2014

RENOwNED

for

Designers

SmeG

Guido Canali

Guido Canali is undoubtedly one of the most important Italian architects of the last decades.

The work of Guido Canali is a synthesis between past and present; useful, practical, beautiful and modern spaces are the result of the combination of aspects of historical works of art with contemporary needs.

Guido Canali has received numerous awards for his work, including the Constructa Preis of

Hanover (1992) and the Compasso D’oro (2004) of Milan.

He was the first architect to collaborate with Smeg.

Mario Bellini

Mario Bellini began his career as a product and furniture designer, and has 25 of his designs on permanent display at the Moma (Museum of Modern Art) in New York.

He has worked as an architect all over the world - in Japan, Europe, USA, Australia, and Saudi

Arabia and has been awarded many major international design and architecture prizes.

In December 2004 he was honoured with the “Golden Medal” by Italian Republic President for his architectural and design work in the world.

His collaboration with Smeg has given life to a number of distinctive products.

Renzo Piano

Renzo Piano celebrates structure in a perfect union of technology and art. He has a strong interest in “elegantly expressed structure”, evident in all of his works.

The work of Renzo Piano is “reinventing architecture” in projects around the world. He is famous for designing museums, but he has also worked on offices, airport terminals, bridges, ocean liners, libraries, football stadia and automobiles!

Renzo Piano was made a UNESCO Goodwill Ambassador for Architecture, and was awarded the Pritzker Architecture prize in 1998.

His collaboration with Smeg began in the 1990’s.

Marc Newson

Marc Newson was born in Sydney in 1963.

He spent his childhood travelling in Europe and Asia before studying jewellery and sculpture atSydney College of the Arts.

After the success, in 1984, of the ‘Lockheed Lounge’, an icon of international design, Newson went to Japan and began to design individual furniture pieces.

During the mid-to-late 1990s, Newson designed a series of interiors, and in 1997 he moved to

London where he set up Marc Newson Ltd as a larger studio capable of tackling more ambitious industrial projects.

In 2004–2005, he received the commission from Qantas to design entire aircraft interiors including airport lounges for the new A380 fleet for and was appointed Creative Director of

Qantas Airways.

In April 2005, Newson was named one of TIME magazine’s Top 100 most influential people in the world.

In 2007 he had a solo show of his newest unique and limited edition pieces at the Gagosian

Gallery in New York, and designed a sub-orbital spacecraft for EADS Astrium.

Marc Newson holds Adjunct Professorships in Design at Sydney College of the Arts, and Hong

Kong Polytechnic University and has been appointed Royal Designer for Industry in the UK.

Oven

Page 4-9

Coffee Maker

Page 9

Microwave

Page 10 -11

Cooker

Page 12-13

Gas Hobs

Page 14-15

Domino hobs

Page 16-19

Induction hobs

Page 20-22

Electric hobs

Page 23

Hoods

Page 24-27

Dishwasher

Page 28-32

Laundry

Page 32-33

Refrigerator

Page 34-40

Wine Cellar

Page 41

Sink & Mixer Tap

Page 42-46

4

NeWSoN

Soft lines, symmetry and colours in domestic appliances that are original works of art.

oveN

In various sizes, materials and colours and with different functions, the Smeg range includes standard ovens with a width of 60cm, and compact models with a reduced height of 45cm. Smeg also offer extra wide ovens with a width of 90cm or double ovens, perfect for batch cooking or for large families. They can all be teamed with a hob or other appliances for coordinated kitchen interior design.

NeWSoN eleCtriC oveN

FP610SV

O ven

, 60 cm

, e lectric

, t hermOventilated

10 functiOns

P yrOlitic

O ven

M arc

N ewsoN

, G reeN

e

NerGy

r atiNG

a r eal coNsuMptioN

: 20% less eNerGy thaN a class

Green

Touch Control

LCD display

ECO

Oven capacity: 68 litres

Nominal power: 3,00 kw;

15 Amps power supply is required

Grill power: 2,70 kw

Voltage/Frequency: 220-240 V - 50 / 60 Hz

Standard Accessories:

Telescopic guides (1 level, partial extraction),

1 Deep tray (depth 40 mm),

1 Traditional tray (20 mm) with insert rack,

1 Rack, 1 Rotisserie kit

10 Cooking functions including:

Turbo, ECO cooking function with power saving consumption (1,80 kwh); Rising function

2 Cleaning function: Pyrolisis and

Pirolisis Eco

Electric programmer with: Minute minder, automatic start, automatic end of cooking

Additional Menu programmes:

Showroom mode,

Limited power consumption mode

ECOlogic (nominal power < 2.3 kw),

Locking function (Child safety lock)

Electronic temperature control

Rapid pre-heating

Temperature range: 30-280 °C

Large 72 Lt cavity (+ 35% volume)

5 cooking levels

Metal side supports

Ever Clean Enamel

Roof liner

2 Halogen lights

Full glass inner door

Removable glasses for cleaning

4 glasses “Cool door”

Tangential cooling system

Automatic heating elements/fan switch off when the door is open

Automatic door block during pyrolisis

FP610AN FP610SBL FP610X FP610AB

5

6 oveN

eleCtriC multifuNCtioN oveN

SFP140

60 cm

"l inea

" P yrOlitic

m ultifunctiOn

O ven

, s tainless steel and

s ilver glass

. e nergy

r ating

a

ECO

Programs / Function

s

N° of functions: 19

Cleaning functions: Pirolysis/ Pirolysis eco

Free personal recipes: 10

Automatic programs: 50

Other functions: warm, Defrost, warmdishes,

Rising, Rotisserie

Controls

Display: TFT graphic, touch screen, with colours

Easyguide display

Options

Time-setting options: Delay start and automatic end cooking

End of cooking acoustic alarm

Minute minder

Limited Power Consumption Mode

Showroom demo option

Controls Lock / Child Safety

Other Option: SmartCooking system

Rapid pre-heating

Minimum Temperature: 30 °C

Maximum temperature: 280 °C

Technical Features

Cavity material: Ever clean Enamel

Net volume of the cavity: 72 l

Gross volume: 79 l

N° of shelves: 5

Shelves support type: Metal racks

Roof Liner

N° of lights: 2

Type of light: Halogen

Light Power: 40 w

Lighting when door is opened

Full glass inner door

Removable inner door

Heating elements stop when door is opened

Cooling system: Tangential

Door: Cool door

Accessories Included

Grid Insert fr tray: 1

Grid with rer stopper: 2

Enamelled deep tray (40mm): 2

Partial Extraction Telescopic Guide: 1

Rotisserie kit: 1

Electrical Connection

Electrical connection rating (w): 3000 w

15 Amp power supply required

SC112

60 cm

“l inear

s eries

” e lectric

m ultifunctiOn

O ven

, s t

/ steel

e nergy

r ating

a

ECO

12 functions

Digital electronic programmer with multi-display

Back-lit knobs 2 LED Display

Rapid pre-heating

Removable inner door glasses

Full glass inner door

Cool door/fresh touch

Maxi cavity

Bread proving function

5 Cooking levels

Electronic thermostatic controls

“Ever clean” enamel

Roof liner

2 Halogen lights

"Cool door"

Standard accessories:

Telescopic guides

1 Deep tray

1 Traditional tray

1 Rack

15 Amps power supply is required

Nominal power: 3.0 kw

Grill power: 2.7 kw

Oven capacity: 68 litres

oveN

SF390X

60 cm

"c lassic

" m ultifunctiOn

O ven

, f inger friendly

s t

/ steel

e nergy rating

a

-20%

72 lt

SAFE

COOK kW

ECO logic

ECO

11 functions

Analogue LCD electronic clock programmer

Triple glazed removable door

Removable inner door glasses

Automatic oven switch-off when door is open

Air cooling system

Closed door grilling

Easy clean enamel interior

Rapid pre-heating

Energy saving option - EcoLogic

2 halogen lights

SF381X

60 cm

O ven

, e lectric

, v entilated

6 functiOns l ine

c lassic

, s t

.

steel

e nergy

r ating

a+

ECO

Real consumption: 10% less energy than A class

Options

Time setting options: Automatic end cooking

End of cooking acoustic alarm

Minute minder

Minimum Temperature: 50 °C

Maximum temperature: 250 °C

Technical Features

Cavity material: Ever clean Enamel

Net volume of the cavity: 72 l

Gross volume: 79 l

N° of shelves: 5

Shelves type: Metal racks

N° of lights: 1

Type of light: Incandescent

Light Power: 20 w

Full glass inner door

Removable inner door

Cooling system: Tangential

Door: Temperate door

Accessories Included

5 cooking levels

Metal side supports

Vapor clean function

Nominal Power: 3.0 kw

Maxi plus Oven GROSS capacity: 79 litres

Maxi plus oven NET capacity: 72 litres

13 Amp power supply required

Standard accessories:

Telescopic guides (Partial Extraction)

Extra deep tray (40mm deep)

Roasting/grill pan (20mm deep)

Chrome shelf

Grid Large: 1

Enamelled deep tray (40 mm): 1

Electrical Connection

Voltage (V): 220-240 V

Electrical connection rating (w): 3000 w

Frequency (Hz): 50/60 Hz

15 Amps power supply is required

SE995XR

90 cm

"c lassic

" e lectric

m ultifunctiOn

O ven

, s t

/ steel e nergy rating

B

6 functions

48cm reduced height model

Digital electronic programmer

4 Cooking levels

“Ever clean” enamel

1 Light

Rotisserie

Standard accessories:

Roasting/ grill pan

Chrome shelf

Stay clean liners

Nominal Power: 3.3 kw

Grill power: 2.9 kw

Oven capacity: 70 litres

15 Amps power supply is required

7

oveN

CompaCt CombiNatioN Steam oveN

SC45VC2

45 cm

"l inea

" c

OmPact

c

OmBinatiOn

s team

O ven

, s t

/ steel

SAFE

COOK kW

ECO logic

Standard accessories:

St/Steel deep tray (40mm deep)

St/Steel tray

Chrome shelf

Oven capacity: gross – 35 litres, net – 32 litres

Nominal power: 3.2kw

15 Amp power supply required

45cm reduced height compact oven

10 Functions

Digital electronic programmer with multi display

Electronic timer with end of cooking alarm

Triple glazed removable door

Air cooling system

Energy saving mode – Ecologic

Closed door grilling

Pizza cooking function water reservoir (1.2 litres)

Electronic thermostatic controls

3 cooking levels

Metal side supports

De-scaling function

Child safety lock

8

CompaCt Steam oveN

SC45V

45 cm

“l inear

s eries

” s team

c

OmPact

O ven

, s t

/s teel e nergy

r ating

n

Ot

a

PPlicaBle

45 cm Reduced height compact oven

6 Functions

Manual steam cooking

Meat cooking

Fish cooking

Vegetable cooking

Regeneration function

Defrost

Electronic programmer with:

Minute timer

Delay timer 24 h (automatic ignition)

End of cooking with alarm (automatic switch off) white LED

Double digital display

Iluminated symbols indicating functions

Recipes already programmed for different types of meat, fish and vegetables water level light

Temperature 40°C – 100°C regulated in steps of 5°C

Electronic temperature control

Stainless steel interior

1.4 Litre water tank

Show-room function (Demo)

Power ECO mode

Child lock

Double glazed door

Tangential cooling system

Standard accessories:

1 st steel deep tray (40 mm)

1 perforated st steel tray

1 rack

Nominal power: 1.8kw

Oven capacity: 35 litres

15 Amp power supply required

oveN

CompaCt miCroWave oveN With Grill

SC45M

45 cm

"l inea

s eries

" c

OmPact

m icrOwave

O ven with

g rill

, s t

/ steel

6 f unctiOns

Digital electronic programmer with multi-display

Electronic timer with end of cooking alarm

Double glazed door

Cooling fan

Tilting grill

Pizza function

Norminal power : 3.30kw

Grill power : 1.50kw

Microwave output power : 1.00kw

15 Amps power supply is required

Oven capacity : gross - 37 litres, net - 34 litres

Standard accessories: Pizza shovel, Glass tray, wire shelf

Technical drawing suitable for SC45V

Coffee maker

Smeg offers built-in coffee machines to complete your kitchen, bringing a touch of style and prestige to the ambience. A completely automatic coffee machine, to make real, professional espresso and cappuccino from the comfort of your own home. Available with Linea or Classic design they coordinate perfectly with other appliances in the same aesthetic line.

