Products for

Visual

Communication

Screen Selection/Resource Center

Draper—

Building on our Experience since 1902

2

The Luther O. Draper Shade Company, now known as Draper, Inc., was founded in Spiceland, Indiana, in 1902. Under the ownership and management of Mr. Draper’s descendants, his simple and straightforward business philosophy continues today: make a quality product and offer it at a reasonable price.

Those products include projection screens, rear projection display systems, video projector mounts and lifts, plasma and

LCD display mounts and lifts, presentation easels, window coverings and gymnasium equipment.

In addition to its Indiana facility, Draper has manufacturing operations in Ohio,

China and Sweden, and sales offices in

California, the United Kingdom and Hong

Kong. Draper products are sold to dealers and shipped throughout the United States and to more than 100 countries. Draper’s dedication to innovation is one reason its workforce has never experienced a layoff.

This catalog features Draper’s full line of products for visual communication, which includes—

Ceiling-Recessed Motorized Screens........... 6-12

Wall-Mounted Motorized Screens ............ 13-17

Video Projector Lifts ............................... 18-22

Aero Mounts for LCD Projectors ............. 23-27

Aero Mounts for Plasma Displays............. 28-31

Aero Mounts for Flat Panel Displays ........ 32-33

Permanently Tensioned Screens ................ 34-37

Manual Projection Screens ....................... 38-44

Portable Projection Screens....................... 44-53

Rigid Rear Projection Screens................... 54-59

Rear Projection Systems ........................... 60-64

Easels ....................................................... 65-68

www.draperinc.com 765-987-7999

Selecting the Right Projection Screen

Draper manufactures the finest and most complete line of projection screens in the world. We want to help you incorporate these screens into the most effective presentation systems. Planning a projection system involves several steps: choosing the screen size, viewing surface, screen model and control system. We’ve provided detailed recommendations to help with these important decisions.

Projection Screen Size Selection

One of the most important decisions in screen selection is to determine the correct size of screen based upon—

1. The dimensions of the audience area.

2. The projection format(s) to be used.

Other key considerations—

Audience Area—The goal is to make the screen large enough so those in the back row can read the subject matter easily, but not so large as to overwhelm the closest viewer.

Height—Use the following formulas for calculating screen height for maximum legibility. For : NTSC moving video and entertainment, screen height should be at least ¹⁄₆ the distance from the screen to the furthest seat; for charts and data, as in a conference or lecture room, use 1⁄4; for complex graphics found in a command/control center, use 1⁄2. For HDTV projection, screen height should equal or exceed 1⁄3 the distance from the screen to the optimum seat.

Width—Screen width is generally determined by the height of the screen and the projection formats to be used.

Ceiling Height—The bottom of the screen should be approximately - above the floor in a room with a level floor and several rows of seats. In rooms with theatre seating or only one or two rows, the bottom of the screen should usually be - above the floor. Evaluate any barriers, and try to make sure that the lower part of the screen will be visible from all seats. Extra drop may be required to position the screen at a comfortable viewing level in a room with a high ceiling.

Projection Format—Once you have determined the correct size of screen based upon the audience area, that size may be modified based upon the projection equipment. If the screen will only be used with one type of projector (NTSC video, HDTV, etc.), it is easy to determine the exact screen dimensions based upon its projection format.

Common Projection Formats

Note: Vertical presentation of a slide reverses its aspect ratio. To allow this, use a 1.00:1.00 aspect ratio for any type slide.

1.00:1.00

Square

5:4 or

1.25:1.00

Data Graphics

4:3 or

1.33:1.00

NTSC Video

1.48:1.00

Horizontal

35mm Slides

16:9 or 1.78:1.00

HDTV

1.85:1.00

WideScreen

2.35:1.00

CinemaScope

Most models of Draper screens are offered in both audio visual and NTSC video formats. Many models are also offered in HDTV and

WideScreen formats. The differences between these formats are described below. We are glad to provide any Draper screen in the size and projection format of your choice, up to and including the largest published size.

Audio visual (or AV) format screens accommodate a variety of projector types and range from square to wide horizontal in aspect ratio. AV format

screens are described in terms of height x width, and are furnished without black borders, although borders are optionally available. Screens with

Tab Tensioning System always include black borders and  of black drop at the top.

NTSC video format screens, on the other hand, are specifically designed for use with video/data projectors. Their format is strictly defined as a 4:3 rectangle, and the size is usually described in terms of a nominal diagonal. Conventional models of NTSC format screens are furnished with black borders to frame the image on all four sides. Tab-tensioned screens include black borders at the sides and bottom, and  of black drop at the top.

HDTV format (16:9) is designed for high-definition television projection, and WideScreen format (1.85:1) is suitable for letterboxed video images.

Data graphics format (5:4) projectors more accurately reproduce the image from a 1024 x 1280 pixel computer screen. Data graphics format screens are available in any model by quotation.

How to Calculate a Custom Size

Draper also manufactures custom size screens to meet your specification. Virtually any size up to the maximum shown for a given model is available.

If you need to calculate a custom size, these formulas may be useful (D = exact diagonal; H = image area height; W = image area width):

4:3 NTSC Video 16:9 HDTV 1.85:1 WideScreen 2.35:1 CinemaScope 5:4 Data Graphics

H = D x .6 H = D x .49 H = D x .4762 H = D x .3915 H = D x .625

W = D x .8 W = D x .87146 W = D x .881 W = D x .92 W = D x .781

D = H x 1.667 D = H x 2.04 D = H x 2.1 D = H x 2.554 D = H x 1.601

D = W x 1.25 D = W x 1.1475 D = W x 1.135 D = W x 1.0868 D = W x 1.281

www.draperinc.com 765-987-7999

3

4

Screen Selection/Resource Center

Which Surface? Textile Backed vs 100% Vinyl

Textile Backed Screen Surfaces—

A reflective surface laminated to a woven textile base. The screen surface hangs suitably flat because of the stability of the material and the weight of the bottom dowel. Good for all types of projection. Commonly used for single lens video projection, as well as for CRT video and data-graphics projection.

Fiberglass Matt White—

The standard to which all other screen surfaces are compared.

Matt white vinyl reflective surface laminated to tear-resistant woven fiberglass. A matt white surface diffuses projected light in all directions, so image can be seen from any angle. Provides accurate color rendition as well as superior clarity. Recommended for use with all high light output projection devices. Requires control of ambient light in the audience area. Washable, flame and mildew resistant. Seamless in all standard sizes through  high.

Gain Charts*

Fiberglass Matt White, Panamax & AT1200

Gain 3.0

2.0

1.0

0.5

Panamax—

Seamless matt white material for large roller operated screens—up to  wide.

Panamax has excellent dimensional stability. Washable. Most motorized screens with Panamax are not UL listed. Refer to specifications on the Web for details: www.draperinc.com.

70˚ 60˚ 50˚ 40˚ 30˚ 20˚ 10˚ 0˚ 10˚ 20˚ 30˚ 40˚ 50˚ 60˚ 70˚

Viewing Angle

Glass Beaded

Glass Beaded—

Spherical glass beads embedded in surface provide brighter on-axis viewing than matt white, within a narrower viewing cone. All glass beaded surfaces have some loss of clarity and perform best with table-mounted projectors. Flame and mildew resistant, cannot be cleaned. Seamless in standard sizes through  high.

Gain 3.0

2.0

1.0

0.5

High Contrast Grey—

Grey textile-backed surface offers excellent resolution while enhancing the blacks of LCD and DLP projected images, even as whites and lighter colors are maintained. Performs well in ambient light. Lower gain of 0.8 allows use with even the brightest projectors. Available on most non-tensioned motorized and manual screens; seamless in sizes up to  in height.

AT1200 and AT Grey—

The most innovative and versatile acoustically transparent screen material. Similar in gain performance to matt white. Acoustical properties comparable to the finest speaker grille cloth. Washable, flame and mildew resistant. Available in sizes through

   or  diagonal. AT1200 is white; AT Grey is grey for high contrast.

60˚ 50˚ 40˚ 30˚ 20˚ 10˚ 0˚ 10˚ 20˚ 30˚ 40˚ 50˚ 60˚

Viewing Angle

High Contrast Grey & AT Grey

Gain 3.0

2.0

1.0

0.5

70˚ 60˚ 50˚ 40˚ 30˚ 20˚ 10˚ 0˚ 10˚ 20˚ 30˚ 40˚ 50˚ 60˚ 70˚

Viewing Angle

100% Vinyl Materials—

These screen surfaces are tensioned vinyl with no backing. Draper offers motorized, crank-operated and permanently tensioned screens with built-in tensioning systems. Advantage—The surface is stretched perfectly flat, resulting in better picture quality. Flatness is always desirable and highly recommended for video or data-graphics projection.

M1300—

The perfect matt white diffusing surface. Extremely broad light dispersion and spectral uniformity. Panoramic viewing angle and true color rendition. For use with any type of projector in rooms where the light level can be reasonably controlled. Washable.

M1300

Gain 3.0

2.0

1.0

0.5

M2500—

A high-contrast front viewing surface with excellent resolution and high gain. For data-graphics projectors producing up to 1000 ANSI lumens. M2500 tolerates a higher ambient light level than most other front projection screen surfaces.

HiDef Grey—

A grey front projection surface that provides excellent contrast and black reproduction with a low gain to handle today’s super-bright projectors. The grey color enhances color contrast, black levels and allows for more ambient light in the audience area.

70˚ 60˚ 50˚ 40˚ 30˚ 20˚ 10˚ 0˚ 10˚ 20˚ 30˚ 40˚ 50˚ 60˚ 70˚

Viewing Angle

M2500

Gain 3.0

2.0

1.0

0.5

Cineflex—

A neutral grey vinyl for rear projection. Cineflex has high resolution and excellent contrast, even in lighted rooms. For use with any type of projection equipment.

When selecting a front projection surface, several key factors need to be considered, including:

60˚ 50˚ 40˚ 30˚ 20˚ 10˚ 0˚ 10˚ 20˚ 30˚ 40˚ 50˚ 60˚

Viewing Angle

• Gain—a relative measure of a screen’s reflectivity.

HiDef Grey

• Contrast—the ability to accurately reproduce and differentiate light and dark characters and

backgrounds, or light and dark areas of an image.

��������

���

���

���

• Ambient light rejection properties—the ability to perform well under normal to adverse audience lighting conditions.

• Resolution—the clarity of the projected image.

�������������������� �������� ��� ���������������������������

�������������

• Uniformity—the screen’s performance when viewed from various points off the projection axis (both horizontally and vertically), and when the brightness of the center of the image is compared to the corners.

• Aspect ratio—the screen’s height and width configuration, formatted for the desired projection source (NTSC video, HDTV, WideScreen, CinemaScope, overhead, slide or motion pictures).

Cineflex

Gain 3.0

2.0

1.0

0.5

50˚ 40˚ 30˚ 20˚ 10˚ 0˚ 10˚ 20˚ 30˚ 40˚ 50˚

Viewing Angle

*These charts depict gain values at various points, measured in degrees from projection axis. Gain is a measure of brightness as compared to a block of magnesium carbonate, which serves as a standard for gain of 1.0. These charts also help in judging uniformity. The flatter the curve in the portion of the viewing cone where viewers will be seated, the more consistent the image they will perceive. The quality of an image which the human eye perceives is primarily a function of gain, contrast, uniformity and resolution.

www.draperinc.com 765-987-7999

Warranty

All products in this catalog are warranted for one year against defects in materials and workmanship. Some products carry a longer warranty term: see product description. Defective products will be repaired or replaced, at Draper’s option. Authorization required prior to return. Detailed warranty terms are available upon request.

Front Projection Screens—Their Surfaces and Features

HC Grey, Fiberglass M1300,

Page Matt White or M2500 or

AT1200/AT Grey  Black Tensioned

Acoustically Cineflex Operator Drop

Sizes

Viewing Ceiling Over 

Screen Model Number Glass Beaded HiDef Grey Panamax Transparent Rear Vinyl (see key) Supplied Surface Closure wide

Access MultiView/Series E 6, 9

Access MultiView/Series V 6, 9 

Access/Series E 6, 7

Access/Series M 6, 38 

M/R 

M/R 

M/R

SR

 Access/Series V 6, 7 

Access Sonata/Series E 6, 9

Access Sonata/Series V 6, 9 

Ambassador 11

Apex 38

Artisan/Series E 13 

Artisan/Series M 40 

Artisan/Series V 13 

Cineperm 37 

Cinefold & Truss Cinefold 48-49

1

Clarion 35

2

Consul 51 

3

Diplomat & Diplomat/R 51

Envoy 11 

Evenroll 41 

3

Exxpress 44-45

Luma, Luma 2, Luma 2/R 41, 43

Luma Elite 43

RoadWarrior 52

Rolleramic 12

Salara 16

Salara/Series M 44

Silhouette/Series E 17

Silhouette/Series M 39

Star 42

Targa 15

Traveller 53

Paragon 12 

3

5

Onyx 34

3

Premier 14

Premier/Series C 40 

ShadowBox Clarion 36

Signature/Series E 10 

Signature/Series V 10

Silhouette/Series C 39

Silhouette/Series V 17

Ultimate Folding Screen 46-47 

1

Ultimate Access/Series E 6, 8

Ultimate Access/Series V 6, 8 

VScreen 42

5

WrapAround Clarion 36

M/R 

M/R 

M/R 

M

SR

M/R

SR

M/R 

PT

P

PT

P

P

M/R

Rope/Pulley

4

P

SR

SR

 

PT

M/R

M/R 

C 

P

M

M/R

SR

PT

M/R

M/R 

C 

M/R

SR

M/R 

SR

M/R

P

P

M/R

M/R 

SR

PT

1

Flexible Matt White is the front projection viewing surface available.

2

Not available with High Contrast Grey or Matt White.

3

Not available with High Contrast Grey.

4

The Exxpress screen surface is made of SpanTec™, a flexible, flame retardant and acoustically transparent polyester material. Alpine White in color.

5

Matt White only.

For specific details, size and surface limitations, see the descriptions and charts on the referenced pages.

Operator Key

C = Crank

M = Motorized

M/R = Motor-in-Roller

P = Portable

PT = Permanently Tensioned

SR = Spring Roller

www.draperinc.com 765-987-7999

5

Ceiling-Recessed Motorized Screens

Access Concept

• Access/Series V, Series E & Series M

• Ultimate Access/Series V & Series E

• Access Sonata/Series V & Series E

• Access MultiView/Series V & Series E

The Access Series is Draper’s innovative solution to the problems that have plagued projection screen buyers for years—incorrect size of screen, aspect ratio or choice of surface, and job site damage during construction—all can be avoided with an Access.

Case Now/Screen Later—The essence of the Access concept is a unique ceiling-recessed, extruded aluminum headbox. The screen itself—viewing surface attached to roller—can either be furnished with the headbox or at any time thereafter. The screen installs in minutes with only a hex key.

The ten models which comprise the Access Series are described here, on pages 7-9, and 38.

What If...

What if you know you want a ceiling-recessed screen, but you don’t know what projector (or projectors) will be used. Therefore, you don’t know the optimum size or aspect ratio of the screen, the optimum screen surface or whether tab tensioning is required.

No problem with the Access—Order the case now. Just make sure it’s large enough to accept the largest screen you think you may need. Order the screen later, after the projector decision is made. Or let the occupant make the decision at a later date.

What if technology changes? What if a new projection format is introduced, or Draper introduces a superior new screen surface?

No problem with the Access—It’s quick, easy and comparatively inexpensive to replace the screen in an Access with no extra electrical or ceiling work.

What if you’re planning a facility and the room design is flexible, or the presentation rooms have not yet been determined?

No problem with the Access—Install an Access case in each room during construction and think about screen selection later. Adds great value to the facility.

6

Access Case

Easy Installation—Easy Access

It’s easy to see why the Access Series is so popular. Designed with solutions in mind, the case features include:

• Hanging brackets that slide in channels on top of the case, allowing unlimited adjustment to avoid interference with conflicting building structures. 

• A pre-wired junction box inside (left end standard), and cable exit holes on top.

• “Pin connector” electrical connection of screen to junction box—eliminating tools.

• Flange that supports ceiling tile or trims the opening of any type of ceiling. 

• Bottom of case that forms a slot for fabric passage , and is removable without tools  for installation or replacement of screen.

The screen (viewing surface attached to roller) comes with easy-to-install roller brackets. These slide along a track inside the top of the case, and may be locked in place at any point so the case can accommodate different screen sizes. Since both brackets are movable, the screen can always be centered in the case—regardless of case size. A large case allows for unlimited flexibility.

The Access case may be ordered in advance of the screen or alone. The installation of a ceiling-recessed projection screen in the aftermarket may cost more than the screen itself, so a pre-installed ceiling-recessed housing adds real value. You can select, order and install the desired Access Series screen at any later date.

One step further—The Ultimate Access

The Ultimate Access case offers all the advantages of the Access, plus an independently motorized “trap door”

ceiling closure. The Ultimate Access’ door opens up into the case. It never dangles behind the viewing surface and when closed, it is perfectly flat without adjustment.

At right, the Ultimate Access case is shown with the ceiling closure closed , then open inside the case. 

Finally, the entire closure extends down as required for screen installation or adjustment. 

www.draperinc.com 765-987-7999

Access Case

Ultimate Access Case

Access Series

Eliminates your installation problems. Install the case now and the screen later.

The Access is the most versatile ceiling-recessed screen on the market. No other projection screen offers you the benefits of installing the case during construction, and quick-connecting the viewing surface at a later date to eliminate job site damage. See page 6 for details of

Draper’s Access case.

Access/Series V—

Features Draper’s Tab Tensioning

System for a perfectly flat projection surface. Choose

M1300, M2500, HiDef Grey or Cineflex rear projection viewing surface. See page 14 for more on the benefits of

Tab Tensioning.

Access/Series V: American Airlines Federal Credit Union, Dallas, Texas. Installation by

Audio Visual Innovations. Photograph by Charles D. Smith–AIA

6

5

/

8

"

6

5

/

8

"

Access/Series E—

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded,

High Contrast Grey, Panamax or acoustically transparent AT1200 or AT Grey.

System Options

Screen up

8

5

/

8

"

8

5

/

8

"

• Extra Drop— black drop at top of image area is now standard on Series V tab-tensioned screens.

Additional drop is optional, either white or black.

(White is standard for Series E in AV format. Black is standard for Series E in all other formats and for all

Series V screens). Extra drop will increase the overall length of the case of a Series V screen.

• Black Masking Borders—Borders are optional for

Series E in AV format. Borders are standard for Series

E in all other formats and for all Series V screens.

• Larger sizes now available.

• Control Options—Refer to page 22. Controls may be built into case and will increase overall length of case.

• Screen/Case Options—Left or right motor location.

Screen down

Bottom panel off during installation

� � �

��

� � �

��

� � �

�������

�����

��

��������

������������

Access/Series V

� � �

��

Access����������

����������������

�����������������

Access/Series E

�������������������

�����������������������

�������������������������

����������������

������������������������������

�����������������������������

������������������

Series E Series V

Size Case Net Wt. Case Dowel Net Wt.

HxW Length* (lbs.) Length* Length (lbs.)

Audio Visual Format

50 x 50 54 50 63 5 58

60 x 60 62 55 72 511 66

70 x 70 7 65 8 610 69

84 x 84 82 72 931⁄4 8 74

72 x 96 92 80 102 9 92

96 x 96 92 90 1043⁄4 911⁄2 92

7 x 9 102 92 1131⁄4 10 95

9 x 9 102 93 1143⁄4 102 95

8 x 10 112 97 1243⁄4 1111⁄2 99

10 x 10 112 107 1261⁄2 1133⁄4 109

9 x 12 132 108 1443⁄4 132 110

12 x 12 132 119 14101⁄2 1351⁄2 121

*Optional built-in controls increase length of case. In Series

V, extra drop also increases case length. Consult factory if this dimension is critical.

U.S. Patent Nos. 6,137,629; 6,421,175 and 6,532,109;

Other patents pending.

Complete Access Series specifications: www.draperinc.com

Series E Series V

Size Image Area Case Net Wt. Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length* (lbs.) HxW Length* Length (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 62 55 421⁄2 x 561⁄2 691⁄2 561⁄2 60

7 50 x 661⁄2 7 61 50 x 661⁄2 771⁄2 641⁄2 68

100 60 x 80 82 71 60 x 80 89 77 73

10 69 x 92 92 82 72 x 96 102 9 92

11 78 x 104 102 96 78 x 104 10111⁄4 98 98

150 87 x 116 112 102 87 x 116 11111⁄4 1091⁄2 104

15 105 x 140 132 108 108 x 144 1443⁄4 132 110

200 118 x 158 148 114 — — — —

HDTV Format (16:9)

92 45 x 80 82 74 45 x 80 89 76 76

106 52 x 92 92 78 52 x 92 99 86 80

119 58 x 104 102 82 58 x 104 109 97 85

133 65 x 116 112 87 65 x 116 1110 107 89

161 79 x 140 132 104 79 x 140 13111⁄4 128 106

184 90 x 160 1410 111 — — — —

WideScreen Format (1.85:1)

99 47 x 87 88 75 47 x 87 94 81 79

108 50 x 92 92 78 50 x 92 99 86 80

120 56 x 104 102 80 56 x 104 109 97 85

132 63 x 116 112 87 63 x 116 1110 107 89

162 76 x 140 132 104 76 x 140 13111⁄4 128 106

182 861⁄2 x 160 1410 111 — — — —

www.draperinc.com 765-987-7999

7

8

Ceiling-Recessed Motorized Screens

Ultimate Access

With an independently motorized ceiling closure.

The Ultimate Access offers all the advantages of the Access, plus

an independently motorized ceiling closure. In its closed position, the motorized closure forms a solid bottom panel giving the ceiling a clean appearance. At the touch of a switch or wireless transmitter, the door of the Ultimate Access opens into the case before the viewing surface descends into the room. Your audience will be impressed by its precision timing and quiet, fluid movement.

No other projection screen offers you so many benefits. Refer to page  for the rewards of installing the Access case during the

“dirty” phase of the construction process. The screen (motor-inroller with attached viewing surface) can be ordered, shipped and stored independently of the headbox, and popped into the case at a future date.

Ultimate Access—the ultimate in projection screen design.

U.S. Patent Nos. 5,341,241; 6,137,629; 6,421,175 and 6,532,109.

Other Patents Pending.

8"

8"

Ultimate Access/Series V—

Features Draper’s Tab Tensioning System for a perfectly flat projection surface. Choose M1300, M2500, HiDef Grey or Cineflex rear projection viewing surface. See page 14 for more on the benefits of Tab Tensioning.

10

1

/

2

"

10

1

/

2

"

Ultimate Access/Series E—

Your choice of a conventional viewing surface: fi berglass matt white, glass beaded, High Contrast Grey, Panamax or acoustically transparent AT1200 or AT Grey.

System Options

Motorized ceiling closure

Ultimate Access/Series V

Ultimate Access/Series E

• Extra Drop— black drop at top of image area is now standard on Series V tab-tensioned screens. Additional drop is optional, either white or black. (White is standard for

Series E in AV format. Black is standard for Series E in all other formats and for all Series V screens). Extra drop will increase the overall length of the case of a Series V screen.

��

��

� � �

� � �

• Black Masking Borders—Borders are optional for Series E in AV format. Borders are standard for Series E in all other formats and for all Series V screens.

������������

�����������

��

�������������������

�����������������������

�������������������������

• Control Options—Refer to page 22. Controls may be built into case.

��

���������������

������������������������������

�����������������������������

������������������

• Screen/Case Options—Left end motor location only.

������������������������

������������������������

� ��

��

������

Series E Series V

Size Case Net Wt. Case Dowel Net Wt.

HxW Length (lbs.) Length* Length (lbs.)

Audio Visual Format

50 x 50 563⁄8 82 637⁄8 5 84

60 x 60 643⁄8 89 727⁄8 511 96

70 x 70 723⁄8 98 87⁄8 610 100

84 x 84 843⁄8 105 941⁄8 8 108

72 x 96 943⁄8 121 1027⁄8 9 134

96 x 96 943⁄8 127 1055⁄8 911⁄2 135

7 x 9 1043⁄8 134 1141⁄8 10 138

9 x 9 1043⁄8 135 1155⁄8 102 139

8 x 10 1143⁄8 141 1255⁄8 1111⁄2 144

10 x 10 1143⁄8 155 1273⁄8 1133⁄4 158

9 x 12 1343⁄8 157 1455⁄8 132 160

12 x 12 1343⁄8 173 14113⁄8 1351⁄2 176

* In Series V, extra drop increases case length.

Consult factory if this dimension is critical.

Complete Ultimate Access Series specifications: www.draperinc.com

Series E Series V

Size Image Area Case Net Wt. Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length (lbs.) HxW Length* Length (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 643⁄8 85 421⁄2 x 561⁄2 6103⁄8 561⁄2 87

7 50 x 661⁄2 723⁄8 96 50 x 661⁄2 783⁄8 641⁄2 99

100 60 x 80 843⁄8 103 60 x 80 8107⁄8 77 106

10 69 x 92 943⁄8 121 72 x 96 1027⁄8 9 134

11 78 x 104 1043⁄8 136 78 x 104 111⁄8 98 140

150 87 x 116 1143⁄8 138 87 x 116 121⁄8 1091⁄2 142

15 105 x 140 1343⁄8 157 108 x 144 1455⁄8 132 160

HDTV Format (16:9)

92 45 x 80 843⁄8 100 45 x 80 897⁄8 76 103

106 52 x 92 943⁄8 120 52 x 92 997⁄8 86 130

119 58 x 104 1043⁄8 132 58 x 104 1097⁄8 97 135

133 65 x 116 1143⁄8 134 65 x 116 11107⁄8 107 137

161 79 x 140 1343⁄8 152 79 x 140 141⁄8 128 155

WideScreen Format (1.85:1)

99 47 x 87 8103⁄8 112 47 x 87 947⁄8 81 110

108 50 x 92 943⁄8 120 50 x 92 997⁄8 86 130

120 56 x 104 1043⁄8 130 56 x 104 1097⁄8 97 134

132 63 x 116 1143⁄8 134 63 x 116 11107⁄8 107 137

162 76 x 140 1343⁄8 152 76 x 140 141⁄8 128 155

www.draperinc.com 765-987-7999

Access Sonata

One screen, four formats.

Access Sonata—a motorized screen and masking system linked electronically provides four different projection formats at the touch of a button—all in a ceiling-recessed Access case.

A flat black mask on a second roller converts the projection screen to your choice of four formats: NTSC, HDTV, WideScreen and CinemaScope.

During format change, the center line and width of the viewing surface remain constant while the mask and projection screen move simultaneously into their factory preset positions.

1.33:1 NTSC 1.78:1 HDTV

Access Sonata—one screen, four formats. Unlimited possibilities.

Access Sonata/Series V—

Features Draper’s Tab Tensioning System for a perfectly flat projection surface. Choose M1300, M2500 or HiDef

Grey. See page 14 for more on the benefits of Tab Tensioning.

Access Sonata/Series E—

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded, High Contrast Grey, or acoustically transparent AT1200 or AT Grey.

System Options

Extra Drop— black drop standard for all screens in both Series. Extra black drop available up to a total screen height of .

1.85:1 WideScreen 2.35:1 CinemaScope

• Black Masking Borders—Borders are standard for all screens in both Series.

• Control Options—Refer to page 22. Single station 6-button wall switch standard. Compatible with Sonata IR remote control.

6

5

/

8

"

Size Screen Image Masked Image Masked Image Masked Image Series V Series E

Nominal NTSC HDTV WideScreen CinemaScope Case Net Wt. Case Net Wt.

Diagonal 4:3 H x W 16:9 H x W 1.85:1 H x W 2.35:1 H x W Length* (lbs.) Length* (lbs.)

8

5

/

8

"

6 421⁄2 x 561⁄2 32 x 561⁄2 301⁄2 x 561⁄2 24 x 561⁄2 6111⁄2 100 645⁄8 100

7 50 x 661⁄2 371⁄2 x 661⁄2 36 x 661⁄2 281⁄2 x 661⁄2 7101⁄2 110 725⁄8 110

100 60 x 80 45 x 80 43 x 80 34 x 80 9 130 841⁄8 130

10 69 x 92 511⁄2 x 92 50 x 92 39 x 92 — — 941⁄8 135

10 72 x 96 54 x 96 52 x 96 41 x 96 1051⁄4 136 — —

11 78 x 104 581⁄2 x 104 56 x 104 441⁄2 x 104 1123⁄4 140 1041⁄8 140

150 87 x 116 65 x 116 63 x 116 491⁄2 x 116 1223⁄4 150 1141⁄8 150

Access MultiView

One screen, two formats.

Access MultiView—a motorized screen and independently motorized masking system provides dual format projection—all in a ceiling-recessed Access case.

U.S. Patent 6,137,629; 6,421,175;

6,532,109. Other patents pending.

Select a projection screen in HDTV or WideScreen format up to  wide. A flat black mask on a second motor-in-roller converts the screen to a NTSC video format by masking the right and left sides of the viewing surface. The height of the viewing surface remains constant.

