SERVICE MANUAL

COLOR TELEVISION

13A21C

SERVICING NOTICES ON CHECKING

1. KEEP THE NOTICES

As for the places which need special attentions, they are indicated with the labels or seals on the cabinet, chassis and parts. Make sure to keep the indications and notices in the operation manual.

2. AVOID AN ELECTRIC SHOCK

There is a high voltage part inside. Avoid an electric shock while the electric current is flowing.

3. USE THE DESIGNATED PARTS

The parts in this equipment have the specific characters of incombustibility and withstand voltage for safety. Therefore, the part which is replaced should be used the part which has the same character.

Especially as to the important parts for safety which is indicated in the circuit diagram or the table of parts as a mark, the designated parts must be used.

4. PUT PARTS AND WIRES IN THE

ORIGINAL POSITION AFTER

ASSEMBLING OR WIRING

There are parts which use the insulation material such as a tube or tape for safety, or which are assembled in the condition that these do not contact with the printed board.

The inside wiring is designed not to get closer to the pyrogenic parts and high voltage parts.

Therefore, put these parts in the original positions.

5. TAKE CARE TO DEAL WITH THE

CATHODE-RAY TUBE

In the condition that an explosion-proof cathoderay tube is set in this equipment, safety is secured against implosion. However, when removing it or serving from backward, it is dangerous to give a shock. Take enough care to deal with it.

6. AVOID AN X-RAY

Safety is secured against an X-ray by considering about the cathode-ray tube and the high voltage peripheral circuit, etc.

Therefore, when repairing the high voltage peripheral circuit, use the designated parts and make sure not modify the circuit.

Repairing except indicates causes rising of high voltage, and it emits an X-ray from the cathoderay tube.

7. PERFORM A SAFETY CHECK AFTER

SERVICING

Confirm that the screws, parts and wiring which were removed in order to service are put in the original positions, or whether there are the portions which are deteriorated around the serviced places serviced or not. Check the insulation between the antenna terminal or external metal and the AC cord plug blades.

And be sure the safety of that.

(INSULATION CHECK PROCEDURE)

Unplug the plug from the AC outlet.

Remove the antenna terminal on TV and turn

on the TV.

Insulation resistance between the cord plug terminals and the eternal exposure metal

[Note 2] should be more than 1M ohm by using the 500V insulation resistance meter

[Note 1].

If the insulation resistance is less than 1M ohm, the inspection repair should be required.

[Note 1]

If you have not the 500V insulation resistance meter, use a Tester.

[Note 2]

External exposure metal: Antenna terminal

Earphone Jack

HOW TO ORDER PARTS

Please include the following informations when you order parts. (Particularly the VERSION LETTER.)

1. MODEL NUMBER and VERSION LETTER

The MODEL NUMBER can be found on the back of each product and the VERSION LETTER can be

found at the end of the SERIAL NUMBER.

2. PART NO. and DESCRIPTION

You can find it in your SERVICE MANUAL.

IMPORTANT

Inferior silicon grease can damage IC's and transistors.

When replacing an IC's or transistors, use only specified silicon grease (YG6260M).

Remove all old silicon before applying new silicon.

GENERAL SPECIFICATIONS

G-1 TV

System

CRT CRT Size / Visual Size

CRT Type

Deflection

Magnetic Field BV/BH

Color System

Speaker

G-2 Tuning

System

Sound Output

NTSC3.58+4.43 /PAL60Hz

Broadcasting System

Tuner and

Receive CH

Position

Size

Impedance

MAX

10%(Typical)

System

Destination

Tuning System

Input Impedance

G-3

G-4

G-5

Power

Regulation

Temperature

CH Coverage

Intermediate Picture(FP)

Frequency Sound(FS)

FP-FS

Preset CH

Stereo/Dual TV Sound

Tuner Sound Muting

Power Source

Power Consumption

DC at AC

Protector

Stand by (at AC)

Per Year

Power Fuse

Safety

Radiation

X-Radiation

Operation

Storage

G-6 Operating Humidity

G-7 On Screen

Display

Menu Type


Contrast

Brightness

Color

Tint

Sharpness

Audio

Bass

Treble

Balance

BBE On/Off

Stable Sound On/Off

CH Set Up

TV/CABLE(CATV)

Auto CH Memory

Add/ Delete

Language

V-chip

CH Label

Favorite CH

Color Stream DVD/DTV

Control Level

Volume

Brightness

Contrast

Color

Tint (NTSC Only)

Sharpness

Tuning

Bass

Treble

Balance

Back Light

Stereo,Audio Output,SAP

Video

Color Stream

Channel(TV/Cable)

CH Label

Sleep Timer

Sound Mute

V-chip Rating

13 inch / 335.4mmV

Normal

90 degree

+0.45G/0.18G

NTSC

1Speaker

Bottom

3 Inch

1.0

0.8

ohm

US System M

1Tuner

Ohers

F-Synth

VHF/UHF 75 ohm

2 - 69, 4A, A-5 - A-1,

A - I, J - W, W+1 - W+84

45.75MHz

41.25MHz

4.50MHz

Yes

120V AC 60Hz

Yes

54 W at AC 120 V 60 Hz

5 W at AC 120 V 60 Hz

-- kWh/Year

Yes

CSA

DOC

HWC

+5oC ~ +40oC

-20oC ~ +60oC

Less then 80% RH

Yes

Character

Yes

G-8 OSD Language

G-9 Clock and

Timer

G-10 Remote

Control

GENERAL SPECIFICATIONS

Sleep Timer

On/Off Timer

OSD Language Setting

Max Time

Step

Program(On Tim / Off Tim)

Wake Up Timer

Timer Back-up (at Power Off Mode) more than

Unit

Glow in Dark Remocon

Format

Custom Code

Power Source Voltage(D.C)

UM size x pcs

Total Keys

Keys

Power

Multi Brand Keys

CH Up

CH Down

Volume Up

Volume Down

TV/Caption/Text

CH1/CH2

TV/Video(TV/AV)

CH RTN/CH ENT(Quick View)

Sleep

RE Call(Call)

Reset

Enter

Mute

Exit

MTS(Audio Select)

Set +

Set -

CH Up(VCR)

CH Down(VCR)

Pause/Still

TV/VCR(VCR)

Code

Rew

Rec

Play

Stop

VCR

Cable

100

English French Spanish

English

120 Min

10 Min

-- Min Sec

RC-EH

Toshiba

40-BF h

UM-4 x 2 pcs

Yes

27 Keys

Yes

G-11 Features

G-12 Accessories

GENERAL SPECIFICATIONS

Auto Degauss

Auto Shut Off

Canal+

CATV

Anti-theft

Rental

Memory(Last CH)

Memory(Last Volume)

V-Chip

BBE

Auto Search

CH Allocation

SAP

Channel Lock

Just Clock Function

Game Position

CH Label

VM Circuit

Full OSD

Premiere

Comb Filter

Type

Auto CH Memory

Hotel Lock

Closed Caption

Stable Sound

FBT Leak Test Protect

Favorite CH

Owner's Manual Language

W/ Warranty

Remote Control Unit

Rod Antenna

Poles

Terminal

Loop Antenna

Terminal

U/V Mixer

DC Car Cord (Center+)

Guarantee Card

Warning Sheet

Circuit Diagram

Antenna Change Plug

Service Station List

Important Safety Instruction

Dew/AHC Caution Sheet

AC Plug Adapter

Quick Set-up Sheet

Battery

UM size x pcs

OEM Brand

AC Cord

AV Cord (2Pin-1Pin)