CMSC45

45 cm

“l inear

” c

Offee

m aker

, st

/ steel

Stainless steel and Stopsol Super silver glass

Back-lit knobs

Multilanguage LCD display

Coffee function: Regular or Double coffee

(1 or 2 cups at same time)

Steam function: for Cappuccino

Hot water function: for Tea or other hot drinks

Rinsing function

Ground coffee option

Coffee intensity adjustable (5 levels):

Extra-light, Light, Medium, Strong, Extra-strong

Coffee length adjustable (3 levels):

Short/Espresso, Medium, Long

Programmable automatic switch on

Automatic Rinsing

Automatic Descaling

Adjustable coffee temperature (3 levels)

Adjustable coffee grinder

Automatic energy saving stand-by

Programmable display multi-language:

ES, EN, FR, DE, PT, NL, IT, RU, Sw, POL, DK, GR

Coffee beans container

Separate container for ground coffee

Removable water tank

Removable container for coffee grounds

Frothing nozzle for cappuccino

Adjustable coffee dispenser

Drip Tray

2 Lights

Telescopic guides

Capacity of water tank: 1.90

Capacity of coffee beans container: 220g

Nominal Power: 1350w

Tension/ Frequency: 220-240 V/50-60 Hz

WarmiNG DraWer

CT15

14 cm

h eight

“l inear

s eries

B uilt

in

w arming

d rawer

, s t

/s teel

Both items together fit standard 60 cm aperture

Suitable for fitting directly beneath a 45 cm compact “Linear series” ovens

Maximum load weight: 45 kg

Minute minder with automatic switch off, can be set from 0 to 240 minutes ,

Drawer has 400 w heater, and is fitted with a tangential cooling fan

Temperature range 30-75°C

Electronic touch controls

9

10 eleCtroNiC CombiNatioN miCroWave oveN

With eleCtriC Grill

MP122

"l inea

" m icrOwave

O ven with electric grill

, s ilver glass

320 mm dePth allOws installatiOn in wall unit

6 functions including pizza

Side opening door

Controls positioned at the bottom

Electronic timer

Tilting grill

Quartz Grill (1.2kw)

Microwave Output Power 850w

Oven Capacity: 22 litres ceramic base

St/steel interior

Cooling system

Auto calculation of defrosting by time or weight

Quick start option

Child safety lock

Standard accessories:

Chrome grill support

FME120

38 cm

“l inear

” m icrOwave

O ven with

e lectric

g rill

, s t

/ steel

Touch controls white LED display

5 Microwave power levels

Electronic timer

Quartz grill

Microwave output power 850 w

20 Litre capacity

St/steel interior

Cooling system

Automatic switch off when door is open

Child safety lock

Standard accessories:

Kit for build in installation

Chrome grill support

Non-stick pizza dish

Turntable

FME20EX

38 cm

B uilt

in

m icrOwave

O ven

a ntifingerPrint s t

/ steel

3 cooking functions

St/steel with fingerproof treatment

Digital clock

5 Microwave power levels

Cooking and defrost automatic functions

Electronic programmer

Programmable memory functions

Auto calculation of defrosting by time or weight

St/steel interior

Cooling system

Safety children security system

Microwave output power 850 w

Oven capacity: 20 litres

Standard accessories:

1 Glass dish, Chrome grill support, Frame kit

461

FMA20X

Digital control; 95 minute timer

Microwave output power 800 w

5 power levels; 8 auto menus

Defrost setting; 245mm glass turntable diameter

Push-button door

Child safety lock; 20 litres capacity

Power consumption 1.25kw

Grill power 1kw

13 amp power supply required

Standard accessories:

Glass dish

Built in frame space for ventilation

595

310

25

600 min 350

560

70

eleCtroNiC CombiNatioN miCroWave oveN

With eleCtriC Grill

the exCelleNCe of maDe iN italy

Designed and produced in Italy, a country with culinary specialities and engineering know-how recognised throughout the world, Smeg ovens have evolved through serious research and development, combined with the specialised knowledge of a nation that mixes the best quality ingredients to create excellent cooking appliances with exclusive designs that always offer peak performance.

Smeg give the opportunity to personalise the kitchen environment with a choice of products in coordinated design lines.

Architect styled Piano Design oven, with complete polished stainless steel both inside and out.

Linear ovens whose aesthetic expresses essential symmetry, underscored by slim-line handles, one-touch illuminated controls and stylish use of glass.

Classic ovens make an unmistakeable style statement in the kitchen, with their original handles and controls and the elegant use of stainless steel.

Marc Newson ovens offer the possibility to have a silver milled handle, giving to the products a more traditional style combined to the modernity of this family.

maxi oveN CavitieS

Increased space and efficiency

Maxi ovens have a cooking cavity that is among the biggest on the market, up to a volume of 68 litres, providing a greater usable capacity inside the oven whilst keeping the same external dimensions, fitting a standard 60cm oven housing.

More cooking levels

5 cooking positions (68 litre cavity) guarantee maximum flexibility, saving time when cooking a number of different dishes at once or when dealing with a large quantity of food.

53 lt 60 lt 68 lt

STANDARD MAxI MAxI PLUS

More versatile innovative telescopic shelf guides, easy to fit and to remove, are a practical solution to putting pans into and removing them from the oven. The guides allow stable, level shelf extraction assuring added safety when checking cooking or removing food.

Increased visibility

Better side lighting increases visibility inside the oven. The 68 litre models have 2 halogen lamps arranged asymmetrically to light the inside even better, eliminating dark corners.

Chef-GraDe CookiNG

a variety of programmes and functions guarantee professional performance even for less experienced chefs. for those who love to experiment in cooking but who never have the time to do so, will find that a Smeg oven becomes a reliable ally.

favourite reCipeS: The Smeg Smart Chef system is preset for certain recipes and you can add others to its memory making it even simpler and quicker to cook your favourite dishes. Just select the dish you want and the oven will program the cooking time and method automatically, even telling you which shelf to put the pan on. time SaviNG: as well as programming end of cooking time, some models even let you set an automatic switch-on to get cooking underway before you get home. The rapid pre-heat option also means the preset temperature is reached in just a few minutes so your favourite recipes can be cooked even faster.

11

12

CookerS

Compact volumes, strict forms, simple and essential design: exceptional domestic appliances, elegant expression of the use of stainless steel in the kitchen.

CookerS

A1-5

90 cm

"O

Pera

" c

OOker with

m ultifunctiOn

O ven and

g as

h

OB

, s t

/ steel e nergy rating

a

O ven

: e nergy

r ating

a

9 functions

Analogue LED electronic clock/programmer

Cooling fan

Triple glazed removable door

Rotisserie

Stay clean liners

Storage drawer beneath the oven

Nominal power: 3kw

Oven capacity: 80 liters

15 Amps power supply is required

Hob:

6 burners including

Rear left: Rapid 3.0 kw

Front left: Ultra rapid 4.0 kw

Rear centre: Fishburner 1.9 kw

Front centre: 1.05 kw

Rear right: Rapid 3.0 kw

Front right: 1.8 kw

Heavy duty pan stands

Automatic electronic ignition

Safety valves

Adaptable for TG / LPG

Standard accessories:

Roasting/grill pan, grill mesh, 2 chrome shelves

(1 doubles as grill mesh), non-stick tray, rotisserie kit wok support extra accessories:

KIT1A1 Splash Back

KIT2A1 St/Steel kick plate

KIT3 Height extension

(to raise appliance 5cm)

KIT4A1 Deep kick plate

(for use with KIT3)

TPKx Tepanjaki grill plate

GT90x Telescopic shelf set

C9IMX

90 cm

“ cOncert

” cOOker with multifunctiOn Oven

& inductiOn hOB

, st

/ steel e nergy

r ating

B

O ven

:

8 functions

Oven capacity: 109 litres

Electronic display

Stopsol glass door

St/steel feet

Door storage compartment

Hob:

5 cook zones

Rear left: Ø 180mm, 1.85/2.5 kw

Front left: Ø 145mm, 1.4/1.8 kw

Centre: Ø 271mm, 2.6/3.7 kw

Rear right extendible: Ø 210mm, 2.3/3.2 kw

Front right: Ø 145mm, 1.4/1.8 kw

Start and stop setting

Embossed guides

Removable door

Tangential cooling system

Electric grill

Timer

End of cooking acoustic alarm

60 Amps supply is required

TPKX

Teppanyaki Grill Plate

Stainless steel grill plate designed for cooking tepanyaki dishes.

Suitable for A1-5

13

oveN liNear

Linea-elite design further extends the Linea range, with a minimalist aesthetic. It is subtly different from the original style, yet co-ordinates well with all existing Linea models.

14

PVA140 ( T owN

G

AS oNLy

)

100cm “l inear series

” ultra lOw PrOfile gas hOB

, antifingerPrint new graPhite glass aesthetics

, anthracite

4 burners including a 4.2 UR:

External left ultra rapid: 4.2 kw

Centre left: 1.0 kw

Centre right: 1.7 kw

External right: 3.1 kw

Antifingerprint new graphite ultra low profile base

Rear illuminated controls

Cast iron pan stands

Automatic electronic ignition

Safety valves

Adaptable for LPG

NB: Depth of hob c. 6cm

PGF95F-2

90 cm

"c lassic

" f lush

-f itted

g as

h

OB

, s t

/ steel

5 burners including

Rear left: 1.80kw Front left: 1.80kw

Centre: Ultra-rapid burner 4.00kw

Rear right: 1.80kw Front right: 1.05kw

St/steel flush base, St/steel controls

Cast iron pan stands, Black burner caps

Automatic electronic ignition, Safety valves

Adaptable for TG / LPG

Pan rest incorporated in central pan stand

NB: Depth of hob c. 7.1 cm

PS906 (LP G

AS

o

NLy

)

90 cm

, "c lassic

" u ltra

l

Ow

P rOfile g as

h

OB

, s t

/s teel

5 burners including

Left: Ultra-rapid burner 4.5 kw

Rear centre: 3.0 kw; Front centre: 1.05 kw

Rear right: 3.0kw; Front right: 1.05 kw

St/steel base St/steel knobs

Cast iron pan stands

Black burner caps

Automatic electronic ignition

Safety valves

Adaptable for LPG

S193AS1

90 cm

g as hOB with

s t

/ steel

5 burners including

Rear left: 1.65 kw

Front left: Ultra-rapid 4.05 kw

Centre: Fish burner 2.90 kw

Rear right: 2.55 kw ; Front right: 1.05 kw

St/steel base, Black knobs and control panel

Enamelled pan stands, Enamelled burner caps

Electronic ignition of buners incorporated in the knobs

Removable burners, Safety valves

Adaptable for TG / LPG

SRV574X.1

70 cm

“c

OntemPOrary

” g as

h

OB

, s t

/ steel

4 burners

Left: 4.05 kw

Front Centre: 1.05 kw; Rear Centre: 1.65 kw

Right: 3.10 kw

St/steel base

Cast iron pan stands

Automatic electronic ignition

Safety valves

Adaptable for TG / LPG

GaS hob

15

16

DomiNo hob -

ultra - loW profile

PGF31GBE

c lassic h

OB

30 cm

, 1 cOOking zOnes c lassic

a esthetic

, s t

.

