VBrick H.264 DME v3.2.4

Admin Guide

May 2014

Copyright

© 2014 VBrick Systems, Inc. All rights reserved.

VBrick Systems, Inc.

2121 Cooperative Way, Suite 100

Herndon, VA 20171 USA

This publication contains confidential, proprietary, and trade secret information. No part of this document may be copied, photocopied, reproduced, translated, or reduced to any machine-readable or electronic format without prior written permission from VBrick Systems, Inc. Information in this document is subject to change without notice and VBrick assumes no responsibility or liability for any errors or inaccuracies. VBrick, VBrick Systems, the VBrick logo, VEMS Mystro,

StreamPlayer, and StreamPlayer Plus are trademarks or registered trademarks of VBrick Systems, Inc. in the United States and other countries. Windows Media, SharePoint, OCS and Lync are trademarked names of Microsoft Corporation in the

United States and other countries. All other products or services mentioned in this document are identified by the trademarks, service marks, or product names as designated by the companies who market those products. Inquiries should be made directly to those companies. This document may also have links to third-party web pages that are beyond the control of

VBrick. The presence of such links does not imply that VBrick endorses or recommends the content of any third-party web pages. VBrick acknowledges the use of third-party open source software and licenses in some VBrick products. This freely available source code is posted at http://www.vbrick.com/opensource

About VBrick Systems

Founded in 1997, VBrick Systems, an ISO 9001 certified vendor, is a privately held company that has enjoyed rapid growth by helping our customers successfully introduce mission critical video applications across their enterprise networks. Since our founding, VBrick has been setting the standard for quality, performance and innovation in the delivery of live and stored video over IP networks—LANs, WANs and the Internet. With thousands of video appliances installed world-wide, VBrick is the recognized leader in reliable, high-performance, easy-to-use networked video solutions.

VBrick is an active participant in the development of industry standards and continues to play an influential role in the

Internet Streaming Media Alliance (ISMA), the MPEG Industry Forum, and Internet2. In 1998 VBrick invented and shipped the world's first MPEG Video Network Appliance designed to provide affordable DVD-quality video across the network.

Since then, VBrick's video solutions have grown to include Video on Demand, Management, Security and Access Control,

Scheduling, and Rich Media Integration. VBrick solutions are successfully supporting a broad variety of applications including distance learning and training, conferencing and remote office communications, security, process monitoring, traffic monitoring, business and news feeds to the desktop, webcasting, corporate communications, collaboration, command and control, and telemedicine. VBrick serves customers in education, government, healthcare, and financial services markets among others.

Contents

DME v3.2.4 Admin Guide

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

How this Manual is Organized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

How to Use this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Font Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

Environmental Goals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

1. Introduction

DME Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Server Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Software-Only Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Software Development Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2. Installation

Installing the Server Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Unpack and Connect the Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Power On/Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Configuring the DME as a VOD Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Configuring the DME in VEMS v5.x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Configuring the DME in VEMS Mystro v6.x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3. Getting Started

How it Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Planning and Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

DME Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Streaming Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

VC Gateway. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

VOD Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

FTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Caching (HTTP) Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Streaming Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Served VOD Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Pushed Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Pulled Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Transmuxed Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

DME Admin Guide iii

Transrated Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

VBAdmin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

End User License Agreement (EULA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

DME Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using Apply, Revert, and Default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Resetting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Home Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Configuration Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

VBDirectory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Configuration Using Secure Shell (SSH) or a Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4. Configuring DME Streams

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Typical Use Cases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

DME Listener Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

DME Input Streams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

In-1 < Push (RTMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

In-2 < RTP Auto Unicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

In-3 < RTP Auto Unicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

In-4 < Unicast/Multicast Transport Streams In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

In-5 < Pull (RTMP). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

In-6 < Pull (RTSP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

In-7 < Pull Transport Stream using RTSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

In-8 < Unicast/Multicast RTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

DME Output Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Out-1 > Serve (RTMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Out-2 > Serve TS via RTSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Out-3 > Serve (RTP). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Out-4 > Serve (RTP). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Out-5 > Push TS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Out-6 > Create HLS (for iPod, iPhone/iPad). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Out-7 > Relay (Unicast/Multicast) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Out-8 > Create HDS (for Flash). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Out-9 > Push (RTMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Out-10 > Push RTP via RTSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Out-11 > Push RTP via RTSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Out-12 > Serve (.wmv, HLS, HDS, other) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

5. System Configuration

Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Host Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

IPV4 Network Interface 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

IPv4 Network Interface 2–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

NAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

iv Contents

Domain Name Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Network Time Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

System Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

System Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Caching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Caching Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Caching Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Manage Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

SSL Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

SAN/iSCSI Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Activate Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

6. SAP Configuration

Announcement Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Announcements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

SAPs for Unannounced Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

7. Input Configuration

Flash/RTSP Pull . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Transport Stream In. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

MPG2TS Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

RTP Playlists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

New Media Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

8. Output Configuration

Flash Push . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

RTSP Push . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Transport Stream Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

HLS Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Playlist Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

HDS Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Playlist Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

RTP Relay. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

New Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Stream Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

9. User Configuration

Username and Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Readonly Username and Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

DME Admin Guide v

Stream Input Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

10. VC Gateway Configuration

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Vendor Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Configuring VC Gateway Streams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Delivering VC Gateway Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Integrating with VEMS Mystro. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Incoming Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Incoming Line Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Destination RTP Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Outgoing Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Outgoing Line Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Creating "Audio Chime" Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

11. Logging

Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

12. Monitor

System Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

RTP Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Multi Protocol Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Relay Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Access History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Upgrade Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Error Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

13. Maintenance

System Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Disk Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Disk Provisioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

14. Diagnostics

Trace Capture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

15. Playing DME Streams

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Playing RTSP/RTP Streams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Playing Multicast RTP Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Playing HLS Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Playing Transport Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Playing Streams with a Flash Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

vi Contents

16. Detailed Use Cases

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Configuring a Multicast Relay with a Unicast Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

H.264 Encoder Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

DME Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Configuring a Multicast Relay with an Auto-Unicast Source . . . . . . . . . . . . . . . . . . . . . . . . 148

H.264 Encoder Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

DME Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

17. Other Tasks

Software Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Installing Security Updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Managing Disk Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

Backup and Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

18. Configuring Devices for the DME

VBrick Encoders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

VBOSS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Rich Media Desktop (RMD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Rich Media Studio (RMS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Streaming to the DME with RMS 1.6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156

Streaming to the DME with RMS 1.3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

More Configuration Examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

RTMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

RTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Transport Stream. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

HLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

DME Admin Guide vii

viii Contents

DME v3.2.4 Admin Guide

Welcome

This document explains how to configure and use VBrick's Distributed Media Engine

(DME). The DME is a versatile, highly-configurable media distribution engine that moves streaming media to and from a wide variety sources and endpoints. It can for example take a unicast RTP stream and multicast it to thousands of local IP users, or it can transmux and serve the same RTP stream to RTMP (Flash) users on the Internet. The information in this document is available with the DME documentation on the VBrick website. For the latest technical documentation for other VBrick products, go to www.vbrick.com/documentation

Note This Admin Guide is not written for casual users. It assumes readers will have a working knowledge of network addressing, communications protocols, and configuration concepts, as well as hands-on experience working with streaming video products.

How this Manual is Organized

This documentation in this document is arranged as follows. Some of it is reference material; some of it is how-to material for specific use cases. For best results, please take a few moments to familiarize yourself with the way the information is organized and follow the

steps listed below in How to Use this Manual.

1. Introduction

2. Installation

3. Getting Started

provides a system overview and provides a detailed explanation of the different DME models available. It also has a glossary of terms that are used in this document.

explains how to setup and test the server hardware. It also explains how to configure the DME as a VOD server in

VEMS.

explains how the DME works including an overview of the major system components. It also explains how to use the

VBAdmin management program.

4. Configuring DME Streams provides detailed use cases with step-by-step instructions

that explain how to configure DME input and output streams for all common scenarios.

5. System Configuration

is a reference chapter. It provides a detailed description of all of the parameters on the System Configuration page in

VBAdmin.

6. SAP Configuration

7. Input Configuration

8. Output Configuration

How to configure SAP announcements for different kinds of streams.

explains how to configure DME input streams including

Flash Pull, TS In, and RTP Playlists. explains how to configure DME output streams including

Flash and RTSP Push, TS Out, HLS, and RTP Relays.

DME Admin Guide ix

x

9. User Configuration

explains how to configure the DME user name and password and the announce settings that let you push streams into the DME.

explains how to set up a video conferencing gateway.

10. VC Gateway

Configuration

11. Logging

12. Monitor

13. Maintenance

14. Diagnostics

15. Playing DME Streams

16. Detailed Use Cases

17. Other Tasks

18. Configuring Devices for the DME

explains how to enable and configure the Access History and the Error Log.

explains how to view the various status and log pages to monitor important DME resources and tasks such as connected users and CPU Load. explains how to reset or shutdown the system.

explains how to capture trace files for VBrick Support

Services when troubleshooting VC Gateway issues.

explains the most common ways that DME end users can view live and stored RTP and RTMP (Flash) streams. shows all of the detailed steps required (on the encoder and on the DME) to configure input and output for a common case.

explains how to upgrade the server when new software is available from VBrick.

explains how to configure VBrick's RMD and RMS applications to stream from the DME.

How to Use this Manual

We have tried to organize this manual in a useful and constructive manner and encourage you to become thoroughly familiar with the information it contains before getting started. The

DME is a complex and highly-configurable product that can be used to transmux and stream video in a variety of different ways. For best results, we recommend you use this manual as follows:

1. Read the introduction and install the hardware as explained in the Introduction and

Installation chapters. Be sure to read the Glossary.

2. Carefully review the Getting Started chapter. Pay particular attention to How it Works and Planning and Preparation.

3. Carefully review the Configuring DME Streams chapter. Find the input and output use

cases that are appropriate for your site and follow the step-by-step instructions.

4. While configuring your DME inputs and outputs, refer to the reference chapters (for

example System Configuration or Input Configuration) for detailed information about

each configurable parameter.

5. If you run into trouble, see the Logging and Monitor chapters for help with finding

errors or troubleshooting problems. If you experience unexpected behavior, see the

DME Release Notes for caveats that may apply.

6. For step-by-step procedures that fully explain the encoder setup and the DME setup for

multicast relays, see the Detailed Use Cases chapter.

Preface

Getting Help

If you can't find the information you need in this document, or from your reseller, you can contact VBrick Support Services on the web, by e-mail, or by calling 1-203 303-0222. For faster service, be sure to have your VBrick product serial number or support contract number. Support Services can usually answer your technical questions in 24 business hours or less. Note that all VBrick documentation is posted on the web. For more information about any VBrick product, go to www.vbrick.com/documentation

Font Conventions

Arial bold

is used to describe dialog boxes and menu choices, for example:

Start > All

Programs > VBrick

Courier fixed-width font is used for scripts, code examples, or keyboard commands.

Courier bold fixed-width font

is used for user input in scripts, code examples, or keyboard commands.

This bold black font is used to strongly emphasize important words or phrases.

Folder names and user examples in text are displayed in this sans serif font.

User input in text is displayed in this bold sans serif font.

Italics are used in text to emphasize specific words or phrases.

Safety Precautions

There is always a danger present when using electronic equipment. Unexpected high voltages can be present at unusual locations in defective equipment and signal distribution systems.

Become familiar with the equipment and observe the following precautions:

• Every precaution has been taken in the design of your system to ensure that it is as safe as possible. However, safe operation depends on you.

• Always be sure your equipment is in good working order. Ensure that all points of connection are secure to the chassis and that protective covers are in place.

• Never work alone when working in hazardous conditions. Always have another person close by in case of an accident.

• Always refer to the manual for safe operation. If you have a question about the application or operation call VBrick for assistance.

• Never allow your equipment to be exposed to water or high moisture environments. If exposed to a liquid, remove power and send unit to be serviced by a qualified technician.

Environmental Goals

At VBrick, we believe that running our company with a "green" conscience is good for the environment and good for business and that environmental awareness is an important part of the value we deliver to our customers. We recognize our responsibilities to our customers, partners, and employees, and also to the communities in which we live and work. We believe that the same ethics and principles that guide our daily business decisions should be applied to the environment as well. We design superior quality, high performance, and energyefficient products and are continually looking for ways to conserve energy and reduce waste.

As a company, we look for ways to be environmentally friendly in designing our products and operating our facilities, and by choosing partners and suppliers who are committed to sustainable development. You can help by recycling batteries and other consumables and by

DME Admin Guide xi

finding new and better ways to protect and preserve our environment. If you have ideas or suggestions that will help to reinforce our commitment to these goals, please let us know. xii Preface

Chapter 1

Introduction

Topics in this chapter

DME Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

DME Overview

The VBrick H.264 Distributed Media Engine (DME) simplifies delivery of high definition video and other rich media content across multi-site enterprises and campus environments. If properly configured, you can simultaneously input multiple streams (of different types) into the DME and output them as the same stream types or as different stream types. For example you can input RTP and TS (transport streams) into the DME and output those same streams as RTMP (Flash) or HLS (for Apple iOS devices). The DME also provides video content caching, storage, and serving to ensure that stored content is delivered from a DME as close to the end user as possible. The Distributed Media Engine may be deployed at a central location, to support transmuxing, or at remote locations to support distribution. It is a single integrated platform providing media redistribution, media transformation and video-ondemand content storage. The DME accepts multiple H.264 media streams from multiple central sites and redistributes that content to diverse endpoints including PCs/MACs, mobile phones and televisions/monitors. This one integrated platform optimizes WAN bandwidth use, simplifies endpoint support and offers local storage of centrally managed content.

Figure 1. DME Model 7530

The Distributed Media Engine is offered on a choice of three robust hardware platforms, all leveraging VBrick's experience with high performance, low touch appliances. It is also offered as a software product to be installed on the customers own hardware (including

DME Admin Guide 1

2

VMWare). Requiring only a web browser interface for management, the H.264 DME seamlessly integrates as a distributed element within the VBrick enterprise IP video platform.

This includes working in concert with a central VBrick Enterprise Management System

(VEMS) to intelligently store and serve content from a local DME. Deploying the H.264

Distributed Media Engine assures users of access to high definition quality video on both fixed and mobile endpoints, even if they are located across campus or across the world.

Applications

The H.264 Distributed Media Engine is deployed on the network edge to support endpoints requiring RTP or RTMP (Flash) streams as well as firewall-friendly HTTP progressive downloads. It supports enhanced scalability and performance across the VBrick suite of applications including:

• Meeting and Event Broadcasting – Provides ubiquitous access to high quality broadcasts and corresponding rich media content at the network edge.

• Training and Lecture Capture – Flash streaming and progressive download via HTTP allow for distribution of content to a wide variety of clients including mobile devices.

• Television Distribution – Simplifies multicast distribution at remote buildings or locations that might not be connected by multicast enabled WAN connections.

• Enterprise YouTube® – Local content storage reduces burden on WAN.

• Surveillance & Monitoring – Deliver more content to diverse endpoints over challenging or far flung network environments.

• Digital Signage – Enhanced performance for greater scalability.

Features and Benefits

• Bandwidth Conservation – Redistribute high quality, live or on-demand, media via RTP multicast; enables more end users to share a single media stream. Leveraging multicast eliminates the need to incrementally scale network bandwidth to support more viewers.

• Media Transformation – Stream high quality H.264 content once and leverage the DME at distributed locations to deliver multiple formats (RTP, RTMP Flash, and/or HTTP progressive download) to reach multiple types of endpoints.

• Mobile Device Support – Enables delivery of live H.264 content to mobile devices as

Flash video or supports HTTP progressive download of video-on-demand content.

• Transrating provides for delivery of content to mobile devices of different types on networks of varying quality.

• Intelligent Central Management – Content is created once and then intelligently managed by the VBrick Enterprise Media System (VEMS) regardless of the location. Stored content is appropriately distributed to local DMEs so users have faster access to frequently viewed content without the need to contend with constrained WAN or

Internet links.

• Robust Appliance Design – Requiring only a web browser for management, the DME eliminates the need to separately manage patches and security updates on commercial server operating systems.

• Secure – Designed to meet the security requirements of demanding government information assurance policies.

• Firewall Friendly – Supports video on demand content via HTTP download; eliminating barriers imposed by network security policies.

© 2014 VBrick Systems, Inc.

Introduction

• Enhanced User Experience – Increases user adoption and impact by assuring outstanding picture quality and response from video applications. The DME easily accommodates increased user demand without degrading performance or the user experience.

Table 1. DME – Supported Protocols

Protocol

Incoming

Outgoing

Management

Description

• RTSP Announce

• RTP Over UDP (with RTCP) Unicast and Multicast

• RTP over TCP (with RTCP) Unicast Only

• RTP over UDP (SDP file delivered via FTP)

• FTP for VOD file transfer

• RTMP via RTMP Push over TCP

• Transport Stream (MPEG2TS delivery of H.264 audio and video content)

• RTP via RTSP (stream)

• UDP, TCP Interleaved, and HTTP Tunneled

• RTP via RTSP (relay - Push)

• UDP, TCP Interleaved using Announce

• RTMP (stream and relay)

• HTTP (progressive download)

• TS (transport stream)

• HLS (Apple HTTP iPad/iPhone live streaming)

• HDS (Adobe Flash HTTP dynamic streaming)

• HTTP Caching Server

• HTTP/HTTPS for management

• IGMPv3

Server Models

VBrick currently supports a variety of shelf and rack-mount models. See the DME Release

Notes for a detailed description of DME models and specifications. There are no absolute rules for sizing a multipurpose device like the DME but there are some basic guidelines that

can help you select the right model. The smaller Model 7530 (Figure 1) does not offer

redundant power supplies or redundant VOD storage so if these attributes are important, you should consider the larger models. The Model 7530 is shelf-mount only while the larger models are rack mount 1U and 2U servers. Users seeking significant VOD content playback should consider one of the two larger models. The RAID arrays built into the Models 7550 and 7570 are much more powerful and better suited for frequent requests than for concurrent VOD playback. The single drive on the Model 7530 is well suited for small to medium offices that have occasional VOD demands.

DME Admin Guide 3

4

Figure 2. DME Model 7550/7570

All of the models have excellent throughput performance and are designed to manage occasional traffic bursts exceed recommended performance characteristics. The throughput recommendations are based on a combination of input and output. For example, a Model

7530 (with 250 Mbps throughput) can support four 1 Mbps streams in, and reflect out 96 1

Mbps unicast streams of RTP or Flash (any combination that equals 250 Mbps). Also keep in mind that one multicast stream out counts as a single stream from a bandwidth perspective, regardless of how many users are watching. Please refer to the DME Release notes for complete

hardware specifications.

Software-Only Version

The DME is available as a hardware/software combination in which case VBrick will deliver the DME server hardware with the DME software already installed. You can also purchase the DME in a VMware virtualized version in which case you must install the DME software on your own server platform. For more about this option, and server hardware recommendations, see the "Software-Only Version" topic in the DME Release Notes.

Software Development Kit

The DME Software Development Kit (SDK) is available for customers who want to build custom applications to control the DME. It assumes the reader is an experienced software developer with a working knowledge of Web Services. All code examples are written in C#.

The SDK includes an .xml document with DME name/value pairs, a sample application, and the DME SDK Reference Guide which explains how to use the APIs. For more information contact your certified VBrick reseller or VBrick Support Services.

Compatibility

Table 2 shows DME compatibility with other VBrick products:

Table 2. DME Compatibility

VBrick Product

VEMS Mystro® Portal Server

VEMS Portal Server

H.264 Encoding Appliance

H.264 Encoding Appliance

H.264 Decoding Appliance

Rich Media Desktop (RMD)

Compatible With Version

6.0.1

5.4

3.0 (RTP)

3.1 (RTP, RTMP)

3.0

1.1

© 2014 VBrick Systems, Inc.

Introduction

VBrick Product

Rich Media Studio

† Use version shown or higher.

Compatible With Version

1.3 (1.6 recommended)

Technical Support

If you can't find the information you need from the documentation or your reseller, you can contact VBrick Support Services on the web. The Support Services website has downloads,

FAQs, documentation, support guidelines, and an on-line form you can use to submit questions. VBrick will make every effort to answer your technical questions in 24 business hours or less.

Figure 3. VBrick On-Line Support Page

Glossary

For best results, please take a few minutes to become familiar with the glossary terms listed below. These technical terms are used throughout this document.

DME Admin Guide 5

6

Auto Unicast A transmitter mode that allows an encoder to "automatically" establish and maintain a connection with a streaming server like Quicktime or Darwin.

The stream is pushed to a configured publishing point external clients can connect to retrieve the stream.

CDN Content delivery networks are distributed server systems of deployed in multiple data centers in the Internet. The goal of a CDN is to serve content to end-users with high availability and high performance.

DASH

DME

Dynamic Adaptive Streaming over HTTP. DASH is a multimedia streaming technology where a multimedia file is partitioned into one or more segments and delivered to a client using HTTP.

Distributed Media Engine is an integrated platform that provides media redistribution, media transformation and video-on-demand content storage.

Caching Server Content is cached at remote locations so subsequent requesting clients can access it locally.

FMS Flash Media Server is a proprietary data and media server from Adobe

Systems. This server works with the Flash Player runtime to create media driven, multiuser Rich Internet Applications.

Flash

FMLE

FTP Server

HDS

HLS

Multimedia platform used to add video and interactivity to web pages.

Flash uses RTMP and is a proprietary Adobe technology.

Adobe Flash Media Live Encoder is a media encoder appliance that streams audio and video in realtime to an Adobe Flash Media Server.

The DME uses File Transfer Protocol to populate the DME with files for progressive download.

HTTP Dynamic Streaming is Adobe's HTTP streaming protocol for Flash players. Like other HTTP adaptive streaming protocols, it breaks the stream into small HTTP-based files so the client can select from different streams containing the same material encoded at different data rates. This allows the streaming session to adapt to available data rates.

HTTP Live Streaming is Apple's HTTP streaming protocol for QuickTime and iPhone. Like other HTTP adaptive streaming protocols, it breaks the stream into small HTTP-based files so that the client can select from different streams containing the same material encoded at different data rates. This allows the streaming session to adapt to available data rates.

HTTP Server The DME has an internal web server that serves VOD files via progressive download.

ICP Internet Cache Protocol coordinates multiple web caches. It finds the most appropriate location to retrieve a requested object when multiple caches are in use at a single site. The goal is to minimize the number of remote requests to the originating server.

Multicast A highly-efficient streaming mechanism wherein one stream is sent to multiple clients without impacting available bandwidth. Multicast is a one-to-many connection between client and server. Used only in local IP

networks (not the Internet); requires support from a switch. See Unicast.

© 2014 VBrick Systems, Inc.

Introduction

Progressive

Download

Pull

Push

RTMP

Progressive download is a method of delivering audio and video that involves caching and playing the downloaded portion of a file while a download is still in progress via FTP. The files are downloaded—not streamed.

The mechanism whereby a video stream is requested, and pulled, from an

RTP server (e.g. QuickTime or Darwin), an RTMP server (e.g. Wowza or

FMS), or another VBrick DME.

The mechanism whereby an RTP or RTMP stream is continuously pushed to a configured destination.

Real Time Messaging Protocol is a proprietary protocol developed by

Adobe for streaming audio and video over the Internet, between a Flash player and a Flash server. The DME has an internal RTMP server for

Flash files. Wowza and FMS are also RTMP servers.

RTMPS

RTP

RTSP

SDP

SIP

StreamPlayer VBrick PC application used to view live and on-demand streams.

StreamPlayer can discover program names on a network by listening for session announcements (SAPs) from VBrick devices.

Transmux

Session Initiation Protocol is a signaling protocol widely used for controlling video conferencing communication sessions.

The process whereby a digital bit stream is converted from one file format or streaming protocol to another—without changing the compression method. An example of transmuxing is when a unicast stream is converted to multicast or when an RTP stream is converted to RTMP.

Transport

Stream (TS)

RTMP over a secure SSL connection. With RTMPS streamed content is encrypted by the Flash Media Server "on the fly" so there is no need to encrypt the source file.

Real Time Transport Protocol is the Internet-standard protocol for the transport of realtime audio and video over the web. The DME has an internal RTP server. Darwin, QuickTime, and VBrick VOD-W streaming servers are RTP servers.

Real Time Streaming Protocol is a network control protocol used to control streaming media servers. RTSP defines the control sequences in streaming playback and uses TCP to maintain an end-to-end streaming connection.

Session Description Protocol. A standard which provides information about the timing and format of a live RTP stream and provides information on how to tune into the stream. It can be provided as part of a session creation in a protocol such as RTSP or as a text file with a .sdp extension.

Transrate

MPEG transport stream (MPEG2TS) is a standard format for transmission and storage of audio and video. Transport Stream specifies a container format encapsulating packetized elementary streams, with error correction and stream synchronization features for maintaining transmission integrity when the signal is degraded.

Change the speed/compression characteristics of a stream without changing the compression algorithm to accommodate different devices

(e.g. laptop, mobile phone) on networks of varying qualities of service

DME Admin Guide 7

8

Unicast

VBAdmin

A bandwidth-intensive streaming mechanism wherein a separate and complete video stream is sent to each requesting client. Unicast is a

one-to-one connection between the client and the server. See Multicast.

An integrated management interface that lets you manage the DME configuration from an external web browser.

VBDirectory A proprietary VBrick application used to auto-discover VBrick devices

(including DMEs) on a local IP network. It is available on the VBrick

Downloads page for new customers and is automatically installed when you perform an upgrade.

VBDME

Download

VC Gateway VBrick's Video Conference Gateway uses standards-based SIP and H.264 technology to become a participant in a video conference and stream the content to multiple endpoints including PCs, Macs, iPads, iPhones, etc.

VEMS

A proprietary VBrick application used to perform a software upgrade on

DME appliances.

VBrick's flagship VBrick Enterprise Media System is an integrated solution that delivers both live and on-demand audio and video over an

IP-based infrastructure. It provides access to a dynamic viewing portal, scheduling and administrative controls, and a media management engine.

VEMS Mystro VEMS Mystro is VBrick's modular enterprise media management system.

Mystro's unique widget-based streaming design lets you personalize and embed IP video in any communications environment such as unified communications, learning management, or mobile devices.

VOD

Wowza

Video-on-demand files are stored streams that can be played from the

DME's FTP server via progressive download.

