IPv4 and IPv6 Transition & Coexistence

IPv4 and IPv6 Transition & Coexistence

IPv4 and IPv6 Transition & Coexistence

Copy …Rights

This slide set is the ownership of the 6DEPLOY project via its partners

The Powerpoint version of this material may be reused and modified only with written authorization

Using part of this material must mention 6DEPLOY courtesy

PDF files are available from www.6deploy.eu

Looking for a contact ?

• 

Mail to : [email protected]

• 

Or [email protected]

Contribs & updates

Jordi Palet, Consulintel

Alvaro Vives, Consulintel

Bernard Tuy, RENATER

Tim Chown, SOTON ECS

Laurent Toutain, Telecom B.

28/08/2010: Updated 6RD & Added

DS-LITE, NAT64/DNS64

18/03/2010: Added 6RD, 6PE,

Softwires and Teredo content

15/04/2009: modified a couple of slides

(see the comment zone of those)

09/2008

Agenda

Introduction

Approaches to deploying IPv6

•  Standalone (IPv6-only) or alongside IPv4

•  Phased deployment plans

Considerations for IPv4 and IPv6 coexistence

Approaches to coexistence

•  1: Dual-Stack

•  2: Tunnelling

•  3: Translation

Specific examples

•  6to4 and Tunnel broker, ISATAP, Softwires, 6RD, DS-LITE,

NAT64/DNS64, 6PE

•  NAT-PT, Application Layer Gateways (ALGs)

05/04/11

Training Location 4

Introduction

Terminology

Transition vs Integration/Coexistence

•  One suggests a change from one protocol to another

•  The other suggests a graceful introduction where both protocols exist together for a period of time

•  The peaceful coexistence of IPv4 and IPv6 is a must

IPv6 Deployment Today

•  Implies ‘legacy’ IPv4 will be present

•  Applications may choose which protocol to use

IPv6 Perspective

•  IPv6 protocols can be added to and are inherently extensible

•  It is thus generally easier to consider integration from the IPv6 perspective

05/04/11

Training Location 5

IPv6 only?

When deploying IPv6, you have two choices:

•  Deploy IPv6-only networking

•  Deploy IPv6 alongside IPv4

Currently IPv6 is not mature in certain commercial application and management products, though support on host OS and router platforms is very good

•  This will influence current decisions towards dual-stack (use IPv6 where available, else IPv4)

•  This situation is continuously improving over time

05/04/11

Training Location 6

Deploy IPv6 standalone

Typically IPv6 will be deployed today dual-stack

But one option is to deploy an IPv6-only network

This introduces specific requirements:

•  All components (network, OS, apps) must be IPv6-capable

•  Likely to need to talk to legacy IPv4-only systems

  Need a way to ‘translate’ between the protocols at some layer

•  Likely to want to communicate with remote IPv6 network

‘islands’ that may only be connected through existing IPv4 networks

  Need a way to send IPv6 packets over/through an intermediate

IPv4-only network

•  IPv6-only deployments are rare today, but will come

05/04/11

Training Location 7

Deploy IPv6 alongside IPv4

Existing network runs IPv4

(Incrementally) introduce IPv6 to the same network, deploying IPv6 in parallel to IPv4

•  Known as ‘dual-stack’ operation

•  Hosts and routers are able to talk using either protocol

Choice of protocol is application-specific

•  DNS returns IPv4 and IPv6 addresses for a given hostname

•  As an example, MS Internet Explorer by default prefers IPv6 connectivity, but can fall back to IPv4 (after a timeout)

•  Thus need to be confident IPv6 connectivity is good, else the application may perform worse than in an IPv4-only network

05/04/11

Training Location 8

Phased IPv6 deployment

Each site or network will need to form its own plan for IPv6 deployment

Need to consider various factors, e.g:

•  Technical

  Do we need upgrades? Applications?

•  Policy

  How do we handle (manage and monitor) IPv6 traffic?

•  Education

  Are our support people trained to operate IPv6?