steel

f rame

, u ltra

lOw PrOfile

Stainless steel; Cast Iron pan stands

Silver Knobs

1 burner dual, triple flame of 5.0 kw

Electronic automatic ignition

Safety valves

Gas setting: natural gas( G20)

Electrical nominal power: 1w

Gas nominal power: 5000w

Central 5000w

Tension/ Frequency: 220-240V/50-60Hz

Linea knobs kit,

Jets for LPG and town gas/ wok support

PGF32GBE

c lassic h

OB

30 cm

, 2 c

OOking zOnes

, c lassic

a esthetic

, s t

.

steel u ltra

lOw PrOfile

Stainless steel; Cast Iron pan stands

Silver knobs

2 Burners

Electric Automatic ignition

Front: 1050w

Rear: 2300w

Tension/ Frequency: 220-240V/50-60Hz

Safety valves

Gas setting: Natural gas (G20)

Electrical nominal power:1w

Gas nominal power: 3350w

Linea knobs kit, Jets for LPG and town gas,

Pan/ wok support

PGF32I

c lassic h

OB

30 cm

, i nductiOn

, 2 cOOking zOnes c lassic

a esthetic

, s t

.

steel

f rame

, u ltra

lOw PrOfile

Ceramic black glass; Silver knobs

2 induction zones; 9 power levels

Residual heat indicators

Overheating protection system

Nominal power: 3000 w

Front: 1400 w - Booster 1800 w

ø 140 mm – minimum ø 100 mm

Rear: 1850 w - Booster 2500 w

ø 180 mm – minimum ø 100 mm

Voltage/ Frequency: 220-240 V / 50 - 60 Hz

Linea knobs kit, Scraper

15 Amps power supply is required

DomiNo hob-

ultra - loW profile

PGF30B

c lassic h

OB

30 cm

, B arBecue c lassic

a esthetic

, s t

.

steel u ltra

lOw PrOfile

Stainless steel / Cast Iron pan stands/ Silver knobs

1 heating element/ 9 power levels water/lava rock basin

In-operation indicator

Electrical Nominal power: 1800 w

Central 1800w

Tension/ Frequency: 200-240V 50-60Hz

Linea knobs kit

13 Amps power supply is required

PGF32C

c lassic h

OB

30 cm

, c eramic

, 2 cOOking zOnes c lassic

a esthetic

, s t

.

steel frame u ltra

lOw PrOfile

Ceramic black glass; Silver knobs

2 high-light zones; 9 power levels

Residual heat indicators

Nominal power: 3000 w

Front: 1200 w ø 140 mm

Rear: 1800 w ø 180 mm

Voltage/ Frequency: 220-240 V / 50 - 60 Hz

Linea knobs kit, Scaper

15 Amps power supply is required

PGF30T

30 cm

“m

Odular

” u ltra

lOw

P rOfile

d

OminO t ePPanyaki

h

OB

, s t

/ steel

2 Induction zones

Front: 1.4 kw (Accelerator 1.8 kw)

Rear: 1.4 kw (Accelerator 1.8 kw)

St/steel ultra-low surface

St/steel knobs

Nominal power: 3.6 kw

15 Amp power supply required

LGPGF

Connecting strip which can be used with the following Domino hobs:

PGF30B, PGF32C, PGF31G, PGF32G, PGF30F,

PGF30T, PGF32I.

17

DomiNo hob

SRV531X

d

OminO

g as

h

OB

, s t

/ steel

1 burner

Ultra-rapid 3-way burner

5.0 kw

St/steel base

St/steel knobs

Cast iron pan stand

St/steel burner caps

Automatic electronic ignition

Safety valves

Adaptable for TG / LPG

SRV532X.1

d

OminO

g as

h

OB

, s t

/ steel

2 burners

Rear: ultra rapid burner 3.3 kw

Front: 1.05 kw

St/steel base

St/steel knobs

Cast iron pan stand

St/steel burner caps

Automatic electronic ignition

Safety valves

Adaptable for TG / LPG

SEGR531X

d

OminO

B arBecue

St/steel base

St/steel knob

Nominal power 2.75 kw

13 Amps power supply is required

“Lava rock” supplied

St/steel tray

DomiNo hob aCCeSSorieS

LG53

c

Onnecting

s triP

f

Or

d

OminO h

OBs

Connecting strip.

Suitable for all domino hobs

18

SEH530X1

d

OminO ceramic hOB

, s t

/ steel

2 High-light zones

Rear: 1.8 kw

Front: 1.2 kw

St/steel base

St/steel knobs

Nominal power 3.00 kw

15 Amp power supply is required

Ø 1 x 180mm rear

Ø 1 x 145mm front

SEFR536X

d

OminO fryer

St/steel base

St/steel knob

Nominal power 2.2 kw

13 Amp power supply required

Removable basket and bowl

Capacity 4 litres approx.

Temperature range: 160°-180°C

SEP510X

30 cm

d

OminO

P arking

P late

18/10 stainless steel

C30CX/1

g lass cOver with st

/ steel frame

Suitable for 30 cm hobs with front controls

(with exclusions of Mod. SEGR531x)

BB3679

c ast

i rOn

g riddle

Cast iron griddle suitable for use on all Colonial gas hobs and most Concert cookers.

DomiNo hob

19

iNDuCtioN hob

Induction cooktops that will change your view of stove-top cooking forever and highspeed ceramic that will deliver full heat within seconds marC NeWSoN iNDuCtioN hob

C oMMoN FuNCTIoN FoR

SI733D ,SI321D

AND

SI644Do

All Marc Newson series equipped highest safety standard such as Residual heat indicators, Child control block, Overheating protection system, Overflow protection system, Protection against accidental start up Automatic pan recognition, Auto-stop when no pan, Fan cooling system

SI321D

h

OB

, 30 cm

, i nductiOn

, 2 zOnes

M arc

N ewsoN

, s traiGht Glass

Easy clean Black ceramic glass

Grey graphics

Touch control

2 induction zones

2 booster (P)

Minimum diameter drawings

Stop-in-temperature function

Keeping-warm function

Quick-set rapid selection

Timer with automatic end of cooking

End cooking acoustic alarm

Other options: nominal power limitation ECOlogic

(2 kw,3kw or 4kw),

Automatic locking function (child safety block),

Showroom mode

Automatic adjustment to pan size

Electronic temperature probes

20

Induction zones power:

Front: 1400 w - Booster 2000 w

ø 160 mm – minimum ø 100 mm

Rear: 2000 w - Booster 3100 w

ø 230 mm – minimum ø 100 mm

Nominal power: 3100 w

15 Amps power supply is required

Voltage/ Frequency: 220-240 V / 50 - 60 Hz

Accessories included:

Scraper, Cable

Color: Grey

iNDuCtioN hob

SI644Do

h

OB

, 60 cm

, i nductiOn

, 4 zOnes m arc

n ewsOn

, s traight edge glass

Easy clean Black ceramic glass

Gold graphics

Touch control

4 induction zones

4 boosters (P)

Minimum diameter drawings

15 power levels

Stop-in-temperature function

Keeping-warm function

Quick-set rapid selection

Timer with automatic end of cooking

End cooking acoustic alarm

Other options: nominal power limitation

ECOlogic

(2 kw, 3kw or 4kw),

Automatic locking function (child safety block),

Showroom mode

Automatic adjustment to pan size

Electronic temperature probes

Induction zones power:

Front left: 2000 w - Booster 2800 w

ø 180 mm – minimum ø 100 mm

Rear left: 2000 w - Booster 2800 w

ø 180 mm – minimum ø 100 mm

Front right: 1400 w - Booster 2000 w

ø 160 mm – minimum ø 100 mm

Rear right: 2000 w - Booster 3100 w

ø 210 mm – minimum ø 100 mm

Nominal power: 5900 w

Voltage/ Frequency: 220-240 V / 50 - 60 Hz

30 Amps power supply is required

Accessories included:

Scraper, Cable

Color: Grey( SI644D)

Orange(SI644DR)

SI733D

h

OB

, 70 cm

, i nductiOn

, 3 zOnes m arc

n ewsOn

, s traight edge glass

Easy clean Black ceramic glass

Grey graphics

Touch control

3 induction zones including giant zone

28 cm/ 4600 w

3 boosters (P)

Minimum diameter drawings

15 power levels

Stop-in-temperature function

Keeping-warm function

Quick-set rapid selection

Timer with automatic end of cooking

End cooking acoustic alarm

Other options: nominal power limitation

ECOlogic (2 kw,

3kw or 4kw), Automatic locking function

(child safety block), Showroom mode

Automatic adjustment to pan size

Electronic temperature probes

Induction zones power:

Front left: 2400 w - Booster 3100 w

ø 230 mm – minimum ø 100 mm

Rear left: 1800 w - Booster 2200 w

ø 160 mm – minimum ø 100 mm

Right: 2800 w - Booster 4600 w

ø 280 mm – minimum ø 100 mm

Nominal power: 8200 w

Voltage/ Frequency: 220-240 V / 50 - 60 Hz

40 Amps power supply is required

Accessories included:

Scraper, Cable

Color: Grey

21

iNDuCtioN hob

SI3321B

30 cm

t

Ouch

c

OntrOl

i nductiOn

h

OB angled edge glass

Front centre: Ø 160mm, 1.4 kw - turbo 2.0 kw

Rear centre: Ø 230mm, 2.0 kw - turbo 3.1 kw

9 power levels

Keep warm

End of cooking acoustic alarm

Residual time indicator

Limited power consumption mode

Controls lock

Front control panel

Nominal power: 3.1 kw

15 Amp power supply is required

SIM62B

60 cm

t

Ouch cOntrOl inductiOn hOB with angled edge glass

Left and right: 2 zones from 0.5/2.3 kw

Multizones from 0.5/4.6 kw

Black glass, easy clean, grey serigraphy

12 power levels

Pre-heat mode

2 programmable quick set levels

Booster mode for each zone

Elapsed time indication

Automatic adjustment to pan size

End of cooking acoustic alarm

Overheat protection function

Reasidual heat indicator for each zone

Automatic safety cut-out

Nominal power: 7.2 kw

30 Amp power supply is required

SI3644B

60cm t

Ouch

c

OntrOl

i nductiOn

h

OB with angled edge glass

Front left: Ø 210/100mm, 1.8 kw - turbo 2.3 kw

Rear left: Ø 180/100mm, 1.6 kw - turbo 2.3 kw

Rear right: Ø 210/100mm, 1.8 kw - turbo 2.3 kw

Front right: Ø 160/100mm, 1.2 kw - turbo 2.0 kw

9 power levels

Timer with aoutomatic end cooking

End cooking acoustic alarm

Residual heat indicator

Control lock

Nominal power: 7.2 kw

30 Amp power supply required

built-iN iNStallatioN, pleaSe refer to fiG.1 before iNStall the iNDuCtioN Cooker

Please strictly follow the procedures:

A minimum of 50mm distance to all side walls must be ensured. Cooker hood must be built with distance of minimum 60 cm above the induction cooker.

