1102422L
Thank yc you for purchasing this Samsung product.
„To receive more complete service,
please regi ister: your product a |
features
Active Speaker System
This unit features an Active Speaker System that provides high sound quality in a single slim unit.
This unit does not require any satellite loudspeakers or speaker cabling, which are normally associated with
conventional surround sound systems.
Multi-function Remote Control
The supplied remote control can be used to control the TV connected to this unit.
The remote control has a TV hotkey that enables you to perform various operations with the simple press of a button.
Special Sound mode
You can select from 7 different sound modes (MUSIC, NEWS, DRAMA, CINEMA, SPORTS, GAME, PASS (Original
Sound) depending on the type of content you want to enjoy.
Compatibility with various audio Technologies
This unit employs decoders compatible with Dolby Digital and DTS (Digital Theater Systems).
— Dolby Digital
This is the standard audio signal format used on DVDs and other purely digital media.
This surround technology delivers high-quality digital audio of up to 5.1 discrete channels to produce a
directional and more realistic effect.
— DTS (Digital Theater Systems)
DTS provides a discrete 5.1 CH digital audio signal for both music and movie content and uses less
compression than Dolby Digital for richer sound.
Wireless Subwoofer
Samsung's wireless module does away with cables running between the main unit and the subwoofer.
Instead, the subwoofer connects to a compact wireless module that communicates with the main unit.
3D Depth Sound
The 3D sound feature adds depth and spaciousness to your listening experience.
HDMI transmits video and audio signals simultaneously, and provides a clearer picture.
And the unit supply ARC function so you can listen TV sound with Crystal Surround Air Track by using only HDMI
Cable. (This function is only available if an ARC-compliant TV is connected.)
“в The accessories may look slightly different than those pictured above.
salety information
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK) NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lighting flash and Arrowhead within
Triangle Is a warming sign alerting you of
dangerous voltage Inside the product
The explanation point within the triangle is a
warning sign alerting you of important
instructions accompanying the product.
WARNING
e To reduce the risk of fire or electric shock, do not expose this appliance 10 rain or moisture.
e To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
CAUTION
e Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.
* The Mains plug is used as a disconnect device and shall stay readily operable at any time.
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent
electromagnetic interference with electric appliances, such as radios and televisions, use shielded cables and connectors for connections.
FOC NOTE (for USA)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged 1o try to correct the interference by one or more of the following measures:
e Reorient or relocate the receiving antenna.
e increase the separation between the equipment and receiver.
e Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
e Consult the dealer or an experienced radio/TV technician for help.
Caution : FCC regulations state that any unauthorized changes or modifications to this equipment may void the user's authority to operate it.
Important Safety Instructions
Head hese operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for
uture reference,
1) Read these instructions. 10) Protect the power cord from being walked on or pinched
2) Keep these Instructions. particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
3} Heed all warnings. 5
11) Only use attachment/accessories
4) Follow ail instructions. specified by the manufacturer.
5) Do not use this apparatus near water. 12) Use only with the cart, stand, tripod,
6) Clean only with dry cloth, bracket, or table specified by the
os as manufacturer, or sold with the apparatus.
71 Do not block any ventilation openings. Install in When a cart is used. use caution when
accordance with the manufacturer's instructions. moving the cart/apparatus combination
8) Do not install near any heat sources such as | | to avoid injury from tip-over.
radiators, heat registers, stoves, or other apparatus (including 18) Unplug this apparatus during lightning storms or when unused for
amplifiers) that produce heat. long periods of time.
9) Do not defeat the safety purpose of the polarized or grounding-type 14) Refer all servicing to qualified service personnel. Servicing is
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. if the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet,
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed fo rain or moisture, does not operate normally, or has
been dropped.
KA
| 2.7 inch
3.8 inch A
ge 7 “ежей .
38 inch 3.9 inch
Ensure that the AC power supply in your house complies with the identification sticker located on the back of your product. Install your
product horizontally, on a suitable base (funiture), with enough space around it for ventilation (3-4 inches). Make sure the ventilation slots
are not covered, Do not place the unit on amplifiers or other equipment which may become hot. This unit is designed for continuous use.
in order to disconnect the unit completely from the power supply, remove the main plug from the wall outlet, especially when left unused
for a long period of time.
During thunderstorms, disconnect the AC main plug from the Do not expose the unit to direct sunlight or other heat sources.
wall outlet. Voltage peaks due to lightning could damage the unit. This could lead to overheating and malfunction of the unit.
