PANASONIC COMMUNICATION SYSTEMS
ADVANCED HYBRID WIRED/WIRELESS
TELEPHONE SYSTEM, ADVANCED HYBRID
& VOICE PROCESSING SYSTEMS
Local Offices listed on last page
Per Master Carton
Model
Number
Description
Units
Weight
UPC
Code
0-37988-
KX-TA308 TELEPHONE SYSTEM CONTROL UNIT
KX-TA308
MAIN UNIT
The KX-TA308 initial and maximum configuration is 3 COs and 8 stations.
Features
• Compatible with CO based Voice Mail
• Basic station programming is done at the factory
• Built in Caller ID
• Built in 2 port Doorphone/Opener Card
• Toll Restriction
• Compatible with KX-TA30800 Series, SLT, KX-TD7895
and KX-T7885 Telephones only
1
10.74 lbs. 85069-3
1
12.35 lbs. 85064-8
KX-TA624 ADVANCED HYBRID SYSTEM CONTROL UNIT
KX-TA624-5
CONTROL UNIT
The KX-TA624-5 is an Advanced Hybrid Telephone System. It's initially
configured to support 3 CO’s 8 stations and 1 KX-TA62493-3 Caller ID
card. The system can grow to 6 CO’s by 24 stations with the addition of
add-on cards (KX-TA62477-3 and the KX-TA62470-2). Two expansion slots
provide the following configurations: 3 X 16, 6 X 16 and 6 X 24.
The KX-TA624-5 is compatible with all KX-T7000, KX-T7300 and KX-T7700
series telephones and Panasonic cordless models KX-T7885 and KX-TD7895
and single line devices.
Major Features
• Voice Mail Integration
• Built-in Caller ID for 3 CO’s with Call Waiting
• Caller ID logging
• SMDR
• Message Waiting
• Modular Design
• Call forwarding (Busy No Answer, Follow Me, Outside Line and All Call)
• Direct Inward System Access (DISA) with Fax detection
KX-TA624 ADVANCED HYBRID SYSTEM EXPANSION COMPONENTS
KX-TA62460
DOOR PHONE/OPENER CARD
• Connects up to 4 door intercoms (KX-T30865) and
provides 4 contact closures
• One per system
3
2.6 lbs.
82552-3
KX-TA62477-3
3 X 8 EXPANSION CARD
• Provides connection for 3 loop start CO Lines and
eight KX-T7700 series telephones or single line devices
• One per system
3
6.0 lbs.
82632-2
KX-TA62470-2
8 PORT EXTENSION CARD
• Provides for connection of eight KX-T7700 series
telephones or single line devices
• Can be installed in either of the two expansion
slots in the KX-TA624-5 control unit.
3
5.1 lbs.
82613-1
Units, Weights and Specifications subject to change.
2
Per Master Carton
Model
Number
Description
Units
Weight
UPC
Code
0-37988-
KX-TA624 ADVANCED HYBRID SYSTEM EXPANSION COMPONENTS (Continued)
KX-TA62491
KX-TA62493-3
DISA OGM/FAX DETECTION CARD
• Installation of this card allows Direct Inward System Access (DISA)
and fax detection
• One per system
3
0.9 lbs.
82550-9
CALLER ID CARD
• Allows caller ID information to appear on the display of the proprietary
KX-T7700 series telephones
• 1 Card required for every 3 caller ID compatible CO lines installed
• 1 KX-TA62493 is pre-installed in the control unit
• Maximum of two per system
• Caller ID service must be provided by the local telephone company
3
1.2 lbs.
82629-2
1
21.4 lbs.
85061-7
KX-TA1232 ADVANCED HYBRID SYSTEM CONTROL UNIT
KX-TA1232-2
CONTROL UNIT
The KX-TA1232 is an Advanced Hybrid PBX system. It’s initially configured
with 8 COs, 16 stations and 1 KX-TA123293 Caller ID Card. It can grow to
12 COs and 32 Stations with the addition of up to 2 of the KX-TA123270
Extension Modules and one KX-TA123280 CO module. The KX-TA1232 is
compatible with Panasonic KX-T7700 series telephones plus Panasonic
cordless models (KX-T7885 and KX-TD7895) and single line devices.
Major Feature
• Modular Design Expandable to 12 x 32
• Non-Blocking
• Voice Mail Integration
• Built-in Caller ID for 4 CO’s
• SMDR
• Direct Inward System Access (DISA)
• Toll Restriction
• Call Forwarding (Busy, No Answer, Follow Me, Outside Line and All Call)
• 4 Doorphones/Openers
• System Configuration Backup Utility
Refer to feature chart on pages 13 and 14 for complete list of features.
KX-TA1232 ADVANCED HYBRID SYSTEM EXPANSION COMPONENTS
KX-TA123260
DOOR PHONE DOOR/OPENER CARD
• Connects up to 4 door intercoms (KX-T30865)
• Provides 4 contact closures to operate electric door locks
• One per system
3
2.2 lbs.
82618-6
KX-TA123270
EXTENSION MODULE
• 8 circuits, Compatible with Panasonic KX-T7700 series telephones
• Panasonic cordless models KX-T7885 and KX-TD7895
and single line devices.
