QUICK DISCONNECT POWER DISTRIBUTION
WHY CHOOSE powerfast™
CONNECTIVITY SOLUTIONS?
COST SAVINGS
• Decrease labor costs by up to 40% over traditional conduit installations
• Reduce the time it takes to install and commission the system
QUALITY PRODUCTS AND SERVICE
• High quality design and materials
• UL approved products
• Robust and reliable environmentally protected connectors
• Superior customer service and product support
ANYONE CAN INSTALL THE SYSTEM
• Professional installations are not required
• Connectors are keyed to avoid installation errors
• Eliminate concerns for mis-wiring
EASY TO RETROFIT
• Modular cordset system
• Easy to maintain and modify on the plant floor
• Cordsets, receptacles and tees provide design flexibility
• Easy customization and expandability
WHERE CAN YOU USE powerfast
CONNECTIVITY SOLUTIONS?
• Motor, heaters, lights and many other electrical devices
• Ideal for conveyor and material handling industries
• New system installations
• Retrofitting existing conduit installations
COMMAND YOUR POWER CONNECTION
powerfast connectors are not intended for
disconnection while under load. Use TURCK’s
tool removable powerlok guards
to prevent any accidental
disconnection. These locking
guards are not required but
offer reliable protection.
BLident RFID tranceivers
read and write data onthe-fly and are available
with a variety of ranges.
Non-contact proximity
sensors are available in a
variety of housing styles.
IP67, IP68 and IP69K robust and reliable
overmolded connectors are capable of
holding up to the harshest environments.
RFID controllers are
machine-mountable
and available for many
network protocols.
Quick disconnect connectors are keyed
for quick installations while providing easy
maintanence and rapid change out.
Multiple power connector sizes are available.
Receptacles are ideal for
supplying power from
a panel or supplying
power to a device.
D-Size 1 3/8” Power
Up to 30 Amps
A-Size 7/8” Power
Up to 15 Amps
M16 Power
Up to 15 Amps
Closure caps may be used to
protect unused connectors
from damage or dirt.
Standard tees are ideal for
splitting main power trunk.
Reducer tees are ideal
for drops to devices with
reduced electrical demands.
Tray-rated exposed-run cable
meets code requirements and
replaces hard wiring and conduit.
TURCK’s powerfast will easily adapt to your design requirements
Closure caps may be used to
protect unused connectors
from damage or dirt.
QUICK DISCONNECT POWER DISTRIBUTION
WHY CHOOSE powerfast™
CONNECTIVITY SOLUTIONS?
COST SAVINGS
• Decrease labor costs by up to 40% over traditional conduit installations
• Reduce the time it takes to install and commission the system
QUALITY PRODUCTS AND SERVICE
• High quality design and materials
Standard tees are ideal for
•splitting
UL approved products
main power trunk.
• Robust and reliable environmentally protected connectors
POWE
A-Size 7/8” pow
• Superior customer service and product support
Reducer tees are ideal
for drops to devices with
reduced electrical demands.
Power reducers are
ideal a for drop to
the lastTray-rated
motor. exposed-run cable
meets code requirements and
replaces hard wiring and conduit.
ANYONE CAN INSTALL THE SYSTEM
• Professional installations are not required
• Connectors are keyed to avoid installation errors
D-Size 1 3/8” po
• Eliminate concerns for mis-wiring
EASY TO RETROFIT
• Modular cordset system
• Easy to maintain and modify on the plant floor
• Cordsets, receptacles and tees provide design flexibility
• Easy customization and expandability
M16 powerfast
WHERE CAN YOU USE powerfast
CONNECTIVITY SOLUTIONS?
• Motor, heaters, lights and many other electrical devices
• Ideal for conveyor and material handling industries
• New system installations
• Retrofitting existing conduit installations
Need to keep up with
your
application
demands?
TURCK’s
powerfast
will easily adapt to your design requirements
M23 powerfast
POWER QUICK REFERENCE
A-Size 7/8” powerfast
•
•
•
•
•
•
•
3- and 4-pin
14 AWG conductors
Tray rated-exposed run PVC cable
STOOW cable available
Up to 15 Amp, 600 Volt rated
NEMA 1,3,4,6P protection
IEC IP67 protection
•
•
•
•
•
•
•
3- and 4-pin
10 to 14 AWG conductors
Tray rated-exposed run PVC cable
STOOW cable available
Up to 30 Amp, 600 Volt rated
NEMA 1,3,4,6P protection
IEC IP67, IP68, IP69K protection
•
•
•
•
•
•
2- and 4-pin
12 and 14 AWG conductors
Shielded versions available
Tray rated-exposed run PVC cable
Up to 18 Amp, 600 Volt rated
IEC IP67 protection
•
•
•
•
•
•
6- to 9-pin
12 to 14 AWG conductors for power, 18 AWG conductors for signal
Shielded versions available
AWM or tray rated-exposed run PVC cable
Up to 30 Amp, 300 and 600 Volt rated
IEC IP67 protection
D-Size 1 3/8” powerfast
M16 powerfast
M23 powerfast
A-Size 7/8" powerfast
3
D-Size 1 3/8" powerfast
9
M16 powerfast
25
M23 powerfast
41
Index
47
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 1
Installation Guidelines
TURCK’s powerfast™ products are easy to
install by following a few simple guidelines:
• It is important to know the electrical requirements of the
application and to select a cordset that has the proper amperage
and voltage ratings for the application.
• Cables must be supported to prevent movement on the
equipment. Per NFPA 79, the cable must be supported every 12
inches in a non-vertical run, every 36 inches in a vertical run and
every 18 inches when suspended in air. The cable should also be
supported at any connection points or terminations.
• The cordsets are not intended for disconnection under load.
TURCK offers powerlok fittings that prevent the possibility of
disconnection. These fittings are not required for use, but can be
used as a precautionary measure.
• Power should never be supplied from the male connector.
The source of power should always be supplied from the
female connector.
• Use TURCK closure caps to protect connectors from damage
or dirt when not connected.
Note: Consult NFPA 79 (Electrical Standard for Industrial Machinery) for required over current protection of
conductors and other selection and installation guidelines for industrial machine applications.
Cable Options
TURCK offers multiple cable options for the powerfast products. The
majority of TURCK’s powerfast products use cables that carry a tray
rated, exposed run (TC-ER) approval. Select TURCK powerfast
products may carry an additional STOOW cable approval, although
versions that carry the STOOW and TC-ER approval are also available
as TC-ER only.
Both the STOOW/TC-ER cable and the TC-ER only cable version are
premium cable offerings, however, the TC-ER only version has a
slightly reduced cable outer diameter. This feature offers more
flexibility and is a more cost effective solution. This cable option
can be designated by adding a “/S4000” to the end of the part
description where applicable.
Estimated hp ratings for D-Size powerfast
(Based on 85% motor efficiency and 90% power factor.)
Single Phase (2 Current Carrying Conductors)
Pin Count
AWG
10 AWG
3-pin
12 AWG
14 AWG
Current
(amps)
30
25
18
Three Phase (3 Current Carrying Conductors)
Voltage
(volts)
Power
(hp)
230
7
460
14
575
17
230
5
230
8
460
11
460
16
575
14
575
20
230
4
230
6
460
8
460
12
575
10
575
15
Pin Count
AWG
10 AWG
4-pin
12 AWG
14 AWG
Current
(amps)
25
20
15
Voltage
(volts)
Power
(hp)
230
10
460
20
575
25
Note: These tables are theoretical values and are for reference only. Values will vary based on load conditions, as well as condition, age and type of motor.
Please consult a qualified electrician for specific product sizing requirements. Current limits for conductor gauge size taken from NFPA 79 2007 edition.
2 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
Part Number Keys
4
Cordset and Receptacle Specifications
5
Cordset and Receptacle Selection Matrix
5
Cordset and Receptacle Dimensions
6
Cordset and Receptacle Pinouts
6
Closure Caps
7
powerlok Accessories
8
Features
• Ideal for small motor applications
• 3 and 4-pin
• 14 AWG conductors
• Up to 15 Amp, 600 Volt rated
• Dual rated TC-ER and STOOW PVC cable
• “/S4000” TC-ER only PVC cable option available
• NEMA 1,3,4,6P protection
• IEC IP67 protection
www.turck.us 1-800-544-7769 Fax: (763) 553-0708 TURCK Inc. Minneapolis, MN 55441
B2300 3
A-Size 7/8" powerfast
A-Size 7/8" powerfast™ Connectivity
A-Size 7/8" powerfast™ Connectivity
A-Size 7/8" powerfast Cordset Part Number Key
Part Number Keys are to assist in IDENTIFICATION ONLY. Consult factory for catalog items not identified.
R K M
34 - *M /S..
A-Size 7/8" powerfast Cordset
Varieties
R = straight
W = right angle
(blank)
/S4000
/S ..
/CS ..
Gender
K = female connector, female threads
S = male connector, male threads
Y = male connector, female threads
= TC-ER STOOW PVC cable jacket
= TC-ER PVC cable jacket
= consult factory, special
= consult factory, special
Length in Meters
Number of Wires / AWG / Color Codes
Coupling Nut Material
34 = 3x14 AWG GN, BK, WH
44 = 4x14 AWG BK, WH, RD, GN
(blank) = nylon
M
= nickel plated brass
V
= 316 stainless steel (hex)
Insertion Point of Extension Cable 2nd Prefix*
* Male connector listed 1st, female connector 2nd
Example: RSM RKM 44-2M
Extension Example:
R S M
R K M
44 - *M
A-Size 7/8" powerfast Receptacle Part Number Key
R K F V
34 - *M /NPT
/S..
A-Size 7/8" powerfast Receptacle
Varieties
/S ..
