and/or location.
■ Test the wall power outlet, plug another product’s power cord into the outlet
where the product’s power cord was plugged in.
■
No picture &No sound
Picture appears slowly
after switching on
■
This is normal, the image is muted during the product startup process. Please
contact your service center, if the picture has not appeared after five minutes.
Adjust Color in menu option.
■ Try unplugging any others electronics that are near by to see if interference is
causing the problem.
■ Try another channel. The problem may be with the broadcast.
■ Are the video cables installed properly?
■ Activate any function to restore the brightness of the picture.
■
No or poor color
or poor picture
■
Check for local interference such as an electrical appliance or power tool.
Station or cable product experiencing problems, tune to another station.
■ Station signal is weak, reorient antenna.
■ Check for sources of possible interference.
■
Poor reception on
some channels
Lines or streaks
in pictures
No picture
when connecting HDMI
■
Check antenna (Change the direction of the antenna).
■
If the HDMI cables don’t support High Speed HDMI, it can cause flickers or no
screen display. In this case use the latest cables that support High Speed HDMI.
APPENDIX
Horizontal/vertical bars
or picture shaking
123
APPENDIX
Audio Problems
Press the VOL or VOLUME button.
■ Sound muted? Press the MUTE button.
■ Try another channel. The problem may be with the broadcast.
■ Are the audio cables installed properly?
■
Picture OK but No sound
No output from one
of the speakers
■
Adjust Balance in menu option.
■
A change in ambient humidity or temperature may result in an unusual noise
when the product is turned on or off and does not indicate a fault with the
product.
Unusual sound from
inside the product
No sound
when connecting HDMI
or USB
Check High Speed HDMI cable.
Check USB cable over version 2.0.
■ Use normal MP3 file.
■
■
*This feature is not available for all models.
P C Mode Problems
The signal is out of range
Vertical bar or stripe on
background &
Horizontal Noise &
Incorrect position
Screen color is unstable
or single color
■
Adjust resolution, horizontal frequency, or vertical frequency.
Check the input source.
■
Work the Auto configure or adjust clock, phase, or H/V position. (Option)
■
Check the signal cable.
Update video card drivers.
■
■
APPENDIX
Power
No Power
■
See troubleshooting flow chart.
■
Adjust Installer menu settings as required.
■
After 2-5-5 + MENU, only channels included in TV controller will appear. If channel is available it can be added to channel scan, rescan channels. If it is not available, the ‘No Signal’ message appears on the TV screen.
Erratic Operation
Installer menu setup
Software Problems
Cannot direct enter channel number or “No Signal”
appears
! NOTE
G
124
For other problems not caused by the TV, refer to other devices’ operating guides.
REFERENCE: LT2002 CLONING PROCEDURE
TROUBLESHOOTING
Warning: Do not use the LT2002 while any PPV card
is installed in the TV or the clone programmer will be
damaged.
Reset Clone After Static Shock
After replacing exhausted batteries, or if the programmer behaves strangely after a static shock, use a paper
clip or similar instrument inserted through the small
hole marked ”RESET” to activate the internal reset
switch and restore normal operation. After a reset,
check the real-time clock setting. It may be necessary
to reset the Clone Programmer clock from a TV containing the correct time.
Note
The LT2002 programmer is designed to be used with
TVs containing the 221-01006 and later processors.
Use with earlier TV sets may give unpredictable results.
Processors used before the 221-01006-04 have a limited screen display capability. They cannot display
entire screens as shown in the quick setup instructions
accompanying the LT2002 clone programmer. Use the
printed menu illustrations on the quick setup sheet
supplied with the Clone as an aid to making your programming choices. (Although the menus are not all displayed, the clone functions all operate normally.)
Clone Programmer Troubleshooting
Clone Programmer
Press Reset on clone programmer, redo teach/learn. (Teach/Learn should take a
minimum of 1 minute.)
Clone copies Setup in less
than 30 seconds
■
Remote32LG3DC
does not operate
clone
(32LG3DC-UA)
32LG3DCH
■ Only
use an LG Installer remote to operate the clone programmer with the TV.
(32LG3DCH-UA)
Connect the M.P.I. cord properly, assure a good connection.
TV must be powered On for the clone to work.
■ Install 4 fresh AA high-quality alkaline batteries.
■
■
Clone menu hard to read
■
Connect the TV to a reliable Analog channel signal source.
No time set
■
Set the time on a TV and then copy the time to the Clone Programmer.
■
■
Try a different LT2002 Clone programmer.
Reset the Clone Programmer.
■
Retry cloning again.
Clone not working
Clone Scans Channels
more than once
Master and Other TVs
APPENDIX
LED does not blink
Wait until procedure complete message is displayed.
■ Cloning is only possible with identical model TVs.
■ Reread cloning pages to be sure all tasks were performed.
32LG3DCH
■
Cloning did not work
32LG3DC
(32LG3DC-UA)
Clone time disappeared
New Setup not present
■
■
(32LG3DCH-UA)
■
Batteries must remain installed to retain time settings.
■
Disconnect newly-cloned TV from power for 5 seconds.
After cloning operations are complete, just unplug the LT2002 from the TV.
If the TV does not display a picture on the TV (blank screen) after a few seconds, just change channels.
125
APPENDIX
TROUBLESHOOTING FLOW CHART
Controller
Quick
Check
Is
'STATUS'
LED on
Analog Board
Blinking
?
No
Yes
Is
TV
Connected to
AC Power
?
No
Plug
into AC
Power Outlet
Press 'POWER' or 'ON/OFF'
key on TV
Yes
Defective
TV
Did
TV Turn
On
?
No
1. Defective TV
Yes
Is
Red LED
on TV
Lit
?
No
Press 'POWER' or 'ON/OFF'
or 'VOLUME UP/DOWN' or
'MUTE' key on Installer
Remote
1. Defective Analog Board.
2. Defective Digital Board.
Yes
Did
TV
Respond
?
Cycle the power by removing
and re-connecting the AC
power cord. Observe the
'POWER' LED and TV screen
as soon as AC power is
re-applied.
Did
Analog
Board 'POWER'
LED Turn On
Momentarily
?
Press 'POWER' or 'ON/OFF'
or 'VOLUME UP/DOWN'
or 'MUTE' key on
User-Supplied Remote
No
Defective
TV
APPENDIX
Did
TV
Respond
?
Yes
No
Check to see if TV
is in Commercial Mode.
See Commercial Mode
Check chart.
Yes
End
126
1. Defective TV
2. Go to Remote
Control Checklist
Yes
Yes
Did TV
Turn On
Momentarily
?
No
No
1. Defective PPV Card
2. Go to Remote
Control Checklist
COMMERCIAL MODE CHECK
RJP Model List
Press the "On/Off" key
on the front panel.
The On/Off key is always operational.
Did
you get
a response
?
REFERENCE: RJP MODEL LIST
AND INPUT HIERARCHY
No
Defective TV
Yes
Leave
the
TV set On
Go to Installer menu
by pressing "MENU" until
the TV stops responding.
Legacy Models
Scaler Models
RJP-101M
Not Support PCB
RJP-101ML
Not Support PCB
RJP-110F
RJP-210F
RJP-110FW
RJP-210FW
RJP-110W
RJP-210W
RJP-110WBR
RJP-210WBR
RJP-110S
RJP-210S
RJP-120G
RJP-220G
RJP-120T
RJP-220T
RJP-201B
RJP-301B
RJP-202B
RJP-302B
RJP Input Hierarchy
Did
TV stop
responding
or continue
to respond
?
Stopped
responding
Continued
to
respond
TV is in
Commercial
Mode.
Priority
Video
Audio
1st. (Highest)
HDMI/DVI
3.5mm Mini Jack
2nd.
RGB
L/R Audio In
3rd.
Composite
HDMI/DVI
4th. (Lowest)
TV (RF of Aux)
TV (RF or Aux)
TV is not in Commercial Mode
Call Technical Support for
Assistance
APPENDIX
127
APPENDIX
GLOSSARY OF TERMS
A list of definitions for some of the words found in this guide
75 OHM RF CABLE
The wire that comes from an off-air
antenna or cable service provider. The
end looks like a hex-shaped nut with a
wire sticking through the middle. It
screws onto the Antenna/Cable threaded jack on the back of the TV.
300 TO 75 OHM ADAPTER
A small device that connects a
two-wire 300 ohm antenna to a 75
ohm RF jack. They are usually about an
inch long with two screws on one end
and a round opening with a wire sticking
out on the other end.
ANALOG TELEVISION
Standard television broadcasting format
in 4:3 picture aspect ratio.
A/V CABLES
Audio/Video cables. Three cables
bunched together—right audio (red),
left audio (white), and video (yellow).
A/V cables are used for stereo playback of videocassettes and other A/V
devices.
A/V DEVICE
Any device that produces video or
sound (VCR, DVD, cable box, or television).
APPENDIX
AMPLIFIER
An electronic device that amplifies
sound from a television, CD player, VCR,
DVD, or other Audio/Video device.
ANTENNA
The physical receiver of television signals
sent over the air. A large metal piece of
equipment does not always have to be
visible to be using an antenna.
CABLE
Cable service box. Refers to the
descrambler box cable subscribers use
to receive cable programming signals.
CABLE TELEVISION
Programming provided by a cable service.
128
DIGITAL TELEVISION
Televisions signals that are transmitted
digitally.
DVI
Digital Video Interface
Accommodates analog and digital interfaces with a single connector.
COMPOSITE VIDEO
Typical video jack, uses one wire for
transporting three-color video signals.
COMPONENT VIDEO
Uses three wires for transporting threecolor video signals. Supports higher
quality video.
