HP Simply StorageWorks reference guide
Your guide to HP storage solutions for small and
midsized businesses
Spring 2008 Edition
Simply StorageWorks
When faced with growing volumes of data to store and protect, it can be a challenge
to find a solution that is easy to set up and manage, and which is also reliable and
affordable. HP Simply StorageWorks makes it easy to find the answer to your
specific storage challenges with solutions that are grouped into three pillars:
Simply Consolidation, Simply File Services, and Simply Business Protection. Each of
these pillars addresses a different business need and provides advice on what storage
solutions best fit your environment.
Simply Consolidation brings greater efficiency and flexibility to growing business
operations by making it easy for customers to centralize and share storage for multiple
application servers. It keeps things simple with entry-level, plug-and-play solutions
such as the All-in-One Storage System as well as storage area network (SAN) products
that can be ordered with one part number such as SAN starter kits, which will be
available in April/May 2008.
Simply File Services helps customers deliver and manage optimized file serving for
their end-user clients that is designed to help improve business performance. It is
simple, with Microsoft® Windows®-based file servers that are tuned to run up to
20 percent faster than build-it-yourself solutions. It features HP products designed
specifically for file serving—HP ProLiant servers integrated with Microsoft Windows
Storage Server software. Full index search capabilities help workers find data faster,
and HP ProLiant Storage Servers and HP All-in-One Storage Systems are preconfigured
to be deployed and managed in minutes, not hours.
Simply Business Protection helps customers keep their businesses running smoothly,
with solutions ranging from backup to disaster recovery to long-term archiving. It is
simple, with easy-to-use disk and tape-based backup and recovery products designed
to fit the unique needs of small and midsized businesses. With a wide range of
solutions designed just for them, your customers can select the right amount of
capacity, whether it is 40 GB or 80 TB. They also have their choice of technologies—
from tape drives and libraries to disk-based backup appliances to data backup
software solutions.
Find out more about Simply StorageWorks at: www.hp.com/go/simplystorageworks
2
Index of content
Simply Consolidation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
HP StorageWorks Modular Smart Arrays and All-in-One Storage Systems family . . . 5
HP StorageWorks All-in-One Storage Systems family . . . . . . . . . . . . . . . . . . . . . 6
HP StorageWorks Modular Smart Array (MSA) family . . . . . . . . . . . . . . . . . . . 12
HP StorageWorks Enterprise Virtual Array . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
HP storage networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
HP StorageWorks B-series infrastructure . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
HP StorageWorks C-series infrastructure . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
HP StorageWorks Fibre Channel host bus adapters (HBAs) . . . . . . . . . . . . . . . .32
Simply File Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
HP ProLiant Storage Server family overview . . . . . . . . . . . . . . . . . . . . . . . . . . .35
HP ProLiant Storage Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Simply Business Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
HP StorageWorks tape drives, autoloaders, and libraries . . . . . . . . . . . . . . . . .45
HP StorageWorks DAT tape drive family . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
HP StorageWorks Ultrium tape family . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
HP StorageWorks rack-mount and tape-array solutions . . . . . . . . . . . . . . . . . . .59
HP StorageWorks Tape Autoloaders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
HP StorageWorks MSL Tape Libraries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
HP storage media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
HP StorageWorks tape storage compatibility . . . . . . . . . . . . . . . . . . . . . . . . . .72
HP StorageWorks tape backup solutions connectivity chart . . . . . . . . . . . . . . . .74
HP disk-based backup solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
HP software for data protection
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
What’s in the box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Jargon buster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
HP Care Pack Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
3
Simply Consolidation
Simply Consolidation provides simple advice on how to implement a SAN solution,
giving you shared capacity for your application servers so that they deliver reliability
and easier management.
A storage area network (SAN) provides resource sharing that is similar to a local area
network (LAN), but is designed specifically for servers to share storage devices such
as disk arrays and tape libraries.
HP has introduced SAN solutions based on the iSCSI protocol, which enables smaller
IT environments to benefit from shared network storage at an achievable cost.
• The HP StorageWorks MSA2000i (iSCSI) and the MSA2000fc (Fibre Channel)
are part of a new generation of storage arrays designed for entry-level customers
that features the very latest in functionality and technology at highly affordable
investment price points.
• The All-in-One Storage Systems provide affordable, easy-to-use, appliance-based,
entry-level consolidation with the added functionality of file serving and integrated
data protection.
Both types of SANs enable growing amounts of data to be stored and managed more
efficiently. Plus, they reduce operational and management costs and provide the
following benefits:
• Online scalability—for the easy addition of extra storage
• High levels of availability—helping to ensure that data and applications are always
fully accessible
• Simple and centralized management—saving vital human resources
• High utilization of disk capacity—enables improved cost-efficiency and rapid ROI
• Faster data restoration—allowing businesses to return to full productivity
For more information, visit: www.hp.com/go/simplystorageworks
4
HP StorageWorks Modular Smart Arrays
and All-in-One Storage Systems family
Affordable, scalable, and manageable high-performance storage
consolidation solutions
All-in-One Storage
Modular Smart Array
EVA4400
Midrange
consolidation
MSA2000fc
MSA2000i
Entry-level
consolidation
AiO1200
AiO600
AiOSB600c
MSA500 G2
AiO400t
AiO400r
MSA70
MSA30
MSA60
Disk
enclosures
MSA20
MSA50
For technical reference, go to quickspecs: www.hp.com/products/quickspecs
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
5
HP StorageWorks All-in-One
Storage Systems family
HP StorageWorks All-in-One Storage Systems
(AiO) are radically simple, integrated, and
affordable network storage solutions that enable
small and midsized companies to manage,
grow, and protect their data easily.
The HP StorageWorks 400t, 400r, 600, 1200, and SB600c All-in-One Storage Systems
are unified storage devices that provide benefits from all three Simply StorageWorks
pillars:
• Simply Consolidation: Integrated iSCSI array enables shared storage, which delivers
more efficient use of capacity and lower operational costs.
• Simply File Services: Optimized file serving for end-user clients (NAS) to improve
productivity and collaboration. These systems are performance tuned and improve
capacity utilization by reducing duplicate files within shared volumes.
• Simply Business Protection: Integrated protection of iSCSI and NAS data while also
enabling data protection of other servers and clients to deliver network backup
consolidation when paired with HP tape products.
These fully integrated solutions are designed to be deployed by IT generalists and require
no storage expertise. They offer everything you need to lower the cost and complexity
associated with rapidly growing data environments.
All-in-One Storage Manager
A single interface that manages storage
and data protection from an applicationcentric point of view.
6
Setup and migration tools
IT generalists can set up storage quickly
and easily and migrate data using
“best-practice” wizards.
Features and benefits
• Breakthrough simplicity to lower the cost and complexity of data management:
HP All-in-One Storage Manager simplifies the growth, management, and protection
of data by hiding complexity and reducing barriers to network storage.
• Integrated and adaptive storage solutions to enable dynamic business growth:
These solutions provide utility and flexibility by combining multiple storage functions
into a single integrated solution. They also allow storage to be a turnkey resource.
• Affordable and cost-effective solution for growing application environments:
Managed through a single interface, they provide multiple storage functions that
are lower than the cost of separate products and do not require you to change
your infrastructure.
• Application-centric storage management simplifies operation and lowers costs:
This management uses terms and functions familiar to application administrators
and has data migration capabilities for key Microsoft applications. It includes iSCSI
management for heterogeneous environments (Microsoft, Linux, VMware, etc.).
For more information, go to: www.hp.com/go/AiOstorage
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
7
HP StorageWorks All-in-One
Storage Systems
HP StorageWorks All-in-One (AiO) Storage
Systems provide shared storage expansion for
application servers (iSCSI SAN), enhanced file
serving for end-user clients (NAS), and
comprehensive data protection features.
NEW: StorageWorks 400t or 400r
All-in-One Storage System (AiO400t
or AiO400r)
Technical specifications
Best suited for customers needing less than 1 TB
total raw capacity.
File-serving
support
SMB/CIFS, NFS, HTTP, FTP
StorageWorks 600 All-in-One Storage
System (AiO600)
iSCSI host
support
Compliant with iSCSI industry
standards and compatible with
industry-standard iSCSI initiators;
additional iSCSI interoperability has
been verified for Windows 2000,
Windows Server 2003, VMware ESX
Server 3, SuSE Linux Enterprise Server
10, Red Hat Enterprise Linux 5, and
QLogic 40xx
Data
protection
features
Hardware RAID, VSS Snapshots
(512 per volume), HP Data Protector
Express software, Microsoft DFS
Replication, and optional HP Storage
Mirroring replication
Operating
system
Windows Storage Server 2003,
Release 2 Standard Edition
All-in-One Storage System family
Best suited for customers looking for increased
capacity, scalability, and hardware redundancy.
StorageWorks 1200 All-in-One Storage
System (AiO1200)
Best suited for customers looking for increased
performance and capacity from 12 internal drives
and a high-performance RAID controller.
StorageWorks All-in-One SB600c
Storage Blade Solution (AiO SB600c)
Best suited for customers looking for unified file
serving and shared storage array features inside of
BladeSystem c-Class environments.
8
Ordering information for AiO400t/400r/600/1200/SB600c
Ordering information AiO400t
Optional software components
AK298A AiO400t 1 TB SATA (Euro)
HP Storage Mirroring
AK296A AiO400t 1 TB SATA (Amer)
T5321A Storage Mirroring for All-in-One Storage
AK297A AiO400t 1 TB SATA (Asia)
Options to extend included Data Protector Express
software
AK299A AiO400t 1 TB SATA (China)
AK300A AiO400t 1 TB SATA (Aust)
(Note: No options are required for basic backup and recovery
of iSCSI LUNs or NAS file volumes.)
AK293A AiO400t 584 GB SAS (Euro)
AK291A AiO400t 584 GB SAS (Amer)
For the protection of networked Windows, Linux, and NetWare
servers by backup to AiO storage pool:
• HP Data Protector Express Network Client Agent (BB121AA)—
one per protected machine
AK292A AiO400t 584 GB SAS (Asia)
AK294A AiO400t 584 GB SAS (China)
AK295A AiO400t 584 GB SAS (Aust)
For the protection of networked Microsoft Exchange servers while
servers are online by backup to AiO storage pool:
• HP Data Protector Express Microsoft Exchange Online Backup
Agent (BB123AA)—one per protected machine
Ordering information AiO400r
AK224A AiO400r 1 TB SATA
AK225A AiO400r 2 TB SATA
• HP Data Protector and Express Network Client Agent
(BB121AA)—one per protected machine
AK226A AiO400r 1.2 TB SAS
For protection of Microsoft SQL Servers while servers are online
by backup to AiO storage pool:
• HP Data Protector Express Microsoft SQL Online Backup Agent
(BB124AA)—one per protected machine
Ordering information AiO600
AG538A AiO600 1.5 TB SATA
AG543A AiO600 3.0 TB SATA
AG549A AiO600 876 GB SAS
• HP Data Protector Express Network Client Agent (BB121AA)—
one per protected machine
AG727A AiO600 1.8 TB SAS
For automated disk-to-disk (AiO storage pool)-to-tape backup:
• HP Data Protector Express D2D2Any Option (BB128AA)
AG546A AiO Tower-to-Rack Conversion Kit
Ordering information AiO1200
AG655A AiO1200 3 TB SATA
AG656A AiO1200 6 TB SATA
AG657A AiO1200 9 TB SATA
AG658A AiO1200 1.7 TB SAS
AG659A AiO1200 3.6 TB SAS
Ordering information AiO SB600c
AG780A AiO SB600c 1 TB SAS Storage Blade Solution
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
9
Technical specifications
AiO400t
AiO400r
AiO600
Processor Dual-core Intel® Pentium® E2160
1.8 GHz
Quad-core Intel® Xeon®
E5405 2.00 GHz (one standard;
up to two supported)
Dual-core Intel® Xeon® 5150
2.67 GHz
One 4 MB L2 cache memory
Memory 2 GB/8 GB
(std./max.)
2 GB/32 GB
1 GB/4 GB
Storage
Smart Array E200 Controller
controller with 128 MB Battery Backed
Write Cache (BBWC)
Smart Array E200 Controller
with 128 MB with BBWC
Smart Array E200i Controller
with 128 MB BBWC
Internal
Four 3.5" (large form factor)
storage
non hot-pluggable drive bays
(varies by • 1 TB SATA model:
model)
four 250 GB 7.2k rpm
SATA HDDs
• 584 GB SAS model:
four 146 GB 15k rpm
SAS HDDs
Four 3.5" (large form factor)
front load, hot-pluggable drive bays
• 1 TB SATA model: four 250 GB
7.2k rpm SATA HDDs
• 2 TB SATA model: four 500 GB
7.2k rpm SATA HDDs
• 1.2 TB SAS model: four 300 GB
15k rpm HDDs
Six 3.5" (large form factor) front
load, hot-pluggable drive bays
• 1.5 SATA model:
6 x 250 GB 7.2k rpm HDDs
• 3 TB SATA model
6 x 500 GB 7.2k rpm HDDs
• 876 GB SAS model
6 x 146 GB 7.2k rpm HDDs
• 1.8 TB SAS model
6 x 300 GB 15k rpm HDDs
Storage
None
expansion
MSA50/60/70
MSA20/30/50/60/70
Network • Embedded NC105i PCIe
controller
Gigabit Ethernet Server
Adapter
• Additional NC360T Dual Port
Gigabit Ethernet Server
Adapter
• Embedded NC320i PCIe
Dual Port Gigabit Ethernet Server
Adapter
• Embedded NC373i Multifunction
Gigabit Network Adapter
• Additional Dual-Port NC360T
10/100/1000T
Form
factor
1U rack
5U (tower or rack)
10
Micro ATX tower
Technical specifications
AiO1200
AiO SB600c
Processor
Dual-core Intel® Xeon® 3070
2.67 GHz
Quad-core Intel® Xeon® 5345 2.33 GHz
(one standard; up to 2 supported)
Memory
(std./max.)
2 GB/4 GB
2 GB/4 GB
Storage
controller
HP Smart Array P400/512 MB
with BBWC
• Integrated HP Smart Array E200i Controller
with 128 MB BBWC
• Smart Array P400/256 MB with BBWC
Internal
storage*
(varies by
model)
Twelve 3.5" (large form factor)
front load, hot-pluggable drive bays
• 3 TB SATA model:
12 x 250 GB 7.2k rpm HDDs
• 6 TB SATA model:
12 x 500 GB 7.2k rpm HDDs
• 9 TB SATA model:
12 x 750 GB 7.2k rpm HDDs
• 1.7 TB SAS model:
12 x 146 GB 15k rpm HDDs
• 3.6 TB SAS models:
12 x 300 GB 15k rpm HDDs
• Two Small Form Factor (SFF) 146 GB 10K SAS
hot-pluggable hard disk drives (in SB600c server
blade)
• Six Small Form Factor (SFF) 146 GB 10K SAS
hot-pluggable hard disk drives (in SB600c storage
blade)
Storage
expansion
MSA50/60/70
None
Network
controller
Embedded NC324i PCIe Dual-Port
Gigabit Server Adapter
Two embedded NC373i Multifunction Gigabit
Server Adapters with TCP/IP offload engine
Form factor 2U (rack)
Simply
Consolidation
Simply File
Services
One half-height BladeSystem c-Class server blade
and one half-height BladeSystem c-Class storage
blade
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
11
HP StorageWorks Modular
Smart Array (MSA) family
The HP StorageWorks MSA family of enclosures
delivers industry-leading availability, storage
density, and upgradability to meet customers’
demanding and growing storage needs.
Ideal for entry-level businesses, departmental, and branch-office customers, MSA models
range from low-cost SATA drive storage enclosure models to high-performance disk arrays,
and all offer:
• High Availability standard with hot-pluggable and redundant power supplies and
cooling fans
For more details about the MSA family, visit: www.hp.com/go/msa2000
For configuration tools, visit: www.hp.com/go/nsssizer
For supported environments, server configurations and storage controllers, visit:
www.hp.com/products/quickspecs and click on Storage Products.
Availability and performance
Direct server
connect
SCSI shared
storage array
MSA60
MSA2000i
MSA50
MSA500 G2
MSA20
Fibre Channel
SAN arrays
MSA2000fc
MSA70
MSA30
12
iSCSI SAN
arrays
HP StorageWorks
MSA20 and MSA30
HP StorageWorks MSA20
These external disk enclosures provide
additional storage capacity for servers as well
as for MSA SAN arrays. They eliminate the
need to buy new servers when only additional
storage is required, and their modular design
enables expansion from a few disks to multiple
terabytes.
HP StorageWorks MSA30
Key features and benefits
• A common storage platform that allows for future storage consolidation to a SAN
• Hot-pluggable disk drives, power supplies, and fans
• Redundant fans and redundant power supplies
• Dual-power hot-pluggable supplies that are sufficient to provide power to the enclosure
and maintain normal operating levels
• Environmental Monitoring Unit (EMU) monitors environmental conditions within the
enclosure and the components, such as the power supply and fans
Technical specifications
MSA20
MSA30
MSA30 MI
Ordering information MSA20
Total drive
count
12 SATA
14 SCSI
14 SCSI
335921-B21 HP StorageWorks MSA20 Enclosure
Drives used
3.5" LFF
3.5" LFF
3.5" LFF
Rack height
2U
3U
3U
349239-B21 HP 250 GB SATA 7.2K
Maximum
storage
9 TB
4.2 TB
4.2 TB
Ordering information MSA30
Storage
controller
SCSI Smart Array controller (server based)
RAID
0, 1, 1+0, 5, 6 (ADG)
OS Support
Windows
Linux
NetWare
SCO
Windows
Linux
NetWare
HP-UX
OpenVMS
Supported SATA 3.5" LFF Hard Disk Drives:
432341-B21 HP 750 GB SATA 7.2K
395473-B21 HP 500 GB SATA 7.2K
302969-B21 HP StorageWorks MSA30 SB
Enclosure (single bus)
302970-B21 HP StorageWorks MSA30 DB
Enclosure (dual bus)
359645-B21 HP StorageWorks MSA30 MI Enclosure
HP-UX
OpenVMS
Supported U320 Universal Hard Disk Drives:
411089-B22 HP 300 GB SCSI 15K
347708-B22 HP 146 GB SCSI 15K
286778-B22 HP 72 GB SCSI 15K
286776-B22 HP 36 GB SCSI 15K
350964-B22 HP 300 GB SCSI 10K
286716-B22 HP 146 GB SCSI 10K
286714-B22 HP 72 GB SCSI 10K
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
13
HP StorageWorks MSA50,
MSA60, and MSA70
These high-availability, high-performance, and
high-capacity SAS disk enclosures support your
existing and future storage needs.
HP StorageWorks MSA50
Technical specifications
Key features and benefits
• Support for SAS AND SATA mix in the same enclosure
(MSA50 and MSA60 only), which delivers data-transfer
rates of up to 3 Gb/s
HP StorageWorks MSA50
Total drive
count
10 SAS/SATA
Drive form
factor*
SFF
Rack height
1U
Maximum
storage
1.4 TB (using 146 GB SAS
SFF disk drives)
Storage
controller
SAS Smart Array controller
P600, P800, or E500 on
server
• Hot-pluggable disk drives, fans and power supplies
RAID
0, 1, 1+0, 5, 6 (ADG)
• Easy removal of parts provides better serviceability, with
no tools required
OS support
Windows, Linux, NetWare
• Provides storage capacity of up to 9 TB per enclosure
• Multi-terabyte scalability by cascading several enclosures
(1 + 3) x 12 = 48 disk slots behind a single SAS controller
port for a potential total capacity of 36 TB (MSA60 only)
• A common storage platform that allows for future storage
consolidation to a SAN
• SFF drives allow increased air flow through the storage unit
for better cooling and reliability
• Small Form Factor (SFF) at 2.5 inches enables growth in
space-constrained environments, lower power
consumption, and higher I/O performance with more disk
drives per unit space
• Large Form Factor (LFF) at 3.5 inches enables multi-terabyte
capacity, high megabyte-per-second performance, and
effective cost-per-gigabyte ratio
Ordering information MSA50
364430-B21 HP StorageWorks MSA50 Enclosure
Supported SAS and SATA 2.5" SFF
hard disk drives:
431935-B21 HP 72 GB SAS 15K SP
431933-B21 HP 36 GB SAS 15K SP
431958-B21 HP 146 GB SAS 10K SP
375861-B21 HP 72 GB SAS 10K SP
375859-B21 HP 36 GB SAS 10K SP
431786-B21 HP 120 GB SATA 5.4K
379306-B21 HP 60 GB SATA 5.4K
14
HP StorageWorks MSA60
HP StorageWorks MSA70
Technical specifications
HP StorageWorks MSA60
HP StorageWorks MSA70
12 SAS/SATA
25 SAS/SATA
LFF
SFF
2U
2U
9 TB (using 750 GB SATA LFF disk drives)
3.6 TB (using 146 GB SAS SFF disk drives)
SAS Smart Array controller P600, P800,
or E500 on server
SAS Smart Array controller P600, P800,
or E500 on server
0, 1, 1+0, 5, 6 (ADG)
0, 1, 1+0, 5, 6 (ADG)
Windows, Linux, NetWare, SCO
Windows, Linux, NetWare, SCO
Ordering information MSA60
Ordering information MSA70
418408-B21 HP StorageWorks MSA60 Enclosure
418800-B21 HP StorageWorks MSA70 Enclosure
Supported SAS and SATA 3.5" LFF Hard Disk Drives:
431944-B21 HP 300 GB SAS 15K SP
Supported SAS and SATA 2.5" SFF Hard Disk Drives:
431935-B21 HP 72 GB SAS 15K SP
375872-B21 HP 146 GB SAS 15K SP
431933-B21 HP 36 GB SAS 15K SP
375870-B21 HP 72 GB SAS 15K SP
431958-B21 HP 146 GB SAS 10K SP
375868-B21 HP 36 GB SAS 15K SP
375861-B21 HP 72 GB SAS 10K SP
416127-B21 HP 300 GB SAS 15K DP
375859-B21 HP 36 GB SAS 10K SP
384854-B21 HP 146 GB SAS 15K DP
418371-B21 HP 72 GB SAS 15K DP
384852-B21 HP 72 GB SAS 15K DP
418369-B21 HP 36 GB SAS 15K DP
432341-B21 HP 750 GB SATA 7.2K
418367-B21 HP 146 GB SAS 10K DP
395473-B21 HP 500 GB SATA 7.2K
384842-B21 HP 72 GB SAS 10K DP
349239-B21 HP 250 GB SATA 7.2K
431786-B21 HP 120 GB SATA 5K
379306-B21 HP 60 GB SATA 5.4K
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
15
HP StorageWorks
MSA2000i
The HP MSA2000i is the iSCSI member of a
new generation of storage arrays. It allows
networked storage to be deployed on a
familiar and cost-effective IP infrastructure.
