Dakota 10 and 20
®
owner’s manual
© 2009–2010 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151st Street,
Olathe, Kansas 66062, USA
Tel. (913) 397.8200 or
(800) 800.1020
Fax (913) 397.8282
Garmin (Europe) Ltd.
Liberty House
Hounsdown Business Park,
Southampton, Hampshire,
SO40 9LR UK
Tel. +44 (0) 870.8501241 (outside the UK)
0808 2380000 (within the UK)
Fax +44 (0) 870.8501251
Garmin Corporation
No. 68, Jangshu 2nd
Road,
Sijhih, Taipei County,
Taiwan
Tel. 886/2.2642.9199
Fax 886/2.2642.9099
All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced,
copied, transmitted, disseminated, downloaded or stored in any storage medium, for any purpose without
the express prior written consent of Garmin. Garmin hereby grants permission to download a single copy
of this manual onto a hard drive or other electronic storage medium to be viewed and to print one copy of
this manual or of any revision hereto, provided that such electronic or printed copy of this manual must
contain the complete text of this copyright notice and provided further that any unauthorized commercial
distribution of this manual or any revision hereto is strictly prohibited.
Information in this document is subject to change without notice. Garmin reserves the right to change
or improve its products and to make changes in the content without obligation to notify any person
or organization of such changes or improvements. Visit the Garmin Web site (www.garmin.com) for
current updates and supplemental information concerning the use and operation of this and other Garmin
products.
Garmin®, Dakota®, BlueChart® g2 are trademarks of Garmin Ltd. or its subsidiaries, registered in the
USA and other countries. myGarmin™ is a trademark of Garmin Ltd. or its subsidiaries. These trademarks
may not be used without the express permission of Garmin.
The Geocaching 4-box logo and the Wherigo logo are registered trademarks of Groundspeak Inc., in the
United States and other countries. Used with permission. Use of geocaching.com data is subject to the
Geocaching.com Terms of Use Agreement located at www.geocaching.com/about/termsofuse.aspx. The
Wherigo application is covered by patent 6,691,032 and US and foreign patents pending. Windows® is a
registered trademark of Microsoft Corporation in the United States and/or other countries. Mac® OS is a
registered trademarks of Apple Computer, Inc. microSD™ is a trademark of SanDisk or its subsidiaries.
October 2010
Part Number 190-01069-00 Rev. B
Printed in Taiwan
Introduction
S ee the Important Safety and
Product Information guide in
the product box for product
warnings and other important
information.
Introduction
Tips and Shortcuts
• Touch
or
to scroll and
see more choices.
• Touch
to return to the
previous screen.
• Touch
to return to the Main
menu.
• Touch
or
on the Map
page to zoom in or zoom out.
• Touch
to accept a change.
• Touch
to search near a
location.
• Touch
to view the keyboard.
Dakota Series Owner’s Manual
Manual Conventions
When you are instructed to “touch”
something, use your finger to touch
that item on the screen.
The small arrows (>) used in the
text indicate that you should touch a
series of items in order. For example,
if you see, “Touch Where To?
> Tracks,” you should touch the
Where To? button on the screen, and
then touch Tracks.
i
Introduction
Table of Contents
Introduction........................... i
Tips and Shortcuts........................i
Manual Conventions.....................i
Getting Started..................... 1
Product Registration................... 1
Contact Garmin.......................... 1
Optional Accessories.................. 1
Caring for the Dakota................. 1
Battery Information..................... 2
Turning On and Off the Dakota.. 2
Adjusting the Backlight Level..... 3
Locking the Screen..................... 3
Acquiring GPS Satellite
Signals..................................... 3
Basic Navigation................. 4
Accessing Applications
from the Main Menu................. 4
Creating Waypoints.................... 4
Navigating to a Destination........ 5
Stop Navigating.......................... 7
Using the Map ........................... 7
Using the Compass.................... 9
ii
Bearing and Course Pointers... 10
Managing Waypoints,
Routes, and Tracks........... 12
Modifying Waypoints................ 12
Creating Routes....................... 13
Viewing Stored Routes............. 13
Editing and Deleting Routes..... 13
Viewing the Active Route.......... 14
Managing Tracks...................... 14
Additional Tools................. 16
Elevation Plot........................... 16
Sharing Information
Wirelessly................................. 17
Calculating the Size of an
Area....................................... 17
Other Tools............................... 17
Monitoring Satellite
Reception............................... 18
Trip Computer........................... 19
GPS Games........................ 20
Geocaches............................... 20
Customizing the Dakota.... 21
Dakota Series Owner’s Manual
Introduction
Changing the Profile................. 21
Setting Up Profiles.................... 21
Using System Setup................. 22
Customizing the Display........... 22
Map Setup................................ 23
Track Setup.............................. 24
Customizing the Main Menu..... 24
Changing Marine Settings........ 25
Changing Time Settings........... 26
Changing Measurement
Units....................................... 26
Position Format........................ 27
Modifying the Compass............ 27
Altimeter Setup......................... 28
Pairing the Dakota.................... 29
Reset........................................ 30
Viewing Your Dakota
Information............................. 30
Transferring Files to Your
Computer............................... 34
Loading and Deleting Files....... 35
Optimizing Battery Life............. 36
Restoring Factory Default
Settings.................................. 36
Attaching a Carabiner, Lanyard,
Mount, or Other Optional
Accessory.............................. 37
Calibrating the Touchscreen..... 37
Software License Agreement... 38
Declaration of Conformity
(DoC)..................................... 38
Index................................... 39
Appendix............................ 31
Specifications........................... 31
Using Demo Mode.................... 32
Connecting Your Dakota to a
Computer............................... 33
Installing a microSD™ Card....... 33
Dakota Series Owner’s Manual
iii
Introduction
Power key
Touchscreen
mini-USB connector
(under weather cap)
Latch
Battery
cover
iv
Mounting
spine
Dakota Series Owner’s Manual
Getting Started
Getting Started
Product Registration
In Europe, go to www.garmin.com
/support and click Contact Support
for in-country support information,
or contact Garmin (Europe) Ltd. by
phone at +44 (0) 870.8501241.