DELETED
Lets you remove channels from the list
that the end user can scroll through
using CH (Channel) Up/Down.
HDMI
High-definition multi-media interface.
HDTV
High-definition television. Refers to television signals that have higher resolution
than ordinary analog TV signals.
HDSTB
High-definition set top box. Refers to a
tuner device that receives high-definition television signals which have higher
resolution than ordinary analog TV signals.
INPUT
Refers to the input jack that receives a
signal from a TV, VCR, DVD Player or
other Audio/Video device.
JACK
An input or output connector on the
back of a TV, VCR, DVD Player or
other Audio/Video device.
MONO SOUND
Mono (monaural) sound is one channel
of sound. On more than one speaker, all
the speakers play the same audio.
OUTPUT
Refers to the output jack that sends a
signal out of a VCR, DVD, or other A/V
device.
PHYSICAL CHANNEL NUMBER
The actual channel number. Analog
channels use the physical channel number and digital channels can use a virtual
channel number.
RGB (Red, Green, Blue)
Connection input or output port available for producing a video image using
three separate colors: Red, Green, and
Blue.
RS-232
Serial communication port through
which firmware is downloaded.
2ND AUDIO PROGRAMMING/SAP
Second Audio Programming (SAP) is
another, separate audio channel available
with some programming. Choosing SAP
often refers to listening to audio in
another language, such as Spanish or
French.
SIGNAL
Picture and sound traveling through a
cable, or over the air, to the TV.
STEREO SOUND
Stereo (Stereophonic) sound refers to
audio that’s divided into right and left
sides.
TUNER
Device that picks up the broadcast signal and turns it into picture and sound.
VIRTUAL CHANNEL NUMBER
A re-mapped channel number. Analog
channels use the actual channel number,
but digital channels use a virtual(or
fake) channel number.
XDS
Extended Data Service: Additional program information included on the signal
provided at the discretion of the broadcaster.
MAINTENANCE
Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you can
enjoy your new TV.
Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning.
Cleaning the Screen
1
Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in a mixture of lukewarm water and a
little fabric softener or dish washing detergent. Wring the cloth until it’s almost dry, and then use it to wipe the screen.
2
Make sure the excess water is off the screen, and then let it air-dry before you turn on your TV.
! WARNING
G
Do not use window/glass cleaner or anything with ammonia to clean the screen.
Cleaning the Cabinet
■
■
To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth.
Please be sure not to use a wet cloth.
Extended Absence
CAUTION
G
If you expect to leave your TV dormant for a long time (such as a vacation), it’s a good idea to unplug
the power cord to protect against possible damage from lightning or power surges.
APPENDIX
129
APPENDIX
PRODUCT SPECIFICATIONS
MODELS
37LG710H
(37LG710H-UA)
42LG710H
(42LG710H-UA)
797 x 597 x 232.5 mm
31.3 x 23.5 x 9.15 inch
918.6 x 684.8 x 293.4 mm
36.1 x 26.9 x 11.5 inch
1026.2 x 734.1 x 293.4 mm
40.4 x 28.9 x 11.5 inch
Dimensions
(Width
x Height
x Depth)
With stand
Without stand
797 x 558.7 x 109.3 mm
31.3 x 21.9 x 4.3 inch
918.6 x 635.8 x 111.7 mm
36.1 x 25.0 x 4.39 inch
1026.2 x 687.9 x 111.8 mm
40.4 x 27.0 x 4.4 inch
Weight
With stand
Without stand
12.89 kg / 28.41 lbs
11.41 kg / 25.15 lbs
17.97 kg / 39.61 lbs
15.41 kg / 33.97 lbs
21.10 kg / 46.51 lbs
18.48 kg / 40.74 lbs
Cable Card
MPI card
3.1 x 0.9 x 6.3 inch
(Width x Height x Depth) 80.0(+0.6/-0.2) x less than 23.0(including pcb thickness) x less than 162.0(excluding cover thickness) mm
Card Bracket Cover
(Width x Height )
Power requirement
Television System
Program Coverage
External Antenna Impedance
Environment
condition
■
APPENDIX
130
32LG710H
(32LG710H-UA)
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
3.7 x 1.1 inch
94.7(±0.5) x 28.3(±0.5) mm
AC100-240V ~ 50/60Hz
NTSC-M, ATSC, 64 & 256 QAM
VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
75 ohm
32 ~ 104°F (0 ~ 40°C)
Less than 80%
-4 ~ 140°F (-20 ~ 60°C)
Less than 85%
The specifications shown above may be changed without prior notice for quality improvement.
MODELS
37LD650H (37LD650H-UA)
37LD655H (37LD655H-UA)
Dimensions
(Width x Height
x Depth)
With stand
797.0 mm x 557.7 mm x 207.0 mm
(31.3 inch x 21.9 inch x 8.1 inch)
916.0 mm x 626.0 mm x 261.0 mm
(36.0 inch x 24.6 inch x 10.2 inch)
Without stand
797.0 x 495.0 x 97.1 mm
(31.3 inch x 19.4 inch x 3.8 inch)
916.0 mm x 560.0 mm x 88.9 mm
(36.0 inch x 22.0 inch x 3.5 inch)
Weight
With stand
Without stand
11.1 kg (24.4 lbs)
9.4 kg (20.7 lbs)
14.6 kg (32.1 lbs)
12.0 kg (26.4 lbs)
42LD650H (42LD650H-UA)
42LD655H (42LD655H-UA)
47LD650H
(47LD650H-UA)
1024.0 mm x 686.6 mm x 261.0 mm
(40.3 inch x 27.0 inch x 10.2 inch)
1137.0 mm x 758.0 mm x 270.0 mm
(44.7 inch x 29.8 inch x 10.6 inch)
MODELS
Dimensions
(Width x Height
x Depth)
With stand
Without stand
1024.0 mm x 621.0 mm x 87.1 mm
(40.3 inch x 24.4 inch x 3.4 inch)
1137.0 mm x 685.0 mm x 76.8 mm
(44.7 inch x 26.9 inch x 3.0 inch)
Weight
With stand
Without stand
17.7 kg (39.0 lbs)
15.1 kg (33.2 lbs)
20.3 kg (44.7 lbs)
18.3 kg (40.3 lbs)
MODELS
55LD650H
(55LD650H-UA)
Dimensions
(Width x Height
x Depth)
With stand
1329.0 mm x 872.0 mm x 330.0 mm
(52.3 inch x 34.3inch x 12.9 inch)
Without stand
1329.0 mm x 796.0 mm x 96.5 mm
(52.3 inch x 31.3 inch x 3.7 inch)
Weight
With stand
Without stand
33.0 kg (72.7lbs)
29.8 kg (65.6 lbs)
Environment
condition
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
AC100-240V ~ 50/60Hz
NTSC-M, ATSC, 64 & 256 QAM
VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
75 ohm
APPENDIX
Power requirement
Television System
Program Coverage
External Antenna Impedance
■
32LD650H (32LD650H-UA)
32LD655H (32LD655H-UA)
32 ~ 104°F (0 ~ 40°C)
Less than 80%
-4 ~ 140°F (-20 ~ 60°C)
Less than 85%
The specifications shown above may be changed without prior notice for quality improvement.
131
APPENDIX
PROGRAMMING THE REMOTE CONTROL
The provided universal remote control can be programmed to operate most remote-controllable devices.
Note that the remote may not control all models of other brands.
Programming a code into a remote mode
APPENDIX
132
1
Testing your remote control.
To find out whether your remote control can operate other components without programming, turn on a
component such as a STB(Set-Top Box) and press the corresponding mode button (such as a S T B) on the
remote control, while pointing at the component. Test the P O W E R and C H
buttons to see if the component responds correctly. If the component does not operate correctly, the remote control requires programming to operate the device.
2
Turn on the component to be programmed, then press the corresponding mode button (such as S T B) on
the remote control. The remote control button of the desired device is illuminated.
3
Press the M E N U and M U T E buttons simultaneously, and the remote control is ready to be programmed with
the code.
4
Enter a code number using the number buttons on the remote control. Programming code numbers for the
corresponding component can be found on the following pages. If the code is correct, the device will turn
off.
5
Press the M E N U button to store the code.
6
Test the remote control functions to see if the component responds correctly. If not, repeat from step 2.
