Logic+
Logic+
06
07
01.
Logic+
Thanks to unrivalled levels of reliability the
Logic+ range of boilers comes with a 7 year
warranty* and supported by the Queen’s
Award for Enterprise 2013, Good Housekeeping
Reader Recommendation and being voted
Product of the Year for 2013.
The Logic+ range has been designed to
ensure a quick and hassle free installation.
Benefiting from concealed connections and
comprehensive controls, all models also feature
a translucent condensate siphon to allow any
debris to be spotted quickly and easily.
key Features
There is no wonder the Logic+ range is
installed by thousands of installers across the
country with a range of key features built in
as standard:
LOGIC+
• Compact cupboard fit
• Low lift weight
(33kg for combination models)
• Plain text display with simple diagnostics
• Pre-formed copper tails
• Pre-wired mains lead
• Wide range of flue options
The Logic+ is the flagship range of high efficiency boilers
from Ideal. Compact in size and fully modulating down
to as low as 4.8kW, the Logic+ provides excellent energy
savings making it the perfect choice for new or replacement
installations.
Siting a Logic+ boiler is quick and simple thanks to a
telescopic flue, push and clip flue turret connections and
zero compartment ventilation, which allows the product to
be installed neatly into a standard kitchen cupboard (always
check measurements before installation).
WINNER
Household Boiler Category.
Survey of 11,941 people by TNS.
*7 year warranty available until 31st December 2014. The standard
warranty period on the Logic+ range is 5 years.
Logic+ Combi
Logic+
08
09
Logic+ Combi 24 30 35
Available in outputs of 24, 30 and 35 kW,
the Logic+ Combi is designed to ensure a
quick and hassle free installation thanks to
concealed connections, built-in automatic
bypass and an integral filling loop.
A translucent condensate siphon also
allows any debris to be spotted quickly
and efficiently.
Siting the product is quick and simple
too thanks to a telescopic flue, fast fix flue
turret connections and zero compartment
ventilation which allows the product to be
installed neatly into a standard
kitchen cupboard.
A clear 16 character backlit display
provides a plain English description of the
heating and hot water functions, together
with fault information. A history log provides
further reassurance.
Complete with a 7 year parts and labour
warranty* and recommended by the Energy
Saving Trust, the Logic+ delivers total home
comfort and customer peace of mind.
Features
Compact
Frost
Protection
Flue
Variants
Clearances & Dimensions
LPG
Conversion**
NOx Class 5
specification
24 30 35
Logic+ Combi.
7 Year
Warranty*
RELIABLE
• Award winning range
• Energy Saving Trust recommended
• 7
year parts and labour warranty*
• B
uilt-in frost protection
• B
uilt-in filling loop
• P
re-heat function
• S
ervice indication
EASY TO INSTALL
• C
ompact cupboard fit
• D
oor to optional timers includes
user instructions
• Fast fix telescopic horizontal flue
• Wide range of additional flueing options
•
•
•
•
•
•
•
•
•
•
ow lift weight (33kg)
L
Pre-formed copper tails
Plain text display
Pre-wired mains lead (2m) & spare
fuses included
Pre-piping kit
PRV wall outlet pipe included
Universal condensate connection
Stand off kit including piping
Compatible with a range of additional
controls inc. weather compensation and
Opentherm controls
LPG conversion kit available
for 30 kW boilers
*7 year warranty available until 31st December 2014. The standard warranty period on the Logic+ range is 5 years.
**30 kW model only.
Note: The minimum front clearance when built into a cupboard is 5mm
from the cupboard door but 450mm overall clearance with the cupboard
door open is required for servicing.
*Bottom clearance after installation can be reduced to 5mm. However, 100mm is required for servicing.
logic+ system
Logic+
10
11
Logic+ system 15 18 24 30
Reccomended by the Energy Saving Trust and
available in a choice of four outputs – 15, 18,
24 and 30 kW, the Logic+ System is suitable
for a wide variety of sealed domestic systems
and features a lightweight compact cupboard
fit design.†† There are concealed connections
at the base and no compartment ventilation
is required, so the Logic+ System can be
conveniently located out of sight in both new
or replacement installations.
Product design and quality is paramount
within the Logic+ System range; additional
features such as a PRV wall outlet pipe
ensure total reliability and a hassle
free installation.
