HP Color LaserJet CM4730 Multifunction Printer series
Workgroup performance soars with this fast, compact, award-winning1 colour MFP.
Get reliable print, copy, fax2 and send-to functionality at a surprisingly affordable
price. Enjoy ease-of-use and access to HP and key partner solutions.
The perfect tool for mid-volume workgroups of 6 to 15 users in both small and medium businesses and enterprise environments, this
fast, colour MFP enables them to be more productive with print, copy, send-to functionality, fax (optional), plus HP and key partner
solutions close at hand.
Work more effectively with a colour MFP that delivers the functionality you need.
Get more done with a fast first page out, print and copy speeds of up to 30 ppm for colour and black, two-sided printing at full speed,
HP Color LaserJet
CM4730 Multifunction
Printer
HP Color LaserJet
CM4730f Multifunction
Printer
plus colour scanning. Send and receive documents by adding fax functionality with an internal 33.6 kbps analogue fax card3.
Facilitate document workflow with embedded send to e-mail functionality, and send to folder and fax with optional HP Digital Sending
Software 44. Professional finishing solutions include a stacker/stapler5 and 3-bin mailbox.
Keep costs down with an MFP that saves money initially and over time.
Preserve your budget and still get the functionality you need with this surprisingly affordable MFP which also delivers a low cost per
colour page. Control costs when you choose Original HP print cartridges, which feature consistent, high-quality performance that saves
your business time and money. Get the benefit of colour with no cost penalty: Colour Access Controls let you monitor colour printing by
user or even by application, and choose when and how colour is used in your workgroup
Now you can focus on your business with an MFP that is easy to use and easy to manage.
Use, manage and maintain your device with HP's simple, award-winning Easy Select Control Panel. Take advantage of your MFP’s
features with an intuitive interface that clearly displays all available applications. Enjoy best-in-class networking through the HP Jetdirect
Internal Print Server.
Proactively manage your MFP and save valuable IT time with HP Web Jetadmin fleet management software. Original HP Color LaserJet
print cartridges with built-in intelligence ensure trouble-free printing.
1 Buyer's Lab gave HP a "Pick of the Year" award in December 2006 for "Outstanding Achievement for the User Interface Design of its Multifunction Printers
2 Fax available with HP Color LaserJet CM4730f MFP and CM4730fsk MFP.
3 Available with HP Color LaserJet CM4730f MFP and CM4730fsk MFP
4 HP Digital Sending Software 4 is not included, sold separately
Software is server based, server required
Trial included
HP Color LaserJet
CM4730fsk Multifunction
Printer
5 Available with HP Color LaserJet CM4730fsk MFP only.
HP Color LaserJet CM4730 Multifunction Printer series
Series at a glance
HP Color LaserJet CM4730 Multifunction Printer
● Print speed of up to 30 ppm colour and black
● 600 dpi resolution
● Imageret 3600
● 384 MB RAM
● 533 MHz processor
● 40 GB hard drive
● USB and parallel port
● EIO slot
● three Flash memory card slots
● standard input capacity of 1600 sheets from
100-sheet MP tray and three 500-sheet trays
● 50-sheet automatic document feeder
● automatic two-sided printing
● Colour Access Controls
HP Color LaserJet CM4730f Multifunction Printer
● As base model plus
● 33.6 kbps analogue fax card
HP Color LaserJet CM4730fsk Multifunction Printer
● As base model plus
● 33.6 kbps analogue fax card
● stapler/stacker unit
Q7521A
T1936AA
Recommended accessories
Q7722A
HP 256 MB DDR 200-pin
SDRAM DIMM
J7951G
Q3701A
HP LaserJet MFP Analog Fax
Accessory 300
HP Jetdirect ew2400 802.11g Wireless Print Server
HP LaserJet MFP 500-sheet
Stapler/Stacker
Q7523A
HP LaserJet MFP 3-bin
Mailbox
J7961G
HP MFP Digital Sending
Software 4.0
