OCTOBER 2007
rs
Receive
ers
Amplifi
rs
Speake
t
n
e
inm
a
t
r
e
t
n
E
r
Ca
IN THIS EDITION...
MARINE
SPEAKERS
AMPLIFIERS
103
Direct connection of an
iPOD is now possible with
a supplied cable to the new
CDXGT50UI head unit.
This connection is located on the rear of the unit
for seamless integration.
HEAD UNIT Drive-S
Shock Resistant
Further more you can display track number and
elapsed playing time.
Sony’s key objective is to deliver the best possible
starting point for a great performing sound system.
That’s why Sony continues with the DRIVE-S
chassis in its 2007 CD head-unit range.
You don’t need to worry about poor battery life
because as long as the car is running or the
ignition switch is set to ACC, the iPOD will also
be charging.
While connected you can navigate track, album
and artist name. This process is even easier with
all the information on the head units display.
Connectivity
Front Auxiliary Input
Sony has made it easier than ever to connect almost any portable audio
device to your car system. One little cable is all it takes and you can listen
to your Walkman, iPod, portable music player or portable DVD players
through your Sony Xplod system. No need to mess around with FM
modulators to listen to your MP3 player in the car. The auxiliary input is
built right in to the face of the head unit. All you need to do is plug-n-play
with the provided cable.
USB
Front USB
The lightweight design of the
DRIVE-S laser optical pick-up
ensures greater efficiency,
rapid response and accurate reading of music
tracks from CDs providing further protection
against skipping.
24BIT Digital to
Analogue Converter
Selected Sony head-units feature
a 24BIT Digital to Analogue
Converter (DAC). The 24BIT
conversion process ensures that music is
accurately reproduced the way it was intended
to be heard. Music tones will sound more
natural and vibrant, providing an enriched
listening experience.
An underpowered amplifier can often result in
distortion, which not only degrades audio quality
but is the main contributor to blown speakers.
In order to overcome this problem, every DRIVES head-unit features a high-powered S-MOSFET
amplifier, capable of delivering a combined power
of up to 208 Watts (max).
ch
ch
ch
ch
ch
ch
ch
ch
Noise and cross talk
SOI Insulator
prevents electrical
charges ocurring
between channels
Unlike conventional MOSFETs, S-MOSFET
features a unique technology called SOI (silicon
on insulator) and its primary function is to reduce
interference that normally occurs between audio
channels. In doing so, SOI ensures that the music
signal is as clean as possible before it reaches your
speakers for maximum sound quality.
The DRIVE-S circuitry
incorporates high-capacity
audio capacitors. Audio
capacitors interconnect audio stages to
minimise signal distortion and enhance
the overall frequency response.
Conventional Mechanism
AMPLIFIER Stream
Bluetooth
The Stream series is Sony’s premium range of car entertainment amplifiers. Each amplifier incorporates these key features.
Bluetooth’s popularity is increasing with over 500 million Bluetooth devices sold
in 2006. Sony has now included the technology into its Xplod series enabling
convenient hands-free chatting via your mobile phone or even wireless music
streaming (using the A2DP profile – see page 40) Sony offers the ability to place
and receive calls right from your car stereo. When you make or receive a call,
it has a built-in microphone and mutes the music while channeling the phone
conversation through one of the vehicle’s speakers.
SPEAKERS HOP
Finding the perfect material for speaker cones is an ongoing quest in speaker design. Exclusive to Sony’s speaker range are cones in a high-tech polymer
called high oriented polyolefine, or HOP.
www.sony.com.au
Only 24mm in height, the slim design of the
DRIVE-S mechanism is much more responsive
and energy efficient compared to conventional
mechanisms. The result is a reduction in heat
that significantly enhances durability, reliability,
and performance from every CD head unit.
Responsive Laser
Optical Pick-Up
S-MOSFET
High-Capacity
Audio Capacitors
*WMA files without DRM
104
Slim-Design Mechanism
Drive-S Mechanism
Sony is committed to making it as easy as possible to enjoy your favourite music,
no matter where you are or what you’re doing. That’s why several models in the
2007 Xplod line up feature a direct USB input conveniently located on the front
panel. This allows you to playback MP3 or WMA* files you may have on a typical
USB storage device through your head unit. Sony supports most brands of MSC
(Mass Storage Class) products but of course, offers even greater connectivity for
Sony Walkman users. Simply plug in a compatible Walkman (e.g. NWE005FV) and
playback your favourite songs complete with track info via your car entertainment
system. It even charges your Walkman at the same time!
What makes HOP remarkable is its ability to remain rigid and light.
To properly perform its function, a speaker cone must balance three
fundamental properties:
(a) it must remain rigid throughout operation to avoid distortion caused by
cone flex.
(b) it must be well-damped, so it doesn’t produce any sounds of its own,
outside those sent to it from the amplifier for reproduction, and
(c) it must be relatively light, so it can respond quickly enough to accurately
reproduce sound waves and transients. Weight is particularly important
when reproducing small, quick waveforms, such as mid-range and
high frequencies.
DRIVE-S fuses a slim, robust
mechanism and efficient
electronic circuitry to deliver
the best sound quality and
durability from CD head-units.
The result is greater shock
protection, rapid response, and superior audio
processing for an uninterrupted sonic experience.
The DRIVE-S shock-resistant
system comprises of 3
progressively-wound springs
coupled with inner silicon-filled
dampers. The CD mechanism is supported at
three points for optimum stability, ensuring that
shocks and bumps are absorbed to provide
uninterrupted skip free music.
CAR & MARINE ENTERTAINMENT
iPod Connection
Unlike conventional materials such as polypropylene, the crystalline
strands in HOP are aligned to an almost perfect parallel orientation.
The parallel strands strengthen the cone surface to minimise any flexing.
This breakthrough technology allows for many more benefits over
conventional speaker cone
materials, including superior
overall efficiency, an ability
to handle more power,
greater bandwidth and
smoother response.
Large Toroidal Power
Transformer and Choke Coils
Aluminium Plate and On
Board Heat Sink
High-powered systems can often put a
strain on an amplifier’s power supply circuit.
This is no problem for Sony’s Stream amplifiers.
Each Stream amplifier uses a large doublewound toroidal power transformer and choke
coils to ensure stable operation. The heavy-duty
double-wound construction ensures that they
are capable of delivering high current when
the system demands it. Each coil is isolated
to supply power to different stages within the
amplifier, resulting in greater stability and
uninterrupted audio reproduction during peak
current demands.
Heat not only can affect stability, but also have
an adverse effect on the long-term reliability
of an amplifier. For this reason, each output
transistor is mounted onto a specially constructed
diecast aluminium heat sink. A layer of thermal
compound grease is applied to each transistor
before being secured in place with an aluminium
plate. The diecast aluminium heat sink is
designed with a large surface area to facilitate
maximum heat dissipation.
Transistor
Aluminium
Plate
Large Gauge, Gold-Plated Terminals
Large gauge terminals are featured on Stream
amplifiers because of their low impedance
characteristics and high electrical current
handling capabilities. Each terminal is gold
plated to eliminate
oxidisation and
enhance conductivity.
Multiple MOSFETs
MOSFETs are the final output stage of the
amplifier and are responsible for driving the
speakers. Having multiple MOSFETs significantly
increases current flow, which dramatically
improves the power handling capabilities of
the amplifier.
