Test and Measurement Calibration RF Audio / Video / Broadcast

Test and Measurement Calibration RF Audio / Video / Broadcast

Test and Measurement

Calibration

RF

Audio / Video / Broadcast

Automotive

Telecom

2013

RoHS www.pomonaelectronics.com

Professionals Trust

Pomona Performance

2

Table of Contents

For over half a century the name

Pomona Electronics has been synonymous with reliability and outstanding value.

52

Calibration Kit

We are proud to have built our

reputation for the delivery of quality products by using only the finest materials available and designing to match real world applications... where you live — everyday.

Pomona Electronics is proud to be there, at your side.

83

Audio/Video/Broadcast

www.pomonaelectronics.com

New Products

Jumper Test Leads and Terminal Jacks for

Nuclear Applications

Models 73084, 73085, 73086, 73087, 73088

Pomona two-part jumpers and connectors are helping nuclear power plants streamline testing procedures and improve human performance by providing a higher-level of quality, reliability and utility than what they were using before. By integrating a common set of connectors and a consistent color scheme into their procedures and peer check processes, plant technicians reduce the risk of placing jumpers on the wrong terminals and causing an event that could shut the plant down.

For more information, please visit our “ Articles” section on nuclear applications at

www.pomonaelectronics.com

Shown on page 37 and 48

CK73041 Calibration Accessory Kit

The Pomona CK73041 Calibration Kit includes the major connectors and test cables you need for instrument calibration in a comprehensive kit. Versatile adapters and flexible cables greatly expand the variety of test cables you can create, reducing the number of special-purpose patch cords and connectors needed for calibration applications.

Perfect for:

• Field calibration

• Outfitting a new technician or lab

• Comprehensive replacement of important connectors and leads

Shown on page 52

3 www.pomonaelectronics.com

New Products

4

Pomona's quality connectors and test accessories are the one answer you need when a reliable signal

is demanded.

For Distributor

Locations:

United States and International www.pomonaelectronics.com

Europe www.pomona.cc

Technical Support

U.S.

[email protected] pomonatest.com

Europe

+31(0) 40 2675 150

Rest of World

1-425-446-5500

Expanding the Selection of RF

Cable Assemblies and Connectors

Pomona has introduced 23 new RF cable assemblies that include smaller SMA, SMB, MCX and MMCX connectors, as well as 19 new RF connectors that include BNC, TNC, N Type and

UHF. The smaller cable assemblies and connectors are designed for professionals working with applications where bandwidth and low signal loss are critical.

Who can use these cables and connectors:

• Electrical and electronics engineers and technicians

• OEM (original equipment manufacturers)

• Commincations technicians

• Instrumentation technicians

• Process control technicians

Shown on page 9-12, 21, 29, and 32.

www.pomonaelectronics.com

Customized Products

Pomona responds to a wide range of special or custom requirements by providing accessories tailored to your needs. Whether we simply modify an existing catalog product or create a unique combination of products, we use only the finest materials to deliver top quality products.

Think of the possibilities!

You can now define your own custom product or kit made of many combinations of cables, wires, connectors, or probes in this catalog.

Can’t find the length or color you need? Pomona makes it easy. Want a unique combination of connectors and cables you just can’t find anywhere? Just ask Pomona!

Combinations of coaxial connector/adapter assemblies can include strain-relief sheathing, marking and lengths.

To order your Pomona Product, please select [Custom Products] and fill out the request form on our Pomona Electronics website.

www.pomonaelectronics.com

5

6

Coaxial Cable Assemblies and Breakouts

Pomona is the professional’s choice, whether in the lab, plant or in the field. Using high-quality materials such as beryllium copper, gold and nickel plating ensures the precision you rely on. With a huge selection of cables and breakouts offering almost every connector and clip combination, Pomona provides you the solution for any application.

How to Order

Example: A 48in (1.2m) coaxial cable assembly with matching BNC (m) ends, stress relief boots on RG58 C/U, 50 Ω cable.

Cable Length

Typical Pomona Part Number: 2249-C-48

Cable Type

Cable Length in Inches

(Measured Inside Connectors)

Model#

2249-C-12

2249-C-24

2249-C-36

2249-C-48

2249-C-60

Length

12.0in (0.3m)

24.0in (0.6m)

36.0in (0.9m)

48.0in (1.2m)

60.0in (1.5m)

Cable Assembly

Holders

Model#

1508

4408

2708

Color “A”

Max Cable Dia.

Orange 0.210in (5.33mm)

Black 0.320in (8.13mm)

Blue 0.450in (11.43mm)

Number of

Slots

14

10

9

11.00in (279.4mm)

2.71in

(68.83mm)

3.50in

(188.9mm)

0.53in

(13.46mm)

A

Technical Specifications for Wire and Cable

Cable

Designation Type

A twisted pair, 2 conductor

C

E

J

Coax, RG58C/U

Coax, RG59B/U

Microphone, 2 conductor, shielded

K

T

Coax, RG174/U

Coax, RG214/U

Impedance

Ω

NA

Capacitance per 1ft/

0.304m

27.0 pf

Insulation/

Dielectric AWG

PVC 18

50

75

90

50

50

32.2 pf

22.0 pf

18 / 32 pf*

30.8 pf

30.8 pf

PE

PE

PE

PE

PE

20

23

22

26

13

Stranding

Strands

X AWG

65X36

Wire

Type

TC

Jacket

Material

PVC

Cable O.D.

0.25in (6.35mm)

19X33

Solid

16X34

7X34

7X22

TC

BCCS

TC

BCCS

PVCNC 0.195in (4.95mm)

PVCNC 0.242in (6.15mm)

PVC

PVC

0.231in (5.84mm)

0.110in (2.79mm)

Shield

NA

TCB

BCB

TCB

TCB

Temperature

(w/o connectors)

-4 to 221°F (-20 to +105°C)

-40 to 185°F (-40 to +85°C)

-40 to 140°F (-40 to +60°C)

-40 to 176°F (-40 to +80°C)

-40 to 167°F (-40 to +75°C)

SPC PVCNC 0.425in (10.8mm) SCCB/SCCB -40 to 176°F (-40 to +80°C)

X

Y

BB

SS

UU

V

V V

Triaxial

Coax, RG142B/U

Coax, RG223/U

Coax, RG316/U

Coax, RG58/U, low noise

Coax, RG178B/U

Coax, RG59/U

Coax, RG179B/U

Coax, RG 58A/U, double shielded

50

50

50

50

50

75

75

50

29.0 pf

30.8 pf

29.0 pf

37.0 pf

29.0 pf

20.4 pf

19.5 pf

30.8 pf

TFE

PE

TFE

CPE / PE

PTFE

PE

PTFE

PE / PE

* Capacitance between conductors / Capacitance between conductor and shield

18

19

26

22

16

23

12

20

Solid

Solid

7X37

7X30

7X.1

Solid

7X.1

7X28

SPCCS FEP 0.195in (4.05mm) SPC/SPC -94 to 392°F (-70 to +200°C)

SPC PVCNC 0.212in (5.38mm) SCB/SCB

-40 to 140°F (-40 to +60°C)

SPCCS FEP

TC PVC

0.096in (2.44mm) SPC

0.195in (4.95mm) BAF/TCB

-94 to 392°F (-70 to +200°C)

-40 to 176°F (-40 to +80°C)

SPCCS FEP

BCCS PVC

0.071in (1.8mm)

0.242in (6.15mm)

SPCCS FEP

TC PVC

0.100in (2.54mm)

0.240in (6.10mm)

SPC

BCB

SPC

TCB /

TCB-40

-67 to 311°F (-55 to +155°C)

-40 to 176°F (-40 to +80°C)

-67 to 311°F (-55 to +155°C)

to 167°F (-40 to +75°C)

AWG = American Wire Gauge

BAF = Bonded Aluminum Foil Polyester Tape

BCB = Bare Copper Braid

BCCS = Bare Copper Covered Steel

CPE = Conductive Polyethylene

FEP = Fluorinated Ethylene Propylene

OD = Outside Diameter

NA = Not Applicable

PE = Polyethylene

PVC = Polyvinyl Chloride

PVCNC = Polyvinyl Chloride Non

Contaminating

SCB = Silver Coated Braid

SPC = Silver Plated Copper

SCCB = Silver Coated Copper Braid

SPCCS = Silver Plated Copper Covered Steel

SSPE = Semi-Solid Polyethylene

TC = Tinned Copper

TCB = Tinned Copper Braid

TFE = Tetrafluoroethylene

www.pomonaelectronics.com

Ratings: The components in this section have a hands free rating for use in controlled voltage environments. However, for CE compliance these products are not intended for hand held use at voltages above 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Coaxial Cable Assemblies and Breakouts

BNC Male Cable with Molded

Strain Relief

3.37in (85.60mm)

Rating: Maximum voltage for hands free use: 500 Vrms*, +122˚F

(+50˚C) max., (“Y” Cable 176°F (+80°C).)

BNC: Body: tarnish resistant nickel-plated brass;

Center Contact: gold-plated brass; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

See chart on page 6 for additional wire and cable specifications.

BNC Male Low-Noise Cable

3.37in (85.60mm)

Model#

4964-SS-12

4964-SS-24

4964-SS-36

4964-SS-48

4964-SS-60

4964-SS-72

4964-SS-120

4964-SS-240

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

72in (1.8m)

120in (3.0m)

240in (6.1m)

Model 4964-SS uses a special low- triboelectric cable which has noise attenuating layers surrounding the center conductor. The cable is ideal for low power, low frequency measurements.

Recommended Frequency Range:

DC to 10KHz

BNC: Body: tarnish resistant nickel- plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

See chart on page 6 for additional wire and cable specifications.

Length 50

Ω Cable O.D.

.195in (4.95mm)

RG58C/U

.5ft (0.2m)

2249-C-6

1ft (0.3m)

2ft (0.6m)

3ft (0.9m)

4ft (1.2m)

5ft (1.5m)

2249-C-12

2249-C-24

2249-C-36

2249-C-48

6ft (1.8m)

8ft (2.4m)

2249-C-60

2249-C-72

2249-C-96

10ft (3.0m)

2249-C-120

12ft (3.7m)

2249-C-144

15ft (4.6m)

2249-C-180

20ft (6.1m)

2249-C-240

25ft (7.6m)

2249-C-300

30ft (9.1m)

2249-C-360

50ft (15.2m) 2249-C-600

50

Ω Cable O.D.

.206in (5.23mm)

RG223

2249-Y-12

2249-Y-24

2249-Y-36

2249-Y-48

2249-Y-60

2249-Y-72

2249-Y-96

2249-Y-120

2249-Y-144

2249-Y-180

2249-Y-240

75

Ω Cable O.D.

.242in (6.15mm)

RG59B/U

2249-E-6

2249-E-12

2249-E-24

2249-E-36

2249-E-48

2249-E-60

2249-E-72

2249-E-120

2249-E-144

2249-E-180

2249-E-240

2249-E-300

2249-E-360

2249-E-600

50

Ω Cable O.D.

.100in (2.54mm)

RG174/U

2249-K-6

2249-K-12

2249-K-24

2249-K-36

2249-K-48

2249-K-60

2249-K-72

2249-K-96

2249-K-120

2249-K-180

2249-K-240

2249-K-300

50

Ω Cable O.D.

.195in 4.95mm)

RG58C/U

5266-C-60

Model 2249-C is Pomona Electronics’ most popular cable. The 50 Ω

RG58C/U cable makes it ideal for most test and measurement applications.

Model 2249-Y is a 50 Ω RG223/U cable with double shield. Use when additional shielding is required.

Model 2249-E RG59B/U is a 75 Ω cable, making it the right choice for use with TV, video and LAN applications.

Model 2249-K RG174/U offers superior flexibility in a 50 Ω cable.

Model 5266-C is the same high quality construction as

Model 2249-C with a connector on (one end only.)

BNC Male True 75Ω

High Flex Cable

3.37in (85.60mm)

Model#

6510-V-12-0

6510-V-24-0

6510-V-36-0

6510-V-48-0

6510-V-60-0

6510-V-72-0

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

72in (1.8m)

Model 6510-V uses a true 75 Ω connector for superior VSWR and low return loss up to 3 GHz. The highly flexible

RG59/U type cable has a gas injected foam polyethylene dielectric with PVC jacket for low loss and superior shield coverage. Highly flexible cable and molded strain relief prevent excessive bending or kinking. An ideal product for

HDTV and digital video as well as test and measurement.

Rating: Maximum voltage for

hands free use: 500 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

See chart on page 6 for additional wire and cable specifications.

Flexible Color-coded

Sleeves for BNC Cables

Model#

6291

Pkg. Qty

20

PVC sleeves which help prevent inadvertent contact with the outer shell of the BNC and allow for color-coding.

Available in 10 colors. Fit most BNC male connectors. Perfect for use with any of the Model 2249- type cables.

Colors: contains 2 ea. of 10 colors.

IEC Insulated BNC Male

50Ω Cable

Model#

72926-C-40

72926-C-80

Length

40in (100cm)

80in (200cm)

Rating: 500V Cat 1, 150V Cat II, 3A.

Color: Black.

7

*see rating message at start of section.

www.pomonaelectronics.com

Coaxial Cable Assemblies and Breakouts

8

BNC Male 50Ω Cable: Field

Servicable Connector

1.06in

(26.92mm)

Model#

BNC-C-18

BNC-C-24

BNC-C-36

BNC-C-48

BNC-C-60

BNC-C-72

BNC-C-96

Length

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

72in (1.8m)

96in (2.4m)

Clamp nut and silicone gasket seal out moisture. Gold-plated center contact and Teflon

®

insulation assure premium performance.

Rating: Maximum voltage for hands

free use: 500 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass contact soldered to cable; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

BNC Male 50Ω Cable

1.15in

(29.21mm)

Model#

5697-6

5697-12

5697-24

5697-36

5697-48

5697-60

5697-72

5697-120

5697-180

5697-240

Rating: Maximum voltage for

hands free use: 500 Vrms*.

Length

6in (0.2m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

72in (1.8m)

120in (3.0m)

180in (4.6m)

240in (6.1m)

Cable Type: 50 Ω, RG58 type

0.19in (4.95mm) O.D.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass contact crimped to cable; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

BNC Male Right Angle

Connector Cable with

Molded Strain Relief

3.98in (101.09mm)

Model#

4276-C-12

4276-C-24

4276-C-36

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

Rating: Maximum voltage for hands

free use: 500 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

1.09in

(27.68mm)

Strain Relief: PVC molded directly to cable and connectors.

See chart on page 6 for additional wire and cable specifications.

BNC Male 50Ω Cable with

Insulated Push-on Connector

3.67in (93.22mm)

Model#

6253-C-36

Length

36in (0.9m)

Unique locking feature assures secure retention with the convenience of a push-on connector.

Rating: Maximum voltage for hands

free use: 500 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Outer Shell: blue thermoplastic; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

See chart on page 6 for additional wire and cable specifications.

BNC Male to BNC Male Right

Angle 50Ω Cable

1.60in

(40.64mm)

Model#

1383-C-24

1383-C-60

Length

24in (0.6m)

60in (1.5m)

Rating: Maximum voltage for hands

free use: 500 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

1.06in

(26.92mm)

BNC Male to BNC Female with Molded Strain Relief

3.58in (90.93m)

Model#

4524-C-36

4524-C-48

4524-C-60

Length

36in (0.9m)

48in (1.2m)

60in (1.5m)

Use to extend BNC Cables.

Rating: Maximum voltage for hands

free use: 500 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass, Center Contact: male: gold-plated brass; female: gold-plated beryllium copper;

Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

See chart on page 6 for additional wire and cable specifications.

www.pomonaelectronics.com

*see rating message at start of section.

Coaxial Cable Assemblies and Breakouts

BNC Female 50Ω Cable with

Molded Strain Relief

Model#

4277-C-24

4277-C-48

3.58in (90.93m)

Length

24in (0.6m)

48in (1.2m)

Rating: Maximum voltage for hands

free use: 500 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated beryllium copper;

Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

See chart on page 6 for additional wire and cable specifications.

SMA Male to SMA Female

1.00in

(25.40mm)

1.00in

(25.40mm)

RG 174/U

4528-K-48

RG 142B/U

4528-X-24

4528-X-48

Length

48in (1.2m)

24in (0.6m)

48in (1.2m)

SMA: Body/Fittings: passivated stainless steel; Contact: gold-plated brass; Dielectric: PTFE.

SMA (F): gold-plated, beryllium copper center contact;

Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

9

BNC Male to SMA Male 50Ω

Teflon Insulated Cable

1.06in

(26.92mm)

1.00in

(25.40mm)

RG 316/U

4935-BB-24

4935-BB-48

4935-BB-60

Length

24in (0.6m)

48in (1.2m)

60in (1.5m)

Rating: Maximum voltage for

hands free use: 335 Vrms*.

SMA: Body /Fittings: passivated stainless steel; Contact: gold-plated brass; Dielectric: PTFE.

BNC: Body: tarnish resistant nickel- plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

SMA Male to Type ‘N’ Male

50Ω Cable

1.40in

(35.56mm)

1.00in

(25.40mm)

Model#

5058-X-36

5058-X-48

5058-X-60

Length

36in (0.9m)

48in (1.2m)

60in (1.5m)

SMA: Body/Fittings: passivated stainless steel; Contact: gold-plated brass; Dielectric: PTFE.

Type ‘N’: Body: white bronze-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

SMA Male 50Ω Cable

4846-C

4846-UU

1.12in

(28.5mm)

0.89in

(22.7mm)

4846-X-60

RG 58C/U

4846-C-12

4846-C-24

4846-C-36

4846-C-48

4846-C-60

RG 178B/U

4846-UU-12

4846-UU-24

4846-UU-36

4846-UU-48

4846-UU-60

RG 174/U

4846-K-24

4846-K-48

4846-K-60

RG 316/U

4846-BB-24

4846-BB-48

4846-BB-60

RG 142B/U

4846-X-24

4846-X-48

Length

24in (0.6m)

48in (1.2m)

60in (1.5m)

24in (0.6m)

48in (1.2m)

60in (1.5m)

24in (0.6m)

48in (1.2m)

60in (1.5m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

SMA: Body/Fittings: passivated stainless steel or gold-plated brass;

Contact: gold-plated brass;

Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

Type ‘N’ Male 50Ω Cable

1.48in

(37.59mm)

Model#

1658-T-18

1658-T-24

1658-T-36

1658-T-48

1658-T-60

Length

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: Maximum voltage for hands

free use: 1,000 Vrms*.

Type ‘N’: Body: white bronze-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

*see rating message at start of section.

www.pomonaelectronics.com

Coaxial Cable Assemblies and Breakouts

10

MMCX Male 50Ω Cable

0.69in

(17.6mm)

RG 316/U

73063-BB-6

73063-BB-12

73063-BB-24

73063-BB-36

RG 178B/U

73077-UU-12

73077-UU-24

73077-UU-36

73077-UU-48

Length

6in (0.15m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

Length

12in (1.5m)

24in (1.8m)

36in (2.4m)

48in (2.4m)

Rating: Maximum voltage for hands

free use: 500 V.

MMCX: Body/Fittings: gold-plated brass; Contact: gold-plated phosphor bronze; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

MCX Male 50Ω Cable

73067-BB

0.81in

(20.5mm)

RG 316/U

73067-BB-6

73067-BB-12

73067-BB-24

73067-BB-36

RG 178B/U

73075-UU-12

73075-UU-24

73075-UU-36

73075-UU-48

Length

6in (0.15m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

Length

12in (1.2m)

24in (1.5m)

36in (1.8m)

48in (3.0m)

Rating: Maximum voltage for

hands free use: 750 V.

MCX: Body/Fittings: gold-plated brass; Contact: gold-plated phosphor bronze; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

73063-BB

MCX Male 75Ω Cable

0.81in

(20.5mm)

RG 179B/U

73075-VV-12

73075-VV-24

73075-VV-36

73075-VV-48

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

Rating: Maximum voltage for hands

free use: 750 V.

MCX: Body/Fittings: gold-plated brass; Contact: gold-plated phosphor bronze; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

SMB Jack 50Ω Cable

0.94in

(23.9mm)

RG 316/U

73072-BB-6

73072-BB-12

73072-BB-24

73072-BB-36

73072-BB-48

Length

6in (0.15m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

Rating: Maximum voltage for hands

free use: 750 V.

SMB: Body/Fittings: gold-plated brass; Contact: gold-plated phosphor bronze; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

SMB Jack 75Ω Cable

0.94in

(24.0mm)

RG 179B/U

73072-VV-12

73072-VV-24

73072-VV-36

73072-VV-48

73072-VV-60

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: Maximum voltage for hands

free use: 750 V.

SMB: Body/Fittings: gold-plated brass; Contact: gold-plated brass;

Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

SMB Jack Right Angle

50Ω Cable

0.60in

(15.2mm)

RG 316/U

73073-BB-6

73073-BB-12

73073-BB-24

73073-BB-36

73073-BB-48

Length

6in (1.5m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

Rating: Maximum voltage for hands

free use: 750 V.

SMB: Body/Fittings: gold-plated brass; Contact: gold-plated phosphor bronze; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

www.pomonaelectronics.com

*see rating message at start of section.

Coaxial Cable Assemblies and Breakouts

MMCX Male to MMCX Male

Right Angle 50Ω Cable

0.47in

(12.0mm)

RG 316/U

73064-BB-6

73064-BB-12

73064-BB-24

73064-BB-36

Length

6in (0.15m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

Rating: Maximum voltage for hands

free use: 500 V*.

MMCX: Body/Fittings: gold-plated brass; Contact: gold-plated phosphor bronze; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

MCX Male Right Angle 50Ω

0.52in

(13.1mm)

RG 316/U

73068-BB-6

73068-BB-12

73068-BB-24

73068-BB-36

Length

6in (0.15m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

Rating: Maximum voltage for

hands free use: 750 V*.

SMA: Body/Fittings: gold-plated brass; Contact: gold-plated phosphor bronze; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

11

0.69in

(17.6mm)

SMA Male to SMA Male

Right Angle 50Ω Cable

0.60in

(15.2mm)

0.76in

(19.3mm)

RG 316/U

73069-BB-12

73069-BB-24

73069-BB-36

73069-BB-48

73069-BB-60

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: Maximum voltage for

hands free use: 750 V*.

SMA: Body/Fittings: gold-plated brass; Contact: gold-plated brass;

Dielectric: PTFE

See chart on page 6 for additional wire and cable specifications.

SMA Male Right Angle to SMA Female Bulkhead

50Ω Cable

0.60in

(15.2mm)

0.84in

(21.3mm)

RG 316/U

73071-BB-12

73071-BB-24

73071-BB-36

73071-BB-48

73071-BB-60

RG 142B/U

73071-X-12

73071-X-24

73071-X-36

73071-X-48

73071-X-60

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: Maximum voltage for hands

free use: 750 V.

SMA: Body/Fittings: gold-plated brass; Contact: beryllium copper and brass, gold-plated;

Dielectric: PTFE

See chart on page 6 for additional wire and cable specifications.

SMA Male to SMA Female

Bulkhead 50Ω Cable

73070-C

0.76in

(19.3mm)

0.84in

(21.3mm)

RG 316/U

73070-BB-12

73070-BB-24

73070-BB-36

73070-BB-48

73070-BB-60

RG 58C/U

73070-C-12

73070-C-24

73070-C-36

73070-C-48

73070-C-60

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

24in (0.6m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: Maximum voltage for

hands free use: 750 V.

SMA: Body/Fittings: gold-plated brass; Contact: beryllium copper and brass, gold-plated;

Dielectric: PTFE

See chart on page 6 for additional wire and cable specifications.

*see rating message at start of section.

www.pomonaelectronics.com

Coaxial Cable Assemblies and Breakouts

12

SMA Male to SMA Male

Quick-Connect 50Ω Cable

1.13in

(28.7mm)

RG 142B/U

73082-X-12

73082-X-24

73082-X-36

73082-X-48

73082-X-60

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.2m)

Rating: Maximum voltage for hands free use: 750 V

SMA: Body/Fittings: brass, goldplated and nickel-plated; Contact: gold-plated brass; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

SMA Male Quick-Connect

50Ω Cable

1.11in

(28.3mm)

1.11in

(28.3mm)

RG 316/U

73083-BB-12

73083-BB-24

73083-BB-36

73083-BB-48

73083-BB-60

RG 142B/U

73083-X-12

73083-X-24

73083-X-36

73083-X-48

73083-X-60

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.2m)

Length

12in (1.2m)

24in (1.5m)

36in (1.8m)

48in (3.0m)

60in (1.2m)

Rating: Maximum voltage for

hands free use: 750 V.

SMA: Body/Fittings: nickel-plated brass; Contact: gold-plated brass;

Dielectric: PTFE

See chart on page 6 for additional wire and cable specifications.

MMCX Male to SMA Female

Bulkhead 50Ω Cable

0.84in

(21.3mm)

0.69in

(17.6mm)

RG 316/U

73065-BB-12

73065-BB-24

73065-BB-36

73065-BB-48

RG 178B/U

73078-UU-12

73078-UU-24

73078-UU-36

73078-UU-48

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

Rating: Maximum voltage for hands

free use: 500 V.

MMCX: Body/Fittings: gold-plated brass; Contact: gold-plated phosphor bronze; Dielectric: PTFE.

SMA: Body/Fittings: gold-plated brass; Contact: gold-plated beryllium copper; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

MMCX Male Right Angle to

SMA Female Bulkhead

50Ω Cable

0.47in

(12.0mm)

RG 316/U

73066-BB-12

73066-BB-24

73066-BB-36

73066-BB-48

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

Rating: Maximum voltage for hands

free use: 500 V.

MMCX: Body/Fittings: gold-plated brass; Contact: gold-plated phosphor bronze; Dielectric: PTFE.

SMB: Body/Fittings: gold-plated brass; Contact: gold-plated beryllium copper; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

0.84in

(21.3mm)

www.pomonaelectronics.com

*see rating message at start of section.

Coaxial Cable Assemblies and Breakouts

Triaxial Male to

Three Alligator

Test Clips, Double

Shielded

f f

1.50in

(38.10mm)

Model# Cable Type Lugs

4725

Triaxial 2

5342

Triaxial 3

Length

36in (0.9m)

36in (0.9m)

Rating: Maximum voltage for hands

free use: 150 Vrms*.

Jaw Opening: 0.30in (7.62mm) Max.

Triaxial: Body/Fittings: tarnish resistant nickel-plated brass;

Intermediate and Center Contacts: gold-plated brass; Dielectric: PTFE.

See chart on page 6 for additional wire and cable specifications.

2.25in

(57.15mm)

6.0in (152.40mm)

2 Lug m

3 Lug m

BNC Male with Molded

Strain Relief to Minipincer

®

Test Clips

3.37in (85.60mm)

1.50in

(38.10mm)

8.0in

(203.2mm)

2.59in

(65.79mm)

Model#

5423-C-24

5423-C-36

5423-C-48

Length

24in (0.6m)

36in (0.9m)

48in (1.2m)

Rating: Maximum voltage for hands

free use: 300 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

Minipincer: Contacts: beryllium gold-plated copper; Insulation: glass filled nylon.

Colors: One black and one red.

See chart on page 6 for additional wire and cable specifications.

Triaxial Male Cables

1.50in

(38.10mm) f f

Model# Cable Type Lugs

5223-36

5223-60

Triaxial 3

5054-36

5054-60

Triaxial 2

Length

36in (0.9m)

60in (1.5m)

36in (0.9m)

60in (1.5m)

Rating: Maximum voltage for hands free use:

500 Vrms*.

Triaxial: Body/Fittings: tarnish resistant nickel-plated brass; Intermediate and Center

Contacts: gold-plated brass; Dielectric: PTFE.

Cable Type: Double Shielded, 50

Ω, RG58A/U.

Colors: 5223: Yellow, 5054: Yellow.

Triaxial to BNC Adapters on page 31.

See chart on page 6 for additional wire and cable specifications.

2 Lug m

3 Lug m

BNC Male with Molded

Strain Relief to

Micrograbber

®

Test Clips

3.37in (85.60mm)

1.50in

(38.10mm)

8.0in

(203.2mm)

1.74in

(44.19mm)

Model#

4777-C-24

4777-C-36

4777-K-24

4777-K-36

4777-K-48

Length

24in (0.6m)

36in (0.9m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

Rating: Maximum voltage for hands

free use: 150 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

Micrograbber: Contacts: beryllium gold-plated copper; Insulation: glass filled nylon.

Colors: One black and one red.

See chart on page 6 for additional wire and cable specifications.

13

BNC Male to Minigrabber

®

Test Clips

1.50in (38.10mm)

1.06in

(26.92mm)

2.56in

(65.02mm)

8.0in (203.2mm)

Model#

3787-C-18

3787-C-24

3787-C-36

3787-C-48

3787-C-60

Length

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: Maximum voltage for hands

free use: 300 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Minigrabber: Contacts: beryllium gold-plated copper; Insulation: glass filled nylon.

Colors: One black and one red.

See chart on page 6 for additional wire and cable specifications.

BNC Male with Molded

Strain Relief to Alligator

Test Clips

2.30in

(58.42mm)

3.37in (85.60mm)

2.13in

(54.10mm)

7.50in (90.50mm)

Model#

4531-C-18

4531-C-24

4531-C-30

4531-C-36

4531-C-48

4531-C-60

Length

18in (0.5m)

24in (0.6m)

30in (0.76m)

36in (0.9m)

48in (1.2mm)

60in (1.5mm)

Rating: Maximum voltage for hands

free use: 150 Vrms*.

Jaws Opening: 0.3in (7.62mm) max.

BNC: Body: tarnish resistant nickel- plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

Alligator: Body: steel-plated nickel.

Colors: Vinyl boots: one black and one red.

See chart on page 6 for additional wire and cable specifications.

*see rating message at start of section.

www.pomonaelectronics.com

Coaxial Cable Assemblies and Breakouts

14

BNC Male with Molded

Strain Relief to

Minigrabber

®

Test Clips

3.37in (85.60mm)

1.50in

(38.10mm)

8.0in

(203.20mm)

2.56in

(65.02mm)

Model#

5187-C-24

5187-C-36

5187-C-48

5187-C-60

5187-K-24

5187-K-36

5187-K-48

5187-K-60

Length

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: Maximum voltage for hands

free use: 300 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

Minigrabber: Contacts: beryllium gold-plated copper; Insulation: glass filled nylon.

Colors: One black and one red.

See chart on page 6 for additional wire and cable specifications.

BNC Male with Molded

Strain Relief to Minigator

®

Test Clips

3.37in (85.60mm)

8.0in (203.2mm)

1.50in (38.10mm)

1.18in

(29.97mm)

Model#

4532-C-24

4532-C-36

4532-C-48

4532-C-60

Length

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: Maximum voltage for hands

free use: 45 Vrms*.

Jaws Opening: to 0.18in

(47.50mm) max.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

Minigator: Body: steel-plated nickel

Colors: Vinyl boots: one black and one red.

Rating: +122˚F (+50˚C) max.

See chart on page 6 for additional wire and cable specifications.

BNC Male with Molded

Strain Relief to SMD

Grabber

®

Test Clips

3.37in (85.60mm)

1.50in

(38.10mm)

1.58in

(40.13mm)

8.0in

(203.2mm)

Model#

5304-K-24

5304-K-36

Length

24in (0.6m)

36in (0.9m)

Rating: Maximum voltage for hands

free use: 150 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Strain Relief: PVC molded directly to cable and connectors.

Grabber: Contacts: gold-plated stainless steel; Insulation: glass filled nylon.

Colors: One black and one red.

See chart on page 6 for additional wire and cable specifications.

BNC Male to Stacking

Pin Tip Plugs

1.06in

(26.92mm)

1.30in

(33.02mm)

8.00in

(203.2mm)

ø .080in

(2.03mm)

1.35in

(34.29mm)

Model#

2882-C-60

Length

60in (1.5m)

Rating: Maximum voltage for hands

free use: 500 Vrms*, +122˚F

(+50˚C) max.

Cable Type: RG58C/U,

0.19in (4.95mm) O.D.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass.

Pin Tip Plug: Body: gold-plated brass; Insulation: polypropylene.

Colors: One black and one red.

Strain Relief: contact soldered to cable.

See chart on page 6 for additional wire and cable specifications.

BNC Male to Multi-Stacking

Double Banana Plugs

Model#

2BC-BNC-36

Length

36in (0.9m)

1.55in

(39.37mm)

0.75in

(19.05mm)

1.25in (31.75mm)

Rating: Maximum voltage for hands

free use: 500 Vrms*, +122˚F

(+50˚C) max.

Cable Type C: RG58C/U,

0.19in (4.95mm) O.D.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass.

2nd End: Double Banana Plugs.

Body: nickel-plated brass beryllium copper spring; Insulation: polyproylene. Color: Black.

Strain Relief: PVC molded directly to cable and connectors.

Strain Relief

Boot

2.75in (69.85mm)

Model# Fits Cable Types

5155-*

RG 58, 141

5156-*

RG 59, 62, 210

5157-*

RG 174, 187, 188

For Cable O.D.

0.185in - .200

(4.70mm - 5.08mm)

0.237in - .247in

(6.02mm - 6.27mm)

0.090in - .110in

(2.29mm - 2.79mm)

Rating: +122˚F (+50˚C) Max.

Use with crimp type connectors.

Sold in packages of 10.

*Std. Colors: -0 Black, -2 Red

www.pomonaelectronics.com

*see rating message at start of section.

Coaxial Cable Assemblies and Breakouts

Insulated BNC Male / 4mm

Shrouded Plugs

2.28in

(58mm)

Model#

72927-C-40

72927-C-80

Length

40in (100cm)

80in (200cm)

Impedance: 50 Ω.

Rating: 500V Cat I, 150 V Cat II, 3A.

Color: Black.

4 mm plugs

1.66in (42mm)

2.20in

(56mm)

IEC Insulated BNC Male to

Stackable/Retractable

2.13in (54mm)

IEC Insulated BNC Female to Stackable/Retractable

4 mm plugs

2.13in (54mm)

2.13in (54mm)

Model#

72908

Length

10in (25cm)

Impedance: 50 Ω.

Rating: 33 Vrms / 70 Vdc, 6A.

Color: Black.

Model#

72909

Length

10in (25cm)

Impedance: 50 Ω.

Rating: 33 Vrms / 70 Vdc, 6A.

Color: Black.

BNC Male to ... the ends listed below

3.37in (85.60mm)

1st End: Crimp BNC Male with Molded

Strain Relief.

Body: tarnish resistant nickel-plated brass; Center Contact: gold-platedbrass;

Impedance: 50 Ω, Boot, PVC; Color: black.

Cable Type C: RG58C/U

Rating: Maximum voltage for hands free

use: 500 Vrms*.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: gold-plated brass

Strain Relief: PVC molded directly to cable and connectors.

Match to any end shown below

BNC Male with Molded

Strain Relief to Multi-

Stacking Banana Plugs

8.0in (203.2mm)

1.30in (33.02mm)

1.55in

(39.37mm)

Model#

5268-C-24

5268-C-36

5268-C-48

5268-C-60

Length

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

2nd End: Stacking Banana Plugs.

Body: nickel-plated brass beryllium copper spring; Insulation: polyproylene; Colors: one black and one red.

See chart on page 6 for additional wire and cable specifications.

BNC Male with Molded

Strain Relief to Multi-

Stacking Double Banana

Plug

1.55in

(39.37mm)

.75in

(19.05mm)

Model#

4530-C-18

4530-C-24

4530-C-36

4530-C-48

4530-C-60

Length

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

2nd End: Double Banana Plugs.

Body: nickel-plated brass beryllium copper spring; Insulation: polyproylene. Color: black.

See chart on page 6 for additional wire and cable specifications.

BNC Male with Molded

Strain Relief to

Retractable Sheath

Banana Plugs

2.19in (55.63mm)

Model#

5343-C-12

5343-C-24

5343-C-36

5343-C-48

5343-C-60

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Ideal for use with binding posts.

2nd End: Sheathed Banana Plugs.

Body: nickel-plated brass beryllium copper spring; Insulation: nylon.

See chart on page 6 for additional wire and cable specifications.

2.72in (69.09mm)

7.92in (201.17mm)

BNC Male with Molded

Strain Relief to Square

Pin Receptacles

7.92in

(201.17mm)

0.52in

(13.21mm)

2.19in (55.63mm) 0.10in (2.54mm)

Model#

4945-K-18

4945-K-24

4945-K-36

4945-K-48

4945-K-60

Length

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

2nd End: 0.025in (0.6mm)

Square Pin Receptacles

Center Contact; gold-plated brass;

Insulation: ABS; Colors: one black and one red.

See chart on page 6 for additional wire and cable specifications.

*see rating message at start of section.

www.pomonaelectronics.com

15

Coaxial Cable Assemblies and Breakouts

16

BNC Male (1st End):

Body: tarnish resistant nickel-plated brass;

Center Contact: gold-plated brass;

Insulation: polypropylene; Dielectric: PTFE.

Nominal impedance: 50 Ω.

Colors: Black.

BNC Male or Female to ... the ends listed below

1.54in

(39.12mm)

1.39in

(34.80mm)

0.59in

(14.99mm)

0.59in

(14.99mm)

Overall length = BNC length + wire length + clip/plug length

Match to any end shown below

BNC Female (1st End):

Body: tarnish resistant nickel-plated brass;

Center Contact: beryllium gold-plated copper;

Insulation: polypropylene; Dielectric: PTFE.

Nominal impedance: 50 Ω.

Colors: Black.

...Minigrabber

®

Clips (2nd End)

2.56in (65.02mm)

Test

...Micrograbber

®

Test Clips (2nd End)

1.73in (43.94mm)

Male

Model#

Female

Model# Wire Length

5.5in (140mm)

3789 3788

Minigrabber: Contacts: beryllium gold-plated copper; Insulation: glass filled nylon.

Colors: One black and one red.

Rating: Maximum voltage for hands free use:

300 Vrms*, +131˚F (+55˚C) max.

... Alligator Test Clips

(2nd End)

2.30in

(58.42mm)

Male

Model#

Female

Model#

2630

Wire Length

5in (127mm)

Alligator: Body: steel-plated nickel.

Colors: Vinyl boots: one black and one red.

Rating: +122˚F (+50˚C) max.

Rating: Maximum voltage for hands free

use: 150 Vrms*.

Jaw Opening: 0.30in (7.62mm).

5189 5188

5.4in (137mm)

Micrograbber: Contacts: beryllium gold- plated copper; Insulation: glass filled nylon.

Colors: One black and one red.

Rating: Maximum voltage for hands free use:

150 Vrms*, +131˚F (+55˚C) max.

... Minigator Test Clips

(2nd End)

1.65in

(41.91mm)

2886 2631

5.9in (149mm)

Minigator: Body: steel-plated nickel.

Colors: Vinyl boots: one black and one red.

Rating: Maximum voltage for hands free use:

45 Vrms*, +122˚F (+50˚C) max.

Jaw Opening: 0.18in (47.50mm).

... SMD Grabber

®

Test Clips (2nd End)

1.73in (43.94mm)

— 5305

5.5in (140mm)

Grabber: Contacts: gold-plated stainless steel; Insulation: glass filled nylon.

Colors: One black and one red.

Rating: Maximum voltage for hands free use:

150 Vrms*, +131˚F (+55˚C) max.

... Stacking Pin Tip

Plugs (2nd End)

1.18in

(29.97mm)

0.08in (2.03mm) Dia.

3901 3221

5.5in (140mm)

Pin Tip Plug: Body: gold-plated brass;

Insulation: polypropylene.

Colors: One black and one red.

Rating: Maximum voltage for hands free use:

500 Vrms*, +131˚F (+55˚C) max.

... Multi-Stacking

Banana Plug (2nd End)

1.55in

(39.37mm)

3957 3073

5.4in (137mm)

Banana Plug: Body: brass, Spring: beryllium copper; gold-plated. Insulation: polypropylene.

Colors: One black and one red

Rating: Maximum voltage for hands free use:

500 Vrms*, +131˚F (+55˚C) max.

... 20 AWG Leads

(2nd End)

4970 4969

5.9in (149mm)

Rating: Maximum voltage for hands free use:

500 Vrms*, +131˚F (+55˚C) max.

2nd End: None.

Female only ... to #8

Spade Lugs (2nd End)

0.98in

(24.89mm)

0.28in

(7.11mm)

0.168in

(4.27mm)

— 5051

5.4in (136mm)

Spade Lug: Body: Copper, tin-plated;

Insulation: vinyl.

Colors: One black and one red.

Rating: Maximum voltage for hands free use:

500 Vrms*, +131˚F (+55˚C) max.

... Stacking Miniature

Banana Plugs (2nd End)

0.89in

(22.61mm)

— 3966

5.5in (140mm)

Banana Plug: Body: brass, Spring: beryllium copper; gold-plated. Insulation: polypropylene.

Colors: One black and one red

Rating: Maximum voltage for hands free use:

500 Vrms*, +131˚F (+55˚C) max.

Female only ... to .025

Square Pin Receptacles

(2nd End)

0.10in

(2.54mm)

— 5069

5.6in (143mm)

Square Pin: Gold-plated phosphor bronze,

ABS insulation.

Colors: One black and one red.

0.52in (13.21mm)

Rating: Maximum voltage for hands free use:

500 Vrms*, +131˚F (+55˚C) max.

www.pomonaelectronics.com

*see rating message at start of section.

RF Coaxial Connectors,

Adapters and Kits

Pomona has everything from a single reliable RF adapter to versatile kits packaged in lightweight, foam padded cases containing all the connections and terminations you might need. Small MCX,

MMCX, SMA and SMB connectors enable attachment in today’s tight spacings. Pomona – connecting with quality.

Universal Adapter Kit

Model# 5698

Kit contains two each: BNC (m),

BNC (f), TNC (m), TNC (f), SMA

(m), SMA (f), N (m), N (f), four intermediate couplers, one double Banana Plug, one double Banana Jack, and case.

Multi-RF Direct Adapter Kit

Model# 72934

A comprehensive kit including the most frequently used 50 Ω RF adapters in a rugged pistol-grip case.

Allows for direct adaptation without intermediate couplers. All parts are precision machined brass, not diecast, with tarnish resistant nickel plating. Male center pin contacts are gold plated brass. Female center contacts are gold plated heat treated beryllium copper. Insulation material is high density PTFE.

Maxi Universal Adapter Kit

Model# 5748

Kit contains two each: BNC (m),

BNC (f), TNC (m), TNC (f), SMA

(m), SMA (f), N (m), N (f), UHF (m),

UHF (F), Mini UHF (m), Mini UHF (f),

F (m), F (f), RCA (m), RCA (f), six intermediate couplers, one double

Banana Plug, one double Banana

Jack, one sampler, and case.

Kit contains:

3535 BNC (m)/Type N (f)

3288 BNC (f)/Type N (m)

3844 TNC (m)/BNC (f)

4288 SMA(m)/BNC(M)

4290 SMA (m)/BNC (f)

4289 SMA (f)/BNC (m)

4291 SMA (f)/BNC (F)

4298 SMA (m)/Type N (f)

4297 SMA (f)/Type N (M)

4299 SMA (f)/Type N (f)

4292 SMA (m)/TNC (m)

4294 SMA (m)/TNC (f)

4293 SMA (f)/TNC (m)

4295 SMA (f)/TNC (f)

4296 SMA (m)/Type N (m)

3283 BNC (f-f)

3533 BNC (m-m)

3285 BNC (f-m-f) TEE

3284 BNC (f-f-f) TEE

4940 TNC (f-f) Adapter

3841 TYPE N (f-f)

3842 TYPE N (m-m)

4282 SMA (m-f) Rt Angle

4283 SMA (m-m)

4284 SMA (f-f)

4286 SMA Termination, 50 Ω (m)

Adapter Kit Accessories

Individual adapters for the Universal

Adapter Kits are also available.

Coupling nut adapter to

BNC (m)

BNC (f)

TNC (m)

TNC (f)

SMA (m)

SMA (f)

N (m)

N (f)

UHF (m)

UHF (f)

Model# 5698 5748

5735 2 2

5739

5736

2

2

2

2

5740

5737

5741

5734

2

2

2

2

2

2

2

2

5738

5752

5756

2

2

2

2

Coupling nut adapter to

Mini UHF (m)

Mini UHF (f)

RCA (m)

RCA (f)

F (m)

F (f)

Coupler

Dbl Banana Plug 5743

Dbl Banana Post 5744

Sampler 5760

Model# 5698 5748

5753 – 2

5757

5754

2

2

5758

5759

5755

5742

4

2

2

2

6

1

1

1

1

1

SMA Adapter Kit

Model# 72931

A consolidated kit including the most frequently used SMA adapters in a rugged pistol-grip case.

Allows for direct adaptation without intermediate couplers. All parts are precision machined brass, not diecast, with tarnish resistant nickel plating. Male center pin contacts are gold plated brass. Female center contacts are gold plated heat treated beryllium copper. Insulation material is high density PTFE.

Kit contains:

4282 Right Angle SMA Female to SMA Male

4283 Inline SMA Male to SMA Male

4284 Inline SMA Female to SMA Female

4286 SMA Male Terminator Plug

4288 SMA Male to BNC Male

4289 SMA Female to BNC Male

4290 SMA Male to BNC Female

4291 SMA Female to BNC Female

4292 SMA Male to TNC Male

4293 SMA Female to TNC Male

4294 SMA Male to TNC Female

4295 SMA Female to TNC Female

4296 SMA Male to N Male

4297 SMA Female to N Male

4298 SMA Male to N Female

4299 SMA Female to N Female

*see rating message at start of section.

www.pomonaelectronics.com

RF Coaxial Connectors, Adapters and Kits

18

N Adapter Kit

Kit contains:

3288 N Male to 50 Ω BNC Female

3535 N Female to 50 Ω BNC Male

3841 Inline N Female to N Female

3842 Inline N Male to N Male

3843 Right Angle N Female to N Male

4286 N Male to SMA Male

4297 N Male to SMA Female

Broadcast BNC

Adapter Kit

Model# 72932

A consolidated kit including the most frequently used Type N adapters in a rugged pistol-grip case.

Allows for direct adaptation without intermediate couplers. All parts are precision machined brass, not die-cast, with tarnish resistant nickel plating. Male center pin contacts are gold plated brass. Female center contacts are gold plated heat treated beryllium copper. Insulation material is high density PTFE.

4298 N Female to SMA Male

4299 N Female to SMA Female

5089 T Style N Female to N Female to N Female

4240-50 50 Ω N Terminator Plug

4240-75 75 Ω N Terminator Plug

7/16 DIN Adapter Kit

Model# 6254

This kit will enable the field service technician to connect equipment that has 7/16 DIN connectors to other equipment that has

Type N connectors. These connectors are not compatible, but both are commonly found on the same types of telephone equipment and test equipment.

The key feature of the 7/16 DIN connector is the extremely high resistance to inter-modulation interference. These connectors are used in cellular phone and PCS systems to reduce interference in crowded cell sites and also in radio, television and repeater sites.

An assortment of the most useful adapters for conversion between 7/16 DIN and Type N.

Kit contains one each:

6256 7/16 DIN Male to Type N Male Adapter

6257 7/16 DIN Male to Type N Female Adapter

6259 7/16 DIN Female to Type N Male Adapter

6260 7/16 DIN Female to Type N Female Adapter

7/16 DIN Male to 7/16 DIN Female Right Angle Adapter

7/16 DIN Female to 7/16 DIN Female Splice

All parts are protected by a custom zippered case with die cut foam padding.