Registration Card (NDL Card)

ESP Card

PTB Sheet

300 ohm to 75 ohm Antenna Adapter

Envelop

Yes

UM4 x 2

Yes

USA,ORION Type

Lines

Yes

English/French

Yes

G-13 Interface

G-14 Set Size

G-15 Weight

G-16 Carton

G-17 Cabinet Material

Switch

Indicator

GENERAL SPECIFICATIONS

Terminals

Front

Rear

Front

Rear

Master Carton

Content

Material

Dimensions W x D x H(mm)

Description of Origin

Gift Box

Power

System Select

Main Power SW

Sub Power

Channel Up/Reset

Channel Down/Enter

Volume Up/Set Up

Volume Down/Set Down

MENU=Volume Up+Volume Down

AC/DC

TV/CATV Selector

Degauss

Main Power SW

Power

Stand-by

On Timer

Video Input

Audio Input

Other Terminal

Video Input(Rear1)

Video Input(Rear2)

Audio Input(Rear1)

Audio Input(Rear2)

Video Output

Audio Output

Euro Scart

Color Stream

Diversity

Ext Speaker

DC Jack 12V(Center +)

VHF/UHF Antenna Input

AC Outlet

Approx. W x D x H (mm)

Net (Approx.)

Gross (Approx.)

Material

Dimensions W x D x H(mm)

Design

Description of Origin

Drop Test

Height (cm)

Container Stuffing

Cabinet Front

Cabinet Rear

Yes

RCA

RCA x 1

Ear Phone

F Type

362 x 360 x 320.5

9.5 kg

11.0kg

( 20.9 lbs)

( 24.4lbs)

----

Sets

/--

-- x -- x --

Yes

Double/Brown

440 x 408 x 380

As per Buyer's

Yes

Natural

Dropping

At 1

Corner / 3

Edges / 6

Surfaces

866

Sets/40' container

PS 94V0 DECABROM

DISASSEMBLY INSTRUCTIONS

1. REMOVAL OF ANODE CAP

Read the following NOTED items before starting work.

After turning the power off there might still be a potential voltage that is very dangerous. When removing the

Anode Cap, make sure to discharge the Anode Cap's potential voltage.

Do not use pliers to loosen or tighten the Anode Cap terminal, this may cause the spring to be damaged.

REMOVAL

1. Follow the steps as follows to discharge the Anode Cap.

(Refer to Fig. 1-1.)

Connect one end of an Alligator Clip to the metal part of a flat-blade screwdriver and the other end to ground.

While holding the plastic part of the insulated Screwdriver, touch the support of the Anode with the tip of the

Screwdriver.

A cracking noise will be heard as the voltage is discharged.

3. After one side is removed, pull in the opposite direction to remove the other.

NOTE

Take care not to damage the Rubber Cap.

INSTALLATION

1. Clean the spot where the cap was located with a small amount of alcohol. (Refer to Fig. 1-3.)

Location of Anode Cap

GND on the CRT

Fig. 1-3

NOTE

Confirm that there is no dirt, dust, etc. at the spot where the cap was located.

Arrange the wire of the Anode Cap and make sure the wire is not twisted.

Turn over the Rubber Cap. (Refer to Fig. 1-4.)

Screwdriver

Support

CRT

Alligator Clip

GND on the CRT

Fig. 1-1

Flip up the sides of the Rubber Cap in the direction of the arrow and remove one side of the support.

(Refer to Fig. 1-2.)

Rubber Cap

Fig. 1-4

4. Insert one end of the Anode Support into the anode button, then the other as shown in Fig. 1-5.

CRT

Support

Fig. 1-2

CRT

Support

Fig. 1-5

Confirm that the Support is securely connected.

Put on the Rubber Cap without moving any parts.

DISASSEMBLY INSTRUCTIONS

2. REMOVAL AND INSTALLATION OF

FLAT PACKAGE IC

REMOVAL

Put the Masking Tape (cotton tape) around the Flat

Package IC to protect other parts from any damage.

(Refer to Fig. 2-1.)

NOTE

Masking is carried out on all the parts located within

10 mm distance from IC leads.

When IC starts moving back and forth easily after desoldering completely, pickup the corner of the IC using a tweezers and remove the IC by moving with the IC desoldering machine. (Refer to Fig. 2-3.)

NOTE

Some ICs on the PCB are affixed with glue, so be careful not to break or damage the foil of each IC leads or solder lands under the IC when removing it.

Blower type IC desoldering machine

Masking Tape

(Cotton Tape)

Tweezers

Fig. 2-1

Heat the IC leads using a blower type IC desoldering machine. (Refer to Fig. 2-2.)

NOTE

Do not add the rotating and the back and forth directions force on the IC, until IC can move back and forth easily after desoldering the IC leads completely.

Blower type IC desoldering machine

Fig. 2-3

Peel off the Masking Tape.

Absorb the solder left on the pattern using the Braided

Shield Wire. (Refer to Fig. 2-4.)

NOTE

Do not move the Braided Shield Wire in the vertical direction towards the IC pattern.

Braided Shield Wire

Soldering Iron

IC pattern

Fig. 2-4

Fig. 2-2

INSTALLATION

DISASSEMBLY INSTRUCTIONS

When bridge-soldering between terminals and/or the soldering amount are not enough, resolder using a Thintip Soldering Iron. (Refer to Fig. 2-8.)

Take care of the polarity of new IC and then install the new IC fitting on the printed circuit pattern. Then solder each lead on the diagonal positions of IC temporarily.

(Refer to Fig. 2-5.)

Thin-tip Soldering Iron

Soldering Iron

Solder temporarily

Fig. 2-5

Supply the solder from the upper position of IC leads sliding to the lower position of the IC leads.

(Refer to Fig. 2-6.)

Fig. 2-8

Finally, confirm the soldering status on four sides of the

IC using a magnifying glass.

Confirm that no abnormality is found on the soldering position and installation position of the parts around the

IC. If some abnormality is found, correct by resoldering.

NOTE

When the IC leads are bent during soldering and/or repairing, do not repair the bending of leads. If the bending of leads are repaired, the pattern may be damaged. So, be always sure to replace the IC in this case.

Solder Soldering Iron

Supply soldering from upper position to lower position

Fig. 2-6

Absorb the solder left on the lead using the Braided

Shield Wire. (Refer to Fig. 2-7.)

NOTE

Do not absorb the solder to excess.

Soldering Iron

Braided Shield Wire

Fig. 2-7

SERVICE MODE LIST

This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily.

To enter the Service Mode, press both set key and remote control key for more than 1 second.

Set Key

VOL. (-) MIN

Remocon Key

Operations

Releasing of V-CHIP PASSWORD.

Initialization of the factory.

NOTE: Do not use this for the normal servicing.

POWER ON total hours is displayed on the screen.

Refer to the "CONFIRMATION OF USING HOURS".

VOL. (-) MIN 8

Can be checked of the INITIAL DATA of MEMORY IC.

Refer to the "NOTE FOR THE REPLACING OF MEMORY IC".

Writing of EEPROM initial data.

NOTE: Do not use this for the normal servicing.

VOL. (-) MIN 9

Display of the Adjustment MENU on the screen.

Refer to the "ELECTRICAL ADJUSTMENT" (On-Screen Display Adjustment).

CONFIRMATION OF USING HOURS

POWER ON total hours can be checked on the screen. Total hours are displayed in 16 system of notation.