= consult factory, special
/CS .. = consult factory, special
Gender
Connection Thread
K = female connector, female threads
S = male connector, male threads
X = female connector, male threads
/NPT = ½-14 NPT threads
Length in Meters
Designator for Receptacle
Number of Wires / AWG / Color Codes
Housing Material
(blank) = nickel plated brass
K
= nylon
V
= 316 stainless steel
4 B2300
34
44
= 3x14 AWG GN, BK, WH
= 4x14 AWG BK, WH, RD, GN
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
A-Size 7/8" powerfast™ Connectivity
A-Size 7/8" powerfast Cordset Specifications
Electrical
Mold material/Color:
PUR/Black
Contact material:
Brass or copper with gold plating
Contact carrier material:
PUR
Cable jacket material/Color:
Standard:
Additional options:
TC-ER STOOW PVC/Black
TC-ER PVC/Black (/S4000 version)
Ratings:
15 Amps, 600 VAC
Coupling nut material:
Standard:
Additional options:
Nickel plated brass
Nylon
316 stainless steel
Environmental protection:
NEMA 1, 3, 4, 6P and IEC IP67
Temperature rating:
-40 to +90°C (-40 to +194°F)
A-Size 7/8" powerfast Receptacle Specifications
Mechanical
Electrical
Contact carrier material:
Housing material/Plating:
Standard:
Additional options:
PUR
Nickel plated brass
Nylon
316 stainless steel
Environmental protection:
NEMA 1, 3, 4, 6P and IEC IP67
Temperature rating:
-40 to +105°C (-40 to +221°F)
Contact material:
Brass or copper with gold plating
Conductor insulation:
PVC
Ratings:
15 Amps, 600 VAC
A-Size 7/8" powerfast Cordset Selection Matrix
1
2
3
4
Straight Female
Straight Male
Right Angle Female
Right Angle Male
Pins
AWG
Current Rating
TC-ER STOOW
TC-ER STOOW
TC-ER STOOW
TC-ER STOOW
3
14
15
RKM 34-*M
RSM 34-*M
4
14
15
RKM 44-*M
RSM 44-*M
Pins
AWG
Current Rating
TC-ER
TC-ER
TC-ER
TC-ER
3
14
15
RKM 34-*M/S4000
RSM 34-*M/S4000
WKM 34-*M/S4000
WSM 34-*M/S4000
4
14
15
RKM 44-*M/S4000
RSM 44-*M/S4000
WKM 44-*M/S4000
WSM 44-*M/S4000
A-Size 7/8" powerfast Receptacle Selection Matrix
5
6
Front Mount
Female
Male
Pins
AWG
Current Rating
1/2-14NPT Mounting Thread
1/2-14NPT Mounting Thread
3
14
15
RKF 34-*M/NPT
RSF 34-*M/NPT
4
14
15
RKF 44-*M/NPT
RSF 44-*M/NPT
See page 6 for dimensional drawings.
* Length in meters. Standard cable lengths are 2, 5 and 10 meters. Standard lead length is 0.5 meters. Consult factory for other lengths.
Note: Extension cables are available, please consult Part Number Key (page 4).
Standard coupling nut material is nickel plated brass. Consult Part Number Key (page 4) for nylon and 316 stainless steel options.
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 5
A-Size 7/8" powerfast
Mechanical
A-Size 7/8" powerfast™ Connectivity
A-Size 7/8" powerfast Cordset and Receptacle Dimensions
1
RKM..
2
RSM..
3
WKM..
4
WSM..
5
RKF..*/NPT..
6
RSF..*/NPT..
A-Size 7/8" powerfast Cordset and Receptacle Pinouts
3-Pin
Female
Pinouts
Male
1. GN
2. BK
3. WH
6 B2300
4-Pin
Female
Pinouts
Male
1.
2.
3.
4.
BK
WH
RD
GN
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
A-Size 7/8" powerfast™ Connectivity
A-Size 7/8" powerfast Closure Cap Selection Matrix
7
Material
Thread
8
9
10
Mates to male
cordsets and
receptacles
Mates to female
cordsets and
receptacles
Mates to male
receptacles
6" SS Loop
Lanyard
6" SS Loop
Lanyard
6" SS Lanyard
with Eyelet
11
12
Mates to female
receptacles
Mates to male
cordsets and
receptacles
Mates to female
cordsets and
receptacles
6" SS Lanyard
with Eyelet
No Lanyard
No Lanyard
Nickel Plated Brass
7/8-16UN
RKM-CC
RSM-CC
RKF-CC
RSF-CC
RKF-MC
RSF-MC
Stainless Steel
7/8-16UN
RKMV-CC
RSMV-CC
RKFV-CC
RSFV-CC
RKFV-MC
RSFV-MC
A-Size 7/8" powerfast
See table below for dimensional drawings.
A-Size 7/8" powerfast Closure Cap Dimensions
7
RKM-CC
8
RSM-CC
9
RKF-CC
10
RSF-CC
11
RKF-MC
12
RSF-MC
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 7
A-Size 7/8" powerfast™ Connectivity
A-Size 7/8" powerlok
Part Number
LOCK-A POWER
Application
Nylon locking guard for straight
A-Size powerfast connectors
A-Size powerlok Open
8 B2300
A-Size powerlok Closed
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
Part Number Keys
10
Cordset, Receptacle and Field Wireable Specifications
12
Cordset, Receptacle and Field Wireable Selection Matrix
13
Cordset, Receptacle and Field Wireable Dimensions
15
Cordset, Receptacle and Field Wireable Pinouts
16
Tee Specifications
17
Tee Selection Matrix
17
Power Reducer Specifications
18
Power Reducer Selection Matrix
18
Tee and Power Reducer Dimensions
19
Tee and Power Reducer Wiring Diagrams
21
Tee and Power Reducer Pinouts
22
Closure Caps
23
powerlok Accessories
24
Features
• Ideal for a complete power distribution system
• Tee configurations utilize other powerfast family connectors
• 3 and 4-pin
• 10-14 AWG conductors
• Up to 30 Amp, 600 Volt rated
• Dual rated TC-ER and STOOW PVC cable
• “/S4000” TC-ER only PVC cable option available
• NEMA 1,3,4,6P protection
• IEC IP67, IP68, IP69K protection
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 9
D-Size 1 3/8" powerfast
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Cordset Part Number Key
Part Number Keys are to assist in IDENTIFICATION ONLY. Consult factory for catalog items not identified.
G S D
M
30 - *M
D-Size 1 3/8" powerfast Cordset
Varieties
Gender
(blank) = TC-ER STOOW PVC cable jacket
/S4000 = TC-ER PVC cable jacket
Length in Meters
K = female connector, female threads
S = male connector, male threads
D-Size Power
Number of Wires / AWG / Color Codes
30
32
34
40
42
44
Configuration
(blank) = straight
W
= right angle
= 3x10 AWG
= 3x12 AWG
= 3x14 AWG
= 4x10 AWG
= 4x12 AWG
= 4x14 AWG
BK, GN, WH
BK, GN, WH
BK, GN, WH
BK, GN, RD, WH
BK, GN, RD, WH
BK, GN, RD, WH
Coupling Nut Material
Insertion Point of Extension Cable 2nd Prefix*
A = anodized aluminum
M = nickel plated brass
V = 316 stainless steel
* Male connector listed 1st, female connector 2nd
Example: GSDM GKDM 30-1M
Extension Example:
G S D M
G K D M
30 - *M
D-Size 1 3/8" powerfast Receptacle Part Number Key
G K D F
30 - *M /14.5/NPT
D-Size 1 3/8" powerfast Receptacle
Thread Type
Gender
/14.5/NPT = ½-14 NPT
/14.75/NPT = 3/4-14 NPT
K = female connector, female threads
S = male connector, male threads
D-Size Power
Designator for Receptacle
Housing Material
Length in Meters
Number of Wires / AWG / Color Codes
30
32
34
40
42
44
=
=
=
=
=
=
3x10 AWG
3x12 AWG
3x14 AWG
4x10 AWG
4x12 AWG
4x14 AWG
BK, GN, WH
BK, GN, WH
BK, GN, WH
BK, GN, RD, WH
BK, GN, RD, WH
BK, GN, RD, WH
(blank) = nickel plated brass
A
= anodized aluminum
V
= 316 stainless steel
10 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Tee Part Number Key
Part Number Keys are to assist in IDENTIFICATION ONLY. Consult factory for catalog items not identified.
G S D M /
2GKDM
30
- *
/S..
D-Size (1 3/8") powerfast Tees
Varieties
Trunk(1) Identifier
/S
= consult factory, special
/CS
= consult factory, special
/S4000 = designates TC-ER cable
K = female connector
S = male connector
Length in Meters
D-Size Power
(blank)
Coupling Nut Material
Number of Wires / AWG / Color Codes
A = anodized aluminum
M = nickel plated brass
V = 316 stainless steel
30
32
34
40
42
44
Trunk(2) and Drop(3) Identifiers
= female trunk(2) and female drop(3)
= male trunk(2) and female drop(3)
= female trunk (2) and cable drop(3)
= female trunk(2) and female A-Size Power drop(3)
= female trunk(2) and female M16 Power drop(3)
BK, GN, WH
BK, GN, WH
BK, GN, WH
BK, GN, RD, WH
BK, GN, RD, WH
BK, GN, RD, WH
D-Size 1 3/8" powerfast
2GKDM
GSDM/GKDM
GKDM/T
GKDM/RKM
GKDM/BKM
= 3x10 AWG
= 3x12 AWG
= 3x14 AWG
= 4x10 AWG
= 4x12 AWG
= 4x14 AWG
Note: Only one male connector per tee available.
Standard female coupling nut material for A-Size Power drop
and M16 Power drop is nickel plated brass.
Part Number Key is based on the number
configuration molded on the tee body.
Trunk(2)
Trunk(1)
Drop(3)
Tee Examples:
G S D M / 2 G K D M
30
G S D M / G K D M / R K M
44
- *
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 11
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Cordset Specifications
Mechanical
Electrical
Mold material/Color:
PVC/Black
Contact material:
Brass or copper with gold plating
Contact carrier material:
PVC
Cable jacket material/Color:
Standard:
Additional options:
TC-ER STOOW PVC/Black
TC-ER PVC/Black (/S4000 version)
Ratings:
15-30 Amps, 600 VAC
Coupling nut material:
Standard:
Additional options:
Nickel plated brass
Anodized aluminum
316 stainless steel
Environmental protection:
NEMA 1, 3, 4, 6P and
IEC IP67, IP68, IP69K
Temperature rating:
-40 to +90°C (-40 to +194°F)
D-Size 1 3/8" powerfast Receptacle Specifications
Mechanical
Contact carrier material:
Housing material/Plating:
Standard:
Additional options:
Electrical
Contact material:
PVC
Nickel plated brass
Anodized aluminum
316 stainless steel
Environmental protection:
NEMA 1, 3, 4, 6P and
IEC IP67, IP68, IP69K
Temperature rating:
-40 to +105°C (-40 to +221°F)
Brass or copper with gold plating
Conductor insulation:
PVC
Ratings:
15-30 Amps, 600 VAC
D-Size 1 3/8" powerfast Field Wireable Specifications
Mechanical
Electrical
Housing material/Color:
Nylon/Black
Contact material:
Brass or copper with gold plating
Contact carrier material:
PVC
Ratings:
Up to 30 Amps, 600 VAC
Coupling nut material:
Standard:
Additional options:
Nickel plated brass
Anodized aluminum
316 stainless steel
Environmental protection:
NEMA 6P and IEC IP67
Temperature rating:
-40 to +90°C (-40 to +194°F)
12 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Cordset Selection Matrix
Pins
3
4
Pins
3
4
2
3
4
Straight Female
Straight Male
Right Angle Female
Right Angle Male
AWG
Current Rating
TC-ER STOOW
TC-ER STOOW
TC-ER STOOW
TC-ER STOOW
10
30 Amps
GKDM 30-*M
GSDM 30-*M
GKDWM 30-*M
GSDWM 30-*M
12
25 Amps
GKDM 32-*M
GSDM 32-*M
GKDWM 32-*M
GSDWM 32-*M
14
18 Amps
GKDM 34-*M
GSDM 34-*M
GKDWM 34-*M
GSDWM 34-*M
10
25 Amps
GKDM 40-*M
GSDM 40-*M
GKDWM 40-*M
GSDWM 40-*M
12
20 Amps
GKDM 42-*M
GSDM 42-*M
GKDWM 42-*M
GSDWM 42-*M
14
15 Amps
GKDM 44-*M
GSDM 44-*M
GKDWM 44-*M
GSDWM 44-*M
AWG
Current Rating
TC-ER
TC-ER
TC-ER
TC-ER
10
30 Amps
GKDM 30-*M/S4000
GSDM 30-*M/S4000
GKDWM 30-*M/S4000
GSDWM 30-*M/S4000
12
25 Amps
GKDM 32-*M/S4000
GSDM 32-*M/S4000
GKDWM 32-*M/S4000
GSDWM 32-*M/S4000
14
18 Amps
GKDM 34-*M/S4000
GSDM 34-*M/S4000
GKDWM 34-*M/S4000
GSDWM 34-*M/S4000
10
25 Amps
GKDM 40-*M/S4000
GSDM 40-*M/S4000
GKDWM 40-*M/S4000
GSDWM 40-*M/S4000
12
20 Amps
GKDM 42-*M/S4000
GSDM 42-*M/S4000
GKDWM 42-*M/S4000
GSDWM 42-*M/S4000
14
15 Amps
GKDM 44-*M/S4000
GSDM 44-*M/S4000
GKDWM 44-*M/S4000
GSDWM 44-*M/S4000
See page 15 for dimensional drawings.