Then schedule the process

05/04/11

Training Location 9

Phase 1: advanced planning

Phase 1 includes:

•  Add IPv6 capability requirements to future tenders

  Ensure you have capability to deploy

•  Obtain IPv6 address space from your ISP/NREN (LIR) or from your RIR if you’re a ISP

  Typically a /48 size prefix (from the LIR)

  And a /32 size prefix (from the RIR)

•  Arrange IPv6 training

•  Encourage in-house experiments by systems staff

  e.g. using Tunnel Broker services

•  Review IPv6 security issues

  IPv6 is often enabled by default - your users may be using IPv6 without your knowledge…

05/04/11

Training Location 10

Phase 2: Testbed/Trials

Phase 2 includes:

•  Deploy IPv6 capable router, with cautious ACLs applied

•  Establish connectivity (probably a tunnel) to your ISP

•  Set up an internal link with host(s), on a /64

  Can be isolated from regular IPv4 network (e.g. a dual-stack DMZ running IPv4 and IPv6 together)

•  Enable IPv6 on the host systems, add DNS entries if appropriate

And in parallel

•  Survey systems and applications for IPv6 capabilities

•  Formulate an IPv6 site addressing plan

•  Document IPv6 policies (e.g. address assignment methods)

05/04/11

Training Location 11

Phase 3: Production rollout

Prudent to enable IPv6 on the wire first, then services

Phase 3 includes:

•  Plan initial deployment areas, e.g. your existing IPv4 DMZ or

WLAN may be good first steps

•  Enable external IPv6 connectivity and ACLs/filters

•  Enable IPv6 routing ‘on the wire’ on selected internal links

•  Deploy IPv6 support in management/monitoring tools

Then enable the services and advertise via DNS:

•  Enable IPv6 in selected services (e.g. web, SMTP)

•  Add IPv6 addresses to DNS, enable IPv6 DNS transport

Remember IPv6 security:

•  e.g. include IPv6 transport in all penetration tests

05/04/11

Training Location 12

Various transition approaches

1: Dual Stack

•  Servers/devices speaking both protocols

2: Tunnels (“connecting the IPv6 islands”)

•  IPv6 encapsulated over IPv4 links

•  IPv6 packet is payload of IPv4 packet

•  Requires “open” holes in firewalls

  Packets whose Protocol field is ‘41’

3: Translation methods (“IPv4-only to IPv6-only”)

•  Rewriting IP header information

•  TCP relay devices

•  Application layer gateways (ALGs)

05/04/11

Training Location 13

1: Dual-stack

Support both protocols on selected links (and nodes)

Requires support in:

•  Host platforms

•  Router platforms

•  Applications and services

  e.g. web, DNS, SMTP

Adds considerations for

•  Security in all components

•  New policies dependent on IPv6-specific features

Can run global IPv6 alongside NAT-ed IPv4

05/04/11

Training Location 14

Dual-stack issues

Application must choose which IP protocol to use

•  DNS returns IPv4 (A record) and IPv6 addresses (AAAA record)

•  e.g. MS Internet Explorer prefers IPv6

•  Don t advertise AAAA record for a host unless you have good

IPv6 connectivity (for all services on host)

Enabling IPv6 should not adversely impact IPv4 performance

•  Consider whether IPv6 tunnels use router CPU for example

Security should be no worse

•  Hosts listen on both protocols; secure both

05/04/11

Training Location 15

Aside: IPv4 mapped addresses

An IPv6 address used to represent an IPv4 address

A socket API may receive an IPv4 connection as an

IPv6 address, known as an IPv4-mapped address

•  Format is ::ffff:<ipv4-address>

•  e.g. ::ffff:152.78.64.1

NB: This is one socket for both address families

Should not be seen ‘on the wire’, i.e. not as source or destination address

May appear in log files, depending on how the application handles a connection

Typically seen in dual-stack deployments

Training Location 16

05/04/11

2: Tunnelling

Initially IPv6 in IPv4, (much) later IPv4 in IPv6

So, IPv6 packets are encapsulated in IPv4 packets

•  IPv6 packet is payload of IPv4 packet

Usually used between edge routers to connect IPv6 ‘islands’

•  Edge router talks IPv6 to internal systems

•  Encapsulates IPv6 in IPv4 towards remote tunnel endpoint

05/04/11 Training Location 17

Packet delivery over the tunnel

IPv6 node A sends packet to IPv6 node B

•  Routed internally to edge router A

Edge router A sees destination network B is reachable over tunnel interface

•  Encapsulates IPv6 packet in IPv4 packet(s)

