Panasonic CT-34WDM60 34" TV

 В
C
N Panasonic. J
CT-34WDM60
Color Video Monitor
Operating
Instructions
—
Safety Instructions
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock do not remove cover or back,
No user-serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash with arrow-
head within a triangle is
intended to tell the user that
parts inside the product are a
risk of electric shock to
persons,
The exclamation point within a
triangle is intended to tell the
user that important operating
and servicing instructions are
in the papers with the
appliance.
Note to CATV System Installer : This reminder is provided to call the CATV system installer’s attention to Article
820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall
be connected to the grounding system of the building, as close to the point of cable entry as practical.
Safety Instructions For Video Monitor
1. Read and apply the operating instructions provided with your video monitor.
2. Read all of the instructions given here and retain them for later use.
3. Unplug this video monitor from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth
for cleaning.
4. Do not use attachments not recommended by the video monitor manufacturer as they may cause hazards.
5. Do not use this video monitor near water. For example : Avoid placing it near a bathtub, washbowil, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool, etc.
6. Do not place this video monitor on an unstable cart, stand, or table. The video monitor may fall, causing serious injury
to a child or adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the video monitor. Wall or shelf mounting should follow the manufacturer's
instructions, and should use a mounting kit approved by the manufacturer.
6A. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart combination to overturn.
7. Slots and openings in the cabinet and the back or bottom are provided for ventilation, and to insure reliable operation
of the video monitor and to protect it from overheating. These openings must not be blocked or covered. The openings
should never be blocked by placing the video monitor on a bed, sofa, rug or other similar surface. This video monitor
should never be placed near or over a radiator or heat register. This video monitor should not be placed in a built-in
installation such as a bookcase unless proper ventilation is provided.
8. Operate only from the type of power source indicated on the marking label. If you are not sure of the type of power
supplied to your home consult your video monitor dealer or local power company. For video monitors designed to
operate from battery power, refer to the operating instructions.
9. This video monitor is equipped with a polarized alternating-current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one way. This is a safety feature. !f you are unable to insert the plug
fully into the outlet, try reversing the plug. If the plug should stiil fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polanzed plug.
10. Do not allow anything to rest on the power cord. Do not locate this video monitor where the cord will be abused by
persons walking on it.
11. Follow all warnings and instructions marked on the video monitor.
12. For added protection for this video monitor during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will prevent damage to the video monitor due to lightning and
power-line surges.
13. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
14.
15.
16.
17.
18.
19,
20.
Never push objects of any kind into this video monitor through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the video monitor.
Do not attempt to service this video monitor yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
Unplug this video monitor from the wall outlet, and refer servicing to qualified an Authorized Service Centor under the
following conditions :
. When the power cord or plug is damaged or frayed.
. If liquid has been spilled into the video monitor.
. If the video monitor has been exposed to rain or water.
. If the video monitor does not operate normally by following the operating instructions. Adjust only those controls
that are covered by the operating instructions as improper adjustment of other controls may result in damage and
will often require extensive work by a qualified technician to restore the video monitor to normal operation.
e. If the video monitor has been dropped or the cabinet has been damaged.
f. When the video monitor exhibits a distinct change in performance - this indicates a need for service.
When replacement parts are required, be sure the service technician has used replacement parts specified by the
manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
Upon completion of any service or repairs to this video monitor, ask the service technician to perform routine safety
checks to determine that the video monitor is in safe operating condition.
WARNING : To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
CAUTION : TO PREVENT ELECTRIC SHOCK DO NOT USE THIS (POLARIZED) PLUG WITH A RECEPTACLE
OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
OO OQ
NOTE : This equipment is designed to operate in the U.S.A, where the broadcasting system and AC house current is
exactly the same as in the U.S.A. .
Important Information Regarding Use of Video Games, Computers, Caption or Other Fixed Image Displays.
The extended use of fixed image program material can cause a permanent “shadow image” on the picture tube. This
background image is viewable on normal programs in the form of a stationary fixed image. This type of irreversible picture
tube deterioration can be limited by observing the following steps :
A.
B.
C.
Reduce the brightness/contrast setting to a minimum viewing level.
Do not display the fixed image for extended periods of time.
Turn the power off when not in actual use.
NOTE : The marking or retained image on the picture tube resulting from fixed image use is not an operating defect and
as such is not covered by Warranty. This product is not designed to display fixed image patterns for extended
periods of time.
Dear Panasonic Customer
Welcome to the Panasonic family of customers. We hope that you will have many years of
enjoyment from your new Color Video Monitor.
To obtain maximum benefit from your set, please read these Instructions before making any
adjustments, and retain them for future reference.
Retain your purchase receipt also, and note down the Model Number and Serial Number of
your set in the space provided on the rear cover of these Instructions.
Table of Contents
IMPORTANT SAFETY NOTICE..................e_.ennaninesoso 5 ASPECT Controls..............e..e..e==esmas00s0eurerionai e 16
Safety Precautions.......................— econo KEHEG 5 PICTURE POS/SIZE Controls ...................eereeee—es 18
Accessories ...............—e.meimococ00ueeno nena nannnenTan ere eee ere 7 PICTURE MENU Controls .................e.ene==nenacenoosona 19
Accessories Supplied....................ee..... einer 7 PICTURE ADJ. MENU …..…..….......…00rerscareeneorensensennense 20
Remote Control Batteries Instaliation.................... 7 AUDIO MENU Controls ............—.-..e-..ere=w=ire=naaene. 22
Quick Start Guide.......................e-....m.nerornenteenao e 8 AUDIO ADJ. Menu ...................e_.esnaneneraooenerananaanets 23
Connect the Plug to the Wall Qutlet........................... 8 SURROUND Controls.....................+1..ere=e=me=nernoooeees 24
How to Turn the Power On... 8 Other Useful Functions ...........-—-e—.c.-m—es=.eresezaanno 25
Select the input signal... 8 OTHER ADJ. Menu ................esmmnmvimnencananoo ree 26
Basic Controls.............e....e..—.e=e_nenecernanenenaenct re ene 9 SET UP Menu............. e. esesnavestcecareenoenenennenDearennee 28
Connections ...............e.+-+--..—e=_e_.esnnernennar ataca rene 10 Troubleshooting.................-.-... ee... ecannancanecenea nen 29
Flowchart of Menu ..........e......e.svesrernenionrnecaco recen 15 Specifications ..............e=—......-.ssrecrocsmee menea: 30
FCC STATEMENT:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
FCC CAUTION:
Pursuant to 47CFR, Part 15.21 of the FCC rules, any changes or modifications to this monitor not expressly approved
by Matsushita Electric Corporation of America could cause harmful interference and would void the user's authority to
operate this device.
