HP XP8010 Multimedia Projector

HP XP8010 Multimedia Projector

hp

xp8010 series digital projector reference guide

1

Notice

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Consumer transactions in Australia and the United Kingdom: The above disclaimers and limitations shall not apply to Consumer transactions in Australia and the United Kingdom and shall not affect the statutory rights of Consumers.

© Copyright 2003, 2004 Hewlett-Packard Development Company, L.P. Reproduction, adaptation, or translation of this manual is prohibited without prior written permission of Hewlett-Packard

Company, except as allowed under the copyright laws.

The programs that control this product are copyrighted and all rights are reserved.

Reproduction, adaptation, or translation of those programs without prior written permission of

Hewlett-Packard Co. is also prohibited.

Microsoft® and Windows® are U.S. registered trademarks of Microsoft Corporation. Adobe® and

Acrobat® are trademarks of Adobe Systems Incorporated.

Hewlett-Packard Company

Digital Projection and Imaging

1000 NE Circle Blvd.

Corvallis, OR 97330

Second Edition (April 2004)

Contents

1 Installation and Setup

What’s in the Box?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Identifying Common Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Projector at a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Projector buttons and lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Back panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Selecting a Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

To install on a table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

To install on the ceiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

To install for rear projection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

To install the cable shroud. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Turning On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

To connect power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

To turn the projector on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

To turn the projector off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

To operate the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

To reset the projector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Making Initial Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

To connect input sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

To connect output devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

To connect control equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Configuring the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

To change settings using the on-screen menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

To set up network access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Securing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Reference Guide 3

Contents

2 Adjustments

Making Basic Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

To aim the projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

To adjust the focus and zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

To adjust the audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Adjusting the Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

To adjust the image according to type of picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

To adjust other image settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

To make adjustments from the web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

3 Presentations

Connecting and Preparing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

To connect a computer using a VGA cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

To connect a handheld organizer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

To connect a computer using other types of cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

To connect other video sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Showing Presentations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

To present from a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

To change the source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

To hide or show the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

4 System Management

Managing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

To find the IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

To set basic projector properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

To set up email for notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

To protect configuration changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Upgrading the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

To update the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

To install an add-on lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

To change the connectivity module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

4 Reference Guide

Contents

5 Maintenance

Using the On-Screen Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Quick Choice menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Input menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Adjust Picture menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Audio menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Help menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Performing Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

To get the projector status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

To clean the projector lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

To replace the lamp module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

To replace the battery in the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

6 Troubleshooting

Troubleshooting Suggestions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Start-up problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Picture problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Sound problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Interruption problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Remote control problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Networking problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Testing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

To run the projector diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

7 Reference

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Laser safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

LED safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Mercury safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Reference Guide 5

Contents

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

U.S.A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

International. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Index

6 Reference Guide

1

Installation and Setup

The chapter explains how to install and set up the HP digital projector.

If you are a presenter who is setting up the projector for short-term use, see Chapter 3,

“Presentations.”

This chapter covers:

“Identifying Common Features” on page 9.

“Selecting a Location” on page 17.

“Turning On and Off” on page 23.

“Making Initial Connections” on page 27.

“Configuring the Projector” on page 34.

“Securing the Projector” on page 36.

Reference Guide 7

Installation and Setup

What’s in the Box?

Before setting up your projector, be sure your shipping box includes the following items. If the shipping box does not contain any of the following items, contact HP.

8

Identifying the contents of the box

Symbol Item

1

2

3

4

5

6

7

8

9

Projector

Function

Displays images.

Cable shroud

Documentation CD

Covers cable connections.

Contains projector documentation.

Warranty and support guides Provide warranty and support information.

Quick Setup Guide

Provides setup instructions.

Remote control

Two AAA batteries

VGA to VGA cable

Power cord

Controls projector.

Powers remote control.

Connects projector to computer.

Connects projector to power source.

Reference Guide

Installation and Setup

Identifying Common Features

This section identifies common features and functions of the projector. The section covers:

“Projector at a glance” on page 10.

“Projector buttons and lights” on page 11.

“Back panel” on page 12.

“Remote control” on page 14.

“Accessories” on page 16.

Reference Guide 9

Installation and Setup

Projector at a glance

10

Identifying the projector

Symbol Item

1

Infrared receiver

2

Cover latch

3

Control panel

4

Zoom ring

5

Focus ring

6

Lens cover

7

Height adjustment

Function

Receive signals from the remote control.

Releases cover for replacing lamp module and connectivity module.

Contains buttons and lights.

Enlarges picture size 100–120%.

Focuses at distances of 1.5–14 m (5–46 ft).

Protects lens.

Adjusts the height of the picture.

Reference Guide

Projector buttons and lights

Installation and Setup

Identifying buttons and lights on the projector

Symbol Item Function

1 Business graphics button Optimizes the picture for data input.

2

Super bright button Maximizes brightness (grayscale picture).

3 Power button

4 Theatre video button

8

Enter button, back button, and directional arrows

9

Source button

Turns the projector on or off. Blinks during warm-up and cool-down.

Optimizes the picture for video input.

5

Lamp-warning light Turns on when lamp fails.

6 Temperature-warning light Turns on when the internal temperature is too high.

7 Auto sync button Resynchronizes the projector to input signal.

Change projector settings using the on-screen menu.

Switches to the next input source.

Reference Guide 11

Installation and Setup

Back panel

12

Identifying the back panel

Symbol Item

1 VGA #1 and VGA #2 input connectors

2 RS232 port

Function

Connects desktop or notebook computers or pocket PCs.

Connects control equipment. Also used for firmware upgrades.

3 VGA-out and audio-out Connects to a monitor or second projector.

Connects to amplified speakers or audio equipment.

4 IR receiver

5 LAN port

Receives infrared signals from the remote control.

Connects the projector to a network.

6

Composite-video input Connects devices like VCRs.

7 S-video input

8

Component-video input

Connects devices like VCRs or camcorders.

Connects advanced DVD players or HDTV devices with YPbPr output.

Reference Guide

Installation and Setup

Identifying the back panel

(continued)

Symbol Item

9 Speakers

Function

Provides stereo sound.

:

Security slot Secures the projector using a cable lock.

;

<

=

Control power output

Analog video input

M1 input

Controls a motorized screen or similar device.

Connects various equipment with RGB, RGBS,

RGBHV, and YPbPr output.

Connects various equipment with analog- and digital-video output. Also supports USB-device output.

Connects power cord to projector.

>

Main power

?

Main disconnect switch Disconnects power. Turn off only when disconnecting power cord.

@ Remote input

A USB device output

Provides a wired connection for the remote control, such as for rear projection.

Sends mouse and keyboard signals from the remote control to a computer.

Certain models contain an L1581A Advanced Connectivity Module with additional ports. See the L1581A manual for information about using this module.

Reference Guide 13

Installation and Setup

Remote control

Before using the remote control, install two AAA batteries.

14

Identifying the remote control with case closed

Symbol Item Function

1

2

3

Page up and page down

Left-click and right-click mouse functions

Hide

Scrolls up and down through pages on a connected computer.

Performs left-click and right-click functions for a connected computer.

Hides the display.

4 Source

5

Power

6 Laser ring

7 Mouse button

Switches to the next input source.

Powers on and off the projector.

Turns on the laser pointer.

Moves the mouse pointer on a connected computer.

Reference Guide

Installation and Setup

Å

WARNING: To reduce the risk of injury to the eyes, do not look directly into the remote control laser light, and do not point the laser light into anyone’s eyes.

Identifying remote control with case open

Symbol Item Function

1

Theatre video button Optimizes the picture for video input.

2

3

Menu buttons

Auto sync

Change projector settings using the on-screen menu.

Resynchronizes the projector to the input signal.

4 Business graphics button Optimizes the picture for data input.

Reference Guide 15

Installation and Setup

Accessories

The following list displays some of the accessories you can buy for the HP projector:

Advanced connectivity module (add an optional 802.11b card for wireless computer connections and more)

Add-on lens

Short-throw

Long-throw

Carrying case

Ceiling mount

Projector screen

Power cables

Replacement lamp module

Video cables

16 Reference Guide

Installation and Setup

Selecting a Location

This section describes how to set up and plan for installing the projector:

“To install on a table” on page 18

“To install on the ceiling” on page 18

“To install the cable shroud” on page 22

“To install for rear projection” on page 21

Setting up the projector with respect to image size

Distance from screen

Diagonal size of projected image

Width of projected image

1.5 m 5 ft

2 m 7 ft

4 m 13 ft

6 m 20 ft

0.8–0.9 m

1.1–1.3 m

2.1–2.5 m

3.2–3.8 m

31–37 in.