Protect the product from moisture (i.e. vases) , and excess heat The batteries used with this product contain chemicals that are harmful to
(e.g.fireplace) or equipment creating strong magnetic or electric fields the environment.
Disconnect the power cable from the AC supply if the unit malfunctions. Do not dispose of batteries in the general household trash.
Your product is not intended for industrial use. Use of this product is for
personal use only.
Condensation may occur if your product has been stored in cold tem-
peratures. If transporting the unit during the winter, wait approximately 2
hours until the unit has reached room temperature before using.
contents
10
11
12
13
13
14
14
15
17
17
20
21
22
Features
What's included
Safety warnings
Precautions
Before reading the user's manual
Front panel
Rear panel
Tour of the remote control
Installing the wall mount
Connecting the wireless subwoofer
Attaching the toroidal ferrite core to the power
cord of the subwoofer
Installing toroidal ferrite to subwoofer
Use iPod/iPhone with a wireless dock cradle
for iPod/iPhone (Sold Separately (HT-WDC10))
How to link the wireless transmitter with the
main unit
Connecting the Crystal Surround Air Track
Basic functions
Advanced functions
Software upgrade
Troubleshooting
Specifications
getting started
Make sure to check the following terms before reading the user manual.
icons that will be used in manual
40 “Caution -| This involves a case where a function does not operate or settings may be
Les | AMÓN | canceled.
e “Note This involves tips or instructions on the page that help each function operate.
Galvis ONILIJO e
About the use of this users manual
1) Be sure to be familiar with Safety Instructions before using this product. ( See page 4)
2) If a problem occurs, check the Troubleshooting. ( See page 21)
Copyright
©2011 Samsung Electronics Co.,Ltd.
All rights reserved; no part or whole of this user's manual may be reproduced or copied without the prior
written permission of Samsung Electronics Co.,Ltd.
descriptions
© Displays the current mode.
Selects the HDMI, Optical, Audio or W.iPod input.
~~ Seleotsthe sound mode!
‚3 SOUNDMODE (MUSIC, NEWS, DRAMA, CINEMA, SPORTS, GAME, PASS
1 Orginal Sound)
Controls the volume level,
5) POWER BUTTON Tums the Crystal Surround Air Track on and off
= When you turn on the power of this unit, there will be a 4 to 5 second delay before it
reproduces sound.
1 “(FOR S/W UPDATES © You can update this unit's software through the USB port.
2 “AUDIOIN JACK = Connect to the analog output of an external device.
(9) о ~ Connect to the digital (optical) output of an external device.
LJ REAR MR REA - cable.
(4) “HDMI OUT JACK т = Outputs digital video and audio signals simultaneously using an HDMI
HDMI cable.
~~ Receives digital video and audio signals simultaneously using an
© Plug the power supply cable into the AC wall outlet.
= When disconnecting the power cable from the wall outlet, hold the plug.
Do not pull the cable.
= Do not connect this unit or other components to the main power until all connections
between components are complete.
о
Го
(OR
=
7
= с
D
emote control
TV POWER BUTTON
Turns your Samsung TV on
POWER BUTTON
Turns the Crystal Surround Air
Track on and off, and off,
TV INFO TV CHANNEL
Use this to display the TV Switches between the available
channel information. TV channels.
VOLUME SOUND MODE
Adjusts the volume level of the Selects the sound mode.
unit. (MUSIC, NEWS, DRAMA,
CINEMA, SPORTS, GAME,
MUTE fun i PASS (Original Sound)
Mutes the sound from the
unit. Press again to restore
the sound to the previous
volume level.
3D SOUND
This feature adds depth and
spaciousness to the sound.
SMART VOLUME
Regulates and stabilizes the
volume level against a drastic
volume change.
DIMMER, DRC
You can control the brightness
of the Display.
You can use this function to
enjoy Dolby Digital sound when
watching movies at low volume
at night (Standard, MAX, MIN).
1 INPUT SELECT
Selects the HDMI, the Digital
(Optical), the Audio or the W.
iPod input.
M 1 AUTO POWER
— Anynet+
AUDIO
This button allows you to
choose to listen to audio from
the Air track or your TV.
Ps 5 Ss JW LEVE L, AV SYN Cc
Adjusts the Subwoofer level.
Used to help sync video to
audio when connected to a
digital TV.
