IBM System Storage Product Guide
The future of your business is already here
IBM System Storage™ solutions are built with the success of
your business in mind. End-to-end storage ingenuity and
unmatched expertise from IBM help you reduce costs, risks
and complexity while improving efficiencies and the
responsiveness of your infrastructure and people.
Go green for the planet—and your bottom line
Saving energy means saving money. Get a green “thumbs up”
when you implement IBM System Storage solutions to drive
down runaway costs in power, cooling and space. Regardless
of the size of your business, IBM offers energy-efficient
strategies and savings for a sustainable enterprise.
Easy come, easy grow with a nimble, responsive IT
infrastructure
Broaden your business horizons with innovation that
matters
Being responsive to changing business needs is often easier
said than done. IBM System Storage helps you unlock business resiliency and stay ahead of everyday challenges, with
easy-to-use, affordable storage offerings that flexibly manage
growth, complexity and risk.
Imagine breakthrough innovations that allow you to run your
organization not only faster, but better, helping to attract new
customers and gain competitive advantages. System Storage
solutions help you stay consistently out front so that you can
make strategic decisions on how to use advancements in
technology to broaden your business and gain a better return
on investment.
Effectively manage your data with the strength and simplicity of
IBM System Storage
●
Power up your savings by powering down storage
inefficiencies
●
Prepackaged storage kits and advanced systems virtualization from IBM facilitate easier ways for you to reduce costs,
lower energy consumption and dramatically improve storage
utilization—without affecting performance.
●
Automated tiered storage management and exceptional data
mobility let you better match applications and investments to
the value of stored data—saving both time and money.
Simplified storage platforms from IBM use graphical interfaces and integrated systems to effortlessly manage both
physical and virtual resources across a heterogeneous
environment—for easier management of your growing
business.
●
IBM System Storage platforms allow you to dynamically and
reliably scale storage with pervasive infrastructure flexibility to
keep you in control of data growth and costs.
●
Protecting data is vital to operating efficiently under normal
business conditions—and rapidly recovering during emergencies. System Storage helps you reduce risk with rocksolid data protection tools and high availability across the
enterprise, especially when you need it most.
2
Transform your business through innovation that matters
●
Delineated along a clear technical roadmap to help ensure
smooth upgrades and transitions, IBM storage platforms are
designed to meet even the most stringent data storage
requirements, regardless of changes in future technology.
●
The long-term binary compatibilities of System Storage platforms foster longevity of the equipment, applications and
skills that support your organization, even as new systems
are introduced.
Storage Area Network (SAN) Products
Entry SAN switches for easy-to-use SMB solutions
IBM System Storage
SAN24B-4 Express
(2498-B24, 249824E)
●
Provides high-performance, scalable and simple-to-use fabric switching with 8, 16 or 24 ports operating at
8, 4, 2 or 1 Gigabits per second (depending on which optical transceiver is used) for servers running Microsoft®
Windows®, AIX®, UNIX®, and Linux® operating systems, server clustering, infrastructure simplification and business continuity solutions. The SAN24B-4 Express includes EZSwitchSetup wizard, which is an embedded setup tool
designed to guide novice users through switch setup, often in less than five minutes.
IBM TotalStorage®
SAN16B-2 (2005-B16)
IBM TotalStorage
SAN16B-2 Express
Model (200516B)
●
Provides high-performance, scalable and simple-to-use fabric switching with 8, 12 or 16 ports operating at
1, 2 and 4 Gigabits per second (Gbps) fabric for servers running Microsoft Windows, AIX, UNIX, Linux, and
IBM OS/400® operating systems, server clustering, infrastructure simplification and business continuity solutions.
The SAN16B-2 includes EZSwitchSetup wizard, which is an embedded setup tool designed to guide novice users
through switch setup, often in less than five minutes.
Cisco® MDS 9124
Express for
IBM System Storage
(2053-424, 241724C)
●
Provides high-performance, scalable and simple-to-use fabric switching with 8, 16 or 24 ports operating at
1, 2 and 4 Gbps for servers running Microsoft Windows, UNIX, Linux, NetWare and OS/400 operating systems,
server clustering, infrastructure simplification and business continuity solutions. The switch includes replaceable
power supply, Virtual SAN, Cisco Fabric Manager and redundant power supply feature designed to simplify setup
and ongoing maintenance for Cisco MDS 9000 users.
Enterprise SAN directors for high availability and scalability enterprise solutions
IBM TotalStorage SAN256B
(2109-M48)
●
High-performance, high-density and high-availability SAN director designed to be the foundation for
large enterprise-class infrastructure simplification and business continuity solutions. The SAN256B
director provides from 16 to 384 ports and contains two control processors for high-availability, supporting one to eight blades. Two different types of switch blades are available; one capable of supporting 4, 2 and 1 Gbps link speeds and the other type capable of supporting 8, 4 and 2 Gbps link speeds.
Switch blades contain 16, 32 or 48 ports. Each port can support either Fibre Channel or FICON® links.
A Fibre Channel Routing blade is available to enable routing between heterogeneous SAN fabrics and
distance extension between sites using FCIP. A 10 Gbps FC switch blade is available to support highspeed Inter-Switch Links (ISLs), and an iSCSI blade is available to enable low-cost connectivity to
servers via Ethernet. Standard features including Advanced Inter-Switch Link (ISL) Trunking, Web Tools,
Advanced Zoning, Fabric Watch, Performance Monitoring and Fabric Access Layer (API).
IBM TotalStorage SAN140M
(2027-140)
●
High-availability enterprise SAN director for Intel® processor-based servers, IBM System i™ systems,
IBM System p™ servers and IBM System z™ servers. Provides 16 to 140 ports, scalable in 4-port
increments; 1, 2 and 4 Gbps Fibre Channel and FICON switch for Windows, Linux, UNIX and z/OS
servers.
Provides 10 Gbps backbone links for high-performance continuity solutions.
●
IBM TotalStorage SAN256M
(2027-256)
●
High-availability enterprise SAN director for Intel processor-based servers, System i systems, System p
servers, IBM System x™ servers and System z mainframes. Provides 64 to 256 ports, scalable in
32-port increments; 1, 2 and 4 Gbps Fibre Channel and FICON director with 10 Gbps backbone links
for Windows, Linux, UNIX and z/OS servers. Includes Director FlexPar capability for up to four logical
partitions with separate fabric services.
Cisco MDS 9506 for
IBM System Storage
(2054-E04)
●
High-availability enterprise SAN director for Intel processor-based servers, System i systems, System p
servers and System z mainframes. Scalable from 12 to 192 1, 2, 4 and 10 Gbps ports with one to four
4-, 12-, 24- and 48-port Fibre Channel modules for Windows, Linux, UNIX and z/OS servers.
An 18/4 4 Gbps Fibre Channel/GbE port multiservice module enables high-performance, cost-effective
SAN extension over IP for continuity solutions.
Midrange SAN switches for scalable SMB and enterprise solutions
IBM System Storage SAN40B-4
(2498-B40, 249840E)
IBM System Storage SAN32B-3
(2005-B5K, 20055KB)
●
●
Provides high-performance, scalable and simple-to-use fabric switching with 24, 32 or 40 ports operating at 8, 4, 2 or 1 Gigabits per second (depending on which optical transceiver is used) for servers running Microsoft Windows, AIX, UNIX, Linux, OS/400 and z/OS® operating systems. Many advanced
functions are available to facilitate operation in medium and large networks.
Provides high-performance, scalable and simple-to-use fabric switching with 16, 24 or 32 ports operating at 1, 2 and 4 Gbps for servers running Microsoft Windows, UNIX, Linux, OS/400 and z/OS operating
systems, server clustering, infrastructure simplification and business continuity solutions. The SAN32B-2
and SAN32B-3 include dual replaceable power supplies, Advanced Zoning, Fabric Watch and Web Tools.
IBM System Storage SAN80B-4
(2498-B80)
●
IBM TotalStorage SAN64B-2
(2005-B64)
●
Provides high-performance, scalable and simple-to-use fabric switching with 32, 48 or 64 port operating
at 1, 2 and 4 Gbps fabric for servers running Microsoft Windows, UNIX, Linux, NetWare, OS/400 and
IBM z/OS operating systems.
Cisco MDS 9134 for
IBM System Storage
(2054-434, -S34)
●
Designed to address the needs of medium-sized businesses and large enterprises.
Model 434 provides high-performance, scalable and simple-to-use fabric switching with 24 or 32 ports
operating at 1, 2 and 4 Gbps for servers running Microsoft Windows, UNIX, Linux, NetWare, OS/400 and
z/OS operating systems, server clustering, infrastructure simplification and business continuity solutions.
Model S34 provides stacked switch bundle with 48, 56 or 64 port switch fabric with two 10 Gbps Inter
Switch Links (ISLs).
●
●
●
Cisco MDS 9509 for
IBM System Storage
(2054-E07)
Provides high-performance, scalable and simple-to-use fabric switching with 48, 64 or 80 ports operating at 8, 4, 2 or 1 Gigabits per second (depending on which optical transceiver is used) for servers running Microsoft Windows, AIX, UNIX, Linux, OS/400 and z/OS operating systems. Many advanced functions
are available to facilitate operation in medium and large networks.
●
●
Cisco MDS 9513 for
IBM System Storage
(2054-E11)
●
●
High-availability enterprise SAN director for Intel processor-based servers, System i systems, System p
servers and System z mainframes. Scalable from 12 to 336 1, 2, 4 and 10 Gbps ports with one to
seven 4-, 12-, 24- and 48-port Fibre Channel modules for Windows, Linux, UNIX and z/OS servers.
An 18/4 4 Gbps Fibre Channel/GbE port multiservice module enables high-performance, cost-effective
SAN extension over IP for continuity solutions.
High-availability enterprise SAN director for Intel processor-based servers, System i systems, System p
servers and System z mainframes. Scalable from 12 to 528 1, 2, 4 and 10 Gbps ports with one to
eleven 4-, 12-, 24- and 48-port Fibre Channel modules for Windows, Linux, UNIX and z/OS servers.
An 18/4 4 Gbps Fibre Channel/GbE port multiservice module enables high-performance, cost-effective
SAN extension over IP for continuity solutions.
SAN routers to connect heterogeneous SAN fabrics and enable distance extension using
Fibre Channel over IP
IBM System Storage SAN04B-R router
(2005-R04)
●
Provides SAN distance extension using FCIP over the Internet for IBM System x servers,
System i systems, and System p server environments. The SAN04B-R includes two 4, 2 and
1 Gbps Fibre Channel ports and two 50 Megabits per second Ethernet ports. FCIP Tunnelling
Service for SAN extension of IP WAN infrastructure features is included.
IBM TotalStorage SAN18B-R SAN router
(2005-R18)
●
Provides multiprotocol SAN routing for IBM System x servers, System i systems, System p
servers and System z mainframes. The SAN18B-R includes sixteen 4, 2 and 1 Gbps Fibre
Channel or FICON ports and two Gigabit Ethernet ports. FC-FC Routing for SAN island consolidation and optional FCIP Tunnelling Service for SAN extension of IP WAN infrastructure features
are included.
Cisco MDS 9222i for
IBM System Storage
(2054-E01)
●
Designed to address the needs of medium-sized businesses and large enterprises, the modular 18/4 (4 Gbps Fibre Channel/GbE) port multiservice SAN router enables high-performance,
cost-effective SAN extension over IP for continuity solutions.
Scalable from 18 to 66 1, 2, 4 and 10 Gbps ports with one 4-, 12-, 24- and 48-port Fibre
Channel module for Windows, Linux, UNIX and z/OS servers.
Enterprise SAN directors for high availability and scalability enterprise solutions
IBM System Storage SAN768B
(2499-384)
●
Premier fabric backbone for data network consolidation in large enterprise data centers. Provides high
performance and high availability data networking with new industry-leading 8 Gbps Fibre Channel
(FC) technology. It is also the first member of the IBM System Storage b-type family designed to exploit
Brocade®’s new Data Center Fabric architecture. The SAN768B introduces Inter-Chassis Links (ICLs)
to connect two systems to form a 768-port fabric. With 16 to 384 ports per system, it includes all
capabilities of SAN256B (including the Fibre Channel Routing Blade and the 10 Gbps FC Blade) plus
adds Adaptive Networking to enable Quality of Service (QoS) management and Integrated Routing to
enable interconnect of heterogeneous SAN fabrics.