Features
Compact
Frost
Protection
Flue
Variants
Clearances & Dimensions
LPG
Conversion**
NOx Class 5
Digital display
specification
15 18 24 30
Logic+ system.
7 Year
Warranty*
RELIABLE
• Award winning range
• Energy Saving Trust recommended
• 7 year parts and labour warranty*
• Built-in frost protection
• Service indication
EASY TO INSTALL
• Compact cupboard fit
• Wide range of flueing options
• Concealed pipe connections
• Low lift weight (28kg)†
• Pre-formed copper tails
• LPG Conversion kit available
for 30 kW boilers
• Stand off kit and pre-pipe options
• PRV wall outlet pipe
• Pre-wired mains lead
Note: The minimum front clearance when built into a cupboard is 5mm
from the cupboard door but 450mm overall clearance with the cupboard
door open is required for servicing.
*7 year warranty available until 31st December 2014. The standard warranty period on the Logic+ range is 5 years.
**30 kW model only.
†Weight with front panel removed.
††Please check kitchen cupboard size prior to installation.
*Bottom clearance after installation can be reduced to 5mm. However, 100mm is required for servicing.
logic+ Heat Only
Logic+
12
13
Logic+ heat only 12 15 18 24 30
Incorporating the latest in heating design
and technology, the Logic+ Heat Only is
an outstanding heat only solution for both
new build or replacement installations alike.
Available in a choice of five outputs – 12, 15,
18, 24 and 30 kW, the Logic+ Heat Only will
deliver total home comfort for a wide range of
domestic properties.
Installers have the further choice of neat direct
rear flue options as required, helping to further
speed up the installation in retro fit situations.
Suitable for open vent and sealed systems, the
Logic+ Heat Only boiler is straightforward to
site and install. No compartment ventilation,
compact fit and a lightweight design mean the
boiler can be neatly installed out of sight in a
kitchen cupboard.†††
7 Year
Warranty*
Compact
Frost
Protection
Flue
Variants
Clearances & Dimensions
LPG
Conversion**
NOx Class 5
digital
display
direct
rear flue
specification
12 15 18 24 30
Logic+ heat only.
Features
RELIABLE
• Energy Saving Trust recommended
• 7 year parts and labour warranty*
• Boiler frost protection
• W
ater flow sensor
EASY TO INSTALL
• Compact cupboard fit
• Direct 80mm diameter rear flue option
• Wide range of flueing options
• Low lift weight (23kg)††
• Top system connections
• 75mm deep translucent condensate siphon
• Stand-off kit
• Terminal wall plate kit
• Security bracket kit
• Low minimum head requirement
• LPG conversion kit available for
30 kW boilers
• Fully modulating operation down
to 4.8 kW †
• Weather compensation kit option
*7 year warranty available until 31st December 2014. The standard warranty period on the Logic+ range is 5 years.
**30 kW model only.
†(30 kW only - 6.1 kW).
††Weight with front panel removed.
†††Please check kitchen cupboard prior to installation.
Note: The minimum front clearance when built into a cupboard is 5mm
from the cupboard door but 450mm overall clearance with the cupboard
door open is required for servicing.
Bottom clearance after installation can be reduced to 5mm. However, 100mm is required for servicing.
Rear flue option - top clearance 100mm.
