1200S Network Series
Portable Dryers
Parts
Manual
PNEG-1447
Date: 10-12-2006
PNEG-1447
Table of Contents
MAIN STRUCTURE ASSEMBLY...................................................................................5
FRAME ASSEMBLY..............................................................................................................................................................5
FRAME, LOWER BASKET, AND METERING ROLLS......................................................................................................8
PLENUM (INSIDE) SCREENS AND METER ROLL UPPER SHIELD.............................................................................12
OUTER SCREENS AND PLENUM DIVIDER...................................................................................................................14
CLEAN OUT DOORS...........................................................................................................................................................16
FRONT AND REAR PLENUM END PANELS AND REAR ACCESS DOORS................................................................18
LADDER ASSEMBLIES......................................................................................................................................................20
BOTTOM AUGER...............................................................................................................................................................22
TOP AUGER WITH WET BIN............................................................................................................................................24
AUGER AND METER ROLL DRIVE TRAINS..............................................................26
BOTTOM AUGER DRIVE..........................................................................................................................................................26
TOP AUGER DRIVE...........................................................................................................................................................28
METER ROLL DRIVE........................................................................................................................................................30
FAN HEATERS.................................................................................................................32
FAN HOUSING ASSEMBLIES.................................................................................................................................................32
FAN MOTOR, MOTOR MOUNT, AND FAN BLADE................................................................................................................34
AIR MIXERS........................................................................................................................................................................35
FLAME PROBE, IGNITOR, AND BURNER ASSEMBLIES..............................................................................................36
LP PIPE TRAIN ASSEMBLIES...........................................................................................................................................38
NG PIPE TRAIN ASSEMBLIES..........................................................................................................................................44
FAN HEATER ORIFICES.............................................................................................................................................47
LP SUPPLY LINE.......................................................................................................................................................48
NG SUPPLY LINE.......................................................................................................................................................49
DRYER ELECTRICAL CONDUITS..................................................................................50
RIGHT AND LEFT GRAIN, AND PLENUM HIGH LIMITS.......................................................................................50
LOWER JUNCTION BOXES, METER ROLL MOTOR CONDUIT, AND REAR DISCHARGE CONDUIT.................52
UPPER JUNCTION BOX, TOP AUGER MOTOR CONDUIT, AND OPERATOR LIGHT...........................................54
AIR SWITCH ASSEMBLY............................................................................................................................................55
CONTROL BOXES..........................................................................................................56
NETWORK CONTROL BOX......................................................................................................................................56
FAN HEATER CONTROL BOX..................................................................................................................................58
LOWER CONTROL BOX CONTROL PANEL...........................................................................................................60
LOWER CONTROL BOX CONTROL PANEL (INSIDE)............................................................................................61
LOWER CONTROL BOX BACK PANEL...................................................................................................................62
UPPER CONTROL BOX.............................................................................................................................................63
NOTES................................................................................................................................67
PNEG-1447
3
4
PNEG-1447
PNEG-1447
Right side
2
5
3
1a
5
3
4a
5
The fan heater end of the dryer is considered by GSI as the front end of the dryer (the
foreground of this photograph is the front end. Right and left sides are labeled above).
1
4
5
3
Frame Assembly (view from fan/heater end with hitch weldment removed).
3
Left side
Frame
**NOTE: The parts pointed out on this page are listed on page 7.
5
Frame
Right front corner of frame.
**NOTE: The right front corner
is shown in the photo. For left
front corner all parts are the
same except for the Hitch
Bracket (use 1a for the left side),
and the Frame Rail (use 4a for
the left side).
3
1
1a
2
4 4a
Left rear corner of frame.
3
5
2
6
4a
4
**NOTE: The left rear corner is
shown in the photo. For right
rear corner all parts are the same
except for the Frame Rail (use 4
for the right side).
PNEG-1447
Frame
Center cross ties.
3
5
4
4a
2
ITEM
NUMBER PART NUMBER
1
1a
2
3
4
4a
4
4a
4
4a
4
4a
4
4a
5
PNEG-1447
D01-0012
D01-0011
D01-0008
D01-0007
D21-0011
D21-0010
D31-0044
D31-0043
D61-0002
D61-0001
D101-0002
D101-0001
D71-0001
D71-0002
D01-0005
DESCRIPTION
HITCH BRACKET RIGHT
HITCH BRACKET LEFT
FRONT & REAR FRAME TIE CHANNEL
CORNER LEG PORTABLE DRYER
FRAME RAIL, 14' RIGHT
FRAME RAIL, 14' LEFT
FRAME RAIL, 18' RIGHT
FRAME RAIL, 18' LEFT
FRAME RAIL, 20' RIGHT
FRAME RAIL, 20' LEFT
FRAME RAIL, 22' RIGHT
FRAME RAIL, 22' LEFT
FRAME RAIL, 26' RIGHT
FRAME RAIL, 26' LEFT
SIDE LEG PORTABLE DRYER
1214S 1218S 1220S 1222S 1226S
1
1
4
6
1
1
1
1
4
6
1
1
4
6
1
1
6
8
1
1
6
8
1
1
1
1
1
1
10
14
16
16
1
1
20
7
Note the hole pattern of
the plenum closure
door angles. This will
distinguish between
L.H. and R.H.
8
7
2
1
6
9
5
10
4
6
3
8
11
5
9
4
6
Dryer frame and lower basket assembly (view from the
front end of the dryer looking down the left side).
Frame, Auger Trough, & Hopper Bulkheads
**NOTE: The parts pointed out on this page are listed on page 11.
PNEG-1447
PNEG-1447
4
13
9
3
12
6
14
15
12
3
11a
Dryer frame and lower basket assembly (view from the
rear end of the dryer looking up the right side).
6
12
5
12
Center hanger bearing support
and cross channel seal plate.
9
6
3
6
20
19
Discharge bearing plate.
4
Wooden meter roll support bearing.
The meter roll sections are spliced
together with a meter roll splice
shaft (part no. D31-0046) that
passes through the support bearing
assembly.
16
17
21
9
18
Frame, Auger Trough, & Hopper Bulkheads
**NOTE: The parts pointed out on this page are listed on page 11.
9
Meter Rolls and Their Placement in the Dryer
Metering Rolls and their placement in the dryer.
NOTE: Item 22 at the rear of
dryer is a front section meter
roll that is used as a rear section
on 16 and 20 foot dryers only.
22
Meter Roll Bearing
See pg. 11
Items 16, 17, 18
24
23
23
Meter Roll Bearing
See pg. 11
Items 16, 17, 18
23
23
13
Meter Roll Bearing
See pg. 11
Items 16, 17, 18
19
19
22
22
This end is the front (fan/heater) end of the dryer.
10
PNEG-1447
Meter Rolls and Their Placement in the Dryer
ITEM
NUMBER PART NUMBER
1
2
3
4
5
6
7
8
9
10
11
11
11
11
11
11A
11A
11A
11A
11A
12
13
14
15
16
17
18
19
20
21
22
23
24
D01-1136Y
D01-1136X
D01-0109
D01-0004
D01-0005
D01-0007
D01-0011
D01-0012
D01-0008
D01-1374
D21-0011
D31-0044
D61-0002
D101-0002
D71-0001
D21-0010
D31-0043
D61-0001
D101-0001
D71-0002
D01-0048
D01-1512
D01-1291
D01-1290
D02-0028
D31-0148
D02-0061
D01-0177
D01-1511
D31-0120
D31-0031
D31-0030
D31-0029
DESCRIPTION
PLENUM CLOSURE DOOR ANGLE, RH
PLENUM CLOSURE DOOR ANGLE, LH
HOPPER BULKHEAD
GUSSET PLATE
SIDE LEG
CORNER LEG
HITCH BRACKET, LH
HITCH BRACKET, RH
FRONT & REAR FRAME TIE CHANNEL
BOTTOM AUGER BEARING PLATE
FRAME RAIL, 14' RIGHT
FRAME RAIL, 18' RIGHT
FRAME RAIL, 20' RIGHT
FRAME RAIL, 22' RIGHT
FRAME RAIL, 26' RIGHT
FRAME RAIL, 14' LEFT
FRAME RAIL, 18' LEFT
FRAME RAIL, 20' LEFT
FRAME RAIL, 22' LEFT
FRAME RAIL, 26' LEFT
TROUGH PANEL
PLATE, CROSS CHANNEL SEAL W/TABS
HANGER BEARING "C" CHANNEL
HANGER BEARING "J" PLATE
CLEVIS PIN 5/16" x 1 3/4"
METER ROLL WASHER
METER ROLL SUPPORT BEARING
SUPPORT STRAP
PLATE, END CHANNEL SEAL W/TAB
DISCHARGE PLATE
METER ROLL, FRONT
METER ROLL, INTERMEDIATE
METER ROLL, REAR
1214S 1218S 1220S 1222S 1226S
6
7
12
16
10
6
1
1
4
1
1
8
9
16
20
14
6
1
1
4
1
9
10
18
22
16
6
1
1
4
1
10
11
20
24
16
8
1
1
6
1
12
13
24
28
20
8
1
1
6
1
1
1
1
1
1
1
1
1
14
1
1
2
32
16
6
7
2
1
2
4
2
18
1
1
2
40
20
8
9
2
1
2
6
2
20
1
1
2
40
20
8
10
2
1
4
6
22
2
2
4
48
24
10
11
2
1
2
8
2
1
26
2
2
4
56
28
12
13
2
1
2
10
2
The part number list above covers all parts pointed out on pages 8, 9, and 10.
PNEG-1447
11
Inside (Plenum) Screens, Plenum Closure Doors
Plenum screens and bulkheads (view from front end).
3
2
1
4
3
5
5
6
16
7
8
10
7
11
13
15
14
18
19
9
12
20
10
This photograph was taken before the front
plenum end panel and outer screens where
installed in order to get a good view of the inside
screens and bulkheads.
20a
21
22
12
Plenum closure door. There are two different plenum closure doors. The door
shown in the photogragh is the rear plenum closure door and is the rear most
plenum closure door, item no. 20 (just inside the rear access door), all others
are item no. 20a. NOTE: Item 22 is the plenum closure door rear frame angle.
PNEG-1447
Meter Roll Upper Shield Assembly
Close up of of meter roll upper shield assembly.
19
18
17
16
17
18
19
ITEM
NUMBER
PART NUMBER
1
2
3
4
5
6
7
8
8
8
8
8
9
9
9
9
9
10
11
12
13
14
15
16
17
*18&19
18
19
20
20a
21
22
PNEG-1447
DESCRIPTION
1214S 1218S 1220S 1222S 1226S
D31-0055
COLUMN BULK HEAD
12
16
18
20
D01-0101
GARNER BULKHEAD
12
16
18
20
D31-0307
COLUMN END PANEL
4
4
4
4
D01-0126
SCREEN,PLENUM TOP,GA,094
14
18
20
22
D31-0012
SCREEN,PLENUM WALL,GA,094
14
18
20
22
D01-1225
SCREEN,PLENUM BOTTOM,GA,094
14
18
20
22
D01-0004
GUSSET PLATE
16
20
22
24
D21-0011
FRAME RAIL, 14' RIGHT
1
D31-0044
FRAME RAIL, 18' RIGHT
1
D61-0002
FRAME RAIL, 20' RIGHT
1
D101-0002
FRAME RAIL, 22' RIGHT
1
D71-0001
FRAME RAIL, 26' RIGHT
D21-0010
FRAME RAIL, 14' LEFT
1
D31-0043
FRAME RAIL, 18' LEFT
1
D61-0001
FRAME RAIL, 20' LEFT
1
D101-0001
FRAME RAIL, 22' LEFT
1
D71-0002
FRAME RAIL, 26' LEFT
D01-0007
CORNER LEG PORTABLE DRYER
6
6
6
8
D01-0012
HITCH BRACKET RIGHT
1
1
1
1
D01-0011
HITCH BRACKET LEFT
1
1
1
1
D01-0008
FRONT & REAR FRAME TIE CHANNEL
4
4
4
6
D01-1374
BOTTOM AUGER BEARING PLATE
1
1
1
1
D01-0005
SIDE LEG PORTABLE DRYER
10
14
16
16
D01-0109
HOPPER BULKHEAD
12
16
18
20
D01-0050P
CONNECTOR SHEET, PERFORATED
14
18
20
22
D01-1180
METER ROLL UPPER SHIELD ASSY.
