2010 Dutchmen Brochure

2010 Dutchmen Brochure
Camping As It Was
Meant To Be
Affordable And Care Free!
CLASSIC, SPORT & LITE TRAVEL TRAILERS
FILE NAME: 10 Dutchmen Classic FINAL 9-11 .ai
STANDARD AND OPTIONAL FEATURES
THE “ORIGINAL DUTCHMEN” VALUE
PACKAGE - PREMIUM STANDARD FEATURES
• Large Power Awning (Classic And Lite Models)
• 13.5 BTU Roof Air Conditioning
• Large Double Door Gas/Electric Refrigerator
• 1 CU Ft. Microwave Oven With Carrousel
• Four Corner Stabilizer Jacks
• Spare Tire With Carrier
• 6 Gallon Quick Recovery Gas/Electric/DSI
Water Heater With Bypass Kit And Low Point
Drains
• Tinted Safety Glass Windows
• Night Shades In Living Area (Classic And Lite
Models Only)
SUPER LOUNGE SLIDE ROOMS
• 155” Extra Wide Super Slide Rooms
• Oversized 84” X 48” U-Shaped Dinette (See
Floor Plans)
• Extra Long 68” Comfort Air - Hide A Bed Sofa
With Air Mattress
• Available in Classic Models - See Floorplans
CLASSIC DUTCHMEN PREMIUM
CONSTRUCTION
Walls
• Aerodynamic Front Profile With Lower Diamond
Plate Rock Guard
• Wood Stud Construction - 16” On Center With
Heavy Duty Belt Rail
• Hurricane Straps Integrate Walls To Roof And
Floor
• Heavy Duty .024” Mesa Sidewall Metal - Thicker
And Stronger Than The Competition
• R7 Fiberglass Insulation
• Prepped For Rear Ladder (Classic And Lite
Models)
• Fiberglass Key-Locking, Radius Corner Exterior
“Storage Plus” Compartments
• Fiberglass Key-Locking, Radius Corner Entry
Door
• Pac-N-Play Storage - See Floorplans
• Large Picture Window At Dinette
• Large Folding XL Entry Handle (Classic And Lite
Models)
• 120V Exterior Outlet
Roof
• Truss Style Walk-On Roof With Fiberglass
Insulation
• Epdm Rubber Roof With 12 Year Mfg Warranty
• 3/8” Roof Decking
• Roof Ducted Air Conditioning (Classic And Lite
Models)
• Extra Long Extended Rain Gutters
Floor
• 3 1/8” Thick Floor Structure With Water
Resistant Underbelly
• 5/8” Floor Decking
• Premium Vinyl Flooring
• Residential Grade Living Room Carpeting With
Pad (Classic Models)
Chassis
• Heavy Duty Steel I-Beam Frame
• Dual Battery Tray
• 2 5/16” Coupler
• Break-Away Trailer Switch
• Heavy Duty Safety Chains
• 12V Electric Slide-Out Motor With Override
• Easy Lube Axles (Classic And Lite Models)
• Extra Deep Easy-Folding Entry Steps
• Rear Bumper With Sewer Hose Storage
ARMOR GUARD PROTECTION PACKAGE
• Classic and Lite Models Only
• Enclosed And Heated Fresh Water Tank
• Large 46 Gallon Fresh Water Tank
• Protects Fresh Water Tank From Road Debris
And Damage
• Water Tank Mounted Below Floor To Increase
Interior Storage
DOUBLE SKYLIGHTS IN EVERY UNIT
• Skylight Over Tub Or Shower
• Skylight In Galley (Classic And Lite Models
Only)
STORE MORE CABINETRY
• New Cabinet Design - More Storage Space Full Access Cabinets, Larger Drawers
• Raised Panel Hardwood Radiant Oak Cabinets
Doors In Galley
• Hardwood Radiant Oak Cabinets Doors And
Drawer Fronts Throughout
• Large Galley Storage Pantry (See Floorplans
For Availability)
• Large Pots And Pan Drawer - With Heavy Duty
Ball Bearing Drawer Glides (Classic Models)
• Solid Wood Drawers With Metal Residential
Drawer Glides
MEDIA CENTER PREMIUM ENTERTAINMENT
SYSTEM
• 19” Or 26” Flat Screen HD LCD TV - See
Floorplans (Classic And Lite Models)
• New Swivel Entertainment Center - TV Viewable
In Bedroom And Living Area - Select Floorplans
• Flat Panel TV Prep (Sport Models)
• 12V AM/FM/CD/DVD Stereo With Mp3 Input
(Classic And Lite Models)