The MSA2000i is specifically designed for
entry-level customers and features the very
latest in functionality and technology at highly
affordable investment price points.
Key features and benefits
• For entry-level IP SAN needs: The MSA2000i is a low-cost,
scalable storage consolidation system that utilizes Ethernet
connectivity to build your SAN. It supports a choice of SAS
drives for high-speed heavy duty work, and SATA drives for
archival storage.
• Simple management: By utilizing the Ethernet protocol
combined with the powerful but easy-to-use management,
MSA2000i software makes it ideal for departmental and
remotely located IP SANs. It features the latest in browserbased controller communication, so access is not restricted
geographically.
Technical specifications
Total drive
count
48 SAS or SATA drives
(with additional enclosures)
Rack height
2U
Maximum
storage
3.6 TB SAS scalable to
14.4 TB
9 TB SATA scalable to
36 TB
RAID
0, 1, 3, 5, 6, 10, 50
• Scalability: With the addition of up to three drive
enclosures, the MSA2000i can control up to 48 drives and
scale capacity to over 14 TB of SAS or 36 TB of SATA.
• Platform support: The MSA2000i supports all HP ProLiant
servers running Windows or Red Hat and SuSE Linux in
single-server or clustered implementations.
• High availability: In addition to having redundant fans,
power supplies, and other hot-pluggable components, the
MSA2000i also provides controller-based snapshot and
clone capabilities for increased data protection.
• Complete solution: All configuration, management, and
partitioning and expansion capability comes as standard,
without unexpected extra charges.
Ordering information
AJ746A HP 2012i SC Modular Smart Array
AJ747A HP 2012i DC Modular Smart Array
AJ748A HP 2000i Modular Smart Array Controller
AJ749A HP StorageWorks MSA2000 Single I/O 3.5"
12-Drive Enclosure
AJ750A HP StorageWorks MSA2000 Dual I/O 3.5"
12-Drive Enclosure
AJ751A HP StorageWorks MSA2000 Drive Enclosure
I/O Module
AJ735A MSA2000 146GB 15K SAS 3.5" HDD
AJ736A MSA2000 300GB 15K SAS 3.5" HDD
AJ738A MSA2000 500GB SATA 3.5" HDD
AJ739A MSA2000 750GB SATA 3.5" HDD
16
The HP StorageWorks
MSA2000fc
The HP MSA2000fc is the newest Fibre
Channel addition to the Modular Smart
Array family, bringing high-speed 4 Gb Fibre
Channel to an array specifically designed
for entry-level users. It features the very latest
in functionality and a mature technology at
highly affordable investment price points.
Key features and benefits
Technical specifications
• Consolidated storage: 4 Gb Fibre Channel technology
provides high-speed access to data stored on enterprise-class
SAS drives or SATA drives for inexpensive archiving. Its low
cost and modular architecture make it ideal for users who
need a storage solution that is able to start small and
expand as their needs grow.
• Scalability: You can start with a single-controller array
with space for 14 hard drives. You can then add a second
controller and grow to 48 drives, increasing capacity to over
14 TB of SAS or 36 TB of SATA as your needs expand.
Total drive
count
48 SAS or SATA drives
(with additional enclosures)
Rack height
2U
Maximum
storage
3.6 TB SAS scalable to
14.4 TB
9 TB SATA scalable to
36 TB
RAID
0, 1, 3, 5, 6, 10, 50
• Simple management: Powerful but easy-to-use management
software makes it ideal for departmental and remote location
SANs.
• OS and server support: The MSA2000fc supports all
HP ProLiant servers, including server blades running
Windows or Red Hat and SuSE Linux in standalone
servers or clustered implementations.
• High availability: In addition to having redundant fans,
power supplies, and other hot-pluggable components, the
MSA2000fc also provides controller-based snapshot and
clone capabilities for increased data protection.
• Complete solution: All configuration, management, and
partitioning and expansion capability comes as standard,
without unexpected extra charges.
Ordering information
AJ742A HP 2012fc SC Modular Smart Array
AJ743A HP 2012fc DC Modular Smart Array
AJ744A HP 2000fc Modular Smart Array Controller
AJ745A HP 2212fc Dual Enhanced Controller
Modular Smart Array
AJ749A HP StorageWorks MSA2000 Single I/O
3.5" 12-Drive Enclosure
AJ750A HP StorageWorks MSA2000 Dual I/O 3.5"
12-Drive Enclosure
AJ751A HP StorageWorks MSA2000 Drive Enclosure
I/O Module
AJ735A MSA2000 146GB 15K SAS 3.5" HDD
AJ736A MSA2000 300GB 15K SAS 3.5" HDD
AJ738A MSA2000 500GB SATA 3.5" HDD
AJ739A MSA2000 750GB SATA 3.5" HDD
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
17
HP StorageWorks 8 Gb
Simple SAN Connection
product family
HP simplifies SANs by combining 8 Gb Fibre
Channel performance with end-to-end SAN
management in a solution capable of
supporting emerging technologies at today’s
4 Gb pricing. The HP StorageWorks 8 Gb
Simple SAN Connection product family makes
installing and managing your SAN easy.
HP StorageWorks 81Q PCI-e
Fibre Channel Host Bus Adaptor
HP StorageWorks 8/20Q
Fibre Channel Switch
Key features and benefits
Technical specifications
• High performance at affordable pricing: State-of-the-art 8 Gb
Fibre Channel technology provides the bandwidth needed to
support emerging technologies.
HP StorageWorks 8/20Q
Fibre Channel Switch
• Enterprise-class features: Powerful switch and HBA features
help you get the most out of your SAN.
Performance
8 Gb/s
• Integrated end-to-end management: You can configure and
monitor HP switches, HBAs, and storage from a convenient
unified dashboard.
Max. ports
20
Min. ports
8
Aggregate
switch
bandwidth
320 Gb/s
Form factor
1U
• Ease of deployment: You can eliminate the risk of expensive
configuration errors with point-and-click wizards.
• Aggressively priced bundle: The 8 Gb Simple SAN
Connection Kit includes everything required for a 4-host SAN
infrastructure, including 8 Gb HBAs, cables, and SFPs—just
add your choice of HP storage.
• Scalability: As your needs change, you can expand using
four-port license keys that provide up to 20 ports per chassis,
then link additional switches and HBAs to create a larger
SAN of any topology.
• Investment protection: The 8 Gb Simple SAN Connection
products are priced competitively with previous generation
products.
Ordering information
AK241A HP StorageWorks 8 Gb Simple SAN Connection Kit
AK242A HP StorageWorks 8/20Q Fibre Channel Switch
AK344A HP StorageWorks 81Q PCI-e FC HBA
T5463A HP StorageWorks 8/20Q 4-port Upgrade LTU
AJ718A HP 8 Gb Short Wave FC SFP+ 1 Pack
18
HP StorageWorks 81Q
PCI-e Fibre Channel HBA
Number of
channels
Single
Port speed
8 Gb/s
Slot type
supported
PCI Express to Fibre Channel
Servers
supported
HP ProLiant ML and DL platforms
HP StorageWorks 4400
Enterprise Virtual Array
The HP StorageWorks EVA4400 provides an
enterprise-class virtual storage array that can be
deployed easily at an affordable price for the
midsized customer.
Key features and benefits
• Affordable enterprise-class storage array functionality:
The EVA4400 is easy to install, upgrade, and manage,
at an affordable price for midsized customers.
• Virtualization improves capacity and reduces management
complexities: Reduces complexities of installations by
employing EVA virtualization capabilities to improve
management resources.
• Less time managing storage: Installation is quick and easy,
taking only a few hours. It’s easy to upgrade, repair, and
replace components without the need for a service call.
• Lower cost of ownership: Contributing to an attractive total
cost of ownership, the EVA4400 is more affordable and less
complex than traditional arrays.
Technical specifications
Total drive
count
96 FC or FATA drives
Rack
height
2U
(2 controllers per enclosure)
Maximum
storage
1 to 96 TB
RAID
Vraid1, Vraid 0+1, Vraid5,
Cross Vraid
• Simplified integration of leading business applications:
EVA4400 Solution Blocks provide blueprints for integration
with Microsoft Exchange, Oracle,® and SAP that combines
the right server, storage, and application components for
quick deployment of typical business projects.
• Storage that keeps pace in the agile world of virtual servers:
In a dynamic VMware environment, the most complementary
storage is one that can respond quickly to change. The
EVA4400 makes it easy to configure and provision storage.
• Complete solution for storage and servers: Combined with
HP BladeSystem, the EVA4400 provides a complete solution
where storage and servers are managed together.
Ordering information
• Easy and robust disaster recovery: Local and remote
replication software, HP StorageWorks Business Copy EVA
and Continuous Access EVA, protect data, so in the event
of a service disruption, recovery is quick and easy.
AJ711A HP StorageWorks 400 GB 10K FC EVA
M6412 Hard Disk Drive
• High availability for planned uptime: High availability with
a dual-redundant architecture of high-end arrays that
supports robust local and remote replication capabilities.
AG637A EVA4400 dual controller assembly (2U)
AG638A M6412 FC Drive Enclosure (2U)
AG556A HP StorageWorks 146 GB 15K rpm 4 Gb
dual-port FC EVA M6412 Hard Disk Drive
AG690A HP StorageWorks 300 GB 15K rpm 4 Gb
dual-port FC EVA M6412 Hard Disk Drive
AG803A HP StorageWorks 450 GB 15K rpm 4 Gb
dual-port EVA M6412 Enclosure Hard Disk Drive
• 8 Gb/s ready: Embedded switch model includes two 8 Gb/s AG691A HP StorageWorks 1 TB FATA dual-port EVA
M6412 Enclosure Hard Disk Drive
embedded 10-port B-series SAN switches, providing access
to the industry’s fastest-performing SAN infrastructure.
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
19
HP storage networking
As the worldwide leader in storage area
networks (SANs), HP StorageWorks delivers
flexible, open, standards-based storage
networking solutions that are suitable for
any business size.
HP’s comprehensive family of SAN products and solutions is designed to meet a range
of storage networking needs from small and medium-sized businesses to the largest
enterprise businesses. HP StorageWorks SAN solutions deliver the scalability,
performance, and broad functionality required for critical data and applications.
Key features and benefits
• Upgradeable: investment protection through backwards compatibility with oldergeneration switches and ability to upgrade device firmware without disruption
• Reduced complexity: architectural guidance through the SAN Design Guide, solutionfocused blueprints, and essential flexible SAN design and efficiency resources such as
SAN Designer and SAN Visibility
• High availability: industry-leading availability levels through director-class products
and redundant-fabric SAN topology designs
• Secured: authentication, authorization, access control, zoning, and data encryption
provide added levels of network security
• Open: support for multiple operating systems and clustering environments; new
standards-based fabric interoperability among B-series, M-series, and C-series for
outstanding flexibility and investment protection; refer to SAN Design Guide for
currently supported configurations
• Scalable: in distance, connectivity, and performance to enable both today’s and
tomorrow’s connectivity needs
• Multiprotocol: ability to support multiprotocol infrastructures, including Fibre Channel,
iSCSI, and Fibre Channel over IP (FCIP)
For detailed information, white papers, and other content on HP’s approach and added
value for the SAN infrastructure, see: www.hp.com/go/san
For technical references, see the quickspecs: www.hp.com/products/quickspecs
20
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
21
HP StorageWorks SAN
Design Guide
As the worldwide leader in SANs,
HP StorageWorks delivers the flexible,
open, standards-based storage infrastructure
solutions suitable for any business size. This
leadership is demonstrated and published
in the HP StorageWorks SAN Design Guide.
HP continues driving simplicity in network storage by providing a completely new edition
of the SAN Design Guide (SDG). The SDG provides customers with the benefit of HP
engineering guidance, when building and designing scalable, highly available enterprise
SANs. More specifically, it provides:
• Architecture guidance
• Massive configuration support
• Implementation best practices
• SAN rules for incorporating new multiprotocol technologies
For in-depth information about HP’s qualified SAN architectures and best practices,
consult the SAN Design Guide: www.hp.com/go/sandesignguide
22
SAN Visibility and
SAN Designer
SAN Visibility and SAN Designer are essential,
flexible resources that help users configure and
improve the efficiency of their SANs. These
easy-to-navigate, intuitive interfaces simplify
the configuration and analysis processes.
SAN Visibility
SAN Visibility is a SAN data analysis tool that analyzes your SAN configuration securely,
providing an automated inventory process for switches, HBAs, and storage systems,
including firmware version verification.
SAN Designer
SAN Designer provides quick and easy ways to design SANs based on specific
performance, cost, and future storage needs. The tool generates a SAN topology diagram,
a detailed list of required SAN components, as well as recommendations for planning
future growth requirements.
For additional information, refer to the Storage Networking Blueprints and Solutions page:
www.hp.com/go/san
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
23
HP StorageWorks
B-series infrastructure
The HP StorageWorks B-series switch family
provides a comprehensive range of SAN
solutions—from flexible SAN switches, software
features, and embedded switches to enterpriseclass director switches.
Key features and benefits
B-series SAN directors and SAN switches provide a
flexible, intelligent platform for networking storage.
With models ranging from entry-level 8-port SAN
switches to 384-port directors with multiple blade
options, the B-series family addresses the needs of
small departments and global enterprise businesses
alike.
Key features include:
• Multiprotocol support (Fibre Channel, FCIP,
and iSCSI)
B-series software features
• Power Pack: includes a specially priced bundle
featuring Advanced Performance Monitoring,
Fabric Watch, ISL Trunking, and Extended Fabric
• Advanced Performance Monitoring: provides
complete resource utilization analysis to measure
end-to-end service levels and optimize performance
in large SANs
• Fabric Watch: proactively monitors the health and
performance of switches and the SAN fabric and
sends alerts about potential faults
• Extended Fabric: increases SAN fabric coverage
over longer distances—up to 500 km
• Flexible, scalable with investment protection
• LSANs (Logical SANs)
• ISL Trunking: logically groups up to eight e-ports to
provide up to 32 GB/s bandwidth in a single
logical pipe
• 1 Gb/s, 2 Gb/s and 4 Gb/s auto-sensing
performance
• Extended Fabrics: extends SANs to provide
“native” Fibre Channel distances up to 500 km
4/256 SAN Director
Enterprise
class
4/64 SAN Switch
4/32B SAN Switch
Midrange
4/16 SAN Switch
4/8 SAN Switch
Entry-level
Embedded
2/8 MSA
SAN Switch
Brocade 4 GB SAN Switch
for HP BladeSystem p-Class
> 10
24
Port count (maximum)
Brocade 4 GB SAN Switch
for HP BladeSystem c-Class
30
< 70
HP B-series SAN Switches
for BladeSystems
HP B-series SAN Switches for BladeSystems
maximize server consolidation and efficiency.
Introducing the Brocade 4 GB SAN Switch for
HP BladeSystem c-Class, the most expandable
embedded SAN switch module for a server
blade in the market.
Brocade 4 GB SAN Switch for
HP BladeSystem p-Class
Brocade 4 GB SAN Switch for
HP BladeSystem c-Class
Technical specifications
Brocade 4 GB SAN Switch for
HP BladeSystem p-Class
Brocade 4 GB SAN Switch for
HP BladeSystem c-Class
Description
Embedded switch providing SAN
Fibre Channel connectivity for
blade servers
Embedded switch providing SAN
Fibre Channel connectivity for
blade servers
HP Part
numbers
12 ports base
A7533A 12 ports full-fabric enabled
AE370A
12 ports full-fabric
A7534A 24 ports full-fabric enabled
AE327A
12 ports Power Pack
A7535A 24 ports Power Pack
AE371A
No. of ports
12 (4 external/8 internal)
12 (any combination
internal/external)
24 (16 internal/8 external)
software upgradable
Performance
1, 2, 4 Gb/s auto-sensing
1, 2, 4 Gb/s auto-sensing
Hardware
redundancy
Hot-pluggable/redundant power
supply in BladeSystem enclosure
Hot-pluggable/redundant power
supply in BladeSystem enclosure
Included
software
Fabric OS
Zoning
Web Tools
Fabric OS
Hardware Enforced Zoning
Web Tools
Dynamic Path Selection
Optional
software
Base switch to full-fabric license
T4261A
Power Pack Software Bundle
T3573A Power Pack Software Bundle
T3573A
SFP 4 Gb/s Short-Wave
A7446B SFP 4 Gb/s Short-Wave
A7446B
Optical
connectivity
2 Short-Wave SFPs included
in all models
SFP 4 Gb/s Long-Wave
Simply
Consolidation
Simply File
Services
Simply Business
Protection
12-port upgrade license for
AE370A
AE373A
2 Short-Wave SFPs included in
12-port models
4 Short-Wave SFPs in 24-port
models
AE493A SFP 4 Gb/s Long-Wave
What’s in the box
Jargon buster
AE493A
HP Care Pack
Services
25
HP B-series SAN Switches
High-performance 8- to 64-port SAN switches
meet high port-count needs for growing
enterprise businesses. The new 4 Gb/s
HP StorageWorks 4/64 SAN Switch delivers
the best performance and value in a 32- to
64-port SAN switch.
HP StorageWorks SAN Switch 4/8, 4/16
HP StorageWorks SAN Switch 4/32B
Technical specifications
Description
B-Series 4/8 and 4/16 SAN Switches
B-Series 4/32B SAN Switch
HP Part
numbers
8 ports base “0 e-port”
8 ports full-fabric
16 ports full-fabric
16 ports Power Pack
16 ports full-fabric
32 ports full-fabric
32 ports Power Pack
No. of ports
8, 12, 16 software
upgradable
6, 24, 32 software
upgradable
Performance
1, 2, 4 b/s auto-sensing
1, 2, 4 Gb/s auto-sensing
Hardware
redundancy
N/A
Redundant hot-swappable
fans and power supplies
Included
software
Fabric OS
Hardware Enforced Zoning
Web Tools
Fabric OS
Hardware Enforced Zoning
Web Tools
Optional
software
Power Pack Software Bundle
4-port upgrade license
Base switch to full-fabric
license
Secure Fabric OS
Fabric Manager (10 domain)
Fabric Manager (unlimited)
T3573A
T4260A
T4261A
SFP 4 Gb/s Short-Wave
SFP 4 Gb/s Long-Wave
A7446B
AE493A
Optical
connectivity
26
A7984A
A8000A
A7985A
A7987A
332924-B21
T4270A
T4269A
AG756A
AG757A
AG758A
Power Pack Software Bundle
8-port upgrade license
Secure Fabric OS
Fabric Manager (10 domain)
Fabric Manager (unlimited)
313448-B21
T3677A
332925-B21
T4270A
T4269A
SFP 4 Gb/s Short-Wave
SFP 4 Gb/s Long-Wave
A7446B
AE493A
HP StorageWorks SAN Switch 4/64
Technical specificationsnical specifications
Description
B-Series 4/64 SAN Switch
HP Part
numbers
32 ports full-fabric
64 ports full-fabric
32 ports Power Pack
No. of ports
32, 48, 64 software
upgradable
Performance
1, 2, 4 Gb/s auto-sensing
Hardware
redundancy
Redundant hot-swappable
fans and power supplies
Included
software
Fabric OS
Hardware Enforced Zoning
Web Tools
Optional
software
Power Pack Software Bundle
16-port upgrade license
Secure Fabric OS
Fabric Manager (10 domain)
Fabric Manager (unlimited)
T4412A
T4411A
332925-B21
T4270A
T4269A
Optical
connectivity
SFP 4 Gb/s Short-Wave
SFP 4 Gb/s Long-Wave
A7446B
AE493A
Simply
Consolidation
Simply File
Services
AE495A
AG457A
AE496A
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
27
HP StorageWorks
C-series infrastructure
Choosing a Cisco MDS 9000 storage
interconnect solution within the
HP StorageWorks family brings you
the technology of the IP networking
market leader as well as the support of a
leading systems and storage manufacturer.