●
3
Tape Storage Systems
Entry-level/Midrange Tape Products
Entry-level Tape Drives
Entry-level Tape Libraries
Midrange Tape Drives
Midrange Tape Libraries
TS2230
TS2240
3580
TS2340
TS3100
TS3100
TS3200
TS3200
TS1030
TS1040
TS3310
TS3500
Product
3580
3580
3580
3580
3573 L2U
3573 L4U
3588
3576
3584
3580
H3L, H3S, PNs
3580L3E,
3580S3E
3580
H4S, PNs
3580S4E,
3580E4S
3580
L33, PN 3580L3H
3580
L43, S43, PNs,
3580L4X,
3580S4X
3588
F3B
3588
F4A
3576
L5U
E9U
3584
L53
D53
Product
strengths
Multiplatform
support
Half-high form
factor
Lower entry price
Multiplatform
support
Backward read
capable to LTO1
Max performance
for LTO3
3 Gbps SAS
attachment
Encryption
capable
Multiplatform
support
High performance
High capacity
Multiplatform
support,
Same capacity as
full high at a
lower price
Supports both
LTO3 and LTO4
Half-high drives
Multiplatform
support
High performance
High capacity
Multiplatform
support
High performance
High capacity
Data protection
Multiplatform
support
High performance
High capacity
Modular design
Multiplatform
support
High performance
High capacity
Number of drives
Max number of
cartridges
WORM/
Encryption
Native capacity
1
1
3 Gbps SAS
attachment
Encryption
capable
Multiplatform
support
High capacity
Half-high form
factor
1
1
3573
L2U and PNs
3573L3S,
3573F3S,
3573L4S,
3573F4S,
3573S4S
Multiplatform
support
High performance
High capacity
3573 L4U featuring Ultrium HalfHigh drives
3573
PNs 3573L34,
3573S34, 3573
S44, 3573 E44
3588
Machine Type
model
3573 L2 3 featuring Ultrium HalfHigh drives
3573
PNs 3573L32,
3573S32, 3573
S42, 3573 E42
1
1
1
1
1
24
1–2 LTO half-high
24
1–2
48
1–4 LTO half-high
48
1
NA
1
NA
1–18
396
1–192
6,8871
yes/no
yes/yes
yes/no
yes/yes
yes/yes
yes/yes
yes/yes
yes/yes
yes/no
yes/yes
yes/yes
yes/yes
Gen 3: 400 GB
Gen 4: 800 GB
Gen 3: 400 GB
Gen 4: 800 GB
Gen 4: 1600 GB
Gen 4: 120 MBps
Gen 3: 19.2 TB
Gen 4: 38.4 TB
Up to 76.8 TB
Up to 480 MBps
800 GB
80 MBps
1600 GB
120 MBps
Gen 3: 158.4 TB
Gen 4: 316.8 TB
Up to 633.6 TB
2.16 GBps
Up to 5.5 PB
Gen 3: 800 GB
Gen 3: 80 MBps
Gen 3: 19.2 TB
Gen 4: 38.4 TB
Up to 76.8 TB
Up to 240 MBps
800 GB
Gen 4: 1600 GB
Gen 4: 120 MBps
Gen 3: 9.6 TB
Gen 4: 19.2 TB
Up to 38.4 TB
Up to 240 MBps
400 GB
Gen 3: 800 GB
Gen 3: 60 MBps
Gen 3: 9.6 TB
Gen 4: 19.2 TB
Up to 38.4 TB
120 MBps
LVD SCSI, 3 Gbps
SAS
3 Gbps SAS
LVD SCSI
LVD SCSI, 3 Gbps
SAS
3 Gbps SAS
LVD SCSI
4 Gbps FC
4 Gbps FC
NA
NA
NA
NA
4 Gbps FC
3 Gbps SAS
LVD SCS
NA
3 Gbps SAS
LVD SCSI
NA
4 Gbps FC
3 Gbps SAS
LVD SCSI
N/A
NA
TS3500
TS3500
System p,
System i,
System x,
Microsoft Window
s, HP-UX,
Sun Solaris, Linux
A, B, C, D, E, F, G,
H, J, L, M
Refer to Tape
Media, page 8
3 years6
CRU
System p,
System x and others supporting
3 Gbps attach
System p,
System i,
System x,
Microsoft Window
s; HP-UX;
Sun Solaris; Linux
A, B, C, D, E, F, G,
H, J, L, M, N7
Refer to Tape
Media, page 8
3 years6
CRU
System p,
System i,
System x,
Microsoft Window
s, HP-UX,
Sun Solaris, Linux
A (others in plan)
System p,
System i,
System x,
Microsoft
Windows; HP-UX;
Sun Solaris; Linux
A, B, C, D, E, F, G,
H, J, L, M, N7
Refer to Tape
Media, page 8
3 years6
CRU
System p,
System i,
System x,
Microsoft
Windows; HP-UX;
Sun Solaris; Linux
A, B (others in
plan)
Refer to Tape
Media, page 8
3 years6
CRU
System p,
System i,
System x,
Microsoft
Windows; HP-UX;
Sun Solaris; Linux
A, B, C, D, E, F, G,
H, J, L, N7
Refer to Tape
Media, page 8
3 years6
CRU
System p,
System i,
System x,
Microsoft
Windows; HP-UX;
Sun Solaris; Linux
A, B (others in
plan)
Refer to Tape
Media, page 8
3 years6
CRU
System p,
System i,
System x,
Microsoft Window
s; HP-UX;
Sun Solaris; Linux
A, B, C, D, E, F, G,
H, J, L7
Refer to Tape
Media, page 8
1 year
Onsite Repair
(24x7)
System p,
System i,
System x,
Microsoft Window
s; HP-UX;
Sun Solaris; Linux
A (others in plan)
Typical capacity
Native
performance
Interface
Supported tape
libraries
Platform
support4
Application
support5
Media
Warranty period
Warranty type
2
A (others in plan)
Refer to Tape
Media, page 8
3 years
CRU
Refer to Tape
Media, page 8
3 years6
CRU
Multiplatform
support,
Same capacity
as full high at a
lower price
Supports both
LTO3 and LTO4
Half-high drives
3573
L4U and PNs
3573L3H,
3573F3H,
3573L4H,
3573F4H,
3573S4H
Multiplatform
support
High performance
High capacity
Refer to Tape
Media, page 8
1 year
Onsite Repair
(24x7)
Up to 11 PB
Up to 23 GBps
4 Gbps FC
3 Gbps SAS
LVD SCSI
NA
4 Gbps FC
System p,
System i,
System x,
Microsoft Window
s; HP-UX;
Sun Solaris; Linux
A, B, C, D, E, F, G,
H, J, L7
Refer to Tape
Media, page 8
1 year
Next Business
Day (9x5)
System p,
System i,
System x,
Microsoft Window
s; HP-UX;
Sun Solaris; Linux
A, B, C, D, E, F, G,
H, J, L7
Refer to Tape
Media, page 8
1 year
Onsite Repair
(24x7)
NA
F/W = Fast/Wide, Diff = Differential, N/A = Not Applicable, FC = Fibre Channel, X = Extended length cartridge, IOE = IBM Onsite Exchange, CRU = Customer Replaceable Unit
NOTES 1: Max number of cartridges decreases as tape drives are added. 2: Typical compression for open system environments is 2:1 (user results may vary) 4: Also includes selected IBM xSeries®, IBM Netfinity®, IBM System i, IBM AS/400® and IBM System p servers. System z support for Linux only
5: Refer to http://www-03.ibm.com/systems/storage/tape/library.html#interoperability for current application support 6: In most countries 7: The following vendors provide application support to the platforms defined above: A = IBM Tivoli® Storage Manager, B = Symantec VERITAS NetBackup, C = Symantec VERITAS Backup
Exec, D = EMC Legato NetWorker, E = CA BrightStor ARCserve Backup, F = HP OpenView Storage Data Protector, G = CommVault Galaxy, H = BakBone NetVault, I = LSC, J = IBM BRMS, K = IBM OnDemand, L = Help/Systems Robot/Save, M = LXI Media Management, N = Dantz.
4
Tape Storage Systems (continued)
Enterprise Tape Products
Tape Drive
Tape Controller
Tape Library
Tape Virtualization
3592
3592
3577
3584
Virtualization Engine
Product
Machine Type
model
TS1120
3592
E05
TS1120
3592
C06
TS3400
3577
L5U
Product
strengths
Multiplatform support
High performance
High capacity
Data protection
1
System z attachment of TS1120 drives
High performance
Compact format
Operates in library or autoloader mode
TS3500
3584
L23
D23
Multiplatform support
Advanced management
Scalable
TS7530
3954
CV7 (requires additional machine types
and models)
Reduces backup window
Reduces recovery time
High capacity
TS7740
3957
V06 (requires additional machine types
and models)
Increases performance
Scalable
Helps reduce cost
1–12
1–2
1–192
yes/yes
yes/yes
yes/yes
yes/yes
Up to 1024 (1 node)*
Up to 4096 (4 node)*
no/yes
Up to 128*
Up to 768* (3 site GRID)
no/no
NA
NA
18
62602
Up to 1,000,000*
60/100 GB (JJ/JR media)
300/500 GB (JA/JW media)
700 GB (JB/JX media)
180/300 GB with JJ/JR
900/1500 GB with JA/JW
2.1 TB with JB/JX
Up to 104 MBps
NA
Varies8
Up to 1.8 TB
Up to 9 TB
Up to 12.6 TB
Up to 5.4 TB
Up to 27 TB
Up to 37.8 TB
Up to 208 MBps
Up to 626 TB
Up to 3.1 PB
Up to 4.3 PB
Up to 1.87 PB
Up to 9.3 PB
Up to 13.1 PB
Up to 19.2 TBps
Up to 64,000 (1 node)*
Up to 256,000 (4 node)*
Up to 1.7 PB
4 Gbps FC
TS3400, TS3500, 3494***
4 Gbps FC
TS3400, TS3500, 3494***
4 Gbps FC
NA
4 Gbps FC
NA
System p, System i, System x, System z;
Microsoft Windows; HP-UX; Sun Solaris;
Linux
A B C D E F G H J L7
System p, System i, System x, System z;
Microsoft Windows; HP-UX; Sun Solaris;
Linux
A B C D E F G H J L7
System p, System i, System x, System z,
Microsoft Windows, HP-UX, Sun Solaris,
Linux
ABCDEJ
Refer to Tape Media, page 8
1 year
Onsite Repair (24x7)
NA
1 year
Onsite Repair (24x7)
Refer to Tape Media, page 8
1 year
Onsite Repair (24x7)
Number of drives
WORM/
Encryption
Number of
cartridges
Native capacity
Typical capacity1
Native
performance
Interface
Supported tape
library
Platform
support5
Application
support6
Media
Warranty period
Warranty type
*
Virtual resource specification
**
for data replication only
***
Product withdrawn from marketing
NA
Up to 6 TB
Up to 18 TB (3 site GRID)
Up to 1.7 PB
Up to 2.6 PB
Up to 18 TB
Up to 54 TB (3 site GRID)
Up to 4.8 GBps
Up to 600 MBps
4 Gbps FC
TS3500, 3494***
System p, System i, System x, System z;
Microsoft Windows; HP-UX; Sun Solaris;
Linux
See drive
4 Gbps FC
TS3500, TS3310, TS3200, TS3100,
3494***
System p, System x, System z10,
System i11; Microsoft Windows; HP-UX;
Sun Solaris; Linux
A, B
E
Refer to Tape Media, page 8
1 year
Onsite Repair (24x7)
NA
1 year
Onsite Repair (24x7)
NA
1 year
Onsite Repair (24x7)
System z
F/W = Fast/Wide, Diff = Differential, N/A = Not Applicable, FC = Fibre Channel, X = Extended length cartridge, IOE = IBM Onsite Exchange, CRU = Customer Replaceable Unit
NOTES 1: Typical compression for mainframe environments is 3:1; 2:1 for open systems (user results may vary) 2: Max number of 3592 cartridges decreases as tape drives are added 3: IBM AIX® 4.1.5 or later. 4: Load and search only 5: Server platforms with SAN-ready attachability, model- and feature-dependent.
