MSI Mega 651 Barebone

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and AC. power cord, if any, must be used in order to comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU RESEAU.

Micro-Star International MEGA 651

Tested to comply

with FCC Standard

For Home or Office Use ii

Lithium Battery Statement

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufactuer. Discard used batteries according to the manufacturer’s instructions.

Macrovision ® Statement

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing users only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

iii

Safety Instructions

Always read the safety instructions carefully.

Keep this User’s Manual for future reference.

Keep this equipment away from humidity.

Lay this equipment on a reliable flat surface before setting it up.

The openings on the enclosure are for air convection hence protects the equipment from overheating. DO NOT COVER THE OPENINGS.

Make sure the voltage of the power source and adjust properly 115/230V before connecting the equipment to the power inlet.

Place the power cord such a way that people can not step on it. Do not place anything over the power cord.

Always Unplug the Power Cord before inserting any add-on card or module.

All cautions and warnings on the equipment should be noted.

10.

Never pour any liquid into the opening that could damage or cause electrical shock.

11.

If any of the following situations arises, get the equipment checked by a service personnel:

- The power cord or plug is damaged.

- Liquid has penetrated into the equipment.

- The equipment has been exposed to moisture.

- The equipment has not work well or you can not get it work according to

User’s Manual.

- The equipment has dropped and damaged.

- The equipment has obvious sign of breakage.

12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

UNCONDITIONED, STORAGE TEMPERATURE ABOVE 60 0 C (140 0 F), IT MAY

DAMAGE THE EQUIPMENT.

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the manufacturer.

Copyright Notice

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document, but no guarantee is given as to the correctness of its contents. Our products are under continual improvement and we reserve the right to make changes without notice.

Trademarks

All trademarks are the properties of their respective owners.

Intel ® and Pentium ® are registered trademarks of Intel Corporation.

PS/2 and OS ® /2 are registered trademarks of International Business Machines

Corporation.

Windows ® 95/98/2000/NT/XP are registered trademarks of Microsoft Corporation.

Netware ® is a registered trademark of Novell, Inc.

Award ® is a registered trademark of Phoenix Technologies Ltd.

AMI ® is a registered trademark of American Megatrends Inc.

Revision History

Revision

V1.0

V1.1

v1.2

v1.3

v1.4

Revision History

First release

Date

April 2003

Add “Media Center” and “Appendix” June 2003

Make update on p. 1-7 & 3-3

Replace v1.0

Special Edition for SI

Remove “Media Center”

Replace v1.1

Update Chapter 3

Replace v1.3

July 2003

Sep. 2003

Introduction

Chapter 1. Getting Started......................................................................1-1

All-in-One Feature Set.......................................................1-2

Front Panel...............................................................1-3

Back Panel.........................................................................1-3

System Specification.....................................................................1-4

Performance PC ............................................................................1-6

Hi-Fi Audio...................................................................................1-8

Home Theater...............................................................................1-10

Chapter 2. Introducing Mainboard...........................................................2-1

Mainboard Layout..........................................................................2-2

CPU/Memory.................................................................................2-3

Introduction to DDR SDRAM................................................2-3

Power Supply.................................................................................2-4

Front Panel...................................................................................2-5

IEEE 1394 Port: J1394-2.......................................................2-5

IEEE 1394 Port: J1394-1........................................................2-6

USB Ports.........................................................................2-6

Mic-in/Head-Phone.............................................................2-7

OPTICAL SPDIF-in..............................................................2-7

Back Panel..................................................................................2-8

Serial Port...........................................................................2-8

VGA Port...........................................................................2-9

Mouse/Keyboard Connectors..............................................2-9

RJ45 LAN Jack..................................................................2-10

USB Ports.............................................................................2-10

OPTICAL SPDIF-out.........................................................2-10

Parallel Port........................................................................2-11

Audio Port..........................................................................2-12

Connectors.................................................................................2-13

IDE Connectors: CN22 & CN23............................................2-13

FDD Connector: CN10.................................................... 2-13

CD-in Connector: CN16......................................................2-14

TV-Tuner Card Connector: CN13...........................................2-14

CPU Fan Connector: CN15.................................................2-14

Front Panel Power Connector: CN4..................................2-15

USB Card Reader Connector: CN6........................................2-15

LCM Connector: CN18.................................................2-16

Modem Module Connector: CN21...........................2-16

Jumper.............................................................................2-17

Clear CMOS Jumper: J2.............................................2-17

Slots......................................................................................2-18

PCI Slot.......................................................................2-18

AGP Slot......................................................................2-18

Chapter 3. Using Audio Function........................................................... 3-1

Introduction.........................................................................3-2

Control Panel..............................................................................3-3

Remote Controller........................................................................3-4

AC Power on................................................................................3-5

Playing CD/MP3 in Hi-Fi Mode.....................................................3-6

Playing FM/AM in Hi-Fi Mode..................................................3-10

Using Audio Function in PC Mode.........................................3-12

Radio Mode.....................................................................3-12

CD\MP Mode......................................................................3-13

Chapter 4: Setting BIOS Function..................................................4-1

Entering Setup..............................................................................4-2

Control Keys..................................................................4-2

Getting Help................................................................4-3

Main Menu........................................................................4-3

Sub-Menu.....................................................................4-3

General Help<F1>............................................................4-3

The Main Menu.............................................................................4-4

vii

Standard CMOS Features.........................................................4-6

Advanced BIOS Features...........................................................4-8

Advanced Chipset Features...........................................................4-11

Integrated Peripherals..............................................................4-13

Power Management Setup.......................................................4-19

PNP/PCI Configurations............................................................4-23

PC Health Status......................................................................4-25

Frequency/Voltage Control...........................................................4-26

Appendix. Using Mega Radio.................................................................A-1

Listening to Radio.........................................................................A-2

Setting Memory Station.................................................................A-6

Recording Music...........................................................................A-7

viii

Introducing Y our

Introduction

Thank you for your purchasing of MEGA 651, the Best of Computing &

Home Entertainment. Based on the design idea of consumer product, the MEGA

651 is not just a PC anymore. The “All-in-One” feature positions MEGA 651 as a

Digital Media Platform.

From the recent years, the ownership and usage of desktop and notebook

PCs across W.W. households has turned computers into a commodity item. While

Microsoft strongly promotes the “Media Center” platform concept “Windows XP

Media Center Edition” on HP “Free Style”, Intel is also exploring their “Digital

Home” concept for the “Home-use” PC.

To meet the new concept of Home PC, the MEGA 651 has been positioned as a Digital Media Platform to perform TV-recording (optional), home theater (DVD+5.1 channels), digital audio playback (MP3, Audio CD), photo and video stream data browsing. Meanwhile, it can also support high game performance (AGP 4x slot). On the other hand, the remote controller allows you to use it like an advanced Hi-Fi stereo in playing CD/MP3 and listening to radio.

An innovative feature to implement the

Hi-Fi stereo into home PC with a fancy equalizer LCM and control panel on the front bezel

Introduction

maximize your connection to the digital planet

- Hi-Fi Stereo: Audio CD+MP3 Player+AM/FM Tuner

- Home Theater: DVD + 5.1 Channel + TV Tuner (option)

- Media Center: Card Reader + 1394 + SPDIF I/O +PVR

- Completed PC: Office + Game Machine

A New Digital Media Form Factor from MSI That Allows You to

- Control Live Television

- Enjoy Home Theater (DVD + 5.1 Channel)

- Listen to Digital Music (MP3, Audio CD)

- Burn Music, Photos and Video

- View Your Favorite Photos

- Incredible Gaming Performance

- And more.....

For Home, For Work & For Fun

Getting Started

1.1 All-inOne Feature Set

1.3 P erformance PC

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

1-1

Chapter 1

1.1 All-in-one Feature Set

The MEGA651 implements all the Hi-Fi Stereo into Home-PC with a fancy equalizer LCM and control panel in the front bezel. When PC is power off, you can use it just like a Hi-Fi Stereo with a remote controller. When PC is power on, you can use it for Home Theater and Media Center PC. The all-in-one feature provides you with multiple functions in a small form factor. It can be set anywhere you want, such as bedroom or living room, while it’s easily be moved to anywhere whenever you need.

