Hydrological Sciences–Journal–des Sciences Hydrologiques, 53(2) April 2008
457
Periodicity of sediment load and runoff in the Yangtze River
basin and possible impacts of climatic changes and human
activities
QIANG ZHANG1,2,3 GUIYA CHEN4, BUDA SU2, MARCUS DISSE5,
TONG JIANG1,2 & CHONG-YU XU6
1 Nanjing Institute of Geography and Limnology, Chinese Academy of Sciences, Nanjing 210008, China
[email protected]
2 Key Laboratory of Climate Change Research, China Meteorological Administration, Beijing 100081, China
3 Department of Geography and Resource Management and Institute of Space and Earth Information Science,
The Chinese University of Hong Kong, Shatin, NT, Hong Kong, China
4 Changjiang Water Resources Commission (CWRC), Ministry of Water Resources, Wuhan 430000, China
5 Universität der Bundeswehr München, Institut für Wasserwesen, Lehrstuhl für Wasserwirtschaft und Ressourcenschutz,
Werner-Heisenberg-Weg 39, D-85577 Neubiberg, Germany
6 Department of Geosciences, University of Oslo, PO Box 1047 Blindern, N-0316 Oslo, Norway
Abstract Periodicity of the runoff and the sediment load, and possible impacts from human activities and
climatic changes, in the Yangtze River basin during 1963–2004 are discussed based on the monthly
sediment and runoff data, and using the wavelet approach. Research results indicated that: (a) Sediment load
changes are severely impacted by the different types of human activity (e.g. construction of water reservoirs,
deforestation/afforestation); and the runoff variability is the direct result of climatic changes, e.g. the
precipitation changes. (b) The impacts of human activity and climatic changes on the sediment load and
runoff changes are greater in smaller river basins (e.g. the Jialingjiang River basin) than in larger river
basins. The response of sediment load and runoff changes to the impacts of human activities and climatic
changes are prompt and prominent in the Jialingjiang River basin relative to those in the mainstem of the
Yangtze River basin. (c) Construction of the Three Gorges Dam has already had obvious impacts on the
sediment transport process in the middle and lower Yangtze River basin, but shows no obvious influence on
the runoff changes. Construction of the Three Gorges Dam will result in further re-adjustment of the
scouring/filling process within the river channel in the middle and lower Yangtze River basin, and have
corresponding effects on the altered sediment load because of the Dam’s operation for the river channel,
ecology, sustainable social economy and even the development of the Yangtze Delta. This will be of
concern to local governments and policy makers.
Key words sediment load; runoff changes; wavelet approach; Yangtze River basin
Périodicité de la charge sédimentaire et de l’écoulement dans le bassin du Fleuve Yangtze et
impacts possibles des changements climatiques et des activités humaines
Résumé La périodicité de l’écoulement et de la charge sédimentaire, ainsi que les impacts possibles des
activités humaines et des changements climatiques, dans le bassin du Fleuve Yangtze durant la période
1963–2004, sont discutés sur la base de données mensuelles d’écoulement et de sédiments, et à l’aide d’une
approche par ondelettes. Les résultats de la recherche indiquent que: (a) Les changements de charge
sédimentaire sont sévèrement influencés par les différents types d’activité humaine (e.g. la construction de
barrages, la déforestation/reforestation); et la variabilité de l’écoulement est le résultat direct de changements
climatiques, e.g. les changements dans les précipitations. (b) Les impacts de l’activité humaine et des
changements climatiques sur la charge sédimentaire et sur les changements d’écoulement sont plus
importants dans les plus petits bassins versants (e.g. le bassin de la Rivière Jialingjiang) que dans les plus
grands. La réponse de la charge sédimentaire et des changements d’écoulement aux impacts des activités
humaines et des changements climatiques sont rapides et dominants dans le bassin de la Rivière Jialingjiang,
par comparaison avec ce qu’on observe dans le cours principal du Fleuve Yangtze. (c) La construction du
Barrage des Trois Gorges a déjà eu des impacts évidents sur le processus de transport sédimentaire dans la
partie centrale et inférieure du bassin du Fleuve Yangtze, mais ne montre pas d’influence nette sur les
changements d’écoulement. La construction du Barrage des Trois Gorges va conduire à un réajustement
supplémentaire du processus d’érosion/sédimentation dans le lit du cours d’eau, dans la partie centrale et
inférieure du Fleuve Yangtze; et avoir, en raison de la gestion du barrage des effets sur la charge en
sédiments altérés et sur le cours d’eau, l’écologie, l’économie sociale durable et même le développement du
Delta du Yangtze. Cela va concerner les gouvernements et les décideurs locaux.
