Routing Switcher Reference Guide

Routing Switcher Features

Signal type

HD SDI/SDI video

Routing switcher type

HDS-X5800

HDS-X3700

HDS-X3600

HDS-X3400

HKSP-061M

Maximum Maximum

Matrix size Multi-level cascadable S-BUS matrix matrix size* size**

264 x 272

128 x 128

1056 x 272 1024 x 1024

1024 x 1024

64 x 64

16 x 16

1024 x 1024

1024 x 1024

8 x 4 16 x 8

SDI/SDTI video***

BKPF-300 8 x 2 112 x 2

BVS-V3232 32 x 32 512 x 512

Analog composite video

BKPF-301 8 x 2 32 x 2

S-BUS

Control

RS-422A

(CART)

Analog audio

BVS-A3232

BKPF-351

AES/EBU audio

Analog composite video, analog audio and

AES/EBU audio

BKPF-350

DVS-128

RS-422A

Time code

DVS-RS1616

DVS-TC3232

32 x 32

8 x 2

8 x 2

128 x 128

32 x 2

112 x 2

512 x 512

1024 x 1024

● ●

16 x 16

32 x 32

128 x 128

256 x 256

512 x 512

512 x 512

Notes:

* An entry in the ‘Maximum cascadable matrix size’ column indicates that routers of this type can be cascaded to form larger matrix, up to the maximum shown.

Cascade sets are required.

** Maximum S-BUS matrix size that can be controlled from the primary station.

*** SDTI is defined as SMPTE305M.

HKSP-061M installs in PFV-SP Series Signal Processing Units. BKPF-300 Series boards install in PFV-D/PFV-HD Series Signal Processing Units.

Ethernet

●(100BASE-TX)

●(10BASE-T)

●(10BASE-T)

●(10BASE-T)

With HKSP-300

A

2

*SGC_001-0010 02.3.16 4:59 PM Page 3

Routing Switcher Reference Guide

Alarm output ISR support

Backup

PSU/CPU option

Standard

Standard

Standard

Standard

Monitor

Standard

Standard

Standard

Board option

Input

Output

Matrix

Rack height

4

1

22

8

BKDS-RS1690

BKDS-RS1690

3

3

BKDS-12890 Standard

BKDS-RS1690

BKDS-RS1690

● ● ●

14

8

8

3

*SGC_001-0010 02.3.16 4:59 PM Page 4

Routing Switcher Reference Guide

Routing Switcher Options

Routing switcher type

Cascade set

HDS-X5800

HDS-X3700

HDS-X3600

HDS-X3400

HKSP-061M

BKPF-300

BVS-V3232

BKPF-301

BVS-A3232

BKPF-351

BKPF-350

DVS-128

DVS-RS1616

DVS-TC3232

HKSP-R80

BKPF-R70A

BKDS-RS1620

BKDS-RS1620

Backup CPU boards

Standard

Standard

Standard

Backup Power

Supply Units

Monitoring output

Standard

Standard

Standard

Standard

Standard

Standard

Standard

Input

HKS-5810M(HD/SD)

HKS-5810SD(SD)

HKDS-X3014(HD/SD)

HKDS-X3011(SD)

BKDS-RS1690 BKDS-PV3291

BKDS-RS1690 BKDS-PV3291

Standard

BKDS-RS1690

BKDS-RS1690

HKSP-R81

BKPF-R70A

Standard

BKDS-RS1691

BKDS-RS1691

BKDS-AV10(Analog video)

BKDS-AA10(Analog audio)

4

*SGC_001-0010 02.3.16 4:59 PM Page 5

Routing Switcher Reference Guide

Distribution

HKS-5820M(HD/SD)

HDS-X3010(HD/SD)

Output

HKS-5860M(HD/SD)

HKS-5860SD(SD)

HKDS-X3064(HD/SD)

HKDS-X3051(SD)

Input expansion

HKS-5811M(HD/SD)

HKS-5811SD(SD)

Matrix

HKS-5830M(HD/SD)

HKS-5830SD(SD)

HKDS-X3060(HD/SD)

HKDS-X3050(SD)

Standard

BKDS-AV11(Analog video)

BKDS-AA11(Analog audio)

5

*SGC_001-0010 02.3.16 4:59 PM Page 6

Routing Switcher Reference Guide

Backup CPU boards

Each type of backup CPU board is identical to the main CPU board it supports. If the main

CPU fails, the backup CPU automatically takes over all control functions and the router continues to function normally.

HDS-X5800/X3700/X3600 video routing switchers incorporate a redundant CPU board as standard. The HKSP-R80 routing switcher controller offers sophisticated primary station functionality, and system redundancy with the HKSP-R81 backup CPU, to any routing switcher system. The HDS-X5800/X3700/X3600 or HKSP-R80 provide full system management of all up-loading and down-loading of configuration files from a PC running

BZR-2000 routing switcher control software via a 10/100Base-T Ethernet-based network.

Backup Power Supply Units

A routing switcher backup Power Supply Unit (PSU) is a valuable option in critical applications, such as on-air play out systems. It operates in parallel with the main router

PSU so that, if this fails, the backup supply continues to supply DC power to the routing switcher. AC power for the backup PSU is fed through a separate connector, so that the main and backup units can be powered from different AC power sources.

6

*SGC_001-0010 02.3.16 4:59 PM Page 7

I/F Processor Functional Index

Mounting frame

Backup power supply

SDI distribution amplifier

SDI monitoring distribution amplifier

Video A to D converter

Video D to A converter

Audio/video multiplexer

Audio/video demultiplexer

4:2:2 to 4 fsc NTSC converter

4 fsc to NTSC 4:2:2 converter

Digital video delay line

Line synchronizer

Frame synchronizer

Analog composite to 4:2:2 decoder

4:2:2 to analog composite encoder

Analog video distribution amplifier

Video delay distribution amplifier

Black burst regenerator

AES/EBU distribution amplifier

Audio distribution amplifier

Audio A to D converter

Audio D to A converter

Audio signal generator

HD to 525 downconverter

525/625 to HD up-converter

HDCAM encoder

HDCAM decoder

Digital video 8 x 2 selector

Analog video 8 x 2 selector

Digital audio 8 x 2 selector

Analog audio 8 x 1 selector

S-BUS expander/repeater

Routing switcher controller

Optical to electrical converter

Electrical to optical converter

HD color corrector

HD/SD multi-format converter

PFV-SP Series

PFV-SP3300

PFV-SP3100

HK-PSU03

HK-PSU01

HKPF-SP003

PFV-HD Series

PFV-HD300A

PFV-HD50A

BKPF-PS300

BKPF-PS50A

HKPF-103M

PFV-D Series

PFV-D300

PFV-D50A

PFV-D10

BKPF-PS300

BKPF-PS50A

HKSP-105

HKSP-106

HKSP-008HD

HKSP-008HD

HKSP-008HD

HKPF-101

HKPF-102

HKPF-105M

HKSP-106M

BKPF-205

BKPF-206

BKPF-012A

BKPF-021

PFV-L Series

PFV-L10

BKPS-LPS10

BKPF-L603

BKPF-L611

BKPF-L612

BKPF-L613C

BKPF-L601C

BKPF-L602C

BKPF-L605

BKPF-L606

BKPF-L608C

BKPF-L608C

BKPF-L641

BKPF-L632

BKPF-L642

BKPF-L703A

BKPF-L723

BKPF-L704

BKPF-L653

BKPF-L753A

BKPF-L751

BKPF-L752

BKPF-L754

HKSP-525

HKSP-1125

HKPF-525V

HKPF-525AV

HKPF-9000

HKPF-1125A

HKPF-9000

HKPF-E270

HKPF-D270

HKSP-061M BKPF-300

BKPF-301

BKPF-350

BKPF-351

BKPF-R70A

BKPF-L803

HKSP-R80

HKSP-R81

HKPF-SP021

HKSP-SP022

HKSP-313

HKPF-9000

7

*SGC_001-0010 02.3.16 4:59 PM Page 8

I/F Processor Cross Reference Guide

Output formats

NTSC/PAL

YCbCr or RGB

Component serial digital

Composite serial digital

HD serial digital

HKPF-1125A

HKSP-1125

HD-SDTI

AES/EBU digital audio

Analog audio

S-BUS control

Optical (SD SDI)

Optical (HD SDI)

NTSC/PAL

BKPF-301

BKPF-L703A

BKPF-L704A

(NTSC output)

BKPF-L723

YCbCr or RGB

BKPF-L641 BKPF-L601

HKPF-101

Input formats

Component serial digital

Composite serial digital

BKPF-L613C

BKPF-L632

BKPF-L642

BKPF-152C

BKPF-L602C

BKPF-103

BKPF-104C

BKPF-105A

BKPF-106A

BKPF-107C

BKPF-108C

BKPF-111

BKPF-112

BKPF-113

BKPF-205

BKPF-206

BKPF-300

BKPFL603

BKPF-L605

BKPF-L606

BKPF-L608C

BKPF-L611

BKPF-L612

BKPF-L613C

HKPF-SP003

HKSP-061M

BKPF-012A

BKPF-205

BKPF-206

BKPF-300

BKPF-L603

BKPF-L605

BKPF-L606

BKPF-L611

BKPF-L612

HKPF-SP003

HKPF-9000

HKSP-061M

HKPF-1125A

HKSP-1125

HKPF-1125A

HKPF-9000

HD serial digital

HKPF-102

HKPF-525V

HKPF-525AV

HKSP-525

HKPF-9000

HKPF-103M

HKPF-105M

HKPF-106M

HKPF-9000

HKPF-SP003

HKSP-008HD

HKSP-061M

HKSP-313

HKPF-E270

HKPF-106M BKPF-L606

BKPF-206

BKPF-L606

BKPF-206

HKPF-SP022 HKPF-SP022

HKPF-SP022

8

*SGC_001-0010 02.3.16 4:59 PM Page 9

I/F Processor Cross Reference Guide

HD-SDTI

AES/EBU digital audio

Analog audio S-BUS control Ethernet control Optical (SD SDI) Optical (HD SDI)

BKPF-L605 BKPF-205 HKPF-SP021

BKPF-L605 BKPF-205 HKPF-SP021

HKPF-D270

HKPF-SP003

HKPF-105M

BKPF-350

BKPF-L653

BKPF-L752

BKPF-L751

BKPF-351

BKPF-L753A

BKPF-L754

(output only)

BKPF-L803

BKPF-R70A

HKSP-R80

HKSP-R81

HKSP-R80

HKSP-R81

HKPF-SP022

HKPF-SP021

HKPF-SP021

9

*SGC_001-0010 02.3.16 4:59 PM Page 10

10

*SGC_0011-0038 02.3.16 4:59 PM Page 11

Routing Switchers

HDS-X5800 . . . . . . . . . . . . . . 12

HDS-X3700 . . . . . . . . . . . . . . 14

HDS-X3600 . . . . . . . . . . . . . . 15

HDS-X3400 . . . . . . . . . . . . . . 16

DVS-128 . . . . . . . . . . . . . . . . 17

DVS-RS1616 . . . . . . . . . . . . . 19

DVS-TC3232 . . . . . . . . . . . . . 20

BVS-A3232 . . . . . . . . . . . . . . 21

BVS-V3232 . . . . . . . . . . . . . . 22

BKS-R1617 . . . . . . . . . . . . . . 23

BKS-R1618 . . . . . . . . . . . . . . 24

BKS-R3216 . . . . . . . . . . . . . . 25

BKS-R3219 . . . . . . . . . . . . . . 26

BKS-R3220 . . . . . . . . . . . . . . 27

BKS-R3240A . . . . . . . . . . . . . 28

BKS-R3242A . . . . . . . . . . . . . 29

BKS-R3248A . . . . . . . . . . . . . 30

BKS-R3280 . . . . . . . . . . . . . . 31

BKS-R3281 . . . . . . . . . . . . . . 32

HKSP-R80. . . . . . . . . . . . . . . 33

BKPF-R70A. . . . . . . . . . . . . . 34

BKS-R5001 . . . . . . . . . . . . . . 35

BZR-2000 . . . . . . . . . . . . . . . 36

BZR-IF310. . . . . . . . . . . . . . . 37

11

*SGC_0011-0038 02.3.16 4:59 PM Page 12

Routing Switchers

HDS-X5800

Multi Bit-Rate Routing Switcher

The HDS-X5800 is a large-scale, multi format and multi bit-rate routing switcher for use in Sony S-BUS systems.

The HDS-X5800 can be expanded up to a maximum matrix size of 1056 x 272. A range of I/O module handles signals from 143 Mb/s to 1.5 Gb/s. Remote maintenance and remote control routing functions are available via a

100 Base-TX network. Four reference inputs and four simultaneous S-BUS control ports are included. The four reference inputs support the co-existence of four different vertical interval switching times. Black burst or tri-level sync is available. The power consumption of a 264 x 272

HDS-X5800 is approx. 900 W including a redundant power supply unit and control board.

Features

*Highly flexible, multi bit-rate routing switcher for use in

S-BUS systems *Compact size and high packing density

— 264 x 272 in 22RU *Flexible input and output configurations — Increments of 33 inputs and/or 34 outputs; HD/SD input and output options; SD input and output options *Non-blocking expansion up to 1056 x

1088 *143 Mb/s to 1.5 Gb/s in the same frame *Auto cable equalization *Auto re-clocking at 143, 177, 270,

360, 540 Mb/s and 1.485 Gb/s — Re-clocks DVB-ASI signals with an optional HKS-5810M/5820M/5830M/

5860M board installed *Robust and powerful Sony S-BUS control system *Quad-standard operation in a single frame — Four vertical interval switching references; Four

S-BUS control ports *Ethernet-based remote control and set-up *Fully redundant internal controllers and power supplies as standard *Front loading and hot swap modules *Low power consumption (approx. 900 W)

Supplied Accessories

Operation manual (1)

BZR-20 backup software (1)

BNC T-bridge connector (1)

75

Ω terminator (5)

Maintenance manual (1)

Installation manual (1)

Optional Boards

HKS-5810M HD/SD Input Board

HKS-5810SD SD Input Board

HKS-5811M HD/SD Cascade Input Board

HKS-5811SD SD Cascade Input Board

HKS-5820M HD/SD Input Distribution Board

HKS-5830M HD/SD Matrix Board

HKS-5830SD SD Matrix Board

HKS-5860M HD/SD Output Board

HKS-5860SD SD Output Board

Optional Software

BZR-2000 Routing Switcher Control Software

Optional Peripherals

BKS-R1617 Multi-Display Control Unit

BKS-R1618 Universal Control Unit

BKS-R3216 Multi-BUS Control Unit

BKS-R3219 Universal Control Unit

BKS-R3220 X-Y Control Unit

BKS-R3240A X-Y Control Unit

BKS-R3242A X-Y Control Unit

BKS-R3248A X-Y Control Unit

BKS-R3280 Single Status Display Unit

BKS-R3281 Single Status Display Unit

12

Rear Panel

*SGC_0011-0038 02.3.16 4:59 PM Page 13

Routing Switchers

Specifications

Inputs/outputs

Serial digital input:

SDI IN connector (BNC type)

(up to 264 in steps of 33) 0.8 Vp-p

610%, 75

Channel coding:

Scrambled NRZI

Cable length

SD options:

200 m max. (With Belden 8281,

Fujikura 5C2V or equivalent coaxial cable)

HD/SD options:

100 m max. (With Belden 1694A,

Fujikura 5CFB or equivalent coaxial cable)

Input return loss

SD options:

15 dB or more (5 MHz to 360 MHz)

HD/SD options:

15 dB or more (5 MHz to 1.485 GHz)

Serial digital output:

SDI OUT connector (BNC type)

(Up to 272 in steps of 34)

Signal standard

SD options:

4:2:2 component serial digital signal

(SDI), conforming to

SMPTE259M-A/B/C/D

HD/SD options:

HD component serial digital signal

(HD SDI), conforming to SMPTE292M

Data transfer rate

SD options:

143 Mb/s to 360 Mb/s

HD/SD options:

143 Mb/s to 1.485 Gb/s

Re-clocking

SD options:

143, 177, 270, 360 Mb/s

HD/SD options:

143, 177, 270, 360, 540 Mb/s;

1.485/1.001, 1.485 Gb/s

Output return loss

SD options:

15 dB or more (5 MHz to 360 MHz)

HD/SD options:

15 dB or more (5 MHz to 1.485 GHz)

REMOTE 1

Connector:

BNC type (4)

Protocol:

Sony S-BUS

Data transfer rate:

312 kb/s (1250 kb/s will be supported in the future)

Data transfer method:

Bi-phase Space

Cable length:

500 m max. (With Belden 8281,

Fujikura 5C2V or equivalent coaxial cable)

REMOTE 2

Connector:

D-sub 9-pin (2), complies with

RS-422A signal standard

Protocol:

Sony Cart+

Data transfer rate:

38.4 kb/s

REMOTE 3

Connector:

D-sub 9-pin male (1), complies with

RS-232C signal standard, 38.4 Kb/s

DTR control, 8 bits, no parity, no check, 1 stop bit

ALARM OUT:

Mini D-sub 9-pin female (4), Parallel

(relay contact outputs 6-ch)

REF IN:

BNC (4), with loop-through output, tri-level sync or black burst signal

NETWORK:

RJ-45 (1), 100BASE-TX

General

Power requirements:

AC 100 V to 240 V, 50 to 60 Hz

Power consumption:

Approx. 900 W (fully loaded)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operational humidity:

10 to 90% (no condensation)

Dimensions (W x H x D)

440 x 974 x 520 mm

(17 3 /8 x 38 3 /8 x 20 1 /2 inches)

(Without projections)

Mass:

Approx. 90 kg (fully loaded) (198 lb)

Service parts: Extension Board EX-847 (Part No,

A-8329-772-A), Maintenance Manual Part II,

Protocol Manual

13

*SGC_0011-0038 02.3.16 4:59 PM Page 14

Routing Switchers

HDS-X3700

Multi Bit-Rate Routing Switchers

The HDS-X3000 Series are ultra-compact multi bit-rate routers developed to support every format defined by Rec

ITU-R BT605, SMPTE259M (SD), and SMPTE292M (HD) as well as 1080/24P format. A range of I/O modules handles signals from 143 Mb/s up to 1.5 Gb/s. Router control is via S-BUS and RS-422A. S-BUS is providing communications and tally management with BKS-R

Series routing switcher control units, Sony MVS/DVS

Series production switchers and so on. Among the many features that S-BUS supports are multi-level working, signal breakaway, phantom operation of cross-points and tie-line management. Router data is maintained in memory by a 24-hour battery backup.

Features

* A range of highly flexible, multi bit-rate routing switchers for use in S-BUS systems * High density, ultra compact design * Up to 128 x 128 SD/HD I/O in 8U * 143 Mb/s to

1.5 Gb/s in the same frame, without any system alteration

* SDI (143, 177, 270, 360 Mb/s and 540 Mb/s) * SDTI

(270 Mb/s) * HD SDI (1.485 and 1.485/1.001 Gb/s) *

Flexible input and output configurations in increments of

16 channels * HD SDI/SD SDI input and output options *

Low-cost SD SDI input and output options * Auto cable equalization on inputs and re-clocking on outputs *

Passes DVB-ASI signals * Supports SMPTE292M, which includes the proposed 1080/24P format * Black burst and tri-level sync reference switching in blocks of 32 outputs *

Monitoring outputs in blocks of 32 channels * S-BUS and

RS-422A control * Redundant control and power supply

Supplied Accessories

Operation manual (1)

Installation manual (1)

Maintenance manual (1)

75

Ω teminator (1)

BNC T-bridge connector (1)

Backup software BZR-20 (1)

Optional Accessories

RMM-10 Rack Mount Kit

Optional Boards

HKDS-X3010 Distribution Board

HKDS-X3011 SD Serial Input Board

HKDS-X3064 SD/HD Serial Output Board

HKDS-X3060 SD/HD Matrix Board

HKDS-X3051 SD Serial Output Board

HKDS-X3050 SD Matrix Board

HKDS-X3014 SD/HD Serial Input Board

Optional Software

BZR-2000 Routing Switcher Control Software

Optional Peripherals

BKS-R1617 Multi-Display Control Unit

BKS-R1618 Universal Control Unit

BKS-R3216 Multi-BUS Control Unit

BKS-R3219 Universal Control Unit

BKS-R3220 X-Y Control Unit

BKS-R3240A X-Y Control Unit

BKS-R3242A X-Y Control Unit

BKS-R3248A X-Y Control Unit

BKS-R3281 Single Status Display Unit

BKS-R3280 Single Status Display Unit

Specifications

Inputs/outputs

REMOTE 1:

S-BUS, BNC type (3)

Data transfer rate:

312 kb/s

Data transfer method:

BI-PHASE SPACE

Transmission distance:

500 m (with Belden 8281, Fujikura

5C2V or equivalent 75

Ω coaxial cable). Isolator/Expander

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

Complies with RS-422A signal standards

D-sub 9-pin (2)

Data transfer rate:

38.4 kb/s

Protocol:

Cart+

REMOTE 3:

Complies with RS-232C signal standards

D-sub 9-pin male (1)

Terminal:

9.6/38.4 kb/s DTR control,

8 bits, no parity, 1 stop bit

REMOTE 4:

S-BUS, BNC type (1) for monitoring

Same specifications as REMOTE 1

Rear Panel

ALARM OUT:

Parallel (relay) (2 connecting points)

Mini D-sub 15-pin female

REF IN:

Tri-level sync/Black burst:

BNC with loop-through (2)

NETWORK:

10Base-T, RJ-45 (2)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

650 W (128 x 128, 1.5 Gb/s)

Operational temperature:

5 to 40 °C (41 to 104 °F)

Operational humidity:

10 to 90%

Dimensions (W x H x D):

440 x 354 x 520 mm

(17 3/8 x 14 x 20 1/2 inches)

Mass:

Approx. 20 kg (44 lb 1 oz) (without modules)

Service parts: Extension Board, Maintenance

Manual Part II, Protocol Manual

14

*SGC_0011-0038 02.3.16 4:59 PM Page 15

Routing Switchers

HDS-X3600

Multi Bit-Rate Routing Switchers

The HDS-X3000 Series are ultra-compact multi bit-rate routers developed to support every format defined by Rec

ITU-R BT605, SMPTE259M (SD), and SMPTE292M (HD) as well as 1080/24P format. A range of I/O modules handles signals from 143 Mb/s up to 1.5 Gb/s. Router control is via S-BUS and RS-422A. S-BUS is providing communications and tally management with BKS-R

Series routing switcher control units, Sony MVS/DVS

Series production switchers and so on. Among the many features that S-BUS supports are multi-level working, signal breakaway, phantom operation of cross-points and tie-line management. Router data is maintained in memory by a 24-hour battery backup.

Features

* A range of highly flexible, multi bit-rate routing switchers for use in S-BUS systems * High density, ultra compact design * 143 Mb/s to 1.5 Gb/s in the same frame, without any system alteration * SDI (143, 177, 270, 360

Mb/s and 540 Mb/s) * SDTI (270 Mb/s) * HD SDI (1.485

and 1.485/1.001 Gb/s) * Flexible input and output configurations in increments of 16 channels * HD SDI/SD

SDI input and output options * Low-cost SD SDI input and output options * Auto cable equalization on inputs and re-clocking on outputs * Passes DVB-ASI signals *

Supports SMPTE292M, which includes the proposed

1080/24P format * Black burst and tri-level sync reference switching in blocks of 32 outputs * Monitoring outputs in blocks of 32 channels * S-BUS and RS-422A control *

Redundant control and power supply

Supplied Accessories

Operation manual (1)

Installation manual (1)

Maintenance manual (1)

75

Ω teminator (1)

BNC T-bridge connector (1)

Backup software BZR-20 (1)

Optional Accessories

RMM-10 Rack Mount Kit

Optional Boards

HKDS-X3010 Distribution Board

HKDS-X3011 SD Serial Input Board

HKDS-X3064 SD/HD Serial Output Board

HKDS-X3060 SD/HD Matrix Board

HKDS-X3051 SD Serial Output Board

HKDS-X3050 SD Matrix Board

HKDS-X3014 SD/HD Serial Input Board

Optional Software

BZR-2000 Routing Switcher Control Software

Optional Peripherals

BKS-R1617 Multi-Display Control Unit

BKS-R1618 Universal Control Unit

BKS-R3216 Multi-BUS Control Unit

BKS-R3219 Universal Control Unit

BKS-R3220 X-Y Control Unit

BKS-R3240A X-Y Control Unit

BKS-R3242A X-Y Control Unit

BKS-R3248A X-Y Control Unit

BKS-R3281 Single Status Display Unit

BKS-R3280 Single Status Display Unit

Specifications

Inputs/outputs

REMOTE 1:

S-BUS, BNC type (2)

Data transfer rate:

312 kb/s

Data transfer method:

BI-PHASE SPACE

Transmission distance:

500 m (with Belden 8281, Fujikura

5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

Complies with RS-422A signal standards

D-sub 9-pin (2)

Data transfer rate:

38.4 kb/s

Protocol:

Cart+

REMOTE 3:

Complies with RS-232C signal standards

D-sub 9-pin male (1)

Terminal:

9.6/38.4 kb/s DTR control,

8 bits, no parity, 1 stop bit

REMOTE 4:

S-BUS, BNC type (1) for monitoring

Same specifications as REMOTE 1

Rear Panel

ALARM OUT:

Parallel (relay) (2 connecting points)

Mini D-sub 15-pin female

REF IN:

Tri-level sync/Black burst:

BNC with loop-through (2)

NETWORK:

10Base-T, RJ-45 (2)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

330 W (64 x 64, 1.5 Gb/s)

Operational temperature:

5 to 40 °C (41 to 104 °F)

Operational humidity:

10 to 90%

Dimensions (W x H x D):

440 x 176 x 520 mm

(17 3/8 x 7 x 20 1/2 inches)

Mass:

Approx. 15 kg (33lb 1 oz) (without modules)

Service parts: Extension Board, Maintenance

Manual Part II, Protocol Manual

15

*SGC_0011-0038 02.3.16 4:59 PM Page 16

Routing Switchers

HDS-X3400

Multi Bit-Rate Routing Switchers

The HDS-X3000 Series are ultra-compact multi bit-rate routers developed to support every format defined by Rec

ITU-R BT605, SMPTE259M (SD), and SMPTE292M (HD) as well as 1080/24P format. A range of I/O modules handles signals from 143 Mb/s up to 1.5 Gb/s. Router control is via S-BUS and RS-422A. S-BUS is providing communications and tally management with BKS-R

Series routing switcher control units, Sony MVS/DVS

Series production switchers and so on. Among the many features that S-BUS supports are multi-level working, signal breakaway, phantom operation of cross-points and tie-line management. Router data is maintained in memory by a 24-hour battery backup.

Features

* A range of highly flexible, multi bit-rate routing switchers for use in S-BUS systems * High density, ultra compact design * 143 Mb/s to 1.5 Gb/s in the same frame, without any system alteration * SDI (143, 177, 270, 360 Mb/s and

540 Mb/s) * SDTI (270 Mb/s) * HD SDI (1.485 and

1.485/1.001 Gb/s) * Flexible input and output configurations in increments of 16 channels * HD SDI/SD

SDI input and output options * Low-cost SD SDI input and output options * Auto cable equalization on inputs and re-clocking on outputs * Passes DVB-ASI signals *

Supports SMPTE292M, which includes the proposed

1080/24P format * Black burst and tri-level sync reference switching in blocks of 32 outputs * Monitoring outputs in blocks of 32 channels * S-BUS and RS-422A control *

Redundant control and power supply

Supplied Accessories

Operation manual (1)

Installation manual (1)

Maintenance manual (1)

75

Ω teminator (1)

BNC T-bridge connector (1)

Backup software BZR-20 (1)

Optional Accessories

RMM-10 Rack Mount Kit

Optional Boards

HKDS-X3010 Distribution Board

HKDS-X3011 SD Serial Input Board

HKDS-X3064 SD/HD Serial Output Board

HKDS-X3060 SD/HD Matrix Board

HKDS-X3051 SD Serial Output Board

HKDS-X3050 SD Matrix Board

HKDS-X3014 SD/HD Serial Input Board

Optional Software

BZR-2000 Routing Switcher Control Software

Optional Peripherals

BKS-R1617 Multi-Display Control Unit

BKS-R1618 Universal Control Unit

BKS-R3216 Multi-BUS Control Unit

BKS-R3219 Universal Control Unit

BKS-R3220 X-Y Control Unit

BKS-R3240A X-Y Control Unit

BKS-R3242A X-Y Control Unit

BKS-R3248A X-Y Control Unit

BKS-R3400 Routing Switcher Control Panel

BKS-R3281 Single Status Display Unit

BKS-R3280 Single Status Display Unit

Specifications

Inputs/outputs

REMOTE 1:

S-BUS, BNC type (1)

Data transfer rate:

312 kb/s

Data transfer method:

BI-PHASE SPACE

Transmission distance:

500 m (with Belden 8281, Fujikura

5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

Complies with RS-422A signal standards

D-sub 9-pin (1)

Data transfer rate:

38.4 kb/s

Protocol:

Cart+

REMOTE 3:

Complies with RS-232C signal standards

D-sub 9-pin male (1)

Terminal:

9.6/38.4 kb/s DTR control,

8 bits, no parity, 1 stop bit

REF IN:

Tri-level sync/Black burst:

BNC with loop-through (1)

Rear Panel

NETWORK:

10Base-T, RJ-45 (1)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

70 W (16 x 16, 1.5 Gb/s)

Operational temperature:

5 to 40 °C (41 to 104 °F)

Operational humidity:

10 to 90%

Dimensions (W x H x D):

440 x 43.6 x 520 mm

(17 3/8 x 1 3/4 x 20 1/2 inches)

Mass:

Approx. 8.5 kg (18 lb 12 oz) (without modules)

Service parts: Extension Board, Maintenance

Manual Part II, Protocol Manual

16

*SGC_0011-0038 02.3.16 4:59 PM Page 17

Routing Switchers

DVS-128

Routing Switcher

The DVS-128 is a compact 128 inputs and 128 outputs routing switcher capable of switching analog video, analog audio and digital audio signals at the same time. It can convert an analog audio input into a digital audio output, and vice versa. Installation of up to four 32-input blocks and four 32-output blocks is allowed. Input and output blocks for analog video, analog audio and digital audio are available. Video and audio blocks can be installed together for married or unmarried A/V switching.

Features

* Matrix size up to 128 x 128 * Handles analog video,

AES/EBU audio and analog audio in blocks of 32 inputs and 32 outputs to form square or rectangular matrix *

Typical audio matrix configuration — I/O 1-32 analog audio in to AES/EBU audio out; I/O 33-64 AES/EBU audio in to analog audio out; I/O 65-96 AES/EBU audio; I/O

97-128 analog audio * Dual references of 525 and 625 allow simultaneous 2-standard vertical interval switching of 60, 59.94 and 50 Hz in blocks of 32 outputs *

Monitoring outputs in blocks of 32 channels. * All plug-in function boards can be hot-swapped for operational convenience * Each signal type can be mapped into

S-BUS space of either 1024 x 1024 with 8 levels, or 1024 x 512 with 16 levels * Up to 2048 Description Names registered in eight alphanumeric characters * 32 name types selectable * Unlimited element groups in tie-line management * Mounts in a 19-inch rack, 14U high

Supplied Accessories

Operation manual (1)

Installation manual (1)

Maintenance manual part 1 (1)

75

Ω terminator (3)

T-bridge (1)

Unit (1)

Optional Accessories

RMM-18DV Rack Slide Kit

RCC-G cables 9-pin/9-pin Cable

Optional Boards

BKDS-AA10 Analog Audio Input Board with

32 channels

BKDS-AA11 Analog Audio Output Board with

32 channels

BKDS-AV10 Analog Video Input Board with 32 channels

BKDS-AV11 Analog Video Output Board with

32 channels

BKDS-DA10 AES/EBU Input Board with 32 channels

BKDS-DA11 AES/EBU Output Board with 32 channels

Optional Software

BZR-2000 Routing Switcher Control Software

Optional Peripherals

BKS-R1617 Multi-Display Control Unit

BKS-R1618 Universal Control Unit

BKS-R3216 Multi-BUS Control Unit

BKS-R3219 Universal Control Unit

BKS-R3220 X-Y Control Unit

BKS-R3240A X-Y Control Unit

BKS-R3242A X-Y Control Unit

BKS-R3248A X-Y Control Unit

BKS-R3280 Single Status Display Unit

BKS-R3281 Single Status Display Unit

17

Rear Panel

*SGC_0011-0038 02.3.16 4:59 PM Page 18

Routing Switchers

Specifications

Control

REMOTE 1:

Standard S-BUS

Connector type: BNC type (3)

Protocol: S-BUS

Transfer speed: 312 kb/s/1250 kb/s

REMOTE 2:

RS-422A

Connector type: D-sub 9-pin female (2)

Protocol: Sony CART+ protocol

Transfer speed: 38.4 kb/s

REMOTE 3:

RS-232C

Connector type: D-sub 9-pin male (1)

Protocol: Terminal/ISR/Data Backup

Transfer speed: 9600 b/s/38.4 kb/s

REMOTE 4:

Monitor S-BUS

Connector type: BNC (1)

Protocol: S-BUS

Transfer speed: 312 kb/s

Video connectors:

BNC type

Inputs return loss:

More than 40 dB DC to 5 MHz

Clamping:

Pedestal clamping or DC coupled

Frequency response:

100 kHz to 10 MHz, +/-0.15 dB

10 MHz to 30 MHz, +0.5/-1.0 dB,

DG:

Less than 0.1%

DP:

Less than 0.1 °

Signal to noise ratio:

More than 73 dB at 5 MHz

Crosstalk:

Less than -60 dB at 5 MHz

Analog audio

Inputs connector:

D-sub 25-pin w/stereo 4 channels by 1 connector

Inputs impedance:

20 k

/600

Ω internally selectable

Max inputs level:

+24 dBm, balanced

Converter:

ADC 48 kHz/20 bits, Linear, AES/EBU digital audio

Frequency response:

20 Hz to 20 kHz, +0.2/-0.3

Distortion:

0.05% or less (1 kHz, reference level,

30 kHz low pass filter)

Signal to noise ratio:

More than 90 dB (30 kHz low pass filter)

Crosstalk:

Less than -90 dB to 15 kHz

Converter:

DAC 48 kHz/20 bits

Maximum output level:

+24 dBm into 600

Ω balanced.

Output impedance:

Approx. 20

Output connector:

D-sub 25-pin w/stereo 4 channels by 1 connector

AES / EBU digital audio

Inputs connector:

BNC type

Signal standards:

AES/EBU specification

75

, unbalanced

SMPTE276M-1995

Television-Transmission of AES/EBU digital audio signals over coaxial cable

Inputs signal level:

1 Vp-p

Max inputs cable length:

600 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

Reference:

Word sync and analog video signal

Outputs connector:

BNC type

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

600 VA max.

Dimensions (W x H x D):

424 x 620 x 550 mm

(16 3/4 x 24 1/2 x 21 3/4 inches)

Mass:

Approx. 40 kg (88.18 lb)

Service parts: Extension board EX-717 (Part No.

A-8323-641-A), Extension board EX-681

(A-8323-641), Maintenance manual Part II,

Protocol Manual

18

*SGC_0011-0038 02.3.16 4:59 PM Page 19

Routing Switchers

DVS-RS1616

RS-422A Remote Routing Switcher

The DVS-RS1616 is a 16 inputs and 16 outputs routing switcher for RS-422A control signals. It can also operate as a 32-port bi-directional router for master/slave applications. Router control is by S-BUS and RS-422A.

S-BUS is a highly sophisticated system, providing communication and tally management with BKS-R Series routing switcher control units, Sony DVS Series video switchers and so on. S-BUS also interfaces with third-party equipment. Among the many features that

S-BUS provides are multi-level working, signal breakaway, phantom operation of crosspoints and tie-line management. Multiple DVS-RS1616 units, fitted with cascade kits, can be connected to form a single matrix as large as 256 x 256. An RS-232C port provides a PC interface for router set up. Router data is maintained in memory by a 24-hour battery backup. The DVS-RS1616 mounts in a standard 19-inch rack and is 8U high.

Features

* 16 x 16 switching matrix for RS-422A control signals *

Expandable to provide a maximum matrix size of 256 x

256 * S-BUS and RS-422A control * Backup power supply and CPU options

Supplied Accessories

AC power cord (for U.S.A and Canada) (1)

AC power cord (for Europe and U.K.) (1)

AC plug adaptor (1)

75

Ω terminators (4)

T-bridge (1)

Plug holder B (black) (1)

Plug holder B (gray) (1)

Operation manual (1)

Maintenance manual (1)

Installation manual (1)

Optional Accessories

RCC-G cables 9-pin/9-pin Cable

RMM-30 Rack Mount Rail

Optional Boards

BKDS-RS1690 Backup Control Board

Optional Peripherals

BKS-R1608 Universal Control Unit

BKS-R1617 Multi-Display Control Unit

BKS-R1618 Universal Control Unit

BKS-R3216 Multi-BUS Control Unit

BKS-R3219 Universal Control Unit

BKS-R3220 X-Y Control Unit

BKS-R3240A X-Y Control Unit

BKS-R3242A X-Y Control Unit

BKS-R3248A X-Y Control Unit

BKDS-RS1691 Backup Power Supply

Specifications

Inputs/outputs

RS-422A input output:

9-pin, complying to RS-422A standards

Reference video signal inputs:

REF IN connectors (BNC type) (2), high impedance, analog video, one is for loop-through connection

Cascade inputs:

CASCADE IN (BKDS-RS1620) 1.27 mm pitch connectors (68-pin type) (7)

Cascade outputs:

CASCADE OUT (BKDS-RS1620) 1.27

mm pitch connectors (68-pin type) (7)

AC power inputs:

3-pin AC connectors (2)

Remote control connectors

REMOTE 1:

S-BUS (BNC type) (4), 47 k

Ω input

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Cable length: 500 m max. (when using a Belden 8281, Fujikura 5C2V or equivalent coaxial cable)

Checksum: HDLC CRC-CCIT x 16 + x 12 + x 5 + 1

Rear Panel

REMOTE 2:

Complying with RS-422A signal standards

D-sub 9-pin (1), 100

/10 k

Data transfer rate: 38.4 kb/s

REMOTE 3:

Complying with RS-232C standard

D-sub 25-pin (1), 9600 b/s, DTR control

8-bit, no parity, no check, 1 stop bit

General

Power requirements:

100 to 240 V AC, 50/60 Hz

1.3 to 0.8 A

Power consumption:

70 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Dimensions (W x H x D):

482 x 354.4 x 450 mm

(19 x 14 x 17 3/4 inches)

(Excluding projecting parts)

Mass:

Approx. 25 kg (55 lb 2 oz)

19

*SGC_0011-0038 02.3.16 4:59 PM Page 20

Routing Switchers

DVS-TC3232

Time Code Routing Switcher

The DVS-TC3232 is a 32 inputs and 32 outputs routing switcher for 32 time code signals. Router control is by

S-BUS and RS-422A. S-BUS is a highly sophisticated system, providing communication and tally management with BKS-R Series routing switcher control units, Sony

DVS Series video switchers and so on. S-BUS also interfaces with third-party equipment. Among the many features that S-BUS supports are multi-level working, signal breakaway, phantom operation of crosspoints and tie-line management. Multiple DVS-TC3232 units, fitted with cascade kits, can be connected to form a single matrix as large as 256 x 256.An RS-232C port provides a

PC interface. Router data is maintained in memory by a

24-hour battery backup. The DVS-TC3232 mounts in a standard 19-inch rack and is 8U high.

