3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Product Overview

Relays Selection Guide

Description

Approvals

XR Series Terminal Block Relays

Page V9-T3-8

D1 Series

Page V9-T3-9

D2 Series

Page V9-T3-11

Features Pluggable relay allows easy field replacement,

LED indicator standard, functional plug-in bridges available

Only 6.2 mm wide for SP and

14 mm wide for DP

DIN rail mounting

Polycarbonate cover

Indicator lamp and pushbutton available

Panel and DIN mounting

Polycarbonate cover

Indicator lamp and pushbutton available

Panel, DIN and flange mounting

Latching

Contact Data

Configuration

Maximum allowable load

Material

Dielectric strength between poles

Coil Data

AC

DC

Power

VA (Vac)

Watts (Vdc)

General Data

Ambient temperature

Storage

Operational

Response time

Life

Mechanical operations

Electrical operations

SPDT

6A or 10A

24 Vac or 120 Vac

12, 24, 110 Vdc

1.5

0.12

–4° to 140°F (–20° to 60°C)

Available upon request

20 million

DPDT

6A

OctoCoupler

2A

SPDT

20A

Silver alloy

1500V

6–240 Vac

6–110 Vdc

0.9 VA

0.7 Watts

–40° to 185°F (–40° to 85°C)

–40° to 131°F (–40° to 55°C)

20 milliseconds

10 million

100,000

DPDT

10A

Silver alloy

1500V

DPDT Latching

10A

6–240 Vac

6–110 Vdc

1.2 VA

0.9 Watts

–40° to 185°F (–40° to 85°C)

–40° to 131°F (–40° to 55°C)

20 milliseconds

10 million

200,000

4PDT

10A

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

V9-T3-2

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

Relays Selection Guide, continued

Description D3 Series

Page V9-T3-13

D4 Series

Page V9-T3-15

D5 Series

Page V9-T3-16

Approvals

Features Polycarbonate cover

Indicator lamp and pushbutton available

Panel and DIN mounting

8- or 11-pin octal plug-in

Latching (D3PR version)

Polycarbonate cover

Indicator lamp available

Panel and DIN mounting

Socket has built-in hold-down spring

Polycarbonate cover

Indicator lamp and pushbutton available

Panel, DIN and PC board mounting

Contact Data

Configuration

Maximum allowable load

Material

Dielectric strength between poles

Coil Data

AC

DC

Power

VA (Vac)

Watts (Vdc)

General Data

Ambient temperature

Storage

Operational

Response time

Life

Mechanical operations

16A

Silver alloy

1500V

6–240 Vac

6–110 Vdc

DPDT

16A

3 VA,1.4 Watts (D3PRand DPF)

2 VA 1.64 Watts (D3PR5 latching)

–40° to 185°F (–40° to 85°C)

–40° to 131°F (–40° to 55°C)

20 milliseconds

3PDT

16A

SPDT

10A at 250 Vac

AgCdO

5000V

6–240 Vac

6–110 Vdc

0.9 VA

0.5 Watts

–40° to 158°F (–40° to 70°C)

–40° to 158°F (–40° to 70°C)

15 milliseconds

DPDT

5A at 240 Vac

DPDT

16A

Silver alloy

1500V

6–240 Vac

6–110 Vdc

3 VA

1.4 Watts

3PDT

16A

–40° to 185°F (–40° to 85°C)

–40° to 131°F (–40° to 55°C)

206 milliseconds

5 million (D3PR and D3PF)

10 million (D3PR5 latching)

100,000

10 million 5 million

Electrical operations 100,000 100,000

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-3

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Relays Selection Guide, continued

Description

Approvals

D7 Series

Page V9-T3-18

D8 Series

Page V9-T3-20

D9 Series

Page V9-T3-22

Features Polycarbonate cover

Indicator lamp and pushbutton available

Panel, DIN and flange mounting

Dust cover

Panel, DIN and flange mounting

Quick-connect and screw terminals

Dust cover

Pushbutton available

Panel mounting

Screw terminals

Contact Data

Configuration

Maximum allowable load

Material

Dielectric strength between poles

Coil Data

AC

DC

Power

VA (Vac)

Watts (Vdc)

General Data

Ambient temperature

Storage

Operational

Response time

Life

Mechanical operations

Electrical operations

SPDT

20A

Silver alloy

1500V

6–240 Vac

6–110 Vdc

1.2 VA

0.9 Watts

–40° to 185°F (–40° to 85°C)

–40° to 131°F (–40° to 55°C)

20 milliseconds (30 milliseconds for latching)

10 million

100,000

DPDP

15A

1500V

1.2 VA

0.9 Watts

100,000

3PDT

15A

2500V

1.5 VA

1.4 Watts

200,000

4PDT

15A

2500V

1.5 VA

1.5 Watts

200,000

SPST-NO

30A at 220 Vac

AgCdO

4000V

6–240 Vac

12–24 Vdc

2.5 VA

1.9 Watts

–4° to 185°F (–20° to 85°C)

–4° to 131°F (–20° to 55°C)

30 milliseconds

5 million

100,000

DPST-NO

25A at 220 Vac

4PST

NO

25A at 220 Vac

AgCdO

4000V

24–240 Vac

12–110 Vdc

2.6 VA

2.0 Watts

–13° to 140°F (–25° to 60°C)

–13° to 140°F (–25° to 60°C)

50 milliseconds

1 million

100,000

NC

8A at 220 Vac

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

V9-T3-4

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

Relays Selection Guide, continued

Description Type AA Series

Page V9-T3-23

XTRE Series

Page V9-T3-24

D93 Series

Page V9-T3-26

Approvals

Features Available blowout magnets for high DC switching

Available auxiliary switches

Combo head screws for simple hook-up

Riveted construction for long service life

Four-pole configurations

IP20 finger and back-of-hand proof

Positively driven contacts between the relay and auxiliary contact modules as well as within the auxiliary contact modules

All solid-state circuitry with no moving parts to wear

Compact, panel mounting for flexible installation

Isolated input and output terminals to protect the system from electrical noise

Internal snubber circuitry to protect the SSR from transients

Contact Data

Configuration

Maximum allowable load

Material

DPDT

40A

Silver cadmium oxide, gold flashed

NO-NC variations in a four-pole relay plus four-pole auxiliary module

16A

SPST-NO (Triac, Zero-cross or MOSFET)

10–75A

Dielectric strength between pole

Coil Data

AC

DC

Power

VA (Vac)

Watts (Vdc)

General Data

Ambient temperature

Storage

Operational

Response time

Life

Mechanical operations

Electrical operations

1500V

6–600 Vac

6–220 Vdc

10 VA

4 Watts

–40° to 185°F (–40° to 85°C)

–40° to 131°F (–40° to 55°C)

35/50 milliseconds

6000

6000 Vac

12–600 Vac

24–240 Vdc

3.3 VA

3 Watts

–40° to 176° (–40° to 80°C)

–13° to 140°F (–25° to 60°C)

12/31 milliseconds

20 million

100,000

4000 Vac

90–280 Vac

3–32 Vdc

Available upon request

Available upon request

–40° to 100°C

–40° to 80°C

Available upon request

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-5

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Relays Selection Guide, continued

Description

Approvals

D96 Series

Page V9-T3-27

D99 Series

Page V9-T3-28

Universal TR Series

Page V9-T3-29

Features All solid-state circuitry has no moving parts to wear

Integral heat sink eliminates the need for added accessories and installation

Flexible mounting allows DIN rail or panel mounting without additional hardware or tools

Isolated input and output terminals protect the system from electrical noise

Internal snubber circuitry protects the SSR from transients

All solid-state circuitry has no moving parts to wear

Integral heat sink eliminates the need for added accessories and installation

Flexible mounting allows DIN rail or panel mounting without additional hardware or tools

Isolated input and output terminals protect the system from electrical noise

Internal snubber circuitry protects the SSR from transients

Multiple user-selectable timing functions and timing ranges in a single unit reduce product variations and stock keeping units (SKUs)

Universal input voltages from 12 or 24–240 Vac or

Vdc eliminate the need to order and stock separate coil voltages

Compact, DIN rail mountable case reduces panel size

Advanced LED indication makes troubleshooting easy

Staggered terminal locations allow access to lower-level terminals after wiring

SPDT or DPDT contacts with 8A ratings

Contact Data

Configuration

Maximum allowable load

Material

SPST-NO (DC switch, zero-cross or random)

8–15A

SPST-NO (zero cross)

10–40A

SPDT and DPDT

8A

Dielectric strength between pole

Coil Data

AC

DC

Power

VA (Vac)

Watts (Vdc)

General Data

Ambient temperature

Storage

Operational

Response time

Life

Mechanical operations

Electrical operations

2500 (4000 on random) Vac

90–280 Vac

3–32 Vdc (3.5–32 Vdc on DC switch)

Available upon request

Available upon request

–40° to 100°C

–30° to 80°C

Available upon request

4000 Vac

90–280 Vac

3–32 Vdc

Available upon request

Available upon request

–40° to 100°C

–30° to 80°C

Available upon request

24–240 Vac SPDT, 12–240 Vac DPDT

24–240 Vdc SPDT, 12–240 Vdc DPDT

4 VA SPDT, 6 VA DPDT

1.5 Watts SPDT, 2W DPDT

–25° to 70°C

–25° to 55°C

100 ms

20,000,000

200,000

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

V9-T3-6

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

Relays Selection Guide, continued

Description TMR5 Series

Page V9-T3-30

TMR6 Series

Page V9-T3-31

TMRP Series

Page V9-T3-32

Approvals

Features Various configurations available with fixed or adjustable time delays

Single operating voltage for simple set-up

Plugs in standard 8- or 11-pin octal sockets

Provides OFF delay function without requiring input voltage during OFF time delay

Duplicates operation of pneumatic OFF delay timers

Each unit has eight timing ranges built in, covering

0.05 seconds to 30 minutes

Selecting a range is easy using a rotary switch

(no math is required or DIP switches to set)

Uses industry-standard 8-pin octal socket

10A DPDT output contacts

Multiple user-selectable timing functions and timing ranges in a single unit reduce product variations and stock keeping units (SKUs)

Universal input voltages from 12–240 Vac/Vdc eliminate the need to order and stock separate coil voltages

Timing ranges up to 9990 hours

Dual LED indication makes troubleshooting easy

Flexible design for backpanel, through-panel

(45 mm x 45 mm cutout), or DIN rail mounting

SPDT or DPDT contacts with 12A ratings

Plastic dust cover keeps out contaminants and eliminates accidental set point changes

Use with standard Eaton D3 sockets

Contact Data

Configuration

Maximum allowable load

Material

Dielectric strength between pole

Coil Data

AC

DC

Power

VA (Vac)

Watts (Vdc)

General Data

Ambient temperature

Storage

Operational

Response time

Life

Mechanical operations

Electrical operations

DPDT

10A

2000V

12–240 Vac

12–240 Vdc

2 VA

–4° to 149°F (–20° to 65°C)

100 milliseconds

10 million

100,000

DPDT

10A

2000V

24, 120 or 240 Vac

24, 120 or 240 Vdc

2 VA

–18° to 150°F (–28° to 65°C)

2,000,000

100,000

SPDT and DPDT

12A

12–240 Vac

12–240 Vdc

2.5 VA

2 Watts

–40° to 85°C

–10° to 55°C

25 milliseconds

10 million

100000

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-7

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Terminal Block Relays

Catalog Number Selection

Terminal Block Relays

Terminal Block Relays

Type

XR = XR Terminal block relay

Product Selection

Standard Terminal Block Relays

Contacts Rated Current

No

No

No

DPDT Screw Connection

No

No

No

No

1PDT Screw Connection

No

No

Yes

No

No

Yes

6A

6A

1PDT Spring-Cage Connection

No 6A

6A

6A

6A

6A

6A

6A

6A

6A

6A

6A

6A

Connection Type

U = Screw

P = Spring-cage

Features

Pluggable relay allows for field replacement

Functional plug-in bridges

LED status indication

Only 6.2 mm wide for single pole versions, 14 mm wide for double pole

XR U 1 D120 G

Number of Poles

1 = 1 PDT

2 = 2 PDT

Supply Voltage

12 Vdc

120 Vac/110 Vdc

120 Vac/110 Vdc

24 Vdc

24 Vac/Vdc

24 Vac/Vdc

12 Vdc

120 Vac/110 Vdc

24 Vdc

24 Vac/Vdc

12 Vdc

120 Vac/110 Vdc

24 Vdc

24 Vac/Vdc

Standard Pack

10

10

10

10

10

10

10

10

10

10

10

10

10

10

Coil Voltage

D12

= 12 Vdc

D1204 = 120 Vac/110 Vdc

D24

= 27 Vdc

D246 = 24 Vac/Vdc

Size

G

= Yes

Blank = No

Catalog Number

XRU1D12

XRU1D120U

XRU1D120UG

XRU1D24

XRU1D24U

XRU1D24UG

XRP1D12

XRP1D120U

XRP1D24

XRP1D24U

XRU2D12

XRU2D120U

XRU2D24

XRU2D24U

V9-T3-8

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

General Purpose Plug-In Relays—D1 Series

Catalog Number Selection

General Purpose Plug-In Relays

D1 Series

1

Family Type

D1PR = Standard relay

D1PF = Full-featured relay

Features

Compact relay capable of breaking relatively large load currents

The contact operation can be easily checked by push-to-test button

Panel and DIN rail mounting

Flag indicator shows relay status in manual or powered condition

LED status lamp shows coil “ON” or “OFF” status—ideal for use in low light applications

Push-to-test button allows for manual operation of relay without the need for coil power

Lock-down door holds pushbutton and contacts in the operate position when activated

Finger-grip cover allows operator to remove relays from sockets easily

ID tag/write label to identify relays in multiple-relay circuits

Bi-polar LED allows for reverse polarity applications

D1PF 1 A A

Contact Configuration

1 = SPDT

Standard Features

A

= LED, test button, flag indicator, flange mounting, lock-down door, finger-grip cover, I.D. tag

