This manual is designed to assist you in using your new digital camera. All information presented is as accurate as possible but is subject to change without notice.

Copyright

This manual contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic or other means, in any form, without prior written permission of the manufacturer.

Intended Use

This device is intended to record photos in a digital format.

It is only designed for private use and not intended for a commercial application.

Do no use the device in extreme cold or heat.

The device is not suitable to be used under extreme conditions.

CE Symbol

This symbol on the device certifies that it complies with EU guidelines on radiated emissions. CE stands for Conformité Européenne (European conformity).

Chapter i: Preface

Trademark Recognition

Windows XP and Vista are registered trademarks of Microsoft Corporation in the

United States and/or other countries. Windows is an abbreviated term referring to the Microsoft Windows Operation System. All other companies or product names are trademarks or registered trademarks of their respective companies.

Safety and Handling Precautions

Camera Information

• Do not take apart or attempt to service the camera yourself.

• Do not expose the camera to moisture, or extreme temperatures.

• Allow the camera to warm up when moving from cold to warm temperatures.

• Do not touch the camera lens.

• Do not expose the lens to direct sunlight for extended periods.

• Do not use abrasive chemicals, cleaning solvents or strong detergents to clean the product. Wipe the product with a slightly damp soft cloth.

Battery Information

• Turn off the camera before installing or removing the battery.

• Use only the provided batteries or type of battery and charger that came with your camera. Using other types of battery or charger may damage the equipment and invalidate the warranty.

• When using Li-ion battery in this product, ensure that they are inserted correctly. Inserting the battery upside down can cause damage to the product and possibly cause an explosion.

• When the camera is used for an extended period of time, it is normal for the camera body to feel warm.

• Download all pictures and remove the battery from the camera if you are going to store the camera for a long period of time.

Using this Menu

Symbols used in this manual are explained below:

This indicates useful information when using your camera.

Note

Warning

This indicates warning message that should be read before using the function.

Chapter 1: Introduction

Introduction

System Requirements

In order to get the most out of your camera, your computer must meet the following system requirements:

For Windows:

• Windows XP/Vista

• Processor: Pentium II 450 MHz or above

• Memory: 128 MB or above

• HDD space: 150 MB or above

• 1024 x 768 pixels, 16 bit color display monitor

• USB port and CD-ROM drive

Main Features

• 10 mega pixels resolution

• Up to 3x optical zoom and 5x digital zoom

• 1/2.3 inch CCD image sensor

• 3 inch color touch screen LCD monitor

• 10 MB internal flash memory with optional external SD/SDHC card

• Supports up to 2 GB of SD card, and up to 8 GB of SDHC card

• Sleek metallic finish

• Easy-to-use button interface

• DCF, DPOF, PictBridge compatibility

• Slideshow feature to review your pictures and movies

• A/V output to view your pictures and movies on your TV

• USB port to transfer photos and movies to your PC

Chapter 1: Introduction

Package Contents

Please check the contents of your camera package. It should contain:

Digital camer Li-ion battery

+ replacement battery

Wrist strap USB cable

Battery charger

Power cord

CD-ROM (with User Man.) Quick Start Guide

2 GB SD card

Camera pouch AV cable

Chapter 1: Introduction

Camera Views

Front View

Flash

Self-timer LED /

AF Assist Lamp

Zoom Lens

Microphone

Back View

LCD screen

Display button

DISP

Top View

Shutter button

LED indicator

Stabilizer button

Power button

Zoom buttons

Play button

Bottom View

Battery/ SD card compartment

Chapter 1: Introduction

USB / TV Out

Speaker

Tripod screw hole

Left View

Strap ring

Camera Buttons

Your camera is equipped with different buttons for ease of use.

Button

Power

Stabilizer

Shutter

Playback

Zoom

Display

(DISP)

Description

Press to turn on/off the power.

The stabilizer sets the optimal ISO value according to light levels to compensate for camera shake.

Press to set stabilizer on/off.

Press to capture an image or start/stop recording video or audio clip.

If the camera is turned off, press and hold for 3 seconds to turn on camera in

Playback mode.

If the camera is turned on, press to toggle camera to Playback or Record mode.

Press the zoom buttons to change zoom focus.

Press to change LCD screen display to show OSD icons and guide lines.

Chapter 1: Introduction

Notifications

Your camera gives feedback to users in two ways:

• LED Indicators

• Operation Sound

Led Indicators

Your camera is equipped with 2 LED indicators:

• Operation Lamp, located on top of your camera. See “Top View” on page 3 to

locate the Operation Lamp, and

• Self-timer Lamp, located in the front of the camera. See “Front View” on page 3

to locate the Self-timer Lamp.

Operation

Lamp

LED

Self-timer

LED

LED Status Camera Status

Off

Green (steady)

Red (slow blinking)

Power Off.

Power On.

Ready to take pictures / record / playback.

Green (fast blinking)

Green (slow blinking)

Camera busy or deleting / copying images

/ recording / data transfer is in progress.

Playing slideshow or recording voice or movie.

Power saving (sleep mode).

Amber (steady)

Amber (very fast blinking) In Record mode, flash is charging or AF error.

In Playback mode, self-timer countdown error.

Amber (fast blinking)

Amber (slow blinking)

Battery low or card error.

Error message: card locked, file / folder error, no memory card, copy / format error.

Off

Red (fast blinking)

Self-timer off.

Self-timer countdown is set between 3 to

10 seconds.

Self timer countdown is set between 0 to 3 seconds.

Chapter 1: Introduction

Operation Sound

Your camera is equipped with a speaker for operation sound.

Buzzer

One beep

Two beeps

Three beeps

Continuous beep

Camera Status

Denotes the start of an operation like recording and printing. Also beeps when using menu and set properties.

Denotes completion of an operation.

Denotes low battery and other warning and error message like memory full and card error.

Beeps every second for countdown if self-timer is set between 3 to

10 seconds. Beeps every half second if self-timer is set between 0 to

3 seconds. Beep goes off after the countdown.

The shutter is pressed to record an image. Shutter sound

A startup sound can be set when you power on your camera in the sound setting menu. See

“Setting System Sound” on page 55

Camera Memory

Internal memory

Your camera is equipped with 32 MB of internal memory. Users can store images up to 10 MB. If there is no memory card inserted in the memory card slot, all images, videos and audio clips recorded are automatically stored in the internal memory.

External storage

Your camera supports SD cards of up to 2 GB in size. It also supports SDHC cards with a maximum capacity of 8 GB. If there is a storage card inserted in the memory slot, the camera automatically saves all images, videos and audio clips in the external storage card.

Chapter 2: Getting Started

Getting Started

Attaching the Wrist Strap

Follow these instructions to attach the wrist strap to your camera to facilitate easy carrying:

1. Insert the short loop of the strap in the strap ring.

2. Thread the larger loop of the strap though the short loop and pull tight to attach the strap to the camera.

DISP

Inserting the Battery

Follow these instructions to insert the Li-ion battery into the battery compartment.

Please read

“Battery Information” on page v

before inserting/removing

batteries.

1. Make sure the power is off before inserting the batteries.

2. Open the battery compartment at the bottom of the camera.

DIS

3. Insert the battery into the compartment with the terminal facing inside the camera and the battery indent next to the compartment door.

DIS

4. Close the battery compartment.

DIS

Chapter 2: Getting Started

Inserting an SD/SDHC Memory Card

Expand your camera’s storage by using SD or SDHC memory cards. Your camera supports SD cards of up to 2 GB and SDHC cards of up to 8 GB in size.

Follow these instructions to insert the SD/SDHC card.

1. Open the battery compartment at the bottom of the camera.

DIS

2. Insert the SD/SDHC card into the memory card slot with the metallic part facing the front side of the camera.

3. Push the SD/SDHC card into the memory slot until it clicks into place.

DIS

LOCK

4. Close the battery compartment.

DISP

Note

To remove the SD/MMC card, gently push the card until it pops out. Pull out the card carefully.