Diecast
Aluminium
Heatsink
Toroidal
Transformer
Choke Coils
Thermal Compound
Mosfets
www.sony.com.au
CAR & MARINE ENTERTAINMENT
KEY TECHNOLOGY
105
CD RECEIVER $349.00 *
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Front Aux Input
• CD-R/RW Playback
• 24 Bit Digital to Analogue Converter
• Rear / Sub Switchable Pre-Out
• 13 seg W.LED LCD Display
• EQ3 Stage 2
• SSIR-EXA Tuner
• Preset : FM18/MW6/SW12
• Detachable Face
q
q
q
q
q
q
q
q
q
q
www.sony.com.au
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18/MW6/SW12
• FM Tuning Range :
87.5-107.9, 87.5-108.0MHz
• AM Tuning Range :
531-1602, 530-1710kHz
AUDIO PROCESSING
SPECIFICATIONS
CD DECK
• DRIVE-S Mechanism
• CD-R/RW Playback
• Playback modes : Repeat /
Shuffle / Pause
• Max Installation Angle : 45°
• Display Type (Back light Colour / LCD
type) : 13 seg W.LED LCD
• Dimmer Control : Manual
q
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 179
• Weight : 1.2kg
S-MOSFET 208 Watts Max
Front USB Input
Front Aux Input
MP3 / WMA§ / ATRAC / AAC§ Playback
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Front Aux Input
• Front USB Input
• CD-R/RW / MP3 / WMA§ /
ATRAC / AAC§ Playback
• 24 Bit Digital to Analogue Converter
• Rear / Sub Switchable Pre-Out
• FL Display
• EQ3 Stage 2
• SSIR-EXA Tuner
• Changer Control
• Remote Included
• Detachable Face
• Preset : FM18 / MW6 / SW12
CD RECEIVER $349.00 *
q
q
✔ S-MOSFET 208 Watts Max
✔ MP3 / WMA§ Playback
✔ Front Aux Input
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Front Aux Input
• CD-R/RW / MP3 / WMA§ Playback
• 24 Bit Digital to Analogue Converter
• Rear / Sub Switchable Pre-Out
• 13 seg W.LED LCD Display
• EQ3 Stage 2
• SSIR-EXA Tuner
• Preset : FM18/MW6/SW12
• Detachable Face
• Remote Included
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18/MW6/SW12
• FM Tuning Range :
87.5-107.9, 87.5-108.0MHz
• AM Tuning Range :
531-1602, 530-1710kHz
AUDIO PROCESSING
q
• DRIVE-S Mechanism
• CD-R/RW/MP3/WMA§ Playback
• Playback modes : Repeat /
Shuffle / Pause
• Max Installation Angle : 45°
• Max Output Power
(@ 4 Ohms 1kHz) : 52W
• Pre-Out : Rear / Sub Switchable
• Pre-Out Voltage : 2
• Pre-Out Impedance : 220
• Input : Front Aux-In
• DAC : 24 Bit
• EQ Type : EQ3 Stage 2
• Bass/Treble : Low / Mid / High
q
q
DISPLAY PANEL
q
• Panel Type : Detachable
• Panel Finish Colour : ‘08 Gun Metallic
• Key Illumination (Colour) : Red
• Display Type (Back light Colour / LCD
type) : 13 seg W.LED LCD
• Dimmer Control : Manual
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 179
• Weight : 1.2kg
✔
✔
✔
✔
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18 / AM12
• FM Tuning Range :
87.5-107.9, 87.5-108.0MHz
• AM Tuning Range :
531-1602, 530-1710kHz
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Front Aux Input
• CD-R/RW / MP3 / WMA§ /
ATRAC / AAC§ Playback
• 24 Bit Digital to Analogue Converter
• Front + Rear / Sub Switchable Pre-Out
• FL Display
• EQ3 Stage 2
• SSIR-EXA Tuner
• Changer Control
• Remote Included
• Detachable Flip Down Face
• DSO2
• Rotary Commander Optional
• Preset : FM18 / AM12
CDXGT50UI
CD RECEIVER $299.00 *
CD RECEIVER $449.00 *
q
q
q
q
✔ S-MOSFET 208 Watts Max
✔ Front Aux Input
✔ Changer Control
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Front Aux Input
• CD-R/RW / MP3 / WMA§ Playback
• 24 Bit Digital to Analogue Converter
• Rear / Sub Switchable Pre-Out
• 13 seg W.LED LCD Display
• EQ3 Stage 2
• SSIR-EXA Tuner
• Preset : FM18/MW6/SW12
• Remote Included
• Detachable Face
• Changer Control
• DRIVE-S Mechanism
• CD-R/RW/MP3/WMA§ Playback
• Playback modes : Repeat /
Shuffle / Pause
• Max Installation Angle : 45°
• CD-R/RW / MP3 / WMA§ / ATRAC
/ AAC§ Playback
• Playback modes : Repeat /
Shuffle / Pause
• Max Installation Angle : 45°
q
q
AUDIO PROCESSING
DISPLAY PANEL
• Max Output Power
(@ 4 Ohms 1kHz) : 52W
• Pre-Out : Rear / Sub Switchable
• Pre-Out Voltage : 2
• Pre-Out Impedance : 220
• Input : Front Aux-In and Front USB
• DAC : 24 Bit
• EQ Type : EQ3 Stage 2
• Bass / Treble : Low / Mid / High
• Panel Type : Detachable
• Panel Finish Colour : Gun Metallic
• Key Illumination Colour : Red / Green
• Display Type (Back light Colour / LCD
type) : FL / 13 seg
• Dimmer Control : Manual
AUDIO PROCESSING
DISPLAY PANEL
• Max Output Power
(@ 4 Ohms 1kHz) : 52W
• Pre-Out : Front + Rear /
Sub Switchable
• Pre-Out Voltage : 2
• Pre-Out Impedance : 220
• Input : Front Aux-In
• DAC : 24 Bit
• DSO : DSO2
• EQ Type : EQ3 Stage 2
• Bass / Treble : Low / Mid / High
• Panel Type : Detachable Flip Down
• Panel Finish Colour : Gun Metallic
• Key Illumination Colour : Red / Green
• Display Type (Back light Colour / LCD
type) : FL / 13 seg
• Dimmer Control : Auto
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 179
• Weight : 1.2kg
S-MOSFET 208 Watts Max
Front Aux Input
Front + Rear / Sub Switchable Pre-Out
LCD FL Display
CDXGT370
CD DECK
CD DECK
• Panel Type : Detachable
• Panel Finish Colour : ‘08 Gun Metallic
• Key Illumination (Colour) : Red
CD RECEIVER $249.00 *
CD DECK
SPECIFICATIONS
DISPLAY PANEL
CDXGT560†
SPECIFICATIONS
q
q
• Max Output Power
(@ 4 Ohms 1kHz) : 52W
• Pre-Out : Rear / Sub Switchable
• Pre-Out Voltage : 2
• Pre-Out Impedance : 220
• Input : Front Aux-In
• DAC : 24 Bit
• EQ Type : EQ3 Stage 2
• Bass/Treble : Low / Mid / High
q
q
q
✔
✔
✔
✔
CDXGT270
SPECIFICATIONS
106
q
q
q
✔ S-MOSFET 208 Watts Max
✔ Selectable Sub-out Pre-Out
✔ Front Aux Input
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18/MW6/SW12
• FM Tuning Range :
87.5-107.9, 87.5-108.0MHz
• AM Tuning Range :
531-1602, 530-1710kHz
AUDIO PROCESSING
q
• Max Output Power
(@ 4 Ohms 1kHz) : 52W
• Pre-Out : Rear / Sub Switchable
• Pre-Out Voltage : 2
• Pre-Out Impedance : 220
• Input : Front Aux-In
• DAC : 24 Bit
• EQ Type : EQ3 Stage 2
• Bass/Treble : Low / Mid / High
q
DISPLAY PANEL
• Panel Type : Detachable
• Panel Finish Colour : ‘08 Gun Metallic
• Key Illumination (Colour) : Red
• Display Type (Back light Colour / LCD
type) : 13 seg W.LED LCD
• Dimmer Control : Manual
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 179
• Weight : 1.2kg
✔
✔
✔
✔
CD DECK
• CD-R/RW / MP3 / WMA§ / ATRAC
/ AAC§ Playback
• Playback modes :
Repeat / Shuffle / Pause
• Max Installation Angle : 45°
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18 / AM12
• FM Tuning Range : 87.5-107.9,
87.5-108.0MHz
• AM Tuning Range : 531-1602,
530-1710kHz
q
q
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 179
• Weight : 1.2kg
In-built iPod Adapter
Front USB and Aux Input
S-MOSFET 208 Watts Max
24 Bit Digital to Analogue Converter
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Rear / Sub Switchable Pre-Out
• FL Display
• EQ3 Stage 2
• SSIR-EXA Tuner
• Changer Control
• Remote Included
• Detachable Face
• Preset : FM18 / MW6 / SW12
SPECIFICATIONS
q
SPECIFICATIONS
CD DECK
• DRIVE-S Mechanism
• CD-R/RW / MP3 / WMA§ / ATRAC / AAC§
Playback
• Playback modes : Repeat /
Shuffle / Pause
• Max Installation Angle : 45°
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18 / AM12
• FM Tuning Range :
87.5-107.9, 87.5-108.0MHz
• AM Tuning Range :
531-1602, 530-1710kHz
AUDIO PROCESSING
q
q
• Max Output Power
(@ 4 Ohms, 1kHz) : 52W
• Pre-Out : Rear / Sub Switchable
• Pre-Out Voltage : 2
• Pre-Out Impedance : 220
• Input : Front Aux-In, Front USB
and iPod Connector
• DAC : 24 Bit
• EQ Type : EQ3 Stage 2
• Bass / Treble : Low / Mid / High
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 179
• Weight : 1.2kg
DISPLAY PANEL
• Panel Type : Detachable
• Panel Finish Colour : Gun Metallic
• Key Illumination (Colour) : Blue
• Display Type (Back light Colour / LCD
type) : FL / 13 seg
• Dimmer Control : Manual
§Non DRM † Selected stores only
*SRP is manufacturer’s suggested retail price only and is inclusive of GST. Prices effective as of 1st October 2007. Prices subject to change without notice.