HP Jetdirect 635n IPv6/IPsec Print Server
C8091A
HP Staple Cartridge Refill
Operating and warranty specifications
Operating temperature:15 to 30° C. Recommended operating temperature:17 to 25º C. Operating humidity:10 to 80% RH. Operating humidity recommended:30 to 70%
RH. Storage temperature:-20 to 40º C. Storage humidity:10 to 90% RH. Noise level per ISO 9296:sound power:LwAd6.7 B(A) (active/printing), 6.3 B(A) (active/copy or
scan), inaudible (ready). Sound pressure:LpAm50 dB(A) (active/printing), 52 dB(A) (active/copy or scan), inaudible (ready)
CISPR 22:2005 / EN 55022:2006 Class A, EN 61000-3-2:2000, EN 61000-3-3:1995, EN 55024:1998, FCC Title 47 CFR, Part 15 Class A / ICES-003, Issue 4 /
GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC and carries the CE-Marking accordingly. ENERGY STAR:Yes
One-year warranty
Operating environment
Certifications
Warranty
Ordering information
HP Color LaserJet CM4730 Multifunction Printer (CB480A)
HP Color LaserJet CM4730f Multifunction Printer (CB481A)
HP Color LaserJet CM4730 MFP, power cord,
As CM4730 MFP plus analogue fax accessory, and
control panel overlay, four print cartridges (one
fax install guide
each: black, cyan, magenta, yellow), software
drivers and documentation on CD-ROM, information
and training CD, in-box documentation (getting
started guide, walk up wall poster, telephone
support flyer)
Accessories, Supplies and Support
Accessories
Service & support
Q7722A
HP 256 MB DDR 200-pin SDRAM DIMM
Q3701A
HP LaserJet MFP Analog Fax Accessory 300
Q7521A
HP LaserJet MFP 500-sheet Stapler/Stacker
HP LaserJet MFP 3-bin Mailbox
Q7523A
HP MFP Digital Sending Software 4.0
T1936AA
C8091A
HP Staple Cartridge Refill
Q5997A
HP LaserJet ADF Maintenance Kit
Supplies
Q6460A
HP Color LaserJet Q6460A Black Print Cartridge
Approximately 12,000 pages at 5% coverage
Q6461A
HP Color LaserJet Q6461A Cyan Print Cartridge
Approximately 12,000 pages at 5% coverage
Q6462A
HP Color LaserJet Q6462A Yellow Print Cartridge
Approximately 12,000 pages at 5% coverage
Q6463A
HP Color LaserJet Q6463A Magenta Print Cartridge
Approximately 12,000 pages at 5% coverage
Q7504A
HP Color LaserJet Q7504A Image Transfer Kit
Q7503A
HP Color LaserJet Q7503A 220V Fuser Kit
Connectivity
J7951G
HP Jetdirect ew2400 802.11g Wireless Print Server
J7961G
HP Jetdirect 635n IPv6/IPsec Print Server
C2946A
HP IEEE 1284-compliant bidirectional parallel cable, 3m
HC119A/E HP Care Pack, 4-Hour, 13x5 Onsite, Hardware
Support, 3 years
HC113A/E HP Care Pack, Next Business Day Onsite, Hardware
Support, 3 years
HC115A/E HP Care Pack, Next Business Day Onsite, Hardware
Support, 5 years
HC114A/E HP Care Pack, Next Business Day Onsite, Hardware
Support, 4 years
UC755PA/PE HP Care Pack, Post Warranty Service, Next Business
Day Onsite, HardwareSupport, 1 year
UC757PA/PE HP Care Pack, Post Warranty Service, 4-Hour, 13x5
Onsite, Hardware Support, 1 year
U2010A/E HP Care Pack, Installation for 1 Network Configuration
for Dept and Color LaserJet printer
For a complete list of supplies, accessories and services, please
refer tohttp://www.hp.com
For workflow, device management and other solutions, please visit
the Global Solutions catalog: www.hp.com/go/gsc
HP Color LaserJet CM4730fsk Multifunction Printer
(CB482A)
As CM4730 MFP plus analogue fax accessory, fax
install guide and stapler/stacker unit
Technical specifications
Print technology
Print speed
Processor
Memory
Print
Fax
Digital sending
Scan
Copy
Media handling
Media types
Interface and connectivity
Operating systems compatibility
Network operating systems compatibility
Minimum system requirements
Standard software
Control panel
Power
Dimensions (w x d x h)
Weight
Printer management
Laser
A4black:Up to 30 ppm, color:Up to 30 ppm. First page out black,< 11 sec (from ready), colour:< 11 sec (from ready). Warm-up time:less than165 sec
Exact speed varies depending on the system configuration, software program and document complexity.
