Owner’s Record
The model and serial numbers are located at the rear of the
projection TV, below the Sony logo, on the sticker, and also on the
TV box (white label). Record these numbers in the spaces provided
below. Refer to them whenever you call upon your Sony dealer
regarding this product.
Model No.
Serial No.
WARNING
To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
How to Reduce the Risk of "Image Retention"
on the Screen
Please take the following steps to reduce the risk of causing
image retention:
· When using video games, computers, and similar products
with your projection TV, or viewing a TV station whose
logo always stays on the screen, keep the Brightness and
Picture functions at low settings. (See page 62 for
instructions on adjusting Brightness and Picture settings.)
· View a variety of programming material. Changing the
program material viewed reduces the possibility that a
single image will become imprinted on the screens.
· This TV was designed primarily for viewing TV broadcasts
in wide screen mode (16:9 aspect ratio). Therefore when
viewing conventional (4:3) aspect ratio TV programs,
select Wide Mode settings that fill the image on your
screen. This will reduce the possibility of the gray sidebars
becoming permanently imprinted.
Please see page 62 for instructions on adjusting picture
settings. See pages 53-54 for information about using Wide
Mode.
IMAGE RETENTION IS NOT COVERED BY YOUR WARRANTY
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
As an ENERGY STAR® Partner, Sony has
determined that this product or product models
meets the ENERGY STAR guidelines for energy
efficiency. ENERGY STAR is a U.S. registered mark.
This symbol is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
Do not expose the TV to dripping or splashing. Avoid placing
liquid-filled objects, such as vases, on top of the TV.
CAUTION
To prevent electric shock, do not use this polarized AC plug with
an extension cord, receptacle or other outlet unless the blades can
be fully inserted to prevent blade exposure.
CAUTION
If a fixed (non-moving) pattern, such as a station logo, is
left on the screen for long periods of time, especially at a
high brightness or picture setting, the image can be
permanently imprinted onto the screen. These types of
imprints are known as “image retention.”
1
AX1X.book Page 2 Wednesday, June 30, 2004 9:21 AM
Note on Caption Vision
❑
This television receiver provides display of television closed
captioning in accordance with §15.119 of the FCC rules.
Note on Convergence Adjustment
Before you use your projection TV, make sure to adjust
convergence. For details, see “Adjusting the Convergence
Automatically (Flash Focus)” on page 40.
Use of this television receiver for other than private viewing of
programs broadcast on UHF or VHF or transmitted by cable
companies for the use of the general public may require
authorization from the broadcaster/cable company and/or
program owner.
NOTIFICATION
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference with radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
❑
❑
❑
❑
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority to
operate this equipment.
Safety
❑ Operate the projection TV only on 120 V AC.
❑ The plug is designed, for safety purposes, to fit into the wall
❑
❑
❑
outlet only one way. If you are unable to insert the plug fully
into the outlet, contact your dealer.
If any liquid or solid object should fall inside the cabinet,
unplug the projection TV immediately and have it checked
by qualified service personnel before operating it further.
If you will not be using the projection TV for several days,
disconnect the power by pulling the plug itself. Never pull on
the cord.
For details concerning safety precautions, see “Important
Safety Instructions” on page 3.
Installing
❑ To prevent internal heat buildup, do not block the ventilation
❑
❑
❑
2
openings.
Do not install the projection TV in a hot or humid place, or in
a place subject to excessive dust or mechanical vibration.
Avoid operating the projection TV at temperatures below 5°C
(41°F).
If the projection TV is transported directly from a cold to a
warm location, or if the room temperature changes suddenly,
the picture may be blurred or show poor color due to
moisture condensation. In this case, please wait a few hours
to let the moisture evaporate before turning on the projection
TV.
To obtain the best picture, do not expose the screen to direct
illumination or direct sunlight. It is recommended to use spot
lighting directed down from the ceiling or to cover the
windows that face the screen with opaque drapery. It is
desirable to install the projection TV in a room where the
floor and walls are not of a reflective material.
Trademark Information
TruSurround, SRS and the
symbol are trademarks of SRS
Labs, Inc. TruSurround technology is incorporated under license
from SRS Labs, Inc.
Licensed by BBE Sound, Inc. under USP4638258, 4482866. “BBE”
and BBE symbol are trademarks of BBE Sound, Inc.
This TV incorporates High-Definition
Multimedia Interface (HDMI™)
technology. HDMI, the HDMI logo and
High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
Steady Sound, Digital Reality Creation, CineMotion, and Twin
View are registered trademarks of Sony Corporation. ClearEdge
VM, and HD Detailer are trademarks of Sony Corporation.
For Safety
Be careful when moving the projection TV
When you place the projection TV in
position, be careful not to drop it on your
foot or fingers.
Watch your footing while installing the
projection TV.
Carry the projection TV in the specified manner
If you carry the projection TV in a manner other than the specified
manner and without the specified number of persons, it may drop
and a serious injury may be caused. Be sure to follow the
instructions mentioned below.
❑
❑
❑
Carry the projection TV with the specified number of persons
(see “Carrying Your Projection TV” on page 10).
Do not carry the projection TV holding the speaker grill.
Hold the projection TV tightly when carrying it.
AX1X.book Page 3 Wednesday, June 30, 2004 9:21 AM
Important Safety Instructions
1
2
3
4
5
6
7
Read these instructions.
Additional Cleaning Instructions
Keep these instructions.
Clean the cabinet of the projection TV with a dry, soft cloth. To
clean the screen of your projection TV, please use only a clean, soft
cloth lightly dampened with water. Stubborn stains such as
fingerprints can be removed with a clean, soft cloth lightly
dampened with a solution of mild soap and warm water. Never
use alcohol or strong solvents (such as thinner, benzene, ammonia,
or alcohol-based), or abrasive cleaning solutions to clean your TV
screen.
8
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10
Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11
Only use attachments/accessories specified by the
manufacturer.
12
Use only with the cart,
stand, tripod, bracket, or
table specified by the
manufacturer, or sold with
the apparatus. When a cart
is used, use caution when
moving the cart/apparatus
combination to avoid injury
from tip-over.
13
Unplug this apparatus during lightning storms or
when unused for long periods of time.
14
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
If the picture becomes dark after using the projection TV for a long
period of time, it may be necessary to clean the inside of the
projection TV. Consult qualified service personnel.
3
AX1X.book Page 4 Wednesday, June 30, 2004 9:21 AM
AX1X.book Page 5 Wednesday, June 30, 2004 9:21 AM
Contents
Introducing the Projection TV
Welcome ........................................................................................................ 7
Package Contents.............................................................................. 7
Features ............................................................................................ 7
Setting Up the Projection TV
Overview .......................................................................................................9
Carrying Your Projection TV.......................................................................10
Positioning the TV.......................................................................................10
TV Controls and Connectors.......................................................................11
Front Video Inputs ...........................................................................11
Front Panel ......................................................................................12
Rear Panel .......................................................................................12
Basic Connections: Connecting a Cable or Antenna.................................14
Cable or Antenna Only ....................................................................15
Cable and Antenna Only .................................................................16
Cable Box and Cable Only ...............................................................18
Cable Box Only................................................................................20
Connecting Optional Equipment ...............................................................21
Making Video Connections..............................................................22
About Using S VIDEO ......................................................................23
VCR and Cable ................................................................................24
VCR and Cable Box .........................................................................26
Satellite Receiver..............................................................................28
Satellite Receiver and VCR ...............................................................30
DVD Player with Component Video Connectors...............................32
DVD Player with S VIDEO and Audio Connectors .............................33
Camcorder ......................................................................................34
Audio Receiver ................................................................................35
DVI-Equipped Device .......................................................................36
HDMI-Equipped Device ....................................................................37
Using the CONTROL S Feature ...................................................................38
Setting Up the Channel List .......................................................................39
Using Auto Program ........................................................................39
Adjusting the Convergence Automatically (Flash Focus).........................40
Notes on Flash Focus .......................................................................40
Adjusting the Convergence Manually .......................................................41
Notes on Adjusting the Convergence Manually................................42
5
AX1X.book Page 6 Wednesday, June 30, 2004 9:21 AM
Using the Remote Control
Using the Features
Overview .....................................................................................................51
Watching TV ................................................................................................52
Using Wide Mode .......................................................................................53
Using Wide Mode with Standard Definition (480i/480p) Sources......53
Using Wide Mode with High-Definition (720p/1080i) Sources ..........54
Using Twin View .........................................................................................55
Displaying Twin Pictures ..................................................................55
Factors Affecting Twin View ............................................................55
Activating the Picture ......................................................................56
Changing the Picture Size ................................................................57
Using Favorite Channels .............................................................................58
Creating a List of Favorite Channels .................................................58
Displaying a List of Favorite Channels ..............................................58
Using the Freeze Function ..........................................................................59
Using the Menus
Overview .....................................................................................................61
Navigating Through Menus .......................................................................61
Using the Video Menu ................................................................................62
Using the Audio Menu ...............................................................................64
Using the Screen Menu ..............................................................................66
Using the Channel Menu ............................................................................67
Using the Parent Menu...............................................................................69
Using the Setup Menu ................................................................................72
Other Information
Overview .....................................................................................................75
Glossary .......................................................................................................76
Contacting Sony ..........................................................................................77
Troubleshooting..........................................................................................77
Specifications ..............................................................................................81
Optional Accessories...................................................................................82
Index ............................................................................................................83
Other Info
SETUP
SETUP
SETUP
SETUP
Welcome
Overview .....................................................................................................43
Inserting Batteries.......................................................................................43
Button Descriptions ....................................................................................44
Programming the Remote Control ............................................................46
Using Other Equipment with Your TV Remote Control ...........................48
All Equipment..................................................................................48
Operating a VCR .............................................................................48
Operating a Satellite Receiver ..........................................................48
Operating a Cable Box.....................................................................49
Operating a DVD Player ...................................................................49
Using the F1 and F2 Buttons............................................................49
6
AX1X.book Page 7 Wednesday, June 30, 2004 9:21 AM
Introducing the Projection TV
Welcome
This chapter describes the contents of the package in which the TV is
shipped and provides an overview of the features of your projection
TV.
Package Contents
Along with your new projection TV, the package contains a remote
control and two AA batteries. No additional cables are included.
These items are all you need to set up and operate the projection TV
in its basic configuration.
Most components (VCRs, DVD players, etc.) come with the necessary
cables to connect them. If you want to set up a complex system, you
may need to buy extra cables, connectors, etc. Be sure to have these
on hand before you start to connect your system.
Features
Some of the features that you will enjoy with your new TV include:
❑
❑
Wide Screen Mode: Watch conventional 4:3 aspect ratio
broadcasts in wide screen (16:9) mode.
DRC® (Digital Reality Creation) Multifunction: Unlike
conventional line doublers, the DRC Multifunction feature
replaces the signal’s NTSC waveform with the HD equivalent,
while doubling the number of vertical and horizontal lines. This
results in four times the density for quality sources, such as DVD,
satellite, and digital camcorders. The Video Menu allows you to
select interlaced, progressive, or CineMotion™ output.
❑
Favorite Channels: Allows you to preview and select from 16 of
your favorite channels.
❑
Twin View™: Using the Multi-Image Driver (MIDX), Twin View
allows you to watch two programs side by side, with the ability
to zoom in one picture. You can watch pictures from two
different sources (1080i, 720p, 480p, and 480i) simultaneously.
(Only the left Twin View window can display 1080i, 720p, and
480p sources.)
❑
ClearEdge VM™ Velocity Modulation: Sharpens picture
definition by enhancing vertical lines.
❑
Steady Sound®: Equalizes volume levels so there is consistent
output between programs and commercials.
7
❑
Component Video Inputs: Offers high quality video for DVD
(480p, 480i), and digital set-top box (HD1080i, 720p) connections.
❑
HD Detailer™: Wideband video amplifier has a high bandwidth
frequency rating, which allows it to send more video information
to the screen, resulting in finer picture quality, especially for HD
sources.
❑
CineMotion™: Reverse 3-2 pulldown processing provides
optimal picture quality for film-based sources (media originally
shot in 24 frames-per-second format).
❑
Parental Control: V-Chip technology allows parents to block
unsuitable programming from younger viewers.
❑
HDMI (High-Definition Multimedia Interface): Provides an
uncompressed, all-digital audio/video interface between this TV
and any HDMI-equipped audio/video component, such as a settop box, DVD player, and A/V receiver. HDMI supports
enhanced, or high-definition video, plus two-channel digital
audio.
8
Introducing
SETUP
SETUP
SETUP
SETUP
SETUP
Welcome
AX1X.book Page 8 Wednesday, June 30, 2004 9:21 AM
AX1X.book Page 9 Wednesday, June 30, 2004 9:21 AM
Setting Up the Projection TV
Overview
This chapter includes illustrated instructions for setting up your TV.
Topic
Page(s)
Carrying Your Projection TV/Positioning the TV
10
TV Controls and Connectors
11-13
Basic Connections: Connecting a Cable or Antenna
14-20
Connecting Optional Equipment
VCR and Cable
VCR and Cable Box
Satellite Receiver
Satellite Receiver and VCR
DVD Player with Component Video Connectors
DVD Player with S VIDEO and Audio Connectors
Camcorder
Audio Receiver
DVI-Equipped Device
HDMI-Equipped Device
Using the CONTROL S Feature
24
26
28
30
32
33
34
35
36
37
38
Setting Up the Channel List
39
Adjusting the Convergence Automatically (Flash Focus)
40
Adjusting the Convergence Manually (Manual Convergence)
41
9
AX1X.book Page 10 Wednesday, June 30, 2004 9:21 AM
Carrying Your Projection TV
SETUP
Carrying the TV requires four or more people.
Models KP-51/57WS520 provide casters. Be sure to move your
projection TV using these casters.
Positioning the TV
Setup
min
. 2.4
m(
ap
57" prox. 8
min
ft.)
. 2.1
m(
app
min
rox
5
1
. 1.8
.7f
"
t.)
m(
ap
46" prox. 6
ft.)
mi
n.
mi
2.4
n.
m
2.1
(ap
mi
m
n.
