GREAT BOILERS FROM BRITAIN.

GREAT BOILERS FROM BRITAIN.

GREAT

BOILERS

FROM

GREAT

BRITAIN.

06.2014

Ideal Boilers

PO Box 103

National Avenue

Kingston upon Hull

East Yorkshire

HU5 4JN

T 01482 492251

WWW.IDEALBOILERS.COM

211086

NEW BUILD

YOUR COMPLETE

SOLUTION.

IDEAL

BOILER

STELRAD

RADIATOR

CYLINDER SOLAR

PANEL

FREE DESIGN

STAGE SAP

(USUALLY £50)

DESIGN

SERVICE

364 DAYS

A YEAR

WWW.IDEALBOILERS.COM

02

WELCOME

TO FIRST

CLASS.

WITH A RANGE OF WARRANTIES

AVAILABLE ON OUR AWARD

WINNING BOILERS, AND

200 QUALITY CHECKS

BEFORE THEY LEAVE OUR

FACTORY - RELIABILITY IS

ALWAYS GUARANTEED.

CONTENTS.

04 IDEAL BOILERS

05 SAP & THE IDEAL PACKAGE

06 THE DESIGN PROCESS

07 DESIGN SAMPLES

08 DEVELOPER CHECKLIST

09 CODE FOR SUSTAINABLE HOMES

10 LOGIC COMBI ES

12

14

16

18

LOGIC CODE COMBI ES

LOGIC SYSTEM

LOGIC HEAT ONLY

LPG CONVERSION KITS

20 CONTROLS

22 FLUEING

24 TECHNICAL SPECIFICATION

NEW ENERGY

28 SOLAR THERMAL FLAT PLATE

COLLECTORS & ACCESSORIES

30 CYLINDERS

32 HEATING

38 CUSTOMER SERVICE

39 AFTERSALES SUPPORT

03

NEW BUILD

04

IDEAL BOILERS.

At Ideal Boilers, with 100 years of manufacturing experience, we pride ourselves on offering a wide range of domestic and commercial heating products designed specifically with the UK market in mind.

Working with Ideal means you get quality and reliability as standard; our Logic range of boilers holds the Queen’s Award for Enterprise and Innovation, as well as Good Housekeeping reader recommended status.

THE IDEAL PRODUCT RANGE.

Representing the next generation in heating design, the Logic range of boilers offers state-of-the-art technology in a choice of outputs, all in one practical compact unit that fits easily into any standard kitchen cupboard.

Available in a choice of DHW outputs, 26 - 38 kW, the Logic

Code Combi ES provides a perfect solution for both new build and retrofit solutions where energy efficiency is a key concern.

The most recent addition to the

Logic range is the Logic Code

Combi ES. Designed to take the headache out of meeting Building

Regulations, the Logic Code

Combi ES from Ideal is a simple one-box solution, capable of supporting up to level 4 of the

Code for Sustainable Homes.

The Logic Code Combi ES is rated NOx class 5 and when used with controls and weather compensation, is the perfect no-nonsense solution for a range of domestic properties.

NEW BUILD

05

Partnered with Ideal, our independent SAP Solution consultants

Briary Energy can offer you a complete value-engineered solution to meet Building Regulations Part L Compliance.

Our aim is to give you the most cost effective solution for your build, including building fabric, U-valve calculations, thermal bridging, ventilation, heating and renewables.

As part of the Ideal Package, we will keep you up to date with the latest legislation helping you to keep ahead of the game. We can even promise any question will be answered within 24 hours.

Our technical customer service team is also available 364 days a year to offer any advice and support on queries once your development is complete.

THE IDEAL PACKAGE.

Our new build development package combines design, energy certification and our high efficiency boilers and radiators as one solution, providing you with the most effective answer to meet

Building Regulations Part L compliance.

Our in-house design team is based at the Ideal Centre of Excellence in Leeds. Once our team have found the right products for your development, designed your system and achieved SAP ratings, a full plan will be provided, which will include the following:

• Full schedule of equipment (boilers, radiators & ancillary components required)

• Detailed layout drawings showing boiler and radiator positions

• Pipe runs and their required sizes for both the heating and domestic water services

• A typical diagrammatic sketch of the arrangement between the boiler and cylinder cupboard

• A comprehensive general specification

• A system guarantee will also be included

IDEAL

BOILER

STELRAD

RADIATOR

CYLINDER SOLAR

PANEL

FREE DESIGN

STAGE SAP

(USUALLY £50)

DESIGN

SERVICE

364 DAYS

A YEAR

NEW BUILD

06

THE DESIGN

PROCESS.

1 2

Enquiry raised by client and a developer check list is completed. This is available to download from www.idealboilers.com or via [email protected]

Email the completed form along with plans, sections and elevations in the formats listed, and any additional information as indicated on the check list to [email protected]

3

The return date on new enquiries is within 20 working days. Should you have a specific deadline please contact the

Design Office or your New Build sales contact.

4

When the designs are completed they will be returned to you in PDF format via email or CD-Rom dependent on your preference.

5

Our internal system is updated and records kept on file should revisions be required.

FOR MORE INFORMATION ON THE DESIGN PROCESS,

PLEASE CONTACT:

[email protected]

DESIGN SAMPLES.

15mm Htg F&R

F.A. BOXED IN

R2

Living

R1

Kitchen/Dining

R4

Hall

Store

R3

Store

22mm Htg F&R

(ZONE 1) T.A.

BOXED IN

22mm Htg F&R

(ZONE 2) T.A.

BOXED IN

COMBI DESIGN.

THIS COMBI DESIGN

SHOWS A TWO ZONE

SYSTEM.

WE CAN TAILOR THE

DESIGN TO MEET YOUR

NEEDS AND TECHNICAL

REQUIREMENTS.