Mots clefs charge sédimentaire; changements d’écoulement; approche par ondelettes; basin du Fleuve Yangtze
Open for discussion until 1 October 2008
Copyright © 2008 IAHS Press
458
Qiang Zhang et al.
INTRODUCTION
Human activities (e.g. land-use changes, dam construction) and climatic changes in a fluvial
system can result in alterations to the sediment load and runoff variability, which are complicated
dynamic processes (Schumm, 1977; Leopold et al., 1964; Crooks & Davies, 2001; Xu, 2002).
Runoff and sediment loads exert significant influences on the fluvial morphology through time and
space, supporting the fluvial ecosystems along the adjoining fluvial surfaces (Gupta et al., 1999;
Chen et al., 2001). Modification of the river channel appears to be initiated by the increase or
decrease in either the water or the sediment load. Kondolf et al. (2002) contrasted changes in the
land use, bed load and channel response of the Pine Creek basin (200 km2) of Idaho, USA and the
Drôme basin (1640 km2), France, showing that in the former, hard-rock mining near the end of the
19th century, road construction, etc., resulted in an increased bed load, which in turn led to the
channel instability.
Construction of the Three Gorges Dam and its possible impacts on the runoff and sediment
loads in the middle and lower Yangtze River basin have attracted concern (e.g. CAS, 1988;
Williams, 1993). The Yangtze River (Changjiang) originates on the Qinghai-Tibet Plateau and
flows about 6300 km eastwards to the East China Sea; it is the longest river in China and the third
longest river in the world. As it is a large river, the runoff and sediment load changes of the
Yangtze River basin have attracted considerable attention (e.g. Xu, 1996; Lu et al., 2003; Zhang et
al., 2006). Zhang & Wen (2004), after analysing the sediment flux and annual runoff of the upper
Yangtze River, indicated that the sediment load of the upper Yangtze River has no visible
changing trend; this may be due to sediment load changes in the two biggest tributaries: Jinsha and
Jialingjiang rivers. Yang et al. (2002) analysed suspended sediment concentration (SSC) at two
hydrological stations (Datong and Yichang stations) for the period 1951–2000 to determine
sediment supply to the delta and discussed the possible human influences on the sediment
variations.
Evidently, there has been much research on sediment loads and runoff changes in the Yangtze
River basin, which is very useful for developing further understanding of the temporal and spatial
changes in sediment loads and runoff in the region. However, it should be noted that: (a) the length
of the hydrological series has not been updated (e.g. Chen et al., 2001) and so it is difficult to
elucidate the recent changes in sediment loads and runoff, and possible human impacts (e.g.
construction of the Three Gorges Dam); and (b) conventional statistical methods (e.g. correlation
analysis), or simply the original series, are demonstrated to show changing patterns of runoff and
sediment loads, but do a relatively poor job in evaluating changes within the cyclic phenomena,
which are limited by the time frame selection and characterize cyclic phenomena by mean and
variance of each time interval (White et al., 2005). In this paper, we apply the wavelet approach to
detect possible impacts of climatic changes and human activities on changes in runoff and
sediment loads.
Here, the monthly suspended sediment load and runoff data of Pingshan, Yichang, Hankou
and Datong stations located on the mainstem of the Yangtze River, and Beipei station on the
Jialingjiang River, were analysed. The Jialingjiang is the main tributary of the Yangtze, and acts as
one of the main sources of sediment load (Fig. 1). The objectives are: (a) to detect the changes in
the periodicity of the runoff and sediment load of the Yangtze River basin over time; and (b) to
explore and discuss the possible influences of human activities and climatic changes on the runoff
and sediment load in the Yangtze River basin.