CAR & MARINE ENTERTAINMENT
q
q
CDXGT460U
CD RECEIVER $199.00 *
q Refer to KEY TECHNOLOGY pages for detailed information.
www.sony.com.au
CAR & MARINE ENTERTAINMENT
q
CDXGT170
107
q
q
q
q
q
MEXDV1000
CD RECEIVER $449.00 *
CD / DVD RECEIVER $499.00 *
✔
✔
✔
✔
✔
✔
✔
✔
Bluetooth® Connectivity
Front Aux Input
24 Bit Digital to Analogue Converter
CD-R/RW / MP3 / WMA§ / ATRAC / AAC§ Playback
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Front Aux Input
• Bluetooth®
• CD-R/RW / MP3 Playback
• 24 Bit Digital to Analogue Converter
• 13 seg White LED LCD Display
• EQLite
• SSIR-EXA Tuner
• Optional Remote
• Detachable Face
• Preset : FM18 / AM12
q
SPECIFICATIONS
q
q
q
CD DECK
• DRIVE-S Mechanism
• CD-R/RW / MP3 Playback
• Playback modes : Repeat /
Shuffle / Pause
• Max Installation Angle : 45°
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18 / MW6 / SW12
• FM Tuning Range :
87.5-107.9, 87.5-108.0MHz
• AM Tuning Range :
531-1602, 530-1710kHz
q
q
q
AUDIO PROCESSING
DISPLAY PANEL
• Max Output Power
(@ 4 Ohms, 1kHz) : 52W
• Input : Front Aux-In
• Bluetooth : Ver 2.0 A2DP
HFP SPP AVRCP
• DAC : 24 Bit
• EQ Type : EQLite
• Bass / Treble : Low / High
• Panel Type : Detachable
• Panel Finish Colour : Gun Metallic
• Key Illumination Colour : Blue
• Display Type (Back light Colour / LCD
type) : 13 seg W.LED LCD
• Dimmer Control : Manual
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 179
• Weight : 1.2kg
DVD / CD / MP3 / WMA§ / JPG / DivX / SACD Playback
4V Pre-Out
Front Aux Input
Karaoke
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Front Aux Input
• DVD-R / RW / CD-R/RW / VCD / MP3 /
WMA§ / JPEG / DIVX Playback
• 4V Pre-Out
• 13 seg White LED LCD Display
• EQ7 Parametric
• SSIR-EXA Tuner
• Changer Control
• Remote Included
• Rotary Commander Optional
• Detachable Face
• Karaoke Mic Input
• Preset : FM18 / AM12
q
q
CD DECK
• DRIVE-S Mechanism
• DVD-R / RW / CD-R/RW / VCD / MP3
/ WMA§ / JPEG / DIVX Playback
• Playback modes : Repeat /
Shuffle / Pause
• Max Installation Angle : 45°
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18 / MW6 / SW12
• FM Tuning Range :
87.5-107.9, 87.5-108.0MHz
• AM Tuning Range :
531-1602, 530-1710kHz
CDXGT760†
CXS2616F
CD RECEIVER $499.00 *
CD RECEIVER AND SPEAKER PACK $299.00 *
✔
✔
✔
✔
✔
q
q
Motorised Detachable Face
Front Aux Input
2 x Pre-Outs + Sub Out
LCD FL/Dot Display
CD-R/RW / MP3 / WMA§ / ATRAC / AAC§ Playback
✔
✔
✔
✔
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Front Aux Input
• CD-R/RW / MP3 / WMA§ /
ATRAC / AAC§ Playback
•24 Bit Digital to Analogue Converter
• 3 Pre-Out
• DSO2
• EQ3 Parametric
• SSIR-EXA Tuner
• Changer Control
• Remote Included
• Rotary Commander Optional
• Motorised Detachable Face
• BBE
• Preset : FM18 / AM12
SPECIFICATIONS
CD DECK
§
• CD-R/RW / MP3 / WMA / ATRAC
/ AAC§ Playback
• Playback modes :
Repeat / Shuffle / Pause
• Max Installation Angle : 45°
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18 / AM12
• FM Tuning Range :
87.5-107.9, 87.5-108.0MHz
• AM Tuning Range :
531-1602, 530-1710kHz
q
q
AUDIO PROCESSING
DISPLAY PANEL
• Max Output Power
(@ 4 Ohms 1kHz) : 52W
• Pre-Out : 2 x Preouts + Sub Out
• Pre-Out Voltage : 2
• Pre-Out Impedance : 220
•Auxiliary Input : Front Aux-In
• DAC : 24 Bit
• DSO : DSO2
• BBE
• EQ Type : EQ3 Parametric
• Bass / Treble : Low / Mid / High
• Panel Type : Motorised Detachable
• Panel Finish Colour : Gun Metallic
• Key Illumination Colour : Blue / Red
• Display Type (Back light Colour / LCD
type) : FL / Dot
• Dimmer Control : Auto
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 179
• Weight : 1.6kg
q
q
q
q
AUDIO PROCESSING
DISPLAY PANEL
• Max Output Power
(@ 4 Ohms, 1kHz) : 52W
• Pre-Out : Rear / Sub Switchable
• Pre-Out Voltage : 4
• Pre-Out Impedance : 220
• Auxiliary Input : Front Aux-In
• EQ Type : EQ7 Parametric
• Panel Type : Detachable Flip Down
• Panel Finish Colour : Gun Metallic
• Key Illumination Colour : Blue
• Display Type (Back light Colour / LCD
type) : 13 seg W.LED LCD
• Dimmer Control : Manual
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 179
• Weight : 1.2kg
S-MOSFET 200 Watts Max (50W x 4)
Front Aux Input
CD-R / MP3 / WMA§ Playback
16cm 2-way Speakers
FEATURES
q
q
SPECIFICATIONS
q
CD HEADUNIT
• S-MOSFET 200 Watts Max (50W x 4)
• Front Aux Input
• CD-R/RW / MP3 / WMA§ Playback
• 24 Bit Digital to Analogue Converter
• 13 seg White LED LCD Display
• EQLite
• SSIR-EXA Tuner
• Preset : FM18 / MW6 / SW12
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18/MW6/SW12
• FM Tuning Range :
87.5-107.9, 87.5-108.0MHz
• AM Tuning Range :
531-1602, 530-1710kHz