Synchronizes the Air Track via Optical
connection via the Optical jack so it
turns on automatically when you tum
Anynet+ is a function that enables you
to control other Samsung Devices with
your Samsung TV's remote control.
The remote control can operate TVs made by SAMSUNG only.
= Depending on the TV you are using, you may not be able to operate your TV with this
remote control. In this case, operate the TV using the TV's remote control.
Installing batteries in the Remote Control
> = “Replace tr the € cover. E
~ oo Assuming typical Tv usage, B
the batteries last for about
1. Lift the cover at the back de 2. “Install two AAA € size > batteries. a.
the remote control upward a as Se “Make sure to match the + and — "end -
Operation Range of the Remote Control
The remote control can be used up to approximately 25 feet (7 meters) in a straight line. It can also be operated at a
horizontal angle of up to 30° from the remote control sensor.
CONNECTIONS
You can use the wall mount bracket to mount this unit on a wall,
Installation Precautions
e Do not install on a place other than a vertical wall.
e For the installation, avoid a location with high temperature or humidity, or wall that cannot sustain the
weight of the set.
e Check the strength of the wall. If the strength of the wall is insufficient for the product installation, make
sure to reinforce the wall before the installation.
e Check the material of the wall. If the wall is made of plaster board, marble, or iron board, purchase and
use the appropriate fixing screws.
e Cables connecting to external devices need to be connected to the set before installing.
e Be sure to turn off and unplug the unit before installation. Otherwise, it may cause electric shock.
“SNOLLOINNOS e
1. Place the wall mount bracket on a wall surface and then
secure it with two screws (not supplied).
2. Then, fit the unit into the corresponding slots of the wall
mount bracket. For secure installation, make sure the
mounting studs slide firmly down into the bottom of the
slots.
3. This is the completion of the suggested wall mount
installation.
2 inches (5 cm) or more
Do not hang onto the installed unit and avoid any impact to the unit.
= Secure the unit firmly to the wall so that it does not fall off. If the unit falls off, it may result in
an injury or damage to the product.
= When the unit is installed on a wall, please make sure that a child does not pull any of
connecting cables, as it may cause it to fall.
= For the optimal performance in a wall mount installation, keep the speaker system at least
2 inches (b cm) distant from the TV.
The Subwoofer's linking ID is preset at the factory and the main unit and sub should link (connect wirelessly)
automatically when main unit is turned on. If the link indicator does not light when main unit and subwoofer are
turned on, please set the ID by following the process below.
1. Plug the power cords of the main unit and subwoofer into an AC power supply.
2. Press the ID SET button on the back of the subwoofer with a small, pointed object for 5 seconds.
e The STANDBY indicator is turned off and the LINK indicator (Blue LED) blinks quickly.
STANDBY
LINK
3. While the main unit is powered off (STANDBY mode), press
MUTE on the remote control for 5 seconds.
4. The Power Indicator on the main unit lights off and on, then
returns to STANDBY mode.
e The main unit and the subwoofer are now linked (connected).
e The Link indicator (blue LED) on the subwoofer is turned on.
e You can enjoy better sound from the wireless subwoofer by
selecting the sound mode. ( See page 18)
Before moving or installing the product, be sure to turn off the power and disconnect the power
cord.
“в If the main unit is powered off, the wireless subwoofer will be in the standby mode and the
STANDBY LED on the upper side will come on after 30 seconds Link indicator (Blue LED)
blinking.
« If you use a device that uses the same frequency (5.2GHz or 5.8GHz) near the system, some
sound interruption may be heard due to interference.
= The transmission distance of the wireless signal between the main unit and sub is about 33 ft.,
but may vary depending on your operating environment. If a steel-concrete or metallic wall is
between the main unit and the wireless subwoofer, the system may not operate at all, because
the wireless signal cannot penetrate metal.
= |f the main unit doesn't make wireless connection, follow steps 1-4 above to retry the
connection between the main unit and wireless subwoofer.
= The wireless receiving antenna is built into the wireless subwoofer. Keep the unit away from
water and moisture.
= For optimal listening performance, make sure that the area around the wireless subwoofer
location is clear of any obstructions.
If you attach a Toroidal ferrite core to the power cord of the Subwoofer, it
will help to prevent RF interference from radio signals.
1. Pull the fixing tab of the Toroidal ferrite core to open it.
2. Make three loops in the power cable of the subwoofer.
3. Attach the Toroidal ferrite core to the Subwoofer power cord as the figure
shows and press it until it clicks.
