Safety Information

Read the operating instructions for the unit and all other components of your car audio system carefully before using the system. They contain instructions about how to use the system in a safe and effective manner. Panasonic assumes no responsibility for any problems resulting from failure to observe the instructions given in this manual.

This manual uses pictographs to show you how to use the product safely and to alert you to potential dangers resulting from improper connections and operations. The meanings of the pictographs are explained below. It is important that you fully understand the meanings of the pictographs in order to use this manual and the system properly.

Warning

This pictograph intends to alert you to the presence of important operating instructions and installation instructions. Failure to heed the instructions may result in severe injury or death.

Caution

This pictograph intends to alert you to the presence of important operating instructions and installation instructions. Failure to heed the instructions may result in injury or material damage.

Warning

Observe the following warnings when using this unit.

The driver should neither watch the display nor

operate the system while driving.

Watching the display or operating the system will distract the driver from looking ahead of the vehicle and can cause accidents. Always stop the vehicle in a safe location and use the parking brake before watching the display or operating the system.

Use the proper power supply.

This product is designed for operation with a negative grounded 12 V DC battery system. Never operate this product with other battery systems, especially a 24 V DC battery system.

Keep batteries and insulation film out of reach of

infants.

Batteries and insulation film can be ingested, so keep them out of the reach of infants. If an infant ingests a battery or insulation film, please seek immediate medical attention.

Protect the Deck Mechanism.

Do not insert any foreign objects into the slot of this unit.

Do not disassemble or modify the unit.

Do not disassemble, modify the unit or attempt to repair the product yourself. If the product needs to be repaired, consult your dealer or an authorized Panasonic Servicenter.

Do not use the unit when it is out of order.

If the unit is out of order (no power, no sound) or in an abnormal state (has foreign matter in it, is exposed to water, is smoking, or smells), turn it off immediately and consult your dealer.

The remote control unit should not lie about in the

car.

If the remote control unit lies about, it could fall on the floor while driving, get wedged under the brake pedal, and lead to a traffic accident.

Refer fuse replacement to qualified service person-

nel.

When the fuse burns out, eliminate the cause and have it replaced with the fuse prescribed for this unit by a qualified service engineer. Incorrect replacement of the fuse may lead to smoke, fire, and damage to the product.

Observe the following warnings when installing.

Disconnect the lead from the negative (–) battery

terminal before installation.

Wiring and installation with the negative (–) battery terminal connected may cause electrical shock and injury due to a short circuit.

Some cars equipped with the electrical safety system have specific procedures of battery terminal disconnection.

FAILURE TO FOLLOW THE PROCEDURE MAY LEAD TO THE

UNINTENDED ACTIVATION OF THE ELECTRICAL SAFETY

SYSTEM RESULTING IN DAMAGE TO THE VEHICLE AND

PERSONAL INJURY OR DEATH.

Never use safety-related components for installa-

tion, grounding, and other such functions.

Do not use safety-related vehicle components (fuel tank, brake, suspension, steering wheel, pedals, airbag, etc.) for wiring or fixing the product or its accessories.

Installing the product on the air bag cover or in a

location where it interferes with airbag operation is prohibited.

Check for piping, gasoline tank, electric wiring, and

other items before installing the product.

If you need to open a hole in the vehicle chassis to attach or wire the product, first check where the wire harness, gasoline tank, and electric wiring are located. Then open the hole from outside if possible.

Never install the product in a location where it inter-

feres with your field of vision.

Never have the power cord branched to supply other

equipment with power.

After installation and wiring, you should check the

normal operation of other electrical equipment.

The continuation of their using in abnormal conditions may cause fire, electrical shock or a traffic accident.

In the case of installation to an airbag-equipping

car, confirm warnings and cautions of the vehicle manufacturer before installation.

Make sure the leads do not interfere with driving or

getting in and out of the vehicle.

Insulate all exposed wires to prevent short circuit-

ing.

CQ-C9901U/C9801U/C9701U

Caution

Observe the following cautions when using this unit.

Keep the sound volume at an appropriate level.

Keep the volume level low enough to be aware of road and traffic conditions while driving.

Do not insert or allow your hand or fingers to be

caught in the unit.

To prevent injury, do not get your hand or fingers caught in moving parts or in the disc slot. Especially watch out for infants.

This unit is designed for use exclusively in automo-

biles.

Do not operate the unit for a prolonged period with

the engine turned off.

Operating the audio system for a long period of time with the engine turned off will drain the battery.

Do not expose the unit to direct sunlight or exces-

sive heat.

Otherwise these will raise the interior temperature of the unit, and it may lead to smoke, fire, or other damage to the unit.

Do not use the product where it is exposed to water,

moisture, or dust.

Exposure of the unit to water, moisture, or dust may lead to smoke, fire, or other damage to the unit. Make especially sure that the unit does not get wet in car washes or on rainy days.

Observe the following cautions when installing.

Refer wiring and installation to qualified service

personnel.

Installation of this unit requires special skills and experience.

For maximum safety, have it installed by your dealer.

Panasonic is not liable for any problems resulting from your own installation of the unit.

Follow the instructions to install and wire the prod-

uct.

Not following the instructions to properly install and wire the product could cause an accident or fire.

Take care not to damage the leads.

When wiring, take care not to damage the leads. Prevent them from getting caught in the vehicle chassis, screws, and moving parts such as seat rails. Do not scratch, pull, bend or twist the leads. Do not run them near heat sources or place heavy objects on them. If leads must be run over sharp metal edges, protect the leads by winding them with vinyl tape or similar protection.

Use the designated parts and tools for installation.

Use the supplied or designated parts and appropriate tools to install the product. The use of parts other than those supplied or designated may result in internal damage to the unit.

Faulty installation may lead to an accident, a malfunction or fire.

Do not block the air vent or the cooling plate of the

unit.

Blocking these parts will cause the interior of the unit to overheat and will result in fire or other damage.

Do not install the product where it is exposed to

strong vibrations or is unstable.

Avoid slanted or strongly curved surfaces for installation. If the installation is not stable, the unit may fall down while driving and this can lead to an accident or injury.

Installation Angle

The product should be installed in a horizontal position with the front end up at a convenient angle, but not more than

30˚.

The user should bear in mind that in some areas there may be restrictions on how and where this unit must be installed.

Consult your dealer for further details.

Wear gloves for safety. Make sure that wiring is

completed before installation.

To prevent damage to the unit, do not connect the

power connector until the whole wiring is completed.

Do not connect more than one speaker to one set of

speaker leads. (except for connecting to a tweeter)

Observe the following cautions when handling the batteries for the remote control unit.

Use only specified battery (CR2025).

Match the polarity of the battery with the (+) and (–) marks in the battery case.

Replace dead battery as soon as possible.

Remove the battery from the remote control unit when not using it for an extended period of time.

Insulate the battery (by placing them in a plastic bag or covering them with vinyl tape) before disposal or storage.

Dispose of the battery according to the local regulations.

Do not disassemble, recharge, heat or short the battery. Do not throw a battery into a fire or water.

In case of battery leakage

Thoroughly wipe the battery liquid off the battery case and insert new battery.

If any part of your body or clothing comes into contact with battery liquid, wash it with plenty of water.

If battery liquid comes into contact with your eyes, wash them with plenty of water and get immediate medical attention.

CQ-C9901U/C9801U/C9701U

3

Safety Information

Caution

THIS PRODUCT IS A CLASS I LASER PRODUCT.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE

OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN

MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR BY YOUR-

SELF. REFER SERVICING TO QUALIFIED PERSONNEL.

The following applies only in the U.S.A.

Part 15 of the FCC Rules

FCC Warning:

Any unauthorized changes or modifications to this equipment would void the user's authority to operate this device.

Before Reading These Instructions

XXXXXXXXXXXXXXX

XXXXXXXXXXXXXXXXX

XXXXXXXXXXXXXXXX

OO-OOOOO

Operating Instructions

(YEFM285646)

Installation Instructions

(YEFM293921)

Instruction kit

Q'ty: 1 set

Owners Information

Card

POWER

SOURCE

SRC

SET

BAND

MENU

MUTE

RANDOM SCAN REPEAT

TUNE

NUMBER

CAR AUDIO

TUNE

DISP

Remote Control Unit

(Includes a battery:

CR2025)

(EUR7641010)

Q'ty: 1

Lock Cancel Plate

Q'ty: 2

Mounting Bolt

Q'ty: 1

Tapping Screw

(5 mmø x 16 mm)

Q'ty: 1

Installation kit (YEP0FZ5701)

Hex. Nut

(5 mmø)

Q'ty: 1

Before Reading These Instructions

Panasonic welcomes you to our constantly growing family of electronic products owners.

We endeavor to give you the advantages of precise electronic and mechanical engineering, manufactured with carefully selected components, and assembled by people who are proud of the reputation their work has built for our company. We know this product will bring you many hours of enjoyment, and after you discover the quality, value and reliability we have built into it, you too will be proud to be a member of our family.

CQ-C9901U

WMA MP3 CD Player/Receiver with 512 Color OEL

(Organic electroluminescence) Display

CQ-C9801U/C9701U

WMA MP3 CD Player/Receiver with Full Dot Matrix

Display

This operating instruction manual is for 3 models CQ-C9901U, CQ-C9801U and CQ-C9701U.

The difference among these models’ are mentioned below.

All screens and main body illustrations in this book represent CQ-C9901U unless otherwise specified.

Features

Display unit

Models

CQ-C9901U

512 Color OEL

CQ-C9801U / CQ-C9701U

Full Dot Matrix (Light Blue)

Trim Plate

(YEFC05654):

CQ-C9801U, C9701U

(YEFC05655):

CQ-C9901U

Q'ty: 1

Mounting Collar

(YEFX0217222)

Q'ty: 1

Removable Face Plate

Case

(YEFA131646)

Q'ty: 1

Power Connector

(YEAJ02871)

Q'ty: 1

Rear Support Strap

(YEFG04019)

Q'ty: 1

Notes:

¡

The number in parenthesis underneath each accessory part name is the part number for maintenance and service.

¡

Accessories and their parts numbers are subject to modification without prior notice due to improvements.

¡

Mounting Collar and Trim Plate are mounted on the main unit at shipment.

CQ-C9901U/C9801U/C9701U

5 4

CQ-C9901U/C9801U/C9701U

Service and Warranty

U.S.A.

Obtain Product Information and Operating Assistance; locate your nearest Dealer or Servicenter; purchase Parts and Accessories; or make Customer Service and

Literature requests by visiting our Web Site at:

http://www.panasonic.com/support

or, contact us via the web at:

http://www.panasonic.com/contactinfo

You may also contact us directly at:

1-800-211-PANA (7262),

Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST.