• Maximum of 2 per system
3
8.14 lbs.
82619-3
KX-TA123280
CO MODULE
• 4 ports, loop start only
• Maximum of one per system
3
8.14 lbs.
82620-9
Units, Weights and Specifications subject to change.
3
Per Master Carton
Model
Number
Description
Units
Weight
UPC
Code
0-37988-
KX-TA1232 ADVANCED HYBRID SYSTEM EXPANSION COMPONENTS (Continued)
KX-TA123291
DISA CARD
• Allows Direct Inward System Access.
• Provides 60 seconds of digitally recorded voice for simple
automated attendant.
• Maximum of one card per system
3
0.6 lbs.
82621-6
KX-TA123293
CALLER ID CARD
• Allows Caller ID information to appear on the display
of the proprietary telephones (KX-T7730, KX-T7735, KX-TD7885
and KX-TD7895) and SMDR printout.
• One card required for every 4 central office lines
• Maximum of 3 cards per system
• 1 KX-TA123293 is pre-installed in the control unit
• Caller ID service must be provided by the telephone company
(Not compatible with Centrex caller ID)
3
0.55 lbs.
82622-3
KX-TAW848 ADVANCED HYBRID WIRED/WIRELESS SYSTEM CONTROL UNIT
KX-TAW848
MAIN UNIT
The KX-TAW848 main unit is initially configured with 4 Extension
Ports and 4 Loop Start CO ports (1 LCOT card), Power Supply, RS232 port,
USB port, MOH port, Paging port and an SD card. The system is
expandable to 8 COs and 24 extension ports. The 24 extension ports can
support a combination 51 wired and wireless extensions. Please refer to the
KX-TAW848 capacities chart #4 before configuring the system.
Features
• Multi-Cell Wireless
• PC-Based Programming
• Automatic Route Selection (ARS)
• Toll Restriction
• Caller ID APT and SLT Telephones
• Voice Mail Integration
• Compatible with KX-T7700, 7300, 7000 Series Telephones and SLT
• Direct Inward System Access (DISA)
1
14.1 lbs.
85094-5
1
3.85 lbs.
85112-6
MOUNTING HARDWARE
KX-A244X
19" RACK MOUNT BRACKET FOR THE KX-TAW848
For mounting the KX-TAW848 cabinet in a 19" rack.
STATION CARDS
KX-TAW84870
4-PORT HYBRID LINE CARD (HLC4)
4 ports per card. Supports KX-T7700 (APT) series telephones, Single
Line (SLT) and DSS console, (KX-T0141) 2 port Cell Station and DPITS
Voice Mail. Maximum one per system. Please refer to KX-TAW848 system
capacities chart # 4 prior to configuring a system.
5
4.4 lbs.
85098-3
KX-TAW84874
8-PORT SINGLE LINE CARD (SLC8)
8 ports per card. Supports single line telephones (SLT). Also equipped with
8 DTMF receivers. 2 cards max per system. Please refer to KX-TAW848
system capacities chart # 4 prior to configuring a system.
5
5.18 lbs.
85099-0
Units, Weights and Specifications subject to change.
4
Per Master Carton
Model
Number
Description
Units
Weight
UPC
Code
0-37988-
STATION CARDS (Continued)
KX-TAW84875
4-PORT PROPRIETARY LINE CARD (PLC4)
4 ports per card. Supports KX-T7700 series (APT),
DSS and DPITS Voice Mail. 1 card max per system.
Please refer to KX-TAW848 system
capacities chart # 4 prior to configuring a system.
5
4.41 lbs.
85100-3
KX-TAW84876
8-PORT PROPRIETARY EXTENSION CARD (PLC8)
8 ports per card. Supports KX-T7700 Series (APT),
DSS and DPITS Voice Mail. 2 cards max per system.
Please refer to KX-TAW848 system
capacities chart # 4 prior to configuring a system.
5
5.1 lbs.
85101-0
5
4.4 lbs.
85102-7
CENTRAL OFFICE CARDS
KX-TAW84880
4 PORT LOOP START CO CARD (LCOT4)
4 ports per card. 2 ports have power failure transfer.
1 optional (KX-TAW84893) 4 port caller ID can be mounted to support
caller ID. Please refer to KX-TAW848 system capacities chart # 4 prior
to configuring a system.
ACCESSORIES
KX-TAW84861
4-PORT DOORPHONE/DOOR OPENER CARD (DPH4)
Support up to 4 KX-T30865 doorphones. Also equipped
with 4 dry contacts for connection to electric door strike
or other compatible type equipment.
Maximum 1 per system.
5
6.3 lbs.
85095-2
KX-TAW84866
8-CHANNEL ECHO CANCELLER CARD (ECHO8)
Provides echo cancellation for conference calls for up to 16 ports.
Maximum of one per system.
5
3.85 lbs.
85096-9
KX-TAW84868
EXTENSION CALLER ID CARD (EXT-CID)
Required to pass Caller ID to Single line telephones, fax, answering
machines etc. Supports up to 8 SLT devises. One card per system.
Mounts in any of the optional slots.
5
3.85 lbs.
85097-6
KX-TAW84893
4-PORT CALLER ID CARD (CID4)
Required to receive Caller ID information from the CO.