• 12V AM/FM/CD Stereo With Mp3 Input (Sport
Models)
• Interior Speakers
• Exterior Speakers (Classic and Lite Models)
• Digital TV Antenna With Booster
• Wired For Cable/Satellite
• Bedroom TV Prep For Flat Panel TV’s
ACU-WEIGHT CERTIFICATION
• Real Weights - All Units Weighed Before
Leaving The Factory
• Weights Include Options - See Acu-Weight
Decal On Unit For Exact Weight Of Your Unit
Interior Features
110 Volt Interior And Exterior Duplex Receptacles
Premium 12 Volt Water Pump
Floor Ducted Heating (Most Models)
Electronic Power Converter With Battery Charger
Living Room Features
Premium Residential Furniture
Large Slide-Out Overhead Cabinets
Premium Slide-Out Fascia
Designer Window Valances With Night Shades in
Living Room (Lite and Classic Models)
Mini Blinds Throughout (Sport Models)
12 Volt Lights Over Dinette
Comfort Air - Hide A Bed Sofa With Air Mattress
(Classic Models)
Flip-Over Sofa Bed (Lite & Sport Models)
Kitchen Features
Power Range Hood With 12 Volt Light And
Exhaust Fan
Extra Large, Double Bowl Sink With High
Rise Faucet
Auto Ignition 3 Burner Range With Oven
Built In Countertop Extension Where
Possible (See Floorplans)
Sink And Stove Cover
www.dutchmen-rv.com
Dutchmen Manufacturing, Inc. • 2164 Caragana Court • Goshen, Indiana 46526
Sales: 574.534.1224 Fax: 574.975.0626
Bedroom Features
Prepped For Flat Screen TV In Bedroom (Classic
And Lite Models)
Lift-Up Bed Platform With Storage Below (See
Floorplans)
Designer Bedding Package With Bedspread And
Headboard
Reading Lights
Deluxe Inner-Spring Mattress
Privacy Curtain Or Sliding Bedroom Doors (See
Floorplans)
Vent In Bedroom (Classic Models)
Bathroom Features
ABS Tub & Shower Surround
Glass Shower Door For Neo-Angle Showers (See
Floorplans)
Shower Curtain For Tub Models (See Floorplans)
Hardwood Medicine Cabinet With Mirror (Classic
And Lite Models)
12 Volt Power Exhaust Roof Vent In Bath
GFI Protected 110 Volt Duplex Receptacles
Foot Flush Toilet
Exterior Features
Lp Quick Connect
Exterior Shower/Wash Station
Extra Large Holding Tanks
LP Bottles With Deluxe ABS LP Bottle Cover with
Quick Fill Panel and Auto Change Over (Classic
Models)
20 Pound Lp Bottles (Sport & Lite Models)
Detachable 30 Amp Power Cord
Optional Features
Fiberglass Sidewall Package
Free-Standing Dinette (Classic Models)
15,000 BTU A/C - Ducted (Classic Models)
*See website for specifications on Park Models
Your Local Dealer
Camping As It Was Meant To Be – Affordable And Care Free!
FEATURES - All MODELS
The “ORIGINAL DUTCHMEN” Value Package
FILE NAME: 10 Dutchmen Classic FINAL 9-11 .ai
“SUPER LOUNGE” Slide Rooms
“CLASSIC DUTCHMEN CONSTRUCTION”
“ARMOR GUARD” Protection Package
“DOUBLE SKYLIGHTS” Kitchen & Bathroom
“STORE MORE” Cabinetry
“MEDIA CENTER” Entertainment Package
“ACU-WEIGHT” Certification
Dutchmen Lite Floorplans
Dutchmen Classic Floorplans
OHC
MICRO
OHC
OHC
OHC
TUB
SOFA
BED
U-SHAPED
DINETTE
84" X 48"
SOFA
BED
PANTRY
26B
W/
SKYLIGHT
SKYLIGHT
QUEEN
BED
SC/NS
OHC
ENT. CENTER
PANTRY
REFER
OHC
SKYLIGHT
STORAGE
PLUS
OHC
TV
DINETTE
QUEEN
BED
REFER
CLOSET
W/ SHELF
MICRO
28G-GS
OHC
OHC
PAC-N-PLAY
STORAGE
PLUS
PANTRY
REFER
STORAGE
PLUS
OHC
MICRO
OHC
QUEEN
BED
29Q-GS
SC/NS
SOFA
BED
STORAGE
PLUS
OVERSIZED
BUNK BEDS
SKYLIGHT
DINETTE
TUB
W/
SKYLIGHT
QUEEN
BED
STORAGE
PLUS
OHC
PANTRY
Park Model Floorplans
TUB
REFER
LINEN
W/
SKYLIGHT
SHIRT CLOSET/
NIGHT STAND
OHC
STORAGE PLUS
CA
BI
NE
T
S
40FLP
DINETTE
REFER
SOFA
CAB.