41–50 in.

83–99 in.

124–149 in.

0.6–0.8 m

0.8–1.0 m

1.7–2.0 m

2.5–3.0 m

25–30 in.

33–40 in.

66–80 in.

99–119 in.

8 m 26 ft

10 m 33 ft

12 m 39 ft

4.2–5.1 m

5.3–6.3 m

6.3–7.6 m

165–199 in.

207–249 in.

248–298 in.

3.4–4.0 m

4.2–5.1 m

5.0–6.1 m

132–159 in.

165–199 in.

199–239 in.

14 m 46 ft 7.4–8.8 m 289–348 in.

5.9–7.1 m 232–278 in.

Reference Guide 17

Installation and Setup

If you do not want to use the distance table, you can use the following equations to help determine where to install the projector relative to the screen.

Calculating projection dimensions

distance from screen = A × width of screen min and max distance from screen = B width of screen = 0.8 × diagonal of screen (for 4:3 screen) projector lens at same level as bottom or top of screen

A = 1.98 to 2.38

B = 1.5 to 14 m (5 to 46 ft)

If your installation does not fall within these ranges, an add-on lens might be required.

See “To install an add-on lens” on page 57.

To install on a table

1. Place the projector on a stable platform located 1.5 to 14 m (5 to 46 ft) in front of the screen.

2. Connect all necessary cables to the projector.

3. If necessary, set the projector to match the installation. Open the on-screen menu and select setup > Projector position. Then choose Front Table from the drop-down list.

To install on the ceiling

Your ceiling mount might differ from the one shown in the following images.

However, the installation steps are basically the same.

HP recommends that a qualified carpenter or electrician install the ceiling mount.

18 Reference Guide

Installation and Setup

1. Align the end of the ceiling-mount bracket

1

with the center hole in the lower-mount bracket

2

, and firmly secure it with a washer

3

and bolt

4

.

2. Align the three holes on the projector with the lower-mount bracket and firmly secure with three screws.

Reference Guide 19

Installation and Setup

3. Attach the ceiling-mount bracket to the ceiling, and firmly secure with four screws capable of holding 9 kg (20 lb). The ceiling-mount bracket must be located 1.5 to

14 m (5 to 46 ft) in front of the screen.

20

4. Adjust the on-screen menu to match your settings. Open the on-screen menu and select setup > Projector position. Then select Front Ceiling from the drop-down list.

5. (Optional) Install the cable shroud to hide the cables. See “To install the cable shroud” on page 22. If you secure the projector with a Kensington lock, the lock

also secures the shroud.

Reference Guide

Installation and Setup

If you do not use an HP ceiling mount, mount the projector according to the following dimensions:

X = 1

76 mm (6.93 in.)

Y = 188 mm 7.40 in.)

Z =

86 mm (3.39 in.)

Thread size = M6

To install for rear projection

1. Place the projector 1.5 to 14 m (5 to 46 ft) behind a translucent screen that is designed for rear projection.

See “To install on a table” on page 18 or “To install on the ceiling” on page 18 for

more instructions.

2. Open the on-screen menu and select setup > Projector position. Then select

Rear Table or Rear Ceiling from the drop-down list.

If the projector is not visible to the remote control, you can use one of two techniques

to enable them to communicate. See “To connect control equipment” on page 33.

Reference Guide 21

Installation and Setup

To install the cable shroud

You can install the cable shroud to hide cable connections from view.

Insert the plastic hooks into the upper slots in the projector case, then push the bottom tabs into the lower slots.

22 Reference Guide

Installation and Setup

Turning On and Off

This section provides the following instructions:

“To connect power” on page 23

“To turn the projector on” on page 24

“To turn the projector off” on page 25

“To operate the remote control” on page 25

“To reset the projector” on page 26

To connect power

1. Connect one end of the power cord to the back of the projector

1

and the other end to an electrical outlet

2

.

2. Turn on the main disconnect switch

3

on the back of the projector.

To maintain network connectivity, the main disconnect switch must remain in the on position.

Reference Guide 23

Installation and Setup

To turn the projector on

1. Be sure the power cord is connected, and the main disconnect switch is turned on.

2. Remove the lens cap by pressing in on the tabs

1

on either side of the lens cap and pulling it straight out

2

.

3. Press the power button

3

on top of the projector, or press the power button on the remote control.

The power button blinks while the projector warms up. When the lamp turns on, the power button stays on, and the projector searches for a signal.

24

4. Connect and power on the source, such as computer, handheld organizer, or DVD

player. See “Making Initial Connections” on page 27 and “Connecting and

Preparing” on page 43 for more information.

Reference Guide

Installation and Setup

To turn the projector off

Press the power button on the projector or remote control to turn off the projector.

The power button blinks until the cool-down cycle completes.

Å

WARNING: Do not unplug the power cord or turn off the main disconnect switch until the cool-down cycles completes and the power button turns off. Failure to follow this precaution can result in damage to the projector.

To operate the remote control

To turn the project on or off, press the power button

5

.

To turn on the laser pointer, hold down the blue laser ring

6

.

To hide or unhide the projected picture, press the hide button

3

.

To switch to a different connected input source, press the source button

4

.

To operate as a mouse on a computer, tilt the mouse button

7

to move the pointer, and press the left-click

2

or right-click

2

button. This feature requires a USB connection between the projector and computer.

Reference Guide 25

Installation and Setup

To control page up and page down on a computer, press the page up

1

and page down

1

buttons. This feature requires a USB connection between the projector and computer.

Slide the remote control case open to use additional buttons.

To optimize the picture for the type of input signal, press the business graphics

or the theatre video button.

To change projector settings using the on-screen menu, press enter and use

the navigation buttons to make the changes. See “To change settings using the on-screen menu” on page 34 for more details.

To exit from any on-screen menu or adjustment, press the back button one or more times.

To adjust synchronization, press the auto-sync button.

For a picture showing the hidden remote control components, see “Remote control” on page 14.

From within a distance of 9 m (30 ft), aim the remote control at the screen or at the front or back of the projector.

Å

WARNING: To reduce the risk of injury to the eyes, do not look directly into the remote control laser light, and do not point the laser light into anyone’s eyes.

To reset the projector

If the projector becomes completely unresponsive, you can reset all circuits by disconnecting power.

1. Press the power button on the projector or remote control to turn off the projector, then wait until the cool-down period ends and the power button stops blinking. If the projector does not turn off, continue to the next step.

2. Turn the main disconnect switch off and wait 60 seconds. Then turn it on.

3. Press the power button to restart the projector.

26 Reference Guide

Installation and Setup

Making Initial Connections

If you are a presenter who is setting up the projector for short-term use, see Chapter 3,

“Presentations.”

The section explains how to connect different types of equipment to the projector:

“To connect input sources” on page 27

“To connect output devices” on page 32

“To connect control equipment” on page 33

To connect input sources

Computer with VGA cable connection

VGA cable

USB A/B cable

Stereo mini-phone audio cable

Reference Guide 27

Installation and Setup

Computer with M1-to-VGA cable connection

M1-to-VGA/USB cable (available from HP)

Stereo mini-phone audio cable

Computer with M1-to-DVI cable connection

M1-to-DVI/USB cable (available from HP)

Stereo mini-phone audio cable

28 Reference Guide

VCR with composite video cable connection

Video-RCA cable

Stereo-audio RCA cable

Installation and Setup

S-video equipment connection

S-video cable

Stereo-audio RCA cable

Reference Guide 29

Installation and Setup

DVD or HDTV with component-video cable connection

YPbPr RCA cable

Stereo-audio RCA cable

SCART-device connection

M1-to-SCART adapter cable (available from HP)

SCART cable

Stereo mini-phone audio cable

30 Reference Guide

RGB-equipment connection

RGB-video BNC cable

Stereo-audio RCA cable

RGBS-equipment connection

RGBS-video BNC cable

Stereo-audio RCA cable

Installation and Setup

Reference Guide 31

Installation and Setup

RGBHV-equipment connection

RGBHV-video BNC cable

Stereo-audio RCA cable

To connect output devices

VGA cable

Stereo-audio RCA cable

32

The speakers must be amplified.

