BIG-IP Local Traffic Manager BIG-IP Available Add-On Modules

BIG-IP Local Traffic Manager BIG-IP Available Add-On Modules
BIG-IP
®
BIG-IP LTM Performance and Reliability
iControl – Creating the Application Aware Network
Available Add-On Modules
Ground-Breaking Performance
BIG-IP LTM delivers the industry’s fastest application traffic
management solution. Its specially designed architecture merges
a high performance switching fabric with individual, best-inclass hardware optimizers for SSL and L4 to completely offload
system CPU. BIG-IP LTM delivers real-world performance across all
functions and provides deep packet inspection at network speeds.
The F5 iControl™ API and SDK help automate communications
between third-party applications and BIG-IP LTM, removing the
need for manual intervention. iControl supports a true publish/
subscribe model. This model reduces network overhead and
improves the performance of applications that integrate with
BIG-IP LTM through the iControl interface. For the majority of
applications, this can reduce network bandwidth and processing
time on both the client and the server.
Intelligent Compression Module
Condenses HTTP traffic using industry-standard gzip and DEFLATE
compression algorithms, reduces bandwidth consumption, and speeds
end-user download times over slower/low bandwidth connections.
Advanced GUI and Simplified Management
An advanced GUI delivers easy product configuration that lowers
setup and ongoing maintenance costs.
Networking
BIG-IP LTM supports basic layer 2 and layer 3 protocols:
Supports STP, MSTP, RSTP
Link aggregation
VLAN tagging
QoS/ToS
Third party MIB support: all default Net-SNMP
BIG-IP – Scale, Secure, and Optimize
Profile-Based Configuration
Profile objects enable you to create traffic behavior templates
that can be applied to different resources, reducing repetition and
providing a centralized approach to changing settings.
Better Visibility
BIG-IP LTM provides detailed system instrumentation on traffic
statistics (globally and per object) to help you better monitor all
activities and resources.
Rich User Interface
Delivered over a secure, SSL browser-based interface, the advanced
GUI includes online help, searching and sorting, in-line creation
and much more, dramatically reducing the time it takes to set up
and maintain large configurations.
More Functions, More User Types
Administrative domains allow you to design customized partitions
and assign varying degrees of administrative rights and views of
BIG-IP LTM functions. Adminstrators can design customized views
by service, application owners, or other segmentation scheme,
providing unprecedented management scale and organizational
efficiency.
BIG-IP LTM intelligently manages hundreds of applications:
Apache
BEA WebLogic
Check Point VPN-1/FireWall-1
Citrix Metaframe Presentation Server
HP OpenView
Lotus/Domino Notes servers
IBM WebSphere
Oracle:
– 9i Application Server
– 10g Application Server
– E-Business Suite 11i
– Collaboration Suite
Microsoft:
– Application Center
– Commerce Server
– Exchange Sever
– Outlook Web Access
– Windows Terminal Services
– SharePoint Portal Server
– Internet Information Services (IIS)
– Live Communications Server
– SQL Server
– Microsoft Operations Manager
– Mobile Information Server
– Internet Security and Acceleration Server
– Visual Studio.NET
Siebel eBusiness Applications
PeopleSoft Enterprise
Macromedia ColdFusion
Trend Micro InterScan
Mercury Business Availability Center
SAP mySAP Business Suite
Netegrity SiteMinder
webMethods Enterprise Services Platform
Tivoli Access Manager
RSA SecureID
RealNetworks RealSystem Servers
Sun iPlanet Servers
...and many more
L7 Rate Shaping Module
Ensures optimal application performance by allocating bandwidth
for higher-priority applications, controls traffic spikes, and
prioritizes traffic based on any L4 or L7 parameter.
Application Security Manager Module
Award-winning web application firewall that secures web
applications and web services from application attacks and helps
organizations comply with PCI and other industry security standards.
Advanced Client Authentication Module
Allows BIG-IP LTM to provide top-level client authentication of
HTTP and other traffic types to LDAP, RADIUS, TACAS and other
centralized authentication devices.
Protocol Security Module
Enforces protocol checks for HTTP(s), FTP, and SMTP at BIG-IP system
speed to prevent attacks that use protocol manipulation techniques.
Ensuring Applications Are Always Secure, Fast, and Available
Advanced Routing Module
Adds support for the following protocols: BGP, BGP4, RIPv1, RIPv2,
RIPng, and IS-IS.
Fast Cache Module
Improves application and server performance by offloading
repetitive requests for content from the back-end infrastructure.
Protocol Security Module
Provides powerful security services for HTTP(s), SMTP, and
FTP at BIG-IP system speed without requiring the expertise
and management overhead of deploying a full-featured web
application firewall.
Message Security Module
Provides an extremely powerful and efficient tool for dealing with
the growing volume of unwanted email by leveraging reputation
data from Secure Computing’s TrustedSource™ multi-identity
reputation engine.
BIG-IP ® Local Traffic Manager™ is an Application Delivery Networking (ADN)
system that provides the most intelligent and adaptable solution to secure,
optimize, and deliver applications to help you effectively and competitively
run your business.
It’s the only system that gives you a set of unified application infrastructure
services that deliver total control, vision, and flexibility into application
security, performance and delivery. The result? Greater business agility
and successful outcomes for the lifeblood of your organization today—the
application itself.
Key Benefits:
• Accelerated Applications – Provides unmatched control to accelerate application performance
by up to 3x, ensuring that priority applications are served first and offloading expensive
server cycles.
BIG-IP Local Traffic Manager is available on seven appliances.
Additional software modules and hardware accelerators can be
added as needed.
BIG-IP Local Traffic Manager is also available on the modular
VIPRION system. This chassis and blade architecture enables simple
scalability as your Application Delivery Network grows.
6800 Series and 6400 Series
• Reduced Server and Bandwidth Cost – Triples server capacity through a rich set of infrastructure
optimization capabilities, and reduces bandwidth costs by up to 80 percent through intelligent
HTTP compression, bandwidth management, and more.
• Greater Network and Application Security – From DoS protection to cloaking to filtering out
application attacks, BIG-IP LTM adds critical security features that simply cannot be addressed
elsewhere in the network.
• Unmatched Application Intelligence and Control – The industry’s only solution that delivers
complete application fluency, enabling network-speed full payload inspection, and
programmable, event-based traffic management to understand and act upon application flows.
VIPRION Performance Blade 100
• Total Integration for All IP Applications – Provides a comprehensive solution that can integrate
with all applications, not just web-based protocols (HTTP/S). Provides organizations with a
centralized solution for all IP applications, including legacy and emerging applications like
VoIP—all in a single, unified system.
VIPRION Chassis
3600 Series
Inefficiencies, delays, and failures in application delivery can cost your
organization millions of dollars in terms of wasted budgets, damage to
company reputation, system and application downtime, legal liability, and
lost opportunities.
• Reliability – Delivers the industry’s most advanced system to ensure that applications are
always available.
Hardware Platforms
8800 Series and 8400 Series
Datasheet
BIG-IP Local Traffic Manager
BIG-IP Local Traffic Manager
• Industry-leading Performance – Delivers the industry’s fastest traffic management solution to
secure, deliver and optimize application performance. As a proven leader, BIG-IP LTM sets the
performance bar with best-in-market SSL TPS, bulk encryption, and the highest concurrent SSL
connections available today.