Each KX-TAW84893 activates caller ID on 4 CO lines.
Mounts on the KX-TAW84880 Loop
Start CO Cards.
5
1.10 lbs.
85104-1
KX-TAW84896
REMOTE CARD (V.90) (RMT)
Modem card for remote maintenance and programming.
Maximum 1 per system. Mounts in any of the optional slots.
5
.881 lbs.
85105-8
KX-TAW84891
2- CHANNEL MESSAGE CARD (MSG2)
Provides 2 ports for outgoing messages for DISA,
Queuing, Wake-Up and internal hold melody.
A maximum of 32 messages can be recorded
with a maximum total recording time of 15 minutes.
Mounts in any of the optional slots.
5
3.85 lbs.
85103-4
Units, Weights and Specifications subject to change.
5
Per Master Carton
Model
Number
Description
Units
Weight
UPC
Code
0-37988-
MULTI-CELL WIRELESS
KX-T0141
KX-TD7690
2-CHANNEL CELL STATION (CS)
2 port cell station unit. Connects to the 4 port Hybrid Extension card that
is included in the main cabinet plus the KX-TAW84870 only. Required for
multi-cell wireless operation. Maximum of 4 per system.
*** For use with the KX-TAW848 only. ***
Please refer to the KX-TAW848 system capacities chart on page 18
prior to configuring a system
5 2.86 lbs. 85093-8
2.4GHZ EXECUTIVE WIRELESS HANDSET
5-line LCD with back-light
• Navi-key operation
• PBX functionality support
• Headset jack
• Speakerphone
• Vibrator ringing
• Auto Answer
3
5.31 lbs.
85060-0
2.4GHZ WIRELESS HANDSET
3-line LCD with back-light
• Navi-key operation
• PBX functionality support
• Headset jack
• Speakerphone
• Vibrator ringing
• Auto Answer
3
4.51 lbs.
85067-9
Backlit LCD Display
KX-TD7680
Backlit LCD Display
KX-A264
CARRYING CASE FOR KX-TD7680
Black, belt mountable carrying case for the KX-TD7680.
N/A
N/A
N/A
KX-A269
CARRYING CASE FOR KX-TD7690
Black belt mountable carrying case for the KX-TD7690.
12
1.55 lbs.
85065-5
Units, Weights and Specifications subject to change.
6
Per Master Carton
Units
Weight
UPC
Code
0-37988-
N/A
N/A
N/A
N/A
N/A
N/A
PROPRIETARY WIRELESS MULTI-LINE TELEPHONE
• Operation Frequency 902-928 Mhz
• 12 CO Line Capability
• 3 Line Multifunction Backlit LCD Display
• Message Waiting
• Caller ID (APITS)
• Headset Jack
• Programmable Ringing or Vibrator
• Dual Mode (SLT or APITS)
• 30 Channel Auto Scanning
• Separate Charging Unit
• Remote Locatable Antenna
• One Long Life, Fast Charge Nickel-Metal Hydride Battery Included
• Max of 15 per installation
3
11.4 lbs.
82591-2
KX-T7885-W WHITE VERSION
3
11.4 lbs.
White
82630-8
DIGITAL SPREAD SPECTRUM (SST) MULTI-LINE TELEPHONE
WITH LCD DISPLAY
• 900 Mhz Spread Spectrum Technology (SST)
• 3 Line Multifunction Backlit LCD Display
• 2 Modes (APITS and SLT)
• 12 Programmable Line/Feature Buttons (APITS Mode)
• 25 Channel Auto Scanning
• Separate Charging Unit
• Separate Wall Mountable Base Antenna
• Headset Jack
• Programmable Ring or Vibrator
• One Nickel Metal Hydride Battery Included
• Max of 3 per installation
3
10.6 lbs.
82610-0
KX-T7895-W WHITE VERSION
3
10.6 lbs.
White
82682-7
KX-A276
3.6 VOLT NICKEL-METAL HYDRIDE BATTERY
• For use with the KX-T7885
3
1.9 lbs.
82593-6
KX-A276-W
WHITE
3.6 VOLT NICKEL-METAL HYDRIDE BATTERY
• For use with the KX-T7885-W
3
1.9 lbs.
82631-5
Model
Number
Description
MULTI-CELL WIRELESS (Continued)
PSZZTD142CE
CELL STATION BATTERY PACK
Used to power the KX-TDA 0142 or the KX-T0141 Cell Station, making it
portable. The Cell Station, along with a KX-TD7680 or a KX-TD7690 can be
used as a tool to assist the installer in determining coverage and the
placement of the cell stations. Requires 1 PSZZ1TD0142 power supply
adapter. Must be purchased from the Panasonic Parts Center at:
800-833-9626.
PSZZ1TDA0142
POWER SUPPLY ADAPTER
Consists of a connector to connect the Cell Station battery pack to
the Cell Station. 1 required with the Cell Station Battery Pack
Must be purchased from the Panasonic Parts Center at: 800-833-9626.
PROPRIETARY WIRELESS TELEPHONES
KX-T7885
KX-T7885-W
Backlit LCD Display
KX-TD7895
KX-TD7895-W
Backlit LCD Display
Units, Weights and Specifications subject to change.