Access MultiView/Series V—

Features Draper’s Tab Tensioning System for a perfectly flat projection surface. Choose M1300, M2500 or HiDef Grey. See page 14 for more on the benefits of Tab Tensioning.

Access MultiView/Series E—

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded, High Contrast Grey, or acoustically transparent AT1200 or AT Grey.

System Options

Extra Drop— black drop standard for all screens in both Series. Extra black drop available up to a total screen height of .

1.78:1 HDTV or 1.85:1 WideScreen

Black Masking Borders—Borders are standard for all screens in both Series.

Control Options—Screen and mask are independently controlled, each by a standard 3-position rocker switch. Options include a 24v, 6-button, single gang wall switch that controls both motors; two wireless IR remote controls; or two wall switches with built-in IR receivers and one transmitter.

1.33:1 NTSC

6

5

/

8

"

From 16:9 HDTV or From 1.85:1 WideScreen To 4:3 NTSC Video Series V Series E

Nominal Open Image Nominal Open Image Nominal Masked Image Case Net Wt. Case Net Wt.

Diagonal Area (16:9) Diagonal Area (1.85:1) Diagonal Area (4:3) Length* (lbs.) Length* (lbs.)

8

5

/

8

"

92 45 x 80 95 45 x 83 75 45 x 60 921⁄4 85 885⁄8 85

106 52 x 92 109 52 x 96 86 52 x 69 105 95 995⁄8 95

123 60 x 107 126 60 x 111 100 60 x 80 118 110 11

5⁄8

120

133 65 x 116 136 65 x 120 108 65 x 87 127 135 1195⁄8 145

*Extra drop, beyond the that is standard, increases length of case on Series V screens. Built-in controls will increase length of case.

www.draperinc.com 765-987-7999

9

Ceiling-Recessed Motorized Screens

10

Signature Series

Sizes through wide;

Automatic ceiling closure.

The Signature Series offers the clean appearance of a ceiling-recessed screen in any size through  wide.

White aluminum case. Signature’s independently motorized ceiling closure disappears into the case when the screen is lowered, for a perfectly unobstructed view. Hinges are completely concealed, and the closure is supported for its entire length—no sag is possible.

These exclusive features mean that the Signature

Series is the best-concealed projection screen you’ve ever seen. Screen can be remotely operated.

Signature/Series V—

Features Draper’s Tab

Tensioning System for a perfectly flat projection surface. Choose M1300, M2500, HiDef Grey or

Cineflex rear projection viewing surface. See page 14 for more on the benefits of Tab Tensioning.

Signature/Series E—

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded,

High Contrast Grey, Panamax or acoustically transparent AT1200 or AT Grey.

Signature/Series E: Radio One, Cincinnati. Installation by

NOR-COM, Inc.

U.S. Patent No. 5,341,241

System Options

• Extra Drop, Series V— black drop at top of image area is now standard on tab-tensioned screens.

Additional drop is optional, either white or black, up to  overall height (black is standard). *Additional drop will increase case and dowel length. Consult

Draper if this dimension is critical.

Complete Signature Series specifications: www.draperinc.com

Series E Series V

Size Case Net Wt. Case Dowel Net Wt.

HxW Length (lbs.) Length* Length* (lbs.)

• Extra Drop, Series E—Up to  overall height, either white or black

(white is standard for Series E in AV format; black for all other formats).

• Black Masking Borders—Borders are optional for Series E in AV format. Borders are standard for Series E in all other formats and for all

Series V screens.

• Control Options—Refer to page 22. Controls may be built into case and will increase the overall length of the case.

Series E Series V

Size Image Area Case Net Wt. Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length (lbs.) HxW Length* Length* (lbs.)

Audio Visual Format

50 x 50 483⁄8 52 56 5 63

60 x 60 563⁄8 63 65 511 75

70 x 70 643⁄8 75 73 610 84

84 x 84 763⁄8 84 861⁄4 8 98

72 x 96 863⁄8 98 95 9 109

96 x 96 863⁄8 109 973⁄4 911⁄2 110

7 x 9 963⁄8 122 1061⁄4 10 124

9 x 9 963⁄8 124 1091⁄2 102 125

8 x 10 1063⁄8 130 1173⁄4 1111⁄2 132

10 x 10 1063⁄8 132 1191⁄2 1133⁄4 136

9 x 12 1263⁄8 153 1391⁄2 132 156

12 x 12 1263⁄8 156 1411⁄2 1351⁄2 158

106 x 14 149 190 161⁄2 1533⁄4 240

14 x 14 149 192 1671⁄4 1591⁄2 250

12 x 16 169 215 1821⁄2 1751⁄2 260

16 x 16 169 216 — — —

Case dimensions: 3⁄4 high x 1⁄8 wide in sizes through  wide;  high x 1⁄8 wide in larger sizes. Mounting brackets extend 1⁄2 beyond each end of case.

9

1

/

8

"

9 1 /

8

"

9

3

/

4

"

Signature Series V

9

3

/

4

"

Signature Series E

NTSC Format (4:3)

6 421⁄2 x 561⁄2 563⁄8 70 421⁄2 x 561⁄2 61⁄2 561⁄2 75

7 50 x 661⁄2 643⁄8 75 50 x 661⁄2 6101⁄2 641⁄2 79

100 60 x 80 763⁄8 78 60 x 80 81 77 95

10 69 x 92 863⁄8 92 72 x 96 95 9 109

11 78 x 104 963⁄8 109 78 x 104 1021⁄4 98 122

150 87 x 116 1063⁄8 117 87 x 116 1121⁄4 1091⁄2 127

15 105 x 140 1263⁄8 132 108 x 144 1391⁄2 132 156

200 118 x 158 145 185 118 x 158 151⁄2 1453⁄4 199

210 126 x 168 151 190 126 x 168 161⁄2 1533⁄4 240

220 132 x 176 159 205 132 x 176 1681⁄2 15113⁄4 250

230 138 x 184 165 210 138 x 184 1761⁄2 1691⁄2 255

240 141 x 188 169 216 144 x 192 1821⁄2 1751⁄2 260

HDTV Format (16:9)

92 45 x 80 763⁄8 78 45 x 80 8 76 94

106 52 x 92 863⁄8 92 52 x 92 9 86 107

119 58 x 104 963⁄8 100 58 x 104 101 97 121

133 65 x 116 1063⁄8 109 65 x 116 111 107 126

161 79 x 140 1263⁄8 132 79 x 140 1321⁄4 128 150

184 90 x 160 145 185 90 x 160 153⁄4 1451⁄2 199

193 941⁄2 x 168 151 190 941⁄2 x 168 1583⁄4 1511⁄2 230

220 106 x 188 169 216 108 x 192 17101⁄2 172 240

WideScreen Format (1.85:1)

99 47 x 87 83⁄8 90 47 x 87 87 81 99

108 50 x 92 863⁄8 92 50 x 92 9 86 107

120 56 x 104 963⁄8 105 56 x 104 10 97 121

132 63 x 116 1063⁄8 109 63 x 116 111 107 126

162 76 x 140 1263⁄8 132 76 x 140 1321⁄4 128 150

182 861⁄2 x 160 145 185 861⁄2 x 160 153⁄4 1451⁄2 199

190 91 x 168 151 190 91 x 168 1583⁄4 1511⁄2 230

218 102 x 188 169 216 104 x 192 17101⁄2 172 240

www.draperinc.com 765-987-7999

7

9

/

16

"

Envoy

Motor-in-roller with ceiling closure.

The Envoy adds a touch of class to any presentation.

The screen is recessed in the ceiling and invisible when not in use. At the touch of a switch, an automatic ceiling closure opens and the screen appears. The ceiling closure can easily be finished to match the ceiling.

7

9

/

16

"

� � �

��

The Envoy operates smoothly and silently. The motor is mounted inside the roller on special vibration insulators.

The screen’s slender profile makes it easy to install above most ceilings.

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded, High Contrast Grey or Panamax.

System Options

• Extra Drop—Up to  overall height, either white or black

(white is standard for AV format, black for other formats).

• Black Masking Borders— Borders are optional for AV format screens and standard for all other format screens.

Standard Offset

Construction Construction

• Control Options—Refer to page 22.

���������������������

�����������

Don R. Daseke ’61 Boardroom in the Union Building at

DePauw University, Greencastle, IN.

Size Case Net Wt.

HxW Length (lbs.)

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

Audio Visual Format

50 x 50 55 60

60 x 60 63 70

70 x 70 71 75

84 x 84 83 80

72 x 96 93 85

NTSC Format (4:3)

6 421⁄2 x 561⁄2 461⁄2 x 591⁄2 63 70

7 50 x 661⁄2 531⁄2 x 691⁄2 71 75

100 60 x 80 64 x 831⁄2 83 80

10 69 x 92 73 x 96 93 85

11 78 x 104 83 x 108 103 105

HDTV Format (16:9)

92 45 x 80 49 x 831⁄2 83 80

106 52 x 92 56 x 96 93 85

119 58 x 104 62 x 108 103 100

133 65 x 116 69 x 120 113 115

161 79 x 140 84 x 144 133 125

96 x 96 93 100

7 x 9 103 105

150 87 x 116 92 x 120 113 115

15 105 x 140 109 x 144 133 125

WideScreen Format (1.85:1)

99 47 x 87 51 x 90 89 82

9 x 9 103 115

108 50 x 92 54 x 96 93 85

8 x 10 113 115

Mounting brackets extend 2 in length beyond ends of case. Center of mounting holes is 1⁄4 from each end

120 56 x 104 60 x 108 103 105

10 x 10 113 120

132 63 x 116 67 x 120 113 115

9 x 12 133 125 of case.

12 x 12 133 130

Ambassador

Complete Envoy and Ambassador specifications: www.draperinc.com

Direct–drive motorized screen with ceiling closure.

162 76 x 140 80 x 144 133 125

The Draper Ambassador is a direct-drive, heavy-duty, electrically operated screen designed specifically for recessed installation above any type of ceiling.

The Ambassador features a fully automatic ceiling closure, which totally conceals the screen when not in use. The ceiling closure can be finished by the contractor to match the ceiling. Your choice of a conventional viewing surface: fiberglass matt white, glass beaded or High Contrast Grey.

System Options

Size Case Net Wt.

HxW Length (lbs.)

• Extra Drop—Up to  overall height, either white or black (white is standard).

• Black Masking Borders—optional.

• Control Options—Refer to page 22.

9

7

/

8

"

10

1

/

4

"

Standard Construction

Audio Visual Format

50 x 50 62 105

60 x 60 7 115

70 x 70 710 120

84 x 84 9 140

72 x 96 10 155

96 x 96 10 160

7 x 9 11 160

Offset Construction

9 x 9 11 170

8 x 10 12 180

10 x 10 12 185

9 x 12 14 205

Extended Hinges for

Attachment of Ceiling Tile

12 x 12 14 210

(Wt. not to exceed 16 oz./s q. ft.)

Mounting brackets extend 4 in length beyond ends of case.

Belden Inc., Richmond, IN. Installation by MCSi,

Indianapolis, IN.

www.draperinc.com 765-987-7999

11

12

Ceiling-Recessed Motorized Screens

Rolleramic

Heavy-duty for big-screen presentations.

The Rolleramic comes in sizes through    or  diagonal to accommodate your biggest presentations. All-wood case may be recessed in the ceiling or painted to match its surroundings.

The viewing surface is concealed when not in use; lower it to any position at the touch of a switch. The direct drive module is mounted on rubber vibration insulators.

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded, High Contrast Grey or Panamax viewing surface.

System Options

• Extra DropUp to  total screen height, either white or black.

• Black Masking Borders—Borders are optional for AV format screens and standard for all other format screens.

• Triangular Shaped Steel Slat at bottom of projection surface. With screen recessed above ceiling, the triangular slat can be set to stop flush with the ceiling, for a clean installation.

• Universal Mounting Bracketsmay be suspended from above, or mounted to wall.

Two brackets supplied on screens up to   . Three supplied on larger screens.

• Control Options—Refer to page 22.

9

1

/

8

"

9

1

/

8

"

Indiana University

School of Law—Indianapolis

Size Case Net Wt. Size Case Net Wt. Size Case Net Wt.

HxW Length (lbs.) HxW Length (lbs.) HxW Length (lbs.)

Audio Visual Format

15 x 20 2010 440 18 x 24 2410 538

20 x 20 2010 450 24 x 24 2410 548

11 x 22 2210 484 13 x 26 2610 572

161⁄2 x 22 2210 494 191⁄2 x 26 2610 582

22 x 22 2210 504 14 x 28 2810 616

12 x 24 2410 528 21 x 28 2810 626

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

Audio Visual Format

50 x 50 62 90 9 x 9 11 * 140 12 x 16 186 240

60 x 60 7 95 8 x 10 12 * 150 16 x 16 186 245

70 x 70 710 105 10 x 10 12 * 155 136 x 18 206 290

84 x 84 9 120 9 x 12 14 * 175 18 x 18 206 320

72 x 96 10 130 12 x 12 14 * 180 8 x 20 226 310

96 x 96 10 135 106 x 14 166 210 15 x 20 226 350

7 x 9 11 * 135 14 x 14 166 220 20 x 20 226 380

Hangers extend 5⁄8 above case. *Cases will be 6 longer with a Panamax viewing surface.

NTSC Format (4:3)

6 421⁄2 x 561⁄2 461⁄2 x 591⁄2 7 95

7 50 x 661⁄2 531⁄2 x 691⁄2 710 105

100 60 x 80 64 x 831⁄2 9 120

10 69 x 92 73 x 96 10 130

11 78 x 104 83 x 108 11 * 135

150 87 x 116 92 x 120 12 * 150

15 105 x 140 109 x 144 14 * 175

200 118 x 158 123 x 162 16 210

20 141 x 188 146 x 192 186 240

250 148 x 198 153 x 202 194 285

25 177 x 236 182 x 240 226 350

Complete Rolleramic and Paragon specifications: www.draperinc.com

Paragon

Large projection screen through  wide.

Choose the Paragon for any setting where a very large screen is required. Sizes up to   , or 35 NTSC. Newly redesigned case of white extruded aluminum can be suspended anywhere, with controls wherever they’re needed. Your choice of a conventional viewing surface: fiberglass matt white or glass beaded.

System Options

• Extra Drop—Up to  total screen height, either white or black (white standard on AV format screens, black on all others).

• Endcap Ceiling Tile Flange Kit—

Extruded aluminum, finished white.

Includes hardware for attaching flanges to endcaps.

• Black Masking Borders— Borders are optional for AV format screens and standard for all other format screens.

• Wall Mount Bracket Kit—Includes hardware for attaching brackets to case.

• Ceiling Tile Flange for Case— length, with hardware for attaching it to case. Please divide length of case requiring trim (in feet) by  and round to next whole number to determine

Peeler Art Center Auditorium, DePauw University,

Greencastle, Indiana. Patent pending.

number of kits to order. Remember to order trim for both front and back of case if required.

• Control Options—Refer to page 22.

12"

Size Case Net Wt. Size Case Net Wt.

HxW Length (lbs.) HxW Length (lbs.)

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

NTSC Format (4:3)

25 177 x 236 182 x 240 2010 440

271⁄2 194 x 260 199 x 264 2210 484

30 212 x 284 217 x 288 2410 528

13

1

/

4

"

321⁄2 230 x 308 235 x 312 2610 572

35 248 x 332 253 x 336 2810 616

Optional wall-mounting brackets extend 13⁄4 beyond each end of case.

www.draperinc.com 765-987-7999

Wall-Mounted Motorized Screens

Artisan Series

Featuring hand-crafted cases in solid hardwood or plastic laminate.

Artisan Series projection screens complement the fi ne furniture in your conference room. They are enclosed in solid hardwood cases with a variety of finishes to match virtually any decor—or in sleek, con tem po rary plastic laminate. Quiet motor-in-roller op er a tion.

Artisan/Series V—

Features Draper’s Tab Tensioning System for a perfectly fl at projection surface. Choose

M1300, M2500 or HiDef Grey. See page 14 for more on the benefi ts of Tab Tensioning.

Artisan/Series E—

Your choice of a con ven tion al viewing surface: fi berglass matt white, glass beaded or High Contrast Grey.

System Options

• Case Styles—Hardwood cases are available in four styles, shown below.

• Case Finishes—Choose from seven hardwoods and fi ve laminates, be low.

Custom fi nishes are available.

• Extra Drop— black drop at top of image area is now standard on

Series V tab-tensioned screens. Additional drop is optional, either white or black. (White is standard for Series E in AV format. Black is standard for Series E in all other formats and for all Series V.) *Additional drop will increase case and dowel length. Consult Draper if this dimension is critical.

• Black Masking Borders—Borders are optional for Series E in AV for mat.

They are standard for all Series V screens, and for Series E in all other formats.

• Control Options—Refer to page 22.

Case Styles

6

3

/

8

"

Radius Rectilinear Traditional Bevel

These colors match as close ly as is possible on the printed page. Samples available for color match ing. Custom finishes avail able.

Solid Hardwoods

6"

Artisan/Series V with

Traditional Case Style

Photography by Barry Rustin, Evanston, IL.

5"

5

1

/

4

"

Artisan/Series E with

Rectilinear Case Style

Case Dimensions

A

B

D

Fabric width + C

A B* C D

Series E 5 51⁄4 12 6

Series V 6 63⁄8 —VARIABLE—

*Add 11⁄8 to height if case is to be bevel style.

Plastic Laminates (rectilinear case style only)

Natural Natural Light Medium Walnut Medium Mahogany

Maple Cherry Oak Oak Cherry

Series E Series V

Size Case Net Wt. Case Dowel Net Wt.

HxW Length (lbs.) Length* Length* (lbs.)

Audio Visual Format

50 x 50 52 50 615⁄8 5 55

60 x 60 6 55 73⁄8 511 60

70 x 70 610 60 7105⁄8 610 70

84 x 84 8 75 917⁄8 8 80

72 x 96 9 80 105⁄8 9 85

96 x 96 9 85 1033⁄8 911⁄2 90

Complete Artisan Series specifi cations: www.draperinc.com

White Beige Dove Grey Bur gun dy Black

Series E Se ries V

Size Image Area Case Net Wt. Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length (lbs.) HxW Length* Length* (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 6 55 421⁄2 x 561⁄2 675⁄8 561⁄2 60

7 50 x 661⁄2 610 60 50 x 661⁄2 757⁄8 641⁄2 70

100 60 x 80 8 70 60 x 80 873⁄8 77 80

10 69 x 92 9 80 72 x 96 105⁄8 9 85

HDTV Format (16:9)

92 45 x 80 8 70 45 x 80 871⁄8 76 80

106 52 x 92 9 80 52 x 92 975⁄8 876 85

WideScreen Format (1.85:1)

99 47 x 87 86 70 47 x 87 925⁄8 81 83

108 50 x 92 9 80 50 x 92 975⁄8 86 85

www.draperinc.com 765-987-7999

13

Wall-Mounted Motorized Screens

Premier

Perfectly flat viewing surface delivers perfect image clarity.

The Premier’s automatic Tab Tensioning System delivers incredible picture quality with its perfectly flat viewing surface. The Premier’s motor is mounted inside the roller on special vibration insulators, so its operation is smooth and silent.

Your choice of M1300, M2500, HiDef Grey or Cineflex rear projection viewing surface. See below for more benefits of Tab Tensioning.

System Options

• Extra Drop— black drop at top of image area is now standard on tabtensioned screens. Additional drop is optional, up to  overall height, either white or black (black is standard). Extra drop will increase the overall length of the case.

• Black Masking Borders—Standard for all formats.

• Projected Mounting Brackets—provides a  clearance.

• Ceiling Opening Trim Kit—for recessed installations.

Available for all sizes of Premier screens. Refer to page 15.

• Control Options—Refer to page 22.

Complete Premier specifications: www.draperinc.com

��

��

� � �

���������

����

7 /

8

" hole for electrical connection

��

��

��

� �

�������

�����������

�����������

����

� � �

S-hook for suspended installation

Fasteners for wall mounting by others

5

7

/

8

"

5

1

/

4

"

14

Size Case Dowel Net Wt.

HxW Length* Length* (lbs.)

Audio Visual Format

50 x 50 58 5 30

60 x 60 663⁄4 511 35

70 x 70 75 610 40

84 x 84 881⁄4 8 50

72 x 96 97 9 55

96 x 96 993⁄4 911⁄2 60

7 x 9 1081⁄4 10 70

9 x 9 1093⁄4 102 75

8 x 10 1193⁄4 1111⁄2 80

10 x 10 11111⁄2 1133⁄4 85

9 x 12 1393⁄4 132 90

12 x 12 1431⁄2 1351⁄2 100

Size Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length* Length* (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 62 561⁄2 35

7 50 x 661⁄2 71⁄4 641⁄2 40

100 60 x 80 813⁄4 77 50

10 72 x 96 97 9 55

11 78 x 104 1041⁄4 98 65

150 87 x 116 1141⁄4 1091⁄2 78

15 108 x 144 1393⁄4 132 90

HDTV Format (16:9)

92 45 x 80 811⁄2 76 50

106 52 x 92 92 86 58

119 58 x 104 102 97 65

133 65 x 116 113 107 75

161 80 x 140 1341⁄4 128 80

Tab Tensioning System

Our improved Tab Tensioning System has a sleek look. Draper changed the roller and attachment method, so no irregularities mar the smoothness of the viewing surface. The entire surface is flatter than ever before, and the dowel caps are now removable allowing you to adjust the surface flatness when necessary. Smaller tabs and a smaller diameter tension cable make the tensioning system less visible.

Tab Tensioning is preferred for perfect picture quality—the flatter the surface the clearer the image. Computer-driven data and graphics presentations, as well as large-screen video images, always look their best on a tensioned screen.

You’ll find these benefits on all Premier and Series V and C screen models: Signature, Access,

Ultimate Access, Access Sonata, Access MultiView, Premier, Silhouette, and Artisan.

Now standard with  of black drop at the top of the viewing area.

Size Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length* Length* (lbs.)

WideScreen Format (1.85:1)

99 47 x 87 89 81 55

108 50 x 92 92 86 58

120 56 x 104 102 97 65

132 63 x 116 113 107 75

162 76 x 140 1341⁄4 128 80

*Extra drop increases length of case and dowel.

Case may be recessed mounted. Dowel clearance for recessed mounting equals dowel length plus 1.

www.draperinc.com 765-987-7999

Targa

Motor-in-roller design for smooth, quiet operation.

Targa—for value and reliability. Draper’s motor-in-roller design allows viewing surface to be centered in its one-piece, white steel case for a trim, balanced appearance. The motor is mounted inside the roller on special vibration insulators, so operating noise is dramatically reduced.

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded,

High Contrast Grey, Panamax or acoustically transparent AT1200 or AT Grey.

System Options

• Extra Drop—Up to  overall height, either white or black (white is standard for

AV format, black for other formats).

• Black Masking Borders—Borders are optional for AV format screens and standard for all other format screens.

• Projected Mounting Brackets— clearance for wall-mounted equipment below screen.

• Ceiling Opening Trim Kit—for recessed installations. Available for all sizes of Targa screens. See below.

• Larger sizes now available.

• Control Options—Refer to page 22.

Spruce Grove Alliance Church, Spruce Grove, Alberta, Canada. Photo courtesy of Inland AV, Canada.

2

5

/

16

"

5

7

/

8

"

5

1

/

4

"

7

/

8

" dia. electrical connection hole

3

3

/

4

"

Fabric width + 7

1

/

2

"

Viewing surface

5

7

/

8

"

5

1

/

4

"

Size Case Net Wt.

HxW Length (lbs.)

Audio Visual Format

50 x 50 481⁄2 26

60 x 60 561⁄2 30

70 x 70 641⁄2 35

84 x 84 761⁄2  40

72 x 96 87 44

96 x 96 87 45

7 x 9 97 47

9 x 9 97 49

8 x 10 107 54

10 x 10 107 58

9 x 12 127 61

12 x 12 127 66

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 461⁄2 x 591⁄2 561⁄2 30

7 50 x 661⁄2 531⁄2 x 691⁄2 641⁄2 35

100 60 x 80 64 x 831⁄2 761⁄2 40

10 69 x 92 73 x 96 87 44

11 78 x 104 83 x 108 97 47

150 87 x 116 92 x 120 107 54

15 105 x 140 109 x 144 127 61

200 118 x 158 123 x 162 141 68

Case dimensions—5³/₁₆ high x 51⁄4 wide.

Hanging brackets extend 5⁄8 above screen case.

Complete Targa specifications: www.draperinc.com

Ceiling Opening Trim Kit

For ceiling-recessed Targa and Premier screens.

Trims out the opening and forms a finished slot in the ceiling allowing for passage of the viewing surface. Attaches to screen end caps. Painted white to match ceiling grid.

This accessory results in a professional, attractive ceiling-recessed installation.

Our finished slot is always flush, square, attractive and the same length as the screen case. Slot includes finished flange to accept acoustical ceiling tile or grid. Slot measures only 1⁄8 in width.

With Draper’s Ceiling Opening Trim Kit, the slot is always exactly the right size and in precisely the right location.

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

HDTV Format (16:9)

92 45 x 80 49 x 831⁄2 761⁄2 40

106 52 x 92 56 x 96 87 44

119 58 x 104 62 x 108 97 46

133 65 x 116 69 x 120 107 54

161 79 x 140 84 x 144 127 61

184 90 x 160 95 x 164 143 68

WideScreen Format (1.85:1)

99 47 x 87 51 x 90 81 40

108 50 x 92 54 x 96 87 44

120 56 x 104 60 x 108 97 49

132 63 x 116 67 x 120 107 54

162 76 x 140 80 x 144 127 66

182 861⁄2 x 160 911⁄2 x 164 143 68

���������

������������

����

������������

www.draperinc.com 765-987-7999

15

16

Wall-Mounted Motorized Screens

Salara

You’ve never seen a screen like this before.

In your home or office, the Salara makes a design statement.

The Salara’s small, elliptical case and domed endcaps are finished in solid white. Floating gunlatch, wall-mounting brackets grip the screen case securely and are barely visible. Power connection is via back of case.

The result—the most attractive screen you’ve ever seen.

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded, High Contrast Grey, AT1200 or AT Grey.

System Options

• Extra drop—Up to  overall height, either white or black (white is standard for AV format, black for other formats).

• Black masking borders—Borders are optional for AV format screens and standard for all other format screens.

Mounting

Brackets

Mounting

Brackets

11⁄2"

• Control options

Hardwired—Wired like other Draper motorized screens. Can be furnished with any standard control options.

11⁄2"

Wall

Hardwired with built-in RF receiver—This version includes a hand-held radio frequency remote control. Motor is hardwired like all standard Draper motorized screens. Wireless wall switch is optional.

Hardwired with built-in IR receiver—This version includes a hand-held infrared remote control. IR receiver is built into the endcap and includes additional interface for dry contact closure and RS232. Motor is hardwired like all standard Draper motorized screens.

Mounting

Brackets

1 1/2 "

Wall

313/16"

5/16"

Plug & Play

Version—With Draper’s all new Plug & Play option, you can have a remote controlled screen on your wall in just  minutes—no electrician required. Plug & Play includes a built-in receiver and hand-held transmitter in your choice of RF or IR. It also includes  of IEC cord, which plugs into socket in the back of the case and the nearest wall outlet.

Wireless wall switch is optional for RF version.

3/8"

Viewing Surface

3/8"

31/8"

51/16"

57/16"

13/8"

37/16"

Plug n' Play

Case Length

Floating

Mounting

Brackets

3/8"

5/16"

31/8"

51/16"

57/16"

Floating Mounting Brackets

Viewing Surface

311/16"

5/16"

13/8"

37/16"

Wall

Case Length

313/16"

5/16"

Back view of Salara case showing Plug

& Play option. Patent pending.

Hand-held RF remote control

5/16"

31/8"

313/16"

37/16"

51/16"

57/16"

Optional wireless wall switch.

Hand-held IR remote control

Size Case Net Wt.

HxW Length (lbs.)

Audio Visual Format

50 x 50 491⁄8 23

60 x 60 571⁄8 26

70 x 70 651⁄8 30

84 x 84 771⁄8 35

72 x 96 875⁄8 38

96 x 96 875⁄8 41

Complete Salara specifications: www.draperinc.com

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 461⁄2 x 591⁄2 571⁄8 25

7 50 x 661⁄2 531⁄2 x 691⁄2 651⁄8 29

100 60 x 80 64 x 831⁄2 771⁄8 34

10 69 x 92 73 x 96 875⁄8 38

HDTV Format (16:9)

92 45 x 80 49 x 831⁄2 771⁄8 32

106 52 x 92 56 x 96 875⁄8 37

WideScreen Format (1.85:17

99 47 x 87 51 x 90 815⁄8 34

108 50 x 92 54 x 96 875⁄8 37

Built into the endcap, Draper’s MC1 enables IR, additional interface for dry contact closure and RS232. Programmable.

5 1/16 "

3

13/16

"

www.draperinc.com 765-987-7999

Plug n' Play

Floating Mounting Brackets

313/16"

5/16"

Silhouette

High tech appearance.

