"OWNERS MANUAL
WARNING: TO PREVENT ELECTRICAL SHOCK OR FIRE HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR-MOISTURE. BEFORE USING THIS APPLIANCE, |
READ THE OPERATING GUIDE FOR FURTHER WARNINGS. —
NEUE NEC = + LA Sa, e ВВея CHORUS SERED POWER
re, | aie AUDITION.
2¢ © DI o: OO: O: ©: ©: © _CHORUS A
GAIN GAIN a TNT suPEnSAT” pos ven ° Gini i PORRES MADE IN USA OFF
B 9 10 11 12
FRONT PANEL
HIGH GAIN INPUT (1)
Used for most electric guitars. It is 6 dB louder than the Low Gain input.
LOW GAIN INPUT (2)
Provided for instruments that have extremely high outputs, which can result in overdriving (distorting) the High Gain input. If
both inputs are used simultaneously, the output levels are the same (both are Low Gain).
LEVEL (3)
Controls the volume level of the normal channel and is not affected by the SuperSat or Post Gain controls.
CHORUS SELECT SWITCH (4)
Is used to activate/defeat the chorus circuit. To activate the circuit, depress the switch to its “in” position
OPERATION NOTE
Chorus activation may also be accomplished by the optional remote footswitch. If remote selections desired, the chorus select
switch must be in the “in” (activated) position.
CHANNEL SELECT SWITCH (5)
Allows selection of the lead or normal channel. The “in” position of the switch selects the lead channel and the “out” position
selects normal.
NOTE: Channel selection may also be accomplished by the remote footswitch. If remote selection is desired the channel switch
must be in the “in” (lead) position.
SUPERSAT® (6)
(Built Under U.S. Patent 44,811,401)
A transistor simulation of tube distortion (soft clipping). To activate the SuperSat® effect, lead channel must be activated.
POST GAIN (7)
Controls the overall volume level of the lead channel. The final level adjustment should be made after the desired sound has
been achieved.
LOW, MID, HIGH EQ (8)
Passive tone controls that regulate the low, mid and high frequencies, respectively.
RATE/DEPTH CONTROL(9)
Simultaneously controls the sweep rate (frequency) and depth (intensity) of the chorus effect. Rotating clockwise increases
the rate and decreases the depth of the chorus effect.
STEREO HEADPHONE JACK (10)
Provided for use with any stereo headset. One channel of the headphones will deliver signals processed by the chorus circuit.
The other side will deliver only “dry” (unprocessed) signals. Use of a monaural headset is not recommended.
POWER LED (11)
lluminates when AC power is being supplied to the amp.
POWER SWITCH (12)
Depress the switch to the “On” position. The red pilot light (LED) will illuminate indicating power is being supplied to the unit.
BACK PANEL
120 VAC
50 Hz
ED WATTS
UTION
TO PREVENT THE RISK OF FIRE AND SHOCK HAZARD,
DO NOT EXPOSE THIS APPLIANCE ТО RAIN OR
MOISTURE. DO MOT REMOVE FROM CASE. MO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
AVIS: RISQUE DE CHOC ELECTAIQUE - NE PAS
OUVAIR.
AUDITION
CHORUS
MADE IN U.S.A.
EE
A PACDUCT OF PEAVEY ELECTRONICS CORP.
MERION, MS PATENT PENDING
10 WATTS 9V AMS
8 OHM MIN. LOAD
EACH CHANNEL © @ © ©
PREAMP OUT FOOT SWITCH
PREAMP OUT (13)
The preamp output can be used to route the amplified signal to a mixing console, tape recorder, etc. Connect the preamp output,
using a shielded cable, to an input of the tape recorder, mixer, etc. This patch does not affect the operation of the amplifier
OPERATION NOTE
If only one preamp out jack is used, the output is a monaural (mixed) chorus output. If both preamp out jacks are used, the
outputs are stereo chorus outputs.
REMOTE SWITCH JACK (14)
Provided for the connection of the optional remote footswitch. Footswitch is used to select the lead or normal channels and
activate/defeat chorus. When using remote footswitch, always insert the plug fully (second click) to insure proper operation.