SPEAKERS
• 16 cm (6.5”) 2-Way
– 190W Max
• H.O.P Woofer Cone
• Rubber Coated Cloth Surround
• Aluminium Diaphragm Midrange
SPECIFICATIONS
• DRIVE-S Mechanism
• CD-R/RW / MP3 / WMA§ Playback
• Playback modes : Repeat /
Shuffle / Pause
• Max Installation Angle : 45°
AUDIO PROCESSING
q
• Max Output Power (@ 4 Ohms, 1kHz)
: 50W x 4
• Auxiliary Input : Front Aux-In
• DAC : 24 Bit
• EQ Type : EQ Lite
• Bass / Treble : Low / High
DISPLAY PANEL
WOOFER
• Panel Type : Detachable
• Panel Finish Colour : Gun Metallic
• Key Illumination (Colour) : Red
• Display Type (Back light Colour / LCD
type) : 13 seg W.LED LCD
• Dimmer Control : Manual
• Surround : Rubber Coated Cloth Surround
• Type : Cone
• Material : High Oriented Polyolefin
• Magnet : Ferrite Magnet
• Size : 16cm
GENERAL
• Surround : Fixed
• Type : Cone
• Material : Aluminium Diaphragm
• Magnet : Neodymium
• Size : 4cm
• Dimensions (WxHxDmm) :
178 x 50 x 179 mm
• Weight : 1.2 kg
• Grille (included)
• Weight : 0.56 kg
• Dimensions (Dia x Hmm without grill) :
158 x 52.9
MID-RANGE
CAR & MARINE ENTERTAINMENT
CAR & MARINE ENTERTAINMENT
q
q
q
MEXBT2500
SPEAKERS
• Sensitivity : 90dB/W/m
• Frequency response : 35Hz-22kHz
• Rated power : 40W
• Size : 16cm (6”)
• Peak power : 190W
§Non DRM † Selected stores only
CDXGT860U
CD RECEIVER $549.00 *
q
q
q
www.sony.com.au
q
108
✔
✔
✔
✔
Knowing Sony just got Easier
S-MOSFET 208 Watts Max (52W x 4)
Front Aux Input
Front USB Input
CD-R/RW / MP3 / WMA§ / ATRAC / AAC§ Playback
FEATURES
• S-MOSFET 208 Watts Max (52W x 4)
• Front Aux Input
• Front USB Input
• CD-R/RW / MP3 / WMA§ / ATRAC / AAC§
Playback
• 24 Bit Digital to Analogue Converter
• 4V-3 Pre-Out
• FL/Dot Display
• DSO2
• BBE
• EQ3 Parametric
• SSIR-EXA Tuner
• Preset : FM18 / AM12
• Changer Control
• Remote Included
• Rotary Commander Optional
• Silver
• Detachable Face
Now there are even more benefits from owning a Sony product!
SPECIFICATIONS
q
CD DECK
• DRIVE-S Mechanism
• CD-R/RW / MP3 / WMA§ / ATRAC
/ AAC§ Playback
• Playback modes :
Repeat / Shuffle / Pause
• Max Installation Angle : 45°
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18 / AM13
• FM Tuning Range :
87.5-107.9, 87.5-108.1MHz
• AM Tuning Range :
531-1602, 530-1711kHz
q
AUDIO PROCESSING
DISPLAY PANEL
• Max Output Power
(@4 Ohm, 1 kHz) : 52W
• Pre-Out : Front + Rear + Sub
• Pre-Out Voltage : 4
• Pre-Out Impedance : 220
• Input : Front Aux-In and Front USB
• DAC : 24 Bit
• DSO : DSO2
• BBE
• EQ Type : EQ3 Parametric
• Bass/Treble : Low / Mid / High
• Panel Type : Low / Mid / High
• Panel Finish Colour : Silver
• Key Illumination (Colour) : Blue / Red
• Display Type (Back light Colour / LCD
type) : FL / Dot
• Dimmer Control : Auto
GENERAL
• Dimensions (WxHxDmm) :
178 x 50 x 190
• Weight : 1.6kg
*SRP is manufacturer’s suggested retail price only and is inclusive of GST. Prices effective as of 1st October 2007. Prices subject to change without notice.
My Sony is your online membership program,
designed to be your convenient, personal
connection to the world of Sony. Membership
is free, registration is simple and as a My Sony
member, you’ll receive these exclusive deals
and benefits:
VIP Treatment
VIP Invitations to special member events and
product demonstrations hosted by Sony.
Receive superior, personalised customer
support via a prioritised member support line.
Exclusive Pre-Order opportunities on exciting
new additions to our range.
Special Offers on Sony products and
services, including extended warranty.
Free shipping on all Sony Style purchases.
q Refer to KEY TECHNOLOGY pages for detailed information.
Manage Your Products
Win! Check out the latest competitions
Keep easy access to product information,
upgrades and instruction manuals, simply by
adding products to your own personal online
product inventory.
For the latest competitions, promotions
and prize giveaways make sure you visit
www.sony.com.au/mysony
Past winners have scored themselves the
ultimate VIP football experience, trips to exotic
destinations and fabulous Sony products including
PLAYSTATION®3s, BRAVIA LCD TVs and more.
Stay Informed
Get the latest news from Sony, tailored to your
interests and sent direct to your inbox.
Have the next edition of Pulse delivered
straight to your door.
Get the latest products at great value
Bid online on My Sony e-auctions
for the latest Sony gear.
Take advantage of SonyCentral
exclusive offers.
How to become a My Sony Member
Simply log on to www.sony.com.au/mysony
and follow the prompts.
If you have a Sony product that you
purchased on or after 1995, you’re eligible
to join My Sony.