•  Sends resulting IPv4 packet(s) to edge router B

•  Delivered over existing IPv4 Internet infrastructure

Edge router B decapsulates IPv6 packet from payload of received IPv4 packet

•  Packet routed internally in network B to node B

•  Node B receives the IPv6 packet

05/04/11

Training Location 18

Tunnel addressing view

05/04/11

Training Location 19

Fragmentation

IPv6 requires that packet fragmentation only occurs at end systems, not on intermediate routers

•  Use Path Maximum Transmission Unit (PMTU) Discovery to choose the MTU

•  Achieved using special ICMP messages

•  Minimum MTU is 1280 bytes in IPv6

When tunnelling IPv6 in IPv4, the IPv4 packets may be fragmented

•  Depends on the IPv4 packet size

•  Additional IPv6 headers (e.g. Authentication Header) will affect this

05/04/11

Training Location 20

Tunnel solution considerations

These include:

•  Security

•  Manual or automatic setup

•  Ease of management

•  Handling dynamic IPv4 addresses

•  Support for hosts or sites to be connected

•  Scalability: 10, 100, or 10,000 served tunnels?

•  Support for NAT traversal

•  Tunnel service discovery

•  Support for special services (e.g. multicast)

•  Tunnel concentration/bandwidth usage issues

We’ll come back to these later…

05/04/11

Training Location 21

Manual or automatic?

Can create tunnels manually or automatically

Manual tunnels

•  Requires manual configuration, at both ends

  Usually just one command/config line in the router at each end

  Agreement on addresses to use for interfaces

•  Good from a management perspective: you know who your tunnels are created with

Automatic tunnelling

•  Tunnels created on demand without manual intervention

•  Includes 6to4 (RFC3056)

  Quite popular in SOHO deployments

•  Also: ISATAP, Teredo, Softwires and 6RD

•  We can consider 6PE under this category

05/04/11

Training Location 22

Configured tunnels

Very easy to setup and configure

Good management potential

•  ISP configures all tunnels, so is in control of its deployment

•  This is the current approach used by many NRENs (including

UKERNA and RENATER) to connect academic sites/users over

IPv6 where native IPv6 connectivity is not available

Usually used router-to-router or host-to-router

•  Desirable to allow end user to register (and subsequently authenticate) to request a tunnel

•  The IPv6 Tunnel Broker (RFC3053) offers such a system, usually for host-to-router connectivity, but sometimes for router-torouter.

05/04/11

Training Location 23

Tunnel broker

Very popular in IPv6 user community

Most well-known broker is www.freenet6.net

•  Hosted in Canada by GoGo6

General mode of operation is:

•  User/client registers with the broker system

•  A tunnel is requested from a certain IPv4 address

•  The broker sets up its end of the requested tunnel on its tunnel server

•  The broker communicates the tunnel settings to the user, for client-side configuration

Can traverse a NAT, e.g. if UDP tunnelling used

05/04/11

Training Location 24

Broker: systems view

1.

  User connects to Tunnel Broker web interface requesting tunnel

2.

  TB returns script to create tunnel to the Tunnel Server, and informs TS of new client

3.

  Client executes script, and gains access to IPv6 networks via the TS

05/04/11

Training Location 25

Broker: Logical view

05/04/11

Training Location 26

Broker issues

Broker’s key advantage is its manageability

•  ISP can track usage levels

A few downsides:

•  If broker is topologically remote, round trip times for data may suffer

  e.g. using freenet6 in Canada to reach UK sites

•  Not well-suited if IPv4 address is dynamic

  Common problem in home DSL networks

•  Client tool required to operate through a NAT

•  If using a remote tunnel broker, your own ISP may not perceive a demand for IPv6

05/04/11

Training Location 27

Automatic tunnelling

Goal is to avoid requiring support staff effort to setup and maintain tunnels

Set up required tunnels on demand

Make deployment and usage simple(r) for the end user

Most common automatic method is 6to4 (RFC3056)

•  Generally used router-to-router

•  Well supported in commercial routing platforms

Other methods include ISATAP (RFC4214), 6RD (RFC5969),

6PE(RFC4798), Softwires (RFC5571) and Teredo (RFC4380)

05/04/11

Training Location 28

6to4

In its basic configuration, 6to4 is used to connect two IPv6 islands across an IPv4 network