7
Per Master Carton
Units
Weight
UPC
Code
0-37988-
12 BUTTON MONITOR TELEPHONE
For use with the KX-TA308 system only. Telephone includes:
12 Programmable Buttons, 10 fixed buttons for (Intercom, Conference,
Program, Voice Mail, Pause, Forward/ Do Not Disturb, Flash/Recall,
Auto Answer/Mute, Auto Dial/Store and Redial) plus 3 large buttons
for hold transfer and speakerphone, Volume control for speaker, ringer
and handset, 2.5mm Headset Jack. Wall mountable and available in white
or charcoal/black
3
2.2 lbs.
85074-7
KX-TA30850-B CHARCOAL/BLACK VERSION
3
2.2 lbs.
Black
85075-4
12 BUTTON SPEAKERPHONE TELEPHONE
For use with the KX-TA308 system only. Telephone Includes:
12 Programmable Buttons, 10 fixed buttons for (Intercom, Conference,
Program, Voice Mail, Pause, Forward/Do Not Disturb, Flash/Recall,
Auto Answer/Mute, Auto Dial/Store and Redial), 3 large buttons for Hold
transfer and speakerphone, volume control for speaker, ringer and handset.
2.5mm Headset Jack. Wall mountable. Available in white or charcoal/black
3
2.2 lbs.
85070-9
KX-TA30850-B CHARCOAL/BLACK VERSION
3
2.2 lbs.
Black
85071-6
12 BUTTON SPEAKERPHONE TELEPHONE
W/1 LINE BACKLIT LCD DISPLAY
For use with the KX-TA308 system only. Telephone Includes:
12 Programmable Buttons, 10 fixed buttons for (Intercom, Conference,
Program, Voice Mail, Pause, Forward/Do Not Disturb, Flash/Recall,
Auto Answer/Mute, Auto Dial/Store and Redial), 3 large buttons for hold
transfer and speakerphone, Navigation Key for volume, display contrast
and function selection, 2.5mm Headset Jack. Wall mountable and
Available in white or charcoal/black
3
2.2 lbs.
85072-3
KX-TA30850-B CHARCOAL/BLACK VERSION
3
2.2 lbs.
Black
85073-0
24 BUTTON MONITOR TELEPHONE
• 24 Programmable Buttons
• 12 CO & 12 Personal/Feature
• 10 fixed buttons for (Intercom, Conference, Program,
Voice Mail, Pause, Forward/Do Not Disturb, Flash/Recall,
Auto Answer/Mute, Auto Dial/Store and Redial)
• 3 large buttons for Hold, Transfer and Monitor
• Volume Control for Speaker, Ringer and Handset
• Headset Jack
• Wall Mountable
3
1.28 lbs.
50136-0
KX-T7750-B CHARCOAL/BLACK VERSION
3
1.28 lbs.
Black
50143-0
Model
Number
Description
KX-TA308 SERIES HYBRID SYSTEM TELEPHONES
KX-TA30850
KX-TA30820
KX-TA30830
Backlit LCD Display
KX-T7700 SERIES HYBRID SYSTEM TELEPHONES
KX-T7750
KX-T7750-B
Units, Weights and Specifications subject to change.
8
Per Master Carton
Units
Weight
UPC
Code
0-37988-
24 BUTTON SPEAKERPHONE TELEPHONE
• 24 Programmable Buttons
• 12 CO & 12 Personal/Feature
• 10 fixed buttons for (Intercom, Conference, Program,
Voice Mail, Pause, Forward/Do Not Disturb, Flash/Recall,
Auto Answer/Mute, Auto Dial/Store and Redial)
• 3 large buttons for Hold, Transfer and Speakerphone
• Volume Control for Speaker, Ringer and Handset
• Headset Jack
• Wall Mountable
3
2.46 lbs.
50051-0
KX-T7720-B CHARCOAL/BLACK VERSION
3
2.46 lbs.
Black
50068-0
24 BUTTON SPEAKERPHONE TELEPHONE WITH
1 LINE BACKLIT LCD DISPLAY
• 24 Programmable Buttons
• 12 CO & 12 Personal/Feature
• 10 fixed buttons for (Intercom, Conference, Program,
Voice Mail, Pause, Forward/Do Not Disturb, Flash/Recall,
Auto Answer/Mute, Auto Dial/Store and Redial)
• 3 large buttons for Hold, Transfer and Speakerphone
• Navigation Key for Volume, Display Contrast and Function selection
• Headset Jack
• Wall Mountable
3
2.55 lbs.
50075-0
KX-T7730-B CHARCOAL/BLACK VERSION
3
2.55 lbs.
Black
50082-0
24 BUTTON SPEAKERPHONE TELEPHONE WITH
3 LINE BACKLIT LCD DISPLAY
• 24 Programmable Buttons
• 12 CO & 12 Personal/Feature
• 10 fixed buttons for (Intercom, Conference, Program, Voice Mail, Pause,
Forward/Do Not Disturb, Flash/Recall, Auto Answer/Mute, Auto Dial/Store
and Redial) • 3 large buttons for Hold, Transfer and Speakerphone
• Navigation Key for Volume, Display Contrast and Function selection
• Headset Jack
• Wall Mountable
Compatible with the KX-TA624-5 and KX-TA1232-2 systems only.