Help us better support you by
completing our online registration
today. Connect to our Web site at
http://my.garmin.com. Keep the
original sales receipt, or a photocopy,
in a safe place.
If needed, the serial number of your
Dakota is located in the battery
compartment. Remove batteries as
indicated on page 2.
Contact Garmin
Optional Accessories
Contact Garmin Product Support if
you have any questions while using
your Dakota®. In the USA, go to
www
.garmin.com/support, or contact
Garmin USA by phone at (913)
397.8200 or (800) 800.1020.
In the UK, contact Garmin (Europe)
Ltd. by phone at 0808 2380000.
Dakota Series Owner’s Manual
For a list of available accessories and
maps, refer to the Garmin Web site at
http://buy.garmin.com.
Caring for the Dakota
Cleaning the screen
Use a soft, clean, lint-free cloth. Use
water, isopropyl alcohol, or eyeglass
lens cleaner. Apply the liquid to the
cloth and then gently wipe the screen
with the cloth.
1
Getting Started
Battery Information
Dakota units operate on two AA
batteries. Use alkaline, NiMH, or
lithium batteries. Use precharged
NiMH or lithium batteries for best
results.
To install the batteries:
1. Slide the latch and remove the
battery cover.
Latch
Battery cover
To select the battery type:
1. Touch Setup > System > Battery
Type.
2. Touch Alkaline, Lithium, or
Rechargeable NiMH.
Long-Term Storage
Remove batteries when you do not
plan to use the Dakota for several
months. Stored data is not lost when
batteries are removed.
Turning On and Off the
Dakota
1. To turn on the Dakota, press .
2. To turn off the Dakota, press and
hold .
2. Insert the battery. Align the
+ (positive) and - (negative)
markings on the device with the
battery.
3. Replace the battery cover.
2
Dakota Series Owner’s Manual
Getting Started
Adjusting the Backlight
Level
1. While the Dakota is on, press and
quickly release .
Locking the Screen
Lock the screen to prevent
inadvertent screen touches.
1. Press and quickly release .
2. Touch Lock Screen (or Unlock
Screen).
Acquiring GPS Satellite
Signals
Before the Dakota can find your
current location and navigate a route,
you must acquire GPS signals.
2. Touch
or
to adjust the
brightness levels.
See page 22 to change the backlight
timeout.
Dakota Series Owner’s Manual
1. Go outdoors to an open area,
away from tall buildings and trees.
2. Turn on the Dakota. Acquiring
satellite signals can take a few
minutes.
The
bars on the Main menu
indicate satellite strength. When
the bars are green, the Dakota has
acquired satellite signals.
3
Basic Navigation
Basic Navigation
Accessing Applications
from the Main Menu
You can access all Dakota
applications from the Main menu.
Main menu
4
Touch
or
to access
additional applications.
Creating Waypoints
Waypoints are locations you record
and store in the Dakota.
To mark your current location as
a waypoint:
1. Touch Mark Waypoint.
2. Touch Save and Edit.
3. Touch an item from the list to
change.
• Touch letters, numbers, or
symbols to make the changes.
• Touch
(except when
changing a symbol). Change
other attributes, if necessary.
• Touch
to discard the
changes.
To edit or delete a waypoint, see
page 12.
Dakota Series Owner’s Manual
Basic Navigation
Navigating to a
Destination
You can use Where To? or choose
a point on the map to navigate to a
destination with the Dakota.
To navigate to a destination
using Where To?:
1. Touch Where To?.
2. Touch a category.
3. Touch one of the items listed
below. This list may vary
depending on the type of maps
loaded on your Dakota.
• Recent Finds—items you
have recently found.
• Waypoints—a list of
waypoints (page 4).
• Tracks—a list of tracks
(page 14).
• Routes—a list of routes
(page 13).
Dakota Series Owner’s Manual
• All POI (Points of Interest)—if
supported by the preloaded
or optional mapping, various
POIs may be listed.
• Coordinates—enter the
coordinates of a location.
• Cities—a list of the 50 closest
cities to your current location.
• Tides—a list of the closest tide
stations.
4. Touch Go. A colored line indicates
your course.
5. Touch
> Compass.
6. Use the compass to navigate to
your destination.
To find a destination by spelling
the name:
1. On the Main menu, touch Where
To? > All POI.
2. Touch
.
3. Touch characters to spell a part of
the name of your destination.
4. Touch
.
5
Basic Navigation
5. Touch the destination.
6. Touch Go. A colored line indicates
your course.
7. Touch
> Compass.
8. Use the compass to navigate to
your destination as indicated on
page 9.
4. Touch Go >
> Compass.
5. Use the compass to navigate to
your destination as indicated on
page 9.
To navigate to a destination near
a waypoint or a recent find:
1. Touch Where To?.
To navigate to a point on the
map:
1. Touch Map.
2. Touch a point on the map.
3. Touch the information button at
the top of the screen.
Information
button
6
2. Touch
.
3. Select from the following options:
• A Recent Find
• A Waypoint
• My Current Location
• A Map Point
Dakota Series Owner’s Manual
Basic Navigation
4. Touch the location you want to
search near.