Blank = Mechanical flag indicator

Note

1 For deciphering catalog numbers. Do not use for ordering as not all combinations are readily available.

Coil Voltage

A = 120 Vac

A1 = 110 Vdc

B = 240 Vac

P

= 6 Vac

P1 = 6 Vdc

R

= 12 Vac

R1 = 12 Vdc

T

= 24 Vac

T1 = 24 Vdc

W1 = 48 Vdc

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-9

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Product Selection

General Purpose Plug-In Relays—D1PR/D1PF

Coil

Voltage

Contact

Configuration

Coil Resistance

(Ohms)

Full Featured

6 Vac

6 Vdc

12 Vac

12 Vdc

24 Vac 50/60 Hz

24 Vdc

48 Vac

48 Vdc

110 Vdc

120 Vac 50/60 Hz

240 Vac 50/60 Hz

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

12.2

47

46

188

180

750

720

2,600

13,800

4,430

15,720

Catalog

Number

D1PF1AP

D1PF1AP1

D1PF1AR

D1PF1AR1

D1PF1AT

D1PF1AT1

D1PF1AW

D1PF1AW1

D1PF1AA1

D1PF1AA

D1PF1AB

Accessories

D1PR/D1PF Socket and Accessories

Type

Standard

Pack

Socket

Flange mount adapter

Metal spring clip

10

25

25

Catalog

Number

D1PAA

PFC-D11

PMC-1781

V9-T3-10

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Coil

Voltage

Plain Cover

6 Vac

6 Vac

12 Vac

12 Vac

24 Vac

48 Vac

48 Vac

110 Vdc

120 Vac 50/60 Hz

240 Vac

Contact

Configuration

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

Coil Resistance

(Ohms)

12.2

47

46

188

750

720

2,600

13,800

4,430

15,270

Catalog

Number

D1PR1P

D1PR1P1

D1PR1R

D1PR1R1

D1PR1T1

D1PR1W

D1PR1W1

D1PR1A1

D1PR1A

D1PR1B

Logic Devices

Relays

3.1

General Purpose Plug-In Relays—D2 Series

Catalog Number Selection

General Purpose Plug-In Relays

D2 Series

1

D2PF

D2PR

Family Type

Product Selection

D2PF/D2PR Relay/Socket Quick Reference

Relay Type Socket Clip

D2PR2

D2PF2

D2PAL

D2PR4

D2PF4

D2PR5

D2PA6

D2PAP

D2PA7

D2PA6

D2PA4

PWC-D24

PQC-1782

PQC-1342

PWC-D24

PQC-1782

PWC-D24

PQC-1782

PQC-1342

PYC-A1

Note

1

For deciphering catalog numbers.

Do not use for ordering as not all combinations are readily available.

Features

Ultra-high sensitivity relay with quick response

Designed small, two-pole type break 5A load and four-pole type, 3A load

High reliability, long life

Panel, DIN rail and flange mounting

Small size

D2PF 2 A A

Contact Configuration

2 = DPDT

4 = 4PDT

5 = DPDT latching

Standard Features

Blank = Plain cover (only with D2PR)

A

= LED, test button, flag indicator, lock-down door, finger-grip cover,

ID tag (only with D2PF)

Coil Voltage

A = 120 Vac

A1 = 110 Vdc

B = 240 Vac

P

= 6 Vac

P1 = 6 Vdc

R

= 12 Vac

R1 = 12 Vdc

T

= 24 Vac

T1 = 24 Vdc

W = 48 Vac

W1 = 48 Vdc

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-11

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

General Purpose Plug-In Relays—D2PR/D2PF

Coil

Voltage

Contact

Configuration

Coil Resistance

(Ohms)

220/240 Vac

12 Vac

12 Vdc

24 Vac

24 Vdc

48 Vdc

110/125 Vdc

120 Vac

220/240 Vac

Full Featured Style

6 Vac DPDT

6 Vdc

12 Vac

12 Vdc

24 Vac

DPDT

DPDT

DPDT

DPDT

24 Vdc

48 Vdc

110/125 Vdc

120 Vac

DPDT

DPDT

DPDT

DPDT

DPDT

4PDT

4PDT

4PDT

4PDT

4PDT

4PDT

4PDT

4PDT

9.6

40

46

160

180

650

2,600

11,000

4,430

15,720

46

160

180

650

2,600

11,000

4,430

15,720

Catalog

Number

D2PF2AP

D2PF2AP1

D2PF2AR

D2PF2AR1

D2PF2AT

D2PF2AT1

D2PF2AW1

D2PF2AA1

D2PF2AA

D2PF2AB

D2PF4AR

D2PF4AR1

D2PF4AT

D2PF4AT1

D2PF4AW1

D2PF4AA1

D2PF4AA

D2PF4AB

Accessories

D2PF/D2PR Sockets and Accessories

Type

Standard

Pack

Socket

Socket

Socket

Socket

Socket

Flange mount adapter

Plastic ejector clip

Metal spring clip

Metal spring clip

Hold-down spring

10

5

25

10

1

10

1

25

25

100

Note

1

Protection category (finger safe), EN 60529 IP20.

Catalog

Number

D2PAL

1

D2PA6

D2PAP

1

D2PA7

1

D2PA4

PFC-D2D72

PWC-D24

PQC-1782

PQC-1342

PYC-A1

V9-T3-12

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Coil

Voltage

Plain Cover Style

6 Vdc

12 Vdc

24 Vac

24 Vdc

48 Vdc

110/125 Vdc

120 Vac

220/240 Vac

6 Vac

6 Vdc

12 Vac

12 Vdc

24 Vac

24 Vdc

110/125 Vdc

120 Vac

220/240 Vac

Contact

Configuration

DPDT

DPDT

DPDT

4PDT

4PDT

4PDT

4PDT

4PDT

DPDT

DPDT

DPDT

DPDT

DPDT

4PDT

4PDT

4PDT

4PDT

Coil Resistance

(Ohms)

40

160

180

650

2,600

40

46

160

180

11,000

4,430

15,720

9.6

650

11,000

4,430

15,720

Catalog

Number

D2PR2P1

D2PR2R1

D2PR2T

D2PR2T1

D2PR2W1

D2PR2A1

D2PR2A

D2PR2B

D2PR4P

D2PR4P1

D2PR4R

D2PR4R1

D2PR4T

D2PR4T1

D2PR4A1

D2PR4A

D2PR4B

Logic Devices

Relays

3.1

General Purpose Plug-In Relays—D3 Series

Catalog Number Selection

General Purpose Plug-In Relays

D3 Series

1

Family Type

D3PR = Standard relay

D3PF = Full-featured relay

Product Selection

D3 Relay/Socket Quick Reference

Relay Type

D3PR2

D3PF2

D3PR3

D3PF3

D3PR5

Socket

D3PA6

D3PAL8

D3PA2

D3PA7

D3PAL11

D3PA3

D3PA7

D3PAL11

D3PA3

Clip

PQC-1332

PQC-1351

PQC-1351

PQC-1332

PQC-1351

PQC-1351

PQC-1351

PQC-1351

PQC-1351

Notes

1

2

For deciphering catalog numbers.

Do not use for ordering as not all combinations are readily available.

D3PR only.

Features

Compact relay capable of breaking relatively large load currents

The contact operation can be easily checked by push-to-test button

Panel and DIN rail mounting

8- or 11-pin octal plug-in

D3PR 2 3 A

Contact Configuration

2 = DPDT (8-pin)

3 = 3PDT (11-pin)

5 = DPDT latching (11-pin) 2

Options

Blank = Plain cover relay (only with D3PR)

A

= LED, test button, flag indicator,

1

lock-down door, finger-grip cover,

ID tag (D3FF only)

= Indicating Light (D3PR only)

Coil Voltage

A = 120 Vac

A1 = 110 Vdc

B = 240 Vac

P

= 6 Vac

P1 = 6 Vdc

R

= 12 Vac

R1 = 12 Vdc

T

= 24 Vac

T1 = 24 Vdc

W = 48 Vac

W1 = 48 Vdc

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-13

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

General Purpose Plug-In Relays—D3PR/D2PF

Coil

Voltage

Contact

Configuration

Coil Resistance

(Ohms)

Full Featured Style

120 Vac DPDT

240 Vac

12 Vdc

24 Vdc

48 Vdc

DPDT

DPDT

DPDT

DPDT

120 Vac

220/240 Vac

6 Vdc

24 Vac

3PDT

3PDT

3PDT

3PDT

3PDT

3PDT

24 Vdc

48 Vdc

Plain Cover Style

120 Vac

110/125 Vdc

220/240 Vac

6 Vac

DPDT

DPDT

DPDT

DPDT

1,700

7,200

32

72

470

1,800

1,700

7,200

120

470

1,800

1,700

10,000

7,200

4.2

Catalog

Number

D3PF2AA

D3PF2AB

D3PF2AR1

D3PF2AT1

D3PF2AW1

D3PF3AA

D3PF3AB

D3PF3AP1

D3PF3AT

D3PF3AT1

D3PF3AW1

D3PR2A

D3PR2A1

D3PR2B

D3PR2P

Accessories

D2PF/D2PR Sockets and Accessories

Type

Standard

Pack

Socket

Socket

Socket

Socket

Socket

Socket

Metal spring clip

Metal spring clip

1

10

10

1

10

10

25

10

Note

1

Protection category (finger safe) EN 60529 IP20.

Catalog

Number

D3PA6

1

D3PAL8

1

D3PA2

D3PA7

1

D3PAL11

1

D3PA3

PQC-1332

PQC-1351

V9-T3-14

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Coil

Voltage

Contact

Configuration

Plain Cover Style, continued

6 Vdc DPDT

12 Vac

12 Vdc

24 Vac

24 Vdc

DPDT

DPDT

DPDT

DPDT

48 Vac

48 Vdc

120 Vac

110/125 Vdc

DPDT

DPDT

3PDT

3PDT

220/240 Vac

12 Vac

12 Vdc

24 Vac

24 Vdc

48 Vdc

3PDT

3PDT

3PDT

3PDT

3PDT

3PDT

Coil Resistance

(Ohms)

32

18

120

72

470

290

1,800

1,700

10,000

7,200

18

120

72

470

1,800

Catalog

Number

D3PR2P1

D3PR2R

D3PR2R1

D3PR2T

D3PR2T1

D3PR2W

D3PR2W1

D3PR3A

D3PR3A1

D3PR3B

D3PR3R

D3PR3R1

D3PR3T

D3PR3T1

D3PR3W1

Logic Devices

Relays

3.1

General Purpose Plug-In Relays—D4 Series

Features

Slim-styled power relay

Socket has built-in hold-down clip

Panel or DIN rail mounting

Catalog Number Selection

General Purpose Plug-In Relays—D4 Series

D4 Series

1

D4PR 1 1 A

Type

D4PR = D4PR standard relay

Contact Configuration

1 = SPDT

2 = DPDT

1 = Indicating light

Options

Coil Voltage

A = 120 Vac

A1 = 110 Vdc

B = 240 Vac

P

= 6 Vac

P1 = 6 Vdc

R

= 12 Vac

R1 = 12 Vdc

T

= 24 Vac

T1 = 24 Vdc

W1 = 48 Vdc

Product Selection

D4 Relay/Socket Quick Reference

Relay Type Socket

D4PR1

D4PR2

D4PA1

D4PA2

Hold Down Clip

2

2

D4 Series

Coil Voltage

3

Catalog

Number

Standard SPDT

24 Vac

D4PR1T

120 Vac

24 Vdc

D4PR1A

D4PR1T1

SPDT with Indicating Light

24 Vac

120 Vac

24 Vdc

D4PR11T

D4PR11A

D4PR11T1

Coil Voltage

3

Catalog

Number

Standard DPDT

24 Vac

120 Vac

12 Vdc

24 Vdc

D4PR2T

D4PR2A

D4PR2R1

D4PR2T1

DPDT with Indicating Light

120 Vac

D4PR21A

24 Vdc

D4PR21T1

Notes

1

2

3

For deciphering catalog numbers. Do not use for ordering as not all combinations are readily available.

Socket has built-in hold down spring.

Additional coil voltages available—consult sales office or customer support center.

Coil Voltage

3

DIN Rail Sockets

Single-Pole

Two-Pole

Accessories

DIN rail end stop

Catalog

Number

D4PA1

D4PA2

PFP-M

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-15

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

General Purpose Plug-In Relays—D5 Series

Catalog Number Selection

General Purpose Plug-In Relays—D5 Series

D5 Series

1

Family Type

D5PR = Standard relay

D5PF = Full featured relay

Contact Configuration

2 = DPDT

3 = 3PDT

Product Selection

D5 Relay/Socket Quick Reference

Relay Type

D5PR2

D5PF2

D5PR3

D5PF3

Socket

D5PAL

D5PA2

D5PA3L

D5PA3S

Clip

PQC-1351

PQC-1351

PQC-1351

PQC-1351

Note

1 For deciphering catalog numbers.

Do not use for ordering as not all combinations are readily available.