Reference Guide

To connect control equipment

9-pin serial cable

2.5-mm (3/32-in) to 3.5-mm (1/8-in) stereo mini-phone cable

3.5 × 1.3-mm DC power cable

Installation and Setup

In some installations, the projector might not be visible to the remote control, such as for rear projection. Use one of these solutions to enable the remote control to work:

Use a remote control extension. Plug its cable into the remote connector on the projector. Install the receiver in the room with the presenter.

Wire the remote control to the projector. Construct a cable with a 2.5-mm

(3/32-in) stereo mini-phone jack at one end and a 3.5-mm (1/8-in) stereo mini-phone jack at the other end. Plug the small connector into the remote control and the large connector into the remote connector on the projector.

Reference Guide 33

Installation and Setup

Configuring the Projector

To change settings using the on-screen menu

You can change the on-screen menu settings with either the buttons on the projector or the remote control buttons.

34

1. Press enter on the projector or the remote control to open the on-screen menu.

2. Press up or down to highlight the desired menu, and press enter to select the highlighted option.

3. Press up or down to highlight the desired parameter, and press enter to select the highlighted option.

4. Press left or right or press up or down to select the desired setting.

For certain parameters, you see a different display while making the change.

5. Press enter to return to the menu.

6. To go to a different menu, press the back button, and select the menu.

7. To close the on-screen menu, press the back button one or more times as needed.

If nothing occurs for a period of time, the on-screen menu closes. To change the amount of time until the on-screen menu closes, open the on-screen menu and select setup > Timeout.

See “Using the On-Screen Menu” on page 61 for a list of all on-screen menu

selections.

Reference Guide

Installation and Setup

To set up network access

1. Plug a CAT5 network cable into the RJ-45 network port on the back of the projector.

If the projector has power, the left indicator light on the network port turns on showing a 10- or 100-Mb/s connection. The light on the right shows network activity.

The projector normally attempts to get an IP address from a Dynamic Host

Configuration Protocol (DCHP) server, or, if a server is not available, it takes a default address. The IP address is displayed at the bottom of the on-screen menu.

2. If you want to view or change the projector's TCP/IP network configuration, turn on the projector, open the on-screen menu, select setup > Network, and enter changes. If you are not running on a DHCP server, talk to your network administrator to find the correct TCP/IP network settings.

To set the advanced network configuration, see “To set basic projector properties” on page 54.

Reference Guide 35

Installation and Setup

Securing the Projector

36

The projector includes a built-in slot to secure the projector with a cable and a lock

(such as the Kensington MicroSaver lock system, available at many computer stores).

1. Wrap the cable around a secure object, such as a table leg. Loop the cable to create a slip knot around the stationary object, and be sure it cannot slip off.

2. Insert the lock

1

into the hole and twist the key

2

.

If the cable shroud is installed on the projector, the lock secures the shroud and the projector.

Reference Guide

2

Adjustments

This chapter describes how to make adjustments to the projector. The chapter covers:

“Making Basic Adjustments” on page 37.

“Adjusting the Picture” on page 40.

Making Basic Adjustments

This section provides the following instructions:

“To aim the projector” on page 38

“To adjust the focus and zoom” on page 39

“To adjust the audio” on page 39

Reference Guide 37

Adjustments

To aim the projector

To raise the projected picture on the screen, raise and hold the height adjustment lever while lifting the front of the projector to the desired display angle, then release the lever to lock the foot.

38

To lower the projected picture, raise and hold the height adjustment lever while pressing down on the front of the projector, then release the lever to lock the foot.

To level the projected picture, turn the two back feet to screw in or out. All four feet are adjustable in this way.

Reference Guide

Adjustments

To adjust the focus and zoom

1. Rotate the focus ring

1

until the image becomes clear. The projector can focus at distances of 1.5 to 14 m (5 to 46 ft).

2. Rotate the zoom ring

2

to adjust the picture size from 100 to 120%.

See “Selecting a Location” on page 17 for more information.

To adjust the audio

1. Open the on-screen menu and select audio.

2. Set the audio adjustments.

From the audio menu, you can select audio inputs, turn off internal speakers, and adjust mute, volume, balance, treble, and bass.

To get descriptions for all available audio adjustments, see “Using the On-Screen

Menu” on page 61.

Reference Guide 39

Adjustments

Adjusting the Picture

This section provides the following instructions:

“To adjust the image according to type of picture” on page 40

“To adjust other image settings” on page 40

“To make adjustments from the web” on page 41

To adjust the image according to type of picture

Use the picture mode buttons on the projector or the remote control to optimize the image.

To optimize the picture for data presentations, press the business graphics

button.

To optimize the picture for video images, press the theatre video

To maximize brightness, press the super-bright

button.

button (not available on the remote control). With this mode, the image is displayed in black and white.

To adjust other image settings

The on-screen menu provides many settings that allow you to fine-tune the picture.

1. Open the on-screen menu and select adjust picture.

2. Change the picture adjustments as needed.

From the adjust picture menu, you can change basic and advanced picture options, such as brightness, contrast, white intensity, aspect ratio, and keystone correction.

To get descriptions for all available picture adjustments, see “Using the On-Screen

Menu” on page 61.

To exit from any on-screen menu or adjustment, press the back button one or more times.

40 Reference Guide

Adjustments

To make adjustments from the web

If you have a computer with internet access, you can adjust the projector without opening the on-screen menu. The web interface has been tested on Microsoft

Windows 2000 and XP, Mac OS 9 and 10, Internet Explorer 5.5 and above, and

Netscape Navigator 7.0 and above.

1. On a networked computer, open an internet browser, enter the IP address of the

projector into the URL bar, and press the Enter key. See “To find the IP address” on page 53 for more information.

2. Click the Projector tab. On the left side of the screen, click adjust picture.

3. To adjust picture settings, select one or more of the options that are displayed on the right side of the screen, and click Apply.

Depending on access permission, you can change all projector settings from your computer browser.

Reference Guide 41

Adjustments

42 Reference Guide

3

Presentations

The chapter explains how to temporarily connect computers and other devices to the projector. This chapter covers:

“Connecting and Preparing” on page 43.

“Showing Presentations” on page 49.

“Disconnecting” on page 51.

Connecting and Preparing

The section provides the following instructions:

“To connect a computer using a VGA cable” on page 44

“To connect a handheld organizer” on page 45

“To connect a computer using other types of cables” on page 46

“To connect other video sources” on page 48

For information about other types of connections, see “Making Initial Connections” on page 27.

Reference Guide 43

Presentations

To connect a computer using a VGA cable

1. Connect a standard VGA cable between the VGA #1 port on the projector

1

and the VGA port on the computer

2

.

2. (Optional) To allow the remote control to function as the computer mouse, connect a USB A/B cable between USB-out port on the projector

3

and the computer

4

.

3. (Optional) To get audio, connect a mini-stereo cable between the VGA #1 audio port on the projector

5

and the computer

6

.

For a desktop computer, you can plug the desktop monitor into the VGA-out port on the projector, so the picture is visible on the projector screen and the desktop monitor.

44 Reference Guide

Presentations

To connect a handheld organizer

1. Be sure the handheld organizer has a VGA-out port. If necessary, install a

VGA-out accessory card into the organizer.

Not all handhelds come with VGA-out ports. For example, the iPAQ Pocket PC requires a VGA-out PC Card with 15-pin connector.

2. Connect a standard VGA cable between the VGA #1 port on the projector

1

and connect the other end to the VGA-out PC Card

2

.

Reference Guide 45

Presentations

To connect a computer using other types of cables

M1 to VGA/USB connection

1. Connect an M1-to-VGA/USB cable (available from HP) between the M1 port on the projector

1

and the VGA port on the computer

2

.

2. (Optional) To allow the remote control to function as the computer mouse, connect the USB plug of the M1-to-VGA/USB cable into the USB port on the computer

3

.

3. (Optional) To get audio, connect a stereo mini-phone cable between the M1-audio port on the projector

4

and the computer

5

.

46 Reference Guide

Presentations

M1 to DVI/USB connection

1. Connect an M1-to-DVI/USB cable (available from HP) between the M1 port on the projector

1

and the DVI port on the computer

2

.

2. (Optional) To allow the remote control to function as the computer mouse, connect the USB plug of the M1-to-DVI/USB cable into the USB port on the computer

3

.

3. (Optional) To get audio, connect a stereo mini-phone between the M1-audio port on the projector

4

and the computer

5

.

Reference Guide 47

.

Presentations

To connect other video sources

DVD player connection

1. Connect a triple RCA cable between the YPbPr ports on the DVD player

1

to the

YPbPr ports on the projector

2

. Observe the color coding of the connectors.