14
18
20
22
D01-0431
METER ROLL STRIKE OFF PLATE
1 PER ASSEMBLY
D01-1226
METER ROLL SHIELD 1995 STYLE
1 PER ASSEMBLY
D01-1214
PLENUM CLOSURE DOOR, REAR
1
1
1
1
D01-1134
PLENUM CLOSURE DOOR
6
8
9
10
DC-974
DANGER FOOT IN AUGER DECAL
2
2
2
2
D01-1217
PLENUM CLOSURE DOOR REAR FRAME ANGLE
1
1
1
1
*ITEM NUMBERS 18 AND 19 TOGETHER MAKE UP THE METER ROLL UPPER SHIELD ASSEMBLY
24
24
4
26
26
26
28
1
1
8
1
1
6
1
20
24
26
26
1
12
2
1
13
Outside Screens / Meter Roll Access Door
4
*
*Note: Item 4 is pointing to
the top edge angle gusset.
There are two types of gusset
on the dryer. The photo right
will help distinguish the
difference between the two.
The arrows are pointing to a
tab on the gusset that makes
them different (tabs are
“bent” up in photo). Item 4a
is used in two places only; 1.)
front right of dryer 2.) rear
left of dryer, all others are
item 4.
1
2
4
4a
Meter roll access door.
3
3
5
6
7
8
9
10
ITEM
NUMBER
1
2
3
4
4a
5
6
7
8
9
10
14
PART NUMBER
D01-0127
D31-0013
D01-0128
D01-0152
D01-0153
D01-0050P
D01-0045P
D01-0039
S-6552
DC-1229
D01-0048
DESCRIPTION
SCREEN,ROOF,GA,094
SCREEN,OUTSIDE WALL,GA,094
SCREEN,HOPPER,GA,094
LH TOP ANGLE GUSSET
RH TOP ANGLE GUSSET
CONNECTOR SHEET, PERFORATED
ACCESS DOOR, PERFORATED
DOOR LATCH
PIN HAIR CLIP 3/32 ZN PLATED
DECAL, WARNING METER ROLL ROT.
TROUGH PANEL WELDMENT
1214S 1218S 1220S 1222S 1226S
14
14
14
12
2
14
14
28
28
14
14
18
18
18
16
2
18
18
36
36
18
18
20
20
20
18
2
20
20
40
40
20
20
22
22
22
20
2
22
22
44
44
22
22
26
26
26
24
2
26
26
52
52
26
26
PNEG-1447
Plenum Divider
Right rear plenum divider section with clean-out door.
1
3
2
2
Plenum divider floor sections.
Plenum divider support channels.
7
4
6
5
4
ITEM
NUMBER
PART NUMBER
1
2
3
4
5
6
7
D31-0259
D31-0260
D61-0028
D61-0024
D61-0026
D61-0025
D61-0027
DESCRIPTION
PLENUM DIVIDER CLEAN-OUT DOOR
CLEAN-OUT DOOR GUIDE PLENUM
PLENUM DIVIDER RH: REAR
PLENUM SUPPORT CHANNEL
PLENUM DIVIDER RH
PLENUM DIVIDER LH
PLENUM DIVIDER LH: REAR
1214S
1218S
1220S
1222S
1226S
1
2
1
8
6
6
1
1
2
1
10
8
8
1
1
2
1
11
9
9
1
1
2
1
12
10
10
1
1
2
1
14
12
12
1
NOTE: The quantities listed for the parts above are for one module only. The plenum divider components
shown are the same for both modules.
PNEG-1447
15
Clean Out Doors
Front and rear handle mechanisms (rear shown in photo).
*Note: Items 9, 10, & 11 together create the
clean out door assembly. There are three
different clean out door assemblies that are used
on GSI Network dryers:
1.) 3 column clean out door assy. (D51-0077).
Item 8a on the part no. listing (pg 17).
1
2.) 4 column clean out door assy. (D11-0032).
Item 8b on the part no. listing (pg 17).
3
2
13
3.) 5 column clean out door assy. (D01-0349).
Item 8c on the part no. listing (pg 17).
A 5 column clean out door assy (D01-0349) is
shown in the photograph below.
4
5
11
Clean out door handle mechanism.
5
4
9
3 3a
2
6
7
Clean out door hinge.
11
10
9
11
10
12
13
11
16
PNEG-1447
Clean Out Doors
Center handle mechanisms (this handle mechanism stradles the center cross channels).
3a
14
1a
14
3a
4
11
2
5
14
ITEM
NUMBER
PART NUMBER
1
1a
2
3
3a
4
5
6
7
8a
9
10
D01-0264
D31-0162
D01-0296
D01-0261
D01-0293
D01-0294
S-4378
S-248
S-7241
D51-0077
D21-0005
D21-0012
PIVOT ROD 25.188"
PIVOT ROD 49.625"
LINKAGE BAR WELDMENT
LINKAGE BAR, 37" LONG
LINKAGE BAR, 30" LONG
CLEAN OUT DOOR HANDLE
PLASTIC GRIP
WASHER, FLAT 3/8 USS ZN
COTTER PIN, 1/8 x 1 1/4
CLEAN OUT DOOR ASSY, 3 COLUMN
CLEAN OUT DOOR, 67"
SUPPORT CHANNEL, CLEAN OUT DOOR
11
8b
9
10
11
D01-0308
D11-0032
D31-0021
D31-0130
D01-0308
CLEAN OUT DOOR HINGE
CLEAN OUT DOOR ASSY, 4 COLUMN
CLEAN OUT DOOR, 91"
SUPPORT CHANNEL, CLEAN OUT DOOR
CLEAN OUT DOOR HINGE
8c
9
10
11
D01-0349
D01-0180
D01-0307
D01-0308
CLEAN OUT DOOR ASSY, 5 COLUMN
CLEAN OUT DOOR, 115"
SUPPORT CHANNEL, CLEAN OUT DOOR
CLEAN OUT DOOR HINGE
12
13
13
13
14
D01-0175
D01-0181
D31-0023
D21-0006
D01-0299
HINGE BRACKET
CLEAN OUT EXTENSION, 119.75"
CLEAN OUT EXTENSION, 90.75"
CLEAN OUT EXTENSION, 66.75"
PIVOT ROD BRACKET
PNEG-1447
DESCRIPTION
1214S 1218S 1220S 1222S 1226S
2
1
4
2
2
4
4
8
8
1
1
2
1
4
2
2
4
4
8
8
2
2
6
2
4
6
6
12
12
1
1 PER ASSEMBLY
1 PER ASSEMBLY
2 PER
1
1 PER
1 PER
2 PER
2
1
4
2
2
4
4
8
8
ASSEMBLY
2
ASSEMBLY
ASSEMBLY
ASSEMBLY
1
2
1 PER ASSEMBLY
1 PER ASSEMBLY
3 PER ASSEMBLY
4
2
2
3
5
2
2
6
4
3
3
6
4
2
6
2
2
6
2
4
6
6
12
12
2
1
7
2
4
6
17
Front End Panels / Fan Support / grill guards
1
5
2
4
5
3
3
18
ITEM
NUMBER
PART NUMBER
1
2
2
2
3
4
4
4
5
5
5
NOT SHOWN
NOT SHOWN
NOT SHOWN
D61-0023
CD-0576
CD-0544
CD-0547
D31-0307
D01-0593
D61-0041
D71-0008
F-7060-Y
CD-0543-Y
CD-0545-Y
D01-0594
D61-0018
D71-0006
DESCRIPTION
TOP ANGLE, FAN SUPPORT PANEL
GRILL GUARD: CD-28 BLACK
GRILL GUARD: 36" BLACK
GRILL GUARD: 40&42" BLACK
COLUMN END PANEL
FRONT FAN SUPPORT 2-28"
FRONT FAN SUPPORT 2-36"
FRONT FAN SUPPORT 2-40"
VENTURI: 28" YEL/OCHRE
VENTURI: 36" OCHRE
VENTURI: 40" OCHRE
FRONT END PANEL 2-28"
FRONT END PANEL 2-36"
FRONT END PANEL 2-40"
1214S
1218S
1220S
1222S
1226S
1
2
1
1
1
1
2
2
2
4
4
4
1
1
1
4
1
2
4
1
2
2
2
2
2
1
1
1
1
1
PNEG-1447
Rear End Panels / Rear Access Door
3
Rear access door (outside).
8
5
6
7
8
9
Rear access door (inside).
5
10
11
12
6
1
10
13
11
4
3
ITEM
NUMBER
PART NUMBER
1
2
3
4
5-13
5
6
7
8
9
10
11
12
13
D31-0307
D01-1800-Y
D01-0044
D01-1510
RDA-29-Y
D01-1783-Y
D01-1781-Y
D03-0512
D01-1782-BLK
DC-973
401-4630-0
401-4669-8
D01-0397
D01-1792
PNEG-1447
DESCRIPTION
COLUMN END PANEL
REAR END PANEL 50/50 29" DOORS
TOP ANGLE BRACKET FRONT & REAR
ASPIRATOR END CAP
REAR DOOR ASSEMBLY 29"SQ OCHR
ASSIST HANDLE 29" SQ. DOOR
DOOR 29" SQUARE OCHRE
DOOR HANDLE,LOCKING CCW
FRAME ANGLE 29" DOOR
DECAL, DANGER FIRE HAZARD
HINGE BRACKET-SQUARE DOOR
HINGE-REAR ACCESS SQ DOOR
LATCH BRACKET
LATCH BAR 29" SQUARE DOOR
2
1214S
1218S
4
1
3
1
2
4
1
3
1
2
1220S
1
1222S
4
1
3
1
2
2/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
4/ASSEMBLY
2/ASSEMBLY
2/ASSEMBLY
2/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
4
1
3
1
2
1226S
4
1
3
1
2
19
Front Ladder Assembly
4
1
5
2
5
3
6
7
ITEM
NUMBER PART NUMBER
1-3
1
2
3
4
5
5
5
6
7
20
D01-1220
D61-0096
D61-0094
D61-0095
D51-0022
F-7060-Y
CD-0543-Y
CD-0545-Y
D51-0021
D31-0082
DESCRIPTION
LADDER ASSY. STACK DRYER FRONT
LADDER RUNG
LADDER SIDE RAIL-LH
LADDER SIDE RAIL-RH
SUPPORT, CONTROL PANEL
VENTURI: 28" YEL/OCHRE
VENTURI: 36" OCHRE
VENTURI: 40" OCHRE
STIFFENER, FRONT FAN SUPPORT
FRONT DIAGONAL SUPPORT CHANNEL
1214S 1218S 1220S 1222S 1226S
1
7
2
2
2
1
1
1
12/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
7
7
7
2
2
2
2
2
2
2
2
2
1
7
2
2
2
PNEG-1447
Rear Ladder Assembly
4
1
2
4
3
ITEM
NUMBER PART NUMBER
1-3
1
2
3
4
PNEG-1447
D04-0388
D61-0096
D61-0092
D61-0093
D61-0097
DESCRIPTION
LADDER ASSEMBLY
LADDER RUNG
LADDER SIDE RAIL-LH
LADDER SIDE RAIL-RH
LADDER MOUNTING BRACKET, REAR
1214S 1218S 1220S 1222S 1226S
1
3
1
1
1
10/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
3
3
3
1
3
21
Bottom Auger
Bottom Auger (view from center of dryer to
the forward end).
Bottom Auger (view from center of dryer to
the rear end).
1
2
2
3
2
4
Bottom Auger center bearing and support.
5
22
7
Bottom Auger rear bearing.
6
8
7
PNEG-1447
Bottom Auger
Rear Discharge Box.
Auger bearing.