* Length in meters. Standard cable lengths are 2, 5 and 10 meters. Consult factory for other lengths.
Note: Extension cables are available, please consult Part Number Key (page 10).
Standard coupling nut material is nickel plated brass. Consult Part Number Key (page 10) for anodized aluminum and 316 stainless steel options.
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 13
D-Size 1 3/8" powerfast
1
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Receptacle Selection Matrix
5
6
7
8
Front Mount
Pins
Female
Male
Female
Male
½-14 NPT
Mounting Thread
3/4-14 NPT
Mounting Thread
3/4-14 NPT
Mounting Thread
AWG
Current Rating
½-14 NPT
Mounting Thread
10
30 Amps
GKDF 30-*M/14.5/NPT
GSDF 30-*M/14.5/NPT
GKDF 30-*M/14.75/NPT
GSDF 30-*M/14.75/NPT
12
25 Amps
GKDF 32-*M/14.5/NPT
GSDF 32-*M/14.5/NPT
GKDF 32-*M/14.75/NPT
GSDF 32-*M/14.75/NPT
14
18 Amps
GKDF 34-*M/14.5/NPT
GSDF 34-*M/14.5/NPT
GKDF 34-*M/14.75/NPT
GSDF 34-*M/14.75/NPT
10
25 Amps
GKDF 40-*M/14.5/NPT
GSDF 40-*M/14.5/NPT
GKDF 40-*M/14.75/NPT
GSDF 40-*M/14.75/NPT
12
20 Amps
GKDF 42-*M/14.5/NPT
GSDF 42-*M/14.5/NPT
GKDF 42-*M/14.75/NPT
GSDF 42-*M/14.75/NPT
14
15 Amps
GKDF 44-*M/14.5/NPT
GSDF 44-*M/14.5/NPT
GKDF 44-*M/14.75/NPT
GSDF 44-*M/14.75/NPT
3
4
See page 16 for dimensional drawings.
* Length in meters. Standard lead length is 0.5 meters. Consult factory for other lengths.
Note: Standard housing material is nickel plated brass. Consult Part Number Key (page 10) for anodized aluminum and 316 stainless steel options.
D-Size 1 3/8" powerfast Field Wireable Selection Matrix
9
10
Front Mount
Female
Male
Pins
AWG
Current Rating
Screw Terminal
Screw Terminal
3
8-14
Up to 30 Amps
GKDM 30-0
GSDM 30-0
4
8-14
Up to 25 Amps
GKDM 40-0
GSDM 40-0
See page 16 for dimensional drawings.
Note: Standard coupling nut material is nickel plated brass. Consult factory for anodized aluminum and 316 stainless steel options.
14 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Cordset Dimensions
GKDM..
2
GSDM..
3
GKDWM..
4
GSDWM..
D-Size 1 3/8" powerfast
1
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 15
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Receptacle and Field Wireable Dimensions
5
GKDF..*/14.5/NPT
6
GSDF..*/14.5/NPT
7
GKDF..*/14.75/NPT
8
GSDF..*/14.75/NPT
9
GKDM..*-0
10
GSDM..*-0
D-Size 1 3/8" powerfast Cordset, Receptacle and Field Wireable Pinouts
3-Pin
Female
Pinouts
Male
1. BK
2. GN
3. WH
16 B2300
4-Pin
Female
Pinouts
Male
1.
2.
3.
4.
BK
GN
RD
WH
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Tee Specifications
Mechanical
Electrical
Mold material/Color:
PVC/Black
Contact material:
Brass or copper with gold plating
Contact carrier material:
PVC
Cable jacket material/Color:
Standard:
Additional options:
TC-ER STOOW PVC/Black
TC-ER PVC/Black (/S4000 version)
Ratings:
15-30 Amps, 600 VAC
Coupling nut material:
Standard:
Additional options:
Nickel plated brass
Anodized aluminum
316 stainless steel
Environmental protection:
NEMA 1, 3, 4, 6P and
IEC IP67, IP68, IP69K
Temperature rating:
-40 to +90°C (-40 to +194°F)
11
IntegralD-SizePower
Connector Drop
Trunk
Pins Drop
AWG Current
Rating
Drop
Current
Rating
12
13
Cable Drop
14
15
Cable Drop With
Cable Drop With
Cable Drop With
D-Size Power Connector A-Size Power Connector M16 Power Connector
TC-ER STOOW
TC-ER STOOW
TC-ER STOOW
10
30 Amps
30 Amps GSDM/2GKDM 30
GSDM/GKDM/T30-*
GSDM/2GKDM 30-*
12
30 Amps
25 Amps
GSDM/GKDM/T32-*
GSDM/2GKDM 32-*
14
30 Amps
18 Amps
GSDM/GKDM/T34-*
GSDM/2GKDM 34-*
10
25 Amps
25 Amps GSDM/2GKDM 40
GSDM/GKDM/T40-*
GSDM/2GKDM 40-*
12
25 Amps
20 Amps
GSDM/GKDM/T42-*
GSDM/2GKDM 42-*
14
25 Amps
15 Amps
GSDM/GKDM/T44-*
GSDM/2GKDM 44-*
GSDM/GKDM/RKM 44-*
Trunk
Pins Drop
AWG Current
Rating
Drop
Current
Rating
TC-ER
TC-ER
TC-ER
3
4
3
4
10
30 Amps
30 Amps GSDM/2GKDM 30
GSDM/GKDM/T30-*
/S4000
GSDM/2GKDM 30-*
/S4000
12
30 Amps
25 Amps
GSDM/GKDM/T32-*
/S4000
GSDM/2GKDM 32-*
/S4000
14
30 Amps
18 Amps
GSDM/GKDM/T34-*
/S4000
GSDM/2GKDM 34-*
/S4000
10
25 Amps
25 Amps GSDM/2GKDM 40
GSDM/GKDM/T40-*
/S4000
GSDM/2GKDM 40-*
/S4000
12
25 Amps
20 Amps
GSDM/GKDM/T42-*
/S4000
GSDM/2GKDM 42-*
/S4000
14
25 Amps
15 Amps
GSDM/GKDM/T44-*
/S4000
GSDM/2GKDM 44-*
/S4000
TC-ER STOOW
GSDM/GKDM/RKM 34-*
TC-ER
GSDM/GKDM/RKM 34-* GSDM/GKDM/BKM 34-*
/S4000
/S4000
GSDM/GKDM/RKM 44-* GSDM/GKDM/BKM 44-*
/S4000
/S4000
See page 19 for dimensional drawings.
* Length in meters. Standard cable lengths are 2, 5 and 10 meters. Consult factory for other lengths.
Note: Extension cables are available, please consult Part Number Key (page 11).
Standard coupling nut material is nickel plated brass. Consult Part Number Key (page 11) for anodized aluminum and 316 stainless steel options.
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 17
D-Size 1 3/8" powerfast
D-Size 1 3/8" powerfast Tee Selection Matrix
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Power Reducer Specifications
Mechanical
Electrical
Mold material/Color:
PVC/Black
Contact material:
Brass or copper with gold plating
Contact carrier material:
PVC
Ratings:
15 Amps, 600 VAC
Coupling nut material:
Standard:
Additional options:
Nickel plated brass
Anodized aluminum
316 stainless steel
Environmental protection:
NEMA 1, 3, 4, 6P and
IEC IP67, IP68, IP69K
Temperature rating:
-40 to +90°C (-40 to +194°F)
D-Size 1 3/8" powerfast Power Reducer Selection Matrix
16
Pins Drop
AWG
17
Current Rating
D-Size Power to A-Size Power Reducer
D-Size Power to M16 Power Reducer
3
14
Up to 15 Amps
GSDM RKM 34-0
GSDM BKM 34-0
4
14
Up to 15 Amps
GSDM RKM 44-0
GSDM BKM 44-0
See page 20 for dimensional drawings.
Note: Standard coupling nut material is nickel plated brass. Consult factory for anodized aluminum and 316 stainless steel options.
18 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Tee Dimensions
Integral D-Size Power Connector Drop
GSDM/2GKDM..
D-Size 1 3/8" powerfast
11
Tee with Cable Drop and Connector Options
12
Cable Drop
GSDM/GKDM/T..
13 D-Size Power Connector
GSDM/2GKDM..
14 A-Size Power Connector
GSDM/GKDM/RKM..
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
15
M16 Power Connector
GSDM/GKDM/BKM..
B2300 19
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Power Reducer Dimensions
20 B2300
16
D-Size Power to A-Size Power Reducer
GSDM RKM..
17
D-Size Power to M16 Power Reducer
GSDM BKM..