www.sony.com.au
q
q
q
109
2 CHANNEL ZR SERIES AMPLIFIER $249.00 *
✔ Motorised 7” Touch TFT Screen
✔ DVD / VCD / MP3 / CD Playback
✔ 3 x AV Input
q
✔ Channel Configuration : 2ch/1ch
✔ MOSFET Power Supply (60W x 2)
✔ Toroidal Transformer
q
q
FEATURES
• ZR Series
• Channel Configuration : 2 Channel Mono
• Line – Low Level Input x 2
• Speaker – Hi Level Input x 2
• MOSFET Power Supply
• Toroidal Transformer
• Gold Plated Terminals
FEATURES
• 7” Touch Screen TFT Active Matrix
16 : 9 Display
• Double Din Chassis Design
• Fast Response touch screen control
• Adjustable angle
• DVD±R/RW/CD/CD-R/CD-RW/MP3
Playback
• 24 bit D/A converter
• Front Angle Adjustment
• 4 Volt High Voltage Pre-Out
• 1 x Audio Video Output
• 3 x Audio Video Input
• S-MOSFET 208 Watts Max (52 x 4)
• Supplied wireless card remote
(RM-X106)
• EQ7 (7-band EQ)
SPECIFICATIONS
AUDIO
• Output Power : 52W
• Pre-Out : Front + Rear + Sub Out
• EQ7 (7-band EQ)
• Bass/Treble
• Balance
• Fader
• ATT
• Preout output level : 4V
• Preout impedance : 220 Ohms
• Maximum output power (4O, 1kHz) :
52W
• Speaker impedance : 4~8 Ohms
AV INPUT
• AV IN (Video=Composite) : x3
• AV IN Level Adjustment
• Back Camera Video IN
• Back Camera : Reverse Link
q
AV OUTPUT
• AV Out (Video=Composite) : x1
BUS CONTROL
• TV Control (model) (XT-V70)
CD/DVD CHANGER CONTROL
• CD-TEXT Display/scroll (Main unit)
• DVD±R/RW/CD/CD-R/CD-RW/MP3
Playback
• Data Disc
• Multi Session
• Mix Mode
• CD-Extra : Playback only CDDA
• MP3 playback (Main unit)
• MP3 : ID3Tag Indication (Version, Title/
Artist/Album) (ID3ver2.4)
• MPEG1/2 Layer2 playback (Main unit)
• Dolby Digital playback (Main unit)
• dts2.0 playback (Main unit)
• Linear PCM playback (Main unit)
• DVD-Video playback (Main unit)
• DVD-VR playback (Main unit)
• DVD+VR playback (Main unit)
• VCD playback (Main unit)
• JPEG playback (Main unit)
• DVD LEVEL Adjust
DVD
• D/A Converter (bit) : 24bit
• Frequency response (Hz,dB) :
10~20k,+/-1dB
• Video Level : 1Vp-p+/-0.1V
CD
q
• Digital Filter (fs) : 8fs
• D/A Converter (bit) : 24bit
• Frequency response (Hz,dB) :
10~20k,+/-1dB
• S/N ratio (dB) : 100dB
• Separation (dB) : 80dB
• ESP : 2 sec
GENERAL
• Region : 4
• Dimensions (WxHxDmm) :
178 x 100 x 189
• Weight : 2.4kg
• Card Remote : RM-X106
MONITOR
PANEL DESIGN
• Panel Type : Double Din Slot
• Panel finish colour : Black
• Key Illumination : White
TUNER RECEIVER
• FM : Tuning range : 87.5-108.0MHz
• MW : Tuning range : 531-1602kHz
• FM : Total harmonic distortion (1kHz,
stereo) (%) : 0.5
• FM : Total harmonic distortion (1kHz,
mono) (%) : 0.3
• Preset : FM18/AM18
• Auto Memory : BTM
q
www.sony.com.au
110
OUTPUT POWER
OUTPUT
• CEA Rating : 60W x 2
• Rated/THD (@ 14.4 V, 20 Hz – 20kHz)
– 4 Ohms : 2 x 60W / 1.0%
(14.4V, 20 – 20kHz)
– 2 Ohms : 2 x 65W / 0.1%
(14.4V, 20 – 20kHz)
• Frequency Response : 5Hz – 50kHz
• Tolerance : +0 / -3dB
• Total Harmonic Distortion (@1kHz) :
0.005%
• CEA SN Ratio : 97dB
• Min Load Impedance/Ch : 2 Ohms
✔ Channel Configuration : 4ch/3ch
✔ MOSFET Power Supply (60W x 4)
✔ Toroidal Transformer
q
q
FEATURES
• ZR Series
• Channel Configuration : 2 Channel Mono
• Line – Low Level Input x 4
• Speaker – Hi Level Input x 4
• MOSFET Power Supply
• Toroidal Transformer
• Gold Plated Terminals
OUTPUT POWER
SPECIFICATIONS
MONITOR
• Angle Range : Linear/90°+30/-20
• Angle Default : 90°
• Slide Adjustment Function
• Slide Range : 5 step 0, 5, 10, 15,
20mm
• Slide Default : 20
• Tilt angle : 20°
• LCD Type : TFT Active Matrix
• Screen Aspect : 16 : 9
• Screen Diagonal : 7” (18cm)
• Resolution : 480 x 234
• Dimmer Method : Illumination Link,
13steps
• Screen Mode : Normal, Full, Wide, Zoom,
Cinema
• Colour System : NTSC / PAL
• Colour System Auto switch
• Contrast Ratio : 300:1
• CEA Rating : 60W x 4
• Rated/THD (@ 14.4 V, 20 Hz – 20kHz)
• 4 Ohms : 4 x 60W / 1.0%
(14.4V, 20 – 20kHz)
• 2 Ohms : 4 x 65W / 0.1%
(14.4V, 20 – 20kHz)
• Viewing Angle (Contrast Ratio
10:1) : Horizontal ±70°
• Vertical up 50° / down 65°”
• Brightness : 340cd / (LCD itself
430cd/)
AUDIO
• Output Power : 50W x 4
• Pre-Out (Front / Rear) : 2
• High Voltage Pre-Out (4V)
• Sub Out
• EQ7 (7-band EQ)
• Bass / Treble
• Balance
• Fader
• ATT
• SSM (Source Sound Memory) : EQ7
• Preout output level : 2V
• Preout impedance : 220 Ohms
• Maximum output power
(4O, 1kHz) : 50W
• ADHOC (THD : 5% 20Hz~20kHz,
4 Ohms, 4ch) : 23.2W
CD/DVD CHANGER CONTROL
• CD-TEXT Display / Scroll (Main Unit)
• DVD±R / RW / CD / CD-R / CD-RW /
VCD / MP3 Playback
• Data Disc : MP3 / JPEG
• Dolby Digital playback (Main Unit)
• dts2.0 playback (Main Unit)
q
q
q
6.2” HEADREST MONITOR $499.00 *
6.2” Touch TFT Screen
2 x AV Inputs
Wide Viewing Angle
Headrest Housing and Mounting Plate Included
FEATURES
• 6.2” TFT monitor
• Wide Viewing Angle
• PAL / NTSC Switchable
• Headrest Housing and
Mounting Plate Supplied
• 2 x Audio Video Input
• Low Pass Filter : 80Hz
• LPF Roll Off Rate : -18dB/oct
• Input sensitivity : 0.3 – 6Volts
SPECIFICATIONS
XVMB62
✔
✔
✔
✔
SPECIFICATIONS
q
Motorised 7” Touch TFT Screen
DVD / VCD / MP3 / CD Playback
2 x AV Inputs
1 x AV Outputs
FEATURES
• 200 Watts Max (50W x 4)
• 7” TFT Active Matrix 16 : 9 Display
• DVD±R / RW / CD / CD-R / CD-RW /
VCD / MP3 Playback
• Slimline Single DIN Chassis Design
• Fast Response touch screen control
• Adjustable angle and depth
• 24 bit D/A converter
• Front A/V input (cable included)
• Front Angle and Depth Adjustment
• Partial Detachable Faceplate
• 4 Volt F/R/Sub Preamp Outputs
• 1 x Audio Video Output
• 2 x Audio Video Input
• Supplied wireless card remote
(RM-X706)
SPECIFICATIONS
MONITOR
• Colour LCD Display
• System : TFT Active Matrix
• Screen Aspect : 16 : 9
• Screen Diagonal : 6.2”
• Screen Size (WxHmm) :
137.52 x 77.22
• Resolution : 480 x 234
• Dimmer : Manual / Auto
• Colour System : PAL / NTSC compatible
INPUT
GENERAL
• Current drain (@ Rated Power – 4 Ohms)
: 15 Amps (at 4 Ohms)
• Weight : 2kg
• Dimensions (WxHxDmm) :
321 x 55 x 200
4 CHANNEL ZR SERIES AMPLIFIER $349.00 *
SINGLE DIN AV MASTER WITH 7” SCREEN $1999.00 *
q
• DIN 45500 Rating (@ 14 V, THD 0.5 %)
– 4 Ohms : 2 x 60W
– 2 Ohms : 2 x 65W
• Maximum (@ 14.4 V)
– 4 Ohms : 2 x 110W
– 2 Ohms : 2 x 150W
XMZR604
• LCD Type : TFT Active Matrix
• Screen Aspect : 16 : 9
• Screen Diagonal : 7” (18cm)
• Resolution : 800 x 480
• Dimmer
• Screen Mode : Normal, Full, Wide, Zoom,
Cinema
• Colour System : NTSC/PAL
• Colour Type : Normally White
XAVC1
✔
✔
✔
✔
CAR & MARINE ENTERTAINMENT
XMZR602
DOUBLE DIN DVD HEADUNIT WITH 7” SCREEN $1999.00 *
• Current drain (for Operation
Mode for Monitor) : 550MA
• Dimensions (WxHxDmm) (Exclude
protrusion) : 164.2 x 29 x 106.6
• Power Requirement : 12V DC
• Operating Temperature : 0-45ºC
• Weight : 400g
CONNECTION BOX
• AV Input : AV x 2 (RCA)
*SRP is manufacturer’s suggested retail price only and is inclusive of GST. Prices effective as of 1st October 2007. Prices subject to change without notice.