N J
Lift up to release the lock and open the core,
\ J
Close the lock back. Make two rounds on the coll with the power cable,
(Start winding at 5-10cm away from the switch),
You can enjoy finer quality of music through the speaker by sending ¡Pod/iPhone's audio signal using a
Wireless Transmitter.
To link the main unit with wireless transmitter, you have to make ID setting when both main unit and wireless
transmitter are turned on.
Turn on the main unit and connect the iPod/iPhone to the Wireless transmitter.
Then press INPUT SELECT button on the remote control to select "W iPod" mode.
The INPUT SELECT mode of the main unit will switches as follows.
Repeatedly press DIGI 1 = DIGI.2 = ANALOG = VW ¡Pod =» HDMI.1 = HDMI.2 ( See page 19 )
The Sound bar will not be turned off if iPod/iPhone is not connected to the Wireless Transmitter.
For more information on HT-WDCH0, refer to the HT-WDC10’s user manual.
Set an ID of the Subwoofer before setting a Transmitter ID. ( See page 12)
1. Turn off your Home Theater (HW-D550, HW-D551).
2. Press the hold "3D SOUND" button on the remote control for 5 seconds.
The standby light on the HW-D550, HYY-D551 will blink once.
3. Connect the iPod/iPhone to the Wireless transmitter,
4. Turn on the iPod/iPhone. Press the "ID SET" button on the back
of the Wireless transmitter for 5 seconds. The link light on the
wireless transmitter will blink fast. e
5. Turn on your Home Theater(make sure the wireless transmitter's Link
LED in ON). To listen to music from your iPod/iPhone over the Home
Theater, select the iPod mode as the Home Theater's source,
e You can control the speaker volume of iPod/iPhone with a
volume wheel or a volume bar.
e \When iPod/iPhone is stopped or in a power saving mode, a
Wireless transmitter is turned to the Sleep Mode.
When iPod/iPhone is turned to the Deep Sleep Mode, the
Wireless transmitter is off.
E J = If you use the main unit nearby a wireless device such as a laptop computer, an AP, or Wifi,
any unstable operation error can happen.
= Do not pairing the subwoofer and iPod/iPhone at the same time. If you pairing at the same
time, iPod/iPhone and subwoofer may not connect to the Sound bar.
iPod/iPhone MODELS THAT CAN BE USED WITH THIS PRODUCT
iPod touch
(1st, 2nd, 3rd, and 4th | IPod classic | ¡Pod with video
generation}
iPod nano
(1st, 2nd, 3rd, 4th, 5th, iPhone 4 iPhone 3GS
and 6th generation)
iPhone 3G iPhone
“Made for iPod," and “Made for iPhone” mean that an electronic Made for
accessory has been designed to connect specifically to IPod or 5 iPod “iPhone
IPhone, respectively, and has been certified by the developer to meet
Apple performance standards. Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards. Please note that the use of this accessory with
IPod or ¡Phone may affect wireless performance.
«Phone, iPod, iPod classic, IPod nano, and iPod touch are trademarks of Apple Inc., registered in
the U.S. and other countries.
# The volume control may not be operated normally except at the referred models. If there is any error
happened at the models above, please update the software of iPod/iPhone at the lastest version.
NECTING
HDMI is a standard digital interface for connection to such devices as a TV, projector, DVD player, Blu-ray
player, set top box and more.
HDMI removes any loss of signal from analog conversion, enabling you to enjoy video and audio sound quality
as it was originally created in the digital source.
HDMI OUT
(ARC) HDMI Cable
| lu TT)
“SNOLLOINNOS e
В HDMI IN
C type A type
{Small Side) (Large Side)
HDMIIN 1,2
HDMI Cable ‚|
ama) Ctype A type HDMI OUT |
(Small Side) (Large Side) | Digital Devices
HDMI OUT (ARC)
e [he ARC function will be activated in the DIGI.1 mode.
e Connect an HDMI cable from the HDMI OUT jack on the back of the product to the HDMI IN jack on your TV.
e This product supports the ARC (Audio Return Channel) functions via an HDMI cable. Note that the ARC function is
supported by the HDMI QUT (ARC) port only.
The ARC function allows digital audio to output via the HDMI QUT (ARC) port. It can be enabled only when the Air
Track is connected to a TV that supports the ARC function.