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Tee Wiring Diagrams
Cable Drop
3-Pin
D-Size Power Drop
4-Pin
3-Pin
A-Size Power Drop
M16 Power Drop
4-Pin
3-Pin
4-Pin
D-Size 1 3/8" powerfast
3-Pin
4-Pin
D-Size 1 3/8" powerfast Power Reducer Wiring Diagrams
D-Size Power to A-Size Power
3-Pin
4-Pin
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
D-Size Power to M16 Power
3-Pin
4-Pin
B2300 21
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Tee and Power Reducer Pinouts
D-Size Power
3-Pin
Female
4-Pin
Male
Female
Male
A-Size Power
3-Pin
Female
4-Pin
Male
Female
Male
M16 Power
3-Pin
Female
22 B2300
4-Pin
Male
Female
Male
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerfast Closure Cap Selection Matrix
18
19
20
21
Mates to male
cordsets and
receptacles
Mates to female
cordsets and
receptacles
Mates to male
receptacles
22
23
Mates to female
receptacles
Mates to male
cordsets and
receptacles
Mates to female
cordsets and
receptacles
Material
Thread
6" SS Loop
Lanyard
6" SS Loop
Lanyard
7" SS Lanyard
with Eyelet
7" SS Lanyard
with Eyelet
No Lanyard
No Lanyard
Nickel Plated Brass
1 3/8-16UN
GKDM-CC
GSDM-CC
GKDF-CC
GSDF-CC
GKDM-MC
GSDM-MC
See table below for dimensional drawings.
18
GKDM-CC
19
GSDM-CC
20
GKDF-CC
21
GSDF-CC
22
GKDM-MC
23
GSDM-MC
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
D-Size 1 3/8" powerfast
D-Size 1 3/8" powerfast Closure Cap Dimensions
B2300 23
D-Size 1 3/8" powerfast™ Connectivity
D-Size 1 3/8" powerlok
Part Number
LOCK-D POWER
Application
Nylon locking guard for
straight or right angle
D-Size powerfast connectors
D-Size powerlok Open
24 B2300
D-Size powerlok Closed
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
Part Number Keys
26
Cordset, Receptacle and Field Wireable Specifications
28
Cordset, Receptacle and Field Wireable Selection Matrix
28
Cordset, Receptacle and Field Wireable Dimensions
30
Cordset, Receptacle and Field Wireable Pinouts
31
Tee Specifications
32
Tee Selection Matrix
32
Tee Dimensions
33
Tee Wiring Diagrams
39
Tee Pinouts
39
Closure Caps
40
powerlok Accessories
40
Features
• Ideal for small motor applications
• Shielded versions available
• Multiple tee configurations
• 2 to 4-pin
• 12 and 14 AWG conductors
• Up to 18 Amp, 600 Volt rated
• Tray rated-exposed run PVC cable
• IEC IP67 protection
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 25
M16 powerfast
M16 powerfast™ Connectivity
M16 powerfast™ Connectivity
M16 powerfast Cordset Part Number Key
Part Number Keys are to assist in IDENTIFICATION ONLY. Consult factory for catalog items not identified.
B S M
34-198
- *
/S..
M16 (16 mm) powerfast Cordset
Varieties
Gender
/S = consult factory, special
/CS = consult factory, special
Length in Meters
K = female connector
S = male connector
Configuration
Number of Wires / AWG / Color Code
M = straight
WM = right angle
22-380 = 2x12 AWG WH, BK
34-198 = 3x14 AWG WH, GN, BK
44-193 = 4x14 AWG WH, GN, BK, RD
Coupling Nut Material
Insertion Point of Extension Cable 2nd Prefix*
(blank) = nickel plated brass
K
= nylon
V
= 316 stainless steel
* Male connector listed 1st, female connector 2nd
Example: BSM BKM 34-198-*
Extension Example:
B S M
B K M
34-198 - *
M16 powerfast Tee Part Number Key
B S M
/ 2BKM
34
- 198 - * -
/S..
M16 (16 mm) powerfast
Varieties
Trunk(1) Identifier
/S = consult factory, special
/CS = consult factory, special
K = female connector
S = male connector
Length in Meters
Configuration
(blank) = connector only
*
= drop cable
*/*/* = trunk(1) cable / trunk(2) cable / drop(3) cable
M = straight
Coupling Nut Material
AWG / Color Code
(blank) = nickel plated brass
K
= nylon
V
= 316 stainless steel
(blank) =
380 =
198 =
193 =
Trunk(2) and Drop(3) Identifiers
connector only
2x12 AWG, WH, BK
3x14 AWG, WH, GN, BK
4x14 AWG, WH, GN, BK, RD
Number of Pins
2BKM
= female trunk(2) and female drop(3)
BSM/BKM = male trunk(2) and female drop(3)
BKM/T
= female trunk(2) and cable drop(3)
22 = 2
34 = 3
44 = 4
Note: Only one male connector per tee available.
Part Number Key is based on the number
configuration molded on the tee body.
Trunk(1)
Tee Examples:
Trunk(2)
B S M / 2 B K M
34
B S M / 2 B K M
44
- 198 - *
Drop(3)
26 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M16 powerfast™ Connectivity
M16 powerfast Receptacle Part Number Key
Part Number Keys are to assist in IDENTIFICATION ONLY. Consult factory for catalog items not identified.
B K F
22 - *
/14.5/NPT
M16 (16 mm) powerfast Receptacle
Thread Type
Gender
/14.5/NPT
/18.375/NPT
/M20
/M18
K = female receptacle
S = male receptacle
= 1/2-14NPT threads
= 3/8-18NPT threads
= M20 threads
= M18 threads
Length in Meters
Designator for Receptacle
Housing Style
Number of Wires / AWG / Color Code
(blank) = front mount
D
= rear mount
22 = 2x12 AWG
34 = 3x14 AWG
44 = 4x14 AWG
WH, BK
WH, GN, BK
WH, GN, BK, RD
Housing Material
(blank) = nickel plated brass
V
= 316 stainless steel
M16 powerfast H/h Style Tee Part Number Key
/ 2BKM
34
- 198 - * -
/S..
H/h Style
Varieties
BH = big H
SH = small h
/S = consult factory, special
/CS = consult factory, special
M16 (16 mm) powerfast
Length in Meters
Trunk(1) Identifier
(blank)
*
*/*/*
*/*/*/*
K = female connector
S = male connector
= connector only
= drop cable
= trunk(1) cable / trunk(2) cable / drop(3) cable
= trunk(1) cable / trunk(2) cable /
drop(3) cable / drop(4) cable
Configuration
AWG / Color Code
M = straight
(blank) =
380 =
198 =
193 =
Coupling Nut Material
(blank) = nickel plated brass
K
= nylon
V
= 316 stainless steel
Number of Pins
Trunk(2) and Drop(3&4) Identifiers
22 = 2
34 = 3
44 = 4
2BKM
BSM/BKM
BKM/T
3BKM
BSM/2BKM
= female trunk(2) and female drop(3) (h)
= male trunk(2) and female drop(3) (h)
= female trunk(2) and cable drop (3) (h)
= female trunk(2) and female drops(3&4) (H)
= male trunk(2) and female drops(3&4) (H)
connector only
2x12 AWG, WH, BK
3x14 AWG, WH, GN, BK
4x14 AWG, WH, GN, BK, RD
Tee Examples:
BH - B S M / 3 B K M
34
- 198 - *
SH - B S M / B S M / B K M
44
Note: Only one male connector per tee.
H tee Part Number Key is based on the number
configuration molded on the tee body.
Trunk(1)
h tee Part Number Key is based on the number
configuration molded on the tee body.
Trunk(2)
Trunk(1)
Drop(3)
Drop(4)
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
Trunk(2)
Drop(3)
B2300 27
M16 powerfast
BH - B S M
M16 powerfast™ Connectivity
M16 powerfast Cordset Specifications
Mechanical
Electrical
Mold material/Color:
PUR/Black
Contact material:
Contact carrier material:
PUR
Cable jacket material/Color:
TC-ER PVC/Black
Ratings:
15-18 Amps, 600 V
Coupling nut material:
Standard:
Additional options:
Environmental protection:
Nickel plated brass
Nylon
316 stainless steel
IEC IP67
Temperature rating:
-40 to +90°C (-40 to +194°F)
Brass or copper with gold plating
M16 powerfast Receptacle Specifications
Mechanical
Electrical
Contact carrier material:
Contact material:
PUR
Housing material/Plating:
Standard:
Additional options:
Nickel plated brass
316 stainless steel
O-Ring material:
Nitrile (BUNA N)
Environmental protection:
IEC IP67
Temperature rating:
-40 to +105°C (-40 to +221°F)
Brass or copper with gold plating
Conductor insulation:
PVC
Ratings:
15-18 Amps, 600 V
M16 powerfast Field Wireable Specifications
Mechanical
Electrical
Housing material/Color:
Glass filled nylon or PVC/Black
Contact material:
Brass or copper with gold plating
Contact carrier material:
PUR
Ratings:
15-18 Amps, 600 VAC
Coupling nut material:
Standard:
Additional options:
Nickel plated brass
Nylon
316 stainless steel
Environmental protection:
NEMA 6P and IEC IP67
Temperature rating:
-40 to +90°C (-40 to +194°F)
M16 powerfast Cordset Selection Matrix
1
2
3
4
Straight Female
Straight Male
Right Angle Female
Right Angle Male
Pins
AWG
Current Rating
TC-ER
TC-ER
TC-ER
TC-ER
2
12
18 Amps
BKM 22-380-*
BSM 22-380-*
BKWM 22-380-*
BSWM 22-380-*
3
14
15 Amps
BKM 34-198-*
BSM 34-198-*
BKWM 34-198-*
BSWM 34-198-*
4
14
15 Amps
BKM 44-193-*
BSM 44-193-*
BKWM 44-193-*
BSWM 44-193-*
Pins
AWG
Current Rating
SHIELDED TC-ER
SHIELDED TC-ER
SHIELDED TC-ER
SHIELDED TC-ER
2
12
18 Amps
BKMS 22-1759-*
BSMS 22-1759-*
BKWMS 22-1759-*
BSWMS 22-1759-*
3
14
15 Amps
BKMS 34-1364-*
BSMS 34-1364-*
BKWMS 34-1364-*
BSWMS 34-1364-*
4
14
15 Amps
BKMS 44-1363-*
BSMS 44-1363-*
BKWMS 44-1363-*
BSWMS 44-1363-*
See pages 30-31 for dimensional drawings.
* Length in meters. Standard cable lengths are 2, 5 and 10 meters. Consult factory for other lengths.
Note: Extension cables are available, please consult Part Number Key (page 26).
Standard coupling nut material is nickel plated brass. Consult Part Number Key (page 26) for nylon and 316 stainless steel options.