Model# 72933

A comprehensive kit including the most frequently used 75 Ω BNC adapters in a rugged pistol-grip case. Allows for direct adaptation without intermediate couplers. All parts are precision machined brass, not die-cast, with tarnish resistant nickel plating. Male center pin contacts are gold plated brass. Female center contacts are gold plated heat treated beryllium copper. Insulation material is high density PTFE.

Universal Adapter Cable

Model#

5749-24

5749-36

5749-48

5749-60

5749-72

Length

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

72in (1.8m)

Make cable assemblies with any of the adapters in the universal adapter kits.

50 Ω RG 58C/U, 195” O.D.

Kit contains

6737 75 Ω BNC f/f Adapter

6738 75 Ω BNC f/f/f Adapter

6739 75 Ω BNC f/m/f Adapter

6740 75 Ω BNC m/m Adapter

6754 BNC (F/M/F) Adapter, In-Line, 75 Ω

6779 BNC (m) / f (f), 75 Ω

6780 BNC (f) / f (f), 75 Ω

6781 BNC (f) / F (m), 75 Ω

6782 BNC (m) / F (m), 75 Ω

1297 Adapter, BNC(f), Phono Plug

3837 BNC (f)/Tini Plug

4043 Adapter, BNC(M), Phono Jack

4267 BNC (f)/Microplug

5319 BNC Female to Phono Plug

4054 BNC (m) to Phono Jack Adapter

4719 BNC (f)/Bantam Plug

5008 BNC (f)/.090 Video Plug

6519 BNC TO Mini-WECO Adapter

3840-75 BNC (m) Resistor Terminator

Plug, 75

Ω

BNC to Banana Plug and

Binding Post Adapter Kit

Model# 5510

An assortment of many of Pomona’s most popular BNC

Kit contains one each:

BNC Female to Stacking Double Banana Plug

BNC Male to Stacking Double Banana Plug

BNC Male to Stackable Binding Posts

BNC Female to Stackable Binding Posts

BNC Female to Female

BNC Male to Male adapters.

BNC 50Ω Attenuator Kit

Model# 5513

Kit contains five Model 4108 BNC 50 Ω attenuators, one each of 3dB, 6dB, 10dB,

14dB and 20dB.

(Same as Model 4108).

www.pomonaelectronics.com

Ratings: The components in this section have a hands free rating for use in controlled voltage environments. However, for CE compliance these products are not intended for hand held use at voltages above 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum.

RF Coaxial Connectors, Adapters and Kits

BNC Female to Double

Stacking Banana Plug

1.13in

(28.70mm)

Model# 1269

0.75in

(19.05mm)

Rating: Maximum voltage for

hands free use: 500 Vrms*, +122˚F

(+50˚C) max.

Material: Banana Plug Jack: brass;

Spring: heat treated beryllium copper; Finish: nickel plating.

2.05in (52.07mm)

4mm Safety Banana Jack to

2mm Banana Plug Adapter

0.35in

(9mm)

Model# Color

72914-02

Set, Black and Red

72914-0

10 pack, Black

72914-2

10 pack, Red

1.81in (46mm)

Accepts 4mm safety-sheathed banana plugs.

Rating: 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum, 36A.

BNC Male to Double

Stacking Banana Plug

1.13in

(28.70mm)

Model# 1270

0.75in

(19.05mm)

Rating: Maximum voltage for

hands free use: 500 Vrms*, +122˚F

(+50˚C) max.

Material: Banana Plug Jack: brass;

Spring: heat treated beryllium copper; Finish: nickel plating.

2.20in (55.88mm)

BNC Female to Stackable

Binding Posts

1.19in

(30.27mm)

Model# 1452

Rating: Maximum voltage for

hands free use: 500 Vrms*, +122˚F

(+50˚C) max.

0.75in

(19.05mm)

BNC Female to Double

Banana Plug

2.05in (52.07mm)

0.75in

(19.05mm)

0.42in (10.67mm)

Model# 1468

4 solder turrets provide access between BNC and isolated banana plugs.

Rating: Maximum voltage for

hands free use: 500 Vrms*, +131˚F

(+55˚C) max.

BNC: isolated from Banana Plugs.

Material: Banana Plug Jack: brass;

Spring: heat treated beryllium copper; Finish: nickel plating.

2.30in (58.42mm)

(open)

BNC Male to Stackable

Isolated Binding Posts with 4 Terminals

0.42in

(10.67mm)

0.75in

(19.05mm)

Model# 1469

4 solder turrets for component attachments.

Use to make your own attenuator, balun, or filter.

Rating: Maximum voltage for

hands free use: 500 Vrms*, +131˚F

(+55˚C) max.

2.48in (62.99mm)

(open)

Insulated BNC Male to Dual

4 mm Banana Plugs/Jacks

2.5in

(63mm)

1.34in

(34mm)

Model#

72910

72937

Type

Plugs

Jacks

Rating: 500V Cat I, 150V Cat II.

BNC Male with Binding Post

0.44in

(11.18mm)

Model# 3430-*

Rating: Maximum voltage for

hands free use: 500 Vrms*, +239˚F

(+115˚C) max.

*Std. Colors: -0 Black, -2 Red.

1.55in

(39.37mm)

BNC Female to Single

Banana Plug

0.50in

(12.70mm)

2.03in (51.56mm)

Model# 1894

Rating: Hands free testing in controlled voltage environment:

500 Vrms*, +122˚F (+50˚C) max.

Insulated BNC Female to

Dual 4 mm Banana

Plugs/Jacks

1.34in

(34mm)

2.72in (69mm)

Model#

72911

72938

Type

Plugs

Jacks

Rating: 500V Cat I, 150V Cat II.

BNC Female to Miniature

Double Banana Plug

1.47in (37.34mm)

0.50in

(12.70mm)

Model# 3269

Allows a BNC male to be used with equipment having 0.50in

(12.70mm) spaced miniature banana jacks.

Rating: Maximum voltage for

hands free use: 500 Vrms*, +122˚F

(+50˚C) max.

BNC Male to Stackable

Binding Posts

1.19in

(30.27mm)

Model# 1296

Rating: Maximum voltage for

hands free use: 500 Vrms*, +122˚F

(+50˚C) max.

0.75in

(19.05mm)

2.49in (63.25mm)

(open)

BNC Male to Miniature

Stackable Binding Posts

0.88in

(22.35mm)

1.93in (49.02mm)

(open)

0.50in

(12.70mm)

Model# 3296

Binding posts also accept miniature double banana plugs.

Rating: Maximum voltage for

hands free use: 500 Vrms*, +122˚F

(+50˚C) max.

19

*see rating message at start of section.

www.pomonaelectronics.com

RF Coaxial Connectors, Adapters and Kits

20

BNC Female to Single

Banana Plug with Ground

Lead

1.54in

(39.12mm)

Model# 4684

Use with equipment having banana plugs or binding posts with non-standard spacing.

18 AWG Ground wire, 2.5in

(63.50mm) long.

Rating: Maximum voltage for

hands free use: 500 Vrms*, +131˚F

(+55˚C) max.

BNC 50Ω Attenuator

1.36in (34.54mm)

2.11in

(53.59mm)

BNC Male/Female with

DC-Blocking Series

Capacitor

1.98in (50.29mm)

Model# 5297

Use for sensitive RF measurements.

Rating: Maximum voltage for

hands free use: 500 Vrms*, +216˚F

(+102˚C) max.

Capacitor: 1000 pF, 600 Vdc.

BNC In-Series Resistor

Attenuator

1.98in (50.29mm)

Type N Male Terminator

Plugs

2.07in

(52.58mm)

Model#

4240-50

Ω

50

Rating: Frequency Range DC to

500 MHz, Power: 1W @ 158°F

(70˚C) max.

Accuracy: 1%.

BNC Within Series

Adapter Kit

Model#

4108-3dB

4108-6dB

4108-10dB

4108-14dB

4108-20dB dB

3dB

6dB

10dB

14dB

20dB

Rating: 2W Avg. @ 77°F (25°C) max.

50 Ω impedance. Metal film resistor attenuator.

Model#

4391-25

4391-50

4391-75

4391-600

Ω

25

50

75

600

Rating: Frequency Range DC to

500 MHz, +216˚F (+102˚C) max.

Add series resistance to coaxial lines.

1%, 2W, non-inductive film resistor.

Model# 5511

An assortment of Pomona’s popular

BNC within series adapters.

Kit contains one each:

BNC Female to Female 3283

BNC T (Female/Female/Female) 3284

BNC T (Female/Male/Female) 3285

BNC Male to Male 3533

BNC Right Angle Male to Female 3534

BNC T (Male /Female/Female) 4896

BNC Male Terminator Plugs

1.44in

(36.83mm)

Model#

3840-50

3840-75

Ω

50

75

Rating: Frequency range dc to

500MHz, power .5W @ 158°F (70˚C) max.

Accuracy: 1%.

BNC Shorting Cap or Dust

Model#

5085

3839

Type

Shorting cap

Dust cap

Shorting cap provides protection and supplies a short across an input.

Dust cap protects sensitive instrument inputs and is non-shorting.

Tarnish resistant plating.

3in (76.20mm) long chain.

BNC Feed-Thru Termination

1.45in

(36.83mm)

Model#

4119-50

4119-75

4119-600

Ω

50

75

600

Rating: 2W Carbon film resistor.

Accuracy: 2%.

Frequency Range: DC to 500 MHz,

+216˚F (+102˚C) max.

www.pomonaelectronics.com

*see rating message at start of section.

RF Coaxial Connectors, Adapters and Kits

BNC Straight RF Plugs

1.06in

(26.92mm)

Fig. 1: Compression Style

1.11in

(28.19mm)

Fig. 2: Crimp Style

0.90in

(24.88mm)

1.19in

(30.23mm)

Fig. 3: Crimp Style

0.90in

(24.88mm)

Fig. 5: Crimp Style*

BNC within Series Adapters

1.26in

(32.0mm)

1.11in

(28.1mm)

6701

1.30in

(33.02mm)

3284/6738

1.25in

(31.75mm)

3533/6740

1.32in

(33.53mm)

3283/6737

0.72in

(18.29mm)

Fig. 4: Crimp Style

0.490in

(12.47mm)

Rating: Maximum voltage for

hands free use: 500 Vrms.

BNC: Body: tarnish resistant nickel-plated brass; Center

Contact: male: gold-plated brass; female: gold-plated beryllium copper; Dielectric: PTFE.

*Performance: 4 GHz with

VSWR of 1.3 maximum from

0 to 4GHz.

**see data sheet on website for ratings.

Model# Type Fig. Cable Group RG /U BNC

50

Ω Impedance Compression

4488

BNC (m) 1 142, 142A, 142B, 223, 58, 58A, 58C, 5B, 5BA,

5BC, 8C, 141, 141A

4997

5307

BNC (m)

BNC (m)

50

Ω Impedance Crimp

5285

BNC (m)

1

1

RG58 only

174, 174A, 179B, 187, 187A, 188, 188A, 316

5344

7035*

7040*

73042**

BNC (f)

BNC (m)

BNC (m)

BNC (m)

2

2

2

3

RG58, 58A, 58C, 141, 141A

58, 58A, 58C, 141, 141A

RG55A, 142, 142A, 223, 400

RG179. 179B, 187, 187A, 174, 188, 188A, 316

73043**

73061

BNC (m)

BNC (m)

75

Ω Impedance

5286

BNC (m)

5

2

5

174, 188, 316

8, 9, 11, 213, 214

58, 141

6702A

6703A

6704A

6746A

BNC (m)

BNC (m)

BNC (m)

BNC (m)

4

4

2

4

59, 59A, 59B, 62, 62A, 62B, 62C, 210

59B, 20 AWG, Belden 1505A

6B, 18 AWG, Belden 1694A

59B, 23 AWG

6752A

7042

BNC (m)

BNC (m)

1

2

2

59, 59A, 59B, 62, 210, Belden 8241, 8263

59A, 59B, 62, 210, Belden 8241, 8263

Belden 1407B, 1417B, 1164B, 1167B, 1418B,

11467B, 11865A

0.92in

(23.37mm)

1.13in

(28.70mm)

1.27in

(32.3mm)

1.53in

(38.8mm)

3534 6700/6754

1.30in

(33.02mm)

1.50in

(38.10mm)

0.70in

(17.78mm)

0.88in

(22.35mm)

4896

1.55in

(39.37mm)

3847/6744

See Cutout

1.30in

(32.90mm)

6705

3285/6739

1.40in

(35.56mm)

0.69in

(17.53mm)

0.660in

(16.76mm)

0.624in

(16.00mm)

3846

See Cut-Out

0.50in (12.70mm)

0.47in

(11.95mm)

Panel Cut-Out for 3846/3847

Model# Type

50

Ω Impedance

3283

BNC (f/f)

3533

3285

3284

4896

3534

3847

3846

6700

6701

BNC (m/m)

BNC (f/m/f)

BNC (f/f/f)

BNC (m/f/f)

BNC (f/m)

BNC (f/f)

Special Features

Right Angle

Hermetically Sealed (b)

BNC (f/f) Isolated Ground (a)

BNC (f/m/f) In-line

BNC (f/m/f) Right Angle

75

Ω Impedance

6705

6737

6738

6739

6740

6744

6754

BNC (f/f)

BNC (f/f)

BNC (f/f/f)

Isolated Ground (a)

BNC (f/m/f)

BNC (m/m)

BNC (f/f)

BNC (f/m/f) In-line

Hermetically Sealed (b)

Notes: (a) Mounting hardware is isolated from outer conductor of BNC, (b) Leakage rate less than

10

-7

cc/sec of tracer gas at one atmosphere.

Rating: Maximum voltage for hands free use:

500 Vrms*, -85˚F to +329˚F (-65˚C to +165˚C).

BNC: Shell: tarnish resistant nickel-plated brass;

Center Contact: male: gold-plated brass; female: gold-plated beryllium copper; Dielectric: PTFE.

Bandwidth: to 4 GHz.

21

*see rating message at start of section.

www.pomonaelectronics.com

RF Coaxial Connectors, Adapters and Kits

22

BNC Panel Receptacles

1.21in (30.73mm)

2447/2447A

Dimensions for 6735

(not shown)

1.13in (28.6mm)

1.08in

(27.43mm)

BNC Female PCB Mount

0.16in

(4.06mm) long

1.15in

(29.25mm)

0.695in

(17.65mm)

4578/6747

1.31in

(33.25mm)

6717

0.94in

(23.87mm)

1.43in

(29.25mm)

(36.2mm)

2451/2451A

Dimensions for 6736

(not shown)

1.06in (26.9mm)

1.15in

0.453in

(11.50mm)

Cut-Out

0.125in

(3.18mm)

for 2447/2447A/6735

0.375in

(9.53mm)

0.125in

(3.18mm)

for 2451/2451A/6736

(see table for spacing)

Cut-Out

Model# Type

50

Ω Impedance

2447

BNC (m)

2451

2447A

BNC (f)

BNC (m)

2451A

BNC (f)

75

Ω Impedance

6735

BNC (m)

Spacing

0.531in (13.46mm) hole spacing center to center

0.50in (12.70mm) hole spacing center to center

6736

BNC (f)

0.50in (12.70mm) hole spacing center to center

0.50in (12.70mm) hole spacing center to center

BNC: Shell: tarnish resistant nickel-plated brass;

Center Contact: male: gold-plated brass; female: gold-plated beryllium copper; Dielectric: PTFE .

0.69in

(17.53mm)

4788/6748

1.31in

(33.25mm)

0.16in

(4.06mm) long

0.88in

(22.23mm)

7073

0.50in

(12.70mm)

0.25in

(6.35mm) long

1.43in

(36.2mm)

0.50in

(12.70mm)

Cut-Out for 4578/4788/7073

0.25in

(6.35mm)

6718

Model# Type

50

Ω Impedance

4578

Vertical BNC

4788

6717

R/A BNC

Dual R/A BNC

7073*

Straight

75

Ω Impedance

6718

BNC (f)

6747

6748

BNC (f)

BNC (f)

Material

Brass

White Valox

Brass

White Valox

Vertical

Right Angle

Rating: Maximum voltage for hands free use:

500 Vrms*, Impedance: 50 Ω, -85 to +329˚F

(+165 to -65˚C)

BNC: Body: tarnish resistant nickel-plated brass;

Contact: gold-plated beryllium copper. Dielectric: PTFE.

*Performance: 4 GHz with Vswr of 1.3 maximum from 0 to 4GHz.

0.10in

(2.54mm)

0.25in (6.35mm)

2x 0.079in (2.0mm)

0.20in

(5.08mm)

4x 0.40in

(10.16mm)

0.20in (5.08mm)

0.40in (10.16mm)

Cut-Out for 6717/6718

BNC Bulkhead Receptacles

1.08in (27.43mm)

4160/6745

1.10in (27.94mm)

3778/6741

1.24in (31.50mm)

4159/6741

0.50in

(12.7mm)

0.47in

(11.95mm)

Cut-Out for 3778

1.21in (30.73mm)

4979

1.32in (33.53mm)

0.35in

(8.89mm)

0.375in

(9.52mm)

Cut-Out for

5148

Model# Type

50

Ω Impedance

3778

5148

Special Features

BNC (f) Isolated Ground,

Teflon Insulation

BNC (f) Isolated Ground,

Valox Insulation

4159

4160

BNC (f)

Max. Panel

Thickness

0.18in (4.57mm)

0.175in (4.45mm)

Hermetically Sealed* 0.37in (9.40mm)

– 0.10in (2.54mm)

4979

BNC (m) –

75

Ω Impedance

6741

BNC (f) Isolated Ground

6745

BNC (f) –

0.19in (4.83mm)

* Leakage rate less than 10 -7 cc/sec of tracer gas at one atmosphere.

BNC: Body: tarnish resistant nickel-plated brass; Center Contact: male: gold-plated brass; female: gold-plated beryllium copper

(except as noted); Dielectric: PTFE.

Mounting hardware is isolated from outer conductor of BNC.

5148 www.pomonaelectronics.com

*see rating message at start of section.

**see data sheet on website for ratings.

RF Coaxial Connectors, Adapters and Kits

SMA within Series Adapters

0.90in

(22.86mm)

0.67in

(17.02mm)

0.64in

(16.26mm)

4283

Model# Type

4282

SMA (f) to (m),

Right Angle

4283

4284

SMA (m) to (m)

SMA (f) to (f)

SMA: Shell: gold-plated brass;

Center Contacts: gold-plated brass;

Dielectric: PTFE.

Frequency Range: 4283, 4284:

12.4GHz; 4282: 12GHz.

0.59in

(14.99mm)

4282

SMA Connector

8.38in

(0.33mm)

7.11in

(0.28mm)

7.92in (0.312mm) Hex

4804/4859 SMA(M)

4805 SMA(F)

4284

6.35in (0.250mm) Hex

SMA Female to Female

Bulkhead Receptacle

0.90in

(22.86mm)

0.26in

(6.60mm)

Panel Cut-Out

0.31in (7.87mm) Hex

Model# 4285

SMA: Shell: gold plated brass;

Center Contacts: gold plated brass;

Dielectric: PTFE.

SMA Shorting Cap

0.36in (9.14mm)

Model# 5088

Screw onto SMA female. Protects sensitive instrument inputs or provides a necessary reference short.

SMA: Shell: gold plated; Center

Contacts: gold-plated steel.

Model# Fits Cable Types

4804

RG174, 179, 187

4805

4859

RG188, 316

RG55, 142

Supplied with center conductor and sleeve.

Impedance: 50 Ω.

SMA: Shell: passivated steel;

Dielectric: PTFE.

0.31in (7.87mm) Hex

SMA Female Panel

Receptacle

0.67in

(17.02mm)

0.340in

(8.63mm)

Model# 4850

0.500in

(12.70mm)

Rating: Maximum voltage for hands

free use: 335 Vrms*, -85˚F to +329˚F

(-65˚C to +165˚C).

Impedance: 50

Ω.

SMA: Body: gold-plated stainless steel; Center Contact: gold-plated. beryllium copper; Dielectric: PTFE.

Flange thickness: 0.065in

(1.65mm).

SMA Male Terminator Plug

0.60in

(15.24mm)

0.31in (7.87mm) Hex

Model# 4286

Rating: Maximum voltage for hands

free use: 335 Vrms*.

Impedance: 50 Ω 1/2 W., 1%.

VSWR: 1.25 max. to 18GHz, 1/2 W,

85˚F to +329˚F (65˚C to +165˚C).

Resistor Terminator.

Gold-plated stainless steel with

Teflon insulation.

Panel Cut-Out

0.102in

25.91mm

x4

23

SMA Plug, 50Ω Termination

0.57in

(14mm)

72975

Bandwidth: 0-12.4 GHz on flexible cable.

Rating: For CE compliance and personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use:

500 Vpeak: RG58, 141, 143; 375

Vpeak: RG174, 188, 316. Do not use on circuits where transient stresses can exceed the rated voltage.

Materials: Body: machined brass, gold-plated finish; Center Contacts: plug: gold-plated brass; jack: gold-plated beryllium copper.

*see rating message at start of section.

www.pomonaelectronics.com

RF Coaxial Connectors, Adapters and Kits

24

RF SMA Connectors

Bandwidth: 0-12.4 GHz on flexible cable (see data sheet on website).

Rating: For CE compliance and personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 500 Vpeak: RG58, 141, 143; 375 Vpeak: RG174, 188, 316. Do not use on circuits where transient stresses can exceed the rated voltage.

Materials: Body: machined brass, gold-plated finish; Center Contacts: plug: gold-plated brass; jack: gold-plated beryllium copper.

Above specifications apply to the models on this page

SMA 50Ω Plug

0.93in (23.7mm)

Model# Description

72943

72944

72945

72946

72950

Straight Crimp

Straight Crimp

Straight Crimp

Straight Crimp

Straight Crimp,

Reverse Polarity

Cable Group

RG_/U

58

141

142, 400

174, 188, 316

174, 188, 316

SMA 50Ω Within

Series Adapters

0.87in (22.0mm)

0.87in (22.0mm)

72964

0.87in (22.2mm)

72974

0.87in (22.2mm)

SMA 50Ω Plug, Right-Angle

Crimp

0.69in (17.4mm)

0.67in

(17.1mm)

Model# Cable Group

RG_/U

72958

72959

72960

58

141, 174, 188,

316

142, 400

72966

0.71in (18.0mm)

72973

0.63in

(16.0mm)

Model# Description

72964

Plug (m/m)

72965

Right-Angle Plug to Jack

72966

Jack (f/f)

72967

Jack, Reverse

Polarity (f/f)

72973

Jack (f) to Jack (f)

72974

Jack to Reverse

SMA Plug

0.58in

(14.8mm)

72965

72967

SMA 50Ω Jack, Straight Crimp

0.55in (14.0mm)

Model# Cable Group

RG_/U

72952

72953

72954

141

142, 400

174, 188, 316

SMA 50Ω Jack, Bulkhead Crimp

0.75in (19.0mm)

Model# Cable Group

RG_/U

72956

174, 178, 188,

316

SMA 50Ω T Type

0.76in

(19.2mm)

72968

0.56in

(14.3mm)

0.76in

(19.2mm)

72969

Model# Description

72968

Jack (f)/

Jack (f)/Jack (f)

72969

Jack (f)/Plug (m)/

Jack (f)

0.68in

(17.3mm)

SMA 50Ω Jack, Panel

Receptacle

1.07in (27.3mm)

Model# Description

72961

2 Hole

72962

4 Hole

SMA 50Ω Jack,

Straight PCB

Receptacle

72963

0.53in (13.5mm)

SMA 50Ω Jack,

Straight PCB

Receptacle Edge

Mount

72970

0.53in (13.5mm)

www.pomonaelectronics.com

SMA 50Ω Jack,

Right-Angle

PCB Receptacle

0.58in (14.8mm)

0.53in

(13.4mm)

72971

*see rating message at start of section.

RF Coaxial Connectors, Adapters and Kits

0.73in (18.5mm)

RF SMB Connectors

Bandwidth: 3-4 GHz, depending upon connector (see data sheet on website).

Materials: Body: machined brass, gold-plated finish; Center Contacts: plug: gold-plated brass; Jack: gold-plated beryllium copper.

Rating: For CE compliance and personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 250 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage.

Above specifications apply to the models on this page except 5375

SMB Jack, Straight Crimp

Model#

72983

72984

72985

Ω

Cable Group

RG_/U

50 178, 196

50 174, 188, 316

75 179, 187

SMB 50Ω Plug,

Panel Receptacle

72999

0.78in (19.7mm)

SMB 50Ω Plug,

Straight PCB

Receptacle

0.50in (12.8mm)

72995

25

SMB Jack, Right-Angle

Crimp

0.46in

(11.8mm)

Model#

72991

72992

72993

Ω

Cable Group

RG_/U

50

178, 196

174, 188, 316

75

179, 187

SMB 50Ω Jack,

Straight PCB

Receptacle

0.45in (11.4mm)

72996

SMB 50Ω Plug,

Right-Angle

PCB Receptacle

72997

0.57in

(14.6mm) 0.55in

(14.0mm)

0.45in

(11.4mm)

SMB Plug, Straight Crimp

0.79in (20.0mm)

Model#

72980

72981

72982

Ω Cable Group

RG_/U

50

178, 196

174, 188, 316

75 179, 187

SMB 50Ω Jack,

Right-Angle

PCB Receptacle

72998

0.61in

(15.5mm)

72980

SMB Plug, Right-Angle

Crimp

0.46in

(11.8mm)

Model#

Ω

Cable Group

RG_/U

72987

72988

72989

50

75

178, 196

174, 188, 316

179, 187

0.45in

(11.4mm)

0.54in

(13.6mm)

SMB Plug, Bulkhead

1.12in (28.5mm)

Model#

73000

73001

Ω Cable Group

RG_/U

50 174, 188, 316

75 179, 187

SMB Plug Connector

Crimp Type

1.22in (30.99mm)

Model# 5375

This SMB (Subminiature “B”) connector snap together for quick assembly.

Fit Cable Types: RG174, 179, 187, 188, 316

Rating: Maximum voltage for hands free use:

335 Vrms*, -85˚F to +329˚F (-65˚C to +165˚C).

Impedance: 50 Ω.

Frequency Range: DC to 4GHz.

SMB: Shell: tarnish resistant nickel-plated brass; Contact: male: gold-plated brass; female: gold-plated beryllium copper;

Dielectric: PTFE.

*see rating message at start of section.

www.pomonaelectronics.com

RF Coaxial Connectors, Adapters and Kits

26

0.70in (17.8mm)

RF MCX Connectors

Bandwidth: 3-6 GHz, depending upon connector. (see data sheet on website.)

Working Voltage: For CE compliance and personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 170 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage.

Materials: Body: brass, gold-plated finish; Center Contacts: plug: gold-plated brass; jack: gold-plated beryllium copper.

Above specifications apply to the models on this page

MCX Plug, Straight Crimp

Model#

73002

73003

73004

Ω

Cable Group

RG_/U

50

174, 316

178

75 179

MCX Jack, Straight Crimp

0.76in (19.3mm)

Model#

73010

73011

73012

Ω

Cable Group

RG_/U

50

174, 316

178

75 179

MCX Plug, Right-Angle

Crimp

0.42in (10.7mm)

0.34in

(8.6mm)

Model#

73005

73006

Ω

Cable Group

RG_/U

50

174, 316

178

MCX 50Ω

Jack, Straight

PCB Receptacle

73007

0.33in (8.3mm)

MCX 50Ω

Jack, Straight

Surface Mount

Receptacle

73018

0.23in (5.9mm)

MCX Plug, Straight

Semi-Rigid Crimp

0.46in (11.8mm)

MCX Plug, Right-Angle

Semi-Rigid Crimp

0.36in

(9.2mm)

0.36in

(9.2mm)

Model#

73014

73015

Ω

Cable Group

RG_/U

50

402

405

MCX 50Ω

Jack, Right-

Angle PCB

Receptacle

0.37in

(9.5mm)

73008

0.30in

(7.7mm)

Model#

73016

73017

Ω

Cable Group

RG_/U

50

402

405

www.pomonaelectronics.com

*see rating message at start of section.

RF Coaxial Connectors, Adapters and Kits

RF MMCX Connectors

Bandwidth: 3-6 GHz, depending upon connector (see data sheet on website).

Working Voltage: For CE compliance and personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 170 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage.

Materials: Body: brass, gold-plated finish; Center Contacts: plug: gold-plated brass; jack: gold-plated beryllium copper.

Above specifications apply to the models on this page

MMCX 50Ω Plug, Straight Crimp

0.57in (14.6mm)

Model# Cable Group

RG_/U

73023

73024

174, 316

178

MMCX 50Ω Jack, Straight

Crimp

0.52in (13.3mm)

Model# Cable Group

RG_/U

73029

73030

174, 316

178

27

MMCX 50Ω Plug, Right-Angle

Crimp

0.39in (10.0mm)

Model# Cable Group

RG_/U

73025

73026

174, 316

178

0.31in

(7.9mm)

MMCX 50Ω Jack, Straight

Semi-Rigid Crimp

0.53in(13.4mm)

Model# Cable Group

RG_/U

73037

405

MMCX 50Ω Plug, Straight

Semi-Rigid Crimp

0.53in (13.5mm)

Model# Cable Group

RG_/U

73034

73035

402

405

MMCX 50Ω

Jack, Right-

Angle PCB

Receptacle

73028

0.28in

(7.0mm)

MMCX 50Ω

Plug, Straight

Edgecard

73038

0.30in (7.7mm)

0.28in

(7.0mm)

MMCX 50Ω Plug, Right-Angle

Semi-Rigid Crimp

0.35in (9.0mm)

Model# Cable Group

RG_/U

73032

73033

402

405

MMCX 50Ω

Jack, Straight

Edgecard

0.31in (7.8mm)

73039

0.34in

(8.6mm)

*see rating message at start of section.

www.pomonaelectronics.com

RF Between Series Adapters

28

SMA to BNC

1.06in

(26.92mm)

4288

SMA to Type N

1.30in

(33.02mm)

4296

SMA to TNC

1.06in

(26.92mm)

4292

SMA to SMB

0.81in

(20.6mm)

72976

BNC to F

1.00in

(25.40mm)

6779

0.87in

1.01in

(25.65mm)

1.21in

(30.73mm)

(25.16mm)

(22.2mm)

72977

4290

4298

1.03in

4294

1.05in

(26.67mm)

6780 www.pomonaelectronics.com

0.70in

(17.9mm)

72978

1.25in

(31.75mm)

4289

1.28in

(35.12mm)

4297

1.17in

(29.72mm)

4293

1.25in

(31.75mm)

6781

0.76in

(19.2mm)

72979

1.00in

(25.40mm)

4291

1.17in

(24.72mm)

4299

1.06in

(26.92mm)

4295

1.22in

(31.0mm)

6782

Model# Type

4288

SMA (m) to BNC (m)

4290

4289

4291

SMA (m) to BNC (f)

SMA (f) to BNC (m)

SMA (f) to BNC (f)

Rating: Maximum voltage for hands free

use: 335 Vrms*.

Impedance: 50 Ω.

SMA: Shell: gold-plated brass; Center

Contacts: male: gold-plated brass; female: gold-plated beryllium coper;

Dielectric: PTFE.

Model# Type

4296

4298

SMA (m) to type N (m)

SMA (m) to type N (f)

4297

4299

SMA (f) to type N (m)

SMA (f) to type N (f)

Rating: Maximum voltage for hands free

use: 335 Vrms*.

Impedance: 50 Ω.

Material: Shell: gold-plated brass;

Center Contacts: gold-plated brass;

Dielectric: PTFE.

Model# Type

4292

SMA (m) to TNC (m)

4294

4293

4295

SMA (m) to TNC (f)

SMA (f) to TNC (m)

SMA (f) to TNC (f)

Maximum voltage for hands free use:

335 Vrms*.

Impedance: 50 Ω.

Material: Shell: gold-plated brass;

Center Contacts: gold-plated brass;

Dielectric: PTFE.

Model# Type

72976

72977

SMA (m) to SMB (m)

SMA (m) to SMB (f)

72978

72979

SMA (f) to SMB (m)

SMA (f) to SMB (f)

50

Bandwidth: 0-12.4 GHz on flexible cable.

Rating: For CE compliance and personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use:

500 Vpeak: RG58, 141, 143; 375 Vpeak: RG174,

188, 316. Do not use on circuits where transient stresses can exceed the rated voltage.

Materials: Body: machined brass, gold-plated finish; Center Contacts: plug: gold-plated brass; jack: gold-plated beryllium copper.

Model# Type

6779

BNC (m)/F (f)

6780

6781

6782

BNC (f)/F (f)

F (m)/BNC (f)

BNC (m)/F (m)

BNC: Shell: tarnish resistant nickel-plated brass; Center Contact: male: gold-plated brass; female: gold-plated beryllium copper

(except as noted); Dielectric: PTFE.

*see rating message at start of section.

RF Coaxial Connectors, Adapters and Kits

Type N Adapters

1.44in

(36.58mm)

3841

1.77in

(44.96mm)

5089

1.28in

(32.51mm)

Type N Male 50Ω Connectors

1.54in

(39.1mm)

1.23in

(31.2mm)

73048

1.09in

(27.7mm)

1.43in

(36.3mm)

3843

1.60in

(40.64mm)

3842

1.29in

(32.77mm)

1.28in

(32.51mm)

73049

1.00in

(25.5mm)

0.95in

(24.0mm)

1.08in

(27.5mm)

73044*

1.54in

(39.0mm)

73045*

1.67in

(42.5mm)

1.43in

(36.4mm)

Model# Type

3841

N (f/f)

3842

3843

N (m/m)

N (f/m)

5089

N (f/f/f)

73044*

N (m/f/m)

73045*

N (f/f) Pressurized Bulkhead

N: Body: nickel plated or bronze-plated white

brass; Center Contact: male: gold-plated brass, female: beryllium copper or phosphor

bronze, gold-plated; Dielectric: PTFE.

Impedance: 50 Ω.

Rating: Maximum voltage for hands free use:

1,000 Vrms*.

*see data sheet on website for ratings

Model# Type

73048

Cable Group RG /U BNC Rating

N (m) Right Angle 214, 225, 393 1000V

73049

73050

N (m) Right Angle 55, 142, 223

N (m) 58, 141

1500V

1500V

73051

73052

73062

N (m)

N (m) Semi-Rigid

N (m)

8, 213

402

8, 9, 144, 165, 213, 214,

216, 225

1500V

1500V

1000V

1.33in

(33.7mm)

N: Body: nickel-plated brass; Center Contact: gold-plated brass; Dielectric: PTFE.

Impedance: 50

Ω.

29

73050 73051 73052

Type N Male Straight

RF Connector Crimp

1.17in

(29.8mm)

Model# 7057

Fit Cable Types: RG55, 142, 223, 400.

Impedance: 50 Ω.

N: Body: bronze-plated white brass; Center

Contact: male: gold-plated brass; female: gold-plated heat treated beryllium copper;

Dielectric: PTFE.

Performance: 11 GHz with Vswr of

1.3 maximum from 0 to 11 GHz.

Use with crimp die set model 7281, crimp tool model 7277.

73062

Type N Male

Connectors

1.37in

(34.80mm)

Type N Panel Mount Receptacle

1.35in

(34.29mm)

0.718in

(18.24mm)

ø 0.125in

(3.18mm)

2455

ø 0.641in

(16.28mm)

Panel Cut-Out for 2455

Type N to TNC

1.39in

(35.4mm)

1.35in

(34.29mm)

4956

Model#

73046

Type

N (f)/TNC (m)

N/TNC: Body: nickel-plated brass; Center

Contact: gold-plated phosphor bronze;

Insulators: PTFE.

Impedance: 50

Ω.

Rating: Maximum voltage for hands free use:

1500 V.

0.718in

(18.24mm)

ø 0.125in

(3.18mm)

ø 0.641in

(16.28mm)

Panel Cut-Out for 4956

Type N to UHF

1.38in

(35.1mm)

*see rating message at start of section.

*see data sheet on website for ratings.

Model# 4787

Fit Cable Types: RG58 and 142, 223,

141, 400.

N: Body: bronze-plated white brass; Center

Contact: male: gold-plated brass; female: gold-plated beryllium copper; Dielectric: PTFE.

Impedance: 50 Ω .

Rating: Maximum voltage for hands free use:

1,000 Vrms*.

Model#

2455

4956

Type

N (f)

N (f)

N: Body: bronze-plated white brass; Center

Contact: female: gold-plated beryllium copper;

Dielectric: PTFE.

Impedance: 50 Ω.

Rating: Maximum voltage for hands free use:

1,000 Vrms*.

Model#

73047

Type

N (f)/UHF (m)

N/UHF: Body: nickel-plated brass; Center

Contact: gold-plated phosphor bronze;

Insulators: PTFE.

Rating: Maximum voltage for hands free

use: 750 V.

www.pomonaelectronics.com

RF Coaxial Connectors, Adapters and Kits

30

2 Lug f f

2 Lug m f

3 Lug m m

Triaxial Cable Plugs and Jacks

1.53in

(38.86mm)

1.53in

(38.86mm)

3600/5056

(Mates with 3580 and 4388)

1.43in

(36.32mm)

5218

(Mates with 5219)

4661

0.47in

(12.01mm)

0.50in

(12.7mm)

Model#

3600

4661

5056

5218

Lugs

2 Lug (m)

3 Lug (m)

Max. Panel

Thickness

Fits Cable Types

2 Lug (m)

Belden twinaxial 9272

0.242in (6.15mm) O.D.

2 Lug (f) 0.14in (3.56mm) Microdot 293-3930

0.175in (4.45mm) O.D.

Belden triaxial 9222

0.242in (6.15mm) O.D.

Triaxial: Body/Fittings: tarnish resistant nickel-plated brass; Center

Contact: male: gold-plated brass; female: gold-plated beryllium copper;

Outer Contact: gold-plated beryllium copper; Dielectric: PTFE.

Panel Cut-Out for 4661

Triaxial Adapters

1.50in

(38.10mm)

5290

1.39in

(35.31mm)

5178

0.47in

(11.94mm)

0.50in

(12.7mm)

Model#

5178

5290

Lugs

2 Lug (f)

2 Lug (f)

Max. Panel Thickness

0.25in (6.35mm)

Triaxial: Body/Fittings: tarnish resistant nickel-plated brass; Center

Contact: female: gold-plated beryllium copper; Outer Contact: gold-plated beryllium copper; Dielectric: PTFE.

Cut-Out for 5178

Triaxial Female Bulkhead Receptacles

1.16in

(29.46mm)

1.31in

(33.27mm)

0.50in

(12.70mm)

0.375in

(9.53mm)

3580

0.35in

(88.90mm)

Cut-Out for 3580 and 4388

0.60in

(15.24mm)

0.453in

(16.5mm)

4388

0.417in

(10.59mm)

Panel Cut-Out for 5219

0.50in

(12.70mm)

1.16in

(29.46mm)

5219

Model# Lugs

3580

2 lug (f)

4388*

2 lug (f)

Max. Panel Thickness

0.25in (6.35mm)

0.25in (6.35mm)

5219

3 lug (f) 0.14in (3.56mm)

*Hermetically sealed leakage less than

10-7 cc/sec tracer gas at one atmosphere.

Triaxial: Body/Fittings: tarnish resistant nickelplated brass; Center Contact: female: gold-plated beryllium copper; Outer Contact: gold-plated beryllium copper; Dielectric: PTFE.

Twinax Cable

Plug

1.13in

(28.70mm)

Model# 4957

Use on twinaxial cable types RG108 and Belden 9272.

Polarized Contact (One Male, One Female).

Rating: Maximum voltage for hands free use: 500 Vrms*,

-85 to +329˚F (-65 to +165˚C).

Material: Body: tarnish resistant nickel-plated brass;

Contact: male: gold-plated brass; female: gold-plated beryllium copper; Dielectric: PTFE.

F Adapters and

PCB Mount Connectors

1.10in

(28.0mm)

0.84in

(21.4mm)

1.031in

(26.20mm)

6801

6802

Model# Type

6801

F (M/F) In-Line adapter

6802

6803

F (F/F) Bulkhead adapter

F (F) PCB mount connector

Material: These 75

Ω connectors are designed for fast installation with no crimping. Connectors are precision machined brass with nickel plating and gold plated center contacts.

Twinax Bulkhead

Receptacle

1.13in

(28.70mm)

Model#

4958

Max. Panel Thickness

0.13in (3.30mm)

0.38in

(9.65mm)

0.35in

(8.68mm)

Rating: Maximum voltage for hands free use:

500 Vrms*, -85 to +329˚F (-65 to +165˚C).

Polarized Contact (One Male, One Female).

Material: Body: tarnish resistant nickel-plated brass; Contact: male: gold-plated Bbrass; female: gold-plated beryllium copper;

Dielectric: PTFE.

Panel Cut-Out

F Female to Female

Bulkhead Receptacle

0.80in

(20.4mm)

F within Series Adapters

1.0in

(25.4mm)

0.92in

(23.3mm)

Model# 6706

In line, with nut and washer

Material: Machined, nickel-plated brass.

Model# Type

6712

F (m/f) Right angle

6713

F (m/f) In line,

Push-on

Material: Machined, nickel-plated brass.

6803

6712

6713 www.pomonaelectronics.com

*see rating message at start of section.

RF Between Series Adapters

Triaxial to BNC

1.37in (34.80mm)

5299

BNC to TNC

1.23in

(31.24mm)

UHF to BNC

1.31in

(33.27mm)

3287

1.46in

(37.08mm)

1.50in (38.10mm)

5298

1.35in (34.29mm)

5090

1.35in (34.29mm)

5300

Triax BNC

Triaxial shell is shorted to outer shield

BNC

Model# Type

3844

BNC (f)/TNC (m)

Rating: Maximum voltage for hands free use:

500 Vrms*, -85˚F to + 325˚F

(-65˚C to +165˚C) (except as noted).

Impedance: 50 Ω (except as noted).

BNC: Shell: tarnish resistant nickel-plated brass;

Center Contact: male: gold-plated brass; female: gold-plated beryllium copper (except as noted);

Dielectric: PTFE.

Traix

BNC Female to Phono

(RCA) Male

1.28in

(32.5mm)

BNC Male to Phono Jack

1.40in

(35.56mm)

Model# Type

5299

3 Lug Triax (f)/BNC (m) adapter

5298

5090

2 Lug Triax (f)/BNC (m) adapter

BNC (f)/2 Lug Triax (m) adapter

5300

BNC (f)/3 Lug Triax (m) adapter

Triaxial: Body: tarnish resistant nickel- plated brass; Center Contact: male: gold-plated brass; female: gold-plated beryllium copper; Outer Contact: goldplated beryllium copper; Dielectric: PTFE.

Model# 5319

Rating: Hands free testing in controlled voltage environment:

500 Vrms*, 216˚F (+102˚C) max.

BNC: Center Contact: gold-plated.

Model# 4054

Rating: Hands free testing in controlled voltage environment:

500 Vrms*, +257˚F (+125˚C) max.

Model#

3287

3286

Type

BNC (m)/

UHF (f)

BNC (f)/UHF

(m)

Special Features

Phos. Bronze

Contact

Nonconstant

Impedance

Nonconstant

Impedance

Rating: Maximum voltage for hands free use:

335 Vrms*, -85 to +325˚F (-65 to +165˚C)

(except as noted).

Impedance: 50 Ω (except as noted).

UHF: Shell: tarnish resistant nickel-plated brass;

Center Contact: male: gold-plated brass; female: gold-plated beryllium copper (except as noted);

Dielectric:

PTFE.

BNC Female to 1/4in

(6.35mm) Phone Plug

2.46in (62.48mm)

0.25in (6.35mm)

Model# 1297

0.25in

(6.35mm)

Rating: Hands free testing in controlled voltage environment:

500 Vrms*, +257˚F (+125˚C) max.

Convert 2 conductor audio jacks to BNC.

31

3286

Type N to BNC

1.46in

(37.08mm)

3535

1.46in

(37.08mm)

Model# Type

3535

BNC (m)/N (f)

3288

Special Features

BNC (f)/N (m) Beryllium Copper

Male Contact

Rating: Maximum voltage for hands free use:

500 Vrms max., -85 to +325˚F (-65 to +165˚C)

(except as noted).

Impedance: 50

Ω (except as noted).

N: Shell: tarnish resistant nickel-plated brass;

Center Contact: male: gold-plated brass; female: gold-plated beryllium copper (except as noted);

Dielectric: PTFE.

BNC Female to Two

Conductor, 0.14in (3.5mm)

Dia. Mini Phone Plug

1.92in (58.77mm)

0.141in

(3.58mm)

Model# 3837

Rating: Hands free testing in controlled voltage environment:

500 Vrms*, +257˚F (+125˚C) max.

Convert 2 conductor audio jacks to BNC.

3288

*see rating message at start of section.

www.pomonaelectronics.com

RF Between Series Adapters

32

TNC Connectors

0.94in

(23.9mm)

0.98in

(25.0mm)

TNC Adapter

0.98in

(25.0mm)

1.24in

(31.4mm)

73054

1.00in

(25.4mm)

1.35in

(34.4mm)

Model# Type

73054

73056

TNC (m)

Right Angle

TNC (m)

73057

TNC (m)

Cable Group RG /U BNC

55, 142, 223, 400

58, 141

59, 62

N: Body: nickel-plated brass; Center Contact: gold-plated brass; Insulators: PTFE.

Impedance: 50 Ω.

Rating: Maximum voltage for hands free use: 1500 V.

73056

73057

Model# Type

73053

TNC (f/m) Right Angle

N/TNC: Body: nickel-plated brass;

Center Contact: male: gold-plated brass, female: gold-plated phosphor bronze;

Insulators: PTFE.

Impedance: 50 Ω.

Rating: Maximum voltage for hands free

use: 1500 V.

UHF Connectors

1.77in

(45.0mm)

Model#

73059

Type

UHF (m)

Cable Group RG /U

8, 9, 11, 63, 87A, 213,

214, 225

UHF: Body: nickel-plated brass; Center Contact: gold-plated phosphor bronze; Insulators: PTFE.

Rating: Maximum voltage for hands free use: 750 V.

UHF Adapter

1.18in

(30.0mm)

2.75in (69.85mm)

Model# Type

73058

UHF (f/f)

UHF: Body: nickel-plated brass; Center

Contact: gold-plated phosphor bronze;

Insulators: PTFE.

Rating: Maximum voltage for hands free

use: 750 V.

Strain Relief

Boot

2.75in (69.85mm)

Model#

5155-*

5156-*

5157-*

Fits Cable Types

RG 58, 141

RG 59, 62, 210

RG 174, 187, 188

For Cable O.D.

0.185in - .200

(4.70mm - 5.08mm)

0.237in - .247in

(6.02mm - 6.27mm)

0.090in - .110in

(2.29mm - 2.79mm)

Rating: +122˚F (+50˚C) Max.

Use with crimp type connectors.

Sold in packages of 10.

*Std. Colors: -0 Black, -2 Red

BNC Male with Strain Relief Boot

Make your own cable with strain relief.

5076: Black boot with nut only.

For use with connectors using a 7/16-28 clamp nut. Simply replace supplied nut with the one on the boot.

Rating: Maximum voltage for hands free

use: 500 Vrms*, +122˚F (+50˚C) max.

Model# Fits Cable Types

5066-*

5068-*

5076-*

RG 58, 141

RG 174, 187, 188

RG 58, 141

*Available in -0 black only

For Cable O.D.