®
e Anynet+ must be turned on.
AND,
HDMIIN1,2
Connect an HDMI cable from the HDMI IN jack on the back of the product to the HDMI OUT jack on your digital
devices.
The small side of the HDMI cable is connected with the Air Track.
= The provided accessory HDMI cable is for connecting SAT and TV. In case of connecting
devices having distance longer than the provided cable, purchase an A-to-C (Min) type cable.
= When buying HDMI cable for connecting source devices, choose A-to-C (Mini) type cable
of enough length for the connection.
This section explains two ways (digital and analog) of connecting the unit to the TV.
This unit is equipped with two optical digital jacks and one audio analog jack for connecting a TV.
AUDIO IN
Audio Cable
DIGITAL AUDIO IN 1,2
Optical Cable
Cn BD/DVD player/
Set-top box/
Game console
AUDIO IN
Connect AUDIO IN on the main unit to the AUDIO OUT of the TV or Source Device.
Be sure to match connector colors.
or,
DIGITAL AUDIO IN (OPTICAL) 1,2
Connect the Digital Input on the main unit to the OPTICAL OUT of the TV or Source Device.
= Do not connect the power cord of this product or your TV to the wall outlet until all
connections between components are complete.
= Before moving or installing this product, be sure to turn off the power and disconnect the
power cord,
= |f you select "ANALOG" without connecting the Audio Cable, the set is turned off automatically
after 20 minutes.
“в [fa TV or any device connected to Air Track with the optical cable is off and there is no
digital input, the Air Track is turned off after 20 minutes. (If there has been no input signal
for over 20 minutes from DIGITAL AUDIO IN 1 or 2, the Air Track will be turned off.)
= When Air Track isn't linked with HT-WDC10 model in the W.iPod mode, Air Track will tum
off after 20 minutes.
tunctons
1. Touch POWER (ch) on the front panel.
or,
Press POWER on the remote control to turn on the power.
2. Touch POWER ((b) on the front panel.
or,
Press POWER on the remote control again to turn off the power.
Adjusting the volume
Touch VOLUME +/- on the front panel.
or,
Press VOLUME +/- on the remote control to increase or decrease the
volume level.
e The numeric value of the volume level appears in the front panel display.
= The volume level increases or decreases when you press VOLUME +/-.
« If vou want to enjoy the sound only from the Crystal Surround Air Track,
you must tum off the TV's speakers in the Audio Setup menu of your
TV. Refer to the owner's manual supplied with your TV.
This is useful when answering a doorbell or telephone call.
1. Press MUTE (0X ) on the remote control to mute the sound.
2. Press MUTE on the remote control again (or press VOLUME +/-) to
restore the sound.
The 3D sound feature adds depth and spaciousness to the sound by using
3D SOUND button.
Press 3D SOUND on the remote control.
e Each time the button is pressed, the selection changes as follows :
3D SOUND ON =» 3D SOUND OFF
2 When you tum on the 3D Depth Sound, the Sound Mode will
automatically change to PASS.
Using the sound mode
You can select from 7 different sound modes (MUSIC, NEWS, DRAMA,
CINEMA, SPORTS, GAME, PASS (Original Sound) depending on the type of
sources you want to enjoy.
Press SOUND MODE on the remote control €,3> or touch SOUND MODE
on the front panel repeatedly to select the sound mode you want.
e Select PASS mode If you want to enjoy the original sound.
« |t is recommended that you select a Sound Mode based on the
source material and your personal taste.
= When you choose the Sound Mode (except PASS), the 3D
Depth Sound will automatically be turned OFF.
1. Press TV POWER on the remote control of this unit.
2. Press TV INFO on the remote control to display the TV channel information.
3. Press TV CH on the remote control to select the TV channel.
= The remote control can operate TVs made by SAMSUNG only.
function
The Crystal Surround Air Track is automatically tured on when you tum the
power on of a TV or any device connected to the Air Track with the optical cable.
Press AUTO POWER on the remote control of this unit,
e Auto power link function turns on and off each time you press AUTO
POWER.
AUTO POWER Ti NK UT Displ ay TTT |
ON POWER LINK ON
OFF POWER LINK OFF
“в [fa TV or any device connected to Air Track with the optical
cable is off and there is no digital input, the Air Track is turned
off after 20 minutes.
= Only if Anynet+ function is ‘off, the Unit will work.