18 19
17
20
9
10
16
21
11
12
ITEM
NUMBER
PART NUMBER
1
2
3
3
3
4
4
5
6
7
8
9-19
9
10
11
12
13
14
15
16
17
18
19
20
21
NOT SHOWN
D01-1214
D01-1134
D21-0017
D31-0092
D31-0092
D31-0267
D61-0184
D01-1290
D01-1291
D01-1246
D31-0076
D01-0481-MS
D01-1884
D01-1886
D01-0405
D01-1752
D01-1751
D31-0298
D01-1885
D01-1650
D31-0299
D01-0466
D01-0467
D32-0001
D31-0005
D31-0079
PNEG-1447
13
14
15
DESCRIPTION
PLENUM CLOSURE DOOR, REAR
PLENUM CLOSURE DOOR
AUGER BOTTOM FRONT WELDMENT
AUGER BOTTOM FRONT WELDMENT
AUGER BOTTOM FRONT WELDMENT (116 3/8" LONG)
AUGER BOTTOM REAR WELDMENT
AUGER BOTTOM REAR WELDMENT (117 7/8" LONG)
HANGER BEARING BOTTOM J-PLATE
HANGER BEARING BOTTOM C-CHANNEL
HANGER BEARING ASSEMBLY (SHORT)
SHAFT, AUGER SPLICE
DISCHARGE BOX ASSEMBLY
DISCHARGE WELDMENT
MOIST. SAMPLER TUBE COVER PLATE
GRAIN SAMPLER ASSEMBLY
DISCHARGE SIDE COVER
DISCHARGE SICE PANEL MC
DISCHARGE SIDE PANEL
MOIST. SAMPLER COVER PLATE
REAR AUGER BEARING SHIELD
DISCHARGE BOX BEARING PLATE
DISCHARGE TOP PANEL
DISCHARGE TOP FLAPPER
FLANGETTE BEARING
SHAFT, TOP & BOT AUGER STUB
DISCHARGE AUGER WELDMENT
1214S 1218S 1220S 1222S 1226S
1
1
1
1
1
6
8
9
10
12
1
1
1
1
1
1
1
2
2
1
2
2
2
4
4
1
1
1
2
2
2
2
2
3
3
2
2
2
3
3
1
1
1
1
1
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
23
Top Auger With Wet Bin Assembly
2
1
1
Top Auger with wet bin (switch paddle end).
3
6
4
7
5
8
1
3
11
9
10
12
8
5
9
13
14
14a
Top Auger (fill end).
24
PNEG-1447
Top Auger bearing support.
Top Auger With Wet Bin Assembly
Top Auger bearing support (inside view).
17
16
16
15
21
22
20
7
23
24
7
25
19
10
21
ITEM
NUMBER
PART NUMBER
1
1
2
3
3
3
3a
5
6
7
7
7
7
8
9
10
10
10
11
12
13
14
14a
15
15
15
16
17
18
19
20
21
21
21
22
23
24
25
D01-1521
D01-1522
D01-0103
D21-0003
D31-0004
D01-0168
D31-0003
D01-0147
D01-0167
D21-0015
D31-0091
D31-0267
D61-0184
D01-0148
D01-1525
D21-0002
D31-0010
D01-0161
D01-1650
D31-0028
D32-0001
D31-0090
D31-0005
D01-1123
D01-1124
D01-1125
D31-0015
D31-0011
D31-0009
D31-0001
D31-0002
D21-0001-Y
D31-0006-Y
D01-0151-Y
D01-0140
D31-0008
D01-1245
D31-0076
PNEG-1447
22
18
DESCRIPTION
WET BIN SIDE,4'SIDE GALV. PERF
WET BIN SIDE,6'SIDE GALV. PER
MERCURY SWITCH SHAFT
TOP EDGE ANGLE 71.875"
TOP EDGE ANGLE 95.875"
TOP EDGE ANGLE 119.875"
TOP EDGE ANGLE SPLICE
TOP AUGER HOUSING HINGE L.H.
MERCURY SWITCH PADDLE WELDMENT
AUGER TOP FRONT WELDMENT
AUGER TOP FRONT WELDMENT
AUGER TOP & BOTTOM WELDMENT
AUGER WELDMENT 117 7/8"
TOP AUGER HOUSING HINGE R.H.
WET BIN END
TOP AUGER TROUGH SIDE/6'
TOP AUGER TROUGH SIDE/8'
TOP AUGER TROUGH SIDE/10'
REAR AUGER BEARING COVER
TOP AUGER HOUSING END
BEARING 1 1/2" DIA W/FLANGETTE
SHAFT, TOP AUGER FRONT
SHAFT, TOP AUGER STUB REAR
TOP AUGER COVER, 30.25"
TOP AUGER COVER, 24.25"
TOP AUGER COVER, 20.25"
TOP AUGER BEARING SUPPORT
CENTER STABILIZER BEAM
GUSSET ATTACH BRACKET
CENTER HANDRAIL GUSSET L.H.
CENTER HANDRAIL GUSSET R.H.
HAND RAIL-SUPPORT,1"EMTX71.75"
HAND RAIL SUPPORT,1"EMTX95.75"
HAND RAIL, 1"EMT X119.75"LONG
HANGER BRACKET-HANDRAIL GALV.
TOP AUGER TROUGH SPLICE
TOP AUGER BEARING HANGER ASSY.
SHAFT, AUGER SPLICE
1214S 1218S 1220S 1222S 1226S
4
2
1
2
2
2
2
1
1
1
2
2
2
2
1
2
2
1
1
1
3
2
1
1
2
2
2
2
2
16
2
1
1
6
1
4
4
1
2
2
2
2
1
4
2
2
1
1
1
2
6
1
2
4
4
2
1
1
1
2
2
2
1
2
2
2
2
1
2
2
1
1
1
5
2
1
1
2
2
2
4
1
2
2
1
1
1
7
2
1
1
2
2
2
2
2
16
2
1
1
4
16
2
1
1
2
2
2
4
1
2
2
1
1
1
5
4
2
2
4
4
4
2
4
24
4
2
2
4
6
1
4
2
4
2
1
1
2
2
2
4
2
1
2
2
1
1
1
7
4
2
2
4
4
4
4
2
24
4
2
2
25
Bottom Auger Drive
Bottom Auger drive components
1
9
10
2
8
3
7
4
6
5
11
11
Bottom Auger motor and motor mount.
12
Forward drive tension adjustment.
13
5
13
Rear drive tension adjustment.
14
16
15
13
18
16
17
26
6
4
PNEG-1447
Bottom Auger Drive
Bottom auger and metering roll drive guard.
21
22
19
20
ITEM
NUMBER PART NUMBER
1
2
3
3
4
5
6
7
8
9
10
11
*12
12
*12
12
12
13
14
15
16
17
17
17
17
17
18
19
20
21
22
PNEG-1447
D01-1376
MHC00490
2818-2
D62-0003
D01-0012
D01-1373
D01-0029
D01-0011
D01-1374
D03-0304
D32-0019
D01-0065
500-1
500-3
712-1
712-3
1000-3
D01-0081
D01-0008
D01-0007
D01-0017
D21-0011
D31-0044
D61-0002
D101-0002
D71-0002
D01-0016
D01-1372
PR-331
DC-971
DC-972
DESCRIPTION
1214S 1218S 1220S 1222S 1226S
BOTTOM FRONT ANGLE BRACKET
1
1
BELT-V BX82
2
2
SHEAVE 2GR 3.35Dx1 1/8"
1
1
SHEAVE 2GR 4.25Dx1 3/8"
HITCH BRACKET, RIGHT
1
1
BELTGUARD, UNLOAD MOTOR SHROUD
1
1
HITCH WELDMENT
1
1
HITCH BRACKET, LEFT
1
1
BOTTOM AUGER BEARING PLATE
1
1
SHEAVE 2GR 20" GRIPBELT
1
1
BUSHING Q1-1 1/2" SPLIT TAPER
1
1
SPACER, BEARING SHIELD
2
2
MOTOR 5HP 1PH 1800RPM
1
1
MOTOR 5HP 3PH 1800RPM
1
1
MOTOR 7.5HP 1PH 1800RPM
MOTOR 7.5HP 3PH 1800RPM
MOTOR 10HP 3PH 1800RPM
MOTOR MOUNT - BOTTOM AUGER
1
1
FRONT & REAR FRAME TIE CHANNEL
4
4
CORNER LEG
6
6
MOTOR ADJUSTMENT BRACKET
2
2
FRAME RAIL, 14' R.H.
1
FRAME RAIL, 18' R.H.
1
FRAME RAIL, 20' R.H.
FRAME RAIL, 22' R.H.
FRAME RAIL, 26' R.H.
MOTOR MOUNT SUPPORT BRACKET
1
1
BELTGUARD, UNLOAD FRONT SHIELD
1
1
PEAK CAP HANDLE
2
2
DECAL, BELT DRIVE WARNING
2
2
DECAL, CHAIN WARNING
2
2
*ITEM 12, PART Nos 500-1 & 712-1 ARE SINGLE PHASE MOTORS
1
2
1
2
1
2
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
2
1
1
1
1
4
6
2
1
6
8
2
1
1
6
8
2
1
1
1
1
2
2
2
1
1
2
2
2
1
1
1
2
2
2
27
Top Auger Drive
1
6
Belt guard upper mount.
1
4
2
3
5
Top Auger drive components.
12
13
Top Auger belt guard cover.
28
PNEG-1447
Top Auger Drive
7
8
9
10
11
Top Auger motor and motor mount.
ITEM
NUMBER
PART NUMBER
1
2
3
4
5
5
6
7
*8
8
*8
8
8
9
10
11
12
13
D01-0453
D52-0001
D32-0019
D01-0464
2818-2
D62-0003
D01-0155
D01-0424
500-1
500-3
712-1
712-3
1000-3
D01-0173
D01-0465
D01-0170
D01-0452-Y
DC-971
PNEG-1447
DESCRIPTION
1214S 1218S 1220S 1222S 1226S
TOP AUGER BELTGARD BODY
1
SHEAVE 2GR 16" GRIPBELT
1
BUSHING Q1-1 1/2" SPLIT TAPER
1
BELT-V BX97
2
SHEAVE 2GR 3.35Dx1 1/8" BORE
1
SHEAVE 2GR 4.25Dx1 3/8"
MOUNTING BRACKET-BELT GD SPCR
1
DRYER TOP HAND HOLD
1
MOTOR 5HP 1PH 1800RPM
1
MOTOR 5HP 3PH 1800RPM
1
MOTOR 7.5HP 1PH 1800RPM
MOTOR 7.5HP 3PH 1800RPM
MOTOR 10HP 3PH 1800RPM
TOP MOTOR MOUNT WELDMENT
1
TURNBUCKLE 1/2" X 6" PLATED
1
ANCHOR BRACKET-MOTOR MOUNT
1
TOP AUGER BELTGUARD COVER OCHR
1
DECAL, BELT DRIVE WARNING
2
*ITEM 8, PART Nos 500-1 & 712-1 ARE SINGLE PHASE MOTORS
1
1
1
2
1
1
1
1
1
1
1
1
1
2
1
1
1
2
1
1
1
2
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
2
1
1
1
1
1
2
29
Metering Roll Drive
SCR Motor/Reduction drive and motor mount assembly.
8
1
7
2
3
4
5
6
Meter roll drive train components.
12
9
14
17
15
16
9
14
10
11
8
30
12
13 14
PNEG-1447
Metering Roll Drive
Front meter roll bearing.
Rear meter roll bearing.
18
18
19
19
20
21
ITEM
NUMBER
PART NUMBER
1
2
2
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
D01-0007
D21-0010
D31-0043
D61-0001
D101-0001
D71-0002
D01-0016
D01-0081
D01-0704
D01-0008
D03-0232
D01-1374
D02-0029
D31-0316
D32-0001
D01-0196
D03-0257
S-9168
S-6290
D02-0031
DC-972
D01-0003
GK1583
D01-0006
D01-0272
PNEG-1447
DESCRIPTION
CORNER LEG PORTABLE DRYER
FRAME RAIL, 14' LEFT
FRAME RAIL, 18' LEFT
FRAME RAIL, 20' LEFT
FRAME RAIL, 22' LEFT
FRAME RAIL, 26' LEFT
MOTOR MOUNT SUPPORT BRACKET
MOTOR MOUNT
SCR MOTOR GEARBOX MOUNT
FRONT & REAR FRAME TIE CHANNEL
MOTOR 3/4 HP DC W/GEAR BOX 50:1
BOTTOM AUGER BEARING PLATE
SPROCKET 40H30
FRONT BOTTOM AUGER SHAFT
FLANGETTE BEARING 1 1/2"
SPROCKET IDLER ASSEMBLY
SPROCKET 4015 x 7/8" BORE W/KEYWAY
KEY SQ. 1/4" x 1"
CHAIN #40 ROLLER CHAIN
#40 CHAIN CONNECTING LINK
DECAL, CHAIN WARNING
ADAPTOR PLATE
FLANGETTE BEARING 1", W/LOCK COLLAR
METER ROLL DRIVE SHAFT (f r o n t )
METER ROLL SHAFT STUB (r ear )
1214S 1218S 1220S 1222S 1226S
6
1
6
6
8
8
1
1
1
1
1
1
4
1
1
2
1
2
2
1
3
6f t
1
2
4
4
2
2
1
1
1
4
1
1
2
1
2
2
1
3
6f t
1
2
4
4
2
2
1
1
1
4
1
1
2
1
2
2
1
3
6f t
1
2
4
4
2
2
1
1
1
6
1
1
2
1
2
2
1
3
6f t
1
2
4
4
2
2
1
1
1
1
6
1
1
2
1
2
2
1
3
6f t
1
2
4
4
2
2
31
Fan Heater Housing Assembly
Fan Heater housing assembly.