Remote Control Code
VCR
Brand
AIWA
AKAI
Codes
Codes
Brand
MAGNAVOX
031
067
012
069
101
027
031
003
033
101
045
013
013
049
151
034
024
012
048
043
053
066
133
SAMSUNG
043 046 124
146
MARANTZ
033
023
037
031
103
039 043
129
033
MARTA
MATSUI
MEI
MEMOREX
040
033
007
108
116
135
041
010 064
110 111
117 119
MGA
MINOLTA
MITSUBISHI
023 039 043
053
017
031
037
131
008
025
034
046
138
009
027
035
101
153
010
033
109
136
012
018
063
033
033
013
066
063 072
144 147
031
050
150
034
048
012
106
033 043
055 060
152
039 043
045
026 034
137 150
015 033
101
MTC
MULTITECH
NEC
NORDMENDE
OPTONICA
PANASONIC
PENTAX
PHILCO
PHILIPS
PILOT
PIONEER
PORTLAND
PULSAR
QUARTZ
QUASAR
RCA
REALISTIC
013 020
114 123
009 013 014
034 101 106
RICO
RUNCO
SALORA
013
063
031
031
067
101
013
108
072
011
033
013
040
107
145
003
031
053
058
148
014
033 034 041
068
031 033 067
030
033
010
034
102
046
020
020
051
014 031
053 072
134 139
059
045 046
059 061
040
034
023 039 043
054
070 074 083
140 145
020 031 033
034 067
033 034 054
071 101
021 048
014
066
020
041
109
147
008
033
054
075
033
062
140
145
034
063
144
010 014
034 040
101
Codes
032
105
113
125
SANSUI
022
SANYO
003
102
SCOTT
017
131
SEARS
003
013
031
101
SHARP
031
SHINTOM
024
SONY
003
056
077
SOUNDESIGN
034
STS
013
SYLVANIA
031
067
SYMPHONIC
034
TANDY
010
TATUNG
039
TEAC
034
TECHNICS
031
TEKNIKA
019
101
THOMAS
034
TMK
006
TOSHIBA
008
059
TOTEVISION
040
UNITECH
040
VECTOR RESEARCH 012
VICTOR
048
VIDEO CONCEPTS 012
VIDEOSONIC
040
WARDS
003
031
053
YAMAHA
012
ZENITH
034
058
040 102 104
107 109 112
115 120 122
043 048 135
007 010 014
134
037 112 129
008 009 010
014 017 020
042 073 081
054 149
009 031 052
057 058 076
078 149
033 034 059
034
043
039 043
033 070
031 033 034
013 042 047
082 112 131
101
APPENDIX
034
016
125
AMPRO
072
ANAM
031
AUDIO DYNAMICS 012
BROKSONIC
035
CANON
028
CAPEHART
108
CRAIG
003
CURTIS MATHES 031
DAEWOO
005
065
112
DAYTRON
108
DBX
012
DYNATECH
034
ELECTROHOME 059
EMERSON
006
029
036
129
FISHER
003
FUNAI
034
GE
031
107
GO VIDEO
132
HARMAN KARDON
HITACHI
004
043
INSTANTREPLAY 031
JCL
031
JCPENNY
012
040
JENSEN
043
JVC
012
048
130
KENWOOD
014
047
LG (GOLDSTAR) 001
101
LLOYD
034
LXI
003
017
MAGIN
040
Brand
034 046
013
033
054
034
048
072
017
034
131
039
056
080
024
040
043
101
133
APPENDIX
HDSTB
Brand
Codes
ALPHASTAR DSR 123
AMPLICA
050
ASTRO PHILIPS(ML) 159
ASTROTHOMPSON(ML)160
ASTRO NOKIA(ML) 161
BIRDVIEW
051
CHANNEL MASTER 013
036
CHAPARRAL
008
CITOH
054
CURTIS MATHES 050
DRAKE
005
011
141
DX ANTENNA
024
ECHOSTAR
038
093
097
122
ELECTRO HOME 089
EUROPLUS
114
FUJITSU
017
133
GENERAL INSTRUMENT 003
031
HITACHI
139
HOUSTON TRACKER 033
057
Brand
126 129
014 015 018
055
009 012 077
145
006 007 010
052 112 116
046
040
094
098
056
057
095
099
076
058
096
100
021
134
004
059
140
037
104
022 027
016 029
101
039 051
Codes
HUGHES
HUMAX(SL)
JANIEL
JERROLD
KATHREIN
LEGEND
LG
LUTRON
LUXOR
MACOM
068
158
060
061
108
057
001
132
062
010
065
MEMOREX
057
NEXTWAVE
028
NORSAT
069
PACE SKY SATELLITE 143
PANASONIC
060
PANSAT
121
PERSONAL CABLE 117
PHILIPS
071
PICO
105
PRESIDENT
019
PRIMESTAR
030
PROSAT
072
PSI(TH)
157
RCA
066
REALISTIC
043
SAMSUNG
123
147
144
059 063 064
124 125
070
142
102
110 111
Brand
Codes
SATELLITE SERVICE CO 028
085
SCIENTIFIC ATLANTA 032
SKY LIFE
150
SONY
103
STARCAST
041
SUPER GUIDE
020
SAMART(TH)
156
TEECOM
023
088
137
TOSHIBA
002
TRUE VISION(TH) 155
UNIDEN
016
044
078
101
UBC(TH)
153
UBC/SAMART(TH) 154
VIEWSTAR
115
VTC(VN)
162
WINEGARD
128
ZENITH
081
091
035 047 057
138
124 125
026 075 087
090 107 130
127
025 042 043
045 048 049
079 080 086
135 136
146
082 083 084
120
106
074
DVD
APPENDIX
134
Brand
Codes
Brand
Codes
Brand
Codes
APEX DIGITAL
DENON
GE
HARMAN KARDON
JVC
LG
MAGNAVOX
MARANTZ
022
020 014
005 006
027
012
001 010 016 025
013
024
MITSUBISHI
NAD
ONKYO
PANASONIC
PHILIPS
PIONEER
PROCEED
PROSCAN
002
023
008
003
013
004
021
005
RCA
SAMSUNG
SONY
THOMPSON
TOSHIBA
YAMAHA
ZENITH
005
011
007
005
019
009
010
017
009
026
006
006
015
006
008
018
016 025
IR CODES
1. How to Connect
■
Connect your wired remote control to the Remote Control port on the TV.
2. Remote Control IR Codes
■
Output waveform
Single pulse, modulated with 37.917KHz signal at 455KHz
Tc
Carrier frequency
FCAR = 1/TC = fOSC/12
Duty ratio = T1/TC = 1/3
T1
■
Configuration of frame
1st frame
Lead code
Low custom code
High custom code
Data code
Data code
C0 C1 C2 C3 C4 C5 C6 C7 C0 C1 C2 C3 C4 C5 C6 C7 D0 D1 D2 D3 D4 D5 D6 D7 D0 D1 D2 D3 D4 D5 D6 D7
Repeat frame
Repeat code
■
Tf
Lead code
9 ms
4.5 ms
■
Repeat code
0.55 ms
■
2.25 ms
Bit description
Bit ”0”
Bit ”1”
0.56 ms
0.56 ms
2.24 ms
1.12 ms
■
APPENDIX
9 ms
Frame interval: Tf
The waveform is transmitted as long as a key is depressed.
Tf
Tf
Tf=108ms @455KHz
135
APPENDIX
APPENDIX
136
(Hexa)
Code
Function
Note
08
POWER
Remote control Button (Power On/Off) D6
0F
TV
Remote control Button
0B
INPUT
Remote control Button
0A
SAP
Remote control Button
79
FF RATIO
Remote control Button
AB
GUIDE
Remote control Button
OC
PORTAL
Remote control Button
AA
INFO
Remote control Button
10-19
Number Key 0-9
Remote control Button
4C
- (Dash)
Remote control Button
1A
FLASHBK
Remote control Button
02
VOL +
Remote control Button
03
VOL -
Remote control Button
00
CH
Remote control Button
01
CH
Remote control Button
0E
GG TIMER
Remote control Button
39
CC
Remote control Button
09
MUTE
Remote control Button
43
MENU
Remote control Button
5B
RETURN
Remote control Button
40
Remote control Button
41
Remote control Button
07
Remote control Button
06
Remote control Button
44
ENTER
Remote control Button
60
PIP
Remote control Button
71
PIP CH +
Remote control Button
72
PIP CH-
Remote control Button
63
PIP SWAP
Remote control Button
61
PIP INPUT
Remote control Button
C1
A Stop
Remote control Button
C0
G Play
Remote control Button
C2
l l Pause
Remote control Button
C3
Ô (Record)
Remote control Button
Code
Function
Note
TV
Discrete IR Code
(TV Input Selection)
5A
AV1
Discrete IR Code
(AV1 Input Selection)
D0
AV2
Discrete IR Code
(AV2 Input Selection)
BF
COMPONENT
Discrete IR Code
(COMPONENT Input Selection)
D5
RGB-PC
Discrete IR Code
(RGB Input Selection)
CE
HDMI1
Discrete IR Code
(HDMI1 Input Selection)
CC
HDMI2
Discrete IR Code
(HDMI2 Input Selection)
76
Ratio 4:3
Discrete IR Code
(Only 4:3 Mode)
77
Ratio 16:9
Discrete IR Code
(Only 16:9 Mode)
AF
Ratio Zoom
Discrete IR Code
(Only Zoom Mode)
C4
POWER ON
Discrete IR Code
(Only Power On)
C5
POWER OFF
Discrete IR Code
(Only Power Off)
(Hexa)
OPEN SOURCE LICENSE
GNU GENERAL PUBLIC LICENSE
Version 2, June 1991
Copyright (C) 1989, 1991 Free Software Foundation, Inc., 51
Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA
Everyone is permitted to copy and distribute verbatim copies of
this license document, but changing it is not allowed.
the program proprietary. To prevent this, we have made it clear
that any patent must be licensed for everyone's free use or not
licensed at all.
The precise terms and conditions for copying, distribution and
modification follow.
Preamble
The licenses for most software are designed to take away your
freedom to share and change it. By contrast, the GNU General
Public License is intended to guarantee your freedom to share
and change free software - to make sure the software is free for
all its users. This General Public License applies to most of the
Free Software Foundation's software and to any other program
whose authors commit to using it. (Some other free software
foundation software is covered by the GNU Lesser General Public
License instead.) You can apply it to your programs, too.
When we speak of free software, we are referring to freedom, not
price. Our General Public Licenses are designed to make sure that
you have the freedom to distribute copies of free software (and
charge for this service if you wish), that you receive source code
or can get it if you want it, that you can change the software or
use pieces of it in new free programs; and that you know you can
do these things.
To protect your rights, we need to make restrictions that forbid
anyone to deny you these rights or to ask you to surrender the
rights. These restrictions translate to certain responsibilities for
you if you distribute copies of the software, or if you modify it.