IMPORTANT SAFETY NOTICE
WARNING: To prevent damage which may result in fire or shock hazard, do not expose this appliance to rain
or moisture.
WARNING: 1) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to
qualified service personnel.
2) Do not remove the grounding pin on the power plug. This apparatus is equipped with a three pin
grounding-type power plug. This plug will only fit a grounding-type power outlet. This is a safety
feature. If you are unable to insert the plug into the outlet, contact an electrician.
Do not defeat the purpose of the grounding plug.
Safety Precautions
WARNING
Set up
Do not place the Monitor on sloped or unstable surfaces.
e The Monitor may fall off or tip over.
Do not place any objects on top of the Monitor.
e If water is spills onto the Monitor or foreign objects get inside it, a short-circuit may occur which could result in fire or
electric shock. If any foreign objects get inside the Monitor, please consult an Authorized Service Center.
When using the Monitor
The Monitor is designed to operate on 120 V AC, 50/60 Hz.
Do not cover the ventilation holes.
e Doing so may cause the Monitor to overheat, which can cause fire or damage to the Monitor.
Securely insert the power cord plug as far as it will go.
e |f the plug is not fully inserted, heat may be generated which could cause fire. if the plug is damaged or the wall
socket plate is loose, they should not be used.
Do not handle the power cord plug with wet hands.
® Doing so may cause electric shocks.
Do not do anything that might damage the power cable.When disconnecting the power cable, hold the plug,
not the cable.
e Do not make any modifications, place heavy objects on, place near hot objects, heat, bend, twist or forcefully pull
the power cable. Doing so may cause damages to the power cable which can cause fire or electric shock. If damages
to the cable suspected, have it repaired at an Authorized Service Center.
If the Monitor is not in use for a long period of time, unplug the power cord from wall outiet.
If problems occur during use
If a problem occurs (such as no picture or no sound), or if smoke or an abnormat odor detected from the
Monitor, Unplug the power cord immediately.
e Continuous use of the Display under these conditions might cause fire or permanent damage to the unit. Have the
Display evaluated at an Authorized Service Center. Services to the Display by any unauthorized personnel are
strongly discouraged due to its high voltage dangerous nature.
If water or foreign objects get inside the Monitor, if the Monitor is dropped, or if the cabinet becomes damaged,
disconnect the power cord plug immediately.
® A short may occur, which could cause fire. Contact an Authorized Service Center for any repairs that need to be
made.
Safety Precautions
When using the Monitor
Do not bring your hands, face or objects close to the ventilation holes of the Monitor.
® Top of Monitor is usually very hot due to high temperature exhaust air from ventilation holes. Burns or personal
injuries can happen if any body parts brought too close. Placing any object near the top of the display could also
result in heat damages to the object as well as to the Display due to its ventilation holes blocked.
Be sure to disconnect all cables before moving the Monitor.
e Moving the Display with its cables attached might damage the cables which in turn can cause fire or electric shock.
Cleaning and maintenance
The front of the display panel has been specially treated. Wipe the panel surface gently using only a soft, lint-
free cloth.
e |f the surface is particularly dirty, wipe with a soft, lint-free cloth which has been soaked in water to which a small
amount of neutral detergent has been added, and then wipe it evenly with a dry cloth of the same type until the
surface is dry.
® Do not scratch or hit the surface of the panel with fingernails or other hard objects. Furthermore, avoid contact with
volatile substances such as insect sprays, solvents and thinners, otherwise the quality of the surface may be
adversely affected.
If the cabinet becomes dirty, wipe it with a soft, dry cloth.
¢ If the cabinet is particularly dirty, soak the cloth in water to which a small amount of neutral detergent has been added
and then wring the cloth dry. Use this cloth to wipe the cabinet, and then wipe it dry with a dry cloth.
® Do not allow any detergent to come into direct contact with the surface of the Monitor. If water droplets get inside the
unit, operating problems may result.
® Avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the
cabinet surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods
in contact with articles made from rubber or PVC.
Disconnect the power plug from the wall outlet as a safety precaution before carrying out any cleaning.
e Electric shocks can result if this is not done.
Clean the power cable regularly to prevent it becoming dusty.
® Built-up dust on power cord plug can increase humidity which might damage the insulation and cause fire. Unplug
the cord from wall outlet and clean it with a dry cloth.
Note:
If still pictures from sources such as video games or computers are projected for long periods, the image may become
burned into the Monitor panel (producing an “afterimage”).
Accessories
Accessories Supplied
Check that you have the accessories and items shown I
Operating Instruction book
|
Remote Control Transmitter
TNQE192
Batteries for the Remote Control
Transmitter
(R6 (AA) Battery x 2)
Press and slide off the battery Insert batteries — note correct polarity
cover (+ and =)
Note:
(1) Make sure that the batteries are fitted properly.
(2) Do not mix old batteries with new batteries. Remove old, exhausted batteries immediately.
(3) Do not mix different battery types, i.e. Alkaline and Manganese. Do not use rechargeable (Ni-Cad) batteries.
Replace the cover
Quick Start Guide
Connect the Plug to the Wall Outlet
Power Indicator
How to Turn the Power On
POWER
—— — — ст
LL — a || |
=
!
POWER R B STAND BY
G + POWER ON
с
| |
Power Indicator
Power Switch
Push the Power switch on the color monitor to turn the set
on.
The Power Indicator will light.