For hearing or speech impaired TTY users, TTY : 1-877-

833-8855

Accessory Purchases:

Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at:

http://www.pasc.panasonic.com

or, send your request by E-mail to:

[email protected]

You may also contact us directly at:

1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)

(Monday-Friday 9 am to 8 pm, EST.)

Panasonic Services Company

20421 84th Avenue South, Kent, WA 98032

(We accept Visa, MasterCard, Discover Card, American

Express, and Personal Checks)

For hearing or speech impaired TTY users, TTY : 1-886-

605-1277

Service in Puerto Rico

Matsushita Electric of Puerto Rico, Inc.

Panasonic Sales Company

Factory Servicenter:

Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial Park,

Carolina, Puerto Rico 00985

Phone (787) 750-4300, Fax (787) 768-2910

CANADA

WARRANTY SERVICE

For product operation and information assistance, please contact your Dealer or our Customer Care Centre at:

Telephone #: (905) 624-5505 Fax #: (905) 238-2360

Web: www.panasonic.ca

For product repairs, please contact one of the following:

•Your Dealer who will inform you of an authorized

Servicentre nearest you.

•Our Customer Care Centre at (905) 624-5505 or www.panasonic.ca

•A Panasonic Factory Servicentre listed below:

Richmond, British

Columbia

Panasonic Canada Inc.

12111 Riverside Way

Richmond, BC V6W 1K8

Tel: (604) 278-4211

Fax: (604) 278-5627

Calgary, Alberta

Panasonic Canada Inc.

6835-8 th St. N. E. Calgary,

AB T2E 7H7

Tel: (403) 295-3955

Fax: (403) 274-5493

Mississauga, Ontario

Panasonic Canada Inc.

5770 Ambler Dr.

Mississauga, ON L4W 2T3

Tel: (905) 624-8447

Fax: (905) 238-2418

Lachine, Quebec

Panasonic Canada Inc.

3075, rue Louis A. Amos

Lachine, QC H8T 1C4

Tel: (514) 633-8684

Fax: (514) 633-8020

U.S.A.

PANASONIC CONSUMER ELECTRONICS COMPANY,

DIVISION OF MATSUSHITA ELECTRIC CORPORATION OF AMERICA

One Panasonic Way, Secaucus, New Jersey 07094

PANASONIC SALES COMPANY,

DIVISION OF MATSUSHITA ELECTRIC OF PUERTO RICO, INC.

Ave. 65 de infanteria, Km. 9.5, San Gabriel Industrial Park

Carolina, Puerto Rico 00985

PANASONIC AUTO PRODUCTS

LIMITED WARRANTY

LIMITED WARRANTY COVERAGE

If your product does not work properly because of defects in materials and workmanship.

Panasonic Consumer Electronics Company or Panasonic Sales Company

(collectively referred to as “the warrantor”) will, for the length of the period indicated in the chart below, which starts with the date of original purchase (“warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or refurbished product. The decision to repair or replace will be made by the warrantor.

Categories Parts Labor

Audio Components (except items listed below) One (1) Year One (1) Year

MXE Series Audio Components (except items listed below)

Speakers

Two (2) Years Two (2) Years

One (1) Year Not Applicable

Accessories (in exchange for defective items) Ninety (90) Days Not Applicable

Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the exclusions may not apply to you.

This warranty gives you specific legal rights and you may also have other rights which vary from state to state. If a problem with this product develops during or after the warranty period, you may contact your dealer or Servicenter. If the problem is not handled to your satisfaction, then write to warrantor’s Consumer Affairs Department at the addresses of the warrantor.

PARTS AND SERVICE WHICH ARE NOT COVERED BY THIS LIMITED

WARRANTY ARE YOUR RESPONSIBILITY.

Customer’s Record

Model

No.

Serial

No.

Dealer’s

No.

Code

No.

Dealer’s

Address

Date of

Purchase

During the “Labor” warranty period, there will be no charge for labor.

During the “Parts” warranty period, there will be no charge for parts.

You must carry in or mail in your product during the warranty period.

If non-rechargeable batteries are included, they are not warranted.

This warranty only applies to products purchased and serviced in the

United States or Puerto Rico. This warranty is extended only to the original purchaser of a new product which was not sold “as is”. A purchase receipt or other proof of the original purchase date is required for warranty service.

CARRY-IN OR MAIL-IN SERVICE

For Carry-In or Mail-In Service in the United States, call 1-800-211-

PANA (7262) or visit

Panasonic Web Site: http://www.panasonic.com

For assistance in Puerto Rico, call Panasonic Sales Company (787)-

750-4300 or fax (787)-768-2910.

LIMITED WARRANTY LIMITS AND EXCLUSIONS

This warranty ONLY COVERS failures due to defects in materials and workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which occurred during shipment, failures which are caused by products not supplied by the warrantor, failures which result from accident, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustment, maladjustment of consumer control, improper maintenance, improper antenna, inadequate signal reception or pickup, power line surge, improper voltage supply, lightning, modification, commercial use (such as use in hotels, offices, restaurants, or other business uses) or rental use of the product, or service by anyone other than the technician from Factory Servicenter or other authorized service centers, or damage that is attributable to acts of God.

THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER

“LIMITED WARRANTY COVERAGE”. THE WARRANTOR IS NOT

LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULT-

ING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY

BREACH OF THIS WARRANTY. (As examples, this excludes damages for lost time, cost of having someone remove or re-install an installed unit if applicable, travel to and from the sevicer, and loss of media, data or other memory contents. The items listed are not exclusive, but are for illustration only.) ALL EXPRESS AND IMPLIED WAR-

RANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY,

ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.

CANADA

Panasonic Canada Inc.

5770 Ambler Drive, Mississauga Ontario L4W 2T3

PANASONIC PRODUCT LIMITED WARRANTY

Panasonic Canada Inc. warrants this product to be free from defects in materials and workmanship and agrees to remedy any such defect for a period as stated below from the date of original purchase.

CAR AUDIO PRODUCT – ONE (1) YEAR, PARTS AND LABOUR

(The labour to install or remove the product is not warranted)

LIMITATIONS AND EXCLUSIONS

This warranty does not apply to products purchased outside Canada or to any product which has been improperly installed, subjected to usage for which the product was not designed, misused or abused, damaged during shipping, or which has been altered or repaired in any way that affects the reliability or detracts from the performance, nor does it cover any product which is used commercially. Dry cell batteries are also excluded from coverage under this warranty.

This warranty is extended to the original end user purchaser only. A purchase receipt or other proof of the original purchase date is required before warranty service is performed.

THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTIC-

ULAR PURPOSE.

IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR ANY

SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES.

In certain instances, some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, or the exclusion of implied warranties, so the above limitations and exclusions may not be applicable.

IF YOU SHIP THE PRODUCT TO A SERVICENTRE

Carefully pack and send prepaid, adequately insured and preferably in the original carton.

Include details of the defect claimed, and proof of the date of original purchase.

CQ-C9901U/C9801U/C9701U

7 6

CQ-C9901U/C9801U/C9701U

8

Features

Full Digital CD Receiver

The CQ-C9901U/C9801U/C9701U uses Radio DSP for digital conversion and processing of FM/AM signals, and a digital amp to provide amplification of the digital data.

With this technology, Panasonic achieves full digital processing of radio and CD signals from input to speaker output. This means faithful reproduction of the original sound.

Radio DSP

By digitally converting and processing FM/AM broadcast signals, this greatly reduces adjacent interference and multipath distortion.

A radio's IF filter has the job of preventing neighboring broadcast frequencies from interfering with reception of your desired station. Panasonic's Radio DSP uses an advanced algorithm to perform this task with digital control. It maintains the optimum balance between noise suppression and sound quality by automatically adjusting the IF filter bandwidth in response to the changing interference characteristics as you drive.

Note: If you enable CS Auto, the following functions are automatically disabled:

SQ, POSITION, BASS/TREBLE, BALANCE/FADER, SUB-

WOOFER LEVEL, LPF, HPF, SBC-SW

SQ (Sound Quality)

You have six preset modes (FLAT, POP, ROCK, VOCAL,

JAZZ, CLUB). You can customize your settings for these

(except FLAT) and save them for instant recall.

SQ9 (9-Band Sound Quality)

Center frequency and level are adjustable in each of nine bands. This lets you fine tune sound quality for each genre to suit car-interior acoustics and your personal preferences. ( a page 18)

Full lineup of optional parts

An optional XM Direct

TM

Receiver allows you to receive the XM radio service. A DVD changer instead of an XM

Direct

TM receiver is also connectable. ( a page 30)

¡ Toll free number

XM Tuner P/N: XMD1000

Call 1-800-XM-RADIO (96-72346)

Extension cord P/N: XMDPAN100

Call 1-800-942-TERK (8375)

Fully Motorized Front Panel

A touch is all it takes to slide the front panel down for access to the disc slot. A three-stage tilt function permits viewing angle to be adjusted to 15, 25 or 35 degrees for optimum display visibility.

256x64 pixel 512-color OEL display

(CQ-C9901U only)

Multicolored expression can be achieved thanks to OEL display. You can use this unit in your original way in collaboration with the customization function.

Sound Control

The XM name and related logos are trademarks of XM

Satellite Radio Inc.

You can also enjoy watching DVDs if the optional DVD changer and display unit are connected.

Notes:

¡ A changer and an XM Direct

TM receiver are not connectable at the same time.

¡ To connect the XM Direct

TM receiver (XMD1000), it is required to use an optional extension cord

(XMDPAN100) that is produced by XM exclusively for

Panasonic products.

CS Auto (Circle Surround Automotive)

CS Auto allows your car interior to change to a splendid audio room in a moment. Every speaker can be finetuned. ( a page 18)

*CS Auto, TruBass, FOCUS, SRS and symbol are trademarks of SRS Labs, Inc.

CS Auto technology is incorporated under license from

SRS Labs, Inc.

Delightful sound space thanks to system buildup

Headrest Monitor: CY-V7100U (Option)

*XM Direct TM receiver

XMD1000: manufactured by XM Satellite Radio

(Option)

CQ-C9901U/C9801U/

CQ-C9701U

Head unit

*DVD Changer

CX-DH801U

(Option)

Sub-Woofer

(Option)

Stereo/Mono

Power Amplifier (Option)

*A changer and an XM Direct TM receiver are not connectable at the same time.