The Wowza Media Server is a proprietary platform that serves multiple protocols and files.

© 2014 VBrick Systems, Inc.

Chapter 2

Installation

Topics in this chapter

Installing the Server Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Configuring the DME as a VOD Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Installing the Server Hardware

This topic explains how to install the server hardware if purchased from VBrick. The installation of the DME server hardware is straightforward. Unpack and inspect the server and connect the cables as described in the high-level overview on the following pages. As noted, all software is pre-installed and no additional software installation is required. For complete installation instructions, please refer to the manufacturer's documentation that was shipped with your server. Server models 7550 and 7570 are shipped on Dell platforms. You may wish to refer to the following Dell document for a detailed technical overview.

Dell PowerEdge R620 Technical Guide

Unpack and Connect the Server

Each shipment includes a complete DME server with all power cords and cables.

To set up the DME server:

1. Connect the monitor, keyboard, mouse, and network cables as described below.

2. If rack mounting the unit, mount the DME server in the rack, using the rack mount kit provided.

3. Connect the DME server to the network by plugging the 10/100/1000 BaseT Ethernet cable into the Ethernet port 1 on the rear of the unit. Port 1 should always be connected first and is the leftmost port as seen below.

Figure 4. Ethernet Port 1

DME Admin Guide 9

Figure 5. DME Model 7530 (rear)

Figure 6. DME Model 7550/7570 (Dell 620 rear)

4. Connect the monitor cable to the blue video port (front or rear) on the DME server.

Turn the monitor on.

5. Connect a mouse and keyboard to any available USB ports (front or rear) on the DME server.

6. Plug the DME server into a power source, using the power cords provided. (All VOD servers have redundant power supplies, each with its own cord.)

7. Turn the DME server's main power on by pressing the power switch at the front of unit.

Figure 7. DME Model 7530 (front)

Figure 8. DME Model 7550/7570 (Dell 620 front without bezel)

10

Figure 9. DME Model 7550/7570 (Dell 620 front LCD panel)

© 2014 VBrick Systems, Inc.

Installation

8. The DME server will boot and automatically load using the default settings. Wait 5–8 minutes for the unit to fully power up. As new hardware is attached (for example a keyboard and mouse) the operating system will automatically find and install the drivers.

Note The DME ships with DHCP enabled and you can use VBDirectory to auto discover

any DMEs in your network. The Login topic explains how to login to the DHCP

address. The IPV4 Network Interface 1 topic explains how to set a static IP address.

To manage the DME with the VBAdmin web interface, you must have IP access to the network where the DME is located. Then you can use the VBDirectory management application to discover and display the name, IP address, and software revision of all VBrick devices on your network, including DMEs. By default, the DME sends management information about itself via multicast so a multicast-enabled network is required.

VBDirectory listens for Management Announcements from VBrick devices on the network and is available free of charge from the Downloads page on the VBrick website. You can also find the IP address of the DME by connecting a monitor to the blue VGA port (Models 7550 and 7570) or the DVI port (Model 7530) of the DME. The IP address will be displayed at start-up.

Power On/Power Off

To power-on DME (7530/7550/7570) servers, press and release the power button on the front of each unit. To power-off DME (7530/7550/7570) servers (and perform an orderly shutdown), press and release the power button again. Do not press and hold the button or you will force an immediate power-off. Note that you can power-off the server using the

Shutdown

button on the Monitor in VBAdmin.

Configuring the DME as a VOD Server

Optional. When used with VEMS, the DME functions as a VOD server. VEMS will auto discover all stored content on the DME and make it searchable in VEMS. If you will be using a DME in this manner server, it must be configured in the VEMS Portal Server before it is recognized as part of the VEMS system.

Configuring the DME in VEMS v5.x

To configure the DME on a VEMS 5.x Portal Server:

1. Launch VEMS Portal Server and login as an administrator.

2. Go to

Global Settings > Servers

and select

DME-Media Engine

from the dropdown list.

DME Admin Guide 11

12

Figure 10. Portal Server 5.x (Add/Modify VOD/FTP Servers)

3. Enter the

IP or Domain

,

Server Description

(optional),

FTP User Name

(default = admin

) and

FTP Password

(default = admin

).

4. Accept the default

Publishing Point

parameters and click

Add

when done.

Sync DME with Portal Server

Once the DME is configured in VEMS, the Portal Server will auto discover any VOD content on the DME. It may take up to 20 minutes before the DME content is available unless you manually sync the DME server with the Portal Server.

To manually sync the DME server with the VEMS Portal Server:

1. Launch the VEMS Portal Server admin tool and go to

Global Settings > Global

Assignments > Assign VOD Polling Interval

.

2. Click

Sync Now

. Do not change anything else and exit when done.

Adding Live DME Streams

The Portal Server can play live streams served from a DME if the URIs are provided to the

VEMS in one of two ways:

• If the stream is sourced from a VBrick H.264 appliance, the URI of the stream can be automatically provided to the Portal Server server using an external announcement. See the "Announce Settings" topic in the VBrick H.264 Encoder Admin Guide for details.

• The URI can be added manually as a live URL. See the "URLs > Add/Modify a URL for a Live Video Stream" topic in the Portal Server 5.x Admin Guide for details.

Configuring the DME in VEMS Mystro v6.x

To configure the DME on a VEMS Mystro 6.x Portal Server:

1. Launch VEMS Portal Server and login as an administrator.

© 2014 VBrick Systems, Inc.

Installation

2. Go to

Devices > Stored Servers

and click

Add New Server

. a. On the

Server Information

page, enter a user-friendly name, a brief description, and click Submit. b. On the

Entry Points

tab, enter the Hostname or IP address. c. On the

Publishing Points

tab, click

Add New Publishing Point

.

Figure 11. Mystro Portal Server 6.x (Stored Server Administration)

3. From the

Type

dropdown select DME.

4. Fill in the remaining fields as appropriate and click

Submit

when done. In most cases you can use the defaults. For more information see the Portal Server 6.x Admin Guide.

Supporting Cached content

The option exists on VEMS Mystro to automatically support the DME caching of live streams. When configuring this DME, the administrator can select a list of DMEs capable of delivering cached HLS or HDS stream is s to clients located a DME’s zone. When a source

DME is configured and HLS or HDS cached on it, Mystro will redirect clients in the DME’s zone to this DME. The content will be accessed via the DME cache

Refresh Stored Content

Once the DME is configured in VEMS, the Portal Server will auto discover any VOD content on the DME at a configured interval.

To force an immediate refresh of stored content on the Portal Server:

1. Launch the VEMS Portal Server admin pages and go to

System Settings > Task

Scheduler.

2. Find

Refresh Stored Content

on the Current Tasks page and click

Run

.

DME Admin Guide 13

Adding Live DME Streams

The Portal Server can play live streams served from a DME if the URIs are provided to the

VEMS in one of two ways:

• Announcements (SAPs) can be automatically provided to VEMS by the DME (see discussion of SAPs in this Administrators Guide)

• If the stream is sourced from a VBrick H.264 appliance, the URI of the stream can be automatically provided to the Portal Server server using an external announcement. See the "Announce Settings" topic in the VBrick H.264 Encoder Admin Guide for details.

• The URI can be added manually as a live URL. See the "Live Entered URLs" topic in the

Portal Server 6.x Admin Guide for details.

14 © 2014 VBrick Systems, Inc.

Chapter 3

Getting Started

Topics in this chapter

How it Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Planning and Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

DME Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Streaming Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

VBAdmin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Home Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

VBDirectory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Configuration Using Secure Shell (SSH) or a Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

How it Works

The VBrick DME is a multi-faceted platform that performs a variety of serving, reflecting, and transmuxing, and transrating activities. In a typical application, a DME receives a unicast stream over the WAN link (often over TCP) to effectively traverse the LAN and pass through firewalls. The DME then streams via unicast and/or multicast to a variety of different clients in the streaming protocol of choice for each client. To conserve bandwidth, reflectors can be linked across the WAN to relay video streams from one remote site to multiple downstream

DME reflectors. The net effect is that a single unicast stream across the WAN can reach tens of thousands of viewers. To improve reliability, reflectors can either pull or push streams across the WAN using TCP. If a network outage occurs, the DMEs will automatically reconnect and resume streaming without any user intervention. The DME is comprised of

the major components shown in Figure 12.

To reach different classes of clients (e.g. PCs, STBs, and mobile devices), a single stream of

H.264-encoded multi-bitrate (MBR) video can work in concert with reflectors to distribute streams in the most efficient manner. Reflectors can also transmux video streams, converting from one type of transport stream on the input to another type of transport on the output. In transmuxing, a digital bit stream is converted from one file format or streaming protocol to another—without changing the compression method. An example of transmuxing is when a unicast stream is converted to multicast or when an RTP stream is converted to RTMP.

H.264 offers a variety of transport protocols to ensure the reliable delivery of video over a variety of networks. For live broadcasts, the Real-Time Transport Protocol (RTP) is efficient, while the Real-time Streaming Protocol (RTSP) offers the player controls (fast forward, rewind) needed for VOD playback. Newer transport protocols like RTMP (for Flash) and

HTTP are optimized for Internet clients and mobile devices.

Planning and Preparation

The DME provides a powerful way to redistribute media by allowing you to reach multiple/ remote locations and multiple users with minimal use of streaming bandwidth. Streams can be converted from unicast to multicast or delivered as Flash HDS and Apple HLS streams

DME Admin Guide 15

from an RTP source. Since the DME accepts multiple types of input streams and provides multiple ways to output streams, it may not be entirely clear which use cases apply to you and what is the simplest way to deploy your solution using the DME. The best way to determine how to use the DME effectively is to understand three basic factors:

• How you will be delivering media to the DME. This is typically determined by how your media is currently being created, for example as RTP, RTMP, etc.

• How your clients will be viewing content from the DME and with what players, for example with StreamPlayer, QuickTime, etc.

• Which firewalls, virtual networks, proxies, encryption systems, etc. are in place that will need to be traversed and/or reconfigured.

Once you have a better understanding of these issues you are ready to start considering what type of input streams you will have (RTP or RTMP) and how will they be distributed. For example they can be pushed to the DME, pulled from the DME, or by unannounced unicast from the source or an announced auto-unicast to the DME. You will also know how your clients will be viewing the content, for example as RTP, RTMP, or both, using a standalone player, an embedded web page, or through VBrick's VEMS Portal Server. You will also know whether or not the content needs to be relayed to another remote DME or to a CDN for

Internet Distribution. Finally, knowing how many users you have and the bandwidth consumed by each will help to clarify how many DMEs and which models you will need to distribute the streams. By gathering this information in advance, and reading this manual carefully, you can help to ensure a successful deployment of the DME in your own unique environment.

To help you understand the various options available, Configuring DME Streams on page 33

defines a number of typical use cases—not all of which will apply to you. The use cases can help to simplify the configuration. They can help, for example to avoid deploying a simple solution in an overly complex way. In other cases you may also choose one method for one requirement, and have to choose a different method for a second requirement, meaning you will have two input streams when one could just as easily be used for both.

Firewalls can also play an important role in determining which use cases are appropriate.

When no firewalls apply, a push or an auto unicast solution can be easily deployed. However if the DME is behind a firewall, you probably cannot reach it with a push without having to reconfigure the firewall. Similarly, you can probably pull a stream from a source into the

DME. However if the source is also behind a firewall, more network planning, such as placing the DME in a "DMZ" (which the source can push to and the destination can pull from) may be a better solution. If virtual IP addresses are used, you will need to know more about the configuration of the network; and if deploying RTP streams that will travel over

UDP, your firewall may need to be configured to allow UDP data in and out.

DME Components

Streaming Servers

As shown in Figure 12, the DME has an RTP server, a Multi Protocol server, and an HTTP

server for progressive download. Each of these servers supports specific types on inputs and outputs which are described in detail on the following pages. For example, as shown in

Figure 19 on page 34, the Multi Protocol streaming server supports multiple input methods

and multiple output methods. The streaming servers and the VOD servers are built on a robust embedded operating system.

16 © 2014 VBrick Systems, Inc.

Getting Started

Figure 12. DME Server Components

VC Gateway

The DME video conferencing solution builds on a simple video conference by delivering a multi-vendor, standards-based stream that lets smartphones, tablets, PCs/Macs, and TVs display the video conference. It provides a cost effective way to leverage existing video conferencing investments by delivering the video conference audio and video as a stream to

other elements in the VBrick ecosystem. See VC Gateway Configuration on page 111 for

more information.

VOD Servers

The DME engine includes an RTP VOD server, a Multi Protocol VOD server, and an HTTP

Progressive Download server. All stored VOD files are added to the DME via FTP. The

VOD servers support all of the file types shown Table 3.

Table 3. Supported VOD File Types

VOD Server

RTP

Supported File Types

mp4, mov, m4a, m4v

Multi Protocol flv, f4v, mp4, mov, m4a, m4v (H.264)

HTTP all available files including M3u8

(HLS) and f4m(HDS)

FTP Server

The DME has a fully functional web server that uses File Transfer Protocol to populate the

DME with files for progressive download. You can FTP to the

FTP

folder on the DME or to a subfolder. When adding VOD files via FTP, you must wait for the ingestion to complete before the stream will play in VEMS. You can view the ingestion progress on the Status page in the VEMS client. If the ingestion is not complete, the title will display but the stream will not play.

Caching (HTTP) Server

The DME has an internal web server that serves VOD files via progressive download. It also serves video content via the various HTTP adaptive streaming protocols. The HTTP content is cached at remote locations so that subsequent requesting clients can acquire the content

that is cached on a local server. See Caching Overview on page 71 for more about the

caching server.

DME Admin Guide 17

Streaming Overview

Depending on how it is configured, the DME can receive or pull from an encoder, a Flash server, a video conferencing device, or another DME; it can also serve streams or push streams to an RTMP server, an RTP server, or to another DME. The DME supports unicast and/or multicast for both input and output. Unicast streams typically have one source and one destination; most network traffic between clients and servers is unicast. Multicast packets however have a single source and multiple destinations. Instead of sending out individual unicast packets to each client, a single stream of multicast packets can be viewed by multiple clients. This can save substantial network bandwidth when multiple clients are accessing the same stream.

Served VOD Streams

The DME has an RTP server, an RTMP server, and an HTTP Progressive Download server for stored VOD files (including Windows Media files). In server mode, a served stream does not become active on the network until requested by a client. The client may be a software player like StreamPlayer or QuickTime running on a PC, a Macintosh, a mobile device, or a set top box like the VBrick Multi Format set top box. The user requests a stream from the

DME by directing the client to issue an RTSP/RTMP/HTTP request via a URL to the DME.

The client and the DME then exchange a sequence of RTSP/RTMP messages to direct the

DME to send the program to the client. The DME server examines the file to determine

Transport Type, Video Rate, Audio Rate, and other parameters. It then plays the stream using optimal settings adjusted for bandwidth, frame rate, etc.

Note New content files that are transferred via FTP will not be available immediately for

VOD RTMP streaming until the associated seek and meta files are generated. Meta and seek files are typically generated within a few minutes of being transferred.

18 © 2014 VBrick Systems, Inc.

Getting Started

Table 4. Supported Stored Stream Types/Players

Windows

Media

(wmv, wma, asf)

Flv, f4v

Progressive

Download m4v

(assumes

AAC audio)

Flv, f4v

Progressive

Download

MPG, TS

(H.264,

Mpeg2)

Progressive

Download

MP4, mov

(H.264)

Progressive

Download

MP4, mov(MPE

G4P2)

Progressive

Download m4v

(assumes

AAC audio)

MP4

(H.264)

Progressive

Download

RTMP,

RTMPT

RTMP,

RTMPT

RTMP,

RTMPT

MP4, mov

(H.264)

RTSP

MP4,

MOV

(Mpeg4P2)

RTSP

MPG, TS

(H.264,

Mpeg2)

RTSP

HLS file

(m3u8 manifest)

HDS file

(f4m manifest)

DASH

DASH

No

No

No

No

No

No

No

No

No

No

No

No

No

WM

Player

Yes

Players

iPhone, iPad

Android QuickTime

(MAC)

QuickTime

(PC)

Flash

Player

StreamPlayer,

VBrick MAC

Player

Silverlight/

Smooth

Streaming

Player

MF-

STB

Amino

STB

No No No No No Yes Yes No No

No

Yes

No

Yes

No

No

No

No

No

No

No

Yes

No

No

No

No

Yes

No

No

No

No

Yes*

No

No

No

Yes

No

Yes

Yes

No

No

No

Yes*

Yes*

No

Yes (4.0) Yes

No No

No

Yes

No

Yes

Yes

No

No

No

Yes*

Yes*

No

No

No

Yes

Yes

No

Yes

No

Yes

Yes

Yes

No

No

No

No

Yes

No

No

No

No

No

No

No

No

Yes*

Yes*

No

No

No

No

No

No

No

No

No

No

No

No

No

No

No

No

No

No No

No No

No No

No

No

No

No

Yes* No

Yes* No

No

No

No

No

No

No

No

No

No

No

No No No No Yes No No Smooth

Streaming files (ism manifest)

DASH

* Only if the MP4 files are hinted

No No No

DME Admin Guide 19

20

Pushed Streams

The DME also pushes live streams to a configured destination. The destination may be a single endpoint in the case of a unicast, or multiple endpoints in the case of multicast. The transmitter does not directly depend on a client to initiate the streaming but is always transmitting (in the case of multicast) and transmits if the client is reachable and listening (in the case of unicast). The streams are transmitted across the network via RTP, RTMP., or

Transport Stream. Note that RTMP is a unicast-only protocol.

Pulled Streams

The Multi-protocol Streaming Server can pull live streams from an RTSP/RTP server or an

RTMP server. It can pull from various outside sources, for example from another DME, or from a Wowza, FMS, QuickTime, or Darwin streaming server. These streams can then be served or pushed via various protocols.

Transmuxed Streams

Transmuxing is the process whereby a digital bit stream is converted from one file format or streaming protocol to another—without changing the compression method (as opposed to

transcoding which actually changes the compression method). The DME transmuxes streams; it does not transcode streams. An example of transmuxing is when a unicast stream is converted to multicast or when an RTP stream is converted to RTMP. The following table shows the live input streams that are supported in the left column and the live output streams that are supported in the top row.

Transrated Streams

Transrating is the process where a digital bit stream is converted from one bit rate to anotherwithout changing the compression. An example of transrating is when a high bit rate stream is converted into multiple lower bit rate streams for delivery to mobile devices. Note that the

DME does not change the resolution of the source stream, although the receiving device will generally display the stream at its preferred resolution.

© 2014 VBrick Systems, Inc.

Getting Started

Table 5. Live Transmux Capabilities

RTMP Unicast

Pull

RTMP Auto-

Unicast

RTP Unicast

Push

RTP Auto-

Unicast

Yes

Yes

Yes

RTP Unicast

RTSP Pull

Yes

RTP Multicast Yes

TS Unicast Push Yes

TS Unicast

RTSP Pull

(3.1.1)

Yes

TS Multicast

Apple HLS

Yes

No

Adobe HDS

VC SIP

DME Output Streams

RTMP

Unicast

Pull

RTMP

Auto-

Unicast

RTP

Unicast

Push

RTP

Auto-

Unicast

RTP

Unicast

RTSP

Pull

RTP

Multicast

TS

Unicast

Push

TS

Unicast

RTSP

Pull

TS

Multicast

Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes

Apple

HLS

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

No

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

No

No

Yes

Yes

Yes

Yes

Yes Yes

Yes

Yes

Yes

Yes

No

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

No

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

No

No

Yes

Yes

Yes

Yes

Yes Yes

Yes

Yes

Yes

Yes

No

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

No

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

No

No

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

Yes

(Cache)

Yes

(Cache)

Yes

VC SIP

No

No

No

No

No

No

No

No

No

No

No

No

VBAdmin

The VBrick DME server has an integrated management interface (VBAdmin) that lets you manage the DME configuration from an external web browser. This allows network managers to remotely configure and monitor the appliances from virtually any location that has web access. The most convenient way to access the VBAdmin interface (Figure 17) is via

the VBDirectory utility. After installing VBDirectory you will see the screen shown in

Figure 18 on page 30. Locate a specific DME and simply double-click on the

Name

to launch

the VBAdmin Login. To optimize the functionality of this tool, set the

Host Name

of the

DME (on the System Configuration > Network page) to a meaningful text string during initial configuration.

Alternatively, if you know the DME's IP address, you can access it directly from a browser.

As shown in Table 6 you can launch VBAdmin in Internet Explorer or Firefox (other browsers are not supported by VBrick). You connect to VBAdmin by pointing to the IP

Address and Port Number (for example: http://192.168.5.5:8181

) of the DME and logging in with valid credentials. Note that the DME's management interface is not on Port 80. By default the admin port for the DME is 8181. This allows Port 80 to be reserved for HTTP downloads.

DME Admin Guide 21

Table 6. Supported Browsers

Browser Version

Microsoft Internet Explorer 8.0 or higher

Mozilla Firefox 3.6 or higher

Login

The DME ships with DHCP enabled and you can use VBDirectory to auto discover the IP

addresses any DMEs in your network. The VBDirectory application (which you can install on a local PC) is provided free of charge. It is available on the VBrick Downloads page for new customers and is automatically installed when you perform an upgrade. Once you know the

DME's IP address, you can login by entering the server's IP address or host name, and the management port (

8181

), in the address bar of your browser. When the login page is displayed, enter a valid

User Name

(default = admin

) and

Password

(default = admin

) to launch the VBAdmin management interface. A typical login URL would have the following format: http://172.22.2.50:8181

22

Figure 13. VBAdmin Login Page

Note Administrators should be aware that the DME’s management interface is not on Port 80 as is typical for most web-based admin tools. By default the admin port for the DME is

8181. This allows Port 80 to be reserved for HTTP downloads.

Log Out

To log out of the application, click

Log Out

in the navigation panel on the left. As a security measure, if no keyboard activity is detected for 20 minutes, VBAdmin will automatically timeout and display the Login page. It is highly recommended that you use the

Username and

Password

page in VBAdmin to change the user name and password after logging in for the first time. The user name and password cannot exceed 20 characters.

End User License Agreement (EULA)

The first time you launch the DME you will need to page down and click on

Accept EULA

.

This means that you accept the end user license agreement for the VBrick software. The application will not run if you decline to accept the EULA.

© 2014 VBrick Systems, Inc.

Getting Started

Figure 14. VBrick EULA

DME Registration

Note If you have purchased a hardware DME, it will come pre-registered from the factory and you do not have to complete the registration steps described in this section.

These steps below are for software-only DMEs only.

After accepting the EULA the registration splash page is automatically displayed with informational data. When the following page is displayed click

Next

to display the DME

Registration page. You will need to register your DME with VBrick before you can run the application.

DME Admin Guide 23

24

Figure 15. DME Registration Page

To register the DME you will need (1) the MAC address of the DME machine; (2) the serial number for future support, and (3) a license file. The MAC address is prefilled on the

Registration Page (see above); the serial number and license file are available using the

"License Activation" letter you received with your order. (After you get the license file you

will copy and paste the entire contents into the text box shown in Table 15.)

To get a license file and register your DME:

1. Contact VBrick Support to obtain the License files needed for the type of DME and features purchased.

2. Click on the green link for information on how to contact support.

3. When prompted, browse to a folder where you will save the .lic license file (once received from support).

4. Open the .lic file in Notepad and copy the entire contents. Then go back to the

Registration Page and paste the contents into the license text box.

5. Enter the serial number from the sticker in the serial number text box.

6. Then click

Finish Registration

and you are done.

Using Apply, Revert, and Default

Depending on screen resolution, it may be necessary to scroll down the page to see additional information and fields. The

Apply

,

Revert

and

Default

buttons however, are always shown at the bottom of the page when appropriate. You may also see

Refresh

,

Reset Counters

, and other buttons depending on what page you are on.

© 2014 VBrick Systems, Inc.

Getting Started

Apply

Revert

Default

Applies the changes made on the screen to the appliance. Each configuration page has an

Apply

button. You must click

Apply

before you exit the page; otherwise your changes will be lost.

Aborts all changes made on the screen and returns to the values that were present prior to any changes. The

Revert

button restores the values that were present prior to the last "apply."

Returns to the default settings for all parameters on the page. You must still click

Apply

for these default settings to take effect.

Resetting the System

A System Reset resets (i.e. reboots) the appliance. It does not change, save, or reset any configuration parameters.

To reset the DME:

1. Navigate to the Maintenance > Maintenance page.

2. Click the

System Reset

button.

Note Some changes to the configuration will initiate an automatic reset. When this happens, wait approximately 60 seconds, then refresh the page and log back in with your user name and password.

Help

A link to the online help system is available from the Configuration Menu on the left side of the VBAdmin page. This help system has a powerful full-text search engine that can quickly find the information you need. You may wish to take a few minutes to familiarize yourself with the help system. It can save time when tying to find information about DME parameters or options. When using VBAdmin, click on the question mark hyperlink in the upper-right

DME Admin Guide 25

corner of each page to get context-sensitive help for that page. Be aware that you must have an

Internet connection to see the online help.

Figure 16. DME Online Help

Home Page

The DME "Home" page (Figure 17) has the Configuration Menu on the left and a read-only snapshot showing the health of the system on the right. Within the Configuration Menu, the

System Configuration

pages let you access all configurable DME parameters; the

Monitor

pages show important status information. The Configuration Menu also lets you log out or get online help. The read-only snapshot fields on the right side of the home page are explained below.

Note Be aware that the VBAdmin pages (including the home page) are not automatically refreshed. To update the page with the latest information, use the refresh or reload button on your browser.

26 © 2014 VBrick Systems, Inc.

Getting Started

Figure 17. DME Home Page

Model Number

Circled above in Figure 17. See Server Models on page 3 for

more about DME models.

Host Name Circled above in Figure 17. The DME Host Name is defined

on System Configuration > Network page.

Day, date, and time ( hh:mm:ss

) the server was last reset.

Status

Current Time on Server

Up Time

System Time (as set on System Configuration > General page.

Aggregate up time since the last server reset.

Application Code Revision DME software code revision currently installed.

RTMP Server Version RTMP server software code revision.

OS Registration Number

RTP CPU Load

RTMP CPU Load

Total CPU Load

OS registration number.