6: The latest ISV support can be found in the connectivity section at http://www-03.ibm.com/systems/storage/tape/library.html#compatibility. 7: The following vendors provide application support to the platforms defined above: A = IBM Tivoli Storage Manager, B = Symantec VERITAS NetBackup, C = Symantec VERITAS
Backup Exec, D = EMC Legato NetWorker, E = CA BrightStor ARCserve Backup, F = HP OpenView Storage Data Protector, G = CommVault Galaxy, H = BakBone NetVault, I = LSC, J = IBM BRMS, K = IBM OnDemand, L = Help/Systems Robot/Save, M = LXI Media Management. 8: Performance varies by environment 10: Applies to Linux
on System z using FCP 11: Requires RPQ 12: EE=Enterprise Edition LE=Limited Edition
5
Tape Storage Systems (continued)
Other Backup Tape Products
Tape Drives
Optical
7206-336
7206-VXA
7207
7212
7214
7210
3996
Product
Machine Type
model
Product
strengths
Number of drives
Max number of
cartridges
Cartridge
capacity native/
compressed
DAT72 Tape Drive
7206
336-DDS Gen 5
Cost-effective
streaming tape drive
1
1
VXA-2 Tape Drive
7206
VX2, VX3
Low-cost, high-capacity VXA-2
technology
1
1
SLR60 Tape Drive
7207
330
Backward read/write compatible
with System i internal
1
1
Device Enclosure*
7212
103
Rack-mountable 2-drive enclosure
utilizes only 1U (1.75") of space
1–2
2
Device Enclosure*
7214
1U2
Rack-mountable 2-drive enclosure
utilizes only 1U (1.75") of space
1–2
2
DVD option
7210
030
External deskside
Library
3996
32, 80, 174
Large scale optical
1
1
Up to 4
Up to 174
36/72 GB
VX2: 80/160 GB
XV3: 160/320 GB
330: 30/60 GB
DVDRAM: Variable (FC1420)
DVDROM: Variable (FC1421)
DAT72: 36/72 GB (FC1400)
4.9/9.4 GB
60 GB
Max drive data
rate1 native/
compressed
Interface
Platform
support3
Media
Warranty period
Warranty type
336: 3/6 MBps
VX2: 6/12 MBps
VX3: 12/24 MBps
330: 4/8 MBps
DVD: Variable (FC1103)
VXA2: 80/160GB (FC1104)
DAT72: 36/72GB (FC1105)
SLR60: Variable (FC1107)
SLR100: Variable (FC1108)
HHLTO2: 200/400GB (FC1109)
XVA320 (FC1114)
DDS/DAT72: 3/6 MBps
VXA: 12/24 MBps
DAT72 3/6 MBps
NA
12 MBps
SCSI-2 F/W SE, LVD/SE
System p
SCSI-3 ULTRA, LVD/SE, 160/320
System p, System i
SCSI-2 SE, ULTRA, LVD/SE, 160/320
System p, System i
SCSI-3 ULTRA, LVS/SE, 160/320
System p, System i
3 Gbps SAS
System p, System i
SCSI-3 ULTRA, LVD-SE, 160/320
System p, System i
LVD SCSI, 160/320
System p, System i, System x
Refer to Tape Media, page 8
1 year
Onsite Repair (24x7)
Refer to Tape Media, page 8
1 year
Onsite Repair (24x7)
Refer to Tape Media, page 8
1 year
Onsite Repair (24x7)
Refer to Tape Media, page 8
1 year
Onsite Repair (24x7)
Refer to Tape Media, page 8
1 year
Onsite Repair (24x7)
Refer to Tape Media, page 8
1 year
CRU, Onsite Repair
Refer to Tape Media, page 8
1 year
Onsite Repair (9x5)
* 7212-102 and 7214-1U2 also offer DVD-ROM and DVD-RAM optical drives
For most current information, visit: ibm.com/servers/storage/tape/compatibility/index.html
F/W = Fast/Wide, Diff = Differential, N/A = Not Applicable, FC = Fibre Channel, X = Extended length cartridge, IOE = IBM Onsite Exchange, CRU = Customer Replaceable Unit
NOTES 1: Compressed data rates are estimates and are data-, application- and processor-dependent. User results may vary. 3: Server platforms with SAN-ready attachability, model- and feature-dependent. 6: The following vendors provide application support to the platforms defined above:
A = IBM Tivoli Storage Manager, B = Symantec VERITAS NetBackup, C = Symantec VERITAS Backup Exec, D = EMC Legato NetWorker, E = CA BrightStor ARCserve Backup, F = HP OpenView Storage Data Protector, G = CommVault Galaxy, H = BakBone NetVault, I = LSC, J = IBM BRMS, K = IBM OnDemand,
L = Help/Systems Robot/Save, M = LXI Media Management, N = Dantz.
6
Tape Storage Systems (continued)
Selecting a Solution
Entry tape
products
Midrange tape
products
Enterprise tape
products
Tape
Virtualization
Other backup
products
IBM Systems
Solution
Native Performance
Capacity*
3580 tape drive
120 MBps
1600 GB
TS3100 tape library
120 MBps
Up to 38.4 TB
TS3100 tape library with
HH drives
240 MBps
Up to 38.4 TB
TS3200 tape library
240 MBps
Up to 76.8 TB
TS3200 tape library with
HH drives
480 MBps
Up to 76.8 TB
TS1040 tape drive
120 MBps
1600 GB
TS3310 tape library
Up to 2.16 GBps
Up to 633.6 TB
TS3500 tape library
Up to 23 GBps
Up to 11 PB
TS1120 tape drive
Up to 104 MBps
2100 GB
TS1120 tape controller
Up to 230 MBps
NA
TS3400 tape library
Up to 208 MBps
Up to 37.8 TB
TS3500 tape library
Up to 19.97 GBps
Up to 13.1 PB
TS7520**
Up to 4.8 GBps
Up to 2.6 PB
TS7740
Up to 600 MBps
Up to 54 TB
3996
Up to 12 MBps
10.4 TB
7206-336
Up to 3 MBps
72 GB
7206-VX2
Up to 6 MBps
60 GB
7206-VX3
Up to 24 MBps
160 GB
7207-330
Up to 4 MBps
60 GB
7212-103
Up to 12 MBps
320 GB
*
Compressed; see ibm.com/storage for specific capacities.
**
Available on System i through AIX/Linux partitioning.
***
See ibm.com/storage for specific open systems connectivity.
System z
System p
System i**
System x
Open
Systems***
Demand for lightning-fast communication and transactions has driven the need for a highperformance, responsive infrastructure that embraces open standards—exactly what you will
find in the IBM Systems product portfolio. Investments in servers often result in demands on
disk and tape storage systems. IBM has a family of storage offerings that complements the
IBM Systems product portfolio. There is no better storage offering for IBM Systems than an
IBM System Storage product. These offerings are tested and supported by IBM and are backed
by outstanding IBM service and support.
IBM System Storage Proven Program Helps Simplify
Interoperability
Overview
The IBM System Storage Proven™ program has been designed on a simple premise: give
customers the ability to select the best combination of interoperable storage technologies to
help minimize their investment risk, increase business efficiency and expedite their infrastructure implementation.
The IBM System Storage Proven program is all about leveraging IBM storage with business
applications, ISV and Business Partner software, and market-leading hardware components
which together deliver solutions that address today’s client needs.
Customer Benefits
● Prequalified configurations
● Customers will be better able to identify a variety of prequalified, interoperable storage
elements. By taking prequalified applications and hardware and combining them with
IBM storage technology clients can more easily identify solutions that address their storage
needs.
IBM Business Partner Benefits
● Potential for reduced sales cycle and integration issues
● For IBM Business Partners, the IBM System Storage Proven program is intended to help
shorten the sales cycle and ease integration issues, allowing more time for higher margin
customization. Another added value for IBM Business Partners is the interoperability qualification program where companies work together with IBM, which can help support their
ability to develop and deliver products or solutions that interoperate with the broad portfolio
of IBM System Storage products.
Please visit the System Storage Proven Web site at ibm.com/storage/proven to view
more than 500 available products and solutions from over 300 participating companies to
meet your storage needs.
IBM Business Partner Innovation Centers (BPIC)
Yes
No
Partial
7
More than 140 worldwide IBM TotalStorage Solution Centers can deliver one-stop shopping for
storage hardware, software and consulting services. The Solution Centers offer you both a local
venue for hands-on testing of IBM storage solutions and a platform for proof-of-concept and
benchmarking activities. These centers also work with the leading storage software providers
to support a wide variety of choices for interoperability. IBM Business Partners will help you
select and implement a solution to help your business succeed in today’s dynamic marketplace. Visit: ibm.com/storage/tssc
Media Guide
Capacity
Length
Media tape
Enterprise tape
Highlights
Technology
●
3592 Tape Cartridge
●
●
●
.31" MP tape
●
●
●
●
LTO® tape
●
●
●
●
●
Optical
cartridge
●
DLTtape
●
●
●
VXA-2/3
●
●
●
●
4 mm Tape
●
●
●
8 mm Tape
●
Custom labeling and initialization services are available
Server tracks help improve data integrity
Cartridge intermix within libraries supports smooth migration, legacy systems
Write Once Read Many (WORM) functionality
Unique midpoint load mechanism enables the system to locate data fast
Durable cartridge case helps protect the tape
Self-contained tape path helps improve reliability and extend tape life
Almost instantaneous head/tape contact at load time speeds processing
Media uses industry-leading, interchangeable LTO format
Cartridge is highest-capacity open standard tape cartridge available
Custom labeling is available
IBM-exclusive Statistical Analysis and Reporting System (SARS) statistics are stored in
cartridge memory
High durability helps support automation environments
Suitable for storing data that can be overwritten and has a finite life span
WORM media helps safeguard against data being erased or changed
Cartridge labelling area and labels are included
VS1 Data Cartridge
Durable coating can resist oxidation and moisture
Advanced archival and capacity properties are included
Wide selection of compatible cartridge capacities support daily or full backups
Media enclosure shutter locks out dirt and debris
Precision-matched tape reels and reel heights help support reliable operation
Proprietary hub lock helps reduce positioning errors to improve data integrity
Improved media coating helps reduce head friction and provide cleaner operation
Special media formulation can help reduce drop-out to improve reliability
Rigid magnetic stability specification helps increase coercivity to prolong shelf life and
improve read reliability
● 100 percent media enclosure can help lock out dirt and debris to protect the cartridge
● Built-in electrostatic discharge shield helps reduce risks to data and hardware
● Sophisticated mirror optics support BOT and EOT recognition
● Advanced media-binder process provides ultra-clean operation
● Stringent wheel-pin perpendicularity specification enables smoother operation and
fewer re-reads
● Proprietary belt design provides steady tension
● Special stippled base-plate design helps provide rigidity and a stable tape path
● Cartridge cover shields against static discharge and airborne debris
● Durastat on drive rollers dissipates static
1-888-IBM-MEDIA ibm.com/storage/media
(m/feet)
825/2706
825/2706
610/2001
610/2001
246/810
246/810
Part
number
23R9830
23R9831
18P7534
18P7538
24R0316
24R0317