ADDRESS DATA

Set the VOLUME to minimum.

Press both VOL. DOWN button on the set and Channel button (6) on the remote control for more than 1 second.

After the confirmation of using hours, turn off the power.

INIT 00 83

CRT ON

FIG. 1

0010

Initial setting content of MEMORY IC.

POWER ON total hours.

= (16 x 16 x 16 x thousands digit value)

+ (16 x 16 x hundreds digit value)

+ (16 x tens digit value)

+ (ones digit value)

NOTE FOR THE REPLACING OF MEMORY IC

If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1.

INI +0 +1

+2 +3 +4 +5 +6 +7 +8 +9 +A

09 A2

B3 24 09

24 FF

Table 1

Enter DATA SET mode by setting VOLUME to minimum.

Press both VOL. DOWN button on the set and Channel button (6) on the remote control for more than 1 second.

ADDRESS and DATA should appear as FIG 1.

ADDRESS is now selected and should "blink". Using the SET + or - keys on the remote, step through the ADDRESS until required ADDRESS to be changed is reached.

Press ENTER to select DATA. When DATA is selected, it will "blink".

Again, step through the DATA using SET + or - until required DATA value has been selected.

Pressing ENTER will take you back to ADDRESS for further selection if necessary.

Repeat steps 3 to 6 until all data has been checked.

When satisfied correct DATA has been entered, turn POWER off (return to STANDBY MODE) to finish DATA input.

The unit will now have the correct DATA for the new MEMORY IC.

ELECTRICAL ADJUSTMENTS

1. BEFORE MAKING ELECTRICAL

ADJUSTMENTS

Read and perform these adjustments when repairing the circuits or replacing electrical parts or PCB assemblies.

CAUTION

• Use an isolation transformer when performing any service on this chassis.

• Before removing the anode cap, discharge electricity because it contains high voltage.

• When removing a PCB or related component, after unfastening or changing a wire, be sure to put the wire back in its original position.

Inferior silicon grease can damage IC's and transistors.

• When replacing IC's and transistors, use only specified silicon grease.

Remove all old silicon before applying new silicon.

Prepare the following measurement tools for electrical adjustments.

1. Oscilloscope

2. Digital Voltmeter

On-Screen Display Adjustment

In the condition of NO indication on the screen.

Press the VOL. DOWN button on the set and the

Channel button (9) on the remote control for more than

1 second to appear the adjustment mode on the screen as shown in Fig. 1-1.

00 OSD 15

Fig. 1-1

Use the Channel UP/DOWN button or Channel button

(0-9) on the remote control to select the options shown in Fig. 1-2.

Press the MENU button on the remote control to end the adjustments.

NO.

FUNCTION

OSD H

CUT OFF

RF AGC DELAY

VIF VCO

H VCO

H PHASE

V SIZE

V SHIFT

R DRIVE

B DRIVE

R BIAS

G BIAS

B BIAS

NO.

FUNCTION

BRIGHTNESS

CONTRAST

COLOR

TINT

SHARPNESS

FM LEVEL

LEVEL

SEPARATION 1

SEPARATION 2

TEST MONO

TEST STEREO

X-RAY TEST

Fig. 1-2

2. BASIC ADJUSTMENTS

2-1: RF AGC DELAY

Place the set with Aging Test for more than 15 minutes.

Receive a 63dB monoscope pattern.

Connect the digital voltmeter to R606.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (02) on the remote control to select "RF AGC DELAY".

Press the VOL. UP/DOWN button on the remote control until the digital voltmeter is 2.5

0.05V.

2-2: CUT OFF

Adjust the unit to the following settings.

R.DRIVE=10, B.DRIVE=10, R.BIAS=64, G.BIAS=64,

B.BIAS=64, BRIGHTNESS=100, CONTRAST=64.

Place the set with Aging Test for more than 15 minutes.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (01) on the remote control to select "CUT OFF".

Adjust the Screen Volume until a dim raster is obtained.

2-3: FOCUS

Receive the monoscope pattern.

Turn the Focus Volume fully counterclockwise once.

Adjust the Focus Volume until picture is distinct.

2-4: WHITE BALANCE

NOTE: Adjust after performing CUT OFF adjustment.

Place the set with Aging Test for more than 10 minutes.

Receive the white 100% signal from the Pattern

Generator.

Using the adjustment control, set the brightness and contrast to normal position.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (10) on the remote control to select "R.BIAS".

Using the VOL. UP/DOWN button on the remote control, adjust the R.BIAS.

Press the CH. UP/DOWN button on the remote control to select the "R.DRIVE", "B.DRIVE", "G.BIAS" or "B.BIAS".

Using the VOL. UP/DOWN button on the remote control, adjust the R.DRIVE, B.DRIVE, G.BIAS or B.BIAS.

Perform the above adjustments 6 and 7 until the white color is looked like a white.

2-5: SUB TINT/SUB COLOR

Receive the color bar pattern. (RF Input)

Connect the oscilloscope to TP023.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (16) on the remote control to select "TINT".

Press the VOL. UP/DOWN button on the remote control until the section "A" becomes a straight line.

(Refer to Fig. 2-1)

Connect the oscilloscope to TP022.

Press the CH DOWN button once to set to "COLOR" mode.

Press the VOL. UP/DOWN button on the remote control until the red color level is adjusted to 110% of the white level. (Refer to Fig. 2-2)

Receive the color bar pattern. (Audio Video Input)

Press the TV/VIDEO button on the remote control to set to the AV mode. Then perform the above adjustments 2~7.

ELECTRICAL ADJUSTMENTS

"A"

2-9: OSD HORIZONTAL

Activate the adjustment mode display of Fig. 1-1.

Press the VOL. UP/DOWN button on the remote control until the difference of A and B becomes minimum. (Refer to Fig. 2-3)

Fig. 2-1

110%

100%

Fig. 2-2

2-6: HORIZONTAL PHASE

Receive the center cross signal from the Pattern

Generator.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (05) on the remote control to select "H PHASE".

Press the VOL. UP/DOWN button on the remote control until the SHIFT quantity of the OVER SCAN on right and left becomes minimum.

2-7: VERTICAL SIZE

NOTE: Adjust after performing adjustments in section 2-6

Receive the crosshatch signal from the Pattern

Generator.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (06) on the remote control to select "V SIZE".

Press the VOL. UP/DOWN button on the remote control until the rectangle on the center of the screen becomes square.

Receive a broadcast and check if the picture is normal.

2-8: VERTICAL SHIFT

NOTE: Adjust after performing adjustments in section 2-7

Receive the crosshatch signal from the Pattern

Generator.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (07) on the remote control to select "V SHIFT".

Press the VOL. UP/DOWN button on the remote control until the horizontal line becomes fit to the notch of the shadow mask.

00 OSD 15

A B

Fig. 2-3

2-10: VIF VCO

Place the set with Aging Test for more than 10 minutes.

Receive an 80dB monoscope pattern.

Connect the digital voltmeter between the pin 5 of

CP601 and the GND.

Activate the adjustment mode display of Fig. 1-1 and press the channel button (03) on the remote control to select "VIF VCO".

Press the VOL. UP/DOWN button on the remote control until the digital voltmeter is 2.5V.

2-11: SUB CONTRAST NORMAL

Activate the adjustment mode display of Fig. 1-1 press the channel button (14) on the remote control to select "CONTRAST".

Press the VOL. UP/DOWN button on the remote control until the contrast step No. becomes "110".

