RCA DVD Recorder/VCR Combo DVD VCR Combo User`s guide

DVD Recorder/VCR

Combo

User’s Guide

Important Disc Information

This Product Can Record on the Following

Disc Types:

DVD+R (2.4x, 4x, 8x, and 16x)

DVD+RW (2.4x and 4x)

This recorder cannot record on DVD-R or DVD-RW discs. Please make sure to purchase discs with the plus “+” symbol on the package.

Changing Entertainment. Again.

Important Information

CAUTION

RISK OF ELECTRIC

SHOCK DO NOT OPEN

This symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts.

This symbol indicates “dangerous voltage” inside the product that presents a risk of electric shock or personal injury.

This symbol indicates important instructions accompanying the product.

FCC INFORMATION

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect this equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This class B digital apparatus meets all requirements of the Canadian Interference – Causing Equipment

Regulations. This class B digital apparatus complies with Canadian CES-003.

Cet appareil numérique de la class B est conforme á la norme du NMB-003 du Canada.

WARNING

To reduce the risk of fi re or shock hazard, do not expose this DVD Recorder to rain or moisture.

CAUTION

THIS PRODUCT UTILIZES A LASER. USE OF

CONTROLS OR ADJUSTMENTS OR PERFORMANCE

OF PROCEDURES OTHER THAN THOSE SPECIFIED

HEREIN MAY RESULT IN HAZARDOUS RADIATION

EXPOSURE. DO NOT OPEN COVERS AND DO NOT

REPAIR YOURSELF. REFER SERVICING TO QUALIFIED

PERSONNEL.

CAUTION

FCC Regulations state that unauthorized changes or modifi cations to this equipment may void the user’s authority to operate it.

Note:

This DVD Recorder is designed and manufactured to respond to the Region Management Information. If the

Region number of a DVD disc does not correspond to the

Region number of this DVD Recorder this DVD Recorder cannot play the disc. The Region number for this DVD

Recorder is Region No 1.

Refer to the identifi cation/rating label located on the back panel of your product for its proper operating voltage.

Product Registration

Please fi ll out the product registration card and return it immediately. Returning the product registration card allows us to contact you if needed.

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. The numbers are located on the back of the

DVD Recorder.

Note:

This device is protected by U.S. patent numbers 4,631,603 and 4,577,216 and 4,819,098 and other intellectual property rights. The use of Macrovision’s copy protection technology in the device must be authorized by Macrovision and is intended for home and other limited pay-per-view uses only, unless otherwise authorized in writing by Macrovision.

Reverse engineering or disassembly is prohibited.

The apparatus shall not be exposed to dripping or splashing and that no objects fi lled with liquids, such as vases, shall be placed on the apparatus.

Model No. __________________________ Serial No. __________________________

Purchase Date: ___________________________________________________________

Dealer/Address/Phone: ____________________________________________________

Ventilation:

You must adequately ventilate the product. Make sure there is adequate space around the DVD

Recorder/VCR to provide proper air fl ow for ventilation. Also, do not block the cooling fan. See diagram.

The AC power cord is polarized (one blade is wider than the other) and only fi ts into AC outlets one way. If the plug won’t go into the outlet completely, turn the plug over and try to insert it the other way. If it still won’t fi t, contact a qualifi ed electrician to change the outlet or use a different one. Do not attempt to bypass this safety feature.

CLASS 1

LASER

PRODUCT