ZONE 1

PROGRAMMABLE

STAT.

NEW BUILD

07

22mm Htg F&R

T.A. TO CYLINDER

FULL DESIGN.

THIS DESIGN SHOWS A

CYLINDER AND HEAT ONLY

BOILER IN A TWO ZONE

SYSTEM.

svp

KITCHEN

R6

UTILITY

R5

15mm Htg F&R

F.A. BOXED IN

FAMILY

R4

STUDY

ZONE 1

PROGRAMMABLE

STAT.

R7

R2

R8

HALL

UP

DINING

LOUNGE

R1

R3

NEW BUILD

08

DEVELOPER CHECKLIST.

As part of the of the design process, a Developer Checklist will need to be completed. The target turnaround time for designs is

20 working days from the receipt of suitably scaled final working drawings and a completed Developer Checklist. The details and information you will need to complete the Developer Checklist are listed below.

THE DEVELOPER CHECKLIST

CAN BE DOWNLOADED FROM OUR WEBSITE

WWW.IDEALBOILERS.COM

ONCE COMPLETED

IT SHOULD BE SUBMITTED, ALONG WITH

DRAWINGS TO

[email protected]

- Boilers

- Radiators

- Ancillary equipment o Renewable requirements o Any other special requirements

CODE FOR SUSTAINABLE HOMES.

The Code for Sustainable Homes was introduced in 2007 by the

UK Government and works as a standard which new build homes in England are required to meet.

Wales and Northern Ireland use the CfSH but levels required may vary from England.

The code has four levels which are star rated, with any new build home that is publicly funded required to achieve a minimum of four stars. Privately built homes need to meet three star rating.

To achieve the various star ratings, new build homes are measured against nine design categories.

• Energy and CO

2

emissions

• Pollution

• Water

• Heath and wellbeing

• Ecology

• Materials

• Surface water run-off

• Management

• Waste

Each category has a different points value depending on the impact it has on making the home sustainable.

The Code works alongside

Building Regulations, which outline the minimum building standards required by

Government legislation.

In relation to the Energy/CO

2 category, the requirements are a percentage reduction in carbon emissions compared with the

Target Emission Rate (TER) calculated in accordance with the Building Regulations

Part L1 (2006).

The standards set out in

The Code are in excess of the

Building Regulations.

NEW BUILD

09

HIGH EFFICIENCY BOILERS

10

LOGIC COMBI ES 24 30 35.

Available in a choice of three outputs of

24, 30 and 35 kW, the Logic Combi ES range of combination boilers from Ideal, provides a hassle free and simple solution for today’s new build housing market.

Complimenting the existing Logic range, the Logic Combi ES design is optimised for new build compliance following the

SAP 2009 design procedure. This is particularly beneficial for small, new build properties.

A quick installation is assured thanks to a wide range of fluing options, fast fix flue turret connections and no need for compartment ventilation allowing this product to be installed out of sight in a standard kitchen cupboard*. The Logic

Combi ES is fully modulating, built with tried and tested technology.

Featuring a simple diagnostics display, the

Logic Combi ES range is compatible with a range of optional timers for the ultimate in control and peace of mind.

FEATURES.

COMPACT DIGITAL

DISPLAY

FROST

PROTECTION

FLUE

VARIANTS

LPG

CONVERSION**

ENERGY SAVING

RECOMMENDED

SPECIFICATION.

• Complete range of Logic combination boilers for new build developers

• Achieves optimum SAP and DER ratings for standard combination boiler usage

• 75mm deep translucent condensate siphon

• Fully modulating operation to low outputs

• Automatic bypass

RELIABLE

Energy Saving Trust Recommended

Boiler frost protection

Built-in filling loop

EASY TO INSTALL

Compact cupboard fit

Fast fix telescopic horizontal flue

Wide range of additional flueing options

Low lift weight (33kg)

Preformed copper tails

Pre-wired mains lead (2m)

Universal condensate connection

• Stand-off kit including piping

• Pre-piping kit

• Compatible with a range of additional controls inc. weather compensation

• LPG conversion kit available for 30 kW boilers

*Please check kitchen cupboard size prior to installation. **LPG Conversion kit available for 30 kW.

SAP REFERENCE

NUMBERS.

Logic Combi ES

24 kW 17043

30 kW 17044

35 kW 17045

LOGIC COMBI ES

11

ADD A WEATHER

COMPENSATION

KIT FOR GREATER

EFFICIENCY.

NOx CLASS 5

HIGH EFFICIENCY BOILERS

12

LOGIC CODE COMBI ES 26 33 38.

Designed to take the headache out of meeting Building Regulations, the Logic

Code Combi ES from Ideal is a simple one box solution, capable of supporting up to level 4 of the Code for Sustainable Homes.

The new ES models optimise design for

SAP and DER ratings.

picks up and recycles waste energy that would have normally been lost through the flue terminal.

This energy is collected and used to warm up the cold hot water supply. This supply, then flows into the plate heat exchanger, where the desired temperature is reached.

Available in a choice of DHW outputs,

26 - 38 kW, the Logic Code Combi ES, provides a perfect solution for both new build and retrofit solutions where energy efficiency is a key concern.

The Logic Code Combi ES has a NOx class

5 rating and a dedicated in-house design* and service network for developers and installers for the ultimate in peace of mind.

Developed using state of the art advanced boiler technology, the Code Combi ES features a built-in stainless steel recuperator located in the flue exit, which cleverly

When used with controls and weather compensation, the Logic Code Combi ES provides the perfect no-nonsense solution for a range of domestic properties.

FEATURES.

COMPACT DIGITAL

DISPLAY

FROST

PROTECTION

FLUE

VARIANTS

LPG

CONVERSION**

ENERGY SAVING

RECOMMENDED

SPECIFICATION.