Power-OFF............... Indicator not illuminated
Stand-by................... Red
Power-ON ................ Green
Select the input signal
| |
eit
("ана ЛР
= G3
INPUT
[oof] cox || | |
JE 0U0
ASPECT INPUT | —VOLUME+
INPUT Button
Press the INPUT button to select the input video signal to
be played back from the equipment such as a VCR which
has been connected to the Monitor.
Basic Controls
POWER RH STAND BY
Main P 6 | POWER ON
ain Power , CD
On/Off Switch | Т | ASPECT INPUT JO
Power Indicator
INPUT Button
corral Button Volume Adjustment
Brightness sensor
This sensor is used to automatically adjust the screen
brightness in accordance with the ambient light level
when AUTO has been set from the PICTURE menu,
to make the picture easier to see.
Recall Button — Stand-by (ON/OFF) Button
Push the “RECALL” Button to display The Monitor must first be switched on at the wall outlet and at
the current system status. the Power Switch. (See page 8)
Push this button to turn the Monitor ON, from STAND-BY mode.
Push it again to turn the Monitor to STAND-BY mode.
Remote control sensor
Off timer
MINPUT Mode
(® Aspect Mode (See page 16) — INPUT Button
(Power Save Mode (See page 25) Panasonic (AV(S-Video)Y Component Mode
@ Off timer ВЕ CT-34WDM Selection)
The off timer indicator is displayed only -34 60 Push the “INPUT” Button to select
when the off timer has been set. AV(S-Video)/Component video
POWER GAME INPUT input signal modes sequentially.
SLEEP (Off Timer) Button (7) G pes | Y
The Monitor may be preset to switch to GAME Button (see page 25
stand-by after a fixed period. RECALL MUTE | | (see page 25)
The setting changes to 30 minutes, 60 Lo | | e] Sound mute On/Off
minutes, 90 minutes and 0 minutes (off SLEEP |
timer cancelled) each time the button 77 (Fa ,
IS presses , = | Push the Volume Up “+” or Do
À 4 + WER SAVE VOL us e volume Up + or Down
=)30>E 160 —E'190 oe о “— Button to increase or decrease
Elo the sound volume level.
When three minutes remain, “Off timer ASPECT ~~ SELF ASPECT
The off timer is cancelled if there is a PICTURE AUDIO SURROUND (see page 16)
power outage. 2 JC SURROUND Button
POWER SAVE Button — MENU NORMAL page 24)
(see page 25) : | L AUDIO MENU Button
ASPECT-MANUAL Button —— (see page 22)
(see page 16) Normalization Button
PICTURE MENU Button (see page 18, 20, 21, 23)
(see page 19) AV ADJ. SCREEN ACTION Button
MENU Button
— | 0000 PICTURE POS SIZE Button
AV Adjustment Button
(see page 20, 23) Cursor Buttons to make
wa J selections and adjustments
Connections
For connecting video cameras
and TV game consoles.
Ze — 6006 желе
S1-VIDEOVIDEC L-AUDIO-R
These output VIDEO and AUDIO signals which are
HE input via the COMPONENT VIDEO INPUT terminals.
== (Signals from the VIDEO INPUT 1 to 4 terminals are not output.)
U т (+ \
O O O O — For connecting sources
VIDEO with Y,Ps,Pr output terminals
[Pe such as digital TV tuners,
> O O O O DVD players and digital
equipment adapters.
O OOO
©||© | © | ©
AUDIO
POE E.
PROG. 2 3 For connecting an audio amplifier.
ec LL These normally output audio signals
COMPONENT VIDEO that match the screen picture.
The Program output terminals
will pass through the video ТУ
and audio signals connected AN,
to the standard Video inputs ©)
1, 2, 3 and 4. _—
The signals connected to © ||e | © | © O
Component Video inputs 1, 2
or 3 are not output. ONONORNEO
oo ee
1 2 3
TO AUDIO
For connecting video equipment
such as a VCR.
Note :
Switching of each input signal can be done in either of two modes : “AUTO” or "MANUAL".
Please refer to INPUT SWITCH MODE on page 26 for further details.
10
Connections
How to connect the AV Input Terminals
S-VIDEO Signal Connection
(S-VIDEO VCR) e
o 000 000 99 O
Audio Video S-Video | O 2 (o)
(9) OJFONO
+ Video input to A
— S-VIDEO jack
| =
VIDEO
AUDIO Fld >
2 x Audio cables ”
(Phono pin type) Audio input to L/R jacks
Video Signal Connection
=>00
@|© ©
| DO | ©
AUCHO-A O ® ®
Video c
able
Video input to
VIDEO jack
PROG.OUT
- @®@ © ©
ONO,
TG AUDIO
AMP
(Phono pin type) uf
2 x Audio cables
(Phono pin type)
Note:
am
Audio input to L/R jacks
(1) Additional equipment and cables shown are not supplied with this set.
(2) When connecting video cables, priority is given to the S-Video cable when the S-Video input terminal
and the video input terminal are connected at the same time.
S-Video 4 pin socket
Chrominance in Luminance in
co
Chrominance earth Luminance earth
© ©
TÓ AUDIO
AMP
x
A
11
Connections
How to connect the AV Prog. Out Terminals
S-VIDEO Signal Connection
(S-VIDEO VCR)
VIDEO
© ©
AUDG-A
[aupioL +
{ AUDIO-R Pp
9,000:
- © © © © -
- OOOO:
- ©©®
PAG. OUT INPUT
LAS nit
Lal
Video output to
S-VIDEO jack
2 x Audio cables
(Phono pin type) Audio output to L/R jacks
Video Signal Connection
© ©® © -
- © © © © -
КОЛОДОК Е
- © © ©
Video output to
VIDEO jack
VIDEO
Video cable
(Phono pin type) uf
2 x Audio cables
(Phono pin type) Audio output to L/R jacks
AUDIO
Note:
(1) Additional equipment and cables shown are not supplied with this set.
(2) When connecting video cables, priority is given to the S-Video cable when the S-Video input terminal
and the video input terminal are connected at the same time.