5. Touch a category. Items are listed
in order of distance from the
location you selected.
6. Touch a destination.
7. Touch Go. A colored line indicates
your course.
8. Touch
> Compass.
9. Use the compass to navigate to
your destination as indicated on
page 9.
3. Touch and drag the screen to pan
the map.
Zoom range
Stop Navigating
To review detailed information
about a point on the map:
1. If necessary, pan to the location
you want to review.
2. Touch the location.
3. Touch the information button at
the top of the screen for additional
information.
To stop navigating, touch Where To?
> Stop Navigation.
Using the Map
To use the map:
1. Touch Map. Your current location
is indicated by a location
marker .
2. Touch
or
to zoom.
Dakota Series Owner’s Manual
Zoom buttons
Location marker
7
Basic Navigation
Information
button
To show or hide data fields at the
top of the screen:
1. Touch Setup > Map > Show Data
Fields.
2. Touch Never, When Navigating,
or Always.
To change the Map page data
fields:
1. On the Map page, touch one of
the data fields.
2. Touch a data type.
8
To save a waypoint on the Map
page:
1. On the Map page, touch the point
you want to save.
2. Touch the information button at
the top of the screen.
3. Touch
to save the waypoint.
Dakota Series Owner’s Manual
Basic Navigation
Using the Compass
Calibrating the Compass
It also provides navigation data such
as current speed, distance to the next
point on the route, and estimated
arrival time.
Calibrate the electronic compass
outdoors. Do not stand near objects
that influence magnetic fields, such
as cars, buildings, or overhead power
lines.
The Compass page guides you to
your destination by displaying a
compass and a bearing pointer.
The electronic compass is similar
to a magnetic compass when you
are stationary or walking. If you
maintain a higher speed, such
as traveling in an automobile,
the compass uses GPS signals to
determine your direction. To turn the
electronic compass off, see page 28.
note: The electronic compass is
unavailable with the Dakota 10.
Calibrate the compass after moving
long distances, experiencing
temperature changes greater than
20°F (11°C), or changing the
batteries.
To open the Compass page:
Touch Compass.
Dakota Series Owner’s Manual
9
Basic Navigation
To calibrate the electronic
compass:
1. Touch Setup > Heading > Press
To Begin Compass Calibration.
OR
From the Compass page, touch
and hold the middle of the
compass.
2. Touch Start and follow the onscreen directions.
If “Calibration Failed” appears, touch
OK, and repeat the process.
Bearing and Course
Pointers
The Dakota can use either a bearing
or course pointer on the compass.
The bearing pointer indicates the
direction to your destination, and
the course pointer indicates your
relationship to a course line leading
to the destination. To select a bearing
or course pointer, see page 27.
Direction you
are currently
traveling
Bearing to
destination
Bearing Pointer
10
Dakota Series Owner’s Manual
Basic Navigation
The bearing pointer points to
your destination, regardless of the
direction you are moving. If the
bearing pointer points toward the
top of the compass, you are traveling
directly toward your destination. If
it points any other direction, turn
toward that direction until the arrow
is pointing toward the top of the
compass.
Direction you
are currently
traveling
Scale
Bearing to
destination
Course deviation
indicator
Course Pointer
Course line to
destination
Dakota Series Owner’s Manual
The course pointer provides an
indication of drift (right or left)
according to the scale shown at the
edge of the compass ring. The scale
refers to the distance between dots
on the course deviation indicator.
The course line to your destination is
based on your original starting point.
Move back to the “course line to
destination” to compensate for
deviation and to get back on course.
This is most useful if you are
navigating on water or where there
are no major obstacles in your path.
It also helps you avoid hazards to
either side of the course, such as
shoals or submerged rocks.
To change the Compass page
data fields:
1. On the Compass page, touch a
data field.
2. Touch a data type.
11
Managing Waypoints, Routes, and Tracks
Managing
Waypoints, Routes,
and Tracks
Modifying Waypoints
You can edit waypoints to change the
name, symbol, comment, location,
elevation, and depth of the waypoint.
You can also use the Waypoint
Manager to relocate a waypoint to
your current location, and to delete
waypoints.
To edit a waypoint:
1. Touch Waypoint Manager.
2. Touch the waypoint.
3. Touch the attribute.
4. Touch letters, numbers, or
symbols to make the changes.
5. Touch
(except when
changing a symbol). Change
other attributes, if necessary.
12
6. Touch
to discard the
changes.
To reposition a waypoint to your
current location:
1. Touch Waypoint Manager.
2. Touch the waypoint you want to
reposition.
3. Touch Reposition Here.
To delete a waypoint:
1. Touch Waypoint Manager.
2. Touch the waypoint you want to
delete.
3. Touch Delete Waypoint.
To delete all waypoints, touch Setup
> Reset > Delete All Waypoints >
Yes.
Dakota Series Owner’s Manual
Managing Waypoints, Routes, and Tracks
Creating Routes
You can create and store up to 50
routes.
To create and navigate a new
route:
1. Touch Route Planner > <Create
Route> > <Select First Point> to
select a starting point.
2. Touch a category.
3. Touch the first item on the route.
4. Touch Use > <Select Next
Point>.
5. Repeat until the route is
complete.
6. Touch
to save the route.
7. Touch
> Where To? >
Routes to navigate the route.
Dakota Series Owner’s Manual
Viewing Stored Routes
To view a route on the map:
1. Touch Route Planner.
2. Touch the route you want to view
> View Map.
Editing and Deleting
Routes
You can edit any of your stored
routes.
To edit a route:
1. Touch Route Planner.
2. Touch the route you want to edit >
Edit Route.