3
2.56 lbs.
50099-0
KX-T7735-B CHARCOAL/BLACK VERSION
3
2.56 lbs.
Black
50105-0
48 BUTTON DSS CONSOLE
• 32 DSS keys with LED’S
• 16 Feature keys wo/LED’S
• Wall Mountable
3
1.28 lbs.
85011-2
KX-T7740-B CHARCOAL/BLACK VERSION
3
1.28 lbs.
Black
85012-9
Model
Number
Description
KX-T7700 SERIES HYBRID SYSTEM TELEPHONES (Continued)
KX-T7720
KX-T7720-B
KX-T7730
KX-T7730-B
Backlit LCD Display
KX-T7735
KX-T7735-B
Backlit LCD Display
KX-T7740
KX-T7740-B
Units, Weights and Specifications subject to change.
9
Per Master Carton
Model
Number
Description
Units
Weight
UPC
Code
0-37988-
DOOR INTERCOMS
KX-T30865-W
DOOR INTERCOM (WHITE)
Compatible with all Digital Super Hybrid, Advanced Hybrid
and TD500 telephone systems
3
1.9 lbs.
50167-0
KX-T30865-B
DOOR INTERCOM (BLACK)
Compatible with all Digital Super Hybrid, Advanced Hybrid
and TD500 telephone systems
3
1.9 lbs.
50179-0
1
4.4 lbs.
82594-3
1
4.7 lbs.
85106-5
LEADER VOICE PROCESSING SYSTEM
KX-TVS50
BASIC CABINET
• Initially configured with 2 ports, (Not Expandable)
• Initially configured for 2 Hours Storage, (Expandable to 4 Hours)
• 32 Mailboxes
• 100 Messages per Mailbox
Features
• Automated Attendant Service
• Voice Mail Service
• Multi-lingual Voice Prompts
• Paging Notification with Callback Number
• Automatic FAX Transfer
• In-band, APITS and DPITS Integration
• Remote and On-Site Administration (External Modem Required)
• Advanced Caller ID features
• Two-Way Record • Live Call Screening
• Refer to charts on pages 15 & 16 for detailed feature
& configuration information
BILINGUAL VOICE PROCESSING SYSTEM
KX-TVS95
BASIC CABINET
• Bilingual Voice Prompts (English & Spanish)
• Initially configured with 2 ports, (Not Expandable)
• Expanded 6 Hours Storage, (No Further Expansion)
• 32 Mailboxes
• 100 Messages per Mailbox
Features
• Automated Attendant Service
• Voice Mail Service • Subscriber Tutorial
• Paging Notification with Callback Number
• Automatic FAX Transfer • In-band, APITS and DPITS Integration
• Remote and On-Site Administration (External Modem Required)
• Advanced Caller ID features
• Two-Way Record
• Live Call Screening
• Refer to charts on pages 15 & 16 for detailed feature
& configuration information
Units, Weights and Specifications subject to change.
10
Per Master Carton
Model
Number
Description
Units
Weight
UPC
Code
0-37988-
ENHANCED BILINGUAL VOICE PROCESSING SYSTEMS
All Models Now Initially Configured with:
1 KX-TVS204 (4 port) Card; Double Time Technology (For up to double the storage time of previous models); Bilingual Voice Prompts
KX-TVS125
BASIC CABINET
• Bilingual Voice Prompts (English & Spanish)
• Initially configured with 1 KX-TVS204 4 port card
• Expandable to 6 ports DPITS with the addition of 1 KX-TVS102 card
• With the initial KX-TVS204 card removed, up to 2 KX-TVS102 cards
can be installed for 4 ports in band
• 32 Hours of Storage • 64 Mailboxes
Features
• Subscriber Tutorial • Automated Attendant Service • Voice Mail Service
• Paging Notification with Callback Number
• Automatic FAX Transfer • In-band and DPITS Integration
• Remote and On-Site Administration (External Modem Required)
• Advanced Caller ID features • Two-Way Record • Live Call Screening
• Refer to charts on pages 15 & 16 for detailed feature
& configuration information
1
16.4 lbs.
85107-2
KX-TVS225
BASIC CABINET
• Bilingual Voice Prompts (English & Spanish)
• Initially configured with 1 KX-TVS204 4 port card
• Expandable to 12 ports DPITS with the addition of 2 KX-TVS204 cards
• With the initial KX-TVS204 card removed, up to 3 KX-TVS102 cards can
be installed for 6 ports in band
• 64 Hours of Storage • 1024 Mailboxes
Features
• Subscriber Tutorial • Automated Attendant Service • Voice Mail Service
• Paging Notification with Callback Number
• Automatic FAX Transfer
• In-band and DPITS Integration
• Remote and On-Site Administration (External Modem Required)
• Advanced Caller ID features
• Two-Way Record • Live Call Screening
• Refer to charts on pages 15 & 16 for detailed feature
& configuration information
1
16.6 lbs.