0.185in - 0.200

(4.70mm - 5.08mm)

0.090in - 0.110in

(2.29mm - 2.79mm)

0.185in - 0.200in

(4.70mm - 5.08mm)

www.pomonaelectronics.com

*see rating message at start of section.

Banana Plugs and Jacks

Just need a reliable plug or jack? Making your own test set? Pomona

Electronics’ selection is designed to meet demanding electrical characteristics. Nickel-plated plugs feature brass bodies and one-piece heat-treated beryllium copper springs with nylon or ABS insulation. Choose Pomona for the reliable and dependable connections your work demands.

Double Banana

Plug with

Wire Guide,

Stackable,

Solderless

1.55in

(39.37mm)

1.13in

(28.70mm)

0.75in

(19.05mm) x-hole ø .125in

(3.175mm)

Model# Plating Insulation *Std. Colors

MDP-*

Nickel Polypropylene -0 Black, -1 Brown,

-2 Red, -3 Orange,

-4 Yellow, -5 Green,

-6 Blue, -7 Violet,

-8 Gray, -9 White

4892-*

4898-*

Gold Polypropylene -0 Black, -2 Red

Nickel Polyphenylene

Sulfide

-0 Black, -6 Blue

4914

Set screws 8-32 x 0.210in (5.33mm), 100/pk

Set screws secure wire. Simplifies cable construction or component mounting. Accepts cables to 0.22in (5.59mm) dia. max., (18-22 AWG wire).

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.

15A, +122˚F (+50˚C) (Model 4898, +302˚F (+150˚C) max.).

Double Banana Plug with Shorting Bar

1.13in

(28.70mm)

1.55in

(39.37mm)

0.75in

(19.05mm) x-hole 0.166in

(4.216mm)

Model# MDP-S-*

Banana plugs internally shorted with #18 AWG wire.

X-hole accepts standard banana plug.

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating; Insulation: Polypropylene.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red, -9 White.

Model# 4914

Set screws 8-32 x 0.210in (5.33mm), 100/pk.

Double Banana Plug with Solder Turret

Terminals

1.13in

(28.70mm)

1.55in

(39.37mm)

0.75in

(19.05mm)

Model# MDP-ST

Similar to MDP above except with bright tin plated solder turrets. Accepts cables to

0.215in (5.46mm) dia. max.

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating;

Insulation: polypropylene.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +131˚F (+55˚C) max.

Color: Black.

Double Banana

Plug, Stackable,

Solderless

1.13in

(28.70mm)

1.55in

(39.37mm)

Model# 1330-*

Similar to MDP without cable loop.

Features recess for mounting small components with set screws.

Model 1330 has setscrews like MDP.

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating;

Insulation: Polypropylene.

0.75in

(19.05mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.15A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model# 4914

Model# 4914

Set screws 8-32 x 0.210in (5.33mm), 100/pk.

Double Banana Plug with Solder Turret

Terminals

1.13in

(28.70mm)

1.55in

(39.37mm)

0.75in

(19.05mm)

Set screws 8-32 x 0.210in (5.33mm), 100/pk.

Model# 1330-ST-*

Similar to Model 1330 above, but features bright tin plated solder turrets.

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating;

Insulation: polypropylene.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +122˚F (+50˚C) max.

Isolated Double

BananaPlug with Four

SolderTerminals

Model# MDP-X

Use to make your own attenuator, balun or filter.

Jacks are isolated from plugs.

0.75in

(19.05mm)

1.13in

(28.70mm)

2.13in

(54.10mm)

0.5in (12.7mm)

0.75in

(19.05mm)

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating;

Insulation: Polypropylene; Solder turrets; bright tin plated.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Color: Red.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

33

Banana Plugs and Jacks

34

Isolated Double Banana

Plug with Three Solder

Terminals

Model# 1837

Use to make your own attenuator, balun or filter.

One jack is isolated.

0.75in

(19.05mm)

2.16in

(54.86mm)

0.75in

(19.05mm)

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating; Insulation: polypropylene; Solder

turrets; bright tin plated.

1.13in

(28.70mm)

0.5in (12.7mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +131˚F (+55˚C) max.

Color: Blue.

4mm Safety Banana

Jack to Banana

Plug Adapter

1.85in (47.0mm)

Model# 6728

Accepts safety-sheathed 4mm banana plug and adapts to standard banana plug.

Material: nickel plated brass.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum, -10 to +55°C.

*Std. Colors: -0 Black, -2 Red.

Double Banana Plug

Splice

1.13in

(28.70mm)

1.50in

(38.10mm)

0.75in

(19.05mm)

Model# 1823-*

Provides rapid method for splicing cables.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Isolated Single Banana

Plug with Two Solder

Terminals

0.38in

(9.65mm)

0.5in

(12.7mm)

2.13in (54.10mm)

Model# 1390-*

Ideal for computers, lab circuit design and testing.

Jack is isolated from plug.

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating; Insulation: polypropylene; Solder

turrets; bright tin plated.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.15A,+131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

QUAD Stacking Plug

0.38in

(9.65mm) 0.5in (12.7mm)

2.65in (67.31mm)

Model# 3364-*

Features one in-line stacking and three cross-stacking connections.

All jacks are connected to plug.

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating; Insulation: ABS.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +122˚F (+50˚C) Max.

*Std. Colors: -0 Black, -2 Red.

Single Banana Plug

Splice

1.50in (38.10mm)

0.38in

(9.65mm)

Model# 1829-*

Provides rapid method for splicing single banana plug patch cords.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +55˚C (+131˚F) max.

*Std. Colors: -0 Black, -2 Red.

Insulated Double Banana

Model# 5145

Plug Shorting Bar

Shorting bar is completely insulated in clear

ABS thermoplastic.

0.99in

(25.15mm)

1.35in

(34.29mm)

0.75in (19.05mm)

Fits standard 0.166in (4.22mm) dia. banana jack.

Material: Banana Plug Body: brass; Spring: beryllium copper; Finish: nickel plating.

Rating: 15A, +122˚F (+50˚C) max., resistance less than 1.5m

Ω.

Triple Banana Plug,

Stackable, Solderless

1.88in

(47.75mm)

1.55in

(39.37mm)

0.75in

(19.05mm)

Model# 2970-*

Use for balanced line 2 conductor shielded cable assemblies. Accepts cables to 0.250in

(6.35mm) dia. max., Setscrews secure wires.

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Finish: nickel plating; Insulation: Polypropylene.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.15A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Do-It-Yourself 4mm

Stackable Banana Plug,

Solder

2.3in (58.4mm)

Model# 6721

Build your own safety stacking leads with do-it-yourself safety-sheathed 4mm stackable banana plugs.

Material: Contacts: nickel-plated brass,

Insulation: lucel acetal polymer.

Rating: IEC61010 1000V Category III**,

20A, 14 to 176°F (-10 to +95°C).

*Std. Colors: -0 Black, -2 Red.

** When plug is correctly assembled and terminated.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Banana Plugs and Jacks

Do-It-Yourself In-Line Sheathed

(4mm) Banana Plug and Jack

3.01in (76.45mm)

6383

1.44in

(36.58mm)

Safety-rated plugs and jacks for use with any wire from 22 to 18 AWG with flexible insulation.

Attaches to wire by crimp or soldering.

Plugs fit most sheathed DMM jacks and DMM test leads to make up your own banana plug or jack test lead or jumper.

See mating panel jacks (6387 on page 37).

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Insulation:

Santoprene

®

.

Rating: CAT II 300V, 15A, +275°F (+135°C) max.

*Std. Colors: -0 Black, -2 Red, -02 Black and Red (2 per pkg).

*Sold in pkgs of 10.

Model#

6383-*

6383-02

6384-*

6384-02

Type

Plug

Jack

6384

Do-It-Yourself Solderless Stackup

Banana Plug with Safety Shield

Internal set screw holds wire firmly.

Safety collar insulates exposed wire leads.

0.78in

(19.81mm)

0.16in (4.06mm)

Max. insulation dia.

Accepts standard banana plug and fits 0.166in (4.22mm) dia. banana jack.

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper.

0.44in

(11.17mm)

1.55in (39.37mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum. Maximum voltage

for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.15A, +122˚F

(+50˚C) max. (Model 4899, +302˚F (+150˚C) max.).

Accepts 18-22 AWG wire.

Model# Plating

4897

4899

Insulation Std. Colors

1825-*

Nickel Polypropylene -0 Black, -1 Brown,

-2 Red, -3 Orange,

-4 Yellow,

-5 Green, -6 Blue,

-7 Violet,

-8 Gray, -9 White.

Sold in pkgs of 10

Gold Polypropylene -0 Black, -2 Red

6545

Nickel Polyphenylene

Sulfide

-0 Black, -6 Blue

Sold in pkgs of 10

Nickel Polypropylene Pkg of 1 ea. of all

10 colors

Do-It-Yourself Solderless Stackup

Banana Plug

4914 set screws 8-32 x 0.210 (5.33mm), 100/pk.

Internal set screw holds wire firmly.

0.44in

(11.18mm)

1.55in

(39.37mm) x-hole 0.125in

(3.17mm)

Model# Plating Insulation

1325-* Nickel Polypropylene

Accepts standard banana plug, fits standard 0.166in

(4.22mm) dia. banana jack.

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.15A, +122˚F

(+50˚C) max. (Model 5230, +302˚F (+150˚C) max.).

Accepts 18-22 AWG wire.

5406

5230

6546

Gold Polypropylene

Nickel Polyphenylene

Sulfide

Nickel Polypropylene

*Sold in pkgs of 10.

Std. Colors

-0 Black, -1 Brown,

-2 Red, -3 Orange,

-4 Yellow, -5 Green,

-6 Blue, -7 Violet,

-8 Gray, -9 White.

-0 Black, -2 Red

-0 Black, -6 Blue

Pkg of 1 ea. of all

10 colors

Do-It-Yourself 4mm Right

Angle Banana Plug

1.28in

(32.4mm)

Model# 6729

Build your own safety leads with do-ityourself safety-sheathed 4mm right angle banana plug.

Material: Contacts: nickel-plated brass;

Insulation: lucel acetal polymer.

Do-It-Yourself

Retractable

Sheath Banana Plug

2.56in (65.02mm)

0.39in (9.90mm)

Rating: IEC61010 1000V Category III**,

20A, 14 to 176°F (-10 to +55°C).

*Std. Colors: -0 Black, -2 red.

** When plug is correctly assembled and terminated.

Model#

122505A

122506A

Color

Black

Red

Do-It-Yourself Retractable Sheath Banana

Plugs provide fast simple assembly and reliable performance.

Rating: For CE CAT II 300V, CAT III 150V.

Maximum voltage for hands free use:

1000 Vrms, 20A, ≤ 2 mΩ.

Accepts 18-22 AWG wire.

Do-It-Yourself

In-Line Sheathed

Banana Plug/

Banana Jack

1.06in

(26.92mm)

1.55in

(14.99mm)

0.36in (9.14mm)

4933/4986 Plugs

0.28in (7.11mm)

4934 Jacks

Model# Accepts wire AWG

4933-* 22, 20, 18

4986-*

16, 14

4934-* 22, 20, 18

Wire Access

Hole

0.159in

(4.04mm) Dia.

0.200in

(50.8mm) Dia.

0.159in

(4.04mm) Dia.

Type

Plug

Plug

Jack

These plugs and jacks are designed to fit together and provide protection from accidental shorting.

Material: Banana Plug/Jack: brass; Spring: beryllium copper; Insulation: polypropylene.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use:

1200V ac/dc. Do not use on circuits where transient stresses can exceed the rated voltage.15A, +176˚F

(+80˚C) max.

*Std. Colors: -0 Black, -2 Red.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

35

Banana Plugs and Jacks

36

Rivet Type Banana

Plug

0.16in

(4.06mm)

0.56in

(14.22mm)

Model#

3257

3258

“X”

0.094in

(2.39mm)

0.125

(3.17mm)

Panel

0.062in

(1.57mm)

0.093in

(2.36mm) x

Rivet

I.D. - 0.14in (3.56mm)

O.D.- 0.25in (6.35mm)

0.135in (3.43mm)

Excellent for riveting to panels or boards.

Fits standard 0.166in (4.22mm) dia. banana jack.

Material: Banana Plug Body: brass; Spring: beryllium copper; Finish: nickel plating.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A.

Sold in pkgs. of 10.

Rivet Type Banana

Plug with Turret

0.135in

(3.43mm)

0.188in

(4.78mm)

0.135in (3.43mm)

Banana Plug with

Threaded Stud and

Solder Lug

0.16in

(4.06mm)

0.56in

(14.22mm)

Model# 3261

Excellent for riveting to panels or boards. Solder turret for rapid attachment of wires.

Fits standard 0.166in (4.22mm) dia. banana jack.

Material: Banana Plug Body: brass; Spring: beryllium copper; Finish: nickel plating.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A.

Sold in pkgs. of 10.

Model#

3263

3264

4512

Thread

6-32 x .50in (12.70mm)

8-32 x .50in (12.70mm)

8-32 x .63in (16.00mm)

Thread

0.16in

(4.06mm)

0.56in

(14.22mm)

Insulated Banana

Plug and Jack with

Flexible Boot, Solder or Crimp

Fits standard 0.166in (4.22mm) dia. banana jack.

Material: Banana Plug Body: brass; Spring: beryllium copper; Finish: nickel plating.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands

free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.15A.

Sold unassembled, in pkgs. of 10.

Model# Accepts wire AWG

5169-*

22, 20, 18

5170-*

16, 14

5167-*

22, 20, 18

5168-*

16, 14

Type Mates with...

Plug

Jack

Jack 5167

Jack 5168

Plug 5169

Plug 5170

5169/5170 Boots

5167/5168 Jacks

Ideal for making patch cords or field repairs.

Snap-on flexible PVC boot allows wire to be crimped or soldered to banana plug or jack.

Fits standard 0.166in (4.22mm) dia. banana jack.

Material: Boot: Banana Plug Body: brass;

Spring: beryllium copper; Finish: nickel plating;

Jack: nickel plated brass.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free

use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.

15A, +122˚F (+50˚C,) max.

*Std. Colors: -0 Black, -2 Red.

Banana Plug with Screw and

Soldering Lug

4mm Banana

Plug with

Threaded M3 Stud

Panel Mount IEC61010

Banana Jacks for

Sheathed Plugs

72912

72913

72930

0.97in (24.63mm)

1.34in (34mm)

1.34in (34mm)

Panel Mount IEC61010

4 mm (0.16in) Banana

Jack for Sheathed Plugs

0.57in

(14.5mm)

0.56in

(14.22mm)

0.75in

(19mm)

0.57in

(14.5mm)

Panel Cut-Out

Terminal Strip

Adapter, 4mm

Safety Banana

Jack to 6/32

1.56in (39.62mm)

Model#

3265

3266

Thread

6-32 x 0.25in (6.35mm)

8-32 x 0.25in (6.35mm)

Fits standard 0.166in (4.22mm) dia. banana jack.

Material: Banana Plug Body: brass; Spring: beryllium copper; Finish: nickel plating.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use:

5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A.

Sold unassembled, in pkgs. of 10.

Model# 72918

4mm plug with threaded M3 stud, 2 nuts; 12mm

(0.5in) stud length.

Sold unassembled, in pkgs. of 10.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use:

5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 36A.

Model# Color

72912-0 Black

72912-2

Red

72913-0 Black

72913-2

Red

72930*

Terminal

Threaded Stud

Solder Tab

Threaded Stud,

Hexagonal Nut

Material: Gold-plated nickel

(72912 and 72913).

Rating: 1000V Cat III, 36A Max.

*Std. Colors: all except -3 orange,see below

Sold in packages of 10 per color.

Model# 5931-*

Accepts flexible test lead sets 5907A,

5908A, 5909A available on page 68.

Max. Panel Thickness: 0.28in

(7.0mm).

Insulation: Nylon.

Rating: 1000 V Cat III per

IEC61010-031 and IEC61010-1, 25A.

*Std. Colors: -0 Black, -2 Red,

-5 Green, -6 Blue, -9 White.

Sold in pkgs. of 10 per color.

Model# 6720

Easily connect your DMM safety sheathed test leads to terminal strips via this handy 6/32 thread adapter.

Material: Contacts: nickel-plated brass, Insulation: lucel acetal polymer.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds 8A maximum.

(14 to 212°F) -10 to +55°C.

*Std. Colors: -0 Black, -2 Red.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Banana Plugs and Jacks

Panel Mount Banana

Jacks with Mounting Base

1.22in

(31.0mm)

1.38in

(35.05mm)

0.75in

(19.05mm)

Typical

Panel Cut-Out

2.13in

(54.10mm)

1.22in

(31.0mm)

Model#

2269-*

5233-0

4601-*

Mounting Base

Double

Double High-Temp

Triple

Mounts in panels from 0.063in

(1.60mm) to 0.375in (9.53mm) thick. One black, one red. Triple has green.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc.

Do not use on circuits where transient stresses can exceed the rated voltage. 15A.

Temp: +239F (+115°C) [5233-0:

+220°F (+428°C)].

*Mounting base color: -0 Black,

-2 Red.

Replacement hex nuts available on page 39.

Panel Mount Banana

Jacks for Sheathed

Plugs

.43in

(11.43mm)

Panel Cut-Out

50 x 28 thread

ST

6387-T-P-C

Model#

6387-ST-T-*

Std. Colors

-0 Black, -2 Red

These banana jacks fit most DMM plugs and all sheathed Pomona plugs. Available with several different terminals. Threaded and press-in style.

Rating: Designed to meet IEC61010 CAT III

1000 Vrms., 15A.

Sold in packages of 10.

Comes with Hex Nut and Lock Washer.

Replacement hex nuts available on page 39.

Color Options: -0 Black, -2 Red.

Plating Option: T=Tin

Terminal Type: ST = Solder Turret

0.75in (19.05mm)Typical

Uninsulated Banana Jack

1/4-32 thread

0.50in

(12.7mm)

0.094in

(2.39mm)

5/16in

(7.92mm) Hex.

Panel Cut-Out

Model# 3267

Fits standard banana plug.

Material: nickel-plated brass.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A.

Replacement hex nuts available on page 39.

Terminal Strip

Banana Jack

Adapter

Model# Thread Vrms Torque In/Lb X Stud Length

5699-*

6-32 1100

5700-*

8-32 1600

5701-* 10-32 1700

7

16

25

0.25in (6.35mm)

0.32in (8.13mm)

0.32in (8.13mm)

5/16in

(7.92mm)Hex.

0.80in

(20.32mm)

X

This adapter provides a banana jack connection by replacing the screw in a terminal strip. Secure connections can be made with standard banana plug patch cords without breaking the connection to the terminal strip. Banana jack 0.166in (4.22mm) dia.

Material: Banana Jack: nickel-plated brass; Insulation: Nylon.

*Std. Colors: -0 Black, -2 Red, -3 Orange, -4 Yellow, -9 White.

Ratings: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands

free use: (see chart for Vrms for each model#). Do not use on circuits where transient stresses can exceed the rated voltage.

25A, +216°F (+102°C) max.

Banana Jack with Wire

Wrap Terminal

1.22in (30.99mm)

0.25in

(6.35mm)

0.50in

(12.7mm)

0.45in

(11.43mm)

.025in square pin

0.375in

(9.52mm)

0.35in

(8.89mm)

Panel Cut-Out

Model# 4005-*

Material: Jack: nickel-plated brass;

Terminal: gold-plated phosphor bronze; Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 3A, +239˚F (+115˚C) max.

*Std. Colors: -0 Black, -2 Red.

Sold in pkgs. of 10 per color.

Replacement hex nuts available on page 39.

Terminal Strip

Banana

Jack Adapter

1.92in (4.88cm)

Model# Thread Torque

In/Lb

73084-*

6-32 male

73085-* 10-32 male

73086-* 10-32 female

7

20

20

73088-*

8-32 male

16

Length

1.92in

(4.88cm)

1.92in

(4.88cm)

1.54in

(3.91cm)

1.92in

(4.88cm)

Easily connect safety sheathed banana plug test leads to terminal strips via this Terminal

Strip Banana Jack Adapter.

Material: Contacts: nickel-plated brass,

Insulation: polypropylene.

*Std. Colors: -0 Black, -2 Red, -4 Yellow,

-6 Blue.

Rating: For CE Compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60

Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

600 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage. 20A, -10º C to +80º C

(+14º F to 176º F).

Panel Mount Banana Jack

1.22in (31.00mm)

1/4-32 thread

0.35in

(8.89mm)

0.375in

(9.52mm)

Panel Cut-Out

Model#

1581-*

2854-*

4900-*

Plating

Bright tin

Gold

Insulation

Polycarbonate

Polycarbonate

Bright tin Polyphenylene Sulfide

Mounts in panels ranging in thickness from 0.063in

(1.60mm) to 0.375in (9.53mm).

Material: Brass.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Std. Colors

-0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

-0 Black, -1 Brown, -2 Red, -4 Yellow,

-5 Green, -6 Blue, -8 Gray, -9 White

-0 Black, -6 Blue

Maximum voltage for hands free use: 2500 Vdc.

Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +239˚F (+115˚C) max.

(Model 4900, +428˚F (+220˚C) max.).

Mounting Bases and replacement hex nuts available on page 38 -39.

Sold in pkgs. of 10 per color.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

37

Banana Plugs and Jacks

38

Binding Posts

0.98in (25.89mm)

Max. open 0.80in

(20.32mm) x-hole 0.100in

(0.254mm)

0.35in

(8.89mm)

0.375in

(9.52mm)

Panel Cut-Out

Model#

3750-*

Material

Gold-plated brass

3760-*

Bright tin-plated brass

3770-*

Gold-plated tellurium copper

Insulation: Polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +239˚F (+115˚C) max.

*Std. Colors: 3750 and 3760: all

10 colors. 3770: -0 Black, -2 Red.

Sold unassembled.

Binding Post with

Double Mounting

0.98in

(24.89mm)

0.80in

(20.32mm)

0.75in

(19.05mm)

Hex Head Binding Post

Model# 5018-*

x-hole 0.100in

(0.254mm)

0.54in

(13.71mm)

0.91in (23.11mm)

1.19in (30.22mm) open

0.458in

(11.63mm)

0.58in

(14.73mm)

Material: Binding Post Body, Nuts,

Lockwasher: gold-plated brass;

Insulation: Nylon MIL-P-20693.

0.490in (12.45mm)

Panel Cut-Out

Meets MIL-P-55149/1A.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 1500 Vrms.

Do not use on circuits where transient stresses can exceed the rated voltage.

30A, +176˚ (+80˚C) max.

*Std. Colors: -0 Black, -2 Red,

-4 Yellow, -5 Green, -6 Blue, -9 White.

Model# 4243-*

Accepts standard banana plugs and 0.080in

(2.03mm) pin tips, wires and probe tips in

0.10in (2.54mm) cross-hole.

One black and one red binding post.

Material: Binding Post: bright tin-plated brass; Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +239˚F

(+115˚C) max.

*Mtg. Base Colors: -0 Black, -2 Red.

Spring Loaded

Binding Post

.0925in

(2.35mm) 0.89in (22.60mm)

Model# 4995-*

0.58in

(14.73mm)

Meets MIL-P-55149/8.

Silicone rubber O-rings provide water resistant seal when mounted in panels from 0.062in to 0.125in

(15.75mm to 3.18mm) thick.

Material: Nickel-plated brass.

*Std. Colors: -0 Black, -2 Red.

2.00in (50.8mm)

Panel Cut-Out

Panel Cut-Out

Dual Binding Posts

1.98in (50.37mm)

6883

1.98in (50.37mm)

0.75in

(19.6mm)

0.75in

(19.6mm)

Model#

6883

6884

Base

Standard

Raised Base

5-way binding post with 3.91 mm

(0.154 in) cross-hole that accepts up to

12 AWG wire and standard banana plugs.

Posts are spaced at the standard 3/4 inch spacing to mate to dual banana plugs.

Material: Binding Post: nickel-plated brass.

Insulators: nylon.

Rating: 30A current.

0.24in

(6.10mm) )

0.75in

(19mm)

Spring Loaded

Binding Post

0.80in

(20.32mm)

1.9in (48.26mm)

Model# 4770-*

0.53in

(13.46mm)

Mounts in panels from 0.06in (1.6mm) to 0.38in (9.53mm) thick.

Accepts wires or plugs up to 0.08in

(2.16mm) dia. with insulation up to

0.16in (4.06mm).

Material: Body: tin plated brass;

Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum. Maximum voltage for hands

free use: 630 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +239˚F

(+115˚C) max.

*Std. Colors: -0 Black, -2 Red.

6884

Panel Cut-Out for 6883/6884

Binding Post/Banana Jack Mounting Bases

C

B

B

C

A

A

For binding post models 3750, 3760, 3770

Model# Type

3862-*

Double

3863-*

Triple

4619-*

Double

4614-*

Triple

4654-*

Double

4590-*

Triple

Used with

Standard

A B C

1.19in (30.22mm) 0.75in (19.05mm) 0.44in (11.18mm)

Binding Posts 1.94in (49.28mm) 0.75in (19.05mm) 0.44in (11.18mm)

Miniature

0.87in (22.09mm) 0.50in (12.70mm) 0.38in (9.65mm)

Banana Jacks

1.38in (35.05mm) 0.50in (12.70mm) 0.38in (9.65mm)

Standard 1.38in (35.05mm) 0.75in (19.05mm) 0.63in (16.00mm)

Banana Jacks 2.13in (54.10mm) 0.75in (19.05mm) 0.63in (16.00mm)

Mount banana jacks and binding posts at standard

0.75in (19.05mm) spacing.

Material: polycarbonate

Rating: +239˚F (+115˚C) Max.

*Std. Colors: -0 Black.

Sold in pkgs. of 10.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Banana Plugs and Jacks

Shorting Link for

Standard Binding Posts

1.03in (26.16mm)

0.25in (6.35mm)

0.43in (10.92mm)

0.65in

(16.51mm)

0.19in

(4.82mm)

Miniature Double

Banana Plug with Set Screws,

Stackable, Solderless

0.75in

(19.05mm)

Miniature Solderless

TypeTriple Banana

Plug with Wire Guide

0.50in (12.7mm)typical

1.26in

(32.00mm)

Replacement

Hex Nuts

Hex Nut

Fits on

6549

3276

4513

0.50in

(12.7mm)

1.11in

(28.19mm)

1.11in

(28.19mm)

6547

3263

4511

6271

Model# 4115

Solid shorting link for binding posts.

Material: nickel-plated brass.

Rating: 15A.

Sold in pkgs. of 10.

Fits Binding Posts on 0.750in

(19.05mm) centers.

Model# 2244-*

Internal set screws secure cable up to 0.15in

(3.81mm) dia. or components.

Plugs fit miniature 0.104in (2.64mm) dia. jacks.

Material: Banana Plug/Jack: brass; Spring: beryllium copper; Finish: gold plating;

Insulation: ABS

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model# Qty. Finish Wrench

Size

6549

6547

Nut Thickness Thread

500 Nickel 3/16in 0.65in (16.51mm)

500 Nickel 1/4in 0.95in (24.13mm)

4-40

6-32

6440

6548

6441

6389

500 Nickel 1/4in 0.95in (24.13mm)

100 Gold

8-32

3/8in 0.95in (24.13mm) 10-32

500 Nickel 3/8in 0.95in (24.13mm) 1/4-32

100 Nickel 9/16in 0.95in (24.13mm) 1/2-28

2142

2143

2382

2383

2439

2440

3264

3542

3750

3760

6440

3770

4022

4098

4243

4512

4543

4773

6272

Model# 4653-0

Use for balanced line 2 conductor shielded cable assemblies.

Material: Banana Plug/Jack: brass; Spring: beryllium copper; Finish: gold plating;

Insulation: ABS.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

Cable strain relief I.D. 0.19in (4.82mm).

Setscrews secure wires.

6548

5018

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

6441

1581

2269

2854

3267

4005

4069

4601

4900

5233

6270

6389

4921

6387

Miniature Solder

Type Banana Plug

0.15in

(3.81mm)

X

0.09in

(2.29mm)

Model#

3690-*

4617-*

Insulator Length (X)

0.45in (11.43mm)

1.00in (25.14mm)

0.19in (4.83mm)

X 0.44in

(11.18mm)

Miniature Banana

Plug with

Threaded Stud

Sold in pkgs. of 10

Material: Banana Plug Body: brass; Spring: beryllium copper; Finish: gold plating; Insulation: nylon.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +176˚F (+80˚C) max.

*Std. Colors: -0 Black, -2 Red.

Fits miniature 0.104in (2.64mm) dia. banana jacks.

Model#

3276

4513

X Length

0.230in (5.84mm)

0.480in (12.19mm)

Fits miniature 0.104in (2.64mm) dia. banana jacks.

Furnished with 4-40 hex nut, 4-40 threaded stud.

Material: Banana Plug Body: brass; Spring: beryllium copper; Finish: gold plating.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use: 2500 Vdc.

Do not use on circuits where transient stresses can exceed the rated voltage. 5A.

Replacement hex nut available on page 39.

Sold unassembled, in pkgs. of 10.

Do-It-Yourself

Miniature Banana

Plug, Stackable,

Solderless

Model# 2944-*

Fits miniature 0.104in (2.64mm) dia. banana jacks.

Wire firmly held in place with internal set screw.

Material: Banana Plug/Jack: brass; Spring: beryllium copper; Finish: gold plating; Insulation: ABS.

0.31in

(2.87mm)

1.11in

(28.19mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use: 2500 Vdc.

Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Do-It-Yourself

Miniature Banana

Plug with Safety

Shield, Stackable,

Solderless

Model# 2945-*

Fits miniature 0.104in (2.64mm) dia. banana jacks.

Wire firmly held in place with internal set screw.

Material: Banana Plug/Jack: brass; Spring: beryllium copper; Finish: gold plating; Insulation: ABS

0.31in

(2.87mm)

1.11in

(28.19mm)

0.086in

(2.18mm) I.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use: 2500 Vdc.

Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Miniature Double

Banana Plug with

Shorting Bar

Model# 2035-*

Plugs fit miniature 0.104in (2.64mm) dia. banana jacks.

Banana plugs internally shorted with 18 AWG wire.

0.50in

(12.7mm)

Material: Banana Plug/Jack: brass; Spring: beryllium copper; Finish: gold plating; Insulation: ABS.

0.75in

(19.05mm)

1.10in

(25.40mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use: 2500 Vdc.

Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

www.pomonaelectronics.com

39

Banana Plugs and Jacks

40

Miniature Double

Banana Plug

Shorting Bar

0.75in

(19.05mm)

0.75in

(19.05mm)

0.50in

(12.70mm)

Miniature Rivet

Type Banana Plug

0.10in

(2.54mm)

0.16in

(4.06mm)

Post

0.38in

(9.65mm)

X

Model# 3030

Center hole accepts 4-40 screw.

Material: Banana Plug Body: brass; Spring: beryllium copper; Finish: gold plating.

Rating: 5A. Resistance less than 1.5 m

Ω.

Fits Miniature Binding Posts and Miniature Banana

Jacks on 0.5in (12.70mm) centers.

0.09in

(2.29mm)

Fits miniature 0.104in (2.64mm) dia. banana jacks.

Material: Banana Plug Body: brass; Spring: beryllium copper; Finish: gold plating.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free

use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A.

Sold in pkgs. of 10.

Miniature Binding

x-hole 0.086in

(0.2.18mm)

0.75in

(19.05mm) open

0.63in

(16.00mm) open

Panel Cut-Out

Model#

3268

3271

3272

Panel

0.062in

(1.57mm)

0.093in

(2.36mm)

0.125in

(3.17mm)

X Dim.

0.094in

(2.39mm)

0.125in

(3.17mm)

0.156in

(3.96mm)

Model#

2382-*

2439-*

Plating

Gold

Tin

Accepts miniature banana plug.

8-32 hex nut and lockwasher included.

Material: Binding Post Body, Nut: brass;

Lockwasher: steel; Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use:

1500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +239˚F

(+115˚C) max.

*Std. Colors: -0 Black, -2 Red, -5 Green, -6 Blue.

Replacement hex nuts available on page 39.

Miniature Banana Jack with Wire Wrap Terminal

0.31in

(7.87mm)

0.74in

(18.80mm)

0.45in

(11.43mm)

1.33in

(33.78mm)

0.250in (6.35mm)

0.234in

(59.44mm)

Panel Cut-Out

Model# 4022-*

Accepts miniature banana plugs.

Mounts in panels up to 0.250in

(6.35mm) thick.

Material: Jack: nickel-plated brass;

Terminal: gold-plated phosphor bronze;

Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

1500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 3A, +239˚F (+115˚C) max.

*Std. Colors: -0 Black, -2 Red.

Sold unassembled, in pkgs. of 10.

www.pomonaelectronics.com

Miniature Insulated

Binding Post with

Double Mounting Base

Model#

2383-*

2440-*

Plating

Gold

Tin

0.86in

(21.84mm) x-hole 0.086in (0.2.18mm)

0.75in (19.05mm)

Max. open

Panel Cut-Out

0.50in

(12.70mm)

0.63in (16.00mm)

Accepts miniature banana plugs.

8-32 hex nut and lockwasher included.

Material: Binding Post Body, Nut: brass; Lockwasher: steel; Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60

Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

1500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +239˚F (115˚C) max.

*Mounting Base Colors: -0 Black, -2 Red.

*Std. Colors: 2383: -0 Black, -2 Red.

2440: -0 Black.

Replacement hex nuts available on page 39.

Model# 3548-*

Do-It-Yourself Pin

Tip Plug with Safety

Shield, Stackable,

Solderless

0.08in (2.03mm) pin

0.31in

(2.87mm)

1.31in (33.27mm)

0.086in

(2.18mm) I.D.

0.50in

(12.70mm)

Accepts miniature banana plug.

Wire firmly held in place with internal set screw.

Material: Pin Tip Plug/Jack: gold-plated brass;

Insulation: ABS.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 3000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.5A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model# 2142-*

Miniature Banana

Jack, Panel Mount

0.72in

(18.29mm)

0.31in

(7.87mm)

0.88in

(22.35mm)

0.250in (6.35mm)

0.234in

(59.44mm)

Panel Cut-Out

Accepts miniature banana plugs.Mounts in panels up to 0.250in (6.35mm) thick.

Material: gold-plated brass; Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 1500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +239˚F (+115˚C) max.

*Std. Colors: -0 Black, -2 Red, -3 Orange,

-4 Yellow, -5 Green, -6 Blue, -9 White.

Uses hex nut 6440.

Replacement hex nuts available on page 39.

Sold unassembled, in pkgs. of 10 per color.

Miniature Rivet Type

Banana Jack with

Turret

0.14in

(3.56mm)

0.105n

(2.67mm)

0.50in

(12.70mm)

0.34in

(8.64mm)

Model# 3277

Accepts miniature banana plugs.

Mounts in panels up to 0.062in

(1.57mm) thick.

Material: Gold-plated brass.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 1500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A.

Sold in pkgs. of 10.

Rec. Mounting Hole: .140 ± .002 (9/64 Drill).

Panel Thickness: 0.062in (1.57mm)

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Banana Plugs and Jacks

Miniature Banana Jack in Double Mounting

Base, Panel Mount

0.87in

(22.10mm)

0.88in (22.35mm)

0.60in

(15.24mm)

Model# 2143-*

0.50in

(12.70mm)

Accepts miniature banana plugs. Mounts in panels up to 0.188in (4.78mm) thick.

Material: gold-plated brass; Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 1500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +239˚F (+115˚C) max.

*Std. Mounting Base Colors: -0 Black,

-2 Red.

Colors: One black and one red jack.

Pin Tip Jacks with

Double Mounting Base

0.87in

(22.10mm)

0.88in (22.35mm)

0.60in

(15.24mm)

0.50in

(12.70mm)

Model# 4543-*

Accepts 0.08in (2.03mm) dia. pin.

Max. panel thickness 0.188in (4.78mm).

Material: Jack: gold-plated brass;

Spring: beryllium copper; Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 1500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +239˚F (115˚C) max.

*Mtg. Base Colors: -0 Black, -2 Red.

41

Panel Cut-Out

Panel Cut-Out

Double Pin Tip Plug with Shorting Bar

0.75in

(19.05mm)

0.50in

(12.7mm)

1.20in

(30.48mm)

Model# 3452-*

Accepts pin tip plugs. Internally shorted with

20 AWG wire. Use as connecting link for

0.50in (12.70mm) spaced pin tip jacks.

Material: Pin Tip Plug/Jack: brass;

Spring: beryllium copper; Finish: gold plating; Insulation: ABS.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 3000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.5A, +239˚F (+115˚C) max.

*Std. Colors: -0 Black, -2 Red.

Do-It-Yourself .080in

(20.32mm) Dia. Pin Tip

Plug with Flexible Boot,

Solder or Crimp

1.50in

(38.10mm)

0.35in

(8.89mm)

Model#

5173-*

Accepts Wire AWG

22, 20,18

Ideal for making patch cords or field repairs.

Snap-on flexible PVC boot allows wire to be crimped or soldered to pin tip plug.

Material: nickel-plated brass.

Accepts 18-22 AWG wire.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 3000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

*Std. Colors: Available in 10 colors.

Double Banana Jack to Miniature Double

Banana Plug Plug

0.75in

(19.05mm)

1.13in

(28.70mm)

1.25in

(31.75mm)

Model# 2952

0.50in

(12.70mm)

Converts standard banana plugs to miniature.

Material: Jack: nickel-plated brass;

Spring: nickel-plated beryllium copper;

Insulation: ABS.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚ C) max.

Color: Black.

Pin Tip Jack

0.72in

(22.35mm)

0.250in (6.35mm)

0.88in

(18.29mm)

0.234in

(59.44mm)

Panel Cut-Out

Model# 3542-*

Accepts 0.080in (2.03mm) dia. pin.

Material: Jack: gold-plated brass; Spring: beryllium copper; Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 1500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.5A, +239˚F (115˚C) max.

*Std. Colors: -0 Black, -2 Red, -3 Orange,

-4 Yellow, -5 Green, -6 Blue, -9 White.

Sold in pkgs. of 10.

Insulated Pin Jack with

Wire Wrap Terminal

0.74in

(18.80mm)

0.45in

(11.43mm)

Model# 4773-*

Accepts 0.080in (2.03mm) dia. pin.

Max. panel thickness 0.25in (6.35mm).

0.31in

(7.87mm)

Material: Jack: nickel-plated brass; Spring: gold-plated beryllium copper; Terminal: gold-plated phosphor bronze; Insulation: polycarbonate.

1.33in

(33.78mm)

0.250in (6.35mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 1500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 3A, +239˚F (+115˚C) max.

0.234in

(59.44mm)

*Std. Colors: -0 Black, -2 Red, -6 Blue,

-9 White.

Panel Cut-Out

Miniature Banana

Jack to Banana Plug

0.44in

(11.18mm) x-hole 0.166in (4.22mm)

1.55in (39.37mm)

Model# 2477-*

Converts miniature banana plugs to standard.

Material: Jack: nickel-plated brass;

Spring: nickel-plated beryllium copper;

Insulation: ABS.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

*Std. Color: -0 Black, -2 Red.

Sold in pkgs. of 10.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

Banana Plugs and Jacks

42

Do-It-Yourself In-Line

4 mm (0.16in) Banana

Plug

0.65in

(16.5mm)

1.73in (44.0mm)

Model# 5934-*

Wire connection by set screw. Accepts 18, 20 and 22 AWG wire.

Material: Insulation: Nylon.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 750 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.25A.

0.19in

(4.65mm)

*Std. Colors: -0 Black, -2 Red.

Sold in pkgs. of 10 per color.

Pin Tip Jack to

Banana Plug

0.44in

(11.18mm) x-hole 0.166in (4.22mm)

1.55in (39.37mm)

Banana Jack to Pin

Tip Plug

x-hole 0.166in

(4.22mm)

0.50in

(12.70mm)

1.5in (38.10mm)

0.44in (11.18mm)

0.080in

(2.03mm)

Model# 1809-*

Accepts 0.080in (2.03mm) pin tip plug or probe tip. Fits standard 0.166in (4.22mm) dia. banana jack.

Material: gold-plated beryllium copper.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.5A, +122˚F (+50˚C) max.

*Std. Color: -0 Black, -2 Red.

Sold in pkgs. of 10.

Model# 1432-*

Use to mate standard banana plug patch cords to equipment having pin jacks.

Material: Jack/Plug: nickel-plated brass;

Insulation: polypropylene.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 3000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Sold in pkgs. of 10.

Banana Jack to

.080in (2mm) Dia.

Pin Tip Jack

1.50in (38.10mm)

Model# 3834-*

0.38in

(9.65mm)

Adapts standard 0.166in (4.22mm) dia. banana plug to 0.080in (2.03mm) dia. pin tip plug.

Material: Banana Jack: nickel-plated brass; Pin

Jack: gold-plated beryllium copper; Insulation: polypropylene.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 3000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +131˚F (+55˚C) max.

*Std Colors: -0 Black.

Model# 5935-*

2mm Banana Jack

0.77in

(19.6mm)

0.14in

(3.5mm)

Panel Cut-Out

Max. Panel Thickness: 0.31in (8mm).

Material: Insulation: nylon; Finish: nickel plating.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 500 Vdc.

Do not use on circuits where transient stresses can exceed the rated voltage. 5A, ≤ 2 mΩ.

*Std. Colors: -0 Black.

Sold in pkgs. of 10 per color.

Not compatible with Miniature Banana Plug or Pin Tip.

Double Banana Plug with Binding Posts,

Stackable, Solderless

x-hole 0.166

in (4.21mm)

1.19in

(30.23mm)

2.48in (62.99mm)

Banana Jack to

Miniature Banana Plug

0.30in (7.62mm)

1.33in

(33.78mm)

0.44in (11.18mm)

0.75in

(19.05mm)

0.120in

(3.04mm)

Model#

1286

5405

Plating

Nickel

Gold

Features insulated binding posts on 0.750in

(19.05mm) centers for rapid mounting and interchangeability of components. Center cross hole 0.166in (4.22mm) dia. provides side stackup connection.

Material: Binding Post/Banana Plug

Body: brass; Spring: beryllium copper;

Insulation: ABS.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +122˚F (+50˚C) max.

Color: Black.

Model# 2138-*

Use to mate standard 0.166in (4.22mm) dia. banana plug to equipment having miniature banana jacks.

Material: Jack: nickel-plated brass; Spring: nickel-plated beryllium copper; Insulation: ABS.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.5A, +122˚F (+50˚C) max.

*Std. Color: -0 Black, -2 Red.

Sold in pkgs. of 10.

Insulated Double

Banana Plug Shorting

Bar with Binding Post

1.35in

(34.29mm)

Banana Plug

0.75in

(19.05mm)

1.78in(45.21mm)

Max. open

Binding Post to

x-hole 0.166in (4.22mm)

2.46in (62.48mm)

Max. open

0.44in (11.18mm)

Model# 5165-*

Fits standard banana jack.

Shorting bar is completely insulated in clear

ABS thermoplastic.

Material: Binding Post/Banana Plug Body/

Shorting Bar: nickel-plated brass; Spring: nickel-plated beryllium copper; Insulation: polycarbonate.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +122˚F (+50˚C) max.

*Binding Post Colors: -0 Black, -2 Red.

Model# 2894-*

Features insulated binding post for rapid mounting and interchangeability of components. Accepts standard banana plug. Center cross hole 0.166in (4.220mm) dia. provides side stackup connection.

Material: Binding Post/Banana Plug Body: nickel-plated brass; Spring: nickel-plated beryllium copper; Insulation: polypropylene

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +122˚F (+50˚C) max.

*Binding Post Colors: -0 Black, -2 Red.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Banana Plugs and Jacks

2mm Banana Plug

0.16in

(4.1mm)

Model# 5936-*

Solder type wire connection.

Accepts 18-22 AWG wire.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 500 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, ≤ 2 mΩ.

*Std. Colors: -0 Black, -2 Red.

Assembled Length: 1.07in (27.2 mm).

Sold unassembled, in pkgs. of 10 per color.

Not compatible with Miniature Banana Plug or Pin Tip.

Test Connector Adapter

Set

Model# 6481

Full set of pin and socket adapters.

18 piece set includes one black and red pin and socket of each size.

Includes Silicone insulated 4ft (1.21m) leads to fit most DMMs from Fluke,

Amprobe, Greenlee and others.

43

Spade Lug to

DMM Banana

Jack

1.71in (43.43mm)

Model# A B Lug Size

3744A-* 0.14in (3.56mm) 0.24in (6.10mm) 4, 5, 6

3777A-*

0.2in (5.0mm) 0.30in (7.7mm) 8, 10

A

B

Plugs into DMM leads. Permits DMM leads to be used with equipment having barrier strips, or binding post.

Material: Banana Jack: nickel-plated brass;

Spade Lug: tin-plated copper; Insulation: polypropylene.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +122˚F

(+50˚C) max.

*Std. Colors: -0 Black, -2 Red, -02 Set of one black and one red.

Connector Test Adapters

Pin type

2.75 - 3.18in (69.9 - 80.8mm)

Socket type

2.49in (63.2mm)

Low Thermal EMF

Insulated Spade Lug to Banana Jack

0.79in

(20.07mm)

0.26in

(6.60mm)

1.42in (36.07mm)

0.38in (9.65mm)

0.50in

(12.70mm)

Model# 2305

Special alloy and plating preserve the accuracy of low voltage measurement equipment. Thermal effects are minimized.

Heavy construction for minimum voltage loss. Mates with low voltage banana plug patch cords and binding posts.

Material: Jack and Spade Lug: gold- plated tellurium copper; Insulation: ABS.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.15A, +122˚F

(+50˚C) max.

Set of one red and one black.

Model# AWG

4690-*

4691-*

3560-*

3561-*

3562-*

3563-*

3564-*

3565-*

22

20

16

12

Contact Size

0.030in (0.76mm)

0.040in (1.02mm)

0.063in (1.60mm)

0.093in (2.36mm)

Type

Socket

Pin

Socket

Pin

Socket

Pin

Socket

Pin

Current

Rating

3A

An ideal test adapter for rapid testing of the hard-to-get at contacts of multi-pin/socket connectors. Flexible tip allows testing of adjacent contacts. Flexibility and full insulation protects against shorting or contact damage. Model 4690 also fits 0.025in

(0.63mm) sq. pins.

Material: Banana Jack: nickel-plated brass;

Socket: gold-plated copper; Pin: gold-plated brass; Insulation: PVC.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2500 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

44

Patch Cords and Test Leads

Pomona has made it easy for you to have exactly what you need with a huge selection of patch cords and test leads designed for reliable, convenient connections. Whether you need a test lead that can access an IC pin without shorting or a patch cord that accommodates multiple stacking, Pomona Electronics’ design and reliability are your connection with quality.

Wire Specifications

Wire

Designation

B

Silicone

P

PTO

AWG Description O.D.

Jacket Temperature Range Color

18 65/36 copper

18 65/36 copper

0.144in (3.66mm) PVC -4 to 221°F (-20 to +105°C) 10 Colors

0.144in (3.66mm) Silicone -58 to 302°F (-50 to +150°C) Black and Red

20 41/35 copper 0.087in (2.20mm) PVC

22 26/36 copper 0.064in (1.62mm) PVC

12 7 x 38/36 copper 0.144in (3.66mm) PVC

-4 to 221°F (-20 to +105°C)

-4 to 221°F (-20 to +105°C)

140°F (+60°C)

10 colors

10 colors

Black, Red, Green

How To Order

Test Lead Length

Typical Pomona Part Number:

Lead Length in Inches

(Measured Inside Connectors)

Specify Color

3781-24-2

Multi-Stacking Banana

Plug Patch Cord

1.55in

(39.37mm)

0.52in

(13.20mm)

Model# Length

2948-12-* 12in (0.3m)

2948-24-* 24in (0.6m)

2948-36-* 36in (0.9m)

2948-48-* 48in (1.2m)

2948-60-* 60in (1.5m)

Special Features

Gold-plated finish

Model 2948 Multi-Stacking Banana Plug Patch

Cord features a gold-plated finish.