We changed the appearance of projection screens with a revolutionary case design. The Silhouette’s case conceals everything:

• Mounting fixtures • Fasteners • Electrical connections

• Optional controls • Dowels retract inside case

The innovative case installs cleanly, and the front fascia removes easily for access to the inside components. Its slender fascia and endcaps are made of gently radiused aluminum and presents a strikingly modern appearance.

There is no need to conceal the Silhouette—it will complement the other high-tech equipment in your room.

Silhouette/Series V—

Features Draper’s Tab Tensioning System for a perfectly flat projection surface. Choose M1300, M2500, HiDef

Grey or Cineflex rear projection viewing surface. See page 14 for more on the benefits of Tab Tensioning.

Silhouette/Series E—

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded, High Contrast Grey or acoustically transparent AT1200 or AT Grey.

System Options

• Case Finishes—Choose a dove grey (standard), black or white lightly textured finish (see at right).

Lapham Hall, University of Wisconsin-Milwaukee. Installation by SPL

Integrated Solutions. Photography by Barry Rustin, Evanston, IL. U.S. Patent

Nos. 5,296,964 and 6,111,694.

Dove Grey

• Extra Drop— black drop at top of image area is now standard on Series V tab-tensioned screens. Additional drop is optional, either white or black. (White is standard for Series E in AV format. Black is standard for Series E in all other formats and for all Series V screens). Extra drop will increase the overall length of the case of a Series V screen.

• Black Masking Borders—Borders are optional for Series E in AV format. Borders are standard for Series E in all other formats and for all Series V screens.

• Control Options—Refer to page 22. Controls may be built into case and will increase the overall length of the case.

7

/

8

" holes for supply wires located on back and top,

2

1

/

2

" from left end of case.

Black

White

6"

4 3/4 "

Silhouette/Series V

4

3/4

"

D

Viewing Surface

6"

Mounting on optional

Extension

Wall Brackets

Silhouette

Series E

Series V

D

5

5

/

16

"

Varies

Silhouette/Series E

Series E Series V

Size Case Net Wt. Case Dowel Net Wt.

HxW Length* (lbs.) Length* Length* (lbs.)

Audio Visual Format

50 x 50 511⁄2 27 63⁄4 5 33

60 x 60 5111⁄2 29 6113⁄4 511 35

70 x 70 691⁄2 34 793⁄4 610 40

84 x 84 7111⁄2 40 91 8 46

72 x 96 9 48 9113⁄4 9 57

96 x 96 9 53 1021⁄2 911⁄2 59

*Built-in controls or extra drop may increase case and/or dowel length. Consult factory if this dimension is critical.

Complete Silhouette Series specifications: www.draperinc.com

Series E Series V

Size Image Area Case Net Wt. Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length* (lbs.) HxW Length* Length* (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 5111⁄2 26 421⁄2 x 561⁄2 671⁄4 561⁄2 39

7 50 x 661⁄2 691⁄2 31 50 x 661⁄2 751⁄4 641⁄2 43

100 60 x 80 7111⁄2 37 60 x 80 873⁄4 77 47

10 69 x 92 9 45 72 x 96 9113⁄4 9 54

HDTV Format (16:9)

92 45 x 80 7111⁄2 37 45 x 80 863⁄4 76 50

106 52 x 92 9 45 52 x 92 963⁄4 86 54

WideScreen Format (1.85:1)

99 47 x 87 86 38 47 x 87 913⁄4 81 47

108 50 x 92 9 45 50 x 92 963⁄4 86 54

www.draperinc.com 765-987-7999

17

18

Video Projector Lifts

Revelation

You won’t see or hear the projector.

The Revelation is totally different from traditional projector lifts and mounts. The Draper Revelation permanently conceals the projector—and its noise—above the ceiling at all times. Other products typically lower the projector into the room from a ceiling recess, or lift it into the seating area from a table hideaway.

You’ll be astonished by what you see—and don’t see—and

don’t hear—when your projector is mounted in a Revelation.

You won’t see or hear the projector—not before, during or after the show. You’ll only see a hinged door in the ceiling, finished in white baked textured powdercoat.

Available in two models, Revelation A and Revelation B both require only 5⁄8 of space above the ceiling, and both can be installed to match a    ceiling grid spacing, or used with reveal-style grid ceilings (like Armstong’s Silhouette-style grid system).

Draper upgraded the Revelation’s dual first surface mirror system to thicker (10 mm) optical grade glass mirrors that are

94% reflective for optimum flatness and reflectivity. A modification to both Revelations allows more space for the projectors and accommodates a wider variety of projectors, including those with offset lenses.

Combine the Revelation with a ceiling-recessed Draper projection screen and take your projection showmanship to a new level. The Revelation A and B are compatible with a wide variety of LCD/DLP projectors.

System Options

• Plenum Enclosure—Aluminum enclosure for use in return air plenum. Includes intake and exhaust fan system with  couplers for connection to ventilation ducts.

• Ceiling Access Door—A    hinged door provides access to the Revelation above a finished ceiling for cleaning, maintenance or repairs without having to damage the ceiling. Available with a white painted finish, or recessed to accept ceiling tile.

• Glass Shield—Made of anti-reflective glass and installed between the Revelation and the first surface mirror/ceiling closure. Reduces projector noise by an additional 80%, and prevents cigarette smoke, grease or other harmful substances from reaching the projector. Virtually none of the projected light is lost as it passes through the Shield.

• Control Options—Refer to page 22.

Draper Revelation projector mount and Access/E projection screen at DTE Energy,

Detroit. Dealer: City Animation, Troy, MI. Architect: Ford & Earl Associates, Inc.,

Troy, MI. U.S. Patent No. 6,379,012.

Complete Revelation specifications: www.draperinc.com

Revelation Model A Model B

Overall unit size (HWL)   1⁄4     1⁄4  

Required space above ceiling* 5⁄8  1⁄4   5⁄8  1⁄4  

Clearance below ceiling approx.  approx. 

Rough ceiling opening for motorized door 1⁄2  1⁄2 1⁄2  1⁄2

Capacity 100 lbs. 100 lbs.

Door’s downward travel distance approx.  approx. 

Travel time 9 sec. 9 sec.

Net weight 85 lbs. 90 lbs.

Projector space (HWL)—To fit within limits of inner pan. Request a planning sheet.

* 5⁄8 is overall height of Revelation with plenum housing ( without plenum).

Electrical Specifications

Operating voltage 110–120 vac 50–60 Hz

Amperes 1 Amp**

Control voltage 12 vac

Motor specifications: Voltage 110–120 vac 50–60 Hz

Amps .43

** Does not include any load placed on internal outlet.

Ceiling tile and hangers

(by ceiling contractor)

Adjustable projector pan

Typical single lens projector

(by others)

First surface mirror

Revelation pan

Trim piece

First surface mirror

(Light path continues to projection screen)

Ceiling closure

www.draperinc.com 765-987-7999

LCD Lift

Compact, lightweight lift fits most LCD/DLP projectors.

Bomb bay doors and a slim cross-section distinguish the LCD Lift. Most popular LCD/DLP/

LCOS projectors fit comfortably inside this unit. Available in two sizes—Model A and Model B.

Plenum housing of aluminum, with closure doors finished in white. Contains internal switched duplex receptacle, 115v ac, which is powered when the unit is fully down. The LCD Lift contains an innovative current sensor that delays closing of the unit until the projector fan has shut off.

Lifting capacity 65 lbs.

System Options

• Ceiling Closure Panel—Universal steel ceiling closure in a white baked enamel finish, or recessed to accept ceiling tile.

• Ceiling Access Door—A    hinged door provides access to lift above a finished ceiling for cleaning, maintenance or repairs without having to damage the ceiling. Available with a white painted finish, or recessed to accept ceiling tile.

A

LCD Model Model

Lift A B

A 24 29

B 173⁄4 223⁄4

C 18 23

D 11 16

A

C Aero Low Profile MountFixed mount attaches to projector lift and combines with Draper’s Aero Universal Projector Bracket for projectors weighing less than 26 pounds. Details on page 20.

B

D

C

For 1 /

2

" threaded rod

(supplied by others)

9

/

16

" dia.

mounting holes

• Factory installed cables for RGB, Video and Control.

• Control OptionsOperated by one 115v rocker switch. For more options, refer to page 22.

Complete LCD Lift and AeroLift 25 specifications: www.draperinc.com

AeroLift 25

With the smallest footprint and height.

Bomb bay door assembly standard.

Flat ceiling closure panel available.

The all-new and very cleverly designed AeroLift 25 has the smallest footprint and height of any video projector lift. It installs easily between standard  thick ceiling joists on  centers.

The AeroLift 25 will accommodate any LCD/DLP/LCOS projector weighing  pounds or less. It’s powered by a strong tubular motor for a simplified design, and features a stabilizing arm which can also be used for cable management.

Its built-in adjustability allows you to deal with job site conditions quickly and easily, like slightly out of square or irregularly spaced joists.

All components can be serviced from below. Projector can be mounted flush to bottom pan, or with Aero Low Profile Lift Bracket

(shown). Aero bracket enables instant registration of projected image.

The standard control for the lift is simple and easy to use. It can be integrated into other low voltage control systems. Note: The AeroLift



can also be used to recess speakers, security cameras, videoconferencing cameras or document cameras.

AeroLift 25

System Options

• Ceiling closure panel—Universal steel ceiling closure in a white baked enamel finish, or recessed to accept ceiling tile.

• Plenum housing—Height varies according to choice of projector. Includes ceiling trim ring. Does not include ceiling closure panel.

• Ceiling finish kit—Ceiling closure panel and ceiling trim ring to finish ceiling opening.

��������

���������

�� � �

�� � �

� � �

��

��

���

�� �

��

��

� �

� �

��

�� � �

LCD Lift shown (above) with standard bomb bay closure and (detail below) with optional flat closure. Dimensions in chart are based on standard closure.

Trim strip

LCD Lift

Ceiling closure panel

(shown slightly lowered)

Patent Pending

Height of lift in closed position 1 

Maximum overall lift dimensions (wxl) 1⁄4  

Ceiling opening (with small closure) 3⁄8  ¹⁄₁₆

Optional plenum housing (small size) (wxl) 2

Max. projector size (with small closure) (wxl)

⁹⁄₁₆  7⁄8

3 3⁄4  

Max. down travel 

Approx. travel time to lowest position  sec.

Total lift capacity (lbs.) 4 

Net weight of lift (lbs.) 5 

Amperes .

1 Not including projector, mount or closure. Optional Aero Low Profile

2

Mount adds 7⁄8 to height, including Universal Projector Bracket.

Maximum plenum height: 1⁄2. Min. plenum height: 1⁄2.

3 Maximum available projector/bracket height (with plenum): 3⁄4.

Minimum available projector/bracket height (with plenum): 3⁄4.

4 Small closure weighs 1⁄2 lbs. Large closure & angle brackets weigh  lbs.

5 Unit only: does not include projector, mount, plenum or closure.

www.draperinc.com 765-987-7999 19

20

Video Projector Lifts

Micro Projector Lift

Designed for today’s smaller projectors.

The Micro Projector Lift (MPL) is small and convenient, just like the projectors it is designed to accommodate. Weighing only 35 pounds, it can be installed in an existing    ceiling opening without disturbing ceiling framework.

All components can be serviced from below the unit. The projector’s “show” position can be set at any point—with infinite adjustability—up to  extension.

The Micro Projector Lift utilizes the same exclusive 3-scissor design as Draper’s popular

Scissor Lift, but features a compact side-folding scissor.

The load is lifted by two  wide Kevlar ® straps. Safety belt provides extra protection.

Closed height of lifting unit is only  tall (not including projector, mounting mechanism or closure), so a minimal amount of overhead ceiling space is required.

System Options

• Ceiling closure panel—Universal steel ceiling closure in a white baked enamel finish, or recessed to accept ceiling tile.

• Plenum housing—Height varies according to choice of projector. Includes ceiling trim ring. Does not include ceiling closure panel.

• Ceiling finish kit—Ceiling closure panel and ceiling trim ring to finish ceiling opening.

• Ceiling Access Door—A    hinged door provides access to the MPL above a finished ceiling for cleaning, maintenance or repairs without having to damage the ceiling.

Available with a white painted finish, or recessed to accept ceiling tile.

• Projector mounting bracket—The Aero Low Profile Mount is described below.

Projector may also be mounted flush to bottom pan.

• Factory installed cables for RGB, Video and Control.

• ControlsDescribed on page 22.

U.S. Patent No. D395,909 and 6,637,711.

Other patents pending

Micro Projector Lift

Height of lift in closed position 1



Overall lift dimensions (wxl)   3⁄4

Ceiling opening 1⁄2  1⁄2

Optional plenum housing (trim edge to trim edge ) 2 7⁄8  7⁄8

Max. projector size (wxl) 3   

Max. down travel 

Capacity (lbs.) 

Capacity with Aero Low Profile Mount (lbs.) 

Net weight of lift (lbs.) 

Amperes

4

.

1 Not including projector, mount or closure. Optional Aero Low Profile

Mount adds 7⁄8 to unit height including Universal Projector Bracket.

2 Max. plenum height: . Min. plenum height: 

3

Max. available projector/bracket height (with Plenum): 1⁄2

Min. available projector/bracket height (with Plenum): 1⁄2

4 Does not include any load placed on MPL’s pre-wired power cable.

21"

203⁄4"

Min. 5"

Max. 53"

Varies with projector/mount and room conditions

Kevlar

®

is a registered trademark of DuPont.

Aero Low Profile Mount

Attach your projector to the Micro Projector Lift, Scissor Lift, LCD

Lift or AeroLift 25 with the optional Aero Low Profile Mount. Provides easy release of projector, 360° rotation, 30° pitch and roll, with minimal head space between projector and pan. Available with Aero Universal Projector

Bracket for projectors under 26 pounds and designed for inverted mounting with threaded mounting holes.

3

/

16

"

3

3 /

8

"

4 7 /

8

"

5/16"

23/4"

33/8"

3/8"

www.draperinc.com 765-987-7999

Scissor Lift—SL Series

“Store, show and service” positions.

Draper’s Scissor Lift will retract your projector to ceiling level or above when not in use, then lower it to the exact projection and service positions you require. Draper factory sets all three positions—“store”, “show” and

“service”—to your specifications. Adjustments are easy after installation.

Scissors on the left, right and back sides of the unit stabilize the projector from any sway both laterally and front–to–back.

Scissor Lift models SL4–SL10 feature a small footprint:  w x 1⁄2 l.

Projector can be bolted directly to the lift’s bottom pan, or mounted with the optional Aero Low Profile Mount (see page 20). The movement of the pan is driven by a gearmotor with a powerful, reliable metal chain drive system. Each lift is equipped with a fail-safe inertial safety belt system, and a

Cable Management System that includes a pre-wired power cable on the back scissor, bringing 110v current right to your projector.

Operation is v; switching is 12v. Lifting capacity is  lbs.

Scissor Lift—SLX Series

Lowers projector up to !

Seven Scissor Lift models offer “service” positions ranging from  to .

A slightly larger footprint ( w x 1⁄2 l) allows for the extended travel with no loss of stability. Lifting capacity is  lbs.

Indiana University School of Law—Indianapolis.

U.S. Patent No. D395,909

Scissor Lift SL Series

Model Number SL4 SL5 SL6 SL7 SL8 SL9 SL10

Height of lift in closed position 1 1⁄8 1⁄8 1⁄8 1⁄8 1⁄8 1⁄8 1⁄8

Max. down travel (service position)       

Approx. travel time to service position  sec.  sec.  sec. 63 sec. 72 sec.  sec. 90 sec.

Net weight (lbs.) 120 125 130 135 140 145 150

Scissor Lift SLX Series

Model Number SLX11 SLX12 SLX13 SLX14 SLX15 SLX16 SLX17

Height of lift in closed position 1 3⁄4 3⁄4 3⁄4 3⁄4 3⁄4 3⁄4 3⁄4

Max. down travel (service position)       

Approx. travel time to service position  sec.  sec.  sec.  sec.  sec.  sec.  sec.

Net weight (lbs.)       

1

Only height of Scissor Lift in closed position. Overall height of projector, plus optional mount, plus optional ceiling closure, plus optional plenum housing adds to overall height of equipment installed above ceiling. Aero Low Profile Mount and Aero Universal Projector Bracket add 7⁄8 to height.

Optional Ceiling Closure Panels for SL & SLX Series—Universal steel ceiling closure, with a recess to accept ceiling tile, or with a smooth surface finished in white. Six sizes available. Select size based on maximum size of projector or other equipment being used. See specifications on the Web at http:// www.draperinc.com/Lifts_Mounts_Brackets/Scissor_Lift.htm.

System Options

• Ceiling closure panel—Universal steel ceiling closure in a white baked enamel finish, or recessed to accept ceiling tile.

• Plenum housing—Height varies according to choice of projector. Includes ceiling trim ring. Does not include ceiling closure panel.

• Ceiling finish kit—Ceiling closure panel and ceiling trim ring to finish ceiling opening.

• Factory installed cables for RGB, Video and Control.

• Decorative Cover—An accordion-action shroud that completely covers all 4 sides of the

Scissor Lift SLX above the projector. White cover conceals scissors in the “show” position. Detaches automatically at pan when lift extends to “service” position. Maximum extension of cover is . Compatible with optional Ceiling Closure Panels S, E, J and G.

• ControlsDescribed on page 22.

Additional Data

• Amperes: 2.6 (Does not include any load placed on Scissor Lift’s prewired power cable.)

• Show Position: Set at factory. Can specify at time of order.

• Max. projector height: Limited only by available space above the ceiling if recessed.

• Minimum clear space above finished ceiling:

Will vary according to height of projector and options selected.

www.draperinc.com 765-987-7999 21

22

Controls for Screens and Lifts

Controls for Motorized Screen and Video Projector Lifts

Single Station Control —

Standard with most Draper electrically operated screens and all Draper video projector lifts. One 3-position rocker switch: 115v for all motorized screens, LCD

Lift, AeroLift 25 and Micro Projector Lift; 24v for Revelation; one 3-position 12v toggle switch for

Scissor Lift (with momentary key switch for service position). Switch operation is maintained contact.

Complete with stainless steel cover plate. UL listed.

Standard switch for motorized screens, MPL,

Revelation and

AeroLift 25

115 Volt Multiple Station Controls —

Identical in appearance to Single Station Control, see above. Automatic override allows only one signal to reach the motor when switches are operated simultaneously.

Standard switch for LCD Lift

*Low Voltage Controls & —

Install switches everywhere they’re needed, add wireless transmitter

(below) or interface with a master control system. Three-button switches have neutral decorator face plates for flush wall mounting. The Low Voltage Control unit is also equipped with jacks for easy connection to Draper RF and IR receivers (see below). Wiring from control unit to switches or receivers is lightweight for 24 volt current.

Optional for all Draper motorized screens, except Access Sonata, and all Draper video projector lifts.

Standard switch for Scissor Lift

*Radio Frequency Remote Control & —

Hand-held transmitter.

3-button control lets you raise or lower screen or adjust format at any point. Receiver plugs into the Draper Low Voltage Control unit (required, see above).

*Infrared Remote Control & —

Infrared transmitter and receiver.

3-button operation for instant access to “up”, “down” and “stop” functions. Fully compatible with “learnable” IR master control systems. Receiver plugs into the Draper Low Voltage

Control unit (required, see above).

Key Operated Power Supply Switch —

Useful with any control system for a Draper electrically operated projection screen or a Draper projector lift—low voltage or



. Key switch mounts next to operating switch and controls power to it.

Locking Switch Cover Plate —

A 3-position control switch for limited access.

Cover plate and locking switch cover are brushed stainless steel. Two keys furnished. 115v only.

Key Operated 3-Position Switch —

Similar to Draper’s standard 3-position control switch, but requires a key for operation.  and low voltage style available. When used alone, a maintained contact switch is provided. With Low Voltage Control , a momentary contact switch is provided and the low voltage control functions as a latching relay, so the screen will operate all the way up or down when the switch is activated. Two keys furnished.

Individual/Group Control for more than one screen per room

The IGC-3N1 is a specialized low voltage control system designed for rooms with two or more motorized screens. Depending on the switches and remote transmitters that are ordered with the control, it is possible to operate screens in tandem, separately or both. Operates up to three motors individually or simultaneously.

IGC-3N1

*Video Interface Control

Operate a Draper video projector lift in tandem with a Draper motorized projection screen using the Video Interface Control. The VIC replaces the screen’s switch; for the projector lift, use the standard switch or any control described above. Touch the switch—or wireless remote control—and the video projector lift and projection screen descend. At the end of the presentation, flip the switch and the lift and screen will rise automatically. Not available for MPL and AeroLift 25. Model vic115 integrates screen operation with equipment with a

115v switched outlet. Models vic12 & vic6 interface screen operation with equipment featuring a 12v/6v output. The vic115, vic12 & vic6 may be purchased with an override switch (vic–os), permitting independent operation.

A VIC is not compatible with an LVC-III, built-in or otherwise.

VIC-115

*These optional controls may be factory-installed into the case of Access, Ultimate Access and Silhouette screens at no extra charge.

Built-in controls may increase length of case, except for the Ultimate Access series. Call for exact dimension if critical. Choose either an LVC-III with or without a wireless transmitter, or choose a VIC. LVC-III and VIC are not compatible on a single motor, built-in or otherwise. Both may be used in an Access MultiView, which has two independently controlled motors.

VIC-6 or VIC-12

Controls for Access Sonata

A programmable low voltage 6-button wall switch that Draper presets with four format settings is standard. Change to any format at the touch of one button! This switch is compatible with multiple stations and the optional Sonata IR remote control.

Sonata wall switch www.draperinc.com 765-987-7999

Aero Mounts for LCD/DLP Projectors

Aero Mounts &

Aero Accuset Mounts

For LCD/DLP projectors.

When the choice is to suspend your LCD or DLP projector from the ceiling, look to Draper as your single source for mounting hardware.

We’ve designed a full line of mounts that are sophisticated in appearance, functional in their abilities and installer-friendly.

Inspired Design

Draper mounts are designed specifically for today’s smaller LCD and

DLP projectors.

Function and Form

Aero Mounts (pages 26-27) and Aero Accuset Mounts (pages 24-25) combine stylish appearance with unique features, such as infinite height adjustment, built-in cable management and an infinitely adjustable ball joint for instant registration of the projected image.

Installer Friendly

The all-new Aero Universal Projector Bracket takes the guesswork out of projector bracket selection, and attaches to your projector in seconds. Its infinite adjustability enables you to quickly find and secure the projector’s center of gravity, so projector hangs level. And if you upgrade your projector, there’s no need to buy a new bracket.

Draper Aero Mount and Rolleramic projection screen. Earlham College,

Richmond, IN. Installation by MCSi, Indianapolis. Patent pending.

Aero Universal

Projector Bracket

Draper has solved the projector bracket problem with a bracket that fits virtually any LCD/DLP projector.* The Aero Universal

Projector Bracket is now standard on all Aero and Aero Accuset projector mounts.

The Aero Universal Projector Bracket is furnished with two sets of horizontal bracket arms—four long and four short—and four threaded vertical spacers. You can mix and match bracket arms as needed to fit your projector. Infinite adjustability both horizontally and vertically enables you to find and secure the projector’s center of gravity in seconds, so projector will hang level.

An Aero Universal Projector Bracket comes assembled with short bracket arms, but longer bracket arms (included) are interchangeable.

Mix and match with the various bolts and threaded vertical spacers

(included) as needed for your projector.

Attach an Aero Universal Projector Bracket to an LCD projector, and then to an Aero Mount or Aero Accuset Mount.

Bracket connects easily to the ball joint at the tip of both projector mounts.

*Any LCD/DLP projector designed for inverted mounting, with threaded mounting holes, weighing  pounds or less.

� � �

��

*

�������������������

��

Attach an Aero Universal Projector Bracket to a projector, and then to an Aero Mount or Aero Accuset Mount. www.draperinc.com 765-987-7999 23

Aero Mounts for LCD/DLP Projectors

Aero Accuset Mounts for

LCD/DLP Projectors

Fixed and adjustable length column mounts.

The Aero Accuset family of LCD/DLP projector mounts dramatically increases the number of installations you can address with Draper mounts.

Draper now has the solution for any installation—from flush ceiling mounting to  of drop. All mounts include the innovative Aero Universal

Projector Bracket* (see page 23). Aero Accuset has five options to choose from, depending on jobsite conditions and your own preferences—

Accuset Component Kit

Consists of Ceiling Plate, Bracket Adapter and Universal Projector

Bracket. You furnish 1⁄2 diameter NPT pipe in your required length. Pipe must be threaded on each end.

Build Your Own Aero Accuset Kit

Order just the pieces you need for your job requirements. Choose from

Ceiling Plate, Bracket Adapter, Extension Adapter, Aero Universal

Projector Bracket, 1⁄2 diameter NPT fixed pipe section in 12 available lengths (may be cut to fit at the job site and threaded on each end), and adjustable pipe sections in seven available ranges.

Aero Accuset Adjustable Mount

Consists of Ceiling Plate, two-piece telescoping NPT pipe ( diameter upper section and 1⁄2 diameter lower section) threaded and slotted on each end, in seven adjustable ranges from which to choose (see chart on page 25),

Extension Adapter, Bracket Adapter and Aero Universal Projector

Bracket.

Exclusive feature—This mount is infinitely adjustable within its specified range to place projector at the preferred height. A positive stop prevents separation of pipe, and the Extension Adapter locks the lower pipe in final position.

All Aero Accuset projector mounts offer infinite adjustment of the projector up to 30° pitch, 30° roll and 360° yaw. Adjustable mounts and fixed extension mounts (see below) provide built-in cable management. Draper’s

Aero Universal Projector Bracket fits any projector designed for inverted mounting with threaded mounting holes on bottom, and allows you to quickly find and secure the projector’s center of gravity. Maximum load is

26 pounds.

Aero Accuset Fixed Extension Mount

Consists of Ceiling Plate, Bracket Adapter, Aero Universal Projector

Bracket and one section of 1⁄2 diameter NPT pipe, threaded and slotted on each end, available in thirteen standard lengths (see chart on page 25).

Aero Accuset Low Profile Mount

Fixed mount for “low profile” ceiling installations with our Aero Universal

Projector Bracket. Places top of projector only 7⁄8 from ceiling (may vary slightly according to choice of projector). Ball joint adjusts infinitely up to

30° pitch, 30° roll and 360° yaw. For projectors less than 26 pounds.

24

*The Aero Universal Projector Bracket fits the vast majority of LCD/DLP projectors designed for inverted mounting, with threaded mounting holes, weighing 26 pounds or less.

Accommodates more than 90% of projector installations. If your projector requires a specific bracket, we will supply it. If unsure, refer to http://www.draperinc.com/Lifts_Mounts_

Brackets/AeroLCDBrackets.htm.

www.draperinc.com 765-987-7999

Aero Accuset

Adjustable Mount—

with Ceiling Plate

, two-piece telescoping

NPT pipe

, Extension

Adapter

Adapter

, Bracket

with cable management and Aero

Universal Projector

Bracket

.

Aero Accuset Fixed Extension Mount

Overall length includes: Ceiling Plate,

Bracket Adapter and Aero Universal

Projector Bracket.

Pipe Overall

Length* Length

Flush 101⁄2

6 141⁄2

12 201⁄2

18 261⁄2

24 321⁄2

36 441⁄2

48 561⁄2

60 681⁄2

72 801⁄2

84 921⁄2

96 1041⁄2

108 1161⁄2

120 1281⁄2

*Pipe length may be cut by installer to fit site requirements.

Aero Accuset Adjustable Mount

Overall length includes: Ceiling Plate,

Bracket Adapter and Aero Universal

Projector Bracket.

Column Overall

Length Length*

6–81⁄2 153⁄8–173⁄4

12–201⁄2 213⁄8–293⁄4

201⁄2–371⁄2 293⁄4–463⁄4

36–681⁄2 443⁄4–773⁄4

48–921⁄2 573⁄8–1013⁄4

60–1161⁄2 693⁄8–1253⁄4

72–1401⁄2 813⁄8–1493⁄4

*Assembled dimension tolerance: ±1⁄4.

Overall

Length

Overall

Length

Aero Accuset Ceiling Plate—

    5⁄8

(w x l x h) plate attaches to building structure or suspends with threaded rod.

Aero Accuset Fixed Extension

Mount—with Ceiling Plate section of 1⁄2 NPT pipe

, one

, Bracket

Adapter

with cable management and

Aero Universal Projector Bracket

.

Aero Accuset Bracket Adapter—

Attaches Aero Universal Projector

Bracket to 1⁄2 NPT pipe. Allows for cable management.

Optional Accessories

• Accuset Low Profile Suspended Ceiling Panel—Steel panel suspends from structure to fit within    ceiling grid. 3⁄4 

3⁄4

white panel provides  of overall lateral adjustment for precise projector placement, plus a ball joint for attaching an

Aero Universal Projector Bracket.

• Accuset Suspended-Ceiling Panel—Steel panel suspends from structure to fit within    ceiling grid. 3⁄4  3⁄4 white panel provides  of overall lateral adjustment for precise projector placement. 1⁄2 and  Aero Accuset pipe will attach directly to threaded opening.