Features

* 32 x 32 switching matrix for time code signals *

Expandable to provide a maximum matrix size of 256 x

256 * S-BUS and RS-422A control * Backup power supply and CPU options

Supplied Accessories

AC power cord (for U.S.A and Canada) (1)

AC power cord (for Europe and U.K.) (1)

AC plug adaptor (1)

75

Ω terminators (4)

T bridge (1)

Plug holder B (black) (1)

Plug holder B (gray) (1)

Operation manual (1)

Maintenance manual (1)

Installation manual (1)

Optional Boards

BKDS-RS1690 Backup Control Board

Optional Peripherals

BKS-R1608 Universal Control Unit

BKS-R1617 Multi-Display Control Unit

BKS-R1618 Universal Control Unit

BKS-R3216 Multi-BUS Control Unit

BKS-R3219 Universal Control Unit

BKS-R3220 X-Y Control Unit

BKS-R3240A X-Y Control Unit

BKS-R3242A X-Y Control Unit

BKS-R3248A X-Y Control Unit

BKDS-RS1620 Cascade Set

BKDS-RS1691 Backup Power Supply

RCC-R cables Cascade Connection Cable

RCC-G cables 9-pin/9-pin Cable

RMM-30 Rack Mount Rail

Specifications

Inputs/outputs

Time code inputs:

XLR 3-pin, female connectors (32)

Time code outputs:

XLR 4-pin, male connectors (32)

Reference video signal inputs:

REF IN connectors (BNC type) (2), high impedance, analog video, one is for loop-through connection

Cascade inputs:

CASCADE IN (BKDS-RS1620) 1.27 mm pitch connectors (68-pin type) (7)

Cascade outputs:

CASCADE OUT (BKDS-RS1620) 1.27

mm pitch connectors (68-pin type) (7)

AC power inputs:

3-pin AC connectors (2)

Remote control connectors

REMOTE 1:

S-BUS (BNC type) (4), 47 k

Ω input

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Cable length: 500 m max. (When using a Belden 8281, Fujikura 5C2V or equivalent coaxial cable)

Checksum: HDLC CRC-CCIT x 16 + x 12 + x 5 + 1

Rear Panel

REMOTE 2:

Complying with RS-422A signal standards

D-sub 9-pin (1), 100

/10 k

Data transfer rate: 38.4 kb/s

REMOTE 3:

Complying with RS-232C standard for terminal correction

D-sub 25-pin (1)

9600 b/s, DTR control

8-bit, No parity, No check, 1 stop bit

General

Power requirements:

100 to 240 V AC, 50/60 Hz

1.3 to 0.8 A

Power consumption:

70 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Dimensions (W x H x D)

482 x 354.4 x 450 mm

(19 x 14 x 17 3/4 inches)

(Excluding projecting parts)

Mass:

Approx. 25 kg (55 lb 2 oz)

20

*SGC_0011-0038 02.3.16 4:59 PM Page 21

Routing Switchers

BVS-A3232

Analog Audio Routing Switcher

The BVS-A3232 is a 32 inputs and 32 outputs routing switcher for analog audio signals. It can also operate as

16 x 16 two-channel switcher for stereo applications.

Router control is by S-BUS and RS-422A. S-BUS is a highly sophisticated system, providing communication and tally management with BKS-R Series routing switcher control units, Sony DVS Series video switchers and so on.

S-BUS also interfaces with third-party equipment. Among the many features that S-BUS supports are multi-level working, signal breakaway, phantom operation of crosspoints and tie-line management. An RS-232C port provides a PC interface. Router data is maintained in memory by a 24-hour battery backup. The BVS-A3232 mounts into a standard 19-inch rack and is 3U high.

Features

* 32 x 32 switching matrix for analog audio signals *

Transformer I/O * S-BUS and RS-422A control * Backup power supply and CPU options

Supplied Accessories

Operation manual (1)

Installation manual (1)

Maintenance manual (1)

75

Ω terminators (3)

T-bridge (B) (1)

D-sub connector screws (2)

Audio connectors (32)

Optional Accessories

RCC-G cables 9-pin/9-pin Cable

RMM-30 Rack Mount Rail

Optional Peripherals

BKS-R1608 Universal Control Unit

BKS-R1617 Multi-Display Control Unit

BKS-R1618 Universal Control Unit

BKS-R3216 Multi-BUS Control Unit

BKS-R3219 Universal Control Unit

BKS-R3220 X-Y Control Unit

BKS-R3240A X-Y Control Unit

BKS-R3242A X-Y Control Unit

BKS-R3248A X-Y Control Unit

BKS-R3280 Single Status Display Unit

BKS-R3281 Single Status Display Unit

Specifications

Inputs/outputs —

Reference video signal inputs:

REF IN connectors (BNC type) (2), high impedance, analog audio signal, with loop-through output

Remote control connectors

REMOTE 1 A, B, C:

S-BUS (BNC type) (4), 47 k

Ω input

Data transfer method: BI-PHASE

SPACE

Data transfer rate: 312.5 kb/s

Cable length: 500 m max. (When using a Belden 8281, Fujikura 5C2V or equivalent coaxial cable )

Checksum: HDLC CRC-CCIT x 16 + x 12 + x 5 + 1

REMOTE 2:

Complies with RS-422A signal standard with loop-through output

D-sub 9-pin (2), 100

/10 k

Data transfer rate: 38.4 kb/s

REMOTE 3:

Complies with RS-232C signal standard for connecting a terminal

D-sub 25-pin

(Fixed with M2.6 screws) (1)

Terminal:

9600 b/s, DTR control, 8-bit, no parity, no check, 1 stop bit

ISR:

9600 b/s, 7-bit, ODD parity, 1 stop bit

AC power input:

3-pin AC IN connectors (2)

Audio signals

Audio signal inputs:

6-pin connector (16) for 32 inputs

Audio signal outputs:

6-pin connector (16) for 32 outputs

Input impedance:

100 k

/600

(selectable)

Standard input/output level:

+4 dBm

Maximum input level:

+24 dBm

Maximum output level:

+24 dBm (600

Ω load, balanced)

Frequency response:

60.1 dB

(20 kHz to 20 kHz, 1 kHz+4 dBm)

Distortion:

0.01% (20 Hz to 20 kHz, with +24 dBm output)

Crosstalk:

Less than -80 dB (20 Hz to 20 kHz, with

+24 dBm output)

Signal-to-noise ratio:

More than 85 dB

(30 kHz LPF, nominal)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

1.2 to 0.6 A

(With all optional boards installed)

Operating temperature:

5 to 40 °C (41 to 104 °F)

21

Rear Panel

Dimensions (W x H x D):

424 x 132 x 500 mm

(16 3/4 x 5 1/4 x 19 3/4 inches)

Mass:

Approx. 16 kg (35 lb 4 oz)

(With all optional boards installed)

*SGC_0011-0038 02.3.16 4:59 PM Page 22

Routing Switchers

BVS-V3232

Analog Video Routing Switcher

The BVS-V3232 is a 32 inputs and 32 outputs routing switcher for NTSC/PAL composite analog video signals.

Router control is by S-BUS and RS-422A. S-BUS is a highly sophisticated system, providing communication and tally management with BKS-R Series routing switcher control units, Sony DVS Series video switchers and so on.

S-BUS also interfaces with third-party equipment. Among the many features that S-BUS supports are multi-level working, signal breakaway, phantom operation of crosspoints and tie-line management. An RS-232C port provides a PC interface for router set up. Router data is maintained in memory by a 24-hour battery backup. The

BVS-V3232 mounts in a standard 19-inch rack and is 3U high.

Features

* 32 x 32 switching matrix for composite analog video signals * S-BUS and RS-422A control * Backup power supply and CPU options

Supplied Accessories

Operation manual (1)

Installation manual (1)

Maintenance manual (1)

75

Ω terminations (3)

T-bridge (B) (1)

D-sub connector screws (2)

Optional Accessories

RCC-G cables 9-pin/9-pin Cable

RMM-30 Rack Mount Rail

Optional Boards

BKDS-RS1690 Backup Control Board

Optional Peripherals

BKDS-PV3291 Backup Power Supply Unit

BKS-R1608 Universal Control Unit

BKS-R1617 Multi-Display Control Unit

BKS-R1618 Universal Control Unit

BKS-R3216 Multi-BUS Control Unit

BKS-R3219 Universal Control Unit

BKS-R3220 X-Y Control Unit

BKS-R3240A X-Y Control Unit

BKS-R3242A X-Y Control Unit

BKS-R3248A X-Y Control Unit

BKS-R3280 Single Status Display Unit

BKS-R3281 Single Status Display Unit

Specifications

Inputs/outputs —

Reference video signal inputs:

REF IN connectors (BNC type) (2), high impedance, analog video signal, with loop-through output

Remote control connectors

REMOTE 1 A, B, C:

S-BUS (BNC type) (4), 47 k

Ω input

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Cable length: 500 m (when using a

Belden 8281, Fujikura 5C2V or equivalent coaxial cable)

Checksum: HDLC CRC-CCIT x 16 + x 12 + x 5 + 1

REMOTE 2:

Complies with RS-422A signal standard with loop through output

D-sub 9-pin (2), 100

/10 k

Data transfer rate: 38.4 kb/s

REMOTE 3:

Complies with RS-232C signal

Standard for connecting a terminal

D-sub 25-pin

(Fixed with M2.6 screws) (1)

Terminal:

9600 b/s, DTR control

8-bit, No parity, No check, 1 stop bit

ISR:

9600 b/s

7-bit, ODD parity, 1 stop bit

AC power input:

3-pin AC IN connectors (2)

Video signals

DG:

Less than 0.5% (1 Vp-p, 10 to 90%)

DP:

Less than 5° (1 Vp-p, 10 to 90%)

Frequency response:

60.2 dB (100 kHz to 8 MHz)

Crosstalk:

Less than -50 dB (at 5 MHz)

Crosspoint delay:

Less than

61%

(Between two inputs at 4.43 MHz)

Signal-to-noise ratio:

More than 65 dB (5 MHz, low pass)

Input return loss:

More than 42 dB

K factor:

Less than 0.5%

Tilt:

Less than 1%

Output gain stability:

60.1 dB

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

1.2 to 0.6 A

(With all optional boards installed)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions (W x H x D):

424 x 132 x 500 mm

(16 3/4 x 5 1/4 x 19 3/4 inches)

Mass:

Approx. 16 kg (35 lb 4 oz)

(With all optional boards installed)

22

Rear Panel

*SGC_0011-0038 02.3.16 4:59 PM Page 23

Routing Switchers

BKS-R1617

Multi-Display Control Unit

The BKS-R1617 multi-display control unit controls matrix cross points in routers connected to an S-BUS system.

The BKS-R1617 also controls the monitoring output of routers that have this facility. Source and destination switching is performed with 16 buttons. The monitoring signal can also be selected as a destination signal. The shallow depth of the unit makes it easy to accommodate the BKS-R1617 in front of a desk-mounted switcher control panel.

Features

* Router control in S-BUS systems * Fully compliant with expanded S-BUS systems * Source/destination selection by scrolling through source and destination names using the Selector knob * Four-digit display for each select button * Button re-assignment using the Selector knob *

Improved monitor function for the selection of destinations

* Alternate source switching using Chop function *

Sources selectable to levels * Sources searched by category * Access can be restricted to a defined block of crosspoints * Large selector buttons show source and destination name (Status shown by button color) * Several crosspoints switchable with a single button (Phantom function) * Route function for expanded sources * Number of sources and destinations controlled expandable with additional units * Control bridge between RS-422A (cart+ protocol) and S-BUS * Easy ROM update * Single cable connection * Reduced depth helps in desk mounting applications

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-RS1616 RS-422A Remote Routing

Switcher

DVS-TC3232 Time Code Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Specifications

Control signals

REMOTE 1:

S-BUS (BNC type) (1)

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Max. cable length 500 m

(when using Belden 8281, Fujikura

5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

D-sub 9-pin (1)

Data transfer method: Conforms to the

EIA RS-422A Cart+

Data transfer rate: 38.4 kb/s

RS-232C:

D-sub 9-pin male (1)

Data transfer method: 8-bit, no parity, 1 stop bit

Data transfer rate: 19.2 kb/s

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

0.35 A

Operating temperature:

0 to 45 °C (32 to 113 °F)

Dimensions (W x H x D):

440 x 44 x 120 mm

(17 3/8 x 1 3/4 x 4 3/4 inches)

Mass:

Approx. 1.5 kg (3 lb 5 oz)

Rear Panel

23

*SGC_0011-0038 02.3.16 4:59 PM Page 24

Routing Switchers

BKS-R1618

Universal Control Unit

The BKS-R1618 universal control unit controls matrix cross points in routers connected to an S-BUS system.

The BKS-R1618 also controls the monitoring output of routers that have this facility. Source and destination switching is performed with 16 buttons, whose functions are pre-defined with the control terminal connected to the primary station of the S-BUS system. The monitoring signal can also be selected as a destination signal. The shallow depth of the unit makes it easy to accommodate the BKS-R1618 in front of a desk-mounted switcher control panel.

Features

* Router control in S-BUS systems * Fully compliant with expanded S-BUS systems * Free assignment of sources/destinations to each button via BZR-2000 router system set-up software * Improved monitor function for the selection of destinations * Alternate source switching using Chop function * Sources selectable to levels * Large selector buttons show source and destination name

(Status shown by button color) * Several crosspoints switchable with a single button (Phantom function) *

Route function for expanded sources * Number of sources and destinations controlled expandable with additional units * Control bridge between RS-422A (cart+ protocol) and S-BUS * Easy ROM update * Single cable connection

* Reduced depth helps in desk mounting applications

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-RS1616 RS-422A Remote Routing

Switcher

DVS-TC3232 Time Code Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Specifications

Control signal

REMOTE 1:

S-BUS (BNC type) (1)

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Max. cable length 500 m (when using

Belden 8281, Fujikura 5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

D-sub 9-pin (1)

Data transfer method: conforms to the

EIA RS-422A Cart+ protocol

Data transfer rate: 38.4 kb/s

RS-232C:

D-sub 9-pin male (1)

Data transfer method: 8-bit, no parity, 1 stop bit

Data transfer rate: 19.2 kb/s

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

0.20 A

Operating temperature:

0 to 45 °C (32 to 113 °F)

Dimensions (W x H x D):

440 x 44 x 120 mm

(17 3/8 x 1 3/4 x 4 3/4 inches)

Mass:

Approx. 1.5 kg (3 lb 5 oz)

24

Rear Panel

*SGC_0011-0038 02.3.16 5:00 PM Page 25

Routing Switchers

BKS-R3216

Multi-BUS Control Unit

The BKS-R3216 multi-bus control unit controls matrix cross points in routers connected to an S-BUS system.

Any combination of inputs and outputs are controllable with a single ‘take’ button.

Features

* Router control in S-BUS systems * Fully compliant with expanded S-BUS systems * Equipped with eight status display windows, each with eight alpha/ numerical symbols * Shows the sources/destinations/levels at a glance * 1024 destinations or 16 levels can be displayed using the Selector knob * Description name displayed in the Preset window (with 16 alpha/ numerical symbols) *

Three source/destination selection systems available *

BPS (D) Selection (Button-Per-Source or Destination) *

Type plus Number Selection * Key Pad Entry

(Telephone-style keypad for alpha/numeric entry of sources/destinations by name) * Improved monitor function for the selection of destinations * Alternate source switching using Chop function * Sources selectable to levels * Sources searched by category *

Large selector buttons show source and destination name

(Status shown by button color) * Several crosspoints switchable with a single button (Phantom function) *

Route function for expanded sources * Number of sources and destinations controlled expandable with additional units * Control bridge between RS-422A (cart+ protocol) and S-BUS * Easy ROM update * Single cable connection

* Reduced depth helps in desk mounting applications

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-RS1616 RS-422A Remote Routing

Switcher

DVS-TC3232 Time Code Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Specifications

Control signal

REMOTE 1:

S-BUS (BNC type) (1)

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Max. cable length 500 m (when using

Belden 8281, Fujikura 5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

D-sub 9-pin (1)

Data transfer method: Conforms to the

EIA RS-422A Cart+

Data transfer rate: 38.4 kb/s

RS-232C:

D-sub 9-pin male (1)

Data transfer method: 8-bit, no parity, 1 stop bit

Data transfer rate: 19.2 kb/s

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

0.4 A

Operating temperature:

0 to 45 °C (32 to 113 °F)

Dimensions (W x H x D):

440 x 88 x 120 mm

(17 3/8 x 3 1/2 x 4 3/4 inches)

Mass:

Approx.1.5 kg (3 lb 5 oz)

Rear Panel

25

*SGC_0011-0038 02.3.16 5:00 PM Page 26

Routing Switchers

BKS-R3219

Universal Control Unit

The BKS-R3219 universal control unit controls matrix cross points in routers connected to an S-BUS system.

The BKS-R3219 also controls the monitoring output of routers that have this facility. Source and destination switching is performed with 32 buttons, whose functions are pre-defined with the control terminal connected to the primary station of the S-BUS system. The monitoring signal can also be selected as a destination signal. The shallow depth of the unit makes it easy to accommodate the BKS-R3219 in front of a desk-mounted switcher control panel.

Features

* Router control in S-BUS systems * Fully compliant with expanded S-BUS systems * Free assignment of sources/destinations to each button via BZR-2000 Router

System Set-up Software * Improved monitor function for the selection of destinations * Alternate source switching using Chop function * Sources selectable to levels * Large selector buttons show source and destination name

(Status shown by button color) * Several crosspoints switchable with a single button (Phantom function) *

Route function for expanded sources * Number of sources and destinations controlled expandable with additional units * Control bridge between RS-422A (cart+ protocol) and S-BUS * Easy ROM update * Single cable connection

* Reduced depth helps in desk mounting applications

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-RS1616 RS-422A Remote Routing

Switcher

DVS-TC3232 Time Code Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Specifications

Control signal

REMOTE 1:

S-BUS (BNC type) (1)

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Max. cable length 500 m (when using

Belden 8281, Fujikura 5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

D-sub 9-pin (1)

Data transfer method: Conforms to the

EIA RS-422A Cart+

Data transfer rate: 38.4 kb/s

RS-232C:

D-sub 9-pin male (1)

Data transfer method: 8-bit, no parity, 1 stop bit

Data transfer rate: 19.2 kb/s

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

0.25 A

Operating temperature:

0 to 45 °C (32 to 113 °F)

Dimensions (W x H x D):

440 x 44 x 120 mm

(17 3/8 x 1 3/4 x 4 3/4 inches)

Mass:

Approx. 1.5 kg (3 lb 5 oz)

26

Rear Panel

*SGC_0011-0038 02.3.16 5:00 PM Page 27

Routing Switchers

BKS-R3220

X-Y Control Unit

The BKS-R3220 X-Y control unit controls matrix cross points in routers connected to an S-BUS system. Any combination of inputs and outputs, pre-defined with the control terminal, are controllable with a single ‘take’ button. The names of the selected sources and destinations are shown on the front panel displays. The shallow depth of the unit makes it easy to accommodate the BKS-R3220 in front of a desk-mounted switcher control panel.

Features

* Router control in S-BUS systems * Fully compliant with expanded S-BUS systems * Two source/destination selection systems available * BPS (D) Selection

(Button-Per-Source or Destination) * Type plus Number

Selection * Button re-assignment using the Selector knob

* Improved monitor function for the selection of destinations * Alternate source switching using Chop function * Sources selectable to levels * Sources searched by category * Access can be restricted to a defined block of crosspoints * Large selector buttons show source and destination name (Status shown by button color) * Several crosspoints switchable with a single button (Phantom function) * Route function for expanded sources * Number of sources and destinations controlled expandable with additional units * Control bridge between

RS-422A (cart+ protocol) and S-BUS * Easy ROM update

* Single cable connection * Reduced depth helps in desk mounting applications

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-RS1616 RS-422A Remote Routing

Switcher

DVS-TC3232 Time Code Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Specifications

Control signal

REMOTE 1:

S-BUS (BNC type) (1)

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Max. cable length 500 m (when using

Belden 8281, Fujikura 5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

D-sub 9-pin (1)

Data transfer method: Conforms to the

EIA RS-422A Cart+

Data transfer rate: 38.4 kb/s

RS-232C:

D-sub 9-pin male (1)

Data transfer method: 8-bit, no parity, 1 stop bit

Data transfer rate: 19.2 kb/s

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

0.25 A

Operating temperature:

0 to 45 °C (32 to 113 °F)

Dimensions (W x H x D):

440 x 44 x 120 mm

(17 3/8 x 1 3/4 x 4 3/4 inches)

Mass:

Approx. 1.5 kg (3 lb 5 oz)

Rear Panel

27

*SGC_0011-0038 02.3.16 5:00 PM Page 28

Routing Switchers

BKS-R3240A

X-Y Control Unit

The BKS-R3240A X-Y control unit controls matrix cross points in routers connected to an S-BUS system. Any combination of inputs and outputs, pre-defined with the control terminal, are controllable with a single ‘take’ button. The names of the selected sources and destinations are shown on the front panel displays. The shallow depth of the unit makes it easy to accommodate the BKS-R3240A in front of a desk-mounted switcher control panel.

Features

* Router control in S-BUS systems * Fully compliant with expanded S-BUS systems * Compact 1U, 19-inch rack mounting design * Four display modes — Type plus

Number display, Description Name display, 4-digit display, and Level display * Three source/destination selection systems available * BPS (D) Selection (Button-Per-Source or Destination) * Type plus Number Selection * Key Pad

Entry (Telephone-style keypad for alpha/numeric entry of sources/destinations by name) * Eight GPI I/O terminals standard * Alternate source switching using Chop function

* Sources selectable to levels * Large selector buttons show source and destination name (Status shown by button color) * Several crosspoints switchable with a single button (Phantom function) * Route function for expanded sources * Number of sources and destinations controlled expandable with additional units * Control bridge between RS-422A (cart+ protocol) and S-BUS *

Easy ROM update * Single cable connection * Reduced depth helps in desk mounting applications

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-RS1616 RS-422A Remote Routing

Switcher

DVS-TC3232 Time Code Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Specifications

Control signal

REMOTE 1:

S-BUS (BNC type) (1)

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Max. cable length 500 m (when using

Belden 8281, Fujikura 5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

D-sub 9-pin (1)

Data transfer method: Conforms to the

EIA RS-422A Cart+

Data transfer rate: 38.4 kb/s

RS-232C:

D-sub 9-pin male (1)

Data transfer method: 8-bit, no parity, 1 stop bit

Data transfer rate: 19.2 kb/s

GPI I/O:

D-sub 25-pin male (1), D-sub 25-pin female (1)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

0.25 A

Operating temperature:

0 to 45 °C (32 to 113 °F)

Dimensions (W x H x D):

440 x 44 x 120 mm

(17 3/8 x 1 3/4 x 4 3/4 inches)

Mass:

Approx. 1.5 kg (3 lb 5 oz)

Rear Panel

28

*SGC_0011-0038 02.3.16 5:00 PM Page 29

Routing Switchers

BKS-R3242A

X-Y Control Unit

The BKS-R3242A X-Y control unit controls matrix cross points in routers connected to an S-BUS system. Any combination of inputs and outputs, pre-defined with the control terminal, are controllable with a single “take” button. The names of the selected sources and destinations are shown on the front panel displays.

Source and destination switching is performed with 16/32 buttons. The monitoring signal can also be selected as a destination signal.

Features

* Router control in S-BUS systems * Fully compliant with expanded S-BUS systems * Compact 2U, half 19-inch rack width design * Four display modes: Type plus

Number display, Description Name display, 4-digit display, and Level display * Three source/destination selection systems available * BPS (D) Selection (Button-Per-Source or Destination) * Type plus Number Selection * Key Pad

Entry (Telephone-style keypad for alpha/numeric entry of sources/destinations by name) * Eight GPI I/O terminals standard * Alternate source switching using Chop function

* Sources selectable to levels * Large selector buttons show source and destination name (Status shown by button color) * Several crosspoints switchable with a single button (Phantom function) * Route function for expanded sources * Number of sources and destinations controlled expandable with additional units * Control bridge between RS-422A (cart+ protocol) and S-BUS *

Easy ROM update * Single cable connection * Reduced depth helps in desk mounting applications

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-RS1616 RS-422A Remote Routing

Switcher

DVS-TC3232 Time Code Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Specifications

Control signal

REMOTE 1:

S-BUS (BNC type) (1)

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Max. cable length 500 m (when using

Belden 8281, Fujikura 5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

D-sub 9-pin (1)

Data transfer method: Conforms to the

EIA RS-422A Cart+

Data transfer rate: 38.4 kb/s

RS-232C:

D-sub 9-pin male (1)

Data transfer method: 8-bit, no parity, 1 stop bit

Data transfer rate: 19.2 kb/s

GPI I/O:

D-sub 25-pin male (1), D-sub 25-pin female (1)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

0.25 A

Operating temperature:

0 to 45 °C (32 to 113 °F)

Dimensions (W x H x D):

220 x 88 x 120 mm

(17 3/8 x 1 3/4 x 4 3/4 inches)

Mass:

Approx. 1.5 kg (3 lb 5 oz)

Rear Panel

29

*SGC_0011-0038 02.3.16 5:00 PM Page 30

Routing Switchers

BKS-R3248A

X-Y Control Unit

The BKS-R3248A X-Y control unit controls matrix cross points in routers connected to an S-BUS system. Any combination of inputs and outputs, pre-defined with the control terminal, are controllable with a single ‘take’ button. Source and destination switching is performed with

32 buttons The shallow depth of the unit makes it easy to accommodate the BKS-R3248 in front of a desk-mounted switcher control panel.

Features

* Router control in S-BUS systems * Fully compliant with expanded S-BUS systems * Compact 2U, 19-inch rack mounting design * Four display modes: Type plus Number display, Description Name display, 4-digit display, and

Level display * Three source/destination selection systems available * BPS (D) Selection (Button-Per-Source or

Destination) * Type plus Number Selection * Key Pad

Entry (Telephone-style keypad for alpha/numeric entry of sources/destinations by name) * Eight GPI I/O terminals standard * Alternate source switching using Chop function

* Sources selectable to levels * Large selector buttons show source and destination name (Status shown by button color) * Several crosspoints switchable with a single button (Phantom function) * Route function for expanded sources * Number of sources and destinations controlled expandable with additional units * Control bridge between RS-422A (cart+ protocol) and S-BUS *

Easy ROM update * Single cable connection * Reduced depth helps in desk mounting applications

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-RS1616 RS-422A Remote Routing

Switcher

DVS-TC3232 Time Code Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Specifications

Control signal

REMOTE 1:

S-BUS (BNC type) (1)

Data transfer method: BI-PHASE SPACE

Data transfer rate: 312.5 kb/s

Max. cable length 500 m (when using

Belden 8281, Fujikura 5C2V or equivalent 75

Ω coaxial cable).

Expandable to 1000 m with a

BKPF-L803 S-BUS Isolator/Expander

REMOTE 2:

D-sub 9-pin (1)

Data transfer method: Conforms to the

EIA RS-422A Cart+

Data transfer rate: 38.4 kb/s

RS-232C:

D-sub 9-pin male (1)

Data transfer method: 8-bit, no parity, 1 stop bit

Data transfer rate: 19.2 kb/s

GPI I/O:

D-sub 25-pin male (1), D-sub 25-pin female (1)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current consumption:

0.35 A

Operating temperature:

0 to 45 °C (32 to 113 °F)

Dimensions (W x H x D):

440 x 88 x 120 mm

(17 3/8 x 1 3/4 x 4 3/4 inches)

Mass:

Approx. 2.1 kg (4 lb 10 oz)

Rear Panel

30

*SGC_0011-0038 02.3.16 5:00 PM Page 31

Routing Switchers

BKS-R3280

Single Status Display Unit

The BKS-R3280 is single status display unit showing alphabetic and numeric characters with bright, seven-segment, amber displays. The BKS-R3280 displays up to seven characters. Connected to a standard

S-BUS or the monitor S-BUS data link, it shows router switching status. The unit can also display preset character strings from external equipment connected to the D-sub 25-pin parallel control TALLY connector.

BKS-R3280 can be mounted in a standard 19-inch rack and are 1U high.

Features

* Signal information display in router systems * Display of source, destination, source line number and source status

* Large displays with four-step brightness control * PGM and PST tally indication * S-BUS or parallel control

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V1201 Analog Video Routing Switcher

BVS-V1212 Analog Video Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-V1201 Digital Video Routing Switcher

DVS-V1616 Digital Video Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Tally label (1)

AC plug adapter (1)

AC power cords (2)

Specifications

Inputs/outputs —

Parallel control:

INPUT connector (D-sub 25-pin type)

(1)

3 to 24 V DC

Low: 0.0 to 0.6 V

High: 3.0 V and higher

Control signal:

REMOTE (BNC type) (1), S-BUS

Data transfer method:

BI-PHASE SPACE

Data transfer rate:

312.5 kb/s

Cable length:

500 m max. (when using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

11 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions (W x H x D):

483 x 44 x 150 mm

(19 1/8 x 1 3/4 x 6 inches)

Mass:

Approx. 2.4 kg (5 lb 5 oz)

31

Rear Panel

*SGC_0011-0038 02.3.16 5:00 PM Page 32

Routing Switchers

BKS-R3281

Single Status Display Unit

BKS-R3281 is single status display unit showing alphabetic and numeric characters with bright, seven-segment, amber displays. The BKS-R3281 displays up to 16 characters, enabling it to show both source and destination information simultaneously.

Connected to a standard S-BUS or the monitor S-BUS data link, it shows router switching status. The unit can also display preset character strings from external equipment connected to the D-sub 25-pin parallel control

TALLY connector. BKS-R3281 can be mounted in a standard 19-inch rack and are 1U high.

Features

* Signal information display in router systems * Display of source, destination, source line number and source status

* Large displays with four-step brightness control * PGM and PST tally indication * S-BUS or parallel control

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V1201 Analog Video Routing Switcher

BVS-V1212 Analog Video Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-128 Routing Switcher

DVS-V1201 Digital Video Routing Switcher

DVS-V1616 Digital Video Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

Supplied Accessories

Operation and maintenance manual (1)

BNC T-bridge connector (1)

Tally label (1)

AC plug adapter (1)

AC power cords (2)

Specifications

Inputs/outputs —

Parallel control:

INPUT connector (D-sub 25-pin type)

(1)

3 to 24 V DC

Low: 0.0 to 0.6 V

High: 3.0 V and higher

Control signal:

REMOTE (BNC type) (1), S-BUS

Data transfer method:

BI-PHASE SPACE

Data transfer rate:

312.5 kb/s

Cable length:

500 m max. (when using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

20 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions (W x H x D):

483 x 44 x 150 mm

(19 1/8 x 1 3/4 x 6 inches)

Mass:

Approx. 2.5 kg (5 lb 10 oz)

32

BKS-R3280

BKS-R3280

Rear Panel

*SGC_0011-0038 02.3.25 10:07 AM Page 33

Routing Switchers

HKSP-R80

Routing Switcher Controller

The HKSP-R80 routing switcher controller is a stand-alone primary station CPU board for Sony routing switchers. With the HKSP-R80 installed in a PFV-SP

Series signal processing unit, a range of features is provided in addition to the primary functions of S-BUS

SUB-NET control and conversion between S-BUS and

Ethernet LAN. For CPU redundancy, the HKSP-R81 is available.

Features

*Provides primary station control or sub-net control in an

S-BUS system *Networking applications — Setting, controlling and up/downloading files from PC with

BZR-2000 routing switcher control software via a

10/100Base-T Ethernet based LAN/Internet;

10/100Base-T Ethernet based remote control; Can be accessed by up to 16 users; S-BUS and Ethernet conversion for S-BUS logging function; Supports SNMP

Remote Maintenance protocol *HKSP-R81 routing switcher backup CPU — Hot-swappable *RS-422A and

RS-232C connections *Supplied software — BZR-IF810

S-BUS SUB-NET Control Software; BZR-20 Routing

Switcher Backup Software; BZR-21 Router Remote

Control Software

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Operation manual (1)

Installation manual (1)

CD-ROM (1) (BZR-20 Data Backup Program /

BZR-21 Router Remote Control Software /

BZR-IF810 S-BUS SUB-NET Control Software)

75

Ω terminations (3)

T-bridge (1)

Optional Board

HKSP-R81 Routing Switcher Backup CPU

Optional Software

BZR-2000 Routing Switcher Control Software

Specifications

Remote —

Remote 1: S-BUS

Connectors:

BNC type (3)

Transfer speed:

312 Kb/s / 1250 Kb/s

Signal level:

1.8 V+/- 0.3 V (75

),

1.1 V+/- 0.3 V (75

)

Remote 2: RS-422A

Connectors:

D-SUB 9-pin female (2)

Protocol:

CART++

Transfer speed:

38.4 Kb/s

Remote 3: RS-2342C

Connector type:

D-SUB 9-pin male (1)

Transfer speed:

38.4 Kb/s

DATA LAN: Ethernet

Connector:

RJ-45 (1), 10BASE-T / 100BASE-TX

TIME CODE

Connector:

BNC type (1)

General

Power requirement:

12 V (Supplied from the PFV-SP Series signal processing unit)

Power consumption:

1000 mA (HKSP-R80)

700 mA (HKSP-R81)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90%

Dimensions

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector panel (W x H x D):

130 x 152.5 x 38 mm

(5 1/8 x 6 1/8 x 1 1/2 inches)

Mass:

Approx. 900 g (1 lb 16 oz)

33

Rear Panel

*SGC_0011-0038 02.3.16 5:00 PM Page 34

Routing Switchers

BKPF-R70A

Routing Switcher Controller Board

The BKPF-R70A routing switcher controller board functions as the primary station of Sony S-BUS remote control system. It has the same control functionality as the CPU board for the Sony digital routing switchers when this is used as the primary station in a system, but with improved overall system and tally response. It can also function as a sub-net controller with BZR-IF310 software installed. In a system that includes BKPF-300 Series boards, the BKPF-R70A improves the functionality and mapping of these boards.

Features

* Provides primary station control or sub-net control in an

S-BUS system * Fully compliant with expanded S-BUS systems * 1024 x 1024 x 8 levels or 1024 x 512 x 16 levels * supports 32 types of signal names and 2048 description names * Dual control, S-BUS and RS-422 *

System redundancy using two BKPF-R70A boards *

Routing switcher back-up software supplied * Supports

ISR

The BKPF Series function boards install in both the PFV-D and the PFV-HD

Series Interface Units. In a PFV-HD Series Interface Unit, they can be installed together with the HKPF Series function boards.

Applicable Models

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

PFV-HD50A HD Digital Video Interface Unit

Supplied Accessories

Operation manual (1)

Installation manual (1)

Slot number label (1)

Routing switcher data backup software

BZR-20 (1)

Optional Software

BZR-IF310 S-BUS SUB-NET Controller

Software

Specifications

General

Power requirements:

+5 V DC (supplied from the

PFV-D/PFV-HD Series Interface Unit)

Current consumption:

700 mA

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90 %

Dimensions (H x W)

Board:

195 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel:

195 x 25 mm

(7 3/4 x 1 inches)

Mass

Board:

Approx. 520 g (1 lb 2 oz)

Connector panel:

Approx. 160 g (6 oz)

Rear Panel

34

*SGC_0011-0038 02.3.16 5:00 PM Page 35

Routing Switchers

BKS-R5001

S-BUS Interface Board

The BKS-R5001 is an S-BUS interface board for installation in an IBM PC/AT compatible machine running

BZR-2000 Routing Switcher Control Software. This

S-BUS interface board allows control of HDS-X Series routing switcher systems from a PC with BZR-2000 software installed.

Applicable Models

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-K5800 Multi Bit-Rate Routing Switcher

DVS-128 Routing Switcher

BKPF-R70A Routing Switcher Controller Board

HKSP-R80 Routing Switcher Controller

35

Rear Panel

*SGC_0011-0038 02.3.16 5:00 PM Page 36

Routing Switchers

BZR-2000

Routing Switcher Control Software

BZR-2000 software is “the complete router control kit”, allowing full configuration, operation and maintenance of an S-BUS system from a single PC terminal. Operating using Windows 95®, Windows98®, Windows2000® or

Windows NT™, the software provides multiple graphic display windows for easy operation and management. A full drag-and-drop facility for the configuration of different routing system devices, allows multiple data bases to be saved for alternative configurations. This feature is particularly useful when the facilities of an OB vehicle are regularly used for several different series of productions.

BZR-2000 can be interfaced to a routing switcher either via an Ethernet, RS-232 terminal of a PC, or as a secondary station using an optional BKS-R5001 S-BUS interface board installed in the same PC. An optional

BKV-100 overlay board installed in the PC provides in-picture monitoring of sources and destinations within the routing system.

Features

* Installs in a PC for rapid setting up and on-line status monitoring of a Sony routing system * Operates on a PC running Windows 95/98 or Windows NT/2000® * Full on-line and off-line modes * Allows for the saving of multiple data bases for different system configurations *

Drag-and-drop operation * Multiple window operation *

Restricted user access via various system rights *

Operates via an Ethernet, RS-232C or using a

BKS-R5001 S-BUS board mounted in a PC * Optional

BKV-100 PC overlay board for monitoring of routing system sources and destinations

Applicable Models

DVS-128 Routing Switcher

HDS-X3400 Multi Bit-Rate Routing Switchers

HDS-X3600 Multi Bit-Rate Routing Switchers

HDS-X3700 Multi Bit-Rate Routing Switchers

HDS-X5800 Multi Bit-Rate Routing Switcher

BKPF-R70A Routing Switcher Controller Board

HKSP-R80 Routing Switcher Controller

Optional Board

BKS-R5001 S-BUS Interface Board

Specifications

Note:

BZR-2000 supports the following Sony routing switchers and control panels.

Routing Switchers

* Used as a primary station:

HDS-X5800/HDS-X3700/X3600/X3400,

DVS-128, BKPF-R70A, HKSP-R80

* Used as a secondary station:

HDS-X5800/X3700/X3600/X3400,

DVS-128/RS1616/TC3232,

BVS-V3232/A3232

,BKPF-300/301/350/351, BKDS-7700,

BZR-IF310.