Key features and benefits
The C-series family expands on the broad HP portfolio of SAN infrastructure solutions.
These solutions provide high performance and scalability and deliver intelligent network
services such as:
• Multiprotocol and multi-transport integration (Fibre Channel, iSCSI, and FCIP)
• Virtual SANs (VSANs)
• Advanced traffic management
• Embedded diagnostics
• Role-based security
Cisco MDS 9509
Director Switch
Cisco MDS 9506
Director Switch
Enterprise
class
Cisco MDS 9513
Director Switch
Cisco MDS 9222i
Fabric Switch
Midrange
Cisco MDS 9124
Fabric Switch
Entry-level
Cisco MDS 9124e Fabric Switch
for HP BladeSystem c-Class
Embedded
> 20
Port count
28
50
100
< 500
HP C-series Fabric Switches
for BladeSystem
HP C-series Fabric Switch for HP BladeSystem
c-Class maximizes server consolidation and
efficiency. The switch has an integrated design
to decrease complexity and reduce costs.
Cisco MDS 9124e Fabric Switch
for HP BladeSystem c-Class
Technical specifications
Description
Cisco MDS 9124e Fabric Switch for HP BladeSystem c-Class
HP Part numbers
12 ports
24 ports
No. of ports
12 ports (8 internal/4 external)
24 ports (16 internal/8 external) software upgradable
Performance
1, 2, 4 Gb/s auto-sensing
Hardware redundancy
Hot-pluggable/redundant power and cooling from
BladeSystem enclosure
Included software
SAN OS 3.1, Virtual SANs, PortChannels,
Quality of Service (QOS), Security,
Embedded Diagnostics
Cisco Fabric Manager
Optional software
Cisco MDS 9124e 12-port upgrade LTU
Cisco MDS 9100 Enterprise Package for 1 switch LTU
Cisco Fabric Manager Server for 1 Switch LTU
T5169A
A7515A
A7512A
Optical connectivity
SFP 4 Gb/s Short-Wave (4-pack) 500 m
SFP 4 Gb/s 4 km
SFP 4 GB/s Long-Wave 10 km
AE379A
AE494A
AE380A
Optional accessories
Cisco MDS 9000 Port Analyzer
A7430A
AG641A
AG642A
Note: The MDS 9124e Fabric Switch is an embedded switch, not a standalone switch.
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
29
Cisco MDS 9124 Fabric Switch
C-Series
Technical specifications
Description
Cisco MDS 9124 Fabric Switch C-Series
HP Part numbers
8 ports
16 ports
24 ports
No. of ports
8 to 24 ports software upgradable
Performance
11, 2, 4 Gb/s auto-sensing
Hardware redundancy
Redundant power supply (optional)
Cooling fans
Included software
SAN-OS 3.1
Virtual SANs
PortChannels
Quality of Service (QOS)
Security
Embedded Diagnostics
Cisco Fabric Manager
Optional software
Cisco MDS 9124 8-Port Upgrade LTU
Cisco MDS 9100 Cisco Fabric Manager Server for 1 switch LTU
Enterprise Package for 1 switch LTU
T5171A
A7512A
A7515A
Optical connectivity
SFP 4 Gb/s Short-Wave (4-pack) 500 m
SFP 4 Gb/s 4 km
SFP 4 GB/s Long-Wave 10 km
AE379A
AE494A
AE380A
Optional accessories
Cisco MDS 9124 2nd/Spare Power Supply
Cisco MDS 9000 Port Analyzer
AG649A
A7430A
For a full overview on these enterprise products, please refer to the quickspecs pages at:
www.hp.com/products/quickspecs
30
AG646A
AG647A
AG648A
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
31
HP StorageWorks Fibre
Channel host bus adapters
(HBAs)
The HP StorageWorks Fibre Channel HBA
product family provides high-performance
connectivity for a range of operating
environments. These enterprise-class products
intelligently connect storage, servers, and
networks.
HP Fibre Channel HBA family
Part number
Name
Technology
PCI bus
Channels
AB378B
PCI-X single-port, 4 GB Fibre Channel adapter
4 GB
PCI-x
Single
AB379B
PCI-X dual-port, 4 GB Fibre Channel adapter
4 GB
PCI-x
Dual
AB429A
HP FC1143 4 GB PCI-X 2.0 HBA
4 GB
PCI-x
Single
AD167A
HP FC2143 4 GB PCI-X 2.0 HBA
4 GB
PCI-x
Single
AD168A
HP FC2243 4 GB PCI-X 2.0 HBA
4 GB
PCI-x
Dual
AE369A
HP FC1243 4 GB PCI-X 2.0 HBA
4 GB
PCI-x
Dual
A8002A
HP FC2142 PCI-e 4 GB HBA
4 GB
PCI-e
Single
A8003A
HP FC2242 PCI-e 4 GB HBA
4 GB
PCI-e
Dual
AE311A
HP FC1142 4 GB PCI-e HBA
4 GB
PCI-e
Single
AE312A
HP FC1242 4 GB PCI-e HBA
4 GB
PCI-e
Dual
AK344A
HP 81Q 8 GB PCI-e HBA
8 GB
PCI-e
Single
32
Designed for customers wishing to support their mission-critical
business applications with reliable, high-performance, Fibre
Channel connectivity, HP StorageWorks Fibre Channel host
bus adapters (HBAs) provide a choice of leading options for
compatibility in a host of operating environments.
OS platform
Array compatibility
Model/
vendor
Server platform
Linux, Netware
MSA, EVA, XP
QLogic
See array quickspec: www.hp.com/products/quickspecs
Linux, Windows
MSA, EVA, XP
QLogic
See array quickspec: www.hp.com/products/quickspecs
Windows, Linux
MSA, EVA, XP
QLogic
ProLiant support
Windows, Linux
XP, EVA, MSA
Emulex
ProLiant support
Windows, Linux
MSA, EVA, XP
Emulex
ProLiant, Intel Itanium support
Windows, Linux
XP, EVA, MSA
QLogic
ProLiant support
Windows, Linux
XP, EVA, MSA
Emulex
ProLiant, Integrity support
Windows, Linux
XP, EVA, MSA
Emulex
ProLiant, Integrity support
Windows, Linux
XP, EVA, MSA
QLogic
ProLiant support
Windows, Linux
XP, EVA, MSA
QLogic
ProLiant support
Windows, Linux
EVA, MSA
QLogic
ProLiant support
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
33
Simply File Services
Small and medium-sized businesses feel the crunch caused by growing storage data
volumes. Much of the storage growth is driven by unstructured files, such as rich
media, productivity documents, and backup files.
A dedicated and optimized file-serving solution consolidates file storage to improve
performance, simplify management, and increase efficiency. Networked storage is
accessible to all computers that can access the network, making it easier to centrally
scale, manage, and protect.
HP ProLiant Storage Servers are Windows-powered enhanced file-and-print server
solutions for small or medium business, branch office, workgroup, or data center
IT environments. These preloaded, preconfigured, and fully tested solutions take
advantage of standard Ethernet-based networks to give you consolidated networkattached storage (NAS) for file-and-print serving.
Like most NAS solutions, they support heterogeneous files. They improve data access
to clients and applications and provide network-accessible storage to a mix of clients
and servers running different operating systems and file access protocols.
Choosing an HP ProLiant Storage Server will enable you to:
• Increase shared file storage capacity quickly and easily while reducing the time
and personnel required to manage and protect data
• Consolidate the number of file-and-print servers to optimize capacity utilization and
performance usage
• Integrate the solution seamlessly into Windows environments and run preferred
backup or antivirus application right on the box
• Deploy a no-frills disk-based backup solution as an interim step or alternative to
tape backup
• Achieve near-real-time full application or file recovery over an IP network, by
combining it with HP StorageWorks Storage Mirroring software
For more information, visit: www.hp.com/go/simplystorageworks
34
HP ProLiant Storage Server
family overview
With a full range of HP ProLiant Storage Servers, you can choose the level of
performance and scalability you need to meet your specific file-serving requirements.
Rack line
Tower line
DL585 G2 Storage Server
Enterprise
Fibre Channel
SAN/EVA
gateways
DL380 G5 x64 SAN Storage Server
Departmental
DL320s Storage Server
Remote office
File/print
appliances
DL380 G5 Storage Server
ML350 G5
Storage Server
DL160 G5 Storage Server
ML110 G5
Storage Server
Want to combine file-and-print serving with application data hosting? Consider the
HP StorageWorks All-in-One Storage Systems featured on pages 5–11.
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
35
HP ProLiant Storage Servers
Key features and benefits
• Add file access to your SAN or tier SAN block
access: Some models act as a file/iSCSI gateway
into a Fibre Channel SAN, providing IP-based
access to virtually unlimited storage.
• Intelligent storage management features: Make
more efficient use of storage space using the file
deduplicating Single-instance Storage (SIS) feature
and the benefits of other storage-specific tools
such as Index-based search, Microsoft SharePoint
Services support, Quotas, File Screening, Storage
Reporting, and DFS Replication.
• Print server support: The print management
console is integrated into the core functionality
of the operating system, allowing management
of multiple printers from a single interface.
• HP ProLiant industry-standard reliability: You can
relax because your investment is protected and
you are not locked into proprietary hardware.
• Microsoft iSCSI Software Target support: Lower
your total cost of ownership by hosting application
(block) storage on your storage server. SAN
gateway models featuring the Microsoft Windows
Unified Data Storage Server 2003 Enterprise x64
Edition operating system include iSCSI target
functionality, while other models can be upgraded
with optional software.
DL585 G2
Enterprise
+800
DL380 G5
x64 SAN
DL380 G5
400 –800
DL320s
Departmental
ML350
G5
50–400
DL160 G5
Remote office
ML110
G5
1–50
> 500 GB
Capacity
36
3 TB
< 9 TB
SAN attach
User numbers
• Fast and easy to deploy: The Windows-powered
operating system is preinstalled and user storage is
preconfigured, so it is a quick, secure, and easy
way to add storage to your network or to add
intelligent file and iSCSI services to your Fibre
Channel SAN.
• A single centralized file server platform to manage
and protect: Consolidate islands of direct-attached
storage to one easy-to-use Windows platform or
create a scalable disk-based backup or replication
target.
• Microsoft Windows-powered operating system
preinstalled: It integrates seamlessly into your
Active Directory and Distributed File System (DFS)
environments, runs your favourite antivirus or
backup applications, and, if you have used
Microsoft Management Console (MMC) before,
will not present a steep learning curve.
• Multiprotocol file serving: You can deploy in wide
range of heterogeneous file-serving environments
with support for SMB/CIFS, NFS, HTTP, FTP,
WebDAV, AppleTalk, and NetWare file protocols.
HP ProLiant ML110 G5
Storage Server
The HP ProLiant ML110 G5 Storage Server
is an affordable single processor tower
file-serving solution designed to provide
a solid network storage foundation essential
to small or remote businesses environments.
Key features and benefits
Technical specifications
• Entry-level tower platform: the two-drive 320 GB SATA
model sets a new standard for ProLiant Storage Server
affordability, while four-drive SATA and SAS models deliver
even more value with additional capacity and performance
Processor
Single-core Intel® Celeron®
420 1.6 GHz (320 GB SATA
model)
Dual-Core Intel® Pentium®
E2160 1.8 GHz (1 TB SATA,
2 TB SATA, and 584 GB
SAS models)
Memory
(std./max.)
512 MB or 1 GB/8 GB
Operating
system
Microsoft Windows Storage
Server 2003 Release 2
(Workgroup x64 Edition—
320 GB SATA model)
(Standard x64 Edition—
1 TB SATA, 2 TB SATA, and
584 GB SAS models)
Storage
controller
None—Software RAID
(320 GB SATA model)
Smart Array E200 Controller
with 128 MB BBWC
(1 TB SATA, 2 TB SATA, and
584 GB SAS models)
Internal
storage
Up to four internal LFF SATA
or SAS HDDs preinstalled
(2 x 160 GB SATA; 4 x 250
or 500 GB SATA or 146 GB
SAS)
Network
controller
Embedded NC105i PCIe
Gigabit Ethernet Server
Adapter
• Simplicity: offers a consolidated, intuitive interface to basic
storage server functionality that both novice and experienced
administrators alike will appreciate
Ordering information
AK303A HP ProLiant ML110 G5 320 GB SATA Storage Server
AK308A HP ProLiant ML110 G5 1 TB SATA Storage Server
AK313A HP ProLiant ML110 G5 2 TB SATA Storage Server
AK318A HP ProLiant ML110 G5 584 GB SAS Storage Server
Form factor Micro ATX tower
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
37
HP ProLiant DL160 G5
Storage Server
The HP ProLiant DL160 G5 Storage Server
is an affordable space-saving rack-mount
network storage solution for small workgroups,
small businesses, or remote offices.
Key features and benefits
Technical specifications
• Industry-standard hardware: the ProLiant DL160 platform
with Smart Array controller is both affordable and powerful
Processor
• Versatility for a wide range of deployments: support for
both SATA and SAS drives helps you balance capacity,
performance, and reliability
Memory
1 GB or 2 GB/32 GB
(std./max.)
Quad-core Intel® Xeon®
E5405 (2.00 GHz)
Operating
system
Microsoft Windows Storage
Server 2003 Release 2
(Standard x64 Edition)
Storage
controller
Smart Array E200 Storage
Controller with 128 MB
BBWC included
Storage
capacity
Four internal LFF SATA or
SAS HDDs preinstalled (4 x
160, 250, 500, or 750 GB
SATA or 300 GB SAS)
Network
controller
Dual embedded NC105i
PCI Express Gigabit Server
Adapters
Form factor 1U rack
Ordering information
AJ672A HP ProLiant DL160 G5 640 GB SATA Storage Server
AJ673A HP ProLiant DL160 G5 1 TB SATA Storage Server
AJ674A HP ProLiant DL160 G5 2 TB SATA Storage Server
AJ675A HP ProLiant DL160 G5 3 TB SATA Storage Server
AJ676A HP ProLiant DL160 G5 1.2 TB SAS Storage Server
38
HP ProLiant ML350 G5
Storage Server
The HP ProLiant ML350 G5 Storage Server
is a powerful tower file-serving solution with
high-availability and performance features plus
unsurpassed flexibility that is ideal for small
and medium businesses.
Key features and benefits
Technical specifications
• High-capacity SATA-based and high-performance SAS-based
models: choose the model best suited to your performance,
capacity, and price needs
• Large-capacity expansion with external storage enclosures:
with a wide range of external storage enclosures that support
SATA, SAS, SCSI, or Fibre Channel–based hard disk drives
• Dual-core Intel Xeon processor technology: dual-core
processor provides excellent performance for the most
demanding file-and-print serving requirements; add a
second processor for even greater performance capability
Processor
Dual-core Intel® Xeon® 5150
(2.67 GHz)
Memory
1 GB/4 GB
(std./max.)
Operating
system
Microsoft Windows Storage
Server 2003, Release 2
(Standard Edition)
Storage
controller
Smart Array E200i Controller
with 128 MB BBWC included
Internal
storage
Six internal 1.5G SATA or
3G SAS HDDs preinstalled
(6 x 160, 250, 500 GB
SATA, or 300 GB SAS)
Network
controller
Embedded NC373i
Multifunction Gigabit
Network Adapter
Form factor 5U tower (Optional Rack Kit
available)
Ordering information
AE420A HP ProLiant ML350 G5 960 GB SATA Storage Server
AE425A HP ProLiant ML350 G5 1.5 TB SATA Storage Server
AE430A HP ProLiant ML350 G5 3 TB SATA Storage Server
AG587A HP ProLiant ML350 G5 1.8 TB SAS Storage Server
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
39
HP ProLiant DL320s
Storage Server
The HP ProLiant DL320s Storage Server
is a highly integrated and high-density fileserving solution with enterprise-level features
at an affordable price for remote office and
departmental environments.
Key features and benefits
• High-density storage on a highly integrated platform:
packs all the storage (with 12 drive slots, the DL320s
Storage Server supports up to 9 TB raw) and I/O you
need into only 2U of rack space
• High-capacity SATA-based and high-performance
SAS-based models: choose the model that best balances
your performance, capacity, and affordability needs
Ordering information
AG650A HP ProLiant DL320s 3 TB SATA Storage Server
AG651A HP ProLiant DL320s 6 TB SATA Storage Server
AG652A HP ProLiant DL320s 9 TB SATA Storage Server
AG653A HP ProLiant DL320s 1.7 TB SAS Storage Server
AG654A HP ProLiant DL320s 3.6 TB SAS Storage Server
40
Technical specifications
Processor
Dual-core Intel® Xeon® 3070
(2.67 GHz)
Memory
(std./max.)
1 GB/4 GB
Operating
system
Microsoft Windows Storage
Server 2003 Release 2
(Standard Edition)
Storage
controller
Smart Array P400/512 MB
Controller (RAID 0, 1, 5, 6)
with BBWC
Internal
storage
Twelve 3.5" LFF SATA or SAS
hard drives, internal storage
capacity of up to 9 TB (12 x
750 GB SATA hard drives)
Network
controller
Embedded NC324i PCIe
Dual-port Gigabit Server
Adapter
Form factor
2U rack
HP ProLiant DL380 G5
Storage Server
HP ProLiant DL380 G5 Storage Servers are
high-performance network storage appliances—
and can also be used in addition to a SAN/EVA
gateway solution—for workgroup and enterprise
environments.
Technical specifications
Key features and benefits
• Flexible: A DL380 Storage Server comes as either a file
server appliance with its own direct-attached storage or as a
SAN/EVA gateway solution that adds services to your Fibre
Channel SAN.
• Scalable to large capacities: File appliance models are
designed for easy expansion with HP StorageWorks MSA
enclosures and either SAS or SATA hard disk drives. Four
models even include an MSA60 and either six or 12 hard
drives to get you started.
Processor
Up to two quad-core
Intel® Xeon® E5345
2.33 GHz
Memory
(std./max.)
2 GB/32 GB on base, 1.2 TB
SCSI, 2 TB SATA, and 1.16 TB
SAS models (all models
except x64 SAN model);
4 GB/32 GB on x64 SAN
model
Operating
system
Microsoft Windows Storage
Server 2003 Release 2
(Standard x64 Edition)—all
models except x64 SAN
model
Microsoft Windows Unified
Data Storage Server 2003
(Enterprise x64 Edition) for
x64 SAN model
Storage
controller
Smart Array P400 with 512
MB BBWC for internal drives
Smart Array 6402 with 128
MB BBWC for external drives
(1.2 TB SCSI and 2 TB SATA
models only)
Smart Array P800/512 MB
(all models except x64 SAN
model); Smart Array
P400/512 MB (x64 SAN
model)
Internal
storage
Two 36 GB SAS HDDs—all
models except 1.16 TB SAS
model (8 x 146 GB)
Network
controller
Embedded Dual NC373i
Multifunction Gigabit NICs
Form factor
2U rack (Storage Server
only)
• Additional file access for SAN or tier SAN block access:
The new x64 SAN Storage Server model is a file and iSCSI
gateway into a Fibre Channel SAN, providing IP-based
access to virtually unlimited SAN storage.
Ordering information
AG815A HP ProLiant DL380 G5 Base Storage Server
AG816A HP ProLiant DL380 G5 1.16 TB SAS
AG817A HP ProLiant DL380 G5 4.5 TB SATA Storage Server
AG818A HP ProLiant DL380 G5 9 TB SATA Storage Server
AG819A HP ProLiant DL380 G5 1.8 TB SAS Storage Server
AG820A HP ProLiant DL380 G5 3.6 TB SAS Storage Server
AG771A HP ProLiant DL380 G5 x64 SAN
Storage Server
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
41
HP ProLiant DL585 G2
Storage Server
The HP ProLiant DL585 G2 Storage Server
is a powerful and highly expandable SAN/EVA
gateway solution that is ideal for mission-critical
data center file-serving and tiered SAN (Fibre
Channel and iSCSI) environments.
Key features and benefits
• Unified storage operating system: The DL585 G2 Storage
Server comes with Microsoft Windows Unified Data Storage
Server 2003, a dedicated file-and-print server operating
system with iSCSI connectivity and clustering capability built
in. It is all based on the proven Windows Storage Server
2003 R2 code base and takes advantage of its superior
security, stability, performance, and management features.
• SAN/file/iSCSI fusion: Designed for use as a file-serving
and/or iSCSI gateway into a Fibre Channel SAN, providing
IP-based access to virtually unlimited storage. It can facilitate
consolidation of islands of direct-attached storage to the
SAN, as well as help tier block storage for application
servers by creating access to the SAN via inexpensive
Ethernet infrastructure.