3592 Cleaning Cartridge
18P7535
30/60/90 GB
05H4434
05H3302-J-less
3590 Cleaning Cartridge
05H4435
60/120/
180 GB
05H3188
08L6091-K-less
Cleaning Cartridge
05H2463
Ultrium Cleaning Cartridge (all)
Leader Pin Attachment Kit
5-pack LTO Ultrium 4 tapes
5-pack LTO Ultrium 3 tapes
35L2086
23R7008
08L9129
95P4278
95P2020
Cleaning Cartridge - VS160
18P8924
3590 Tape Cartridge
320/1050
3590E Tape Cartridge
634/2070
20/40/60 GB
IBM Magstar® MP Fast Access
Linear Tape Cartridge
Magstar MP Fast Access Linear Tape
Cartridge—XL
Ultrium 4
Ultrium 4 WORM
Ultrium 3
Ultrium 3 WORM
Ultrium 2
Ultrium 1
3996 Ultra Density Optical (UDO)
167/54
5 GB
15 GB
227/745
7 GB
21 GB
820/2690
820/2690
680/2231
680/2231
609/1998
609/1998
NA
Part
number
160 GB
05H2462—B
08L6187—C
08L6663C-XL
95P4436
95P4450
24R1922
96P1203
08L9870
08L9120
23R2568
23R2567
59H5629
59H5628
18P8923
40 GB
80 GB
160 GB
80 GB
160 GB
320 GB
24R2134
24R2136
24R2137
Cleaning Cartridge—X-MEDIA
24R2138
125/410
150/492
170/557
22/73
170/557
12 GB
20 GB
36 GB
2.5 GB
20 GB
24 GB
40 GB
72 GB
5 GB
40 GB
59H3465
59H4456
18P7912
59H2671
59H2678
Cleaning Cartridge—4 mm
21F8763
Cleaning Cartridge—AME
35L1409
5.25" SLR5/QIC-4GB-DC
5.25" MLR1/QIC-5010-DC
5.25" MLR3/QIC-5120-DC
5.25" SLR60
5.25" SLR60
5.25" SLR100
458/1500
458/1500
462/1515
274/900
366/1200
47/156
4 GB
16 GB
25 GB
30 GB
37.5 GB
5 GB
8 GB
32 GB
50 GB
60 GB
75 GB
10 GB
59H3660
59H4175
59H4128
19P4209
24R0146
35L0661
QIC 5.25" MLR/SLR Cleaning
Cartridge (50 uses)
35L0844
5.25" SLR100
457/1500
50 GB
100 GB
35L0968
VS1
563/1850
800 GB
800 GB
400 GB
400 GB
200 GB
100 GB
30 GB
30 GB WORM
60 GB
60 GB WORM
80 GB
VXA 8 mm—X6
VXA 8 mm—X10
VXA 8 mm—X23
62/203
124/406
230/754
DDS-3
DDS-4
DAT72
AME
●
SLR (QIC)
cartridges
Related products
Compressed
(typical)
2.1 TB
2.1 TB
900 GB/1.5 TB
900 GB/1.5 TB
180/300 GB
180/300 GB
native
700 GB
700 GB WORM
300/500 GB
300/500 GB
WORM
60/100 GB
60/100 GB
WORM
10/20/30 GB
8
1600 GB
1600 GB
800 GB
800 GB
400 GB
200 GB
Disk Storage Systems
Entry-level Disk Systems
System x and IBM BladeCenter® Direct Attach or SAN Solutions
System p Only Direct Attach Solutions
EXP3000
DS3200
DS3300
DS3400
EXP24
Product
Machine/model
EXP3000
1727-01X, 1727-02T Telco DC Power Model
Windows 2003, RedHat 3, RedHat 4, SUSE 9
DS3300
1726-31X, 1726-32X
1726-31E Express
1726-32E Express, 1726-32T Telco DC Power
Model
Windows 2003, RedHat 4, RedHat 5, SUSE 9,
SUSE 10
DS3400
1726-41X, 1726-42X
1726-41E Express
1726-42E Express, 1726-42T Telco DC Power
Model
Windows 2003, RedHat 4, RedHat 5, SUSE 9,
SUSE 10, NetWare, VMware 2.5.4, VMware 3.0.1,
VMware 3.0.2, VMware 3.5/3i, AIX 5.2, AIX 5.3
EXP24
7031-D24—Rack version
7021-T24—Tower version
Platform
support1
DS3200
1726-21X, 1726-22X
1726-21E Express
1726-22E Express, 1726-22T Telco DC Power
Model
Windows 2003, RedHat 4, RedHat 5, SUSE 9,
SUSE 10, NetWare, VMware 3.5/3i
Host
connectivity
SAN support
Copy services
Availability
features
SAS
SAS
iSCSI
4 Gbps Fibre Channel
N/A
N/A
Fault-tolerant RAID, Redundant Hot-swap power,
Hot-swap drives, Dual pathing drives
MegaRAID 8480
256 MB battery backup
Switched, IP SAN
IBM FlashCopy, IBM VolumeCopy
Fault-tolerant, RAID, Redundant Hot-swap power,
Hot-swap drives, Dual controller, dual pathing
drivers
Dual active 1 Gbps iSCSI RAID Controllers
512 MB, 2 GB battery backup
Direct, Switched Fabric
IBM FlashCopy, IBM VolumeCopy
Fault-tolerant, RAID, Redundant Hot-swap power,
Hot-swap drives, Dual controller, dual pathing
drivers
Dual Active 4 GB FC RAID Controllers
512 MB, 2 GB battery backup
N/A
N/A
Fault-tolerant RAID, Redundant Hot-swap power,
Hot-swap drives
Controller
Cache
(min, max)
RAID support
Capacity
(min, max)
Drive interface
N/A
IBM FlashCopy®, IBM VolumeCopy
Fault-tolerant, RAID, Redundant Hot-swap power,
Hot-swap drives, Dual controller, dual pathing
drivers
Dual active 3 Gbps SAS RAID Controllers
512 MB, 2 GB battery backup
0, 1, 5, 10, 50
146 GB, 12 TB in a single EXP3000 Expansion Units
0, 1, 3, 5, 10
146 GB, 48 TB with 3 EXP3000 Expansion Units
0, 1, 3, 5, 10
146 GB, 48 TB with 3 EXP3000 Expansion Units
0, 1, 3, 5, 10
146 GB, 48 TB with 3 EXP3000 Expansion Units
0, 1, 3, 5, 10
73 GB, 7.2 TB
3 Gbps SAS,
3 Gbps SATA II
SAS: 73 GB, 146 GB, 300 GB 15,000 rpm disk
drives; 500 GB, 750 GB, 1 TB SATA II 7,200 rpm
3 Gbps SAS
3 Gbps SATA II
SAS: 73 GB, 146 GB, 300 GB 15,000 rpm disk
drives,
SATA: 500 GB, 750 GB, 1 TB SATA II 7,200 rpm
Microsoft Windows MSCS
3 Gbps SAS
3 Gbps SATA II
SAS: 73 GB, 146 GB, 300 GB 15,000 rpm disk
drives,
SATA: 500 GB, 750 GB, 1 TB 7,200 rpm
Microsoft Windows MSCS
3 Gbps SAS
3 Gbps SATA II
SAS: 73 GB, 146 GB, 300 GB 15,000 rpm disk
drives,
SATA: 500 GB, 750 GB, 1 TB 7,200 rpm
Microsoft Windows MSCS
Ultra320 SCSI
Drive support
Clustering
Support
N/A
9
AIX 5L 5.2
AIX 5L 5.3
RedHat 3
RedHat 4
RedHat 5
SUSE 9
SUSE 10
SCSI
System p FC 5741 & 5742 SCSI Repeaters
N/A
73 GB, 146 GB, 300 GB 10,000 rpm disk drives;
36 GB, 73 GB, 146 GB, 300 GB 15,000 rpm disk
drives
HACMP™
Disk Storage Systems (continued)
Midrange Disk Systems
DS4200 Express
DS4700 Express
DS4800
DS4200 Express Disk System
1814-7VA/7VH
Microsoft Windows Server® 2003 w/SP1, R2, and x64, Windows 2000
Server & Advanced Server w/SP4, Novell NetWare 6.5 w/SP5
Red Hat Enterprise Linux 3.8
Red Hat Enterprise Linux 4.4
SUSE Linux Enterprise Server 8 SP4
SUSE Linux Enterprise Server 9 SP3
VMware ESX 3.0/3.5/3i
AIX 5.1, 5.2, 5.3, 6.1
HP-UX 11.0, 11i and 11.23 with PVLinks
Solaris 8, 9, 10
Fibre Channel
DS4700 Express Disk System
1814-72A/70A
System p, System x, System i w/ VIOS, Windows Server 2003 w/SP1,
Windows 2000 Server & Advanced Server w/SP4, Novell NetWare 6.0
w/SP5 & 6.5 w/SP5, Red Hat Enterprise Linux 3.0 U7, Red Hat Enterprise
Linux 4.0 U3
SUSE Linux Enterprise Server 8 SP4, SUSE Linux Enterprise Server 9
SP3, VMware ESX 3.0/3.5/3i, VMware ESX 2.5.2
AIX 5.1, 5.2, 5.3, 6.1 HP-UX 11i and 11.23, Solaris 8, 9, 10
DS4800 Disk System
1815-80A/82A/84A/88A
System p, System x, System i w/VIOS, Windows Server 2003 w/SP1,
Windows 2000 Server & Advanced Server w/SP4, Novell NetWare 6.0
w/SP5 & 6.5 w/SP5, Red Hat Enterprise Linux 3.0 U7, Red Hat Enterprise
Linux 4.0 U3
SUSE Linux Enterprise Server 8 SP4, SUSE Linux Enterprise
Server 9 SP3, AIX 5.1, 5.2, 5.3, 6.1, VMware ESX 3.0/3.5/3i
HP-UX 11i and 11.23, Solaris 8, 9, 10
Fibre Channel
Fibre Channel
Direct, FC-AL, Switched Fabric
Enhanced Remote Mirroring, FlashCopy, VolumeCopy
Fault-tolerant RAID, redundant power/cooling, hot-swap drives, dual controllers, concurrent microcode update capability, dual-pathing driver
Dual 4 GB RAID controller
2 GB
Direct, FC-AL, Switched Fabric
Enhanced Remote Mirroring, FlashCopy, VolumeCopy
Fault-tolerant RAID, redundant power/cooling, hot-swap drives, dual controllers, concurrent microcode update capability, dual-pathing driver
Dual active 4 Gbps RAID controllers
2 GB, 4 GB (70A/72A)
RAID support
Capacity
(min, max)
Drive interface
Drive support
0, 1, 3, 5, 6, 10
500 GB, supports 84 TB with six Expansion Units
Certifications
Microsoft Clustering Services, IBM SAN Volume Controller 3.1.0 and
4.1.0
0, 1, 3, 5, 6, 10
36.4 GB, 33.6 TB via EXP810, EXP710 (FC), 84 TB via EXP810 (SATA),
44.8 TB via EXP100
4 Gbps Switched
2 Gbps 73.4 GB, 146.8 GB and 300 GB 10,000 rpm; (FC) 36.4 GB,
73.4 GB, 146.8 GB 15,000 rpm; 4 Gbps 36.4 GB, 73.4 GB, 146.8 and
300 GB 15,000 rpm (FC) (Serial ATA) 250 GB, 400 GB, 500 GB and
750 GG, 1 TB 7,200 rpm (SATA)
Microsoft RAID, Cluster, NetWare Cluster, HACMP,
VERITAS Clustering4
Direct, FC-AL, Switched Fabric
Enhanced Remote Mirroring, FlashCopy, VolumeCopy
Fault-tolerant RAID, redundant power/cooling, hot-swap drives, dual controllers, concurrent microcode update capability, dual-pathing driver
Dual active 4 Gbps RAID controllers
4 GB, 4 GB (80A/82A)
8 GB, 8 GB (84A)
16 GB, 16 GB (88A)
0, 1, 3, 5, 10
36.4 GB, 67.2 TB via EXP810/EXP700/EXP710 (FC) 400 GB, 89.6 TB via
EXP100 (Sl ATA), 168 TB via EXP810 (SATA)
4 Gbps Switched
2 Gbps 73.4 GB, 146.8 GB and 300 GB 10,000 rpm; (FC) 36.4 GB,
73.4 GB, 146.8 GB 15,000 rpm; 4 Gbps 36.4 GB, 73.4 GB, 146.8 and
300 GB 15,000 rpm (FC) (Serial ATA) 250 GB, 400 GB, 500 GB and
750 GG, 1 TB 7,200 rpm (SATA)
Microsoft RAID, Cluster, NetWare Cluster, HACMP,
VERITAS Clustering4
Product
Machine/model
Platform
support1
Host
connectivity
SAN support
Copy services
Availability
features
Controller
Cache
(min, max)
4 GB FC-AL
500 GB EV-DDM, 750 GB EV-DDM, 1 TB EV-DDM 7,200 rpm SATA
disk drives
10
Disk Storage Systems (continued)
Enterprise Disk Systems
Product
Machine/model
Platform
support1
Host
connectivity
SAN support
Copy services
Availability
features
Controller
Cache
(min, max)
RAID support
Capacity
(min, max)
Drive interface
Drive support
Certifications
DS6800
DS8100
DS8300
ESS 800
IBM System Storage DS6800
1750/522
System x, System i, System p, System z,
IBM i5/OS®, OS/400, AIX, Solaris, HP-UX,
Windows 2000, Windows Server 2003, Linux for
IBM System z, z/OS, IBM z/VM®, IBM VSE/ESA™,
TPF, Linux for System i, Linux for System p, Linux for
Intel systems, OpenVMS, TRU64, NetWare, VMware,
Apple Macintosh OS X, Fujitsu PRIMEPOWER,
SGI IRIX
1 Gbps and 2 Gbps Fibre Channel/FICON
IBM System Storage DS8000™ Turbo
2421, 2422, 2423, 2424/931
System x, System i, System p, System z, i5/OS,
OS/400, AIX, Solaris, HP-UX, Windows 2000,
Windows Server 2003, Linux for System z, z/OS,
z/VM, VSE/ESA, TPF, Linux for System i, Linux for
System p, Linux for Intel systems, OpenVMS, TRU64,
NetWare, VMware, Apple Macintosh OS X, Fujitsu
PRIMEPOWER, SGI IRIX
IBM System Storage DS8000 Turbo
2421, 2422, 2423, 2424/932/9B2
System x, System i, System p, System z, i5/OS,
OS/400, AIX, Solaris, HP-UX, Windows 2000,
Windows Server 2003, Linux for System z, z/OS,
z/VM, VSE/ESA, TPF, Linux for System i, Linux for
System p, Linux for Intel systems, OpenVMS, TRU64,
NetWare, VMware, Apple Macintosh OS X, Fujitsu
PRIMEPOWER, SGI IRIX
ESS Model 800 Refurbished with Warranty
2105/800
System x, System i, System p, System z, i5/OS,
OS/400, AIX, Solaris, HP-UX, Microsoft Windows
NT®, Windows 2000, Windows Server 2003,
NetWare, Linux for System z, z/OS, z/VM, OS/390®,
VM/ESA®, VSE/ESA, TPF, Linux for Intel systems,
Dynix, OpenVMS, Tru64, VMware, Fujitsu PRIMEPOWER, SGI Origin IRIX
2 Gbps and 4 Gbps Fibre Channel, FICON, ESCON®
2 Gbps and 4 Gbps Fibre Channel, FICON, ESCON
Direct, FC-AL, Switched Fabric
FlashCopy, Metro Mirror, Global Mirror, Global Copy,
as target for z/OS Global Mirror
Fault tolerant, dual redundant and hot-swap RAID
controller cards, Battery Backup Units, Fibre Channel
switch controllers, power supplies, non-disruptive