Charging the Battery

The battery that comes along with your package is not charged. You need to charge the battery before using the camera.

1. Insert the battery into the battery charger as shown.

2. Connect the power cord to the battery charger.

3. Plug the power cord to the main outlet (230 V ~ 50 Hz).

The battery charging time is 2 hours.

Chapter 2: Getting Started

The battery icon on the LCD screen indicates the battery level. See

“LCD

Screen Layout” on page 11

Turning the Power On and Off

There are two ways to turn on the camera:

• Press and hold the Power button for 0. 3 seconds. The start up image displays briefly and the startup sound plays if enabled. The zoom lens extends and the camera is turned on in Record mode.

• Press and hold the Playback button for 0.3 seconds. The camera is turned on in Playback mode. The zoom lens are not extended.

To turn off the camera, press the Power button.

See

“Modes” on page 10

to know more about Record and Playback mode.

Initial Settings

When you turn on your camera for the first time, you will be asked to do the initial settings of your camera.

When you turn the Power button on, the Language Menu is displayed on the LCD screen for you to setup the display language.

Setting the Language

1. Tap , to move through the selection.

2. Tap to select language.

Setting the Date & Time

1. Tap the screen to move through date and time.

2. Tap or to change the value of date and time.

3. Tap SET to apply.

Now, you are ready to start taking photos and videos.

Note

If the batteries are removed for more than 48 hours, the Date & Time will have to be re-set.

Chapter 2: Getting Started

Modes

Your camera has two modes:

Record mode

• Set to Record mode to capture images and record videos and audio clips.

• Record mode can be further set to:

• Snapshot mode. Use this mode to capture still images. Other scene modes can be selected in Snapshot mode.

• Camcorder mode. Use this mode to record video.

• Voice Recorder mode. Use this mode to record voice clips.

See

"Selecting the Record mode options"

below.

Playback mode

• Set your camera to Playback mode to view and edit captured images and playback videos and audio clips. You can also attach voice memo to images in this mode.

When you turn on your camera using the Power button, you are automatically turned on Record mode.

Switching between Record mode and Playback Mode

In Record mode, press the Playback button to switch to Playback mode.

In Playback mode, press the Playback button to switch back to Record mode.

Selecting the Record mode options

Maximize the quality and ease of use of your camera by using the different mode options. The mode options allow you to capture images with preset settings according to scene conditions.

1. Set the camera to Record mode.

2. Tap to launch Quick-Set Bar.

3. Tap submenu.

to launch Scene Mode

4. Tap to select scene.

5. Tap to close menu.

ISO

AUTO

Note

Scene mode icon may vary depending on the current mode.

For more information, see “Setting Snapshot Menu”, p.27 and “Using Quick Set Bar", p. 19

Chapter 3: Using the LCD Screen

Using the LCD Screen

The high resolution 3” touch screen LCD screen shows all important information regarding camera settings as well as the visual image of your photo or video. The display on the LCD screen is called the On Screen Display or OSD.

LCD Screen Layout

The following illustrations show the LCD screen layout and icon descriptions.

Record Mode Screen Layout

1 2 3 4 5 6 7

No.

Item

1 Record Mode

2 Flash

3 Focus Mode

4 Self-timer / Burst

5 Zoom indicator

6 Shots available

7 Resolution

8 Quality

9 Focus frame

15 14 13 12

Description

Indicates the current record mode settings.

Indicates flash settings.

Indicates focus mode settings.

Indicates drive mode settings.

Displays zoom.

Indicates the remaining shots available.

Displays resolution settings.

Displays quality settings.

Use to frame subject to capture.

Chapter 3: Using the LCD Screen

No.

Item

10 Exposure

11 Quick-Set Bar

12 ISO

13 White Balance

14 Metering

15 Histogram

16 Battery

Description

Displays exposure settings.

Tap to activate Quick-Set Bar.

Displays ISO settings.

Displays white balance settings.

Displays metering settings.

Graphic display of ISO settings.

Indicates battery level.

Playback Mode Screen Layout

The Playback mode display varies depending on the type of image being viewed.

Playback mode display of still images:

1 2

F 3.0

1/ 30

7 6 5 4

No.

Item Description

Battery

File no. / Total no.

Indicates battery level.

Indicates the file number over the total number of files in the memory.

Recording information Displays recording information of the file.

Quick-Set Bar Tap to activate Quick-Set Bar.

Slideshow

Tap to display next file.

Tap to start slideshow.

No.

Item

Voice memo

9 DPOF

10 Protect

Chapter 3: Using the LCD Screen

Description

Tap to display previous file.

Indicates voice memo is attached.

Indicates the file is marked for printing.

Indicates the file is protected.

Chapter 3: Using the LCD Screen

Playback mode of videos:

1 2

7 6 5 4

00:30/00:50

No.

Item

Battery

File no. / Total no.

Movie clip

Quick-Set Bar

Slideshow

Description

Indicates the battery level.

Indicates the file number over the total number of files in the storage card.

Indicates the file is a movie.

Tap to activate Quick-Set Bar.

Tap to display next file.

Tap to activate slideshow.

Chapter 3: Using the LCD Screen

No.

Protect

Item

Volume

Playback buttons

11 Playing status

12 Played time

Description

Tap to display previous file.

Indicates the file is protected.

Adjusts and displays volume level.

Tap buttons to play / pause / stop / fast forward / rewind movie.

Displays playing status.

Indicates played time.

Chapter 3: Using the LCD Screen

Playback mode of audio clips:

1 2

7 6 5 4

00:30/00:50

No.

Item Description

Battery Indicates the battery level.

File no. / Total no.

Indicates the file number over the total number of files in the storage card.

Voice memo

Quick-Set Bar

Slideshow

Indicates the file is an audio file

Tap to activate Quick-Set Bar.

Tap to display next file.

Tap to activate slideshow.

Chapter 3: Using the LCD Screen

No.

Item Description

Protect

Tap to display previous file.

Indicates the file is protected.

Volume Adjusts and displays volume level.

Playback buttons Tap buttons to play / pause / stop / fast forward / rewind audio playback.

11 Playing status

12 Played time

Displays playing status.

Indicates played time.

Chapter 3: Using the LCD Screen

Changing the LCD Screen Display

The type of information displayed on the LCD screen can be changed using the

Display

button.

Press the Display button repeatedly to change the LCD display from one type to another.

In Record Mode, the LCD display can be changed into any of the following:

OSD on Full OSD on

Guide lines on OSD off

Note

• The OSD information may vary depending on the record mode type.

• Use the “Guide lines” to properly set image for capture.

In Playback mode, the LCD display can be changed into any of the following:

F 3.0

1/ 30

OSD on Full OSD on

Note

LCD display cannot be changed in the following situations:

• Manual exposure mode

• Recording movie or audio clips

• Playing movie or audio clips

• Playing slideshow

OSD off

Chapter 3: Using the LCD Screen

Using Quick-Set Bar

The Quick-Set Bar acts as a shortcut menu to adjust basic settings in Record and Playback Mode.

The menu icons show the current settings for each function. The icons vary depending on the selected mode and its settings.

Tap to launch Quick-Set Bar.

Tap to close Quick-Set Bar.

Snapshot Mode

ISO

AUTO

Quick-Set Bar icon

The Quick-Set Bar in Snapshot mode contains nine menu options, three of which are user-defined.

Availability of some menu functions vary depending on the scene mode selected.

Unavailable functions or functions with preset settings appear as gray icons.

5 7

No.

Menu Item

Scene Mode

Flash

Focus Mode

Drive Mode

Main Menu

Hot Key

Description

Tap to select scene mode.

Tap to change flash settings.

Tap to change focus mode settings.

Tap to change drive mode settings.

Tap to go to Snapshot and Settings Menu.

Tap to change settings of selected function. The three hot keys can be changed by the user. See

“Setting Hot Key” on page 57

Tap to close Quick-Set Bar.

7 Close

To enter the function submenu, tap the corresponding icon. For example, to access Flash mode submenu, click Flash mode icon, the submenu options pop up. See illustration on the right.