We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives you legal permission to copy, distribute and/or modify the software.
0. This license applies to any program or other work which contains a notice placed by the copyright holder saying it may be
distributed under the terms of this General Public License. The
"Program", below, refers to any such program or work, and a
"work based on the Program" means either the Program or any
derivative work under copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with
modifications and/or translated into another language.
(Hereinafter, translation is included without limitation in the
term "modification".) Each licensee is addressed as "you".
Activities other than copying, distribution and modification
are not covered by this license; they are outside its scope.
The act of running the Program is not restricted, and the output from the program is covered only if its contents constitute
a work based on the program (independent of having been
made by running the program). Whether that is true depends
on what the program does.
1. You may copy and distribute verbatim copies of the program's
source code as you receive it, in any medium, provided that
you conspicuously and appropriately publish on each copy an
appropriate copyright notice and disclaimer of warranty; keep
intact all the notices that refer to this license and to the
absence of any warranty; and give any other recipients of the
program a copy of this license along with the Program.
You may charge a fee for the physical act of transferring a
copy, and you may at your option offer warranty protection in
exchange for a fee.
Also, for each author's protection and ours, we want to make certain that everyone understands that there is no warranty for this
free software. If the software is modified by someone else and
passed on, we want its recipients to know that what they have is
not the original, so that any problems introduced by others will
not reflect on the original authors' reputations.
2. You may modify your copy or copies of the program or any
portion of it, thus forming a work based on the Program, and
copy and distribute such modifications or work under the
terms of section 1 above, provided that you also meet all of
these conditions:
Finally, any free program is threatened constantly by software
patents. We wish to avoid the danger that redistributors of a free
program will individually obtain patent licenses, in effect making
a) You must cause the modified files to carry prominent
notices stating that you changed the files and the date of
any change.
APPENDIX
For example, if you distribute copies of such a program, whether
gratis or for a fee, you must give the recipients all the rights that
you have. You must make sure that they, too, receive or can get
the source code. And you must show them these terms so they
know their rights.
GNU GENERAL PUBLIC LICENSE
TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION
AND MODIFICATION
137
APPENDIX
b) You must cause any work that you distribute or publish,
that in whole or in part contains or is derived from the
Program or any part there of, to be licensed as a whole at
no charge to all third parties under the terms of this
license.
c) If the modified program normally reads commands interactively when run, you must cause it, when started running
for such interactive use in the most ordinary way, to print
or display an announcement including an appropriate
copyright notice and a notice that there is no warranty (or
else, saying that you provide a warranty) and that users
may redistribute the program under these conditions, and
telling the user how to view a copy of this license.
(Exception: if the Program itself is interactive but does not
normally print such an announcement, your work based on
the Program is not required to print an announcement.)
These requirements apply to the modified work as a whole. If
identifiable sections of that work are not derived from the
Program, and can be reasonably considered independent and
separate works in themselves, then this license, and its terms,
do not apply to those sections when you distribute them as
separate works. But when you distribute the same sections as
part of a whole which is a work based on the Program, the distribution of the whole must be on the terms of this license,
whose permissions for other licensees extend to the entire
whole, and thus to each and every part regardless of who
wrote it.
Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the
intent is to exercise the right to control the distribution of
derivative or collective works based on the program.
In addition, mere aggregation of another work not based on
the program with the Program (or with a work based on the
program) on a volume of a storage or distribution medium
does not bring the other work under the scope of this license.
APPENDIX
138
3. You may copy and distribute the program (or a work based on
it, under section 2) in object code or executable form under
the terms of sections 1 and 2 above provided that you also
do one of the following:
a) Accompany it with the complete corresponding machinereadable source code, which must be distributed under the
terms of sections 1 and 2 above on a medium customarily
used for software interchange; or,
b) Accompany it with a written offer, valid for at least three
years, to give any third party, for a charge no more than
your cost of physically performing source distribution, a
complete machine-readable copy of the corresponding
source code, to be distributed under the terms of sections
1 and 2 above on a medium customarily used for software
interchange; or,
c) Accompany it with the information you received as to the
offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and
only if you received the program in object code or executable form with such an offer, in accord with Subsection
b above.)
The source code for a work means the preferred form of the
work for making modifications to it. For an executable work,
complete source code means all the source code for all modules it contains, plus any associated interface definition files,
plus the scripts used to control compilation and installation
of the executable. However, as a special exception, the source
code distributed need not include anything that is normally
distributed (in either source or binary form) with the major
components (compiler, kernel, and so on) of the operating
system on which the executable runs, unless that component
itself accompanies the executable.
If distribution of executable or object code is made by offering access to copy from a designated place, then offering
equivalent access to copy the source code from the same
place counts as distribution of the source code, even though
third parties are not compelled to copy the source along with
the object code.
4. You may not copy, modify, sublicense, or distribute the Program
except as expressly provided under this license. Any attempt
otherwise to copy, modify, sublicense or distribute the
Program is void, and will automatically terminate your rights
under this license. However, parties who have received copies,
or rights, from you under this license will not have their licenses terminated so long as such parties remain in full compliance.
5. You are not required to accept this license, since you have not
signed it. However, nothing else grants you permission to
modify or distribute the Program or its derivative works.
These actions are prohibited by law if you do not accept this
license. Therefore, by modifying or distributing the program
(or any work based on the program), you indicate your acceptance of this license to do so, and all its terms and conditions
for copying, distributing or modifying the program or works
based on it.
6. Each time you redistribute the program (or any work based on
the Program), the recipient automatically receives a license
from the original licensor to copy, distribute or modify the
Program subject to these terms and conditions. You may not
impose any further restrictions on the recipients' exercise of
the rights granted herein. You are not responsible for enforcing compliance by third parties to this license.
7. If, as a consequence of a court judgment or allegation of
patent infringement or for any other reason (not limited to
patent issues), conditions are imposed on you (whether by
court order, agreement or otherwise) that contradict the conditions of this license, they do not excuse you from the conditions of this license. If you cannot distribute so as to satisfy simultaneously your obligations under this license and any
other pertinent obligations, then as a consequence you may
not distribute the program at all. For example, if a patent
license would not permit royalty-free redistribution of the
program by all those who receive copies directly or indirectly
through you, then the only way you could satisfy both it and
this license would be to refrain entirely from distribution of
the program.
any later version published by the Free Software Foundation.
If the program does not specify a version number of this
license, you may choose any version ever published by the
Free Software Foundation.
10.If you wish to incorporate parts of the program into other free
programs whose distribution conditions are different, write to
the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free
Software Foundation; we sometimes make exceptions for this.
Our decision will be guided by the two goals of preserving the
free status of all derivatives of our free software and of promoting the sharing and reuse of software generally.
NO WARRANTY
If any portion of this section is held invalid or unenforceable
under any particular circumstance, the balance of the section
is intended to apply and the section as a whole is intended to
apply in other circumstances.
It is not the purpose of this section to induce you to infringe
any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of
protecting the integrity of the free software distribution system, which is implemented by public license practices. Many
people have made generous contributions to the wide range
of software distributed through that system in reliance on
consistent application of that system; it is up to the
author/donor to decide if he or she is willing to distribute
software through any other system and a licensee cannot
impose that choice.
This section is intended to make thoroughly clear what is
believed to be a consequence of the rest of this license.
12.IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR
AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER,
OR ANY OTHER PARTY WHO MAY MODIFY AND/OR
REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE, BE
LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA
OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE
PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS),
EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
APPENDIX
8. If the distribution and/or use of the program is restricted in
certain countries either by patents or by copyrighted interfaces, the original copyright holder who places the program
under this license may add an explicit geographical distribution
limitation excluding those countries, so that distribution is
permitted only in or among countries not thus excluded. In
such case, this license incorporates the limitation as if written
in the body of this license.
11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE,
THERE IS NO WARRANTY FOR THE PROGRAM, TO THE
EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN
OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS
IS" WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE
RISK AS TO THE QUALITY AND PERFORMANCE OF THE
PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE
DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY
SERVICING, REPAIR OR CORRECTION.
9. The Free Software Foundation may publish revised and/or
new versions of the General Public License from time to time.
Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns.
Each version is given a distinguishing version number. If the
program specifies a version number of this license which
applies to it and "any later version", you have the option of
following the terms and conditions either of that version or of
139
APPENDIX
END OF TERMS AND CONDITIONS
How to apply these terms to your new programs
If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to
make it free software which everyone can redistribute and change
under these terms.
To do so, attach the following notices to the program. It is safest
to attach them to the start of each source file to most effectively convey the exclusion of warranty; and each file should have at
least the "copyright" line and a pointer to where the full notice is
found.
one line to give the program's name and a brief idea of what it
does.
Copyright (C) <year> <name of author>
This program is free software; you can redistribute it and/or
modify it under the terms of the GNU General Public License as
published by the Free Software Foundation; either version 2 of
the license, or (at your option) any later version.
This program is distributed in the hope that it will be useful, but
WITHOUT ANY WARRANTY; without even the implied warranty
of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.
You should have received a copy of the GNU General Public
License along with this program; if not, write to the Free Software
Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA
02110-1301 USA.
APPENDIX
140
Also add information on how to contact you by electronic and
paper mail.
If the program is interactive, make it output a short notice like
this when it starts in an interactive mode:
Gnomovision version 69, Copyright (C) year name of author
Gnomovision comes with ABSOLUTELY NO WARRANTY; for
details type ‘show w’. This is free software, and you are welcome
to redistribute it under certain conditions; type ‘show c’ for
details.