1600 Series
F5 Networks, Inc.
Corporate Headquarters
F5 Networks
Asia-Pacific
F5 Networks Ltd.
Europe/Middle-East/Africa
F5 Networks
Japan K.K.
401 Elliott Avenue West
Seattle, WA 98119
206-272-5555 Phone
888-88BIGIP Toll-free
206-272-5556 Fax
www.f5.com
[email protected]
+65-6533-6103 Phone
+65-6533-6106 Fax
[email protected]
+44 (0) 1932-582-000 Phone
+44 (0) 1932-582-001 Fax
[email protected]
+81-3-5114-3200 Phone
+81-3-5114-3201 Fax
[email protected]
Part No. DS-BIG-IP LTM 0708
System High Availability and Management
BIG-IP LTM improves system management through critical features
such as multi-boot, warm upgrades, and lights-out management. As a
high availability device, BIG-IP LTM also provides unmatched visibility
into the status of all processes running under the “HA table.”
SSL Acceleration Module
Dramatically improves the performance of servers while providing
security, speed, and traffic management during business-critical
online transactions.
IPv6 Gateway Module
Provides complete IP transformation and load balancing
capabilities between v4 and v6 networks. Makes user migration
and the pooling of mixed IPv4 and IPv6 host resources
manageable, cost-effective, and possible.
v9 Series
© 2008 F5 Networks, Inc. All rights reserved. F5, F5 Networks, the F5 logo, BIG-IP, FirePass, and iControl are trademarks or registered trademarks of F5 Networks, Inc. in the U.S. and in certain other countries.
• Easy to Manage, Better Visibility – An advanced GUI greatly simplifies product configuration,
offering granular visibility into traffic and box resources, as well as support for making rapid
changes across large configurations.
• Extends Collaboration Between Network and Application Groups – Through partitioned views
and application/protocol-specific monitors, BIG-IP LTM improves administrative functions and
provides more application-aware traffic management.
The Powerful TMOS Architecture: Complete Application Intelligence and Network Adaptability
Available
Fast
At the heart of BIG-IP LTM is a revolutionary architecture called TMOS™ that provides a unified system for optimal application delivery,
giving you total vision, flexibility, and control across all services. TMOS empowers BIG-IP LTM to intelligently adapt to the diverse and evolving
requirements of applications and networks.
BIG-IP LTM removes single points of failure and virtualizes the
network and applications by providing industry-leading L7
intelligence. This ensures that all applications are always on and
more scalable and easier to manage than ever before.
The unequalled intelligence of BIG-IP LTM provides a powerful
solution to help you improve your organization’s application
performance, increase the capacity of your existing infrastructure,
lower infrastructure costs, and accelerate your applications.
Application Health Knowledge
BIG-IP LTM provides sophisticated monitors to check device,
application, and content availability, including specialized monitors
for many applications (including various application servers, SQL,
SIP, LDAP, XML/SOAP, RTSP, SASP, SMB and many more) as well as
customized monitors to check content and simulate application
calls. In addition, BIG-IP LTM can effectively manage applications
on a shared server and allow applications to proactively report on
their health.
WAN Optimization and Application Acceleration
BIG-IP LTM provides a highly targeted, centralized, and efficient
means for reducing traffic volumes and minimizing the effect of
Internet latency and client connection bottlenecks on application
performance. Through capabilities such as Intelligent Compression,
BIG-IP LTM provides rich support for compressing a variety of file
types, including HTTP, XML, Javascript, J2EE applications, and many
others. This accelerates application performance as much as 3x
while reducing bandwidth utilization by up to 80 percent.
High Availability and Transaction Assurance
BIG-IP LTM delivers sub-second system failover and comprehensive
connection mirroring, resulting in a highly available solution
regardless of system, server, or application failure. BIG-IP LTM can
proactively inspect and respond to any server or application error.
Your organization can achieve superior reliability while reducing
the system load.
Ensure Critical Application Performance
Flexible L7 Rate Shaping capabilities help you to manage
bandwidth to ensure that priority applications are delivered
without delay. BIG-IP LTM also provides customized control to set
application-based bandwidth limits, allowable bandwidth spikes,
and even queuing relationships between applications.
TMOS Fast Application Proxy
TCP
Client Side
TCP
Server Side
TMOS Fast Application Proxy
TMOS enables BIG-IP LTM to efficiently isolate clients from the
server-side flows and independently maintain optimal performance
for each connecting device, translating communications between
systems for improved application performance. Any system or IP
application connected to BIG-IP LTM will work more efficiently.
TCP Express
TCP Express™, an industry first, is integrated into F5 TMOS
architecture. A state-of-the-art TCP stack, it offers a clientless
approach for WAN optimization, delivering up to 80 percent
performance gain for users and up to a four-fold improvement
in bandwidth efficiency. Your enterprise can achieve higher
performance, mitigate WAN-induced errors, and increase
bandwidth efficiency for your existing infrastructure.
iRules and Universal Inspection Engine
TMOS incorporates F5’s customizable iRules™ and Universal
Inspection Engine to provide unprecedented control over how to
handle application traffic at any moment within the application
transaction or flow. With complete payload inspection and
transformation capabilities, event-driven iRules, and session-aware
switching, BIG-IP LTM offers you the most intelligent control point
to address diverse application delivery issues at network speeds.
Comprehensive Load Balancing
BIG-IP LTM includes rich static and dynamic load balancing
methods, including Dynamic Ratio, Least Connections, and
Observed Load Balancing, which tracks dynamic performance
levels of servers in a group. This ensures that the best resources are
always selected for improved performance and scale.
Comprehensive Functionality to Deliver Secure, Fast, and Available Applications
BIG-IP LTM provides the cohesive set of functionality you need to ensure your applications are always secure, fast, and available. Invoked
through an easy-to-manage GUI and traffic profiles or through iRules, this functionality enables you to combine, target, and extend services
to improve the efficiency of each application deployment.
Available...
Fast...
Secure...
Comprehensive Load Balancing
SSL Accelerator™ (M)
Advanced Client Authentication™ (M)
Advanced Application Switching
Intelligent Compression™ (M)
Resource Cloaking
Session/Flow Switching
TCP Optimization
Cookie Encryption
Customized Health Monitoring
L7 Rate Shaping™ (M)
Selective Content Encryption
Intelligent Network Address Translation
Content Spooling/Buffering
Application Attack Filtering
Universal Persistence
Content Transformation
DoS Attack and SYN Flood Protection
Response Error Handling
Connection Acceleration
Firewall – Packet Filtering
IPv6 Gateway™ (M)
Intelligent Quality of Service
Packet Sanitization
Advanced Routing™ (M)
WAN Optimization
Application Security Manager™ (M)
Intelligent Port Mirroring
Fast Cache™ (M)
Protocol Security Module™ (M)
(M) = Available as an add-on module
Intelligent Application Switching
Because BIG-IP LTM has the unique ability to read all IP applications,
it can switch and persist on information unique to: a specific
vendor’s application server (BEA, Microsoft, IBM, Oracle, SUN, etc.);
XML data for Web services applications; or custom values indicative
to mobile/wireless applications. Your organization can achieve
greater reliability and scalability thanks to the ability of BIG-IP LTM
to switch, log, and persist in the payload or stream. You also have
extraordinary flexibility to solve your organization’s application
delivery challenges using the F5 iRules control language.