hardware and software code load updates, multipathing device driver
Dual active/active
4 GB
Direct, FC-AL, Switched Fabric
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror,
Global Copy, z/OS Global Mirror, Metro/Global Mirror
Fault tolerant, dual redundant and hot-swap RAID
controller cards, Battery Backup Units, Fibre Channel
switch controllers, power supplies, non-disruptive
hardware and software code load updates, multipathing device driver
Dual active/active
16/128 GB
Direct, FC-AL, Switched Fabric
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror,
Global Copy, z/OS Global Mirror, Metro/Global Mirror
Fault tolerant, dual redundant and hot-swap RAID
controller cards, Battery Backup Units, Fibre Channel
switch controllers, power supplies, non-disruptive
hardware and software code load updates, multipathing device driver
Dual active/active
32/256 GB
1 Gbps and 2 Gbps Fibre Channel/FICON, ESCON,
SCSI
Direct, FC-AL, Switched Fabric
FlashCopy, Metro Mirror, Global Mirror, Global Copy,
z/OS Global Mirror, Metro/Global Mirror(RPQ)
Fault-tolerant, RAID, redundant power/cooling, hotswap drives, dual controllers, concurrent microcode
update capability, dual pathing driver
5, 10
292 GB, 64 TB
5, 10
1.1 TB, 192 TB
5, 10
1.1 TB, 512 TB
5, 10
582 GB, 55.9 TB
2 Gbps Fibre Channel
73 GB 15K, 146 GB 15K, 300 GB 15K,
500 GB FATA, 7.2K
Oracle OSCP Validation of Compatibility, HACMP,
Solaris Ready, VERITAS Cluster
2 Gbps Fibre Channel
73 GB 15K, 146 GB 15K, 300 GB 15K, 500 GB
7.2 FATA
Oracle OSCP Validation of Compatibility, HACMP,
GDPS, Solaris Ready, VERITAS Cluster
2 Gbps Fibre Channel
73 GB 15K, 146 GB 15K, 300 GB 15K, 500 GB
7.5K FATA
Oracle OSCP Validation of Compatibility, HACMP,
GDPS, Solaris Ready, VERITAS Cluster
SSA
36.4 GB, 72.8 GB and 145.6 GB 10,000 rpm disk
drives 36.4 GB and 72.8 GB 15,000 rpm disk drives
Microsoft RAID, Cluster and Data Center, GDPS,
HACMP, Solaris Ready
SMB dual active; optional turbo feature
8 GB, 64 GB
1: Consult product information for details. 2: RedHat, SUSE Linux and TurboLinux. Please verify specific product information for details. 3: Via IBM TotalStorage SAN Controller 160; no cluster or HACMP support. 4: Also, verification will be completed for HP Service Guard.
5: Metro Mirror is synchronous replication; Global Mirror is asynchronous replication; Metro/Global Mirror is three-site cascading asynchronous replication; Global Copy is extended distance copying.
11
Disk Storage Systems (continued)
Selecting a solution
DS4700
Express
DS4800
DS6800
DS8100
Turbo
DS8300
Turbo
Product
DS8300 Turbo
Highlights
●
●
ESS
●
Local copy within controller
●
●
Remote Copy (>10 km)
DS8100 Turbo
Centralized management
●
●
Storage area network
●
●
Concurrent heterogeneous
servers (UNIX and Intel)
Concurrent microcode
install
DS6800
●
●
●
Intermix disk capacities
●
Multiple RAID options
Through DS
Storage Manager
Server
Controller-based call-home
Through DS
Storage Manager
Server
Enterprise
Storage Server®
Model 800
Refurbished with
Warranty
Through DS
Storage Manager
Server
Rack mount
●
●
●
●
●
Virtualization
DS4800
Virtualization through SAN
Volume Controller
●
●
●
* Remote Copy (>10 km) is via System Storage Proven vendors (CNT, Legato, NSI)
Yes
●
No
DS4700 Express
●
●
●
Selecting a solution (continued)
EXP3000
DS3200
DS3300
DS3400
DS4200
Express
●
EXP24
DS4200 Express
Local copy within controller
●
●
Remote Copy (>10 km)
●
Centralized management
DS3400
Storage area network
Concurrent heterogeneous
servers (UNIX and Intel)
Concurrent microcode
install
●
●
●
●
Intel/AMD only
Intel/AMD only
Intel/AMD only
Intel/AMD/AIX
DS3300
●
●
●
●
Intermix disk capacities
DS3200
Multiple RAID options
●
●
●
Controller-based call-home
EXP3000
●
●
Virtualization
EXP24
Virtualization through SAN
Volume Controller
* Remote Copy (>10 km) is via System Storage Proven vendors (Legato, CNT, NSI)
●
●
Rack mount
●
●
Yes
No
Outstanding enterprise class functionality with extraordinary performance and scalability up to 512 TB of physical capacity
Host connectivity via 4 Gbps FC/FICON or ESCON interfaces to a wide variety of UNIX, Windows, Linux, System i systems,
System p servers, System x servers and System z mainframes
Top notch storage consolidation system with Storage System LPAR capability
Offers FlashCopy, FlashCopy SE, Global and Metro Mirroring functions (2 site and 3 site)
Call home and remote support as well as an Enterprise Choice 1-year, 2-year, 3-year or 4-year warranty
Outstanding enterprise class functionality and performance with scalability up to 192 TB of physical capacity
Host connectivity via 4 Gbps FC/FICON or ESCON interfaces to wide variety of UNIX, Windows, Linux, System p servers,
System x servers, System i systems and System z mainframes
Offers FlashCopy, FlashCopy SE, Global and Metro Mirroring functions (2 site and 3 site)
Call home and remote support as well as an Enterprise Choice 1-year, 2-year, 3-year or 4-year warranty
Provides enterprise-class disk offering in a modular package at an affordable price
Designed to provide host connectivity via FC/FICON to a wide variety of UNIX, Windows, Linux, System p servers, System x
servers, System i systems and System z mainframes
Features FlashCopy as well as Global and Metro Mirroring functions
Enterprise-class warranty, 24x7, same day IBM onsite response
Affordable enterprise strength reliability and function for modular and mainframe servers
Great second-tier storage option for backup, remote mirroring, test or archive needs
Host connectivity via SCSI, FC/FICON, or ESCON interfaces to a wide variety of UNIX, Windows, System i systems and
System z mainframes
Features copy services for rapid backup and disaster recovery
Full 3 year warranty on Refurbished with Warranty systems available worldwide
Provides SAN-ready flexible disk storage system for UNIX and Intel processor-based environments
Offers high-performance, full fibre solution with 4 Gbps Fibre Channel connectivity
Supports business continuance with its optional high-availability software and advanced Enhanced Remote Mirroring
function
Helps protect customer data with its multi-RAID capability and hot-swappable redundant components
Provides SAN-ready flexible disk storage system for UNIX and Intel processor-based environments
Offers high-performance, full fibre solution with 4 Gbps Fibre Channel connectivity
Supports business continuance with its optional high-availability software and advanced Enhanced Remote Mirroring
function
Helps protect customer data with its multi-RAID capability and hot-swappable redundant components
An SATA-only solution designed to provide an economical alternative storage solution that supports data archiving,
reference data and near-line storage applications
Offers high-performance, full fibre solution with 4 Gbps Fibre Channel connectivity
Supports business continuance with its optional high-availability software and advanced Enhanced Remote-Mirroring
function
Helps protect customer data with its multi-RAID capability and hot-swappable redundant components
Scalable to 12 terabytes (TB) of storage capacity with 1 TB hot-swappable Serial ATA (SATA) disks
Expandable by attaching up to three EXP3000s, a total of 48 TB of storage capacity
Flexible for use with IBM System x and BladeCenter servers
1 Gbps iSCSI interface technology
Easy to deploy and manage with the DS3000 Storage Manager
Scalable to 12 TB of storage capacity with 1 TB hot-swappable Serial ATA(SATA) disks
Expandable by attaching up to three EXP3000s, a total of 48 TB of storage capacity
3 Gbps Serial Attached SCSI (SAS) interface technology
Easy to deploy and manage with the DS3000 Storage Manager
Scalable to 12 TB of storage capacity with 1 TB hot-swappable Serial ATA (SATA) disks
3 Gbps SAS interface technology
Support for up to 12 TB of storage in a single enclosure
Support for up to 48 TB in a cascaded configuration with MegaRAID 8480 adapter
Powerful and comprehensive management and configuration tools included
Supports up to 7.2 TB of data
Supports up to 24 U320 SCSI drives in four groups of six drives or two groups of 12 drives
Additional information on these IBM Disk Storage products is available on the Web at ibm.com/storage/disk
12
Disk Storage Systems (continued)
Operating Systems and Copy Services Platform Coverage
DS4800
DS6800
DS8100 Turbo
ESS 800
RwW
DS8300 Turbo
Windows NT
FlashCopy, VolumeCopy, Metro Mirror, Global Copy and
Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
Windows 2000
FlashCopy, VolumeCopy, Metro Mirror, Global Copy and
Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
Windows Server 2003
FlashCopy, VolumeCopy, Metro Mirror, Global Copy and
Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
NetWare
FlashCopy, VolumeCopy, Metro Mirror, Global Copy and
Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
Linux1
FlashCopy, VolumeCopy, Metro Mirror, Global Copy and
Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
AIX
FlashCopy, VolumeCopy, Metro Mirror, Global Copy and
Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
VMware
FlashCopy, VolumeCopy, Metro Mirror, Global Copy and
Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
Dynix
HP-UX
FlashCopy, VolumeCopy, Metro Mirror, Global Copy and
Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
Solaris
FlashCopy, VolumeCopy, Metro Mirror, Global Copy and
Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
IRIX
*
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
Tru64 UNIX
*
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
OpenVMS
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
z/OS, OS/390, TPF
FlashCopy, Metro Mirror, Global Mirror, Global Copy,
as target for z/OS Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, z/OS Global Mirror, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, z/OS Global Mirror, Metro/Global Mirror
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ), z/OS Global Mirror (XRC)
i5/OS
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Copy
FlashCopy, Metro Mirror, Global Mirror, Global Copy, Metro/
Global Mirror (RPQ)
Apple Macintosh OSX
FlashCopy, Metro Mirror, Global Mirror, Global Copy
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
FlashCopy, FlashCopy SE, Metro Mirror, Global Mirror, Global
Copy, Metro/Global Mirror
*
Request via RPQ process
1:
Linux distribution support varies per product. Refer to product-specific information for current support. This chart reflects IBM’s current intentions. Changes may
occur without notice. Consult the appropriate Web pages for support details.