LINE CORD (120 VOLT PRODUCTS ONLY)
For your safety, we have incorporated a 3-wire line (mains) cable with proper grounding facilities. Itis not advisable to remove
the ground pin under any circumstances. If it is necessary to use the equipment without proper grounding facilities, suitable
grounding adaptors should be used. Less noise and greatly reduced shock hazard exists when the unit is operated with the
proper grounded receptacles.
13 14
TONE SETTING CHART
ADJUST TO ADJUST TO
TASTE TASTE
e. NORMAL GAIN Chorus „ (ЕАО САМ r—— EQUALIZATION =—— CHORUS e TÉREG
27”N7 [J | 3, ‘о зи N 7 зщ 7 зи | ау 7 AUDITION.
2 8 2 в г 2 в 8 2 8 В
s [J 9 1 1 g g (y: 1 9 CH ORUS
0 o 0 “10 10 0 0 оо.
CAN GAIN LeveL — CHANNEL E sypersat~ POST AATE/DEPTH | PHONES | 2} manemusa
METAL
ADJUST TO ADJUST TO
TASTE TASTE
INPUTS NORM, САМ CHORALE e LEAD GAIN я ен EQUALIZATION —— CH us STEREO
© 3, - No Yt © 7 7 2/3) CY AUDITION.
( ) 2 8 2 в г 8 8 2 в | г 8
O [3 13 i о To" 0] 7%. CHORUS
О a 0 10 i
GAIN GAIN LEVEL — A" E SUPERSATT POST LOW MID HIGH RATE/DEPTH J PHONES MADE IN USA.
COUNTRY (MILD DISTORTION)
ADJUST TO ADJUST TO
TASTE TASTE
OX Me sa = qe A Ep ÉGUALE Pi ZU STEREO
(a (9: NI AUDITION.
o © о (9:1 e |: а CHORUS
010 -
GAIN © LEVEL oe UC — “iow 0 a wo нен __Двате/реетн [ РНОМЕВО ДЮ) маое муза
JAZZ
Tone settings given are general and will vary according to type of guitar, type and gauges of strings, type of pickup
and even type of pick. Personal taste, playing style, and type of music greatly contribute to desired tonality.
AUDITION CHORUS SPECIFICATIONS
POWER AMPLIFIER SECTION:
10 W AMS per channel into 8 ohms
POWER @ CLIPPING: (Typically)
(5% THD, 1 kHz, 120 VAC line)
10 W RMS per channel into 8 ohms
TOTAL HARMONIC DISTORTION:
Less than 0.3%, 100 MW to 7 W AMS,
60 Hz to 10 kHz, 8 ohms
Typically below 0.2%
POWER CONSUMPTION:
30 watts, 50/60 Hz, 120 VAC
PREAMP SECTION:
The following specs are measured @ 1 kHz with
the controls preset as follows:
Chorus Effect (Off/Out)
Channel Select (Norm/Out)
SuperSat™ @ 0
Post Gain @ 10
Low & High EQ @ 10
Mid EQ @ 0
Rate/Depth @ 0
PREAMP LOW GAIN INPUT:
Impedance: High Z, 44K Oms
Nominal Input Level: -14 dBV, 200 MV RMS
Minimum Input Level: -24 dBV, 60 MV RMS
Maximum Input Level: +6 dBY, 2 Y RMS
PREAMP QUTPUTS (1 & 2):
Load Impedance: 10 K ohms or greater
Nominal Output: 0 dBV, 1 V AMS
(Switching jacks, outputs bridged (summed) if only one output
is patched;stereo if both are patched)
STEREO HEAD-PHONE OUTPUT:
Load Impedance: 4 ohms per channel or greater
Nominal Power Output: 100 MW per channel into 4 ohms
(Stereo jack, stereo signal, disconnects internal
speakers when phone plug is inserted)
SYSTEM HUM & NOISE @ NOMINAL INPUT LEVEL:
(20 Hz to 20 kHz unweighted)
66 dB below rated power
EQUALIZATION:
Special Low, Mid & High passive type EQ
Automatic Thick EQ when lead channel selected
EXTERNAL FOOTSWITCH FUNCTION:
NOMINAL LEVELS ARE WITH NORMAL GAIN LEVEL @ 5
MINIMUM LEVELS ARE WITH NORMAL GAIN LEVEL @ 10
PREAMP HIGH GAIN INPUT:
Impedance: High £Z, 220K Ohms
Nominal Input Level: -20 dBV, 100 MV RMS
Minimum Input Level; -30 dBV, 30 MV RMS
Chorus Defeat (when selected with button)
Lead Channel Defeat (when selected with button)
Maximum Input Level: O dBV, 1 V AMS
BLOCK DIAGRAM
SUPER GAIN
THICK AMP POST
LEAD Ш 8 OHM
> SPEAKER
PWR. AMP 1
SWITCH Fa
LOGIC SUPERSAT™ 9 [1 PREAMP
INPUT PUSH CHORUS switch | OUT
SELECT LOGIC 1
FT. SW. Pay [| PREAMP
PUSH A ud
2
TONE
CHANNEL PRE AMP
STEREO > ME
FT. SW. LL » SPEAKER
CHORUS
LOW MID HIGH
NORMAL PWR. AMP 2
LEVEL o CHORUS 2 RATE/DEPTH
This block diagram shows signal flow within the unit. In order to thoroughly understand the unit's functions, pleass study the block diagram carsfully.
THIS LIMITED WARRANTY VALID ONLY WHEN PURCHASED AND REGISTERED IN THE UNITED STATES OR CANADA. ALL EXPORTED PRODUCTS ARE SUBJECT TO
WARRANTY AND SERVICES ТО BE SPECIFIED AND PROVIDED BY THE AUTHORIZED DISTRIBUTOR FOR EACH COUNTRY.
Ces clauses de garantie ne sont valables qu'aux Etats-Unis et au Canada. Dans tous les autres pays, les clauses de garantie el de maintenance sont fixees par le distributeur national et
assuree par lul seion la legislation en vigueur.
Diese Garantie ist nur in den USA and Kanada gultig. Alle Export-Produkte sind der Garantie und dem Service des Importeurs des jewelligen Landes unterworien.
Esta garantia es valida solamente cuando el producto es comprado en E.U. continentales o en Canada. Todos los productos que sean com prados enel extranjero, estan sujetos alas
garantias y servicio que cada distribuidor autorizado determine y ofrezca en los diferentes paises.
ONE-YEAR LIMITED WARRANTY/REMEDY
PEAVEY ELECTRONICS CORPORATION ("PEAVEY") warrants this product, EXCEPT for covers, footswitches, patchcords, tubes and meters, to be free from defects in material
and workmanship for a period of one (1) year from date of purchase, PROVIDED, however that this limited warranty is extended only to the original retail purchaser and is subject to the
conditions, exclusions and limitations hereinafter set forth:
PEAVEY 90-DAY LIMITED WARRANTY ON TUBES AND METERS
If this product contains tubes or meters, Peavey warrants the tubes or meters contained in the product to be free from defects in material and workmanship for a period of ninety (90)
days from date of purchase; PROVIDED, however, that this limited warranty is extended only to the original retail purchaser and is also subject to the conditions, exclusions and
limitations hereinafter set forth.
CONDITIONS, EXCLUSIONS AND LIMITATIONS OF LIMITED WARRANTIES
These limited warranties shall be void and of no effect if:
a. The first purchase of the product is for the purpose of resale; or
b. The original retail purchase is not made from an AUTHORIZED PEAVEY DEALER; or
¢. The product has been damaged by accident or unreasonable use, neglect, improper service or maintenance, or other causes not arising out of defects in material or
workmanship; or
d. The serial number affixed to the product is altered, defaced or removed.