85108-9
KX-TVS325
BASIC CABINET
• Bilingual Voice Prompts (English & Spanish)
• Initially configured with 1 KX-TVS204 4 port card
• Expandable to 24 ports DPITS with the addition of 5 KX-TVS204 cards
• With the initial KX-TVS204 card removed, up to 6 KX-TVS102 cards can be
installed for 12 ports in band • 128 Hours of Storage • 1024 Mailboxes
Features
• Subscriber Tutorial • Automated Attendant Service • Voice Mail Service
• Built in Modem for Remote Access
• Paging Notification with Callback Number
• Automatic FAX Transfer
• In-band and DPITS Integration
• Remote and On-Site Programming
• Advanced Caller ID features
• Two-Way Record
• Live Call Screening
• Refer to charts on pages 15 & 16 for detailed feature
& configuration information
1
16.6 lbs.
85109-6
Units, Weights and Specifications subject to change.
11
Per Master Carton
Model
Number
Description
Units
Weight
UPC
Code
0-37988-
VOICE PROCESSING EXPANSION CARDS
KX-TVS52
MEMORY EXPANSION CARD
• Adds 2 hours’ memory storage to the KX-TVS50
A maximum of one KX-TVS52 can be installed in the KX-TVS50
3
0.66 lbs.
82595-0
KX-TV102
EXTENSION/LINE INTERFACE CARD
• 2 port interface circuit card.
Provides for connection of two analog extensions/lines (single line
telephone extension or Loop Start CO) or one Panasonic Digital
Super Hybrid system extension (effectively two extensions).
1
2.5 lbs.
82508-0
EXTENSION/LINE INTERFACE CARD
• 4 port digital integration card for installation in the
The KX-TVS204 allows 2 DPITS data pairs to be connected providing
4 digitally integrated ports.
1
0.2 lbs.
82530-1
(For KX-TVS100, 110, 200,
220, 225, 300, 320 & 325)
KX-TV204
(For KX-TVS100, 110, 120, 125,
200, 220, 225, 300, 320 & 325)
Units, Weights and Specifications subject to change.
12
TELEPHONE SYSTEMS FEATURE LIST
System Features
KX-TA308
KX-TA624-5
KX-TA1232-2
KX-TAW848
• Absent Message Capability
6
6
9
9
• Account Code Entry (Forced Verified)
24
24
128
1,000
• Account Code Entry (Optional)
X
X
X
X
X
X
X
• Automated Attendant (with DISA/OGM)
• Automatic CO Hunting
X
X
X
X
• B.G.M. (Back Ground Music) Jack
X
X
X
X
• Call Back Busy
X
X
X
X
• Call Forwarding
X
X
X
X
• Call Hunting (Terminal or Circular)
X
X
X
X
(300 Numbers)
(300 Numbers)
(300 Numbers)
Programmable
• Call Parking Zones
10
10
10
X
• Call Park Retrieve
X
X
X
X
• Call Pick Up
X
X
X
X
• Call Retrieve from TAM
X
X
• Call Log System
• Call Transfer/Transfer Recall
X
X
X
X
• Call Waiting
X
X
X
X
• Caller ID, Call Logging
(20/Station)
(20/Station)
(20/Station)
Programmable
• Caller ID, Call Log Lock
X
X
X
X
• Caller ID, Callback
X
X
X
X
• Caller ID Call Waiting
X
X
X
X
• Caller ID (Name and/or Number) to APT
X
X
X
• Caller ID (Name and Number) to SLT
X
X
• Caller ID Internal
X
X
X
X
• Class of Service
5
5
8
64
• CO Limited Duration Timer
X
X
X
X
• CO Line Status (Two Color LED)
X
X
X
X
• Conference Calling (3 Party)
X
X
X
X
• Data Dump (Print Out of System Program Data)
X
X
X
X
• Data Line Security (for Fax or Modem)
X
X
X
X
• Date and Time Display
X
X
X
X
• Delayed Ringing
X
X
X
X
• Conference Calling (8 Party)
• D.I.L. (Direct in Line)
X
X
X
X
X
• D.I.S.A. (Direct Inward System Access)
(NO OGM)
X
X
X
• D.I.S.A. Single Digit Access
(NO OGM)
X
X
X
• Distinctive Ringing Tone (Doorphone, Intercom, CO)
X
X
X
X
• D.N.D. (Do Not Disturb)
X
X
X
X
• Do Not Disturb Override
X
X
X
X
2/2
4/4
4/4
4/4
2
4
24
• Door Intercoms/Door Opener Contacts
• DSS/BLF Consoles
• Dual Port Usage (Parallel SLT Station)
X
X
X
X
• Duration Time of Call Display
X
X
X
X
• Electronic Station Lock
X
X
X
X
• Extension Groups
X
8
8
32
• Exclusive Hold
X
X
X
X
• Executive Override
X
X
X
X
• Executive Override Deny
X
X
X
X
• External Paging Access
1
1
2
1
• Fax Transfer
X
X
X
X
• Flexible CO Keys (DSS/BLF, One Touch Dial)
X
X
X
X
• Flexible DSS Keys (One Touch, Feature Access)
X
X
X
X
• Flexible Key Assignments
X
X
X
X
• Flexible Line Assignment
X
X
X
X
• Flexible Night Service/Programmable/Manual
X
X
X
X
• Flexible Ringing Assignment (Day, Night, Lunch)
X
X
X
X
• Flexible Station Numbering
X
X
X
X
Units, Weights and Specifications subject to change.