• DIN 45500 Rating (@ 14 V, THD 0.5 %)
– 4 Ohms : 4 x 60W
– 2 Ohms : 4 x 65W
• Maximum (@ 14.4 V)
– 4 Ohms : 4 x 110W
– 2 Ohms : 4 x 150W
INPUT
• Low Pass Filter : 80Hz
• LPF Roll Off Rate : -18dB/oct
• Subsonic High Pass Filter : 80Hz
• Input sensitivity : 0.3 – 6Volts
OUTPUT
• Frequency Response : 5Hz – 50kHz
• Tolerance : +0 / -3dB
• Total Harmonic Distortion (@1kHz) :
0.005%
• CEA SN Ratio : 97dB
• Min Load Impedance/Ch : 2 Ohms
GENERAL
• Current drain (@ Rated Power – 4 Ohms)
: 33 Amps (at 4 Ohms)
• Weight : 3.1kg
• Dimensions (WxHxDmm) :
396 x 55 x 256
XM4S
XM1S
SMALL FOOTPRINT
4 CHANNEL
AMPLIFIER $399.00 *
SMALL FOOTPRINT
1 CHANNEL
AMPLIFIER $499.00 *
✔ Small Foot Print Design
✔ MOSFET Power Supply (50W x 4)
✔ Gold Plated Terminals
q
✔
✔
✔
✔
FEATURES
• Small Foot Print Design
• Channel Configuration : 1 Channel Mono
• Line – Low Level Input x 2
• Speaker – Hi Level Input x 2
• MOSFET Output Stage
• MOSFET Power Supply
• Bass Boost Control : 40Hz, 0-10dB
• Toroidal Transformer
• Gold Plated Terminals
• Active Thermal Control
Small Foot Print Design
MOSFET Power Supply (500W x 1)
Gold Plated Terminals
Active Thermal Control
FEATURES
• Small Foot Print Design
• Channel Configuration : 4 Channel
• Line – Low Level Input x 4
• Speaker – Hi Level Input x 4
• MOSFET Power Supply
• Bass Boost Control : 40Hz,
0-10dB (Rear)
• Toroidal Transformer
• Gold Plated Terminals
• Cooling Fan
INPUT
q
• Subsonic High Pass Filter : 80Hz (Front)
• Low Pass Filter : 80Hz (Rear)
• LPF Roll Off Rate : -18dB/oct
• Subsonic HPF, Roll Off Rate
• Balanced Input Circuit
• Input sensitivity : 0.3 – 6Volts
q
q
SPECIFICATIONS
OUTPUT
SPECIFICATIONS
OUTPUT POWER
• Frequency Response : 5-100kHz
• Tolerance : +0 / -3dB
• Signal to Noise Ratio (@ Rated Power)
: 106dB
• Total Harmonic Distortion (@1kHz) :
0.005%
• CEA SN Ratio : 90dB
• Min Load Impedance/Ch : 2 Ohms
OUTPUT POWER
• CEA Rating : 50W x 4
• Rated/THD (@ 14.4 V, 20 Hz – 20kHz)
– 4 Ohms : 4 x 50W / 0.04%
(14.4V, 20 – 20kHz)
– 2 Ohms : 4 x 60W / 1.0%
(14.4V, 20 – 20kHz)
• DIN 45500 Rating (@ 14 V, THD 0.5
%)
– 4 Ohms : 4 x 50W
– 2 Ohms : 4 x 60W
• Maximum (@ 14.4 V)
– 4 Ohms : 4 x 95W
– 2 Ohms : 4 x 125W
GENERAL
• Illumination : Blue
• Current drain (@ Rated Power –
4 Ohms) : 25 Amps (at 4 Ohms)
• Weight : 2.2kg
• Dimensions (WxHxDmm) :
223 x 43.5 x 196
q Refer to KEY TECHNOLOGY pages for detailed information.
• CEA Rating : 280W x 1
• Rated / THD (@ 14.4 V,
20 Hz-300kHz)
– 4 Ohms : 1 x 290W / 0.2%
– 2 Ohms : 1 x 500W / 1.0%
(14.4V, 100Hz)
• DIN 45500 Rating
(@ 14 V, THD 0.5 %)
– 4 Ohms : 1 x 280W
– 2 Ohms : 1 x 500W
INPUT
• Low Pass Filter : 50-300Hz (Variable)
• LPF Roll Off Rate : -12 dB/oct
• Subsonic HPF, Roll Off Rate
• Balanced Input Circuit
• Input sensitivity : 0.3-6Volts
• Maximum (@ 14.4 V)
– 4 Ohms : 1 x 600W
– 2 Ohms : 1 x 900W
OUTPUT
• Frequency Response : 5Hz – 300Hz
• Tolerance : +0 / -3dB
• Signal to Noise Ratio
(@ Rated Power) : 90dB
• Total Harmonic Distortion
(@1kHz) : 0.1% (50Hz)
• CEA SN Ratio : 65dB
• Min Load Impedance/Ch : 2 Ohms
GENERAL
• Illumination : Blue
• Current drain (@ Rated Power 4 Ohms
1kHz) : 30 Amps (at 4 Ohms)
• Weight : 2.3kg
• Dimensions (WxHxDmm) :
223 x 43.5 x 196
www.sony.com.au
CAR & MARINE ENTERTAINMENT
q
XAVW1
111
XSL120P5
BOX120P5B
16CM 2-WAY
SPEAKERS $99.00 *
12" PENTAGONAL
SUBWOOFER $149.00 *
XSL120P5 IN SONY
ENCLOSURE $199.00 *
FEATURES
• 2-Way – 190W Max
• H.O.P Woofer Cone
• Rubber Coated Cloth Surround
• HDLD (High Density Layered
Diaphragm) Midrange
FEATURES
• Size : 30cm (12")
• Peak power : 1000W
• Rated power : 300W
• Enclosure Type Subwoofer
• Single Voice Coil
• Injected Polypropylene Pentagonal Cone
• Ferrite Magnet
• Stroke Stabiliser Rubber Surround
FEATURES
• XSL120P5 installed into a new Sony
enclosure
• Mirrored sides with Sony logo
• “Serious about sound” embroidery
• Durable non-slip carpet finish
FEATURES
• 2-Way – 130W Max
• H.O.P Woofer Cone
• Rubber Coated Cloth Surround
• HDLD (High Density Layered
Diaphragm) Midrange
q
• Material : High Oriented Polyolefin
• Type : Cone
• Surround : Rubber Coated Cloth
Surround
• Size : 10cm
• Magnet : Ferrite Magnet
SPECIFICATIONS
• Size : 16cm (6.5”)
• Peak power : 190W
• Rated power : 40W
• Frequency response : 35Hz-22kHz
• Sensitivity : 90dB/W/m
• Grille (included)
• Weight : 0.4kg
q
WOOFER
• Material : High Oriented Polyolefin
• Type : Cone
• Surround : Rubber Coated Cloth
Surround
• Size : 16cm
• Magnet : Ferrite Magnet
SPECIFICATIONS
• Impedance : 4 Ohms
• Sensitivity : 89dB/W/m
• Frequency response : 22Hz-2.5kHz