• Accuset Angled Ceiling Plate—     (w x l x h) plate attaches to vaulted or angled ceilings. Adjusts from 0–25° allowing the projector to remain level. Must be used with Aero Accuset

Ceiling Plate.

• Security Lock Kit—While no system can guarantee complete security, the Security Lock Kit is an excellent deterrent, and designed to keep your projector safe and secure when mounted to an Aero or Aero

Accuset. Kit includes  cable, key lock,  loopers, flexible adhesive pad and microslot lock.

• Escutcheon Ring—Chrome ring trims the ceiling hole around your mount.

Aero Accuset Low Profile

Suspended Ceiling Panel

Accuset Angled

Ceiling Plate

Adhesive pad attached to projector.

www.draperinc.com 765-987-7999

Aero Accuset Suspended

Ceiling Panel

Microslot lock engaged.

Security Lock Kit

25

Aero Mounts for LCD/DLP Projectors

Aero Mounts for

LCD/DLP Projectors

Stylish column mounts.

Draper Aero Mounts complement the latest generation of

LCD and DLP projectors. But more than a shapely column,

Aero Mounts have innovative features that simplify installation procedures.

Adjustable steel ceiling mounting plate

has slotted screw holes for fine adjustments.

One screw

adjusts column pitch ±30°. Adapts to cathedral ceilings without special fixtures.

26

Telescoping extruded aluminum column

in your choice of 5 extension ranges.

Black powdercoat finish.

Inner column

is infinitely adjustable within the specified range. Loosen one concealed setscrew, lower to the exact extension you need and tighten the screw. Inner column has a mechanical safety stop to prevent it from disengaging from outer column.

Races for cable management

are concealed by “peel off” black moldings. Conveniently located on sides of the column. Hide almost any combination of cables without threading them through a column. Put cables into races after making connections to projector.

Orient your projector

quickly with the steel ball-in-socket located at tip of inner column. Provides instant registration of the projected image and adjusts up to 30° pitch,

30° roll and 360° rotation. Locks with a turn of two setscrews.

Aero Universal Projector

Bracket

attaches in just seconds to the mount’s steel ball joint with twist-lock engagement.

Projector-specific brackets

for projectors that do not have threaded mounting holes on the bottom, are not compatible with our Universal

Projector Bracket, but aren’t required to sit in a tray. Attach to any

Aero or Aero Accuset mount.

Projector Shelf

for projectors not designed for inverted mounting. Holds projectors up to 3⁄4   3⁄4   3⁄4

and up to 26 lbs. Provides platform for projector. Attaches to any Aero or Aero

Accuset mount.

www.draperinc.com 765-987-7999

Aero Adjustable Mount Dimensions

Model A(Min) B(Max) C

1214-N 133⁄8 153⁄8 2

2030-N 211⁄4 311⁄8 97⁄8

2636-N 271⁄4 371⁄8 97⁄8

3444-N 351⁄8 45 97⁄8

4252-N 43 527⁄8 97⁄8

Maximum load—26 pounds

Adjustability Pitch Roll Yaw

At ceiling plate ±30° 0° 0°

At ball joint ±30° ±30° 360°

� � �

��

� � �

� � �

� � �

Aero Adjustable Mount—

with adjustable ceiling plate

, telescoping column

, steel ball-in-socket

and Aero

Universal Projector

Bracket

.

Aero Model 4–N Mount

Fixed extension mount for installations close to the ceiling with our Aero Universal Projector

Bracket. Places top of projector only 3⁄8 from ceiling. (May vary slightly according to choice of projector, and choice of mounting technique.)

Steel ceiling mounting plate has slotted screw holes for fine adjustments. Unique ball joint with twist-lock engagement installs in seconds and locks in place. Ball joint adjusts infinitely up to 30° pitch, 30° roll and 360° rotation.

For projectors weighing less than 26 pounds.

Aero Model 4–N Dimensions

� � �

Aero Low Profile Mount

Fixed mount for “low profile” ceiling installations with our Aero Universal Projector Bracket. Places top of projector only 7⁄8 from ceiling (may vary slightly according to choice of projector).

Ball joint adjusts infinitely up to 30° pitch, 30° roll and 360° yaw.

For projectors less than 26 pounds.

Dimensional Drawings: Aero Low Profile Fixed Mount

3 3 /

8

"

3/16"

*

*47/8"

3 /

8

"

5 /

16

"

2

3

/

4

"

Optional Accessories

• Escutcheon Ring—Flexible ring trims the rough cut of the ceiling through which the

Aero or Aero Accuset column descends. Shaped to fit outer column. Provides a clean finish to your installation. Black

Escutcheon Ring pictured at left is form fitted for the Aero

Mount. Adhesive tabs included.

Chrome rings are available for 1⁄2 and  diameter Aero

Accuset mounts.

• Escutcheon Clips—Black clips are available to trim the rough cut of the ceiling through which the Aero’s inner column descends. Snaps against inner column. Provides a nice, neat finish to your installation.

www.draperinc.com 765-987-7999 27

Aero Mounts for Plasma Displays

28

Aero Mounts for

Plasma Displays

Whether you choose to suspend your plasma display from the ceiling or mount it to the wall, look to Draper as your single source for mounting hardware. We’ve designed a full line of mounts that are sophisticated in appearance, functional in their abilities and installer-friendly.

Inspired Design

As plasma displays become more prevalent in work and home environments, the importance of a good looking

“mount” increases. Our sophisticated design incorporates cutting edge technology to harmonize with today’s displays.

Function and Form

Aero Mounts combine high-tech appearance with functional features: unique Slide Mounting System; universal and display-specifi c mounting brackets; height adjustments; and on most models—built-in cable management, rotation, tilt, monitor orientation, concealed power outlets and adjustable shelves.

Installer Friendly

The keystone-shaped Aero Slide Mounting System makes mounting your display as easy as hanging a picture, and as stable as the wall or ceiling it’s attached to. Moving or upgrading your display is easy. Our Security Lock Kit is an excellent theft deterrent. Plus, the addition of the new

Universal Plasma Bracket takes the guesswork out of ordering a mounting bracket (see at right).

Exclusive Aero Features

• Aero Slide Mounting

System—Each Aero

Mount con sists of an at trac tive and sturdy mount de signed for wall, ceil ing or fl oor mount ing, and an

Aero Universal

Plasma Bracket

(or plasma-specifi c bracket) which bolts to the back of the plas ma mon i tor. The brack et has a large keystone shaped plate, which slides into a uni ver sal mat ing bracket on the Aero mount. Once in place, the bracket is secured with lock devices. The slide system is universal to all Aero brackets and mounts, so it’s easy to move your display from one venue to another. If you buy a new display, you don’t have to buy a new mount.

• Cable Management—Conceal cables inside the col umn. A dis crete channel is provided for cable passage; cables are kept in their chan nel with a simple clip.

Installation location courtesy of Vectren Corporation. Installation by Data Projections, Inc.

Complete Aero Mounts for Plasma Displays specifi cations: www.draperinc.com

Universal Plasma Bracket

Draper has solved the problem of choosing a mounting bracket to fi t the variety of plasma displays on the market today—with the innovative Universal Plasma

Bracket. The Aero Universal Plasma Bracket attaches to almost any plasma display through  diagonal and under 100 lbs. No need to order a plasma-specifi c bracket.

Specially shaped keystone plate works for both portrait and landscape installation on any Draper Aero Mount for

Plasma Displays—ceiling, fl oor, wall or mobile. Assembled bracket is less than one inch deep, fi nished in black powdercoat.

Each Aero

Universal Plasma

Bracket comes with a full set of screws, washers, extenders, spacers, extension plates and extension arms to fi t virtually any plasma model.

Patent pending.

Aero Universal Plasma Bracket in landscape orientation

Aero Universal

Plasma Bracket in portrait orientation

A full set of hardware to fi t virtually any plasma model is included www.draperinc.com 765-987-7999

Aero Wall Mounts for Plasma Displays

Basic Tilt Wall Mount

The Basic Tilt has an extremely low profi le, protruding only  from the wall (not including a universal or plasma-specifi c bracket). Mount any plasma display fl at to the wall or tilted up to °. Formed of heavy gauge steel, the Aero Basic Tilt attaches to two wall studs on  centers, with two installation points per stud. The tilting mechanism locks into place. Maximum capacity  lbs. Handles displays up to  diagonal. A safety lock secures the display in the bracket. Finished in black powdercoat and includes the Draper Universal Plasma Bracket.

3Dimension Wall Mount

The 3Dimension provides complete fl exibility in positioning your plasma display. Folded fl at, it’s just  from the wall. Yet it fl oats easily to any position up to  away from the wall. Pull it out, move it left-to-right and tilt it forward (up to °)—in any combination!

This mount is an excellent choice for corner installations. Supports one plasma display with complete stability and safety, in either portrait or landscape orientation. Maximum capacity  pounds (most  and  displays). Finished in black powdercoat and includes the Draper Universal Plasma Bracket.

V4 Wall Mount

The Aero V4 articulating wall mount swivels and rotates the display in all directions, limited only by the wall. The Aero V4 swivels at both the wall and bracket support, so you can position the display fl ush against the wall when not in use. Extends the plasma display up to  from the wall. Display can be tilted up to ° and rotated °. Swivel

±° (depending on size of display). Maximum capacity  lbs. Handles displays up to  diagonal. Formed entirely of heavy gauge steel, fi nished in black powdercoat and includes the Draper Universal Plasma Bracket.

W490 and W1150 Wall Mounts

Mount plasmas on attractive extruded aluminum columns with built-in cable management system and concealed 2-socket electrical panel. Column attaches to wall with heavy gauge steel mounting plates, and enables display to be rotated °. Display can be mounted either horizontally or vertically and tilted up to °. Maximum capacity  lbs. Handles displays up to  diagonal. Finished in black powdercoat and includes the Draper

Universal Plasma Bracket.

W490 is a  column and holds one plasma.

W1150 is a  column and holds up to two displays and optional shelves. The plasma can be raised or lowered over a 1⁄2 range in



increments. Optional shelves for VCR, DVD player, amplifi er and related equip ment available in black or grey.

W/F2000 Wall-to-Floor Mount

This innovative mount features a  extruded aluminum column which attaches to the wall and fl oor with sturdy steel swivel brackets. Mount up to three plasma displays horizontally, or either one or two vertically, depending on display sizes. Displays can be raised or lowered over a  range in  increments. Two lock devices secure each display in its bracket. Column has a built-in cable management system and concealed 2-socket electrical panel. Displays can be tilted up to ° if mounted horizontally; ±° swivel left-to-right. Maximum capacity  lbs. Entire weight of the mount is supported by the fl oor. Handles displays up to  diagonal. Finished in black powdercoat and includes the

Draper Universal Plasma Bracket. Optional shelves for VCR, DVD player, amplifi er and related equip ment available in black or grey.

Basic Tilt

3Dimension

W1150 with a plasma display and an optional shelf

V4

W490

W/F2000 www.draperinc.com 765-987-7999 29

30

Aero Mounts for Plasma Displays

Aero Ceiling Mounts for Plasma Displays

C Basic Ceiling Mount

C Basic

Quickly and safely install Draper’s C Basic pipe-style plasma mount to the ceiling or above it. Attach a Universal Plasma Bracket to the back of the plasma and slide its keystone-shaped plate onto the C

Basic’s universal mating bracket.

C490

Allows up to  of vertical adjustment in  increments. Display can be tilted up to ° and has ° rotation. Maximum capacity is  lbs. and handles displays up to  diagonal. Column has built-in cable management system—cables run inside the column. Finished in black powdercoat and includes the Draper

Universal Plasma Bracket.

C490 and C1150 Ceiling Mounts

The C490 suspends a single plasma display from a  long extruded aluminum column mounted to a heavy gauge steel ceiling bracket. Ceiling bracket swivels to permit a complete ° horizontal rotation, and display can be tilted up to °. Display can also be raised and lowered on column over a  range in  increments. For screens up to  diagonal, the display’s center-line can be 5⁄8 to 1⁄2 from the ceiling bracket. For screens  diagonal and larger, the display’s center-line can be 3⁄4 to 5⁄8 from the ceiling bracket.

The C1150 is similar to the C490 but offers a  long column. Display can be raised or lowered over a  range in  increments. For screens up to  diagonal, the display’s center-line can be 595⁄8 to 1⁄2 from ceiling bracket. For screens  diagonal and larger, the display’s center-line can be 3⁄4 to 5⁄8 from bracket.

For both the C490 and C1150, the maximum capacity is 165 lbs. A multi-socket electrical panel is concealed in the back of the column. Finished in black powdercoat and includes the Draper Universal Plasma Bracket.

CD490 and CD1150 Dual Ceiling Mounts

Both the CD490 and CD1150 suspend two plasma displays, back-to-back.

The CD490 suspends two plasma displays from a  long extruded aluminum column mounted to a heavy gauge steel ceiling bracket. Ceiling bracket swivels to permit a complete



° horizontal rotation. Display can be tilted up to °, raised or lowered on column over a



range in  increments. For all screen sizes, the display’s center-line can be 1⁄8 to  from the ceiling bracket.

The CD1150 offers a  long column. Display can be raised and lowered over a  range in  increments. For all screen sizes, the display’s center-line can be 1⁄4 to  from bracket.

For both the CD490 and CD1150, the maximum capacity is 325 lbs. A multi-socket electrical panel is concealed in the back of the column. Finished in black powdercoat and includes the

Draper Universal Plasma Bracket.

T4 Ceiling Mount

Install a plasma with the top of the image virtually fl ush with the ceiling line. Complete ° rotation and up to ° of tilt are standard. A separate “above the ceiling” mounting bracket is available for structural support with a suspended ceiling installation—or it may be exposed in rooms with higher ceilings. This extension bracket adjusts from 1⁄2 to 1⁄4 long. Maximum capacity  lbs. Finished in black powdercoat and includes the Draper Universal Plasma

Bracket.

T4

CD1150

T4 with adjustable upper bracket

C/F3000

C/F3000 Ceiling-to-Floor Mount

The Aero C/F3000 features a  extruded aluminum column with sturdy steel swivel mounts for attachment to ceiling and fl oor. A built-in ± height adjuster makes the Aero C/F3000 installer friendly, and it can also be shortened in the fi eld if desired. Mount up to three plasma displays horizontally or two vertically. Displays can be raised or lowered over a  range in  increments. Two lock devices secure each display in its bracket. Column has a built-in cable management system and concealed 2-socket electrical panel. Displays can be tilted up to ° if mounted horizontally; ±° swivel left-to-right. Maximum capacity is  lbs. Entire weight of the mount is supported by the fl oor. Handles displays up to  diagonal. Finished in black powdercoat and includes the Draper Universal Plasma Bracket. Optional shelves for VCR,

DVD player, amplifi er and related equip ment available in black or grey.

www.draperinc.com 765-987-7999

Mobile Mounts

Mobile 1450

The Mobile 1450 offers instant port a bil i ty of your plasma display. A wide track tubular steel base and  swivel casters enable safe, easy move ment from room to room.

The plasma display mounts onto a sturdy 3⁄8 high ex trud ed alu mi num column.

Standard height setting places center of display image ap prox i mate ly 3⁄4 off the fl oor. Display can be raised or lowered over a  range in  in cre ments. Col umn has the Aero built-in cable man age ment system. Display can be mounted either horizontally or vertically.

Optional base shelf and adjustable column shelves provide for VCR, DVD player, amplifi er and related equipment. Available in black or grey. See below.

Floor Stand

Mobile Mount

Mobile 2000

The Mobile 2000 is identical to the Mobile 1450, just taller. The extruded alu mi num column is 1⁄8 high. Standard height setting places center of dis play image approximately 3⁄4 off the fl oor. Display can be raised or lowered over a



range in  increments.

For both the Mobile 1450 and Mobile 2000, maximum capacity is  lbs.

Handles displays up to  diagonal. Column has a built-in cable management system. Finished in black powdercoat and includes the Draper Universal

Plasma Bracket.

Optional Accessories

Floor Stands

F1450

Well-balanced shape and weighted base ensure a stable and safe platform for even the largest plasma display. Base is 1⁄8 wide x 1⁄2 deep. Display mounts onto a sturdy extruded aluminum column. Total height is 1⁄2. Column has a  range of vertical adjustment. At the highest setting, the display’s center-line is 3⁄4 above the fl oor, regardless of screen size.

Table Stand

• Adjustable Shelves—Optional grey or black shelves, 3⁄8 wide x 5⁄8 deep.

Shelves can hold up to 22 lbs. each and ac com mo date a variety of pe riph er als.

A positive locking clip keeps shelves securely at tached. Shelf height may be ad just ed in  in cre ments.

F2000

Same as above, except total height of stand is 1⁄8 with  of vertical adjustment. At the highest setting, the display’s center-line is

3⁄8 above the fl oor, regardless of screen size.

• Security Lock Kit—While no system can guarantee complete security, the Security Lock Kit is an excellent deterrent. Use with plasma, DVD, VCR, amplifi er and other related equipment.

Kit includes  cable, key lock,  loopers, fl exible adhesive pad and microslot lock.

For both the F1450 and F2000, maximum capacity is  lbs.

Handles displays up to  diagonal. Column has a built-in cable management system. Finished in black powdercoat. Mount display either horizontally or vertically with the Universal Plasma Bracket

(included). Optional adjustable column shelves (available in black or grey) hold related equipment.

Table Stand

• FPD Adapter—Aero FPD

Adapter allows you to convert any Aero Mount for Plasma

Displays into a mount for LCD/

TFT fl at panel displays. Mounting plate fi ts any LCD/TFT fl at panel display with a  mm or  mm mounting hole pattern. Maximum weight capacity  lbs.

Adjustable

Shelves

Security Lock Kit

The Aero Table Stand allows for easy placement of a plasma display on a table or credenza for trade shows, offi ce or board-rooms. Its modern design complements the sleek proportions of any plasma display.

• Base Shelf—Optional widetrack grey or black base shelf for Aero Mobile

Mounts. 3⁄4 wide x 7⁄8 deep.

FPD Adapter

The Table Stand’s well-balanced shape and weighted base ensure a stable and safe platform for even the largest plasma display. It stands

3⁄8

high. The base is  wide x 1⁄4 deep.

Maximum capacity is  lbs. Handles displays up to  diagonal.

Column has a built-in cable management system. Finished in black powdercoat and includes Draper’s Universal Plasma Bracket.

Base Shelf for

Mobile Mounts www.draperinc.com 765-987-7999 31

Aero Mounts for Flat Panel Displays

Aero FPD Ceiling Mounts

Aero Flat Panel Display (FPD) Ceiling Mount

Attractive, telescoping column of natural anodized aluminum for suspending

LCD flat panel displays from the ceiling. Quickly and safely install Draper’s Aero

FPD Ceiling Mount to the ceiling or above it. With the exclusive Aero Slide

Mounting System, just attach an FPD Bracket to the back of the monitor and slide it onto the column’s keystone-shaped plate.

Available in five lengths—each infinitely adjustable within the specified range (see chart at right). ° of tilt at the ceiling plate. -° of tilt at the display bracket. ° of rotation.

Column has built-in cable management system. FPD Bracket (included) fits both

VESA

 mm and  mm mounting hole patterns on LCD and TFT panels.

Maximum weight capacity  lbs.

Aero FPD C800

The Aero FPD C800 ceiling mount has a column length of 1⁄2. Display can be positioned anywhere along the column. Multiple LCD flat panels can be mounted to column using the

Multi-Panel Bracket. Holds up to

4 displays. Built-in cable management in side of column exits the column through the ceiling plate. Maximum weight capacity 88 lbs.

FPD C800

Ceiling Mount with single display.

The FPD C800 includes one Multi-Panel

Bracket and VESA ™  mm or  mm plate. Allows ±9° of rotation and

±° of tilt.

The FPD C800 can be inverted and permanently mounted to a table.

Cable Management is a simple task with the Aero FPD

Ceiling Mount.

FPD C800 Ceiling

Mount holds up to

displays using the

Multi-Panel Bracket.

Adjustable range—from display’s

Model center-line to ceiling bracket

FPD1214 101⁄4—123⁄8

FPD2030 16—26

FPD2636 24—34

FPD3444 32—42

FPD4252 40—50

Complete Aero FPD Mount specifications: www.draperinc.com.

32

Aero FPD Table Mounts

Aero FPD T400

The Aero FPD T400 is the latest permanent tablestand for small screen displays. Perfect for receptions, hotels, shops and any kind of information counter. Very stable when mounted on a surface.

Column length is 3⁄4. Built-in cable management in side of column exits the column through the mounting plate.

Includes one Multi-Panel Bracket and VESA

 or  plate.

Allows ±° of rotation and ±° of tilt.

Display can be positioned anywhere along the column. The

Aero FPD T400 is designed to be permanently mounted to table or solid surface. It can be used with Aero FPD Clamp (see page

32) to attach to side of table or solid surface for a non-permanent installation. It can also be inverted and mounted to the ceiling— making it a shorter ceiling mount than the FPD C800.

The Aero FPD T400 holds displays weighing up to  lbs.

Multiple flat panels can be mounted to the column opposite each other using the Multi-Panel Bracket.

www.draperinc.com 765-987-7999

Aero FPD T400-3D

The Aero FPD T400-3D is the same as the T400 but also includes the extension arm from the Aero

FPD 3Dimension Light. Extension arm provides for about  of extension from the T400-3D column. Holds LCD displays weighing up to  lbs.

Aero Flat Panel Display Wall Mounts

Aero FPD Wall Infi nite Mount Aero FPD Wall AT Mount

The monitor can be angled or tilted. Back of

Rotate, tilt or angle your display at will, while placing the back of your monitor only  from the wall. Silver lacquer your display is only 1⁄8 from the wall.

Silver lacquer fi nish. ° tilt up and down; fi nish. Ball joint allows ° adjustment in all directions. Exclusive Aero Slide



° rotation left to right. Exclusive Aero

Slide Mounting

Mounting

System. FPD

System. FPD

Bracket included.

Bracket included. Max.

Max. weight capacity:

 lbs.

weight capacity:



lbs.

Aero FPD Wall Mount

The bracket cannot be tilted or angled, but the display is only 5⁄8 from the wall. Silver lacquer fi nish.

Exclusive Aero Slide Mounting

System. FPD Bracket included.

Max. weight capacity:  lbs.

Aero FPD Bracket

The Aero FPD Bracket is included with all FPD ceiling and wall mounts.

This universal bracket attaches to all display panels with a VESA ™

75 mm hole pattern

100 mm hole pattern



mm or  mm mounting hole pattern. The bracket measures 3⁄8 square. With the exclusive Slide Mounting System, just attach an

FPD Bracket to the back of the monitor and slide it onto the mount’s keystone-shaped plate.

Aero FPD W800/W1200

Both the FPD W and W are the perfect partners for creative displays mounted to the wall. Column lengths are 1⁄2 and 1⁄4 respectively, and have built-in cable management.

Each mount includes one Multi-Panel Bracket and VESA

 mm or  mm plate. Allows

±° of rotation and ±° of tilt. The fl at panel display can be positioned anywhere along the column. Maximum weight capacity is 88 lbs.

Attach optional shelves to hold a DVD player, additional equipment, etc. Multiple fl at panels can be mounted to the column using the

Multi-Panel Bracket.

Aero FPD 3Dimension Light

The Aero FPD 3Dimension

Light provides complete fl exibility in positioning your LCD display. The articulating arm extends the display up to  from the wall and allows ±° of rotation and ±° of tilt.

The mount supports one LCD display with complete stability and safety, in either portrait or landscape orientation with VESA ™  mm or  mm mounting holes. Maximum weight capacity is  lbs.

Aero Flat Panel Display Accessories

Aero FPD Multi-Panel Bracket

The Aero FPD Multi-Panel Bracket is used when you want to mount more than one LCD display to any of the Aero FPD column mounts. It attaches to the side of the column. Brackets can be mounted on either side of column so displays are directly opposite each other. It allows ±° of rotation and ±° of tilt.

Includes mounting plate for VESA™  mm x  mm or  mm x  mm mounting hole pattern.

Aero FPD Clamp

The FPD Clamp allows non-permanent attachment of the FPD T400 mount to the side of a table or solid surface. It can also be used to convert the T400 to a suspended mount—clamping to a pipe or truss up to 1⁄2 diameter or 1⁄8 thick table or solid surface. It replaces the standard mounting plate that ships with the Aero FPD T400.

Aero FPD 3D Arm

The Aero FPD 3D Arm is an extension arm exactly like the one on the

Aero FPD 3Dimension Light.

Mounts to any of the columns and provides articulating capabilities.

Aero FPD Acrylic Shelf

Clear adjustable shelf can be attached to the column of the FPD W800, W1200 or

C800 mounts. Has green tint when viewed from edge of shelf. Shelf holds up to  lbs.

Aero FPD Black Shelf

Black adjustable shelf can be attached to the column of the FPD W800, W1200 or

C800 mounts. Shelf holds up to  lbs.

www.draperinc.com 765-987-7999 33

Permanently Tensioned Screens

Onyx

Quick and easy assembly plus adjustable surface tension—without snaps!

You can have a beautifully framed image hanging on the wall in just 10 to 15 minutes—assembly is that easy!

An attractive frame and a new fabric tensioning system make

Onyx the leader in permanently tensioned screens. The  wide beveled, extruded aluminum frame interconnects on site with one simple hand tool that Draper provides. Each side piece slip fits tightly to injection molded plastic corners, forming perfectly mitered edges.

A radical new approach to fabric attachment will amaze even the toughest of critics. There are no snaps! Uniform tension is applied to the entire surface area, so the surface is perfectly flat. Unique fabric retention system enables you to adjust the surface tension

(up to 1⁄2) in just seconds, without tools.

System Options

• Viewing Surfaces—M1300, M2500, HiDef Grey, acoustically transparent AT1200 or AT Grey for front projection or Cineflex rear projection vinyl.

• Custom Sizes—Available up to    image area depending on viewing surface.

• Frame Finishes—Black aluminum is standard.

Cover the frame with optional velvety black textile,

Vel-Tex, to eliminate reflections.

Mounting—Permanent wall mount

(brackets included).

Draper’s Onyx. Patent Pending. Installation by Fullhouse Media Solutions, Inc., Atlanta, GA.

Photography by Ed Wolkis, Atlanta, GA.

Injection molded plastic corners, form perfectly mitered edges.

34

Standard Onyx Sizes

Nominal Image Area Overall Size Net Wt.

Diagonal H x W H x W (lbs.)

Audio Visual Format

50 x 50 58 x 58 27

60 x 60 68 x 68 32

70 x 70 78 x 78 37

84 x 84 92 x 92 44

96 x 96 104 x 104 50

9 x 9 116 x 116 56

10 x 10 128 x 128 63

NTSC Format (4:3)

6 43 x 57 51 x 65 27

61⁄2 47 x 63 55 x 71 30

7 50 x 67 58 x 75 31

71⁄2 54 x 72 62 x 80 33

100 60 x 80 68 x 88 37

10 72 x 96 80 x 104 43

150 90 x 120 98 x 128 54

15 108 x 144 116 x 152 66

HDTV Format (16:9)

92 45 x 80 53 x 88 34

106 52 x 92 60 x 100 37

119 58 x 104 66 x 112 41

133 65 x 116 73 x 124 46

161 80 x 140 88 x 148 57

WideScreen Format (1.85:1)

99 47 x 87 55 x 95 35

108 493⁄4 x 92 573⁄4 x 100 37

120 561⁄4 x 104 641⁄4 x 112 41

132 623⁄4 x 116 703⁄4 x 124 46

162 753⁄4 x 140 833⁄4 x 148 55

www.draperinc.com 765-987-7999

��

� � �

Frame

���������������

��������

Viewing surface width + 8"

Viewing surface

Clarion

Perfect picture quality from a fixed projection screen.

Improve your image—with a Clarion projection screen. How? The viewing surface is perfectly flat. And a perfectly flat viewing surface means perfect picture

quality. The Clarion’s viewing surface is stretched tightly over a self-concealing aluminum frame, which also forms an attractive border, for a clean, theatrelike appearance.

System Options

• Viewing Surfaces—M1300, M2500, HiDef Grey, glass beaded, or acoustically transparent AT1200 or

AT Grey.

• Custom Sizes—Available up to the maximum standard size in the chart below. Overall size, including frame, equals image area plus 1⁄2.

• Frame Finishes—Black acrylic is standard. Also available with velvety black Vel–Tex to eliminate reflections on the frame.

• Black Masking Borders—The frame serves as the border in all formats.

• Mounting—Permanent wall mount

(brackets included).

Complete Onyx and Clarion specifications: www.draperinc.com

Standard Clarion Sizes

Nominal Image Area Overall Size Net Wt.

Diagonal H x W H x W (lbs.)