533 MHz. RISC
448 MB: 384 MB RAM and 64 MB fixed memory. Expandable to 512 MB RAM, 2 available Flash memory slots for font cards or third-party solutions. Hard Disk Capacity:Standard, 40
GB
Quality
HP ImageREt 3600
Resolution
Black:Up to 600 x 600 dpi, Color:Up to 600 x 600 dpi
Printer languages
HP PCL 6, HP PCL 5c, HP Postscript level 3 emulation, direct PDF printing (v 1.4), PML (Printer Management Language)
Economical printing
Economode, immediate return to Power-safe mode after each print job due to Instant-on fuser technology (saves electricity). Standard automatic two-sided
printing and N-up printing (saves paper)
Typefaces/fonts
80 internal TrueType fonts scalable in HP PCL and HP Postscript Level 3 emulation; additional font solutions available via Flash memory
Duty cycle (monthly, A4)
Up to 175000 pages
Recommended monthly page
5000 to 9000
volume
Print margins (mm)
Top:4.2 mm. Left:4.2 mm. Right:4.2 mm. Bottom:4.2 mm
Maximum print area
205.9 x 345.6 mm
Modem speed
CM4730:Up to 33.6 Kbps (with optional analog fax accessory); CM4730f:Up to 33.6 kbps; CM4730fsk:Up to 33.6 kbps
Telecom compliance
Telecom: TBR-21:1998; EG 201 121:1998, FCC Part 68; CIT certificate per TBR-21 (Croatia); Spec. for Terminal Equipment No. 023/96 (Israel); MoC
Tec. Requirements plus GOST Telecom series (Russia); TE001, 003, 006 (South Africa)
Fax resolution
Standard:200 x 100 dpi. Fine:200 x 200 dpi. Superfine:300 x 300 dpi. Photo:300 x 300 dpi
Quick dialing
100
File formats
PDF, JPEG, TIFF, MTIFF
Installation
Fast Ethernet (standard), Gigabit (optional), 802.11g wireless (optional), Bluetooth wireless (optional)
Features
Standard:Embedded scan to e-mail
Type
Flatbed, ADF. Colour scanning:Yes
Scan resolution
Optical:Up tp 600 dpi. Enhanced:Up tp 600 dpi
Bit depth
30-bit
Grey scale levels
256
Scannable area
Minimum media size:14.8 x 12.7 cm (from ADF). Maximum media size:12.7 x 14.8 cm (Letter size via the glass), 21.6 x 29.7 cm (Legal size via the ADF)
Copy speed
Up to 30 cpm
Copy resolution
Up to 600 x 600 dpi
Multiple copies
Up to 999
Input:
Capacity
Weight
Size
Tray 1
sheets: 100, envelopes: 20, transparencies: 10 mm 60 to 220 g/m²
A4, A5, B5 (JIS), executive (JIS), 16K, D Postcard
stack
(JIS), envelopes (DL, C5, B5), custom 76 x 127 to
216 x 356 mm
Tray 2
sheets: 500, transparencies: 56 mm stack
60 to 120 g/m²
A4, A5, B5 (JIS), executive (JIS), 16K, custom 148
x 210 to 216 x 356 mm
Tray 3
sheets: 500, transparencies: 56 mm stack
60 to 120 g/m²
A4, A5, B5 (JIS), executive (JIS), 16K, custom 148
x 210 to 216 x 356 mm
ADF
sheets: 50
60 to 120 g/m²
Output:
Sheets: Up to 500. Envelopes: Up to 20
Duplex printing:Automatic (standard)
Paper (plain, preprinted, letterhead, prepunched, bond, recycled, colour, light, intermediate, heavy, extra heavy, rough, glossy, heavy glossy, tough), transparencies, labels, envelopes, card
stock
Bidirectional IEEE-1284C parallel port, Hi-Speed USB 2.0, HP Jetdirect Fast Ethernet Embedded Print Server, 1 open EIO slot, foreign interface harness, host USB accessory port.