Control Panels

* Used as a secondary station:

BKS-R3280/3281,

BKS-R1617/R3216/R3219 (Firmware

V1.03 and higher),

BKS-R1618/R3220,

BKS-R3240A/R3242A/R3248A

36

*SGC_0011-0038 02.3.16 5:00 PM Page 37

Routing Switchers

BZR-IF310

S-BUS SUB-NET Controller Software

BZR-IF310 S-BUS sub-net controller software installs in the BKPF-R70A routing switcher controller board.

BZR-IF310 not only expands the capability of an S-BUS network to interface with a large number of devices, but also provides the advantages of sub-net topology in creating a powerful, fast and convenient network operating environment.

Features

* Installs in a BKPF-R70A routing switcher controller board to form the S-BUS sub-net controller * Major increase in the number of devices that an S-BUS network can accommodate * 253 sub-nets can be constructed within an S-BUS network * Each sub-net can connect to as many as 253 control units * Provides a highly flexible and reliable decentralized control environment * Bus protection in a primary station common with sub-net stations * Improves response time by decentralizing communication load * Compliant with centralized network set-up and data management * The complete network can be set up via the primary station while the sub-net can be set up via the S-BUS sub-net controller (BKPF-R70A with

BZR-IF310 installed) * Redundant operation available

Applicable Models

BKPF-R70A Routing Switcher Controller Board

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

PFV-HD50A HD Digital Video Interface Unit

37

*SGC_0011-0038 02.3.16 5:00 PM Page 38

Routing Switchers

38

*SGC_0039-0040 02.3.16 5:01 PM Page 39

Cables

ECD-C cables . . . . . . . . . . . . 40

ECD-10C. . . . . . . . . . . . . . . . 40

ECD-30C. . . . . . . . . . . . . . . . 40

ECD-3C. . . . . . . . . . . . . . . . . 40

RCC-R cables . . . . . . . . . . . . 40

RCC-5R . . . . . . . . . . . . . . . . 40

39

*SGC_0039-0040 02.3.16 5:01 PM Page 40

Cables

ECD-C cables

XLR-3-Pin Type - XLR-3-Pin Type Digital Audio

Interface Cable

ECD-10C

ECD-30C

ECD-3C

Applicable Models

BKPF-205 Audio/Video Multiplexer Board

BKPF-206 Audio/Video Demultiplexer Board

Specifications

ECD-3C:

3m (10 ft)

ECD-10C:

10m (33 ft)

ECD-30C:

30m (100 ft)

RCC-R cables

Cascade Connection Cable

RCC-5R

Applicable Models

DVS-TC3232 Time Code Routing Switcher

Specifications

RCC-5R

5m

40

*SGC_0041-0042 02.3.16 5:01 PM Page 41

Common Accessories

RMM-30 . . . . . . . . . . . . . . . . 42

41

*SGC_0041-0042 02.3.16 5:01 PM Page 42

Common Accessories

RMM-30

Rack Mount Rail

The RMM-30 is a rack mount rail designed to mount audio/video equipment into a 19-inch standard rack, and allow the equipment to be pulled forward for servicing access. The RMM-30 consists of a pair of rails (each rail having an inner and an outer rail), a stopper and a bracket. The pair of inner rails are fixed to the unit, while the pair of outer rails are fixed to the 19-inch rack. The inner rails are then slid into the outer rails. Equipment that satisfies the following conditions can be mounted in an equipment rack that has a depth of 660 to 830 mm (26 to 32 3/4 inches):Mass—less than 40 kg (88 lb 3 oz)Width between rail mounting surfaces —424 mm (16 3/4 inches)Includes appropriate fixing holes.

Applicable Models

BVS-A3232 Analog Audio Routing Switcher

BVS-V3232 Analog Video Routing Switcher

DVS-RS1616 RS-422A Remote Routing

Switcher

DVS-TC3232 Time Code Routing Switcher

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

PFV-HD50A HD Digital Video Interface Unit

42

*SGC_0043-0068 02.3.16 5:02 PM Page 43

Interface Processor SP Series

PFV-SP3100 . . . . . . . . . . . . . 44

PFV-SP3300 . . . . . . . . . . . . . 45

HKSP-008HD . . . . . . . . . . . . 46

HKSP-061M . . . . . . . . . . . . . 48

HKSP-105 . . . . . . . . . . . . . . . 50

HKSP-106 . . . . . . . . . . . . . . . 52

HKSP-300 . . . . . . . . . . . . . . . 54

HKSP-525 . . . . . . . . . . . . . . . 55

HKSP-313 . . . . . . . . . . . . . . . 57

HKSP-1125 . . . . . . . . . . . . . . 59

HKPF-SP003 . . . . . . . . . . . . . 61

HKPF-SP021 . . . . . . . . . . . . . 63

HKPF-SP022 . . . . . . . . . . . . . 65

UCP-8060 . . . . . . . . . . . . . . . 67

43

*SGC_0043-0068 02.3.19 0:12 AM Page 44

Interface Processor SP Series

PFV-SP3100

Signal Processing Unit

The PFV-SP3100 is a 1RU signal processing unit that accommodates up to four HKSP/HKPF-SP Series function boards with a redundant power supply. With an HKSP-300 processing module controller installed, PFV-SP Series processing boards can be managed via a LAN 100Base-T

Ethernet network.

Features

*Compact, high-density mounting frame for HKSP and

HKPF-SP function boards *1RU high frame, fitting a

19-inches rack unit — Houses up to 4 HKSP/HKPF-SP

Series function boards; Internal forced-air cooling

*Accommodates a range of modules for multi-format, multi bit-rate compliant applications — Ideal migration path from SD to HD; Both HD tri-level sync and black burst signal can be used *Networking applications — Enables the setting, controlling, and up/downloading of the set-up data of other HKSP function boards in a PFV-SP Series signal processing unit when used in combination with a

UCP-8060 universal control panel connected via a

Ethernet 100Base-TX based network (When HKSP-300 installed) *Reference input to supply reference signal to installed function boards *High reliability and ease of maintenance — Optional hot-swappable back-up power supply; Front panel status indication of power supply units, frame and module boards; Rear panel Status Out connector

Supplied Accessories

Operation manual (1)

Installation manual (1)

Optional Boards

HKPF-SP003 Digital Video Distribution Amp

HKPF-SP021 Optical to Electrical Converter

HKPF-SP022 Electrical to Optical Converter

HKSP-008HD HD Frame/Line Synchronizer

HKSP-061M 8 x 4 Digital Video Selector

HKSP-105 HD Audio/Video Multiplexer Board

HKSP-106 HD Audio/Video Demultiplexer

Board

HKSP-1125 HD Up-converter Board

HKSP-300 Processing Module Controller

HKSP-313 HD Color Corrector Board

HKSP-525 Down Converter Board

HKSP-R80 Routing Switcher Controller

HKSP-R81 Routing Switcher Backup CPU

UCP-8060 Universal Control Panel

Optional Peripherals

HK-PSU01 Power Supply Unit

Specifications

Inputs/outputs

Remote:

S-BUS remote connector (BNC type) (1)

SYNC inputs:

HD tri-level sync or black burst signal

(BNC type) (2) (with loop-through outputs)

Status output:

STATUS OUT

(mini D-sub 15-pin, female) (1)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power supply capacity:

+12 V DC: Max 4.4 A

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions (W x H x D):

440 x 43.2 x 550 mm

(21 3/4 x 1 3/4 x 17 3/8 inches)

Service part: Maintenance manual

44

*SGC_0043-0068 02.3.19 0:12 AM Page 45

Interface Processor SP Series

PFV-SP3300

Signal Processing Unit

The PFV-SP3300 is a 3 RU signal processing unit that accommodates up to 17 processing modules that are compliant with multi-format and multi bit-rate operation. It has two reference inputs for SD and HD signals. With an

HKSP-300 processing module controller installed, PFV-SP

Series processing boards can be managed via a LAN

100Base-T Ethernet

Features

*Compact and high-density mounting frame for HKPF-SP and HKSP processing modules — Compact 3 RU height size frame, fitting a 19-inches rack unit; Houses up to 17

HKPF-SP/HKSP Series modular boards; Internal forced-air cooling *Accommodates a range of modules for multi-format, multi bit-rate compliant applications — Ideal migration path from SD to HD; Both HD tri-level sync and black burst signal can be used *Networking applications

— Enables the setting, controlling, and up/downloading of the set-up data of other HKSP function boards in a

PFV-SP Series signal processing unit when used in combination with a UCP-8060 universal control panel connected via a Ethernet 100Base-TX based network

(When HKSP-300 installed) *High reliability and ease of maintenance — Optional hot-swappable back-up power supply; Front panel status of power supply units, frame and module boards; Rear panel STATUS OUT connector

Supplied Accessories

Operation manual (1)

Installation manual (1)

Optional Boards

HKPF-SP003 Digital Video Distribution Amp

HKPF-SP021 Optical to Electrical Converter

HKPF-SP022 Electrical to Optical Converter

HKSP-008HD HD Frame/Line Synchronizer

HKSP-061M 8 x 4 Digital Video Selector

HKSP-105 HD Audio/Video Multiplexer Board

HKSP-106 HD Audio/Video Demultiplexer

Board

HKSP-1125 HD Up-converter Board

HKSP-300 Processing Module Controller

HKSP-313 HD Color Corrector Board

HKSP-525 Down Converter Board

HKSP-R80 Routing Switcher Controller

HKSP-R81 Routing Switcher Backup CPU

UCP-8060 Universal Control Panel

Optional Peripherals

HK-PSU03 Backup Power Supply Unit

Specifications

Inputs/outputs

Remote:

S-BUS remote connector (BNC type) (1)

SYNC inputs:

HD tri-level sync or black burst signal

(BNC type) (2) (with loop-through outputs)

Status output:

STATUS OUT (mini D-sub 15-pin, female) (1)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Current drain

100 V AC: Max 3.5 A, 240 V AC: Max

1.5 A

Power supply capacity:

+12 V DC: Max 18.7 A

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions (W x H x D):

440 x 550 x 132.4 mm

(5 1/4 x 21 3/4 x 17 3/8 inches)

Mass:

Approx. 10 kg (22 lb 1 oz) (Not including optional boards)

Service part: Maintenance manual

Rear Panel

45

*SGC_0043-0068 02.3.16 5:02 PM Page 46

Interface Processor SP Series

HKSP-008HD

HD Frame/Line Synchronizer

The HKSP-008HD frame/line synchronizer board synchronizes the input HDTV video signal to an external reference. One equalized input, three distribution outputs and one black burst or tri-level sync reference input with passive loop-through output are provided. Three types of operation mode are selectable. When an error in the input signal is detected, a variety of freeze functions are available.

Features

*HD frame/line synchronizer with three modes of operation — Frame Synchronization mode; Line

Synchronization mode; Delay Line mode *Supports a wide range of video standards — 1080/60i, 59.94i, 50i;

1035/60i, 59.94i; 1080/30P, 29.97P, 25P, 24P, 23.976P

*Freeze function when an error is detected in the input signal — Auto/Manual Freeze selectable; Field/Frame

Freeze selectable *Passes eight channels of embedded audio and other ancillary data on VBI — Automatically mutes embedded audio when picture frozen; 20-bit audio sample rate conversion in Frame Synchronization mode;

Variable audio delay in Frame Synchronization mode

*H/V phase adjustment available in Frame

Synchronization mode *By-pass mode selectable

*Built-in test Signal Generator *Local and remote status monitoring and set up *Remotely controllable from an optional HKDV-503/900 Digital Video Controller via a

RS-422 (GPI also provided) or UCP-8060 Universal

Control Panel (Ethernet 100BASE-TX)

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Installation manual (1)

Installation guide (1)

Front Panel Rear Panel

46

*SGC_0043-0068 02.3.16 5:02 PM Page 47

Interface Processor SP Series

Specifications

Inputs/outputs

Video standard:

1035/60, 59.94i

1080/60, 59.94i, 50i

1080/30PsF, 29.97PsF, 25PsF, 24PsF,

23.976PsF

HD component serial digital signal (HD

SDI):

Conforming to SMPTE-292M

1.485/1001, 1.485 Gb/s

Serial digital video input:

SDI IN connector (BNC type) (1)

Reference input:

REF IN connector (BNC type) (1)

0.43 Vp-p

610%, 75

Black Burst or Tri-level sync signal

Serial digital video outputs:

SDI OUT connector (BNC type) (3)

0.8 Vp-p

610%, 75

Reference output:

Passive loop-through output connector

(BNC type) (1)

GPI:

REMOTE connector (Mini D-sub 15-pin)

(1)

General

Power requirements:

+12 V DC: 1.7 A

(Supplied from PFV-SP Series Signal

Processing Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector Panel (H x D x W):

130 x 152.5 x 38 mm

(5 1/8 x 6 1/8 x 3/4 inches)

Mass

Board:

Approx. 680 g (1 lb 8 oz)

Connector Panel:

Approx. 300 g (11 oz)

Service part: Maintenance manual

HD SDI IN

REF IN

PASSIVE LOOP-THROUGH

Frame Sync

Line Sync

Delay Line

CLK Frame

Memory

REF CPU Bus

HD SDI OUT 1

HD SDI OUT 2

HD SDI OUT 3

REMOTE

47

*SGC_0043-0068 02.3.16 5:02 PM Page 48

Interface Processor SP Series

HKSP-061M

8 x 4 Digital Video Selector

The HKSP-061M digital video selector board features 8 inputs x 4 outputs and can route serial digital signals at up to 1.5 Gb/s without any setting changes. A variety of matrix configurations are available.

Features

* Multi bit-rate transmission; Auto bit-rate detection, SD

SDI signals at 143, 177, 270, 360 and 540 Mb/s, HD SDI signal at 1.5 Gb/s *Auto re-clocking function; Reduces output signal jitter, Automatic switching with bit rate of input signal, Re-clocking on/off switchable *Auto cable equalization of up to 100 m of coaxial cable *Excellent configuration flexibility for a wide range of applications;

One 8 x 4 matrix or one 8 x 2 matrix and two distribution outputs, Two 4 x 2 matrices or two 4 x 1 matrices and two distribution outputs, Four 2 x 1 matrices, Expandable to

16 x 8 by cascade connecting two units *Powerful matrix control function via Sony S-BUS remote interface; S-BUS connections with BKS-R Series control panels to form a simple primary station for signal switching *Synchronized switching with external reference signal; Provides both black burst and tri-level sync signal *Retains crosspoint data to restore setting after power-off *Remote status monitoring, plus local monitoring with front panel LED

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Install guide (1)

Install manual (1)

Expansion harness (1)

Front Panel Rear Panel

48

*SGC_0043-0068 02.3.16 5:02 PM Page 49

Interface Processor SP Series

Specifications

- Inputs/outputs -

Serial digital video input:

SDI in connectors (BNC type) (8)

Data transfer rates:

143 Mb/s to 1.485 Gb/s

Input signal:

Scrambled NRZI, 0.8 Vp-p

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 1.485 GHz)

Cable length:

100 m max. (When using a 5C-FB cable (Fujikura) or Belden 1694 coaxial cable or the equivalent is used)

Reference inputs:

Supplied through the REF IN connectors on the PFV-SP Series signal processing units

REF IN connectors (BNC type) (2)

Black Burst or Tri-level sync signal

Serial digital video output:

SDI out connectors (BNC type) (4)

Data transfer rates:

143 Mb/s to 1.485 Gb/s

Re-clock bit rates:

143, 177, 270, 360, 540 Mb/s:

1.485/1.001, 1.485 Gb/s

Output amplitude:

0.8 Vp-p

610%

Rise/fall time:

270 ps or less

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

Remote:

S-BUS (BNC type) (1)

Data transfer rates:

312.5 kb/s

- General -

Power requirements:

+12 V DC: 2.0 A

Operating temperature:

5 to 40 °C (41 to +104 °F)

Storage temperature:

-20 to 60 °C (-4 to 104 °C)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector panel (W x H x D):

130 x 152.5 x 38 mm

(5 1/8 x 6 1/8 x 1 1/2 inches)

Mass

Board:

Approx. 450 g (16 oz)

Connector panel:

Approx. 300 g (11 oz)

Service part: Maintenance manual

INPUT

SDI IN x 8

REMOTE

S-BUS

REF A

REF B

CPU

EXPAND IN

RECLOCK

RECLOCK

RECLOCK

RECLOCK

SDI OUT 1

SDI OUT 2

SDI OUT 3

SDI OUT 4

EXPAND OUT

INT DATA BUS

49

*SGC_0043-0068 02.3.25 10:10 AM Page 50

Interface Processor SP Series

HKSP-105

HD Audio/Video Multiplexer Board

The HKSP-105 is a video/audio multiplexer board that multiplexes four AES/EBU format digital audio signals (8 channels) with an HD SDI video signal. Two outputs of the multiplexed signal are provided. By cascading two

HKSP-105 boards, a further four AES/EBU signals can be multiplexed onto one HD SDI signal, making a total of eight pairs/sixteen channels.

Features

*Multiplexes four AES/EBU signals with an HD SDI signal

*Audio delay adjustable (maximum two video frames)

*Auto selection of HD multi-format *Remotely controllable from an optional UCP-8060 Universal Control Panel

(Ethernet 100BASE-TX) *Masks and retains of HANC area and embedded audio data *Transfers UMID and

VITC data *Provides simplified Signal Generator

*External reference input (PFV-SP Series Signal

Processing Unit)

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Operation manual (1)

Installtion manual (1)

Slot number label (1)

Front Panel Rear Panel

50

*SGC_0043-0068 02.3.16 5:02 PM Page 51

Interface Processor SP Series

Specifications

Inputs/outputs

Digital video signal input:

HD SDI IN connector (BNC type) (1)

HD serial digital signal conforming to

SMPTE291M/292M/299M, 1.4835 or

1.485 Gb/s

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 1.485 GHz)

Transmission loss:

20 dB or less (at 742.5 MHz)

Cable length:

100 m max. (When using a 5C-FB coaxial cable or PD-3079 COOPER

RG-6/U type Super Low Loss Digital

Video Coax or equivalents)

Reference inputs:

Supplied through the REF IN connectors on the PFV-SP Series signal processing units

REF IN connectors (BNC type) (2)

Black Burst or Tri-level sync signal

Digital audio signal inputs:

DIGITAL IN AUDIO connectors (BNC type) (4)

AES3-format digital audio signal

Input impedance:

75

, unbalanced

Input return loss:

25 dB or more

Input level:

1.1 to 0.1 Vp-p

Digital signal outputs:

HD SDI OUT connectors (BNC type) (2)

HD serial digital signal conforming to

SMPTE291M/292M/299M, 1.4835 or

1.485 Gb/s

Output level:

800 m Vp-p

610% (at 75 Ω

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

Rise/fall time:

Less than 270 ps

Alignment jitter:

Within 135 ps

Digital input/output system delay

Video:

Less than 1.4 µs

General

Power requirements:

+12 V DC: less than 1.0 A

Power consumption:

Approx. 12 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 55 °C (-4 to 131 °F)

Operating humidity:

10 to 90 % (without condensation)

Dimensions:

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector panel (H x D x W):

130 x 152.5 x 19 mm

(5 1/8 x 6 1/8 x 25/35 inches)

Mass

Board:

Approx 400 g (14 oz)

Connector panel:

Approx. 220 g (8 oz)

Service parts: Extension boards (EX-834; Part No.

A-8327-357-A and EX-833; Part No.

A-8327-356-A), Maintenance manual

Auto

EQ

S/P HD SDI IN

AES/EBU IN 1

AES/EBU IN 2

AES/EBU IN 3

AES/EBU IN 4

A/V

MUX

P/S

Control Panel

UCP-8060

CPU Board

HKSP-300

HD SDI OUT 1

HD SDI OUT 2

51

*SGC_0043-0068 02.3.25 10:12 AM Page 52

Interface Processor SP Series

HKSP-106

HD Audio/Video Demultiplexer Board

The HKSP-106 is a video/audio de-multiplexer board that de-multiplexes four AES/EBU-format digital audio signals from a multiplexed HD SDI signal. The HD SDI input signal is distributed to two outputs. Up to eight pairs/sixteen channels of audio can be separated from a multiplexed HD SDI signal by connecting two HKSP-106 boards in cascade.

Features

*De-multiplexes eight channel audio signals from an HD

SDI signal and outputs four AES/EBU digital audio signals

*Audio delay adjustable (maximum two video frames)

*Remotely controllable from an optional UCP-8060 universal control panel (Ethernet 100BASE-TX)

*Transfers UMID and VITC data *Provides simplified

Signal Generator *External reference input (PFV-SP

Series Signal Processing Unit)

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Operation manual (1)

Installtion manual (1)

Slot number label (1)

Front Panel Rear Panel

52

*SGC_0043-0068 02.3.16 5:02 PM Page 53

Interface Processor SP Series

Specifications

Inputs/outputs

Digital video signal input:

HD SDI IN connector (BNC type) (1)

HD serial digital signal conforming to

SMPTE291M/292M/299M, 1.4835 or

1.485 Gb/s

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 1.485 GHz)

Transmission loss:

20 dB or less (at 742.5 MHz)

Cable length:

100 m max. (When using a 5C-FB coaxial cable or PD-3079 COOPER

RG-6/U type Super Low Loss Digital

Video Coax or equivalents)

Reference inputs:

Supplied through the REF IN connectors on the PFV-SP Series signal processing units

REF IN connectors (BNC type) (2)

Black Burst or Tri-level sync signal

Digital signal outputs:

HD SDI OUT connectors (BNC type) (2)

HD serial digital signal conforming to

SMPTE291M/292M/299M, 1.4835 or

1.485 Gb/s

Output level:

800 m Vp-p

610% (at 75 Ω

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

Rise/fall time:

Less than 270 ps

Alignment jitter:

Within 135 ps

Digital audio signal outputs:

DIGITAL AUDIO OUT connectors (BNC type) (4)

AES3 digital audio signal

Output impedance:

75

, unbalanced

Output level:

1.0 Vp-p

610%

Digital input/output system delay

Video:

Less than 1.4 µs

General

Power requirements:

+12 V DC: less than 1.0 A

Power consumption:

Max. 12 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 55 °C (-4 to 131 °F)

Operating humidity:

10 to 90 % (without condensation)

Dimensions:

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector panel (H x D x W):

130 x 152.5 x 19 mm

Mass

(5 1/8 x 6 1/8 x 25/35 inches)

Board:

Approx 400 g (14 oz)

Connector panel:

Approx. 220 g (8 oz)

Service parts: Extension boards (EX-834; Part No.

A-8327-357-A and EX-833; Part No.

A-8327-356-A), Maintenance manual

HD SDI IN

Auto

EQ

S/P P/S

A/V

DE MUX

HD SDI OUT 1

HD SDI OUT 2

AES/EBU OUT 1

AES/EBU OUT 2

AES/EBU OUT 3

AES/EBU OUT 4

Control Panel

UCP-8060

CPU Board

HKSP-300

53

*SGC_0043-0068 02.3.16 5:02 PM Page 54

Interface Processor SP Series

HKSP-300

Processing Module Controller

With an HKSP-300 processing module controller installed, the function boards accommodated within the same

PFV-SP Series processing units can be controlled from a

UCP-8060 universal control panel over an Ethernet-based network. A redundant CPU is available by installing two

HKSP-300 boards. The newly developed set-up data backup function retains the settings of the function boards when they have been exchanged. Set-up for networking can be carried out through a connected PC.

Features

*Networking applications; Enables the setting, control, and up/downloading of the set-up data of other HKSP function boards in a PFV-SP Series signal processing unit when used in combination with a UCP-8060 universal control panel connected via a Ethernet 100BASE-TX based network, Interactively up/downloads set-up data via a

Sony System Manager, Multiple control panels can operate with multiple processors *Redundant CPU available by installing two HKSP-300 boards *Auto backup function for set-up data; Periodically backs up the set-up data of function boards and restores to any exchanged boards *Eight inputs and four outputs of GPI interface

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Installation guide (1)

Installation manual (1)

3.5 inches floppy disk (1)

Specifications

- Inputs/outputs -

Reference inputs :

Supplied through the REF IN connectors on the PFV-SP Series signal processing units

REF IN connectors (BNC type) (2)

Black Burst or Tri-level sync signal

Remote

CONTROL LAN:

RJ-45 (1), Ethernet 100Base-TX

DATA LAN:

RJ-45 (1), Ethernet

100Base-TX/10Base-T

RS-422:

D-sub 9-pin (1)

GPI:

Mini D-sub 15-pin (1)

- General -

Power requirements:

+12 V DC: 0.8 A

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 104 °C)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

112.2 x 388.3 mm

( 4 1/2 x 15 3/8 inches)

Connector panel (W x H x D):

130 x 152.5 x 19 mm

(5 1/8 x 6 1/8 x 25/32 inches)

Mass

Board:

Approx. 350 g (12 oz)

Connector panel:

Approx. 130 g (5 oz)

Control Panel

UCP-8060

CONTROL LAN

DATA LAN

GPI

RS-422

CPU

Front Panel

54

Rear Panel

HKSP/HKPF-SP Series

Option Boards

INT BUS

REF A

REF B

*SGC_0043-0068 02.3.16 5:02 PM Page 55

Interface Processor SP Series

HKSP-525

Down Converter Board

The HKSP-525 down converter board converts an HD

SDI signal to an SD SDI signal. It accepts an HD SDI input with embedded audio, and provides three SD SDI outputs (525/625) with embedded audio, plus an analog monitor output.

Features

*Down converts an HD SDI signal to an SD SDI (D1) signal; From 1035(1125) / 59.94i, 29.97PsF to 480(525) /

59.94i, 29.97PsF, From 1080(1125) / 59.94i, 29.97PsF to

480(525), / 59.94i, 29.97PsF, From 1080(1125) / 50i,

25PsF to 576(625) / 50i, 25PsF *Provides an analog composite monitor output *Handles eight embedded audio channels *Retains ancillary data (VITC) and UMID that are on an HD SDI input to an SD SDI output *Output signal aspect ratio modes selectable from Squeeze, Edge

Crop, Letter Box (16:9) and Semi Letter Box (13:9. 14:9,

15:9) *Minimum delay/frame delay selectable *Remotely controllable from an optional HKDV-503/900 digital video controller via a RS-422 (GPI also provided) or UCP-8060 universal control panel (Ethernet 100BASE-TX) *Auto colorimetry selection between 1035 and 1080 active lines

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Operation manual (1)

Installtion manual (1)

Slot number label (1)

Now

Printing

HD DWN

STATUS

SDI IN

REF IN

AUDIO IN

REMOTE

LOCAL

ASPECT

SQ

LD

EC

HKSP-525

I

N

P

U

T

525

HD IN

SD OUT

1

T

P

O

U

U

T

2

3

MONITOR

(Tentative)

Front Panel

(Tentative)

Rear Panel

55

*SGC_0043-0068 02.3.16 5:02 PM Page 56

Interface Processor SP Series

Specifications

Inputs/outputs

Digital video signal input:

HD SDI IN connector (BNC type) (1)

HD serial digital video signal conforming to SMPTE291M/292M/299M

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 M to 1.5 GHz)

Transmission loss:

Less than 20 dB

Cable length:

100 m max. (when using a 5C-FB coaxial cable)

Data rate:

1.4835 or 1.485 Gb/s

Reference inputs:

Supplied through the REF IN connectors on the PFV-SP Series signal processing units

REF IN connectors (BNC type) (2),

Black Burst

Digital video outputs:

D1 SDI OUT 1, 2, 3 (BNC type) (1 each)

525/625 component serial digital video signal conforming to SMPTE259M

Output impedance:

75

, unbalanced

Amplitude:

800 mVp-p

610%

Output return loss:

15 dB or more (5 M to 270 MHz)

Cable length:

200 m max. (when using a 5C-2B coaxial cable)

Data rate:

270 Mb/s

Analog video output:

Monitor output connector (BNC type) (1)

NTSC/PAL composite video signal

Output impedance:

75

, unbalanced

Amplitude:

1.0 Vp-p

System delay:

90 H/1 video frames selectable

General

Power supply:

+12 V DC: 1.0 A

Power consumption:

Approx. 12W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90%

Dimensions:

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector panel (H x D x W):

130 x 152.5 x 19 mm

(5 1/8 x 6 1/8 x 25/35 inches)

Mass:

Board:

Approx. 1500 g (3 lb 5 oz)

Connector panel:

Approx. 500 g ( 1 lb 2 oz)

Service parts: Extension boards (EX-834; Part No.

A-8327-357-A and EX-833; Part No.

A-8327-356-A), Maintenance manual

HD SDI IN

Video Controller

HKDV-503/900

(

REF IN

From PFV-SP Series signal processing unit

)

RS-422A

REMOTE IN

Control Panel

UCP-8060

TG

CPU Board

HKSP-300

D/C P/S

ENC

D/A

SDI OUT 1

SDI OUT 2

SDI OUT 3

MONITOR

OUT

56

*SGC_0043-0068 02.3.25 10:13 AM Page 57

Interface Processor SP Series

HKSP-313

HD Color Corrector Board

The HKSP-313 color corrector board provides control of various color control parameters for different types of signal and complies with multiple HD formats. It also provides line conversion between 1035 and 1080, and format conversion between 1080 and 720P.

Features

*HD signal color correction control; Master / Y, Pb, Pr / R,

G, B / Video Gain, Chroma Gain, Hue, Set up / Gamma /

White/Black Clip, Support for SMPTE292M formats:

1035/60i, 59.94i, 1080/60i, 59.94i, 50i, 1080/30PsF,

29.976PsF, 25PsF, 24PsF, 23.976PsF, 720/60P, 59.94P

*Enhancer control *Active line conversions between 1035 and 1080 *Format conversion between 1080 and 720P

*Audio delay function; Maximum two audio frames *HD

SDI active loop-through output *Retains ancillary data and embedded audio data *Transfers UMID and VITC data *Built-in Signal Generator *System delay available;

With format conversion: 1 frame, Without format conversion: in steps of µs or 3H *Remotely controllable from an optional HKDV-503/900 digital video controller via

RS-422 (GPI also provided) or UCP-8060 universal control panel (Ethernet 100BASE-TX) *Up to eight

HKSP-313 boards can be installed in a PFV-SP3300 signal processing unit

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Operation manual (1)

Installtion manual (1)

Slot number label (1)

Front Panel Rear Panel

57

*SGC_0043-0068 02.3.16 5:02 PM Page 58

Interface Processor SP Series

Specifications

Inputs/outputs

Digital video signal input:

HD SDI IN connector (BNC type) (1)

HD component serial digital signal conforming to SMPTE291M/292M/299M,

1.4835 or 1.485 Gb/s

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 1.485 GHz)

Transmission loss:

20 dB or less (at 742.5 MHz)

Cable length:

100 m max. (when using a 5C-FB coaxial cable or PD-3079 COOPER

RG-6/U type Super Low Loss Digital

Video Coax or equivalents)

HD SDI ACTIVE THROUGH OUT connector (BNC type) (1)

Output level:

800 m Vp-p

610% (at 75

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

Reference inputs:

Supplied through the REF IN connectors on the PFV-SP Series signal processing units

REF IN connectors (BNC type) (2)

Black Burst or Tri-level sync signal

Digital signal outputs:

HD SDI OUT connectors (BNC type) (3)

HD serial digital signal conforming to

SMPTE291M/292M/299M, 1.4835 or

1.485 Gb/s

Output level:

800 m Vp-p

610% (at 75 Ω

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

Rise/fall time:

Less than 270 ps

Alignment jitter:

Within 135 ps

Digital input/output system delay

Video:

1 frame/3H/L.T.10 µ

General

Power requirements:

+12 V DC: less than 1.5 A

Power consumption:

Max. 18 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 55 °C (-4 to 131 °F)

Operating humidity:

10 to 90 % (without condensation)

Dimensions

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector panel (H x D x W):

130 mm x 152.5 x 38 mm

(5 1/8 x 6 1/8 x 1 1/2 inches)

Mass

Board:

Approx 500 g (1 lb 2 oz)

Connector panel:

Approx. 200 g (7 oz)

Service parts: Extension boards (EX-834; Part No.

A-8327-357-A and EX-833; Part No.

A-8327-356-A), Maintenance manual

HD SDI IN

THROUGH-OUT

RS-422A

Auto EQ S/P

Color

Corrector

CPU

Video Controller

HKDV-503/900

Control Panel

UCP-8060

CPU Board

HKSP-300

P/S

HD SDI OUT 1

HD SDI OUT 2

HD SDI OUT 3

58

*SGC_0043-0068 02.3.25 10:14 AM Page 59

Interface Processor SP Series

HKSP-1125

HD Up-converter Board

The HKSP-1125 is a 525-line or a 625-line to 1125i or

720P up-converter with an auto colorimetry selection capability and selectable output modes. The HKSP-1125 accepts inputs in conventional NTSC composite analog or

NTSC composite serial digital or 525/625 component serial digital signal format, and provides three HD serial digital outputs to the 1125i or 720P interlaced HDTV standard. The 1125 output can be in the 1035 or 1080 active line format.

Features

*Up-converts a 625 component serial digital, a 525 component or NTSC composite serial digital, or an NTSC composite analog video signal to the 1125/59i, 1125/50i or 720/59P HDTV standard *525/625 Black Burst or 1125 tri-level Sync input *Three distribution outputs of HD SDI with embedded audio *1035 or 1080 active lines output switchable *Remotely controllable from an optional

HKDV-503/900 Digital Video Controller via a RS-422 (GPI also provided) or UCP-8060 Universal Control Panel

(Ethernet 100BASE-TX) *Provides color matt *Auto colorimetry selection between 1035 and 1080 active lines

*Aspect ratio modes selectable from Squeeze, Letter Box and Edge Crop *Provides frame synchronizer *Motion adaptive and non-adaptive conversion modes selectable from Frame/Field adaptive, Field fixed and Frame fixed

*Color Corrector function control *Anti Image Enhancer control *Gamma Correction control *Up to eight

HKSP-1125 boards can be installed in a PFV-SP Series

Signal Processing Unit

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Operation manual (1)

Installtion manual (1)

Slot number label (1)

Front Panel Rear Panel

59

*SGC_0043-0068 02.3.19 0:12 AM Page 60

Interface Processor SP Series

Specifications

Inputs/outputs

Digital signal input:

SDI IN connector (BNC type) (1),

NTSC composite or 525/625 component serial digital signal with embedded audio conforming to SMPTE259M-A/C

(ITU-R BT.601/BT.656), 270 Mb/s, 143

Mb/s, 75

, unbalanced

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 270 MHz)

Cable length:

More than 200 m (when using

Belden 8281, Fujikura 5C2V or equivalent coaxial cable)

Analog signal input:

ANALOG VIDEO IN connector (BNC type) (1),

Video level:

1.0 Vp-p

Input impedance:

75

, unbalanced

Reference inputs :

Supplied through the REF IN connectors on the PFV-SP Series signal processing units

REF IN connectors (BNC type) (2)

Black Burst or Tri-level sync signal

Digital signal outputs:

HD SDI OUT connectors (BNC type) (3)

HD component serial digital signal conforming to SMPTE291M/292M/299M,

1.4835 or 1.485 Gb/s

Output level:

800 m Vp-p

610% (at 75 Ω

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

Rise/fall time:

Less than 270 ps

Alignment jitter:

Within 135 ps

Digital input/output system delay

Video:

1frame

0.6 to 1.6 frames (frame synchronizer)

General

Power requirement

12VDC; Less Than 1.8A

Power consumption

Max; 21.6W

Operating temperature:

5 °to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector panel (H x D x W):

130 x 152.5 x 38 mm

Mass

(5 1/8 x 6 1/8 x 1 1/2 inches)

Board:

Approx 600 g (1 lb 2 oz)

Connector panel:

Approx. 200 g (7 oz)

Service parts: Extension boards (EX-834; Part No.

A-8327-357-A and EX-833; Part No.

A-8327-356-A), Maintenance manual

525/625 COMPONENT/

525 COMPOSITE SDI IN

NTSC COMPOSITE

ANALOG VIDEO IN

(

REF IN

From PFV-SP Series signal processing unit

)

(

LOOP-THROUGH

From PFV-SP Series signal processing unit

)

RS-422A

Video Controller

HKDV-503/900

Control Panel

UCP-8060

S/P

A/D

CLK

Up-Conv.

Frame

Sync

P/S

CPU Board

HKSP-300

HD SDI OUT 1

HD SDI OUT 2

HD SDI OUT 3

60

*SGC_0043-0068 02.3.16 5:02 PM Page 61

Interface Processor SP Series

HKPF-SP003

Digital Video Distribution Amp

The HKPF-SP003 distributes a multi-bit rate signal from

143 Mb/s to 1.5 Gb/s to six outputs. The input signal is re-clocked before distribution.

Features

*Distribution of an SD or HD SDI signal *Re-clocking at

143 Mb/s, 177 Mb/s, 270 Mb/s, 360 Mb/s, 540 Mb/s, 1.5

Gb/s *Six distribution outputs *Auto bit rate detection

*Auto cable equalization of up to 100 m (at 1.5 Gb/s)

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Installation Guide (1)

Installation Manual (1)

61

Front Panel Rear Panel

*SGC_0043-0068 02.3.16 5:02 PM Page 62

Interface Processor SP Series

Specifications

Inputs/outputs

Serial digital input:

SDI IN connector (BNC type) (1)

Data transfer rate:

143 Mb/s to 1.485 Gb/s

Input signal:

Scramble NRZI signal, 0.8 V p-p

Input return loss:

15 dB or more (5 MHz to 1.485 GHz)

Cable length:

100 m (when a 5C-FB cable (Fujikura) or Belden1694 coaxial cable or the equivalent is used)

Serial digital output:

SDI OUT connector (BNC type) (1)

Data transfer rate:

143 Mb/s to 1.485 Gb/s

Re-clocking:

143 Mb/s, 177 Mb/s, 270 Mb/s, 360

Mb/s, 540 Mb/s, 1.485/1.001 Gb/s,

1.485 Gb/s

Output amplitude:

0.8 Vp-p

610%

Rise/fall time:

270 ps or less

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

General

Power Requirements:

+12 V dc: 0.42 A

(supplied from a PFV-SP Series Signal

Processing Unit)

Operation temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (No condensation)

Dimensions

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector Panel (H x D x W):

130 x 152.5 x 19 mm

(5 1/8 x 6 1/8 x 3/4 inches)

Mass

Board:

Approx. 200 g (7 oz)

Connector Panel:

Approx. 155 g (5 oz)

Service parts: Maintenance manual

HD/SD SDI IN

Equalizer Reclocker

HD/SD SDI OUT 1

HD/SD SDI OUT 2

HD/SD SDI OUT 3

HD/SD SDI OUT 4

HD/SD SDI OUT 5

HD/SD SDI OUT 6

62

*SGC_0043-0068 02.3.16 5:02 PM Page 63

Interface Processor SP Series

HKPF-SP021

Optical to Electrical Converter

The HKPF-SP021 is an optical to electrical signal converter with an operational frequency range of 143

Mb/s to 1.5 Gb/s. In combination with the HKPF-SP022 electrical to optical converter board, it extends the transmission distance over an optical fiber to two km. The

HKPF-SP021 has one optical input and provides three electrical digital outputs. The bit rate of the input signal is detected automatically.