2. (Optional) To get audio, connect a stereo RCA cable between the stereo-audio ports on DVD player

3

and the YPbPr audio ports on the projector

4

. Observe the color coding of the connectors.

VCR connection

1. Connect a composite-video cable between the composite-video connector on the

VCR

1

and the projector

2

.

2. (Optional) To get audio, connect an RCA cable between the stereo-audio ports on

VCR

3 and the composite-audio ports on the projector

4

. Observe the color coding of the connectors.

48 Reference Guide

Presentations

Showing Presentations

The following section describes several things you can do during presentations:

“To present from a computer” on page 49

“To change the source” on page 50

“To hide or show the display” on page 50

To present from a computer

1. Be sure the computer is connected to the projector. See “Connecting and

Preparing” on page 43 for more information.

2. Be sure the computer and the projector are on. See “To turn the projector on” on page 24 for more information.

If the computer display is not projected on the screen, you might have to press a function key (such as Fn + F4) to turn on the computer’s video port. See the video port card shipped with the projector.

3. If you want to adjust the projected image, see “Adjusting the Picture” on page 40.

4. You can use the remote control to enhance your presentation. For more

information, see “To operate the remote control” on page 25.

To page through a presentation, press the page-up or page-down buttons.

To move the mouse pointer, tilt the mouse button.

To turn on the laser pointer, hold down the laser ring.

Å

WARNING: To reduce the risk of injury to the eyes, do not look directly into the remote control laser light, and do not point the laser light into anyone’s eyes.

For the mouse and page-up or page-down operations, aim the remote control at the screen or at the front or back of the projector from within a distance of 9 m (30 ft).

These operations require a USB connection from the projector to the computer.

Reference Guide 49

Presentations

To change the source

Press the source button on the projector or remote control, or

Open the on-screen menu, select input, and select the port to which the input source is connected.

To hide or show the display

You can easily hide the display from your audience temporarily.

Press the hide button on the remote control. The screen remains blank until you press the hide button again.

If you are using Microsoft PowerPoint, you can also press the B key or the W key to hide the display. The screen remains blank until you press the B key or the W key again.

50 Reference Guide

Presentations

Disconnecting

Ä

CAUTION: Do not disconnect power or turn off the projector until the projector has cooled down (the fan stops) and the power button light stops blinking. Otherwise, you might shorten the life of the lamp.

1. Press the power button on the projector or remote control to turn off the projector.

The power button blinks during the two-minute cool-down period. Then, the projector enters Standby mode, which retains network connectivity.

2. You can disconnect video and audio equipment from the projector during the cool-down period but not the power cord.

If the projector is connected to a network, do not turn off the main disconnect switch or unplug power. Disconnecting the power breaks the network connection.

3. If you must unplug or remove the projector, wait until the power button light stops blinking. Then turn off the main disconnect switch on the back of the projector and unplug the power cord.

If you try to turn on the projector again during the cool-down period, it does not turn on. Wait until the cool-down period ends and the power button stops blinking.

Reference Guide 51

Presentations

52 Reference Guide

4

System Management

This chapter explains how you can manage one or more projectors. If the projector is connected to a network, you can work from a central location by accessing the projector’s embedded web server, rather than being in the same room as the projector.

You can check the projector's current status, change its configuration, program automatic shutdown times, and upgrade firmware—all from a remote location.

The web interface has been tested on Microsoft Windows 2000 and XP, Mac OS 9 and 10, Internet Explorer 5.5 and above, and Netscape Navigator 7.0 and above.

This chapter covers:

“Managing the Projector” on page 53.

“Upgrading the Projector” on page 56.

Managing the Projector

This section provides the following instructions:

“To find the IP address” on page 53

“To set basic projector properties” on page 54

“To set up email for notifications” on page 55

“To protect configuration changes” on page 55

To find the IP address

Press enter on the projector or remote control to open the on-screen menu. Record the IP address, shown as a series of numbers on the bottom of the menu.

Press the back button to close the menu.

Reference Guide 53

System Management

To set basic projector properties

1. On a networked computer, open an internet browser, enter the IP address of the

projector in the URL bar, and press Enter. See “To find the IP address” on page 53 for more information.

2. Depending on the property you want to view or change, go to the location indicated in the following table.

3. Make any necessary changes and click Apply.

Changing Projector Properties

Projector Property Location in Web Interface

Status

Web interface language

Home > Device Info

Home > Select Language

Picture and audio* Projector

Basic network configuration* Networking > TCP/IP (or Wired

Settings on certain models)

Advanced network configuration Networking

*These properties are also available in the on-screen menu.

54 Reference Guide

System Management

To set up email for notifications

The projector can send email messages to specified recipients when certain critical events occur.

1. On a networked computer, open an internet browser, enter the IP address of the

projector into the URL bar, and press Enter. See “To find the IP address” on page 53 for more information.

2. Click the Management tab, and on the left side of the screen, click Alerts.

3. Select one or more of the events that cause email alerts.

4. Enter the email addresses to receive the alerts.

5. Enter the IP address of the Simple Mail Transfer Protocol (SMTP) server used by the projector for outgoing email. The SMTP server relays messages to recipients.

6. Click Apply.

To protect configuration changes

1. On a networked computer, open an internet browser, enter the IP address of the

projector into the URL bar, and press Enter. See “To find the IP address” on page 53 for more information.

2. Click the Networking tab, and on the left side of the screen, click Admin.

Account.

3. Enter and confirm a password.

You must use this password for all access and configuration parameter changes.

To disable the password, delete the password and leave the field blank.

4. Click Apply.

Reference Guide 55

System Management

Upgrading the Projector

The section provides the following instructions:

“To update the firmware” on page 56

“To install an add-on lens” on page 57

“To change the connectivity module” on page 59

To update the firmware

HP might periodically release updated versions of the projector firmware to enhance the projector performance. The projector firmware version is shown in the on-screen menu at help > About this projector and in the web interface on the Home tab.

Check for updated versions at http://www.hp.com/go/proj_firmware.

Web Method

1. On a networked computer, open an internet browser, enter the IP address of the

projector in the URL bar, and press the Enter key. See “To find the IP address” on page 53 for more information.

2. If the projector is turned on, press the power button to turn it off. Or you can do this in the browser by clicking the Projector tab, then clicking the Power button.

3. Click the Management tab, and on the left side of the screen, select Firmware

Upgrade.

4. Click the link for finding upgrade files on the web, then download the latest upgrade file.

5. Return to the projector Firmware Upgrade page and click Browse. Then, select the file you downloaded.

6. Click the upgrade button to start the upgrade process. Follow the displayed instructions.

56 Reference Guide

System Management

To install an add-on lens

If the projector distance and image size are not compatible with the room configuration, an add-on lens might provide a solution.

Use the following table to coordinate distance to the screen, width of the screen, and lens size.

Identifying lens range

Lens Distance Distance/Width Ratio

Short-throw lens

Normal lens

Long-throw lens

1.5–12 m (5–40 ft)

1.5–14 m (5–46 ft)

1.5–18 m (5–60 ft)

1.56–1.88

1.98–2.38

2.35–2.81

1. Be sure the lens cover is removed.

2. Turn the focus ring fully counter-clockwise.

Reference Guide 57

System Management

3. Press and hold the release latch on the focus ring

1

, and turn the ring

2

fully counterclockwise until it stops, and pull off the ring

3

.

4. Line up the marks on the lens and projector. Insert the add-on lens

1

into the slots on the main lens, then turn the lens

2

fully clockwise until the lens clicks into place.

58 Reference Guide

System Management

To change the connectivity module

1. Turn off the projector and disconnect power.

2. Open the lid

1

.

3. Remove the screw directly behind the back infrared receiver

2

.

4. Loosen the two screws

3

on the faceplate of the connectivity module at the back of the projector.

5. Use the screws to pull the module out of the projector

4

.

Reverse the procedure to install the connectivity module.

Reference Guide 59

System Management

60 Reference Guide

5

Maintenance

This chapter explains how to maintain the projector. The chapter covers:

“Using the On-Screen Menu” on page 61.

“Performing Routine Maintenance” on page 68.

Using the On-Screen Menu

The following tables describe all the functions available in the on-screen menu for the firmware version at publication. If your firmware is a different version, some menus might differ from those shown.

“Quick Choice menu” on page 62

“Input menu” on page 62

“Adjust Picture menu” on page 64

“Audio menu” on page 66

“Setup menu” on page 66

“Help menu” on page 67

To exit from any on-screen menu or adjustment, press the back button one or more times.