See the following for the feature:

TV-out(option)

5.1 Channel

Hi-Fi Power Switch

TV-Tuner (Option)

Optical Drive (Option)

PC Power Switch

Equalizer LCM

Card Reader (Standard)

FDD/2 nd

HDD (Option)

MDC Modem

Remote Controller

-

Hi-Fi Stereo: Audio CD+ MP3 Player+ AM/FM Tuner (power off)

Home Theater: DVD+ 5.1 Channel

Media Center: A/V Browsing/Radio Turning (Card Reader+

1394+ SPDIF I/O+CD-RW) + PVR (TV Tuner)

Completed PC: Office+ Game Machine

1-2

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Front Panel

Hi-Fi Power Switch

IR Receiver

Mode

Eject/Stop

Forward

Play/Pause

Backward

Shuttle Controller

PC Power Switch

HDD LED

PC Reset

Back Panel

Optical SPDIF-in

Mic-in

USB x 2

J1394-1

Head-Phone

J1394-2

Power Jack

Mouse

LAN Port

Parallel Port

Getting Started

Radio Antenna

Jack

Modem Serial Port

Keyboard

VGA Port

USB x 2

Lin-in

Speak-out

PCI Slot

AGP Slot

Optical SPDIF-out

Mic-in

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

1-3

Chapter 1

1.2 System Specification

M/B

- MS-6760 (Proprietary F/F), 185 x 290 mm (4 layer)

CPU:

- Support Socket 478 for Pentium ® 4, 2.8 GHz

Chipset:

- SiS 651 + SiS 962

Memory:

- DDR 333 x 2, support memory up to 2.0GB

On-Board Audio:

- AC’97 Codec integrated in ALC 650, support 5.1 channel , SPDIF In/Out.

On-Board VGA:

- Integrated (AGP 4X)

** On-Board VGA memory: None

On-Board Communication

- LAN: integrated in Realtek (10/100Mb)

- Modem: 56K MDC module

On-Board USB

- Front x 2; Rear x 2; On-Board x 2 for Card Reader & RF K/B, M/S (MFG Option)

On-Board IEEE 1394:

- RTL8801B PHY (2 ports), Front x 2 (4 pin, 6 pin)

Expansion Slots:

- PCI 2.2 x 1, AGP (4X) x1

Power Off Function:

- Playback Audio CD, MP3, AM/FM Radio Tuner (with Remote Controller)

TV Tuner Function

- MS-8606 (Option PCI with remote controller)

Power Supply:

- 200W (PFC 5V/12V SB) Full Range

Chassis:

- 202(W) x 320(D) x 151(H) mm (9.76 Liters)

1-4

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Getting Started

On-Board Headers & Connectors

- Rear Panel: Parallel Port x 1, Serial Port x 1, VGA x 1, PS/2 x 2, Mic in/Line in/

Line out x 1, USB x 2, LAN (RJ45) x 1, SPDIF/O x 1, Modem (RJ11) x 1

- Front Panel: Mic in/Headphone x 1, USB x 2, SPDIF/I x 1, 1394 x 1 (4-pin), 1394 x 1(6-pin)

BIOS

- 2MB Flash

Others

- Microsoft

PC 2001

- LAN Wake Up Function

- Suspend to RAM/DISk function

- Top Tech III (Thermal Overheat Protection Technology)

- PC Alert System Hardware Monitor

- On-Board BlueBird Module for Power-Off features

- On-Board Equalizer (LCM)

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

1-5

Chapter 1

1.3 Performance PC

When PC is power on, the MEGA651 is your performance PC. Power on means “If the power button of PC is pressed, the Hi-Fi stereo has no function even you press the Hi-Fi button.”

Press the Power button to start the PC function

Features

CPU support: Intel P4

PCI/AGP Expansion

Front I/O

- Mic-in/Head-Phone

- USB x 2

- 1394 x 2 (6-pin & 4-pin)

- Optical SPDIF-in

- 6-in-1 Card Reader

Rear I/O

- COM/VGA/Parallel/PS2 x 2

- LAN (RJ45)

- USB x 2

- Optical SPDIF-out

- Speaker-out/Line-in/Mic-in (5.

1channel)

- Modem

- Radio Antenna

See Chapter 2 for more information of mainboard, Front and Rear I/O.

1-6

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Getting Started

Target Operating System

-- Microsoft Windows XP Home Edition

Security

-- The security features protect the data of machine from unveiled publicity and unauthorized access through BIOS control.

Password

-- The MEGA651 uses two levels of BIOS access (User Password & Supervisor

Password) to protect the computer system.

Storage Subsystem

1) Floppy (Standard Floppy & USB Floppy)

2) Hard Disk

3) CD-ROM (OPTIONAL)

4) DVD-ROM (OPTIONAL)

5) CD-RW (OPTIONAL)

6) DVD/CD-RW Combo (OPTIONAL)

In pure barebone Hi-Fi mode with NO CPU, Memory, Had

Disk intalled, if you push the PC power button, the system will deadly hang up. The Hi-Fi mode will be malfunction.

It’s impossible to recover the system by pressing power button for 4 seconds. The only way is to unplug power cord and reset the system.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

1-7

Chapter 1

1.4 Hi-Fi Audio

When PC is power off, the MEGA651 can be used as a Hi-Fi audio. You can press the Hi-Fi button or use the remote controller to start the audio function.

Power-off means “When used as a Hi-Fi audio, the PC should be in power-off status. If you press the PC power button on, the Hi-Fi audio will be disabled .”

Option 1

Press the Power button to use the audio function

Option 2

Press the Hi-Fi button to use the audio function

Features

LCM Display, Clock, AM/FM Radio Tuner, Audio CD Play,

MP3 CD Play, SRS

See Chapter 3 for more information of using audio function.

1-8

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

SRS

MEGA651 is equipped with SRS audio enforcement technology. SRS (Sound Retrieval System) was the first generation of 3D sound, dramatically improving the quality of standard stereo. SRS is based on the human hearing system and was designed to retrieve the natural spatial cues and ambient information that is present in audio but masked by traditional recording and playback methods.

Whether the signal is mono or stereo, SRS expands the audio material to create a realistic threedimensional sound image. SRS has no sweet-spot and fills the room with a sound experience much closer to that of a live performance.

SRS is a trademark of SRS Labs, Inc. SRS technology is incorporated under license from SRS Labs,

Inc.

Getting Started

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

1-9

Chapter 1

1.5 Home Theater

Except the general PC function, the MEGA651 has the extra Home Theater function when PC button is pressed on.

When PC button is pressed on, you can use the equipped optical drive to play DVD. The equipped 5.1 channel audio effect gives you a wonderful feeling of home theater while playing DVD.

Plus, the OPTIONAL MS-8606 TV-Tuner card allows you to watch TV.

The top part of remote controller is designed specially for the TV-Tuner function.

For more informaiton on MS-8606 TV Tuner card, please refer to the maual packed in MS-8606. After inserting the TV Tuner card, remember to install the driver packed in CD to using the function.

1-10

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2.3 P ower Supply

2.4 Front P anel

2.5 Back P anel

Introducing Mainboard

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2-1

Chapter 2

2.1 Mainboard layout

The MEGA651 is equipped with MS6760 proprietary mainboard.

See the following for the mainboard layout:

IDE Connectors

DDR DIMM Slots

FDD Connector

Front Panel Connector

USB Card Reader Connector

Radio Module

USB Connector

Radio Antenna Connector

LCM Connector

Front Panel Power

Connector

AGP Slot

Clear CMOS Jumper

CPU Fan Connector

ATX Power Supply

PCI Slot

Modem Module Connector

Power Supply Connector

TV Audio Connector

CD-IN Connector

Hi-Fi Power Connector

2-2

MS6760 v1.X Mainboard

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Introducing Mainboard

2.2 CPU/memory

The MEGA651 supports Intel

Pentium

4 processors in the 478-pin package. The mainboard uses a CPU socket called PGA478 for easy CPU installation. When you are installing the CPU, make sure the CPU has a heat sink and a cooling fan attached on the top to prevent overheating.