• High performance, reliable, and expandable: Supports up to
four processors, up to 128 GB of memory, eight available
I/O expansion slots, multifunction gigabit NICs, Hardware
RAID, and redundant power and cooling.
Ordering information
AG630A HP ProLiant DL585 G2 Storage Server
42
Technical specifications
Processor
Two Dual-Core AMD
Opteron™ 8220SE 2.8 GHz
Memory
(std./max.)
4 GB/128 GB
Operating
system
Microsoft Windows Unified
Data Storage Server 2003
(Enterprise x64 Edition)
Storage
controller
HP Smart Array P400 with
512 MB of BBWC (in a PCI
Express slot)
Internal
storage
Two 36 GB 10k SFF SAS
HDDs
Network
controller
Embedded dual NC371i
multifunction gigabit network
adapters
Form factor
4U rack
HP StorageWorks All-in-One
Storage Systems as a fileserving solution
HP StorageWorks All-in-One (AiO) Storage
Systems are radically simple, integrated, and
affordable network storage solutions that enable
small and midsized companies to manage,
grow, and protect their data easily.
The HP StorageWorks AiO400t, AiO400r, AiO600, AiO SB600c, and new AiO1200
Storage Systems provide shared storage expansion for application servers (iSCSI SAN),
enhanced file serving for end-user clients (Windows NAS), and comprehensive data
protection. These fully integrated solutions are designed to be deployed on the existing
TCP/IP network or subnet and provide everything you need to lower the cost and
complexity associated with rapidly growing data environments.
All-in-One Storage Manager
A single interface to manage storage and
data protection from an application-centric
point of view.
Set-up and migration tools
IT generalists can set up storage quickly
and easily and migrate data using “bestpractice” wizards.
For full product overview go to pages 6 – 11 of this guide or to:
www.hp.com/go/AiOstorage
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
43
Simply Business Protection
Reliable data protection is one of the most important challenges that businesses face
today. To help ensure data availability in the event of any threat, it is essential to have
the appropriate data protection and recovery strategy in place.
With Simply Business Protection, HP makes it easy to choose the right strategy. We
offer simple and reliable solutions for every need—from instant recovery of businesscritical data to the complete protection afforded by media held offsite—all backed
by comprehensive support for lasting peace of mind:
• HP StorageWorks DAT tape drives: for low-cost, high-reliability backup of small
servers and workstations
• HP StorageWorks Ultrium tape drives: the best choice for investment protection,
in a choice of full- and half-height models
• HP StorageWorks tape autoloaders: for unattended backup that frees up IT
resources and minimizes the risk of human error
• HP StorageWorks MSL tape libraries: for centralized backup to a single automated
device
• HP Storage Media: tested and certified for all StorageWorks drives and
automation solutions
• HP StorageWorks disk-based backup solutions: disk-based iSCSI-connected solution
for unattended backup and improved restore performance
• HP Data Protection Storage Servers: near-continuous protection for Windows
file servers that allows end users to restore their own files
• HP Storage Software: customized software solutions protecting infrastructure
and data
For more information, visit: www.hp.com/go/simplystorageworks
44
HP StorageWorks tape drives,
autoloaders, and libraries
HP meets customer needs for tape backup, from small
and medium-sized businesses to enterprise corporations.
Tape drives
Tape autoloaders and libraries
Ultrium 1840
MSL8096
Ultrium 1760
Corporate/
networked
backup
Ultrium 960
Departmental/
local network
Ultrium 448
MSL6060
SB920c
Tape Blade
Ultrium 920
MSL4048
Ultrium 448c
Tape Blade
MSL6030
MSL2024
Ultrium 232
Office servers
1/8 G2
Autoloader
DAT 160
DAT 72
DAT 72x10
Autoloader
DAT 40
Workstations
All HP StorageWorks tape drives, autoloaders, and libraries come complete with an in-box
CD containing an electronic user guide, drivers, and HP StorageWorks Library and Tape
Tools diagnostic utilities.
For more information about products and connectivity, refer to: www.hp.com/go/tape and
www.hp.com/go/connect
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
45
HP StorageWorks DAT
tape drive family
The HP StorageWorks DAT tape drive family
provides the perfect balance between low cost
and high reliability for backing up small servers
and workstations.
HP StorageWorks DAT drives are based on Digital Data Storage (DDS) format, the most
successful tape backup format of all time. DDS technology has led the tape market for so
many years because it meets the needs of small and medium-sized businesses for reliable,
cost-effective data protection better than any other technology. HP’s long experience in
developing DAT drives provides customers with a proven track record of reliability.
200 GB
DAT 160
Office or
department
servers
DAT 72
50 GB
DAT 40
Individual
workstations
Capacity (compressed*)
HP StorageWorks DAT family positioning
25 GB
6
12
25
50
Speed GB/hr (compressed*)
DAT 40
DAT 72
DAT 160
Generation
Gen 4 (DDS-4)
Gen 5
Gen 6
Capacity (compressed*)
40 GB
72 GB
160 GB
Transfer rate
(GB/hr compressed*)
21.6 GB/hr
21.6 GB/hr
49.3 GB/hr
Interface
USB or SCSI
USB or SCSI
USB, SCSI, or SAS
* Assumes 2:1 data compression
46
DAT 40 SCSI Tape Drive
HP StorageWorks
DAT 40 SCSI and
DAT 40 USB Tape Drives
These tape drives provide dependable entry-level
backup solutions for smaller servers and
workstations—an ideal balance between cost
and performance. Choose between SCSI or
USB interface.
Key features and benefits
DAT 40 USB Tape Drive
Technical specifications
• Entry-level capacity: up to 40 GB* of data on a single tape
• Performance: transfer rate up to 21.6 GB/hr*
• Proven reliability: DAT has a long track record of reliability
and the largest installed base of any tape technology
Capacity
Native
20 GB
Compressed* 40 GB
Performance
Native
3.2 MB/s
Compressed* 6.4 MB/s
Burst Transfer
Rate
40 MB/s
Interface
DAT 40 SCSI: Wide Ultra
SCSI (LVD/SE)
• Low cost of ownership: lowest media price of any tape
technology
• Investment protection: full read/write compatibility with
DDS/DAT drives and media from HP and other
manufacturers
• Simplicity: HP OBDR restores your entire system at the touch
of a button
• Compact: small, half-height form factor
• Broad compatibility: with a wide range of servers, operating
systems, and backup software
• Manageability: HP StorageWorks Library and Tape Tools
utilities
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option, and
HP StorageWorks Library and Tape Tools
DAT 40 USB: USB 2.0
Series B receptacle
Reliability
125,000 hours at 100%
duty cycle
Media
compatibility
DDS-4
DDS-3
DDS-2
Dimensions
(HxWxD in.)
SCSI version:
Internal: 1.6 x 5.7 x 6.1
External: 2.2 x 7.1 x 8.7
USB version:
External: 2.2 x 7.1 x 8.7
Weight
Ordering information
SCSI version:
Internal: 2.1 lb
External: 4.2 lb
USB version:
External: 4.2 lb
HP StorageWorks DAT 40 SCSI Tape Drive
C5686C DAT 40 Internal SCSI
C5687D DAT 40 External SCSI
C7497C DAT 40 SCSI Array Module
HP StorageWorks DAT 40 USB Tape Drive
DW022A DAT 40 Internal USB
DW023A DAT 40 External USB
*Assumes 2:1 data compression
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
47
HP StorageWorks
DAT 72 SCSI and
DAT 72 USB Tape Drives
These tape drives provide the optimum
balance of dependable backup capacity
and low cost of ownership for small and
medium-sized businesses, remote offices, and
workgroups. Choose between SCSI or USB
interface.
Key features and benefits
• Entry-level capacity: up to 72 GB* of data on a single tape
• Performance: transfer rate up to 21.6 GB/hr*
• Proven reliability: DAT has a long track record of reliability
and the largest installed base of any tape technology
DAT 72 SCSI Tape Drive
DAT 72 USB Tape Drive
Technical specifications
Capacity
Native
36 GB
Compressed* 72 GB
Performance
Native
3.2 MB/s
Compressed* 6.4 MB/s
Burst Transfer
Rate
40 MB/s
Interface
DAT 72 SCSI: SCSI-3
Ultra160
• Low cost of ownership: lowest media price of any tape
technology
• Investment protection: full read/write compatibility with
DDS/DAT drives and media from HP and other
manufacturers
• Simplicity: HP OBDR and the Data Protector Express Bare
Metal Disaster Recovery option restore your entire system
at the touch of a button
• Compact: small, half-height form factor
• Broad compatibility: with a wide range of servers, operating
systems, and backup software
• Manageability: HP StorageWorks Library and Tape Tools
utilities
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option, and
HP StorageWorks Library and Tape Tools
Ordering information
HP StorageWorks DAT 72 SCSI Tape Drive
Q1522B DAT 72 Internal SCSI
DAT 72 USB: USB 2.0
Series B receptacle
Reliability
125,000 hours at 100%
duty cycle
Media
compatibility
DAT 72
DDS-4
DDS-3)
Dimensions
(HxWxD in.)
SCSI version:
Internal: 1.6 x 5.7 x 6.1
External: 2.2 x 7.1 x 8.7
USB version:
External: 2.2 x 7.1 x 8.7
Weight
SCSI version:
Internal: 2.1 lb
External: 4.2 lb
USB version:
External: 4.2 lb
Q1523B DAT 72 External SCSI
Q1524C DAT 72 SCSI Array Module
HP StorageWorks DAT 72 USB Tape Drive
DW026A DAT 72 Internal USB
DW027A DAT 72 External USB
*Assumes 2:1 data compression
48
HP StorageWorks
DAT 160 SCSI, USB, and
SAS Tape Drives
DAT 160 SCSI Tape Drive
DAT 160 USB Tape Drive
These are the highest-capacity and performance
DAT drives available with speeds of around
50 GB/hr to complete a full tape backup in
approximately three hours. Choose between
SCSI, USB, or SAS interface.
DAT 160 SAS Tape Drive
Key features and benefits
• Entry-level capacity: up to 160 GB* of data on a single tape
• Performance: transfer rate up to 50 GB/hr*
• Proven reliability: DAT has a long track record of reliability
and the largest installed base of any tape technology
• Low cost of ownership: lowest media price of any tape
technology
• Investment protection: full read/write compatibility with
DDS/DAT drives and media from HP and other
manufacturers
• Simplicity: HP OBDR and the Data Protector Express Bare
Metal Disaster Recovery option restore your entire system
at the touch of a button
• Compact: small, half-height form factor
• Broad compatibility: with a wide range of servers, operating
systems, and backup software
• Manageability: HP StorageWorks Library and Tape Tools
utilities
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option. and
HP StorageWorks Library and Tape Tools
Ordering information
HP StorageWorks DAT 160 SCSI
Tape Drive
HP StorageWorks DAT 160 USB
Tape Drive
Q1573A DAT 160 Internal SCSI
Q1580A DAT 160 Internal USB
Q1574A DAT 160 External
SCSI
Q1581A DAT 160 External USB
Q1575A DAT 160 SCSI Array
Module
Simply File
Services
Capacity
Native
80 GB
Compressed* 160 GB
Performance Native
6.9 MB/s
Compressed* 13.8 MB/s
Burst Transfer
Rate
6.9 MB/s
Interface
DAT 160 SCSI:
SCSI-3 Ultra 160
DAT 160 USB: USB 2.0
DAT 160 SAS: SAS 1.1
Reliability
125,000 hours at 100%
duty cycle
Media
DAT 160
compatibility DAT 72
DAT 40
Dimensions
(HxWxD in.)
Internal (SAS and USB):
1.6 x 5.7 x 7.2
Internal (SCSI):
1.6 x 5.7 x 7.0
External (all):
2.6 x 7.1 x 9.3
Weight
Internal (all): 2.7 lb
External (all): 5 lb
HP StorageWorks DAT 160 SAS
Tape Drive
Q1587A DAT 160 Internal SAS
Q1588A DAT 160 External SAS
Simply
Consolidation
Technical specifications
Simply Business
Protection
*Assumes 2:1 data compression
What’s in the box
Jargon buster
HP Care Pack
Services
49
HP StorageWorks
Ultrium tape family
HP’s premier line of backup devices is available
in full-height and half-height drives. Based on
the LTO Ultrium format, an open standard with a
well-defined six-generation roadmap, HP Ultrium
tape drives provide customers with the best
choice for investment protection.
Ultrium 1760
Ultrium 1840
Corporate/
networked
backup
2 TB
1 TB
Ultrium 920
Ultrium 960
Capacity (compressed*)
HP StorageWorks Ultrium family positioning
800 GB
Ultrium 448
400 GB
Ultrium 232
Department/
local network
200 GB
50
100
200
400
600
800
Speed GB/hr (compressed*)
Ultrium 232
Ultrium 448
Ultrium 920
Ultrium 960
Ultrium 1760
Ultrium 1840
Generation
Gen 1
Gen 2
Gen 3
Gen 3
Gen 4
Gen 4
Capacity
(compressed*)
200 GB
400 GB
800 GB
800 GB
1.6 TB
1.6 TB
Transfer rate
(GB/hr
(compressed*)
115 GB/hr
172 GB/hr
432 GB/hr
576 GB/hr
576 GB/hr
864 GB/hr
Form factor
Half-height
Half-height
Half-height
Full-height
Half-height
Full-height
Interface
SCSI
SCSI and SAS SCSI and SAS SCSI
SAS
SCSI and
SAS
* Assumes 2:1 data compression
50
HP StorageWorks Ultrium 232
Internal Tape Drive
HP StorageWorks
Ultrium 232 Tape Drive
This affordable first-generation LTO superdrive
delivers enterprise-class backup capacity,
performance, and reliability at a midrange price.
Key features and benefits
HP StorageWorks Ultrium 232
External Tape Drive
Technical specifications
• Affordable capacity: up to 200 GB* on a single cartridge
• High performance: transfer rate of 115 GB/hr*
• Compact: half-height form factor taking up less space in rack
environments
• Enterprise-class reliability: with active head cleaning, lower
power consumption, and intelligent tape handling
• Simplicity: HP OBDR and the Data Protector Express Bare
Metal Disaster Recovery option restore your entire system at
the touch of a button
• Investment protection: full read/write compatibility with
Ultrium drives and media from HP and other manufacturers
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option, and
HP StorageWorks Library and Tape Tools
Capacity
Native
100 GB
Compressed* 200 GB
Performance Native
16 MB/s
Compressed* 32 MB/s
Burst Transfer
Rate
160 MB/s
Interface
Wide Ultra2 SCSI (LVD)
Reliability
> 250,000 at 100%
duty cycle
Media
LTO1 Ultrium
compatibility
Dimensions
(HxWxD in.)
Internal: 1.6 5.7 x 8.1
External: 3.0 x 8.8 x 11.7
Weight
Internal: 3.2 lb
External: 10.3 lb
• Data rate matching: enables the drive to dynamically match
the transfer rate to the speed of the host for enhanced
performance and reliability
Ordering information
DW064A Ultrium 232 Internal
DW065B Ultrium 232 External
* Assumes 2:1 data compression
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
51
HP StorageWorks
Ultrium 448 Tape Drive
Based on second-generation LTO technology,
the half-height Ultrium 448 provides an
affordable backup solution for SAS- or
SCSI-based departmental servers.
Key features and benefits
• Affordable capacity: up to 400 GB* on a single cartridge
• High performance: transfer rate of 172 GB/hr*
• Compact: half-height form factor takes up less space in rack
environments
HP StorageWorks Ultrium 448
Internal Tape Drive
HP StorageWorks Ultrium 448
External Tape Drive
Technical specifications
Capacity
Native
200 GB
Compressed* 400 GB
Performance
Native
24 MB/s
Compressed* 48 MB/s
Burst Transfer
Rate
160 MB/s
Interface
Ultra160 SCSI (LVD)
3 Gb/s SAS
Reliability
> 250,000 at 100%
duty cycle
Media
compatibility
LTO2, LTO1 Ultrium
Dimensions
(HxWxD in.)
Internal: 1.6 x 5.7 x 8.1
External: 3.0 x 8.8 x 11. 7
Weight
Internal: 3.2 lb
External: 10.3 lb
• Enterprise-class reliability: with active head cleaning, lower
power consumption, and intelligent tape handling
• Simplicity: HP OBDR and the Data Protector Express Bare
Metal Disaster Recovery option restore your entire system at
the touch of a button
• Investment protection: full read/write compatibility with
Ultrium drives and media from HP and other manufacturers
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option, and
HP StorageWorks Library and Tape Tools
• Data rate matching: enables the drive to dynamically match
the transfer rate to the speed of the host for enhanced
performance and reliability
Ordering information
DW016A Ultrium 448 SCSI Internal
DW017B Ultrium 448 SCSI External
DW019A Ultrium 448 SCSI Array Module
DW028B Ultrium 448 SCSI in a 1U Rack-mount
DW085A Ultrium 448 SAS Internal
DW086A Ultrium 448 SAS External
* Assumes 2:1 data compression
52
HP StorageWorks
Ultrium Tape Blades
HP StorageWorks Ultrium
448c Tape Blade
HP StorageWorks Ultrium Tape Blades
deliver an internal tape backup solution
for HP BladeSystem c-Class customers
not connected to a SAN.
HP StorageWorks Ultrium
SB920c Tape Blade
Key features and benefits
• Integrated data protection solution: by integrating within
the BladeSystem c-Class enclosure, a complete server,
storage, and data protection solution is achieved
• Versatility: provides direct-attached data protection of adjacent server, as well as network backup of all
other data within the BladeSystem c-Class enclosure
• Investment protection: full read/write compatibility with Ultrium drives and media from HP and other
manufacturers
• Complete solution: includes HP Data Protector Express Single Server Edition backup and recovery software,
the HP Data Protector Express Bare Metal Disaster Recovery option and HP StorageWorks Library and
Tape Tools to help with installation, management, and troubleshooting
• Data rate matching: enables the drive to dynamically match the transfer rate to the speed
of the host for enhanced performance and reliability
Technical specifications
Ultrium 448c Tape Blade
SB920c Tape Blade
Capacity
Native
200 GB
Compressed* 400 GB
Native
400 GB
Compressed* 800 GB
Performance
Native
24 MB/s
Compressed* 48 MB/s
Burst Transfer
Rate
300 MB/s
Native
60 MB/s
Compressed* 120 MB/s
Burst Transfer
Rate
300 MB/s
Interface
3 Gb/s SAS
3 Gb/s SAS
Form factor
Half-height
BladeSystem c-Class
Half-height
BladeSystem c-Class
Reliability
> 250,000 at 100%
duty cycle
> 250,000 at 100%
duty cycle
Media
compatibility
LTO2, LTO1 Ultrium
(read/write)
LTO3, LTO2 Ultrium
(read/write)
LTO1 Ultrium (read-only)
Dimensions
(HxWxD in.)
2.19 x 7.15 x 20.1
2.19 x 7.15 x 20.1
Weight
11 lb
11 lb
Ordering information
440947-B21 HP StorageWorks
Ultrium 448c Tape Blade
AJ401A SB920c Tape Blade
* Assumes 2:1 data compression
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
53
HP StorageWorks
Ultrium 920 Tape Drive
Based on third-generation LTO technology, the
half-height Ultrium 920 provides enterprise
customers with a high density tape backup
solution at a midrange price.
Key features and benefits
• Maximum capacity: up to 800 GB* on a single cartridge
• High performance: transfer rate of 576 GB/hr*
• Write Once, Read Many (WORM): the Ultrium Generation 3
WORM data protection feature provides a simple and secure
method of archiving records as part of a compliance
solution, to meet the toughest of industry regulations
• Enterprise-class reliability: with active head cleaning, lower
power consumption, and intelligent tape handling
• Simplicity: HP OBDR and the Data Protector Express Bare
Metal Disaster Recovery option restore your entire system at
the touch of a button
• Investment protection: full read/write compatibility with LTO2
and LTO3 media as well as read support for LTO1 media
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option, and
HP StorageWorks Library and Tape Tools
• Data rate matching: enables the drive to dynamically match
the transfer rate to the speed of the host for enhanced
performance and reliability
HP StorageWorks Ultrium 920
Internal Tape Drive
HP StorageWorks Ultrium 920
External Tape Drive
Technical specifications
Capacity
Native
400 GB
Compressed* 800 GB
Performance
Native
60 MB/s
Compressed* 120 MB/s
Burst Transfer
Rate
320 MB/s
Interface
Wide Ultra320 SCSI
(LVDS)
3 Gb/s SAS
Reliability
> 250,000 at 100%
duty cycle
Media
compatibility
LTO3, LTO2 Ultrium
LTO3 Ultrium WORM
LTO1 Utlrium (read-only)
Dimensions
(HxWxD in.)
