Quick Installation Guide

TK-407K

Deutsch .....................................................................................................

1. Bevor Sie anfangen ...........................................................................

2. Installation .........................................................................................

3. Bedienung .........................................................................................

1

1

2

4

Troubleshooting ........................................................................................

5

Version 01.05.2006

1. Bevor Sie anfangen

Packungsinhalt

TK-407

Anleitung zur Schnellinstallation

Programm-CD

4 Sätze USB-KVM-Kabel

Systemanforderungen

USB-A Tastatur

USB-A Maus

VGA- oder SVGA-kompatibler Monitor

Windows 98SE/ME/2000/XP/2003, Linux oder Mac OS

Anwendung

PC 3 PC 1 PC 2 PC 4

LCD Monitor

USB

Keyboard

USB

Mouse

1

Deutsch

4-Port USB

KVM Switch

(TK-407K)

2. Installation

1. Schalten Sie beide Computer und die Peripheriegeräte aus und trennen Sie alle

Stromversorgungskabel ab.

2. Verbinden Sie die gemeinsam genutzte Tastatur, den Monitor und die Maus mit dem Konsolen-Port des KVM-Umschalters.

3. Verbinden Sie Ihren PC über die mitgelieferten KVM-Kabel mit

Ihrem KVM-Umschalter.

2

Deutsch

4. Schalten Sie den ersten Computer

EIN und warten Sie, bis der

Systemstart abgeschlossen ist.

PC 1

5. Drücken Sie die Taste auf der

Vorderseite des KVM-Umschalters, um zum zweiten Computer zu wechseln. (Optional)

6. Schalten Sie den zweiten

Computer

EIN und warten Sie, bis der Systemstart abgeschlossen ist.

PC 2

Ihre Installation ist beendet!

3

Deutsch

3. Bedienung

Hinweis: Zum Umschalten zwischen den PCs können Sie die Tasten auf der

Vorderseite des KVM-Umschalters, eine Tastenkombination auf der Tastatur oder das Umschaltprogramm (nur mit Windows) verwenden. Weitere

Informationen zum Umschaltprogramm finden Sie in der Bedienungsanleitung auf der CD.

Tasten auf der Vorderseite des Umschalters

Drücken Sie auf die entsprechende

Taste auf der Vorderseite, um den gewünschten PC auszuwählen.

Tastenkombination

Sobald Sie die ScrLk-Taste (ROLLEN-Taste) gedrückt haben, müssen Sie die

Taste innerhalb von 2 Sekunden nochmals drücken. Wenn Sie innerhalb von 2

Sekunden keine Taste drücken, wird die Tastenkombination nicht wirksam.

Allgemeine Tastenkombination

Befehl

PC auswählen

Tastenkombination

ScrLk

+

ScrLk

Beschreibung

Wählt den aktiven PC-Kanal aus:

PC-Kanal 1 oder PC-Kanal 2.

4

Deutsch

Troubleshooting

Q1: Where is the power supply? I did not find one in the box.

A1:

The TK-407K does not require a power supply. It draws power from your computer's

USB connection. As long as your KVM switch is connected to the USB port, it will receive the necessary power to function.

Q2: I have the KVM switch connected properly, but my keyboard and mouse don’t work.

A2:

First, make sure your computer’s USB port is working properly by testing it with your other USB devices. Second, once you confirm that the computer’s USB port is functional, please reboot all computers, and try to use the KVM switch again. Third, if your computer is running Windows 98SE, you may need to download and install the USB hot fix. Please go to this link for download and installation instructions: http://support.microsoft.com/kb/q240075.

Once the hot fix is installed, follow the installation instructions in Section 2.

Q3: Can I connect and disconnect the USB cables while the computers are turned on?

A3:

Yes, you can connect or disconnect the USB cables while the computers are turned on because the USB interface is Plug-and-Play and Hot-Pluggable.

Q4: Will the KVM switch remember the keyboard settings between computers?

A4:

Yes, the KVM switch will remember the keyboard settings when switching between your computers. (i.e.: Cap lock, Num key, etc.)

Q5: How do I switch from one computer to another with the KVM switch?

A5:

PC User: Push Buttons, Hot-Key Commands or Client Switching Software

Mac User: Push Buttons

Linux User: Universal Hot-Key Commands

If you still encounter problems or have any questions regarding the TK-407K, please contact

TRENDnet’s Technical Support Department.