• Weight : 4.35kg
• Suggested Enclosure : 42.5litre /
1.5 cu.ft (Sealed)
MID-RANGE
GENERAL
• Material : HDLD (High Density Layered
Diaphragm)
• Type : Balanced Dome
• Size : 2.5cm
• Magnet : Neodymium
• Material : HDLD (High Density Layered
Diaphragm)
• Type : Balanced Dome
• Size : 3.5cm
• Magnet : Neodymium
• Grille (included)
• Weight : 0.65kg
XSGTF6935B
XSV6942A
XSL124P5B
BOX124P5B
6X9 3-WAY
SPEAKERS $129.00 *
6X9 4-WAY
SPEAKERS $169.00 *
12" HIGH POWER
PENTAGONAL
SUBWOOFER $199.00 *
XSL124P5B IN SLIM
SONY ENCLOSURE
$249.00 *
FEATURES
• H.O.P Woofer Cone
• Cloth Surround
• Paper Midrange
• Film Super Tweeter
FEATURES
• Peak Power : 1300W
• Rated Power : 380W
• Frequency Response : 18Hz-2kHz
• Impedence : 4 Ohms
• Sensitivity : 89dB/W/m
• Injected Polypropylene Diaphragm
• Ferrite Magnet
• Rubber Edge
• New Basket Cover and Capless Design
FEATURES
• XSL124P5B installed into a new ported
Sony enclosure
• Narrow depth and angled back to take
up less boot space
• Grille to protect the subwoofer
diaphragm
• Brushed aluminium “Serious about
sound” badge
• Mirrored side with Sony logo
• Durable, non slip carpet finish
FEATURES
• 3-Way – 300W Max
• H.O.P Woofer Cone
• Rubber Coated Cloth Surround
• HDLD (High Density Layered
Diaphragm) Midrange
• Piezo Tweeter
SPECIFICATIONS
• Size : 16cm x 24cm (6”x9”)
• Peak power : 300W
• Rated power : 60W
• Frequency response : 27-30kHz
• Sensitivity : 93dB/W/m
q
WOOFER
GENERAL
MID-RANGE
• Material : HDLD (High Density Layered
Diaphragm)
• Type : Balanced Dome
• Size : 6cm
• Magnet : Ferrite Magnet
www.sony.com.au
q
SPECIFICATIONS
• Size : 10cm (4”)
• Peak power : 130W
• Rated power : 30W
• Frequency response : 45-25kHz
• Sensitivity : 88dB/W/m
MID-RANGE
112
q
q
TWEETER
• Type : Piezo
• Size : 1cm
q
WOOFER
• Material : High Oriented Polyolefin
• Type : Cone
• Surround : Rubber Coated Cloth
Surround
• Size : 16cm x 24cm
• Magnet : Ferrite Magnet
SPECIFICATIONS
• Size : 16cm x 24cm (6" x 9")
• Peak power : 320W
• Rated power : 80W
• Frequency response : 25Hz-34kHz
• Sensitivity : 93db/W/m
SPECIFICATIONS
• Size : 30cm (12”)
• Type : Enclosure
• Peak Power : 1300W
• Rated Power : 380W
• Impedance : 4 Ohms
• Frequency Response : 18-2kHz
• Sensitivity : 89dB
• Diaphragm Material : Injected
Polypropylene
• Magnet Material : Ferrite
• Enclosure Volume : 27.3litre / 0.96cu.ft
• Weight : 4.5kg
GENERAL
• Grille (included)
• Weight : 0.65kg
XSGS160
XSL154P5B
XSL12S
BOX12SLIM
COMPONENT
SPEAKERS $149.00 *
15" HIGH POWER
PENTAGONAL
SUBWOOFER $249.00 *
12" SLIM
PENTAGONAL
SUBWOOFER $249.00 *
XSL12S IN SLIM
SONY ENCLOSURE
$299.00 *
FEATURES
• H.O.P Woofer Cone
• Rubber Coated Cloth Surround
• Polyester Soft Dome Tweeter
• In-line Passive Cross-Over
• Mounting Accessories
FEATURES
• New Basket Cover and Capless Design
• Peak Power : 1500W
• Rated Power : 450W
• Frequency Response : 15Hz-2kHz
• Impedence : 4 Ohms
• Sensitivity : 89dB/W/m
• Injected Polypropylene Diaphragm
• Ferrite Magnet
• Rubber Edge
FEATURES
• New Shallow Sub Design
• Peak Power : 1500W
• Rated Power : 380W
• Frequency Response : 18Hz – 2kHz
• Impedence : 4 Ohms
• Sensitivity : 89dB/W/m
• Injected Polypropylene Diaphragm
• Ferrite Magnet
• Rubber Edge
FEATURES
• XSL12S installed into a new slim Sony
enclosure
• Narrow depth and angled back to take
up less boot space
• Grille to protect the subwoofer
diaphragm
• Brushed aluminium “Serious about
sound” badge
• Durable, non slip carpet finish
SPECIFICATIONS
• Size : 38cm (15”)
• Type : Enclosure
• Peak Power : 1500W
• Rated Power : 450W
• Impedance : 4 Ohms
• Frequency Response (Hz) : 15-2k
• Sensitivity (dB) : 89
• Diaphragm Material : Injected
Polypropylene
SPECIFICATIONS
• Size : 30cm (12”)
• Type : Enclosure
• Peak Power : 1500W
• Rated Power : 380W
• Impedance ( Ohms) : 4
• Frequency Response (Hz) : 18-2k
• Sensitivity (dB) : 89
• Diaphragm Material : Injected
Polypropylene
SPECIFICATIONS
• Size : 16cm (6")
• Peak power : 200W
• Rated power : 50W
• Freq response : 30Hz-26kHz
• Sensitivity : 91db/W/m
• Cross Over Freq : 5kHz
• Roll Off Rate : 12dB/Oct
CAR & MARINE ENTERTAINMENT
XSGTF1625B
10CM 2-WAY
SPEAKERS $79.00 *
• Magnet Material : Ferrite
• Enclosure Volume : 61.1litre / 2.15cu.ft
• Weight : 6kg
*SRP is manufacturer’s suggested retail price only and is inclusive of GST. Prices effective as of 1st October 2007. Prices subject to change without notice.
• Magnet Material : Ferrite
• Enclosure Volume : 26.9litre / 0.95cu.ft
• Weight : 3.9kg
q Refer to KEY TECHNOLOGY pages for detailed information.
