Enterprise Wireless Networking

Session ID #: 2498

Abbas Masnavi

Presentation Title Verdana

Bold

34 pt.

Presenter’s Name

Presenter’s Title

Presenter’s Company (or Group)

Agenda

Introduction

Mobility

WLAN Security

Quality of Service

Closing Remarks/Q&A

Momentum is Building in Wireless

LANs

Wireless LANs are an “addictive” technology

Strong commitment to Wireless LANs by technology heavy-weights

Cisco, IBM, Intel, Microsoft

Embedded market is growing

Laptops & PDA’s with “wireless inside”

Phones are next

The WLAN market is expanding from Industry-Specific Applications to Universities, Municipalities,

Homes, & Offices

Evolution of the WLAN Business

Early Adopters

Specific Industries

Hotels Hospitals

Retail Manufacturing

Education

Universities

K1-12 Libraries

Mainstream

Home

Networking

Office

WLANs

Outdoor

Wireless

Bridging

Next Wave

Public Access “Hotspots”

Airports Restaurants

Hotels

Entire Towns

Coffee Shops

Convention Centers

New Applications

Phones, PDA’s, Printers

Buses, Sports Events, Construction Sites

Public Safety (Police, Ambulances)

Enterprise-Class WLAN Solutions

Security

802.1X: LEAP, PEAP

TKIP, WPA

Cost of ownership

In-line power

Software upgradeability

Hardware upgradeability

Performance

Throughput

Load balancing

100 mW radios (802.11b)

Product line diversity

Variety of antennas

Interoperable client solutions

Partnerships

WLAN Product Line

In-building Infrastructure

Clients

350 Series 2.4 GHz

5 GHz client adapter

Wireless IP Phone

1200 Series

1100 Series

Antennas

Bridges

350 and

1400

Series

Outdoor Wireless Bridges:

Applications

Government Buildings

Connect buildings’ data networks

Cheaper than T1 (fast ROI)

Cheaper than trenching fiber

Backup system for when cables get cut

Education

Public school system sharing WAN link

Colleges expanding into leased facilities

Connecting classroom trailers to main bldg.

Municipal Applications

Emergency response (police, fire, city hall)

Public transportation (buses)

Courthouse

Temporary Broadband Link

Construction sites

Sporting events

County Fairs

16+ miles

11 Mbps

WLAN “Alphabet Soup”:

IEEE 802.11 Standards Activities

802.11a: 5GHz, 54Mbps

802.11b: 2.4GHz, 11Mbps

802.11d: Multiple regulatory domains

802.11e: Quality of Service (QoS)

802.11F: Inter-Access Point Protocol (IAPP)

Recommended Practice (this is not a standard)

802.11g: 2.4GHz, 54Mbps

802.11h: Dynamic Frequency Selection (DFS) and

Transmit Power Control (TPC)

802.11i: Security (currently at Draft 3.0)

802.11j: Japan 5GHz Channels (4.9-5.1 GHz)

802.11k: Measurement

5 GHz vs. 2.4 GHz Comparison

5 GHz—802.11a

Maximum WLAN data rate:

54 Mbps

12 channels available (4 for outdoor only)

Initially approved for use in only certain countries

(including U.S.)

Less interference

2.4 GHz—802.11b and g

11Mbps Æ 54Mbps

3 channels

Worldwide compatibility

Compatibility with installed base of 802.11b products

Easy upgrade path to highspeed 802.11g

Wide selection of client devices

Lower cost products

Lower power requirements

(important for handhelds)

Agenda

Introduction

Mobility

Dynamic Coverage

L2/L3 Roaming

Wireless Mobility

WLAN Security

Quality of Service

Closing Remarks/Q&A

Dynamic/Complete Coverage

Site surveys can be expensive and are a snapshot in time

The WLAN needs to be able to detect RF environment changes and automatically adjust power, frequency, and bit rate

Seamless Layer 2 Roaming

Wired LAN Connecting APs

(Intra-Subnet Roaming)

4

5

3

4. AP B Sends MAC Multicast Using

Source Address of AP B;