*Std. Colors: -0 Black, -2 Red.

Model#

B-4-*

B-8-*

B-12-*

B-18-*

B-24-*

B-36-*

B-48-*

B-60-*

B-72-*

Length

4in (0.1m)

8in (0.2m)

12in (0.3m)

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

72in (1.8m)

Model B: Multi-Stacking Banana

Plug Patch Cord features a nickelplated finish.

Cable: 18 AWG Wire, 0.144in

(3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc.

Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +131˚F (+55˚C) max.

*Std. Colors: Available in 10 Colors.

Test Lead Holders

Model#

1508

4408

2708

Color “A”

Max Cable Dia.

Orange 0.210in (5.33mm)

Black 0.320in (8.13mm)

Blue 0.450in (11.43mm)

Number of Slots

14

10

9

11.00in (279.4mm)

2.71in

(68.83mm)

0.53in

(13.46mm)

A

3.50in

(188.9mm)

Multi-stacking Sheathed

(4mm) Banana Plug

Patch Cord

Model# 6727-*

4ft (1.2 meter) stackable safety lead.

Material: Contacts: nickel-plated brass;

Wire: multi-strand copper,

Insulation: silicone.

Rating: IEC61010 1000V Cat III, 20A max

(10A cont.), 14 to 131°F (-10 to +55°C).

*Std. Colors: -0 Black only, -2 Red only.

Horizontal Stacking Banana

Plug Patch Cord

1.96in

49.78mm

Model#

HB-12-*

HB-24-*

HB-36-*

HB-48-*

HB-60-*

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Cable: 18 AWG Wire, 0.144in

(3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free

use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.

15A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Cross Stacking Banana

Plug Patch Cord

1.55in

(39.37mm)

0.38in (9.65mm)

Model#

1440-12-*

1440-18-*

1440-24-*

1440-36-*

1440-48-*

1440-60-*

Length

12in (0.3m)

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Cable: 18 AWG Wire, 0.144in (3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.15A, +131˚F (+55˚C) max.

*Std. Colors: -0 blk, -2 red.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Patch Cords and Test Leads

Multi-Stacking Banana Plug

Coiled Patch Cord

Multi-Stacking Banana Plug

Patch Cord with In-Line

Fuse Holder

Multi-Stacking Banana Plug to Miniature Stacking

Banana Plug

1.55in (39.37mm)

1.55in

(39.37mm)

0.88in (22.35mm)

1.55in

(39.37mm)

Model#

2484*

Model#

4274-36-*

Model#

3014-36-*

3014-60-*

Ext. Length

48in (1.23mm)

Cable: 20 AWG Wire, 0.087in

(2.21mm) O.D.

Extended Length: 48in (1.2mm).

One patch cord replaces many different lengths.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for

hands free use: 270 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A,

+131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Length

36in (0.9m)

Cable: 18 AWG Wire, 0.144in

(3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 5000 Vdc.

Do not use on circuits where transient stresses can exceed the rated voltage.15A, +131˚F (+55˚C).

*Std. Colors: -0 Black, -2 Red.

Length

36in (0.9m)

60in (1.5m)

Cable: 20 AWG Wire, 0.087in

(2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for

hands free use: 3000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A,

+131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Multi-Stacking Banana

Plug to Minigrabber

Test Clip

2.54in (64.52mm)

Multi-Stacking Banana

Plug to Minigrabber

®

Test Clip

2.54in (64.52mm)

®

1.55in

(39.37mm)

1.55in

(39.37mm)

Multi-Stacking Banana

Plug to Minigrabber

Test Clip (Coiled)

Patch Cord

1.55n

(39.37mm)

®

Model#

3782-12-*

3782-24-*

3782-36-*

3782-48-*

3782-60-*

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Hook attaches to component leads up to 0.060in (1.52mm) O.D.

Cable: 20 AWG Wire, 0.087in

(2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free

use: 300V. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red,

-4 Yellow, -5 Green, -6 Blue.

Model#

6249-12-*

6249-24-*

6249-36-*

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

Features a slim 0.36in (9.14mm) body width. Hook attaches to component leads up to 0.060in (1.52mm) O.D.

Cable: 18 AWG Silicone insulated wire,

0.144in (3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free

use: 300V. Do not use on circuits where transient stresses can exceed the rated voltage. 5A.

*Std. Colors: -0 Black, -2 Red.

Model#

4538-*

Ext. Length

48in (1.2m)

Hook attaches to components up to

0.060in (1.52mm) O.D.

Cable: 20 AWG Retractile Cord,

0.087in (2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum. Maximum voltage for hands

free use: 300V. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +131˚F (+55˚C).

*Std. Colors: -0 Black, -2 Red.

Multi-Stacking Banana Plug to Maxigrabber

®

Test Clip

6.00in (152.4mm)

Model#

4996-36-*

Length

36in (0.9m)

Hook attaches to components up to

0.060in (1.52mm) O.D.

1.55in

(39.37mm)

Cable: 20 AWG Wire, 0.087in

(2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 300V. Do not use on circuits where transient stresses can exceed the rated voltage.

5A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

2.54in

(64.52mm)

Right Angle Stacking

Banana Plug Patch Cord

0.89in (22.60mm)

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Model#

2864-24-*

Length

24in (0.6m)

Cable: 18 AWG Wire, 0.14in

(3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free

use: 5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

www.pomonaelectronics.com

45

Patch Cords and Test Leads

46

Multi-Stacking Banana Plug to Micrograbber

®

Test Clip

Minigrabber

6244

®

1.71in

(43.43mm)

1.55in

(39.37mm)

Minigrabber

®

Test

Clip with Sheathed

Model#

6248-12-*

Model#

5053-24-*

5053-36-*

5053-48-*

Length

24in (0.6m)

36in (0.9m)

48in (1.2m)

Hook attaches to components up to

0.040in (1.02mm) O.D.

Cable: 20 AWG Wire, 0.087in

(2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for

hands free use: 150V. Do not use on circuits where transient stresses can exceed the rated voltage. 3A, +131˚F

(+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Plug Type

Sheathed

Banana Jack

Ratings

IEC61010-031

CAT II 300V

Test Lead Extender.

Silicone insulated 1ft (0.3m) leads fit on the end of modular test leads such as Pomona 5907A.

Std. Colors: -0 Black, -2 Red.

Test Clip Leads

5428/6231

Multi-Stacking Double

Banana Plugs on

Retractile (Coiled) Cord

1.55in

(39.37mm)

Model#

3864-48

3864-72

Extended Length

48in (1.2m)

72in (1.8m)

0.75in

(19.05mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 90 Vac/

270 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. +122˚F (+50˚C) max.

Cable Type: Shielded Microphone

Cable.

Multi-Stacking Banana

Plug to SMD Grabber

®

Test Clip

1.71in

(43.43mm)

1.55in

(39.37mm)

Double Banana Plug with Safety Shrouds

Model#

5302-12-*

5302-24-*

5302-36-*

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

Pincer Opening: 0.040in (1.02mm).

Cable: 22 AWG Wire, 0.064in

(1.63mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 150V. Do not use on circuits where transient stresses can exceed the rated voltage.

0.5A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

6283-C-36

6283-C-48

6283-C-60

Length

36in (0.9m)

48in (1.2m)

60in (1.5m)

Fits Digital Multi-meters and other instruments with shrouded jacks.

Offset design designates hot and ground leads.

Black and red banana plug shrouds.

Molded strain relief for long life.

MIL spec coaxial cable.

Overvoltage CAT II, 600V, 5A per

IEC61010-031.

2.53in

(64.28mm)

Model# Plug Type

6244-48-*

Right-angle DMM

5428-48-*

Right-angle DMM

6231

Right-angle DMM

6245-48-*

Straight DMM

Ratings

CAT II 300V

300 Vrms*

300 Vrms*

CAT II 300V

6245

Silicone insulated 4ft (122m) leads fit most meters from Fluke, Wavetek (Meterman), HP, Amprobe,

Greenlee and others

Std. Colors: -0 Black, -2 Red

*Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use:

300 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage.

Multi-Stacking Double to

Multi-Stacking Single

Banana Plugs

1.55in

(39.37mm)

5.0in (127.0mm)

1.55in

(39.37mm)

Model#

1368-A-18

1368-A-24

1368-A-30

1368-A-36

1368-A-48

1368-A-60

Length

18in (0.5m)

24in (0.6m)

30in (0.76m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

0.75in

(19.05mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 300 Vrms.

Do not use on circuits where transient stresses can exceed the rated voltage.

+122˚F (+50˚C) max.

See chart on page 6 for additional cable specifications.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Patch Cords and Test Leads

Two Conductor shielded

Balanced Line

1.55in (39.37mm)

0.75in

(19.05mm)

Multi-Stacking

Double Banana

Plug Cables

1.55in

(39.27mm)

Model#

2BA-18

2BA-24

2BA-36

2BA-48

2BA-60

2BC-24

2BC-36

2BC-48

2BC-60

Model#

1167-18

1167-24

1167-30

1167-36

1167-48

1167-60

Length

18in (0.5m)

24in (0.6m)

30in (0.76m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use: 1000 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage. +131˚F (+55˚C) max.

Cable Type I: See chart on page 6 for additional cable specifications.

Cable Type

Two Conductor

Twisted

Pair, 18 AWG,

0.25in (6.35mm) O.D.

RG58C/U,

0.195in (4.95mm) O.D.

Length

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

0.75in

(19.05mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2BA: 300 Vrms, 2BC:

1400 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage. +131˚F (+50˚C) max.

Double Banana Plug to

Micrograbber

®

Test Clips

1.55in

(39.37mm)

Model#

4768-K-24

4768-K-36

4768-K-48

4768-K-60

Length

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

1.50in (38.10mm)

8.0in (203.2mm)

0.75in

(19.05mm)

1.74in

(44.20mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 150 Vrms.

Do not use on circuits where transient stresses can exceed the rated voltage.+122˚F (+50˚C) max.

See chart on page 6 for additional cable specifications.

Double Banana Plug to

Stacking Pin Tip Plugs

8.0in (203.2mm)

1.55in (39.37mm)

1.35in

(34.29mm)

0.75in

(19.05mm)

0.80in

(2.03mm)

1.30in (33.02mm)

Model#

2BC-PP-36

2BC-PP-48

2BC-PP-60

Length

36in (0.9m)

48in (1.2m)

60in (1.5m)

Cable Type: RG58C/U 0.195in

(4.95mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use: 1400 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage.

+122˚F (+50˚C) max.

Multi-Stacking Banana

Plugs, Two Each End

6.0in (152.4mm)

1.61in

(40.90mm)

Multi-Stacking Double

Banana Plug to

Minigrabber

®

Test Clips

1.55in

(39.37)

1.50in

(38.1mm)

8.0in

(203.2mm)

2.56in

(65.02mm)

0.75in

(19.05mm)

Multi-Stacking Double

Banana Plug,

One End Only

1.55in

(39.37mm)

0.75in

(19.05mm)

Model#

2239-C-24

2239-C-36

2239-C-48

Length

24in (0.6m)

36in (0.9m)

48in (1.2m)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use: 1400 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage.

+131˚F (+55˚C) Max.

See chart on page 6 for additional cable specifications.

Model#

3786-C-18

3786-C-24

3786-C-36

3786-C-48

3786-C-60

Length

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 300 Vrms.

Do not use on circuits where transient stresses can exceed the rated voltage.

+122˚F (+50˚C) max.

See chart on page 6 for additional cable specifications.

Model#

1326-A-60

1326-C-60

Length

60in (1.5m)

60in (1.5m)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: A:

300 Vrms, C: 1400 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage. +131˚F

(+55˚C) max.

See chart on page 6 for additional cable specifications.

Miniature Double Banana

Plug Cable

1.00in

(25.40mm)

Model#

2247-K-24

Length

24in (0.6m)

0.50in

(12.70mm)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

1000 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage. +131˚F (+55˚C) max.

Cable Type: RG174/U, 0.100in

(2.54mm) O.D.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

47

Patch Cords and Test Leads

48

Double Banana Plug to

Minigator Test Clips

1.55in

(39.37mm)

0.75in

(19.05mm)

Model#

2BC-MG-36

Length

36in (0.9m)

Cable Type: RG58C/U.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 45 Vrms.

Do not use on circuits where transient stresses can exceed the rated voltage.

+122˚F (+50˚C) max.

Jaw Opening: 0.187in (4.75mm) max.

Minigator Clips to Miniature

Double Banana Plug

1.00in

(25.40mm)

0.50in

(12.70mm)

1.30n (33.02mm)

Model#

3027-K-24

Length

24in (0.6m)

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 45 Vrms.

Do not use on circuits where transient stresses can exceed the rated voltage.

+122˚F (+50˚C) max.

Jaw Opening: 0.187in (4.75mm)

See chart on page 6 for additional cable specifications.

8.0in

(203.2mm)

1.70in

(43.18mm)

1.18in

(29.97mm)

Double Banana Plug to

Alligator Test Clips

7.30in

(185.4mm)

Model#

2BA-AL-36

2BA-AL-48

Length

36in (0.9m)

48in (1.2m)

1.55in

(39.37mm)

1.30in (33.02mm)

2.13in

0.75in

(19.05mm)

(54.10mm)

Cable Type: Two cond. Twisted Pair.

Model#

2BC-AL-36

2BC-AL-60

Length

36in (0.9m)

60in (1.5m)

Cable Type: RG58C/U50.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 150 Vrms.

Do not use on circuits where transient stresses can exceed the rated voltage.

+122˚F (+50˚C) max.

Jaw Opening: 0.30in (7.62mm) max.

Jumper Test Lead Set

2.68in

(6.81cm)

2.15in (5.46cm)

Model#

73087-6-*

73087-9-4

73087-12-*

73087-20-4

73087-24-*

73087-36-*

73087-72-*

73087-150-4

73087-210-4

Length

6in (0.15m)

9in (0.23m)

12in (0.3m)

20in (0.5m)

24in (0.6m)

36in (0.9m)

72in (1.8m)

150in (3.8m)

210in (5.3m)

Each Jumper Test Lead Set includes a Sheathed (4mm) Banana Plug Test

Lead, and Sheathed Banana Plug to

Sheathed Banana Jack Patch Cord.

Cable: 18 AWG Wire, 0.146in

(3.7mm) O.D.

Insulation: Silicone

Rating: For CE Compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use: 1000 Vrms.

Do not use on circuits where transient stresses can exceed the rated voltage. 10A, -4° to +131°F

(-20° to +55°C).

*Std. Colors: -0 Black, -2 Red,

-4 Yellow, -6 Blue.

8.20in(208.53mm) 1.18in

(29.97mm)

Minigrabber

®

Test Clip

Patch Cord

2.54in (64.52mm)

Minigrabber

®

Test

Clip Patch Cord Kit

One End Only

Model#

3781-8-*

3781-12-*

3781-18-*

3781-24-*

3781-36-*

3781-48-*

3781-60-*

Length

8in (0.2m)

12in (0.3m)

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Hook attaches to component leads up to 0.060in (1.52mm) O.D.

Cable: 20 AWG Wire, 0.087in

(2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 300V.

Do not use on circuits where transient stresses can exceed the rated voltage.

5A, +216˚F (+102˚C) max.

*Std. Colors: Available in 10 colors.

Model# 5523

Kit contains 10 pcs. of

Model 3781-24, one of each color.

Model#

3780-60-*

Length

60in (1.5m)

*Std. Colors: -0 Black, -2 Red.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Patch Cords and Test Leads

Low Thermal EMF Patch Cords

Special alloy plating and construction preserve the accuracy of microvolt and nanovolt measurement equipment. Designed to greatly minimize the effect of Thermal Electric Voltage

(Thermal EMF). Thermal EMF is generated at the junction of dissimilar metals at different temperatures and is common source of error in micro- and nano- volt measurements.

Shielded Low Thermal

EMF Spade Lug Patch

Cord

0.14in (3.56mm) O.D.

0.25in

(6.35mm) O.D.

0.26in

(6.60mm)

0.50in

(12.70mm)

0.14in

(3.56mm) O.D.

Model#

1756-24

1756-48

Length

24in (0.6m)

48in (1.2m)

Cable: 12 AWG Wire, Shield Leads:

18 AWG.

Material: Spade Lug: gold-plated

Electrolytic Tough Pitch (ETP) 110 Copper

Alloy, 1/2 hard.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

2000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 20A, 131+˚F (+55˚C) max.

SMD Grabber

®

Test

Clip Patch Cord

1.71in (43.43mm)

Model#

5301-12-*

5301-24-*

Length

12in (0.3m)

24in (0.6m)

Pincer Opening: 0.04in (1.63mm).

Cable: 22 AWG Wire, 0.064in

(1.60mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 150V. Do not use on circuits where transient stresses can exceed the rated voltage.

0.5A, +216˚F (+102˚C) max.

*Std. Colors: -0 Black, -2 Red

Low Thermal EMF

Spade Lug Patch Cord

1.41in

(35.84mm)

0.26in

(6.60mm)

Low Thermal EMF

Retractable Sheath

Banana Plug Patch

Cord

Spade Lug

2.72in

(69.09mm)

Banana Plug to

0.50in

(12.70mm)

Low Thermal EMF

Retractable Sheath

1.41in

(35.81mm)

0.26in (6.60mm)

0.50in (12.70mm)

2.72in (60.09mm)

Model#

1693-36-*

1693-60-*

Length

36in (0.9m)

60in (1.5m)

Cable: 12 AWG Wire, 0.144in (3.56mm) O.D.

Material: Spade Lug: gold-plated Electrolytic

Tough Pitch (ETP) 110 Copper Alloy,

1/2 hard.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 2000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 20A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

5291A-12-*

5291A-36-*

5291A-60-*

Length

12in (0.3m)

36in (0.9m)

60in (1.5m)

Cable: 12 AWG Wire, 0.144in (3.56mm) O.D.

Material: Plug Body: gold-plated tellurium copper; Spring: gold-plated Beryllium Copper.

Rating: 1000V per IEC61010-031, 7A, +131˚F

(+55˚C).

*Std. Colors: -0 Black, -2 Red.

Modle#

5295-36-*

Length

36in (0.9m)

Cable: 12 AWG Wire, 0.144in (3.56mm) O.D.

Material: Spade Lug: gold-plated Electrolytic

Tough Pitch (ETP) 110 Copper Alloy, 1/2 hard; Plug End: gold- plated tellurium copper.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 1000V. Do not use on circuits where transient stresses can exceed the rated voltage. 7A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

MicroGrabber

®

Test

Clip Patch Cord

SMD

Model# 5521

Grabber

®

Test Clip

Patch Cord Kit

Kit contains 10 pcs. of Model 5301-24, one each of ten colors.

Model#

4613-12-*

4613-24-*

4613-36-*

4613-48-*

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

1.71in

(43.43mm)

Hook attaches to components up to

0.040in (1.02mm) O.D.

20 AWG Wire, 0.087in (2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60

Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use: 150V.

Do not use on circuits where transient stresses can exceed the rated voltage. 3A,

+216˚F (+102˚C) max.

*Std. Colors: -0 Black, -2 Red.

MicroGrabber

®

Test

Clip Patch Cord Kit

Model# 5525

Kit contains 10 pcs. of Model 4613-24, one each of ten colors.

Multi-Stacking Banana

Plug to Alligator

Test Clip

2.30in (58.42mm)

Model#

1166-12-*

1166-24-*

1166-36-*

1166-48-*

1166-60-*

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

1.55in

(39.37mm)

Banana Plug to

Alligator Clip Patch

Cord Kit

Jaw Opening: 0.300in (7.62mm).

Cable: 18 AWG Wire, 0.144in

(3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60

Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use: 150V.

Do not use on circuits where transient stresses can exceed the rated voltage. 5A,

+122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

6357-36

Length

36in (0.9m)

Kit contains 10 pcs. of Model 1166 patch cords, one each of 10 colors.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

49

Patch Cords and Test Leads

50

Minigator Test Clip

Patch Cord

1.79in (45.47mm)

1000V Alligator

Patch Cord

2.5in (63.5mm)

Alligator Test Clip

Patch Cord

2.30in (58.42mm)

Alligator Test

Clip Patch

Cord Kit

Model#

MG-B-12-*

MG-B-24-*

Length

12in (0.3m)

24in (0.6m)

Jaw Opening: 0.187in (4.75mm).

Cable: 18 AWG Wire, 0.144in (3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free

use: 45V. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F

(+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

1236-24-*

Length

24in (0.6m)

Cable: 20 AWG Wire, 0.087in (2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free

use: 45V. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F

(+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

6576-24-*

6576-36-*

Length

24in (0.6m)

36in (0.9m)

Jaw Opening: 0.300in (7.62mm).

Material: Body: nickel-plated steel; Boot: santoprene rubber.

Cable: 18 AWG Wire, silicone insulated.

Rating: Maximum voltage for hands free use:

1000V. 10A, -13 to 176°F (-25°C to 80°C).

*Std. Colors: -0 Black, -2 Red.

5 Way Alligator to

Sheathed Right

Angle Set

Model# Length

6483-48-02

48in (1.2mm)

Clip includes bed of nails and single needle tip for easy, versatile piercing of wire insulation to contact inner conductor for measurement.

Pierces 19 to 26 AWG wire.

Std. Colors: -0 Black, -2 Red, -02 Set of one black and one red.

Multi-Stacking Banana

Plug to Minigator Test

Clip

1.55in

(39.37mm)

1.79in

(45.47mm)

Retractable Sheath

Banana Plug Patch

Cord

2.72in (69.09mm)

Model#

3220-12-*

3220-24-*

3220-36-*

3220-48-*

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

Jaw Opening: 0.187in (4.75mm).

Cable: 20 AWG Wire, 0.087in (2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 45V. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

4911A-12-*

4911A-24-*

4911A-36-*

4911A-48-*

4911A-60-*

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Cable: 18 AWG Wire, 0.144in (3.56mm) O.D.

Rating: 1000V per IEC61010-031, 10A,

+176°F (+80°C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

AL-B-12-*

AL-B-24-*

AL-B-36-*

AL-B-48-*

AL-B-60-*

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Jaw Opening: 0.300in (7.62mm).

Cable: 18 AWG Wire, 0.144in (3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free

use: 150V. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F

(+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

6356-12

6356-24

6356-36

6356-60

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

60in (1.5m)

Kit contains

10pcs. of Model

AL-B patch cords, one each of 10 colors.

Extra Large Alligator

Test Clip to Sheathed

Banana Plug

Patch Cord

3.50in

(88.90mm)

Model#

6570-36-*

Length

36in (0.9m)

Alligator length: 3.6in (91.44mm),

Jaw Opening: 0.8in (20.32mm).

Rating: Conforms to IEC61010-031,

Overvoltage.

Category III, 1000V, 10A.

Cable: High flex 18 AWG Silicone wire.

*Std. Colors: -0 Black, -2 Red.

Minigrabber

®

Test Clip to Straight Banana

Plug Patch Cord

2.54in

(64.51mm)

1.54in

(39.12mm)

Model#

4650-24-*

4650-36-*

Length

24in (0.6m)

36in (0.9m)

Hook attaches to component leads up to

0.060in (1.52mm) O.D.

Cable: 20 AWG Wire, 0.087in (2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 300V. Do not use on circuits where transient stresses can exceed the rated voltage.5A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Patch Cords and Test Leads

0.025in (0.64mm)

Square Pin Jack to

Straight Banana Plug

Model#

4771-24-*

4771-36-*

Length

24in (0.6m)

36in (0.9m)

1.52in

(38.61mm)

0.10in

(2.54mm)

Cable: 22 AWG Wire, 0.064in (1.63mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum.

Do not use on circuits where transient stresses can exceed the rated voltage. 3A,

+122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

0.52in (13.21mm)

0.025in (0.64mm)

Square Pin Jack

Patch Cord

0.10in (2.54mm)

Model#

4741-6-*

4741-12-*

4741-24-*

Length

6in (0.15m)

12in (0.3m)

24in (0.6m)

0.52in (13.21mm)

Cable: 22 AWG Wire, 0.064in (1.63mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 45 Vac/60 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 3A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

0.025in (0.64mm)

Square Pin Jack

Patch Cord Kit

Model# 5948

Kit contains 10 pcs. of Model 4741-6, one ea. of 10 colors.

0.025in (0.64mm)

Square Pin Jack to

0.080in (2.03mm)

Pin Tip Plug

0.65in (16.51mm)

0.48in

(12.19mm)

0.52in

(13.21mm)

Model# Length

4772-24-* 24in (0.6m)

Cable: 22 AWG Wire, 0.064in

(1.63mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for

hands free use: 45 Vac/60 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 3A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

Banana Plug to

Banana Jack

1.52in

(39.37mm)

1.28in

(32.51mm)

0.52in (13.21mm)

Stacking Pin Tip Plug

Patch Cord

1.35in

(34.29mm)

Model#

P-4-*

P-8-*

P-12-*

P-18-*

P-24-*

P-36-*

Length

4in (0.1m)

8in (0.2m)

12in (0.3m)

18in (0.5m)

24in (0.6m)

36in (0.9m)

Cable: 20 AWG Wire, 0.087in (2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 3000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

4702-24-*

4702-36-*

4702-48-*

Length

24in (0.6m)

36in (0.9m)

48in (1.2m)

Cable: 18 AWG Wire, 0.144in

(3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

5000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 15A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Minigrabber

®

Test Clip to Miniature Stacking

Banana Plug

2.54in (64.52mm)

Alligator Test Clip to

Insulated Spade Lug

1.41in

(35.81mm)

0.89in

(22.61mm)

Miniature Stacking

Banana Plug Patch Cord

0.89in

(22.61mm)

0.26in (6.60mm)

0.50in (12.70mm)

2.30in

(58.42mm)

Model#

3784-24-*

3784-36-*

Length

24in (0.6m)

36in (0.9m)

Hook attaches to component leads up to

0.06in (1.52mm) O.D.

Cable: 20 AWG Wire, 0.087in

(2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

300V. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

1081-4-*

1081-8-*

1081-12-*

1081-18-*

1081-24-*

1081-36-*

1081-48-*

1081-60-*

Length

4in (0.1m)

8in (0.2m)

12in (0.3m)

18in (0.5m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

Cable: 20 AWG Wire, 0.087in

(2.21mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

3000 Vdc. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +131˚F (+55˚C) max.

*Std. Colors: -0 Black, -2 Red.

Model#

1960-36-*

Length

36in (0.9m)

Jaw Opening: 0.30in (7.62mm).

Cable: 18 AWG Wire, 0.144in

(3.56mm) O.D.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/

60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use:

150V. Do not use on circuits where transient stresses can exceed the rated voltage. 5A, +122˚F (+50˚C) max.

*Std. Colors: -0 Black, -2 Red.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

51

52

Calibration Kits

Pomona has made it easy for you to have exactly what you need with a huge selection of patch cords and test leads designed for reliable, convenient connections. Whether you need a test lead that can access an IC pin without shorting or a patch cord that accommodates multiple stacking, Pomona Electronics’ design and reliability are your connection with quality.

Calibration Accessory Kit

Model# CK73041

The Pomona CK73041 Calibration Kit includes the major connectors and test cables you need for instrument calibration in a comprehensive kit. Versatile adapters and flexible cables greatly expand the variety of test cables you can create, reducing the number of specialpurpose patch cords and connectors needed for calibration applications.

Perfect for:

• Field Calibration

• Outfitting a new technician or lab

• Comprehensive replacement of important connectors and leads

The Calibration Kit allows you to:

• Combine connectors with patch cords to create a wide variety of necessary test cables.

• Reduce the number of test cables needed by creating multiple combinations.

• Make low voltage precision measurements with shielded low thermal EMF spade lug patch cords.

• Easily connect to a variety of test equipment with BNC to banana and BNC to binding post adapters.

• Use shielded coax cables for test and calibration rather than unshielded leads.

• Turn banana plug patch cords into test leads terminated with alligator clips, spade lugs, or pin tips.

• Access N Type instrument jacks.

• Connect to analog components from coaxial cables.

• Take advantage of shielded dual conductor patch cords.

• Daisy-chain leads for those long lead situations.

For data sheets / specifications of the individual components contained in the CK73041

Calibration Kit, please visit our Pomona website at: www.pomonaelectronics.com

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Boxes and Enclosures

Pomona – the place to make your connections. From setting up system electronics to circuitry prototyping to creating permanent junctions, Pomona provides you with the boxes and enclosures to securely seal signal sensitive cables and wires. The large variety of die-cast aluminum connectorized enclosures and phenolic or molded thermoplastic boxes are ready to house components in styles and sizes that will simplify your interconnections.

Miniature Size Die Cast Aluminum Box with Cover

3753/3754

3752

Model# Finish

3754

3753

3751

3752

4742

4864

2352

None

BBE

BBE

Type

Connector: A

Length

Type

Connector: B

Length

BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm)

BBE BNC (F) 0.72in (18.29mm) BNC (M) 0.85in (21.59mm)

Replacement cover

Cover screws, 100/pkg

Connector screws with solder turret,100/pkg

BBE = Blue Baked Enamel Cover and screws included with all boxes.

0.08in (2.03mm)

1.13in

(28.70mm)

A

B

3751

A

1.50in (38.10mm)

B

0.88in

(22.35mm) depth

“A” Size Die Cast Aluminum

Box with Cover

2397/2400

2391

2401

2399

2390

2392

2393

2398

2393

2398

2399

4245

3728

4864

2352

Model# Finish Type

2400

2397

None

BBE

2390

2391

2392

2401

BBE

BBE

Connector: A

Length

Type

Connector: B

Length

BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm)

BNC (M) 0.85in (21.59mm) BNC (F) 0.72in (18.29mm)

Type

Connector: C

Length

BBE BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm)

BBE BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm) BNC (M) 0.85in (21.59mm)

BBE BNC (F) 0.72in (18.29mm) BNC (M) 0.85in (21.59mm) PDB 0.82in (20.83mm)

BBE SMA (F) 0.38in (9.69mm) SMA (M) 0.38in (9.69mm) – –

– – BBE SMA (F) 0.38in (9.69mm) SMA (F) 0.38in (9.69mm)

Replacement cover

Flange mounting cover

Cover screws, 100/pkg

Connector screws with solder turret

BBE = Blue Baked Enamel PDB = Post, Double Binding Cover and screws included with all boxes.

C

0.08in

(2.03mm)

C

1.13in

(28.70mm)

A B

A 2.25in (57.15mm) B 0.88in

(22.35mm) depth

www.pomonaelectronics.com

Boxes and Enclosures

54

“B” Size Die Cast

Aluminum Box with

Cover

2417/2428

3230

3231

2411

Model# Finish Type

2428

2417

3230

None

BBE

Connector: A

Length

Type

Connector: B

Length

BBE BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm)

3231

2411

3239

2420

BBE BNC (F) 0.72in (18.29mm) BNC (M) 0.85in (21.59mm)

BBE

BBE

N (M) 0.81in (20.57mm) N (F) 0.75in (19.05mm)

IBNC 0.47in (11.94mm) IBNC 0.47in (11.94mm)

BBE BNC (F) 0.72in (18.29mm) N (M) 0.75in (19.05mm)

3232

3234

4246

3719

4864

2352

Type

Connector: C

Length

BBE BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm)

Type

Connector: D

Length

BBE BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm) BNC (F) 0.72in (18.29mm)

Replacement cover

Flange mounting cover

Cover screws, 100/pkg

Connector screws with solder turret

BBE = Blue Baked Enamel IBNC = Isolated BNC Cover and screws included with all boxes.

C

C

0.08in

(2.03mm)

3239

1.38in

(35.05mm)

A B

A

2.25in (57.15mm)

B

1.13in

(28.70mm) depth

A

3232

B

2420

C D

3234

“C” Size Die Cast Aluminum Box with Cover

Model# Finish Type

2906

2901

2902

4248

2352

None

BBE

BBE BNC (F)

Replacement cover

Connector: A

Length

0.72 (18.29mm)

Connector screws with solder turret

Type

BNC (F)

BBE = Blue Baked Enamel Cover and screws included with all boxes.

Connector: B

Length

0.72 (18.29mm)

4.75in (120.65mm) 1.75in (44.45mm)

2.64in

(67.07mm)

A B

A 4.25in (107.95mm) B 1.71in

(43.43mm) depth

2902 www.pomonaelectronics.com

Boxes and Enclosures

“D” Size Die Cast Aluminum Box with Cover

Model# Finish Type

3606

None –

3601

3602

BBE

BBE

BNC (F)

3603

4726

2352

Connector: A

Length

BBE BNC (F)

Replacement cover

0.72 (18.29mm)

0.72 (18.29mm)

Connector screws with solder turret

Type

BNC (F)

BNC (M)

BBE = Blue Baked Enamel Cover and screws included with all boxes.

Connector: B

Length

0.72 (18.29mm)

0.85 (21.59mm)

0.09in (2.29mm)

55

3602

3603

3.00in

(76.20mm)

A B

“E” Size Die Cast

Aluminum Box with Cover

4226

3601/3606

Model# Finish

5186

None

4226

4416

Blue Baked Enamel

Replacement cover

Cover and screws included.

Recommended Circuit Board Sizes:

8.00in x 1.49in x .062in,

(203.2mm x 37.85 x 1.57mm) Thick.

3.90in x 1.49in x .062in,

(99.06mm x 37.85 x 1.57mm) Thick.

7.60in x 3.40in x .062in,

(193.04mm x 86.36mm x 1.57mm) Thick.

“F” Size Extruded Aluminum Box with Covers

3301/3306

4.22in

(107.19mm)

A

2.63in (66.80mm)

B 1.65in

(41.91mm) depth

8.87in (225.30mm)

8.32in (211.33mm)

2.75in

(69.85mm)

1.72in

(43.69mm) depth

Model# Finish Type

3306

None –

3301

3302

BBE –

BBE BNC (F)

4247

4862

2352

Connector: A

Replacement cover

Length

0.72in (18.29mm)

Cover screws, 100/pkg

Connector screws with solder turret

Type

BNC (F)

BBE = Blue Baked Enamel Cover and screws included with all boxes.

Connector: B

Length

0.72in (18.29mm)

0.20in (5.08mm)

2.68in

(68.07mm)

A B

3302

A 4.13in (104.90mm)

B

1.66in

(42.16mm) depth

Recommended Circuit Board Sizes:

3.90in x 1.48in x 0.062in,

(99.06mm x 37.59 x 1.57mm) Thick.

2.40in x 1.48in x 0.062in,

(60.96mm x 37.59mm x 1.57mm) Thick.

www.pomonaelectronics.com

Boxes and Enclosures

56

“G” Size Extruded

Aluminum Box with

Cover

Model# Finish

3316

None

3311

4247

4862

Blue Baked Enamel

Replacement cover

Cover screws, 100/pkg

Cover and screws included.

Recommended Circuit Board Sizes:

3.90in x 2.98in x .062in,

(99.06mm x 75.69mm x 1.57mm) Thick.

2.40in x 2.98in x .062in,

(60.96mm x 75.69mm x 1.57mm) Thick.

3311

“H” Size Extruded

Aluminum Box with

Cover

Model# Finish

3743

None

3742

4247

4862

Blue Baked Enamel

Replacement cover

Cover screws, 100/pkg

Cover and screws included.

Recommended Circuit Board Sizes:

3.90in x 5.98in x .062in,

(99.06mm x 75.69mm x 1.57mm) Thick.

2.40in x 5.98in x 0.062in,

(60.96mm x 75.69mm x 1.57mm) Thick.

3742

“J” Size Die Cast Aluminum Box with Cover

4655/5255

4656

2.68in

(68.07mm)

2.68in

(68.07mm)

0.20in (5.08mm)

4.13in (104.90mm)

0.20in (5.08mm)

4.13in (104.90mm)

3.16in

(80.26mm) depth

6.16in

(156.46mm) depth

Model# Finish Type

5255

4655

4656

4658

4864

None

BBE

BBE

BNC (F)

Connector: A

Length

0.72 (18.29mm)

Replacement cover

Cover screws, 100/pkg

Type

BNC (F)

BBE = Blue Baked Enamel Cover and screws included with all boxes.

Connector: B to E

Length

0.72 (18.29mm)

B-E

1.50in

(38.10mm)

A

B C D E

A

4.25in (107.95mm) 1.06in

(26.92mm) depth

Recommended Circuit Board Sizes:

4.13in x 0.87in x 0.062in,

(104.9mm x 22.10mm x 1.57mm) Thick.

1.38in x 0.87in x .062in,

(35.05mm x 22.10mm x 1.57mm) Thick.

www.pomonaelectronics.com

Boxes and Enclosures

“L” Size Die Cast

Aluminum Box with

Cover

4903

Model# Finish

5203

None

4903

5198

4864

Blue Baked Enamel

Replacement cover

Cover screws, 100/pkg

Cover and screws included.

Recommended Circuit Board Sizes:

5.88in x 1.48in x .062in,

(149.35mm x 37.59mm x 1.57mm) Thick.

2.88in x 1.48in x .062in,

(73.15mm x 37.59mm x 1.57mm) Thick.

3.00in

(76.20mm)

Black Phenolic Box with Cover

6.00in (152.40mm) 1.67in

(42.42mm) depth

Model# Finish Type

2105

EGP –

2259

2098

2096

EGP

EGP

EGP

PDB

DBJ

Connector: A

Length

0.80in (20.32mm)

Type

DBP

DBP

DBP

Connector: B

Length

0.70in (17.78mm)

0.70in (17.78mm)

0.70in (17.78mm)

EGP = Electrical Grade Phenolic

PDB = Post, Double Binding

DBJ = Double Banana Jack

DBP = Double Banana Plug

Cover and screws included with all boxes.

2105 2259

57

2098 2096

1.44in

(36.58mm)

A

A

B

B

A 1.75in (44.45mm) B

0.69in

(17.53mm) depth

Black Phenolic Box with Cover

2103

Model# Finish Type

2103

EGP –

2099

EGP BNC (M)

EGP = Electrical Grade Phenolic

DBJ = Double Banana Jack

DBP = Double Banana Plug

Connector: A

Length

0.85 (21.59mm)

Type

BNC (F)

Connector: B

Length

0.72 (18.29mm)

Cover and screws included with all boxes.

1.00in

(25.40mm)

A

A 2.25in (57.15mm)

B

B

1.00in

(25.40mm) depth

2099 www.pomonaelectronics.com

Boxes and Enclosures

58

Black Phenolic Box with Cover

2224

Model# Finish Type

2104

EGP –

2224

EGP DBJ

Connector: A

Length

Type

DBP

Connector: B

Length

0.70 (17.78mm)

EGP = Electrical Grade Phenolic

DBJ = Double Banana Jack

DBP = Double Banana Plug

Cover and screws included with all boxes.

1.53in

(38.86mm)

A

A

2.38in (60.45mm)

B

B

B

1.53in

(38.86mm) depth

2104

Molded Thermoplastic

Box with Card Guides and Cover

Model#

3850-0

3850-6

4864

Finish

Black - Thermoplastic

Blue - Thermoplastic

Cover screws, 100/pkg

Cover and screws included.

Recommended Circuit Board Sizes:

2.51in x 1.60in x .062in,

(63.35mm x 40.64mm x 1.57mm) Thick.

3850-0

Molded Thermoplastic

Box with Card Guides and Cover

Model#

4384-0

4384-6

4864

Finish

Black - Thermoplastic

Blue - Thermoplastic

Cover screws, 100/pkg

Cover and screws included.

Recommended Circuit Board Sizes:

3.93in x 1.58in x 0.062in

(99.82mm x 40.13mm x 1.57mm) Thick.

3.90in x 2.98in x 0.062in,

(99.06mm x 75.69mm x 1.57mm) Thick.

4384-0

1.81in

(45.97mm)

3.16in

(80.26mm)

2.69in (68.33mm) 1.37in

(34.80mm) depth

4.33in (109.98mm) 1.75in

(44.45mm) depth

www.pomonaelectronics.com

DMM Accessories and Kits

Connecting with the industry’s leading digital multimeter brands, Pomona provides the world’s largest selection of test leads and probes. Superior materials and outstanding design, assure conformity with industry- leading reliablility and performance standards. From high-density

IC leads to voltage on a distribution panel, Pomona connects you with the right solution.

Deluxe Multi-Use DMM Maxi-Kit

3

10

6

9

5

8

2

4

Electronic DMM Maxi-Kit

2

7

1

5

6

10

7

11

8

3

11

1

12

Model# 5677B

1. Silicone insulated 4ft (1.2m) leads with right angle plug.

2. Modular probe set with replaceable tips.

3. 5 sets of replacement tips.

4. Retractable tip test probe set.

5. Test lead coupler set.

6. Medium alligator clip set.

7. Large alligator clip set.

8. Spade lugs.

9. IC probe tip adapter.

10. Minigrabber

®

test clip leads.

11. Minipincer

®

test clip leads.

12. Nylon storage pouch.

• Modular probes with interchangeable tips.

• Silicone insulated 4ft (1.2m) test leads with right-angle

DMM plugs for most meters from Fluke, HP, Meterman,

Amprobe, and others.

• New retractable tip probe with 3in (76.2mm) long tip and silicone leads.

• Minigrabber

®

and Minipincer

®

test clip leads attach to test leads.

• Test lead coupler connects leads to probe set for

16ft (4.8m) reach.

• Nylon storage pouch with compartments for accessories.

4

Model# 6340

1. Silicone insulated 4ft (1.2m) leads.

2. Modular probe set.

3. Precision electronic probes.

4. 4 sets of replacements tips.

5. Test lead couplers.

6. Medium alligator clips.

7. Large alligator clips.

8. Minigrabber

®

test clip leads.

9. Minipincer

®

test clip leads.

10. Spade lugs.

11. Nylon storage pouch.

• Modular probes with caged-spring tips fit 4mm sockets.

• Silicone insulated 4ft (1.2m) test leads with right-angle

DMM plugs fit most meters from Fluke, HP, Meterman,

Amprobe, Greenlee and others.

• Precision Electronic probe with replacement tips offers flexibility in testing.

• Minigrabber test points.

® and Minipincer

®

test clip leads for smaller

• Nylon storage pouch with compartments for accessories.

9

59 www.pomonaelectronics.com

DMM Accessories and Kits

60

Deluxe Electronic DMM Test Lead Kit

6

9

4

1

Model# 5674C

1. Silicone insulated 4 ft (1.2m) leads with right-angle plug.

2. Modular probe set with standard tips.

3. Extended probe tip adapters.

4. Medium alligator clips.

5. IC probe tip adapters.

6. Minigrabber

®

test clip leads.

7. Minipincer

®

test clip leads.

8. Maxigrabber

®

test clips with pincer tip.

9. Nylon storage pouch.

• Modular probes with standard probe tips.

• Insulated 4ft (1.2m) test leads with right-angle DMM plugs fit most meters from Fluke, HP, Meterman, and others.

• Probe tip extender with 3in (76.2mm) long tip.

• Minigrabber

®

test clip leads attach to test leads.

• Minipincer

®

test clip leads for fine pitch chip leads.

• Maxigrabber

®

test clips attach to test leads.

• Nylon storage pouch with compartments for accessories.

2

3

5

7 8

Electronic DMM Test Lead Kit

9

4

7

8

11

Basic Electronic DMM Test Lead Kits

6

5

3

2

Model# 5543B

1. Silicone insulated 4ft (1.2m) test. leads with right-angle DMM plugs.

2. Modular electronic test probes with standard tips.

3. Extended fine-tip probe adapter -red.

4. Medium alligator clip -black.

5. IC probe tip adapter -red.

6. Insulated spade lug -black.

7. Minipincer

®

test clip lead -red.

8. Minigrabber

®

test clip lead -red.

9. Nylon storage pouch.

• Silicone insulated 4ft (1.2m) test leads fit meters from Fluke, HP,

Meterman, and others.

• Modular electronic test probes attach to leads.

• Extended fine-point adapter attaches to probe tips.

• IC adapter attaches to probe for secure probing on chip leads.

• Minipincer

®

test clip lead for fine pitch chip leads.

• Minigrabber

®

test clip lead extend the reach of the test leads.

1

2

Model#

6343

5672A

6344

Plug Type

Right-angle DMM plugs

Right-angle banana plug

Straight DMM plugs

5325A

Stacking banana plugs

1. Comfort-grip DMM test probes.

2. Silicone insulated 4ft (1.2m) leads.

3. Extended probe tip adapters.

4. Alligator clip probe tip adapters.

5. Plastic storage case (not shown).

Note: Model 5672A has HEAVY-DUTY stainless-steel tips.

See page 67 for banana plug types.

Ratings

IEC61010, CAT III 1000V

CAT II 1000V without protective cap

30 Vrms/42.4 Vpk/60 Vdc

IEC61010, CAT III 1000V

CAT II 1000V without protective cap

30 Vrms/42.4 Vpk/60 Vdc

• Featuring Pomona’s new comfort-grip probes.

• Monolithic probes with fixed tips.

• DMM plugs fit most meters from

Fluke, Meterman, HP, Amprobe,

Greenlee, and others.

• Extended tip adapter has sharp needle point.

• Alligator clip adapter snaps onto the probe tip.

3

4 www.pomonaelectronics.com

DMM Accessories and Kits

Deluxe Electronic Bench DMM Test Lead Kit

5

2

3

1

8

7

6

4

9

Electronic Bench DMM Test Lead Kit

3

4

6

5

1

Model# Features

6204A

Straight DMM plugs

1. Silicone insulated 4ft (1.2m) test leads with straight DMM plugs.

2. Modular electronic test probes with standard tips.

3. Extended fine-tip probe adapters.

4. Medium alligator clips.

5. IC lead probe tip adapters.

6. Insulated spade lugs.

7. Minipincer

®

test clip leads.

8. Minigrabber

®

test clip leads.

9. Nylon storage pouch.

Ratings

CAT III, 600V per IEC61010-031

• Silicone insulated 4ft (1.2m) leads fit meters from Fluke, HP (Agilent),

Keithley and others.

• Modular electronic test probes attach to leads.

• Extended fine-point adapters attach to probe tips.

• IC adapters attach to probes for secure probing on chip leads.

• Minipincer

®

test clip leads for fine pitch chip leads.

• Minigrabber

®

test clip leads extend the reach of the test leads.

61

7

Model# 5901B

1. Silicone insulated 4ft (1.2m) test leads with straight DMM plugs.

2. Modular electronic test probes with replaceable tips.

3. 5 sets of replacement probe tips

4. Medium alligator clips.

5. Insulated spade lugs.

6. Minigrabber

®

test clip leads.

7. Nylon storage pouch.

• DMM plugs fit meters from Fluke,

HP (Agilent), Keithley and others.

• Modular electronic test probes with replaceable tips adapt to many different modes.

• Replacement probe tips offer a wide variety of probing solutions.

• Alligator clips attach to test lead for reliable connections.

• Spade lugs attach to test leads for binding posts or terminal screws.

• Minigrabber

®

test clip leads extend the reach of the test leads.

• Uses 080 probe tips, see 17 for replacement tips.

• Rated CAT II 600V 10A.

