Ducting DX high pressure direct expansion air conditioning

Ducting DX high pressure direct expansion air conditioning
direct expansion air conditioning
Ducting DX
high
pressure
•U
nit with static high pressure, ideal for commercial places and
offices.
➤ range
• 4 sizes : 7.1, 10, 12.5 and 14 kW.
• US kit : in 20 and 25 kW.
➤ Easy installation
• Reversible : heating and cooling mode.
• Available static pressure up to 70 Pa.
➤ advantages
• Adapted for large places.
• Automatic functioning mode of fan.
• Functioning up to – 20 °C in heating mode.
• Choice of temperature sensor in interior unit or in cabled control.
• Inverter.
• Air filter included.
• Reversible.
• Anti-smell cleaning and washing.
• Foresee an extract grille with filter.
➤ application
•R
eversible air conditioning for several rooms by ducting
network (ducts, diffusers).
KIT-F28DD2E5
3 CV
Models
Refrigerant
KIT-F34DD2E5
4 CV
KIT-F43DD2E5
5 CV
KIT-F50DD2E8
6 CV
KIT-200E1DPQ-1
KIT-250E1DPQ-1
R410A
R410A
R410A
R410A
R410A
kW
7,1 (2,1~7,5)
10 (4~12)
12,5 (4~13,5)
14 (4~16)
20,0 (10~22)
25,0 (12,5~27,5)
Heating power
kW
8 (2,2~8,5)
11,2 (4~13,5)
14 (4~15,5)
16 (4~18)
Coefficient of performance
cooling EER
3,01
3,27
3,01
2,77
3,21
2,81
Coefficient of performance
heating COP
3,42
3,41
3,21
3,30
3,41
3,28
Energic label
cooling
B
A
B
D
A
C
B
B
C
C
B
C
23,0 (11,5~25,3) 27,0 (13~29,7)
Energic label
heating
Available pressure
GV (Pa)
70
100
100
100
250
250
Air flow
(m3/h) GV
1 320
2 280
2 400
2 700
4 200
5 340
interior unit
(db(A))
41
45
45
45
45
45
exterior unit
(db(A))
35
48
48
48
57
57
Sound pressure (PV/GV)
Electric supply
V/Hz/phase
Positioning of electric connection
Electric connection between units
Nominal intensity
Absorbed power
230
230
230
400
400
400
exterior unit
exterior unit
exterior unit
exterior unit
exterior unit
exterior unit
4 x 1,5 to 2,5
4 x 1,5 to 2,5
4 x 1,5 to 2,5
4 x 1,5 to 2,5
4 x 1,5 to 2,5
4 x 1,5 to 2,5
cooling (A)
10,7
13,8
18,8
7,7
20
24,1
heating (A)
10,6
14,9
19,7
7,4
23
16,4
cooling (W)
2 360
3 060
4 150
5 060
6 230
8 580
8 220
heating (W)
2 340
3 280
4 360
4 850
6 740
interior unit
35
48
48
48
87
92
exterior unit
71
110
110
105
198
198
interior unit
290 x 1 100 x 500
360 x 1 100 x 550
360 x 1 100 x 650
360 x 1 100 x 650
1 400 x 450 x 900
1 400 x 450 x 900
exterior unit
795 x 900 x 320
1 340 x 900 x 320
1 340 x 900 x 320
1 340 x 900 x 320
930 x 1 680 x 735
930 x 1 680 x 765
liquid diameter
3/8
3/8
3/8
3/8
-
-
gas diameter
5/8
5/8
5/8
5/8
-
-
Initial load of refrigerant
g
2,35
3,3
3,3
3,5
-
-
Standard length without adding
refrigerant
m
30
30
30
30
-
-
Maximum total length
m
50
50
50
50
-
-
Maximum drop
m
30
30
30
30
-
-
Addition refrigerant
g/m
50
50
50
50
-
-
cooling (°C)
- 5/43
- 5/43
- 5/43
- 5/43
- 5/43
- 5/43
heating (°C)
- 20/24
- 20/24
- 20/24
- 20/24
- 15/15
- 15/15
Weight (kg)
Dimensions (L x H x P - mm)
Piping (inch)
Limits of outside
Guide created by France Air 2010 – All rights reserved.
www.france-air.com
629
ducting dx
high pressure
R410A
Cooling power