13
Yes
No
Disk Storage Systems (continued)
Operating Systems and Copy Services Platform Coverage (continued)
EXP3000/MegaRAID
DS3200/DS3300/DS3400
DS4200 Express
DS4700 Express
Windows NT
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
Windows 2000
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
Windows Server 2003
FlashCopy, VolumeCopy
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
NetWare
FlashCopy, VolumeCopy
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
Linux1
FlashCopy, VolumeCopy
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
AIX
FlashCopy, VolumeCopy
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
HP-UX
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
Solaris
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
FlashCopy, VolumeCopy, Metro Mirror,
Global Copy and Global Mirror
IRIX
*
*
Tru64 UNIX
*
*
VMware
Dynix
OpenVMS
z/OS, OS/390
i5/OS
DG/UX
*
Request via RPQ process
1:
Linux distribution support varies per product. Refer to product-specific information for current support. This chart reflects IBM’s current intentions. Changes may
occur without notice. Consult the appropriate Web pages for support details.
2:
Metro Mirror is synchronous replication; Global Mirror is asynchronous replication; Metro/Global Mirror is two- or three-site cascading asynchronous replication;
Global Copy is extended distance copying.
3:
VolumeCopy, Metro Mirror, Global Copy and Global Mirror require turbo option.
14
Yes
No
Disk Storage Systems (continued)
IBM System Storage N series—Unified Storage Systems
N3000 Express series
Model
Maximum raw capacity
Integrated Onboard I/O
ports*
PCI expansion slots for
additional FC HBAs or GbE
NIC cards*
Performance*
NVRAM*
Random Access Memory*
N5000 series
N7000 series
N3700
N3300 Express
N3600 Express
N5200
N5300
N5600
N7700
N7900
2863-A10 (single)
2863-A20 (clustered)
16 TB
Two optical FC ports for
tape attachment
Four 1 Gbps Ethernet
NA
2859-A10 (single)
2859-A20 (clustered)
68 TB
Up to four (4) 4 Gbps Fibre
Channel ports
Up to four (4) 1 GbE ports
0
2862-A10 (single)
2862-A20 (clustered)
104 TB
Up to four (4) 4 Gbps Fibre
Channel ports
Up to four (4) 1 GbE ports
2
2864-A10 (single)
2864-A20 (clustered)
84 TB
Eight 2 Gbps FC
Eight 1 Gbps Ethernet
2869-A10 (single)
2869-A20 (clustered)
336 TB
Eight 4 Gbps FC
Eight 1 Gbps Ethernet
2868-A10 (single)
2868-A20 (clustered)
504 TB
Eight 4 Gbps FC
Eight 1 Gbps Ethernet
2866-A11 (single)
2866-A21 (clustered)
840 TB
Sixteen 4 Gbps FC
Twelve 1 Gbps Ethernet
2867-A11(single)
2867-A21 (clustered)
1176 TB
Sixteen 4 Gbps FC
Twelve 1 Gbps Ethernet
6
6
6
16
16
13,620 IO/sec
256 MB
2 GB
146 MB/sec
256 MB
2 GB
181 MB/sec
512 MB
4 GB
34,089 IO/sec
1 GB
4 GB
58,906 IO/sec
1 GB
8 GB
85,615 IO/sec
1 GB
16 GB
100,295 IO/sec
1 GB
32 GB
136,048 IO/sec
1 GB
64 GB
All N series systems provide the following features:
Storage controllers/filers
Fibre channel (FC) disk
drive support
SATA disk drive support
SAS disk drive support
(N3300 and N3600)
Host connectivity &
platform support
Network protocol support
Other protocol support
Operating system
Data protection
Redundancy/
high availability
Backup
RAID levels
System management/
Storage management
Standard software
features
Optional software
features
Active/Active with automatic failover to secondary system
2 Gbps FC: 144 GB 10K, 300 GB 10K, 144 GB 15K
4 Gbps FC: 144 GB 15K, 300 GB 15K
250 GB 7.2K, 320 GB 7.2K, 500 GB 7.2K, 1 TB, 7.2K
144 GB 15K, 300 GB 15K
The N series systems support a multitude of host attachment capabilities via FCP, CIFS, NFS and iSCSI protocols. See product “N series Interoperability Matrix” for more information
NFS V2/V3/V4 over UDP or TCP, PCNFSD V1/V2 for (PC) NFS client authentication, Microsoft CIFS, iSCSI, FCP, VLD, HTTP 1.0, HTTP 1.1 Virtual Host
SNMP, NDMP, LDAP, NIS, DNS
Data ONTAP®
Double Parity RAID, Snapshot™, SnapRestore®, SnapMirror®, SyncMirror®, SnapVault®, Open System Snap Vault, MetroCluster, Protection Manager™
CompactFlash dual redundant hot-plug integrated cooling fans, hot-swappable auto-ranging power supplies, clustered filers, hot-swappable disk bays
External tape (SCSI or Fibre Channel)
RAID 4, RAID-DP™ (double parity)
FilerView®, SecureAdmin™, SNMP, Operations Manager, Protection Manager, Industry-standard NDMP protocols
Snapshot™, FlexVol®, FlexShare™, Integrated Automatic RAID Manager, Fast Boot, NIS, DNS, SNMP, FilerView, NDMP, LDAP, iSCSI, AutoSupport, SyncMirror, SnapMover®, FTP protocol feature, SecureAdmin, Disk Sanitization
CIFS protocol, Clustered Failover, Data ONTAP, Disk Sanitization. FCP protocol, FlexCache, FlexClone®, FlexShare, FlexScale, FlexVol, FTP protocol, HTTP protocol, iSCSI protocol, LockVault™ Enterprise, MetroCluster, MultiStore®, NDMP protocol, NearStore® (near-line),
NFS protocol, Open Systems SnapVault (OSSV), Operations Manager Core & SRM License, Protection Manager, Provisioning Manager, RAID 4, RAID-DP, SecureAdmin, Single Mailbox Recovery for Exchange (SMBR), SnapDrive®, SnapLock® Enterprise, SnapManager® for
Exchange, SnapManager for Oracle, SnapManager for SAP SnapManager for SQL Server®, SnapManager for Microsoft Office SharePoint® Server, SnapMirror, SnapMover, SnapRestore, Snapshot, SnapValidator™, SnapVault, SyncMirror, Virtual File Manager™ (VFM)
15
Disk Storage Systems (continued)/IBM System Storage N series
IBM System Storage N series—Unified Storage Systems
N series Highlights
●
●
N5000 Gateway series
Model
Maximum raw capacity
Onboard I/O ports*
PCI expansion slots for
additional FC HBAs or GbE
NIC cards*
Performance*
NVRAM*
Random Access Memory*
N7000 Gateway series
N5200
N5300
N5600
N7700
N7900
2864-G10 (single)
2864-G20 (clustered)
84 TB
Eight 2 Gbps FC
Eight 1 Gbps Ethernet
6
2869-G10 (single)
2869-G20 (clustered)
336 TB
Eight 4 Gbps FC
Eight 1 Gbps Ethernet
6
2868-G10 (single)
2868-G20 (clustered)
504 TB
Eight 4 Gbps FC
Eight 1 Gbps Ethernet
6
2866-G11 (single)
2866-G21 (clustered)
840 TB
Sixteen 4 Gbps FC
Twelve 1 Gbps Ethernet
16
2867-G11 (single)
2867-G21 (clustered)
1176 TB
Sixteen 4 Gbps FC
Twelve 1 Gbps Ethernet
16
34,089 IO/sec
1 GB
4 GB
58,906 IO/sec
1 GB
8 GB
85,615 IO/sec
1 GB
16 GB
100,295 IO/sec
1 GB
32 GB
136,048 IO/sec
1 GB
64 GB
●
●
●
●
●
●
All N series Gateway systems provide the following features:
Storage controllers/filers
Host connectivity &
platform support
Network protocol support
Other protocol support
Operating system
Data protection
Redundancy/
high availability
Backup
RAID levels
System management/
Storage management
Standard software
features
Optional software
features
●
Active/Active with automatic failover to secondary system
The N series systems support a multitude of host attachment capabilities via FCP, CIFS, NFS and iSCSI protocols. See product “N series Interoperability Matrix” for
more information
NFS V2/V3/V4 over UDP or TCP, PCNFSD V1/V2 for (PC) NFS client authentication, Microsoft CIFS, iSCSI, FCP, VLD, HTTP 1.0, HTTP 1.1 Virtual Host
SNMP, NDMP, LDAP, NIS, DNS
Data ONTAP
Snapshot, SnapRestore, SnapMirror, SyncMirror, SnapVault, Open System Snap Vault, MetroCluster, Protection Manager
CompactFlash dual redundant hot-plug integrated cooling fans, hot-swappable auto-ranging power supplies, clustered filers, hot-swappable disk bays
External tape (SCSI or Fibre Channel)
Provided by backend storage system
FilerView, SecureAdmin, SNMP, Operations Manager/Industry-standard NDMP protocols
●
●
●
●
●
●
Snapshot, FlexVol, FlexShare, Integrated Automatic RAID Manager, Fast Boot, NIS, DNS, SNMP, FilerView, NDMP, LDAP, iSCSI, AutoSupport, SyncMirror, SnapMover, FTP
protocol feature, SecureAdmin
CIFS protocol, Clustered Failover, Data ONTAP, Disk Sanitization. FCP protocol, FlexCache, FlexClone, FlexShare, FlexScale, FlexVol, FTP protocol, HTTP protocol, iSCSI
protocol, LockVault Enterprise, MetroCluster, MultiStore, NDMP protocol, NearStore (near-line), NFS protocol, Open Systems SnapVault (OSSV), Operations Manager
Core & SRM License, Protection Manager, Provisioning Manager, SecureAdmin, Single Mailbox Recovery for Exchange (SMBR), SnapDrive, SnapLock Enterprise,
SnapManager for Exchange, SnapManager for Oracle, SnapManager for SAP
SnapManager for SQL Server, SnapManager for Microsoft Office SharePoint Server, SnapMirror, SnapMover, SnapRestore, Snapshot, SnapValidator, SnapVault,
SyncMirror, Virtual File Manager (VFM)
●
●
●
Unified storage architecture—provides a single storage platform to support heterogeneous, multiprotocol storage requirements with the capability of simultaneously handling
both Block I/O (with FCP or iSCSI protocol) and File I/O (with CIFS, NFS, HTTP, FTP protocols)
application needs
Application-aware software—SnapManager software provides host-based data management of N series storage for databases and business applications. Simplifies applicationconsistent policy-based automation for data protection and disaster recover. Snapshot
copies and automates error-free data restores and enables application-aware disaster
recovery
Thin Provisioning—allows applications and users to get more space dynamically and nondisruptively without IT staff intervention
Ease of installation—offers installation tools designed to help simplify installation and
setup
Increased access—allows heterogeneous access to IP attached storage and Fibre Channel
attached storage subsystems
Operating system—optimized and finely tuned for storing and sharing data assets,
designing to enable greater efficiency within your organization and help lower total cost of
ownership through improved efficiency and productivity
Flexibility—enables cross-platform data access for Microsoft Windows, UNIX and Linux
environments that can help reduce network complexity and expense, and allow data to be
shared across the organization
Network Attached Storage (NAS)—supports Network File System (NFS), Common
Internet File System (CIFS) protocols for attachment to Microsoft Windows, UNIX and Linux
systems
IP SAN—supports Internet Small Computer System Interface (iSCSI) protocols for IP SAN
attached to a multitude of host servers including Microsoft Windows, Linux, and UNIX
systems
FC SAN—supports Fibre Channel protocols (FCP) for accommodating attachment and
participation in fibre channel SAN environments
Scalability—supports non-disruptive capacity increases as well as thin-provisioning
(dynamically allow the increase and decrease of user capacity assignments). Allows you to
scale your storage infrastructure to keep pace with company growth
Designed to maintain availability and productivity during upgrades
Manageability—includes integrated system diagnostics and management tools, which are
designed to help minimize downtime
Redundancy—several redundancy and hot-swappable features provide the highest system
availability characteristics
Copy Services—provides extensive outboard services that help recover data in disaster
recovery environments. SnapMirror provides one-to-one, one-to-many and many-to-one
mirroring over Fibre Channel or IP infrastructures
NearStore (near-line) feature—SATA drive technology enables online and quick access to
archived and non-intensive transactional data
Advanced Single Instance Storage (A-SIS)—provides block-level deduplication of data
stored in NearStore volumes
Compliance and data retention—software and hardware features that offer non-erasable
and non-rewritable data protection to meet the industry’s highest regulatory requirements
for retaining company data assets
NOTES:
*Systems are based on dual clustered storage controllers. Divide all numbers by one-half if a single
storage controller system is ordered.