28 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M16 powerfast™ Connectivity
M16 powerfast Receptacle Selection Matrix
5
6
7
8
Front Mount
Female
Male
Female
Male
Pins
AWG
Current Rating
1/2-14NPT
Mounting Thread
1/2-14NPT
Mounting Thread
3/8-18NPT
Mounting Thread
3/8-18NPT
Mounting Thread
2
12
18 Amps
BKF 22-*/14.5/NPT
BSF 22-*/14.5/NPT
BKF 22-*/18.375/NPT
BSF 22-*/18.375/NPT
3
14
15 Amps
BKF 34-*/14.5/NPT
BSF 34-*/14.5/NPT
BKF 34-*/18.375/NPT
BSF 34-*/18.375/NPT
4
14
15 Amps
BKF 44-*/14.5/NPT
BSF 44-*/14.5/NPT
BKF 44-*/18.375/NPT
BSF 44-*/18.375/NPT
9
10
11
12
Front Mount
Female
Male
Female
Male
Pins
AWG
Current Rating
M18 Mounting Thread
M18 Mounting Thread
M20 Mounting Thread
M20 Mounting Thread
2
12
18 Amps
BKF 22-*/M18
BSF 22-*/M18
BKF 22-*/M20
BSF 22-*/M20
3
14
15 Amps
BKF 34-*/M18
BSF 34-*/M18
BKF 34-*/M20
BSF 34-*/M20
4
14
15 Amps
BKF 44-*/M18
BSF 44-*/M18
BKF 44-*/M20
BSF 44-*/M20
13
14
Female
Male
Pins
AWG
Current Rating
M18 Mounting Thread
M18 Mounting Thread
2
12
18 Amps
BKFD 22-*/M18
BSFD 22-*/M18
3
14
15 Amps
BKFD 34-*/M18
BSFD 34-*/M18
4
14
15 Amps
BKFD 44-*/M18
BSFD 44-*/M18
M16 powerfast
Rear Mount
See pages 30-31 for dimensional drawings.
* Length in meters. Standard lead length is 0.5 meters. Consult factory for other lengths.
Note: Standard housing material is nickel plated brass. Consult Part Number Key (page 27) for 316 stainless steel options.
M16 powerfast Field Wireable Selection Matrix
15
16
Straight Female, PG 11 Cable Gland
Accepts 8-11 mm Cable Diameter
Straight Male, PG 11 Cable Gland
Accepts 8-11 mm Cable Diameter
Pins
Acceptable
Conductor AWG
Current Rating
Screw Terminal
Screw Terminal
2
12
18 Amps
BK 22-0
BS 22-0
3
14
15 Amps
BK 34-0
BS 34-0
4
14
15 Amps
BK 44-0
BS 44-0
See pages 30-31 for dimensional drawings.
Note: Standard coupling nut material is nickel plated brass. Consult factory for nylon and 316 stainless steel options.
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 29
M16 powerfast™ Connectivity
M16 powerfast Cordset, Receptacle and Field Wireable Dimensions
1
BKM..
2
BSM..
3
BKWM..
4
BSWM..
5
BKF..*/14.5/NPT
6
BSF..*/14.5/NPT
7
BKF..*/18.375/NPT
8
BSF..*/18.375/NPT
9
BKF..*/M18
10
BSF..*/M18
11
BKF..*/M20
12
BSF..*/M20
30 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M16 powerfast™ Connectivity
M16 powerfast Cordset, Receptacle and Field Wireable Dimensions
13
BKFD..*/M18
14
BSFD..*/M18
15
BK..
16
BS..
2-Pin
Female
Pinouts
Male
3-Pin
Female
Pinouts
Male
1. WH
2. BK
4-Pin
Female
M16 powerfast
M16 powerfast Cordset, Receptacle and Field Wireable Pinouts
1. WH
2. GN
3. BK
Pinouts
Male
1.
2.
3.
4.
WH
GN
BK
RD
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 31
M16 powerfast™ Connectivity
M16 powerfast Tee Specifications
Mechanical
Electrical
Mold material/Color:
PUR/Black
Contact material:
Contact carrier material:
PUR
Cable jacket material/Color:
TC-ER PVC/Black
Ratings:
15-18 Amps, 600 V
Coupling nut material:
Standard:
Additional options:
Environmental Protection:
Brass or copper with gold plating
Nickel plated brass
Nylon
316 stainless steel
IEC IP67
Temperature Rating:
Integral connector version:
Cable version:
-40 to +105°C (-40 to +221°F)
-40 to +90°C (-40 to +194°F)
M16 powerfast Tee Selection Matrix
17
18
Integral M16 Power
Connector Drop
19
20
Cable Drop with
M16 Power Connector
Cable Trunk and Cable Drop
with M16 Power Connectors
Cable Drop
TC-ER
TC-ER
TC-ER
Pins
AWG
Current
Rating
2
12
18 Amps
BSM/2BKM 22
BSM/2BKM 22-380-*
BSM/2BKM 22-380-*/*/*
BSM/BKM/T22-380-*
3
14
15 Amps
BSM/2BKM 34
BSM/2BKM 34-198-*
BSM/2BKM 34-198-*/*/*
BSM/BKM/T34-198-*
4
14
15 Amps
BSM/2BKM 44
BSM/2BKM 44-193-*
BSM/2BKM 44-193-*/*/*
BSM/BKM/T44-193-*
M16 powerfast h-Style Tee Selection Matrix
21
Trunk #1: Male Connector
22
Integral M16 Power
Connector Drop
23
24
Cable Drop with
M16 Power Connector
Cable Trunk and Cable Drop
with M16 Power Connectors
Cable Drop
TC-ER
TC-ER
TC-ER
Pins
AWG
Current
Rating
2
12
18 Amps
SH-BSM/2BKM 22
SH-BSM/2BKM 22-380-*
SH-BSM/2BKM 22-380-*/*/*
SH-BSM/BKM/T22-380-*
3
14
15 Amps
SH-BSM/2BKM 34
SH-BSM/2BKM 34-198-*
SH-BSM/2BKM 34-198-*/*/*
SH-BSM/BKM/T34-198-*
4
14
15 Amps
SH-BSM/2BKM 44
SH-BSM/2BKM 44-193-*
SH-BSM/2BKM 44-193-*/*/*
SH-BSM/BKM/T44-193-*
25
Trunk #2: Male Connector
26
Integral M16 Power
Connector Drop
27
28
Cable Drop with
M16 Power Connector
Cable Trunk and Cable Drop
with M16 Power Connectors
Cable Drop
TC-ER
TC-ER
TC-ER
Pins
AWG
Current
Rating
2
12
18 Amps
SH-BKM/BSM/BKM 22
SH-BKM/BSM/BKM 22-380-* SH-BKM/BSM/BKM 22-380-*/*/*
SH-BKM/BSM/T22-380-*
3
14
15 Amps
SH-BKM/BSM/BKM 34
SH-BKM/BSM/BKM 34-198-* SH-BKM/BSM/BKM 34-198-*/*/*
SH-BKM/BSM/T34-198-*
4
14
15 Amps
SH-BKM/BSM/BKM 44
SH-BKM/BSM/BKM 44-193-* SH-BKM/BSM/BKM 44-193-*/*/*
SH-BKM/BSM/T44-193-*
See pages 33-38 for dimensional drawings.
* Length in meters. Standard cable lengths are 2, 5 and 10 meters. Consult factory for other lengths.
Note: Standard coupling nut material is nickel plated brass. Consult Part Number Key (page 27) for nylon and 316 stainless steel options.
32 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M16 powerfast™ Connectivity
M16 powerfast H-Style Tee Selection Matrix
30
Integral M16 Power
Connector Drop
Trunk #1: Male Connector
31
Cable Drop with
M16 Power Connector
Cable Trunk and Cable Drop with
M16 Power Connectors
TC-ER
TC-ER
Pins
AWG
Current
Rating
2
12
18 Amps
BH-BSM/3BKM 22
BH-BSM/3BKM 22-380-*
BH-BSM/3BKM 22-380-*/*/*/*
3
14
15 Amps
BH-BSM/3BKM 34
BH-BSM/3BKM 34-198-*
BH-BSM/3BKM 34-198-*/*/*/*
4
14
15 Amps
BH-BSM/3BKM 44
BH-BSM/3BKM 44-193-*
BH-BSM/3BKM 44-193-*/*/*/*
32
33
Integral M16 Power
Connector Drop
Trunk #2: Male Connector
34
Cable Drop with
M16 Power Connector
Cable Trunk and Cable Drop with
M16 Power Connectors
TC-ER
TC-ER
Pins
AWG
Current
Rating
2
12
18 Amps
BH-BKM/BSM/2BKM 22
BH-BKM/BSM/2BKM 22-380-*
BH-BKM/BSM/2BKM 22-380-*/*/*/*
3
14
15 Amps
BH-BKM/BSM/2BKM 34
BH-BKM/BSM/2BKM 34-198-*
BH-BKM/BSM/2BKM 34-198-*/*/*/*
4
14
15 Amps
BH-BKM/BSM/2BKM 44
BH-BKM/BSM/2BKM 44-193-*
BH-BKM/BSM/2BKM 44-193-*/*/*/*
See pages 37-38 for dimensional drawings.
* Length in meters. Standard cable lengths are 2, 5 and 10 meters. Consult factory for other lengths.
Note: Standard coupling nut material is nickel plated brass. Consult Part Number Key (page 27) for nylon and 316 stainless steel options.
M16 powerfast Tee Dimensions
17
Integral M16 Power Connector Drop
BSM/2BKM..
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 33
M16 powerfast
29
M16 powerfast™ Connectivity
M16 powerfast Tee Dimensions
34 B2300
18
Cable Drop with M16 Power Connector
BSM/2BKM..
19
Cable Trunk and Cable Drop with M16 Power Connectors
BSM/2BKM..
20
Cable Drop
BSM/BKM/T..
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M16 powerfast™ Connectivity
M16 powerfast h-Style Tee Dimensions
Integral M16 Power Connector Drop, Trunk #1 Male
SH-BSM/2BKM..
22
Cable Drop with M16 Power Connector, Trunk #1 Male
SH-BSM/2BKM..
23
Cable Trunk and Cable Drop with M16 Power Connectors, Trunk #1 Male
SH-BSM/2BKM..
24
Cable Drop, Trunk #1 Male
SH-BSM/BKM/T..
M16 powerfast
21
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 35
M16 powerfast™ Connectivity
M16 powerfast h-Style Tee Dimensions
36 B2300
25
Integral M16 Power Connector Drop, Trunk #2 Male
SH-BKM/BSM/BKM..
26
Cable Drop with M16 Power Connector, Trunk #2 Male
SH-BKM/BSM/BKM..
27
Cable Trunk and Cable Drop with M16 Power Connectors, Trunk #2 Male
SH-BKM/BSM/BKM..
28
Cable Drop, Trunk #2 Male
SH-BKM/BSM/T..
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M16 powerfast™ Connectivity
M16 powerfast H-Style Tee Dimensions
Integral M16 Power Connector Drop, Trunk #1 Male
BH-BSM/3BKM..
30
Cable Drop with M16 Power Connector, Trunk #1 Male
BH-BSM/3BKM..
31
Cable Trunk and Cable Drop with M16 Power Connectors, Trunk #1 Male
BH-BSM/3BKM..
M16 powerfast
29
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 37
M16 powerfast™ Connectivity
M16 powerfast H-Style Tee Dimensions
38 B2300
32
Integral M16 Power Connector Drop, Trunk #2 Male
BH-BKM/BSM/2BKM..
33
Cable Drop with M16 Power Connector, Trunk #2 Male
BH-BKM/BSM/2BKM..