Comprehensive IPv6 Gateway
BIG-IP LTM can provide your organization with a seamless network
migration strategy to meet growing IPv6 requirements. Through
the IPv6 Gateway module, BIG-IP LTM provides complete IP
transformation and load balancing capabilities between IPv4 and
IPv6 networks, giving you a manageable and cost-effective means
to migrate users and pool mixed IPv4 and IPv6 host resources.
Increased Server Capacity and Improved Site Responsiveness
BIG-IP LTM provides extensive connection management as well
as TCP and content offloading capabilities that optimize server
performance and dramatically speed page load times. For example,
OneConnect™ connection pooling can increase server capacity by
up to 60 percent by aggregating millions of requests into hundreds
of server-side connections, ensuring requests are handled
efficiently by the back-end system.
Fast Cache – Up to a 9x Boost in Server Capacity
Intelligent caching functionality provides tremendous scalability
and cost savings by offloading repetitive traffic from web and
application servers. It’s also the only solution that offers multistore
caching to manage distinct cache repositories per application or
department, delivering precise and intelligent control for priority
applications.
Encryption Everywhere
As the leading solution for SSL acceleration, BIG-IP LTM provides
dramatic scalability for SSL processing with up to 2 Gbps of
sustained SSL throughput. By accelerating the encryption of both
bulk and setup, organizations can migrate 100 percent of their
communications to SSL using more secure ciphers with virtually no
application performance penalty or bottlenecks.
Content Transformation
BIG-IP LTM provides a comprehensive solution to offload many
burdensome or repetitious functions onto a centralized and highpowered network device. Beyond SSL, Compression, and many other
functions, BIG-IP LTM provides a complete content transformation
gateway to redirect, insert, or holistically transform application
content for effective and efficient application integration.
Users
Applications
Mobile Phone
PDA
Laptop
TMOS
Desktop
CRM
Database
Siebel
BEA
Legacy
.NET
SAP
Peoplesoft
IBM
ERP
SFA
Custom
Co-location
Secure
It’s not just about stopping attacks—it’s also about simultaneously serving legitimate users. BIG-IP LTM delivers the best of both worlds,
providing a suite of security services that play a significant role in bolstering network and application security. From adding powerful
network and protocol level security to filtering application attacks, BIG-IP LTM is deployed at a critical gateway to your most precious
resources—the applications that run your business.
Bolsters Application Security
• Resource Cloaking – BIG-IP LTM virtualizes and hides all
application, server error codes, and real URL references that may
provide hackers with clues about infrastructure, services and
their associated vulnerabilities.
• Customized Application Attack Filtering – Full inspection and
event-based policies deliver a greatly enhanced ability to search
for, detect, and apply numerous rules to block known L7 attacks.
BIG-IP LTM also applies secure application templates to block
unknown attacks and attacks targeted at the business logic of
the application. Additional layers of security protect against
hackers, viruses, and worms, while allowing continuous service
to legitimate traffic.
• Centralized Authentication – By acting as an authentication
proxy for various traffic types, BIG-IP LTM provides top-level
authentication for applications. This means you can push your
security perimeter one level further down in the network and
away from the applications, for greater protection of your web
and application tiers.
More Protection for Critical Content
• Selective Encryption – BIG-IP LTM delivers the industry’s most
selective encryption to holistically, partially, or conditionally
encrypt data. This fine-grain control enables secure and optimized
communications with a variety of different constituencies.
• Cookie Encryption – Cookies and other tokens transparently
distributed to legitimate users are encrypted. You gain superior
security for all stateful applications (e-commerce, CRP, ERP and
other business-critical applications) and a higher level of user
identity trust.
• Advanced Encryption Standard for SSL – BIG-IP LTM supports
higher-standard AES algorithms with the most secure SSL encryption
available on the market, at no additional processing cost.
• Content Protection – You can use BIG-IP LTM to prevent sensitive
documents or content from leaving your site.
Protects Against Heavy Attack Volumes
BIG-IP LTM combines a suite of security features to provide
comprehensive protection against DoS attacks, SYN floods, and
other network-based attacks. Features such as SYNCheck™ provide
comprehensive SYN flood protection for the servers that sit
behind the BIG-IP device. BIG-IP LTM acts as a security proxy that is
designed to protect the entire network. BIG-IP LTM uses Dynamic
Reaping, an adaptive method for reaping idle connections, to
filter out the heaviest attacks while simultaneously delivering
uninterrupted service for legitimate connections.
Insulation from Protocol Attacks
BIG-IP LTM provides Protocol Sanitization and a Full TCP
Termination point that independently manages client and serverside connections, protecting all back-end systems and applications
from malicious attacks.
Firewalling – Packet Filtering
BIG-IP LTM integrates a control point to define and enforce
L4‑based filtering rules (based on PCAP, similar to network
firewalls) to improve network protection.
The Powerful TMOS Architecture: Complete Application Intelligence and Network Adaptability
Available
Fast
At the heart of BIG-IP LTM is a revolutionary architecture called TMOS™ that provides a unified system for optimal application delivery,
giving you total vision, flexibility, and control across all services. TMOS empowers BIG-IP LTM to intelligently adapt to the diverse and evolving
requirements of applications and networks.
BIG-IP LTM removes single points of failure and virtualizes the
network and applications by providing industry-leading L7
intelligence. This ensures that all applications are always on and
more scalable and easier to manage than ever before.
The unequalled intelligence of BIG-IP LTM provides a powerful
solution to help you improve your organization’s application
performance, increase the capacity of your existing infrastructure,
lower infrastructure costs, and accelerate your applications.
Application Health Knowledge
BIG-IP LTM provides sophisticated monitors to check device,
application, and content availability, including specialized monitors
for many applications (including various application servers, SQL,
SIP, LDAP, XML/SOAP, RTSP, SASP, SMB and many more) as well as
customized monitors to check content and simulate application
calls. In addition, BIG-IP LTM can effectively manage applications
on a shared server and allow applications to proactively report on
their health.
WAN Optimization and Application Acceleration
BIG-IP LTM provides a highly targeted, centralized, and efficient
means for reducing traffic volumes and minimizing the effect of
Internet latency and client connection bottlenecks on application
performance. Through capabilities such as Intelligent Compression,
BIG-IP LTM provides rich support for compressing a variety of file
types, including HTTP, XML, Javascript, J2EE applications, and many
others. This accelerates application performance as much as 3x
while reducing bandwidth utilization by up to 80 percent.
High Availability and Transaction Assurance
BIG-IP LTM delivers sub-second system failover and comprehensive
connection mirroring, resulting in a highly available solution
regardless of system, server, or application failure. BIG-IP LTM can
proactively inspect and respond to any server or application error.
Your organization can achieve superior reliability while reducing
the system load.
Ensure Critical Application Performance
Flexible L7 Rate Shaping capabilities help you to manage
bandwidth to ensure that priority applications are delivered
without delay. BIG-IP LTM also provides customized control to set
application-based bandwidth limits, allowable bandwidth spikes,
and even queuing relationships between applications.