Features

Industrial rated 300V, 15A relay in two-pole and three-pole configurations

Compact design can be panel or DIN rail mounted

D5PR 3 1 A

Options

Blank = Plain cover (D5PR only)

A

= LED, test button, flag indicator,

1

lock-down door, finger-grip cover,

ID tag (D5PF only)

= Indicating light (D5PR only)

Coil Voltage

A = 120 Vac

A1 = 110 Vdc

B = 240 Vac

G1 = 74 Vdc

P

= 6 Vac

P1 = 6 Vdc

R

= 12 Vac

R1 = 12 Vdc

T

= 24 Vac

T1 = 24 Vdc

W = 48 Vdc

W1 = 48 Vdc

V9-T3-16

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

General Purpose Plug-In Relays—D5

Coil

Voltage

Contact

Configuration

Coil Resistance

(Ohms)

Full Featured

120 Vac

110/125 Vdc

220/240 Vac

12 Vdc

24 Vac

24 Vdc

48 Vdc

120 Vac

110/125 Vdc

220/240 Vac

12 Vdc

24 Vac

Plain Cover

120 Vac

110/125 Vdc

220/240 Vac

74 Vdc

6 Vac

DPDT

DPDT

DPDT

DPDT

DPDT

DPDT

DPDT

3PDT

3PDT

3PDT

3PDT

3PDT

DPDT

DPDT

DPDT

DPDT

DPDT

1,700

10,000

7,200

120

72

470

1,800

1,700

10,000

7,200

120

72

1,700

10,000

7,200

4,800

4.2

Catalog

Number

D5PF2AA

D5PF2AA1

D5PF2AB

D5PF2AR1

D5PF2AT

D5PF2AT1

D5PF2AW1

D5PF3AA

D5PF3AA1

D5PF3AB

D5PF3AR1

D5PF3AT

D5PR2A

D5PR2A1

D5PR2B

D5PR2G1

D5PR2P

Accessories

D5 Sockets and Accessories

Description

Standard

Pack

Socket

Socket

Socket

Socket

Metal spring clip

10

10

10

10

10

Note

1

Protection category (finger safe), EN 60529 IP20.

Catalog

Number

D5PAL

1

D5PA2

D5PA3L

D5PA3S

PQC-1351

Coil

Voltage

Contact

Configuration

Plain Cover, continued

6 Vdc DPDT

12 Vac

12 Vdc

DPDT

DPDT

24 Vac

24 Vdc

48 Vac

48 Vdc

DPDT

DPDT

DPDT

DPDT

120 Vac

110/125 Vdc

220/240 Vac

74 Vdc

6 Vac

6 Vdc

12 Vac

12 Vdc

24 Vac

24 Vdc

48 Vdc

3PDT

3PDT

3PDT

3PDT

3PDT

3PDT

3PDT

3PDT

3PDT

3PDT

3PDT

Coil Resistance

(Ohms)

4.2

32

18

120

1,700

10,000

7200

4,800

32

18

120

72

470

290

1,800

72

470

1,800

Catalog

Number

D5PR2P1

D5PR2R

D5PR2R1

D5PR2T

D5PR2T1

D5PR2W

D5PR2W1

D5PR3A

D5PR3A1

D5PR3B

D5PR3G1

D5PR3P

D5PR3P1

D5PR3R

D5PR3R1

D5PR3T

D5PR3T1

D5PR3W

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-17

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

General Purpose Plug-In Relays—D7 Series

Catalog Number Selection

General Purpose Plug-In Relays—D7 Series

D7 Series

1

Type

D7PR = Standard relay

D7PF = Full featured relay

Contact Configuration

1 = SPDT

2 = DPDT

3 = 3PDT

4 = 4PDT

Product Selection

D7 Relay/Socket Quick Reference

Relay Type

D7PR1

D7PR2

D7PF1

D7PF2

D7PR3

D7PF3

D7PR4

Socket/Adapter

D7PAA

D7PA9

PFC-D2D72

D7PAB

PFC-D73

D7PAD

Clip

PQC-1342

PQC-1349

PQC-1342

PQC-1783

PMC-1783

PQC-1784

PMC-1784

— D7PF4 PFC-D74

Note

1

For deciphering catalog numbers.

Do not use for ordering as not all combinations are readily available.

Features

Arc barrier equipped relay with high dielectric strength

Panel, DIN rail and flange mounting

D7PR 1 1 A

Options

A

= LED, test button, flag indicator, lock-down door, finger-grip cover,

ID tag

Blank = Plain cover

Coil Voltage

A = 120 Vac

A1 = 110 Vdc

B = 240 Vac

P

= 6 Vac

P1 = 6 Vdc

R

= 12 Vac

R1 = 12 Vdc

T

= 24 Vac

T1 = 24 Vdc

W = 48 Vdc

W1 = 48 Vdc

V9-T3-18

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

General Purpose Plug-In Relays—D7

Coil

Voltage

Contact

Configuration

Coil Resistance

(Ohms)

6 Vdc

12 Vac

12 Vdc

24 Vac

24 Vdc

48 Vdc

48 Vac

24 Vac

24 Vdc

48 Vac

48 Vdc

120 Vac

6 Vac

6 Vdc

12 Vac

24 Vac

24 Vdc

48 Vac

48 Vdc

120 Vac

110/125 Vdc

240 Vac

6 Vac

Full Featured

120 Vac

6 Vac

6 Vdc

12 Vac

24 Vdc

48 Vac

48 Vdc

120 Vac

110/125 Vdc

220/240 Vac

6 Vac

6 Vdc

12 Vac

12 Vdc

3PDT

3PDT

3PDT

3PDT

4PDT

4PDT

4PDT

4PDT

DPDT

DPDT

DPDT

DPDT

3PDT

3PDT

3PDT

3PDT

4PDT

4PDT

4PDT

4PDT

4PDT

4PDT

4PDT

SPDT

DPDT

DPDT

DPDT

DPDT

DPDT

DPDT

DPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

103

400

412

1,600

2,220

7,340

9,120

5.4

180

650

788

2,600

2,770

6

25

25.3

24

21.2

96

84.5

388

1,550

410

9.6

40

46

160

2,600

4,430

11,000

15,720

4,430

9.6

40

46

650

788

Catalog

Number

D7PF2AT

D7PF2AT1

D7PF2AW

D7PF2AW1

D7PF3AA

D7PF3AP

D7PF3AP1

D7PF3AR

D7PF3AT

D7PF3AT1

D7PF3AW

D7PF3AW1

D7PF4AA

D7PF4AA1

D7PF4AB

D7PF4AP

D7PF1AA

D7PF1AP

D7PF1AP1

D7PF1AR

D7PF1AT1

D7PF1AW

D7PF1AW1

D7PF2AA

D7PF2AA1

D7PF2AB

D7PF2AP

D7PF2AP1

D7PF2AR

D7PF2AR1

D7PF4AP1

D7PF4AR

D7PF4AR1

D7PF4AT

D7PF4AT1

D7PF4AW

D7PF4AW1

Accessories

D7 Sockets and Accessories

Type

Standard

Pack

Socket

Socket

Socket

Socket

Flange mount adapter

Flange mount adapter

Flange mount adapter

25

25

25

1

Note

1

Protection category (finger safe) EN 60529 IP20.

Catalog

Number

D7PAA

1

D7PA9

D7PAD 1

D7PAB

1

PFC-D2D72

PFC-D73

PFC-D74

Coil

Voltage

12 Vdc

24 Vac

24 Vdc

120 Vac

240 Vac

6 Vac

12 Vac

12 Vdc

24 Vac

24 Vdc

48 Vdc

120 Vac

110/125 Vdc

240 Vac

6 Vac

24 Vac

24 Vdc

48 Vdc

Plain Cover

120 Vac

110/125 Vdc

220/240 Vac

6 Vac

12 dc

24 Vac

24 Vdc

48 Vdc

120 Vac

110/125 Vdc

220/240 Vac

6 Vac

6 Vdc

12 Vac

Type

Metal spring clip

Plastic ID clip

Metal spring clip

Plastic ID clip

Hold-down spring

Metal spring clip

Plastic ID clip

Standard

Pack

10

25

10

10

25

10

25

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Coil Resistance

(Ohms)

103

400

1,600

2,220

7,340

9,120

5.4

84.5

388

1,550

160

180

650

2,770

12,100

6

25.3

100

650

2600

4,430

11,000

15,720

9.6

40

46

4,430

11,000

15,720

9.6

160

180

Contact

Configuration

3PDT

3PDT

3PDT

4PDT

4PDT

4PDT

4PDT

4PDT

4PDT

4PDT

DPDT

DPDT

DPDT

3PDT

3PDT

3PDT

3PDT

3PDT

SPDT

SPDT

DPDT

DPDT

DPDT

DPDT

DPDT

DPDT

SPDT

SPDT

SPDT

SPDT

SPDT

SPDT

Catalog

Number

D7PR2R1

D7PR2T

D7PR2T1

D7PR3A

D7PR3B

D7PR3P

D7PR3R

D7PR3R1

D7PR3T

D7PR3T1

D7PR3W1

D7PR4A

D7PR4A1

D7PR4B

D7PR4P

D7PR4T

D7PR4T1

D7PR4W1

D7PR1A

D7PR1A1

D7PR1B

D7PR1P

D7PR1R1

D7PR1T

D7PR1T1

D7PR1W1

D7PR2A

D7PR2A1

D7PR2B

D7PR2P

D7PR2P1

D7PR2R

Catalog

Number

PQC-1342

PQC-1349

PQC-1784

PMC-1784

PYC-B2

PQC-1783

PMC-1783

V9-T3-19

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

General Purpose Plug-In Relays—D8 Series

Catalog Number Selection

General Purpose Plug-In Relays—D8 Series

D8 Series

1

Type

D8PR = Standard relay

D8PR 6 TE A

Contact Configuration

6 = SPST-NO

7 = DPST-NO

Product Selection

D8 Relay/Socket Quick Reference

Relay Type

D8PR6TE

D8PR7TE

Mounting

Bracket

D8PA5

D8PA5

Note

1 For deciphering catalog numbers.

Do not use for ordering as not all combinations are readily available.

Adapter Track/

Panel Mount

D8PA1

D8PA1

Features

Allows switching of 25A and 30A loads

A high-capacity, high-withstand voltage relay compatible with momentary voltage drops

No contact chattering for momentary voltage drops up to

50% of rated voltage

TE = E-bracket

TF = Range mount

Options

Front Connecting

Sockets Track/

Panel Mount

D8PA2

D8PA2

Coil Voltage

A = 120 Vac

B = 240 Vac

R1 = 12 Vdc

T = 24 Vac

T1 = 24 Vdc

V9-T3-20

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

D8 Series

Coil Voltage

SPST E-Bracket

24 Vac

24 Vdc

SPST Flange Mount

120 Vac

24 Vdc

DPST E-Bracket

120 Vac

DPST Flange Mount

120 Vac

24 Vdc

Accessories

D8 Series Sockets and Accessories

Description

Standard

Pack

Sockets

DIN rail adapter

Screw terminal adapter

Bracket adapter

Accessory

DIN rail end stop

10

10

10

100

Catalog

Number

D8PR6TET

D8PR6TET1

D8PR6TFA

D8PR6TFT1

D8PR7TEA

D8PR7TFA

D8PR7TFT1

Catalog

Number

D8PA1

D8PA2

D8PA5

PFP-M

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-21

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

General Purpose Plug-In Relays—D9 Series

Catalog Number Selection

General Purpose Plug-In Relays—D9 Series

D9 Series

1

Type

D9PR = Standard relay

Contact Configuration

8B = 4PST-NO

9B = 3PST-NO/SPST-NC

10B = DPST-NO/DPST-NC

Product Selection

D9 Series

Coil Voltage

4PST-NO Power Relay

24 Vac

120 Vac

240 Vac

24 Vdc

3PST-NO/SPST-NC Power Relay

120 Vac

DPST-NO/DPST-NC Power Relay

24 Vac

120 Vac

24 Vdc

Catalog Number

D9PR8BT

D9PR8BA

D9PR8BB

D9PR8BT1

D9PR9BA

D9PR10BT

D9PR10BA

D9PR10BT1

Note

1

For deciphering catalog numbers.

Do not use for ordering as not all combinations are readily available.

Features

Ideal for three-phase motor control applications

No contact chattering for momentary voltage drops up to

50% of rated voltage

Push-to-test button is a standard feature to check contact operation

D9PR 8B A

A = 120 Vac

A1 = 110 Vdc

B = 240 Vac

Coil Voltage

R1 = 12 Vdc

T = 24 Vac

T1 = 24 Vdc

V9-T3-22

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

General Purpose Type AA Relays

Features

Type AA panel mounted relays are rated (each pole) 40A up to

300 Vac, 50/60 Hz; 5A at 480/600 Vac, 50/60 Hz and 40A at

28 Vdc

9575H Series 3000 relays are ideal for applications when controlling smaller loads such as single-phase motors

Catalog Number Selection

General Purpose Type AA Relays

Type AA

9575H3 A 000

Type

9575H3 = Type AA relay

Product Selection

Type AA Relays

Relay Style

Relay (DPDT)

Relay with auxiliary switch

Relay with blowout magnets

Relay with auxiliary switch and blowout magnets

A = 120 Vac

B = 240 Vac

C = 480/440 Vac

D = 600/550 Vac

Coil Voltage

E = 208 Vac

H = 277 Vac

J = 6 Vac

K = 12 Vac

L = 24 Vac

M = 48 Vac

P = 110 Vdc

Q = 220 Vdc

R = 6 Vdc

S = 12 Vdc

T = 24 Vdc

W = 48 Vdc

Catalog Number

1

9575H3_000

9575H3_010

9575H3_100

9575H3_110

Option

000 = None

010 = Auxiliary switch

100 = Blowout magnets

110 = Auxiliary switch and blowout magnets

Coil Voltage Selection Table

Coil Voltage Hz

208

277

6

12

24

48

Volts AC

120

240

480/440

600/550

50/60

50/60

60/50

60/50

50/60

50/60

50/60

50/60

50/60

50/60

Suffix Code

E

H

J

K

A

B

C

D

L

M

Note

1 Underscore (_) indicates missing coil voltage suffix code. See table above.

Coil Voltage

Volts DC

110

220

6

12

24

48

Hz

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Suffix Code

P

Q

R

S

T

W

V9-T3-23

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

XTRE Control Relays

Catalog Number Selection

XTRE Control Relays

XTRE Relays

Product Line Prefix

XT = XT IEC Power Control

Product Family Code

RE = IEC Control Relay

Product Selection

XTRE Control Relays

Conventional

Thermal Current

I th

(A), Open at 60°C

16

Contact

Configuration

4NO

16

16

3NO-1NC

2NO-2NC

Features

16A conventional thermal current (open at 60°C I th

)

Four-pole configurations

4NO

3NO-1NC

2NO-2NC

Expandable to eight-pole with add-on front-mount auxiliary contacts

Built-in surge suppression on DC coils

XT RE 10 B 22 A

Conventional Thermal

Current Rating

10 = 10A

Frame

B = 45 mm—standard

Rated Operational Current AC-15 I e

(A)

220–240V

6

380–414V

4

500V

1.5

6

6

4

4

1.5

1.5

Coil Voltage Suffix

Coil Voltage

Suffix

Code

110V 50 Hz, 120V 60 Hz

A

220V 50 Hz, 240V 60 Hz

B

24V 50/60 Hz

T

Coil Voltage

Suffix

Code

24 Vdc

TD

415V 50 Hz, 480V 60 Hz

C

Notes

1

2

Underscore (_) indicates magnet coil suffix required. See table above.