Overheating

Overheating will seriously damage the CPU and system, always make sure the cooling fan can work properly to protect the CPU from overheating.

The mainboard provides 2 slots for 184-pin DDR SDRAM DIMM (Double

In-Line Memory Module) modules and supports the memory size up to 2GB. You can install PC2700/DDR333 or PC2100/DDR266 modules into the DDR DIMM slots (CN28/26).

Introduction to DDR SDRAM

DDR (Double Data Rate) SDRAM is similar to conventional SDRAM, but doubles the rate by transferring data twice per cycle. It uses 2.5 volts as opposed to 3.

3 volts used in SDR SDRAM, and requires

184-pin DIMM modules rather than 168pin DIMM modules used by SDR SDRAM.

High memory bandwidth makes DDR an ideal solution for high performance PC, workstations and servers.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2-3

Chapter 2

2.3 Power Supply

The system is equipped with a 200W(PFC) ATX power supply. The power cord of power supply has been connected to the connectors on the mainboard when shipped out. You can find two connectors (20-Piin & CN 20) on the mainboard.

ATX Power Supply Pin Definition

10 20

PIN SINGAL PIN SIGNAL

3.3V

GND

PW_OK

5V_SB

12V

3.3V

-12V

GND

PS_ON

GND

20-Pin

Connector

CN20 Pin Definition

PIN SINGAL

GND

12V

CN 20

Power Supply Specification

Dimension

PFC

70 (H)x1450(W)x105(D) mm

Yes (passive)

2-4

Electrical Design Specification AC Output :100-127/200-240 VAC, Switch

Selectable, Auto Protection

DC Output :+3.3V 17A

:+5V 12A

:+12V 13.5A

:-12V 0.5A

:+5Vsb 3A

:+12Vsb 2.5A

80 mm PWM Fan

Certificate FCC/UL/CUL/BSMI/CB/NEMKO/TUV

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Introducing Mainboard

2.4 Front panel

The Front Panel is independent and extended from the mainboard. It’s connected to the Front Panel Connector on the mainboard. You can find the following ports on the Front Panel.

Optical SPDIF-In

Mic-In Head-Phone

USB x 2 J1394-1 J1394-2

IEEE 1394 Port: J1394-2

The mainboard provides two IEEE 1394 ports. This smaller one is designed for you to connect the IEEE 1394 device with external power. The IEEE

1394 high-speed serial bus complements USB by providing enhanced PC connectivity for a wide range of devices, including consumer electronics audio/video

(A/V) appliances, storage peripherals, other PCs, and portable devices.

Software Support

IEEE 1394 Driver is provided by Windows ® 98 SE, Windows ® XP, Windows ® ME and Windows ® 2000. Just plug in the IEEE 1394 connector into the port. These Operating Systems will install the driver for IEEE 1394.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2-5

Chapter 2

IEEE 1394 Port: J1394-1

The bigger 6-pin IEEE 1394 Port on the back panel is designed for you to connect to IEEE 1394 devices without external power. That means the mainboard can provide the power for the devices connected to this port.

Software Support

USB Ports

The mainboard provides an OHCI (Universal Host Controller Interface)

Universal Serial Bus root for attaching USB devices such as keyboard, mouse or other USB-compatible devices. You can plug the USB device directly into the connector.

USB Port Description

PIN SIGNAL

VCC

-Data 0

+Data 0

GND

VCC

-Data 1

+Data 1

GND

DESCRIPTION

+5V

Negative Data Channel 0

Positive Data Channel 0

Ground

+5V

Negative Data Channel 1

Positive Data Channel 1

Ground

2-6

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Introducing Mainboard

Mic-in/Head-Phone

Mic-in is a connector for microphone. Head-Phone is a connector for

Speakers or Headphones.

OPTICAL SPDIF-in

The OPTICAL connector allows you to receive the audio file of SPDIF interface for recording and playing.

The SPDIF (Sony & Philips Digital Interface) is developed jointly by the

Sony and Philips corporations . A standard audio file transfer format, SPDIF allows the transfer of digital audio signals from one device to another without having to be converted first to an analog format.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2-7

Chapter 2

2.5 Back panel

The Back Panel provides the following ports:

Serial Port Mouse LAN Port Parallel Port

VGA Port Keyboard USB x 2 Optical SPDIF-out Lin-in Mic-in

Speak-out

Serial Port

The mainboard offers a 9-pin male DIN serial port . The port is 16550A high speed communication ports that sends/receives 16 bytes FIFOs. You can attach a serial mouse or other serial devices directly to the connector.

1 2 3 4 5

6 7 8 9

9-Pin Male DIN Connector

PIN

Pin Definition

SIGNAL

DCD

SIN

SOUT

DTR

GND

DSR

RTS

CTS

DESCRIPTION

Data Carry Detect

Serial In or Receive Data

Serial Out or Transmit Data

Data Terminal Ready

Ground

Data Set Ready

Request To Send

Clear To Send

Ring Indicate

2-8

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Introducing Mainboard

VGA Port

The mainboard provides one DB 15-pin female connector to connect a

VGA monitor.

Pin Definition

5 1

15 11

DB 15-Pin Female Connector

Analog Video Display Connector (DB-15s)

PIN SIGNAL DESCRIPTION

Red

Green

Blue

Not used

Ground

Power

Ground

Not used

SDA

Horizontal Sync

Vertical Sync

SCL

Mouse/Keyboard Connectors

The mainboard provides two standard mini DIN connectors for attaching

PS/2

mouse and keyboard. You can plug a PS/2

mouse or keyboard directly into the connector.

Pin Definition

2 1

PS/2 Mouse (6-pin Female)

PIN

SIGNAL DESCRIPTION

Mouse DATA Mouse DATA

GND

No connection

Ground

VCC +5V

Mouse Clock Mouse clock

NC No connection

6 5

PS/2 Keyboard (6-pin Female)

Pin Definition

PIN SIGNAL

DESCRIPTION

Keyboard DATA Keyboard DATA

GND

VCC

No connection

Ground

+5V

Keyboard Clock Keyboard clock

NC No connection

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2-9

Chapter 2

RJ45 LAN Jack

The mainboard provides one standard RJ-45 jack for connection to Local

Area Network (LAN). You can connect a network cable to the LAN jack.

PIN

Pin Definition

SIGNAL

TDP

TDN

RDP

RDN

DESCRIPTION

Transmit Differential Pair

Receive Differential Pair

Not Used

Receive Differential Pair

Not Used

USB Ports

The mainboard provides an OHCI (Universal Host Controller Interface)

Universal Serial Bus root for attaching USB devices such as keyboard, mouse or other USB-compatible devices. You can plug the USB device directly into the connector.

1 2 3 4

5 6 7 8

USB Ports

USB Port Description

PIN SIGNAL

VCC

-Data 0

+Data 0

GND

VCC

-Data 1

+Data 1

GND

DESCRIPTION

+5V

Negative Data Channel 0

Positive Data Channel 0

Ground

+5V

Negative Data Channel 1

Positive Data Channel 1

Ground

OPTICAL SPDIF-out

The OPTICAL connector allows you to play the audio file of SPDIF interface.

See p. 2-7 for more information.

2-10

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Introducing Mainboard

Parallel Port

The mainboard provides a 25-pin female centronic connector as LPT. A parallel port is a standard printer port that supports Enhanced Parallel Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.