3. Touch the point you want to edit
and select from the following
options:
• Review—shows the point on
the map.
• Move Down (or Up)—
changes the order of the point
on the route.
13
Managing Waypoints, Routes, and Tracks
• Insert—adds an additional
point on the route. The
additional point is inserted
before the point you are
editing.
• Remove—removes the point
from the route.
To reverse the order of points on
a route:
1. Touch Route Planner.
2. Touch the route you want to
reverse > Reverse Route.
To delete a route:
1. Touch Route Planner.
2. Touch the route you want to delete
> Delete Route.
Viewing the Active
Route
1. Touch Active Route. The points
on your current route are shown.
2. Touch a point for additional
details.
Managing Tracks
A track is a recording of the path you
have traveled.
To record your tracks:
1. Touch Setup > Tracks > Track
Log.
2. Touch Do Not Record; Record,
Do Not Show; or Record, Show
On Map.
If you select Record, Show On
Map, a line on the Map page
indicates your track.
For more information on Tracks
setup, see page 24.
14
Dakota Series Owner’s Manual
Managing Waypoints, Routes, and Tracks
To save and view your current
track:
Touch Track Manager > Current
Track.
• View Map—shows your
current track on the map.
• Elevation Plot—shows the
elevation plot page 16 for your
current track.
• Save Track—saves your
current route.
• Save Portion—allows you to
select a portion of your current
track to save.
Dakota Series Owner’s Manual
To clear your current track:
Touch Setup > Reset > Clear
Current Track > Yes.
To open a saved track:
1. Touch Where To? > Tracks.
2. Touch a saved track.
Archived or loaded tracks are listed
on the Track Manager page. You can
view the tracks on the map, view
elevation plots, or navigate the track.
15
Additional Tools
Additional Tools
Data fields
Elevation Plot
note: Elevation plot is
unavailable on the Dakota 10.
The Dakota can record elevation
changes over distance or time, or
pressure (barometric or ambient)
changes over time. To set which
changes are recorded, see page 28.
1. Touch Elevation Plot to open the
Elevation Plot page.
2. To adjust the distance or time
scale, touch the scale and then
touch
or
.
3. To display elevation data, touch a
point on the plot. The time, date,
and elevation recorded at that
point are shown.
16
Distance or
time scale
Elevation Plot Page
Changing the Elevation Plot
Data Fields
1. Touch Elevation Plot.
2. Touch a data type at the top of
the screen.
3. Select from the options listed
to replace the data type on the
screen.
Dakota Series Owner’s Manual
Additional Tools
Sharing Information
Wirelessly
note: Sharing information
wirelessly is unavailable with the
Dakota 10.
The Dakota can wirelessly share
waypoints, routes, tracks, and
geocaches with another wirelessenabled Garmin recreational
handheld.
1. Place the units within 10 feet (3
meters) of each other.
2. On the Main menu of both units,
touch Share Wirelessly.
3. On the receiving unit, touch
Receive. The receiving unit
indicates when it is ready to
receive data.
4. On the sending unit, touch Send.
5. On the sending unit, touch the
category of data to send.
6. On the sending unit, touch an
item to send and touch Send.
Dakota Series Owner’s Manual
7. Both units indicate that the
transfer is complete.
8. Touch OK on both units.
Calculating the Size of
an Area
1. Touch Area Calculation > Start.
2. Walk around the perimeter of the
area you want to calculate.
3. Touch Calculate when finished.
Other Tools
Select from the following options on
the Main menu to access additional
tools:
• Calendar—use a calendar.
• Calculator—use a calculator.
• Sun and Moon—view sunrise
and sunset times along with
the moon phase.
17
Additional Tools
• Alarm Clock—set your
Dakota to sound an alarm. You
can also set the unit to turn on
at a specific time.
note: The alarm clock is
unavailable with the Dakota 10.
• Hunt and Fish—view the
predicted best dates and times
for hunting and fishing at your
current location.
• Stopwatch—use a timer, mark
a lap, and time laps.
• Man Overboard—mark a
man overboard position and
start navigation. Follow the
on-screen instructions.
• Waypoint Averaging—refine
a waypoint location with
multiple samples to achieve
the most accurate location
possible. Follow the onscreen instructions. For more
information, refer to Trail Tech
at www.garmin.com.
18
• Sight N’ Go—point the
unit at an object to lock in
the direction and navigate
to it. Follow the on-screen
instructions.
note: Sight N’ Go is unavailable
with the Dakota 10.
Monitoring Satellite
Reception
The Satellite page shows your current
location, the GPS accuracy, your
current elevation, satellite locations,
and signal strength.
To view the Satellite page:
Touch
at the bottom of the
Main menu.
Dakota Series Owner’s Manual
Additional Tools
Dashboard
Satellite
locations
Elevation
Satellite
strength
Satellite Page
The green bars indicate GPS satellite
strength. White bars indicate that the
Dakota is still collecting data.
Trip Computer
The Trip Computer displays your
current speed, average speed,
maximum speed, trip odometer, and
other helpful statistics.
Touch a field to change what is
shown in that field.
Dakota Series Owner’s Manual
Trip Computer
To reset trip data, touch Setup >
Reset > Reset Trip Data > Yes.
To change the dashboard
background:
1. Touch
at the bottom of the
screen.
2. Touch Default, Automotive,
Geocaching, Small Data Fields,
or Large Data Fields.
To display two larger data fields:
Touch
to toggle between two
larger data fields and the default
view.
19
GPS Games
GPS Games
Geocaches
Geocaching is a type of treasure
hunting in which geocachers
seek hidden treasures using GPS
coordinates posted on the Internet by
those hiding the geocache.