In the event of a defect in material and/or workmanship covered by this limited warranty, Peavey will:
a. In the case of tubes or meters, replace the detective component without charge;
b. In other covered cases (i.e., cases involving anything other than covers, footswitches, patchcords, tubes or meters), repair the defect in material or workmanship or replace
the product, at Peavey's option;
and provided, however, that, in any case, all costs of shipping, if necessary, are paid by you, the purchaser.
THE WARRANTY REGISTRATION CARD SHOULD BE ACCURATELY COMPLETED AND MAILED TO AND RECEIVED BY PEAVEY WITHIN FOURTEEN (14) DAYS FROM THE
DATE OF YOUR PURCHASE.
In order to obtain service under these warranties, you must:
a. Bring the defective item to any AUTHORIZED PEAVEY DEALER or AUTHORIZED PEAVEY SERVICE CENTER and present therewith the ORIGINAL PROOF OF
PURCHASE supplied to you by the AUTHORIZED PEAVEY DEALER in connection with your purchase from him of this product,
If the DEALER or SERVICE CENTER is unable to provide the necessary warranty service you will be directed to the nearest other PEAVEY AUTHORIZED DEALER or
AUTHORIZED PEAVEY SERVICE CENTER which can provide such service.
OR
b. Ship the defective iter, prepaid, to:
PEAVEY ELECTRONICS CORPORATION
International Service Center
Highway 80 East
MERIDIAN, MS 39301
including therewith a complete, detailed description of the problem, together with a legible copy of the original PROOF OF PURCHASE and a complete return address, Upon
Feavey's receipt of these items:
If the defect is remedial under these limited warranties and the other terms and conditions expressed herein have been complied with, Peavey will provide the necessary
warranty service to repair or replace the product and will return it, FREIGHT COLLECT, to you, the purchaser.
Peavey's liability to the purchaser for damages from any cause whatsoever and regardless of the form of action, including negligence, is limited to the actual damages up to the
greater of $500.00 or an amount equal to the purchase price of the product that caused the damage or that is the subject of or is directly related to the cause of action, Such purchase
price will be that in effect for the specific product when the cause of action arose. This limitation of liability will not apply to claims for personal injury or damage to real property or
tangible personal property allegedly caused by Peavey's negligence. Peavey does not assume liability for personal injury or property damage arising out of or caused by a non-Feavey
alteration or attachment, nor does Peavey assume any responsibility for damage to interconnected non-Peavey equipment that may result from the normal functioning and
maintenance of the Peavey equipment.
UNDER NO CIRCUMSTANCES WILL PEAVEY BE LIABLE FOR ANY LOST PROFITS, LOST SAVINGS, ANY INCIDENTAL DAMAGES OR ANY CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OR INABILITY TO USE THE PRODUCT, EVEN IF PEAVEY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
THESE LIMITED WARRANTIES ARE IN LIEU OF ANY AND ALL WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE; PROVIDED, HOWEVER, THAT IF THE OTHER TERMS AND CONDITIONS NECESSARY TO THE EXISTENCE OF
THE EXPRESS, LIMITED WARRANTIES, AS HEREINABOVE STATED, HAVE BEEN COMPLIED WITH, IMPLIED WARRANTIES ARE NOT DISCLAIMED DURING THE
APPLICABLE ONE-YEAR OR NINETY-DAY PERIOD FROM DATE OF PURCHASE OF THIS PRODUCT.
SOME STATES DO NOT ALLOW LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS, OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THESE LIMITED WARRANTIES GIVE YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.
THESE LIMITED WARRANTIES ARE THE ONLY EXPRESS WARRANTIES ON THIS PRODUCT, AND NO OTHER STATEMENT, REPRESENTATION, WARRANTY OR
AGREEMENT BY ANY PERSON SHALL BE VALID OR BINDING UPON PEAVEY.
In the event of any modification or disclaimer of express or implied warranties, or any limitation of remedies, contained herein conflicts with applicable law, then such modification,
disclaimer or limitation, as the case may be, shall be deemed to be modified to the extent necessary to comply with such law.
Your remedies for breach of these warranties are limited to those remedies provided herein and Peavey Electronics Corporation gives this limited warranty only with respect to
equipment purchased in the United States of America.