CQ-C9901U/C9801U/C9701U

Contents

English

Français

Español

¡

Safety Information

¡

Before Reading These Instructions

¡

Service and Warranty

¡

Features

¡

Controls Layout

¡

Preparation

¡

General

¡

Sound Control

¡

Radio

¡

CD Player

¡

MP3/WMA Player

¡

XM Tuner (XM Direct

TM

receiver)

¡

Disc Changer (when CDs or MP3 discs are loaded)

¡

Disc Changer (when DVDs or VCDs are loaded)

¡

Audio Setting

¡

Function Setting

¡

Display Setting

¡

Customize the Display (Customize Function)

¡

Troubleshooting

¡

Error Display Messages

¡

Notes on Discs

¡

Maintenance

¡

Contents by Functions

¡

Specifications

CQ-C9901U/C9801U/C9701U

47

48

48

49

36

38

39

40

42

46

21

24

26

30

32

34

50

98

10

12

14

18

6

8

2

4

9

Controls Layout

Note: This instruction manual explains operations for use with the buttons on the main unit. (Different operations excluded)

SRC Source

PWR Power

VOLUME

PUSH SEL Select

CS Circle Surround Automotive

SQ Sound Quality

P·SET

Preset

DISC

(FOLDER)

MENU

DIM Dimmer

SRC

CS

TILT

OPEN (eject)

y / 5 Pause/Play

BAND

SET

APM

Auto Preset

Memory

MUTE

SBC·SW Super Bass

Control·Subwoofer

D•M Direct Memory

DISP

Display

TUNE

TRACK (FILE)

Release

Disc slot

10

CQ-C9901U/C9801U/C9701U

Number Buttons

8

~

Number

RANDOM

SCAN

REPEAT

SRC Source

PWR Power

BAND

SET

APM

Auto Preset

Memory

TUNE

TRACK (FILE)

P·SET

(Preset)

DISC (FOLDER)

One-touch operation is available for selecting a track playing style by use of [4] (RANDOM), [5] (SCAN), or

[6] (REPEAT). (For a Folder/Disc playing style, hold down the same button for 2 sec. or more.)

Direct Access

A track (CD mode), disc (Disc changer), file, folder

(MP3/WMA mode) and channel (XM) can be directly selected.

Example: Track number 5

1

Press [#] (NUMBER).

2

Press [5].

3

Press [BAND] (SET).

SEL Select

MENU

POWER

SOURCE MENU

SET

RANDOM SCAN REPEAT

TUNE

NUMBER

CAR AUDIO

TUNE

VOL Volume

}:Up

{:Down

MUTE

SBC·SW Super Bass

Control·Subwoofer

DISP Display

CQ-C9901U/C9801U/C9701U

11

12

Preparation

When the power is switched on for the first time, a demonstration message appears on the display. Press

[DISP] to change to regular mode.

1

Set your car’s ignition switch to the ACC or ON position.

The demonstration screen appears.

Example: CQ-C9901U

SRC

CS

2

Press [DISP] (Display).

The demonstration screen is cancelled, and no more appears.

Note: If you would like to turn on the power and make the demonstration message appear, hold down [SRC]

(PWR: Power) for 4 sec. or more after turning off the power in other than the XM mode.

Preparation Before Initial Use

Pull the insulation film out from the backside of remote control gently.

Warning

¡ Keep batteries and insulation film out of reach of infants. If an infant ingests a battery, please seek immediate medical attention.

Battery Replacement

q Remove the battery holder with the remote control unit placed on a flat surface.

q Stick your thumbnail into the groove, and push the holder in the direction of the arrow, and at the same time.

w Pull it out in the direction of the arrow using a tough pointed object.

w Put a battery in the case with

(+) side facing up.

e Put the case back.

Insulation film

Tough pointed object

Back side q w

2

Caution

¡

Remove and dispose of an old battery immediately.

¡

Do not disassemble, heat or short a battery. Do not throw a battery into a fire or water.

¡

Follow local regulations when disposing of a battery.

¡

Improper use of a battery may cause overheating, an explosion or ignition, resulting in injury or a fire.

Note:

¡ Battery Information:

Battery Type: Panasonic lithium battery (CR2025)

(Included in the remote control)

Battery Life: Approximately 6 months under normal use (at room temperature)

3

The following functions are activated when the Security

Function is ON. ( a page 38)

¡

The security indicator blinks when removing the face plate.

¡ The alarm sounds and the message appears on the screen to warn you to remove the face plate at power off.

Security Indicator

CQ-C9901U/C9801U/C9701U

You may need to set the following depending on the devices to be connected.

Using Subwoofer

¡ Subwoofer level adjustment ( a page 36)

¡ Subwoofer low pass filter ( a page 36)

Connecting an XM Direct

TM

receiver

Preparation:

¡ Connect the optional XM Direct TM receiver (XMD1000).

¡

To connect the XM Direct

TM receiver (XMD1000), it is required to use an optional extension cord (XMDPAN100) that is produced by XM exclusively for Panasonic products.

Getting Started

It is required to sign up to become an XM Satellite Radio subscriber. After checking your XM Satellite Radio ID, sign up on the XM’s website or by calling them.

1

Check of XM Satellite Radio ID

¡ Write down the ID indicated on the lower right of your XM Direct TM receiver (XMD1000).

¡ Check the ID shown by tuning your XM Radio to channel 0. ( a page 30)

2

Activate the XM Satellite Radio

Select either of the below to sign up.

¡

Web site: http://www.xmradio.com/activation

¡ Phone number: 1-800-XM-RADIO (96-72346)

Note: Refer to the operating instructions for the XM

Direct

TM receiver for details.

Connecting an AV device (TV, VTR)

If you connect TV to AUX1 terminal, set the AUX1 setting to TV.

1

Press [SRC] (Source) to select the

AUX1 mode.

( a page 16)

2

Press [MENU] to display the menu display.

For using the remote control, hold down [MENU] for 2 sec. or more.

3

Press [BAND] (SET) to adjust.

: TV

: Other devices (Default)

Note: When using an external TV unit manufactured by a third party, select the TV mode.

4

Press [MENU] to confirm the adjustment.

Note: Adjust the clock when “ADJUST” appears on the display.

5

Adjust the setting value.

1

Press [MENU] to display the menu display.

For using the remote control, hold down [MENU] for 2 sec. or more.

2

Press []] or [[] to display the DIS-

PLAY menu.

3

Press [ {

] to select “CLOCK ADJ”.

4

Press [BAND] (SET) to confirm the display.

[[]

: Adjusting minutes

[]]

: Adjusting hours

[

}

]

: Forward

[

{

]

: Backward

6

Press [BAND] (SET) to confirm the adjustment.

7

Press [MENU].

For using the remote control, hold down [MENU] for 2 sec. or more.

CQ-C9901U/C9801U/C9701U

13

14

General

This chapter explains how to turn on or off the power, how to adjust the volume, etc.

Power on

Press [SRC] (PWR: Power).

CS

Notes:

¡ The opening screen appears. You can overwrite the opening screen (moving picture) with new one. ( a page 40)

¡ When the power is switched on for the first time, a demonstration message appears on the display. Press

[DISP] to change to regular mode. ( a page 12)

Power off

Hold down [SRC] (PWR: Power) for 2 sec.

or more.

Note: The ending screen appears. You can overwrite the ending screen (moving picture) with new one. ( a page

40)

You can remove the face plate to prevent it from being stolen.

3

Put the face plate in the case.

Removing

1

Turn off the power.

( a page 14)

2

Press [

] (Release).

(The face plate disengages with a click when it is removed.)

The face plate automatically closes in 5 seconds if it is open or tilted.

The power is automatically turned off while the unit is active.

Mounting

1

Slide the left side of the face plate in place.

2

Press the right end of the face plate until “click” is heard.

Cautions:

¡

It is recommended to remove or mount the face plate when the plate is at the closed position.

Do not remove or mount the face plate when the plate is in motion.

¡

This face plate is not waterproof. Do not expose it to water or excessive moisture.

¡

Do not remove the face plate while driving your car.

¡

Do not place the face plate on the dashboard or nearby areas where the temperature rises to high levels.

¡

Do not touch the contacts on the face plate or on the main unit, since this may result in poor electrical contacts.

¡

If dirt or other foreign substances get on the contacts, wipe them off with clean and dry cloth.

¡

To avoid damaging the face plate, do not push it down or place objects on it while it is open.

CQ-C9901U/C9801U/C9701U

Open/Eject

Press [

] (OPEN).

When a disc is already loaded, the disc will automatically be ejected.

SRC

CS

Cautions:

¡

To avoid damaging the face plate, do not push it down or place objects on it while it is open.

¡

Do not pinch your finger or hand in the face plate.

¡ Do not insert foreign objects into the disc slots.

¡

For the following cases, the face plate automatically closes. Use caution not to catch your finger.

¡

After a lapse of 20 seconds

¡ When a disc is inserted

¡

When the face plate is removed ( a page 14)

Tilt

The display angle changes among 4 levels as follows every time you hold down [

] (TILT) for 1 sec. or more and release.

Close

Press [

] (OPEN).

Note: The last selected angle is maintained even after turning off the power.

TILT 1

TILT 2

TILT 3

OPEN

TILT OFF q Up w Down

Setting Range: 0 to 40

Default: 18

Notes:

¡

The volume level can be set independently for each source. (For radio, one volume setting for AM, one volume setting for all FMs)

¡ The volume is not adjustable while an error display is on the monitor. ( a page 46)

Volume off (down)

Press [

](MUTE).

SRC

CS

Cancel

Press [

](MUTE) again.

Note:

Volume-down range can be specified. ( a page

38)

CQ-C9901U/C9801U/C9701U

15

General

The source changes as follows every time

[SRC]

(Source) is pressed.

CS

Radio

FM1, FM2, FM3, AM ( a page 21)

Auxiliary (AUX2)

When connecting CD Changer, DVD Changer ( a page

32, 34)

Player

When loading CD ( a page 24)

When connecting XM Direct

TM receiver ( a page 30)

When loading MP3/WMA disc ( a page 26)

Auxiliary (AUX 1)

When connecting a TV

When connecting a device that is not compatible with this unit

When connecting a device that is not compatible with this unit

Note: Please connect a CD changer or a DVD changer to

AUX2. ( a Installation Instructions)

16

CQ-C9901U/C9801U/C9701U

The display changes as follows every time [DISP] is pressed.

Note: You can select a graphic pattern and a still image from originally stored data. ( a page 39) You can also use your original images. (Customize Function a page 40)

At power-on:

Mode

SRC

CS

Display OFF

All displays disappear in 5 seconds.

Folder hierarchy (MP3/WMA mode only.)

Ordinary display + clock

XM Satellite Radio category (XM Direct TM receiver mode only)

Ordinary display + graphic pattern

Only graphic pattern

Only still image

Ordinary display + still image

At power-off:

Clock display (default)

Off

The dimmer level changes as follows every time you hold down [MENU] (DIM:Dimmer) for 2 sec. or more.