DATA AND METHODOLOGY
The monthly runoff and suspended sediment load data of the four mainstem stations (Pingshan,
Yichang, Hankou and Datong) and of Beipei station on the Jialingjiang River for 1963–2004 were
analysed; these data were provided by the Changjiang Water Resources Commission, China
(CWRC). The sediment load in this study refers to suspended sediment only. The location,
Copyright © 2008 IAHS Press
Periodicity of sediment load and runoff in the Yangtze River basin
459
Fig. 1 Location of the study region and hydrological gauging stations.
Table 1 Detailed hydrological record of stations along the tributary and mainstream of the Yangtze River.
Station name
Drainage area
(km2)
Stations along the mainstem of the Yangtze River:
Pingshan
485 099
Yichang
1 005 501
Hankou
1 488 036
Datong
1 705 383
Stations along the tributary of the Yangtze River:
Beipei
156 142
Time interval:
Runoff
Sediment load
1963–2004
1963–2004
1963–2004
1963–2004
1963–2004
1963–2004
1963–2004
1963–2004
1963–2004
1963–2004
drainage areas and lengths of the series are displayed in Fig. 1 and Table 1. The homogeneity and
reliability of the data were firmly controlled by the CWRC before the data were released. The
series used in this study show good consistency with no missing data. The lengths of the series are
various and, for consistency in the series length, a time interval of 1963–2004 is accepted.
The continuous wavelet transform (CWT) technique (Farge, 1992; Torrence & Compo, 1998;
Grinsted et al., 2004), as a tool for analysing localized variations of power within a time series, is
applied in the current study. The wavelet transform has also been applied successfully to analyse
the hydrological effects of the construction and operation of the Grand Canyon Dam on the
Colorado River in (White et al., 2005). More recently, the authors have applied this method in the
Copyright © 2008 IAHS Press
460
Qiang Zhang et al.
study of annual maximum streamflow series of the Yangtze River basin (Zhang et al., 2007). In
the current study, before the technique was applied, we tested the normality of the hydrological
series by using the Kolmogorov-Smirnov test (Xu, 2001). Through CWT analysis, we decomposed
the hydrological series into time–frequency space to determine both the dominant modes of
variability and how those modes vary in time (Torrence & Compo, 1998). The concept and
procedure of the wavelet method are thoroughly explained and discussed by Torrence & Compo
(1998), who have provided wavelet software at: http://paos.colorado.edu/research/wavelets/.
RESULTS
Sediment load and runoff changes in the mainstream of the Yangtze River
The Yangtze River basin is climatically characterized by the subtropical monsoon; precipitation
events mainly occur in summer and there is less precipitation in winter (Zhang et al., 2005). The
wavelet power spectra of the monthly runoff changes of the stations on the mainstream of the
Yangtze (upper panels of Fig. 2(a)–(d)) demonstrate the pronounced annual and sub-annual cycles
of the runoff changes. The upper panels of Fig. 2 clearly show that the prominent 1-year band
dominates the whole monthly runoff series along the mainstream of the Yangtze River. The interannual variance changes in the runoff series are significant at >95% confidence level. Furthermore, significant 0.5- and 0.25-year bands are sparsely distributed along the whole runoff series.
What is interesting is that the shorter periods can be identified in the runoff series when serious
flood events occurred. The 1998 flood extended over the whole Yangtze basin but the 1983 flood
occurred in the middle and lower basin and can be identified using the wavelet transform method
featured by appearance of the shorter periods.
As for the wavelet power spectrum of the monthly sediment load (lower panels of Fig. 2(a)–
(d)), different changing patterns can be identified compared to the corresponding upper panels.