2

Deluxe Automotive DMM Test Lead Kit

8

5

2

6

7

1

3

Mode# 6530A

1. Silicone insulated 4ft (1.2m) test leads with right-angle DMM plugs.

2. Heavy-duty modular test probes with stainless-steel tips.

3. Heavy-duty alligator clips.

4. Insulation piercing clips.

5. Maxigrabber

®

test clips with alligator jaws.

6. Maxigrabber

®

test clips with hook.

7. Backprobe pins.

8. Nylon storage pouch.

4

• Alligator clips attach to test lead for reliable connections.

• Sharp stainless-steel probe tips resist wear.

• Insulation piercing clips make connections without stripping insulation from wires.

• Backprobe pins access contacts through the back side of automotive connectors.

• DMM plugs fit meters from Fluke,

Meterman, Amprobe, Greenlee and others.

• Maxigrabber

®

test clips with alligator jaws for quick and easy connections.

www.pomonaelectronics.com

DMM Accessories and Kits

62

Industrial/Automotive DMM Test Lead Kit

6

5

1

2

3

Model# 5903A

1. Silicone insulated 4ft (1.2m) test leads with right-angle DMM plugs.

2. Heavy-duty modular test probes.

3. Heavy-duty alligator clips.

4. Insulation piercing clips.

5. Maxigrabber

®

test clips with alligator jaws.

6. Nylon storage pouch.

• DMM plugs fit meters from Fluke,

Meterman, Amprobe, Greenlee and others.

• Sharp stainless-steel probe tips resist wear.

• Alligator clips attach to test lead for reliable connections.

• Insulation piercing clips make connections without stripping insulation from wires.

• Maxigrabber

®

test clips with alligator jaws for quick and easy connections.

4

2

5

Deluxe Electrical DMM Test Lead Kit

7

1

6

8

Model#

5904A

Plug Type

Right-angle DMM plug

1. Silicone insulated 4ft (1.2m) test leads.

2. Modular electrical test probes with stainless-steel tips.

3. Maxigrabber

®

test clips with jaws.

4. Maxigrabber

®

test clips with hooks.

5. Maxigrabber

®

test clips with pincers.

6. Large alligator clips.

7. Nylon Storage pouch.

8. Protective caps

Ratings

CAT III 1000V per IEC61010-031

CAT II 1000V without protective cap

• DMM plugs fit meters from Fluke,

Meterman, Amprobe, Greenlee and others.

• Alligator clips attach to the test leads for secure connections.

• Maxigrabber

®

test clips attach to test leads.

• Nylon storage pouch to contain all kit components.

4 3

Electrical DMM Test Lead Kit

4

3

6

1

Model# 5673B

1. Silicone insulated 4ft (1.2m) test leads with right-angle DMM plugs.

2. Modular electrical test probes with stainless-steel tips.

3. Extended tip probe adapters.

4. Insulated spade lugs.

5. Medium alligator clips.

6. Large alligator clips.

7. Nylon storage pouch.

• DMM plugs fit meters from Fluke,

Meterman, Greenlee, Amprobe and others.

• Spade lugs connect to test leads and can be secured to binding posts or terminals.

• Alligator clips plug into the test leads.

2

5

7 www.pomonaelectronics.com

See page 61 for more Test Companion Kits.

DMM Accessories and Kits

Basic Electrical DMM Test Lead Kit

4

1

Model#

5900A

Plug Type

Right-angle DMM plug

1. Silicone insulated 4ft (1.2m) test leads with right-angle DMM plugs.

2. Modular electrical test probes with standard tips.

3. Maxigrabber

®

test clips.

4. Nylon storage pouch.

Ratings

CAT III 1000V per IEC61010-031

CAT II 1000V without protective cap

• DMM plugs fit meters from Fluke,

Metermam, Greenlee, Amprobe and others.

• Maxigrabber

®

test clips with jaws attach to test leads.

• Nylon carrying pouch included.

63

3

2

Multi-Use DMM Test Lead Kit

5

3

2

Deluxe Industrial Test Companion

Kit

4

9

8

6

2

5

1

4

Model# Ratings

5899A

CAT III 1000V per IEC61010-031

CAT II 1000V without protective cap

1. Silicone insulated 4ft (1.2m) test leads with right-angle DMM plugs.

2. Modular electrical test probes with standard tip.

3. Maxigrabber

®

with pincer tips.

4. Medium alligator clips.

5. Nylon storage pouch.

6. Protective caps

• DMM plugs fit meters from Fluke,

Meterman, Greenlee, Amprobe and others.

• Alligator clips attach to test lead for reliable connections.

• Maxigrabber connections.

®

test clips with pincers for quick and easy

3

6

Model# 6173A

Includes shoulder-pack style Cordura carrying case plus the following IEC61010 compliant test accessories:

1. Modular Electrical Test Probe Set with Banana

Plug Tip.

2. Flexible Test Lead Set with Right-Angle and

Straight Banana Plugs.

3. Probe Lead Set with Sharp Stainless Steel Tip.

4. Maxigrabber

®

Test Clip Set with Pincer Tip.

5. Maxigrabber

®

Test Clip Set with Hook Tip.

6. Maxigrabber

®

Test Clip Set with Jaws.

7. Extra Large Alligator Clip Set.

8. Medium Alligator Clip Set.

9. Insulated Spade Lug Sets (2).

7

See page 61 for more Test Companion Kits.

1 www.pomonaelectronics.com

64

Deluxe Electronic Test Companion

Kit

5 6

3

1

2

12

11

10

Industrial Test Companion

Kit

4

6

9

5

7

DMM Accessories and Kits

8

1

4

7

Model# 6345

Includes large briefcase style Cordura carrying case plus the following test accessories:

1. Modular Electronic Probe Set with Replaceable Tip.

2. Assorted Replacement Tips.

3. Flexible Test Lead Set with Right Angle and

Straight Banana Plugs.

4. SMD Test Tweezer

®

to Banana Plugs.

5. Minigrabber

®

Test Clip Leads.

6. Minipincer

®

Test Clip Leads.

7. Micrograbber

®

Test Clip Leads.

8. SMD Grabber

®

Test Clip Leads.

9. Medium Alligator Clip Set.

10. Slide-on Extended Tip Set.

11. Slide-on IC Tip Set.

12. Spade Lug Adapter Set.

Model# 6172A

Includes shoulder-pack style Cordura carrying case plus the following IEC61010 compliant test accessories:

1. Modular Electrical Test Probe Set with Banana

Plug Tip.

2. Flexible Test Lead Set with Right-Angle and

Straight Banana Plugs.

3. Probe Lead Set with Sharp Stainless Steel Tip.

4. Maxigrabber

®

Test Clip Set with Pincer Tip.

5. Maxigrabber

®

Test Clip Set with Hook Tip.

6. Medium Alligator Clip Set.

7. Insulated Spade Lug Set.

3

2

Electronic Test Companion

Kit

6

5

2

4 www.pomonaelectronics.com

3

1

10

9

7

8

Model# 6174

Includes shoulder-pack style Cordura carrying case plus the following test accessories:

1. Modular Electronic Probe

Set with 0.080in (2.03mm) diameter tip.

2. Flexible Test Lead Set with Right-Angle and

Straight Banana Plugs.

3. SMD Test Tweezer

®

to Banana Plugs.

4. Minigrabber

®

Test Clip Leads

5. Micrograbber

®

Test Clip Leads.

6. SMD Grabber

®

Test Clip Leads.

7. Medium Alligator Clip Set.

8. Slide-on Extended Tip Set.

9. Slide-on IC Tip Set.

10. Spade Lug Adapter Set.

See page 66 for more Test Companion Kits.

DMM Accessories and Kits

Probe and Lead Kit for Portable Scopes

1

10

2

6

4

3

5

Model# 72942

Includes shoulder-pack style Cordura carrying case plus the following test accessories:

1. Red Scope Probe, 500 MHz, see page 77.

2. Black Ground Lead.

3. Red Sprung Hook.

4. Probe Tip Ground.

5. Modular Test Probe with Standard 0.080in (2mm) Tip.

6. Flexible Test Lead Set with Straight and Right-Angle Banana Plugs.

7. Medium Alligator Clip Set.

8. Extra Large Alligator Clip Set.

9. Maxigrabber

®

Set Pincer Style.

10. Maxigrabber

®

Test Clip Set with Jaws.

65

7

9

Precision Electronic Test Probe Set

4.3in (109.22mm)

Safety 2mm/4mm

Test Probe Set

Model#

6601

Ratings

IEC61010 1000V CAT III

CAT II 1000V without protective cap

• Versatile 2mm probe tip with screw-on 4mm tip.

• Each probe includes Protective Cap designed to meet Guidance Note

GS38.

• Silicon insulated 4ft (1.2m) test leads with right-angle DMM plugs.

• Comfort-grip textured surface.

Retractable Needle

Tip Test Probes

See page 62 for banana plug types.

Model# Plug Type Ratings

5953A

Right-angle DMM CAT II 600V*

5952A

Stacking banana 600V**

*per IEC61010

• Silicone insulated 4ft (1.2m) leads fits most meters from Fluke, Meterman, HP, Amprobe,

Greenlee and others.

• Fully insulated tip extends to 3in (76.2mm).

• Durable 0.040in (1.02mm) stainless-steel needle tips reach into inaccessible areas.

• Set of 2 probes, one black and one red.

**Ratings: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.2 Vpk / 60 Vdc or current exceeds 8A maximum.

Maximum voltage for hands free use: 600 Vrms.

Do not use on circuits where transient stresses can exceed the rated voltage.

3

4

5

1

2

Model# Features

6341

Probe set with complete set of 5 tips

6342

6275

6354

Probe set with sharp point gold pogo pin tips

Probe set with sharp stainless steel rigid tips

Replacement probe tips. Set of 5 types.

• Replaceable 0.04in (1.01mm) pogo-pin tips.

• Small outline for tight test situations.

• Replaceable pogo-pin tips.

• Comfort-grip textured surface.

• Fits all meters including Fluke, HP

(Agilent), Keithley, Meterman and others.

• Silicone insulated leads resist abrasion and heat.

Ratings

IEC61010 CAT II 1000V*

CAT II 1000V

CAT II 1000V

Replacement Tips

1. Sharp-point gold pogo-pin.

2. Tri-point gold pogo-pin.

3. Quad-point gold pogo-pin.

4. Sharp stainless steel rigid.

5. 3in (76.2mm) long extended.

Stainless steel.

*except when used with 3in (76.2mm) tip which is 33Vrms/70Vdc.

See page 71 for more probe tips.

Test Probes with

Screw-on

Alligator Clips

Additional Screw-on

Alligator Clip Set for 6723

Model#

6723

Ratings

IEC61010 1000V CAT III

20A (probe alone)

IEC61010 1000V CAT II without protective cap

IEC61010 300V, CAT II 10A

(with alligator clip attached)

• Probe set includes 2 screw-on alligator clips.

• 8-32 threaded tips allow secure, attachment of alligator clips.

• Silicon insulated 4ft (1.2m) test leads with right-angle DMM plugs.

• Comfort-grip textured surface.

• Wide temperature range of 14 to 131°F

(-10 to +55°C).

Model#

6726

Ratings

300V, CAT II 10A

• Set of 2 screw-on alligator clips.

• Designed for use with 8-32-UNC 2A threaded probe like the Pomona 6723.

• 8-32 threaded tips allow secure attachment of alligator clips.

• Wide temperature range of 14 to 131°F

(-10 to +55°C).

www.pomonaelectronics.com

DMM Accessories and Kits

66

Test Companion Kits include your favorite probes, clips, and leads in their own specially designed carrying case. Select from the following table.

6112A 6162 6171

Kit Model#

6172A 6173A 6174 6175 6237 Model#

Test Probes

5689A Probe with Replaceable Tip

5906A Probe with 0.16in (4mm) Banana Tip

6232A Probe with 0.080in (2.03mm) Brass Tip

Test Leads

5678 SMD Test Tweezers with DMM Plugs

5898 Right-Angle Banana/Probe

5907A Straight/Right-Angle Banana

5908A Straight/Straight Sheath Banana Plugs

Alligator Clips

5916A Medium Alligator Clips (2)

6041B Large Alligator Clips (2)

Grabbers

5910B Maxigrabber Set with Pincer Tips (2)

5911B Maxigrabber with Hook Tip Set

5912B Maxigrabber Alligator Clip Set

Patch Cords

6244 Minigrabber to Right-Angle Sheathed Banana Plug

6248 Minigrabber to Sheathed Banana Jack

Oscilloscope Probes

4550B Oscilloscope Probe

Probe Tips/Tip Adapters

5133 Probe Tip Stainless Steel, Dog Leg Micro (2)

5682 Extended Tip Adapter

6262 Extended Tip Adapter

6263 IC Test Tip Adapter

Spade Lug Adapters

6203 Insulated Spade Lug

Coaxial Cable Assemblies/Adapters

2249 BNC (M) Cable Assembly

3788 BNC (M) to Minigrabber Adapter

Carrying Cases

5955 Tri-fold Pouch

6146 Briefcase

6147 Medium Shoulder-pack

6345

Page

68

68

68

71

67

68

68

70, 75

69, 75

70

7

16

66

66

66

46

46

80

69

69

69

71

70

70

71

Pomona’s Test

Companion

Accessory

Cases and Pouches

Model# Description

6146

Briefcase style with carrying strap

6147

5955

Medium shoulder-pack with carrying strap

Folding case with Velcro

6146

6147 www.pomonaelectronics.com

5955

DMM Accessories and Kits

Replacement DMM Test Lead Sets with

Fixed Tips

5.5in (139.7mm)

Probe Kit with Full Set of 5

0.060in (1.52mm) Replacement Tips

4.85in (123.19mm)

3

4

1

2

5

Replaceable 0.060in (1.52mm) Tip Probes

4.85in (123.19mm)

3

4

1

2

5

Model# Features

5519A

Standard tip Nickel/brass

6365

6366

Standard tip Nickel/brass

Standard tip Nickel/brass

Plug Type

Right-angle DMM (1)

Straight DMM (2)

Retractable sleeve (5)

5898

Stainless steel heavy-duty tip Right-angle DMM (1)

5309A

Stainless steel heavy-duty tip Stacking banana (3)

Ratings

CAT III 1000V*

CAT III 1000V*

CAT III 1000V*

CAT III 1000V*

1000V**

*per IEC61010-031

CAT II 1000V without protective caps

• Monolithic probes with fixed tips.

• Durable 080 tips for long life.

• Comfort-grip probe.

• Silicone insulated 4ft (1.2m) leads fit most

DMMs from Fluke, HP (Agilent), Meterman,

Amprobe, Greenlee and others.

For Plug Type, see below.

**Ratings: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free use:

1000 Vrms. Do not use on circuits where transient stresses can exceed the rated voltage.

67

Model# Description

5676A

Hand held DMM probe set

• Two test probes with a full set of all

5 probe tips (10 tips total).

• Silicone insulated 4ft (1.2m) leads.

• 0.06in (1.52mm) tip diameter.

Plug Type

Right-angle DMM (1)

Ratings

CAT II 1000V*

*per IEC61010-031

Replacement Tips

1. Sharp gold-plated plunger tip.

2. Triple-point gold-plated pogo pin.

3. Gold plated micro tip pogo.

4. Stainless-steel sharp-point.

5. Standard brass.

See page 71 for more probe tips.

Model# Probe Tip

6469

6470

6477

Gold-plated Microtip pogo

Gold-plated Microtip pogo

Stainless-steel sharp-point

5950A

Stainless-steel sharp-point

5951A

Nickel-plated brass

• New 0.06in (1.52mm) diameter solid and pogo-pin probe tips can be easily replaced without tools making this versatile probe the perfect tool for nearly every test.

• Comfort-grip probe handle.

Replacement tips available as 6475.

Plug Type

Right-angle DMM (1)

Straight DMM (2)

Right-angle DMM (1)

Straight banana (4)

Right-angle banana (6)

Ratings

CAT II 1000V*

CAT II 1000V*

CAT II 1000V*

1000V**

1000V**

*per IEC61010-031

1. Sharp gold-plated plunger tip.

2. Triple-point gold-plated pogo pin.

3. Gold-plated micro tip pogo.

4. Stainless-steel sharp-point.

5. Standard brass.

See page 71 for more probe tips.

**Ratings: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk / 60 Vdc or current exceeds

8A maximum. Maximum voltage for hands free

use: 1000 Vrms Vdc. Do not use on circuits where transient stresses can exceed the rated voltage.

Plug Types

1. Right-angle DMM plug*

2. Straight DMM plug*

3. Stacking banana plug

4. Straight banana plug

5. Retractable sleeve banana plug

6. Right-angle banana plug

* Shrouded DMM plugs fit most DMMs from Fluke, Meterman, HP (Agilent),

Amprobe, Greenlee and others.

1 2 3 4 5 6 www.pomonaelectronics.com

DMM Accessories and Kits

68

Replacement DMM Test Leads

Choose plug for this end from below

Plugs into probes below

Model# Application

5907A

Hand held DMM modular test leads

5908A

Bench-top DMM modular test leads

5909A

6358

Hand held DMM modular test leads

Universal DMM test leads

Features

Right-angle DMM plug (1)

Straight DMM plugs (2)

• Leads for Pomona Modular Test Probes.

• Plugs fit most popular DMMs from

Fluke, Meterman, HP (Agilent), Amprobe,

Greenlee and others.

• Silicone insulated 4ft (1.2m) leads.

• Wear indication with double insulated silicone leads for increased safety.

• Retractable sleeve plug fits all banana jacks, binding posts and DMM input jacks.

Ratings

CAT III 1000V*

CAT III 1000V*

Right-angle DMM plug at both ends (1)

Retractable sheath DMM plugs (3)

CAT III 1000V*

CAT III 1000V*

*per IEC61010-031

Plug Types

1. Right-angle DMM.

2. Straight DMM.

3. Retractable sheath 0.16in (4mm).

1 2 3

Replacement Modular Test Probes

6232A

5906A

Model# Probe Type

6232A

6479

5906A

5689A

Modular electrical probe

Industrial modular probe

Lantern tip

Replaceable tip modular probe

• Modular probes fit all Pomona test leads.

• Lantern tip probes fit into banana jacks.

Features

Standard 0.08in (2.03mm) tip

Stainless-steel 0.08in

(2.03mm) sharp-point

Fits 4mm Jack

Stainless-steel 0.08in

(2.03mm) sharp-point

Ratings

CAT III 1000V*

CAT III 1000V*

CAT III 1000V*

CAT III 600V*

*per IEC61010-031

CAT II 1000V without protective cap

6479

5689A

Replacement Modular Test Probe Sets

Model# Description

6286

6288

6304

Standard tip with right-angle

DMM plug

Stainless-steel tip with right-angle

DMM plug

Lantern tip probe with right-angle

DMM plug

Probe

Type

6232A

6479

5906A

Test Lead

Type

5907A

Ratings

CAT III 1000V*

5907A

5907A

CAT III 1000V*

CAT III 1000V*

*per IEC61010-031

CAT II 1000V without protective cap

6232A

6479

5906A 5689A

• Modular test probes sets contain one set of modular probes and test leads in one package.

• Silicone insulated 4ft

(1.2m) leads fit most meters from Fluke,

Meterman, HP (Agilent),

Amprobe, Keithley,

Greenlee and others.

www.pomonaelectronics.com

DMM Accessories and Kits

SMD Micro Tip/Test Probe

Maxigrabber

®

Test Clip Set with Pincer

6405

Maxigrabber

®

Test Clip Set with Hook

Model# 5911B

Includes set of 2, one red and one black.

Hook Fits Test Points to: 0.060in

(1.52mm) diameter.

Hook Opens to: 0.25in (6.5mm).

Rating: Overvoltage CAT III, 1000V,

10A per IEC61010-031.

Large Alligator Clip Set

Maxigrabber

®

Test Clip Set with Jaws

Model#

5144-48-0

5144-48-2

6235

Color

Black

Red

Set of two: Black,

Red

The probe microtip is specially designed to probe SMD contacts.

It features a stainless steel needle tip that is flexible to help prevent damage to SMD lands. The tip is curved to aid in probing hard to reach areas.

Ratings: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum. Maximum voltage for

hands free use: 1200 Vrms Max. Do not use on circuits where transient stresses can exceed the rated voltage.

Model# 5910B

Includes set of 2, one red and one black.

Pincer Opening: 0.080in (2.03mm) dia. test point.

Rating: Overvoltage CAT III, 1000V,

10A per IEC61010-031.

Model# 5912B

Includes set of 2, one red and one black.

Jaw Opening: 0.50in (12.70mm) dia.

Rating: Overvoltage CAT III, 1000V,

10A per IEC61010-031.

BNC Shielded Test

Probe Kit

Insulation Piercing

Clip Sets

3.58in (90.9mm)

Industrial Alligator

Clip Set

Model# 5292-48

Shield extends to within 1.5in

(3.8cm) of probe tip. Compatible with DMM banana plug inputs when using Pomona 1269 BNC to double banana plug adapter. Alligator or

Minigrabber test clip can be quickly threaded onto ground lead. Stainless steel dog leg tip excellent for SMD probing. Kit includes: Shielded test probe, Minigator with 6-32 thread for ground lead and insulated flex boot for

Minigator, Minigrabber test clip with

6-32 thread for ground lead, Dog leg probe tip.

Ratings: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum. Maximum voltage for hands free use: 500 Vrms

Max. Do not use on circuits where transient stresses can exceed the rated voltage.

Model#

6405

6413

Features

Attach to test leads 4in

(10.2cm) long

Attach to 0.080in

(2.03mm) probe tip(10.2cm) long

Colors

Set of red/black

Set of red/black

• Double V block centers wire

• Set of 2, (red and black jacks)

• Bright yellow for easy location

• Attach to test leads

Model#

6041B

6042B-*

Color

Set of 2: Black, Red

1 Clip

Fits on any DMM or banana plug test lead.

Rating: IEC61010-031 CAT III

1000V 20A.

Jaw Opening: 1.0in (25.40mm).

*For singles, order: -0 Black,

-2 Red.

Insulation Piercing

Maxigrabber

®

Test Clip Set

3.20in (81.3mm)

Model# 5914

Fits on any DMM or banana plug test lead.

Rating: IEC61010-031 CAT III

600V 10A.

Jaw Opening: to 1.0in (25.40mm).

*Std. Colors: -0 Black, -2 Red.

Model# 5913

Includes set of 2, one red and one black.

Pierces insulation to make connection on wire up to 0.144in

(3.66mm) diameter.

Rating: Overvoltage per

IEC61010-031 CAT III,

1000V, 5A.

69 www.pomonaelectronics.com

DMM Accessories and Kits

70

Medium Alligator Clip Set

2.27in (57.7mm)

Model#

5916A

5787A-*

Color

Set of 2: Black, Red

1 Clip

Fits on any DMM or banana plug test lead.

Rating: CAT I. 300V 5A.

Jaw Opening: to 0.30in. (7.62mm).

*For singles, order: -0 Black, -2 Red.

Test Lead Couplers

Model# 6252

Banana plug splice.

Maintains overvoltage rating up to CAT III

1000V per IEC61010-031.

Use with any Pomona DMM test leads, even 0.16in (4mm plugs).

Test Probe Tip Adapters

2.96in (75.2mm)

Model# 6264-*

Alligator Clip.

Attach to probe tip.

Rating: CAT I. 300V. 5A

Works with comfort-grip style and modular electrical probes.

*Std. Colors: -0 Black, -2 Red.

Test Probe Tip Adapters

1.99in (50.42mm)

3.95in (100.3mm)

6262

2.0in (50.8mm)

Model# Application

6262-* fits comfort-grip style and modular probes 6232A and 6479

5682-* fits modular probe 5689A

Extended Fine Point.

Insulated probe for hard to reach test points.

Maximum 3A.

Std. Colors: -02 1 ea. Black,

Red.

Test Probe Tip Adapters

6263

Fits 5519A etc.

Model# Application

6263-*

fits comfort-grip style and modular probes 6232A and 6479

IC Probe Tip.

Attach to 0.08in (2mm) probe tips.

Rating: IEC61010 CAT II, 300V, 5A.

*Std. Colors: -0 Black, -2 Red.

AC Voltage Detector and Flashlight

Model# 7290

AC Voltage Detector – Detects voltages from 40 Vac to 300 Vac from 1 to 15 inches away from the source. Flashlight feature includes ultra-bright white LED with 100,000 hour bulb. Offers long battery life with standard alkaline AAA battery. No lithium battery needed.

3.27in (83.1mm)

5682

Insulated Spade Lug

Adapters

6203

Model#

6203

1614A-*

Color

Set of 2: Black, Red

1 Clip

Connect banana plug patch cords to binding posts.

Fits screws or binding posts from #10:

0.32in to 0.25in (8.13mm to 6.35mm).

Compatible with any Pomona banana jack shrouded or unshrouded

*For singles, order: -0 Black, -2 Red.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

DMM Accessories and Kits

0.08in (2.03mm)

Replacement

Probe Tips

1

2

Model# Item

5133

3

6364

Features

SMD Microtip™ stainless-steel tip

Full set Set of all tips

1(4ea) Nickel-plated standard tip

2(2ea) Stainless-steel sharp point

3(2ea) SMD Microtip™ stainless-steel tip

4(2ea) Sharp needle-point stainless-steel

3

4

0.04in (1.01mm)

Replacement

Probe Tips

1

2

3

Model# Item

6212

3

6354

Features

Quad-point gold-plated pogo pin

Full set Set of all tips

1 Sharp gold-plated

4

5

2

3

Triple-point gold-plated pogo pin

Quad-point gold-plated pogo pin

Sharp stainless-steel

3in (76.2mm) long extended.

4

5

0.06in (1.52mm)

Replacement

Probe Tips

1

2

Model# Item Features

6475

Full set Set of all tips

1

2

3

4

5

Sharp gold-plated plunger tip

Triple-point gold-plated pogo pin

Gold-plated micro tip pogo

Stainless-steel sharp-point

Standard brass

3

4

5

SMD Test Tweezer Products

0.04in (1.01mm)

Min. Closed

Model# Features

5143-K-48

Stacking Banana Plug

5142-K-48

BNC Male

Ratings

30 Vrms /42.4 Vpk/60 Vdc,3A

30 Vrms/42.4 Vpk/60 Vdc,3A

5678-K-48

Right-Angle DMM Plug 30 Vrms/42.4 Vpk/60 Vdc,3A

Length: 48in (1.22m)

0.33in

(8.38mm)

4.40in (111.76mm)

0.1in (2.54mm)

71

5143

RF Detector Test Probes

5142 5678

Model#

6106

Turn-On

Voltage (mV)

350

Bandwidth

(MHz)

1MHz-1GHz ± 1.5 dB

Input

Capacitance

(pF)

6

Peak AC

Input (V)

30

Displays RF voltages on multimeter.

Manufactured with high reliability SMD components.

Slim-line probes will show AC voltages with sine wave shapes between 500 Hz and 1 GHz.

Display will show 1 VDC for 1 VRMS of the sine wave signal.

Works best on multimeters with 10M Ω input impedance.

Cable Length: 4ft (1.2m).

DC Isolation

Incl. Peak

AC (V)

100

www.pomonaelectronics.com

DMM Accessories and Kits

72

Create Your Own Test Leads for Your Own

Specific Needs with the Following:

Kelvin Probes

Test Lead Wire with

Silicone or PVC

Insulation

Do-It-Yourself 4mm

Right Angle

Banana Plug

1.28in

(32.4mm)

Model# Insulation

Type

6733-*

6734-*

Silicone

PVC

Length

50ft (15.2m)

50ft (15.2m)

• 50ft (15.2m) of unterminated 18 AWG test lead wire 50ft (15.2m lengths only.)

• Choose from heat-resistant silicone or

PVC insulation.

• Very flexible with 192 strands of

41 AWG base copper conductor.

• Wear indication with double insulated silicone leads for increased safety.

• Create your own test leads with the adapters shown below.

• Wide temperature range of -58 to 302°F

(-50 to 150°C) with PVC insulation.

*Std. Colors: -0 Black, -2 Red.

See pages 34-35 for more do-it-yourself plugs.

Model# 6729

Build your own safety leads with do-ityourself safety-sheathed 4mm right-angle banana plug.

Material: Contacts: nickel-plated brass;

Insulation: lucel acetal polymer.

Rating: IEC61010 1000V Category III**,

20A, 14 to 131°F (-10 to +55°C).

*Std. Colors: -0 Black, -2 Red.

** When plug is correctly assembled and terminated.

Kelvin Lead Set with

Kelvin Clips

Kelvin Clip Set

Do-It-Yourself 4mm

Stackable Banana Plug

2.3in (58.4mm)

Model# 6721

Build your own safety stacking leads with do-it-yourself safety-sheathed 4mm stackable banana plugs.

Material: Contacts: nickel-plated brass,

Insulation: lucel acetal polymer.

Rating: IEC61010 1000V Category III**,

20A, 14 to 131°F (-10 to +55°C).

*Std. Colors: -0 Black, -2 Red.

** When plug is correctly assembled and terminated.

Do-It-Yourself In-Line Sheathed (4mm) Banana Plug and Jack

3.01in (76.45mm)

6383

1.44in

(36.58mm)

Model# 6303

For 4-wire and 2-wire measurements.

Patented design for high precision rapid testing.

Gold-plated for accuracy.

Easily move from one test point to another for rapid readings.

For use with 4-wire Kelvin meters such as Agilent 34401A, and 3458A.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or current exceeds

8A maximum

Length: 48in (122cm)

Model# 6730

• Gold-plated Kelvin clip jaws allow

4-wire resistive measurements.

• Silicone insulated 3.3ft (1m) test lead.

• Safety sheathed straight DMM plugs for convenient bench use.

• Clips firmly grip test points for low-loss connection.

Rating: 30 Vrms/42.4 Vpk/60 Vdc

2A Max.

Model# 5940

Two gold-plated clips connect to test points for 4-wire resistive measurement.

Clips open to 0.25in (6.35mm) maximum.

Gold-plated plugs and clips.

Rating: For CE compliance and for personal safety, do not hold in hand when voltages exceed

30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A maximum.

Overall Length: 26.5in (67.3cm).

• Safety-rated plugs and jacks for use with any wire from 22 to 18 AWG with flexible insulation.

• Plugs fit most sheathed

DMM jacks and DMM test leads to make up your own banana plug or jack test lead or jumper.

See mating panel jacks

(6387 on page 37).

Material: Banana Plug/Jack: brass; Spring: heat treated beryllium copper; Insulation:

Santoprene

®

.

Model #

6383-*

6383-02

6384-*

6384-02

Type

Plug

Jack

Attaches to wire by crimp or soldering.

Rating: IEC61010 CAT II

300V, 15A, +275°F (+135°C) max.

*Std. Colors: -0 Black,

-2 Red, -02 Black and Red

(2 per pkg).

*Sold in pkgs of 10.

6384 www.pomonaelectronics.com

*see rating message at start of section.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Grabbers and Test Clips

Pomona Electronics’ Grabber

®

Test Clips connect rapidly to component test leads, terminals and IC leads. Specially designed tips slide easliy onto wire-wrap terminals.

And do-it-yourself Grabber test clips can be assembled quickly and easily by the user.

0.06in (1.52mm)

0.016in - 0.02in

(0.4mm - 0.5mm)

0.14in (3.56mm)

Minipincer

SMD Grabber

Page 74

0.14in (3.56mm)

0.06in (1.52mm)

SMD

0.06in (1.52mm)

0.016in - 0.02in

(0.4mm - 0.5mm)

0.016in - 0.02in

(0.4mm - 0.5mm)

Micrograbber

Page 73

0.04in (1.02mm)

0.04in (1.02mm)

0.09in (2.29mm)

0.087in (2.21mm)

0.14in (3.56mm)

Micro

0.12in (3.05mm)

Minigrabber

Page 73

Minigrabber

®

Test Clip with Banana Jack

Model# 4723-*

Banana Jack built into plunger.

Overall Length: 2.54in (64.52mm).

Rating: Maximum voltage for hands free use:

300V. 5A, 216˚F (+102˚C) max.

*Std Colors: -0 Black, -2 Red.

Rotating

Micrograbber

Page 74

1.71in (43.43mm)

1.71in (43.43mm)

Page 79

Page 74

Do-It-Yourself

Minigrabber

®

Test Clips

Model# Max. Wire Dia. Temperature

3925-*

4555-*

0.090in

(2.29mm)

0.144in

(3.55mm)

216°F (102°C)

300°F (149°C)

Overall Length: 2.35in (59.69mm).

Rating: Maximum voltage for hands free use:

300V. 5A, +216˚F (+102˚C) max.*

Std Colors: -0 Black, -2 Red.

Model# Features

4176-02

Kit contains 2 pcs. of 3925, one black/one red

5522

Kit contains 10 pcs. of 3925, one of each color

0.09in (2.29mm)

0.10in (2.54mm)

2.54in (64.52mm)

0.09in (2.29mm)

0.12in (3.05mm)

0.04in (1.02mm)

0.12in (3.05mm)

SMD

0.04in (1.02mm)

0.087in (2.21mm)

0.10in (2.54mm)

0.10in (2.54mm)

0.10in (2.54mm)

0.087in (2.21mm)

2.59in (65.79mm)

6.22in (158.0mm)

Page 73

Page 74

Page 74

Minigrabber

®

Test Clip with Pin Tip Jack

Model# 4826-*

A pin jack is built right into the plunger, allowing this test clip to be attached directly to the end of a pin tip patch cord. It can also be used as an adapter for test probes with

0.080in (2.03mm) tips.

Overall Length: 2.54in (64.52).

Rating: Maximum voltage for hands free use:

300V. 5A, 216˚F (+102˚C) max..

*Std Colors: -0 Black, -2 Red.

Oscilloscope Probe Tip

Adapters

6443

Model# Probe Type

6443

Monolithic Series

6553

Modular Series

• Adapter attaches directly to the oscilloscope probe tip.

• Designed for use with Micro SMD Grabber

Test Clips.

0.09in (2.29mm)

0.09in (2.29mm)

Maxi

6.22in (158.0mm)

0.12in (3.05mm)

0.09in (2.29mm)

Page 74

6553

0.14in (3.56mm)

0.12in (3.05mm)

0.10in (2.54mm)

Page 74

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow, 5 Green, -6 Blue,

-7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

0.10in (2.54mm)

0.016in - 0.02in

(0.4mm - 0.5mm)

0.04in (1.02mm)

73

0.087in (2.21mm)

0.09in (2.29mm)

0.09in (2.29mm)

0.12in (3.05mm)

0.10in (2.54mm)

Grabbers and Test Clips

74

SMD Grabber

®

Test

Clip with 0.025in

(0.635mm) Square Pin

Model#

5360

Features

Sold Individually

Pincer type contact designed for testing 0.05in

(1.25mm) lead pitches such as SOJ, SOIC and

PLCC surface mounted packages.

0.15in (3.81mm) sq. access hole leads to

0.025in (0.635mm) sq. pin.

Overall Length: 1.73in (43.94mm).

Rating: Maximum voltage for hands free use:

150V. 0.5A, 216˚F (+102˚C) max.

*Std Colors: -0 Black, -2 Red.

0.025in (0.635mm) Square Pin Patch Cords available, see page 51.

Do-It-Yourself

Maxigrabber

®

Test Clips

Model#

4225-*

4565-*

Max. Wire Dia.

0.090in (2.29mm)

0.144in (3.66mm)

Fits entry holes as small as 0.25in

(6.35mm) dia.

Overall Length: 6.00in (152.4mm).

Rating: Maximum voltage for

hands free use: 300V, 5A, +216˚F

(+102˚C) max.

*Std Colors: -0 Black, -2 Red.

For hook dimensions see page 73.

Model # 5830-*

Do-It-Yourself SMD

Grabber

®

Test Clips

Model#

5243-*

5520

Max. Wire Dia.

0.090in (2.29mm)

Kit containing 10 pcs of

5243 one of each color

Pincer type contact designed for testing 0.05in

(1.27mm) lead pitches such as SOJ, SOIC and

PLCC surface mounted packages.

Overall Length: 1.71in (43.43mm).

Rating: Maximum voltage for hands free use:

150V. 0.5A, 216˚F (+102˚C) max.

*Std Colors: -0 Black, -2 Red, -4 Yellow,

-5 Green, -9 White.

Do-It-Yourself Flexible

Maxigrabber

®

Test Clips

Rotating pincer type contact for easier access. Standard banana jack and screw for direct wire termination.

Overall Length: 6.22in (157.9mm).

Rating: Maximum voltage for hands

free use: 250V.

*Std Colors: -0 Black, -2 Red.

For pincer dimensions see page 73.

Do-It-Yourself

Micrograbber

®

Test

Clips

Model#

4233-*

Features

-0 Black, -2 Red, -5 Green,

-9 White

Overall Length: 1.71in (43.43mm).

Material: Gold plated brass

Rating: 150V, 3A, +216˚F (+102˚C) max.

For hook dimensions see page 73.

Insulated Minigator

Test Clip to Pin

Tip Jack

Model# 3491-*

Jaw Opening: Alligator clip has

0.187in (4.75mm) max.

Overall Length: 2.05in (52.07mm).

Rating: Maximum voltage for hands

free use: 45V. 5A, 122˚F (+50˚C) max.

*Std Colors: -0 Black, -2 Red.

Micrograbber

®

Test

Clip with 0.025in

(0.635mm) Square Pin

Model#

4521*

Features

Sold individually

*Std Colors: -0 Black, -2 Red.

Do-It-Yourself

Minipincer

®

Test Clip

Model# 5418-*

Pincer type contact.

Overall Length: 2.59in (65.79mm).

Rating: Maximum voltage for hands

free use: 300V. 5A, 176˚F (+80˚C) max.

*Std Colors: -0 Black, -2 Red

For pincer dimensions see page 73.

www.pomonaelectronics.com

Ratings: The components in this section have a hands free rating for use in controlled voltage environments.

However, for CE compliance these products are not intended for hand held use at voltages above 33 Vrms/70 Vdc.

Grabbers and Test Clips

Miniature Alligator Test

Clip with 2mm Banana

Jack

5788-*

Jaw Opening: 0.24in (6.10mm) max. .

Overall Length: 1.57”.

Rating: 45V, +80˚C (+176˚F) max.

*Std. Colors: -0 Black, -2 Red.

Sold in pkgs of 10 per color.

Medium Alligator

Clip Set

Model#

5916A

Features

Set of 2 Clips Black and

Red

Insulated clip with sheathed 0.16in (4mm) receptacle accepts flexible lead sets 5907A,

5908A, 5909A (p. 64).

Jaw Opening: 0.30in (7.62mm) max.

Overall Length: 2.25in (57.15mm).

Rating: Cat I 300V, 5A.

75

Mini-alligator Clip with 2mm Jack

Model#

72924-0

72924-2

Rating: 600V Cat II, 10A.

Color

Black

Red

Alligator Test Clip to Banana Jack, with Insulator,

Solderable

Model# Plating

3289-*

Gold

2240-*

Nickel

6567 Nickel

Features

1 clip and insulator/pkg.

10 clips and insulators/pkg.

10 clips w/o insulators/pkg.

Jaw Opening: Alligator clip has 0.30in

(7.62mm) max.

Overall Length: 2.16in (54.86mm).

Rating: Maximum voltage for hands free use:

150V. 5A, 122˚F (+50˚C) max.

*Std Colors: -0 Black, -2 Red.

Sold unassembled.

Large Alligator Clip Set

Model#

6041B

6042B-*

Features

Set of 2 Clips Black and Red

1 Clip

Insulated clip with sheathed 0.16in (4mm) receptacle accepts flexible lead sets 5907A,

5908A and 5909A (p. 64).

Jaw Opening: 1.0in (25.40mm) max.

Overall Length: 3.5in (88.90mm).

Rating: Conforms to IEC61010-2-031,

Overvoltage Cat III, 1000V, 20A max.

*Std. Colors: -0 Black, -2 Red.

*see rating message at start of section.

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

www.pomonaelectronics.com

76

SMD Multi-Use Test Kit

SMD High Density Circuit Test Kit

SMD/Micro Format Test

Components and circuit boards are getting smaller and smaller. Pomonamakes your job easier by providing clips and leads designed for micro-test, including a variety of 2mm connectors for use in tight spaces. From clips designed for chip pitches down to 0.008" (0.2 mm), to patch cords, and even complete SMD test kits,

Pomona has the connection you need.

Model# 72928

SMD test kit designed for multiple small format test applications.

Kit includes:

1. 72902-0 Micro SMD Grabber Test Clips, (Black)

2. 72902-2 Micro SMD Grabber Test Clips, (Red)

3. 72906-0 Mini SMD Grabber Test Clips, (Black)

4. 72906-2 Mini SMD Grabber Test Clips, (Red)

5. 72905-0 Clip lead for Micro SMD Grabber - 0.8mm female/4 mm female, (Black)

6. 72905-2 Clip lead for Micro SMD Grabber - 0.8mm female/4 mm female, (Red)

7. 5908A Bench-top DMM Modular Test leads

8. 72920-39-0 Multi-stacking 2mm safety sheathed patch cords, PVC, 100mm (39in), (Black)

9. 72920-39-2 Multi-stacking 2mm safety sheathed patch cords, PVC, 100mm (39in), (Red)

10. 72923-0 SMD test probe with sharp, spring mounted tip, 2mm jack, (Black)

11. 72923-2 SMD test probe with sharp, spring mounted tip, 2mm jack, (Red)

12. 72917-0 4mm banana plug to 2mm sheathed banana jack adapter, (Black)

13. 72917-2 4mm banana plug to 2mm sheathed banana jack adapter, (Red)

14. 72924-0 Mini-alligator clip with 2mm jack, (Black)

15. 72924-2 Mini-alligator clip with 2mm jack, (Red)

Large Folding Test Kit Pouch

Model# 72935

SMD test kit designed for probing high density circuits.

Kit includes: 2 DMM leads with 4mm plugs, 2 test probes with spring-loaded tips,

6 micro SMD grabbers (72902), 6 adapter leads 0.8mm female to 0.4mm jack, 2 mini

SMD grabbers with 4mm connectors,

2 holding rods (72903).

www.pomonaelectronics.com

SMD/Micro Format Test

Micro SMD Grabber

Test Clips Kit

Micro SMD Grabber

Test Clips

Holding Rods for

Micro SMD Clips

Model#

72902

Includes

12 clips, 12 leads, 6 rods

Kit of 12 Micro SMD Grabbers in 6 colors.

Grabbers are designed for easy attachment to SMD chips with pitches down to 0.008in

(0.20 mm). Thin yet durable design permits attachment with close spacing in tight areas. Insulated tip minimizes shorting on adjacent pins. Gold plating for low resistance connections. Kit also includes

6 holding rods to reinforce connection positions during side-by-side measurements (order Model# 72903). In addition, kit includes 12 micro leads with 0.8mm female / 0.8mm male connectors.

Clip lead for Micro SMD

Grabber 0.8mm/2mm

Model#

72904-0

72904-2

Color

Black

Red

Clip lead for easy attachment of Micro SMD

Grabber to test leads with 2mm plugs.

0.8mm female/2 mm female.

Model#

72902-0

72902-2

Color

Singles - Black

Singles - Red

Designed for easy attachment to SMD chips with pitches down to 0.008in (0.20 mm).

Thin yet durable design permits attachment with close spacing in tight spaces. Insulated tip minimizes shorting on adjacent pins.

Gold plating for low resistance connections. Holding rods available to reinforce connection positions during side-by-side measurements (order Pomona model number 72903). Order Pomona model number

72905-0 for clip lead for Micro SMD

Grabber – 0.8mm female/4 mm female

(black) or 72905-2 (red) for easy attachment to standard test leads. 72902 includes one black and one red clip. (Black).

Model# 72903

Holding rods reinforce 72902 connection positions during side-by-side measurements. (10/pkg).

Clip lead for Micro SMD

Grabber 0.8mm/4mm

Model#

72905-0

72905-2

Color

Black

Red

Clip lead for easy attachment of Micro SMD

Grabber (Pomona 72902) or Mini SMD

Grabber (Pomona 72906) to standard test leads. 0.8mm female/4 mm female.

Mini SMD Grabber

Test Clips

Model#

72906-0

72906-2

Color

Black

Red

Designed for easy attachment to SMD chips with pitches down to 0.032in (0.80 mm).

Insulated shaft can be bent up to

36 degrees for versatile attachment in awkward locations or close proximity to other clips. Rotating jaws increase versatility in connection and stacking. Thin (3mm) profile allows close placement to adjacent clips.

Compatible with leads with Ø0.8 mm female connectors. Order Pomona model number

72905-0 for clip lead for SMD Mini Grabber

– 0.8mm female/4 mm female (black) or

72905-2 (red) for easy attachment to standard test leads.

77

Mini SMD Grabber

Test Clip with

Lead and

2mm Jack

Model#

72907-20-0

72907-20-2

Color

Black

Red

Mini SMD Grabber Test Clip (Pomona

72906) with 20 inch (50cm) lead and

2mm Jack.

www.pomonaelectronics.com

SMD/Micro Format Test

78

Mini SMD Grabber

Test Clip with

Lead and

4mm Jack

Model#

72929-20-0

72929-20-2

Color

Black

Red

Mini SMD Grabber Test Clip (Pomona

72906) with 20 inch(50cm) lead and 4mm

Jack for easy attachment to DMM leads.

Do-it-yourself 2mm

Stackable Safety

Sheathed Plug

Model#

72925-0

72925-2

Rating: 600V Cat II 10A.

Color

Black

Red

SMD Test Probe with Sharp, Spring

Mounted Tip

Model#

72923-0

72923-2

Color

Black

Red

SMD test probe with sharp, spring mounted tip and 2mm jack. Provides ultra-fine control for probing high density SMD circuits. Very fine 0.03in (0.7mm) diameter stainless steel tip is spring-mounted for controlled pressure. Removable, clear IC insulator cap prevents shorting of adjacent

IC loges. Sheathed 2mm receptacle adapts to 2mm test leads and adapters.

Rating: 600V Cat III, 1A.

Mini-alligator Clip with 2mm Jack

Model#

72924-0

72924-2

Rating: 600V Cat II, 10A.

Color

Black

Red

Multi-stacking 2mm

Safety Sheathed

Patch Cords

Model# Length

72920-20-0

20in (50cm)

Color

Black

72920-20-2

20in (50cm) Red

72920-39-0

39in (100cm) Black

72920-39-2

39in (100cm) Red

Multi-stacking 2mm safety sheathed male/male patch cords, PVC.

Rating: 600V Cat II, 10A Max.

2mm Safety Sheathed

Patch Cords

Model# Length Color

72919-20-0

20in (50cm) Black

72919-20-2

20in (50cm) Red

72919-39-0 39in (100cm) Black

72919-39-2 39in (100cm) Red

2mm safety sheathed male/male patch cords, PVC.

2mm/4mm Male-male Test Leads

Model#

72936-0

72936-2

Length Color

3.9in (99.1mm) Black

3.9in (99.1mm) Red

www.pomonaelectronics.com

SMD/Micro Format Test

4mm Safety Banana

Jack to 2mm Banana

Plug Adapter

2mm Sheathed Jack to

2mm Unsheathed

Plug Adapter

2mm Safety Sheathed

Jacks

Model#

72914-02

72914-0

72914-2

Color

One Black and One Red

Black

Red

Accepts 4mm safety-sheathed banana plugs.

10/pkg.

Rating: 33 Vac/70 Vdc, 36A

Model#

72915-0

72915-2

Color

Black

Red

Accepts 2mm safety-sheathed banana plugs.