To select option, tap the desired settings icon.

Tap to exit submenu.

ISO

AUTO

Chapter 3: Using the LCD Screen

Camcorder Mode

The Quick-Set Bar in Camcorder mode contains 10 menu options. You can easily set basic video settings using the menu options here.

Functions with preset settings appear as gray icons. To activate the function submenu, tap the function icon.

To access other camcorder settings, tap the Main Menu icon.

No.

Menu

Scene Mode

Quality

Frame Rate

White Balance

Main Menu

Movie Size

Focus Mode

Effect

Voice Recorder Mode

Description

Tap to select scene mode.

Tap to change quality settings.

Tap to change frame rate settings.

Tap to adjust white balance.

Tap to go to Camcorder and Settings Menu.

Tap to change size settings.

Tap to change focus mode settings.

Tap to add effects.

Tap to close Quick-Set Bar.

The Quick-Set Bar in Voice Recorder mode contains three menu options.

To access the settings menu, tap the Main Menu icon.

No.

Menu

Scene Mode

Main Menu

Description

Tap to change scene mode.

Tap to go to Settings Menu.

Tap to close Quick-Set Bar.

Chapter 3: Using the LCD Screen

Playback Mode

The Quick-Set Bar in Playback mode contains 10 menu options. Unavailable functions or functions with preset settings appear as gray icons.

To activate the function submenu, tap the function icon.

To access other playback settings, tap the Main Menu icon.

No.

Menu Item

Effect

Rotate

Z-Lighting

Protect

Main Menu

Add Memo

Photo Frame

DPOF

Delete

Description

Tap to add effects to image.

Tap to rotate image.

Tap to adjust Z-lighting settings.

Tap to lock image.

Tap to go to Main Menu.

Tap to add a memo dialog to the image.

Tap to add photo frame to image.

Tap to mark image for printing.

Tap to delete image.

Tap to close Quick-Set Bar.

Chapter 4: Recording Photos, Videos and Voices

Recording Photos, Videos and Voices

Taking Photos

Now that you are familiar with your camera, you are now ready to take your photos.

Taking photos with your camera is very simple.

1. Turn on the camera by pressing the

Power button. By doing this, your camera is also set to Record mode.

2. Frame the shot using the focus bracket on the LCD screen. See illustration on the right.

3. Half press the Shutter button. The camera automatically adjusts the focus and exposure. When the camera is ready to take the photo, the frame bracket turns green, the shutter speed and aperture value are displayed.

4. Fully press the Shutter button to capture image.

When the shake warning icon appears, hold the camera steadily, with your arms at your side or use a tripod to stabilize the camera to prevent blurred images.

Using the Stabilizer

The Stabilizer function prevents blurred images caused by shaking.

This function is only available if ISO is set to Auto. See

“ISO” on page 28

on how to adjust the ISO settings.

Stabilizer button

Chapter 4: Recording Photos, Videos and Voices

To activate Stabilizer

• Press the Stabilizer button on top of your camera to enable/disable stabilizer.

Setting Zoom Control

Your camera features up to 3x optical zoom and up to 5x of digital zoom. Optical zoom is achieved by mechanically adjusting the lens. While digital zoom is activated through the menu settings. Please refer to

“Setting Digital Zoom” on page 55

on how to setup digital zoom.

To adjusts optical zoom:

1. Press the Zoom buttons to zoom in or zoom out an image.

2. The zoom indicator appears on the LCD screen.

Zoom buttons

Press to zoom in.

Press to zoom out.

To adjusts digital zoom:

1. Activate digital zoom. See

“Recording Movies” on page 35

2. Press the T button to optically zoom in to the maximum until it stops.

3. Release the button.

4. Press the T button again to switch to digital zoom automatically. Zooming continues.

Optical zoom

Digital zoom

Note

Digital zoom is not activated in recording movies.

Chapter 4: Recording Photos, Videos and Voices

Setting Scene Mode

Setting the Scene mode allows you to capture images with preset settings according to the scenes or environment.

1. Tap > to launch Scene

Mode submenu.

2. Tap to select desired scene.

Note:

The Scene Mode icon may vary depending on the current settings.

ISO

AUTO

The succeeding table shows the available scene mode settings.

Icon

Auto

Portrait

Item

Program

Description

The simplest way to shoot basic images. Settings are adjusted automatically.

The camera automatically adjusts suitable shooting settings like shutter speed and aperture values.

The camera blurs the background to focus on the subject.

Landscape

Sunset

Backlight

Smile Detection

Kids

Night Scene

Fireworks

This feature is used to emphasize wide scenic views.

This feature enhances the red hue for recording sunset images.

This feature is used to capture the image of a backlight object by changing the metering.

This feature uses smile tracking to auto detect faces to capture. When smiles are detected, it continuously captures the image. See

“Using Smile Detection

Mode” on page 25

This feature is used to capture still images of moving kids.

This feature is used to capture images with night scenery background.

This feature slows shutter speed to capture fireworks explosions.

Chapter 4: Recording Photos, Videos and Voices

Icon

Sports

Item

Party

Candlelight

NIght Portrait

Soft Skin

Description

This feature captures still images in high speed motions.

This feature is used for wedding or indoor party settings.

This feature is used to capture warm candle light effects.

This feature is used to capture portrait pictures with night or dark background.

This feature enhances skin tone thus facial skin appears smooth.

Food

Building

Text

Auction

Camcorder

This feature is used to capture food images. The increased saturation in this mode makes the captured image more enticing.

This feature enhances the edges of captured images.

This feature enhances the black and white contrast normally used when capturing text images.

Pictures taken in Auction mode are automatically saved under a specific folder named “_AUCT”. See

“Folder Structure” on page 62

for more

information.

This mode is used to record movie clips.

Voice Recorder This mode is used to record audio clips.

Using Smile Detection Mode

The Smile Detection mode uses smile tracking to automatically capture images.

Pressing the shutter button will enable the camera to take continuous shots whenever a smile is detected. This feature is most useful in capturing different angles and smiles of moving people.

To activate Smile Detection

1. Select from Scene Mode submenu.

2. Focus the camera on the subject to capture.

Chapter 4: Recording Photos, Videos and Voices

3. Press the shutter button to start smile detecting. The smile detection icon blinks every second to denote camera activity.

Smile Detection Icon

Camera dislays frame when smile is detected.

4. When smile is detected, the camera will automatically take a shot of the image.

It will continuously take shots whenever a smile is detected.

5. To stop shooting, press the shutter button again. The smile detection icon stops blinking to denote camera inactivity.

Setting Flash

When taking pictures in difficult lighting conditions, use the Flash to get correct exposure.

This function cannot be activated in recording movies or continuous shooting.

1. Tap > Flash mode icon.

2. Tap your desired flash mode.

Your camera is equipped with six flash modes:

Auto flash. The flash fires automatically whenever extra lighting is needed.

Forced off. The flash is turned off.

Forced on. The flash fires whenever you press the shutter button regardless of lighting conditions.

Auto Red-eye. The flash fires twice to reduce the red-eye effect when necessary.

ISO

AUTO

Auto flash is enabled.

Red-eye reduction. The flash fires twice to reduce the red-eye effect.

Slow sync. The flash fires with a slow shutter speed.

Chapter 4: Recording Photos, Videos and Voices

Setting Snapshot Menu

The Snapshot menu allows you to adjust other capture settings. Some menu functions may be disabled depending on current scene mode.

In Snapshot mode,

Resolution

Quality

ISO

Metering

ISO

AUTO

2. Tap or to move to the next/ previous page of menu selection.

3. To select an item, tap the icon.

4. To change the submenu settings, tap the icon of desired settings.

5. Tap to exit submenu.

1/5

Indicates current page no. / total no. of menu page.

Resolution

The Resolution function is used to set the resolution before you capture the image.

Changing the resolution affects the number of images that can be stored in your memory card. The higher the resolution, the more memory space is required.

The table below shows the resolution values for still images.