Current processing load on RTP server.

Current processing load on RTMP server.

Total CPU load as a percentage of available resource.

Current # of Connections Total number of clients currently connected.

Current Throughput Current throughput in bits/sec.

Multi Protocol Connections

Count

Current number of input and output multi protocol connections.

Multi Protocol Max Count Maximum number of multi protocol connections (configured

on System Configuration > Streaming page).

RTP Connections Count Current number of input RTP connections.

DME Admin Guide 27

RTP Connections Max

Count

Disk Usage System

Disk Usage Content iSCSI Usage

Disable Server

IP Address

Maximum number of RTP connections (configured on

System Configuration > Streaming page).

Total megabytes used and available for DME system resources.

Total megabytes used and available for DME content.

Total megabytes used and available on iSCSI device ( if enabled).

Use this button to quickly terminate all connections. The

"Server is running" message will be replaced with "Server is idle."

The DME's IP address is shown in the lower right corner.

Configuration Menu

The DME Configuration Menu on the left side of the VBAdmin page provides access to all configurable DME parameters. Use the (plus and minus) tree controls to expand or collapse the menu. Click on any item in the menu to display the corresponding configuration page.

Note that the DME is a reflector and always sends what is received. For this reason, there are no video or audio configuration fields on the DME pages nor do the destination pages let you select different video and audio rates.

28 © 2014 VBrick Systems, Inc.

Getting Started

Table 7. Configuration Menu Options

Home Page

System Configuration

SAP Configuration

Input Configuration

Output Configuration

User Configuration

Displays a snapshot of important status indicators including software version and the current number of client connections.

Provides access to configurable system parameters such as Network, Streaming and Caching.

Allows configuration of announcements of DME capabilities and streams

Lets you configure input stream types.

Lets you configure output stream types.

Lets you configure the DME user name and password and the announce settings that let you push streams into the DME.

VC Gateway Configuration

Explains how to configure the DME as a video conferencing gateway.

Logging

Lets you enable and configure the Access History

and the Error Log.

Monitor The Monitor pages show status information for

users and relays as well as the Access History and the Error Log.

Maintenance

Diagnostics

Log Out

Help

Provides access to system maintenance options including Shutdown and Reset.

Explains how to run diagnostics when troubleshooting VC Gateway issues.

Logs out the current user and displays the Login.

VBAdmin automatically times out and displays the

Login page after 20 minutes with no activity.

Displays the online help system. You can also click the question mark (?) icon on any page to go directly to the help for that page. You will need an

Internet connection to display the online help.

VBDirectory

VBDirectory is VBrick management application that discovers and displays all VBrick devices (including DMEs) connected to your network. It shows the

Name

(as DME and MAC

Address),

IP Address

, and

Model

(see Table 8) for each DME on your network. VBDirectory

is an easy way to connect to the management pages for the DME or other VBrick devices.

The VBDirectory application is available on the VBrick Downloads page for new customers and is automatically installed when you perform an upgrade. Be aware that you will need

VBDirectory v5.3 or higher to discover the DMEs on your network. Click on the

Upgrade

button

to launch the VBDMEDownload upgrade tool. See Software Upgrade on page 151 for more

about upgrading your software.

DME Admin Guide 29

Figure 18. VBDirectory

Table 8. DME Models

Type Model Recommended Concurrent Users

DME

DME

DME

BPS 7530

XPS 7550

HPS 7550

50–100

1000 or less

1000 or more

Configuration Using Secure Shell (SSH) or a Console

It is recommended that you use Secure Shell (SSH) or a Console to perform basic configuration tasks such as configuring your network before you access the user interface of your DME. To use the SSH interface, login to the DME using PuTTY or a similar Telnet/

SSH client (default administrator login name and password: admin

| admin

). The

Configure

Network

option (see below) lets you configure for DHCP or set a static address (including

IPaddress

,

Subnet Mask

, and

Gateway

), for example. SSH is enabled by default on the System

Configuration > Security page. Each configuration option is described in the Table below.

30 © 2014 VBrick Systems, Inc.

Getting Started

Configure Network

Set Hostname

Clear DNS

Reset to Default Settings

Reset to Factory Default

Settings

Show Network

Configuration

Reboot Device with Disk

Check

Reboot Device

Shutdown Device

Exit

Used to quickly configure your network and includes the ability to configure for DHCP or static address and designate an IP address, Subnet Mask, and Gateway. This is the same ability that is included on the System Configuration >

Network screen on the DME. This is useful to set your IP address on your DME before you begin using your appliance.

The DME Host Name may also be defined on System

Configuration > Network page. It will display in the banner

graphic in the top right area of all DME configuration pages and defaults to DME <Mac_Address> which is a hardware address unique to each node of a network. The DME

Hostname also identifies the appliance to various network applications including DHCP and the VBDirectory management application.

If the DNS entries are not reachable, the device may respond sluggishly. Clearing the DNS entries will alleviate the situation.

This task resets most settings except for network settings and passwords to their default settings. The same task may be executed from the System Configuration > Manage

Configuration form in the DME.

This task resets ALL settings including network and passwords to factory defaults. Use with caution. The same task maybe be executed from the System Configuration >

Manage Configuration form in the DME.

This task will show your entire network configuration including your IP address, Subnet Mask, Gateway, DNS1, and

DNS2 settings.

If the DME is shut down improperly, the disk may need to be checked to verify and recover any bad sectors. Use this option to do so.

Reboots the device without running a check disk.

A graceful shutdown and power off that will require human intervention to power the device back on.

Exits the session.

DME Admin Guide 31

32 © 2014 VBrick Systems, Inc.

Chapter 4

Configuring DME Streams

Topics in this chapter

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

DME Input Streams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

DME Output Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Overview

The diagram in Figure 19 shows the most common input and output streams supported by the

DME. The DME Input Streams shown on the left in the diagram are live inputs from a

VBrick encoder or streams from another live source—these streams can be inputs to either

the RTP server or to the Multi Protocol server in the DME. The DME Output Streams on the

right may include live streams as well as stored streams from any of the three (RTP, Multi

Protocol, HTTP) onboard VOD servers. Live output streams are reflected from the RTP server or the Multi Protocol server. For an important conceptual overview of the DME,

please read Planning and Preparation on page 15.

For both Input and Output cases the numbering reflects the general priority of the various

streams. For example, other factors being equal RTMP push in (In-1) is the preferred method for delivering streams into the DME. The alternate mechanisms may be required, however, based on a number of factors as follows:

1. Ability of the source to deliver a stream by a given protocol.

2. Ability of the firewalls to manage delivery of the stream via the given protocol.

3. Specific requirements of the stream. Prominent examples of these requirements are (1) closed captioning which cannot be transported via RTMP within the VBrick ecosystem; and (2) KLV metadata which can only be transported via Transport Stream in the VBrick ecosystem.

Tip: Click an input or output method on the image map below (e.g. In-8 or Out-3)

to view a step-by-step description of how to configure that method.

DME Admin Guide 33

Figure 19. Supported Input/Output Streams

Note The VBrick H.264 Appliance Admin Guide has complete configuration details for the

H.264 encoder. Please refer to this document when configuring the DME. This document is included with the DME documentation on the VBrick website.

Typical Use Cases

Input Streams

In-1 < Push (RTMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

In-2 < RTP Auto Unicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

In-3 < RTP Auto Unicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

In-4 < Unicast/Multicast Transport Streams In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

In-5 < Pull (RTMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

In-6 < Pull (RTSP). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

In-7 < Pull Transport Stream using RTSP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

In-8 < Unicast/Multicast RTP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Output Streams

Out-1 > Serve (RTMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

34 © 2014 VBrick Systems, Inc.

Configuring DME Streams

Out-2 > Serve TS via RTSP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Out-3 > Serve (RTP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Out-4 > Serve (RTP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Out-5 > Push TS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Out-6 > Create HLS (for iPod, iPhone/iPad) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Out-7 > Relay (Unicast/Multicast) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Out-8 > Create HDS (for Flash) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Out-9 > Push (RTMP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Out-10 > Push RTP via RTSP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Out-11 > Push RTP via RTSP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Out-12 > Serve (.wmv, HLS, HDS, other). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

DME Listener Ports

The following table shows the listeners that are configured by default on the DME. They are used in differing use case scenarios as shown below.

Table 9. DME Listener Ports

DME Port Protocol Description

554 RTSP Auto Unicast Announce (UDP/TCP)

Where Used

In-3 < RTP Auto Unicast

5544

1935

RTSP Auto Unicast Announce (TCP)

RTMP Push from a Flash encoder, for example a VBrick encoder or an Adobe FMLE.

In-2 < RTP Auto Unicast

In-1 < Push (RTMP)

DME Input Streams

In-1 < Push (RTMP)

This is the preferred method for providing stream input to the DME. In this scenario the

DME input is a live stream push from an RTMP transmitter. Common examples of sources that produce the RTMP live stream push include H.264 encoders, VB7000 v3.1 or higher,

VB9000, another DME, and a Flash Media Live Encoder (FMLE). Since no configuration on the DME is required for this input mode, the stream name is derived from the RTMP stream name on the source. This stream name is used for redistributing the stream to various outputs.

Note If you wish to redistribute the stream using Unannounced RTP (Out-7), or using

Served RTP from the RTP Server (Out-4), or Push RTP via RTSP from the RTP

Server (out-11) an internal RTP Push (Out-10) must be configured.

DME Admin Guide 35

Figure 20. Encoder RTMP Push to DME

36 © 2014 VBrick Systems, Inc.

Configuring DME Streams

To configure a Push (RTMP) input:

Objective: This use case allows the DME to receive a live stream from an RTMP push source. The source can be an FMLE, a VBrick encoder, or another DME. If you are pushing from a VBrick encoder go to "When sending a stream from a VBrick encoder." If you are pushing from another DME go to "When sending a stream from another DME." If you are using a FMLE, please refer to the FMLE documentation for help pushing to a

Flash Media Server.

When sending a stream from a VBrick encoder:

1. In the encoder, set the desired Audio/Video configuration for frame rate, resolution, video and audio rate, sampling frequency etc.

2. Select a stream to send, set the stream type to RTMP, and select the streams you want to send to the DME (including audio, video, or both).

3. Select a transmitter for the selected stream and setup the information to send the stream out to the DME. From Stream Select, select the RTMP stream to be used for this transmitter. Enter either the IP address of the DME or DNS host name. The destination port is 1935 by default unless the administrator changed it on the DME. Do not use the hostname of the DME unless the DME hostname is registered via DNS.

Enter the application name in the DME. It can be live

, vbrick

, vbApp

, vod

, or just vb

.

Enter a unique string name for the RTMP Stream. You need to make sure no other stream (in the destination DME) is using the same stream name. Also enter the user name and password for the DME to receive the stream if authentication is enabled. You can get this information from the administrator who configured the DME. By default, the username and password are broadcast

/ broadcast

.

4. Enable the stream to be sent to the DME.

When sending a stream from another DME:

1. In the DME, launch the management interface, log in, and go to System Configuration

> Flash Push Settings. Find an open slot from the 25 possible slots, enter the server IP address or DNS host name, and enter the port (1935 is the default port for RTMP). The port number is required. You also need an entry for Application name for the destination. If the destination is another DME, most likely the name would be live

.

Enter the destination publishing point name. In the stream name field, enter the name of the stream that exists on the local DME that you want to push out. The

Target Name

is optional and is the synonymous with the publishing point name. The other fields like

Emulate

,

swfURL

, and

pageURL

are optional and are only needed if the destination server requires special value to be inserted for them. They are not required for a destination DME. The DME push component currently emulates a FMLE v3.0. If a different emulation string is required, enter it here. This is not required for a destination

DME. If security is enabled on the destination server you will need the user name and password so enter the appropriate values here.

2. This stream can now be redistributed by the DME.

In-2 < RTP Auto Unicast

From a source perspective, these two mechanisms are very similar. The only major difference is whether the stream is sent to the RTP Server or the Multi-protocol server. This is determined by DME port that the stream is sent to. In general, In-2 is preferred to In-3. The only situation where In-3 should be used is if the UDP protocol is required. since IN-2 does

DME Admin Guide 37

38 not support UDP. Note that depending on the mechanism used, and the output protocols required, manual configuration of In-6 or Out-10 is needed so the stream can pass between the two servers.

This use case is commonly used to publish streams to the DME from VB7000 encoders running v3.0 or earlier software. These early versions of the VBrick appliance did not support

RTMP, hence the preferred mechanism of RTMP Push (IN-1) is not available. In this scenario the input is sourced from an Auto Unicast transmitter on a VBrick 7000/9000 Series

(H.264) encoder. Auto Unicast is a transmitter mode that allows the VBrick encoder to

"automatically" establish and maintain a connection with a streaming server. The stream is pushed to a configured publishing point location on the DME to which external clients can connect to retrieve the stream. For example, you can place a VBrick encoder inside a private network and configure it to Auto Unicast to a DME. External clients will then connect to the

DME server via the Internet. Auto Unicast uses RTSP to control the session. It establishes a connection with the streaming server, negotiates ports, and begins streaming to the server.

Once established, the encoder will push this stream to the DME until the session is terminated (typically by disabling the transmitter).

In the case of both In-2 and In-3, the Auto Unicast transmitter can be configured to send a

UDP stream or a TCP stream. The key difference is that a TCP stream provides guaranteed delivery and therefore adds additional overhead; UDP does not and lost UDP packets are not retransmitted. If overhead is not a factor, TCP is recommended. See the "Auto Unicast

Mode" topic in the H.264 Encoder Appliance Admin Guide for more information. In addition, please keep the following points in mind when configuring this input method:

• If using UDP (IN-3), the DME chooses the audio and video ports. The default DME

Auto Unicast Destination Port = 554.

• If using In-3 or In-2 and Flash Server Authentication is enabled on the DME Security page, you will need to configure an Auto Unicast Destination Username and Password.

• This input method has the desirable characteristic that no input configuration is required on the DME so the stream name is generated by the stream configuration parameters on the source side. This name must be unique in the DME. derived from two encoder parameters which must be configured to be consistent. One of these is the sdp file name.

The second name source is the incoming program name. In some cases, multiple streams with different bit rates are to be sent to the DME. In these cases, the unique program names are preserved using the Announce Session Name Override parameter to override the common program name.

© 2014 VBrick Systems, Inc.

Configuring DME Streams

Figure 21. Encoder Auto Unicast Listener

To configure an RTSP Announce (RTP) input:

Objective: Send a unicast set of streams via Auto Unicast to the DME as input. RTP streams can be generated either by an encoder or another DME, and the corresponding

SDP file describes the RTP stream(s). Configure your encoder as follows:

1. Set the desired Audio/Video configuration for frame rate, resolution, video and audio rate, sampling frequency etc.

2. Select a stream to send, set the stream type to RTP, and select the streams you want to send to the DME (including audio, video, or both).

3. Select a transmitter to use for the selected stream and setup the information to send the stream out to the DME. Select either auto-unicast UDP or auto-unicast TCP. If transmitting to the Multi Protocol server, only TCP may be used. The destination port, must be the Multi-Protocol or the RTP Server port as configured on the DME. The destination of the stream is the IP address or hostname of the target DME. Do not use the hostname of the DME unless it is registered via DNS. Also enter the user name and password of the DME to receive the stream if using In-3 or if required and using In-3.

By default, the username and password are broadcast

/ broadcast

but may have been changed by the DME administrator.

4. Configure the DME stream name by setting the Program name, sdp file name, and

Announce Session Override as required per the discussion above.

5. Enable the stream to be sent to the DME.

DME Admin Guide 39

40

Figure 22. Encoder Auto Unicast Listener

In-3 < RTP Auto Unicast

See following text In-2 < RTP Auto Unicast.

In-4 < Unicast/Multicast Transport Streams In

This is the preferred method for providing stream input to the DME when Transport Stream is required. Transport Stream is required in cases where transport of metadata such as KLV is required, since no other protocol is capable of transporting this metadata. In this scenario the

DME input is a live stream push from a Transport Stream transmitter. Common examples of sources capable of producing a live Transport Stream push include a VB6000/7000/9000

VBrick MPEG-2/H.264

encoder or another DME.

Note If you wish to redistribute the stream using Unannounced RTP (Out-7), Served RTP from the RTP Server (Out-4), or Push RTP via RTSP from the RTP Server (out-11) an internal RTP Push (Out-10) must be configured.

© 2014 VBrick Systems, Inc.

Configuring DME Streams

To configure a Unicast/Multicast (TS) input:

Objective: Use this option if you need to tune into an MPEG2TS carrying an H.264 load and need to distribute it further. The transport stream is either a multicast on your network or a unicast directed to this DME from a source. If multicast, you will need to know the IP address and port the multicast is being sent on. If unicast to you, you will need to know which port number it being sent to.

1. Fill in the multicast address and port if multicast, or enter 127.0.0.1 and port if unicast.

For source specific multicasts, enter the multicast address followed by a colon and then the source address. Example: 232.1.1.1:172.22.2.166

2. Enter the port number. The port number needs to be unique for all unicast sources specified in the list.

3. Enter a name for this incoming transport stream. You can also use the default name, or create another meaningful name for this stream. The name is used to distribute the stream to other destinations and stream types.

4. Enable the location and click Apply. The status will indicate "

Receiving

" if the stream is found and being received. It will display "

Waiting For Stream

" if the stream is not detected. For multicast sources, the multicast address and port combination must be unique. For unicast sources, the port number must be unique (i.e. the same port cannot be used for multiple unicast receive.)

TS Pull supports true pass-through without any parsing of the stream so the stream and all of its contents including KLV (if any) can be passed through to other TS destinations. See

use case Out-5 > Push TS for more information.

The incoming name specified in the user interface can now also be used to stream the incoming transport stream as RTMP, RTP (via RTSP), or HLS. Once configured, you can

see details about this stream in the Monitor > Multi Protocol Connections page.

In-5 < Pull (RTMP)

This scenario is the same as method In-6 Pull RTSP/RTP above except that it is an RTMP pull from an RTMP server (for example Wowza, FMS, QuickTime) or from another DME. In this case the stream is pulled by the DME from a source with a URL similar to: rtmp:// server:port/application/publishing_point

. If pulling from another DME it is convenient to make the stream name on this DME the same as the publishing point on the source DME in order to retain the same stream name throughout the ecosystem. The following example shows the original RTMP URL from a VBOSS URL and the parameters on the Flash Pull

Setting page from which the URL is derived: rtmp://fml.2D84.edgecastcdn.net/202D84/fls/2D84

Server:Port

Application

Publishing Point

Stream Name fml.2D84.edgecastcdn.net

202D84/fls

2D84 myprogram

Note that if you wish to redistribute the stream using Unannounced RTP (Out-7) Served

RTP from the RTP Server (Out-4), or Push RTP via RTSP from the RTP Server (out-11) an internal RTP Push (Out-10) will need to be configured

DME Admin Guide 41

.

To configure a Pull (RTMP) input:

Objective: Pull a RTMP stream from another DME or a Flash server to redistribute.

1. In the DME, launch the management interface, log in, and go to System Configuration

> Flash Pull Settings. You will need to pull an RTMP stream from a source, so find an open slot from the 25 possible slots and select RTMP as the type. Enter the server IP address or DNS host name, and enter the port if not already 1935 (default port for

RTMP). Since this is RTMP an entry in Application is required. Enter the source RTMP server application name, for example live

. Also fill in the publishing point name, which identifies the resource on the remote system that we need to pull from. Enter a unique stream name to be used for redistributing the stream within the DME. In most cases there will be no need for the user name and password since this is a pull. This stream can now be redistributed in several ways by the DME. It can also act as a source for

uses case Out-4 > Serve (RTP) and Out-11 > Push RTP via RTSP.

In-6 < Pull (RTSP)

In this scenario the input originates from an RTSP/RTP external source. Examples are the server on an H.264 encoder another DME, a

Wowza, QuickTime, or Darwin server. The stream is pulled (via the

RTSP session protocol) from the external source. The DME can pull from various outside sources (e.g. from another DME, or from a

Wowza, QuickTime, or Darwin server). An RTSP Pull is configured in the DME on the System Configuration > Flash Pull Settings page.

The stream packets are received as RTP and used as a source for any of the output protocols.

Another use of this protocol is to pull the live stream from the DME's RTP server and deliver it as a source for one of the Multi Protocol server’s output protocols or as a source for transrating.

42 © 2014 VBrick Systems, Inc.

Configuring DME Streams

Figure 23. Flash/RTSP Pull

Type

Server:Port

• RTSP – pull the RTSP stream into the DME. See In-6 < Pull

(RTSP).

• RTMP – pull the RTMP stream into the DME. See In-5 < Pull

(RTMP).

The IP address and port number of the VBrick server. Enter a port number only if you are not using the default RTMP port (1935) or the default RTSP port (554).

Application Only required if you are pulling RTMP from an RTMP server such as

another DME or an FMS. See In-5 < Pull (RTMP). This string is

defined by the source.

Publishing Point This is the

Resource Name

on the Program Configuration > Servers page on the encoder.

Stream Name

User Name

User-friendly name displayed on the DME. Used, for example, to simplify cryptic publishing point names coming from a CDN. This name becomes the incoming stream name the DME uses to distribute the stream in multiple ways.

If the incoming stream requires authentication, enter the user name and password.

DME Admin Guide 43

44

Password

Use RTCP

Status

If the incoming stream requires authentication, enter the user name and password.

Lets you use RTCP sync reports for the incoming stream. If you know your source does not produce RTCP reports, uncheck this box.

Displays the high-level status (Disabled | Connected | Receiving) of the incoming stream.

To configure a Pull (RTSP) input:

Objective: Pull an RTSP unicast RTP stream(s) from a source as input to the DME. If the stream is coming from an external server, like a VBrick H264 encoder, follow steps 1 and 2, and 3. Otherwise the stream should be active and available either from another DME, or internally from the same DME, and you can start at Step 4.

1. In the encoder, set the desired Audio/Video configuration for frame rate, resolution, video and audio rate, sampling frequency etc.

2. In the encoder, select a stream to send, set the stream type to RTP, and select the streams you want to send to the DME (including audio, video, or both).

3. In the encoder, select the resource name of the stream to be used in the server component of the encoder. The default name for streams served from the encoder is vbStream1S1

. You can change the name to anything you want. You also need to enable the server.

4. In the DME, launch the management interface, log in, and go to System Configuration

> Flash/RTSP Pull Settings. You will need to pull an RTSP stream from a source, so find an open slot from the 25 possible slots and select RTSP as the type. Enter the server IP address or DNS host name, and enter the port if not already 554 (default port for RTSP). Since this is RTSP, no entry for Application is required. Enter the publishing point name like vbStream1S1

. If you are pulling a stream specified in use case In-8 <

Unicast/Multicast RTP or In-3 < RTP Auto Unicast, enter the sdp filename used when

creating the stream. In most cases there will no need for the user name and password since this is a pull. Note: the pull uses RTSP Interleaved streams delivered by TCP only so make sure this is supported on the source.

5. If you know the RTSP source does not generate RTCP reports, or the RTCP reports do not have accurate time sync information, uncheck the

Use RTCP

box and the DME will not look for RTCP reports or ignore those coming in. Note: RTCP reports help to enable audio and video sync. If unchecked, there will be no way to "re-sync" the stream once it has started. Uncheck only if you have knowledge of the source and the RTCP reports it sends.

6. Enable the stream and apply, and the DME will start acquiring the stream. This stream can now be redistributed by the DME.

In-7 < Pull Transport Stream using RTSP

This protocol is not supported in DME 3.x.

In-8 < Unicast/Multicast RTP

This input is sourced from a unicast or multicast transmitter on a VBrick 7000/9000 Series

(H.264) encoder or equivalent source. In this scenario, a transmitter is configured to send a

© 2014 VBrick Systems, Inc.

Configuring DME Streams live unicast stream (e.g.

172.xxx.xxx.xxx

) to the DME or a live multicast stream (e.g.

239.xxx.xxx.xxx

) to a multicast address. For both of these options you will need to manually fetch

the SDP file from the encoder and FTP it to the root folder (or a subfolder) on the DME. The SDP file has information describing the stream such as profile, bit rate, addressing, and transmission method.

Note • In order to redistribute a stream via any of the mechanisms sourced from a multiprotocol server, an RTSP pull (In-6) must be configured between the RTP streaming server and the multi-protocol server

• Similarly, if this input mechanism is used to source a transrating operation, the

RTSP Pull must be set up. Announcements need manual configuration if this input mechanism is used

To stream from a VBrick encoder:

1. Launch the VBAdmin page for the encoder.

2. Go to the Program Configuration > Transmitters page.

3. Click on the

SDP File URL

button.

4. FTP the SDP file to the root folder (or a subfolder) on the DME.

When configuring the encoder, the default Video Port is 4444; the default encoder Audio

Port is 4644. These ports must be unique for each stream and must match those configured in the DME. The DME administrator must ensure that all SDP files have unique port numbers and that no port numbers are duplicated across all SDP files. Subsequently the encoder must also be configured to transmit on unique ports when streaming to the DME.

Figure 24. Encoder Unicast/Multicast Configuration

DME Admin Guide 45

To configure a Unicast/Multicast input:

Objective: Send a unicast or multicast RTP set of streams to the DME as input. RTP streams can be generated either by an encoder or another DME, and the corresponding

SDP file describes the RTP stream(s). Configure your encoder (v3.0 or higher) as follows:

1. Set the desired Audio/Video configuration for frame rate, resolution, video and audio rate, sampling frequency etc.

2. Select a stream to send, and set the stream type to be RTP, and select the streams you want to sent to the DME (including audio, video, or both).

3. Select a transmitter to use for selected stream and setup the Destination Port parameter to send the stream out of a port that is not already used on the DME. This is a manual process to determine which other streams are on the DME. Usually, choosing a high number in the 20000 range is likely safe and will not conflict. Use an even number, then use the next sequential even number for the next stream (audio or video), for example

Video Port 20100, Audio Port 20102.

4. Enable the stream to be sent to the DME either as a unicast or multicast out. The

Destination IP address determines whether it is a unicast or multicast.

5. Extract the SDP stream once the settings above are applied and active. Place the SDP file in DME via FTP in the root folder. Make sure the SDP filename you use is unique when placing the file in the DME. This stream can now be redistributed by the DME.

