series
900
e
The cutting edge of evolution
Sennheiser electronic GmbH & Co. KG
Am Labor 1, 30900 Wedemark, Germany
Phone: +49 (51 30) 60 00, Fax: +49 (51 30)60 03 00
www.sennheiser.com
e 900
Introducing the best
professional microphones in
the world
Sennheiser’s new e 900 series. Designed for demanding, uncompromising professional use.
Musicians and singers love them because they know they deserve only the best.
PA rental companies choose them because they love satisfied customers.
Sound engineers rely on them because they know they’ll never be let down.
Sennheiser has a world-beating reputation for superior sound solutions. A unique insight into the demands of
musical performance.
And Sennheiser’s new e 900 series takes sound evolution a step higher – as close to the pinnacle of perfection
as it is possible to get.
e 935
The cardioid e 935 is a state-of-the-art professional vocal
through high on-stage levels.
Features
microphone, designed to cut
Delivery includes
New, stage-compatible sound design
“Gain before feedback” increased by 3–6 dB
(compared to e 835)
Sturdy reinforced metal body
Powerful sound with presence boost for improved
vocal intelligibility
e 935 microphone
Pouch
MZQ 800 microphone clamp Cat. No. 4711
Instruction manual
Guarantee certificate
The supercardioid e 945 is a premium professional lead vocal microphone which will cut
through the mix and project a smooth, natural sound. Its warm tonal response is matched with
rugged construction and unbeatable feedback rejection.
Features
e 945
Delivery includes
New, stage-compatible sound design
“Gain before feedback” increased by 3–6 dB
(compared to e 845)
Rugged reinforced metal body
Powerful sound with presence boost for improved
vocal intelligibility
Specifications e 935
Specifications e 945
Transducer principle . . . . . . . . . . . . . . . . . . dynamic
Frequency response . . . . . . . . . . . . . . . . . . 40–18,000 Hz
Pick-up pattern . . . . . . . . . . . . . . . . . . . . . . cardioid
Sensitivity
(free field, no load) (at 1 kHz) . . . . . . . . . 2.8 mV/Pa
Nominal impedance (at 1 kHz) . . . . . . . . . 350 O
Min. terminating impedance . . . . . . . . . . . 1,000 O
Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR, gold plated
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330 g
Dimensions (Ø x h) . . . . . . . . . . . . . . . . . . . 47 x 181 mm
Transducer principle . . . . . . . . . . . . . . . . . . dynamic
Frequency response . . . . . . . . . . . . . . . . . . 40–18,000 Hz
Pick-up pattern . . . . . . . . . . . . . . . . . . . . . . supercardioid
Sensitivity
(free field, no load) (at 1 kHz) . . . . . . . . . 2.0 mV/Pa
Nominal impedance (at 1 kHz) . . . . . . . . . 350 O
Min. terminating impedance . . . . . . . . . . . 1,000 O
Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR gold-plated
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330 g
Dimensions (Ø x h) . . . . . . . . . . . . . . . . . . . 47 x 186 mm
Specials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hum compensating coil
Shock-mounted capsule
Specials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hum compensating coil
Shock-mounted capsule
e 945 microphone
Pouch
MZQ 800 microphone clamp Cat. No. 4711
Instruction manual
Guarantee certificate
e 901
The half-cardioid boundary layer e 901 is the optimal microphone for kick drum and grand
piano. It is highly robust and completely step-resistant. It benefits from an integrated pre-amp.
Features
Delivery includes
Frequency response optimized for kick drum reception
Very fast attack
Built-in XLR plug, no need for special cable
No microphone stand needed for kick drum
Slip-free, dampening rubber pad underneath
e 901 microphone
Pouch
Specifications e 902
e 902
The cardioid polar pattern e 902 is a dynamic instrument microphone especially designed for
deep bass frequencies such as kick drums, bass guitar amps, and tuba.