(ap 57 prox
1.8
"
.8
m 51" prox
ft.
.7
)
46 (app
f
"
t.)
ro
60˚
x.
6f
t.)
SETUP
20˚
POWER
+
— CHANNEL
+
— VOLUME
TV/VIDEO
FLASH
PRO
STD/DUO
FOCUS
TIMER
STAND
BY
20˚
60˚
POWER
+
TIMER
STAND
BY
— CHANNEL
+
— VOLUME
TV/VIDEO
FLASH
FOCUS
PRO
STD/DUO
SETUP
SETUP
SETUP
Recommended Vertical Viewing Angle
10
Recommended Horizontal Viewing Angle
AX1X.book Page 11 Wednesday, June 30, 2004 9:21 AM
TV Controls and Connectors
Models KP-51/57WS520 provide video inputs (Video 2) on the front.
To access, push up and release as shown.
SETUP
Model KP-46WT520 provides video inputs (Video 2) on the side. To
access, push in and release as shown.
KP-51/57WS520
KP-46WT520
Setup
POWER
+
TIMER
STAND
BY
POWER
— CHANNEL
+
+
TIMER
STAND
BY
— CHANNEL
— VOLUME
+
TV/VIDEO
FLASH
— VOLUME
FOCUS
TV/VIDEO
PRO
FLASH
STD/DUO
FOCUS
PRO
STD/DUO
SETUP
SETUP
Front Video Inputs
VIDEO 2 IN
S VIDEO
1
VIDEO
1
2
L (MONO)
2
SETUP
AUDIO
R
S VIDEO
VIDEO
L (MONO)
R
AUDIO
VIDEO 2 IN
KP-46WT520
KP-51/57WS520
Connects to the S VIDEO OUT jack on your
camcorder or other video equipment that has S
VIDEO. Provides better picture quality than
composite video (2).
2 VIDEO/L(MONO)AUDIO-R
VIDEO 2 INPUT
Connects to the composite A/V output jacks on your
camcorder or other video equipment.
11
SETUP
1 S VIDEO
VIDEO 2 INPUT
AX1X.book Page 12 Wednesday, June 30, 2004 9:21 AM
SETUP
Setup
SETUP
Front Panel
1
2
FLASH FOCUS
TV/VIDEO
3
— VOLUME
4
+
— CHANNEL
+
5
6
7
TIMER
STAND BY
POWER
8
Item
Description
1 FLASH FOCUS
Press to adjust the convergence (see page 40).
2 TV/VIDEO
Press repeatedly to cycle through the video equipment connected to the TV’s
video inputs.
3 -VOLUME +
Press to adjust the volume.
4 -CHANNEL+
Press to scan through channels. To scan quickly through channels, press and
hold down either CHANNEL button.
5 TIMER LED
When lit, indicates one of the timers is set. When the timer is set, this LED will
remain lit even if the TV is turned off. For details, see page 73.
6 STAND BY LED
Blinks when the TV is turned on, then shuts off when the picture is displayed.
If the LED blinks continuously, this may indicate the TV needs service (see
“Contacting Sony” on page 77).
7 POWER
Press to turn on and off the TV.
8 Infrared Receiver (IR)
Receives IR signals from the TV’s remote control.
SETUP
Rear Panel
1
SETUP
2
9
3
4
SETUP
5
6
12
7 8
AX1X.book Page 13 Wednesday, June 30, 2004 9:21 AM
1 AUX
Auxiliary RF input that connects to your antenna, CATV cable, or cable box output
jack. This is convenient if you are using two VHF/UHF sources (antenna, CATV
cable, or cable box). For details, see pages 16 to 19.
2 TO CONVERTER
Connects to your cable box input jack. This VHF/UHF output jack lets you set up
your TV to switch between scrambled channels (coming through a cable box) and
unscrambled cable channels. Use this jack instead of a splitter to get better picture
quality when you need to switch between scrambled and unscrambled cable
channels. For details, see pages 18 to 19.
3 S VIDEO IN 1/3
Connects to the S VIDEO OUT jack of your VCR or other video equipment that has
S VIDEO. S VIDEO provides better picture quality than either composite video (4)
or VHF/UHF (8) connections.
4 VIDEO IN 1/3/4
VIDEO/L(MONO)
-AUDIO-R
Connect to the composite A/V output jacks on your VCR or other video
component. A fourth component A/V input jack (VIDEO 2) is located on the front
of the TV. These video connections provide better picture quality than the
VHF/UHF (8) connections.
5 CONTROL S
IN/OUT
Allows the TV to receive (IN) and send (OUT) remote control signals to other Sony
infrared-controlled audio or video equipment that has the CONTROL S function.
Connects to the left and right audio input jacks of your audio or video equipment.
You can use these outputs to listen to your TV’s audio through your stereo system.
8 VHF/UHF
Primary RF input that connects to your VHF/UHF antenna or cable box.
9 HDMI
(VIDEO 7 IN)
HDMI (High-Definition Multimedia Interface) provides an uncompressed, alldigital audio/video interface between this TV and any HDMI-equipped
audio/video component, such as a set-top box, DVD player, and A/V receiver.
HDMI supports enhanced, or high-definition video, plus two-channel digital audio.
SETUP
7 AUDIO OUT (VAR/FIX)
L (MONO)/R
SETUP
6 HD/DVD IN 5/6
Connect to your DVD player’s or digital set-top box’s component video (Y, PB, PR)
(1080i/720p/480p/480i) and audio (L/R) jacks. Component video provides better picture quality than 3,
4, or 8).
Setup
Description
SETUP
Jack
SETUP
SETUP
13
AX1X.book Page 14 Wednesday, June 30, 2004 9:21 AM
Basic Connections: Connecting a Cable or Antenna
SETUP
The way in which you will connect your TV varies, depending on
how your home receives a signal (cable, cable box, antenna) and
whether or not you plan to connect a VCR.
If You Are Connecting
See Page
Cable or Antenna Only
15
❏
No cable box or VCR
Cable and Antenna Only
❏
Setup
Cable Box and Cable Only
❏
❏
18
Cable box unscrambles only some
channels (usually premium channels)
No VCR
Cable Box Only
❏
❏
16
No cable box or VCR
20
Cable box unscrambles all channels
No VCR
SETUP
SETUP
SETUP
SETUP
If you are connecting a VCR
❑ See the connections described on pages 24 and 26.
14
AX1X.book Page 15 Wednesday, June 30, 2004 9:21 AM
For best results, use one of the following connections if you are connecting a
cable or an antenna and you:
❑ Do not need a cable box to unscramble channels. (If you have a
cable box, see pages 18-20.)
❑
Do not intend to connect a VCR. (If you have a VCR, see pages 24
and 26.)
SETUP
Cable or Antenna
Only
The connection you choose depends on the cable type you have in
your home, as described below.
Connect As Shown
VHF Only or
combined
VHF/UHF or
Cable
75-ohm
coaxial
cable
Setup
75-ohm coaxial cable (usually found in newer homes)
Cable Type
VHF/UHF
TV
SETUP
300-ohm twin lead cable (usually found in older homes)
Cable Type
VHF Only or
UHF Only or
combined
VHF/UHF
Connect As Shown
300-ohm twin
lead cable
VHF/UHF
TV
SETUP
Antenna connector
(not supplied)
75-ohm coaxial and 300-ohm twin lead cable (found in some homes)
Cable Type
VHF and UHF
Connect As Shown
75-ohm
coaxial cable
SETUP
VHF/UHF
TV
U/V mixer
(not supplied)
300-ohm twin
lead cable
SETUP
15
SETUP
AX1X.book Page 16 Wednesday, June 30, 2004 9:21 AM
Cable and Antenna
Only
For best results, use this connection if you:
❑ Have a cable and an antenna.
(This is convenient if you are using a separate rooftop antenna to
receive additional channels, such as HDTV channels, that are not
provided by your cable company.)
❑
Do not have a cable box or VCR. (if you have a cable box, see
pages 18 to 20. If you have a VCR, see pages 24 and 26.)
Cable Type
Setup
Cable TV (CATV)
and Antenna
Connect As Shown
CATV cable
TV
AUX
(No connection to
TO CONVERTER)
SETUP
Antenna cable
TO
CONVERTER
VHF/UHF
About Using This Connection with Dual Picture (Twin View, etc.) Features
SETUP
SETUP
SETUP
With this connection, you cannot view CATV channels in the right dual picture window.
16
AX1X.book Page 17 Wednesday, June 30, 2004 9:21 AM
Notes on Using This Connection
Do This ...
Switch the TV’s input
between the cable and
antenna
Press ANT to switch back and forth between the TV’s VHF/UHF and AUX
inputs.
SETUP
To Do This ...
Setup
SETUP
SETUP
SETUP
SETUP
17
SETUP
AX1X.book Page 18 Wednesday, June 30, 2004 9:21 AM
Cable Box and
Cable Only
✍ DIGITAL CABLE BOX USERS: Do not use this connection. The TO CONVERTER
jack is not compatible with digital cable boxes.
For best results, use this connection if:
❑ Your cable company scrambles some channels, such as premium
channels (which requires you to use a cable box), but does not
scramble all channels.
Setup
❑
You do not have a VCR. (If you have a VCR, see pages 24 and 26.)
With this connection you can:
❑ Use the TV remote control to change channels coming through
the cable box to the TV’s AUX input jack. (You must first program
the remote control for your specific cable box; see “Programming
the Remote Control” on page 46.)
SETUP
❑
Use the TV remote control to change channels coming directly
into the TV’s VHF/UHF input. (The TV’s tuner provides a better
signal than the cable box.)
About Using This Connection with Dual Picture (Twin View, etc.) Features
With this connection, you can use all the dual picture features for unscrambled channels
coming directly into the TV’s VHF/UHF input jack.
SETUP
SETUP
SETUP
However, you can use only some of the dual picture features for channels coming
through the cable box to the TV’s AUX input jack. For example, when you switch the TV’s
input to AUX — to select the cable box input — the picture displays only in the left
window. For example, if you turn on Twin View, you can watch cable channels coming
into the VHF/UHF jack in the right window, but you cannot swap the pictures between
the left and right windows.
18
AX1X.book Page 19 Wednesday, June 30, 2004 9:21 AM
To connect the cable box and cable
1 Connect the cable from your cable company to the TV’s
2 Use a coaxial cable to connect the TV’s TO CONVERTER jack to
the cable box’s input jack. (The TV’s internal converter lets you
switch between unscrambled signals coming straight into the TV
and scrambled signals coming in through the cable box,
eliminating the need for an external splitter.)
SETUP
VHF/UHF jack.
3 Use a coaxial cable to connect the cable box’s output jack to the
TV’s AUX jack.
on page 39.
Cable box
IN
OUT
Coaxial cable
TV
AUX
3
2
SETUP
If you have a digital cable
box, you cannot use this
connection because the
TO CONVERTER jack is not
compatible with digital
cable boxes.
Setup
4 Run Auto Program, as described in “Setting Up the Channel List”
TO
CONVERTER
Coaxial cable
1
Cable (unscrambled channels) VHF/UHF
Notes on Using This Connection
Do This ...
Tune the TV to the channel the cable box is set to (usually channel 3 or 4)
and then use the cable box to switch channels.
Set up the TV remote control
to operate the cable box
Program the remote control. See “Programming the Remote Control” on
pages 46-47.
SETUP
To Do This ...
Use the cable box
Activate the remote control to Press SAT/CABLE FUNCTION.
operate the cable box
When using the cable box, you need the TV to stay on the channel the cable
box is set to (usually channel 3 or 4). You can use the TV’s Channel Fix
feature to lock in a specific channel. For details, see “Using the Channel
Menu” on page 67.
Switch the TV’s input
between the cable box and
cable
Press ANT to switch back and forth between the TV’s VHF/UHF and AUX
inputs.
SETUP
Prevent the accidental
switching of TV channels
SETUP
19
AX1X.book Page 20 Wednesday, June 30, 2004 9:21 AM
SETUP
Cable Box Only
For best results, use this connection if:
❑ Your cable company scrambles all channels, which requires you
to use a cable box.
❑
You do not have a VCR. (If you have a VCR, see pages 24 and 26.)
With this connection you can:
❑ Use the TV remote control to change channels coming through
Setup
the cable box to the TV’s VHF/UHF jack. (You must first
program the remote control for your specific cable box.)
About Using This Connection with Dual Picture (Twin View, etc.) Features
With this connection, all channels come into the TV through your cable box and only one
unscrambled signal is sent to the TV, so you cannot use the dual picture features. If some
of your channels are scrambled, but others are not, consider using the “Cable Box and
Cable” connection on page 18 instead.
To connect the cable box
SETUP
1 Connect the CATV cable to the cable box’s input jack.
2 Use a coaxial cable to connect the cable box’s output jack to the
TV’s VHF/UHF jack.
3 Run Auto Program, as described in “Setting Up the Channel List”
SETUP
on page 39.
CATV
cable
Coaxial cable
1
2
IN
VHF/UHF
TV
OUT
Cable box
SETUP
Notes on Using This Connection
To Do This ...
Do This ...
Use the cable box
Tune the TV to the channel the cable box is set to (usually channel 3 or 4)
and then use the cable box to switch channels.
Set up the TV remote control
to operate the cable box
Program the remote control. See “Programming the Remote Control” on
pages 46-47.
Activate the remote control to Press SAT/CABLE FUNCTION.
operate the cable box
SETUP
Prevent the accidental
switching of TV channels
20
When using the cable box, you need the TV to stay on the channel the cable
box is set to (usually channel 3 or 4). You can use the TV’s Channel Fix
feature to lock in a specific channel. For details, see “Using the Channel
Menu” on page 67.
