Amphenol Cable Glands and Cord Grips

Amphenol Cable Glands and Cord Grips
Amphenol Cable Glands and
Cord Grips
®
12-055-1
Amphenol
Table of Contents
Introduction
Amphenol® Cable Glands
Page Number
1
2-3
ATEX Approved Glands Featuring Elastometric Seals
EX-20
4-5
EX-25
6-7
EE-30
8-9
EX-35
10-11
EX-40
12-13
EX-45
14-15
EE-RG
16-17
ATEX Approved Glands Featuring Elastometric Seals for Flat Cable
EX-50
18-19
EX-55
20-21
ATEX Approved Barrier Glands
EX-60
22-23
EX-65
24-25
EX-70
26-27
EX-75 Stopper Box
28-29
Industrial Glands
CGA
30-31
CGSS
32-33
CGDS
34-35
CGU
36-37
Accessories
ARAdaptors & Reducers
38-39
Nylon Adaptors & Reducers
40-41
Insulated Adaptors
42-43
Mushroom Head Stopping Plugs
44-45
Nylon Mushroom Head Stopping Plugs
46-47
Type A & Type B Stopping Plugs
48-49
Breather Drain
50-51
Locknuts, Earth Tags, etc.
52
Entry Thread Reference Tables
53
Ingress Protection, Gland Weight Data
54
Amphenol®/Pyle® Cord Grips
55
Cord Grip Specifications
56-57
DB/DBM Group
58-59
DBZ Group
60-61
DBL/DBZL Group
62-63
DBA Group
64-65
DBF Group, Flared Nipples
66-67
DBZP Series
68-69
Grommets
70-71
Accessories
72-73
Addtional Amphenol® Industrial Products
Amphenol Sales Offices and Distributors Listing
74-75
76
For further information on your individual application requirements, contact:
Amphenol Corporation
Amphenol Industrial Operations
40-60 Delaware Avenue
Sidney, New York 13838-1395
Phone: 607-563-5011
Fax: 607-563-5351
View and download or print Amphenol catalogs on-line at: www.amphenol-industrial.com
Amphenol operates quality systems that are certified to ISO 9001:2000 by third party registrars.
For product specific questions regarding RoHS compliance, consult Amphenol Industrial Operations, or call the
RoHS Product Compliance and Technical Support line: 1-866-315-8559
Amphenol Industrial Operations
Amphenol® Cable Glands and Cord Grips
Amphenol Industrial offers more choices, more solutions, and more options than any other interconnect
manufacturer in the world. In addition to the broadest range of connector solutions in the market, we also offer an
extensive line of Explosion Proof and General Duty Cable Glands. We also carry a complete line of liquid tight strainrelief products in our Cord Grip line of performance cable seals. Our combination of Glands and Cord Grips makes
Amphenol Industrial the one stop supplier for all your connector and cable sealing solutions.
Cable Glands
Amphenol Industrial Operations, the worldwide leader
of explosion proof and hazardous environment
interconnects, introduces our broad range of
explosion proof and industrial cable glands. The new
Cable Gland product line is designed toperform in the
most demanding environments. Amphenol’s
complete line of EX Zone 1 and 2 rated cable glands
offers our customers great flexibility. In addition, we
have a complete line of general duty industrial
application cable glands suitable for armored and
unarmored cable.
• SIRA/ATEX certified to Exd/Exe (Class I, Div. I)
• CSA Approved
• IP66/68; Deluge; NEMA rated products
• Temperature Ranges from -40°F to +180°F
• Brass and Stainless Steel available.
pheno
l
Am
Amphenol Cable Glands are RoHS
Compliant.
E
U
C
HS
Ro
E
/2
002 / 95 /
Cord Grips
Whether you need a straight, 45°, or 90° strain relief,
Amphenol’s family of cord Grips has you covered.
Strong, lightweight aluminum components provide a
long lasting, reliable liquid tight solution. Amphenol
Industrial Cord Grips offer a complete line of strain
relief options that include gland nuts, mechanical
clamps and basketweave cable grips. UL and CSA
listed, our Cord Grips have been put to the test for
over 40 years.
• Tapered rubber grommets and seal
• Machined Components
• Male and female threads available
• Tapered conduit threads
pheno
l
Am
E
U
C
HS
Ro
E
/2
002 / 95 /
Amphenol Cord Grips are available
with RoHS Compliant options. Please
contact Amphenol Industrial Operations
for information.
1
Amphenol Cable Glands and Cord Grips
Amphenol Explosion Proof and Industrial Cable Glands
This section will provide you with information on Amphenol’s complete family of cable glands, and will assist you in
determining which of our glands will satisfy your specific need. If you have further questions, please contact our
factory or one of the Amphenol Industrial distributors listed in the back of this catalog.
Amphenol Industrial Operations, the recognized leader in explosion proof and hazardous environment interconnects,
offers a complete line of Industrial and Explosion Proof Glands. Whether part of an integrated connector solution, or
as part of a bulkhead feed through, Amphenol has the solution you are looking for. Our product range includes
general duty industrial cable glands meant to seal on unarmored cable, right up to our ATEX approved EX glands
capable of protecting the most rugged cable in your zone rated applications.
Our EX Approved Glands also provide a complete zone rated interconnect solution when used in conjunction with
our ATEX approved Star-Line EX explosion proof connector series. For additional information on the Star-Line EX
product, consult Amphenol catalog 12-054.
Features & Benefits
ATEX and CSA Certified: Approved to perform in the most hazardous environments.
Variety of Styles: Cable glands available to accommodate any cable type.
IP Ratings Included: Watertight seals allow for both indoor and outdoor applications.
Machined Components made from brass and stainless steel.
Complete Line of Accessories: Including locknuts, washers, and earth tags.
Entry Thread Flexibility: Both metric and NPT threads available on most styles.
Applications
• Oil and Gas Exploration Equipment
• Machine and Heavy Electronics
• Pharmaceutical Manufacturing Facilities
• Production Platforms
• Chemical and Paint Manufacturing Facilities
• Robotics and Welding Equipment
• Process Control Equipment
• Motors and Generators
2
Amphenol Cable Glands
Cable Gland Selection Guide
This table is designed to be a quick reference to the cable glands found in this publication.
Gland Type
Outer Seal
Inner Seal Lead Option
Armor Clamp
Certification
IP Rating
Page Number
ATEX/CSA Approved Glands with Elastomeric Seals
EX-20
✓
✓
✓
✓
Exd/Exe
Deluge, IP66, 68
NEMA, 4X
4
EX-25
✓
✓
✓
✓
Exd/Exe
(Not CSA)
IP66, IP67
6
EE-30
✓
✕
✓
✕
Exe
IP66
8
(Not CSA)
EX-35
✓
✕
✕
✕
Exd/Exe
IP66
IP68
NEMA 4X
10
EX-40
✓ x2
✕
✕
✕
Exd/Exe
IP66
IP68
NEMA 4X
12
EX-45
✓
✕
✕
✕
Exd/Exe
IP66
IP68
NEMA 4X
14
EE-RG
✓
✕
✕
✕
Exe
IP66
IP68
16
ATEX/CSA Approved Glands with Elastomeric Seals for Flat Cable
EX-50
Flat Cable
Flat Cable
✕
Braid
Exd/Exe
IP66
18
EX-55
Flat Cable
✕
✕
✕
Exd/Exe
IP68
20
ATEX Approved Compound Filled Barrier Glands
EX-60
EX-65
✓
Compound
✓
✓
Exd
Deluge, IP66, IP68
NEMA, 4X
22
Compound Compound
✓
✕
Exd
Deluge, IP66, IP68
24
NEMA, 4X
EX-70
✓
Compound
✓
✕
Exd
Deluge, IP66, IP68
26
NEMA, 4X
EX-75
✕
Compound
✕
✕
Exd
(stopper box)
Deluge, IP66, IP68
28
NEMA, 4X
Non Hazardous Industrial Glands
CGA
✕
✕
✕
✓
Industrial (BS6121)
IP30
30
CGSB
✓
✕
✕
✓
Industrial
IP66
32
CGDS
✓
✓
✓
✓
Industrial
IP67
34
CGU
✓
✕
✓
✕
Industrial
IP66, IP66
36
www.amphenol-industrial.com
3
ATEX/CSA Approved Glands with Elastomeric Seals
EX-20
EX-20 type glands provide a seal on the inner sheath, a seal on the outer sheath, an entry thread seal and a
universal armor clamp for armored cable. The armor clamp provides an electrical bond between the cable armor and
the gland. EX-20 glands can also be used to terminate unarmored or lead sheathed cables. EX-20 type glands
maintain Flameproof Exd and Increased Safety Exe methods of explosion protection; IP66, 68 to 25 meters and is
deluge resistant. An integral ‘O’ ring entry thread seal is fitted to metric versions as standard.
EXAMPLE PART NUMBER
EX-20
W
X
Y
R
YY
ZZ
[W]
-
[X] [Y] [R] [YY] [ZZ]
Gland material (B = Brass / S = Stainless Steel)
Seal Material (1 = Neoprene / 3 = Silicone)
Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
Reduced bore option
Gland size (Cable Range)
Entry thread
B
A
D
Sample: EX-20-B-1-0-R-20-M20
DESIGN STANDARD
EN50014:1998, EN50018:2000, EN50019:2000 & EN 50281-1-1:1998
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
CSA Exd IIC/Exe II 4X, Class 1, Zone 1
Sira 05ATEX1120X - Ex Notified Body No. 0518
Pending
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-20-B-1-0-R-20-M20 XX Sira 05ATEX1120X
II 2GD EExdIIC / EExe II (XX = Year Code)
APPLICATION
EExd Equipment
EX-20 type glands will only maintain Flameproof Exd integrity when used with cable that is substantially round and compact with extruded
bedding. The cable shall be deemed to be effectively filled. Ref: IEC60079-14:2002 Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use Type EX-20 Gland
IIC, IIB, IIA
NO
Any
Zone 1 or 2
YES
IIB, IIA
YES
Any
Zone 2
YES
IIB, IIA
YES
2 liters or less
Zone 1
YES
EExe Equipment
Gas Group II, Zones 1 and 2
Other Equipment
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66 and IP68 @ 25 meters, Enclosure Type 4X
Meets the requirements of DTS01 1991
OPERATING TEMPERATURES
Standard Seals -20°C to +85°C
Extended Seals - 60°C to +180°C (Silicone seals)
MATERIALS
Brass CZ121 (EX-20-B)
316 Stainless Steel (EX-20-S)
Inner and outer sheath material: Standard (EX-20-W-1) Neoprene, black. Option (EX-20-W-3) Silicone, white.
Reduced bore outer sheath seal (R) Silicone, red (EX-20-W-X-Y-R)
Entry thread seal: Nitrile is supplied with neoprene seal version. Silicone is supplied with silicone seal version
4
C
THREADS
SEALS
ISO Metric; NPT; NPS; ISO Pipe Thread
(BSP Taper, BSP Parallel)
PLATING
Extended operating temperature -60°C to +180°C,
halogen free versions:
Brass (EX-20-B-3); 316 Stainless Steel (EX-20-S-3)
Nickel (1); Tin (2); Zinc (3); Electroless
Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC)
Gland and accessory kits:
K1- includes gland, locknut, earthtag, nylon IP washer and PVC shroud
Gland
Size
Entry Threads
Entry
Thread
Length
Max
Max
Across Protrusion
Corners
Length
Cable Inner
Sheath [C]
Min
Metric
NPT/BSP
[B]
Gland Seal Range
Cable Outer Sheath [D]
Standard
Reduced (R)
Max
Min
Max
Min
Armor
Acceptance
Range
Shroud
Size
Max
[A]
16
M20
N1 or N2
16
28.0
78.0
3.4
8.4
9.0
13.5
6.7
10.3
0.15 - 1.25
L24
20s
M20
N1 or N2
16
28.0
78.0
7.2
11.7
11.5
16.0
9.4
12.5
0.15 - 1.25
L24
20
M20
N1 or N2
16
33.0
78.0
9.4
14.0
15.5
21.1
12.0
17.6
0.15 - 1.25
EL30
25
M25
N2 or N3
16
41.4
90.0
13.5
20.0
20.3
27.4
16.8
23.9
0.15 - 1.60
EL38
32
M32
N3 or N4
16
50.6
105.0
19.5
26.3
26.7
34.0
23.2
30.5
0.15 - 2.00
EL46
40
M40
N4 or N5
16
60.5
113.0
23
32.2
33.0
40.6
28.6
36.2
0.20 - 2.00
EL55
50s
M50
N5 or N6
16
71.5
125.0
28.1
38.2
39.4
46.7
34.8
42.4
0.30 - 2.50
EL65
50
M50
N6
16
71.5
125.0
33.1
44.1
45.7
53.2
41.1
48.5
0.30 - 2.50
EL65
63s
M63
N6 or N7
19
88.0
125.0
39.2
50.1
52.1
59.5
47.5
54.8
0.30 - 2.50
EL80
63
M63
N7
19
88.0
125.0
46.7
56.0
58.4
65.8
53.8
61.2
0.30 - 2.50
EL80
75s
M75
N7 or N8
19
99.0
131.0
52.1
62.0
64.8
72.2
60.2
68.0
0.30 - 2.50
EL90
75
M75
N8
19
99.0
131.0
58.0
68.0
71.1
78.0
66.5
73.4
0.30 - 2.50
EL90
80
M80 x 2
N8 or N9
25
115.2
170.0
62.2
72.0
77.0
84.0
-
-
0.45 - 3.15
L104
80H
M80 x 2
N8 or N9
25
115.2
170.0
62.2
72.0
79.6
90.0
-
-
0.45 - 3.15
L104
85
M85 x 2
N8 or N9
25
115.2
170.0
69.0
78.0
79.6
90.0
75.0
85.4
0.45 - 3.15
L104
90
M90 x 2
N9 or N10
25
125.7
170.0
74.0
84.0
88.0
96.0
-
-
0.45 - 3.15
L114
90H
M90 x 2
N9 or N10
25
125.7
170.0
74.0
84.0
92.0
102.0
-
-
0.45 - 3.15
L114
100
M100 x 2
N9 or N10
25
125.7
170.0
82.0
90.0
92.0
102.0
87.4
97.4
0.45 - 3.15
L114
All Dimensions are in millimeters
NOTES:
• NPT entry thread reference details on page 53.
•
Gland Size does not necessarily equate to the entry thread size.
•
Integral entry thread seal option is not available for glands with tapered entry threads. IP washers can be supplied if required.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
Where EX-20 type glands are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth circuit of the
system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
•
When used to terminate unarmored cable, the gland is suitable only for fixed installations. The cable must be clamped near the gland to
prevent pulling and twisting.
5
ATEX/CSA Approved Glands with Elastomeric Seals
EX-25
EX-25 type glands provide a seal on the inner sheath, a seal on the outer sheath and an armor specific clamp for
armored cable. The armor clamp provides an electrical bond between the cable armor and the gland. EX-25 type
connectors can be used to terminate lead sheath cables. EX-25 type glands maintain Flameproof Exd and
Increased Safety Exe methods of explosion protection and IP66, IP67.
EXAMPLE PART NUMBER
EX-25*
*
W
X
Y
R
YY
ZZ
[W] [X] [Y] [R] [YY] [ZZ]
- Armor Types (W = SWA / X = SWB / Z = STA)
- Gland material (B = Brass / S = Stainless Steel)
- Seal Material (1 = Neoprene / 3 = Silicone / 4 = No Seal)
- Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
- Reduced bore option
- Gland size (Cable Range)
- Entry Thread
B
A
D
C
Sample: EX-25-W-B-1-0-R-20-M20
DESIGN STANDARD
EN50014:1998, EN50018:2000, EN50019:2000 and EN 50281-1-1:1998
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
SIRA 05ATEX1122X - Ex Notified Body No. 0518
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-25W-B-1-0-R-20-M20 XX SIRA 05ATEX1122X
II 2GD IP67 EExdIIC / EExe II (XX = Year Code)
APPLICATION
EExd Equipment
EX-25 type glands will only maintain Flameproof Exd integrity when used with cable that is substantially round and compact with extruded
bedding. The cable shall be deemed to be effectively filled. Ref: IEC60079-14:2002 Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use Type EX-25 Gland
IIC, IIB, IIA
NO
Any
Zone 1 or 2
YES
IIB, IIA
YES
Any
Zone 2
YES
IIB, IIA
YES
2 litres or less
Zone 1
YES
EExe Equipment
Gas Group II, Zones 1 and 2
Other Equipment
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66 and IP67
OPERATING TEMPERATURES
Standard Seals -20°C to +80°C
Silicone Seals - 60°C to +180°C
VARIATIONS
Omission of outer seal:
Brass (EX-25*-B-4); 316 Stainless Steel (EX-25-*-S-4)
MATERIALS
Brass CZ121 (EX-25-*-B)
316 Stainless Steel (EX-25-*-S)
6
SEALS
Extended operating temperature -60°C to +180°C, halogen free versions:
Brass (EX-25-B-3); 316 Stainless Steel (EX-25-S-3)
THREADS
ISO Metric; NPT; NPS; ISO Pipe Thread
(BSP Taper, BSP Parallel)
CLAMPS
PLATING
SWA steel wire armor (EX-25-W)
SWB woven steel wire armor (EX-25-X)
STA steel tape armor (EX-25-Z)
Nickel (1); Tin (2); Zinc (3); Electroless
Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC); PCP (EX-PCP); Low Smoke Zero Halogen (EX-LSH)
Gland and accessory kits:
K2 - includes gland, locknut, earthtag, fibre IP washer and PVC shroud
K3 - includes gland, locknut, earthtag, nylon IP washer and PCP shroud
K4 - includes brass gland, brass locknut, brass earthtag, IP washer and zero halogen shroud
Gland
Size
Entry Threads
Metric
Entry
Max
Max
Thread Across Protrusion
Length Corners
Length
[B]
[A]
Cable Inner
Sheath [C]
Min
Max
Gland Seal Range
Cable Outer Sheath [D]
Standard
Reduced (R)
Min
Max
Min
Armour Acceptance
Range
Shroud
Size
Max
W
NPT/BSP
XZ
16
M20
N1 or N2
16
26.5
58.0
4.0
8.4
8.4
13.5
4.9
10.0
0.90
0.15-0.35
L24
20s
M20
N1 or N2
16
26.5
58.0
8.0
11.7
11.5
16.0
9.4
12.5
0.90-1.25
0.15-0.35
L24
20
M20
N1 or N2
16
33.0
58.0
6.7 *
14.0
15.5
21.1
12.0
17.6
0.90-1.25
0.15-0.50
L30
25
M25
N2 or N3
16
41.4
58.0
13.0
20.0
20.3
27.4
16.8
23.9
1.25-1.60
0.15-0.50
L38
32
M32
N3 or N4
16
50.6
65.0
19.0
26.3
26.7
34.0
23.2
30.5
1.60-2.00
0.15-0.55
L46
40
M40
N4 or N5
16
60.5
72.0
25.0
32.2
33.0
40.6
28.6
36.2
1.60-2.00
0.20-0.60
L55
50s
M50
N5 or N6
16
71.5
73.0
31.5
38.2
39.4
46.7
34.8
42.4
2.00-2.50
0.20-0.60
L65
50
M50
N6
16
71.5
73.0
36.5
44.1
45.7
53.2
41.1
48.5
2.00-2.50
0.30-0.80
L65
63s
M63
N6 or N7
19
88.0
76.0
42.5
50.1
52.1
59.5
47.5
54.8
2.50
0.30-0.80
L80
63
M63
N7
19
88.0
76.0
49.5
56.0
58.4
65.8
53.8
61.2
2.50
0.30-0.80
L80
75s
M75
N7 or N8
19
99.0
82.0
54.5
62.0
64.8
72.2
60.2
68.0
2.50
0.30-1.00
L90
75
M75
N8
19
99.0
82.0
60.5
68.0
71.1
78.0
66.5
73.4
2.50
0.30-1.00
L90
80
M80 x 2
N8 or N9
25
115.2
110.0
62.2
72.0
77.0
84.0
-
-
3.15
0.45-1.00
L104
80H
M80 x 2
N8 or N9
25
115.2
110.0
62.2
72.0
79.6
90.0
-
-
3.15
0.45-1.00
L104
85
M85 x 2
N8 or N9
25
115.2
110.0
69.0
78.0
79.6
90.0
75.0
85.4
3.15
0.45-1.00
L104
90
M90 x 2
N9 or N10
25
125.7
110.0
74.0
84.0
88.0
96.0
-
-
3.15
0.45-1.00
L114
90H
M90 x 2
N9 or N10
25
125.7
110.0
74.0
84.0
92.0
102.0
-
-
3.15
0.45-1.00
L114
100
M100 x 2
N9 or N10
25
125.7
110.0
82.0
90.0
92.0
102.0
87.4
97.4
3.15
0.45-1.00
L114
All Dimensions are in Millimeters
NOTES:
* EX-25 gland size 20, the silicone inner seal only seals to a minimum of 11.0mm and NOT 6.7mm.
• NPT entry thread reference details on page 53.
• Gland Size does not necessarily equate to the entry thread size.
• "W" refers to the wire diameter in a steel wire armored cable.
• "XZ" refers to the wire diameter in a woven steel wire armored cable or the tape thickness in a steel tape armored cable.
• Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
• Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
• For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
• Where EX-25 type glands are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth circuit of the
system.
• The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
• Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
7
ATEX/CSA Approved Glands with Elastomeric Seals
EE-30
EE-30 type glands provide a seal on the outer sheath and an armor specific clamp for armored cable. The armor
clamp provides an electrical bond between the cable armor and the gland. EE-30 type glands maintain Increased
Safety Exe methods of explosion protection and IP66.