34
Cable Trunk and Cable Drop with M16 Power Connectors, Trunk #2 Male
BH-BKM/BSM/2BKM..
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M16 powerfast™ Connectivity
M16 powerfast Tee Wiring Diagrams
2-Pin
3-Pin
4-Pin
M16 powerfast h-Style Tee Wiring Diagrams
Trunk #1 Male, 3-Pin
Trunk #1 Male, 4-Pin
Trunk #2 Male, 2-Pin
Trunk #2 Male, 3-Pin
Trunk #2 Male, 4-Pin
M16 powerfast
Trunk #1 Male, 2-Pin
M16 powerfast H-Style Tee Wiring Diagrams
Trunk #1 Male, 2-Pin
Trunk #1 Male, 3-Pin
Trunk #1 Male, 4-Pin
Trunk #2 Male, 2-Pin
Trunk #2 Male, 3-Pin
Trunk #2 Male, 4-Pin
M16 powerfast Tee Pinouts
2-Pin
Female
3-Pin
Male
Female
4-Pin
Male
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
Female
Male
B2300 39
M16 powerfast™ Connectivity
M16 powerfast Closure Cap Selection Matrix
35
36
37
38
Mates to male
cordsets and
receptacles
Mates to female
cordsets and
receptacles
Mates to male
receptacles
39
40
Mates to female
receptacles
Mates to male
cordsets and
receptacles
Mates to female
cordsets and
receptacles
Material
Thread
6" Loop
Lanyard
6" Loop
Lanyard
6" Lanyard
with Eyelet
6" Lanyard
with Eyelet
No Lanyard
No Lanyard
Nickel Plated Brass
M16
BKM-CC
BSM-CC
BKF-CC
BSK-CC
BKM-MC
BSM-MC
See table below for dimensional drawings.
M16 powerfast Closure Cap Dimensions
35
BKM-CC
36
BSM-CC
37
BKF-CC
38
BSF-CC
39
BKM-MC
40
BSM-MC
M16 powerlok
Part Number
Application
LOCK-M16
Nylon locking guard for straight
M16 powerfast connectors
LOCK-M16-TEE
M16 powerlok Open
40 B2300
M16 powerlok Closed
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M23 powerfast™ Connectivity
42
Cordset and Receptacle Specifications
43
Cordset and Receptacle Selection Matrix
44
Cordset and Receptacle Dimensions
45
Cordset and Receptacle Pinouts
46
M23 powerfast
Part Number Keys
Features
• Options for combination of power and signal wires in one cable
• Shielded versions available
• 6 to 9-pin
• 12 to 14 AWG conductors for power, 18 AWG conductors for signal
• Up to 30 Amp, 600 Volt rated for power
• Up to 8 Amp, 300 Volt rated for signal
• AWM or tray rated-exposed run PVC cable
• IEC IP67 protection
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 41
M23 powerfast™ Connectivity
M23 powerfast Cordset Part Number Key
Part Number Keys are to assist in IDENTIFICATION ONLY. Consult factory for catalog items not identified.
C K M
64-078 - *
/S..
M23 (23 mm) powerfast Cordset
Varieties
Gender
(blank) = PVC jacket
/S90
= PUR jacket
K
S
SS
= female contact holder, female threads
= male contact holder, female threads
= male contact holder, male threads
Length in Meters
Number of Wires / AWG / Color Codes
Configuration
64-078 = 6x14 AWG WH, RD, GN, OG, BK, BU
74-079 = 7x14 AWG WH/BK, BK, WH, RD, OG, BU, GN
94-080 = 3x14 & 6X18 AWG RD, WH, WH/BK, BU, OG, BK, GN/BK, GN, RD/BK
622-059 = 6x12 AWG BU, RD, GN, BN, OG, YE
822-287 = 4x12 & 4X18 AWG BU, GN, WH, BK, OG, RD, WH/BK, RD/BK
622-286 = 6x12 AWG BU, RD, GN, BN, OG, YE
822-288 = 4x12 & 4X18 AWG BU, GN, WH, BK, OG, RD, WH/BK, RD/BK
M
= straight
WM
= right angle
(blank) = straight assembled connector
Coupling Nut Material / Shielding
(blank) =nickel plated brass
V
= stainless steel
S
= shielded
Insertion Point of Extension Cable 2nd Prefix*
* Male connector listed 1st, female connector 2nd
Example: CSM CKM 64-078-1
Extension Examples:
C K M
C K M
C SS M
74-079 - *
C K M
/S..
622-059 - *
/S..
M23 powerfast Receptacle Part Number Key
C K F
64-6
M23 (23 mm) powerfast Receptacle
- *
Length in Meters
Gender
Number of Wires / AWG / Color Codes
K = female contact holder, male threads
S = male contact holder, male threads
64-6
74-7
94-9
622-6
822-8
Designator for Receptacle
= 6x14 AWG WH, RD, GN, OG, BK, BU
= 7x14 AWG WH/BK, BK, WH, RD, OG, BU, GN
= 3x14 & 6X18 AWG RD, WH, WH/BK, BU, OG, BK, GN/BK, GN, RD/BK
= 6x12 AWG BU, RD, GN, BN, OG, YE
= 4x12 & 4X18 AWG BU, GN, WH, BK, OG, RD, WH/BK, RD/BK
Mounting Style
(blank)
D
F
MF
L
42 B2300
= front mount
= rear mount
= flange
= flange, rotating coupling nut
= front mount, long threads
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M23 powerfast™ Connectivity
M23 powerfast Single Keyway Cordset Specifications
Mechanical
Electrical
Mold material/Color:
PUR/Black
Contact material:
Brass with gold plating
Contact carrier material:
Nylon or PBT
Cable jacket material/Color:
PVC/Yellow
Coupling nut material:
Standard:
Additional options:
Ratings:
Nickel plated brass
316 stainless steel
Environmental Protection:
IEC IP67
Temperature Rating:
-40 to +105°C (-40 to +221°F)
Power:
Signal:
20 Amps, 300 V
8 Amps, 150 V
M23 powerfast 3-Key Cordset Specifications
Mechanical
Electrical
Mold material/Color:
PUR/Black
Contact material:
Brass with gold plating
Contact carrier material:
Nylon or PBT
Cable jacket material/Color:
TC-ER PVC/Yellow
Ratings:
Nickel plated brass
Environmental Protection:
IEC IP67
Temperature Rating:
-40 to +90°C (-40 to +194°F)
Power:
Signal:
30 Amps, 600 V
9 Amps, 300 V
M23 powerfast
Coupling nut material:
Standard:
M23 powerfast Single Keyway Receptacle Specifications
Mechanical
Contact carrier material:
Electrical
Nylon or PBT
Housing material/Plating:
Standard:
Additional options:
Nickel plated brass
316 stainless steel
Environmental Protection:
IEC IP67
Temperature Rating:
-30 to +90°C (-40 to +194°F)
Contact material:
Brass with gold plating
Conductor insulation:
PVC
Ratings:
Power:
Signal:
20 Amps, 300 V
8 Amps, 150 V
M23 powerfast 3-Key Receptacle Specifications
Mechanical
Electrical
Contact carrier material:
Nylon or PBT
Housing material/Plating:
Standard:
Nickel plated brass
Environmental Protection:
IEC IP67
Temperature Rating:
-30 to +80°C (-40 to +176°F)
Contact material:
Brass with gold plating
Conductor insulation:
PVC
Ratings:
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
Power:
Signal:
30 Amps, 600 V
9 Amps, 300 V
B2300 43
M23 powerfast™ Connectivity
M23 powerfast Single Keyway Cordset Selection Matrix
1
1
2
Straight Female
Straight Male
Straight Male
Pins
AWG
Current Rating
Single Keyway
Single Keyway
Single Keyway
6
14
20 Amps
CKM 64-078-*
CSM 64-078-*
CSSM 64-078-*
7
14
20 Amps
CKM 74-079-*
CSM 74-079-*
CSSM 74-079-*
9
3x14; 6x18
8 Amps (1-3,5,7,9), 20 Amps (4,6,8)
CKM 94-080-*
CSM 94-080-*
CSSM 94-080-*
M23 powerfast 3-Key Cordset Selection Matrix
3
Pins
AWG
4
5
6
Straight Female
Straight Male
Right Angle Female
Right Angle Male
Current Rating
3-Key
3-Key
3-Key
3-Key
6
12
30 Amps
CKM 622-059-*
CSSM 622-059-*
CKWM 622-059-*
CSSWM 622-059-*
8
4x12; 4x18
9 Amps (A-D), 30 Amps (1-4)
CKM 822-287-*
CSSM 822-287-*
CKWM 822-287-*
CSSWM 822-287-*
Pins
AWG
Current Rating
Shielded 3-Key
Shielded 3-Key
Shielded 3-Key
Shielded 3-Key
6
12
30 Amps
CKMS 622-286-*
CSSMS 622-286-*
CKWMS 622-286-*
CSSWMS 622-286-*
8
4x12; 4x18
9 Amps (A-D), 30 Amps (1-4)
CKMS 822-288-*
CSSMS 822-288-*
CKWMS 822-288-*
CSSWMS 822-288-*
M23 powerfast Single Keyway Receptacle Selection Matrix
7
7
8
8
Front Mount
Female
Male
Female
Male
Pins
AWG
Current Rating
M20 Mount,
Standard Thread
M20 Mounting,
Standard Thread
M20 Mounting,
Long Thread
M20 Mounting,
Long Thread
6
14
20 Amps
CKF 64-6-*
CSF 64-6-*
CKFL 64-6-*
CSFL 64-6-*
7
14
20 Amps
CKF 74-7-*
CSF 74-7-*
CKFL 74-7-*
CSFL 74-7-*
9
3x14; 6x18
8 Amps (1-3,5,7,9), 20 Amps (4,6,8)
CKF 94-9-*
CSF 94-9-*
CKFL 94-9-*
CSFL 94-9-*
M23 powerfast 3-Key Receptacle Selection Matrix
9
10
11
Front Mount
Female
Male
Male
Pins
AWG
Current Rating
Flange Mount
Flange Mount
M20 Mounting Thread
6
12
30 Amps
CKFMF 622-6-*
CSFF 622-6-*
CSF 622-6-*
8
4x12; 4x18
9 Amps (A-D), 30 Amps (1-4)
CKFMF 822-8-*
CSFF 822-8-*
CSF 822-8-*
See pages 45-46 for dimensional drawings.
* Length in meters. Standard cable lengths are 2, 5 and 10 meters. Standard lead length is 0.5 meters. Consult factory for other lengths.
Note: Extension cables are available, please consult Part Number Key (page 42).
Standard coupling nut and housing material is nickel plated brass. Consult Part Number Key (page 42) for 316 stainless steel options.
44 B2300
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
M23 powerfast™ Connectivity
M23 powerfast Single Keyway Cordset Dimensions
1
CKM (CSM)..
2
CSSM..
M23 powerfast 3-Key Cordset Dimensions
CKM..