TMOS Fast Application Proxy
TCP
Client Side
TCP
Server Side
TMOS Fast Application Proxy
TMOS enables BIG-IP LTM to efficiently isolate clients from the
server-side flows and independently maintain optimal performance
for each connecting device, translating communications between
systems for improved application performance. Any system or IP
application connected to BIG-IP LTM will work more efficiently.
TCP Express
TCP Express™, an industry first, is integrated into F5 TMOS
architecture. A state-of-the-art TCP stack, it offers a clientless
approach for WAN optimization, delivering up to 80 percent
performance gain for users and up to a four-fold improvement
in bandwidth efficiency. Your enterprise can achieve higher
performance, mitigate WAN-induced errors, and increase
bandwidth efficiency for your existing infrastructure.
iRules and Universal Inspection Engine
TMOS incorporates F5’s customizable iRules™ and Universal
Inspection Engine to provide unprecedented control over how to
handle application traffic at any moment within the application
transaction or flow. With complete payload inspection and
transformation capabilities, event-driven iRules, and session-aware
switching, BIG-IP LTM offers you the most intelligent control point
to address diverse application delivery issues at network speeds.
Comprehensive Load Balancing
BIG-IP LTM includes rich static and dynamic load balancing
methods, including Dynamic Ratio, Least Connections, and
Observed Load Balancing, which tracks dynamic performance
levels of servers in a group. This ensures that the best resources are
always selected for improved performance and scale.
Comprehensive Functionality to Deliver Secure, Fast, and Available Applications
BIG-IP LTM provides the cohesive set of functionality you need to ensure your applications are always secure, fast, and available. Invoked
through an easy-to-manage GUI and traffic profiles or through iRules, this functionality enables you to combine, target, and extend services
to improve the efficiency of each application deployment.
Available...
Fast...
Secure...
Comprehensive Load Balancing
SSL Accelerator™ (M)
Advanced Client Authentication™ (M)
Advanced Application Switching
Intelligent Compression™ (M)
Resource Cloaking
Session/Flow Switching
TCP Optimization
Cookie Encryption
Customized Health Monitoring
L7 Rate Shaping™ (M)
Selective Content Encryption
Intelligent Network Address Translation
Content Spooling/Buffering
Application Attack Filtering
Universal Persistence
Content Transformation
DoS Attack and SYN Flood Protection
Response Error Handling
Connection Acceleration
Firewall – Packet Filtering
IPv6 Gateway™ (M)
Intelligent Quality of Service
Packet Sanitization
Advanced Routing™ (M)
WAN Optimization
Application Security Manager™ (M)
Intelligent Port Mirroring
Fast Cache™ (M)
Protocol Security Module™ (M)
(M) = Available as an add-on module
Intelligent Application Switching
Because BIG-IP LTM has the unique ability to read all IP applications,
it can switch and persist on information unique to: a specific
vendor’s application server (BEA, Microsoft, IBM, Oracle, SUN, etc.);
XML data for Web services applications; or custom values indicative
to mobile/wireless applications. Your organization can achieve
greater reliability and scalability thanks to the ability of BIG-IP LTM
to switch, log, and persist in the payload or stream. You also have
extraordinary flexibility to solve your organization’s application
delivery challenges using the F5 iRules control language.
Comprehensive IPv6 Gateway
BIG-IP LTM can provide your organization with a seamless network
migration strategy to meet growing IPv6 requirements. Through
the IPv6 Gateway module, BIG-IP LTM provides complete IP
transformation and load balancing capabilities between IPv4 and
IPv6 networks, giving you a manageable and cost-effective means
to migrate users and pool mixed IPv4 and IPv6 host resources.
Increased Server Capacity and Improved Site Responsiveness
BIG-IP LTM provides extensive connection management as well
as TCP and content offloading capabilities that optimize server
performance and dramatically speed page load times. For example,
OneConnect™ connection pooling can increase server capacity by
up to 60 percent by aggregating millions of requests into hundreds
of server-side connections, ensuring requests are handled
efficiently by the back-end system.
Fast Cache – Up to a 9x Boost in Server Capacity
Intelligent caching functionality provides tremendous scalability
and cost savings by offloading repetitive traffic from web and
application servers. It’s also the only solution that offers multistore
caching to manage distinct cache repositories per application or
department, delivering precise and intelligent control for priority
applications.
Encryption Everywhere
As the leading solution for SSL acceleration, BIG-IP LTM provides
dramatic scalability for SSL processing with up to 2 Gbps of
sustained SSL throughput. By accelerating the encryption of both
bulk and setup, organizations can migrate 100 percent of their
communications to SSL using more secure ciphers with virtually no
application performance penalty or bottlenecks.
Content Transformation
BIG-IP LTM provides a comprehensive solution to offload many
burdensome or repetitious functions onto a centralized and highpowered network device. Beyond SSL, Compression, and many other
functions, BIG-IP LTM provides a complete content transformation
gateway to redirect, insert, or holistically transform application
content for effective and efficient application integration.
Users
Applications
Mobile Phone
PDA
Laptop
TMOS
Desktop
CRM
Database
Siebel
BEA
Legacy
.NET
SAP
Peoplesoft
IBM
ERP
SFA
Custom
Co-location
Secure
It’s not just about stopping attacks—it’s also about simultaneously serving legitimate users. BIG-IP LTM delivers the best of both worlds,
providing a suite of security services that play a significant role in bolstering network and application security. From adding powerful
network and protocol level security to filtering application attacks, BIG-IP LTM is deployed at a critical gateway to your most precious
resources—the applications that run your business.
Bolsters Application Security
• Resource Cloaking – BIG-IP LTM virtualizes and hides all
application, server error codes, and real URL references that may
provide hackers with clues about infrastructure, services and
their associated vulnerabilities.
• Customized Application Attack Filtering – Full inspection and
event-based policies deliver a greatly enhanced ability to search
for, detect, and apply numerous rules to block known L7 attacks.
BIG-IP LTM also applies secure application templates to block
unknown attacks and attacks targeted at the business logic of
the application. Additional layers of security protect against
hackers, viruses, and worms, while allowing continuous service
to legitimate traffic.
• Centralized Authentication – By acting as an authentication
proxy for various traffic types, BIG-IP LTM provides top-level
authentication for applications. This means you can push your
security perimeter one level further down in the network and
away from the applications, for greater protection of your web
and application tiers.
More Protection for Critical Content
• Selective Encryption – BIG-IP LTM delivers the industry’s most
selective encryption to holistically, partially, or conditionally
encrypt data. This fine-grain control enables secure and optimized
communications with a variety of different constituencies.
• Cookie Encryption – Cookies and other tokens transparently
distributed to legitimate users are encrypted. You gain superior
security for all stateful applications (e-commerce, CRP, ERP and
other business-critical applications) and a higher level of user
identity trust.
• Advanced Encryption Standard for SSL – BIG-IP LTM supports
higher-standard AES algorithms with the most secure SSL encryption
available on the market, at no additional processing cost.
• Content Protection – You can use BIG-IP LTM to prevent sensitive
documents or content from leaving your site.