AX1X.book Page 21 Wednesday, June 30, 2004 9:21 AM
Connecting Optional Equipment
If You Are Connecting
SETUP
Use the directions in this section to connect the following optional
equipment:
See Page
VCR and Cable
24
VCR and Cable Box
26
28
Satellite Receiver and VCR
30
DVD Player with Component Video
Connectors
32
DVD Player with S VIDEO and Audio
Connectors
33
Camcorder
34
Audio Receiver
35
DVI-Equipped Device
36
HDMI-Equipped Device
37
Setup
Satellite Receiver
SETUP
SETUP
SETUP
SETUP
21
SETUP
AX1X.book Page 22 Wednesday, June 30, 2004 9:21 AM
Making Video
Connections
Your TV includes several types of video inputs. When connecting
your TV, use the inputs that are available on your components that
provide the best video performance, as described below.
Best Video Performance
HDMI (High-Definition
Multimedia Interface)
Setup
Component video
S VIDEO
Composite video
RF/Coaxial
SETUP
SETUP
SETUP
SETUP
Good Video Performance
22
AX1X.book Page 23 Wednesday, June 30, 2004 9:21 AM
If the optional equipment you are connecting has an S VIDEO
jack (shown at left), you can use an S VIDEO cable for
improved picture quality (compared to an A/V cable).
Because S VIDEO carries only the video signal, you also need
to connect audio cables for sound, as shown below.
SETUP
About Using
S VIDEO
Example of an S VIDEO Connection
TV
Setup
S VIDEO
cable
Equipment with S VIDEO
SETUP
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
Audio cable
SETUP
SETUP
SETUP
23
AX1X.book Page 24 Wednesday, June 30, 2004 9:21 AM
SETUP
VCR and Cable
For best results, use this connection if:
❑ Your cable company does not require you to use a cable box.
About Using This Connection with Dual Picture (Twin View, etc.) Features
With this connection, you can use all the dual picture features.
To connect the VCR and cable
Setup
Using
S VIDEO jacks?
See page 23.
1 Connect the CATV cable to the VCR’s VHF/UHF input jack.
2 Use a coaxial cable to connect the VCR’s VHF/UHF output jack
to the TV’s VHF/UHF jack.
3 Use an A/V cable to connect the VCR’s A/V output jacks to the
TV’s A/V input jacks.
4 Run Auto Program, as described in “Setting Up the Channel List”
on page 39.
SETUP
TV
SETUP
Coaxial cable
VCR
SETUP
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
CATV cable
SETUP
A/V cable
24
AX1X.book Page 25 Wednesday, June 30, 2004 9:21 AM
Notes on Using This Connection
Watch the VCR
Press TV/VIDEO repeatedly to select the VCR input (VIDEO 1 in the
illustration).
Watch cable channels
Press TV/VIDEO repeatedly to select the cable input (VHF/UHF in the
illustration).
Set up the TV remote control
to operate the VCR
If you have a non-Sony VCR, you must program the remote control. See
“Programming the Remote Control” on pages 46-47.
Activate the TV remote
control to operate the VCR
Press DVD/VCR FUNCTION.
Control VCR functions with
the TV remote control
See “Operating a VCR” on page 48.
Setup
Do This ...
SETUP
To Do This ...
See the instructions for setting up Video Labels on pages 72-73.
Label video inputs to easily
identify equipment connected
to the TV
SETUP
SETUP
SETUP
SETUP
25
AX1X.book Page 26 Wednesday, June 30, 2004 9:21 AM
SETUP
VCR and Cable Box
For best results, use this connection if:
❑ Your cable company scrambles some channels, such as premium
channels (which requires you to use a cable box), but does not
scramble all channels.
About Using This Connection with Dual Picture (Twin View, etc.) Features
With this connection, you can use all the dual picture features.
Setup
With this connection you can:
❑ Use the TV remote control to change channels coming through
SETUP
the cable box. (You must first program the remote control for
your specific cable box; see “Programming the Remote Control”
on page 46.)
❑
Use the TV remote control to change channels coming directly
into the TV’s VHF/UHF jack. (The TV’s tuner provides a better
signal than the cable box.)
❑
Record channels coming through the cable box and channels
coming directly into the TV.
SETUP
To connect a VCR and cable box, you need:
❑ A splitter, which is a small, inexpensive device that you can
❑
purchase at your local electronics store.
Three coaxial cables.
❑
Two A/V cables or S VIDEO cables with audio cables.
To connect the VCR and cable box
1 Connect the CATV cable to the single (input) jack of the splitter.
2 Use a coaxial cable to connect one of the splitter’s two output
jacks to the TV’s VHF/UHF jack.
3 Use a coaxial cable to connect the splitter’s other output jack to
the cable box’s input jack.
SETUP
4 Use a coaxial cable to connect the cable box’s output jack to the
VCR’s RF input jack.
5 Use an A/V cable to connect the cable box’s A/V output jacks to
Using
S VIDEO jacks?
See page 23.
the TV’s A/V input jacks.
6 Use an A/V cable to connect the VCR’s A/V output jacks to the
TV’s A/V input jacks.
7 Run Auto Program, as described in “Setting Up the Channel List”
SETUP
on page 39.
26
AX1X.book Page 27 Wednesday, June 30, 2004 9:21 AM
TV
SETUP
Coaxial
cable
CATV
cable
Coaxial
cable
Setup
Splitter
(not supplied)
Cable box
Coaxial
cable
A/V cable
SETUP
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
VCR
A/V cable
Notes on Using This Connection
Watch cable box (scrambled)
channels
Press TV/VIDEO repeatedly to select the cable box input (VIDEO 3 in the
illustration). Use the cable box to change channels.
Watch the VCR
Press TV/VIDEO repeatedly to select the VCR input (VIDEO 1 in the
illustration).
Set up the TV remote control
to operate the cable box or
VCR
If you have a non-Sony VCR, you must program the remote control. See
“Programming the Remote Control” on pages 46-47.
SETUP
Do This ...
Press TV/VIDEO repeatedly to select the cable input (VHF/UHF in the
illustration).
SETUP
To Do This ...
Watch cable (unscrambled)
channels
Activate the remote control to For the cable box, press SAT/CABLE FUNCTION. For the VCR, press DVD/VCR
operate the cable box or VCR FUNCTION.
Control specific cable box and See “Operating a Cable Box” on page 49 and “Operating a VCR” on page 48.
VCR functions with the TV
remote control
SETUP
See the instructions for setting up Video Labels on pages 72-73.
Label video inputs to easily
identify equipment connected
to the TV
27
AX1X.book Page 28 Wednesday, June 30, 2004 9:21 AM
Satellite Receiver
To connect a satellite receiver
SETUP
1 Connect the satellite antenna cable to the satellite receiver’s
Using
S VIDEO jacks?
See page 23.
satellite input jack.
2 Use an A/V cable to connect the satellite receiver’s A/V output
jacks to the TV’s A/V input jacks.
3 Connect your cable or antenna to the satellite receiver’s
VHF/UHF input jack.
4 Use a coaxial cable to connect the satellite receiver’s VHF/UHF
Setup
output jack to the TV’s VHF/UHF jack.
5 Run Auto Program, as described in “Setting Up the Channel List”
on page 39.
TV
SETUP
CATV cable
Coaxial
cable
SETUP
Satellite receiver
Satellite
antenna cable
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
SETUP
SETUP
A/V cable
28
AX1X.book Page 29 Wednesday, June 30, 2004 9:21 AM
Notes on Using This Connection
Do This ...
Watch the satellite receiver
Press TV/VIDEO repeatedly to select the satellite receiver input
(VIDEO 1 in the illustration).
Set up the TV remote control to operate the
satellite receiver
If you have a non-Sony satellite receiver, you must program
the remote control. See “Programming the Remote Control”
on pages 46-47.
Activate the TV remote control to operate
the satellite receiver
Press SAT/CABLE FUNCTION.
Label video inputs to easily identify
equipment connected to the TV
See the instructions for setting up Video Labels on pages 7273.
Setup
Control satellite receiver functions with the See “Operating a Satellite Receiver” on page 48.
TV remote control
SETUP
To Do This ...
SETUP
SETUP
SETUP
SETUP
29
SETUP
AX1X.book Page 30 Wednesday, June 30, 2004 9:21 AM
Satellite Receiver
and VCR
Using
S VIDEO jacks?
See page 23.
To connect a satellite receiver and VCR
1 Connect the CATV cable to the single (input) jack of the splitter.
2 Use a coaxial cable to connect one of the splitter’s two output
jacks to the TV’s VHF/UHF jack.
3 Use a coaxial cable to connect the splitter’s other output jack to
the satellite receiver’s VHF/UHF input jack.
4 Connect the satellite antenna cable to the satellite receiver’s
satellite input jack.
Setup
5 Use a coaxial cable to connect the satellite receiver’s VHF/UHF
output jack to the VCR’s VHF/UHF input jack.
6 Use an A/V cable to connect the satellite receiver’s A/V output
jacks to the TV’s A/V input jacks.
7 Use an A/V cable to connect the VCR’s A/V output jacks to the
TV’s A/V input jacks.
SETUP
SETUP
8 Run Auto Program, as described in “Setting Up the Channel List”
on page 39.
Notes on Using This Connection
To Do This ...
Do This ...
Watch the satellite receiver
Press TV/VIDEO repeatedly to select the satellite receiver input (VIDEO 3 in
the illustration).
Watch the VCR
Press TV/VIDEO repeatedly to select VCR input (VIDEO 1 in the illustration).
Set up the TV remote control
to operate the satellite
receiver or VCR
If you have a non-Sony VCR or satellite receiver, you must program the
remote control. See “Programming the Remote Control” on pages 46-47.
For the satellite receiver, press SAT/CABLE FUNCTION. For the VCR, press
Activate the TV remote
control to operate the satellite DVD/VCR FUNCTION.
receiver or VCR
See “Operating a Satellite Receiver” on page 48 and “Operating a VCR” on
page 48.
See the instructions for setting up Video Labels on pages 72-73.
Label video inputs to easily
identify equipment connected
to the TV
SETUP
SETUP
Control satellite receiver and
VCR functions with the TV
remote control
30
AX1X.book Page 31 Wednesday, June 30, 2004 9:21 AM
CATV
cable
SETUP
Splitter
(not supplied)
TV
Coaxial
cable
Coaxial
cable
Satellite
antenna
cable
Setup
Satellite receiver
CATV
cable
SETUP
VCR
A/V cable
7
SETUP
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
A/V cable
SETUP
SETUP
31
SETUP
AX1X.book Page 32 Wednesday, June 30, 2004 9:21 AM
DVD Player with
Component
Video Connectors
For best results, use this connection if your DVD player has
component video (Y, PB, PR) jacks.
To connect a DVD player with component video connectors
1 Use component video cables to connect the DVD player’s Y, PB
and PR jacks to the Y, PB and P R jacks (VIDEO 5) on the TV.
✍ The Y, PB and PR jacks on your DVD player are sometimes labeled Y,
Setup
CB and CR, or Y, B-Y and R-Y. If so, connect the cables to like colors.
2 Use an audio cable to connect the DVD player’s audio output
jacks to the TV’s VIDEO 5 audio input jacks.
Component video cables
TV
SETUP
DVD player
SETUP
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
Audio cable
SETUP
SETUP
Notes on Using This Connection
To Do This ...
Do This ...
Watch the DVD player
Press TV/VIDEO repeatedly to select the DVD input (VIDEO 5 in the
illustration).
Set up the TV remote control
to operate the DVD player
If you have a non-Sony DVD player, you must program the remote control.
See “Programming the Remote Control” on pages 46-47.
Activate the TV remote
control to operate the DVD
player
Press DVD/VCR FUNCTION.
Control DVD functions with
the TV remote control
See “Operating a DVD Player” on page 49.
See the instructions for setting up Video Labels on pages 72-73.
Label video inputs to easily
identify equipment connected
to the TV
✍ You cannot record the signal from any equipment connected into the Y, PB,
PR jacks.
32
AX1X.book Page 33 Wednesday, June 30, 2004 9:21 AM
Use this connection if your DVD player does not have component
video (Y, PB, PR) jacks.
SETUP
DVD Player with
S VIDEO and Audio
Connectors
To connect a DVD player with A/V connectors
1 Use an audio cable to connect the DVD player’s audio output
jacks to the TV’s audio input jacks.
2 Use an S VIDEO cable to connect the DVD player’s S VIDEO jack
to the TV’s S VIDEO jack.
Setup
TV
S VIDEO
cable
SETUP
DVD player
SETUP
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
Audio cable
Notes on Using This Connection
Do This ...
Watch the DVD player
Press TV/VIDEO repeatedly to select the DVD input (VIDEO 1 in the
illustration).
Set up the TV remote control
to operate the DVD player
If you have a non-Sony DVD player, you must program the remote control.
See “Programming the Remote Control” on pages 46-47.
Activate the TV remote
control to operate the DVD
player
Press DVD/VCR FUNCTION.
Control DVD functions with
the TV remote control
See “Operating a DVD Player” on page 49.
SETUP
See the instructions for setting up Video Labels on pages 72-73.
Label video inputs to easily
identify equipment connected
to the TV
SETUP
To Do This ...
33
AX1X.book Page 34 Wednesday, June 30, 2004 9:21 AM
SETUP
Camcorder
For easy connection of a camcorder, the TV has front A/V input jacks.
If you prefer, however, you can connect the camcorder to the TV’s
rear A/V input jacks.
Using
S VIDEO jacks?
See page 23.
To connect a camcorder
1 Open the front video panel, as shown on page 11.
2 Use A/V cables to connect the camcorder’s A/V output jacks to
the TV’s A/V input jacks.
Setup
KP-51/57WS520
S VIDEO
VIDEO
L (MONO)
R
VIDEO 2 IN
AUDIO
Cables are often
color-coded to connectors.
Connect red to red,
white to white, etc.
SETUP
VIDEO 2 IN
S VIDEO
VIDEO
L (MONO)
AUDIO
A/V cable
R
SETUP
To A/V output
Camcorder
KP-46WT520
If you have a mono camcorder, connect its audio output jack to the
TV’s L MONO audio jack.
To Do This ...
Do This ...
Watch the camcorder
Press TV/VIDEO repeatedly to select the camcorder input (VIDEO 2 in the
illustration).