• Complete range of Logic combination boilers for new build developers

• Achieves optimum SAP and DER ratings for standard combination boiler usage

• Higher DHW flow rates than standard boiler – approximately 10% increase

RELIABLE

EASY TO INSTALL

One single appliance to install – quick and easy

Built-in pipework; no extra space at the side of the product needed

• Standard combination connections

• No additional maintenance requirement

• Compact and light solution for new build or retrofit installations • Energy Saving Trust Recommended

• High DHW efficiency - reduced running costs

• Less waste DHW water as DHW inlet is preheated

• Reduced pluming on DHW

*A charge may apply for this service. **LPG Conversion kit available for 38 kW.

SAP REFERENCE

NUMBERS.

Logic Code Combi ES

26 kW 17178

33 kW 17179

38 kW 17180

LOGIC CODE COMBI ES

13

ADD A WEATHER

COMPENSATION

KIT FOR GREATER

EFFICIENCY.

NOx CLASS 5

HOW IT WORKS.

OPERATION WITH RECUPERATOR IN FLUE

• Hot water tap is opened and boiler senses flow

• Burner on

• Combustion gases heat primary water heat exchanger and flue gases exit to the flue

• Cold water from mains flows through the recuperator in the flue

• Energy from the flue gases is transferred to the in coming water

• The cooled flue gases exit the boiler

• Preheated water enters the boiler and is further heated by the secondary heat exchanger

• Hot water is produced at the tap

HIGH EFFICIENCY BOILERS

14

LOGIC SYSTEM 15 18 24 30.

High SEDBUK efficiency rating and easy to install, the Logic System range of appliances from Ideal provide a simple and reliable solution for a wide variety of sealed domestic systems.

Available in a choice of four outputs -

15, 18, 24 and 30 kW, the Logic System provides a dependable and efficient solution for new and replacement installations alike. Siting and installing a

Logic System is hassle free thanks to a simple telescopic flue option. Time saving fast fix flue turret connections and a wide range of alternative fluing solutions help to ensure the product is installed quickly and efficiency in virtually any domestic situation.

With a lightweight design, concealed connections at the base and no compartment ventilation required, the

Logic System can be conveniently fitted out of sight into a standard kitchen cupboard*.

The Logic System boiler provides simple heating control, all from a single compact appliance.

FEATURES.

COMPACT DIGITAL

DISPLAY

FROST

PROTECTION

FLUE

VARIANTS

LPG

CONVERSION**

ENERGY SAVING

RECOMMENDED

SPECIFICATION.

• Digital display and simple diagnostics

• Fully modulating operation down to 4.8 kW

• Weather compensation kit option

RELIABLE

• Energy Saving Trust Recommended

• Boiler frost protection

• Built-in condensate trap

EASY TO INSTALL

• Compact cupboard fit

• Wide range of flueing options

• Concealed pipe connections

• Low lift weight (28kg)†

• Preformed copper tails

• LPG Conversion kit available

for 30 kW boilers

• Stand-off kit and pre-pipe options

• Pre-wired mains lead

*Please check kitchen cupboard size prior to installation. **LPG Conversion kit available for 30 kW.

† Weight with front panel removed.

SAP REFERENCE

NUMBERS.

Logic System

15 kW 16396

18 kW 16395

24 kW 16394

30 kW 16393

LOGIC SYSTEM

15

ADD A WEATHER

COMPENSATION

KIT FOR GREATER

EFFICIENCY.

NOx CLASS 5

HIGH EFFICIENCY BOILERS

16

LOGIC HEAT ONLY 12 15 18 24 30.

Incorporating the latest in heating design and technology, the Logic Heat is an outstanding heat only solution for both new build or replacement installations alike. Available in the choice of five outputs - 12, 15, 18, 24 & 30 kW, the Logic

Heat will deliver total home comfort for a wide range of domestic properties. a kitchen cupboard*. Installers have the further choice of a neat direct rear flue option as required, helping to speed up the installation in retro fit situations even further.

Suitable for open vent and sealed systems, the Logic heat boiler is straightforward to site and install. Benefiting from no compartment ventilation, compact fit, and a lightweight design means the boiler can be neatly installed out of sight into

High SEDBUK efficiency rated and capability of modulating down to 4.8 kW*

2

, the Logic heat is highly efficient and easy to operate thanks to straightforward controls featuring a clear digital display.

The Logic heat is a reliable and efficient heat only solution for domestic installations.

FEATURES.

COMPACT DIGITAL

DISPLAY

FROST

PROTECTION

FLUE

VARIANTS

LPG

CONVERSION**

DIRECT

REAR FLUE

ENERGY SAVING

RECOMMENDED

SPECIFICATION.

• Fully modulating operation down to

4.8 kW*

2

• Weather compensation kit option

• Water flow sensor

RELIABLE

• Energy Saving Trust Recommended

• Boiler frost protection

EASY TO INSTALL

• Compact cupboard fit

• Direct 80mm diameter rear flue option

• Wide range of flueing options

• Low lift weight (23kg)†

• Top system connections

• 75mm deep translucent condensate siphon

• Stand-off kit

• Terminal wall plate kit

• Security bracket kit

• Low minimum head requirement

• LPG conversion kit available for

30 kW boilers

*Please check kitchen cupboard size prior to installation.

* 2 (30 only - 6.1 kW). **LPG Conversion kit available for 30 kW.

† Weight with front panel removed.

SAP REFERENCE

NUMBERS.

Logic Heat Only

12 kW 16401

15 kW 16400

18 kW 16399

24 kW 16398

30 kW 16397

LOGIC HEAT ONLY

17

ADD A WEATHER

COMPENSATION

KIT FOR GREATER

EFFICIENCY.