The local wavelet power is relatively broadly and uniformly distributed in the 0.25- to 1-year
band, but the 1-year band was prevalent, which illustrates the obvious influences of streamflow on
transportation of the sediment load. Walling & Moorehead (1987) and Walling & Webb (1992)
found that, at local scales, the relationship between suspended sediment load and water discharge
is complicated and can be generalized as different patterns. Furthermore, more areas featured by
the significant wavelet power are identified in the 0.25- to 0.5-year bands, showing possible
impacts from flash climatic events (e.g. rainstorm events) on the sediment load (Kirkby, 1978; Yu
et al., 1997). The lower panels of Fig. 2 show that larger areas dominated by the significant
wavelet power spectrum are identified in the 0.25- to 1-year band in the time intervals near to
1980, 1981 and 1998, when serious flood events occurred in the Yangtze basin, indicating the
significant influence of flood events on the sediment transportation. After about 2002, the annual
cycle of the sediment load series was removed. However, the removal of the annual cycle of the
sediment load series at Pingshan station was relatively slow. The time when the removal of the
annual cycle of sediment load series of Yichang (Fig. 2(b)), Hankou (Fig. 2(c)) and Datong
(Fig. 2(d)) stations occurred is in good agreement with the functioning of the Three Gorges Dam,
where water storage commenced at the end of 2002, and reflects the impacts on sediment
transportation. It should be noted that the Gezhouba Dam (construction of which started in 1970
and operation in the 1980s, with a total storage of 1.58 × 109 m3) had little influence on the runoff
changes (Chen & Huang, 1991), but it had a major effect on sediment load transport (Chen &
Huang, 1991). However, the lower panel of Fig. 2(b) shows that the influence of the Gezhouba
Dam on suspended sediment transport was not enough to completely remove the annual cycle of
the sediment load series. The removal of the annual cycle of the sediment series at Pingshan
station may partly be the result of the decreasing precipitation in the upper Yangtze River basin.
Furthermore, up to the end of the 1980s, 1880 water reservoirs were constructed in the Jinshajiang
River basin with a total storage of 2.813 × 109 m3 (Xu, 2005), which may in part be responsible for
the removal of the annual cycle of the sediment load series at Pingshan.
Copyright © 2008 IAHS Press
(b)
(c)
(d)
Periodicity of sediment load and runoff in the Yangtze River basin
Fig. 2 Continuous wavelet power spectrum for the normalized time series of monthly runoff (upper panel) and monthly sediment loads (lower panel) of (a) Pingshan
station; (b) Yichang station; (c) Hankou station; and (d) Datong station. The thick black contour designates the 95% confidence level against red noise, and the cone of
influence (COI), where edge effects might distort the picture, is shown as a U-shaped line.
461
Copyright © 2007 IAHS Press
(a)
462
Qiang Zhang et al.
Sediment load and runoff changes in the tributary of the Yangtze River
The wavelet spectrum is broadly and uniformly distributed in the 0.25- to 1-year band for the
runoff series (upper panel, Fig. 3) and sediment load series (lower panel, Fig. 3) of Beipei station.
The upper Jialingjiang River basin is dominated by the decreasing precipitation trend (Zhang et
al., 2005), which is demonstrated by gradual removal of the annual cycle and other cyclic
components (e.g. 0.5-year cycle) of the runoff series. The decreasing precipitation in the upper
Jialingjiang River was enough to remove the annual cycle of the runoff series at Beipei station
after about 1995. Up to the end of the 1980s, 11 931 water reservoirs were constructed in the
Yangtze River basin, with a total storage of 2.05 × 1010 m3, of which 4542 reservoirs were on the
Jialingjiang River with a total storage of 3.61 × 109 m3 (Xu, 2005). To a large extent, the reservoirs
retained much sediment, resulting in abrupt removal of the annual cycle of the sediment load series
of Beipei station (lower panel, Fig 3). Figure 3 indicates four periods with different periodicity
characteristics of the sediment load: 1965–1970, 1970–1977, 1977–1985, and 1985–2004.
According to research by Xu (2000), large-scale and intensive deforestation during 1958–1968 led
to serious soil erosion and high sediment loads in the river channel. Between 1969 and 1979, many
reservoirs were built and started to function; they retained much of the sediment load, so greatly
decreasing the sediment load of the river downstream of the reservoirs. The sediment load in the
river channel began increasing after 1978 because of deforestation-induced soil erosion. This is the
direct result of the flexible (not fixed) ownership of the forest which enabled large-scale
deforestation (Xu, 2000). After 1985, however, extensive forestation and construction of water
reservoirs in the Jialingjiang River basin, together with a significant decrease in precipitation
(Zhang et al., 2005), resulted in a considerably reduced sediment load in the river, and these are
the key factors responsible for the removal of the annual cycle of the sediment load series at Beipei
station after about 1985. It should be noted that the areas that feature a significant annual cycle for
the runoff series were not yet persistent, especially after about 1995. This is mainly because of
significantly decreased precipitation in the upper Jialingjiang River basin (Zhang et al., 2005).