DME Output Streams

The DME supports the output methods described on the following pages. There are different output scenarios available depending on whether the stream originates from the

RTP server, the RTMP server, or the HTTP server. This is illustrated in the diagram in

Figure 19. Please refer to this diagram when configuring DME output streams.

Out-1 > Serve (RTMP)

Live streams content can be served via unicast RTMP. Note that the port generally will not have to be defined in the URL provided the default port 1935 is used. You can play the stream in a Flash player using a URL similar to the following: rtmp://server:port/application/publishing_point

For live streams the publishing point is the stream name and the application is typically "live".

For stored the publishing point is the file name and the application is "vod". No explicit configuration of this option is required.

To configure a Serve (RTMP) output:

Objective: This use case is typically used to allow Flash clients using RTMP streaming to acquire a live stream or a VOD stream.

1. Enter the RTMP URL information in the embedded Flash client with an application of live

or vod

depending on the type of content served.

46 © 2014 VBrick Systems, Inc.

Configuring DME Streams

Out-2 > Serve TS via RTSP

You can serve available live streams and stored files via unicast RTSP/TS. Note that the port must be explicitly identified in the URL. The port required is the Multi Protocol server port - default 5544.

Live

No explicit configuration of this option is required. All live streams in Multi-Protocol server are available for serving via an appropriate URL. Generally only Transport streams containing H.264 video are supported, but for transport streams which are brought into the

DME using a transport stream protocol and are transmitted using transport stream protocol, any codec will be supported. This allows support of MPEG-2 video in transport stream for this use case. There are number of possible formats for the URLs. The recommended URL format includes " ts

" in the URL path: rtsp://<dme_ip_address:port>/ts/<stream_name>

Alternate URLs are available for backward compatibility. These URLS are not recommended. If the stream has been provided using a TS push only (In-4) the following

URLs are acceptable: rtsp://<dme_ip_address:port>/<stream_name>_ts rtsp://<dme_ip_address:port>/ts/<stream_name>_ts rtsp://<dme_ip_address:port><stream_name>?ForceTS

rtsp://<dme_ip_address:port><stream_name>_ts>?ForceTS

rtsp://<dme_ip_address:port>/ts/<stream_name>?ForceTS

rtsp://<dme_ip_address:port>/ts/<stream_name>_ts>?ForceTS

If the stream has been provided using another Input use cases, the following URLs are legal: rtsp://<dme_ip_address:port><stream_name>?ForceTS

rtsp://<dme_ip_address:port>/ts/<stream_name>?ForceTS

Stored

ts/mpg, mov, or mp4 files can be served using unicast RTSP/TS. Only files containing H.264 content video are supported. The recommended URL format for this use case is as follows.

Alternate URLs are available but not recommended.

rtsp://<dme_ip_address:port>/vodts/<filename.extension>

If the file is a transport stream file then the following formats can be used: rtsp://<dme_ip_address:port>/vod/<filename.extension> rtsp://<dme_ip_address:port>/vod/<filename.extension>?ForceTS

rtsp://<dme_ip_address:port>/vodts/<filename.extension>?ForceTS

If the file is a mov or mp4 file then the following format are acceptable: rtsp://<dme_ip_address:port>/vod/<filename.extension>?ForceTS

rtsp://<dme_ip_address:port>/vodts/<filename.extension>?ForceTS

You can serve an available stream via unicast RTSP with the resulting URL as follows

(append "

_ts

" to the URL path).

DME Admin Guide 47

48 rtsp://<dme_ip_address>:5544/<stream_name>_ts

Out-3 > Serve (RTP)

The Multi-Protocol server on the DME serves live or stored content using the RTSP/RTP protocol. You can play the stream in StreamPlayer, QuickTime, or VLC using a URL similar to this: rtsp://server:port/<publishing_point>

Since the Multi-Protocol server uses a non-standard RTSP port (default 5544), the port number is required in the URL. There are two use cases for serving RTSP. Out-4 should be used for optimal stream stability, but if many simultaneous users are expected, the equivalent

Out-3 is preferred. There are three possible protocols used for RTP serving: UDP; TCP using RTSP interleaved; TCP using HTTP tunneling. Out-4 supports all three of these options while Out-3 does not support HTTP tunneling. This difference may determine which

RTSP/RTP server to utilize.

Live

This output option requires no explicit configuration on the DME but is available for all live content present on the Multi-Protocol server, whether brought directly into the server or

Pulled from the RTP server using an internal In-6. An example of a live publishing point is: rtsp://<dme_ip_address:port>/<streamname>

Stored

There are two options for serving RTSP. Out-4 is used if the VOD content contains

MPEG-4 Part2 video or PCM audio. Since Out-4 is more generally applicable it is recommended for this use case. Stored content is accessed using the filename of the content.

Examples of stored URLs are: rtsp://<dme_ip_address:port>/filename.mov

rtsp://<dme_ip_address:port>/filename.mp4

The RTP server on the DME serves RTP files. Play the stream in StreamPlayer, QuickTime, or VLC using a URL similar to this: rtsp://server:port/publishing_point.sdp

Since the Multi Protocol RTP server uses an non-standard RTSP port – default 5544 – normally the port must be explicitly included in the URL.

To configure a Serve (RTP) output:

Objective: This use case explains how a stream available on the Multi Protocol server is served to clients that support RTSP streams. Further, this server is commonly used for delivering VOD content.

From a client that supports RTSP RTP streams, enter the RTSP URL, typically: rtsp:// DME_ip_address:5544/streamname

Out-4 > Serve (RTP)

The RTP server on the DME serves live or stored content using the RTSP/RTP protocol.

You can play the stream in StreamPlayer, QuickTime, or VLC using a URL similar to this:

© 2014 VBrick Systems, Inc.

Configuring DME Streams rtsp://server:port/<publishing_point>

Normally the default port 554 is assigned to the RTSP/RTP server, so the port number is optional in the URL. If an alternate port is assigned to the RTSP/RTP server, then the port number must be entered. There are two use cases for serving RTSP. Out-4 should be used for optimal stream stability, but if many simultaneous users are expected, the equivalent Out-3 is preferred. There are three possible protocols used for RTP serving: UDP; TCP using RTSP interleaved; TCP using HTTP tunneling. Out-4 supports all three of these options while

Out-3 does not support HTTP tunneling. This difference may affect which RTSP/RTP server to use.

Live

Note that this output option requires no explicit configuration on the DME but is available for all live content present on the RTP streaming server, whether brought directly into the

RTP server or Pushed from the Multi Protocol server using an internal Out-10. A live publishing point includes the ".sdp" extension in the publishing point name so an example of a live publishing point is: rtsp://<dme_ip_address>/my_streamname.sdp

Stored

There are two options for serving RTSP. Out-4 must be used if the VOD content contains

MPEG-4 Part2 video or PCM audio. Stored content is accessed using the filename of the content. Examples of stored URLs are: rtsp://<dme_ip_address>/filename.mov

rtsp://<dme_ip_address>/filename.mp4

To configure a Serve (RTP) output:

Objective: This use case explains how to allow a stream acquired through use case In-8 <

Unicast/Multicast RTP or In-3 < RTP Auto Unicast, or most commonly via an internal

Push form the Multi Protocol server (Out-10), to be served via an RTSP server from the

DME to clients that support RTSP streams. Additionally this server is commonly used for delivering VOD content.

1. From a client that supports RTSP RTP streams, enter the RTSP URL, typically rtsp:// dme_ip_address/streamname.sdp

where the streamname.sdp

file is the original output

SDP file name.

DME Admin Guide 49

Out-5 > Push TS

To configure a Push TS output:

Objective: This use case explains how to distribute available streams to unicast or multicast

Transport Stream destinations. Note that although any stream available to the Multi-

Protocol server can be distributed as a Transport Stream, if it is required for KLV metadata, the stream must remain in a Transport Stream container in all cases.

1. Enter the destination unicast or multicast address.

2. Enter the destination port to send the stream to.

3. Enter the name of the incoming stream you want to distribute to your destination.

4. Enable the stream and click Apply.

5. The status will indicate either "

Sending

" or "

Waiting for Stream

" if the specified input stream cannot be found.

6. You can also verify the detailed status of your outbound transport stream on the

Monitor> Multi Protocol Connections page.

50 © 2014 VBrick Systems, Inc.

Configuring DME Streams

Out-6 > Create HLS (for iPod, iPhone/iPad)

To create an HLS stream for Serving via HTTP:

Objective: This use case explains how to create an HLS (HTTP Live Streaming) stream which is essentially a set of TS files made from an input H.264 stream with a playlist, so that it can be played on Apple iPad/iPhone/iPad devices via a wireless connection. Mac

QuickTime X players (and some VLC players) can also play the stream.

The playlist generated can either be from a single input stream or multiple input streams.

Multiple streams are useful in varying bandwidth environments. If you need to create an adaptive playlist that allows the player to switch between multiple rate streams to adapt to the fluctuating bandwidth, you need to create multiple HLS output streams—all with the same Master Playlist Name.

The playlist generated can vary depending on the configuration. Since the segments must be generated on an IDR (Key Frame) boundary, the source must be producing IDR frames at a regular interval in the stream. It is helpful to know how often IDR frames are being inserted into stream from the source and it is a good idea to set a Minimum Segment

Length that is a multiple of IDR interval number. Larger segment sizes increase latency.

The default settings will create a latency of about 30 seconds (a common latency for HLS).

This is probably optimal in terms of IDR frame interval/segment sizes. You can reduce latency by forcing the incoming IDR interval to 1 and setting the minimum segment length to 1 but this will make the source, the DME, and the client work much harder than they may need to.

You can also enter the bandwidth associated with each incoming stream. The stream bandwidth is important when generating an adaptive bitrate stream with multiple streams.

Although VBrick 7000/9000 Series (H.264) encoders include the bandwidth information in the stream, some stream sources do not. You may need to provide this information (if your encoder does not) because HLS generation for adaptive bitrate streaming requires accurate bandwidth information to work properly.

1. Enter the stream name for the generated HLS stream.

2. To create an adaptive bit rate playlist, enter a unique name for your master playlist. This must be different from any incoming stream name, otherwise leave blank. When blank, the default non-adaptive playlist name created is "HLS" which is required in the playback URL. Use the same name when creating multiple HLS streams which are then all associated with the adaptive bitrate master playlist. The highest bandwidth streams should be at the top of the list of (1 to 25) HLS streams.

3. If you know your incoming stream does not have bandwidth information, enter a value

(in kbps) in the bandwidth override field for the stream. This value supersedes any value actually in the stream.

4. Playlists that are created using "rolling" means that the old segments are deleted as new segments are created for a live stream. In some applications, you may want to keep all your segments and create an ever growing playlist. This lets you create a DVR-like

DME Admin Guide 51

52 feature where users can tune in late into a live presentation, and rewind to the beginning or jump back to the present. Caution: the "appending" setting does not delete segments and may adversely impact the space available on your hard drive. You could conceivably use all remaining disk space if you leave a live stream running from the source into the

DME. Thus a built-in safeguard stops creating appending segments and switches to rolling segments after 7 days. Note: if you need to archive appending (non-rolling segmentation), the segments and playlist are available via FTP in the folder:

/HLS/ streamname

or

/MultiplePlaylistName/streamname

, only when the stream is enabled and active. When disabled, all associated playlists and segments are deleted from disk.

5. The

Playlist Length

field signals the playlist size of segments and controls the length of

DVR functionality when Type = Rolling. This field is ignored when Type = Appending.

Leave at the default (rolling) unless you have a compelling reason to change.

6. The

Minimum Segment Length

is a number (in seconds) that determines minimum size of segments that will be created. Although reducing this number reduces latency, it also creates smaller files meaning that the player will need to request new segments more frequently. Make this number a multiple (2x) of the IDR Frame Interval. For VBrick encoders, the default interval is 4, so that 8 (the default) is a recommended value.

7. Enable the stream(s) and click Apply.

8. The status will indicate "

Active

" if HLS streams are being created or "

Waiting for

Stream

" if the input stream cannot be found.

9. You can also verify the detailed status of your outbound TS stream on the Monitor >

Multi Protocol Connections page.

Out-7 > Relay (Unicast/Multicast)

Relays can be used to output RTP streams as either unicast or multicast. However, it is normally used for multicast, since pushing RTP should use OUT-10 whenever possible. As explained below, after configuring the stream source, there are two ways to configure the relay destination. You can (1) configure an Announced UDP relay where the stream is announced and transmitted via Auto Unicast (Out-11); or (2) configure an Unannounced

UDP relay where the destination device requires access to the sdp file located on the source

DME.

The use case for Auto Unicast is not recommended—use Out-11 instead, a similar use case.

Details are covered in Out-10 > Push RTP via RTSP below. If using Unannounced relay with

a unicast destination the sdp file may have to be manually copied the from the source to the destination - an error prone and inconvenient process. It is occasionally necessary to use this technique to communicate with an end device depending on firewall settings. The dominant use for the Relay configuration is to generate an RTP multicast. Typically the sdp file is accessed via HTTP. The sdp file contains all of the information needed for the client to

locate the multicast. Each of these options is explained below. See RTP Relay for more about

relays.

Note For a step-by-step procedure that explains how to configure a multicast relay in greater

detail, see Playing DME Streams on page 141.

© 2014 VBrick Systems, Inc.

Configuring DME Streams

Figure 25. RTP Relay Page

Source Settings

Every relay has one source and one or more destinations. The source is typically the

Hostname or IP address of the DME.

Source Hostname or IP Address

Mount Point

The Hostname or IP address of the DME.

The incoming stream .sdp filename.

DME Admin Guide 53

54

Request incoming stream

Wait for announce d stream(s)

This option creates an RTSP pull for an RTP stream. It is recommended that this option NOT be used. If this option is needed please use In-6 and configure an RTPS push to the RTP Server (Out-

10). Check this box to request an incoming stream from the specified

DME source. If the source is a DME server, you must specify the administrative username and password of that server.

• User Name – valid administrator name on the DME.

• Password – valid administrator password on the DME.

This is the preferred option. Check this box to wait for a stream to be announced (via Auto Unicast). The DME will start relaying when a new stream is announced on the source IP address. Under normal circumstances the Auto Unicast is a local RTP Push via RTSP (Out-10) internal to the DME

Destination Settings

As noted a relay has one source but it can have multiple destinations. Use

Add Destination

or

Remove Destination

to manage the destinations. Always click

Apply

to save your changes or the changes will be lost when you exit the page.

Hostname or IP

Address

This is the unicast or multicast destination IP address, typically an

QuickTime or Darwin server or a another DME.

Announced UDP This option is not recommended. Please use the equivalent Push RTP via RTPS (Out-10). Check this box when the stream will be announced automatically and continually via an Auto Unicast configured on the encoder. No .sdp file is required with this method.

• Mount Point – this is the .sdp file name.

• User Name – valid administrator name on the DME.

• Password – valid administrator password on the DME.

Unannounced UDP Check this box when the stream will not be announced via Auto

Unicast. The stream will be sent to the specified IP address and port number. The most feature is most commonly used for multicast stream distribution. In this use case, the most common means for a player to access this stream is by fetching the sdp file via HTTP. For unicast the only method for playback requires the inconvenient step of placing an.sdp file on the destination server so it is not recommended.

• Base Port – the port to which the stream is sent. It can be an arbitrary port. It must however be an even number and, in the case of

unicast, be a unique port number on the destination server. The Base

Port will be used to send either audio or video depending on the order of streams in the .sdp file. The first stream uses the Base

Port number; the next stream uses Base Port number + 2.

• Multicast TTL – Used to specify the number of routers the multicast stream will pass through before it stops propagating over the network. Range = 1–255. Set this for the topology of the network you are working on.

© 2014 VBrick Systems, Inc.

Configuring DME Streams

To configure a Unicast/Multicast output:

Objective: This use case describes how an existing RTP stream can be relayed as a unicast or multicast output from the DME. This allows the rebroadcast of stream acquired through

use case In-8 < Unicast/Multicast RTP or In-3 < RTP Auto Unicast or (most commonly)

through an RTP Auto Unicast (Out-10) from the Multi Protocol server. For a step-by-step

procedure that explains how to configure a multicast relay in greater detail, see Playing

DME Streams on page 141.

Announced UDP

– follow Steps 1–4, and 7.

Unannounced UDP

– follow Steps 1–6.

1. The SDP file generated for input use case In-8 < Unicast/Multicast RTP will need to be

copied, renamed, and modified when relayed to another destination. Leave the original

SDP file in place. For the remaining cases, the sdp file will be automatically generated

2. Create a new Relay in System Configuration > RTP Relay Settings by clicking on new relay.

3. Enter a relay name identifying this relay.

4. In Source Settings enter the IP address

127.0.0.1

, Select Request incoming stream.

If the input is In-8, enter the original SDP filename for mount point. In other cases, select the Target Name of the “Push RTP via RTSP”. Note that the mount point must always have a “.sdp” file extension. For In-3 or Out-10, use the stream name. If using

Announced UDP, go to Step 7.

5. Enter the multicast or unicast address or hostname to send the stream to in

Destination

Settings

. Since this is not an auto-unicast relay to another DME (Step 7) or a server that supports auto-unicast, select

Unannounced UDP

and enter the first port number used by the first stream listed in the SDP file. Subsequent streams use an incremental even number value. If this is a multicast, and needs to adhere to multicast time-to-live restrictions, enter the value in the Multicast TTL field.

6. Enable and apply the relay and stream will start to be delivered. You will need to distribute the new SDP file created in Step 1 for your destination for subsequent multicast clients to use to tune into the relay. If using Unannounced UDP you are done.

7. If you are utilizing the Auto Unicast output feature select

Announced UDP

and enter the user name and password if required by the destination device. If the input is from an Unannounced Unicast/Multicast (In-8) be sure to use the new SDP name.

Out-8 > Create HDS (for Flash)

To create an HDS stream for Serving via HTTP:

Objective: This use case explains how to create an HDS (HTTP Dynamic Streaming) stream which is essentially a set of Flash video fragments made from an input H.264 stream with a playlist, so that it can be played on Flash players via an HTTP protocol

The configuration of the HDS is equivalent to the configuration of HLS streams in Out-6 above; the same steps may be followed. The screens for configuring these options are identical.

DME Admin Guide 55

Out-9 > Push (RTMP)

In this scenario the DME functions as a live encoder that sends the stream to another RTMP

(i.e. Flash) server such as a Wowza, an FMS, or another DME. The parameters on this page are similar to those on the Flash Pull Settings page (see Figure 23 on page 43) but there are also additional fields marked with (o). These (o)ptional fields may be required at the destination device, for example by a Wowza or other Flash server. For more about these

fields, see Flash Push on page 89.

56

Figure 26. DME Flash Push

To configure a Push (RTMP) output:

Objective: This use case is similar to use case In-1 < Push (RTMP) where the stream is incoming into a DME. See In-1 < Push (RTMP) for more details.

© 2014 VBrick Systems, Inc.

Configuring DME Streams

Out-10 > Push RTP via RTSP

To push an incoming stream out via Auto Unicast:

Objective: This use case explains how to push an incoming stream via RTSP RTP Auto

Unicast to another destination. This feature is typically used to bring a TS or RTMP stream into the DME and send the stream via RTSP to the internal RTP server so that you can multicast the RTP stream via a multicast relay.

1. Enter the destination address. This is typically the loopback address (

127.0.0.1

). The port is assumed to be port 554. If not 554 enter a different port number, for example:

127.0.0.1:555

2. Enter the incoming stream name you want to publish as an RTP stream. This can be another incoming RTP, RTMP, or TS stream name.

3. Enter the target name (typically name.sdp) which then can be used to serve or relay the

RTP stream using the SDP name. Be sure the name is not already in use when pushing to this destination.

4. Most likely external destinations will require authentication. If so, enter the username and password.

5. Select Enabled and click Apply.

6. The status will indicate "

Active

" if a stream is being delivered, "

Waiting for Stream

" if the input stream cannot be found, or "

Disconnected

" if the destination cannot be written to.

7. You can also verify the detailed status of your outbound TS stream on the Monitor >

Multi Protocol Connections page.

Once the stream is being pushed to the destination, example localhost (

127.0.0.1

), it can be used to stream to more clients via RTSP, or you can setup a multicast relay to send the original incoming RTMP stream out via an RTP multicast.

Out-11 > Push RTP via RTSP

This is not a recommended configuration, Please use the equivalent Out-10 instead. It should be noted, however, that Out-11 will do RTP via RTSP Push using UDP while Out-

10 will use RTSP interleaved, a TCP protocol. The TCP protocol is recommended, but firewall considerations may require use of the UDP option. Configuration of this option is

discussed briefly under use case Out-7 > Relay (Unicast/Multicast).

Out-12 > Serve (.wmv, HLS, HDS, other)

Use this option to serve .wmv, HLS, or other files via progressive download. The DME has a built-in HTTP Progressive Download server for stored VOD files only that have been FTPed to the DME. A Progressive Download server lets you begin viewing the stream before it has

been completely downloaded. It streams all file types supported on the DME (see Table 3 on page 17) including Windows Media (.wmv), HLS (.m3u8), and HDS (f4m) files. This is the

only way to serve .wmv files from the DME. The HTTP server uses Port 80 by default but this can be changed on the System Configuration > Port Settings page. You can play the stream in an appropriate player (see Table 10) for example in a QuickTime, Flash, or HLS (iPhone) respectively using a URL similar to these: http://<ip_address>/filename.wmv

http://<ip_address>/subfolder/filename.flv

DME Admin Guide 57

58

HLS

For HLS, use the following options:

To play a live non-adaptive HLS stream when no master playlist is selected: http://<dme_ip_address>/HLS/<stream_name>/playlist.m3u8

To play a stored non-adaptive HLS stream when no master playlist has been created: http://<dme_ip_address>/<stream_name>/playlist.m3u8

To play a live or stored adaptive HLS stream and have the player specifically select one stream (normally for test purposes): http://<dme_ip_address>/<master_playlist_name>/<stream_name>/playlist.m3u8

To play a live or stored adaptive HLS stream and (typically) have the stream selected by automatic negotiation between the player and the server: http://<dme_ip_address>/<master_playlist_name>/playlist.m3u8

HDS

For live HDS, use the following options for a configured live stream.

To play a non-adaptive HDS stream when no master playlist is selected: http://<dme_ip_address>/HDS/<stream_name>/manifest.f4m

To play an adaptive HDS stream and (typically) have the specific stream selected by automatic negotiation between the player and the server: http://<dme_ip_address>/HDS/<master_playlist_name>/manifest.f4m

For stored HDS content the content must be placed in the hdsvod directory under ftproot.

Use the following URLs for playback:

To play a non-adaptive HDS stream when no master playlist is selected: http://<dme_ip_address>/hdsvod/<filename>.f4m

To play a stored adaptive HDS stream and (typically) have the specific stream selected by automatic negotiation between the player and the server: http://<dme_ip_address>/hdsvod/<filename>.f4m

Table 10. Outputs and Associated Players

DME Output Supported Players

RTP VBrick StreamPlayer, QuickTime

RTMP

WMV

Flash players (e.g. Adobe, JW, VLC, etc.)

Windows Media Player, VBrick StreamPlayer

HLS

HDS iOS devices (iPhone, iPad, iPod)

Flash players via HTTP

© 2014 VBrick Systems, Inc.

Configuring DME Streams

To configure a Serve (WMV) output:

Objective: This use case allows files to be delivered via HTTP to a destination client. Files of type .wmv (Windows Media) cannot currently be served via the DME. Files can however be delivered via HTTP progressive download. This u is not restricted to WMV files, and almost any file type can be served via HTTP.

DME Admin Guide 59

60 © 2014 VBrick Systems, Inc.

Chapter 5

System Configuration

Topics in this chapter

Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Caching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Manage Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

SSL Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

SAN/iSCSI Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Activate Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Network

DME Admin Guide 61

62

Host Name

Use this field to configure the host name shown in the banner graphic in the top right area of all DME configuration pages. The Host Name defaults to

DME<MAC_Address>

, a hardware address that uniquely identifies each node of a network. The DME Host Name also identifies

the appliance to various network applications including DHCP and the VBDirectory

management application.

IPV4 Network Interface 1

The DME supports up to four network interface (NIC) cards you can use to increase the bandwidth and throughput available to the DME. A DME with one NIC card has an overall bandwidth limitation of 1GB for all output streams. A DME with the load shared over four

NIC cards provides 4GB of bandwidth. Note that when load sharing is enabled, the primary

NIC card (IPV4 Network Interface 1) cannot use DHCP. With multiple NIC cards and load

sharing enabled all NICs will use the same IP address as the primary.

Network DHCP

IP Address

Default = Enabled. Dynamic Host Configuration Protocol. If

DHCP is enabled, the appliance gets its IP Address, Subnet Mask, and Gateway from the DHCP server. If the DHCP server supplies the DNS server address, these parameters will replace the user-entered DNS settings.

The DME is setup by default to acquire an IP address via DHCP.

If the DHCP server is not available at boot time, the DME

DHCP IP address acquisition will fail and the appliance will retry to re-acquire the address every 10 minutes. During the 10 minute retry period, the appliance uses a default IP address of

172.17.1.5

with a subnet mask of

255.255.0.0

. If you need to change the DME to use a static IP address instead of getting one from DHCP, connect the DME to the network, connect a laptop to the network, set the laptop to be on the same subnet, and give the laptop a fixed IP address of

172.17.1.6

with subnet of

255.255.0.0

. You can then go into the DME management interface (default: http://172.17.1.5:8181

) to login and give the appliance a static IP address.

This is either a static or a DHCP-enabled IPv4 address. If IPv6 is turned on for this segment of the network, this will be an autogenerated global IPv6 address. If using IPv6, use the IPV6

Address field below. Note: Although the IPv6 address is displayed, it cannot be used to manage the appliance as yet.

Subnet Mask

Gateway IP Address

Subnet mask for the DME address.

Gateway IP Address for communicating across distinct network segments.

Maximum Transmission

Unit Size

Range 500–1500 (default = 1500). The MTU is used for all network traffic from the DME and defines the largest network packet size that will be transmitted. A higher MTU brings higher bandwidth efficiency and VBrick recommends using the default.