4
CSSM..
5
CKWM..
6
CSSWM..
8
CKFL (CSFL) ..
M23 powerfast
3
M23 powerfast Single Keyway Receptacle Dimensions
7
CKF (CSF)..
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
B2300 45
M23 powerfast™ Connectivity
M23 powerfast 3-Key Receptacle Dimensions
9
CKFMF..
10
11
CSFF..
CSF..
M23 powerfast Single Keyway Cordset and Receptacle Pinouts
6-Pin
Female
Pinouts
Male
1.
2.
3.
4.
5.
6.
9-Pin
Female
7-Pin
Female
Pinouts
Male
1.
2.
3.
4.
5.
6.
7.
WH
RD
GN
OG
BK
BU
WH/BK
BK
WH
RD
OG
BU
GN
Pinouts
Male
1.
2.
3.
4.
5.
6.
7.
8.
9.
RD
WH
WH/BK
BU
OG
BK
GN/BK
GN
RD/BK
M23 powerfast 3-Key Cordset and Receptacle Pinouts
6-Pin, 3-Key
Female
Pinouts
Male
1. BU
2. RD
^. GN
4. BN
5. OG
6. YE
46 B2300
8-Pin, 3-Key
Female
Pinouts
Male
1. BU
^. GN
3. WH
4. BK
A. OG
B. RD
C. WH/BK
D. RD/BK
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
powerfast™ Connectivity
BH-BKM/BSM/2BKM 22 . . . . . . . .
BH-BKM/BSM/2BKM 22-380-* . . . .
BH-BKM/BSM/2BKM 22-380-*/*/*/*
BH-BKM/BSM/2BKM 34 . . . . . . . .
BH-BKM/BSM/2BKM 34-198-* . . . .
BH-BKM/BSM/2BKM 34-198-*/*/*/*
BH-BKM/BSM/2BKM 44 . . . . . . . .
BH-BKM/BSM/2BKM 44-193-* . . . .
BH-BKM/BSM/2BKM 44-193-*/*/*/*
BH-BSM/3BKM 22 . . . . . . . . . . .
BH-BSM/3BKM 22-380-* . . . . . . .
BH-BSM/3BKM 22-380-*/*/*/* . . . .
BH-BSM/3BKM 34 . . . . . . . . . . .
BH-BSM/3BKM 34-198-* . . . . . . .
BH-BSM/3BKM 34-198-*/*/*/* . . . .
BH-BSM/3BKM 44 . . . . . . . . . . .
BH-BSM/3BKM 44-193-* . . . . . . .
BH-BSM/3BKM 44-193-*/*/*/* . . . .
BKF 22-*/14.5/NPT . . . . . . . . . . .
BKF 22-*/18.375/NPT . . . . . . . . .
BKF 22-*/M18 . . . . . . . . . . . . . .
BKF 22-*/M20 . . . . . . . . . . . . . .
BKF 34-*/14.5/NPT . . . . . . . . . . .
BKF 34-*/18.375/NPT . . . . . . . . .
BKF 34-*/M18 . . . . . . . . . . . . . .
BKF 34-*/M20 . . . . . . . . . . . . . .
BKF 44-*/14.5/NPT . . . . . . . . . . .
BKF 44-*/18.375/NPT . . . . . . . . .
BKF 44-*/M18 . . . . . . . . . . . . . .
BKF 44-*/M20 . . . . . . . . . . . . . .
BKF-CC . . . . . . . . . . . . . . . . . .
BKFD 22-*/M18 . . . . . . . . . . . . .
BKFD 34-*/M18 . . . . . . . . . . . . .
BKFD 44-*/M18 . . . . . . . . . . . . .
BKM 22-380-* . . . . . . . . . . . . . .
BKM 34-198-* . . . . . . . . . . . . . .
BKM 44-193-* . . . . . . . . . . . . . .
BKM-CC . . . . . . . . . . . . . . . . . .
BKM-MC . . . . . . . . . . . . . . . . .
BKMS 22-1759-* . . . . . . . . . . . .
BKMS 34-1364-* . . . . . . . . . . . .
BKWM 22-380-*. . . . . . . . . . . . .
BKWM 34-198-*. . . . . . . . . . . . .
BKWM 44-193-*. . . . . . . . . . . . .
BKWMS 22-1759-* . . . . . . . . . . .
BKWMS 34-1364-* . . . . . . . . . . .
BSF 22-*/14.5/NPT . . . . . . . . . . .
BSF 22-*/18.375/NPT . . . . . . . . .
BSF 22-*/M18 . . . . . . . . . . . . . .
BSF 22-*/M20 . . . . . . . . . . . . . .
BSF 34-*/14.5/NPT . . . . . . . . . . .
BSF 34-*/18.375/NPT . . . . . . . . .
BSF 34-*/M18 . . . . . . . . . . . . . .
BSF 34-*/M20 . . . . . . . . . . . . . .
BSF 44-*/14.5/NPT . . . . . . . . . . .
BSF 44-*/18.375/NPT . . . . . . . . .
BSF 44-*/M18 . . . . . . . . . . . . . .
BSF 44-*/M20 . . . . . . . . . . . . . .
BSFD 22-*/M18 . . . . . . . . . . . . .
BSFD 34-*/M18 . . . . . . . . . . . . .
BSFD 44-*/M18 . . . . . . . . . . . . .
BSK-CC . . . . . . . . . . . . . . . . . .
BSM 22-380-* . . . . . . . . . . . . . .
BSM 34-198-* . . . . . . . . . . . . . .
BSM 44-193-* . . . . . . . . . . . . . .
BSM/2BKM 22 . . . . . . . . . . . . . .
BSM/2BKM 22-380-* . . . . . . . . . .
BSM/2BKM 22-380-*/*/* . . . . . . .
BSM/2BKM 34 . . . . . . . . . . . . . .
BSM/2BKM 34-198-* . . . . . . . . . .
BSM/2BKM 34-198-*/*/* . . . . . . .
BSM/2BKM 44 . . . . . . . . . . . . . .
BSM/2BKM 44-193-* . . . . . . . . . .
BSM/2BKM 44-193-*/*/* . . . . . . .
BSM/BKM/T22-380-*. . . . . . . . . .
BSM/BKM/T34-198-*. . . . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
29
29
29
29
29
29
29
29
29
29
29
29
40
29
29
29
28
28
28
40
40
28
28
28
28
28
28
28
29
29
29
29
29
29
29
29
29
29
29
29
29
29
29
40
28
28
28
32
32
32
32
32
32
32
32
32
32
32
BSM/BKM/T44-193-*. . .
BSM-CC . . . . . . . . . . .
BSM-MC . . . . . . . . . .
BSMS 22-1759-*. . . . . .
BSMS 34-1364-*. . . . . .
BSWM 22-380-* . . . . . .
BSWM 34-198-* . . . . . .
BSWM 44-193-* . . . . . .
BSWMS 22-1759-* . . . .
BSWMS 34-1364-* . . . .
CKF 64-6-* . . . . . . . . .
CKF 74-7-* . . . . . . . . .
CKF 94-9-* . . . . . . . . .
CKFL 64-6-* . . . . . . . .
CKFL 74-7-* . . . . . . . .
CKFL 94-9-* . . . . . . . .
CKFMF 622-6-* . . . . . .
CKFMF 822-8-* . . . . . .
CKM 622-059-* . . . . . .
CKM 64-078-* . . . . . . .
CKM 74-079-* . . . . . . .
CKM 822-287-* . . . . . .
CKM 94-080-* . . . . . . .
CKMS 622-059-* . . . . .
CKMS 822-287-* . . . . .
CKWM 622-059-* . . . . .
CKWM 822-287-* . . . . .
CKWMS 622-059-* . . . .
CKWMS 822-287-* . . . .
CSF 622-6-* . . . . . . . .
CSF 64-6-* . . . . . . . . .
CSF 74-7-* . . . . . . . . .
CSF 822-8-* . . . . . . . .
CSF 94-9-* . . . . . . . . .
CSFF 622-6-*. . . . . . . .
CSFF 822-8-*. . . . . . . .
CSFL 64-6-* . . . . . . . .
CSFL 74-7-* . . . . . . . .
CSFL 94-9-* . . . . . . . .
CSM 64-078-* . . . . . . .
CSM 74-079-* . . . . . . .
CSM 94-080-* . . . . . . .
CSSM 622-059-* . . . . .
CSSM 64-078-* . . . . . .
CSSM 74-079-* . . . . . .
CSSM 822-287-* . . . . .
CSSM 94-080-* . . . . . .
CSSMS 622-059-*. . . . .
CSSMS 822-287-*. . . . .
CSSWM 622-059-* . . . .
CSSWM 822-287-* . . . .
CSSWMS 622-059-* . . .
CSSWMS 822-287-* . . .
GKDF 30-*M/14.5/NPT .
GKDF 30-*M/14.75/NPT.
GKDF 32-*M/14.5/NPT .
GKDF 32-*M/14.75/NPT.
GKDF 34-*M/14.5/NPT .
GKDF 34-*M/14.75/NPT.
GKDF 40-*M/14.5/NPT .
GKDF 40-*M/14.75/NPT.
GKDF 42-*M/14.5/NPT .
GKDF 42-*M/14.75/NPT.
GKDF 44-*M/14.5/NPT .
GKDF 44-*M/14.75/NPT.
GKDF-CC . . . . . . . . . .
GKDM 30-*M . . . . . . .
GKDM 30-*M/S4000 . . .
GKDM 30-0. . . . . . . . .
GKDM 32-*M . . . . . . .
GKDM 32-*M/S4000 . . .
GKDM 34-*M . . . . . . .
GKDM 34-*M/S4000 . . .
GKDM 40-*M . . . . . . .
GKDM 40-*M/S4000 . . .
GKDM 40-0. . . . . . . . .
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
32
40
40
28
28
28
28
28
28
28
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
44
14
14
14
14
14
14
14
14
14
14
14
14
23
13
13
14
13
13
13
13
13
13
14
GKDM 42-*M . . . . . . . . . . . .
GKDM 42-*M/S4000 . . . . . . . .
GKDM 44-*M . . . . . . . . . . . .
GKDM 44-*M/S4000 . . . . . . . .
GKDM-CC . . . . . . . . . . . . . .
GKDM-MC . . . . . . . . . . . . . .
GKDWM 30-*M . . . . . . . . . . .
GKDWM 30-*M/S4000. . . . . . .
GKDWM 32-*M . . . . . . . . . . .
GKDWM 32-*M/S4000. . . . . . .
GKDWM 34-*M . . . . . . . . . . .
GKDWM 34-*M/S4000. . . . . . .
GKDWM 40-*M . . . . . . . . . . .
GKDWM 40-*M/S4000. . . . . . .
GKDWM 42-*M . . . . . . . . . . .
GKDWM 42-*M/S4000. . . . . . .
GKDWM 44-*M . . . . . . . . . . .
