Making Video Connections
KLV-23M1
Best Video
Performance
Quick Setup Guide
The remote control is preset to operate Sony brand video equipment.
Connector type
HDMI
(High-Definition Multimedia Interface)
Component video
Composite video
zzzzzzzz
2
zzzzzzzz
3
zzzzzzzz
Programmable Code Number
DVD/VCR
601 (Sony Dream System)
SAT/Cable
801 (Sony Satellite Receiver)
Note
RF/Coaxial
4
Sony Equipment
If you have video equipment other than Sony brand that you want to
control with the TV’s remote control, use the following procedures to
program the remote control.
S VIDEO
Please follow the steps to setup your TV:
1
4 Programming the
Remote Control
Your TV includes several types of video inputs. Use the inputs that
are available on your components that provide the best video
performance, as described below.
The equipment must have infrared (IR) remote capability in order to be used with this
remote control.
Using the code list below, find the three-digit code number for the
manufacturer of your equipment. (If more than one code number is
listed, use the number listed first.)
Additional Connections
Checking the
Supplied Accessories
Connecting Your TV
(See reverse side)
Running Initial
Setup
Programming
the Remote Control
5
For best audio performance, connect your digital audio components
using either digital optical or digital coaxial audio connections.
Depending on which components are in your system, you may need
to complete additional connections. For example, if you have a
satellite receiver, you’ll need to connect the satellite antenna. If you
have an AV receiver, you’ll need to connect speakers.
DVD/
MUTING VCR
buttons simultaneously, or press the SAT/CABLE
(FUNCTION) and RESET buttons simultaneously.
DVD/VCR and SAT/CABLE buttons flash.
SAT/ POWER
CABLE
MODE
PICTURE WIDE SLEEP DISPLAY
3
• The connection diagrams shown in the reverse side are recommendations only; other
possible solutions may exist. Connections that include an AV receiver can often be very
complex, so check your AV receiver’s instruction manual for additional details.
• The ferrite core is attached to one end of (not the center of) the cable. When connecting the
cable to the TV, insert the end with the ferrite core into the VHF/UHF jack.
2 Press the function button you want to program.
To program video equipment
Press DVD/VCR (FUNCTION).
4
TOP MENU FAVORITES
MENU
Notes
If your product is not working properly
DO NOT RETURN TO THE STORE.
For service and technical assistance
Call our Customer Information Service Center (Toll Free):
1-800-222-SONY (7669) for US residents.
1-877-899-SONY (7669) for Canadian residents.
1 Press the DVD/VCR (FUNCTION) and RESET
F1
F2
TV
1, 2
VIDEO 1/2 VIDEO 3 VIDEO 4
4 Press ENT (enter).
5 To check if the code number works, aim the TV’s
RESET FREEZE MTS/SAP
GUIDE
To program a cable box or a satellite receiver
Press SAT/CABLE (FUNCTION).
3 Enter the three-digit manufacturer’s code number
using the 0-9 buttons.
TV/SAT
remote control at the equipment and press DVD/
VCR and/or SAT/CABLE (POWER) that corresponds with that equipment. If it responds, the
programming is completed. If not, try using the
other codes listed for that manufacturer.
1
Sony Corporation © 2004 Printed in Japan
1 Checking the
Supplied Accessories
Remote control (RM-Y1109) (1)
and size AA batteries (2)
2 Connecting Your TV
3 Running Initial Setup
• Review the following chart to determine which diagram to use to
connect the components in your system:
75-ohm coaxial cable (1)
or
Note
or
See reverse
side
A
B
AC power cord (1)
or
• Operating Instructions (1)
• Quick Setup Guide (1)
• Warranty Card (1)
or
Inserting Batteries into the Remote Control
Insert two size AA batteries (supplied) by matching the e and E on
the batteries to the diagram inside the remote control’s battery
compartment.
• If more than one code number is listed, try entering them one by
one until you come to the correct code for your equipment.
• If you enter a new code number, the code number you
previously entered at that setting is erased.
Manufacturer’s Codes
For these components
Do not detach the ferrite core from the cable.
Tips
C
D
E
F
• See the “Cables Required” chart that appears with the diagram to
determine which cables you’ll need. You may need to purchase
extra accessories, such as cables and splitters, depending on the
components you plan to connect.
• Turn off and unplug all components before making connections.
• If you are connecting a digital cable box, you’ll need a special bidirectional splitter that’s compatible with your cable box. Contact
your cable provider for details.
1
2
DVD Players
Press 1 (Power) on the TV.
The Auto Setup menu automatically appears on the screen when
you turn on the TV for the first time.
Press CH+ on the remote control or on the control panel of your
TV to perform Auto Program.
To open the control door of your TV, push the door just under the
“V OPEN” mark.
When all the receivable channels are stored, the “Channel Skip/
Add” menu appears.
Auto Program is set to scan cable TV channels by default. To watch
VHF/UHF channels with an antenna, see “To watch VHF/UHF
channels with an antenna” in the operating instructions.
If you need to perform Auto Program again
1 Press MENU.
2 Press V/v to select
(Channel), then press
3 Press V/v to select “Auto Program,” then press
4 Press
.
.
.
“Auto Program” appears and the TV starts scanning and
presetting channels automatically. When all the receivable
channels are stored, the “Channel Skip/Add” menu appears.
Using this menu, you can start skipping unnecessary channels
(see “To skip channels” in the operating instructions).
5 Press MENU to exit the menu screen.