Fixed onto an Oven when you are going to fix the oven below the induction cooker, you must assure to separate the heat from the oven and provided good ventilation

Min 15mm

NB: Only pans with a ferrous (magnetic) base are suitable for induction hobs

22

fig.1

Min 60cm

Min 50mm

Min 50mm

50cm

2

50cm 2

SE2321TE2

30 cM

t ouch

c oNtrol

c eraMic

h ob with

a

NGled

e dGe

G lass

2 high-light radiant zones :

Front ø 140 mm, 1200 watt;

Rear ø 120 mm. expanding to 180 mm.,

800/2000 watt

"Suprema" black ceramic glass

Residual heat indicators

Automatic safety cut-out

Child control block

Nominal power 3.2kw

15 Amps power supply is required eleCtriC hob

SE2641TC

60 cM

t ouch

c oNtrol

c eraMic hob with aNGled edGe Glass

4 High-light radiant zones, including one dual

Rear left: ø 140mm, 1.2kw

Front left: ø 180mm, 1.8kw

Rear right dual zone: ø 140/210mm,

1.1/2.4kw

Front right: ø 140mm, 1.2kw

“High-Trans” black ceramic glass

Residual heat indicators

Automatic safety cut-out

Front control panel

Nominal power: 6.6 kw

30 Amps power supply is required

SE2772TC

77 cm

t

Ouch

c

OntrOl

c eramic

h

OB with angled edge glass

4 High- light radiant zones, including 1 dual and 1 extendible

Rear left: Ø 140mm, 1.2 kw

Front left: Ø 140/210mm, 1.1 kw/2.4 kw

Rear right: Ø 170/265mm, 1.4 kw/2.2 kw

Front right: Ø 180mm, 1.8 kw

Timer with automatic end cooking

End cooking acoustic alarm

Independet timer

Option accellerator/quick timer

Option keeping warm

Residual heat indicator

Automatic child block

Nominal power: 7.4 kw

30 Amp power supply required

SE2951TC

90 cm

t

Ouch cOntrOl ceramic hOB with angled edge glass

5 “full power” electric zones including:

Rear left: Ø 140mm, 1.2 kw

Front left: Ø 140/180mm, 0.8/2.0 kw

Centre: Ø 140/210/270mm, 0.7/1.6/2.7 kw

Rear right: Ø 200mm, 1.9 kw

Front right: Ø 140mm, 1.2 kw

Easy clean black ceramic glass

Timer with automatic end cooking

End cooking acousting alarm

Independent timer

Option accelerator/quick start

Option keeping warm

Automatic child block

Nominal power: 9.1 kw

40 Amp power supply required

23

oveN

hooDS

Hoods play an important role in the kitchen, both aesthetic and functional. Designed to offer the best combination of styling and functionality, Smeg hoods reflect the elegance and style of the other kitchen appliances with which they are installed.

Quality

Smeg always utilises the best materials, selecting the finest 18/10 stainless steel for brushed or polished finishes, tempered glass and coloured enamel. During production all hoods are subjected to rigorous testing of materials, operating noise, functions, and equipment both electrical and electronic.

All models are given the Nemko quality mark, and the Smeg manufacturing plants are certified

ISO 9001 and 14000.

precise Control

Functional and ergonomic, Smeg hood controls are designed for quick and simple operation to regulate extraction speed and lighting to perfection. They vary from a glass panel with touch controls to electronic buttons and electromechanical controls styled to co-ordinate with other Smeg products.

Ducted vS recirculation

Smeg hoods can operate in either a ducted or recirculation mode, but the best extraction performance is achieved in the ducted mode, the preferred choice wherever possible.

24

ChimNey hooD

hooDS

KMN75X

n ewsOn

a esthetic

75cm a ngled c himney

h

OOd

, s t

/ steel

1 high performance motor 340w

3 speeds, plus intensive (10 min)

2 x 20w halogen lights

Tilting glass panel

Electronic touch controls

2 st/steel perimeter extraction filters

Delay timer

Internal re-circulation possible

Co-ordinates well with “Newson” style, see www.smeguk.com for further Newson products

Extraction rates:

Ducted 880 m³/h

Recirculated 720 m³/h

Noise level: 68 dB

KTS75C

linea

75 cm

“l inea

s eries

” a ngled

c himney

h

OOd

, s t

/ steel

& g lass

1 high performance motor 240w

4 speed/ 2 halogen lamps

Tilting glass panel/ Electronic controls

1 st/steel anti grease filter (dishwasher safe)

Automatic switch off (10 minute timer) for each speed

Filter cleaning/replacement indicator

Vent outlet Ø 150mm/ Nominal power 240w

Extraction rates: Ducted: 800 m³/h

Recirculated: 720 m³/h/ Noise level: 45 dB(A)

Options : KITF960 - Charcoal filters

KSE951X

90 cm

B lack

g lass

& s t

/ steel

“l inea

s eries

” c himney

h

OOd

1 high performance motor 350 w

4 speeds / 3 halogen lamps

Touch controls / Red LED

Automatic switch off (10 minutes timer) for each speed

Filter cleaning/replacement indicator

Vent outlet: Ø 150 mm

Extraction rates: Ducted: 870 m³/h

Noise level: 44 dB(A)/ Options: KITFC161 - Charcoal filters

KSE905X

90 cM

s t

/ steel

c hiMNey

h ood

Subfamily: wall decorative hood

Aesthetics: Neutral/ width: 900 mm

Design: T flat/ Colour: Black

Material: St. Steel / St Steel Type: Brushed

Glass Type: Normal

Control setting: Touch controls

Led colour: Red/ Display: Digital

Programs / Functions

N° of speed: 3

Technical Features

N° of lights: 2

Type of light: Halogen

Light Power: 20 w/ Motor power: 250 w

Filters number: 3

Anti-grease filters: Aluminium

Charcoal filters included/ Vent outlet: 150 mm

Electrical Connection

Electrical connection rating: 290 w

Voltage: 220-240 V

Frequency: 50-60 Hz

Optional

Charcoal filter: KITFC906

Vent outlet: IMB120

Extraction rates: Ducted: 680 m³/h

Noise level: 71 dB(A)

25

hooDS

26

iSlaND hooD

KS9500X

90 cM

s t

/ steel

c hiMNey

h ood

1 high performance motor, 250w

4 speeds

2 halogen lamps

3 st/steel grease filters (dishwasher safe)

Electronic controls

Timer for automatic switch off

Internal re-circulation possible

Vent outlet Ø 150mm

Nominal power 240w

Extraction rates:

Ducted 800 m³/h

Recirculated 720 m³/h

Noise level: 51 dB

Options : FLT3 - Charcoal filters

KD90X

90 cM

s t

/ steel

“o pera

” c hiMNey

h ood

1 motor, 165 w, twin fan

3 speeds

3 st/steel grease filters (dishwasher safe)

2x20 w Halogen lights

Internal recirculation possible

Vent outlet Ø 150mm

Nominal power 205w

Extraction rates:

Ducted 800 m³/h

Recirculated 720 m³/h

Noise level: 42 dB

Options: FLTK-1 - Charcoal filters

KS1250X

120 cM

s t

/ steel

c hiMNey

h ood

1 high performance motor

4 speeds

2 halogen lamps

4 st/steel grease filters (dishwasher safe)

Electronic controls

Timer for automatic switch off

Internal re-circulation possible

Vent outlet: Ø 150mm

Extraction rates: Ducted 800 m³/h

Recalculated 720 m³/h

Noise level: 44 dB(A)

KSIV960X

100 cm

g lass

& s t

/ steel

i sland

c himney

h

OOd

1 high performance motor, 250w, double fan

Electronic controls

3 speeds

Filter cleaning pilot lamp

Charcoal filter replacement indicator light

1 metal grease filter

4 halogen lamps

Internal re-circulation possible

Vent outlet Ø150mm

Nominal power: 280w

Extraction rates: Ducted 800 m³/h

Re-circulated 600 m³/h

Noise level: 47 dB

Options : KITFC900 - Long life Charcoal filters

274

teleSCopiC hooD built-uNDer hooD

KSET600X

60 cM

s t

/ steel

t elescopic

h ood

2 high performance motors, 110w

Speed cursor

2 metal grease filters

2 halogen lamps

Internal re-circulation possible

Vent outlet: Ø 120 mm

Nominal power 150w

Extraction rates:

Ducted: 700m³/h

Recirculated: 560 m³/h

Options: KITFC 150 - Charcoal filters

KSET900X

90 cm

s t

/ steel

t elescOPic

h

OOd

2 high performance motors, 110w

Speed cursor

2 metal grease filters

2 halogen lamps

Internal re-circulation possible

Vent outlet: Ø 120 mm

Nominal power 150w e xtractiOn rates

:

Ducted: 700 m³/h

Recirculated: 560 m³/h

Options: KITFC 150 - Charcoal filters

KSEC61X

60 cm

s t

/ steel

B uilt

under

h

OOd

1 high performance motor

2 metal grease filters

(dishwasher safe)

Internal re-circulation possible

Vent outlet Ø 120mm

3 Speeds

Nominal power: 205w

Motor power: 125w

Extraction rates: ducted 510m3/h

Noise level: 66 dB(A)

Optional: KITC2R Charcoal filter

KSEC91X

90cm s t

/ steel

B uilt

under

h

OOd

1 high performance motor

3 metal grease filters

(dishwasher safe)

Internal re-circulation possible

Vent outlet Ø 120mm

3 Speeds

Nominal power : 205w

Motor power : 125w

Extraction rates: ducted 380 m3/h

Noise level: 44 dB(A)

Options: KITC2R Charcoal filters

hooDS

27

ClaSSiC

Compact volumes, strict forms, simple and essential design: exceptional domestic appliances, elegant expression of the use of stainless steel in the kitchen.

Orbital spray system

In the 60cm Smeg dishwashers the quality of the wash is enhanced by the unique Orbital wash System. This system consists of a double spray arm, with contra-action rotation, which distributes water evenly throughout the cavity. The spary arm jets are perfectly shaped to direct water with precision, ensuring an excellent quality of wash and a greatly reduced noise level.

28

Shuttle system

Because the 45cm dishwasher is rectangular rather than square, the normal spray arm does not adequately spray the front and the back of the machine. The “Shuttle system” patented by Smeg overcomes this problem shuttling the lower spray from front to back on a secondary supporting arm. This ensures optimum water distribution throughout. Like the Orbital System, the Shuttle System has revolutionized dishwashing, delivering excellent wash results whilst maintaining low consumption of water and energy.

Load capacity: 14 place settings

The baskets have been designed to optimise loading and wash efficiency,They have an " open spacea' design exclusive to Smeg which accommodates the official international 14 place settings, including the stipulated additional bowls and other items.

Load capacity: 10 place settings

Previous 45cm dishwashers have catered for 8 or maximum 9 place settings, but Smeg has now introduced to the market 45cm models with 10 place settings.

dishwasher

Designed to produce optimum wash results with minimum use of energy and water, dishwashers are offered in a variety of types to suit any installation, and many of the styles can be co-ordinated with other Smeg appliances.