Uses special ‘trick’ for the 2002::/16 IPv6 prefix that is reserved for 6to4 use

•  Next 32 bits of the prefix are the 32 bits of the IPv4 address of the 6to4 router

•  For example, a 6to4 router on 192.0.1.1 would use an IPv6 prefix of 2002:c000:0101::/48 for its site network

When a 6to4 router sees a packet with destination prefix 2002::/16, it knows to tunnel the packet in

IPv4 towards the IPv4 address indicated in the next 32 bits

05/04/11

Training Location 29

6to4 basic overview

05/04/11

Training Location 30

6to4 features

Simple to deploy and use

•  Fully automatic; no administrator effort per tunnel

•  Tunnelled packets automatically

•  Route efficiently to the destination network (following best IPv4 path)

But there’s an important capability missing:

•  How does a node on a 6to4 site communicate with an IPv6 node on a regular, ‘real’ IPv6 site?

  Without requiring all IPv6 sites to support 6to4

=> 6to4 relays have been conceived and implemented to that end

And 6to4 relays can be abused (DoS attacks)

•  See RFC3964 for appropriate checks to deploy

05/04/11

Training Location 31

6to4 relay

A 6to4 relay has a 6to4 interface and a ‘real’ IPv6 interface

Two cases to consider:

•  IPv6 packets sent from a 6to4 site to a destination address outside 2002::/16 are tunnelled using 6to4 to the relay, are decapsulated, and then forwarded on the relay’s ‘real’ IPv6 interface to the destination site

  The 6to4 relay is advertised on a well-known IPv4 anycast address

192.88.99.1.

•  IPv6 packets sent from a ‘real’ IPv6 site towards an address using the 2002::/16 prefix (a 6to4 site) are routed to the 6to4 relay and then tunnelled using 6to4 to the destination 6to4 site

  The relay advertises 2002::/16 to connected IPv6 neighbours

05/04/11

Training Location 32

6to4 with relay

05/04/11

Training Location 33

6to4 issues

In principle 6to4 is attractive

•  But there are operational concerns

Problem 1: possible relay abuse

•  Relay could be used for a DoS attack

•  Tunnelled IPv6 traffic addresses may be spoofed

Problem 2: asymmetric model/reliability

•  The 6to4 site may use a different 6to4 relay to the ‘real’ IPv6 site

•  One of the sites may not see a 6to4 relay at all, if ISPs choose to only deploy relays for their own customers, and thus filter routing information

But for 6to4 relay to 6to4 relay operation, it’s good

05/04/11

Training Location 34

Asymmetric 6to4

05/04/11

Training Location 35

6RD: a 6to4 refinement …

6RD: IPv6 Rapid Deployment on IPv4 infrastructures

•  6RD relies on IPv4 to provide production quality IPv6 and IPv4

Internet access to customer sites.

Has been standardized as RFC 5969

Implemented by FREE (a French ISP)

•  In a 5 week-time frame the service was available

Changes from 6to4:

•  Address format (again) => implementation effort

•  Uses normal IPv6 prefix scheme within 2000::/3, instead of 2002::/16

•  From user site perspective and the IPv6 Internet: perceived as native IPv6

•  Relay (or gateway) is only inside ISP backbone at the border of the IPv6

Internet

•  Multiple instances are possible: advertised with an IPv4 anycast address

•  Under strict control of the ISP

05/04/11

Training Location 36

6RD: Address Format

ISP IPv6 relay prefix

32

Site IPv4 address

32

Interface ID

64

ISP IPv6 relay prefix

32-n

Site IPv4 address

32

SN

n

05/04/11

Training Location

Interface ID

64

37

6RD: Pros & cons

Pros

•  Seems easy to implement and deploy if network gears are

« under control » (CPEs, …)

•  Solve all (?) the 6to4 issues

  security, asymmetric routing, …

  Relay (or gateway) is in the ISP network then under its control

•  Transparent for the customer

  Automatic configuration of the CPE

•  Works with public as well as private IPv4 addresses

  allocated to the customer

Cons

•  Change the code running on all the CPEs

  Only a couple of them at the time being

•  Add a new box: 6RD relay/gateway

  Until other router vendors support 6RD (Cisco already does)