Press the TV/VIDEO button on the remote control to set to the AV mode. Then perform the above adjustments 2~3.

2-12: BRIGHTNESS

Activate the adjustment mode display of Fig. 1-1 and press the channel button (13) on the remote control to select "BRIGHTNESS".

Press the VOL. UP/DOWN button on the remote control until the brightness step No. becomes "96".

Press the TV/VIDEO button on the remote control to set to the AV mode. Then perform the above adjustments

1~2.

Press the TV/VIDEO button on the remote control to set to the CS mode. Then perform the above adjustments

1~2.

ELECTRICAL ADJUSTMENTS

3. PURITY AND CONVERGENCE

ADJUSTMENTS

NOTE

Turn the unit on and let it warm up for at least 30 minutes before performing the following adjustments.

Place the CRT surface facing east or west to reduce the terrestrial magnetism.

Turn ON the unit and demagnetize with a Degauss Coil.

3-1: STATIC CONVERGENCE (ROUGH ADJUSTMENT)

Tighten the screw for the magnet. Refer to the adjusted

CRT for the position. (Refer to Fig. 3-1)

If the deflection yoke and magnet are in one body, untighten the screw for the body.

Receive the green raster pattern from the color bar generator.

Slide the deflection yoke until it touches the funnel side of the CRT.

Adjust center of screen to green, with red and blue on the sides, using the pair of purity magnets.

Switch the color bar generator from the green raster pattern to the crosshatch pattern.

Combine red and blue of the 3 color crosshatch pattern on the center of the screen by adjusting the pair of

4 pole magnets.

Combine red/blue (magenta) and green by adjusting the pair of 6 pole magnets.

Adjust the crosshatch pattern to change to white by repeating steps 6 and 7.

3-2: PURITY

NOTE

Adjust after performing adjustments in section 3-1.

Receive the green raster pattern from color bar generator.

Adjust the pair of purity magnets to center the color on the screen.

Adjust the pair of purity magnets so the color at the ends are equally wide.

Move the deflection yoke backward (to neck side) slowly, and stop it at the position when the whole screen is green.

Confirm red and blue colors.

Adjust the slant of the deflection yoke while watching the screen, then tighten the fixing screw.

DEFLECTION YOKE

DEFLECTION YOKE SCREW

MAGNET SCREW

3-3: STATIC CONVERGENCE

NOTE

Adjust after performing adjustments in section 3-2.

Receive the crosshatch pattern from the color bar generator.

Combine red and blue of the 3 color crosshatch pattern on the center of the screen by adjusting the pair of

4 pole magnets.

Combine red/blue (magenta) and green by adjusting the pair of 6 pole magnets.

3-4: DYNAMIC CONVERGENCE

NOTE

Adjust after performing adjustments in section 3-3.

Adjust the differences around the screen by moving the deflection yoke upward/downward and right/left.

(Refer to Fig. 3-2-a)

Insert three wedges between the deflection yoke and

CRT funnel to fix the deflection yoke.

(Refer to Fig. 3-2-b)

R G B

UPWARD/DOWNWARD SLANT RIGHT/LEFT SLANT

Fig. 3-2-a

WEDGE

WEDGE POSITION

Fig. 3-2-b

WEDGE

R G B

Fig. 3-1

PURITY MAGNETS

6 POLE MAGNETS

4 POLE MAGNETS

MAJOR COMPONENTS LOCATION GUIDE

TU001

R606

CP601

MAIN PCB

FB401

FOCUS VOLUME

SCREEN VOLUME

J801

TP023

TP022

CRT PCB

BLOCK DIAGRAM

CH UP

VOL UP

CH DOWN

VOL DOWN

POWER

OS101

AT+5V

X101

EFOEC8004T4

MICON IC

IC101 OEC7063A

5 P02/AUDIO MUTE

26 AD6/KEY2

CVIN 17

AD5/KEY1

RED R 42

GREEN G 41

BLUE B 40

OUT1/BLANK BL

INT1/REMOCON

P50/H. SYNC

P51/V. SYNC

19 XIN

SCL1

SDA1

RESET

20 XOUT

29 X-RAY

TU001

X602

3.579545MHz

CF601

SAW FILTER

SDA SCL

MEMORY IC

IC199

S-24C02BDP-1A

Q503

PROTECT

DRIVE

Q504

FEED BACK

T502

UNREG + 12V

Q507

FEED BACK

SW.

Q502

BUFFER

Q501

D501~D504

RECTIFIER

DEGAUSS COIL

L503

L501

F501

J703

J702

1 2

CHROMA IC

IC601 M61206FP

X' TAL

RF AGC OUT

VIF IN (1)

VIF IN (2)

40 Y SW OUT

30 R IN

G IN

20 B IN

27 FAST BLK

12 INV FBP OUT

29 V PULSE OUT

5 SCL

SDA

MCU RESET

52 EXT AUDIO IN

EXT C IN

V-OUT IC

IC401 AN5522

7 5

PUMP UP

AMP

VCC

6 2

AUDIO OUT

POWER ON

CONT

Q607

8.7V REG OUT

R OUT

G OUT

B OUT 16

5.7V REG OUT

Q603

REG

FBP IN

START UP VCC

H OUT

5V REG

VREG VCC 55

V OUT

IC351 AN7511

2 6

SOUND AMP

Q606

REG

Q801

RED OUT

Q802

GREEN OUT

UNREG + 12V

Q803

BLUE OUT

Q402

H. DRIVE

Q401

H. OUTPUT

Q604, Q605

REG

Heater

FB401

CRT

SP351

AC IN

PRINTED CIRCUIT BOARDS

MAIN/CRT (INSERTED PARTS)

SOLDER SIDE

CD501_2

_A_V

L501_1

R500_1

D509

CP502

R504

C526_1

TP004

D109

FH502

F501

S501A

FH501

4A125VOR250V

OS101

W804

C514_1

D504

C502

R542

C503

CP801

W068

S101Y

Q803

C801

Q802

R429

W024

C418

W070

R413

S101X

CP802A

R409

C422

W023

R416

R423

W044

R418_1

W028

W027

W029

W019

W111

D411

W032

W106

W031

TU001

R404

FB401

R414

R417_1

W069

CP401

W026

W074

C511

C520

Q502

C501

D512

D508

TP003

Q801

TP023

R802

TP022

TP024

R805_1

C442_1

Q504

D528

Q401

HS402

R405

C440

R410

R606

C443

W107

R446

Q402

C446_1

D406

W076

R002

D505

T502

D513

D518

Q503

R523

R525

R507

R514

W098

B504

R518

W045

Q507

Q605

Q604

C517

C521_2

C622

R645

W101

W047

W052

W007

W008

Q606

C605

CF603

L607

Q607

Q603

R517_1

C630

X602

C609

C604 C632

C624

C606

L601

CF601

C637

W050

W820

W819

D611

J801

W099

C607

C354

IC351

IC199

W822

W049

W058

C134

W018

R110

R807_1

C352

C356

W835

R703

W110

X101_1

W001

R115

W104

PRINTED CIRCUIT BOARDS

MAIN/CRT (CHIP MOUNTED PARTS)

SOLDER SIDE

R134

C120

C138

C140

IC101

R127

C116

R132

R113

R702

R007

R122

R626

R360

C353

R605

IC601

R634

C650

R512

R813

R420

TM101

RC-EH010

ACCESSORY

UM-4

BT001

R03(AB)E_20_T

UM-4

BT002

R03(AB)E_20_T

C D E

MICON/TUNER SCHEMATIC DIAGRAM

(MAIN PCB)