28” burner support and collector
cup.
13
1
14
2
3
14a
13a
36”& 40” burner support and collector cup.
4
5
6
7
32
8
PNEG-1447
Fan Heater Housing Assembly
ITEM
NUMBER
PART NUMBER
1
1
1
2
2
3
3
3
4
5
6
7
8
9
9a
9a
10
10a
10a
D01-1996
D01-1963
D01-1997
D01-0529
D01-1452
D01-0528
D01-1480
D01-1479
401-5759-6-B
069-1303-2
DC-1224
DC-1225
DC-1227
HF-983
D01-1484
D01-1485
HF-7092
D01-1482
D01-1483
DESCRIPTION
WRAPPER, 28" FAN HEATER
WRAPPER, 36" FAN HEATER
WRAPPER, 40" FAN HEATER
STRAIGHTENING VANE, 28" F/H
STRAIGHTENING VANE, 36-42" F/H
INNER CAN, 26" & 28" F/H
INNER CAN, 36" F/H
INNER CAN, 40" F/H
ACCESS DOOR-GALV FAN BLACK
SIGHT GLASS
DECAL, DANGER HI-VOLTAGE
DECAL, WARNING ROTATING BLADE
DECAL, WARNING FIRE
COLLECTOR CUP, 28" FAN HEATER
COLLECTOR CUP, 36" FAN HEATER
COLLECTOR CUP, 40" FAN HEATER
SUPPORT PLATE, 28" FAN HEATER
SUPPORT BRACKET, 36" FAN HEATER
SUPPORT BRACKET, 40" FAN HEATER
2812
3612
3615
1
1
4025
1
1
11
11
11
1
1
1
1
1
1
1
1
1
1
1
1
1
1
11
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Matching the right size fan heater to the model number of the dryer.
Fan Heater
28", 10 - 12 hp
(2812)
36", 10 - 12 hp
(3612)
36", 10 - 16 hp
(3615)
40", 25 hp
(4025)
PNEG-1447
Dryer Model No.
1214S 1218S 1220S 1222S 1226S
x
x
x
x
x
33
Fan Motor, Motor Mount, & Fan Blade
Fan motor and motor mount.
1
2
FAN HEATER;
(Dia., HP)
ITEM NUBER
1
28" 12Hp
36" 12Hp
36" 15Hp
40" 25Hp
34
Fan blade and bushing.
3
DESCRIPTION
220V 1Ph
208V 3Ph
MOTOR MOUNT
D01-0530
D01-0530
4
PART NUMBER
220V 3Ph
440V 3Ph
D01-0530
575V Ph
D01-0530
D01-0530
2
MOTOR
CD-0110
CD-0239
CD-0239
CD-0239
D03-0193
3
FAN BLADE
D03-0302
D03-0302
D03-0302
D03-0302
D03-0302
4
BUSHING
PT0778
PT0778
PT0778
PT0778
PT0778
1
MOTOR MOUNT
D01-1478
D01-1478
D01-1478
D01-1478
D01-1478
NOT SHOWN
MOTOR MOUNT ADAPTER
CD-0233
CD-0233
CD-0233
CD-0233
CD-0233
2
MOTOR
CD-0110
CD-0239
CD-0239
CD-0239
CH-6819
3
FAN BLADE
D01-0468
D01-0468
D01-0468
D01-0468
D01-0468
4
BUSHING
FH-1009
FH-1009
FH-1009
FH-1009
FH-1009
1
MOTOR MOUNT
D01-1478
D01-1478
D01-1478
D01-1478
D01-1478
2
MOTOR
002-1073-2
CH-1050
CH-1050
CH-1050
CH-6820
3
FAN BLADE
D82-0002
D82-0002
D82-0002
D82-0002
D82-0002
4
BUSHING
FH-1009
FH-6963
FH-6963
FH-6963
FH-6963
1
MOTOR MOUNT
N/A
D01-1477
D01-1477
D01-1477
D01-1477
2
MOTOR
N/A
C-2049
C-2049
C-2049
CH-6692
3
FAN BLADE
N/A
D72-0003-25
D72-0003-25
D72-0003-25
D72-0003-25
4
BUSHING
N/A
CE-00617
CE-00617
CE-00617
CE-00617
PNEG-1447
Air Mixer Assemblies
Air mixer assemblies (36” air mixer shown in photo).
1
1a
2
ITEM
NUMBER PART NUMBER
PNEG-1447
DESCRIPTION
1-2
1
1a
2
1-2
1&1a
2
D01-0955
D01-0951
D01-0950
CD-0228
CD-0113
D01-1303
CD-0083
AIR MIXER ASSEMBLY, 28"
AIRMIXER CAN, 28" x 15" LONG
AIRMIXER CAN, 28" x 8" SHORT
SMALL DIA. CAN AIR MIXER VANE
AIR MIXER ASSEMBLY, 36"
AIRMIXER CAN, 36" W/ACCESS
AIR MIXER VANE
1-2
1&1a
2
CD-0117
D01-1218
CD-0083
AIR MIXER ASSEMBLY, 40"
AIRMIXER CAN, 40" W/ACCESS
AIR MIXER VANE
28" F/H 36" F/H 40" F/H
1
1/ASSEMBLY
1/ASSEMBLY
6/ASSEMBLY
1
2/ASSEMBLY
8/ASSEMBLY
1
2/ASSEMBLY
8/ASSEMBLY
35
Flame Probe, Ignitor, Vaporizer Coil, and Burner Assemblies
8
1
Ignitor
2
7
3
6
5
Flame probe
4
9
10
Items 9 and 10 are used in LP Fan/Heaters only.
ITEM
10
10
10
10
PART No.
CD-0414
HF-7207
HF-7251
HF-7319
DESCRIPTION
VAPORIZOR COIL 26 28" 3 WRAP
VAPORIZER COIL 36-42"10-17HP
VAPORIZER 3/4" 3 WRAP 36-42"
VAPOR COIL (SPIRAL) 42" 40HP
2812 3612 3615 4025
1
1
1
1
Burner housing high limit switch.
28” Fan heater burner assembly.
11
12
13
14 15
16
18
19
17
36
PNEG-1447
Flame Probe, Ignitor, Vaporizer Coil, and Burner Assemblies
36” Fan heater burner assembly.
40” &42” Fan heater burner assembly.
24
19
20
21
22
ITEM PART NUMBER
1-3
1
2
3
4-8
4
5
6
7
8
9
9
10
11
12
13
14
15
15-18
15
16
17
18
19-23
19
20
21
22
23
24-27
24
25
26
27
PNEG-1447
TF-1559-N
HH-7025
THH-4179
CD-0187
TF-1558
HF-7204
D01-0878
HF-7201
CD-0238
TF-1876
HH-7054
HH-7056
THH-4064
027-1006-9
D01-1473
No Number
TFC-0076
BA-28
HF-7629
THF-3144
THF-3141
THF-3113
BA-36
THF-3038
THF-3038P
THF-3039
THF-3057
CD-0091
BA-40-2
CD-0448P
CD-0448
CD-0208
THF-3057
23
27
25
26
28" F/H 36" F/H 40" F/H
DESCRIPTION
FLAME PROBE ASSY NETWK
1
1
1
BOOT 8MM SILICONE 90DEGREE
1/ASSEMBLY
FLAME SENSOR 6" LONG ROD
1/ASSEMBLY
FLAME SENSOR BRACKET
1/ASSEMBLY
IGNITOR ASSEMBLY
1
1
1
DUAL PROBE IGNITOR BRACKET
1/ASSEMBLY
IGNITOR AIR DEFLECTOR ANGLE
1/ASSEMBLY
2/ASSEMBLY
IGNITOR HALF CLAMP
IGNITOR FLAME
2/ASSEMBLY
IGNITION WIRE ASSY (includes both wires)
1/ASSEMBLY
CONE 26/28" BURNER S.S.
1
CONE 36/42" BURNER S.S.
1
1
SEE CHART ON PAGE 36
UNILET TYPE LRL CONDUITBX1/2"
1
1
1
THERMOSTAT - HI LIMIT 200F AUT
1
1
1
HOUSING HI LIMIT PLATE
1
1
1
LID FOR LRL CONDUIT BOX IS PART OF ITEM 11
NOT APPLICABLE
NEOPRENE GASKET, CONDUIT BODY
1
1
1
28" BURNER ASSEMBLY
1
DIVERTER WELDMENT 28"
1/ASSEMBLY
FLAME SPREADER 28"
1/ASSEMBLY
HEATER GUN MACHINED 28"
1/ASSEMBLY
28" DIVERTER BRACKET
1/ASSEMBLY
36" BURNER ASSEMBLY
1
DIVERTER BRACKET 36" & 40"
3/ASSEMBLY
DIVERTER BRACKET 36" & 40" PERFED
4/ASSEMBLY
DIVERTER BRACKET 36" & 40" W/HOLE
1/ASSEMBLY
FLAME SPREADER 36-42"
1/ASSEMBLY
BURNER WELDMENT CD 36" & 40"
1/ASSEMBLY
40" BURNER ASSEMBLY
1
DIVERTER BRACKET 42" PERFD
4/ASSEMBLY
DIVERTER BRACKET 42"
4/ASSEMBLY
BURNER WELDMENT CD 42"
1/ASSEMBLY
FLAME SPREADER 36-42"
1/ASSEMBLY
37
LP Pipe Train Assemblies
26” & 28” Fan heater LP pipe train assembly.
24 25 26
10
4
1
11
2
3
4
23 24
5
6
7
8
9
18
21
13
2
12
11
14
20
17
19
17
16
12
15
22
26” & 28” Vaporizer coil connection and adjustment
brackets.
29
27
28
38
PNEG-1447
LP Pipe Train Assemblies
PNEG-1447
ITEM
NUMBER
PART NUMBER
1
THH-4120
ELBOW, 3/4" - 90 DEG SCH 40
1
2
THH-4121
NIPPLE, 3/4" CLOSE SCH 40
2
3
007-1048-3
BALL VALVE, 3/4" W/LEVER HANDLE
1
4
THH-4125
NIPPLE, 3/4" x 2 SCH 40
2
5
THH-4154
TEE, 3/4" x 3/4" x 1/4" SCH 40
1
6
HH-2984
GUAGE, PRESSURE 0-30# LP
1
DESCRIPTION
28" FAN
7
THH-4136
NIPPLE, 3/4" x 3" SCH 40
1
8
056-2223-8
VALVE, SOLENOID 3/4"NPT 115V DIN
1
9
056-2228-7
VALVE, SOLENOID 3/4"NPT 115V BYP
1
10
THH-4066
ELBOW 3/4-90 STREET SCH 40
1
11
THH-4149
ELBOW, 3/4"-1/2" REDUCER SCH 40
1
12
HH-2029
NIPPLE, 1/2" x 1 1/2" SCH 40
2
13
HH-1453
TEE, 1/2" x 1/2" x 1/2" SCH 40
1
14
HH-7013
SWITCH SCREW-IN VAPOR HI-LIMIT
1
15
THH-4071
ELBOW 1/2"-90 SCH 40
1
16
TFC-0023-50
REGULATOR, 1/2" NPT 50PSI
1
17
D07-0019
NIPPLE, 1/2" x 1 1/2" SCH 80
2
18
031-1008-7
PRESSURE RELIEF VALVE 300PSI
1
19
HH-4846
TEE, 1/2" x 1/2" x 1/4" SCH 80
1
20
HH-1251
STRAINER, 1/2" "Y" SCH 80
1
21
HH-1932
ELBOW, 1/2" PIPE - 1/2" FLARE BRASS
1
22
TFC-0095
HOSE, 1/2" x 24" LP GAS
2
23
TF-1227
PIPETRAIN BRACKET FOR 36 & 42"
1
24
326-1047-9
U-BOLT 5/16-18 X 1-3/8 X 2-3/16
3
25
401-5503-8
PLUMBG MTG BRKT
1
26
401-5255-5
PLUMBG MTG BASE BRKT
1
27
HH-4847
ELBOW, 1/2"-90 SCH 80
2
28
D01-2217
VAPORIZER SUPPORT PLATE BLACK
1
29
410-1783-1-B
VAPORIZER ADJUSTING WELD 1/2"
1
39
LP Pipe Train Assemblies
36” Fan heater LP pipe train assembly.