Features

*Used with HKPF-SP022 to extend transmission distance of HD/SD SDI signals up to 2 km *Passes pathological signal *Three distribution outputs *Re-clocking at 143

Mb/s, 177 Mb/s, 270 Mb/s, 360 Mb/s, 540 Mb/s and 1.5

Gb/s. *Auto bit rate detection *Status indication and output

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Installation Guide (1)

Installation Manual (1)

Front Panel Rear Panel

63

*SGC_0043-0068 02.3.16 5:02 PM Page 64

Interface Processor SP Series

Specifications

Inputs/outputs

OPTICAL IN connector:

SC/PC type (1)

Adaptive plug :

SC/PC type plug (1)

Adaptive cable:

1310 nm single mode optical fiber

Optical device:

Photo diode

Laser wavelength:

1310 nm

Input signal:

Scrambled NRZI

Optical input level:

-14.6 dBm to -4.5 dBm

SDI OUT connectors:

BNC Type (3)

Data transfer rate:

143 Mb/s to 1.485 Gb/s

Output amplitude:

0.8 V p-p

610%

Rise/fall time:

270 ps or less

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

General

Power requirements:

+ 12 V DC: 0. 37 A

(supplied from PFV-SP Series Signal

Processing Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector Panel (H x D x W):

130 x 152.5 x 19 mm

(5 1/8 x 6 1/8 x 3/4 inches)

Mass

Board:

Approx. 200 g (7 oz)

Connector Panel:

Approx. 130 g (5 oz)

Service parts: Maintenance manual

OPTICAL IN O/E Reclocker

HD/SD SDI OUT 1

HD/SD SDI OUT 2

HD/SD SDI OUT 3

64

*SGC_0043-0068 02.3.16 5:02 PM Page 65

Interface Processor SP Series

HKPF-SP022

Electrical to Optical Converter

The HKPF-SP022 converts a variety of serial digital electrical signals to optical signals and re-clocks them at a bit rate from 143 Mb/s to 1.5 Gb/s. In combination with the

HKPF-SP021 Optical To Electrical Converter board, it provides a transmission distance over an optical fiber of up to 2 km. The bit rate of the input video signal can be detected automatically. One digital video signal input, one re-clocked electrical digital video signal output and one converted optical signal output connectors are provided.

Features

*Used with HKPF-SP021 to extend transmission distance of HD/SD SDI signals up to two km *Passes pathological signal *Re-clocking at 143 Mb/s, 177 Mb/s, 270 Mb/s,

360 Mb/s, 540 Mb/s and 1.5 Gb/s. *Auto bit rate detection

*Status indication and output

The HKPF-SP/HKSP function boards install in PFV-SP Series Signal

Processing Units in any combination with other HKPF-SP/HKSP function boards.

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Supplied Accessories

Installation Manual (1)

Installtion Guide (1)

Front Panel Rear Panel

65

*SGC_0043-0068 02.3.16 5:02 PM Page 66

Interface Processor SP Series

Specifications

Inputs/outputs

SDI IN connector:

BNC type (1)

Data transfer rate:

143 Mb/s to 1.485 Gb/s

Input signal:

Scrambled NRZI, 0.8 V p-p

Input return loss:

15 dB or more (5 MHz to 1.485 GHz)

Input cable length:

100 m (when a 5C-FB cable (Fujikura) or Belden 1694 coaxial cable or the equivalent is used)

Active loop-through out:

BNC Type (1)

Data transfer rate:

143 Mb/s to 1.485 Gb/s

Re-clock bit rate:

143 Mb/s, 177 Mb/s, 270 Mb/s, 360

Mb/s, 540 Mb/s, 1.485/1.001 Gb/s,

1.485 Gb/s

Output amplitude:

0.8 Vp-p

610%

Rise/fall time:

270 ps or less

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

OPTICAL OUT connector:

SC/PC Type (1)

Adaptive plug:

SC/PC Type Plug

Adaptive cable:

1310 nm single mode optical fiber

Optical device: laser diode

Laser wave length:

1310 nm

Optical output level:

-11 dBm to -7.5 dBm

General

Power Requirements:

+12 V DC: 0.37 A

(supplied from PFV-SP Series Signal

Processing Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Dimensions

Board (H x W):

112.2 x 388.3 mm

(4 1/2 x 15 3/8 inches)

Connector Panel (H x D x W):

130 x 152.5 x 19 mm

(5 1/8 x 6 1/8 x 3/4 inches)

Mass

Board:

Approx. 200 g (7 oz)

Connector Panel:

Approx. 130 g (5 oz)

Service parts: Maintenance manual

HD/SD SDI IN

66

Equalizer Reclocker E/O OPTICAL OUT

ACTIVE LOOP-THROUGH

*SGC_0043-0068 02.3.16 5:02 PM Page 67

Interface Processor SP Series

UCP-8060

Universal Control Panel

The UCP-8060 universal control panel can be used for a wide range of applications where control of PFV-SP

Series is required. Its compact size and low-profile design makes the UCP-8060 compatible in almost any system environment. A color touch screen helps to provide quick and positive operation.

Features

*Wide range of applications — Remotely controls the functions and monitors the status of the HKSP-008HD HD frame/line synchronizer board, HKSP-105 audio/video multiplexer board, HKSP-106 audio/video demultiplexer board, HKSP-313 HD color corrector board, HKSP-525 down-converter board and HKSP-1125 HD up-converter board; Sony Memory Stick ™ used to store and load set-up data or install software *Compact 3RU height and

2/3 19-inch rack width size — Fits neatly into a control desk; 19-inch rack mountable *Combines touch-screen operation with knob and button operation — Easy-to-use menu system with simplified layers; Shares common operability with MVS-8000 Series production switchers

Applicable Models

PFV-SP3100 Signal Processing Unit

PFV-SP3300 Signal Processing Unit

Note: An HKSP-300 Processing Module

Controller board is required.

Supplied Accessories

Operation manual (1)

Installation manual (1)

Rack mount kit (1)

Specifications

Control signal

DATA LAN:

RJ-45 (1), 100BASE-TX

EXT PANEL1:

D-sub 9pin male (1), RS-485

RS-232C (Factory use only):

D-sub 9-pin female (1), RS-232C

General

Power requirements:

85 to 265 V AC, 47 to 63 Hz

Power consumption:

5 V, 15 W

Dimensions (H x D x W):

130 x 75 x 306 mm

(5 1/8 x 3 x 12 1/8 inches)

Mass:

Approx. 1.5kg (3 lb 5 oz)

Service parts: Maintenance manual, AD code

67

*SGC_0043-0068 02.3.16 5:02 PM Page 68

Interface Processor SP Series

68

*SGC_0069-0098 02.3.16 5:03 PM Page 69

Interface Processor L Series

PFV-L10 . . . . . . . . . . . . . . . . 70

BKPF-L601C . . . . . . . . . . . . . 71

BKPF-L602C . . . . . . . . . . . . . 72

BKPF-L603 . . . . . . . . . . . . . . 73

BKPF-L605 . . . . . . . . . . . . . . 75

BKPF-L606 . . . . . . . . . . . . . . 76

BKPF-L608C . . . . . . . . . . . . . 77

BKPF-L611 . . . . . . . . . . . . . . 79

BKPF-L612 . . . . . . . . . . . . . . 80

BKPF-L613C . . . . . . . . . . . . . 81

BKPF-L632 . . . . . . . . . . . . . . 83

BKPF-L641 . . . . . . . . . . . . . . 84

BKPF-L642 . . . . . . . . . . . . . . 86

BKPF-L653 . . . . . . . . . . . . . . 88

BKPF-L703A . . . . . . . . . . . . . 89

BKPF-L704 . . . . . . . . . . . . . . 91

BKPF-L723 . . . . . . . . . . . . . . 92

BKPF-L751 . . . . . . . . . . . . . . 93

BKPF-L752 . . . . . . . . . . . . . . 95

BKPF-L753A . . . . . . . . . . . . . 96

BKPF-L754 . . . . . . . . . . . . . . 97

BKPF-L803 . . . . . . . . . . . . . . 98

69

*SGC_0069-0098 02.3.16 5:03 PM Page 70

Interface Processor L Series

PFV-L10

Interface unit

The PFV-L10 is a 19-inch rack mountable compact interface unit with an impressive price/performance ratio.

Only 2U high, it makes small demands on space in equipment environments. Up to 10 BKPF-L Series function boards can be accommodated in any combination. The controls of these boards are all accessible from the front of the PFV-L10, and all boards can be hot-swapped. An optional redundant power supply unit, the BKPF-LPS10, can be installed in the PFV-L10.

This unit is identical to the standard power supply. In the event of a fault in the standard power supply, the

BKPF-LPS10 automatically functions, ensuring continuous operation by maintaining power to the installed boards.

Features

* Compact design of 2U height * Accepts up to 10 digital and analog video/audio function boards in any combination * Redundant power supply * Hot-swappable boards * Status output port for system configuration convenience such as diagnostic system * Fan cooled operation * Power status LED on the front panel * 100 V to 240 V AC operation * 19-inch rack mountable

Optional Accessories

RMM-10 Rack Mount Kit

Optional Boards

BKPF-L803 S-BUS Distribution Board

BKPF-L601C Video A to D Converter Board

BKPF-L602C Video D to A Converter Board

BKPF-L603 SDI Distribution Board

BKPF-L605 Audio/Video Multiplexer Board

BKPF-L606 Audio/Video Demultiplexer Board

BKPF-L608C 4:2:2 Frame/Line Synchronizer

Board

BKPF-L611 3-ch SDI Distribution Board

BKPF-L612 2-ch SDI Distribution Board

BKPF-L613C Monitoring SDI Distribution

Board

BKPF-L632 Monitoring Composite Encoder

Board

BKPF-L641 NTSC/PAL To 4:2:2 Decoder

Board

BKPF-L642 4:2:2 To NTSC/PAL Encoder

Board

BKPF-L653 AES/EBU Distribution Board

BKPF-L703A Analog Video Distribution Board

BKPF-L704 Black Burst Regenerator Board

BKPF-L723 Video Delay Distribution Board

BKPF-L751 Audio A to D Converter Board

BKPF-L752 Audio D to A Converter Board

BKPF-L753A Analog Audio Distribution Board

BKPF-L754 Audio Signal Generator Board

Optional Peripherals

BKPF-LPS10 Backup Power Supply Unit

Specifications

General

Power requirements:

AC 100 to 240 V, 50/60 Hz

Power consumption:

Max. 130 VA

Supply capability:

DC +5 V 13 A max. for the installed boards

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Humidity:

10 to 90% (No condensation)

Dimensions (W x H x D)

440 x 88 x 353.2 mm

(17 3/8 x 3 1/2 x 14 inches)

Mass:

Approx. 6.2 kg (13 lb 10.7 oz)

(Excluding backup supply unit)

Status output port:

D-sub 15-pin (1)

Backup power supply:

Available (BKPF-LPS10)

Maximum number of boards installed:

10 BKPF-L Series boards

Service parts: EX-731 Extension Board (Part No.

A-8322-598-A), Maintenance Manual

70

Rear Panel

*SGC_0069-0098 02.3.16 5:03 PM Page 71

Interface Processor L Series

BKPF-L601C

Video A to D Converter Board

The BKPF-L601C is a high quality yet cost effective A to

D converter board which converts a 525 or 625-line component analog video signal to a component serial digital video signal. Y, B-Y, R-Y or RGB signals can be input. Four distribution outputs of the converted signal are provided.

Features

* Converts a 525/625 component analog video signal to a

525/625 component serial digital video signal * 10-bit conversion and signal path * 2X oversampling * CCIR,

Betacam™ with 7.5% or 0% setup or RGB signal inputs *

Four serial digital distribution outputs * Automatic

525/625-line selection * EDH insertion

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Inputs/outputs

Analog inputs:

ANALOG IN Y/G, B-Y/B, R-B19Y/R connectors

(BNC type) (1 each)

525/625 component analog video signals or RGB signals (selectable with on-board switch)

RGB signals:

R: 0.7 Vp-p, 75

G: 0.7 Vp-p, 75

B: 0.7 Vp-p, 75

Defined with the color bar signal

100/0/100/0.

YUV (CCIR) signals:

Y: 1.0 Vp-p, 75

(incl. Y sync 300 mV)

B-Y: 0.7 Vp-p, 75

R-Y: 0.7 Vp-p, 75

Defined with the color bar signal

100/0/100/0.

YUV (Betacam 7.5% setup) signals:

Y: 1.0 Vp-p, 75

(incl. Y sync 286 mV)

B-Y: 0.7 Vp-p, 75

R-Y: 0.7 Vp-p, 75

Defined with the color bar signal

100/7.5/77/7.5.

YUV (Betacam 0% setup) signals:

Y: 1.0 Vp-p, 75

(incl. Y sync 286 mV)

B-Y: 0.756 Vp-p, 75

R-Y: 0.756 Vp-p, 75

Defined with the color bar signal

100/0/75/0.

Sync signal input:

SYNC connector (BNC type) (1)

0.28 Vp-p-10%, 75

(black burst)

Serial digital outputs:

SDI OUT connectors (BNC type) (4)

525/625 component serial digital signal conforming to SMPTE259M-C, 0.8

Vp-p

610%, 75 Ω

System delay:

Approx. 3.31 ms

Data transmission

Channel coding:

Scrambled NRZI

Transmission speed:

Output: 270 Mb/s

Amplitude:

0.8 Vp-p-10%

Digital output return loss:

15 dB or more (5 MHz to 270 MHz)

Signal format:

525/625 component serial digital signal conforming to SMPTE259M-C, Serial digital interface

Video characteristics

Sampling frequency:

Y: 13.5 MHz R-B15Y, B-Y: 6.75 MHz

Digitization:

10 bits

Band width:

Y: 5.75 MHz R-Y, B-B83Y: 2.75 MHz

Y, R-Y, B-Y phase error:

20 ns or less

K factor (2T pulse):

1% or less

Signal-to-noise ratio:

60 dB or more

EDH:

Conforms to SMPTE RP165

General

Power requirements:

+5 V DC: 1.2 A

(Supplied from the PFV-L Series

Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Rear Panel

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

Approx. 140 g (5 oz)

Connector panel:

Approx. 120 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

525/625 COMPONENT

ANALOG VIDEO

(R/G/B or Y/R-Y/B-Y)

G/Y IN

R/R-Y IN

B/B-Y IN

SYNC IN

A/D EDH

SDI OUT 1

525/625

COMPONENT

DIGITAL VIDEO

SDI OUT 2

SDI OUT 3

SDI OUT 4

71

*SGC_0069-0098 02.3.16 5:03 PM Page 72

Interface Processor L Series

BKPF-L602C

Video D to A Converter Board

The BKPF-L602C is a high quality yet cost effective video

D to A converter board which converts a 525 or 625-line component serial digital video signal to a component analog video signals. Y, B-Y, R-Y or RGB signals can be selected for outputs. Two distribution outputs of the converted signal are provided.

Features

* Converts a 525/625 component serial digital signal to a

525/625 component analog signal * 10-bit conversion and signal path * 525/625 component serial digital input with active-through outputs * Two distribution outputs of CCIR,

Betacam with 7.5% or 0% setup or RGB signals * Two

Sync outputs * Automatic 525/625-line detection * EDH monitoring * SDI input presence lamp

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part No.A-8322-598-A) (1)

Specifications

Inputs/outputs

Serial digital input:

SDI IN connector (BNC type) (1)

0.8 Vp-p-10%, 75

4:2:2 component serial digital signal

Serial digital outputs:

Active-through output connector (BNC type)

(1)

0.8 Vp-p-10%, 75

4:2:2 component serial digital video signal

Analog outputs:

ANALOG OUT Y/G, B-Y/B, R-Y/R connectors

(BNC type) (2 each)

Analog component video signals or RGB signals (selectable with on-board switch)

RGB signals:

R: 0.7 Vp-p, 75

G: 0.7 Vp-p, 75

B: 0.7 Vp-p, 75

Defined with the color bar signal 100/0/100/0.

YUV (CCIR) signals:

Y: 1.0 Vp-p, 75

(incl. Y sync 300 mV)

B-Y: 0.7 Vp-p, 75

R-Y: 0.7 Vp-p, 75

Defined with the color bar signal 100/0/100/0.

YUV (Betacam 7.5% setup) signals:

Y: 1.0 Vp-p, 75

(incl. Y sync 286 mV)

B-Y: 0.7 Vp-p, 75

R-Y: 0.7 Vp-p, 75

Defined with the color bar signal

100/7.5/77/7.5.

YUV (Betacam 0% setup) signals:

Y: 1.0 Vp-p, 75

(incl. Y sync 286 mV)

B-Y: 0.756 Vp-p, 75

R-Y: 0.756 Vp-p, 75

Defined with the color bar signal 100/0/75/0.

Sync signal outputs:

SYNC connectors: BNC type (2)

2.0 Vp-p-10%, 75

Data transmission

Channel coding:

Scrambled NRZI

Transmission speed:

Input: 270 Mb/s

Amplitude:

0.8 Vp-p-10%

Cable length:

200 m max. (when using a Belden 8281,

Fujikura 5C2V or equivalent coaxial cable)

Digital input/output return loss:

15 dB or more (5 MHz to 270 MHz)

Signal format:

4:2:2 component serial digital video signal conforming to SMPTE259M

Serial digital interface

Video characteristics

Sampling frequency:

Y: 13.5 MHz R-Y, B-Y: 6.75 MHz

Digitization:

10 bits

Bandwidth:

Y: 5.75 MHz R-Y, B-Y: 2.75 MHz

Y, R-Y, B-Y phase error:

20 ns or less

K factor (2T pulse):

1% or less

Signal-to-noise ratio:

60 dB or more

System delay:

Approx. 3.7 µs

EDH:

Conforms to SMPTE PR165

General

Power requirements:

+5 V DC: 1.0 A

(Supplied from the PFV-L Series Interface

Unit)

Rear Panel

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

Approx. 140 g (5 oz)

Connector panel:

Approx. 120 g (4 oz)

Service parts: Extension board (Part No.A-8322-598-A),

Maintenance manual

525/625

COMPONENT

DIGITAL VIDEO

SDI IN

ACTIVE LOOP-THROUGH

EDH D/A

Y/G OUT 1

B-Y/B OUT 1

R-Y/R OUT 1

SYNC OUT 1

Y/G OUT 2

B-Y/B OUT 2

R-Y/R OUT 2

SYNC OUT 2

525/625 COMPONENT

ANALOG VIDEO

(R/G/B or Y/R-Y/B-Y)

72

*SGC_0069-0098 02.3.16 5:03 PM Page 73

Interface Processor L Series

BKPF-L603

SDI Distribution Board

The BKPF-L603 SDI distribution board accepts a 525/625 component serial digital or NTSC/PAL composite serial digital video signal and distributes it to eight outputs. The output cable length can be up to 200 m (Belden 8281,

Fujikura 5C2V or equivalent cable).

Features

* 525/625 component serial digital or NTSC/PAL composite serial digital video input * Eight equalized and re-clocked distribution outputs * High quality 10-bit signal processing * Automatic equalization for output cable length of up to 200m (with Belden 8281, Fujikura 5C2V or equivalent cable)

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Rear Panel

73

*SGC_0069-0098 02.3.16 5:03 PM Page 74

Interface Processor L Series

Specifications

Inputs/outputs

Serial digital input:

SDI IN connector (BNC type) (1)

Serial digital outputs:

SDI OUT connectors (BNC type) (8)

0.8 Vp-p, 75

Data transmission

Channel coding:

Scrambled NRZI

Transmission speed:

143 Mb/s (NTSC composite serial digital)

177 Mb/s (PAL composite serial digital)

270 Mb/s (525/625 component serial digital)

Amplitude:

0.8 Vp-p-10%

Cable length:

200 m max. (when using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

Digital input/output return loss:

-15 dB or more (5 MHz to 270 MHz)

Signal format:

NTSC/PAL composite or 525/625 component serial digital signal conforming to SMPTE259M-A/ B/C

(ITU-R BT.601/BT.656); 143, 177, 270

Mb/s

General

Power requirements:

+5 V DC: 0.3 A

(Supplied from the PFV-L Series

Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(10 5/8 x 3 1/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board

Approx. 110 g (4 oz)

Connector panel

Approx. 100 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

SDI IN

NTSC/PAL COMPOSITE DIGITAL or

525/625 COMPONENT DIGITAL

RE-

CLOCKING

NTSC/PAL COMPOSITE DIGITAL or

525/625 COMPONENT DIGITAL

SDI OUT x 8

74

*SGC_0069-0098 02.3.16 5:03 PM Page 75

Interface Processor L Series

BKPF-L605

Audio/Video Multiplexer Board

The BKPF-L605 is an audio/video multiplexer that embeds two AES/EBU stereo pairs (four individual channels) into a

525/625 component or NTSC composite serial digital video signal, offering lower system cost by reducing the number of modules required for multiple Audio Group multiplexing. By cascading two BKPF-L605 boards, a further four AES/EBU signals can be embedded to a serial digital video signal, making a total of eight

AES/EBU stereo pairs (16 audio channels). The

BKPF-L605 distributes the serial digital video with embedded audio signal to four outputs.

Features

* Multiplexes four AES/EBU stereo pair signals into a

525/625 component or NTSC composite serial digital video signal * Up to 16 individual audio channels multiplexed by cascading two boards * One serial digital input with an active loop-through output * Four serial digital distribution outputs * Four AES/EBU stereo pair inputs (eight individual channels) * Channel swap capabilities * Audio Group assignment selectable with on-board switch * Function selection for channels 3/4 *

EDH monitoring and insertion

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Inputs/outputs

SDI

SDI input:

SDI IN connector (BNC type) (1)

4:2:2 component serial digital video signal or 4 fsc NTSC composite digital video signal conforming to

SMPTE259M (selectable with on-board switch)

Input impedance:

75

Cable length:

200 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

SDI outputs:

Active-through output connector

(BNC type) (1)

SDI OUT connectors (BNC type) (4)

Serial digital video signal of the same format as that to the input connector

0.8 Vp-p

610%, 75

Digital audio inputs

Digital audio signal inputs:

AES/EBU IN connectors (BNC type)

(4)

48 kHz/20 bits

AES/EBU digital audio signal, 1

Vp-p

610%, 75 Ω

, unbalanced

Cable length:

1000 m max. (when using a Belden

8281,

Fujikura 5C2V or equivalent coaxial cable)

Multiplex format:

Conforms to SMPTE272M

EDH:

Conforms to SMPTE PR165

General

Power requirements:

+5 V DC: 1.0 A

(Supplied from the PFV-L Series

Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Rear Panel

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

Approx. 130 g (5 oz)

Connector panel:

Approx. 120 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

NTSC COMPOSITE DIGITAL or

525/625 COMPONENT DIGITAL VIDEO

SDI IN

ACTIVE LOOP-THROUGH

AES/EBU IN 1

AES/EBU IN 2

AES/EBU IN 3

AES/EBU IN 4

S/P

A/V

MUX

EDH P/S

SDI OUT 1

SDI OUT 2

SDI OUT 3

SDI OUT 4

NTSC COMPOSITE DIGITAL or

525/625 COMPONENT DIGITAL

VIDEO WITH EMBEDDED AUDIO

75

*SGC_0069-0098 02.3.16 5:03 PM Page 76

Interface Processor L Series

BKPF-L606

Audio/Video Demultiplexer Board

The BKPF-L606 is an audio/video demultiplexer board that extract AES/EBU format digital audio signals from a multiplexed 525/625 component serial or NTSC composite serial digital video signal. A single BKPF-L606 board will extract two AES/EBU stereo pairs (four audio channels).

Up to eight AES/EBU stereo pairs (16 audio channels) can be separated from a 525/625 component serial digital video signal by cascading four BKPF-L606 boards. The

BKPF-L606 distributes an input serial digital video signal to four outputs and each of two extracted AES/EBU stereo pairs to four outputs.

Features

* Demultiplexes two AES/EBU stereo from a 525/625 component or NTSC composite serial digital video signal *

Up to 16 individual audio channels demultiplexed by cascading two boards * One serial digital input with an active loop-through output * Four serial digital distribution outputs * Four AES/EBU stereo outputs * Channel swap capabilities * Audio Group assignment selectable with on-board switch * EDH monitoring and insertion

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part No.A-8322-598-A) (1)

Specifications

Inputs/outputs

SDI

SDI input:

SDI IN connector (BNC type) (1)

4:2:2 component serial digital video signal or 4 fsc NTSC composite digital video signal conforming to SMPTE259M

(selectable with on-board switch)

Input impedance:

75

Cable length:

200 m max. (when using a Belden 8281,

Fujikura 5C2V or equivalent coaxial cable)

SDI outputs:

Active-through output connector (BNC type) (1)

SDI OUT connectors (BNC type) (4)

Serial digital video signal of the same format as that to the input connector

0.8 Vp-p

610%, 75 Ω

Digital audio outputs

Digital audio signal outputs:

AES/EBU OUT connectors (BNC type) (4)

48 kHz/20 bits

AES/EBU digital audio signal, 1

Vp-p

610%, 75 Ω

, unbalanced

Multiplex system:

Conforms to SMPTE 272M

EDH:

Conforms to SMPTE PR165

General

Power requirements:

+5 V DC: 1.1 A

(Supplied from the PFV-L Series Interface

Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

Approx. 130 g (5 oz)

Connector panel:

Approx. 120 g (4 oz)

Service parts: Extension board (Part No.A-8322-598-A),

Maintenance manual

SDI IN

ACTIVE LOOP-THROUGH

S/P EDH P/S

A/V

DEMUX

Rear Panel

SDI OUT 1

SDI OUT 2

SDI OUT 3

SDI OUT 4

AES/EBU OUT 1

AES/EBU OUT 2

AES/EBU OUT 3

AES/EBU OUT 4

525/625

COMPONENT

DIGITAL

76

*SGC_0069-0098 02.3.16 5:03 PM Page 77

Interface Processor L Series

BKPF-L608C

4:2:2 Frame/Line Synchronizer Board

The BKPF-L608C is a 4:2:2 frame/line synchronizer board used to that synchronizes a 4:2:2 component serial digital video input signal to an external analog reference. This

10-bit serial 4:2:2 synchronizer features a Freeze control that is field/frame auto/manual selectable and also includes phase adjustment. The selection of frame sync or line sync mode solves timing problem in a component serial digital environment. Up to eight embedded audio channels can be passed. Four distribution outputs are provided.

Features

*High performance frame/line synchronizer — 10-bit 4:2:2 internal processing; Supports SMPTE259M-C; One equalized input with active loop-through output; Four distribution outputs; Black burst reference input with passive loop-through output; GPI input *Two synchronization modes selectable to synchronize the input signal to the external reference in steps of single frame or single line — Frame Synchronization mode and

Line Synchronization mode *H/V phase adjustment available in Frame Synchronization mode *Freeze function when an error is detected in the input signal —

Auto/Manual freeze selectable; Field/Frame freeze selectable *Passes eight embedded audio channels and other ancillary data in VBI — Automatically mutes embedded audio when picture frozen *EDH monitoring and insertion

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

Installation manual (1)

Installaton guide (1)

Slot number label (1 set) (1)

EX-731 extension board (Part No.

A-8322-598-A) (1)

Rear Panel

77

*SGC_0069-0098 02.3.16 5:03 PM Page 78

Interface Processor L Series

Specifications

Inputs/outputs

Video standard:

525/625, 4:2:2 component serial digital signal (SDI), conforming to

SMPTE259M-C, 270 Mb/s

Serial digital input:

SDI IN connector (BNC type) (1)

Digital input return loss:

15 dB or more (5 MHz to 270 MHz)

Cable length:

200 m max. (with Belden 8281, Fujikura

5C2V or equivalent coaxial cable)

Serial digital outputs:

Active-through output connector (BNC type) (1),

SDI OUT connector (BNC type) (4),

0.8 Vp-p

610%, 75

Digital output return loss:

15 dB or more (5 MHz to 270 MHz)

Reference input:

REF IN connector (BNC type) (1)

0.3 Vp-p

610%, 75 Ω

, black burst signal

Reference output:

Passive loop-through output connector

(BNC type) (1)

GPI:

REMOTE connector (D-sub 9-pin) (1), open collector input

Memory:

4 fields

Phase adjustment range:

Line: -2 H, -1 H,

60 H, +1 H

Clock: -5.0 to +9.4 µs (74 ns steps

Fine: more than 80 ns (continuously variable)

General

Power requirements:

+5 V DC: 0.7 A

(Supplied from PFV-L Series Interface

Unit)

Operating temperature:

5 to 40 °C (41 to +104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

77 x 267 mm

(3 1/8 x 10 3/4 inches)

Connector panel (H x D x W):

130 x 152.5 x 38 mm

(5 1/8 x 6 1/8 x 1 1/2 inches)

Mass

Board:

Approx. 130 g (5 oz)

Connector panel:

Approx. 120 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

525/625 COMPONENT

SERIAL DIGITAL

SDI IN

ACTIVE

LOOP-THROUGH

REF IN

PASSIVE LOOP-THROUGH

FRAME/LINE

SYNC

CLK

78

SDI OUT 1 525/625 COMPONENT

SERIAL DIGITAL

SDI OUT 2

SDI OUT 3

SDI OUT 4

*SGC_0069-0098 02.3.16 5:03 PM Page 79

Interface Processor L Series

BKPF-L611

3-ch SDI Distribution Board

The BKPF-L611 is a three-input SDI distribution amplifier board, distributing each input to two outputs. It accepts any component or composite serial digital video signal.

The BKPF-L611 can operate at bit rates of up to 540 Mb/s

(143, 177, 270, 360 and 540 Mb/s serial formats) and can be used for DVB/ASI signal distribution. The BKPF-L611 is suitable to double the outputs of a digital video router that does not have the dual output.

Features

* Three 525/625 component or NTSC/PAL composite serial digital video inputs * Two equalized and re-clocked distribution outputs from each input * Auto selection of

143, 177, 270, 360 and 540 Mb/s serial formats (manual selection also available with on-board switch) *

High-quality 10-bit signal processing * Automatic equalization for output cable lengths of up to 150m/200 m

(at 540 Mb/s/360, 270, 177, 143 Mb/s with Belden 8281,

Fujikura 5C2V or equivalent cable) * Accepts DVB/ASI signals * SDI input presence lamp

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Inputs/outputs

Serial digital inputs:

SDI IN connectors (BNC type) (3)

NTSC/PAL composite or 525/625 component serial digital signal conforming to SMPTE259M-A/ B/C

(ITU-R BT.601/ BT.656)/D (ITU-R BT.601/

BT.656); 143,177,270, 360 Mb/s

Component serial digital signal: 540

Mb/s

(Selectable by auto or manual settings)

Input return loss:

15 dB or more (at 5 MHz to 540 MHz)

Cable length:

143, 177, 270, 360 Mb/s: 200 m max.

540 Mb/s: 150 m max. (When using a

Belden 8281, Fujikura 5C2V or equivalent coaxial cable)

Serial digital outputs:

SDI OUT connectors (BNC type) (6;3 for each channel)

0.8 Vp-p

610%, 75

Output return loss:

15 dB or more (at 5 MHz to 540 MHz)

Rise time/fall time:

0.5 to 0.75 ns (20% and 80% amplitude points)

Overshoot:

Less than 10%

Alignment jitter:

Less than 0.2 UIp-p (UI = Unit Interval)

DC offset:

Less than 0

60.5 V

General

Power requirements:

+ 5 V DC: 0.7 A (supplied from the

PFV-L Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °C)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

140 g (5 oz)

Connector panel:

100 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

525/625

COMPONENT

DIGITAL or

NTSC/PAL

COMPOSITE

DIGITAL

SDI IN 1

SDI IN 2

SDI IN 3

Rear Panel

SDI OUT 1-1

SDI OUT 1-2

SDI OUT 2-1

SDI OUT 2-2

SDI OUT 3-1

SDI OUT 3-2

525/625

COMPONENT

DIGITAL or

NTSC/PAL

COMPOSITE

DIGITAL

79

*SGC_0069-0098 02.3.16 5:03 PM Page 80

Interface Processor L Series

BKPF-L612

2-ch SDI Distribution Board

The BKPF-L612 is a two-input SDI distribution amplifier board, distributing each input to four outputs. It accepts any component or composite serial digital video signal.

The BKPF-L612 can operate at bit rates of up to 540

Mbps (143, 177, 270, 360 and 540 Mb/s serial formats) and can be used for DVB/ASI signal distribution. By installing dual, one input - four outputs distribution amplifier boards, like the BKPF-L612, into a PFV-L10 interface unit, a high packing density distribution amplifier unit can be built up.

Features

* Two 525/625 component serial digital or NTSC/PAL composite serial digital video inputs * Four equalized and re-clocked distribution outputs from each input * Auto selection of 143, 177, 270, 360 and 540 Mb/s serial formats (manual selection also available with on-board switch) * High-quality 10-bit signal processing * Automatic equalization for output cable lengths of up to 150m/200 m

(at 540 Mbps/360, 270, 177, 143 Mb/s with Belden 8281,

Fujikura 5C2V or equivalent cable) * Accepts DVB/ASI signals * SDI input presence lamp

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Inputs/outputs

Serial digital inputs:

SDI IN connectors (BNC type) (2)

NTSC/PAL composite or 525/625 component serial digital signal conforming to SMPTE259M-A/B/C

(ITU-R BT.601/BT.656)/D (ITU-R

BT.601/BT.656); 143,177,270, 360 Mb/s

Component serial digital signal: 540

Mb/s

(Selectable by auto or manual settings)

Input return loss:

15 dB or more (at 5 MHz to 540 MHz)

Cable length:

143, 177, 270, 360 Mb/s: 200 m max.

540 Mb/s: 150 m max.

(When using a Belden 8281, Fujikura

5C2V or equivalent coaxial cable)

Serial digital outputs:

SDI OUT connectors (BNC type) (8; 4 for each channel)

0.8 Vp-p

610%, 75

Output return loss:

15 dB or more (at 5 MHz to 540 MHz)

Rise time/fall time:

0.5 to 0.75 ns (20% and 80% amplitude points)

Overshoot:

Less than 10%

Alignment jitter:

Less than 0.2 UIp-p (UI = Unit Interval)

DC offset:

Less than 0

60.5 V

General

Power requirements:

+ 5 V DC: 0.6 A (supplied from the

PFV-L Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches) (h/d)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

140 g (5 oz)

Connector panel:

100 g (4 oz)

525/625

COMPONENT

DIGITAL or

NTSC/PAL

COMPOSITE

DIGITAL

SDI IN 1

SDI IN 2

Rear Panel

SDI OUT 1-1

SDI OUT 1-2

SDI OUT 1-3

SDI OUT 1-4

SDI OUT 2-1

SDI OUT 2-2

SDI OUT 2-3

SDI OUT 2-4

525/625

COMPONENT

DIGITAL or

NTSC/PAL

COMPOSITE

DIGITAL

80

*SGC_0069-0098 02.3.16 5:03 PM Page 81

Interface Processor L Series

BKPF-L613C

Monitoring SDI Distribution Board

The BKPF-L613C monitoring SDI distribution board accepts a 525/625 component serial digital video signal and distributes it to four outputs. An active loop-through output of the input signal is also provided. A D to A converter also provides four analog outputs for monitoring purposes. These monitoring outputs can provide either four composite signals, or a single composite output plus a YUV or RGB output. The output cable length can be up to 200 m (Belden 8281, Fujikura 5C2V or equivalent cable).

Features

* Distributes a 525/625 component serial digital input signal to four outputs * Analog video monitoring outputs

(composite analog, Y/U/V or R/G/B component analog) *

Active through output * Supports EDH

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Rear Panel

81

*SGC_0069-0098 02.3.16 5:03 PM Page 82

Specifications

Inputs/outputs

Serial digital input:

SDI IN connector (BNC type) (1)

0.8 Vp-p

610%, 75 Ω

525/625 component serial digital signal conforming to SMPTE259M-C (ITU-R

BT.601/BT.656), 270 Mb/s

Serial digital outputs:

Active-through output connectors (BNC type) (4)

0.8 Vp-p

610%, 75

Serial digital video signal of the same format as that to the input connector

SDI OUT connectors (BNC type) (4)

0.8 Vp-p

610%, 75

Serial digital video signal of the same format as that to the input connector

Analog outputs:

MONITOR OUT connectors (BNC type) (4)

4 NTSC/PAL composite analog video signals or 1 each R/G/B signals or 1 each

Y/U/V signals and 1 NTSC/PAL composite analog video signals

RGB signals:

R: 0.7 Vp-p, 75

G: 0.7 Vp-p, 75

B: 0.7 Vp-p, 75

YUV (CCIR level, 625 mode only) signals:

Y: 1.0 Vp-p, 75

(incl. Y sync 300 mV)

B-Y: 0.7 Vp-p, 75

R-Y: 0.7 Vp-p, 75

Defined with the color bar signal

100/0/100/0

YUV (Betacam 7.5% setup, 525 mode only) signals:

Y: 1.0 Vp-p, 75

(incl. Y sync 286 mV)

B-Y: 0.7 Vp-p, 75

R-Y: 0.7 Vp-p, 75

Defined with the color bar signal

100/7.5/77/7.5

YUV (Betacam 0% setup, 525 mode only) signals:

Y: 1.0 Vp-p, 75

(incl. Y sync 286 mV)

B-Y: 0.756 Vp-p, 75

R-Y: 0.756 Vp-p, 75

Defined with the color bar signal 100/0/75/0

NTSC composite video (525 mode only) signals:

1.0 Vp-p, 75

(incl. Y sync 286 mV)

Defined with the color bar signal

100/7.5/77/7.5

PAL composite video (625 mode only) signal:

1.0 Vp-p, 75

(incl. Y sync 286 mV)

Defined with the color bar signal 100/0/75/0

Data transmission

Channel coding:

Scrambled NRZI

Transmission speed:

Input: 270 Mb/s

Amplitude:

0.8 Vp-p

610%

Interface Processor L Series

Cable length:

200 m max. (When using a Belden 8281,

Fujikura 5C2V or equivalent coaxial cable)

Digital input/output return loss:

15 dB or more (5 MHz to 270 MHz)

Signal forma:

525/625 component serial digital signal conforming to SMPTE259M-C (ITU-R

BT.601/BT.656), 270 Mb/s

Video characteristics

Sampling frequency:

Y: 13.5 MHz R-Y, B-Y: 6.75 MHz

Composite signal: 27 MHz

Digitization:

8 bits (Only for the composite signals, interpolating 8 bits to 10 bits.)