The hypothetical commands ‘show w’ and ‘show c’ should show
the appropriate parts of the General Public License. Of course,
the commands you use may be called something other than
‘show w’ and ‘show c’; they could even be mouse-clicks or menu
items-whatever suits your program.
You should also get your employer (if you work as a programmer)
or your school, if any, to sign a “copyright disclaimer” for the program, if necessary. Here is a sample; alter the names:
Yoyodyne, Inc., hereby disclaims all copyright interest in the program ‘Gnomovision’ (which makes passes at compilers) written by
James Hacker.
signature of Ty Coon, 1 April 1989
Ty Coon, President of Vice
This General Public License does not permit incorporating your
program into proprietary programs. If your program is a subroutine library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to
do, use the GNU Lesser General Public License instead of this
license.
GNU LESSER GENERAL PUBLIC LICENSE
Version 2.1, February 1999
Copyright (C) 1991, 1999 Free Software Foundation, Inc. 51
Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA
Everyone is permitted to copy and distribute verbatim copies of
this license document, but changing it is not allowed.
[This is the first released version of the Lesser GPL. It also
counts as the successor of the GNU Library Public License, version 2, hence the version number 2.1.]
Preamble
The licenses for most software are designed to take away your
freedom to share and change it. By contrast, the GNU General
Public Licenses are intended to guarantee your freedom to share
and change free software - to make sure the software is free for
all its users.
This license, the Lesser General Public License, applies to some
specially designated software packages - typically libraries - of
the Free Software Foundation and other authors who decide to
use it. You can use it too, but we suggest you first think carefully about whether this license or the ordinary General Public
License is the better strategy to use in any particular case, based
on the explanations below.
When we speak of free software, we are referring to freedom of
use, not price. Our General Public Licenses are designed to make
sure that you have the freedom to distribute copies of free software (and charge for this service if you wish); that you receive
source code or can get it if you want it; that you can change the
software and use pieces of it in new free programs; and that you
are informed that you can do these things.
For example, if you distribute copies of the library, whether gratis
or for a fee, you must give the recipients all the rights that we
gave you. You must make sure that they, too, receive or can get
the source code. If you link other code with the library, you must
provide complete object files to the recipients, so that they can
relink them with the library after making changes to the library
and recompiling it. And you must show them these terms so they
know their rights.
We protect your rights with a two-step method: (1) we copyright
the library, and (2) we offer you this license, which gives you legal
permission to copy, distribute and/or modify the library.
Finally, software patents pose a constant threat to the existence
of any free program. We wish to make sure that a company cannot effectively restrict the users of a free program by obtaining a
restrictive license from a patent holder. Therefore, we insist that
any patent license obtained for a version of the library must be
consistent with the full freedom of use specified in this license.
Most GNU software, including some libraries, is covered by the
ordinary GNU General Public License. This license, the GNU
Lesser General Public License, applies to certain designated
libraries, and is quite different from the ordinary General Public
License. We use this license for certain libraries in order to permit linking those libraries into non-free programs.
When a program is linked with a library, whether statically or
using a shared library, the combination of the two is legally
speaking a combined work, a derivative of the original library. The
ordinary General Public License therefore permits such linking
only if the entire combination fits its criteria of freedom. The
Lesser General Public License permits more lax criteria for linking
other code with the library.
We call this license the "Lesser" General Public License because
it does Less to protect the user's freedom than the ordinary
General Public License. It also provides other free software developers Less of an advantage over competing non-free programs.
These disadvantages are the reason we use the ordinary General
Public License for many libraries. However, the Lesser license provides advantages in certain special circumstances.
For example, on rare occasions, there may be a special need to
encourage the widest possible use of a certain library, so that it
becomes a de-facto standard. To achieve this, non-free programs
must be allowed to use the library. A more frequent case is that
a free library does the same job as widely used non-free libraries.
In this case, there is little to gain by limiting the free library to free
software only, so we use the Lesser General Public License.
APPENDIX
To protect your rights, we need to make restrictions that forbid
distributors to deny you these rights or to ask you to surrender
these rights. These restrictions translate to certain responsibilities
for you if you distribute copies of the library or if you modify it.
To protect each distributor, we want to make it very clear that
there is no warranty for the free library. Also, if the library is modified by someone else and passed on, the recipients should know
that what they have is not the original version, so that the original author's reputation will not be affected by problems that
might be introduced by others.
In other cases, permission to use a particular library in non-free
programs enables a greater number of people to use a large body
of free software. For example, permission to use the GNU C
Library in non-free programs enables many more people to use
the whole GNU operating system, as well as its variant, the
GNU/Linux operating system.
141
APPENDIX
Although the Lesser General Public License is Less protective of
the users' freedom, it does ensure that the user of a program that
is linked with the Library has the freedom and the wherewithal to
run that program using a modified version of the Library.
each copy an appropriate copyright notice and disclaimer of
warranty; keep intact all the notices that refer to this license
and to the absence of any warranty; and distribute a copy of
this license along with the Library.
The precise terms and conditions for copying, distribution and
modification follow. Pay close attention to the difference between
a "work based on the library" and a "work that uses the library".
The former contains code derived from the library, whereas the
latter must be combined with the library in order to run.
You may charge a fee for the physical act of transferring a
copy, and you may at your option offer warranty protection in
exchange for a fee.
GNU LESSER GENERAL PUBLIC LICENSE
TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION
AND MODIFICATION
0. This license agreement applies to any software library or other
program which contains a notice placed by the copyright holder or other authorized party saying it may be distributed
under the terms of this Lesser General Public License (also
called “this license”). Each license is addressed as "you".
A “library” means a collection of software functions and/or
data prepared so as to be conveniently linked with application
programs (which use some of those functions and data) to
form executables.
The “Library”, below, refers to any such software library or work
which has been distributed under these terms. A “work based
on the Library” means either the Library or any derivative work
under copyright law: that is to say, a work containing the
library or a portion of it, either verbatim or with modifications
and/or translated straightforwardly into another language.
(Hereinafter, translation is included without limitation in the
term “modification”.)
APPENDIX
“Source code” for a work means the preferred form of the
work for making modifications to it. For a library, complete
source code means all the source code for all modules it contains, plus any associated interface definition files, plus the
scripts used to control compilation and installation of the
library.
Activities other than copying, distribution and modification
are not covered by this license; they are outside its scope.
The act of running a program using the Library is not restricted, and output from such a program is covered only if its contents constitute a work based on the library (independent of
the use of the Library in a tool for writing it). Whether that is
true depends on what the library does and what the program
that uses the library does.
1. You may copy and distribute verbatim copies of the library's
complete source code as you receive it, in any medium, provided that you conspicuously and appropriately publish on
142
2. You may modify your copy or copies of the Library or any
portion of it, thus forming a work based on the Library, and
copy and distribute such modifications or work under the
terms of section 1 above, provided that you also meet all of
these conditions:
a) The modified work must itself be a software library.
b) You must cause the files modified to carry prominent
notices stating that you changed the files and the date of
any change.
c) You must cause the whole of the work to be licensed at no
charge to all third parties under the terms of this license.
d) If a facility in the modified Library refers to a function or a
table of data to be supplied by an application program that
uses the facility, other than as an argument passed when
the facility is invoked, then you must make a good faith
effort to ensure that, in the event an application does not
supply such function or table, the facility still operates, and
performs whatever part of its purpose remains meaningful.
(For example, a function in a library to compute square roots
has a purpose that is entirely well-defined independent of the
application. Therefore, Subsection 2d requires that any application-supplied function or table used by this function must be
optional: if the application does not supply it, the square root
function must still compute square roots.)
These requirements apply to the modified work as a whole. If
identifiable sections of that work are not derived from the
library, and can be reasonably considered independent and
separate works in themselves, then this license, and its terms,
do not apply to those sections when you distribute them as
separate works. But when you distribute the same sections as
part of a whole which is a work based on the library, the distribution of the whole must be on the terms of this license,
whose permissions for other licenses extend to the entire
whole, and thus to each and every part regardless of who
wrote it.
Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the
intent is to exercise the right to control the distribution of
derivative or collective works based on the library.
In addition, mere aggregation of another work not based on
the library with the library (or with a work based on the
library) on a volume of a storage or distribution medium does
not bring the other work under the scope of this license.
3. You may opt to apply the terms of the ordinary GNU General
Public License instead of this License to a given copy of the
Library. To do this, you must alter all the notices that refer to
this License, so that they refer to the ordinary GNU General
Public License, version 2, instead of to this License. (If a newer
version than version 2 of the ordinary GNU General Public
License has appeared, then you can specify that version
instead if you wish.) Do not make any other change in these
notices.
Once this change is made in a given copy, it is irreversible for
that copy, so the ordinary GNU General Public License applies
to all subsequent copies and derivative works made from that
copy.
This option is useful when you wish to copy part of the code
of the library into a program that is not a library.
4. You may copy and distribute the library (or a portion or derivative of it, under Section 2) in object code or executable form
under the terms of Sections 1 and 2 above provided that you
accompany it with the complete corresponding machinereadable source code, which must be distributed under the
terms of sections 1 and 2 above on a medium customarily
used for software interchange.
If distribution of object code is made by offering access to
copy from a designated place, then offering equivalent access
to copy the source code from the same place satisfies the
requirement to distribute the source code, even though third
parties are not compelled to copy the source along with the
object code.
5. A program that contains no derivative of any portion of the
Library, but is designed to work with the Library by being
compiled or linked with it, is called a “work that uses the
Library”. Such a work, in isolation, is not a derivative work of
the Library, and therefore falls outside the scope of this
license.
When a “work that uses the library” uses material from a header file that is part of the library, the object code for the work
may be a derivative work of the library even though the source
code is not.