12
Connections
How to connect the AV Input Terminals
S-VIDEO Signal Connection
(VIDEO CAMERA) (TV GAME)
© (9) (®)- (©) МРОТ
S1 VIDED VIDED L-AUDIO-F
>
Video input to S-VIDEO jack
AUDIO rama
2 x Audio cables |
(Phono pin type) Audio input to L/R jacks
Note:
{1) Additional equipment and cables shown are not supplied with this set.
(2) If the component to be connected has no S-VIDEQ signal output terminals, connect to the VIDEO terminals.
How to connect the AUDIO Output Terminals
AUDIO Signal Connection
(AUDIO AMP)
O co [vioeo > O (9) (9) [auDio-A > oN
TT ©|©|®, © |
OOO ©
AUDIO rf +
2 x Audio cables Cam > )
(Phono pin type) Audio output to L/R jacks
Note:
(1) Additional equipment and cables shown are not supplied with this set.
13
Connections
How to connect the COMPONENT VIDEO Input Terminals
Component signals (Y,Ps, Pr) Connection
DVD Player
||
В Digital TV tuner « DS oo
or | _ | EOS © | ©
a © @|©
O ©) |© | ©
© e © ©
Video input to o |
Y,Pe,Pr jacks
me >
3x Video cables
{Phono pin type)
AUDIO
ramo >
2 x Audio cables
(Phono pin type)
Note:
Sam >
Audio input to L/R jacks
Additional equipment and cables shown are not supplied with this set.
How to connect the COMPONENT VIDEO Prog. Out Terminals
Component signals (Y,Ps, Pr) Connection
; oh
ORORNONONR
© © © ©
о о ооо
© © © © ©
+
=
2
9
©
®
x
с
©
№
=
z
[|
A 1 3
[4] INPUT
COMPONENT YIDEO
Video output to
Y, Pa, Pa jacks
3 x Video cables
(Phono pin type)
Monitor |
Je
+ + т
AUDIO
Y,Ps,Pe | =
amo >
2 x Audio cables
(Phono pin type)
Note:
anf >
Audio output to L/R jacks
Additional equipment and cables shown are not supplied with this set.
14
Flowchart of Menu
If the MENU button is pressed, the Menu screen will be displayed.
If the MENU button is pressed once more while the menu screen is displayed, the Menu screen will be cleared.
Menu On-Screen Indication
@r Sur | ACTION PONE You adjust
"<> CHANGE
PICTURE ADJ. PIGTURE MEN AUTO
[color [o] +3]
va
AUDIO ADJ. =>
— lo TINT 0
PICTURE ADJ. | OTHER ADJ. ee ——
SET UP PICTURE
ESHARPNESS 0
(Refer to COLOR TEMP
page 20.) ADVANCED NO
JL [Y] (MENU) END NORMALIZE
Bp §=e| ACTION [ESI ge Tono
(==) AUDIO MENU MUSICA
>
—_—— TREBLE
AUDIO ADJ. OTHER ADJ. BALANCE
SET UP CENTER VOL.
SPEAKERS
{Refer to BBE SOUND 18
page 23.)
Cm =
Bp © seecr ACTION OTHER ADJ. <S> S SELECT
— (em!
PICTURE ADJ. PICTURE OFF MDN
Fo 3D Y/C FILTER
OTHER ADJ. SELECT
PAGE 27 <S> ® CHANGE
OVC PLAYBACK MODE
J
|
wh Le
AUDIO ADJ. FRAME |
OTHER ADJ. 10-1
FRAME/LINE —
SET UP LINE ||
INPUT SWITCH MODE
(Refer to | MANUAL
page 26.) 480p COLOR MATRIX
LÀ — E]
(MENU)
<S> Ser] ACTION [SETUP
CO ACTION
PICTURE ADJ. INPUT LABEL
| SELF ASPECT 4:3
AUDIO ADJ. =>
LL JUST
SET UP OTHER ADJ. GEQMAGNETIC CORRECT |
Cl ACTION
C END
SET UP REMOTE CONTROL Osmeet |
(Refer to
page 28.)
The color monitor will allow you to enjoy viewing the picture at its maximum size, including wide screen “cinema format”
vr
E— Л
(1) For a 480p signal input during “Component” input signal
mode, the mode switches between “ZOOM” and “FULL”
only.
(2) When a 10801 signal is being received, the mode is set to
“FULL” mode, and switching is not possible.
picture.
1 SELFASPECT SELF ASPECT Button
Press the SELF ASPECT button to switch to
SELF ASPECT mode. The display will
automatically become enlarged.
CT-34WDM60 =
POWER GAME INPUT Q e O O
E For an elongated image Image is expanded
RECALL MUTE
— J O O Changes in accordance with
the SELF ASPECT mode
a. = setting. {Refer to page 28.)
POWER SAVE VOL
= о О
ASPECT SELF ASPECT For a 4:3 image
2 Е | 1
"MENU MENU SURROUND Note:
LJ CJC] (1) If a 480p or 10801 signal is input during Component input
= 7 NORMAL signal mode, the controls will not operate.
A
ACTION
(mm)
2 ASPECT ASPECT Button
PD) CT) The aspect mode changes each time the
AV ADJ. SCREEN ASPECT button is pressed.
N—
Ш —> ZOOM
JUST €— FULL J
16
ASPECT Controls
Mode Picture Explanation
NORMAL will display a 4:3 picture at its
| 4 — standard 4:3 size and can be selected if you
NORMAL O | wish to view in this format.
NORMAL
al |
ZOOM mode magnifies the central section of
4 1 |- 16 da the picture.
O O | ~~ |
ZOOM 3 > 9
O O | A m |
FULL will display the picture at its maximum
4 A size but with slight elongation.
O O |
FULL
3
ll
JUST mode will display a 4:3 picture at
° 4 a maximum size but with aspect correction
O O | applied to the center of the screen so that
JUST à elongation is only apparent at the left and right
| edges of the screen. The size of the picture will
O O + depend on the original signal.
Note:
(1) The S-Video terminal on this set can detect specially encoded signals that are compatible with wide screen monitors.
When a full image from the S-Video terminal of specially encoded video is detected by the set, the screen size
automatically sets to “FULL” mode.