*
**
logic+
Logic+
14
15
Technical specification
Logic+ Combi
Boiler Model
Size
24
18
395
278
37.7
37.8
38
278
278
34.4
28.7
28.0
24
30
32.7
32.8
33
CH output (kW) Min/Max @ 70°C
4.8 - 24.2
6.1 - 24.2
7.1 - 24.2
4.8 - 15.0
4.8 - 18.0
4.8 - 24.2
6.1 - 30.3
4.8 - 12.0
4.8 - 15.0
4.8 - 18.0
4.8 - 24.2
6.1 - 30.3
CH output (kW) Min/Max @ 40°C
5.1 - 25.6
6.4 - 25.6
7.5 - 25.6
5.1 - 15.9
5.1 - 19.1
5.1 - 25.6
6.4 - 31.0
5.1 - 13.0
5.1 - 15.9
5.1 - 19.1
5.1 - 25.6
6.4 - 31.0
DHW output (kW) Max
24.2
30.3
35.3
DHW flow rate l/min. 35°C rise
9.9
12.4
14.5
91
89.0
91.1
89.0
91
88.9
9 1.1
89 .3
91
89.2
91
89.5
91.1
89.1
No
No
No
No
Yes
Heat exchanger material
Yes
23.0
N/A
N/A
N/A
CLASS 5
No
N/A
91
89.5
91.1
89.6
91.2
89.4
91.1
89.3
No
Yes
No
No
CLASS 5
91
89.2
CLASS 5
No
Cast Aluminium - Silicon Alloy
Cast Aluminium - Silicon Alloy
Cast Aluminium - Silicon Alloy
Downward firing pre-mix
Downward firing pre-mix
Downward firing pre-mix
Fully modulating
Yes
Yes
Yes
DHW plate heat exchanger
Yes
N/A
N/A
Integrated hydroblock
Yes
N/A
N/A
Suitable for sealed systems
Yes
Yes
Yes
Suitable for open-vent systems
No
No
Yes
Filling loop
Yes
No
No
Pre-wired mains lead
Yes
Yes
No
Flow regulator
Yes
N/A
N/A
In-built system bypass
Yes
Yes
No
In-built condensate trap/siphon
Yes
Yes
Yes
In-built boiler frost protection
Yes
Yes
Yes
Zero compartment ventilation
Yes
Yes
Yes
Top (mm) (from top of boiler)
165
165
165 (100 rear outlet flue)
Side (mm)
2.5
2.5
2.5
100*
100*
100*
Bottom (mm)
Front (mm)
450*
450*
450*
User display
Plain text
Plain text
Plain text
Text display & manual controls
Digital display & manual controls
Digital display & manual controls
User interface
Diagnostics
User adjustable
‘Eco’ setting on CH
Connections**
15
395
Burner type
Flues
12
395
NOx Classification
Pipes
Logic+ Heat Only
30
Width (mm)
Optional LPG kit
User Interface
24
700
SEDBUK (2005) %
SEDBUK (2009) %
Clearances
18
700
Maximum installation weight kg
Installation
15
700
Depth (mm)
Construction
Logic+ System
35
Height (mm)
Weight (packed) kg
Performance
30
Plain English text
Fault diagnosis display
Fault diagnosis display
Manual heating & hot water controls
Manual heating control
Manual heating control
Yes
Yes
Yes
In-built programmer
Optional
No
No
Pre-piping kit
Optional
Yes
No
Stand-off kit
Optional
Yes
Yes
Stand-off kit inc. pipes
Optional
Yes
Max horizontal
9m
8m
6m
9m
9m
No
9m
8m
9m
9m
9m
9m
Max vertical
7.5m
7.5m
7.5m (Also available: High Level Flue Outlet Kit/
Direct Rear Flue Kit (55/80)
Powered vertical
22m
22m
22m (Also available: High Level Flue Outlet Kit/
Direct Rear Flue Kit (55/80)
Gas supply connection
15mm copper compression
15mm
15mm
CH flow connection
22mm copper compression
22mm
22mm
CH return connection
22mm copper compression
22mm
22mm
Inlet connection - DHW
15mm copper compression
N/A
N/A
Outlet connection - DHW
15mm copper compression
N/A
N/A
21.5mm
21.5mm
21.5mm
Condensate drain
*Can be reduced to 5mm, 450mm required for servicing.
**For outputs exceeding 18 kW (60,000 Btu/h), 28mm primary pipework will be required.
8m
vogue
VOGUE
16
17
02.
vogue
Showcasing unique boiler innovation, the Vogue from Ideal
Boilers utilises modern technology teamed with premium
parts and components to bring you the next step in
domestic heating intelligence.
The complete design, from component specification,
manufacture and build, through to consumer use is
engineered with quality in mind. All models in the Vogue
range deliver premium performance, reliability and are
supported by a premium aftersales support service.
vogue
The Vogue range comes complete with
comprehensive components and a 7 year
warranty as standard for complete
peace of mind.
As well as receiving a Good Housekeeping
Reader Recommendation, the Vogue is the
ideal solution for customers looking for a top
of the range product.
vogue
vogue
18
19
vogue
Combi 26 32 40 SYSTEM 15 18 26 32
Every model in the Vogue range comes
complete with a 7 year parts and labour
warranty. When choosing Vogue, installers
and homeowners can rest assured that they
will be receiving ultimate peace of mind.