Whether this is true is especially significant if the work can be
linked without the library, or if the work is itself a library. The
threshold for this to be true is not precisely defined by law.
If such an object file uses only numerical parameters, data
structure layouts and accessories, and small macros and small
inline functions (ten lines or less in length), then the use of
Otherwise, if the work is a derivative of the library, you may
distribute the object code for the work under the terms of
Section 6. Any executable containing that work also fall under
Section 6, whether or not they are linked directly with the
library itself.
6. As an exception to the sections above, you may also combine
or link a "work that uses the library" with the library to produce a work containing portions of the library, and distribute
that work under terms of your choice, provided that the terms
permit modification of the work for the customer's own use
and reverse engineering for debugging such modifications.
You must give prominent notice with each copy of the work
that the library is used in it and that the Library and its use
are covered by this license. You must supply a copy of this
license. If the work during execution displays copyright
notices, you must include the copyright notice for the library
among them, as well as a reference directing the user to the
copy of this license. Also, you must do one of these things:
a) Accompany the work with the complete corresponding
machine-readable source code for the library including
whatever changes were used in the work (which must be
distributed under Sections 1 and 2 above); and, if the work
is an executable linked with the Library, with the complete
machine-readable “work that uses the Library”, as object
code and/or source code, so that the user can modify the
library and then relink to produce a modified executable
containing the modified library. (It is understood that the
user who changes the contents of definitions files in the
library will not necessarily be able to recompile the application to use the modified definitions.)
b) Use a suitable shared library mechanism for linking with the
library. A suitable mechanism is one that (1) uses at run time
a copy of the library already present on the user’s computer
system, rather than copying library functions into the executable, and (2) will operate properly with a modified version
of the library, if the user installs one, as long as the modified
version is interface-compatible with the version that the
work was made with.
c) Accompany the work with a written offer, valid for at least
three years, to give the same user the materials specified in
Subsection 6, above, for a charge no more than the cost of
performing this distribution.
d) If distribution of the work is made by offering access to
copy from a designated place, offer equivalent access to
copy the above specified materials from the same place.
e) Verify that the user has already received a copy of these
materials or that you have already sent this user a copy.
APPENDIX
However, linking a “work that uses the library” with the Library
creates an executable that is a derivative of the Library
(because it contains portions of the library), rather than a
“work that uses the library”. The executable is therefore covered by this license. Section 6 states terms for distribution of
such executable.
the object file is unrestricted, regardless of whether it is legally a derivative work. (Executable containing this object code
plus portions of the library will still fall under Section 6.)
143
APPENDIX
For an executable, the required form of the "work that uses
the library" must include any data and utility programs needed for reproducing the executable from it. However, as a special exception, the materials to be distributed need not
include anything that is normally distributed (in either source
or binary form) with the major components (compiler, kernel,
and so on) of the operating system on which the executable
runs, unless that component itself accompanies the executable.
It may happen that this requirement contradicts the license
restrictions of other proprietary libraries that do not normally accompany the operating system. Such a contradiction
means you cannot use both them and the library together in
an executable that you distribute.
7. You may place library facilities that are a work based on the
library side-by-side in a single library together with other
library facilities not covered by this license, and distribute
such a combined library, provided that the separate distribution of the work based on the Library and of the other library
facilities is otherwise permitted, and provided that you do
these two things:
a) Accompany the combined library with a copy of the same
work based on the Library, uncombined with any other
library facilities. This must be distributed under the terms
of the sections above.
b) Give prominent notice with the combined library of the
fact that part of it is a work based on the library, and
explaining where to find the accompanying uncombined
form of the same work.
APPENDIX
8. You may not copy, modify, sublicense, link with, or distribute
the library except as expressly provided under this license.
Any attempt otherwise to copy, modify, sublicense, link with,
or distribute the library is void, and will automatically terminate your rights under this license. However, parties who have
received copies, or rights, from you under this license will not
have their licenses terminated so long as such parties remain
in full compliance.
9. You are not required to accept this license, since you have not
signed it. However, nothing else grants you permission to modify or distribute the library or its derivative works. These
actions are prohibited by law if you do not accept this license.
Therefore, by modifying or distributing the library (or any work
based on the library), you indicate your acceptance of this
license to do so, and all its terms and conditions for copying,
distributing or modifying the library or works based on it.
10.Each time you redistribute the library (or any work based on
the Library), the recipient automatically receives a license
from the original licensor to copy, distribute, link with or modify the library subject to these terms and conditions. You may
not impose any further restrictions on the recipients' exercise
144
of the rights granted herein.
You are not responsible for enforcing compliance by third
parties with this license.
11. If, as a consequence of a court judgment or allegation of
patent infringement or for any other reason (not limited to
patent issues), conditions are imposed on you (whether by
court order, agreement or otherwise) that contradict the conditions of this license, they do not excuse you from the conditions of this license. If you cannot distribute so as to satisfy simultaneously your obligations under this license and any
other pertinent obligations, then as a consequence you may
not distribute the library at all. For example, if a patent license
would not permit royalty-free redistribution of the library by
all those who receive copies directly or indirectly through
you, then the only way you could satisfy both it and this
license would be to refrain entirely from distribution of the
library.
If any portion of this section is held invalid or unenforceable
under any particular circumstance, the balance of the section
is intended to apply, and the section as a whole is intended to
apply in other circumstances.
It is not the purpose of this section to induce you to infringe
any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of
protecting the integrity of the free software distribution system which is implemented by public license practices. Many
people have made generous contributions to the wide range
of software distributed through that system in reliance on
consistent application of that system; it is up to the
author/donor to decide if he or she is willing to distribute
software through any other system and a license cannot
impose that choice.
This section is intended to make thoroughly clear what is
believed to be a consequence of the rest of this license.
12.If the distribution and/or use of the library is restricted in certain countries either by patents or by copyrighted interfaces,
the original copyright holder who places the library under this
license may add an explicit geographical distribution limitation
excluding those countries, so that distribution is permitted
only in or among countries not thus excluded. In such case,
this license incorporates the limitation as if written in the body
of this license.
13.The Free Software Foundation may publish revised and/or
new versions of the Lesser General Public License from time to
time. Such new versions will be similar in spirit to the present
version, but may differ in detail to address new problems or
concerns.
Each version is given a distinguishing version number. If the
library specifies a version number of this license which applies
to it and “any later version”, you have the option of following
the terms and conditions either of that version or of any later
version published by the Free Software Foundation.
If the library does not specify a license version number, you
may choose any version ever published by the Free Software
Foundation.
14.If you wish to incorporate parts of the library into other free
programs whose distribution conditions are incompatible with
these, write to the author to ask for permission. For software
which is copyrighted by the Free Software Foundation, write
to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of
preserving the free status of all derivatives of our free software
and of promoting the sharing and reuse of software generally.
To apply these terms, attach the following notices to the library.
It is safest to attach them to the start of each source file to most
effectively convey the exclusion of warranty; and each file should
have at least the “copyright” line and a pointer to where the full
notice is found.
one line to give the library's name and a brief idea of what it does.
Copyright (C) <year> <name of author>
This library is free software; you can redistribute it and/or modify
it under the terms of the GNU Lesser General Public License as
published by the Free Software Foundation; either version 2.1 of
the license, or (at your option) any later version.
NO WARRANTY
15.BECAUSE THE LIBRARY IS LICENSED FREE OF CHARGE,
THERE IS NO WARRANTY FOR THE LIBRARY, TO THE
EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN
OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE LIBRARY "AS
IS" WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE
RISK AS TO THE QUALITY AND PERFORMANCE OF THE
LIBRARY IS WITH YOU. SHOULD THE LIBRARY PROVE
DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY
SERVICING, REPAIR OR CORRECTION.
You should have received a copy of the GNU Lesser General
Public License along with this library; if not, write to the Free
Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston,
MA 02110-1301 USA
Also add information on how to contact you by electronic and
paper mail.
You should also get your employer (if you work as a programmer)
or your school, if any, to sign a “copyright disclaimer” for the
library, if necessary. Here is a sample; alter the names:
Yoyodyne, Inc., hereby disclaims all copyright interest in the
library ‘Frob’ (a library for tweaking knobs) written by James
Random Hacker.
signature of Ty Coon, 1 April 1990
Ty Coon, President of Vice
APPENDIX
16.IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR
AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER,
OR ANY OTHER PARTY WHO MAY MODIFY AND/OR
REDISTRIBUTE THE LIBRARY AS PERMITTED ABOVE, BE
LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OR INABILITY TO USE THE
LIBRARY (INCLUDING BUT NOT LIMITED TO LOSS OF DATA
OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE
LIBRARY TO OPERATE WITH ANY OTHER SOFTWARE),
EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
This library is distributed in the hope that it will be useful, but
WITHOUT ANY WARRANTY; without even the implied warranty
of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser General Public License for more
details.
END OF TERMS AND CONDITIONS
How to apply these terms to your new libraries
If you develop a new library, and you want it to be of the greatest possible use to the public, we recommend making it free software that everyone can redistribute and change. You can do so
by permitting redistribution under these terms (or, alternatively,
under the terms of the ordinary General Public License).
145
APPENDIX
MOZILLA PUBLIC LICENSE
Version 1.1
--------------code which is described in the source code notice
required by exhibit as original code, and which, at the time
of its release under this license is not already covered
code governed by this license.
1.Definitions.
1.0.1. “Commercial use” means distribution or otherwise making
the covered code available to a third party.
1.1.
“Contributor” means each entity that creates or contributes to the creation of modifications.
1.2.