Bandwidth:

Y, R, G, B composite: 5 MHz

R-Y, B-Y: 2 MHz

Y, R-Y, B-Y phase error:

20 ns or less

K factor (2T pulse):

1% or less

Signal-to-noise ratio:

Y, R-Y, B-Y: 48dB or more

Composite signal: 54 dB or more

(when the lamp signal is input)

DG:

2% or less

DP:

2° or less

System delay:

Approx. 2.3 ms

EDH:

Conforms to SMPTE RP165

General

Power requirements:

+5 V DC: 1.0 A

(Supplied from the PFV-L Series Interface

Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(10 5/8 x 3 1/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

Approx. 150 g (5 oz)

Connector panel:

Approx. 120 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

RE-

CLOCKING

EDH 525/625 COMPONENT SDI IN

ACTIVE LOOP-THROUGH

D/A

SDI OUT x 4

(FOR MONITORING)

COMPOSITE ANALOG VIDEO OUT x4

(NTSC/PAL) or

Y/U/V + COMPOSITE ANALOG VIDEO OUT x 1 or

R/G/B + COMPOSITE ANALOG VIDEO OUT x 1

82

*SGC_0069-0098 02.3.16 5:03 PM Page 83

Interface Processor L Series

BKPF-L632

Monitoring Composite Encoder Board

The BKPF-L632 is 525/625 component serial digital to

NTSC/PAL composite analog encoder board. It has two component inputs, and provides three distribution outputs from each input. Either 525 or 625-line input signals can be converted and encoded to NTSC/PAL composite analog video signals. 8-bit processing is used to provide output signals suitable for picture monitoring purposes.

The BKPF-L632 is an ideal system integration component, meeting the need to provide multi-channel picture monitoring in video systems.

Features

* Two 525/625 component serial digital inputs with active loop-through * Converts and distributes each input signal to three NTSC/PAL composite analog outputs * Accepts either 525-line or 625-line signals with auto selection function (manual selection also available with on-board switch) * 7.5 IRE setup ON/OFF selectable for 525-line signals * 8-bit processing for monitoring purpose * SDI input presence lamp * -5 V warning lamp

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

Installation guide (1)

Installtion manual (1)

Slot number label (1 set) (1)

EX-731 Extension Board (Part No.A-8322-598-A) (1)

Specifications

Inputs/outputs

Serial digital inputs:

SDI IN connectors (BNC type) (2)

525/625 component serial digital signal conforming to SMPTE259M-C (ITU-R

BT.601/BT.656), 270 Mb/s

Input return loss:

15 dB or more (at 5 MHz to 270 MHz)

Cable length:

200 m max. (When using a Belden 8281,

Fujikura 5C2V or equivalent coaxial cable)

Serial digital outputs:

Active loop-through output connectors

(BNC type) (2)

0.8 Vp-p

610%, 75 Ω

Output return loss:

15 dB or more (at 5 MHz to 540 MHz)

Rise time/fall time:

0.5 to 0.75 ns

(20% and 80% amplitude points)

Overshoot:

Less than 10%

Alignment jitter:

Less than 0.2 UIp-p (UI = Unit Interval)

DC offset:

Less than

60.5 V

Analog outputs:

VIDEO OUT connectors (BNC type)

(6; 3 for each channel)

NTSC: 1.0 Vp-p

63% (714 mVp-p/286 mVp-p), 75

PAL: 1.0 Vp-p

63%, (700 mVp-p/300 mVp-p),

75

Analog Video Characteristics

Sampling frequency:

27.0 MHz

Resolution:

10 bits (conversion from 8 bits to 10 bits)

Signal to noise ratio:

54 dB or more

Frequency response:

60.5 dB

DG/DP:

NTSC: Less than 2%/2°

PAL: Less than 2%/3.5°

Y/C delay:

Less than

620 ns

General

Power requirements:

+ 5 V DC: 1.0 A (supplied from the PFV-L

Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 F°)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Rear Panel

Mass

Board:

140 g (5 oz)

Connector panel:

100 g (4 oz)

Service parts: Extension board (Part No.A-8322-598-A),

Maintenance manual

525/625

COMPONENT

DIGITAL

SDI IN 1

ACTIVE

LOOP-THROUGH

SDI IN 2

ACTIVE

LOOP-THROUGH

S/P

CONV.

DIGITAL

ENCODER

S/P

CONV.

DIGITAL

ENCODER

VIDEO OUT 1-1

VIDEO OUT 1-2

VIDEO OUT 1-3

VIDEO OUT 2-1

VIDEO OUT 2-2

VIDEO OUT 2-3

NTSC/PAL

COMPOSITE

ANALOG

83

*SGC_0069-0098 02.3.16 5:03 PM Page 84

Interface Processor L Series

BKPF-L641

NTSC/PAL To 4:2:2 Decoder Board

The BKPF-L641 is a decoder board that converts an

NTSC/PAL composite analog input signal into a 4:2:2 component serial digital video output signal. This decoder board features 10-bit digital internal processing, a three-line adaptive comb filter and a frame synchronizer.

In conjunction with the BKPF-L642 4:2:2 to NTSC/PAL encoder board, the color frame ID inserter function avoids the reverse color framing that may be generated by the encode/decode chain. It maintains the content of the VBI.

Four distribution outputs are provided. An internal test signal generator is included for maintenance purposes.

Features

*High performance NTSC/PAL decoder to component SDI

— 10-bit 4:2:2 internal processing; Supports

SMPTE259M-C; One equalized input with passive loop-through output; Four distribution outputs; Black burst reference input with passive loop-through output *3-line adaptive comb filter *NTSC/PAL selectable — Setup removal on/off selectable for NTSC signal *Built-in frame synchronizer — On /Off selectable; Auto/Manual freeze selectable (External reference mode only); H/V phase adjustment *Color frame ID insertion *Maintains the content of the VBI *EDH insertion *Built-in test signal generator

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

Installation guide (1)

Installation manual (1)

Slot number label (1 set) (1)

Rear Panel

84

*SGC_0069-0098 02.3.16 5:03 PM Page 85

Interface Processor L Series

Specifications

Inputs/outputs

Analog video input:

Analog IN connector (BNC type) (1),

1.0 Vp-p, 75

, NTSC/PAL composite analog video signal

Reference input:

REF IN connector (BNC type) (1), 0.3

Vp-p

610%,

75

, black burst signal

Analog video output:

Passive loop-through output connector

(BNC type) (1),

1.0 Vp-p, 75

, NTSC/PAL composite analog video signal

Serial digital outputs:

SDI OUT Connectors (BNC type) (4),

0.8 Vp-p, 75

, SDI conforming to

SMPTE259M-C, 270 Mb/s

Reference output:

Passive loop-through output connector

(BNC type) (1)

Cable length:

200 m max. (with Belden 8281, Fujikura

5C2V or equivalent coaxial cable)

Channel coding:

Scrambled NRZI

Digital output return loss:

15 dB or more (5 MHz to 270 MHz)

Video characteristics

Quantization:

10 bits

Sampling frequency

Input:

28.636 MHz (NTSC input), 35.468

MHz (PAL input)

Output:

13.5 MHz (Y), 6.75 MHz (B-Y/R-Y)

Band width:

5.75 MHz (Y)

K factor (2T pulse):

1% or less

Signal-to-noise ratio:

58 dB or more (using Flat Field)

Memory:

4 fields

Processing delay:

74 µs (NTSC)/137 µs (PAL)

Phase adjustment range

Line:

-2 H, -1 H,

60 H, +1 H

INPUT Lock mode:

0.1 to 9 µs, 37 ns step

External REF mode:

-4.5 to +4.5 µs, 37 ns step

Test signal:

75% color bars with 100% white

General

Power requirement:

+5 V DC: 1.4A

(Supplied from PFV-L Series Interface

Unit)

Operating temperature:

5 °C to 40 °C (41 °F to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

77 x 267 mm

(3 1/8 x 10 3/4 inches)

Connector panel (H x W):

85 x 33 mm

(3 3/8 x 1 5/16 inches)

Mass

Board:

Approx. 170 g (6 oz)

Connector panel:

Approx. 100 g (4 oz)

The total power consumption of the installed function boards should not exceed 13 A at 5 V

(PFV-L10) . Service part: Maintenance manual

NTSC/PAL COMPOSITE

ANALOG VIDEO

VIDEO IN

PASSIVE LOOP-THROUGH

REF IN

PASSIVE LOOP-THROUGH

85

A/D DEC

CLK

SDI OUT 1

SDI OUT 2

SDI OUT 3

SDI OUT 4

525/625 COMPONENT

SERIAL DIGITAL

VIDEO OUTPUTS

*SGC_0069-0098 02.3.16 5:03 PM Page 86

Interface Processor L Series

BKPF-L642

4:2:2 To NTSC/PAL Encoder Board

The BKPF-L642 is an encoder board that converts a component 4:2:2 serial digital signal into an NTSC/PAL composite analog signal. It features 12-bit internal processing (10-bit signal path), 2x over sampling and a line synchronizer. In conjunction with the BKPF-L641 4:2:2 to NTSC/PAL decoder board, the color frame ID extractor function avoids the reverse color framing that may be generated by the encode/decode chain. It maintains ancillary data within the VBI. An internal test signal generator is provided for maintenance purposes. Four distribution outputs are provided. The BKPF-L642 uses

10-bit signal path for quality-critical application such as distribution or on-air transmission applications, while the

BKPF-L632 8-bit NTSC/PAL encoder board is designed to support monitoring solution for 4:2:2 serial digital environment at a lower cost.

Features

*High performance NTSC/PAL encoder — 12-bit internal processing; Supports SMPTE259M-C; One equalized input with active loop-through output; Four distribution outputs; Black burst reference input with passive loop-through output *NTSC/PAL selectable — Setup on/off selectable for NTSC signal *Built-in line synchronizer — H phase adjustment *Color frame ID extraction *Maintains VBI data to support Closed Caption

*EDH monitoring *Built-in test signal generator

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

Installation guide (1)

Installation manual (1)

Slot number label (1 set) (1)

Rear Panel

86

*SGC_0069-0098 02.3.16 5:03 PM Page 87

Interface Processor L Series

Specifications

Inputs/outputs

Serial digital input:

SDI IN connector (BNC type) (1),

0.8 Vp-p, 75

, 4:2:2 component serial digital signal, conforming to

SMPTE-259M-C, 270 Mb/s

Reference input:

REF IN connector (BNC type) (1), 0.3

Vp-p

610%, 75

, black burst signal

Digital input return loss:

15 dB or more (5 MHz to 270 MHz)

Serial digital output:

Active loop-through output connector

(BNC type) (1),

0.8 Vp-p, 75

, 4:2:2 component serial digital signal, conforming to

SMPTE-259M-C, 270 Mb/s

Analog video outputs:

ANALOG OUT connectors (BNC type)

(4),

NTSC/PAL composite analog video signal, 1.0 Vp-p, 75

Reference output:

Passive loop-through output connector

(BNC type) (1),

0.3 Vp-p

610%, 75 Ω

, black burst signal

Digital output return loss:

15 dB or more (5 MHz to 270 MHz)

Cable length:

200 m max. (with Belden 8281, Fujikura

5C2V or equivalent coaxial cable)

Channel coding:

Scrambled NRZI

Video characteristics

Sampling frequency:

27 MHz

Quantization:

10 bits

Band width:

5.75 MHz

DG:

1% or less

DP:

Within 1 °

K factor (2T pulse):

1% or less

Signal-to-noise ratio:

60 dB or more (using Flat Field)

Y/C delay:

610 ns or less

Processing delay:

4 µs (NTSC)/7.5 µ (PAL)

Phase adjustment range

Line:

-2 H, -1 H,

60 H, +1 H

Input lock mode:

0.1 to 8.5 µs (NTSC), 0.1 to 7.0 µs

(PAL)

External REF mode:

-4.2 to +4.2 µs (35 ns steps NTSC),

-3.5 to +3.5 µs (28 ns steps PAL),

Test signal 75% color bars with 100% white

General

Power requirement:

+5 V DC: 1.2 A (supplied from PFV-L

Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

77 x 267 mm

(3 1/8 x 10 3/4 inches)

Connector panel (H x W):

33 x 85 mm

(3 3/8 x 1 5/16 inches)

Mass

Board:

Approx. 150 g (5 oz)

Connector panel:

Approx. 100 g (4 oz)

Service part: Maintenance manual

525/625 COMPONENT

SERIAL DIGITAL

SDI IN

ACTIVE

LOOP-THROUGH

REF IN

PASSIVE LOOP-THROUGH

87

ENC D/A

CLK

VIDEO OUT 1

VIDEO OUT 2

VIDEO OUT 3

VIDEO OUT 4

NTSC/PAL COMPOSITE

ANALOG VIDEO

*SGC_0069-0098 02.3.16 5:03 PM Page 88

Interface Processor L Series

BKPF-L653

AES/EBU Distribution Board

The BKPF-L653 is a AES/EBU distribution board that operates in single eight-output or dual four-output modes for 75

AES/EBU signals. Ten BKPF-L653 fit in one 2U

PFV-L10 frame and provide high packing density of up to

80 AES/EBU distribution outputs within 2U rack space.

Features

* Single or dual distribution configuration (selectable with on-board switch) * Eight distribution outputs from one

AES/EBU stereo pair input * Four distribution outputs from two AES/EBU stereo pair inputs * 75

Ω unbalanced

AES/EBU inputs and outputs * Automatic cable equalization * Data re-clocking for jitter reduction

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Input/output connectors

Audio inputs:

AES/EBU IN connectors (BNC type) (2),

75

, unbalanced

Audio outputs:

AES/EBU OUT connectors (BNC type)

(8), 75

, unbalanced

Input characteristics

Standard input level:

1 V p-p

Sampling frequency:

48 kHz, 44.1 kHz, 32 kHz

Input jitter margin:

25 ns or more

Input return loss:

25 dB or more (0.1 MHz to 6 MHz)

Cable length:

1000 m max.

(when using a Belden 8281 coaxial cable, Fujikura 5C2V or equivalents)

Output characteristics

Output signal level:

1 V p-p

6 10% (Terminated with 75

)

DC offset:

Within

6 50 mV

Waveform rising/falling:

37

6 7 ns

Output jitter:

Within 10 ns

Output return loss:

25 dB or more (0.1 MHz to 6 MHz)

System delay:

Approx. 150 ns (during re-clocking)

Approx. 50 ns (during non re-clocking)

General

Power requirements:

+5 V DC: 0.22 A

(Supplied from the PFV-L Series

Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

Approx. 120 g (4 oz)

Connector panel:

Approx. 120 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

AES/EBU IN 1

AES/EBU IN 2

88

Rear Panel

AES/EBU OUT 1-1

AES/EBU OUT 1-2

AES/EBU OUT 1-3

AES/EBU OUT 1-4

AES/EBU OUT 2-1/1-5

AES/EBU OUT 2-2/1-6

AES/EBU OUT 2-3/1-7

AES/EBU OUT 2-4/1-8

*SGC_0069-0098 02.3.16 5:03 PM Page 89

Interface Processor L Series

BKPF-L703A

Analog Video Distribution Board

The BKPF-L703A analog video distribution board accepts an NTSC/PAL composite analog video signal and distributes it to eight outputs. The output cable length can be up to 300 m (Belden 8281, Fujikura 5C2V or equivalent cable).

Features

* Distributes an NTSC/PAL composite analog input signal to eight outputs * Differential input * Passive loop-through output * Equalization for up to 300 m cable (Belden 8281,

Fujikura 5C2V or equivalent cable) * Clamping ON/OFF selectable

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Rear Panel

89

*SGC_0069-0098 02.3.16 5:03 PM Page 90

Interface Processor L Series

Specifications

Inputs/outputs

Video input:

VIDEO IN connector (BNC type) (1)

Video outputs:

Loop-through output connector (BNC type) (1)

VIDEO OUT connectors (BNC type) (8)

1 Vp-p, 75

Video characteristics

Frequency response:

5 MHz (-0.3 dB)

30 MHz (+0/-3 dB)

Input return loss:

40 dB or more (8 MHz or less)

K factor:

1% or less

DG:

1% or less

DP:

1% or less

Signal-to-noise ratio:

70 dB or more (using FLAT FIELD)

Cable length:

300 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

General

Power requirements:

+5 V DC: 250 mA (supplied from the

PFV-L Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

267 x 77 mm

(10 5/8 x 3 1/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

Approx. 110 g (4 oz)

Connector panel:

Approx. 110 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

VIDEO IN

PASSIVE

LOOP-THROUGH

Differential

Input

EQ

VIDEO OUT 1

VIDEO OUT 2

VIDEO OUT 3

VIDEO OUT 4

VIDEO OUT 5

VIDEO OUT 6

VIDEO OUT 7

VIDEO OUT 8

90

*SGC_0069-0098 02.3.16 5:03 PM Page 91

Interface Processor L Series

BKPF-L704

Black Burst Regenerator Board

The BKPF-L704 is an analog I/O black burst regenerator board with a range of NTSC system applications. For example, it can be used in a mixed analog/digital system, delaying the sync signal to the analog equipment to compensate for the longer video delay of the digital equipment. The BKPF-L704 is an ideal and cost-effective tool for use in systems that are making the transition from analog to digital—where both analog and digital equipment has to co-exist. For this type of application, the BKPF-L704 exactly meets customer needs.

Features

* Regenerates black burst signals * NTSC composite analog input with passive loop-through * Six black burst outputs * Continuously variable delay of -4 H to +3 H * 0

IRE to 44 IRE variable setup * Video input presence lamp

* SCH warning lamp * -5 V warning lamp

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Inputs/outputs

Video input:

VIDEO IN connectors (BNC type) (1)

0.286 Vp-p (SYNC, Burst) at 75

Input return loss:

40 dB or more (at above 5 MHz)

Analog output:

Passive loop-through output connector

(BNC type) (1)

Black burst outputs:

BLACK BURST OUT connectors (BNC type) (6), conforming to RS-170A

Output level:

SYNC: 0.286 Vp-p

62% at 75

BURST: 0.286 Vp-p

65% at 75

SCH:

Less than

65°

Output return loss:

40 dB or more (above 5 MHz)

H phasing:

Approx. -4.5 to + 59.0 µs (all “0” position)

V phasing:

-4 to +3 H

General

Power requirements:

+ 5 V DC: 0.35 A (supplied from the

PFV-L Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

140 g (5 oz)

Connector panel:

100 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

NTSC

COMPOSITE

ANALOG

VIDEO IN

PASSIVE

LOOP-THROUGH

BLACK

BURST

RE-GEN.

91

Rear Panel

BLACK BURST OUT 1

BLACK BURST OUT 2

BLACK BURST OUT 3

BLACK BURST OUT 4

BLACK BURST OUT 5

BLACK BURST OUT 6

*SGC_0069-0098 02.3.16 5:03 PM Page 92

Interface Processor L Series

BKPF-L723

Video Delay Distribution Board

The BKPF-L723 is a video delay distribution board with an adjustable delay range of 50 ns to 1430 ns. It accepts either an NTSC or PAL analog video signal, and distributes the delayed video signal to eight outputs. Up to 300 m of output video cable can be equalized. The board is designed for a range of different applications, making it a valuable system integration tool.

Features

* Distributes an NTSC or PAL analog signal, with a delay function * Adjustable delay range, 50 ns to 1430 ns *

Eight distribution outputs * Passive loop-through output *

Equalization for up to 300 m cable (Belden 8281, Fujikura

5C2V or equivalent cable) * Clamping ON/OFF selectable

* Output level adjustment range:

6

2 dB * -5 V warning lamp

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Inputs/outputs

Video input:

VIDEO IN connector (BNC type) (1), 1

Vp-p

Input return loss:

40 dB or more (at under 5 MHz)

Video outputs:

VIDEO OUT connectors (BNC type) (8)

Passive loop-through output connector

(BNC type) (1)

Cable length:

300 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

Output return loss:

40 dB or more (at above 5 MHz)

System delay:

Approx. 50 to 1430 ns

350 ns x 3 STEP

75 ns x 5 STEP

15 ns x 5 STEP

FINE adjustment: 15 ns

Analog Video Characteristics

Signal to noise ratio:

70 dB or more (10 kHz to 6 MHz)

Frequency response:

Less than -2.5 dB

DG/DP:

Less than 0.5%/0.5°

K factor:

0.5% or less

General

Power requirements:

+ 5 V DC: 0.6 A (supplied from the

PFV-L Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

170 g (6 oz)

Connector panel:

120 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

NTSC/PAL

COMPOSITE

ANALOG

VIDEO IN

PASSIVE

LOOP-THROUGH

DLY UNIT

92

Rear Panel

VIDEO OUT 1

VIDEO OUT 2

VIDEO OUT 3

VIDEO OUT 4

VIDEO OUT 5

VIDEO OUT 6

VIDEO OUT 7

VIDEO OUT 8

NTSC/PAL

COMPOSITE

ANALOG

*SGC_0069-0098 02.3.16 5:03 PM Page 93

Interface Processor L Series

BKPF-L751

Audio A to D Converter Board

The BKPF-L751 is a dual channel audio analog to digital converter board that accepts up to two analog audio stereo inputs and converts them into two AES/EBU format outputs. The signals carried by the two AES/EBU outputs can be interchanged. Conversion is at a resolution of 24 bits and at a sampling frequency of 48 kHz. Either a video reference (NTSC, PAL or HD) or a 48 kHz audio word clock can be used as a reference signal. A word clock output is available by setting an internal switch on the board so that other cascade-connected BKPF-L751 boards can be operated synchronously.

Features

* Converts two stereo analog audio signals to two

AES/EBU digital audio signals * 24 bits conversion at 48 kHz sampling frequency * The signals carried by the two

AES/EBU outputs can be interchanged * Sync input accepts an NTSC/PAL/HD video or 48 kHz word clock signal (manual selection with on-board switch) * Word

Clock output available (selectable with on-board switch) *

Output level adjustment range:

6

4 dB * -5 V warning lamp

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

Phoenix type 6-pin connectors (2)

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Rear Panel

93

*SGC_0069-0098 02.3.16 5:03 PM Page 94

Interface Processor L Series

Specifications

Inputs/outputs

Analog audio inputs:

AUDIO IN connectors (Phoenix type

6-pin)

(2; 4 channels -2 stereo pairs)

Input level:

+ 4 dBm (600

/20 k

Ω selectable, balanced)

Reference input:

REF VIDEO/WORD CLOCK IN connector

(BNC type) (1)

Video input:

0.3 Vp-p (525/29.9 Hz, 625/25 Hz,

1125/60 Hz)

Word sync:

0.5 to 5.0 Vp-p (48 kHz)

Input return loss:

40 dB or more (at 5 MHz, 75

Ω terminated)

AES/EBU audio outputs:

AES/EBU OUT connectors (BNC type)

(2; 1 for each stereo pair)

1.0 Vp-p

610%, 75 Ω

Output return loss:

25 dB or more (at 0.1 MHz to 6.0 MHz)

Rise time/fall time:

30 to 44 ns

Alignment jitter:

Less than

620 nsp-p

DC offset:

Less than 0

650 mV

Reference output:

Passive loop-through output connector

(selectable to Word Clock output connector)

(BNC type) (1)

Word sync output:

1.0 Vp-p or 2.8 Vp-p, 48 kHz

Video characteristics

Sampling frequency:

48 kHz

Resolution:

24 bits

Head room:

20 dB (at +4 dBm)

Channel coding:

AES/EBU format

Frequency response:

Within +0.1/-0.2 dB (20 Hz to 20 kHz)

Distortion:

Less than 0.02%

Signal to noise ratio:

103 dB or more

Crosstalk:

Less than -90 dB (at under 15 kHz)

CMRR (Common Mode Rejection Ratio):

More than 80 dB (at 60 Hz)

Phase difference between channels:

Less than 4° (at 1 kHz)

Encoding delay:

Approx. 0.9 ms

General

Power requirements:

+ 5 V DC: 1.1 A (supplied from the

PFV-L Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

160 g (6 oz)

Connector panel:

110 g (4 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

AUDIO IN CH-1

AUDIO IN CH-2

AUDIO IN CH-3

AUDIO IN CH-4

REF IN

LOOP-THROUGH or WORD CLOCK OUT

ADC

ADC

CLOCK

GEN.

94

AES/EBU OUT 1

AES/EBU OUT 2

*SGC_0069-0098 02.3.16 5:03 PM Page 95

Interface Processor L Series

BKPF-L752

Audio D to A Converter Board

The BKPF-L752 is a dual channel digital audio to analog audio converter board. It converts each of two AES/EBU stereo-digital input signals into two monaural analog audio signals at a resolution of 24 bits/sample at 48 kHz. A de-emphasis function is provided.

Features

* Converts AES/EBU digital signals to analog audio signals * 24 bits conversion at 48 kHz sampling frequency

* Dual AES/EBU inputs are each output as two analog signals * De-emphasis ON/OFF selectable with on-board switch * AES/EBU channel status lamp *

6

12 V warning lamp

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

Phoenix type 6-pin connectors (2)

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Inputs/outputs

AES/EBU digital audio inputs:

AES/EBU IN connectors (BNC type) (2),

75

Cable length:

1200 m max. (1 Vp-p input)

Input return loss:

25 dB or more (at 0.1 MHz to 6 MHz)

Analog audio outputs:

AUDIO OUT connectors (Phoenix type

6-pin)

(2; 4 channels -2 stereo pair)

Output level:

+4 dBm

Maximum output level:

+24 dBm (at 0 dB FS input)

Output impedance:

Approx. 22

Video characteristics

Sampling frequency:

48 kHz

Resolution:

24 bits

Head room:

20 dB (at +4 dBm)

Channel coding:

AES/EBU format

Frequency response:

Within 20 Hz to 20 kHz, +0.1/-0.2 dB

Distortion:

Less than 0.02%

Signal to noise ratio:

95 dB or more

Crosstalk:

Less than -90 dB (at under 15 kHz)

Phase difference between channels:

Less than 4° (at 1 kHz)

Decoding delay:

Approx. 0.7 ms

General

Power requirements:

+5 V DC: 1.3 A (supplied from the

PFV-L Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

180 g (6 oz)

Connector panel:

90 g (3 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

AES/EBU IN 1

AES/EBU IN 2

DAC

DAC

95

Rear Panel

ANALOG AUDIO OUT CH-1

ANALOG AUDIO OUT CH-2

ANALOG AUDIO OUT CH-3

ANALOG AUDIO OUT CH-4

*SGC_0069-0098 02.3.16 5:03 PM Page 96

Interface Processor L Series

BKPF-L753A

Analog Audio Distribution Board

The BKPF-L753A analog audio distribution board distributes an analog stereo audio signal to four outputs or an analog monaural audio signal to eight outputs. A gain control allows the input reference level to be varied between -4 dBm and +12 dBm. Phoenix type connector for each distribution block carries its input and output signals.

Features

* Single or dual distribution configuration (selectable with on-board switch) * Eight distribution outputs of a mono analog audio input * Four distribution outputs of a stereo analog audio input * Low noise * Gain control function

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

Phoenix type 15-pin connectors (2)

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Inputs/outputs

Inputs/outputs (selectable with on-board switch)

Stereo:

1 input/4 outputs

Monaural:

1 input/8 outputs

Input impedance (selectable with on-board switch):

600

/20 k

Standard input/output level:

+4 dBm

Maximum input level:

+28 dBm

Maximum output level:

+24 dBm (600

Ω load)

CMRR:

80 dB or more (at 60 Hz)

Frequency response:

60.1 dB

(20 Hz to 20 kHz, at 1 kHz standard, standard level)

Input/output gain settings:

-8, -4, 0, +4, +8 dB (selectable)

Gain control range:

62 dB

Distortion:

0.01% or less

(20 Hz to 20 kHz, at +24 dBm output, with 0 dB gain)

Signal-to-noise ratio:

115 dB or more (at +24 dBm output, 30 kHz LPF)

Crosstalk:

-95 dB or less

(20 Hz to 20 kHz at +24 dBm input/output, each channel)

General

Power requirements:

+5 V DC: 1.2 A

(Supplied from the PFV-L Series

Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

Mass

(1 5/16 x 3 3/8 inches)

Board:

Approx. 180 g (6 oz)

Connector panel:

Approx. 70 g (2 oz)

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

Rear Panel

ANALOG AUDIO IN 1

ANALOG AUDIO IN 2

ANALOG AUDIO OUT 1

ANALOG AUDIO OUT 2

96

*SGC_0069-0098 02.3.16 5:03 PM Page 97

Interface Processor L Series

BKPF-L754

Audio Signal Generator Board

The BKPF-L754 is an audio signal generator board that has a dual audio signal generator. Each signal generator can be selected between 1 kHz or 440 Hz (440 Hz switchable to 400 Hz) via GPI or on-board switch.

Three-channel outputs of each of these two signals are provided. Normally the left and right channels carry the same frequency, but they can be switched to carry different frequencies. The BKPF-L754 is especially of use as an audio identification for video sources, or as a centralized tone source.

Features

* Provides two channels of test signals * Independent frequency setting of both signals to either 440 Hz or 1 kHz (440 Hz can be changed to 400 Hz with on-board switch) via GPI or a switch on the front panel * Three outputs of each test signal * Output level adjustment

SELECTABLE: 0/+4/+8 dBm

6

0.1 dB VARIABLE: -2 to

+10 dBm *

6

12 V internal power status lamp

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

Phoenix type 15-pin connectors (2)

EX-731 Extension Board (Part No.A-8322-598-A)

(1)

Specifications

Inputs/outputs

Audio outputs (including remote)

OUT and CONT connectors:

(Phoenix type 15-pin) (2)

(6 channels - 3 stereo pair and 1 GPI)

Video characteristics

Output frequency:

400 Hz/440 Hz/1 kHz

610%

Distortion:

Less than 0.01%

Output level:

FIX: 0/+4/+8 dBm

60.1 dB (600 Ω loaded)

VARIABLE: -2 to +10 dBm (600

Ω loaded)

General

Power requirements:

+ 5 V DC: 0.5 A (supplied from the PFV-L

Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

140 g (5 oz)

Connector panel:

100 g (4 oz)

440 or

400Hz

SG

ATT

ATT

1kHz

SG

Service parts: Extension board (Part No.A-8322-598-A),

Maintenance manual

97

Rear Panel

ANALOG AUDIO OUT 1-1

ANALOG AUDIO OUT 1-2

ANALOG AUDIO OUT 1-3

ANALOG AUDIO OUT 2-1

ANALOG AUDIO OUT 2-2

ANALOG AUDIO OUT 2-3

*SGC_0069-0098 02.3.16 5:03 PM Page 98

Interface Processor L Series

BKPF-L803

S-BUS Distribution Board

The BKPF-L803 is a two-input, eight-output S-BUS distribution board. It can be switched to provide four outputs from each of its inputs, or eight outputs from one input. The Sony S-BUS router control system has already earned an excellent reputation for the operational flexibility it brings to many system applications. The BKPF-L803 provides a further enhancement to the capability of the

Sony router system by increasing the transmission distance of S-BUS signals by 500 m to a total of 1,000 m.

It also provides multiple S-BUS control ports, a feature of particular use in OB vehicles.

Features

* Two inputs * Four distribution outputs from each input *

Switchable to a single input, eight output configuration *

Equalization for up to 500 m cable (Belden 8281, Fujikura

5C2V or equivalent cable)

The BKPF-L Series function boards install in the PFV-L Series Interface Units in any combination with other BKPF-L Series function boards.

Applicable Models

PFV-L10 Interface unit

Supplied Accessories

Operation manual (1)

Installation manual (1)

Slot number label (1)

EX-731 Extension Board (Part

No.A-8322-598-A) (1)

Specifications

Inputs/outputs

A, B inputs:

IN connectors (BNC type) (2)

S-BUS, 2.0 Vp-p -0.5 V, 75

A, B output:

OUT connectors (BNC type) (8; 4 for each channel)

S-BUS, 2.0 Vp-p

60.5 V, 75

Cable length:

500 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

General

Power requirements:

+5 V DC: 0.55 A (supplied from the

PFV-L Series Interface Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x D):

77 x 267 mm

(3 1/8 x 10 5/8 inches)

Connector panel (W x H):

33 x 85 mm

(1 5/16 x 3 3/8 inches)

Mass

Board:

Approx. 100 g (4 oz)

Connector panel:

Approx. 100 g (4 oz)

S-BUS

IN-1

S-BUS

DA-1

4-8

SET

S-BUS

IN-2

S-BUS

DA-2

Service parts: Extension board (Part

No.A-8322-598-A), Maintenance manual

98

Rear Panel

3

4

1

2

S-BUS

OUT

1 (5)

2 (6)

3 (7)

4 (8)

*SGC_0099-0116 02.3.16 5:04 PM Page 99

Interface Processor D Series

HDTV

PFV-HD50A . . . . . . . . . . . . . 100

PFV-HD300A . . . . . . . . . . . . 101

HKPF-101 . . . . . . . . . . . . . . 102

HKPF-102 . . . . . . . . . . . . . . 103

HKPF-103M. . . . . . . . . . . . . 104

HKPF-105M. . . . . . . . . . . . . 105

HKPF-106M. . . . . . . . . . . . . 106

HKPF-1125A . . . . . . . . . . . . 107

HKPF-525V . . . . . . . . . . . . . 109

HKPF-525AV . . . . . . . . . . . . 110

HKPF-D270 . . . . . . . . . . . . . 111

HKPF-E270 . . . . . . . . . . . . . 113

HKPF-9000 . . . . . . . . . . . . . 115

HKDV-900 . . . . . . . . . . . . . . 116

99

*SGC_0099-0116 02.3.16 5:04 PM Page 100

Interface Processor D Series

PFV-HD50A

HD Digital Video Interface Unit

HKPF Series boards provide a range of audio and video signal processing and distribution functions for HDTV signals. The PFV-HD50A HD digital video interface unit accommodates up to four of these boards, providing an interface for HDTV system connections. The interface unit supplies power to the boards, an optional BKPF-PS50A backup power supply can be installed for critical applications. The PFV-HD50A mounts into a standard

19-inch rack and is 3U high.

Features

* Accommodates and powers four function boards *

Accepts all Sony HKPF boards * Redundant power supply option

Supplied Accessories

Operation manual (1)

Installation manual (1)

Optional Accessories

BKPF-PS50A Backup Power Supply Unit

RMM-30 Rack Mount Rail

Optional Boards

HKPF-101 HD A to D Converter Board

HKPF-102 HD D to A Converter Board

HKPF-103M HD Digital Video Distribution Board

HKPF-105M HD Audio/video Multiplexer Board

HKPF-106M HD Audio/Video Demultiplexer Board

HKPF-D270 HDCAM decoder board

HKPF-E270 HDCAM encoder board

HKPF-525AV HD-SD downconverter board

HKPF-525V HD-SD downconverter board

HKPF-1125A HD up-converter board

HKPF-9000 Multi-format converter

BKPF-R70A Routing Switcher Controller Board

Optional Software

BZR-IF310 S-BUS SUB-NET Controller Software

Specifications

Output

STATUS OUT:

D-sub 25-pin connector (1)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

1.8 to 0.9 A

Maximum power supply capacity:

+5 V DC: max. 8 A

For installed boards -5 V DC: max. 8 A

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90%

Dimensions (W x H x D)

424 x 132 x 428 mm

(16 3/4 x 5 1/4 x 16 7/8 inches)

Mass:

Approx. 8 kg (17 lb 10 oz)

(not including the optional boards)

Rear Panel

The total power consumption of the four installed function boards should not exceed 8 at 5 V and 8 at

-5 V.

100

*SGC_0099-0116 02.3.16 5:04 PM Page 101

Interface Processor D Series

PFV-HD300A

HD Digital Video Interface Unit

HKPF Series boards provide a range of audio and video signal processing and distribution functions for HDTV signals. The PFV-HD300A HD digital video interface unit accommodates up to 14 of these boards, providing an interface for HDTV system connections. The interface unit supplies power to the boards, an optional HKPF-PS300 backup power supply can be installed for critical applications. The PFV-HD300A mounts into a standard

19-inches rack and is 7U high.

Features

*Houses up to 14 HKPF series modules *Power supply capacity increase to 31A maximum for +5V DC *Standard

19-inches rack mountable *Redundant power supply option (HKPF-PS300)

Supplied Accessories

Operation Manual (1)

Installation Manual (1)

Optional Boards

HKPF-101 HD A to D Converter Board

HKPF-102 HD D to A Converter Board

HKPF-103M HD Digital Video Distribution

Board

HKPF-105M HD Audio/video Multiplexer

Board

HKPF-106M HD Audio/Video Demultiplexer

Board

HKPF-1125A HD up-converter board

HKPF-525AV HD-SD downconverter board

HKPF-525V HD-SD downconverter board

HKPF-D270 HDCAM decoder board

HKPF-E270 HDCAM encoder board

BKPF-R70A Routing Switcher Controller

Board

Optional Software

BZR-IF310 S-BUS SUB-NET Controller

Software

Optional Peripherals

HKPF-9000 Multi-format converter

Specifications

Outputs

STATUS OUT:

D-sub 25-pin, female (1)

General

Power requirements:

100 to 240 V AC, 50/60Hz

Power consumption:

5.0 to 2.0 A

Power supply capacity

+5 V DC: 31 A max., -5 V DC: 23 A max.

Operating temperature:

5 to 40 °C (41 to +104 °F)

Performance guaranteed temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (No Condensation)

Dimensions (W x H x D):

424 x 310 x 460 mm

(16 3/4 x 12 1/4 x 18 1/8 inches)

Mass:

Approx. 18 kg (39 lb 11 oz)

(Not including the optional boards)

101

Rear Panel

*SGC_0099-0116 02.3.16 5:04 PM Page 102

Interface Processor D Series

HKPF-101

HD A to D Converter Board

The HKPF-101 HD A to D converter board converts an

HD component analog video signal to an HD component serial digital video signal. The input signal can be either in Y/PB /PR or RGB format. Four outputs of the converted signal are provided. The HKPF-101 is switchable to operate between 1080 and 1035 active lines and automatically switches between 59.94 and 60.00 Hz field rate operation.

Features

* Converts an HD component analog signal to an HD component serial digital signal * Supports ISR

The HKPF Series function boards install in the PFV-HD Series Interface Units together with the BKPF Series function boards.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Specifications

Inputs/outputs

Video inputs:

ANALOG IN Y/G, PB /B, and PR /R connectors (BNC type) (1 each)

HD component analog video signals

(SMPTE240M/274M (59.94 or 60.00 Hz) standard) 75

Video outputs:

DIGITAL OUT 1, 2, 3, and 4 connectors (BNC) (1 each)

HD component serial digital video signal conforming to SMPTE292M, 1.5 Gb/s

(BTA S-004B)

Output level:

0.8 Vp-p

610%, 75

Output impedance:

75

, unbalanced

Return loss:

15 dB or more (5 to 750 MHz)

10 dB or more (750 MHz to 1.5 GHz)

Rise/fall time:

270 ps or less, 20% to 80%

Jitter:

270 ps or less

Data rate:

1.4835 GHz or 1.485 GHz

Delay time:

1500 ns or less

ISR output information

Status messages: 1 item

Setup messages: 3 items

General

Power requirements:

+5.0 V DC: 1.3 A, -5.0 V DC: 700 mA

(Supplied from the PFV-HD300A/HD50A

Interface Unit)

Power consumption:

Approx. 11 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

(8 5/8 x 3 7/8 x 1 inches)

Mass

Board:

Approx. 700 g (1 lb 8 oz)

Connector panel:

Approx. 200 g (7 oz)

HD COMPONENT ANALOG

VIDEO INPUT

G / B / R or

Y / P

B

/ P

R

102

A/D

Rear Panel

1

2

3

HD SERIAL DIGITAL

VIDEO OUTPUT

4

*SGC_0099-0116 02.3.16 5:04 PM Page 103

Interface Processor D Series

HKPF-102

HD D to A Converter Board

The HKPF-102 HD D to A converter board converts an

HD component serial digital video signal to an HD component analog video signal. The input is switchable to accept either a Y/PB /PR or RGB format signal. Two sets of outputs are provided. The HKPF-102 automatically switches between 1080 and 1035 active lines and 59.94

or 60.00 Hz field rate operation.