DC operated control relays XTRE(C)10B22_ can only be combined with two-pole auxiliary contacts.

Coil Voltage

550V 50 Hz, 600V 60 Hz

D

208V 60 Hz

E

Suffix

Code

Contact

Configuration

40 = 4NO

31 = 3NO-1NC

22 = 2NO-2NC

Circuit

Symbol

A1 13 23 33 43

A2 14 24 34 44

A1 13 21 33 43

A2 14 22 34 44

13 21 33

Coil Code

See table below.

Catalog Number—

Screw Terminals

1

XTRE10B40_

XTRE10B31_

XTRE10B22_

2

V9-T3-24

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

Front Mount Auxiliary Contacts for Use with XTRE Control Relays

1

Conventional

Thermal Current

I th

(A), Open at 60°C

16

16

Poles

2

2

Rated Operational Current AC-15 I e

(A)

220V

230V

240V

380V

400V

415V 500V

6

6

3

3

1.5

1.5

Contact

Configuration

2NO

1NC-1NC

Circuit

Symbol

53 63

54 64

53 61

54

62

Package

Quantity

5

5

Catalog Number—

Screw Terminals

XTCEXFAC20v

XTCEXFAC11

16

16

4

4

6

6

3

3

1.5

1.5

4NO

2NO-2NC

53 6373 83

54 6474 84

53 61 73 83

54 62 74 84

5

5

XTCEXFAC40

XTCEXFAC22

Note

1

Interlocked opposing contacts, to IEC/EN 60947-5-1 Annex L (positively driven), within the auxiliary contact modules (not NOE and NCL contacts) and between the auxiliary contacts and built-in contacts of the XTRE control relays.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-25

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Solid-State Relays—D93 Series

Catalog Number Selection

Solid-State Relays—D93 Series

D93 Series

Description

D93 = Hockey puck

D96 = Compact

D99 = DIN rail

Output Voltage

1 = 2–60 Vdc

2 = 24–280 Vac

3 = 3–200 Vdc

4 = 48–480 Vac

6 = 48–600 Vac

Current

Output current in amps

Product Selection

D93 Series

Input Voltage

90–280 Vac

3–32 Vdc

3–32 Vdc

90–280 Vac

3–32 Vdc

3–32 Vdc

90–280 Vac

3–32 Vdc

3–32 Vdc

90–280 Vac

3–32 Vdc

90–280 Vac

3–32 Vdc

3–32 Vdc

3–32 Vdc

3–32 Vdc

Output Voltage

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

3–200 Vdc

3–200 Vdc

3–200 Vdc

Accessory

Heat Sink Accessory

Description

Heat sink

Catalog Number

D93HS1

Contact Configuration

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

Switching Type

Zero cross

Zero cross

Triac

Zero cross

Zero cross

Triac

Zero cross

Zero cross

Triac

Zero cross

Zero cross

Zero cross

Zero cross

MOSFET

MOSFET

MOSFET

Features

All solid-state circuitry with no moving parts to wear

Compact, panel mounting for flexible installation

Isolated input and output terminals to protect the system from electrical noise

Internal snubber circuitry to protect the SSR from transients

UL ® /cUL ® listed—UL 508

CSA ® certified

CE marked

RoHS compliant

D93 3 25 A M D 2

Contact

Configuration

A = SPST-NO

B = SPST-NC

C = DPST-NO

D = DPST-NC

Output Type

C = SCR

T = Triac

M = MOSFET

Rated Current Load (A)

75

75

12

25

40

40

50

50

25

25

40

10

10

10

25

40

Turn On Type

Z = Zero cross

R = Random

D = DC switch

Input Voltage

1 = 90–280 Vac

2 = 3–32 Vdc

3 = 3.5–32 Vdc

4 = 4–15 Vdc

5 = 20–50 Vdc

Catalog Number

D93210ACZ1

D93210ACZ2

D93210ATZ2

D93225ACZ1

D93225ACZ2

D93225ATZ2

D93240ACZ1

D93240ACZ2

D93240ATZ2

D93250ACZ1

D93250ACZ2

D93275ACZ1

D93275ACZ2

D93312AMD2

D93325AMD2

D93340AMD2

V9-T3-26

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Relays

3.1

Solid-State Relays—D96 Series

Product Selection

Solid-State Relays—D96 Series

D96 Series

Input Voltage

3.5–32 Vdc

3.5–32 Vdc

90–280 Vac

3–32 Vdc

90–280 Vac

3–32 Vdc

3–32 Vdc

90–280 Vac

3–32 Vdc

90–280 Vac

3–32 Vdc

90–280 Vac

90–280 Vac

3–32 Vdc

Output Voltage

3–50 Vdc

3–150 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

48–480 Vac

48–480 Vac

48–480 Vac

48–480 Vac

48–600 Vac

48–600 Vac

48–600 Vac

Contact Configuration

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NC

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

Features

All solid-state circuitry has no moving parts to wear

Integral heat sink eliminates the need for added accessories and installation

Flexible mounting allows DIN rail or panel mounting without additional hardware or tools

Isolated input and output terminals protect the system from electrical noise

Internal snubber circuitry protects the SSR from transients

UL/cUL listed—UL 508

CSA certified

CE marked

RoHS compliant

Switching Type

DC switch

DC switch

Random

Random

Zero cross

Zero cross

Random

Random

Random

Zero cross

Zero cross

Random

Zero cross

Zero cross

Rated Current Load (A)

10

10

10

10

10

10

10

10

10

10

15

8

10

10

Catalog Number

D96115ACZ3

D96208ACZ3

D96210ACR1

D96210ACR2

D96210ACZ1

D96210ACZ2

D96210BCR2

D96410ACR1

D96410ACR2

D96410ACZ1

D96410ACZ2

D96610ACR1

D96610ACZ1

D96610ACZ2

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-27

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Solid-State Relays—D99 Series

Product Selection

Solid-State Relays—D99 Series

D99 Series

Input Voltage

90–280 Vac

3–32 Vdc

90–280 Vac

3–32 Vdc

90–280 Vac

3–32 Vdc

90–280 Vac

3–32 Vdc

90–280 Vac

3–32 Vdc

90–280 Vac

3–32 Vdc

Output Voltage

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

24–280 Vac

48–600 Vac

48–600 Vac

48–600 Vac

48–600 Vac

48–600 Vac

48–600 Vac

V9-T3-28

Contact Configuration

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

SPST-NO

Switching Type

Zero cross

Zero cross

Zero cross

Zero cross

Zero cross

Zero cross

Zero cross

Zero cross

Zero cross

Zero cross

Zero cross

Zero cross

Features

All solid-state circuitry has no moving parts to wear

Integral heat sink eliminates the need for added accessories and installation

Flexible mounting allows DIN rail or panel mounting without additional hardware or tools

Isolated input and output terminals protect the system from electrical noise

Internal snubber circuitry protects the SSR from transients

UL/cUL listed—UL 508

CSA certified

CE marked

RoHS compliant

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Rated Current Load (A)

10

10

25

25

10

10

25

25

40

40

40

40

Catalog Number

D99210ACZ1

D99210ACZ2

D99225ACZ1

D99225ACZ2

D99240ACZ1

D99240ACZ2

D99610ACZ1

D99610ACZ2

D99625ACZ1

D99625ACZ2

D99640ACZ1

D99640ACZ2

Logic Devices

Relays

3.1

Universal TR Series Timing Relays

Product Selection

Universal TR Series Timing Relays

Universal TR Series

Supply Voltage Description

4-Function

24–240 Vac/Vdc Compact DIN rail mount, SPDT

7-Function

24–240 Vac/Vdc

12–240 Vac/Vdc

Compact DIN rail mount, SPDT

Compact DIN rail mount, DPDT

Asymmetrical pulse generator, DPDT

Catalog Number

TRL04

TRL07

TRL27

TRW27

Features

Multiple user-selectable timing functions and timing ranges in a single unit reduce product variations and stock keeping units

(SKUs)

Universal input voltages from 12 or 24–240 Vac/Vdc eliminate the need to order and stock separate coil voltages

Compact, DIN rail mountable case reduces panel size

Advanced LED indication makes troubleshooting easy

Staggered terminal locations allow access to lower-level terminals after wiring

SPDT or DPDT contacts with 8A ratings cULus listed

CE marked

RoHS compliant

IEC/EN 61812

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-29

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

TMR5 Series Timing Relays

Catalog Number Selection

TMR5 Series Timing Relays

TMR5 Series

Type

TMR5 = TMR5 Series timing relays

Features

Single timing range for each unit

Ranges available from 0.02 sec. to 24 hours

Wide variety of functions available

10A DPDT output contacts

TMR5 N 05 120

8-Pin Octal Sockets

Operational Mode

11-Pin Octal Sockets

N

= ON delay

T

= Interval ON

L

= Flasher

R

1

= Repeat cycle

(OFF time first followed by

ON time and repeating)

Y 1 = Repeat cycle

(ON time first followed by

OFF time and repeating)

F = OFF delay, control switch trigger

C = Single shot, control switch trigger

W = Watchdog, control switch trigger

(retriggerable single shot)

P = OFF delay, power trigger

G = Single shot, power trigger

D = Watchdog, power trigger

(retriggerable single shot)

Input Voltage

120 = 120 Vac/Vdc

24 = 24 Vac/Vdc

12 = 12 Vac/Vdc

240 = 240 Vac/Vdc

12 = 12 Vac/Vdc

240 = 240 Vac/Vdc

Timing Range

23

03 = 0.02–2 sec.

05 = 0.1–10 sec.

08 = 0.6–60 sec.

12 = 3–300 sec.

15 = 0.3–30 min.

16 = 0.6–60 min.

20 = 4.8–8 hr.

22 = 6 sec.–10 min.

23 = 14.4 min.–24 hr.

Product Selection

TMR5 Time Delay Relays

Input Voltage

ON Delay

Interval ON

120 Vac/Vdc

120 Vac/Vdc

24 Vac/Vdc

24 Vac/Vdc

Socket

120 Vac/Vdc

120 Vac/Vdc

24 Vac/Vdc

24 Vac/Vdc

8-pin

OFF Delay, Control Switch Trigger

120 Vac/Vdc 11-pin

120 Vac/Vdc

24 Vac/Vdc

24 Vac/Vdc

8-pin

Timing Range

0.1–10 sec.

0.6–60 sec.

0.1–10 sec.

0.6–60 sec.

0.1–10 sec.

0.6–60 sec.

0.1–10 sec.

0.6–60 sec.

0.1–10 sec.

0.6–60 sec.

0.1–10 sec.

0.6–60 sec.

Catalog Number

TMR5N05120

TMR5N08120

TMR5N0524

TMR5N0824

TMR5F05120

TMR5F08120

TMR5F0524

TMR5F0824

TMR5T05120

TMR5T08120

TMR5T0524

TMR5T0824

Input Voltage Socket

Single Shot, Control Switch Trigger

Timing Range

Repeat Cycle (ON Time First Followed by OFF Time and Repeating)

120 Vac/Vdc

120 Vac/Vdc

24 Vac/Vdc

24 Vac/Vdc

8-pin 0.1–10 sec.

0.6–60 sec.

0.1–10 sec.

0.6–60 sec.

Catalog Number

120 Vac/Vdc

120 Vac/Vdc

24 Vac/Vdc

24 Vac/Vdc

11-pin 0.1–10 sec.

0.6–60 sec.

0.1–10 sec.

0.6–60 sec.

TMR5C05120

TMR5C08120

TMR5C0524

TMR5C0824

Repeat Cycle (OFF Time First Followed by ON Time and Repeating)

120 Vac/Vdc 8-pin 0.1–10 sec.

TMR5R05120

120 Vac/Vdc

24 Vac/Vdc

24 Vac/Vdc

0.6–60 sec.

0.1–10 sec.

0.6–60 sec.

TMR5R08120

TMR5R0524

TMR5R0824

TMR5Y05120

TMR5Y08120

TMR5Y0524

TMR5Y0824

Notes

1

2

Indicates DUAL knob unit. All dual knob units can have independently selectable and adjustable ON and OFF times. If different ON and OFF times are desired, add two codes for time ranges in the part number. The first code listed indicates the first timing range of the unit (OFF time for R, ON time for Y) and the second code indicates the second timing range (ON time for R, OFF Time for Y).

Any time range can be created as a custom unit. Contact Eaton for details.

3

Fixed time delay settings are available for orders of 50 pieces or more.

V9-T3-30

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Devices

Relays

3.1

Logic

TMR6 Series Timing Relays

Features

Provides OFF delay function without requiring input voltage during OFF time delay

Duplicates operation of pneumatic OFF delay timers

Each unit has eight timing ranges built in, covering 0.05 seconds to 30 minutes

Selecting a range is easy using a rotary switch (no math is required or DIP switches to set)

Uses industry-standard

8-pin octal socket

10A DPDT output contacts cRUus

UL listed (with Eaton socket)

RoHS compliant

CE marked

Catalog Number Selection

TMR6 Series Timing Relays

TMR6 Series

TMR6 X 00 120

Family Type

TMR6 Operational Mode

X = True OFF delay

Product Selection

TMR6 True OFF Delay Relays

Input Voltage Timing Range

120 Vac/Vdc

24 Vac/Vdc

240 Vac/Vdc

0.05 sec.–30 min.