Internal: 1.6 x 5.7 x 8.1
External: 3.0 x 8.8 x 11.7
Weight
Internal: 3.2 lb
External: 10.3 lb
Ordering information
EH841A Ultrium 920 SCSI Internal
EH842A Ultrium 920 SCSI External
EH903A Ultrium 920 SCSI in a 1U Rack-mount
EH847A Ultrium 920 SAS Internal
EH848A Ultrium 920 SAS External
* Assumes 2:1 data compression
54
HP StorageWorks
Ultrium 960 Tape Drive
HP StorageWorks Ultrium 960
Internal Tape Drive
The HP StorageWorks Ultrium 960 Tape Drive
is a third-generation drive in the HP Ultrium
tape drive family, providing a fast-performing,
high-capacity backup solution and compatibility
with LTO1 and LTO2 media.
HP StorageWorks Ultrium 960
External Tape Drive
Key features and benefits
• Maximum capacity: up to 800 GB* on a single cartridge
• High performance: transfer rate of 576 GB/hr*
• Write Once, Read Many (WORM): the Ultrium Generation 3
WORM data protection feature provides a simple and secure
method of archiving records as part of a compliance
solution, to meet the toughest of industry regulations
• Enterprise-class reliability: with active head cleaning, lower
power consumption, and intelligent tape handling
• Simplicity: HP OBDR and the Data Protector Express Bare
Metal Disaster Recovery option restore your entire system at
the touch of a button
• Investment protection: full read/write compatibility with
Ultrium 1 and 2 drives and media from HP and other
manufacturers
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option, and
HP StorageWorks Library and Tape Tools
• Data rate matching: enables the drive to dynamically match
the transfer rate to the speed of the host for enhanced
performance and reliability
Technical specifications
Capacity
Native
400 GB
Compressed* 800 GB
Performance Native
80 MB/s
Compressed* 160 MB/s
Burst Transfer
Rate
320 MB/s
Interface
Wide Ultra320 SCSI (LVDS)
Reliability
> 250,000 at 100%
duty cycle
Media
LTO3, LTO2 Ultrium
compatibility LTO3 Ultrium WORM
LTO1 Ultrium (read-only)
Dimensions
(HxWxD in.)
Internal: 3.3 x 5.7 x 8.2
External: 4.7 x 8.6 x 11.7
Weight
Internal: 4.9 lb
External: 12.3 lb
Ordering information
Q1538A Ultrium 960 Internal
Q1539B Ultrium 960 External
Q1540A Ultrium 960 Array Module
Q1595A Ultrium 960 in a 3U Rack-mount
* Assumes 2:1 data compression
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
55
HP StorageWorks LTO4
Ultrium 1760 Tape Drive
HP StorageWorks LTO4 Ultrium 1760
Internal Tape Drive
The HP StorageWorks LTO4 Ultrium 1760 Tape
Drive delivers a compressed storage capacity of
1.6 TB and a compressed data transfer rate of
576 GB/hour while providing hardware data
encryption to deliver the ultimate data protection
for entry-level and midsized customers.
HP StorageWorks LTO4 Ultrium 1760
External Tape Drive
Key features and benefits
Technical specifications
• High capacity: stores up to 1.6 TB of data on a single data
cartridge using 2:1 compression. High-capacity drive reduces
the costs associated with data protection by requiring fewer
data cartridges to complete backups.
• Higher performance with dynamic data rate matching:
provides a compressed data transfer rate of 576 GB/hr,
allowing customers to scale their backup capacities without
having to increase their backup windows. HP’s exclusive
dynamic data rate matching feature can match the
throughput of the host and reduce starting and stopping
the tape drive.
• Half-height form factor for easy installation and integration:
allows for installation into all standard 5.25-inch media
bays.
• AES 256-bit hardware data encryption: provides easy-toenable security to protect the most sensitive data and prevent
unauthorized access of tape cartridges.
• Management and diagnostics software included: Tape
drive management, performance optimization, and
troubleshooting are made simple using the HP StorageWorks
Library and Tape Tools application that is included with the
HP Ultrium 1760 Tape Drive.
• WORM (Write-Once, Read-Many) media support: For IT
organizations with stringent, long-term data retention
requirements, LTO4 WORM provides a simple and secure
method for archiving records that allows customers to
affordably meet the toughest industry compliance
regulations.
Capacity
Native
800 GB
Compressed* 1.6 TB
Performance Native
80 MB/s
Compressed* 160 MB/s
Burst Transfer
Rate
300 MB/s
Interface
3 Gb/s SAS
Reliability
> 250,000 at 100%
duty cycle
Media
LTO4, LTO3 Ultrium
compatibility LTO4, LTO3 Ultrium WORM
LTO2 Ultrium (read-only)
Only LTO4 Ultrium media
can be encrypted.
Dimensions
(HxWxD in.)
Internal: 1.6 x 5.7 x 8.1
External: 3.0 x 8.8 x 11.7
Weight
Internal: 3.2 lb
External: 10.3 lb
Ordering information
EH919A Ultrium 1760 SAS Internal
EH920A Ultrium 1760 SAS External
EH946A Ultrium 1760 SAS in a 1U Rack-mount
* Assumes 2:1 data compression
56
HP StorageWorks LTO4
Ultrium 1840 Tape Drive
HP StorageWorks LTO4 Ultrium 1840
Internal Tape Drive
The HP StorageWorks LTO4 Ultrium 1840 Tape
Drive represents HP’s fourth-generation of LTO
tape drive technology, which is capable of
storing up to 1.6 TB per cartridge while
providing hardware-based data encryption
to enable greater levels of security and
unprecedented performance.
HP StorageWorks LTO4 Ultrium 1840
External Tape Drive
Key features and benefits
• Maximum capacity: up to 1.6 TB* on a single cartridge
• High performance: transfer rate of 864 GB/hr*
• AES 256-bit hardware data encryption: provides easy-toenable security to protect the most sensitive data and prevent
unauthorized access of tape cartridges.
• Write Once, Read Many (WORM): support for LTO4 WORM
media provides a simple and secure method of archiving
records as part of a compliance solution, to meet the
toughest of industry regulations
• Enterprise-class reliability: with active head cleaning, lower
power consumption, and intelligent tape handling
• Simplicity: HP OBDR and the Data Protector Express Bare
Metal Disaster Recovery option restore your entire system
at the touch of a button
• Investment protection: read/write compatibility with LTO3
media and read compatibility with LTO2 media
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option, and
HP StorageWorks Library and Tape Tools
• Data rate matching: enables the drive to dynamically match
the transfer rate to the speed of the host for enhanced
performance and reliability
Technical specifications
Capacity
Native
800 GB
Compressed* 1.6 TB
Performance
Native
120 MB/s
Compressed* 240 MB/s
Burst Transfer
Rate
240 MB/s
Interface
Wide Ultra320 SCSI
(LVDS) 3 Gb/s SAS
Reliability
> 250,000 at 100%
duty cycle
Media
compatibility
LTO3 Ultrium
LTO4, LTO3 Ultrium WORM
LTO4 UltriumB
LTO2 Ultrium (read-only)
Only LTO4 Ultrium media
can be encrypted.
Dimensions
(HxWxD in.)
Internal: 3.3 x 5.7 x 8.2
External: 4.7 x 8.6 x 11.7
Weight
Internal: 4.9 lb
External: 12.8 lb
Ordering information
EH853A Ultrium 1840 SCSI Internal
EH854A Ultrium 1840 SCSI External
EH856A Ultrium 1840 SCSI Array Module
EH926A Ultrium 1840 SCSI in a 3U Rack-mount
EH860A Ultrium 1840 SAS Internal
EH861A Ultrium 1840 SAS External
* Assumes 2:1 data compression
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
57
58
HP StorageWorks rack-mount
and tape-array solutions
Rack-mount and tape-array solutions are both designed to provide a modular enclosure
for direct-attached SCSI, USB, and SAS backup and archiving applications.
HP StorageWorks Rack-Mount Kits
HP rack-mount enclosures allow customers to expand and migrate between different capacity
points or drive technologies as required.
Rack-mount enclosures (one drive installed)
1U
HP StorageWorks USB Rack-Mount Kit with one
DAT 72 drive installed
AG594A
1U
HP StorageWorks USB Rack-Mount Kit with one
DAT 160 drive installed
AG703A
1U
HP StorageWorks Rack-Mount Kit with one
Ultrium 448 SCSI drive installed
DW028B
1U
HP StorageWorks Rack-Mount Kit with one
Ultrium 920 SCSI drive installed
EH903A
3U
HP StorageWorks Rack-Mount Kit with one
Ultrium 960 SCSI drive installed
Q1595B
1U
HP StorageWorks Rack-Mount Kit with one
Ultrium 1760 SAS drive installed
EH946A
3U
HP StorageWorks Rack-Mount Kit with one
Ultrium 1840 SCSI drive installed
EH926A
Rack-mount enclosures (no drive installed)
1U
HP StorageWorks Rack-Mount Kit:
holds 2 half-height SCSI drives
A7445B
1U
HP StorageWorks Rack-Mount Kit:
holds 2 half-height USB drives
A8007A
1U
HP StorageWorks Rack-Mount Kit:
holds 2 half-height Ultrium SAS drives
AE459A
3U
HP StorageWorks Rack-Mount Kit:
holds 4 half-height or 2 full-height SCSI drives
274338-B22
3U
HP StorageWorks Rack-Mount Kit:
holds 2 full-height or 4 half-height Ultrium SAS drives
AG576A
HP StorageWorks Tape Array 5300
HP StorageWorks Tape Array 5300
C7508B
HP StorageWorks Tape Array 5300—factory racked
C7508BZ
HP Tape Array 5300 Power Supply Fan Kit
C7496B
HP DVD+RW Array Field Module
Q1592B
This 3U rack enclosure holds two full-height, four half-height, or one full-height and two half-height
drive modules. The offline hot-swappable array allows you to replace drives without powering down
the server. An optional redundant power supply and fan module is also available.
Note: see tape drive section for information on drive variants
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
59
HP StorageWorks Tape
Autoloaders
This is where versatility and flexibility meet.
HP StorageWorks Tape Autoloaders provide you
with unattended backup that frees up your IT
resources and minimizes the risk of human error.
HP StorageWorks DAT 72x10 Tape Autoloader
This offers simple unattended DAT backup with 10 cartridge slots, allowing for one cartridge
each day plus a weekly cleaning cycle.
HP StorageWorks 1/8 G2 Tape Autoloader
Ultrium 1760
1/8 G2 Autoloader
400
Ultrium 920
1/8 G2 Autoloader
300
Departmental
Ultrium 448
1/8 G2 Autoloader
200
Remote office
DAT 72x10
Autoloader
> 1 TB
* Assumes 2:1 data compression
100
Ultrium 232
1/8 G2 Autoloader
50
3 TB
Backup capacity (compressed*)
60
600
5 TB
7 TB
< 12 TB
Backup performance GB/hr (compressed*)
This family is designed for basic data protection and provides cost-effective, easy-to-install
unattended backup.
HP StorageWorks
DAT 72x10 Tape Autoloader
The HP StorageWorks DAT 72x10 Tape
Autoloader is a low-cost, entry-level, automated
tape backup solution for small and mediumsized businesses or remote offices with limited
IT staff.
Key features and benefits
Technical specifications
• Reduced IT staff requirements: backups can be scheduled
to occur automatically at any time of day
Form factor
1U
Capacity
(native/
compressed*)
360 GB/720 GB
Number of
drives
supported
1
• Highly reliable: reduces manual administrative tasks and
the risk of error in the backup process
Number of
slots
10
• Industry standard: DAT offers a proven track record of
reliability and assured investment protection
Maximum
transfer rate
(compressed*)
21.6 GB/hr
Interface
Ultra160 SCSI LVD/SE
Dimensions
(HxWxD in.)
1.7 x 17.6 x 31.2
Weight
23.6 lb
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option, and
HP StorageWorks Library and Tape Tools
• Low media cost: uses the least-expensive tape media to help
lower the cost of ownership
• Easy disaster recovery: OBDR and the Data Protector Express
Bare Metal Disaster Recovery option can restore an entire
system at the touch of a button, without the need for system
disks or software CDs
• Backward compatible: reads and writes industry-standard
DDS-3, DDS-4, and DAT 72 media
• Broad compatibility: supports many different servers,
operating systems and backup software applications
• Management and diagnostics: tape drive management and
performance optimization is simple with HP StorageWorks
Library and Tape Tools software
• Space efficient: provides a 10-cartridge capacity in a
1U form factor
Ordering information
AE313B DAT 72x10 Tape Autoloader
* Assumes 2:1 data compression
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
61
HP StorageWorks
1/8 G2 Tape Autoloader
An ideal data backup solution for multiple
servers, the 1/8 G2 Tape Autoloader is
equipped with an Ultrium 1760 SAS,
Ultrium 920 SCSI or SAS, Ultrium 448 SCSI,
or Ultrium 232 SCSI tape drive.
Key features and benefits
• High capacity: up to 12.8 TB* of data with Ultrium 1760
• High performance: up to 160 MB/s* with Ultrium 1760
• Simplified IT: integrated Web-based remote management
interface to manage the autoloader from across the room or
across the world
Technical specifications
Form factor
1U
Capacity
(native/
compressed*)
6.4 TB/12.8 TB with
Ultrium 1760
3.2 TB/6.4 TB with
Ultrium 920
1.6 TB/3.2 TB with
Ultrium 448
800 GB/1.6 TB with
Ultrium 232
Number
of drives
supported
1
Number of
slots
8
Maximum
transfer rate
(compressed*)
576 GB/hr with
Ultrium 1760
432 GB/hr
with Ultrium 920
172.8 GB/hr with
Ultrium 448
115.2 GB/hr with
Ultrium 232
Interface
Ultra320 LVD/SE SCSI
with Ultrium 920
3 Gb/s SAS with Ultrium
1760/920
Ultra160 LVD/SE SCSI
with Ultrium 448/232
Dimensions
(HxWxD in.)
1.7 x 17.6 x 31.2
Weight
25.4 lb
• Manageability: integrated barcode reader to easily manage
your media
• Affordability: automates the backup process at a price
comparable to standalone drives
• Investment protection: migrate 1/8 G2 Tape Autoloader
drives into HP StorageWorks MSL2024, MSL4048, or
MSL8096 Tape Libraries as performance and capacity
needs change
• Compatibility: works with leading operating systems and
backup software
• Reliability: provides consistent backup and changes tapes
automatically, minimizing the risk of operator error
• Compact: holds eight cartridges and one drive in a
1U rack space
• Complete solution: includes HP Data Protector Express Single
Server Edition backup and recovery software, the Data
Protector Express Bare Metal Disaster Recovery option, and
HP StorageWorks Library and Tape Tools
Ordering information
AH163A 1/8 G2 Ultrium 232 Tape Autoloader
AH164A 1/8 G2 Ultrium 448 Tape Autoloader
AH165A 1/8 G2 Ultrium 920 Tape Autoloader
AH558A 1/8 G2 Ultrium 920 SAS Tape Autoloader
AK377A 1/8 G2 Ultrium 1760 SAS Tape Autoloader
Note: all models can be rack mounted with an
optional rack-mount kit
* Assumes 2:1 data compression
62
HP StorageWorks MSL
Tape Libraries
HP StorageWorks Tape Libraries are flexible,
scalable, manageable solutions for centralized
backup to a single automated device.
HP StorageWorks MSL Tape Libraries
HP StorageWorks Tape Libraries provide:
• Unattended backup that frees up your IT resources and minimizes the risk of user error
• Investment protection with both capacity and performance upgrades for environments with
unpredictable data growth
• Easy manageability with intelligent tools that streamline and simplify the backup process
• Compatible with industry-leading servers, operating systems, and backup software
MSL8096
Corporate/
networked
backup
100
80
MSL6060
MSL4048
60
40
MSL6030
Departmental
Number of slots
For more information, visit: www.hp.com/go/ebs
MSL2024
25
Remote office
10
35 TB
55 TB
75 TB
100 TB
165 TB
Total capacity
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
63
HP StorageWorks
MSL2024/4048/8096
Tape Libraries
These tape libraries provide flexible and
manageable solutions for centralized
backup to a single automated device,
freeing valuable IT resources for more
strategic work.
Key features and benefits
• Greater value: provides exceptional storage density
with up to 153.6 TB* of compressed capacity in the
8U form factor
• Manageability: integrated Web-based
management features reduce the dependency on
local IT resources, allowing multiple sites to be
supported centrally
• Investment protection: you can choose from a
broad range of LTO tape drives and increase
capacity and/or performance easily with tool-free
upgrades
• Simplifies IT: standard library features including a
barcode reader provide faster inventory times and
facilitate tracking of media
• MSL2024: the ideal entry-level tape library that
combines tape library capacity and features in the
compact form of a tape autoloader
• MSL4048: perfect for small to medium business,
unattended workgroups, or remote offices, and
backup and restore is easily managed from across
the room or across the globe with browser-based
remote management interface
Technical specifications
MSL2024
Form factor
2U
Capacity
(native/
compressed*)
19.2 TB/38.4 TB
with Ultrium 1840
19.2 TB/38.4 TB
with Ultrium 1760
9.6 TB/19.2 TB
with Ultrium 960/920
4.8 TB/9.6 TB with Ultrium 448
Max. number
of drives
One or two Ultrium
1760/920/448
One Ultrium 960/1840
Number of slots 24
Maximum
transfer rate
(max. drives)
(compressed*)
1.1 TB/hr with Ultrium 1760
864 GB/hr with Ultrium 1840
576 GB/hr with Ultrium 960
864 GB/hr with Ultrium 920
345.5 GB/hr with Ultrium 448
Interface
Ultra160 SCSI LVD/SE
with Ultrium 448
Ultra320 SCSI LVD/SE
with Ultrium 1840/960/920
4 Gb Native Fibre Channel
with Ultrium 1840/960
3 Gb/s SAS
with Ultrium 1760/920
Dimensions
(HxWxD in.)
3.4 x 18.9 x 31.7
Weight
32.9 lb
• MSL8096: meets a broad range of demanding
data storage needs, including unattended backup,
archive, and disaster recovery for medium to large
businesses, workgroups, or remote offices
* Assumes 2:1 data compression
64
Technical specifications
MSL4048
MSL8096
Form factor
4U
8U
Capacity
(native/
compressed*)
38.4 TB/76.8 TB
with Ultrium 1840/1760
19.2 TB/38.4 TB
with Ultrium 960/920
76.8 TB/153.6 TB with Ultrium 1840/1760
38.4 TB/76.8 TB with Ultrium 960/920
Max. number
of drives
One to four Ultrium 1760/920
One or two Ultrium 960/1840
Two to four Ultrium 960/920/1840/1760
Number of slots 48
96
Maximum
transfer rate
(max. drives)
(compressed*)
2.3 TB/hr with Ultrium 1760
1.7 TB/hr with Ultrium 1840
1.15 TB/hr with Ultrium 960
1.7 TB/hr with Ultrium 920
3.4 TB/hr with Ultrium 1840
2.3 TB/hr with Ultrium 960/1760
1.7 TB/hr with Ultrium 920
Interface
Ultra320 SCSI LVD/SE
with Ultrium 1840/960/920
4 Gb Native Fibre Channel
with Ultrium 1840/960
3 Gb/s SAS
with Ultrium 1760/920
4 Gb Native Fibre Channel with Ultrium 960
Ultra320 SCSI LVD/SE with Ultrium 1840/960
3 Gb/s SAS with Ultrium 1760/920
Dimensions
(HxWxD in.)
6.9 x 18.9 x 31.7
13.9 x 18.9 x 31.7
Weight
47.2 lb
102.7 lb
* Assumes 2:1 data compression
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
65
Ordering information for MSL2024/4048/8096
Ordering information MSL2024
Ordering information MSL8096
AG116A MSL2024 1 Ultrium 448 Drive Library
AH218A MSL8096 2 Ultrium 960 FC Drive Library
AG117A MSL2024 2 Ultrium 448 Drive Library
AH219A MSL8096 2 Ultrium 960 SCSI Drive Library
AG115A MSL2024 1 Ultrium 960 Drive Library
AH561A MSL8096 2 Ultrium 920 SAS Drive Library
AG326B MSL2024 1 Ultrium 960 FC Drive Library
AJ039A MSL8096 2 Ultrium 1840 Drive Library
AH169A MSL2024 1 Ultrium 920 Drive Library
AJ040A MSL8096 2 Ultrium 1840 FC Drive Library
AH170A MSL2024 2 Ultrium 920 Drive Library
AK382A MSL8096 2 Ultrium 1760 SAS Drive Library
AH559A MSL2024 1 Ultrium 920 SAS Drive Library
Upgrade drives for MSL2024/4048/8096
AJ033A MSL2024 1 Ultrium 1840 Drive Library
AJ034A MSL2024 1 Ultrium 1840 FC Drive Library
AK378A MSL2024 1 Ultrium 1760 SAS Drive Library
AK379A MSL2024 Zero Drive Library
AG118A MSL2024/4048 Ultrium 448 SCSI Drive
AH173A MSL2024/4048 Ultrium 920 SCSI Drive
AG327A MSL2024/4048/8096 Ultrium 960 SCSI Drive
AG328B MSL2024/4048/8096 Ultrium 960 FC Drive
Ordering information MSL4048
AH562A MSL2024/4048/8096 Ultrium 920 SAS Drive
AG322A MSL4048 1 Ultrium 960 Drive Library
AJ041A MSL2024/4048/8096 Ultrium 1840 SCSI Drive
AG323A MSL4048 2 Ultrium 960 Drive Library
AJ042A MSL2024/4048/8096 Ultrium 1840 FC Drive
AG324B MSL4048 1 Ultrium 960 FC Drive Library
AK383A MSL2024/4048/8096 Ultrium 1760 SAS Drive
AG325B MSL4048 2 Ultrium 960 FC Drive Library
AH171A MSL4048 1 Ultrium 920 Drive Library
AH172A MSL4048 2 Ultrium 920 Drive Library
AH560A MSL4048 1 Ultrium 920 SAS Drive Library
AJ035A MSL4048 1 Ultrium 1840 Drive Library
AJ037A MSL4048 2 Ultrium 1840 Drive Library
AJ036A MSL4048 1 Ultrium 1840 FC Drive Library
AJ038A MSL4048 2 Ultrium 1840 FC Drive Library
AK380A MSL4048 2 Ultrium 1760 SAS Drive Library
AK381A MSL4048 Zero Drive Library
66
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
67
HP StorageWorks
MSL6000 Tape Libraries
This product family provides a complete
backup and restore solution for midrange
and departmental environments, delivering
performance, investment protection, and
unparalleled flexibility.