(2) The screen size also changes if ID-1 is detected.
(3) The screen size will also change if S1 detection has been set.
17
PICTURE POS./SIZE Controls
1 es SCREEN Button
SCREEN When the SCREEN button is pressed, the
Picture Pos./Size menu appears, and the
picture size and vertical picture position can
then be adjusted.
The adjustable items and adjustment ranges
vary for each input signal and aspect mode.
During “AV(S-Video)” and “Component” input signal modes
Panasonic | The Position Left “4” and Ri
ght («4 ] (pp | [POSITION ADJ.
CT-34WDM60 “D>” buttons can be used to Er Pom
| change the picture size. [SIZE Pa
POWER GAME INPUT GE e
LI DJ] The Position Up “4” and Down
RECALL MUTE “Y” buttons can be used to adjust
[| es the vertical picture position. y)
SLEEP
|| Button Picture
POWERSAVE VOL Changing the size | Example : “NORMAL” mode
[=]
ASPECT SELF ASPECT
[J LJ JD) - “fl >> e
PER RG SRD
un
MENU NORMAL Moving the vertical
Jai) position (up) J
ACTION O O
(©) (==) (5) E -
FO 1 Moving the vertical
AV ADJ. SCREEN position (down) +
— — (NT
Note:
Ni J (1) The picture size cannot be changed in “ZOOM” mode when a
480p component signal is being input.
(2) The vertical position cannot be changed when Size 1 and Size
2 have been selected in “NORMAL” mode and when Size 1 has
been selected in “FULL” mode. In addition, the vertical position
cannot be changed when 1080i signals are being input.
‘g- Helpful Hint ("®4' Normalization)
If the NORMAL button on the remote control unit is pressed when the POSITION ADJ. display is active, all adjustment
values will be returned to the factory setting level.
18
PICTURE MENU Controls
1 rene PICTURE MENU Button
The setting changes each time the button is
pushed.
on —> STANDARD
DYNAMIC <— CINEMA a
Panasonic
CT-34WDM60
POWER GAME INPUT
LH (JL
RECALL MUTE
CJ as
SLEEP '
| [ PICTURE MENU [AUTO
POWER SAVE VOL
=
Sa EL The screen brightness is adjusted
PICTURE AUDIO SUARDÓND AUTO automatically in accordance with the ambient
MENU MENU light level to make the picture easier to see.
1 Е) С)
MENU NORMAL For viewing in normal (evening lighting)
environments.
STANDARD This menu selects normal levels of Brightness
and Contrast.
CINEMA Select when viewing video tapes or similar.
AV ADJ. SCREEN For viewing in brighter environments.
DYNAMIC This menu selects higher than normal levels of
~—— Brightness and Contrast.
Note:
(1) If you would like to change the picture and color of the selected
№ J PICTURE MENU to something else, adjust using the “PICTURE
ADJ.” menu command in the Menu. (Refer to page 20.)
(2) will be set during game mode.
(3) If the picture brightness changes so that the picture becomes
difficult to see when “AUTO” is set, change the PICTURE MENU
setting to a different setting.
19
PICTURE ADJ. Menu
1.Push the “MENU” Button.
2.Select the “PICTURE ADJ.” Menu by pushing
the Position Up “A” or Down “Y” Button and
Access the "PICTURE ADJ.” Menu by pushing
the “ACTION” Button.
3.5elect the required function by pushing the
Position Up “4” or Down “ Y” buttons, and
access and alter the setting by pushing the
Position Left “€” or Right “»>” buttons.
=
m
=
<
de del
"e 1:
=
=>
1,2 | «©» © == | 3 PICTURE ADI
9 ACTON
SET UP
PICTURE ADJ.
AUDIO ADJ.
OTHER ADJ.
E
> SELECT
<J [> CHANGE
TINT
BRIGHTNESS
SHARPNESS
COLOR TEMP
ADVANCED
(HERD) END
PICTURE MENU AUTO
39 | -
0 1:
(HORMAL) NORMALIZE
Note:
(1) You can change the level of each Function
(COLOR, TINT, BRIGHTNESS, PICTURE,
SHARPNESS, COLOR TEMP, ADVANCED)
for each picture Menu.
(2) The adjustment details are stored separately
for each PICTURE MENU setting.
a function.
to adjust.
1.Push the 453, button to select
2.Use the (J and (>) buttons
* Refer to page 23 for audio
function adjustments.
AY ADJ.
All functions other than ADVANCED can also be
adjusted using the AY adjustment button CJ.
Audio
functions functions
BRIGHTNESS
COLOR TEMP
Note:
(1) If the “ADVANCED” setting is changed to YES
and the Position Down “ Y” button is pressed,
the ADVANCED Menu will be displayed.
(Refer to page 21.)
(2) The adjustment range values should be used
as an adjustment reference.
Item Effect Adjustment range
COLOR < > 30 ——— 30
TINT 4 > -30 151] 30
BRIGHTNESS « La 15 5—— 15
PICTURE < > 30 — 30
SHARPNESS < > 155=—x—315
COLOR TEMP < > Warm / Normal / Cool
* ADVANCED | < D No / Yes
x ADVANCED can only be selected when the PICTURE MENU
setting is STANDARD or CINEMA.
‘g- Helpful Hint ("®4' Normalization)
If the NORMAL button on the remote control unit is pressed when the “PICTURE ADJ.” menu is displayed, all
adjustment values will be returned to the factory setting level of each picture mode.
20
PICTURE ADJ. Menu (ADVANCED Menu)
1.Use the Position Up “47 or Down “ Y” buttons
ES SELECT 3
PICTURE MENU STANDARD
to select the “ADVANCED” menu from the 14) = 9 De PAE © sued ADVANCED SD Ski
Y]
“PICTURE ADJ.” menu, and then use the
Position Right “X” button to select “ON”.
2.Press the Position Down * Y ” button.
(The “ADVANCED” menu screen will thenbe [wr |
displayed.)
3.Select the required function by pushing the
Position Up “A” or Down “VW” buttons, and [A] (<)
access and alter the setting by pushing the Y) => (>)
Position Left “4” or Right “>” buttons.