EXAMPLE PART NUMBER
EE-30*
*
W
X
Y
R
YY
ZZ
[W] [X] [Y] [R] [YY] [ZZ]
- Armor Type (W = SWA / X = SWB / Z = STA)
- Gland material (B = Brass / S = Stainless Steel)
- Seal Material (1 = Neoprene / 3 = Silicone)
- Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
- Reduced bore option
- Gland size (Cablle Range)
- Entry thread
B
A
D
C
Sample: EE-30W-B-1-0-R-20-M20
DESIGN STANDARD
EN 50014:1998, EN 50019:2000 and EN 50281-1-1:1998
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exe II
SIRA 05ATEX1122X - Ex Notified Body No. 0518
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EE-30W-B-1-0-R-20-M20 XX SIRA 05ATEX1122X
II 2GD IP66 EExe II ( XX = Year Code)
APPLICATION
EExe Equipment
Gas Group II, Zones 1 and 2
Other Equipment
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66
OPERATING TEMPERATURES
Standard Seals -20°C to +80°C
Silicone Seals - 60°C to +180°C
MATERIALS
Brass CZ121 (EE-30*-B)
316 Stainless Steel (EE-30*-S)
SEALS
Extended operating temperature -60°C to +180°C, halogen free versions:
Brass (EE-30*-B-3); 316 Stainless Steel (EE-30*-S-3)
THREADS
ISO Metric; NPT; NPS; ISO Pipe Thread
(BSP Taper, BSP Parallel)
CLAMPS
PLATING
SWA steel wire armor (EE-30-W)
SWB woven steel wire armor (EE-30-X)
STA steel tape armor (EE-30-Z)
8
Nickel (1); Tin (2); Zinc (3); Electroless
Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC); PCP (EX-PCP); Low Smoke Zero Halogen (EX-LSH)
Gland and accessory kits:
K1 - includes gland, locknut, earthtag, nylon IP washer and PVC shroud
K4 - includes brass gland, brass locknut, brass earthtag, IP washer and zero halogen shroud
Gland
Size
Entry Threads
Entry
Max
Max
Thread Across Protrusion
Length Corners
Length
[B]
[A]
Gland Seal Range
Cable Inner
Sheath [C]
Min
Max
Cable Outer Sheath [D]
Standard
Reduced (R)
Min
Max
Min
Armour Acceptance
Range
Max
W
Metric
Shroud
Size
XZ
NPT/BSP
16
M20
N1 or N2
10
26.5
54.0
-
11.7
9.0
13.5
6.7
10.3
0.90-1.25
0.15-0.35
L24
20s
M20
N1 or N2
10
26.5
54.0
-
11.7
11.5
16.0
9.4
12.5
0.90-1.25
0.15-0.35
L24
20
M20
N1 or N2
10
33.0
54.0
-
14.0
15.5
21.0
12.0
17.6
0.90-1.25
0.15-0.50
L30
25
M25
N2 or N3
10
41.4
54.0
-
20.0
20.3
27.4
16.8
23.9
1.25-1.60
0.15-0.50
L38
32
M32
N3 or N4
10
50.6
60.0
-
26.3
26.7
34.0
23.2
30.5
1.60-2.00
0.15-0.55
L46
40
M40
N4 or N5
15
60.5
67.0
-
32.2
33.0
40.6
28.6
36.2
1.60-2.00
0.20-0.60
L55
50s
M50
N5 or N6
15
71.5
67.0
-
38.2
39.4
46.7
34.8
42.4
2.00-2.50
0.20-0.60
L65
50
M50
N6
15
71.5
67.0
-
44.1
45.7
53.2
41.1
48.5
2.00-2.50
0.30-0.80
L65
63s
M63
N6 or N7
15
88.0
69.0
-
50.1
52.1
59.5
47.5
54.8
2.50
0.30-0.80
L80
63
M63
N7
15
88.0
69.0
-
56.0
58.4
65.8
53.8
61.2
2.50
0.30-0.80
L80
75s
M75
N7 or N8
15
99.0
77.0
-
62.0
64.8
72.2
60.2
68.0
2.50
0.30-1.00
L90
75
M75
N8
15
99.0
77.0
-
68.0
71.1
78.0
66.5
73.4
2.50
0.30-1.00
L90
80
M80 x 2
N8 or N9
20
115.2
104.0
-
72.0
77.0
84.0
-
-
3.15
0.45-1.00
L104
80H
M80 x 2
N8 or N9
20
115.2
104.0
-
72.0
79.6
90.0
-
-
3.15
0.45-1.00
L104
85
M85 x 2
N8 or N9
20
115.2
104.0
-
78.0
79.6
90.0
75.0
85.4
3.15
0.45-1.00
L104
90
M90 x 2
N9 or N10
20
125.7
104.0
-
84.0
88.0
96.0
-
-
3.15
0.45-1.00
L114
90H
M90 x 2
N9 or N10
20
125.7
104.0
-
84.0
92.0
102.0
-
-
3.15
0.45-1.00
L114
100
M100 x 2
N9 or N10
20
125.7
104.0
-
90.0
92.0
102.0
87.4
97.4
3.15
0.45-1.00
L114
All Dimensions are in Millimeters
NOTES:
• NPT entry thread reference details on page 53.
•
Gland Size does not necessarily equate to the entry thread size.
•
"W" refers to the wire diameter in a steel wire armored cable.
•
"XZ" refers to the wire diameter in a woven steel wire armored cable or the tape thickness in a steel tape armored cable.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
Where EX-30 type glands are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth circuit of
the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
9
ATEX/CSA Approved Glands with Elastomeric Seals
EX-35
EX-35 type glands provide a single pull resistant seal on the outer sheath of unarmoured cable. EX-35 type
glands maintain Flameproof Exd and Increased Safety Exe methods of explosion protection and IP66, IP68 to
25 meters. Integral O-Ring entry thread seal, as illustrated, is provided as standard on metric versions.
EXAMPLE PART NUMBER
EX-35
W
X
Y
YY
ZZ
[W]
-
[X] [Y] [YY] [ZZ]
Gland material (B = Brass / S = Stainless Steel)
Seal Material (1 = Neoprene / 3 = Silicone)
Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
Gland size (Cable Range)
Entry thread
B
A
D
Sample: EX-35-B-1-0-20-M20
DESIGN STANDARD
EN50014:1998, EN50018:2000, EN50019:2000 and EN 50281-1-1:1998
CERTIFICATION.
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
CSA Exd IIC/Exe II 4X, Class 1, Zone 1
SIRA 05ATEX1123X - Ex Notified Body No. 0518
Pending
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-35-B-1-0-20-M20 XX SIRA 05ATEX1123X
II 2GD IP68 EExdIIC / EExe II (XX = Year Code)
APPLICATION
EExd Equipment
EX-35 type glands will only maintain Flameproof Exd integrity when used with cable that is substantially round and compact with extruded
bedding. The cable shall be deemed to be effectively filled. Ref: IEC60079-14:2002 Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use EX-35 Gland
IIC, IIB, IIA
NO
2 liters or less
Zone 1 or 2
YES
IIB, IIA
YES
Any
Zone 2
YES
IIB, IIA
YES
2 liters or less
Zone 1
YES
EExe Equipment
Gas Group II, Zones 1 and 2
Other Equipment
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66 and IP68 @ 25 meters, Enclosure Type 4X
OPERATING TEMPERATURES
Standard Seals -20°C to +80°C
Silicone Seals - 60°C to +180°C
MATERIALS
Brass CZ121 (EX-35-B)
316 Stainless Steel (EX-35-S)
Outer sheath seal material:
Standard (EX-35-W-1) Neoprene, black. Option (EX-35-W-3) Silicone, white.
Integral entry thread seal: Nitrile is supplied with neoprene outer seal version. Silicone is supplied with silicone outer seal version.
10
THREADS
SEALS
PLATING
ISO Metric; NPT; NPS; ISO Pipe
Thread (BSP Taper, BSP Parallel)
Extended operating temperature -60°C to +180°C, halogen free
versions:
Brass (EX-35-B-3); 316 Stainless Steel (EX-35-S-3)
Nickel (1); Tin (2); Zinc (3);
Electroless Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-SPVC); PCP (EX-SPCP); Low Smoke Zero Halogen (EX-LSH)
Gland and accessory kits:
K2 - includes gland, locknut, fiber IP washer and PVC shroud
K3- includes gland, locknut, nylon IP washer and PCP shroud
Gland Size
Entry Threads
Entry Thread
Length
Max Across
Corners
Max
Protrusion
Length
Gland Seal Rance
Shroud Size
Cable Outer/Lead Sheath
[B]
[A]
Min
Max
N1 or N2
16
28.0
33.0
4.0
8.4
L24
M20
N1 or N2
16
M20
N1 or N2
16
28.0
33.0
7.2
11.7
L24
33.0
33.0
9.6
14.0
L30
25
M25
N2 or N3
16
41.4
33.0
13.5
20.0
L38
32
M32
40
M40
N3 or N4
16
50.6
33.0
19.5
26.3
L46
N4 or N5
16
60.5
37.0
23.0
32.2
L55
50s
M50
N5 or N6
16
71.5
37.0
28.2
38.2
L65
50
M50
N6
16
71.5
37.0
33.2
44.1
L65
63s
M63
N6 or N7
19
88.0
37.0
39.3
50.1
L80
63
M63
N7
19
88.0
37.0
46.7
56.0
L80
75s
M75
N7 or N8
19
99.0
37.0
52.3
62.0
L90
75
M75
N8
19
99.0
37.0
58.1
68.0
L90
80
M80 x 2
N8 or N9
25
115.2
50.0
62.3
72.0
L104
85
M85 x 2
N8 or N9
25
115.2
50.0
69.1
78.0
L104
Metric
NPT/BSP
16
M20
20s
20
90
M90 x 2
N9 or N10
25
125.7
50.0
74.1
84.0
L114
100
M100 x 2
N9 or N10
25
125.7
50.0
82.1
90.0
L114
All Dimensions are in Millimeters
NOTES:
• NPT entry thread reference details on page 53.
•
Suitable only for fixed installations. The cable must be clamped near the gland to prevent pulling and twisting.
•
Gland Size does not necessarily equate to the entry thread size.
•
Integral entry thread seal option is not available for glands with tapered entry threads. IP washers can be supplied if required.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
Where EX-35 type glands are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth circuit
of the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
11
ATEX/CSA Approved Glands with Elastomeric Seals
EX-40
EX-40 type glands provide two pull resistant seals on the outer sheath of any cable. EX-40 type glands maintain
Flameproof Exd and Increased Safety Exe methods of explosion protection and IP66, IP68 to 25 meters. An
integral O-Ring entry thread seal, as illustrated, is provided as standard on metric versions.
EXAMPLE PART NUMBER
EX-40
W
X
Y
YY
ZZ
[W]
-
[X] [Y] [YY] [ZZ]
Gland material (B = Brass / S = Stainless Steel)
Seal Material (1 = Neoprene / 3 = Silicone)
Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
Gland size (Cable Range)
Entry thread
A
D
Sample: EX-40-B-1-0-20-M20
B
DESIGN STANDARD
EN50014:1998, EN50018:2000, EN50019:2000 and EN 50281-1-1:1998
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
CSA Exd IIC/Exe II 4X, Class 1, Zone 1
SIRA 05ATEX1123X - Ex Notified Body No. 0518
Pending
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-40-B-1-0-20-M20 XX SIRA 05ATEX1123X
II 2GD IP68 EExdIIC / EExe II (XX = Year Code)
APPLICATION
EExd Equipment
EX-40 type glands will only maintain Flameproof Exd integrity when used with cable that is substantially round and compact with extruded
bedding. The cable shall be deemed to be effectively filled. Ref: IEC60079-14:2002 Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use EX-40 Gland
IIC, IIB, IIA
NO
Any
Zone 1 or 2
YES
IIB, IIA
YES
Any
Zone 2
YES
IIB, IIA
YES
2 litres or less
Zone 1
YES
EExe Equipment
Gas Group II, Zones 1 and 2
Other Equipment
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66 and IP68 @ 25 meters, Enclosure Type 4X
OPERATING TEMPERATURES
Standard Seals -20°C to +80°C
Silicone Seals - 60°C to +180°C
MATERIALS
Brass CZ121 (EX-40-B)
316 Stainless Steel (EX-40-S)
Outer sheath seal material: Standard (EX-40-W-1) Neoprene, black. Option (EX-40-W-3) Silicone, white
Integral entry thread seal: Nitrile is supplied with neoprene outer seal version. Silicone is supplied with silicone outer seal version.
12
THREADS
SEALS
ISO Metric; NPT; NPS; ISO Pipe Thread
(BSP Taper, BSP Parallel)
PLATING
Extended operating temperature -60°C to +180°C,
halogen free versions:
Brass (EX-40-B-3); 316 Stainless Steel (EX-40-S-3)
Nickel (1); Tin (2); Zinc (3); Electroless
Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC); PCP (EX-PCP); Low Smoke Zero Halogen (EX-LSH)
Gland Size
Entry Threads
Entry Thread
Length
Max Across
Corners
[B]
[A]
N1 or N2
16
28.0
M20
N1 or N2
16
M20
N1 or N2
16
Max
Protrusion
Length
Gland Seal Rance
Shroud Size
Cable Outer/Lead Sheath
Min
Max
66.0
4.0
8.4
L24
28.0
66.0
7.2
11.7
L24
29.7
66.0
9.6
14.0
L27
Metric
NPT/BSP
16
M20
20s
20
25
M25
N2 or N3
16
39.6
66.0
13.5
20.0
L36
32
M32
N3 or N4
16
45.1
66.0
19.5
26.3
L41
40
M40
N4 or N5
16
55.9
74.0
23.0
32.2
L51
50s
M50
N5 or N6
16
71.5
74.0
28.2
38.2
L65
50
M50
N6
16
71.5
74.0
33.2
44.1
L65
63s
M63
N6 or N7
19
88.0
74.0
39.3
50.1
L80
63
M63
N7
19
88.0
74.0
46.7
56.0
L80
75s
M75
N7 or N8
19
99.0
74.0
52.3
62.0
L90
75
M75
N8
19
99.0
74.0
58.1
68.0
L90
80
M80 x 2
N8 or N9
25
115.2
100.0
62.3
72.0
L104
85
M85 x 2
N8 or N9
25
115.2
100.0
69.1
78.0
L104
90
M90 x 2
N9 or N10
25
125.7
100.0
74.1
84.0
L114
100
M100 x 2
N9 or N10
25
125.7
100.0
82.1
90.0
L114
All Dimensions are in Millimeters
NOTES:
• NPT entry thread reference details on page 53.
•
Suitable only for fixed installations. The cable must be clamped near the gland to prevent pulling and twisting.
•
Gland Size does not necessarily equate to the entry thread size.
•
Integral entry thread seal option is not available for glands with tapered entry threads. IP washers can be supplied if required.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
Where EX-35 type glands are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth circuit
of the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
13
.
ATEX/CSA Approved Glands with Elastometric Seals
EX-45
EX-45 type glands provide a seal on the outer sheath of unarmoured cable and a conduit connection thread. EX40-M type glands provide a male thread for connection and EX-40-F type glands provide a female thread for
connection. EX-45 type glands maintain Flameproof Exd and Increased Safety Exe methods of explosion
protection and IP66, IP68 to 25 metres. An ‘O’ ring IP entry thread seal is fitted as standard.
EXAMPLE PART NUMBER
EX-45
A
W
X
Y
Z
YY
ZZ
[A]
-
[W] [X] [Y] [YY] [ZZ]
M = Male Connector / F = Female Connector
Gland material (B = Brass / S = Stainless Steel)
Seal Material (1 = Neoprene / 3 = Silicone)
Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
Connection Thread
Gland size (Cable Range)
Entry thread
B
A
D
B
A
Sample: EX-45-F-B-1-0-M20-20-M20
DESIGN STANDARD
EN50014:1998, EN50018:2000, EN50019:2000 and EN 50281-1-1:1998
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
CSA Exd IIC/Exe II 4X, Class 1, Zone 1
SIRA 05ATEX1123X - Ex Notified Body No. 0518
Pending
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-45-F-B-1-0-M20-20-M20 XX SIRA 05ATEX1123X
II 2GD IP68 EExdIIC / EExe II (XX = Year Code)
APPLICATION
EExd Equipment
EX-45 type glands will only maintain Flameproof Exd integrity when used with cable that is substantially round and compact with extruded
bedding. The cable shall be deemed to be effectively filled. Ref: IEC60079-14:2002 Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use EX-45 Gland
IIC, IIB, IIA
NO
Any
Zone 1 or 2
YES
IIB, IIA
YES
Any
Zone 2
YES
IIB, IIA
YES
2 litres or less
Zone 1
YES
EExe Equipment
Gas Group II, Zones 1 and 2
Other Equipment
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66 and IP68 @ 25 meters, Enclosure Type 4X
OPERATING TEMPERATURES
Standard Seals -20°C to +80°C
Silicone Seals - 60°C to +180°C
MATERIALS
Brass CZ121 (EX-45-A-B)
316 Stainless Steel (EX-45-A-S)
Outer sheath seal material: Standard (EX-45-A-W-1) Neoprene, black. Option (EX-45-A-W-3) Silicone, white
Integral entry thread seal: Nitrile is supplied with neoprene outer seal version. Silicone is supplied with silicone outer seal version.
14
D
THREADS
SEALS
ISO Metric; NPT; NPS; ISO Pipe Thread
(BSP Taper, BSP Parallel); PG
PLATING
Extended operating temperature -60°C to +180°C,
halogen free versions:
Brass (EX-45-A-B-3); 316 Stainless Steel
(EX-45-A-S-3)
Nickel (1); Tin (2); Zinc (3); Electroless
Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Gland Size
Entry Threads
Entry Thread
Length
Max Across
Corners
Gland Seal Rance
Conduit Connector
Cable Outer Sheath [D]
[B]
Metric
[A]
Min
Max
NPT/BSP
NPT
ISO
16
M20
N1 or N2
16
28.0
4.0
8.4
N1 or N2
M20
20s
M20
N1 or N2
16
28.0
7.2
11.7
N1 or N2
M20
20
M20
N1 or N2
16
33.0
9.6
14.0
N1 or N2
M20
25
M25
N2 or N3
16
41.4
13.5
20.0
N2 or N3
M25
32
M32
N3 or N4
16
50.6
19.5
26.3
N3 or N4
M32
40
M40
N4 or N5
16
60.5
23.0
32.2
N4 or N5
M40
50s
M50
N5 or N6
16
71.5
28.2
38.2
N5 or N6
M50
50
M50
N6
16
71.5
33.2
44.1
N6
M50
63s
M63
N6or N7
19
88.0
39.3
50.1
N6or N7
M63
63
M63
N7
19
88.0
46.7
56.0
N7
M63
75s
M75
N7 or N9
19
99.0
52.3
62.0
N7 or N9
M75
75
M75
N9
19
99.0
58.1
68.0
N9
M75
All Dimensions are in Millimeters
NOTES:
• Suitable only for fixed installations. The cable must be clamped near the gland to prevent pulling and twisting.
•
Gland Size does not necessarily equate to the entry thread size.
•
Integral entry thread seal option is not available for glands with tapered entry threads. IP washers can be supplied if required.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
Where EX-35 type glands are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth circuit
of the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
•
Other conduit connection threads eg PG, BSP are available upon request.
15
ATEX/CSA Approved Glands with Elastometric Seals
EE-RG
EE-RG type glands provide a seal on the outer sheath of unarmoured cable. EE-RG type glands maintain
Increased Safety Exe method of explosion protection and IP66, IP68.
EXAMPLE PART NUMBER
EE-RG[X]-[ZZ]
X - Material (1 = Black Polyamide 6 / 2 = Blue Polyamide 6 / 3 =
Grey Polyamide 6)
ZZ - Entry Thread
EE-RG1-M20
DESIGN STANDARD
EN50014:1997 and EN50019:2000
CERTIFICATION
ATEX II 2 GD, E Exe II
CERTIFICATE
SIRA 00ATEX 1072 - Ex Notified Body No. 0518
GLAND MARKING
Example:
SIRA 00ATEX1072X EB (Cable Range) II2GD EExeII
For industrial versions the hazardous area information is omitted
APPLICATION
Exe Equipment
Gas Group II, Zones 1 and 2
INGRESS PROTECTION
IP66 without a sealing washer
IP68 with a sealing washer
OPERATING TEMPERATURES
Sizes M25 and below: -20°C to +60°C
Sizes above M25: -10°C to +60°C
MATERIALS
Standard (EX-RG1) Black Polyamide 6
Option (EE-RG2) Blue Polyamide 6
Industrial, Non Ex Versions: Grey Polyamide 6 (EE-RG3)
Note: Polyamide 6 is self extinguishing, flame retardant and halogen free
Outer Seath seal material: Santoprene, black
THREADS
ISO Metric
ACCESSORIES
Locknut - Nylon (EX-NLN); Brass (EX-BLN)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
16
Gland Size
Entry
Thread
Length
Max
Across
Corners
Metric
Gland Seal Range
Cable Outer Sheath
Min
Max
6.0
-
9
16.5
3.5
M16
9
20.9
5.0
8.0
-
9
24.2
6.0
10.0
M20
10
26.4
8.0
13.5
-
10
28.6
10.0
15.0
M25
11
35.2
13.0
19.0
M32
12
45.1
18.0
25.0
M40
14
57.2
24.0
32.0
M50
16
64.9
29.0
38.0
M63
16
71.5
36.0
44.0
All Dimensions are in Millimeters
NOTES:
•
Suitable only for fixed installations. The cable must be clamped near the gland to prevent pulling and twisting
•
Gland sizes M25 and above shall not be used for applications where there is a "high" risk of mechanical damage
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full
17
ATEX/CSA Approved Glands with Elastometric Seals for Flat Cable
EX-50
EX-50 type glands provide pull resistant seals on the inner and outer sheath and a braid armor clamp. The armor
clamp provides an electrical bond between the cable armor and the gland. EX-50 type glands maintain
Flameproof Exd and Increased Safety Exe methods of explosion protection and IP66.