Resolution

3648x2736

3648x2432

3264x2448

1/3

Icon

10M

Pixel Size

Print Size

Suggestion

3648 x 2736 A2 Size

Icon

Pixel Size

Print Size

Suggestion

2048 x 1536 4” x 6”

3:2

3648 x 2432 A2 Size

16:9

1920 x 1080 16:9

3264 x 2448 A3 Size

2592 x 1944 A4 Size

VGA

640 x 480 E-mail

Chapter 4: Recording Photos, Videos and Voices

Quality

The Quality function lets you adjust the quality settings of your photos before you capture them. The quality determines the amount of compression applied to your photos. More compression results in a more detailed image.

However, the higher the quality, the more memory space is required in your memory card.

Available settings for still images are as follows:

Quality

Superfine

Fine

Normal

1/1

Super fine, Fine, and Normal.

ISO

The ISO function lets you adjust the ISO sensitivity in recording still images depending on the lightning levels of your surroundings.

• Use a higher ISO setting in dim conditions and a lower ISO setting in brighter conditions.

• As you move through the selections, the preview on the LCD screen changes synchronously.

ISO

AUTO

ISO

100

ISO

200

Auto

100

200

1/3

• Available settings are: Auto, 100, 200, 400, 800, 1600, and 3200.

Metering

The Metering function lets you select the area of the subject or frame by which the camera measures light to record still images or movies.

Metering

Multi

Center

Spot

1/1

Icon

Multi

Item

Center

Spot

Description

The camera measures the exposure readings from multiple points in the subject area.

The camera measures the average light from the entire frame but gives more importance to the values near the center.

The camera selects the exposure value based on the center of your picture.

Chapter 4: Recording Photos, Videos and Voices

White Balance

The White Balance function allows you to adjust the camera settings according to the white light when recording still images and movies.

• When you tap a selection, you can see the preview on the LCD screen synchronously.

• Tap SET to save and apply settings.

White Balance

Icon

AWB

Auto

Item

Daylight

Description

The camera automatically adjusts the white balance.

Ideally used for bright sunny conditions.

Cloudy Ideally used for cloudy conditions.

Tungsten

Fluorescent

Custom

Ideally used for indoor photos with tungsten or halogen lighting without a flash.

Ideally used for indoor photos with fluorescent lighting conditions.

Used when light source cannot be specified. When user taps this icon,

icon appears.

White Balance Used to measure the white balance manually.

Effect

The Effect function lets you record still images or movies and apply different colors or tones for a more artistic effect.

• Tap a selection to view the effect on the

LCD screen.

• Tap SET to save and apply settings.

Effect

Icon

Normal

Item Description

The camera records normally.

Chapter 4: Recording Photos, Videos and Voices

Icon

Vivid

Item Description

The camera captures the image with more contrast and saturation emphasizing on the bold colors.

Images are captured in sepia tones.

Sepia

B&W Images are captured in black and white.

Vivid Red

Vivid Green

Vivid Blue

Captured image becomes reddish. Ideally used to record images like flowers and cars to make them more vivid.

Captured image becomes greenish. Ideally used to record images like mountains and lawns to make them more vivid.

Captured image becomes bluish. Ideally used to record images like the sky and the ocean, to make them look more vivid.

AF Area

Automatic Focus (AF) determines the area on which the camera focuses.

AF Area

The table below shows the available AF area settings.

Center

Wide

Manual

1/2

Icon Item Description

Center

Wide

Manual

Face Tracking

The focus area is fixed on the center.

The camera automatically selects focus area within the wide frame.

Users manually determines the area of focus.

The camera automatically detects the position of a face and sets the focus.

Chapter 4: Recording Photos, Videos and Voices

Using Manual AF Area mode

When you exit the menu after selecting manual mode, a white focus frame appears on the LCD screen.

White Focus Frame

Tap the white focus frame to display the instruction frame.

Instruction Frame

To manually choose the object of focus, drag the white focus frame within the instruction frame.

Flash Intensity

The Flash Intensity function allows users to adjust the intensity of flash to capture image with a brighter or dimmer lighting effect. The table below shows the available settings.

Icon

High

Normal

Item

Low

Description

Captures image with brighter lighting.

Normal lighting is applied.

Captures image with dimmer lighting.

EV Compensation

In difficult lighting condition, the auto exposure function of your camera may be misled into giving the wrong readings.

Exposure Value (EV) function allows you to adjust the exposure value and correctly expose your images. Available for still images only.

EV Compensation

Chapter 4: Recording Photos, Videos and Voices

• To adjust EV settings, tap and , drag or tap the slider bar to increase/ decrease the value. As you adjust the settings, the LCD screen synchronously displays the image applying the EV settings.

• Tap SET to save and apply changes.

• The available settings are: OEV, +2.0EV, +1.7EV, +1.3EV, +1.0EV, +0.7EV and

+0.3EV.

Photo Frame

The Photo Frame functions allows users to capture image enclosed in a frame for added effects.

To activate Photo Frame:

• Tap On.

• The LCD screen displays the frame. Tap the

or to move through other frame selections.

• Press the shutter button to capture image with selected frame.

Sharpness

This function allows you to enhance or soften finer details of your photos.

The table below shows the available Sharpness settings.

Icon Item Description

High Sharpens the image.

Normal Normal sharpness.

Low Softens the image.

Saturation

The Saturation function lets you adjust the color saturation in your photos. Use a higher saturation setting for rich colors and a lower saturation setting for more natural tones.

The table below shows the available Saturation settings.

Icon

High

Item Description

Enhances saturation.

Chapter 4: Recording Photos, Videos and Voices

Icon

Normal

Item Description

Normal saturation is applied.

Low Reduces saturation.

Contrast

This function allows you to adjust the contrast of your photos.

The table below shows the available Contrast settings.

Icon Item Description

High Enhances the contrast.

Normal Normal contrast.

Low Reduces the contrast.

Date Stamp

The Date Stamp function allows you to add the recorded date and time on your photos.

The recording date and time are based on your camera’s clock settings. Once date and time are stamped on a photo, they can no longer be edited or deleted.

Limitations of Date Stamp functions are as follows:

• Available for still images only.

• May slowdown AEB/ continuous shooting when Date Stamp is enabled in AEB/

Burst mode.

• If Date Stamp is enabled, digital zoom is automatically turned off.

• In vertical or rotated images, the date and time on your photos still appear horizontally.

Available settings are: Date, Date & Time, Off.

Focus Mode

This function allows users to define the type of focus to capture image.

The table below shows the available settings.

Icon

Item Description

Auto Focus Camera automatically focuses on a specific object.

Chapter 4: Recording Photos, Videos and Voices

Icon Item

Macro

Description

Camera focuses on the detail and sharpness of a very close image. If Macro is enabled, the macro icon is displayed on the LCD screen.

Camera focuses on every object.

Pan Focus

INF

Infinity Camera focuses on distant objects.

Drive Mode

Your camera features a Self-timer and Burst which can be set in the Drive mode function. The Self-timer allows you to take photos after a pre-defined delay. While burst lets you take consecutive shots. This function is only available in recording still images. The Drive mode setting is automatically set to off when you turn off the camera.

The table below shows the available Drive mode settings.

Icon

10 x

Off

Item Description

Captures an image without time delay.

10 Sec Self-timer

2 Sec Self-timer

Double Self-timer

Burst

AEB

Sets a 10-second delay to capture image after pressing the shutter button.

Sets a 2-second delay to capture image after pressing the shutter button.

Performs delay and capture twice:

• Performs a 10-second delay, then captures the image.

• Performs another 2-second delay then captures the image again.

Performs continuous shooting when the shutter button is pressed. Stops shooting when the shutter button is released.

Automatic Exposure Bracketing (AEB) captures the same image with three different exposure settings: standard, under, and over exposure.

Chapter 4: Recording Photos, Videos and Voices

AF Lamp

The AF Lamp function allows you to record images even in low light conditions.

