4-461-833-61(1)
Personal Audio System
Operating Instructions GB
This symbol on the product or on its packaging
indicates that this product shall not be treated as
household waste. Instead it shall be handed over
to the applicable collection point for the recycling
of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you
will help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate waste
handling of this product. The recycling of
materials will help to conserve natural resources.
For more detailed information about recycling of
this product, please contact your local Civic
Office, your household waste disposal service or
the shop where you purchased the product.
Applicable accessory: Remote control
Disposal of waste batteries
(applicable in the European
Union and other European
countries with separate
collection systems)
This symbol on the battery or on the packaging
indicates that the battery provided with this
product shall not be treated as household waste.
On certain batteries this symbol might be used in
combination with a chemical symbol. The
chemical symbols for mercury (Hg) or lead (Pb)
are added if the battery contains more than
0.0005% mercury or 0.004% lead.
By ensuring these batteries are disposed of
correctly, you will help prevent potentially
negative consequences for the environment and
human health which could otherwise be caused
by inappropriate waste handling of the battery.
The recycling of the materials will help to
conserve natural resources.
©2013 Sony Corporation
In case of products that for safety, performance or
data integrity reasons require a permanent
connection with an incorporated battery, this
battery should be replaced by qualified service
staff only.
To ensure that the battery will be treated properly,
hand over the product at end-of-life to the
applicable collection point for the recycling of
electrical and electronic equipment.
Printed in China
RDP-M7iPN
WARNING
To reduce the risk of fire or electric
shock, do not expose this apparatus to
rain or moisture.
To reduce the risk of fire, do not cover the
ventilation of the apparatus with newspapers,
tablecloths, curtains, etc. And do not place lighted
candles on the apparatus.
To reduce the risk of fire or electric shock, do not
expose this apparatus to dripping or splashing,
and do not place objects filled with liquids, such
as vases, on the apparatus.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
Do not expose the batteries (battery pack or
batteries installed) to excessive heat such as
sunshine, fire or the like for a long time.
As the main plug of AC adaptor is used to
disconnect the AC adaptor from the mains,
connect it to an easily accessible AC outlet.
Should you notice an abnormality in it,
disconnect it from the AC outlet immediately.
The unit is not disconnected from the AC power
source (mains) as long as it is connected to the wall
outlet, even if the unit itself has been turned off.
The nameplate and important information
concerning safety are located on the bottom
exterior of the main unit and on the surface of the
AC adaptor.
CAUTION
Danger of explosion if battery is incorrectly
replaced. Replace only with the same type.
Notice for customers: the following
information is only applicable to equipment
sold in countries applying EU directives
This product has been manufactured by or on
behalf of Sony Corporation, 1-7-1 Konan Minatoku Tokyo, 108-0075 Japan. Inquiries related to
product compliance based on European Union
legislation shall be addressed to the authorized
representative, Sony Deutschland GmbH,
Hedelfinger Strasse 61, 70327 Stuttgart, Germany.
For any service or guarantee matters, please refer
to the addresses provided in the separate service
or guarantee documents.
Precautions
To disconnect AC power, grasp the plug itself,
not the cord.
Since a strong magnet is used for the speaker,
keep credit cards using magnetic coding or
spring-wound watches, CRT-based TVs, or
projectors, etc., away from the unit to prevent
possible damage from the magnet.
Do not leave the unit in a location near a heat
source such as a radiator or airduct, or in a
place subject to direct sunlight, excessive dust,
mechanical vibration, or shock.
Allow adequate air circulation to prevent
internal heat build-up. Do not place the unit on
a surface (a rug, a blanket, etc.) or near
materials (a curtain) which might block the
ventilation holes.
Should any solid object or liquid fall into the
unit, unplug the unit and have it checked by
qualified personnel before operating it any
further.
Do not touch the unit with wet hands.
Do not place the unit anywhere near water.
NOTES ON LITHIUM BATTERY
Wipe the battery with a dry cloth to assure a
good contact.