(user selectable, eight ranges)

Catalog Number

TMR6X00120

TMR6X0024

TMR6X00240

Accessories

Accessories for Use with TMR6 Time Delay Relays

Description Standard Pack Catalog Number

8-pin socket

Hold-down spring

10

10

D3PA2

D65CHDS

True OFF Delay

ON

Input

Power

(Voltage)

OFF

Output

(Load)

ON

OFF

Delay

Timing Range

00 = Programmable

Input Voltage

120 = 120 Vac/Vdc

24 = 24 Vac/Vdc

240 = 240 Vac/Vdc

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-31

3.1

Logic Devices

Relays

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

TMRP Series Timing Relays

Product Selection

TMRP Series Timing Relays

TMRP Timing Relays

Supply Voltage Description

10-Function

12–240 Vac/Vdc Control switch trigger, DPDT

Control switch trigger, SPDT

Power trigger, DPDT

V9-T3-32

Catalog Number

TMRP5100

TMRP5101

TMRP5102

Features

Multiple user-selectable timing functions and timing ranges in a single unit reduce product variations and stock keeping units (SKUs)

Universal input voltages from 12–240 Vac/Vdc eliminate the need to order and stock separate coil voltages

Timing ranges up to 9990 hours

Dual LED indication makes troubleshooting easy

Flexible design for back-panel, through-panel (45 mm x

45 mm cutout), or DIN rail mounting

SPDT or DPDT contacts with 12A ratings

Plastic dust cover keeps out contaminants and eliminates accidental set point changes

Use with standard Eaton D3 sockets

UL recognized

CE marked

RoHS compliant

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Programmable Logic Controllers

3.2

Product Overview

Programmable Logic Controllers Selection Guide

Description

Fusion Integrated

Machine Controllers

Page V9-T3-36

EASY

Intelligent Relays

Page V9-T3-37

MFD

Intelligent Relays

Page V9-T3-39

ELC

Eaton Logic Controllers

Page V9-T3-41

User Interface

LCD display (text/graphics)

Seven-segment display

Keypad for programming

Hand-held programmer

Potentiometers

I/O Digital

Embedded digital input types

3-, 4- or 5-line text

(embedded)

Yes

Simulated using display

4-line text

(embedded)

Optional

Simulated using optional display

4-line text and graphics

(embedded)

4 characters (simulated)

Optional

Simulated using optional display

Text and graphics thru HM

i

or ELC-GP (external)

PA only = 2 digital

Available for all

PC/PH = two embedded

Embedded digital output types

3.5–30 Vdc

24 Vdc transistor or high current relay (5A resistive)

Embedded digital inputs/outputs per unit

Expansion digital input types

Expansion digital output types

10 control inputs

3 counter inputs/

2 transistors

5 relays

12 Vdc/24 Vdc

24 Vac or 110/240 Vac

24 Vdc transistor or high current relay (8A resistive)

24 Vac or 110/240 Vac

(using MFD I/O)

24 Vdc transistor or high current relay (8A resistive)

(using MFD I/O)

12/4

(using MFD I/O)

24 Vdc or 110/240 Vac

24 Vdc transistor or relay

Max. digital I/O includes embedded and expansion

20

EASY500 = 8/4

EASY700/800 = 12 (6 or 8)

24 Vdc or 110/240 Vac

24 Vdc transistor or high current relay (8A resistive)

EASY500 = 12

EASY700/800 = 40

EASY800 (link up to 8 expanded units using EASY-NET) = 320

24 Vdc or 110/240 Vac

24 Vdc transistor or high current relay (8A resistive)

(link up to 8 expanded units with EASY-NET) = 320

PA = 4/2

PB = 8/6

PC/PH = 8/4

PV = 16/12

24 Vdc or 110/240 Vac

24 Vdc transistor, relay or high current relay (6A resistive)

PA/PB/PC/PH =

112 in/112 out and embedded

PV = 240 in/240 out embedded

I/O Analog

Embedded analog input quantity and types

2 at 4–20 mA

2 at 0–10 Vdc

Embedded analog input resolution 6.5 bit

Embedded analog outputs quantity and types

1 at 4–20 mA

1 at 0–10 Vdc

Embedded analog output resolution 6.5 bit

Expansion analog input types —

Expansion analog input resolution —

Expansion analog outputs types —

10 bit

0

0

Optional on 24 Vac or DC input units

EASY500 = 2

EASY700 = 4

EASY819/821 = N/A

EASY820/822 = 1

All 0 to +10 Vdc

10 bit

Optional EASY820/822 = 1

All 0 to +10 Vdc

Optional on 24 Vac or Vdc input units = 4

All 0 to +10 Vdc

10 bit

Available using

MFD-RA17 or MFD-TA17

MFD I/O Modules = 1

All 0 to +10 Vdc

10 bit

0

0

PA = 2 at either –10 to +10 Vdc or –20 to +20 mA

12 bit

PA = 2 at either –10 to +10 Vdc or –20 to +20 mA

12 bit

–10 to +10 Vdc or

–20 to +20 mA

V = 12 bits, I = 11 or 13 bits 1

0 to 20 mA, 4 to 20 mA

0 to 10 Vdc, 2 to 10 Vdc 1

Note

1 Combo modules have 11 bit resolution; analog input-only modules support 13 bit.

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-33

3.2

Logic Devices

Programmable Logic Controllers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Programmable Logic Controllers Selection Guide, continued

Description

I/O Analog

Expansion analog output resolution

Max. expansion analog inputs/outputs

Fusion Integrated

Machine Controls

EASY

Intelligent Relays

0/0

MFD

Intelligent Relays

0/0

ELC

Eaton Logic Controllers

Voltage = 14 bit

Current = 11 or 12 bit 1

Up to 32/up to 32

(max. using eight combo modules = 32 in + 16 out)

I/O Specialty Inputs

RTD PT100

Thermocouple

Programming

Programming tools

Program size

Programming languages

Timers

General counters

High speed counters

Quantity at max. speed

(pulse train output use may limit maximum counter frequency)

Pulse train outputs

Quantity at max. speed

(high speed input use may limit maximum speed for outputs)

Software or front panel

100 rungs with up to 6 contacts and 1 coil per rung

Ladder

8

8

Up to 14 kHz with five presets and prewarn

Software; on-board keypad; memory module transfer

EASY500/700 = 128 rungs

EASY800 = 256 rungs

Ladder; function block

EASY500/700 = 16

EASY800 = 32

EASY500/700 = 16

EASY800 = 32

1 kHz

Software; on-board keypad; memory module transfer

MFD = 256 rungs

Ladder; function block

32

32

3 kHz

Four point expansion module

Four point expansion module

Software; memory module transfer; hand-held programmer

PB = 4k steps

PA/PC/PH = 8k steps

PV = 16k steps

Instructions, ladder, sequential function chart

PB = 128

PA/PC/PH/PV =

244 standard with additional timers for subroutine and retentive applications

PB = 128

PA/PC/PH = 235

PV = 253

PB = up to 4, 2 at 20 kHz

PA/PC = up to 6, 1 at 30 kHz and 1 at 10 kHz

PH = up to 8, 1 at 100 kHz and 1 at 30 kHz

PV = up to 8, 2 at 200 kHz

2 at 20 kHz; and 2 at 10 kHz

PB = 2 at 10 kHz

PA/PC = 1 at 30 kHz; and 1 at 10 kHz

PH = 1 at 100 kHz; and 1 at 30 kHz

PV = up to 2 at 200 kHz; and 1 at 40 kHz

PA/PC/PH/PV = Yes

Not available on PB

Real time clock Yes EASY500 = Optional

EASY700/800 = Yes

Note

1 Combo modules have 11 bit resolution; analog input-only modules support 13 bit.

Yes

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

V9-T3-34

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Programmable Logic Controllers

3.2

Programmable Logic Controllers Selection Guide, continued

Description

Communications

Ports

DeviceNet

Ethernet OPC

ASi

Profibus

CanOpen

Modbus Serial

General Specifications

Hazardous location

Class I, Division 2

Agency certifications

Operating temperature range

Fusion Integrated

Machine Controls

1 RS-232/RS-485

Slave only

EASY

Intelligent Relays

Programming only

EASY700/800 = slave only

EASY700/800 = slave only

EASY700/800 = slave only

EASY700/800 = slave only

EASY700/800 = slave only

MFD

Intelligent Relays

Programming only

Slave only

Slave only

Slave only

Slave only

Slave only

ELC

Eaton Logic Controllers

1 RS-232 slave or programming

1 RS-485 master or slave

PA/PB/PC/PH = slave only

PV = master and slave

PA/PB/PC/PH = slave only

PV = limited master and slave

ASCII/RTU master and slave

Storage/transport temperature range

Nominal operating power

UL/CUL/CE

0° to 50°C

(32° to 122°F)

–20° to 70°C

(–4° to 158°F)

100/240 Vac

24 Vdc

12 Vdc

Yes

UL/CSA/CE/C-Tick

–25° to 55°C

(–13° to 131°F)

–40° to 70°C

(–40° to 158°F)

100/240 Vac

24 Vdc

12 Vdc

UL/CSA/CE/C-Tick

–25° to 55°C

(–13° to 131°F)

Display –5° to 50°C

–40° to 70°C

(–40° to 158°F)

100/240 Vac

24 Vdc

Yes

UL/CUL/CE/C-Tick

0° to 55°C

(32° to 131°F)

–25° to 70°C

(–13° to 158°F)

24 Vdc

110/240 Vac using

ELC power supply

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-35

3.2

Logic Devices

Programmable Logic Controllers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Fusion

®

Integrated Machine Controller

Product Selection

Fusion Integrated Machine Controller

Fusion Integrated Machine Controller

Description

Fusion integrated machine controller—10–30 Vdc power

Fusion integrated machine controller—85–265 Vac power

V9-T3-36

Catalog Number

57550400

57551400

Features

User-configurable operator interface with back-lit LCD display and 18-button tactile feedback keypad

High-speed counter with five presets and prewarn, totalizer, batch counter and ratemeter

10 parameter sets

13 digital inputs

(2) 4–20 mA inputs

(2) 0–10V input

(3) Form C, 2 Form A, 2 NPN transistor, (1) 4–20 mA, and

(1) 0–10V output

RS-232 and RS-485 serial communications

100-line ladder logic processor for ultimate flexibility

Configuration software included

Type 4X enclosure

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Programmable Logic Controllers

3.2

EASY Intelligent Relays

Catalog Number Selection

EASY Intelligent Relays

EASY Intelligent Relays

Programmable Relay Type

5xx = 12 digital I/O embedded

7xx = 18–20 digital I/O embedded

Expandable up to 40 I/O

8xx = 18–20 digital I/O embedded

Available embedded analog out

Expandable up to 320 I/O using EASY-NET

See catalog for available configurations.

Features

EASY500 Series—for controlling small applications with up to

12 input/output signals

EASY700 Series—for controlling medium-sized applications with up to 40 input/output signals

EASY800 Series—for controlling large-scale applications with up to 320 input/output signals; use EASY-NET for applications beyond 40 I/O

MFD Series—for controlling applications with visualization.

The MFD display can be linked to the EASY500/700/800 models for text only; graphics capabilities are available when using the CP8 modules

EASY 512 AB R C X

Digital Inputs

AC = 110–240 Vac

DC = 24 Vdc

AB = 24 Vac

DA = 12 Vdc

All units except those with 110–240 Vac inputs have optional 0–10 Vdc analog inputs.

Digital Outputs

R = Relay

(8A resistive max.)

T = Transistor (0.5A max.)

Some 800 Series units have analog outputs.

Clock

C

= Clock

Blank = No clock

(only for select

500 Series)

Display

Blank = Display

X

= No display

EASY Expansion

EASY 618 – DC – R E

Expansion Modules

202 = 2 I/O point

6xx = 18–20 I/O points

4xx = 6–11 I/O points

Use EASY200-EASY coupling module for local expansion.

See catalog for details on available combinations.

Digital Inputs

AC

= 110–240 Vac

DC

= 24 Vdc

Blank = No inputs (only for EASY202-RE)

All units except those with 110–240 Vac inputs have optional 0–10 Vdc analog inputs.

Digital Outputs

R = Relay

(8A resistive max.)

T = Transistor (0.5A max.)

M = Special analog and RTD

(see catalog for details)

Expansion

E = Expansion Module

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-37

3.2

Logic Devices

Programmable Logic Controllers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

MFD Intelligent Relay Displays and Controllers

MFD AC-CP8 – ME

MFD Display

80

Processor

AC-CP8 = Processor with clock; requires user-supplied

100–240 Vac

CP8

= Processor with clock; requires user-supplied

24 Vdc

I/O Modules

AC-R16 = 12 110–240 Vac inputs

4 relay outputs

R16

= 12 24 Vdc + 4 analog inputs

4 relay out

RA17

= 12 24 Vdc + 4 analog inputs

4 relay + 1 analog outputs

T16

= 12 24 Vdc + 4 analog inputs

4 transistor outputs

TA17

= 12 24 Vdc + 4 analog inputs

4 transistor + 1 analog outputs

MFD Display to Remote EASY Processor Interface

AC-CP4 = MFD interface adapter; requires user-supplied 100–240 Vac

CP4

= MFD interface adapter; requires user-supplied 24 Vdc

MFD Display

B

= With buttons

Blank = No buttons

Processor

ME

= Select when only local expansion is required

NT

= Expansion locally and through EASY-NET

MFD Display to Remote EZ Processor Interface

500

= Connects to 500 or 700

800

= Connects to 800 to remote MFD-CP8 or MFD-AC-CP8

Product Selection

EASY500 Intelligent Relays

Description

12 I/O, clock, display

12 I/O, clock, no display

12 I/O, no clock, display

12 I/O, clock, display

12 I/O, clock, no display

12 I/O, clock, display

12 I/O, clock, no display

12 I/O, no clock, display

12 I/O, clock, display

12 I/O, clock, no display

12 I/O, clock, display

12 I/O, clock, no display

Inputs

24 Vac

8

8

110–240 Vac

8

8

8

12 Vdc

8

8

24 Vdc

8

8

8

8

8

Analog

1

2

2

2

2

2

2

2

2

2

Note

1

Analog inputs optional; use of analog inputs will result in a decrease in the same number of available digital inputs.