See the instructions for setting up Video Labels on pages 72-73.
Label video inputs to easily
identify equipment connected
to the TV
SETUP
SETUP
Notes on Using This Connection
34
AX1X.book Page 35 Wednesday, June 30, 2004 9:21 AM
Audio Receiver
To connect an audio system
1 Use an audio cable to connect the TV’s audio output jacks to the
SETUP
For improved sound quality, you may want to play the TV’s audio
through your stereo system.
audio receiver’s line input jacks.
TV
Setup
SETUP
Cables are often
color-coded to connectors.
Connect red to red,
white to white.
SETUP
Audio cable
To line input
2 Using the TV’s Audio Menu, set the Speaker option to Off. Then set
SETUP
Receiver
the Audio Out option to Fixed or Variable, depending on how you want
to control the volume. For details, see “Using the Audio Menu”
on page 64.
3 Turn on the audio receiver, and then set the receiver’s line input
SETUP
to the jack into which you connected the TV.
35
SETUP
AX1X.book Page 36 Wednesday, June 30, 2004 9:21 AM
DVI-Equipped
Device
If you have a device, such as an HDTV receiver, that has DVI (Digital
Video Interface) output, use the following connection.
To connect a device that has DVI OUT:
1 Use an HDMI-to-DVI cable to connect the device’s DVI OUT jack
to the TV’s HDMI IN jack.
✍ You can purchase HDMI cables (or cable adapters) at your local electronics
Setup
store.
2 Use an audio cable to connect the device’s audio output jacks to
the TV’s HDMI analog audio input jacks.
TV
SETUP
HDMI/DVI (or adaptor-equipped) cable
SETUP
SETUP
Audio cable
HDTV Receiver
Notes on Using This Connection
To Do This ...
Do This ...
Watch the DVI device
Press TV/VIDEO repeatedly to select the VIDEO 7 input.
SETUP
See the instructions for setting up Video Labels on pages 72-73.
Label video inputs to easily
identify equipment connected
to the TV
36
AX1X.book Page 37 Wednesday, June 30, 2004 9:21 AM
If you have a device, such as an HDTV receiver, that has a HighDefinition Multimedia Interface (HDMI), use the following
connection.
SETUP
HDMI-Equipped
Device
To connect a device that has HDMI OUT:
1 Use the HDMI cable that came with your device to connect the
device’s HDMI OUT jack to the TV’s HDMI IN jack.
✍ HDMI cables transmit both audio and video signals. (Separate audio cables
Setup
are not necessary.) You can purchase HDMI cables at your local electronics
store.
TV
HDMI cable
SETUP
SETUP
HDTV Receiver
To Do This ...
Do This ...
Watch the HDMI device
Press TV/VIDEO repeatedly to select the VIDEO 7 input.
SETUP
Notes on Using This Connection
See the instructions for setting up Video Labels on pages 72-73.
Label video inputs to easily
identify equipment connected
to the TV
SETUP
37
AX1X.book Page 38 Wednesday, June 30, 2004 9:21 AM
Using the CONTROL S Feature
SETUP
CONTROL S allows you to control your system and other Sony
equipment with one remote control. In addition to allowing you to
control multiple devices with one remote control, the CONTROL S
feature allows you to always point your remote control at your TV,
instead of having to point it at the other equipment, which might be
hidden or out of direct line of sight.
Use CONTROL S IN to send signals to the TV.
Setup
Use CONTROL S OUT to send signals to connected equipment.
SETUP
SETUP
SETUP
SETUP
TV
38
AX1X.book Page 39 Wednesday, June 30, 2004 9:21 AM
Setting Up the Channel List
Using Auto
Program
SETUP
After you finish connecting the TV, you need to run the Auto
Program feature, which automatically creates a list of available
channels. The Auto Program screens appear when you turn on your
TV for the first time after hooking it up.
To run Auto Program the first time you turn on your TV
1 Press POWER to turn on the TV.
2 When prompted to start Auto Program, press the CH+ button to
start Auto Program.
Setup
The Initial Setup screen appears.
To run Auto Program again at a later time
❑ Use the Auto Program feature as described on page 67.
To reset the TV to factory settings
SETUP
1 Press POWER to turn on the TV.
2 Hold down RESET on the remote control.
3 Press TV POWER on the TV. (The TV will turn itself off, then back
on.)
4 Release RESET.
SETUP
SETUP
SETUP
39
AX1X.book Page 40 Wednesday, June 30, 2004 9:21 AM
Adjusting the Convergence Automatically (Flash Focus)
SETUP
The projection tube image appears on the screen in three colors (red,
green and blue). If they do not converge, the color is poor and the
picture blurs. Before you use your TV, be sure to adjust the
convergence. The Flash Focus feature allows you to adjust the
convergence automatically.
Setup
✍ It is recommended that you perform Flash Focus about 30 minutes after the
z You can also access Flash
Focus in the Setup Menu. For
details, see page 72.
TV is first turned on.
1 Tune to a TV or cable TV program.
2 Press the FLASH FOCUS button on the front panel of the TV (see
page 12).
The cross pattern appears and Flash Focus begins to work.
SETUP
,
The adjustment is completed when the TV picture returns.
To Perform Additional Fine Manual Adjustments
Use the Manual Convergence feature, described on page 41.
❑
SETUP
SETUP
SETUP
Notes on Flash Focus
40
You cannot perform any other functions until Flash Focus has completed its cycle. If you
perform any other operation while Flash Focus is in progress, the Flash Focus operation is
canceled.
AX1X.book Page 41 Wednesday, June 30, 2004 9:21 AM
Adjusting the Convergence Manually
✍ Before adjusting the convergence manually for the first time, you must first
SETUP
The Convergence feature gives you more control over the picture’s
convergence than the Flash Focus feature, allowing you to fine-tune
the convergence.
perform Flash Focus (as described on page 40).
1 Press MENU to display the Menu.
2 Press B or b to highlight the Setup icon and press
3 Highlight Convergence and press
.
.
A pattern of white crosses appears, with a yellow around one
of the crosses. Aligned crosses (which do not need adjustment)
look white and have little or no red or blue showing. Crosses that
are not aligned show red or blue shades beyond their edges.
Setup
SETUP
-
<
-
-
SETUP
<
Full/Normal
Move <
<
z For details on using the
Setup Menu, see page 72.
Select:
End: Menu
You can scroll up and down through the 9 x 7 field of crosses to
manually converge all portions of the screen.
. The
to surround a cross that you want to adjust. Press
changes to red.
5 If the cross that you selected has red edges, move until the red
SETUP
4 Move the
image is replaced with a white cross. Once you have finished this
(or the cross does not have red edges), press
. The changes
to blue.
6 If the cross you selected has blue edges, move until the blue
7 Repeat steps 4 to 6 to adjust other crosses. When finished, press
MENU to exit the Setup Menu.
41
SETUP
image is replaced with a white cross. Once you have finished this,
press
. The changes to yellow again.
Notes on
Adjusting the
Convergence
Manually
❑
Allow the TV to warm up for about 30 minutes before you adjust
the convergence.
❑
For best results, stand about 3 to 5 feet back from the picture
when adjusting the convergence. Begin with the crosses in the
center area of the screen and, once those are adjusted, move to the
crosses on the edges of the screen.
❑
You can make separate adjustments in the each of the following
viewing modes:
Setup
SETUP
AX1X.book Page 42 Wednesday, June 30, 2004 9:21 AM
❑
For standard-definition (480i/480p) sources: Wide Zoom,
Normal/Full, and Zoom modes (see page 53).
❑
For high-definition (720p/1080i) sources: Full, Wide Zoom, and
Zoom modes (see page 54); in Twin View (see page 55).
SETUP
SETUP
SETUP
SETUP
In each of these viewing modes, the cross pattern looks different,
but the adjustment procedure is the same.
42
❑
To optimize the conditions for convergence adjustment, in the
Video Menu, set Mode to Pro or Movie and lower the Picture level
settings (see page 62).
❑
You can reset the adjustments by pressing the RESET button on the
remote control.
AX1X.book Page 43 Wednesday, June 30, 2004 9:21 AM
Using the Remote Control
Overview
This chapter describes how to set up, program, and use the TV’s
remote control.
Topic
Page
Inserting Batteries
43
Button Descriptions
44
Programming the Remote Control
46
Using Other Equipment with Your TV Remote Control
48
Inserting Batteries
1 Remove the battery cover from the remote control.
2 Insert two size AA (R6) batteries (supplied) by matching the e
and E terminals on the batteries to the diagram inside the battery
compartment.
3 Replace the battery cover.
1
2
✍ Remove the batteries to avoid damage from possible battery leakage
whenever you anticipate that the remote control will not be used for an
extended period.
Handle the remote control with care.
Avoid dropping it, getting it wet, placing it in direct sunlight, near a heater,
or where the humidity is high.
43
AX1X.book Page 44 Wednesday, June 30, 2004 9:21 AM
SETUP
Button Descriptions
1
DVD/
VCR
MUTING
SAT/ POWER
CABLE
2
3
MODE
PICTURE WIDE
TV/
DISPLAY VIDEO
qj
Button
Description
qk
ql
1 DVD/VCR
POWER
Press to turn on and off the DVD player or VCR.
w;
2 MUTING
Press to mute the sound. Press again or press VOL+ to
restore the sound. *
3 PICTURE MODE
Press repeatedly to cycle through the available video
picture modes: Vivid, Standard, Movie, Pro. Also available
in the Video Menu. For details, see “Selecting Video
Options” on page 62.
4 WIDE MODE
Press repeatedly to step through the Wide Mode
settings. Also available in the Screen Menu. For
details, see pages 53 and 66.
5 0-9
ENT
Press 0 - 9 to select a channel; the channel changes after
3 seconds. Press ENT (ENTER) to change channels
immediately.
6 JUMP
Press to jump back and forth between two channels.
The TV alternates between the current channel and the
last channel that was selected.
7 TOP MENU
Press to display the DVD Menu.
8
Press Vv B b to move the on-screen cursor. To select
an item, press
.
9 SAT/CABLE
FUNCTION
Press to have the remote control operate the satellite
receiver or cable box.
0 DVD/VCR
FUNCTION
Press to have the remote control operate the DVD
player or VCR.
qa Transport
Buttons
m Rewind
4
SETUP
5
6
JUMP
ENT
TOP MENU
FAVORITES
MENU
wa
ws
Remote Control
7
8
9
q;
SAT/
CABLE
DVD/VCR
TV
F1
qa
wf
F2
FREEZE
qs
qd
TV/SAT
CH
VOL
qf
SETUP
wd
ANT
GUIDE
wg
wh
wj
RESET
SLEEP
MTS/SAP
qg
qh
wk
wl
RM-Y916
N Play
M Fast forward
SETUP
x Stop
X Pause
SETUP
z Record (press together with N)
qs
Press to turn on and off Twin View. For details, see
pages 55-57.
qd FREEZE
Press to freeze the window picture. Press again to
restore the picture. For details see page 59.
qf VOL +/-
Press to adjust the volume. *
* MUTING and VOL +/- buttons also function with Sony DVD Dream™
Systems
44
AX1X.book Page 45 Wednesday, June 30, 2004 9:21 AM
qh SLEEP
Press repeatedly until the TV displays the time in
minutes (15, 30, 45, 60, or 90) that you want the TV to
remain on before shutting off automatically. To cancel
press until Sleep Off appears. While the Sleep feature is
set, press once to display the remaining time.
qj SAT/CABLE
POWER
Press to turn on and off the satellite receiver or cable
box.
qk TV POWER
Press to turn on and off the TV.
ql DISPLAY
Press once to display the current channel number,
current time, and program information banner (if set).
Press again to turn Display off.
w; TV/VIDEO
Press repeatedly to cycle through the video equipment
connected to the TV’s video inputs.
wa MENU
Press to display the Menu. Press again to exit from the
Menu. For details, see page 61.
ws FAVORITES
Press to display the Favorite Channels list. For details,
see page 58.
wd TV FUNCTION
Press to have the remote control operate the TV.
wf F1/F2
Functions only while the remote control is in DVD/VCR
FUNCTION mode. For details, see “Using the F1 and F2
Buttons” on page 49.
wg ANT
Press to switch between the sources connected to the
TV’s VHF/UHF and AUX inputs.
wh TV/SAT
When the remote control is set to operate the satellite
receiver, press to switch between the satellite
receiver’s TV and SAT (satellite) inputs.
wj CH +/-
Press to scan through channels. To scan quickly
through channels, press and hold down either CH
button.
wk
Press repeatedly to step through the Audio Effect
options. Also available in the Audio Menu. For details,
see page 64.
wl MTS/SAP
Press repeatedly to cycle through the Multi-channel
TV Sound (MTS) options: Stereo, Auto SAP (Second
Audio Program), and Mono. Also available in the
Audio Menu. For details, see “Using the Audio Menu”
on page 64.
45
SETUP
When the remote control is set to operate the satellite
receiver, press to display the program guide.
SETUP
GUIDE
SETUP
Press to reset the settings to the factory defaults. See
pages 63 and 65. Also used to clear Favorite Channels,
(see page 58), and Manual Convergence (see page 42).
Remote Control
qg RESET
SETUP
Description
SETUP
Button
AX1X.book Page 46 Wednesday, June 30, 2004 9:21 AM
Programming the Remote Control
SETUP
The remote control is preset to operate Sony brand video equipment.
If you have video equipment other than Sony brand that you want to
control with the TV’s remote control, use the following procedure to
program the remote control.
✍ The equipment must have infrared (IR) remote capability in order to be used
with the remote control.
1 Turn to the list of “Manufacturer’s Codes” on page 47, and find
SETUP
the three-digit code number for the manufacturer of your
equipment. (If more than one code number is listed, try the
number listed first.)
2 While holding down DVD/VCR FUNCTION or SAT/CABLE FUNCTION, press
Remote Control
RESET. Then release both buttons. (The DVD/VCR FUNCTION and
SAT/CABLE FUNCTION buttons will flash.)