Features

* Converts an HD component serial digital signal to an HD component analog signal * Supports ISR

The HKPF Series function boards install in the PFV-HD Series Interface Units together with the BKPF Series function boards.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Specifications

Inputs/outputs

Video input:

DIGITAL IN connector (BNC type) (1)

HD component serial digital video signal conforming to SMPTE292M, 1.5

Gb/s (BTA S-004B)

Input impedance:

75

, unbalanced

Return loss:

15 dB minimum (5 to 750 MHz)

10 dB minimum (750 MHz to 1.5 GHz)

Cable length:

100 m max. (when using 5C-FB coaxial cable)

Data rate:

1.4835 GHz or 1.485 GHz

Video outputs:

ANALOG OUT Y/G, PB/B, and PR/R connectors (BNC type) (2 sets)

HD component analog video signal

(SMPTE240M/274M (59.94 or 60.00 Hz) standard)

Output impedance:

75

, unbalanced

Output level:

1.0 Vp-p

61% (Y, R, G, B)

0.7 Vp-p

61% (PB, PR)

Frequency characteristics:

60.3 dB (60 Hz to 20 MHz)

60.7 dB (20 to 30 MHz)

Sync signal:

ANALOG OUT SYNC connector (BNC type) (1)

Conforming to SMPTE240M/274M

(59.94 or 60.00 Hz) standard.

Impedance:

75

, unbalanced

Level:

0.6 Vp-p

61%

Delay time:

1000 ns or less

ISR output information:

Status messages: 2 items

Setup messages: 3 items

General

Power requirements:

+5.0 V DC: 1.4 A, -5.0 V DC: 700 mA

(Supplied from the PFV-HD300A/HD50A

Interface Unit)

Power consumption:

Approx. 10 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

Mass

(8 5/8 x 3 7/8 x 1 inches)

Board:

Approx. 700 g (1 lb 8 oz)

Connector panel:

Approx. 200 g (7 oz)

HD SERIAL DIGITAL

VIDEO INPUT

D/A

103

Rear Panel

HD COMPONENT ANALOG

VIDEO OUTPUT

G / B / R or

Y / P

B

/ P

R

HD COMPONENT ANALOG

VIDEO OUTPUT

G / B / R or

Y / P

B

/ P

R

HD ANALOG SYNC OUTPUT

*SGC_0099-0116 02.3.16 5:04 PM Page 104

Interface Processor D Series

HKPF-103M

HD Digital Video Distribution Board

The HKPF-103M HD digital video distribution board accepts an HD component serial digital video input signal and distributes it to six outputs. Automatic equalization is provided for input cable lengths of up to 100 m (with

Fujikura 5C-FB or PD-3709 Cooper RG-6/U or equivalent cable).

Features

* Accepts an SMPTE291M/292M/299M format input signal * Automatic equalization for input cable lengths of up to 100 m * Six distribution outputs * Support

SMPTE292M formats * 1035(1125)/60i, 59.94i *

1080(1125)/60i, 59.94i, 50i * 1080(1125)/30PsF,

29.976PsF, 25PsF, 24PsF, 23.976PsF * 720(750)/60P,

59.94P * Auto selection of SMPTE292M video formats *

Format indication on the front panel * Status output

The HKPF Series function boards install in the PFV-HD Series Interface Units.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Specifications

Inputs/outputs

Digital signal input:

DIGITAL IN connector (BNC type) (1)

HD component serial digital signal conforming to SMPTE291M/292M/299M

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 1.485 GHz)

Transmission loss:

20 dB or less (at 742.5 MHz)

Cable length:

100 m max. (When using Fujikura

5C-FB or

PD-3079 COOPER RG-6/U type Super

Low Loss Digital Video Coax or equivalents)

Digital signal outputs:

DIGITAL OUT connectors (BNC type)

(6)

HD component serial digital signals conforming to SMPTE291M/292M/299M

Output signal amplitude:

800 m Vp-p

610% (at 75 Ω

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

Jitter:

Within 673 ps (timing jitter)

Within 135 ps (alignment jitter)

Digital input/output system delay:

900 ns or less

General

Power requirements:

+5 V DC: 1.4 A, -5 V DC: 1.2 A

(Supplied from the PFV-HD300A/HD50A

Interface Unit)

Power consumption:

Approx. 14 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 55 °C (-4 to 131 °F)

Humidity:

10 to 90% (without condensation)

Dimensions

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

Mass

(8 5/8 x 3 7/8 x 1 inches)

Board:

700 g (1 lb 8.7 oz)

Connector panel:

300 g (11 oz)

HD SDI IN

Auto

EQ

Re-

Clock

104

Rear Panel

HD SDI OUT 1

HD SDI OUT 2

HD SDI OUT 3

HD SDI OUT 4

HD SDI OUT 5

HD SDI OUT 6

*SGC_0099-0116 02.3.16 5:04 PM Page 105

Interface Processor D Series

HKPF-105M

HD Audio/video Multiplexer Board

The HKPF-105M is a video/audio multiplexer board that multiplexes four AES/EBU format digital audio signals (8 channels) with an SMPTE291M/292M/299M format component serial digital video signal. Two outputs of the multiplexed signal are provided. By cascading two

HKPF-105M boards, a further four AES/EBU signals can be multiplexed onto one HD signal, making a total of eight pairs/sixteen channels. Automatic equalization is provided for input cable lengths of up to 100 m (5C-FB or PD-3709

Cooper RG-6/U cable or equivalents).

Features

* Multiplexes two AES/EBU signals with an HD component serial digital video signal * Selection of the audio group to be multiplexed * Audio delay function - one video frame * Support SMPTE292M formats *

1035(1125)/60i, 59.94i * 1080(1125)/60i, 59.94i, 50i *

1080(1125)/30PsF, 29.976PsF, 25PsF, 24PsF, 23.976PsF

* 720(750)/60P, 59.94P * Auto selection of SMPTE292M video formats * Format indication on the front panel *

Status output

The HKPF Series function boards install in the PFV-HD Series Interface Units.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Specifications

Inputs/outputs

Digital video signal input:

DIGITAL IN VIDEO connector (BNC type) (1)

HD component serial digital signal conforming to SMPTE291M/292M/299M

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 1.485 GHz)

Transmission loss:

20 dB or less (at 742.5 MHz)

Cable length:

100 m max. (When using a 5C-FB coaxial cable or PD-3079 COOPER RG-6/U type

Super Low Loss Digital Video Coax or equivalents)

Digital audio signal inputs:

DIGITAL IN AUDIO connectors (BNC type)

(4)

AES/EBU-format signal

75

, 1 Vp-p, unbalanced

Digital signal outputs:

DIGITAL OUT connectors (BNC type) (2)

HD component serial digital signal conforming to SMPTE291M/292M/299M

Output signal amplitude:

800 m Vp-p

610% (at 75

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

Jitter:

Within 673 ps (timing jitter)

Within 135 ps (alignment jitter)

Audio delay

Setting method:

Delay range is set by the on-board rotary switch; the offset delay time is set by the on-board DIP switch

Variable range:

0 to 157 samples

Offset delay time:

0 or 1 frame

Digital input/output system delay

Video:

1.6 µs (without lip-sync)

General

Power requirements:

+5 V DC: 1.6 A, -5 V DC: 1.3 A

(Supplied from the PFV-HD300/HD50A

Interface Unit)

Power consumption:

Approx. 15 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 55 °C (-4 to 131 °F)

Humidity:

10 to 90 % (without condensation)

Dimensions:

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

(8 5/8 x 3 7/8 x 1 inches)

Mass

Board:

700 g (1 lb 8.7 oz)

Connector panel:

300 g (11 oz)

HD SD IN

AES/EBU IN 1

AES/EBU IN 2

AES/EBU IN 3

AES/EBU IN 4

Auto

EQ

S/P

A/V

MUX

P/S

Rear Panel

HD SDI OUT 1

HD SDI OUT 2

105

*SGC_0099-0116 02.3.16 5:05 PM Page 106

Interface Processor D Series

HKPF-106M

HD Audio/Video Demultiplexer Board

The HKPF-106M is a video/audio demultiplexer board that demultiplexes four AES/EBU-format digital audio signals from a multiplexed SMPTE291M/292M/299M component serial digital video signal. The input video signal is distributed to two outputs. Up to eight pairs/sixteen channels of audio can be separated from a multiplexed

HD component serial digital video signal by connecting two HKPF-106M boards in cascade.

Features

* Demultiplexes and outputs the AES/EBU digital audio signals from an HD component serial digital video signal *

Selection of the audio groups (1-8 or 9-16) to be demultiplexed * Audio output channel pairs interchangeable * Support SMPTE292M formats * 1035

(1125)/60i, 59.94i * 1080(1125)/60i, 59.94i, 50i *

1080(1125)/30PsF, 29.976PsF, 25PsF, 24PsF, 23.976PsF

* 720(750)/60P, 59.94P * Auto selection of SMPTE292M video formats * Format indication on the front panel *

Status output

The HKPF Series function boards install in the PFV-HD Series Interface Units.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Specifications

Inputs/outputs

Digital video signal input:

DIGITAL IN connector (BNC type) (1)

HD component serial digital signal conforming to SMPTE291M/292M/299M

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 1.485 GHz)

Transmission loss:

20 dB or less (at 742.5 MHz)

Cable length:

100 m max. (When using a 5C-FB coaxial cable or PD-3079 COOPER

RG-6/U type Super Low Loss Digital

Video Coax or equivalent)

Digital audio signal outputs:

DIGITAL OUT AUDIO connectors (BNC type) (4)

AES/EBU-format digital audio signal 75

,

1 Vp-p, unbalanced

Digital video signal outputs:

DIGITAL OUT VIDEO connectors (BNC type) (2)

HD component serial digital signal conforming to SMPTE291M/292M/299M

Output signal amplitud:

800 m Vp-p

610% (at 75

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 1.485 GHz)

Jitter:

Within 673 ps (timing jitter)

Within 135 ps (alignment jitter)

Digital input/output system delay

Video:

1.3 µs (without lip-sync)

General

Power requirements:

+5 V DC: 1.5 A, -5 V DC: 1.2 A

(Supplied from the PFV-HD300A/HD50A

Interface Unit)

Power consumption:

Approx. 15 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 55 °C (-4 to 131 °F)

Humidity:

10 to 90% (without condensation)

Dimensions

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

(8 5/8 x 3 7/8 x 1 inches)

Mass

Board:

700 g (1 lb 8.7 oz)

Connector panel:

300 g (11 oz)

HD SD IN

Auto

EQ

S/P P/S

A/V

DE MUX

Rear Panel

HD SDI OUT 1

HD SDI OUT 2

AES/EBU OUT 1

AES/EBU OUT 2

AES/EBU OUT 3

AES/EBU OUT 4

106

*SGC_0099-0116 02.3.16 5:05 PM Page 107

Interface Processor D Series

HKPF-1125A

HD up-converter board

The HKPF-1125A is a 525-line or a 625-line to 1125-line up-converter with an auto colorimetry selection capability and selectable output modes. To produce optimum image quality, it also features a motion adaptive conversion mode, anti image enhancer, colorimetry and gamma correction functions. The HKPF-1125A accepts inputs in conventional NTSC composite analog or NTSC composite serial digital or 525/625 component serial digital signal format, and provides three HD serial digital outputs to the

1125-line interlaced HDTV standard. The 1125 output can be in the 1035 or 1080 active line format.

Features

*Up-converts a 625 component serial digital, a 525 component or NTSC composite serial digital, or an NTSC composite analog video signal to the 1125-line HDTV standard *525/625 Black Burst or 1125 Tri-level Sync input *Three distribution output of HD SDI with embedded audio *1035 or 1080 active lines output switchable (for 525 input only) *Auto colorimetry selection between 1035 and 1080 active lines *Aspect ratio modes selectable from Squeeze, Letter Box and Edge Crop

*Motion adaptive and non-adaptive conversion modes selectable from Frame/Field adaptive, Field fixed and

Frame fixed *Anti Image Enhancer control *Gamma

Correction control *Controlled from an optional

HKDV-503/900 Digital Video Controller via RS-422 (GPI also provided) *Provides color matt

The HKPF Series function boards install in the PFV-HD Series Interface Units.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Supplied Accessories

Operation manual (1)

Installation manual (1)

Slot number label (1)

107

Rear Panel

*SGC_0099-0116 02.3.16 5:05 PM Page 108

Interface Processor D Series

Specifications

Inputs/outputs

Digital signal input:

VIDEO IN SDI connector (BNC type) (1),

NTSC composite or 525/625 component serial digital signal with embedded audio conforming to SMPTE259M-A/C (ITU-R

BT.601/BT.656), 270 Mb/s,143 Mb/s, 75

, unbalanced

Cable length:

200 m max. (With Belden 8281, Fujikura

5C2V or equivalent coaxial cable)

Input return loss:

15 dB or more (5 MHz to 270 MHz)

Analog signal input:

VIDEO IN ANALOG connector (BNC type)

(1),

1.0 Vp-p, 75

, unbalanced

Reference input:

REF IN connector (BNC type) (1), 1125 tri-level sync signal conforming to

SMPTE274M or 525/625 Black Burst signal

Digital signal outputs:

DIGITAL OUT 1,2,3 connector (BNC type)

(3),

HD serial digital signal with embedded audio conforming to SMPTE292M, BTA S-004B,

800 m Vp-p

610%, 75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 1.5 GHz)

Reference output:

Loop-through output connector (BNC type)

(1),

With 75

Ω termination switch

General

Power requirements

+5 V DC: 1.9A,.-5 V DC: 1.6 A

(Supplied from a PFV-HD300A Interface Unit)

Operating temperature

5 to 40 °C (41 to 104 °F)

Storage temperature

-20 to 60 °C (-4 to 140 °F)

Operating humidity

10 to 90% (no condensation)

Dimensions

Board (H x W):

195 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x W):

195 x 75 mm

(1 1/2 x 3 inches)

Mass

Board:

Approx. 1.5 kg (3 lb 5 oz)

Connector panel:

Approx. 200 g (7 oz)

Service Parts: Maintenance Manual, Extension Board

NTSC

COMPOSITE

ANALOG

SDI IN

VIDEO IN

REF

PASSIVE LOOP-THROUGH

RS-422A

Video Controller

HKDV-503/900

A/D

Up-

Convert

CLK

108

HD SDI OUT 1

(1080i/1035i)

HD SDI OUT 2

HD SDI OUT 3

*SGC_0099-0116 02.3.16 5:05 PM Page 109

Interface Processor D Series

HKPF-525V

HD-SD downconverter board

The HKPF-525 HD downconverter board converts a HD component serial digital video signal to a SD component serial digital signal and distributes it to four outputs. The

525-line component output signal format is selectable to

4:2:2 Y/B-Y/R-Y, 4:4:4 Y/B-Y/R-Y or 4:4:4 GBR. In the case of 4:4:4 format signals, only two outputs are available.

Features

* Downconverts an HD serial digital video signal to a SD component serial digital signal * Support 1080 (1035) i to

485i at 59.94 Hz and 1080i to 576i at 50 Hz conversion *

Output signal aspect ratio selectable: squeeze, edge crop, semi letter box (13:9, 14:9) and letter box (16:9) *

Minimum delay/frame delay selectable * Remote control from HKDV-503 digital video controller * Parallel alarm output

The HKPF Series function boards install in the PFV-HD Series Interface Units together with the BKPF Series function boards.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Specifications

Inputs/outputs

Digital video signal input:

DIGITAL IN connector (BNC type) (1)

HD component serial digital video signal conforming to SMPTE292M, 1.5

Gb/s (BTA S-004B)

Input impedance:

75

, unbalanced

Input return loss:

15 dB minimum (5 to 750 MHz)

15 dB minimum (750 MHz to 1.5 GHz)

Cable length:

100 m max. (When using a 5C-FB coaxial cable)

Data rate:

1.4835 GHz/1.485 GHz

Remote control signals:

REMOTE IN connector (D-sub 9-pin) (1)

RS-422

Digital video outputs:

DIGITAL OUT 1, 2, 3, and 4 (BNC type)

(1 each)

525/625-line component serial digital video signal

(switchable between Y/PB /PR and

GBR)

Supported formats (selectable):

525/625 4:2:2 Y/B-Y/R-Y component serial digital video

525/625 4:4:4 Y/B-Y/R-Y component serial digital video

525/625 4:4:4 GBR component serial digital video

Three selectable modes (squeeze, edge crop, and letter box)

Adjustable delay range:

Minimum Delay Mode

525:42 H -1~+100 H

625: 50 H -1~+100 H

Frame Delay Mode

525: 525 H

65 H

625: 625 H

65 H

Adjustable parameters:

Detail gain, detail frequency, level depend., crispness, H/V ratio, limit level, gamma

General

Power supply:

+5.0 V DC: 2.0 A, -5.0 V DC: 1.0 A

(Supplied from the PFV-HD300A/HD50A

Interface Unit)

Power consumption:

Approx. 15 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions:

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

(8 5/8 x 3 7/8 x 1 inches)

Mass

Board:

Approx. 1500 g (1 lb 8 oz)

Connector panel:

Approx. 200 g (7 oz)

HD SDI IN

REF IN

LOOP-THROUGH

RS-422

REMOTE IN

HKDV-503

Video Controller

D/A

CLK

Rear Panel

1

2

SDI OUT

3

4

IN CASE OF 4:4:4

LINK A

LINK B

109

*SGC_0099-0116 02.3.16 5:05 PM Page 110

Interface Processor D Series

HKPF-525AV

HD-SD downconverter board

The HKPF-525 HD downconverter board converts a HD component serial digital video signal to a SD component serial digital signal and distributes it to four outputs. The

525-line component output signal format is selectable to

4:2:2 Y/B-Y/R-Y, 4:4:4 Y/B-Y/R-Y or 4:4:4 GBR. In the case of 4:4:4 format signals, only two outputs are available.

Features

* Downconverts an HD serial digital video signal to a SD component serial digital signal * Support 1080 (1035) i to

485i at 59.94 Hz and 1080i to 576i at 50 Hz conversion *

Output signal aspect ratio selectable: squeeze, edge crop, semi letter box (13:9, 14:9) and letter box (16:9) *

Minimum delay/frame delay selectable * Remote control from HKDV-503 digital video controller * Passes embedded audio * Parallel alarm output

The HKPF Series function boards install in the PFV-HD Series Interface Units together with the BKPF Series function boards.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Specifications

Inputs/outputs

Digital video signal input:

DIGITAL IN connector (BNC type) (1)

HD component serial digital video signal conforming to SMPTE292M, 1.5

Gb/s (BTA S-004B)

Input impedance:

75

, unbalanced

Input return loss:

15 dB minimum (5 to 750 MHz)

15 dB minimum (750 MHz to 1.5 GHz)

Cable length:

100 m max. (When using a 5C-FB coaxial cable)

Data rate:

1.4835 GHz/1.485 GHz

Remote control signals:

REMOTE IN connector (D-sub 9-pin) (1)

RS-422

Digital video outputs:

DIGITAL OUT 1, 2, 3, and 4 (BNC type)

(1 each)

525/625-line component serial digital video signal

(switchable between Y/PB /PR and

GBR)

Supported formats (selectable):

525/625 4:2:2 Y/B-Y/R-Y component serial digital video

525/625 4:4:4 Y/B-Y/R-Y component serial digital video

525/625 4:4:4 GBR component serial digital video

Three selectable modes (squeeze, edge crop, and letter box)

Adjustable delay range:

Minimum Delay Mode

525:42 H -1~+100 H

625: 50 H -1~+100 H

Frame Delay Mode

525: 525 H

65 H

625: 625 H

65 H

Adjustable parameters:

Detail gain, detail frequency, level depend., crispness, H/V ratio, limit level, gamma

General

Power supply:

+5.0 V DC: 2.0 A, -5.0 V DC: 1.0 A

(Supplied from the PFV-HD300A/HD50A

Interface Unit)

Power consumption:

Approx. 15 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions:

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

(8 5/8 x 3 7/8 x 1 inches)

Mass

Board:

Approx. 1500 g (1 lb 8 oz)

Connector panel:

Approx. 200 g (7 oz)

HD SDI IN

REF IN

LOOP-THROUGH

RS-422

REMOTE IN

HKDV-503

Video Controller

D/A

CLK

Rear Panel

1

2

SDI OUT

3

4

IN CASE OF 4:4:4

LINK A

LINK B

110

*SGC_0099-0116 02.3.16 5:05 PM Page 111

Interface Processor D Series

HKPF-D270

HDCAM decoder board

The HKPF-D270 HDCAM Decoder Board is designed to convert SDTI (HDCAM) signals to HD SDI signals

(conforming to SMPTE292M/BTA S-004B). The bit rate and the maximum transmission distance are common between SDTI and SDI. This means that by combining

HKPF-E270 HDCAM encoder and HKPF-D270 HDCAM decoder boards, existing routing and processing equipment for SDTV serial digital signals can be upgraded to also support HDTV signals. This preserves past investments.

Features

* Converts 270 Mb/s SDTI (conforming to SMPTE305M) into 1.5 Gb/s HD component serial digital * Video with eight channels of embedded audio signal *

Non-compressed digital audio signals * Adopts HDCAM

CODEC for superb picture quality and highly efficient compression * Automatic detection of 1035/1080 active lines input (59.94 Hz field frequency fixed) * Transmission up to 200 m over SDTI (Belden 8281, Fujikura 5C2V or equivalent cable) * 1125 or 525 reference input with passive loop-through * Error correction function for transmission of SDTI * Supports ISR * EDH detection

The HKPF Series function boards install in the PFV-HD Series Interface Units together with the BKPF Series function boards.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Supplied Accessories

Operation manual (1)

Maintenance manual (1)

Slot number label (1)

111

Rear Panel

*SGC_0099-0116 02.3.16 5:05 PM Page 112

Interface Processor D Series

Specifications

Inputs/outputs

Digital input:

SDTI IN (HDCAM) connector (BNC type)

(1)

HDCAM over SDTI signal conforming to

SMPTE305M

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 270 MHz)

Cable length:

HD-SDI: 100 m max. (When using 5CFB coaxial cable or equivalent cable)

SDTI: 200 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

Active through output:

75

, unbalanced

SYNC signal input:

REF IN connector (BNC type) (1)

1125 or 525 SYNC signal

Input impedance:

75

, unbalanced

Digital signal outputs:

DIGITAL OUT connectors (BNC type) (3)

HD serial digital signal conforming to

SMPTE292M (BTA S-004B)

Output signal amplitude:

800 m Vp-p +/-10% (at 75

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 741.8 MHz)

10 dB or more (741.8 MHz to 1.484 GHz)

Digital input/output system delay

REF lock:

2 frames (to reference)

Minimum delay:

1.7 frames (to input)

ISR output information

Status messages:

8 items

Set-up messages:

3 items

General

Power requirements:

+5 V DC: 1.9 A, -5 V DC: 1.6 A

(Supplied from the PFV-HD300A/HD50A

Interface Unit)

Power consumption:

Approx.17.5 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 55 °C (-4 to 131 °F)

Operating humidity:

10 to 90% (without condensation)

Dimensions

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

(8 5/8 x 3 7/8 x 1 inches)

Mass

Board:

Approx. 700 g (1 lb 8.7 oz)

Connector panel:

Approx. 300 g (10.6 oz)

Service Part: Extension Board

SDTI

(270 Mb/s)

ACTIVE

LOOP-THROUGH

REF. SYNC

525 (B.B) or

REF. SYNC

1125 (TRI. SYNC)

112

S/P

SDTI

(270 Mb/s)

DEC

HD SDI

(1.5 Gb/s)

P/S

1

2

HD SDI

(1.5 Gb/s)

3

*SGC_0099-0116 02.3.16 5:05 PM Page 113

Interface Processor D Series

HKPF-E270

HDCAM encoder board

The HKPF-E270 HDCAM Encoder Board is designed to convert HD SDI signals (conforming to SMPTE292M/BTA

S-004B) to SDTI (HDCAM) signals. The bit rate and the maximum transmission distance are common between

SDTI and SDI. This means that by combining

HKPF-E270 HDCAM encoder and HKPF-D270 HDCAM decoder boards, existing routing and processing equipment for SDTV serial digital signals can be upgraded to also support HDTV signals. This preserves past investments.

Features

* Encodes 1.5 Gb/s HD component serial digital video with eight channels of embedded audio signal into 270

Mb/s SDTI (conforming to SMPTE305M) *

Non-compressed digital audio signals * Adopts HDCAM

CODEC for superb picture quality and highly efficient compression * Automatic detection of 1035/1080 active lines input (59.94 Hz field frequency fixed) * Transmission up to 200 m over SDTI (Belden 8281, Fujikura 5C2V or equivalent cable) * 1125 or 525 reference input with passive loop-through * Error correction function for transmission of SDTI * Supports ISR * EDH insertion

The HKPF Series function boards install in the PFV-HD Series Interface Units together with the BKPF Series function boards.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Supplied Accessories

Operation manual (1)

Maintenance manual (1)

Slot number label (1)

113

Rear Panel

*SGC_0099-0116 02.3.16 5:05 PM Page 114

Interface Processor D Series

Specifications

Inputs/outputs

Digital signal input:

DIGITAL IN (HDCAM) connector (BNC type)

(1), HD serial digital signal conforming to

SMPTE291M/292M/299M,BTA-004B/005B/00

6B)

Input impedance:

75

, unbalanced

Input return loss:

15 dB or more (5 MHz to 741.8 MHz)

10 dB or more (741.8 MHz to 1.484 GHz)

Transmission loss:

20 dB or less (at 741.8 MHz)

Cable length:

HD-SDI: 100 m max. (Using 5CFB coaxial cable or equivalent cable)

SDTI: 200 m max. (Using Belden 8281,

Fujikura 5C2V or equivalent cable)

Active through output:

75

, unbalanced

SYNC signal input:

REF IN connector (BNC type) (1)

1125 or 525 SYNC signal

Input impedance:

75

, unbalanced

Loop-through output:

With 75

Ω termination switch

Digital signal outputs:

SDTI (HDCAM) OUT connectors (BNC type)

(3)

HDCAM over SDTI signal conforming to

SMPTE305M

Output signal amplitude:

800 m Vp-p +/-10% (at 75

)

Output impedance:

75

, unbalanced

Output return loss:

15 dB or more (5 MHz to 270 MHz)

Digital input/output system delay

REF lock:

2 frames (to reference)

Minimum delay:

1.2 frames (to input)

ISR output information

Status messages:

8 items

Set-up messages:

3 items

General

Power requirements:

+5 V DC: 1.8 A, -5 V DC: 1.2 A

(Supplied from the PFV-HD300A/HD50A

Interface Unit)

Power consumption:

Approx.15 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 55 °C (-4 to 131 °F)

Operating humidity:

10 to 90% (without condensation)

Dimensions

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

(8 5/8 x 3 7/8 x 1 inches)

Mass

Board:

Approx. 700 g (1 lb 8.7 oz)

Connector panel:

Approx. 300 g (10.6 oz)

HD SDI

(1.5 Gb/s)

Service Part: Extension Board

REF. SYNC

525 (B.B) or

REF. SYNC

1125 (TRI. SYNC)

114

S/P

HD SDI

(1.5 Gb/s)

ENC

SDTI

(270 Mb/s)

P/S

1

2

SDTI

(270 Mb/s)

3

*SGC_0099-0116 02.3.16 5:05 PM Page 115

Interface Processor D Series

HKPF-9000

Multi-format converter

The HKPF-9000 multi-format converter converts 1080/24P

HDTV format signals to a variety of HD/SD formats. It provides optional functions that convert SDTV or 720P to

HDTV 1080, frame rate and aspect ratio. For details, see the Format Conversion Table. The HKPF-9000 is configured as two boards for installation in the PFV-HD

Series Interface Units in any combination with other HKPF

Series boards.

Features

*Built-in colorimetry conversion between 601/240M/709

*Down/up-conversion to/from 720/60P (with optional

HZPF-9001 software) *Up-converts SDTV signal to 1080i

(with optional HZPF-9002/9003 software) *Line conversion between 1035 and 1080 active lines (with optional HZPF-9006 software) *Built-in image enhancer and output gamma corrector *Selectable aspect ratio conversion (Edge Crop/Squeeze/Letter Box) *Embedded audio and time code are locked to the output signal after video format conversion *Variable image trimming and aspect ratio manipulation, background color selection

(with optional HZPF-9005 software) — Remote Control function enables video gain, image enhancer, etc., to be remotely controlled from an optional HKDV-900 HD digital video controller

The HKPF Series function boards install in the PFV-HD Series Interface Units.

Applicable Models

PFV-HD50A HD Digital Video Interface Unit

Supplied Accessories

Operation manual (1)

Installation manual (1)

Optional Software

HZPF-9003 576 Input Option Software

HZPF-9005 Aspect/Color Processing Option

Software

HZPF-9006 1035/30P Option Software

HZPF-9001 720P Input Option Software

HZPF-9002 480 Input Option Software

Optional Peripherals

HKDV-900 HD Digital Video Controller

Specifications

Inputs/outputs

Digital signal inputs:

SD IN 1,2 connector (BNC type) (2),

525/625 component digital serial signal with embedded audio conforming to

SMPTE259M, 270 Mb/s, 0.8 Vp-p, 75

, unbalanced

HD IN connector (BNC type) (1), HD digital serial signal with embedded audio conforming SMPTE291M/292M/

299M, BTA S-004B/005B/006B, 1.4835

Gb/s or 1.485 Gb/s, 75

, unbalanced

Cable length:

200 m max. (SD)

(With Fujikura 5C2V or equivalent coaxial cable)

100 m max. (HD)

(with Fujikura 5C-FB or equivalent coaxial cable)

Input return loss:

15 dB or more (5 MHz to 270 MHz)

Reference input:

REF IN connector (BNC type) (1), 1125 tri-level sync signal conforming to

SMPTE274M or 525/625 Black Burst signal

Digital signal outputs:

SD OUT1, 2 connector (BNC type) (2), component digital serial signal with embedded audio conforming to

SMPTE259M, 270 Mb/s, 0.8 Vp-p

610%, 75 Ω

, unbalanced

HD OUT1, 2 connector (BNC type) (2),

HD digital serial signal with embedded audio conforming SMPTE291M/292M/

299M, BTA S-004B/005B/006B, 0.8 Vp-p

610%, 75 Ω

, unbalanced

Output return loss:

15 dB or more (5 MHz to 270 MHz)

Jitter:

Alignment jitter, 740 ps (SD), 135 ps or less (HD)

Rise/fall time:

1.5 ns or less (SD), 270 ps or less (HD)

Loop-through output:

Loop-through output connector (BNC type) (1)

Remote control:

D-sub 9-pin, female (2)

General

Power requirements:

+5 V DC: 5.0 A, -5 VDC: 3.0 A

(Supplied from PFV-HD Series Interface

Unit)

Operating temperature:

5 to 40 °C (41 to 104 °F)

115

Rear Panel Rear Panel

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

194 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x D x W):

218 x 98 x 25 mm

(8 5/8 x 3 7/8 x 1 inches)

Mass

Board:

Approx. 700 g (1 lb 3 oz)

Connector panel:

Approx. 600 g (1 lb 5 oz)

*SGC_0099-0116 02.3.16 5:05 PM Page 116

Interface Processor D Series

HKDV-900

HD Digital Video Controller

The HKDV-900 digital video controller connects to

HDW-F500/500/2000 HD digital VTRs and controls the

HD/SD output video signals and the image enhancer of the down converter built into these VTR. It can also be used as a remote controller for the HKPF-9000 multi-format converter, HKPF-1125A 525/625 to HD up-converter and the 525A/AV NTSC down-converter board installed in PFV-HD Series Interface Units. The

HKDV-900 can be connected to a maximum of four devices (VTR, HKPF-9000). Only one device can be controlled at a time.

Features

*Remote control of the HKPF-9000 multi-format converter

*Controls the HKPF-525V/AV HD-SD down-converter board, the HKPF-1125A 525-HD up-converter board and the HKDV-501 HD/SD down-converter board *Installs in a

19-inches rack unit

Applicable Models

HDW-2000 HDCAM Recorder

HDW-M2000 HDCAM Recorder

HDW-M2000P HDCAM Recorder

HDW-M2100 HDCAM Player

HDW-M2100P HDCAM Player

HKPF-9000 Multi-format converter

Supplied Accessories

PSW 4

316 Screws, for Rack mounting (4)

Operation manual (1)

Installation manual (1)

Optional Accessories

RCC-15H cables 9-pin/15-pin Remote Control Cable

Specifications

General

Power requirement:

25 W or less

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Rear Panel

Operating humidity:

20 to 80% (no condensation)

Dimensions:

424 x 43.6 x 171 mm

(16 3/4 x 1 3/4 x 6 3/4 inches)

Mass:

Approx. 2.9 kg (4 oz)

116

*SGC_0117-0132 02.3.16 5:05 PM Page 117

Interface Processor D Series

SDTV

SDTV

PFV-D10 . . . . . . . . . . . . . . . 118

PFV-D50A . . . . . . . . . . . . . . 119

PFV-D300 . . . . . . . . . . . . . . 120

BKPF-012A . . . . . . . . . . . . . 121

BKPF-021 . . . . . . . . . . . . . . 123

BKPF-205 . . . . . . . . . . . . . . 124

BKPF-206 . . . . . . . . . . . . . . 126

BKPF-300 . . . . . . . . . . . . . . 128

BKPF-301 . . . . . . . . . . . . . . 129

BKPF-350 . . . . . . . . . . . . . . 130

BKPF-351 . . . . . . . . . . . . . . 131

117

*SGC_0117-0132 02.3.16 5:05 PM Page 118

Interface Processor D Series

PFV-D10

Digital Video Interface Unit

BKPF Series boards provide a wide range of audio and video signal processing and distribution functions for analog and digital signals. The PFV-D10 digital video interface unit accommodates any one of these boards, providing an interface for system connections. The

PFV-D10 supplies power to the board and includes BNC connectors for a looped video reference signal input and

S-BUS remote control. The PFV-D10 mounts into a standard 19-inch rack and is 1U high.

Features

* Accommodates and powers one BKPF Series board *

S-BUS control and reference video connectors

Supplied Accessories

Operation manual (1)

Installation manual (1)

Optional Boards

BKPF-012A 525-line component digital to

NTSC composite analog/digital video converter board

BKPF-021 NTSC Composite Digital to

525-Line Component Digital Video Converter

Board

BKPF-205 Audio/Video Multiplexer Board

BKPF-206 Audio/Video Demultiplexer Board

BKPF-300 Digital Video Selector Board

BKPF-301 Analog Video Selector Board

BKPF-350 Digital Audio Selector Board

BKPF-351 Analog Audio Selector Board

BKPF-R70A Routing Switcher Controller

Board

Optional Software

BZR-IF310 S-BUS SUB-NET Controller

Software

Specifications

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

100 V: 0.8 A, 240 V: 0.4 A

Maximum power supply capacity:

+5 V DC: max. 2.4 A

For installed board -5 V DC: max. 2.4 A

Operating temperature:

5 to 40 °C (41 to 104 °F)

Rear Panel

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90%

Dimensions (W x H x D):

424 x 44 x 426 mm

(16 3/4 x 1 3/4 x 16 7/8 inches)

Mass:

Approx. 5 kg (11 lb 4 oz)

(not including the optional boards)

118

*SGC_0117-0132 02.3.16 5:05 PM Page 119

Interface Processor D Series

PFV-D50A

Digital Video Interface Unit

BKPF Series boards provide a wide range of audio and video signal processing and distribution functions for analog and digital signals. The PFV-D50A digital video interface unit accommodates up to four of these boards, providing an interface for system connections. One of these boards can be a BKPF-500, providing an interface to an ISR system. The PFV-D50A supplies power to the boards, an optional BKPF-PS50A backup power supply can be installed for critical applications. BNC connectors for a looped video reference signal input and S-BUS remote control are provided, together with an ISR Status

Out connector. The PFV-D50A mounts into a standard

19-inch rack and is 3U high.

Features

* Accommodates and powers four BKPF Series boards *

S-BUS control and reference video connectors *

Redundant power supply option * Supports ISR

Supplied Accessories

Operation manual (1)

Installation manual (1)

Optional Accessories

RMM-30 Rack Mount Rail

Optional Boards

BKPF-012A 525-line component digital to

NTSC composite analog/digital video converter board

BKPF-021 NTSC Composite Digital to

525-Line Component Digital Video Converter

Board

BKPF-205 Audio/Video Multiplexer Board

BKPF-206 Audio/Video Demultiplexer Board

BKPF-300 Digital Video Selector Board

BKPF-301 Analog Video Selector Board

BKPF-350 Digital Audio Selector Board

BKPF-351 Analog Audio Selector Board

BKPF-R70A Routing Switcher Controller

Board

Optional Software

BZR-IF310 S-BUS SUB-NET Controller

Software

Optional Peripherals

BKPF-PS50A Backup Power Supply Unit

Specifications

Output

STATUS OUT:

D-sub 25-pin

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

100 V AC: max. 1.8 A

240 V AC: max. 0.9 A

Maximum power supply capacity:

+5 V DC: max. 8 A

For installed boards -5 V DC: max. 8 A

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90%

Dimensions (W x H x D)

424 x 132 x 428 mm

(16 3/4 x 5 1/4 x 16 7/8 inches)

Mass:

Approx. 8 kg (17 lb 10 oz)

(not including the optional boards)

The total power consumption of the four installed function boards should not exceed 8 A at 5 V and

8 A at -5 V.

Rear Panel

119

*SGC_0117-0132 02.3.16 5:05 PM Page 120

Interface Processor D Series

PFV-D300

Digital Video Interface Unit

BKPF Series boards provide a wide range of audio and video signal processing and distribution functions for analog and digital signals. The PFV-D300 digital video interface unit accommodates up to 14 of these boards, providing an interface for system connections. One of these boards can be a BKPF-500, providing an interface to an ISR system. The PFV-D300 supplies power to the boards, an optional BKPF-PS300 backup power supply can be installed for critical applications. BNC connectors for a looped video reference signal input and S-BUS remote control are provided, together with an ISR Status

Out connector. The PFV-D300 mounts into a standard

19-inch rack and is 7U high.