AP A Drops Client from Association Table

3. AP B Sends MAC Multicast Using

Source Address of the Client; This

Updates the CAM Tables in Upstream

Switches and Directs Further LAN

Traffic for the Client to AP B, and

Not AP A

2

2. Client Re-Authenticates and

Re-Associates with AP “B”

1

1. Client Moves into AP “B” Coverage Area from AP “A” (Both APs in Same Subnet);

Moving from AP A’s Coverage Area Will

Trigger a “Roaming Event” (e.g. Max Retries

Met); the Client Will then Initiate Normal

Scanning Process for Available APs

Scanning for APs:

To Associate with AP B (Satisfy One or

More Criteria)

Signal strength 20% better?

Fewer hops to backbone?

Assoc(AP B) + 4 < Assoc(AP A)?

Mobile IP Terminology

MN

HA

CN

Internet

COA

HA, Home Agent

Maintains an Association between the MN’s “Home” IP Address and

Its Care of Address (Loaned

Address) on the Foreign Network

Redirects and Tunnels Packets to the Care of Address on the

Foreign Network

MN

MN, Mobile Node

FA

CN, Correspondent Node

Destination IP Host in

Session with a Mobile Node

FA, Foreign Agent

Provides an Addressable Point of Attachment to the MN Called

Care of Address (COA)

Maintains an Awareness for All

Visiting MNs

Acts as a “Relay” between the

MN and Its Home Agent

Receives All Packets for the MN from the MN’s Home Agent

An IP Host that Maintains Network

Connectivity Using Its “Home” IP

Address, Regardless of which Subnet

(or Network) It Is Connected to

Roaming Layer 3

Without mobile IP, roaming is achieved by extending the Layer 2 network

Cisco has supported mobile IP for a number of years

Mobile IP has been waiting on mainstream clients; these are now available

The easiest first step is the use of collocated CAs, and a central HA

(no FA needed)

Additional WLAN Mobility Issues

L2 roaming latency

L3 subnet roaming

Mobile IP, Proxy Mobile IP, IAPP – which one is best?

Power saving modes affect multicast

(buffering)

New roaming and power saving technologies being developed (Cisco Fast

Secure Roaming)

Agenda

Introduction

Mobility

WLAN Security

Quality of Service

Closing Remarks/Q&A

Standard Wireless LAN Security

Issue

Wireless sniffer can view all WLAN data packets

Anyone in AP coverage area can get on WLAN

Solution

Encrypt all data transmitted between client and AP

Without encryption key, user cannot transmit or receive data

Wireless LAN

(WLAN) Wired LAN

client access point (AP)

Goal: Make WLAN security equivalent to that of wired LANs (Wired Equivalent Privacy)

WEP Encryption

Wired Equivalent Privacy

Based on the RC4 symmetric stream cipher

Requires matching static, pre-shared, 64-bit or

128-bit keys on both the client and access point

24-bit Initialization Vector (IV) plus 40- or 104-bit secret key yields 64- or 128-bit data encryption

Limitations of 802.11 Security

Shared, static WEP keys

No centralized key management

Lack of integrated user administration

Poor protection from variety of security attacks*

Need for separate user databases; no use of

RADIUS

No effective way to deal with lost or stolen adapter

Possessor has access to WLAN and any network resource for which no network logon is required

Re-keying of all WLAN devices is required

Potential to identify user by

MAC address, not username

No usage accounting and auditing; no means to detect unusual activity

* “In practice, most installations use a single key that is shared between all mobile stations and access points. More sophisticated key management techniques can be used to help defend from the attacks we describe…”

University of California-Berkeley report on WEP security: www.isaac.cs.berkeley.edu/isaac/wep-faq.html

Key Initiatives

Continue to enhance enterprise-class WLAN security solutions to extend leadership

Drive standards efforts

Develop greater wired/wireless integration since

WLANs are an extension of the wired network

Create partnerships to provide customer solutions for different markets

Share technology to extend the value of Cisco’s advanced features to a variety of client devices

WLAN Security:

802.1X Authentication

LEAP – Cisco Lightweight EAP

Nearly all major OS’s supported:

WinXP/2K/NT/ME/98/95/CE/CE .NET, Linux,

Mac, and DOS

CCX program being rolled out now

Radius

Server

EAP-TLS (Transport Layer Security)

EAP-Transport Layer Security

Mutual Authentication implementation

EAP-TTLS (Tunneled TLS)

Hybrid—Certificate/password

PEAP (Protected EAP)

Establishes secure tunnel (similar to VPN)

Co-developed by Cisco, Microsoft, & RSA Security

Option: One-Time Passwords (“OTP”)

AP

Client

WLAN Security:

802.1x Authentication

Centralized, scalable, userbased authentication

Mutual authentication

Various authentication types

Dynamic WEP key support

WEP key refresh

TKIP or

AES

802.1x/EAP Architecture

Wireless EAP Access Point EAP

Radius Server

Laptop Computer with

EAP Supplicant

EAP Types:

LEAP

EAP-TLS

EAP-MD5

EAP-PEAP

EAP-TTLS

Etc.

Driver for Operating System

Support for at least one of the

EAP protocols

Dynamic WEP key support

Capable of speaking EAP

Client/Supplicant

EAP Authenticator

EAP-LEAP

EAP-TLS and EAP-MD5

EAP-SIM

EAP-PEAP and

EAP-TTLS

Authenticator

EAP Radius Server

Cisco secure ACS, Cisco access register, Funk,

Interlink, etc.

Internal authentication database

Capability to interoperate with external user Databases

(Windows NT/2000 AD,

LDAP, etc.)

EAP Radius DLL

Support of mixed EAP protocols deployment

MS-MPPE-Send-key support

EAP extensions for Radius

Backend/RADIUS Server

802.1X for 802.11 – Benefits

Scalable, standards-based, Can be used in wired networks as well

Supports a variety of authentication types

EAP-Cisco Wireless, or LEAP

EAP-TLS with Windows XP and other

Windows versions

Others, as they are developed

Enables centralized policy control

Session timeout triggers reauthentication and new WEP

key

802.1x in campus prevents Rogue APs

Cisco RF monitoring solutions will detect and

graphically locate rogue APs

Broadening Support for LEAP

Cisco has licensed LEAP to many companies:

LEAP support: RADIUS servers

Funk Software: Steel-Belted Radius Server

Interlink: Secure.XS Radius Server

LEAP support: Client Devices

Apple: Powerbooks/iBooks

HP: Print Servers

Symbol: Handhelds

Intermec: Handhelds

LEAP support: Client Software

Funk Software: Odyssey Client v.1.1

Meetinghouse: Aegis Client v.1.3.6

LEAP support: Chipsets

Intel

Intersil

Atheros

Atmel

TI

Marvell

Agere

Broadcom

What is PEAP?

802.1X- based authentication protocol

Based on EAP

Leverages server-side EAP-TLS using digital certificates

Supports a variety of different client authentication methods, including log-on passwords and onetime passwords (OTPs)

Based on a RFC Draft jointly submitted by Cisco

Systems, Microsoft and RSA Security to the IETF

Initial support on Windows XP, now available on

Window 2000 SP3

PEAP Implementation

PEAP Authentication Mechanisms:

One Time Password Server

Clear-text password support for LDAP and NDS user

databases

Support for Password Change (Microsoft)

Cisco Secure ACS v. 3.1:

Database support (including LDAP and NDS)

Triggering password change, etc. through tunnel

Windows XP client software implementation:

New supplicant for PEAP

User interfaces

Updated Aironet Client Utility (v. 5.05.001)

PEAP Authentication Process

Two Phase Authentication:

Phase 1: Server side TLS authentication is

performed to create an encrypted tunnel

(similar to SSL)

Phase 2: Methods such as Generic Token Card

(GTC) are used to authenticate the Client to the

Server

PEAP requires Server-side certificate only (whereas

EAP-TLS requires both Server and Client side certificates)

PEAP Authentication Overview

Enterprise

Network

RADIUS

Server

Supplicant

EAPOL Start

EAP—Request/Identity

EAP—Response/Identity

(NAI)