COLOR BLACK EXTENSION
TINT
BRIGHTNESS =] WHITE CHAR CORR
PICTURE 30 | ——
SHARPNESS Û COLOR TEMP CORA
COLOR TEMP
END
(MENU) END NORMALIZE
Item Effect Adjustment range Details
VM gain <4 > 0 (No correction) Adjusts the emphasis for the vertical
Less More 15 (Strong correction) contours.
Black 4 > 9 (Black metas are lighter) Adjusts the tone gradations for
extension Less More 15 (Black details are darker) medium to dark areas.
White 0 (No correction) Emphasizes the whiteness of parts
character < > such as white characters
correction Less More 15 (Strong correction) -
Color -7 (Low color temperature)<Reddish> Allows further fine adjustment of the
temperature < 4 l color temperature which has been
correction Less More +7 (High color temperature)<Bluish> selected from the PICTURE menu.
Note:
(1) The adjusted values are memorized separately for each PICTURE M
ENU (STANDARD/CINEMA).
{2) The adjustment range values should be used as an adjustment reference.
‘g- Helpful Hint ("®* Normalization)
If the NORMAL button on the remote control unit is pressed when the “ADVANCED” menu is displayed, all
adjustment values will be returned to the factory setting level.
21
AUDIO MENU Controls
CT-34WDM60
POWER GAME INPUT
0
RECALL MUTE
(J CJ
SLEEP
[|
POWERSAVE VOL
(=)
ASPECT SELF ASPECT
PETE TRIS SURROUND
>
1 axe
©
AUDIO MENU Button
The setting changes each time the button is
pushed.
— STANDARD > AUTO
— MUSIC? <— MUSIC1 <
AUDIO MENU [AUTO |
STANDARD
Reproduces the same sound as the input
signal.
MENU —_ NORMAL
mil
ACTION
|=)
|] 19) ||
AVADJ. SCREEN
~~—
AUTO
Automatically distinguishes between
conversation and music to make the sound
easier to hear.
MUSIC1
Enhances the treble sound range [around 4
kHz] for programs consisting primarily of
music.
u)
MUSIC2
Further enhances the treble sound range
(around 4 kHz).
(This function is recommended for elderly
people who have some trouble hearing treble
ranges.)
Note:
(1) will be set during game mode.
(2) AUDIO MENU settings (MUSIC1 and MUSIC?) automatically
adjust the sound output so that quiet sounds which are difficult to
hear and sudden increases in volume are made easier to listen to.
(Automatic audio level adjustment ... the number showing the
adjustment leve! set using the VOL buttons remains unchanged.)
22
AUDIO ADJ. Menu
1.Push the “MENU” Button. MENU 1,2 Ep © we 3 AUDIO ADJ. yr, © seer
2 Select the “AUDIO ADJ.” Menu by pushing the — ro pan
Position Up “A” or Down “VW” Button and (A) ACTION TREBLE
Access the “AUDIO ADJ.” Menu by pushing OTHER ADJ. ——
the “ACTION” Button. Ka SET UP ENTER VOL
3.Select the required function by pushing the
Position Up “A” or Down “VW” buttons, and [a] EE pe e
access and alter the setting by pushing the =>
LY) (>)
Position Left “«” or Right “>” buttons. Eon
SPEAKERS
Note:
: All functions can also be adjusted using
(1) You can change the level of each Function .
(BASS, TREBLE, BALANCE, CENTER VOL., | | the AV adjustment button OD.
SPEAKERS, BBE SOUND) for each AUDIO 1.Push the =, button to select Audio | Picture |
Menu. a function. functions functions
(2) The adjustment details are stored separately SASS
for each AUDIO MENU setting. 2.Use the (© and (>) buttons o Ss Te =
to adjust. CENTER VOL, BRIGHTNESS
* Refer to page 20 for picture
function adjustments.
Note: )
(1) “BBE SOUND" adjusts the clarity of the sound. tem Eftect Adjustment range
An adjustment value of “0” is for normal sound. BASS 48 | +
(2) When AUDIO MENU is set to “Auto”, the “Bass” < > rx]
and “Treble” settings cannot be adjusted. - | N
Furthermore, “BBE SOUND” is set to either TREBLE < > 1591
“Off or “Auto”. < >
(3) Adjustment values other than the “Balance” BALANCE -30 7 | + 30
value are memorized separately for each Lei SP. Right SP. A
AUDIO MENU (STANDARD/AUTO/MISIC1/
MUSIC2). CENTER VOL. 4 > OFF / LOW / NORMAL / HIGH
(4) The adjustment range values should be used
as an adjustment reference. SPEAKERS | 4 } OFF / ON
(5) “CENTER VOL.” adjusts the volume of the
sound from the center speaker. BBESOUND | 4 > lo —] 30 (Off or Auto) *
(6) “SPEAKERS” turns the sound from all Less More
speakers (left, right and center) on and off, x Only when “Auto” has been selected from the “AUDIO ADJ.”
Menu,
‘о Helpful Hint ('*“ Normalization)
if the NORMAL button on the remote control unit is pressed when the “AUDIO ADJ.” menu is displayed, all
adjustment values will be returned to the factory setting level of each sound mode.
23
SURROUND Controls
Panasonic
CT-34WDM60
POWER GAME INPUT
CI 3
RECALL MUTE
as С)
SLEEP
[_]
POWERSAVE VOL
(=)
ASPECT SELF ASPECT
PICTURE AUDIO SURROUND
[|
|
MENU NORMAL
xi
ACTION
Jv)
AVADJ. SCREEN
au
—
J
1 SURROUND Surround Button
0 The benefits of surround sound are
enormous. You can be completely enveloped
In sound; just as if you were at a concert hall
or cinema.
The surround setting switches on and off each
time the SURROUND button is pressed.
ON <— OFF
SURROUND [ ON ]|
Note:
(1) The surround settings are memorized separately for each input
terminal (AV, COMPONENT).