Protects Against Heavy Attack Volumes
BIG-IP LTM combines a suite of security features to provide
comprehensive protection against DoS attacks, SYN floods, and
other network-based attacks. Features such as SYNCheck™ provide
comprehensive SYN flood protection for the servers that sit
behind the BIG-IP device. BIG-IP LTM acts as a security proxy that is
designed to protect the entire network. BIG-IP LTM uses Dynamic
Reaping, an adaptive method for reaping idle connections, to
filter out the heaviest attacks while simultaneously delivering
uninterrupted service for legitimate connections.
Insulation from Protocol Attacks
BIG-IP LTM provides Protocol Sanitization and a Full TCP
Termination point that independently manages client and serverside connections, protecting all back-end systems and applications
from malicious attacks.
Firewalling – Packet Filtering
BIG-IP LTM integrates a control point to define and enforce
L4‑based filtering rules (based on PCAP, similar to network
firewalls) to improve network protection.
The Powerful TMOS Architecture: Complete Application Intelligence and Network Adaptability
Available
Fast
At the heart of BIG-IP LTM is a revolutionary architecture called TMOS™ that provides a unified system for optimal application delivery,
giving you total vision, flexibility, and control across all services. TMOS empowers BIG-IP LTM to intelligently adapt to the diverse and evolving
requirements of applications and networks.
BIG-IP LTM removes single points of failure and virtualizes the
network and applications by providing industry-leading L7
intelligence. This ensures that all applications are always on and
more scalable and easier to manage than ever before.
The unequalled intelligence of BIG-IP LTM provides a powerful
solution to help you improve your organization’s application
performance, increase the capacity of your existing infrastructure,
lower infrastructure costs, and accelerate your applications.
Application Health Knowledge
BIG-IP LTM provides sophisticated monitors to check device,
application, and content availability, including specialized monitors
for many applications (including various application servers, SQL,
SIP, LDAP, XML/SOAP, RTSP, SASP, SMB and many more) as well as
customized monitors to check content and simulate application
calls. In addition, BIG-IP LTM can effectively manage applications
on a shared server and allow applications to proactively report on
their health.
WAN Optimization and Application Acceleration
BIG-IP LTM provides a highly targeted, centralized, and efficient
means for reducing traffic volumes and minimizing the effect of
Internet latency and client connection bottlenecks on application
performance. Through capabilities such as Intelligent Compression,
BIG-IP LTM provides rich support for compressing a variety of file
types, including HTTP, XML, Javascript, J2EE applications, and many
others. This accelerates application performance as much as 3x
while reducing bandwidth utilization by up to 80 percent.
High Availability and Transaction Assurance
BIG-IP LTM delivers sub-second system failover and comprehensive
connection mirroring, resulting in a highly available solution
regardless of system, server, or application failure. BIG-IP LTM can
proactively inspect and respond to any server or application error.
Your organization can achieve superior reliability while reducing
the system load.
Ensure Critical Application Performance
Flexible L7 Rate Shaping capabilities help you to manage
bandwidth to ensure that priority applications are delivered
without delay. BIG-IP LTM also provides customized control to set
application-based bandwidth limits, allowable bandwidth spikes,
and even queuing relationships between applications.
TMOS Fast Application Proxy
TCP
Client Side
TCP
Server Side
TMOS Fast Application Proxy
TMOS enables BIG-IP LTM to efficiently isolate clients from the
server-side flows and independently maintain optimal performance
for each connecting device, translating communications between
systems for improved application performance. Any system or IP
application connected to BIG-IP LTM will work more efficiently.
TCP Express
TCP Express™, an industry first, is integrated into F5 TMOS
architecture. A state-of-the-art TCP stack, it offers a clientless
approach for WAN optimization, delivering up to 80 percent
performance gain for users and up to a four-fold improvement
in bandwidth efficiency. Your enterprise can achieve higher
performance, mitigate WAN-induced errors, and increase
bandwidth efficiency for your existing infrastructure.
iRules and Universal Inspection Engine
TMOS incorporates F5’s customizable iRules™ and Universal
Inspection Engine to provide unprecedented control over how to
handle application traffic at any moment within the application
transaction or flow. With complete payload inspection and
transformation capabilities, event-driven iRules, and session-aware
switching, BIG-IP LTM offers you the most intelligent control point
to address diverse application delivery issues at network speeds.
Comprehensive Load Balancing
BIG-IP LTM includes rich static and dynamic load balancing
methods, including Dynamic Ratio, Least Connections, and
Observed Load Balancing, which tracks dynamic performance
levels of servers in a group. This ensures that the best resources are
always selected for improved performance and scale.
Comprehensive Functionality to Deliver Secure, Fast, and Available Applications
BIG-IP LTM provides the cohesive set of functionality you need to ensure your applications are always secure, fast, and available. Invoked
through an easy-to-manage GUI and traffic profiles or through iRules, this functionality enables you to combine, target, and extend services
to improve the efficiency of each application deployment.
Available...
Fast...
Secure...
Comprehensive Load Balancing
SSL Accelerator™ (M)
Advanced Client Authentication™ (M)
Advanced Application Switching
Intelligent Compression™ (M)
Resource Cloaking
Session/Flow Switching
TCP Optimization
Cookie Encryption
Customized Health Monitoring
L7 Rate Shaping™ (M)
Selective Content Encryption
Intelligent Network Address Translation
Content Spooling/Buffering
Application Attack Filtering
Universal Persistence
Content Transformation
DoS Attack and SYN Flood Protection
Response Error Handling
Connection Acceleration
Firewall – Packet Filtering
IPv6 Gateway™ (M)
Intelligent Quality of Service
Packet Sanitization
Advanced Routing™ (M)
WAN Optimization
Application Security Manager™ (M)
Intelligent Port Mirroring
Fast Cache™ (M)
Protocol Security Module™ (M)
(M) = Available as an add-on module
Intelligent Application Switching
Because BIG-IP LTM has the unique ability to read all IP applications,
it can switch and persist on information unique to: a specific
vendor’s application server (BEA, Microsoft, IBM, Oracle, SUN, etc.);
XML data for Web services applications; or custom values indicative
to mobile/wireless applications. Your organization can achieve
greater reliability and scalability thanks to the ability of BIG-IP LTM
to switch, log, and persist in the payload or stream. You also have
extraordinary flexibility to solve your organization’s application
delivery challenges using the F5 iRules control language.
Comprehensive IPv6 Gateway
BIG-IP LTM can provide your organization with a seamless network
migration strategy to meet growing IPv6 requirements. Through
the IPv6 Gateway module, BIG-IP LTM provides complete IP
transformation and load balancing capabilities between IPv4 and
IPv6 networks, giving you a manageable and cost-effective means
to migrate users and pool mixed IPv4 and IPv6 host resources.
Increased Server Capacity and Improved Site Responsiveness
BIG-IP LTM provides extensive connection management as well
as TCP and content offloading capabilities that optimize server
performance and dramatically speed page load times. For example,
OneConnect™ connection pooling can increase server capacity by
up to 60 percent by aggregating millions of requests into hundreds
of server-side connections, ensuring requests are handled
efficiently by the back-end system.
Fast Cache – Up to a 9x Boost in Server Capacity
Intelligent caching functionality provides tremendous scalability
and cost savings by offloading repetitive traffic from web and
application servers. It’s also the only solution that offers multistore
caching to manage distinct cache repositories per application or
department, delivering precise and intelligent control for priority
applications.