-L function
You can control the base volume with S/W Level button on the Remote
control.
1. Press the S/W LEVEL button on the Remote control.
2. “SW 00” is appeared on the Display.
3. Press “+” on the LEVEL key if you want to increase the subwoofer
volume. You can set it from SW+01 to SW+06.
4. Press “=” on the LEVEL key if you want to decrease the subwoofer
volume. You can set it from SW-01 to SW-06.
Video may look slower than the audio if it is connected with digital TV.
If this occurs, adjust the audio delay time to match the video.
Press AY SYNC +/-. button on the remote control of this unit.
e You can use +, - button to set the audio delay time between O ms and
300 ms.
This feature balances the range between the loudest and quietest sounds.
You can use this function to enjoy Dolby Digital sound when watching
movies at low volume at night.
Press DRC on the remote control of this unit.
“SNOLLONNA
e Each time the button is pressed, the selection changes as follows :
DRC MIN = DRC STANDARD = DRC MAX
function
This feature control the brightness of the Display.
Press DIMMER on the remote control of this unit.
e Fach time the button is pressed, the selection changes as follows :
DIMMER ON = DIMMER OFF
function
This will regulate and stabilize the volume level against a drastic volume
change in case of a channel change or scene transition.
Press S.VOL on the remote control of this unit.
e Fach time the button is pressed, the selection changes as follows :
SMART VOLUME ON = SMART VOLUME OFF
=) on the front panel repeatedly to select the HDMI, Optical Digital, Audio
input or W.iPod input.
Optical Digital input
Р 9 Р DIGI.2
Audio input ANALOG
iPod mode W.iPod
HDMI. 1
HDMI input
HDMI.2
= Although it appears on the input mode display, IPod connection is not
possible with this model. It is only available with model HT-WDC10
(sold separately)
Anynet+ is a function that enables you to control other Samsung Devices with
your Samsung TV's remote control.
Anynet+ function turns on and off each time you press Anynet+.
1. Connect the product to a Samsung TV with the HDMI cable.
(See page 15)
2. Set the Anynet+ function on your TV. (See the TV instruction manual
for more information.)
= The Anynet+ function supports some buttons of the remote control.
(TV POWER, TY INFO, TY CH)
= Depending on your TV, certain HDMI output resolutions may not
work.
“ Please refer to the user's manual of your TV. Please check the
Anne" logo (If your TV has an Anysee: logo, then it supports
Anynet+ function.)
button
This button enables you to select between listening to audio from your TV
or audio from the Air Track when connected via HDMI.
Press AUDIO on the remote control of this unit.
AU DIO M ODE - MODE - ; - - - o SL 5 croll Displ ay Be : : : = = : = - o Dis pl ay - = : = =
HDMI IN ТУ HDMI AUDIO TV SND TV
AVR HDMI AUDIO AVR HDMI
ARC ТУ SOUND TV S MUTE
AVR SOUND AVR TV ARC
Samsung may offer upgrades for the Crystal Surround
Air Track's system's firmware in the future.
Please visit Samsung.com or contact the Samsung call center
to receive information about downloading upgrades and
using a USB drive.
Upgrades will be possible by connecting a USB drive to the
USB port located on your Air Track.
2. Insert a USB drive containing the firmware upgrade into the USB port on the back of the main unit.
= Please be careful to not disconnect the power or remove the USB drive while upgrades are being applied. The
main unit will turn off automatically after completing the firmware upgrade.
When software is upgraded, settings you have made will return to their default (factory) settings. We recommend
you write down your settings so that you can easily reset them after the upgrade.
= |f the firmware fails to upgrade, we recommend formatting the USB data in FAT16 and trying again.
= For upgrading purposes, do not format USB data in NTFS because it is not a supported file system.
= Depending on the manufacturer, the USB may not be supported.
troublesnootina
Before requesting service, please check the following.
The ur unit wil not tum on. uu
® |5 the power cord plugged
Into the outlet?
* Connect the power plug to
the outlet.
- e |s there static electricity in
the air?
e Disconnect the power plug
and connect it again.
© e |s the unit properly
connected to your TV?
- | e |s the Mute function on?
“| e Is the volume set to
minimum”?
e Connect it correctly.
e Press the Mute button to
cancel the function.
e Adjust the volume.
Picture does. not appear o on a atv
when the function is selected.
® |5 the TV connected
property?
e Connect it correctly.
ко e Are the batteries drained?