Outputs

Relay

4

4

4

4

4

4

4

4

4

4

Transistor

4

4

Catalog Number

EASY512-AB-RC

EASY512-AB-RCX

EASY512-AC-R

EASY512-AC-RC

EASY512-AC-RCX

EASY512-DA-RC

EASY512-DA-RCX

EASY512-DC-R

EASY512-DC-RC

EASY512-DC-RCX

EASY512-DC-TC

EASY512-DC-TCX

V9-T3-38

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Programmable Logic Controllers

3.2

EASY700 Intelligent Relays

Description

Inputs

24 Vac

18 I/O, clock, display

18 I/O, clock, no display

18 I/O, clock, display

18 I/O, clock, no display

18 I/O, clock, display

18 I/O, clock, no display

18 I/O, clock, display

18 I/O, clock, no display

20 I/O, clock, display

20 I/O, clock, no display

12

12

EASY800 Intelligent Relays

Description

Inputs

110–240 Vac

18 I/O, clock, display

18 I/O, clock, no display

18 I/O, clock, display

18 I/O, clock, no display

19 I/O, clock, display

19 I/O, clock, no display

20 I/O, clock, display

20 I/O, clock, no display

21 I/O, clock, display

21 I/O, clock, no display

12

12

24 Vdc

12

12

12

12

12

12

12

12

110–240 Vac

12

12

12 Vdc

12

12

Analog

2

4

4

4

4

4

4

4

4

24 Vdc

12

12

12

12

Outputs

Relay

6

6

6

6

6

6

Analog

1

4

4

4

4

4

4

4

4

Outputs

Relay

6

6

6

6

6

6

6

6

Transistor

8

8

8

8

Analog

2

1

1

1

1

Transistor

8

8

Catalog Number

EASY719-AB-RC

EASY719-AB-RCX

EASY719-AC-RC

EASY719-AC-RCX

EASY719-DA-RC

EASY719-DA-RCX

EASY719-DC-RC

EASY719-DC-RCX

EASY721-DC-TC

EASY721-DC-TCX

Catalog Number

EASY819-AC-RC

EASY819-AC-RCX

EASY819-DC-RC

EASY819-DC-RCX

EASY820-DC-RC

EASY820-DC-RCX

EASY821-DC-TC

EASY821-DC-TCX

EASY822-DC-TC

EASY822-DC-TCX

MFD Intelligent Relays

MFD Displays (MFD-80) and MFD Controllers (MFD-CP8)

Description Catalog Number

MFD, no buttons

MFD, buttons

MFD CPU with 24 Vdc, power supply, clock

MFD CPU with 24 Vdc, power supply, clock, EASY-NET

MFD CPU with 100–240 Vac, power supply, clock

MFD CPU with 100–240 Vac, power supply, clock, EASY-NET

MFD-80

MFD-80-B

MFD-CP8-ME

MFD-CP8-NT

MFD-AC-CP8-ME

MFD-AC-CP8-NT

MFD Display to EASY Communication Modules (MFD-CP4)

Description Catalog Number

MFD-CP4-500

MFD display to EASY500/700 DC communication module.

Use with EASY800 communication cable (MFD-CP4-800-CAB5)

MFD display to EASY800 or MFD DC powered communication module.

Use with EASY800 communication cable (MFD-CP4-800-CAB5)

MFD display to EASY500/700 AC communication module with

EASY500/700 communication cable (MFD-CP4-500-CAB5)

MFD display to EASY800 or MFD AC powered communication module.

Use with EASY800 communication cable (MFD-CP4-800-CAB5)

MFD-CP4-800

MFD-AC-CP4-500

MFD-AC-CP4-800

Notes

1

2

Analog inputs optional; use of analog inputs will result in a decrease in the same number of available digital inputs.

Analog inputs optional; analog outputs optional; use of analog inputs will result in a decrease in the same number of available digital inputs.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-39

3.2

Logic Devices

Programmable Logic Controllers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

MFD Controller I/O Modules

Description

Inputs

110–240 Vac 24 Vdc

16 I/O

16 I/O

17 I/O

16 I/O

17 I/O

12

12

12

12

12

EASY/MFD I/O Expansion Modules

2

Description

Inputs

110–240 Vac 24 Vdc

2 I/O expansion

18 I/O expansion

12

18 I/O expansion — 12

20 I/O expansion — 12

Coupling module for remote mounting of expansion modules

Analog

1

4

4

4

4

Outputs

Relay

4

4

4

Transistor

4

4

EASY/MFD Communication Interface Modules

Description

PROFIBUS-DP slave interface module

AS-interface slave with 4 in and 4 out interface module

CANopen interface module

DeviceNet slave interface module

Ethernet OPC Gateway

Outputs

Relay

2

6

6

Transistor

8

Analog

1

1

Catalog Number

MFD-AC-R16

MFD-R16

MFD-RA17

MFD-T16

MFD-TA17

Catalog Number

EASY202-RE

EASY618-AC-RE

EASY618-DC-RE

EASY620-DC-TE

EASY200-EASY

Catalog Number

EASY204-DP

EASY205-ASI

EASY221-CO

EASY222-DN

EASY209-SE

EASY/MFD-CP8 Power Supplies and Software

Description

Programming software for EASY500/700/800 and MFD

100–240 Vac input to 12 Vdc at 20 mA/24 Vdc at 250 mA

100–240 Vac input to 24 Vdc at 1.25A

EASY/MFD Cables and Connectors

EASY500/700 to MFD-CP4 communication cable, 5m

EASY800 to MFD-CP8 communication cable, 2m

EASY800 to MFD-CP8 communication cable, 5m

EASY800 to MFD-CP4 communication cable, 5m

EASY800/MFD EASY-NET cable, 0.3m

EASY800/MFD EASY-NET cable, 0.8m

EASY800/MFD EASY-NET cable, 1.5m

EASY800/MFD network termination resistor, 2/pack

EASY800/MFD EASY-NET cable (cable only, no connectors, see EASY-NT-RJ45), 100m

RJ45 network connectors for EASY-NET cable (EASY-NT-CAB), 10/pack

Notes

1

2

Analog inputs optional; use of analog inputs will result in a decrease in the same number of available digital inputs.

All expansion modules include one EASY-LINK-DS.

Catalog Number

EASYSOFT

EASY200-POW

EASY400-POW

MFD-CP4-500-CAB5

MFD-800-CAB

MFD-800-CAB5

MFD-CP4-800-CAB5

EASY-NT-30

EASY-NT-80

EASY-NT-150

EASY-NT-R

EASY-NT-CAB

EASY-NT-RJ45

V9-T3-40

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Programmable Logic Controllers

3.2

ELC Programmable Logic Controllers

Features

Modular PLC logic platform with a range of basic to sophisticated CPUs

Ethernet and DeviceNet master communications

Distributed I/O for EtherNet/IP, Modbus TCP, PROFIBUS-DP,

DeviceNet and Modbus serial networks

Catalog Number Selection

ELC Programmable Logic Controllers

Controllers and Expansion Modules

ELC – PA 10 A A D R

Device Types

PA = Analog model

PB = Base model

PC = Clock/calendar model

PH = High-speed model

PV = Advanced model

AN = Analog expansion module

EX = Digital expansion module

PT = Platinum RTD expansion module

TC = Thermocouple expansion module

I/O Count

xx = Total number of I/O

Analog Inputs

A = Analog

N = None

Analog Outputs

A = Analog

N = None

Master Communication Modules

ELC – CO ENETM

Device Type

CO = Communication interface model

Module Type

DNETM = DeviceNet master module

1

ENETM = Ethernet module 1

Digital Inputs

A = AC

D = DC

S = Switch

N = None

Distributed I/O Adapter Modules

ELC – CA ENET

Device Type

CA = Distributed I/O communication adapter

Module Type

ENET = Modbus TCP/EtherNet/IP adapter

DNET = DeviceNet adapter

RS485 = Modbus serial RS-485 adapter

PBDP = PROFIBUS-DP adapter

Note

1 Left side communications module.

Digital Outputs

T = Transistor NPN

R = Relay

I = High current relay

N = None

P = Transistor PNP

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-41

3.2

Logic Devices

Programmable Logic Controllers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Product Selection

Controllers

Description

ELC-PB Model and 14 I/O built-in

ELC-PC Model and 12 I/O built-in

ELC-PH Model and 12 I/O built-in

ELC-PA Model and 10 I/O built-in

ELC-PV Model and 28 I/O built-in

Inputs

(8) 24 Vdc

(8) 24 Vdc

(8) 24 Vdc

(8) 24 Vdc

(8) 110 Vac

(8) 24 Vdc

(4) 24 Vdc

(4) 24 Vdc

(16) 24 Vdc

(16) 24 Vdc

Distributed I/O Adapter Modules

Description

Modbus TCP/EtherNet/IP I/O adapter

Modbus serial RS-485 I/O adapter

DeviceNet I/O adapter

PROFIBUS-DP I/O adapter

Outputs

(6) Relay, 1.5A

(6) Transistor, 100 mA

(4) Relay, 1.5A

(4) Transistor, 100 mA

(4) Relay, 1.5A

(4) Transistor, 100 mA

(2) Relay, 1.5A

(2) Relay, 1.5A

(12) Relay, 1.5A

(12) Transistor, 100 mA

Network Communication Master Modules (Left Side Bus)

Description

Ethernet Modbus TCP (master/node)

DeviceNet scanner (master/node)

Analog

(2) In and (2) Out

(2) In and (2) Out

Catalog Number

ELC-CAENET

ELC-CARS485

ELC-CADNET

ELC-CAPBDP

Catalog Number

ELC-COENETM

ELC-CODNETM

High Speed I/O

(2) 20 kHz inputs

(2) 20 kHz inputs

(1) 30 kHz inputs

(1) 30 kHz inputs

(1) 30 kHz inputs

(1) 100 kHz inputs

(1) 30 kHz inputs

(1) 30 kHz inputs

(2) 200 kHz inputs

(2) 200 kHz inputs

V9-T3-42

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Maximum Current

Consumption

(at 24 Vdc)

150 mA

150 mA

150 mA

150 mA

150 mA

170 mA

210 mA

210 mA

220 mA

220 mA

Catalog Number

ELC-PB14NNDR

ELC-PB14NNDT

ELC-PC12NNDR

ELC-PC12NNDT

ELC-PC12NNAR

ELC-PH12NNDT

ELC-PA10AADR

ELC-PA10AADT

ELC-PV28NNDR

ELC-PV28NNDT

Logic Devices

Programmable Logic Controllers

Digital Expansion Modules (Right Side Bus)

Description

8 DC input module

16 DC input module

8 DC input/output module

16 DC input/output module

16 DC input/output module

8 DC input/relay output module

16 DC input/relay output module

8 AC input module

8 Transistor output module

8 Relay output module

6 High current relay output module

8 Toggle switch input module

Inputs

(8) 24 Vdc

(16) 24 Vdc

(4) 24 Vdc

(8) 24 Vdc

(8) 24 Vdc

(4) 24 Vdc

(8) 24 Vdc

(8) 110 Vac

(8) Switches

Outputs

(4) Transistor (sink), 0.3A

(8) Transistor (sink), 0.3A

(8) Transistor (source), 0.3A

(4) Relay, 1.5A

(8) Relay, 1.5A

(8) Transistor (sink), 0.3A

(8) Relay, 1.5A

(6) Relay, 6A

Maximum Current

Consumption

(at 24 Vdc)

50 mA

100 mA

70 mA

90 mA

100 mA

70 mA

90 mA

50 mA

70 mA

70 mA

70 mA

20 mA

Catalog Number

ELC-EX08NNDN

ELC-EX16NNDN

ELC-EX08NNDT

ELC-EX16NNDT

ELC-EX16NNDP

ELC-EX08NNDR

ELC-EX16NNDR

ELC-EX08NNAN

ELC-EX08NNNT

ELC-EX08NNNR

ELC-EX06NNNI

ELC-EX08NNSN

Analog and Temperature Expansion Modules (Right Side Bus)

Description

Analog

Inputs

Analog

Outputs

Maximum Current

Consumption

(at 24 Vdc)

4 Analog input module

2 Analog output module

4 Analog output module

6 Analog input/output module

4 Thermocouple input module (J, K, R, S and T)

4 Platinum RTD input module (PT100)

4

4

4

4

4

2

2

90 mA

125 mA

170 mA

90 mA

90 mA

90 mA

Catalog Number

ELC-AN04ANNN

ELC-AN02NANN

ELC-AN04NANN

ELC-AN06AANN

ELC-TC04ANNN

ELC-PT04ANNN

Specialty Expansion Modules (Right Side Bus)

Description

Single axis motion control module (Add up to 8 modules per controller)

RS-485 Easy Connect adapter (DB9, RJ12, 2-pin connections to RS-485)

Catalog Number

ELC-MC01

ELC-485APTR

Accessories and Software

Description

ELC programming software

24 Vdc, 1A power supply

24 Vdc, 2A power supply

Cable to connect a PC or a GP unit to ELC, 1 meter (DB9 pin female to 8-pin DIN)

Cable to connect a PC or a GP unit to ELC, 3 meters (DB9 pin female to 8-pin DIN)

Cable to connect a PC to a GP unit, 3 meters (DB9 pin female to DB9 pin female)

Program transfer module for ELC controllers

Plate mount for specialty modules, qty. 10

ELC starter kit (includes ELC-PA10AADT, ELC-PS01, ELC-GP04, ELC-CBPCELC3,

ELC-CBPCGP3, ELCSoft, ELCSoft GP)

Catalog Number

ELCSOFT

ELC-PS01

ELC-PS02

ELC-CBPCELC1

ELC-CBPCELC3

ELC-CBPCGP3

ELC-ACPGMXFR

ELC-ACCOVER

ELCSTARTKIT1

3.2

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-43

3.2

Logic Devices

Programmable Logic Controllers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