24 25 26
10
4
1
2
3
4
23 24
5
6
7
8
9
18
21
13
2
12
11
14
20
17
19
17
16
12
15
22
36” Vaporizer coil connection and adjustment brackets.
29
27
28
40
PNEG-1447
LP Pipe Train Assemblies
ITEM
NUMBER
PART NUMBER
1
THH-4120
ELBOW, 3/4" - 90 DEG SCH 40
1
2
THH-4121
NIPPLE, 3/4" CLOSE SCH 40
2
3
007-1048-3
BALL VALVE, 3/4" W/LEVER HANDLE
1
4
THH-4125
NIPPLE, 3/4" x 2 SCH 40
2
5
THH-4154
TEE, 3/4" x 3/4" x 1/4" SCH 40
1
6
HH-2984
GUAGE, PRESSURE 0-30# LP
1
7
THH-4136
NIPPLE, 3/4" x 3" SCH 40
1
8
056-2223-8
VALVE, SOLENOID 3/4"NPT 115V DIN
1
PNEG-1447
DESCRIPTION
36" LP F/H
9
056-2228-7
VALVE, SOLENOID 3/4"NPT 115V BYP
1
10
THH-4066
ELBOW 3/4-90 STREET SCH 40
1
11
THH-4149
ELBOW, 3/4"-1/2" REDUCER SCH 40
1
12
HH-2029
NIPPLE, 1/2" x 1 1/2" SCH 40
2
13
HH-1453
TEE, 1/2" x 1/2" x 1/2" SCH 40
1
14
HH-7013
SWITCH SCREW-IN VAPOR HI-LIMIT
1
15
THH-4071
ELBOW 1/2"-90 SCH 40
1
16
TFC-0023-50
REGULATOR, 1/2" NPT 50PSI
1
17
D07-0019
NIPPLE, 1/2" x 1 1/2" SCH 80
2
18
031-1008-7
PRESSURE RELIEF VALVE 300PSI
1
19
HH-4846
TEE, 1/2" x 1/2" x 1/4" SCH 80
1
20
HH-1251
STRAINER, 1/2" "Y" SCH 80
1
21
HH-1932
ELBOW, 1/2" PIPE - 1/2" FLARE BRASS
1
22
TFC-0095
HOSE, 1/2" x 24" LP GAS
2
23
TF-1227
24
PIPETRAIN BRACKET FOR 36 & 42"
1
326-1047-9
U-BOLT 5/16-18 X 1-3/8 X 2-3/16
3
25
401-5503-8
PLUMBG MTG BRKT
1
26
401-5255-5
PLUMBG MTG BASE BRKT
1
27
HH-4847
ELBOW, 1/2"-90 SCH 80
2
28
D01-2217
29
410-1783-1-B
VAPORIZER SUPPORT PLATE BLACK
1
VAPORIZER ADJUSTING WELD 1/2"
1
41
LP Pipe Train Assemblies
40” LP pipe train assemblies.
23 24 25
2
1
10
1
2
3
2
4
8
7
5
6
23
9
17
22
19
12
13
2
12
21
20
18
17
16
11
14
15
40” with 25hp and larger motors vaporizer coil
connection and adjustment brackets.
28
29
26
28
27
42
PNEG-1447
LP Pipe Train Assemblies
ITEM
NUMBER PART NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
PNEG-1447
THH-4115
007-1104-4
007-1296-8
007-1106-9
D07-0027
HH-2984
THH-4037
056-2224-6
056-2230-3
007-1242-2
007-1288-5
HH-2029
HH-1453
HH-7013
THH-4071
TFC-0023-50
D07-0019
HH-4846
031-1008-7
HH-1251
HH-1932
TF-1227
326-1047-9
401-5503-8
401-5255-5
D01-2217
D01-2220
007-1930-2
HH-1082
DESCRIPTION
ELBOW, 1" -90 DEG SCH 40
NIPPLE, CLOSE 1"
BALL VALVE, 1" WITH LEVER HANDLE
TEE, 1" x 1" x 3/4"
REDUCER, 3/4"-1/4" HEX BUSHING
PRESSURE GUAGE, 0-30# LP
NIPPLE, 1" x 2 1/2" SCH 40
VALVE, SOLENOID 1" NPT 115V DIN
VALVE, SOLENOID 1" NPT 115V BYPASS
NIPPLE, 1" x 2" SCH 40
ELBOW, 1" - 1/2" SCH 40
NIPPLE, 1/2" x 1 1/2" SCH 40
TEE, 1/2" x 1/2" x 1/2" SCH 40
SWITCH SCREW-IN VAPOR HI-LIMIT
ELBOW 1/2"-90 SCH 40
REGULATOR, 1/2" NPT - CSA 50PSI
NIPPLE, 1/2" x 1 1/2" SCH 80
TEE, 1/2" x 1/2" x 1/4" SCH 80
PRESSURE RELIEF VALVE 300 PSI
STRAINER, 1/2" "Y" SCH 80
ELBOW, 1/2" PIPE - 1/2" FLARE BRASS
PIPETRAIN BRACKET FOR 36 & 42"
U-BOLT 5/16-18 X 1-3/8 X 2-3/16
PLUMBG MTG BRKT
PLUMBG MTG BASE BRKT
VAPORIZER SUPPORT PLATE BLACK
VAPORIZER ADJUSTING WELD 3/4"
REDUCER, BELL 3/4" - 1/2" SCH 80
ELBOW, 1/2"-90 DEG STREET SCH 80
40" LP
2
4
1
1
1
1
1
1
1
1
1
2
1
1
1
1
2
1
1
1
1
1
3
1
1
1
1
2
2
43
NG Pipe Train Assemblies
26” & 28” Fan heater NG pipe train assembly.
12 13 14
10
4
1
2
3
4
5
6
7
8
1A
9
2
11
44
ITEM
NUMBER
PART NUMBER
1
THH-4120
ELBOW, 3/4" -90 SCH 40
1
2
THH-4121
NIPPLE, 3/4" CLOSE SCH 40
2
3
007-1048-3
BALL VALVE, 3/4" W/LEVER HANDLE
1
4
THH-4125
NIPPLE, 3/4" x 2" SCH 40
2
5
THH-4154
TEE, 3/4" x 3/4" x 1/4" SCH 40
1
6
D08-0022
GAUGE, PRESSURE 0-15#
1
7
THH-4136
NIPPLE, 3/4" x 3" SCH 40
1
8
056-2223-8
VALVE, SOLENOID 3/4"NPT 115V DIN
1
9
056-2228-7
VALVE, SOLENOID 3/4"NPT 115V BYP
1
10
THH-4066
ELBOW, 3/4" x 90 DEG STREET SCH 40
1
11
007-1307-3
ELBOW, 1 - 3/4" REDUCER SCH 40
1
12
326-1047-9
U-BOLT 5/16-18 X 1-3/8 X 2-3/16
2
13
401-5503-8
PLUMBG MTG BRKT
1
14
401-5255-5
PLUMBG MTG BASE BRKT
1
DESCRIPTION
28" FANS
PNEG-1447
NG Pipe Train Assemblies
36” Fan heater NG pipe train assembly.
12 13 14
2
8
7
1
2
3
2
4
7
9
5
6
10
11
PNEG-1447
ITEM
NUMBER
PART NUMBER
1
007-1307-3
ELBOW, 1" - 3/4"
1
2
007-1104-4
NIPPLE, CLOSE 1"
3
3
007-1296-8
BALL VALVE, 1" W/LEVER HANDLE
1
4
007-1106-9
TEE, 1" x 1" x 3/4"
1
5
D07-0027
REDUCER, 3/4" - 1/4" HEX BUSHING
1
6
D08-0022
GAUGE, PRESSURE 0-15#
1
7
007-1242-2
NIPPLE, 1" x 2" SCH 40
2
8
THH-4115
ELBOW, 1"-90 DEG. SCH 40
1
DESCRIPTION
36" FAN
9
056-2224-6
VALVE, SOLENOID 1"NPT 115V DIN
1
10
056-2230-3
VALVE, SOLENOID 1"NPT 115V W/BYP
1
11
THH-4164
ELBOW, 1"-90 DEG. STREET SCH 40
1
12
326-1047-9
U-BOLT 5/16-18 X 1-3/8 X 2-3/16
2
13
401-5503-8
PLUMBG MTG BRKT
1
14
401-5255-5
PLUMBG MTG BASE BRKT
1
45
NG Pipe Train Assemblies
40” & 42” Fan heater NG pipe train assembly.
11 12 13
2
1
7
1
2
3
2
4
7
9
5
6
10
8
ITEM
NUMBER
46
PART NUMBER
DESCRIPTION
40" FANS
1
THH-4115
ELBOW, 1" - 90 DEG SCH 40
2
2
007-1104-4
NIPPLE, CLOSE 1"
3
3
007-1296-8
BALL VALVE, 1" W/LEVER HANDLE
1
4
007-1106-9
TEE, 1" x 1" x 3/4"
1
5
D07-0027
REDUCER, 3/4" - 1/4" HEX BUSHING
1
6
D08-0022
GAUGE, PRESSURE 0-15#
1
7
007-1242-2
NIPPLE, 1" x 2" SCH 40
2
8
THH-4164
ELBOW, 1"-90 DEG. STREET SCH 40
1
9
056-2224-6
VALVE, SOLENOID 1"NPT 115V DIN
1
10
056-2230-3
VALVE, SOLENOID 1"NPT 115V W/BYP
1
11
326-1047-9
U-BOLT 5/16-18 X 1-3/8 X 2-3/16
2
12
13
401-5503-8
401-5255-5
PLUMBG MTG BRKT
PLUMBG MTG BASE BRKT
1
1
PNEG-1447
Fan Heater Orifices
LIQUID PROPANE ORIFICES
FAN HEATER ORIFICE SIZE PART NUMBER ITEM NO.
28"12hp
.25"
THF-3241
3
36"12hp
.2813"
THF-3242
3
36"15hp
.3281"
CD-0150
3
40"25hp
.3438"
THF-3058
3
NATURAL GAS ORIFICES
FAN HEATER ORIFICE SIZE PART NUMBER ITEM NO.
28"12hp
.375"
THF-3140
3
36"12hp
.4063"
THF-3243
3
36"15hp
.5"
THF-3244
3
40"25hp
.5156"
THF-3246
3
3
PNEG-1447
47
LP Supply Line
Liquid propane fuel supply line.
1
Supply line mounting brackets.
2
3
14
15
4
5
13
8
4
6
16
12
4
11
10
7
9
48
1
ITEM No.
PART No.
1
2
3
4
5
5
6
6
7
8
9
10
11
12
13
14
15
16
TFC-0027
D67-0015
D67-0016
HH-7036
D67-0019
D01-1011
D67-0018
D01-1018
D67-0011
D07-0019
D67-0021
D67-0008
D67-0016
D28-0001
TFC-0092
D31-0074
HH-1096
D31-0075
DESCRIPTION
VALVE, 1/4" NPT 250 PSI RELIEF
RDCR 3/4" x 1/4" BELL SCH 80
NIPPLE, 3/4" x 8" SCH 80
TEE, 3/4" x 3/4" x 1/2" SCH 80
NIPPLE, 3/4" x 42" SCH 80
NIPPLE, 3/4" x 46" SCH 80
NIPPLE, 3/4" x 68"
NIPPLE, 3/4" x 68"
ELBOW, 3/4"-90 SCH 80
NIPPLE, 1/2" x 1 1/2" SCH 80
NIPPLE, 3/4" CLOSE SCH 80
STRAINER, "Y" SCH 80
NIPPLE, 3/4" x 8" SCH 80
VALVE, 3/4" NPT ELECT SHUTOFF
VALVE, 1/2" NPT SOLENOID LP GAS
GAS MANIFOLD MOUNTING BRACKET
CLAMP, 1/2"
GAS MANIFOLD CARRIER BRACKET
1214S-22S
1226S
2
1
1
2
1
2
1
1
2
1
1
1
2
2
1
1
1
2
3
3
1
1
1
2
2
1
1
1
2
3
3
1
PNEG-1447
NG Supply Line
5
7
1
8
5
6
6
7
1
1
2
2
ITEM No.