‘| e Is the distance between
remote control and main unit
too far?
e Replace with new batteries.
e Operate at a close distance.
Thes sound from the elefüright
channels i is reversed.
= e Are the left/right audio
output cables from the TV
connected properly?
e Check the left/right channel
and connect it/them
correctly.
_ DNILOOHS3TENOEL
e temperature range oo © +41°F to +95°F
Operating humidity range o “10 % to 75 %
Rated output Main unit - 80W/CH, 40, THD = 10%, 1kHz
o Subwoofer с | 150\М ЗО, THD = 10%, 100HZ
Analog input EE “ 20Hz- 20kHz(+30B)
Digital input/48kHz. PCM o - 20HZ- 20kHz(+3dB)
* S/N ratio, distortion, separation and usable sensitivity are based on measurement using AES (Audio
Engineering Society) guidelines.
* Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice
- Weight and dimensions are approximate.
This SAMSUNG brand product, as supplied and distributed by Samsung Electronics America, Inc. (SAMSUNG) and delivered new,
in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and
workmanship for a limited warranty period of;
One (1) Year Parts and Labor*
(*90 Days Parts and Labor for Commercial Use)
This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To
receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service
can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as
proof af purchase to SAMSUNG or SAMSUNG's authorized service center. Transportation of the product to and from
the service center is the responsibility of the purchaser.
SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts
or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the
property of SAMSUNG and must be retuned to SAMSUNG. Replacement parts and products assume the remaining original warranty,
or ninety (90) days, whichever is longer.
SAMSUNG's obligations with respect to software products distributed by SAMSUNG under the SAMSUNG brand name are set forth in the
applicable end user license agreement. Non-SAMSUNG hardware and software products, if provided, are on an “AS 15” basis.
Non-SAMSUNG manufacturers, suppliers, publishers, and service providers may provide their own warranties.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, and except to the extent
otherwise expressly provided for in this statement, noncommercial use of this product, and shall not apply to the following, including,
but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not
intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning or other
acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs,
external wiring or connectors not supplied and authorized by SAMSUNG, or which damage this product or result in service problems;
incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions, cleaning,
maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal or reinstallation;
reception problems and distortion related to noise, echo, interference or other signal transmission and delivery problems. SAMSUNG
does not warrant uninterrupted or error-free operation of the product.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES
WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND
NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS
PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE
TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED
BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS
BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF
ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG
AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY
FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER'S PROPERTY AND TO OTHERS AND THEIR PROPERTY
ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY
THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
To obtain warranty hardware service, please contact SAMSUNG customer care center,
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG
customer care center.
Gr тейса
Canada 1-800-SAMSUNG (726-7864) | www.samsung.com
Mexico 01-800-SAMSUNG (720-7864) | www.samsung.com
USA 1-800-SAMSUNG (726-7864) | www.samsung.com