3 Press either DVD/VCR FUNCTION or SAT/CABLE FUNCTION, depending on
which button you want to program.
4 Enter the three-digit manufacturer’s code number.
5 Press ENT.
✍ You must do step 5 within 10 seconds of step 4, or you must redo
steps 3 through 5.
6 To check if the code number works, aim the TV’s remote control
SETUP
at the equipment and press the POWER button that corresponds
with that equipment. If it responds, you are done. If not, try using
another code listed for that manufacturer.
Notes
❑ If more than one code number is listed, try entering them one by
SETUP
SETUP
one until you come to the correct code for your equipment.
46
❑
If you enter a new code number, the code number you previously
entered at that setting is erased.
❑
In some cases, you may not be able to operate your equipment
with the supplied remote control. In such cases, use the
equipment’s own remote control.
❑
Whenever you remove the batteries to replace them, the code
numbers may revert to the factory setting and must be reset.
AX1X.book Page 47 Wednesday, June 30, 2004 9:21 AM
Manufacturer’s Codes
Code
301, 302, 303
327
DVD Changers
Manufacturer
Code
Sony
Panasonic
765
766
DVD/VCR Combination Units
Manufacturer
Code
Sony
Broksonic
JVC
Panasonic
Samsung
Toshiba
Zenith
767
776
775
777
774
773
768
HDD/DVD Combination Units
Code
770, 771, 772
DVD 5.1 Ch
Manufacturer
Code
Sony (DAV)
601, 602, 603,
604
Cable Boxes
Manufacturer
Code
Sony
Hamlin/Regal
230
222, 223, 224,
225, 226
201, 202, 203,
204, 205, 206,
207, 208, 218,
222
227, 228, 229
219, 220, 221
214, 215
209, 210, 211
216, 217
212, 213
Jerrold/G.I./
Motorola
Oak
Panasonic
Pioneer
Scientific Atlanta
Tocom
Zenith
Satellite Receivers
Manufacturer
Code
Sony
Dish Network
Echostar
General Electric
Hitachi
Hughes
Mitsubishi
Panasonic
RCA/PROSCAN
Toshiba
801
810
810
802
805
804
809
803
802, 808
806, 807
SETUP
Manufacturer
Sony
Code
751
755
758
756
757
761
753
757
752
755
758
754
760
SETUP
A/V Receivers
Manufacturer
Code
Sony
764
SETUP
322, 339, 340
332
306, 304, 305, 338
309, 308
309, 305, 304, 330,
314, 336, 337
JVC
314, 336, 337, 345,
346, 347
Kenwood
314, 336, 332, 337
LG
332
LXI (SEARS)
332, 305, 330, 335,
338
Magnavox
308, 309, 310
Marantz
314, 336, 337
Marta
332
Memorex
309, 335
Minolta
305, 304
Mitsubishi/MGA 323, 324, 325, 326
Multitech
325, 338, 321
NEC
314, 336, 337
Olympic
309, 308
Optimus
327
Orion
317
Panasonic
308, 309, 306, 307
Pentax
305, 304
Philco
308, 309
Philips
308, 309, 310
Pioneer
308
Quasar
308, 309, 306
RCA/PROSCAN 304, 305, 308, 309,
311, 312, 313, 310,
329
Realistic
309, 330, 328, 335,
324, 338
Yamaha
Zenith
338
308, 309, 338, 310
338
332
314, 336, 337
314, 336, 338, 337
309, 308
312, 311
327, 328, 335, 331,
332
314, 330, 336, 337
331
Manufacturer
Sony
General Electric
Hitachi
JVC
Magnavox
Mitsubishi
Panasonic
Philips
Pioneer
RCA/Proscan
Samsung
Toshiba
Zenith
Remote Control
Fisher
Funai
General
Electronics
Go Video
Goldstar
Hitachi
Instant Replay
JC Penney
338, 344
314, 337
319, 317
309, 308
332
302, 332
304, 338, 309
341, 312, 309
314, 336, 337
304
319, 320, 316, 317,
318, 341
330, 335
338
329, 304, 309
Sharp
Shintom
Signature 2000
(M.Ward)
SV 2000
Sylvania
Symphonic
Tashiro
Tatung
Teac
Technics
Toshiba
Wards
DVD Players
SETUP
Manufacturer
Sony
Admiral
(M. Ward)
Aiwa
Audio Dynamic
Broksonic
Canon
Citizen
Craig
Curtis Mathes
Daewoo
DBX
Dimensia
Emerson
Code
314
322, 313, 321
330, 335
312, 313, 321, 335,
323, 324, 325, 326
327, 328
315
338, 327
SETUP
VCRs
Manufacturer
Sansui
Samsung
Sanyo
Scott
47
AX1X.book Page 48 Wednesday, June 30, 2004 9:21 AM
All Equipment
Operating a
Satellite Receiver
SETUP
SETUP
SETUP
To Do This ...
Do This ...
Switch the TV’s input to the
VCR, DVD player, or other
connected equipment
Press TV/VIDEO repeatedly to cycle
through the video equipment connected
to the TV’s video inputs.
Set up the TV remote control to
operate non-Sony equipment
You must program the remote control the
first time you use it. See “Programming
the Remote Control” on pages 46 to 47.
Operating a VCR
Remote Control
SETUP
SETUP
Using Other Equipment with Your TV Remote Control
To Do This ...
Press
Activate the remote control
to operate the VCR
DVD/VCR FUNCTION
Change channels
CH +/-
Record
N and z simultaneously
Play
N
Stop
x
Fast forward
M
Rewind the tape
m
Pause
X
Search the picture forward
or backward
M or m during playback
(release to resume normal playback)
To Do This ...
Press
Activate the remote control
to operate the satellite
receiver
SAT/CABLE FUNCTION
Turn on/off
SAT/CABLE POWER
Select a channel
0-9, ENT
Change channels
CH +/-
Back to previous channel
JUMP
Display channel number
DISPLAY
Display SAT Guide
GUIDE
Display SAT Menu
MENU
Move highlight (cursor)
VvBb
Select item
48
AX1X.book Page 49 Wednesday, June 30, 2004 9:21 AM
Turn on/off
SAT/CABLE POWER
Select a channel
0-9, ENT
Change channels
CH +/-
Back to previous channel
JUMP
To Do This ...
Press
Activate the remote control
to operate the DVD
DVD/VCR FUNCTION
Play
N
Stop
x
Pause
X
Step through different
tracks of the disc
M to step forward or m to step backward
Step through different
chapters of a video disc
CH+ to step forward or CH- to step backward
Display the DVD player
Menu (Setup)
MENU
Display the DVD Menu
TOP MENU
Move highlight (cursor)
VvBb
Remote Control
SETUP
Using the F1 and
F2 Buttons
Press
SAT/CABLE FUNCTION
SETUP
Operating a DVD
Player
To Do This ...
Activate the remote control
to operate the cable box
SETUP
Operating a Cable
Box
F1 Selects
F2 Selects
DVD/VCR Combination
DVD source
VCR source
DVD HDD Combination
HDD source
DVD source
DVD Dream™ System
Input Select function
(toggles through all
inputs)
Disc Skip function
DVD Five- and Mega-Disc
Changers
Disk Skip function
(no function)
SETUP
Using this Sony Device ...
SETUP
49
AX1X.book Page 50 Wednesday, June 30, 2004 9:21 AM
AX1X.book Page 51 Wednesday, June 30, 2004 9:21 AM
Using the Features
Overview
This chapter describes how to use the features of your TV.
Topic
Page
Watching TV
52
Using Wide Mode
53
Using Twin View
55
Using Favorite Channels
58
Using the Freeze Function
59
51
AX1X.book Page 52 Wednesday, June 30, 2004 9:21 AM
z For a complete list of all
the functions of the remote
control, see pages 43-47.
SETUP
SETUP
Watching TV
To Do This ...
Do This ...
Activate the remote control to
operate the TV
Press TV FUNCTION
Turn on/off the TV
Press TV POWER
Tune directly to a channel
To tune to channels, press 0-9 and then
ENT.
Adjust the volume
Press VOL +/-
Mute the sound
Press MUTING (press again to unmute)
Alternate back and forth
between two channels
Press JUMP
The TV alternates between the current
channel and the last channel tuned.
Display the current channel
Press DISPLAY once to display the channel
number (and other information) number, current time, and channel label
(if set). Press DISPLAY again to turn Display
off.
SETUP
Switch the TV’s input to the
VCR, DVD player, or other
connected equipment
Press TV/VIDEO repeatedly to cycle through
the video equipment connected to the
TV’s video inputs.
Press MENU to display the Menu. For
Change video and audio
details, see “Using the Menus” on
options, customize the TV’s
setup, set parental controls, and page 61.
more
SETUP
SETUP
Features
Switch the TV’s input between
sources connected to the TV’s
VHF/UHF and AUX inputs
52
Press ANT to alternate between sources
connected to the TV’s VHF/UHF and
AUX inputs.
AX1X.book Page 53 Wednesday, June 30, 2004 9:21 AM
Using Wide Mode
❑
Press WIDE MODE repeatedly to toggle through the following Wide
Mode settings.
SETUP
z You can also access the
Wide Mode settings in the
Screen Menu. For details, see
page 66.
The Wide Mode feature lets you change the picture size for both
standard-definition (480i/480p) and high-definition (720p/1080i)
sources.
Using Wide Mode with Standard Definition (480i/480p) Sources
Example
Description
SETUP
Wide Zoom enlarges the center portion of the
picture proportionately. The left and right
edges of the picture are stretched to fill the
16:9 screen.
WIDE
Wide Zoom
m
SETUP
Normal displays the 4:3 picture in its original
size. Bars are shown to fill the 16:9 screen.
WIDE
Normal
m
Features
Full stretches the 4:3 picture horizontally, to
fill the 16:9 screen.
WIDE
Full
m
SETUP
Zoom enlarges the 4:3 picture
proportionately to fill the 16:9 screen. Some
clipping may occur. Zoom is useful for
watching Letterbox movies.
WIDE
Zoom
53
SETUP
When you change channels or inputs, the Wide Mode settings revert
to the 4:3 Default setting in the Screen Menu. To retain the current Wide
Mode setting as channels and inputs are changed, set 4:3 Default to Off.
For details, see page 66.
AX1X.book Page 54 Wednesday, June 30, 2004 9:21 AM
Using Wide Mode with High-Definition (720p/1080i) Sources
SETUP
Example
Description
Full displays the picture at its original size.
WIDE
If the source is a 16:9 high-definition
(720p/1080i) signal, the picture fills the
screen.
Full (native 16:9)
SETUP
If the source is a 4:3 standard-definition
signal that has been upconverted, bars are
shown to fill the 16:9 screen.
Full (upconverted 4:3)
m
Wide Zoom enlarges the center portion of the
picture proportionately. The left and right
edges of the picture are stretched to fill the
16:9 screen.
SETUP
WIDE
Wide Zoom
m
Zoom enlarges the 4:3 picture
proportionately to fill the 16:9 screen. Some
clipping may occur. Zoom is useful for
watching Letterbox movies.
Features
WIDE
Zoom
SETUP
SETUP
When you change channels or inputs, the Wide Mode settings revert
to the 4:3 Default setting in the Screen Menu (only if the input source is
480i or 480p).
54
AX1X.book Page 55 Wednesday, June 30, 2004 9:21 AM
Using Twin View
1 Tune the TV to a working channel.
2 Press .
SETUP
Displaying Twin
Pictures
SETUP
Twin View lets you see two pictures from two sources — from an
antenna, VCR, DVD, etc. — on the screen at the same time. You hear
the sound from only one of the sources at a time, but you can choose
which source’s sound is selected. You can also change the relative size
of each of the pictures.
A second picture appears. The active picture is highlighted in
blue.
,
SETUP
,
To cancel Twin View and watch the active picture
or
.
❑ Press
If you use a cable box to view all channels, the same channel appears in both windows of
Twin View because the cable box unscrambles only one channel at a time.
❑
If you use a cable box, you can view the cable box output in one Twin View window and
view a different source (such as a VCR or DVD player) in the second window by using the
TV/VIDEO button. For details, see “Connecting Optional Equipment” on page 21.
❑
Sources connected to the AUX, VIDEO 5, VIDEO 6, and VIDEO 7 inputs display in the left
Twin View window, but not the right.
❑
If you are viewing a 4:3 source and a 16:9 enhanced source (such as a DVD) side by side in
Twin View, the 4:3 source appears larger.
❑
Twin View does not display channels that are blocked by parental settings (see page 69).
SETUP
❑
Features
Factors Affecting Twin View
SETUP
55
Activating the
To Do This ...
You can use the B and b buttons to activate the left and right pictures
while using Twin View.
Do This ...
To activate the picture in the
right window
To activate the picture in the
left window
SETUP
SETUP
SETUP
AX1X.book Page 56 Wednesday, June 30, 2004 9:21 AM
SETUP
SETUP
Features
Functions Available in the Active (Highlighted) Window
56
To Do This ...
Do This ...
Tune directly to a channel
To tune to channels, press 0-9 and then
ENT or
Press CH+/-
Adjust the volume
Press VOL +/-
Mute the sound
Press MUTING (press again to unmute)
Switch the TV’s input between
sources connected to the TV’s
VHF/UHF and AUX inputs
Press ANT (left window only)
Switch the TV’s input between
sources connected to the TV’s
A/V inputs
Press TV/VIDEO
Change the picture size
Press V or v. (For details, see “Changing
the Picture Size” on page 57.)
AX1X.book Page 57 Wednesday, June 30, 2004 9:21 AM
To Do This ...
The zoom feature lets you vary the relative size of the left and right
pictures.
Do This ...
Enlarge the active picture
SETUP
Changing the
Picture Size
Make the active picture
smaller
SETUP
When you adjust the picture sizes, the TV
memorizes the change. The next time you use the
Twin View function, the memorized sizes appear.
SETUP
Features
SETUP
SETUP
57
AX1X.book Page 58 Wednesday, June 30, 2004 9:21 AM
Using Favorite Channels
SETUP
The Favorite Channels feature lets you select programs from a list of
up to 16 favorite channels that you specify.