Reference Guide 61

Maintenance

Quick Choice menu

This menu provides quick access to commonly used functions from other menus. The menu in your projector may differ from the menu shown below.

quick choice

Brightness Brightens or darkens the image.

Contrast

Keystone correction

Reset keystone correction

Hide

Sets the difference between light and dark areas.

Corrects the slanted edges of an image. This function compensates for an off-center projector location.

Resets the keystone correction to zero.

Removes all images from the screen.

Input menu

This menu was named the Connect menu in earlier firmware versions. For a visual

aid, see “Back panel” on page 12.

input

VGA #1 Shows the input to the VGA #1 port. The VGA #1 usually connects the projector to a computer. This port usually connects to a computer. This input is normally considered a graphics input.

VGA #2

Composite video

Shows the input to the VGA #2 port. The VGA #2 usually connects the projector to a computer. This port usually connects to a computer. This input is normally considered a graphics input.

Shows the input to the yellow composite port (the input to the left of the S-video port on the back panel). The port usually connects to TV or VCR. This input is normally considered a video input.

62 Reference Guide

Maintenance

input (continued)

S-video

Component video (YPbPr)

Shows the input to the S-video port. This usually connects to a video device, such as a VCR, camcorder, or DVD player. This connection is normally considered a video input.

Shows the input to the three-connector YPbPr port.

This connects to a high-quality video device, such as a DVD player.

Analog video (RGBHV) Shows the input to the five-connector RGBHV port.

This usually connects to an analog graphics device with 3, 4, or 5 connectors. Automatically detects the signal type: RGB, RGBS, RGBHV, YPbPr, YCbCr. This connection is normally considered a graphics input.

Digital/analog graphics (M1) Shows the digital or analog input to the M1 port.

This port connects to several types of devices, including analog VGA and SCART devices and digital DVI (Digital Video Interface) devices. This connection is considered graphics or video input, depending on the device.

Source auto-search Sets whether the projector automatically searches for input signals and displays the next one found.

Reference Guide 63

Maintenance

Adjust Picture menu

adjust picture

Picture mode

White intensity

Brightness

Contrast

Color space

Keystone correction

Reset keystone correction

Aspect ratio

Magnify

Advanced picture >

Color saturation

Adjusts the color palette according to the type of picture. You can optimize the picture for computer presentations, video output, or super-bright grayscale output. The remote control and projector have buttons to change the picture mode.

Sets the brightness of white areas.

Brightens or darkens the image.

Sets the difference between light and dark areas.

For certain component inputs, selects the type of signal encoding used by the input source. You can override the selection made by the projector.

Corrects the slanted edges of an image. This function compensates for an off-center projector location.

Resets the keystone correction to zero.

Selects proportions of the image.

• To automatically adapt to most inputs, select

Best fit.

• If a wide-screen picture seems stretched, select

16:9.

• To stretch the picture to cover the entire projection area, select Fill.

• To show each picture dot as one projected dot, select 1-to-1.

Enlarges a portion of the picture, so it fills the entire screen.

Adjusts the advanced picture settings.

Adjusts the intensity of colors.

64 Reference Guide

Maintenance

adjust picture (continued)

Tint

Sharpness

Color temperature

Auto-sync

Vertical position

Horizontal position

Frequency

Tracking

Reset video settings

Shifts colors toward red or green.

Sharpens or softens the image.

Shifts colors toward red or blue.

Resynchronizes the projector to the input signal. This can compensate for any change in the signal.

Shifts the image up or down within the projection area.

Shifts the image left or right within the projection area.

Adjusts the timing of the projector relative to a computer graphics card.

Synchronizes the projector to a computer graphics card.

Resets the video settings to their default settings.

Reference Guide 65

Maintenance

Audio menu

audio

Mute

Volume

Balance

Treble

Bass

Audio input select

Internal speakers

Reset audio settings

Setup menu

setup

Language

Lamp saver

Projector position

Enable sources

Timeout for menu

66

Stops the audio output.

Changes the loudness of the audio.

Changes the loudness of the left and right audio.

Changes the loudness of the higher frequencies.

Changes the loudness of the lower frequencies.

Selects the audio input source, independent of the video source.

Sets whether the built-in speakers are active. Useful when the audio output is connected to an external audio system.

Resets the audio settings to the default values.

Selects the language for the menus.

Sets a lower light output for longer lamp life.

Adjusts the image to match the orientation of the projector: upright or upside-down, in front of or behind the screen. Inverts or reverses the image accordingly.

For each input source, sets whether it is searched or ignored when the projector searches for an input.

Sets how long the on-screen menu waits for input before it closes.

Reference Guide

setup (continued)

Network >

DHCP

IP address

Subnet mask

Gateway

Reset lamp hours

Machine reset

Help menu

help

About this projector

Diagnostics

Maintenance

Sets up the TCP/IP network parameters. Check with the network administrator.

Sets whether a DHCP server is used to assign an IP address to the projector. Do not use DHCP if you want the projector to have a fixed IP address every time power is connected.

Sets the projector IP address if not using DHCP.

Sets the projector subnet mask if not using DHCP.

Sets the projector gateway address if not using

DHCP.

For a new lamp, resets hours of use.

Resets most of the menu settings to default.

Displays information and status for the projector.

Show tests for checking the operation of the projector and the remote control.

Reference Guide 67

Maintenance

Performing Routine Maintenance

This section provides the following instructions:

“To get the projector status” on page 68

“To clean the projector lens” on page 68

“To replace the lamp module” on page 69

“To replace the battery in the remote control” on page 70

To get the projector status

Open the on-screen menu and select help > About this projector. This screen shows information and status for the projector.

To clean the projector lens

To minimize the risk of damaging or scratching the lens surface, blow dust particles off the lens with clean, dry, deionized air.

If this method does not work, use the following method:

Wipe the lens in a single direction with a clean, dry cloth. Do not wipe back and forth across the lens.

If the cloth is dirty or smears the lens, wash the cloth. If the cloth is still dirty after washing it or the fabric is damaged, replace it.

Ä

CAUTION: Cleaning requires special consideration:

Do not spray any type of fluid or cleaner directly on the lens surface. Cleaners might damage the lens.

Do not use fabric softener when washing a cleaning cloth or softener sheets when drying the cloth. Chemicals on the cloth might damage the surface of the lens.

Do not store a cleaning cloth in contact with the lens for a long time because doing so contaminates the lens with dye from the cloth. The cloth can be contaminated if left in the open air.

68 Reference Guide

Maintenance

To replace the lamp module

Å

WARNING:

When the lamp nears its end of life, it might break. To reduce the risk of injury, be careful when removing the lamp cover as broken glass might be present. For a ceiling installation, wear goggles and gloves when removing the lamp module. If the lamp is broken, contact HP about repairs that might be required.

Wait 30 minutes before opening the lamp cover and removing the lamp module because the lamp assembly operates at a very high temperature. If you open the lid during cool-down, you increase the cool-down time because the lid safety switch disconnects power and turns off the fan.

1. Turn off the projector and allow it to cool for 30 minutes.

2. Open the lid

1

on the top of the projector.

3. Use a Phillips screwdriver to loosen the three screws

2

holding the lamp module.

4. Lift the handle

3

and unplug the lamp module

4

from the projector.

Ä

CAUTION: Do not touch any internal parts of the projector. You could easily damage delicate or precision parts.

5. Insert the new lamp module and tighten the three screws.

Reference Guide 69

Maintenance

6. Close the lid.

7. Turn on the projector. If the lamp does not turn on after the warm-up period, try reinstalling the lamp again.

8. Open the on-screen menu and select setup > Reset lamp hours.

Å

WARNING: The lamp contains a small amount of mercury. If the lamp breaks, adequately ventilate the area where the breakage occurred. Disposal of this lamp may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance (www.eiae.org).

To replace the battery in the remote control

1. Slide the remote control case open to reveal the battery compartment.

2. On the back of the remote control remove the battery cover

1

to reveal the batteries.

3. Remove the old batteries, and install two new AAA batteries

2

.

4. Install the battery cover.

70

When discarding old batteries, contact your local waste-disposal provider regarding local restrictions on the disposal or recycling of batteries.

Reference Guide

6

Troubleshooting

This chapter describes potential problems and offers suggestions to help correct them.

This chapter covers:

“Troubleshooting Suggestions” on page 71.

“Testing the Projector” on page 81.

Troubleshooting Suggestions

To use this section, find the problem statement that is closest to your problem, then try each bulleted item one at a time until your problem is fixed. If the suggestions do not solve your problem, contact HP. See the Support Guide included with the projector.