If AF Lamp is set to Auto, the AF lamp located in

the front of the camera, see

“Front View” on page 3

, emits a red light by half pressing the shutter button allowing the camera to focus easily. Available settings are: [Auto] and [Off].

AF Lamp

Auto

Off

Recording Movies

1/1

00:10:00

1. To select Camcorder mode, tap from

Scene Mode menu.

2. Focus your camera on the subject that you want to take.

3. Press the Shutter button to start recording.

4. Use the control to zoom in and zoom out an image.

5. To stop recording, press the Shutter button.

Note

• Sound cannot be recorded while pressing the control.

• Digital zoom is not available in movie recording.

• The camera will automatically stop recording when the memory capacity is full.

Setting Camera to Record Movies

Use the Quick-Set Bar to change camera video settings. The Quick-Set

Bar contains shortcuts to the following menu items: Quality, Movie Size,

Frame Rate, Stabilizer, White Balance, Effect, and Main Menu.

Tap an icon to open the submenu.

Use the Camcorder Menu to change other settings like: Sharpness, Saturation, Contrast,

Focus Mode and AF Lamp. To access Camcorder

Menu, tap to open Main Menu from the

Quick-Set Bar. Then tap .

Movie Size

Quality

Frame Rate

White Balance

1/3

Chapter 4: Recording Photos, Videos and Voices

Setting Movie Size

The Movie Size function icon appears only in

Movie Mode. Use this function to adjust the resolution and quality of movie clips.

The table below shows the available size and corresponding image quality settings.

Icon

848 X 480

640 X 480

320 x 240

640 x 480

Frame Size Image Quality

16:9

High Quality

Normal

YouTube Mode

YouTube Mode allows you to record movies with predefined video settings for easy upload to the YouTube website.

YouTube supports two file upload standards:

• Single File Uploader. The maximum movie file size is up to 100 MB.

• YouTube Uploader. The maximum movie file size is up to 1 GB.

Most uploaded movie length ranges within 5 minutes, although you can upload a maximum movie length of 10 minutes.

Therefore when you record using the YouTube mode, the following standards are followed:

• Recorded movies are set to YouTube standard resolution of 640 X 480.

• Recording automatically stops when the file reaches 100 MB.

Recorded movies in the YouTube mode are stored following the DCF rule, however movies are saved in a specific folder named “_UTUBE”. For more details, please

refer to

“Folder Structure” on page 62

• To record a YouTube movie, select from the Movie Size function.

Available recording time for a YouTube movie is up to 10 minutes.

Chapter 4: Recording Photos, Videos and Voices

Setting Frame Rate

Frame Rate function appears only in Camcorder mode. Use this function to specify the number of frames to capture per second (fps). The higher the frame rate value, the smoother the movie playback will be. Available settings are:

15fps, and

30 fps.

To set frame rate, tap to activate Quick-Set Bar. Tap the frame rate icon, then select option.

Setting Focus Mode

This function allows users to define the type of focus to when recording movies.

To set focus mode, tap to activate Quick-Set

Bar. Tap the focus mode icon, then select option.

The table below shows the available settings.

Icon

Item Description

Auto Focus Camera automatically focuses on a specific object.

Macro

Pan Focus

Camera focuses on the detail and sharpness of a very close image. If Macro is enabled, the macro icon is displayed on the LCD screen.

Camera focuses on every object.

INF

Infinity Camera focuses on distant objects.

Recording Voices

1. To select Voice Recording mode, tap from Scene Mode menu. The Voice

Recording Quick-Set Bar is displayed on the

LCD screen.

2. Close the Quick-Set Bar to display voice recording screen layout. See picture on the right.

Ready to record

00:00:00

00:10:00

Chapter 4: Recording Photos, Videos and Voices

3. Tap

4. Tap

or press the Shutter button to start recording.

or press the Shutter button again to stop recording.

Note

Voice recording will automatically stop when the maximum memory capacity is full.

Chapter 5: Playback

Playback

View images, videos and voice recordings through your camera’s Playback mode.

Viewing in Single Navigation

The Single navigation mode displays the image one by one on the LCD screen. To view images/videos/voice recordings, follow the steps below.

1. Press the Playback button to set or turn on the camera to Playback mode.

2. The LCD screen displays an image. To understand the icons and other

information on the screen, please see

“Playback Mode Screen Layout” on page 12

Still Image Movie Audio Clip

3. Tap or

to view next/previous image/video/voice recording.

4. To access Quick-Set Bar, tap .

5. To play a video or a voice recording, tap anywhere on the LCD screen. See

“Playing Movies” on page 42

and

“Playing Voice Recording” on page 42

for more details.

Viewing Slideshow

The Slideshow function allows you to view all stored images/videos/voice recordings in still image format in a continuous sequence.

To view slideshow, tap .

To stop slideshow, tap anywhere on the LCD screen.

Chapter 5: Playback

Viewing in Drag & Play Mode

1. Press the W button to view files in Drag &

Play mode.

2. Flick your finger to the left/right or tap or previous/next file.

to change display to

3. Tap the image/video/voice recording to view/play it normally.

Viewing Thumbnails

1. From single navigation mode, press the W button twice to view 12-image thumbnails.

2. Tap or to view next/previous page.

3. Tap a thumbnail to view it normally.

Thumbnail icons

When you view the thumbnails, some images may contain icons. These icons indicate the type of file or recording.

Icons Type

Voice Memo

Movie

Locked File

Description

Indicates that a voice memo is attached to the image.

Indicates a recorded movie. The image displayed is the first frame of the movie clip.

Indicates that the image has been locked. Locked files cannot be edited or deleted.

Chapter 5: Playback

Icons Type

Voice Record

DPOF File

File Error

Description

Indicates a voice recording file.

Indicates the file is marked for printing.

Indicates an error file.

Zooming Images

The zoom view function works with still images only.

In normal view, press the T button to activate zoom function, see picture below.

Shows zoom location.

2.0x

You can zoom view an image from 1x to 12X. To achieve desired zoom view, press the T button repeatedly to increase zoom. Press the W button to decrease zoom.

You can also tap or

to decrease/increase zoom.

To trim an image based on selected zoom view, tap .

To exit zoom function, tap .

Trimming an Image

The Trim function allows you to trim an image to another image size. This function is only available for still images.

1. View the image to trim.

2. Press the T button to activate zoom function.

or repeatedly until desired image view 3. Press the T/W button or tap to trim.

4. Tap to trim image.

Chapter 5: Playback

5. Confirm trim, select whether to:

• Save As. Save changes to a new file.

• No. Discard changes.

• Overwrite. Save and apply changes to the current file.

Playing Movies

1. Select video to play. A video file has a video icon displayed on screen. See picture on the left.

2. Tap anywhere on the LCD screen to play video.

3. During playback, tap anywhere on the LCD screen to display the video toolbar.

4. During playback, use the to control volume.

Press the T/W button to increase/ decrease volume.

5. Tap or

or the slider bar to rewind or fast forward the movie.

00:30/00:50

6. Tap to pause playback. Tap

to resume playback.

7. Tap to stop playback. The LCD screen displays the movie frame image in Single navigation mode.

Playing Voice Recording

1. Select the voice recording file to play.

2. Tap anywhere on the LCD screen to play recording.

3. During playback, use the to control volume. Press the T/W button to increase/ decrease volume.

4. Tap or

or the slider bar to rewind or fast forward the voice recording.

00:30/00:50

Chapter 5: Playback

5. Tap to pause playback. Tap to resume playback.

6. Tap to stop playback. The LCD screen displays the movie frame image in Single navigation mode.

Playing Voice Memo

Voice memo is recorded and attached separately

to a captured image. See

“Voice Memo” on page 51

on how to record voice memo.

1. Select the image with voice memo. An image file with voice memo has a voice memo icon located on the left side of the

LCD screen.

2. Tap the voice memo icon to play voice memo.

3. During playback, use the to control volume. Press the T/W button to increase/ decrease volume.

4. Tap or

or the slider bar to rewind or fast forward the voice recording.