WARDROBE
PULL-OUT
TRASH
WARDROBE
OHC
STORAGE PLUS
PANTRY
W/
SKYLIGHT
MICRO
COFFEE TABLE
FLUSH FLOOR SLIDEOUT
CABINETS W/ SHELF
Sport Floorplans
KING
BED
FULL-HEIGHT
PANTRY
& DRAWERS
SHELF
SHELVING
TUB
NS/
SC
PAC-N-PLAY
OHC/
SHELF
OHC
18B
NS/
SC
QUEEN BED
SKYLIGHT
MICRO
OHC
STORAGE
PLUS
SHIRT CLOSET/
NIGHT STAND
60" X 74"
OHC
REFER
OHC
OHC
CHAIR
OHC
MICRO
CLOSET
CHAIR
PASSTHRU
STORAGE
PLUS
CLOSET
ENT. CENTER
OVERSIZED
U-SHAPED
DINETTE
84" X 48"
NS/
SC
OHC
68” AIR MATTRESS SOFA
STORAGE
PLUS
OHC
ENT. CENTER
27RL
OHC
QUEEN
BED
PAC-N-PLAY
BUNK BEDS
OHC
DINETTE
REFER
PANTRY
ENT. CENTER
LINEN
CLOSET
DOUBLE BED
HINGED BUNK
SKYLIGHT
NEO-ANGLE
SHOWER W/
SKYLIGHT
WARD
SC/NS
SKYLIGHT
PANTRY
OHC
68" SOFA
BED
NS/
SC
OHC
U-SHAPED
DINETTE
84" X 48"
ENT. CENTER
27F
W/
SKYLIGHT
OHC
STORAGE
PLUS
SOFA
BED
CLOSET
TUB
OHC
NS/
SC
STORAGE
PLUS
OHC
SC/NS
OHC
STORAGE
PLUS
TUB W/
SKYLIGHT
BUNK BEDS
25C-GS
NS/
SC
STORAGE
PLUS
CLOSET
110V
REFER
WASHER/
DRYER READY
DRESSER
W/OHC
SHELVING
ENT.
CENTER
OHC
PATIO DOOR
WARD
76"
SOFA BED
DOUBLE BED
40RLP
H
TC
“L” SOFA WITH AIR BED
HU
DINETTE
HINGED BUNK
/O
W
DINETTE
HC
OHC
COFFEE TABLE
PANTRY
SHELF
TUB W/
SKYLIGHT
MICRO
OHC
SHELF
STORAGE
PLUS
REFER
NS/
SC
OHC
OHC
OHC
QUEEN
BED
CLOSET
KING
BED
32″ LCD TV
110V REFER
SOFA
BED
NEO-ANGLE
SHOWER
& SKYLIGHT
SHELF / NS
25F
FIREPLACE WITH
CHIMNEY
FLUSH FLOOR SLIDEOUT
OHC
OHC
CLOSET
WASHER/
DRYER READY
VANITY W/ OHC
PATIO DOOR
DINETTE
CLOSET
W/ SHELF
27B
STORAGE
PLUS
OHC
NS/
SC
WEIGHTS & SPECIFICATIONS
STORAGE PLUS
MICRO
SHELF
SC
REFER
TUB
W/
SKYLIGHT
SOFA
BED
DOUBLE BED
HINGED BUNK
QUEEN
BED
OHC
WARD
OHC
DINETTE
OHC
SC
18B SPORT
25C-GS
25F SPORT
26B
27F
27B SPORT
27RL
28G-GS
29Q-GS
40FLP Park
Model
40RLP Park
Model
Unloaded
Weight
4262
5004
Hitch
Weight
444
462
Net Cargo
Capacity
3438
2696
Exterior
Length
23' 19"
26' 2"
Exterior
Height
10' 3"
10' 4"
6202
6368
4646
6150
5476
5920
9783
9836
804
708
604
775
676
780
1111
1010
3478
3312
3054
3529
2224
1780
1393
1340
28' 8"
30' 1"
28' 7"
30' 0"
29' 11"
31' 8"
42' 6"
41' 8"
11' 0"
11' 0"
10' 4"
11' 0"
10' 3"
10' 4"
12' 10"
12' 10"
Fresh
Water
46
46
46
46
46
46
46
46
46
60
60
Grey
Water
42
42
42
42
42
42
42
42
42
42/36
42/36
Black
Water
42
42
42
42
42
42
42
42
42
42
42
Furnace
Size
20,000
25,000
25,000
30,000
30,000
25,000
30,000
30,000
30,000
34,000
34,000