13
TELEPHONE SYSTEMS FEATURE LIST
System Features
KX-TA308
KX-TA624-5
KX-TA1232-2
KX-TAW848
• Hands-Free Answer Back Intercom
X
X
X
X
• Handset/Headset-Display Phones
X
X
X
X
• Hold
X
X
X
X
• Hold Recall/Hold Reminder
X
X
X
X
• Industry Standard Telephone Capability
X
X
X
X
• Internal Paging (All Call Paging)
X
X
X
X
• Internal Paging (Zone Paging)
8-Zones
8-Zones
8-Zones
32-Zones
• Last Number Redial
X
X
X
X
• Limited Call Duration
X
X
X
X
• Login/Logout
X
X
X
X
• Memory Back-up
X
X
X
X
• Message Waiting - Proprietary Phones
X
X
X
X
• M.O.H. (Music on Hold)
X
X
X
• Multi-Cell Wireless
X
X
• Multiple Voice Mail Lamps
X
X
X
• Off-Hook Tone Signaling
X
X
X
X
• On-Site Programming Diagnostics
X
X
X
X
• Operator Call
X
X
X
X
• Power Failure Transfer
X
X
X
X
• Pre-Selection (Central Office of Intercom)
X
X
X
X
• Privacy Release
X
X
X
X
• Ring Groups
X
X
X
X
• Ringing Line Preference
X
X
X
X
• Room Monitor
X
X
X
X
• Saved Number Redial
X
X
X
X
• Secret Dialing
X
X
X
X
• S.M.D.R. (Station Message Detail Recording)
X
X
X
X
• Station Name Display
X
X
X
X
• Station Speed Dial
10
10
10
10
• Station to Station Messaging
X
X
X
X
• System Configuration Backup Utility
• System Speed Dial Numbers
• Timed Reminder
• Toll Restriction
100
100
X
X
500
1,000
X
X
X
X
5-Class
5-Class
8-Class
32-Class
• Toll Restriction Override
X
X
X
X
• Tone/Pulse Conversation
X
X
X
X
• Tone/Pulse Dialing (By CO Line)
X
X
X
X
• Transfer (Screened/Unscreened)
X
X
X
X
• Trunk Groups
X
X
X
X
• Unattended Conference Call
X
X
X
X
• Voice Mail CO-Based
X
X
X
X
X
• Voice Mail Integration (APITS)
X
• Voice Mail Integration (DPITS)
• Walking Class of Service
X
Units, Weights and Specifications subject to change.
14
X
KX-TVS50, KX-TVS95, KX-TVS125, KX-TVS225 AND KX-TVS325 FEATURES
Mailbox Services
Greeting, After Hours
Greeting, Busy
Greeting, No answer
Internal message delivery
Mailbox name
Mailbox password
Message delivery status
Message reception mode
Message, Erase
Message, Fast Forward
Message, Pause
Message, Playback
Message, Repeat
Message, Rewind
Message, Scan
Message, Skip
New message notification
Play previous message
Private messages
Reply to subscriber(s)
Time and date stamp
Transfer message with comments
Transfer message without comments
System Administration
Auto configuration (DPITS/APITS only)
Integration, Digital
Integration, In-band
PC-based programming
Quick setup
System manager administration
Utility Commands
System Features
All calls transferred to mailbox
Alternate extension transfer sequence
Auto message move/copy
Built-in Modem Card for Remote Access*
Broadcast message
Call blocking
Call screening
Call transfer status
Call transfer to an outside line***
Callback number entry
Caller ID callback***
Caller ID Name Announce (DPITS/APITS only)
Caller ID Routing (DPITS/APITS only)
Class of service
Coverage mode, Busy
Coverage mode, No answer
Covering extensions
Day/night service
Day/night/lunch service with PBX
Mailbox, General Delivery
Mailbox, Guest
Mailbox, Interview
Mailbox, Message Manager
Mailbox, Subscriber
Mailbox, System Manager
Message waiting notification, Continuous
Message waiting notification, Lamp
Message waiting notification, Outdial
Message waiting notification, Pager
Message waiting notification, Scheduled
Multiple company greetings
Operator service, Day/Night
Personal Greeting for Caller
ID (DPITS/APITS only)
Prerecorded bilingual prompts
(English/Spanish)**
Recordable system prompts
Remote call forwarding set (DPITS/APITS only)
Remote change of company greeting
(DPITS/APITS only)
(DPITS/APITS only)
Daylight saving time assignment
Department dialing
Dial by name
Direct mailbox access (DPITS/APITS only)
External message delivery
External message delivery status
Fax management
Fax transfer
Group distribution lists, Personal
Group distribution lists, System
Groups mailbox
Hold call
Holiday service
Intercom paging notification (DPITS/APITS only)
Live call screening (DPITS/APITS only)
* Available in KX-TVS325 only
** Spanish prompts not available in KX-TVS50
*** Available only in the KX-TVS95, 125, 225, & 320
Units, Weights and Specifications subject to change.