Be sure to observe the correct polarity when
installing the battery.
Do not hold the battery with metallic tweezers,
otherwise a short-circuit may occur.
Note
In the Operating Instructions, “iPod” is used as
a general reference to functions on an iPod or
iPhone, unless otherwise specified by the text
or illustrations.
For all other batteries, please view the section on
how to remove the battery from the product
safely. Hand the battery over to the applicable
collection point for the recycling of waste
batteries.
For more detailed information about recycling of
this product or battery, please contact your local
Civic Office, your household waste disposal
service or the shop where you purchased the
product.
If you have any questions or problems concerning
your unit, please consult your nearest Sony dealer.
General
Information
Troubleshooting
General
There is no power.
Make sure the AC adaptor is connected to the
wall outlet firmly.
Make sure the batteries are inserted correctly.
Replace all the batteries with new ones if they
are weak.
There is no sound.
Adjust VOLUME +/− (VOL +/− on the remote).
There is noise.
Make sure that the unit is not in the vicinity of
in-use portable phones, etc.
If you use an audio connecting cable,
disconnect the cable when it is not in use.
Two different music sources are mixed
together during playback.
Stop playback of either the iPod or the optional
component.
The OPR/BATT indicator flashes.
The OPR/BATT indicator flashes when the unit
receives a signal from the remote, or when the
batteries are weak. In these cases, the flashing
does not mean there is an error or fault.
iPod
There is no sound.
Make sure the iPod is connected firmly.
An operation is not performed.
Make sure the iPod is connected firmly.
Check that the iPod is compatible with this unit
(see “Compatible iPod/iPhone models”).
The iPod does not charge.
Make sure the iPod is connected firmly.
Make sure the AC adaptor is connected firmly.
Check that the iPod is compatible with this unit
(see “Compatible iPod/iPhone models”).
Audio-in
There is no sound.
Make sure the audio connecting cable is
connected firmly.
Make sure that the connected component is on
playback status.
The sound is low.
Check the volume of the connected optional
component.
Remote control
The remote does not function.
Replace the battery in the remote with a new
one if it is weak.
Make sure that you are pointing the remote at
the remote sensor on the unit.
Do not cover or place any objects just in front
of the receiver.
Remove any obstacles in the path of the remote
and the unit.
Make sure the remote sensor is not exposed to
strong light such as direct sunlight or
fluorescent lamp light.
If the problem persists, consult your nearest Sony dealer.
Specifications
iPod
Rated voltage: DC 5 V
Rated current: Max. 1 A
General
Speaker
Approx. 50 mm dia. × 2
Input
AUDIO IN jack (ø 3.5 mm stereo minijack)
Input impedance: 10 kΩ
Standard input level: 245 mV
Power output
2 W + 2 W (at 10% harmonic distortion)
Power source
Rated external power source: DC IN 6V, 1.3 A
(With supplied AC adaptor (AC 230 V, 50 Hz)) or
4 × AAA/LR03 type batteries
Battery life:
Approx. 10 hours (Sony manufactured AAA/
LR03 alkaline batteries)
Approx. 8 hours (Sony manufactured NH-AAA
rechargeable batteries)
Dimensions
Approx. 226 mm × 165 mm × 151 mm (w/h/d)
(Including projecting parts and controls)
Mass
Approx. 1.1 kg (Including batteries)
Supplied accessories
AC adaptor (1)
Remote control (with a lithium battery) (1)
Operating Instructions (1)
Design and specifications are subject to change
without notice.
Continued on the reverse side
iPod 
− VOLUME +
/
Startup Guide
OPR/BATT indicator

ENTER
Execute the selected menu item or begin
playback.
To remove the iPod
VOL +/– (Volume plus/minus)
Adjust the volume.
Press VOLUME +/− (VOL +/− on the remote).
Tip
The OPR/BATT indicator flashes three times
when the sound is set to either maximum or
minimum volume.
