Socket 478 (Intel)
865PE-A
Socket 754 (AMD)
Socket 462 (AMD)
Socket 478 for Intel Pentium 4 processor
Socket 370 (Intel/VIA)
Archives
Graphic Card
Notebook
z
FSB 800
z
HT CPU Support
z
Dual DDR-400
z
Serial ATA
z
AGP 8X
z
6 Channel Audio
zoom in
Mobile PC
Desktop PC
Feature
| Specification |
Driver
|
BIOS
|
Manual
| CPU Support
Specification
CPU
Socket 478 for Intel Pentium 4 processor
FSB 800/ 533/ 400MHz
Support Hyper-Threading Technology
CHIPSET
Intel® 865PE & ICH5
North Bridge: Intel® 865PE
South Bridge: Intel® ICH5
MEMORY
Dual-channel DDR memory architecture
4 x184-pin DDR DIMM socket support up to 4 GB
Support DDR400/333/266/200 2.5V DDR SDRAM
EXPANSION
SLOT
STORAGE
1 x AGP 8X/4X slot
5 x PCI slots
Support by Intel® ICH5
-- 4 x Ultra DMA100/66 devices
-- 2 x Serial ATA devices
AUDIO
Realtek ALC655 6-Channel audio CODEC
Compliant with AC'97 2.3 specification
LAN
REAR PANEL
I/O
Realtek RTL8100C 10/100 Mbps Fast Ethernet Controller
1 x PS/2 keyboard & PS/2 mouse connectors
4 x USB ports
1 x RJ45 LAN connector
1 x Parallel port (LPT1)
1 x Serial port (COM1)
1 x Audio ports (Line-in, Line-out, Mic-in)
INTERNAL I/O
1 x 20-pin ATX Power Supply Connector & 4-pin 12V Connector
CONNECTORS
1 x Floppy connector supports 360K~2.88M Bytes, 3 Mode FDDs or
& HEADERS
LS120
2 x IDE connectors
2 x Serial ATA connectors
2 x USB 2.0 header support additional 4 USB Ports
1 x SPDIF out header
1 x Speaker header
1 x Front panel switch/LED header
1 x Front panel audio header
CD in/ AUX in headers
CPUFAN/PWRFAN/SYSFAN connectors
SYSTEM BIOS
Award BIOS with 4Mb Flash ROM
Supports Plug and Play 1.0B, APM 1.2, Multi Boot, DMI
Full Support for ACPI revision 1.0 specification
FORM FACTOR
ATX Form Factor, 305*244mm