PLA4645X

45Cm b uilt in

D ishwasher with s tainless

s teel

F ront

p anel

r ating

aa

10 place settings

9 programmes: Soak, Rapid, Crystals, Eco, Bio,

Auto 40° 50°, Auto 60° 70°, Strong, Super

5 washing temperatures: 38°, 45°C, 55°C,

65°C, 70°C

Finger proof st/steel front panel with display for delayed start, indication of programme duration and time to end

Lights: salt and rinse aid

Delay Timer 1-12 h option

Automatic soak by delayed start

FlexiTabs tablet option

Grey baskets

Height adjustable upper basket by extraction

Lower basket with single tilting rack

Fully st/Steel tank

Third upper basket/ Shuttle spray system

St/steel filter/ Electronic adjusted water softener

Concealed heating element

Aquatest/ Total aquastop

Self balanced hinges

Back foot adjustable from the front

Noise level 46 dB(A) re 1 pW

Energy consumption: 0,93 kWh/cycle

Energy consumption in stand-by off mode: 0,02 W

Energy consumption in stand-by left on mode: 1,5 W

Water consumption: 11 litres/cycle

Normative cycle: ECO

Duration of the normative cycle: 175 min

Annual energy consumption: 266 kWh/y

Annual water consumption: 3.080 litres/year

Nominal power: 1,9 kW

*R ating

aaa- Energy efficiency: A ;

Washing performance: A Drying performance: A

STA4502

F amily

: D ishwasher

, i nstallation type

: F ull

integrateD

,

C olour

: s ilver

, C ommerCial wiDth

: 45

Cm

,

C ommerCial height

: 82

Cm

, n umber oF plaCe settings

: 10, n oise level

: 46

D b(a) re

1 p w, e nergy rating

: aa

Programs / Functions

Number of programmes: 5

Washing temperatures: 45°, 50°, 65°, 70° C

Soak, Crystal, ECO, Ultraclean, Daily 1/2 load

Options

Delay timer option: 3-6-9 hours, with automatic soak

Options for tabs FlexiTabs

Baskets

Basket colour: Gray

Basket components colour: Gray

Upper Basket: With central fixed racks

Height adjustement of the upper basket:

On two levels, by extraction

Lower Basket: With fixed racks

Technical Features

Controls: Electronic

Salt light indicator: Light

Rinse aid light indicator

End of cycle indicator: Acustic signal

Washing system: SwingWash

Third spray arm: Single

Water softner: With electronic setting

Water protection system: Single Acquastop

Water alimentation: Single; cold/ hot water max. 60°C -energysave with hot water up to 35%

Drying system: Natural condenser drying

Tub material: Stainless steel

Filter: Stainless Steel

Hinges: Self balancing with fixed fulcrum

Adjustable feet: 7 cm, da 820 a 890 mm

Energy consumption per cycle (kWh/ciclo):

0.94 kWh

Water consumprion per cycle (l/cycle): 11 l

Annual energy consumption: 266 kWh

Annual water consumption: 3080 l

Reference programme: ECO

Total cycle time of reference programme (min):

165 min

Energy consumption - stand by off mode: 0.02 W

Energy consumption - stand by on mode: 0.80 W

Duration of the stand by on mode (min): 5 min

Electrical Connection

Nominal power: 1400 W

Current: 10 A

Voltage: 220-230 V

Frequency: 50 Hz

Plug type: Schuko

29

30 dishwasher

STA6448

60

Cm built in Dishwasher

F amily

: D ishwasher

, i nstallation type

:

F ull

- integrateD

, C olour

: s ilver

, C ommeriCal w iDth

: 60

Cm

, C ommeriCal height

: 82

Cm

, n umber oF plaCe setting

: 12 n oise level

: 48

Db

( a) re

1 pw

, e nergy rating

a +a

Programs/ Functions

Number of Programmes: 5

Washing temperatures: 45°C, 50°C , 65°C , 70 °C

Soak, Crystal, Normal, ECO, Super

Options: Options for tabs Flexitabs, Baskets

Basket color: Gray

Basket Components color: Light blue

Upper Basket: With central fixed racks

Technical Features:

Controls: Electronic

Salt light indicator: light

Rinse aid light indicator

End of cycle indicator: Acustic signal

Washing system: Orbital; Third spray arm: Single

Water softner: With electonic setting

Water protection system: Singly Acquastop

Water alimentation: Single; cold/hot water max. 60 energy save with hot water up to 35%

Drying system: Natural condenser dryig

Tub material: Stainless steel; Filter: Stainless steel

Hinges: Self balancing with fixed fulcrum

Adjustable feel: 7 cm, da 820 a 890mm

Performance/ Energy label:

Energy consumption per cycle (kWh/ciclo): 1.01 kWh

Water consumption per cycle (I/cycle): 121

Annual energy consumption: 289 kWh

Annual water consumption: 3360 I

Reference programme: ECO

Total cycle time of reference programme

(min):180 min

Energy consumption- stand by off mode: 0.02W

Energy consumption- stand by on mode: 1.5W

PL313X

60

Cm built in Dishwasher

F inger

p rooF

s t

/s teel

F ront

p anel

*r ating

aaa

13 place settings

5 programmes: Soak, Speed 27 min, ECO, Daily ½ load, 4 washing temperatures (38°C, 50°C, 65°C,

70°C) Optic indicator: salt and rinse aid

Programme Daily ½ load

Height adjustable upper basket by extraction

Lower basket with fixed racks

Fully st/steel tank

Third upper spray arm, Orbital washing system

St/steel filter, Electronic adjustable water softener

Concealed heating element, Natural condenser drying

Double Aquastop

Self balancing hinges, Hinges with variable fulcrum

Back foot adjustable from the front

Hot water supply (max. 60°C): energy save up to 35%

Noise level 48 dB(A) re 1 pW

Energy consumption: 1,06 kWh/cycle

Water consumption: 12 litres/cycle

Normative cycle: ECO

Duration of the normative cycle: 180 min

Annual energy consumption: 233 kWh/year

Annual water consumption: 2.640 litres/year

Nominal power: 1,90 kW

Voltage /Frequency: 220-230 V/50 Hz

dishwasher

LSP327X

60

Cm built in Dishwasher

D ishwasher sub

top

, anti

-

Fingerprint stainless steel

Color

.

Features/ Performance

Energy efficiency class: A +

Washing efficiency class: A

Drying Efficiency Class: A

Sound power: 47 dB (A)

Capacity Capacity: 13

Energy consumption in the Eco cycle: 1.03 kWh

Water consumption in the Eco cycle: 9.5 liters

Annual energy consumption in the Eco-cycle: 292 kWh

Annual water consumption in the Eco Cycle: 2660 lt

Washing system: Orbital

Drying: A natural condensation

Delayed start 3-6-9 h soaking with automatic

Salt light indicator/Rinse aid light indicator

FlexiZone ½/ Audible end of cycle

Softener: A electronic control

5 Programs

Soaking/ Echo/Normal/ Quick 27 minutes/

UltraClean

Upper basket height adjustable on three levels

Upper basket with fixed inserts

Lower basket with folding single insert

Baskets gray with blue inserts

Bath: Stainless Steel; Filter: Stainless Steel

Adjustable feet: 7 cm, from 820 to 890 mm

Water supply single, hot / cold water up to 60 ° C

Physical Characteristics

Dimensions (W x H x D): 60 x 82 x 57 cm

Color: Stainless steel anti-fingerprint

Door panel not included.

STO905

90

Cm

F ully integrateD horizontal Dishwasher e nergy

r ating

aaa

12 place settings, 10 programmes

5 temperatures (38°, 45°, 55°, 65°, 70°C)

Buttons, On/off, Programme selector

Frige layer tablet selector,Delay timer

Additional programmes

Lights, Salt, Rinse aid

Orbital wash system,Total Aquastop

Concealed heating element, Adjustable water softener

Easy door assembly, Easyglide stainless steel baskets with anti-drip device, St/steel filter

Aquatest, Interior light

Accomodates plates of up 300mm

Noise level 43 dB(A) re 1 pW

Bio programme: EN50242

Water : 13 litres

Energy: 1.5 kWh

Nominal power: 1.9 kWh

Available in the following version:

STO903

Silver colour of the panel

Silver baskets

Aquatest not available

Interior light not available

Noise level 45 db(a) re 1 pw

For both models on this page:

Energy efficiency: A

Washing performance: A

Drying performance: A

Optional extras:

Antifingerprint st/steel door with handle kit – height 36 cm + 36 cm

KIT73636X

Antifingerprint st/steel door with handle kit – height 36cm + 24cm

KIT73624X

31

dishwasher

F

ReeSTAnding mOdeLS

BLV2R

60

Cm

50’ s retro FreestanDing Dishwasher in reD e nergy

r ating

: aa

14 place settings

10 programmes, incl. quick wash

5 temperatures (38° 45° 55° 65° 70°)

Water: 15 litres

Energy: 1.08 kWh

Noise level: 43 dB (A) RE 1 pW

Model features: Triple class A, Delay timer, Half load, Total aqua stop, Orbital system

Programme option: Flexy tab, Aqua test

Maximum plate diameter 30cm

Average wash time approximately 100 mins

Colour co-ordinating cutlery basket and racks

Retro fires, refrigeration and laundry are also available

BLV2AZ

Pastel Blue

BLV2NE Black BLV2O Orange BLV2P Cream BLV2R Red BLV2RO Pink BLV2VE

Lime Green

BLV2X Silver

32

laundry, washing & drying expertise

Offering excellent performance and sought after style, the distinctive design of Smeg washing machines and washer dryers make them not simply appliances useful for doing the chores, but also inspirational pieces of kitchen furniture combining practicality with technology and grace.

laundry

integrated washer- dryer

Smeg laundry appliances are produced with the environment in mind, using minimium amounts of water and electricity to keep running costs low. The front panel can be removed, ensuring easy access to all components for maintenance..

LSTA 126

F ully integrateD washer

-

Dryer e nergy

r ating

ba hK e nergy

l abel

g raDe

1

Fully integrated washer-deyer front load

Load capacity 6/4 kg

(6 kg washing and 4 kg drying capacity)

Variable spin speed up to 1200rpm

Electronic control

Display for: delay timer up to 24h, time to end and recommended load

Programmed/temperature selector

Buttons: start/pause, drying, delay timer, option selection and confirmation, spin speed selection display indication of the programme status

12 washing programmes

Special programmes: Mix, quick Wash 15 mins

Additional options: Prewash, Intensive Easy ironing, Additional Rinse and Rapid Option

2 time drying programme ( for delicate 60° and resistant 90° textiles)

Special programme Clean, to remove residual fluffy

Variable spin speed

( no spin-500-600-800-1000-1200rpm)

(washing-washing+ drying): 47-90Iitres

Duration of the nomrative programme

( cotton 60° C) 365 min.

Annual Energy consumption

( washing-washing + drying): 204-970kWh

Annual water consumption (washing-washing + drying): 204-970kWh

Nominal power 2000W

Tension- Frequency: 220-240V/50Hz

Noise level db(A) re1pW- rif EN60704-2-4

(washing- spinning-drying phase): 56-

689_58dB(A)

WdF12C7

60

Cm washer

-

Dryer

, white

e nergy rathing

ba hK e nergy

l abel

: g raDe

1

Free-standing washer-dryer front load

Load capacity 7/4 kg (7 kg washing and 4 kg drying capacity)

Variable spin speed up to 1200 rpm

Electronic control

Central display for: delay timer up to 24 h, time to end, recommended load and drying type

Programme selector

Buttons: start/pause, drying, option selection and confirmation, spin speed selection and temperature selection

Display indication of the programme status

15 washing programmes

Special programmes: Mix, Shirts, Gym, Night,

Softener and Super Fast 15 min

Additional options: Delay Timer, Prewash, Intensive,

Easy ironing, Additional Rinse and FlexiTime

2 time drying programmes (for delicate 60° and resistant 90° textile)

Special programme Clean, to remove residual fluffy

Variable spin speed (no spin – 600 – 800 – 1000

– 1200 rpm)

Variable temperature (cold – 30° - 40° - 60° - 75° -

90°C)

End of cycle signal

Automatic variable load

Load balance control system

Antifoam system

Overflow system

St/st drum and polypropylene tank

SelfClean detergent drawer

Wide door with 30 cm diameter

Door opening angle 180°

Easy to access filter

Norm. programme: cotton 60°C

Energy consumption

(washing – washing + drying):

1,19 –5,44 kWh

Water consumption

(washing – washing + drying): 47 - 103 l

Duration of the normative programme

(cotton 60°C) 410 min.

Annual energy consumption

(washing – washing + drying):

238 – 1.088 kWh

Annual water consumption

(washing – washing + drying):

9.400 – 20.600 litres

Nominal power 2000 W

Tension – Frequency: 220-240V/ 50Hz

UK plug

Noise level dB(A) re1pW – rif. EN60704-2-

4 (washing –spinning – drying phase):

56 – 68 - 58 dB(A)

Product sheet date: 10.08.30

33

34

Oven

50's style refrigeratOr

Colour and retro lines for style icons: the glamour of the 1950’s in appliances that have become cult objects.