EXAMPLE PART NUMBER
EX-50 [W] [Y] [YY] [ZZ]
W - Gland Material (B = Brass / S = Stainless Steel)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
YY - Gland Size (Cable Range)
ZZ - Entry Thread
B
A
D
C
Sample: EX-50-B-3-20S-M20
DESIGN STANDARD
EN 50014:1998, EN 50018:2000, EN 50019:2000 and EN 50281-1-1:1998
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
SIRA 05ATEX1121X - Ex Notified Body No. 0518
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-50-B-3-20S-M20 XX SIRA 05ATEX1121X
II 2GD IP66 EExdIIC / EExe II (XX = Year Code)
APPLICATION
EExd Equipment
EX-50 type glands will only maintain Flameproof Exd integrity when used with cable that has a suitable profile and is compact with extruded
bedding. The cable shall be deemed to be effectively filled. Ref: IEC60079-14:2002 Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use EX-50 Gland
IIC, IIB, IIA
NO
2 litres or less
Zone 1 or 2
YES
IIB, IIA
YES
Any
Zone 2
YES
IIB, IIA
YES
2 litres or less
Zone 1
YES
EExe Equipment
Gas Group II, Zones 1 and 2
Other Equipment
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66
OPERATING TEMPERATURES
Standard Seals - 60°C to +180°C
MATERIALS
Brass CZ121 (EX-50-B)
316 Stainless Steel (EX-50-S)
PLATING
THREADS
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
18
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Gland
Size
Entry Threads
Metric
Entry
Thread
Length
Max Across
Corners
[B]
[A]
Gland Seal Range
Max
Protrusion
Length
Cable Inner Sheath [C]
Width
Thickness
Min
Max
Min
Max
Cable Outer Sheath [D]
Width
Min
Max
Thickness
Min
Max
Armor
Acceptance
Range
[X]
20s
M20
16
26.5
58.0
6.3
11.7
4.0
7.0
7.9
11.7
4.5
7.0
0.1-0.3
20R
M20
16
33.0
58.0
8.1
13.5
5.8
6.2
7.5
16.1
3.0
8.3
0.1-0.45
20
M20
16
33.0
58.0
10.3
13.5
5.6
9.0
11.0
13.5
4.5
9.0
0.1-0.3
All Dimensions are in Millimeters
NOTES:
• Gland Size does not necessarily equate to the entry thread size.
•
"X" refers to the wire diameter in a braided cable.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
Where EX-50 type glands are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth circuit of
the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
19
ATEX/CSA Approved Glands with Elastometric Seals for Flat Cable
EX-55
EX-55 type glands provide a single pull resistant seal on the outer sheath of unarmoured flat cable. EX-55 type glands
maintain Flameproof Exd and Increased Safety Exe methods of explosion protection and IP68 to 25 meters.
EXAMPLE PART NUMBER
B
EX-55 [W] [Y] [YY] [ZZ]
W - Gland Material(B = Brass / S = Stainless Steel)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
YY - Gland Size (Cable Range)
ZZ - Entry Thread
A
D
EX-55-B-3-20S-M20
DESIGN STANDARD
EN50014:1998, EN50018:2000, EN50019:2000 and EN50281-1-1:1998
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
SIRA 05ATEX1121X - Ex Notified Body No. 0518
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-55-B-3-20S-M20 XX SIRA 05ATEX1121X
II 2GD IP68 EExdIIC / EExe II (XX = Year Code)
APPLICATION
EExd Equipment
EX-55 type glands will only maintain Flameproof Exd integrity when used with cable that has a suitable profile and is compact with extruded
bedding. The cable shall be deemed to be effectively filled. Ref: IEC60079-14:2002 Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use EX-55 Gland
IIC, IIB, IIA
NO
Any
Zone 1 or 2
YES
IIB, IIA
YES
Any
Zone 2
YES
IIB, IIA
YES
2 litres or less
Zone 1
YES
EExe Equipment
Gas Group II, Zones 1 and 2
Other Equipment
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP68 @ 25 meters
OPERATING TEMPERATURES
Standard Seal - 60°C to +180°C (Silicone seal)
MATERIALS
Brass CZ121 (EX-55-B)
316 Stainless Steel (EX-55-S)
Outer sheath seal material: Silicone, red or white
THREADS
PLATING
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
20
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Gland
Size
Entry Threads
Entry
Thread
Length
Max
Across
Corners
Gland Seal Range
Cable Outer Sheath [D]
Metric
[B]
[A]
Min
Max
Width
Thickness
Min
Max
20s
M20
16
26.5
6.3
11.7
4.0
7.0
20R
M20
16
33.0
8.1
13.5
5.8
6.2
20
M20
16
33.0
10.3
13.5
5.6
9.0
All Dimensions are in Millimeters
NOTES:
• Suitable only for fixed installations. The cable must be clamped near the gland to prevent pulling and twisting.
•
Gland Size does not necessarily equate to the entry thread size.
•
Integral entry thread seal option is not available for glands with tapered entry threads. IP washers can be supplied if required.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
Where EX-55 type glands are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth circuit of
the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
21
ATEX / CSA Approved Compound Filled Barrier Glands
EX-60
EX-60 type glands provide a Flameproof EExd compound filled barrier, a seal on the outer sheath, a universal
armor clamp for armored, screened or braided cable and an entry thread seal. The armor clamp provides an
electrical bond between the cable armor, screen or braid and the gland. EX-60 type glands maintain EExd
Flameproof method of explosion protection; IP66, 68 to 100 meters and is deluge resistant.
EXAMPLE PART NUMBER
EX-60 [W] [Y] [R] [YY] [ZZ]
W - Gland Material (B = Brass / S = Stainless Steel)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
R - Reduced bore option
YY - Gland Size (Cable Range)
ZZ - Entry Thread
B
A
D
EX-60-B-1-R-20S-M20
DESIGN STANDARD
EN50014:1998, EN50018:2000, EN50019:2000 and EN50281-1-1:1998
IEC 60079-0 (2000-06), IEC 60079-1 (2001-02)
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
CSA Exd I & IIC 4X, Class 1, Zone 1
SIRA 05SIRA1124X - Ex Notified Body No. 0518
Pending
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-60-B-1-R-20S-M20 XX SIRA 05ATEX1124X I M2 II 2GD EExd I & IIC IP68 (XX = Year Code)
APPLICATION
EExd Equipment
EX-60 type Glands will maintain Flameproof Exd integrity when used with any armored or unarmored cable types. Ref: IEC60079-14:2002
Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use EX-60 Gland
I, IIC, IIB, IIA
YES
Any
Zone 1 or 2
YES
Other Equipment
Mining Equipment Group I, M2
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66 & IP68 @ 100 Meters
Meets the requirements of DTS01 1991
CURING TIME
@ 21°C
Conductor termination can be effected after 1 hour
The equipment can be energised after 4 hours
The compound chamber can be inspected after 4 hours
OPERATING TEMPERATURES
- 60°C to +85°C
22
C
MATERIALS
Brass CZ121 (EX-60-B)
316 Stainless Steel (EX-60-S)
Inner LSOH compound
Standard outer sheath seal is LSOH silicone, white (EX-60-W-Y)
Reduced bore outer sheath seal is LSOH silicone, red (EX-60-W-Y-R)
Entry thread Seal: Red LSOH silicone
THREADS
PLATING
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC)
Gland and accessory kits:
K5- includes gland, locknut, earthtag, integral IP “O” ring & PVC shroud
Gland
Size
Entry Threads
Entry
Thread
Length
Max
Max
Across Protrusion
Corners
Length
[B]
[A]
GlandSeal Range
Cable Inner
Cable Outer Sheath [D]
Standard
Reduced (R)
Sheath / Cores [C]
Max
Max
No. of Over
Metric
NPT/BSP
16
M20
N1 or N2
16
28.0
72.0
20s
M20
N1 or N2
16
28.0
20
M20
N1 or N2
16
33.0
Armor
Acceptance
Range
Max
Inner
Min
Max
Min
Max
6.7
10.3
0.15 - 1.25
Shroud
Size
7
9.0
11.7
9.0
13.5
L24
72.0
8
10.4
11.7
11.5
16.0
9.4
12.5
0.15 - 1.25
L24
73.0
14
12.5
14.0
15.5
21.1
12.0
17.6
0.15 - 1.25
EL30
25
M25
N2 or N3
16
41.4
83.0
25
17.8
20.0
20.3
27.4
16.8
23.9
0.15 - 1.60
EL38
32
M32
N3 or N4
16
50.6
103.0
50
23.5
26.3
26.7
34.0
23.2
30.5
0.15 - 2.00
EL46
40
M40
N4 or N5
16
60.5
105.0
80
28.8
32.2
33.0
40.6
28.6
36.2
0.20 - 2.00
EL55
50s
M50
N6
16
71.5
115.0
100
34.2
38.2
39.4
46.7
34.8
42.4
0.20 - 2.50
EL65
50
M50
N6
16
71.5
115.0
100
39.4
44.1
45.7
53.2
41.1
48.5
0.20 - 2.50
EL65
63s
M63
N7
19
88.0
115.0
120
44.8
50.1
52.1
59.5
47.5
54.8
0.30 - 2.50
EL80
63
M63
N7
19
88.0
115.0
120
50.0
56.0
58.4
65.8
53.8
61.2
0.30 - 2.50
EL80
75s
M75
N8
19
99.0
122.0
140
55.4
62.0
64.8
72.2
60.2
68.0
0.30 - 2.50
EL90
75
M75
N8
19
99.0
122.0
140
60.8
68.0
71.1
78.0
66.5
73.4
0.30 - 2.50
EL90
80
M80x2
N8 or N9
25
115.2
162.0
160
64.4
72.0
77.0
84.0
-
-
0.45 - 3.15
L104
85
M85x2
N8 or N9
25
115.2
162.0
180
69.8
78.0
79.6
90.0
75.0
85.4
0.45 - 3.15
L104
90
M90x2
N9 or N10
25
125.7
166.0
200
75.1
84.0
88.0
96.0
-
-
0.45 - 3.15
L114
100
M100x2
N9 or N10
25
125.7
166.0
220
80.5
90.0
92.0
102.0
87.4
97.4
0.45 - 3.15
L114
All Dimensions are in Millimeters
NOTES:
• NPT entry thread reference details on page 53.
•
Gland Size does not necessarily equate to the entry thread size.
•
Integral entry thread seal option is not available for glands with tapered entry threads. IP washers can be supplied if required.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
If EX-60 type glands are fitted into non-metallic enclosures they must be included within the earth circuit of the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
23
ATEX / CSA Approved Compound Filled Barrier Glands
EX-65
EX-65 type glands provide a Flameproof EExd compound filled barrier and an entry thread seal. EX-65 type glands
maintain EExd Flameproof method of explosion protection; IP66, 68 to 100 meters and is deluge resistant.
EXAMPLE PART NUMBER
EX-65 [W] [Y] [YY] [ZZ]
W - Gland Material (B = Brass / S = Stainless Steel)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
YY - Gland Size (Cable Range)
ZZ - Entry Thread
B
A
D
EX-65-B-1-20S-M20
DESIGN STANDARD.
EN50014:1998, EN50018:2000, & EN50281-1-1:1998
IEC 60079-0 (2000-06), IEC 60079-1 (2001-02)
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
CSA Exd I & IIC/Exe II 4X, Class 1, Zone 1
SIRA 05ATEX1124X - Ex Notified Body No. 0518
Pending
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-65-B-1-20S-M20 XX SIRA 05ATEX1124X I M2 II 2GD EExd I & IIC IP68 (XX = Year Code)
APPLICATION
EExd Equipment
EX-65 type Glands will maintain Flameproof Exd integrity when used with any armored or unarmored cable types. Ref: IEC60079-14:2002
Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use EX-65 Gland
I, IIC, IIB, IIA
YES
Any
Zone 1 or 2
YES
Other Equipment
Mining Equipment Group I, M2
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66 & IP68 @ 100 Meters
Meets the requirements of DTS01 1991
CURING TIME
@ 21°C
Conductor termination can be effected after 1 hour
The equipment can be energised after 4 hours
The compound chamber can be inspected after 4 hours
OPERATING TEMPERATURES
-60°C to +85°C
24
C
MATERIALS
Brass CZ121 (EX-65-B)
316 Stainless Steel (EX-65-S)
Inner LSOH compound
Entry thread Seal: Red LSOH silicone
PLATING
THREADS
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC)
Gland and accessory kits:
K5- includes gland, locknut, earthtag, integral IP “O” ring & PVC shroud
Gland Size
Entry Threads
Entry Thread
Length
Max Across
Corners
[B]
[A]
Max
Protrusion
Length
Gland Seal Range
Cable Sheath / Cores
Shroud Size
Max
No. of
Cores
Max
Over
Cores [C]
Max
Sheath
Diameter [D]
Metric
NPT/BSP
20s
M20
N1 or N2
16
28.0
42.0
8
10.4
11.7
L24
20
M20
N1 or N2
16
33.0
44.0
14
12.5
14.0
L20
25
M25
N2 or N3
16
41.4
48.0
25
17.8
20.0
L38
32
M32
N3 or N4
16
50.6
53.0
50
23.5
26.3
L46
40
M40
N4 or N5
16
60.5
54.0
80
28.8
32.2
L55
50
M50
N6
16
71.5
54.0
100
39.4
44.1
L65
63
M63
N7
19
88.0
55.0
120
50.0
56.0
L80
75
M75
N8
19
99.0
60.0
140
60.8
68.0
L90
80
M80x2
N8 or N9
25
115.2
80.0
160
64.4
72.0
L104
85
M85x2
N8 or N9
25
115.2
80.0
180
69.8
78.0
L104
90
M90x2
N9 or N10
25
125.7
85.0
200
75.1
84.0
L114
100
M100x2
N9 or N10
25
125.7
85.0
220
80.5
90.0
L114
All Dimensions are in Millimeters
NOTES:
• NPT entry thread reference details on page 53.
•
Gland Size does not necessarily equate to the entry thread size.
•
Integral entry thread seal option is not available for glands with tapered entry threads. IP washers can be supplied if required.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
If EX-65 type glands are fitted into non-metallic enclosures they must be included within the earth circuit of the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
25
ATEX / CSA Approved Compound Filled Barrier Glands
EX-70
EX-70 type glands provide a Flameproof EExd compound filled barrier, a secondary weather seal on the outer
sheath and an entry thread seal. EX-70 type glands maintain EExd Flameproof method of explosion protection;
IP66, 68 to 100 meters and is deluge resistant.
EXAMPLE PART NUMBER
EX-70 [W] [Y] [YY] [ZZ]
W - Gland Material (B = Brass / S = Stainless Steel)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
YY - Gland Size (Cable Range)
ZZ - Entry Thread
B
A
D
EX-70-B-1-20S-M20
DESIGN STANDARD
EN50014:1998, EN50018:2000, & EN50281-1-1:1998
IEC 60079-0 (2000-06), IEC 60079-1 (2001-02)
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
CSA Exd I & IIC/Exe II 4X, Class 1, Zone 1
SIRA 05ATEX1124X - Ex Notified Body No. 0518
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-70-1-20S-M20 XX SIRA 05ATEX1124X I M2 II 2GD EExd I & IIC IP68
APPLICATION
EExd Equipment
EX-70 type Glands will maintain Flameproof Exd integrity when used with any armored or unarmored cable types. Ref: IEC60079-14:2002
Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use EX-70 Gland
I, IIC, IIB, IIA
YES
Any
Zone 1 or 2
YES
Other Equipment
Mining Equipment Group I, M2
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66 & IP68 @ 100 Meters
Meets the requirements of DTS01 1991
CURING TIME
@ 21°C
Conductor termination can be effected after 1 hour
The equipment can be energised after 4 hours
The compound chamber can be inspected after 4 hours
OPERATING TEMPERATURES
-60°C to +85°C
26
C
MATERIALS
Brass CZ121 (Ex-70-B)
316 Stainless Steel (EX-70-S)
Inner LSOH compound
Entry thread Seal: Red LSOH silicone
THREADS
PLATING
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC)
Gland and accessory kits:
K5- includes gland, locknut, integral IP “O” ring & PVC shroud
Gland Size
Entry Threads
Entry
Thread
Length
Max
Across
Corners
[B]
[A]
Max
Protrusion
Length
Gland Seal Range
Cable Inner
Sheath / Cores [C]
Cable Outer
Sheath [D]
Max
No. of
Cores
Max
Over
Cores
Max
Sheath
Diameter
Min
Max
7
8.4
8.4
3.4
8.4
Shroud
Size
Metric
NPT/BSP
16
M20
N1 or N2
16
28.0
73.0
20s
M20
N1 or N2
16
28.0
73.0
8
10.4
11.7
4.8
11.7
L24
20
M20
N1 or N2
16
33.0
73.0
14
12.5
14.0
9.5
14.0
EL30
25
M25
N2 or N3
16
41.4
74.0
25
17.8
20.0
11.7
20.0
EL38
32
M32
N3 or N4
16
50.6
80.0
50
23.5
26.3
18.1
26.3
EL46
40
M40
N4 or N5
16
60.5
87.0
80
28.8
32.2
22.6
32.2
EL55
50s
M50
N6
16
71.5
87.0
100
34.2
38.2
28.2
38.2
EL65
L24
50
M50
N6
16
71.5
87.0
100
39.4
44.1
33.1
44.1
EL65
63s
M63
N7
19
88.0
88.0
120
44.8
50.1
39.3
50.1
EL80
63
M63
N7
19
88.0
88.0
120
50.0
56.0
46.7
56.0
EL80
75s
M75
N8
19
99.0
97.0
140
55.4
62.0
52.3
62.0
EL90
75
M75
N8
19
99.0
97.0
140
60.8
68.0
58.0
68.0
EL90
80
M80x2
N8 or N9
25
115.2
123.0
160
64.4
72.0
61.9
72.0
L104
85
M85x2
N8 or N9
25
115.2
123.0
180
69.8
78.0
69.1
78.0
L104
90
M90x2
N9 or N10
25
125.7
123.0
200
75.1
84.0
74.1
84.0
L114
100
M100x2
N9 or N10
25
125.7
123.0
220
80.5
90.0
81.8
90.0
L114
All Dimensions are in Millimeters
NOTES:
• NPT entry thread reference details on page 53.
•
Gland Size does not necessarily equate to the entry thread size.
•
Integral entry thread seal option is not available for glands with tapered entry threads. IP washers can be supplied if required.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
If EX-70 type glands are fitted into non-metallic enclosures they must be included within the earth circuit of the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
27
ATEX / CSA Approved Compound Filled Barrier Glands
EX-75
EX-75 type glands provide a Flameproof EExd compound filled barrier seal on the cables individual conductors
within a conduit. It also provides an entry thread seal. EX-75 type glands maintain EExd Flameproof method of
explosion protection; IP66, 68 to 100 meters and is deluge resistant.
EXAMPLE PART NUMBER
EX-75 [W] [Y] [YY] [ZZ1] [ZZ2]
W - Gland Material (B = Brass / S = Stainless Steel)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
YY - Gland Size (Cable Range)
ZZ1 - Male Thread
ZZ2 - Female Entry Thread
MATING CONDUIT OR
CABLE GLAND
A
B
D
EX-75-B-1-20S-M20
DESIGN STANDARD
EN50014:1998, EN50018:2000, & EN50281-1-1:1998
IEC 60079-0 (2000-06), IEC 60079-1 (2001-02)
CERTIFICATION
CERTIFICATE
ATEX II 2 GD, E Exd IIC / E Exe II
CSA Exd I & IIC/Exe II 4X, Class 1, Zone 1
SIRA 03ATEX1479X - Ex Notified Body No. 0518
GLAND MARKING
CENELEC and ATEX
Example:
Amphenol 13838 USA EX-75-B-1-20S-M20 XX SIRA05ATEX1120X
I M2 II 2GD EExd I & IIC IP68
APPLICATION
EExd Equipment
EX-75 type Glands will maintain Flameproof Exd integrity when used with any armored or unarmored cable types. Ref: IEC60079-14:2002
Section 10.4.2
Gas Group Internal Ignition Source Enclosure Volume
Which Zone
Use EX-75 Gland
I, IIC, IIB, IIA
YES
Any
Zone 1 or 2
YES
Other Equipment
Mining Equipment Group I, M2
Ignitable Dust, Zones 21 and 22
INGRESS PROTECTION
IP66 & IP68 @ 100 Meters
Meets the requirements of DTS01 1991
CURING TIME
@ 21°C
Conductor termination can be effected after 1 hour
The equipment can be energised after 4 hours
The compound chamger can be inspected after 4 hours
OPERATING TEMPERATURES
-60°C to +85°C
28
C
MATERIALS
Brass CZ121 (EX-75-B)
316 Stainless Steel (EX-75-S)
Inner LSOH compound
Entry thread Seal: Red LSOH silicone
THREADS
PLATING
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Fitting
Size
Ref
Male Entry
Female Entry
Entry
Thread
Length
Max
Across
Corners
Metric
NPT
Metric
NPT
[B]
[A]
20
M20
N1 or N2
M20
N1 or N2
16
33.0
25
M25
N2 or N3
M25
N2 or N3
16
41.4
32
M32
N3 or N4
M32
N3 or N4
16
40
M40
N4 or N5
M40
N4 or N5
16
50
M50
N6
M50
N6
63
M63
N7
M63
N7
Max
Protrusion
Length
Sealing Range
Cable Conductors / Cores
Max
No. of
Cores
Max
Over
Cores [C]
Max Cable
Inside Fitting
[D]
57.0
14
12.5
14.0
63.0
25
17.8
20.0
50.6
67.0
50
23.5
26.3
60.5
68.0
80
28.8
32.2
16
71.5
68.0
100
39.4
44.1
19
88.0
72.0
120
50.0
56.0
75
M75
N8
M75
N8
19
99.0
78.0
140
60.8
68.0
80
M80x2
N8 or N9
M80x2
N8 or N9
25
115.2
103.0
160
64.4
72.0
85
M85x2
N8 or N9
M85x2
N8 or N9
25
115.2
103.0
180
69.8
78.0
90
M90x2
N9 or N10
M90x2
N9 or N10
25
125.7
104.0
200
75.1
84.0
100
M100x2
N9 or N10
M100x2
N9 or N10
25
125.7
104.0
220
80.5
90.0
All Dimensions are in Millimeters
NOTES:
• NPT thread reference details on page 53.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Integral entry thread seal option is not available for glands with tapered entry threads. IP washers can be supplied if required.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
For Flameproof Exd applications the female thread into which the gland is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for
tapered threads.