10/pkg.

Rating: 33 Vac/70 Vdc, 10A.

Model#

72916-0

72916-2

Color

Black

Red

Accepts 2mm and 4mm safety-sheathed banana plugs. 10/pkg.

Rating: 33 Vac/70 Vdc, 10A.

Model#

72921-0

72921-2

Color

Black

Red

2mm safety sheathed jack with 1.9mm wire wrap connecting pin.

Materials: Contacts: Nickel plated brass.

Insulation: Polyamide.

Rating: 600V Cat II, 10A.

Micro SMD

Grabber

®

Test

Clip for 0.05 to 0.01in (1.25 to 0.2 mm)

Lead Pitch

Model# Profile

Height

6442

0.28in

(7mm) low

6351

6352

0.55in

14mm

0.55in

14mm

6353

0.55in

14mm

Lead Pitch

0.05 -0.01in

(1.25 -0.3mm)

0.03 -0.01in

(0.85 -0.2mm)

0.05 -0.01in

(1.25 -0.3mm)

0.05 -0.01in

(1.25 -0.3mm)

Tip Qty Colors

Long 10

Long 10

Long 10

Short 10

10

2

2

2

• Use with PQFP, SOIC, TSOP and SSOP packages with lead pitches down to

0.01 to 0.02in (0.2 to 0.5 mm).

• Thin body allows an unlimited number of clips to be stacked side by side.

• Maximum frequency is 100MHz.

Rating: For CE compliance and personal safety, do not hold in hand when voltages exceed 30 Vrms/42.4 Vpk/60 Vdc or current exceeds 8A mximum.

Maximum voltage for hands free use:

70 Vrms Max.

Supplied with female to male flying leads.

4mm Banana Jack to

2mm Banana Jack

Adapter

4mm Banana Plug to

2mm Sheathed Banana

Jack Adapter

Model#

72917-0

72917-2

Color

Black

Red

Accepts 2mm safety-sheathed banana plugs.

10/pkg.

Rating: 33 Vac/70 Vdc, 10A.

Rotating Micrograbber

®

Test Clip with Two 0.025in

(0.635mm) Square Pins

Model#

5790-*

Features

Sold individually

Use when testing IC leads at 0.05in

(1.25mm) pitch or in other tight situations. Pincers rotate for ease of access.

Overall Length: 2.12in (53.85mm)

Rating: 33 Vrms/70 Vdc

*Std Colors: -0 Black, -2 Red.

Micro SMD Grabber

®

Test

Clip for 0.05 to 0.02in

(1.25 to 0.5 mm)

Lead Pitch

Model# 6490-*

• Use with PQFP & SOIC packages with 0.02in (0.5mm) lead pitch or greater.

• Pincers and 0.03in (0.76mm) pin plug are directly connected; no sliding parts.

• Pincers are stationary. Housing moves to close tips together.

• Device under test must be inactive when connecting pincers.

Rating: For CE compliance and personal safety, do not hold in hand when voltages exceed 30 Vrms/

42.4 Vpk/60 Vdc or currrent exceeds

8A maximum.

Maximum voltage for hands free use:

70 Vrms Max.

*Std Colors: -0 Black, -2 Red.

2mm Safety Sheathed

Jack with Solder Tab

Model#

72922-0

72922-2

Color

Black

Red

Materials: Contacts: Nickel plated brass,

Insulation: Polyamide.

Rating: 600V Cat II, 10A.

79 www.pomonaelectronics.com

80

Oscilloscope Probes and

Accessories

Pomona’s oscilloscope probes give you the full range you need.

Designed, rated, and specified to match the bandwidth of your instrument, they provide you with full voltage read-out over the entire rated bandwidth of each probe.

Replacement Passive

Oscilloscope Probes

These general purpose monolithic passive voltage probes feature high performance for greater test flexibility. Complete accessory kit included.

See selection guide below.

Monolithic Passive Oscilloscope Probes

Model# Probe

Ratio

4550B

5795A

5800A

5803A

5806A

1:1

10:1

10:1

1:1

10:1

1:1

10:1

5809A

5812A

5827A

6049A

6069A

6101A

6102A

6265

10:1

10:1

100: 1

10:1

10:1

10:1

10:1

10:1

6266

1:1

10:1

SP150B

1:1

10:1

Replacement Accessory

Kit: 6267

Kit includes:

Retractable Hook Tip

BNC Adapter

IC Adapter

Insulating Tip

Trimmer Tool

6in (0.15m) Ground Lead with Alligator Clip

Maximum Input

Voltage CAT I

1

300

2

300

300

300

2

300

300

300

300

300

300

2

300

300

300

300

300

300

2

300

300

2

300

System Bandwidth

MHz (-3 dB)

Up to 15

3

100

100

Up to 30

200

Up to 20

3

200

300

300

200

150

250

150

250

60

Up to 20

60

Up to 15

150

3

3

3

System

Risetime (ns)

< 23.33

3

< 3.50

< 3.50

< 17.5

< 5.83

< 23.33

< 3.33

Oscilloscope Probe Tip Adapter Model# 6443

3

3

< 11.66

3

< 1.75

< 17.5

3

< 1.75

< 1.17

< 1.17

< 1.75

< 2.33

< 1.40

< 2.33

< 1.40

< 5.83

Probe Input

Resistance (M

)

1

10

10

1

10

1

10

10

10

10

10

10

10

10

10

1

10

1

10

Probe Input

Capacitance (pF)

< 64 + O-Scope

< 10.5

< 9.5

< 57 + O-Scope

< 10

< 77 + O-Scope

< 11.5

< 17

< 17

< 5.5

< 10.5

< 10

< 10.5

< 10

< 10.5

< 65 + O-Scope

< 11

< 50+ O-Scope

< 15

Compensation

5

Range (pF)

NA

10 - 60

10 - 60

NA

10 - 60

NA

10 - 60

10 – 60

10 -60

15 - 50

10 - 30

10 -30

10 - 30

10 - 30

10 - 60

NA

10 - 60

NA

10 - 60

Readout

Actuator

No

No

No

No

No

No

Yes

Yes

No

No

Yes

No

No

No

No

4

Cable

Length

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

6.6ft (2.0m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

Pomona adapters with

0.025in (0.635mm) pins

5360

5790

6353

6490

All “IC” test clips

6351

6352

6442

This adapter provides an easy, fast, and reliable way to connect your oscilloscope probe to IC test adapters, test clips and grabbers using 0.025in (0.635mm) connection pins.

1 Rating: All probes are rated 300V (DC + Peak AC), CAT I, per IEC1010-031. Maximum voltage allowed on the LO connection including shell and housing must not exceed 30V.

2 Maximum input voltages are dependent on the oscilloscope input characteristics; take the lesser of the two specifications.

3 Dependent upon oscilloscope input characteristics.

4 Any oscilloscope that uses the Tektronix

®

style range actuator.

5 For oscilloscopes with 1 M Ω input resistance.

www.pomonaelectronics.com

Oscilloscope Probes and Accessories

Modular Passive Oscilloscope Probes

Featuring a new, compact, ergonomically designed probe handle, these modular general purpose passive voltage probes are ideal for use with a wide variety of oscilloscopes. They also feature a spring-loaded, pogo-pin replaceable tip. The fine tip probes are perfectly suited for probing high-density chip leads with less than

0.060in (1.52mm) spacing. Modular in design, the probe handle is capable of receiving a variety of spring-loaded and fixed tips, providing greater testing versatility. An affordable, versatile probe for many uses.

Probe sets includes the probe, BNC adapter, ground blade, 8.7in (22cm) ground lead,

IC tip adapters with 0.8mm to 1.27mm pitch, insulating tip, protection cap, solid tip, spring tip, sprung hook, trimmer tool, 2 footer positioner, and complete set of instructions and specifications.

81

6500

Model#

6491

6493

6494

6495

6496

6497

6498

6499

6500

Probe

Ratio

1:1

10:1

10:1

10:1

10:1

10:1

100:1

1:1

10:1

1:1

10:1

Replacement Accessory

Kit: 73040

Kit includes:

Retractable Hook Tip

BNC Adapter

Insulating Tip

Trimmer Tool

8.7in (22cm) Ground Lead with Alligator Clip

1 ea. Rigid Probe Tip

1 ea. Spring Probe Tip

55 V

300 V

300 V

300 V

300 V

300 V

1000 V

55 V

300 V

55 V

300 V

Maximum Input

Voltage CAT II

1

Recommended

Scope Bandwidth

MHz

60

60

60

100

350

350

500

60

100

Bandwidth MHz

(-3dB)

(Probe) (System)

30

150

-

-

150

250

-

-

-

350

-

-

20

150

30

250

350

400

-

-

-

-

System

Risetime

(ns)

< 12

< 2.4

< 2.4

< 1.4

< 1

< 1

< 0.9

< 18

< 2.4

< 12

< 1.4

Probe Input

Resistance (M

)

1

10

10

10

10

10

50

1

10

1

10

Probe Input

Capacitance (pF)

< 39.5

< 12.5

< 12.5

< 12.5

< 14.5

< 14.5

< 7.5

< 78

< 13

< 80

< 13

Oscilloscope Probe Tip Adapter Model# 6553

Compensation

Range (pF)

Readout

Actuator

2

-

15 - 40

15 - 40

10 - 35

10 - 35

10 - 35

10 - 50

-

15 - 40

NA

10 - 35

-

No

Yes

No

No

Yes

No

No

No

Cable Length

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

4ft (1.2m)

6.6ft (2m)

4ft (1.2m)

4ft (1.2m)

Pomona adapters with

0.025in (0.635mm) pins

5360

5790

6351

6352

6353

6490

6442

All “IC” test clips

This adapter provides an easy, fast, and reliable way to connect your oscilloscope probe to IC test adapters, test clips and grabbers using 0.025in (0.635mm) connection pins.

1 Rating: Per IEC61010-031. Maximum voltage allowed on the low or ground connection including shell and housing must not exceed 30V.

2 Any oscilloscope that uses the Tektronix

®

style range actuator

www.pomonaelectronics.com

Oscilloscope Probes and Accessories

82

Microline Passive Oscilloscope Probes

82

500 MHz X10 Passive Voltage

Probe 4ft (1.2m) cable,

500V peak.

The perfect solution for accessing hard-to-reach test points, particularly fine pitch

IC leads. The Microline Probe features a 500 MHz X10 passive voltage probe compactly designed for on-the-go field service or in the lab.

Pomona adapters with

0.025in (0.635mm) pins

5360

5790

6351

6352

6353

6490

6442

All “IC” test clips

Replacement Accessory

Kit: 73040

Kit includes:

Retractable Hook Tip

BNC Adapter

Insulating Tip

Trimmer Tool

8.7in (22cm) Ground Lead with Alligator Clip

1 ea. Rigid Probe Tip

1 ea. Spring Probe Tip

Oscilloscope Probe Tip Adapter Model# 6553

Tips can be replaced with Pomona

0.60in (1.52mm) probe tips model number 6475, see page 66.

This adapter provides an easy, fast, and reliable way to connect your oscilloscope probe to

IC test adapters, test clips and grabbers using 0.025in (0.635mm) connection pins.

Model#

6551

6554

Probe

Ratio

10: 1

10: 1

Maximum Input

Voltage CAT I

300 V

300 V

1

Recommended

Scope Bandwidth

MHz

500

500

System

Bandwidth MHz

(-3dB)

500

500

System

Risetime

(ns)

< 0.7

< 0.7

Probe Input

Resistance (M

)

10

10

Probe Input

Capacitance (pF)

1 Rating: Per IEC61010-031. Maximum voltage allowed on the low or ground connection including shell and housing must not exceed 30V.

2 Any oscilloscope that uses the Tektronix

®

style range actuator

< 11

< 11

Compensation

Range (pF)

Readout

Actuator

2

Cable Length

10 - 20

10 - 20

Yes

No

4ft (1.2m)

4ft (1.2m)

Insulated Oscilloscope Probes for Portable Applications

Features

• With a CAT II, 600 V (CAT III, 300 V) rating, these probes are perfect for use with portable oscilloscopes.

• And with a 500 MHz bandwidth, these probes provide plenty of headroom for those high frequency measurements.

• Fully Insulated.

• Meets IEC 61010-031.

• Ergonomic Design with Comfort Grip.

Accessories Included

• Push-On Hook Clip.

• Push-On Reference Contact.

• Reference lead with alligator clip for the connection to the 0.2 mm safety socket in the handle.

Model#

72940-*

72941 (set)

72942

Probe Ratio

10: 1

10: 1

See page 60

1 Derated with frequency.

2 For oscilloscopes with 1M

Ω input resistance.

*Standard Colors: -2 Red, -8 Gray

Maximum Input

Voltage CAT II

1

600 V

600 V

www.pomonaelectronics.com

Bandwidth

(MHz)

500

500

Input Resistance

(M

)

10

10

Input Capacitance

(pF)

13

13

Approximate

Risetime (ns)

1

1

Compensation

Range (pF)

10 - 30

10 - 30

Cable Length

4ft (1.2m)

4ft (1.2m)

Whether setting up your own home theater or looking for connectors for that next broadcast event, Pomona audio/video/broadcast accessories get you connected reliably. From F connectors to phono jacks, look to Pomona for parts you can depend on.

High Definition 75 BNC Connectors

1.18in

(30.0mm)

6702A

1.18in

(30.0mm)

XLR Straight Cable Connectors — General Duty

5125A

6703A

5126A

1.18in

(30.0mm)

6704A

Model# For Cable

6702A

RG59B/U, 20 AWG, Belden 1505A

6703A

6704A

RG6B/U, 18 AWG, Belden 1694A

RG59B/U, 23 AWG

Precision matched to Belden cable for digital and analog SDI/HDTV signals.

Performance: 3 GHz with VSWR of 1.15

Impedance: 75 Ω.

BNC: Shell: precision machined tarnish resistant black nickel-plated brass; Center Contact: male: gold-plated brass (20 micro inches).

Dielectric: PTFE.

Model# Type Pins Shell Contacts

5125A

5126A

6850

6851

7283

7284

(f)

(m)

(f)

(m)

(m)

(f)

5

5

3

3

3

3

Nickel

Nickel

Black Nickel

Black Nickel

Nickel

Nickel

Silver

Silver

Gold

Gold

Silver

Silver

Streamlined profile with compact shell. Time saving assembly (3 parts).

No set screws. Solderable.

Lbs of

Pull

45

45

45

45

45

45

XLR Plug to XLR

Jack Low Noise

Cable Assembly

XLR/RCA Adapters

7269

7270

7271

7272

Model#

6869-180

6869-300

Length

4.6 m (15 ft)

7.6 m (25 ft)

Low noise audio cable includes a 3-pin XLR male connector and a 3 contact XLR female connector.

Pull: 45.35 kg (100 lbs).

Material: Shell: tarnish resistant black nickel-plated brass; Center Contact: gold-plated brass.

XLR (F) 3-Pin Square

Flanged Panel

Receptacle

7115

3-pin XLR square panel mount female receptacle with sturdy all metal one piece design.

Housing is die-cast zinc alloy with tarnish resistant black nickel plating and gold-plated contacts. Solder cup terminations. Front mountable.

Model#

7269

7270

7271

7272

Type

XLR (f)/RCA (m)

XLR (m)/RCA (m)

XLR (f)/RCA (f)

XLR (m) /RCA (f)

Audio adapters offer 3 contact XLR to RCA

(phono) conversion. Body is die cast zinc alloy with tarnish resistant nickel plating.

Contacts are nickel-plated brass.

XLR Female Panel

Receptacle, 3-Pin

5113A

3-pin XLR rectangular panel mount receptacle with sturdy all metal one piece design. Housing is die-cast zinc alloy with tarnish resistant nickel plating. Solder cup terminations. Front mountable.

www.pomonaelectronics.com

83

Audio/Video/Broadcast

84

XLR Adapters

6856

6857

Model#

6856

6857

Type

XLR (F)/XLR (F)

XLR (M)/XLR (M)

Body is die cast zinc alloy with tarnish resistant nickel plating. Male pin contacts are nickel-plated brass. Female contacts are nickel-plated beryllium copper.

XLR Male Panel

Receptacle, 3-Pin

5117A

3-pin XLR rectangular panel mount male receptacle with sturdy all metal one piece design. Housing is die-cast zinc alloy with tarnish resistant nickel plating. Solder cup terminations. Front mountable.

XLR to 1/4 in Adapters

6863

Model# Type

6863

XLR (F) / 1/4 in Plug (stereo)

6864

XLR (M)/1/4 in Plug (stereo)

Adapters offers 3 contact XLR to 1/4 inch conversion. Sleek light weight design. XLR body is die cast zinc alloy with tarnish resistant nickel-plating. 1/4 inch plugs are nickel-plated machined brass. XLR contacts are nickel-plated brass.

XLR Female Panel

Receptacle, 5-Pin

6864

6854

5-pin XLR rectangular panel mount receptacle with sturdy all metal one piece design.

Housing is die-cast zinc alloy with tarnish resistant nickel plating. Solder cup terminations.

Front mountable.

XLR (M) Panel

Receptacle, 5-Pin

6855

5-pin XLR rectangular panel mount male receptacle with sturdy all metal one piece design.

Housing is die-cast zinc alloy with tarnish resistant nickel plating. Solder cup terminations.

Front mountable.

BNC Female to Phono

(RCA) Male

1.28in

(32.5mm)

Model# 5319

Rating: Maximum voltage for

hands free use: 500 Vrms, 216˚F

(+102˚C) max.

BNC: Center Contact: gold-plated.

XLR Female, 4-Pin,

Rectangular Flanged

Panel Mount

7107

4-pin XLR rectangular panel mount receptacle with sturdy all metal one piece design. Housing is die-cast zinc alloy with tarnish resistant nickel plating. Solder cup terminations. Front mountable.

BNC Male to Phono Jack

1.40in

(35.56mm)

Model# 4054

Rating: Maximum voltage for

hands free use: 500 Vrms, +257˚F

(+125˚C) max.

www.pomonaelectronics.com

Ratings: The components in this section have a hands free rating for use in controlled voltage environments.

However, for CE compliance these products are not intended for hand held use at voltages above 33 Vrms/70 Vdc.

Audio/Video/Broadcast

XLR Female 3-Pin,

Rectangular Flanged

Panel Mount

7108

3-pin XLR rectangular panel mount receptacle with sturdy all metal one piece design. Housing is die-cast zinc alloy with tarnish resistant black nickel plating. Solder cup terminations. Front mountable.

BNC Female to 1/4in

(6.35mm) Phone Plug

2.46in (62.48mm)

Model# 1297

0.25in

(6.35mm)

Rating: Maximum voltage for

hands free use: 500 Vrms, +257˚F

(+125˚C) max.

Convert 2 conductor audio jacks to BNC.

0.25in (6.35mm)

85

1/4 in, PC Board Mount

Phone Jacks

7158

7159

7160

Model# Type

7158

7159

PC board mount,

3-conductor

PC board mount,

2-conductor

7160

PC board mount,

3-conductor

PC board mounts for connection with standard commercial phone plugs. Solderable with nickel silver contacts.

BNC Female to Two

Conductor, 0.14in (3.5mm)

Dia. Mini Phone Plug

1.92in (58.77mm)

Model# 3837

Rating: Maximum voltage for

hands free use: 500 Vrms, +257˚F

(+125˚C) max.

Convert 2 conductor audio jacks to BNC.

0.141in

(3.58mm)

1/4 in, Panel Mount

Phone Jacks

7156 7157

Model# Type

7156

2-conductor

7157

3-conductor

Designed for insulated panel mount with low internal contact resistance.

Body is diecast zinc alloy with tarnish resistant nickel plating.

Hardware includes one copper alloy nickel-plated hex nut, and one steel nickel-plated washer.

Right-Angle and Straight

1/4 in. Standard Phone Plugs

6874

Model#

6873

6874

7142

7150

7151

7152

Description

1/4 in. Phone Plug, 2 Pole

1/4 in. Phone Plug, 3 Pole

Straight 3-Conductor Balanced 1/4 in. Std. Phone Plug (Stereo)

Shielded 2-Conductor 1/4 in. Phone Plug, Long Handle

Right-Angle 2-Conductor 1/4 in. Plug (Mono)

Shielded 3-Conductor Balanced 1/4 in. Phone Plug (Stereo)

Shell

Black Nickel

Black Nickel

Nickel

Nickel

Nickel

Nickel

Contacts Lbs of Pull

Gold 45

Gold

Nickel

Nickel

Nickel

Nickel

45

45

45

45

45

7152

F Adapters and PCB

Mount Connector

1.10in

(28.0mm)

6801

0.84in

(21.4mm)

6802

1.031in

(26.20mm)

6803

Model# Description

6801

F (M/F) In-Line adapter

6802

F (F/F) Bulkhead adapter

6803

F (F) PCB mount connector

Material: These 75 Ω connectors are designed for fast installation with no crimping.

Connectors are precision machined brass with nickel plating and gold plated center contacts.

*see rating message at start of section.

www.pomonaelectronics.com

Audio/Video/Broadcast

86

BNC Male to 1/4in (6.35mm)

Two Conductor Phone Jack

2.86in (72.64mm)

Model# 4043

Rating: Maximum voltage for

hands free use: 500 Vrms, +257˚F

(+125˚C) max.

Convert 2 conductor phone plugs to BNC.

1/4 in Plug/RCA Jack

6878

Two pole mono-to-mono adapters in easy-to-use configurations. Contacts are nickel-plated brass.

F Female to

Female

Bulkhead

Receptacle

0.80in

(20.4mm)

Model# 6706

In line, with nut and washer

Material: Machined, nickel-plated brass.

RCA (phono) Jack

6880

Sleek silver and gold compact design.

Handles up to 6.0 mm (0.24 in) O.D. cable. Body is made of die cast zinc alloy with tarnish resistant nickel-plating.

Contacts are gold-plated brass.

F Within Series Adapters

1.0in

(25.4mm)

0.92in

(23.3mm)

Model# Type

6712

F (m/f) Right angle

6713

F (m/f) In line,

Push-on

Material: Machined, nickel-plated brass

RCA (phono) Plug

6712 6713

6881

Sleek silver and gold compact design.

Handles up to 6.0 mm (0.24 in) O.D. cable. Body is made of die cast zinc alloy with tarnish resistant nickel-plating.

Contacts are gold-plated brass.

Phono Jack to Double

Stacking Banana Plug

1.82in

(46.23mm)

1.13in

(28.70mm)

Model# 1442

Rating: Maximum voltage for

hands free use: 500 Vdc, +122˚F

(+50˚C) max.

1.13in

(28.70mm)

Permits phono plug to be used with equipment having standard banana jacks or binding posts.

RCA (phono) Adapter

(F/M/F)

6882

One plug and two jack configuration with compact design. Contacts are gold-plated brass for low contact resistance.

www.pomonaelectronics.com

*see rating message at start of section.

Audio/Video/Broadcast

1/4in (6.35mm) Phone

Jack to Double Stacking

Banana Plug

2.80in (71.12mm)

0.75in

(19.05mm)

1.22in

(30.99mm)

Model# 4044

Rating: Maximum voltage for

hands free use: 500 Vrms, +122˚F

(+50˚C) max.

2 conductor 0.25in (6.35mm) dia. phone jack.

1/4 in Jack/RCA Plug

6879

Two pole mono-to-mono adapters in easy-to-use configurations. Contacts are nickel-plated brass.

87

*see rating message at start of section.

www.pomonaelectronics.com

88

Automotive

Offering a variety of test accessories designed specifically for the automotive environment, Pomona simplifies automotive diagnostics.

Pomona automotive accessories give you access to wiring or cables in congested engine compartments, under- dash wiring harnesses, and other generally hard-to-reach places.

Insulation

Piercing

Clip Sets

Model#

6405

6413

Features

Attach to test leads

Attach to 0.080in

(2.03mm) Probe tip

Colors

Set of red/black

Set of red/black

• Double V block centers wire.

• 6405, 6413: set of 2, (red and black jacks).

• Bright yellow for easy location.

• Attach to test leads.

Rigid Backprobe Pin

3.95in (100.3mm)

Model# 6262-02

• Sharp point to pierce insulation or weather boot up to 2in (50.8mm) deep.

• For low voltage use < 30V.

• Set of 2 (red + black).

• Fits comfort-grip style and modular probes 6232A and 6479.

6405

Insulation Piercing

Maxigrabber

®

Test Clip Set

Model# 5913

• Insulated probe for hard to reach test points.

• Set of 2, red and black.

Test Connector Adapter Set

Model# 6481

• Full set of pin and socket adapters

• 18 piece set includes one black and red pin and socket of each size.

• Contact sizes: 0.03in (0.75mm),

0.04in (1mm), 0.06in (1.5mm),

0.10in (2.5mm).

• Includes Silicone insulated 4ft

(1.22m) leads to fit most DMMs from Fluke, Amprobe, Greenlee and others.

Test Lead Rack

Basic Backprobe Pins

Model # 4408M

• Magnetic, attach to tool box or other steel cabinet.

• Neat storage for leads.

• Easy access.

Model# 6411

• Make connection to terminals inside connectors up to 1in

(25.40mm) deep.

• For low voltage use < 30V.

• Pkg of 10.

Coaxial Lead Set Lead Set

Model # 6534

• Complete set of coaxial leads.

• Molded strain relief.

• Seven piece set from 1 to 10ft

(0.3 to 3.05m).

• Standard BNC connectors fit oscilloscopes and other instruments.

www.pomonaelectronics.com

IC Test Clips and Adapters

Innovative solutions. Pomona Electronics’ IC Test Clips – designed for your chip. Uniquely designed for testing surface mount devices – easily, securely and successfully. Low-profile fine-pitch chips, densely populated boards, or vertical boards, POMONA test clips connect you with confidence.

How to Measure or

Calculate the Critical

Dimension for Your

QFP Test Clip

Test Clip Selection Made Easy

To select the Pomona IC Test Clip specifically designed for your chip, find the table for your chip type and follow the selection procedure outlined in this section.

89

Measure Critical Dimension with calipers parallel to the plane of the PCB

Critical Dimension

T

D

Critical Dim. C = D - 2 (L - T)

L

PLCC

To find your PLCC Quad Clip

®

test adapter, see PLCC table on page

89 and reference the following characteristics of your target chip:

1. Number Of Leads

2. Body Size

DIP

To find your DIP test clip, see DIP table on page 90 and reference the following characteristics of your target chip:

1. Number Of Leads

2. Test Clip Contact Style

(see Fig. 1 & 2, page 90)

SOIC/SOJ

To find your SOIC Clip

®

test clip, see SOIC/SOJ table on page 90 and reference the following characteristics of your target chip:

1. Number Of Leads

2. Confirm Body Width Compatibility

3. For Lower and Top Test Clip Width

(see Fig. 1, 2 & 3, page 90)

Pomona offers a wide variety of Micro-SMD Grabber

®

Test Clips for use in testing fine pitch PQFP devices.

See SMD/Micro Format Test section for complete selection.

PLCC Test Clips

Single

Testing

Adjacent

Testing

X Min.

0.120in

(3.1mm)

0.325

(8.3mm)

Y Min.

0.110in

(2.8mm)

0.285

(7.2mm)

Y

X

Pomona’s low-cost Quad

Clip

®

test clips quickly lock onto J-leaded PLCCs, providing easy access for testing surface-mounted devices.

PLCC test clips attach to

PLCC chips with a sliding cam that clamps onto the chip body. Access to chip leads is provided by

0.025in (0.635mm) pins at

0.100in (2.54mm) spacing.

Pomona offers a Quad Clip

® test clip to fit all currently available PLCC chip sizes.

Lead Pitch: 0.050in

(1.27mm)

Model# No.

Leads

5279

5280

5733

5281

5312

5401

5402

20

28

32

Lead

Pattern

5 X 5

7 X 7

7 X 9

44 11 X 11

52 13 X 13

68 17 X 17

84 21 X 21

Body Size

0.36in X 0.36in

(9.14mm x 9.14mm)

0.46in X 0.46in

(11.68mm x 11.68mm)

0.46in X 0.56in

(11.68mm x 14.22mm)

0.63in X 0.63in

(16.00mm x 16.00mm)

0.75in X 0.75in

(19.05mm x 19.05mm)

0.95in X 0.95in

(24.13mm x 24.13mm)

1.15in X 1.15in

(29.21mm x 29.21mm)

5515A

20-84

– –

Typical Applications

Intel 85C220

Intel 5C60, 85C224, Philips

8XC751, Raytheon TMC1173

AMD 29F040, Xicor

X28TC256, Cypress CY7B991

AMD MACH110, 80C88,

Seimens SAB-C501

Intel 87C196, 87C196,

Motorola 68008

Intel 80C188, AMD

MACH220, Hitachi H8/330

AMD MACH130, Altera

EPF8452, Cirrus Logic

CLi6005

PLCC Clip Kit containing 1 of each size PLCC Clip

www.pomonaelectronics.com

IC Test Clips and Adapters

90

DIP Test Clips

Model# No.

Leads

5108

5208

5014

5114

3916A

5220

8

8

14

14

16

20

Chip Width

0.3in (7.62mm)

0.3in (7.62mm)

0.3in (7.62mm)

0.3in (7.62mm)

0.3in (7.62mm)

0.3in (7.62mm)

Contact

Style

Closed

Open

Closed

Open

Closed

Open

Contact

Material

Typical Applications

Gold Plate

Gold Plate

Nickel Silver

Nickel Silver

Nickel Silver Analog Devices AD7715

Gold Plate –

Fig.

Pomona DIP Test Clips provide fast, reliable and secure connections to socketed and through-hole

DIP chips. Available in two styles, DIP Test Clips give you the option of full coverage of clip contacts for maximum durability or open contacts at the board level for easier access to chip leads.

Fig.1: Spring-actuated clip features gold-plated beryllium copper or spring-tempered nickel silver pins to assure positive contact in a firm wiping action for hands-free testing.

Fig. 2: Clip features same construction as Figure 1 except for an opening on the outside of the contact housing to permit probing while the clip is attached to the DIP.

1

2

1

2

1

2

Fig. 1

Fig. 2

SOIC/SOJ Test Clips

SOIC Clip

®

test clips feature a narrow-profile design that makes testing SOIC and SOJ chips on densely-populated boards easier and safer.

A

A

A

B

Fig. 1

B

Fig. 2

B

Fig. 3

Fig. 1:

Spring-loaded SOIC

Clip

®

attaches to target chip and holds on with spring pressure against the chip body. Contacts on top of the clip are

0.025in (0.635mm) pins at 0.10in

(2.54mm) spacing.

Designed to attach to surface-mounted chips with either gull wing or “J” leads.

Fig. 2:

This 14-pin clip features a slider that presses the contact housings against the chip and provides a more secure connection on surface mounted chips with gull wing or “J” leads.

Compact design is ideal for testing on densely-populated boards.

Fig. 3:

New 32-, 40- and

44-pin SOIC/SOJ test clip is a new design of the spring-loaded clip that features double-row .025 wire wrap pins for easy connection to ribbon cable.

This clip will fit all

SOIC/SOJ chips between 0.30in

(7.62mm) and

0.60in (15.24mm) width.

Lead Pitch: 0.050in (1.27mm).

Model# No.

Leads

5250

8

5251

5252

5253

5254

5437

6107

6108

6109

5514

14

16

20

24

28

32

40

44

Lower

Width (A)

0.26in

(6.60mm)

0.410

(10.41mm)

0.460

(11.68mm)

0.560

(14.22mm)

0.660

(16.76mm)

0.760

(19.30mm)

0.870

(22.10mm)

1.070

(27.18mm)

1.170

(29.72mm)

Body Widths

0.15in to 0.3in

(3.81mm to 7.62mm)

0.15in to 0.3in

(3.81mm to 7.62mm)

0.15in to 0.3in

(3.81mm to 7.62mm)

0.15in to 0.3in

(3.81mm to 7.62mm)

0.15in to 0.3in

(3.81mm to 7.62mm)

0.15in to 0.3in

(3.81mm to 7.62mm)

0.30in to 0.60in

(7.62mm to 15.24mm)

0.30in to 0.60in

(7.62mm to 15.24mm)

0.30in to 0.60in

(7.62mm to 15.24mm)

Top Width

(B)

0.430in

(10.92mm)

0.755in

(19.18mm)

0.830in

(21.08mm)

1.030in

(26.16mm)

1.230in

(31.24mm)

1.430in

(36.32mm)

0.870in

(22.10mm)

1.070in

(27.18mm)

1.170in

(29.72mm)

Typical Applications

Analog Devices AD834JR,

Triquint TQ9122N

Motorola HCT08A, Philips

74HC125

Maxim MAX791, Microlinear

ML6509, AMD 26LS31

Linear Tech. LT1130, Maxim

MX7226, Motorola HCT373A

Altera EP610APC, Linear Tech.

LT1130, Motorola MC22V10S

Texas Inst. SN74F32D, Altera

EPM5032, Raytheon TMC1171

Toshiba TMPN3120, Hitachi

HM628128, NEC D431000AGW

SOIC Clip

®

Test Kit contains 1 each 8 - 28 pin clips

Fig.

1

1

1

1

1

1

3

3

3

www.pomonaelectronics.com

Static Control Products

Working with static sensitive devices? Pomona enables you to work with confidence when using our static control accessories. Whether you choose to purchase our selection of grounding systems or build your own ESD set-up, Pomona gives you a variety of individual accessories. Our accessories also make a perfect addition to our Test Companion Kits.

Large Service Kit

Model# 6088

Provides a larger working area than

Model 6087. This kit provides a staticsafe 24in x 24in (609.6mm x 609.6mm) laminated red vinyl mat. The mat includes a 10mm snap socket and two

8in x 11in (203.2mm x 279.4mm) pockets. Carry those often used tools right with the mat. A common point ground connector with two Banana Plug

Jacks and a 15ft (4.5m) ground lead.

An adjustable elastic wrist strap and a resistive coil cord complete the kit.

Folds down to fit into your tool box.

Adjustable Elastic Wrist

Strap Kit

Model# 6082

A complete wrist strap kit features adjustable elastic wrist strap. Also included:

Resistive Coil Cord (1M Ω resistor molded in) extendable to 6ft (1.8m) with a

Straight Banana Plug and Alligator Clip.

Field Service Kit

Model# 6087

A complete and durable service kit for static sensitive work. Features a staticsafe 18in x 22in (460mm x 558.8mm) laminated red vinyl mat. The kit includes a mat with two 0.39in (10mm) snap sockets, common point ground connector with two Banana Plug Jacks and a

15ft (4.5m) ground lead, an adjustable elastic wrist strap and a resistive coil cord. Folds down to fit into your tool kit.

Wrist Strap Tester

Model# 6088 and 6087

Mat Color: Red.

Thickness: 0.018in (0.46mm).

Surface Resistivity: 108 to 109 Ω / Sq.

Volume Resistivity: 109

Ω cm.

Static Decay: 0.01sec 5000V to 0V

12%RH.

Adjustable Metal Wrist

Strap Kit

Model# 6084

Complete wrist strap kit features the adjustable metal wrist strap. Also included: Resistive Coil Cord (1M Ω resistor molded in) extendable to 6ft (1.8m) with a Straight Banana Plug and Alligator Clip.

Wrist Straps

Model# 6086

Test any wrist strap connected to utility ground with a simple touch. The tester has two Banana Plug Sockets for Wrist

Strap cord attachments. Once connected, the user simply touches the unit and a green light and audible sound indicate a proper ground. (Audible indicator has selectable on or off).

The tester can be mounted near your work area with Velcro

®

strips (supplied) or, using an integral button 10mm snap stud, attached directly to your staticsafe work mat. Powered by a 120 VAC wall adapter (supplied), the tester has a “Power on” indicator. It is practical for both a quick test or as a continuous ground point connection. UL listed.

Touch Type On-Demand Tester and

Common Point Ground.

Model#

6083

Adjustable

5529

Medium

Expand

Circumference – Min.

5.5in (139mm)

13in (330.2mm)

6.5in (165mm)

12in (304mm)

Made of non-allergenic stainless steel, each link has a 0.08in (2mm) PVF film laminated on top for electrical insulation. Quick and easy adjustment without tools, the wrist strap will fit most users.

A standard 0.16in (4mm) snap stud allows attachment to resistive coil cords.

Material: Band: Stainless steel / PVF Insulation.

Cover: Thermoplastic.

Wrist Circumference: 5.5in to 13.0in

(139.7mm x 330.2mm).

Width: 0.63in (16.0mm).

91 www.pomonaelectronics.com

Static Control Products

92

Ring Terminal

Stacking Snap

Banana Jack

Model# 5531

Attach this terminal to table or cabinet to create a banana jack for grounding wrist strap. Screw hole accepts up to

#10 screw.

Adjustable Elastic

Wrist Strap

Model# 6081

An adjustable, one size fits all, wrist strap. The wristband features a dual stainless steel cam that securely locks the plastic band, but allows easy adjustment without tools. The washable fabric band has silver impregnated nylon threads knitted into its inner surfaces.

Only non-allergenic stainless steel and silver touch the skin. Standard 4mm snap stud allows attachment to resistive coil cords (Pomona modles 5534 and 6085). Wrist circumference: 2.5in

(64mm) to 13in (330mm).(183cm).

Model# 5532

Attach this jack to either banana snap stud (male) or banana snap socket

(female). It allows multiple attachment to the same grounding point. Snap is

3/8in (9.52mm).

Material: High conductivity copper with tin plated finish.

Antistatic Ground Cord

Model# 5534

This patch cord features a molded-in

1 Megohm resistor at the snap end.

The 5534 has a straight banana plug.

Nominal extended length is 72in

(183cm).

www.pomonaelectronics.com

Telecom Products

Accuracy and repeatability – Pomona connects to the telecom industry with an impressive selection of test accessories. Ideal for network testing, troubleshooting, leave-in-the-line patching, or system prototyping, Pomona Electronics’ traditional reliability adds up to the quality connection telecom professionals demand.

Universal DSX-3 Test Kit

Model# 6568

• Ideal for OSP/CO technicians.

• Kit reduces the need for multiple cables to service and test DSX-3 panels.

• Adapters quickly convert BNC cables to Mini or

Standard WECO interfaces.

• Cables are color coded blue (transmit) and red

(receive) for ease of testing.

• Strain reliefs are molded directly to the cable and

BNC plugs for added pull strength.

• Test Companion pouch allows for convenient accessory storage.

Kit includes:

One blue BNC Male Cable Assembly

One red BNC Male Cable Assembly

Four Standard WECO to BNC Adapters

Four Mini-WECO to BNC Adapters

Test Companion Shoulder Pack

True 75 BNC Male Cable

Model#

6510-V-12-0

6510-V-24-0

6510-V-36-0

6510-V-48-0

6510-V-60-0

6510-V-72-0

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in(1.5m)

72in (1.8m)

BNC connectors are perfectly matched to 75 Ω impedance for superior VSWR and return loss performance.

Ideal for digital video and telecommunication applications.

Cable Type: High Flex,

Multi-strandcenter conductor,

RG59 Type, Black.

True 75 BNC Cable

(Transmit/Receive)

Model# Length

6510-V-72-2 72in (1.8m)

6510-V-72-6

72in (1.8m)

Color

Red

Blue

Cable and Strain Relief are color coded red and blue for easy identification of transmit and receive lines.

Cable Type: High Flex, Multi-strand center conductor, RG59 Type.

BNC Male to Bantam

Plug Cable

Model#

6517-96

Length

96in (2.4m)

Cable Type: RG59 Type.

Bantam: Nickel-plated brass.

93

Ratings: The components in this section have a hands free rating for use in controlled voltage environments.

However, for CE compliance these products are not intended for hand held use at voltages above 33 Vrms/70 Vdc.

www.pomonaelectronics.com

Telecom Products

94

BNC Female to WE309/

WE310 Plug Adapters

BNC Female to Bantam

Plug Adapters

75 BNC Male to Mini-WECO

(440) Connector Cable

Model#

2798

1794

Plug Type

WE310

WE309

Rating: Maximum voltage for

hands free use: 500V Peak, +122°F

(+50°) max.

Model# 4719

Rating: Maximum voltage for

hands free use: 500V Peak, +122°F

(+50°) max.

Convert Bantam style jacks to BNC.

BNC Female to Mini/Standard

WECO Plug Adapters

Model#

6519

5008

Plug Type

Mini WECO (440)

Std. WECO

(WE090)

Permits BNC male to be used with equipment having Std. WECO or

Mini WECO plugs.

Rating: Maximum voltage for

hands free use: 500 Vrms,

+216°F (+102°C) max.

Bantam Plug Patch Cord

Model#

6515-96

Length

96in (2.4m)

Cable Type: RG59 Type.

Model#

4279-12

4279-24

4279-36

4279-48

4279-60

4279-72

Length

12in (0.3m)

24in (0.6m)

36in (0.9m)

48in (1.2m)

60in (1.5m)

72in (1.8m)

Bantam Plug:

4279: Unplated brass.

4279N: Nickel-plated brass.

Rating: Maximum voltage for

hands free use: 300 Vrms:

300 Vrms*, +122˚F (+50˚C) max.

Cable Type: 2 Conductor

Shielded Twisted Pair, 0.180in

(4.57mm) O.D.

75BNC Male to Standard

WECO (WE090) Connector

Cable

Model#

6516-96

Length

96in (2.4m)

Cable Type: RG59 Type.

Mini-WECO (440) Plug

Patch Cord

Model#

6502-96

Length

96in (2.4m)

Cable Type: RG59 Type.

Bantam Plug to Two

Alligator Clips

Model#

5026-36

5026-60

5026N-60

Length

36in (0.9m)

60in (1.5m)

60in (1.5m)

Bantam Plug:

5026: Unplated brass.

5026N: Nickel-plated brass.

Rating: Maximum voltage for

hands free use: 150 Vrms, +122˚F

(+50˚C) max.

Cable Type: 2 Conductor Shielded

Microphone, 0.180in (4.57) O.D.

Bantam Plug to Minigrabber

®

Test Clips

Model#

5019-60

5019N-60

Length

60in (1.5m)

60in (1.5m)

Bantam Plug:

5019: Unplated brass.

5019N: Nickel-plated brass.

Rating: Maximum voltage for

hands free use: 300 Vrms,

+122˚F (+50˚C) max.

Cable Type: 2 Conductor Shielded cable, 0.180in (4.57) O.D.

www.pomonaelectronics.com

*see rating message at start of section.

Telecom Products

Bantam Plug to Double

Banana Plug

Model#

6523-96

Length

96in (2.4m)

Bantam Plug: Nickel-plated brass.

Cable Type: RG59 Type.

Bantam Plug to RJ48/RJ45

Connector Cable

Model#

6324-96

Length

96in (2.4m)

Bantam Plug: Nickel-plated brass.

Rating: Maximum voltage for hands

free use: 300 Vrms.

Cable Type: 2 Conductor Shielded

Twisted Pair.

Pin Out: 4-Ring, 5-Tip.

95

Bantam Plug to

Micrograbber

®

Test Clips

Model#

4778-60

Length

60in (1.5m)

Bantam Plug: Unplated brass.

Rating: Maximum voltage for hands free use: 150 Vrms*, +122˚F

(+50˚C) max.

Cable Type: 2 Conductor Shielded cable, 0.180in (4.57mm) O.D.

Two Single Bantam Plugs to RJ48/RJ45 Connectors

Model#

6320-96

Length

96in (2.4m)

Bantam Plug: Nickel-plated brass.

Rating: Maximum voltage for hands

free use: 300 Vrrms.

Cable Type: 2 and 4 Conductor

Shielded Twisted Pair. Bantam “Y”

(Tx and Rx) to RJ48 modular plug.

Pin out: 1-Ring, 2-Tip, 4-Ring,

5-Tip.

Bantam Plug to Double

Banana Plug, Balanced Line

Model#

4281-60

Length

60in (1.5m)

Bantam Plug: Unplated brass.

Rating: Maximum voltage for hands

free use: 500V Peak, +131˚F

(+55˚C) max.

Cable Type: 2 Conductor Shielded

Microphone, 0.180in (4.57mm) O.D.

Bantam Plug to WE310

Plug Patch Cable

Model#

4280N-36

4280-48

4280-60

Length

36in (0.9m)

48in (1.2m)

60in (1.5m)

WE310 and Bantam Plugs:

4280: Unplated brass.

4280N: Nickel-plated brass

Rating: Maximum voltage for

hands free use: 300 Vrrms., +122˚F

(+50˚C) max.

Cable Type: 2 Conductor

Shielded Twisted Pair, 0.180in

(4.57mm) O.D.

Bantam Plug to RJ11

Connector Cable

Model#

6323-96

Length

96in (2.4m)

Bantam Plug: Nickel-plated brass.

Rating: Maximum voltage for hands

free use: 300 Vrms..

Cable Type: 2 Conductor Shielded

Twisted Pair.

Pin out: 3-Ring, 4-Tip

Bantam (Female) to WE310

Plug Adapter

Model#

4993

6315

Plating

Unplated

Nickel

Plug Body: Brass.

3 Conductor adapter. Converts bantam cable into a WE310 plug-end patch cable.

*see rating message at start of section.

www.pomonaelectronics.com

Telecom Products

96

Dual Bantam Plug

Patch Cable

Model#

6331-96

Length

96in (2.4m)

Bantam Plugs: Nickel-plated brass.

Rating: Maximum voltage for hands

free use: 300 Vrms.

Cable Type: 4 Conductor Shielded

Twisted Pair.

Two Single WE310 Plugs to RJ48/RJ45 Plug

Model#

6316-96

Length

96in (2.4m)

WE310 Plug:

3352: Unplated brass.

3352N: Nickel-plated brass.

Rating: Maximum voltage for

hands free use: 150 Vrms., +122˚F

(+50˚C) max.

Cable Type: 2 Conductor Twisted

Pair, 0.250in (6.35mm) O.D.

Bantam or WE310 Plug to

Binding Post

Model#

2112

5001

Plug Type

WE310

Bantam

Rating: Maximum voltage for

hands free use: 500V Peak, +122°F

(+50°C) max.

Adapts Bantam or WE310 style equipment to binding posts and double banana plugs.

Piercing Clips to

Sheathed Banana

Test Leads

Model# Clip Type

6483-48-* Bed of Nails and

Single Needle

6485-48-* Bed of Nails

Length

48in (1.2m)

48in (1.2m)

Pierces 19 to 26 AWG Wire.

Wire: 18 AWG Silicone Test Lead Wire.

For use with DMM’s from Fluke, Wavetek

(Meterman), Amprobe, Greenlee and others.

*Colors: -0 Black, -2 Red, -02 includes both

Black and Red.

WE310 Plug to Double

Banana Plug Cable

Model#

6524-96

Cable Type: RG59.

Length

96in (2.4m)

Piercing Clip Styles for Test

Leads and Patch Cords

Bed of Nails/Single Needle

Small wire and single penetration of heavier wire.

Bed of Nails

Small wire penetration.

WE310 Plug to Two

Alligator Clips

Model#

3352-A-60

3352N-A-60

Length

60in (1.5m)

60in (1.5m)

WE310 Plug:

3352: Unplated brass.

3352N: Nickel-plated brass.

Rating: Maximum voltage for

hands free use: 150 Vrms., +122˚F

(+50˚C) max.

Cable Type: 2 Conductor Twisted

Pair, 0.250in (6.35mm) O.D.

Piercing Clips to

Bantam Plugs

Patch Cord

Model#

6484-60

6486-60

Clip Type

Bed of Nails and

Single Needle

Bed of Nails

Length

60in

(1.52m)

60in

(1.52m)

Cable: Two Conductor Twisted Pair.