Features

* Accommodates and powers fourteen BKPF Series boards * S-BUS control and reference video connectors *

Redundant power supply option * Supports ISR

Supplied Accessories

Operation manual (1)

Installation manual (1)

Optional Accessories

RMM-30 Rack Mount Rail

Optional Boards

BKPF-012A 525-line component digital to

NTSC composite analog/digital video converter board

BKPF-021 NTSC Composite Digital to

525-Line Component Digital Video Converter

Board

BKPF-205 Audio/Video Multiplexer Board

BKPF-206 Audio/Video Demultiplexer Board

BKPF-300 Digital Video Selector Board

BKPF-301 Analog Video Selector Board

BKPF-350 Digital Audio Selector Board

BKPF-351 Analog Audio Selector Board

BKPF-R70A Routing Switcher Controller

Board

Optional Software

BZR-IF310 S-BUS SUB-NET Controller

Software

Optional Peripherals

BKPF-PS300 Backup Power Supply Unit

Specifications

Output

STATUS OUT:

D-sub 25-pin connector (1)

General

Power requirements:

100 to 240 V AC, 50/60 Hz

Power consumption:

600 VA max.

Maximum power supply capacity:

+5 V DC: max. 23 A

For installed boards -5 V DC: max. 23 A

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to +60 °C (-4 to +140 °F)

Operating humidity:

10 to 90%

Dimensions (W x H x D)

424 x 310 x 450 mm

(16 3/4 x 12 1/4 x 17 3/4 inches)

Mass:

Approx. 18 kg (39 lb 11 oz)

(not including the optional boards)

The total power consumption of the14 installed function boards should not exceed 23 A at 5 V and 23 A at -5 V.

120

Rear Panel

*SGC_0117-0132 02.3.16 5:06 PM Page 121

Interface Processor D Series

BKPF-012A

525-line component digital to NTSC composite analog/digital video converter board

The BKPF-012A converts a 525-line component serial digital video signal into both an NTSC composite serial digital and an NTSC composite analog video signal. Four outputs of the composite serial digital signal and two outputs of the composite analog signal are provided. Four channels of audio embedded in the input signal can be transferred to the composite serial digital outputs. Frame synchronizing to an external video reference signal and an auto-freeze function are provided.

Features

* Converts a 525-line component serial digital video signal to NTSC composite analog and composite serial digital signals * Frame synchronization function * Transfers embedded audio signals * Supports ISR * Supports EDH

The BKPF Series function boards install in both the PFV-D and the PFV-HD

Series Interface Units. In a PFV-HD Series Interface Unit, they can be installed together with the HKPF Series function boards.

Applicable Models

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

121

Rear Panel

*SGC_0117-0132 02.3.16 5:06 PM Page 122

Interface Processor D Series

Specifications

Inputs/outputs

Serial digital input:

SDI IN connector (BNC type) (1)

0.8 Vp-p, 75

Serial digital outputs:

Active through-out connector (BNC type) (1)

0.8 Vp-p

610%, 75 Ω

SDI OUT connectors (BNC type) (4)

0.8 Vp-p

610%, 75 Ω

Reference video input:

REF IN connector (BNC type) (1)

Reference video output:

Loop-through output connector (BNC type) (1)

Analog NTSC outputs:

ANALOG OUT connectors (BNC type)

(2)

1.0 Vp-p

63%, 75

System delay (INPUT mode):

Approx. 8.5 µs (with DIGITAL H-PHASE

“00”)

Approx. 6.5 µs (with ANALOG H-PHASE

“00”)

Output phase adjustable range

(Comparing the REF signal phase with the output signal phase)

(REF/frame synchronization ON mode)

Serial digital output:

0

68.8 µs (in 70 ns steps)

Analog NTSC output:

0

68.8 µs (in 17.5 ns steps)

(REF/frame synchronization OFF mode)

Serial digital output:

Approx. 21 to 37 µs (in 70 ns steps)

Analog NTSC output:

Approx. 19 to 35 µs (in 17.5 ns steps)

Data transmission

Channel coding:

Scrambled NRZI

Transmission bit rate:

Input: 270 Mb/s

Output: 143 Mb/s

Modulation:

0.8 Vp-p

Cable length:

200 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

Digital input/output return loss:

-15 dB or less (5 to 270 MHz)

Signal format

Input:

525-line component serial digital signal conforming to SMPTE259M-C

(ITU-R BT.601/BT.656), 270 Mb/s

Output:

NTSC composite serial digital signal conforming to SMPTE259M-A, 143

Mb/s

Video characteristics

Band width:

6 MHz

K factor:

Less than 1%

Signal-to-noise ratio:

More than 60 dB (5 MHz LPF)

DG:

Less than 1%

DP:

Less than 1°

General

Power requirements:

+5 V DC: 1800 mA, -5 V DC: 700 mA

(Supplied from the PFV-D/PFV-HD

Series Interface Unit)

Power consumption:

12.5 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

195 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x W):

195 x 25 mm

Mass

(7 3/4 x 1 inches)

Board:

Approx. 600 g (1 lb 5 oz)

Connector panel:

Approx. 200 g (7 oz)

525-LINE COMPONENT

SERIAL DIGITAL VIDEO

ACTIVE LOOP-THROUGH

REF IN

PASSVE LOOP-THROUGH

FRAME

SYNC

ENC

EDH

DET

CLK

EDH

ADD

ISR

D/A

122

NTSC COMPOSITE SERIAL

DIGITAL VIDEO

NTSC COMPOSITE ANALOG VIDEO

*SGC_0117-0132 02.3.16 5:06 PM Page 123

Interface Processor D Series

BKPF-021

NTSC Composite Digital to 525-Line Component Digital

Video Converter Board

The BKPF-021 converts an NTSC composite serial digital video signal to a 525-line component serial digital video signal with 10-bit resolution. A frame synchronizing function synchronizes the output video signal to either an external reference signal or the input signal.

Features

* Converts an NTSC composite serial digital video signal to a 525-line component serial digital video signal * Phase adjustment of output signal * Set-up remove function *

Auto-freeze function * Selection of Y/C separation point *

Supports ISR * Supports EDH

The BKPF Series function boards install in both the PFV-D and the PFV-HD

Series Interface Units. In a PFV-HD Series Interface Unit, they can be installed together with the HKPF Series function boards.

Applicable Models

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

Specifications

Inputs/outputs

Serial digital input:

SDI IN connector (BNC type) (1)

0.8 Vp-p, 75

NTSC composite serial digital signal conforming to SMPTE259M-A, 143 Mb/s

Cable length:

200 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

Serial digital outputs:

Active through-out connector (BNC type) (1)

0.8 Vp-p

610%, 75

Serial digital video signal of the same format as that to the input connector

SDI OUT connectors (BNC type) (4)

0.8 Vp-p

610%, 75

525-line component serial digital signal conforming to SMPTE259M-C (ITU-R

BT.601/BT.656), 270 Mb/s

Reference video input:

REF IN connector (BNC type) (1)

Reference video output:

Loop-through output connector (BNC type) (1)

System delay:

Approx. 70.5 µs

(in INPUT mode, with SYSTEM

H-PHASE “00”)

Output phase adjustable range:

Coarse adjustment: -4.74 µs to +4.70 µs

(-128 CK to +127 CK) in INPUT mode: 0 to +9.44 µs (0 to

+255 CK)

(1 CK: approx. 37 nsec)

Video characteristics

Band width:

6 MHz

K factor:

Less than 1%

Signal-to-noise ratio:

More than 58 dB DG (10 kHz to video fg.)

General

Power requirements:

+5 V DC: 1400 mA, -5 V DC: 600 mA

(supplied from the PFV-D/PFV-HD Series

Interface Unit)

Power consumption:

10 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

195 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x W):

195 x 25 mm

(7 3/4 x 1 inches)

Mass

Board:

Approx. 650 g (1 lb 7 oz)

Connector panel:

Approx. 200 g (7 oz)

NTSC COMPOSITE

SERIAL DIGITAL

VIDEO INPUT

ACTIVE

LOOP-THROUGH

REF IN

LOOP-THROUGH

DEC

CLK

123

Rear Panel

3

4

1

2 525-LINE COMPONENT

SERIAL DIGITAL

VIDEO OUTPUT

*SGC_0117-0132 02.3.16 5:06 PM Page 124

Interface Processor D Series

BKPF-205

Audio/Video Multiplexer Board

The BKPF-205 is an audio/video multiplexer board that converts four analog audio signals to two AES/EBU digital audio signals. These signals are then multiplexed on to a

525/625 component serial digital or NTSC composite serial digital video signal input to the board. Two outputs of this multiplexed video signal are provided. These outputs support a cable length of 200 m (Belden 8281,

Fujikura 5C2V or equivalent cable). Eight analog audio channels can be converted to the AES/EBU format and multiplexed onto one 525/625 component serial digital video signal by cascading two BKPF-205 boards.

Features

* Converts four analog audio signals to two AES/EBU digital audio signals. * Multiplexes the two AES/EBU signals onto a 525/625 component serial digital or NTSC composite serial digital video signal * Audio mute function

* Supports ISR * Supports EDH

The BKPF Series function boards install in both the PFV-D and the PFV-HD

Series Interface Units. In a PFV-HD Series Interface Unit, they can be installed together with the HKPF Series function boards.

Applicable Models

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

Optional Accessories

ECD-C cables XLR-3-Pin Type - XLR-3-Pin

Type Digital Audio Interface Cable

124

Rear Panel

*SGC_0117-0132 02.3.16 5:06 PM Page 125

Interface Processor D Series

Specifications

Inputs/outputs

SDI input:

SDI IN connector (BNC type) (1)

NTSC composite or 525/625 component serial digital signal conforming to

SMPTE259M-A/C (ITU-R

BT.601/BT.656); 143, 270, Mb/s

(Selectable with on-board switch)

Input impedance:

75

Input return loss:

15 dB or more

Cable length:

200 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

SDI outputs:

SDI OUT connectors (BNC type) (2)

Serial digital video signal of the same format as that to the input connector

0.8 Vp-p

610%, 75 Ω

Output return loss:

15 dB or more (5 MHz to 270 MHz)

Analog audio signal inputs:

ANALOG IN AUDIO connectors (4)

XLR-3-31 (female), balanced (electronic balance)

Input impedance:

600

/20 k

(selectable with on board switch)

Reference input level:

+4 dBm (-10 to +8 dBm continuously variable)

Conversion characteristics

Quantization:

20 bit linear/48 kHz sampling

Headroom:

20 dB (at operation level)

Frequency response:

20 Hz to 20 kHz within +0.2/-0.3 dB (at

1 kHz standard)

Distortion:

Less than 0.05% (at 1 kHz, reference level, 30 kHz low-pass)

Signal-to-noise ratio:

More than 106 dB

(Maximum output level, 30 kHz low-pass)

Crosstalk:

Less than -90 dB (up to 15 kHz)

Input signal common-mode rejection ratio

More than 80 dB (at 60 Hz)

Phase difference between channels

Within the same board: 0.1° or less (at 1 kHz)

Between the cascaded boards: 6° or less (at 1 kHz)

Multiplex format:

Conforms to SMPTE 272M

Signal delay:

Component digital: approx. 0.78 µs

NTSC composite digital: approx. 1.47

µs

Analog audio:

Approx. 1.1 ms (at 525/625 component serial digital)

Approx. 1.3 ms (at NTSC composite serial digital)

EDH:

Conforms to SMPTE RP165

ISR Output information

Status message:

5 items

Status message:

8 items

General —

Power requirements:

+5 V DC: 610 mA, -5 V DC: 630 mA

(Supplied from the PFV-D/PFV-HD

Series Interface Unit)

Power consumption:

Approx. 6.2 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

195 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x W):

195 x 25 mm

(7 3/4 x 1 inches)

Mass

Board:

Approx. 530 g (1 lb 3 oz)

Connector panel:

Approx. 180 g (6.3 oz)

NTSC COMPOSITE/

525/625 COMPONENT SERIAL

DIGITAL VIDEO INPUT

ANALOG AUDIO

INPUT

V+A

EDH

A/D

ISR

125

NTSC COMPOSITE/

525/625 COMPONENT

SERIAL DIGITAL VIDEO

WITH EMBEDDED AUDIO

*SGC_0117-0132 02.3.16 5:06 PM Page 126

Interface Processor D Series

BKPF-206

Audio/Video Demultiplexer Board

The BKPF-206 is an audio/video demultiplexer board that separates the digital audio signals multiplexed onto a component serial digital or NTSC composite serial digital video signal. After demultiplexing, the digital audio signals are converted to analog audio signals and output. A single BKPF-206 board demultiplexes two AES/EBU signals from a 525/625 component serial digital or an

NTSC composite serial digital video signal into four analog outputs. Up to four boards can be connected in cascade to demultiplex up to 16 analog audio channels from a 525/625 component serial digital signal.

Features

* Demultiplexes AES/EBU digital audio signals multiplexed onto a 525/625 component serial digital or NTSC composite serial digital video signal * Demultiplexing audio group selection (with a component serial digital video signal input) * Supports ISR * Supports EDH

The BKPF Series function boards install in both the PFV-D and the PFV-HD

Series Interface Units. In a PFV-HD Series Interface Unit, they can be installed together with the HKPF Series function boards.

Applicable Models

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

Optional Accessories

ECD-C cables XLR-3-Pin Type - XLR-3-Pin

Type Digital Audio Interface Cable

126

Rear Panel

*SGC_0117-0132 02.3.16 5:06 PM Page 127

Interface Processor D Series

Specifications

Inputs/outputs

SDI input:

SDI IN connector BNC type (1)

NTSC composite or 525/625 component serial digital signal conforming to

SMPTE259M-A/C (ITU-R

BT.601/BT.656); 143, 270, Mb/s

(selectable with on-board switch)

Input impedance:

75

Input return loss:

15 dB or more

Cable length:

200 m max. (When using a Belden

8281, Fujikura 5C2V or equivalent coaxial cable)

SDI outputs:

SDI OUT connectors (BNC type) (2)

Serial digital video signal of the same format as that to the input connector

0.8 Vp-p

610%, 75

Output return loss:

15 dB or more (5 MHz to 270 MHz)

Analog audio signal outputs:

ANALOG OUT AUDIO connectors (4)

XLR-3-32 (female), balanced

(transformerless electronic balanced differential output)

Output impedance:

Approx. 20

Reference input level:

+4 dBm (-10 to +8 dBm continuously variable)

Maximum output level:

+23.5 dBm or more (with a 600

Ω load)

+25.0 dBu or more

(into a high impedance load)

Conversion characteristics

Quantization:

20 bit linear/48 kHz sampling

Headroom:

20 dB (at operation level)

Frequency response:

20 Hz to 20 kHz within +0.2/-0.3 dB (at

1 kHz standard)

Distortion:

Less than 0.05% (at 1 kHz, reference level, 30 kHz low-pass)

Signal-to-noise ratio:

More than 93 dB

(Maximum output level, 30 kHz low-pass)

Crosstalk:

Less than -90 dB (up to 15 kHz)

Input signal common-mode rejection ratio:

More than 80 dB (at 60 Hz)

Phase difference between channels:

Within the same board: 0.1° or less (at 1 kHz)

Between the cascaded boards connected in parallel or cascade: 6° or less (at 1 kHz)

Deemphasis:

Automatically activated (time constant

50 µs/15 µs)

Signal delay:

Component digital: approx. 0.48 µs

NTSC composite digital: approx. 0.91

µs

Analog audio:

Approx. 0.76 ms (at 525/625 component serial digital)

Approx. 0.90 ms (at NTSC composite serial digital)

EDH:

Conforms to SMPTE RP165

ISR Output information

Status message:

7 items

Status message:

6 items

General

Power requirements:

+5 V DC: 460 mA, -5 V DC: 620 mA

(Supplied from the PFV-D/PFV-HD

Series Interface Unit)

Power consumption:

Approx. 5.4 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Storage temperature:

-20 to 60 °C (-4 to 140 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions

Board (H x W):

195 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel (H x W):

195 x 25 mm

(7 3/4 x 1 inches)

Mass

Board:

Approx. 530 g (1 lb 3 oz)

Connector panel:

Approx. 160 g (6.3 oz)

NTSC COMPOSITE/

525/625 COMPONENT

SERIAL DIGITAL VIDEO

WITH EMBEDDED AUDIO

EDH

D/A

ISR

127

NTSC COMPOSITE/

525/625 COMPONENT

SERIAL DIGITAL VIDEO

OUTPUT

ANALOG AUDIO

OUTPUT

*SGC_0117-0132 02.3.16 5:06 PM Page 128

Interface Processor D Series

BKPF-300

Digital Video Selector Board

The BKPF-300 digital video selector board is an eight input to two output switching matrix for component digital signals. Crosspoint information is memorized for 24 hours. Up to 14 BKPF-300 boards can be integrated to form a 112 input, 2 output, and switching matrix.

Features

* Eight input, two output, switching matrix * Simultaneous control of multiple signals with matrix level setting *

Control from BKS-R Series control units via S-BUS network * Supports ISR

The BKPF Series function boards install in both the PFV-D and the PFV-HD

Series Interface Units. In a PFV-HD Series Interface Unit, they can be installed together with the HKPF Series function boards.

Applicable Models

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

Specifications

Inputs/outputs

SDI inputs:

SDI IN connectors (BNC type) (8)

NTSC composite or 525/625 component serial digital signal conforming to

SMPTE259M-A/C (ITU-R BT.601/BT.656);

143, 270 Mb/s.

(Selectable with on-board switch)

SDI outputs:

SDI OUT connectors (BNC type) (2)

Serial digital video signal of the same format as that to the input connector

0.8 Vp-p

610%, 75 Ω

Input/output impedance:

75

Input/output return loss:

More than 15 dB (at 5 MHz to 270 MHz)

Cable length:

200 m max. (When using a Belden 8281,

Fujikura 5C2V or equivalent coaxial cable)

Rise and fall time:

Less than 1.5 ns

ISR output information

Status messages:

3 items

Setup messages:

2 items

General

Power requirements:

+5 V DC, 0.5 A, -5 V DC, 1.0 A

(Supplied from the PFV-D/PFV-HD Series

Interface Unit)

Power consumption:

Approx. 7.5 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions (H x W)

Board:

195 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel:

195 x 25 mm

(7 3/4 x 1 inches)

Mass

Board:

Approx. 550 g (1 lb 3 oz)

Connector panel:

Approx. 200 g (7 oz)

128

Rear Panel

NTSC COMPOSITE/

525/625 COMPONENT

SERIAL DIGITAL SIGNAL

INPUT

1

2

NTSC COMPOSITE/

525/625 COMPONENT

SERIAL DIGITAL SIGNAL

OUTPUT

*SGC_0117-0132 02.3.16 5:06 PM Page 129

Interface Processor D Series

BKPF-301

Analog Video Selector Board

The BKPF-301 analog video selector board is an eight input to two output switching matrix for NTSC/PAL composite analog signals. Cross point information is memorized for 24 hours.Up to four BKPF-301 boards can be integrated to form a 32 input, 2 output, and switching matrix.

Features

* Eight input, two output, switching matrix * Simultaneous control of multiple signals with matrix level setting *

Control from BKS-R Series control units via S-BUS network * Supports ISR

The BKPF Series function boards install in both the PFV-D and the PFV-HD

Series Interface Units. In a PFV-HD Series Interface Unit, they can be installed together with the HKPF Series function boards.

Applicable Models

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

Specifications

Inputs/outputs

Video inputs:

VIDEO IN connectors (BNC type) (8)

Video outputs:

VIDEO OUT connectors (BNC type) (2)

DG:

Less than 0.5% (1 Vp-p, 10 to 90%)

DP:

Less than 0.5° (1 Vp-p, 10 to 90%)

Frequency response:

60.2 dB (100 kHz to 8 MHz)

Crosstalk:

Less than -50 dB (at 5 MHz)

Signal-to-noise ratio:

Less than 65 dB (5 MHz LPF)

K factor:

Tilt:

Less than 0.5%

Less than 1%

Output gain stability:

60.1 dB

DC offset:

Less than

650 mV

Input/output return loss:

More than 40 dB

ISR output information

Status messages:

3 items

Setup messages:

1 item

General

Power requirements:

+5 V DC, 0.5 A, -5 V DC, 1.0 A

(supplied from the PFV-D/PFV-HD Series

Interface Unit)

Power consumption:

Approx. 3.5 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions (H x W)

Board:

195 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel:

195 x 25 mm

(7 3/4 x 1 inches)

Mass

Board:

Approx. 550 g (1 lb 3 oz)

Connector panel:

Approx. 200 g (7 oz)

129

NTSC/PAL

COMPOSITE ANALOG

VIDEO SIGNAL INPUT

Rear Panel

1

2

NTSC/PAL

COMPOSITE ANALOG

VIDEO SIGNAL OUTPUT

*SGC_0117-0132 02.3.16 5:06 PM Page 130

Interface Processor D Series

BKPF-350

Digital Audio Selector Board

The BKPF-350 digital audio selector board is an eight input to two output switching matrix for AES/EBU audio signals. Crosspoint information is memorized for 24 hours. Up to 14 BKPF-350 boards can be integrated to form a 112 input, 2 output switching matrix. Input and outputs are via BNC connectors.

Features

* Eight input, two output, switching matrix * Simultaneous control of multiple signals with matrix level setting *

Control from BKS-R Series control units via S-BUS network * Supports ISR

The BKPF Series function boards install in both the PFV-D and the PFV-HD

Series Interface Units. In a PFV-HD Series Interface Units, they can be installed together with the HKPF Series function boards.

Applicable Models

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

Specifications

Inputs/outputs

Audio signal inputs:

AES/EBU IN connectors (BNC type) (8)

Audio signal outputs:

AES/EBU OUT connectors (BNC type)

(2)

Rise and fall time:

37 ns

DC offset:

Less than

650 mV

ISR output information

Status messages:

3 items

Setup messages:

1 item

General

Power requirements:

+5 V DC, 0.5 A, -5 V DC, 1.0 A

(supplied from the PFV-D/PFV-HD

Series Interface Unit)

Power consumption:

Approx. 6 W

Operating temperature:

5 to 40 °C (41 to 104 °F)

Dimensions (H x W)

Board:

195 x 310 mm

(7 3/4 x 12 1/4 inches)

Connector panel:

195 x 25 mm

(7 3/4 x 1 inches)

Mass

Board:

Approx. 550 g (1 lb 3 oz)

Connector panel:

Approx. 200 g (7 oz)

AES/EBU DIGITAL

AUDIO INPUT

Rear Panel

1

2

AES/EBU DIGITAL

AUDIO OUTPUT

130

*SGC_0117-0132 02.3.16 5:06 PM Page 131

Interface Processor D Series

BKPF-351

Analog Audio Selector Board

The BKPF-351 analog audio selector board is an eight stereo input to one stereo output switching matrix for analog audio signals. Cross point information is memorized for 24 hours. Up to four BKPF-350 boards can be integrated to form a 32 input, 1 output stereo switching matrix. Inputs are via two D-sub 25-pin connectors and the output via a Phoenix type 6-pin connector.The BKPF Series function boards install in both the PFV-D and the PFV-HD Series Interface Units. In a

PFV-HD Series Interface Unit, they can be installed together with the HKPF Series function boards.

Features

* Eight analog stereo inputs, one stereo output switching matrix * Simultaneous control of multiple signals with matrix level setting * Control from BKS-R Series control units via S-BUS network * Supports ISR

Applicable Models

PFV-D10 Digital Video Interface Unit

PFV-D300 Digital Video Interface Unit

PFV-D50A Digital Video Interface Unit

Specifications

Inputs/outputs

Audio input:

ANALOG AUDIO IN (L) (R) connectors

(D-sub 25-pin)

(1 each)

Audio output:

ANALOG AUDIO OUT connector

(Phoenix type 6-pin) (1)

Input impedance:

20 k

/600

(selectable with on-board switch)

Output impedance:

Approx. 22

Nominal input/output level:

+4 dBm

Maximum input level:

+24 dBm

Maximum output level:

+24 dBm (600

Ω load, balanced)

Frequency response:

60.1 dB (20 Hz to 20 kHz, 1 kHz+4 dBm)

Distortion:

0.01% (20 Hz to 20 kHz, at +24 dBm output)

Crosstalk:

Less than -80 dB (20 Hz to 20 kHz, at

+24 dB output)

Signal-to-noise ratio:

More than 105 dB (30 kHz LPF, at nominal level)

ISR output information

Status messages:

3 items

Setup messages:

1 item

General

Power requirements:

+5 V DC, 0.5 A

-5 V DC, 1.0 A

(supplied from the PFV-D/PFV-HD Series

Interface Unit)

Power consumption:

Approx. 8 W

Operating temperature:

5 °C to 40 °C (41 °F to 104 °F)

Dimensions (H x W)

Board:

195 x 310 mm (7 3/4 x 12 1/4 inches)

Connector panel:

195 x 25 mm (7 3/4 x 1 inches)

Mass

Board:

Approx. 550 g (1 lb 3 oz)

Connector panel:

Approx. 200 g (7 oz)

ANALOG AUDIO

INPUT (L)

Rear Panel

ANALOG AUDIO

INPUT (R)

D-sub 25-pin

1 ANALOG AUDIO OUTPUT (R)

2 ANALOG AUDIO OUTPUT (L)

Phoenix 6-pin

131

*SGC_0117-0132 02.3.16 5:06 PM Page 132

Interface Processor D Series

132

*SGC_0133-0142 02.3.16 5:07 PM Page 133

Interface Processor Others

SIU-80 . . . . . . . . . . . . . . . . . 134

BKSI-2010 . . . . . . . . . . . . . . 135

BKSI-2011 . . . . . . . . . . . . . . 135

BKSI-2020 . . . . . . . . . . . . . . 136

BKSI-2030 . . . . . . . . . . . . . . 136

BKSI-2040 . . . . . . . . . . . . . . 137

BKSI-2041 . . . . . . . . . . . . . . 137

BKSI-2042 . . . . . . . . . . . . . . 138

BKSI-2043 . . . . . . . . . . . . . . 138

BKSI-2044 . . . . . . . . . . . . . . 139

BKSI-2070 . . . . . . . . . . . . . . 139

BKSI-2080 . . . . . . . . . . . . . . 140

BKSI-PS80 . . . . . . . . . . . . . 140

AMS-100 . . . . . . . . . . . . . . . 141

133

*SGC_0133-0142 02.3.16 5:07 PM Page 134

Interface Processor Others

SIU-80

System Interface Unit

Features

*Forms the core of a FlexSys system *Can accommodate up to eight BKSI Series boards *Continuous operation — the redundant power supply unit can be hot-swapped to ensure power supply to the boards *Equipped with ISR

(Interactive Status Reporting) *19-inch standard rack mountable and six rack units height

Optional Boards

BKSI-2010 Disk Controller Board

BKSI-2011 Disk Controller Memory Board

BKSI-2020 Bit Rate Reduction Encoder Board

BKSI-2030 Bit Rate Reduction Decoder

Board

BKSI-2040 Intelligent Device Controller (IDC)

CPU Board

BKSI-2041 IDC Serial Link Connector Board

BKSI-2042 IDC Serial I/F Connector Board

BKSI-2043 IDC Parallel I/F Connector Board

BKSI-2044 IDC S-BUS/VS-BUS I/F Connector

Board

BKSI-2050 Video A to D Converter Board

BKSI-2050P Video A to D Converter Board

BKSI-2060 Video D to A Converter Board

BKSI-2060P Video D to A Converter Board

BKSI-2070 Audio A to D Converter Board

BKSI-2080 Audio D to A Converter Board

Optional Software

BZA-900 Multi-Channel Manager Software

BZA-90 Time shift transmission manager software

BZA-81 Copy manager software

Specifications

Inputs/outputs

Input:

REF VIDEO INPUT connector (BNC type) (1)

Active loop-through output connector

(1)

REMOTE:

D-sub 25-pin, female (1)

S-BUS (BNC type) (1)

Active loop-through output connector

(1)

General

Power requirements:

AC 100 to 240 V

610%, 50/60 Hz

Power consumption:

Max. 400 W

Operation temperature:

5 to 40 °C (41 to 104 °F)

Operating humidity:

10 to 90% (no condensation)

Dimensions (W x H x D):

424

3 265 3 470 mm

(16 3/4 x 10 1/2 x 18 5/8 inches)

Mass:

Approx. 15 kg (33 lb 1 oz)

Rear Panel

134

*SGC_0133-0142 02.3.16 5:07 PM Page 135

Interface Processor Others

BKSI-2010

Disk Controller Board

The BKSI-2010 disk controller board converts SDDI

(Serial Digital Data Interface) signals to SCSI format signals and outputs them to be recorded on HDD arrays.

SCSI format playback signals from HDD arrays are converted back to SDDI format signals. As standard, the

BKSI-2010 supports two BKSI-2030 bit rate reduction boards, which convert the SDDI output signal to SDI. Two

RS-422A ports are provided to support control via the

Sony 9-pin disk protocol. Up to eight MAV-S100/S110

HDD arrays can be controlled via a daisy-chain connection, providing up to 24 hours of recording.

Applicable Models

SIU-80 System Interface Unit

BKSI-2011

Disk Controller Memory Board

The BKSI-2011 disk controller memory board is a daughter board of the BKSI-2010 disk controller board.

With the BKSI-2011 installed on the BKSI-2010, up to four outputs, or one input and three outputs can be controlled.

The output signals are multiplexed into an SDDI signal.

Applicable Models

SIU-80 System Interface Unit

Rear Panel

135

*SGC_0133-0142 02.3.16 5:07 PM Page 136

Interface Processor Others

BKSI-2020

Bit Rate Reduction Encoder Board

The BKSI-2020 bit rate reduction encoder board accepts an SDI signal, two AES/EBU digital audio signals and a time code signal. The SDI signal is compressed and, together with the digital audio and time code signals, converted to an SDDI format signal and output. * Video compression format: MPEG-2 4:2:[email protected] * Compression rate and GOP length: 18 Mbps, 2 Frame GOP * Audio encoding: two, uncompressed AES/EBU signals (48 kHz,

16 bit)

Applicable Models

SIU-80 System Interface Unit

BKSI-2030

Bit Rate Reduction Decoder Board

The BKSI-2030 bit rate reduction decoder board accepts an SDDI signal that combines compressed video with uncompressed AES/EBU audio and time code signals. It decodes and outputs these signals as an SDI signal which combines uncompressed video and audio signals.

Three outputs of this SDI signal are provided. The two

AES/EBU audio signals are also available on separate outputs, while a third AES/EBU output carries L/R channels selected from the four individual channels carried by the two AES/EBU signals. The time code signal is also output separately. The BKSI-2031 BRR

Decoder Jog Kit is attached to the BKSI-2030.

Applicable Models

SIU-80 System Interface Unit

Rear Panel

Rear Panel

136

*SGC_0133-0142 02.3.16 5:07 PM Page 137

Interface Processor Others

BKSI-2040

Intelligent Device Controller (IDC) CPU Board

The BKSI-2040 IDC CPU board is used in two ways. As a root controller the board receives commands from a

Server Management System Gateway (SMS/GW) computer and provides control to other BKSI-2040 boards used as sub-IDC boards within an SIU-80 interface unit.

As a device controller (sub-IDC board) it provides control for servers, routers, VTRs and other remote devices.

Each sub-IDC board must be used in conjunction with the appropriate connection board; BKSI-2041, BKSI-2042,

BKSI-2043 or BKSI-2044.

Applicable Models

SIU-80 System Interface Unit

BKSI-2041

IDC Serial Link Connector Board

The BKSI-2041 IDC serial link connector board is used in conjunction with a BKSI-2040 IDC CPU board configured as a root IDC. The BKSI-2041 provides the interface connections between the Server Management System

Gateway (SMS G/W) computer and the SIU-80 interface unit using D-sub 9-pin connectors. It also provides the interface connections for multiple SIU-80 interface units operating from a single SMS G/W.

Applicable Models

SIU-80 System Interface Unit

Rear Panel

137

*SGC_0133-0142 02.3.16 5:07 PM Page 138

Interface Processor Others

BKSI-2042

IDC Serial I/F Connector Board

The BKSI-2042 IDC serial interface connector board is used in conjunction with a BKSI-2040 IDC CPU board configured as a serial device controller (sub-IDC board).

The BKSI-2042 provides up to six simultaneous RS-232C or RS-422A control connections, on D-sub 9-pin connectors, between the SIU-80 interface unit and remote devices.

Applicable Models

SIU-80 System Interface Unit

Rear Panel

BKSI-2043

IDC Parallel I/F Connector Board

The BKSI-2043 IDC parallel interface connector board is used in conjunction with a BKSI-2040 IDC CPU board configured as a parallel device controller (sub-IDC board).

The BKSI-2043 provides up to 48 input/output connections (e.g. triggers and tallies), on a D-sub 50-pin connector, between the SIU-80 interface unit and up to two remote devices.

Applicable Models

SIU-80 System Interface Unit

Rear Panel

138

*SGC_0133-0142 02.3.16 5:07 PM Page 139

Interface Processor Others

BKSI-2044

IDC S-BUS/VS-BUS I/F Connector Board

The BKSI-2044 IDC S-BUS/VS-BUS interface connector board is used in conjunction with a BKSI-2040 IDC CPU board configured as an S-BUS or VS-BUS device controller (sub-IDC board). The BKSI-2044 has two sets of BNC connections, which provide the interface between the SIU-80 interface unit and the remote devices, such as routers or video servers.

Applicable Models

SIU-80 System Interface Unit

Rear Panel

BKSI-2070

Audio A to D Converter Board

The BKSI-2070 Audio A to D converter board accepts four analog audio signals and converts them into two

AES/EBU digital audio signals. Individual input level controls are provided internally, and externally via PCNS.

Input connectors are XLR type, the AES/EBU output signals are via BNC type connectors. A Frame Pulse input allows the BKSI-2070 to operate in synchronism with a video A to D converter, such as a

BKSI-2050/2050P.

Applicable Models

SIU-80 System Interface Unit

Rear Panel

139

*SGC_0133-0142 02.3.16 5:07 PM Page 140

Interface Processor Others

BKSI-2080

Audio D to A Converter Board

The BKSI-2080 audio D to A converter board accepts three AES/EBU digital audio signals and converts them into six analog audio signals. Individual output level controls are provided internally. The AES/EBU input connectors are BNC type, the analog output signals are via XLR type connectors.

Applicable Models

SIU-80 System Interface Unit

Rear Panel

BKSI-PS80

Backup Power Supply Unit

The BKSI-PS80 is an optional backup power supply for installation in an SIU-80 interface unit. It operates in parallel with the main PSU so that, if this fails, the

BKSI-PS80 will continue to supply DC power to the

SIU-80 and to installed BKSI Series boards.

140

*SGC_0133-0142 02.3.16 5:07 PM Page 141

Interface Processor Others

AMS-100

Audio Monitor Speaker

Features

*Analog/digital input capability; inputs are configured with optional modules, the BKAM-101 (Analog), the BKAM-102

(AES/EBU), and BKAM-103 (SDI with embedded audio).