•
If EX-75 type glands are fitted into non-metallic enclosures they must be included within the earth circuit of the system.
•
The user should seek expert advice if intending to combine flammable gases and combustible dusts in one environment/installation.
•
To maintain ingress protection a thread sealant should be applied to the conduit thread.
•
Full assembly instructions are supplied with glands, the instructions must be read prior to installation and adhered to in full.
29
Non-Hazardous Industrial Glands
CGA
CGA type glands provide an integral armor clamp for armored cable. The integral armor clamp provides an
electrical bond between the cable armor and the gland. CGA type glands maintain IP30.
EXAMPLE PART NUMBER
CG[X]
X
W
Y
YY
ZZ
[W]
-
[Y] [YY] [ZZ]
Clamp Type (See Clamps)
Gland Material ( B = Brass / S = Stainless Steel)
Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
Gland Size (Cable Range)
Entry Thread
B
A
D
D
Sample: CGA-B-3-20S-M20
DESIGN STANDARD
BS 6121:1989
GLAND MARKING
INGRESS PROTECTION
Example:
BS6121 Part 1 CGA-B-3-20S-M20 Amphenol
IP30
OPERATING TEMPERATURES
MATERIALS
-100°C to +600°C
Brass CZ121 (CGA-B)
VARIATIONS
All variants of the CGA type gland feature a separate armor clamping ring to allow for inspection of the clamped armor:
Brass (CGA-B)
THREADS
ISO Metric only
CLAMPS
PLATING
SWA Clamping using gland body (CGA)
SWA steel wire armor - clamping ring (CGL)
SWB woven steel wire armor or STA steel
tape armor - clamping ring (CGZ)
ACCESSORIES
Locknut - Brass (EX-BLN); Steel (EX-MLN)
Earth Tag - Brass (EX-BET)
Shroud - PVC (EX-PVC)
Gland and accessory kits:
K6- includes gland, steel locknut, earthtag and PVC shroud
30
Nickel (1); Tin (2); Zinc (3); Electroless
Nickel (4)
Gland
Size
Entry
Threads
Entry
Threads
Length
M<ax
Across
Corners
Max
Protrusion
Length
Metric
[B]
[A]
20s
M20
10
24.2
20.0
-
11.7
-
20
M20
10
29.7
20.0
-
14.0
25
M25
10
45.1
22.0
-
20.0
32
M32
10
50.6
25.0
-
40
M40
15
60.5
30.0
50
M50
15
71.5
63
M63
15
75
M75
80
M80
85
90
100
Cable Inner
Sheath [C]
Min
Gland Seal Range
Cable Outer
Sheath [D]
Max
Min
Armor Acceptance
Range
Max
Shroud
Size
W
XZ
Clamp Ring
Version Only
16.0
0.90-1.25
0.15-0.35
S22
-
21.0
0.90-1.25
0.15-0.50
S27
-
27.4
1.25-1.60
0.15-0.50
S36
26.3
-
34.0
1.60-2.00
0.15-0.55
S41
-
32.2
-
40.6
1.60-2.00
0.20-0.60
L55
32.0
-
44.1
-
53.2
2.00-2.50
0.20-0.60
L65
88.0
42.0
-
56.0
-
65.8
2.50
0.30-0.80
L80
15
99.0
50.0
-
68.0
-
78.0
2.50
0.30-1.00
L90
20
115.2
50.0
-
72.0
-
84.0
3.15
0.45-1.00
S104
M85
20
115.2
50.0
-
78.0
-
90.0
3.15
0.45-1.00
S104
M90
20
125.7
50.0
-
84.0
-
96.0
3.15
0.45-1.00
S114
M100
20
125.7
50.0
-
90.0
-
102.0
3.15
0.45-1.00
S114
All Dimensions are in Millimeters
NOTES:
•
Gland Size does not necessarily equate to the entry thread size
•
"W" refers to the wire diameter in a steel wire armored cable
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch
•
Shroud sizes above are for CGA type only.
•
Full assembly instructions are available upon request, the instructions should be read prior to installation and adhered to in full
31
Non Hazardous Industrial Glands
CGSB or CGSS
CGSB and CGSS type glands provide a seal on the outer sheath and an armor specific clamp for armored cable.
The armor clamp provides an electrical bond between the cable armor and the gland; and maintain IP66 rating.
EXAMPLE PART NUMBER
CGSB* [W] [Y] [R] [YY] [ZZ]
* - Armor Type (W = SWA / X = SWB / Z = STA)
W - Seal Material (1 = Neoprene / 3 = Silicone)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
R - Reduced bore option
YY - Gland Size (Cable Range)
ZZ - Entry Thread
B
A
D
Sample: CGSB-W-1-3-R-20S-M20
DESIGN STANDARD
BS EN 50262: 1999
GLAND MARKING
INGRESS PROTECTION
Example:
CGSB-W-1-3-R-20S-M20 Amphenol
IP66
OPERATING TEMPERATURES
Standard Seals -20°C to +80°C
Silicone Seals - 60°C to +200°C
MATERIALS
Brass CZ121 (CGSB)
316 Stainless Steel (CGSS)
Outer sheath seal material: Standard Neoprene, black. Option Silicone, white
Reduced bore outer sheath seal (R) Silicone, red
THREADS
SEALS
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel);
Extended operating temperature -60°C to +200°C, halogen free
versions:
Brass (CGSB-*-3); 316 Stainless Steel (CGSS-*-3)
CLAMPS
PLATING
SWA steel wire armor (CGSB-W)
SWB woven steel wire armor or STA steel tape armor (CGSB-X)
SWA, SWB and STA armor clamps (CGSB-Z)
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC); PCP (EX-SPCP); Low Smoke Zero Halogen (EX-LSH)
Gland and accessory kits:
K7- includes gland, locknut, earthtag and PVC shroud
K8 - includes brass gland, brass locknut, brass earthtag and zero halogen shroud
32
C
Gland
Size
Entry Threads
Metric
Entry
Max
Max
Thread Across Protrusion
Length Corners
Length
[B]
[A]
Gland Seal Range
Cable Inner
Sheath [C]
Min
Max
Armour Acceptance
Range
Cable Outer Sheath [D]
Standard
Min
Max
Shroud
Size
Reduced (R)
Min
Max
NPT/BSP
W
XZ
16
M20
N1 or N2
10
26.5
54.0
-
11.7
9.0
13.5
6.7
10.3
0.90
0.15-0.35
L24
20s
M20
N1 or N2
10
26.5
54.0
-
11.7
11.5
16.0
9.4
12.5
0.90-1.25
0.15-0.35
L24
20
M20
N1 or N2
10
33.0
54.0
-
14.0
15.5
21.0
12.0
17.6
0.90-1.25
0.15-0.50
L30
25
M25
N2 or N3
10
41.4
54.0
-
20.0
20.3
27.4
16.8
23.9
1.25-1.60
0.15-0.50
L38
32
M32
N3 or N4
10
50.6
60.0
-
26.3
26.7
34.0
23.2
30.5
1.60-2.00
0.15-0.55
L46
40
M40
N4 or N5
15
60.5
67.0
-
32.2
33.0
40.6
28.6
36.2
1.60-2.00
0.20-0.60
L55
50s
M50
N5 or N6
15
71.5
67.0
-
38.2
39.4
46.7
34.8
42.4
2.00-2.50
0.20-0.60
L65
50
M50
N6
15
71.5
67.0
-
44.1
45.7
53.2
41.1
48.5
2.00-2.50
0.30-0.60
L65
63s
M63
N6 or N7
15
88.0
69.0
-
50.1
52.1
59.4
47.5
54.8
2.50
0.30-0.80
L80
63
M63
N7
15
88.0
69.0
-
56.0
58.4
65.8
53.8
61.2
2.50
0.30-0.80
L80
75s
M75
N7 or N8
15
99.0
77.0
-
62.0
64.8
72.2
60.2
68.0
2.50
0.30-1.00
L90
75
M75
N8
15
99.0
77.0
-
68.0
71.1
78.0
66.5
73.4
2.50
0.30-1.00
L90
80
M80 x 2
N8 or N9
20
115.2
104.0
-
72.0
77.0
84.0
-
-
3.15
0.45-1.00
L104
80H
M80 x 2
N8 or N9
20
115.2
104.0
-
72.0
79.6
90.0
-
-
3.15
0.45-1.00
L104
85
M85 x 2
N8 or N9
20
115.2
104.0
-
78.0
79.6
90.0
75.0
85.4
3.15
0.45-1.00
L104
90
M90 x 2
N9 or N10
20
125.7
104.0
-
84.0
88.0
96.0
-
-
3.15
0.45-1.00
L114
90H
M90 x 2
N9 or N10
20
125.7
104.0
-
84.0
92.0
102.0
-
-
3.15
0.45-1.00
L114
100
M100 x 2
N9 or N10
20
125.7
104.0
-
90.0
92.0
102.0
87.4
97.4
3.15
0.45-1.00
L114
All Dimensions are in Millimeters
NOTES:
•
NPT entry thread reference details on page 53.
•
Gland Size does not necessarily equate to the entry thread size.
•
"W" refers to the wire diameter in a steel wire armored cable.
•
"XZ" refers to the wire diameter in a woven steel wire armored cable or the tape thickness in a steel tape armored cable.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
Full assembly instructions are available upon request, the instructions should be read prior to installation and adhered to in full.
33
Non Hazardous Industrial Glands
CGDS
CDGS type glands provide a seal on the inner sheath, a seal on the outer sheath and an armor specific armor
clamp for armored cable. The armor clamp provides an electrical bond between the cable armor and the gland.
CGDS type glands maintain IP66, IP67.
EXAMPLE PART NUMBER
CGDS* [W] [Y] [R] [YY] [ZZ]
* - Armor Type (W = SWA / X = SWB / Z = STA)
W - Gland Material (B = Brass / S = Stainless Steel)
X - Seal Type ( 0 = None / 1 = Neoprene / 3 = Silicone)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
R - Reduced bore option
YY - Gland Size (Cable Range)
ZZ - Entry Thread
B
A
D
C
Sample: CGDS-W-B-0-3-R-20S-M20-K1
DESIGN STANDARD
BS EN 50262: 1999
GLAND MARKING
INGRESS PROTECTION
Example:
CDGS-W-B-0-3-R-20S-M20 Amphenol
IP66 and IP67
OPERATING TEMPERATURES
Standard Seals -20°C to +80°C
Silicone Seals - 60°C to +200°C
MATERIALS
Brass CZ121 (CGDS-*-B)
316 Stainless Steel (CGDS-*-S)
Inner and outer sheath seal material: Standard Neoprene, black. Option Silicone, white
Reduced bore outer sheath seal (R) Silicone, red
VARIATIONS
Omission of outer seal:
Brass (CDGS-*-B-0); 316 Stainless Steel (CDGS-*-S-0)
THREADS
SEALS
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
Extended operating temperature -60°C to +200°C, halogen free
versions:
Brass (CDGS-*-B-3); 316 Stainless Steel (CDGS-*-S-3)
CLAMPS
PLATING
SWA steel wire armor (CGDS-W)
SWB woven steel wire armor (CGDS-X)
STA steel tape armor (CGDS-Z)
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
34
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC); PCP (EX-PCP); Low Smoke Zero Halogen (EX-LSH)
Gland and accessory kits:
K1 - includes gland, locknut, earthtag and PVC shroud
K8 - includes brass gland, brass locknut, brass earthtag and zero halogen shroud
Gland
Size
Entry Threads
Metric
Entry
Max
Max
Thread Across Protrusion
Length Corners
Length
[B]
[A]
Gland Seal Range
Cable Inner
Sheath [C]
Min
Max
Armour Acceptance
Range
Cable Outer Sheath [D]
Standard
Min
Max
Shroud
Size
Reduced (R)
Min
Max
NPT/BSP
W
XZ
16
M20
N1 or N2
16
26.5
58.0
4.0
8.4
8.4
13.5
4.9
10.0
0.90
0.15-0.35
L24
20s
M20
N1 or N2
16
26.5
58.0
8.0
11.7
11.5
16.0
9.4
12.5
0.90-1.25
0.15-0.35
L24
20
M20
N1 or N2
16
33.0
58.0
6.7 *
14.0
15.5
21.0
12.0
17.6
0.90-1.25
0.15-0.50
L30
25
M25
N2 or N3
16
41.4
58.0
13.0
20.0
20.3
27.4
16.8
23.9
1.25-1.60
0.15-0.50
L38
32
M32
N3 or N4
16
50.6
65.0
19.0
26.3
26.7
34.0
23.2
30.5
1.60-2.00
0.15-0.55
L46
40
M40
N4 or N5
16
60.5
72.0
25.0
32.2
33.0
40.6
28.6
36.2
1.60-2.00
0.20-0.60
L55
50s
M50
N5 or N6
16
71.5
73.0
31.5
38.2
39.4
46.7
34.8
42.4
2.00-2.50
0.20-0.60
L65
50
M50
N6
16
71.5
73.0
36.5
44.1
45.7
53.2
41.1
48.5
2.00-2.50
0.30-0.80
L65
63s
M63
N6 or N7
19
88.0
76.0
42.5
50.1
52.1
59.4
47.5
54.8
2.50
0.30-0.80
L80
63
M63
N7
19
88.0
76.0
49.5
56.0
58.4
65.8
53.8
61.2
2.50
0.30-0.80
L80
75s
M75
N7 or N8
19
99.0
82.0
54.5
62.0
64.8
72.2
60.2
68.0
2.50
0.30-1.00
L90
75
M75
N8
19
99.0
82.0
60.5
68.0
71.1
78.0
66.5
73.4
2.50
0.30-1.00
L90
80
M80 x 2
N8 or N9
25
115.2
110.0
62.2
72.0
77.0
84.0
-
-
3.15
0.45-1.00
L104
80H
M80 x 2
N8 or N9
25
115.2
110.0
62.2
72.0
79.6
90.0
-
-
3.15
0.45-1.00
L104
85
M85 x 2
N8 or N9
25
115.2
110.0
69.0
78.0
79.6
90.0
75.0
85.4
3.15
0.45-1.00
L104
90
M90 x 2
N9 or N10
25
125.7
110.0
74.0
84.0
88.0
96.0
-
-
3.15
0.45-1.00
L114
90H
M90 x 2
N9 or N10
25
125.7
110.0
74.0
84.0
92.0
102.0
-
-
3.15
0.45-1.00
L114
100
M100 x 2
N9 or N10
25
125.7
110.0
82.0
90.0
92.0
102.0
87.4
97.4
3.15
0.45-1.00
L114
All Dimensions are in Millimeters
NOTES:
* CGDS gland size 20, the silicone inner seal only seals to a minimum of 11.0mm and NOT 6.7mm.
•
NPT entry thread reference on page 53.
•
Gland Size does not necessarily equate to the entry thread size.
•
"W" refers to the wire diameter in a steel wire armored cable.
•
"XZ" refers to the wire diameter in a woven steel wire armored cable or the tape thickness in a steel tape armored cable.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
Full assembly instructions are available upon requests, the instructions should be read prior to installation and adhered to in full.
35
Non Hazardous Industrial Glands
CGU
CGU type glands provide a single pull resistant seal on the outer sheath of unarmoured cable. CGU type glands
maintain IP66, IP68 to 25 meters.
EXAMPLE PART NUMBER
CGU
W
X
Y
YY
ZZ
[W]
-
B
[Y] [YY] [ZZ]
Gland Material (B = Brass / S = Stainless Steel)
Seal (1 = Neoprene / 3 = Silicone)
Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
Gland Size (Cable Range)
Entry Thread
A
D
Sample: CGU-B-1-3-20S-M20
DESIGN STANDARD
BS EN 50262: 1999
GLAND MARKING
INGRESS PROTECTION
Example:
CGU-B-1-3-20S-M20
IP66 and IP68 @ 25 metres
OPERATING TEMPERATURES
Standard Seals -20°C to +80°C
Silicone Seals - 60°C to +200°C
MATERIALS
Brass CZ121 (CGU-B)
316 Stainless Steel (CGU-S)
Outer sheath seal material:
Standard Neoprene, black. Option Silicone, white
THREADS
SEALS
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP
Parallel);
Extended operating temperature -60°C to +200°C, halogen free
versions:
Brass (CGU-B-3); 316 Stainless Steel (CGU-B-3);
PLATING
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
ACCESSORIES
Locknut - Brass (EX-BLN); 316 Stainless Steel (EX-SLN)
Earth Tag - Brass (EX-BET), 316 Stainless Steel (EX-SET)
IP Washer - Nylon (EX-NSW); Red Fibre (EX-FSW)
Serrated Lock Washer - 316 Stainless Steel (EX-SSW), Galvanised Steel (EX-GSW)
Shroud - PVC (EX-PVC); PCP (EX-PCP); Low Smoke Zero Halogen (EX-LSH)
Gland and accessory kits:
K9 - includes gland, locknut and PVC shroud
36
Gland Size
Entry Threads
Entry Thread
Length
Max Across
Corners
[B]
[A]
Max
Protrusion
Length
Gland Seal Range
Cable Outer/Lead Sheath
[D[
Shroud Size
Min
Max
33.0
4.0
8.4
L24
28.0
33.0
7.2
11.7
L24
33.0
33.0
9.6
14.0
L30
16
41.4
33.0
13.5
20.0
L38
16
50.6
33.0
19.5
26.3
L46
Metric
NPT/BSP
16
M20
N1 or N2
16
28.0
20s
M20
N1 or N2
16
20
M20
N1 or N2
16
25
M25
N2 or N3
32
M32
N3 or N4
40
M40
N4 or N5
16
60.5
37.0
23.0
32.2
L55
50s
M50
N5 or N6
16
71.5
37.0
28.2
38.2
L65
50
M50
N6
16
71.5
37.0
33.2
44.1
L65
63s
M63
N6 or N7
19
88.0
37.0
39.3
50.1
L80
63
M63
N7
19
88.0
37.0
46.7
56.0
L80
75s
M75
N7 or N8
19
99.0
37.0
52.3
62.0
L90
75
M75
N8
19
99.0
37.0
58.1
68.0
L90
80
M80 x 2
N8 or N9
25
115.2
50.0
62.3
72.0
L104
85
M85 x 2
N8 or N9
25
115.2
50.0
69.1
78.0
L104
90
M90 x 2
N9 or N10
25
125.7
50.0
74.1
84.0
L114
100
M100 x 2
N9 or N10
25
125.7
50.0
82.1
90.0
L114
All Dimensions are in Millimeters
NOTES:
•
NPT entry thread reference details on page 53.
•
Gland Size does not necessarily equate to the entry thread size.
•
Please note that dimensions (A) and (B) may differ for glands with non-Metric entry threads. Please refer to our thread data tables for
specific dimensions.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
•
Full assembly instructions are avalable upon request, the instructions should be read prior to installation and adhered to in full.
37
Accessories: Adaptors and Reducers
EXR
EXR Series Dual Certified Adaptors and Reducers provide a method of matching electrical thread forms on Ex
equipment while maintaining Flameproof Exd and Increased Safety Exe methods of explosion protection and
IP66, 68 for IEC type applications. Class I, Division 1 and NEMA 4X, 6P for NEC/CEC type applications.
EXAMPLE PART NUMBER
EXR [W] [Y] [ZZ1] [ZZ2]Sample: EXR-B-0-M20-M20
W Material (B = Brass / S = Stainless Steel)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
ZZ1 Male Thread
ZZ2 Female Entry Thread
CERTIFICATION
CENELEC
SIRA 00ATEX 1094 (Metric Female)
SIRA 99ATEX 1115U (Non-Metric Female)
I M2 II 2DG E Ex de IandIIC
CSA / A Ex
Class I, Zone 1, Ex de IandIIC
Class I, Division 1and2 ABCD
Class II EFG, Class III
GOST R-Exde IICU
POCC GB 05.B00482
INGRESS PROTECTION
IMPACT RESISTANCE
IP66 68, CSA Enclosure Type (NEMA) 4X 6P
20Nm
OPERATING TEMPERATURES
-50°C to +85°C
MATERIALS
Brass CZ121 (EXR-B)
316 Stainless Steel (EXR-S)
THREADS
SEALS
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel);
The standard 'O' Ring material is Nitrile.
Tapered male thread options are not normally supplied c/w ‘O’ ring
seal, thread sealant should be used to maintain the desired level of
ingress protection
PLATING
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
38
SIZES AVAILABLE AND DIMENSION REFERENCES
Metric
Bore
NPT
Bore
ISO Pipe
Bore
Et
M16
10.0
M20
M25
M32
M40
14.0
N1
15.0
1/2"
15.0
3/4"
14.0
18.0
N2
19.0
3/4"
19.0
1"
18.0
24.0
N3
25.0
1"
25.0
N4
24.0
32.0
N4
32.0
N4
32.0
11/2"
32.0
M50
41.0
N5
38.0
11/2"
38.0
2"
41.0
M63
53.0
N6
49.0
2"
49.0
N7
53.0
M75
64.0
N7
60.0
N7
60.0
3"
64.0
M80 x 2.0
69.0
N8
75.0
3"
75.0
M85 x 2.0
73.0
N9
88.0
31/2"
88.0
M90 x 2.0
78.0
N10
100.0
4"
100.0
M100 x 2.0
88.0
Bore
All Dimensions are in Millimeters
NOTES:
•
Full installation instructions are supplied with adaptors and reducers, the instructions must be read prior to installation and adhered to in full
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch
•
For Flameproof Exd applications the female thread into which the adaptor or reducer is to be fitted must comply with clause 5.3 of EN
50018:2000 (clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be
achieved for tapered threads
•
For NEC/CEC Explosion Proof applications an engagement of at least 8 full threads must be achieved for parallel threads and 5 full
threads must be achieved for tapered threads
•
Where EXR adaptors and reducers are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth
circuit of the system
•
316 Stainless Steel versions do not feature a marking band. This reduces the overall length of reducers by 5mm, it does not affect the
overall length of Adaptor
•
Adaptors are used where the thread size of the cable gland or connection device is larger than, or of an equivalent size to the entry thread
of the enclosure
•
Reducers are used to reduce the entry thread of an enclosure to accept a cable gland or connection device with a smaller thread
39
Accessories: Nylon Adaptors and Reducers
EXRN
EXRN Series Certified Adaptors and Reducers provide a method of matching electrical threadforms on Ex
equipment while maintaining Increased Safety Exe methods of explosion protection and IP66, 68 for IEC type
applications.