Audio Visual Format

50 x 50 531⁄2 x 531⁄2 31

60 x 60 631⁄2 x 631⁄2 38

70 x 70 731⁄2 x 731⁄2 39

84 x 84 871⁄2 x 871⁄2 55

96 x 96 991⁄2 x 991⁄2 63

9 x 9 1111⁄2 x 1111⁄2 71

10 x 10 1231⁄2 x 1231⁄2 79

NTSC Format (4:3)

6 43 x 57 461⁄2 x 601⁄2 32

61⁄2 47 x 63 501⁄2 x 661⁄2 37

7 50 x 67 531⁄2 x 701⁄2 38

71⁄2 54 x 72 571⁄2 x 751⁄2 42

100 60 x 80 631⁄2 x 831⁄2 45

10 72 x 96 751⁄2 x 991⁄2 55

150 90 x 120 931⁄2 x 1231⁄2 72

15 108 x 144 1111⁄2 x 1471⁄2 80

HDTV Format (16:9)

92 45 x 80 481⁄2 x 831⁄2 41

106 52 x 92 551⁄2 x 951⁄2 46

119 58 x 104 611⁄2 x 1071⁄2 54

133 65 x 116 681⁄2 x 1191⁄2 59

161 80 x 140 831⁄2 x 1431⁄2 73

Wide Screen Format (1.85:1)

99 47 x 87 501⁄2 x 901⁄2 46

108 493⁄4 x 92 531⁄4 x 951⁄2 48

120 561⁄4 x 104 593⁄4 x 1071⁄2 54

132 623⁄4 x 116 661⁄4 x 1191⁄2 61

162 753⁄4 x 140 791⁄4 x 1431⁄2 73

Earlham College, Richmond, IN. Installation by MCSi, Indianapolis.

Trim Frame has lip on rear side

Viewing Surface

Wall Mounting

Brackets

Trim frame

Viewing surface width + 31⁄2"

Viewing surface

www.draperinc.com 765-987-7999

35

Permanently Tensioned Screens

36

Eclipse/H to use with Clarion or Cineperm

92 95 75

106 1091⁄2 861⁄2

123 126 100

133 1361⁄2 108

147 1511⁄2 120

2

3

/

4

"

Eclipse/H

3

9

/

16

"

6"

6"

6"

ShadowBox Clarion

ShadowBox Clarion screens are constructed with a viewing surface that snaps onto the back side of a 1⁄2 extruded aluminum frame with a black powdercoat finish. The assembled unit features a perfectly flat viewing surface with a clean, finished appearance.

System Options

• Viewing Surfaces—M1300, M2500,

HiDef Grey, AT1200 or AT Grey for front projection, or Cineflex for rear projection.

• Standard Sizes—Same Image Area sizes as

Clarion (page 35). Overall Size, including frame, equals Image Area plus  in each dimension.

• Custom Sizes—Available up to the maximum standard size on page 35.

• Frame Finishes—Black aluminum is standard. The standard black frame may be covered with velvety black Vel–Tex, to eliminate reflections on the frame.

WrapAround Clarion

With a WrapAround Clarion, the viewing surface wraps completely around the perimeter frame and attaches to the back side, so the screen is solid white—and perfectly flat—with no visible frame or border. Ideal for any application where the screen must be perfectly unobtrusive.

System Options

• Viewing Surfaces—M1300, M2500 or HiDef Grey.

• Sizes—Available in any size up to the largest standard size shown in the chart for the Clarion on page 35. Image Area will match the Overall Size.

• Frame and borders—No frame or borders are visible since the surface wraps completely around the frame.

• Mounting—Permanent wall mount

(brackets included).

• Black Masking Borders—The frame serves as the border in all formats.

• Mounting—Permanent wall mount (brackets included).

Eclipse Masking System

Switch instantly between two formats

The Eclipse is a motorized masking system that mounts to the wall, framing a Draper Clarion or Cineperm. A special channel system keeps the screen as close as possible to the masking borders, giving it a seamless appearance.

Images are fully bordered in flat black, so nothing interferes with your projected image—in any format. The Eclipse eliminates the need to buy two projection screens.

System Options

• Series V—Image Area masked from top and bottom and the width remains constant. Standard format changes from 4:3 NTSC to 16:9 HDTV, or from

4:3 NTSC to 1.85:1 WideScreen.

Series H—Image Area masked on the sides and the height remains constant. Standard format changes are from either 16:9 HDTV or 1.85:1

WideScreen to 4:3 NTSC.

Control Options—Refer to page 22.

Eclipse/V U.S. Patent No. 5,523,880

From 16:9 HDTV to 4:3 NTSC, or

From 1.85:1 WideScreen to 4:3 NTSC

HDTV Open WideScreen Open NTSC Masked

Image Area (16:9) Image Area (1.85:1) Image Area (4:3)

Nom. Diag. Nom. Diag. Nom. Diag.

From 4:3 NTSC to 16:9 HDTV, or

From 4:3 NTSC to 1.85:1 WideScreen

NTSC Open HDTV Masked WideScreen

Image Area Image Area Masked Image Area

(4:3) Nom.Diag. (16:9) Nom.Diag. (1.85:1) Nom.Diag.

6"

2 3 /

4

"

Eclipse/V

3 9 /

16

"

Eclipse/V to use with Clarion

6 651⁄2 643⁄4

61⁄2 721⁄4 711⁄2

7 77 76

90 823⁄4 813⁄4

100 92 91

10 1101⁄4 109

150 1373⁄4 1361⁄4

Eclipse/V to use with Cineperm

6 651⁄2 643⁄4

61⁄2 721⁄4 711⁄2

71⁄2 823⁄4 813⁄4

100 92 91

10 108 1063⁄4

11 1201⁄2 1191⁄4

150 1373⁄4 1361⁄4

www.draperinc.com 765-987-7999

Cineperm

Snap-On screen with aluminum frame.

The Cineperm offers a contemporary, theatre-like appearance wherever a permanently mounted front or rear screen is required. Flexible viewing surface is stretched perfectly flat and snaps onto a 1 tubular aluminum frame. The viewing surface conceals the frame completely with 2 black leatherette borders on all sides. Pull handles at each corner of the surface help stretch the fabric during attachment, and can be removed after snapping surface onto frame.

Suitable for mounting to a wall, suspending from a ceiling, or “flying” for theatrical uses.

System Options

• Viewing Surfaces—M1300, M2500, HiDef Grey, AT1200 or AT

Grey for front projection, or Cineflex rear projection vinyl.

• Standard Sizes—Listed in the chart below.

• Custom Sizes—We make virtually any size. Overall size, including frame, equals image area plus .

• Truss Sizes—Sizes larger than 1⁄2   are manufactured with truss-style construction, using a 6 wide frame and borders.

• Black Masking Borders—Standard for all formats.

Draper Cineperm screens installed at NTC Flight Training,

Moose Jaw, SK. Photo courtesy of Inland AV, Canada.

Cineperm

Standard Construction

Image Area Overall Size Net Nominal Image Area Overall Net

H x W H x W Wt. (lbs.) Diagonal H x W Size Wt. (lbs.)

AV Format NTSC Format (4:3)

46 x 46 50 x 50 34 6 43 x 57 47 x 61 22

56 x 56 60 x 60 36 61⁄2 47 x 63 51 x 67 23

66 x 66 70 x 70 38 71⁄2 54 x 72 58 x 76 24

80 x 80 84 x 84 40 100 60 x 80 64 x 84 25

70 x 94 74 x 98 41 10 70 x 94 74 x 98 28

92 x 92 96 x 96 42 11 79 x 105 83 x 109 32

90 x 120 94 x 124 44 150 90 x 120 94 x 124 35

116 x 116 10 x 10 48 15 104 x 140 108 x 144 46

104 x 140 9 x 12 50 200 122 x 164 126 x 168 49

140 x 140 12 x 12 56 250* 144 x 194 156 x 206 98

25* 180 x 242 192 x 254 109

Complete Cineperm and Lace & Grommet specifications: www.draperinc.com

Nominal Image Area

Diagonal H x W

Cineperm

Truss-Style Construction

(very large sizes only)

Overall Net

Size Wt. (lbs.)

HDTV Format (16:9)

92

106

119

133

161

45 x 80

52 x 92

58 x 104

65 x 116

80 x 140

49 x 84 27

56 x 96 28

62 x 108 31

69 x 120 35

84 x 144 41

Wide Screen Format (1.85:1)

99 47 x 87 51 x 91 27

108 493⁄4 x 92 533⁄4 x 96 28

120 561⁄4 x 104 601⁄4 x 108 31

132 623⁄4 x 116 663⁄4 x 120 35

162 753⁄4 x 140 793⁄4 x 144 41

*This size requires truss-style construction.

Lace & Grommet

Draper Lace & Grommet screens are furnished with reinforced borders on all four sides and grommets on



centers. Every Lace & Grommet screen is custom built to your order—sizes up to   .

Ideal for theatres, auditoriums and stage events.

System Options

• Viewing Surfaces—For front projection, flexible matt white is the standard viewing surface. Fiberglass matt white, glass beaded, pearlescent, aluminized,

M1300, M2500 and HiDef Grey are also available.

For rear projection, choose Cineflex vinyl.

Lacing

Lacing

Reinforced

Border

Reinforced

Border

Viewing

Surface

Aluminum frame–

Inside laced

Lacing

• Frames—Wood, aluminum or steel for wall or suspended mounting.

Reinforced

Border

Viewing

Surface

• Surface Attachment—Lacing cords, springs or shock cords may be used to attach surface to frame.

Wraparound style frames are optionally available, as well as rigid masking systems.

Wood frame–Front laced

Draper Lace & Grommet with surface attached to steel frame via springs. Westside Recreation Centre, Calgary,

Alberta, Canada. Photo courtesy of Inland AV, Canada.

Springs to attach surface to frame

Springs

Reinforced

Border

Viewing

Surface

www.draperinc.com 765-987-7999

37

38

Ceiling-Recessed Manual Screens

Access/Series M

Install the case now and the screen later.

The Access is the most versatile ceiling-recessed screen on the market. No other projection screen offers you the benefits of installing the case during construction and the viewing surface at a later date to eliminate job site damage. See page

6 for details of Draper’s Access case. Your choice of a conventional viewing surface: fiberglass matt white, glass beaded or High Contrast Grey.

System Options

• Extra Drop—Up to  overall height, either white or black (white is standard in AV format; black for all other formats).

• Black Masking Borders—Borders are optional for Series M in AV format.

They are standard for all other formats.

• Control Options—Aluminum Operating Pole, choice of two sizes:  and .

Use in place of the factory attached pull cord.

U.S. Patent No. 6,532,109. Other patents pending.

Size Case Net Wt.

HxW Length (lbs.)

Audio Visual Format

50 x 50 48 33

60 x 60 56 39

70 x 70 64 45

84 x 84 76 51

72 x 96 86 53

96 x 96 86 56

7 x 9 96 57

9 x 9 96 65

8 x 10 106 72

10 x 10 106 77

9 x 12 126 88

12 x 12 126 104

8

5

/

8

"

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 461⁄2 x 591⁄2 56 36

7 50 x 661⁄2 531⁄2 x 691⁄2 64 43

100 60 x 80 64 x 831⁄2 76 50

10 69 x 92 73 x 96 86 53

11 78 x 104 83 x 108 96 60

150 87 x 116 92 x 120 106 72

15 105 x 140 109 x 144 126 88

6

5

/

8

"

Access/Series M

4

1/2

"

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

HDTV Format (16:9)

92 45 x 80 49 x 831⁄2 76 45

106 52 x 92 56 x 96 86 53

119 58 x 104 62 x 108 96 57

133 65 x 116 69 x 120 106 72

161 79 x 140 84 x 144 126 88

WideScreen Format (1.85:1)

99 47 x 87 51 x 90 8 48

108 50 x 92 54 x 96 86 50

120 56 x 104 60 x 108 96 55

132 63 x 116 67 x 120 106 72

162 76 x 140 80 x 144 126 88

Apex

6

1/8

"

4

5/8

"

Apex

6 1/2 "

The first spring-roller screen with automatic ceiling closure.

The Apex is the first manually operated screen expressly designed for concealed installation.

Extruded aluminum case installs above the ceiling. The Apex features a white closure panel at the bottom of the screen surface which seals the ceiling opening when the screen is retracted. Trim fl ange surrounds the perimeter of the screen case to finish the installation, whether in a suspended or drywall ceiling. Bottom of case and closure are finished in ceiling white.

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded or High Contrast Grey.

System Options

• Extra Drop—Up to  overall height, either white or black (white is standard in AV format; black for all other formats).

• Black Masking Borders—Borders are optional for Apex in AV format.

They are standard for all other formats.

• Control Options—Aluminum Operating Pole is furnished in one of two sizes:  and  as required.

Complete Access and Apex specifications: www.draperinc.com

Size Case Net Wt.

HxW Length (lbs.)

Audio Visual Format

50 x 50 451⁄2 25

60 x 60 531⁄2 29

70 x 70 611⁄2 35

84 x 84 731⁄2 40

72 x 96 84 47

96 x 96 84 50

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 461⁄2 x 591⁄2 531⁄2 29

7 50 x 661⁄2 531⁄2 x 691⁄2 611⁄2 35

100 60 x 80 64 x 831⁄2 731⁄2 40

10 69 x 92 73 x 96 84 48

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

HDTV Format (16:9)

92 45 x 80 49 x 831⁄2 731⁄2 37

106 52 x 92 56 x 96 84 47

WideScreen Format (1.85:1)

99 47 x 87 51 x 90 710 37

108 50 x 92 54 x 96 84 47

www.draperinc.com 765-987-7999

Wall-Mounted Manual Screens

Silhouette

With a high-tech appearance.

We changed the appearance of projection screens with a revolutionary case design. The Silhouette’s case conceals everything:

6"

4

3/4

"

Mounting fixtures Fasteners

Viewing surface retracts completely inside case

The innovative case installs cleanly, and the front fascia is easily removable for access to the inside components. Its slender fascia and endcaps are made of gently radiused aluminum

Silhouette/Series C

and present a strikingly modern appearance. There is no need to conceal the Silhouette—it will complement the other high-tech equipment in your room.

Silhouette/Series C—

Features Draper’s Tab Tensioning

System for a perfectly flat projection surface. Choose M1300,

M2500, HiDef Grey or Cineflex rear projection viewing surface. See page 14 for more on the benefits of Tab

Tensioning.

6"

4

3/4

"

Silhouette/Series M—

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded or High

Contrast Grey.

System Options

Silhouette/Series M

• Case Finishes—Choose a dove grey (standard), black or white lightly textured finish (see page 17). Dowels on both Series retract completely inside case.

Silhouette/Series C

U.S. Patent No. 5,296,964 and 6,111,694.

• Extra Drop—Up to  overall height, either white or black (white is standard for Series C in all formats and for Series M in AV format; black is standard for Series M in all other formats). Extra drop will increase the overall length of the case of a Series C.

• Black Masking Borders—Borders are optional for Series M in AV format. Borders are standard for Series M in all other formats and for all Series C screens.

• Control Options—Series C is operated by a slim, polished aluminum crank, which may be detached for storage. Series

M is spring roller operated.

Notch at center of screen case.

Silhouette/Series M

Silhouette Operation D

Series M Spring

Series C

1

1

/

2

"

Crank

Varies

Tab Tensioned

D

Ceiling mounting bracket.

Hardware by others.

Viewing Surface

Wall mounting bracket.

Hardware by others.

2

3

/

8

"

Mounting on optional

Extension

Wall Brackets

Series M Series C

Size Case Net Wt. Case Dowel Net Wt.

HxW Length* (lbs.) Length* Length (lbs.)

Audio Visual Format

50 x 50 441⁄2 18 63⁄4 5 30

60 x 60 521⁄2 21 6113⁄4 511 32

70 x 70 61⁄2 25 793⁄4 610 37

84 x 84 721⁄2 28 91 8 43

6 x 8 83 29 9113⁄4 9 54

8 x 8 83 33 1021⁄2 911⁄2 56

* Extra drop may increase case and/or dowel length. Consult factory if this dimension is critical.

Complete Silhouette specifications: www.draperinc.com

Series M Series C

Size Image Area Case Net Wt. Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length* (lbs.) HxW Length* Length (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 521⁄2 20 421⁄2 x 561⁄2 671⁄4 561⁄2 36

7 50 x 661⁄2 61⁄2 24 50 x 661⁄2 751⁄4 641⁄2 40

100 60 x 80 721⁄2 25 60 x 80 873⁄4 77 44

10 69 x 92 83 29 72 x 96 9113⁄4 90 51

HDTV Format (16:9)

92 45 x 80 721⁄2 25 45 x 80 863⁄4 76 47

106 52 x 92 83 29 52 x 92 963⁄4 86 51

WideScreen Format (1.85:1)

99 47 x 87 79 25 47 x 87 913⁄4 81 44

108 50 x 92 83 29 50 x 92 963⁄4 86 51

www.draperinc.com 765-987-7999

39

40

Wall-Mounted Manual Screens

Premier/Series C

Crank-Operated Screen with Tensioning.

Premier/Series C—the manually operated screen with a perfectly fl at viewing surface. Its Tab Tensioning System delivers perfect picture quality and meets the exacting requirements of large-screen video and data projection. Operated by a slim, polished aluminum crank, which may be detached for storage. Steel case and special tensioning dowel are finished in flat black.

5

7/8

"

Your choice of M1300, M2500, HiDef Grey or Cineflex rear projection viewing surface. See page 14 for more benefits of Tab Tensioning.

System Options

• Extra Drop—Up to  overall height, either white or black (white is standard). Extra drop will increase the overall length of the case.

• Black Masking Borders—Standard for all formats.

• Projected Mounting Brackets—provides a  clearance.

5

1/4

"

Fasteners for wall mounting by others.

Mounting angle and hardware by others.

Suggested for recessed installations.

S Hooks for suspended installation.

1

13

/

16

"

5

7

/

8

"

1"

5 1 /

4

"

1

3

/

8

"

Mounting hole

Size Case Dowel Net Wt.

HxW Length* Length* (lbs.)

Size Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length* Length* (lbs.)

15 /

16

"

2

1

/

8

"

Size Image Area Case Dowel Net Wt.

Nom. Diag. HxW Length* Length* (lbs.)

Audio Visual Format

50 x 50 58 5 30

60 x 60 663⁄4 511 35

70 x 70 75 610 40

84 x 84 881⁄4 8 50

72 x 96 97 9 55

96 x 96 993⁄4 911⁄2 60

7 x 9 1081⁄4 10 60

9 x 9 1093⁄4 102 65

8 x 10 1193⁄4 1111⁄2 70

10 x 10 11111⁄2 1133⁄4 75

9 x 12 1393⁄4 132 80

12 x 12 1431⁄2 1351⁄2 85

NTSC Format (4:3)

6 421⁄2 x 561⁄2 62 561⁄2 35

7 50 x 661⁄2 71⁄4 641⁄2 40

100 60 x 80 813⁄4 77 50

10 72 x 96 97 9 55

11 78 x 104 1041⁄4 98 60

150 87 x 116 1141⁄4 1091⁄2 70

15 108 x 144 1393⁄4 132 80

HDTV Format (16:9)

92 45 x 80 811⁄2 76 50

106 52 x 92 92 86 60

119 58 x 104 102 97 65

133 65 x 116 113 107 70

161 79 x 140 1341⁄4 128 80

Complete Premier and Artisan specifications: www.draperinc.com

Artisan/Series M

Hand-crafted to complement your room furnishings.

3

1

/

2

"

4 or

1

/

4

"

3

4

1

/

/

2

" or

1

4

"

Artisan Series projection screens complement the fine furniture in your conference room. They are enclosed in solid hardwood cases with a variety of finishes to match virtually any decor—or in sleek, contemporary plastic laminate. Your choice of a conventional viewing surface: fiberglass matt white, glass beaded or High Contrast Grey.

Left end

WideScreen Format (1.85:1)

99 47 x 87 89 81 55

108 50 x 92 92 86 60

120 56 x 104 102 97 65

132 63 x 116 113 107 70

162 76 x 140 1341⁄4 128 80

*Extra drop increases length of case and dowel.

Case may be recess-mounted. Dowel clearance for recessed mounting equals dowel length plus 1.

System Options

• Case Styles—Hardwood cases are available in four styles. Refer to page 13.

• Case Finishes—Choose from seven hardwoods and five laminates. Refer to page 13.

• Extra Drop—Up to  overall height, either white or black

(white is standard on AV format; black for all other formats).

Size Case Net Wt.

HxW Length (lbs.)

• Black Masking Borders—Borders are optional for AV format screens and standard for all other formats.

Z-brackets supplied with screen

(Wall Mounting).

Hardware by others.

Wall

Z-brackets on rear of case

Screen Case

Eye Bolt supplied with screen

1 /

4

"-20 T-nut for

Ceiling Mounting.

1 each end.

Audio Visual Format

50 x 50 45 17

60 x 60 53 19

70 x 70 61 21

84 x 84 74 39

72 x 96 84 42

96 x 96 84 43

Size Image Area Case Net Wt.

Nom. Diag. HxW Length (lbs.)

NTSC Format (4:3)

6 421⁄2 x 561⁄2 53 19

7 50 x 661⁄2 61 21

100 60 x 80 74 33

10 69 x 92 84 38

HDTV Format (16:9)

92 45 x 80 74 33

106 52 x 92 84 38

WideScreen Format (1.85:1)

99 47 x 87 710 36

108 50 x 92 84 38

www.draperinc.com 765-987-7999

Luma 2

Heavy duty spring roller projection screen.

The Luma 2 is an attractive and practical choice wherever a large spring-roller screen is required. Simple in design and rugged in construction, the Luma 2 is housed in a white steel case with matching heavy-gauge endcaps. Fiberglass matt white, glass beaded and High Contrast Grey viewing surfaces available.

System Options

• Extra Drop—Up to  overall height, either white or black (white is standard in AV format; black for all other formats).

• Black Masking Borders—Available on AV format screens: 1⁄2 wide in sizes through   ;  wide in larger sizes. All other format screens have black borders to frame image on all four sides.

• Projected Mounting Brackets— fixed for all sizes;  fixed and – adjustable for sizes through  wide. Bracket information on page 43.

• Luma 2/R with Floor Stand—Matt white (standard) or glass beaded projection screen designed to lay in the Floor Stand and pull up from its scratch-resistant case (at right). Case can be covered with black carpet.

Adjustable Floor Stand of heavy gauge steel and anodized aluminum.

Telescoping upright holds top of viewing surface when extended

(maximum of ). Floor Stand weighs 25 lbs.

Luma 2/R with Floor Stand

Size Case Net Wt.

HxW Length (lbs.)

Audio Visual Format

50 x 50 451⁄2 23

60 x 60 531⁄2 26

70 x 70 611⁄2 29

84 x 84 731⁄2 32

72 x 96 825⁄8 32

96 x 96 825⁄8 34

7 x 9 931⁄4 37

9 x 9 931⁄4 42

8 x 10 1031⁄4 41

10 x 10 1031⁄4 47

9 x 12 1231⁄4 55

12 x 12 1231⁄4 66

5

7/8

"

5

1/4

"

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

NTSC Format (4:3)

100 60 x 80 64 x 831⁄2 731⁄2 32

10 69 x 92 73 x 95 825⁄8 32

11 78 x 104 83 x 107 931⁄4 36

150 87 x 116 92 x 119 1031⁄4 41

15 105 x 140 109 x 143 1231⁄4 55

Case dimensions—5³⁄₆ high x 51⁄4 wide.

Hanging brackets extend 5⁄8 above screen case.

Complete Luma 2, Luma 2/R and Evenroll specifications: www.draperinc.com

Size Image Area Overall Case Net Wt.

Nom. Diag. HxW Size Length (lbs.)

HDTV Format (16:9)

92 45 x 80 49 x 831⁄2 731⁄2 32

106 52 x 92 56 x 95 825⁄8 32

119 58 x 104 62 x 107 931⁄4 35

133 65 x 116 69 x 119 1031⁄4 39

161 79 x 140 84 x 143 1231⁄4 54

WideScreen Format (1.85:1)

99 47 x 87 51 x 90 825⁄8 32

108 50 x 92 54 x 95 825⁄8 32

120 56 x 104 60 x 107 931⁄4 35

132 63 x 116 67 x 119 1031⁄4 40

162 76 x 140 80 x 143 1231⁄4 53

Evenroll Rope-and-Pulley

Simple and economical for large audiences.

When a large, roller-operated screen is required, choose the Evenroll. Sizes to

  

, installs easily to wall or ceiling. Rope-and-pulley operation utilizes nylon marine pulleys and flanged spools for smooth operation, with no mistracking cords.

Select fiberglass matt white or glass beaded viewing surface.

If screen installs in center of stage and operating cords are to extend to wall, be sure to indicate distance from edge of screen to wall and request extra cord, double wheel pulley, and cord cleat on wall plate. Batten and roller are  wider than viewing surface ( on each side). Screen depth is  (front to back).

Maximum screen height when closed is .

System Options

• Extra Drop—Up to  overall height, either white or black

(white is standard).

• Black Masking Borders—Available in  widths.

• Wall Mounting Brackets—Extend screen  from wall. Formed of 1⁄4 strap steel.

Divide screen width by 5 for proper number.

Flanged aluminum spools at ends of roller contain operating cords, preventing them from tracking into the viewing surface. Nylon marine pulleys operate smoothly and silently. Steel housings prevent cords from slipping off pulleys.

www.draperinc.com 765-987-7999

Size Ship Wt.

H x W (lbs.)

Size Ship Wt.

H x W (lbs.)

7 x 14 70

11 x 14 75

14 x 14 80

8 x 16 80

12 x 16 95

16 x 16 110

9 x 18 185

136 x 18 215

18 x 18 230

10 x 20 260

15 x 20 270

20 x 20 280

12 x 24 350

18 x 24 380

24 x 24 425

14 x 28 450

21 x 28 475

15 x 30 450

226 x 30 500

30 x 30 550

41

Wall-Mounted Manual Screens

Star

Economy and durability in a sturdy, reliable classroom screen.

Durable construction and attractive design—at an economical price. Sturdy, cylindrical, white steel case. Heavy gauge endcaps have a matching fi nish and form universal hanging brackets for attachment to wall, ceiling or map rail hooks. Tearproof, flame retardant fiberglass matt white offers a sharp image from any viewing angle.

2

7/8

"

System Options

• Extra Drop—Up to  overall height, either white or black (white is standard).

• Black Masking Borders—Available 1⁄2 wide in sizes through   ;  wide in larger sizes.

3

7/8

"

• Pull Cord—For all sizes  wide and larger, or any size ship ping with wall extension brackets, a pull cord is factory attached.

• Mounting Options—Projected Mounting Brackets— and  fi xed, and



– ad just able; T-Bar Twist Clips; or mount to the wall or ceiling.

Brackets T-bar Twist Clips Ceiling Wall

Size Case Net Wt.

HxW Length (lbs.)

Audio Visual Format

50 x 50 521⁄4 7

60 x 60 621⁄4 8

70 x 70 721⁄4 12

84 x 84 861⁄4 15

Complete Star and V Screen specifi cations: www.draperinc.com

2"

42

3"

V Screen

The only screen with a 5-year warranty.

The Draper V Screen offers extremely durable construction at very reasonable prices.

Due to the extreme simplicity of its design, the V Screen has the longest life expectancy of any classroom screen. These exclusive features target the areas where many classroom projection screens wear out:

• Tearproof fiberglass matt white viewing surface.

• High-tech fabric attachment prevents fabric from pulling off roller.

• Patented design eliminates friction between viewing surface and metal parts.

• VBar aluminum support attaches easily to wall, ceiling or map rails.

• Warranted for five full years (see below).

Mounting Options

• Projected Mounting Brackets— and  fi xed and – adjustable provides clearance for wall-mounted equipment below screen.

• T-Bar Twist Clips—Mount to “T” irons in drop ceiling.

• Flat Steel Plates—Permanently mount to ceiling or into corner.

Size Overall Closed Dims Net Wt.

H x W Length Height Depth (lbs.)

AV Format

40 x 40 411⁄8 31⁄4 21⁄4 5

50 x 50 511⁄8 31⁄4 21⁄4 6

60 x 60 611⁄8 31⁄4 21⁄4 7

70 x 70 711⁄8 31⁄4 21⁄4 11

84 x 84 851⁄8 35⁄8 25⁄8 14

96 x 96 971⁄8 4 3 18

108 x 108 1091⁄8 41⁄8 31⁄8 22

Five-Year Warranty

All Draper VScreens are warranted against defects in materials and/or workmanship for five (5) years from date of ship ment from company.

Brackets T-bar Twist Clips Ceiling Corner

www.draperinc.com 765-987-7999

16-25"

Luma

Pentagonal-shaped case for wall- or ceiling-mounting.

The Luma projection screen is attractive and dependable in the classroom or conference room.

Its case and endcaps have a scratch-resistant, white polyester fi nish. Heavy-gauge endcaps form universal hanging brackets for attachment to wall, ceiling or map rail hooks.

Your choice of a conventional viewing surface: fiberglass matt white, glass beaded or High Contrast Grey.

System Options

• Extra Drop—Up to  overall height, either white or black

(white is standard for AV format, black for other formats).

• Black Masking Borders—Available on AV format screens:

1⁄2

wide in sizes through   ;  wide in larger sizes.