AP

Start EAP Authentication

Ask Client for Identity

RADIUS Access

Request

Access Request with NAI

EAP Success

Client Derives

Session Key

EAPOL—Key (Multicast)

EAPOL—Key (Session

Parameters)

Server-Side TLS

Client-Side

Authentication

RADIUS Access Success

(Pass Session Key to AP)

Perform Sequence

Defined by PEAP

Deliver Broadcast Key

Encrypted with Session Key and Session Parameters

802.1X EAP Authentication

Comparison

Multi-Operating System Support

Single Sign On For Windows Log-In

Dynamic WEP Key and Mutual

Authentication

Static Password Support

One Time Password Support

Server Certificate Required

Client Certificate Required

Layer 3 Roaming Support

MS Windows Password Change

Microsoft Backend DB Support

LDAP/NDS Backend DB Support

LEAP

Yes

Yes

Yes

Yes

No

No

No

Yes

No

Yes

No

PEAP

No

No

Yes

Yes

Yes

Yes

No

Yes

Yes

Yes

Yes

EAP-TLS

No

Yes

Yes

No

No

Yes

Yes

Yes

No

Yes

Yes

Wi-Fi Protected Access (WPA)

WPA is the biggest thing to happen to WLAN security since Cisco LEAP

Cisco has supported the base technologies of

WPA longer than any other vendor

WPA is being incorporated into Wi-Fi testing by

WECA

Mandatory WPA certification started August, 2003

Products from ten companies including Cisco’s AP1200 and

AP1100 have been certified

Components of WPA

Authenticated Key Management using 802.1X:

EAP Authentication and Pre-Shared Key (PSK) Authentication

Unicast and Broadcast Key Management

TKIP: Per-packet Keying and Message Integrity Check

(MIC)

IV-space expansion: 48 bit IVs

Migration Mode – coexistence of WPA and non-WPA devices

WLAN Security—Encryption

TKIP

Temporal Key Integrity Protocol

Dec. ’01: Cisco’s pre-standard TKIP

Aug. ’03: 802.11i-standard TKIP

(part of WPA)

AES

Advanced Encryption Standard

“The Gold Standard”

Optional part of 802.11i spec

Hardware encryption vs. software encryption

TKIP or

AES

Enterprise-Class WLAN Security:

The Cisco Wireless Security Suite

WPA

Built on Standards

Optimized for Enterprise

Broad Adoption

Tested for Interoperability

802.1X

TKIP or

AES

CCX

WPA

Wi-Fi

Protected

Access

TKIP

Temporal Key Integrity Protocol

AES

Advanced Encryption Standard

CCX

Cisco Compatible eXtensions

Campus WLAN Mobility

User-Based Network Access

Cisco Secure ACS 3.1

Based upon user’s credentials via 802.1x

(User Identity)

Unauthorized users or those without 802.1x running on their laptop can be denied or placed into a Guest VLAN

Developer

Human Resources

Eng inee

VLA ring

N 1

0

_VL

Authentication-Based Resource Access

1. Eng Can Only Access Eng Resources

2. HR Only Can Access HR Servers

3. Guest Access for Trusted 3 rd Party Contractors

Guest or Contractor

VLAN 20

HR_VLAN

VL

Co ntr

AN act

30 or_

VL

AN

Campus WLAN Mobility

Secure WLAN Access

Several secure deployment options—LEAP, IPSec VPN with Auto Initiation, and dynamic WEP

802.1x with PEAP provides industry standard future direction for WLAN security

VLAN support in AP’s provide co-existence and migration from current installed-based security models

Corporate

Network

IPSec

Tunnel

Static

WEP

LEAP

Secured

Corporate

Resources

802.1x

Client with PEAP

Yesterday —WLAN

Security Options

Today

VLAN’s on AP’s Allow for Coexistence with 802.1x/PEAP and Current Install Base

Today —Industry

Standard WLAN

Security Direction

802.1x/EAP vs. IPSec

Layer 3

Core Network

802.1x/EAP is architecturally superior

It is a MAC-layer connection

Provides LAN functionality

802.1x/EAP vs. IPSec

WLAN

Layer 3

Core

Network

Client VPN is a gateway

IP only

Not transparent to IP

Point to point

VPN Security for WLANs

Remote

Access

Dialing into

Corporate Network from Home, Hotel,

Airport, etc.

