Top sound for top stars—with a maximum range of applications and absolutely secure sound transmission, the new generation of
evolution 500 series wireless microphones will truly win you over. You will feel optimally equipped on all the major stages of the world with
the 500 series. So it should come as no surprise that the world’s top sound technicians rely on Sennheiser. On the one hand, this is due to
the microphones’ highly robust design—the metal housings are true survivors in the rough and tumble world of live music. On the other,
the new series provides even more features, so the microphones can be used in an unusually flexible and professional manner. You Know
You Can Rock The Crowd.
090146 G3 500er BROSCHUERE_GB.indd 2
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:25:16 Uhr
Can
090146 G3 500er BROSCHUERE_GB.indd 3
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:25:23 Uhr
Generation 3
The evolution wireless 500 series offers a range of new features that will convince you professionally on
all the major stages. Increased switching bandwidth of 42 MHz and 1,680 switchable frequencies, plus an expanded setting
range for audio sensitivity, ensure that vocals and instruments are transmitted in reliable and crystal-clear fashion. What is
more, PC frequency management for transmitter and receiver guarantees clear monitoring and professional data management
of multi-channel systems. In the fast pace of daily stage life, the soundcheck mode and integrated equalizer are just as practical
as the battery status display and true diversity receiver for optimal reception.
The 500 series combines the finest Sennheiser live sound with a range of technical innovations—it is your
companion in the world of professional wireless sound transmission. evolution wireless G3: You Know You Can.
090146 G3 500er BROSCHUERE_GB.indd 4
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:25:27 Uhr
2
1
NEW
Expanded setting
range for audio sensitivity
NEW
Ethernet port for connecting
to the Wireless Systems Manager (WSM)
software for control via computer
NEW
Enhanced AF
frequency range
5
3
4
NEW
Wireless transmitter
synchronization via
infrared interface saves valuable
time when setting up
NEW
Enhanced frequency
bank management
with up to 32 compatible
frequencies in 26 banks
090146 G3 500er BROSCHUERE_GB.indd 5
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:25:27 Uhr
Vocal Set
You Know You Can
Raise Your Voice
Lends strong voices a strong sound—the 500 series vocal set ensures brilliant sound, even during quiet sections. This
means that professional soul and rock voices sound as perfectly nuanced as classical singing voices. Experienced sound engineers
rely on this set, especially for large stages and unusual live events. Professionals can select from three different microphone heads
with cardioid and super-cardioid directional patterns.
Available
Sets
ew 500-935©
ew 500-945©
SKM 500-935©
handheld transmitter with cardioid
dynamic head,
with EM 500© true
diversity receiver,
GA 3 rack mount,
and MZQ 1 microphone clamp
SKM 500-945©
handheld transmitter with cardioid
dynamic head,
with EM 500© true
diversity receiver,
GA 3 rack mount,
and MZQ 1 microphone clamp
090146 G3 500er BROSCHUERE_GB.indd 6
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
ew 500-965©
SKM 500-965© handheld transmitter,
switchable polar patterns: cardioid/supercardioid true condenser,
dual large diaphragm,
with EM 500© true
diversity receiver, GA 3
rack mount, and MZQ 1
microphone clamp
20.03.2009 13:25:27 Uhr
True diversity receiver
•Ethernet port for connecting to the
WSM(Wireless Systems Manager)
•Infrared interface for wireless
synchronization of transmitters
•Headphone monitor
1
Switchable
transmission power (10mW/30mW)
mixing
console
2
5
Clear, distinct
transmission due to highly
accentuated live sound. Clearly
highlights the microphone voice
3
Easy to exchange
microphone heads
from the e900 pro series
4
090146 G3 500er BROSCHUERE_GB.indd 7
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
Transmission
control is simple with
the large display
20.03.2009 13:26:28 Uhr
True diversity receiver
•Ethernet port for connecting to the
WSM(Wireless Systems Manager)
•Infrared interface for wireless
synchronization of transmitters
•Headphone monitor
Extremely small
bodypack transmitter
guarantees absolute
freedom of movement
3
1
RF/AF mute
2
guitar
amp
instrument
4
Integrated
guitar tuner
5
7
Easy-to-read display
with battery level display:
for full control at the gig
Charging
contacts
6
Integrated control menu
with guitar cable emulation
090146 G3 500er BROSCHUERE_GB.indd 8
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:26:35 Uhr
Instrument Set
NEW
Guitar tuner
tune in to perfect
sound
You Know You Can
Rock The Crowd
Wireless sound transmission has become the standard for a professional live performance. The evolution wireless G3 500 Series
Instrument Set not only frees you from cables—its flexibility, sturdiness, and lightness all set absolutely professional standards. The
ultra-light bodypack transmitter can be attached inconspicuously to a belt or guitar strap. The clear dot matrix display leads you intuitively
through the control menu, and can be easily read—even under difficult lighting conditions. A brand-new feature of G3: a guitar tuner
that is extremely practical, as it is integrated directly into the receiver—and makes a tuning device for guitar and e-bass unnecessary!