05/04/11

Training Location 38

6RD: Architecture

Customer site (DS):

•  IPv6 RD prefix allocated: => native IPv6 LAN(s)

•  (+IPv4)

CPE (= 6RD CE = 6RD router):

•  Provides native IPv6 connectivity (customer side)

•  runs 6RD code (6to4 like) and

•  Has a 6RD virtual mutipoint interface to support IPv6 in IPv4 en/ decapsulation

•  Receives a 6RD IPv6 prefix from SP’s device

•  And an IPv4 address (WAN side = ISP’s network)

6RD relay (= border relay)

•  gateway between IPv4 ISP infrastructure and native IPv6

Internet

•  advertise an IPv4 address to the CPEs

  An anycast address can be used for redundancy purposes

05/04/11

Training Location 39

6RD: Implementation Scenarios

IPv4 ANYCAST ADDRESS

OF 6RD RELAYS

IPv4 ADDRESSES OF

CUSTOMER SITES

Global IPv6

Internet

Service Provider

IPv6 Prefix

Announced

DUAL-STACK

CUSTOMER

SITES

6RD CPEs

(modified 6to4)

05/04/11

ISP IPv4

Infrastructure

Training Location

6RD RELAYS

(modified 6to4)

40

Softwires

Softwires is not a new protocol

•  but the definition of how to use existing protocols in order to provide IPv6 connectivity on IPv4 only networks and vice versa

•  It is based on L2TPv2 and L2TPv3

Some characteristics

•  IPv6-in-IPv4, IPv6-in-IPv6, IPv4-in-IPv6, IPv4-in-IPv4

•  NAT traversal on access networks

•  Provides IPv6 prefix delegation (/48, /64, etc.)

•  User authentication for tunnel creation using AAA infrastructure

•  Possibility of secure tunnels

•  Low overhead of IPv6 packets over the tunnels

•  Supports portable devices with scarce hardware resources

L2TP-based softwires (RFC5571)

•  Two entities: Softwires Initiator (SI), Softwires Concentrator (SC)

•  PPP is used to transport IPvx (x=4 or 6) in IPvx (x=4 or 6) packets

05/04/11

•  Optionally PPP packets can be encapsulated on UDP for NAT traversal

Training Location 41

Softwires: Basic Overview

DUAL-STACK

CUSTOMER

SITES

05/04/11

Softwire Tunnel

CPE and SI

CPE and SI

Softwire Tunnel

ISP IPv4

Infrastructure

Training Location

Global IPv4

Internet

SC

(Softwire Concentrator)

Global IPv6

Internet

42

Teredo

Teredo is defined in RFC4380

•  Thought for providing IPv6 to hosts that are located behind a NAT box that is not able to support proto-41 forwarding

Some characteristics

•  Encapsulates the IPv6 packets into UDP/IPv4 packets

•  Uses different agents: Teredo Server, Teredo Relay, Teredo

Client

•  User configures in its host a Teredo Server which provides an IPv6 address from the 2001:0000::/32 prefix, based on the user s public IPv4 address and used UDP port

•  By means of IPv6 anycast, Teredo Relays are announced, so the user has also IPv6 connectivity with any IPv6 host, otherwise, the user only has IPv6 connectivity with other Teredo users

•  Microsoft currently provides public Teredo Servers for free, but not

Teredo Relays

•  There are already other open Teredo Relays

Training Location 43

05/04/11

Teredo: Basic Overview

Native IPv6

Teredo

Server

Teredo

RELAY

IPv6 Internet

IPv4 Internet

IPv6 Host

Teredo

RELAY

Teredo Tunnel

05/04/11

TEREDO

Setup

Teredo

Client

NAT

BOX A

NAT

BOX B

TEREDO

Setup

Teredo Tunnel

Teredo

Client

Training Location 44

Dual Stack Lite

•  To cope with the IPv4 exhaustion problem.

•  Sharing (same) IPv4 addresses among customers

by combining:

•  Tunneling

•  NAT

•  No need for multiple levels of NAT.