NOx CLASS 5

LPG CONVERSION KITS

18

LPG CONVERSION KITS.

Designed for use with Logic combi, heat and system 30 kW boilers and the new Code

Combi ES 38 kW, the Ideal LPG (propane) conversion kit provides a simple and robust gas conversion solution.

With kits available for natural gas to LPG, and LPG to natural gas, these quick to install accessories provides a simple and pragmatic solution without the need for products to be adjusted.

Each kit contains specific components for each required boiler type.

FEATURES.

• Available for all product types (combi, heat & system)

• Suitable most property sizes

• Fast & simple conversion with preset gas valve for no product adjustment

APPLICABLE MODELS.

• Logic Code Combi ES 38

• Logic Combi ES 30

• Logic Heat 30

• Logic System 30

LPG CONVERSION KITS

19

SPECIFICATION.

BOILER MODEL

Min. output (kW)

Max. output (kW)

Max DHW output (kW)

COMBI

8.0

24.3

30.3

CODE

8.7

24.2

38.2

HEAT

8.0

30.3

N/A

SYSTEM

8.0

30.3

N/A

PRODUCT CODE

207649

208433

210394

207651

207653

PRODUCT CODE

176657

176823

177371

176659

176661

NG - LPG CONVERSION KIT

Logic Combi 30 NG-LPG Conversion Kit

Logic Combi ES 30 NG-LPG Conversion Kit

Logic Code Combi ES 38 NG-LPG Conversion Kit

Logic Heat 30 NG-LPG Conversion Kit

Logic System 30 NG-LPG Conversion Kit

LPG - NG CONVERSION KIT

Logic Combi 30 LPG-NG Conversion Kit

Logic Combi ES 30 LPG-NG Conversion Kit

Logic Code Combi ES 38 LPG-NG Conversion Kit

Logic Heat 30 LPG-NG Conversion Kit

Logic System 30 LPG-NG Conversion Kit

NATURAL GAS TO LPG KIT CONTENTS

EACH KIT COMPRISES:

• Gas valve (preset operation)

• Burner injector

• BCC (boiler chip card)

• Data plate labels

• Instructions

Use of the preset gas valve ensures the safety feature of a non adjustable gas valve is retained during conversion.

Two data plate labels are provided in the kits inclusive of a new data plate providing LPG details and a label to retain boiler serial number identity.

CONTROLS

20

COMBI

CONTROLS.

PROGRAMMABLE THERMOSTATS AND TIMERS

Here at Ideal we believe that choosing the right control to meet the needs of your customer is almost as important as choosing the right product; this is why the Logic and Logic Code Combi ES ranges are fully compatible with a range of thermostats and timers for the ultimate in home comfort.

MECHANICAL TIMER

(Part No. 204839)

Simple heating control through a plug in analogue timer. 24 hour tappet operation with off/timed/continuous periods.

ELECTRONIC TIMER

(Part No. 204545)

Easy to use heating control through a plug in digital timer. Plain text operating and diagnostics information. 7 day and up to 3 time periods/day. Automatic summer

/winter time update.

EXTERNAL ROOM CONTROLS

RF MECHANICAL PROGRAMMABLE

THERMOSTAT (Part No. 204824)

Wireless radio frequency (RF) analogue timer and room thermostat providing heat control. Easy to use 24 hour tappet control.

COMBI

CONTROLS.

CONTROLS

21

RF ELECTRONIC PROGRAMMABLE

THERMOSTAT

(Part No. 204789)

Wireless radio frequency (RF) digital timer and room thermostat providing heating control. 7 day, plain text operating and diagnostics display. Automatic summer/winter time update.

RF MECHANICAL TIMER AND ROOM

THERMOSTAT KITS

(Part No. 208352)

Easy to use radio frequency timer (RF), complete with room thermostat. The timer is prewired with plug-in connections to the boiler wiring and features a 24hr tappet operation with off/timed continuous period.

The room thermostat can be freestanding or wallmounted and has a compact design with LCD display and simple symbols to indicate the control.

COMBI, SYSTEM, & HEAT ONLY

CONTROLS.

WEATHER COMPENSATION

OUTDOOR SENSOR

(Part No. 204914 - combi models only)

(Part No. 206152 - heat only and system models)

The Logic and Logic Code Combi ES boilers provide weather compensation when fitted with an outdoor sensor (which is available as an optional accessory).

Weather compensation works by measuring the temperature outside the home and adjusting the temperature (or flow) of the radiators inside.

If the weather is particularly cold outside, the outdoor sensor will communicate with the boiler intelligently to increase the radiator temperature. This process also works in reverse, as the outdoor temperature increases, the flow to the radiators too will decrease.

This process allows the system to operate more efficiently by only heating to the minimum temperature necessary and also preventing spikes in heating activity.

FLUEING: COMBI & SYSTEM

22

FLUEING OPTIONS & ACCESSORIES

LOGIC RANGE.

CODE COMBI ES, COMBI ES & SYSTEM

Standard horizontal flue (600mm long)

Telescopic horizontal flue

1m horizontal flue

Raised horizontal flue inc vertical flue adaptor and 1m extension

1m flue extension

90 degree flue elbow

45 degree flue bends (pair)

Plume management kit

Plume management kit extension pipe

Plume management kit 90 degree elbow

Plume management kit 45 degree bends (pair)

Vertical flue connector to convert boiler for vertical flue

Vertical flue (does not include vertical flue adaptor)

Angled weather collar for vertical flue fits slate and tiles

Flat roof weather collar for vertical flue

Flue deflector. Clips on end of flue and angles pluming away

Stand off kit (Combi ES & System)

Stand off kit inc piping (Combi ES)

Stand off kit inc piping (System)

Stand off kit (Code Combi ES)

Stand off kit inc piping (Code Combi ES)

Weather compensator kit (Combi models)

Weather compensator kit (System only)

LPG conversion Logic Combi ES 30 kW

LPG conversion Logic Code Combi ES 38 kW

LPG conversion Logic system 30 kW

Balcony flue kit

206154

208383

206679

204914

206152

208433

210394

207653

208177

203230

208175

203132

152258

152259

208176

204913

204872

IDEAL CODE

208171

208169

208174

208290

203129

203130

203131

208178

203228

203229

FLUEING OPTIONS & ACCESSORIES

LOGIC RANGE.