Note
Some operations may differ or may not be
available for different models of iPod.
Remote sensor
When to replace the battery
Dock connector
With normal use, battery life (CR2025) should
last for about 6 months. When the remote can no
longer operate the unit, replace the battery with a
new one.
 side facing up
The VOLUME + and  buttons have a tactile dot.
AAA/LR03 × 4 *
Operations
How to handle an iPod
To set an iPod

To remove an iPod
To use batteries
Insert four AAA/LR03 alkaline batteries, or four
NH-AAA rechargeable batteries (not supplied).
When to replace the batteries
When the batteries are weak, the OPR/BATT
indicator will become faint, and the sound may be
distorted.
Notes on batteries
Manganese batteries cannot be used.
The unit cannot recharge any batteries.
Do not carry batteries with coins or other
metallic objects. It can generate heat if the
positive and negative terminals of the batteries
are accidentally contacted by a metallic object.
Be sure to observe the correct polarity when
installing the battery.
If you are not going to use the unit for a long
time, remove the batteries to avoid damage
from battery leakage and corrosion.
Do not use different types of batteries at the
same time.
When you replace the batteries, replace all of
them with new ones.
Battery performance depends on manufacturer
and type, and battery life may be reduced,
especially when used in low temperature.
Remote control
Before using the supplied remote for the first
time, remove the insulation film.
Aim the remote at the (Remote sensor) of the
unit.
The OPR/BATT indicator flashes when the
remote’s signal is received.

Notes
An iPod in a case or cover can be set in this
unit. However, if the case or cover interferes
with the connection, remove the case or cover
before setting the iPod on the dock connector.
When placing or removing the iPod, hold it at
the same angle as the dock connector on the
unit. Do not pull the iPod forward too far.
When placing or removing the iPod, hold the
unit securely.
Do not twist or bend the iPod as this may result
in connector damage.
Remove the iPod when transporting it;
otherwise, a malfunction may result.

Power source
You can use this unit with mains electricity or
with batteries.
Auto power off
After playback of an iPod (or component
connected to the AUDIO IN jack) has finished, if
no operation is performed for about 20 minutes,
the unit will automatically turn off.
To use AC adaptor
Alkaline battery
LR03
Manganese battery
R03
* Alkaline batteries are not supplied. Manganese batteries (R03) cannot be used. The unit
cannot recharge any batteries.
Connect the supplied AC adaptor to the DC IN
6V jack on the back of this unit firmly, and then
plug the adaptor into a wall outlet.
Note on the AC adaptor
When operating the unit with internal batteries,
remove the AC adaptor from the wall outlet
and the DC IN 6V jack. Make sure that the plug
of the external power source is disconnected
before operating the unit.
Use the supplied Sony AC adaptor only. The
polarity of the plugs of other manufacturers
may be different. Failure to use the supplied AC
adaptor may cause the unit to malfunction.
Note
If you are not going to use the remote for a long
time, remove the battery to avoid any damage
that may be caused by leakage and corrosion.
Compatible iPod/
iPhone models
The compatible iPod/iPhone models are as
follows.
Update the software of the iPod/iPhone to the
latest version before using it with this unit.
iPod touch (5th generation)
iPod nano (7th generation)*
iPhone 5
* The iPod nano (7th generation) cannot be
controlled by the remote when the command of
“MENU,” “,” “,” and “ENTER” is pressed.
On copyrights
­­
iPhone,
iPod, iPod nano, and iPod touch are
trademarks of Apple Inc., registered in the U.S.
and other countries.
Lightning is a trademark of Apple Inc.
“Made for iPod,” and “Made for iPhone” mean
that an electronic accessory has been designed to
connect specifically to iPod or iPhone,
respectively, and has been certified by the
developer to meet Apple performance standards.
Apple is not responsible for the operation of this
device or its compliance with safety and
regulatory standards. Please note that the use of
this accessory with iPod or iPhone may affect
wireless performance.