TU001 TECC1040PG32D

C003

50V 4.7

F G

OS101

PIC-28143SY-2

R114

10K

R115

47K

C130

0.01

NOTE:

THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST

WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

POWER LED

D109

SLR-342VCT32

R132

270

R116

47K

R111

10K

C140

100P SL

R117

47K

X101_1

EFOEC8004T4

W822

C122

R130

50V 1 KA

C121

200P CH

C120

0.001 Y

C124 R134

0.1

470

R131

100

4.0

0.8

4.7

4.8

4.0

4.8

4.9

1.9

0.2

2.6

2.3

1.6

IC101

MICON IC

OEC7063A

P50/H.SYNC

RED R

P51/V.SYNC

GREEN G

P00/EXT MUTE BLUE B

P01/I2C_OFF

OUT1/BLANK BL

AD4/AFT

P02/AUDIO MUTE

P03/(Surround)

P20/AV2

P21/AV1

P04

P22/POWER

P05/(Center_SP) P10/DEGAUSS_H

4.9

INT2/P.FAIL

SCL1

INT1/REMOCON SCL2

4.8

3.2

P23/SYNC

SDA1

P24

P25/ON_TIMER

SDA2

AD1/X_RAY_TEST

4.8

3.2

AVCC

X-RAY

HLF

V.HOLD

AD5/KEY1

4.9

CVIN

AD6/KEY2

4.8

CNVSS

RESET

2.5

Xin OSC1

2.5

Xout OSC2

2.5

VSS VCC

4.9

C117 220P B

R006

R007 270

270

R105

4.7K

C116

220P B

R106

4.7K

R107

10K W809

W813

W815

C114

12P CH

C113

12P CH

R112

2.2K

R113

2.2K

C118

6.3V

470 YK

R123

4.7K

R122

4.7K

R121

4.7K

R120

4.7K

4.8

4.9

R119

W819

W820

CAUTION: SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES

DESCRIBED IN PARTS LIST ONLY

ARE

ATTENTION: LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE

N’UTILISER QUE CELLS DECRITES

DANS LA NOMENCLATURE DES PIECES

E F

R002

18K 1/2W

W837

R001

18K 1/2W

C129

C125

50V 0.1

C137

50V 0.1

R101

560

R126

2.7K

R128

560

DEFLECTION SIGNAL

TUNER VIDEO SIGNAL

R.SIGNAL

G.SIGNAL

B.SIGNAL

FROM/TO CHROMA

AGC

GND

TUNER+5V

I2C_OFF

OSD_R

OSD_G

OSD_B

OSD_BLK

FROM TV POWER

X-RAY

TO SOUND/AV

AUDIO_MUTE

POWER

FROM DEFLECTION/CRT

X-RAY

FROM/TO CHROMA

POWER

SCL

SDA

AFT

RESET

AT+5V

Y_VIDEO

SYNC

PCB010

TMA511

FROM TV POWER

UNREG+12V

A B C D E

CHROMA SCHEMATIC DIAGRAM

(MAIN PCB)

F G H

FROM/TO SOUND/AV

AUDIO_OUT

AUDIO_IN

GND

FROM/TO MICON/TUNER

Y_VIDEO

AT+5V

SYNC

TUNER+5V

RESET

AFT

AGC

W827

REG

Q604

KTC3203_Y

REG

Q605

KTC3203_Y

7.2

4.9

7.2

5.5

R639

100

REG

Q606

KTC3203_Y

7.9

8.5

11.3

REG

8.8

Q603

KTC3203_Y

4.9

5.5

CF604

TPSRA4M50C00-A0

CF603

EFCT4R5YS5A

R615

470

3.0

2.2

46 45

7.9

5.7

5.6

2.5

3.2

1.9

8.5

W817

R611 10K

R634

10K

W806

C642

50V 1 KA

R618

C604

50V 1 KA

C655

0.0068 Y

C623 0.0033

10M 1/4W

C632 50V 2.2

R632

220

C621_1 0.01 Y

R606

C602_1 0.01

10K

C626 0.001 Y

C606

50V 0.22

SAW FILTER

CF601

SAFGP45M7VHCZR

IN IN G OUT OUT

1 2 3 4 5

8.7

3.2

2.2

2.3

2.4

2.2

3.0

2.8

4.6

2.9

1.5

2.9

3.2

1.9

AUDIO OUT

AUDIO BYPASS

EXT AUDIO IN

FM DIRECT OUT

VIF VCO F/B

VREG Vcc

VIF APC FILTER

VIF VIDEO OUT

46 SW REG CONT

47 LIMITER IN

48 IF AGC

49 QIF OUT

34 EXT C in

33 8.7V REG OUT

32 X’TAL

3.3

ACL/ABCL

2.6

R IN

V PULSE OUT

4.7

G IN

FAST BLK

SPOT KILLER fsc OUT

7.0

2.8

VIF GND

AFT OUT

QIF IN

64 VIF IN (1)

1 VIF IN (2)

CHROMA IC

IC601

M61206FP

17 V OUT

16 B OUT

4.9

VIDEO CHROMA Vcc

4.9

V RAMP CAP

4.7

V RAMP FEEDBACK

2.8

B IN

STRAT UP Vcc

7.9

RF AGC OUT

RF AGC FILTER

1 2 3

1.5

4.9

7.9

V OUT

4.9

11 12 13

3.4

3.9

4.9

14 15

2.0

3.6

L601

1.2uH

C609

0.1

R641

22K +-1%

W818

R627 100

R630

100

R631 100

1K R617

SWITCHING

Q607

DTC114ESTP

4.9

R638

22K

R646

68K

C638

50V 4.7

R642

22K

D605

11E1-EIC

C613

50V 1 YK

C645

16V 47 YK

R613_1

560 1/2W

C647

50V 1 KA

FROM SOUND/AV

VIDEO_IN

FROM/TO DEFLECTION/CRT

V_OUT

ABCL

V_FEEDBACK

GND

H_OUT

H_SYNC

B.OUT

G.OUT

R.OUT

CLAMP

TEST POINT

CP601 173979-6

B.OUT

INT.MONI

IIC_OFF

SDA

SCL

GND

POWER

OSD_B

OSD_BLK

OSD_G

OSD_R

I2C_OFF

SDA

SCL

NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

NOTE:

THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST

WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

CAUTION: SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES

DESCRIBED IN PARTS LIST ONLY

ARE

D E

ATTENTION: LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE

N’UTILISER QUE CELLS DECRITES

DANS LA NOMENCLATURE DES PIECES

CAUTION: DIGITAL TRANSISTOR

R.SIGNAL

G.SIGNAL

B.SIGNAL

PCB010

TMA511

AUDIO SIGNAL

LUMINANCE SIGNAL

DEFLECTION SIGNAL

TUNER VIDEO SIGNAL

A B C D E

TV POWER SCHEMATIC DIAGRAM

(MAIN PCB)

4A 125V

F501

51MS040LCC

FH501

EYF-52BC

51MS040LCC

FH502

EYF-52BC

AC120V_60Hz

CD501_2

0R414903

BLACK

WHITE

4A 125V

CAUTION:

ATTENTION:

FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,

REPLACE ONLY WITH THE SAME TYPE 4A 125V (F501)

FUSE.