INSTRUCTIONS — WARRANTY REGISTRATION CARD
1. Mail the completed WARRANTY REGISTRATION CARD to:
PEAVEY ELECTRONICS CORPORATION
POST OFFICE BOX 2898
MERIDIAN, MISSISSIPPI 39302-2896
a. Keep the PROOF OF PURCHASE. In the event warranty service is required during the warranty period, you will need this document. There will be no identification card
issued by Peavey Electronics Corporation.
2 IMPORTANCE OF WARRANTY REGISTRATION CARDS AND NOTIFICATION OF CHANGES OF ADDRESS:
a. Completion and mailing of WARRANTY REGISTRATION CARDS — Should notification become necessary for any condition that may require correction, the REGISTRATION
CARD will help ensure that you are contacted and properly notified,
b. Notice of address changes — If you move from the address shown on the WARRANTY REGISTRATION CARD, you should notify Peavey of the change of address so as to
tacilitate your receipt of any bulletins or other forms of notification which may become necessary in connection with any condition that may require dissemination of
information or correction.
3. You may contact Peavey directly by telephoning (601) 483-5365.
4. Please have the Peavey product name and serial number available when communicating with Peavey Customer Service.
о
ns
ei
—J
DURATION PER DAY IN HOURS
a
6
4
a
2
for future E
Obey all cautions in the operating instructions and on the
back of the umi.
All operating instructions should be followed.
This product should not be used near water, Le. à
bathlub, sink, swimming pool, wet basement, etc.
This product should be located so that its position does
not interfere with ils proper ventilation. № should not be
placed flat against a wall or placed in a built-in enclosure
that will impede the flow of cooling ar.
This product should not be placed near a source of heat
such as a stove, radiâtor or another heat producing
amplifier.
DANGER
EXPOSURE TO EXTREMELY HIGH NOISE LEVELS MAY CAUSE A PERMANENT HEARING LOSS. INDIVIDUALS VARY CONSIDERABLY IN SUSCEPTIBILITY TO NOISE INDUCED HEARING LOSS, BUT NEARLY
EVERYONE WILL LOSE SOME HEARING IF EXPOSED TO SUFFICIENTLY INTENSE NOISE FOR A SUFFICIENT TIME.
THE U.S. GOVERNMENT'S OCCUPATIONAL SAFETY AND HEALTH ADMINISTRATION (OSHA) HAS SPECIFIED THE FOLLOWING PERMISSIBLE MOISE LEVEL EXPOSURES
SOUND LEVEL dBA, SLOW REAPONIE
PCE the ground pin dti
For MOTE information on
booklet “Shock Hazard and Grounding.”
Power supply cords should always be handied carefully.
Never walk or place equipment on power Suera cords.
Pariodically check cords for cuts or signs of stress,
especially at the plug and the point where Ihe cord exits
the unit.
pplyi
. The power supply cord should be unplugged when the
unit 1% to be unugzed for long periods of time,
ifthis productisto be moun ted in an equipment rack, rear
support should be provided.
EP =
Fou ding wre for our free
. Care should be taken 50 that ob)
ts do not fall and
liquids are not spilled inte the unit through the ventilation
holes or any other openings.
. This unit should be checked by a qualified service
technician if:
A. The power supply cord or plug has been damaged
B. Anything has fallen ог been spilled inlo the unit.
C. Tha unit does nol operate correctly.
0. The unil has been dropped or the enclosure damaged,
. The user should not to attempt to service this equipmant.
All service work should be done by a qualified service
technician,
Peavey Electronics Corporation / 711 A Street / Meridian, MS 39302-2898 / U.S.A. / (601) 483-5365 Telex: 504115 / Fax: 484-4278
©1989 Printed in the U.S.A.
Pl
Features and specifications subject to change without notice.
480300753 3/89
Was this manual useful for you? yes no
Thank you for your participation!

* Your assessment is very important for improving the work of artificial intelligence, which forms the content of this project

Download PDF

advertisement