Available
Sets
Set
090146 G3 500er BROSCHUERE_GB.indd 9
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
ew 572©
SK 500© bodypack
transmitter,
EM 500© true
diversity receiver,
CI 1 guitar cable,
and GA 3 rack
mount
20.03.2009 13:26:41 Uhr
Presentation Set
You Know You Can
Impress
These days, successful presentations depend on many factors. One of the most important: absolutely reliable sound
transmission. The G3 Presentation Set offers the professional quality standard demanded by TV studios and on large stages.
Presenters and lecturers can move freely – and due to the special frequency response of the professional clip-on microphone,
their voices can even be heard in the very last rows. Connected to the flexible bodypack transmitter, the cable is hidden discreetly
under the clothing.
Available
Sets
Set
090146 G3 500er BROSCHUERE_GB.indd 10
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
ew 512©
MKE 2 clip-on
microphone,
omnidirectional,
EM 500© true
diversity receiver,
SK 500© bodypack
transmitter, and
GA 3 rack mount
20.03.2009 13:27:14 Uhr
True diversity receiver
•Ethernet port for connecting to the
WSM(Wireless Systems Manager)
•Infrared interface for wireless
synchronization of transmitters
•Headphone monitor
1
Large display ensures
the necessary control
over the performance, even
in bad light
2
mixing
console
Charging
contacts
3
5
Extremely small
clip-on microphone
4
Optimized frequency
response for clear,
distinct transmission
090146 G3 500er BROSCHUERE_GB.indd 11
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:27:37 Uhr
You Know You Can
Expand
With the evolution wireless G3, complete sets can be tailored to your individual needs using professional accessories and individual components. Simply expand your G3 system as your requirements grow.
GA 3 Rack mount
AB 3 Antenna booster
CC 3 System case
BA 2015 Rechargeable battery pack
LA 2 Charging adapter for SKM, used with L 2015
A 2003 Directional UHF antenna
A 1031 Passive omnidirectional UHF antenna
L 2015 Charging unit
NT 1-1 Mains unit for ASA 1 and L 2015
NT 2-3 Mains unit for EM 500©
AM 2 Antenna front mount
090146 G3 500er BROSCHUERE_GB.indd 12
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:27:49 Uhr
Mic heads
MMD 835/845/935/945
MME 865/MMK 965
KEN 2 Color-coded identification
MZW 1 Windshield
CL 2 Line cable
rings for handheld transmitter
You Know You Can
Control
Everything
HSP 2 Headset, omnidirectional
HSP 4 Headset, cardioid
The “Wireless Systems Manager” (WSM) enables realtime
monitoring and remote control of all relevant equipment parameters during
live operation. Using the WSM PC software you can:
• display and monitor the connected equipment
• configure the connected equipment
• conduct a frequency preset scan
• control combined systems and multichannel systems
• access updates at www.sennheiser.com
HHP 2 Pouch for handheld
BPP 1 Bodypack pouch
transmitter
090146 G3 500er BROSCHUERE_GB.indd 13
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:28:20 Uhr
You Know You Can
Have Them All
e9 35 Professional vocal
microphone with cardioid pattern,
dynamic.
e 901 The half-cardioid is the
e9 45 Professional vocal microphone
with super-cardioid pattern, dynamic.
e9 65 Professional vocal microphone
with true condenser capsules with switchable polar pattern (cardioid & supercardioid) in large diaphragm technology.
e 902 is a dynamic cardioid
instrument microphone, which was
designed for lowest bass signals
with very high sound pressure levels.
It is suitable for kick drums, bass
guitar-amps, tuba, and other bass
instruments.
e 904 is a cardioid dynamic instru-
e 905 The cardioid can handle
perfect condenser microphone for
kick drum. It is highly robust and
step-resistant. It benefi ts from an
integrated preamp.
ment microphone especially designed
for drums.
very high sound pressure levels and
has an excellent transient response.