However you may wish to reduce MTU size to meet the requirements of some networks with VPN or other security tunnels that cannot tolerate 1500 byte packets.

© 2014 VBrick Systems, Inc.

System Configuration

Configured Interface

Speed / Duplex

Detected Interface

Speed / Duplex

MAC Address

Default = Auto Detect. Use Auto Detect or manually set the bit rate and duplex setting for network devices that do not support auto negotiation. With Auto Detect the DME will automatically adjust its duplex setting and speed to match the switch or hub to which it is attached.

Read only. Displays the current connection speed and duplex setting.

The Media Access Control address is a unique identifier assigned to the DME for network communications.

Optional. Enter an IPv6 address.

IPV6 Address

IPv4 Network Interface 2–4

IPV4 Network

Interface 2-4

The DME will auto detect the number of NIC cards installed. If more than one NIC is installed, you can use the additional card(s) to increase bandwidth and throughput.

• Disabled – Default. You can disable the NIC if, for example, you have bandwidth constraints imposed by your network or service provider.

• Load Share Enabled – The NIC will load balance the resources used by output streams.

NAT

Network address translation is the method by which private IP address are held and referenced in a network translation table. It is common practice to hide an entire IP address space, usually consisting of private IP addresses, behind a single IP address. To avoid ambiguity in the handling of packets, a one-to-many NAT alters higher level information such as TCP/UDP ports in outgoing communications and maintains a translation table so that return packets can be handled correctly. The DME allows stream access through a direct

IP address, a Natted IP address, or both.

NAT Public IP Address The public IP address in a network translation table.

Domain Name Server

Primary Server IP Address This is the primary server used for DNS. Note: An invalid

IP address will adversely impact the operation of the user

interface. If the user interface pages are loading slowly, make sure this is a valid IP address. If you are not using a

DNS server, leave this field blank.

Secondary Server IP Address This is the secondary server used for DNS.

Network Time Synchronization

These fields are used to synchronize network time using the host name or IP address of a known server to provide a synchronized time for all appliances in the network.

DME Admin Guide 63

Note Network Administrators please note. DHCP Option 4 (TIME) and Option 42 (NTP) are requested from the DHCP server to obtain SNTP server addresses. One or both of these options must be enabled in the DHCP server for these addresses to be returned to the DME. If both are returned, the DME will use the NTP server address.

If the DHCP server configuration is unknown, it is recommended that the address(es) be manually entered since the DHCP server-supplied address will always override a manually-entered address.

Ports

Network Time Protocol Check to enable network time synchronization. Default =

Disabled.

Primary Server IP Address Primary host name (DME Host Name or DNS Host Name) or IP address of valid SNTP server providing time synchronization. A blank field indicates the server address will be acquired via the DHCP server only if the

Network

DHCP

field above is checked.

Secondary Server IP Address Secondary host name (DME Host Name or DNS Host

Name) or IP address of valid SNTP server providing time synchronization. A blank field indicates the server address will be acquired via the DHCP server only if the

Network

DHCP

field above is checked.

64 © 2014 VBrick Systems, Inc.

System Configuration

RTSP Server Port

RTMP Server Port

Default = 554. RTSP port for VOD streams from RTP server. Cannot be changed. Used to receive an RTP Auto

Unicast stream as input and to serve RTSP RTP clients for output

Default = 1935. RTMP port for Flash VOD streams from

RTMP server. Allows RTP streams as input. For example a

VBrick H.264 encoder can be an RTMP input stream.

Default = 4443. Secure Flash alternate of RTMP.

Default = 5544. The port number used by the

Multi-Protocol Server to listen for announcements.

RTMPS Server Port

Multi-Protocol Server RTSP port

RTMP Server Announce

Listener Port

VBAdmin Server Port

Default = 5544. Allows for listening for auto unicast sessions from RTSP clients. Lets you send RTP streams to an RTMP streaming server via Auto Unicast (for transmuxing to Flash, HLS, or TS). Also allows TS streams to be served via RTSP on this port.

Default = 8181. Specifies the listener port for HTTP management connections as follows: http://

IPaddress:port

where

IPaddress

= DME IP address or hostname, and port. The port number can be moved to another port if required as long as it does not conflict with another existing port in the system.

Conversion Input Port Start Default = 64879. The starting port number used by the

Stream Conversion feature.

Secure VBAdmin Server Port Default = 8383. Specifies the listener port for management and HTTPS connections. Used for HTTPS connections

when enabled on the Security configuration page. Can be

moved to another port number if required.

HTTP Server Port Default = 80. Sets the port used for progressive download

(HTTP), HLS streams, and Caching. This port can be 80 or a safe port in the range 1025–65535. An error message will indicate an invalid port.

HTTPS Server Port

HTTP Streaming

Tunneling Port

Default=443 Secure HTTP port

Default = 8080. Sets the port for HTTP tunneling via RTSP.

The default is 8080 but if you are streaming HTTP directly from a DME via the Internet, it is a common practice to change this to 80 and to set any other service using port 80 to a different port. If you change this value you will need to

make a comparable change on the player and on the DME

configuration (i.e. HTTP Tunnel Port) in VEMS.

HTTP Caching ICP Port Default = 3131. Sets the port used to discover multiple web caches on the local (source) DME and on remote DMEs.

A/V RTP Port Range Start Outgoing port range for RTP/RTCP reports. Default =

56000.

SIP Port SIP port used with VC Gateway. Default = 5060.

DME Admin Guide 65

Security

66

External FTP Server Default = Enabled. Disabled will prevent FTP sessions to the DME appliance. Note that this feature must be enabled to upgrade the appliance firmware.

External FTP Server

Mode

Determines the FTP mode, standard (default) or encrypted over

SSL (FTPS), in which the external FTP server will run when FTPing files to the DME. Any changes to this setting will not reboot the server but will restart the FTP service—ending any active FTP transfers in progress. The options let you configure the server to use

TLS, SSLv3, or both. Transport Layer Security (TLS) and Secure

Sockets Layer (SSLv3) are cryptographic protocols that provide communication security over the Internet. TLS and SSLv3 require an FTP client to communicate with the FTP server in the same protocol. Most FTPS clients will support TLS. However since there may be legacy clients that only use SSLv3, the mode selection lets you pick one option or both options. The client and server will then negotiate a stateful connection and agree on various parameters to establish a secure connection. The DME FTP server supports FTPS

(FTP over SSL); it does not support other secure FTP connections.

This FTPS server supports only explicit FTPS.

• Standard FTP – standard File Transfer Protocol. Not encrypted.

• FTPS TLS Forced – forces the client and server to communicate via TLS.

• FTPS SSLv3 Forced – forces the client and server to communicate via SSL.

FTP TLS or SSLv3 Forced – forces the client and server to communicate via TLS or SSL.

SSH Shell Default = Enabled. SSH Secure Shell access may be used by VBrick

Support Services. Do not use except as directed.

© 2014 VBrick Systems, Inc.

System Configuration

RTMP Server

RTMPS Server

Default = Enabled. Enable the RTMP server for Flash streaming.

Default = Disabled. Enable the RTMP server for secure Flash streaming. Note that if RTMPS is used, the DME must be identified to the player via a FQDN (Fully Qualified Domain Name)

Default = Enabled.

RTMP Announce

Receiver

HTTP Server

Flash Server

Authentication

Default = Enabled. Enable the HTTP server.

Default = Enabled. If checked, a Flash server can send streams to the DME without authentication being required.

External VBAdmin VBAdmin cannot be completely disabled: select HTTP or HTTPS.

Default = HTTP.

• HTTP – VBAdmin is enabled via HTTP.

• HTTPS Only – VBAdmin is encrypted and secured using

HTTPS.

Cache Manager

Utility

Default = Disabled. For debugging only.

External VBAdmin Specifies how an external administrator will connect to the DME.

Choices are HTTP or HTTPS for a secure connection

General

DME Admin Guide 67

System Maintenance

The

Name

,

Location

, and

Contact

fields are used to identify the appliance. They are not changed when you click

Default

. (They are changed when you reset to the defaults on the

Manage Configuration page.)

System Description Read-only. Company name and product name.

System Model Number 7530, 7550, or 7570.

System Serial Number Unique serial number assigned to unit. See label on DME.

System Licenses Displays whatever licenses are currently installed and may include:

DME Base, VC Gateway, among others.

System Name

System Location

System Contact

User-defined. System name, for example Biology Dept.

User-defined. System location, for example West Campus.

User-defined. Contact person, for example Jane Doe.

Login

System Login Message This customized message (max = 256 chars) will be displayed on

the Login page.

System Login

Banner(200x45px)

If default is unchecked a custom Logo can be uploaded.

System Time

Date Time Sets system date and time in mm/dd/yyyy hh:mm

format. The appliance will reset when you click

Set Time

.

Select from list: (GMT-12) Eniwetok – (GMT +12) Auckland. Time Zone

Daylight Saving Time U.S. only. Check this box and the appliance will automatically adjust for Daylight Savings Time. This is particularly useful when monitoring the System Logs.

System Reset

Reset Resets (i.e. reboots) the appliance. A reset does not change, save, or reset any configuration parameters.

Streaming

This page is used to set various configuration constraints. Be aware that it is possible to overload the DME. That is you can configure the maximum number of RTP connections

(and the maximum throughput) in such a way that performance will be seriously degraded. If this happens all clients will be affected and some connections may actually be rejected.

Guidelines for choosing the number of connections depend on the model number (shown on

the System Configuration > General page) of your DME. For best results, use the

recommendations shown below.

68 © 2014 VBrick Systems, Inc.

System Configuration

Max. Number of RTP

Connections

Range: 0–1000. Select this value based on number of expected connections. When selecting the number of connections, the total expected bandwidth of the streams should not exceed recommendations. The recommendations shown here for each model are for total throughput (input and output) in megabits per second:

DME Model BPS 7530

- Do not exceed 100 Mbps.

• Hardware Part # 8000-0222-0x00

• Software Part # 7500-0250-0x00

DME Model XPS 7550

- Do not exceed 500 Mbps.

• Hardware Part # 8000-0223-0x00

• Software Part # 7500-0251-0x00

DME Model HPS 7570

- Do not exceed 3000 Mbps.

• Hardware Part # 8000-0224-0x00

• Software Part # 750-0252-0x00

Max. Number of Multi

Protocol Connections

Shows the maximum number of allowed connections. Default =

500.

RTP Server Max.

Throughput

Multi Server Max.

Throughput

Set maximum allowed throughput in mbit/sec or kbits/sec. See recommendations above.

Maximum amount of bandwidth used by streaming clients for flash streams. This number is capped by the appropriate DME license, but can be set lower to limit the actual max bandwidth used.

DME Admin Guide 69

RTP Buffer Length

(seconds)

RTCP Timeout

(seconds)

The maximum time a packet will sit in a streaming buffer before being delivered to the client. This is adjusted for poor quality networks between client and server. Lower numbers may reduce playback latency. The higher number allows it to behave better with poor network connections.

The maximum time the DME will wait for a RTP server will wait before timing out the connection. Setting a value of 0 means never timeout. This is useful if the source is not sending any

RTCP reports. Also, when using Pause in a RTP player, this number is what the server will wait as a maximum before terminating the paused connections. Setting it to 360 will allow a maximum pause of 5 minutes. It also means it will wait up to 5 minutes to drop connections that do not terminate gracefully, including live content, where the stream is interrupted.

Default Authentication

Scheme

• Basic – the DME server sends authentication credentials over the network in Base64 encoded text.

• Digest – the DME server sends encrypted authentication using MD5 credentials over the network.

Differentiated Services The value is set in the IP header to allow QoS for the data packet.

This value is in decimal. The value is usually set for priority delivery of UDP packets.

Cache System Settings

Used

Be aware that this setting has a direct impact on memory usage. If not configured properly, system memory will not be available for other functions. Do not change the default (Normal) unless you will be using the DME for a different function as explained below.

• Low – the DME will not be used for caching.

• Normal – the DME will be used primarily as a reflector and secondarily as a caching engine.

• High – the DME will be primarily used as a caching engine and secondarily as a reflector.

• Exclusive – the DME will be used exclusively for caching.

Caching

HTTP Caching of content allows a particular piece of HTTP content to be retrieved once from a remote source on request of a viewer and then delivered locally to any subsequent viewers. This scheme offers the benefit of reducing the bandwidth required to deliver content requested by multiple viewers across WAN links. The DME can cache http content whether stored internally by the DME or externally by another DME or other HTTP source. This caching is limited to relatively small files not the large files typically delivered via progressive download. A primary use of the caching is to deliver video from the family of http adaptive streaming protocols - HLS, HDS, Smooth Streaming, and DASH. Currently the DME is capable (on its own) of generating only HLS and HDS (see the specific discussion of content sourcing elsewhere in his manual) so content utilizing these protocols is often sourced from an external source

70 © 2014 VBrick Systems, Inc.

System Configuration

Caching Overview

The goal of configuring the caches on each DME in a network is to allow a client in any subnet (i.e. a "zone" in the VEMS context) to access content hosted by an HTTP server elsewhere in the network. Although, a major focus of the feature is to allow access to HLS or

HDS content created in another DME, the mechanism is generally the same for all HTTP accessed content. This is accomplished by creating a configuration of parents and alternate sources (i.e. siblings) on each DME. Then a client is directed to a DME located in the same zone by providing the URL of the local DME. It is not uncommon to have different sources for different types of HTTP content. Given that the most common and efficient way to configure the caching network is to configure parent relationships, the configuration allows different parent configuration for each major type of HTTP content.

As shown on the System Configuration > Caching Settings page, each DME configuration consists of parents for each of a number of types of HTTP content, one Default Parent, and multiple Alternate Sources. When the DME receives a request for HTTP content it will first determine if the content is cached locally. It will then try to find the content by (1) seeing if it is being produced locally; (2) checking with the alternate sources; and (3) trying to get it from a Parent. Content Specific Parents are checked before the Default Parent. Each parent may follow the same process trying to locate the content. Once the content is found, it is delivered to the requesting client through the discovery path. Each DME in the path will also cache the content to allow provide more efficient delivery to other requestors. For many simple caching matrices, configuring the Default Parent is all that is required. Note that

HLS/HDS/Smooth Streaming/DASH playlists are never cached since in the case of a live events, the playlists are constantly updated.

Figure 27 shows a sample network diagram of multiple DMEs with one DME in each zone.

In general, the goal is (1) to allow any DME to be a source of appropriate HTTP content, and

(2) to allow clients in any subnet to access appropriate HTTP created in any other DME.

Figure 27. Multiple DME Configuration (Sample Network Diagram)

Caching Configuration

When configuring a DME, the first step is to designate one Content Specific Parent for each content type. Also identify a Default Parent for the DME for content not explicitly handled by one of the other parents. In the following example for simplicity, we have only a Default

Parent for each DME - no Content Specific Parents. When Content Specific Parents are present, separate caching matrices exist for each content type.

In order to minimize the amount of required information, the master parent (DME A in the diagram above) should be at the "center" of the caching mesh, although you can actually designate any DME as the master. Each DME should designate as its parent the DME most efficiently on the path to the master parent. The master parent should designate all other

DME Admin Guide 71

DMEs that may be generating content as Alternate Sources (i.e. siblings). It is recommended

(but not required) that any DMEs which can not be efficiently accessed on the master parent path, be entered as Alternate Sources. Table 1 shows the recommended configuration for the sample mesh shown in Figure 26.

Table 11. Recommended Sample Configuration

F

D

DME Default Parent Alternate Source

G E None

A

D

A

None

G

E, F, G

B, C, D, E, F, G

In another example, suppose a client co-located with DME E in Figure 26 wants to access an

HLS stream initiated on DME G. Since this configuration defines DME A as the Master

Parent, the ultimate path for content delivery would be as follows (with asterisks showing where caching occurs):

DME G* > DME E > DME D > DME A* > DME D* > DME E*

Note that if DME G was designated as an alternate source for DME E, the path would simply be: DME G* > DME E*. Although this example designates a DME as master parent

(as often happens if the content to be cached is HLS or HDS where content is not sourced from a DME, e.g. Smooth Streaming), the master parent will likely be an HTTP server. In the

VBrick ecosystem, a VBrick H.264 encoder can generate a Smooth Stream to a Microsoft IIS server that can then deliver it to multiple Silverlight clients or to DME caching engines. Since

IIS servers do not utilize the same caching protocols as the DME, an IIS server cannot be used as an alternate source.

72 © 2014 VBrick Systems, Inc.

System Configuration

Display

Mystro Server Default

Parent

Force HTTPS:

Select number of sources (20, 50, or 200) and the number of available entries in the Alternate Sources table will be adjusted to match.

A DME has one Default parent. When the DME receives a request for content, this is the final place it looks after failing to discover the content locally, at an alternate source, or being directed to a content specific parent. The syntax is:

<ip_address>:port

Note: The specified port number overrides the displayed port

number. See Ports on page 64 for more information.

Secure SSL communication can be enforced between a DME and any of its parents (selected individually). A DME can also communicate securely with alternate sources (siblings) on an all or nothing basis.

DME Admin Guide 73

Content Specific Parent Certain types of content that can be cached and streamed may not be created directly by a DME. This can be because a DME cannot transcode into that type (Smooth Streaming or DASH), or simply because the administrator decided not to do that with a specific device. In this case, an administrator can name an "alternate parent" for a specific type of content. The DME will look to the alternate parent when a specific type of content is requested, is not in cache, and cannot be located on an alternate source. In all cases the syntax is:

<ip_address>:port

Note: The specified port number overrides the displayed port

number. See Ports on page 64 for more information

Apple HLS

Smooth Streaming

HTTP Adaptive Streaming used for display of live or stored streams on iPhone/iPad.

Microsoft-specific HTTP adaptive streaming typically used by the

Microsoft Silverlight player or Windows mobile video display.

Adobe HDDS

MPEG DASH

WM Session Files

HTTP Dynamic Streaming used by Flash players for HTTP adaptive display of video.

An emerging video distribution standard for display of video via

HTTP adaptive streaming. Players are not yet widely available.

WM Session Files (asx or nsc) are often used to display WM video and are required for display of Windows Media multicast. They are generated by a VBrick Appliance (not DME)

MPEG Multicast

Session Files

Alternate Sources

(siblings)

MPEG multicast Session Files (.sdp) are required for display of

RTP multicast video. They are generated by VBrick VB6000,

VB7000, and VB9000 appliances.

If the DME does not already contain the requested content it will look sequentially through the alternate sources before it checks the parents. The syntax is:

<ip_address>:port

Note: The specified port numbers override the displayed port

numbers. See Ports on page 64 for more information.

Manage Configuration

Use this page to manage the DME configuration. It lets you set the defaults or reset to the factory defaults. It also lets you save the configuration to an xml file or restore the configuration from a previously saved xml file.

Note Be aware that when you change the user name and password for the server (See

Username and Password on page 107) you are changing the FTP user name and

password as well. However, when restoring previously saved settings, the FTP username and password will not be the same as the system user name and password.

For best results you will need to login again and change the user name and password to match the FTP username and password. (To keep the same username and password, change the username and password to something different, and then change it back again to the current username and password.)

74 © 2014 VBrick Systems, Inc.

System Configuration

Set Defaults

Set Factory Defaults Reset all settings including Network Settings and passwords to the factory defaults.

Save Configuration

Reset most settings except for Network Settings, and passwords to the factory defaults.

Save all configuration settings that can be restored at a later time.

This action will (1) save all settings in a system location (i.e. a

"snapshot point") and (2) prompt you to save a physical file that can be restored at a later time.

Restore Configuration • Restore from a file – Restore a previously saved configuration settings file. Note that this operation will not restore the FTP user name and password. After a "restore configuration" you will need to manually change this (if desired) using the

Username and Password page. Typically you would change the

user name and password to something and then change it back to the desired user name/password after a restore.

• Restore from a snapshot point – Restores from the snapshot point created with a "Save Configuration." Note: This option only works if there is a previously saved snapshot created with a

"Save Configuration."

SSL Certificates

When using SSL, a server certificate is required for secure communications. DME Supports two types of SSL security certificates:

Self-Signed

and

Authority Generated

(e.g. Verisign). If an organization elects to use a certificate from an authority, the necessary information is entered here. Organizational requirements determine which to use. Both are supported by

DME Admin Guide 75

the DME. In the case of self-signed certificates, the certificate is simply generated and installed by the DME. For an authority generated certificate, this screen allows generation of a certificate request. The request must then be supplied to the certificate authority who will provide a certificate which can then be installed using this screen.

76

Self Signed Certificate Select a self signed certificate.

Certificate Authority

Generated Certificate

Country

Select a certificate authority-generated certificate.

Information only. Country of certificate holder.

State (Province)

City

Information only. State of certificate holder.

Information only. City of certificate holder.

Company or

Organization

Department

Information only. Company of certificate holder.

Information only. Department of certificate holder.

Full Domain Name The complete name of the domain as registered on any internet

DNS

Contact email address Information only. Email address of certificate holder.

© 2014 VBrick Systems, Inc.

System Configuration

Generate Certificate

Request

Certificate

Install Certificate

The information in the previous fields is used to generate the request.

Authority Generated Certificate is entered into this text field.

Install the certificate for SSL use.

SAN/iSCSI Setup

This page is used to set the parameters for accessing content over a Storage Area Network.

Device Enables the DME for SAN use. Disabling will remove the SAN device and restart the DME. Enabling the device will discover the device and provision the disk using the folder name specified below.

Username/Password SAN access rights may require use of a user name and password.

Device IP Address Where the SAN is found on the network.

Virtual Folder Name The name given to the SAN disk as a mapped folder. "iSCSI" is recommended and becomes the folder name in the default FTP path. Be sure the name you choose is not already in use.

Format Destination • Do Not Format – Default.

• Force Format – When used in conjunction with enabling the device, this option will delete all content on the disk. If the disk was previously provisioned, you may not want to format the disk again.

Discovered Device Read-only. If the SAN is found the device identification will be provided automatically.

Status Read-only. Displays the disk size, or "unknown" if no SAN is discovered.

DME Admin Guide 77

Activate Feature

Some optional DME features, for example the VC Gateway Configuration and Stream

Conversion must be "activated" before the functionality is available on the Configuration

Menu. To activate a feature you will need (1) the MAC address of the DME machine, (2) the serial number for future support, and (3) a license file for the feature. The MAC address of the DME machine is shown on the

Activate Feature

page (see below); the serial number and license file are available using the "License Activation" letter you received with your order.

After you get the license file (as explained below) you will copy and paste the entire contents of the file into the License Content text box. Once activated, the system license will be shown

on the System Configuration > General page.

78

Figure 28. Activate Feature Page

To obtain a license file and activate a feature:

1. Contact VBrick Support to obtain the License files needed for the type of DME and features purchased.

2. Click on the green link for information on how to contact support.

3. Open the .lic file in Notepad and copy the entire contents. Then go back to the Activate

Feature Page and paste the contents into the license text box.

4. Enter the serial number from the sticker in the serial number text box.

5. Click

Activate

to close the application and display the login page.

6. Login and repeat these steps for each additional licensed feature.

© 2014 VBrick Systems, Inc.

Chapter 6

SAP Configuration

Topics in this chapter

Announcements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

SAPs for Unannounced Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Announcement Types

Management SAP

Management SAPs provide the ability for a DME to announce its existence to interested programs/devices on a network. The major clients for these announcements are:

• VBDirectory - A free application from VBrick. VBDirectory provides an easy way to access a DME from any PC for configuration or upgrade. It lets you see the status and code revision levels of all networked VBrick devices.

• VEMS Mystro - VBrick's portal product uses the announcements to recognize the existence of DMEs and to make DME configuration easier and less error-prone.

Figure 29. VBDirectory

Announce SAP

Announce SAPs are used by a DME to announce the existence of live streams. The major clients for these announcements are:

• StreamPlayer – This application provides an easy way for a PC to view video transmitted by DMEs. It can be useful as a test device for VEMS Mystro users, or as a standalone player for much of the content distributed by the DME.

• VEMS Mystro – VBrick's portal product uses the announcements to recognize the existence of video streams from DMEs. Streams appear on the Mystro interface without manually configuring URLs of the sourced video.

DME Admin Guide 79

Announcements

80

Transmit Enable

Group Name

Unit Number

Retransmit Time

Time To Live

Management SAP

Check to enable transmit for management SAPs. Default =

Enabled.

Optional. This parameter defines the Group Name. It is included in the Management SAPs used by VBDirectory. It is used for organizing VBrick devices into groups to simplify use of VBDirectory.

Optional. The appliance unit number (range 0–2147483647) is used to identify each DME in a group.

Defines the Management SAP Retransmit Time.

For Unicast, the number of hops (between routers) for which an IP packet is valid in the network. For multicast the distribution scope of the SAP.

© 2014 VBrick Systems, Inc.

SAP Configuration

Differentiated Services The six bit Differentiated Services Code Point (DSCP) field in the header of IP packets for packet classification purposes.

DSCP replaces the three bit Type of Service byte of the IP header.

Defines the Destination IP Address for Management SAPs.

IP Address

Port Defines the Destination Port for Management SAPs.

Announce SAP

Enables configuration of the Announcement.

Announce Enable

Send SAP for Internal IP Destination IP address of the Multicast Announcement for

Stream Announcements. Most commonly for multicast, but can be unicast for direct transmission to, for example, a VEMS

Mystro server.

Send SAP for NAT'ed IP Send a SAP for the natted IP address configured on the System

Configuration > Network page.

IP Address

Port

Actual IP address of the SAP announcement.

Announcement Destination Port.

Transmit Interval

Time to Live

Differentiated Services

Author

Copyright

How often the Announcement is transmitted in seconds.

For unicast, the number of hops (between routers) for which an

IP packet is valid in the network. For multicast, the distribution scope of the SAP.

8-bit value that instructs (capable) routers on how to handle a packet. These are generally quality of service items. This is typically set to all zeros.

Optional author information

Optional copyright information

DME Admin Guide 81

SAPs for Unannounced Streams

Use this page to enable SAPs for streams which have been configured for input to the DME using Unannounced Unicast/Multicast (In-8). This is not a common configuration and it is recommended that an alternate input method be utilized if possible.

