2007
YFZ450 SE
KEY FEATURES:
1 . The YFZ450 Special Edition with hi/lo-speed adjustable
piggyback shocks now comes with all-black with red flames graphic
package or hot flaming graphics.
2 . Front and rear piggyback shocks adjust for high- and low-speed
compression damping—as well as rebound damping and spring
preload.
3 . The lightest, most powerful ATV ever, winner of just about every
magazine shootout, 2005 GNCC and Quadcross Championships, and
ATV Illustrated's Sport ATV of the Year (a tie with our own Raptor
700R).
4 . Most powerful industry-exclusive five-titanium-valve engine and
350-pound dry weight give the YFZ450 the best power-to-weight
ratio of any ATV ever produced.
5 . Ultra-compact, lightweight, high-tensile steel frame with fully
adjustable suspension means YFZ450 is also the best handling race
bred ATV ever produced.
Black/Carbon Flames
$7,449 MSRP
White/Red Carbon Flames
$7,449 MSRP
Manufacturer's Suggested Retail Price (MSRP) shown. Does not include tax, title, prep or destination charges. Actual prices set by dealer.
6 . The YFZ450 comes standard with pushbutton electric starting, a
convenient flip-type parking brake and suspension calibrated for
performance.
2007
FEATURES & BENEFITS
NEW FOR 2007:
Front and rear piggyback shocks adjust for high- and low-speed
compression damping—as well as rebound damping and spring
preload.
—
New, ProTaper aluminum handlebar is light, strong and comfortable.
—
New front brake master cylinder and lever gives excellent feel and
feedback.
—
New, drilled rear brake disc reduces unsprung weight and offers
excellent feel and feedback.
—
A new internal oil jet aimed at the piston bottom keeps things cool
and well lubricated.
—
An improved clutch offers consistent operation and big-time strength.
ENGINE:
449cc liquid-cooled, DOHC four-stroke with five titanium valves
features 95mm bore and 63.4mm stroke for massive power with high
over-rev capacity and crisp, linear throttle response.
—
Large-capacity radiator is optimally mounted in the frame to guard
against damage.
—
Reliable, pushbutton electric start in any gear adds extra convenience.
—
High performance 39mm Keihin FCR flat-slide carburetor with throttle
position sensor (TPS) delivers ultra-precise fuel/air mixing and crisp
throttle response.
—
Additional weight-saving engine features include: magnesium cylinder
head cover and right side crankcase cover; small-design cam chain
tensioner and oil pump; aluminum oil hose; and light CDI ignition
unit.
—
Trick, works-style clutch lever features oversize barrel adjuster for easy,
no tool adjustability of lever/cable play.
—
Dry-sump engine carries oil in an aluminum tank directly in front of the
engine for excellent cooling and optimal protection from rocks or mud.
YFZ450 SE
Smooth-shifting YZ-spec ratchet-type five-speed transmission and
heavy-duty clutch deliver all that power to the rear tires with maximum
efficiency.
Large capacity airbox features no-tool access to the oiled dual foam
filter for easy maintenance.
Ignition coil is integrated into the spark plug cap; extremely light and
compact.
Easy-to-use, toggle link-type handlebar-mounted parking brake can be
set with one hand.
—
CHASSIS/SUSPENSION:
Independent aluminum upper A-arm front suspension features fully
adjustable competition-spec Kayaba piggyback shocks with 9.1 inches
of travel and separate adjusters for preload, rebound and compression
damping.
—
New rear suspension system is YZ linkage-type, controlled by a fully
adjustable Showa shock with 10.6 inches of travel and separate
adjusters for preload, rebound and compression damping.
—
Ultra-rigid cast aluminum swingarm reduces weight and ensures
optimal suspension action.
—
Titanium heat shield is super light and strong.
—
Long travel out back means an excellent ride and handling.
—
Controlled Fill cast aluminum subframe is light and super-strong.
—
Eccentric chain adjuster mechanism simplifies that job, and a twinpiston rear brake caliper provides strong, controllable rear braking.
—
Numerous aluminum components—including the swingarm, upper Aarms, oil tank, grab bars and wheels—help keep overall dry weight
down to a paltry 350 pounds.
—
Lightweight front and rear master cylinders, combined with twin
161mm front discs with twin-piston calipers and single 200mm rear
disc, deliver incredible stopping power with progressive control and
feel.
—
High-performance 21x7R-10 front and 20x10R-9 rear Dunlop radials,
designed specifically for the YFZ450, deliver superb, class-leading
traction.
—
Long, low and narrow YZ-style seat enhances the quick, balanced
steering and optimal rider movement.
—
ADDITIONAL FEATURES:
High-performance stainless steel exhaust header is mated to a USFSapproved spark arrestor.
—
Dual 30-watt multireflector halogen headlights set back in the front
cowl add the perfect menacing appearance. LED taillight is tough,
draws less current and has an incorporated brake light for added
convenience.
—
—
DC ignition system delivers ultra-precise spark and 3D timing for faster,
stronger engine response during hard acceleration.
Large-capacity, 2.6 gallon fuel tank ensures excellent range.
Rugged 45mm-wide serrated footrests provide excellent grip and rider
comfort.
Specifications subject to change without notice. This document contains many of Yamaha's valuable trademarks. It may also contain trademarks belonging to other companies. Any references to other companies or their
products are for identification purposes only, and are not intended to be an endorsement. © 2017 Yamaha Motor Corporation, U.S.A. All rights reserved.
—
yamahamotorsports.com
For Accessories, visit shopyamaha.com
2007
YFZ450 SE
SPECIFICATIONS:
Specifications subject to change without notice. This document contains many of Yamaha's valuable trademarks. It may also contain trademarks belonging to other companies. Any references to other companies or their
products are for identification purposes only, and are not intended to be an endorsement. © 2017 Yamaha Motor Corporation, U.S.A. All rights reserved.
Engine Type
449cc liquid-cooled w/fan, 4-stroke; DOHC, 5
titanium valves
Bore x Stroke
95.0 x 63.4mm
Compression Ratio
11.4:1
Fuel Delivery
Keihin 39mm FCR w/throttle position sensor
Ignition
DC-CDI
Starting System
Electric
Transmission
5-speed; wet multiplate clutch
Drive Train
2WD; sealed O-ring chain, eccentric adjustment
Suspension / Front
Independent double wishbone, w/piggy back High/Lo-speed compression, rebound and threaded
preload adjustment, 9.1-in travel
Suspension / Rear
Cast aluminum swing arm w/rebound,High-/Lospeed compression and threaded preload, 10.6-in
travel
Brakes / Front
Dual ventilated hydraulic disc, twin piston
Brakes / Rear
Ventilated hydraulic disc, twin piston
Tires / Front
AT21x7-10 radial
Tires / Rear
AT20x10-9 radial
LxWxH
72.4 x 46.1 x 42.9
Seat Height
31.9 in
Wheelbase
50.4 in
Maximum Ground
Clearance
4.4 in
Fuel Capacity
2.6 gal
Wet Weight
373 lb
Dry Weight
350 lb
Lighting
Dual 30W Krypton multireflector headlights &
3.9/0.5W brake light
Color
Black/Carbon Flames; White/Red Carbon Flames
*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as
applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is
useful in making real
real--world comparisons with other models.