15
Rotary telephone service
Service access commands
Service, Automated Attendant
Service, Custom
Service, Interview
Service, Voice Mail
Subscriber tutorial***
System clock
System clock sync with PBX
(DPITS/APITS only)
System prompts after personal greeting
System reports
Two-way record (DPITS/APITS only)
Two-way transfer ((DPITS/APITS only)
Trunk group based routing
VOICE PROCESSING SPECIFICATIONS CHART 1
APITS
Ports
DPITS
Ports
In-Band
Ports
Bilingual
Voice Prompts
Storage
(Hours)
Mailboxes
Messages
per Mailbox
KX-TVS50
2
2
2
No
2 Expandable to 4
32
100
KX-TVS95
2
2
2
Engl/Span
6
64
100
KX-TVS125
–
6
4
Engl/Span
32
64
100
KX-TVS225
–
12
6
Engl/Span
64
1024
100
KX-TVS325
–
24
12
Engl/Span
128
1024
100
Model
VOICE PROCESSING PORT CONFIGURATION CHART 2
System
Expansion Cards Required
Type of Integration
Supported
KX-TVS50
Configured with 2 Ports – Not Expandable
DPITS/APITS/Inband
KX-TVS95
Configured with 2 Ports – Not Expandable
DPITS/APITS/Inband
KX-TVS125
Initially configured with 1 KX-TVS204 4 port card. Expandable to 6 Ports
DPITS with the addition of 1 KX-TVS102 card. With the initial
KX-TVS204 card removed, up to 2 KX-TVS102 cards can be installed
for 4 ports inband.
DPITS/Inband
KX-TVS225
Initially configured with 1 KX-TVS204 4 port card. Expandable to 12 Ports
DPITS with the addition of 2 KX-TVS204 cards. With the initial
KX-TVS204 card removed, up to 3 KX-TVS102 cards can be installed
for 6 ports inband.
DPITS/Inband
KX-TVS325
Initially configured with 1 KX-TVS204 4 port card. Expandable to 24 Ports
DPITS with the addition of 5 KX-TVS204 cards. With the initial
KX-TVS204 card removed, up to 6 KX-TVS102 cards can be installed
for 12 ports inband.
DPITS/Inband
Units, Weights and Specifications subject to change.
16
KX-TA624-5
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
KX-TA1232-2
KX-TA624-4
O
O
O
O
O
O
O
O
O
O
O
KX-TA1232
KX-TA624-3
KX-TA624-2
KX-TA624-1
KX-TA624
MODEL
KX-TA308
ADVANCED HYBRID REVISION COMPATIBILITY CHART 3
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
Hybrid Expansion Components
KX-TA62460
KX-TA62477
KX-TA62477-2**
KX-TA62477-3**
KX-TA62470
KX-TA62470-2**
KX-TA62491
KX-TA62493
KX-TA62493-1
KX-TA62493-2
KX-TA62493-3
KX-TA123260
KX-TA123270
KX-TA123280
KX-TA123293
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
Telephones
Industry Standard Single Line Telephones (SLT)
KX-T7750, KX-T7750-B
KX-T7720, KX-T7720-B
KX-T7730, KX-T7730-B
KX-T7735, KX-T7735-B
KX-T7740, KX-T7740-B
KX-T7885, KX-T7885-W
KX-TD7895, KX-TD7895-W
KX-T30865-W & KX-T30865-B
KX-TA30850 & KX-TA30850-B
KX-TA30820 & KX-TA30820-B
KX-TA30830 & KX-TA30830-B
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
** Any combination of the KX-TA62477, KX-TA62477-2, KX-TA62477-3 and KX-TA62470, KX-TA62470-2
can be installed in KX-TA624, KX-TA624-1, KX-TA624-2, KX-TA624-3, KX-TA624-4 and KX-TA624-5.
Units, Weights and Specifications subject to change.
17
O
O
O
O
O
O
O
O
O
O
O
O
O
KX-TAW848 MAXIMUM CAPACITIES CHART #4
Trunk Port
8
Extension Port
24
Single Line Telephone
24
Analog Proprietary Telephone and DSS Console
KX-T7700, 7300 and 7000 Series
24
Cell Station (KX-TA0141)
4
Voice Processing System
4 Ports (1 System)
Wireless Telephone (KX-TD7680 and KX-TD7690)
28
Doorphones Port (KX-T30865)
4
Specifications
CO Lines
Extensions
ICM Paths
Door
Intercoms
KX-TA308
3
8
4
2
KX-TA624-5
6
24
4
4
KX-TA1232-2
12
32
Non-Blocking
4
Power Source: AC 120V 60Hz
Wiring: two pair for Proprietary Telephones
one pair for Industry Standard Telephones
FCC Registration No.
KX-TA308:
ACJGTB-32973-MF-E
KX-TA624:
ACJGTB-32973-MF-E
KX-TA1232:
ACJGTB-43121-MF-E
KX-TAW848:
ACJMF03AKX-TDA50
Units, Weights and Specifications subject to change.
18
NOTES
Units, Weights and Specifications subject to change.
19
3DQDVRQLF7HOHSKRQH6\VWHPV
See More
Panasonic Manuals
www.voicesonic.com
Phone: 877-289-2829
© Matsushita Electric Corporation of America, 2004
Printed in U.S.A.
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