82

Enable

Publishing Point

Status

Enables the SAP of the stream

The publishing point of the stream. The format of this publishing point is <streamname>.sdp and is the file name which has be manually placed on the DME. See the discussion on In-8 above.

Current status of the connection and the SAP transmission for this stream.

© 2014 VBrick Systems, Inc.

Chapter 7

Input Configuration

Topics in this chapter

Flash/RTSP Pull . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Transport Stream In. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

RTP Playlists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Flash/RTSP Pull

Use this page to configure streams that will be pulled into the RTMP Multi-protocol server on the DME. Both RTMP and RTPS streams are configured on this page. As shown below the number of supported streams depends on the DME hardware you purchased. See table below for the number of configurable input streams.

DME Admin Guide 83

Stream Name

Type

Source IP/

Address:Port

Application

Publishing Point

User Name

Password

Use RTCP

Enable

Status

Name used within the DME to connect input and output streams.

It is possible to effectively retain the input stream name by making stream name and Publishing Point names the same or changing the stream name to the name used within the DME. In some cases, the publishing point names may be cryptic as is typically true if coming from a CDN

• RTSP – pull the RTSP stream into the DME.

• RTMP – pull the RTMP stream into the DME.

Enter the IP address of the source server. Enter a port number only if you are not using the default RTMP port (1935) or the default

RTSP port (554). If pulling RTSP from the RTP Streaming server, enter

127.0.0.1.

Only required if you are pulling RTMP. This string is defined by the source. For example, on a VBrick encoder, this string corresponds to the

RTMP Application

value on the Program Configuration >

Transmitters page. Valid strings are limited to: live

, vod

, vbrick

, and vbApp

.

This is Publishing Point Name on the source server. If the source is a VBrick encoder, use the

Resource Name

on the Program

Configuration > Servers page on the encoder.

Required if client-side authentication is required by the source server.

Required if client-side authentication is required on the source server.

Default = Enabled. RTCP server reports assist maintaining audio/ video synchronization for some players. Uncheck if your server does not generate RTCP reports of if you wish to ignore RTCP reports from the source.

Use this dropdown to enable or disable the stream. All streams are disabled by default.

Read only: Disabled | Connected | Receiving.

DME Model Number of Configurable Input and Output Streams

7530 25

7550

7505

35

60

Transport Stream In

Use this page to configure streams pushed via unicast or multicast to the Multi-Protocol server using transport stream. The number of streams supported depends on the model of the DME.

84 © 2014 VBrick Systems, Inc.

Input Configuration

MPG2TS Streams

The DME can accept a live unicast or multicast MPEG2TS (with an MP2 or MP4 H264 payload) and deliver it from the DME as unicast or multicast. (A live MPEG2TS is typically pushed from a a VB6000/7000/9000 VBrick MPEG-2/H.264

encoder or another DME.)

For H264 content wrapped in an MPEG2TS, the stream can also be transmuxed and delivered as Flash, HLS, RTP, or HDS. For MPEG-2 content, there is no transmuxing. In order to identify an incoming Transport Stream with MPEG-2 content (so that it can be

"passed through" without further parsing), the incoming stream name must be prepended with " mp2:

" For example when configuring a

Transport Stream In

(with MPEG-2 content) the

Stream Name

must be: mp2:streamname

. Similarly you must use the same

Stream Name

(prepended with mp2:

) when configuring the stream for

Transport Stream Out

. Using this stream as input for HLS or other conversions will not work. Passthrough Transport Streams preserve KLV data when being delivered through the DME.

DME Admin Guide 85

Stream Name

Multicast Source /

Localhost

Port

Enable

Status

Name used within the DME to connect input and output streams. Use the default stream name (

TSPullStream1

,

TSPullStream2

, etc.) or

override as desired. See above, MPG2TS Streams (with MP2 content)

must be prepended with mp2:

Source of multicast stream/local host. If the stream is a unicast to the

DME, enter the DME's IP address.

For source specific multicast addresses, enter it as

"multicastipaddress:sourceipaddress.". Example:

232.1.1.1:172.22.2.166

Port on which the stream is unicast or multicast. If there are multiple unicast input streams, be sure that each input stream has a unique port number.

Use to enable an input stream.

Read only: Disabled | Connected | Receiving.

RTP Playlists

RTP Playlists make it possible to send stored .mp4 (Part 2 or Part 10) VOD files as live streams. They can consist of a single file or multiple files can be reordered and concatenated into a single playlist. They can be weighted and played in differing modes: for example they can be looped or played sequentially. You can then use a playlist to create a multicast relay using the .sdp file, i.e. the

Mount Point

. For more about this scenario, see Out-7 > Relay

(Unicast/Multicast) on page 52. To launch a playlist, you can use it in an RTSP URL by

specifying the .sdp file name or you can use it to create an RTP Relay.

86

Available Playlists

The playlist is playing.

The playlist is stopped.

New Media Playlist Create a new Media Playlist.

Edit Playlist Edit the selected Playlist.

© 2014 VBrick Systems, Inc.

Delete Playlist Delete the selected Playlist.

New Media Playlist

Input Configuration

Name

Mount Point

Play Mode

Repetition

DME Admin Guide

Unique name for the playlist.

The .sdp file name associated with the playlist in ftproot

.

Determines the order in which individual streams are played.

• Sequential – the streams are played once sequentially. Drag the streams up or down to set the order in which they are played.

• Sequential Looped – the streams are played sequentially in an endless loop.

• Weighted Random – the streams are played randomly according to the weighted value. Use the arrow icons to set the weight from 1–10.

Items only repeat after nnn

other items have played.

87

Available Content

Items in This Playlist Order – click and drag file up or down to modify order.

Title – click to select.

Weight – use arrow controls to assign weight (1 – 10).

Open Folder

Use the dropdown to go up one folder at a time. Click and drag files from the left to the right to add to your playlist.

This control is active when you select a folder (icon shown here) in the Available Content list. Open a folder, then drag in a file and click Apply.

Remove Item

Log this playlist's activity

Send this playlist to a broadcast server

This control is active when you select an item in the playlist.

Log this playlist's activity in the Access History log.

• Hostname or IP Address – enter server host name or IP address of broadcast server.

• User Name – enter valid administrator name on broadcast server.

• Password – enter valid administrator password on broadcast server.

88 © 2014 VBrick Systems, Inc.

Chapter 8

Output Configuration

Topics in this chapter

Flash Push . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

RTSP Push . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Transport Stream Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

HLS Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

HDS Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

RTP Relay. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Stream Conversion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Flash Push

Use this page to configure streams that will be pushed to a destination device using RTMP.

Possible destinations for Flash push include a Flash server or a CDN (content delivery network) like Akamai or EdgeCast. This is the preferred protocol for sending streams to another DME. As shown below the number of supported streams depends on the DME hardware you purchased. Note that some fields marked with a trailing (o): these (o)ptional fields may be required at the destination device, for example by a Wowza or other Flash server. See table below for the number of configurable output streams.

DME Admin Guide 89

90

Stream Name

Target Name

Destination IP/

Address:Port

Application

Emulate (o) swf URL (o)

Page URL (o)

User Name

Password

Enable

Status

Name identified on the Multi Protocol input for this stream.

Stream name on the destination. When pushing to another DME it is generally easiest to reuse the Stream Name as the Target Name.

The IP address and port number of the destination server.

This string is defined by the source. For example, on a VBrick encoder, this string corresponds to the

RTMP Application

value on the

Program Configuration > Transmitters page. Valid strings are limited to: live

, vod

, vbrick

, and vbApp

.

Optional May be required for some destination devices.

Optional May be required for some destination devices.

Optional May be required for some destination devices.

Required if client-side authentication is required by the destination server

Required if client-side authentication is required on the destination server

Use dropdown to enable or disable the stream. All streams are disabled by default.

Read only: Disabled | Streaming | Waiting for Stream (

Input source

<stream_name> not yet available.

)

© 2014 VBrick Systems, Inc.

Output Configuration

DME Model Configurable Output Streams

7530 25

7550

7505

35

60

RTSP Push

Use this page to configure streams that will be pushed to a destination device using Auto

Unicast RTP. Possible destinations include servers such as Darwin, Wowza, another DME or a CDN. The number of configurable streams is dependent on the model of the DME.

Stream Name

DME Admin Guide

Name identified on the Multi Protocol input for this stream.

91

Target Name Sets the stream name on the destination. The Target Name has the format <TargetStreamName>.sdp. When pushing to another DME it is generally most straightforward to reuse the Stream Name as the Target Name.

Destination IP/Address:Port Enter the destination IP address. Override the Port if not using the default (554).

User Name

Password

Required if client-side authentication is required by the destination server.

Required if client-side authentication is required by the destination server.

Enable

Status

Default - Disabled - Enables the push.

Read only: Disabled | Streaming | Waiting for Stream

(

Input source <stream_name> not yet available.

)

92 © 2014 VBrick Systems, Inc.

Transport Stream Out

Output Configuration

Stream Name The input stream name you will be sending out as a transport stream.

Note: For MPEG-2 content, the Stream Name must be prepended with " mp2:

" See MPG2TS Streams on page 85 for more information.

Multicast/

Destination IP/

Address

Port

If multicast output, the multicast address of the output stream, If unicast, the destination IP address.

The port number you will be sending the stream to.

Announce Name (optional) If multicast, the program name to be included in the SAP for this stream. If not filled in, Stream Name is used.

Enable

Status

Enable or disable the output transport stream.

Disabled | Waiting for Stream | Streaming

DME Admin Guide 93

HLS Streaming

HLS (HTTP Live Streaming) is an HTTP-based media streaming protocol implemented by

Apple Inc. as part of their QuickTime and iPhone software. It works by breaking the overall stream into a sequence of small HTTP-based file downloads, each download loading one short chunk of a transport stream. As the stream is played, the client can select from a number of different alternate streams containing the same material encoded at a variety of data rates, allowing the streaming session to adapt to the available data rate. At the start of the streaming session, it downloads an extended M3U playlist containing the metadata for the various substreams which are available. Since its requests use only standard HTTP transactions, HLS is capable of traversing any firewall or proxy server that allows standard

HTTP traffic, unlike UDP-based protocols such as RTP.

94

Stream Name Input stream used to generate HLS content.

Master Playlist Name If the stream will be part of a group of alternate streams identified by a master playlist, enter the master playlist name. A group may consist of multiple streams with different bit rates and the iOS client will switch between available streams to provide the best viewing experience. When using this page to create a group, you must put

the highest bit rate stream first (at the top of the list). This is the first stream the client will try to play. You will typically have more than one HLS stream referencing the same Master Playlist Name. If this stream is not part of a master playlist, leave this field blank.

Announcement

Name

(optional) The program name to be included in the SAP for this stream. If not filled in, Stream Name is used

© 2014 VBrick Systems, Inc.

Output Configuration

Bandwidth Override Master Playlists for multiple bit rate streams require the bandwidth of each individual stream to be included in the Master Playlist. For example, if the stream is sourced from a VBrick H.264 encoder, the

DME will detect the bandwidth associated with each multiple bit rate stream. For non-VBrick encoders, enter the bandwidth value (in

Kbps) associated with the stream. In general, use this field only if the encoder does not supply a bandwidth value. Be aware that if

used, this value will override the encoder–supplied value.

Type The number of video segments in a playlist is defined by the Playlist

Length. This field determines how the DME will handle the generated segments:

• Rolling – the playlist will have a fixed length regardless of the number of HLS segments generated. Segments will be added or deleted to maintain a fixed playlist length.

• Appending – the Playlist Length is ignored and the DME creates a continuously growing playlist. The maximum playlist duration is seven days.

Note 1: Multiple appending playlists may use a large amount of disk space unnecessarily. Use this option only if you will need to return to the beginning of the playlist.

Note 2: The entire playlist will be deleted if you "disable" HLS

generation (on the HLS Streaming page). When the stream is

active, the playlists and associated segments can be extracted via

FTP.

Playlist Length

Minimum Segment

Length

The number of segments to include in a playlist. Default = 10. This value is used to enable scroll back in the client player. You can scroll back up to the number of segments specified here. Be aware that this

function uses disk space for segments that may never be viewed.

The number of seconds for which a media segment is created.

Range 1–60. Default = 8. By increasing this number you will increase the initial time it takes to play the HLS stream. Since a separate HTTP access is required for each segment,

Performance is optimized by keeping this number larger. Since a separate HTTP access is required for each segment, performance is improved by keeping this number larger. For best results, this number should always be a multiple of the IDR Frame Interval on the encoder. For example, if the IDR Frame Interval is 4, this value should be 8, 12, 16.

Enable

Status

Enable or disable the stream.

Disabled | Waiting | Active.

Playlist Conventions

When generating HLS streams it is important to understand the conventions used for creating playlists so they can be played via an HTTP URL.

DME Admin Guide 95

To Play:

Individual streams that are part of a master playlist:

Individual streams that are not part of a master playlist:

All streams in a master playlist:

iOS Viewing URL

http://<dme_ip_address>/<master_playlist_name>/

<stream_name>/playlist.m3u8

http://<dme_ip_address>/HLS/<stream_name>/ playlist.m3u8

http://<dme_ip_address>/<master_playlist_name>/ playlist.m3u8

HDS Streaming

HDS (Adobe MPEG-4 based HTTP adaptive file streaming protocol) is an HTTP-based media streaming protocol implemented by Adobe. It works by breaking the overall stream into a sequence of small HTTP-based downloads, each download loading one short chunk of a video stream. As the stream is played, the client can select from a number of different alternate streams containing the same material encoded at a variety of data rates, allowing the streaming session to adapt to the available data rate. At the start of the streaming session, it downloads an extended f4m playlist containing the metadata for the various substreams which are available. Since its requests use only standard HTTP transactions, HDS is capable of traversing any firewall or proxy server that allows standard HTTP traffic, unlike UDPbased protocols such as RTP.

96 © 2014 VBrick Systems, Inc.

Output Configuration

Stream Name Input stream used to generate HLS content.

Master Playlist Name If the stream will be part of a group of alternate streams identified by a master playlist, enter the master playlist name. A group may consist of multiple streams with different bit rates and the Flash player will switch between available streams to provide the best viewing experience. When using this page to create a group, you

must put the highest bit rate stream first (at the top of the list).

This is the first stream the client will try to play. You will typically have more than one HLS stream referencing the same Master

Playlist Name. If this stream is not part of a master playlist, leave this field blank.

Announcement

Name

(optional) The program name to be included in the SAP for this stream. If not filled in, Stream Name is used.

DME Admin Guide 97

98

Bandwidth Override Master Playlists for multiple bit rate streams require the bandwidth of each individual stream to be included in the Master Playlist. For example, if the stream is sourced from a VBrick H.264 encoder, the

DME will detect the bandwidth associated with each multiple bit rate stream. For non-VBrick encoders, enter the bandwidth value (in Kbps) associated with the stream. In general, use this field only if the encoder does not supply a bandwidth value. Be aware that if used, this value

will override the encoder-supplied value.

Type The number of video segments in a playlist is defined by the Playlist

Length. This field determines how the DME will handle the generated segments:

• Rolling – the playlist will have a fixed length regardless of the number of HDS segments generated. Segments will be added or deleted to maintain a fixed playlist length.

• Appending – the Playlist Length is ignored and the DME creates a continuously growing playlist. The maximum playlist duration is seven days.

Note 1: Multiple appending playlists may use a large amount of disk space unnecessarily. Use this option only if you will need to return to the beginning of the playlist.

Note 2: The entire playlist will be deleted if you "disable" HDS generation (on the HDS Streaming page). When the stream is active, the playlists and associated segments can be extracted via FTP.

Playlist Length

Minimum Segment

Length

The number of segments to include in a playlist. Default = 10. This value is used to enable scroll back in the client player. You can scroll back up to the number of segments specified here. Be aware that this

function uses disk space for segments that may never be viewed.

The number of seconds for which a media segment is created.

Range 1–60. Default = 8. By increasing this number you will also increase the initial time it takes to play the HLS stream. For best results, this number should always be a multiple of the IDR Frame

Interval on the encoder. For example, if the IDR Frame Interval is

4, this value should be 8, 12, 16 ...

Enable

Status

Enable or disable the stream.

Disabled | Waiting | Active.

Playlist Conventions

When generating HLS streams it is important to understand the conventions used for creating playlists so they can be played via an HTTP URL.

To Play:

Individual streams that are not part of a master playlist:

All streams in a master playlist:

iOS Viewing URL

http://<dme_ip_address>/HDS/<stream_name>/ playlist.f4m

http://<dme_ip_address>/HDS/<master_playlist_name>/ playlist.f4m

© 2014 VBrick Systems, Inc.

Output Configuration

RTP Relay

Use this page to configure or edit relays. A streaming RTP relay forwards an RTP stream from a source to either a multicast or multiple unicast destinations. One of the primary functions of a relay is to minimize the usage of network bandwidth across limited bandwidth

WAN links by receiving an single incoming stream and outputting either a multicast stream or serving multiple unicast streams. Relays can also be used to distribute the load across multiple servers. The incoming stream can be provided to multiple destination servers and then redistributed to clients. Possible destination servers, include QuickTime, Darwin, or another DME. There are a number of methods for receiving an incoming stream. The most common is to receive an incoming stream into the Multi Protocol Server and then push the stream to the RTP Server (Out-10). It is also possible to receive a Push directly into the RTP server (In-3) or to receive an unannounced unicast or multicast. In this scenario you will need to manually place the multicast/unicast .sdp file from the source on the destination server.

Another important use case for providing input to the RTP server is from the VC Gateway.

This input does not require explicit configuration. In addition to the output options for delivering multicast or unicast streams via Push mechanisms, streams are available via the

RTPSP/RTP server without any explicit configuration. When clients open an RTSP stream to the .sdp file from a server, they will receive a reflected unicast of the incoming stream.

This method can be used to distribute the stream to either client players or to multiple destination servers.

Note If a stream which is present on the RTP server is to be used as source for any output from the Multi Protocol serer, an RTSP/RTP Pull (In-6) must configured on the Multi

Protocol server. For more about configuring this scenario, see Out-7 > Relay

(Unicast/Multicast) on page 52.

DME Admin Guide 99

Relays

New Relay

Edit Relay

Delete Relay

Shows all defined relays.

Define a new relay.

Edit the selected relay.

Delete the selected relay.

100 © 2014 VBrick Systems, Inc.

New Relay

Output Configuration

Relay Name

Status

Enter a unique relay name.

Check to enable. Remember to click

Apply

before you exit the page.

Source Settings

These settings describe the source of the stream to be relayed. It can be sourced internally from the DME (127.0.0.1); it can be fetched from elsewhere; or you can wait for it to be announced. The dominant use case is to source the stream internally from the DME.

DME Admin Guide 101

102

Source Hostname or

IP Address

Mount Point

Request incoming stream

User Name

Password

Wait for announced stream(s)

Hostname or IP address of the source server. Commonly this is

127.0.0.1. This is set to an external address only if a stream is being requested from an external server via RTSP/RTP. Normally RTSP/

RTP requests originate at the Multi Protocol Server (In-6).

SDP file name.

For all normal use cases, this option is selected. Check to request a stream from another DME or server.

(optional) Name used for authentication on source server. Used only in the uncommon case of a stream requested from an external server via RTSP/RTP.

(optional) Name used for authentication on source server. Used only in the uncommon case of a stream requested from an external server via RTSP/RTP.

Check to wait for an announced stream from the specified hostname or IP address. This is an uncommon case.

Destination Settings

Hostname or IP

Address

Hostname or IP address of the destination server.

Announced UDP Use when relaying a stream to another DME or server via auto unicast.

• User Name – Name used for push authentication to destination server.

• Password – Password used for push authentication to destination server.

Unannounced UDP Use when pushing the stream to another DME or server and publishing the associated .sdp file. Although this option can be used for either multicast to clients and servers or unicast to a specific server, the dominant case is multicast.

• Base Port – The base port will be incremented by 2 for each

RTP stream.In most common cases, there are two RTP streams

(audio and video) so 4 ports are required for the relay. The ports must be unique on the destination device for unicast or on the multicast IP.

• Output SDP file – Auto-generates an .sdp file using the

Output

SDP file

name and including the destination information.

• Multicast TTL – For unicast, the number of hops (between routers) for which an IP packet is valid in the network. For multicast defines the distribution scope of the stream. Range =

1–255.

Add | Remove

Destination

A relay can send the stream to multiple destinations. Use this button to add or remove a configured destination.

© 2014 VBrick Systems, Inc.

Output Configuration

Stream Conversion

Use this page to configure input/output stream type conversion. The most common use of the converted streams is to convert a high rate stream into multiple lower rate streams for delivery via one of the HTTP adaptive protocols (HDS or HLS). The conversion process does not modify the resolution of the incoming stream—the end devices will usually efficiently scale the incoming video to fit the screen. The conversion changes the bit rate, and in some cases, will modify the frame rate.

Note If you purchased the Stream Conversion feature, the license for this feature must be activated before the

Stream Conversion

option is shown in the DME's Configuration

Menu. For more information see Activate Feature on page 78.

The stream conversion function is part of the Multi Protocol server. This means that the source stream must be present in the Multi Protocol Server and the output stream is available to the Multi Protocol server. If the input stream is sourced from the RTP server (In-3 or

In-8) or from the VC Gateway, then it will need to be pulled into the Multi Protocol server by an internal RTSP/RTP pull (In-6). The output parameters for the various available conversion templates are shown below: The number of conversions configurable is limited

according to model number of the DME as shown in Table 13.

Stream Name Name of the preconfigured source stream selected from the dropdown list

Conversion Type Sets the video, audio, and resolution parameters for the output stream.

Framerate is the framerate of the source input stream. See Table 12 for

parameter details.

Converted Output

Stream Name

The stream name for the converted output stream. This is used as an input Stream name when defining how the converted stream is to be used as an Output.

DME Admin Guide 103

104

Extra Parms

Enable

Status

CPU Load

Use this field to enter specific parameters that may be necessary for the stream to play on devices with specific conversion requirements. For example you may need to configure an incoming DME stream with a modified Key Frame Interval for compatibility with a certain player.

For a library of possible conversion options go to http://libav.org/ avconv.html Libav is software project that produces libraries and programs for handling multimedia data. Use these options with care.

They will override the selected template in the

Conversion Type

field but are not tested or supported by VBrick. If not used properly they can adversely affect DME performance.

Enables/Disables the conversion.

Disabled | Waiting | Active

CPU status for transrated streams.

Table 12. Conversion Type Parameters †

Conversion Type

iPod/iPhone/SmartPhone iPad/Tablet Low Resolution iPad/Tablet High Resolution

Set Top Box

Video/Audio Bit Rate Resolution

300/32 (Kbps)

400/32

700/48

800/48

Cloud Delivery Low 200 Kbps 200/16

Cloud Delivery Medium 500 Kbps 500/32

QVGA

VGA

SVGA

VGA

QVGA

QVGA

Cloud Delivery High 1000 Kbps 1000/32

LAN HD 2000 Kbps 2000/48

LAN HD 4000 Kbps 4000/48

VGA

HD720

HD720

† Framerate is the framerate of the source input stream.

Table 13. Number of Permitted Conversions

Model Number of Permitted Conversions

7530

7550

7570

3

6

10

© 2014 VBrick Systems, Inc.

Output Configuration

Notes • The actual number of supportable conversions depends on the hardware deployed.

This is a particularly important consideration when using a virtual machine versions of the DME. Each conversion takes a minimum of one core. Further if the bit rate of the output stream exceeds 500K an additional core is required. If the bit rate exceeds 1Mbps, then two additional cores are needed.

• In order to play converted streams, some PCs may need to have the Catalyst

Control Center (for the video card) installed and the option "Enforce Smooth

Video Playback" disabled.

DME Admin Guide 105

106 © 2014 VBrick Systems, Inc.

Chapter 9

User Configuration

Topics in this chapter

Username and Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Stream Input Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Username and Password

Use this page section to change the user name (default = admin

) and password (default = admin

) for the DME server (and the FTP server). There is only one user name and password on the system with the exception of ReadOnly access which is described below. If you change the user name and password, be sure to record the new name and password. If you lose the user name or password you will be unable to login to the server.

Note Be aware that when you change the user name and password for the server you are

changing the FTP user name and password as well. See the Note on page 74 for more

information.

Current User Name

Current Password

New User Name

New Password

Enter current user name.

Enter current password.

Enter new administrator user name.

Enter new administrator password.

DME Admin Guide 107

Re-enter New Password Re-enter new password and be sure to click

Change Password

.

Readonly Username and Password

Use this page section to change the

Readonly

user account password if desired. The Readonly account user name (default = readonly

) and password (default = readonly

) is used specifically for read only access to the DME server. When logged in as a Readonly user, the user may only browse the DME GUI. No modifications may be made.

Note Be aware that you must know the current Administrator User Name and Password to change the Readonly password. Further, while you may change the password for the

Readonly account, the User Name will always be the default, readonly, as referenced above.

108

Current Administrator Enter current Administrator user name.

Current Administrator

Password

Enter current Administrator password.

Readonly User New

Password

Enter new Readonly password.

Re-enter New Password Re-enter new password and be sure to click

Change Readonly

Password

.

© 2014 VBrick Systems, Inc.

User Configuration

Stream Input Authentication

Use this page to configure a "broadcast" password that will allow you to publish streams to this server. This password is needed when sending a stream via auto unicast to a DME using either In-2 or In-3 or when sending an RTMP stream from a live encoder to the DME In-1.

Only one login user name and password are used for all inputs into the system. The login name cannot be the same name as the administrator name.

Current Stream Input

Authentication User

Name

New User Name

Read only. Default = broadcast |broadcast (user name/ password).

Enter new announce user name.

New Password Enter new announce password.

Re-enter New Password Re-enter new password and be sure to click

Change Password

.

DME Admin Guide 109

110 © 2014 VBrick Systems, Inc.

Chapter 10

VC Gateway Configuration

Topics in this chapter

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Incoming Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Outgoing Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Overview

Video conferencing enables people at different locations to see and hear each other, and to share access to documents, slides, and desktop applications. Each site typically has a video camera, a display device, as well as a microphone and speakers. The DME video conferencing solution builds on a simple video conference by delivering a multi-vendor, standards-based stream that lets smartphones, tablets, PCs/Macs, and TVs display the video conference. It provides a cost effective way to leverage existing video conferencing investments by delivering the video conference audio and video as a stream to other elements in the VBrick ecosystem. The stream can be centrally managed and delivered to thousands of users across multiple sites. It can also be recorded for subsequent on-demand viewing.