Note
This unit is not specified for use with an iPad,
and malfunction may result if used with one.
Operating an iPod
1 Set an iPod on the dock connector.
The dock connector can be tilted slightly.
For details, see “How to handle an iPod.”
2 Press .
The VOL + and  buttons have a tactile dot.
/ (On/Standby)
Turns the unit on/off. The OPR/BATT
indicator lights up when the unit is turned on.
When using batteries, press the / button on
the unit. The / button of the remote works
only when the AC adaptor is used.
 (Play/Pause)
Start playing an iPod. Press again to pause/
resume playback.
 (Forward)
Go to the next track.
Press and hold while listening to the sound to
locate a desired point.
 (Backward)
Go back to the previous track. During
playback, this operation returns to the
beginning of the current track. To go back to
the previous track, press twice.
Press and hold while listening to the sound to
locate a desired point.
MENU
Go back to the previous menu.
 (Up)/ (Down)
Select a menu item or track for playback.
When using batteries, press / on the unit,
then press .
The iPod begins playback.
You can operate the connected iPod via this
unit or the iPod itself.
Notes
If a pop-up message appears on the display of
the iPod touch or iPhone, see “About App.”
If the battery of the iPod is extremely low,
charge it for a while before operation.
Sony cannot accept responsibility in the event
that data recorded to an iPod is lost or damaged
when using an iPod connected to this unit.
For details of environmental conditions for
operating the iPod, check the website of Apple
Inc.
For details, see “How to handle an iPod.”
To adjust the volume
To charge an iPod (AC only)
You can use the unit as a battery charger for an
iPod when the power is supplied by the AC adaptor.
Charging begins when the iPod is connected to
the unit. The charging status appears in the
display on the iPod. For details, refer to the user’s
guide of the iPod.
Connecting optional
components
You can enjoy the sound from an optional
component, such as a portable digital music
player, through the speakers of this unit. Be sure
to turn off the power of each component before
making any connections.
1 Firmly connect the line output jack of a
portable digital music player (or other
component) to the AUDIO IN jack on the
back of the unit, using a suitable audio
connecting cable (not supplied).
2 Press  to turn on the unit.
3 Turn the connected component on.
4 Play the connected component.
The sound from the connected component is
output from the speakers of this unit.
Notes
The necessary type of audio connecting cable
depends on the optional component. Make sure
to use the correct type of cable.
If the volume level is low, adjust the volume of
the unit first. If the volume is still too low,
adjust the volume of the connected component.
When playing an optional component
connected to the AUDIO IN jack, stop playback
of an iPod.
Disconnect the audio connecting cable from
the unit when it is not in use.
About App
A dedicated Dock App for iPod touch/iPhone
available at Apple App Store.
Search for “D-Sappli” and download the free App
to find out more about the functions.
Features
D-Sappli includes various timer functions:
Alarm, Music Play Timer, and Sleep Timer.
You can set up to 10 alarms, using songs in iPod
or Preset Sound in D-Sappli for the alarm
sound.
The Music Play Timer allows you to play/pause
desired music at a desired time. The Sleep
Timer allows you to specify a time at which to
stop music playback. The Music Play Timer and
Sleep Timer work in combination with the
power supply of the unit.
Music Play Timer, Sleep Timer and Alarm are
available only when D-Sappli is activated.
D-Sappli also includes a clock display enlarge
feature.
Notes
If the App to link with this unit is not
downloaded to your iPod touch/iPhone, a popup message prompting you to download DSappli may appear repeatedly.
Deactivate the App’s link function to stop the
pop-up message.
To deactivate the App’s link function: Connect
the AC adaptor, and then press / to turn off
the unit. Remove your iPod touch/iPhone from
the dock connector. While holding down ,
also press and hold / on the unit for at least 2
seconds. (The OPR/BATT indicator flashes
twice when the function is deactivated.)
To re-activate the App’s link function, repeat the
above steps. (The OPR/BATT indicator flashes
once when the function is activated.)
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