50's style refrigeratOr with ice cOmpartment

FAB28RO

50' s style

r eFrigerator with iCe Compartment r ight hanD hinge

, e nergy eFFiCienCy Class

a+ hK energy label

: g raDe

1

Gross capacity: 256 litres

Tropicalized compressor

Energy consumption: 215 Kw/h per year

Climatic selector switch

Fresh food capacity: 222 litres, Automatic defrost

3 adjustable glass shelves

1 fruit and vegetable container

1 covered storage box

1 chrome wine rack

Ice Box

Frozen food capacity: 26 litres, Ice cube tray

Also available with left hand hinges (L) i.e FAB28LO

*A gap of 175mm must be left on the hinged side of the

product to allow the door to open. refrigeratOr

FAB28Rne FAB28RB FAB28RX FAB28RR FAB28RVe FAB28RP

FAB28RRO FAB28RV FAB28RAZ

FAB28RBL FAB28RG FAB28RCg

FAB28RUJ FAB28RiT FAB28RCS FAB28RdB

35

36 refrigeratOr

style side by side refrigeratOr

SS55PnL1

s iDe by siDe reFrigerator

, gloss blaCK e nergy

e

FFiCienCy

C lass

a+

Frost free

Elegant handle in aluminum

Total gross capacity 600 litres

LED display and soft touch control panel

Ice and water dispenser

Holiday function

Child lock function

Internal water filter cartridge refrigerator:

Net volume 365 litres

Air ventilation

Extra fresh zone with touch control

2 drawers with humidity control

4 glass shelves

Chrome wine rack

Egg tray

Light

4 temperature sensors

Temperature alarm

Inner door:

3 dairy balconies

2 bottle balconies

Freezer :

Net volume 173 litres

Express freezing

2 drawers

4 glass shelves

4 temperature sensors

Temperature alarm

Inner door:

3 frozen food/pizza balconies

Energy consumption: 440 kWh/y

Nominal power: 120W

Climatic class: T

SS55PTL

s iDe by

s iDe

r eFrigerator

, s tainless steel eFFeCt

, energy efficiency a+

Class

,

Frost free

Soft touch home bar

Elegant handle in aluminium

Total gross capacity 600 lt

LCD display and soft touch control panel

Ice and water dispenser

Holiday function

Child lock function refrigerator

Net volume 365 lt

Air ventilation

“Extra Fresh” zone with soft-touch control

2 drawers with humidity control

Chrome wine rack

Egg tray light

4 temperature sensors

Temperature alarm

INNER DOOR:

3 dairy balconies

2 bottle balconies freezer

Net volume 173 lt

****

Express freezing

2 drawers

4 glass shelves

4 temperature sensors

Temperature alarm inner door:

3 frozen food/pizza balconies

refrigeratOr

FQ60XPe

4 D oors reFrigerator

, anti

-

Fingerprint st

/ steel e nergy

e

FFiCienCy

C lass

a+

Total Gross Capacity 610 litres

Convertible compartment

Touch Control Display

Holiday function

Economy function

Aluminum alloy handle

Full No Frost refrigerator:

Total Net Capacity 385 litres (462 litres with convertible compartment)

Internal width: 83cm

Extra Fresh Zone

4 controlled humidity drawers

3 glass shelves

Internal light

Active Fresh Blue Light

Temperature acoustic alarm

Egg holder

Counterdoor:

4 balconies; 2 bottle balcony

2 balcony with transparent cover freezer :

Convertible compartment freezer/refrigerator

Net capacity 78 litres (155 litres with convertible compartment)

Fast freezing function

5 drawers

1 shelf

Manual internal Icemaker

Temperature acoustic alarm

Nominal power: 200W

Energy consumption: 455 kWh/y

Climatic class: SN-T

FA160X

s iDe by siDe reFrigerator

-

Freezer

,s tainless steel Finishing

, a+ energy Class

, n o

F rost

Net capacity: 537 litres

LED Temperature digital display

Fingerprint free stainless steel front door

Stainless steel kick plate

Completely frost-free Door open alarm refrigerator:

Fresh food capacity: 339 lt.net

4 adjustable glass shelves

1 chilled case drawer

2 humidity controlled crisper

4 door pockets (1 dairy room)

1 egg case

Freezer:

4 glass shelves

2 plastic drawers

5 door pockets

Ice maker tray

Frozen food capacity: 198 litres net

903

605

670

734

.5

37

38 refrigeratOr

built-under refrigeratOr

FR138A

u nDer

-w orKtop

l arDer

r eFrigerator with

i

Ce

box e nergy eFFiCienCy Class

a hK energy label

: g raDe

2

Gross capacity: 132 litres

Reversible door refrigerator:

Fresh food capacity: 111 litres

2 Adjustable glass shelves

1 Crisper shelf, 2 crisper containers

Dairy compartment

Further door storage

Ice box ****

Frozen food capacity: 18 litres

Energy consumption: 220 kW/h per year

Climatic class: N

FL130A

u nDer

-w orKtop

l arDer

r eFrigerator with i

Ce

b ox e nergy eFFiCienCy Class

a hK energy label

: g raDe

1

Gross capacity: 130 litres

Reversible doors

Refrigerator:

Fresh food capacity: 105 litres

Automatic defrost

1 adjustable shelf

1 vegetable container

Freezer: ****

Frozen food capacity: 21 litres

1 ice-cube container

Energy consumption: 208 kW/h per year

Climatic class: ST

Freezing capacity: 2 kg/24 h

Thaw time: 12 h

Vi100A

u nDer Counter Freezer a energy Class

, F ixeD hinge hK energy label

: g raDe

1

A energy class , Total gross capacity: 96lt

Reversible door

Right door mounted hinge

Self closing door freezer

Net volume 86lt manual defrosting fast freezing function temperature adjustable

3drawers

Visible and sound alarm performance:

Energy consumption: 204 kWh/year

Climatic class: SN

Freezing capacity: 8kg/24h

Rising time: 17h

Noise level: 42dBA

refrigeratOr

built-in refrigeratOr/freezer

CR322AnF

i n

C olumn

C ombineD

r eFrigerator anD

n o

F rost

F reezer hK energy label

: g raDe

1

Gross capacity 278 liters refrigerator:

Fan ventilator

Fresh food capacity: 202 liters

Automatic defrosting

3adjustable glass shelves

1 glass fruit and vegetable cover

1 fruit and vegetable containers

Inner door:

1 bottle balcony

2 adjustable balconies

1 balcony with transparent cover

1 egg-tray

Energy consumption: 318 kWh/year

Climatic class: SN - ST

Freezing capacity: 3 kg/24h

Rising time: 13 h freezer:****

Frozen food capacity 62 liters

Ice-cube tray

2 transparent drawers

1 compartment with flap

CR325APL

i n

C olumn

C ombineD

r eFrigerator anD

F reezer e nergy eFFiCienCy Class

a+ hK energy label

: g raDe

1

Gross capacity 281 liters

Reversible doors

Sliding rail fitting refrigerator:

Fresh food capacity: 198 liters

Automatic defrost

4 adjustable glass shelves

1 glass fruit and vegetable cover

2 fruit and vegetable containers

Comprehensive door storage freezer:****

Frozen food capacity 65 liters

Ice-cube tray

3 transparent drawers

Fast freezing compartment

Energy consumption: 270 kWh/year

Climatic class: SN - ST

Freezing capacity: 6kg/24h

Thaw time: 19 h

FR315APL

i n

C olumn

l arDer

r eFrigerator e nergy

e

FFiCienCy

C lass

a+ hK energy label

: g raDe

1

Gross capacity: 321 litres

Reversible doors

Sliding rail fitting refrigerator:

Fresh food capacity: 320 litres

Automatic defrost

6 adjustable glass shelves

1 glass fruit and vegetable covers

2 fruit and vegetable containers

Comprehensive door storage

39

40 refrigeratOr

built-in refrigeratOr

FL227P

i n

C olumn

l arDer

r eFrigerator with

F reezer

C ompartment e nergy eFFiCienCy Class

a hK energy label

: g raDe

1

Gross capacity: 205 litres

Reversible doors refrigerator:

Fresh food capacity: 185 litres

Automatic defrost

3 adjustable glass shelves

Glass fruit and vegetable cover

2 fruit and vegetable containers

Comprehensive door storage freezer: ****

Frozen capacity: 16 litres

1 ice-cube container

free stand refrigeratOr-freezer

FCA375

WhiTe

/

SiLVeR

net capacity: 332 litres hK energy label

: g raDe

1

LED Temperature digital display

Multi Air Flow System - NO FROST

Dimensions: 1898H x 595W x 640D (mm) fridge:

Fresh food capacity: 242 lt.net

4 adjustable glass shelves freezer :Ice maker tray

Frozen food capacity: 90 litres net

595

640

wine cellar

wine cellar

built-in wine cOOler with dOuble temperature zOne

Smeg’s wine cabinet range caters for the wine connoisseurs with the ability to store white and red wines all at your desired temperature.

SCV115

w ine

C ooler in

g loss

b laCK anD

s t

/ steel with

g lass

D oor

(r ight hanD hinge

)

Gross capacity: 368 litres

Space for 115 bottles using original shelf layout

Maximum storage capacity is 198 standard 75cl bottles, with some shelves removed, and bottles stored facing front and back.

Glass door has anti UV ray tint and Classic style st/steel handle

Wine cooler can be free-standing or built-in

Temperature range from 6 to 22°C

Acoustic alarm when temperature falls below 2°C

LEDInternal light

Electronic controls

Two internal temperature zones can be set from the control panel

Door lock at base

6 wooden adjustable and removable shelves

Active carbon filter

Automatic defrost

Height adjustable front feet, rear rollers

Anti vibration compressors

Wine Storage Temperature Guide

Mature, full-bodied reds 16° - 18°C

Young reds 14° - 16°C

New reds 10° - 14°C

Mature whites 12° - 14°C

Mature, full-bodied roses 12° - 14°C

Young whites 10° - 12°C

Light roses 10° - 12°C

Sparkling reds and whites 8° - 12°C

Optional: Also available with left hand hinge SCV115S

NB: If the cooler is built-in a space of at least

5cm must be left behind and above the appliance.

41

sinks

Smeg sinks and taps are high quality products with captivating design and aesthetics. The collection constitutes a number of design orientated and functional sinks that will make an eye-catching style statement in any kitchen.

stylish sinks and taps for every home

Smeg have a large range of stainless steel sinks with outstanding quality and superb style. The drainers are considered a design feature, with a number of different solutions that make Smeg sinks quite unmistakeable. A spectrum of choices - Mira, Quadra, Alba and Rigae - are available to suit your kitchen.

The majority of Smeg sinks are in high quality

18/10 st/steel, with a substantial thickness resulting in a long working life. Finishes include, brushed: a brilliant effect that keeps its good looks and a finger friendly scratch resistant ‘fabric’ finish.

The new Mira sink range features minimum radius

15mm corners instead of square ones, making cleaning easier whilst still offering a refined aesthetic.

the perfect sink, tap and accessory for every kitchen

To complement the Linea cooking range Smeg offer a sink with matching glass boards that combine practicality with good looks as on the reverse they have a highly durable stainless steel finish for a practical working surface. No detail is too much with the neat stainless steel cover for the strainer waste ensuring that a fluid line is maintained even in the bottom of the sink.

practical accessories for versatile sinks

To make the best possible use of the available surface area, Smeg produces stainless steel drainer baskets and hard-wood chopping boards that fit perfectly over the sink. Some models also have a colander that slides into place when in use.

installation options

The large range of models offers a selection of installation choices in a variety of widths with co-ordinating accessories and taps.

inset undermOunt coordinating taps

Smeg offers various types of mixer taps, different designs, functions and finishes. You can choose from models with a brushed steel or chrome-plated finish, with extractable spout or built in water filters.

extra deep bowls

Extra deep sinks offer a greater capacity and versatility. The majority of Smeg sinks are

210mm deep, approximately 40% deeper than most other sinks on the market.