Adaptors are used where the thread size of the cable gland or connection device is larger than, or of equivalent size to
the entry thread of the enclosure.
Reducers are used to reduce the entry thread of an enclosure to acept a cable gland or connection device with a
smaller thread.
EXAMPLE PART NUMBER
EXRN [ZZ1] [ZZ2]
ZZ1 Male Thread
ZZ2 Female Entry Thread
Sample: EXRN-M20-M25
CERTIFICATION
CENELEC
SIRA 00ATEX 3091 (Metric Female)
SIRA 99ATEX 3116U (Non-Metric Female)
II 2DG E Ex e II
CSA / A Ex
Class I, Zone 1, Ex e II
Class I, Division 2 ABCD
Class II EFG, Class III
INGRESS PROTECTION
OPERATING TEMPERATURES
IP66 68, CSA Enclosure Type (NEMA) 4X 6P
-50°C to +85°C
IMPACT RESISTANCE
7Nm
MATERIALS
30% Glass Filled Nylon (EXRN)
THREADS
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
SEALS
The standard 'O' Ring material is Nitrile
40
SIZES AVAILABLE AND DIMENSION REFERENCES
Metric
Bore
NPT
Bore
ISO Pipe
Bore
ET
Bore
M16
9.3
M20
M25
11.0
N1
12.0
I1
12.0
E2
11.0
16.0
N2
13.0
I2
13.0
E3
16.0
M32
21.0
N3
18.0
I3
18.0
E4
21.0
M40
31.0
N4
33.0
I4
33.0
E5
31.0
M50
40.0
N5
38.0
I5
38.0
E6
40.0
All Dimensions are in Millimeters
NOTES:
•
Full installation instructions are supplied with adaptors and reducers, the instructions must be read prior to installation and adhered to in full
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch
•
Adaptors are used where the thread size of the cable gland or connection device is larger than, or of an equivalent size to the entry thread
of the enclosure
•
Reducers are used to reduce the entry thread of an enclosure to accept a cable gland or connection device with a smaller thread
41
Accessories: Insulating Adaptors
EXIA Insulating Adaptors
EXIA series Insulated Adaptors provide a method of insulating the cable gland or connection device from the
equipment into which it has been installed. EXIA series Insulated Adaptors maintain Flameproof Exd method of
explosion protection and IP66, 68 for IEC type applications. Class I, Division 1 and NEMA 4X, 6P for NEC/CEC type
applications.
EXAMPLE PART NUMBER
EXIA [W] [X] [ZZ1] [ZZ2]
W - Material (B = Brass / S = Stainless Steel)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc /
4 = Electroless Nickel)
ZZ1 - Male Thread
ZZ2 - Female Entry Thread (See NPT reference data on
page 53)
Sample:EXIA-B-1-M20-N1
CERTIFICATION
CENELEC
SIRA 00ATEX 1098 (Metric Female)
SIRA 99ATEX 1117U (Non-Metric Female)
II 2DG E Ex d IIC
CSA / A Ex
Class I, Zone 1, Ex d IIC
Class I, Division 2 ABCD
Class II EFG, Class III
GOST R-Exde IICY
POCC GB 05.B00482
APPLICATION
To avoid relying on the contact between cable termination and equipment enclosure for grounding the cable armor, an insulated adaptor can
be fitted to both ends of the cable with a grounding device (i.e. earth tag/lug) fitted between the adaptor and the termination. The armor
current can then be taken from the grounding device to ground in a controlled, positive manner that can be inspected easily.
Single Point Grounding
- In many application it is sufficient to ground the cable armor at one end. For single point grounding the insulated adaptors would again be
used at both ends of the cable but with the earth tag fitted only to the end where grounding is required.
Single Point Grounding can
- reduce the circulating currents that can cause heating of high capacity cables.
- reduce the risk of damage to electronic equipment within the enclosure in the even of a short circuit to ground through the enclosure.
- reduce the problems of electrical noise on the armor affecting the clean earth required for some sensitive instruments.
Electrical properties of insulating material
- Dielectric strength: 90KV/mm
- Volume resistivity: 8.6 x 10x14 O/cm
- Minimum thickness of insulator: 5mm +/- 1mm
- 2KV 'Wet Withstand' Tested
INGRESS PROTECTION
OPERATING TEMPERATURES
IP54, CSA Enclosure Type (NEMA) 3
IP66 68 can be maintained with the use of either IP washers or a
non-hardening thread sealant
-50°C to +85°C
42
MATERIALS
IMPACT RESISTANCE
Brass CZ121 (EXIA-B)
316 Stainless Steel (EXIA-S)
7Nm
THREADS
PLATING
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
SIZES AVAILABLE AND DIMENSION REFERENCES
Metric
Hex A/F
Hex A/C
Total Length
Male Length
Female Depth
Bore
M20
30.5
35.5
54.0
16.0
17.0
13.5
M25
37.6
43.2
54.0
16.0
17.0
19.0
M32
47.2
54.3
54.0
16.0
17.0
25.0
M40
55.9
64.1
54.0
16.0
17.0
30.0
M50
70.1
80.8
54.0
16.0
17.0
40.5
M63
80.0
92.0
54.0
16.0
17.0
53.0
M75
95.3
109.5
54.0
16.0
17.0
65.0
M80 x 2.0
100.0
114.0
63.0
20.0
22.0
70.0
M85 x 2.0
106.4
114.0
63.0
20.0
22.0
75.0
M90 x 2.0
106.4
114.0
63.0
20.0
22.0
80.0
All Dimensions are in Millimeters
NOTES:
• Full installation instructions are supplied with insulated adaptors, the instructions must be read prior to installation and adhered to in full
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch
•
For Flameproof Exd applications the female thread into which the adaptor is to be fitted must comply with clause 5.3 of EN
50018:2000 (clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be
achieved for tapered threads
43
Accessories: Stopping Plugs
EXSPH Stopping Plugs
EXSPH Series Dual Certified Metallic Dome Head Stopping Plugs provide a method of filling unused entries in
Ex equipment while maintaining Flameproof Exd and Increased Safety Exe methods of explosion protection and
IP66, 68 for IEC type applications. Class I, Division 1 and NEMA 4X, 6P for NEC/CEC type applications.
EXAMPLE PART NUMBER
EXSPH [W] [Y] [ZZ]
W - Material (B = Brass / S = Stainless Steel)
Y - Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
ZZ - Male Entry Thread
Sample: EXSPH-B-1-M20
CERTIFICATION
CENELEC
SIRA 00ATEX1094 I M2 II 2DG E Ex de IandIIC
CSA / A Ex
Class I, Zone 1, Ex de IandIIC
Class I, Division 1and2 ABCD
Class II EFG, Class III
GOST R-Exde IICY
POCC GB 05.B00482
INGRESS PROTCTION
IMPACT RESISTANCE
IP66 68, CSA Enclosure Type (NEMA) 4X 6P
20Nm
OPERATING TEMPERATURES
-50°C to +85°C
THREADS
MATERIALS
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
Brass CZ121 (SPMH-B)
316 Stainless Steel (SPMH-S)
SEALS
PLATING
The standard 'O' Ring material is Nitrile
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
44
SIZES AVAILABLE AND DIMENSION REFERENCES
Metric
Dim Ref
NPT
Dim Ref
ISO Pipe
Dim Ref
M16
A
M20
M25
B
N1
C
P1
C
B
N2
C
P2
C
M32
B
N3
E
P3
C
M40
B
N4
E
P4
C
M50
B
N5
E
P5
C
M63
B
N6
E
P6
C
M75
B
N7
F
P7
C
M80 x 2.0
D
N8
F
P8
C
M85 x 2.0
D
N9
F
M90 x 2.0
D
N10
F
M100 x 2.0
D
DIMENSIONS
Dimension Reference
A
Head Diameter
B
C
D
E
F
Minimum 6.0mm larger than the major thread diameter
Hex Socket A/F
8.0
10.0
10.0
10.0
10.0
10.0
Total Length
21.5
21.5
24.5
25.5
29.0
39.0
Thread Length
16.0
16.0
19.0
22.0
23.5
33.5
All Dimensions are in Millimeters
NOTES:
•
EXSPH type stopping plugs are designed for use within either clearance holes or parallel threaded entries, for taper threaded entries we
would recommend the use of EXSP type stopping plugs on page 48.
•
Full installation instructions are supplied with stopping plugs, the instructions must be read prior to installation and adhered to in full
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch
•
For Flameproof Exd applications the female thread into which the stopping plug is to be fitted must comply with clause 5.3 of EN 50018:2000
(clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be achieved for tapered
threads
•
For NEC/CEC Explosion Proof applications an engagement of at least 8 full threads must be achieved for parallel threads and 5 full threads
must be achieved for tapered threads
•
Where metallic stopping plugs are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth circuit of
the system
45
Accessories: Stopping Plugs
EXSPHN Stopping Plug
EXSPHN Series Glass Filled Nylon Dome Head Stopping Plugs provide a method of filling unused entries in
increased safety equipment, maintaining Increased Safety Exe methods of explosion protection and IP66, 68 for
IEC type applications.
EXAMPLE PART NUMBER
EXSPHN [ZZ]
ZZ Male Thread size
Sample: EXSPHN-M20
CERTIFICATION
CENELEC
SIRA 00ATEX3091 II 2DG E Ex eII
CSA / A Ex
Class I, Zone 1, Ex e II
Class I, Division 2 ABCD
Class II EFG, Class III
INGRESS PROTECTION
IMPACT RESISTANCE
IP66 68, CSA Enclosure Type (NEMA) 4X 6P
7Nm
OPERATING TEMPERATURES
-50°C to +85°C
MATERIALS
30% Glass Filled Nylon (SPMHN)
THREADS
SEALS
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP
Parallel); PG
The standard 'O' Ring material is Nitrile
46
SIZES AVAILABLE AND DIMENSION REFERENCES
Metric
Dim Ref
NPT
Dim Ref
M16
B
M20
M25
C
N1
D
C
N2
D
M32
C
N3
F
M40
C
N4
F
M50
C
N5
F
M63
C
N6
F
M75
C
N7
G
B
C
DIMENSIONS
Dimension Reference
A
Head Diameter
Minimum 6.0mm larger than the major thread diameter
Hex Socket A/F
6.0
8.0
10.0
Total Length
21.5
21.5
21.5
Thread Length
16.0
16.0
16.0
All Dimensions are in Millimeters
NOTES:
•
EXSPHN type stopping plugs are designed for use within either clearance holes or parallel threaded entries, for taper threaded entries
we would recommend the use of EXSP type stopping plugs on page 48.
•
Full installation instructions are supplied with adaptors and reducers, the instructions must be read prior to installation and adhered to
in full.
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch.
47
Accessories: Stopping Plugs
EXSP T
ype Stopping Plug
Type
EXSP Series Certified Metallic Stopping Plugs provide a method of filling unused entries in Ex equipment,
maintaining Flameproof Exd method of explosion protection and IP54 for IEC type applications. Class I, Division 1
and NEMA 3 for NEC/CEC type applications.
EXSP-A Type - Externally accessible hexagon recess
EXSP-B Type - Internally accessible hexagon recess
EXAMPLE PART NUMBER
EXSP [T] [W] [Y] [ZZ]
T - Type (A = Type A / B = Type B)
W - Material (B = Brass / S = Stainless Steel)
Y
- Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
ZZ - Male Thread Size
Sample: EXSP-A-B-1-M20
CERTIFICATION
CENELEC
SIRA 99ATEX1113 II 2DG E Ex d IIC
CSA / A Ex
Class I, Zone 1, Ex d IIC
Class I, Division 1and2 ABCD
Class II EFG, Class III
INGRESS PROTECTION
IMPACT RESISTANCE
IP54, CSA Enclosure Type (NEMA) 3
7Nm
OPERATING TEMPERATURES
-50°C to +85°C
MATERIALS
Brass CZ121 (EXSP-T-B)
316 Stainless Steel (EXSP-T-S)
THREADS
PLATING
ISO Metric; NPT; NPS; ISO Pipe Thread (BSP Taper, BSP Parallel)
Nickel (1); Tin (2); Zinc (3); Electroless Nickel (4)
48
SIZES AVAILABLE AND DIMENSION REFERENCES
Metric
Dim Ref
NPT
Dim Ref
ISO Pipe
Dim Ref
M16
A
M20
B
N1
C
P1
E
M25
B
N2
C
P2
E
M32
B
N3
D
P3
G
M40
B
N4
D
P4
G
M50
B
N5
D
P5
G
M63
B
N6
D
P6
G
M75
B
N7
F
P7
G
M80 x 2.0
F
N8
F
P8
G
M85 x 2.0
F
N9
F
M90 x 2.0
F
N10
F
M100 x 2.0
F
DIMENSIONS
Dimension Reference
A
B
C
D
E
F
G
Hex Socket A/F
8.0
10.0
10.0
10.0
10.0
10.0
10.0
Length (min)
17.0
17.0
14.0
16.0
18.0
22.0
25.0
All Dimensions are in Millimeters
NOTES:
•
Full installation instructions are supplied with stopping plugs, the instructions must be read prior to installation and adhered to in full
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch
•
For Flameproof Exd applications the female thread into which the stopping plug is to be fitted must comply with clause 5.3 of EN
50018:2000 (clause 5.3 IEC 79-1) and an engagement of at least 5 full threads must be achieved for parallel threads and should be
achieved for tapered threads
•
For NEC/CEC Explosion Proof applications an engagement of at least 8 full threads must be achieved for parallel threads and 5 full
threads must be achieved for tapered threads
49
Accessories: Breather Drain
EXBD
EXBD Series Breather Drain provides a method of effectively draining any moisture within an enclosure whilst
allowing the air inside the enclosure to breathe with the surrounding atmosphere. EXBD series breather drains
maintain Increased Safety Exe method of explosion protection and IP66 for IEC type applications.
EXAMPLE PART NUMBER
EXBD [W] [Y] [ZZ]
W - Material (B = Brass / S = Stainless Steel / N = 30% Glass Filled
Nylon)
Y
- Plating (0 = No Plating / 1 = Nickel / 2 = Tin / 3 = Zinc / 4 =
Electroless Nickel)
YY - Male Thread
ZZ - 10 or 15
Sample: EXBD-B-0-M20-15
Moisture
Castellated
Locknut
Internal
Dust Seal
CERTIFICATION
CENELEC
SIRA99ATEX3050U I M2 II 2DG EExe I/II; II 2DG E Exe (Glass Filled
Nylon)
Captive
'O' Ring Seal
Moisture Out
Air In
CSA / A Ex
Class I, Zone 1, Exe II; Class I Division 2, Groups ABCD
External
Drainage
GOST R-Exde IICY
POCC GB 05.B00482
APPLICATION
Internal Dust Seal provides ingress protection to IP66 and 4x, with the largest possible pore size to aid draining, whilst retaining filtration
capabilities that remove debris from the moisture and retains it on the surface where it can easily be removed with compressed air.
Additionally the structural strength and chemical resistance characteristics of the material enable the filter to meet the requirements of
hazardous area installations
Castellated Locknut allows moisture to pass between the locknut and the enclosure, draining via holes in the thread without any build up of
moisture in the bottom of the enclosure
Captive 'O' Ring Seal is located within a recess on the face of the breather drain again optimising ingress protection, ensuring the 'o'ring is
not displaced during installation and helping protect the 'O' ring from the environmental damage
External Drainage via two ports optimises ingress protection without compromising the draining capabilities
INGRESS PROTECTION
IMPACT RESISTANCE
IP66, CSA Enclosure Type 4x, NEMA 4x
20Nm. (7Nm GF Nylon)
OPERATING TEMPERATURES
-50°C to +85°C
MATERIALS
Brass CZ121 (EXBD-B)
316 Stainless Steel (EXBD-S)
30% Glass Filled Nylon (EXBD-N)
VARIATIONS
Clearance Hole: 10mm length of thread, supplied complete with a castellated locknut and having 2 holes in the thread wall positioned directly
opposite each other (EXBD-W-Y-YY-10)
Threaded Entry: 15mm length of thread, either supplied with castellated locknut (EXBD-W-Y-YY-15) or without castellated locknut (EXBD-W-YYY-15NL) and having 3 holes in the thread wall, offset to provide a 9mm range to accommodate differing wall thickness.
50
THREADS
SEALS
ISO Metric; NPT; NPS; ISO Pipe Thread
(BSP Taper, BSP Parallel); PG
PLATING
The standard 'O' Ring material is Nitrile
Nickel (1); Tin (2); Zinc (3); Electroless
Nickel (4)
DIMENSIONAL DATA
Size
Hex A/F
Hex A/C
M20 - N1
28.6mm
32.9mm
M25 - N2
34.9mm
40.2mm
Thread Length
Head Length
10 (2 Hole) or 15 (3 Hole)
15mm
All Dimensions are in Millimeters
NOTES:
• 30% glass filled nylon variations are only available with 15mm length of thread version and are supplied with or without a brass
castellated nut
•
Full installation instructions are supplied with the breather drain, the instructions must be read prior to installation and adhered to in full
•
Unless otherwise stated ISO Metric entry threads have a 1.5mm pitch
•
Where metallic breather drains are fitted into non-metallic Increased Safety Exe enclosures they must be included within the earth
circuit of the system
51
Accessories: General
A full range of accessories including locknuts, earthtags, sealing washers, serrated washers and shrouds for
use with all our cable glands
AVAILABILITY
ACCESSORY TYPE
GLAND TYPES/SIZE
THREAD TYPES
METRIC
NPT
BSP
FRENCH
Locknuts provide a method of securing a threaded entry component into a piece of equipment
Brass (EX-BLN)
316 Stainless Steel (EX-SLN)
All
M16 to M100
1/2" to 4"
1/2" to 4"
F48
316 Stainless Steel
M16 to M100
1/2" to 4"
1/2" to 4"
F48
Nylon (EX-NLN)
Nylon
M20 to M63
-
-
-
Steel (EX-MLN)
Industrial
M20 to M50
-
-
-
1/2" to 4"
1/2" to 4"
F48
Earth Tags provide an earth bond connection for an entry component
Brass (EX-BET)
All
M16 to M100
IP Sealing Washers are fitted between an entry component and the equipment to maintain the IP rating of the equipment
Nylon (EX-NSW)
All
M16 to M100
1/2" to 4"
1/2" to 4"
F48
Red Fibre (EX-SFW)
All
M20 to M75
-
-
-
Serrated Star Washers can be used in conjunction with a locknut to provide additional fixing security and improve bonding
316 Stainless Steel (EX-SSW)
All
M16 to M100
1/2" to 4"
1/2" to 4"
F48
Galvanised Steel (EX-GSW)
All
M20 to M75
-
-
-
Shrouds can be used to protect the gland from the surrounding environment
PVC (EX-PVC)
16 to 100
PCP (EX-PCP)
16 to 85
LSOH (EX-LSH)
16 to 85
Shrouds are not available for all glands, please see specific gland page for exact details
NOTES:
•
As standard ISO Metric threads are supplied with a 1.5mm pitch up to and including M75 and a 2.0mm pitch for sizes above M75
52
Entry Thread Reference Tables
Thread Types
ISO
METRIC
IEC 60423
1993
NPT
ANSI
B1.20.1
1983
NPS
ANSI
B1.20.1
1983
Thread Ref
Size
Major Ø
TPI
Pitch
Thread Length
Min Hex A/C
M16
16 x 1.5
15.97
16.93
1.50
16.0
26.5
M20
20 x 1.5
19.97
16.93
1.50
16.0
33.0
M25
25 x 1.5
24.97
16.93
1.50
16.0
41.4
M32
32 x 1.5
31.97
16.93
1.50
16.0
50.6
M40
40 x 1.5
39.97
16.93
1.50
16.0
60.4
M50
50 x 1.5
49.97
16.93
1.50
16.0
71.5
M63
63 x 1.5
62.97
16.93
1.50
19.0
88.0
M75
75 x 1.5
74.97
16.93
1.50
19.0
99.0
M80
80 x 2.0
19.97
12.70
2.00
25.0
115.2
M85
85 x 2.0
84.97
12.70
2.00
25.0
115.2
M90
90 x 2.0
89.97
12.70
2.00
25.0
125.7
M100
100 x 2.0
99.97
12.70
2.00
25.0
125.7
N1
1/2"
21.22
14.00
1.81
19.9
26.5
N2
3/4"
26.57
14.00
1.81
20.1
33.0
N3
1"
33.23
11.50
2.20
21.5
41.4
N4
11/4"
41.99
11.50
2.20
25.6
50.6
N5
11/2"
48.05
11.50
2.20
26.0
60.5
N6
2”
60.09
11.50
2.20
26.9
71.5
N7
21/2"
72.70
8.00
3.18
39.9
88.0
N8
3”
88.61
8.00
3.18
41.5
99.0
N9
31/2"
101.36
8.00
3.18
42.8
115.2
N10
4"
113.97
8.00
3.18
44.0
125.7
S1
1/2"
20.90
14.00
1.81
19.9
26.5
S2
3/4"
26.26
14.00
1.81
20.1
33.0
S3
1"
32.84
11.50
2.20
21.5
41.4
S4
11/4"
41.61
11.50
2.20
25.6
50.6
S5
11/2"
47.67
11.50
2.20
26.0
60.5
S6
2"
59.72
11.50
2.20
26.9
71.5
S7
21/2"
72.16
8.00
3.18
39.9
88.0
S8
3"
88.06
8.00
3.18
41.5
99.0
S9
31/2"
100.78
8.00
3.18
42.8
115.2
S10
4"
113.43
8.00
3.18
44.0
125.7
F48
PG48 (FR)
59.61
11.00
2.31
26.9
71.5
P1
1/2"
20.96
14.0
1.81
19.9
26.5
P2
3/4"
26.44
14.0
1.81
20.1
33.0
P3
1”
33.25
11.0
2.31
25.0
41.4
BS2779
P4
11/4"
41.91
11.0
2.31
25.6
50.6
(BSPP, G,
R, PF)
P5
11/2"
47.80
11.0
2.31
26.0
60.5
P6
2"
5961
11.0
2.31
26.9
71.5
P7
21/2"
75.18
11.0
2.31
39.9
88.0
T1
1/2"
20.96
14.0
1.81
19.9
26.5
T2
3/4"
26.44
14.0
1.81
20.1
33.0
T3
1"
33.25
11.0
2.31
25.0
41.4
T4
11/4"
41.91
11.0
2.31
25.6
50.6
T5
11/2"
47.80
11.0
2.31
26.0
60.5
T6
2"
5961
11.0
2.31
26.9
71.5
T7
21/2"
75.18
11.0
2.31
39.9
88.0
ISO Pipe
Parallel
ISO R/7;
ISO Pipe
Taper to
ISO R/7;
BS21
(BSPT, GK)
53
Ingress Protection
It is essential when selecting cable glands and/or accessories to ensure that the products will maintain the IP rating of
the equipment and the integrity of the installation.