It is suitable for a wide range of
instruments and an perfect choice
for snare drums.
e 906 The supercardioid e 906
e 908 The condenser e 908 is available
e 912 is a highquality, pre-polarized
e 914 is a high grade condenser
instrument microphone was especially designed for guitar amplifiers,
but it is also an excellent choice for
percussion and brass instruments.
for two different applications:
e 908 D perfect for drums and percussion.
e 908 B especially designed for brass
instruments.
condenser microphone with halfcardioid pick-up pattern, acoustically
optimized for picking up speech.
microphone for very demanding
applications. Its outstanding sound
properties qualify the e 914 for
highly sophisticated tasks.
090146 G3 500er BROSCHUERE_GB.indd 14
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:28:28 Uhr
You Know You Can
Check It Out
Animated instruction manual at www.sennheiser.com. Experience G3 on our Web site
www.sennheiser.com. Online applications simulating a realistic stage setup are available here.
G3 at www.sennheiser.com:
Detailed product descriptions
Animated instruction manuals
Virtual area to try out the sets
New guitar tuner check
•
•
•
•
090146 G3 500er BROSCHUERE_GB.indd 15
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:28:46 Uhr
series
100
incl. Wireless Monitor Set
• NEW: Wireless synchronization of transmitters via infrared
interface
• NEW: Enhanced frequency bank management with up to
12 compatible frequencies per bank
• NEW: 42 MHz bandwidth, 1,680 switchable frequencies*
• NEW: Easy-to-read illuminated dot matrix display
• NEW: 4-level charge indicator for transmitter battery
• NEW: More control options (menu)
• NEW: Enhanced AF frequency range
• NEW: Increased range for audio sensitivity
• NEW: Soundcheck mode
• NEW: Integrated equalizer
• NEW: Guitar cable emolution
• NEW: Contacts for recharging the BA 2015 accupack directly
in the transmitter
You Know You Can
Make Up
Your Mind
The evolution wireless G3 is at home on all the stages of
the world—from small clubs to large concert halls, as well as theater and opera stages. The only important thing left to do is decide
on the right set. The various features of the evolution wireless G3
100 / 300 / 500 series have been designed to suit specific requirements.
• NEW: Integrated guitar tuner in receivers
• NEW: Portable receivers with adaptive diversity reception
• NEW: Easy-to-exchange handheld capsules
• 2 AA batteries for more than 8 hours of use
• HDX compander for crystal-clear sound
• True diversity receiver for optimum reception
• High RF output power for large range*
• Suitable for 19" rack mounting (1 U)
• Easy-to-exchange capsules
Wireless Monitor Set
• NEW: SR 300 IEM with Ethernet port
• NEW: Receiver with Adaptive Diversity
• NEW: Combined balanced XLR/6.3 mm audio inputs
• NEW: Balanced 6.3 mm Audio Loop Outs
• NEW: Graphical 5 band EQ in transmitter
• NEW: Audio limiter in Receiver adjustable in 4 steps
Instrument
Presentation
Head
Wireless Monitor
*See accompanying information for regulations regarding correct deployment and frequency use
090146 G3 500er BROSCHUERE_GB.indd 16
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:28:50 Uhr
series
series
300
500
• NEW: Ethernet port for connecting to the Wireless Systems
• NEW: Ethernet port for connecting to the Wireless Systems
• NEW: Wireless synchronization of transmitters via infrared
• NEW: Wireless synchronization of transmitters via infrared
• NEW: Enhanced frequency bank with up to 24 compatible
• NEW: Enhanced frequency bank with up to 32 compatible
• NEW: 42 MHz bandwidth, 1,680 switchable frequencies*
• NEW: Increased range for audio sensitivity
• NEW: Large, illuminated dot matrix display with warning indicator
• NEW: More control options (menu)
• NEW: Enhanced AF frequency range
• NEW: Soundcheck mode
• NEW: Integrated equalizer
• NEW: Switchable RF output power*
• NEW: Optional remote switch
• NEW: Configurable mute modes
• NEW: Easy-to-reach configurable mute button on handheld
• NEW: 42 MHz bandwidth, 1,680 switchable frequencies*
• NEW: Increased range for audio sensitivity