42

Inset, low profile and undermounted styles with curved or squared corners, and single, double or triple bowl options, with or without drainer, all of them easy to install.

sink & mixer tap

LQVS862-1

l inea

86

Cm

"l inea

" ultra low proFile sinK st

/ steel with glass Chopping boarD

Bowl depth: 245 mm

Bowl width: 360 mm

Standard accessories:

Overflow/ Drain

Gaskets

Fixing clips

Dishwasher drain trap

2 Stopsol glass Supersilver and stainless-steel chopping boards

Sliding colander

LQ116D

l inea

( right hanD Drainer

)

D ouble

b owls

s ingle

D rainer u ltra l ow

p roFile

s inK

, r ight hanD

Drainer

Bowl depth: 218mm

Bowl widths: 2x350mm

Drain: 3.5”

Standard accessories:

Overflow,Drain

Gaskets,Fixing clips

Dishwasher drain trap

LQ116S (left hand drainer)

AG116S

s inK

3,5", 116

Cm

, n on

sCratCh s t

/ steel s ingle Drainer inset sinK

( right hanD Drainer

)

2 bowls single drainer inset sink with

1x450mm and 1x300mm bowls

RHD

Drain: 3.5"

Bowl depth: 2x210mm standard accessories:

Overflow, drain, gaskets, holding clamps, dishwasher drain trap

LQ862

linea

D ouble

b owl

u ltra

l ow

p roFile s inK

Bowl depth: 218mm

Bowl widths: 2x350mm

Drain: 3.5” standard accessories:

Overflow

Drain

Gaskets

Fixing clips

Dishwasher drain trap

43

44 sink & mixer tap

LV116FD-3

S ink

S meg

lV116fD-3 receSSeD StainleSS Steel wire toP

, 116 cm

.r

iSPetto image iS the DriP Pan right tanks each 34 cm wide

Bowl depth 21 cm invaded depth 17 mm equipment: overflow, drains 3 "1 / 2, gaskets, clamps and trap dishwasher connection with supplied individually wrapped and packaged draining to the right inserted into the base to 80 cm

NB: mixer request

Sg862

s meg

b owls

i nset

s inK

2 bowls inset sink

2 bowls sink with 1x450mm+1x300mm bowls

Drain: 3.5"

Bowl depth: 2x210mm

Standard accessories: overflow, drain, gaskets, holding clamps, dishwasher drain trap

LQ861S

S ingle

B owl

S ingle

D rainer

U ltra

l ow

P rofile

S ink

, r ight hanD

Drainer

Bowl depth: 216mm

Bowl widths: 350mm

Drain: 3.5”

Standard accessories:

Overflow,Drain, Gaskets, Fixing clips,

Dishwasher drain trap

LPd861d

piano Design

86Cm s ingle

b owl anD

s ingle

D rainer

s inK

, p olisheD

s t

/ steel

, r ight

Drainer

Bowl depth: 200 mm

Bowl width: 340 mm

Drain: 3"1/2 x2

Standard accessories:

Overflow, Drain , Gaskets , Fixing clips

Dishwasher drain trap

LPD861S (left hand drainer)

VSTQ72-2

s ingle square unDermounteD sinK

70 cm" Linear" Rectanglar Undermounted single bowl, st steel

Bowl depth: 210mm

Bowl dimensions:

720mm W x 400mm D

Drain: 3.5”

Standard accessories:

Overflow, Drain, Gaskets, Fixing clips

Dishwasher drain trap

VSTQ40-2

s ingle square unDermounteD sinK

40 cm" Linear" Rectanglar

Undermounted single bowl sink, steel

Bowl depth: 210mm

Bowl dimensions:

400mm W x 400mm D

Drain: 3.5”

Standard accessories:

Overflow, Drain, Gaskets, Fixing clips

Dishwasher drain trap

10i3P

r ounD bowl inset sinKs

Inset round bowl sink

Rond bowl Ø 430mm

Possible combination with basin Mod.11l

Standard accessories: overflow, drain, gaskets, holding clamps sink & mixer tap

mFQ6-iS

s ingle

l ever

m ixer

Brushed stainless-steel finish

Swivel spout

Single lever mixer

mFQ8-iS

s ingle

l ever

m ixer

Brushed stainless-steel finish

Swivel spout

Single lever mixer

45

46 sink & mixer tap

md14CR

s ingle

l ever

m ixer

Chrome finish

Single lever mixer

Pull-out spray

Swivel spout

md1

s ingle lever mixer to matCh

p iano

D esign anD

e volution proDuCts

Polish nickel finish

Single lever mixer to match Piano

Design and Evolution products

Swivel spout

mF2

s ingle lever mixer

Polish nickel finish

Single lever mixer to match Piano Design and Evolution products

Swivel spout sink accessOries

Stainless steel drainer

dB30

Stainless steel drainer basket to fit 300 mm bowl

dB34

Stainless steel drainer basket to fit 340 mm bowl

dB45

Stainless steel drainer basket to fit 450mm bowl

Chopping board

CB30

Hardwood chopping board for 300mm bowl

CB34

Hardwood chopping board for 340mm bowl

Circulaire:

The combination of the fan and circular element around it gives a hot air cooking method. This provides many benefits including no preheat if cook time is more than 20 minutes, no flavour transfer when cooking different foods at the same time, less energy, and shorter cook times. Good for all types of food.

Circulaire with upper and lower elements:

The use of the fan with both elements allows food to be cooked quickly and effectively, ideal for large joints that require thorough cooking. It offers a similar result to rotisserie, moving the heat around the food, instead of moving the food itself, enabling any size or shape to be cooked.

Circulaire with lower element:

The addition of the lower element adds extra heat at the base for food which requires extra cooking.

Circulaire with upper element:

Similar to fan with upper element with the added cooking speed of circulaire, ideal for dishes with a crispy topping.

Upper and lower element only:

A traditional cooking method best suited for single items located in the centre of the oven. The top of the oven will always be hottest. Ideal for roast, fruit cakes, bread etc.

Lower heating element only:

Ideal for foods that require extra base temperature without browning, e.g. pastry dishes, pizza. Also suitable for slow cooking of stews and casseroles.

Top element only:

Useful for browning the tops of dishes such as lasagne and potato or cheese topped recipes.

Grill element/Half grill:

For rapid cooking and browning of foods. Best results can be obtained by using the top shelf for small items, the lower shelves for larger ones, such as chops or sausages. For half grill heat is generated only at the centre of the element, so is ideal for smaller quantities.

Fan with upper and lower elements:

The elements combined with the fan aim to provide more uniform heat, a similar method to conventional cooking, so pre-heat is required. Most suitable for items requiring slow cooking methods.

Fan with upper element:

The same functionality as top element only but will distribute the heat around the cavity allowing for plate warming etc at the same time.

Fan with grill element:

The fan reduces the fierce heat from the grill, providing an excellent method of grilling various foods, chops, steaks, sausages etc. giving even browning and heat distribution, without drying out the food. The top two levels recommended for use, and the lower part of the oven can be used to keep items warm at the same time, an excellent facility when cooking a grilled breakfast.

Half grill (centre portion only) is ideal for small quantities of food.

Oven functiOns

Fan with lower element:

This combination completes cooking more quickly of foods that are ready on the surface, but require more cooking inside, without further browning.

Pizza function:

The simultaneous operation of these three elements ensures an optimum cooking facility when used with the Smeg pizza stone.

Defrost:

Both symbols refer to the same function.

The circulation of enables quicker thawing of frozen food, without the use of any heat. Ideal for use prior to cooking of ready-made dishes, or cream filled products etc.

Snowflake:

With the switch on this symbol, no heating is possible even if the thermostat is turned.

Fan:

As above but with thermostat set a ‘0’. type of food very gently retaining moisture, optimising the foods nutrition ion, taste and aroma. Ideal for many types of food.

Steam:

The steam and hot air combination system cooks any

Microwave:

Microwave energy cooks very quickly and with considerable energy savings. The microwave function can also be combined with conventional functions to save time. Ideal for all types of food.

Bread proving:

Air at 40°C provides the perfect environment for proving yeast type dough mixes. Simply select the function and place dough in the cavity for allotted time.

Rotisserie:

The rotisserie (where installed) works in combination with the grill element whilst constantly turning the food.

These symbols allow use of the rotisserie with full or half grill.

This symbol adds top heat to cook food more quickly.

Toaster:

Selecting the toaster symbol on the function control activates the toaster section of the oven. The toasting duration can be set using the programmer.

Eco:

The Eco setting is a fast preheat function, which combines grill, fan and lower element to achieve optimum energy efficiency. Only to be used prior to selecting the main cook function.

Pyrolitic cleaning:

Pyrolitic cleaning at 500°C destroys all the dirt deposits inside the oven.

The Eco pyrolitic cleaning function can be selected when the oven has a lighter build up of dirt.

This function has a maximum duration of 1.5 hours.

Vapor clean

The Vapor Clean function makes cleaning simple, by using steam generated using a customised programme.

47

48

Oven functiOns

Smeg ovens offer diverse cooking possibilities from more traditional cooking methods to solutions that allow you to optimize cooking times and prepare foods in the most healthy and natural way possible creating cooking solutions perfect for different lifestyles.

A:

Product energy rating, measured from A+++ to D / G depending on the product family.

-20%

A-20%

All Smeg ovens are energy rated A, and some can reduce energy consumption by a further 20% from the standard A Energy rating

72 lt

72 litres

Maxi plus ovens feature 72 litres of usable space

SAFE

COOK kW

ECO logic

finger-friendly stainless steel

The st/steel material used on the exteriors of Smeg dishwashers has a finger-friendly finish to assist in maintaining the surfaces in a pristine condition.

Safe Cook:

Smeg ovens incorprate safe cook, the system for closed door grilling to keep cooking smells inside the oven and ensure a safe cooking environment.

ECO-logic: option allows you to restrict the power limit of the appliance real energy saving.

Child lock: some models are fitted with a device to lock the programme/cycle so it cannot be accidentally changed.

Circulaire + grill

Circulaire + grill

The inner door glass can be removed with a few quick movements for cleaning.

Bread Proving

Air at 40°C provides the perfect environment for proving yeast type dough mixes. Simply select the function and place dough in the cavity for allotted time.

Rapid preheat

The rapid preheat function can be used to reach the selected temperature in just a few minutes.

Telescopic rails allow you to pull out the dish and check it without having to remove it from the oven entirely.

5 different cooking levels

The oven cavity has 5 different cooking levels for maximum flexibility.

Side lights

Two opposing side lights increase visibility inside the oven.

Pizza function

This function allows pizza to be cooked quickly using microwave energy.

Illuminated controls: are a safety device to alert the user that the appliance is on as well as being a stunning design feature.

3

Triple glazed doors: are featured on several Smeg appliances.

SurfacePlus:

The complete base of the microwave can be used for cooking, so no turntable is required.

Air cooling system: to ensure a safe surface temperatures.

Combination steam : ovens can be used either as a steam oven, or as a traditional oven, or alternatively the two methods can be combined.

Circulaire element with steam:

The combination of Circulaire element with steam allows food to be effectively cooked in the most natural way, leaving all the foods properties, flavour and aroma intact.

Microwave:

Penetrating straight into the food, microwaves cook very quickly and with considerable energy savings. Suitable for cooking without fat, they are also able to thaw and heat food without altering its original appearance and aroma. The microwave function can also be combined with conventional functions with all the resulting advantages. Ideal for all types of food.

Microwave + grill element:

To achieve a combined cooking with grill that cooks the outside whilst assuring an internal cooking thanks to the microwave function.

Fan with upper and lower elements

The elements combined with the fan aim to provide more uniform heat.

This is a similar method to conventional cooking, so pre-heat is required.