•  Two elements:

•  DS-Lite Basic Bridging BroadBand (B4)

•  DS-Lite Address Family Transition Router (AFTR)

•  Also called CGN (Carrier Grade NAT) or LSN (Large Scale NAT)

05/04/11

Training Location 45

DS-Lite Overview

IPv4 Internet

IPv6 Internet

05/04/11

IPv4-in-IPv6

Tunnel

AFTR

AFTR

ISP Core

CPE

IPv6-only access

CPE v4 v4

10.0.0.0/16 v4 v4/v6

10.0.0.0/16

Training Location

IPv6 Traffic

46

NAT64 (1)

•  When ISPs only provide IPv6 connectivity, or

devices are IPv6-only (cellular phones).

•  But still some IPv4-only boxes are on the Internet.

•  Similar idea as NAT-PT, but working correctly.

•  Optional element, but decoupled, DNS64.

05/04/11

Training Location 47

NAT64 (2)

•  Stateful NAT64 is a mechanism for translating IPv6

packets to IPv4 packets and vice-versa.

•  The translation is done by translating the packet headers according to the IP/ICMP Translation Algorithm.

•  The IPv4 addresses of IPv4 hosts are algorithmically translated to and from IPv6 addresses by using a specific algorithm.

•  The current specification only defines how stateful NAT64 translates unicast packets carrying TCP, UDP and ICMP traffic.

•  DNS64 is a mechanism for synthesizing AAAA resource records

(RR) from A RR. The IPv6 address contained in the synthetic AAAA

RR is algorithmically generated from the IPv4 address and the

IPv6 prefix assigned to a NAT64 device

•  NAT64 allows multiple IPv6-only nodes to share an

IPv4 address to access the IPv4 Internet.

05/04/11

Training Location 48

NAT64 Overview

DNS64

IPv6 Internet

NAT64

IPv4 Internet v4 v6

05/04/11

Training Location 49

Looking back at considerations

Earlier we asked how do tunnelled transition mechanisms fare for:

•  Security

•  Manual or automatic setup

•  Ease of management

•  Handling dynamic IPv4 addresses

•  Support for hosts or sites to be connected

•  Scalability: 10, 100, or 10,000 served tunnels?

•  Support for NAT traversal

•  Tunnel service discovery

•  Support for special services (e.g. multicast)

•  Tunnel concentration/bandwidth usage issues

05/04/11

Training Location 50

Comparison for discussion

Feature

Security

Setup

Ease of management

Dynamic IPv4 addresses

Host or site tunnels

Scalability

NAT traversal

Tunnel service discovery

Special service support

Bandwidth concentration

6to4 Teredo Softwires

Potential for abuse Potential for abuse

Automatic Automatic

Poor (automatic)

Good

Automatic

Poor (automatic) Good

Poor ?

Primarily site

Very good

Tricky

Automatic

Variable

Only at 6to4 relay

05/04/11

Poor ?

Host

Very Good

Very Good

Automatic

Variable

Teredo Server/

Relay

Poor ?

Primarily site

Good

Very Good

6RD

Supported (the same used in the IPv4 net)

Automatic

Good

Poor ?

Primarily host

Very Good

Not a problem

Tunnel broker

Supports authentication

Manual / automatic

Good (but …)

Poor

Primarily host

Good

Yes, with TSP

Configured Automatic

Variable Variable

Sofwires

Concentrator

Training Location

On 6RD relays

(could be replicated)

Manual configuration

Variable

At tunnel server

51

ISATAP

Intra-Site Automatic Tunnel Addressing Protocol

(RFC4214)

•  Automatic tunneling

•  Designed for use within a site

•  Used where dual-stack nodes are sparsely deployed in the site

(very early deployment phase)

Host-to-host or host-to-router automatic tunnels

•  Uses a specific EUI-64 host address format

•  Format can be recognised and acted upon by ISATAP-aware nodes and routers

05/04/11

Training Location 52

ISATAP addresses

The EUI-64 is formed by

•  A reserved IANA prefix (00-00-5e)

•  A fixed 8-bit hex value (fe)

•  The

32 -bit IPv4 address of the node

•  Toggling the globally unique (u) bit

For example, 152.78.64.1 would have an EUI-64 host address for IPv6 of:

•  0200:5efe:984e:4001

05/04/11

Training Location 53

ISATAP tunneling

Relies on the OS supporting ISATAP

Use one ISATAP router per site, usually advertised under FQDN isatap.domain

•  Virtual IPv6 link over the IPv4 network

•  Know the IPv4 tunnel end-point address from last 32-bits of the

IPv6 ISATAP address

•  Get network prefix via ND from router

Not widely deployed

Better to deploy proper dual-stack

•  Allows better managed control of deployment

05/04/11

Training Location 54

6PE: IPv4/MPLS Network deployed

Strategies:

1. Native IPv6 routing:

•  Without MPLS. Needs IPv6 support on all network devices and configuration of all of them. No MPLS benefits.