13 1

PIN

25 14

Pin Definition

SIGNAL

SLIN#

GND

STROBE

DATA0 Data0

DATA1

DATA2

DATA3

DATA4

DATA5

DATA6

DATA7

ACK#

BUSY

SELECT

AUTO FEED#

ERR#

INIT#

DESCRIPTION

Strobe

Data1

Data2

Data3

Data4

Data5

Data6

Data7

Acknowledge

Busy

Paper End

Select

Automatic Feed

Error

Initialize Printer

Select In

Ground

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2-11

Chapter 2

Audio Port

Speak-out is a connector for Speakers or Headphones. Line In is used for external CD player, Tape player, or other audio devices. Mic-in is a connector for microphones.

Speak-out Lin-in Mic-in

2-12

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Introducing Mainboard

2.6 Connectors

IDE Connectors: CN22 & CN23

The mainboard has a 32-bit Enhanced PCI IDE and Ultra DMA 33/66/100 controller that provides PIO mode 0~4, Bus Master, and Ultra DMA/33/66/100 function. The two connectors on the mainboard allows you to connect to two

IDE device.

CN22 (Primary IDE Connector)

- CN22 can only connect a HDD.

CN23 (Secondary IDE Connector)

- CN23 can only connect a CD-ROM drive.

CN22

CN23

If you install two hard disks on cable, you must configure the second drive to Slave mode by setting its jumper.

Refer to the hard disk documentation supplied by hard disk vendors for jumper setting instructions.

FDD Connector: CN10

The mainboard provides you with a standard floppy disk drive connector that supports 1.44M floppy disk type.

CN10

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2-13

Chapter 2

CD-in Connector: CN16

The connector is for CD-ROM audio connector.

CN16

TV-Tuner Card Connector: CN13

The mainboard provides the connector to connect the TV-Tuner card.

The TV-Tuner card is included in the package. You can insert the TV-Tuner card into the PCI Slot 1.

CN13

CPU Fan Connector: CN15

The CPU Fan connector supports system cooling fans with +12V that is controlled by PWM. When connecting the wire to the three-pin head connectors, always note that the red wire is the positive and should be connected to the +12V

(that is controlled by PWM), the black wire is Ground and should be connected to GND.

CN15

GND

+12V

SENSOR

2-14

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Introducing Mainboard

Front Panel Power Connector: CN4

The mainboard provides a Front Panel connector for electrical connection to the Front Panel switches and LEDs. CN4 is compliant with Intel ® Front Panel

I/O Connectivity Design Guide.

1 2

HDD

LED

Power LED

Reset

Switch

Power

Switch

9 10

CN4

PIN

CN4 Pin Definition

SIGNAL

HD_LED_P

FP PWR/SLP

HD_LED_N

FP PWR/SLP

RST_SW_N

PWR_SW_P

RST_SW_P

PWR_SW_N

RSVD_DNU

DESCRIPTION

Hard disk LED pull-up

MSG LED pull-up

Hard disk active LED

MSG LED pull-up

Reset Switch low reference pull-down to GND

Power Switch high reference pull-up

Reset Switch high reference pull-up

Power Switch low reference pull-down to GND

Reserved. Do not use.

USB Card Reader Connector: CN6

The mainboard provides a connector to connect the USB Card Reader on the Front Panel.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2-15

Chapter 2

LCM Connector: CN8

The connector is used to connect the LCM on the front panel.

+12VSBY

CN 8

VCC3SBY

Key (0-~5)

GND

VCC5SBY

SPI Bus

CD_SMI

VCC5

HDLED

PWRBTNH

FP_RST

GND

LED-BL

Modem Module Connector: CN21

The mainboard provides the connector to connect the modem module.

The modem module is directly inserted into the connector without an extra cable.

2-16

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Introducing Mainboard

2.7 Jumper

There is a CMOS RAM on board that has a power supply from external battery to keep the data of system configuration. With the CMOS RAM, the system can automatically boot OS every time it is turned on. That battery has long life time for at least 5 years. If you want to clear the system configuration, use the

JBAT1 (Clear CMOS Jumper ) to clear data. Follow the instructions below to clear the data:

Clear CMOS Jumper: J2

1 1

Keep Data

Clear Data

You can clear CMOS by shorting 2-3 pin while the system is off. Then return to 1-2 pin position. Avoid clearing the CMOS while the system is on; it will damage the mainboard.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

2-17

Chapter 2

2.8 Slots

PCI Slot

The PCI slot allows you to insert PCI card or TV Tuner card. The TV Tuner card is included in the MEGA651.

When adding or removing expansion cards, make sure that you unplug the power supply first. Meanwhile, read the documentation for the expansion card to make any necessary hardware or software settings

NOTE: You can insert the OPTIONAL MS8606 card into the

PCI slot to enjoy watching TV.

PCI Slot 1

AGP (Accelerated Graphics Port) Slot

The AGP slot allows you to insert the AGP graphics card. AGP is an interface specification designed for the throughput demands of 3D graphics. It introduces a 66MHz,

32-bit channel for the graphics controller to directly access main memory and provides three levels of throughputs: 1x

(266Mbps), 2x (533Mbps) and 4x (1.07Gbps).

AGP Slot

2-18

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Using Audio Function

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

3-1

Chapter 3

Introduction

The MEGA 651 is featured with audio function. There are two ways to use audio function: in PC mode, in Hi-Fi mode. As the Mega 651 is shipped out in barebone, you must install the necessary components (such as HDD, CPU, RAM...) before using audio function in PC mode. However, there is no limit to use audio function in Hi-Fi mode, although the system is not set up completely.

You can use control panel or remote controller to select the audio function in Hi-Fi mode. However, you can also use

the control panel or remote control to select the audio function

in PC mode. See 3.1 and 3.2 for information on control panel and remote controller. On the other hand, the “Mega Radio” software has been included in package which allows you to listen to the radio in PC mode. See Appendix for information on

“Mega Radio”.

In this chapter, we will tell you how to use audio function in Hi-Fi and PC mode. The LCM pictures are used to provide the information step by step.

3-2

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

3.1 Control Panel

Hi-Fi Power Switch

IR Receiver

Mode

Eject/Stop

Forward

Play/Pause

Backward

Shuttle Controller

Using Audio Function

HiFi Power Start the audio function.

Mode Choose the audio mode (CD/MP3, FM, AM)

Eject/Stop

Forward

Eject the CD/MP3 or stop the play. In Hi-Fi mode, you can press this button to recall memory sub-mode.

Forward the channel search in FM/AM mode or forward the music selection in MP3 mode.

Play/Pause

Backward

Play or pause the play in CD/MP3, AM, FM modes.

In Hi-Fi mode, you can press this button to store the memory station.

Backward the channel search in FM/AM mode or backward the music selection in CD/MP3 mode.

Shuttle a. Adjust volume b. Set EQ/Play mode c. Set SRS and timer

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

3-3

Chapter 3

3.2 remote Controller

The buttons on the bottom are used for audio function while the ones on the top are used for TV application. See the manual of TV Tuner Card MS8606

for information on top part button.

SRS on/off Button

Mute Button

Mode Button

(CD/MP3/FM/AM)

EQ Mode Button

Function Keys for TV application

Control Buttons

Hi-Fi Power

Adjusting Volume

Play Mode Button

Control Buttons These buttons allow you to eject/stop, forward, play/pause and backward the play in CD, MP3, AM or FM mode. See p. 3-3 for detail desciption.

Mute Button

Press this button to mute the volume.

Hi-Fi Power Press this button to use the function of Hi-Fi audio.

Mode Button

Adjusting

Volume

EQ Mode

There are three buttons:CD/MP3, FM and AM. Choose the mode you want.

Use this button to adjust the volume.

Use this button to set EQ sub-mode (Normal, POP, Classic, Jazz) in playing

CD. See p. 3-9 for more information.

Play Mode

3-4

Use this button to set play sub-mode (Normal, Random, Repeat Disc) in playing CD. See p. 3-8 for more information.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

3.3 AC Power ON

- Plug in the power cord

Plug in the power cord. You will see the panel (LCM) items FLASH 2 times.