Impacts of the 1998 flood events on the runoff and sediment load are also identified by the
significant wavelet power in the 0.25- to 0.5-year band in 1998 (Fig. 3). Figure 3 also indicates
that the reservoirs may have exerted more influence on sediment loads than on runoff variations.
Fig. 3 Continuous wavelet power spectrum for the normalized time series of monthly runoff (upper
panel) and monthly sediment loads (lower panel) of Beipei station. The thick black contour designates
the 95% confidence level against red noise, and the cone of influence (COI), where edge effects might
distort the picture, is shown as a U-shaped line.
Copyright © 2008 IAHS Press
Periodicity of sediment load and runoff in the Yangtze River basin
463
CONCLUSIONS AND DISCUSSION
The sediment load and runoff are the key components of the fluvial system. The changes in the
sediment load and runoff from the upper Yangtze River basin are the main causes of flood hazards
in the middle and lower Yangtze River basin (Li et al., 2002; Zhang et al., 2006). Changes in the
sediment load and runoff have considerable influences on the fluvial ecological system. The
negative influences of the decreasing sediment load on the development of the Yangtze Delta have
already caused concern (Yang et al., 2003). The variability of the sediment load and the runoff of
the Yangtze River basin are analysed using the continuous wavelet approach. Interesting results
were obtained as follows:
1. The factors influencing the sediment load and runoff changes, e.g. precipitation, land-use
changes and construction of reservoirs, are various and are different in different parts of the
Yangtze River basin. The reservoirs had more influence on the sediment transport process
than on the runoff changes (Xu, 2000). This is clearly shown by the wavelet analysis of the
sediment load and the runoff series along the mainstem of the Yangtze River. The Gezhouba
Dam has not influenced the runoff processes, but has had considerable effect on the sediment
transport process. However, this is not great enough to impact the annual cycle of the
sediment load series at Yichang station. The annual cycle of the sediment series in the
Jialingjiang River was removed after the construction and operation of reservoirs, but the
annual cycle of the runoff series was not affected, demonstrating the greater influence of
water reservoirs on sediment transport than on the runoff processes.
2. Sediment generation is directly influenced by different types of human activity. In the
Jianglingjiang River basin, the land exploitation was extensive due to socio-economic
development, and led to a serious degradation of vegetation coverage. The succeeding 10-year
cultural revolution maintained this vegetation deterioration (Xu, 2000). The significant
wavelet power spectrum during 1963–1970 illustrates these influences. Water reservoirs
exerted their tremendous influences on sediment transport after 1968, as elucidated by the
removal of the annual cycle after 1968 (Fig. 3). Large-scale deforestation started after 1978,
and the annual cycle appears again. Large-scale water and soil conservation commenced after
the 1980s and the vegetation of about 230 000 km2 recovered, which greatly decreased the
sediment generation (Zhang & Wen, 2004). The removal of the annual cycle after the 1980s in
the lower panel of Fig. 3 illustrates this phenomenon. Decreased precipitation after about 1980
influenced the persistence of the annual cycle of the runoff series of Beipei station and finally
removed the annual cycle after about 1995.
3. The basin area can alter the influence of human activities (construction of reservoirs, land-use
changes) and climatic changes (particularly precipitation changes) on the sediment load and
runoff. These influences are less prominent in the larger basins than in the smaller ones. The
0.25- to 0.5-year band is more pronounced in the sediment and runoff series of Beipei station
than in those of the other stations along the mainstem of the Yangtze River. The construction
of reservoirs in the tributaries has had a significant influence on sediment transport in the
Jialingjiang River. The effects of the Gezhouba Dam on sediment transport are not great
enough to remove the annual cycle. Furthermore, the thousands of reservoirs in the tributaries
of the Yangtze River do not show obvious impacts on sediment transport and runoff processes
within the mainstem of the river. The impact of river basin size is closely related to the degree
of human activities and climatic changes.
4. We can tentatively conclude that the runoff in the Yangtze River is mainly influenced by
climatic changes (especially precipitation changes). The removal of the annual cycle in the
runoff series at Beipei station post-1995 may be the direct result of the significant decrease in
precipitation in the Jialingjiang River basin in recent years. The annual cycle of the sediment
and runoff series is seriously impacted by human activities and climatic changes in the
Jialingjiang River basin. The annual cycle in the sediment series was removed after the
construction of the dam; however, the annual cycle of the runoff series was not impacted by
Copyright © 2008 IAHS Press
464
Qiang Zhang et al.
the dam construction. Wavelet analysis results clearly demonstrate the tremendous influence
of the Three Gorges Dam on sediment transport in the middle and lower Yangtze River basin.