Brighter (Default)

Medium

Darker

SRC

CS

Note: This setting is not adjustable with the remote control.

CQ-C9901U/C9801U/C9701U

17

18

CS Auto allows your car interior to change to a splendid audio room in a moment. Every speaker can be finetuned.

You can toggle the CS Auto function on and off every time you press [CS] (Circle Surround). Select CS Auto on or off after setting each item.

Note: If you enable CS Auto, the following functions are automatically disabled:

SQ, POSITION, BASS/TREBLE, BALANCE/FADER, SUB-

WOOFER LEVEL, LPF, HPF, SBC-SW

SRC

Lights when CS Auto is activated.

You have six preset modes (FLAT, POP, ROCK, VOCAL,

JAZZ, CLUB).

SQ9 (9-Band Sound Quality)

Center frequency and level are adjustable in each of nine bands. This lets you fine tune sound quality for each genre to suit car-interior acoustics and your personal preferences.

You can toggle the SQ function on and off every time you press [CS] (SQ).

Notes:

¡ Each SQ level is changeable. ( a page 20)

¡ If you enable SQ, the following functions are automatically disabled:

CS Auto, F-TruBass, R-TruBass, S.W.-TruBass,

F-Focus, R-Focus, F-R MIX

SBC-SW: Super Bass Control-Subwoofer

The rear speaker can be used as a substitutional subwoofer when a subwoofer is not connected.

Holding down [ ] (SBC-SW) for 2 sec. or more toggles SBC-SW on and off.

Off (default)

SRC

Lights when SQ is activated.

(Hidden in the FLAT mode)

SRC

CS

On

Notes:

¡ If ON is selected, the settings of subwoofer level adjustment and subwoofer low pass filter are activated. ( a page 36)

¡ When SBC-SW is set to ON, the CS mode automatically turns off.

CQ-C9901U/C9801U/C9701U

Lights when SBC-SW is activated.

You can optimize the performance of CS Auto (Circle

Surround Automotive) by following the steps below.

1

Set the CS Auto mode to on.

2

Hold down [CS] (Circle Surround) for 2 sec. or more to display the audio menu display.

SRC

CS AUTO MODE

Three-dimensional natural sound field is reproduced with clarity in response to sound.

: Music

(default in other than the AM mode)

: Cinema

: Monaural (default in the AM mode)

3

Press [BAND]

(SET) to adjust.

4

Press [DISP] to confirm the adjustment.

CQ-C9901U/C9801U/C9701U

19

Sound Control

You can make a fine adjustment of SQ and Position.

1

Set the SQ mode to on.

2

Hold down [CS] (SQ) for 2 sec. or more to display the audio menu display.

SQ PRESET SELECT

Select your favorite type from 6 kinds of SQ Presets.

SRC

Note: You can also select the SQ preset number by pressing [1] to [6] on the remote control.

SQ ADJUSTMENT (SQ9)

You can make a fine adjustment to the currently selected

SQ presetting in each type (except FLAT).

3

Press [ }

] or [

{

] to select a function to

be adjusted.

4

Press [BAND]

(SET) to adjust.

[

]

][

[

]:

Frequency band selection qw:

Frequency selection

[

}

][

{

]: Level up/down

Note: If you hold down [BAND] for 2 sec. or more, the presetting that is called up can be turned into the default.

SQ PRESET MEMORY

The current value is assigned to one of SQ preset 2 to 6.

5

Adjust the setting value.

[}][{][]][[

]

: Select

[BAND] (SET): Confirm

6

Press [DISP] to confirm the adjustment.

1

Select a preset number by pressing

[}],

[{], []] or

[[]

.

2

Hold down

[BAND]

for 2 sec. or more.

Note: You can also select the SQ preset number by pressing [2] to [6] on the remote control, and assign the current value to the selected preset number by holding down the same button for 2 sec. or more.

POSITION

You can make the optimal sound field in accordance with your seat.

Radio

A radio DSP is integrated into this unit. The IF filter allows the radio to adjust the bandwidth automatically to maintain optimum reception.

1

Press [SRC] (Source) to select the radio mode.

2

Press [BAND] to select a band.

CS

Notes:

¡

For tuning in on only stations whose receiving conditions are good in the station search, set LOCAL to ON.

( a page 23)

¡ For reducing noise when a receiving FM stereo wave is weak, set MONO to ON. ( a page 23)

3

Select a station.

Frequency adjustment

[]] (TUNE): Lower

[[] (TUNE): Higher

Note: Hold down for 0.5 sec. or more and release for station search.

Preset station selection

[{] (P·SET: Preset):

[}] (P·SET: Preset):

Lower preset number

Higher preset number

Note:

¡ Direct Access can be executed with [1] to [6] buttons on remote control.

¡ Stations in FM 1 to 3 are sequentially selectable without changing bands when “ALL BAND” is selected in “AUTO PRESET”.

Preset Number

Band

Lights while receiving an FM stereo signal.

(“STEREO”: CQ-C9801U, CQ-C9701U)

Lights when MONO is activated.

( a page 23)

Frequency

Indicates the intensity of the radio wave.

Lights when LOCAL is activated.

( a page 23)

CQ-C9901U/C9801U/C9701U

21 20

CQ-C9901U/C9801U/C9701U

Radio

You can assign your favorite broadcasting station to the

[D•M] button. As the result of doing that, your favorite broadcasting station can be received even if the CD mode or the CD changer mode is activated. (Default: FM 87.9

MHz)

Note: For the use of an FM transmitter, it is useful for users to register applicable frequencies on D•M

(Direct Memory).

D•M station calling

1

Press [D•M] (Direct Memory).

D•M station writing

1

Select a station you would like to preset.

2

Hold down [D•M] (Direct Memory) for

2 sec. or more.

SRC

CS

Lights when the D•M mode is activated.

Up to 6 stations can be preset in AM, FM1, FM2, and FM3 respectively.

Preset stations can be simply called up by pressing [}]

(P·SET) or [{] (P·SET).

Notes:

¡ Direct Access can be executed with [1] to [6] buttons on remote control.

¡ You can switch between 6 and 18 for FM presetting stations. ( a page 23)

¡ Preset stations are changeable.

( a page 23)

Auto Preset Memory (APM)

Stations with good receiving conditions are automatically preset.

1

Select a band.

2

Hold down [BAND]

(APM) for 2 sec. or more.

The preset stations under best receiving conditions are received for 5 sec. each after presetting the stations (SCAN). To stop scanning, press [}] or [{].

Note: New stations overwrite existing saved stations.

Manual station preset

1

Tune in to a station.

2

Hold down

[}] or

[{] for 2 sec. or more.

3

Select a preset number by pressing

[}] or

[{]

.

4

Preset the station by holding down

[}] or

[{] for 2 sec. or more.

Frequency/preset number blinks once.

Notes:

¡ New stations overwrite existing saved stations.

¡ In step 2, a station can be registered by holding down the numeric button [1] to [6] for 2 sec. or more.

¡ To stop presetting stations, press [DISP] (Display).

22

CQ-C9901U/C9801U/C9701U

In the AM mode, only NOISE SUPPRESSION and LOCAL can be selected.

1

Press [MENU] to display the menu display.

For using the remote control, hold down

[MENU] for 2 sec. or more.

2

Press [

}

] or [

{

] to select a mode to be

adjusted.

3

Press [BAND]

(SET) to adjust.

4

Press [MENU] to confirm the adjustment.

For using the remote control, hold down [MENU] for 2 sec. or more.

NOISE SUPPRESSION

IF filter setting for noise suppression

: Wide range

: Middle range (default)

: Narrow range

AUTO PRESET

You can select 6 or 18 stations for FM presetting with the use of APM.

:

Presets 6 stations to FM1 to FM3 respectively, that is, 18 stations in total at the same time. This function is useful for presetting more than 6 stations. (default)

:

Presets 6 stations with good reception to the selected band from FM1 to FM3. This function is useful for presetting stations in different areas in different bands.

PRESET EDIT

You can arrange the order of the preset stations. Preset stations can be reordered as you like after executing APM or the like.

1

Press [ }

], [

{

], [

]

] or [

[

] to select one

station to be interchanged.

2

Press [BAND] to confirm your selection.

3

Press [

}

], [

{

], [

]

] or [

[

] to select the

other station to be interchanged.

4

Press [BAND] to confirm your selection.

MONO (Monaural)

Noise reduction when the signal strength decreases

: Receiving in stereo (default)

: Receiving in mono and reducing the noise level

Calling an FM station registered on D•M.

RADIO AUDIO FILTER

You can select the reception status (band) of FM stations registered on D•M.

: OFF (default)

: High cut level 1

: High cut level 2

LOCAL

Setting when searching for a station

: Searching even for a relatively low-intensity radio wave station (default)

: Searching only for a high-intensity radio wave station

CQ-C9901U/C9801U/C9701U

23

CD Player

When a disc is already loaded, press [SRC] (Source) to select the CD mode.

1

Press [

] (OPEN) to open the face

plate.

When a disc is already loaded (

will automatically be ejected.

lights), the disc

2

Load a disc with the label-side facing up.

The face plate closes automatically, and the unit recognizes the disc and starts playing automatically, too.

Track number

SRC

CS

3

Select a desired track.

Track selection

[7] (TRACK): Next track

[6] (TRACK): Preceding track (press twice)

Note: Hold down for fast forward/reverse.

Pause

Press [BAND] (h / 5).

Press again to cancel.

4

Press [

] (OPEN/eject) to eject the

disc.

Time

CD-TEXT display

Notes:

¡

For scrolling text, hold down [DISP] for 2 sec. or more.

¡

“NO TEXT” is displayed when there is no information on the disc.

Play Mode indicators

Lights when each mode is activated.

Lights when the disc is loaded.

24

CQ-C9901U/C9801U/C9701U

Cautions:

¡ This unit does not support 8 cm {3˝ } discs.

¡ Do not use irregularly shaped discs. ( a page 47)

¡ Do not use discs that have a seal or label attached.

¡ To avoid damaging the face plate, do not push it down or place objects on it while it is open.

¡ Do not pinch your finger or hand in the face plate when the panel is in motion.

¡ Do not insert foreign matter into the disc slots.

¡

Refer to the section on “Notes on CD/CD Media (CD-ROM,

CD-R, CD-RW)” ( a page 47).

¡

This unit does not support a MIX mode CD (a CD containing both CD-DA and MP3/WMA data). In case of using such a

CD, problems may occur such as anacoustic playback.

Random and Repeat play can be set.

1

Press [MENU] to display the menu display.

For using the remote control, hold down

[MENU] for 2 sec. or more.

RANDOM

: Off (default)

: Random playback

2

Press [ }

] or [

{

] to select a mode to be

adjusted.