- Set Timer

Then you can adjust time by shuttle. You will see timer 00:00 flash

Using Audio Function

Turn the shuttle clockwise to adjust minute.

Turn the shuttle counterclockwise to adjust hour. After adjusting the minute and hour, press the shuttle to set the timer. The second will be reset to zero while setting the timer.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

3-5

Chapter 3

3.4 playing CD/Mp3 in Hi-fi mode

- Select CD/MP3

Press HiFi button to start the audio function. Press MODE on the Control

Panel to select CD/MP3 mode or press

CD/MP3 on the remote controller to play CD/MP3.

If there is no CD in the tray or CD is broken, the LCM shows “NO disc”.

Press the Eject/Stop button to open the disc tray and put CD/MP3 in.

If the disc in the tray is CD, the LCM shows CD. If the disc in the tray is MP3, the LCM shows MP3.

- Play music

Press the “Forward” button to play the music. The icon will run a circle.

The LCM shows .

1 means the first song. 00 means minute.

02 means second.

3-6

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Using Audio Function

- Pause Music

Press “Play/Pause” button to pause the music. The LCM shows .

- Play Next Song

Press the “Forward” button to play the next song. There is no action if you hold “Forward” button.

- Replay the song

Press “Backward” button once to replay the song.

- Replay previous song

Press the “Backward” button twice (in

2 seconds) to play the previous song

(After 2 seconds, it replay the song).

- Eject/Stop

Press the “Eject/Stop” button once to stop the music or open the CD-ROM.

Press “Forward

” button to play the song after rejecting.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

3-7

Chapter 3

- Adjusting volume

Turn the shuttle clockwise to turn the volume up and counterclockwise to turn the volume down.

- Set Play Sub-Mode

Press the shuttle once to set the Play

Sub-Mode (NORMAL, RANDOM,

REPEAT, and REPEAT DISC)

Turn the shuttle to choose Play Sub-

Mode. The item you choose will flash and the others are on. Wait for 5 seconds to set the Play Sub-Mode and go back to volume mode. You can also press the shuttle to set it and change to the EQ Sub-Mode at the same time.

: :Allows you to play the CD in normal selection.

:Allows the system makes the random selection.

:Allows you to repeat the song.

:Allows you to repeat the whole disc.

NOTE: You can also press the “PLAY MODE” button on the remote controller to set the Sub-

Mode.

Press the shuttle twice (if you want to skip the Play Sub-Mode) to set the EQ

Sub-Mode (NORMAL, POP, CLASSIC,

JAZZ).

3-8

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Using Audio Function

- Set EQ Sub-Mode

Turn the shuttle to choose EQ Sub-

Mode. The item you choose will flash and the others are on. Wait for 5 seconds to set the EQ Sub-Mode and go back to volume mode. You can also press the shuttle to set it and change to the Timer Sub-Mode at the same time.

: To play the CD/MP3 in Normal mode.

: To play the CD/MP3 in Classic mode.

: To play the CD/MP3 in Jazz mode.

: To play the CD/MP3 in POP mode.

NOTE: You can also press the “EQ MODE” button on the remote controller to set it.

Press the shuttle thrice (if you want to skip Play and EQ sub-modes) to set the

Timer sub-mode. The operation of setting is the same as AC power on. After that, it changes to the Volume submode. The LCM shows .

- Turn on SRS

Press the shuttle four times to turn on

SRS. You can also press the MTS button on the remote controller to turn on

SRS.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

3-9

Chapter 3

3.5 playing FM/AM in Hi-fi mode

- Select AM/FM

Press the “MODE” button on the Control Panel to set AM/FM mode or press

AM/FM button on the Remote Controller to switch to AM or FM station.

- Next Available Station

Press the “Forward” button to jump to the next available station.

- Previous Available Station

Press the “Backward” button to jump to the previous available station.

- Memory Station

Press the “mem.set (Play/Pause)” button to store the memory station and turn the shuttle to choose the spot you want to save. Press the shuttle to set it

(You can set up to 6 spots. You will see

“ “ on the LCM.)

3-10

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Using Audio Function

- Adjusting Volume

Turn the shuttle to adjust the volume.

- Recall Memory Station

Press the “Eject/Stop” once to recall the memory sub-mode and turn the shuttle to choose the number of spot (1-6) to play.

- Set EQ Sub-Mode

Press the shuttle once into the “EQ” sub-mode. Turn the shuttle to choose the sub-mode. The operation is the same as in CD/MP3 mode.

- Set Timer

Press the shuttle twice to set the Timer sub-mode (operation is the same as in

AC power on). After you set the hour and minute, it changes to the volume sub-mode. The LCM shows .

NOTE: Press the shuttle thrice or press the MTS button on the remote controller to turn the SRS on.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

3-11

Chapter 3

3.6 Using audio function in PC mode

Radio Mode

You can use Remote Controller or Front Panel to control the audio function.

Basically, the operation is very similar to that in Hi-Fi mode. The difference is

in memory station setting.

Remote Controller Function

1. Press “Hi-Fi” button to turn on/off radio.

2. Press “FM/AM” button to launch MSI Mega Radio to listen to radio.

3. Press “Mute” button to mute the volume.

4. Press “Vol up/down” button to adjust volume.

5. Press “Forward/Backward” button to get an available station.

<Setting Memory Station> a. Get an available station.

b. Press “mem.set”.

c. Use “Forward/Backward” button to choose the station number you want to store.

d. Press “mem.set” again.

<Calling Memory Station> a. Press “Memory”.

b. Use “Forward/Backward” button to choose the memory station.

3-12

<Reset Memory Station> a. Use “Forward/Backward” button to choose the NEW station number.

b. Press “mem.set” to reset the station.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Using Audio Function

Front Panel Function

1. Press “Hi-Fi” button to turn on/off radio.

2. Press “Mode” button to launch MSI Radio to listen to radio.

3. Turn “Shuttle” to adjust the volume.

4. Press “Forward/Backward” button to get an available station.

Memory Station

The shuttle is not allowed to set the memory station as in Hi-Fi mode. Use the “mem.set” button on the remote controller to set the memory station.

CD/MP3 Mode

To listen to the play of CD/MP3 in PC mode, you must use the application

“Media Player” that is equipped in Windows. As in Radio Mode, there are two ways (Remote Controller/Front Panel) to use the CD/MP3 audio function.

Before playing MP3 in PC mode, you need to download the

MP3 file into system, and then add the file to the playlist.

The Mega 651 is not allowed to play music automatically after inserting MP3

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

3-13

Chapter 3

Remote Controller Function

1. Press “Hi-Fi” button to turn on/off CD/MP3.

2. Press “FM/AM/CDMP3” button to select the mode you want.

3. Press “Mute” button to mute the volume.

4. Press “Vol up/down” button to adjust volume.

5. Press “Forward/Backward” button to get the next/last song.

6. Press “Play/Pause” button to play/pause the song.

7. Press “Eject” button to eject/retrieve the tray.

Memory Station

The “Eject” button is not allowed to recall the memory station as in Hi-Fi mode. It can only be used to eject or retrieve the tray.

Front Panel Function

1. Press “Hi-Fi” button to turn on/off CD/MP3.

2. Press “FM/AM/CDMP3” button to select the mode you want.

3. Turn “Shuttle” to adjust the volume.

4. Press “Forward/Backward” button to get an available station.

6. Press “Play/Pause” button to play/pause the song.

7. Press “Eject” button to eject/retrieve the tray.

Memory Station

The “Eject” button is not allowed to recall the memory station as in Hi-Fi mode. It can only be used to eject or retrieve the tray.

3-14

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

4.6 Integrated P eripherals

4.7 P ower Management Setup

4.10 Frequency/V oltage Control

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-1

< ↑ >

< ↓ >

←

→

<Enter>

<Esc>

<+/PU>

<-/PD>

<F1>

<F5>

<F6>

<F7>

<F10>

Chapter 4

4.1 Entering Setup

Power on the computer and the system will start POST (Power On Self

Test) process. When the message below appears on the screen, press <DEL> key to enter Setup.