Key features and benefits
• Scalability: multiunit stacking allows the libraries to grow
using any combination of contiguous 5U and 10U MSL6000
tape libraries, for up to 240 slots and 16 drives in a 40U
rack space that provides a maximum capacity of 384 TB*
• Flexibility: MSL tape libraries are available with either
Fibre Channel or SCSI interfaces for use in direct or networkattached environments
• Manageability: the user-friendly GUI control panel and
Web interface make library management easy from a
remote or onsite location
• Easy to use: the libraries offer one (MSL6030) or two
(MSL6060) configurable mail slots for quick load/unload
and removal of magazines
• High performance: MSL6000 tape libraries provide the
performance and capacity that are required to address
increasing data volumes and decreasing backup windows
• Reliability: using LTO Ultrium drives and proven library
robotics, MSL6000 tape libraries provide the necessary
high reliability for today’s demanding environments
• Compatibility: MSL6000 tape libraries are compatible with
a broad range of operating systems, ISV packages, and
hardware platforms to provide best-in-class interoperability
68
Ordering information
AD597B MSL6030 0 Drive Ultrium Library
AJ029A MSL6030 1 Ultrium 1840 Drive Library
AJ030A MSL6030 1 Ultrium 1840 Drive Fibre
Channel Library
AD606B MSL6030 1 Ultrium 960 Drive Library
AD607B MSL6030 2 Ultrium 960 Drive Library
AD608B MSL6030 1 Ultrium 960 Drive Fibre
Channel Library
AD609B MSL6030 2 Ultrium 960 Drive Fibre
Channel Library
AD602B MSL6060 0 Drive Ultrium Library
AJ031A MSL6060 2 Ultrium 1840 Drive Library
AJ032A MSl6060 2 Ultrium 1840 Drive Fibre
Channel Library
AD610B MSL6060 2 Ultrium 960 Drive Library
AD611B MSL6060 2 Ultrium 960 Drive Fibre
Channel Library
Upgrade drives for MSL6000
Ultrium Tape Libraries
AJ028A MSL6000 Ultrium 1840 Drive
AD612B MSL6000 Ultrium 960 Drive
Technical specifications
MSL6030
MSL6060
Form factor
5U
10U
Capacity
(native/
compressed*)
24 TB/48 TB with Ultrium 1840
12 TB/24 TB with Ultrium 960
48 TB/96 TB with Ultrium 1840
24 TB/48 TB with Ultrium 960
Max. number
of drives
2
4
Number of slots
30
60
Maximum
transfer rate
(max. drives)
(native/
compressed*)
864 GB/hr/1.7 TB/hr with
Ultrium 1840
576 GB/hr/1.15 TB/hr with
Ultrium 960
1.7 TB/hr/3.4 TB/hr with Ultrium 1840
1.15 TB/hr/2.3 TB/hr with Ultrium 960
Interface
Ultra320 LVD SCSI
4 Gb Fibre Channel
Ultra320 LVD SCSI
4 Gb Fibre Channel
Dimensions
(HxWxD in.)
8.8 x 17.0 x 30.0
17.5 x 17.0 x 30.0
Weight
43.0 to 52.2 lb
95.0 to 104.2 lb
* Assumes 2:1 data compression
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
69
HP storage media
You need to know that your media gives you
the best recovery in the industry. HP understands
that there are no second chances when it comes
to data recovery—the smallest imperfection
could ultimately put someone out of business.
All HP media is tested and certified for all
StorageWorks drives and automation solutions.
Why choose HP storage media?
• More businesses store their data on HP-branded LTO, SuperDLT, DLT, and DDS
cartridges than on any other media brand.
• No other brand of storage media is tested so extensively for optimum quality,
reliability, and performance on HP drives and libraries.
• HP guarantees the highest level of restore reliability with media specifications that
far exceed industry standards. In tests, HP media delivered three times the number
of successful backup and restores compared to another leading brand.
• HP storage media is guaranteed to be compatible with certified drives and libraries
from all other manufacturers. For additional information on storage media, visit:
www.hp.com/go/storagemedia
70
Drive type
Cartridge capacity
(compressed)
Data cartridge
Cleaning
cartridge
DAT 24
24 GB
C5708A
C5709A
DAT 40
40 GB
C5718A
C5709A
DAT 72
72 GB
C8010A
C5709A
Ultrium 230, 232
200 GB
C7971A
C7978A
Ultrium 448, 460
400 GB
C7972A
C7978A
Ultrium 960,
960 WORM
800 GB
C7973A
C7978A
Ultrium 1840
1.6 TB
C7974A
C7978A
SDLT 320
320 GB
C7980A
C7982A
SDLT 600
600 GB
Q2020A
C7982A
HP labeled media for automation
• For automation customers, HP sells Custom Labeled and Non-Custom Labeled data
cartridges: high-quality HP-branded storage media with a TriOptic bar code label.
• Choose Custom Labeled media when you need to specify the exact sequence of
bar codes for your backup system.
• Choose Non-Custom Labeled media when you need fast delivery “off the shelf.”
Bar codes are never duplicated but sequences are randomized.
Drive type
Custom
Labeled
Non-Custom
Labeled
LTO1
C7971AL
C7971AN
LTO2
C7972AL
C7972AN
LTO3 RW
C7973AL
C7973AN
LTO3 WORM
C7973WL
N/A
LTO4 RW
C7974AL
C7974AN
LTO4 WORM
C7974WL
N/A
SDLT I
C7980AL
N/A
SDLT II
Q2020AL
N/A
HP Storage Media Kits
• HP Storage Media Kits provide a complete solution for HP LTO and DAT users at
a price that is about 5 percent less expensive than the cost of purchasing all of
the components separately.*
• Each kit contains 14 DAT or 20 LTO data cartridges, a DAT or LTO cleaning
cartridge, as well as a complete set of tools to make backup part of your
everyday business routine:
Drive type
Storage
Media Kit
LTO1
C8013A
LTO2
C8014A
LTO3 RW
C8017A
DAT 72
C8012A
* Based on product list price
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
71
HP StorageWorks
tape storage compatibility
HP’s extensive compatibility testing program
helps ensure that HP StorageWorks tape
drives and tape automation products work
with leading servers, operating systems, and
backup applications—and not just those
sold by HP.
Our tape solutions work seamlessly in many environments, making them especially
suitable if you have a mixed-system environment. For the latest list of servers, workstations,
operating systems, and backup software that support HP StorageWorks tape drives,
check the tape backup compatibility pages at: www.hp.com/go/connect or
www.hp.com/go/ebs
For tape media compatibility, visit: www.hptapecompat.com
Compatibility with HP servers
• HP ProLiant
• HP Integrity
• HP 9000
• HP AlphaServers
• HP Workstations
Compatibility with non-HP servers
• Dell
• IBM
• Sun
• Other third-party chip-sets—Adaptec, LSI
Note:
HP does not support One-Button Disaster Recovery on non-HP systems. HP does not support
SDLT or DLT VS technology on non-HP systems.
Compatible operating systems and software
Operating systems include Microsoft Windows Server, Windows 2000, and Windows XP;
HP-UX; Novell Netware; Red Hat Linux; Sun Solaris; IBM AIX; Tru64 UNIX®; OpenVMS;
and SCO.
Backup software applications include HP Data Protector and Data Protector Express
software, CA BrightStor ARCserv, Symantec Backup Exec, Veritas NetBackup, Yosemite
TapeWare, Legato NetWorker, Dantz Retrospect, IBM Tivoli, Ultrabak, and Columbia.
72
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
73
HP StorageWorks tape backup solutions connectivity chart
74
Ultrium
External tape drives
DAT
Ultrium
Model
P/N
DL145 G31
DL160 G51
DL180 G51
DL185 G51
DL320 G51
DL320 G5p1
DL320s1
DL360 G51
DL3651
DL380 G51
DL385 G21
Internal tape drives
DAT
Category
DL140 G31
ProLiant servers
DAT 40 USB
DW022A
R
R
R
R
R
R
R
R
R
R
R
R
DAT 40 SCSI
C5686C
R
R
R
R
R
R
R
R
R
R
R
R
DAT 72 USB
DW026A
R
R
R
R
R
R
R
R
R
R
R
R
DAT 72 SCSI
Q1522B
R
R
R
R
R
R
R
R
R
R
R
R
DAT 160 USB
Q1580A
R
R
R
R
R
R
R
R
R
R
R
R
DAT 160 SCSI
Q1573A
R
R
R
R
R
R
R
R
R
R
R
3
3
3
3
3
3
3
3
3
3
R
3
R3
DAT 160 SAS
Q1587A
R
LTO1 Ultrium 232 SCSI
DW064A
R
R
R
R
R
R
R
R
R
R
R
LTO2 Ultrium 448 SCSI
DW016A
R
R
R
R
R
R
R
R
R
R
R
LTO2 Ultrium 448 SAS
DW085A
R
Ultrium 448c Tape Blade
440947-B21
SB920c Tape Blade
AJ401A
LTO3 Ultrium 920 SCSI
EH841A
R
R
R
R
R
R
R
R
R
R
R
R
LTO3 Ultrium 920 SAS
EH847A
R3
R3
R3
R3
R3
R3
R3
R3
R3
R3
R3
R3
LTO3 Ultrium 960 SCSI
Q1538A
R
R
R
R
R
R
R
R
R
R
R
R
LTO4 Ultrium 1760 SAS
EH919A
R3
R3
R3
R3
R3
R3
R3
R3
R3
R3
R3
R3
LTO4 Ultrium 1840 SCSI
EH853A
R
R
R
R
R
R
R
R
R
R
R
R
LTO4 Ultrium 1840 SAS
EH860A
R
DAT 40 USB
DW023A
•
•
•
•
•
•
•
•
•
•
•
•
DAT 40 SCSI
C5687D
•
•
•
•
•
•
•
•
•
•
•
•
DAT 72 USB
DW027A
•
•
•
•
•
•
•
•
•
•
•
•
DAT 72 SCSI
Q1523B
•
•
•
•
•
•
•
•
•
•
•
•
DAT 160 USB
Q1581A
•
•
•
•
•
•
•
•
•
•
•
•
DAT 160 SCSI
Q1574A
•
•
•
•
•
•
•
•
•
•
•
•
DAT 160 SAS
Q1588A
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
LTO1 Ultrium 232 SCSI
DW065B
•
•
•
•
•
•
•
•
•
•
•
•
LTO2 Ultrium 448 SCSI
DW017B
•
•
•
•
•
•
•
•
•
•
•
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
R
R
R
R
R
3
3
R3
R3
•
3
•3
LTO2 Ultrium 448 SAS
DW086A
•
LTO3 Ultrium 920 SCSI
EH842A
•
•
•
•
•
•
•
•
•
•
•
•
LTO3 Ultrium 920 SAS
EH848A
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
LTO3 Ultrium 960 SCSI
Q1539B
•
•
•
•
•
•
•
•
•
•
•
•
LTO4 Ultrium 1760 SAS
EH920A
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
LTO4 Ultrium 1840 SCSI
EH854A
•
•
•
•
•
•
•
•
•
•
•
•
LTO4 Ultrium 1840 SAS
EH861A
•
3
•
•
3
•
•
3
•
•
3
•
•
3
•
•
3
•
•
3
•
•
3
•
•
3
•
•
3
•
•
3
•3
DL580 G41
DL580 G51
DL585 G21
ML110 G42
ML110 G52
ML1152
ML150 G32
ML150 G51
ML310 G42
ML310 G52
ML350 G52
ML370 G52
ML570 G42
ProLiant servers (continued)
R
•
R
•
•
•
•
•
•
•
•
•
•
R
•
R
•
•
•
•
•
•
•
•
•
•
R
•
R
•
•
•
•
•
•
•
•
•
•
R
•
R
•
•
•
•
•
•
•
•
•
•
R
•
R
•
•
•
•
•
•
•
•
•
•
R
•
R
•
•
•
•
•
•
•
•
•
•
R
3
•
3
R
3
•
3
•
3
3
3
•
•
•
3
3
3
•
•
•
3
3
•
•3
R
•
R
•
•
•
•
•
•
•
•
•
•
R
•
R
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•3
R
3
•
3
R
3
•
3
•
3
3
3
3
3
3
3
3
R
•
R
•
•
•
•
•
•
•
•
•
•
R3
•3
R3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
R
R
R
R
R
R
•
•
R
R
•
•
R
R3
R3
R3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
R
R
R
R
R
R
•
•
R
R
•
•
R
•
•
•
•3
R
3
R
3
R
3
R
3
R
3
R
3
3
3
•
•
•
3
3
3
3
•
•
•
•
•
•
•
•
•
•
•
•
•
• Supported; for internal drives (includes
rack-mount)
•
•
•
•
•
•
•
•
•
•
•
•
•
R Rack-mount only supported
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•
•
•
•
•
•
•
•
•
•
•
•
•
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•
•
•
•
•
•
•
•
•
•
•
•
•
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•
•
•
•
•
•
•
•
•
•
•
•
•
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
•3
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Recommended solutions for this server
Not supported/not applicable
1
HP SC11Xe SCSI Controller (412911-B21) is
required for SCSI tape drives attaching to this
server.
2
HP Single Channel U320 SCSI Controller
(374654-B21) is recommended for SCSI tape
drives attaching to this server.
3
HP SC44Ge Host Bus Adaptor (416096-B21)
is recommended to attach SAS tape drives to
this server.
To reference the latest
connectivity data, go to:
www.hp.com/go/connect
Jargon buster
HP Care Pack
Services
75
HP StorageWorks tape backup solutions connectivity chart
76
Ultrium
External tape drives
DAT
Ultrium
Model
P/N
DL320 SS1
DL585 G2 SS1
DL380 G5 SS1
ML110 G5 SS2
ML350 G5 SS2
Internal tape drives
DAT
Category
DL160 G5 SS1
ProLiant storage servers
DAT 40 USB
DW022A
R
R
R
R
•
•
DAT 40 SCSI
C5686C
R
R
R
R
•
•
DAT 72 USB
DW026A
R
R
R
R
•
•
DAT 72 SCSI
Q1522B
R
R
R
R
•
•
DAT 160 USB
Q1580A
R
R
R
R
•
•
DAT 160 SCSI
Q1573A
R
R
R
R
•
3
3
3
3
•
3
•3
DAT 160 SAS
Q1587A
R
LTO1 Ultrium 232 SCSI
DW064A
R
R
R
R
•
LTO2 Ultrium 448 SCSI
DW016A
R
R
R
R
•
LTO2 Ultrium 448 SAS
DW085A
R
Ultrium 448c Tape Blade
440947-B21
SB920c Tape Blade
AJ401A
LTO3 Ultrium 920 SCSI
EH841A
R
R
R
R
•
•
LTO3 Ultrium 920 SAS
EH847A
R3
R3
R3
R3
•3
•3
LTO3 Ultrium 960 SCSI
Q1538A
R
R
R
R
R
•
LTO4 Ultrium 1760 SAS
EH919A
R3
R3
R3
R3
•3
•3
LTO4 Ultrium 1840 SCSI
EH853A
R
R
R
R
R
•
LTO4 Ultrium 1840 SAS
EH860A
R
DAT 40 USB
DW023A
•
•
•
•
•
•
DAT 40 SCSI
C5687D
•
•
•
•
•
•
DAT 72 USB
DW027A
•
•
•
•
•
•
DAT 72 SCSI
Q1523B
•
•
•
•
•
•
DAT 160 USB
Q1581A
•
•
•
•
•
•
DAT 160 SCSI
Q1574A
•
•
•
•
•
•
DAT 160 SAS
Q1588A
•3
•3
•3
•3
•3
•3
LTO1 Ultrium 232 SCSI
DW065B
•
•
•
•
•
•
LTO2 Ultrium 448 SCSI
DW017B
•
•
•
•
•
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
R
R
R
3
3
3
•
•
R
•
•
3
3
•3
•3
•
3
•3
LTO2 Ultrium 448 SAS
DW086A
•
LTO3 Ultrium 920 SCSI
EH842A
•
•
•
•
•
•
LTO3 Ultrium 920 SAS
EH848A
•3
•3
•3
•3
•3
•3
LTO3 Ultrium 960 SCSI
Q1539B
•
•
•
•
•
•
LTO4 Ultrium 1760 SAS
EH920A
•3
•3
•3
•3
•3
•3
LTO4 Ultrium 1840 SCSI
EH854A
•
•
•
•
•
•
LTO4 Ultrium 1840 SAS
EH861A
•
3
•
•
3
•
•
3
•
•
3
•
•
3
•3
•
R
R
•
R
•
R
•
R
•
R
•
R
•
R
•
R
•
3
R
3
•
R
•
R
•
R
•
R
•
•
R
R
R
R
3
•
R
•
•
•3
•3
R
R
•
R
•3
R3
•3
R3
R
R
•
R
•
3
•4
•
•
•
•
•4
•4
•4
•
•
•
• Supported; for internal drives (includes
rack-mount)
•
•
•
•
R Rack-mount only supported
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•3
•3
•3
•3
•
•
•
•
•
•
•
•
•
•
•3
•3
•3
•3
•
•
•
•
•3
•3
•3
•3
•
•4
•
•
•
•4
R3
•
•
•
R3
R3
R
•
R
3
R
3
•
R
•
3
•
3
•3
R
•
3
3
BL685c4
R
•
BL680c4
•
BL480c4
R
BL465c
•
BL460c
AiO12002
R
c7000 enclosure
AiO6002
•
c3000 enclosure
AiO400r2
•
c-Class blades
AiO400t2
AiO4002
AiO
•
•
•
•
•3
•3
•3
•3
•
•
•
•
•3
•3
•3
•3
Simply
Consolidation
Simply File
Services
Recommended solutions for this server
Not supported/not applicable
1
HP SC11Xe SCSI Controller (412911-B21) is
required for SCSI tape drives attaching to this
server.
2
HP Single Channel U320 SCSI Controller
(374654-B21) is recommended for SCSI tape
drives attaching to this server.
3
HP SC44Ge Host Bus Adaptor (416096-B21)
is recommended to attach SAS tape drives to
this server.
4
HP PCI Express Mezzanine Pass-Thru Card
for HP BladeSystem c-Class (431643-B21)
is required when installing a tape blade
adjacent to a full-height server blade.
To reference the latest
connectivity data, go to:
www.hp.com/go/connect
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
77
HP disk-based backup
solutions
HP disk-based backup solutions provide easy
integration of disk into your existing backup
environment. The new HP StorageWorks D2D
Backup System, Virtual Library Systems, and
Data Protection Storage Servers dramatically
improve backup and recovery performance
of LAN and SAN servers.
The HP Virtual Library System 1000i is a disk-based backup solution that appears like
a normal tape-based solution to the user. It emulates physical tape drives or autoloaders,
making it ideal for most existing storage environments.
The HP StorageWorks D2D Backup Systems provide reliable, consolidated data protection
for up to six servers in a single, self-managing device. They are designed to work with
your existing backup software application to fully automate daily backup jobs, requiring
less manual handling than tape-based systems.
To learn more about disk-based backup, go to: www.hp.com/go/disktodisk
3 TB
2.5 TB
High-end
consolidation
D2D120 Backup System
2 TB
VLS1000i
Midrange
consolidation
1.5 TB
D2D Backup System
1 TB
Entry-level
consolidation
50
Speed GB/hr
78
100
180
216
.5 TB
Capacity
D2D130 Backup System
HP StorageWorks 1000i
Virtual Library System
The HP StorageWorks 1000i Virtual Library
System is a disk-based, iSCSI-connected
storage solution that provides unattended
backup and improved restore performance
for midmarket, remote, or branch-office
customers.
Key features and benefits
Technical specifications
• Unattended backup: Automated backup of application and
file data provides a more simple and reliable data protection
strategy.
• Improved efficiency and performance: By emulating multiple
tape devices, it can back up multiple servers simultaneously.
Plus, disk-based storage simplifies and accelerates data
restores from hours to minutes.