2. Native IPv6 routing and MPLS over IPv6:

•  Replication of the IPv4/MPLS scheme for IPv6 traffic. Needs IPv6 and MPLS support on all devices and configuration of all of them.

3. Use the existing IPv4/MPLS infrastructure to forward IPv6 traffic:

3.1 IPv6 Provider Edge Routers (6PE): 6PE or edge routers of the IPv4/

MPLS cloud must be dual-stack and support Multiprotocol-BGP

3.2 IPv6 over a Circuit Transport over MPLS: Dedicated interfaces are created using static circuits configured over MPLS (AToM or EoMPLS). No configuration changes on routers of the MPLS cloud. Static and not scalable mechanism.

3.3 IPv6 Using Tunnels on the Customer Edge Routers: User s routers are in charge of creating 6in4 tunnels between IPv6 networks, transparently to the IPv4/MPLS cloud. Static and not scalable mechanism.

05/04/11

Training Location 55

6PE: Strategies

05/04/11

Training Location 56

6PE: IPv6 Provider Edge Routers

Defined on RFC4798

Communication between the remote IPv6 domains over IPv4 MPLS IPv4 core network

•  Uses MPLS label switched paths (LSPs)

•  This feature relies on multiprotocol BGP extensions in the IPv4 network configuration on the provider edge (PE) router to exchange IPv6 reachability information in addition to an MPLS label for each IPv6 address prefix to be advertised

PE Edge routers

•  Are configured to be dual stack running both IPv4 and IPv6

•  Uses the IPv4 mapped IPv6 address for IPv6 prefix reachability exchange

05/04/11

Training Location 57

6PE

6PE-1 learns from 6PE-2 through MBGP the following:

Prefix Next-Hop Tag-IPv6

------- -------- --------

2001:db8:3::/64 ::FFFF:IPv4-2 tag-2

2001:db8:4::/64 ::FFFF:IPv4-2 tag-1

05/04/11

Training Location 58

3: Translation

When an IPv4-only system needs to communicate with an IPv6-only system, translation is required

Can be done at various layers

Network layer

•  Rewrite IP headers

Transport layer

•  Use a TCP relay

Application layer

•  Use an application layer gateway (ALG)

Ideally avoid translation

•  Use IPv4 to speak to IPv4 systems and IPv6 for IPv6 systems

05/04/11

Training Location 59

Translation scenarios

Generally when deploying IPv6-only network elements and you need them to communicate with IPv4-only systems

•  Legacy applications that cannot be ported to support IPv6

  Or perhaps source code not available

•  Legacy IPv4-only operating systems

  For example Windows 98

•  Legacy IPv4-only hardware

  Printers

05/04/11

Training Location 60

Network layer: NAT-PT

Network Address Translation - Protocol

Translation

•  Defined in RFC2766

•  Like IPv4 NAT, but with protocol translation

Uses Stateless IP/ICMP Translation (SIIT)

•  Defined in RFC2765

•  SIIT defines algorithms to translate between the IPv4 and IPv6 header fields, where it s possible

NAT-PT extends SIIT with IPv4 address pools

•  IPv4-to-IPv6 and IPv6-to-IPv4 supported

05/04/11

Training Location 61

NAT-PT topology

05/04/11

Training Location 62

NAT-PT and DNS

Internal network IPv6 only

DNS ALG watches for IPv6 (AAAA) DNS queries, and translates to IPv4 (A) queries

When IPv4 DNS response comes back, DNS

ALG maps the result to an IPv6 address

•  <IPv6-prefix>:<IPv4 address>

•  A special NAT-PT IPv6 prefix is taken from the IPv6 network s address space

Querying host now uses an IPv6 destination that NAT-PT maps to real IPv4 destination

05/04/11

Training Location 63

NAT-PT downsides

Has all shortcomings of IPv4 NAT, and more

•  IP addresses may be embedded in payload (e.g. FTP)