POUR UNE PROTECTION CONTINUE LES RISQUES

D’INCEIE N’UTILISER QUE DES FUSIBLE DE MEME

TYPE 4A 125V (F501).

DEGAUSS COIL

L503

8R140030

CP502

TV-50P-02-A1

TH501

TP002

003P-2100

ZPB45BL3R0A

W821

L501_1

1R5A102F20

2 1

5 4

5.6

R501

C502

500V 0.001

TP003

003P-2100

C506

250V 0.01

C508

250V 0.01

KH 144.0

SWITCHING

Q501

2SK2662

4.8

0.1

R505

220 1W

C509

0.047 M

BUFFER

Q502

2SC2120Y

4.8

HS501

763WSA0005

0.1

C511

1.7

144.0

10.3

6.6

10.3

T502 81290264

10.0

132.3

11.3

18 NC

D518

1SS133

R520

150K 1/2W

11.5

0.1

FEED BACK

Q504

LTV-817M-VB

10.5

9.5

FEED BACK

SWITCHING

Q507

KTC3198

5.5

9.5

6.0

D505

SB290S

C516

500V 470P B

B504

BL01RN1-A63

D510

RU2AM-EIC

C517

2KV 0.001

R517_1

1.2

D513

SB290S

R519

1.2K

F G

R523

47K

PROTECT DRIVE

135.0

Q503

2SA1624

135.0

R524

1.5 2W

R514

22K 1/2W

D516

1SS133

NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

A B C

NOTE:

THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST

WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

CAUTION: SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES

DESCRIBED IN PARTS LIST ONLY

ARE

ATTENTION: LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE

N’UTILISER QUE CELLS DECRITES

DANS LA NOMENCLATURE DES PIECES

PCB010

TMA511

TO SOUND/AV

GND

SOUND+B

SOUND_GND

TO DEFLECTION/CRT

UNREG+12V

GND

TO CHROMA

UNREG+12V

TO MICON/TUNER

X-RAY

FROM CHROMA

CLAMP

G.OUT

R.OUT

B.OUT

A B C

R414

100 1/4W

V-OUT IC IC401 AN5522

THERMAL

PROTECTION

3.5

25.0

2.0

PUMP

5 6

12.0

25.0

3.5

R418_1

22K 1/4W

D403

11E1-EIC

R420

3.3K

HS401

763WSA0004

TO MICON/TUNER

X-RAY

FROM/TO CHROMA

GND

V_FEEDBACK

V_OUT

ABCL

H_OUT

H_SYNC

FROM TV POWER

GND

R401

100K 1/4W

+-1%

D402

MTZJ11B

R409

12K +-1%

C439

500V 22P

T401

305Y001

0.3

27.0

H.DRIVE

Q402

2SC1473A-QA

130.0

H.OUTPUT

Q401

2SD2627LS-CBC11

HS402

763WSA0004

R403

22K 1/4W

C406

500V 56P SL

UNREG+12V

R645

47 1/2W

D406

1SS133

R404

100 1/2W

PCB010

TMA511

A B C

130.0

COL

FB401 3213012R

132.5

VIDEO

132.5

B+

48.0

7.0

AFC

HEA

TER

GND

E12

25.0

E25

GND

ABL

4.3

GND

R415

820 1/2W

R429

4.7

GND

CLAMP

G.OUT

R.OUT

B.OUT

HEATER

GND

180V

CP802A

B2013H02-10P

GND

CLAMP

G.OUT

R.OUT

B.OUT

HEATER

GND

180V

CD801_1

CP802B

B2013H02-10P

GND

CLAMP

G.OUT

R.OUT

B.OUT

HEATER

GND

180V

GND

CLAMP

G.OUT

R.OUT

B.OUT

HEATER

GND

180V

CP801

TBS-X01X-A1

F G

100.6

3.2

RED OUT

Q801

2SC1473A

2.7

98.4

3.2

GREEN OUT

Q802

2SC1473A

2.7

95.4

3.2

BLUE OUT

Q803

2SC1473A

2.7

TO DY

CP401

B05B-DVS

V801

A34AGT13X98(L)

5 7 1

TP022

TP024

TP023

R445

180K 1/4W

FOCUS

SCREEN

FOCUS

CP806

005P-2100

SCREEN

6.4

101.6

96.4

99.6

J801

HPS3200-010501

PCB110

TCA366

ATTENTION: LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE

N’UTILISER QUE CELLS DECRITES

DANS LA NOMENCLATURE DES PIECES

ARE CAUTION: SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES

DESCRIBED IN PARTS LIST ONLY

NOTE: THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST

WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

R.SIGNAL

G.SIGNAL

B.SIGNAL

DEFLECTION SIGNAL

TO CHROMA

AUDIO_IN

VIDEO_IN

GND

B C D E

SOUND/AV SCHEMATIC DIAGRAM

(MAIN PCB)

AUDIO 2

VIDEO 2

R703

820 1/4W

J703

AV1-09D-4

(FRONT)

A_IN

V_IN

J702

AV1-09D-3

F G H

6 6

C352

16V 47 YK

R356

12 1/2W

HEADPHONE_JACK

J352

HSJ1403-01-010

CD351

CH122301

SP OUT L+

SOUND GND

SPEAKER

SP351

S08F21

8 OHM

FROM TV POWER

SOUND_GND

SOUND+B

GND

FROM MICON/TUNER

AUDIO_MUTE

POWER

FROM CHROMA

AUDIO_OUT

C355

50V 0.1

R360

68K

R359

47K

C354

10V 2200 YK

R353

68K

NOTE:

THE DC VOLTAGE AT EACH PART WAS MEASURED

WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST

WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.

A B

NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME

OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE

C D

CAUTION: SINCE THESE PARTS MARKED BY

CRITICAL FOR SAFETY,USE ONES

DESCRIBED IN PARTS LIST ONLY

ARE

8.2

3.5

+ -

3.4

5.1

0.3

3.9

ATTENTION: LES PIECES REPAREES PAR UN ETANT

DANGEREUSES AN POINT DE VUE SECURITE

N’UTILISER QUE CELLS DECRITES

DANS LA NOMENCLATURE DES PIECES

F G

TUNER VIDEO SIGNAL

AUDIO SIGNAL

PCB010

TMA511

MICON/TUNER

WAVEFORMS

1 200mV 200ms/div 6

0.5V 20

s/div

11 1V 20

s/div

2 0.5V 20

s/div 7 500mV 20

s/div

12 1V 20

s/div

3 200mV 20

s/div 8 20V 20

s/div 13 1V 20

s/div

DEFLECTION/CRT

4 200mV 5ms/div

CHROMA

9 200mV 20

s/div 14 0.5V 5ms/div

5 0.5V 2ms/div

10 0.5V 5ms/div 15 20V 20

s/div

NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.

WAVEFORMS

16 2V 20

s/div 21 50V 20

s/div

26 500mV 20us/div

17 200V 20

s/div

22 50V 20

s/div

SOUND/AV

18 10V 5ms/div

23 0.5V 1ms/div

19 10V 5ms/div 24 1V 1ms/div

20 50V 20

s/div

25 500mV 1ms/div

NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.

MECHANICAL EXPLODED VIEW

201

113

110

201

102

114

V801

114

J801

109

201

103

204

106

L503

114 PCB110

(CRT PCB)

FB401

114

203

108

111

107

112

202

205

104

203

202

TU001

PCB010

(MAIN PCB)

SP351

105

101

MECHANICAL REPLACEMENT PARTS LIST

Location No. TSB P/N Reference No.