• iSCSI connectivity: Provides easy integration into existing
Ethernet networks, which allows multiple servers to be
configured with their own SCSI-connected virtual tape device.
• Seamless integration: Emulates both tape drives and tape
autoloaders for easy and seamless integration to tape-based
environments.
• Streamlined media management: Disk-based storage
minimizes the problems and costs associated with tape
media management.
• Easy deployment and management: Preconfigured for virtual
tape applications and easily auto-discovered on the LAN
during setup. Web-based management enables remote
access to configuration and diagnostics.
• High reliability: These systems provide high reliability, thanks
to HP ProLiant server technology, RAID 5 data protection
and hot-pluggable drive technology.
• Secure as tape: As is the case with a tape device, there
is no external file system or server operating system access
to protect.
• Ready-to-use: Comes with a free copy of HP Data Protector
Express Single Server Edition. Upgrades are available for
larger configurations.
Form factor
1U
Capacity
1.5 TB/up to 3 TB
(native/
compressed*)
Max. number Up to 12 HP Ultrium LTO2
tape drives (6 can be
of virtual
configured as HP 1/8
drives
autoloaders)
Disk drive
interface
Serial ATA (SATA)
Disk drive
capacity/
type
500 GB, SATA 7,200 rpm
Number of
disk drives
4
Storage
controller
RAID 5
Interface
1 Gb Ethernet iSCSI
Performance
Up to 60 MB/s
Dimensions 1.7 x 17.0 x 26.5
(HxWxD in.)
Weight
25.6 lb
Ordering information
AG124A VLS1002i Virtual Library System
* Assumes 2:1 data compression
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
79
HP StorageWorks D2D
Backup System
The HP StorageWorks D2D Backup System is
an easy-to-install, easy-to-use disk-based backup
for small and medium businesses that automates
daily backup for up to six servers and lets you
restore users’ files in seconds instead of hours.
The HP StorageWorks D2D Backup System works with your existing backup software application to provide
automated backup for multiple servers at less than the cost of a single LTO tape autoloader. Consolidating
your backups onto a self-managing, disk-based device reduces the risk of losing data. There are fewer
devices to manage, and the intuitive, browser-based management interface also lets you monitor your backup
device from anywhere at any time. The system can help to improve backup performance by supporting the
direct backup of up to six servers simultaneously.
This simple solution fits right into your existing Windows or Linux environment, working with your current
hardware and software in most cases. Existing tape drives and backup software may be used with the
HP D2D Backup System. Alternatively, the system comes with an optional integrated LTO tape drive or with
a Data Protector Express Software Kit that includes all of the components needed to protect up to four servers
and automatically move or copy backups from the D2D Backup System to tape.
Key features and benefits
• Simplicity: Automating backup simplifies your data protection processes. Implementing unattended daily
backup is especially good for businesses with limited IT resources.
• Reliability: Automation makes your data protection processes more dependable by reducing the risks of
human error and problems associated with tape hardware and media—the two biggest causes of failed
backups.
• Affordability: Scheduling daily backups to the HP D2D Backup System provides automated backup for
up to six servers at less than the cost of a single LTO autoloader.
• Fast restore: Disk-based data protection provides online access to your backup data, allowing lost or
corrupted files to be restored in minutes instead of hours or days.
• Fast backup: Backing up six servers simultaneously to a disk instead of one after the other to a tape
drive or autoloader means that all backups get completed within your backup window.
• Manageability: A browser-based application lets you monitor your backup device from anywhere, locally
or remotely, enabling you to check on available capacity, view and change device setup, add or change email alerts, or copy backups to tape.
80
Technical specifications
HP StorageWorks HP StorageWorks
D2D110 Backup
D2D120 Backup
System
System
HP StorageWorks
D2D130 Backup
System
Processor
Intel Celeron® D
processor
Intel Celeron D
processor
Intel Celeron D
processor
Capacity
(useable/
raw)
750 GB/1 TB
1.5 TB/2 TB
2.25 TB/3 TB
Disk drive
capacity/
type
250 GB, SATA
7,200 rpm
500 GB, SATA
7,200 rpm
750 GB, SATA
7,200 rpm
Number of
disk drives
4
4
4
Storage
controller
Software RAID 5
Software RAID 5
Software RAID 5
Interface
One 1 Gb iSCSI
(Ethernet)
One 1 Gb iSCSI
(Ethernet)
One 1 Gb iSCSI
(Ethernet)
Performance
Up to 50 MB/s
Up to 50 MB/s
Up to 50 MB/s
Form factor
Tower
Tower
Tower
Dimensions
14.6 x 6.9 x 17.3
(HxWxD in.)
14.6 x 6.9 x 17.3
14.6 x 6.9 x 17.3
Weight
26.5 lb
26.5 lb
26.5 lb
Ordering information
EH880A D2D110 Backup System 1 TB
EH884A D2D120 Backup System 2 TB
EH950A D2D130 Backup System 3 TB
EH923A D2D110 Backup System 1 TB
with Data Protector Express Software Kit
EH924A D2D120 Backup System 2 TB
with Data Protector Express Software Kit
EH951A D2D130 Backup System 3 TB
with Data Protector Express Software Kit
EH881A D2D110 Backup System 1 TB
with Ultrium 448 Tape Drive
EH885A D2D120 Backup System
with Ultrium 920 Tape Drive
EH952A D2D130 Backup System with
Ultrium 920 Tape Drive
For current D2D110 and D2D120 users, a free firmware upgrade is now available that will enable you to update your system to the specifications stated
above. Please use the firmware upgrade feature in the HP D2D Backup System device management interface to complete this upgrade.
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
81
HP software for data
protection
HP software provides customized solutions
that protect your customers’ infrastructures
and data.
With HP software and disaster-tolerant solutions, there is no problem if the weather, system
glitches, or human error threaten to disrupt business.
The normal flow of business continues and your data is safe. HP customizes the solution to
your data availability, replication, automation, and management requirements.
Data protection software
Enterprise
HP Data Protector
software
HP StorageWorks
Storage Mirroring
Departmental
Remote office
Workstations
82
Business continuity software
HP Data Protector
Express software
HP Data Protector Express
software
Designed to be easy to install, easy to use, and
easy to manage for nonspecialist staff, this is the
ideal software for a single machine or a small
network that needs robust data protection. HP Data
Protector Express offers the flexibility to back up
data to tape, disk, CD, or a hierarchy of these
media. It provides advanced features without
compromising its ease of use.
Key features and benefits
• Easy to install, configure, and manage without specialist staff
• Support for backup to disk, tape, and CD/DVD from Windows, Linux, and NetWare
operating systems
• Includes secure backup data encryption to all supported media as well as support
for HP LTO4 tape drive-based data encryption
• Can be extended easily with optional features when required
• Simple licensing structure: no complexities such as capacity-based licensing, perprocessor licensing, or different licenses for different operating systems
• Special package for users of Microsoft Small Business Server operating systems
Note: HP Data Protector Express Single Server Edition (and the Data Protector Express
Bare Metal Disaster Recovery option) is included with all HP StorageWorks tape drives
and autoloaders. It is based on Data Protector Express and includes many of its features to
provide robust protection of a single machine. Data Protector Express Single Server Edition
can be upgraded easily to Data Protector Express by ordering a special part number that
provides a significant discount to the regular price of Data Protector Express.
Ordering information
Base product
BB117EA HP Data Protector Express Backup Server
BB118EA HP Data Protector Express for Microsoft Small Business Server
Upgrade products (to get the Data Protector Express base product at a
reduced price)
BB117ET Upgrade from HP Data Protector Express Single Server Edition
Options
For Data Protector Express options, see:
www.hp.com/go/dataprotectorexpress/options
To try Data Protector Express for 60 days or for more information about the product,
visit: www.hp.com/go/dataprotectorexpress
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
83
HP Data Protector software
Scalable from single server to heterogeneous
enterprise, this data management software
automates high-performance backup and recovery
from both disks and tapes—delivering maximum
data protection while providing 24x7 business
operations.
Key features and benefits
• Robust and proven enterprise backup solution used by more than 22,000 customers.
• Low cost of ownership responds to the pressure to reduce IT costs and achieve greater
operational efficiency. A simple and flexible license model includes the first year of
support.
• Easy-to-deploy installation is made simple with the capability for fully automated
distribution of agent software to all connected clients and a centralized licensing facility
that reduces complexity.
• Outstanding integration for HP environments that supports a broad range of
heterogeneous environments.
• Respond to the need for 24x7 application availability by integrating techniques to
eliminate backup windows. These include Online Backup, Open File Backup, and
Zero Downtime Backup (local and remote replication).
• Utilizing Instant Recovery, Data Protector software meets the demands of the most
complex enterprise businesses for specific recovery time and recovery point objectives,
as well as enables terabytes of critical data to be recovered within minutes.
• Unique, industry-first virtual full backup reduces the time and resources needed to
perform a full backup. By using “pointers” rather than duplicating data, HP Data
Protector software improves tape utilization and provides heterogeneous data protection.
To try Data Protector software for 60 days or for more information about the product, visit
the Data Protector Web site at: www.hp.com/go/dataprotector
Ordering information on Starter Packs
B6951AA HP Data Protector Starter Pack
(license and DVD) for HP-UX
B6951BA HP Data Protector Starter Pack
(license only) for HP-UX
B6951DA HP Data Protector Starter Pack
(license and DVD) for Sun Solaris
B6951CA HP Data Protector Starter Pack
(license only) for Sun Solaris
B6961AA HP Data Protector Starter Pack
(license and DVD) for Windows
B6961BA HP Data Protector Starter Pack
(license only) for Windows
B6961DA HP Data Protector Starter Pack
(license and DVD) for Linux
B6961CA HP Data Protector Starter Pack
(license only) for Linux
For complete ordering information, see the
quickspecs: www.hp.com/go/dataprotector
84
HP StorageWorks Storage
Mirroring
HP StorageWorks Storage Mirroring software
is a host-based Windows application that
performs continuous data replication and
enables server failover over a customer’s
existing IP LAN or WAN.
Key features and benefits
Ordering information
Business protection:
• Storage Mirroring protects business data, enabling
restoration of data and the ability to failover servers within
minutes to maintain a seamless working environment
• Provides extremely high levels of protection through stable
performance, reduced latency and the ability to handle
heavy amounts of data
T5438A HP StorageWorks Storage Mirroring
Server Edition 1 LTU
T5439A HP StorageWorks Storage Mirroring
Server Edition 10 LTU
T5440A HP StorageWorks Storage Mirroring
Enterprise Server Ed 1 LTU
T5441A HP StorageWorks Storage Mirroring
Enterprise Server Ed 10 LTU
T5442A HP StorageWorks Storage Mirroring
NAS Edition 1 LTU
• No distance limitations
• Real-time or scheduled replication
Cost effective:
• Provides the best continuous protection at the lowest cost
• Simple licensing model—licensed per server, according to
the Microsoft operating system the server is running on, with
no need to buy additional modules for different applications
• By replicating only the bytes that change, Storage Mirroring
utilizes the absolute minimum bandwidth required to protect
your data
Ease of use and installation:
• Allows companies even with limited IT expertise to install and
maintain the solution, helping to ensure a high level of data
protection and business continuity
T5443A HP StorageWorks Storage Mirroring
NAS Edition 10 LTU
T5444A HP StorageWorks Storage Mirroring
for 5 Virtual Machines 1 LTU
T5445A HP StorageWorks Storage Mirroring
Itanium Server Edition 1 LTU
T5446A HP StorageWorks Storage Mirroring
AiO Storage System Edition 1 LTU
T5447A HP StorageWorks Storage Mirroring
Server Recovery Option 1 LTU
T5448A HP StorageWorks Storage Mirroring
Linux Edition 1 LTU
T5449A HP StorageWorks Storage Mirroring
Linux Edition 10 LTU
T5450A HP StorageWorks Storage Mirroring
for VMware Virtual Infrastructure 1 LTU
• Simple-to-use management console with flexible GUI, central
view of all HP StorageWorks Storage Mirroring servers and
the ability to view as many or as few servers as desired
• Works on any type of storage design—DAS, NAS, and
SAN, as well as on any Windows server platform that runs
Windows—ProLiant, Integrity, or third-party servers
• When disaster strikes, Storage Mirroring can immediately
reassign the source server identity to a target server
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
85
HP StorageWorks CD
HP Data Protector Express SSE
HP StorageWorks L & TT Utilities
Screws
Accessories
Installation poster
Drive & rack enclosure
OD1 option available
External drive
Hot-swap array module
Drive type
Internal drive
What’s
in the
box
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
D*
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
D*
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
D*
• • •
• • •
D*
•
•
•
•
•
•
D*
DAT 40
DAT 40 Internal
C5686C
DAT 40 External
C5687D
DAT 40 USB Internal
DW022A
DAT 40 USB External
DW023A
DAT 40 Array Module
C7497C
•
•
•
•
•
•
•
•
D*
D*
•
D*
D*
DAT 72
•
DAT 72 Internal
Q1522B
DAT 72 External
Q1523B
DAT 72 USB Internal
DW026A
DAT 72 USB External
DW027A
DAT 72 Array Module
Q1524C
DAT 72 1U Rack-mount
A7443A
•
DAT 160 SCSI Internal
Q1573A
•
DAT 160 SCSI External
Q1574A
DAT 160 USB Internal
Q1580A
DAT 160 USB External
Q1581A
DAT 160 SCSI Array Module
Q1575A
•
•
•
•
•
•
•
• •
•
D*
D*
•
D*
D*
D*
DAT 160
DAT 160 USB 1U Rack Enclosure AG703A
DAT 160 SAS Internal
Q1587A
DAT 160 SAS External
Q1588A
•
•
•
•
•
•
•
•
•
• •
•
•
•
D*
D*
•
D*
D*
D*
D*
•
D*
Ultrium 232
Ultrium 232 Internal
DW064A
Ultrium 232 External
DW065B
•
•
•
•
D*
Ultrium 448
Ultrium 448 Internal
DW016A
Ultrium 448 External
DW017B
Ultrium 448 Internal SAS
DW085A
Ultrium 448 External SAS
DW086A
Ultrium 448 m Drive
DW019A
Ultrium 448 in 1U Rack (1drive)
DW028B
* D = Available as free download
86
•
•
•
•
•
•
•
•
•
• •
•
•
•
•
•
•
•
•
•
•
•
•
•
D*
D*
D*
D*
D*
•
•
• •
•
•
•
Simply
Consolidation
Simply File
Services
• •
• •
•
•
• • •
•
•
•
•
•
•
• • •
•
•
•
•
•
• • •
•
•
•
• •
•
•
•
•
•
•
•
•
• •
•
•
Simply Business
Protection
SCSI terminator
Media
External SAS cable
SAS cable for ProLiant
Internal SAS cable
Power cord
Power extender
External SCSI cable
50-68-pin SCSI adapter
SCSI ribbon cable
Integral USB cable
USB cable for ProLiant
Cable routing kit
Standard USB cable
Cables
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
HP Ultrium 2 data cartridge
HP Ultrium 1 data cartridge
HP DAT160 data cartridge
HP DAT72 data cartridge
HP DDS-4 data cartridge
•
HP DDS cleaning cartridge
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
What’s in the box
Jargon buster
HP Care Pack
Services
87
HP StorageWorks CD
HP Data Protector Express SSE
HP StorageWorks L & TT Utilities
Screws
•
•
•
•
•
•
•
•
•
•
D*
•
•
•
•
•
•
•
•
•
•
•
•
•
D*
•
•
•
• •
• •
• •
D*
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
D*
•
•
•
•
•
•
•
•
•
•
•
•
D*
User manual & drivers
Accessories
•
•
•
•
•
Installation poster
Drive & rack enclosure
OD1 option available
Hot-swap array module
Internal drive
External drive
Drive type
What’s
in the
box
Ultrium 920
Ultrium 920 Internal
EH841A
Ultrium 920 External
EH842A
Ultrium 920 Internal SAS
EH847A
Ultrium 920 External SAS
EH848A
Ultrium 920 1U Rack
EH903A
•
•
•
•
•
•
•
•
D*
D*
•
D*
D*
Ultrium 960
Ultrium 960 Internal
Q1538A
Ultrium 960 External
Q1539B
Ultrium 960 Array Module
Q1540A
Ultrium 960 in 3U Rack (1drive) Q1595B
•
•
•
•
•
•
• •
•
D*
D*
D*
Ultrium 1760
•
Ultrium 1760 Internal SAS
EH919A
Ultrium 1760 External SAS
EH920A
Ultrium 1760 SAS Rack-mount
EH946A
•
Ultrium 1840 Internal
EH853A
•
Ultrium 1840 External
EH854A
Ultrium 1840 Array Module
EH926A
•
•
• •
D*
D*
Ultrium 1840
Ultrium 1840 in 3U Rack (1drive) EH856A
Ultrium 1840 SAS Internal
EH860A
Ultrium 1840 SAS External
EH861A
•
•
•
•
•
•
• •
•
•
D*
D*
D*
D*
D*
Tape Autoloaders
DAT 72x10
AE313B
1/8 G2 Ultrium 232
AH163A
1/8 G2 Ultrium 448
AH164A
1/8 G2 Ultrium 920
AH165A
1/8 G2 Ultrium 920 SAS
AH558A
1/8 G2 Ultrium 1760 SAS
AK377A
* D = Available as free download
88
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
D*
D*
D*
D*
D*
•
•
•
•
•
•
•
•
•
•
•
•
•
Simply
Consolidation
•
•
•
•
•
•
•
• •
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Simply File
Services
•
•
•
•
•
•
•
•
•
•
• •
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Simply Business
Protection
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
What’s in the box
Jargon buster
HP Care Pack
Services
89
HP Ultrium 4 data cartridge
HP Ultrium 3 data cartridge
HP Ultrium cleaning cartridge
Media
External SAS cable
SAS cable for ProLiant
Internal SAS cable
PDU power cord
Power cord
Ethernet cable
External SCSI cable
SCSI ribbon cable
Cables
Rubber feet for tabletop
SCSI terminator
OD1 option available
Installation poster
User manual & drivers
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Accessories
Rack-mount installation kit
Drive type
What’s
in the
box
MSL2024 Tape Libraries
MSL2024 1 Ultrium 960
AG115A
MSL2024 1 Ultrium 448
AG116A
MSL2024 2 Ultrium 448
AG117A
MSL2024 1 Ultrium 960 FC
AG326B
MSL2024 1 Ultrium 920
AH169A
MSL2024 1 Ultrium 920 SAS
AH559A
MSL2024 2 Ultrium 920
AH170A
MSL2024 1 Ultrium 1760 SAS
AK378A
MSL2024 1 Ultrium 1840
AJ033A
MSL2024 1 Ultrium 1840 FC
MSL2024 0 Drive Library
AJ034A
AK379A
MSL4048 Tape Libraries
MSL4048 1 Ultrium 960
AG322A
MSL4048 2 Ultrium 960
AG323A
MSL4048 1 Ultrium 960 FC
AG324B
MSL4048 2 Ultrium 960 FC
AG325B
MSL4048 1 Ultrium 920 SAS
AH560A
MSL4048 1 Ultrium 920
AH171A
MSL4048 2 Ultrium 920
AH172A
MSL4048 2 Ultrium 1760 SAS
AK380A
MSL4048 1 Ultrium 1840
AJ035A
MSL4048 1 Ultrium 1840 FC
AJ036A
MSL4048 2 Ultrium 1840
AJ037A
MSL4048 2 Ultrium 1840 FC
AJ038A
MSL4048 0 Drive Library
AK381A
MSL8096 Tape Libraries
MSL8096 2 Ultrium 960 FC
AH218A
MSL8096 2 Ultrium 960
AH219A
MSL8096 2 Ultrium 920 SAS
AH561A
MSL8096 2 Ultrium 1840
AJ039A
MSL8096 2 Ultrium 1840 FC
AJ040A
MSL6000 Tape Libraries
90
MSL6030 0 Drive Ultrium Library
AD597B
MSL6030 1 Ultrium 960
AD606B
MSL6030 2 Ultrium 960
AD607B
MSL6030 1 Ultrium 960 FC
AD608B
MSL6030 2 Ultrium 960 FC
AD609B
MSL6030 1 Ultrium 1840
AJ029A
MSL6030 1 Ultrium 1840 FC
AJ030A
MSL6060 0 Drive Ultrium Library
AD602B
MSL6060 2 Ultrium 960
AD610B
MSL6060 2 Ultrium 960 FC
AD611B
MSL6060 2 Ultrium 1840
AJ031A
MSL6060 2 Ultrium 1840 FC
AJ032A
D*
•
•
•
•
•
•
•
•
•
•
•
•
D*
D*
D*
•
D*
D*
•
D*
D*
D*
•
•
D*
D*
D*
D*
D*
•
•
D*
D*
•
D*
D*
•
D*
D*
D*
•
D*
D*
•
D*
D*
D*
D*
D*
D*
D*
D*
D*
D*
D*
D*
•
•
•
•
•
•
•
•
•
•
•
•
Simply
Consolidation
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Ethernet cable
SCSI terminator
•
D*
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Simply File
Services
PDU power cord
•
•
•
•
•
D*
•
•
•
•
•
•
•
•
•
•
•
Power cord
D*
D*
•
•
•
0.5M LVD HDTS to LVD HDTS
•
•
•
•
•
•
•
•
•
•
•
•
•
D*
External SCSI cable
D*
Cables
HP StorageWorks L & TT Utilities
HP StorageWorks CD
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
* D = Available as free download
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
91
D2D Backup Systems
D2D110 Backup System 1 TB
D2D110 Backup System 1 TB
with Data Protector Express Software Kit
D2D110 Backup System 1 TB
with Ultrium 448 Tape Drive
D2D120 Backup System 2 TB
D2D120 Backup System 2 TB
with Data Protector Express Software Kit
D2D120 Backup System
with Ultrium 920 Tape Drive
D2D130 Backup System 3 TB
D2D130 Backup System 3 TB
with Data Protector Express Software Kit
D2D130 Backup System
with Ultrium 920 Tape Drive
92
EH880A
EH923A
EH881A
•
EH884A
EH924A
EH885A
•
EH950A
EH951A
EH952A
•
OD1 option available
Integrated Ultrium 920 SAS internal tape drive
AG124A
Rack-mount installation kit
Virtual Library
1002i 2 TB Virtual Library System
Integrated Ultrium 448 SAS internal tape drive
Drive type
What’s
in the
box
•
•
HP StorageWorks CD
Quick restore & diagnostic CD
Device firmware CD
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Simply
Consolidation
Simply File
Services
•
•
•
HP Data Protector Express SSE (CD and LTU)
•
•
•
•
•
Simply Business
Protection
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
What’s in the box
•
•
•
Jargon buster
HP Ultrium 4 data cartridge
HP Ultrium 3 data cartridge
HP Ultrium 2 data cartridge
Media
Integrated SAS cable
IEC power cord
Power cord
Ethernet cable
Cables
Integrated HP SC44Ge Host Bus Adapter
HP StorageWorks L & TT Utilities
End user license
HP Data Protector Express D2D2Any option
HP Data Protector Express Software Kit
HP D2D backup system CD
Installation poster
User manual & drivers
Accessories
•
•
•
•
•
HP Care Pack
Services
93
94
OD1 option available
•
•
•
•
HP ProLiant DL160 G5 Storage Server
DL160 G5 640 GB SATA
DL160 G5 1 TB SATA
DL160 G5 2 TB SATA
DL160 G5 3 TB SATA
DL160 G5 1.2 TB SAS
AJ672A
AJ673A
AJ674A
AJ675A
AJ676A
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
HP ProLiant ML350 G5 Storage Server
ML350 G5 960 GB SATA
ML350 G5 1.5 TB SATA
ML350 G5 3 TB SATA
ML350 G5 1.8 TB SAS
AE420A
AE425A
AE430A
AG587A
•
•
•
•
•
•
•
•
•
•
•
•
HP ProLiant DL320s Storage Server
DL320s 3 TB SATA
DL320s 6 TB SATA
DL320s 9 TB SATA
DL320s 1.7 TB SAS
DL320s 3.6 TB SAS
AG650A
AG651A
AG652A
AG653A
AG654A
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
HP ProLiant DL380 G5 Storage Server
DL380 G5 base
DL380 G5 1.6 TB SAS
DL380 G5 4.5 TB SATA
DL380 G5 9 TB SATA
DL380 G5 1.8 TB SAS
DL380 G5 3.6 TB SAS
DL380 G5 x64 SAN
AG815A
AG816A
AG817A
AG818A
AG819A
AG820A
AG771A
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
HP ProLiant DL585 Storage Server
DL585 G2 Unified SAN
DL585 G2 Unified SAN w/factory rack
AG630A
AG630A#0D1
•
•
External drive
AK303A
AK308A
AK313A
AK318A
Internal drive
ProLiant Storage Servers
HP ProLiant ML110 G5 Storage Server
ML110 G5 320 GB SATA
ML110 G5 1 TB SATA
ML110 G5 2 TB SATA
ML110 G5 584 GB SAS
Drive type
Drive & rack enclosure
What’s
in the
box
•
•
•
•
•
•
End-user license
Quick restore
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Simply
Consolidation
Power cord
User manual & drivers
•
•
•
•
Cables
Installation poster
Accessories
•
•
•
•
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
95
OD1 option available
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
AG780A
•
•
•
External drive
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Internal drive
AG659A
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Drive type
Drive & rack enclosure
What’s
in the
box
ProLiant Storage Servers (continued)
HP StorageWorks All-in-One Storage Systems
96
All-in-One 400t 1 TB SATA
AK298A
All-in-One 400t 584 GB SAS
AK293A
All-in-One 400r 1 TB SATA
AK224A
All-in-One 400r 2 TB SATA
AK225A
All-in-One 400r 1.2 TB SAS
AK226A
All-in-One 600 1.5 TB
AG538A
All-in-One 600 3 TB
AG543A
All-in-One 600 876 GB SAS
AG549A
All-in-One 600 1.8 TB SAS
AG727A
All-in-One 600 Tower to Rack Conversion Kit
AG546A
All-in-One 1200 3 TB SATA
AG655A
All-in-One 1200 6 TB SATA
AG656A
All-in-One 1200 9 TB SATA
AG657A
All-in-One 1200 1.7 TB SAS
AG658A
All-in-One 1200 3.6 TB SAS
All-in-One SB600c 1 TB SAS
Storage Blade Solution
End-user license
Quick restore
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Simply
Consolidation
Power cord
User manual & drivers
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Cables
Installation poster
Accessories
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
97
Jargon buster
Cascading
Data replication
The ability to connect switches to one
another to create a larger SAN fabric.
