37” SNOW PLOW AND DOZER ELADE
MFG. NO. 1010
с
=
oy
=
of
A
=
QG
£2
tan
=
En
=
с
я
LL
=
«=
«т
e
aj
F
=
md
Cl.
=
Er
SEM, FORM- 177563
LI THE? IE. A,
1376
PACKING
The 42" snow plow and dozer comes packed complete in
one bundle.
INSTALLATION
Attach the push bar assembly to the blade using a king pit
and install a spring clip through the king pio. Flage the pivot
pin through the blade assembly bracket and push bar. Po-
sition the push bar under the tractor front axel and attach
it to the axel using two pins and spring clips. Attach the
spring end of the Lift rod to the push bar assembly and the
other end to the tractor Lift arm using two spring clips.
OPERATION
Alternate holes are provided to permit adjustment of the
shoe assemblies for raising or lowerisq the blade when
cleaning gravel doves or walks, When cleaning concrete it is
desirable to allow the blade to scrape the surface.
The angle of the blade 15 adjustable to permit plowing to
the left or right by moving pivot pio to the desired hole in
the blade mounting bracket.
&
1971 AND NEWER MODELS
DIRECTION ROD >
BRACKET ATTACHES HERE
. и
=. WHEEL WEIGHTS
E
TT CHAINS
236 |
When using this equipment is is recommended that chains
and wheel weights be installod on the tractor. Loose moutit-
ing of the chains will make them self-cleaning.
IT it is desirod to use a tiller or other attachment when the
blade iz mounted, the transport hook which is bolted to the
frame at the front of the tractor should be used. With the
blade haaked in the transport position, the lift arm can be
removed from the tractor. The lift can then be used Eo
raise or lower another attachment.
MODELS PRIOR TO
1971
ATTACH BLADE HITCH
HERE
Ref. Fart Oty.
No. No. Reg. Description
E 107047 1 42°" Blade Assembly
2 107045 | 1 Wear Plate
3 703004 | 6 Carriage Bolt, 3/8"-16 x 3/4"
4 720002 Ú Lack Washer, 5/87
5 717003 | 6 Hex Nue, Full, 3/8-16
Ú 107024 2 Shoe Assembly
7 702002 | 4 Carciage Bolt, 3/8 16 Xx 17
5 720002 | 4 Lock Washer, 3/8"
q 717003 4 Hex Nue, Full, 3709-16
10 1605601 | 1 Fivot Pin
| 11 1603602 | 1 King Pin
12 3161045 | 1 Spring Chp
15 1607911] 1 Push Gar Assembly
14 118053 | 2 Pin
15 106788 | 2 Hairpin Clip
16 8031007] 2 Collar
17 713006 | 2 Set Screw, 5/167-18 x 3/5"
18 171679 | 1 Rod Guide
14 171011 | 1 Spring
20 160823 | 1 Front Lift Rod
21 106788 | 2 Hairpin Clip
22 172432 | 1 Fuel Tank Cap (Winterized) |
23 177973 | 1 Transport Chain Assembly |
24 106719 | 1 Film, Simplicity
#5 103005 1 Model Mo. Plate
26 107142 | 1 Decal, Instructions
Ref. ty.
|; No. Part No. + Reg. Description
1 705009 | 1 Hex {apscrew,
1 2816 x 1-1/2"
2 154177 | 1 Spacer
3 716001 | | Plain Washer, 3/8"
4 720002 | 1 Lock Washer, 5/8”
1 5 717003 1 Hax Nut, Full, 27816 |
7 6 | 174438 | 1 Deflector
q Y 705002 § 2 Hex Capscrew,
1/4"-20 x 172"
4 8 | 720008 | 2 Lock Washer, 1/4"
9 9 717005 | 2 Hex Nut, 174.20
=
177273 Transport Chain |
From Previous Page
1
0
pt
a - 177045
Carb. Simeld
FILM SHIELD
Install the deflector as illustrated. If the unit is equip 170252
ped with lights the deflector is mounted using the same
hardware that secures the headlight,
‘5 DEFLECTOR
MOUNTS INSIDE
HOOD