HEAT ONLY

Standard horizontal flue (600mm long)

Telescopic horizontal flue

1m horizontal flue

Raised horizontal flue inc vertical flue adaptor and 1m extension

1m flue extension

Rear outlet flue

90 degree flue elbow

45 degree flue bends (pair)

Plume management kit

Plume management kit (for rear flue only)

Plume management kit extension pipe

Plume management kit 90 degree elbow

Plume management kit 45 degree bends (pair)

Vertical flue connector to convert boiler for vertical flue

Vertical flue (does not include vertical flue adaptor)

Angled weather collar for vertical flue fits slate and tiles

Flat roof weather collar for vertical flue

Flue deflector. Clips on end of flue and angles pluming away

Stand off kit

Weather compensator kit

LPG conversion Logic heat only 30 kW

203228

203229

203230

208175

203132

152258

152259

208176

206153

206152

207651

IDEAL CODE

208171

208169

208174

208290

203129

205990

203130

203131

208178

205989

FLUEING: HEAT ONLY

23

TECHNICAL SPECIFICATION

24

LOGIC COMBI ES.

BOILER MODEL

SIZE

PERFORMANCE

CONSTRUCTION

INSTALLATION

CLEARANCES

USER INTERFACE

PIPES

FLUES

CONNECTIONS *

2

Casing dimensions (h w d)(mm)

Height

Width

Depth

Weight (packed) kg

Maximum installation weight kg

CH output (kW) min/max @ 70°C

CH output (kW) min/max @ 40°C

DHW output (kW) Max

DHW flow rate l/min. 35°C rise

SEDBUK (2005) %

SEDBUK (2009) %

NOx classification

Adjustable to LPG

Heat exchanger material

Burner type

Fully modulating

DHW plate heat exchanger

Integrated hydroblock

Suitable for sealed systems

Suitable for open-vent systems

Filling loop

Pre-wired mains lead

Flow regulator

Inbuilt system bypass

Inbuilt condensate trap/siphon

Inbuilt boiler frost protection

Zero compartment ventilation

Top (mm) (from top of boiler)

Side (mm)

Bottom (mm)

Front (mm)

User display

User interface

Diagnostics

User adjustable

‘Eco’ setting on CH

Inbuilt programmer

Pre-piping kit

Stand-off kit

Stand-off kit inc. pipes.

Max horizontal

Max vertical

Powered vertical

Gas supply connection

CH flow connection

CH return connection

Inlet connection - DHW

Outlet connection - DHW

Ccondensate Drain

24

LOGIC COMBI ES

30 35

37.7

32.7

4.8 - 24.2

5.1 - 25.6

24.2

9.9

91

89.0

No

700

395

278

37.8

32.8

6.1 - 24.2

6.4 - 25.6

30.3

12.4

91.1

89.0

CLASS 5

Yes

Aluminium - silicon alloy

Downward firing pre-mix

No

Yes

Yes

Yes

Yes

165

2.5

100*

450*

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

9m

Digital (alpha/numeric)

Digital display & manual controls

Fault diagnosis display

Manual heating & hot water controls

Yes

Optional

Optional

Optional

Optional

8m

7.5m

22m

15mm copper compression

22mm copper compression

22mm copper compression

15mm copper compression

15mm copper compression

21.5mm

6m

38

33

7.1 - 24.2

7.5 - 25.6

35.3

14.5

91

88.9

* Can be reduced to 5mm for cupboard fit, 450mm required for servicing.

*2 For outputs exceeding 18kW (60,000Btu/h, 28mm primary pipework will be required.

TECHNICAL SPECIFICATION

25

LOGIC CODE COMBI ES.

BOILER MODEL

SIZE

PERFORMANCE

CONSTRUCTION

INSTALLATION

CLEARANCES

USER INTERFACE

PIPES

FLUES

CONNECTIONS

Casing dimensions (h w d)(mm)

Height

Width

Depth

Weight (packed) kg

Maximum installation weight kg

CH output (kW) min/max @ 70°C

CH output (kW) min/max @ 40°C

DHW output (kW) Max

DHW flow rate l/min. 35°C rise

SEDBUK (2005) %

SEDBUK (2009) %

NOx classification

Adjustable to LPG

Heat exchanger material

Burner type

Fully modulating

DHW plate heat exchanger

Integrated hydroblock

Suitable for sealed systems

Suitable for open vent systems

Filling loop

Pre-wired mains lead

Flow regulator

Inbuilt system bypass

Inbuilt condensate trap/siphon

Pump exercise

Inbuilt boiler frost protection

Zero compartment ventilation

Copper tail connections

Top (mm) (from top of boiler)

Side (mm)

Bottom (mm)

Front (mm)

User display

User interface

Diagnostics

User adjustable

‘Eco’ setting on CH

Inbuilt programmer

Pre-piping kit

Stand-off kit

Stand-off kit inc. pipes.