This section covers:

“Start-up problems” on page 72.

“Picture problems” on page 73.

“Sound problems” on page 77.

“Interruption problems” on page 78.

“Remote control problems” on page 79.

“Networking problems” on page 79.

Reference Guide 71

Troubleshooting

Start-up problems

If no lights or sounds turn on:

Ensure that the power cable is securely connected to the projector and the other end is plugged into an outlet with power.

Verify the main disconnect switch is turned on (1), not off (0).

Verify that lid of the projector is latched shut.

Press the power button again.

Reset the projector by turning the main disconnect switch off, wait 60 seconds, then turn it on again.

If nothing is projected, but the projector seems to start up:

Ensure the lens cap has been removed.

If the lamp indicator is on, replace or reinstall the lamp module.

If the temperature indicator is on, turn off the projector and allow it to cool before restarting it. If the warning lights turn on again, contact HP for assistance.

If the projector makes a “ticking” sound, if the projector lamp does not turn on, and if warning lamp light is on:

The projector lamp is too hot to light. Turn the projector off and wait for it to cool before turning it on again.

The projector lamp is not making a good connection. Turn off the projector and allow it to cool. Then remove and reinstall the lamp module.

The projector lamp has reached the end of its life. Replace the lamp.

72 Reference Guide

Troubleshooting

Picture problems

If the image is not displayed on the screen, but the HP startup screen is displayed:

Press the source button on the projector or remote control.

Turn off or disable the notebook or desktop computer screen saver function.

For a computer connection, ensure your notebook computer's external video port is turned on. See the video port card shipped with the projector. On some notebooks, for example, press the

Fn + F4 function keys to turn on the external video port.

Verify that the right input source is connected. Open the on-screen menu and select input. Then set the correct input source where the equipment is connected.

Verify that the input port is enabled for auto-searching. Open the on-screen menu and select setup > Enable sources.

Verify that auto search is enabled. Open the on-screen menu and select input > Source auto-search.

If the wrong input source is displayed:

Press the source button on the projector or the remote control to select another active input source.

Verify that the right input source is connected. Open the on-screen menu and select input. Then set the correct input source.

Verify that the input port is enabled for auto-searching. Open the on-screen menu and select setup > Enable sources.

Verify that auto search is enabled. Open the on-screen menu and select input > Source auto-search.

If the image is out of focus:

Ensure the lens cap is removed.

While displaying the on-screen menu, adjust the focus ring. (The image size should not change; if it does, you are adjusting the zoom not the focus.)

Reference Guide 73

Troubleshooting

Ensure the projection screen is 1.5 to 14 m (5 to 46 ft) from the projector. It can be farther if a long range add-on lens is installed.

For a computer connection, set the display resolution on the computer to 1024 x 768.

Check the projection lens to see if it needs cleaning.

If an upside-down or reversed image is displayed:

The projector has been set to the wrong position setting. Open the on-screen menu, select setup > Projector position, and choose the correct setting

If the image is too small or too large:

Adjust the zoom ring on top of the projector.

Ensure the projector is 1.5 to 14 m (5 to 46 ft) from the projection screen.

Open the on-screen menu and select adjust picture > Aspect

ratio. Set to Best fit. For a wide-screen picture, try setting the aspect ratio to 16:9.

See “To install an add-on lens” on page 57 for more information.

If the image has slanted edges:

As much as possible, reposition the projector so that it is centered on the screen and level with the bottom or top of the screen.

Open the on-screen menu and select adjust picture > Keystone

correction. Adjust the horizontal and vertical settings as needed.

If a scrolling or cut-off image is displayed:

Press the auto sync button on the projector or remote control.

If the Magnify function is activated, press enter to cancel it.

For a computer connection, turn everything off, then power on the projector first and power on the notebook or desktop computer second.

For a computer connection, if the above steps do not correct the display image, adjust the resolution of the notebook or desktop computer to 1024 x 768.

74 Reference Guide

Troubleshooting

If the image is flickering or unstable:

Press the auto sync button on the projector panel or remote control.

For a computer connection, set the display resolution to

1024 x 768.

For a computer connection, open the on-screen menu and select

adjust picture > Advanced picture. Try adjusting the

Frequency or Tracking.

If the image is stretched:

Open the on-screen menu and select adjust picture > Aspect

ratio. Set to Best fit. For a wide-screen picture, try setting the aspect ratio to 16:9. Try setting the aspect ratio to 1-to-1.

If the image disappears from the computer screen:

For a notebook computer, you might be able to turn on both the external VGA port and the built-in screen. See the computer manual or the projector’s video port guide.

For a desktop computer, you can connect your monitor to the projector’s VGA output port.

If the projected colors seem slightly wrong:

If the business graphics button on the projector is lit, try pressing the theatre video button on the projector or remote control.

Open the on-screen menu and select adjust picture > Advanced

picture. Adjust the advanced settings as needed.

Open the on-screen menu and select adjust picture > Color

space. Try changing the selection.

Open the on-screen menu and select help > Diagnostics. Run color tests.

Reference Guide 75

Troubleshooting

If the projected colors seem completely wrong:

If the super-bright button on the projector is lit, the picture is displayed in grayscale. To display colors, press the business graphics button or the theatre video button on the projector or remote control.

For a YPbPr or RGB input device, be sure all the video connectors are correctly matched.

Ensure the pins on the cable connectors are not bent or broken.

Open the on-screen menu and select adjust picture > Color

space. Try changing the selection.

Open the on-screen menu and select help > Diagnostics. Run color tests.

Reset the picture settings to the factory-default settings. See the following problem.

If the picture settings are completely wrong and you cannot fix them:

Reset the projection settings to the factory-default settings. To do this, hold down these three buttons on the projector for 5 seconds:

back + up-arrow + auto sync. (This does not reset network settings.)

If a DVI device causes an error message or garbage on the screen:

Certain high-definition digital sources incorporate HDCP

(High-bandwidth Digital-Content Protection) content protection.

Such content cannot be displayed by this projector. If the device has another output port, such as YPbPr, try connecting that port to the projector.

If a VGA monitor displays a bad picture for certain inputs:

If you connect certain types of VGA monitors to the VGA output port, it might have a blank or erratic display for video inputs, but it should have a good display for computer graphics input. If this occurs, trying using a different type of monitor.

If the projector stops responding to all controls:

If possible, turn off the projector. Then turn the main disconnect switch off, wait 60 seconds, then turn it on again.

76 Reference Guide

Troubleshooting

Sound problems

If no sound is coming out of the projector:

Be sure you have an audio cable securely connected between the projector and the input device.

Be sure that the mute and volume settings are correct on the input device, such as a computer, DVD player, or camcorder.

Open the on-screen menu and select audio. Check the following settings:

Mute is turned off.

Volume is correct.

Internal speakers are turned on.

Audio input select shows the correct audio input for your video port.

If the projector speakers interfere with an external audio system:

Open the on-screen menu and select audio > Internal speakers.

Then, disable the internal speakers.

Reference Guide 77

Troubleshooting

Interruption problems

If the projector suddenly shuts down and the temperature light turns on:

If the temperature light is blinking, the fan is not working. Allow the projector to cool for several minutes.

If the temperature light is steady, the projector has overheated.

Allow it to cool for several minutes.

If airflow is obstructed, remove the obstruction.

If possible, remove any sources of excess heat in the room.

If the condition occurs after restarting the projector, contact HP to have the projector serviced or repaired.

If the lamp shuts off during a presentation:

A minor power surge might cause the lamp to shut off. Wait a few minutes, then power on the projector.

The lamp module might have burned out. Replace the lamp module.

If the lamp burns out or makes a popping sound:

When the lamp reaches its end of life, it might burn out and make a popping sound. If this happens, the projector will not turn back on until the lamp module has been replaced.

If the lamp breaks, contact HP about repairs that might be required.

78 Reference Guide

Troubleshooting

Remote control problems

If the remote control does not operate:

If the indicator light on the front of the remote control blinks when you press buttons, the remote control is working properly.

If the light does not blink, install two new AAA batteries in the remote control.

Be sure nothing is blocking the infrared receivers on the front and back of the projector. Move to within 9 m (30 ft) of the projector.

Open the on-screen menu and select help > Diagnostics. Run remote control tests.

If only the mouse and page up and down buttons do not work:

Be sure you have a USB connection between the projector and the computer.

Open the on-screen menu and select help > Diagnostics. Run remote control.