Encryption Everywhere
As the leading solution for SSL acceleration, BIG-IP LTM provides
dramatic scalability for SSL processing with up to 2 Gbps of
sustained SSL throughput. By accelerating the encryption of both
bulk and setup, organizations can migrate 100 percent of their
communications to SSL using more secure ciphers with virtually no
application performance penalty or bottlenecks.
Content Transformation
BIG-IP LTM provides a comprehensive solution to offload many
burdensome or repetitious functions onto a centralized and highpowered network device. Beyond SSL, Compression, and many other
functions, BIG-IP LTM provides a complete content transformation
gateway to redirect, insert, or holistically transform application
content for effective and efficient application integration.
Users
Applications
Mobile Phone
PDA
Laptop
TMOS
Desktop
CRM
Database
Siebel
BEA
Legacy
.NET
SAP
Peoplesoft
IBM
ERP
SFA
Custom
Co-location
Secure
It’s not just about stopping attacks—it’s also about simultaneously serving legitimate users. BIG-IP LTM delivers the best of both worlds,
providing a suite of security services that play a significant role in bolstering network and application security. From adding powerful
network and protocol level security to filtering application attacks, BIG-IP LTM is deployed at a critical gateway to your most precious
resources—the applications that run your business.
Bolsters Application Security
• Resource Cloaking – BIG-IP LTM virtualizes and hides all
application, server error codes, and real URL references that may
provide hackers with clues about infrastructure, services and
their associated vulnerabilities.
• Customized Application Attack Filtering – Full inspection and
event-based policies deliver a greatly enhanced ability to search
for, detect, and apply numerous rules to block known L7 attacks.
BIG-IP LTM also applies secure application templates to block
unknown attacks and attacks targeted at the business logic of
the application. Additional layers of security protect against
hackers, viruses, and worms, while allowing continuous service
to legitimate traffic.
• Centralized Authentication – By acting as an authentication
proxy for various traffic types, BIG-IP LTM provides top-level
authentication for applications. This means you can push your
security perimeter one level further down in the network and
away from the applications, for greater protection of your web
and application tiers.
More Protection for Critical Content
• Selective Encryption – BIG-IP LTM delivers the industry’s most
selective encryption to holistically, partially, or conditionally
encrypt data. This fine-grain control enables secure and optimized
communications with a variety of different constituencies.
• Cookie Encryption – Cookies and other tokens transparently
distributed to legitimate users are encrypted. You gain superior
security for all stateful applications (e-commerce, CRP, ERP and
other business-critical applications) and a higher level of user
identity trust.
• Advanced Encryption Standard for SSL – BIG-IP LTM supports
higher-standard AES algorithms with the most secure SSL encryption
available on the market, at no additional processing cost.
• Content Protection – You can use BIG-IP LTM to prevent sensitive
documents or content from leaving your site.
Protects Against Heavy Attack Volumes
BIG-IP LTM combines a suite of security features to provide
comprehensive protection against DoS attacks, SYN floods, and
other network-based attacks. Features such as SYNCheck™ provide
comprehensive SYN flood protection for the servers that sit
behind the BIG-IP device. BIG-IP LTM acts as a security proxy that is
designed to protect the entire network. BIG-IP LTM uses Dynamic
Reaping, an adaptive method for reaping idle connections, to
filter out the heaviest attacks while simultaneously delivering
uninterrupted service for legitimate connections.
Insulation from Protocol Attacks
BIG-IP LTM provides Protocol Sanitization and a Full TCP
Termination point that independently manages client and serverside connections, protecting all back-end systems and applications
from malicious attacks.
Firewalling – Packet Filtering
BIG-IP LTM integrates a control point to define and enforce
L4‑based filtering rules (based on PCAP, similar to network
firewalls) to improve network protection.
BIG-IP
®
BIG-IP LTM Performance and Reliability
iControl – Creating the Application Aware Network
Available Add-On Modules
Ground-Breaking Performance
BIG-IP LTM delivers the industry’s fastest application traffic
management solution. Its specially designed architecture merges
a high performance switching fabric with individual, best-inclass hardware optimizers for SSL and L4 to completely offload
system CPU. BIG-IP LTM delivers real-world performance across all
functions and provides deep packet inspection at network speeds.
The F5 iControl™ API and SDK help automate communications
between third-party applications and BIG-IP LTM, removing the
need for manual intervention. iControl supports a true publish/
subscribe model. This model reduces network overhead and
improves the performance of applications that integrate with
BIG-IP LTM through the iControl interface. For the majority of
applications, this can reduce network bandwidth and processing
time on both the client and the server.
Intelligent Compression Module
Condenses HTTP traffic using industry-standard gzip and DEFLATE
compression algorithms, reduces bandwidth consumption, and speeds
end-user download times over slower/low bandwidth connections.
Advanced GUI and Simplified Management
An advanced GUI delivers easy product configuration that lowers
setup and ongoing maintenance costs.
Networking
BIG-IP LTM supports basic layer 2 and layer 3 protocols:
Supports STP, MSTP, RSTP
Link aggregation
VLAN tagging
QoS/ToS
Third party MIB support: all default Net-SNMP
BIG-IP – Scale, Secure, and Optimize
Profile-Based Configuration
Profile objects enable you to create traffic behavior templates
that can be applied to different resources, reducing repetition and
providing a centralized approach to changing settings.
Better Visibility
BIG-IP LTM provides detailed system instrumentation on traffic
statistics (globally and per object) to help you better monitor all
activities and resources.
Rich User Interface
Delivered over a secure, SSL browser-based interface, the advanced
GUI includes online help, searching and sorting, in-line creation
and much more, dramatically reducing the time it takes to set up
and maintain large configurations.
More Functions, More User Types
Administrative domains allow you to design customized partitions
and assign varying degrees of administrative rights and views of
BIG-IP LTM functions. Adminstrators can design customized views
by service, application owners, or other segmentation scheme,
providing unprecedented management scale and organizational
efficiency.
BIG-IP LTM intelligently manages hundreds of applications:
Apache
BEA WebLogic
Check Point VPN-1/FireWall-1
Citrix Metaframe Presentation Server
HP OpenView
Lotus/Domino Notes servers
IBM WebSphere
Oracle:
– 9i Application Server
– 10g Application Server
– E-Business Suite 11i
– Collaboration Suite
Microsoft:
– Application Center
– Commerce Server
– Exchange Sever
– Outlook Web Access
– Windows Terminal Services
– SharePoint Portal Server
– Internet Information Services (IIS)
– Live Communications Server
– SQL Server
– Microsoft Operations Manager
– Mobile Information Server
– Internet Security and Acceleration Server
– Visual Studio.NET
Siebel eBusiness Applications
PeopleSoft Enterprise
Macromedia ColdFusion
Trend Micro InterScan
Mercury Business Availability Center
SAP mySAP Business Suite
Netegrity SiteMinder
webMethods Enterprise Services Platform
Tivoli Access Manager
RSA SecureID
RealNetworks RealSystem Servers
Sun iPlanet Servers
...and many more
L7 Rate Shaping Module
Ensures optimal application performance by allocating bandwidth
for higher-priority applications, controls traffic spikes, and
prioritizes traffic based on any L4 or L7 parameter.
Application Security Manager Module
Award-winning web application firewall that secures web
applications and web services from application attacks and helps
organizations comply with PCI and other industry security standards.