3. Touch Go. A colored line indicates
your course.
4. Touch
> Compass.
5. Use the compass to navigate to
your destination as indicated on
page 9.
For more information on geocaching,
visit www.geocaching.com.
You can download Geocache sites
from www.geocaching.com. The
Web site supports the transfer of
geocache sites to your Dakota, and,
after registering and installing the
Garmin Communicator plug-in from
www.garmin.com/products
/communicator, you can download
geocaches directly to your Dakota.
To navigate to a geocache using
Geocaches:
1. Touch Geocaches > Find a
Geocache.
2. Touch a geocache location.
20
Dakota Series Owner’s Manual
Customizing the Dakota
Customizing the
Dakota
Changing the Profile
Profiles are a collection of settings
that allow you to optimize your
Dakota from one type of use to
another, such as moving from
recreational use to automotive use.
When you are in a profile and change
settings such as data fields, units of
measurement, or position settings,
they are saved automatically as part
of your current profile.
Setting Up Profiles
To change a profile
1. On the Main menu, touch Profile
Change. Your current profile is
indicated on the screen.
2. Touch the profile you want to use.
Dakota Series Owner’s Manual
To change the name of a profile:
1. Touch Setup > Profiles.
2. Touch a profile > Edit Name.
3. Touch letters, numbers, or
symbols to make the changes.
4. Touch
.
To change the order of the
profiles:
1. Touch Setup > Profiles.
2. Touch the profile you want to
move.
3. Touch Move Up or Move Down.
To delete a profile:
It is not possible to delete your
current profile.
1. Touch Setup > Profiles.
2. Touch a profile > Delete.
21
Customizing the Dakota
To add a new profile:
Touch Setup > Profiles >
<Create New Profile>. This
profile is a copy of your current
profile. The new profile becomes
your current profile.
Using System Setup
Touch Setup > System.
GPS—select Normal, WAAS
(Wide Area Augmentation System),
or Demo Mode (GPS off). For
information about WAAS, go to
www.garmin.com/aboutGPS
/waas.html.
Language—select the text language
on the Dakota. Changing the text
language does not change the
language of user-entered data or map
data, such as street names.
22
Battery Type—select the type of
battery you are using.
Tones—turn audible tones On or
Off.
note: Tones are unavailable
with the Dakota 10.
Customizing the Display
Touch Setup > Display.
Backlight Timeout—select the
amount of time you would like the
backlight to remain on after you
touch the screen.
To capture screen shots:
1. On the Main menu, touch Setup >
Display > Screen Capture > On.
2. Go to the screen you want to
capture.
3. Press and quickly release .
Dakota Series Owner’s Manual
Customizing the Dakota
4. Connect the Dakota to your
computer with the included USB
cable. The bitmap file is saved
in the Garmin\scrn folder on the
Dakota drive.
Map Setup
On the Main menu, touch Setup >
Map.
Orientation—select how the map
is shown on the page. North Up
shows north at the top of the page.
Track Up shows your current
direction of travel toward the top of
the page. Automotive Mode shows
an automotive perspective with
next-turn information to use while
driving.
Auto Zoom—automatically selects
the appropriate zoom level for
optimal use on your map. When Off
is selected, you must zoom in or out
manually.
Dakota Series Owner’s Manual
Show Data Fields—hide or show
data fields on the Map page.
Advanced Map Setup—set the
zoom levels, the text size, and the
detail level of the map.
• Zoom Levels—select the zoom
level for map items.
• Text Size—select the text size for
map items.
• Detail—select the amount
of detail shown on the map.
Showing more detail may cause
the map to redraw more slowly.
• Shaded Relief—turn on shaded
relief maps if available.
Map Information—touch the check
box to display a map. This can be
helpful if several maps are loaded on
the Dakota.
23
Customizing the Dakota
Track Setup
A track is a recording of your path.
On the Main menu, touch Setup >
Tracks.
Track Log—turn track recording on
or off.
Record Method—select a track
recording method. Touch Distance,
Time, or Auto. If your record
method is time or distance, enter the
specific time or distance interval.
Touch Auto to record the tracks at
a variable rate to create an optimum
representation of your tracks.
Interval—select a track log
recording rate. Recording points
more frequently creates a moredetailed track, but fills the track log
faster.
24
Customizing the Main
Menu
You can rearrange applications on
the Main menu.
To change the order of
applications on the Main menu:
1. Touch Setup > Main Menu.
2. Touch the application you want to
move.
3. Touch another application to
switch places.
To deactivate an application and
move it to the end of the list:
1. Touch Setup > Main Menu.
2. Touch the application.
3. Touch
.
note: To reactivate an
application, select the application
and select another application to
switch places.
Dakota Series Owner’s Manual
Customizing the Dakota
Route Setup
Touch Setup > Routing.
Guidance Method—select a
guidance method for calculating your
route
• Off Road—calculates point-topoint routes.
• On Road For Time—calculates
on-road routes that require
minimal time to drive.
• On Road For Distance—
calculates on-road routes that are
shorter in distance.
Calculate Routes for—select a
transportation method for which to
optimize your routes.
Lock On Road—lock the current
location marker on the nearest road,
compensating for variances in map
position accuracy (requires routable
maps).
Dakota Series Owner’s Manual
Off Road Transitions—select a
transition method for routing off
roads.
• Auto—automatically routes you
to the next point.
• Manual—allows you to select
the next point on the route by
touching the point on the active
route page.
• Distance—routes you to the next
point on the route when you are
within a specified distance of
your current point.
Avoidance Setup—touch the road
type you want to avoid.
Changing Marine
Settings
Touch Setup > Marine.
Marine Chart Mode—select the
chart type.