5. Tap to pause playback. Tap to resume playback.

00:30/00:50

6. Tap to stop playback. The LCD screen displays the movie frame image in Single navigation mode.

Using My Drawing

My Drawing function lets you draw freely and add other graffiti on still images. This function is not available for images captured with VGA and 16:9

HD resolution.

1. View image to add drawings to.

2. Tap > . The My Drawing toolbar is displayed on the LCD screen.

3. Tap on an icon to use the function. For example, to draw freely on the image, tap the pen icon.

4. Press Display button to hide the toolbar.

Chapter 5: Playback

5. Start drawing on the image. See picture on the right.

6. When done, press Display button to display the toolbar.

7. Tap to save changes.

8. Select whether to:

• Save As. Save changes to a new file.

• No. Discard changes.

• Overwrite. Save and apply changes to the current file.

Save changes?

Save As

Overwrite?

Using My Drawing Toolbar

The toolbar icons may vary depending on the current function selected.

Icon Description

Tap to draw freely on the photo.

Icon Description

Tap to select color.

Tap to undo/redo last operation.

Tap to stamp symbols on the photo.

Tap to erase drawings on the photo.

Tap to select pen stroke.

Tap to select stamp stroke.

Tap to reset all operations.

Tap to save changes.

Tap to exit My Drawing function.

Adding a Memo Dialog to an Image

The Add Memo function lets you add a memo dialog to a still image. This function is not available for images captured with VGA and 16:9 HD resolution.

1. View the image to add memo dialog to.

2. Tap > . The My Drawing toolbar is displayed on the LCD screen.

3. Tap to use add memo function. Tap to select dialog stroke.

4. Press Display button to hide the toolbar.

Chapter 5: Playback

5. Tap on the LCD screen position to add memo dialog. See picture on the right.

6. When done, press Display button to display the toolbar.

7. Tap to save changes.

8. Select whether to:

• Save As. Save changes to a new file.

• No. Discard changes.

• Overwrite. Save and apply changes to the current file.

Save changes?

Save As

Overwrite?

Rotating Images

The Rotate function lets you change the orientation of a saved photo. This function in only available for still images. Rotated images are saved as the current file.

1. View the image to rotate.

2. Tap > .

3. Tap or to rotate image 90º counter clockwise / clockwise. Tap the icons repeatedly until desired orientation is achieved. The preview on the LCD screen changes synchronously.

4. Tap SET to apply and save changes.

Adding Photo Frame

For a more artistic effect, you can frame your still images using the Photo Frame function. This function is for still images only. However, photo frame is not available for images captured in 16:9 HD resolution.

1. View the image you want to add photo frame to.

2. Tap > . The framed image is displayed on the LCD screen.

3. Tap or photo frame selections.

to move through the

Chapter 5: Playback

4. Tap SET to add selected photo frame.

5. Select whether to:

• Save As. Save image as a new file.

• No. Discard changes.

• Overwrite. Save and apply changes to the current file.

Add frame?

Save As

Overwrite?

Setting Z-Lighting

The Z-Lighting function allows you to manually adjust the exposure to compensate for inadequate lighting conditions. This function is only applicable for still images.

The edited image can be saved as a new file.

1. View the file to adjust lighting.

2. Tap > .

Z-Lighting

3. Tap or

or the slider bar to increase/ decrease the value. As you adjust the settings, the LCD screen synchronously displays the image applying the new settings.

• Available settings are: 0.0, 1.0, 2.0, 3.0, and 4.0.

4. Tap SET to continue.

5. Select whether to:

• Save As. Save as another file.

• No. Discard changes.

• Overwrite. Save and apply changes to the current file.

Save changes?

Save As

Overwrite?

Setting DPOF

The Digital Print Order Format (DPOF) function allows you to mark still images in your memory card for printing and allows you to specify the number of copies that you want to print at a later date. When all images to be printed are marked, take the memory card to a digital printing service, or use a DPOF compatible printer.

To set DPOF on a single file

1. View image/video/voice recording you want to set DPOF on the LCD screen.

Set DPOF?

Yes

2. Tap > . See picture below.

3. To set DPOF on currently viewed file, tap Yes.

Select

All

Chapter 5: Playback

4. Set the number of copies and date stamp on/ off. Tap the up/down keys to change settings.

5. Tap SET to save settings.

DPOF Setting

Copies

Date

Yes

To set DPOF on multiple files

1. Tap > .

2. Tap Select. The LCD screen displays files in thumbnail view.

3. Tap a thumbnail to mark file for printing. The

DPOF icon appears on the thumbnail.

4. Tap DPOF to continue.

5. Select Yes to confirm protect.

6. Set the number of copies and date stamp on/ off.

7. Tap SET to save settings.

Set DPOF?

Yes

To set DPOF on all files

1. Tap > .

2. Tap All.

3. Confirm to set DPOF on all files.

4. Set the number of copies and date stamp on/ off.

5. Tap SET to save settings.

Set DPOF?

Yes

Select

All

To set DPOF off

Files marked for printing can be set off following the same procedures above.

Note

If the camera is in thumbnail mode, tapping > displays protect multiple files interface.

You can specify up to 30 copies for DPOF. If you specify 0 copies, the DPOF setting of that image is automatically disabled.

Chapter 5: Playback

Protecting/Unprotecting Files

The Protect function lets you lock a file to protect it from being modified or accidentally erased. A protected file has a lock icon when viewed on Playback mode.

Note

If the camera is in thumbnail mode, tapping interface.

> displays protect multiple files

To protect a file

1. View image/video/voice recording you want to protect on the LCD screen.

2. Tap > . See picture on the right.

3. To protect currently viewed file, tap Yes.

To protect multiple files

1. Tap > .

2. Tap Select. The LCD screen displays files in thumbnail view.

3. Tap a thumbnail to mark file for protection. The protect icon appears on the thumbnail.

4. Tap Protect to protect marked files.

5. Select Yes to confirm protect.

To protect all files

1. Tap > .

2. Tap All.

3. Confirm to protect all files.

To unprotect files

Protected files can be unlocked following the same procedures above. Tapping > displays an unprotect confirmation message. See picture on the right.

Yes

Protect this file?

Yes

Select

All

Protect selected?

Unprotect this file?

Yes

Select

All

Chapter 5: Playback

Deleting Files

The Delete function lets you remove unwanted files in the internal memory or on the memory card.

Note

Protected files can not be deleted. Make sure the file is not protected before proceeding. To

unprotect a file, see “To unprotect files” on page 48 . If the camera is in thumbnail mode,

tapping > displays delete multiple files interface.

To delete a file

1. View image/video/voice recording file you want to delete on the LCD screen.

2. Tap > . See picture on the right.

3. To delete currently viewed file, tap Yes.

To delete a voice memo

1. View the image file with voice memo attached on the LCD screen.

Delete this file?

Yes

Voice only

Select

All

Voice only icon is enabled only when viewed image has a voice memo attached.

2. Tap > .

3. To delete the voice memo only, tap Voice only.

To delete multiple files

1. Tap > .

2. Tap Select. The LCD screen displays files in thumbnail view.

3. Tap a thumbnail to mark file for deletion. The recycle bin icon appears on the thumbnail.

4. Tap Delete to delete marked files.

5. Select Yes to confirm delete.

To delete all files

1. Tap > .

2. Tap All.

3. Confirm to delete all files.

Delete the selected?

Yes

Chapter 5: Playback

Setting Playback Menu

The Playback menu allows you to edit images, delete files, records voice memo, and setup other playback settings.

To go to Playback Menu:

Resize

Voice Memo

Protect

Delete

1/3

2. Tap or to move to the next/previous page of menu selection.

3. To select an item, tap the icon.

Indicates current page no. / total no. of menu page.

4. To change the submenu settings, tap the icon of desired settings.

5. Tap to exit submenu.

Resize

The Resize function allows you to change the image resolution of large images to smaller ones. This function is only available for still images.

To resize an image:

1. View image to resize on the LCD screen.

2. From the Playback menu, tap Resize

.