Press DEL to enter SETUP

If the message disappears before you respond and you still wish to enter

Setup, restart the system by turning it OFF and On or pressing the RESET button.

You may also restart the system by simultaneously pressing <Ctrl>, <Alt>, and

<Delete> keys.

Control Keys

Move to the previous item

Move to the next item

Move to the item in the left hand

Move to the item in the right hand

Select the item

Jumps to the Exit menu or returns to the main menu from a submenu

Increase the numeric value or make changes

Decrease the numeric value or make changes

General help, only for Status Page Setup Menu and Option Page

Setup Menu

Restore the previous CMOS value from CMOS, only for Option Page

Setup Menu

Load the default CMOS value from Fail-Safe default table, only for

Option Page Setup Menu

Load Optimized defaults

Save all the CMOS changes and exit

4-2

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

Getting Help

Menu.

After entering the Setup menu, the first menu you will see is the Main

Main Menu

The main menu lists the setup functions you can make changes to. You can use the control keys (

↑↓

) to select the item. The on-line description of the highlighted setup function is displayed at the bottom of the screen.

Sub-Menu

If you find a right pointer symbol (as shown in the right view) appears to the left of certain fields that means a sub-menu containing additional options can be launched from this field. You can use control keys (

↑↓

) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press <Esc >.

8

IDE Primary Master

8

IDE Primary Slave

8

IDE Secondary Master

8

IDE Secondary Slave

General Help <F1>

The BIOS setup program provides a General Help screen. You can call up this screen from any menu by simply pressing <F1>. The Help screen lists the appropriate keys to use and the possible selections for the highlighted item. Press

<Esc> to exit the Help screen.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-3

Chapter 4

4.2 The main menu

Once you enter Phoenix-Award

BIOS CMOS Setup Utility, the Main Menu

(Figure 1) will appear on the screen. The Main Menu allows you to select from twelve setup functions and two exit choices. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu.

Standard CMOS Features

Use this menu for basic system configurations, such as time, date etc.

Advanced BIOS Features

Use this menu to setup the items of AWARD

special enhanced features.

Advanced Chipset Features

Use this menu to change the values in the chipset registers and optimize your system’s performance.

Integrated Peripherals

Use this menu to specify your settings for integrated peripherals.

4-4

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

Power Management Setup

Use this menu to specify your settings for power management.

PNP/PCI Configurations

This entry appears if your system supports PnP/PCI.

PC Health Status

This entry shows your PC health status.

Frequency/Voltage Control

Use this menu to specify your settings for frequency/voltage control.

Load Fail/Safe Defaults

Use this menu to load factory default settings into the BIOS for stable system performance operations.

Load Optimized Defaults

Use this menu to load the BIOS values for the best system performance, but the system stability may be affected.

Set Supervisor Password

Use this menu to set Supervisor Password.

Set User Password

Use this menu to set User Password.

Save & Exit Setup

Save changes to CMOS and exit setup.

Exit Without Saving

Abandon all changes and exit setup.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-5

Chapter 4

4.3 standard cmos features

The items in Standard CMOS Features Menu are divided into 12 categories.

Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.

Date

This allows you to set the system to the date that you want (usually the current date). The format is <day><month> <date> <year>.

Time

This allows you to set the system time that you want (usually the current time).

The time format is <hour> <minute> <second>.

IDE Primary/Secondary Master/Slave

Press PgUp/<+> or PgDn/<-> to select Manual, None or Auto type. Note that the specifications of your drive must match with the drive table. The hard disk will not work properly if you enter improper information for this category. If your hard disk drive type is not matched or listed, you can use Manual to define your own drive type manually.

4-6

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

If you select Manual, related information is asked to be entered to the following items. Enter the information directly from the keyboard. This information should be provided in the documentation from your hard disk vendor or the system manufacturer.

Access Mode

Capacity

Cylinder

The settings are CHS, LBA, Large, Auto.

The formatted size of the storage device.

Number of cylinders.

Head

Precomp

Landing Zone

Sector

Number of heads.

Write precompensation.

Cylinder location of the landing zone.

Number of sectors.

Drive A

This item allows you to set the type of floppy drives installed.

Video

The setting controls the type of video adapter used for the primary monitor of the system. Available options are EGA/VGA.

Halt On

The setting determines whether the system will stop if an error is detected at boot.

Available options are:

All Errors

No Errors

The system stops when any error is detected.

The system doesn’t stop for any detected error.

All, But Keyboard The system doesn’t stop for a keyboard error.

All, But Diskette

The system doesn’t stop for a disk error.

All, But Disk/Key

The system doesn’t stop for either a disk or a key

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-7

Chapter 4

4.4 advanced bios features

Quick Boot

Setting the item to Enabled allows the system to boot within 5 seconds since it will skip some check items. Available options: Enabled, Disabled.

Boot Sequence

The items allow you to set the sequence of boot devices where BIOS attempts to load the disk operating system.

NOTE: If you want to boot from USB device like USB FDD, please turn on either

USB keyboard or mouse enable.

CPU L1 & L2 Cache

Cache memory is additional memory that is much faster than conventional DRAM

(system memory). When the CPU requests data, the system transfers the requested data from the main DRAM into cache memory, for even faster access by the CPU. This setting enables/disables the internal cache (also known as L1 or level 1 cache) and external cache (also known as L2 or level 2 cache). Settings are: Enabled and Disabled.

4-8

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

CPU L2 Cache ECC Checking

This setting allows you to enable or disable the ECC (Error-Correcting Code) feature for error detection and correction when data passes through L2 cache memory.

Setting options: Disabled, Enabled.

Seek Floppy

Setting to Enabled will make BIOS seek floppy drive A: before booting the system.

Settings: Disabled, Enabled.

Boot Up Num-Lock Status

This setting is to set the Num Lock status when the system is powered on. Setting to On will turn on the Num Lock key when the system is powered on. Setting to

Off will allow users to use the arrow keys on the numeric keypad. Setting options:

On, Off.

Typematic Rate Setting

This item is used to enable or disable the typematic rate setting including Typematic

Rate & Typematic Delay.

Typematic Rate (Chars/Sec)

After Typematic Rate Setting is enabled, this item allows you to set the rate

(characters/second) at which the keys are accelerated. Settings: 6, 8, 10, 12, 15,

20, 24 and 30.

Typematic Delay (Msec)

This item allows you to select the delay between when the key was first pressed and when the acceleration begins. Settings: 250, 500, 750 and 1000.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-9

Chapter 4

Security Option

This specifies the type of BIOS password protection that is implemented. Settings are described below:

Option

Setup

System

Description

The password prompt appears only when end users try to run Setup.

A password prompt appears every time when the computer is powered on or when end users try to run Setup.

HDD S.M.A.R.T Capability

This allows you to activate the S.M.A.R.T. (Self-Monitoring Analysis & Reporting

Technology) capability for the hard disks. S.M.A.R.T is a utility that monitors your disk status to predict hard disk failure. This gives you an opportunity to move data from a hard disk that is going to fail to a safe place before the hard disk becomes offline. Settings: Enabled and Disabled.

HT CPU Function

The Intel processor uses Hyper-Threading technology to increase transaction rates and reduces end-user response times. The technology treats the two cores inside the processor as two logical processors that can execute instructions simultaneously. In this way, the system performance is highly improved. If you disable the function, the processor will use only one core to execute the instructions. Settings: Enabled and Disabled.

APIC Mode

This field is used to enable or disable the APIC (Advanced Programmable Interrupt Controller). Due to compliance with PC2001 design guide, the system is able to run in APIC mode. Enabling APIC mode will expand available IRQ resources for the system. Settings: Enabled and Disabled.

4-10

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

4.5 advanced chipset features

Advanced DRAM Control 1

Press <Enter> to enter the sub-menu and the following screen appears:

System Performance

The DRAM timing is controlled by the DRAM Timing Registers. The Timings programmed into this register are dependent on the system design. Slower rates may be required in certain system designs to support loose layouts or slower memory. Setting options: Safe Mode, Normal Mode, Fast Mode, Turbo Mode,

Ultra Mode.