VPN is the

Best Solution!

On-Campus

Access

Accessing

Corporate Network while inside the

Enterprise

?

VPN may not be the

Best Answer

VPN/WLAN On Campus – Pros

Familiar

Is in use at most enterprises

Makes user interface consistent for both

WLAN & remote access

Trusted for authentication & privacy

Supports central security management

Ensures 3DES encryption from client to concentrator

Compatible with wide range of client devices from multiple vendors

VPN/WLAN On Campus – Cons

Cost: Requires VPN concentrators behind APs

Performance: Client software encryption lowers throughput

Roaming: Roaming between VPN concentrators forces application restarts

QoS: All traffic is IPSec traffic; no QoS, multicast, or multiprotocol support

Client Devices: Not supported on phones, scanners, or other specialized devices

Convenience: Additional steps required beyond

Windows logon

Agenda

Introduction

Mobility

WLAN Security

Quality of Service

Closing Remarks/Q&A

802.11 QoS

Quality of Service contends with

Packet loss

Delay or latency

Delay Variance (“jitter”)

Two key issues

Prioritization

Service commitment

QoS in 802.11e and Wireless

Multimedia Extensions (WME)

To meet service commitments, the AP needs to act as a coordinator

Point Coordination Function (PCF) was too restrictive, had scaling issues and required

Distributed Coordination Function (DCF), an access contention method using CSMA/CA

Enhanced DCF and Hybrid Coordination

Function (HCF) are more flexible and are being written into 802.11e and WME to support voice over WLAN

Agenda

Introduction

Mobility

WLAN Security

Quality of Service

Closing Remarks/

Q&A

Wireless LAN Direction

Ubiquity - Usability + Serviceability

Integration into devices, and OSs

Multi-mode radios

Dynamic coverage

Transparent roaming

Transparent mobility

Transparent security mechanisms

Management interface for clients

Transparent QoS

Structured Wireless-Aware Network

Management Products

“Air”/RF Management

Rogue AP/Network Detection

Assisted Site Surveys

Secure Mobility

Cisco Secure ACS, CiscoWorks LAN Management

Solution and WLSE

Multilayer Switching Products

Secure Mobility

L2 Mobility

L3 Mobility (Future)

Catalyst 37xx, 4xxx, 65xx

Wireless APs

AP1200 AP1100

Cisco & Cisco

Compatible Clients

Increase “Air”/RF Measurement effectiveness by

10X to 20X in most cases

Cisco Compatible Program (CCX) for WLAN Client Cards

No cost licensing of Cisco wireless technology, via

Cisco Compatible eXtensions (“CCX”) specification for use in non-Cisco wireless client devices

Independent testing to ensure interoperability with

Cisco infrastructure

Marketing of these devices by Cisco and the client suppliers under the Cisco Compatible brand

Wireless Integrated Network Solutions

(WINS) Lab

Cisco WINS Lab in San Jose

Showcase for WLAN products and solutions from Cisco and partners

Exhibits for:

Enterprise

Healthcare

Education

Retail/supply chain mgmt.

Transportation

Bridging

Network management

Site survey tools

White Papers and Training

Check these sites for excellent technical references:

www.cisco.com/go/safe

www.cisco.com/go/aironet

www.cisco.com/en/US/products/hw/wireless/ps430/pro d_white_papers_list.html

Cisco Qualified Specializations (CQS) for Wireless

Design and Support

www.cisco.com/go/certifications

Summary:

Cisco Wireless Security Suite

On-Campus

802.1X

WPA

TKIP or

AES

Strong Security

Low Cost

Interoperability

Mobility

Scalability

CCX

Remote Access

Remote

Access

VPN is the Best

Solution for

Remote Access!

Thank You

Q&A

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
