STM32F102x4 STM32F102x6

STM32F102x4 STM32F102x6
STM32F102x4
STM32F102x6
Low-density USB access line, ARM-based 32-bit MCU with
16/32 KB Flash, USB FS, 5 timers, ADC & 5 com. interfaces
Datasheet - production data
Features
• Core: ARM 32-bit Cortex™-M3 CPU
– 48 MHz maximum frequency,
1.25 DMIPS/MHz (Dhrystone 2.1)
performance at 0 WS memory access
– Single-cycle multiplication and hardware
division
• Memories
– 16 or 32 Kbytes of Flash memory
– 4 or 6 Kbytes of SRAM
• Clock, reset and supply management
– 2.0 to 3.6 V application supply and I/Os
– POR, PDR and programmable voltage
detector (PVD)
– 4-to-16 MHz crystal oscillator
– Internal 8 MHz factory-trimmed RC
– Internal 40 kHz RC
– PLL for CPU clock
– 32 kHz oscillator for RTC with calibration
• Low power
– Sleep, Stop and Standby modes
– VBAT supply for RTC and backup registers
• Debug mode
– Serial wire debug (SWD) and JTAG
interfaces
LQFP64
10 × 10 mm
• Up to 5 timers
– Two 16-bit timers, each with up to 4
IC/OC/PWM or pulse counter
– 2 watchdog timers (Independent and
Window)
– SysTick timer: 24-bit downcounter
• Up to 5 communication interfaces
– One I2C interface (SMBus/PMBus)
– Two USARTs (ISO 7816 interface, LIN,
IrDA capability, modem control)
– One SPI (12 Mbit/s)
– One USB 2.0 full speed interface
• CRC calculation unit, 96-bit unique ID
• ECOPACK® packages
Table 1. Device summary
Reference
• DMA
– 7-channel DMA controller
– Peripherals supported: timers, ADC, SPIs,
I2Cs and USARTs
LQFP48
7 × 7 mm
Part number
STM32F102x4
STM32F102C4, STM32F102R4
STM32F102x6
STM32F102C6, STM32F102R6
• 1 × 12-bit, 1.2 µs A/D converter (up to 16
channels)
– Conversion range: 0 to 3.6 V
– Temperature sensor
• Up to 51 fast I/O ports
– 37/51 I/Os all mappable on 16 external
interrupt vectors and almost all 5 V-tolerant
August 2013
This is information on a product in full production.
DocID15057 Rev 4
1/77
www.st.com