Dai et al. (2005) indicate that the Three Gorges Dam retains considerable amounts of
sediments; the sediment retained during June–December 2003 amounted to 1.24 × 108 t. The
Three Gorges Dam does not show obvious influences on the runoff process so far, the annual
cycle being apparent throughout the study period. However, the Three Gorges Dam has
already exerted tremendous influence on sediment transport processes, which will alter the
spatial and temporal distribution of the scouring and filling processes within the river channel.
This should concern local governments and policy makers.
Acknowledgements Cordial thanks are extended to the Changjiang Water Resources Commission
(Ministry of Water Resources, China; CWRC) for kindly providing the hydrological data used in
the current text. This research was financially supported by the Alexander von Humboldt
Foundation, Germany, the Foundation of Nanjing Institute of Geography and Limnology, the
Chinese Academy of Sciences (no. S260018) and by the Climate Change Research Fund of China
Meteorological Administration (CMA, grant no: CCSF2007-35).
REFERENCES
CAS (Leading Group of the Three Gorge Project Ecology and Environment Research Project, Chinese Academy of Sciences)
(1988) Ecological and Environmental Impact of the Three Gorges Project and Countermeasures (in Chinese). Science
Press, Beijing, China.
Chen, S. R. & Huang, G. H. (1991) Water level changes of Yichang station after operation of Gezhouba Dam. Yangtze River 1,
30–37 (in Chinese).
Chen, Z. Y., Li, J. F., Shen, H. T. & Wang, Z. H. (2001) Yangtze River of China: historical analysis of discharge variability and
sediment flux. Geomorphology 41, 77–91.
Crooks, S. & Davies, H. (2001) Assessment of land use change in the Thames basin and its effect on the flood regime of the
river. Phys. Chem. Earth 26, 7–8.
Dai, S. B., Yang, S. L., Zhao, H. Y. & Li, M. (2005) Response of middle and lower reaches of Yangtze River to the initial
operation stage of the Three Gorges Dam. J. Sediment Research 5, 35–39 (in Chinese).
Farge, M. (1992) Wavelet transform and their application to turbulence. Annual Rev. Fluid Mech. 24, 395–457.
Grinsted, A., Moore, J. C. & Jevrejeva, S. (2004) Application of the cross wavelet transform and wavelet coherence to
geophysical time series. Nonlinear Processes in Geophysics 11, 561–566.
Gupta, A., Kale, V. S. & Rajaguru, S. N. (1999). The Narmada River, India, through space and time. In: Varieties of Fluvial
Form (ed. by A. J. Miller & A. Gupta), 114–143. Wiley, Chichester, UK.
Jevrejeva, S., Moore, J. C. & Grinsted, A. (2003) Influence of the Arctic Oscillation and El Niño-Southern Oscillation (ENSO)
on ice conditions in the Baltic Sea: the wavelet approach. J. Geophys. Res. 108(21), 4677, doi:10.1029/2003JD003417.
Kirkby, M. J. (ed.) (1978) Hillslope Hydrology. Wiley, New York, USA.
Kondolf, G. M., Piegay, H. & Landon, N. (2002). Channel response to increased and decreased bed load supply from land use
change: contrasts between two catchments. Geomorphology 45, 35–51.
Leopold, L. B., Wolman, M. G. & Miller, J. P. (1964) Fluvial Processes in Geomorphology. Freeman, San Francisco, USA.
Li, Y. T., Deng, J. Y. & Sun, Z. H. (2002) Relationships between environmental degradation and water-sediment hazards in the
Yangtze River basin. J. Soil & Water Conserv. 16(6), 31–35 (in Chinese).
Lu, X. X., Ashmore, P. & Wang, J. (2003) Sediment load mapping in a large river basin: the Upper Yangtze, China.
Environmental Modelling & Software 18, 339–353.
Schumm, S. (1977) The Fluvial System. Wiley, New York, USA.