3

Press [BAND]

(SET) to adjust.

REPEAT

: Off (default)

: Playing the current track repeatedly

TEXT

Text display

: Enabled (default)

: Disabled

4

Press [MENU] to confirm the adjustment.

For using the remote control, hold down [MENU] for 2 sec. or more.

Play Mode Selection

One-touch operation is available for selecting a track playing style by use of [RANDOM] or [REPEAT].

RANDOM

Press [RANDOM] (Random).

Press again to cancel.

REPEAT

Press [REPEAT] (Repeat).

Press again to cancel.

Direct Access

A track can be directly selected.

Example: track number 5

1

Press [#] (NUMBER).

2

Press [5].

3

Press [SET].

Note: To suspend direct selection, press [DISP]

(Display).

SCAN play

You can find your favorite track by playing first 10-sec. of each track.

Press [SCAN].

Press again to cancel.

CQ-C9901U/C9801U/C9701U

25

MP3/WMA Player

When a disc is already loaded, press [SRC] (Source) to select the CD mode.

1

Press [

] (OPEN) to open the face

plate.

When a disc is already loaded ( lights), the disc

will automatically be ejected.

2

Load a disc with the label-side facing up.

The face plate closes automatically, and the unit recognizes the disc and starts playing automatically, too. (It may take several minutes to start for a disc that has a lot of files.)

SRC

CS

3

Select a desired folder/file.

Folder selection

[}] (FOLDER): Next folder

[{] (FOLDER): Preceding folder

File selection

[7] (TRACK): Next file

[6] (TRACK): Preceding file (press twice)

Note: Hold down for fast forward/reverse.

Pause

Press [BAND] (h / 5).

Press again to cancel.

4

Press [

] (OPEN/eject) to eject the

disc.

Time File number

Folder number

File type indicator

Information Display

Notes:

¡ For scrolling text, hold down [DISP] for 2 sec. or more.

¡ “NO TEXT” is displayed when there is no information on the disc.

¡ ID3/WMA tag information is displayed for the album name and title/artist name.

Play Mode indicators

Lights when each mode is activated.

Lights when the disc is loaded.

(Folder Random)

(Folder Repeat)

(Folder Scan)

Notes:

¡ Refer to the section on “Notes on MP3/WMA” ( a page 28)

¡ This unit does not support a MIX mode CD (a CD containing both CD-DA and MP3/WMA data). In case of using such a

CD, problems may occur such as anacoustic playback.

Random and Repeat play can be set.

1

Press [MENU] to display the menu display.

For using the remote control, hold down

[MENU] for 2 sec. or more.

2

Press [ }

] or [

{

] to select a mode to be

adjusted.

3

Press [BAND]

(SET) to adjust.

4

Press [MENU] to confirm the adjustment.

For using the remote control, hold down [MENU] for 2 sec. or more.

RANDOM

: Off (default)

: Random playback (from whole disc)

FOLDER RANDOM

: Off (default)

: Random playback (from selected folder)

REPEAT

: Off (default)

: Playing the current file repeatedly

FOLDER REPEAT

: Off (default)

: Playing the current folder repeatedly

TEXT

: Folder name/File name

(default)

: Album/Title (tag information)

: No display

Play Mode Selection

One-touch operation is available for selecting a file playing style by use of [RANDOM] or [REPEAT].

RANDOM, REPEAT

Press the button. Press again to cancel.

FOLDER RANDOM, FOLDER REPEAT

Hold down the button for 2 sec. or more. Hold down again to cancel.

SCAN play

You can find your favorite file by playing first 10-sec. of each file.

SCAN (All files)

Press [SCAN]. Press again to cancel.

FOLDER SCAN (1st file in each folder)

Hold down [SCAN] for 2 sec. or more. Hold down again to cancel.

Direct Access

A file in the current folder can be directly selected.

Example: file number 5

1

Press [#] (NUMBER).

2

Press [5].

3

Press [SET].

Notes:

¡ For folder selection, enter a number after pressing [#]

(NUMBER) twice.

¡ If there is no playable file in the selected folder, the first file or folder on the disc is selected.

¡ To suspend direct selection, press [DISP] (Display).

CQ-C9901U/C9801U/C9701U

27 26

CQ-C9901U/C9801U/C9701U

MP3/WMA Player

What is MP3/WMA?

MP3 (MPEG Audio Layer-3) and WMA (Windows Media TM

Audio) are the compression formats of digital audio. The former is developed by MPEG (Motion Picture Experts

Group), and the latter is developed by Microsoft

Corporation. Using these compression formats, you can record the contents of about 10 music CDs on a single

CD media (This figures refer to data recorded on a

650MB CD-R or CD-RW at a fixed bit rate of 128 kbps and a sampling frequency of 44.1 kHz).

Display Information

Displayed items

¡

CD-TEXT

Disc title

Track title

¡

MP3/WMA

Folder name

File name

¡

MP3 (ID3 tag)

Album name

Title name/Artist name

¡

WMA (WMA tag)

Album name

Title name/Artist name

Notes:

¡

MP3/WMA encoding and CD writing software programs are not supplied with this unit.

¡

CD writing software is not supplied with this unit.

Displayable characters

¡

Displayable length of file name/folder name: within 64 characters.

¡

Name files and folders in accordance with the standard of each file system. Refer to the instructions of writing software for details.

¡ ASCII character set and special characters in each language can be displayed.

Points to remember when making MP3/WMA files

Common

¡ High bit rate and high sampling frequency are recommended for high quality sound.

¡ Selecting VBR (Variable Bit Rate) is not recommended because playing time is not displayed properly and sound may be skipped.

¡ The playback sound quality differs depending on the encoding circumstances. For details, refer to the user manual of your own encoding software and writing software.

MP3

¡

It is recommended to set the bit rate to “128 kbps or more” and “fixed”.

WMA

¡ It is recommended to set the bit rate to “64 kbps or more” and “fixed”.

¡ Do not set the copy protect attribute on the WMA file to enable this unit to play back.

ASCII character set

A to Z, a to z, digits 0 to 9, and the following symbols:

(space) ! ” # $ % & ’ ( ) * + , - . / : ; < = > ? @ [ \ ] ˆ

_ ` { | } ~

Notes:

¡ With some software in which MP3/WMA format files have been encoded, the character information may not be displayed properly.

¡

Undisplayable characters and symbols will be converted into an asterisk (

*

).

¡

It is recommended that the length of the file name is less than 8 (excluding the file extension).

Caution: Never assign the “.mp3”, or

“.wma” file name extension to a file that is not in the MP3/WMA format. This may not only produce noise from the speaker damage, but also damage your hearing.

28

CQ-C9901U/C9801U/C9701U

Recording MP3/WMA files on a CD-media

¡

You are recommended to minimize the chances of making a disc that contains both CD-DA files and

MP3/WMA files.

¡

If CD-DA files are on the same disc as MP3 or WMA files, the songs may not play in the intended order, or some songs may not play at all.

¡

When storing MP3 data and WMA data on the same disc, use different folders for each data.

¡ Do not record files other than MP3/WMA files and unnecessary folder on a disc.

¡ The name of MP3/WMA file should be added by rules as shown in the following descriptions and also comply with the rules of each file system.

¡ The file extension “.mp3” or “.wma” should be assigned to each file depending on the file format.

¡ You may encounter trouble in playing MP3/WMA files or displaying the information of MP3/WMA files recorded with certain writing software or CD recorders.

¡ This unit does not have the play list function.

¡ Although Multi-session recording is supported, the use of Disc-at-Once is recommended.

Supported file systems

ISO 9660 Level 1/Level 2, Apple Extension to ISO 9660,

Joliet, Romeo

Note: Apple HFS, UDF 1.50, MIX mode CD, CD Extra are not supported.

Compression formats

(Recommendation: “Points to remember when making MP3/WMA files” on the previous page)

Compression method

MPEG 1 audio layer 3 (MP3)

Bit rate

32 k-320 kbps

VBR

Yes

Sampling frequency

32, 44.1, 48 kHz

MPEG 2 audio layer 3 (MP3)

Windows Media Audio Ver. 2, 8

8 k-160 kbps

64 k-192 kbps

Yes

No

16, 22.05, 24 kHz

32, 44.1, 48 kHz

Folder selection order/file playback order

Maximum number of files/folders

¡ Maximum number of files: 999

¡ Maximum number of files in one folder: 255

¡ Maximum depth of trees: 8

¡ Maximum number of folders: 255 (Root folder is included.)

Notes:

¡

This unit counts the number of folders irrespective of the presence or absence of MP3/WMA file.

¡

If the selected folder does not contain any MP3/WMA files, the nearest MP3/WMA files in the order of playback will be played.

¡ Playback order may be different from other MP3/WMA players even if the same disc is used.

¡ “ROOT” appears when displaying the root folder name.

1

2

3

5

6

Root Folder

(Root Directory)

4 q

7 w

Tree 1

Tree 2

8 e

Folder Selection

In the order

1

8

File Selection

In the order q

– y r

Tree 3

t y

Tree 4 Tree 8

(Max.)

Windows Media, and the Windows logo are trademarks, or registered trademarks of

Microsoft Corporation in the United States and/or other countries.

Copyright

It is prohibited by copyright laws to copy, distribute and deliver copyrighted materials such as music without the approval of copyright holder except enjoying yourself personally.

No warranty

Above description complies with our investigations as of

December 2004. It has no warranty for reproducibility and displayability of MP3/WMA.

CQ-C9901U/C9801U/C9701U

29

30

XM Tuner

(XM Direct

TM

receiver)

An optional XM Direct TM receiver allows you to receive the XM radio service.

Note: A changer and an XM Direct TM receiver are not connectable at the same time.

1

Press [SRC] (Source) to select the XM tuner.

2

Press [BAND] to select a band.

CS

Preparation:

¡

Connect the optional XM Direct TM

(XMD1000).

receiver

¡

To connect the XM Direct TM receiver

(XMD1000), it is required to use an optional extension cord (XMDPAN100) that is produced by XM exclusively for Panasonic products.

Notes:

¡ “RADIO ID” is displayed with channel 0.

¡ “UPDATING” is displayed during the update of the identification code.

¡ “LOADING” is displayed during the acquisition of audio data or information.

3

Select a station.

Channel selection

[]] (TUNE): Preceding channel

[[] (TUNE): Next channel

Preset station selection

[{] (P·SET: Preset):

[}] (P·SET: Preset):

Lower preset channel

Higher preset channel

Note: Direct Access can be executed with [1] to [6] buttons on remote control.

Preset Number

Band

Channel number/name

Indicates the satellite tuner is ready.

Artist name/Song title Indicates the intensity of the radio wave.

