SureTemp Plus 690 specifications

SureTemp Plus 690 specifications
®
The SureTemp Plus 690—
setting the standard
SureTemp Plus 690 specifications
®
Calibration Accuracy ................................................................±0.2 °F (±0.1 °C) (Monitor Mode)
Temperature Predict Time:
Oral..............................................................................................................................................Approx. 4-6 secs
of care even higher
Adult Axillary (18 years and older) ..........................................................Approx. 15 secs
Pediatric Axillary (17 years and younger) ......................................Approx. 10 secs
Rectal..........................................................................................................................................Approx. 10 secs
Unit Dimensions ......................................................................................................................8.46" x 3.18" x 2.43"
(215 mm x 81 mm x 62 mm)
Weight ............................................................................................................................................................12.6 oz (357 g)
Ambient Temperature Range ..........................................50.0 °F (10 °C) to 104 °F (40.0 °C)
Patient Temperature Range..........................................80.0 °F (26.7 °C) to 110 °F (43.3 °C)
Power Source ............................................................................................................(3) 1.5 Vdc AA batteries
Battery Life ........................................................................................................Approx. 6,000 temperatures
Warranty ....................................................................................................................2-year limited instrument,
1-year limited probe,
and
90-day
limited
probe well
ordering
information
thermometers
accessories
AL-61936 SureTemp Plus Electronic Thermometer
AL-61948 Wall Holder
AL-61949 Holder for Spare Probe and Well
AL-61950 Calibration Key Assembly, 690/692
AL-61951 Probe and Well Kit, 4 ft, Rectal
AL-61952 Probe and Well Kit, 9 ft, Rectal
AL-61953 Probe and Well Kit, 4 ft, Oral
AL-61954 Probe and Well Kit, 9 ft, Oral
AL-61955 Probe Well, Blue
AL-61956 Probe Well, Red
AL-61957 Thermometer Stand with Holder for Spare
Probe and Well
AL-61958 Bracket, M600 Stand Upgrade,with Holder for
Spare Probe and Well
(Model 690), Oral Probe with Oral
Probe Well, 2-Year Limited Warranty
AL-61937 SureTemp Plus Electronic Thermometer
(Model 690), Rectal Probe with Rectal
Probe Well, 2-Year Limited Warranty
AL-61938 SureTemp Plus Electronic Thermometer
(Model 690), One Per Room, Wall Mount,
9ft Oral Probe with Oral Probe Well,
2-Year Limited Warranty (must be locked
to the wall)
AL-61940 SureTemp Plus Electronic Thermometer
(Model 690), One Per Room, Wall Mount,
replacement probe covers
9ft Rectal Probe with Rectal Probe Well,
2-Year Limited Warranty (must be locked
AL-50302 Case of 1,000 Probe Covers
AL-79964 Case of 7,500 Probe Covers
to the wall)
AL-61941 SureTemp Plus Electronic Thermometer
(Model 690), Wall Mount, Oral Probe with
Oral Probe Well, 2-Year Limited Warranty
AL-61942 SureTemp Plus Electronic Thermometer
(Model 690), Wall Mount, 9ft Oral Probe with
Oral Probe Well, 2-Year Limited Warranty, with
Rolling Stand and Holder for Spare Probe &
Well
Call ALCO Sales to order the SureTemp Plus 690
6851 High Grove Boulevard
Burr Ridge, IL 60527 USA
(p) 800-3234282 • (f) 800-950-1167
®
www.alcosales.com
Introducing the
SureTemp Plus 690
Electronic Thermometer
®
Now taking temperatures is easier, safer, and more accurate.
And taking care of all your patients is more convenient.
The SureTemp Plus 690—
®
Interchangeable probe with
push-button probe cover
ejection
with the speed and
Removable probe
well for easy cleaning
accuracy you require, and
the versatility you need for
Convenient storage for
25 probe covers
use with all your patients,
all the time.
When we set out to improve the SureTemp, we knew we had our
•
Easy to use, intuitive operation
work cut out for us. After all, when you start with the
thermometer that helped set the standard for speed and
accuracy, the expectations run pretty high.
•
Removable probe well reduces
the risk of cross-contamination
So how did we do? See for yourself by taking a look at the
Improved accuracy for even more
reliable readings
User-selectable icon and/or words for
identification of thermometer mode
Large, easy-toread LCD
C/F button for toggling
between Fahrenheit
and Celsius
Mode button for selecting
oral, pediatric axillary, or
adult axillary
Prominent recall button
for display of last
temperature taken
innovative SureTemp Plus 690—easier, safer and more accurate
than the original, and still built to withstand constant use in
•
Battery life
indicator
demanding environments.
Ergonomic
design with
rubberized grips
Easy: An easy-to-read LCD display with flashing
icons that clearly communicate in any language,
and an intuitive user interface and ergonomic shape
•
Greater versatility for use with
all your patients, all the time
make using the SureTemp Plus 690 a breeze.
Safe: Patient safety is improved thanks to an
interchangeable probe well that reduces the risk
of cross-contamination.
Fast and Accurate: In addition to improved accuracy,
Optional wall
mount has storage
space for 50
additional probe
covers
Interchangeable rectal
probe and well reduce risk
of cross-contamination
the SureTemp Plus 690 is one of the fastest thermometers
on the market, providing approximately 4-6 second
oral, 10-second pediatric axillary, 15-second adult
axillary, and 10-second rectal measurements.
Versatile: To top it all off, you can now use the
SureTemp Plus 690 with all your patients, from
infants to adults—whether you need to take oral,
axillary or rectal temperatures.
®
The SureTemp Plus 690