Unrivalled levels of reliability are achieved
through integrated product design - only
high specification components and interface
are used, and all our suppliers have market
leading technical competence and quality
assured processes.
COMBI 26 32 40 SYSTEM 15 18 26 32
Vogue.
The Vogue range also comes with a dedicated
customer service helpline.
Features
7 Year
Warranty
Compact
Frost
Protection
Flue
Variants
NOx Class 5
digital
display
premium
components
high
performance
dedicated
Customer service
LPG
Conversion
key features
• A
utomatic bypass**
• Filling loop**
• Service display with installer telephone
number input
• Pre-wired mains lead
• Pre-formed copper tails at pipe
clip distance
• Stainless steel heat exchanger
**Combi only.
•
•
•
•
•
•
niversal condensate drain connection
U
Casing clean point
Pump, diverter valve exercise & anticycling
Boiler frost protection
Commissioning function
Fault history & help text
vogue
vogue
20
21
Clearances & Dimensions
Technical specification
Vogue Combi
2.5
445
2.5
from case
Boiler Model
330
Size
Flue
terminal
Performance
26
445
445
Depth (mm)
330
41.7
43.7
37.7
38.0
40.9
41.1
Installation weight (kg)
34.8
36.1
38.1
32.6
33
35.8
36.1
CH output (kW) Min/Max @ 70°C
18
26
32
15
18
26
32
CH output (kW) Min/Max @ 40°C
19.3
27.9
34.3
16.2
19.3
27.9
34.3
26
32
40
10.6
13.1
16.4
91
91.1
91
91
91.1
91.1
91.1
SEDBUK (2009) %
89.1
89.2
89.1
88.9
89.3
89.3
89.3
EASY TO INSTALL
• Modulating pump
• Longer maximum flue lengths
with easy access sampling points
• Brass waterset including readily
accessible parts
• Choice of plug-in controls
RELIABLE
• 7 year parts & labour warranty
as standard
• Dedicated customer services helpline
• High flow 40 kW Combi
• Comprehensive standard components
premium components
• Stylish chassis with full size door complete
with damped opening
• Stainless steel heat exchanger
Yes
Stainless steel
Pre-mix steel with ‘Cool burner door’
7:1
5:1
Yes
N/A
Brass with
Modulating pump
Modulating pump
Suitable for sealed systems
Yes
Yes
Suitable for open-vent systems
No
No
Filling loop
Yes
No
Pre-wired mains lead
Yes
No
In-built system bypass
Yes
Yes
In-built condensate trap/siphon
Yes
Yes
In-built boiler frost protection
Yes
Yes
PRV Wall outlet pipe standard
Yes
Yes
Zero compartment ventilation
Yes
Yes
Top (mm) (from top of boiler)
165
165
Side (mm)
2.5
2.5
Bottom (mm)
100
100
450*
450*
User display
Large backlit LCD with text & symbols
User interface
Text display & manual controls
Diagnostics
User adjustable
Plain English text
Manual heating & hot
water controls
Yes
Yes
DHW preheat
Yes
N/A
Pressure gauge
Pipes
Flues
Analogue in control panel
Optional
(Mech. & electronic)
Optional
Stand-off kit
Yes
Yes
Stand off kit inc. pipes.
Yes
Yes
Max horizontal
10
Max vertical
Connections**
Manual heating control
Eco setting on CH
In-built Programmer
8
8
10
10
10
10
10
Gas Supply Connection
22mm
22mm
CH Flow Connection
22mm
22mm
CH Return Connection
22mm
22mm
Inlet Connection - DHW
15mm
N/A
Outlet Connection - DHW
Condensate Drain
*Bottom clearance after installation can be reduced to 5mm. However, 100mm is required for servicing.
5
Yes
Front (mm)
User Interface
N/A
5
Heat exchanger material
Pump & hydroblock
product intelligence
• Cool door technology
• Modulating pump
• Up to 7:1 modulation
• Large 10 litre expansion vessel
• Large backlit LCD with plain text
• Service display & telephone number input
N/A
SEDBUK (2005) %
DHW plate heat exchanger
Clearances
330
40.4
Fully modulating output
specification
32
Packaged weight (kg)
Burner type
Dimensions applicable to all models.