Up to 6 channels can be preset in XM1 to XM3.

Preset channels can be simply called up by pressing

[}] (P·SET) or [{] (P·SET).

Note: Direct Access can be executed with [1] to [6] buttons on remote control.

4

Preset the channel by holding down or

[{] for 2 sec. or more.

1

Tune in to a channel.

2

Hold down

[}] or

[{] for 2 sec. or more.

3

Select a preset number by pressing

[}] or

[{]

.

channnel name/preset number blinks once.

Notes:

¡ New channels overwrite existing saved stations.

¡

In step 2, a channel can be registered by holding down the numeric button [1] to [6] on the remote control unit for 2 sec. or more.

¡ To stop presetting, press [DISP] (Display).

[}]

CQ-C9901U/C9801U/C9701U

You can toggle the category on and off every time you hold down [BAND] for 2 sec. or more. If the category is set to on, the unit operates as follows for each button:

Channel selection

[]] (TUNE): Preceding channel in current category

[[] (TUNE): Next channel in current category

Category selection

[{] (P·SET: Preset): Preceding category

[}] (P·SET: Preset): Next category

SRC

CS

Lights when category is activated.

1

Press [MENU] to display the menu display.

For using the remote control, hold down

[MENU] for 2 sec. or more.

2

Press [ }

] or [

{

] to select a mode to be

adjusted.

TEXT

Text display

: Enabled (default)

: Disabled

3

Press [BAND]

(SET) to adjust.

4

Press [MENU] to confirm the adjustment.

For using the remote control, hold down [MENU] for 2 sec. or more.

Direct Access

A channel can be directly selected.

Example: channel number 5

1

Press [#] (NUMBER).

2

Press [5].

3

Press [SET].

Note: To suspend direct selection, press [DISP]

(Display).

CQ-C9901U/C9801U/C9701U

31

Disc Changer

(when CDs or MP3 discs are loaded)

You can play CDs or MP3 discs when connecting this unit to a CD changer or a DVD changer.

1

Load a magazine (discs).

When a magazine is already loaded ( lights), press [SRC] (Source) to select the CD changer mode.

CS

The unit recognizes the magazine and starts playing automatically.

Note: The changer is automatically turned on when the magazine is inserted.

2

Select a desired disc/folder/file/track.

Disc selection

[}]: Next disc

[{]: Preceding disc

Folder selection

Hold down for 2 sec. or more.

[}] (FOLDER): Next folder

[{] (FOLDER): Preceding folder

Track/File selection

[7]: Next track/file

[6]: Preceding track/file (press twice)

Note: Hold down for fast forward/reverse.

Pause

Press [BAND] (h / 5).

Press again to cancel.

32

Disc number

Changer indicator

(CD changer)

(DVD changer)

Disc type (DVD changer only)

(CQ-C9801U/C9701U)

(MP3)

CQ-C9901U/C9801U/C9701U

Lights when the changer is connected.

Play Mode indicators

Lights when each mode is activated.

Disc type (DVD changer only)

(CQ-C9901U)

(MP3)

(Folder Repeat)

(Disc Random) CD changer only

(Disc Repeat)

(Disc Scan) CD changer only

Notes:

¡ Please connect a CD changer or a DVD changer (CX-DH801U) to CH/AUX2.

¡ When CX-DP880 or CX-DH801U is connected, a CD-RW disc is playable.

¡ Trouble may occur while playing CD-Rs. Refer to the section on “Notes on CD/CD Media (CD-ROM, CD-R, CD-RW)” ( a page 47).

Random and Repeat play can be set.

1

Press [MENU] to display the menu display.

For using the remote control, hold down

[MENU] for 2 sec. or more.

2

Press [ }

] or [

{

] to select a mode to be

adjusted.

3

Press [BAND]

(SET) to adjust.

4

Press [MENU] to confirm the adjustment.

For using the remote control, hold down [MENU] for 2 sec. or more.

RANDOM

¡

CD-DA

RANDOM playback of the selected disc (DVD changer)

RANDOM playback of all discs in the magazine (CD changer)

¡

MP3 disc

RANDOM playback of the selected folders

: Off (default)

: Random playback

DISC RANDOM

: Off (default)

: Random playback (from selected disc)

REPEAT

: Off (default)

: Playing the current track/file repeatedly

DISC REPEAT

: Off (default)

: Playing the current disc repeatedly

FOLDER REPEAT (only for MP3 disc)

: Off (default)

: Playing the current folder repeatedly

Play Mode Selection

One-touch operation is available for selecting a track playing style by use of [RANDOM] or [REPEAT].

RANDOM, REPEAT

Press the button. Press again to cancel.

DISC RANDOM, DISC REPEAT, FOLDER REPEAT

Hold down the button for 2 sec. or more. Press again to cancel.

SCAN play

You can find your favorite track by playing first 10-sec. of each track.

SCAN (All tracks)

Press [SCAN]. Press again to cancel.

DISC SCAN (1st track in each disc)

Hold down [SCAN] for 2 sec. or more. Hold down again to cancel.

Direct Access

A disc can be directly selected.

Example: disc number 5

1

Press [#] (NUMBER).

2

Press [5].

3

Press [SET].

Note: To suspend direct selection, press [DISP]

(Display).

CQ-C9901U/C9801U/C9701U

33

Disc Changer

(when DVDs or VCDs are loaded)

You can play DVDs or VCDs when connecting this unit to a CD changer or a DVD changer.

1

Load a magazine (discs).

When a magazine is already loaded ( lights), press [SRC] (Source) to select the CD changer mode.

The unit recognizes the magazine and starts playing automatically.

CS

Note: The changer is automatically turned on when the magazine is inserted.

Notes:

¡ For DVD operations other than the above (i.e. DVD menu, closed caption, etc.), use the remote control unit supplied with the DVD changer.

¡

The remote control unit supplied with the DVD changer does not work properly when you aim it at this unit.

¡ When using the remote control unit supplied with the DVD changer, aim it at the monitor display

(CY-V7100U).

2

Select a desired disc/chapter.

Disc selection

[}]: Next disc

[{]: Preceding disc

Chapter selection

[7]: Next chapter / Next track

[6]: Preceding chapter (press twice)

Preceding track (press twice)

Note: Hold down for fast forward/reverse.

Pause

Press [BAND] (h / 5).

Press again to cancel.

Disc number Lights when the changer is connected.

Disc type (DVD changer only)

(CQ-C9801U/C9701U)

Play Mode indicators

Lights when each mode is activated.

Disc type (DVD changer only)

(CQ-C9901U)

(Disc Repeat)

(Chapter Repeat)

(Title Repeat)

Notes:

¡ Please connect a CD changer or a DVD changer (CX-DH801U) to CH/AUX2.

¡ "AUX2" is displayed when connecting a changer that is not compatible with this unit.

Random and Repeat play can be set.

1

Press [MENU] to display the menu display.

For using the remote control, hold down

[MENU] for 2 sec. or more.

For a DVD insertion

CHAPTER REPEAT

: Off (default)

: Playing the current chapter repeatedly

2

Press [ }

] or [

{

] to select a mode to be

adjusted.

3

Press [BAND]

(SET) to adjust.

TITLE REPEAT

: Off (default)

: Playing the current title repeatedly

Note: The unit may not operate for some DVDs.

For a VCD insertion

REPEAT

: Off (default)

: Playing the current track repeatedly

4

Press [MENU] to confirm the adjustment.

For using the remote control, hold down [MENU] for 2 sec. or more.

DISC REPEAT

: Off (default)

: Playing the current disc repeatedly

Notes:

¡

The unit may not operate for some VCDs.

¡ The unit may not operate for a disc with the play back function activated.

Play Mode Selection

One-touch operation is available for selecting a track playing style by use of [REPEAT].

CHAPTER REPEAT, REPEAT

Press the button. Press again to cancel.

TITLE REPEAT, DISC REPEAT

Hold down the button for 2 sec. or more. Press again to cancel.

Direct Access

A disc can be directly selected.

Example: disc number 5

1

Press [#] (NUMBER).

2

Press [5].

3

Press [SET].

Note: To suspend direct selection, press [DISP]

(Display).

CQ-C9901U/C9801U/C9701U

35 34

CQ-C9901U/C9801U/C9701U

36

Audio Setting

Adjustment to each speaker and an optional subwoofer

1

Set the CS Auto mode to off.

( a page 18)

2

Press [VOLUME]

(SEL: Select) to display the menu display.

Balance adjustment

(Setting range: L15 to R15 and Center, Default: Center) q : Right enhanced w : Left enhanced

3

Press [VOL-

UME] (SEL:

Select) to select a mode to be adjusted.

4

Turn [VOLUME] clockwise or counterclockwise to adjust.

Note: If no operation takes place for more than 10 sec.

in the audio menu (2 sec. in Main volume adjustment), the display returns to the regular mode.

Fader adjustment

(Setting range: R15 to F15 and Center, Default: Center) q : Front enhanced w : Rear enhanced

Subwoofer level adjustment

(Setting range : mute (-

∞),-6 dB to +6 dB, 2 dB Step,

Default: 0) q : Up w : Down

Main volume adjustment

(Setting range: 0 to 40, Default: 18) q : Up w : Down

Subwoofer Low Pass Filter

(Setting range: Filter OFF, 60 Hz to 160 Hz, 5 Hz Step,

Default 120 Hz) q : Up w : Down

BASS

(Setting range: –12 to +12 dB, 2 dB step, Default: Bass 0) q : Up w : Down

Subwoofer output range

Other speakers output ranges

High Pass Filter

(Setting range: Filter OFF, 90 Hz to 225 Hz, 5 Hz Step,

Default: Filter OFF) q : Up w : Down

TREBLE

(Setting range: –12 to +12 dB, 2 dB step, Default: Treble

0) q : Up w : Down

Note: Do not activate SQ and Bass/Treble at the same time to avoid causing sound distortion.

CQ-C9901U/C9801U/C9701U

You can adjust the settings of bass sound reproduction and 3-dimensional sound field in the CS Auto mode.

1

Set the CS Auto mode to on.

( a page 18)

2

Press [VOLUME]

(SEL: Select) to display the menu display.

S.W-TruBass (Sub Woofer TruBass)

(Setting range: Lv 1 to Lv 10 and OFF, Default: Lv 4) q : Up w : Down

3

Press [VOL-

UME] (SEL:

Select) to select a mode to be adjusted.

4

Turn [VOLUME] clockwise or counterclockwise to adjust.

Note: If no operation takes place for more than 10 sec.

in the audio menu (2 sec. in Main volume adjustment), the display returns to the regular mode.