25
Customizing the Dakota
Spot Soundings—turn spot
soundings that indicate depth
locations on or off.
• Shallow Water—set an alarm to
sound when you enter an area that
is too shallow.
Light Sectors—turn the navigational
light on or off for specific sectors.
Selecting Auto causes some light
sectors to not be shown when the
density of light sectors in an area is
high.
Changing Time Settings
Symbol Set—select the set of marine
navaid symbols.
Marine Alarm Setup—turn marine
alarms on or off.
• Anchor Drag Alarm—set an
alarm to sound when you drift
more than a specified distance.
• Off Course Alarm—set an alarm
to sound when you are a specified
distance off course.
• Deep Water—set an alarm to
sound when you enter an area of
water that is too deep.
26
Touch Setup > Time.
Time Format—select a 12-hour or
24-hour format.
Time Zone—select the time zone for
your location.
Changing Measurement
Units
Touch Setup > Units.
Distance/Speed—select distance and
speed units.
Elevation (Vert. Speed)—select
elevation and vertical speed units.
Depth—select depth units in feet,
fathoms, or meters for marine use.
Dakota Series Owner’s Manual
Customizing the Dakota
Temperature—select water
temperature in degrees Celsius or
degrees Fahrenheit.
Pressure—select barometric
pressure units in inches (Hg),
millibars, or hectopascals.
Position Format
Use the default settings unless
you are using a map or chart that
specifies a different position format.
To change the position format:
Touch Setup > Position Format.
Modifying the Compass
Touch Setup > Heading.
Display—select the type of
directional heading shown on the
compass:
• Directional Letters—sets
the Compass page reading to
directional letters (N, S, E, W).
Dakota Series Owner’s Manual
• Numeric Degrees—sets the
Compass page reading to degrees
(0°–359°).
• Mils—sets the Compass page
reading to mils (0 mils–1000
mils).
North Reference—select the north
reference of the compass:
• True—sets true north as the
heading reference.
• Magnetic—automatically sets
the magnetic declination for your
location.
• Grid—sets grid north as the
heading reference (0°).
• User—allows you to set the
magnetic variation value.
Go To Line/Pointer (depending on
your unit)—select Bearing to show
the Bearing Pointer, which indicates
the direction to your destination.
Touch Course to select the Course
27
Customizing the Dakota
Pointer, which indicates your
relationship to a course line leading
to the destination (page 10).
Compass—select Auto to switch
from an electronic compass to a GPS
compass when you are traveling
at a higher rate of speed for a set
period of time. Select Off to turn the
electronic compass off and use the
GPS compass.
note: The compass auto setting
is unavailable for the Dakota 10.
Altimeter Setup
note: Altimeter Setup is
unavailable with the Dakota 10.
Touch Setup > Altimeter.
Auto Calibration—allow the
altimeter to self-calibrate each time
you turn the Dakota on.
Barometer Mode—select Variable
28
Elevation (used when moving)
or Fixed Elevation (used when
stationary, allowing the altimeter to
function as a standard barometer).
Pressure Trending—select when the
pressure data is recorded. Touch Save
Always to record pressure data every
15 minutes, even when the Dakota
is turned off. Touch Save When
Power On to record data only when
the Dakota is turned on. This can be
useful when you are watching for
pressure fronts.
Plot Type—select the elevation plot
type:
• Elevation/Time—records
elevation changes over a period
of time.
• Elevation/Distance—records
elevation changes over a distance.
• Barometric Pressure—records
barometric pressure over a period
Dakota Series Owner’s Manual
Customizing the Dakota
of time.
• Ambient Pressure—records
ambient pressure changes over a
period of time.
To manually calibrate the
altimeter:
1. Go to a location where you know
the elevation or the barometric
pressure.
2. Touch Setup > Altimeter > Press
To Begin Altimeter Calibration.
3. Touch Yes if you know the
elevation, touch No > Yes if you
know the barometric pressure.
4. Enter the elevation or barometric
pressure, and then touch
.
Pairing the Dakota
note: Connecting to wireless
sensors is unavailable with the
Dakota 10.
The Dakota can be used with an
optional Garmin heart rate monitor
Dakota Series Owner’s Manual
to display your heart rate. It can also
be used with an optional Garmin
cadence bike sensor to display your
pedaling cadence. When connected
to the appropriate Garmin device, the
heart rate and bike cadence values
are listed as data-field options on the
Map page, the Compass page, and the
Trip Computer.
Pairing is connecting your Dakota
with wireless sensors, such as a heart
rate monitor or a cadence bike sensor.
After you pair the first time, your
Dakota automatically recognizes the
wireless sensor whenever they are
turned on and within range of each
other.
To pair the Dakota with a
wireless sensor:
1. Place the Dakota within 10 feet
(3 meters) of the wireless sensor
(heart rate monitor or speed/
cadence bike sensor).
29
Customizing the Dakota
2. Turn the wireless sensor on.
3. On the Main menu, touch Setup >
Fitness > Heart Rate Monitor or
Bike Cadence Sensor.
4. Touch Search for new.
5. A “Connected” message appears.
Note: To prevent your Dakota
from communicating with wireless
sensors, touch Setup > Fitness
> Heart Rate Monitor (or Bike
Cadence Sensor) > Off.
Viewing Your Dakota
Information
On the Main menu, touch
Setup > About... to view the Dakota
software version, unit ID number,
GPS software version, and legal
information.