24
Other Useful Functions
Panasonic
CT-34WDM60
POWER GAME INPUT
(AJ LU
RECALL MUTE
J) |
SLEEP
(3
POWERSAVE VOL
1177-53 =
ASPECT SELF ASPECT
"MENU. MENU SURROUND
MENU NORMAL |
AV ADJ. SCREEN
N~e— ee
U
2
1 POWER SAVE POWER SAVE Button
The setting changes each time the button is
pushed.
STANDARD <—> SAVING
| POWER [SAVING]|
SAVING ......... Reduces the peak luminance in scenes which are
particularly bright to produce a more natural-looking
picture and to reduce power consumption.
STANDARD... Shows the picture according to the PICTURE MENU
setting selected or at the brightness level which you
have selected.
Note:
(1) The effectiveness of the “SAVING” setting will be reduced when
the PICTURE MENU setting is “CINEMA” or during GAME mode.
(2) The “SAVING” and “STANDARD” settings are retained when the
power is turned off and on.
2 GAME GAME Button
The mode switches to GAME mode when this
button is pushed.
The screen switches between the GAME
screen for the console connected to the
VIDEO INPUT 4 terminal and the original input
picture each time the button is pushed.
GAME
Elapsed time - -|------------------- GAME 30
The display disappears after GANE 60
90 minutes have passed. [GAME 90
Note:
(1) The “GAME” setting is retained when the power is turned off and on.
(2) Refer to pages 20 and 23 for details on adjusting the picture and
sound to the desired levels.
25
OTHER ADJ. Menu
1.Push the “MENU” Button. MENU 1,2 Bp © э=2т 3 OTHER ADJ. «Sp @ ===!
2.Select the "OTHER ADJ.” Menu by pushing PICTURE ADJ. PICTURE — | OFF COM
the Position Up “A” or Down a A Button and | ACTION AUDIO ADJ. | => 30 Y/C FILTER
Access the “OTHER ADJ.” Menu by pushing => (zum) OFF
A) OTHER ADJ.
de I FRAMEAINE
the “ACTION” Button. Y) SET UP LINE
3.Select the required mode by pushing the
Position Up “A” or Down “Y” buttons, and set AUTO | MANUAL
the appropriate function by the Position Left Y] => Г») 480p COLOR MATRIX
INPUT SWITCH MODE
“<4” or Right “Pp” buttons. Ce JDE
. (MENU) END
Note: OTHER ADS. gp © SELECT
(1) The “OTHER ADJ.” menu comprises two DVC PLAYBACK MODE
pages.The page displayed will change [Norma NT
automatically when the (A ) and (Y ) buttons ID-1 OFF
are pushed. (VENU) END
Mode Function
PICTURE Set to “OFF” if you would like to turn off the picture and only listen to the sound.
* Pictures will always be output from the PROG OUT terminal at the rear of the unit even if
this setting is changed to “OFF”.
This setting will return to “ON” if the channel is changed or if the power is turned off and
back on.
3D Y/C FILTER | Set to “OFF” in order to view the picture in its natural format.
* This setting cannot be changed for signals being input to the S INPUT 1, 2 and 4 terminals
or the COMPONENT VIDEO INPUT 1 to 3 terminals.
FRAME / LINE Set to “LINE” mode only when using a Video Game machine.
* This setting cannot be changed for 480p, 1080i video signals.
INPUT “AUTO”... The input ts selected automatically to match the component connected, such as a
SWITCH digital TV tuner.
MODE The input changes as follows each time the INPUT button is pushed.
VIDEO1 VIDEO? VIDEO3
or” —> or” — or VIDEO4
COMPONENT VIDEO! COMPONENT VIDEO? COMPONENT VIDEOS
|
* If components have been connected to both the VIDEO and COMPONENT
VIDEO terminals, the COMPONENT VIDEO signals will have priority.
“MANUAL”... The input changes as follows each time the INPUT button is pushed.
| VIDEO! > VIDEO | VIDEO3 —X VIDEO4 |
T
| COMPONENT VIDEQ3k— COMPONENT VIDEO2 <— COMPONENT VIDEO! K-————
(Only when connected) (Only when connected) (Only when connected)
26
OTHER ADJ. Menu
Mode Function
480p COLOR If the output signals from the source connected to the COMPONENT VIDEO input terminals
MATRIX are in 480p format, the colors in the images from this source will be set to their natural colors.
e SD........ If the signals are in current TV format (NTSC).
e HD........ If the signals are 480p video signals.
DVC If watching a norma! image, select the “NORMAL”.
PLAYBACK If the recording mode used for a device such as a digital video camera is “Frame”, select the
MODE “Frame” to obtain a higher-quality playback image.
Note:
(1) This can only be changed for VIDEO 1 to 4 and GAME screen input.
(2) If normal playback images are viewed using the “FRAME” setting, sections of movement in
these images may look unnatural. If this happens, select “NORMAL”.
ID-1 If the video signals input to the VIDEO INPUT 1 to 4 terminals or the 480i signals input to the
COMPONENT VIDEO INPUT 1 to 3 terminals have a screen size identification signal
component, the screen size will change automatically.
e ON ....... When a screen size identification signal is detected, the screen size changes
automatically.
e OFF...... The screen size does not change automatically.
(If this function does not work correctly, set to “OFF”.)
27
Set up Menu
1.Push the “Menu” Button.
2.5elect the “Set up” Menu by pushing the
Position Up “A” or Down “ Y” Button and
access the “Set up” Menu by pushing the
“ACTION” Button.
=
m
<=
€
ACTION
=> ба)
db 1
nm E SELECT SET UP
3
2? cmon |
PICTURE ADJ. Cr
RI SELF ASPECT 4:3
D . |
( AUDIO ADJ. | > NORMAL] JUST ||
OTHER ADJ. | GEOMAGNETIC CORRECT
SET UP REMOTE CONTROL D SELECT
= QO ACTION
OD END
INPUT LABEL (Video input labels can be rewritten according to the connection of VCR, DVD, etc.)
1.Select the “INPUT LABEL” by pushing the
Position Up “A” or Down “VW” Button and
access the “INPUT LABEL” Menu by
pushing the “ACTION” Button.