PART NUMBER
1
2
3
4
5
5
6
6
7
7
8
9
10
11
12
13
D01-1013
D01-1015
D68-0016
D68-0004
D08-0023
D08-0008
THH-4117
D08-0009
HH-7087
D68-0002
D68-0010
D68-0015
D68-0014
D68-0012
D68-0018
D68-0011
DESCRIPTION
NIPPLE 2 1/2" x 45" SCH 40
NIPPLE 2 1/2" x 34" SCH 40
NIPPLE 2 1/2" x 26" SCH 40
UNION 2 1/2" FEMALE SCH 40
VALVE 1" NPT B-COCK
VALVE 1 1/2" NPT B-COCK
NIPPLE 1" CLOSE SCH 40
NIPPLE 1 1/2" CLOSE SCH 40
TEE 2 1/2" x 2 1/2" x 1" SCH 40
TEE 2 1/2" x 2 1/2" x 1 1/2" SCH 40
PLUG 2 1/2 SQUARE SCH 40
VALVE 2 1/2" NPT ELECT SHUTOFF
ELBOW 2 1/2"-90 SCH 40
NIPPLE 2 1/2" x 4" SCH 40
NIPPLE 2 1/2" x 9" SCH 40
STRNR 2 1/2" Y SCH 40
1214S
1218S-26S
1
1
1
1
2
1
1
1
1
2
2
2
2
1
1
1
1
1
1
2
1
1
1
1
1
1
4
3
9
10
PNEG-1447
11
12
13
49
Right & Left Grain and Plenum High Limits
Left grain and plenum high limit
Right grain high limit thermothermostat enclosures.
stat enclosures.
Upper plenum high limit
8
12
7
Left grain high limit
11
4
Conduit from
right grain high
limit is run to
right lower
junction box.
Lower plenum high limit
Upper plenum high limit thermostat.
Grain temperature thermister. There are
2 thermisters in each (right & left)
grain high limit thermostat assemblies.
3
1
2
9
Right & left grain high limit thermostat.
4
5
1
Lower plenum high limit thermostat.
1
6
2
3
8
7
7
10
3
4
50
8
PNEG-1447
Right & Left Grain and Plenum High Limits
Upper plenum high limit thermostat conduit.
13
14
15
16
12
Lower plenum high limit thermostat conduit.
ITEM No.
1
2
2
3
4
5
6
6
7
8
9
10
11
12
13
13
14
15
16
DESCRIPTION
HIGH LIMIT MOUNTING BRACKET
plenum-thermostat 10' 300deg (for 14' dryers only)
PLENUM-THERMOSTAT 24' 300DEG (for dryers that are 16' and longer)
ENCLOSURE 4x4x2.5 WHITE PVC
SEALTITE PVC 3/8"
ELBOW 3/8" 90 DEGREE PVC W/NUT
grain thermo hi-lmt 10' 210deg (for 14' dryers only)
GRAIN THERMO HI-LMT 24' 210DEG (for dryers that are 16' and longer)
CONNECTOR 1/2" EMT COMPRESSION
CONDUIT 1/2" EMT METALLIC
GRAIN TEMP THERMISTOR SER2000
SEAL 3/8 STRAIGHT PVC W/NUT
CONNECTOR 3/8" LIQUID-TITE TO 1/2" EMT
CLAMP 1/2" CONDUIT
CONDUIT BODY, LL TYPE
COVER ALUMINUM, CONDUIT BODY
PLENUM THERMISTOR BOLT
PIPE SCH 40 1/2"
CLAMP, BEAM 1/2"
PART No.
D01-0254
D03-0004
D03-0377
FH-6972
FH-7038
FH-7050
D03-0005
D03-0378
D03-0054
D03-0057
D03-0258
FH-7049
D03-0060
HH-1096
D03-0375
TFC-0075
HF-7236
DM60001
GT3-0241
the following components make up the grain high limit conduits that run through the grain columns. The conduit assemblies are not shown in the
photos.
not shown conduit 1/2" emt metallic
D03-0057
not shown connector 1/2" emt compression (2/conduit; 1 at each end of the dryer.)
D03-0054
not shown coupler 1/2" emt compression (couples the lengths of 1/2" emt)
D33-0002
not shown
enclosure 4x4x2.5 white pvc (as of 2003 a 4x4 enclosure has been added to these assemlies and is mounted
on the rear column end panels into which thr grain high limit thermostat conduits now terminate.)
PNEG-1447
FH-6972
51
Lower Junction Box, Meter Roll Motor Conduit, Rear Discharge Conduit
Lower junction box (right).
Lower junction box (left).
5
6
7
3
7
4
8
6
9
5
2
2
1
Conduit to
Meter Roll
Motor
(see photo
below)
1
2
3
4
1
Meter roll motor conduit connection.
8
10
Conduit to Meter Roll Speed
Sensor & Rear Discharge Switch
(see photos below & on next page)
1
11
Meter roll speed sensor and rear discharge switch conduit.
This is a photo of the front section of the conduit that runs
through the gussets on the left side of the dryer.
Rear discharge switch conduit at rear
left gusset where 1/2” EMT conduit
terminates.
14
13
12
14
1
13
Coupler for 1/2” EMT conduit.
14
52
15
14
PNEG-1447
Lower Junction Box, Meter Roll Motor Conduit, Rear Discharge Conduit
Meter roll speed sensor.
16
Rear discharge switch conduit at rear left
gusset.
17
18
19
2
1
11
1
7
Rear discharge switch (open to show mercury switch).
7
11
1
20
8
24
9
23
21
ITEM No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
PNEG-1447
22
DESCRIPTION
SEALTITE PVC 3/8"
CONNECTOR PVC 3/8" 45' W/NUT
SEALTITE PVC 3/4"
STRAIGHT PVC W/LOCKNUT 3/4"
FITTING COMPRESSION 3/4-TO BOX
CONDUIT 3/4" EMT
ENCLOSURE 4x4x2.5 WHITE PVC
CONNECTOR 1/2"
WIRE 18/2 TYPE SJOW-A BLACK
RDCR 3/4"X1/2"HEX BUSHING
ELBOW 3/8" 90 DEGREE PVC W/NUT
CONNECTOR 3/8" LIQUID-TITE TO 1/2" EMT
CONNECTOR 1/2" EMT COMPRESSION
CONDUIT 1/2" EMT METALLIC
CONNECTOR 1/2" EMT COMPRESSION
SPEED SENSOR BOX BRACKET
SCR METER ROLL SPEED SENSOR
DISCONNECT .187 FEM
METERING ROLL TIMING GEAR ASSB
DISCHARGE SWITCH MOUNTING PLATE
COVER ALUMINUM, CONDUIT BODY
CLIP, MERCURY SWITCH
MERCURY SWITCH
CONDUIT BODY, LL TYPE
PART No.
FH-7038
F-6913
FH-7063
FH-7053
D03-0199
D03-0086
FH-6972
FH-1310
WR-182SJOWA
D07-0028
FH-7050
D03-0060
D03-0054
D03-0057
D33-0002
D01-0462
D01-0527
HH-7046
D01-0687
D01-1105
TFC-0075
SPD-2098
D03-0010
D03-0375
53
Upper Juntion Box, Top Auger Motor Conduit, & Operator Light
Top auger motor conduit.
Upper junction box.
1
4
3
5
Operator light.
6
Fill switch assembly (installed).
7
2
9
12
10
1
9
11
2
15
11
10
1
2
8
Fill switch assembly (opened).
13
14
Items 9 - 14 are components of the mercury
switch box assembly (fill switch assembly) part
no. D01-0192.
9
ITEM No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
54
DESCRIPTION
CONDUIT 1/2" EMT METALLIC
CONNECTOR 1/2" EMT COMPRESSION
CLAMP 1/2" CONDUIT
CONNECTOR 1/2" EMT TO SEALTITE
SEALTITE PVC 1/2"
ELBOW 1/2" 90 DEGREE PVC WITH
LAMP 90 DEGREE W/JUNC.BOX
BULB, 100W 130V ROUGH SERVICE
ENCLOSURE 4x4x2.5 WHITE PVC
CONNECTOR 1/2"
WIRE 18/2 TYPE SJOW-A BLACK
MOUNTING PLATE WLDMNT, MERC.BX
MERCURY SWITCH 6-DEG. 6" LEADS
CLIP MERCURY SWITCH
MERCURY SWITCH SHAFT
PART No.
D03-0057
D03-0054
HH-1096
D03-0075
FH-7039
FH-7052
D03-0117
D03-0575
FH-6972
FH-1310
WR-182SJOWA
D01-0358
D03-0010
SPD-2098
D01-0103
PNEG-1447
Air Switch Assembly
Air switch assembly (part # D01-0672).
Air switch assembly (internal parts).
3
7
9
2
8
4
5
6
1
Upper air switch assembly (installed).
Lower air switch assembly (installed).
10
10
1-9
11
12
11
11
10
1-9
ITEM No.
PART No.
1-9
1
2
3
4
5
6
7
8
9
D01-0672
D01-0671
D01-0670
DC-1103
D03-0177
HF-7227
HF-7228
HF-7226
HF-7229
D03-0167
ITEM No.
10
11
12
PNEG-1447
10
QUANTITY
DESCRIPTION
AIR SWITCH ASSEMBLY
AIR SWITCH BOX CONDUIT HALF
AIR SWITCH BOX FACE PLATE
DECAL, AIR PRESSURE ADJUSTMENT
GROMMET, 11/16" ID x 1" OD
COUPLING, 1/4" STD BLACK STEEL
BUSHING, 1/4" - 1/8" HEX
NIPPLE, 1/8" CLOSE
ELBOW, 1/8" - 90 SCH 40
AIR PRESSURE SWITCH
DESCRIPTION
CONDUIT, 3/8" SEALTITE
CONNECTOR, 3/8" x 90
CONNECTOR, 3/8" STRAIGHT
2/DRYER
2/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
2/ASSEMBLY
1/ASSEMBLY
1/ASSEMBLY
PART No.
FH-7038
FH-7050
FH-7049
55
Network Control Box
3
1
4
2
5
17
19a
18
Conduit from fan
control box (same for
upper and lower
network box)
Conduit from air
switch assembly
(same for upper
and lower network
box)
2
18
18
19b
Conduit from:
1.)upper network box
(lower network box)
2.)upper plenum high limit
(upper network box)
Conduit from fan
heater pipe train
(same for upper
and lower
network box)
6
7
Conduit from:
1.)lower junction box (lower
network box)
2.)lower network box (upper
network box)
8
9
16
15
14
13
12
11
ITEM No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19a
19b
56
DESCRIPTION
NETWOK BOX MOUNTING CHANNEL
ENCLOSURE, 12" x 10 " x 5.25"
PLASTIC HOLE PLUG 1/2" DIA
DECAL, NETWORK FAN/HEATER
CONTROL BOARD MOUNTING PLATE
CONTROL BOARD REST
DECAL, GROUND
GROUND LUG
FAN/HEATER NETWORK CONTROL BOARD
HINGE, ALUMINUM
CONTROL BOARD REST
NETWORK BOX BACK PANEL
TERMINAL-BLOCK ENTRELEC 4MM
TERMINAL-BLANK END PROTECTOR
TERMINAL-ENTRELEC END STOP
TERMINAL-ENTRELEC GROUND BLOCK
elbow 1/2" 90deg pvc
elbow 3/8" 90deg pvc
elbow 3/4" 90deg pvc (lower network control box only)
elbow 3/8" 90deg pvc (upper network control box only)
10
5
PART No.
D01-1664
TF-1439
HH-2833
DC-1513
TF-1426
TF-1429A
DC-1254
FH-6634
HF-7276
D02-0037
TF-1429
TF-1428
D01-0531
D01-0532
D01-0533
D01-0534
FH-7052
FH-7050
FH-7054
FH-7050
PNEG-1447
Fan Heater Electrical Box
Fan Heater control box and electrical components.