Reset
1. Touch Setup > Reset.
2. Touch an item to reset it.
30
Dakota Series Owner’s Manual
Appendix
Appendix
Specifications
Physical
Size:
3.9 in. H × 2.2 in. W × 1.3
in. D (100 × 55 × 33 mm)
Weight: 3.5 oz. (100 g) without
batteries
5.25 oz (148.8 g) with
batteries
Display: 2.6 in. diagonal (66 mm)
backlit 65K color TFT
display (160 × 240 pixels)
Case: Rugged plastic, water
resistant to IPX7
Temperature Range: From 5°F
to 158°F (from -15 to
70°C)*
*The temperature rating of the Dakota
may exceed the usable range of some
batteries. Some batteries can rupture at
high temperatures.
Dakota Series Owner’s Manual
Power
Source:
Two AA batteries
(alkaline, NiMH, or
lithium)
Battery Life: Up to 20 hours
Accuracy
GPS: < 33 ft. (10 m) 95% typical*
*Subject to accuracy degradation to 100
m 2DRMS under the U.S. DoD imposed
Selective Availability (SA) Program
when activated.
DGPS:
From 10 to 16 ft. (from
3 to 5 m) 95% typical
(WAAS accuracy in
North America)
Velocity: 0.328 ft./sec. (0.1 m/
sec) steady state
Interfaces: USB mass storage
device
Data Storage Life: Indefinite;
no memory
battery
required
31
Appendix
Map Storage: Internal or
microSD™ Card
Performance
Receiver: more than 12 channel
WAAS enabled/High
sensitivity
Acquisition Times: < 1 second
(warm start)
< 33 seconds (cold
start)
< 36 seconds
(autolocate)
Update Rate: 1/second,
continuous
Compass: Accuracy: ± 2 degrees
(± 5 degrees in extreme
Northern and Southern
latitudes)*
Resolution: 1 degree
Altimeter: Accuracy: ± 10 ft. (± 3
m)*
Resolution: 1 ft. (.3 m)
Range: from -2,000 ft.
32
to 30,000 ft. (from -610
to 9144 m)
*
Subject to proper user calibration.
Using Demo Mode
Demo mode turns the GPS receiver
off for use indoors or for practice.
The unit does not track satellites in
Demo mode.
Caution: Do not try to
navigate using Demo mode
because the GPS receiver is turned
off. Any satellite signal-strength
bars shown are only simulations
and do not represent the strength
of actual satellite signals.
Dakota Series Owner’s Manual
Appendix
To turn Demo Mode on, touch Setup
> System > GPS > Demo Mode.
Connecting Your Dakota
to a Computer
You can connect the Dakota to your
computer using the supplied USB
cable.
To connect your Dakota to your
computer:
1. Lift the weather cap on the top of
the Dakota.
2. Insert the smaller connector on
the USB cable into the USB
mini-B jack.
3. Connect the other end of the
cable to a USB port on your
computer.
Dakota Series Owner’s Manual
Installing a microSD™
Card
note: The microSD option is
unavailable with the Dakota 10.
The Dakota microSD data card tray
is located beneath the AA batteries.
You can purchase microSD memory
cards from an electronics supplier,
or purchase preloaded detailed map
data cards from your Garmin dealer.
In addition to map and data storage,
the memory cards can be used to
store files such as images, cartridges,
geocaches, routes, waypoints, and
custom POIs. Go to http://buy.
garmin.com for compatible map
products.
To install or remove a microSD
card:
1. Slide the latch on the back of the
Dakota (page 2) and remove the
battery cover and the batteries.
2. Lift the metal cover.
33
Appendix
3. Push the card into the microSD
card tray and close the metal
cover.
Metal
cover microSD
card
microSD
card tray
Transferring Files to
Your Computer
After you have connected the device
to your computer, you can copy and
paste files from your computer into
the device drives/volumes.
1.
2.
3.
4.
Browse your computer for the file.
Select the file.
Select Edit > Copy.
Open the “Garmin” or memory
card drive/volume.
5. Select Edit > Paste.
4. To remove the microSD card, lift
the metal cover and remove the
card from the microSD card tray.
5. Replace the batteries and the
battery cover.
In addition to map and data storage,
the microSD card can be used to
store files such as images, cartridges,
geocaches, routes, waypoints, and
custom POIs.
34
Dakota Series Owner’s Manual
Appendix
Before transferring data to or from
a Web site directly to the Dakota,
install the Garmin Communicator
plug-in from www.garmin.com
/products/communicator.
Loading and Deleting
Files
You can use the Dakota as a USB
mass storage device, and you can
purchase a separate microSD card
for additional external memory.
Note: The Dakota is not
compatible with Windows® 95,
98, Me, or NT. It is also not
compatible with Mac® OS 10.3 or
earlier.
Dakota Series Owner’s Manual
To load a file onto the Dakota or
microSD card:
1. Remove the battery cover and
insert a microSD card (page 33).
2. Connect the USB cable to the
Dakota and your computer.
3. Copy the file from your computer.
4. Paste the file into the Garmin or
the microSD card/volume.
To delete a file from the Dakota
or microSD card:
1. Open the Garmin or SD card
drive/volume.
2. Highlight the file and press the
Delete key on your computer
keyboard.
note: When deleting files, do
not delete pre-programmed map
data (files that end with “.img”). It
is not recoverable.
35
Appendix
Optimizing Battery Life
Use premium batteries for optimal
performance and maximum
battery life. The best performance
is provided by lithium batteries,
precharged (ready-to-use) NiMH
batteries, and NiMH rechargeable
batteries less than one year old with
a capacity greater than 2500 mAh.
Consider the following suggestions
to maximize battery life:
• Do not adjust the backlight more
than is necessary (page 3). Using
a backlight level above 50% of
maximum level for a prolonged
period of time will significantly
decrease battery life.
• Select a shorter backlight timeout
(page 22).