a Latin America MN NINA
Argentine 0800-333-3733 WWW.Samsung.com
Brazil 0800-124-421 / 4004-0000 WWW.Samsung.com
Chile 800-SAMSUNG (726-7864) www. samsung.com
Colombia 01-8000112112 WWW.Samsung.com
Costa Rica 0-800-507-7267 WWW.Samsung.com
Dominica 1-800-751-2676 WWW.Samsung.com
Ecuador 1-800-10-7267 www. samsung.com
El Salvador 800-6225 WWW.Samsung.com
Guatemala 1-800-299-0013 WWW.Samsung.com
Honduras 800-7919267 WWW.Samsung.com
Jamaica 1-800-234-7267 WWW.Samsung.com
Nicaragua 00-1800-5077267 www. samsung.com
Panama 800-7267 WWW samsung com
Peru 0-800-777-08 WWW samsung com
Puerto Rico 1-800-682-3180 WWW.Samsung.com
A, & 1-800-SAMSUNG (726-7804) | www.samsung.com
Venezuela 0-800-100-5303 WWW.Samsung.com
TR 0 —
Albania 42 27 5755
Austria 200 mo (7267864, WWW samsung.com
Www.samsung.com/
be (Dutch)
Belgium 02-201-24-16 at con
be fr (French)
Bosnia 05133 1999 -
Bulgaria 07001 33 11 WWW.Samsung.com
Croatia 062 SAMSUNG (062 726 7864) | www.samsung.com
800-SAMSUNG (800-726786)
Czech Samsung Zrt, Ceská organizatni | yy samsung.com
siozka, Oasis FHorenc, Soko-
lovska394/17, 180 00, Praha 8
Denmark 70701870 WWW.Samsung.com
Finland 030 - 6227 515 www. samsung.com
France 01 48 63 00 00 WWW samsung com
Germany Co Мо (726-7864 www.samsung.com
Hungary 06-80-SAMSUNG (726-7864) | www.samsung.com
Italia 800-SAMSUNG (726-7864) WWW.Samsung.com
Kosovo +381 0113216859 -
Luxemburg 26103710 WWW.Samsung.com
Macedonia 023 207 777
Montenegro 020 405 888
Netherlands (0900 7267264 (€ 0,10/Min) Www.samsung.com
Norway 815-56 480 WWW. samsung.com
Poland ; oo pa (172678) www samsung.com
Portugal 80820-SAMSUNG (726-7864) | www.samsung.com
1. 08010 SAMSUNG (72678) -
doar cin rejeaua Romtelecom,
Rumania tarif local www. samsung.com
2. 021.206.01.10 - din orice
retea, tarif normal
Serbia 7864) amsung ( www.samsung.com
Slovakia 0800-SAMSUNG (726-7864) www.samsung.com
Spain 902-1-SAMSUNG (902 172 678) www.samsung.com
Sweden 0771 726 7864 (SAMSUNG) www.samsung.com
, . www. samsung.com/ch
Switzerland ve (7267864, aw samsung.com/
Sh ch_fr/(French)
UK 0330 SAMSUNG (7267864) www.samsung.com
Fire 0818 717100 www.samsung.com
Lithuania 8-800-77777 www.samsung.com
Latvia 8000-7267 www.samsung.com
Estonia 800-7267 www.samsung.com
E CIS con PTT TT TT ST SET TS
Russia 8-800-555-55-55 www.samsung.com
Georgia 8-800-555-555
Armenia 0-800-05-555
Azerbaijan 088-55-55-555
Kazakhstan GSM. 7709) 0-55-500 www.samsung.com
Uzbekistan 8-10-800-500-55-500 www.samsung.com
Kyrgyzstan 00-800-500-55-500 WWW.samsung.com
Tadjikistan 8-10-800-500-55-500 www.samsung.com
www samsung.ua
Ukraine 0-800-502-000 www.samsung.com/
ua ru
Belarus 810-800-500-55-500
Moldova 00-800-500-55-500
“a Asia Pacific НАМ
Australia 1300 362 603 www.samsung.com
New Zealand 0800 SAMSUNG (0800 726 786) | www.samsung.com
China 400-810-5868 / 010-6475 1880 | www. samsung.com
www.samsung.com/hk
Hong Kong (852) 3698 4698 www.samsung.com/
hk_en/
nda 1600 3000 8262 / 1800 266 69 | Sang on
Indonesia Lea 7777 www. samsung.com
Japan 0120-327-527 WWW.samsung.com
Malaysia 1800-88-9999 www.samsung.com
1-600-10-SAMSUNG(726-7864) /
Philippines | “400.8 SAMSUNG 725-7804) Www.samsung.com
02-5805777
Singapore 1800-SAMSUNG (726-7864) www.samsung.com
Thailand 1800-29-3232 / 02-089-3232 | www samsung.com
Taiwan 0800-329-999 www.samsung.com
Vietnam 1 800 588 889 www.samsung.com
= Middle East o a NA С
Bahrain 8000-4726 www.samsung.com
Egypt 08000-726786 WWW.samsung.com
Jordan 800-22273 www.samsung.com
Morocco 080 100 2255 Www.samsung.com
Oman 800-SAMSUNG (726-7864) www.samsung.com
Saudi Arabia 9200-21230 www.samsung.com
Turkey 444 77 11 www.samsung.com
UAE 800-SAMSUNG (726-7864) www.samsung.com
a Africa TI TATI TA
Nigeria 0800-SAMSUNG (726-7864) www.samsung.com
South Africa 0860-SAMSUNG (726-7864 ) www.samsung.com
QUESTIONS OR COMMENTS?
Л COUNTRY CALL > OR VISIT US ONLINE AT- Lee 000
Samsung Electronics America, Inc.
IN THE US Cerne WWW. Samsung.com/us 85 Challenger Road Ridgefield Park,
NJ 07660-0511
Code no. AHES-02334A(00)
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