1
4
5
2
13
12
3
14
6
ITEM
NUMBER PART NUMBER
1
2
2
2
3
4
4
5
6
ITEM
NUMBER
7
8
9
10
11
12
13
14
7
8
9
10
11
12
13
14
7
8
9
10
11
12
13
14
PNEG-1447
F-942
CD-0005
CD-0065
CD-0193
FH-4429-1
CD-0202
CD-0203
HH-7048
HH-7016
DESCRIPTION
ELECT. CONTROL BOX LID
FAN CONTROL BOX WRAPPER 26-28"
FAN CONTROL BOX WRAPPER 36"
FAN CONTROL BOX WRAPPER 40-42"
LATCH CONTROL BOX
FAN CONTROL BOX BOTTOM 26-28"
FAN CONTROL BOX BOTTOM 36-42"
GROMMET 1/2" OD, 3/8" ID
GROMMET 1 1/2" ID
DESCRIPTION
11
7
8
9 10
28" FAN
36" FAN
40" FAN
HEATERS HEATERS HEATERS
1
1
1
1
1
2
1
3
1
2
1
2
1
3
1
1
3
1
10-12 HP FAN MOTORS (2812, 3612 FAN HEATERS)
220V 1Ph
208V 3Ph
220V 3Ph
440V 3Ph
575V 3Ph
TERMINAL-BLOCK ENTRELEC 4MM
D01-0531
D01-0531
D01-0531
D01-0531
D01-0531
TERMINAL-BLANK END PROTECTOR
D01-0532
D01-0532
D01-0532
D01-0532
D01-0532
TERMINAL-ENTRELEC END STOP
D01-0533
D01-0533
D01-0533
D01-0533
D01-0533
TERMINAL-ENTRELEC GRND BLOCK
D01-0534
D01-0534
D01-0534
D01-0534
D01-0534
CONTACTOR
D03-0495
D03-0494
D03-0494
D03-0492
D03-0490
OVERLOAD
D03-0483
D03-0482
D03-0482
D03-0476
D03-0475
LUG GROUND,#TA-2
E160-1137
E160-1137
E160-1137
E160-1137
E160-1137
GRP-TRANSFORMER 2POLE IGNITION HH-1093-GRP HH-1093-GRP HH-1093-GRP HH-1093-GRP HH-1093-GRP
10-16 HP FAN MOTORS (3615 FAN HEATERS)
220V 1Ph
208V 3Ph
220V 3Ph
440V 3Ph
575V 3Ph
TERMINAL-BLOCK ENTRELEC 4MM
D01-0531
D01-0531
D01-0531
D01-0531
D01-0531
TERMINAL-BLANK END PROTECTOR
D01-0532
D01-0532
D01-0532
D01-0532
D01-0532
TERMINAL-ENTRELEC END STOP
D01-0533
D01-0533
D01-0533
D01-0533
D01-0533
TERMINAL-ENTRELEC GRND BLOCK
D01-0534
D01-0534
D01-0534
D01-0534
D01-0534
CONTACTOR
D03-0497
D03-0494
D03-0494
D03-0492
D03-0491
OVERLOAD
D03-0485
D03-0483
D03-0483
D03-0477
D03-0478
LUG GROUND,#TA-2
E160-1137
E160-1137
E160-1137
E160-1137
E160-1137
GRP-TRANSFORMER 2POLE IGNITION HH-1093-GRP HH-1093-GRP HH-1093-GRP HH-1093-GRP HH-1093-GRP
25 HP FAN MOTORS (4025 FAN HEATERS)
220V 1Ph
208V 3Ph
220V 3Ph
440V 3Ph
575V 3Ph
TERMINAL-BLOCK ENTRELEC 4MM
N/A
D01-0531
D01-0531
D01-0531
D01-0531
TERMINAL-BLANK END PROTECTOR
N/A
D01-0532
D01-0532
D01-0532
D01-0532
TERMINAL-ENTRELEC END STOP
N/A
D01-0533
D01-0533
D01-0533
D01-0533
TERMINAL-ENTRELEC GRND BLOCK
N/A
D01-0534
D01-0534
D01-0534
D01-0534
CONTACTOR
N/A
D03-0496
D03-0496
D03-0494
D03-0492
OVERLOAD
N/A
D03-0485
D03-0485
D03-0482
D03-0479
LUG GROUND,#TA-2
N/A
E160-1137
E160-1137
E160-1137
E160-1137
GRP-TRANSFORMER 2POLE IGNITION
N/A
HH-1093-GRP HH-1093-GRP HH-1093-GRP HH-1093-GRP
57
Control Box Control Panel
Network control panel (front).
10
1
2
14
13
3
12
4
11
10
5
58
6
7
8
9
ITEM
NUMBER
DESCRIPTION
CIRCUIT
PART NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
DECAL, NETWORK DRYER 2 FAN
SWITCH 2 POS. SELECTOR AMBER
SWITCH 2 POS. SELECTOR GREEN
SWITCH 3 POS. SELECTOR WHITE
SWITCH 2 POS. SELECTOR CLEAR
3 POS. SELECTOR SWITCH YELLOW
SWITCH 3 POS. SELECTOR BLUE
SWITCH 3 POS. SELECTOR RED
KNOB, AUGAT #PK-70B-1/4
LATCH, SOUTHCO SLOTTED
SWITCH STOP BLOCK (RED)
SWITCH START N.O.(ILLUMINATED)
SWITCH 3 POS. SELECTOR AMBER
TOUCH PANEL TOP DRY AUTO
MISC.
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
MISC.
MISC.
CONTROL
CONTROL
CONTROL
MISC.
DC-1521
D01-0444
D01-0446
D03-0182
D01-0448
D01-0579
D01-0449
D01-0447
E115-1060
TF-1519
D03-0020
D03-0017
D01-0445
TAF-6150
PNEG-1447
Control Box Control Panel (Inside)
Network control panel (rear).
1
7
2
3
6
1
Detailed view of a two
position switch.
Detailed view of a
single position switch.
4
4
5
5
4
ITEM
NUMBER
DESCRIPTION
CIRCUIT
PART NUMBER
1
2
3
4
5
6
7
LATCH, SOUTHCO SLOTTED
NETWORK DRYER DISPLAY BOARD
COMPUTER MOUNTING PLATE
BLOCK, CONTACT N/O
BLOCK, LIGHT 12/24/120V LAMPS
SCR POTENTIOMETER 10K
NETWORK SWITCH PANEL
MISC.
CONTROL
MISC.
CONTROL
CONTROL
CONTROL
MISC.
TF-1519
D03-0593
TF-1544
D63-0006
D01-0455
D03-0595
D01-1666
PNEG-1447
59
Lower Control Box Back Panel
Lower control box back panel.
1
2
3
Emergency stop switch
(outside).
10
11
Emergency stop switch
(inside).
4
5
6
7
8
5
10
12
9
60
ITEM
NUMBER
DESCRIPTION
CIRCUIT
PART NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
FILTER RFI "B" SERIES
WIRE TIE ANCHOR
WIRE TIE, 5" PANDUIT
DIN RAIL, TERMINAL BLOCK MOUNTING
TERMINAL - ENTRELEC END STOP
TERMINAL - ENTRELEC GROUND BLOCK
TERMINAL - BLOCK ENTRELEC 4MM
TERMINAL - END PROTECTOR
LOWER CONTROL BOX BACK PANEL
EMERGENCY STOP SWITCH
DECAL, EMERGENCY STOP
BLOCK, CONTACT N/C
CONTROL
MISC.
MISC.
MISC.
MISC.
MISC.
MISC.
MISC.
MISC.
SAFETY
MISC.
SAFETY
D03-0181
D02-0039
D03-0247
D03-0013
D01-0533
D01-0534
D01-0531
D01-0532
D01-0486
TF-1279
DC-1317
D63-0013
PNEG-1447
Upper Control Box
Upper control box power distrbution panel.
36
1
35
2
6
34
3
7
33
4
32
8
5
9
31
30
29
10
11
12
13
28
14
15
27
16
PNEG-1447
17
18 19 20
21
22
23
24
25 26
61
1214 Upper Control Box Component Part Numbers
1214S Upper control box power distrbution panel parts listing.
ITEM
NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
62
DESCRIPTION
1214S PART NUMBER
CIRCUIT
POWER BOX BOCK PANEL
N/A
OVERLOAD
LOAD
OVERLOAD
LOAD AUX.
OVERLOAD
UNLOAD
OVERLOAD
UNLOAD AUX.
CONTACTOR
LOAD
CONTACTOR
LOAD AUX.
CONTACTOR
UNLOAD
CONTACTOR
UNLOAD AUX.
TERMINAL-BLOCK ENTRELEC 4MM
CONTROL
TERMINAL-BLANK END PROTECTOR
CONTROL
TERMINAL-ENTRELEC END STOP
CONTROL
TERMINAL-ENTRELEC GRND BLOCK
CONTROL
RELAY, 3PDT 120V RH3B-U IDEC
CONTROL
RELAY BASE, 3PDT
CONTROL
TRANSFORMER
CONTROL
TERMINAL GROUND BAR
GROUND
NETWORK DRYER CONTROL BOARD MOUNT PLATE
N/A
NETWORK DRYER CONTROL BOARD
CONTROL
NETWORK DRYER CONTROL BOARD COVER PLATE
N/A
BREAKER 6 AMP 1 POLE 110VAC
CONTROL
BREAKER 10 AMP 2 POLE DELAYED
METER ROLL
BREAKER 3 AMP 2 POLE DELAYED
CONTROL
SCR CONTACTOR 15 AMP 3 POLE
METER ROLL
SCR DRIVE BOARD BASE UNIT
METER ROLL
SCR ISOLATED TERMINAL BOARD
METER ROLL
POWER BOX CATCH ANGLE, BOTTOM
N/A
MAIN BREAKER
POWER
BREAKER
UNLOAD AUX.
BREAKER
UNLOAD
DISTRIBUTION BLOCK
POWER
BREAKER
LOAD AUX.
BREAKER
LOAD
BREAKER
FAN 1
BREAKER
FAN 2
POWER BOX CATCH ANGLE, TOP
N/A
220V 1Ph
D01-0480
D03-0487
D03-0482
D03-0487
D03-0482
D03-0492
D03-0494
D03-0492
D03-0494
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D01-0493
D03-0460
D03-0460
D03-0300
D03-0460
D03-0460
D03-0466
D03-0466
D01-0551
208V 3Ph
D01-0480
D03-0477
D03-0480
D03-0477
D03-0480
D03-0491
D03-0493
D03-0491
D03-0493
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
070975553
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0728
D03-0108
D03-0711
D03-0592
D01-0550
D01-0503
D03-0461
D03-0453
D03-0293
D03-0461
D03-0453
D03-0461
D03-0461
D01-0551
220V 3Ph
D01-0480
D03-0475
D03-0479
D03-0475
D03-0479
D03-0490
D03-0492
D03-0490
D03-0492
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D01-0450
D03-0461
D03-0451
D03-0293
D03-0461
D03-0451
D03-0461
D03-0461
D01-0551
440V 3Ph
D01-0480
D03-0473
D03-0475
D03-0473
D03-0475
D03-0488
D03-0490
D03-0488
D03-0490
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D03-0271
D03-0545
D03-0389
D35-0001
D03-0545
D03-0389
D03-0545
D03-0545
D01-0551
575V 3Ph
D01-0480
D03-0472
D03-0475
D03-0472
D03-0475
D03-0488
D03-0489
D03-0488
D03-0489
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D03-0175
D03-0395
D03-0531
D35-0001
D03-0395
D03-0531
D03-0395
D03-0395
D01-0551
PNEG-1447
1218 Upper Control Box Component Part Numbers
1218S Upper control box power distrbution panel parts listing.
ITEM
NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
DESCRIPTION
POWER BOX BOCK PANEL
OVERLOAD
OVERLOAD
OVERLOAD
OVERLOAD
CONTACTOR
CONTACTOR
CONTACTOR
CONTACTOR
TERMINAL-BLOCK ENTRELEC 4MM
TERMINAL-BLANK END PROTECTOR
TERMINAL-ENTRELEC END STOP
TERMINAL-ENTRELEC GRND BLOCK
RELAY, 3PDT 120V RH3B-U IDEC
RELAY BASE, 3PDT
TRANSFORMER
TERMINAL GROUND BAR
NETWORK DRYER CONTROL BOARD MOUNT PLATE
NETWORK DRYER CONTROL BOARD
NETWORK DRYER CONTROL BOARD COVER PLATE
BREAKER 6 AMP 1 POLE 110VAC
BREAKER 10 AMP 2 POLE DELAYED
BREAKER 3 AMP 2 POLE DELAYED
SCR CONTACTOR 15 AMP 3 POLE
SCR DRIVE BOARD BASE UNIT
SCR ISOLATED TERMINAL BOARD
POWER BOX CATCH ANGLE, BOTTOM
MAIN BREAKER
BREAKER
BREAKER
DISTRIBUTION BLOCK
BREAKER
BREAKER
BREAKER
BREAKER
POWER BOX CATCH ANGLE, TOP
PNEG-1447
1218S PART NUMBER
CIRCUIT
N/A
LOAD
LOAD AUX.
UNLOAD
UNLOAD AUX.
LOAD
LOAD AUX.
UNLOAD
UNLOAD AUX.
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
GROUND
N/A
CONTROL
N/A
CONTROL
METER ROLL
CONTROL
METER ROLL
METER ROLL
METER ROLL
N/A
POWER
UNLOAD AUX.
UNLOAD
POWER
LOAD AUX.