“Contributor version” means the combination of the original code, prior modifications used by a contributor, and
the modifications made by that particular contributor.
1.3.
“Covered code” means the original code or modifications
or the combination of the original code and modifications,
in each case including portions thereof.
1.4.
“Electronic distribution mechanism” means a mechanism
generally accepted in the software development community for the electronic transfer of data.
1.5.
“Executable” means covered code in any form other than
source code.
1.6.
“Initial developer” means the individual or entity identified
as the initial Developer in the Source Code notice required
by exhibit A.
1.7.
“Larger work” means a work which combines covered code
or portions thereof with code not governed by the terms
of this License.
1.8.
“License” means this document.
APPENDIX
1.8.1. “Licensable” means having the right to grant, to the maximum extent possible, whether at the time of the initial
grant or subsequently acquired, any and all of the rights
conveyed herein.
1.9.
“Modifications” means any addition to or deletion from
the substance or structure of either the original code or
any previous modifications. When covered code is
released as a series of files, a modification is:
A. Any addition to or deletion from the contents of a file
containing original code or previous modifications.
B. Any new file that contains any part of the original code
or previous modifications.
1.10. “Original code” means source code of computer software
146
1.10.1.“Patent claims” means any patent claim(s), now owned or
hereafter acquired, including without limitation, method,
process, and apparatus claims, in any patent licensable by
grantor.
1.11. “Source code” means the preferred form of the covered
code for making modifications to it, including all modules
it contains, plus any associated interface definition files,
scripts used to control compilation and installation of an
executable, or source code differential comparisons
against either the original code or another well known,
available covered code of the contributor's choice. The
source code can be in a compressed or archival form, provided the appropriate decompression or de-archiving software is widely available for no charge.
1.12. “You” (or “Your”) means an individual or a legal entity
exercising rights under, and complying with all of the terms
of, this license or a future version of this license issued
under section 6.1.
For legal entities, “You” includes any entity which controls,
is controlled by, or is under common control with You. For
purposes of this definition, “control” means (a) the power,
direct or indirect, to cause the direction or management of
such entity, whether by contract or otherwise, or (b) ownership of more than fifty percent (50%) of the outstanding shares or beneficial ownership of such entity.
2. Source Code License.
2.1.
The initial developer grant.
The initial developer hereby grants You a world-wide, royalty-free, non-exclusive license, subject to third party intellectual property claims:
a) under intellectual property rights (other than patent or
trademark) licensable by initial developer to use, reproduce, modify, display, perform, sublicense and distribute the original code (or portions thereof) with or without modifications, and/or as part of a larger work; and
(b) under patents claims infringed by the making, using or
selling of original code, to make, have made, use, practice, sell, and offer for sale, and/or otherwise dispose
of the original code (or portions there of).
(c) the licenses granted in this section 2.1(a) and (b) are
effective on the date Initial developer first distributes
original code under the terms of this license.
(d) Notwithstanding section 2.1(b) above, no patent
license is granted: 1) for code that You delete from the
original Code; 2) separate from the original code; or
3) for infringements caused by: i) the modification of
the original code or ii) the combination of the original
code with other software or devices.
2.2.
Availability of source code.
Any modification which you create or to which you contribute must be made available in source code form under
the terms of this license either on the same media as an
executable version or via an accepted electronic distribution mechanism to anyone to whom you made an executable version available; and if made available via electronic distribution mechanism, must remain available for at
least twelve (12) months after the date it initially became
available, or at least six (6) months after a subsequent
version of that particular modification has been made
available to such recipients. You are responsible for ensuring that the source code version remains available even if
the electronic distribution mechanism is maintained by a
third party.
3.3.
Description of modifications.
You must cause all covered code to which you contribute to
contain a file documenting the changes You made to create
that covered code and the date of any change. You must
include a prominent statement that the modification is
derived, directly or indirectly, from original code provided by
the initial developer and including the name of the initial
developer in (a) the source code, and (b) in any notice in an
executable version or related documentation in which you
describe the origin or ownership of the covered code.
3.4.
Intellectual property matters
(a) Third party claims.
If contributor has knowledge that a license under a third
party's intellectual property rights is required to exercise
the rights granted by such contributor under sections 2.1
or 2.2, contributor must include a text file with the source
code distribution titled "LEGAL" which describes the claim
and the party making the claim in sufficient detail that a
recipient will know whom to contact. If contributor obtains
such knowledge after the modification is made available as
described in section 3.2, contributor shall promptly modify the LEGAL file in all copies contributor makes available
thereafter and shall take other steps (such as notifying
appropriate mailing lists or newsgroups) reasonably calculated to inform those who received the covered code that
new knowledge has been obtained.
(b) Contributor APIs.
If contributor's modifications include an application
programming interface and contributor has knowledge of
patent licenses which are reasonably necessary to implement
that API, contributor must also include this information in
the LEGAL file.
3. Distribution Obligations.
Application of license.
The modifications which You create or to which you contribute are governed by the terms of this license, including
without limitation section 2.2. The source code version of
covered code may be distributed only under the terms of
this license or a future version of this license released
under section 6.1, and you must include a copy of this
license with every copy of the source code you distribute.
APPENDIX
3.2.
Contributor Grant.
Subject to third party intellectual property claims, each
contributor hereby grants You a world-wide, royalty-free,
non-exclusive license
(a) under intellectual property rights (other than patent
or trademark) licensable by contributor, to use,
reproduce, modify, display, perform, sublicense and
distribute the modifications created by such contributor (or portions thereof) either on an unmodified
basis, with other modifications, as covered code
and/or as part of a larger work; and
(b) under patent claims infringed by the making, using, or
selling of modifications made by that contributor
either alone and/or in combination with its contributor
version (or portions of such combination), to make,
use, sell, offer for sale, have made, and/or otherwise
dispose of: 1) modifications made by that contributor
(or portions thereof); and 2) the combination of modifications made by that contributor with its contributor
version (or portions of such combination).
(c) the licenses granted in sections 2.2(a) and 2.2(b) are
effective on the date contributor first makes commercial use of the covered code.
(d) Notwithstanding section 2.2(b) above, no patent
license is granted: 1) for any code that contributor has
deleted from the contributor version; 2) separate from
the contributor version; 3) for infringements caused
by: i) third party modifications of contributor version
or ii) the combination of modifications made by that
contributor with other software (except as part of the
contributor version) or other devices; or 4) under
patent claims infringed by covered code in the
absence of modifications made by that contributor.
3.1.
You may not offer or impose any terms on any source code
version that alters or restricts the applicable version of
this license or the recipients' rights hereunder. However,
you may include an additional document offering the
additional rights described in section 3.5.
147
APPENDIX
3.5.
3.6.
APPENDIX
148
(c) Representations.
contributor represents that, except as disclosed pursuant
to section 3.4(a) above, contributor believes that contributor's
modifications are contributor's original creation(s)
and/or contributor has sufficient rights to grant the rights
conveyed by this license.
3.7.
Required notices.
You must duplicate the notice in exhibit A in each file of
the source code. If it is not possible to put such notice in
a particular source code file due to its structure, then You
must include such notice in a location (such as a relevant
directory) where a user would be likely to look for such a
notice. If You created one or more modification(s), you
may add your name as a contributor to the notice
described in exhibit A. you must also duplicate this license
in any documentation for the source code where You
describe recipients' rights or ownership rights relating to
covered code. You may choose to offer, and to charge a
fee for, warranty, support, indemnity or liability obligations
to one or more recipients of covered code. However, you
may do so only on your own behalf, and not on behalf of
the Initial developer or any contributor. You must make it
absolutely clear than any such warranty, support, indemnity or liability obligation is offered by you alone, and You
hereby agree to indemnify the Initial developer and every
contributor for any liability incurred by the Initial developer or such contributor as a result of warranty, support,
indemnity or liability terms you offer.
4. Inability to comply due to statute or regulation.
If it is impossible for you to comply with any of the terms
of this license with respect to some or all of the covered
code due to statute, judicial order, or regulation then you
must: (a) comply with the terms of this license to the maximum extent possible; and (b) describe the limitations and
the code they affect. Such description must be included in
the LEGAL file described in section 3.4 and must be
included with all distributions of the source code. Except
to the extent prohibited by statute or regulation, such
description must be sufficiently detailed for a recipient of
ordinary skill to be able to understand it.
Distribution of executable versions.
You may distribute covered code in executable form only if
the requirements of section 3.1-3.5 have been met for
that covered code, and if you include a notice stating that
the source code version of the covered code is available
under the terms of this license, including a description of
how and where you have fulfilled the obligations of section
3.2. The notice must be conspicuously included in any
notice in an executable version, related documentation or
collateral in which you describe recipients' rights relating
to the covered code. You may distribute the executable
version of covered code or ownership rights under a
license of your choice, which may contain terms different
from this license, provided that you are in compliance with
the terms of this license and that the license for the executable version does not attempt to limit or alter the recipient's rights in the source code version from the rights set
forth in this license. If you distribute the executable version under a different license you must make it absolutely
clear that any terms which differ from this license are
offered by you alone, not by the Initial developer or any
contributor. You hereby agree to indemnify the initial
developer and every contributor for any liability incurred
by the initial developer or such contributor as a result of
any such terms You offer.
Larger works.
You may create a larger work by combining covered code
with other code not governed by the terms of this license
and distribute the larger work as a single product. In such
a case, you must make sure the requirements of this
license are fulfilled for the covered code.
5. Application of this license.
This license applies to code to which the initial developer has
attached the notice in exhibit A and to related covered code.
6. Versions of the license.
6.1.
New versions.