Features
Delivery includes
Frequency response optimized for kick drums
Very fast attack
Exceptionally clean and clear pick-up of the lowest
bass signals
Integral stand mount
Ultra-strong full metal body
Shock-mounted capsule
e 902 microphone
Pouch
Specifications e 902
30∞
0∞
0
30∞
5
10
Transducer principle . . . . . . . . . . . . . . . . . . condenser
Frequency response . . . . . . . . . . . . . . . . . .
Pick-up pattern . . . . . . . . . . . . . . . . . . . . . . half-cardioid
Sensitivity
(free field, no load) (at 1 kHz) . . . . . . . . .
Sensitivity
Nominal impedance (at 1 kHz) . . . . . . . . . 200 O
Min. terminating impedance . . . . . . . . . . . 1,000 O
Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR gold-plated
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . approx. 350 g
Dimensions (Ø x h) . . . . . . . . . . . . . . . . . . . 128.5 x 105 x 26.5 mm
Transducer principle . . . . . . . . . . . . . . . . . . dynamic
Frequency response . . . . . . . . . . . . . . . . . . 20–18,000 Hz
Pick-up pattern . . . . . . . . . . . . . . . . . . . . . . cardioid
Sensitivity
(free field, no load) (at 1 kHz) . . . . . . . . . 0.2 mV/Pa
Sensitivity
(free field, no load) (at 60 Hz) . . . . . . . . . 0.6 mV/Pa
Nominal impedance (at 1 kHz) . . . . . . . . . 350 O
Min. terminating impedance . . . . . . . . . . . 1,000 O
Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR gold-plated
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 440 g
Dimensions (Ø x h) . . . . . . . . . . . . . . . . . . . 60 x 128.5 mm
Specials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hum compensating coil
Shock-mounted capsule
Product will be available from 2005. For further information please refer to www.sennheiser.com.
60∞
60∞
15
20
25
90∞
dB
90∞
120∞
120∞
150∞
150∞
125
250
500
1000
Hz
Hz
Hz
Hz
180∞
2000
4000
8000
16000
Hz
Hz
Hz
Hz
e 904
The cardioid polar pattern e 904 is a dynamic instrument
microphone especially designed for drums.
Features
Full, impressive, lively sound
for drums and percussion
Very fast attack
Compact body ideal for
mounting on toms and
snare drum
Excellent sound profiling,
adapts to all percussive styles
Robust reinforced metal
casing
Specifications e 904
30∞
0∞
0
30∞
5
10
60∞
Transducer principle . . . . . . . . . . . . . . . . . . dynamic
Frequency response . . . . . . . . . . . . . . . . . . 40–18,000 Hz
Pick-up pattern . . . . . . . . . . . . . . . . . . . . . . cardioid
Sensitivity
(free field, no load) (at 1 kHz) . . . . . . . . . 2 mV/Pa
Nominal impedance (at 1 kHz) . . . . . . . . . 350 O
Min. terminating impedance . . . . . . . . . . . 1,000 O
Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR gold-plated
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125 g
Dimensions (Ø x h) . . . . . . . . . . . . . . . . . . . 41 x 63 mm
60∞
15
20
25
90∞
dB
90∞
120∞
120∞
150∞
150∞
125
250
500
1000
180∞
Hz
Hz
Hz
Hz
2000
4000
8000
16000
Hz
Hz
Hz
Hz
Delivery includes
e 904
microphone
MZH 604 drum clip
Pouch
e 905
The cardioid e 905 has a high maximum SPL and an
excellent transient response, suitable for a wide range
of instruments and an ideal choice for snare drums.