LOAD
FAN 1
FAN 2
N/A
220V 1Ph
D01-0480
D03-0478
D03-0482
D03-0478
D03-0482
D03-0492
D03-0494
D03-0492
D03-0494
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D01-0493
D03-0464
D03-0460
D03-0300
D03-0464
D03-0460
D03-0466
D03-0466
D01-0551
208V 3Ph
D01-0480
D03-0477
D03-0480
D03-0477
D03-0480
D03-0491
D03-0493
D03-0491
D03-0493
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
070975553
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0728
D03-0108
D03-0711
D03-0592
D01-0550
D01-0503
D03-0461
D03-0453
D03-0293
D03-0461
D03-0453
D03-0461
D03-0461
D01-0551
220V 3Ph
D01-0480
D03-0475
D03-0479
D03-0475
D03-0479
D03-0490
D03-0492
D03-0490
D03-0492
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D01-0450
D03-0461
D03-0451
D03-0293
D03-0461
D03-0451
D03-0465
D03-0465
D01-0551
440V 3Ph
D01-0480
D03-0473
D03-0475
D03-0473
D03-0475
D03-0488
D03-0490
D03-0488
D03-0490
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D03-0271
D03-0545
D03-0389
D35-0001
D03-0545
D03-0389
D03-0529
D03-0529
D01-0551
575V 3Ph
D01-0480
D03-0472
D03-0475
D03-0472
D03-0475
D03-0488
D03-0489
D03-0488
D03-0489
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D03-0533
D03-0395
D03-0531
D35-0001
D03-0395
D03-0531
D03-0532
D03-0532
D01-0551
63
1220 Upper Control Box Components Part Numbers
1220S Upper control box power distrbution panel parts listing.
ITEM
NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
64
DESCRIPTION
POWER BOX BOCK PANEL
OVERLOAD
OVERLOAD
OVERLOAD
OVERLOAD
CONTACTOR
CONTACTOR
CONTACTOR
CONTACTOR
TERMINAL-BLOCK ENTRELEC 4MM
TERMINAL-BLANK END PROTECTOR
TERMINAL-ENTRELEC END STOP
TERMINAL-ENTRELEC GRND BLOCK
RELAY, 3PDT 120V RH3B-U IDEC
RELAY BASE, 3PDT
TRANSFORMER
TERMINAL GROUND BAR
NETWORK DRYER CONTROL BOARD MOUNT PLATE
NETWORK DRYER CONTROL BOARD
NETWORK DRYER CONTROL BOARD COVER PLATE
BREAKER 6 AMP 1 POLE 110VAC
BREAKER 10 AMP 2 POLE DELAYED
BREAKER 3 AMP 2 POLE DELAYED
SCR CONTACTOR 15 AMP 3 POLE
SCR DRIVE BOARD BASE UNIT
SCR ISOLATED TERMINAL BOARD
POWER BOX CATCH ANGLE, BOTTOM
MAIN BREAKER
BREAKER
BREAKER
DISTRIBUTION BLOCK
BREAKER
BREAKER
BREAKER
BREAKER
POWER BOX CATCH ANGLE, TOP
1220S PART NUMBER
CIRCUIT
N/A
LOAD
LOAD AUX.
UNLOAD
UNLOAD AUX.
LOAD
LOAD AUX.
UNLOAD
UNLOAD AUX.
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
GROUND
N/A
CONTROL
N/A
CONTROL
METER ROLL
CONTROL
METER ROLL
METER ROLL
METER ROLL
N/A
POWER
UNLOAD AUX.
UNLOAD
POWER
LOAD AUX.
LOAD
FAN 1
FAN 2
N/A
220V 1Ph
D01-0480
D03-0482
D03-0482
D03-0482
D03-0482
D03-0494
D03-0494
D03-0494
D03-0494
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D01-0504
D03-0464
D03-0464
D03-0300
D03-0464
D03-0464
D03-0510
D03-0510
D01-0551
208V 3Ph
D01-0480
D03-0479
D03-0483
D03-0479
D03-0483
D03-0492
D03-0494
D03-0492
D03-0494
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
070975553
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0728
D03-0108
D03-0711
D03-0592
D01-0550
D01-0497
D03-0468
D03-0459
D03-0293
D03-0468
D03-0459
D03-0468
D03-0468
D01-0551
220V 3Ph
D01-0480
D03-0477
D03-0483
D03-0477
D03-0483
D03-0491
D03-0494
D03-0491
D03-0494
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D01-0475
D03-0465
D03-0457
D03-0293
D03-0465
D03-0457
D03-0461
D03-0461
D01-0551
440V 3Ph
D01-0480
D03-0474
D03-0477
D03-0474
D03-0477
D03-0489
D03--0492
D03-0489
D03-0492
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D03-0271
D03-0529
D03-0528
D35-0001
D03-0529
D03-0528
D03-0529
D03-0529
D01-0551
575V 3Ph
D01-0480
D03-0473
D03-0476
D03-0473
D03-0476
D03-0489
D03-0490
D03-0489
D03-0490
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D03-0175
D03-0532
D03-0531
D35-0001
D03-0532
D03-0531
D03-0395
D03-0395
D01-0551
PNEG-1447
1222 Upper Control Box Component Part Numbers
1222S Upper control box power distrbution panel parts listing.
ITEM
NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
DESCRIPTION
POWER BOX BOCK PANEL
N/A
OVERLOAD
LOAD
OVERLOAD
LOAD AUX.
OVERLOAD
UNLOAD
OVERLOAD
UNLOAD AUX.
CONTACTOR
LOAD
CONTACTOR
LOAD AUX.
CONTACTOR
UNLOAD
CONTACTOR
UNLOAD AUX.
TERMINAL-BLOCK ENTRELEC 4MM
CONTROL
TERMINAL-BLANK END PROTECTOR
CONTROL
TERMINAL-ENTRELEC END STOP
CONTROL
TERMINAL-ENTRELEC GRND BLOCK
CONTROL
RELAY, 3PDT 120V RH3B-U IDEC
CONTROL
RELAY BASE, 3PDT
CONTROL
TRANSFORMER
CONTROL
TERMINAL GROUND BAR
GROUND
NETWORK DRYER CONTROL BOARD MOUNT PLATE
N/A
NETWORK DRYER CONTROL BOARD
CONTROL
NETWORK DRYER CONTROL BOARD COVER PLATE
N/A
BREAKER 6 AMP 1 POLE 110VAC
CONTROL
BREAKER 10 AMP 2 POLE DELAYED
METER ROLL
BREAKER 3 AMP 2 POLE DELAYED
CONTROL
SCR CONTACTOR 15 AMP 3 POLE
METER ROLL
SCR DRIVE BOARD BASE UNIT
METER ROLL
SCR ISOLATED TERMINAL BOARD
METER ROLL
POWER BOX CATCH ANGLE, BOTTOM
N/A
MAIN BREAKER
POWER
BREAKER
UNLOAD AUX.
BREAKER
UNLOAD
DISTRIBUTION BLOCK
POWER
BREAKER
LOAD AUX.
BREAKER
LOAD
BREAKER
FAN 1
BREAKER
FAN 2
POWER BOX CATCH ANGLE, TOP
N/A
PNEG-1447
1222S PART NUMBER
CIRCUIT
208V 3Ph
D01-0480
D03-0479
D03-0483
D03-0479
D03-0483
D03-0492
D03-0494
D03-0492
D03-0494
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
070975553
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0728
D03-0108
D03-0711
D03-0592
D01-0550
D01-0497
D03-0468
D03-0459
D03-0293
D03-0468
D03-0459
D03-0468
D03-0468
D01-0551
220V 3Ph
D01-0480
D03-0477
D03-0483
D03-0477
D03-0483
D03-0491
D03-0494
D03-0491
D03-0494
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D01-0475
D03-0465
D03-0457
D03-0293
D03-0465
D03-0457
D03-0461
D03-0461
D01-0551
440V 3Ph
D01-0480
D03-0474
D03-0477
D03-0474
D03-0477
D03-0489
D03-0492
D03-0489
D03-0492
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D03-0271
D03-0529
D03-0528
D35-0001
D03-0529
D03-0528
D03-0529
D03-0529
D01-0551
575V 3Ph
D01-0480
D03-0473
D03-0476
D03-0473
D03-0476
D03-0489
D03-0490
D03-0489
D03-0490
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D03-0175
D03-0532
D03-0531
D35-0001
D03-0532
D03-0531
D03-0395
D03-0395
D01-0551
65
1226 Upper Control Box Component Part Numbers
1226S Upper control box power distrbution panel parts listing.
ITEM
NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
66
DESCRIPTION
POWER BOX BOCK PANEL
OVERLOAD
OVERLOAD
OVERLOAD
OVERLOAD
CONTACTOR
CONTACTOR
CONTACTOR
CONTACTOR
TERMINAL-BLOCK ENTRELEC 4MM
TERMINAL-BLANK END PROTECTOR
TERMINAL-ENTRELEC END STOP
TERMINAL-ENTRELEC GRND BLOCK
RELAY, 3PDT 120V RH3B-U IDEC
RELAY BASE, 3PDT
TRANSFORMER
TERMINAL GROUND BAR
NETWORK DRYER CONTROL BOARD MOUNT PLATE
NETWORK DRYER CONTROL BOARD
NETWORK DRYER CONTROL BOARD COVER PLATE
BREAKER 6 AMP 1 POLE 110VAC
BREAKER 10 AMP 2 POLE DELAYED
BREAKER 3 AMP 2 POLE DELAYED
SCR CONTACTOR 15 AMP 3 POLE
SCR DRIVE BOARD BASE UNIT
SCR ISOLATED TERMINAL BOARD
POWER BOX CATCH ANGLE, BOTTOM
MAIN BREAKER
BREAKER
BREAKER
DISTRIBUTION BLOCK
BREAKER
BREAKER
BREAKER
BREAKER
POWER BOX CATCH ANGLE, TOP
1226S PART NUMBER
CIRCUIT
N/A
LOAD
LOAD AUX.
UNLOAD
UNLOAD AUX.
LOAD
LOAD AUX.
UNLOAD
UNLOAD AUX.
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
CONTROL
GROUND
N/A
CONTROL
N/A
CONTROL
METER ROLL
CONTROL
METER ROLL
METER ROLL
METER ROLL
N/A
POWER
UNLOAD AUX.
UNLOAD
POWER
LOAD AUX.
LOAD
FAN 1
FAN 2
N/A
208V 3Ph
D01-0480
D03-0480
D03-0483
D03-0480
D03-0483
D03-0493
D03-0494
D03-0493
D03-0494
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
070975553
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0728
D03-0108
D03-0711
D03-0592
D01-0550
D03-0657
D03-0468
D03-0461
D03-0293
D03-0468
D03-0461
D03-0144
D03-0144
D01-0551
220V 3Ph
D01-0480
D03-0479
D03-0483
D03-0479
D03-0483
D03-0492
D03-0494
D03-0492
D03-0494
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D01-0505
D03-0465
D03-0461
D03-0293
D03-0465
D03-0461
D03-0467
D03-0467
D01-0551
440V 3Ph
D01-0480
D03-0475
D03-0477
D03-0475
D03-0477
D03-0490
D03-0492
D03-0490
D03-0492
D03-0493
D03-0494
D03-0495
D03-0496
D03-0497
D03-0498
D03-0499
D03-0500
D03-0501
D03-0502
D03-0503
D03-0504
D03-0505
D03-0506
D03-0507
D03-0508
D03-0509
D03-0510
D03-0535
D03-0529
D03-0545
D35-0001
D03-0529
D03-0545
D03-0547
D03-0547
D01-0551
575V 3Ph
D01-0480
D03-0475
D03-0476
D03-0475
D03-0476
D03-0489
D03-0490
D03-0489
D03-0490
D01-0531
D01-0532
D01-0533
D01-0534
HF-7203
07097555
FH-3807
006-1184-8
TF-1713
D03-0587
D01-1710
D03-0661
D03-0660
D03-0726
D03-0106
D03-0711
D03-0592
D01-0550
D03-0175
D03-0532
D03-0395
D35-0001
D03-0532
D03-0395
D03-0141
D03-0141
D01-0551
PNEG-1447
NOTES
This Equipment shall be installed in accordance
with the current installation codes and applicable
regulations which should be carefully followed in
all cases. Authorities having jurisdiction should be
consulted before installation occurs.
The GSI Group, Inc.
1004 E. Illinois St.
Assumption, IL 62510-0020
Phone: 217-226-4421
Fax: 217-226-4420
e-mail: [email protected]
internet: http://www.grainsystems.com
Copyright © 2006 by The GSI Group
Printed in the USA
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