Networking problems

If you cannot access the projector via the web:

Check that you are using the correct IP address. The projector's IP address is shown in the on-screen menu on the projector.

Check the network cable connections at the projector and at the wall.

Check the left indicator light on the LAN port on the projector. If the light is not on, the network might not be active. Try a different cable or check the network outlet at the wall using a computer.

If your model includes an L1581A Advanced Connectivity

Module, see the L1581A manual.

Check whether the projector’s IP address shown in the on-screen menu is 169.254.x.x. If the projector is set to use a DHCP server, this address means no DHCP server is available. If the projector does not use a DHCP server, this address means no IP address is

Reference Guide 79

Troubleshooting

set for the projector—contact the network administrator for a valid TCP/IP network configuration, then set up the projector accordingly.

If you forget the projector’s web administrator password:

Reset the projector's network configuration to the factory-default values. To do this, turn off the projector. Then insert a straightened paperclip into the small hole in the connectivity module panel. While pressing the small button inside, turn the main disconnect switch off and on and continue holding the button for at least 15 seconds.

If you can access the projector via the web, but only the home page:

The web interface has been protected by the web administrator.

Contact the administrator.

If the network configuration is completely wrong and you cannot fix it:

Reset the projector's network configuration to the factory-default values. To do this, turn off the projector. Then insert a straightened paperclip into the small hole in the connectivity module panel. While pressing the small button inside, turn the main disconnect switch off and on and continue holding the button for at least 15 seconds.

80 Reference Guide

Troubleshooting

Testing the Projector

The on-screen menu contains diagnostic tests you can use to verify the proper operation of the projector and the remote control.

To run the projector diagnostics

1. Open the on-screen menu and select help > Diagnostics.

2. Select a test to perform.

Reference Guide 81

Troubleshooting

82 Reference Guide

7

Reference

This chapter lists the specifications, safety information, and regulatory information for the projector. The chapter covers:

“Specifications” on page 83.

“Safety Information” on page 90.

“Regulatory Information” on page 92.

Specifications

Because HP continually improves its products, the following specifications are subject to change. For the latest specifications, visit the HP website at http://www.hp.com.

Identifying the projector specifications

Luminance

xp8010:

Business graphics: 2200 ANSI lumens, 2600 ANSI (max) lumens

Super bright: 3850 ANSI lumens, 4600 ANSI (max) lumens

xp8020:

Business graphics: 2350 ANSI lumens, 3000 ANSI (max) lumens

Super bright: 3700 ANSI lumens, 4400 ANSI (max) lumens

Resolution XGA

Technology DLP

Contrast ratio 800:1 (typical)

Reference Guide 83

Reference

Identifying the projector specifications

(continued)

Video connectors M1-DA graphics (optional M1-DA cables for VGA, DVI, and SCART)

VGA #1 input

VGA #2 input

VGA output

S-video input

Composite-video input (1 RCA)

Component-video input (3 RCA)

Analog BNC input (5 BNC)

Audio connectors

I/O connectors

Connectivity module connectors

IR receivers

Cable shroud

Size

Weight

Appropriate video connectors paired with each video input

Stereo audio output

USB type-B for computer control

Wired-remote control input

12-V output for motorized screen control

LAN (RJ45)

RS-232

Advanced connectivity module only: two CompactFlash slots (Type II), two USB 1.1 Type A*, mini-phone microphone input*

* Reserved for future use

Front and rear for remote control

Included

442 × 302 × 139 mm (17.4 × 11.9 × 5.5 in) including handle, focus ring, and feet

6 kg (14 lb)

84 Reference Guide

Reference

Identifying the projector specifications

(continued)

Lens Standard: 1.98:1 to 2.38:1 throw ratio (distance/width)

Accessories:

Short-throw: 1.56:1 to 1.88:1

Long-throw: 2.35:1 to 2.81:1

Optical zoom

Digital zoom

Keystone

Audio

Lamp

Light engine

Color system

Remote control

Mounting options

Security

Power

1.2:1

Yes

Up to ±40° vertical

Up to ±17° horizontal

5-W peak stereo with sealed, resonating sound chambers xp8010: 250-W P-VIP lamp, 1.3-mm arc xp8020: 300-W P-VIP lamp, 1.3-mm arc

2000 hours rated life

Lamp-saver mode reduces lamp power by 20%

Replacement lamp: L1582A (xp8010), L1583A (xp8020)

0.7 12° DDR DMD

XGA

Dual color wheels providing three modes:

Business graphics

Theatre video

Super-bright grayscale

Integrated USB mouse with laser pointer

Supports wired connection

Ceiling and tabletop, front and rear projection

Kensington lock compatible

100 to 120 V, 200 to 240 V at 50 to 60 Hz.

Battery backup for time and date

Reference Guide 85

Reference

Identifying the projector specifications

(continued)

Noise level xp8010: 32±2 dBA xp8020: 36±2 dBA

Environment

Operating:

Temperature: 10 to 35°C (50 to 95°F)

Humidity: 80% RH max, non-condensing

Altitude: up to 3,000 m (10,000 ft), up to 25°C (77°F)

Storage:

Temperature: -20 to 55°C (-4 to 131°F)

Humidity: 80% RH max, non-condensing

Altitude: up to 12,000 m (40,000 ft)

Analog Video Mode Compatibility

Compatibility Resolution

VGA

SVGA

640 x 350

640 x 350

640 x 400

640 x 480

640 x 480

640 x 480

640 x 480

720 x 400

720 x 400

800 x 600

800 x 600

800 x 600

800 x 600

V-Sync (Hz)

72

75

85

70

70

85

85

60

85

56

60

72

75

H-Sync (kHz)

31.5

37.9

37.9

31.5

37.9

37.5

43.3

31.5

37.9

35.2

37.9

48.1

46.9

86 Reference Guide

Reference

SXGA+

UXGA

UXGA

MAC LC 13

MAC II 13

MAC 16

MAC 19

MAC

MAC G4

MAC G4

MAC G4 i Mac DV i Mac DV i Mac DV i Mac DV

Analog Video Mode Compatibility

Compatibility Resolution

XGA

SXGA

800 x 600

1024 x 768

1024 x 768

1024 x 768

1024 x 768

1280 x 1024

1280 x 1024

1400 x 1050

1600 x 1200

1600 x 1200

640 x 480

640 x 480

832 x 624

1024 x 768

1152 x 870

640 x 480

640 x 480

1024 x 768

640 x 480

800 x 600

1024 x 768

1152 x 870

V-Sync (Hz)

60

75

66.66

66.68

74.55

75

75.06

60

85

60

75

60

85

60

70

75

120

120

117

95

75

75

H-Sync (kHz)

75

93.75

34.98

35

49.725

60.24

68.68

31.35

53.7

48.4

56.5

60.0

68.7

63.98

79.98

63.98

68.03

97.09

60

60

60

68.49

Reference Guide 87

Reference

Analog Video Mode Compatibility

Compatibility Resolution

i Mac DV i Mac DV

1280 x 960

1280 x 1024

Digital Video Mode Compatibility

Compatibility Resolution

VGA

SVGA

XGA

SXGA

640 x 350

640 x 350

640 x 400

640 x 480

640 x 480

640 x 480

640 x 480

720 x 400

720 x 400

800 x 600

800 x 600

800 x 600

800 x 600

800 x 600

1024 x 768

1024 x 768

1024 x 768

1280 x 1024

V-Sync (Hz)

75

75

H-Sync (kHz)

75

90.9

V-Sync [Hz]

75

85

60

70

85

56

60

72

75

60

72

75

85

70

70

85

85

60

H-Sync [kHz]

37.9

35.2

37.9

48.1

46.9

53.7

48.4

56.5

60.0

63.98

31.5

37.9

37.9

31.5

37.9

37.5

43.3

31.5

88 Reference Guide

Reference

Digital Video Mode Compatibility

Compatibility Resolution

SXGA+

UXGA

1280 x 1024

1400 x 1050

1600 x 1200

V-Sync [Hz]

75

60

60

H-Sync [kHz]

79.98

63.98

75

Reference Guide 89

Reference

Safety Information

Safety precautions

To prevent eye injury, do not look into the lens when the lamp is on. Do not point any laser light at anyone's eyes.

To prevent electrical shock, do not expose the projector to rain or moisture. Do not open the projector except as instructed by the manual.

Allow the projector to cool before removing any cover and touching internal components, as instructed by the manual.

Keep paper and other combustible material away from the projector lens to prevent the possibility of fire.