Creating a List of
Favorite Channels
SETUP
MENU
z For details on using the
Channel Menu, see page 67.
1
2
3
4
Press MENU to display the Menu.
Press B or b to highlight the Channel icon and press
Press
.
to select Favorite Channels.
Press V or v to highlight a Favorite Channel number (1-16) and
press
.
5 Press V or v to highlight a channel you want to assign to the
Favorite Channel number. A preview of the highlighted channel
appears in the upper right of the screen. Press
to select that
channel as a Favorite Channel.
6 To add more channels to your favorites list, repeat steps 4-5.
SETUP
To clear a Favorite Channel, press V or v to highlight the channel
you want to clear. Press
and then press RESET.
7 Press MENU to exit the Menu.
SETUP
Features
Displaying a List
of Favorite
Channels
1 Press FAVORITES. The Favorite Channels list appears.
Preview of
highlighted
Favorite
Channel
FAVORITES
Favorites
V
z To assign Channel Labels
(e.g., ABC, HBO, MTV, etc.) to
channel numbers, as shown at
right, use the Channel Label
feature in the Channel Menu
(see page 68).
2 Channels
BRAVO
10
ABC
20
HBO
36
MTV
6
FOX
8
CBS
37
COMED
Favorite
Channels
v
2 Press V or v to highlight the channel you want to watch.
A preview of the highlighted Favorite Channel appears.
SETUP
3 Press
58
to select the channel you want to watch.
AX1X.book Page 59 Wednesday, June 30, 2004 9:21 AM
Using the Freeze Function
✍ The Freeze feature is not available while you are using the Twin View.
SETUP
The FREEZE button allows you to temporarily capture a program’s
picture. You can use this feature to write down information such as
phone numbers, recipes, etc.
1 When the program information you want to capture is displayed,
press FREEZE.
picture on the right, while the current program continues on the
left.
SETUP
2 The TV switches to Twin View mode and displays the “frozen”
FREEZE
Current
program
in progress
Frozen
3 To cancel and return to normal viewing, press FREEZE (or just tune
SETUP
Call 555-1234
to another channel).
Features
SETUP
SETUP
59
AX1X.book Page 60 Wednesday, June 30, 2004 9:21 AM
AX1X.book Page 61 Wednesday, June 30, 2004 9:21 AM
Using the Menus
Overview
The Menu gives you access to the following features:
Menu Icon
Description
Page
62
Allows you to make adjustments to your picture
settings. It also allows you to customize the Picture
Mode based on the type of program you are viewing,
select Advanced Video options, and more.
z Press MENU to enter and
exit Menus.
Offers enhanced audio options such as listening to
second audio programming (SAP) or customizing
the Effect of the sound on your TV.
64
Allows you to make Wide Mode adjustments and
make changes to the screen’s vertical center.
66
Allows you to set up a Favorite Channels list, run the 67
Auto Program function, skip and label channels, and
more.
Lets you control the viewing of programs based on
their ratings.
69
72
Provides options for setting up your system,
including selecting closed caption modes, setting the
Timer, labeling video inputs, selecting the language
of the on-screen menus, and more.
Navigating Through Menus
z Menus include navigation
help text that appears at the
bottom of each Menu.
To Do This ...
Press
Display the Menu
MENU
Move through the Menus
Bb
Move through the Menu options
Vv
Select an option to change
Change an option’s settings
Select (confirm) changed setting
VvBb
or B
Exit the Menu
MENU
61
AX1X.book Page 62 Wednesday, June 30, 2004 9:21 AM
Using the Video Menu
SETUP
To access the Video Menu, follow these steps:
1. Display Menu
2. Highlight
3. Select
MENU
Mode: Vivid
Brightness
Color
Hue
Sharpness
Color Temp.: Cool
ClearEdge VM: High
Advanced Video
To exit the Menu, press MENU.
Selecting Video
Options
The Video Menu includes the following options:
Option
Description
To change from one Mode
to another, use the
PICTURE MODE button on the
remote control.
Mode
Customized
viewing
Vivid
Select for enhanced picture contrast and
sharpness.
Standard
Select for standard picture settings.
Movie
Select to display a film-like picture.
Pro
Select to display a picture with minimum
enhancements.
z You can alter the Video
Menu settings (Picture,
Brightness, Color, etc.) for each
Mode.
Menus
SETUP
Menus
SETUP
To change settings, press V v B b.
Press
to confirm the selection.
Adjust to increase picture contrast and deepen the color, or
decrease picture contrast and soften the color.*
Brightness
Adjust to brighten or darken the picture.*
Color
Adjust to increase or decrease color intensity.
Hue
Adjust to increase or decrease the green tones.
Sharpness
Adjust to sharpen or soften the picture.
Color Temp.
White
intensity
adjustment
Cool
Select to give the white colors a blue tint.
Neutral
Select to give the white colors a neutral tint.
Warm
Select to give the white colors a red tint
(NTSC-Standard).
ClearEdge VM Sharpens picture definition to give every object a sharp, clean
edge. Select from High, Medium, Low, Off.
Velocity
Modulation
SETUP
* Image retention is accelerated by higher “Brightness” and “Picture” settings.
See page 1 for information on image retention.
62
AX1X.book Page 63 Wednesday, June 30, 2004 9:21 AM
Description
Advanced
Video
Select Program to choose among the DRC Mode and Noise
Reduction options while viewing NTSC sources.
DRC Mode
SETUP
z DRC Mode options are not
available (grayed out) when
watching 480p, 720p, and 1080i
sources.
Option
Creates a high-resolution picture with 4x
density, for high quality sources (i.e., DVD
player, satellite receiver).
Interlaced
Recommended for moving
pictures.
Progressive Recommended for still images and
text.
CineMotion Provides an optimized display by
automatically detecting film
content and applying a reverse 3-2
pulldown process. Moving
pictures will appear clearer and
more natural-looking.
Noise
Reduction
On
Reduces repetitive random noise.
Off
Turns off Noise Reduction.
SETUP
z For best results, use
CineMotion with Video 5 or 6
(HD/DVD IN) or Video 7 (HDMI
IN).
Menus
* Image retention is accelerated by higher “Brightness” and “Picture” settings.
See page 1 for information on image retention.
To restore the factory default settings for the Video settings (excluding DRC
Mode) of the Mode setting (Vivid, Standard, etc.) the TV is set to:
❑ Press RESET on the remote control when in the Video Menu.
SETUP
Menus
SETUP
63
AX1X.book Page 64 Wednesday, June 30, 2004 9:21 AM
Using the Audio Menu
SETUP
To access the Audio Menu, follow these steps:
1. Display Menu
2. Highlight
3. Select
MENU
Treble
Bass
Balance
Steady Sound: Off
Effect: Simulated
MTS: Stereo
BBE: Off
Speaker: On
Audio Out: Fixed
SETUP
To change settings, press V v B b.
Press
to confirm the selection.
To exit the Menu, press MENU.
Menus
Selecting Audio
Options
SETUP
To change quickly from one
Effect to another, use the
button on the remote control.
The Audio Menu includes the following options:
Option
Description
Treble
Adjust to decrease or increase higher-pitched sounds.
Bass
Adjust to decrease or increase lower-pitched sounds.
Balance
Adjust to emphasize left or right speaker balance.
Steady Sound
On
Select to stabilize the volume.
Off
Select to turn off Steady Sound.
Effect
Menus
MTS
Enjoy stereo,
bilingual and
mono programs
SETUP
BBE
64
TruSurround Select for surround sound (for stereo programs
only).
Simulated
Adds a surround-like effect to mono programs.
Off
Normal stereo or mono reception.
Stereo
Select for stereo reception when viewing a
program broadcast in stereo.
Auto SAP
Select to automatically switch the TV to second
audio programs when a signal is received. (If
no SAP signal is present, the TV remains in
Stereo mode.)
Mono
Select for mono reception. (Use to reduce noise
during weak stereo broadcasts.)
On
Select to give sound more impact by
compensating for phase effects in speakers.
Off
Select for normal stereo or mono reception.
AX1X.book Page 65 Wednesday, June 30, 2004 9:21 AM
Description
Speaker
On
Select to turn on the TV speakers.
Off
Select to turn off the TV speakers and listen to
the TV's sound only through your external
audio system speakers.
Audio Out
Easy control of
volume
adjustments
SETUP
Option
This option can be set only when the Speaker option is set
to Off.
The TV’s speakers are turned off, but the audio
output from your audio system can still be
controlled by the TV’s remote control.
Fixed
The TV’s speakers are turned off and the audio
output of the TV is fixed. Use your audio
receiver’s remote control to adjust the volume
(and other audio settings) through your audio
system.
SETUP
Variable
To restore the factory default settings for Treble, Bass, and Balance
❑ Press RESET on the remote control when in the Audio Menu.
Menus
SETUP
Menus
SETUP
65
AX1X.book Page 66 Wednesday, June 30, 2004 9:21 AM
Using the Screen Menu
SETUP
To access the Screen Menu, follow these steps:
1. Display Menu
2. Highlight
3. Select
Wide Mode: Wide Zoom
4:3 Default: Wide Zoom
Vertical Center
MENU
Menus
SETUP
To change settings, press V v B b.
Press
to confirm the selection.
To exit the Menu, press MENU.
Selecting Screen
Options
The Screen Menu includes the following options:
Option
Description
To change from one Wide
Mode to another, use the
WIDE MODE button on the
remote control.
Wide Mode
Enables you to change the picture size for both standarddefinition (480i/480p) and high-definition (720p/1080i)
sources.
For 480i/480p
sources
Select from: Wide Zoom, Normal, Full, Zoom.
For details, see page 53.
For 720p/1080i Select from: Full, Wide Zoom, Zoom. For
sources
details, see page 54.
Wide Mode is unavailable while in Twin View.
SETUP
✍ In some cases, wide-screen programs will be shown in
aspect ratios that require the display of bars at the top
and bottom of your 16:9 screen. For more details, see
page 79.
4:3 Default
Select the default Wide Mode to use for 4:3 sources.
Menus
To select a Wide Mode to use when channels or inputs are
changed, select from: Wide Zoom, Normal, Full, Zoom. For
details, see page 53.
To continue using the current Wide Mode setting when the
channel or input is changed, select Off.
Vertical Center
Allows you to move the position of the picture up and
down in the window. (Available only in Wide Zoom and Zoom
modes.)
SETUP
Press V or v and press
to choose a correction between
+15 and -15 (Zoom mode), and +10 and -10 (Wide Zoom
mode).
66
AX1X.book Page 67 Wednesday, June 30, 2004 9:21 AM
Using the Channel Menu
To access the Channel Menu, follow these steps:
2. Highlight
3. Select
MENU
SETUP
1. Display Menu
Favorite Channels
Cable: On
Channel Fix: Off
Auto Program
Channel Skip/Add
Channel Label
To change settings, press V v B b.
Press
to confirm the selection.
SETUP
To exit the Menu, press MENU.
Selecting Channel
Options
The Channel Menu includes the following options:
Cable
Channel Fix
Useful when you
have a cable box
or satellite
receiver
connected
Menus
Auto Program
SETUP
Description
Lets you set up a list of your favorite channels. For
details, see “Using Favorite Channels” on page 58.
On
Select if you are receiving cable channels
with a CATV cable.
Off
Select if you are using an antenna.
✍ You should run Auto Program after changing this
option.
Off
Turns off Channel Fix.
2-6
“Fix” your TV’s channel setting to 2-6 and
use the cable box or satellite receiver to
change channels. Select one of these
settings if you connected the equipment to
the VHF/UHF jack.
AUX 2-6
Same as 2-6, except you select one of these
settings if you connected the equipment to
the AUX jack (see page 13).
Video 1
Use this setting if you have connected the
equipment to the A/V input jacks.
Automatically sets up the channel list on the TV for all
receivable channels.
Menus
Option
Favorite Channels
SETUP
67
z Channels that you set to be
skipped can be accessed only
by direct (0-9 buttons) tuning.
SETUP
SETUP
AX1X.book Page 68 Wednesday, June 30, 2004 9:21 AM
Option
Description
Channel
Skip/Add
Allows you to customize the channels that appear when
you use the CH+/- buttons.
1 Press V or v to scroll through the channels until you
find the channel you want to skip or add. Then press
to select it.
2 Press V or v to toggle between Add or Skip. Then
press
to select.
3 To add or skip more channels, repeat steps 1 and 2.
4 Press B to return to the Channel Menu, or press
MENU to exit the Menus.
Allows you to assign labels (such as station call letters) to
channel numbers. You can label up to 40 channels.
1 Highlight Channel and press
.
2 Press V v to scroll through the channel numbers.
Then press
to select the channel number that
you want to assign a label.
3 Highlight Label and press
.
4 Press V v to scroll through the label characters (A-Z,
0-9, etc.). Then press
to select the highlighted
character.
Repeat to add up to 5 characters to the label.
Menus
Channel Label
SETUP
Menus
SETUP
5
6
68
To assign labels to more channels, repeat steps 1-4.
Press B to return to the Channel Menu, or press
MENU to exit the Menus.
AX1X.book Page 69 Wednesday, June 30, 2004 9:21 AM
Using the Parent Menu
SETUP
The Parent Menu allows you to set up the TV to block programs according to their
content and rating levels.
To access the Parent Menu, follow these steps:
1. Display Menu
2. Highlight
3. Select
Password:
____
MENU
Press + to enter
password
SETUP
Use the 0-9 buttons on the remote control to enter a four-digit password.
If this is the first time you are creating this password, confirm the password by
entering it again. (The Parent Menu options appear.)
To change settings, press V v B b. Press
to confirm the selection.
To exit the Menu, press MENU.
Menus
✍ You need your password for any future access into the Parent Menu. If you lose your
password, see “Lost password” on page 80.
Setting Parent
Menu Options
The Parent Menu includes the following options:
z If you are not familiar with
the Parental Guideline rating
system, you should select Child,
Youth, or Young Adult to help
simplify the rating selection. To
set more specific ratings, select
Custom.