26
Width (mm)
Optional LPG kit
450 (Inc. clearance)
18
740
NOx Classification
100*
15
740
DHW flow rate l/min. 35°C rise
Construction
Vogue System
40
Height (mm)
DHW output (kW) Max
740
32
*Can be reduced to 5mm, 450mm required for servicing.
**For outputs exceeding 18kW (60,000 Btu/h), 28mm primary pipework will be required.
15mm
N/A
21.5mm Universal
21.5mm Universal
8
thermostats & timers
KITS & Controls
22
23
03.
electronic Timer
Easy to use heating control through a plug-in
digital timer. Plain text operating and diagnostics
information. 7 day and up to 3 time periods per
day. Automatic summer/winter time update.
• Part No. 204545 Logic+ Combi
• Part No. 208907 Vogue Combi
• Part No. 208909 Vogue System
Image shown is 204545
Mechanical Timer
Simple heating control through a plug -in
analogue timer. 24 hour tappet operation with
off/timed/continuous periods.
• Part No. 204839 Logic+ Combi only
• Part No. 208445 Vogue Combi only
Image shown is 204839
kits &
controls
Here at Ideal we believe that choosing the right control to
meet the needs of your customer is as important as choosing
the right product; that’s why the Logic+ and Vogue boilers
are fully compatible with a range of thermostats and timers
for the ultimate in home comfort.
RF Electronic
Programmable
Thermostat
Wireless Radio Frequency (RF) digital timer
and room thermostat providing heating
control. 7 day, plain text operating and
diagnostics display. Automatic summer/winter
time update.
• Part No. 204789 Logic+ Combi only
• Part No. 208427 Vogue Combi only
Image shown is 208427
LPG CONVERSION KITS
KITS & Controls
24
25
LPG CONVERSION KITS
Designed for use with the Logic+ and Vogue range of
boilers, the Ideal LPG (propane) conversion kit provides
a simple and robust conversion solution.
RF Mechanical
Timer and Room
Thermostat Kits
Easy to use remote frequency timer, complete with
room thermostat. The timer is prewired with plug-in
connections to the boiler wiring and features a 24hr
tappet operation with off/timed/continuous period.
The room thermostat can be freestanding or wall
mounted and has a compact design with LCD
display and simple symbols to indicate the control.
Image shown is 208352
Weather compensation
Outdoor Sensor
Ideal boiler ranges provide weather compensation when fitted with
an outdoor sensor (which is available as an optional accessory).
Weather compensation works by measuring the temperature outside
the home and adjusting the temperature (or flow) of the radiators
inside. If the weather is particularly cold outside, the outdoor sensor
will communicate with the boiler intelligently to increase the radiator
temperature. This process also works in reverse, as the outdoor
temperature increases, the flow to the radiators will decrease.
This process allows the system to operate more efficiently by
only heating to the minimum temperature necessary and
also preventing spikes in heating activity.
• Part No. 204914 Logic+ Combi
• Part No. 206152 Logic+ System & Heat
• Part No. 208921 Vogue Combi & System
Image shown is 204914/206152
Wireless Radio Frequency (RF) analogue
timer and room thermostat providing heat
control. Easy to use 24 hour tappet control.
• Part No. 204824 Logic+ Combi only
• Part No. 208974 Vogue Combi only
Image shown is 208974
natural gas to
lpg kit contents
• Available for all Logic+ and Vogue ranges
(Combi, Heat & System)
• Suitable for most property sizes
• Fast & simple conversion with pre-set
gas valve for no product adjustment
Each kit comprises:
• Gas valve (preset operation)
• Burner injector
• BCC (Boiler chip card)
• Data plate labels
• Instructions
products applicable
• Logic+ Combi 30 kW (serial letter code ZJ and onwards)
• Logic+ Heat 30 kW
• Logic+ System 30 kW
• Vogue Combi 26, 32, 40 kW
• Vogue System 15, 18, 26, 32 kW
• Part No. 208352 Logic+ Combi only
• Part No. 208912 Vogue Combi only
RF Mechanical
Programmable
Thermostat
features and
benefits
Please note the above kits are only applicable to
Logic+ Combi boilers with serial code letters shown above
(produced from June 2011).
Use of the preset gas valve ensures the safety of a
non-adjustable gas valve is retained during conversion.