Breakout Wire: 18 AWG.

www.pomonaelectronics.com

*Color Code: -0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,

-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White

Telecom Products

BNC Female to WE310

Phone Plug

0.25in (6.35mm)

0.50in (12.70mm)

Model# 2798

Rating: Maximum voltage for hands

free use: 500V Peak, +122˚F

(+50˚C) max.

BNC Female to Mini-WECO

(440) Plug Adapter

0.38in

(9.65mm)

2.125in (53.85mm)

Model# 6519

Rating: Maximum voltage for

hands free use: 500V Peak,

+216°F (+102°C) max.

Permits BNC male to be used with equipment having mini-WECO jacks.

Video plug equivalent to WE-090.

2.90in (73.66mm)

97

BNC Female to

Bantam Phone Plug

0.50in (12.70mm)

0.173in (4.40mm)

2.63in (66.80mm)

Model# 4719

Rating: Maximum voltage for hands

free use: 500V Peak, +122˚F

(+50˚C) max.

Convert Bantam style jacks to BNC.

BNC Female to Standard

WECO (WE090) Plug

Adapter

0.38in

(9.65mm)

2.83in (71.88mm)

Model# 5008

Rating: Maximum voltage for

hands free use: 500V Peak, +216˚F

(+102˚C) max.

Permits BNC male to be used with equipment having standard

WECO jacks.

Video plug equivalent to WE-090.

Bantam Phone Jack to

WE310 Phone Plug

0.25in (6.35mm)

3.27in (83.06mm)

Model# 4993

Rating: Maximum voltage for hands

free use: 500V Peak.

Use cords with Bantam style plugs on equipment with WE-310 jacks.

BNC Female to WE309

Phone Plug

0.206in (5.23mm)

0.50in (12.70mm)

2.89in (73.41mm)

Model# 1794

Rating: Maximum voltage for hands

free use: 500V Peak, +122˚F

(+50˚C) max.

Stackable Binding Posts to Bantam Phone Plug

0.173in (4.40mm)

0.75in

(19.05mm)

Model# 5001

Rating: Maximum voltage for

hands free use: 500V Peak, +122˚F

(+50˚C) max.

Adapts Bantam style equipment to binding posts and double banana plugs.

2.74in (69.60mm) open

Stackable Binding Posts to WE310 Phone Plug

0.25in (6.35mm)

0.75in

(19.05mm)

Model# 2112

Rating: Maximum voltage for

hands free use: 500V Peak, +122˚F

(+50˚C) max.

3.11in (79.00mm) open

*see rating message at start of section.

www.pomonaelectronics.com

Category Index

98

Category Page#

Adapters

Adapter Accessories . . . . . . . . . . . . . . . . . . . 6-29

Adapter Kit, Coaxial Cable . . . . . . . . . . . . . . 17-20

Banana Jack and Plug . . . . . . . . . . . . . . . . . 33-43

[see separate Banana Plugs & Jacks section]

Banana to Connector Pin and Socket . . . . 42-43

Banana to Pin Tip . . . . . . . . . . . . . . . . . . . . . . 42

Banana Plug to Phono Jack . . . . . . . . . . . . . . . 86

Bantam to Binding Post . . . . . . . . . . . . . . . . 96, 97

Bantam to WE310 . . . . . . . . . . . . . . . . . . . . . . . 96

BNC Dust Cap . . . . . . . . . . . . . . . . . . . . . . . . . . 20

BNC to 1/4in Phone Plug . . . . . . . . . . . . . . . . . . 86

BNC to 3.5mm Plug . . . . . . . . . . . . . . . . . . . . . . 86

BNC to Banana Plug . . . . . . . . . . . . . . . . . . . . . . 19

BNC to Bantam . . . . . . . . . . . . . . . . . . . . . . . . . 97

BNC to Binding Post . . . . . . . . . . . . . . . . . . . . . 19

BNC to BNC . . . . . . . . . . . . . . . . . . . . . . . . . 17, 21

BNC to F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

BNC to Mini Phone Plug . . . . . . . . . . . . . . . . . . 86

BNC to N . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 31

BNC to Phone Plug . . . . . . . . . . . . . . . . . . . . . . 86

BNC to Phono Jack . . . . . . . . . . . . . . . . . . . . . . 86

BNC to SMA . . . . . . . . . . . . . . . . . . . . . . . . . 17, 28

BNC to TNC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

BNC to Tini Plug . . . . . . . . . . . . . . . . . . . . . . . . 86

BNC to Triax . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

BNC to UHF . . . . . . . . . . . . . . . . . . . . . . . . . 17, 31

BNC to WE309 . . . . . . . . . . . . . . . . . . . . . . . . . 97

BNC to WE309 / 310 . . . . . . . . . . . . . . . . . . . . . 97

BNC to WECO . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Coaxial Adapters and Kits . . . . . . . . . . . . . . 17-20

Coaxial Connectors and Adapters . . . . . . . . 17-32

F to F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

N to N . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18, 29

Oscilloscope Probe Tip . . . . . . . . . . . . . . . . 80-83

Phone Plug 1/4in to Banana Plug . . . . . . . . . . . 87

Phone Plug to Banana Plug . . . . . . . . . . . . . . . 87

Safety Banana Jack to Banana Plug . . . . . . . . . . 34

SMA to “N” . . . . . . . . . . . . . . . . . . . . . . . . . 17, 28

SMA to SMA . . . . . . . . . . . . . . . . . . . . . . . . 17, 23

SMA to TNC . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Terminal Strip to Banana Jack . . . . . . . . . . . . . 36

Test Probe, DMM . . . . . . . . . . . . . . . . . . . . 59-72

Pin Tip to Banana . . . . . . . . . . . . . . . . . . . . . . . . 42

TNC to TNC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Triax to Triax . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Triaxial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Type N to BNC . . . . . . . . . . . . . . . . . . . . . . . 17, 31

Universal Kits . . . . . . . . . . . . . . . . . . . . . . . . 17-20

WE310 to Binding Post . . . . . . . . . . . . . . . . . . . 97

Alligator Clips, Regular Size

To Banana Jack . . . . . . . . . . . . . . . . . . . . . . 70, 75

Breakout to BNC . . . . . . . . . . . . . . . . . . . . . 14, 16

DMM Test Lead . . . . . . . . . . . . . . . . 49-50, 66, 91

Extra Large . . . . . . . . . . . . . . . . . . . . . . . . . . 69, 75

Patch Cord to Alligator Clip . . . . . . . . . . . . . 49-51

Patch Cord to Bantam . . . . . . . . . . . . . . . . . 94-97

Patch Cord to BNC . . . . . . . . . . . . . . . . . . . 14, 16

Patch Cord to 1000V Alligator Clip . . . . . . . . . . 50

Alligator Clips, Mini

To 2mm Banana Jack . . . . . . . . . . . . . . . . . 75, 78

Breakout to BNC . . . . . . . . . . . . . . . . . . . . . . . . 16

DMM Test Lead . . . . . . . . . . . . . . . . . . . . . . 49-50

Patch Cord to Banana, double . . . . . . . . . . . . . . 47

Patch Cord to Banana, single . . . . . . . . . . . . . . . 50

Patch Cord to Banana, mini, double . . . . . . . . . 48

Patch Cord to Mini Alligator Clip . . . . . . . . . . . . 50

Patch Cord to Mini Grabber . . . . . . . . . . . . . . . . 50

Alligator Clips, Micro

Patch Cord to Micro Alligator Clip . . . . . . . . . . 48, 50

Attenuators

BNC Attenuator . . . . . . . . . . . . . . . . . . . . . . . . . 20

Category Page#

Audio

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84-87

XLR Connecter . . . . . . . . . . . . . . . . . . . . . . . 84-86

Automotive

Automotive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Backprobe Pin . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Connector Test Probe . . . . . . . . . . . . . . . . . . . . 88

Connector Test Socket . . . . . . . . . . . . . . . . . . . . 88

Lead Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Piercing Probes . . . . . . . . . . . . . . . . . . . . . . . . . 88

Test Pins and Sockets . . . . . . . . . . . . . . . . . . . . 88

Banana Plugs and Jacks (Binding Posts too)

Banana Jack Mounting Base . . . . . . . . . . . . . . . 38

Banana Jack, panel mount with wire wrap . . 40-41

Banana Jack to Banana Jack . . . . . . . . . 33, 46, 70

Banana Jack to Miniature Banana Plug . . . . 39, 42

Banana Jack Miniature Panel Mount . . . . . . . . . 40

Banana Jack to Pin Tip Jack . . . . . . . . . . . . . . . 42

Banana Jack Panel Mount . . . . . . . . . . . 37, 40, 41

Banana Miniature Jack to Banana Plug . . . . . . . 41

Banana Miniature Plug Panel Mount . . . . . . 36, 37

Banana Miniature Plug Shorting Bar . . . . . . . . . 43

Banana Plug Adapters . . . . . . . . . . . . . . . . . . . . 43

Banana Plug Panel Mount . . . . . . . . . . . . . . . . . 36

Banana Plug to Pin Tip Plug . . . . . . . . . . . . . . . 47

Banana Plugs and Jacks . . . . . . . . . . . . . . . 33-43

Banana Shorting Bar . . . . . . . . . . . . . . . . . . . . . 39

Binding Post . . . . . . . . . . . . . . . . . . . . . . . . 38-42

Binding Post, Double . . . . . . . . . . . . . . . . . . . . . 38

Binding Post Miniature . . . . . . . . . . . . . . . . . . . 40

Binding Post Mounting Base . . . . . . . . . . . . . . . 38

Binding Post Shorting Bar . . . . . . . . . . . . . . . . . 39

Binding Post, Spring Loaded . . . . . . . . . . . . . . . 38

Binding Post to Banana Plug . . . . . . . . . . . . . . . 42

Connector Test Probe . . . . . . . . . . . . . . . . . . . . 43

Connector Test Socket . . . . . . . . . . . . . . . . . . . . 43

Coupler . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34, 70

Double Banana Plugs . . . . . . . . . . . . . . . . . . . . . 34

Double Banana Jacks, Panel Mount . . . . . . . . . . 37

Low Thermal . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Miniature Banana Jack . . . . . . . . . . . . . . . . . . . . 42

Miniature Banana Plug . . . . . . . . . . . . . . . . . 42, 46

Nut, Hex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Pin Tip Jack Panel Mount . . . . . . . . . . . . . . . . . 41

Safety Banana Jack to Banana Plug adapter . . . 34

Safety Banana, Jacks . . . . . . . . . . . . . . . . . . 34, 37

Safety Banana, panel mount . . . . . . . . . . . . . . . 43

Safety Banana Plugs . . . . . . . . . . . . . . . . . . 34, 35

Safety Banana Plug, right angle . . . . . . . . . . . . . 35

Safety Banana Plug, stackable . . . . . . . . . . . 34-35

Single Banana Jacks . . . . . . . . . . . . . . . . . . . . . 36

Single Banana, Plugs . . . . . . . . . . . . . . . 35-36, 39

Solderless Banana Plug, double . . . . . . . . . . . . 33

Solderless Banana Plug, single . . . . . . . . . . . . . 35

Solderless Banana Plug, triple . . . . . . . . . . . . . . 34

Solderless Binding Post, double . . . . . . . . . 40, 42

Solderless Mini Banana Plug, double. . . . . . . . . 39

Solderless Mini Banana Plug, single . . . . . . . . . 39

Solderless Mini Banana Plug, triple . . . . . . . . . . 39

Spade Lug . . . . . . . . . . . . . . . . . . . . . . . . . . 43, 70

Stackable Banana Plug, double . . . . . . . . . . . . . 33

Stackable Banana Plug, single . . . . . . . . . . . . . . 35

Stackable Banana Plug, triple . . . . . . . . . . . . . . 34

Stackable Binding Post, double . . . . . . . . . . . . . 42

Stackable Mini Banana Plug, double . . . . . . . . . 39

Stackable Mini Banana Plug, single . . . . . . . . . . 39

Stackable Mini Banana Plug, triple. . . . . . . . . . . 39

Stacking Banana Plug, quad, single . . . . . . . . . . 34

Test Pins and Sockets . . . . . . . . . . . . . . . . . . . . 43

Triple Banana Plugs . . . . . . . . . . . . . . . . . . . . . . 34

Triple Banana Jacks, panel mount . . . . . . . . . . . 37

Category Page#

Boxes and Enclosures

Boxes and Enclosures . . . . . . . . . . . . . . . . . 53-58

Box, Aluminum . . . . . . . . . . . . . . . . . . . . . . 53-57

Box, Plastic . . . . . . . . . . . . . . . . . . . . . . . . . 57-58

Breakouts

Assemblies and Breakouts . . . . . . . . . . . . . . . 6-16

BNC to Alligator Clips . . . . . . . . . . . . . . . . . . . . 16

BNC to Banana Plug . . . . . . . . . . . . . . . . . . .15,16

BNC to Pin Tip . . . . . . . . . . . . . . . . . . . . . . . .15,16

BNC to Spade lugs . . . . . . . . . . . . . . . . . . . . . . . 16

BNC to Square Jack . . . . . . . . . . . . . . . . . . . .15,16

BNC to Test Clips . . . . . . . . . . . . . . . . . . . . . . . . 16

BNC to Wire Lead . . . . . . . . . . . . . . . . . . . . . . . 16

Broadcast

BNC Color-Coded Sleeves . . . . . . . . . . . . . . . . . . 7

BNC High Definition Coaxial Connectors . . . . . . 84

BNC Terminator . . . . . . . . . . . . . . . . . . . . . . . . . 20

XLR Connectors . . . . . . . . . . . . . . . . . . . . . . 84-86

Cable Assemblies

Assemblies and Breakouts . . . . . . . . . . . . . . . 6-16

Banana Miniature Plug . . . . . . . . . . . . . . . . . . . . 16

BNC Color-Coded Sleeves . . . . . . . . . . . . . . . . . . 7

BNC to Alligator Clips . . . . . . . . . . . . . . . . . 16, 19

BNC to Banana Plug . . . . . . . . . . . . . . . . 17, 18, 19

BNC to BNC . . . . . . . . . . . . . . . . . . . . . 7-9, 87, 93

BNC to Pin Tip . . . . . . . . . . . . . . . . . . . . . . . 14, 16

BNC to SMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

BNC to Spade lugs . . . . . . . . . . . . . . . . . . . . . . . 16

BNC to Square Jack . . . . . . . . . . . . . . . . . . . 15, 16

BNC to Test Clips . . . . . . . . . . . . . . . . . . 13-14, 16

BNC to Wire Lead . . . . . . . . . . . . . . . . . . . . . . . 16

Coaxial Cable Set . . . . . . . . . . . . . . . . . . . . . . . . 88

Lead Holder . . . . . . . . . . . . . . . . . . . . . . . 6, 44, 88

N to N . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Phone Plug . . . . . . . . . . . . . . . . . . . . . . . . . 31, 86

SMA to “N” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

SMA to SMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Triax to Alligator Clips . . . . . . . . . . . . . . . . . . . . 13

Triax to Triax . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

UHF to UHF . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Calibration Accessory Kit

Assemblies and Breakouts . . . . . . . . . . . . . . . . . 52

Connectors

Banana Plugs & Jacks [see separate

Banana Plugs & Jacks section] . . . . . . . . 33-35

Binding Post

[see Banana Plugs & Jacks section] . . . . 38-42

BNC 75 Ω . . . . . . . . . . . . . . . . . . . . . . . . . 7, 20, 84

BNC Bulkhead Receptacle,

Hermetically Sealed . . . . . . . . . . . . . . . . . . . . . . 22

BNC Plugs, Jacks . . . . . . . . . . . . . . . . . 17-22, 31

BNC, Hermetically Sealed . . . . . . . . . . . . . . . . . 22

BNC High Definition . . . . . . . . . . . . . . . . . . . . . . 84

BNC, Isolated, Bulkhead Receptacle . . . . . . . . . 22

BNC Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

BNC PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

BNC Strain Relief Boot . . . . . . . . . . . . . . . . . . . . 14

Broadcast Connectors and Adapters . . . . . . 84-87

Coaxial Connectors and Adapters . . . . . . . . 17-32

F Plugs, Jacks . . . . . . . . . . . . . . . . . . . . . . . 30, 87

F Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

F to BNC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30, 87

MCX Plugs, Jacks . . . . . . . . . . . . . . . . . . . . . . . 26

MCX Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

MCX PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

MMCX Plugs, Jacks . . . . . . . . . . . . . . . . . . . . . . 27

MMCX PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Grabber Type Clips . . . . . . . . . . . . . . . . 69, 73-75

N Coaxial . . . . . . . . . . . . . . . . . . . . . . . . . . . 20, 29

N Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

N Terminator . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

www.pomonaelectronics.com

Category Index

Category Page#

SMA Plugs, Jacks . . . . . . . . . . . . . . . . 17, 23, 24, 28

SMA Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

SMA PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

SMB Plugs, Jacks . . . . . . . . . . . . . . . . . . . . . . . 24

SMB PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Tip Pin, Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Tip Pin, Panel Mount . . . . . . . . . . . . . . . . . . . . . 41

Tip Pin, Panel Mount with Wire Wrap . . . . . . . . 41

TNC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Triax Plugs, Jacks . . . . . . . . . . . . . . . . . . . . . . . 31

Triax Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Twinax Plugs, Jacks . . . . . . . . . . . . . . . . . . . . . 30

Twinax Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

XLR Connectors . . . . . . . . . . . . . . . . . . . . . . . . . .

(many models in Broadcast Catalog) . . . . 84-87

DC Blocking

BNC Blocking Capacitor . . . . . . . . . . . . . . . . . . . 20

DMM Accessories

0.04”, 0.06” & 0.08” Replaceable Probe Tips . . 67

Alligator Clips . . . . . . . . . . . . 59-66, 69, 70, 75, 78

Automotive Leads . . . . . . . . . . . . . . . . . . . . . . . 88

Backprobe Pins . . . . . . . . . . . . . . . . . . . . . . 61, 88

Banana Jack to Banana Jack . . . . . . . . . . . . 34, 67

Cases and Pouches . . . . . . . . . . . . . . . . . . . . . . 66

Couplers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34, 70

Couplers, Test Lead, Banana . . . . . . . . . . . . . . . 70

DMM Accessories and Kits . . . . . . . . . . . . . 59-72

DMM Accessories Cases and Pouches . . . . . . . 66

Do It Yourself DMM Accessories . . . . . . . . . . . . 70

Kelvin Clips with Leads . . . . . . . . . . . . . . . . . . . 70

Kelvin Probe Set . . . . . . . . . . . . . . . . . . . . . . . . 70

Kit List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Piercing Alligator Clips to Banana Plug . . . . . . . 69

Piercing Probes . . . . . . . . . . . . . . . . . . . 64, 67, 88

Pogo Tip Probes . . . . . . . . . . . . . . . . . . . . . 65, 67

Probe Tip Adapter . . . . . . . . . . . 60, 61, 62, 63, 70

Probe Tips, Spring-Loaded (Pogo Pin) . . . . 65, 67

Probe Tips, Replacable . . . . . . . . . . . . . 59, 64, 67

Retractable Needle Tip Test Probes . . . . . . . . . . 71

RF Detector Test Probe . . . . . . . . . . . . . . . . . . . 71

Screw-on Alligator Clips Set . . . . . . . . . . . . . . . 65

Shielded Leads . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Spade Lug . . . . . . . . . . . . . . . . . . . . . . . . . . 43, 70

Spade Lug Adapter . . . . . . . . . . . . . . . . . . . . . . 70

Spring Loaded Probe tip sets . . . . . . . . . . . . . . 64

Test Clips . . . . . . . . . . . . . . . . . . . . . . . . 69, 73-75

Test Lead Kits . . . . . . . . . . . . . . . . . . . . . . . 59-66

Test Lead Wire . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Test Leads and Test Lead Kits . . . . . . . . . . . . . . 68

Test Leads, Modular . . . . . . . . . . . . . . . . . . . . . 68

Test Probe RF Detector . . . . . . . . . . . . . . . . . . . 71

Test Probe Selection Table . . . . . . . . . . . . . . . . 66

Test Probe SMD Tweezers . . . . . . . . . . . . . . . . . 71

Test Probe Tip Adapters . . . . . . . . . . . . . . . 60-63

Test Probe with Leads . . . . . . . . . . . 65, 68, 71, 72

Test Probe, Modular . . . . . . . . . . . . . . . . . . . . . 68

Wire Piercing Test Clip . . . . . . . . . . . . . . . . . . . 69

Wire, Test Lead . . . . . . . . . . . . . . . . . . . . . . . . . 72

Do-It-Yourself

Leads and Grabbers . . . . . . . . . . . . . . . . . . . . . . 72

IC Test Clips

IC Test Clips and Adapter . . . . . . . . . . . . . . 89-90

Kelvin Clips

Kelvin Probes, Clips with Leads . . . . . . . . . . . . . 72

Oscilloscope Probes

Differential Probe . . . . . . . . . . . . . . . . . . . . . . . . 83

Probes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80-83

Probes Accessory Kit . . . . . . . . . . . . . . . . . . 80-83

Probes and Accessories . . . . . . . . . . . . . . . . 80-83

. . . . . . . . . . . . . . . . . . . . . . . . 74, 77, 80, 82

SMD Adapter . . . . . . . . . . . . . . . . . . . . . . . . 80-82

Category Page#

Patch Cords

Alligator to Alligator . . . . . . . . . . . . . . . . . . . . . . 51

Banana Jack to Banana Plug . . . . . . . . . . . . . . . 51

Banana Jack to Minigrabber . . . . . . . . . . . . . . . 45

Banana Jack, Sheathed to Minigrabber. . . . . . . 46

Banana Jack to Test Clip . . . . . . . . . . . . . . . . . . 45

Banana Plug . . . . . . . . . . . . . . . . . . . . . . . . . 33-42

Banana Plug to Maxigrabber . . . . . . . . . . . . . . . 45

Banana Plug to Micrograbber . . . . . . . . . . . . . . 46

Banana Plug Miniature . . . . . . . . . . . . . . . . . . . . 45

Banana Plug Miniature to Test Clip . . . . . . . . . . 45

Banana Plug, Miniature to Minigrabber . . . . . . 51

Banana Plug to Minigrabber . . . . . . . . . . . . 45, 47

Banana Plug to Alligator Clip . . . . . . . . . 48, 49, 50

Banana Plug to Pin Tip . . . . . . . . . . . . . . . . . . . 47

Banana Plug, Retractable Sheathed to

SMD Grabber . . . . . . . . . . . . . . . . . . . . 69, 73-75

Banana Plug, Sheathed to Extra

Large Alligator Clip . . . . . . . . . . . . . . . . . . . . . 50

Banana Plug to Square Pin Jack . . . . . . . . . . . . 51

Banana Plug to Test Clip . . . . . . . . . . . . 45, 46, 49

Banana Plug, Miniature to Standard . . . . . . . . . 45

Bantam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Bantam to Alligator . . . . . . . . . . . . . . . . . . . . . . 94

Bantam to Banana Plug . . . . . . . . . . . . . . . . . . . 94

Bantam to RJ11 . . . . . . . . . . . . . . . . . . . . . . . . . 95

Bantam to RJ45 / RJ48 . . . . . . . . . . . . . . . . . . . 95

Bantam to Test Clip . . . . . . . . . . . . . . . . . . . . . . 94

Bantam to WE310 . . . . . . . . . . . . . . . . . . . . . . . 95

BNC 75 Ω . . . . . . . . . . . . . . . . . . . . . . . . . 7, 20, 84

BNC to Alligator Clip . . . . . . . . . . . . . . . . . . 13, 16

BNC to Double Banana Plug . . . . . . . . . . . . . . . 14

BNC to BNC . . . . . . . . . . . . . . . . . . . . . . . . . 17, 25

BNC to Grabbers and Pincers . . . . . . . . . . . 13, 14

BNC to Type N . . . . . . . . . . . . . . . . . . . . . . 16, 31

BNC to Bantam . . . . . . . . . . . . . . . . . . . . . . . . . 97

BNC to Phono Plug . . . . . . . . . . . . . . . . . . . . . . 86

BNC to Pin Tip Plug . . . . . . . . . . . . . . . . . . . . . . 42

BNC to SMA . . . . . . . . . . . . . . . . . . . . . . . . . 17, 28

BNC to TNC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

BNC to UHF . . . . . . . . . . . . . . . . . . . . . . . . . 17, 30

BNC to WE310 . . . . . . . . . . . . . . . . . . . . . . . . . 97

BNC to WECO l . . . . . . . . . . . . . . . . . . . . . . . . . 97

Coax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-32

Coiled Patch Cords . . . . . . . . . . . . . . . . . . . 45, 46

Double Shielded Coax, Triaxial . . . . . . . . . . 30, 31

Fuse Holder Banana Plug . . . . . . . . . . . . . . . . . . 45

Lead Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Large Alligator Clip . . . . . . . . . . . . . . . . . . . . . . 75

Low Thermal . . . . . . . . . . . . . . . . . . . . . . . . 43, 49

Miniature Banana Plug to Minigrabber . . . . . . . 51

Minigrabber to Pin Tip Plug . . . . . . . . . . . . . . . . 73

Type N . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Patch Cords and Test Leads . . . . . . . . . . . . 44-51

Patch Cord to Banana, Double . . . . . . . . . . . 47, 48

Patch Cord to Banana, Single . . . . . . 44-46, 49-51

Patch Cord to Large Alligator Clip . . . . . . . . . . . 75

Patch Cord to Spade Lug . . . . . . . . . . . . . . . 49, 51

Patch Cord to Triaxial . . . . . . . . . . . . . . . . . . . . 13

Patch Cord to WE310 . . . . . . . . . . . . . . . . . 95-96

Pin Tip . . . . . . . . . . . . . . . . . . . . . . 16, 41, 42, 74

Pin Tip to Test Clip . . . . . . . . . . . . . . . . . . . . . . 51

Retractable Sheath Banana . . . . . . . . . . . . . . . . 50

Retractable Sheathed Banana

Plug to SMD Grabber . . . . . . . . . . . . . . . . . . . 76

Sheathed Banana Jack to Minigrabber . . . . . . . . 46

Sheathed Banana Plug to Extra

Large Alligator Clip . . . . . . . . . . . . . . . . . . . . . 50

Shielded, Double Banana . . . . . . . . . . . . . . . . . . 46

Shielded Twisted Pair, Triaxial . . . . . . . . . . . . . . 16

SMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 23, 28

SMD Test Clip . . . . . . . . . . . . . . . . . 46, 49, 74, 76

Spade Lug . . . . . . . . . . . . . . . . . . . . . . . . . . 49, 51

Spade Lug to Alligator . . . . . . . . . . . . . . . . . . . . 51

Square Pin to Banana . . . . . . . . . . . . . . . . . . . . 51

Spade Lug to Banana Plug . . . . . . . . . . . . . . . . . 51

Category Page#

Square Pin Jack to Pin Tip . . . . . . . . . . . . . . . . . . . 51

Test Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49, 51

Test Clip to Alligator . . . . . . . . . . . . . . . . . . . . . 51

Triaxial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Twisted Pair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

UHF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

WE310 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95, 96

WE310 to Alligator . . . . . . . . . . . . . . . . . . . . . . . 96

WE310 to Banana Plug . . . . . . . . . . . . . . . . . . . 96

WE310 to RJ45 / RJ48 . . . . . . . . . . . . . . . . . . . 95

WECO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94, 97

Shorting Cap

BNC Shorting Cap . . . . . . . . . . . . . . . . . . . . . . . 20

SMA Shorting Cap . . . . . . . . . . . . . . . . . . . . . . . 23

Static Control

Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Patch Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Static Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Tester . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Wrist Strap . . . . . . . . . . . . . . . . . . . . . . . . . . 91, 92

Telecom

BNC to Bantam . . . . . . . . . . . . . . . . . . . 93, 94, 97

Bantam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94, 95

Bantam to Alligator . . . . . . . . . . . . . . . . . . . . . . 94

Bantam to Banana Plug . . . . . . . . . . . . . . . . . . . 95

Bantam to RJ11 . . . . . . . . . . . . . . . . . . . . . . . . . 95

Bantam to RJ45 / RJ48 . . . . . . . . . . . . . . . . . . . 95

Bantam to Test Clip . . . . . . . . . . . . . . . . . . . . . . 94

Bantam to WE310 . . . . . . . . . . . . . . . . . . . . . . . 95

BNC to Bantam . . . . . . . . . . . . . . . . . . . . . . . . . 97

BNC to WE310 . . . . . . . . . . . . . . . . . . . . . . 94, 97

BNC to WECO . . . . . . . . . . . . . . . . . . . . . . . 94, 97

Patch Cords . . . . . . . . . . . . . . . . . . . . . . . . . 93-96

WE310 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94-97

WE310 to Alligator . . . . . . . . . . . . . . . . . . . . . . . 96

WE310 to Banana Plug . . . . . . . . . . . . . . . . . . . 95

WE310 to RJ45 / RJ48 . . . . . . . . . . . . . . . . . . . 96

WECO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94, 97

Piercing Alligator Clips to Banana Plug . . . . . . . 96

Telecom . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93-97

Test Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Bantam to Binding Post . . . . . . . . . . . . . . . . 96, 97

Bantam to WE310 . . . . . . . . . . . . . . . . . . . . 95, 97

Terminators

BNC Terminator . . . . . . . . . . . . . . . . . . . . . . . . . 20

SMA Terminator . . . . . . . . . . . . . . . . . . . . . . . . . 23

Test Clips

Banana Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Pin Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Solder Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Grabbers and Test Clips . . . . . . . . . . . . . . . . 73-75

Kelvin Clips with Leads . . . . . . . . . . . . . . . . . . . 72

Pin Tip to Alligator Clip . . . . . . . . . . . . . . . . . . . 75

Test Leads

Patch Cords and Test Leads . . . . . . . . . . . . 44-51

Test Probes

Test Probes . . . . . . . . . . . . . . . . . . . . . . . . . 59-72

SMD Tweezers . . . . . . . . . . . . . . . . . . . . . . . . . 71

Video

Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84-87

Wire

Test Lead Wire . . . . . . . . . . . . . . . . . . . . . . . . . . 72

99 www.pomonaelectronics.com

Category Index/Alphabetical Index

100

Alphabetical Listed Items Page#

Alligator Clips . . . . . . . . . . . . . . . . . . . . . . . . 75,78,83

Attenuators, BNC . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Automotive Leads . . . . . . . . . . . . . . . . . . . . . . . . . 88

Backprobe Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Cases & Pouches . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Coiled Patch Cords . . . . . . . . . . . . . . . . . . . . . 45, 46

Couplers . . . . . . . . . . . . . . . . . . . . . . . . . . . 34, 42, 70

Differential Oscilloscope probe . . . . . . . . . . . . . . . 83

ESD Control Products . . . . . . . . . . . . . . . . . . . 91, 92

Grabber type clips . . . . . . . . . . . . . . . . . . . . . . 73-75

Hanging Rack . . . . . . . . . . . . . . . . . . . . . . . . 6, 44, 88

Hardware, replacement . . . . . . . . . . . . . . . . . . . . . 39

Hermetically Sealed BNC . . . . . . . . . . . . . . . . . . . . 22

Kit List, DMM Test Leads . . . . . . . . . . . . . . . . . . . 66

Low Thermal Patch Cord . . . . . . . . . . . . . . . . . . . . 43

Low Thermal Lug . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Magnetic Test Lead holder . . . . . . . . . . . . . . . . . . . 88

Maxi Grabber Clips . . . . . . . . . . . . . . . . . . . . . 69, 74

Micro Grabber Clips . . . . . . . . . . . . . . . . . . . . . 69, 74

Mini Grabber Clips . . . . . . . . . . . . . . . . . . . . . . . . . 73

Mini Pincer Clip . . . . . . . . . . . . . . . . . . . . . . . . 69, 74

Mounting Bases, panel mount . . . . . . . . . . . . . . . . 38

Nuts, Hex, replacements . . . . . . . . . . . . . . . . . . . . 39

Piercing Probes . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Pogo Tip Probes . . . . . . . . . . . . . . . . . . . . 65, 67, 71

Pouches & Cases . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Retractable Sheath Banana Plug . . . . . . . . . . . . . . 35

Screw-on Alligator clip probes . . . . . . . . . . . . . . . . 60

Shielded Leads, DMM . . . . . . . . . . . . . . . . . . . . . . 64

Shorting Link, binding post . . . . . . . . . . . . . . . . . . 35

Shorting Plugs . . . . . . . . . . . . . . . . . . . 33, 34, 39, 41

Sleeves, color-coded . . . . . . . . . . . . . . . . . . . . . . . . 7

SMD Grabber Clips . . . . . . . . . . . . . . . . . . . . . . . . 78

SMD Oscilloscope Grabber Clips . . . . . 74, 77, 80-82

Spade Lugs . . . . . . . . . . . . . . . . . . . . . . . . . . . 43, 49

Splices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34, 42, 70

Spring Loaded Tip Probes . . . . . . . . . . . . . 65, 67, 71

Static Control Products . . . . . . . . . . . . . . . . . . 91-92

Strain Relief Boot . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Terminators, BNC . . . . . . . . . . . . . . . . . . . . . . . . . 20

Terminators, Type N . . . . . . . . . . . . . . . . . . . . . . . 20

Test Lead Rack Holders . . . . . . . . . . . . . . . . 6, 44, 86

Tini Plug to BNC adapter . . . . . . . . . . . . . . . . . . . . 86

Triaxial Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Triaxial Connectors . . . . . . . . . . . . . . . . . . . . . . . . 30

Triaxial Patch Cords . . . . . . . . . . . . . . . . . . . . . . . . 13

Tweezers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Wire Wrap Items . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Wire Reference Table, Coax . . . . . . . . . . . . . . . . . . . 6

Wire Reference Table, Patch Cord and Test Lead. . . 44

Model# Page#

2142 . . . . . . . . . . . . . . . . . . . . . . . .40

2143 . . . . . . . . . . . . . . . . . . . . . . . .41

2224 . . . . . . . . . . . . . . . . . . . . . . . .58

2239-C . . . . . . . . . . .47

2240 . . . . . . . . . . . . . . . . . . . . . . . .75

2244 . . . . . . . . . . . . . . . . . . . . . . . .39

2247-K . . . . . . . . . . .47

2249-C . . . . . . . . . 6, .7

2249-K . . . . . . . . . . . .7

2249-E . . . . . . . . . . . .7 .

2249-Y . . . . . . . . . . . .7

2259 . . . . . . . . . . . . . . . . . . . . . . . .57

2269 . . . . . . . . . . . . . . . . . . . . . . . .37

2305 . . . . . . . . . . . . . . . . . . . . . . . .43

2352 . . . . . . . . . . . 53, .54, .55

2382 . . . . . . . . . . . . .40

2383 . . . . . . . . . . . . . . . . . . . . . . . .40

2390 . . . . . . . . . . . . . . . . . . . . . . . .53

2391 . . . . . . . . . . . . . . . . . . . . . . . .53

2392 . . . . . . . . . . . . . . . . . . . . . . . .53

2393 . . . . . . . . . . . . . . . . . . . . . . . .53

2397 . . . . . . . . . . . . . . . . . . . . . . . .53

2398 . . . . . . . . . . . . . . . . . . . . . . . .53

2399 . . . . . . . . . . . . . . . . . . . . . . . .53

2400 . . . . . . . . . . . . . . . . . . . . . . . .53

2401 . . . . . . . . . . . . . . . . . . . . . . . .53

2411 . . . . . . . . . . . . . . . . . . . . . . . .54

2417 . . . . . . . . . . . . . . . . . . . . . . . .54

2420 . . . . . . . . . . . . . . . . . . . . . . . .54

2428 . . . . . . . . . . . . . . . . . . . . . . . .54

2439 . . . . . . . . . . . . . . . . . . . . . . . .40

2440 . . . . . . . . . . . . . . . . . . . . . . . .40

2447 . . . . . . . . . . . . . . . . . . . . . . . .22

2447A . . . . . . . . . . .22

2451 . . . . . . . . . . . . . . . . . . . . . . . .22

2451A . . . . . . . . . . .22

2455 . . . . . . . . . . . . . . . . . . . . . . . .29

2477 . . . . . . . . . . . . . . . . . . . . . . . .41

2484 . . . . . . . . . . . . . . . . . . . . . . . .45

2630 . . . . . . . . . . . . . . . . . . . . . . . .16

2631 . . . . . . . . . . . . . . . . . . . . . . . .16

2708 . . . . . . . . . . . . . . . . . . . 6, .44

2798 . . . . . . . . . . . . . . . . . 94, .97

2854 . . . . . . . . . . . . . . . . . . . . . . . .37

2864 . . . . . . . . . . . . .45

2882-C . . . . . . . . . . .14

2886 . . . . . . . . . . . . .16

2894 . . . . . . . . . . . . .42

2901 . . . . . . . . . . . . .54

2902 . . . . . . . . . . . . .54

2906 . . . . . . . . . . . . .54

2944 . . . . . . . . . . . . .39

2945 . . . . . . . . . . . . .39

2948 . . . . . . . . . . . . .44

2952 . . . . . . . . . . . . .41

2970 . . . . . . . . . . . . .34

2BA . . . . . . . . . . . . .47

2BA-AL . . . . . . . . . .48

2BC . . . . . . . . . . . . .47

2BC-AL . . . . . . . . . .48

Model# Page#

AL-B . . . . . . . . . . . .50

B . . . . . . . . . . . . . . .44

BNC-C . . . . . . . . . . . .8 .

CK73041 . . . . . . . 3,52

HB . . . . . . . . . . . . . .44

MDP . . . . . . . . . . . . .33

MDP-S . . . . . . . . . . .33

MDP-ST . . . . . . . . . .33

MDP-X . . . . . . . . . . .33

MG-B . . . . . . . . . . . .50

P . . . . . . . . . . . . . . .51

SP150B . . . . . . . . . .80

1081 . . . . . . . . . . . . . . . . . . . . . . .51

1166 . . . . . . . . . . . . .49

1167 . . . . . . . . . . . . .47

122505A . . . . . . . . .35

122506A . . . . . . . . .35

1236 . . . . . . . . . . . . .50

1269 . . . . . . . . . . . . .19

1270 . . . . . . . . . . . . .19

1286 . . . . . . . . . . . . .42

1296 . . . . . . . . . . . . .19

1297 . . . . . . . . . 31, .85

1325 . . . . . . . . . . . . .35

1326-A . . . . . . . . . . .47

1326-C . . . . . . . . . . .47

1330 . . . . . . . . . . . . . . . . . . . . . . . .33

1330-ST . . . . . . . . . .33

1368-A . . . . . . . . . . .46

1383-C . . . . . . . . . . . .8

1390 . . . . . . . . . . . . . . . . . . . . . . . .34

1432 . . . . . . . . . . . . . . . . . . . . . . . .42

1440 . . . . . . . . . . . . . . . . . . . . . . . .44

1442 . . . . . . . . . . . . . . . . . . . . . . . .86

1452 . . . . . . . . . . . . . . . . . . . . . . . .19

1468 . . . . . . . . . . . . . . . . . . . . . . . .19

1469 . . . . . . . . . . . . . . . . . . . . . . . .19

1508 . . . . . . . . . . . . . . . . . . . 6, .44

1581 . . . . . . . . . . . . . . . . . . . . . . . .37

1614A . . . . . . . . . . .70

1658-T . . . . . . . . . . . .9

1693 . . . . . . . . . . . . . . . . . . . . . . . .49

1756 . . . . . . . . . . . . . . . . . . . . . . . .49

1794 . . . . . . . . . . . . . . . . . 94, .97

1809 . . . . . . . . . . . . . . . . . . . . . . . .42

1823 . . . . . . . . . . . . . . . . . . . . . . . .34

1825 . . . . . . . . . . . . . . . . . . . . . . . .35

1829 . . . . . . . . . . . . . . . . . . . . . . . .34

1837 . . . . . . . . . . . . . . . . . . . . . . . .34

1894 . . . . . . . . . . . . . . . . . . . . . . . .19

1960 . . . . . . . . . . . . . . . . . . . . . . . .51

2035 . . . . . . . . . . . . . . . . . . . . . . . .39

2096 . . . . . . . . . . . . . . . . . . . . . . . .57

2098 . . . . . . . . . . . . .57

2099 . . . . . . . . . . . . . . . . . . . . . . . .57

2103 . . . . . . . . . . . . . . . . . . . . . . . .57

2104 . . . . . . . . . . . . . . . . . . . . . . . .58

2105 . . . . . . . . . . . . . . . . . . . . . . . .57

2112 . . . . . . . . . . . . . . . . . 96, .97

2138 . . . . . . . . . . . . . . . . . . . . . . . .42

Model# Page#

2BC-BNC . . . . . . . . .14

2BC-MG . . . . . . . . . .48

2BC-PP . . . . . . . . . .47

3014 . . . . . . . . . . . . .45

3027-K . . . . . . . . . . .48

3030 . . . . . . . . . . . . .40

3073 . . . . . . . . . . . . .16

3220 . . . . . . . . . . . . . . . . . . . . . . . .50

3221 . . . . . . . . . . . . .16

3230 . . . . . . . . . . . . .54

3231 . . . . . . . . . . . . . . . . . . . . . . .54

3232 . . . . . . . . . . . . . . . . . . . . . . . .54

3234 . . . . . . . . . . . . .54

3239 . . . . . . . . . . . . . . . . . . . . . . .54

3257 . . . . . . . . . . . . . . . . . . . . . . .36

3258 . . . . . . . . . . . . . . . . . . . . . . .36

3261 . . . . . . . . . . . . . . . . . . . . . . .36

3263 . . . . . . . . . . . . .36

3264 . . . . . . . . . . . . .36

3265 . . . . . . . . . . . . . . . . . . . . . . . .36

3266 . . . . . . . . . . . . . . . . . . . . . . . .36

3267 . . . . . . . . . . . . . . . . . . . . . . . .37

3268 . . . . . . . . . . . . . . . . . . . . . . . .40

3269 . . . . . . . . . . . . . . . . . . . . . . . .19

3271 . . . . . . . . . . . . . . . . . . . . . . . .40

3272 . . . . . . . . . . . . . . . . . . . . . . . .40

3276 . . . . . . . . . . . . . . . . . . . . . . . .39

3277 . . . . . . . . . . . . . . . . . . . . . . . .40

3283 . . . . . . . . . . . . . . . . . . . . . . . .21

3284 . . . . . . . . . . . . . . . . . . . . . . . .21

3285 . . . . . . . . . . . . . . . . . . . . . . . .21

3286 . . . . . . . . . . . . . . . . . . . . . . . .31

3287 . . . . . . . . . . . . . . . . . . . . . . . .31

3288 . . . . . . . . . . . . . . . . . . . . . . . .31

3289 . . . . . . . . . . . . . . . . . . . . . . . .75

3296 . . . . . . . . . . . . . . . . . . . . . . . .19

3301 . . . . . . . . . . . . . . . . . . . . . . . .55

3302 . . . . . . . . . . . . . . . . . . . . . . . .55

3306 . . . . . . . . . . . . . . . . . . . . . . . .55

3311 . . . . . . . . . . . . . . . . . . . . . . . .56

3316 . . . . . . . . . . . . . . . . . . . . . . . .56

3352-A . . . . . . . . . . .96

3352N-A . . . . . . . . .96

3364 . . . . . . . . . . . . . . . . . . . . . . . .34

3430 . . . . . . . . . . . . . . . . . . . . . . . .19

3452 . . . . . . . . . . . . . . . . . . . . . . . .41

3491 . . . . . . . . . . . . . . . . . . . . . . . .74

3533 . . . . . . . . . . . . . . . . . . . . . . . .21

3534 . . . . . . . . . . . . . . . . . . . . . . . .21

3535 . . . . . . . . . . . . . . . . . . . . . . . .31

3542 . . . . . . . . . . . . . . . . . . . . . . . .41

3548 . . . . . . . . . . . . . . . . . . . . . . . .40

3560 . . . . . . . . . . . . . . . . . . . . . . . .43

3561 . . . . . . . . . . . . . . . . . . . . . . . .43

3562 . . . . . . . . . . . . . . . . . . . . . . . .43

3563 . . . . . . . . . . . . . . . . . . . . . . . .43

3564 . . . . . . . . . . . . . . . . . . . . . . . .43

3565 . . . . . . . . . . . . . . . . . . . . . . . .43

3580 . . . . . . . . . . . . . . . . . . . . . . . .30

3600 . . . . . . . . . . . . . . . . . . . . . . . .30

Model# Page#

3601 . . . . . . . . . . . . .55

3602 . . . . . . . . . . . . . . . . . . . . . . . .55

3603 . . . . . . . . . . . . . . . . . . . . . . . .55

3606 . . . . . . . . . . . . . . . . . . . . . . . .55

3690 . . . . . . . . . . . . . . . . . . . . . . . .39

3719 . . . . . . . . . . . . . . . . . . . . . . . .54

3728 . . . . . . . . . . . . . . . . . . . . . . . .53

3742 . . . . . . . . . . . . . . . . . . . . . . . .56

3743 . . . . . . . . . . . . . . . . . . . . . . . .56

3744A . . . . . . . . . . .43

3750 . . . . . . . . . . . . . . . . . . . . . . . .38

3751 . . . . . . . . . . . . . . . . . . . . . . . .53

3752 . . . . . . . . . . . . . . . . . . . . . . . .53

3753 . . . . . . . . . . . . . . . . . . . . . . . .53

3754 . . . . . . . . . . . . . . . . . . . . . . . .53

3760 . . . . . . . . . . . . . . . . . . . . . . . .38

3770 . . . . . . . . . . . . . . . . . . . . . . . .38

3777A . . . . . . . . . . .43

3778 . . . . . . . . . . . . . . . . . . . . . . . .22

3780 . . . . . . . . . . . . . . . . . . . . . . . .48

3781 . . . . . . . . . . . . . . . . . . . . . . . .48

3782 . . . . . . . . . . . . . . . . . . . . . . . .45

3784 . . . . . . . . . . . . . . . . . . . . . . . .51

3786-C . . . . . . . . . . .47

3787-C . . . . . . . . . . .13

3788 . . . . . . . . . . . . . . . . . . . . . . . .16

3789 . . . . . . . . . . . . . . . . . . . . . . . .16

3834 . . . . . . . . . . . . . . . . . . . . . . . .42

3837 . . . . . . . . . . . . . . . . . 31, .85 .