Note If you purchased the Video Conferencing feature, the license for this feature must be activated before the

VC Gateway Configuration

option is shown in the DME's

Configuration Menu. For more information see Activate Feature on page 78.

Vendor Compatibility

The VC Gateway is a standards-based solution. It integrates with video conference

infrastructure using SIP (RFC 3264) and H.264. The products shown in Table 14 have been

tested successfully at VBrick. Many of the listed vendors make similar products within the same families that share the same software and operating parameters and it is expected that these devices will interoperate successfully as well. However, there are always variations in software releases and interoperability cannot be guaranteed without testing your specific product. In short a trial is always recommended. Other vendors and other products may also work with the VC Gateway but have not been tested.

Table 14. Supported Videoconferencing Vendors

Vendor

Avaya

Product

1X Communicator, Avaya Flare, Avaya 1020, Avaya 1050

LifeSize

Polycom

DME Admin Guide

Express 220, Team 220

HDX 8000 HD, iPad

111

112

Configuring VC Gateway Streams

The DME's Video Conferencing module has two basic methods that are used to create and

stream a video conference: (1) Incoming Lines allow the he DME to be invited into a video

call by a remote video conferencing system. (2) Outgoing Lines are used to initiate a call from

the DME to a remote video conferencing system. In both cases the DME delivers the video conference as a stream to other elements in the VBrick ecosystem. As shown in Table 15, the

total number of incoming and outgoing lines available is limited by the license you purchased.

The

Total Number Lines

read-only field on the

Defaults

page shows the number of lines available with your license. You can configure any combination of incoming and outgoing lines that do not exceed the total number of available lines. (If you purchased hardware and software from VBrick, the number of lines is determined by the DME model; if you purchased software-only, the number of lines is determined by license.)

Table 15. Available VC Gateway Lines

DME Model

7530 (BPS)

7550 (XPS)

7570 (HPS)

Total Lines Available

12

30

60

Delivering VC Gateway Streams

The VC Gateway creates an RTP input stream of the video conference which you can output in multiple ways to local and remote viewers. A VC Gateway stream is no different than any other DME input stream. This means you can use any of the streaming output methods

(Flash Push, RTSP Push, Transport Stream, HLS Streaming, RTP Relay) supported by the

DME. See DME Output Streams on page 46 for more about delivering VC Gateway streams

The VC Gateway streams are delivered to the RTP Server. If you wish to deliver the VC

Gateway stream using any of the output use cases supported by the Multi-protocol server, you must configure an internal RTSP/RTP pull (In-6) to make the stream available to the

Multi-Protocol server.

Playing Back VC Gateway Streams

Playback of VC Gateway streams is only limited by the configured output and the players you have available to play that output. For more about playing back VC Gateway streams, see

Playing DME Streams on page 141.

Note The DME can receive a G.711 audio stream from the VC Gateway via a connected call and will convert the audio to AAC which can then be streamed out of the DME via

RTP and other delivery methods. Without a VC Gateway the DME cannot pull directly from a source that has G.711 audio. The video input through the VC Gateway must be H.264.

Integrating with VEMS Mystro

The VC Gateway is closely integrated with the VEMS Portal Server. It can display live VC

Gateway streams on the

Live Video

pages in VEMS. It can record and save VC Gateway streams on the

Stored Video

pages (in VEMS 6.x only). VEMS Mystro recording functionality is configured on the Details pages for incoming and outgoing lines.

© 2014 VBrick Systems, Inc.

VC Gateway Configuration

Live Video – Provided SAPs are enabled for the outgoing streams, DME streams sourced from the VC Gateway are automatically discovered and displayed in VEMS.

Stored Video – The VC Gateway can be configured to automatically record and ingest streams into VEMS Mystro 6.x only using the VC Gateway "record" feature. These streams will be displayed on the

Stored Video

pages.

Note If you exceed the permitted number of recordings, allowed by VEMS Mystro, the recording(s) will fail and an application error will be shown on the VEMS

Dashboard—not in the DME.

Incoming Lines

The DME can be invited into a video call by an individual video conference camera and codec or by a multipoint control unit (MCU). When the remote video conferencing system will be initiating a call to the DME, the VC Gateway is configured using the Incoming Lines pages. The Incoming Lines page shows the line table. This table shows the current state of all available incoming lines.

Note As a best practice when using the VC Gateway for incoming audio-only calls, define one or more lines for audio-only usage. To subsequently use those lines for incoming

audio/video calls you must restart the Streaming Server Service on the System

Maintenance page.

Line Name The SIP Line name is used as Stream name elsewhere in the system

Page Refresh Interval Select a refresh interval from the dropdown or

Never

(not recommended).

DME Admin Guide 113

114

State

Edit

Delete

Activate

Line

Record

Default

Displays various descriptive messages indicating the current "state" of the line. The first connected line will display as connected

; additional connected lines will display as bridged

.

Edit | New

. Click to create a new line or to edit an existing line.

Click and confirm to delete a line.

Activate | Deactivate

. Click and confirm to activate an existing line.

A call cannot be connected until the line is activated.

Hang Up

. Click on Hang Up to end the currently connected call.

Record | Stop Record

. Click to record the VC Gateway stream on the configured VEMS Mystro server. The recording automatically terminates when the line disconnects.

Use with care. This button will delete all lines in the table.

To accept an incoming call from a videoconferencing system:

1. Make sure the Incoming Line Details (including the

Line Identity

) are configured correctly for the selected

Line Name

.

2. The VC Gateway listens for incoming calls. When the

Hang Up

button is displayed, an incoming call is connected to the VC Gateway.

3. Verify the State is " connected

" on the Incoming Lines page.

4. Verify you have audio and video on the videoconferencing monitor or your desktop.

5. If a Live Entered URL is configured in VEMS Mystro, verify the stream is present.

Incoming Line Details

This page shows parameter details for the incoming line. In many cases you can use the

default values which are derived from the Defaults page. Click on the

Default

button to set or reset to the defaults. Once a line is activated, it will automatically listen for incoming calls from the configured video conferencing source (i.e. the

Line Identity

).

© 2014 VBrick Systems, Inc.

VC Gateway Configuration

Line Number Click once to select and edit any color-coded line (1–n).

New line (grey)

Connected line (green)

Not connected line (red)

Line Name

Line Identity

User-configured line name. Default =

IncomingLine<n>

The DME line name and IP address in the format shown. This is the identifier the remote videoconferencing unit will use to call into the DME: sip:<line_name>@<dme_ip_address

>

Should Register

Registrar Address

The session will be registered with a SIP registration server if present. Default = Enabled.

Optional field to add the IP address of a registrar if one is required.

Line Authentication Id Line Authentication Id for configured SIP registration server.

DME Admin Guide 115

116

Line Authentication

Password

Never Hang Up

Maximum Call Time

Video Resolution

P-Mode

I-Frame Interval

Audio Bit Rate

Activate Line

Configure Destination

RTP Relay

VEMS Mystro User

VEMS Mystro

Password

Automatic Record

Line Authentication password for configured SIP registration server.

Do not hang up. If you leave the call connected it will automatically hang up after 720 minutes.

Maximum duration for any call after which the system will automatically hang up. Default = 120 minutes.

Select from dropdown list. Sets the desired video encoding resolution (the width and height respectively) of the compressed video stream. Note that the actual resolution is determined by negotiation between endpoints.

• 1920x1088 @ 60fps at 4096kbps

• 1920x1088 @ 30fps at 2048kbps

• 1280x720 @ 60fps at 2048kbps

• 1280x720 @ 30fps at 1024kbps

• 960x544 @ 30fps at 1024kbps

• 704x480 @ 30fps at 512kbps

• 704x576 @ 25fps at 512kbps

• 352x240 @ 30fps at 256kbps

• 352x288 @ 25fps at 256kbps

Packetization mode defines the packetization rule for the incoming/outgoing stream. Default = standard. Do not change except as directed.

Video conferencing systems typically do not send IDR frames although they are required for most players. This is the frequency at which IDR (Intra Dynamic Refresh) frames are inserted.

Default = 5 seconds.

Select from dropdown: 16K, 32K, 64K.

The line cannot be used for a videoconference until it has been activated. Default = disabled.

Check box to automatically configure a destination RTP relay to

stream the video conference over RTP. See Destination RTP

Relay below.

If the video conference will be recorded to VEMS, the VEMS user name it will be associated with. This user determines which categories will be available for the recorded video. If blank, this user will be the VEMS Mystro User configured on the SIP

Defaults page.

If the video conference will be recorded to VEMS, the VEMS password it will be associated with. If blank, this user will be the

VEMS Mystro Password configured on the SIP Defaults page.

Automatically record the videoconference in VEMS Mystro.

Default = disabled.

© 2014 VBrick Systems, Inc.

VC Gateway Configuration

Title

Description

Keywords

• Default – "

Incoming Linen n

"

• Add Time Stamp – appends the date and time to the VEMS title. For example:

Incoming Line_n_12_01_27_15_02_51

VEMS metadata. Descriptive text used for content search.

VEMS metadata. Keywords used for content search.

Categories VEMS metadata. The categories that the recorded stream will be associated with. These categories are determined by the configured VEMS Mystro User.

Note: If category permissions are changed on the VEMS Mystro server, it may take up to 30 minutes before the updated categories are shown on this DME page.

Reference Material Link VEMS metadata. This will add a link to a web page on the

Reference Material tab.

• Title – Descriptive name for URL.

• URL – Fully qualified path to a web page.

Note The Incoming and Outgoing Details pages have an

OK

button (in addition to Apply,

Revert, and Default). Use the

OK

button to save changes and exit back to the previous page. Use the

Apply

button to save changes without leaving the Details page. This makes it easy to edit a different line without leaving the Details page.

Destination RTP Relay

Use the

Destination RTP Relay

check box on this page (and configure the parameters) to

create a destination RTP relay. Instead of going to the RTP Relay page, you can simply check

this box to run a wizard that automatically creates the destination relay. A destination RTP relay forwards a multicast stream to local users in an IP network using an auto-generated .sdp file that becomes part of the URL to the stream, for example: http://<dme_ip_address>/ mystream.sdp.

When clients open a player and point to the .sdp file with a URL, the player will tune into the stream. Be aware that if you change the setting on this page (for a previously created relay) you will actually be creating a new relay and leaving the old relay in

place. Consequently you will need to open the RTP Relay page and manually disable and

delete the old relay. For best results, if you need to make changes, edit the relay on the RTP

Relay page rather than on the VC Gateway page.

Configure Multicast

RTP Relay

Relay Name

Check this box to enable and display the relay configuration options. Default = disabled.

Enter a unique name for the relay.

DME Admin Guide 117

Multicast IP

Base Port

Out SDP File

Multicast TTL

Enter a valid multicast address for your network, for example:

239.22.118.72

Use this parameter when pushing the stream to another DME.

The base port will be incremented by 2 for each RTP stream. Use numbers that are not already being used for the entire SDP sequence set.

Enter a name for the auto-generated .sdp file.

Specify the number of routers the multicast stream will pass through before it stops propagating over the network. Range = 1–

255.

Outgoing Lines

The DME can also initiate a call into a videoconference. When the DME initiates a call to the remote video conferencing system, the VC Gateway is configured using the Outgoing Lines pages. The Outgoing Lines page shows the line table. This table shows the current state of all available outgoing lines.

118

Page Refresh Interval Select a refresh interval from the dropdown or

Never

(not recommended).

Line Name

State

User-configured line name. Default =

OutgoingLine<n>

Displays various descriptive messages indicating the current "state" of the line. The first connected line will display as connected

; additional connected lines will display as bridged

.

Edit

Edit | New

. Click to create a new line or to edit an existing line.

© 2014 VBrick Systems, Inc.

VC Gateway Configuration

Delete

Line

Record

Default

Click and confirm to delete a line.

Call | Hang Up

. Click Call to initiate a videoconference with the configured endpoint or Hang Up to end the call.

Click to record the VC Gateway stream on the configured VEMS

Mystro server.

Use with care. This button will delete all lines in the table.

To place an outgoing call to a videoconferencing system:

1. Make sure the Outgoing Line Details (including the

Destination Identity

) are configured correctly for the selected

Line Name

.

2. Click the

Call

button for the selected

Line Name

on the Outgoing Lines page.

3. Verify the State is " connected

" on the Outgoing Lines page.

4. Verify you have audio and video on the videoconferencing monitor or your desktop.

5. If a Live Entered URL is configured in VEMS Mystro, verify the stream is present.

Outgoing Line Details

This page shows parameter details for outgoing lines. The parameters shown on this page are

identical to those on the Incoming Line Details page except for the three fields explained below. In

most cases you can use the values specified on the Defaults page. Click on the

Default

button to set or reset to the defaults. You can initiate a call by enabling

Call Line

and clicking

Apply

or

OK

or by using the

Call

button on the Outgoing Lines page. Either method will auto connect with the configured video conferencing endpoint (i.e. the

Destination Identity

).

DME Admin Guide 119

Destination Identity The name and IP address of the videoconferencing destination endpoint in the format shown. This is the identifier the DME will use to call into the remote videoconferencing unit: sip:[email protected]<destination_ip_address>

(or

<host name>

).

Proxy Address

Call Line

Optional field to list the IP address of a proxy server if one is required.

Automatically initiates a call when you check the box and click

OK

or

Apply

.

Defaults

Use this page to set SIP defaults for many of the parameters on the incoming and outgoing line detail pages. Note that any changes you make on this page do not affect existing lines.

Changes made on this page will apply only to "new" incoming or outgoing lines.

120 © 2014 VBrick Systems, Inc.

VC Gateway Configuration

Line Identity

IP, Host, or Domain

SIP Bind Address

IP address, host name, or domain of the DME.

Typically the same as the DME. However, you can configure the source IP address of signaling and media packets to a specific interface's IP address. Packets not destined to the bound address are discarded.

Total Number Lines

Number Incoming

Lines

Number Outgoing

Lines

Read-only. The total number of incoming and outgoing lines available depends on your license. See Table 15 on page 112.

Determines the number of available lines shown on the Incoming

Lines page. Total cannot exceed license.

Activate Incoming Line Automatically activate newly created incoming lines.

Call Outgoing Line Automatically call newly created outgoing lines.

Video Resolution

Determines the number of available lines shown on the Outgoing

Lines pages. Total cannot exceed license.

Select from dropdown list. Sets the video encoding resolution

(the width and height respectively) of the compressed video stream.

DME Admin Guide 121

122

P-Mode

I-Frame Interval

Packetization mode defines the packetization rule for the incoming/outgoing stream. Default = standard. Do not change except as directed.

Video conferencing systems do not send IDR frames although they are typically required for most stream players. This is the frequency at which IDR (Intra Dynamic Refresh) frames are inserted. Default = 5 seconds.

Audio Bit Rate

Log Level

Never Hang Up

Select from dropdown: 16K, 32K, 64K.

• Debug – Provides verbose information (default).

• Info – Provides limited information.

Do not hang up. If you leave the call connected it will automatically hang up after 720 minutes. Default = disabled.

Maximum duration for any call after which the system will automatically hang up. Default = 120 minutes.

Incoming Maximum

Call Time

Outgoing Maximum

Call Time

Should Register

Maximum duration for any call after which the system will automatically hang up. Default = 120 minutes.

The session will be registered with a SIP Registration server if present. Default = Enabled.

Audio Chime A chime sound is played (before the Audio Welcome Prompt) when placing or receiving calls to or from an endpoint. To use a different sound, uncheck

Default

and upload your own file. See

Creating "Audio Chime" Files below for details.

Audio Welcome Prompt An audio message ("Welcome to VBrick DME") is played when placing or receiving calls to or from an endpoint. To use a different message, uncheck

Default

and upload your own file. See

Creating "Audio Chime" Files below for details.

VEMS Mystro Address VEMS Mystro 6.x only. Set default VEMS Mystro IP address or host name for recorded files. If SSL is configured on the VEMS

Mystro server, you must use a host name in this URL.

VEMS Mystro User Set default VEMS Mystro user name.

VEMS Mystro Password Set default VEMS Mystro password.

Automatic Record Set auto-record on VEMS Mystro.

Creating "Audio Chime" Files

As noted a chime sound and a brief welcome message are played when placing or receiving calls to or from a video conferencing endpoint. You can replace these default audio files by uploading your own recordings that were created in .raw format only. The following steps explain how to create a .raw file on a Windows machine that has an audio recording device.

To generate an audio file in .raw format on a Windows machine:

1. Go to the

Search

box on the

Start

menu, type:

soundrecorder/file outputfile.wav

and press

Enter

. This will launch your audio recording device if present.

2. Record an audio file and save it as outputfile.wav

3. Install the latest version of SoX (Sound eXchange) from http://sox.sourceforge.net

© 2014 VBrick Systems, Inc.

VC Gateway Configuration

4. Convert the recorded outputfile.wav file

to *.raw format by running:

c:\<sox-installed-path>\sox.exe outputfile.wav -r 16000 -e signed-integer -b 16

-c 1 outputfile.raw

where

<sox-installed-path>

is typically

C:\Program Files\sox-14-4-0

or

C:\Program

Files (x86)\sox-14-4-0

. Note that the SoX version you installed may be different than

14-4-0

.

5. Uncheck the Default box next to the appropriate audio selection. This will enable the upload feature. Upload the new outputfile.raw

file and test by placing and receiving a call through the VC Gateway.

DME Admin Guide 123

124 © 2014 VBrick Systems, Inc.

Chapter 11

Logging

Topics in this chapter

Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Logging

The Error Log on the Monitor > Error Log page displays DME status messages as well as

errors. The Access History on the Monitor > Access History page shows files that have been

accessed since the last reset. This page enables or disables logging and sets overwrite rules.

Error Log

Access Log

Logging

Roll log

Shows DME status messages as well as errors.

Shows files that have been accessed since the last reset.

Check to enable the Error Log and/or the Access History. Logged entries are shown the respective Monitor pages. Both logs are enabled by default.

Overwrite the log every nnn

days or every nnn

KB (whichever comes first).

DME Admin Guide 125

126 © 2014 VBrick Systems, Inc.

Chapter 12

Monitor

Topics in this chapter

System Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

RTP Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Multi Protocol Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Relay Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Access History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Upgrade Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Error Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

System Usage

Page Refresh Interval Select the desired page refresh interval from the dropdown.

RTP CPU Load Shows the CPU load on the RTP server.

RTMP CPU Load

Total CPU Load

Disk Usage System

Shows the CPU load on the RTMP server.

Shows the CPU load on both the RTP and RTMP servers.

Total megabytes used and available for DME system resources.

DME Admin Guide 127

Disk Usage Content

Total megabytes used and available for DME content.

RAM Total Shows the physical RAM present on system.

RAM Used Shows the RAM currently being used.

RAM Free Shows the RAM available for use.

Swap Memory Total Shows the total Swap Memory on system.

Swap Memory Used Shows the Swap Memory currently being used.

Swap Memory Free Shows the Swap Memory available for use.

Memory Total

Memory Used

Memory Free

Shows total memory (physical and swap space) available.

Shows physical and swap space used.

Shows physical and swap space free.

RTP Connections

This page shows all RTP users currently connected to the DME. Click on the column header to sort the entries up or down.

128

Display entries From the dropdown, select the number of entries you wish to display on the page.

Page Refresh Interval Select the desired page refresh interval from the dropdown.

Connected Users The DME displays the following information for each connected user. Click on the header field to sort ascending or descending.

• Type – indicates a stream is present.

• IP Address – user IP address.

• Bit Rate – stream bit rate in Kbps.

• Bytes Sent – total bytes sent.

• % Packet Loss – percentage packet loss.

• Time Connected – total time connected.

• Connected To – target IP address.

© 2014 VBrick Systems, Inc.

Monitor

Multi Protocol Connections

This page shows all RTMP users currently connected to the DME. Click on the column header to sort the entries up or down

Display entries From the dropdown, select the number of entries you wish to display on the page.

Page Refresh Interval From the dropdown, select the desired page refresh interval.

Connected RTMP

Streams

The DME displays the following information for each connected stream. Click on the header field to sort ascending or descending.

• Type – indicates a stream is present.

• Stream Type – the following strings are displayed only when data is being streamed. "Active" denotes an inbound stream (i.e. one being generated); "Streaming" denotes an outbound stream.

– In RTMP Active

– In RTP Active

– In TS Active

– Out RTMP Streaming | blank

– Out RTP Streaming | blank

– Out TS Streaming | blank

– Out HLS Active | blank

– Out HDS Active | blank

• IP Address – IP address of connected user.

• Port – port to which user is connected.

• Session ID – unique session ID for connection.

• Packets Sent – number of packets sent.

• Packets Lost – number of packets lost.

• Time Connected – total time of connection.

• Connected To – target IP address.

Relay Status

This page shows the status of all defined relays. Click on the column header to sort the entries up or down

DME Admin Guide 129

Display entries From the dropdown, select the number of entries you wish to display.

Page Refresh Interval From the dropdown, select the page refresh interval.

Connected Relays The DME displays the following information for each connected relay. Click on the header field to sort ascending or descending.

• Relay Name – relay name.

• Source – source IP address.

• Destination – destination IP address.

• Bit Rate – stream bit rate in Kbps.

• Bytes Relayed – total bytes relayed.

Access History

This page shows the file names that have been requested by all users since the last DME reset. It is enabled and rolls over (i.e. overwrites the information) as configured on the

Logging page.

130

Files Requested

Requests

File names requested since the last DME reset.

Number of times the individual file was requested.

© 2014 VBrick Systems, Inc.

Monitor

Upgrade Log

This log shows a history of all DME upgrade activity. Any .rpm upgrades will be reported on this page as successful, incorrectly signed, or failed. These results are explained in more detail

below. For an explanation of how to upgrade your DME, see Software Upgrade on page 151.

Success The .rpm was signed by VBrick and successfully installed.

Not Signed The .rpm you tried to install does not have the correctly signed VBrick key.

Fail Either the .rpm upgrade has already been installed or is not valid for this

DME.

Error Log

The Error Log shows status messages as well as errors. It is enabled and rolls over (i.e.

overwrites the file) as configured on the Logging page. To reset the Error Log manually,

scroll to the bottom of the page (if necessary) and click

Reset Error Log

. If problems occur, you can copy and paste the error text from this page and send to VBrick Support Services via email. You may also be asked to fetch other log files available in DME root via FTP.

DME Admin Guide 131

132 © 2014 VBrick Systems, Inc.

Chapter 13

Maintenance

Topics in this chapter

System Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Disk Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

System Maintenance

Note After a power failure the DME may go into read-only mode and FTB will be disabled.

As a best practice, always run

Reset with Check Disk

after a power failure.

Reset with Check Disk Performs a System Reset (see below) and runs a check disk at startup. Use this option if the system was powered off unexpectedly. Be aware that, depending on the amount of content on the hard drive, a check disk can be time consuming.

Shutdown

Reset

Performs graceful shutdown and removes power. Toggle the power switch on the server to restart.

Resets (i.e. reboots) the appliance. A reset does not change, save,

or reset any configuration parameters.

Note: RTP UDP Auto Unicast connections from a VBrick encoder are not restored after a System Reset. To restore the connection, disable and then enable the RTP transmitter on the encoder.

DME Admin Guide 133

Clear Licenses

Restart Streaming

Service

Clear Cache

Remove Active

Streams

Demo licenses for features are good for 31 days. Use this button to clear a demo license and activate a feature before your demo

license has expired. After clearing licenses, go to the Activate

Feature to activate a new license.

When using VC Gateway lines for audio-only calls you may need to restart the streaming server to subsequently use those lines for

audio/video calls. See VC Gateway Configuration > Incoming

Lines for more information.

Use this button to clear the Internet cache on the DME's internal

HTTP web server so that the web server will start fetching and serving new web pages rather than cached pages. This option works around the default "duration" timeout setting (50 minutes) on the DME web server.

This button will remove all actively configured input and output streams. Should be used in conjunctions with VBrick Support only.

After use, all active streams will need to be disabled and then reenabled to start again.

Disk Status

This page shows the size and status of

Existing Disks

(i.e. those disks that were present originally or were added using the "provisioning" process) and of

New Disks Found

which have not yet been provisioned.

134

Page Refresh Interval • Never – Never refresh page.

• 30 seconds – Refresh page every 30 seconds.

© 2014 VBrick Systems, Inc.

Maintenance

Existing Disks

New Disks Found

Provision

• Disk Name – Disk name.

• Size – Configured size in KB.

• Status – Displays either "Built-in Disk" or "Provisioning" if a provisioning is in progress.

• Disk Name – Disk name.

• Size – Configured size in KB.

Shown only when a new disk has been found. Click the named button to start the provisioning process for that disk. Note that this

step is irreversible. See Disk Provisioning below for more

information.

Disk Provisioning

This topic explains how to provision a new disk in a virtual environment. DME Release 3.1.5 or higher lets you add a new disk to your VMWare virtual environment in order to extend the current content area available in the DME. The default partition for each new disk is 250 GB.

You can add more disks to the provisioned set by adding more virtual disks and repeating the process explained below. The number of disks you can add is limited only by the resources of your server machine.

Notes • Be aware that disk provisioning is irreversible. Once you have added a new virtualized disk, it cannot be removed.

• Always create a VMWare "snapshot" before you begin so that you can revert to you original configuration if anything goes wrong.

• Provisioning a disk is not the same as adding an iSCSI disk to the DME. If you

are adding an iSCSI disk see SAN/iSCSI Setup on page 77.

To add a new disk in a virtual environment:

1. For best results restart the virtual machine with a disk check unless you are sure your disk does not have errors. To run a disk check on the DME:

a. Go to the Maintenance > System Maintenance page.

b. Click on

Reset With Disk Check

.

2. When the DME comes up, shutdown the virtual machine using the

Shutdown

button on

the Maintenance > System Maintenance page.

3. Using the VMWare client tools or other method, create a snapshot of the virtual machine so that you can revert if anything goes wrong.

4. Add a disk to this virtual machine using the VMWare client tools or any other method you use to manage your virtual machines.