IP Codes are based on the IEC Standard 529, degrees of protection provided by enclosures.
In most cases Peppers cable glands will maintain Ingress Protection of the equipment into which they are installed to:
IP 66
• Dust Tight. No ingress of dust possible.
• Protected against heavy seas or powerful jets of water
IP67
• Dust Tight. No ingress of dust possible
• Protected against harmful ingress of water when immersed between a depth of 150mm to 1m
IP68
• Dust Tight. No ingress of dust possible.
• Protected against submersion. Suitable for continuous immersion in water at stated depth.
• Depth stated for Amphenol cable glands is 25m
DTS 01 (Deluge)
• This test was originally constructed by shell and Esso in the UK to simulate the routine deluging of electrical equipment on offshore
installations.
IP 54- Minimum requirement for Hazardous Location products
• Dust protected. Prevents ingress of dust sufficient to cause harm.
• Protected from splashing water from any direction
As a general guide to selecting the sealing method that is most likely to maintain the required IP rating for different
entry types, we recommend:
• Clearance Holes - Integral ‘O’ ring seal or nylon IP washer
• Parallel Threaded Entries - Integral ‘O’ ring seal, IP washer or non-hardening thread sealant
• Taper Threaded Entries - Non-hardening thread sealant
Gland Weight Data
Gland Size
Entry
Thread
Cable Gland Type
EX-20
EX-25
EE-30
EX-35
EX-40
EE-RG
EX-60
EX-65
EX-70
EX-75
16
M20
164
144
134
84
142
6
165
-
-
-
-
20s
M20
160
130
124
90
144
-
165
115
180
-
52
20
M20
250
186
180
94
158
8
240
170
260
215
84
25
M25
400
262
262
152
256
16
400
260
385
340
140
32
M32
750
420
402
176
298
28
725
384
570
485
180
40
M40
1095
672
680
332
556
35
1060
585
885
730
436
50s
M50
1415
980
1040
570
980
-
1435
-
1035
-
-
50
M50
1295
758
764
458
796
65
1340
700
1160
875
480
63s
M63
2345
1410
1410
850
1410
-
2100
-
1555
-
-
63
M63
2005
1140
1185
684
1170
74
2025
1040
1695
1355
910
75s
M75
1980
1745
1730
954
1565
-
2330
-
1750
-
-
75
M75
2200
1375
1495
764
1310
-
2240
1150
1880
1475
1070
80
M80
3970
3255
3130
1430
2130
-
4985
2730
3860
3415
1770
85
M85
3300
2655
2500
1290
1980
-
4065
2255
3250
2830
-
90
M90
4314
3559
3280
1510
2360
-
5215
2790
3985
3985
-
100
M100
3537
2795
3054
1485
2285
-
4410
2450
3580
3580
-
All weights are approximate and shown in grams
NOTES:
•
Weights shown are for Brass versions (except Nylon EE-RG)
•
To estimate weights for 316 Stainless Steel versions apply a factor of 0.92
•
Weights for glands with non-metric entry threads will vary
•
Approximate weights for EX-45, EX-50, EX-55 are available on application
•
Approximate weights for CGDS, CGSS and CGU industrial glands are the same as for EX versions
54
CGA
Amphenol®/Pyle® Industrial Cord Grips
Amphenol®/Pyle® Industrial Cord Grips make sure your cord or cable stays in and everything else stays out. This
product is designed for liquid-tight strain relief of cord, cable, and flexible conduit. Available in straight, 45°, and 90°
styles, Amphenol®/Pyle® cord grips are UL listed, and CSA certified.
This section will provide information on a large family of cable pass-thru and strain relief devices for use with
industrial connectors by showing complete assemblies as well as component parts. Contact your Amphenol®/Pyle®
distributor for assistance.
Features & Benefits
UL Listed and CSA certified. Used for sealing where moving parts or handling can abuse connections.
Tapered rubber grommet and seat. Secure cord the entire length of grommet making a liquid-tight seal.
Variety of styles: straight, 45°, 90°, and flexible. Assures ease of installation and permits custom cable routing
Various strain relief options: Standard compression nut, mechanical clamp nut or basket weave styles.
Tapered conduit threads. Provide strong water and oil-tight joint.
Machined components. Strong, lightweight, and have long service life.
Male and female threads. Provides versatility in panelboard or threaded hub applications
Applications
FOR POWER CONTROL:
• Switchboards
• Machine Tools
• Heating and Cooling
• Lighting and Ballasts
• Portable Equipment
• Motors and Generators
• Production Machinery
• Processing Equipment
• Robotics and Welding
• Standby Power
• Medical/Dental Equipment
FOR COMMUNICATION:
• Radio and Radar
• Television
• Transformers
• Data Processing
• Instruments
FOR TRANSPORATION
• Shipyards
• Refrigerated Containers
• Railroad and Trucking
Materials and Finishes
Straight Bodies
45° & 90° Bodies
Grommets
Washers
Compression Nuts
Mechanical Nuts
Copper-free aluminum bar stock
Cadmium plated ferrous alloy
Oil-resistant synthetic rubber
Cadmium plated cold rolled steel
Copper-free aluminum bar stock
Cast Aluminum
55
Amphenol Cord Grips
CORD
GRIP
SPECIFICATIONS
Cord Grip
Specifications
Allowable Ampacities
of Insulated Conductors
Fraction Conversion Table
Fraction
as taken from 1987 Edition of National Electric Code.
Rated 0-2000 Volts, 60° to 90°
Not More Than Three Conductors in Raceway or Cable or Earth
(Directly Buried), Based on Ambient Temperature of 30°C(86°F)
Temperature Rating of Conductors (Copper)
Size
60°C
(140°F)
75°C
(176°F)
85°C
(185°F)
90°C
(194°F)
†TW, †UF
†FEPW, †RH,
†RHW, †THW,
†THWN,†XHHW,
†USE, †ZW
V
TA, TBS, SA,
AVB, SIS, †FEP,
†FEPB, †RHH,
†THHN
†XHHW*
...
...
20†
25†
30
40
55
70
85
95
110
125
...
...
20†
25†
35†
50
65
85
100
115
130
150
...
18
25
30
40
55
70
95
110
125
145
165
14
18
25†
30†
40†
55
75
95
110
130
150
170
AWG
MCM
18
16
14
12
10
8
6
4
3
2
1
0
Ampacity Correction Factors
For ambient temperatures other than 30°C, multiply
the ampacities shown above by the appropriate factor
shown below.
Ambient
Temp. °C (°F)
60°C
(140°F)
75°C
(176°F)
85°C
(185°F)
90°C
(194°F)
31-40 (87-104)
41-45 (105-113)
46-50 (114-122)
51-60 (123-141)
61-70 (142-158)
71-80 (159-176)
.82
.71
.58
...
...
...
.88
.82
.75
.58
.35
...
.90
.85
.80
.67
.52
.30
.91
.87
.82
.71
.58
.41
†The overcurrent protection for conductor types marked with an obelisk (†) shall not exceed 15
amperes for 14AWG and 30 amperes for 10 AWG copper.
*For dry locations only. See 75°C column for wet locations
56
Mm
Fraction
1/64
1/32
3/64
1/16
5/64
Decimal
0.0156
0.0312
0.0469
0.0625
0.0781
0.379
0.794
1.191
1.588
1.984
33/64
17/32
35/64
9/16
37.64
Decimal
0.5156
0.5312
0.5469
0.5625
0.5781
13.097
13.494
13.891
14.288
14.684
Mm
3/32
7/64
0.0938
0.1094
2.381
2.778
19/32
39/64
0.5938
0.6094
15.081
15.478
1/8
0.1250
3.175
5/8
0.6250
15.875
9/64
5/32
11/64
3/16
13/64
7/32
15/64
1/4
0.1406
0.1562
0.1719
0.1875
0.2031
0.2188
0.2344
0.2500
3.572
3.969
4.366
4.762
5.159
5.556
5.953
6.350
41/64
21/32
43/64
11/16
45/64
23/32
47/64
3/4
0.6406
0.6562
0.6719
0.6875
0.7031
0.7188
0.7344
.7500
16.272
16.669
17.066
17.462
17.859
18.256
18.653
19.050
17/64
9/32
19/64
5/16
21/64
11/32
23/64
3/8
0.2656
0.2812
0.2969
0.3125
0.3281
0.3438
0.3594
0.3750
6.747
7.144
7.541
7.938
8.334
8.731
9.128
9.525
49/64
26/32
51/64
13/16
53/64
27/32
55/64
7/8
0.7655
0.7812
0.7969
0.8125
0.8281
0.8438
0.8594
0.8750
19.447
19.844
20.241
20.638
21.034
21.431
21.828
22.225
25/64
13/32
27/64
7/16
29/64
15/32
31/64
1/2
0.3906
0.4062
0.4219
0.4375
0.4531
0.4688
0.4844
0.5000
9.922
10.319
10.716
11.112
11.509
11.906
12.303
12.700
57/64
29/32
59/64
15/16
61/64
31/32
63/64
1
0.8906
0.9062
0.9219
0.9375
0.9531
0.9688
0.9844
1.0000
22.622
23.019
23.416
23.812
24.209
24.606
25.003
25.400
Amphenol Cord Grips
Cord Grip Specifications
Amperages of OF
Electric
Motors MOTORS
AMPERAGES
ELECTRIC
Selected Cord and Cable Diameters
Type of Cord
AWG
Size of
Conductors
Number of Conductors and
Approximate O.D. in Inches
2
3
4
SJ, SJO
18
16
14
.300
.330
.375
.330
.360
.395
.360
.390
.420
S, SO, ST, STO
18
16
14
12
10
8
.385
.400
.530
.600
.640
.820-.930
.400
.425
.560
.635
.690
.885-1.010
.430
.480
.605
.665
.745
.975-1.100
6
4
3
2
1
1/0
2/0
3/0
4/0
250
.700-.840
1.080
1.170
1.270
1.440
1.520
1.650
1.770
1.920
2.160
.750-.910
1.170
1.240
1.340
1.510
1.650
1.750
1.890
2.070
2.390
.820-.990
1.270
1.340
1.480
1.680
1.790
1.930
2.070
2.260
–
14
12
10
8
–
–
–
–
–
–
–
–
.410
.450
.530
.670
W
Bus Drop Cable
NOTE: Dimensions are approximate. When possible consult manufacturer’s data.
Motor Full Load Current (Amps)
Motor
Horse
Power
200 V.
230V.
460V
575V.
115V.
230V.
1/20
1/12
1/8
1/6
0.39
0.55
0.74
0.90
0.34
0.48
0.64
0.78
0.17
0.24
0.32
0.39
0.14
0.19
0.26
0.31
1.30
1.90
2.60
3.24
0.65
0.95
1.30
1.62
1/4
1/3
1/2
3/4
1.22
1.52
2.07
2.88
1.06
1.32
1.80
2.50
0.53
0.66
0.90
1.25
0.42
0.53
0.72
1.00
4.40
5.47
7.45
10.1
2.20
2.74
3.73
5.07
1
1½
2
3
3.68
5.18
6.67
9.66
3.20
4.50
5.80
8.40
1.60
2.25
2.90
4.20
1.28
1.80
2.32
3.36
126
17.2
21.4
29.1
6.31
8.59
10.7
14.5
5
7½
10
15
15.4
22.6
29.7
43.6
13.4
19.6
25.8
38.0
6.68
9.82
12.9
19.0
5.35
7.86
10.3
15.2
42.9
58.4
...
...
21.4
29.2
36.3
49.4
20
25
30
40
57.4
70.9
84.3
111.
49.9
61.7
73.3
96.4
24.9
30.8
36.7
48.2
20.0
24.7
29.3
38.5
...
...
...
...
...
...
...
...
50
60
75
137.
163.
201.
119.
142.
175.
59.6
70.8
87.6
47.6
56.6
70.0
...
...
...
...
...
...
Three Phase
Single Phase
NOTE: These are approximate currents to be used for selecting cord wire sizes.
57
U
®L
DB/DBM GROUP
Strain-relief connectors for
flexible cord and cable
LISTED
File No. E53509
CERTIFIED
File No. LR-64107
small straight body, male thread
Aluminum body and compression nut with
washer and single hole oil-resistant grommet
This small body connector is ideal
for internal uses, as well as
conduit hub and panel-board
mounting into threaded bodies or
with locknuts. Complete units
listed require no other parts
excecpt cable. Component parts
allow expansion or updating of
present equipment.
CONDUIT
HUB
SIZE
1
/4”
PANEL
HOLE
SIZE
9
/16”
3
11
1
/2”
7
3
/4”
11/8”
1”
13/8”
/8”
/16”
Suitable for use in hazardous
locations per National Electric
Code Class I, Div. 2; Class II, Div. 1
& 2; Class III, Div. 1&2.
/8”
Insulated throat option:
Add suffix “T” to all complete
assembly part numbers on this
page. E.g.: DB-9916T.
CORD
DIAMETER
RANGE IN (MM)
.125-.187 (3.17-4.75)
.187-.250 (4.75-6.35)
.250-.312 (6.35-7.92)
.125-.187 (3.17-4.75)
.187-.250 (4.75-6.35)
.250-.312 (6.35-7.92)
.312-.375 (7.92-9.52)
.375-.437 (9.52-11.1)
.125-.187 (3.17-4.75)
.187-.250 (4.75-6.35)
.250-.312 (6.35-7.92)
.312-.375 (7.92-9.52)
.375-.437 (9.52-11.1)
.125-.250 (3.17-6.35)
.187-.312 (4.75-7.92)
.250-.375 (6.35-9.52)
.312-.437 (7.92-11.1)
.375-.500 (9-52-12.7)
*.437-.562 (11.1-14.3)
*.500-.625 (12.7-15.9)
*.625-.687 (15.9-17.4)
*.687-.750 (17.4-19.1)
.125-.250 (3.17-6.35)
.187-.312 (4.75-7.92)
.250-.375 (6.35-9.52)
.312-.437 (7.92-11.1)
.375-.500 (9.52-12.7)
.437-.562 (11.1-14.3)
.500-.625 (12.7-15.9)
.625-.687 (15.9-17.4)
.687-.750 (17.4-19.1)
*.750-.875 (19.1-22.2)
*.875-1.00 (22.2-25.4)
.375-.437 (9.52-11.1)
.437-.500 (11.1-12.7)
.500-.562 (12.7-14.3)
.562-.625 (14.3-15.9)
.625-.687 (15.9-17.4)
.687-.750 (17.4-19.1)
.687-.812 (17.4-20.6)
.750-.875 (19.1-22.2)
.812-.937 (20.6-23.8)
*.875-1.00 (22.2-25.4)
COMPLETE ASSEMBLY PART NUMBERS
WITH
WITH
WITH
COMPRESSION NUT MECHANICAL NUT WOVEN GRIP
DB-44316
DB-4414
DB-44516
DB-4316
DB-414
DB-4516
DB-438
DB-4
DB-3316
DB-314
DB-3516
DB-338
DB-3
DB-7
DB-9516
DB-8
DB-9716
DB-9
DB-9916
DB-10
DB-91116
DB-934
DB-614
DB-6516
DB-638
DB-6716
DB-612
DB-6919
DB-6
DB-111116
DB-11
DB-2514
DB-2516
DB-33716
DB-3312
DB-33916
DB-3358
DB-331116
DB-33
DB-1413
DB-1478
DB-141516
DB-14
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
DBM-1204-M
DBM-1205-M
DBM-1206-M
DBM-1207-M
DBM-1208-M
DBM-1209-M
DBM-1210-M
DBM-1311-M
DBM-1312-M
DBM-2204-M
DBM-2205
DBM-2206-M
DBM-2207-M
DBM-2208-M
DBM-2209-M
DBM-2210-M
DBM-2311-M
DB-2312-M
DBM-2514-M
DBM-2516-M
DBM-3307-M
DBM-3308-M
DBM-3309-M
DBM-3310-M
DBM-3311-M
DBM-3312-M
DBM-3513-M
DBM-3514-M
DBM-3515-M
DBM-3516-M
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
DBKM-1205
DBKM-1206
DBKM-1207
DBKM-1208
DBKM-1209
DBKM-1210
DBKM-1311
DBKM-1312
.....
DBKM-2205
DBKM-2206
DBKM-2207
DBKM-2208
DBKM-2209
DBKM-2210
DBKM-2311
DBKM-2312
DBKM-2514
DBKM-2516
DBKM-3307
DBKM-3308
DBKM-3309
DBKM-3310
DBKM-3311
DBKM-3312
DBKM-3513
DBKM-3514
DBKM-2515
DBKM-3516
*Maximum cord size will not pass through body without removing outer jacket.
Other grommets both single and multi-hole are available–see page 70.
See pages 60-61 for dimensional information.
58
FORM
SIZE
1
BODY
BORE--IN (MM)
DB-4-G
.35 (8.9)
1
DB-4-A
.44 (11.2)
1
DB-3-A
.44 ( 11.2
2
DB-9-A
.64 (16.3
3
DB-934-A
.62 (15.7)
2
DB-6-A
.64 (16.3)
3
DB-11-A
.75 (19.1)
DB-25-M
.81 (20.6)
5
3
DB-33-A
.75 (19.1)
5
DB-14-A
1.03 (26.2)
GROMMET
DB-4-F
DB-4-J
DB-4-D
DB-4-F
DB-4-J
DB-4-D
DB-4-E
DB-4-C
DB-4-F
DB-4-J
DB-4-D
DB-4-E
DB-4-C
DB-9-F
DB-9-V
DB-9-E
DB-9-J
DB-9-D
DB-9-U
DB-9-C
DB-11-O
DB-11-C
DB-9-F
DB-9-V
DB-9-E
DB-9-J
DB-9-D
DB-9-V
DB-9-C
DB-11-O
DB-11-C
DB-14-H
DB-14-C
DB-11-E
DB-11-D
DB-11-R
DB-11-K
DB-11-O
DB-11-C
DB-14-K
DB-14-H
DB-14-L
DB-14-C
PLAIN
WASHER
COMPONENT PART NUMBERS
COMPRESSION
MECHANICAL
NUT
NUT
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
PX-4-CS
DB-4-B
PX-4-CS
DB-4-B
PX-4-CS
DB-4-B
PX-8-CS
DB-9-B
PX-10
PX-11-CS
DB-11-B
PX-11
PX-8-B
DB-9-B
PX-10
PX-11-CS
DB-11-B
PX-11
PX-14-CS
DB-14-B
PX-14
PX-11-CS
DB-11-B
PX-11
PX-14-CS
DB-14-B
PX-14
WOVEN
GRIP
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
DBKG-5
DBKG-6
DBKG-8
DBKG-8
DBKG-10
DBKG-10
DBKG12
DBKG-12
.....
DBKG-5
DBKG-6
DBKG-8
DBKG-8
DBKG-10
DBKG-10
DBKG-12
DBKG-12
DBKG-14
DBKG-16
DBKG-8
DBKG-8
DBKG-10
DBKG-10
DBKG-12
DBKG-12
DBKG-14
DBKG-14
DBKG-16
DBKG-16
WOVEN GRIP
WASHER
WOVEN GRIP
NUT
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
∆
∆
∆
∆
∆
PX-8-CS
PX-11-CS
PX-11-CS
.....
∆
∆
∆
∆
∆
PX-8-CS
PX-11-CS
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
∆
PX-14-CS
DBK-11-W
DBK-11-W
DBK-11-W
DBK-11-W
PX-11-CS
PX-11-CS
∆
∆
PX-14-CS
PX-14-CS
DBK-14-B
DBK-9-B
DBK-11-B
DBK-11-B
DBK-9-B
DBK-11-B
DBK-11-B
DBK-14-B
∆ Not required
59
U
®L
DBZM GROUP
Strain relief connectors for
flexible cord and cable
LISTED
File No. E3509
CERTIFIED
File No. LR-64107
Large straight body, male thread
Aluminum body and compression nut with washer
and single hole oil-resistant grommet
Large body DBZ connectors can
CONDUIT
be employed in retrofit or new
HUB
installations. Versatility allows use SIZE
in panelboards and in threaded
hubs. Component parts are
available separately.
1
PANEL
HOLE
SIZE
1 /4”
13/4”
11/2”
2”
2”
21/2”
21/2”
3”
3”
35/8”
Suitable for use in hazardous
locations per National Electric
Code Class I, Div. 2; Class II, Div. 1
& 2; Class III, Div. 1&2.