ELCB Programmable Logic Controller

Catalog Number Selection

ELCB Programmable Logic Controllers

Controllers

Device Types

PB = Base model

Product Selection

Controllers

Inputs

Description

10 I/O

14 I/O

20 I/O

30 I/O

40 I/O

AC

DC

6

6

8

8

12

12

18

18

24

24

I/O Count

xx = Total number of I/O

(10, 14, 20, 30, 40)

Analog

Outputs

8

12

16

Relay

4

6

6

8

12

16

NPN Sinking

Transistor

4

Analog

Accessories and Software

Description

ELC programming software requires version 2.02 or later

Cable to connect a PC or a GP unit to ELC, 1 meter (DB9 pin female to 8-pin DIN)

Cable to connect a PC or a GP unit to ELC, 3 meters (DB9 pin female to 8-pin DIN)

Cable to connect a PC to a GP unit, 3 meters (DB9 pin female to DB9 pin female)

Program transfer module for ELC controllers

Analog Inputs

N = None

Features

Basic PLC logic with just enough I/O for simple DC in/relay or transistor out applications

This non-expandable PLC has a built-in AC power supply and provides up to 400 mA of DC sensor power

Each controller supports one RS-232 programming port and one RS-485 Modbus serial (master/node) port

ELCB – PB 10 N N D R

Analog Outputs

N = None

Catalog Number

ELCB-PB10NNDR

ELCB-PB10NNDT

ELCB-PB14NNDR

ELCB-PB14NNDT

ELCB-PB20NNDR

ELCB-PB20NNDT

ELCB-PB30NNDR

ELCB-PB30NNDT

ELCB-PB40NNDR

ELCB-PB40NNDT

Catalog Number

ELCSOFT

ELC-CBPCELC1

ELC-CBPCELC3

ELC-CBPCGP3

ELC-ACPGMXFR

Digital Inputs

D = DC

Digital Outputs

T = Transistor

R = Relay

V9-T3-44

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Programmable Logic Controllers

3.2

ELCM Programmable Logic Controller

Features

Midrange brick style controller with digital, analog, thermocouple and RTD expansion capability

Expansion modules can optionally be used to increase the total number of I/O, to provide a mix of different types of I/O, or both

These controllers include an embedded AC power supply and provide up to 400 mA of DC sensor power

Each controller supports two RS-485 Modbus serial (master/ node) and one RS-232 programming port

Catalog Number Selection

ELCM Programmable Logic Controllers

Controllers and Expansion Modules

ELCM – PA 16 A A D R

Device Types

PH = High-speed model

PA = Analog model

AN = Analog expansion module

EX = Digital expansion module

PT = Platinum rtd expansion module

TC = Thermocouple expansion module

I/O Count

xx = Total number of I/O

(16, 24, 32, 40 digital;

20 analog and digital)

Analog Inputs

A = Analog

N = None

Analog Outputs

A = Analog

N = None

Product Selection

Controllers

Description

16 I/O PH model

24 I/O PH model

32 I/O PH model

40 I/O PH model

20 I/O PA model

Inputs

AC

DC

8

8

16

8

8

24

24

16

16

16

4

4

Analog

16

6

16

Outputs

Relay

8

8

16

6

8

16

Transistor

8

2

2

Analog

Catalog Number

ELCM-PH16NNDR

ELCM-PH16NNDT

ELCM-PH24NNDR

ELCM-PH24NNDT

ELCM-PH32NNDR

ELCM-PH32NNDT

ELCM-PH40NNDR

ELCM-PH40NNDT

ELCM-PA20AADR

ELCM-PA20AADT

Digital Inputs

A = AC

D = DC

N = None

Digital Outputs

T = Transistor

R = Relay

N = None

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-45

3.2

Logic Devices

Programmable Logic Controllers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Right Side Digital Expansion Modules

Inputs

Description AC

DC

Sink/Source

DC input module

Relay output module

Transistor output module

8 DC input/relay output module

16 DC input/relay output module

8 DC input/output module

16 DC input/output module

8

16

4

8

4

8

Right Side Analog and Specialty Modules

Description

4 Analog input module

2 Analog output module

4 Analog output module

6 Analog input/output module

4 Thermocouple input module (J, K, R, S and T)

4 Platinum RTD input module (PT100)

Analog Inputs

4

4

4

4

Accessories and Software

Description

ELC programming software requires version 2.02 or later

Cable to connect a PC or a GP unit to ELC, 1 meter (DB9 pin female to 8-pin DIN)

Cable to connect a PC or a GP unit to ELC, 3 meters (DB9 pin female to 8-pin DIN)

Cable to connect a PC to a GP unit, 3 meters (DB9 pin female to DB9 pin female)

Program transfer module for ELC controllers

Outputs

Relay

8

16

8

16

4

8

NPN Sinking

Transistor

4

8

Analog Outputs

4

2

2

Catalog Number

ELCM-EX08NNDN

ELCM-EX16NNDN

ELCM-EX08NNNR

ELCM-EX16NNNR

ELCM-EX08NNNT

ELCM-EX16NNNT

ELCM-EX08NNDR

ELCM-EX16NNDR

ELCM-EX08NNDT

ELCM-EX16NNDT

Catalog Number

ELCM-AN04ANNN

ELCM-AN02NANN

ELCM-AN04NANN

ELCM-AN06AANN

ELCM-TC04ANNN

ELCM-PT04ANNN

Catalog Number

ELCSOFT

ELC-CBPCELC1

ELC-CBPCELC3

ELC-CBPCGP3

ELC-ACPGMXFR

V9-T3-46

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Preset Counters

3.3

Product Overview

Preset Counters Selection Guide

Description

Display

Power supply

Number of digits

Panel cut-out size

Scaling capability

Number of presets

Max. counting speed

Front panel protection

Other features/functions

Relay rating(s)

E5-148-C1400

Page V9-T3-48

Two-line LCD

Replaceable lithium batteries

6

45 x 45 mm (1/16 DIN)

1

25 Hz

IP65

2A

E5-648-C Series

Page V9-T3-48

Two-line LCD

10–30 Vdc or 90–260 Vac

6

45 x 45 mm (1/16 DIN)

Yes

2 or 4

10 kHz

IP65

Timer/rate indicator

3A

Eclipse Series

Page V9-T3-49

LED

9–30 Vdc or 85–265 Vac

6

92 x 45 mm (1/8 DIN)

Yes

2

Up to 8,250 Hz

Type 4X

Analog retransmission/RS-485 communications

5A

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-47

3.3

Logic Devices

Preset Counters

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

1/16 DIN LCD Preset Counter

Catalog Number Selection

1/16 DIN LCD Preset Counter

LCD Preset Counter

Type

E5 = E5 Series

Counter Type

1 = Pulse counter

6 = Multifunction counter with rate/ratio

Product Selection

1/16 DIN LCD

Description

Battery Powered 1 Preset LCD

Battery power 1.89 x 1.89 in (48 x 48 mm)

AC/DC Powered 2 Preset LCD

90–260 Vac power 1.89 x 1.89 in (48 x 48 mm)

10–30 Vdc power 1.89 x 1.89 in (48 x 48 mm)

AC Powered 4 Preset Two-Color LCD

90–260 Vac power 1.89 x 1.89 in (48 x 48 mm)

V9-T3-48

Features

Battery powered

Two-line LC displays count, preset and level of the output

Replacement for electromechanical preset counters

No power supply necessary (battery operated)

Count and reset input electrically separated from counter through optocoupler input range 12–250 Vac/Vdc

AC/DC powered

Two-line LCD with optional two-color display

Programmable as impulse counter, frequency meter or time meter with sign and zero blanking

Batch mode

Add/subtract/ratio functions

E5 1 48 C 2 400

Front Dimension

48 = 48 x 48 mm

Catalog Number

E5-148-C1400

E5-648-C2421

E5-648-C2422

E5-648-C4461

Display

C = LCD

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Presets

2 = 2 presets

4 = 4 presets

Power

421 = AC power with backlit LCD display

422 = DC power with backlit LCD display

461 = AC power with two-color LCD display

1/18 DIN Eclipse Series Preset Counter

Logic Devices

Preset Counters

Features

1/8 DIN cutout

Type 4X front panel protection

Seven-segment LED display

3.3

Catalog Number Selection

1/18 DIN Eclipse Series Preset Counter

Eclipse Series Preset Counter

Type

577 = Eclipse Series

Power

00 = DC power

01 = AC power

577 00 48 1

Function

48 = Counter

Outputs

1 = Dual relay out

2 = Analog output (4–20 mA + 0–10V)

3 = Dual relay + analog output

4 = RS-485 communications

5 = Dual relay + RS-485 communications

6 = Analog output + RS-485 communications

7 = Dual relay, RS-485 communications + analog output

Product Selection

LED Count Control, 6-Digit

Description

Relay out, 9–30 Vdc power

Relay out, 85–265 Vac power

Relay and analog out, 9–30 Vdc power

Relay and analog out, 85–265 Vac power

Relay and RS-485 out, 9–30 Vdc power

Relay and RS-485 out, 85–265 Vac power

Relay, analog and RS-485 out, 9–30 Vdc power

Relay, analog and RS-485 out, 85–265 Vac power

Catalog Number

57700481

57701481

57700483

57701483

57700485

57701485

57700487

57701487

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-49

3.4

Logic Devices

Ratemeters

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Product Overview

Ratemeters Selection Guide

Description

Display

Power supply

Number of digits

Panel cut-out size

Scaling capability

Number of presets

Update time

Front panel protection

Other features/functions

Relay rating(s)

Courier Series

Page V9-T3-51

LCD

Replaceable lithium battery

5

68 x 33 mm

Yes

700 ms

Type 4X

Optional backlight, optional extended temperature range

Eclipse Series

Page V9-T3-52

LED

9–30 Vdc or 85–265 Vac

6

92 x 45 mm (1/8 DIN)

Yes

2 (with optional relay out model)

500 ms

Type 4X

Analog retransmission/RS-485 communications

5A

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

V9-T3-50

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Courier Series Battery Powered Ratemeter

Logic Devices

Ratemeters

Features

1/Tau ratemeter

Scaling capabilities

Type 4X protection

Internal battery: 3V, lithium

3.4

Catalog Number Selection

Courier Series Battery Powered Ratemeter

Courier Series

Type

533 = Courier Series

Power

0 = Battery powered

533 0 0 404

Counter

0 = No option

1 = Extend temperature range

2 = Backlight option (24 Vdc required)

Product Selection

1/Tau LCD Ratemeter

Description

Battery powered

Catalog Number

53300404

Function

404 = Ratemeter

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-51

3.4

Logic Devices

Ratemeters

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Eclipse Series 1/8 DIN LED Ratemeter

Catalog Number Selection

Eclipse Series 1/8 DIN LED Ratemeter

Eclipse Series

Type

577 = Eclipse Series

Power

00 = DC power

01 = AC power

Product Selection

Eclipse Series 5-Digit LED Ratemeter

Description

9–30 Vdc

9–30 Vdc, alarms

9–30 Vdc, analog out

9–30 Vdc, alarms, analog out

9–30 Vdc, RS-485

9–30 Vdc, alarms, RS-485

9–30 Vdc, analog out, RS-485

9–30 Vdc, alarms, analog out, RS-485

85–265 Vac

85–265 Vac, alarms

85–265 Vac, analog out

85–265 Vac, alarms, analog out

85–265 Vac, RS-485

85–265 Vac, alarms, RS-485

85–265 Vac, analog out, RS-485

85–265 Vac, alarms, analog out, RS-485

Function

47 = Ratemeter

Catalog Number

57700470

57700471

57700472

57700473

57700474

57700475

57700476

57700477

57701470

57701471

57701472

57701473

57701474

57701475

57701476

57701477

Features

1/8 DIN cutout

Type 4X front panel protection

Front panel programming

577 00 47 1

Outputs

1 = Dual relay out

2 = Analog output (4–20 mA + 0–10V)

3 = Dual relay + analog output

4 = RS-485 communications

5 = Dual relay + RS-485 communications

6 = Analog output + RS-485 communications

7 = Dual relay, RS-485 communications + analog output

V9-T3-52

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Hour Meters

3.5

Product Overview

Hour Meters Selection Guide

Description

Panel cut-out size

Display type

Number of digits

Power supply

Timing method

Front panel protection

Resolution

T48 Series

Page V9-T3-54

45 x 45 mm (1/16 DIN)

Mechanical

7 for AC versions,

8 for DC versions

10–30 Vdc or

100–130 Vac

Synchronous motor

IP65

0.1 hour

6-T-3H Series

Page V9-T3-54

50.8 mm (2 in) round

Mechanical

6

115 Vac

Quartz

Type 4X

0.1 hour

E5-224 Series

Page V9-T3-55

22 x 45 mm (1/32 DIN)

LCD

8

Internal battery

Solid-state

IP65

0.1 second

E42 Series

Page V9-T3-55

52.3 mm (2.06 in) round OR

24 x 36.8 mm

LCD

6

12–60 Vdc or

48–230 Vac

Solid-state

No protection ratings

0.1 hour

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-53

3.5

Logic Devices

Hour Meters

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Electromechanical Hour Meters

Catalog Number Selection

Electromechanical Hour Meters

Hour Meters

Number of Digits

6 = 6 digits

7 = 7 digits

8 = 8 digits

Function

T = Time meter

Product Selection

Electromechanical Hour Meters

Description

1/16 DIN

10–30 Vdc, 1.89 x 1.89 in (48 x 48 mm)

100–130 Vac, 1.89 x 1.89 in (48 x 48 mm)