Security bracket kit

PRV wall outlet kit

Terminal wall plate kit

Weather compensation kit

Max horizontal

Max vertical

Powered vertical

High level flue outlet kit

Direct rear flue kit (55/80)

Gas

CH flow & return

DHW inlet & outlet

Pressure relief valve

Condensate drain

26

LOGIC CODE COMBI ES

33 38

41.3

35.9

4.8 - 24.2

5.1- 25.6

26.1

10.7

91

89.0

No

9

830

395

278

41.4

36.0

6.1 - 24.2

6.4 - 25.6

32.7

13.4

91.1

89.0

CLASS 5

No

Cast aluminium- silicon alloy

Downward firing pre-mix

Yes

Yes

Yes

Yes

Yes

Yes

165

2.5

100

Yes

Yes

Yes

No

Yes

Yes

Yes

Yes

450*

Digital (alpha/numeric)

Digital display & manual controls

Fault diagnostic display

Manual heating control

Yes

Optional

Yes

Yes

Yes

Yes

Yes

No

Yes

8

7.5

22

Yes

No

15mm

22mm

15mm

15mm

21.5mm

41.6

36.2

7.1 - 24.2

7.5 - 25.6

38.2

15.7

91

88.9

Yes

6

* Can be reduced to 5mm for cupboard fit, 450mm required for servicing.

TECHNICAL SPECIFICATION

26

LOGIC HEAT ONLY.

BOILER MODEL

SIZE

PERFORMANCE

CONSTRUCTION

INSTALLATION

CLEARANCES

USER INTERFACE

PIPES

FLUES

CONNECTIONS *

2

CH output (kW) min/max @ 40°C

DHW output (kW) Max

12

5.1 - 13.0

15

LOGIC HEAT ONLY

18

5.1 - 19.1

N/A

24 30

Casing dimensions (h w d)(mm)

Height

Width

Depth

Weight (packed) kg

Maximum installation weight kg

700

395

278

28.7

23.0

CH output (kW) min/max @ 70°C 4.8 - 12.0

4.8 - 15.0

4.8 - 18.0

4.8 - 24.2

6.1 - 30.3

5.1 - 15.9

5.1 - 25.6

6.4 - 31.0

DHW flow rate l/min. 35°C rise

SEDBUK (2005) %

SEDBUK (2009) %

NOx classification

91.2

89.4

91.1

89.3

N/A

91

89.2

CLASS 5

91

89.5

91.1

89.6

Adjustable to LPG

Heat exchanger material

Burner type

No No No No

Cast aluminium - silicon alloy

Downward firing pre-mix

Yes

Fully modulating

DHW plate heat exchanger

Integrated hydroblock

Suitable for sealed systems

Suitable for open-vent systems

Filling loop

Pre-wired mains lead

Flow regulator

Inbuilt system bypass

Inbuilt condensate trap/siphon

Inbuilt boiler frost protection

Zero compartment ventilation

Top (mm) (from top of boiler)

Side (mm)

Bottom (mm)

Front (mm)

User display

User interface

Diagnostics

User adjustable

‘Eco’ setting on CH

Inbuilt programmer

Pre-piping kit

Stand-off kit

Stand-off kit inc. pipes.

Max horizontal

Max vertical

Powered vertical

Gas supply connection

CH flow connection

CH return connection

Inlet connection - DHW

Outlet connection - DHW

Condensate drain

7.5m

22m

Yes

N/A

N/A

Yes

Yes

No

No

N/A

No

Yes

Yes

Yes

165 (100 rear outlet flue)

2.5

100

450*

Digital (alpha/numeric)

Digital display & manual controls

Fault diagnosis display

Manual heating control

Yes

No

No

Yes

No

9m

(Also available: High Level Flue Outlet Kit/

Direct Rear Flue Kit (55/80)

15mm

22mm

22mm

N/A

N/A

21.5mm

8m

* Can be reduced to 5mm for cupboard fit, 450mm required for servicing.

*2 For outputs exceeding 18kW (60,000Btu/h, 28mm primary pipework will be required.

TECHNICAL SPECIFICATION

27

LOGIC SYSTEM.

BOILER MODEL

SIZE

PERFORMANCE

CONSTRUCTION

INSTALLATION

CLEARANCES

USER INTERFACE

PIPES

FLUES

CONNECTIONS *

2

15

LOGIC SYSTEM

18 24

30

Casing dimensions (h w d)(mm)

Height

Width

Depth

Weight (packed) kg

Maximum Installation Weight kg

CH output (kW) min/max @ 70°C

CH output (kW) min/max @ 40°C

DHW output (kW) Max

DHW flow rate l/min. 35°C rise

SEDBUK (2005) %

SEDBUK (2009) %

NOx classification

Adjustable to LPG

Heat exchanger material

Burner type

Fully modulating

DHW plate heat exchanger

Integrated hydroblock

Suitable for sealed systems

Suitable for open-vent systems

Filling loop

Pre-wired mains lead

Flow regulator

Inbuilt system bypass

Inbuilt condensate trap/siphon

Inbuilt boiler frost protection

Zero compartment ventilation

Top (mm) (from top of boiler)

Side (mm)

Bottom (mm)

Front (mm)

User display

User interface

Diagnostics

User adjustable

‘Eco’ setting on CH

Inbuilt programmer

Pre-piping kit

Stand-off kit

Stand-off kit inc. pipes.

Max horizontal

Max vertical

Powered vertical

Gas supply connection

CH flow connection

CH return connection

Inlet connection - DHW

Outlet connection - DHW

Condensate drain

4.8 - 15.0

5.1 - 15.9

91.1

89.3

No

700

395

278

34.4

28.0

4.8 - 18.0

5.1 - 19.1

4.8 - 24.2

5.1 - 25.6

N/A

N/A

91

89.2

91

89.5

CLASS 5

No No

Cast aluminium - silicon alloy

Downward firing pre-mix

Digital (alpha/numeric)

Digital display & manual controls

Fault diagnosis display

Manual heating control

Yes

No

Yes

Yes

Yes

9m

7.5m

22m

15mm

22mm

22mm

N/A

N/A

21.5mm

Yes

Yes

Yes

Yes

165

2.5

100

450*

Yes

N/A

N/A

Yes

No

No

Yes

N/A

6.1 - 30.3

6.4 - 31.0

91.1

89.6

Yes

8m

* Can be reduced to 5mm for cupboard fit, 450mm required for servicing.