All other formats have black borders on all four sides.

• Projected Mounting Brackets— and  fi xed, and



– adjustable.

• Pull Cord—For all sizes  wide and larger, or any size shipping with wall extension brackets, a pull cord is factory attached.

3

3/16

"

4

3/4

"

Manual Screen Mounting Accessories

T-Bar Twist Clips

Mount screens di rect ly to T-irons sup port ing sus pend ed ceilings—with out tools. For V Screen

(all siz es); Luma and Star through  wide.

-Adjustable Brackets

16-25" brack ets. Adjustable from



to  ex ten sion. For

V Screen, Star, Luma

Elite, and Luma (all sizes);

Luma 2 through  wide.

12"

6"

Non-Adjustable Brackets

Heavy gauge angle steel. Avail able in  and  extension.  ex ten sion for V Screen,

Star, Luma Elite, Luma, and Luma 2.



extension for V Screen, Star, Luma Elite, and Luma (all sizes); Luma 2 through  wide.

Size Case Net Wt. Size Image Overall Case Net Wt.

H x W Length (lbs.) Nom. Diag. Area Size Length (lbs.)

Audio Visual Format

50 x 50 521⁄4 9

60 x 60 621⁄4 11

70 x 70 721⁄4 15

84 x 84 861⁄4 20

72 x 96 981⁄4 22

96 x 96 981⁄4 23

NTSC Format (4:3)

6 421⁄2 x 561⁄2 461⁄2 x 591⁄2 621⁄4 11

7 50 x 661⁄2 531⁄2 x 691⁄2 721⁄4 14

100 60 x 80 64 x 831⁄2 891⁄4 17

10 69 x 92 73 x 96 981⁄4 21

HDTV Format (16:9)

92 45 x 80 49 x 831⁄2 891⁄4 16

106 52 x 92 56 x 96 981⁄4 23

WideScreen Format (1.85:1)

99 47 x 87 51 x 90 921⁄4 19

108 50 x 92 54 x 96 981⁄4 21

5

1/2

"

5"

Complete Luma and Luma Elite specifi cations: www.draperinc.com

Luma Elite

Concealed tension arm holds surface flat.

The Luma Elite is similar to the Luma, plus an automatic tension arm to hold the viewing surface flat. Screen unrolls from its white case and is tensioned in one continuous motion. Must be suspended from ceiling or from extension wall brackets (described above).

Your choice of a conventional viewing surface: fiberglass matt white or glass beaded.

System Options

• Custom Sizes and Extra Drop—Not available.

• Black Masking Borders—Available in  wide.

• Projected Mounting Brackets— and  fi xed, and



– adjustable.

Size Case Net Wt.

HxW Length (lbs.)

Audio Visual Format

50 x 50 53 14

60 x 60 63 17

70 x 70 73 20

www.draperinc.com 765-987-7999

43

Wall-Mounted Manual Screens

Salara/Series M

You’ve never seen a screen like this before.

In your home or offi ce, the Salara makes a design statement on your wall.

5

1/16

"

The Salara’s small, elliptical case and domed endcaps are fi nished in solid white. Floating gunlatch wall mounting brackets grip the screen case securely and are barely visible.

3

13/16

"

Your choice of conventional viewing surface: fi berglass matt white, glass beaded or High

Contrast Grey.

System Options

Mounting

Brackets

• Extra drop—Up to  overall height, either white or black (white is standard for AV format, black for other formats).

Wall

11⁄2"

• Black masking borders—Borders are optional for AV format screens and standard for all other format screens.

Mounting

Brackets

11⁄2"

Wall

3/8"

Mounting

Brackets

Wall

313/16"

5/16"

31/8"

37/16"

Plug n' Play

13/8"

Case Length

Floating

Mounting

Brackets

11⁄2"

Size Case Net Wt.

HxW Length (lbs.)

Mounting

Audio Visual Format

Brackets

13/8"

50 x 50 491⁄8 18

60 x 60 571⁄8 21

51/16"

57/16"

3/8"

Viewing Surface

313/16"

5/16"

Size Image Area Overall Case Net Wt.

13/8"

Case Length

Floating Mounting Brackets

Size Image Area Overall Case Net Wt.

31/8"

NTSC Format (4:3)

3/8"

Viewing Surface

7 50 x 661⁄2 531⁄2 x 691⁄2 651⁄8 24

100 60 x 80 64 x 831⁄2 771⁄8 29

5/16"

10 69 x 92 73 x 96 875⁄8 33

HDTV Format (16:9)

92 45 x 80 49 x 831⁄2 771⁄8 27

106 52 x 92 56 x 96 875⁄8 32

WideScreen Format (1.85:17

57/16"

108 50 x 92 54 x 96 875⁄8 32

313/16"

84 x 84 771⁄8 30

72 x 96 875⁄8 33

31/8"

37/16"

51/16"

44

Exxpress

When time is money and every second counts.

The Exxpress combines compact size and portability with fast, easy setup.

Set up the Exxpress in minutes! Just remove it from its luggage-style case...open it up...stand it up, and pull the side drapes around the frame.

Viewing Surface

The Exxpress viewing surface is made of SpanTec ™ , a fl exible, fl ame retardant and acoustically transparent polyester material. Alpine White in color, SpanTec is solution dyed so it won’t fade and is treated to resist stains. The surface comes attached securely to the frame with hook and loop

(similar to Velcro ® ), and removes for machine washing. Surface is complete with black masking border, skirt and side drapes to conceal frame.

Velcro

® is a registered trademark of Velcro Industries B.V.

www.draperinc.com 765-987-7999

Portable Projection Screens

Exxpress

Frame

The Exxpress frame is constructed of satin anodized aluminum, and each section is octagonal in shape for extra strength. Metal fasteners hold the screen in place. The Exxpress is available in four NTSC sizes ranging from  diagonal through  diagonal. The Overall Size dimensions in the chart below include the black masking borders and skirt.

Size Image Area

Nom. Diag. HxW

Overall Size Skirt Net Wt.

HxWxD Height (lbs.)

NTSC Format (4:3)

100 60 x 80 1043⁄8 x 84 x 18 423⁄8 25

120 723⁄8 x 961⁄2 125 x 1001⁄2 x 24 505⁄8 29

150 903⁄4 x 121 1491⁄2 x 125 x 24 563⁄4 34

180 109 x 1451⁄2 174 x 1491⁄2 x 24 63 38

Case

The Exxpress case is a soft bag with wheels and reinforcements similar to a suitcase. The handle is positioned lower on one end to make pulling easier. It sits upright and features three extra side pockets for storage

(two on one side and one on the other).

Metal fasteners along both sides hold the fabric tight to the frame

Surface comes attached to frame with Hook & Loop and may be detached for cleaning Exxpress Case

Push Button

Latch

Push-button latch releases tension for disassembly

Casters on selected joints aid portability

The Exxpress comes in its own wheeled case. Just unzip, extract from the bag, open it up, stand it up and position the side drape grommets onto the metal fasteners. It’s quick and easy to assemble.

www.draperinc.com 765-987-7999

45

46

Portable Projection Screens

Ultimate Folding Screen

The world’s most precisely manufactured folding screen.

The new standard in portable folding screens, the Ultimate

Folding Screen is the fi rst screen manufactured with 100%

CNC (Computer Numerical Controlled) components and assembly. The tubing is CNC machined, surfaces and borders are CNC cut; even rivet and snap holes are CNC placed. No competitive product meets

this standard—and we did not stop there.

Our new Lock & Load latch (patent pending) is designed for ease of operation and maximum life. Lock

& Load mortise latches bite down when the surface is attached, making the frame extremely rigid. Latch parts are internal for better protection,

Lock & Load

Latch

and they completely fi ll the tube for superior strength. The resilient latch retention spring is captured and constantly fl exed so that it cannot

Closed

be dislodged. These advancements translate into the most user friendly

Open

and incredibly durable hinge locking mechanism available. Couple these advantages with clear anodized 1.25 x .070 wall aluminum tubing and you’ve got the precision and stability that allows Draper to offer the Ultimate Folding Screen in sizes through   .

System Options

• Viewing Surfaces—Choose a fl exible matt white for front projection or Cinefl ex vinyl for rear projection. For maximum fl exibility, choose both! All surfaces— front and rear—have square corners. Borders are electronically welded using a new PVC material that provides straighter, cleaner edges.

• Sizes: Two Format Options Available—UFS Standard Sizes (chart at right), and UFS Euro sizes (chart on page 47). Standard format viewing surfaces may be interchanged freely with Cinefold surfaces and have 23⁄4 of black masking border. (Cinefold detailed on page 48.) Euro format viewing surfaces have 4 of black masking border.

• Frame & Legs—Standard Legs support the Ultimate Folding Screen in a vertical position. The screen may also be tilted for keystone elimination using Heavy-

Duty Legs which offer extra stability using an adjustable gusset (screen pictured above has Heavy-Duty Legs ). Super Heavy-Duty Legs are recommended for added stability on frame heights greater than 1⁄2.

Carrying Case—The Ultimate Folding Screen comes packed in Draper’s heavy-duty, molded polyethylene wheeled carrying case. Designed for service and dependability, each case has two wheels. The handles are molded into each end of the case. Lid handle is steel with a rubber grip and recessed into an inset. Lid is secured with two adjustable straps. Multiple cases stack with lids on, or nest compactly with lids off.

Corner

Hinge

Open

Corner Hinge

Closed www.draperinc.com

Patent Pending

765-987-7999

UFS Standard Sizes

Overall Size Image Nominal Net Wt.

H x W Area Diagonal (lbs.)

Square Format (1:1)

6 x 6 661⁄2 x 661⁄2 — 71

7 x 7 781⁄2 x 781⁄2 — 81

8 x 8 1 901⁄2 x 901⁄2 — 87

9 x 9 1 1021⁄2 x 1021⁄2 — 93

10 x 10

1

1141⁄2 x 1141⁄2 — 99

12 x 12 2 1381⁄2 x 1381⁄2 — 112

NTSC Format (4:3)

54 x 74 481⁄2 x 681⁄2 71⁄2 66

62 x 83 561⁄2 x 771⁄2 100 68

6 x 8 661⁄2 x 901⁄2 10 73

76 x 10 1 841⁄2 x 1141⁄2 150 74

9 x 12

1

1021⁄2 x 1381⁄2 15 87

106 x 14 2 1201⁄2 x 1621⁄2 200 93

144 x 196 2 1381⁄2 x 1901⁄2 240 106

HDTV Format (16:9)

56 x 96 501⁄2 x 901⁄2 106 74

62 x 108 561⁄2 x 1021⁄2 119 81

69 x 120 631⁄2 x 1141⁄2 133 87

83 x 144 771⁄2 x 1381⁄2 161 91

112 x 196 1 1061⁄2 x 1901⁄2 220 97

Slide Format (1.48:1)

48 x 72 421⁄2 x 661⁄2 — 77

60 x 90 541⁄2 x 841⁄2 — 78

72 x 108 661⁄2 x 1021⁄2 — 82

84 x 126 781⁄2 x 1201⁄2 — 87

96 x 144 1 901⁄2 x 1381⁄2 — 89

1 Heavy-Duty Legs are recommended for frame heights greater than 71⁄2.

2

Super Heavy-Duty Legs are recommended for added stability on frame heights greater than 101⁄2.

Ultimate Folding

Dress Kit

For a professional appearance.

Make your presentation one to remember. Create a professional, theatrelike appearance by draping your Ultimate Folding Screen with an eyecatching velour Dress Kit. Drapery curtains surround the viewing surface, pulling the audience’s focus to your presentation on the screen.

All Ultimate Folding Screen Dress Kit fabrics are fl ame proofed, meeting fi re safety codes. In addition to framing your presentation, the velour curtains will hide projection equipment, shield projector light from the audience, and help eliminate ambient light in the projection area.

A complete Dress Kit includes 46 skirt, 12 valance, and two

32 side drapes, all in rich velour. 100% CNC (Computer Numerical

Controlled) valance bar and drapery bars fi t snugly into the top of the

Ultimate Folding Screen frame—no tools needed. The viewing surface is fi tted with snaps to accept the skirt.

System Options

• Fabric—20 oz. velour made from 100% cotton is offered in black (standard), rich navy (optional) or a variety of custom colors. Details available on request.

• Frame & Legs—Heavy-Duty Legs are recommended with all Dress Kits.

Carrying Case—A carrying case is optional for all Dress Kits.

Heavy-Duty

Legs

The valance bar assembles to the top of the

Ultimate Folding Screen frame. Two drapery side bars slide easily into each end of the valance bar and lock into place with a ball detent (shown at right).

Valance Bar

Ball Detent

Þ

Drapery Side Bar www.draperinc.com 765-987-7999

UFS Euro Sizes

Overall Size Image Nominal Net Wt.

H x W Area Diagonal (lbs.)

Square Format (1:1)

68 x 68 72 x 72 — 75

82 x 82 1 90 x 90 — 85

98 x 98 1 108 x 108 — 91

112 x 112 2 126 x 126 — 98

128 x 128

2

144 x 144 — 104

148 x 148 2 168 x 168 — 104

NTSC Format (4:3)

52 x 68 54 x 72 90 69

57 x 73 59 x 79 100 71

68 x 88 72 x 96 120 77

77 x 910

1

83 x 110 138 77

82 x 108 1 90 x 120 150 78

88 x 114 1 96 x 128 160 84

98 x 128 1 108 x 144 180 91

102 x 134

1

114 x 152 190 95

112 x 148 2 126 x 168 200 98

128 x 168 2 144 x 192 240 111

HDTV Format (16:9)

48 x 710 48 x 86 98 75

57 x 95 59 x 105 120 85

68 x 114 72 x 128 147 92

82 x 1311 1 90 x 159 183 96

98 x 168 1 108 x 192 220 103

Slide Format (1.48:1)

48 x 68 48 x 72 — 81

57 x 8 59 x 88 — 83

68 x 98 72 x 108 — 87

77 x 1011

1

83 x 123 — 92

88 x 128 1 96 x 144 — 94

1 Heavy-Duty Legs are recommended for frame heights greater than 71⁄2.

2

Super Heavy-Duty Legs are recommended for added stability on frame heights greater than 101⁄2.

47

48

Portable Projection Screens

Cinefold

The original folding screen in a wheeled case.

C is a portable screen that packs into an innovative case with wheels. Trainers, presenters, producers, everyone who takes a show on the road will appreciate the Cinefold’s many advantages.

Every Cinefold sets up quickly without tools, and collapses into a compact luggage-type wheeled case for travel or storage.

The Cinefold frame and legs are built of  square structural aluminum tubing and are conveniently color-coded and labeled for quick assembly. Steel hardware is cadmium plated. When assembled, the bottom of the frame is normally  above the fl oor and adjusts in  increments. Hinges are tempered steel and lock positively. Frame, legs, viewing surfaces and accessories are all standardized for easy replacements or additions to the system. Front projection and rear projection surfaces are easily interchangeable. Sizes and formats to meet virtually any specification: custom and truss sizes available.

System Options

• Viewing Surfaces—Choose a fl exible matt white for front projection or Cinefl ex vinyl for rear projection. Surfaces are bordered in black and are interchangeable.

• Sizes—Standard sizes are shown below. Multi-image and custom sizes available.

Carrying Case—The Cinefold comes packed in Draper’s heavy-duty, molded polyethylene wheeled carrying case. Designed for service and dependability, each case has two wheels.

The handles are molded into each end of the case. Lid handle is steel with a rubber grip and recessed in an inset. Lid is secured with two adjustable straps. Multiple cases stack with lids on, or nest compactly with lids off.

T-Legs

Standard legs constructed of sturdy  square hard-alloy struc tur al aluminum tubing, clear etched and an od ized for long life. Hinged inverted “T” shape, with rub ber-tipped feet.

Overall Size Image Nominal Shipping Carrying Case

H x W Area Diagonal Wt. (lbs.) Size (in. h x w x l)

Square Format (1:1)

5 x 5 56 x 56 — 56 91⁄2 x 131⁄2 x 45

6 x 6 68 x 68 — 57 91⁄2 x 131⁄2 x 45

7 x 7 80 x 80 — 65 12 x 153⁄4 x 52

8 x 8 92 x 92 — 70 12 x 153⁄4 x 58

9 x 9 1 104 x 104 — 75 12 x 153⁄4 x 52

10 x 10 1 116 x 116 — 80 12 x 153⁄4 x 52

12 x 12

1

140 x 140 — 90 12 x 153⁄4 x 58

NTSC Format (4:3)

47 x 60 43 x 56 6 53 91⁄2 x 131⁄2 x 45

54 x 74 50 x 70 71⁄2 55 91⁄2 x 131⁄2 x 45

62 x 83 58 x 79 100 59 12 x 153⁄4 x 52

6 x 8 68 x 92 10 60 91⁄2 x 131⁄2 x 45

76 x 10 86 x 116 150 70 12 x 153⁄4 x 52

9 x 12 1 104 x 140 15 75 12 x 153⁄4 x 52

106 x 14 2 122 x 164 200 85 12 x 153⁄4 x 52

HDTV Format (16:9)

56 x 96 52 x 92 106 60 91⁄2 x 131⁄2 x 45

62 x 108 58 x 104 119 65 91⁄2 x 131⁄2 x 45

69 x 120 65 x 116 133 70 91⁄2 x 131⁄2 x 45

83 x 144 79 x 140 161 73 12 x 153⁄4 x 52

Slide Format (1:1.48)

4 x 6 44 x 68 — 55 91⁄2 x 131⁄2 x 45

5 x 76 56 x 86 — 62 91⁄2 x 131⁄2 x 45

6 x 9 68 x 104 — 63 91⁄2 x 131⁄2 x 45

7 x 106 80 x 122 — 70 12 x 153⁄4 x 52

8 x 12 1 92 x 140 — 72 12 x 153⁄4 x 52

1

Heavy-duty legs rec om mend ed.

2 Heavy-duty legs and anti-sway stabilizers recommended.

Please Note: Shipping weights and carrying cases are based on one stan dard

Cinefold: frame, standard T-legs, snap-on viewing surface and carrying case.

Op tions may increase the weight and/or the carrying case size. Custom sizes are available—Inquire if the size you need is not shown.

Keystone Elimination

T-legs may be adjusted to allow the

Cinefold to tilt forward up to °.

Eases viewing and helps to com pen sate for image distortion.

Heavy-Duty Legs

Extra reinforcement against front-to-back movement. Strongly rec om mend ed for any screen over

1⁄2  

or for any screen used with a Dress Kit .

Anti-Sway Stabilizers

Reinforce against side-to-side move ment. May be mounted either inside or outside Cinefold leg.

Rec om mend ed for screens over 1⁄2   and for use with Dress Kits.

Joining Clamp

Join two or more screens for a really wide screen. Clamps join screen frames from back, then L-shaped sec-

tion wraps to front and accepts snaps on masking strips. Mask ing strips con ceal hard ware and pro vide image continuity. White mask ing for use with matt white; black for Cinefl ex.

www.draperinc.com 765-987-7999

Truss-Style

Cinefold

For larger-than-life presentations.

The Truss-Style Cinefold has extra-rigid truss-style frames and legs constructed of parallel sections of  square hard-alloy aluminum tubing, heliarc welded to form a sturdy  wide truss. All alu mi num is clear satin anodized for long life; steel parts are cad mi um plated. Truss frames have  wide piano hinges reinforced by two positive locking hinge latches and a Handy

Crank directly through the hinge point.

All Truss-Style Cinefolds include heavy-duty legs and anti-sway stabilizers.

System Options

• Viewing Surfaces—Truss-Style Cinefolds are avail able with fl exible matt white front and Cinefl ex rear pro jec tion surfaces.

Carrying Case—Two or more heavy-duty, molded polyethylene wheeled carrying cases are included. Di men sions are    5⁄8   1⁄8 .

Dress Kits—Optional Dress Kit includes:  skirt, 12 valance and two 32 side drapes, all in rich velour. Tubular aluminum valance bar and drapery bars attach without tools to the Dress Kit fi ttings found on all Truss-Style

Cinefold frames. The viewing surface is fi tted with snaps to accept the skirt or select optional adjustable skirt bar. Skirt bar allows for adjustment of screen size and aspect ratio by raising the skirt in 6 increments.

Overall Image Shipping No.

Size Area Wt. (lbs.) Cases

Square Format (1:1)

9 x 9 8 x 8 220 2

10 x 10 9 x 9 220 2

11 x 11 10 x 10 230 2

13 x 13 12 x 12 240 2

NTSC Format (4:3)

7 x 9 6 x 8 215 2

8 x 11 76 x 10 220 2

10 x 13 9 x 12 230 2

116 x 15 106 x 14 255 2

13 x 17 12 x 16 265 2

16 x 21 15 x 20 275 2

19 x 25 18 x 24 310 3

HDTV Format (16:9)

10 x 17 9 x 16 220 2

11 x 19 10 x 18 240 2

123 x 21 113 x 20 255 2

146 x 25 136 x 24 300 3

Please note: Shipping weight and number of cases

are based on one Truss-Style Cinefold, with

frame, heavy-duty legs, anti-sway sta bi liz ers, one viewing surface in pouch and carrying cases. Screens with additional viewing surfaces and hardware will be heavier and may require ad di tion al cases.

L-Brace

All Cinefold over



wide feature a special back brace consisting of a full-width truss at tached to the top of the frame at right angles to the screen. Adds strength and prevents sagging, while main tain ing complete port a bil i ty.

Frame Stiffeners

All horizontal hinges on Truss-

Style Cinefold are reinforced by truss frame stiffeners, which mount across the back of the hinge and are held rigidly in place by 

Handy Cranks.

Handy Cranks

Handy Cranks are ⁵⁄₁₆ di a. crankbolts, for quick as sem bly without tools for both the Cinefold and

Truss-Style Cinefold.

www.draperinc.com

Heavy-Duty Legs

Standard equipment on all Truss-Style

Cinefold, heavyduty legs reinforce against front-toback move ment.

Anti-Sway

Stabilizers

Furnished with all Truss-Style

Cinefold to prevent side-to-side movement. Install to inside or outside of truss foot.

Dress Kits

A com plete Dress

Kit in cludes:  skirt,  valance and two  side drapes, all in rich ve lour. Tubular alu mi num side drapery bars 

and valance bar  attach without tools to the dress kit fi ttings found on all

Cinefold frames. The viewing surface is fitted with snaps to accept the skirt, or select op tion al ad just able skirt bar. Skirt bar allows for ad just ment of screen size and aspect ratio by raising the skirt in  in cre ments.

765-987-7999

49

Portable Projection Screens

Dress Kits

Dress up your presentation.

For a memorable presentation, you can give your Cinefold or Truss-Style

Cinefold a professional, cinema-like appearance with a striking velour Dress Kit.

Stage curtains surround the viewing surface, focus the audience’s attention on the screen and frame your visual presentation.

All Dress Kit fabrics are flame proofed, meeting fire safety codes. Dress Kits are especially worthwhile for rear screen presentations. Besides improving the appearance of the screen, the velour curtains conceal the projection equipment, shield the audience from projector light and help exclude ambient light in the projection area.

Your Dress Kit Includes...

A complete Dress Kit includes  skirt,  valance, and two  side drapes, all in rich velour. Tubular aluminum valance bar and drapery bars attach without tools to the dress kit fittings found on all Cinefold and Truss-Style Cinefold frames.

They are fitted with brackets that slip easily over the shoulder rivets mounted on all

Cinefold frames, then lock in position.

The viewing surface is fitted with snaps to accept the skirt, or select optional adjustable skirt bar. Skirt bar allows for adjustment of screen size and aspect ratio by raising the skirt in  increments.

System Options

• Fabric—20 oz. velour made from 100% cotton is offered in black (standard), rich navy (optional) or a variety of custom colors. Details available on request.

• Hardware—Heavy-Duty Legs and Anti-Sway Stabilizers (both pictured at right), are highly recommended for all Cinefolds with Dress Kits. They are standard with all Truss-Style Cinefolds.

• Carrying Case—A wheeled, polyethylene carry case is highly recommended for each

Dress Kit.

At right: Cinefold with Cinefl ex viewing surface, valance bar, drapery bars, skirt bar, Heavy-Duty Legs and Anti-Sway Stablilzers. Above: navy velour drapes attached to Cinefold.

50

Pipe & Drape Runo

This universal portable Pipe & Drape

Runoff (PDR) system can extend the theatre-like ap pear ance of a Cinefold,

Truss-Style Cinefold or Ultimate

Folding Screen Dress Kit on either side of your screen. PDR is a com-

plete ly free- stand ing modular system that can be as sem bled in min utes to virtually any size or con fig u ra tion— without tools. Also suit able for use as a room divider or to mask unsightly areas.

View of the back of a Cinefold with Dress Kit and Pipe & Drape Runoffs.

Horizontal Drape Support

Drape panels are available in  or  widths, to be reduced for fullness.

Height of  or , with hems top and bot tom to accept horizontal drape sup ports. All fabrics are flame retardant.

Fabrics

• Velour—% cotton. Black or rich navy. Additional custom colors are available. Details available on request.

• Vellite—Lightweight brushed polyester. Black or rich navy.

• Classic Twill—Lightweight polyester with special weave to reduce wrinkling and subdue luster. Black or rich navy. Additional custom colors are available. Details available on request.

• Poly-Knit—Lightweight smooth polyester. Black or rich navy.

Infi nitely adjustable, with preset positive locking stops—10 length, with stops at 6, 8 and 10. 12 length, with stops at 7, 10 and 12. Attaches to uprights with sturdy steel hook and slot.

Slip-Lok Upright

Telescoping uprights are infi nitely adjustable from minimum to maximum height settings. Friction lock bears virtually any weight, yet has fi ngertip release.

Steel Bases

Sturdy and inconspicuous. Alternate stud positions allow for setup against a wall or in a corner. 3⁄8 x 18 x 18 (35 lbs.) or choose lightweight base, 3

/

16

x 18 x 18 (18 lbs.).

www.draperinc.com 765-987-7999

Diplomat

Built-in keystone eliminator.

The Diplomat combines simplicity of design, rugged components and careful workmanship. Easy setup and one-hand case adjustment make the Diplomat a pleasure to use. Suspension slat saddle in all sizes maintains a flat viewing surface. Exclusive Bell Leg Lock protects the Diplomat’s sturdy gabled aluminum legs during storage and transportation (see detail photo). Your choice of viewing surfaces: fi berglass matt white, glass beaded or High Contrast Grey.

Key stone Elim i na tor

System Options

• Case Color—Steel case and endcaps fi nished in black. Case measures  high x 1⁄8 wide.

• Black Masking Borders—Optional for AV format screens, standard for all other formats.

• Keystone Eliminator—The Diplomat’s built-in keystone eliminator extends . Invisible when not in use.

• Patented Bell Leg Lock—Exclusive Bell Leg Lock clamps legs securely to center tube for storage and transportation. Eliminates all risk of bent or broken legs. Releases easily for setup.

• Carrying Case—Black leatherette zippered carrying case is available for storage and transportation.

Diplomat/R

Case finished for durability in the rental marketplace.

All the best features of the Dip lo mat made more du ra ble to with stand the wear and tear of the rental market. The stan dard case for a Dip lo mat/R is scratch re sis tant baked-on black plas ti sol on steel. Or choose a rug ged, black carpet cov ered case (pic tured above). In same stan dard siz es as the Dip lo mat.

Bell Leg Lock

U.S. Patent No. 4,097,013

Size Net Bottom of Top of

H x W Wt. Case screen at screen at

(lbs.) Length lowest level highest level

AV Format—Consul Tripod Screen

40 x 40 12 421⁄4 161⁄2 78

50 x 50 14 521⁄4 161⁄2 92

60 x 60 19 621⁄4 20 1071⁄4

70 x 70 21 721⁄4 20 1091⁄4

AV Format—Diplomat and Diplomat/R Tripod Screens

50 x 50 23 521⁄4 17 1001⁄4

60 x 60 26 621⁄4 181⁄2 1103⁄4

70 x 70 26 721⁄4 181⁄2 1263⁄4

84 x 84 32 861⁄4 193⁄4 1263⁄4

72 x 96 37 981⁄4 193⁄4 1263⁄4

96 x 96 39 981⁄4 193⁄4 1263⁄4

Size Image Overall Net Bottom of Top of

Nom i nal Area Size Wt. Case screen at screen at

Di ag o nal (lbs.) Length low est level highest level

NTSC Format (4:3)—Diplomat and Diplomat/R Tripod Screens

6 421⁄2 x 561⁄2 461⁄2 x 591⁄2 24 621⁄4 181⁄2 1103⁄4

7 50 x 661⁄2 531⁄2 x 691⁄2 27 721⁄4 181⁄2 1263⁄4

100 60 x 80 64 x 831⁄2 31 891⁄4 193⁄4 1263⁄4

10 69 x 92 73 x 96 37 981⁄4 193⁄4 1263⁄4

Optional Carrying Case for Diplomat,

Diplomat/R and Consul.

Consul

Quality and economy.