Use only an approved power cord rated for the voltage and current marked on the product label. Do not overload any outlet or extension cord.

Laser safety

The laser pointer on the remote control is certified as Class 2 laser device according to the U.S. Department of Health and Human Services (DHHS) Radiation Performance

Standard and International Standards IEC 825/IEC 825-1 (EN60825/EN60825-1).

This device is not considered harmful, but the following precautions are recommended:

Ensure proper use by reading and following the instructions carefully.

If the unit requires service, contact an authorized HP service center.

Do not attempt to make any adjustment to the unit.

Avoid direct exposure to the laser beam.

90 Reference Guide

Reference

LED safety

The infrared ports located on the digital projector and remote control are classified as

Class 1 LED devices according to International Standard IEC 825-1 (EN60825-1).

This device is not considered harmful, but the following precautions are recommended:

If the unit requires service, contact an authorized HP service center.

Do not attempt to make any adjustment to the unit.

Avoid direct eye exposure to the infrared LED beam. Be aware that the beam is invisible light and cannot be seen.

Do not attempt to view the infrared LED beam with any type of optical device.

Mercury safety

Å

WARNING: This digital projector lamp contains a small amount of mercury. If the lamp breaks, adequately ventilate the area where the breakage occurred. Disposal of the lamp might be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance http://www.eiae.org.

Reference Guide 91

Reference

Regulatory Information

This section presents information that shows how your digital projector complies with regulations in certain regions. Any modifications to your digital projector not expressly approved by HP could void the authority to operate the digital projector in these regions.

U.S.A.

This digital projector has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This digital projector generates, uses, and can radiate radio frequency energy.

If not installed and used in accordance with the instructions, it can cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this digital projector does cause harmful interference to radio or television reception (which can be determined by unplugging the unit), try the following:

Reorienting or relocating the receiving antenna.

Relocating the digital projector with respect to the receiver.

Connecting the digital projector's power cord to another power outlet.

Connections to peripheral devices

To maintain compliance with FCC Rules and Regulations, use properly shielded cables with this device.

For more information, consult your dealer, an experienced radio/television technician, or the following booklet, prepared by the Federal Communications Commission, How

to Identify and Resolve Radio-TV Interference Problems. This booklet is available from the U.S. Government Printing Office, Washington, DC 20402, Stock Number

004-000-00345-4. At the first printing of this manual, the telephone number was

(202) 512-1800.

Canada

This Class B digital apparatus complies with Canadian ICES-003.

92 Reference Guide

Japan

Korea

Reference

Reference Guide 93

Reference

International

For regulatory identification purposes, your product is assigned a regulatory model number. The regulatory model number for your product is listed in the declaration following table. This regulatory number is different from the marketing name and product number.

Manufacturer's Name:

Manufacturer's Address:

DECLARATION OF CONFORMITY

According to ISO/IEC Guide 22 and EN 45014

Hewlett Packard Company

Hewlett Packard Company

Digital Projection & Imaging

1000 NE Circle Blvd.

Corvallis, OR 97330-4239

Declares, that the product(s):

Product Name:

Model Number(s):

Regulatory Model:

Conforms to the following product specifications:

Safety: IEC 60950:1999/ EN 60950:2000

Digital Projector xp8010 and xp8020

CRVSB-03CA and CRVSB-04CA

IEC 60825-1:1993 +A1 / EN 60825-1:1994 +A11 Class 1 LED

GB4943-1995

EMC: EN 55022: 1998 Class B [1]

CISPR 24:1997 / EN 55024: 1998

IEC 61000-3-2:1995 / EN 61000-3-2:2000

IEC 61000-3-3:1994 / EN 61000-3-3:1995+A1:2001

GB9254-1998

FCC Title 47 CFR, Part 15 Class B/ANSI C63.4:1992

AS/NZS CISPR 22:2002

Supplementary information:

The product herewith complies with the requirements of following Directives and carries the CE marking accordingly:

-Low Voltage Directive: 73/23/EEC

-EMC Directive: 89/336/EEC

[1] The product was tested in a typical configuration with Hewlett Packard Personal Computer peripherals.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Corvallis, Oregon, March 1, 2004

94

Steve Brown, General Manager

European Contact for regulatory topics only: Hewlett Packard GmbH, HQ-TRE, Herrenberger Straße 140, 71034

Boeblingen, Germany. (FAX:+49-7031-143143).

USA Contact: Hewlett Packard Co., Corporate Product Regulations Manager, 3000 Hanover Street, Palo Alto, CA

94304. Phone: (650) 857-1501.

Reference Guide

A

accessories listing

16

see Reference Guide

add-on lens installing

57

range

57

adjustments from the web 41 admin. account

see configuration

aiming the projector raising and lowering

38

alerts

see email

analog video mode compatibility

86

audio adjusting

39

connecting

27

,

43

B

back panel identifying

12

business graphics mode

see picture mode

buttons projector

11

remote control

14

Reference Guide

Index

C

ceiling installation setting up

18

ceiling mount

19

ceiling mount bracket

see ceiling installation

computer connecting

27

,

43

configuration admin. account

55

protecting

55

using on-screen menu

34

connecting computer with M1 to DVI

28

,

47

with M1 to VGA

27

,

28

,

44

,

46

connecting devices 43

see Reference Guide

connecting DVD

see also connecting input sources

with YPbPr ports

48

connecting input sources computer with M1 cable to DVI

28

,

47

computer with M1 cable to VGA

28

,

46

computer with VGA cable

27

,

44

DVD or HDTV with triple RCA cable

30

RGA equipment

31

RGBC equipment

31

RGBHV equipment

32

SCART device

30

VCR with video cable

29

,

48

Index 95

Index

connecting output devices monitor and speaker

32

connections

see back panel

connectivity module installing

59

removing

59

contents in the box

8

D

digital video mode compatibility

88

disconnecting projector

51

distance

see also lens

setting up with respect to image

17

E

email setting notifications

55

embedded web server

53

events

see email

F

firmware updating from network

56

updating from serial port

56

focus adjusting

39

range of

39

G

graphics mode

see picture mode

Index 96

H

handheld organizer connecting

45

hide button

50

I

input/output connectors

see back panel

installation

see Reference Guide

installing

see location

IP address finding

53

setting

35

K

Kensington lock

36

L

lamp module replacing

69

see Reference Guide

laser pointer

25

laser safety precautions

90

LED safety precautions

91

lens cleaning

68

damaging

68

finding range

57

installing

57

lights identifying

11

location

see also ceiling installation

see also rear projection installation

see also table installation

selecting

17

Reference Guide

lock

36

see Reference Guide

lower-mount bracket

see ceiling installation

M

maintenance routine maintenance

68

see Reference Guide

menu

see on-screen menu

mercury

70

N

network advanced

54

configuring

54

connecting

35

troubleshooting

35

network access connecting

35

networking

see Reference Guide

notifications

see email

O

on-screen menu adjust picture menu definitions

64

audio menu definitions

66

help menu definitions

67

input menu definitions

62

quick choice menu definitions

62

setup menu definitions

66

using 34

P

password disabling

55

setting

55

Reference Guide

Index

picture adjusting

40

picture mode changing

26

,

40

definition

40

power plugging in

23

turning off

25

turning on

24

presentations from a computer

49

source changing

50

projector identifying parts

10

maintaining

68

maintaining see Reference Guide

R

rear panel

see back panel

rear projection installation setting up

21

regulatory information

Canada

92

European Union

94

Japan

93

Korea

93

U.S.A.

92

remote control battery replacement

70

extension

33

identifying with doors closed

14

identifying with doors open

15

using

25

remote control extension

33

resetting network settings

80

projection settings

76

projector

26

Index 97

Index

S

safety information laser safety

90

LED

91

precautions

90

securing the projector installing lock

36

security locking

36

see Reference Guide

SMTP

see email

sound

see audio

source changing

50

connecting

27

,

43

specifications of the projector

83

see Reference Guide

status on-screen menu viewing

68

web viewing

54

super-bright mode

see picture mode

T

table installation setting up

18

TCP/IP

see network

testing diagnostics

81

theatre video mode

see picture mode

troubleshooting interruption problems

78

picture problems

73

remote control problems

79

sound problems

77

start-up problems

72

suggestions

71

turning off

25

disconnecting

51

turning on

24

U

upgrading

see add-on lens installing

see firmware updating

using

50

V

video connecting

27

,

43

video mode

see picture mode

W

web accessing projector 41

,

54

Z

zoom adjusting

39

range of

39

Index 98 Reference Guide

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement

Table of contents