*2 For outputs exceeding 18kW (60,000Btu/h, 28mm primary pipework will be required.

NEW ENERGY

28

TS8000 ON-ROOF & TS8001

IN-ROOF COLLECTORS.

These lightweight flat panel collectors are manufactured on their own robotic line.

The number of individual components has been kept to a minimum for this product concept. A specially developed glue is the only joining technique used on the flat plate collector.

The collectors come with an aluminium absorber. Equipped with a modular mounting system, the collectors can be used for both flat-roof and roof-mounted installations.

SAP DATA.

TS8000 - ON-ROOF

(part number 206500)

Aperture area - 1.922m

2

Conversion factor N

0

0.769

Heat loss coefficient a

1

3.847W/m

2

K

TS8001 - IN-ROOF

(part number 206507)

Aperture area - 2.33m

2

Conversion factor N

0

0.776

Heat loss coefficient a

1

3.293W/m

2

K

SOLAR PUMP STATION (PU1).

• A custom built fully insulated pump station

• Visible temperature gauges:

- Display temperature rise

- Isolation points

• Visible pressure gauge

• Side access for pump and filling points so no need to remove the cover for most operations

• Supplied with a two years parts and labour warranty

• Quick and easy to install

• Temperature gauges

• Flow meter

• Flow & return check valves

• Pressure relief valve and pressure gauge

• Expansion vessel connection

• Filling & drain connection

SOLAR CONTROLLER (EC1).

SOLAR CONTROLLER

(EC1)

• A standard controller or an East/West controller can be supplied with the system

• Controllers are user friendly and easy to install

• Supplied with a two year parts and labour warranty

• Neat design

• Quick to install

• Simple and easy to use

• Two year parts and labour warranty

NEW ENERGY

29

CYLINDERS

30

IDEAL THERMSTORE.

The Ideal Thermstore range of stainless steel unvented indirect cylinders are manufactured to the highest standards.

The range features 8 models and 2 years parts and labour warranty so you can be sure the Thermstore combines the twin demands of excellent product quality and outstanding value.

IDEAL THERMSTORE

AVAILABLE MODELS:

90, 120, 150, 180, 210,

250, 300 & 400L

FEATURES.

• 2 year parts and labour and 25 year vessel warranty

• Duplex stainless steel construction to offer excellent resistance to corrosion

• Global Warming Potential (GWP) of 0.7 provides CfSH benefits

• Insulated using the latest HCFC free

Envirofoam

• Corrugated heat transfer coil to give

20% faster recovery than plain tube

• Manufactured in accordance with

BS EN 12897

• Complete with all quality fittings according to model

• Lightweight for ease of installation

APPLIANCE SUPPLIED.

• Hot water draw off 22mm compression

• Temperature and pressure relief valve

95˚C/6 bar

• Hot water secondary return 22mm (not fitted to cylinders below 210 litres)

• Immersion heater 1

¾” BSP 3kW

• Cold supply 22mm compression

• Dual control/overheat thermostat pocket

• Boiler control sensor pocket (spare)

• Primary flow 22mm compression –

(28mm tails for 400 litre model only)

• Primary return 22mm compression –

(28mm tails for 400 litre model only)

KIT SUPPLIED.

• Combination inlet group incorporating pressure reducing valve, strainer, check valve, balanced cold take off point, expansion relief valve and expansion vessel connection points

• Potable expansion vessel complete with flexible hose and wall bracket

• Tundish

• Dual control thermostat and combined overheat thermostat

• Two port 22mm zone valve for primary circuit

• Wiring junction box for primary system

IDEAL SOLAR THERMSTORE.

To compliment our range of solar thermal products, the Ideal Solar Thermstore range of unvented cylinders is now available. With a choice of five sizes, all of which come complete with a 2 year warranty, the Ideal Solar Thermstore range is certain to suit your cylinder needs no matter the situation.

IDEAL SOLAR THERMSTORE

AVAILABLE MODELS:

180, 210, 250,

300 & 400L

FEATURES.

• 2 year parts and 25 year vessel warranty

• Twin corrugated heating coil

• Low standing heat losses

• Global Warming Potential (GWP) of 0.7 provides CfSH benefits

• Compatible with all Ideal Solar Thermal

Kits

• Compatible with a wide range of solar systems available in the UK

APPLIANCE SUPPLIED.

• Hot water draw off 22mm compression

• Temperature and pressure relief valve

95˚C/6 bar

• Hot water secondary return 22mm (not fitted to cylinders below 210 litres)

• Immersion heater 1

¾” BSP 3kW

• Cold supply 22mm compression

• Dual control/overheat thermostat pocket

• Primary flow 22mm compression –

(28mm tails for 400 litre model only)

• Primary return 22mm compression –

(28mm tails for 400 litre model only)

• Solar coil return to collector 22mm compression

• Solar coil flow from collector 22mm compression

• Solar thermostat pocket

KIT SUPPLIED.

• Combination inlet group incorporating pressure reducing valve, strainer, check valve, balanced cold take off point, expansion relief valve and expansion vessel connection points

• Potable expansion vessel complete with flexible hose and wall bracket

• Tundish

• Dual control thermostat and combined overheat thermostat

• Two port 22mm zone valve for primary circuit

• Wiring junction box for primary system

CYLINDERS

31

HEATING

32

STELRAD ELITE.