Up to two modules are installed in the AMS-100. *Input selection up to 32 channels (when two modules are installed) *Input selection using external equipment via a remote connector *Monitoring through headphones and external equipment *Level indication on the front panel

LED VU meters *Magnetic shielding *Compact 1RU size,

19-inch rack-mountable unit *100 to 240 V AC operation with automatic switching

Supplied Accessories

Rack mounting plate (factory-installed) (2)

Optional Boards

BKAM-101 Analog Module

BKAM-102 AES/EBU Module

BKAM-103 SDI Module

Specifications

Inputs/Outputs

Parallel remote control interface:

TTL level, D-sub 25P (x1)

Monitor output (via remote connector):

2ch, +4 dBm, +24 dBm max., 600

Built-in speaker output:

2 W + 2 W

Headphone output:

-12 dBu at 8

Audio characteristics (via remote connector)

Frequency response:

20 Hz to 20 kHz

61 dB

Crosstalk between channels:

Less than -75 dB at 8 kHz

Signal-to-noise ratio:

More than 90 dB

T.H.D.:

Less than 0.05% at reference level

General

Power requirements:

AC 100 to 240 V, 50/60 Hz

Power consumption:

25 W

Rear Panel

Dimensions (W x H x D):

424 x 44 x 350 mm

(16 3/4 x 1 3/4 x 13 7/8 inches)

Mass:

5 kg (11 lb)

141

*SGC_0133-0142 02.3.16 5:07 PM Page 142

Interface Processor Others

142

*SGC_0143-0144 02.3.16 5:08 PM Page 143

PRODUCT INDEX

GENERAL INDEX

A

AMS-100 . . . . . . . . . . . . . .141

B

BKPF-012A . . . . . . . . . . . .122

BKPF-021 . . . . . . . . . . . . .124

BKPF-205 . . . . . . . . . . . . .125

BKPF-206 . . . . . . . . . . . . .127

BKPF-300 . . . . . . . . . . . . .129

BKPF-301 . . . . . . . . . . . . .130

BKPF-350 . . . . . . . . . . . . .131

BKPF-351 . . . . . . . . . . . . .132

BKPF-L601C . . . . . . . . . . . .71

BKPF-L602C . . . . . . . . . . . .72

BKPF-L603 . . . . . . . . . . . . .73

BKPF-L605 . . . . . . . . . . . . .75

BKPF-L606 . . . . . . . . . . . . .76

BKPF-L608C . . . . . . . . . . . .77

BKPF-L611 . . . . . . . . . . . . .79

BKPF-L612 . . . . . . . . . . . . .80

BKPF-L613C . . . . . . . . . . . .81

BKPF-L632 . . . . . . . . . . . . .83

BKPF-L641 . . . . . . . . . . . . .84

BKPF-L642 . . . . . . . . . . . . .86

BKPF-L653 . . . . . . . . . . . . .88

BKPF-L703A . . . . . . . . . . . .89

BKPF-L704 . . . . . . . . . . . . .91

BKPF-L723 . . . . . . . . . . . . .92

BKPF-L751 . . . . . . . . . . . . .93

BKPF-L752 . . . . . . . . . . . . .95

BKPF-L753A . . . . . . . . . . . .96

BKPF-L754 . . . . . . . . . . . . .97

BKPF-L803 . . . . . . . . . . . . .98

BKPF-R70A . . . . . . . . . . . .34

BKS-R1617 . . . . . . . . . . . . .23

BKS-R1618 . . . . . . . . . . . . .24

BKS-R3216 . . . . . . . . . . . . .25

BKS-R3219 . . . . . . . . . . . . .26

BKS-R3220 . . . . . . . . . . . . .27

BKS-R3240A . . . . . . . . . . .28

BKS-R3242A . . . . . . . . . . .29

BKS-R3248A . . . . . . . . . . .30

BKS-R3280 . . . . . . . . . . . . .31

BKS-R3281 . . . . . . . . . . . . .32

BKS-R5001 . . . . . . . . . . . . .35

BKSI-2010 . . . . . . . . . . . .135

BKSI-2011 . . . . . . . . . . . .135

BKSI-2020 . . . . . . . . . . . .136

BKSI-2030 . . . . . . . . . . . .136

BKSI-2040 . . . . . . . . . . . .137

BKSI-2041 . . . . . . . . . . . .137

BKSI-2042 . . . . . . . . . . . .138

BKSI-2043 . . . . . . . . . . . .138

BKSI-2044 . . . . . . . . . . . .139

BKSI-2070 . . . . . . . . . . . .139

BKSI-2080 . . . . . . . . . . . .140

BKSI-PS80 . . . . . . . . . . . .140

BVS-A3232 . . . . . . . . . . . . .21

BVS-V3232 . . . . . . . . . . . . .22

BZR-2000 . . . . . . . . . . . . . .36

BZR-IF310 . . . . . . . . . . . . .37

D

DVS-128 . . . . . . . . . . . . . . .17

DVS-RS1616 . . . . . . . . . . .19

DVS-TC3232 . . . . . . . . . . . .20

E

ECD-10C . . . . . . . . . . . . . .40

ECD-30C . . . . . . . . . . . . . .40

ECD-3C . . . . . . . . . . . . . . .40

ECD-C cables . . . . . . . . . . .40

H

HDS-X3400 . . . . . . . . . . . .16

HDS-X3600 . . . . . . . . . . . .15

HDS-X3700 . . . . . . . . . . . .14

HDS-X5800 . . . . . . . . . . . .12

HKDV-900 . . . . . . . . . . . . .116

HKPF-101 . . . . . . . . . . . . .102

HKPF-102 . . . . . . . . . . . . .103

HKPF-103M . . . . . . . . . . .104

HKPF-105M . . . . . . . . . . .105

HKPF-106M . . . . . . . . . . .106

HKPF-1125A . . . . . . . . . . .107

HKPF-525AV . . . . . . . . . .110

HKPF-525V . . . . . . . . . . . .109

HKPF-9000 . . . . . . . . . . . .114

HKPF-D270 . . . . . . . . . . .111

HKPF-E270 . . . . . . . . . . . .117

HKPF-SP003 . . . . . . . . . . .61

HKPF-SP021 . . . . . . . . . . .63

HKPF-SP022 . . . . . . . . . . .65

HKSP-008HD . . . . . . . . . . .46

HKSP-061M . . . . . . . . . . . .48

HKSP-105 . . . . . . . . . . . . . .50

HKSP-106 . . . . . . . . . . . . . .52

HKSP-1125 . . . . . . . . . . . . .59

HKSP-300 . . . . . . . . . . . . . .54

HKSP-313 . . . . . . . . . . . . . .57

HKSP-525 . . . . . . . . . . . . . .55

HKSP-R80 . . . . . . . . . . . . .33

P

PFV-D10 . . . . . . . . . . . . . .119

PFV-D300 . . . . . . . . . . . . .121

PFV-D50A . . . . . . . . . . . . .120

PFV-HD300A . . . . . . . . . .101

PFV-HD50A . . . . . . . . . . .100

PFV-L10 . . . . . . . . . . . . . . .70

PFV-SP3100 . . . . . . . . . . . .44

PFV-SP3300 . . . . . . . . . . . .45

R

RCC-5R . . . . . . . . . . . . . . .40

RCC-R cables . . . . . . . . . . .40

RMM-30 . . . . . . . . . . . . . . .42

S

SIU-80 . . . . . . . . . . . . . . .134

U

UCP-8060 . . . . . . . . . . . . . .67

143

*SGC_0143-0144 02.3.16 5:08 PM Page 144

PRODUCT INDEX

CATEGORY INDEX

Cables

ECD-10C . . . . . . . . . . . . . .40

ECD-30C . . . . . . . . . . . . . .40

ECD-3C . . . . . . . . . . . . . . .40

ECD-C cables . . . . . . . . . . .40

RCC-5R . . . . . . . . . . . . . . .40

RCC-R cables . . . . . . . . . . .40

Common Accessories

RMM-30 . . . . . . . . . . . . . . .42

Interface Processor D Series

BKPF-012A . . . . . . . . . . . .122

BKPF-021 . . . . . . . . . . . . .124

BKPF-205 . . . . . . . . . . . . .125

BKPF-206 . . . . . . . . . . . . .127

BKPF-300 . . . . . . . . . . . . .129

BKPF-301 . . . . . . . . . . . . .130

BKPF-350 . . . . . . . . . . . . .131

BKPF-351 . . . . . . . . . . . . .132

HKDV-900 . . . . . . . . . . . . .116

HKPF-101 . . . . . . . . . . . . .102

HKPF-102 . . . . . . . . . . . . .103

HKPF-103M . . . . . . . . . . .104

HKPF-105M . . . . . . . . . . .105

HKPF-106M . . . . . . . . . . .106

HKPF-1125A . . . . . . . . . . .107

HKPF-525AV . . . . . . . . . .110

HKPF-525V . . . . . . . . . . . .109

HKPF-D270 . . . . . . . . . . .111

HKPF-E270 . . . . . . . . . . . .117

PFV-D10 . . . . . . . . . . . . . .119

PFV-D300 . . . . . . . . . . . . .121

PFV-D50A . . . . . . . . . . . . .120

PFV-HD300A . . . . . . . . . .101

PFV-HD50A . . . . . . . . . . .100

Interface Processor L Series

BKPF-L601C . . . . . . . . . . . .71

BKPF-L602C . . . . . . . . . . . .72

BKPF-L603 . . . . . . . . . . . . .73

BKPF-L605 . . . . . . . . . . . . .75

BKPF-L606 . . . . . . . . . . . . .76

BKPF-L608C . . . . . . . . . . . .77

BKPF-L611 . . . . . . . . . . . . .79

BKPF-L612 . . . . . . . . . . . . .80

BKPF-L613C . . . . . . . . . . . .81

BKPF-L632 . . . . . . . . . . . . .83

BKPF-L641 . . . . . . . . . . . . .84

BKPF-L642 . . . . . . . . . . . . .86

BKPF-L653 . . . . . . . . . . . . .88

BKPF-L703A . . . . . . . . . . . .89

BKPF-L704 . . . . . . . . . . . . .91

BKPF-L723 . . . . . . . . . . . . .92

BKPF-L751 . . . . . . . . . . . . .93

BKPF-L752 . . . . . . . . . . . . .95

BKPF-L753A . . . . . . . . . . . .96

BKPF-L754 . . . . . . . . . . . . .97

BKPF-L803 . . . . . . . . . . . . .98

PFV-L10 . . . . . . . . . . . . . . .70

Interface Processor Others

AMS-100 . . . . . . . . . . . . . .141

BKSI-2010 . . . . . . . . . . . .135

BKSI-2011 . . . . . . . . . . . .135

BKSI-2020 . . . . . . . . . . . .136

BKSI-2030 . . . . . . . . . . . .136

BKSI-2040 . . . . . . . . . . . .137

BKSI-2041 . . . . . . . . . . . .137

BKSI-2042 . . . . . . . . . . . .138

BKSI-2043 . . . . . . . . . . . .138

BKSI-2044 . . . . . . . . . . . .139

BKSI-2070 . . . . . . . . . . . .139

BKSI-2080 . . . . . . . . . . . .140

BKSI-PS80 . . . . . . . . . . . .140

SIU-80 . . . . . . . . . . . . . . .134

Interface Processor SP Series

HKPF-SP003 . . . . . . . . . . .61

HKPF-SP021 . . . . . . . . . . .63

HKPF-SP022 . . . . . . . . . . .65

HKSP-008HD . . . . . . . . . . .46

HKSP-061M . . . . . . . . . . . .48

HKSP-105 . . . . . . . . . . . . . .50

HKSP-106 . . . . . . . . . . . . . .52

HKSP-1125 . . . . . . . . . . . . .59

HKSP-300 . . . . . . . . . . . . . .54

HKSP-313 . . . . . . . . . . . . . .57

HKSP-525 . . . . . . . . . . . . . .55

PFV-SP3100 . . . . . . . . . . . .44

PFV-SP3300 . . . . . . . . . . . .45

UCP-8060 . . . . . . . . . . . . . .67

Routing Switchers

BKPF-R70A . . . . . . . . . . . .35

BKS-R1617 . . . . . . . . . . . . .23

BKS-R1618 . . . . . . . . . . . . .24

BKS-R3216 . . . . . . . . . . . . .25

BKS-R3219 . . . . . . . . . . . . .26

BKS-R3220 . . . . . . . . . . . . .27

BKS-R3240A . . . . . . . . . . .28

BKS-R3242A . . . . . . . . . . .29

BKS-R3248A . . . . . . . . . . .30

BKS-R3280 . . . . . . . . . . . . .31

BKS-R3281 . . . . . . . . . . . . .32

BKS-R5001 . . . . . . . . . . . . .35

BVS-A3232 . . . . . . . . . . . . .21

BVS-V3232 . . . . . . . . . . . . .22

BZR-2000 . . . . . . . . . . . . . .36

BZR-IF310 . . . . . . . . . . . . .37

DVS-128 . . . . . . . . . . . . . . .17

DVS-RS1616 . . . . . . . . . . .19

DVS-TC3232 . . . . . . . . . . . .20

HDS-X3400 . . . . . . . . . . . .16

HDS-X3600 . . . . . . . . . . . .15

HDS-X3700 . . . . . . . . . . . .14

144

HDS-X5800 . . . . . . . . . . . .12

HKSP-R80 . . . . . . . . . . . . .33

VTR Accessories/Peripherals

HKPF-9000 . . . . . . . . . . . .114

*SGC_0145-0161 02.3.19 5:37 PM Page 145

Technical References

Routing Switchers . . . . . . . . 146

ISR . . . . . . . . . . . . . . . . . . . 158

EDH . . . . . . . . . . . . . . . . . . 160

145

*SGC_0145-0161 02.3.19 5:37 PM Page 146

Technical References

Routing Switchers

Introduction to the Sony Signal Routing System

The Sony routing system on a complete range of flexible, modular, signal routing matrixes. It interfaces to other routing equipment, production and presentation switchers, tally and UMD systems to from multi-signal switching systems. The range includes:

• HDS-X5800/X3000 Series, a range of multi bit-rate routing switchers

• DVS-128, a routing switcher for both analog video and analog/digital audio

• DVS-RS1616 for separate RS-422A and RS-232C control routing

• DVS-TC3232 for separate line code routing

• BVS-V3232 for routing PAL and NTSC composite analog video

• BVS-A3232 for routing analog audio

• BKPF-300 Series, a routing of four boards for dogital/analog, video/audio routing.

The BKPF-300 Series mount into PFV-D/PFV-HD Series Interface Units.

• HKSP-061M for routing serial digital signals

HKSP-061M mounts into PFV-SP Series Interface Units.

Some router types have the capability of being expanded to form a lager matrix.

For example, an HDS-X5800 router has a 264 x 272 matrix. However, using optional kits several units can be connected to form a lager square or rectangular routing matrix.

When forming a multi-switching system, several different signal types may be included in the system-digital video and audio, analog video and audio, time code and RS-422A. To allow independent switching of different signal types, routing matrix can be placed on different signal types switching can be independent or married- i.e. two different signal types switched simultaneously. In the Sony routing system, up to sixteen levels are available to accommodate different signal types.

S-BUS Router Control

Supporting the overall range is the Routing Controll System, a highty sophisticated local area network called Sony S-BUS. However, S-BUS gose beyond just being a control system-it is an operational philosophy blending a sophisticated control system with elements such as control panels, production switchers and third-party router integration and lallies.

S-BUS connects all these elements together using standard video coaxial cables.

This is an advantage, as both interconnection and maintenance are low in cost.

146

*SGC_0145-0161 02.3.19 5:37 PM Page 147

Technical References

S-BUS also features some advanced features:

Free I/O assingment across all levels

• any source or destination can be freely assigned to any crosspoint regardless of physical connection

Full signal breakaway

• sources in a multilevel system can be switched married or unmarried

Descriptive naming

• sources and destinations can be named to match the user’s needs

Virtual matrix management

• matrix can be placed virtualy within S-BUS space for more efficient operation

Tie-line management

• tie-line management provides for connection of different routing switchers for signal interconnections

Source, destination and crosspoint protection mechanisms

• sources and destination can be inhibited, protected or made secret

Password protection

• passwords can be used to restrict the personnel able to make changes

Powerful phantom facilities

• multiple crosspoint changes can be made from a single push-button depression

In addition to S-BUS, Sony routing systems can be controlled from RS-422A.This method of control permits additional flexibility, interfacting to automation system is just one example. In smaller routing matrix, parallel control is adopted to provide a low-cost control system

System Control

A wide range of control units is available a Sony routing system.

• Sixteen and thirty-two button-pet-souce control units

• Multi-source control units

• Multi-destination control units

• X/Y control units

Some of these units support VTR transport control, level switching and destination control. A unique feature is that unit software and set-up data can easily be copied from one unit to another using S-BUS.

Extenderd control features, provided by BZR-2000 software running on an IBM compatible machine include:

• graphic displays of crosspoint maps

• interactive graphics for system configuration

• display of video signal sources and destinations on a PC VDU

• multiple-user environment

147

*SGC_0145-0161 02.3.19 5:37 PM Page 148

Technical References

Integrated Systems

A key element of Sony routing systems is their ability to provide an integrated solution for the user.

Sony routing systems can be interfaced to Sony MVS-8000 Series/DVS-7000 Series production switchers. With the high level of integration available, destinations fed from the router to the switcher can be controlled, so that the production switcher is effectively expanded to be able to accommodate all the available sources. In addition the router source named can be displayed on the control panel of the production switcher. It is also possible to control the router from the switcher and vice-versa.

Legacy third-party routing systems may also require to be controlled. Sony routing systems can either control the router or, in some cases, be controlled from the legacy system.

Within S-BUS, significant support is provided for tally and management. The power of this process is clearly visible in an integrated solution, where tallies can pass through several routers without losing IDs. Sony camera systems can also be interfaced, eliminating separate connections to each

CCU for Red and Green tallies.

Critical Applications

In any mission-critical system redundancy is a pre-requisite to ensure that the system is available at all times, even in the unlikely event of a power supply or system fault.

Sony routing systems are no exception to this philosophy. Backup power supplies are available for most routing and interfacting equipment.

Redundancy also extends to being able to provide backup control boards for the CPUs in a routing system.

In addition to providing redundant power supplies and control boards, data is held in on-board memories with a 24-hour battery backup, and can also be saved to floppy disk. In Sony routing systems, BZR-20 software is supplied as an accessory so that the systems data contents easily saved.

148

*SGC_0145-0161 02.3.19 5:37 PM Page 149

Technical References

S-BUS System Components and Control

PC TERMINAL

Ethernet

S-BUS

PORTS

MULTI BIT-RATE

ROUTING SWITCHER

HDS-X5800/X3000

SERIES

PRIMARY STATION

PC WITH BZR-2000

ROUTING SWITCHER

SETUP SOFTWARE

S-BUS

TO OTHER SYSTEM

COMPONENTS

MAX. NUMBER OF UNITS

CONNECTED-253

MAX. CABLE LENGTH 500m

S-BUS DISTRIBUTION

BOARD

BKPF-L803

COMMAND

NETWORK UNIT

CNU-700

MVS-8000

SWITCHER SYSTEM

SOURCES

ANALOG VIDEO

ROUTING SWITCHER

BVS-V3232

ANALOG AUDIO

ROUTING SWITCHER

BVS-A3232

DESTINATIONS

TALLY INTERFACE

UNIT

BKDS-7700

MULTI-DISPLAY

CONTROL UNIT

BKS-R1617

UNIVERSAL

CONTROL UNIT

BKS-R1608/R1618

MULTI BUS

CONTROL UNIT

BKS-R3216

UNIVERSAL

CONTROL UNIT

BKS-R3219

X-Y CONTROL UNIT

BKS-R3220

BVP/HDC SERIES

VIDEO CAMERA

DVS-7000 SERIES

VIDEO SWITCHER

HYBRID ANALOG

A/V SWITCHER

DVS-128

TIME CODE

ROUTING SWITCHER

DVS-TC3232

X-Y CONTROL UNIT

BKS-R3240A/3242A/3248A

SINGLE STATUS

DISPLAY UNIT

BKS-IR3280/R3281

S-BUS SUB-NET

CONTROLLER

BKPF-R70A, BZR-IF310

S-BUS SUB-NET

THIRD PARTY

ROUTING SYSTEM

S-BUS INTERFACE

RS-422A

ROUTING SWITCHER

DVS-RS1616

ROUTING SWITCHER

CONTROLLER

HKSP-R80/R81

S-BUS SUB-NET

149

*SGC_0145-0161 02.3.19 5:37 PM Page 150

Technical References

Powerful Matrix Control Functions of Sony HDS-X5800/X3000 Series

The introduction of the Sony multi bit-rate routing switchers has become an effective way of solving the problems caused by the rapid increase in the number of signal formats. Their benefits include:

● Space and cost saving

• SD SDI & HD SDI in a single frame under the same control

● Flexible and simple SD/HD migration

● Efficient use of conversion equipment

• Sharing up/down converters between multiple signal paths

Figure-1

Conventional SDTV/HDTV routing system

SDTV Digital

Video Editing Suite

Analog

Production

Facilties

Video A/D

Converter

Video A/D

Converter

SDTV Digital

Video Router

SDTV to HDTV

Up Converter

HDTV to SDTV

Down Converter

HDTV Digital

Video Editing Suite

HDTV Digital

Video Router

Simplified routing system using HDS-X3000 Series

SDTV Digital

Video Editing Suite

HDTV Digital

Video Editing Suite

Analog

Production

Facilties

Video A/D

Converter

Video A/D

Converter

Multi Bit-rate Router

SDTV to HDTV

Up Converter

HDTV to SDTV

Down Converter

Using the HDS-X5800/X3000 Series to Simply Operation with Signal Coexistence

The multi bit-rate matrix system only becomes an effective signal management system when it is combined with various control functions. In particular, the equipment expansion method shown

In Figure-1 requires down conversion and D/A conversion each time HDTV signal elements are taken into analog equipment and cannot be implemented without the tie-line function described below.

The HDS-X5800/X3000 Series not only provides complete compatibility with control systems used with legacy Sony routing switchers but also fully utilizes the many matrix control functions developed by Sony.

150

*SGC_0145-0161 02.3.19 5:37 PM Page 151

Technical References

Input/output system protection functions (protect and secret functions)

There are two protection functions:

“Protect” function prevents the output destination from being re-assigned from another remote control panel.

“Secret” function ‘hides’ the input sources that cannot be selected to any destination from any remote control panel.

Crosspoint disabling function

This function inhibits individual crosspoints to limit the availability of each source to individual destinations.

Figure-2 Crosspoint disabling function

SET INHIBIT TABLE

DEST.

SOURCE

001

OUT001

OUT002

OUT003

01--08 09--16 17--24

HDS-X5800 V1.00

25--32 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

33--40

--------

STATION NUMBER 1

41--48

--------

49--56

--------

57--64

--------

----------------------------xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

OUT004

OUT005

OUT006

OUT007 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

OUT008

DEST.

009

OUT009

OUT010

OUT011

OUT012

OUT013

OUT014

OUT015

OUT016 xxxxxxxx

SOURCE

01--08 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

09--16 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

17--24 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

25--32 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

33--40 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

41--48 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

49--56 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

57--64 xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx xxxxxxxx

F1: SEARCH F2: JUMP F3: LEFT F4: RIGHT

Ctrl-E: RETURN TO MENU

“-” mark is an inhibited crosspoint.

Phantom function (salvo function)

This function allows the switching of multiple crosspoints at the same time with a single button operation. The following two types of settings can be made:

(1) “Local phantom”: Registers up to 64 crosspoints for each remote control panel.

(2) “Global phantom”: Registers up to 2,800 crosspoints for the routing switchers set by the primary stations.

Names can be set for phantoms (groups of crosspoints switched simultaneously). Since local phantoms are registered for each remote control panel, the same name can be used for a different group of crosspoints on each remote control panel.

On the other hand, global phantoms are useful when there are many crosspoints to switch simultaneously, or when sharing the same phantom across multiple remote control panels.

Also, the number of phantoms set for each unit can be increased by combining global phantoms and local phantoms.

151

*SGC_0145-0161 02.3.19 5:37 PM Page 152

Technical References

Name setting function

Names can be set for Sources and Destinations in order to identify the signals connected.

The following two methods are available for setting names.

(1) “Type name (VTR, CAM, etc.) + Number”: 32 names each comprising up to four letters and three numbers.

(2) “Descriptive name (REPORT_FROM_LA, etc)”: Name made of up to 16 Latin alphanumeric characters.

Eight group of data can be registered within the primary station with each group containing

160 descriptive names. This data can be sent and displayed on UMDs (Under Monitor

Displays) and remote control panels.

Tie-line function

This function automatically selects signal paths

Figure-3

across multiple routing switchers. This function is used to effectively utilize external devices between routers, or to increase the number of inputs/outputs. Up to 255 signal paths connecting specific inputs and outputs can be registered for each group (source, net, and destination). When the input and output are selected, the primary station CPU automatically selects an unused signal path. Signal paths can be set over multiple levels (Figure 3). This function makes possible the efficient system operation of complicated signal paths through routing switchers without having to separately activate the appropriate crosspoints in each of these routers.

D/A converter

Digital Matrix Switcher

(LEVEL-2)

Figure-4

A/D converter

Analog Matrix Switcher

(LEVEL-1)

Tie-Line Function Concept Diagram

12

Free input and output assignment function

Free assignment of inputs and outputs allows

Level-3

(Time Code)

10

Level-2

(Audio)

1

Level-1

(Video)

VTR 001

3

7

To digital production facilities

4

To analog production facilities sources and destinations on different levels to be grouped under a single source or destination

CUT 004 name. For example the video, audio and time code signals of VTR-001 do not have to be

Free Input and Output Assignment

assigned to the same channel on each level, but could be assigned as, say, channel 1 of the video router, channel 10 of the audio router and channel 12 of the time code router. This function provides a much more flexible signalhandling environment.

152

*SGC_0145-0161 02.3.19 5:37 PM Page 153

Technical References

Virtual mapping function

This function lays out routing switcher crosspoints on a virtual matrix of 1024 inputs x 1024 outputs when eight levels are used or 1024 inputs x 512 outputs when 16 levels are used.

The virtual mapping capability of Sony routing switchers features two types of mapping:

(1) A single routing switcher can be mapped to operate as a number of individual routing switchers. For example, a single 256 x 256 multi bit rate routing switcher can be divided into, say, a 192 x 192 switcher and a 64 x 64 switcher so that the corresponding crosspoints on these two levels are switched simultaneously. This allows a 192 x 192 HD switcher and a

64 x 64 SD switcher to be created (Figure-5).

Figure-5

256 192

(a)

1

1

192

64

64

1

1

1

1

64

64 LEVEL-3

(b)

HDS-X5800

192

256

LEVEL-2

192

Virtual Mapping Function Concept Diagram 1

(2) Multiple routing switchers can be mapped on a larger, virtual routing level (Figure-6). This application could be used in the tie-line management system described above in section 5.

Figure-6

150 136 104

HDS-X3600

(LEVEL-2)

40 32 16 1

1

16

32

40

HDS-X3400

(LEVEL-1)

HDS-X3400

(LEVEL-3)

104

DVS-A3232

(LEVEL-4)

136

150

Virtual Mapping Function Concept Diagram 2

Virtual Matrix Space

Self-diagnostic function

This function can send information on errors and the presence/absence of inputs to a control terminal connected to the primary station for display.

153

*SGC_0145-0161 02.3.19 5:37 PM Page 154

Technical References

Main Features of the HDS-X5800/X3000 Series

Support for multiple bit rates independent of signal format

These switches support not only HD SDI, but also various other transmission rates of SDI

(540 Mb/s, 360 Mb/s, 270 Mb/s and 143 Mb/s) and SDTI (Table 1), and support embedded

AES/EBU Audio.

Both HD-SDI and SD-SDI I/O boards can be simultaneously installed, providing a real opportunity to meet tomorrow’s routing requirements. Installed HDS-X3000/5800 routers containing SD-SDI I/O boards can easily include HD-SDI I/O boards when necessary.

Equalization of both the HDS-X5800 and –X3000 Series is optimized to 1.5 Gb/s when fitted with

HD SDI/SDI compliant boards.

Table 1 Signal Formats Supported by the HDS-X5800/X3000 Series

Signal Format

Composite Digital Video (NTSC)

Composite Digital Video (PAL)

Component Digital Video (13.5/18 MHz Sampling)

Bit Rate

143 Mb/s

177 Mb/s

270 Mb/s, 360 Mb/s

(NRZI coded)

Component HDTV (1035i/1080i/720p)

SDTI (Compressed Video Transport)

1.485 Gb/s

270 Mb/s

(NRZI coded)

Mezzanine HDTV (Proposed)540 Mb/s

* Rise and fall times of SD-SDI output signals may be faster than defined by SMPTE259M.

SMPTE (Draft)

Standard

SMPTE259M-A

SMPTE259M-B

SMPTE259M-C/D

SMPTE292M A-M

SMPTE305M, SMPTE259M

Modular structures for flexible construction and expansion of different sizes of matrix

HDS-X5800/X3000 Series routers may be configured to meet initial size requirements, and then easily increased in size and format as required.

154

*SGC_0145-0161 02.3.19 5:37 PM Page 155

Technical References

Figure-7

Ref. In A/B

In 1-16 In 17-32 In 33-48 In 49-64 In 65-80 In 81-96 In 97-112 In 113-128

In CN

16

In CN

16

1:4 Distributor (1)

In CN

16

In CN

16

1:4 Distributor (2)

In CN

16

In CN

16

1:4 Distributor (3)

In CN

16

In CN

16

1:4 Distributor (4)

32

32

32

32

32

Backup CPU

32

128 In x 32 Out Matrix and Monitor Out (1)

32 32

128 In x 32 Out Matrix and Monitor Out (2)

32 32

128 In x 32 Out Matrix and Monitor Out (3)

32 32

128 In x 32 Out Matrix and Monitor Out (4)

32

17

Out CN

17

Out CN

32

17

Out CN

17

Out CN

32

17

Out CN

17

Out CN

32

17

Out CN

17

Out CN

Backup Power Supply

CPU Power Supply

Network A/B

(10Base-T)

Alarm Out

Remote 1 (S-BUS)

Remote 2 (RS-422A)

Remote 3 (RS-232C)

AC In A AC In B

HDS-X3700 Internal Configuration Diagram

Figure-8

Out 1-16

Mon Out 1

Out 7-32

Mon Out 1

Out 33-48

Mon Out 1

Out 49-64

Mon Out 1

Out 65-80

Mon Out 1

Out 81-96

Mon Out 1

Out 97-112

Mon Out 1

Out 113-128

Mon Out 1

Out 1-17

Out 18-34

Out 35-51

Out 52-68

In 1-17 In 18-33 In 34-50 In 51-66

Cas CN

17

17

Cas CN

Cas CN

17

Cas CN

17

In CN In CN

17 16

1:8 Distributor (1)

33

33

In CN In CN

17 16

1:8 Distributor (2)

33

264 In x 34 Out Matrix (1)

33

264 In x 34 Out Matrix (2)

In 232-248 In 249-264

In CN In CN

17 16

1:8 Distributor (8)

33

33

17

Out CN

17

Out CN

17

Out CN

17

Out CN

Out 1-17

Out 18-34

Out 35-51

Out 52-66

Out 239-255

Out 256-272

Cas CN

17

17

Cas CN

Ref. In A/B/C/D

33

CPU

33

264 In x 34 Out Matrix (8)

Backup CPU Backup Power Supply

POWER Supply

33

17

Out CN

17

Out CN

Out 239-255

Out 256-272

Network

(100Base-TX)

Alarm Out

Remote 1 A/B1/B2/C/D (S-BUS)

Remote 2 (RS-422A)

Remote 3 (RS-232C)

AC In A1

AC In A2

AC In B2

AC In B2

HDS-X5800 Internal Configuration Diagram

155

*SGC_0145-0161 02.3.19 5:37 PM Page 156

Technical References

Affinity with and expandability in current broadcast and production environments.

HDS-X5800/X3000 Series routing switchers are easily installed into today’s system environments, providing:

(1) Tri-level sync and black burst sync input

(2) 59.94 and 50 Hz vertical sync both possible

(3) Simultaneous control of multiple signals through level settings

(4) Four systems of signal switching control – S-BUS terminal, RS-422A control,

RS-232C control, and Ethernet control

Compact and space saving

Every possible measure has been taken to reduce the space requirements of

HDS-X5800/X3000 Series routing switchers so that they can be used in environments where there is very little margin of space such as existing remote vehicles and crowded machine rooms. To overcome these issues, all Sony routers have been designed with a small chassis and high-density matrix, and in the case of the HDS-X3400, local control panels are available.

Figure-9

~AC IN

B1

B2

Securing maintainability and reliability

Although designed to be compact, maintenance and reliability have not been compromised:

(1) Backup power supplies and CPU boards are available on most models

(2) Crosspoint data storage

(3) Board maintenance from front

(4) Fault notice functions

(self-diagnostic functions)

~AC IN

A1

A2

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

IN 1 OUT 1

IN 1

1

OUT 1

1

IN 1 OUT 1

IN 1

1

OUT 1

1

IN 1 OUT 1

IN 1

1

OUT 1

1

IN 1 OUT 1

IN 1

1

OUT 1

1

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

IN 1 OUT 1

IN 1

1

OUT 1

1

IN 1 OUT 1

IN 1

1

OUT 1

1

IN 1 OUT 1

IN 1

1

OUT 1

1

IN 1 OUT 1

IN 1

1

OUT 1

1

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

16

17

14

15

12

13

10

11

8

9

6

7

4

5

2

3

IN 1

1

OUT 1

1

IN 1

1

OUT 1

1

IN 1

1

OUT 1

1

IN 1

1

OUT 1

1

2 2 2 2 2 2 2 2

13

14

11

12

15

16

9

10

7

8

5

6

3

4

15

16

17

13

14

11

12

9

10

7

8

5

6

3

4

13

14

11

12

15

16

9

10

7

8

5

6

3

4

15

16

17

13

14

11

12

9

10

7

8

5

6

3

4

13

14

11

12

15

16

9

10

7

8

5

6

3

4

15

16

17

13

14

11

12

9

10

7

8

5

6

3

4

15

16

17

13

14

11

12

9

10

7

8

5

6

3

4

13

14

11

12

15

16

9

10

7

8

5

6

3

4

IN 1

1

OUT 1

1

IN 1

1

OUT 1

1

IN 1

1

OUT 1

1

IN 1

1

OUT 1

1

2 2 2 2 2 2 2 2

REF IN

REMOTE 1

A

A

B1

13

14

11

12

15

16

9

10

7

8

5

6

3

4

15

16

17

13

14

11

12

9

10

7

8

5

6

3

4

15

16

17

13

14

11

12

9

10

7

8

5

6

3

4

13

14

11

12

15

16

9

10

7

8

5

6

3

4

15

16

17

13

14

11

12

9

10

7

8

5

6

3

4

13

14

11

12

15

16

9

10

7

8

5

6

3

4

13

14

11

12

15

16

9

10

7

8

5

6

3

4

15

16

17

13

14

9

10

7

8

5

6

3

4

B

C

D

11

12

REMOTE 2 REMOTE 3

A A

B

B2

C

D

B

CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN CAB IN

CASCADE

IN

NETWORK

1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH 1-8 CH

9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH 9-17 CH

HDS-X5800 Rear Panel

156

*SGC_0145-0161 02.3.19 5:37 PM Page 157

Technical References

Figure-10

IN 1-264

264 boards

PFV-SP3300

HKPF-SP003

IN 265-528

264 boards

PFV-SP3300

HKPF-SP003

IN 529-792

264 boards

PFV-SP3300

HKPF-SP003

IN 793-1024 (+extra 32*)

264 boards

PFV-SP3300

HKPF-SP003

HDS-X5800 HDS-X5800 HDS-X5800 HDS-X5800

OUT

1-272

HDS-X5800 HDS-X5800 HDS-X5800 HDS-X5800

OUT

273-544

HDS-X5800 HDS-X5800 HDS-X5800 HDS-X5800

OUT

545-816

HDS-X5800 HDS-X5800 HDS-X5800 HDS-X5800

OUT

817-1024

(+extra 64*)

*Remarks: Maximum size is thecrefically (Physically) 1056 x1090 but 1024 x 1024 effectually due to current S-BUS mapping space

Cascade Connection Example of HDS-X5800

157

Features and specifications are subject to change without notice.

*SGC_0145-0161 02.3.19 5:37 PM Page 158

Technical References

Technical References: ISR

ISR—Interactive Status Reporting

Television broadcast and production systems become ever more complex and the ability to monitor equipment ever more important – but at the same time increasingly difficult. Equipment downtime can have a dramatic effect on revenue, so knowledge of potential equipment failure is of great value. The solution is the Sony ISR

(Interactive Status Reporting) system, which allows a wide range of digital broadcast equipment to be remotely monitored.

Digital equipment has brought new levels of performance and operational benefits at every stage of the program making process - acquisition, production, post and play out. These benefits now include detailed equipment database management, allowing significant improvements to be made in operating efficiency.

ISR provides status reporting, error logging and remote control and remote diagnostics on VTRs, camera systems, routers, servers, switchers and edit controllers. This wealth of information brings levels of centralized system management never before possible.

ISR runs on industry-standard PC platforms and can monitor a single unit or up to 1,000 individual items of equipment, depending on the type of ISR software in use.

The ISR system

• Status monitoring provides continuous displays of

• error and warning status of equipment

• VTR channel condition

• EDH and EDA status of equipment

• system log files status

• Remote diagnostics

• diagnostic checks of remote equipment

• intelligent remote control functions for VTRs

• Database management

• reception and storage of error and warning messages, logged by device serial number

• selective or complete uploading, storage, editing, and downloading of VTR set-up parameters

• management and retrieval of historical data

• logging of VTR channel condition, with time stamp and time code

• management of equipment in discrete groups

• export of data to Microsoft Excel™

• Software options

• BZI-500/03, supports connection of up to eight devices*

• BZI-500/03 plus BZI-501/03 supports connection of up to 64 devices**

• BZI-502 supports connection of up to 1,000 devices and acts as a system supervisor***

• more than one supervisory node can exist on the same system

* May require an additional RS-232C expansion card

** Will require network components and software

*** Requires NT 3.51 server if more than three 500/501 nodes exist on the same system

158

*SGC_0145-0161 02.3.19 5:37 PM Page 159

Technical References

Conceptual ISR Configurations

ENGINEERING MAINTENANCE

APPLICATION FOR BZI-501/03

CONTROLLING UP TO 64

UNITS IN DIFFERENT

TECHNICAL AREAS

ETHERNET REPEATER

EDIT

SUITE 1

TERMINAL

SERVER

RS-232C

1 ~ 16

EDIT

SUITE 2

TERMINAL

SERVER

RS-232C

1 ~ 16

STUDIO 1

TERMINAL

SERVER

RS-232C

1 ~ 16

TRANS-

MISSION

TERMINAL

SERVER

RS-232C

1 ~ 16

BZI-501/03

A CAMERA CONTROL

ENVIRONMENT

RS-232C

CNU-700

RCP-740

CCA-CABLE

MSU-700

CCU-700A/AP

159

*SGC_0145-0161 02.3.19 5:37 PM Page 160

Technical References

Technical References: EDH

EDH – Error Detection and Handling

The need for EDH

Video installations never get any simpler. In fact, the growth in viewer expectations of seeing what they want when they want, has resulted in a huge, world wide expansion in systems devoted to the switching and routing of video signals. Continuous quality monitoring of every signal path is, in many cases, impractical. Signals may arrive at a switching center, be routed to a destination, and leave the center without any check being made to ensure that the signal going out is as good as the signal coming in. When these signals are serial digital video, their inherent resistance to distortion will generally mean that they do pass through a system unchanged. However, a digital signal can have deteriorated to the point where a minor equipment fault or a few extra meters of cable can cause a catastrophic failure. EDH has been developed as a way of avoiding this type of situation and is supported by SMPTE RP165 as an on-line quality checking system.

The concept of EDH

The concept of EDH is very simple. The data bits making up the each frame of a serial digital video signal are 'counted' to generate a check sum. This check sum is inserted in the blanking interval of the same video frame. At a later point along the path of the video signal, the check sum for each individual video frame is recalculated and compared to the check sum carried in its blanking period. If the sums do not agree, then data corruption has occurred somewhere between these two points.

In a practical system this basic concept is expanded and refined to become a valuable tool in an operational environment. The ultimate use of EDH in a system is that every item of video equipment has the ability to carry out this checking process so that the precise point of data corruption can be located.

EDH in practice

Once the check sums have been attached to each frame of a video signal, identifying the point where data errors have been introduced is carried out by a three-part, frame-by-frame, checking process:

• The check sum for the frame is recalculated.

• This check sum is compared to the check sum in the blanking interval. If they do not agree, a warning flag is generated to warn of data corruption earlier in the signal path.

• The recalculated check sum is inserted into the blanking period, replacing the previous one so that the checking process can continue.

This recalculating and comparing process can happen as often as required, the more frequently it is done the greater the accuracy in determining where data corruption has occurred in the signal path.

160

*SGC_0145-0161 02.3.19 5:37 PM Page 161

Technical References

Error reporting

Errors are reported in five different ways:

• Error detected here, edh

• Error detected already, eda

• Unknown error status, ues

• Internal error detected here, idh

• Internal error detected already, ida

The last two reports, idh and ida, are used when a piece of equipment has the capability to check for data corruption between its input and output.

EDH actually checks and reports each video frame in three ways, calculating separate check sums for the complete frame, the active picture area and the ancillary area. (The ancillary area is the area of the frame blanking interval that can contain digital audio signals and other multiplexed information.) A reason for this division of areas is so that errors in the active picture area can be given a higher fault priority, simply because they have direct effect on the program audience.

Sony is supporting EDH, and an increasing number of relevant products(down to board level in some cases) now have the ability to provide a visual eda report with an LED indicator.

EDH and ISR

In an overall system, EDH-equipped devices can report to a computer network, with status indication displayed by a PC. EDH is complementary to the well-established Sony ISR

(Interactive Status Reporting) system, which can be used to report EDH status checks. In this way, detailed information on the performance of individual pieces of equipment is combined with information on the performance of their interconnections.

161

©2002 Sony Corporation. All rights reserved.

Reproduction in whole or in part without written permission of Sny is prohibited.

Features and specifications subject to change without notice.

All non-metric weights and measures are approximate.

Sony is a registered trademark of Sony Corporation.

Betacam and Betacam SP are trademarks of Sony Corporation.

Belden is a registered trademark of Cooper Industries.

All other trademarks are the properties of their respective owners.

Distributed by

MK7807V1OHB02MAR Printed in Japan

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