Lightweight yet durably constructed, the Consul is designed specifically for audiovisual use. Specifi ed for schools worldwide. The Consul’s legs are of sturdy gabled steel.  and  sizes feature suspension slat saddle, keeping viewing surface flat. Case adjusts easily to any level on tripod upright.

Choice of viewing surfaces: fiberglass matt white or glass beaded.

System Options

• Case Color—Steel case and endcaps fi nished in black. Case measures

1⁄2

high x 3⁄4 wide.

• Black Masking Borders—1⁄2 borders are optional.

• Carrying Case—Black leatherette zippered carrying case.

• Optional Keystone Eliminator—Will extend top of viewing surface up to .

www.draperinc.com 765-987-7999

51

Portable Projection Screens

RoadWarrior

The ultra portable screen for today’s ultra portable projectors.

The Draper RoadWarrior lets you travel light and still deliver a big presentation. Designed with today’s presenter in mind, the

RoadWarrior has a strikingly modern appearance.

Setting up the RoadWarrior is a snap. Screen height adjusts instantly, at the touch of a fi nger. Extend the screen to desired height (pneumatic cylinders support it at any level). Includes  of black “rise” below the image area.

It’s available in four sizes, and sets up in seconds just where you want it—fl oor or table. Release two clasps to open the lid. Rotate feet into position for stability. Aluminum housing and feet are sturdy and streamlined. Detachable shoulder strap included.

System Options

• Viewing Surfaces—Compatible with resolutions up to 1200 x

1600 and beyond, its tear-resistant fi berglass matt white screen surface is designed for computer-driven presentations and meets the needs of today’s LCD projectors and computer-generated text—high resolution, broad viewing cone and accurate color rendition. Also available in glass beaded and High Contrast

Grey. All viewing surfaces have 3⁄4 black borders at sides and are supported by 7⁄8 black aluminum dowel with full-width slat saddle.

• Padded Carrying Case—Draper’s Padded Carrying Case will protect your RoadWarrior from life’s hard knocks. Constructed of 1⁄2 thick shock-absorbing material sandwiched between tearresistant black nylon inner and outer sleeves. Case protects screen from dents, scuffs and scratches. Zippered case has heavy nylon strap (removable) for easy transport.

Optional Padded

Carrying Case

Back view of

RoadWarrior with pneumatic cylinders

52

Nom i nal Image Height Shipping Net Dimensions

Di ag o nal Area Range Wt. Wt. Closed

(H x W) (lbs.) (lbs.) (D x H x L)

NTSC Format (4:3)

60 36 x 48 41–691⁄4 23 21 41⁄2 x 5 x 531⁄2

80 48 x 64 53–813⁄4 24 22 41⁄2 x 5 x 691⁄2

HDTV Format (16:9)

55 27 x 48 32–691⁄4

73 36 x 64 41–813⁄4

23

24

21

22

41⁄2 x 5 x 531⁄2

41⁄2 x 5 x 691⁄2

www.draperinc.com 765-987-7999

Traveller

Attractive, simple and lightweight— sets up in seconds.

It doesn’t make sense to hit the road with a 5-pound projector and a 35-pound screen. Lighten up with the Traveller.

Designed with today’s presenter in mind, the Traveller is similar in appearance to the RoadWarrrior, with a lightweight, simplifi ed design. Self contained in a sturdy, extruded aluminum case, the Traveller is durable and easy to carry.

Setting up the Traveller is easy. Just place it on the fl oor or table. Release two clasps to open the lid. Rotate feet into position for stability. Raise screen to desired height. Includes  of black “rise” below the image area. An infi nitely adjustable telescoping support twist locks to position screen at desired height.

System Options

• Viewing Surfaces—Compatible with resolutions up to 1200 x 1600 and beyond, its tear-resistant fi berglass matt white screen surface is designed for computer-driven presentations and meets the needs of today’s LCD projectors and computer-generated text—high resolution, broad viewing cone and accurate color rendition. Also available in glass beaded and High

Contrast Grey. All viewing surfaces have 3⁄4 black borders at sides and are supported by 7⁄8 black aluminum dowel with full-width slat saddle.

• Padded Carrying Case—Draper’s Padded Carrying Case will protect your

Traveller from life’s hard knocks. Constructed of 1⁄2 thick shock-absorbing material sandwiched between tear-resistant black nylon inner and outer sleeves. Case protects screen from dents, scuffs and scratches. Zippered case has heavy nylon strap (removable) for easy transport.

Optional Padded

Carrying Case

Nom i nal Image Height Shipping Net Dimensions

Di ag o nal Area Range Wt. Wt. Closed

(H x W) (lbs.) (lbs.) (D x H x L)

NTSC Format (4:3)

50 30 x 40 451⁄2–771⁄2 16 14 41⁄2 x 5 x 461⁄2

60 36 x 48 451⁄2–831⁄2 17 15 41⁄2 x 5 x 541⁄2

72 431⁄2 x 58 631⁄2–91 21 19 41⁄2 x 5 x 631⁄2

80 48 x 64 631⁄2–951⁄2 24 21 41⁄2 x 5 x 701⁄2

100 60 x 80 631⁄2–1071⁄2 27 25 41⁄2 x 5 x 861⁄2

HDTV Format (16:9)

46 221⁄2 x 40 451⁄2–771⁄2 16 14 41⁄2 x 5 x 461⁄2

55 27 x 48 451⁄2–831⁄2 17 15 41⁄2 x 5 x 541⁄2

661⁄2 321⁄2 x 58 631⁄2–91 21 19 41⁄2 x 5 x 631⁄2

73 36 x 64 631⁄2–951⁄2 24 21 41⁄2 x 5 x 701⁄2

92 45 x 80 631⁄2–1071⁄2 27 25 41⁄2 x 5 x 861⁄2

Above: back view of Traveller with Telescoping Upright. Below: screen is self contained in a sturdy, extruded aluminum case.

www.draperinc.com 765-987-7999

53

54

Rigid Rear Projection Screens

Rear Projection Screens

From the acknowledged leader in the most demanding area of the industry come 5 unique rear screens.

Each rear projection system has a unique set of parameters which define what screen is required—audience seating pattern, projection equipment (light output, resolution and image format) and ambient light level. Draper is the industry leader in the development of rigid rear projection screens. Only Draper can provide five unique rear projection screen technologies to satisfy any requirement.

IRUS—Infinite Resolution Uniformity Screen—Proprietary technology, available only from Draper. The IRUS is designed specifically for use with high resolution single lens video and data projectors. Provides a crisp, clear image with

SXGA and UXGA displays. Page 56.

 Cinescreen ® —Draper’s diffusion coated projection screen. Our wide range of optical coatings and tints allows you to select a combination that’s customized to fi t your exact application. Suitable for use with CRT or single-lens video and data projectors, as well as traditional audio-visual projection formats. Page 57.

 Vortex—This unique new rear screen combines the benefits of diffusion and optical technologies. Provides an exceptionally wide viewing cone—in both horizontal and vertical axes—with the uniformity required for demanding control center applications. Page 58.

DiamondScreen

—Draper’s optical rear projection screen. The Diamond-

Screen provides an extremely bright image with a full 180° viewing cone, making it perfect for use with CRT or low light output single lens projectors. The DiamondScreen’s optics are specially designed for the best reproduction of images projected by CRT projectors, with maximum brightness. Page 58.

HoloView—Revolutionary rear screen adds drama to point-of-purchase and public displays. The transparent screen is suspended in an inconspicuous aluminum frame. When a projector’s beam strikes it, the image seems to come from nowhere! Page 59.

Draper dealers and personnel will be pleased to give you personal assistance in selecting a rear projection screen to fit your requirements.

Complete specifications for all Draper rear projection screens and systems are located on the Internet at www.draperinc.com.

AT&T Solutions Presentation Center, Dublin, OH.

MultiScreen System with three  diagonal Dia-

mondScreens and custom front panels.

High Contrast Black

Draper’s High Contrast Black rear projection screen is a super high contrast black rear screen for videowall and other demanding requirements.

Provides vivid color contrast under any ambient lighting condition. Advanced optical light control and the totally black surface prevent ambient light from degrading the black level in an image. Available by quotation.

Cineframe

®

For Draper Rear Screens

3

/

4

"

Rigid rear screen installation costs and problems are virtually eliminated with factory-installed Cineframes. Simply place the screen in the finished wall opening, shim into position and trim as desired. No need to hire a glazier. Four styles available. All are extruded of 6063-t5 alloy anodized aluminum.

1

3

/

4

"

Vinyl gasket

Setting block

Extruded aluminum base

3"

Systems 300 and 200

System 400

System 400 simplifies your installation. Cut a rough opening 1⁄4 larger than the overall frame size, slide the screen in and bolt into place. No finish carpentry required. System

400 has a 3⁄4 wide dress trim that hides the opening. The audience only sees an attractive frame around a rear screen. Suitable for Cineplex in sizes through    in 3⁄8 thickness,

1⁄4

Cineplex in all sizes, IRUS and Vortex, and DiamondScreen in sizes through 160 diagonal, and 1⁄4 and 3⁄8 Cineglass in sizes through   . Black finish.

Screen

Vinyl gasket

Screen stop

Setting block

3

1

/

2

"

System 400

Removable sash

1

/

4

"

1

3

/

16

"

7

/

16

"

System 100

1

3

/

16

"

1

/

2

"

2

15

/

16

"

1

3

/

4

"

Gasket

System 300

Adds 1⁄4 to overall size of screen; reduces clear image area by  in each dimension.

Suitable for any Cinescreen 3⁄8 or 1⁄2 thick.

Black or clear anodized finish.

System 200

Same sturdy design as the System 300, extruded to a slightly thinner wall. Suitable for 1⁄4 and 3⁄8 Cineglass in sizes through

  

, 1⁄4 and 3⁄8 Cineplex in all sizes,

IRUS and Vortex in all sizes, and Diamond-

Screen through  diagonal. Black or clear anodized finish.

System 100

Simple, clean frame for smaller rear screens.

Adds 3⁄4 to overall height and width of screen; reduces clear image area by 7⁄8 in each dimension. Suitable for 1⁄4 Cineglass in sizes through   , 1⁄4 Cineplex, IRUS, DiamondScreen and Vortex in sizes through

 diagonal. Black or clear anodized finish.

www.draperinc.com 765-987-7999

Planning For

Rear Projection

For best rear screen performance, a number of variables must be considered to determine the correct screen size, placement and optical qualities.

Size—For legibility, we suggest this rule:

• L = distance from screen to back row of seats

• Screen height ≥ l÷ for : aspect ratio. (For dual image presentation, use l÷. For Command/Control centers, use l÷).

Placement—Screen should be installed high enough for all seats to have an unobstructed view, but with its center no more than ° above the eye level of any viewer. In a room with a level floor, the bottom of the screen should be - above the floor.

Audience—Ideally, all viewers should be seated within ° of the projection axis and never more than ° off axis. The front row of seats should be set back at least twice the width of the screen.

Audience Lighting—Most Draper rear projection screens are designed for use in lighted rooms. Optical qualities will be enhanced if lighting is controlled so that no direct or reflected light strikes the screen.

��������

Projection Area—Ideally, the depth of the projection room should be x the screen width. This is often not feasible, so high quality first surface mirrors may be used

���

���

��� to fold the projection path, achieving the desired image size within a shorter distance. A Rear Projection

System from Draper is an easy, convenient solution.

(See page 62 for details.)

���� ���� ���� ���� ���� ��� ���� ���� ���� ���� ���

Cine 10

Gain 3.0

Photo courtesy of Ceavco Audio Visual Company

�������������

��������

���

���

���

���� ���� ���� ���� ���� ��� ���� ���� ���� ���� ���

Cine 13

��������

�������������

2.0

���

Brightness & Uniformity

1.0

0.5

���

���

The charts at right are useful for evaluating gain (brightness) and uniformity of Draper rear projection screens.

The flatter the curve within the cone where the audience will be seated, the more uniform the image they will see.

Many current projectors are much brighter in the center of the image than at the edge, so this is a critical factor in the success of your installation. The higher the curve against the “Y” axis, the brighter the image at center.

50˚ 40˚ 30˚ 20˚ 10˚ 0˚ 10˚ 20˚ 30˚ 40˚ 50˚

Cine 15

Viewing Angle

��������

���

���

���

���� ���� ���� ���� ���� ��� ���� ���� ���� ���� ���

Cine 18

�������������

��������

���

���

���

���� ���� ���� ���� ���� ��� ���� ���� ���� ���� ���

Cine 20

�������������

���� ���� ���� ���� ���� ��� ���� ���� ���� ���� ���

Cine 25

�������������

Cinescreen optical coatings offer the opportunity to customize your rear projection screen for a precise fit to your room and projection equipment. Select the optical coating for brightness and uniformity, choose the optical tint to set the contrast level and specify the desired substrate. (See page 57 for details.)

IRUS

���� ���

���

���

The IRUS provides outstanding uniformity and legibility with projectors of all types. This screen was designed specifically to meet the resolution needs of SXGA,

UXGA and higher projectors. (See page 56.)

The new Vortex combines the best features of two rear screen technologies—optical and diffusion. Provides extraordinary uniformity and a broad viewing cone. (More information on page 58.)

Vortex

��������

��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� �� �� �� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ���

��������������

���

���

���

���� ����

DiamondScreen’s complex cast acrylic lens system distributes projected light in a wedge-like formation covering a wide horizontal viewing cone, minimizing vertical light distribution. Provides excellent brightness and uniformity with CRT projection. The Diamond-

Screen optics may in some cases conflict with images from single-lens video and data projectors. (Refer to page

58 for more on DiamondScreen.)

���� ���� ���� ���� ���� ���� ���� ���� ���� ���� ���� ��� ��� ���

�������������

����

DiamondScreen

���� ���

���� ���� ���� ���� ���� ���� ���� ���

���

���

����������

������������

���

���

���

��������

������������

��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� �� �� �� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ���

��������������

www.draperinc.com 765-987-7999

55

Rigid Rear Projection Screens

56

ConAgra Foods, Continental Divide Training Room, Greeley, CO. Second Prize, Classrooms and Training Facilities, 2002 Best Presentation Rooms,

Presentations Magazine. diagonal IRUS rear screen. Photo courtesy of Ceavco Audio Visual Co. Inc.

IRUS—

I

nfinite

R

esolution

U

niformity

S

creen

Nominal

Diagonal

60

67

72

84

Image*

Area

36 x 48

Overall

Size

37 x 49

501⁄2 x 671⁄4 511⁄2 x 681⁄4

Net

Wt. (lbs.)

16

401⁄4 x 535⁄8 411⁄4 x 545⁄8 18

431⁄4 x 575⁄8 441⁄4 x 585⁄8 20

27

90

96

100

120

54 x 72 55 x 73

575⁄8 x 767⁄8 585⁄8 x 777⁄8

60 x 80

72 x 96

61 x 81

73 x 97

31

44

46



HDTV Format (16:9)

92 45 x 80 46 x 81 31

106 52 x 92 53 x 93 52

*Image area listed is typical and choice of framing may cause a variation.

When legibility is the key.

The Draper IRUS—Infinite Resolution Uniformity Screen—is specifically designed to provide maximum legibility with any projector. Today’s SXGA and UXGA displays offer higher resolutions than ever before—which means more information for your audience to absorb. With these projectors, you need a screen that’s up to the challenge.

In order to convey an increasing amount of information to the viewer, the IRUS uses proprietary technology to display the sharpest, most uniform image you’ve ever seen.

An improvement for every rear screen application, the IRUS actually provides higher resolution than the human eye can perceive. The image is so consistent that it can be clearly seen even at 90° off axis (although most subject matter would be extremely distorted from this perspective). Brightness is consistent from center to corner—free of

“hot spots”. The IRUS provides excellent contrast, even in lighted rooms, with superior color reproduction.

The IRUS is perfect for command and control centers, where operators often have to watch for small changes in a large grid of screens for hours on end. Under those demanding conditions, the IRUS offers—

Uniform resolution compatibility

Uniform center–to–corner brightness

Superior color reproduction

Excellent contrast

Unique antiglare finish on 1⁄4 acrylic substrate

1.0 gain

180° viewing cone

Sizes up to  diagonal

Ideal for SXGA or UXGA displays; ready for the next generation of higher resolution projectors

Installation

When framing a single screen, select Draper’s System 100, 200 or 400 framing systems

(see page 54). For multiple screens or VideoWall applications, our Zero Edge, Clear

Lexan or System 200 VideoWall Framing Systems are compatible (see page 60).

www.draperinc.com 765-987-7999

Cinescreen

®

Only From Draper

Fakespace WorkWall in automotive application.

Installation by Fakespace Systems.

Draper Cinescreens differ from any other rigid rear projection screens in two extremely important respects:

 Cinescreen optical coatings have been formulated to provide inherent abrasion resistance. No other manufacturer offers you this protection.

 Only Draper offers you a choice of six different optical coatings, each of which is available in your choice of three unique optical tints. With a

Draper Cinescreen, you can select the optimum combination of optical coating and tint based upon your projection equipment, audience seating pattern, desired contrast level, screen aspect ratio, ambient light level and aesthetic considerations. Only Draper offers you this versatility. Draper dealers and personnel will be pleased to give you personal assistance in determining the ideal optical coating and tint for your particular requirements.

Planning Checklist

When specifying or ordering a Cinescreen, we need to know the following:

 Dimensions  Substrate  Thickness  Optical coating

Tint  ArmorKote or NonGlare, if required

 Factory-installed framing—system number and finish, if required

Substrates

Draper uses the finest plate glass and clear acrylic as Cinescreen substrates. Optical qualities are very similar: today’s acrylics have been improved and exhibit slightly better transmission than plate glass. Here are some other distinguishing characteristics:

• Cineglass

®

—Recommended for maximum sound isolation, scratch resistance, and service life. Weighs approximately twice as much as acrylic, breaks more easily, must be installed by a glazier.

Cineplex

®

—Lightweight, durable and break resistant. Easier to install.

Requires more care in cleaning, as acrylic scratches more easily than glass.

Less soundproof than glass.

Optical Tints

The optical tint is an important modifier of the optical coating. Tint influences image contrast and color value. All six optical coatings are available in 3 optical tints (ng, hc, w), to allow the specifier to select the optimum combination of brightness, viewing angle and contrast level for the planned installation.

HC—High Contrast (e.g. Cine 13hc)—Dark grey tint. Exceptional contrast and color rendition. Excellent light dispersion properties. Enhances legibility of computer generated data displays with light or bright text against a dark background: dark colors and black are reproduced with remarkable accuracy. HC tint performs equally well with static and moving displays.

NG—Neutral Grey (e.g. Cine 13ng)—Standard formulation.

Medium grey tint. Normal contrast levels and good color rendition. Brightness levels are uniform throughout entire viewing cone. Suitable for all projection formats and images.

W—White (e.g. Cine 13w)—Neutral white tint. Low contrast levels with some loss in color rendition. Enhances rear screen’s ability to reflect a laser pointer beam. Not recommended for computer graphic/data displays. Requires lower light level in audience area.

Be sure to specify ng, hc, or w along with the required optical and protective coatings.

Optical Coatings

Cinescreens may be furnished with your choice of six optical coatings:

• Cine 10—Ultra-wide angle coating for maximum center-to-corner uniformity of projected image: gain 1.0. Suitable for high output projectors.

• Cine 13—Gain of 1.3, with extremely broad viewing cone and uniform distribution of projected light. For all formats, including higher-luminance projectors.

• Cine 15—Benchmark wide-angle coating. Gain of 1.5, with uniform distribution of projected light. For all formats, including higher-luminance projectors.

• Cine 18—For medium to wide-angle viewing, with on-axis gain of 1.8.

Suitable for all projection formats, including video.

• Cine 20—Peak gain ., with a somewhat broader viewing cone than

Cine 25. Suitable for relatively high ambient light conditions. For all projection formats, including data, graphics and video.

• Cine 25Suitable for narrow viewing cones and lower output projection formats. On-axis gain of 2.5. Good image resolution, color reproduction.

Optional Coatings

Cineglass Cineplex

Thickness

1⁄4 3⁄8 1⁄2 1⁄4 3⁄8

1⁄2

Max. Size* 72 x 96 120 x 204* 120 x 204* 100 x 150 108 x 240* 108 x 240*

Weight/sq. ft (lbs.)

Net 3.5

Shipping 8.5

5

10.5

7

12.5

1.5

6.5

*Larger sizes available on request. Contact Draper for details.

2.5

7.5

3.5

8.5

• ArmorKote ®

—While Draper’s optical coatings are inherently abrasion resistant, further insure your Cinescreen against damage by adding ArmorKote treatment. Highly resistant to solvents, abrasion and normal impacts of fingernails, pointers, pencils and pens. While ArmorKote will be damaged by repeated or willful abuse through impacts of sharp objects, use as a writing surface, etc., it is an excellent “insurance policy” against accident and error.

Virtually impervious to grease, oil and ammonia; very resistant to most solvents, even permanent markers and chalk. It is invisible, does not affect image quality and is by far the toughest protective coating available.

NonGlare—Applied to front or viewing side of the screen for anti-reflective properties. Slightly diminishes resolution. Recommended when using certain mirror systems and/or optical coating is being installed toward the projector. Ask for more details.

Installation

Draper Cinescreens may be framed at the job site or shipped with a factory-installed Cineframe ® (detailed on page 54). Cinescreens are usually installed with the coated side facing the audience. The coated side may be installed toward the projector when there are concerns about abuse, with only a slight reduction in image quality.

www.draperinc.com 765-987-7999

57

58

Rigid Rear Projection Screens

Vortex

Combining the best of optical and diffusion rear screen technology.

The new Vortex is a marriage of the best features of two rear screen technologies— optical and diffusion.

A 0.5 mm Fresnel lens gathers the light from the projector and directs it at a right angle through the screen. As the light exits the screen on the audience side, a diffusion medium redistributes the light evenly in all directions—up, down, left, right and center. The result is an extraordinary projected image with—

Superior resolution

Superb color contrast

An exceptionally wide viewing cone in both the horizontal and vertical axes

Extraordinary center-to-corner brightness ratio

Uniform brightness without hot spots

The unique features of the Vortex provide important advantages and benefits—

The Vortex is designed for use with single lens projectors

Projected light is collimated, then diffused evenly, making the Vortex well suited for use in videowalls and rooms with tiered seating patterns

Charcoal grey tint provides superior color contrast even under harsh ambient light

The diffusion medium is in the acrylic, so the diffusion medium can’t be scratched or damaged

Large Sizes

Photography by Barry Rustin, Evanston, IL.

The Vortex is available in sizes up to and including 160 diagonal NTSC Video format.

Installation

When framing a single screen, select Draper’s System 100, 200 or 400 framing systems.

See details on page 54. For multiple screens or VideoWall applications, our Zero Edge,

Clear Lexan or System 200 VideoWall Framing Systems are compatible.

Nominal

Diagonal

60

67

72

84

90


Area

Overall

Size

36 x 48 37 x 49

401⁄4 x 535⁄8 411⁄4 x 545⁄8

431⁄4 x 575⁄8 441⁄4 x 585⁄8

501⁄2 x 671⁄4 511⁄2 x 681⁄4

54 x 72 55 x 73

96

100

120

575⁄8 x 767⁄8 585⁄8 x 777⁄8

60 x 80 61 x 81

72 x 96 73 x 97

125 743⁄4 x 993⁄4 753⁄4 x 1003⁄4

140 853⁄8 x 1133⁄8 863⁄8 x 1143⁄8

150 913⁄8 x 1213⁄8 923⁄8 x 1223⁄8

160 973⁄8 x 1293⁄8 983⁄8 x 1303⁄8

HDTV Format (16:9)

92

106

119

133

45 x 80

52 x 92

58 x 104

65 x 116

46 x 81

53 x 93

59 x 105

66 x 117

DiamondScreen

The brightest rear projection screen in the world.

DiamondScreen ™ —the first rear projection screen designed specifically for video and data projection. Unlike conventional rear screens, the DiamondScreen is cast

(molded) and derives its incredible optical performance from its patented Fresnel/ lenticular lens system. Particularly well suited for use with CRT or low light output single lens projectors.

The DiamondScreen offers—

The world’s most sophisticated, efficient rear projection screen

A panoramic 180° horizontal viewing cone, and the largest vertical viewing cone of any product of its type

High Contrast grey optical tint, for superior color contrast

Anti-reflective properties for superior performance even under conditions of high ambient light

Superior corner-to-center brightness ratio, with no “hot spots”

3.5 gain on axis

The widest range of sizes—and the largest sizes—in the industry

DiamondScreen is available in any custom size up to a maximum overall size of

  

(see chart on page 59).

Factory installed Cineframes ® are also available to simplify installation—refer to page 54 for details.

31

52

71

83

Two  DiamondScreen rear projection screens.

Health Science Center at University of Wisconsin-La Crosse.

Photo courtesy of SPL Integrated Solutions.

Net Wt.

(lbs.)

31

44

46

66

71

128

16

18

20

27

146

165

www.draperinc.com 765-987-7999

HoloView

Transparent rear screen. You’ve never seen an image like this before.

The HoloView rear screen stops prospective customers in their tracks. Grab the spotlight at trade shows, in showrooms, shopping malls and any retail environment. Cast a dramatic visual image in museums, banks, entertainment venues—anywhere you need to catch your audience’s eye.

A HoloView screen consists of transparent 1⁄4 acrylic, with an optical medium in its matrix. The viewer can see a clear image—and see through the screen—at the same time.

For the most dramatic visual images, the HoloView should be suspended from wires or cables so the projected image appears to be floating in space. Screen is provided with aluminum grip strips at top and bottom for this purpose. Compatible with any single lens projector with digital keystone correction. Projector should be placed 22-36° off perpendicular from the plane of the screen—above or below. The HoloView rejects incident light, so you don’t have to enclose the projection area—you can even hang this screen in a store window!

Large Sizes

The HoloView is available in sizes through 120 diagonal. All sizes are single element, without seams or visible lens pattern. The sharpest, clearest and most accurate transparent image you’ll find.

System Options

• Aluminum grip strips standard at top and bottom. Also available on left and right.

• Standard screen orientation is horizontal (landscape). May also be hung vertically

(portrait position).

• Typical installation is free hanging. In-wall installation also possible, using System 100 or 200 Cineframe (see page 54).

Dantanna’s Surf & Turf Restaurant, Atlanta, GA.

Photo courtesy of Communications & Entertainment

Inc. (CEI), Atlanta, GA.

HoloView

Nominal

Diagonal


Area 1

Overall

Size 2

Net

Wt. (lbs.)

40

46

50

60

67

201⁄2 x 333⁄4

245⁄8 x 385⁄8 273⁄4 x 385⁄8

267⁄8 x 423⁄8 30 x 423⁄8

331⁄8 x 503⁄8

373⁄8 x 551⁄8

235⁄8 x 333⁄4

361⁄4 x 503⁄8

401⁄2 x 551⁄8

9

10

11

15

19

72

84

90

3

96

3

100

3

110

3

120

3

401⁄8 x 60

471⁄4 x 693⁄4 503⁄8 x 693⁄4

507⁄8 x 743⁄8

535⁄8 x 80

563⁄8 x 841⁄4

601⁄2 x 925⁄8

431⁄4 x 60

54 x 743⁄8

563⁄4 x 80

591⁄2 x 841⁄4

635⁄8 x 925⁄8

21

29

33

37

41

45

667⁄8 x 1007⁄8 70 x 1007⁄8 49

1

With aluminum grip strips at top and bottom of screen.

Grip strips also available on left and right sides through  diagonal.

2

Aluminum grip strips will add 1⁄8 to relevant dimension.

3

Large Screen Mounting Frame at top and bottom of screen. Draper recommends framing  diagonal screens and larger to prevent bowing.

DiamondScreen

Nominal

Diagonal


*

Area

Overall

Size

Net Wt.

(lbs.)

60

67

72

84

90

96

100

120

125

140

1

150

1

160

1

170

2

180

2

190

2

200

2

36 x 48

401⁄4 x 535⁄8

431⁄4 x 575⁄8

501⁄2 x 671⁄4

37 x 49

411⁄4 x 545⁄8

441⁄4 x 585⁄8

511⁄2 x 681⁄4

54 x 72

575⁄8 x 767⁄8

60 x 80

72 x 96

743⁄4 x 993⁄4

55 x 73

585⁄8 x 777⁄8

61 x 81

73 x 97

753⁄4 x 1003⁄4

853⁄8 x 1133⁄8 863⁄8 x 1143⁄8

913⁄8 x 1213⁄8 923⁄8 x 1223⁄8

973⁄8 x 1293⁄8 983⁄8 x 1303⁄8

1013⁄4 x 1353⁄4 1031⁄4 x 1371⁄4

1073⁄4 x 1433⁄4 1091⁄4 x 1451⁄4

1133⁄4 x 1513⁄4 1151⁄4 x 1531⁄4

1181⁄2 x 1581⁄2 120 x 160

HDTV Format (16:9)

92

106

119

133

1

161

2

45 x 80

52 x 92

58 x 104

65 x 116

80 x 140

46 x 81

53 x 93

59 x 105

66 x 117

81 x 141

31

52

71

83

150

* Image area listed is typical and choice of framing may cause a variation.