• NEW: Large, illuminated dot matrix display with warning
Manager (WSM) software for control via computer—this
delivers a good overview of monitoring and professional
data management for multichannel systems
interface
frequencies
transmitters
• NEW: Handheld transmitters with charging contacts
• 2 AA batteries for more than 8 hours of use
• 4-level charge indicator for transmitter battery
• Contacts for recharging the BA 2015 accupack directly in the
transmitter
• HDX compander for crystal-clear sound
• True diversity receiver for optimum reception
• Incl. installation kit for 19" rack mounting (1 U)
Head
Manager (WSM) software for control via computer—this
delivers a good overview of monitoring and professional
data management for multichannel systems
interface
frequencies
indicator
• NEW: More control options (menu)
• NEW: Enhanced AF frequency range
• NEW: Guitar cable emulation
• NEW: Switchable RF output power*
• NEW: Handheld transmitters with charging contacts
• NEW: Integrated guitar tuner in receivers
• Soundcheck mode
• Integrated equalizer
• 2 AA batteries for more than 8 hours of use
• 4-level charge indicator for transmitter battery
• Contacts for recharging the BA 2015 accupack directly in
the transmitter
• HDX compander for crystal-clear sound
• True diversity receiver for optimum reception
• Incl. installation kit for 19" rack mounting (1 U)
• Professional e 900 microphone capsules
Presentation
090146 G3 500er BROSCHUERE_GB.indd 17
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
Instrument
Presentation
20.03.2009 13:29:05 Uhr
Technical Data
ew500 ©
Modulation
Frequency ranges
Transmission/receiving frequencies
Switching bandwidth
Noise reduction system
AF frequency response
S/N ratio (at 1 mV and peak deviation)
THD (at nominal deviation and 1 kHz)
wideband FM
516–558, 566–608, 626–668, 734–776, 780–822, 823–865
20 channel banks, 6 fixed banks, 32 factory preset channels each
42 MHz
Sennheiser HDX
25–18,000 Hz
≥ 115 dBA
≤ 0.9%
Receivers
EM500 ©
Receiver principle
Sensitivity (with HDX, peak deviation)
Adjacent channel rejection
Intermodulation attenuation
Blocking
Pilot-tone squelch
Antenna inputs
AF output voltage (at peak deviation, 1 kHz AF)
Power supply
Dimensions
Weight
true diversity
< 2 µV at 52 dBAeff S/N
≥ 75 dB
≥ 70 dB
≥ 75 dB
detachable
5 BNC sockets
¼" (6.3 mm) jack socket, unbalanced: +12 dBu
XLR socket, balanced: +18 dBu
12 V DC
202 mm x 212 mm x 43 mm
approx. 980 g
Transmitters
SK500 ©
SKM500 ©
RF output power at 50 O
typ. 30/10 mW, switchable
25–18,000 Hz (line)
80–18,000 Hz (mic)
3 Veff
40 kO, unbalanced / 1 MO
2 AA batteries, 1.5 V
2.4 V
typ. 8 h
82 x 64 x 24 mm / 3.23" x 2.52" x 0.94"
approx. 160 g
typ. 30/10 mW, switchable
80–18,000 Hz
AF frequency response
Max input voltage transmitter / line
Input impedance transmitter / line
Power supply
Nominal voltage
Operating time
Dimensions
Weight
090146 G3 500er BROSCHUERE_GB.indd 18
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
2 AA batteries, 1.5 V
2.4 V
typ. 8 h
∅ 50 x 265 mm
approx. 450 g / 15.87 oz
20.03.2009 13:29:17 Uhr
Microphones
MKE2- ew
Transducer principle
Sensitivity
Pick-up pattern
Max. SPL
condenser
6.3 mV/Pa ±2.5 dB
omnidirectional
142 dB SPL
Microphonehea ds
SKM 500-935©
SKM 500-945©
SKM 500-965©
Transducer principle
Sensitivity
Pick-up pattern
Max. SPL
dynamic
2.5 mV/Pa
cardioid
154 dB SPL
dynamic
1.8 mV/Pa
super-cardioid
154 dB SPL
condenser
1.8 mV/Pa / 5.7 mV/Pa
cardioid / super-cardioid, switchable
144 dB SPL/154 dB SPL
090146 G3 500er BROSCHUERE_GB.indd 19
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
20.03.2009 13:29:17 Uhr
Sennheiser is a registered trademark of Sennheiser electronic GmbH & Co. KG. www.sennheiser.com
090146 G3 500er BROSCHUERE_GB.indd 20
Prozessfarbe CyanProzessfarbe MagentaProzessfarbe GelbProzessfarbe SchwarzPANTONE 877 CPANTONE 2925 C
Printed in Germany
Am Labor 1, 30900 Wedemark, Germany
Phone: +49 (5130) 60 00, Fax: +49 (5130) 60 03 00
www.sennheiser.com
526490 03/09
Sennheiser electronic GmbH & Co. KG
20.03.2009 13:24:59 Uhr

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