F-FOCUS (Front Focus)

(Setting range: Lv 1 to Lv 10 and OFF, Default: Lv 5) q : Up w : Down

R-FOCUS (Rear Focus)

(Setting range: Lv 1 to Lv 10 and OFF, Default: Lv 5) q : Up w : Down

Main volume adjustment

(Setting range: 0 to 40, Default: 18) q : Up w : Down

F-R MIX (Front to Rear Mixing)

(Setting range: Lv 1 to Lv 10 and OFF, Default: Lv 4) q : Up w : Down

F-TruBass (Front TruBass)

(Setting range: Lv 1 to Lv 10 and OFF, Default: Lv 4) q : Up w : Down

R-TruBass (Rear TruBass)

(Setting range: Lv 1 to Lv 10 and OFF, Default: Lv 4) q : Up w : Down

Notes:

¡

TruBass

TruBass is an audio technology to which the technique of bass sound reproduction used in pipe organs is electrically applied, and in which an equalizer is not used at all and bass sound from the speakers to be used is richly reproduced.

¡

FOCUS

Focus is an audio technology that moves the sound image of playing sound vertically to reproduce the sounds of instruments and voices clearly.

CQ-C9901U/C9801U/C9701U

37

Function Setting

Adjustment to display on the FUNCTION menu

1

Press [MENU] to display the menu display.

For using the remote control, hold down

[MENU] for 2 sec. or more.

2

Press [ ]

] or [

[

] to display the FUNC-

TION menu.

MUTE KEY

Setting [MUTE] buttons’ functions

: Volume off (Default)

: Volume down by 10 steps

: Volume down by 5 steps

3

Press [ }

] or [

{

] to select a function to

be adjusted.

4

Press [BAND]

(SET) to confirm the adjustment.

SECURITY

Setting the security function ( a page 12)

: ON (Default)

: OFF

BUILT-IN AMP

You can toggle the integrated amplifier on and off.

: Amplifier on (Default)

: Amplifier off (when the external amplifier is used)

5

Press [MENU].

For using the remote control, hold down [MENU] for 2 sec. or more.

Display Setting

Adjustment to display on the DISPLAY menu

1

Press [MENU] to display the menu display.

For using the remote control, hold down

[MENU] for 2 sec. or more.

STILL IMAGE

(Setting range: 11types, Default: All)

Switching by [ ]

] or [

[

]

All:

No.1-10

Sequential display from pattern 1 to 10

2

Press []] or [[] to display the DIS-

PLAY menu.

3

Press [

}

] or [

{

] to select a function to

be adjusted.

4

Press [BAND]

(SET) to confirm the display.

CONTRAST (CQ-C9801U/C9701U only)

(Setting range: 1 to 5, Default: Contrast 3)

[[]:

Tilting up view angle

[]]:

Tilting down view angle

5

Adjust the setting value.

6

Press [BAND] (SET) to confirm the adjustment.

7

Press [MENU].

For using the remote control, hold down [MENU] for 2 sec. or more.

RGB ADJ (CQ-C9901U only)

(Setting range: 1 to 11, Default: 1)

You can adjust the screen color.

[[]:

Up

[]]:

Down

[}][{]:

Select

GRAPHIC PATTERN

(Setting range: 5 types (CQ-C9901U)/ 6 types (CQ-

C9801U/C9701U), Default: All)

Switching by [ ]

] or [[]

All: Sequential display from pattern A to E.

Pattern A-E

Pattern E: CQ-C9801U/C9701U only

CLOCK ADJ

Note: Adjust the clock when “ADJUST” appears on the display.

[[]:

Adjusting minutes

[]]:

Adjusting hours

[

}

]:

Forward

[

{

]:

Backward

Notes:

¡ The graphic pattern and still image are changeable.

( a page 40)

¡ If corrupted data is selected, “DISPLAY FILE INCOM-

PLETE” appears. ( a page 41)

CQ-C9901U/C9801U/C9701U

39 38

CQ-C9901U/C9801U/C9701U

40

Customize the Display (Customize Function)

You can edit the moving images and still images that are initially stored in the unit. You also can use the data that is downloaded from the Panasonic Web site and the data that is stored with a digital camera or other devices and processed with exclusive software,

IMAGE STUDIO. See "Notes on Customize Function"( a page 41) as well.

Note: Visit Panasonic Web site (http://panasonic.co.jp/pas/en/software/customize/index.html) for details.

Preparation:

Put the CD-R/RW that contains data to be customized in hand.

1

If there is a disc inside, take out the disc.

2

Press [SRC]

(Source) to select the CD mode.

CS

6

Select a file.

Example: GRAPHIC PATTERN

3

Hold down [SEL] for 4 sec. or more to display the menu screen.

[}][{][]][[]:Select

[BAND] (SET): Confirm

Notes:

¡ Files are automatically identified by their extensions, and target files are displayed.

¡ If [BACK] is selected, the screen of step 5 appears.

7

For a moving image file or still image file, select where to save the file.

4

Load a CD-R/RW that contains data.

Note:

¡

It may take time for the unit to identify the CD-

R/RW.

¡ Discs recorded by the packet writing software are not supported.

5

Select an item to be customized.

[]][[]: Select

[BAND] (SET): Confirm

Notes:

¡

New data overwrites existing data.

¡

If [BACK] is selected, the screen of step 6 appears.

8

Confirm the changed item.

[}][{]: Select

[BAND] (SET): Confirm

Note: To exit the customize menu, hold down

[SEL] 4 sec. or more.

GRAPHIC PATTERN

Moving image data ( a page 39)

STILL IMAGE

Still image data ( a page 39)

OPENING MESSAGE

Moving image at power on ( a page 14)

CLOSING MESSAGE

Moving image at power off ( a page 14)

[]][[]: Select

[BAND] (SET): Confirm

Customization is performed. Do not turn off the power in mid-operation. (It takes approx. 8 minutes to complete this operation for a 751 KB moving image.) After completion of this operation, the screen of step 5 appears.

Note: If [NO] is selected, the screen of step 5 appears.

9

Press [OPEN] to eject the disc.

10

Hold down [SEL] for 4 sec. or more.

The CD mode comes back.

CQ-C9901U/C9801U/C9701U

Note on Download Service

The download service may be suspended or stopped without advance notice. The download service is not available in some areas. Please visit the site below for further information.

Panasonic Web site:

(http://www.panasonic.co.jp/global/)

Error Display Messages

NO FILES DETECTED

No customize-specific data on the disc a

Load a disc that contains customize-specific data.

Notes on IMAGE STUDIO

¡

This download service is not available in some areas.

For details, please access the Panasonic website.

¡

IMAGE STUDIO is available only by downloading from the address below. It is not bundled with this unit.

¡

Refer to the downloaded operating manual for how to use IMAGE STUDIO.

CUSTOMIZING FAILED

Customize failed a

Check to see whether or not the extension is correct and file contents are appropriate.

DISPLAY FILE INCOMPLETE

Intended moving image or still image is damaged.

a

Customize it again and overwrite the file with new one.

Notes on File

¡ The customize-specific file is downloadable from the

URL below. You can create exclusive files stored with a digital camera or other devices by using exclusive software, IMAGE STUDIO that can be accessed from the same URL.

¡

Do not change the extension. Otherwise, the data cannot be recognized.

At Disc Making

¡ Save only customize-specific data.

¡ Save all data in the root directory. Files contained in a folder cannot be recognized.

¡ Follow the table below with regard to the number of files that are saved to a disc. Files beyond the specified capacity are not readable.

Type

GRAPHIC PATTERN

STILL IMAGE

OPENING MESSAGE

CLOSING MESSAGE

Extension

.pfm

.pfs

.pfo

.pfe

Max. number

10

15

5

5

At Customizing

¡ If customizing is interrupted on account of turning off the power, stopping the engine, removing the face plate or other reasons, you may lose the data. In such a case, try customizing again.

¡ The default image exists on the Panasonic Web site. If you would like to restore it, download the image from the site.

Download site:

http://panasonic.co.jp/pas/en/software/ customize/index.html

CQ-C9901U/C9801U/C9701U

41

Troubleshooting

42

If You Suspect Something Wrong

Check and take steps as described below.

If the described suggestions do not solve the problem, it is recommended to take the unit to your nearest authorized Panasonic

Servicenter. The product should be serviced only by qualified personnel.

Please refer the checking and the repair to professionals. Panasonic shall not be liable for any accidents arising out of neglect of checking the unit or your own repair after your checking.

Warning

¡ Do not use the unit in an irregular condition, for example, without sound, or with smoke or foul smell, which can cause ignition or electric shock.

Immediately stop using the unit and consult your dealer.

¡ Never try to repair the unit by yourself because it is dangerous to do so.

Problem

No power to the unit

Sound is not generated.

The demonstration screen displayed and no operable

Possible cause a

Possible solution

The power cord (battery, power and ground) is connected in the wrong way.

a

Check the wiring.

Fuse blowout a

Eliminate the cause of fuse blowout and replace the fuse with new one.

Consult your dealer.

MUTE is set to ON.

a

Set MUTE to OFF.

The wiring of speaker lines are not correct, or a break or poor contact arises.

a

Check the wiring in accordance with the wiring diagram. (Installation

Instructions)

BUILT-IN AMP is set to ON.

a

Set BUILT-IN AMP to OFF. Observe that “AMP OFF” is displayed on the screen.

You cannot operate the unit while the demonstration screen appears.

a

Press [DISP] to end the demonstration screen.

If the demonstration screen appears frequently, there is a possibility that poor contact or wrong wiring arises between the battery lead of the unit and the battery cable of the car. (The battery lead should be always powered.) a

Check the battery wiring in accordance with the wiring diagram.

Noise

There is an electromagnetic-wave generator such as a cellular phone near the unit or its electrical lines.

a

Keep an electromagnetic-wave generator such as a cellular phone away from the unit and the wiring of the unit. In case that noise cannot be eliminated due to the wiring harness of the car, consult your dealer.

The contact of the ground lead is poor.

a

Make sure that the ground lead is connected to an unpainted part of the chassis securely.

Noise is made in step with engine revolutions.

Alternator noise comes from the car.

a

Change the wiring position of the ground lead.

a

Mount a noise filter on the power supply.

CQ-C9901U/C9801U/C9701U

Problem

Some operations are not executable.

Possible cause a

Possible solution

Some operations are not executable in particular modes such as menu mode.

a

Read the operating instructions carefully and cancel the mode.

If the unit is still out of order, consult your dealer.

No sound from speaker (s)

Balance/Fader setting is not appropriate.

a

Readjust Balance/Fader.

There is a break, a short circuit, poor contact or wrong wiring regarding the speaker wiring.

a

Check the speaker wiring.

The speaker channels are reversed between right and left.

The sound field is not clear in the stereo mode.

Central sound is not settled.