71.1 mm Round

115 Vac, 2.80 in (71.1 mm) round

10–80 Vdc, 2.80 in (71.1 mm) round

Accessories

DIN Rail Adapter

DIN Rail Adapter

Description

DIN rail adapter for DIN electromechanical hour meter

Option

65 = IP65 seal

3H = 3-hole mount

Catalog Number

8-T-65-4848PM-402

7-T-65-4848PM-406

6-T-3H-508RPM-406

6-T-3H-508RPM-402

Catalog Number

T4848DINADAPT

Features

1/16 DIN

High shock-resistance

Without reset

Data retention if power is lost

71.1 mm round

6-digit hour meter for round panel cut-out

Low cost

Waterproof

Type 4X protection

6 T – 3H 508R PM – 406

Size

508R = 50.8 mm round

4848 = 48 x 48 mm square

Mounting

PM = Panel mount

Voltage

402 = DC voltage

406 = AC voltage

V9-T3-54

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Hour Meters

3.5

Electronic LCD Hour Meters

Product Selection

Electronic LCD Hour Meters

LCD Hour Meters

Description

Battery Powered 1/32 DIN 8-Digit LCD

Hours/minutes, 0.94 x 1.89 in (24 x 48 mm)

Hours/minutes, 10–260V input, 0.94 x 1.89 in (24 x 48 mm)

Minutes/seconds, 0.94 x 1.89 in (24 x 48 mm)

Minutes/seconds, 10–260V input 0.94 x 1.89 in (24 x 48 mm)

AC/DC Powered Round LCD

Elapsed hour meter, 48–150 Vdc/100–230 Vac

Elapsed hour meter w/reset, 48–150 Vdc/100–230 Vac

Elapsed hour meter, 12–48 Vdc/20–60 Vac

AC/DC Powered Compact Rectangular LCD

Elapsed hour meter, 48–150 Vdc/100–230 Vac

Elapsed hour meter, w/reset, 48–150 Vdc/100–230 Vac

Elapsed hour meter, 12–48 Vdc/20–60 Vac

Catalog Number

E5-224-C0440

E5-224-C0448

E5-224-C0450

E5-224-C0458

E42DIR48230

E42DIR48230R

E42DIR1260

E42DI2448230

E42DI2448230R

E42DI241260

Features

Battery powered

Low price and high efficiency

Large 8-digit LCD display, height of the figures 0.31 in (8 mm)

Different time ranges from 0.1 second to 100,000 hours

Lifetime of the battery is approximately eight years

AC/DC powered

Solid-state hour meters

Record and display up to 99,999.9 hours, rollover and continue timing

EEPROM memory can retain data for 25+ years

Time accumulation indicated by flashing hourglass icon

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-55

3.6

Logic Devices

Totalizers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Product Overview

Totalizers Selection Guide

Description

Display type

Number of digits

Power supply

Mounting configuration(s)

Maximum counting speed

Count reset method(s)

Front panel protection

Electromechanical Micro

Page V9-T3-57

Mechanical

7

12 Vdc

Front panel

(13 x 30 mm cut-out)

25 Hz

IP65

Totalizers Selection Guide, continued

SE Series

Page V9-T3-57

Mechanical

6

12 or 24 Vdc, 120 or 240 Vac

Base mount, bottom mount, top mount, or front panel mount

10 Hz

E5-024-C Series

Page V9-T3-58

LCD

8

Internal battery

Front panel

22 x 45 mm (1/32 DIN)

12 kHz

Front panel or electronic, can be locked out

IP65

E5-x24-E Series

Page V9-T3-58

LED

6

10–30 Vdc

Front panel

22 x 45 mm (1/32 DIN)

20 kHz

Front panel or electronic, can be locked out

IP65

Description

Display type

Number of digits

Power supply

Mounting configuration(s)

Maximum counting speed

Count reset method(s)

Courier Series

Page V9-T3-59

LCD

8

Replaceable battery

Front panel

68 x 33 mm

10 kHz

Front panel or electronic, can be locked out

Type 4X

E5-496 Series

Page V9-T3-60

LED

6

10–30 Vdc or 90–260 Vac

Front panel

92 x 45 mm (1/8 DIN)

60 kHz

Front panel or electronic, can be locked out

IP65

Eclipse Series

Page V9-T3-60

LED

6

9–30 Vdc or 85–265 Vac

Front panel

92 x 45 mm (1/8 DIN)

8.2 kHz

Front panel or electronic, can be locked out

Type 4X Front panel protection

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

V9-T3-56

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Totalizers

3.6

Electromechanical Totalizers

Features

Micro display

Low power consumption; suitable for battery consumption

Small dimensions

Long service life

SE Series

Low-cost electromechanical counter

Multiple voltage ranges for almost any application

Compact with various mounting options

Catalog Number Selection

Electromechanical Totalizers

Totalizers

6 – Y – 41610 – 401 – SE

Number of Digits

6 = 6 digits

7 = 7 digits

Function

Y = Compact electromechanical totalizer

41610 = Bottom mount

41611 = Base mount

41612 = Top mount

41613 = Panel mount

Mounting Configuration

41622

= Special base mount

41623

= Special top mount

42613

= Snap-in mount

3013PM = 30 x 13 mm panel mount

Voltage

401 = 12 Vdc

402 = 24 Vdc

406 = 120 Vac

407 = 240 Vac

Product Selection

Micro Display Counter

Description

Micro display counter—12 Vdc

Catalog Number

7-Y-3013PM-401

SE Series Electromechanical Totalizers

Description

Catalog

Number

6-Digit Counter

Bottom mount sub-miniature 12 Vdc

Bottom mount sub-miniature 24 Vdc

Bottom mount sub-miniature 120 Vac

Bottom mount sub-miniature 240 Vac

Base mount sub-miniature 12 Vdc

Base mount sub-miniature 24 Vdc

Base mount sub-miniature 120 Vac

Base mount sub-miniature 240 Vac

Top mount sub-miniature 12 Vdc

Top mount sub-miniature 24 Vdc

Top mount sub-miniature 120 Vac

Top mount sub-miniature 240 Vac

Panel mount sub-miniature 12 Vdc

Panel mount sub-miniature 24 Vdc

6-Y-41610-401-SE

6-Y-41610-402-SE

6-Y-41610-406-SE

6-Y-41610-407-SE

6-Y-41611-401-SE

6-Y-41611-402-SE

6-Y-41611-406-SE

6-Y-41611-407-SE

6-Y-41612-401-SE

6-Y-41612-402-SE

6-Y-41612-406-SE

6-Y-41612-407-SE

6-Y-41613-401-SE

6-Y-41613-402-SE

Order

Number

41610401

41610402

41610406

41610407

41611401

41611402

41611406

41611407

41612401

41612402

41612406

41612407

41613401

41613402

Contact

Configuration

SE

= SE Series

Blank = Micro display counter

Description

6-Digit Counter, continued

Panel mount sub-miniature 120 Vac

Panel mount sub-miniature 240 Vac

Special base mount sub-miniature 12 Vdc

Special base mount sub-miniature 24 Vdc

Special base mount sub-miniature 120 Vac

Special base mount sub-miniature 240 Vac

Special top mount sub-miniature 12 Vdc

Special top mount sub-miniature 24 Vdc

Special top mount sub-miniature 120 Vac

Special top mount sub-miniature 240 Vac

Snap-in mount sub-miniature 12 Vdc

Snap-in mount sub-miniature 24 Vdc

Snap-in mount sub-miniature 120 Vac

Snap-in mount sub-miniature 240 Vac

Catalog

Number

6-Y-41613-406-SE

6-Y-41613-407-SE

6-Y-41622-401-SE

6-Y-41622-402-SE

6-Y-41622-406-SE

6-Y-41622-407-SE

6-Y-41623-401-SE

6-Y-41623-402-SE

6-Y-41623-406-SE

6-Y-41623-407-SE

6-Y-42613-401-SE

6-Y-42613-402-SE

6-Y-42613-406-SE

6-Y-42613-407-SE

Order

Number

41613406

41613407

41622401

41622402

41622406

41622407

41623401

41623402

41623406

41623407

42613401

42613402

42613406

42613407

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-57

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3.6

Logic Devices

Totalizers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Electronic 1/32 DIN Totalizers

Catalog Number Selection

Electronic 1/32 DIN Totalizers

Electronic Totalizers

Type

E5 = E5 Series

Product Selection

1/32 DIN LCD Totalizers

Description

Battery Powered 8-Digit LCD Totalizer

0.94 x 1.89 in (24 x 48 mm) LCD totalizer

10–260V input 0.94 x 1.89 in (24 x 48 mm) LCD totalizer

Count up/down 0.94 x 1.89 in (24 x 48 mm) LCD totalizer

DC Powered 6-Digit LED Totalizer

LED single channel totalizer, 10–30 Vdc power 0.94 x 1.89 in

(24 x 48 mm)

LED multifunction totalizer/timer/ratemeter, 10–30 Vdc power

0.94 x 1.89 in (24 x 48 mm)

LED double-function totalizer/timer/ratemeter, 10–30 Vdc power

0.94 x 1.89 in (24 x 48 mm)

LED totalizer with quadrature, 10–30 Vdc power 0.94 x 1.89 in

(24 x 48 mm)

E5-024-E0402

E5-424-E0402

E5-524-E0402

E5-024-E0432

Features

Battery powered LCD

Low price and high efficiency

Large 8-digit LCD display, height of the figures 0.31 in (8 mm)

Lifetime of the battery is approximately 8 years

DC Powered LED

Display counter adding and subtracting

Position display

Frequency counter/ratemeter

Timer

Supply voltage: 10–30 Vdc with reverse polarity protection

Polarity of inputs: programmable, NPN or PNP

E5 – 4 – 24 – E – 0 40 2

Function

0 = Totalizer

4 = Multi-function totalizer/ timer/ratemeter

5 = Double function totalizer/ timer/ratemeter

Size

24 = 24 x 48 mm

Catalog Number

E5-024-C0400

E5-024-C0408

E5-024-C0410

Display

C = LCD

E = LED

Presets

0 = 0

Option

40 = None

41 = Bi-directional

43 = Quadrature

Options

40 = Battery

41 = Battery with 10–260V input signal

43 = 10–30 Vdc

V9-T3-58

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Totalizers

3.6

Electronic Courier Series Battery Powered LCD Totalizers

Catalog Number Selection

Electronic Courier Series Battery Powered LCD Totalizers

Courier Series

533 00 400

Type

533 = Courier Series

Option

00 = None

01 = Ext. temperature range

02 = Backlight

Product Selection

Courier Series, 8-Digit LCD Totalizers

Description

Totalizer, battery

Add/subtract (10k Hz, PNP input) totalizer, battery

Add/subtract (20 Hz, NPN/contact input) totalizer, battery

Quadrature (10k Hz, PNP input) totalizer, battery

Totalizer/ratemeter, battery

Catalog Number

53300400

53300401

53300402

53300403

53300405

Features

8-digit totalizer

1/Tau ratemeter is an additional capability on the 53300405 only

Scaling capabilities

Remote reset terminal

Type 4X protection

Internal battery: 3V, lithium, replaceable battery

Function

400 = Totalizer

401 = Add/subtract (10 kHz, PNP input)

402 = Add/subtract (20 kHz, NPN/contact input)

403 = Quadrature

405 = Totalizer/ratemeter

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-59

3.6

Logic Devices

Totalizers

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Electronic 1/8 DIN LED Totalizers

Product Selection

Electronic 1/8 DIN LED Totalizers

1/8 DIN LED Totalizers

Description

LED Multifunction Counter/Timer/Ratemeter

90–260 Vac power 3.78 x 1.89 in (96 x 48 mm)

10–30 Vdc power 3.78 x 1.89 in (96 x 48 mm)

Eclipse Series LED Totalizer

9–30 Vdc power

85–265 Vac power

Analog out, 9–30 Vdc power

Analog out, 85–265 Vac power

RS-485 out, 9–30 Vdc power

RS-485 out, 85–265 Vac power

RS-485 out and analog out, 9–30 Vdc power

RS-485 out and analog out, 85–265 Vac power

V9-T3-60

Catalog Number

E5-496-E0401

E5-496-E0402

57700480

57701480

57700482

57701482

57700484

57701484

57700486

57701486

Features

LED Multifunction

Display counter adding and subtracting

Position display

Frequency counter/ratemeter

Display: 6-digit red, 7-segment LED display; 0.55 in (14 mm) high

Polarity of inputs: programmable, NPN or PNP for all inputs

Eclipse Series

1/8 DIN cutout

Type 4X front panel protection

Front panel programming

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Logic Devices

Encoders

3.7

Product Overview

Encoders Selection Guide

Description

Power supply

Output signal

Pulses per revolution

Maximum shaft speed

Mounting configuration(s)

Shaft size

Maximum axial loading

Quadrature output available

Cube

Page V9-T3-62

5–28 Vdc

NPN transistor

Up to 600

6000 RPM

Face or base mounted

3/8 in

10 lbs

Yes

Right-Angled

Page V9-T3-62

5–28 Vdc

NPN transistor

Up to 1,800

8000 RPM

Flange mounted

3/8 in

80 lbs

Yes

For our complete product offering, see Volume 7—Logic Control, Operator Interface and Connectivity Solutions, CA08100008E and

PG05400001E.

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

V9-T3-61

3.7

Logic Devices

Encoders

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

3

Shaft Encoders

Product Selection

Shaft Encoders

Cube Shaft Encoders

Description

Single Channel

60 pulses per revolution

100 pulses per revolution

120 pulses per revolution

600 pulses per revolution

Quadrature

60 pulses per revolution

100 pulses per revolution

120 pulses per revolution

600 pulses per revolution

Right-Angled Shaft Encoders, Size 20

Description

100 pulses per revolution

120 pulses per revolution

600 pulses per revolution

1000 pulses per revolution

1800 pulses per revolution

Catalog Number

38150060

38150100

38150120

38150600

38151060

38151100

38151120

38151600

Catalog Number

38159100

38159120

38159600

381591000

381591800

V9-T3-62

Features

Cube style

5–28 Vdc input power

Single channel and quadrature models

3/8 in (9.5 mm) double-ended shaft

Right-angled

5–28 Vdc input power

Quadrature output, two square waves

Flange mounting

3/8 in (9.5 mm) shaft diameter

Volume 9—OEM Product Guide CA08100011E—July 2012 www.eaton.com

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