GKDWM 44-*M/S4000. . . . . . .
GSDF 30-*M/14.5/NPT . . . . . .
GSDF 30-*M/14.75/NPT. . . . . .
GSDF 32-*M/14.5/NPT . . . . . .
GSDF 32-*M/14.75/NPT. . . . . .
GSDF 34-*M/14.5/NPT . . . . . .
GSDF 34-*M/14.75/NPT. . . . . .
GSDF 40-*M/14.5/NPT . . . . . .
GSDF 40-*M/14.75/NPT. . . . . .
GSDF 42-*M/14.5/NPT . . . . . .
GSDF 42-*M/14.75/NPT. . . . . .
GSDF 44-*M/14.5/NPT . . . . . .
GSDF 44-*M/14.75/NPT. . . . . .
GSDF-CC . . . . . . . . . . . . . . .
GSDM 30-*M. . . . . . . . . . . . .
GSDM 30-*M/S4000 . . . . . . . .
GSDM 30-0. . . . . . . . . . . . . .
GSDM 32-*M. . . . . . . . . . . . .
GSDM 32-*M/S4000 . . . . . . . .
GSDM 34-*M. . . . . . . . . . . . .
GSDM 34-*M/S4000 . . . . . . . .
GSDM 40-*M. . . . . . . . . . . . .
GSDM 40-*M/S4000 . . . . . . . .
GSDM 40-0. . . . . . . . . . . . . .
GSDM 42-*M. . . . . . . . . . . . .
GSDM 42-*M/S4000 . . . . . . . .
GSDM 44-*M. . . . . . . . . . . . .
GSDM 44-*M/S4000 . . . . . . . .
GSDM BKM 34-0 . . . . . . . . . .
GSDM BKM 44-0 . . . . . . . . . .
GSDM RKM 34-0 . . . . . . . . . .
GSDM RKM 44-0 . . . . . . . . . .
GSDM/2GKDM 30 . . . . . . . . .
GSDM/2GKDM 30-* . . . . . . . .
GSDM/2GKDM 30-*/S4000. . . .
GSDM/2GKDM 32-* . . . . . . . .
GSDM/2GKDM 32-*/S4000. . . .
GSDM/2GKDM 34-* . . . . . . . .
GSDM/2GKDM 34-*/S4000. . . .
GSDM/2GKDM 40 . . . . . . . . .
GSDM/2GKDM 40-* . . . . . . . .
GSDM/2GKDM 40-*/S4000. . . .
GSDM/2GKDM 42-* . . . . . . . .
GSDM/2GKDM 42-*/S4000. . . .
GSDM/2GKDM 44-* . . . . . . . .
GSDM/2GKDM 44-*/S4000. . . .
GSDM/GKDM/BKM 34-*/S4000 .
GSDM/GKDM/BKM 44-*/S4000 .
GSDM/GKDM/RKM 34-* . . . . .
GSDM/GKDM/RKM 34-*/S4000 .
GSDM/GKDM/RKM 44-* . . . . .
GSDM/GKDM/RKM 44-*/S4000 .
GSDM/GKDM/T30-* . . . . . . . .
GSDM/GKDM/T30-*/S4000 . . .
GSDM/GKDM/T32-* . . . . . . . .
GSDM/GKDM/T32-*/S4000 . . .
GSDM/GKDM/T34-* . . . . . . . .
GSDM/GKDM/T34-*/S4000 . . .
GSDM/GKDM/T40-* . . . . . . . .
www.turck.us · 1-800-544-7769 · Fax: (763) 553-0708 · TURCK Inc. Minneapolis, MN 55441
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
13
13
13
13
23
23
13
13
13
13
13
13
13
13
13
13
13
13
14
14
14
14
14
14
14
14
14
14
14
14
23
13
13
14
13
13
13
13
13
13
14
13
13
13
13
18
18
18
18
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
GSDM/GKDM/T40-*/S4000 . . . . . . . . 17
GSDM/GKDM/T42-* . . . . . . . . . . . . . 17
GSDM/GKDM/T42-*/S4000 . . . . . . . . 17
GSDM/GKDM/T44-* . . . . . . . . . . . . . 17
GSDM/GKDM/T44-*/S4000 . . . . . . . . 17
GSDM-CC. . . . . . . . . . . . . . . . . . . . 23
GSDM-MC . . . . . . . . . . . . . . . . . . . 23
GSDWM 30-*M . . . . . . . . . . . . . . . . 13
GSDWM 30-*M/S4000. . . . . . . . . . . . 13
GSDWM 32-*M . . . . . . . . . . . . . . . . 13
GSDWM 32-*M/S4000. . . . . . . . . . . . 13
GSDWM 34-*M . . . . . . . . . . . . . . . . 13
GSDWM 34-*M/S4000. . . . . . . . . . . . 13
GSDWM 40-*M . . . . . . . . . . . . . . . . 13
GSDWM 40-*M/S4000. . . . . . . . . . . . 13
GSDWM 42-*M . . . . . . . . . . . . . . . . 13
GSDWM 42-*M/S4000. . . . . . . . . . . . 13
GSDWM 44-*M . . . . . . . . . . . . . . . . 13
GSDWM 44-*M/S4000. . . . . . . . . . . . 13
LOCK-A POWER. . . . . . . . . . . . . . . . . 8
LOCK-D POWER. . . . . . . . . . . . . . . . 24
RKF 34-*M/NPT . . . . . . . . . . . . . . . . . 5
RKF 44-*M/NPT . . . . . . . . . . . . . . . . . 5
RKF-CC . . . . . . . . . . . . . . . . . . . . . . 7
RKF-MC . . . . . . . . . . . . . . . . . . . . . . 7
RKFV-CC . . . . . . . . . . . . . . . . . . . . . 7
RKFV-MC . . . . . . . . . . . . . . . . . . . . . 7
RKM 34-*M . . . . . . . . . . . . . . . . . . . 5
RKM 34-*M/S4000 . . . . . . . . . . . . . . . 5
RKM 44-*M . . . . . . . . . . . . . . . . . . . 5
RKM 44-*M/S4000 . . . . . . . . . . . . . . . 5
RKM-CC. . . . . . . . . . . . . . . . . . . . . . 7
RKMV-CC. . . . . . . . . . . . . . . . . . . . . 7
RSF 34-*M/NPT . . . . . . . . . . . . . . . . . 5
RSF 44-*M/NPT . . . . . . . . . . . . . . . . . 5
RSF-CC . . . . . . . . . . . . . . . . . . . . . . 7
RSF-MC . . . . . . . . . . . . . . . . . . . . . . 7
RSFV-CC . . . . . . . . . . . . . . . . . . . . . 7
RSFV-MC . . . . . . . . . . . . . . . . . . . . . 7
RSM 34-*M. . . . . . . . . . . . . . . . . . . . 5
RSM 34-*M/S4000 . . . . . . . . . . . . . . . 5
RSM 44-*M. . . . . . . . . . . . . . . . . . . . 5
RSM 44-*M/S4000 . . . . . . . . . . . . . . . 5
RSM-CC. . . . . . . . . . . . . . . . . . . . . . 7
RSMV-CC . . . . . . . . . . . . . . . . . . . . . 7
SH-BKM/BSM/BKM 22 . . . . . . . . . . . . 32
SH-BKM/BSM/BKM 22-380-* . . . . . . . . 32
SH-BKM/BSM/BKM 22-380-*/*/* . . . . . 32
SH-BKM/BSM/BKM 34 . . . . . . . . . . . . 32
SH-BKM/BSM/BKM 34-198-* . . . . . . . . 32
SH-BKM/BSM/BKM 34-198-*/*/* . . . . . 32
SH-BKM/BSM/BKM 44 . . . . . . . . . . . . 32
SH-BKM/BSM/BKM 44-193-* . . . . . . . . 32
SH-BKM/BSM/BKM 44-193-*/*/* . . . . . 32
SH-BKM/BSM/T22-380-* . . . . . . . . . . 32
SH-BKM/BSM/T34-198-* . . . . . . . . . . 32
SH-BKM/BSM/T44-193-* . . . . . . . . . . 32
SH-BSM/2BKM 22 . . . . . . . . . . . . . . 32
SH-BSM/2BKM 22-380-* . . . . . . . . . . 32
SH-BSM/2BKM 22-380-*/*/* . . . . . . . . 32
SH-BSM/2BKM 34 . . . . . . . . . . . . . . 32
SH-BSM/2BKM 34-198-* . . . . . . . . . . 32
SH-BSM/2BKM 34-198-*/*/* . . . . . . . . 32
SH-BSM/2BKM 44 . . . . . . . . . . . . . . 32
SH-BSM/2BKM 44-193-* . . . . . . . . . . 32
SH-BSM/2BKM 44-193-*/*/* . . . . . . . . 32
SH-BSM/BKM/T22-380-* . . . . . . . . . . 32
SH-BSM/BKM/T34-198-* . . . . . . . . . . 32
SH-BSM/BKM/T44-193-* . . . . . . . . . . 32
WKM 34-*M/S4000 . . . . . . . . . . . . . . 5
WKM 44-*M/S4000 . . . . . . . . . . . . . . 5
WSM 34-*M/S4000. . . . . . . . . . . . . . . 5
WSM 44-*M/S4000. . . . . . . . . . . . . . . 5
B2300 47
Index
Index
USA
MEXICO
TURCK MEXICO S. DE R.L. DE C.V.
Carr. Saltillo-Zacatecas km 4.5 s/n
Parque Industrial “La Angostura”
Saltillo, COAH. C.P. 25070
Mexico
Phone: +52 (844) 411-6650/46
Fax: +52 (844) 482-6926
Local Toll Free: 01-800-01-88725
E-mail:[email protected]
CANADA
Chartwell Automation Inc.
140 Duffield Drive
Markham, Ontario
Canada, L6G 1B5
Phone: (905) 513-7100
Fax: (905) 513-7101
Toll Free: 1-877-513-7769
AUSTRALIA
TURCK Australia Pty. Ltd.
Unit 5, 6-7 Gilda Court
Mulgrave, Victoria 3170
Australia
Phone: (+61) 3 9560 9066
Fax: (+61) 3 9560 1620
Local Toll Free: 1300 132566
E-mail:[email protected]
GERMANY
WORLD HEADQUARTERS
Hans TURCK GmbH & Co. KG
Witzlebenstrasse 7
D-45472 Muelheim an der Ruhr
Federal Republic of Germany
Phone: (+49) 208-49 52-0
Fax: (+49) 208-49 52 264
Printed in USA
©2010 by TURCK Inc. All rights reserved. No part of the
publication may be reproduced without written permission.
www.turck.com
TURCK Inc.
3000 Campus Drive
Minneapolis, MN 55441
Phone: (763) 553-7300
Fax: (763) 553-0708
Application Support:
1-800-544-7769
E-mail:[email protected]
www.turck.us
B2300
8/10
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