The speaker wiring is reversed between right and left.

a

Perform the speaker wiring in accordance with the wiring diagram.

The plus and minus terminals at right and left channels of speakers are connected reversely.

a

Perform the speaker wiring in accordance with the wiring diagram.

The power of the unit fails unintentionally.

The safety device works.

a

Consult your dealer, or your nearest Panasonic Servicenter.

Playing sound is interrupted

An inappropriate speaker network (device) is used.

a

Use a speaker without any speaker network, or use an appropriate speaker network system that does not cause interruption.

Disc unejectable

Something such as a peeled label obstructs the disc coming out.

a

Press and hold the [OPEN] for more than 2 seconds when the face plate is open (disc forced ejection). In case that the disc forced ejection does not work, consult your dealer.

The microcontroller in the unit operates abnormally due to noise or other factors.

a

Unplug the power cord and plug it again. In case the unit is still out of order, consult your dealer.

CQ-C9901U/C9801U/C9701U

43

Troubleshooting

Problem

Poor reception or noise

Possible cause a

Possible solution

Antenna installation or wiring of antenna cable is faulty.

a

Check whether the antenna mounting position and its wiring are correct. In addition, check to see whether the antenna ground is securely connected to the chassis.

No power is supplied to the antenna amplifier (when using a film antenna, etc.).

a

Check the wiring of the antenna battery lead.

Stereo broadcast is received only in mono.

The MONO mode is active.

a

Cancel the MONO mode.

Only nearby stations can be received.

The LOCAL mode is active.

a

Cancel the LOCAL mode.

The number of auto preset stations is less than 6.

The number of receivable stations is less than 6.

a

Move to an area where receivable stations number is maximum, and try presetting.

Preset stations cannot be stored.

The contact of the battery lead is poor, or the battery lead is not always powered.

a

Make sure that the battery lead is connected securely, and preset stations again.

Channel unselectable

No contract with XM Satellite Radio Inc.

a

Refer to page 30 of this book and the XM's website to sign up for XM Radio service.

44

CQ-C9901U/C9801U/C9701U

Problem

No playback or disc ejected

Possible cause a

Possible solution

The disc is inserted upside down.

a

Insert a disc correctly.

There is a flaw or foreign material on the disc.

a

Remove the foreign material, or use a flawless disc.

Sound skipping or noise

There is a flaw or foreign material on the disc.

a

Remove the foreign material, or use a flawless disc.

Sound skipping due to vibration

The unit is not sufficiently secured.

a

Secure the unit to the console box.

The unit is tilted at over 30˚ in the front-to-end direction.

a

Make the angle 30˚ or less.

The CD-R/RWs that are playable on other devices are not playable on this unit.

The playability of some CD-R/RWs may depend on the combination of media, recording software and recorder to be used even if these CD-R/RWs are playable on other devices such as a PC.

a

Make CD-R/RWs in different combination of media, recording software and recorder after referring to the description about MP3/WMA.

Sound skipping or noise

There is a flaw or foreign material on the disc.

a

Remove the foreign objects, or use a flawless disc. For MP3/WMA, refer to the description about MP3/WMA.

Playing VBR (Variable Bit Rate) files may cause sound skipping.

a

Play Non-VBR files.

Note:

¡ Refer to “Notes on MP3/WMA”. ( a Page 28)

No response to pressing buttons

The battery is inserted in the wrong direction. A wrong battery is inserted.

a

Insert a correct battery in the correct direction.

The battery is weak.

a

Replace the battery with new one.

The aiming direction of the remote control unit is wrong.

a

Aim the remote control unit at the sensor of the unit and press buttons.

The sensor is exposed to direct sunlight. (The remote control unit may not be operable when the sensor is exposed to direct sunlight. In such a case, the system is not faulty.) a

Block off sunlight to the sensor.

CQ-C9901U/C9801U/C9701U

45

46

Error Display Messages

Display

Possible cause a

Possible solution

The disc is dirty or upside down.

a

Check the disc.

The disc has scratches.

a

Check the disc.

No operation by some cause.

a

Unplug the power cord and plug it again. In case the unit is still out of order, consult your dealer.

The file is not readable.

Error display continues when there is no playable file in the disc at the direct folder selection.

a

Eject the disc.

(After 5 seconds)

To next file automatically

A WMA file can be copyrighted. a

The file protected by copyright is not playable.

No disc.

Disc is dirty, or is upside down.

Disc has scratches.

(After 5 seconds)

To next disc automatically a

Eject the magazine.

¡ Check the disc.

¡

Load the disc again.

No operation by some cause.

a

Eject the magazine. If failure persists, press the reset switch on the CD changer. If normal operation is not restored, call the store where you purchased the unit or the nearest Panasonic Servicenter to ask for repairs.

An error arises in the DVD changer.

a

Check the DVD changer. (“REGION ERROR” etc.)

No disc is in the CD changer (magazine). a

Insert discs into the changer (magazine).

The changer has become disconnected from the unit in the changer mode.

a

Verify the wiring.

Note: Messages in the action and display sections of the error chart vary with changers. Refer to the operating instructions for the CD changer for details.

CQ-C9901U/C9801U/C9701U

Cannot receive XM satellite radio.

a

Verify the wiring.

XM antenna unconnected.

a

Connect the XM antenna.

XM broadcasts unreceivable because of poor receiving conditions.

a

Move to an area where XM broadcasts can be received well.

Channel not in service a

This channel is not currently in service. Tune to another channel.

Notes on Discs

If you use commercial CDs, they must have either of these labels shown at right.

Some copy-protected music CDs are not playable.

How to hold the disc

¡ Do not touch the underside of a disc.

¡

Do not scratch on a disc.

¡ Do not bend a disc.

¡

When not in use, keep a disc in the case.

Do not use irregularly shaped discs.

Do not leave discs in the following places:

¡

In direct sunlight

¡ Near car heaters

¡

Dirty, dusty and damp areas

¡ On seats and dashboards

Disc cleaning

Use a dry, soft cloth to wipe from the centre outward.

Do not attach any seals or labels to your discs.

Do not write on the disc label with a ballpoint pen or other hard-point pens.

<Correct>

TEXT

Label side

Do not use irregularly shaped discs.

<Wrong>

¡

You may have trouble playing back some CD-R/RW discs recorded on CD recorders (CD-R/RW drives), either due to their recording characteristics or dirt, fingerprints, scratches, etc. on the disc surface.

¡

CD-R/RW discs are less resistant to high temperatures and high humidity than ordinary music CDs. Leaving them inside a car for extended periods may damage and make playback impossible.

¡

Some CD-R/RWs can not be played back successfully due to incompatibility among writing software, a CD recorder

(CD-R/RW drive) and the discs.

¡

This player cannot play the CD-R/RW discs if the session is not closed.

¡ This player cannot play the CD-R/RW discs which contains other than CD-DA or MP3/WMA data.

¡

Be sure to observe the instructions of CD-R/RW disc for handling it.

CQ-C9901U/C9801U/C9701U

47

48

Maintenance

This unit is designed and manufactured to ensure the minimum of maintenance. Use a dry, soft cloth for routine exterior cleaning. Never use benzine, thinner, or other solvents.

If the fuse blows out, consult your dealer, or your nearest authorized Panasonic Servicenter.

Warning

Use fuses of the same specified rating (15 A). Using substitutes or fuses with higher ratings, or connecting the unit directly without a fuse could cause fire or damage to the unit. If the replaced fuse fails, contact your near-

est authorized Panasonic Servicenter.

Contents by Functions

Clock adjustment

(CLOCK ADJ)

Temporary Volume off (Down)

(MUTE (ATT : Attenuation))

Display Change

(DISP : Display)

Dimmer Control

(DIM : Dimmer)

SBC-SW: Super Bass Control-Subwoofer

Direct Memory

(D • M : Direct Memory)

CQ-C9901U/C9801U/C9701U

13

15

17

17

18

22

Specifications

Power Supply

DC 12 V (11 V – 16 V), Test Voltage 14.4 V, Negative Ground

Tone Controls (Bass/Treble)

Bass; ±12 dB at 80 Hz, Treble; ±12 dB at 6 kHz

Equalizer Center Frequency (SQ)

62.5, 125, 250, 500, 1 k, 2 k, 4 k, 8 k, 16 k (Hz, default)

Variable Range of Equalizer

Current Consumption

Maximum Power Output

Power Output

Speaker Impedance

Pre-amp output voltage

Subwoofer-output voltage

Pre-amp output impedance

-12 dB to 12 dB (2 dB step)

Less than 2.5 A (CD mode, 0.5 W 4-Speaker)

70 W x 4 (at 1 kHz) volume control maximum

31 W x 4 (at 4

Ω)

4 – 8

5 V (CD mode; 1 kHz, 0 dB)

Subwoofer-output impedance

External Input Impedance

External Input Sensitivity

Dimensions (Main Unit)

Weight (Main Unit)

5 V

60

60

10 k

Ω (AUX1, CH/AUX2 IN)

Max. 2 V (AUX1, CH/AUX2 IN)

178 (W) x 50 (H) x 155 (D) mm {7˝ x 1 15 /

16

˝ x 6 1 /

8

˝}

1.7 kg {3 lbs. 12 oz}

Sampling Frequency

Pick-Up Type

Light Source

Wavelength

Frequency Response

Signal to Noise Ratio

Total Harmonic Distortion

Wow and Flutter

Channel Separation

8 times oversampling

Astigma 3-beam

Semiconductor laser

790 nm

20 Hz – 20 kHz (±1 dB)

96 dB (2 V), 106 dB (5 V)

0.01 % (1 kHz)

Below measurable limits

86 dB (2 V)

FM

Frequency Range

Usable Sensitivity

50 dB quieting sensitivity

Frequency Response

Alternate channel selectivity

Stereo Separation

Image response ratio

IF response ratio

Signal to noise ratio

87.9 MHz – 107.9 MHz

12.2 dBf. (1.12 µV, 75

Ω)

15.2 dBf. (1.59 µV, 75

Ω)

30 Hz – 15 kHz (±3 dB)

75 dB

40 dB (1 kHz)

75 dB

100 dB

62 dB

AM

Frequency Range

Usable Sensitivity

Above Specifications comply with EIA standards.

530 kHz – 1 710 kHz

25 dB/µV (11V, S/N 20 dB)

Power Output:

31 W RMS x 4 Channels at 4

Ω and ≤ 1%

THD+N

Signal to Noise Ratio:

80 dBA (reference: 1 W into 4

Ω)

Notes:

¡

Specifications and design are subject to modification without notice due to improvements.

¡ Some figures and illustrations in this manual may be different from your product.

CQ-C9901U/C9801U/C9701U

49

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project