Two data plate labels are provided in the kits inclusive of a
new data plate providing LPG details and a label to retain
boiler serial number identity.
lpg heat outputs
Boiler Model
Logic+
Combi 30
Logic+
Heat 30
Logic+
System 30
Min. output (kW)
8.0
8.0
8.0
4.4
5.4
6.7
3.8
4.4
5.2
8.0
Max. output (kW)
24.3
30.3
30.3
18.0
26.0
32.0
15.0
18.0
26.0
32.0
Max. DHW output (kW)
30.3
N/A
N/A
26.0
32.0
40.0
N/A
N/A
N/A
N/A
Product Code
207650
Vogue Combi
26
32
40
NG - LPG Conversion Kits
Logic+ Combi 30
207652
Logic+ Heat 30
207654
Logic+ System 30
209282
Vogue Combi 26
209283
Vogue Combi 32
209284
Vogue Combi 40
209285
Vogue System 15
209286
Vogue System 18
209287
Vogue System 26
209288
Vogue System 32
Product Code
LPG - NG Conversion Kit
176658
Logic+ Combi 30
176660
Logic+ Heat 30
176662
Logic+ System 30
177107
Vogue Combi 26
177108
Vogue Combi 32
177109
Vogue Combi 40
177110
Vogue System 15
177111
Vogue System 18
177112
Vogue System 26
177113
Vogue System 32
15
Vogue System
18
26
32
High Efficiency cylinders
26
High Efficiency cylinders
27
04.
High
Efficiency
cylinders
If you’re installing a heat only or system boiler from
the Ideal Logic+ or Vogue range, then consider the
Thermstore range of cylinders – the perfect solution for
new or replacement installations.
thermstore
High
Efficiency cylinders
thermstore
28
06
29
thermstore
90 120 150 180 210 250 300 400
The Ideal Thermstore range of stainless steel
unvented, indirect cylinders are manufactured
to the highest standards. We have 8 models in
the range, all with a 2 years parts and labour
warranty so you can be sure the Thermstore
allies the twin demands of excellent product
quality with outstanding value.
KEY Features
90 120 150 180 210 250 300 400
thermstore.
• 2
year parts and labour and 25 year
vessel warranty
• Duplex stainless steel construction to offer
excellent resistance to corrosion
• Global Warming Potential (GWP) of 0.7
provides CfSH benefits
• Insulated using the latest HCFC
free Envirofoam
• C
orrugated heat transfer coil to give 20%
faster recovery than plain tube
• Manufactured in accordance with
BS EN 12897
• Complete with all quality fittings according
to model
• Lightweight for ease of installation
• Standing heat loss as low as 0.8 kW hr/24hr
basic appliance
(supplied)
• H
ot water draw of 22mm compression
• Temperature and pressure relief valve 95˚C/6 bar
• Hot water secondary return 22mm (not fitted to cylinders below 210
litres)
• Immersion heater 1 3/4” BSP 3 kW
• Cold supply 22mm compression
• Dual control/overheat thermostat pocket
• Boiler control sensor pocket (spare)
• Primary flow 22mm compression (28mm tails for 400 litre
model only)
• Primary return 22mm compression (28mm tails for 400 litre
model only)
component kit
(supplied)
Home Set up
• C
ombination inlet group incorporating pressure reducing valve,
strainer, check valve, balanced cold take-off point, expansion relief
valve and expansion vessel connection points
• Portable expansion vessel complete with flexible hose and
wall bracket
• Tundish
• Dual control thermostat and combined overheat thermostat
• Two port 22mm zone valve for primary circuit
• Wiring junction box for primary system
Technical specification
Ideal Thermstore
Boiler Model
Size
90
120
150
180
210
250
300
400
Height (mm)
745
930
1120
1305
1495
1745
1992
2030
Diameter (mm)
550
550
550
550
550
550
550
630
Weight (empty) (kg)
Performance
19
22
26
28
33
38
44
55
Weight (full) (kg)
109
142
176
208
243
288
344
455
Capacity (litres)
400
90
120
150
180
210
250
300
Pressure regulator (bar)
3
3
3
3
3
3
3
3
Expansion vessel size (litres)
12
12
18
18
24
24
35
2 x 24
Rating of primary coil (kW)
16.5
18.0
18.5
19.0
20.5
21.5
25.0
30.5
Recovery time after 70% draw off (min)
16
19
19
21
26
30
32
36
Heat up time from 15°C to 60°C (min)
21
27
28
33
41
44
48
55
0.80
1.06
1.27
1.48
1.70
1.85
2.04
2.82
Standing losses (kWhr/24hr)
FLUE KITS
flue siting
30
31
FLUE SITING
There are a substantial number of fluing
options available with the Ideal ranges, giving
excellent siting flexibility for almost
all applications.