---

201

202

203

204

205

110

111

112

113

114

101

102

103

104

105

106

107

108

109

AD300815 A3J816A720

BZ710009 741WUA0019

AD300802 713WPAA038

AD300808 735WPA0396

AD300801 701WPJB228

AD300803 713WPAA039

AD300804 735WPBA226

BZ710260 899HV3T000

AD300805 702WPAA136

AD300816 722549A027

AD300843 800WQ00044

AD300132 7230006818

AD300807 726000A016

BZ710275 8121J50B54

BZ710035 8117540A64

BZ710019 8109630802

BZ710239 8109I30A04

BZ710030 8110630804

BZ710031 8110630A04

AD300809 792WHAA052

AD300810 792WHAA053

AD300811 793WCDA987

AD300817 A3J816A975

AD300436 J3I70416

AD300139 J3I70715

AD300140 J3I70717

AD300502 J3I70725

AD300818 J3J81601

AD300845 JB5UD500

Description

CABINET,FRONT ASSY

SPRING,EARTH

GLASS,LED

SPEAKER HOLDER

CABINET,FRONT

GUIDE,REMOCON

BUTTON,FRAME

HOLDER,ANODE WIRE

CABINET,BACK

SHEET,RATING

FELT SHEET

SHEET,CAUTION

SHEET,CRT SERVICEMAN

SCREW,TAPPING(B0) GW20

SCREW,TAPPING(B0) TRUSS

SCREW,TAP TITE(B) BRAZIER

SCREW,TAP TITE(B) WH7

SCREW,TAP TITE(P) BRAZIER

PACKAGE,TOP

PACKAGE,BOTTOM

GIFT BOX

INSTRUCTION BOOK KIT

IMPORTANT SAFETY INSTRUCTIONS

SERVICE STATION LIST

REGISTRATION CARD

ENVELOPE

INSTRUCTION BOOK

POLY BAG

5x28

4x16

3x8

3x10

3x8

3x10

ELECTRICAL REPLACEMENT PARTS LIST

Location No. USA-TOSHIBA

! D502

! D503

! D504

! D505

D506

D507

D508

! D509

! D510

D512

! D513

D514

D516

D001

D109

! D401

! D402

D403

D404

! D405

! D406

D408

! D410

! D411

! D501

D518

D519

D528

D601

! C503

! C505

! C506

! C508

! C511

C514

! C515

C517

! C519

C521

! C526

C819

C354

! C403

! C414

! C418

! C434

C437

C442

! C443

! C446

! C448

! C502

! R401

! R405

! R406

! R407

! R408

! R409

! R426

! R429

! R500

! R501

! R504

! R505

! R509

! R515

! R517

! R518

! R519

R524

! R542

! R629

! R803

! R805

! R807

AD300072

BZ410054

AD300069

AD300071

BZ410043

BZ410066

BZ410063

BZ410006

BZ410043

BZ410063

BZ410085

BZ410076

AD300670

BZ410006

AD300671

BZ410080

BZ410006

BZ410076

BZ410006

BZ410021

BZ410006

AD300785

BZ110149

AD300662

BZ110041

AD300064

BZ110136

BZ110002

BZ110046

BZ110157

AD300664

BZ110080

BZ110145

AD300787

AD300788

BZ110122

BZ110081

AD300077

BZ110081

AD300060

BZ110089

AD300078

BZ210013

BZ210023

AD300780

BZ210053

AD300037

BZ210114

AD300651

BZ210116

BZ210080

AD300782

AD300660

AD300783

AD300655

AD300656

AD300784

AD300602

AD300658

BZ210097

BZ210058

AD300660

BZ210099

D94TA30013

0021721150

D97U02701B

D97U01101B

D2WT011E10

D97U06R21B

D2WTAU02A0

D1VT001330

D2WT011E10

D2WTAU02A0

D2WXN40050

D2WXB290S0

D97U01501B

D1VT001330

D97U01801B

D2WXRU2AM0

D1VT001330

D2WXB290S0

D1VT001330

D97U05R61B

D1VT001330

E02LT1222M

E02LT4471M

E02LT4101M

E02LT3471M

E02LT8220M

P4J7F3394J

C01BBP713K

P414F9822H

E02LT5220M

E5EZTC220M

C0J0B0513K

P2472B104M

CB3LF0M14M

E02LU5010M

C0JLYR7U2K

E02LT2471M

C0JLYR713K

E02LT2471M

E62NFB101M

E02LFC221M

C0JBB0713K

Reference No.