COMPLETE ASSEMBLY PART NUMBERS
CORD
DIAMETER
RANGE IN (MM)
WITH
WITH
WITH
COMPRESSION NUT MECHANICAL NUT WOVEN GRIP
.750- .875 (19.1-22.2)
.875-1.000 (22.2-25.4)
1.000-1.125 (25.4-28.6)
1.125-1.250 (28.6-31.8)
*1.250-1.375 (31.8-34.9)
.750- .875 (19.1-22.2)
.875-1.000 (22.2-25.4)
1.000-1.125 (25.4-28.6)
1.125-1.250 (28.6-31.8)
1.250-1.375 (31.8-34.9)
1.375-1.500 (34.9-38.1)
*1.500-1.625 (38.1-41.3)
*1.625-1.750 (41.3-44.5)
*1.750-1.875 (44.5-47.6)
1.250-1.375 (31.8-34.9)
1.375-1.500 (34.9-38.1)
1.500-1.625 (38.1-41.3)
1.625-1.750 (41.3-44.5)
1.750-1.875 (44.5-47.6)
1.875-2.000 (47.6-50.8)
2.000-2.125 (50.8-54.0)
2.125-2.250 (54.0-57.2)
2.250-2.375 (57.2-60.3)
1.875-2.000 (47.6-50.8)
2.000-2.125 (50.8-54.0)
2.125-2.250 (54.0-57.2)
2.250-2.375 (57.2-60.3)
DBZM-4714
DBZM-4716
DBZM-4718
DBZM-4720
DBZM-4722
DBZM-5714
DBZM-5716
DBZM-5718
DBZM-5720
DBZM-5722
DBZM-5824
DBZM-5826
DBZM-5828
DBZM-5830
DBZM-6822
DBZM-6824
DBZM-6826
DBZM-6828
DBZM-6830
DBZM-7932
DBZM-7934
DBZM-7936
DBZM-7938
DBZM-8932
DBZM-8934
DBZM-8936
DBZM-8938
DBZM-4714-M
DBZM-4716-M
DBZM-4718-M
DBZM-4720-M
DBZM-4722-M
DBZM-5714-M
DBZM-5716-M
DBZM-5718-M
DBZM-5720-M
DBZM-5722-M
DBZM-5824-M
DBZM-5826-M
DBZM-5828-M
DBZM-5830-M
DBZM-6822-M
DBZM-6824-M
DBZM-6826-M
DBZM-6828-M
DBZM-6830-M
DBZM-7932-M
DBZM-7934-M
DBZM-7936-M
DBZM-7938-M
DBZM-8932-M
DBZM-8934-M
DBZM-8936-M
DBZM-8938-M
DBZM-4714-K
DBZM-4716-K
DBZM-4718-K
DBZM-4720-K
DBZM-4722-K
DBZM-5714-K
DBZM-5716-K
DBZM-5718-K
DBZM-5720-K
DBZM-5722-K
DBZM-5824-K
DBZM-5826-K
DBZM-5828-K
DBZM-5830-K
DBZM-6822-K
DBZM-6824-K
DBZM-6826-K
DBZM-6824-K
DBZM-6830-K
DBZM-7932-K
DBZM-7934-K
DBZM-7936-K
DBZM-7938-K
DBZM-8932-K
DBZM-8934-K
DBZM-8936-K
DBZM-8938-K
*Maximum cord size will not pass through body without removing outer jacket.
Other grommets both single and multi-hole are available–see page 70.
E
MAX
C
A
D*
B*
DB/DBM, FORMS 1, 2, 3, 5
60
COMPONENT PART NUMBERS
FORM
SIZE
BODY
BORE–IN (MM)
7-Z
DBZ-47-M
1.31 (33.2)
7-Z
DBZ-57-M
1.44 (36.6)
8-Z
DBZ-58-M
1.56 (39.7)
8-Z
DBZ-68-M
1.94 (49.2)
9-Z
DBZ-79-M
2.44 (62.0)
9-Z
DBZ-89-M
2.44 (62.0)
GROMMET
PLAIN
WASHER
DBZ-714
DBZ-716
DBZ-718
DBZ-720
DBZ-722
DBZ-714
DBZ-716
DBZ-718
DBZ-720
DBZ-722
DBZ-824
DBZ-826
DBZ-828
DBZ-830
DBZ-822
DBZ-824
DBZ-826
DBZ-828
DBZ-830
DBZ-932
DBZ-934
DBZ-936
DBZ-938
DBZ-932
DBZ-934
DBZ-936
DBZ-938
DBZ-716-W
DBZ-716-W
DBZ-720-W
DBZ-720-W
DBZ-723-W
DBZ-716-W
DBZ-716-W
DBZ-720-W
DBZ-720-W
DBZ-723-W
DBZ-824-W
DBZ-826-W
DBZ-828-W
DBZ-831-W
DBZ-824-W
DBZ-824-W
DBZ-828-W
DBZ-828-W
DBZ-831-W
DBZ-932-W
DBZ-936-W
DBZ-936-W
DBZ-939-W
DBZ-932-W
DBZ-936-W
DBZ-936-W
DBZ-939-W
COMPRESSION
NUT
MECHANICAL
NUT
DBZ-7-B
DBZ-7-B
DBZ-7-B
DBZ-7-M
DBZ-8-B
DBZ-8-M
DBZ-8-B
DBZ-8-M
DBZ-9-B
DBZ-9-M
DBZ-9-B
DBZ-9-M
WOVEN
GRIP
DBKG-14
DBKG-16
DBKG-18
DBKG-20
DBKG-22
DBKG-14
DBKG-16
DBKG-18
DBKG-20
DBKG-22
DBKG-26
DBKG-26
DBKG-28
DBKG-28
DBKG-22
DBKG-26
DBKG-26
DBKG-28
DBKG-28
DBKG-34
DBKG-34
DKGZ-38
DBKG-38
DBKG-34
DBKG-34
DBKG-38
DBKG-38
WOVEN GRIP
WASHER
LZW-9316-16A
LZW-9316-16A
LZW-9316-20A
LZW-9316-20A
∆
LZW-9316-16A
LZW-9316-16A
LZW-9316-20A
LZW-9316-20A
∆
∆
∆
∆
∆
LZW-9320-22A
∆
∆
∆
∆
∆
∆
∆
∆
∆
∆
∆
∆
WOVEN GRIP
NUT
DBZ-7-B
DBZ-7-B
DBZ-8-B
DBZ-8-B
DBZ-9-B
DBZ-9-B
∆ Not required
DIMENSIONS
A
B * ACROSS
C FLATS
D*
E MAX
E Max
C
1
.88
1.53
–
–
–
2
1.13
1.84
1.38
2.49
1.66
FORM SIZE
3
5
7-Z
1.25 1.63 2.23
2.06 2.69 3.22
1.38 1.75 2.00
2.69 3.50 4.02
1.66 2.069 2.78
*With nut snug, grommet not compressed.
A
D*
B*
DBZ, FORMS 7-Z, 8-Z, 9-Z
61
8-Z
2.53
3.22
2.50
4.43
3.46
9-Z
3.28
3.91
3.00
4.88
4.10
DBL/DBZL GROUP
U
®L
Strain-relief connectors
for flexible cord and cable
LISTED
File No. E53509
CERTIFIED
File No. LR-64107
90° elbow body, male thread
Ferrous alloy body, aluminum compression nut
with washer and single hole oil-resistant grommet
These 90° connectors allow the
installation of cord and cable even
in tight quarters. Rugged ferrous
alloy body and aluminum
compression nut assure long life in
abusive situations.
Suitable for use in hazardous
locations per National Electric
Code Class I, Div. 2; Class II, Div. 1
& 2; Class III, Div. 1&2.
Insulated throat option:
Add suffix “T” to complete
assembly part numbers
for ½”-1” only.
E.g.:DBL-3514-MT.
CONDUIT
HUB
SIZE
1
/2”
PANEL
HOLE
SIZE
7
/8”
3
/4”
11/8”
1”
13/8”
11/4”
13/4”
11/2”
2”
2”
21/2”
CORD
DIAMETER
RANGE IN (MM)
COMPLETE ASSEMBLY PART NUMBERS
WITH
WITH
WITH
COMPRESSION NUT MECHANICAL NUT WOVEN GRIP
.125-.250 (3.17-6.35)
.187-.312 (4.75-7.92)
.250-.375 (6.35-9.52)
.312-.437 (7.92-11.1)
.375-.500 (9.52-12.7)
* .437-.562 (11.1-14.3)
* .500-.625 (12.7-15.9)
.312-.375 (7.92-9.52)
.375-.437 (9.52-11.1)
.437-.500 (11.1-12.7)
.500-.562 (12.7-14.3)
.562-.625 (14.3-15.9)
.625-.687 (15.9-17.4)
* .687-.750 (17.4-19.1)
.687-.812 (17.4-20.6)
.750-.875 (19.1-22.2)
.812-.937 (20.6-23.8)
* .875-1.000 (22.2-25.4)
.750-.875 (19.1-22.2)
.875-1.000 (22.2-25.4)
1.000-1.125 (25.4-28.6)
1.125-1.250 (28.6-31.8)
*1.250-1.375 (31.8-34.9)
*1.375-1.500 (34.9-38.1)
*1.500-1.625 (38.1-41.3)
*1.625-1.750 (41.3-44.5)
*1.750-1.875 (44.5-47.6)
*1.375-1.500 (34.9-38.1)
*1.500-1.625 (38.1-14.3)
*1.625-1.875 (44.5-47.6)
*1.750-1.875 (44.5-47.6)
DB-790
DB-9590
DB-890
DB-9790
DB-990
DB-9990
DB-1090
DB-113890
DB-1171690
DB-111290
DB-1191690
DB-115890
DB-11111690
DB-1190
DB-141390
DB-147890
DB-14151690
DB-1490
DBZL-4714
DBZL-4716
DBZL-4718
DBZL-4720
DBZL-4722
DBZL-5824
DBZL-5826
DBZL-5828
DBZL-5830
DBZL-6824
DBZL-6826
DBZL-6828
DBZL-6830
DBL-1204-M
DBL-1205-M
DBL-1206-M
DBL-1207-M
DBL-1208-M
DBL-1209-M
DBL-1210-M
DBL-2306-M
DBL-2307-M
DBL-2308-M
DBL-2309-M
DBL-2310-M
DBL-2311-M
DBL-2312-M
DBL-3513-M
DBL-3514-M
DBL-3515-M
DBL-3516-M
DBZL-4714-M
DBZL-4716-M
DBZL-4718-M
DBZL-4720-M
DBZL-4722-M
DBZL-5824-M
DBZL-5826-M
DBZL-5828-M
DBZL-5830-M
DBZL-6824-M
DBZL-6826-M
DBZL-6828-M
DBZL-6830-M
.....
DBKL-1205
DBKL-1206
DBKL-1207
DBKL-1208
DBKL-1209
DBKL-1210
DBKL-2306
DBKL-2307
DBKL-2308
DBKL-2309
DBKL-2310
DBKL-2311
DBKL-2312
DBKL-3513
DBKL-3514
DBKL-3515
DBKL-3516
DBZL-4714-K
DBZL-4716-K
DBZL-4718-K
DBZL-4720-K
DBZL-4722-K
DBZL-5824-K
DBZL-5826-K
DBZL-5828-K
DBZL-5830-K
DBZL-6824-K
DBZL-6826-K
DBZL-6828-K
DBZL-6830-K
*Maximum cord size will not pass through body without removing outer jacket.
Other grommets both single and multi-hole are available–see page 70.
DBL, FORMS 2, 3, 5
DBLZ, FORMS 7-Z, 8-Z
E†
B†
B†
F
D
C
C
D
A
A
62
FORM
SIZE
BODY
BORE–IN (MM)
2
DB-990-A
.56 (14.3)
3
DB-1190-A
.75 (19.1)
5
DB-1490-A
1.03 (26.2)
7-Z
DBZ-47-L
1.25 (31.8)
8-Z
DBZ-58-L
1.44 (36.6)
8-Z
DBZ-68-L
1.88 (47.7)
PLAIN
WASHER
GROMMET
DB-9-F
DB-9-V
DB-9-E
DB-9-J
DB-9-D
DB-9-U
DB-9-C
DB-11-V
DB-11-E
DB-11-D
DB-11-R
DB-11-K
DB-11-O
DB-11-C
DB-14K
DB-14-H
DB-14-L
DB-14-C
DBZ-714
DBZ-716
DBZ-718
DBZ-720
DBZ-722
DBZ-824
DBZ-826
DBZ-828
DBZ-830
DBZ-824
DBZ-826
DBZ-828
DBZ-830
COMPONENT PART NUMBERS
COMPRESSION
MECHANICAL
NUT
NUT
PX-8-CS
DB-9-B
PX-10
PX-11-CS
DB-11-B
PX-11
PX-14-CS
DB-14-B
PX-14
DBZ-7-B
DBZ-7-M
DBZ-8-B
DBZ-8-M
DBZ-8-B
DBZ-8-M
DBZ-716-W
DBZ-716-W
DBZ-720-W
DBZ-720-W
DBZ-723-W
DBZ-824-W
DBZ-828-W
DBZ-828-W
DBZ-831-W
DBZ-824-W
DBZ-828-W
DBZ-828-W
DBZ-831-W
WOVEN
GRIP
WOVEN GRIP
WASHER
.....
DBKG-5
DBKG-6
DBKG-8
DBKG-8
DBKG-10
DBKG-10
DBKG-6
DBKG-8
DBKG-8
DBKG-10
DBKG-10
DBKG-12
DBKG-12
DBKG-14
DBKG-14
DBKG-16
DBKG-16
DBKG-14
DBKG-16
DBKG-18
DBKG-20
DBKG-22
DBKG-26
DBKG-26
DBKG-28
DBKG-28
DBKG-26
DBKG-26
DBKG-28
DBKG-28
.....
∆
∆
∆
∆
∆
PX-8-CS
DBK-11-W
DBK-11-W
DBK-11-W
DBK-11-W
DBK-11-W
PX-11-C
PX-11-C
∆
∆
PX-14-CS
PX-14-CS
LZW-9316-16A
LZW-9316-16A
LZW-9316-20A
LZW-9316-20A
∆
∆
∆
∆
∆
∆
∆
∆
∆
WOVEN GRIP
NUT
DBK-9-B
DBK-11-B
DBK-14-B
DBZ-7-B
DBZ-8-B
DBZ-8-B
∆ Not required
DIMENSIONS
A
B†
C
D ACROSS
FLATS
E†
F MAX
E†
F
†
63
2
1.13
1.88
1.44
1.38
2.53
1.66
FORM SIZE
3
5
1.25
1.63
1.86
2.94
1.56
2.00
1.38
1.75
2.51
3.75
1.66
2.06
With nut snug, grommet not compressed.
7-Z
2.23
3.28
2.38
2.00
4.12
2.78
8-Z
2.53
3.78
2.88
2.50
4.69
3.46
U
®L
DBA GROUP
Strain relief connectors for
flexible cord and cable
LISTED
File No. E53509
CERTIFIED
File No. LR-64107
45° elbow body, male thread
Ferrous alloy body, aluminum compression nut
with washer and single hole oil-resistant grommet
Customize your installation
with our 45° DBA connectors.
Like the DBL, the steel body
and aluminum compression
nut will provide many years of
trouble free service.
CONDUIT
HUB
SIZE
PANEL
HOLE
SIZE
1
/2”
7
3
/4”
11/8”
1”
13/8”
/8”
Insulated throat option:
Add suffix “T” to all complete
assembly part numbers
on this page.
E.g.:DBKA-3513-T.
CORD
DIAMETER
RANGE IN (MM)
.125-.250 (3.17-6.35)
.187-.312 (4.75-7.92)
.250-.375 (6.35-9.52)
.312-.437 (7.92-11.1)
.375-.500 (9.52-12.7)
* .437-.562 (11.1-14.3)
*.500-.625 (12.7-15.9)
.312-.375 (7.92-9.52)
.375-.437 (9.52-11.1)
.437-.500 (11.1-12.7)
.500-.562 (12.7-14.3)
.562-.625 (14.3-15.9)
.625-.687 (15.9-17.4)
*.687-.750 (17.4-19.1)
.687-.812 (17.4-14.2)
.750-.875 (19.1-22.2)
.812-.937 (14.2-23.8)
*.875-1.000 (22.2-25.4)
COMPLETE ASSEMBLY PART NUMBERS
WITH
WITH
WITH
COMPRESSION NUT MECHANICAL NUT WOVEN GRIP
DB-745
DB-9545
DB-845
DB-9745
DB-945
DB-9945
DB-1045
DB-113845
DB-1171645
DB-111245
DB-1191645
DB-15845
DB-11111645
DB-1145
DB-141345
DB-147845
DB-14151645
DB-1445
DBA-1204-M
DBA-1205-M
DBA-1206-M
DBA-1207-M
DBA-1208-M
DBA-1209-M
DBA-1210-M
DBA-2306-M
DBA-2307
DBA-2308-M
DBA-2309-M
DBA-2310-M
DBA-2311-M
DBA-2312-M
DBA-3513-M
DBA-3514-M
DBA-3515-M
DBA-3516-M
.....
DBKA-1205
DBKA-1206
DBKA-1207
DBKA-1208
DBKA-1209
DBKA-1210
DBKA-2306
DBKA-2307
DBKA-2308
DBKA-2309
DBKA-2310
DBKA-2311
DBKA-2312
DBKA-3513
DBKA-3514
DBKA-3515
DBKA-3516
*Maximum cord size will not pass through body without removing outer jacket.
Other grommets both single and multi-hole are available–see page 70.
C
C
D†
B†
A
FORM SIZE
2
3
5
1.13 1.25 1.63
1.31 1.56 2.31
1.31 1.38 1.44
1.96 2.21 3.12
1.38 1.38 1.75
1.66 1.66 2.06
†
With nut snug, grommet not
compressed
E
F
64
DIMENSIONS
A
B†
C
D†
EACROSS
FLATS
FMAX
FORM
SIZE
BODY
BORE–IN (MM)
2
DB-945-A
.56 (14.3)
3
DB-1145-A
.75 (19.1)
5
DB-1445-A
1.03 (26.2)
GROMMET
DB-9-F
DB-9-V
DB-9-E
DB-9-J
DB-9-D
DB-9-U
DB-9-C
DB-11-V
DB-11-E
DB-11-D
DB-11-R
DB-11-K
DB-11-O
DB-11-C
DB-14-K
DB-14-H
DB-14-L
DB-14-C
PLAIN
WASHER
COMPONENT PART NUMBERS
COMPRESSION
MECHANICAL
NUT
NUT
PX-8-CS
DB-9-B
PX-10
PX-11-CS
DB-11-B
PX-11
PX-14-CS
DB-14-B
PX-14
WOVEN
GRIP
.....
DBKG-5
DBKG-6
DBKG-8
DBKG-8
DBKG-10
DBKG-10
DBKG-6
DBKG-8
DBKG-8
DBKG-10
DBKG-10
DBKG-12
DBKG-12
DBKG-14
DBKG-14
DBKG-16
DBKG-16
WOVEN GRIP
WASHER
.....
∆
∆
∆
∆
∆
PX-8-C
DBK-11-W
DBK-11-W
DBK-11-W
DBK-11-W
DBK-11-W
PX-11-CS
PX-11-CS
∆
∆
PX-14-CS
PX-14-CS
WOVEN GRIP
NUT
DBK-9-B
DBK-11-B
DBK-14-B
∆ Not required
65
U
®L
DBF GROUP
Strain-relief connectors for
flexible cord and cable
LISTED
File No. E53509
CERTIFIED
File No. LR-64107
Straight body, female thread
Aluminum body and compression nut with
single hole oil-resistant grommet
For panelboard and bulkhead
CONDUIT
HUB
installations, as well as for drop
SIZE
cords and cables from overhead
power sources. Also for mounting
to existing threaded conduit and
3
/8”
to conduit nipples.
PANEL
HOLE
SIZE
/16”
7
3
11/8”
1”
13/8”
/4”
COMPLETE ASSEMBLY PART NUMBERS
WITH
WITH
WITH
COMPRESSION NUT MECHANICAL NUT WOVEN GRIP
.125-.187 (3.17-4.75)
.187-.250 (4.75-6.35)
.250-.312 (6.35-7.92)
.312-.375 (7.92-7.52)
.375-.437 (9.52-11.1)
.125-.187 (3.17-4.75)
.187-.250 (4.75-6.35)
.250-.312 (6.35-7.92)
.312-.375 (7.92-9.52)
.375-.437 (9.52-11.1)
.125-.250 (3.17-6.35)
.187-.312 (4.75-7.92)
.250-.375 (6.35-9.52)
.312-.437 (7.92-11.1)
.375-.500 (9.52-12.7)
.437-.562 (11.1-14.3)
.500-.625 (12.7-15.9)
.125-.250 (3.17-6.35)
.187-.312 (4.75-7.92)
.250-.375 (6.35-9.52)
.312-.437 (7.92-11.1)
.375-.500 (9.52-12.7)
.437-.562 (11.1-14.3)
.500-.625 (12.7-25.4)
.625-.687 (15.9-17.4)
.687-.750 (17.4-19.1)
.687-.812 (17.4-20.6)
.750-.875 (19.1-22.2)
.812-.937 (20.6-23.8)
.875-.937 (22.2-25.4)
11
1
/2”
CORD
DIAMETER
RANGE IN (MM)
/8”
DBF--4316
DBF-414
DBF-4516
DBF-438
DBF-4
DBF-3316
DBF-314
DBF-3516
DBF-338
DBF-3
DBF-7
DBF-9516
DBF-8
DBF-9716
DBF-9
DBF-9916
DBF-10
DBF-614
DBF-6516
DBF-638
DBF-6716
DBF-612
DBF-6916
DBF-6
DBF-111116
DBF-11
DBF-1413
DBF-1478
DBF-141516
DBF-14
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
Use Form 2
Use Form 2
DBF-1204-M
DBF-1205-M
DBF-1206-M
DBF-1207-M
DBF-1208-M
DBF-1209-M
DBF-1210-M
DBF-2204-M
DBF-2205-M
DBF-2206-M
DBF-2207-M
DBF-2208-M
DBF-2209-M
DBF-2210-M
DBF-2311-M
DBF-2312-M
DBF-3513-M
DBF-3514-M
DBF-3515-M
DBF-3516-M
.....
DBKF-1205
DBKF-1206
DBKF-1207
DBKF-1208
DBKF-1209
DBKF-1210
.....