Netscape communications corporation (“Netscape”) may
publish revised and/or new versions of the license from
time to time. Each version will be given a distinguishing
version number.
6.2.
Effect of new versions.
Once covered code has been published under a particular
version of the license, you may always continue to use it
under the terms of that version. You may also choose to
use such covered code under the terms of any subsequent
version of the license published by netscape. No one
other than netscape has the right to modify the terms
applicable to covered code created under this license.
6.3.
Derivative works.
If You create or use a modified version of this license
(which you may only do in order to apply it to code which
is not already covered code governed by this license), You
must (a) rename Your license so that the phrases
"Mozilla", "MOZILLAPL", "MOZPL", "Netscape", "MPL",
"NPL" or any confusingly similar phrase do not appear in
your license (except to note that your license differs from
this license) and (b) otherwise make it clear that Your
version of the license contains terms which differ from the
Mozilla Public license and netscape Public License. (Filling
in the name of the initial developer, original code or contributor in the notice described in exhibit A shall not of
themselves be deemed to be modifications of this license.)
7. DISCLAIMER OF WARRANTY.
COVERED CODE IS PROVIDED UNDER THIS LICENSE
ON AN “AS IS” BASIS, WITHOUT WARRANTY OF ANY
KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING,
WITHOUT LIMITATION, WARRANTIES THAT THE COVERED CODE IS FREE OF DEFECTS, MERCHANTABLE, FIT
FOR A PARTICULAR PURPOSE OR NON-INFRINGING.
THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE COVERED CODE IS WITH YOU.
SHOULD ANY COVERED CODE PROVE DEFECTIVE IN
ANY RESPECT, YOU (NOT THE INITIAL DEVELOPER OR
ANY OTHER CONTRIBUTOR) ASSUME THE COST OF
ANY NECESSARY SERVICING, REPAIR OR CORRECTION.
THIS DISCLAIMER OF WARRANTY CONSTITUTES AN
ESSENTIAL PART OF THIS LICENSE. NO USE OF ANY
COVERED CODE IS AUTHORIZED HEREUNDER EXCEPT
UNDER THIS DISCLAIMER.
8. TERMINATION.
8.1.
8.2.
This license and the rights granted hereunder will terminate
automatically if you fail to comply with terms herein and
fail to cure such breach within 30 days of becoming aware
of the breach. All sublicenses to the covered code which
are properly granted shall survive any termination of this
license. Provisions which, by their nature, must remain in
effect beyond the termination of this license shall survive.
If you initiate litigation by asserting a patent infringement
claim (excluding declatory judgment actions) against initial developer or a contributor (the initial developer or
contributor against whom you file such action is referred
to as “Participant”) alleging that:
8.3.
If you assert a patent infringement claim against participant alleging that such participant's contributor version
directly or indirectly infringes any patent where such claim
is resolved (such as by license or settlement) prior to the
initiation of patent infringement litigation, then the reasonable value of the licenses granted by such participant
under sections 2.1 or 2.2 shall be taken into account in
determining the amount or value of any payment or
license.
8.4.
In the event of termination under sections 8.1 or 8.2
above, all end user license agreements (excluding distributors
and resellers) which have been validly granted by you or
any distributor hereunder prior to termination shall survive
termination.
9. LIMITATION OF LIABILITY.
UNDER NO CIRCUMSTANCES AND UNDER NO LEGAL
THEORY, WHETHER TORT (INCLUDING NEGLIGENCE),
CONTRACT, OR OTHERWISE, SHALL YOU, THE INITIAL
DEVELOPER, ANY OTHER CONTRIBUTOR, OR ANY DISTRIBUTOR OF COVERED CODE,OR ANY SUPPLIER OF
ANY OF SUCH PARTIES, BE LIABLE TO ANY PERSON FOR
ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY CHARACTER INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF GOODWILL,
WORK STOPPAGE, COMPUTER FAILURE OR MALFUNCTION, OR ANY AND ALL OTHER COMMERCIAL DAMAGES OR LOSSES, EVEN IF SUCH PARTY SHALL HAVE
BEEN INFORMED OF THE POSSIBILITY OF SUCH DAMAGES. THIS LIMITATION OF LIABILITY SHALL NOT APPLY
TO LIABILITY FOR DEATH OR PERSONAL INJURY RESULTING FROM SUCH PARTY'S NEGLIGENCE TO THE EXTENT
APPLICABLE LAW PROHIBITS SUCH LIMITATION. SOME
JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THIS EXCLUSION AND LIMITATION MAY NOT
APPLY TO YOU.
APPENDIX
(a) such participant's contributor version directly or indirectly infringes any patent, then any and all rights
granted by such participant to you under sections 2.1
and/or 2.2 of this license shall, upon 60 days notice
from Participant terminate prospectively, unless if within
60 days after receipt of notice you either: (i) agree in
writing to pay participant a mutually agreeable reasonable
royalty for your past and future use of modifications
made by such participant, or (ii) withdraw your litigation
claim with respect to the contributor version against
such participant. If within 60 days of notice, a reasonable
royalty and payment arrangement are not mutually
agreed upon in writing by the parties or the litigation
claim is not withdrawn, the rights granted by participant to you under sections 2.1 and/or 2.2 automatically terminate at the expiration of the 60 day notice
period specified above.
(b) any software, hardware, or device, other than such participant's contributor Version, directly or indirectly
infringes any patent, then any rights granted to You by
such participant under sections 2.1(b) and 2.2(b) are
revoked effective as of the date you first made, used,
sold, distributed, or had made, modifications made by
that participant.
10. U.S. GOVERNMENT END USERS.
The covered code is a "commercial item," as that term is
defined in 48 C.F.R. 2.101 (Oct. 1995), consisting of
"commercial computer software" and "commercial computer
software documentation," as such terms are used in 48
C.F.R. 12.212 (Sept. 1995). Consistent with 48 C.F.R.
12.212 and 48 C.F.R. 227.7202-1 through 227.7202-4
(June 1995), all U.S. Government end users acquire covered code with only those rights set forth herein.
149
APPENDIX
11. MISCELLANEOUS.
This license represents the complete agreement concerning
subject matter hereof. If any provision of this license is
held to be unenforceable, such provision shall be reformed
only to the extent necessary to make it enforceable. This
License shall be governed by California law provisions
(except to the extent applicable law, if any, provides otherwise), excluding its conflict-of-law provisions. With
respect to disputes in which at least one party is a citizen
of, or an entity chartered or registered to do business in
the united states of america, any litigation relating to this
License shall be subject to the jurisdiction of the federal
courts of the northern district of california, with venue
lying in santa clara county, california, with the losing party
responsible for costs, including without limitation, court
costs and reasonable attorneys' fees and expenses. The
application of the united nations convention on contracts
for the International sale of goods is expressly excluded.
Any law or regulation which provides that the language of
a contract shall be construed against the drafter shall not
apply to this license.
EXHIBIT A -Mozilla Public License.
12. RESPONSIBILITY FOR CLAIMS.
As between initial developer and the contributors, each
party is responsible for claims and damages arising, directly
or indirectly, out of its utilization of rights under this
license and you agree to work with initial developer and
contributors to distribute such responsibility on an equitable
basis. Nothing herein is intended or shall be deemed to
constitute any admission of liability.
Alternatively, the contents of this file may be used under the
terms of the _____ license (the "[___] License"), in which case
the provisions of [______] license are applicable instead of those
above. If you wish to allow use of your version of this file only
under the terms of the [____] license and not to allow others to
use your version of this file under the MPL, indicate your decision
by deleting the provisions above and replace them with the
notice and other provisions required by the [___] license. If you
do not delete the provisions above, a recipient may use your version
of this file under either the MPL or the [___] license."
13. MULTIPLE-LICENSED CODE.
Initial developer may designate portions of the covered
code as "Multiple-Licensed". "Multiple-Licensed" means
that the initial developer permits you to utilize portions of
the covered code under your choice of the NPL or the
alternative licenses, if any, specified by the initial developer
in the file described in exhibit A.
APPENDIX
150
The contents of this file are subject to the Mozilla Public License
Version 1.1 (the “license”); you may not use this file except in
compliance with the License. You may obtain a copy of the
license at http://www.mozilla.org/MPL/
Software distributed under the license is distributed on an "AS
IS" basis, WITHOUT WARRANTY OF ANY KIND, either express
or implied. See the license for the specific language governing
rights and limitations under the License.
The Original Code is ______________________________________.
The
Initial
Developer
of
the
Original
Code
is___________________.
Portions created by ______________________ are Copyright (C)
_______________________. All Rights Reserved.
Contributor(s): ______________________________________.
NOTE: The text of this exhibit A may differ slightly from the text
of the notices in the source code files of the original code. You
should use the text of this exhibit A rather than the text found in
the original code/source code for Your modifications.
OWNER’S MANUAL
LCD TV
Please read this manual carefully before operating
your set and retain it for future reference.
The model and serial number of the TV is located
on the back and/or on one side of the TV.
Record these numbers below should you ever need
service.
MODEL
1-800-243-0000 USA, Consumer User
1-888-865-3026 USA, Commercial User
1-888-542-2623 CANADA
LG Customer Information Center
32LG710H
37LG710H
42LG710H
32LD650H
37LD650H
42LD650H
47LD650H
55LD650H
32LD655H
37LD655H
42LD655H
SERIAL
This product qualifies for ENERGY STAR in the “factory default”
setting.
Changing the factory default settings or enabling other features
may increase power consumption that could exceed the limits
necessary to quality for ENERGY STAR.
P/NO : SAC34134301 (1007-REV02)
www.lg.com
Download PDF

advertising