A single controller can be easily upgraded to a dual controller system as your computing needs increase.
The dual controller is a fully redundant system and is designed to provide failover and failback
capabilities.
The N series Interoperability Matrix can be found at the following Web site:
ibm.com/storage/network/interophome.html
The following are trademarks or registered trademarks of NetApp Inc.; Data ONTAP, FlexCache,
FlexScale, FlexVol, FilerView, Protection Manager, SecureAdmin, RAID-DP, SecureAdmin, FlexClone,
MultiStore, SnapLock, LockVault, Snapshot, SnapDrive, SnapMirror, SnapMover, SnapRestore, SnapVault,
SnapManager, SnapValidator, SyncMirror, FlexShare, NearStore, Virtual File Manager
16
Data Archiving & Retention Systems/System Storage Software
IBM System Storage DR550/Disk Storage Virtualization
Disk Storage Virtualization
Create a tiered storage environment and help increase the flexibility and efficiency of your storage infrastructure by introducing solutions based on
IBM System Storage virtualization software.
Product
IBM System
Storage SAN
Volume Controller
(SVC)
Product
Machine/model
Platform
support
Host
connectivity
Software
Archiving application interface
Controller
Operating
system
Management
interface
Systems
supported
Backup sw
Backup hw
Copy services
Encryption
RAID support
Capacity
(min, max)
Drive support
DR550
DR550
IBM System Storage DR550
2233 DR1
All IBM systems platforms and other vendor platforms
IBM System Storage DR550
2233 DR2
All IBM systems platforms and other vendor platforms
2 port Gigabit Copper or Fibre Ethernet (upgrades
available)
IBM System Storage Archive Manager (SSAM)
SSAM application programming interface (API) v5.5.0 or
DR550 File System Gateway
Single System p5™ POWER5+™
IBM AIX, Version 5.3
2 port Gigabit Copper or Fibre Ethernet (upgrades
available)
IBM System Storage Archive Manager (SSAM)
SSAM application programming interface (API) v5.5.0 or
DR550 File System Gateway
Single or Dual active/passive System p5 POWER5+
IBM AIX, Version 5.3 Dual server includes IBM HACMP 5.3
IBM Director 5.20.2
IBM Director 5.20.2
External Tape and Optical
External Tape and Optical
Included in SSAM
External tape
NA
Disk or tape, 128-bit AES or 56-bit DES encryption
technology
5
880 GB, 37 TB
Included in SSAM
External tape
Metro or Global mirroring
Disk or tape, 128-bit AES or 56-bit DES encryption
technology
5
6 TB, 168 TB
750 GB SATA
750 GB SATA
●
●
●
●
●
●
●
●
●
●
●
●
Highlights
Manage storage volumes from a central point: SVC is designed to
enhance the flexibility of your storage environment. It can combine
the storage capacity from multiple disk systems from different suppliers into a single pool of storage that can be managed from a central
point. In this way, fewer skills are required and storage administrators
can become more productive.
● Virtually eliminate downtime related to storage: SVC enables data
migrations, maintenance and upgrades to the SVC system itself, and
changes to the physical storage without impacting host applications.
● Improve storage resource utilization: By combining the storage
capacity from multiple disk systems into a single pool, SVC uses
existing storage capacity more efficiently, which can allow you to
defer additional storage purchases to save costs.
● A single, cost-effective set of advanced copy services: SVC can
apply copy services across all the managed storage, regardless of the
disk system supplier. This capability helps simplify the environment,
can reduce the costs of implementing disaster recovery solutions,
increases flexibility in using storage and increases personnel
productivity.
● Create a tiered storage environment: Using virtualization technology, SVC enables customers to match the cost of the storage to the
value of their data. For example, mission-critical data can be stored
on high-performance, highly available Fibre Channel disks while nonmission-critical data can be stored on Serial ATA disks. Data can easily be moved from one tier to another without application disruption.
●
IBM TotalStorage Expert Family
Adds value to the storage subsystem solution by providing information for better management.
DR550 Highlights
●
Function and Value
Based on virtualization technology, the
IBM System Storage SAN Volume Controller
is designed to increase the efficiency and
flexibility of your storage infrastructure by
pooling storage and centralizing management, and enabling changes to the physical
storage while avoiding disruption to
applications.
An award-winning and industry-proven information archiving and retention offering with built-in lifecycle management capabilities to help organizations meet the growing challenges of efficiently managing, protecting and retaining data.
Repository for all kinds of content (e-mail, database, documents, images, files, etc.)
Provide non-erasable, non-rewritable archival storage; prevents deletion or alteration of data stored on the system
Support multiple storage tiers for long-term archiving (disk, tape and optical) helping lower TCO
Provide the facilities to migrate archive data from aging disk or tape subsystems to new ones
Offer automatic provisioning, migration, expiration and archiving capabilities
Offer scalability up to 168 TB raw physical capacity and supports petabytes of storage with attached tape and optical
Offer chronological and event-based data retention
Offer high-availability option to avoid single points of failure
Provide security and protection through data encryption and data shredding options
Support and integrate with broad set of IBM and non-IBM content management applications
Protect customer data against disasters through Synchronous or Asynchronous Replication
Award-winning: Data Protection Summit—Information Lifecycle Management (ILM)—Best of Show, 2007 and AIIM (The Enterprise Content
Management Association)—Best in Show, 2005, 2006
Product
IBM TotalStorage ETL Expert
Function and Value
Provides a high-performance monitoring tool to help simplify the management of IBM tape subsystems that
include the IBM TotalStorage Enterprise Tape Library, Virtual Tape Server and Peer-to-Peer Virtual Tape Server
IBM TotalStorage XRC
Performance Monitor
Provides the ability to monitor and evaluate the performance of a running XRC configuration; the monitor
function provides information at the real-time, historic and summary levels
DFSMS™ Family
Provides automated and central storage management in the z/OS environment
17
Product
DFSMSdfp™
Function and Value
Provides data access, program and device management functions that furnish effective management of
active data
DFSMSdss™
Provides data movement, copy, backup and space management functions
DFSMShsm™
Provides backup, recovery, migration and space management functions that furnish effective management of
inactive data
DFSMSrmm™
Provides a policy-driven solution for the management of removable media, such as tape cartridges and reels
DFSORT™
Provides a solution for faster and easier data sorting, reporting and analysis
DFSMStvs
Enables batch jobs and IBM CICS® (Customer Information Control Systems) online transactions to update
shared VSAM data sets concurrently
System Storage Software/System Storage Services
IBM Tivoli Storage Manager
Function and Value
IBM Tivoli Storage Manager is designed to protect your
24x7 applications and key data in the event of hardware,
software or network failures. It offers move-and-store techniques and policy-based automation, which are designed to
work together to help increase data and application protection, decrease disaster recovery time and reduce storage
administration costs. It manages inactive data, helping you
match the value of the data to the most cost-effective storage
management practices. Tivoli Storage Manager is designed to
scale easily to protect hundreds of computers running a
dozen operating systems ranging from laptops to mainframes
and connected together via the Internet, WANs, LANs or
SANs. Tivoli Storage Manager also offers open, easy-to-use
APIs designed to enable ISVs to more easily adapt their solutions to IBM software, allowing customers to customize, better secure and extend the functionality of their storage
environment.
Highlights
Designed to protect valuable data in the most
cost-effective manner
● Designed to archive inactive data to help reduce
costs
● Designed to help ensure
continuity and recovery
●
IBM Tivoli Storage Manager Extended Edition
IBM Tivoli Storage Manager Extended Edition expands on Tivoli Storage Manager backup,
restore and archive abilities. It helps expedite disaster recovery with detailed planning and
automated scripts. Disaster recovery reporting functionality can track where offsite copies of
data are stored.
IBM Tivoli Storage Manager Express
Tivoli Storage Manager Express uses proven Tivoli Storage Manager technology to back up and
recover vital data. It is easily installed, competitively priced, and designed to deliver reliable,
robust backup and recovery services that integrate as you grow.
IBM Tivoli Storage Manager for Advanced Copy Services
IBM Tivoli Storage Manager for Copy Services
IBM Tivoli Storage Manager for Advanced Copy Services and IBM Tivoli Storage Manager for
Copy Services help protect mission-critical data that requires 24x7 availability. They offer
ready-to-use, product-based solutions designed to implement high-efficiency backup and
restore processes and helps eliminate backup-related performance issues. TSM for Copy
Services provides the integration with Microsoft Volume Shadow Copy Service (VSS) and VSS
providers for snapshots. TSM for Advanced Copy Services provides the integration with
IBM FlashCopy as supported by IBM System Storage SAN Volume Controller (SVC), IBM System
Storage DS6000, IBM System Storage DS8000, and other snapshot mechanisms.
IBM Tivoli Storage Manager for Storage Area Networks
IBM Tivoli Storage Manager for Storage Area Networks works with servers and client computers to make data transfers over SAN. It allows SAN-connected Storage Manager servers and
Storage Manager client computers to make maximum use of their direct network connection
to storage.
Tivoli Storage Manager for System Backup and Recovery
IBM Tivoli Storage Manager for System Backup and Recovery delivers a flexible backup
method for your AIX systems. It offers a comprehensive system backup, restore, and reinstallation tool and can be executed from either the AIX command line or by using the SMIT menu
interface.
IBM Tivoli Storage Manager for Enterprise Resource
Planning
IBM Tivoli Storage Manager for Enterprise Resource Planning protects your vital SAP system
data. Now you can improve the availability of your SAP database servers and reduce your
administration workload with automated data protection designed for mySAP environments.
IBM Tivoli Continuous Data Protection for Files
IBM Tivoli Continuous Data Protection for Files backs up your most important files the moment
they are saved. It provides a real-time, continuous data protection solution for desktop and laptop computers, effortlessly and transparently, without administrative intervention.
IBM Tivoli Storage Manager for Mail
IBM Tivoli Storage Manager for Mail protects data on e-mail servers running Lotus® Domino®
or Microsoft Exchange. This software module for Tivoli Storage Manager automates data protection, enables “hot” backups without shutting down the server and improves data restore
performance.
IBM Tivoli Storage Manager for Microsoft SharePoint
Cristie Bare Machine Restore
Cristie Bare Machine Recovery (CBMR) integrates with IBM Tivoli Storage Manager to provide a
Bare Machine Recovery (BMR) solution for Windows, Linux, SUN Solaris and HP-UX. CBMR
combined with Tivoli Storage Manager functionality allows customers to recover a
Windows 2000, XP or 2003 operating system to a new disk drive, RAID array or a completely
new machine using only a CD and a disaster recovery backup stored in the Tivoli Storage
Manager server. This functionality is also supported for Linux, SUN Solaris and HP-UX operating
systems.