Logic+ & Vogue
The range of options include standard and
telescopic flues as well as roof flue and
powered verticle flue options.
flue kits
To ensure siting issues are kept to a minimum
High Level Flue Outlet kit options and Flue
Deflector kits are available.
Minimum dimensions of
flue terminal positions
300m
m
min
FLUE TERMINAL POSITION
MIN. SPACING
690mm
fixed
1.Directly below, above or alongside an opening 300mm (12”)
window, air vent or other ventilation opening.
2. Below guttering, drain pipes or soil pipes
BS5440-1 2008
3.Below eaves.
BS5440-1 2008
4.Below balconies or car port roof.
BS5440-1 2008
5.From vertical drain pipes or soil pipes.
BS5440-1 2008
Aluminium shield
25mm (1”)*
75mm (3”)
m
0m
300mm 30 in
m
min
25mm (1”)*
200mm (8”)
25mm (1”)*
200mm (8”)
LOGIC+
625mm
fixed
Stand off kits
25mm (1”)*
150mm (6”)
25mm (1”)*
BS5440-1 2008
300mm (12”)
7.Above ground, roof or balcony level
300m (12”)
8.From a surface or boundary facing a terminal.
600mm (24”)
9.From a terminal facing a terminal.
1200mm (48”)
10.From an opening in a car port (eg. door or
window) into dwelling.
1200mm (48”)
11.Vertically from a terminal on the same wall.
1500mm (60”)
12.Horizontally from a terminal on the wall.
300mm (12”)
• Part No. 204913 Stand off kit
• Part No. 204872 Stand off kit inc. piping (combi)
• Part No. 206154 Stand off kit inc. piping (system)
• Part No. 206153 Stand off kit inc. piping (heat only)
A
A
A
B
13.Above the roof pitch with roof slope of
all angles.
300mm (12”)
Above flat roof.
300mm (12”)
14.From a single wall face.
300mm (12”)
300mm (12”)
A = 600mm
B = 2000mm
15.Below Velux window.
2000mm (79”)
16.Above or side of Velux window.
600mm (24”)
The flue terminal shall not penetrate the shaded
area of the roof.
From corner walls.
*Only one reduction down to 25mm is allowable per installation
otherwise BS5440-1 2008 dimensions must be followed.
Stand off kits
• Part No. 208442 Stand off kit
• Part No. 208443 Stand off kit inc. piping (combi)
• Part No. 208707 Stand off kit inc. piping (system)
VERTICAL FLUES
VOGUE
07
98
RF
6.From an internal or external corner or to a
boundary alongside the terminal.
• Part No. 208171 Standard horizontal flue (600mm long)
• Part No. 208169 Telescopic horizontal flue
• Part No. 208174 1m horizontal flue
• Part No. 208290 Raised horizontal flue inc. vertical flue adaptor and 1m extension
• Part No. 203129 1m flue extension
• Part No. 203130 90 degree flue elbow
• Part No. 203131 45 degree flue bends (pair)
• Part No. 208178 Plume management kit
• Part No. 203228 Plume kit 1m extension
• Part No. 203229 Plume kit 90 degree elbow
• Part No. 203230 Plume kit 45 degree bends (pair)
• Part No. 208175 Vertical flue connector to convert boiler for vertical flue
• Part No. 203132 Vertical flue (does not include vertical flue adaptor)
• Part No. 152258 Angled weather collar for vertical flue (fits slate & tiles)
• Part No. 152259 Flat roof weather collar for vertical flue
• Part No. 208176 Flue deflector (clips on end of flue & angles pluming away)
• Part No. 205990 Rear outlet flue (Logic+ heat only)
• Part No. 205989 High level flue outlet kit (Logic+ heat only, rear flue only)
• Part No. 208177 Balcony flue outlet kit
32
Great
Boilers
from
great
Britain.
Ideal Boilers
PO Box 103
National Avenue
Kingston upon Hull
East Yorkshire
HU5 4JN
T 01482 492251
[email protected]
www.idealboilers.com
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