www.sony.com.au
CAR & MARINE ENTERTAINMENT
q
XSGTF1025B
113
RMX55M
10” MARINE
SUBWOOFER $149.00 *
WIRED MARINE
CONTROL WITH LCD
DISPLAY $179.00 *
✔ S-MOSFET 208 Watts Max
✔ Splash proof
✔ CD-R/RW / MP3 / WMA§ / ATRAC / AAC§ Playback
FEATURES
• 52W x 4 S-MOSFET Power
• CD-R/RW / MP3 / WMA§ / ATRAC / AAC§
Playback
• 24 Bit Digital to Analogue Converter
• Front + Rear/Sub Switchable Pre-Out
• 13 seg W.LED LCD Display
• DSO2
• EQ3 Stage 2
• SSIR-EXA Tuner
• Preset : FM18/AM12
• Changer Control
• Remote Included
• Rotary Commander Optional
• White
SPECIFICATIONS
q
CD DECK
• DRIVE-S Mechanism
• CD-R/RW / MP3 / WMA§ / ATRAC
/ AAC§ Playback
• Playback modes :
Repeat / Shuffle / Pause
• Max Installation Angle : 45°
TUNER RECEIVER
• Tuner Type : SSIR-EXA
• Preset No : FM18 / AM12
• FM Tuning Range : 87.5-107.9,
87.5-108.0MHz
• AM Tuning Range : 531-1602,
530-1710kHz
AUDIO PROCESSING
• Max Output Power
(@4 Ohm, 1 kHz) : 52w
• Pre-Out : 1
• Pre-Out Voltage : 2
• Pre-Out Impedance : 220
• DAC : 24 Bit
• DSO : DSO2
• EQ Type : EQ3 Stage 2
• Bass/Treble : Low / Mid / High
• Speaker Impedance : 4 Ohms
Also available in Silver (CDXHS70MS)
• Panel Type : Fixed Weather Resistant
• Panel Finish Colour : White
• Key Illumination (Colour) : Red
• Display Type (Back light Colour/LCD type)
: 13 seg W.LED LCD
• Dimmer Control : Auto
SPECIFICATIONS
• Size : 25cm (10”)
• Type : Infinite Baffle
• Peak Power : 800W
• Rated Power : 200W
• Impedance ( Ohms) : 6
• Frequency Response (Hz) : 27-3k
• Sensitivity (dB) : 88
MARINE FEATURE
• Conformal coating for circuit board
• Weather resistant resin/paint for
front panel
• Plastic cover on the top of deck
• Anti-rusted screw for front and sub panel
• Splash-proof (IPx5)
• UV Exposure (ASTM G154)
• Salt Fog Exposure (ASTM B117)
GMD616
SPLASH PROOF
MARINE COVER FOR
CAR HEAD UNIT $99.00 *
q
q
✔ MOSFET Power supply (60W x 4)
✔ Toroidal Transformer
✔ Gold plated terminals
• Maximum (@ 14.4 V)
– 4 Ohm : 4 x 110W
– 2 Ohm : 4 x 150W
q
q
FEATURES
• Marine Amplifier
• Channel Configuration : 4 Channel
• Line – Low Level Input x 4
• Speaker – Hi Level Input x 4
• MOSFET Power Supply
• Toroidal Transformer
• Gold Plated Terminals
SPECIFICATIONS
OUTPUT
GENERAL
MARINE FEATURE
OUTPUT POWER
• Frequency Response : 5Hz – 300Hz,
5-50kHz
• Tolerance : +0 / -3dB, +0/-3dB
• Signal to Noise Ratio (@ Rated Power) :
100dB 110dB
• Total Harmonic Distortion (@1 kHz) :
< 0.04% 0.005%
• CEA SN Ratio : 97dB
• Min Load Impedance/Ch : 2 Ohm
• Current drain (@ Rated Power – 4 Ohm) :
55 Amps (at 2 Ohm),
32 Amps (at 4 Ohm)
• Fuse Rating : 40 Amps x 2
• Weight : 3.2kg
• Dimensions (WxHxDmm) :
401 x 55 x 264
• Conformal Coated Circuit Boat
• Anti-Rust Screw for Surface
• Anti-Rust Screw for Mounting
• Gold Plated Terminal
INPUT
• Low Pass Filter : 80Hz(Rear)
• LPF Roll Off Rate : -18dB/oct
• Subsonic High Pass Filter :
• Balanced Input Circuit : Yes
• Input sensitivity (V) : 0.3-6
XSMP1610W
XSMP1620W
16 CM MARINE
SPEAKERS $99.00 *
16 CM 2-WAY
MARINE SPEAKERS
$149.00 *
SPECIFICATIONS
• Size : 16cm (6.5”)
• Peak power : 140W
• Rated power : 40W
• Frequency response : 40Hz-20kHz
• Sensitivity : 90dB/W/m
WOOFER
• Material : Polypropylene
• Type : Cone
• Surround : Cloth
• Size : 16cm (6.5”)
• Magnet : Ferrite Magnet
GENERAL
• Grille (incl.)
• Weight : 0.65kg
• Anti-Rust Screw for Mounting
• Splash-proof (IPx5) : Front Face
• UV Exposure (ASTM G154 : Front Face
• Salt Fog Exposure (ASTM B117) : Front
Face
Also available in Black (XSMP1610B)
SPECIFICATIONS
WATER RESISTANCE :
• Meets ASTM B117 salt/fog exposure
standard
• Meets ASTM G154 UV exposure
standard
• Meets Ipx7 (International Protection
ratings against liquids)
DIMENSIONS :
• Diaphragm Material : Injected
Polypropylene
• Magnet Material : Ferrite
• Weight : 3.9
• Chassis Size : 965mm (3.8”)
• Cutout Size : 787mm (3.1”)
• Mounting Depth : 356mm (1.4”)
• Mounting Height : 229mm (0.9”)
FEATURES
• Splash Cover for Head Units
• Front mask opening type for
easy operation
• Durable Injection Molded
Polycarbonate frame
• Weatherproofed with O-Ring Seal
• Compatible with all 2-shaft and
DIN-sized head units
The marine range is the latest in mobile entertainment
technology. The conditions on any boat can be harsh.
Besides the obvious water threat, corrosion through sea salt and direct UV exposure
are harmful to sensitive electronics.
FEATURES
• 2-Way – 160W Max
• Polypropylene Cones
• Water Resistant Design
• UV Resistant
• Cone Tweeter
MARINE FEATURES
✔ Splash proof
DID YOU KNOW?
✔ Splash proof
FEATURES
• 140W Max
• Polypropylene Cones
• Water Resistant Design
• UV Resistant
q
§Non DRM
MARINE AMPLIFIER $270.00 *
✔ Splash proof
www.sony.com.au
DISPLAY PANEL
FEATURES
• Marine Subwoofer
• Peak Power : 800W
• Rated Power : 200W
• Frequency Response : 27Hz – 3kHz
• Impedance : 6 Ohms
• Sensitivity : 88dB/W/m
• Injected Polypropylene Diaphragm
• Ferrite Magnet
• Rubber Edge
XM604M
• CEA Rating : 60W x 4
• DIN 45500 Rating (@ 14 V, THD 0.5 %)
– 4 Ohm : 4 x 60W
– 2 Ohm : 4 x 70W
Rated/THD (@ 14.4 V, 20 Hz – 20 kHz)
– 4 Ohm : 4 x 60W / 1.0%
(14.4V, 20 – 20kHz)
– 2 Ohm : 4 x 70W / 1.0%
(14.4V, 20 – 20kHz)
114
✔ Splash proof
✔ No subwoofer enclosure required
CAR & MARINE ENTERTAINMENT
q
XSL100P5M
MARINE CD RECEIVER $499.00 *
SPECIFICATIONS
• Size : 16cm (6.5”)
• Peak power : 160W
• Rated power : 45W
• Frequency response : 35Hz-26kHz
• Sensitivity : 91dB/W/m
TWEETER
WOOFER
MARINE FEATURES
• Material : Polypropylene
• Type : Cone
• Surround : Rubber
• Size : 16cm (6.5”)
• Magnet : Ferrite Magnet
• Anti-Rust Screw for Mounting
• Splash-proof (IPx5) : Front Face
• UV Exposure (ASTM G154 : Front Face
• Salt Fog Exposure (ASTM B117) :
Front Face
• Type : Cone
• Size : 5.2cm
GENERAL
• Grille (incl.)
• Weight : 0.95kg
The Sony Marine range has been designed specifically for these harsh conditions.
The CDXHR70MW CD head-unit features a water-resistant front panel that can handle
severe splashing. You can fold up the front panel to seal out moisture completely, and
the internal circuitry has also been treated with a protective coating. The speakers are often the
most exposed in these environments, for this reason both the speakers and the sub have been designed to
stand up to the harmful effects of direct UV rays, water and salt. This includes rust proof baskets and rubbercoated tinsel leads (the lead between the terminals and the speaker driver).
If you prefer to mount your equipment in the protection of the cabin, you can use the optional wired remote
control. It comes with an 18-foot (5.4m) cable. This allows for safe mounting of your equipment out of the
elements while the remote weathers the storm. The remote has been extensively tested with UV, salt and is
water resistant.
Also available in Black (XSMP1620B)
*SRP is manufacturer’s suggested retail price only and is inclusive of GST. Prices effective as of 1st October 2007. Prices subject to change without notice.
q Refer to KEY TECHNOLOGY pages for detailed information.
www.sony.com.au
CAR & MARINE ENTERTAINMENT
q
CDXHS70MW
115
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