Optional:HP Jetdirect internal and external print servers, HP wireless print servers, Bluetooth wireless printer adapter
Microsoft® Windows® XP Home, XP Professional, XP Professional x64, Server 2003; Windows Vista® Ready. Optional:Windows® 2003 and Windows® XP Home and XP Professional;
IPsec on IPv4 only on Windows® 2003 and Windows®. Recent printer drivers and software for all supported operating systems are available at
http://www.hp.com/support/ljcm4730mfp.
Microsoft® Windows Vista™ Compatible, Windows Vista™ Premium, XP, Server 2003, XP, 2003 64-bit, XP 64-bit, 2000 (IPv6 only supported on Windows® 2003 and Windows® XP;
IPsec on IPv4 only on Windows® 2003 and Windows® XP); Novell 5.1 and later; Apple Mac OS 9.x, OS X 10.2 and later; RED HAT Linux 7.x and later; SUSE Linux 8.x and later; HP-UX
10.20, 11.x, 11.i; Solaris® 2.5 and later (SPARC® systems only); IBM® AIX 3.2.5 and later 1; MPE-iX; Citrix® MetaFrame Server; Windows® Terminal Services. Optional:Windows®
2000, Windows® Server 2003 x86, XP x86, Windows Vista™ x86, Vista x64, Windows® Server 2003 x64, XP x64; Mac OS 10.2 and higher
133 MHz processor, 64 MB RAM (Windows® 2000); 233 MHz processor, 64 MB RAM (Windows® XP Home, XP Professional); Pentium® 150, 32 MB RAM (Windows® Me); 550 MHZ
processor, 128 MB RAM (Windows® Server 2003); 220 MB of free hard disk space for Windows®, CD-ROM drive or Internet connection, IEEE 1284-compliant bidirectional parallel port,
USB 1.1 port, USB port (compatible with USB 2.0 specifications). Mac OS 9.x, Mac OS X v 10.1 or higher, 160 MB available hard disk space, CD-ROM drive, USB port
Windows® Installer for 2000 and up x86 and x64; Mac Installer for OS 10.2 and higher. Drivers on the web:Printing system; PCL 6 driver only, PCL 5 driver only, Postscript driver only;
WJA applet; UPD PCL 6; UPD PCL 5, UPD Postscript; Easy printer care; PC Fax Driver
Touch screen graphical display, job control buttons, numeric keypad, LED status lights
Requirements:Input voltage 100 to 127 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz); Input voltage 220 to 240 VAC (+/- 10%), 50/60 Hz (+/-2 Hz). Values subject to change. See
http://www.hp.com/support for current information. Power numbers are the highest values measured using all standard voltages.
Out of package:CM4730:788 x 639 x 1153 mm; CM4730f:788 x 639 x 1153 mm; CM4730fsk:1106 x 639 x 1153 mm. Packaged:CM4730:900 x 815 x 1518 mm; CM4730f:900 x
815 x 1518 mm; CM4730fsk:900 x 815 x 1636 mm
Out of package:CM4730:124 kg; CM4730f:124 kg; CM4730fsk:136 kg. Packaged:CM4730:154.2 kg; CM4730f:154.2 kg; CM4730fsk:169.43 kg
HP Embedded Web Server, HP Web Jetadmin, HP Easy Printer Care Software (Web only), HP LaserJet Utility, HP Universal Print Driver
http://www.hp.com/uk
© Copyright Hewlett-Packard Development Company, L.P. 2007.The information contained herein is subject to change without notice. The only warranties for HP Products and services
are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be
liable for technical or editorial errors or omissions contained herein.
Published in EMEA 10/09 4AA0-9482EEE