This is not as effective as circulaire cooking but can also be used to cook biscuits and pastry.

Pizza function

The simultaneous operation of these three elements ensures an optimum cooking facility, ideal not only for pizza but also for cookies, quiches and flans.

Manual function:

Adjustable cooking temperature and duration depending on user’s wish.

Meat Cooking function:

Automatic function with 5 preset programs to cook different types of meat.

Preset cooking duration can be modified.

Fish Cooking function:

Automatic function with 5 preset programs to cook different types of fish.

Preset cooking duration can be modified.

Vegetable Cooking function:

Automatic function with 5 preset programs to cook different types of vegetable. Preset cooking duration can be modified.

Reheating and Sterilising function:

Special function with 6 preset programs to reheat food previously prepared or to steralize marmalade jars or even baby bottles. Readymeal cooking program is also included in this function.Preset cooking duration can be modified.

Defrost by time:

The circulation of air enables quicker thawing of frozen food, without the use of any heat. The microwaves power will be automatically varied to achieve the best thawing results.

Defrost by weight:

The circulation of air enables quicker thawing of frozen food, without the use of any heat. The defrosting time will be calculated based on the food’s type and weight and the microwaves power will be automatically varied to achieve the best thawing results.

Model Description

WOKGHU

LG53

LGPGF

C30CX/1

BB3679

TPKX

inDuCtiOn hOb

SI321D

SI3321B

SI644DO

SIM62B

SI3644B

SI733D

eLeCtriC hOb

SE2321TE2

SE2641TC

SE2772TC

SE2951TC

hOOD

KTS75C

KMN75X

KSE951X

gaS hOb

PVA140

PGF95F-2

PS906

S193AS1

SRV574X.1

DOminO hOb

PGF31GBE

PGF32GBE

PGF32I

PGF30B

PGF32C

PGF30T

SRV531X

SRV532X.1

SEGR531X

SEH530X1

SEFR536X

SEP510X

aCCeSSOrieS

GRWK2

Oven

FP610

SF390X

SC112

SF381X

SFP140

SE995XR

60cm, 10 Functions, " Marc Newson" , Pyrolitic

60cm ,11 Functions, "Classic"Series,

60cm, 12 Functions, 68L "Linear Series"

60cm, 6 Functions, 60L "Classic Series"

60cm, 12 Functions, 68L "Linear Series"

90cm, 6 Functions, "Classic Series"

COmpaCt45 (Linear SerieS)

SC45VC2 45cm Height , compact combination steam oven , 35L

SC45V

SC45M

CMSC45

CT15-2

45cm Height , compact steam oven, 35L , 40°C-100°C

45cm Height , compact microwave oven with grill , 6 function, 37L

45cm Height , compact coffee maker , 1.9 L water tank

14cm Height , compact warming drawer

miCrOwave with eLeCtriC griLL

FMA20X 20L, microwave output : 800W, Grill : 1000W

FME20EX

FME120

MP122

COOker

A1-5

C9IMX-1

20L, microwave output : 850W, Grill : 1000W

20L, microwave output : 850W, Grill : 1050W

22L, microwave output : 850W, Grill : 1200W

90cm, "OPERA" cooker with multifunction oven and gas hob

90cm, "CONCERT" cooker with multi oven & induction hob

100cm, 4 Burners, Ultra low profile , TG only

90cm, 5 Burners, Flush-Fitted , TG/LPG

90cm, 5 Burners, Ultra Low Profile, LPG only

90cm, 5 Burners, TG/LPG

70cm, 4 Burners, TG/LPG

30cm, Gas, 1 cooking zone, Ultra-low profile "Classic" TG/LPG

30cm, Gas, 2 cooking zones, Ultra-low profile "Classic" TG/LPG

30cm, Induction, 2 cooking zones, Ultra-low profile "Classic"

30cm, Barbecue, Ultra-low Profile "Classic"

30cm, Ceramic, 2 cooking zones, Ultra-low profile "Classic"

30cm, Tepanyaki Hob

30cm, 1 Burner Gas Hob with Heavy Duty Pan Stand, TG/LPG

30cm, 2 Burners Gas Hob with Heavy Duty Pan Stand, TG/LPG

30cm, Barbecue

30cm, Ceramic Hob

30cm, Fryer

30cm, Parking Plate

Cast Iron Wok Stand

Cast Iron Wok Stand

Connecting Strip (SRV series)

Connecting Strip (PGF series)

Cover (Except SEGR531X)

Cast Iron Griddle

Tepanjaki Grill Plate, suitable for A1-5

30cm, 2 zones, Touch control, Grey graphics "Marc Newson"

30cm, 2 zones, Touch Control

60cm, 4 zones, Gold graphics "Marc Newson"

60cm, 2 MultiZone

60cm, 4 zones, Touch Control

70cm, 3 zones,Touch control, Grey graphics "Marc Newson"

30cm, 2 zones, 15Amp, Touch Control

60cm, 4 zones, 30Amp, Touch Control

77cm, 4 zones, 40Amp, Touch Control

90cm, 5 zones, 40Amp, Touch Control

75cm, Angled Chimney Type, 800m³/h

75cm, Angled Chimney Type, 880m³/h

90cm, Chimney Type, 870m³/h ,Touch Control , Black glass prOduct price list

Material Retail Price

(HKD)

Multi

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

Cast Iron

Cast Iron

St/steel

St/steel

St/steel

Cast Iron

St/Steel

Black glass

Black glass

Black glass

Black glass

Black glass

Black glass

Black glass

Black glass

Black glass

Black glass

St/steel

St/steel

St/steel

20,800

16,100

14,300

9,000

18,400

17,800

23,800

18,800

14,300

28,800

8,300

4,980

7,900

12,800

12,800

38,800

43,600

18,000

10,500

13,000

7,900

7,280

10,600

10,000

12,800

10,800

10,000

23,800

5,100

5,500

8,500

6,300

9,300

900

390

390

500

800

1,200

1,800

3,300

9,500

9,900

18,800

24,500

14,800

18,800

6,700

10,800

11,500

11,800

23,000

23,500

12,100

49

Model

WDF12C7

Sink

LQVN862-1

LQ116D

AG116S

LV116FD-3

LQ862

SG862

LQ861S

LPD861D

VSTQ72-2

VSTQ40-2

10I3P

mixer tap

MFQ6-IS

MFQ8-IS

MD14CR

MD1

MF2

Sink aCCeSSOrieS

DB30

DB34

DB45

CB30

50

CB34

FA160X

FCA375-W

FCA375-S

FR138A

FL130A

VI100A

FL227P

CR322ANF

CR325APL

FR315APL

wine CeLLar

SCV115

DiShwaSher

PLA4645X

STA4502

STA6448

PL313X

LSP327X

STO905

BLV2R

LaunDry

LSTA126

KSE905X

KS9500X

KD90X

KS1250X

KSIV960X

KSET600X

KSET900X

KSEC61X

KSEC91X

refrigeatOr

FAB28

FAB28RUJ

FAB28RIT

FAB28RCS

FAB28RDB

SS55PNL1

SS55PTL

FQ60XPE prOduct price list

Description Material

90cm, Chimney Type, 800m³/h

90cm, Chimney Type, 800m³/h

90cm, Chimney Type, 800m³/h "Opera"

120cm, Chimney Type, 800m³/h

100cm, Island Chimney Type, 800m³/h

60cm, Telescopic Type,700m³/h

90cm, Telescopic Type,700m³/h

60cm, Built-Under Type, 380m³/h

90cm, Built-Under Type, 380m³/h

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

St/steel

50's Style Refrigerator with Ice Compartment, 256L

50's Style Refrigerator with Ice Compartment, 256L

50's Style Refrigerator with Ice Compartment, 256L

50's Style Refrigerator with Ice Compartment, 256L

50's Style Refrigerator with Ice Compartment, 256L

Side by side refrigerator with ice & water dispenser, 600L

Side by Side Refrigerator with ice & water dispenser, 600L

4 Doors refigerator, 610L.

Single color 18,000

Union Jack 28,900

Tricolore 32,400

Colour Stripe 33,500

Jean gloss black

St/steel

St/steel

33,500

55,900

53,300

40,800

Side by Side Refrigerator, 537L

Free Stand Refrigerator-Freezer, 332L

Free Stand Refrigerator-Freezer, 332L

Single door, Built-under Refrigerator, Automatic Defrost, 132L

Single door, Built-under Refrigerator, Automatic Defrost, 130L

Single door, Built-under Freezer , Manual Defrost, 96L /

/

Single door, Built-in Refrigerator, Automatic Defrost, 205L

Double door, Built-in Refrigerator, No Frost Freezer, 278L /

/

Double door, Built-in Refrigerator, Automatic Defrost, 281L

Single door, Built-in Refrigerator, Automatic Defrost, 321L.

/

/

St/steel Door 17,000

White 11,600

/

Silver 12,600

8,300

8,500

8,800

8,900

19,800

15,800

17,300

Retail Price

(HKD)

10,300

9,800

9,700

18,200

20,800

6,300

7,300

2,100

3,000

Wine Cooler in Gloss Black & St/steel with Glass Door, 115 bottles

45cm, 10 Place Settings, 9 Programmes, 5 Temperatures

45cm, 10 Place Settings, 5 Programmes, 4 Temperatures

60cm, 12 Place Settings, 5 Programmes, 5 Temperature

60cm, 13 Place Settings, 5 Programmes, 4 Temperatures

60cm, 13 Place Settings, 5 Programmes, 4 Temperatures

90cm, 12 Place Settings, 10 Programmes, 5 Temperature

60cm, 14 Place Settings, 10 Programmes, 5 Temperatures

Fully Integrated Washer-Dryer, 6kgs/4kgs. Spin Speed: 500-1200 RPM

Free standing Washer-Dryer, 7kgs./4 kgs., Spin Speed: 1200RPM

Stainess steel ultra low profile sink with black glass chopping board

Double bowls single drainer ultra low profile sink

116cm, single drainer inset sink , non-scratch st/steel and left hand drainer

116cm st/steel sink

Double bowl ultra low profile sink

86cm, 2 bowls inset sink , glazed

Single bowl single drainer ultra low profile sink , Left hand drainer

Piano design single bowl sink, 116cm

Single rectangular undermounted sink, 720W x 400D mm

Single square undermounted sink, 400W x 400D mm

Round bowl inset sinks, st/steel

Single lever mixer brushed stainless-steel finish

Single lever mixer brushed stainless-steel finish

Single lever mixer

Single lever mixer

Single lever mixer

Stainless steel drainer basket to fit 300mm bowl

Stainless steel drainer basket to fit 340mm bowl

Stainless steel drainer basket to fit 450mm bowl

Hardwood chopping board for 300mm bowl

Hardwood chopping board for 340mm bowl

Gloss Black 28,000

/

St/steel Panel 14,400

11,800

12,300

St/steel Panel 15,800

/

/

St/Steel 17,300

19,500

25,400

/

White

15,800

14,800

5,300

7,700

5,800

5,300

3,900

800

1,000

1,080

750

850

19,800

12,800

3,800

5,100

9,500

3,500

8,500

3,400

4,280

3,880

1,800

great treasure (building supplies & engineering) limited

Hong Kong Showroom: address: 2/f. amber commercial building, 70-74 morrison hill road , causeway bay, hong kong tel: (852) 3118 7449 fax: (852) 3176 7449

Macau Showroom: address: rua londres, no.196 r/c ae, edf, golden dragon centre. dynasty area, macau tel: (853) 2872 3661 fax: (853) 2872 2861

Customer Services Centre: block e, 10/f., mai tak industrial building, 221 wai yip street, kwun tong, kowloon, hong kong tel: (852) 3752 6111 fax: (852) 2722 1856

www.gtgroup.com.hk

smeg reserves the right to change specification without notice

Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