Su, B. D., Xiao, B., Zhu, D. M. & Jiang, T. (2005) Trends in frequency of precipitation extremes in the Yangtze River basin,
China: 1960–2003. Hydrol. Sci. J. 50(3), 479–492.
Torrence, C. & Compo, G. P. (1998) A practical guide to wavelet analysis. Bull. Am. Met. Soc. 79, 61–78.
Walling, D. E. & Moorehead, P. W. (1987) Spatial and temporal variation of the particle-size characteristics of fluvial sediment.
Geografisk Annaler 69A (1), 47–59.
Walling, D. E. & Webb, B. W. (1992) Water quality: I. Physical characteristics. In: The River Handbook (ed. by P. Calow &
G. Petts), 48–72. Blackwell, Oxford, UK.
White, A. M., Schmidt, C. J. & Topping, J. D. (2005) Application of wavelet analysis for monitoring the hydrologic effects of
dam operation: Glen Canyon Dam and the Colorado River at Lees Ferry, Arizona. River Res. Applic. 21, 551–565.
Williamsi, P. (1993) Sedimentation analysis. In: Damming the Three Gorges (by M. Barber & G. Ryder), 126–132. Earthscan
Publications, London, UK.
Xu, C.-Y. (2001) Statistical analysis of a conceptual water balance model, methodology and case study. Water Resour. Manage.
15, 75–92.
Xu, J. X. (1996) Wandering braided river channel pattern developed under quasi-equilibrium: an example from the Hanjiang
River, China. J. Hydrol. 181, 85–103.
Xu, J. X. (2000) Runoff and sediment variations in the upper reaches of Changjiang River and its tributaries due to
deforestation. Shuili Xuebao 1, 72–80 (in Chinese).
Copyright © 2008 IAHS Press
Periodicity of sediment load and runoff in the Yangtze River basin
465
Xu, J. X. (2002) Complex behaviors of natural sediment-carrying streamflow and the geomorphological implications. Earth
Surf. Processes & Landf. 27, 749–758.
Xu, J. X. (2005) Variation in grain size of suspended load in upper Changjiang River and its tributaries by human activities.
J. Sediment Res. 3, 8–16 (in Chinese).
Yang, S. L., Belkin, I. M., Belkina, A. I., Zhao, Q. Y., Zhu, J. & Ding, P. X. (2003) Delta response to decline in sediment
supply from the Yangtze River: evidence of the recent four decades and expectations for the next half-century. Estuarine,
& Coastal Shelf Science 57, 689–699.
Yang, S. L., Zhao, Q. Y. & Belkin, I. M. (2002). Temporal variation in the sediment load of the Yangtze River and the
influences of human activities. J. Hydrol. 263, 56–71.
Yu, B., Rose, C. W., Coughlan, K. J. & Fente, B. (1997) Plot-scale rainfall–runoff characteristics and modeling at six sites in
Australia and Southeast Asia. Trans. Am. Soc. Agric. Engrs 40(5), 1295–1303.
Zar, J. H. (1999) Biostatistical Analysis. Prentice-Hall, Old Tappan, New Jersey, USA.
Zhang, Q., Jiang, T., Gemmer, M. & Becker, S. (2005) Precipitation, temperature and discharge analysis from 1951 to 2002 in
the Yangtze Basin, China. Hydrol. Sci. J. 50(1), 65–80.
Zhang, Q., Liu, C. L., Xu, C.-Y., Xu, Y. P. & Jiang, T. (2006) Observed trends of annual maximum water level and streamflow
during past 130 years in the Yangtze River basin, China. J. Hydrol. 324, 255–265.
Zhang, Q., Xu, C.-Y., Becker, S. & Jiang, T. (2006) Sediment and runoff changes in the Yangtze River basin during past 50
years. J. Hydrol. 331, 511–523.
Zhang, Q., Xu, C.-Y., Jiang, T, & Wu, Y. J. (2007) Possible influence of ENSO on annual maximum streamflow of Yangtze
River, China. J. Hydrol. 333, 265–274.
Zhang, X. B. & Wen, A. B. (2004). Current changes of sediment load in the upper Yangtze River and its two biggest tributaries,
China. Global& Planetary Change 41, 221–227.
Received 5 June 2006; accepted 2 July 2007
Copyright © 2008 IAHS Press
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