3839 . . . . . . . . . . . . . . . . . . . . . . . .20

3840 . . . . . . . . . . . . . . . . . . . . . . . .20

3841 . . . . . . . . . . . . . . . . . . . . . . . .29

3842 . . . . . . . . . . . . . . . . . . . . . . . .29

3843 . . . . . . . . . . . . . . . . . . . . . . . .29

3844 . . . . . . . . . . . . . . . . . . . . . . . .31

3846 . . . . . . . . . . . . . . . . . . . . . . . .21

3847 . . . . . . . . . . . . . . . . . . . . . . . .21

3850 . . . . . . . . . . . . . . . . . . . . . . . .58

3862 . . . . . . . . . . . . . . . . . . . . . . . .38

3863 . . . . . . . . . . . . . . . . . . . . . . . .38

3864 . . . . . . . . . . . . . . . . . . . . . . . .46

3901 . . . . . . . . . . . . . . . . . . . . . . . .16

3916A . . . . . . . . . . .90

3925 . . . . . . . . . . . . . . . . . . . . . . .73

3957 . . . . . . . . . . . . . . . . . . . . . . . .16

3966 . . . . . . . . . . . . .16

4005 . . . . . . . . . . . . . . . . . . . . . . . .37

4022 . . . . . . . . . . . . . . . . . . . . . . . .87

4043 . . . . . . . . . . . . . . . . . . . . . . . .86

4044 . . . . . . . . . . . . . . . . . . . . . . . .87

4054 . . . . . . . . . . . . . . . . . 31, .84

4108 . . . . . . . . . . . . . . . . . . . . . . . .20

4115 . . . . . . . . . . . . . . . . . . . . . . . .39

4119 . . . . . . . . . . . . . . . . . . . . . . . .20

4159 . . . . . . . . . . . . . . . . . . . . . . . .22

4160 . . . . . . . . . . . . . . . . . . . . . . . .22

4176 . . . . . . . . . . . . . . . . . . . . . . . .73

4225 . . . . . . . . . . . . . . . . . . . . . . . .74

4226 . . . . . . . . . . . . . . . . . . . . . . . .55

4233 . . . . . . . . . . . . . . . . . . . . . . . .74 . .

www.pomonaelectronics.com

Model Number Index

Model# Page#

4654 . . . . . . . . . . . . . . . . . . . . . . . .38

4655 . . . . . . . . . . . . . . . . . . . . . . . .56

4656 . . . . . . . . . . . . . . . . . . . . . . . .56

4658 . . . . . . . . . . . . . . . . . . . . . . . .56

4661 . . . . . . . . . . . . . . . . . . . . . . . .30

4684 . . . . . . . . . . . . . . . . . . . . . . . .20

4690 . . . . . . . . . . . . . . . . . . . . . . . .43

4691 . . . . . . . . . . . . . . . . . . . . . . . .43

4702 . . . . . . . . . . . . . . . . . . . . . . . .51

4719 . . . . . . . . . . . . . . . . . 94, .97

4723 . . . . . . . . . . . . . . . . . . . . . . . .73 .

4725 . . . . . . . . . . . . . . . . . . . . . . . .13

4726 . . . . . . . . . . . . . . . . . . . . . . . .55

4741 . . . . . . . . . . . . . . . . . . . . . . . .51

4742 . . . . . . . . . . . . . . . . . . . . . . . .53

4768-K . . . . . . . . . . .47

4770 . . . . . . . . . . . . . . . . . . . . . . . .38

4771 . . . . . . . . . . . . . . . . . . . . . . . .51

4772 . . . . . . . . . . . . . . . . . . . . . . . .51

4773 . . . . . . . . . . . . . . . . . . . . . . . .41

4777-C . . . . . . . . . . .13

4777-K . . . . . . . . . . .13

4778 . . . . . . . . . . . . . . . . . . . . . . . .95

4787 . . . . . . . . . . . . . . . . . . . . . . . .29

4788 . . . . . . . . . . . . . . . . . . . . . . . .22

4804 . . . . . . . . . . . . . . . . . . . . . . . .23

4805 . . . . . . . . . . . . . . . . . . . . . . . .23

4826 . . . . . . . . . . . . . . . . . . . . . . . .73

4846-BB . . . . . . . . . .9 .

4846-C . . . . . . . . . . . .9

4846-K . . . . . . . . . . . .9

4846-X . . . . . . . . . . . .9

4846-UU . . . . . . . . . .9 .

4850 . . . . . . . . . . . . . . . . . . . . . . . .23

4859 . . . . . . . . . . . . . . . . . . . . . . . .23

4862 . . . . . . . . . . . . . . . . . 55, .56

4864 . . . . .54, .56, .57, .58

4892 . . . . . . . . . . . . . . . . . . . . . . . .33

4896 . . . . . . . . . . . . . . . . . . . . . . . .21

4897 . . . . . . . . . . . . . . . . . . . . . . . .35

4898 . . . . . . . . . . . . . . . . . . . . . . . .33

4899 . . . . . . . . . . . . . . . . . . . . . . . .35

4900 . . . . . . . . . . . . . . . . . . . . . . . .37

4903 . . . . . . . . . . . . . . . . . . . . . . . .57

4911A . . . . . . . . . . .50

4914 . . . . . . . . . . . . . . . . . . . . . . . .33

4933 . . . . . . . . . . . . . . . . . . . . . . . .35

4934 . . . . . . . . . . . . . . . . . . . . . . . .35

4935-BB . . . . . . . . . .9

4945-K . . . . . . . . . . .15

4956 . . . . . . . . . . . . . . . . . . . . . . . .29

4957 . . . . . . . . . . . . . . . . . . . . . . . .30

4958 . . . . . . . . . . . . . . . . . . . . . . . .30 .

4964-SS . . . . . . . . . .7

4969 . . . . . . . . . . . . . . . . . . . . . . . .16

4970 . . . . . . . . . . . . . . . . . . . . . . . .16

4979 . . . . . . . . . . . . . . . . . . . . . . . .22

4986 . . . . . . . . . . . . . . . . . . . . . . . .35

4993 . . . . . . . . . . . . . . . . . 95, .97

4995 . . . . . . . . . . . . . . . . . . . . . . . .38

Model# Page#

4240 . . . . . . . . . . . . . . . . . . . . . . . .20

4243 . . . . . . . . . . . . . . . . . . . . . . . .38

4245 . . . . . . . . . . . . . . . . . . . . . . . .53

4246 . . . . . . . . . . . . . . . . . . . . . . .54

4247 . . . . . . . . . . . . . . . . . 55, .56

4248 . . . . . . . . . . . . . . . . . . . . . . .54

4274 . . . . . . . . . . . . . . . . . . . . . . .45

4276-C . . . . . . . . . . . .8

4277-C . . . . . . . . . . . .9

4279 . . . . . . . . . . . . . . . . . . . . . . . .94

4280 . . . . . . . . . . . . . . . . . . . . . . . .95

4280N . . . . . . . . . . .95

4281 . . . . . . . . . . . . . . . . . . . . . . . .95

4282 . . . . . . . . . . . . . . . . . . . . . . . .23 .

4283 . . . . . . . . . . . . . . . . . . . . . . . .23

4284 . . . . . . . . . . . . . . . . . . . . . . . .23

4285 . . . . . . . . . . . . . . . . . . . . . . . .23

4286 . . . . . . . . . . . . . . . . . . . . . . . .23

4288 . . . . . . . . . . . . . . . . . . . . . . . .28

4289 . . . . . . . . . . . . . . . . . . . . . . . .28

4290 . . . . . . . . . . . . . . . . . . . . . . . .28

4291 . . . . . . . . . . . . . . . . . . . . . . . .28

4292 . . . . . . . . . . . . . . . . . . . . . . . .28

4293 . . . . . . . . . . . . . . . . . . . . . . . .28

4294 . . . . . . . . . . . . . . . . . . . . . . . .28

4295 . . . . . . . . . . . . . . . . . . . . . . . .28

4296 . . . . . . . . . . . . . . . . . . . . . . . .28

4297 . . . . . . . . . . . . . . . . . . . . . . . .28

4298 . . . . . . . . . . . . . . . . . . . . . . . .28

4299 . . . . . . . . . . . . . . . . . . . . . . . .28

4384 . . . . . . . . . . . . . . . . . . . . . . . .58

4388 . . . . . . . . . . . . . . . . . . . . . . . .30

4391 . . . . . . . . . . . . . . . . . . . . . . . .20

4408 . . . . . . . . . . . . . . . . . . . 6, .44

4408M . . . . . . . . . . .88

4416 . . . . . . . . . . . . . . . . . . . . . . . .55

4488 . . . . . . . . . . . . . . . . . . . . . . . .21

4512 . . . . . . . . . . . . . . . . . . . . . . . .36

4513 . . . . . . . . . . . . . . . . . . . . . . . .39

4521 . . . . . . . . . . . . . . . . . . . . . . . .74

4524-C . . . . . . . . . . . .8

4528-K . . . . . . . . . . . .9

4528-X . . . . . . . . . . . .9

4530-C . . . . . . . . . . .15

4531-C . . . . . . . . . . .13

4532-C . . . . . . . . . . .14

4538 . . . . . . . . . . . . . . . . . . . . . . . .45

4543 . . . . . . . . . . . . . . . . . . . . . . . .41

4550B . . . . . . . . . . .80

4555 . . . . . . . . . . . . . . . . . . . . . . . .73

4565 . . . . . . . . . . . . . . . . . . . . . . . .74

4578 . . . . . . . . . . . . . . . . . . . . . . . .22

4590 . . . . . . . . . . . . . . . . . . . . . . . .38

4601 . . . . . . . . . . . . . . . . . . . . . . . .37

4613 . . . . . . . . . . . . . . . . . . . . . . . .49

4614 . . . . . . . . . . . . . . . . . . . . . . . .38

4617 . . . . . . . . . . . . . . . . . . . . . . . .39

4619 . . . . . . . . . . . . . . . . . . . . . . . .38

4650 . . . . . . . . . . . . . . . . . . . . . . . .50

4653-0 . . . . . . . . . . .39

Model# Page# Model# Page#

4996 . . . . . . . . . . . . . . . . . . . . . . . .45

4997 . . . . . . . . . . . . . . . . . . . . . . . .21

5001 . . . . . . . . . . . . . . . . . 96, .97

5008 . . . . . . . . . . . . . . . . . 94, .97

5014 . . . . . . . . . . . . . . . . . . . . . . . .90

5018 . . . . . . . . . . . . . . . . . . . . . . . .38

5019 . . . . . . . . . . . . . . . . . . . . . . . .94

5019N . . . . . . . . . . .94

5026 . . . . . . . . . . . . . . . . . . . . . . . .94

5026N . . . . . . . . . . .94

5051 . . . . . . . . . . . . . . . . . . . . . . . .16

5053 . . . . . . . . . . . . . . . . . . . . . . . .46

5054 . . . . . . . . . . . . . . . . . . . . . . . .13

5056 . . . . . . . . . . . . . . . . . . . . . . . .30

5058-X . . . . . . . . . . . .9

5066 . . . . . . . . . . . . . . . . . . . . . . . .32

5068 . . . . . . . . . . . . . . . . . . . . . . . .32

5069 . . . . . . . . . . . . . . . . . . . . . . . .16

5076 . . . . . . . . . . . . . . . . . . . . . . . .32

5085 . . . . . . . . . . . . . . . . . . . . . . . .20

5088 . . . . . . . . . . . . . . . . . . . . . . . .23

5089 . . . . . . . . . . . . . . . . . . . . . . . .29

5090 . . . . . . . . . . . . . . . . . . . . . . . .31

5108 . . . . . . . . . . . . . . . . . . . . . . . .90

5113A . . . . . . . . . . .83 .

5114 . . . . . . . . . . . . . . . . . . . . . . . .90

5117A . . . . . . . . . . .84 .

5125A . . . . . . . . . . .83 .

5126A . . . . . . . . . . .83

5133 . . . . . . . . . . . . . . . . . . . . . . . .71

5142-K . . . . . . . . . . .71

5143-K . . . . . . . . . . .71

5144 . . . . . . . . . . . . . . . . . . . . . . . .69

5145 . . . . . . . . . . . . . . . . . . . . . . . .34

5148 . . . . . . . . . . . . . . . . . . . . . . . .22

5155 . . . . . . . . . . . . . . . . . 14, .32

5156 . . . . . . . . . . . . . . . . . 14, .32

5157 . . . . . . . . . . . . . . . . . 14, .32

5165 . . . . . . . . . . . . . . . . . . . . . . . .42

5167 . . . . . . . . . . . . . . . . . . . . . . . .36

5168 . . . . . . . . . . . . . . . . . . . . . . . .36

5169 . . . . . . . . . . . . . . . . . . . . . . . .36

5170 . . . . . . . . . . . . . . . . . . . . . . . .36

5173 . . . . . . . . . . . . . . . . . . . . . . . .41

5178 . . . . . . . . . . . . . . . . . . . . . . . .30

5186 . . . . . . . . . . . . . . . . . . . . . . . .55

5187-C . . . . . . . . . . .14

5187-K . . . . . . . . . . .14

5188 . . . . . . . . . . . . . . . . . . . . . . . .16

5189 . . . . . . . . . . . . . . . . . . . . . . . .16

5198 . . . . . . . . . . . . . . . . . . . . . . . .57

5203 . . . . . . . . . . . . . . . . . . . . . . . .57

5208 . . . . . . . . . . . . . . . . . . . . . . . .90

5218 . . . . . . . . . . . . . . . . . . . . . . . .30

5219 . . . . . . . . . . . . . . . . . . . . . . . .30

5220 . . . . . . . . . . . . . . . . . . . . . . . .90

5223 . . . . . . . . . . . . . . . . . . . . . . . .13

5230 . . . . . . . . . . . . . . . . . . . . . . . .35

5233 . . . . . . . . . . . . . . . . . . . . . . . .37 .

5243 . . . . . . . . . . . . . . . . . . . . . . . .74

5250 . . . . . . . . . . . . . . . . . . . . . . . .90

5251 . . . . . . . . . . . . . . . . . . . . . . . .90

5252 . . . . . . . . . . . . . . . . . . . . . . . .90

5253 . . . . . . . . . . . . . . . . . . . . . . . .90

5254 . . . . . . . . . . . . . . . . . . . . . . . .90

5255 . . . . . . . . . . . . . . . . . . . . . . . .56 .

5266-C . . . . . . . . . . . .7

5268-C . . . . . . . . . . .15

5279 . . . . . . . . . . . . . . . . . . . . . . . .89

5280 . . . . . . . . . . . . . . . . . . . . . . . .89

5281 . . . . . . . . . . . . . . . . . . . . . . . .89

5285 . . . . . . . . . . . . . . . . . . . . . . . .21

5286 . . . . . . . . . . . . . . . . . . . . . . . .21

5290 . . . . . . . . . . . . . . . . . . . . . . . .30

5291A . . . . . . . . . . .49

5292 . . . . . . . . . . . . . . . . . . . . . . . .69

5295 . . . . . . . . . . . . . . . . . . . . . . . .49

5297 . . . . . . . . . . . . . . . . . . . . . . . .20

5298 . . . . . . . . . . . . . . . . . . . . . . . .31

5299 . . . . . . . . . . . . . . . . . . . . . . . .31

5300 . . . . . . . . . . . . . . . . . . . . . . . .31

5301 . . . . . . . . . . . . . . . . . . . . . . . .49

5302 . . . . . . . . . . . . . . . . . . . . . . . .46

5304-K . . . . . . . . . . .14

5305 . . . . . . . . . . . . . . . . . . . . . . . .16

5307 . . . . . . . . . . . . . . . . . . . . . . . .21

5309A . . . . . . . . . . .67

5312 . . . . . . . . . . . . . . . . . . . . . . . .89

5319 . . . . . . . . . 31, .84

5325A . . . . . . . . . . .60

5342 . . . . . . . . . . . . . . . . . . . . . . . .13

5343-C . . . . . . . . . . .15

5344 . . . . . . . . . . . . . . . . . . . . . . . .21

5360 . . . . . . . . . . . . . . . . . . . . . . . .74

5375 . . . . . . . . . . . . . . . . . . . . . . . .25

5401 . . . . . . . . . . . . . . . . . . . . . . . .89

5402 . . . . . . . . . . . . . . . . . . . . . . . .89

5405 . . . . . . . . . . . . . . . . . . . . . . . .42

5406 . . . . . . . . . . . . . . . . . . . . . . . .35

5418 . . . . . . . . . . . . . . . . . . . . . . . .74

5423-C . . . . . . . . . . .13

5428 . . . . . . . . . . . . . . . . . . . . . . . .46

5437 . . . . . . . . . . . . . . . . . . . . . . . .90

5510 . . . . . . . . . . . . . . . . . . . . . . . .18

5511 . . . . . . . . . . . . . . . . . . . . . . . .20

5513 . . . . . . . . . . . . . . . . . . . . . . . .18

5514 . . . . . . . . . . . . . . . . . . . . . . . .90

5515A . . . . . . . . . . .89

5519A . . . . . . . . . . .67

5520 . . . . . . . . . . . . . . . . . . . . . . . .74

5521 . . . . . . . . . . . . . . . . . . . . . . . .49

5522 . . . . . . . . . . . . . . . . . . . . . . . .73

5523 . . . . . . . . . . . . . . . . . . . . . . . .48

5525 . . . . . . . . . . . . . . . . . . . . . . . .49 .

5529 . . . . . . . . . . . . . . . . . . . . . . . .91

5531 . . . . . . . . . . . . . . . . . . . . . . . .92

5532 . . . . . . . . . . . . . . . . . . . . . . . .92

5534 . . . . . . . . . . . . . . . . . . . . . . . .92

5543B . . . . . . . . . . .60

5672A . . . . . . . . . . .60

Model# Page#

5673B . . . . . . . . . . .62

5674C . . . . . . . . . . .60

5676A . . . . . . . . . . .67

5677B . . . . . . . . . . .59

5678-K . . . . . . . . . . .71

5682 . . . . . . . . . . . . . . . . . . . . . . . .70

5689A . . . . . . . . . . .68

5697 . . . . . . . . . . . . . . . . . . . . . . . . . .8

5698 . . . . . . . . . . . . . . . . . . . . . . . .17

5699 . . . . . . . . . . . . . . . . . . . . . . . .37

5700 . . . . . . . . . . . . . . . . . . . . . . . .37

5701 . . . . . . . . . . . . . . . . . . . . . . . .37

5733 . . . . . . . . . . . . . . . . . . . . . . . .89

5748 . . . . . . . . . . . . . . . . . . . . . . . .17

5749 . . . . . . . . . . . . . . . . . . . . . . . .18

5787A . . . . . . . . . . .70

5788 . . . . . . . . . . . . . . . . . . . . . . . .75

5790 . . . . . . . . . . . . . . . . . . . . . . . .79

5795A . . . . . . . . . . .80

5800A . . . . . . . . . . .80

5803A . . . . . . . . . . .80

5806A . . . . . . . . . . .80

5809A . . . . . . . . . . .80

5812A . . . . . . . . . . .80

5827A . . . . . . . . . . .80

5830 . . . . . . . . . . . . . . . . . . . . . . . .74

5898 . . . . . . . . . . . . . . . . . . . . . . . .67

5899A . . . . . . . . . . .63

5900A . . . . . . . . . . .63

5901B . . . . . . . . . . .61

5903A . . . . . . . . . . .62

5904A . . . . . . . . . . .62

5906A . . . . . . . . . . .68

5907A . . . . . . . . . . .68

5908A . . . . . . . . . . .68

5909A . . . . . . . . . . .68

5910B . . . . . . . . . . .69

5911B . . . . . . . . . . .69

5912B . . . . . . . . . . .69

5913 . . . . . . . . . . . . . . . . . 69, .88

5914 . . . . . . . . . . . . . . . . . . . . . . . .69

5916A . . . . . . . 70, .75

5931 . . . . . . . . . . . . . . . . . . . . . . . .36

5934 . . . . . . . . . . . . . . . . . . . . . . . .42

5935 . . . . . . . . . . . . . . . . . . . . . . . .42

5936 . . . . . . . . . . . . . . . . . . . . . . . .43

5940 . . . . . . . . . . . . . . . . . . . . . . . .72

5948 . . . . . . . . . . . . . . . . . . . . . . . .51

5950A . . . . . . . . . . .67

5951A . . . . . . . . . . .67

5952A . . . . . . . . . . .65

5953A . . . . . . . . . . .65

5955 . . . . . . . . . . . . . . . . . . . . . . . .66

6041B . . . . . . . 69, .75

6042B . . . . . . . 69, .75

6049A . . . . . . . . . . .80

6069A . . . . . . . . . . .80

6081 . . . . . . . . . . . . . . . . . . . . . . . .92

6082 . . . . . . . . . . . . . . . . . . . . . . . .91

6083 . . . . . . . . . . . . . . . . . . . . . . . .91

Model# Page#

6084 . . . . . . . . . . . . . . . . . . . . . . . .91

6086 . . . . . . . . . . . . . . . . . . . . . . . .91

6087 . . . . . . . . . . . . . . . . . . . . . . . .91

6088 . . . . . . . . . . . . . . . . . . . . . . . .91

6101A . . . . . . . . . . .80

6102A . . . . . . . . . . .80

6106 . . . . . . . . . . . . . . . . . . . . . . . .71

6107 . . . . . . . . . . . . . . . . . . . . . . . .90

6108 . . . . . . . . . . . . . . . . . . . . . . . .90

6109 . . . . . . . . . . . . . . . . . . . . . . . .90

6112A . . . . . . . . . . .66

6146 . . . . . . . . . . . . . . . . . . . . . . .66

6147 . . . . . . . . . . . . . . . . . . . . . . .66

6162 . . . . . . . . . . . . . . . . . . . . . . . .66

6172A . . . . . . . . . . .64

6173A . . . . . . . . . . .63

6174 . . . . . . . . . . . . . . . . . . . . . . . .64

6175 . . . . . . . . . . . . . . . . . . . . . . . .66

6203 . . . . . . . . . . . . . . . . . . . . . . . .70

6204A . . . . . . . . . . .61

6212 . . . . . . . . . . . . . . . . . . . . . . . .71

6231 . . . . . . . . . . . . . . . . . . . . . . . .46

6232A . . . . . . . . . . .68

6235 . . . . . . . . . . . . . . . . . . . . . . . .69

6237 . . . . . . . . . . . . . . . . . . . . . . . .66

6244 . . . . . . . . . . . . . . . . . . . . . . . .46

6245 . . . . . . . . . . . . . . . . . . . . . . . .46

6248 . . . . . . . . . . . . . . . . . . . . . . . .46

6249 . . . . . . . . . . . . . . . . . . . . . . . .45

6252 . . . . . . . . . . . . . . . . . . . . . . . .70

6253-C . . . . . . . . . . . .8

6254 . . . . . . . . . . . . . . . . . . . . . . . .18

6262 . . . . . . . . . . . . . . . . . . .70,88

6263 . . . . . . . . . . . . . . . . . . . . . . . .70

6264 . . . . . . . . . . . . . . . . . . . . . . . .70

6265 . . . . . . . . . . . . . . . . . . . . . . . .80

6266 . . . . . . . . . . . . . . . . . . . . . . . .80 .

6267 . . . . . . . . . . . . . . . . . . . . . . . .80

6275 . . . . . . . . . . . . . . . . . . . . . . . .65

6283-C . . . . . . . . . . .46

6286 . . . . . . . . . . . . . . . . . . . . . . . .68

6288 . . . . . . . . . . . . . . . . . . . . . . . .68

6291 . . . . . . . . . . . . . . . . . . . . . . . . . .7

6303 . . . . . . . . . . . . . . . . . . . . . . . .72

6304 . . . . . . . . . . . . . . . . . . . . . . . .68

6315 . . . . . . . . . . . . . . . . . . . . . . . .95

6316 . . . . . . . . . . . . . . . . . . . . . . . .96

6320 . . . . . . . . . . . . . . . . . . . . . . . .95

6323 . . . . . . . . . . . . . . . . . . . . . . . .95

6324 . . . . . . . . . . . . . . . . . . . . . . . .95

6331 . . . . . . . . . . . . . . . . . . . . . . . .96

6340 . . . . . . . . . . . . . . . . . . . . . . . .59

6341 . . . . . . . . . . . . . . . . . . . . . . . .65

6342 . . . . . . . . . . . . . . . . . . . . . . . .65

6343 . . . . . . . . . . . . . . . . . . . . . . . .60

6344 . . . . . . . . . . . . . . . . . . . . . . . .60

6345 . . . . . . . . . . . . . . . . . . . . . . . .64

6351 . . . . . . . . . . . . . . . . . . . . . . . .79

6352 . . . . . . . . . . . . . . . . . . . . . . . .79

6353 . . . . . . . . . . . . . . . . . . . . . . . .79

101 www.pomonaelectronics.com

Model Number Index

102

Model# Page#

6485 . . . . . . . . . . . . . . . . . . . . . . . .96

6486 . . . . . . . . . . . . . . . . . . . . . . . .96

6490 . . . . . . . . . . . . . . . . . . . . . . . .79

6491 . . . . . . . . . . . . . . . . . . . . . . . .81

6493 . . . . . . . . . . . . . . . . . . . . . . . .81

6494 . . . . . . . . . . . . . . . . . . . . . . . .81

6495 . . . . . . . . . . . . . . . . . . . . . . . .81

6496 . . . . . . . . . . . . . . . . . . . . . . . .81

6497 . . . . . . . . . . . . . . . . . . . . . . . .81

6498 . . . . . . . . . . . . . . . . . . . . . . . .81

6499 . . . . . . . . . . . . . . . . . . . . . . . .81

6500 . . . . . . . . . . . . . . . . . . . . . . . .81

6502 . . . . . . . . . . . . . . . . . . . . . . . .94

6510-V . . . . . . . . 7, .93

6515 . . . . . . . . . . . . . . . . . . . . . . . .94

6516 . . . . . . . . . . . . . . . . . . . . . . . .94

6517 . . . . . . . . . . . . . . . . . . . . . . . .93

6519 . . . . . . . . . . . . . . . . . 94, .97

6523 . . . . . . . . . . . . . . . . . . . . . . . .95

6524 . . . . . . . . . . . . . . . . . . . . . . . .96

6530A . . . . . . . . . . .61

6534 . . . . . . . . . . . . . . . . . . . . . . . .88 .

6545 . . . . . . . . . . . . . . . . . . . . . . . .35

6546 . . . . . . . . . . . . . . . . . . . . . . . .35

6547 . . . . . . . . . . . . . . . . . . . . . . . .39

6548 . . . . . . . . . . . . . . . . . . . . . . . .39

6549 . . . . . . . . . . . . . . . . . . . . . . . .39

6551 . . . . . . . . . . . . . . . . . . . . . . . .82

6553 . . . . . . . . . . . 73, .81, .82

6554 . . . . . . . . . . . . . . . . . . . . . . . .82

6567 . . . . . . . . . . . . . . . . . . . . . . . .75

6568 . . . . . . . . . . . . . . . . . . . . . . . .93

6570 . . . . . . . . . . . . . . . . . . . . . . . .50

6576 . . . . . . . . . . . . . . . . . . . . . . . .50

6354 . . . . . . . . . . . . . . . . . 65, .71

6356 . . . . . . . . . . . . . . . . . . . . . . . .50

6357 . . . . . . . . . . . . . . . . . . . . . . . .49

6358 . . . . . . . . . . . . . . . . . . . . . . . .68

6364 . . . . . . . . . . . . . . . . . . . . . . . .71

6365 . . . . . . . . . . . . . . . . . . . . . . . .67

6366 . . . . . . . . . . . . . . . . . . . . . . . .67

6383 . . . . . . . . . . . . . . . . . 35, .72

6384 . . . . . . . . . . . . . . . . . 35, .72

6387 . . . . . . . . . . . . . . . . . . . . . . . .37

6389 . . . . . . . . . . . . . . . . . . . . . . . .39

6405 . . . . . . . . . . . . . . . . . 69, .88

6411 . . . . . . . . . . . . . . . . . . . . . . . .88

6413 . . . . . . . . . . . . . . . . . 69, .88

6440 . . . . . . . . . . . . . . . . . . . . . . . .39

6441 . . . . . . . . . . . . . . . . . . . . . . . .39

6442 . . . . . . . . . . . . . . . . . . . . . . . .79

6443 . . . . . . . . . . . . . . . . . 73, .80

6469 . . . . . . . . . . . . . . . . . . . . . . . .67

6470 . . . . . . . . . . . . . . . . . . . . . . . .67

6475 . . . . . . . . . . . . . . . . . . . . . . . .71

6477 . . . . . . . . . . . . . . . . . . . . . . . .67

6479 . . . . . . . . . . . . . . . . . . . . . . . .68

6481 . . . . . . . . . . . . . . . . . 43, .88

6483 . . . . . . . . . . . . . . . . . 50, .96

6484 . . . . . . . . . . . . . . . . . . . . . . . .96

Model# Page# Model# Page#

6601 . . . . . . . . . . . . . . . . . . . . . . . .65

6700 . . . . . . . . . . . . . . . . . . . . . . . .21

6701 . . . . . . . . . . . . . . . . . . . . . . . .21

6702A . . . . . . . 21, .83

6703A . . . . . . . 21, .83

6704A . . . . . . . 21, .83

6705 . . . . . . . . . . . . . . . . . . . . . . . .21

6706 . . . . . . . . . . . . . . . . . 30, .86

6712 . . . . . . . . . . . . . . . . . 30, .86

6713 . . . . . . . . . . . . . . . . . 30, .86

6717 . . . . . . . . . . . . . . . . . . . . . . . .22

6718 . . . . . . . . . . . . . . . . . . . . . . . .22

6720 . . . . . . . . . . . . . . . . . . . . . . . .36

6721 . . . . . . . . . . . . . . . . . 34, .72

6723 . . . . . . . . . . . . . . . . . . . . . . . .65

6726 . . . . . . . . . . . . . . . . . . . . . . . .65

6727 . . . . . . . . . . . . . . . . . . . . . . . .44

6728 . . . . . . . . . . . . . . . . . . . . . . . .34

6729 . . . . . . . . . . . . . . . . . 35, .72

6730 . . . . . . . . . . . . . . . . . . . . . . . .72

6733 . . . . . . . . . . . . . . . . . . . . . . . .72

6734 . . . . . . . . . . . . . . . . . . . . . . . .72

6735 . . . . . . . . . . . . . . . . . . . . . . . .22

6736 . . . . . . . . . . . . . . . . . . . . . . . .22

6737 . . . . . . . . . . . . . . . . . . . . . . . .21

6738 . . . . . . . . . . . . . . . . . . . . . . . .21

6739 . . . . . . . . . . . . . . . . . . . . . . . .21

6740 . . . . . . . . . . . . . . . . . . . . . . . .21

6741 . . . . . . . . . . . . . . . . . . . . . . . .22

6745 . . . . . . . . . . . . . . . . . . . . . . . .22

6744 . . . . . . . . . . . . . . . . . . . . . . . .21 .

6746A . . . . . . . . . . .21

6747 . . . . . . . . . . . . . . . . . . . . . . . .22

6748 . . . . . . . . . . . . . . . . . . . . . . . .22 .

6752A . . . . . . . . . . .21

6754 . . . . . . . . . . . . . . . . . . . . . . . .21

6779 . . . . . . . . . . . . . . . . . . . . . . . .28

6780 . . . . . . . . . . . . . . . . . . . . . . . .28

6781 . . . . . . . . . . . . . . . . . . . . . . . .28

6782 . . . . . . . . . . . . . . . . . . . . . . . .28 . .

6801 . . . . . . . . . . . . . . . . . 30, .85 . .

6802 . . . . . . . . . . . . . . . . . 30, .85

6803 . . . . . . . . . . . . . . . . . 30, .85

6850 . . . . . . . . . . . . . . . . . . . . . . . .83

6851 . . . . . . . . . . . . . . . . . . . . . . . .83

6854 . . . . . . . . . . . . . . . . . . . . . . . .84

6855 . . . . . . . . . . . . . . . . . . . . . . . .84

6856 . . . . . . . . . . . . . . . . . . . . . . . .84

6857 . . . . . . . . . . . . . . . . . . . . . . . .84

6863 . . . . . . . . . . . . . . . . . . . . . . . .84

6864 . . . . . . . . . . . . . . . . . . . . . . . .84

6869 . . . . . . . . . . . . . . . . . . . . . . . .83 .

6873 . . . . . . . . . . . . . . . . . . . . . . . .85

6874 . . . . . . . . . . . . . . . . . . . . . . . .85

6878 . . . . . . . . . . . . . . . . . . . . . . . .86

6879 . . . . . . . . . . . . . . . . . . . . . . . .87

6880 . . . . . . . . . . . . . . . . . . . . . . . .86

6881 . . . . . . . . . . . . . . . . . . . . . . . .86

6882 . . . . . . . . . . . . . . . . . . . . . . . .86

6883 . . . . . . . . . . . . . . . . . . . . . . . .38

6884 . . . . . . . . . . . . . . . . . . . . . . . .38

7035 . . . . . . . . . . . . . . . . . . . . . . . .21

7040 . . . . . . . . . . . . . . . . . . . . . . . .21

7042 . . . . . . . . . . . . . . . . . . . . . . . .21

7057 . . . . . . . . . . . . . . . . . . . . . . . .29

7073 . . . . . . . . . . . . . . . . . . . . . . . .22

7107 . . . . . . . . . . . . . . . . . . . . . . . .84

7108 . . . . . . . . . . . . . . . . . . . . . . . .85

7115 . . . . . . . . . . . . . . . . . . . . . . . .83

7142 . . . . . . . . . . . . . . . . . . . . . . . .85

7150 . . . . . . . . . . . . . . . . . . . . . . . .85

7151 . . . . . . . . . . . . . . . . . . . . . . . .85

7152 . . . . . . . . . . . . . . . . . . . . . . . .85

7156 . . . . . . . . . . . . . . . . . . . . . . . .85

7157 . . . . . . . . . . . . . . . . . . . . . . . .85

7158 . . . . . . . . . . . . . . . . . . . . . . . .85

7159 . . . . . . . . . . . . . . . . . . . . . . . .85

7160 . . . . . . . . . . . . . . . . . . . . . . . .85

7269 . . . . . . . . . . . . . . . . . . . . . . . .83

7270 . . . . . . . . . . . . . . . . . . . . . . . .83

7271 . . . . . . . . . . . . . . . . . . . . . . . .83

7272 . . . . . . . . . . . . . . . . . . . . . . . .83

7283 . . . . . . . . . . . . . . . . . . . . . . . .83

7284 . . . . . . . . . . . . . . . . . . . . . . . .83

7290 . . . . . . . . . . . . . . . . . . . . . . . .70

72902 . . . . . . . . . . . . . . . . . . . . . .77

72903 . . . . . . . . . . . . . . . . . . . . . .77

72904 . . . . . . . . . . . . . . . . . . . . . .77

72905 . . . . . . . . . . . . . . . . . . . . . .77

72906 . . . . . . . . . . . . . . . . . . . . . .77

72907 . . . . . . . . . . . . . . . . . . . . . .77

72908 . . . . . . . . . . . . . . . . . . . . . .15

72909 . . . . . . . . . . . . . . . . . . . . . .15

72910 . . . . . . . . . . . . . . . . . . . . . .19

72911 . . . . . . . . . . . . . . . . . . . . . .19

.72912 . . . . . . . . . . . . . . . . . . . . . .36

72913 . . . . . . . . . . . . . . . . . . . . . .36

72914 . . . . . . . . . . . . . . . 19, .79

72915 . . . . . . . . . . . . . . . . . . . . . .79

72916 . . . . . . . . . . . . . . . . . . . . . .79

72917 . . . . . . . . . . . . . . . . . . . . . .79

72918 . . . . . . . . . . . . . . . . . . . . . .36

72919 . . . . . . . . . . . . . . . . . . . . . .78

72920 . . . . . . . . . . . . . . . . . . . . . .78

72921 . . . . . . . . . . . . . . . . . . . . . .79

72922 . . . . . . . . . . . . . . . . . . . . . .79

72923 . . . . . . . . . . . . . . . . . . . . . .78

72924 . . . . . . . . . . . . . . . 75, .78

72925 . . . . . . . . . . . . . . . . . . . . . .78

72926-C . . . . . . . . . . .7

72927-C . . . . . . . . . .15

72928 . . . . . . . . . . . . . . . . . . . . . .76

72929 . . . . . . . . . . . . . . . . . . . . . .78

72930 . . . . . . . . . . . . . . . . . . . . . .36

72931 . . . . . . . . . . . . . . . . . . . . . .17

72932 . . . . . . . . . . . . . . . . . . . . . .18

72933 . . . . . . . . . . . . . . . . . . . . . .18

72934 . . . . . . . . . . . . . . . . . . . . . .17

72935 . . . . . . . . . . . . . . . . . . . . . .76

72936 . . . . . . . . . . . . . . . . . . . . . .78

Model# Page#

72937 . . . . . . . . . . . . . . . . . . . . . .19

72938 . . . . . . . . . . . . . . . . . . . . . .19

72940 . . . . . . . . . . . . . . . . . . . . . .82

72941 . . . . . . . . . . . . . . . . . . . . . .82

72942 . . . . . . . . . . . . . . . 65, .82

72943 . . . . . . . . . . . . . . . . . . . . . .24

72944 . . . . . . . . . . . . . . . . . . . . . .24

72945 . . . . . . . . . . . . . . . . . . . . . .24

72946 . . . . . . . . . . . . . . . . . . . . . .24

72950 . . . . . . . . . . . . . . . . . . . . . .24

72952 . . . . . . . . . . . . . . . . . . . . . .24

72953 . . . . . . . . . . . . . . . . . . . . . .24

72954 . . . . . . . . . . . . . . . . . . . . . .24

72956 . . . . . . . . . . . . . . . . . . . . . .24

72958 . . . . . . . . . . . . . . . . . . . . . .24

72959 . . . . . . . . . . . . . . . . . . . . . .24

72960 . . . . . . . . . . . . . . . . . . . . . .24

72961 . . . . . . . . . . . . . . . . . . . . . .24

72962 . . . . . . . . . . . . . . . . . . . . . .24

72963 . . . . . . . . . . . . . . . . . . . . . .24

72964 . . . . . . . . . . . . . . . . . . . . . .24

72965 . . . . . . . . . . . . . . . . . . . . . .24

72966 . . . . . . . . . . . . . . . . . . . . . .24

72967 . . . . . . . . . . . . . . . . . . . . . .24

72968 . . . . . . . . . . . . . . . . . . . . . .24

72969 . . . . . . . . . . . . . . . . . . . . . .24

72970 . . . . . . . . . . . . . . . . . . . . . .24

72971 . . . . . . . . . . . . . . . . . . . . . .24

72973 . . . . . . . . . . . . . . . . . . . . . .24

72974 . . . . . . . . . . . . . . . . . . . . . .24

72975 . . . . . . . . . . . . . . . . . . . . . .23

72976 . . . . . . . . . . . . . . . . . . . . . .28

72977 . . . . . . . . . . . . . . . . . . . . . .28

72978 . . . . . . . . . . . . . . . . . . . . . .28

72979 . . . . . . . . . . . . . . . . . . . . . .28

72980 . . . . . . . . . . . . . . . . . . . . . .25

72981 . . . . . . . . . . . . . . . . . . . . . .25

72982 . . . . . . . . . . . . . . . . . . . . . .25

72983 . . . . . . . . . . . . . . . . . . . . . .25

72984 . . . . . . . . . . . . . . . . . . . . . .25

72985 . . . . . . . . . . . . . . . . . . . . . .25

72987 . . . . . . . . . . . . . . . . . . . . . .25

72988 . . . . . . . . . . . . . . . . . . . . . .25

72989 . . . . . . . . . . . . . . . . . . . . . .25

72991 . . . . . . . . . . . . . . . . . . . . . .25

72992 . . . . . . . . . . . . . . . . . . . . . .25

72993 . . . . . . . . . . . . . . . . . . . . . .25

72995 . . . . . . . . . . . . . . . . . . . . . .25

72996 . . . . . . . . . . . . . . . . . . . . . .25

72997 . . . . . . . . . . . . . . . . . . . . . .25

72998 . . . . . . . . . . . . . . . . . . . . . .25

72999 . . . . . . . . . . . . . . . . . . . . . .25

73000 . . . . . . . . . . . . . . . . . . . . . .25

73001 . . . . . . . . . . . . . . . . . . . . . .25

73002 . . . . . . . . . . . . . . . . . . . . . .26

73003 . . . . . . . . . . . . . . . . . . . . . .26

73004 . . . . . . . . . . . . . . . . . . . . . .26

73005 . . . . . . . . . . . . . . . . . . . . . .26

73006 . . . . . . . . . . . . . . . . . . . . . .26

73007 . . . . . . . . . . . . . . . . . . . . . .26

Model# Page#

73008 . . . . . . . . . . . . . . . . . . . . . .26

73010 . . . . . . . . . . . . . . . . . . . . . .26

73011 . . . . . . . . . . . . . . . . . . . . . .26

73012 . . . . . . . . . . . . . . . . . . . . . .26

73014 . . . . . . . . . . . . . . . . . . . . . .26

73015 . . . . . . . . . . . . . . . . . . . . . .26

73016 . . . . . . . . . . . . . . . . . . . . . .26

73017 . . . . . . . . . . . . . . . . . . . . . .26

73018 . . . . . . . . . . . . . . . . . . . . . .26

73023 . . . . . . . . . . . . . . . . . . . . . .27

73024 . . . . . . . . . . . . . . . . . . . . . .27

73025 . . . . . . . . . . . . . . . . . . . . . .27

73026 . . . . . . . . . . . . . . . . . . . . . .27

73028 . . . . . . . . . . . . . . . . . . . . . .27

73029 . . . . . . . . . . . . . . . . . . . . . .27

73030 . . . . . . . . . . . . . . . . . . . . . .27

73032 . . . . . . . . . . . . . . . . . . . . . .27

73033 . . . . . . . . . . . . . . . . . . . . . .27

73034 . . . . . . . . . . . . . . . . . . . . . .27

73035 . . . . . . . . . . . . . . . . . . . . . .27

73037 . . . . . . . . . . . . . . . . . . . . . .27

73038 . . . . . . . . . . . . . . . . . . . . . .27

73039 . . . . . . . . . . . . . . . . . . . . . .27

73040 . . . . . . . . . . . . . . . 81, .82

73041 . . . . . . . . . . . . . . . . . 3, .52

73042 . . . . . . . . . . . . . . . . . . . . . .21 .

73043 . . . . . . . . . . . . . . . . . . . . . .21 .

73044 . . . . . . . . . . . . . . . . . . . . . .29 .

73045 . . . . . . . . . . . . . . . . . . . . . .29 .

73046 . . . . . . . . . . . . . . . . . . . . . .29 .

73047 . . . . . . . . . . . . . . . . . . . . . .29 .

73048 . . . . . . . . . . . . . . . . . . . . . .29 .

73049 . . . . . . . . . . . . . . . . . . . . . .29 .

73050 . . . . . . . . . . . . . . . . . . . . . .29 .

73051 . . . . . . . . . . . . . . . . . . . . . .29 .

73052 . . . . . . . . . . . . . . . . . . . . . .29 .

73053 . . . . . . . . . . . . . . . . . . . . . .32 .

73054 . . . . . . . . . . . . . . . . . . . . . .32 .

73056 . . . . . . . . . . . . . . . . . . . . . .32 .

73057 . . . . . . . . . . . . . . . . . . . . . .32 .

73058 . . . . . . . . . . . . . . . . . . . . . .32 .

73059 . . . . . . . . . . . . . . . . . . . . . .32 .

73061 . . . . . . . . . . . . . . . . . . . . . .21 .

73062 . . . . . . . . . . . . . . . . . . . . . .29 .

73063-BB . . . . . . . .10 .

73064-BB . . . . . . . .11 .

73065-BB . . . . . . . .12 .

73066-BB . . . . . . . .12 .

73067-BB . . . . . . . .10 .

73068-BB . . . . . . . .11 .

73069-BB . . . . . . . .11 .

73070-BB . . . . . . . .11 .

73070-C . . . . . . . . . .11 .

73071-BB . . . . . . . .11 .

73071-X . . . . . . . . . .11 .

73072-BB . . . . . . . .10 .

73072-VV . . . . . . . . .10 .

73073-BB . . . . . . . .10 .

73075-VV . . . . . . . . .10

73075-UU . . . . . . . .10 .

Model# Page#

73077-UU . . . . . . . .10 .

73078-UU . . . . . . . .12 .

73082-X . . . . . . . . . .12 .

73083-BB . . . . . . . .12 .

73083-X . . . . . . . . . .12 .

73084 . . . . . . . . . . . . . . . . . 3, .37 .

73085 . . . . . . . . . . . . . . . . . 3, .37 .

73086 . . . . . . . . . . . . . . . . . 3, .37 .

73087 . . . . . . . . . . . . . . . . . 3, .48 .

73088 . . . . . . . . . . . . . . . . . 3, .37

www.pomonaelectronics.com

Many Ways to Find Answers

Many Ways to Find Answers

You .can .quickly .find .complete .product .specifications .and .discover . .

Pomona’s .newest .product .announcements .when .you .visit .our .website: .

www.pomonaelectronics.com

Now there are three ways for you to find the product you are looking for.

1. Search by Keywords or Model #

On the left-hand column of our homepage, simply enter the description of the product or model number of the

Pomona product in the [Search] field and select [GO].

2. Search by Advanced Search

You will find our [Advanced Search] link on the left-hand column of the homepage. This allows you to choose from a number of search options to help you find exactly what you're looking for.

3. Search by Category

From the homepage, select [View Products] under either

“Test and Measurement” or “Broadcast/Multimedia”.

You will see a list of product categories from which to choose.

Whichever method you choose, you will be presented with model numbers and “pdf” hotkeys which will take you directly to specification information on the product you want.

Check Stock Availability

Once you have a specific Pomona model number you are interested in, you can immediately find a distributor with stock on hand. You can click the “Check Stock

Availability” link or from the left-hand navigation column, select [View Distributor Stock], enter the model number into the box, and click [GO]. You will be presented with a list of distributors with that part on hand.

Print a RoHS Compliance Certificate

Also, you can find RoHS Compliance Certifications on the left-hand navigation column by selecting [RoHS

Compliant Products] and selecting the model you are looking for.

Make the Pomona site your “favorite” place to “go to” when you need the world’s most complete line of quality test accessories.

Technical Support

[email protected]

Because technical questions about products or applications can arise almost anywhere, Pomona offers technical support with a qualified resource via e-mail or visiting the Pomona website. While you are in the Technical

Support section of our website, you can also refer to selector guides, view or request a catalog, or go directly to the specific product information you seek.

Nothing in this catalog is to be construed as an offer. Product availability, prices and delivery dates are subject to Pomona’s order confirmation form. The same applies to orders based on development samples delivered. Pomona products are intended to be used in accordance with the specifications in this catalog. Any use or application that deviates from those specifications may be dangerous. A limited warranty applies to Pomona products. Pomona will not be

liable for any loss, damage, cost of repair, or incidental or consequential damages of any kind, arising in connection with the design, manufacture, sale, or repair of the products, whether based on express or implied contract, negligence or strict liability. Pomona will not be liable to buyer for any amount

exceeding the purchase price of the product which proves to be defective. Pomona will not be responsible or liable for any patent infringements or other rights of third parties, which may result from the use of this catalog. Registered trademarks used in this catalog are the property of their respective companies.

www.pomonaelectronics.com

Professionals Trust

Pomona Performance

In the United States:

Pomona Electronics

9028 Evergreen Way

Everett, WA 98204

United States

www.pomonaelectronics.com

Tel: 1-800-490-2361

Fax: 1-425-446-5844

Lit.#: 2074413 C-ENG-N Rev.E

Volume 53

In Europe:

Pomona Electronics

P.O.Box 1186

5602 BD Eindhoven

The Netherlands

www.pomona.cc [email protected]

Tel: +31 (0) 40 2675 150

Fax: +31 (0) 40 2675 151

Pub ID: 11299-eng Rev 02

All other areas: www.pomonaelectronics.com

Tel: 1-425-446-5500

Fax: 1-425-446-5844

Products in this catalog are available through:

Copyright .© .2007 . .Pomona .is .a .trademark .of .Pomona .Electronics . . .All .other .product .and .

company .names .are .trademarks .or .registered .trademarks .of .their .respective .companies . . .

Specifications .subject .to .change .without .notice . .All .rights .reserved . .Printed .in .the .U .S .A . .

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