3. Tap desired size. Select size among: 8M, 5M,

3M, and VGA. Available size settings may vary depending on original image size.

Unavailable settings appear as gray icons.

Resize this file?

VGA

4. After selecting size, tap to confirm whether to:

• Save As. Save the new file as a new one.

• No. Discard resize.

• Overwrite. Apply and save changes to the current file.

Save changes?

Save As

Overwrite?

Note

Resize function is not available for photos with image size set to VGA.

Chapter 5: Playback

Voice Memo

The Voice Memo function allows you to record and attach a voice memo to a saved image. You can record a maximum of 20 seconds of Voice memo per image. This function is only available for still images.

To record voice memo:

1. View image to attach voice memo on the LCD screen.

2. From the Playback menu, tap Voice Memo.

The voice recording interface is displayed on the LCD screen.

Resize

Voice Memo

Protect

Delete

1/3

3. Tap to start recording.

Recording Memo

00:12

Time left for recording.

4. Tap to stop recording. The voice memo is automatically saved and attached to the image.

To attach voice memo to an image with existing voice memo:

1. View the image with an attached voice memo on the LCD screen.

2. From the Playback menu, tap Voice Memo.

3. The Overwrite confirmation message appears.

Tap whether to:

Overwrite?

• Yes. Record another voice memo to replace the existing one.

• No. Retain existing voice memo and exit the function.

Yes

4. When you select Yes, the Recording memo interface is displayed on the LCD screen. Follow the procedure in recording a voice memo mentioned above.

Red-Eye Correction

The Red-Eye Correction function is used to reduce red-eye in captured images.

This function is only available for still images. Red-eye correction can be applied to an image several times, but the quality may gradually deteriorate.

Chapter 5: Playback

To activate Red-Eye Correction:

1. View the image on the LCD screen.

Red-eye Correction

2. From the Playback menu, tap Red-eye

Correction

3. The image is displayed on the LCD screen with corrected red-eye.

4. Tap SET to apply red-eye correction.

5. Tap whether to:

• Save As. Save the image to a new file.

• No. Disregard red-eye correction.

• Overwrite. Apply and save changes to the existing file.

Effect

The Effect function lets you edit still images to apply different colors or tones for a more artistic effect.

To add Effect:

1. View the image on the LCD screen.

2. From the Playback menu, tap Effect. The Effect icons appear.

Effect

3. Tap desired settings to preview effect on the

LCD screen. See table for more information.

4. Tap SET to continue.

5. Tap whether to:

• Save As. Save the image to a new file.

• No. Disregard changes.

• Overwrite. Apply and save changes to the existing file.

The succeeding table shows the available settings.

Description

No effect is added to the image.

Icon

Normal

Item

Sepia

B&W

Negative

Neg.

Mosaic

Image is saved with a sepia tone.

Image is saved in black and white.

Image appears to be the opposite of the original image.

Image is saved with mosaic tiles.

Vivid Red Image is saved with reddish tint.

Icon Item

Vivid Green

Vivid Blue

Chapter 5: Playback

Description

Image is saved with greenish tint.

Image is saved with bluish tint.

Chapter 6: Using the Setting Menu

Using the Setting Menu

You can access the Setting menu whether you are in Record or Playback mode.

The Setting menu allows you to configure general camera settings. Submenu options may vary depending on the current mode. Unavailable are disabled.

To go to Setting Menu:

Memory Kit

1. Tap > > .

Auto Review

2. Tap or

to move to the next/ previous page of menu selection.

3. Tap a submenu option to change submenu settings.

4. Tap to exit submenu.

Digital Zoom

System Sound

1/4

Indicates current page no. / total no. of menu page.

Setting Memory Kit

Use this function to manage contents of the internal memory or memory card.

Available settings are:

• Format. Select to format currently used memory.

• Copy to Card. Select to copy all files stored in the internal memory to the memory card.

Note

Memory Kit

Format

Copy to Card

1/1

• If there is a memory card inserted in the memory slot, the camera automatically saves all files to the memory card.

• If there is no memory card or the internal memory is empty, the Copy to Card function is disabled.

Setting Auto Review

The Auto Review function lets you view the captured image right after shooting it.

Available settings are: Off, 1 sec., 2 sec., 3 sec., and 5 sec.

To set Auto Review

1. From the Setting menu, tap Auto Review.

2. Tap to apply desired settings.

This function is not available in camcorder mode.

Auto Review

Off

1 sec.

2 sec.

1/2

Chapter 6: Using the Setting Menu

Setting Digital Zoom

This feature controls the digital zoom mode of your camera.

Your camera enlarges an image using the optical zoom first. When the zoom scale exceeds 5x, the camera uses digital zoom.

To set Digital Zoom

1. From the Setting menu, tap Digital Zoom.

2. Tap to apply desired settings.

The table below shows the available Digital Zoom settings.

Icon Item

Intelligent Zoom

Standard Zoom

Description

Enlarges the image digitally with almost no distortion.

Enlarges all image sizes up to a maximum of 12x, but the image quality deteriorates.

Off Uses the optical zoom only.

Note

The maximum Intellect zoom scale varies depending on the image type and resolution.

Setting System Sound

Use the Sound menu function to enable/disable sound when a button is pressed or tapped.

Available settings are: On, Off.

1. From the Setting menu, select System

Sound

2. Tap to apply desired settings.

Setting Volume

Use the Volume function to control sound volume produced by the camera. Available settings are:

Volume 0(Off), Volume 1, Volume 2, Volume 3,

Volume 4, Volume 5.

1. From the Setting menu, select Volume.

2. Tap to apply desired settings.

System Sound

Off

1/1

Volume

Volume 0

Volume 1

Volume 2

1/2

Chapter 6: Using the Setting Menu

Setting LCD Brightness

Use the LCD Brightness function to control the

LCD brightness. Available settings are:

• Bright. Enhances LCD brightness.

LCD Brightness

Bright

Normal

• Normal. Normal LCD brightness.

1/1

Setting Power Save

The Power Save function allows you to set an idle time after which the camera automatically sets to sleep mode to save power. After a minute of being in sleep mode, the camera eventually turns off power.

Available settings are: 1 min., 3 min., and 5 min.

This function is not available in the following instances:

• Recording a movie or audio file

• Playing a slideshow/movie/audio file

• Using the USB connector.

Power Save

1 min.

3 min.

5 min.

1/1

Setting Date & Time

Use the Date & Time function to set the date and time of your camera. This function is useful in attaching date stamps on captured images.

Your camera uses a 24-hour time format.

1. Tap value. or to adjust date and time

2. Tap SET to apply changes.

Date & Time

2008 / 07 / 14 16 : 10

YY/MM/DD

Setting TV Out

Use the TV Out function to adjusts video output signal to accommodate different regional settings. If TV out is not set correctly, the image may not display properly on TV.

Chapter 6: Using the Setting Menu

Available settings are:

•

NTSC

NTSC.

Applicable in Japan, USA, Canada,

Taiwan and others.

•

PAL

PAL.

Applicable in Europe, Asia (excluding

Taiwan), Oceania and others.

TV Out

NTSC

PAL

1/1

Setting Hot Key

The Hot Key function is available only in snaphshot mode. This function allows you to define the three shortcut icons on the Snapshot Mode Quick-Set

Bar.

1. From the Settings menu, tap Hot Key. The

Hot key interface appears.

Hot Key

ISO

AUTO

2. Tap an icon on the Quick-Set Bar to replace. A pop up selection appears.

3. Tap desired submenu.

4. To replace other icons, repeat steps 2-3.

5. Tap SET to save and apply changes.

Hot Key

ISO

AUTO

ISO

AUTO

Setting Startup Image

The Startup Image function allows you to setup a startup image when you turn on your camera.

1. From the Setting menu, tap Startup


. The menu selection appears.

2. Tap to select option:

• Off. Disable the startup image.

• System. Use camera default image.

• My Photo. Select image from captured images in memory card. Tap this option to display thumbnails and select image.