Advanced Client Authentication Module
Allows BIG-IP LTM to provide top-level client authentication of
HTTP and other traffic types to LDAP, RADIUS, TACAS and other
centralized authentication devices.
Protocol Security Module
Enforces protocol checks for HTTP(s), FTP, and SMTP at BIG-IP system
speed to prevent attacks that use protocol manipulation techniques.
Ensuring Applications Are Always Secure, Fast, and Available
Advanced Routing Module
Adds support for the following protocols: BGP, BGP4, RIPv1, RIPv2,
RIPng, and IS-IS.
Fast Cache Module
Improves application and server performance by offloading
repetitive requests for content from the back-end infrastructure.
Protocol Security Module
Provides powerful security services for HTTP(s), SMTP, and
FTP at BIG-IP system speed without requiring the expertise
and management overhead of deploying a full-featured web
application firewall.
Message Security Module
Provides an extremely powerful and efficient tool for dealing with
the growing volume of unwanted email by leveraging reputation
data from Secure Computing’s TrustedSource™ multi-identity
reputation engine.
BIG-IP ® Local Traffic Manager™ is an Application Delivery Networking (ADN)
system that provides the most intelligent and adaptable solution to secure,
optimize, and deliver applications to help you effectively and competitively
run your business.
It’s the only system that gives you a set of unified application infrastructure
services that deliver total control, vision, and flexibility into application
security, performance and delivery. The result? Greater business agility
and successful outcomes for the lifeblood of your organization today—the
application itself.
Key Benefits:
• Accelerated Applications – Provides unmatched control to accelerate application performance
by up to 3x, ensuring that priority applications are served first and offloading expensive
server cycles.
BIG-IP Local Traffic Manager is available on seven appliances.
Additional software modules and hardware accelerators can be
added as needed.
BIG-IP Local Traffic Manager is also available on the modular
VIPRION system. This chassis and blade architecture enables simple
scalability as your Application Delivery Network grows.
6800 Series and 6400 Series
• Reduced Server and Bandwidth Cost – Triples server capacity through a rich set of infrastructure
optimization capabilities, and reduces bandwidth costs by up to 80 percent through intelligent
HTTP compression, bandwidth management, and more.
• Greater Network and Application Security – From DoS protection to cloaking to filtering out
application attacks, BIG-IP LTM adds critical security features that simply cannot be addressed
elsewhere in the network.
• Unmatched Application Intelligence and Control – The industry’s only solution that delivers
complete application fluency, enabling network-speed full payload inspection, and
programmable, event-based traffic management to understand and act upon application flows.
VIPRION Performance Blade 100
• Total Integration for All IP Applications – Provides a comprehensive solution that can integrate
with all applications, not just web-based protocols (HTTP/S). Provides organizations with a
centralized solution for all IP applications, including legacy and emerging applications like
VoIP—all in a single, unified system.
VIPRION Chassis
3600 Series
Inefficiencies, delays, and failures in application delivery can cost your
organization millions of dollars in terms of wasted budgets, damage to
company reputation, system and application downtime, legal liability, and
lost opportunities.
• Reliability – Delivers the industry’s most advanced system to ensure that applications are
always available.
Hardware Platforms
8800 Series and 8400 Series
Datasheet
BIG-IP Local Traffic Manager
BIG-IP Local Traffic Manager
• Industry-leading Performance – Delivers the industry’s fastest traffic management solution to
secure, deliver and optimize application performance. As a proven leader, BIG-IP LTM sets the
performance bar with best-in-market SSL TPS, bulk encryption, and the highest concurrent SSL
connections available today.
1600 Series
F5 Networks, Inc.
Corporate Headquarters
F5 Networks
Asia-Pacific
F5 Networks Ltd.
Europe/Middle-East/Africa
F5 Networks
Japan K.K.
401 Elliott Avenue West
Seattle, WA 98119
206-272-5555 Phone
888-88BIGIP Toll-free
206-272-5556 Fax
www.f5.com
[email protected]
+65-6533-6103 Phone
+65-6533-6106 Fax
[email protected]
+44 (0) 1932-582-000 Phone
+44 (0) 1932-582-001 Fax
[email protected]
+81-3-5114-3200 Phone
+81-3-5114-3201 Fax
[email protected]
Part No. DS-BIG-IP LTM 0708
System High Availability and Management
BIG-IP LTM improves system management through critical features
such as multi-boot, warm upgrades, and lights-out management. As a
high availability device, BIG-IP LTM also provides unmatched visibility
into the status of all processes running under the “HA table.”
SSL Acceleration Module
Dramatically improves the performance of servers while providing
security, speed, and traffic management during business-critical
online transactions.
IPv6 Gateway Module
Provides complete IP transformation and load balancing
capabilities between v4 and v6 networks. Makes user migration
and the pooling of mixed IPv4 and IPv6 host resources
manageable, cost-effective, and possible.
v9 Series
© 2008 F5 Networks, Inc. All rights reserved. F5, F5 Networks, the F5 logo, BIG-IP, FirePass, and iControl are trademarks or registered trademarks of F5 Networks, Inc. in the U.S. and in certain other countries.
• Easy to Manage, Better Visibility – An advanced GUI greatly simplifies product configuration,
offering granular visibility into traffic and box resources, as well as support for making rapid
changes across large configurations.
• Extends Collaboration Between Network and Application Groups – Through partitioned views
and application/protocol-specific monitors, BIG-IP LTM improves administrative functions and
provides more application-aware traffic management.
BIG-IP
®
BIG-IP LTM Performance and Reliability
iControl – Creating the Application Aware Network
Available Add-On Modules
Ground-Breaking Performance
BIG-IP LTM delivers the industry’s fastest application traffic
management solution. Its specially designed architecture merges
a high performance switching fabric with individual, best-inclass hardware optimizers for SSL and L4 to completely offload
system CPU. BIG-IP LTM delivers real-world performance across all
functions and provides deep packet inspection at network speeds.
The F5 iControl™ API and SDK help automate communications
between third-party applications and BIG-IP LTM, removing the
need for manual intervention. iControl supports a true publish/
subscribe model. This model reduces network overhead and
improves the performance of applications that integrate with
BIG-IP LTM through the iControl interface. For the majority of
applications, this can reduce network bandwidth and processing
time on both the client and the server.
Intelligent Compression Module
Condenses HTTP traffic using industry-standard gzip and DEFLATE
compression algorithms, reduces bandwidth consumption, and speeds
end-user download times over slower/low bandwidth connections.
Advanced GUI and Simplified Management
An advanced GUI delivers easy product configuration that lowers
setup and ongoing maintenance costs.
Networking
BIG-IP LTM supports basic layer 2 and layer 3 protocols:
Supports STP, MSTP, RSTP
Link aggregation
VLAN tagging
QoS/ToS
Third party MIB support: all default Net-SNMP
BIG-IP – Scale, Secure, and Optimize
Profile-Based Configuration
Profile objects enable you to create traffic behavior templates
that can be applied to different resources, reducing repetition and
providing a centralized approach to changing settings.
Better Visibility
BIG-IP LTM provides detailed system instrumentation on traffic
statistics (globally and per object) to help you better monitor all
activities and resources.