Off
Parental Lock
Turn ratings
on/off and select a Child
rating system
Parental lock is off. No programs are
blocked from viewing.
Youth
Maximum ratings permitted are:
❏ US: TV-PG, PG
❏ Canada: C8+, PG, 8 ans+, TV-PG
Y. Adult
Maximum ratings permitted are:
❏ US: TV-14, PG-13
❏ Canada: 14+, 13 ans+, TV-14
Custom
Select to set ratings manually.
❏ US: See page 70 for details.
❏ Canada: See page 71 for details.
Maximum ratings permitted are:
❏ US: TV-Y, TV-G, G
❏ Canada: C, G, TV-Y
For changing your password.
Select Country
U.S.A.
Select to use USA ratings (see page 70).
Canada
Select to use Canadian ratings (see
page 71).
SETUP
Change Password
Menus
z For descriptions of Child,
Youth, and Young Adult
ratings, see page 70.
Description
SETUP
Option
69
US Models:
Selecting Custom
Rating Options
z The Content-Based Ratings
are linked to the level of the
Age-Based Rating. For example,
a program with an Age-Based
Rating of TV-PG V (Violence)
rating may contain moderate
violence, while a TV-14 V
(Violence) rating may contain
more intense violence.
For US models, the Custom Rating Menu includes the following
options. (For Canadian models, see page 71.)
Option
Description
Movie Rating
G
All children and General Audience.
PG
Parental Guidance suggested.
PG-13
Parental Guidance for children under 13.
R
Restricted viewing, parental guidance is
suggested for children under 17.
NC-17
and X
No one 17 or under allowed.
TV Rating
Block programs
by their rating,
content or both
Age-Based Ratings
TV-Y
All children.
TV-Y7
Directed to children age 7 and older.
TV-G
General Audience.
z To ensure maximum
blocking capability, set the AgeBased Ratings.
TV-PG
Parental Guidance suggested.
TV-14
Parents Strongly cautioned.
TV-MA
Mature Audience only.
z If you block unrated TV
programs, be aware that the
following types of programs
may be blocked: emergency
broadcasts, political programs,
sports, news, public service
announcements, religious
programs and weather.
Content-Based Ratings
Viewing Blocked
Programs
SETUP
Menus
SETUP
Menus
SETUP
SETUP
AX1X.book Page 70 Wednesday, June 30, 2004 9:21 AM
70
Unrated
Block programs
or movies that
are broadcast
without a rating
FV
Fantasy Violence.
D
Suggestive Dialogue.
L
Strong Language.
S
Sexual situations.
V
Violence.
Block
Blocks all programs and movies that are
broadcast without a rating.
Allow
Allows programs and movies that are
broadcast without a rating.
You can view blocked programs by entering the password. Press the
ENT (ENTER) button when tuned to a blocked program, then enter the
password. This temporarily switches off the Parental Lock. To
reactivate the Parental Lock settings, turn off the TV. When the TV is
turned on again, your Parental Lock settings are reactivated.
AX1X.book Page 71 Wednesday, June 30, 2004 9:21 AM
For Canadian models, the Custom Rating Menu includes the
following options. (For US models, see page 70.)
Description
C
All children.
C8+
Children 8 years and older.
G
General programming.
PG
Parental Guidance.
14+
Viewers 14 and older.
18+
Adult programming.
G
General programming.
8 ans+
Not recommended for young children.
13 ans+
Not recommended for ages under 13.
16 ans+
Not recommended for ages under 16.
18 ans+
Programming restricted to adults.
French Rating
U.S.A. Rating
See “US Models” on page 70 for details.
You can view blocked programs by entering the password. Press the
ENT (ENTER) button when tuned to a blocked program, then enter the
password. This temporarily switches off the Parental Lock. To
reactivate the Parental Lock settings, turn off the TV. When the TV is
turned on again, your Parental Lock settings are reactivated.
Menus
Viewing Blocked
Programs
SETUP
Option
English Rating
SETUP
Canadian Models:
Selecting Custom
Rating Options
SETUP
Menus
SETUP
71
AX1X.book Page 72 Wednesday, June 30, 2004 9:21 AM
Using the Setup Menu
SETUP
To access the Setup Menu, follow these steps:
1. Display Menu
2. Highlight
3. Select
MENU
Caption Vision: Off
Info Banner
Video Label
Language: English
Clock/Timers
Flash Focus
Convergence
SETUP
To change settings, press V v B b.
Press
to confirm the selection.
To exit the Menu, press MENU.
The Setup Menu includes the following options:
Option
Description
Caption Vision
Allows you to select from three closed caption modes (for
programs that are broadcast with closed caption).
z If DISPLAY is on, Caption
Vision automatically dims
after three seconds to prevent
image burn-in.
SETUP
Menus
Selecting
Setup Options
SETUP
Menus
Info Banner
72
CC1, CC2,
CC3, CC4
Displays a printed version of the
dialog or sound effects of a
program. (Should be set to CC1 for
most programs.)
Text1,Text2,
Text3,Text4
Displays network/station
information presented using either
half or the whole screen (if
available). For closed captioning,
set to CC1.
Off
Turns off Caption Vision.
Displays the program name and the time remaining in the
program (if the broadcaster offers this service). Displays
when the channel is changed or the DISPLAY button is
pressed. Set to On or Off.
AX1X.book Page 73 Wednesday, June 30, 2004 9:21 AM
Video Label
Allows you to identify A/V equipment you connected to
the TV, such as a VCR, DVD, etc. For example, if you have
a DVD player connected to the VIDEO 5 jack, you can
select the label DVD for the VIDEO 5 input. Then when
you press the TV/VIDEO button to change inputs, the Video
Label you assigned to that input appears on screen.
1 Press V or v to highlight the video input (VIDEO 17) to which you want to assign a label. Then press
to select the input.
2 Press V or v to highlight one of the displayed labels.
Then press
to select the label.
z The Skip label is useful for
inputs that do not have
equipment connected to
them.
You can select from the following labels for each input:
Video 1/2/3/4
VHS, DVD, Receiver, Satellite, Cable Box,
8mm, DTV, LD, Beta, Skip
Video 5/6/7
DVD, Satellite, Cable Box, DTV, HD, Skip
SETUP
Description
SETUP
Option
✍ If you select Skip, your TV skips this input when you
press the TV/VIDEO button.
Select to display all on-screen Menus in your language of
choice.
Clock/Timers
Select to set the clock and to program your TV to turn on
and off at two scheduled viewing times.
Timer 1
Timer 2
You can use the Timers to program
the TV to turn on and off and tune
to a specific channel at two
scheduled viewing times.
Timer 1 and Timer 2 are not available to be set until you set
the Current Time.
1 Press V or v to highlight Timer 1 or
Timer 2. To set the timer, press b.
2 Press V or v to highlight one of the following
options, then press
.
4
Select to set the Timer by day,
time, duration, and channel.
Off
Select to turn off the Timer. (Your
previous settings are saved.)
73
SETUP
If you selected Program in step 2, press V and v to set
the day(s), hour, minute, duration, and channel
number. Press
or press b to confirm each
setting and move to the next setting. Press B to go
back to the previous setting.
Press MENU to exit the Menu. An LED on the front
panel will light, indicating the timer has been set.
Menus
3
Program
SETUP
z To go directly to
programming Timer 1 or 2,
press
instead of pressing
b.
Menus
Language
z You can also access Flash
Focus by pressing the FLASH
FOCUS button on the front
panel of the TV.
SETUP
Menus
SETUP
Menus
SETUP
SETUP
AX1X.book Page 74 Wednesday, June 30, 2004 9:21 AM
74
Option
Description
Clock/Timers
(continued)
Current Time
1 Press
to select Current Time.
2 Press V and v to set the current time (day, hour, and
3
minute). Press
(or press b) to confirm each
setting and move to the next setting. Press B to go
back to the previous setting.
Press MENU to exit the Menu.
Flash Focus
Allows you to adjust the convergence automatically. For
details, see page 40.
Convergence
Allows you to fine-tune the convergence manually. For
details, see page 41.
AX1X.book Page 75 Wednesday, June 30, 2004 9:21 AM
Other Information
Overview
This chapter includes the following topics:
Topic
Page
Glossary
76
Contacting Sony
77
Troubleshooting
77
Specifications
81
Optional Accessories
82
Index
83
75
AX1X.book Page 76 Wednesday, June 30, 2004 9:21 AM
Glossary
Welcome
analog signal
aspect ratio
A signaling method that uses continuous changes in the amplitude or frequency of an
electronic transmission to convey information.
Refers to the ratio between the width and height of the screen. This TV has a 16:9
(widescreen) aspect ratio, as opposed to a 4:3 aspect ratio.
SETUP
4:3 aspect ratio
component video
SETUP
composite video
HDMI (High-Definition
Multimedia Interface)
16:9 aspect ratio
Component video is sent through three cables: two color shade (chrominance) signals and one
brightness (luminance) signal. Component video achieves greater color accuracy than
composite video or S VIDEO by splitting chrominance into two separate portions.
Composite video is sent through a single cable. Composite video combines the color shade
(chrominance) and brightness (luminance) information into one video signal.
Provides an uncompressed, all-digital audio/video interface between this TV and any HDMIequipped audio/video component, such as a set-top box, DVD player, and A/V receiver. HDMI
supports enhanced, or high-definition video, plus two-channel digital audio.
A unit of the Federal Communications Commission, Washington, DC, that establishes
television standards in the United States, such as NTSC Color, the standard used in this TV.
RF
Radio Frequency. That part of the frequency spectrum that is used to transmit TV and radio
signals.
Other Info
Other Info
Other Info
National Television System
Committee (NTSC)
76
S VIDEO
S VIDEO requires a single cable, which carries the brightness (luminance) and color
(chrominance) signals of the picture separately. S VIDEO provides better resolution than
composite video, which carries the signals together.
VHF/UHF
VHF (Very High Frequency) is the part of the frequency spectrum from 30 to 300 megahertz.
UHF (Ultra High Frequency) is the part of the frequency spectrum from 300 to 3,000
megahertz.
480i
Provides 480 lines of resolution. Displays images using interlaced scanning, which first
transmits all the odd lines on the TV screen and then the even lines.
480p
Provides 480 lines of resolution. Displays images using progressive scanning, which transmits
each line from top to bottom.
720p
Provides 720 lines of resolution. Displays images using progressive scanning, which transmits
each line from top to bottom.
1080i
Provides 1080 lines of resolution. Displays images using interlaced scanning, which first
transmits all the odd lines on the TV screen and then the even lines. 1080i is one of the
formats used by HDTV (High Definition TV).
AX1X.book Page 77 Wednesday, June 30, 2004 9:21 AM
Contacting Sony
Before calling Sony customer support, please write down the model
and serial numbers of your TV. You’ll find this information on the
front cover of this manual.
If you are having problems with your TV, you can reset all the TV’s
settings to their original factory default settings, as follows.
SETUP
Troubleshooting
Welcome
If, after reading these operating instructions, you have additional
questions related to the use of your Sony television, please call our
Customer Information Services Center at 1-800-222-SONY (7669) (US
residents only) or (416) 499-SONY (7669) (Canadian residents only).
✍ Notice: The following procedure resets all custom settings, channel lists,
etc., to the factory default settings.
Turn on the TV.
SETUP
1
2
3
4
Hold down the RESET button on the remote control.
Press the POWER button on the front panel of the TV.
Release the RESET button on the remote control.
Problem
Possible Remedies
I cannot get Twin View to
work
❏
❏
There is no Twin View
window, or it is just static
❏
❏
❏
Twin View displays the same ❏
program in both windows
77
Other Info
Twin View cannot display
anything but TV channels
SETUP
❏
If you are using a cable box to unscramble all channels (as shown on
page 20), you cannot use the Twin View feature. This is because the cable
box can unscramble only one channel at a time. But if you need the cable
box to unscramble only some (usually premium) channels, you can use
Twin View for unscrambled channels if you connect both a cable and cable
box, as shown on page 18.
You can use Twin View to view a signal from a different source that is
connected to the TV's A/V jacks (such as a VCR or DVD player) in the
second window by pressing the TV/VIDEO button while in Twin View.
Sources connected to the AUX, VIDEO 5, VIDEO 6, and VIDEO 7 inputs, as
well as digital sources, display in the left Twin View window, but not the
right.
Be sure the Twin View window is set to a video input or channel that has a
signal airing.
You might be tuned to a video input with nothing connected to it. Try
cycling through the video inputs by pressing the TV/VIDEO button.
Try cycling through the video inputs by pressing the TV/VIDEO button.
Check that the Video Label option is not set to Skip. (See the Setup Menu on
page 73.)
Both Twin View windows might be set to the same channel. Try changing
channels in either window.
Other Info
Twin View
AX1X.book Page 78 Wednesday, June 30, 2004 9:21 AM
SETUP
Welcome
Remote Control
Problem
Possible Remedies
Remote control
does not operate
❏
❏
❏
Cannot change channels
with the remote control
❏
❏
❏
❏
SETUP
❏
Remote control
does not operate non-Sony
video equipment
❏
❏
Channels
Problem
Possible Remedies
Cannot receive upper
channels (UHF) when
using an antenna
TV is fixed to one channel
❏
Use Auto Program in the Channel Menu to add receivable channels that are
not presently in the TV’s memory (see page 67).
❏
Use Auto Program in the Channel Menu to add receivable channels that are
not presently in the TV’s memory (see page 67).
Check your Channel Fix settings (see page 67).
Use Auto Program in the Channel Menu to add receivable channels that are
not presently in the TV’s memory (see page 67).
Cannot receive any
channels when using
cable TV
Cannot receive or select
channels
Other Info
Other Info
Other Info
❏
The batteries could be weak. Replace the batteries.
Check the orientation of the batteries.
Press the TV FUNCTION button. You may have inadvertently pressed the
SAT/CABLE FUNCTION button, which changes the remote control to SAT or
CABLE mode.