5. When done, restart the DME virtual machine.

6. After the restart, go to the Maintenance > Disk Status page.

A new disk will be shown in the

New Disks Found

area and a named button will let you provision the new disk. If you added more than one disk, the button will provision only one disk at a time and you will need to repeat the provisioning process for each additional disk.

DME Admin Guide 135

7. Press the

Provision Disk

button to begin provisioning the new disk as an extension to the existing disk. A pop-up message will indicate approximately how long this will take. (The provisioning time is usually minimal but may take several hours depending on the type of disk being added.) Be aware that this will stop all streaming services from the DME

until provisioning is complete and the device reboots.

136 © 2014 VBrick Systems, Inc.

Maintenance

8. When the provisioning is complete, the DME will reboot, the streaming services will

restart, and the Maintenance > Disk Status page will show the new disk as active and

available for use.

9. Go to the Monitor > System Usage and the

Disk Usage Content

field will show exactly how much space is in use and available for use.

DME Admin Guide 137

138 © 2014 VBrick Systems, Inc.

Chapter 14

Diagnostics

Topics in this chapter

Trace Capture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Trace Capture

The Trace Capture utility creates a TCP dump of network traffic that can be used by VBrick

Support Services when troubleshooting VC Gateway issues. It captures packets based on the criteria you select and can subsequently be viewed in Wireshark or a similar application. As explained below, you run the utility, retrieve the capture file, and send to it VBrick.

Page Refresh Interval Choose how often to refresh the information on the page.

Interface to capture from

• eth0 – this is the same as bond0 if load sharing is enabled on the

IPv4 network interface.

• bond0 – captures a trace across all network interfaces that are enabled.

• any – captures a trace for both external and internal interfaces

(bond0 and lo).

• lo – captures a trace of the local host interface (127.0.0.1) only.

Capture file size Specify the size (default = 50 MB) of the capture file. The capture will terminate when file size reaches this value.

Status Displays

Capturing

while a trace capture is in progress or blank when finished or idle.

Start | Stop Capture Start or stop the capture process.

To create a trace capture:

1. Select an interface from the dropdown.

2. Specify a size for the capture file. You can use the default or the value suggested by

VBrick Support Services.

DME Admin Guide 139

3. Click

Start Capture

and confirm.

4. Run the capture until complete or click

Stop Capture

at any point.

5. FTP to the device and navigate to the trace

folder.

6. The trace file will be in DME root with a name similar to this:

/trace/eth0.pcap

7. Copy the file and send to VBrick Support Services.

140 © 2014 VBrick Systems, Inc.

Chapter 15

Playing DME Streams

Topics in this chapter

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Playing RTSP/RTP Streams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Playing Multicast RTP Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Playing HLS Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Playing Transport Streams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Playing Streams with a Flash Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Overview

DME input and/or output streams can be configured to play on desktops (with a variety of players), set top boxes, and mobile devices at different locations and in a variety of different physical configurations. The DME supports live RTP, Transport Stream, RTMP (Flash), HLS, and HDS streams. It also functions as a progressive download server for .wmv and other files.

Stored VOD files are supported by the onboard RTP and Multi-Protocol VOD servers and added to the DME via FTP. To play these streams you will need a corresponding player.

Often these players are available either as Standalone players or embedded into a web page.

Table 16. DME Protocol Types and Players

Protocol

RTSP/RTP H.264

SDP/RTP H.264

RTSP WM

RTMP, RTMPS

HDS

HLS

Typical Players

StreamPlayer, QuickTime, VLC

StreamPlayer, QuickTime, VLC

Windows Media Player

Adobe Flash Player, JW Player, FLV Player

Adobe Flash Player, JW Player, FLV Player iDevices, QuickTime MAC, VLC

Playing RTSP/RTP Streams

Live or stored RTP streams are playable via unicast in VBrick StreamPlayer, Apple

QuickTime, VLC, and other players using RTSP for stream control. An RTP player can also be embedded on an HTML page. It is possible to utilize either the Multi-Protocol Server or the RTP server to play these streams. As discussed above, for live content the RTP server should be used for optimal stream stability, but if many simultaneous users are expected, the equivalent RTSP server from the Multi-Protocol Server is preferred. Regardless of the server used, to play the live stream an RTSP URL in the following format points to the stream: rtsp://<dme_ip_address:port>/<publishing point>

DME Admin Guide 141

When using the RTP server the port does not need to be identified unless it has been changed from the default 554. Normally, the publishing point format is <streamname>.sdp so, a URL would look like: rtsp://<dme_ip_address>/vbStream1S1.sdp

When using the Multi-Protocol server, the port does need to be identified. The publishing point is the stream name so, an example URL would be: rtsp://<dme_ip_address:5544>/vbStream1S1

Regardless of the server used, playing stored content uses an RTSP URL pointing to the file in the this format: rtsp://<dme_ip_address:port>/<filename>

The RTP server can play files containing a variety of codecs, though it is recommended only for stored content. Again, the port does not need identification unless it has been changed from the default 554. An example URL would be: rtsp://<dme_ip_address>/myfile.mov

In StreamPlayer, enter the full RTSP URL in the IP Address field:

Figure 30. VBrick StreamPlayer

Playing Multicast RTP Streams

You can play multicast RTP streams using an SDP file. An .sdp file is a text file that provides descriptive information about the stream and gives the user's computer instructions for tuning in. In one case (In-8), the SDP file must be manually FTPed to the DME. For other live use cases or stored streams, the SDP file is automatically created on the RTP or RTMP

VOD server. To play streams with an SDP file you will use a URL similar to the following: http://<dme_ip_address>/mystream.sdp

In QuickTime or VLC you open the player and point to the .sdp file. In StreamPlayer you must enter the complete path to the file in the IP Address field and then click

Play

.

142 © 2014 VBrick Systems, Inc.

Playing DME Streams

Playing HLS Streams

HLS streams are typically played on iPhones and other iOS devices using an HTTP URL.

The HTTP URL syntax is shown below. HLS streams can be played directly from the source

DME or a local caching DME. Use the local DME name if it is configured to cache from the source DME.

To play live non-adaptive HLS streams you will use a URL similar to the following: http://<dme_ip_address>/HLS/<stream_name>/ playlist.m3u8

To play live adaptive HLS streams you will use a URL similar to the following: http://<dme_ip_address>/<masterplaylistname>/ playlist.m3u8

To play stored non-adaptive HLS streams you will use a URL similar to the following: http://<dme_ip_address>/<stream_name>/ playlist.m3u8

To play stored adaptive HLS streams you will use a URL similar to the following: http://<dme_ip_address>/<masterplaylistname>/ playlist.m3u8

Playing Transport Streams

Multicast Transport stream playback is defined on the Transport Stream Out page. When

viewing a multicast stream, use a player like VLC to tune in to the stream via a URL similar to the following. (In VBrick StreamPlayer, just use the multicast IP address and port number.) udp://@<multicast_ip_address>:<port>

Alternatively you can play a transport stream via a "served unicast." You will need a player, like VLC or StreamPlayer, that supports delivery of transport stream via RTSP. The recommended RTSP URL for live playback is: rtsp://<source_dme_ip_address:port>/ts/<stream_name>

The recommended URL for stored playback is: rtsp://<source_dme_ip_address:port>/ts/<filename>

The port is required even if not changed from the default (5544). If necessary see Out-2 >

Serve TS via RTSP on page 47 for alternative URLs.

Playing Streams with a Flash Client

You can play live or stored RTMP, RTMPS, or HDS streams from any Flash server including the DME by downloading and installing a desktop Flash player (Figure 31). You can also can embed the player in a web page that will invoke a Flash plugin. Adobe, Long Tail and others have resources on the web explaining how to embed a Flash player in a web page. See http:// www.longtailvideo.com/support/jw-player/13/embedding-flash for a good example.

To play live streams from a DME on a Flash client using RTMP you will use a URL similar to the following: rtmp://<dme_ip_address>/live/<stream_name>

To play stored streams from a DME on a Flash client using RTMP you will use a URL similar to the following: rtmp://<dme_ip_address>/vod/<filename>

A port number is not required, unless the default port (1935) has been changed.

DME Admin Guide 143

144

To play live streams from a DME on a Flash client using RTMPS you use a URL similar to the following: rtmps://<dme_ip_address:port>/live/<stream_name>

To play stored streams from a DME on a Flash client using RTMPS you will use a URL similar to the following. Note the port number is required: rtmp://<dme_ip_address:port>/vod/<filename>

HDS streams can be played directly from the source DME or a local DME via caching. Use the local DME name if it is configured to cache from the source.

To play live non-adaptive HDS streams on a Flash client you will use a URL similar to the following: http://<dme_ip_address>/HDS/<stream_name>/manifest.f4m

To play live adaptive HDS streams on a Flash client you will use a URL similar to the following: http://<dme_ip_address>/HDS/<masterplaylistname>/manifest.f4m

Figure 31. Desktop Flash Player

© 2014 VBrick Systems, Inc.

Chapter 16

Detailed Use Cases

Topics in this chapter

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Configuring a Multicast Relay with an Auto-Unicast Source . . . . . . . . . . . . . . . . . . . . . . . . 148

Configuring a Multicast Relay with a Unicast Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

Overview

These use cases describe all of the steps you will need to perform in order to create a

Multicast RTP Relay. The first example explains how to configure for unicast source; the second example explains how to configure for an auto unicast source. These use cases provide a complete example of the types of things you will need to do to use the DME effectively. The VBrick Distributed Media Engine contains a fully featured RTP server which lets you create an Multicast RTP Relay stream. The relay can be streamed from a unicast source or from an auto unicast source on a VBrick (7000/9000 Series) H.264 encoder. Both of these scenarios are explained in detail on the following pages. For more information about encoder settings and parameters, see the VBrick H.264 Encoder Admin Guide.

Note The multicast relay configuration explained here corresponds to the output stream

described in Out-7 > Relay (Unicast/Multicast) on page 52. The key difference is that

this topic explains how to configure a multicast relay in much greater detail.

Configuring a Multicast Relay with a Unicast Source

This example shows how to use the DME to relay an H.264 unicast stream from a VBrick

H.264 encoder as a multicast stream. Clients will then be able to join the multicast via HTTP to the DME. This example shows how a relay can be streamed from a unicast source on a VBrick

H.264 encoder.

H.264 Encoder Setup

1. Configure a 7000/9000 Series H.264 encoder with a valid RTP stream then configure a transmitter to unicast to the DME (using higher video/audio port values).

2. Configure the transmitter as shown below:

DME Admin Guide 145

DME Setup

1. Create a new Relay.

146 © 2014 VBrick Systems, Inc.

Detailed Use Cases

2. Configure the RTP Relay as follows: a. Enter a

Relay Name

. b. Set the

Status

to Enabled. c. Enter the IP Address as

127.0.0.1

and enter the original .sdp file name.

d. Select

Request incoming stream

. e. Enter the Multicast IP Address from the .sdp file.

f.

Enter the

Output SDP file

name. g. Enter the Video Port value and Multicast TTL.

The user will view the video using QuickTime and entering the HTTP url to the SDP file located on the DME. In the example above the original sdp file is taco-uni.sdp

and the output sdp is taco-uni1.sdp

. So the URL will be http://172.22.2.50/taco-uni1.sdp

.

DME Admin Guide 147

Configuring a Multicast Relay with an Auto-Unicast

Source

The VBrick Distributed Media Engine contains a fully featured RTP server, giving the administrator the ability to provide an RTP Relay Multicast stream. When configured, clients will then be able to join the multicast via HTTP to the DME. This example shows how a relay

can be streamed from an auto unicast source on a VBrick H.264 encoder.

H.264 Encoder Setup

1. Configure the encoder with a valid Auto Unicast (TCP) stream then configure a transmitter to unicast to the DME.

148

2. Configure the transmitter with the following settings: a. Set the

Auto Unicast Dest Port

to the RTSP port of the DME. b. Configure the

Auto Unicast Dest Pub Point Name

to the desired sdp file name. This

.sdp file will be automatically placed in the root folder. (Note: The file name must be appended with .sdp or the auto unicast will fail.) c. Enable the transmitter and verify it is sending to the DME.

DME Setup

1. Configure a new Relay:

© 2014 VBrick Systems, Inc.

Detailed Use Cases

2. Play the Multicast Relay using QuickTime with a URL in the following format. If desired, a URL can be added to the VBrick's external

Announce Settings

on the Program

Configuration > Transmitters page. http://<dme_ip_Address>/<testmulti2.sdp>

DME Admin Guide 149

150 © 2014 VBrick Systems, Inc.

Chapter 17

Other Tasks

Topics in this chapter

Software Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Installing Security Updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Managing Disk Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

Backup and Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

Software Upgrade

You can upgrade the DME software using VBrick's VBDirectory management application and the

VBDMEDownload

upgrade tool. You can launch the upgrade tool from the

Start

menu

(go to Start > All Programs > VBrick > VBDMEDownload) or from VBDirectory. For

details that explain how to use the tool, see the DME Release Notes. To view the history of all

previous upgrade activity, see the Upgrade Log on page 131.

Figure 32. VBDMEDownload Upgrade Tool

Installing Security Updates

Signed VBrick security updates may be periodically available. Do not neglect to install these updates but to avoid impacting performance, install updates only when the system is idle. Do not update the DME with any software except as directed by VBrick.

DME Admin Guide 151

Managing Disk Space

Your system has differing amounts of content storage available depending on the model you purchased. For example the Model 7570 has (6) 300 GB of RAID 5 storage. For best results and to avoid impacting performance it is important to regularly monitor your CPU Load and

Disk Usage on the Monitor > System Usage page.

Figure 33. System Usage Page

Backup and Restore

As a best practice you should periodically save your configuration settings in case they need

to be restored at a later time. Manage Configuration on page 74 explains how to save and

restore the configuration as well as how to reset the DME to the VBrick factory defaults.

152 © 2014 VBrick Systems, Inc.

Chapter 18

Configuring Devices for the DME

Topics in this chapter

VBrick Encoders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

VBOSS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Rich Media Desktop (RMD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Rich Media Studio (RMS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

More Configuration Examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

This topic explains how to configure various VBrick devices to stream to and from the DME.

For more information about these products, see the corresponding VBrick documentation.

All VBrick documentation is posted on the web at www.vbrick.com/documentation. Note that the examples in this topic refer to the following drawing.

Figure 34. Supported Input/Output Streams

DME Admin Guide 153

VBrick Encoders

The following uses cases are supported for streams from 7000/9000 Series VBrick encoders to the DME. Note that regardless of the way the stream is sent to DME, all output use cases are possible. The order of this table corresponds to the recommended transport mechanisms. Note that to maintain KLV, only Transport Stream protocols can be used

(In-4, In-7, Out-2, Out-5) The table refers to Figure 34 on page 153.

RTMP (Flash)

IN-8

RTP

In-2

In-3

In-6

In-8

† KLV data preserved.

Playback Examples

TS

In-4 †

In-7

VEMS Mystro

(Live Entered URL)

RTMP rtmp://<dme_ipaddress>/live/<stream_name>

RTP vbrtsp://<dme_ipaddress>/filename.sdp

TS

HLS vbricksys://<multicast_ipaddress>:port http://<dme_ipaddress>/HLS/ <stream_name>/ playlist.m3u8

HLS

RTP

Multicast http://<dme_ipaddress>/HDS/ <master_playlist>.f4m/ http://<dme_ipaddress>/<multicast_sdp_file.sdp

VBOSS

Example 1

To send a stream from VBrick Encoder > VBOSS > DME > Flash client:

1. Configure an RTMP Transmit from encoder to VBOSS URL.

2. In the DME, configure

E

to

L

(to pull the VBOSS URL).

3. Distribute as Flash: vbrtsp://<dme_ipaddress>/live/<stream_name>

Example 2

To send a stream from VBrick Encoder > DME > VBOSS:

1. Configure an RTP Auto Unicast (

In-2

) from encoder to DME.

2. Configure

RTMP Push (

Out-9) to the VBOSS publishing point.

Rich Media Desktop (RMD)

Requires RMD 1.1 or higher. You can use RMD to send a Flash (RTMP) stream to the

DME. To configure a a Flash stream, launch RMD, go to Broadcast > Broadcast Settings, and configure the following page with the values shown below. (As shown in the example, "live" is the default application name for the DME.) You will also need to click

Set Credentials

and

enter the User Name and Password for the DME's Stream Input Authentication user (default

154 © 2014 VBrick Systems, Inc.

Configuring Devices for the DME

= broadcast | broadcast). When done, go to Broadcast > Start/Stop Broadcasting to start streaming to the DME. You can then use any of the DME output methods to redistribute the

stream. See Configuring DME Streams on page 33 for details.

Figure 35. RMD Broadcast Page

Playback Examples

VEMS Mystro

(Live Entered URL)

VBOSS iOS rtmp://<VODServerIPaddress>/live/mystream rtmp://fml.2D84.edgecastcdn.net/202D84/fls/2D84/mystream http://<dme_ip_address>/HLS/<stream_name>/playlist.m3u8

Rich Media Studio (RMS)

Although the DME is integrated with VBrick RMS v1.3 or higher, for best results, VBrick recommends v1.6 or above.

Table 17. Recommended Streaming Methods

RMS Version

RMS 1.6 †

RMS 1.3 †

Recommended Streaming Method

• See Streaming to the DME with an RTP Auto-Unicast Push

• See Streaming to the DME with an RTMP Push.

• See Streaming to the DME with RMS 1.3 With this method you

will have to copy the .sdp file to the DME every time you modify the RMS video parameters.

† or higher

DME Admin Guide 155

156

Streaming to the DME with RMS 1.6

Streaming to the DME with an RTP Auto-Unicast Push

To configure an RMS stream for a DME:

1. Open RMS and enter a destination address on the Broadcast page. In the

Destination

Address

field (Figure 35) enter the unicast IP address of the DME.

2. Change the source port to a legal port number that is unused on the source RMS.

Note When entering metadata (e.g. Session Info, Origin E-Mail, etc.) be sure to remove any leading spaces.

Figure 36. RMS Broadcast Options (Part 1)

© 2014 VBrick Systems, Inc.

Configuring Devices for the DME

Figure 37. RMS Broadcast Options (Part 2)

3. Enter the DME IP Address as the RTSP Address. Enter the DME Auto Unicast destination port as the RTSP port. You can indicate use of the Auto Unicast listener on either the RTP server or the Multi Protocol server by designating the appropriate DME port. The Multi Protocol server (In-2) is recommended. If password security is enabled the RTSP Username and Password must be entered. Enter an

SDP File Name

. This name will be the stream name for stream redistribution.

4. After starting the session, a live RTP stream will be available in the DME that can be served in a number of ways (see Figure 37). For example, you can reflect the stream as a

multicast relay or auto-unicast it to another DME. See Configuring DME Streams on page 33 for more information.

Figure 38. RMS/DME Integration

DME Admin Guide 157

Playback Examples

VEMS Mystro (Live

Entered URL) iOS vbrtsp://172.1.1.1/vbStream1S1 vbhttp://172.1.1.1/vbStream1T1.sdp

http://<dme_ip_address>/HLS/<stream_name>/playlist.m3u8

Streaming to the DME with an RTMP Push

This topic explains how to configure an RMS-to-DME stream using an RTMP Push output.

This is an alternate improved interface (that requires DME 3.1.1 or higher).

To configure an RTMP Push to a DME:

1. Go to the

Session Properties

page and then click

Outputs

and

Create

.

2. Click on the

Live

icon, highlight

H.264 for Flash

, and click

Next

.

3. Click on the

Options

button, scroll down to

Broadcast (RTMP)

, and expand the pane.

158

4. Configure the

URL

,

Stream

name, and credentials as follows:

URL

Stream

DME IP address in this format: rtmp://<DME_IP_Addr>:1935/live

User configurable stream name that will be shown on Monitor >

Multi Protocol Connections page and used in a Flash player.

Username DME user name from User Configuration > Stream Input Authentication page.

Password DME user name from User Configuration > Stream Input Authentication page.

5. When done click

OK

and

Finish

and the

H.264 for Flash

option will be added to the

Outputs

menu as a selectable output option.

© 2014 VBrick Systems, Inc.

Configuring Devices for the DME

Streaming to the DME with RMS 1.3

You can use RMS to send an H.264 unicast push or a multicast output stream to the DME.

With both methods you will need to publish the .sdp file to the DME

To configure an RMS stream for a DME:

1. Open RMS and enter a destination address on the Broadcast page. In the

Destination

Address

field (Figure 39) enter a multicast IP address (for example 239.2.127.254) or the

unicast IP address of the DME.

Note When entering metadata (e.g. Session Info, Origin E-Mail, etc.) you may need to backspace to the beginning of the field to remove any leading spaces.

DME Admin Guide 159

Figure 39. RMS Broadcast Options (Part 1)

2. Extract the .sdp file. Once the session is active, the .sdp file is automatically created (in the specified folder) by “enabling” the broadcast and name the file using the SDP File

Name().

160

Figure 40. RMS Broadcast Options (Part 2)

3. Verify the .sdp file. When creating an .sdp the information in the file is sourced from the

Broadcast page in RMS. Be aware that any leading spaces (see line 3 below), will cause the

.sdp file to fail when published to the DME. For this reason, be sure to delete leading spaces before publishing.

© 2014 VBrick Systems, Inc.

Configuring Devices for the DME

4. Publish the .sdp file (via FTP) to the root folder on the DME using FTP. After you FTP the file, there will be a live RTP stream in the DME that can be served in a variety of ways (see Figure 37). For example you can reflect the stream as a multicast relay or autounicast it to another DME. See Configuring DME Streams on page 33 for more information.

Playback Examples

VEMS Mystro (Live

Entered URL) iOS vbrtsp://172.1.1.1/vbStream1S1 vbhttp://172.1.1.1/vbStream1T1.sdp

http://<dme_ip_address>/HLS/<stream_name>/playlist.m3u8

More Configuration Examples

The configuration examples on the following pages refer to the configuration diagram in

Figure 34. The examples explain various ways you can configure the following stream types:

RTMP

RTP

Transport Stream

HLS

RTMP

Desired Result

Acquire a RTMP stream from RMD and RMS

Solution

• RMD:

In-1

• RMS:

In-2

Desired Result

Use the stream to create a HLS and multicast RTP output

Solution

• RMD and HLS:

In-1 to Out-6

• RMS and HLS:

in-2 to Out-6

• RMD to Multicast:

In-1 to Out-10 to Out-7

• RMS to Multicast:

In-2 to Out-10 to Out-7

DME Admin Guide 161

162

Desired Result

Acquire a RTMP stream from another source, like VBoss, which is also being archived on VBoss.

Solution

In-5

Archiving on VBOSS not currently supported.

Desired Result

Use the RTMP stream to generate unicast flash streams, and convert it to

RTP to be able to multicast it as well.

Solution

• Unicast Flash:

n-5 to Out-3

• Multicast RTP: I

n-5 to Out-10 to Out-7

RTP

Desired Result

Send announced and unannounced RTP streams from an encoder to the

DME and give it a name in the DME.

Solution

• Unannounced:

In-8

• Announced:

In-5 to Out-10 to Out-7

Desired Result

Use the received RTP stream to create a multicast to a multicast address to play in an enterprise stream player.

Solution

• Unannounced: I

n-8 to Out-7

• Announced:

In-2 to Out-10 to Out-7 (preferred) or In-3 to Out-7

Desired Result

Use the received RTP stream to create a flash stream to play in a Flash player via unicast

Solution

• Unannounced:

In-8 to In-6 to Out-1

• Announced

In-2 to Out-1 (Preferred) or In-3 to In-6 to Out-1

Desired Result

Use the created Flash stream to generate a HLS stream so that the stream can be played on an iPad via unicast.

Solution

• Unannounced:

In-8 to In-6 to Out-6

• Announced:

In-2 to Out-6 (Preferred) or In-3 to In-6 to Out-6

Transport Stream

Desired Result

Send an unannounced Transport stream from an encoder with KLV data to DME and give it a name.

Solution

In-4

Desired Result

Use the name TS stream to send out to 3 other TS destination via RTSP.

Solution

In-4 to Out-2

© 2014 VBrick Systems, Inc.

Configuring Devices for the DME

Desired Result

Use the same TS stream to multicast to a single multicast address.

Solution

In-4 to Out-5 ( T S )

or

In-4

to

Out-10

to

Out-7 (RTP)

Desired Result

Use the same TS stream to play via Flash player.

Solution

In-4 to Out1

Desired Result

Use the same TS stream to create a HLS stream to be played on an iPhone/iPod touch.

Solution

In-4

to

Out-6

HLS

Desired Result

Generate a HLS stream from any source and have a second DME be able to deliver the stream to its HLS clients (vice versa).

Solution

1. Generate a HLS stream: Either (

In-3 or In-8)

to

In-6

to

Out-6

or (

In-2

,

In-6

,

In-5

,

In-1

,

In-4

, or

In-7

) to

Out-6

2. Do so on both DMEs, make sure HLS names are different from each other

3. Modify Caching Alternative Source on DME 1 to have IP address of

DME 2.

4. Modify Caching Alternative Source on DME 2 to have IP address of

DME 1.

5. The URL for both streams available in both DMEs: http://IPofDME1/HLS/stream1/playlist.m3u8

http://IPofDME1/HLS/stream2/playlist.m3u8

http://IPofDME2/HLS/stream1/playlist.m3u8

http://IPofDME2/HLS/stream3/playlist.m3u8

Desired Result

Generate three different streams, coming in three separate ways, from the same source, into a DME to create a master playlist with three streams in reverse bitrate order so that all of them can be played on an iPad. You should use the ideal setting for the best video/audio playable on an iPad.

Solution

1. Use same source type from encoder, not three different types.

2. Select either RTP out as

IN-2

; RTMP out as

In-1

; or TS out as

In-4

.

3. Use Announce Session Override in encoder to name streams

Rate1High, Rate2Mid, Rate3Low if using

In-2

or

In-1

as input.

4. Use the names above in the DME if using

In-4

as input.

5. Add each stream for HLS generation (

Out-6

).

6. Use the same name for master playlist name (e.g. dmeconfig

) to make them part of an adaptive set

Adaptive URL: http://<dme_ipaddr>/dmeconfig/playlist.m3u8

DME Admin Guide 163