RESISTORS

R4X5T4104F

R4X5T4183F

R903N8102J

R002T22R2J

R4X5T6153F

R4X5T6123F

R002T4272J

R655814R7J

R0G3K2275K

R5Y2CD5R6J

R3X28B330J

R3X181221J

R903N8222J

R002T2683J

R3X1811R2J

R4X5T6222F

R903N8122J

R3X18A1R5J

R3X181R68J

R3X28B330J

R3X181153J

CAPACITORS

DIODES

R,METAL

R,FUSE

R,CEMENT

R,METAL OXIDE

R,METAL

R,METAL OXIDE

CMP

CMPP

DIODE,ZENER

LED

DIODE,ZENER

DIODE,SILICON

DIODE,ZENER

DIODE,SILICON

DIODE,ZENER

DIODE,SILICON

DIODE,ZENER

DIODE,SILICON

DIODE,ZENER

DIODE,SILICON

Description

100K OHM 1/4W

18K OHM 1/4W

1K OHM 1/8W

2.2 OHM 1/2W

15K OHM 1/6W

12K OHM 1/6W

2.7K OHM 1/4W

4.7 OHM 1W

2.7M OHM 1/2W

5.6 OHM 5W

33 OHM 3W

220 OHM 1W

2.2K OHM 1/8W

68K OHM 1/2W

1.2 OHM 1W

2.2K OHM 1/6W

1.2K OHM 1/8W

1.5 OHM 2W

0.68 OHM 1W

33 OHM 3W

15K OHM 1W

HZ30-3L TD

SLR-342VCT32

MTZJ27B T-77

MTZJ11B T-77

11E1-EIC

MTZJ6.2B T-77

AU02A-EIC

1SS133T-77

11E1-EIC

AU02A-EIC

1N4005-EIC

SB290S

MTZJ15B T-77

1SS133T-77

MTZJ18B T-77

RU2AM-EIC

1SS133T-77

SB290S

1SS133T-77

MTZJ5.6B T-77

1SS133T-77

2200 UF 10V

470 UF 35V

100 UF 35V

470 UF 25V

22 UF 100V

0.39 UF 250V PMS

0.001 UF 2KV BP

0.0082UF 1.6KV ECWH

22 UF 50V

22 UF 200V

0.001 UF 500V B

0.1 UF 275V PHE840

0.01 UF 250V

1 UF 50V

680 PF 2KV YR

470 UF 16V

0.001 UF 2KV YR

470 UF 16V

100 UF 160V

220 UF 200V

0.001 UF 2KV B

ELECTRICAL REPLACEMENT PARTS LIST

Location No. USA-TOSHIBA

L101

L405

! L501

! L503

L601

L606

L607

L801

T401

! T502

! Q401

! Q402

! Q501

! Q502

Q503

! Q504

Q507

Q603

Q604

Q605

Q606

Q607

! Q801

! Q802

! Q803

D602

D605

D610

D611

D612

D613

D615

D616

IC101

IC199

! IC351

! IC401

IC601

J352

J702

J703

! J801

SW101

SW102

SW103

SW104

SW105

PCB010

PCB110

B504

CD351

! CD501

CF601

CF603

CF604

! CP401

! CP502

CP601

CP801

CP806

CP802A

CP802B

EL001

EL002

! F501

! FB401

FH501

FH502

OS101

! SP351

BZ410058

BZ410043

AD300070

BZ410006

AD300672

AD300790

BZ611001

BZ611053

BZ611055

BZ310016

AD300684

AD300685

AD300621

BZ613015

AD300686

BZ614020

BZ614018

BZ614135

AD300800

BZ614058

BZ614273

BZ614043

BZ614044

AD300688

BZ614111

BZ614005

BZ614171

AD300689

BZ510036

AD300791

AD300675

BZ510044

BZ510004

BZ410088

BZ510069

BZ510070

BZ510023

AD300794

AD300676

BZ310004

AD300677

AD300795

AD300678

BZ310009

BZ310043

BZ310041

BZ310080

AD300796

AD300797

AD300680

AD300681

BZ614004

BZ612001

AD300813

AD300814

Reference No.

DIODES

D97U08R21B

D2WT011E10

D97U01201B

D1VT001330

ICS

I56F07063A

A3J813A015

I01DP75110

I01TD55220

I06FC61206

TRANSISTORS

TD30026270

TCKT1473AQ

T25FK26620

TC5T021204

TA3T016240

0002E00610

TCATC31980

TCAT032034

DIODE,ZENER

DIODE,SILICON

DIODE,ZENER

DIODE,SILICON

Description

TRANSISTOR, SILICON

TRANSISTOR,FIELD EFF

TRANSISTOR,SILICON

PHOTO COUPLER

TRANSISTOR, SILICON

MTZJ8.2B T-77

11E1-EIC

MTZJ12B T-77

1SS133T-77

OEC7063A

S-24C02BDP-1A

AN7511

AN5522

M61206FP

2SD2627LS-CBC11

2SC1473A-Q-TA

ECT 2SK2662

2SC2120Y(TPE2)

2SA1624-AA

LTV-817M-VB

KTC3198-AT(Y,GR)

KTC3203_Y-AT

A3J816A01A

A3J816A11A

024AT03655

06CH122301

120R414903

1022T45R73

1011T4R504

1012T4R519

069X450029

069W420029

0694260139

069W010030

069W010010

067U010049

124116281A

124120301A

081PC04004

043213012R

06710T0006

077Q014003

070Y132018

TNYTB03001

TCKT1473A0

021679472K

029T00A7M1

028R140030

0216731R2K

021LA62R2K

021LA6150K

COMPOUND TRANSISTOR

TRANSISTOR, SILICON

DTC114ESTP

2SC1473A-TA-(RQ)

2SC1473A-TA-(RQ) TCKT1473A0 TRANSISTOR, SILICON

COILS & TRANSFORMERS

021LA63R3K COIL

02167F101J

03305Y0018

0481290264

COIL

COIL,LINE FILTER

COIL,DEGAUSS

COIL

3.3 UH

4.7 MH

1R5A102F20

8R140030

1.2 UH

2.2 UH

15 UH

COIL

TRANS,HORIZONTAL DRIVE

100 UH

305Y001

TRANSFORMER,SWITCHING 81290264

JACKS

0602121012

060Q401077

060Q401076

JACK,RCA 3.5

RCA JACK

HSJ1403-01-010

AV1-09D-3

AV1-09D-4

066X120014 SOCKET,CATHODE RAY TUBE HPS3200-010501

SWITCHES

0504201T31

SWITCH,TACT

SKHVBED010

SKHVBED010 SWITCH,TACT

P.C.BOARD ASSEMBLIES

PCB ASS'Y

MISCELLANEOUS

CORE BEADS

CORD,CONNECTOR

CORD,AC BUSH

FILTER,SAW

FILTER,CERAMIC

FILTER,CERAMIC TRAP

CONNECTOR PCB SIDE

WIRE HOLDER

EYE LET

FUSE

TRANSFORMER,FLYBACK

HOLDER,FUSE

REMOTE RECEIVER

SPEAKER

TMA511A

TCA366A

BL01RN1-A63T6

CH122301

0R414903

SAFGP45M7VHCZR

EFCT4R5YS5A

TPSRA4M50C00-A0

B05B-DVS

TV-50P-02-A1

173979-6

TBS-X01X-A1

005P-2100

B2013H02-10P

XRY16X28BD

XRY20X30BD

51MS040LCC

3213012R

EYF-52BC

PIC-28143SY-2

S08F21

ELECTRICAL REPLACEMENT PARTS LIST

Location No. USA-TOSHIBA

! TH501

TM101

! TU001

! V801

X101

X602

BZ410079

AD300690

BZ610125

BZ614141

AD300624

BZ613004

DF5EL3R0A0

076N0EH010

0145K00055

Reference No.

COILS & TRANSFORMERS

DEGAUSS ELEMENT

TRANSMITTER

TUNER,VHF-UHF

Description

ZPB45BL3R0A

RC-EH010

TECC1040PG32D

098Q1404B2

1001T8R004

100CT3R505

CRT W/DY

CERAMIC,OSCILLATOR

CRYSTAL

A34AGT13X98(L)

EFOEC8004T4

HC-49/C

RESISTOR

RC...................

CARBON RESISTOR

CAPACITORS

CC...................

CE...................

CP...................

CPP..................

CPL..................

CERAMIC CAPACITOR

ALUMI ELECTROLYTIC CAPACITOR

POLYESTER CAPACITOR

POLYPROPYLENE CAPACITOR

PLASTIC CAPACITOR

CMP.......................

METAL POLYESTER CAPACITOR

CMPL................

METAL PLASTIC CAPACITOR

CMPP................

METAL POLYPROPYLENE CAPACITOR

TOSHIBA OF CANADA LTD.

HEAD OFFICE / 191 McNABB STREET MARKHAM,ONTARIO L3R 8H2,CANADA

Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project

Related manuals

24AF42 TV TOSHIBA2015-05-08 21:202.1 MB

13A22 COLOR TELEVISION SERVICE MANUAL FILE NO. 050-200205

Disney DT1900-C Service Manual

Memorex MT2271S Service Manual

Memorex MT1134 Service manual

13A24 COLOR TELEVISION SERVICE MANUAL FILE NO. 050-200408

Toshiba 19A26 Service manual

Toshiba 20A23, 20A42, 20A43 Service Manual

Toshiba 14AF41C Service manual

19A25C COLOR TELEVISION SERVICE MANUAL FILE NO. 050-200524GR

Disney DT1350-C, DT1350-P Service Manual

COLOR TELEVISION

13A23 COLOR TELEVISION SERVICE MANUAL FILE NO. 050-200306

19A24 COLOR TELEVISION SERVICE MANUAL FILE NO. 050-200409

13A23W COLOR TELEVISION SERVICE MANUAL FILE NO. 140-200312

Toshiba 27A51 27" TV - C:\Documents and Settings\Owner\My Documents\Toshiba Repair Guide27A51[1]

COLOUR TELEVISION

Orion TVDVD092 9 in. TV/DVD Combo - S:\Orion\DTV2784\DTV278

SERVICE MANUAL

Pacific Digital PTV3606 User's Manual

Toshiba 14N21NS CRT Television User Manual

Toshiba 27A41 Service Manual

Download PDF