Make sure the TV’s power cord is connected securely to the wall outlet.
Locate the TV at least 3-4 feet away from fluorescent lights.
If you are using the TV to change channels, first press the TV FUNCTION
button.
If you are using another device to change channels, be sure you have not
inadvertently switched your TV from the channel 3 or 4 setting. Use the
Channel Fix option to “fix” the channel based on the hookup you used (see
page 67).
If you are using another device to change channels, be sure to press the
FUNCTION button for that device. For example, if you are using your cable
box to change channels, be sure to press the SAT/CABLE FUNCTION button.
If you replaced the batteries to the remote recently, the code numbers for
the video equipment may need to be reset.
There may be more than one code for the equipment that you are
attempting to operate.
There is a possibility that some non-Sony equipment cannot be operated by
your Sony TV remote.You may need to use the equipment’s original
remote control.
78
❏
❏
❏
Use Auto Program in the Channel Menu to add receivable TV channels that
are not presently in TV memory (see page 67).
AX1X.book Page 79 Wednesday, June 30, 2004 9:21 AM
Video
Possible Remedies
❏
Double images or ghosts
❏
“Black box” on screen
❏
SETUP
Certain programs on DVD or ❏
other digital sources display
a loss of detail, especially
during fast-motion or dark
scenes
Other Info
❏
Bars appear at the
top and bottom of the screen
SETUP
Dotted lines
or stripes
❏
❏
❏
❏
❏
❏
No color
Only snow and noise
appear on the screen
SETUP
Dark, poor or no
picture (screen lit),
good sound
No Video on
VIDEO 3 Input
❏
❏
❏
❏
❏
❏
❏
❏
If your TV does not turn on, and a red light keeps flashing, your TV may
need service. Call your local Sony Service Center.
Make sure the power cord is plugged in.
Press the POWER button on the front of the TV.
Press the TV/VIDEO button to cycle through the connected video sources.
Try another channel; it could be station trouble.
Adjust the Picture option in the Video Menu (see page 62).
Adjust the Brightness option in the Video Menu (see page 62).
Check the antenna/cable connections.
Check to be sure that you have not connected both S VIDEO and composite
video cables to the VIDEO 3 input. You can use S VIDEO or composite
video inputs for VIDEO 3, but not both.
Adjust the Color option in the Video Menu (see page 62).
Check the antenna/cable connections.
Try another channel; it could be station trouble.
Press ANT to change the input mode (see page 45).
Adjust the antenna.
Move the TV away from noise sources such as cars, neon signs, or hairdryers.
Using a highly directional outdoor antenna or a cable may solve the
problem.
You have selected a text option in the Setup Menu and no text is available.
(See page 72 to reset Setup selections.) To turn off this feature, set the
Caption Vision option to Off. If you were trying to select closed captioning,
select CC1 instead of Text 1-4.
Some wide-screen programs are filmed in aspect ratios that are greater
than 16:9 (this is especially common with theatrical releases). Your TV will
show these programs with bars at the top and bottom of the screen. For
more details, check the documentation that came with your DVD (or
contact your program provider).
The compression used by certain digital broadcasts and DVDs may cause
your TV's screen to display less detail than usual, or cause artifacts (small
blocks or dots, pixelations) to appear on your screen. This is due to your
TV's large screen and ability to show very fine detail, and is normal for
certain digitally recorded programs.
Welcome
Problem
No picture
(screen not lit), no sound
Other Info
79
AX1X.book Page 80 Wednesday, June 30, 2004 9:21 AM
SETUP
Welcome
Audio
Problem
Possible Remedies
Good picture,
no sound
Cannot gain enough volume
when using a cable box
Sound seems weak or
insufficient
❏
❏
❏
❏
Cannot raise the volume on ❏
external audio speakers
General
Problem
Possible Remedies
How to reset TV to
factory settings
❏
How to restore Video settings ❏
to factory settings
How to restore Audio
❏
settings to factory settings
❏
Cannot cycle through the
other video equipment
connected to the TV
Cannot operate Menu
❏
Lost password
❏
LED on front panel is lit
❏
❏
Other Info
Other Info
Other Info
SETUP
❏
Press MUTING so that Muting disappears from the screen (see page 44).
Make sure the Speaker option is set to On in the Audio Menu (see page 65).
Increase the volume of the cable box using the cable box’s remote control.
Then press TV FUNCTION and adjust the TV’s volume.
The TV’s audio might be set to Auto SAP or Mono, when it might be better set
to Stereo. In the Audio Menu (see page 64), set the MTS setting to Stereo. If
already set to Stereo, switch to Mono (which may reduce background noise
during weak stereo broadcasts).
If the Speaker option is set to Off and the Audio Out option is set to Fixed (in
order to output the sound to your audio system) use your audio receiver to
adjust the sound (see page 64). Or, to use the TV remote control, set the
Audio Out option to Variable.
To turn on the TV speakers, set the Speaker option to On (see page 64).
80
Turn on the TV. While holding down the RESET button on the remote
control, press the POWER button on the TV. (The TV will turn itself off, then
back on again.) Release the RESET button.
Press the RESET button on the remote control while in the Video Menu (see
page 63).
Press the RESET button on the remote control while in the Audio Menu (see
page 65).
Be sure the Video Label option is not set to Skip (see page 73).
If a menu option appears in gray, this indicates that the TV is in a state in
which the menu option is not available.
In the password screen (see page 69), enter the following master password:
4357. The master password clears your previous password; it cannot be
used to temporarily unblock channels.
The STAND BY LED (see page 12) blinks when the TV is turned on, then
shuts off when the picture is displayed. If the LED blinks continuously, this
may indicate the TV needs service.
The TIMER LED (see page 12) indicates that the timer is set. When the
timer is set, this LED will remain lit even when the TV is turned off.
AX1X.book Page 81 Wednesday, June 30, 2004 9:21 AM
Specifications
Projection Lenses
Antenna
Television System
Channel Coverage
Video
Audio
4 total (1 on front panel)
3 total (1 on front panel)
Audio (IN)
7 total (1 on front panel)
Component Video Input
2 (Y, PB , PR)
CONTROL S (IN/OUT)
Variable/Fixed Audio (OUT)
1
1
Speaker Output
Remote Control
AA (R6) Batteries
KP-46WT520
KP-51WS520
KP-57WS520
20W x 2
Dimensions (W x H x D)
KP-46WT520
Screen Size (measured diagonally)
KP-51WS520
Mass
Power Consumption
KP-46WT520
KP-51WS520
KP-57WS520
In Use
In Standby
1086 x 1017 x 609 mm
(42 3/4 x 40 x 24 in)
1194 x 1280 x 666 mm
(47 x 50 1/2 x 26 1/4 in)
1326 x 1377 x 692
(52 1/4 x 54 1/4 x 27 1/4 in)
61.3 Kg (135 lbs)
77.2 Kg (170 lbs)
88 Kg (194 lbs)
235 W
Under 1 W
SETUP
KP-57WS520
Other Info
Supplied Accessories
More than 408 mVrms at the maximum
volume setting (Variable)
More than 408 mVrms (Fixed)
Impedance (output): 2 kilohms
RM-Y916
2 supplied for remote control
46 inches
51 inches
57 inches
SETUP
Video (IN)
S Video (IN)
1080i, 720p, 480p, 480i
Two channel linear PCM 32, 44.1 and 48 kHz,
16, 20 and 24 bit
1 Vp-p, 75 ohms unbalanced, sync negative
Y: 1 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
500 mVrms (100% modulation)
Impedance: 47 kilohm
Y: 1.0 Vp-p, 75 ohms unbalanced, sync
negative; PB: 0.7 Vp-p, 75 ohms
PR: 0.7 Vp-p, 75 ohms
SETUP
Power Requirements
Inputs/Outputs
HDMI IN
3 picture tubes, 3 lenses, horizontal in-line system
7-inch high-brightness monochrome tubes (6.3 raster size), with optical
coupling and liquid cooling system
High performance, large diameter hybrid lens F1.1
75 ohm external terminal for VHF/UHF
NTSC
American TV Standard
VHF
2-13
UHF
14-69
CATV
1-125
120V, 60 Hz
Welcome
Projection System
Picture Tube
Other Info
Design and specifications are subject to change without notice.
81
AX1X.book Page 82 Wednesday, June 30, 2004 9:21 AM
Other Info
Other Info
Other Info
SETUP
SETUP
Welcome
Optional Accessories
82
❑
A/V Cable (VMC-810/820/830 HG)
❑
Audio Cable (RKC-515HG)
❑
Component Video Cable (VMC-10/30 HG)
❑
Control S Cable (RK-G69HG)
❑
TV Stand for KP-46WT520 (SU-46WT11)
AX1X.book Page 83 Wednesday, June 30, 2004 9:21 AM
Index
0-9 buttons 44, 52, 56
4:3 Default settings 66
A
Advanced Video 63
ANT button 45, 52
antenna, connecting 15
Audio Menu 61
Audio Out 65
AUDIO OUT jack 13
audio receiver, connecting 35
Auto Program (channel
setup) 39, 67
Auto SAP, MTS setting 64
AUX jack, described 13
B
balance, adjusting 64
bass, adjusting 64
batteries, inserting in remote
43
BBE 64
bilingual audio 64
blocking programs. See
ratings.
brightness, adjusting 62
C
cable
Channel Fix 67
Channel Menu 61
Channel Skip/Add 68
channels, creating labels 68
CineMotion 8, 63
ClearEdge VM 7, 62
clearing, Favorite Channels 58
closed caption modes 61, 72
color, adjusting 62
CONTROL S 38
CONTROL S IN/OUT jacks,
described 13
Convergence 12, 74
adjusting automatically 40
adjusting manually 41
convergence 74
Cool, Color Temperature 62
F1/F2 buttons 45
Fast-forward button 44
Favorite Channels
clearing 58
in Channel Menu 67
using 58
FAVORITES button 45
features 7
Fixed audio setting 65
Flash Focus 40, 74
FLASH FOCUS button 12
FREEZE button 44, 59
Freeze, using 59
Full 53, 54
G
GUIDE button 45
D
Digital Reality Creation 7
DISPLAY button 45, 52, 72
DRC Mode 63
DRC. See Digital Reality
Creation.
DVD Dream™ System 49
DVD Five- and Mega-Disc
Changers 49
DVD HDD Combination 49
DVD player
H
connecting 32, 33
using with TV remote
control 49
I
connecting 15
with VCR, connecting 24
cable box
F
connecting with VCR 26
Twin View issues 55
using with TV remote
control 49
Cable setting 67
Caption Vision 72
carrying the TV 10
DVD/VCR Combination 49
DVD/VCR FUNCTION
button 44
DVD/VCR POWER button 44
DVI (Digital Video Interface)
CATV. See cable
CH buttons 12, 45
changing picture size, in Twin
View 57
E
36
Effect button 45
ENTER button 44, 52, 56
HD Detailer 8
HD/DVD IN (1080i/720p/
480p/480i) jacks, described
13
High-Definition Multimedia
Interface (HDMI) 8, 13, 36,
37, 76
hue, adjusting 62
Info Banner 72
Infrared Receiver 12
interlaced 7, 63, 76
J
JUMP button 44, 52
L
label, channels 68
Language, setting 73
83
AX1X.book Page 84 Wednesday, June 30, 2004 9:21 AM
SETUP
Index
M
remote control
MENU button 45, 52, 58, 61
Menus
Audio 61
Channel 61
Parent 61, 69
Screen 61
Setup 61, 72
Video 61
Mono, MTS setting 64
Movie mode 62
MTS 64
MTS/SAP button 45
MUTING button 44 , 52
N
SETUP
62
Noise Reduction 63
Normal 53
O
off, turning off the TV 12
on, turning on the TV 12
SETUP
P
Index
removing, Favorite Channels
58
RESET button 45
resetting, Audio options 65
Rewind button 44
Parent Menu 61, 69
parental control, described 8
password, changing 69
Pause button 44
picture contrast, adjusting 62
Picture in Picture. See Twin
View.
PICTURE MODE button 44
Play button 44
POWER button 12
powering on/off, the TV 12
presetting channels 67
Pro (Video) mode 62
problems, troubleshooting
77–80
progressive 7, 63, 76
R
ratings, setting 69–71
ratings, viewing blocked
programs 70, 71
Record buttons 44
84
TruSurround 64
TruSurround, Effect 64
turning on/off the TV 12
TV FUNCTION button 45, 52
TV POWER button 45, 52
TV/SAT button 45
TV/VIDEO button 12, 45, 52
Twin View
button 44
described 7
using 55–57
S
S VIDEO jack, described 11,
13
SAT/CABLE FUNCTION
button 44
SAT/CABLE POWER button
45
Neutral, Color Temperature
Other Info
inserting batteries 43
programming 46–47
satellite receiver, using with
TV remote control 48
Screen Menu 61
Setup Menu 61, 72
sharpness, adjusting 62
Simulated, Effect 64
sizing, picture in Twin View
57
SLEEP button 45
speakers
turning on/off 65
using external speakers 65
specifications 81
STAND BY indicator 12, 80
Standard mode 62
Steady Sound
described 7
setting 64
V
Variable audio setting 65
VCR
using with TV remote
control 48
with cable box, connecting
26
with cable, connecting 24
with satellite receiver,
connecting 30
Vertical Center, adjusting 66
VHF/UHF jack, described 13
VIDEO (L/R)/AUDIO jacks,
described 13
Video 2 access 11
Video Menu 61
Video modes, selecting 62
Vivid mode 62
VOL buttons 12, 44, 52
W
Stereo, MTS setting 64
Stop button 44
surround sound 64
Warm, Color Temperature 62
Wide Mode 53, 66
WIDE MODE button 44, 53
Wide Zoom 53, 54
T
Z
Timer 73
TIMER indicator 80
TIMER LED 12
timers, setting 73
TO CONVERTER 13
TOP MENU 44
transport buttons 44
treble, adjusting 64
troubleshooting 77–80
Zoom 53, 54
zoom feature, with Twin
View 57