The ability to replicate data to another
system or site via either a LAN or SAN
connect with Distributed File System (DFS).
System administrators using this protocol
can make it easy for users to access and
manage files that are physically distributed
across a network. Files appear to users as if
they reside in one place on the network.
CIFS, NFS, NCP, MAC, HTTP, and FTP
Protocols that allow machines to send
information to one another over a network.
Clustering
The ability to group multiple servers for high
availability or performance and appear to
the user as one logical server (file server or
application server). A server in a cluster is
called a node, that is, four servers are a
four-node cluster.
Compressed capacity
Compressed capacity is the amount of data
processed or transferred by a device. This
data may have been encoded in such a
way as to compress it, by either software
or hardware processing. The tape industry
normally quotes a 2:1 compression ratio as
the standard, but actual compression ratios
vary greatly depending on the type of data
being compressed and may be more or less
than 2:1.
98
Digital Audio Tape (DAT)
A term used interchangeably with Digital
Data Storage (DDS). It refers to the
technology originally used for audio
recording, which was adapted by HP
and Sony in 1988 for data storage. DAT
is an open format produced by multiple
manufacturers.
Direct-attached storage (DAS)
Deployment of dedicated storage devices
for each server. Disadvantages include
inefficient storage use and allocation, and
multivendor storage and management
interfaces.
Disk-based backup
Integrated Lights-Out (iLO) management
Disk-to-disk (D2D) backup solutions provide
online access to your data, allowing lost or
corrupted files to be restored in minutes
instead of hours or days, thus reducing
downtime and its impact on productivity.
Two-stage backups, often called disk-to-diskto-tape (D2D2T), combine disk-based and
tape-based data protection to achieve the
benefits of both.
Selected HP ProLiant storage servers provide
embedded lights-out technology, which
enables users to perform a full range of
management tasks without physically being
in front of the server. Find out more at:
www.hp.com/servers/ilo
Dynamic Data Rate Matching (DDRM)
Dynamic Data Rate Matching (DDRM)
is a unique feature on all HP Ultrium drives
that allows the speed of the tape to be
varied to match the incoming data from
the host. This maximizes write performance
and minimizes tape repositioning.
Fibre Channel
The topology and transport protocol used to
send block-level data information between
server and storage.
Host bus adapter (HBA)
A PCI adapter that connects a server to the
SAN fabric. Each HBA installed is referred
to as a host.
Simply
Consolidation
Simply File
Services
Simply Business
Protection
IP and iSCSI protocol
iSCSI is a new networking protocol similar
to the Fibre Channel protocol, but which
uses standard Ethernet-based Internet
Protocol (IP) networks. iSCSI is particularly
interesting for small environments with lower
performance requirements.
Linear Tape-Open (LTO)
A magnetic tape format technology
developed as an alternative to DLT by a
consortium of HP and other manufacturers.
The first generation of LTO cartridge (LTO1)
was released in 2000 with a native storage
capacity of 100 GB. The latest generation is
LTO4, which provides 800 GB of native
capacity per data cartridge.
Native capacity
Native capacity is the actual number of bits
and bytes that a device or a piece of media
can store without considering data
compression.
What’s in the box
Jargon buster
HP Care Pack
Services
99
Jargon buster
Near-online
SAN fabric
Technology that uses disk-based storage
devices to store infrequently accessed data.
This includes tiered storage environments or
disk-to-disk-to-tape backup. Near-online is
often implemented with low-cost disk drives.
However, their ability to match requirements
needs to be verified.
The hardware that connects workstations
and servers to storage devices in a SAN.
The SAN infrastructure enables any-serverto-any-storage-device connectivity through
Fibre Channel switching.
Redundant Array of Independent Disks
(RAID)
Interface technology for disk drives,
providing the lowest cost per megabyte—
ideal for storing low-usage reference
information (an increasing regulatory
requirement). SATA provides basic reliability
and performance (based on an eight-hour
and 10 percent to 30 percent duty cycle)
compared to SCSI (and Fibre Channel)
HDDs, which are more advanced, providing
a 24x7 and 80 percent to 100 percent
active duty cycle (read/write).
A method of writing data simultaneously
over multiple disk drives used in disk arrays
for increased data protection and/or
increased performance.
Replication
Mirroring data between two arrays—
usually located in separate data centers—
to achieve the highest availability in case
of failure of one data center. This can be
achieved via host/IP-based replication or—
for enterprise arrays such as EVA or XP—
via SAN-based replication directly between
two arrays.
RTO and RPO
The Recovery Time Objective (RTO) is the
amount of time a business process can be
down. The Recovery Point Objective (RPO)
is the amount of data a business can afford
to lose. For 24x7 applications, the RPO
could be the most recent transaction,
whereas for file servers it could be last
night’s backup.
100
Serial Advanced Technology Attachment
(SATA)
Serial Attached SCSI (SAS)
A next-generation SCSI interface that uses
serial technology.
Small Computer System Interface (SCSI)
A protocol used to communicate with SCSI
devices. It is also used by Fibre Channel
technology to communicate with disk drives.
Snapshot
The ability to duplicate data within a server,
NAS device, or RAID Array and promote it
as a copy of data while utilizing minimal
disk space.
Storage area network (SAN)
Virtualization
High-speed, special-purpose network
connecting different data storage devices to
servers. May extend to multiple or remote
locations for backup and archival storage.
Technologies that help remove physical
storage boundaries by treating all available
storage, regardless of its location, as one
“virtual” pool.
TOE card (TCP/IP Offload Engine)
Write-Once, Read-Many (WORM)
Network cards that offload network
protocol tasks from the standard server
CPUs.
A data storage technology that allows
information to be written to storage media
only once. It is used to prevent data from
being altered or erased and it helps
organisations meet regulatory requirements
for retaining data securely in an unalterable
format. Data can be appended but not
changed or overwritten.
Ultrium
A high-capacity tape format based on
LTO technology. It is an open format used
by multiple manufacturers that provides
enhanced performance and reliability over
earlier formats.
Virtual Tape
Virtual tape is a disk-based technology
that emulates one or more tape drives,
autoloaders, or libraries. A virtual tape
device appears to the backup software and
other devices on the network as a tape
device, and its type depends on its
configuration.
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
101
HP Care Pack Services
Scalable, flexible, dependable—just like your storage.
Your storage is evolving. Now you can have the scalable support that evolves with it. HP Care Pack Services
is an easy-to-buy, easy-to-use family of packaged services covering your lifecycle needs. You can rely on our
highly skilled, HP-certified professionals to provide the expertise that spans leading storage technologies,
and work side by side with you for better results. They will reduce the cost and complexity of defining,
implementing, managing and improving your increasingly crucial storage processes. Push services beyond
expectations and choose support that meets the changing needs of your business with the same reliability,
scalability, and flexibility you demand of your storage.
Choose from the following range of services:
• HP Storage Deployment—Installation & Startup, Implementation, Data Center Service, Per-Event Services
• HP Storage Support Services—Hardware, Software Support Services, Mission Critical Storage Support
Services, Multivendor Environment Support Services
• Solution Service Capabilities
• HP Storage Education and Financial Services
HP Care Pack Services resources
To find out more about HP Storage Services, contact your local HP sales representative,
Authorised Channel Partner, or visit the following sites:
• For HP Care Pack Services, visit: www.hp.com/hps/carepack
• For HP SAN Solution Services, visit: www.hp.com/hps/storage
• For HP Care Pack Education Services, visit: http://education.hp.com/carepack
• For HP Fibre Channel switches and multi-protocol routers, visit: www.hp.com/go/san
102
HP StorageWorks All-in-One Storage Systems
Installation
3 Years
Support Plus
Support Plus 24
UH167E
UH168E
AiO600
UE984E
UE985E
AiO1200
UG008E
UG009E
AiO400t, AiO400r
UF285E
Services are only ordered as an Electronic HP Care Pack Services (xxxxx-E)
HP StorageWorks Modular Smart Arrays
MSA20/30/50
Installation
Installation &
Start-up
HA upgrade
kit (*)
NBD
4-Hour, 13x5
HW Support
4-Hour, 24x7
HW Support
6-Hour, CTR,
24x7
U8132E
N/A
N/A
U8128E
U8129E
U8130E
U8131E
UF301E
UF302E
UF303E
UF304E
U8132E
UA868E
N/A
UJ647E
UJ651E
UJ652E
UJ653E
MSA60/70
MSA2000i/2000fc
N/A: Not Applicable
For more information, please visit: www.hp.com/hps/carepack
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
103
HP Care Pack Services
HP StorageWorks B-Series Infrastructure
Product family series
Warranty
Installation
3 Years,
HW Support
4-Hour,
13x5
3 Years,
3 Years,
HW Support Support
4-Hour,
Plus
24x7
Brocade series 8 ports
1 Year Next
Business Day
On-site
U5988E
U2088E
U2089E
U5988E
H4620E
H4621E
Brocade series 32 ports
U5988E
UA259E
UA260E
Brocade series 64 ports
U5988E
H5546E
H5547E
Brocade series 16 ports Power Pack
U5988E
U5957E
U5958E
Brocade series 32 ports Power Pack
U5988E
UF199E
UF200E
Brocade series 64 ports Power Pack
SAN Solution
Service
Brocade series 256 ports
U5988E
Brocade series iSCSI Blade for
4/256 SAN Director
U5988E
Brocade Blade SAN Switch 4Gb
and 4/12 Series
U5988E
UE437E
UE438E
Brocade Blade SAN Switch 4/24
Power Pack
U5988E
UD570E
UD571E
Brocade Blade SAN Switch 4/24
U5988E
UC008E
UC009E
Brocade Blade SAN Switch 4Gb
Power Pack
U5988E
Brocade series 16 ports
3 Years,
Support
Plus 24
HA110A3
UC008E
3 Years,
Proactive
24
HA111A3
UC009E
UC019E
UC020E
UE728E
UE729E
HP StorageWorks C-Series Infrastructure
Cisco MDS 9020 Fabric Switch
U5988E
UF972E
UF973E
U5988E
UG017E
UG018E
Cisco MDS 9140 Fabric Switch
U5988E
U9280E
U9281E
Cisco MDS 9216 series
U5988E
HA103A3
HA104A3
Cisco MDS 9216i series
HA113A1
HA103A3
HA104A3
Cisco MDS 95xx Series
SAN Solution
Service
Cisco MDS 9000 PA Adapter
U5988E
Cisco MDS 9222i Multi-service
series
Cisco MDS 9000 18/4 Module
Cisco MDS 9124e Fabric Switch for
HP BladeSystem c-Class
104
1 Year Next
Business Day
On-site
HA110A3
HA111A3
SAN Solution
Service
HA110A3
HA111A3
HA113A1
HA110A3
HA111A3
U9919E
U9920E
HP ProLiant Storage Servers
Installation
Installation and
Start-up
3 Years
Support Plus
Support Plus 24
U7986E
N/A
UH161E
UH162E
DL160 G5
UH173E
UH174E
ML350 G5
UB995E
UC544E
DL320s
UF990E
UF991E
UC573E
UC574E
UE420E
UE421E
UC573E
UC574E
DL380 G5 x64 SAN
UH069E
UH070E
DL585 G2
UF998E
UF999E
ML110 G5
DL380 G5 (base, standard OS)
U7986E
N/A
DL380 G5 (external SCSI/SATA,
standard)
DL380 G5 (enterprise)
N/A
U9521E
For more information, please visit: www.hp.com/hps/carepack
Simply
Consolidation
Simply File
Services
Simply Business
Protection
What’s in the box
Jargon buster
HP Care Pack
Services
105
HP Care Pack Services
HP StorageWorks Tape Drives
Installation
3 Years
Next Business
Day
4-Hour, 13x5 HW 4-Hour, 24x7
Support
HW Support
6-Hour Call-toRepair, 24x7 HW
Support
UD064E
UD065E
UD066E
U6358E
USB DAT 40, DAT 72
(3-Year Parts Warranty)
H3155E
H4616E
U2068E
U6358E
DAT 24, DAT 40, DAT 72, DLT VS80,
DLT VS160 (3-Year Parts Warranty)
H3155E
H4616E
U2068E
U6358E
H3157E
H4617E
H4622E
U6359E
Low end
USB DAT 24
(1-Year Parts Warranty)
U2090E
High end
SDLT 320, SDLT 600, Ultrium 215,
U2090E
Ultrium 230, Ultrium 232, Ultrium
448, Ultrium 920, Ultrium 960,
Ultrium 1840 (3-Year Parts Warranty)
HP StorageWorks Rack-Mount and Tape Array Solutions
Installation
1U Rack-mount Kit
U2090E
3 Years
NBD, 9x5 HW
Support
4-Hour, 13x5 HW
Support
4-Hour, 24x7 HW
Support
6-Hour Call-toRepair HW Support
UB136E
UB135E
UB137E
UB138E
3U Rack-mount Kit
N/A
H4618E
H4623E
U6368E
3U Rack-mount Kit with
2 DLT/SDLT or 1 LTO
U6335E
U6336E
U6337E
U9285E
For HP Care Pack Services, the ‘box-level strategy’ applies, i.e., the service is sold on the entire rack-mount and support applies to
any number of drives inside, even if added at a later date.
HP StorageWorks Autoloaders and MSL Tape Libraries
Installation
3 Years
NBD—Parts
Exchange
4-Hour, 13x5 HW
Support
4-Hour, 24x7 HW 6-Hour, 24x7 HW
Support
Support
DAT 72x10
U2090E
UE272E
UD849E
UD850E
1/8 G2 Autoloader
U2090E
H2698E
H5526E
H4624E
U6367E
MSL2024
U4823E
UE293E
UE295E
UE296E
UE308E
MSL4048
U4823E
UE286E
UD834E
UD835E
UE307E
MSL8096
U4824E
N/A*
UF839E
UF840E
MSL6030
U4823E
N/A*
U2860E
U2861E
MSL6060
U4824E
N/A*
U2863E
U2864E
* NBD—On-site Parts Exchange
106
HP D2D Backup System
Installation 3 Years
D2D Backup
Solution with
Data Protector
SW
D2D 110 &
D2D 120
UD056E
D2D 110 &
D2D 120
NBD—
Parts
Exchange
NBD, 9x5
HW
Support
4-Hour,
13x5 HW
Support
4-Hour,
24x7 HW
Support
6-Hour
Support
Call-toPlus
Repair HW
Support
Support
Plus 24
UE309E
UE314E
UE315E
UE316E
UE317E
UF831E
UF832E
UE309E
UE314E
UE315E
N/A
N/A
UE316E
UE317E
HP Virtual Library System
Installation
VLS1000i
UD056E
Installation and
Start-up
3 Years
NBD—Parts
Exchange
4-Hour, 13x5 HW
Support
4-Hour, 24x7 HW
Support
N/A
UE273E
UD819E
UD820E
HP ProLiant Data Protection Storage Servers
Installation
3 Years
Support Plus
Support Plus 24
DL100
1TB
UC990E
UC991E
DL100
3TB
UD413E
UD414E
DL100
6TB
UD422E
UD423E
DL380
9TB
UD431E
UD432E
U7986E
© Copyright 2008 Hewlett-Packard Development Company, L.P. The information contained herein is
subject to change without notice. The only warranties for HP products and services are set forth in the
express warranty statements accompanying such products and services. Nothing herein should be
construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors
or omissions contained herein.
Microsoft, Windows, and Windows Server are registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. Oracle is a registered U.S. trademark of
Oracle Corporation, Redwood City, California. UNIX is a registered trademark of The Open Group.
4AA0-6887ENW, April 2008

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project