Features
Impressive and full sound
Very fast attack
Short microphone body to
facilitate optimal positioning
by drums
Integral stand mount
Sturdy reinforced aluminum
metal body
Delivery includes
e 905
microphone
Pouch
Specials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hum compensating coil
Specifications e 905
Transducer principle . . . . . . . . . . . . . . . . . . dynamic
Frequency response . . . . . . . . . . . . . . . . . . 40–18,000 Hz
Pick-up pattern . . . . . . . . . . . . . . . . . . . . . . cardioid
Sensitivity
(free field, no load) (at 1 kHz) . . . . . . . . . 2.6 mV/Pa
Nominal impedance (at 1 kHz) . . . . . . . . . 350 O
Min. terminating impedance . . . . . . . . . . . 1,000 O
Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR gold-plated
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210 g
Dimensions (Ø x h) . . . . . . . . . . . . . . . . . . . 41 x 116 mm
dBv
- 40
- 50
Specials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hum compensating coil
Shock-mounted capsule
- 60
- 70
- 80
- 90
20
50
100
500 1000 2000
200
5000 10000 20000 Hz
0∞, 1 m
e 906
The cardioid e 906 instrument microphone was especially
designed for guitar amps, and is also excellent for
percussion and horns.
Features
Lively, full sound
Very fast attack
Flat shape perfect for
guitar amps
Switchable presence filters
(3 levels)
Extra-resistant reinforced
metal body
Delivery includes
e 906
microphone
MZQ 100 microphone clip
Pouch
Specifications e 906
30∞
0∞
0
30∞
5
10
60∞
Transducer principle . . . . . . . . . . . . . . . . . . dynamic
Frequency response . . . . . . . . . . . . . . . . . . 40–18,000 Hz
Pick-up pattern . . . . . . . . . . . . . . . . . . . . . . supercardioid
Sensitivity
(free field, no load) (at 1 kHz) . . . . . . . . . 2.2 mV/Pa
Nominal impedance (at 1 kHz) . . . . . . . . . 350 O
Min. terminating impedance . . . . . . . . . . . 1,000 O
Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR gold-plated
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 g
Dimensions (Ø x w x h) . . . . . . . . . . . . . . . 55 x 134 x 134 mm
Center frequency of the presence filter . . 4.2 kHz
Specials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Hum compensating coil
Shock-mounted capsule
60∞
15
20
25
90∞
dB
90∞
120∞
120∞
150∞
150∞
125
250
500
1000
Hz
Hz
Hz
Hz
180∞
2000
4000
8000
16000
Hz
Hz
Hz
Hz
e 908 D
The e 908 D condenser instrument microphone was especially designed for drums
and percussion.
Features
The e 914 is a high-grade condenser microphone for very demanding applications. Its outstanding sound properties qualify the e 914 for highly sophisticated applications like acoustic guitars,
cymbals, percussion, overhead, orchestras, and grand pianos.
Delivery includes
Exceptionally lively, clear sound
Easy and flexible set-up, comes with drum-set clamp
Optimal positioning with long-necked, flexible boom
Integrated shock absorber eliminates handling noise
Intelligent MZA 900 P pre-amp (cable, phantom power,
and level check) included
e 908 D microphone
MZH 908 D drum clip
In-line pre-amplifier MZA 900 P
Windshield
Pouch
MZA 900 P pre-amp included
e 908 B
The e 908 B condenser instrument microphone was especially designed for brass
instruments.
Features
Delivery includes
Exceptionally lively, clear sound
Quick and flexible set-up; comes with mounting clamp
Optimal positioning with long-necked, flexible boom
Integrated shock absorber eliminates handling noise
Intelligent MZA 900 P pre-amp (cable, phantom power,
and level check) included
e 908 B microphone
MZH 908 B instrument clip
In-line pre-amplifier MZA 900 P
Windshield
Pouch
MZA 900 P pre-amp included
These products will be available from 2005. For further information please refer to www.sennheiser.com.
Features
Exceptionally lively, clear sound
Three-position sensitivity switch
Three-position bass roll-off/cut-off switch
Very high sound pressure handling capability
Exchangeable capsule
Delivery includes
e 914
microphone
Microphone clip
Windshield
Pouch
e 914
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