Rich User Interface
Delivered over a secure, SSL browser-based interface, the advanced
GUI includes online help, searching and sorting, in-line creation
and much more, dramatically reducing the time it takes to set up
and maintain large configurations.
More Functions, More User Types
Administrative domains allow you to design customized partitions
and assign varying degrees of administrative rights and views of
BIG-IP LTM functions. Adminstrators can design customized views
by service, application owners, or other segmentation scheme,
providing unprecedented management scale and organizational
efficiency.
BIG-IP LTM intelligently manages hundreds of applications:
Apache
BEA WebLogic
Check Point VPN-1/FireWall-1
Citrix Metaframe Presentation Server
HP OpenView
Lotus/Domino Notes servers
IBM WebSphere
Oracle:
– 9i Application Server
– 10g Application Server
– E-Business Suite 11i
– Collaboration Suite
Microsoft:
– Application Center
– Commerce Server
– Exchange Sever
– Outlook Web Access
– Windows Terminal Services
– SharePoint Portal Server
– Internet Information Services (IIS)
– Live Communications Server
– SQL Server
– Microsoft Operations Manager
– Mobile Information Server
– Internet Security and Acceleration Server
– Visual Studio.NET
Siebel eBusiness Applications
PeopleSoft Enterprise
Macromedia ColdFusion
Trend Micro InterScan
Mercury Business Availability Center
SAP mySAP Business Suite
Netegrity SiteMinder
webMethods Enterprise Services Platform
Tivoli Access Manager
RSA SecureID
RealNetworks RealSystem Servers
Sun iPlanet Servers
...and many more
L7 Rate Shaping Module
Ensures optimal application performance by allocating bandwidth
for higher-priority applications, controls traffic spikes, and
prioritizes traffic based on any L4 or L7 parameter.
Application Security Manager Module
Award-winning web application firewall that secures web
applications and web services from application attacks and helps
organizations comply with PCI and other industry security standards.
Advanced Client Authentication Module
Allows BIG-IP LTM to provide top-level client authentication of
HTTP and other traffic types to LDAP, RADIUS, TACAS and other
centralized authentication devices.
Protocol Security Module
Enforces protocol checks for HTTP(s), FTP, and SMTP at BIG-IP system
speed to prevent attacks that use protocol manipulation techniques.
Ensuring Applications Are Always Secure, Fast, and Available
Advanced Routing Module
Adds support for the following protocols: BGP, BGP4, RIPv1, RIPv2,
RIPng, and IS-IS.
Fast Cache Module
Improves application and server performance by offloading
repetitive requests for content from the back-end infrastructure.
Protocol Security Module
Provides powerful security services for HTTP(s), SMTP, and
FTP at BIG-IP system speed without requiring the expertise
and management overhead of deploying a full-featured web
application firewall.
Message Security Module
Provides an extremely powerful and efficient tool for dealing with
the growing volume of unwanted email by leveraging reputation
data from Secure Computing’s TrustedSource™ multi-identity
reputation engine.
BIG-IP ® Local Traffic Manager™ is an Application Delivery Networking (ADN)
system that provides the most intelligent and adaptable solution to secure,
optimize, and deliver applications to help you effectively and competitively
run your business.
It’s the only system that gives you a set of unified application infrastructure
services that deliver total control, vision, and flexibility into application
security, performance and delivery. The result? Greater business agility
and successful outcomes for the lifeblood of your organization today—the
application itself.
Key Benefits:
• Accelerated Applications – Provides unmatched control to accelerate application performance
by up to 3x, ensuring that priority applications are served first and offloading expensive
server cycles.
BIG-IP Local Traffic Manager is available on seven appliances.
Additional software modules and hardware accelerators can be
added as needed.
BIG-IP Local Traffic Manager is also available on the modular
VIPRION system. This chassis and blade architecture enables simple
scalability as your Application Delivery Network grows.
6800 Series and 6400 Series
• Reduced Server and Bandwidth Cost – Triples server capacity through a rich set of infrastructure
optimization capabilities, and reduces bandwidth costs by up to 80 percent through intelligent
HTTP compression, bandwidth management, and more.
• Greater Network and Application Security – From DoS protection to cloaking to filtering out
application attacks, BIG-IP LTM adds critical security features that simply cannot be addressed
elsewhere in the network.
• Unmatched Application Intelligence and Control – The industry’s only solution that delivers
complete application fluency, enabling network-speed full payload inspection, and
programmable, event-based traffic management to understand and act upon application flows.
VIPRION Performance Blade 100
• Total Integration for All IP Applications – Provides a comprehensive solution that can integrate
with all applications, not just web-based protocols (HTTP/S). Provides organizations with a
centralized solution for all IP applications, including legacy and emerging applications like
VoIP—all in a single, unified system.
VIPRION Chassis
3600 Series
Inefficiencies, delays, and failures in application delivery can cost your
organization millions of dollars in terms of wasted budgets, damage to
company reputation, system and application downtime, legal liability, and
lost opportunities.
• Reliability – Delivers the industry’s most advanced system to ensure that applications are
always available.
Hardware Platforms
8800 Series and 8400 Series
Datasheet
BIG-IP Local Traffic Manager
BIG-IP Local Traffic Manager
• Industry-leading Performance – Delivers the industry’s fastest traffic management solution to
secure, deliver and optimize application performance. As a proven leader, BIG-IP LTM sets the
performance bar with best-in-market SSL TPS, bulk encryption, and the highest concurrent SSL
connections available today.
1600 Series
F5 Networks, Inc.
Corporate Headquarters
F5 Networks
Asia-Pacific
F5 Networks Ltd.
Europe/Middle-East/Africa
F5 Networks
Japan K.K.
401 Elliott Avenue West
Seattle, WA 98119
206-272-5555 Phone
888-88BIGIP Toll-free
206-272-5556 Fax
www.f5.com
[email protected]
+65-6533-6103 Phone
+65-6533-6106 Fax
[email protected]
+44 (0) 1932-582-000 Phone
+44 (0) 1932-582-001 Fax
[email protected]
+81-3-5114-3200 Phone
+81-3-5114-3201 Fax
[email protected]
Part No. DS-BIG-IP LTM 0708
System High Availability and Management
BIG-IP LTM improves system management through critical features
such as multi-boot, warm upgrades, and lights-out management. As a
high availability device, BIG-IP LTM also provides unmatched visibility
into the status of all processes running under the “HA table.”
SSL Acceleration Module
Dramatically improves the performance of servers while providing
security, speed, and traffic management during business-critical
online transactions.
IPv6 Gateway Module
Provides complete IP transformation and load balancing
capabilities between v4 and v6 networks. Makes user migration
and the pooling of mixed IPv4 and IPv6 host resources
manageable, cost-effective, and possible.
v9 Series
© 2008 F5 Networks, Inc. All rights reserved. F5, F5 Networks, the F5 logo, BIG-IP, FirePass, and iControl are trademarks or registered trademarks of F5 Networks, Inc. in the U.S. and in certain other countries.
• Easy to Manage, Better Visibility – An advanced GUI greatly simplifies product configuration,
offering granular visibility into traffic and box resources, as well as support for making rapid
changes across large configurations.
• Extends Collaboration Between Network and Application Groups – Through partitioned views
and application/protocol-specific monitors, BIG-IP LTM improves administrative functions and
provides more application-aware traffic management.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