3. Tap SET to apply changes.

Startup Image

Off

System

My Photo

Tap thumbnail, then tap SET to select image and close selection.

Chapter 6: Using the Setting Menu

Resetting

The Reset function is used to reset the camera to its initial default settings and to reset file numbering when saving images/videos/voice recordings.

To Reset

1. From the Setting menu, select Reset.

Reset

2. Tap option:

Reset File No.

• Reset File No. Tap to reset file numbering. To understand folder and file structure of your camera, see

“About Folder and File Names” on

Reset

1/1

page 62

• Reset. Tap to reset camera to initial default settings.

3. A confirmation message appears. Tap Yes to reset. Tap No to exit submenu.

Setting Language

The Language function allows you to choose the language of the on screen display (OSD) menu.

1. From the Setting menu, tap Language.

2. Tap to apply desired language.

Language

1/7

Chapter 7: Making Connections

Making Connections

You can connect your camera to:

• TV

• Computer

• Printer

Connecting the Camera to a TV

To connect your camera to a TV

1. Turn on the camera.

2. Set the TV out to match TV’s video out format. See

“Setting

TV Out” on page 56

3. Connect the USB/AV 3-in-1 cable to the USB port on the bottom of your camera.

4. Connect the other end of the cable to the TV’s AV input port.

5. The LCD screen turns black and all images and video clips are displayed on the TV.

To view photos

Video Audio

• To navigate photos, use .

Press T button to go to previous photo and W button to go to next photo.

• For slideshow, press Playback button to start/stop slideshow.

• To display/hide function keys on the TV screen, press Display button.

Chapter 7: Making Connections

Connecting the Camera a PC

You can transfer photos, videos and audio files to your PC.

1. Connect the camera to a PC using the USB cable.

2. Turn on the camera.

3. The PC detects the connection.

The camera’s internal memory and memory card display as removable drives in the file manager. No image is displayed on the LCD screen.

Note

You can also use a card reader to access the memory card contents of your camera

Connecting the Camera to a Printer

You can print your photos directly using a PictBridge compatible printer. PictBridge allows you to print images captured by your camera without connecting the camera to a PC. Print images with a PictBridge compatible printer directly.

1. Turn on your camera.

2. Connect the camera to the printer using the USB cable.

Chapter 7: Making Connections

3. The camera detects the connection and turns to USB mode. Tap Printer.

USB Mode:

Mass Storage

Printer

4. Select print settings then confirm to print photos.

Print Select

Print All

Print Index

Print all?

Yes

Setup

Setting PictBridge Menu

To ensure quality of printed photos, activate the PictBridge menu to setup print settings.

To access PictBridge menu, tap Setup in the confirmation selection before printing photos.

Quality

Layout

Paper Size

Paper Type

1/2

The table below shows the PictBridge submenu options and their available settings.

Indicates current page no. / total no. of menu page.

Submenu Available Settings

Quality

Layout

Default, Fine, Normal, Draft

Default, 2, 4, 6, 12, Full

Paper Size Default, Postcard, Letter, A4, 4”x 6”

Paper Type Default, Plain, Photo, Fast Photo

Date Stamp Default, On, Off

Filename Default, On, Off

Appendix

Appendix

About Folder and File Names

Your camera automatically creates specific directory of folders in the internal memory or memory cards to organize captured images, videos and audio files.

Folder Structure

Your camera creates three directory names:

• DICAM. All captured images, videos and audio files are stored in this folder except for files recorded using the Auction or YouTube mode.

• _AUCT. Captured images using the Auction mode are saved in this folder.

• _UTUBE. Captured videos using the YouTube mode are saved in this folder.

Folder names begin with a 3-digit number from 100 to

999 and followed by “DICAM” or “_AUCT” or

“_UTUBE”. Each folder holds up to 9999 files. If new files are saved, a new folder named in sequence will be automatically created.

File Naming

File names begin with “DSCI” and followed by a 4-digit number that increases in sequence. File numbering starts from 0001 when a new folder is created.

If the highest folder number is 999 and the highest file number exceeds 9999, the camera will display the warning message “Folder cannot be created.” When this happens, try one of the following ways:

• Reset the file number. See

“Resetting” on page 58

• Plug in a new memory card.

Warning

Do not change the folder and file names in the memory card using your PC. It may be unable to playback the data using the camera.

Troubleshooting

Troubleshooting

Problem Cause and/or Action

Camera does not turn on.

Camera turns off automatically.

LCD turns blank.

Empty battery icon is displayed on the LCD, then the camera turns off.

LCD screen displays ‘No image’.

LCD screen displays ‘Not available for this file’.

LCD screen displays ‘Memory full’.

LCD screen displays ‘File locked’

LCD screen displays ‘Card locked’.

LCD screen displays ‘Format error’.

LCD screen displays ‘Copy error’.

No image displays on the TV screen

The batteries may be exhausted. Charge or replace the batteries.

Press any button except the Power button to turn on the camera.

Press any button except the Power button to turn on the

LCD.

Batteries are exhausted, please replace or recharge.

The image file on the memory card. Image file format may not be supported.

Function is only available for specific file types. File format is not supported.

Memory card is full. Replace the memory card with a new one or delete unnecessary images.

This file is locked. Unlock the file. See “Protecting/

Unprotecting Files” on page 48.

The memory card is protected. Remove the card and slide the write-protect switch to its unlock position.

The memory card is full. Replace card or delete unnecessary files.

Incorrect TV-out type was selected. Set the correct

TV-out type to match your TV system.

Specifications

Specifications

Sensor

Lens

LCD Monitor

Focus Range

Aperture

Shutter

File Format

Resolution

Scene Mode

Sensitivity

White Balance

Exposure Control

Metering

Drive Mode

Flash

Photo Edit

Storage

TV system

10 Mega Pixels CCD, Size: 1 / 2.3"

Focal Length: f = 6.3 - 18.9 mm,

3x optical zoom, 5x digital zoom

3.0” color LTPS LCD

Normal: 0.4m - Infinity (All zoom step)

Macro: 0.1m - 0.6m (At wide only)

F = 3.1 - 5.6

Auto: 1 - 1/2000 sec.

Night: 15 - 1/2000 sec.

Fireworks: 2 sec.

Still Image: EXIF 2.2 compatible format (JPEG compression)

Video: AVI (MJPEG)

Audio: WAV

Image: 10M (3648 X 2736), 3:2 (3648 X 2432), 8M (3264

X 2448), 5M (2592 X 1944), 3M (2048 X 1536), HD 16:9

(1920 x 1080), VGA (640 X 480)

Auto, Program, Aperture Priority, Shutter Priority, Manual

Exposure, Portrait, Landscape, Sunset, Backlight, Smile

Detection, Kids, Night Scene, Fireworks, Snow, Sports,

Party, Candlelight, Night Portrait, Soft Skin, Soft Flowing

Water, Food, Building, Text, Auction, Movie, Voice Rec

Auto, 100, 200, 400, 800, 1600

Manual (5 modes in manual selection: Daylight, Cloudy,

Tungsten, Fluorescent, Custom)

-2EV to + 2EV (1/3EV steps)

Multi, Spot, Center-weighted

10 sec., 2 sec., Double, Burst, AEB

Auto, Red-eye Reduction, Slow Sync, Forced On, Forced

Off

Black & White, Sepia, Negative, Mosaic, Vivid Red, Vivid

Green, Vivid Blue

32 MB internal memory, 10 MB real size for mass storage

SD (max. size 2 GB)

SDHC card (max. size 8 GB)

NTSC, PAL

Specifications

Battery Li-ion battery

Operating Temperature 0 ºC - 40 ºC

Operating Humidity

Microphone

0% - 90%

Built-in

Speaker

Dimensions

Weight

Built-in

Normal size 9.6 X 5.7 X 1.9 cm

130 g

Thank you for your participation!

* Your assessment is very important for improving the workof artificial intelligence, which forms the content of this project

Related manuals

Download PDF