CAS Latency Setting

The option lets you override the SPD timing to control the CAS latency, which determines the timing delay before SDRAM starts a read command after receiving it. Settings: 2 Clocks, 2.5 Clocks, 3 Clocks and Disabled. 2 Clocks increases system performance while 3 Clocks provides more stable system performance.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-11

Chapter 4

MA 1T/2T Select

This setting controls the SDRAM command rate. Setting to Auto allows the SDRAM command rate to be determined by the BIOS. Selecting MA 1T/MA 2T makes

SDRAM signal controller run at 1T/2T rate. 1T is faster than 2T. Setting options:

Auto, MA 2T, MA 1T.

AGP Aperture Size

This setting controls just how much system RAM can be allocated to AGP for video purposes. The aperture is a portion of the PCI memory address range dedicated to graphics memory address space. Host cycles that hit the aperture range are forwarded to the AGP without any translation. The option allows the selection of an aperture size of 4MB, 8MB, 16MB, 32MB, 64MB, 128MB, and

256 MB.

AGP Fast Write

The item enables or disables the AGP Fast Write feature. The Fast Write technology allows CPU to write directly into the graphics controller without passing anything through system memory and improves 8x speed accordingly. Select

Enabled only when your AGP card supports the feature. Options: Disabled,

Enabled.

4-12

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

4.6 integrated peripherals

SIS OnChip IDE Device

Press <Enter> to enter the sub-menu and the following screen appears:

Internal PCI/IDE

This setting enables or disables the internal primary and secondary PCI & IDE controllers. Setting options: Disabled, Primary, Secondary, Both.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-13

Chapter 4

IDE Primary/Secondary Master/Slave PIO

The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports. Modes 0 through 4 provide successively increased performance. In Auto mode, the system automatically determines the best mode for each device. The settings are:

Auto, Mode 0, Mode 1, Mode 2, Mode 3, Mode 4.

Primary/Secondary Master/Slave UltraDMA

Ultra DMA/33 implementation is possible only if your IDE hard drive supports it and the operating environment includes a DMA driver (Windows 95 OSR2 or a third-party IDE bus master driver). If your hard drive and your system software both support Ultra DMA/33, Ultra DMA/66 and Ultra DMA/100 select Auto to enable BIOS support. The settings are: Auto, Disabled.

IDE DMA Transfer Access

This item allows users to enable or disable the DMA transfer function of the IDE hard drive. The settings are: Enabled, Disabled.

SIS OnChip PCI Device

Press <Enter> to enter the sub-menu and the following screen appears:

SIS USB Controller

This setting is used to enable/disable the onboard USB controller. Setting options:

Disabled, Enabled.

4-14

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

USB 2.0 Supports

Set to Enabled if you need to use any USB 2.0 device in the operating system that does not support or have any USB 2.0 driver installed, such as DOS and SCO

Unix. Setting options: Disabled, Enabled.

USB Keyboard Support

Select Enabled if you need to use a keyboard in the operating system. Setting options: Enabled, Disabled.

USB Mouse Support

Select Enabled if you need to use a mouse in the operating system. Setting options:

Enabled, Disabled.

SIS AC97 AUDIO

Auto allows the motherboard’s BIOS to detect whether you’re using any audio device. If so, the onboard audio controller will be enabled. If not, the onboard audio controller will be disabled. If you want to use different controller cards to connect audio connectors, set the field to Disabled. Setting options: Disabled,

Auto.

SIS S/W Modem

Auto allows the mainboard to detect whether a modem is used. If a modem is detected, the onboard S/W modem controller will be enabled; if not, it is disabled.

Disable the controller if you want to use other controller cards to connect a modem. Settings: Auto, Disabled.

SIS 1394 Controller

This item allows you to enable/disable the onboard IEEE1394 controller. Setting options: Enabled and Disabled.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-15

Chapter 4

Onboard Super IO Device

Press <Enter> to enter the sub-menu and the following screen appears:

Onboard FDC Controller

Select Enabled if your system has a floppy disk controller (FDD) installed on the system board and you wish to use it. If you install add-on FDC or the system has no floppy drive, select Disabled in this field. The settings are: Enabled and

Disabled.

Onboard Serial Port 1

Select an address and corresponding interrupt for the first and second serial ports.

The settings are: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, Disabled, Auto.

Onboard Parallel Port Mode

SPP : Standard Parallel Port

EPP : Enhanced Parallel Port

ECP : Extended Capability Port

ECP + EPP: Extended Capability Port + Enhanced Parallel Port

To operate the onboard parallel port as Standard Parallel Port only, choose “SPP.

” To operate the onboard parallel port in the EPP mode simultaneously, choose

“EPP.” By choosing “ECP”, the onboard parallel port will operate in ECP mode only. Choosing “ECP + EPP” will allow the onboard parallel port to support both the ECP and EPP modes simultaneously.

4-16

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

EPP Mode Select

The onboard parallel port is EPP Spec. compliant, so after the user chooses the onboard parallel port with the EPP function, the following message will be displayed on the screen: “EPP Mode Select.” At this time either EPP 1.7 spec or EPP

1.9 spec can be chosen.

ECP Mode Use DMA

The ECP mode has to use the DMA channel, so choose the onboard parallel port with the ECP feature. After selecting it, the following message will appear: “ECP

Mode Use DMA.” At this time, the user can choose between DMA channel 3 or

Init Display First

This item specifies which VGA card is your primary graphics adapter. Settings:

PCI Slot and AGP.

System Share Memory Size

For SiS650 chipset, the system shares memory to the onboard VGA card. This setting controls the exact memory size shared to the VGA card. Setting options:

4MB, 8MB, 16MB, 32MB, 64MB, 24MB.

SiS301 Display Type

This item allows you to set the TV display type. Setting options: CRT1+S-V PAL

OTV, CRT1+S-V PAL UTV, CRT1+S-V NTSC OTV, CRT1+S-V NTSC UTV.

LCD&TV Select

This item allows you to select LCD or TV for display type. Setting options: off,

LCD, TV, LCD+TV.

Display From CMOS

This item allows you to enable or disable the function of display from CMOS in

Window 2000. Setting options: Disabled, Enabled.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-17

Chapter 4

Onboard LAN Device

This item is used to enable or disable the onboard LAN controllers. Setting options:

Enabled, Disabled.

Onboard Lan Boot ROM

The items enable or disable the initialization of the onboard LAN Boot ROMs during bootup. Selecting Disabled will speed up the boot process.

4-18

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

4.7 Power management setup

Sleep State

This item specifies the power saving modes for ACPI function. If your operating system supports ACPI, such as Windows 98SE, Windows ME and Windows 2000, you can choose to enter the Standby mode in S1(POS) or S3(STR) fashion through the setting of this field. Options are:

S1/POS

S3/STR

The S1 sleep mode is a low power state. In this state, no system context is lost (CPU or chipset) and hardware maintains all system context.

The S3 sleep mode is a lower power state where the in formation of system configuration and open applications/ files is saved to main memory that remains powered while most other hardware components turn off to save energy. The information stored in memory will be used to restore the system when a “wake up” event occurs.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-19

Chapter 4

Power Management

This item is used to select the degree (or type) of power saving and is related to these modes: Suspend Mode and HDD Power Down. There are three options for power management:

Min Saving Minimum Power Management. Suspend Mode=1 Hour

Max Saving Maximum Power Management. Suspend Mode=1 Min

User Define Allows end users to configure each mode separately.

Suspend Mode

After the selected period of system inactivity, all devices except the CPU shut off.

Settings: Disabled, 1Min, 2Min, 4Min, 8Min, 12Min, 20Min, 30Min, 40Min, 1

Hour.

MODEM Use IRQ

This determines the IRQ in which the MODEM can use. Activity of the selected

IRQ always awakens the system. Settings: 3, 4, 5, 7, 9, 10, 11, NA.