DBKF-2205
DBKF-2206
DBKF-2207
DBKF-2208
DBKF-2209
DBKF-2210
DBKF-2311
DBKF-2312
DBKF-3513
DBKF-3514
DBKF-3515
DBKF-3516
FORM SIZE
DIMENSIONS 1
E
MAX
D
A
A
B†
C†
D
E MAX
2
.88 1.13
1.53 1.84
– 2.49
– 1.38
– 1.66
3
5
1.25
2.05
2.70
1.38
1.66
1.63
2.59
3.40
1.75
2.06
†With nut snug, grommet not compressed.
C*
B*
66
FORM
SIZE
BODY
BORE–IN (MM)
1
DBF-4-A
.440 (11.2)
1
DBF-3-A
.440 (11.2)
2
DBF-9-A
.620 (15.7)
2
DBF-6-A
.620 (15.7)
3
DBA-11-A
.750 (19.1)
5
DBF-14-A
1.030 (26.2)
GROMMET
DB-4-F
DB-4-J
DB-4-D
DB-4-E
DB-4-C
DB-4-F
DB-4-J
DB-4-D
DB-4-E
DB-4-C
DB-9-F
DB-9-V
DB-9-E
DB-9-J
DB-9-D
DB-9-V
DB-9-C
DB-9-F
DB-9-V
DB-9-E
DB-9-J
DB-9-D
DB-9-V
DB-9-C
DB-11-O
DB-11-C
DB-14-K
DB-14-H
DB-14-L
DB-14-C
PLAIN
WASHER
COMPONENT PART NUMBERS
COMPRESSION MECHANICAL WOVEN
NUT
NUT
GRIP
PX-4-CS
DB-4-B
PX-4-CS
DB-4-B
PS-8-CS
DB-9-B
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
DBKG-5
DBKG-6
DBKG-8
DBKG-8
DBKG-10
DBKG-10
.....
DBKG-5
DBKG-6
DBKG-8
DBKG-8
DBKG-10
DBKG-10
DBKG-12
DBKG-12
DBKF-14
DBKG-14
DBKG-16
DBKFG-16
PX-10
PX-8-CS
DB-9-B
PX-10
PX-11-CS
DB-11-B
PX-11
PX-14-CS
DB-14-B
PX-14
WOVEN GRIP
WASHER
WOVEN GRIP
NUT
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
∆
∆
∆
∆
∆
PX-8-CS
.....
∆
∆
∆
∆
∆
PX-8-CS
PX-11-CS
PX-11-CS
∆
∆
PX-14-CS
PX-14-CS
.....
.....
.....
.....
.....
.....
.....
.....
.....
.....
*FLARED NIPPLE
HUB MAX. PANEL PART
SIZE THICKNESS NO.
Used for mounting type DBF connectors on sheet metal
boxes and cabinets, and for drop cords/cables from
overhead power distribution ducts.
3/8”
1/2”
3/4”
1”
Flared Nipple not included unless specially ordered. To
include flared nipple with assembly change catalog numbers
as follows:
1/8”
3/16”
3/16”
1/4”
DH-38
DH-1
DH-2
DH-3
• with compression nut, change DBF to DHF
• with mechanical nut, change DBF to DBH
• with weave grip, change DBKF to DBKH
DH-38
DH-1
DBK-9-B
DH-1
.....
DBK-9-B
DH-2
DBK-11-B
DH-2
DBK-14-B
DH-3
DIMENSIONS
A
B
.86 .44
1.00 .56
1.25 .80
1.50 1.00
C
D
E
F
.33
.44
.44
.56
.12
.12
.12
.19
.09
.12
.12
.16
.69
.86
1.09
1.36
E
B
F – Recommended minimum clearance
(Standard knockouts satisfactory).
A
C
67
FLARED
NIPPLE*
D
DBZP GROUP
Strain-relief panelboard and
bulkhead connector
Straight body, male thread
aluminum body and compression nut with
washer, gasket, and single hole oil-resistant grommet
These bulkhead mounting cord
connectors have an oil-resistant
rubber gasket furnished with
each body which permits
mounting from either the front or
the back of panels and
bulkheads.
CONDUIT
HUB
SIZE
13/8”*
Where 45° angle mounting is
required, choose adapters listed
on page 72.
As with the other DB Series
grips, the DBZP provides
effective strain-relief and is
liquid-tight through the
assembled unit.
17/8”*
23/8”*
27/8”*
33/8”*
Note: See page 72 for information on
Panelboard Adapters & Conduit
Fitting Boxes
CORD
DIAMETER
RANGE IN (MM)
COMPLETE ASSEMBLY PART NUMBERS
WITH
WITH
WITH
COMPRESSION NUT
MECHANICAL NUT WOVEN GRIP
.062- .125 (1.57-3.17)
.125- .250 (3.17-6.35)
.250- .375 (6.35-9.52)
.375- .500 (9.52-12.7)
.500- .625 (12.7-15.9)
.625- .750 (15.9-19.1)
.750- .875 (19.1-22.2)
.750- .875 (19.1-22.2)
.875-1.000 (22.2-25.4)
1.000-1.125 (25.4-28.6)
1.125-1.250 (28.6-31.8)
1.250-1.375 (31.8-34.9)
1.250-1.375 (31.8-34.9)
1.375-1.500 (34.9-38.1)
1.500-1.625 (38.1-41.3)
1.625-1.750 (41.3-44.5)
1.750-1.875 (44.5-47.6)
1.750-1.875 (44.5-47.6)
1.875-2.000 (47.6-50.8)
2.000-2.125 (50.8-54.0)
2.125-2.250 (54.0-57.2)
2.250-2.375 (57.2-60.3)
2.250-2.375 (57.2-60.3)
2.375-2.500 (60.3-63.5)
2.500-2.625 (63.5-66.7)
2.625-2.7500 (66.7-69.9)
2.750-2.875 (69.9-73.0)
DBZP-502
DBZP-504
DBZP-506
DBZP-508
DBZP-510
DBZP-512
DBZP-514
DBZP-714
DBZP-716
DBZP-718
DBZP-720
DBZP-722
DBZP-822
DBZP-824
DBZP-826
DBZP-828
DBZP-830
DBZP-930
DBZP-032
DBZP-934
DBZP-936
DBZP-938
DBZP-1038
DBZP-1040
DBZP-1042
DBZP-1044
DBZP-1046
.....
.....
DBZP-506-M
DBZP-508-M
DBZP-510-M
DBZP-512-M
DBZP-514-M
DBZP-714-M
DBZP-716-M
DBZP-718-M
DBZP-720-M
DBZP-722-M
DBZP-822-M
DBZP-824-M
DBZP-836-M
DBZP-828-M
DBZP-830-M
DBZP-930-M
DBZP-932-M
DBZP-934-M
DBZP-936-M
DBZP-938-M
DBZP-1038-M
DBZP-1040-M
DBZP-1042-M
DBZP-1044-M
DBZP-1046-M
.....
.....
DBZP-506-K
DBZP-508-K
DBZP-510-K
DBZP-512-K
DBZP-514-K
DBZP-714-K
DBZP-716-K
DBZP-718-K
DBZP-720-K
DBZP-722-K
DBZP-822-K
DBZP-824-K
DBZP-836-K
DBZP-828-K
DBZP-830-K
DBZP-930-K
DBZP-932-K
DBZP-934-K
DBZP-936-K
DBZP-938-K
DBZP-1038-K
DBZP-1040-K
DBZP-1042-K
DBZP-1044-K
DBZP-1046-K
* Bore hole in panelboard
1/64” larger than
dimension “E” for
back mounting.
A
FORM SIZE
B
D†
A
B
MOUNTING
HOLES
MAX MOUNTING
SCREW SIZE
D†
E
F
E
C–Diam.
3/16"
Max. panel
thickness
for rear
mounting
F
68
7-Z
2 1/ 8”
8-Z
2 5/ 8”
9-Z
3 1/ 8”
10-Z
3 3/ 4”
1 1/ 4”
1 11 / 16 ”
2 3 / 32 ”
2 17 / 32 ”
3 1 / 32 ”
3
C
A B
5-Z**
1 8/ 8”
ACROSS
FLATS
/ 16 ”
7
#8
#10
2 15 / 16 ”
2 15 / 32 ”
2 15 / 32 ”
2 15 / 32 ”
2 15 / 32 ”
1 3/ 8”
1 7/ 8”
2 3/ 8”
2 7/ 8”
3 3/ 8”
21
1 / 32 ”
/ 32 ”
1
2 / 32 ”
9
/ 32 ”
1
/4
17
2 / 32 ”
† With nut snug, buit grommet not compressed.
**No adapter avaliable for from size 5-Z
11
5
/ 32 ”
/ 16
1
3 / 32 ”
11
5
/ 32 ”
/ 16
3 19 / 32 ”
FORM
SIZE
BODY
BORE–IN (MM)
5-Z
DBZ-5-P
.937 (23.8)
7-Z
DBZ-7-P
1.437 (36.5)
8-Z
DBZ-8-P
1.937 (49.2)
9-Z
DBZ-9-P
2.437 (61.9)
10-Z
DBZP-10-P
2.875 (73.0)
GROMMET
DBZ-502
DBZ-504
DBZ-506
DBZ-508
DBZ-510
DBZ-512
DBZ-514
DBZ-714
DBZ-716
DBZ-718
DBZ-720
DBZ-722
DBZ-822
DBZ-824
DBZ-826
DBZ-828
DBZ-830
DBZ-930
DBZ-932
DBZ-934
DBZ-936
DBZ-938
DBZ-1038
DBZ-1040
DBZ-1042
DBZ-1044
DBZ-1046
PLAIN
WASHER
DBZ-504-W
DBZ-504-W
DBZ-508-W
DBZ-508-W
DBZ-512-W
DBZ-512-W
DBZ-515-W
DBZ-716-W
DBZ-716-W
DBZ-720-W
DBZ-720-W
DBZ-723-W
DBZ-824-W
DBZ-824-W
DBZ-828-W
DBZ-828-W
DBZ-831-W
DBZ-932-W
DBZ-932-W
DBZ-936-W
DBZ-936-W
DBZ-939-W
DBZP-1040-W
DBZP-1040-W
DBZP-1044-W
DBZ-1044-W
DBZ-1046-W
COMPONENT PART NUMBERS
COMPRESSION
MECHANICAL
NUT
NUT
.....
.....
DBZ-5-B
DBZ-5-M
DBZ-7-M
DBZ-7-M
DBZ-8-B
DBZ-8-M
DBZ-9-B
DBZ-9-M
DBZ-10-B
DBZ-10-M
WOVEN
GRIP
.....
.....
DBKG-6
DBKG-8
DBKG-10
DBKG-12
DBKG-14-Z
DBKG-14
DBKG-16
DBKG-18
DBKG-20
DBKG-22
DBKG-22
DBKG-26
DBKG-26
DBKG-28
DBKG-28
DBKG-28
DBKG-34
DBKG-34
DBKG-38
DBKG-38
DBKG-38
DBKG-40-Z
DBKG-46-Z
DBKG-46-Z
DBKG-46-Z
WOVEN GRIP
WASHER
.....
.....
LZW-9312-10A
LZW-9312-10A
LZW-9312-12A
LZW-9312-12A
∆
LZW-9316-16A
LZW-9316-16A
LZW-9316-20A
LZW-9316-20A
∆
LZW-9320-22A
∆
∆
∆
∆
LZW-9324-28A
∆
∆
∆
∆
LZW-9328-38A
∆
∆
∆
∆
∆ Not required
69
WOVEN GRIP
NUT
.....
.....
DBZ-5-B
DBZ-7-B
DBZ-8-B
DBZ-9-B
DBZ-10-B
GROMMETS
U
®L
LISTED
for DB/DBZ series connectors
CERTIFIED
Molded oil-resistant synthetic rubber
These tapered grommets fit in the
tapered bodies of all appropriate
DB Series metallic connectors.
They provide strain-relief by
gripping the cord jacket inside the
grommet, and efficiently seal out
water and oil from internal
connections.
CABLE
RANGE (inches)
BLANK
.062-.125
.125-.187
.125-.250
.187-.250
.187-.312
.250-.312
.250-.375
Amphenol®/Pyle® rubber grommets .312-.375
are specially compounded and
.312-.437
.375-.437
molded to resist age-hardening,
adding many more years to the life
.375-.500
of installations.
.437-.500
.437-.562
.500-.562
.500-.625
.562-.625
.562-.687
.625-.687
.625-.750
.687-.750
.687-.812
.750-.875
.812-.937
.875-.937
.875-1.000
1.000-1.125
1.125-1.250
1.250-1.375
1.375-1.437
1.375-1.500
1.500-1.625
1.625-1.750
1.750-1.875
1.875-1.937
1.875-2.000
2.000-2.125
2.125-2.250
2.250-2.375
2.375-2.437
2.375-2.500
2.500-2.625
2.625-2.750
2.750-2.875
FORM1
FORM2
FORM 3
DB-4-Z
DB-9-Z
DB-11-Z
FORM 5
FORM 5Z
FORM 7Z
FORM 8Z
FORM 9Z
FORM 10Z
DBZ-502
DB-4-F
DB-9-F
DBZ-504
DB-4-J
DB-9-V
DB-4-D
DB-11-X
DB-9-E
DB-4-E
DBZ-506
DBZ-706
DBZ-508
DBZ-708
DBZ-510
DBZ-710 DBZ-810
DB-14-J
DBZ-512
DBZ-712 DBZ-812
DB-14-K
DB-14-H
DB-14-L
DBZ-514
DBZ-714 DBZ-814
DB-11-4
DB-9-J
DB-4-C
DB-14-N
DB-11-E
DB-9-D
DB-11-D
DB-9-U
DB-14-M
DB-11-R
DB-9-C
DB-11-K
DB-14-E
DB-11-O
DB-11-C
DBZ-515
DB-14-C
DBZ-716
DBZ-718
DBZ-720
DBZ-722
DBZ-723
DBZ-816
DBZ-818
DBZ-820
DBZ-822
DBZ-916
DBZ-918
DBZ-920
DBZ-922
DBZ-824
DBZ-826
DBZ-828
DBZ-830
DBZ-831
DBZ-924
DBZ-926
DBZ-928
DBZ-930
DBZ-932
DBZ-934
DBZ-936
DBZ-938
DBZ-939 DBZ-1038
DBZ-1040
DBZ-1042
DBZ-1044
DBZ-1046
70
Multi-hole grommets
C
BODY AND
COMPRESSION
NUT USED
Form 1
B
A
2
Hole
Form 2
3
Hole
Form 5
Form 2
Form 3
A
NOMINAL SIZE
PART NO. CORD OR CABLE
DB-4-H
.170
DB-9-MA
.100
DB-9-X
.125
DB-9-XA
.156
DB-9-H
.250
DB-9-O
.281
DB-14-D
.437
DB-9-L
.218
DB-11-M
.281
B
C
/32 3/8
15
/16 5/8
15
/16 5/8
15
/16 5/8
15
/16 5/8
15
/16 5/8
9
1 /32 11/32
15
/16 5/8
1
1 /32 23/32
21
Cord protecting sleeve/grommet
BODY AND
COMPRESSION
NUT USED
Form 2
71
PART NO.
DBY-9-J
A
NOMINAL SIZE
CORD OR CABLE
.312 to .437
C
B OVERALL
O.D. LENGTH
15
/16
3
ACCESSORIES
Panelboard adapters
Aluminum construction. Accepts DBZP panelboard FORM
SIZE
connectors
7-Z
All adapter covers come complete with screws and
8-Z
clips for mounting the connector, plus bolts,
washers, and gasket for attaching cover to panel or 9-Z
conduit fitting box.
10-Z
PART NUMBER
DIMENSIONS
A
B
C
D
E
F
ZP-C-2516-12
3
4 /16”
3
4 /16”
9
3 /16”
9
15
3 /16”
2 /16”
1
ZP-C-2520-12
41 / 2 ”
41 / 2 ”
37 / 8 ”
37 / 8 ”
339/64”
1
33
11
/4-20 x /4”
1 /16”
/4-20 x 3/4”
ZP-C-2524-12
8”
8”
7”
7”
3 /64”
1
ZP-C-2528-12
8”
8”
7”
7”
35/8”
1
A
C
G
3
23/32”
3
217/32”
/2-13 x /4”
/2-13 x 3/4”
31/32”
E
F
B D
G
1/16" GASKET
Conduit fitting boxes
A
Ferrous alloy construction
Conduit fitting box to fit adapters.
Mounting hardware is not included.
Thru-feed styles available upon
request.
E
C
F
G
A
E
C
F
G
8" H
B D
B D
H
Form sizes 7-Z & 8-Z
Form sizes 9-Z & 10-Z
FORM
SIZE
7-Z
8-Z
9-Z
CONDUIT
HUB
SIZE
3
/ 4”
1”
11/4”
11/2”
11/4”
11/2”
2”
21/2”
3”
PART
NUMBER
P-202760-42
P-202760-43
P-202760-64
P-202760-65
JRZ-610064
JRZ-610065
JRZ-610066
JR-720036-A
JRZ-820036-A
72
DIMENSIONS
A
B
C
D
E
F
G
H
9
/32”
DIA.
39/16”
9
37/8”
13
/16”
13
/16”
1”
1”
51/4”
51/4”
45/8”
45/8”
23/8”
6”
6”
51/4”
51/4”
33/4”
17/16”
8”
103/4”
63/4”
91/2”
33/4”
41/2”
17/8”
21/8”
/32”
DIA.
7
/16”
DIA.
7”
Cord Grip handles
For use with Star-Line® and other
electrical devices that are tapped for
conduit and use flexible cord or cable.
TYPE PH D-HANDLE
A
These handles not only fit electrical
connectors, but will also work well on heavy
duty portable equipment.
Both D and T handles are made of cast
aluminum and come complete with a locknut
on male thread “A.” Hub “B” accepts type DB
cord grips with male thread (not included)
Serves also as a convenient means for
hanging your plugs, receptacles or portable
equipment.
PART
NUMBER
PH-2
PH-3
PH-5
“A” MALE
THREAD
¾”
1”
1½”
“B”FEMALE
THREAD
¾”
1”
1½”
PHA-22
PHA-33
¾”
1”
¾
1”
B
TYPE PHA T-HANDLE
A
B
73
Amphenol Industrial Operations
Additional Amphenol® / Pyle® Industrial Products
Amphenol is one of the largest manufacturers of interconnect solutions worldwide. Amphenol’s broad offering of
products are highly suitable for industrial applications where cable glands and cord grip products are used. Several of
the Amphenol Heavy Duyy Connectors are shown here and on the next page.
For more information, please see relevant literature or Amphenol’s Website: www.amphenol-industrial.com
Star-Line® Heavy Duty
Connectors
Amphenol/Pyle Star-Line connectors are heavy duty
environmental solutions for high amperage and high density
control and instrumentation applications. They are designed
to perform up to amperages of 1135 amps at 1000/VAC or
VDC rating. Other features include:
• Exceeds MIL-5015 E and R specifications
• UL listed and CSA listed
• Double lead Acme threads provide complete coupling in
one turn of the coupling nut and do not clog under
adverse weather conditions
• Large wiring space provided in cable housing and conduit
fitting bodies.
• Operating temperatures from -67°F to +257°F
• IP67 rated for environmental sealing.
• Hard anodic coating provides dielectric strength with heat
and corrosion resistance.
• 5 Shell styles with over 150 insert patterns available.
• Solder, crimp and pressure terminals available. Circuit
breaking power and control types.
• Variety of backend accessories including basketweave
cable grips, straight or angled adapters and receptacle
mounted to junction boxes.
Typical markets include mass transportation, automotive
tooling, power generation, and petrochemical. For more
information ask for catalog 12-054.
Star-Line EX® Connectors for
Harsh/Explosive Environments
Amphenol/Pyle Star-Line EX connectors are a hybrid form of
the Star-Line series with higher temperature ranges. This
family shares features of the Star-Line with additional
features that include:
• Ceneluc Certified for use in Zone 1-IIc locations.
• EX Certified to ATEX certification #03ATEX 1101X
• Can be terminated onto unarmored or armored and
sheathed cables built to several popular standards.
• Custom cable assemblies are available
Typical markets include mass transportation,
pharmaceutical, manufacturing, power generation, and
petrochemical. For more information, ask for catalog 12-054.
74
Amphenol Industrial Operations
Additional Amphenol® / Pyle® Industrial Products
Amphenol offers RADSOK® contact technology for several industrial connectors. The RADSOK contact is designed
for high amperage applications.
Star-Line® and MIL-5015
Connectors with RADSOK®
Connectors enhanced with RADSOK high amperage
contacts can handle up to 150% higher amperages than
connectors with standard contacts. These are called AmphePower™ Connectors and are currently offered in three
popular industrial connector families:
• 5015 AC Series
• GT Reverse Bayonet
• Pyle P-Lok Series
Also, the Star-Line Series has inserts available with special
RADSOK contacts, and the Neptune® Series is offered
exclusively with RADSOK contacts.
The RADSOK patented contact has a hyperbolic, stamped
grid configuration within the socket cylinder. As a male pin is
inserted, axial members in the female socket deflect,
enabling high current flow across the connection with
minimal voltage loss.
Typical markets: power generation, petrochemical, and mass
transportation. For more information on RADSOK high
amperage contacts, ask for Brochure SL-391,
Amphe-Power™ Connectors with RADSOK Technology.
Amphenol Neptune® Connectors
with RADSOK®
The Neptune® Series is a new power connector family
featuring the RADSOK contact system. Feature include:
•
•
•
•
•
•
•
Machined aluminum components
IP 68-8 rated through SIRA
Operating temperature rated to -67°F to +225°F
Three key design to limit cross mating.
Anodic hardcoat plating.
Double lead acme threads for easy coupling.
Decreased weight and panel layout in comparison to the
competition.
• Contacts are nickel silver alloy plated and they are
designed for longer life/mating cycles.
The Neptune is offered exclusively with RADSOK contact
technology. Currently inserts are available with 30 Amp
through 400 Amp/480 volts.
Typical Markets include oil exploration equipment,
convention center power distribution, geophysical trucks,
portable power distribution equipment, and communication
shelters. For more information on the Neptune Series of
connectors ask for Product Data Sheet 192.
75
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