•  DNS considerations are complex

Can use from IPv4 network into IPv6 network

•  If enough IPv4 global addresses available to advertise special NAT-PT prefix addresses externally

It s considered a last resort mechanism

•  NAT-PT has been deprecated historical within the

IETF (see RFC4966 for details)

05/04/11

Training Location 64

Transport layer: TRT

Transport Relay Translator (TRT)

•  Designed for use in IPv6-only networks wishing to connect to external IPv4-only systems

•  TRT has internal IPv6 and external IPv4 interfaces

External IPv6 connections work as usual

Trick is handling connections to IPv4 nets

•  Relies on use of a DNS proxy

•  Internal IPv6 host looks up destination IP address

•  If an IPv6 address, traffic is sent to IPv6 Internet

•  If an IPv4 address, traffic is routed to the TRT

05/04/11

Training Location 65

TRT topology

05/04/11

Training Location 66

DNS proxy address mapping

If internal IPv6 host is trying to reach an

IPv4-only system, the DNS proxy (ALG) returns a special IPv6 destination

•  First 64 bits assigned to be unique locally

•  Next 32 bits all zero

•  Last 32 bits are the real IPv4 destination

  <IPv6-prefix>:0:0:<IPv4 address>

<ipv6-prefix> is routed internally to the TRT

•  Which terminates the TCP/IPv6 connection

•  And opens connection to the real IPv4 destination

05/04/11

Training Location 67

TRT pros and cons

Pros

•  Transparent to hosts/applications

•  Scalable - can use multiple TRTs, with one internal /

64 prefix used per TRT device

•  TRT can work with one global IPv4 address

Cons

•  Like NAT, problems with embedded IP addresses in payload (e.g. FTP)

•  No simple way to allow connections initiated inbound from external IPv4 to internal IPv6 hosts

05/04/11

Training Location 68

Application: ALGs

NAT-PT and TRT are somewhat complex

Luckily, application layer gateways (ALGs) offer a simpler alternative

Many applications support ALGs already

•  Web cache

•  SMTP gateway

•  DNS resolver

•  SIP proxy

•  etc

We can leverage this in a simple way

05/04/11

Training Location 69

ALG topology

05/04/11

Training Location 70

ALG pros and cons

Pros

•  Simple to deploy

•  ALGs already commonly in use, e.g.

  Web cache to reduce bandwidth usage

  SMTP relay to channel mail through one server

•  Avoids complexity of NAT-PT or TRT

Cons

•  Requires client configuration to use ALG

•  Only works for specific ALG-supported applications - not suited for peer-to-peer apps

05/04/11

Training Location 71

But what’s the best method?

We have a “toolbox” of IPv6 transition methods

Some suited to certain scenarios

IPv4 hosts will be around for a long time, with transition ongoing for many years (10-20+ years)

Usage depends on scenario

•  A university may run dual-stack internally, and use a manual tunnel to their NREN until a native connection is available

•  A home user with IPv6 enabled on his laptop may use a tunnel broker to gain IPv6 connectivity to their home

•  Alternatively, a SOHO environment may be suited to 6to4

  Especially where a static IPv4 address is available

There is no single ‘best’ solution

05/04/11

Training Location 72

Finally: perspectives

Potentially deployed by a (campus) site:

•  Dual-stack networking

•  Manual tunnels

•  ALGs

•  

6to4 router (for small, typically SOHO, sites)

•  

NAT-PT (for IPv6-only subnets without ALG capability)

Potentially offered/supported by an ISP:

•  Tunnel broker server

•  Manual tunnels

•  Softwires

6RD

6to4 relay

•  

6PE

•  

Teredo

05/04/11

Training Location 73

Conclusions

There is a large set of IPv6 transition tools available

•  No single ‘best’ solution

•  Transition plan is likely to be site-specific

Current ‘best practice’ is dual-stack deployment

•  Natural path via procurement cycles

•  Allows experience in IPv6 operation to be gained early

IPv6-only networks can be deployed

•  But very limited in number to date, and missing some apps

Ultimate driver is IPv4 address space availability

•  But also need IPv4 addresses for a smooth transition

05/04/11

Training Location 74

05/04/11

Questions …

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