2.Push the Position Up “47 or Down “Y”
Button to select the desired input mode,
and then push the Position Left "« or Right
“>” Button to change the display.
ACTION
(a)
~ = =
[4) (JJ
T°”
INPUT LABEL
WDEO3 Ze » VIDEO3 — VCR
VIDEOA
COMPONENT!
VIDEO
VIDEO?
(BLANK) — LD
COMPONENT2 HD-VCR GAME
COMPONENT3 [COMPONENTS]
COMPONENTS [COMPONENTS] DTV <— DVD
REMOTE CONTROL DO SELECT
CHANGE
Cl END
SELF ASPECT 4:3
1.Select the “SELF ASPECT” by pushing the
Position Up “A” or Down “VW” Buttons, and
set appropriate function by pushing the
Position Left “4” or Right “>” Buttons.
=>
<>
ula
Set to NORMAL" if using the SELF ASPECT
button function to view 4:3 images in an
unchanged format. If you would like to view
4:3 images in “JUST” format, set to JUST”,
GEOMAGNETIC CORRECT (Adjust if the picture is tilted slightly due to the effects of geomagnetism.)
1.Select the “GEOMAGNETIC CORRECT”
by pushing the Position Up “A” or Down
“Y” Button and Access the Adjusting mode
by pushing the “ACTION” Button.
2.Push the Position Left “4” or Right ">"
Button to adjust the picture tilt.
3.Push the “ACTION” Button to complete the
adjustment.
e When the “ACTION” Button is pushed, a
click will be heard and “DEGAUSSING”
will appear on the screen. (The picture
will become distorted for a moment.)
e When another click is heard, the display
[4) ACTION
v= =
<a
>)
ACTION
(am)
will disappear and the setting will be complete.
Note:
(1) If the setting-up location or direction is changed, readjustment will
be necessary.
(2) if color distortion continues to appear after adjustment because
the TV is being affected by magnetism from causes such as
reinforced concrete, turn off the power and change the setting-up
location. After turning the power back on, wait about 20 minutes
and then repeat the adjustment.
GEOMAGNETIC CORRECT
REMOTE CONTROL
3 D AOJUST
0 END
|
Adjustment
Adjust so that the
value line is horizontal.
Screen Adjustment
direction value guide
North Approx. 15
East or west Approx. 31
South Approx. 45
28
Troubleshooting
Before you call for service, determine the symptoms and make a few simple checks as shown below.
Symptoms
Checks
Picture Sound
A Volume
(> (Check whether the mute function has been
activated on the Remote Control.)
Check speakers ON/OFF in Audio ADJ. Menu.
Normal Picture No Sound
M Not plugged into AC outlet
> (2 Not switched on
м Contrast and Brightness/Volume setting
AN (Check by pushing the Power Switch or
No Picture No Sound Stand-by Button on the Remote Control.)
No Color
À
>
2
Normal Sound
Color controls set at minimum level.
y
No Picture
4
>
Ч
Normal Sound
PICTURE “OFF”
(Refer to page 26)
29
Specifications
| Power Source
120 V AC, 50/60 Hz
| Power Consumption
Normal use: 214 W (Maximum Current 3.3 A)
Stand-by condition: 0.35 W
| CRT
34-inch, 16:9 aspect ratio
Screen size
29.36"(745.9 mm) (W) x 16.5"(419.5 mm) (H) x 33.68"(855.7 mm) (diagonal)
| Operating conditions
Temperature: 34°— 104°F (0°— 40°C)
Humidity: 20% — 80% (non-condencing)
| Connection terminals
AY INPUT 1-4
INPUT 3 has no
S-VIDEO terminal.
AV PROG. OUT
TO AUDIO AMP
COMPONENT VIDEO
INPUT1-3
COMPONENT VIDEO
PROG. OUT
VIDEO
(Phono Jack Type)
S-VIDEO
(Mini DIN 4-pin)
AUDIO L-R
(Phono Jack Type x 2)
VIDEO
(Phono Jack Type)
S-VIDEO
(Mini DIN 4-pin)
AUDIO L-R
(Phono Jack Type x 2)
AUDIO L-R
(Phono Jack Type x 2)
Y
PB/PR
AUDIO L-R
. (Phono Jack Type x 2)
Y
Рв/Рв
AUDIO L-R
(Phono Jack Type x 2)
1.0 Vp-p (75 Q)
Y: 1 Vp-p (75 Q),C: 0.286 Vp-p (75 Q)
0.5 Vrms
1.0 Vp-p (75 Q)
Y: 1 Vp-p (75 Q),C: 0.286 Vp-p (75 Q)
0.5 Vrms
0.5 Vrms
1.0 Vp-p (including synchronization)
+ 0.35 Vp-p
0.5 Vrms
1.0 Vp-p (including synchronization)
+ 0.35 Vp-p
0.5 Vrms
30
Specifications
| Accessories Supplied
Remote control Transmitter TNQE192
Battery (2 x R6 (AA) Size)
Warranty
| Dimensions (W x D x Н)
34.4"(874mm) x 23.15"(588mm) x 25.1" (637mm)
| Weight (Mass)
180.8 Ib.(82kg) Net
Note:
Design and Specifications are subject to change without notice. Weight and Dimensions shown are approximate.
Sound “BBE” has been created under license from BBE Sound Incorporated.
BEE is a registered trademark of BBE Sound Incorporated.
31
Customers Record
The model number and serial number of this product can be found on its rear cover. You should note
this serial number in the space provided below and retain this book plus your purchase receipt as a
permanent record of your purchase to aid in identification in the event of theft or loss, and for Warranty
Service purposes.
Mode! Number CT-34WDM60 Serial Number
Ee
Panasonic Consumer Electronics Panasonic SALES Company
Company, Division of Matsushita Division of Matsushita Electric of
Electric Corporation of America Puerto Rico Inc. (“PSC”)
One Panasonic Secaucus Ave. 65 de Infanteria, Km 9.5
New Jersey 07094 San Gabriel Industrial Park,
Carolina, Puerto Rico 00985
Printed in Japan
S0399-0A

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