FEATURES.

Outstanding choice, versatility, quality and performance make Stelrad Elite the UK’s most popular radiator - the perfect solution when maximum heat output is needed from a steel panel radiator. The Elite range is readily available nationwide.

• 183 models

• Heights: 300mm to 700mm

• Lengths: 400mm to 3000mm

• Outputs: 190 to 6033 watts, 650 to

20585 Btu/hr

• Types: P1, K1, P+ & K2

STELRAD COMPACT.

HEATING

33

FEATURES.

The Compact is the UK’s best selling and most comprehensive range of compact radiators. They’re proven, high performance winners - ideal for every room and every application where space is at a premium.

HORIZONTAL

• 240 horizontal models

• Heights: 300mm to 700mm

• Lengths: 400mm to 3000mm

• Outputs: 190 to 5883 watts, 647 to

20073 Btu/hr

• Types: P1, K1, P+, K2 & K3

VERTICAL

21 vertex models

Heights: 1800mm, 2000mm

& 2200mm

Lengths: 300mm to

700mm

Outputs: 1146 to 3003 watts, 3910 to 10246 Btu/hr

• Types: P2 & K2

HEATING

34

STELRAD COMPACT WITH STYLE RANGE.

FEATURES.

The subtle architectural look and feel of the Compact with Style is combined with value, range and availability to give you sophisticated designer styling for any room, commercial or domestic, at affordable prices.

HORIZONTAL

• 52 horizontal models

• Heights: 200mm to 600mm

• Lengths: 400mm to 2000mm

• Outputs: 235 to 3202 watts, 802 to

10925 Btu/hr

• Types: K1, P+ & K2

VERTICAL

• 24 vertical models

• Heights: 1600mm to 2200mm

• Lengths: 300mm to 700mm

• Outputs: 693 to 2772 watts, 2365 to

9458 Btu/hr

• Types: P2 & K2

STELRAD TOWEL RAIL.

HEATING

35

FEATURES.

Stelrad Towel Rails offer stylish looks and effective heating and drying performance - in the bathroom or in the kitchen. Available from stock in white or chrome.

• 26 models

• Heights: 678mm to 1744mm

• Lengths: 400mm, 500mm & 600mm

• Outputs: 240 to 1022 watts, 820 to 3489 Btu/hr

• Types: Straight, curved, white or chrome

HEATING

36

STELRAD STR.

FEATURES.

This simple design is the ultimate in neat, efficient functionality for towel warming and space heating. The superbly integrated unit allows towels and clothes to warm without interfering with the vital flow of convected room heat.

• 5 models

• Heights: 645mm & 745mm

• Lengths: 425mm & 625mm

• Outputs: 419 to 922 watts, 1430 to 3147

Btu/hr

• Type: K1

STELRAD PLANAR.

HEATING

37

FEATURES.

Simple and understated design makes Planar the ultimate in minimalism for radiators.

With its completely flat, smooth finish and integrated top grille and side panels it has a remarkably slim and stylish profile that will enhance any space.

HORIZONTAL

• 100 horizontal models

• Heights: 300mm to 700mm

• Lengths: 400mm to 3000mm

• Outputs: 235 to 4901 watts, 802 to

16729 Btu/hr

• Types: K1 & K2

VERTICAL

12 vertical models

Heights: 1800mm, 2000mm & 2200mm

Lengths: 400mm to 700mm

Outputs: 1476 to 2961 watts, 5036 to

10103 Btu/hr

Types: K2

TO SEE THE FULL STELRAD RANGE,

PLEASE VISIT WWW.STELRAD.COM

CUSTOMER SERVICE

38

CUSTOMER SERVICE.

At Ideal Boilers, we are committed to delivering the highest level of customer service. With more than 100 years’ experience in the heating industry, we know how important confidence and trust are to our customers.

WITHIN OUR CALL CENTRE

All customer calls will be answered by trained members of staff who will take ownership of the call. Trained staff will assist with enquiries or help diagnose and resolve faults over the telephone. If a resolution is not reached over the phone, an engineer visit will be arranged.

OUR ENGINEERS

All Ideal Boilers’ engineers are trained to the highest possible standard, including being Gas Safe Registered.

ENGINEER VISITS

In the event of an engineer being required, we endeavour to make all visits within one day of receiving a call for boilers and three working days for solar products. On the day of the scheduled visit, the appointed engineer will telephone between 8am and 9am to confirm the time of their arrival.

TOTAL PEACE OF MIND

During the engineer’s visit the engineer will fully explain any actions taken and in the event of any further work that need to be done the team will keep you fully informed throughout. All letters and emails will be replied to within five working days.

AFTERSALES SUPPORT.

With a range of tools to help you grow your business, Ideal is on hand to ensure you have the support you need.

Our dedicated customer service department is available 364 days a year, 8am to 8pm Monday to Friday, as well as 8am to

4pm on a Saturday and 8am to 12 noon on a Sunday.

Installer helpline 01482 498663

Homeowner helpline 01482 498660

Technical customer service 01482 498663

We also have a team of expert engineers, fully trained to exacting standards and Gas Safe registered, on hand to provide one-to-one advice on the road, over the phone or online ensuring you’re fully supported, wherever and whenever you need.

PARTS REQUESTS.

Ideal’s extensive quality testing procedures ensure that all of our products are manufactured to the highest quality standards.

In the unlikely event that a spare part is required, you can rest assured that most parts are readily available to order via your local spares outlet for up to 10 years after appliance production has ceased.

Ideal spare parts can be obtained from any of Ideal’s nationwide network of approved stockists.

For more information about Ideal spare parts and for a list of stockists, please visit our website or call our parts department on:

01482 498665 www.idealparts.com

AFTERSALES SUPPORT

39

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