1 These sizes require factory installed System 200 frame.

2

These sizes require Large Screen System Frame (not factory installed).

31

44

46

66

71

128

146

16

18

20

27

165

238

244

263

269

www.draperinc.com

HoloView

Typical HoloView Installation Method

765-987-7999

Range of projector lens “hotspots”:

The HoloView is designed for the projector to be installed off axis for eye comfort.

Select projector position to fit location and usage.

22

˚

35

˚

59

60

Rear Projection Systems

Custom VideoWall

Framing Systems

Essential to our superior VideoWall design.

Multiple rear screen VideoWalls are used in command and control rooms, network operations centers, sports and gaming venues, point of purchase advertising and the entertainment industry. Since 1985, Draper has developed a particular expertise in the design and manufacture of custom rear screen

VideoWalls and related products for electronic information display. With installations in more that 70 countries, Draper is the acknowledged world leader in the most demanding area of the projection screen industry.

With more unique types of rear projection screens, videowall framing systems, and projector mounting systems, and more combined years of design experience than any other projection screen manufacturer, Draper’s highly skilled engineers can provide an optimum solution for any information display requirement. Both technological and human factors are always carefully considered. All proposals are supported by CAD-generated dimensional drawings.

The IRUS, Vortex, Cineplex and DiamondScreen may be used in a

VideoWall, with individual screen sizes from  diagonal through  diagonal. Draper offers three VideoWall framing systems.

Caltrans, Irvine, CA.—Transportation Management Center. Installed by MCSi. A 3 x 3 MultiScreen System of IRUS screens in Zero Edge frames. Includes custom monitor arrays.

Zero Edge Framing System

Draper’s mullionless Zero Edge Framing System is the first and only optically seamless large screen videowall framing system. Zero Edge incorporates a proprietary screen attachment system supported by extruded aluminum light baffles on all four sides. Screens are assembled with “zero” separation. Actual screen separation is approximately .5 mm.

Zero Edge VideoWall modules may be installed in-wall or can be incorporated in a freestanding Draper

MultiScreen System. Panoramic or tilted VideoWalls are possible in any configuration. Individual modules are completely self-supporting, reducing the possibility of screen warpage. U.S Patent No. 6,000,668.

Close Edge Clear Lexan

®

Framing System

Individually framed screen modules with a “close-edge” transparent Lexan perimeter support frame, for a near-seamless appearance. Actual screen separation is approximately 4 mm. Screen modules include an extruded aluminum light baffle on all four sides. These modules are assembled within an existing rough opening. Panoramic or tilted VideoWalls are possible with Clear Lexan frames. U.S. Patent

No. 6,296,214.

�������������������

�������

���������

������

�������������������������

�������������������

�����������������

����������������������

����������������������

System 200 VideoWall Framing System

Offers maximum flexibility of design and structural integrity while accommodating rear screens of any size. Completely unitized for perfectly uniform contiguous images regardless of the number of screens or tiers in the array. The manufacturing and assembly of complex panorama radius VideoWalls is executed with precision and unparalleled structural integrity.

A patented two-piece image separator system, consisting of vertical mullions and horizontal muntins, enables removal of individual screens within the videowall without disturbing the rest of the system. Light separating baffles eliminate overscan between adjacent projected images. All System 200 components are extruded aluminum with black anodized finish. Every component is stamped and coded, and detailed assembly instructions and legend are provided. U.S. Patent

No. 5,103,339.

��������������������������� � �

����������������������

����������������

���������������

�����������������

��������

����

��������������

���������

����

��������������������������������

���������������������������������������

����������������

� � �

��

���� � �

��

�������������������

�����������

���������������

�������������������� � �

��

���� � �

��

www.draperinc.com 765-987-7999

MultiScreen System

The Draper MultiScreen System is a unitized, self-supporting rear screen/projector cradle/first surface mirror system designed for control center and other videowall installations. Each unit consists of 2 or more rear screens, cradles and mirrors, all positioned in the exact required relationship to each other and to the audience. A projector access panel is located at the bottom, and is equipped for easy removal without tools.

• Designed and custom built to your specific requirements.

• Totally unitized and designed to conserve floor space.

• Available 2, 3, or 4 screens high, with upper screens tilted as necessary.

• Alignment Platform available for precise positioning of projectors.

• Choice of rear screen: IRUS, Vortex, Cinescreens or DiamondScreens.

Typical MSS

(2 screens shown)

• Choice of screen frames: Zero Edge (optically seamless) or transparent Clear Lexan ® .

• Screen sizes from  through  diagonal.

Projector Support Structures

When building a custom videowall system, video and data graphics projectors must be safely and securely mounted at the proper focal distance from the screen. Draper offers sophisticated Projector Support

Structures, designed and built to your specific requirement. Projectors will be positioned in the exact required relationship to a multiple screen videowall. Features:

• Custom-fitted projector cradles

• Machined aluminum pivot plates for quick alignment

• Unitized welded tubular steel framework

• Optional Alignment Platform for precise positioning of projectors

• Available in any grid configuration, in either straight throw or mirrored design.

• Mirrors, if required, are 94% reflective optical grade fi rst surface glass. (See page 64.)

VideoConferencing Camera Box

Draper’s VideoConferencing Camera Box makes installing a videoconferencing camera quick and easy. The box allows the camera to be recessed in the wall, behind a hinged tempered glass door. The installer simply cuts the desired opening in the wall, inserts the five-sided steel enclosure and engages the “quick clamps”. No additional hardware or brackets are required. There’s no finishing either: the box features a bezel that trims the rough opening.

All visible surfaces are finished with black epoxy powdercoat. Four convenient cable exits make wire management a simple proposition. Suitable for use with thin panels or gypsum board wall openings. Size is 7⁄8 high  3⁄8 wide   deep. Also available in locking version to protect sensitive equipment. Two keys provided.

Features Include:

• Precision formed and punched from -gauge cold rolled steel.

• Finished inside and out with durable black epoxy powdercoat.

• Front of enclosure features a 7⁄8 finishing frame bezel that is self-trimming.

• Enclosure features four “knock out” wire management locations for cabling options.

• Enclosure will mount in any opening utilizing built-in “quick clamps” that can clamp to most walls or panels.

• Glass door is hinged to fold down for easy access.

Custom IDS products

Draper specializes in custom rear screen products and configurations for simulation applications, virtual reality systems, point-of-purchase displays, command and control centers, network operation centers, conference rooms, board rooms, training rooms, commercial simulation, product and process design, sports and gaming venues, broadcast and teleconferencing. Contact your Draper dealer for details.

www.draperinc.com 765-987-7999

61

62

Rear Projection Systems

Draper RPX—

Rear Projection System

Takes the guesswork out of rear screen system design.

Draper designed the Rear Projection System to provide perfect rear screen picture quality, while saving valuable floor space. The RPX folds the light from a video, datagraphics, LCD, DLP, CRT, digital, or slide projector using the finest optical quality, first surface glass mirror.

The RPX consists of a custom designed projector cradle, first surface glass mirror, and a unitized framework of blue extruded aluminum to position the pro jec tor and mirror in precisely the right relationship to each other and to the rear screen.

The projector cradle is customized for your projector, and allows for both tilt-axis adjustment and micro-fine height adjustment—without tools—to position the image on the rear screen. The cradle holds a six axis adjustment sled allowing movement to be modifi ed for best image alignment.

The real beauty of the RPX is that it is built specifically for your unique requirement.

You provide us with the make and model of projector, desired screen size, and a few simple room dimensions. Our designers evaluate the optics and determine the proper light path geometry. The RPX is preset for a perfect fit. If the room dimensions or pro jec tor specifi cations change, the RPX can now be adjusted in the field. Mirror height, pro jec tor height, mirror angle, and projector position (front to back) are all adjustable.

The RPX ships complete with all required fasteners and hand tools.

RPX System Components

Supporting frame is constructed of unitized framework of blue extruded aluminum with a  square cross section, fabricated from - alloy. It is sized to fit perfectly in your projection room, based upon dimensions you furnish.

Sled Base features heavy-duty leveling feet and predrilled anchor points: when the system is correctly set, it may be permanently fastened in place.

Pivot plates are predrilled for the proper angle of installation, and calibrated in degrees for quick, precise adjustments if required. Mirror plate features shoulder bolts to simplify installation and slots for height adjustment.

Projector cradle is custom-fitted to your projector. It is positioned on the frame in exactly the proper location for correct geometry. Pre-drilled adjustment holes allow for changes in room confi guration. Cradle formed of –ga. steel, finished in black epoxy powdercoat and predrilled for your projector.

Glass, first surface mirror is 94% reflective, box framed in black anodized aluminum. Sized and positioned to reflect a perfect image on the rear projection screen. Height and angle may be adjusted when needed.

The RPX features metallic blue aluminum extrusions.

The standard RPX con fi g u ra tion is pictured above.

6-Axis Adjustable Platform

Draper’s new -Axis Adjustable Platform is standard with all RPX and RPX/Complete units. The platform allows all movement to be modifi ed for best image alignment. The projector light path can be adjusted in all  axes for a perfect picture every time.

Exclusive Features for Adjustability

Mirror Pivot Plate—The new mirror pivot plate makes mount ing the mirror much easier: shoul der bolts mean the mirror can simply be lifted into position and sta bi lized at the proper angle while a second bolt is installed. After installation, adjusting the height or angle of the mirror is easy with the cal i brat ed plate and predrilled ad just ment holes.

Cradle Pivot Plate and Height Adjustment—

With the new calibrated pivot plate, micro-fi ne fi nger adjustment of tilt angle and height, and cradle-to-mirror dis tance adjustment, re set ting the RPX in the fi eld is simple. You may even be able to adjust for a new projector. Draper can provide en gi neer ing as sis tance with readjustment as well as with the orig i nal setting.

alignment. See page 64.

www.draperinc.com 765-987-7999

RPX/Complete

The Draper RPX/Complete has all the features of the RPX plus a framed rear screen at tached to the structural uprights. Choice of an IRUS, Vor tex, Cinescreen or DiamondScreen in a

Sys tem 400 frame attached to the RPX for a per fect ly aligned system. Screen sizes through  high x  wide. The advantages of an RPX/Complete are staggering:

• Framed screen “fl oats” in your wall opening. The wall does not bear the weight of the screen, so no fi nishing or reinforcement of the opening is required. Cut a rough opening and set up the system.

• Since the wall’s expansion/contraction properties do not put pressure on the screen, the result is a consistently fl atter screen.

• Each element in the system is locked into its proper relationship, square with the others: screen-to-projector platform; projector platform-to-mirror; mirror-to-screen.

• Save installation time. Assemble the system, adjust the leveling feet on the base of the RPX and the entire system is level.

• Since the screen is automatically square with the mirror, installation of projector and alignment of image is made easier.

RPX/Precision

The Draper RPX/Precision offers the world’s most precise image alignment ca pa bil i ties in a custom-built rear projection system. Why is that so important?

Today’s digital projectors often allow little or no electronic image position adjustment. Therefore, precise physical positioning of the projector becomes critical in aligning and edge matching side-byside images, and even in precisely locating a single projected image.

With incredible accuracy, the fi ne tuning capabilities of the Draper RPX/Precision Alignment

Platform gives you isolated adjustment of each individual projector in all six axes: height, front-toback position, side-to-side position, pitch, roll and yaw.

Draper’s unique Alignment Platform will allow single lens projectors, which have no internal or electronic adjustments, to adjust horizontal keystone, image size, image shift and image rotation.

Alignment Platform is also available in a lightweight version for today’s smaller projectors.

Alignment

Platform

Front-to-back adjustment knob

Yaw adjustment knob

Side-to-side adjustment knob

Roll adjustment knob

Cradle pivots on pivot plate for pitch adjustment

The RPX/Precision with

Alignment Platform can be adjusted in all six axes. Also available with Projector

Support Structure and Multi-

Screen System. See page .

RPX/Lite

The Draper RPX/Lite is an economical mirror system designed for use with lighter weight LCD and DLP projectors. Any projector weighing less than 50 pounds is suitable for the RPX/Lite.

This mirror system is lighter in overall weight but maintains the same high quality workmanship and superior components as our RPX and RPX/Precision systems. Stability, rigidity and precise engineering are not compromised on the RPX/Lite. Your projector sits on a black laminate projector shelf, secured through mounting holes pre-drilled at the factory to fit its footprint.

The RPX/Lite incorporates many of the features that make Draper units the fi nest in both engineering and execution: Draper first surface optical grade glass mirror; alignment holes on pivot plates of both the mirror and projector shelf for quick precise alignment; heavy-duty leveling feet and predrilled anchor points; easy to follow assembly instructions. Includes the hand tools needed for assembly.

www.draperinc.com 765-987-7999

63

Rear Projection Systems

64

First Surface Mirrors

Sold separately, or with rear screen systems.

Draper provides optical grade first surface mirrors for improved rear projection image quality.

First surface mirrors are frequently used in rear projection systems design to fold the light from the projector, reducing the required depth of the projection area behind the rear screen. Conventional mirrors are not satisfactory for this purpose, because the reflective coating is on the back side of the glass. Under projection, the majority of light would be reflected by the reflective coating and a minority by the first surface of the mirror, resulting in an objectionable double image.

Draper first surface mirrors consist of a 94% reflective optical grade vacuum coating on a 6 mm thick glass substrate.

We offer first surface mirrors in nine standard sizes ranging

Mirror Standard Sizes

from    through   , or in any custom size of your choice. Mirrors are available with or without a factory installed protective frame.

Mirror

Size (H x W)

25 x 40

Mirror

Size (H x W)

48 x 60

First surface mirrors are also provided with Draper Rear

Projection Systems, MultiScreen Systems or Projector Support Structures, all designed specifically for your projection requirement (see page 61-63).

30 x 40

43 x 50

43 x 60

43 x 74

48 x 74

60 x 90

74 x 100

Larger and cut down sizes available.

Draper also offers a unique and highly effective stiffening system for mirrors    and larger. This system ensures flatness and eliminates the pin cushion effect, double imaging and dead spots, resulting in significantly improved image quality.

Projection room at Michigan Virtual University,

Lansing. Installation by AXXIS Incorporated.

Mirror Manager

No more lost pixels.

You may know how tough it can be to make those final tweaks so the projector will put a perfectly square image on the rear projection screen. Lining up all the images in a control center videowall may be the work of several days. Mirror Manager is

Draper’s innovative solution to that problem.

The Mirror Manager may be used as part of a Draper Rear Projection System,

Retro, MultiScreen System or anywhere a Draper first surface mirror is installed.

With Mirror Manager, the final image adjustments are quick and easy. After you have adjusted all the larger controls: the projector, its platform, and mirror position… then Mirror Manager goes to work. Using its hand-operated knobs, you can quickly fine-tune the image to eliminate pincushioning, barrel distortion and just to square up the corners. The mirror remains securely mounted in a black anodized extruded aluminum frame.

Mirror Manager saves installation time and money— and improves the image—by actually bending the mirror in tiny, highly controlled increments. Use eight knobs around the perimeter to make the precise adjustment you need. Mirror Manager should be used only for those minor tweaks that look so easy and take so long without it.

Retro/QA

Retrofit any room with rear projection.

We custom design and build the Retro/QA based upon your choice of projector and screen. Select any projector and any screen size through  diagonal.

Screen Size

(diagonal)

The Retro/QA is a portable, self-contained rear projection system. Disassembles for transport or storage.

All components fit through a standard door. Assembles easily and quickly on site. Includes the Draper IRUS,

Cineplex, Vortex or DiamondScreen with a 3⁄8 low profile frame of black anodized aluminum or clear matt

Lexan.

60

67

72

84

90

96

Overall Size*

H x W x D

921⁄2 x 48 x 48

921⁄2 x 541⁄4 x 50

921⁄2 x 587⁄8 x 56

1021⁄2 x 681⁄2 x 60

1061⁄2 x 741⁄4 x 64

1101⁄2 x 79 x 68

100 1121⁄2 x 821⁄4 x 731⁄2

The Retro/QA features the same high quality projector cradle and first surface mirror assembly as other Draper

Information Display Systems products. Also available: Alignment Platform, Zero Edge framing,  urethane swivel casters, -outlet surge protected power strip and cooling fan. Multiple units will abut to form a portable videowall. May be finished in your choice of laminates or veneers.

120 1161⁄2 x 981⁄4 x 96

125 1181⁄2 x 101 x 98

Distance From

Bottom of Screen to Floor

561⁄2

501⁄2

48

503⁄4

503⁄4

505⁄8

501⁄4

421⁄4

421⁄2

*Above dimensions are typical, and will vary for certain projectors. If in doubt, contact Draper for exact dimensions.

Memphis, TN, Welcome Center. Photography by

Michael J. Dougherty.

www.draperinc.com 765-987-7999

Easels

Draper Easels

For effective visual presentations.

Quality easels from one of America’s oldest and largest manufacturers of visual communication products. Draper Easels stand rock-solid on wobble-proof legs, fold easily for transport or storage. Numerous exclusive features insure effective, trouble-free visual presentations time after time.

Draper offers the largest selection of paper pad, dry-erase, poster and decorative display easels in the world. From heavy-duty models to decorative poster units, Draper offers easels for every situation. Careful attention to quality, function and appearance, plus an expanded range of decorative finishes, make Draper the world’s premier line of professional easels.

In paper pad and writing surface easels, Draper offers two separate standards—DR

Series and OP Series. Both are carefully assembled of high quality components with all-riveted construction.

DR Series

Constructed entirely of the highest quality structural grade aluminum alloy. Exclusive features such as a spring-loaded paper pad clamp, ball detent leg locks, hinged pen tray/ chart shelf, hinged chart holders and a hinged storage compartment for writing instruments make Draper DR Series Easels the preferred choice of professional presenters.

OP Series

OP Series Easels use many of the same high quality components as the DR Series, and feature a spring-loaded paper pad clamp and ball detent leg locks. These have a trim, fixed pen tray and do not have hinged chart holders or a storage compartment. OP Series Easels feature a rugged, magnetic steel backboard.

Quality, Function and Appearance

Spring-Loaded

Paper Clamp

Paper pad attaches instantly to studs concealed under spring-loaded clamp. Pad is held securely in place—no moving parts to get lost.

Accessory Storage Box

Writing instruments are safely stored in the builtin storage compartment on all Draper DR Series

Easels. Latch releases at the touch of a lever.

Ball Detent Leg Locks

Rugged ball detent hinge assembly automatically locks legs in place, releases at the touch of a finger. No exposed parts to bend or break.

Rubber Leg Tips

Rubber leg tips keep your easel firmly in place on any floor— won’t “walk” when you write.

Gold Anodized www.draperinc.com

Hinged Pen Tray

Hinged tray holds markers, eraser and charts. Folds flat for transport or storage. No protruding parts to break or to damage other equipment. Standard on DR Series Easels.

Fixed Pen Tray

Narrow profile for transport or storage, yet large enough for markers, pointer, eraser or charts. Made of heavy-gauge steel. Standard on OP Series

Easels.

Hinged Chart Holders

Aluminum arms fold down to support a hefty 80 lbs. of posters or charts. Arms fold fl at when not in use. Standard on DR Series Easels.

Grey Epoxy Powdercoat

Finishes

These finishes are available for many of the products in our Easel line.

Silver Anodized

765-987-7999

Black Epoxy Powdercoat

65

66

Easels

Paper Pad Easels

DR Series/OP Series

DR400/OP400 —Grey Epoxy Powdercoat DR500—Silver Anodized

DR450/OP450—Black Epoxy Powdercoat DR550—Gold Anodized

Quality, durable Paper Pad Easels available in two series: DR and OP. Both offer a

28 x 38 panel to accommodate all standard easel paper pads. Folds from 70 height to a compact 28 x 38 x 2. Finished in tough epoxy powdercoat or attractive brushed anodized aluminum.

The exclusive features of the all-alluminum DR Series are depicted on page 65. Hinged chart holders and pen tray/chart shelf allow for poster presentations at different heights.

The OP Series features spring-loaded paper clamp, ball detent leg locks and rubber leg tips. The backboard for OP Series easels is rugged magnetic steel. Fixed pen tray is standard. Chart holders and storage box not included.

Writing Surface Easels

DR Series/OP Series

DR800—Porcelain Whiteboard/Gold Anodized

DR850/OP850—Porcelain Whiteboard/Black Epoxy Powdercoat

All the quality and convenience of Draper DR Series Paper Pad Easels, plus a built-in white porcelain on steel writing surface. The surface is smooth, framed on all four sides and has no visible fasteners. Use it with a paper pad for prepared presentations or to preserve notes; without paper for impromptu “chalk-talks”. Chip-proof porcelain wipes clean instantly, never discolors. Useful for magnetic displays, or as a paper pad or poster easel.

The OP Series features include the spring-loaded paper clamp, ball detent leg locks and rubber leg tips. A fixed pen tray is standard. Chart holders and storage box are not included.

DR650—Powdercoat Whiteboard/Black Epoxy Powdercoat

Now you can have a lightweight, sturdy all-aluminum powdercoat easel, plus a dry erase writing surface! Provides the functionality of the DR850, at a lower cost. Legs, paper clamp and braces are finished in black, while the panel and its rivets are finished in dry erase white. The DR650’s dry erase finish will stand up to the toughest use and still wipe clean. All-aluminum construction makes a lighter easel without sacrificing strength.

OP450 and DR400

Options and Accessories

Vinyl Carrying Case SC30—Fits all models on this page.

Paper Pads (box of 4)

Paper Pad Marking Pens (set of 24)

Model Net Wt. (lbs.) Model Net Wt. (lbs.)

DR Series Paper Pad Easels

DR400 12

DR450 12

DR500 12

DR550 12

OP Series Paper Pad Easels

OP400 15

OP450 15

DR Series Writing Surface Easels

DR800 21

DR850 21

DR650 13

OP Series Writing Surface Easels

OP850 21

All units have the same dimensions when set up: 70 high x 28 wide, and fold to     .

Easel Accessories

PEN1 Paper Pad Pens—Quality water soluble chisel point marking pens. Set of 24 in black, blue, red and green, or all one color on request.

POR1 Dry-Erase Porcelain Marking Pens—Set of 4 includes black, blue, red and green. Ink dries instantly, wipes off porcelain with eraser or dry cloth.

CLE1 Porcelain Cleaner—Restores dry erase panel to original factory condition. 8 oz. pump spray bottle.

ER1 Eraser—For dry erase surfaces.

MAG1 Magnets—Set of 24 colorful button magnets for dry-erase porcelain easel presentations.

DR800 and DR650

Options and Accessories

Paper Pads (box of 4)

Paper Pad Marking Pens (set of 24)

Dry-Erase Marking Pens (set of 4)

Porcelain Cleaner

Eraser

Magnets (set of 24)

Writing Accessories

www.draperinc.com 765-987-7999

Heavy-Duty Easels

Paper Pad Easels

DR890—A-Frame Easel

Draper heavy-duty paper pad easels are the world’s toughest. Designed and built to perform time after time—and keep their good looks. Heliarc welded 1 square tubular aluminum frames and sturdy aluminum backboards take the hardest knocks with complete sta bil i ty.

The DR890 features an A-frame design and a durable satin silver anodized fi nish. Steel pen tray is fixed in position. Does not include accessory storage box. Entire unit folds flat for storage or transportation.

DR891—A-Frame With Casters

Identical to the DR890, but with roll-around casters (2 with locks).

DR895—Folding A-Frame

Like the DR890, but with folding legs. The entire unit folds to a compact

6 x 29 x 39. Fits op tion al SC30 carrying case.

Writing Surface Easels

DR990—Dry-Erase A-Frame Easel

The DR990 is identical to the DR890, described above, except that the panel and rivet heads are fi nished in dry-erase white powdercoat. Finally, a dry erase easel that can really stand up to the demands of the hotel and rental market!

DR995—Dry-Erase Folding A-Frame Easel

This sturdy easel also includes a dry-erase panel and rivet heads. Folding legs allow the entire unit to fold to a com pact 6 x 29 x 39. Fits optional SC30 carrying case.

DR990 and DR895

Options and Accessories

Vinyl Carrying Case SC30—Fits DR895 and DR995

Paper Pads (box of 4)

Paper Pad Marking Pens (set of 24)

Dry-Erase Marking Pens (set of 4)

Porcelain Cleaner

Eraser

Magnets (set of 24)

Model Height(Set Up) Dimensions(Folded) Net Wt. (lbs.)

DR890 72 4 x 29 x 72 19

DR891 75 4 x 29 x 75 21

DR895 72 6 x 29 x 39 20

DR990 72 4 x 29 x 72 19

DR995 72 6 x 29 x 39 20

SC20

Carrying Cases

SC30

Easel Carrying Cases

Attractive, durable leatherette carrying cases protect your easel and ac ces so ries in storage or transport. Reinforced stitching, zipper and closures.

SC20—For folding aluminum Poster Easels (Models DR250 and DR270).

SC30—For all Draper Paper Pad, Writing Surface and Heavy-Duty Folding Easels.

Easel Paper Pads

Standard 27 x 34 easel paper pads fit all Drap er easels and most other models. High quality 16 lb. white sulfite bond does not bleed. Se cure ly bound at top to heavy chipboard backing, and perforated for quick removal of used sheets. Drilled on 171⁄2 centers. Fifty sheets per pad, four pads per car ton ex cept as noted.

PP10

Plain 16 lb. white sulfite bond. Deluxe headstrip binds top of pad.

AV15

Same as PP10, but with out headstrip.

AV15-40

Same top quality pads as our standard AV15, but packed 40 sheets per pad, 5 pads per car ton.

GP20

16 lb. white sulfite, with 1 square light blue grid.

RP30

16 lb. white sulfite, horizontally ruled at

1 in ter vals.

67

Easels

Poster Easels

Folding Aluminum Poster Easels

DR250—Gold Anodized

DR270— Black Powdercoat

Lightweight yet rugged tripod easel can be used for posters or paper pads. Weighs only 7 pounds, travels easily and sets up in seconds. Hinged chart holders are attached to sturdy aluminum legs at four different heights for poster display.

Spring-Loaded Chart Clamp (standard) attaches without tools, accommodates standard easel paper pads. Folds easily to 41 x 51⁄4 x 2.

Non-Folding Aluminum Poster Easels

DR200— Gold Anodized

DR205— Black Powdercoat

DR220— Gold Anodized

DR225— Black Powdercoat

Sturdy tripod style easels. Hinged chart holders are riveted to sturdy aluminum legs at three different heights for poster display. These easels weigh 5 pounds or less, and flatten in one quick motion to  or  x 51⁄4 x 2 for storage.

Decorative Poster Easels

DR150—Brass Easel

Make an impression in hotel and restaurant lobbies, art galleries, museums, theatres—even shopping malls. Solid brass easel is fully lacquered to prevent tarnishing. Classic design draws attention to posters and announcements, complements any work of art. Just under  tall, the DR150 enhances any setting.

DR160—Black Hardwood/Brass Easel

Similar to the DR150 in styling, the DR160 has a frame of fine-grained hard maple finished in black lacquer. Decorative brass accents are lacquer-coated.

DR170—Stained Hardwood/Brass Easel

A solid oak frame gives the DR170 its distinctive appearance. Available finishes include light and medium oak, walnut, cherry and mahogany. The elegant brass accents are lacquer-coated.

DR170 Finishes

Light Oak Med. Oak Walnut Cherry Mahogany

DR150, DR250 and DR205

Options and Accessories for Aluminum

Poster Easels

Vinyl Carrying Case SC20—Fits DR250 and DR270

Paper Pads (box of 4)

Paper Pad Marking Pens (set of 24)

Model Height Dimensions Net Wt.

(Set Up) (Folded) (lbs.)

Aluminum Poster Easels

DR200 60 60 x 51⁄4 x 2 4

DR205 60 60 x 51⁄4 x 2 4

DR220 72 72 x 51⁄4 x 2 5

DR225 72 72 x 51⁄4 x 2 5

DR250 72 41 x 51⁄4 x 2 6

DR270 72 41 x 51⁄4 x 2 6

Decorative Poster Easels

DR150 59 4

DR160 59 5

DR170 59 6

Note: Finishes are reproduced as accurately as possible within the limitation of the printing process.

� www.draperinc.com E-mail: [email protected]

FAX AV/Video Sales: 866-637-5612

FAX Contract Sales: 866-637-5611

FAX Customer Service: 866-397-7353

FAX International Sales: 765-987-1689

©2004 Draper, Inc. Form PVC04 Printed in U.S.A.

Technical data, installation instructions and the most current specifications for Draper products can be found on the Internet at www.draperinc.com. Draper also manufactures FlexShade Systems,

Window Shades and Gymnasium Equipment.

On the cover:

An Access/Series E projection screen, size   , and a ceiling-recessed

Revelation projector mount in the Council Chambers at City Hall in Lethbridge, Alberta, Canada. Installation by Inland AV, Canada.

Photography by Lorne Kemmet, MPA. Lorne Kemmet Photography

Ltd. Lethbridge, Alberta, Canada.

Unless otherwise noted, all photos in this publication by Wayne Williams Photography. All photos © Draper, Inc. except where noted.

www.draperinc.com 765-987-7999

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
