User manual | H1180HD HOME CINEMA

HOME
CINEMA
H1180HD
The H1180HD is an outstanding Home
Cinema projector
The H1180HD is Full HD 3D projector that is
economic to run thanks to a new generation
lamp that allows an extended lamp life up to
6,000h. With 2000 ANSI lumen of brightness
and a contrast ratio of 10,000:1 is a perfect
projector to entertain in a variety of dark or
moderate lighting environments. The new
1080p chipset, as well as a smart lamp power
management, help to deliver a high contrast
level of 10,000:1 and amazing black levels for
a great viewing experience in either 2D or in
3D.
Features
 Full high definition 1080p (1920x1080)
resolution for the best quality, sharpness
and clarity of video
 Super bright at 2000 ANSI lumens for
vibrant and dazzling images
 10,000:1 contrast ratio for crisp and sharp
text
 DLP® DarkChip3™ and BrilliantColor™
technologies from Texas Instruments
®
 SRS WOW significantly improves the
playback quality of audio, delivering a
deep, rich bass sound
 High-efficiency lamp that last up to 6000
hours (in economy mode)
 Host of connectivity options including
HDMI v1.4, VGA-in, S-video, component
and composite
 Direct 3D via HDMI
 Top sided lamp cover for convenient lamp
replacement
Specifications
Display Type
Brightness
Native Resolution
Maximum Resolution
Contrast Ratio
Uniformity
Lamp Life and Type
Throw Ratio
Image Size (Diagonal)
Projection Distance
Projection Lens
Zoom Ratio
Aspect Ratio
Offset
Keystone Correction
Horizontal Frequency
Vertical Scan Rate
Speakers
3D Ready
Video Compatibility
I/O Connection Ports
Projection Method
Security Solutions
Dimensions (W x D x W)
Weight
Noise Level
Power Supply
Power Consumption
Warranty
Standard Accessories
Optional Accessories
UPC
DLP®
2000 ANSI Lumens
1080p (1920 x 1080)
WUXGA [email protected]
10,000:1
95%
4500/6000 Hours; 190W/160W (Normal/Eco Mode)
1.39-2.09:1
66.5 -833.1cm (26.2"-328")
1.2 - 10m
F=2.418~2.97, f = 20.7~31.05mm
1.5x
16:9 Native, 16:10 and 4:3 compatible
130% ± 10%
Vertical ± 40°
15.6 – 91.1kHz
50 - 85Hz
SRS WOW®, 10W Speaker
Yes (Direct 3D through HDMI)
SDTV (480i, 576i), EDTV (480p, 576p), HDTV (720p,
1080i/p), NTSC (M, 3.58/4.43 MHz), PAL (B, D, G, H, I,
M, N), SECAM (B, D, G, K, K1, L)
HDMI v1.4 (x2), Component (YPbPr RCA)(x3), VGA-In,
S-Video, Composite Video, Audio-In RCA (L/R), AudioIn (Mini-Jack), Audio-Out (Mini-Jack), 12V Trigger, RS232, 3D Sync-Out, Std-USB (5V,1.5A), Mini-USB
(Service)
Table Top, Ceiling Mount (Front or Rear)
Kensington® Security Slot, Security Bar, Keypad Lock
285 x 261 x 121.8 mm
2.7kg
29dB / 32 dB for Eco / Normal
AC 100-240V, 50/ 60Hz
260W (Normal Mode), 230W (Eco. Mode), <0.5W
(Standby Mode)
3 Years, 1 Year (or 1,000h) on the Lamp
AC Power Cord, HDMI Cable, Remote Control,
Batteries for Remote, Lens Cap, Documentation Kit
Replacement Lamp, Remote
814964 338907
Product Pictures