IBM Tivoli Storage Manager for Microsoft SharePoint is a policy-based backup and recovery
solution. Quickly and confidently restore your Microsoft SharePoint business data and content
after almost any kind of business interruption.
FilesX Xpress Restore CDP
IBM Tivoli Storage Manager for Space Management
IBM Tivoli Storage Manager for Space Management moves inactive data to reclaim online disk
space for important active data. It frees administrators and users from manual file system
pruning tasks, and can allow you to defer the need to purchase additional disk storage.
18
Next-generation data protection and recovery solutions from FilesX, an IBM company, provide
the power to quickly recover any amount of Microsoft Windows server data, anywhere in the
organization, from any previous point-in-time, no matter what happens to cause a loss of data.
These solutions are an excellent complement to IBM Tivoli Storage Manager offerings, providing additional protection and recovery capabilities for Microsoft Windows servers in the data
center and in remote/branch offices.
System Storage Software/System Storage Services (Continued)
IBM TotalStorage Productivity Center
Product
IBM TotalStorage
Productivity
Center Basic
Edition
IBM TotalStorage
Productivity
Center for Disk
IBM TotalStorage
Productivity
Center for Data
IBM TotalStorage
Productivity
Center for Fabric
Function and Value
IBM TotalStorage Productivity
Center Basic Edition is designed
to provide basic storage
resource management through
a centralized location. It extends
existing management of a single storage system and provides
capabilities such as storage
reporting, monitoring, policybased management and storage provisioning.
In a pooled or virtualized SAN
environment, multiple devices
work together to create a storage solution. IBM TotalStorage
Productivity Center for Disk is
designed to provide integrated
administration, performance
analytics, capacity utilization,
storage optimization, green tools
and replication features for
these environments.
IBM TotalStorage Productivity Center
Highlights
Inexpensive entry point for IT
managers requiring basic
asset and capacity reporting.
● Designed to provide storage
management via the SNIA
Storage Management
Interface Specification
(SMI-S), which includes the
IBM System Storage DS family, IBM System Storage SAN
Volume Controller (SVC) and
other vendor storage devices
that have implemented support for the SMI-S standards.
●
●
●
●
●
IBM TotalStorage Productivity
Center for Data is a Storage
Resource Management (SRM)
tool for storage environments
that provides a set of policydriven, automated tools for
managing storage capacity,
availability, events, performance
and assets, including DAS, NAS
and SAN technologies.
●
IBM TotalStorage Productivity
Center for Fabric is designed to
help automate the management
of heterogeneous storage networks and works with a broad
range of devices so businesses
can leverage and better use
existing technology investments.
It is designed to provide comprehensive management of
physical and logical configurations for multi-vendor SANs with
automatic resource discovery,
event monitoring and alerting,
zone control and SAN errorprediction capabilities.
●
●
●
●
●
IBM TotalStorage
Productivity
Center for
Replication
TotalStorage Productivity Center
for Replication is available in
both Two-Site and Three-Site
Business Continuity options and
provides disaster recovery management through planned and
unplanned failover and failback
automation for the IBM ESS
Model 800, IBM DS6000,
IBM DS8000 and the
IBM System Storage SAN
Volume Controller.
Designed to help reduce the
complexity and cost of storage management while
improving data availability
Offers centralized, open
standards–based management of storage devices
Designed to help enhance
storage administrator
productivity
Offers proactive management
of storage devices
Designed to help leverage
and optimize existing storage
resources and perform storage management with a high
level of control
Designed to help maximize
storage utilization
Designed to help you manage more storage with the
same staff
TotalStorage Productivity Center
for Replication is designed to
simplify and automate the configuration of your replication
environment allowing for more
effective Metro Mirror, Global
Mirror and IBM FlashCopy management. It is also designed to
monitor and automate copy
operations across devices
to support a replication
environment.
IBM TotalStorage
Productivity
Center Standard
Edition
Combines the best of Disk, Data
and Fabric products together as
one orderable product.
Designed to help predict storage network failures before
they happen, enabling preventative maintenance
Designed to help accelerate
problem isolation when failures occur
Designed to create a single
point of control, administration and security for the management of heterogeneous
storage networks
●
●
●
●
●
Automates the configuration
of your IBM DS8000,
DS6000™ and ESS Model
800 and the IBM SAN Volume
Controller advanced copy
services features
Monitors and manages the
replication operations to
ensure successful completion
from your source volumes to
your disaster recovery
volumes
Allows you to monitor the
progress of the copy services
so you can verify the amount
of replication that has been
done as well as the amount
of time needed to complete
the replication
Designed to provide automated failover to keep your
critical data online and available to your users even if
your primary site fails. When
the primary site comes back
on, the software manages
failback to the default
configuration as well.
Having Disk, Data and Fabric
allows higher levels of
value—i.e., combined SAN
and disk performance reports
or automated workflows to
do provisioning (under the
control of Tivoli Provisioning
Manager)
IBM Global Services for System Storage and Storage
Networking
Data Storage Services from IBM can help you achieve business objectives by creating costeffective data storage solutions that address the requirements of key business applications.
These solutions can support multiple platforms and product vendors, helping to provide
enhanced protection for critical business data, increased asset utilization, availability and
reliability levels with reduced management costs.
IBM Global Services, as the leading data storage services provider, brings best practices from
its thousands of customer engagements to work with your employees to integrate new solutions and technology with your business and IT needs. IBM offers a comprehensive portfolio of
data storage services including:
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
Analysis of enterprise information needs and environment
Defined enterprise-wide storage strategies
Quantified business benefits
Backup/restore and business continuity planning
Performance and capacity planning
Enterprise security architecture
Storage migration and consolidation
Networked storage architecture design
SAN configuration and integration services
Proof of concept, validation and certification
Implementation, testing and migration services
Education and training
Installation, relocation, cabling and site preparation
Business and application recovery services
Systems monitoring and management
Managed Storage Services
IBM Global Services has a track record in offering services for open and mainframe storage,
data migration, installation and support services for IBM and non-IBM environments.
Some examples are:
● IBM Storage Strategy Assessment assists with the vision and strategy, assessment, architecture and conceptual designs to help customers optimize their storage infrastructure to
new architectures.
● IBM Planning Services for 3494 Automated Tape Library and Virtual Tape Server can help
improve tape storage management and gain control of an often expanding library of tapes.
● IBM Operational Support Services for Tivoli Storage Manager assists customers in the planning and implementation of storage management software.
● IBM Managed Storage Services offer scalable, cost-effective storage capacity, management
and backup/restore services on a usage basis.
More information about IBM storage services can be found at ibm.com/services/
storage.
IBM Global Financing
IBM Global Financing offers competitive financing to credit-qualified customers and
IBM Business Partners to assist them in acquiring IT solutions. Our offerings include financing
for IT acquisition—including hardware, software and services, from IBM and other manufacturers or vendors—as well as commercial financing (revolving lines of credit, term loans, acquisition facilities and inventory-financing credit lines) for IBM Business Partners. Offerings (for all
customer segments: small, medium and large enterprise), rates, terms and availability may
vary by country. Contact your local IBM Global Financing organization or visit the Web at
ibm.com/financing.
19
ibm.com/storage
© Copyright IBM Corporation 2008
IBM Systems and Technology Group
Route 100
Somers, NY 10589
Produced in the United States
June 2008
All Rights Reserved
This document could include technical inaccuracies or typographical errors.
IBM may make changes, improvements, or alterations to the products, programs
and services described in this document, including termination of such products,
programs and services, at any time and without notice. Any statements regarding
IBM’s future direction and intent are subject to change or withdrawal without
notice, and represent goals and objectives only. The information contained in this
document is current as of the initial date of publication only and is subject to
change without notice. IBM shall have no responsibility to update such
information.
IBM is not responsible for the performance or interoperability of any
non-IBM products discussed herein. Performance data for IBM and nonIBM products and services contained in this document was derived under specific
operating and environmental conditions. The actual results obtained by any party
implementing such products or services will depend on a large number of factors
specific to such party’s operating environment and may vary significantly.
IBM makes no representation that these results can be expected or obtained in
any implementation of any such products or services.
MB, GB and TB equal 1,000,000, 1,000,000,000 and 1,000,000,000,000 bytes,
respectively, where referring to storage capacity. Actual storage capacity will vary
based upon many factors and may be less than stated. Some numbers given for
storage capacities give capacity in native mode followed by capacity using data
compression technology.
THE INFORMATION IN THIS DOCUMENT IS PROVIDED “AS-IS” WITHOUT ANY
WARRANTY, EITHER EXPRESSED OR IMPLIED. IBM EXPRESSLY DISCLAIMS
ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE OR INFRINGEMENT. IBM products are warranted according to the
terms and conditions of the agreements (e.g., IBM Customer Agreement,
Statement of Limited Warranty, International Program License Agreement, etc.)
under which they are provided.
References in this document to IBM products, programs or services does not
imply that IBM intends to make such products, programs or services available in
all countries in which IBM operates or does business. Any reference to an
IBM program or product in this document is not intended to state or imply that
only that program may be used. Any functionally equivalent program or product,
that does not infringe IBM’s intellectual property rights, may be used instead. It is
the user’s responsibility to evaluate and verify the operation of any nonIBM product, program or service.
Each IBM customer is responsible for ensuring its own compliance with legal
requirements. It is the customer’s sole responsibility to obtain advice of competent
legal counsel as to the identification and interpretation of any relevant laws and
regulatory requirements that may affect the customer’s business and any actions
the customer may need to take to comply with such laws. IBM does not provide
legal advice or represent or warrant that its services or products will ensure that
the customer is in compliance with any law.
IBM, the IBM logo, ibm.com, IBM, the IBM logo, AIX, AS/400, BladeCenter,
CICS, DFSMS, DFSMSdfp, DFSMSdss, DFSMShsm, DFSMSrmm, DFSMStvs,
DFSORT, Domino, DS6000, DS8000, Enterprise Storage Server, ESCON, FICON,
FlashCopy, HACMP, i5/OS, Lotus, Magstar, Netfinity, OS/390, OS/400,
POWER5+, xSeries, System i, System p, System p5, System x, System z,
System Storage, System Storage Proven, Tivoli, TotalStorage, VM/ESA, VSE/ESA,
WebSphere, z/OS and z/VM are trademarks or registered trademarks of
International Business Machines Corporation in the United States, other countries,
or both. If these and other IBM trademarked terms are marked on their first
occurrence in this information with a trademark symbol (® or ™), these symbols
indicate U.S. registered or common law trademarks owned by IBM at the time this
information was published. Such trademarks may also be registered or common
law trademarks in other countries. A current list of IBM trademarks is available on
the Web at “Copyright and trademark information” at ibm.com/legal/
copytrade.shtml
LTO and Ultrium are registered trademarks of International Business Machines
Corporation, Hewlett-Packard and Certance.
Microsoft, SharePoint, SQL Server, Windows, Windows NT and Windows Server
are trademarks of Microsoft Corporation in the United States, other countries
or both.
Intel is a registered trademark of Intel Corporation in the United States, other
countries or both.
Linux is a registered trademark of Linus Torvalds in the United States, other
countries or both.
UNIX is a registered trademark of The Open Group in the United States and other
countries.
The following are trademarks or registered trademarks of Network Appliance, Inc.:
Data ONTAP, FilerView, FlexClone, FlexShare, FlexVol, LockVault, MultiStore,
NearStore, Protection Manager, RAID-DP, SecureAdmin, SnapDrive, SnapLock,
SnapManager, SnapMirror, SnapMover, SnapRestore, Snapshot, SnapValidator,
SnapVault, SyncMirror and Virtual File Manager.
Other company, product and service names may be trademarks or service marks
of others.
IBM Global Financing offerings are provided through IBM Credit Corporation in
the United States and IBM Canada Ltd. in Canada to qualified commercial and
government customers. Rates are based on a customer’s credit rating, financing
terms, offering type, equipment type and options, and may vary by country. Other
restrictions may apply. Rates and offerings are subject to change, extension or
withdrawal without notice.
IBM hardware products are manufactured from new parts, or new and used parts.
In some cases, the hardware product may not be new and may have been
previously installed. Regardless, IBM warranty terms apply.
TSO00364-USEN-28
G325-3369-28
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