Hot Key Function As

This setting specifies the function of the preset hot key. Settings: Disabled, Power

Off, Suspend.

HDD Off After

If enabled and after the set time of system inactivity, the hard disk drive will be powered down while all other devices remain active. Settings: Disabled, 1 Min

~ 15Min.

Power Button Function

This feature sets the function of the power button. Settings are:

4-20

Power Off

The power button functions as normal power off button.

Suspend

When you press the power button, the computer enters the suspend/sleep mode, but if the button is pressed for more than four seconds, the computer is turned off.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

After AC Power Lost

This setting specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are:

Off

Leaves the computer in the power off state.

Leaves the computer in the power on state.

Last State

Restores the system to the status before power failure or

PM Wake Up Events

interrupt occurred.

Press <Enter> and the following sub-menu appears.

IRQ [3-7, 9-15], NMI & IRQ 8 Break Suspend

This setting enables/disables the monitoring of the specified IRQ line. If set to

Enabled, the activity of the specified IRQ line will prevent the system from entering power saving modes or awaken it from power saving modes. Setting options:

Disabled, Enabled.

Wake Up On PME/Ring

These two fields specify whether the system will be awakened from power savings modes when activity or input signal of the specified hardware peripheral or components is detected. Setting options: Disabled, Enabled.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-21

Chapter 4

USB Wake Up from S3

This item allows the activity of the USB device to wake up the system from S3

(Suspend to RAM) sleep state. Settings are: Enabled and Disabled.

PS2KB Wake Up from S3/S4/S5

This setting allows you to enter “Any Key” (max. 8 numbers) to wake up the system from S3/S4/S5 state. Settings are: Hot Key, Disabled, Password.

PS2MS Wake Up from S3/S4/S5

This setting allows the activity of the mouse to wake up the system from S3/S4/S5 state. Settings are: Disabled, Click, Move & Click.

Resume By Alarm

This function is for setting date and time for your computer to boot up. During

Disabled, you cannot use this function. During Enabled, choose the Month, Day, and Time Alarm:

Month Alarm You can choose which month the system will boot up.

Day of Month Alarm You can choose which day of the preset month the system will boot up. Set to 0, to boot every day.

Time (hh:mm:ss) Alarm You can choose what hour, minute and second the system will boot up.

**Reload Global Timer Events**

Primary/Secondary IDE 0/1, FDD, COM, LPT Port, PCI PIRQ [A-D] #

The global timer is the hardware timer that counts down to the power saving modes. If the monitoring of the listed hardware peripherals or components is enabled, the activity of the specified peripherals or components will awaken the system or reload the original count of global timer when they are accessed.

4-22

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

4.8 pnp/pci configurations

This section describes configuring the PCI bus system and PnP (Plug &

Play) feature. PCI, or Peripheral Component Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.

Clear ESCD

Normally, you leave this field Disabled. Select Enabled to reset Extended System

Configuration Data (ESCD) when you exit Setup if you have installed a new addon and the system reconfiguration has caused such a serious conflict that the operating system can not boot. The settings are: Enabled and Disabled.

Resources Controlled By

The Award Plug and Play BIOS has the capacity to automatically configure all of the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as

Windows ® 95/98. If you set this field to “manual” choose specific resources by going into each of the sub menu that follows this field (a sub menu is preceded by

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-23

Chapter 4

a “¾”). The settings are: Auto (ESCD), Manual.

IRQ Resources

The items are adjustable only when Resources Controlled By is set to Manual.

Press <Enter> and you will enter the sub-menu of the items. IRQ Resources list

IRQ 3/4/5/7/9/10/11/12/14/15 for users to set each IRQ a type depending on the type of device using the IRQ. Settings are:

PCI Device For Plug & Play compatible devices designed for PCI bus architecture.

Reserved

The IRQ will be reserved for further request.

PCI/VGA Palette Snoop

When set to Enabled, multiple VGA devices operating on different buses can handle data from the CPU on each set of palette registers on every video device.

Bit 5 of the command register in the PCI device configuration space is the VGA

Palette Snoop bit (0 is disabled).

4-24

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4.9 PC health status

Setting BIOS Function

Shutdown Temperature

When the processor reaches the preset temperature, the ACPI-aware system will be shut down. Settings: Disabled, 85

C/185 o

F, 90 o

C/194 o

System/CPU Temperature, CPU Fan, Vcore, 3.3V, +5V, +12V, -12V, VBAT (V),

5VSB(V)

These items display the current status of all of the monitored hardware devices/ components such as CPU voltages, temperatures and all fans’ speeds.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-25

Chapter 4

4.10 Frequency/Voltage Control

CPU Clock Ratio

This setting controls the multiplier that is used to determine the internal clock speed of the processor relative to the external or motherboard clock speed.

Auto Detect DIMM/PCI Clk

This option allows you to enable/disable the feature of auto detecting the clock frequency of the installed DIMM/PCI bus. The settings are: Enabled, Disabled.

Spread Spectrum

When the motherboard’s clock generator pulses, the extreme values (spikes) of the pulses creates EMI (Electromagnetic Interference). The Spread Spectrum function reduces the EMI generated by modulating the pulses so that the spikes of the pulses are reduced to flatter curves. If you do not have any EMI problem, leave the setting at Disabled for optimal system stability and performance. But if you are plagued by EMI, activate the Spread Spectrum for EMI reduction. Remember to disable Spread Spectrum if you are overclocking because even a slight jitter can introduce a temporary boost in clockspeed which may just cause your overclocked processor to lock up. Options: Disabled, Enabled.

4-26

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

Setting BIOS Function

CPU Frequency

Use this item to select the appropriate frequency for your CPU FSB. Options:

Default, 100MHz, 133MHz.

DRAM Frequency

This setting shows the current frequency of DDR DRAM (read only). Options: By

SPD, 200MHz, 266MHz, 333MHz.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

4-27

.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

A-1

The Mega Radio Application is developed by MSI which is used for Mega

651 only. The application allows you to listen to radio, set memory station and record music in Windows XP. Please pay attention to the fact as below:

If the AC power is off while you are using Mega Radio application, the system will lose the data saved before when the power is turned on again.

See the following for the three functions:

Listening to Radio

When you launch the Mega Radio application, you will see the control panel as below.

There are some functions on the control panel.

a. Choosing previous/next station

Clicking on the PREVIOUS/NEXT buttons allows you to choose the previous or next radio station.

b. Choosing FM/AM station

Clicking on the FM/AM buttons allows you to choose FM/AM station.

c. Adjusting volume

Click on the small circle on the VOL button and turn the circle clockwise to adjust the volume.

A-2

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

d. Preference Setting

Clicking on the SET button allows you to set preference. There are four kinds of preference you can set

In “Configuration” window, you can set “Area” and “EQ Mode”.

There are six options in “Area”: Asia, Middle East, Near East, Russia, South

Africa and Others (Europe). Choose the area you live in.

NOTE: Each area has its proprietary frequency range. If you are not unable to receive some stations in your area, there might be improper setting in this option.

In “EQ Mode”, you have four options: Normal, POP, Classic, Jazz. Choose the mode you prefer.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

A-3

In “AM Memory List” or “FM Memory List” window, you can set 6 AM or

FM memory stations. Just type the AM or FM frequency and station name to set the memory station.

A-4

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

The window shows the Mega Radio version you are using. Click the web address to contact us if you need more information about our products.

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

A-5

Setting Memory Station

Click on the PREVIOUS or NEXT button to choose the station you want to memorize. After selecting the station, click on the memory station number you want to memorize. There are 6 station numbers you can use. The number you choose will become “yellow” while others are in “white” color.

Click on the station number you want to memorize

If you want to reset the memory station, click on the station number you want to reset. Then, click on the left top of the mouse, a window as below will pop up:

Click on “Yes” to erase the memory station. Then follow the steps mentioned to reset the memory station.

A-6

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