• Turn tones off if not needed
(page 22).
36
• Turn the electronic compass off if
not needed (page 28).
• If you plan on using the Dakota
extensively in your automobile,
consider purchasing a vehicle
power cable (http://buy.garmin
.com).
Restoring Factory
Default Settings
You can restore your Dakota to the
original factory settings. Changes
you have made using Setup are
restored to the default settings.
To restore factory settings, touch
Setup > Reset > Restore Defaults
to Factory Settings > Yes.
Dakota Series Owner’s Manual
Appendix
Attaching a Carabiner,
Lanyard, Mount,
or Other Optional
Accessory
1. Position the accessory in the
slots on the mounting spine of the
Dakota.
Accessory
(carabiner)
Clip
Calibrating the
Touchscreen
The Dakota screen does not normally
require calibration. However, if the
buttons do not seem to be responding
properly, use the following process.
To calibrate the touchscreen:
1. While the unit is turned off, press
and hold for approximately 30
seconds.
2. Follow the instructions on the
screen until “Calibration is
complete” is displayed.
Mounting
spine
2. Slide the clip up until it locks in
place.
To remove the clip, lift the bottom
of the clip and slide the clip off the
mounting spine.
Dakota Series Owner’s Manual
37
Appendix
Software License
Agreement
BY USING THE Dakota, YOU AGREE
TO BE BOUND BY THE TERMS AND
CONDITIONS OF THE FOLLOWING
SOFTWARE LICENSE AGREEMENT.
PLEASE READ THIS AGREEMENT
CAREFULLY.
Garmin grants you a limited license to
use the software embedded in this device
(the “Software”) in binary executable
form in the normal operation of the
product. Title, ownership rights, and
intellectual property rights in and to the
Software remain in Garmin.
You acknowledge that the Software
is the property of Garmin and is
protected under the United States
of America copyright laws and
international copyright treaties. You
further acknowledge that the structure,
organization, and code of the Software
are valuable trade secrets of Garmin
and that the Software in source code
form remains a valuable trade secret of
Garmin. You agree not to decompile,
38
disassemble, modify, reverse assemble,
reverse engineer, or reduce to human
readable form the Software or any part
thereof or create any derivative works
based on the Software. You agree not to
export or re-export the Software to any
country in violation of the export control
laws of the United States of America.
Declaration of
Conformity (DoC)
Hereby, Garmin, declares that this
Dakota is in compliance with the
essential requirements and other
relevant provisions of Directive
1999/5/EC.
To view the full Declaration of
Conformity, see the Garmin Web site
for your Garmin product:
www.garmin.com
Dakota Series Owner’s Manual
Index
Index
A
accessories 1
active route 14
advanced map setup 23
alarm clock 18
alarms, marine 26
altimeter
calibration 29
setup 28
ambient pressure 28
automotive mode 23
auto zoom 23
avoidance setup 25
B
background
dashboard 19
backlight 3
timeout 22
barometer mode 28
battery 2
optimal battery type
36
replacing 2
bearing 27
C
cadence sensor 29
calculator 17
calendar 17
calibration
altimeter 29
compass 9
carabiner 37
Communicator
Garmin 20
Dakota Series Owner’s Manual
compass
calibration 9
north reference 27
course 27
D
data fields
changing 8, 11,
16, 23
show or hide 8
default settings 36
demo mode 32
directional letters 27
E
edit
routes 13
elevation
fixed or variable 28
elevation/distance 28
elevation/time 28
elevation plot 16
customizing 28
39
Index
F
factory settings 36
fitness setup 29
fixed elevation 28
G
geocaches 20
GPS setting 22
grid north 27
guidance method 24
H
heart rate monitor 29
hunt and fish 18
L
language 22
light sectors 25
lock on road 25
lock screen 3
40
M
magnetic north 27
man overboard 18
map information 7
marine 25
mark waypoint 4
microSD card
installing 33
loading files 35
mils 27
N
navigation 5
stop 7
north reference, compass
27
north up 23
numeric degrees 27
O
off road 24
off road transitions 25
on road for distance 25
on road for time 24
orientation, map 23
P
pairing 29
plot type 28
POI 5
points of interest 5
position format 27
pressure
ambient 28
barometric 28
trending 28
unit of measurement
26
profiles 21
R
recent finds 5
record method, tracks 24
reverse
route points 14
routes
calculate 25
edit 13
reverse 14
setup 24
view 14
Dakota Series Owner’s Manual
Index
S
satellite signals 3
SD card 33
sensors 29
serial number 1
share wirelessly 17
sight N go 18
size of an area
calculating 17
spot soundings 25
stop navigating 7
stopwatch 18
sun and moon 17
T
text size, maps 23
timeout, backlight 22
time zone 26
tones 22
tracks
clearing current 15
recording 24
setup 24
viewing 15
track up 23
trip computer 19
true north 27
V
variable elevation 28
view
tracks 15
W
WAAS 22
waypoint averaging 18
waypoints
creating 4
wireless sharing 17
Z
zoom 23
U
unlock screen 3
Dakota Series Owner’s Manual
41
For the latest free software updates (excluding map data) throughout the life of
your Garmin products, visit the Garmin Web site at www.garmin.com.
© 2009–2010 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151st Street, Olathe, Kansas 66062, USA
Garmin (Europe) Ltd.
Liberty House, Hounsdown Business Park, Southampton, Hampshire, SO40 9LR UK
Garmin Corporation
No. 68, Jangshu 2nd Road, Sijhih, Taipei County, Taiwan
www.garmin.com
October 2010
Part Number 190-01069-00 Rev. B
Printed in Taiwan

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
